Page 4 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS

Juki 1190 parts on page 4
Ref	Part number	Part name
1	1	FRAME & MISCELLANEOUS COVER COMPONENTS
2	2	SCREW
3	3	BRACKET
4	4	BRACKET
5	5	BRACKET
6	6	BRACKET
8	8	SCREW
9	9	COVER
10	10	COVER
11	11	COVER
12	12	SCREW
13	13	WASHER
14	14	BRACKET
15	15	BRACKET
16	16	BRACKET
17	17	BRACKET
18	18	BRACKET
19	19	BRACKET
20	20	BRACKET
21	21	BRACKET
22	22	BRACKET
23	23	SCREW
24	24	COVER
25	25	BRACKET
26	26	BRACKET
27	27	SCREW
28	28	WASHER
29	29	SCREW
30	30	BRACKET
31	31	SHAFT
32	32	BRACKET
33	33	SCREW
34	34	BRACKET
35	35	BRACKET
36	36	BRACKET
37	37	SCREW
38	38	BRACKET
39	39	BRACKET
40	40	BRACKET
41	41	BRACKET
42	42	SCREW
43	43	BRACKET
44	44	SCREW
45	45	SCREW
46	46	BRACKET
47	47	BRACKET
48	48	SCREW
49	49	SCREW
50	50	WASHER
51	51	BRACKET
52	52	BRACKET
53	53	COVER
54	54	COVER
55	55	COVER
56	56	SCREW
57	57	BRACKET
58	58	BRACKET
59	59	BRACKET
60	60	BRACKET
61	61	BRACKET
62	62	BRACKET
63	63	BRACKET
64	64	BRACKET
65	65	KNOB
66	66	WASHER
67	67	SCREW
68	68	BRACKET
69	69	BRACKET
70	70	LABEL
71	71	LABEL
72	72	BRACKET
73	73	BRACKET
74	74	COVER

Page 5

Juki 1190 parts on page 5
Part number	Part name	Qty
129-20955	FACE PLATE ASM.	1
SS-4120915-SP	SCREW 3/16-28 L=9	3
129-21003	FACE PLATE GASKET	1
TA-1250406-RO	RUBBER PLUG D=12.5 L=4	1
TA-1250406-RO	RUBBER PLUG D=12.5 L=4	2
129-51000	SPROCKET WHEEL COVER	1
129-39104	LOPER THREAD TUBE A	1
SS-6122030-SP	SCREW 3/16-28 L=20	6
129-21201	SPROCKET WHEEL AUXILIARY COVER	1
129-21409	SPROCKET WHEEL COVER PLATE	1
B1219-019-000	TIMING BELT	1
SS-7151210-SP	SCREW 15/64-28 L=12	2
SS-4090815-SP	SCREW 9/64-40 L=8	3
B1156-019-000	RUBBER CUSHION, C	1
B1157-019-000	LOOPER THREAD TUBE (C)	1
B1160-019-0AA	LOOPER COVER ASM.RIGHT	1
129-25608	FRAME THREAD GUIDE, NEEDLE	1
SS-3090610-SP	SCREW 9/64-40 L=6	4
129-22704	CHAIN CUTTER BLADE	1
SS-3060410-SP	SCREW 3/32-56 L=4	2
B1162-019-0AA	LOOPER COVER ASM.LEFT	1
B1805-019-000	FRONT BUSHING COVER	1
SS-5090610-SP	SCREW 9/64-40 L=6	1
B1806-019-000	GASKET	1
129-22357	BED COVER ASM.	1
129-22506	BED COVER GASKET	1
SS-7740740-SP	SCREW 3/8-28 L=6.5	2
RO-0681901-00	RUBBER RING	11
SS-5110810-SP	SCREW 11/64-40 L=8	11
129-32158	PUSH BUTTON GUIDE ASM.	1
129-32000	PUSH BUTTON STUD	(1)
129-32109	PUSH BUTTON GUIDE	(1)
B1622-541-000	SPRING	(1)
RO-0401002-10	O-RING	(1)
RE-0400000-KO	E-RING 4	(1)
B1806-019-000	GASKET	1
SS-7111120-SP	SCREW 11/64-40 L=10.5	3
B1104-191-0AA	BELT COVER ASM.	(1)
B1104-191-A0A	BELT COVER	(1)
B1104-191-A0B	TOP COVER	(1)
B1104-191-A0C	BELT COVER PLATE	(1)
SS-6110480-SP	SCREW 11/64-40 L=4.3	(10)
CM-5003000-01	DIRECTION LABEL	1
SS-7151210-SP	SCREW 15/64-28 L=12	4
SS-9284043-CP	SCREW 7/16-16 L=40	2
PS-0200082-KH	SPRING PIN	1
B3512-191-000	FELT	1
SS-7110710-SP	SCREW 11/64-40 L=7	2
B1165-026-000	TENSION RELEASE LEVER	1
SS-7090710-SP	SCREW 9/64-40 L=6.8	1
B1130-051-000	FRAME THREAD GUIDE, MIDDLE	1
129-20807	NEEDLE DISPLAY SHEEL	4
B1124-804-000	THREAD GUIDE, SMALL	1
129-21607	RUBBER PLUG	1
129-23207	TENSION COVER	1
SS-410815-SP	SCREW 11/64-40 L=8	2
129-34303	BRACKET	1
WP-0371016-SD	WASHER 3.7X8X1	2
SS-7090710-SP	SCREW 9/64-40 L=6.8	2
129-34402	THREAD TAKE UP GUIDE	1
WP-0320501-SE	WASHER 3.2X7X0.5	2
SS-6080410-SP	SCREW 1/8-44 L=4	2
10T-04203	OIL POT WINDOW	1
TA-0850604-RO	RUBBER PLUG	1
SS-5820540-SP	SCREW 1/2-28 L=5.0	1
B1140-019-000	GASKET	1
229-20607	ARM THREAD GUIDE B	1
SS-7110710-SP	SCREW 11/64-40 L=7	1
129-40102	LOOPER THREAD GUIDE PLATE	1
CM-3002001-01	SAFETY LABEL, 1(SMALL).	1
CM-3002001-AT	SAFETY LABEL, 3 (SMALL).	1
CM-3002000-01	ATTENTION SEAL	1
CM-3002000-C1	CAUTION LABEL	1
129-43700	BELT GUARD INSTALLING BASE	1
WP-0370316-SD	WASHER 3.7X8X0.3	3

Page 6 — 2. LOOPER THREAD GUIDE COMPONENTS

Juki 1190 parts on page 6
Ref	Part number	Part name
1	1	PLATE
2	2	BASE
3	3	PIN
4	4	SPRING
5	5	WASHER
6	6	GUIDE
7	7	GUIDE
8	8	GUIDE
9	9	GUIDE
10	10	SCREW
11	11	SCREW
12	12	NUT
13	13	SCREW
14	14	SCREW
15	15	SPRING
16	16	BRACKET
17	17	SHAFT
18	18	SCREW
19	19	PLATE
20	20	BRACKET
21	21	COVER
22	22	SCREW
23	23	COVER
24	24	BRACKET
25	25	SCREW
26	26	PIN
27	27	ROD
28	28	BRACKET
29	29	SCREW
30	30	BRACKET
31	31	BRACKET
32	32	SPRING
33	33	SCREW
34	34	SPRING
35	35	SPRING
36	36	WASHER
37	37	SCREW
38	38	SCREW
39	39	KEY
40	40	PLATE
41	41	SCREW
42	42	BRACKET
43	43	SCREW
44	44	BRACKET
45	45	BRACKET
46	46	SCREW
47	47	WASHER
48	48	SPRING
49	49	WASHER
50	50	SPRING
51	51	SCREW
52	52	COVER
53	53	COVER
54	54	COVER
55	55	SCREW
56	56	SCREW
57	57	SCREW
58	58	CAP
59	59	BRACKET
60	60	SCREW
61	61	SPRING
62	62	BRACKET
63	63	BRACKET

Page 7

Juki 1190 parts on page 7
Part number	Part name	Qty
129-38007	TENSION THREAD GUIDE A	1
129-38106	TENSION THREAD GUIDE B	1
B2310-019-000	TENSION RELEASING PIN	2
129-38205	TENSION POST	2
B3126-012-000	THREAD TENSION DISK	4
119-57305	THREAD DISC PRESSER	2
129-38304	TENSION SPRING	2
B3112-704-000	TENSION SPRING BUSHING	2
119-56703	THREAD TENSION KNOB, RED	2
SS-6110610-TP	SCREW 11/64-40 L=6	1
SS-8111160-SP	SCREW 11/64-40 L=11.0	1
NS-6110310-SP	NUT 11/64-40	1
SS-5060410-SP	SCREW 3/32-56 L=3.5	8
SS-6122510-SP	SCREW 3/16-28 L=25	1
129-39302	THREAD EYELET	1
129-37801	TENSION STUD BUSHING	1
129-37900	TENSION RELEASE SHAFT	1
SS-7090520-SP	SCREW 9/64-40 L=4.5	2
B2402-019-000	THREAD GUIDE	4
129-39203	THREAD GUIDE MOUNTING BRACKET	1
129-38908	THREAD GUIDE MOUNTING BRACKET	1
SS-4090815-SP	SCREW 9/64-40 L=8	1
129-36803	LOOPER THREAD TAKE-UP COVER	1
B2208-019-000	LOOPER THREAD TAKE-UP COVER SP	1
SS-6060220-SP	SCREW 3/32-56 L=2.0	1
PS-0500202-KP	SPRING PIN 5X20	1
129-36902	LOOPER THREAD TAKE-UP PIN	1
129-36506	STRIPPER PLATE BRACKET	1
SS-7111410-SP	SCREW 11/64-40 L=14	1
129-35706	CAM HOLDER	1
129-35607	CAM HOLDER BRACKET	1
SS-7090530-SP	SCREW 9/64-40 L=4.5	1
SS-7090850-SP	SCREW 9/64-40 L=8	1
129-35516	TENSION TAKE-UP STRIPPER PLATE	1
129-35904	LOOPER THREAD GUIDE	1
WP-0371016-SD	WASHER 3.7X8X1	3
SS-7090530-SP	SCREW 9/64-40 L=4.5	3
SS-7110840-SP	SCREW 11/64-40 L=7.8	1
129-36100	LOOPER THREAD GUIDE A	1
129-36217	FELT	1
SS-5090420-SP	SCREW 9/64-40 L=3.5	1
129-22803	COVER SPRING	1
SS-6110610-TP	SCREW 11/64-40 L=6	2
129-39559	TENSION POST ASM.	1
129-39500	TENSION BASE PLATE	(1)
129-39609	TENSION POST	(2)
129-39708	TENSION DISC	(4)
129-39807	TENSION SPRING	(2)
129-39906	TENSION DISC	(2)
NS-6110350-SP	NUT 11/64-40	(2)
SS-7110710-SP	SCREW 11/64-40 L=7	2
129-21805	LOOPER THREAD TUBE COVER	1
129-21904	LOOPER THREAD TUBE COVER HING A	1
129-22001	LOOPER THREAD TUBE COVER HING B	1
B1534-816-000	HINGE SCREW	2
SS-7110840-SP	SCREW 11/64-40 L=7.8	2
SS-7110840-SP	SCREW 11/64-40 L=7.8	2
400-38331	VIBRATION-PROOF RUBBER	2
129-39005	THREAD GUIDE BRACKET SUPPORT	1
SS-7110710-SP	SCREW 11/64-40 L=7	1
129-36001	LOOPER THREAD GUIDE	1
129-35805	LOOPER THREAD GUIDE	1
129-22100	COVER HOOK	1

Page 8 — 3. NEEDLE BAR & MAIN SHAFT COMPONENTS

Juki 1190 parts on page 8
Ref	Part number	Part name	Qty
	1	NEEDLE BAR & MAIN SHAFT COMPONENTS
	2	PIN
	3	COLLAR
	4	LINK
	5	WASHER
	6	NEEDLE BAR HOLDER
	7	SCREW
	8	SCREW
	9	BEARING
	10	BASE PLATE
	11	BASE PLATE
	12	BRACKET
	13	BRACKET
	14	BRACKET
	15	SCREW
	16	COLLAR
	17	COLLAR
	18	MAIN SHAFT
	19	SPRING
	20	NEEDLE PLATE
	21	GEAR
	22	SPRING
	23	COLLAR
	24	SPRING
	25	COVER
	26	COVER
	27	COVER
	28	COVER
	29	WASHER
	30	SCREW
	31	BRACKET
	32	SCREW
	33	SCREW
	34	COLLAR
	35	BEARING
	36	BEARING
	37	SCREW
	38	BRACKET
	39	NEEDLE BAR
	40	CLAMP
	41	PULLEY
	42	SCREW
	44	ROD
	45	SCREW
	46	BRACKET
	47	SCREW
	48	BELT
	49	JOINT
	50	JOINT
	51	SCREW
	52	COLLAR
	53	NEEDLE BAR
	54	NEEDLE BAR HOLDER
	55	SCREW
	56	NEEDLE
	57	BASE PLATE
	58	SCREW
	59	COLLAR
	60	COVER
	61	COVER
	62	SCREW

Page 10 — 4. PRESSER BAR & LOWER SHAFT COMPONENTS

Juki 1190 parts on page 10
Ref	Part number	Part name
41	41	SCREW
16	16	SPRING
15	15	BRACKET
9	9	COLLAR
49	49	WASHER
13	13	NEEDLE PLATE
14	14	SCREW
52	52	BRACKET
23	23	SPRING
22	22	HOLDER
18	18	HOLDER
21	21	SPRING
20	20	SCREW
19	19	SPRING
17	17	SPRING
24	24	SHAFT
25	25	HOLDER
29	29	SPRING
30	30	HOLDER
26	26	SCREW
28	28	SCREW
27	27	HOLDER
31	31	SCREW
33	33	SCREW
32	32	HOLDER
1	1	SPRING
2	2	BALL
3	3	SPRING
51	51	WASHER
11	11	HOLDER
5	5	HOLDER
12	12	SPRING
6	6	SCREW
8	8	SCREW
7	7	SHAFT
4	4	SHAFT
10	10	SCREW
53	53	CLIP
54	54	SCREW
47	47	SHAFT
46	46	COLLAR
42	42	SHAFT
45	45	BEARING
43	43	HOLDER
44	44	BEARING
48	48	COLLAR
50	50	PULLEY
36	36	BEARING
35	35	PULLEY
38	38	SCREW
37	37	HOLDER
39	39	SPRING
34	34	SCREW

Page 11

Juki 1190 parts on page 11
Part number	Part name	Qty
B1509-191-000	PRESSER SPRING REGULATOR	1
B1510-191-000	PRESSER GUIDE BAR	1
B1505-191-000	PRESSER SPRING	1
B1501-191-000-A	PRESSER BAR	1
229-07208	PRESSER BAR GUIDE BRACKET	1
SS-8660610-TP	SCREW 1/4-40 L=6	1
229-07109	PRESSER BAR BUSHING, LOWER	1
SS-8150310-SP	SCREW 15/64-28 L=3.4	1
129-42801	NEEDLE GUARD HOLDER	1
SS-7091110-TP	SCREW 9/64-40 L=10.5	1
129-27760	PRESSER FOOT ASM, 3/16	1
129-29600	NEEDLE GUARD	1
B1166-019-000	LOOPER COVER SPRING	(1)
SS-7110710-SP	SCREW 11/64-40 L=7	1
129-42900	LOOPER THREAD EYELET	1
SS-6090510-SP	SCREW 9/64-40 L=5	1
129-42355	NEEDLE GUARD ASM.	(1)
129-42306	REAR NEEDLE HOLDER, R	(1)
129-42603	FRONT NEEDLE HOLDER, L	(1)
SS-7090910-SP	SCREW 9/64-40 L=8.5	(1)
129-42405	REAR NEEDLE HOLDER, L	(1)
129-42405	NEEDLE GUARD, RIGHT	(1)
SS-7090520-SP	SCREW 9/64-40 L=4.5	(1)
129-40557	LOOPER, R 3/16 ASM.	1
129-40508	LOOPER, R 3/16	(1)
SS-4080620-TP	SCREW 1/8-44 L=6	(1)
129-41100	LOOPER HOLDER, 1	(1)
SS-6090910-TP	SCREW 9/64-40 L=9	(1)
129-41456	LOOPER, L3/16 ASM.	1
129-41407	LOOPER, L 3/16	(1)
SS-4080620-TP	SCREW 1/8-44 L=6	(1)
129-42009	LOOPER HOLDER, 2	(1)
SS-6090910-TP	SCREW 9/64-40 L=9	(1)
SS-7110830-SP	SCREW 11/64-40 L=7.5	1
B1802-019-000	BALL BEARING, FRONT	1
B1803-019-000	BALL BEARING, INTERMEDIATE	1
B1808-019-0AD	SLEEVE ASM.	1
SS-8110310-SP	SCREW 11/64-40 L=2.8	(2)
129-37256	LOOPER THREAD CAM ASM.	1
SS-8110310-SP	SCREW 11/64-40 L=2.8	(2)
SS-6091210-TP	SCREW 9/64-40 L=12	1
129-33610	HOOK DRIVING SHAFT	1
129-24767	BUSHING REAR ASM.	1
B1203-512-000	BUSHING, REAR	(1)
129-24718	BUSHING	(1)
SS-8150710-SP	SCREW 15/64-28 L=7	(2)
RE-1200000-KO	E-RING 12	1
SS-8150822-TP	SCREW 15/64-28 L=8	2
SS-6110610-TP	SCREW 11/64-40 L=6	1
129-33719	SPROCKET WHEEL B	1
WP-0550800-SP	WASHER 5.5X10X0.8	1
MAM-2950CCAA	HOLDER 3/16A	1
129-24809	METAL PRESSER	3
SS-6111610-SP	SCREW 11/64-40 L=16	3

Page 12 — 5. FEED MECHANISM COMPONENTS

Juki 1190 parts on page 12
Ref	Part number	Part name	Qty
	1	1
	2	2
	3	3
	4	4
	5	5
	6	6
	7	7
	8	8
	9	9
	10	10
	11	11
	12	12
	13	13
	14	14
	15	15
	16	16
	17	17
	18	18
	19	19
	20	20
	21	21
	22	22
	23	23
	24	24
	25	25
	26	26
	27	27
	28	28
	29	29
	30	30
	31	31
	32	32
	33	33
	34	34
	35	35
	36	36
	37	37
	38	38
	39	39
	40	40
	41	41
	42	42
	43	43
	44	44
	45	45
	46	46
	47	47
	48	48
	49	49
	50	50
	51	51
	52	52
	53	53
	54	54
	55	55
	56	56
	57	57
	58	58
	59	59
	60	60
	61	61
	62	62

Page 13

Juki 1190 parts on page 13
Part number	Part name	Qty
B2502-019-000	BUSHING, FRONT	1
SS-8080660-TP	SCREW 1/8-44 L=5.5	2
B2501-019-000	LOOPER ROCKER SHAFT	1
B2505-019-0A0	CONNECTION CRANK ASM.	1
SS-7111110-TP	SCREW 11/64-40 L=10.5	(1)
B2109-019-0A0	FEED ROCKER CONNECTING ROD ASM	1
SS-7090920-SP	SCREW 9/64-40 L=8.5	(4)
SS-7111110-TP	SCREW 11/64-40 L=10.5	(1)
B2116-191-00A	FEED CONNECTING LINK PIN	2
B2116-191-00B	FEED CONNECTING LINK PIN	2
SS-7080510-TP	SCREW 1/8-44 L=4.5	2
NS-6150310	NUT 15/64-28	1
B2107-019-000	FEED ROCKER SHAFT	1
SS-8150710-SP	SCREW 15/64-28 L=7	1
129-35011	FEED ROCKER	1
B2122-019-000	WASHER	1
SS-7110830-SP	SCREW 11/64-40 L=7.5	1
B2006-019-0A0	LOOPER AVOIDING ECCENTRIC CAM	1
SS-8110410-TP	SCREW 11/64-40 L=3.5	(2)
B1635-191-000	SLIDE BLOCK	1
B2004-191-0A0	LOOPER AVOIDING SHAFT ASM.	1
SS-7111110-TP	SCREW 11/64-40 L=10.5	(1)
SS-8150410-SP	SCREW 15/64-28 L=4	1
B2001-019-000	LOOPER ROCKER SHAFT	1
B2503-019-000	LOOPER ROCKER SHAFT BUSHING, R	1
SS-8120410-SP	SCREW 3/16-28 L=3.8	1
129-32307	FEED DOG	1
SS-7621040-SP	SCREW 3/16-32 L=9.5	1
B1610-019-000	SLIDE BLOCK	1
SS-8110422-TP	SCREW 11/64-40 L=4	1
RO-0611801-00	RUBBER RING	1
B1608-019-000-A	FEED BAR ECCENTRIC HINGE PIN	1
B2108-019-000	FEED ROCKER SLIDE BLOCK STOPPE	1
SS-8110510-SP	SCREW 11/64-40 L=5	2
B2105-019-000	FEED ROCKER SLIDE BLOCK	1
B2106-019-000	FEED ROCKER SLIDE BLOCK PIN	1
RO-0952001-00	RUBBER RING	1
B2101-191-000-A	LOOPER AVOID LEVER	1
129-35102	FEED ROCKER ECCENTRIC	1
SS-8660610-TP	SCREW 1/4-40 L=6	2
B1635-191-000	SLIDE BLOCK	1
B1602-019-000	FEED LIFTING FORKED CONNECTION	1
B1606-191-000	FEED ECCENTRIC SLIDE BLOCK	1
B1601-019-000	FEED BAR	1
SS-7111110-TP	SCREW 11/64-40 L=10.5	2
129-31903	BODY CAP	1
B1624-191-000	FEED ECCENTRIC BASE ASM.	1
129-31465	RATCHET PAWL	(1)
B1625-191-000	SPRING PIN 2.5X8	(1)
PS-0250081-KO	SCREW	(1)
B1626-191-000	RATCHET PAWL SPRING	(1)
B1625-191-000	RATCHET GEAR	(1)
B1623-191-000	FEED ECCENTRIC	(1)
129-31408	SCREW	(1)
129-31606	SCREW	(1)
129-31507	FEED ECCENTRIC BODY	(1)
SS-8110410-TP	SCREW 11/64-40 L=3.5	(2)
B1621-261-000-A	FEED ECCENTRIC GUIDE	(1)
129-31705	SCREW	(1)
129-31002	VERTICAL FEED CAM	(1)
SS-8110410-TP	SCREW 11/64-40 L=3.5	2
129-32208	FEED DOG 1/8	1
SS-6121840-SP	SCREW 3/16-28 L=18	1

Page 14 — 6. KNEE LIFTER COMPONENTS

Juki 1190 parts on page 14
Ref	Part number	Part name
2	2	SCREW
1	1	WASHER
3	3	BOLT
4	4	LINK
9	9	SPRING
5	5	LEVER
6	6	SCREW
7	7	BRACKET
8	8	SCREW
10	10	BRACKET
11	11	BRACKET
12	12	BOLT
13	13	BRACKET
14	14	SPRING
15	15	BRACKET
16	16	BOLT
17	17	BRACKET
18	18	BRACKET
19	19	SHAFT
20	20	SCREW
21	21	BRACKET
22	22	BRACKET
23	23	BOLT
24	24	BRACKET
25	25	BRACKET
26	26	ROD
27	27	BOLT

Page 15

Juki 1190 parts on page 15
Ref	Part number	Part name	Qty
1	B2322-019-000	PRESSER BAR LIFTING BRACKET LI	1
2	SD-0790431-SP	HINGE SCREW D= 7.94 H= 4.3	1
3	B3701-019-000	HINGE SCREW	1
4	B2319-191-00A	PRESSER BAR LIFTING LEVER	1
5	129-38502	LEVER	1
6	SD-0450211-SP	HINGE SCREW D= 4.50 H= 2.1	2
7	B2317-019-000	TENSION RELEASING SHAFT CRANK	1
8	SS-7110710-SP	SCREW 11/64-40 L=7	1
9	B2321-019-000	PRESSER BAR LIFTING LEVER SPRI	1
10	B8101-191-0A0	KNEE LIFTER ASM.	1
11	B8102-191-000	KNEE LIFTER LEVER	(1)
12	SS-9151210-TP	SCREW 15/64-28 L=11.8	(1)
13	B8101-191-000	KNEE DRIVING SHAFT MOUNTING	(1)
14	B8511-180-000	SPRING	(1)
15	129-44906	SPRING HOOK	(1)
16	SS-9182010-TE	BOLT 9/32-20 L=20	(2)
17	129-44906	SPRING HOOK	(1)
18	229-32453	BRACKET ASM.	(1)
19	B3421-012-000	KNEE PRESS ROD	(1)
20	SK-3482500-SC	WOOD SCREW D= 4.8 L=25	4
21	229-34251	KNEE PAD PLATE ASM.	1
22	229-34202	KNEE PAD PLATE	(1)
23	229-34301	KNEE PAD PLATE SUPPORT	(1)
24	229-34400	KNEE PAD PLATE RUBBER	(1)
25	229-34509	KNEE PAD PLATE COVER	(1)
26	229-34608	KNEE PAD UPRIGHT SHAFT	(1)
27	SM-9061203-SE	SCREW M6 L=12	(1)

Page 16 — 7. THREAD STAND COMPONENTS

Juki 1190 parts on page 16
Ref	Part number	Part name	Qty
	131-67556	THREAD STANDING DEVICE ASM.
	229-30556	SPOOL REST ARM ASM.
	229-30507	SPOOL REST ARM
	229-30705	THREAD GUIDE ARM JOINT
	229-31406	THREAD STANDING ROD RUBBER CAP
	229-30408	THREAD STANDING ROD, UPPER
	229-31307	THREAD STANDING ROD JOINT
	131-67903	THREAD STANDING THREAD GUIDE
	131-68000	THREAD STANDING GUIDE BASE
	131-68109	THREAD STANDING GUIDE ARM
	131-68208	THREAD STANDING GUIDE ARM BASE
	229-30309	THREAD STANDING ROD, LOWER
	229-31109	SPOOL RETAINER
	229-31000	SPOOL PIN
	229-30903	SPOOL REST CUSHION
	229-30804	SPOOL REST
	SM-6061610-SC	SCREW M6 L=16
	SM-4051405-SE	SCREW M5 L=14
	NM-6050001-SE	NUT M5
	SM-4041001-SC	SCREW M4X0.7 L=10
	NM-6040002-SE	NUT M4X0.7
	SM-4041201-SC	SCREW M4 L=12
	SM-4042001-SC	SCREW M4 X 20
	NM-6040002-SE	NUT M4X0.7
	WP-1612616-SE	WASHER 16X30X2.6
	WS-1643202-KR	SPRING WASHER
	NM-6160511-SE	NUT M16X1.5
	NM-6050001-SE	NUT M5
	WS-0510002-KN	SPRING WASHER

Page 17 — 8. OPTIONAL PARTS COMPONENTS (FOR MS-1190)

Juki 1190 parts on page 17
Ref	Part number	Part name
1	129-32653	FEED DOG ASM.
2	129-32752	FEED DOG ASM., 1/4.
3	129-32604	FEED DOG
4	129-32703	FEED DOG 1/4
5	129-64409	NEEDLE HOLDER ADJUSTING BASE
6	SS-7090510-SP	SCREW 9/64-40 L=4.6
7	SS-7091110-TP	SCREW 9/64-40 L=10.5
8	129-78805	NEEDLE HOLDER (LEFT)
9	129-78904	NEEDLE HOLDER (RIGHT)
10	129-79001	NEEDLE HOLDER (B)
11	SS-6090670-TP	SCREW 9/64-40 L=6
12	129-43007	LOOPER THREAD GUIDE.

Page 19

Juki 1190 parts on page 19
Part number	Part name	Qty
129-23561	GAUGE PARTS SET 1/8	1
129-23660	GAUGE PARTS SET 5/32	1
129-23462	GAUGE PARTS SET 3/16	1
129-23769	GAUGE PARTS SET 7/32	1
129-23868	GAUGE PARTS SET 1/4	1
129-23504	THROAT PLATE 1/8	1
129-23603	THROAT PLATE 5/32	1
129-23405	THROAT PLATE(3/16)	1
129-23702	THROAT PLATE 7/32	1
129-23801	THROAT PLATE 1/4	1
129-24007	THROAT PLATE 5/16	1
129-26051	NEEDLE CLAMP 1/8 ASM.	1
129-26150	NEEDLE CLAMP 5/32 ASM.	1
129-25954	NEEDLE CLAMP 3/16 ASM.	1
129-26259	NEEDLE CLAMP 7/32 ASM.	1
129-26358	NEEDLE CLAMP 1/4 ASM.	1
129-26457	NEEDLE CLAMP 5/16	1
129-27869	PRESSER FOOT ASM. 1/8	1
129-27968	PRESSER FOOT ASM. 5/32	1
129-27760	PRESSER FOOT ASM. 3/16	1
129-28065	PRESSER FOOT ASM. 7/32	1
129-28164	PRESSER FOOT ASM. 1/4	1
129-28354	PRESSER ASM., 5/16	1
129-32307	FEED DOG	1
129-32307	FEED DOG	1
129-32307	FEED DOG	1
129-32307	FEED DOG	1
129-32406	FEED DOG 1/4	1
129-32802	FEED DOG 5/16	1
129-41555	LOOPER,L 1/8 ASM.	1
129-41654	LOOPER,L 5/32 ASM.	1
129-41456	LOOPER,L 3/16 ASM.	1
129-41753	LOOPER,L 7/32 ASM.	1
129-41852	LOOPER,L 1/4 ASM.	1
129-41951	LOOPER (L) ASM. 5/16	1
129-40656	LOOPER,R 1/8 ASM.	1
129-40755	LOOPER,R 5/32 ASM.	1
129-40557	LOOPER,R 3/16 ASM.	1
129-40854	LOOPER,R 7/32 ASM.	1
129-40953	LOOPER,R 1/4 ASM.	1
129-41050	LOOPER (R) ASM. 5/16	1
MAM-2950AAAA	HOLDER 1/8A	1
MAM-2950BBAA	HOLDER 5/32A	1
MAM-2950CCAA	HOLDER 3/16A	1
MAM-2950DDAA	HOLDER 7/32A	1
MAM-2950EEAA	HOLDER 1/4A	1
MAM-2960AAAA	HOLDER 1/8M	1
MAM-2960BBAA	HOLDER 5/32M	1
MAM-2960CCAA	HOLDER 3/16M	1
MAM-2960DDAA	HOLDER 7/32M	1
MAM-2960EEAA	HOLDER 1/4M	1
MAM-2970AAAA	HOLDER 1/8MH	1
MAM-2970BBAA	HOLDER 5/32MH	1
MAM-2970CCAA	HOLDER 3/16MH	1
MAM-2970DDAA	HOLDER 7/32MH	1
MAM-2970EEAA	HOLDER 1/4MH	1
MAM-2970GGAA	HOLDER ASM. 5/16MH	1
129-32653	FEED DOG ASM.	1
129-32653	FEED DOG ASM.	1
129-32653	FEED DOG ASM.	1
129-32752	FEED DOG ASM., 1/4.	1
129-43007	LOOPER THREAD GUIDE.	1
129-43007	LOOPER THREAD GUIDE.	1
129-43007	LOOPER THREAD GUIDE.	1
129-43007	LOOPER THREAD GUIDE.	1
129-43007	LOOPER THREAD GUIDE.	1
129-23306	THROAT PLATE 1/8	1
129-32208	FEED DOG 1/8	1

Page 21

Juki 1190 parts on page 21
Part number	Part name	Qty
129-80561	GAUGE PARTS SET 1/8	1
129-80660	GAUGE PARTS SET 5/32	1
129-80462	GAUGE PARTS SET 3/16	1
129-80769	GAUGE PARTS SET 7/32	1
129-80868	GAUGE PARTS SET 1/4	1
129-80504	THROAT PLATE 1/8M	1
129-80603	THROAT PLATE 5/32M	1
129-80405	THROAT PLATE 3/16M	1
129-80702	THROAT PLATE (7/32M)	1
129-80801	THROAT PLATE 1/4M	1
129-26051	NEEDLE CLAMP 1/8 ASM.	1
129-26150	NEEDLE CLAMP 5/32 ASM.	1
129-25954	NEEDLE CLAMP 3/16 ASM.	1
129-26259	NEEDLE CLAMP 7/32 ASM.	1
129-26358	NEEDLE CLAMP 1/4 ASM.	1
129-82666	PRESSER FOOT ASM. 1/8M	1
129-82765	PRESSER 5/32M ASM. (EXPORT)	1
129-82567	PRESSER FOOT ASM. 3/16M	1
129-82864	PRESSER 7/32M ASM.	1
129-82963	PRESSER FOOT ASM. 1/4M	1
129-83508	FEED DOG M	1
129-83508	FEED DOG M	1
129-83508	FEED DOG M	1
129-83508	FEED DOG M	1
129-83607	FEED DOG 1/4M	1
129-41555	LOOPER, L 1/8 ASM.	1
129-41654	LOOPER, L 5/32 ASM.	1
129-41456	LOOPER, L3/16 ASM.	1
129-41753	LOOPER, L 7/32 ASM.	1
129-41852	LOOPER, L 1/4 ASM.	1
129-40656	LOOPER, R 1/8 ASM.	1
129-40755	LOOPER, R 5/32 ASM.	1
129-40557	LOOPER, R 3/16 ASM.	1
129-40854	LOOPER, R 7/32 ASM.	1
129-40953	LOOPER, R 1/4 ASM.	1
MAM-2960AAAA	HOLDER 1/8M	1
MAM-2960BBAA	HOLDER 5/32M	1
MAM-2960CCAA	HOLDER 3/16M	1
MAM-2960DDAA	HOLDER 7/32M	1
MAM-2960EEAA	HOLDER 1/4M	1
MAM-2970AAAA	HOLDER 1/8MH	1
MAM-2970BBAA	HOLDER 5/32MH	1
MAM-2970CCAA	HOLDER 3/16MH	1
MAM-2970DDAA	HOLDER 7/32MH	1
MAM-2970EEAA	HOLDER 1/4MH	1
129-80900	THROAT PLATE 1/8M	1
129-83706	FEED DOG 1/8M	1

Page 22 — 11. LIST FOR INFORMATION OF CHANGE

Juki 1190 parts on page 22
Ref	Part number	Part name
6	129-21300	129-21300
10	119-56901	119-56901
58	115-03604	115-03604
25	B3501-019-0A0	B3501-019-0A0
29	B3508-019-000	B3508-019-000
31	B3501-019-000	B3501-019-000
5	110-06004	110-06004
1	119-69458	119-69458
6	129-51000	129-51000
58	400-38331	400-38331
25	400-26875	400-26875
29	R0-0691801-00	R0-0691801-00
31	400-26874	400-26874
5	229-07208	229-07208
1	131-67556	131-67556

Page 24 — NUMERICAL INDEX OF PARTS

Juki 1190 parts on page 24
Ref	Part number	Part name	Qty
10	129-23801	129-23801	16
5	129-23868	129-23868	16
11	129-24007	129-24007	16
18	129-24502	129-24502	6
36	129-24718	129-24718	6
45	129-24718	129-24718	8
34	129-24767	129-24767	6
43	129-24767	129-24767	8
53	129-24809	129-24809	8
21	129-24916	129-24916	6
41	129-25004	129-25004	6
23	129-25202	129-25202	6
60	129-25301	129-25301	6
17	129-25608	129-25608	2
54	129-25954	129-25954	6
14	129-25954	129-25954	16
12	129-26051	129-26051	16
11	129-26051	129-26051	18
13	129-26150	129-26150	16
12	129-26150	129-26150	18
15	129-26259	129-26259	16
14	129-26259	129-26259	18
16	129-26358	129-26358	16
15	129-26358	129-26358	18
17	129-26457	129-26457	16
11	129-27760	129-27760	8
20	129-27760	129-27760	16
18	129-27869	129-27869	16
19	129-27968	129-27968	16
21	129-28065	129-28065	16
22	129-28164	129-28164	16
23	129-28354	129-28354	8
12	129-29600	129-29600	8
59	129-31002	129-31002	10
53	129-31408	129-31408	10
47	129-31465	129-31465	10
55	129-31507	129-31507	10
54	129-31606	129-31606	10
58	129-31705	129-31705	10
31	129-31903	129-31903	2
31	129-32000	129-32000	2
32	129-32109	129-32109	2
30	129-32158	129-32158	2
69	129-32208	129-32208	16
27	129-32307	129-32307	10
24	129-32307	129-32307	16
25	129-32307	129-32307	16
26	129-32307	129-32307	16
27	129-32307	129-32307	16
28	129-32406	129-32406	16
3	129-32604	129-32604	14
1	129-32653	129-32653	14
58	129-32653	129-32653	16
59	129-32653	129-32653	16
60	129-32653	129-32653	16
61	129-32653	129-32653	16
4	129-32703	129-32703	14
2	129-32752	129-32752	14
62	129-32752	129-32752	16
29	129-32802	129-32802	16
42	129-33610	129-33610	8
50	129-33719	129-33719	8
44	129-34014	129-34014	6
57	129-34105	129-34105	2
60	129-34303	129-34303	2
39	129-34402	129-34402	10
15	129-35011	129-35011	10
34	129-35102	129-35102	4
34	129-35516	129-35516	4
31	129-35607	129-35607	4
30	129-35706	129-35706	4
62	129-35805	129-35805	4
35	129-35904	129-35904	4
61	129-36001	129-36001	4
39	129-36100	129-36100	4
40	129-36217	129-36217	4
28	129-36506	129-36506	4
23	129-36803	129-36803	4
27	129-36902	129-36902	4
39	129-37256	129-37256	8
16	129-37801	129-37801	4
17	129-37900	129-37900	4
2	129-38106	129-38106	4
4	129-38205	129-38205	4
7	129-38304	129-38304	4
5	129-38502	129-38502	12
21	129-38908	129-38908	4
59	129-39005	129-39005	4
7	129-39104	129-39104	2
20	129-39203	129-39203	4
15	129-39302	129-39302	4
45	129-39500	129-39500	4
44	129-39559	129-39559	4
46	129-39609	129-39609	4
47	129-39708	129-39708	4
48	129-39807	129-39807	4
49	129-39906	129-39906	4
69	129-40102	129-40102	2
25	129-40508	129-40508	8
38	129-40557	129-40557	16
33	129-40557	129-40557	18
36	129-40556	129-40556	16
31	129-40656	129-40656	18
37	129-40755	129-40755	16
32	129-40755	129-40755	18
39	129-40854	129-40854	16
34	129-40854	129-40854	18
40	129-40953	129-40953	16
35	129-40953	129-40953	18
41	129-41050	129-41050	16
27	129-41100	129-41100	8
30	129-41407	129-41407	8
29	129-41456	129-41456	8
32	129-41456	129-41456	16
30	129-41555	129-41555	16
26	129-41555	129-41555	18
31	129-41654	129-41654	16
27	129-41654	129-41654	18
33	129-41753	129-41753	16
29	129-41753	129-41753	18
34	129-41852	129-41852	16
30	129-41852	129-41852	18
35	129-41951	129-41951	16
32	129-42009	129-42009	8
18	129-42306	129-42306	8
17	129-42355	129-42355	8
22	129-42405	129-42405	8
21	129-42504	129-42504	8
19	129-42603	129-42603	8
9	129-42801	129-42801	8
15	129-42900	129-42900	14
64	129-43007	129-43007	16
65	129-43007	129-43007	16
66	129-43007	129-43007	16
67	129-43007	129-43007	16
19	129-43106	129-43106	6
74	129-43700	129-43700	2
15	129-44906	129-44906	12
17	129-44906	129-44906	12
6	129-51000	129-51000	2
5	129-64409	129-64409	14
8	129-78805	129-78805	14
9	129-78904	129-78904	14
10	129-79001	129-79001	14
8	129-80405	129-80405	18
3	129-80462	129-80462	18
6	129-80604	129-80604	18
7	129-80605	129-80605	18
7	129-80603	129-80603	18
8	129-80702	129-80702	18
9	129-80701	129-80701	18
10	129-80801	129-80801	18
5	129-80868	129-80868	18
11	129-80900	129-80900	6
59	129-81502	129-81502	6
61	129-81601	129-81601	6
18	129-82567	129-82567	18
16	129-82666	129-82666	18
17	129-82765	129-82765	18
19	129-82864	129-82864	18
20	129-82963	129-82963	18
21	129-83508	129-83508	18
22	129-83508	129-83508	18
23	129-83508	129-83508	18
24	129-83508	129-83508	18
25	129-83607	129-83607	18
47	129-83706	129-83706	18
1	131-67556	131-67556	13
8	131-67903	131-67903	13
9	131-68000	131-68000	13
10	131-68109	131-68109	13
11	131-68208	131-68208	13
7	229-07109	229-07109	8
5	229-07208	229-07208	8
67	229-20607	229-20607	2
12	229-30309	229-30309	13
6	229-30408	229-30408	13
3	229-30507	229-30507	13
2	229-30556	229-30556	13
4	229-30705	229-30705	13
4	229-30709	229-30709	13
15	229-30804	229-30804	13
15	229-30903	229-30903	13
14	229-31000	229-31000	13
13	229-31109	229-31109	13
7	229-31307	229-31307	13
5	229-31406	229-31406	13
22	229-34202	229-34202	12
21	229-34251	229-34251	12
23	229-34301	229-34301	12
24	229-34400	229-34400	12
25	229-34509	229-34509	12
26	229-34608	229-34608	12
31	400-26874	400-26874	6
25	400-26875	400-26875	6
58	400-38331	400-38331	4

Juki 1190 — parts catalog

Page 1 — PARTS LIST

JUKI 2-Needle,Feed-off-the-arm Double Chainstitcher 高速筒型二本針二重環縫ミシン MS-1190 MS-1190M PARTS LIST 29138203 No.0935-06 jintex.in

Page 2 — HOW TO MAKE USE OF THIS PARTS LIST

HOW TO MAKE USE OF THIS PARTS LIST 1. Explanation of codes 1) "*" mark...means this part is changed from the previous parts book. As to the details of the change, refer to "List for information of change". 2) "01" ...refer to "Note" explanation at bottom of page. 2. Codes on the "Qty" column Each numeral indicates the number of parts required. "0.1" and "2.5" indicate the length (in meters) of the respective parts. 3. Parentheses mean that the corresponding part is a subpart that constructs an assembly part. 4. Dotted lines on the Figures indicate assembly parts. パーツリストご利用に際して 1. "注記" 欄の記号説明 1) "*"印...前回のパーツブックに比較して今回変更された部品を意味します。変更内容は"変更情報リスト"を参照してください。 2) "01"...ページ下の"注記"の説明を参照してください。 2. 数量欄の数字は、個数を表し、0.1、2.5等の数値は、長さ(単位メートル)を表します。 3. 数量欄の( )は、組部品を構成している子部品であることを意味します。 4. イラストページのー－－－ー枠は、組構成であることを意味します。 jintex.in

Page 3 — CONTENTS

CONTENTS 目次 1. FRAME & MISCELLANEOUS COVER COMPONENTS 頭部・外装関係 2. LOOPER THREAD GUIDE COMPONENTS カム糸案内関係 3. NEEDLE BAR & MAIN SHAFT COMPONENTS 針棒・上軸関係 4. PRESSER BAR & LOWER SHAFT COMPONENTS 押さえ棒・下軸関係 5. FEED MECHANISM COMPONENTS 送り関係 6. KNEE LIFTER COMPONENTS 膝上げ関係 7. THREAD STAND COMPONENTS 糸立装置関係 8. OPTIONAL PARTS COMPONENTS (FOR MS-1190) オプション関係 (MS-1190用) 9. TABLE OF EXCHANGING GAUGE (FOR MS-1190) 交換ゲージ一覧表 (MS-1190用) 10. TABLE OF EXCHANGING GAUGE (FOR MS-1190M) 交換ゲージ一覧表 (MS-1190M用) 11. LIST FOR INFORMATION OF CHANGE 変更情報リスト NUMERICAL INDEX OF PARTS 索引 1 3 5 7 9 11 13 14 15 17 19 20

Page 4 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS

1. FRAME & MISCELLANEOUS COVER COMPONENTS 頭部・外装関係 6 9 49 50 56 55 4 3 2 1 5 19 20 16 17 18 15 21 72-73 29 23 22 25 26 47 61 62 58 59 60 51 57 24 27 28 65 66 63 64 70-71 6 14 30 35 36 32 33 31 34 44 40 43 42 37 39 41 74 45 -1- jintex.in 8 12 13 54 10 11 53 69 48 38 42

Page 5

REF. NO NOTE PART NO. DESCRIPTION Qty. 1 129-20955 FACE PLATE ASM. 1 2 SS-4120915-SP SCREW 3/16-28 L=9 3 3 129-21003 FACE PLATE GASKET 1 4 TA-1250406-RO RUBBER PLUG D=12.5 L=4 1 5 TA-1250406-RO RUBBER PLUG D=12.5 L=4 2 6 * 129-51000 SPROCKET WHEEL COVER 1 7 129-39104 LOPER THREAD TUBE A 1 8 SS-6122030-SP SCREW 3/16-28 L=20 6 9 03 129-21201 SPROCKET WHEEL AUXILIARY COVER 1 10 129-21409 SPROCKET WHEEL COVER PLATE 1 11 B1219-019-000 TIMING BELT 1 12 SS-7151210-SP SCREW 15/64-28 L=12 2 13 SS-4090815-SP SCREW 9/64-40 L=8 3 14 B1156-019-000 RUBBER CUSHION, C 1 15 B1157-019-000 LOOPER THREAD TUBE (C) 1 16 B1160-019-0AA LOOPER COVER ASM.RIGHT 1 17 129-25608 FRAME THREAD GUIDE, NEEDLE 1 18 SS-3090610-SP SCREW 9/64-40 L=6 4 19 129-22704 CHAIN CUTTER BLADE 1 20 SS-3060410-SP SCREW 3/32-56 L=4 2 21 B1162-019-0AA LOOPER COVER ASM.LEFT 1 22 B1805-019-000 FRONT BUSHING COVER 1 23 SS-5090610-SP SCREW 9/64-40 L=6 1 24 B1806-019-000 GASKET 1 25 129-22357 BED COVER ASM. 1 26 129-22506 BED COVER GASKET 1 27 SS-7740740-SP SCREW 3/8-28 L=6.5 2 28 RO-0681901-00 RUBBER RING 11 29 SS-5110810-SP SCREW 11/64-40 L=8 11 30 129-32158 PUSH BUTTON GUIDE ASM. 1 31 129-32000 PUSH BUTTON STUD (1) 32 129-32109 PUSH BUTTON GUIDE (1) 33 B1622-541-000 SPRING (1) 34 RO-0401002-10 O-RING (1) 35 RE-0400000-KO E-RING 4 (1) 36 B1806-019-000 GASKET 1 37 SS-7111120-SP SCREW 11/64-40 L=10.5 3 38 B1104-191-0AA BELT COVER ASM. (1) 39 B1104-191-A0A BELT COVER (1) 40 B1104-191-A0B TOP COVER (1) 41 B1104-191-A0C BELT COVER PLATE (1) 42 SS-6110480-SP SCREW 11/64-40 L=4.3 (10) 43 CM-5003000-01 DIRECTION LABEL 1 44 SS-7151210-SP SCREW 15/64-28 L=12 4 45 SS-9284043-CP SCREW 7/16-16 L=40 2 46 PS-0200082-KH SPRING PIN 1 47 B3512-191-000 FELT 1 48 SS-7110710-SP SCREW 11/64-40 L=7 2 49 02 B1165-026-000 TENSION RELEASE LEVER 1 50 SS-7090710-SP SCREW 9/64-40 L=6.8 1 51 02 B1130-051-000 FRAME THREAD GUIDE, MIDDLE 1 52 129-20807 NEEDLE DISPLAY SHEEL 4 53 B1124-804-000 THREAD GUIDE, SMALL 1 54 129-21607 RUBBER PLUG 1 55 129-23207 TENSION COVER 1 56 SS-410815-SP SCREW 11/64-40 L=8 2 57 01 129-34303 BRACKET 1 58 01 WP-0371016-SD WASHER 3.7X8X1 2 59 01 SS-7090710-SP SCREW 9/64-40 L=6.8 2 60 01 129-34402 THREAD TAKE UP GUIDE 1 61 01 WP-0320501-SE WASHER 3.2X7X0.5 2 62 01 SS-6080410-SP SCREW 1/8-44 L=4 2 63 10T-04203 OIL POT WINDOW 1 64 TA-0850604-RO RUBBER PLUG 1 65 SS-5820540-SP SCREW 1/2-28 L=5.0 1 66 B1140-019-000 GASKET 1 67 229-20607 ARM THREAD GUIDE B 1 68 SS-7110710-SP SCREW 11/64-40 L=7 1 69 129-40102 LOOPER THREAD GUIDE PLATE 1 70 04 CM-3002001-01 SAFETY LABEL, 1(SMALL). 1 71 05 CM-3002001-AT SAFETY LABEL, 3 (SMALL). 1 72 06 CM-3002000-01 ATTENTION SEAL 1 73 04 CM-3002000-C1 CAUTION LABEL 1 74 129-43700 BELT GUARD INSTALLING BASE 1 75 WP-0370316-SD WASHER 3.7X8X0.3 3 NOTE (注記) 01...FOR MS-1190 MS-1190用 02...FOR MS-1190M MS-1190M用 03...FOR EXCEPT VO VOなしの時使用 04...FOR USE IN JAPAN 日本用 05...FOR JE AND USE IN JAPAN JE, 日本用を除く 06...FOR JE JE用 - 2 - jintex.in

Page 6 — 2. LOOPER THREAD GUIDE COMPONENTS

2. LOOPER THREAD GUIDE COMPONENTS カム糸案内関係 -3- jintex.in

Page 7

REF_NO NOTE PART NO. DESCRIPTION Qty. 1 129-38007 TENSION THREAD GUIDE A チョウシタライトアンナイ(A) 1 2 129-38106 TENSION THREAD GUIDE B チョウシタライトアンナイ(B) 1 3 B2310-019-000 TENSION RELEASING PIN イトエルメヒン 2 4 129-38205 TENSION POST イトチョウシボウ 2 5 B3126-012-000 THREAD TENSION DISK イトチョウシータラ 4 6 119-57305 THREAD DISC PRESSER チョウシタラオタエ 2 7 129-38304 TENSION SPRING イトチョウシハネ 2 8 B3112-704-000 TENSION SPRING BUSHING ハネプツシュ 2 9 119-56703 THREAD TENSION KNOB, RED イトチョウシタマミ (アカ) 2 10 SS-6110610-TP SCREW 11/64-40 L=6 ヒラネジ 11/64-40 L=6 1 11 SS-8111160-SP SCREW 11/64-40 L=11.0 トメネジ 11/64-40 L=11 1 12 NS-6110310-SP NUT 11/64-40 ロツカクナット 11/64-40 1 13 SS-5060410-SP SCREW 3/32-56 L=3.5 トラスネジ 3/32-56 L=3.5 8 14 SS-6122510-SP SCREW 3/16-28 L=25 ヒラネジ 3/16-28 L=25 1 15 129-39302 THREAD EYELET ウツイイトアンナイ 1 16 129-37801 TENSION STUD BUSHING イトチョウシボウダイ 1 17 129-37900 TENSION RELEASE SHAFT イトエルメシヤフト 1 18 SS-7090520-SP SCREW 9/64-40 L=4.5 マルヒラネジ 9/64-40 L=4.5 2 19 B2402-019-000 THREAD GUIDE オオキイイトアンナイ 4 20 129-39203 THREAD GUIDE MOUNTING BRACKET ウツイイトアンナイタイ 1 21 129-38908 THREAD GUIDE MOUNTING BRACKET オオキイタ 1 22 SS-4090815-SP SCREW 9/64-40 L=8 ナベネジ 9/64-40 L=8 1 23 129-36803 LOOPER THREAD TAKE-UP COVER カムカバー 1 24 B2208-019-000 LOOPER THREAD TAKE-UP COVER SP カムカバーハネ 1 25 SS-6060220-SP SCREW 3/32-56 L=2.0 ヒラネジ 3/32-56 L=2.0 1 26 PS-0500202-KP SPRING PIN 5X20 スプリングピン 5.0X20 1 27 129-36902 LOOPER THREAD TAKE-UP PIN カムカバーピン 1 28 129-36506 STRIPPER PLATE BRACKET カムイタトリツクダイ 1 29 SS-7111410-SP SCREW 11/64-40 L=14 マルヒラネジ 11/64-40 L=14 1 30 129-35706 CAM HOLDER シタイカムオサエ 1 31 129-35607 CAM HOLDER BRACKET シタイカムオサエトリツクダイ 1 32 SS-7090530-SP SCREW 9/64-40 L=4.5 マルヒラネジ 9/64-40 L=4.5 1 33 SS-7090850-SP SCREW 9/64-40 L=8 マルヒラネジ 9/64-40 L=8 1 34 129-35516 TENSION TAKE-UP STRIPPER PLATE イトチョウシカミイタ 1 35 129-35904 LOOPER THREAD GUIDE シタイカムアンナイホウ 1 36 WP-0371016-SD WASHER 3.7X8X1 ヒラガネ 3.7X8X1 3 37 SS-7090530-SP SCREW 9/64-40 L=4.5 マルヒラネジ 9/64-40 L=4.5 3 38 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 1 39 129-36100 LOOPER THREAD GUIDE A シタイカムアンナイ(A) 1 40 129-36217 FELT ユオウフェルト 1 41 SS-5090420-SP SCREW 9/64-40 L=3.5 トラスネジ 9/64-40 L=3.5 1 42 129-22803 COVER SPRING シタイカバースプリング 1 43 SS-6110610-TP SCREW 11/64-40 L=6 ヒラネジ 11/64-40 L=6 2 44 129-39559 TENSION POST ASM. シタイチョウウン(クミ) 1 45 129-39500 TENSION BASE PLATE シタイチョウウントリツケタイ (1) 46 129-39609 TENSION POST シタイチョウウンヨウセツグ (2) 47 129-39708 TENSION DISC シタイイトチョウシザラ (4) 48 129-39807 TENSION SPRING シタイチョウシハネ (2) 49 129-39906 TENSION DISC シタイチョウウンダイヤル (2) 50 NS-6110350-SP NUT 11/64-40 ロツカクナット 11/64-40 (2) 51 SS-7110710-SP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 2 52 129-21805 LOOPER THREAD TUBE COVER シタイドウカンカバー 1 53 129-21904 LOOPER THREAD TUBE COVER HING A シタイカバーヒンジ A 1 54 129-22001 LOOPER THREAD TUBE COVER HING B シタイカバーヒンジ B 1 55 B1534-816-000 HINGE SCREW ダンヌイオサエヒンジネジ 2 56 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 2 57 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 2 58 * 400-38331 VIBRATION-PROOF RUBBER ヌノダイイボウシンゴム A 2 59 129-39005 THREAD GUIDE BRACKET SUPPORT オウキイタササエイタ 1 60 SS-7110710-SP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 1 61 129-36001 LOOPER THREAD GUIDE シタイカムアンナイ(B) 1 62 129-35805 LOOPER THREAD GUIDE シタイカムアンナイ(D) 1 63 129-22100 COVER HOOK シタイカバーフック 1 - 4 - jintex.in

Page 8 — 3. NEEDLE BAR & MAIN SHAFT COMPONENTS

3. NEEDLE BAR & MAIN SHAFT COMPONENTS 針棒・上軸関係 1 2 3 6 7 5 4 9 19 38 14 15 13 12 44 18 37 34 24 23 59 35 36 22 21 41 40 39 44 45 51 50 49 52 53 54 55 56 20 58 10 11 57 25 48 30 29 32 31 28 27 26 60 61 62 - 5 - jintex.in

Page 10 — 4. PRESSER BAR & LOWER SHAFT COMPONENTS

4. PRESSER BAR & LOWER SHAFT COMPONENTS 押さえ棒・下軸関係 41 16 15 9 13 13 14 52 49 23 22 18 21 20 19 17 24 29 26 30 28 27 31 33 32 51 11 5 12 48 6 8 7 47 42 45 43 46 44 40 39 36 35 38 37 34 -7- jintex.in

Page 11

REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 B1509-191-000 PRESSER SPRING REGULATOR オサエチョーセツネジナ 1 2 B1510-191-000 PRESSER GUIDE BAR オサエアンナイボー 1 3 B1505-191-000 PRESSER SPRING オサエチョーセツバネ 1 4 B1501-191-000-A PRESSER BAR オサエボウ 1 5 229-07208 PRESSER BAR GUIDE BRACKET オサエボウウタキ 1 6 SS-8660610-TP SCREW 1/4-40 L=6 トメネジ 1/4-40 L=6 1 7 229-07109 PRESSER BAR BUSHING, LOWER オサエボウウンタクメタル 1 8 SS-8150310-SP SCREW 15/64-28 L=3.4 トメネジ 15/64-28 L=3.4 1 9 129-42801 NEEDLE GUARD HOLDER ハリウケチョウセツンク 1 10 SS-7091110-TP SCREW 9/64-40 L=10.5 マルヒラネジ 9/64-40 L=10.5 1 11 01 129-27760 PRESSER FOOT ASM, 3/16 オサエ 3/16 (クミ) ユシュウヨウ 1 12 129-29600 NEEDLE GUARD ニードルガード 1 13 B1166-019-000 LOOPER COVER SPRING マトイタバネ (1) 14 SS-7110710-SP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 1 15 129-42900 LOOPER THREAD EYELET ルーバーイトアンナイ 1 16 SS-6090510-SP SCREW 9/64-40 L=5 ヒラネジ 9/64-40 L=5 1 17 129-42355 NEEDLE GUARD ASM. ハリウケ(クミ) (1) 18 129-42306 REAR NEEDLE HOLDER, R ウシロハリウケ (R) (1) 19 129-42603 FRONT NEEDLE HOLDER, L マエハリウケ (L) (1) 20 SS-7090910-SP SCREW 9/64-40 L=8.5 マルヒラネジ 9/64-40 L=8.5 (1) 21 129-42405 REAR NEEDLE HOLDER, L ウシロハリウケ (L) (1) 22 129-42405 NEEDLE GUARD, RIGHT マエハリウケ (R) (1) 23 SS-7090520-SP SCREW 9/64-40 L=4.5 マルヒラネジ 9/64-40 L=4.5 (1) 24 01 129-40557 LOOPER, R 3/16 ASM. ルーバー-(R) 3/16(クミ) 1 25 01 129-40508 LOOPER, R 3/16 ルーバー-(R) 3/16 (1) 26 SS-4080620-TP SCREW 1/8-44 L=6 ナベネジ 1/8-44 L=6 (1) 27 129-41100 LOOPER HOLDER, 1 ルーバー・シシウデ (1) (1) 28 SS-6090910-TP SCREW 9/64-40 L=9 ヒラネジ 9/64-40 L=9 (1) 29 01 129-41456 LOOPER, L3/16 ASM. ルーバー-(L) 3/16(クミ) 1 30 01 129-41407 LOOPER, L 3/16 ルーバー-(L) 3/16 (1) 31 SS-4080620-TP SCREW 1/8-44 L=6 ナベネジ 1/8-44 L=6 (1) 32 129-42009 LOOPER HOLDER, 2 ルーバー・シシウデ (2) (1) 33 SS-6090910-TP SCREW 9/64-40 L=9 ヒラネジ 9/64-40 L=9 (1) 34 SS-7110830-SP SCREW 11/64-40 L=7.5 マルヒラネジ 11/64-40 L=7.5 1 35 B1802-019-000 BALL BEARING, FRONT シタジクマエベアリング 1 36 B1803-019-000 BALL BEARING, INTERMEDIATE シタジクナカベアリング 1 37 B1808-019-0AD SLEEVE ASM. シタジクナカメタルプシュクミ 1 38 SS-8110310-SP SCREW 11/64-40 L=2.8 トメネジ 11/64-40 L=2.8 (2) 39 129-37256 LOOPER THREAD CAM ASM. シタイトカム(クミ) 1 40 SS-8110310-SP SCREW 11/64-40 L=2.8 トメネジ 11/64-40 L=2.8 (2) 41 SS-6091210-TP SCREW 9/64-40 L=12 ヒラネジ 9/64-40 L=12 1 42 129-33610 HOOK DRIVING SHAFT シタジク 1 43 129-24767 BUSHING REAR ASM. アトメタル(クミ) 1 44 B1203-512-000 BUSHING, REAR ウワジクウシロベアリング (1) 45 129-24718 BUSHING メタルプッシュ (1) 46 SS-8150710-SP SCREW 15/64-28 L=7 トメネジ 15/64-28 L=7 (2) 47 RE-1200000-KO E-RING 12 Eカクタトメワ 12 1 48 SS-8150822-TP SCREW 15/64-28 L=8 トメネジ 15/64-28 L=8 2 49 SS-6110610-TP SCREW 11/64-40 L=6 ヒラネジ 11/64-40 L=6 1 50 129-33719 SPROCKET WHEEL B スプロツケツトハグルマ(B) 1 51 WP-0550800-SP WASHER 5.5X10X0.8 ヒラサガネ 5.5X10X0.8 1 52 01 MAM-2950CCAA HOLDER 3/16A ホルダ- 3/16A 1 53 129-24809 METAL PRESSER メタルオサエ 3 54 SS-6111610-SP SCREW 11/64-40 L=16 ヒラネジ 11/64-40 L=16 3 NOTE (注記) 01...REFER TO THE TABLE OF 15ページの交換部品一覧表を EXCHANGING ON P.15 ご参照下さい。 -8- jintex.in

Page 12 — 5. FEED MECHANISM COMPONENTS

5. FEED MECHANISM COMPONENTS 送り関係 1 3 4 5 6 7 2 11 15 12 14 13 9 10 8 16 17 27 61 28 24 26 25 62 23 21 20 18 19 29 30 31 32 33 35 44 45 42 43 41 34 38 39 40 46 59 58 51 50 48 49 52 57 55 56 53 54 47 37 36 -9- jintex.in

Page 13

REF. NO NOTE PART NO. DESCRIPTION Qty. B2502-019-000 BUSHING, FRONT 1 SS-8080660-TP SCREW 1/8-44 L=5.5 2 B2501-019-000 LOOPER ROCKER SHAFT 1 B2505-019-0A0 CONNECTION CRANK ASM. 1 SS-7111110-TP SCREW 11/64-40 L=10.5 (1) B2109-019-0A0 FEED ROCKER CONNECTING ROD ASM 1 SS-7090920-SP SCREW 9/64-40 L=8.5 (4) SS-7111110-TP SCREW 11/64-40 L=10.5 (1) B2116-191-00A FEED CONNECTING LINK PIN 2 B2116-191-00B FEED CONNECTING LINK PIN 2 SS-7080510-TP SCREW 1/8-44 L=4.5 2 NS-6150310 NUT 15/64-28 1 B2107-019-000 FEED ROCKER SHAFT 1 SS-8150710-SP SCREW 15/64-28 L=7 1 129-35011 FEED ROCKER 1 B2122-019-000 WASHER 1 SS-7110830-SP SCREW 11/64-40 L=7.5 1 B2006-019-0A0 LOOPER AVOIDING ECCENTRIC CAM 1 SS-8110410-TP SCREW 11/64-40 L=3.5 (2) B1635-191-000 SLIDE BLOCK 1 B2004-191-0A0 LOOPER AVOIDING SHAFT ASM. 1 SS-7111110-TP SCREW 11/64-40 L=10.5 (1) SS-8150410-SP SCREW 15/64-28 L=4 1 B2001-019-000 LOOPER ROCKER SHAFT 1 B2503-019-000 LOOPER ROCKER SHAFT BUSHING, R 1 SS-8120410-SP SCREW 3/16-28 L=3.8 1 129-32307 FEED DOG 1 SS-7621040-SP SCREW 3/16-32 L=9.5 1 B1610-019-000 SLIDE BLOCK 1 SS-8110422-TP SCREW 11/64-40 L=4 1 RO-0611801-00 RUBBER RING 1 B1608-019-000-A FEED BAR ECCENTRIC HINGE PIN 1 B2108-019-000 FEED ROCKER SLIDE BLOCK STOPPE 1 SS-8110510-SP SCREW 11/64-40 L=5 2 B2105-019-000 FEED ROCKER SLIDE BLOCK 1 B2106-019-000 FEED ROCKER SLIDE BLOCK PIN 1 RO-0952001-00 RUBBER RING 1 B2101-191-000-A LOOPER AVOID LEVER 1 129-35102 FEED ROCKER ECCENTRIC 1 SS-8660610-TP SCREW 1/4-40 L=6 2 B1635-191-000 SLIDE BLOCK 1 B1602-019-000 FEED LIFTING FORKED CONNECTION 1 B1606-191-000 FEED ECCENTRIC SLIDE BLOCK 1 B1601-019-000 FEED BAR 1 SS-7111110-TP SCREW 11/64-40 L=10.5 2 129-31903 BODY CAP 1 B1624-191-000 FEED ECCENTRIC BASE ASM. 1 129-31465 RATCHET PAWL (1) B1625-191-000 SPRING PIN 2.5X8 (1) PS-0250081-KO SCREW (1) B1626-191-000 RATCHET PAWL SPRING (1) B1625-191-000 RATCHET GEAR (1) B1623-191-000 FEED ECCENTRIC (1) 129-31408 SCREW (1) 129-31606 SCREW (1) 129-31507 FEED ECCENTRIC BODY (1) SS-8110410-TP SCREW 11/64-40 L=3.5 (2) B1621-261-000-A FEED ECCENTRIC GUIDE (1) 129-31705 SCREW (1) 129-31002 VERTICAL FEED CAM (1) SS-8110410-TP SCREW 11/64-40 L=3.5 2 129-32208 FEED DOG 1/8 1 SS-6121840-SP SCREW 3/16-28 L=18 1 NOTE (注記) 01...SELECTIVE PARTS 選択部品 02...REFER TO THE TABLE OF 15ページの交換部品 EXCHANGING PARTS ON P.15 一覧表をご参照下さい。 03...OPTION オプション - 10 - jintex.in

Page 14 — 6. KNEE LIFTER COMPONENTS

6. KNEE LIFTER COMPONENTS 膝上げ関係 - 11 - jintex.in

Page 15

REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 B2322-019-000 PRESSER BAR LIFTING BRACKET LI オタエアケテコ 1 2 SD-0790431-SP HINGE SCREW D= 7.94 H= 4.3 ダンネンシ D= 7.94 H= 4.3 1 3 B3701-019-000 HINGE SCREW ヒダアケテコダンネンシ 1 4 B2319-191-00A PRESSER BAR LIFTING LEVER ヒダアケテコ 1 5 129-38502 LEVER イトゥルメルレバー 1 6 SD-0450211-SP HINGE SCREW D= 4.50 H= 2.1 ダンネンシ D= 4.5 H= 2.1 2 7 B2317-019-000 TENSION RELEASING SHAFT CRANK イトゥルメルウデ 1 8 SS-7110710-SP SCREW 11/64-40 L=7 マルヒラネンシ 11/64-40 L=7 1 9 B2321-019-000 PRESSER BAR LIFTING LEVER SPRI ヒダアケテコハネ 1 10 B8101-191-0A0 KNEE LIFTER ASM. ヒダアケテコソーチトゥリツクダイクミ 1 11 B8102-191-000 KNEE LIFTER LEVER ヒダアケレバー - (1) 12 SS-9151210-TP SCREW 15/64-28 L=11.8 ロツカクボルト 15/64-28 (1) 13 B8101-191-000 KNEE DRIVING SHAFT MOUNTING ヒダアケソーチトゥリツクダイ (1) 14 B8511-180-000 SPRING ヒダアケハネ (1) 15 129-44906 SPRING HOOK ヒダアケハネ (1) 16 SS-9182010-TE BOLT 9/32-20 L=20 ロツカクボルト 9/32-20 L=20 (2) 17 129-44906 SPRING HOOK ヒダアケハネ (1) 18 229-32453 BRACKET ASM. ヒダアケテシクトリツケダイ (クミ) (1) 19 B3421-012-000 KNEE PRESS ROD ヒダアケテココヨシク (1) 20 SK-3482500-SC WOOD SCREW D= 4.8 L=25 マルモクネジ D= 4.8 L=25 4 21 229-34251 KNEE PAD PLATE ASM. ヒダアケテシイタ (クミ) 1 22 229-34202 KNEE PAD PLATE ヒダアケテシイタ (1) 23 229-34301 KNEE PAD PLATE SUPPORT ヒダアケテシササエ (1) 24 229-34400 KNEE PAD PLATE RUBBER ヒダアケテシゴム A (1) 25 229-34509 KNEE PAD PLATE COVER ヒダアケテシイタカバー - (1) 26 229-34608 KNEE PAD UPRIGHT SHAFT ヒダアケテシタテジク (1) 27 SM-9061203-SE SCREW M6 L=12 ロツカクボルト M6 L=12 (1) - 12 - jintex.in

Page 16 — 7. THREAD STAND COMPONENTS

7. THREAD STAND COMPONENTS 糸立装置関係 REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 131-67556 THREAD STANDING DEVICE ASM. イトタテツク(クミ) (1) 2 229-30556 SPOOL REST ARM ASM. イトタテウデ(クミ) (2) 3 229-30507 SPOOL REST ARM イトタテウデ (2) 4 229-30705 THREAD GUIDE ARM JOINT イトタテボウウシメカクナツ (4) 5 229-31406 THREAD STANDING ROD RUBBER CAP イトタテボウウエニヨウゴム (1) 6 229-30408 THREAD STANDING ROD, UPPER イトタテボウ(ウエ) (1) 7 229-31307 THREAD STANDING ROD JOINT イトタテボウウツギテ (1) 8 131-67903 THREAD STANDING THREAD GUIDE イトタテイトアンナイ (1) 9 131-68000 THREAD STANDING GUIDE BASE イトタテイトアンナイ(シタ)タイ (1) 10 131-68109 THREAD STANDING GUIDE ARM イトタテイトアンナイウデ (1) 11 131-68208 THREAD STANDING GUIDE ARM BASE イトタテイトアンナイウデ・タイ (1) 12 229-30309 THREAD STANDING ROD, LOWER イトタテボウ(シタ) (1) 13 229-31109 SPOOL RETAINER イトマキフレト・メ (4) 14 229-31000 SPOOL PIN イトマキウケホ・ウ (4) 15 229-30903 SPOOL REST CUSHION イトマキウケラクツション (4) 16 229-30804 SPOOL REST イトマキウケ・ラ (4) 17 SM-6061610-SC SCREW M6 L=16 ヒラコネジ M6 L=15 (4) 18 SM-4051405-SE SCREW M5 L=14 ナベコネジ M5 L=14 (2) 19 NM-6050001-SE NUT M5 ロツカクナット M5 (2) 20 SM-4041001-SC SCREW M4X0.7 L=10 ナベコネジ M4X0.7 L=10 (2) 21 NM-6040002-SE NUT M4X0.7 ロツカクナット M4X0.7 2シュ (2) 22 SM-4041201-SC SCREW M4 L=12 ナベコネジ M4 L=12 (1) 23 SM-4042001-SC SCREW M4 X 20 ナベコネジ M4X0.7 L=20 (1) 24 NM-6040002-SE NUT M4X0.7 ロツカクナット M4X0.7 2シュ (2) 25 WP-1612616-SE WASHER 16X30X2.6 ヒラサガネ (2) 26 WS-1643202-KR SPRING WASHER バネザガネ 16.4X26.6X3.2 (1) 27 NM-6160511-SE NUT M16X1.5 ロツカクナット M16X1.5 1シュ (1) 28 NM-6050001-SE NUT M5 ロツカクナット M5 (4) 29 WS-0510002-KN SPRING WASHER バネザガネ 5.1X9.2X1.3 (4) - 13 - jintex.in

Page 17 — 8. OPTIONAL PARTS COMPONENTS (FOR MS-1190)

8. OPTIONAL PARTS COMPONENTS (FOR MS-1190) オプション関係 (MS-1190用) REF. NO NOTE PART NO. DESCRIPTION Qty. 1 01 129-32653 FEED DOG ASM. オクリバ (クミ) 1 2 01 129-32752 FEED DOG ASM., 1/4. オクリバ (クミ) 1/4" 1 3 01 129-32604 FEED DOG オクリバ (1) 4 01 129-32703 FEED DOG 1/4 オクリバ 1/4 (1) 5 129-64409 NEEDLE HOLDER ADJUSTING BASE ウケチョウセツタイ (1) 6 SS-7090510-SP SCREW 9/64-40 L=4.6 マルヒラネシ 9/64-40 L=4.6 (1) 7 SS-7091110-TP SCREW 9/64-40 L=10.5 マルヒラネシ 9/64-40 L=10.5 (1) 8 129-78805 NEEDLE HOLDER (LEFT) ハリウケ (ヒダリ) (1) 9 129-78904 NEEDLE HOLDER (RIGHT) ハリウケ (ミギ) (1) 10 129-79001 NEEDLE HOLDER (B) ハリウケシタイ (B) (1) 11 SS-6090670-TP SCREW 9/64-40 L=6 ヒラネジ 9/64-40 L=6 (1) 12 129-43007 LOOPER THREAD GUIDE. ルーパーアナイ 1 NOTE (注記) 01...SELECTIVE PARTS 選択部品 - 14 - jintex.in

Page 19

REF. NO NOTE PART NO. DESCRIPTION Qty. 1 129-23561 GAUGE PARTS SET 1/8 1 2 129-23660 GAUGE PARTS SET 5/32 1 3 129-23462 GAUGE PARTS SET 3/16 1 4 129-23769 GAUGE PARTS SET 7/32 1 5 129-23868 GAUGE PARTS SET 1/4 1 6 129-23504 THROAT PLATE 1/8 1 7 129-23603 THROAT PLATE 5/32 1 8 129-23405 THROAT PLATE(3/16) 1 9 129-23702 THROAT PLATE 7/32 1 10 129-23801 THROAT PLATE 1/4 1 11 129-24007 THROAT PLATE 5/16 1 12 129-26051 NEEDLE CLAMP 1/8 ASM. 1 13 129-26150 NEEDLE CLAMP 5/32 ASM. 1 14 129-25954 NEEDLE CLAMP 3/16 ASM. 1 15 129-26259 NEEDLE CLAMP 7/32 ASM. 1 16 129-26358 NEEDLE CLAMP 1/4 ASM. 1 17 129-26457 NEEDLE CLAMP 5/16 1 18 129-27869 PRESSER FOOT ASM. 1/8 1 19 129-27968 PRESSER FOOT ASM. 5/32 1 20 129-27760 PRESSER FOOT ASM. 3/16 1 21 129-28065 PRESSER FOOT ASM. 7/32 1 22 129-28164 PRESSER FOOT ASM. 1/4 1 23 129-28354 PRESSER ASM., 5/16 1 24 129-32307 FEED DOG 1 25 129-32307 FEED DOG 1 26 129-32307 FEED DOG 1 27 129-32307 FEED DOG 1 28 129-32406 FEED DOG 1/4 1 29 129-32802 FEED DOG 5/16 1 30 129-41555 LOOPER,L 1/8 ASM. 1 31 129-41654 LOOPER,L 5/32 ASM. 1 32 129-41456 LOOPER,L 3/16 ASM. 1 33 129-41753 LOOPER,L 7/32 ASM. 1 34 129-41852 LOOPER,L 1/4 ASM. 1 35 129-41951 LOOPER (L) ASM. 5/16 1 36 129-40656 LOOPER,R 1/8 ASM. 1 37 129-40755 LOOPER,R 5/32 ASM. 1 38 129-40557 LOOPER,R 3/16 ASM. 1 39 129-40854 LOOPER,R 7/32 ASM. 1 40 129-40953 LOOPER,R 1/4 ASM. 1 41 129-41050 LOOPER (R) ASM. 5/16 1 42 MAM-2950AAAA HOLDER 1/8A 1 43 MAM-2950BBAA HOLDER 5/32A 1 44 MAM-2950CCAA HOLDER 3/16A 1 45 MAM-2950DDAA HOLDER 7/32A 1 46 MAM-2950EEAA HOLDER 1/4A 1 47 MAM-2960AAAA HOLDER 1/8M 1 48 MAM-2960BBAA HOLDER 5/32M 1 49 MAM-2960CCAA HOLDER 3/16M 1 50 MAM-2960DDAA HOLDER 7/32M 1 51 MAM-2960EEAA HOLDER 1/4M 1 52 MAM-2970AAAA HOLDER 1/8MH 1 53 MAM-2970BBAA HOLDER 5/32MH 1 54 MAM-2970CCAA HOLDER 3/16MH 1 55 MAM-2970DDAA HOLDER 7/32MH 1 56 MAM-2970EEAA HOLDER 1/4MH 1 57 MAM-2970GGAA HOLDER ASM. 5/16MH 1 58 129-32653 FEED DOG ASM. 1 59 129-32653 FEED DOG ASM. 1 60 129-32653 FEED DOG ASM. 1 61 129-32752 FEED DOG ASM., 1/4. 1 62 129-43007 LOOPER THREAD GUIDE. 1 63 129-43007 LOOPER THREAD GUIDE. 1 64 129-43007 LOOPER THREAD GUIDE. 1 65 129-43007 LOOPER THREAD GUIDE. 1 66 129-43007 LOOPER THREAD GUIDE. 1 67 129-23306 THROAT PLATE 1/8 1 68 129-32208 FEED DOG 1/8 1 - 16 - jintex.in

Page 21

REF_ NO NOTE PART NO. DESCRIPTION Qty. 1 129-80561 GAUGE PARTS SET 1/8 1 2 129-80660 GAUGE PARTS SET 5/32 1 3 129-80462 GAUGE PARTS SET 3/16 1 4 129-80769 GAUGE PARTS SET 7/32 1 5 129-80868 GAUGE PARTS SET 1/4 1 6 129-80504 THROAT PLATE 1/8M 1 7 129-80603 THROAT PLATE 5/32M 1 8 129-80405 THROAT PLATE 3/16M 1 9 129-80702 THROAT PLATE (7/32M) 1 10 129-80801 THROAT PLATE 1/4M 1 11 129-26051 NEEDLE CLAMP 1/8 ASM. 1 12 129-26150 NEEDLE CLAMP 5/32 ASM. 1 13 129-25954 NEEDLE CLAMP 3/16 ASM. 1 14 129-26259 NEEDLE CLAMP 7/32 ASM. 1 15 129-26358 NEEDLE CLAMP 1/4 ASM. 1 16 129-82666 PRESSER FOOT ASM. 1/8M 1 17 129-82765 PRESSER 5/32M ASM. (EXPORT) 1 18 129-82567 PRESSER FOOT ASM. 3/16M 1 19 129-82864 PRESSER 7/32M ASM. 1 20 129-82963 PRESSER FOOT ASM. 1/4M 1 21 129-83508 FEED DOG M 1 22 129-83508 FEED DOG M 1 23 129-83508 FEED DOG M 1 24 129-83508 FEED DOG M 1 25 129-83607 FEED DOG 1/4M 1 26 129-41555 LOOPER, L 1/8 ASM. 1 27 129-41654 LOOPER, L 5/32 ASM. 1 28 129-41456 LOOPER, L3/16 ASM. 1 29 129-41753 LOOPER, L 7/32 ASM. 1 30 129-41852 LOOPER, L 1/4 ASM. 1 31 129-40656 LOOPER, R 1/8 ASM. 1 32 129-40755 LOOPER, R 5/32 ASM. 1 33 129-40557 LOOPER, R 3/16 ASM. 1 34 129-40854 LOOPER, R 7/32 ASM. 1 35 129-40953 LOOPER, R 1/4 ASM. 1 36 MAM-2960AAAA HOLDER 1/8M 1 37 MAM-2960BBAA HOLDER 5/32M 1 38 MAM-2960CCAA HOLDER 3/16M 1 39 MAM-2960DDAA HOLDER 7/32M 1 40 MAM-2960EEAA HOLDER 1/4M 1 41 MAM-2970AAAA HOLDER 1/8MH 1 42 MAM-2970BBAA HOLDER 5/32MH 1 43 MAM-2970CCAA HOLDER 3/16MH 1 44 MAM-2970DDAA HOLDER 7/32MH 1 45 MAM-2970EEAA HOLDER 1/4MH 1 46 129-80900 THROAT PLATE 1/8M 1 47 129-83706 FEED DOG 1/8M 1 -18- jintex.in

Page 22 — 11. LIST FOR INFORMATION OF CHANGE

11. LIST FOR INFORMATION OF CHANGE 変更情報リスト As to the place changed, refer to the corresponding Rev.No. When previous parts(Obsoleted part)and new parts(Added parts)are not interchangeable with each other: In this case, even obsoleted parts(D.)can be ordered with the obsoleted part number, so select the parts with changed dates and place your orders. 変更箇所は、該当Rev.No.版をご参照ください。部品の互換性がない変更の場合は、削除された品番でも、ご注文できます。 29138203 No.0935-06 Rev.No. *A:Added parts追加部品/D:Obsoleted parts削除部品/E:Errata訂正 Rev. Page Ref. Parts No. Rev. Page Ref. Parts No. No. No. 頁 No. No. 頁 No. * D 05 2 6 129-21300 * A 06 2 6 129-51000 D 05 4 10 119-56901 D 05 4 58 115-03604 A 06 4 58 400-38331 D 05 6 25 B3501-019-0A0 A 06 6 25 400-26875 D 05 6 29 B3508-019-000 A 06 6 29 R0-0691801-00 D 05 6 31 B3501-019-000 A 06 6 31 400-26874 D 05 8 5 110-06004 A 06 8 5 229-07208 D 05 13 1 119-69458 A 06 13 1 131-67556 - 19 - jintex.in

Page 24 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS 索引 PART NO PAGE REF NO PART NO PAGE REF NO PART NO PAGE REF NO 品番頁 NO 品番頁 NO 品番頁 NO 129-23801 16 10 129-36100 4 39 129-80462 18 3 129-23868 16 5 129-36217 4 40 129-80604 18 6 129-24007 16 11 129-36506 4 28 129-80605 18 7 129-24502 6 18 129-36803 4 23 129-80603 18 7 129-24718 6 36 129-36902 4 27 129-80702 18 8 129-24767 6 45 129-37256 8 39 129-80701 18 9 129-24767 8 43 129-37801 4 16 129-80769 18 4 129-24809 8 53 129-37900 4 17 129-80801 18 10 129-24916 6 21 129-38106 4 2 129-80868 18 5 129-25004 6 41 129-38205 4 4 129-80900 6 11 129-25202 6 23 129-38304 4 7 129-81502 6 59 129-25301 6 60 129-38502 12 5 129-81601 6 61 129-25608 2 17 129-38908 4 21 129-82567 18 18 129-25954 6 54 129-39005 4 59 129-82666 18 16 129-25954 16 14 129-39104 2 7 129-82765 18 17 129-26051 16 12 129-39203 4 20 129-82864 18 19 129-26051 18 11 129-39302 4 15 129-82963 18 20 129-26150 16 13 129-39500 4 45 129-83508 18 21 129-26150 18 12 129-39559 4 44 129-83508 18 22 129-26259 16 15 129-39609 4 46 129-83508 18 23 129-26259 18 14 129-39708 4 47 129-83508 18 24 129-26358 16 16 129-39807 4 48 129-83607 18 25 129-26358 18 15 129-39906 4 49 129-83706 18 47 129-26457 16 17 129-40102 2 69 131-67556 13 1 129-27760 8 11 129-40508 8 25 131-67903 13 8 129-27760 16 20 129-40557 16 38 131-68109 13 10 129-27869 16 18 129-40557 18 33 131-68208 13 11 129-27968 16 19 129-40556 16 36 129-28065 16 21 129-40656 18 31 229-07109 8 7 129-28164 16 22 129-40755 16 37 229-07208 8 5 129-28354 8 23 129-40755 18 32 229-30309 13 12 129-29600 8 12 129-40854 16 39 229-30408 13 6 129-31002 10 59 129-40854 18 34 229-30507 13 3 129-31408 10 53 129-40953 16 40 229-30556 13 2 129-31465 10 47 129-40953 18 35 229-30705 13 4 129-31507 10 55 129-41050 16 41 229-30709 13 4 129-31606 10 54 129-41100 8 27 229-30804 13 15 129-31705 10 58 129-41407 8 30 229-30903 13 15 129-31903 2 31 129-41456 8 29 229-31000 13 14 129-32000 2 31 129-41456 16 32 229-31109 13 13 129-32109 2 32 129-41555 16 30 229-31307 13 7 129-32158 2 30 129-41555 18 26 229-31406 13 5 129-32208 16 69 129-41654 16 31 229-34202 12 22 129-32307 10 27 129-41654 18 27 229-34251 12 21 129-32307 16 24 129-41753 16 33 229-34301 12 23 129-32307 16 25 129-41753 18 29 229-34400 12 24 129-32307 16 26 129-41852 16 34 229-34509 12 25 129-32307 16 27 129-41852 18 30 229-34608 12 26 129-32406 16 28 129-41951 16 35 129-32604 14 3 129-42009 8 32 400-26874 6 31 129-32653 14 1 129-42306 8 18 400-26875 6 25 129-32653 16 58 129-42355 8 17 400-38331 4 58 129-32653 16 59 129-42405 8 22 129-32653 16 60 129-42504 8 21 129-32653 16 61 129-42603 8 19 129-32703 14 4 129-42801 8 15 129-32752 14 2 129-42900 14 12 129-32752 16 62 129-43007 16 64 129-32802 16 29 129-43007 16 65 129-33610 8 42 129-43007 16 66 129-33719 8 50 129-43007 16 67 129-34014 6 44 129-43106 6 19 129-34105 2 57 129-43700 2 74 129-34303 2 60 129-44906 12 15 129-34402 10 39 129-44906 12 17 129-35011 10 15 129-51000 2 6 129-35102 4 34 129-64409 14 5 129-35516 4 34 129-78805 14 8 129-35607 4 31 129-78904 14 9 129-35706 4 30 129-79001 14 10 129-35805 4 62 129-80405 18 8 129-35904 4 35 129-36001 4 61 - 21 - jintex.in

Page 25 — MEMO

MEMO - 22 - jintex.in

Page 26 — MEMO

MEMO - 23 - jintex.in

Page 27

jinttex.in jintex.in

Page 4 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS

Page 5

Page 6 — 2. LOOPER THREAD GUIDE COMPONENTS

Page 7

Page 8 — 3. NEEDLE BAR & MAIN SHAFT COMPONENTS

Page 10 — 4. PRESSER BAR & LOWER SHAFT COMPONENTS

Page 11

Page 12 — 5. FEED MECHANISM COMPONENTS

Page 13

Page 14 — 6. KNEE LIFTER COMPONENTS

Page 15

Page 16 — 7. THREAD STAND COMPONENTS

Page 17 — 8. OPTIONAL PARTS COMPONENTS (FOR MS-1190)

Page 19

Page 21

Page 22 — 11. LIST FOR INFORMATION OF CHANGE

Page 24 — NUMERICAL INDEX OF PARTS

Part Books

Search

Ref	Part number	Part name	Qty
	1	1
	2	2
	3	3
	4	4
	5	5
	6	6
	7	7
	8	8
	9	9
	10	10
	11	11
	12	12
	13	13
	14	14
	15	15
	16	16
	17	17
	18	18
	19	19
	20	20
	21	21
	22	22
	23	23
	24	24
	25	25
	26	26
	27	27
	28	28
	29	29
	30	30
	31	31
	32	32
	33	33
	34	34
	35	35
	36	36
	37	37
	38	38
	39	39
	40	40
	41	41
	42	42
	43	43
	44	44
	45	45
	46	46
	47	47
	48	48
	49	49
	50	50
	51	51
	52	52
	53	53
	54	54
	55	55
	56	56
	57	57
	58	58
	59	59
	60	60
	61	61
	62	62

Ref	Part number	Part name	Qty
	1	1
	2	2
	3	3
	4	4
	5	5
	6	6
	7	7
	8	8
	9	9
	10	10
	11	11
	12	12
	13	13
	14	14
	15	15
	16	16
	17	17
	18	18
	19	19
	20	20
	21	21
	22	22
	23	23
	24	24
	25	25
	26	26
	27	27
	28	28
	29	29
	30	30
	31	31
	32	32
	33	33
	34	34
	35	35
	36	36
	37	37
	38	38
	39	39
	40	40
	41	41
	42	42
	43	43
	44	44
	45	45
	46	46
	47	47
	48	48
	49	49
	50	50
	51	51
	52	52
	53	53
	54	54
	55	55
	56	56
	57	57
	58	58
	59	59
	60	60
	61	61
	62	62

Ref	Part number	Part name	Qty
	1	1
	2	2
	3	3
	4	4
	5	5
	6	6
	7	7
	8	8
	9	9
	10	10
	11	11
	12	12
	13	13
	14	14
	15	15
	16	16
	17	17
	18	18
	19	19
	20	20
	21	21
	22	22
	23	23
	24	24
	25	25
	26	26
	27	27
	28	28
	29	29
	30	30
	31	31
	32	32
	33	33
	34	34
	35	35
	36	36
	37	37
	38	38
	39	39
	40	40
	41	41
	42	42
	43	43
	44	44
	45	45
	46	46
	47	47
	48	48
	49	49
	50	50
	51	51
	52	52
	53	53
	54	54
	55	55
	56	56
	57	57
	58	58
	59	59
	60	60
	61	61
	62	62
