Juki 7700 Parts Book (PDF)
Text index — Juki 7700
Page 5 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 134-38007 | COVERING_GUARD_R | 1 |
| 2 | 134-38106 | COVERING_GUARD_L | 1 |
| 3 | SM-8040412-TP | SET SCREW M4 L=4 | 3 |
| 4 | TA-2050406-RO | RUBBER PLUG | 1 |
| 5 | TA-1250406-RO | RUBBER PLUG D=12.5 L=4 | 2 |
| 6 | TA-1701002-RO | RUBBER PLUG | 1 |
| 7 | 229-01805 | GROUND MARK | 1 |
| 8 | CM-3002000-01 | ATTENTION SEAL | 2 |
| 9 | 133-00959 | ASSY_HEAD_COVER | 1 |
| 10 | 133-00900 | HEAD COVER | (1) |
| 11 | 229-02506 | FACE PLATE | (1) |
| 12 | TA-1050504-RO | RUBBER PLUG | (1) |
| 13 | SM-4041055-SP | SCREW | 4 |
| 14 | 133-01007 | GASKET H | 1 |
| 15 | 133-01304 | NEEDLE BAR GUARD | 1 |
| 16 | SM-4040655-SP | SCREW M4 L=6 | 2 |
| 17 | 133-01759 | PROTECTION_SHIELD_ASSY | 1 |
| 18 | 133-01502 | BRACKET HOLDER | (1) |
| 19 | 133-01601 | BRACKET | (1) |
| 20 | 133-01700 | PROTECTION SHIELD | (1) |
| 21 | WZ-0641510-KP | WAVED WASHER 6.4X11X0.3 | (1) |
| 22 | SM-4030455-SN | SCREW | (2) |
| 23 | NM-6040001-SP | NUT M4X0.7 | (1) |
| 24 | SD-0640246-SP | HINGE SCREW D=6.35 H=2.4 | (1) |
| 25 | SM-6060800-SP | SCREW M6 L=8 | 1 |
| 26 | 133-01403 | THREAD COVER | 1 |
| 27 | SM-4040655-SP | SCREW M4 L=6 | 1 |
| 28 | 133-02401 | LMS_FAN_COVER | 1 |
| 29 | SM-4040655-SP | SCREW M4 L=6 | 2 |
| 30 | 133-01809 | SUPPORT STUD | 4 |
| 31 | 134-00957 | SWING_DOWN_COVER_ASSY | 1 |
| 32 | 134-00908 | SWING DOWN COVER | (1) |
| 33 | 133-02302 | RUBBER BUMPER | (1) |
| 34 | 134-01203 | HINGE | (1) |
| 35 | SM-8040360-TP | SCREW | (1) |
| 36 | 134-01005 | CLOTH PLATE FRONT | (1) |
| 37 | SM-1040800-SP | SCREW | (3) |
| 38 | 134-02706 | PIN FOR COVER | (1) |
| 39 | SM-8040360-TP | SCREW | (1) |
| 40 | 134-03506 | PIN_FOR_S_D_COVER | (1) |
| 41 | RE-0300000-K0 | E-RING 3 | (1) |
| 42 | WP-0550800-SP | WASHER 5.5X10X0.8 | (1) |
| 43 | 133-02708 | RUBBER_WASHER | (2) |
| 44 | 134-03605 | RUBBER_PLATE | (1) |
| 45 | SM-6051400-SP | SCREW | 2 |
| 46 | 134-02904 | BRACKET N | 1 |
| 47 | 134-01104 | BRACKET | 1 |
| 48 | SM-6030600-SP | SCREW M3X0.5 L=6 | 2 |
| 49 | SL-4040805-SC | SCREW | 2 |
| 50 | SM-4041055-SP | SCREW | 1 |
| 51 | NM-6040001-SP | NUT M4X0.7 | 1 |
| 52 | 133-02302 | RUBBER BUMPER | 1 |
| 53 | TA-1900502-RO | RUBBER PLUG | 1 |
| 54 | 133-02658 | DRIVING BELT COVER ASSY | 1 |
| 55 | 133-02609 | DRIVING BELT COVER | (1) |
| 56 | CM-3002000-A1 | CAUTION LABEL(16) | (1) |
| 57 | SM-4051255-SP | SCREW.,M5 L=12. | 2 |
| 58 | SM-4050855-SP | SCREW | 1 |
Page 7 — 2. FRAME & MISCELLANEOUS COVER COMPONENTS (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | TA-0850604-RO | RUBBER PLUG | 3 |
| 2 | 107-53309 | WINDOW PLATE RUBBER PLUG | 1 |
| 3 | TA-2351004-RO | RUBBER PLUG | 1 |
| 4 | SM-8060612-TP | SCREW M6 L=6 | 2 |
| 5 | CM-3002001-B1 | SAFETY LABEL 12 | 1 |
| 6 | 133-00702 | TOP COVER | 1 |
| 7 | SM-4041055-SP | SCREW | 8 |
| 8 | 107-53309 | WINDOW PLATE RUBBER PLUG | 1 |
| 9 | RO-1952401-00 | RUBBER RING | 1 |
| 10 | 229-24708 | OIL SIGHT WINDOW | 1 |
| 11 | 133-00801 | GASKET T | 1 |
| 12 | 133-01106 | PULLER DRIVE COVER | 1 |
| 13 | SM-6060800-SP | SCREW M6 L=8 | 6 |
| 14 | 133-01205 | GASKET P | 1 |
| 15 | 134-01757 | SIDE_COVER_ASSY | 1 |
| 16 | 134-01500 | CYLINDER COVER | (1) |
| 17 | 134-01807 | CYLINDER COVER PLATE | (1) |
| 18 | SM-4040655-SP | SCREW M4 L=6 | (2) |
| 19 | 134-01708 | SIDE COVER | (1) |
| 20 | 134-01906 | LATCH SPRING 2 | (1) |
| 21 | SM-4040655-SP | SCREW M4 L=6 | (1) |
| 22 | PH-0300252-CO | PARALLEL PIN | (2) |
| 23 | SM-8040360-TP | SCREW | (2) |
| 24 | RO-0371801-00 | RUBBER RING | (2) |
| 25 | 134-01609 | GASKET | 1 |
| 26 | SM-4041055-SP | SCREW | 4 |
| 27 | 134-00650 | ASSY_TP_SUPPORT | 1 |
| 28 | 134-00601 | THROAT PLATE SUPPORT | (1) |
| 29 | 133-01908 | DOWEL PIN | (1) |
| 30 | 133-02500 | DOWEL PIN 2 | (1) |
| 31 | 236-30007 | TUBE | (0.01) |
| 32 | 134-03407 | SLIDE_COVER_SUPPORT | (1) |
| 33 | SM-4030655-SP | SCREW | (2) |
| 34 | 134-03605 | RUBBER_PLATE | (1) |
| 35 | 133-02203 | SCREW | 2 |
| 36 | SM-4040855-SP | SCREW | 3 |
| 37 | 134-00700 | BED TOP COVER | 1 |
| 38 | 134-00809 | GASKET B | 1 |
| 39 | SM-6040870-SP | SCREW | 1 |
| 40 | 134-02300 | NIPPER PLATE | 1 |
| 41 | 134-02805 | SPRING | 1 |
| 42 | 134-02409 | NIPPER SPRING PLATE | 2 |
| 43 | 133-26202 | SHOULDER SCREW | 1 |
| 44 | 134-02003 | LATCH SPRING | 1 |
| 45 | SM-1040860-SP | SCREW | 9 |
| 46 | 134-01351 | CLOTH_PLATE_ASSY | 1 |
| 47 | 134-01302 | CLOTH PLATE REAR | (1) |
| 48 | 134-02102 | THD GUIDE | (1) |
| 49 | PS-0150042-KO | SPRING PIN 1.5X 4 | (1) |
| 50 | 134-01401 | SLIDE COVER | 1 |
| 51 | SM-4041055-SP | SCREW | 3 |
| 52 | 134-02201 | LOOPER THD GUIDE | 1 |
| 53 | SM-4040655-SP | SCREW M4 L=6 | 1 |
Page 9 — 3. MAIN SHAFT COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 133-07004 | UPPER MAINSHAFT RIGHT | 1 |
| 2 | 134-06608 | UPPER_PULLEY | 1 |
| 3 | SM-8061212-TP | SCREW M6X12 | 2 |
| 4 | 133-07251 | BEARING ASSY A | 1 |
| 5 | SM-8060842-TP | SCREW M6 L=8 | (1) |
| 6 | SM-8060612-TP | SCREW M6 L=6 | (1) |
| 7 | 133-07301 | UMS_SPROCKET | 1 |
| 8 | SM-8060812-TP | SCREW M6 L=8 | 4 |
| 9 | 133-07459 | BEARING ASSY B | 1 |
| 10 | SM-8060612-TP | SCREW M6 L=6 | (2) |
| 133-07657 | UMS_LEFT_ROD_ASSY | 1 | |
| 133-24108 | SCREW | (4) | |
| SM-6061402-TP | SCREW M6 L=14 | (1) | |
| 133-24009 | ROD | (1) | |
| 133-09208 | SCREW FOR COUNTERWEIGHT | 1 | |
| SM-8080812-TP | SCREW M8X8 | 1 | |
| SM-6061200-SP | SCREW | 1 | |
| 134-08307 | BALANCE WEIGHT UMS | 2 | |
| 134-06905 | TIMING BELT | 1 | |
| 134-07101 | LOWER MAINSHAFT RIGHT | 1 | |
| 134-06707 | LOWER PULLEY | 1 | |
| 133-09158 | BEARING ASSY_F | (1) | |
| 133-09000 | LMS_FAN | (1) | |
| PS-0400082-KP | SPRING PIN | (1) | |
| 133-08309 | LMS SPROCKET | 1 | |
| 134-07457 | BEARING ASSY E | 1 | |
| 134-08406 | BALANCE_WEIGHT_LMS_1 | (1) | |
| SM-8050512-TP | SCREW M5 L=5 | 2 | |
| 134-08505 | BALANCE_WEIGHT_LMS_2 | 2 | |
| 134-07507 | JOINT GEAR | 1 | |
| SB-1150023-00 | - BEARING | 2 | |
| 134-07259 | CRANK JOINT ROD ASSY | 1 | |
| 133-37100 | GUIDE LOOPER ROD | (1) | |
| WS-0510002-KP | SPRING WASHER 5.1X9.2X1.3 | (1) | |
| 134-07200 | CRANK JOINT | (1) | |
| 134-24205 | ROD | (1) | |
| 134-24106 | CRANK | (1) | |
| 134-07705 | BUSHING LMS MIDDLE | 1 | |
| 134-08703 | OIL SEAL | 1 | |
| 134-07903 | OIL SEAL | 1 | |
| 134-08604 | FELT LMS LEFT BUSH | 1 | |
| PS-0300122-KH | SPRING PIN 3X12 | 1 | |
| 134-06806 | COVER LMS M BUSH | 1 | |
| 133-09406 | HOUSING C | 1 | |
| SM-8550952-TP | SCREW | 1 | |
| 134-07606 | LOWER MAINSHAFT LEFT | 1 | |
| SM-8050412-TP | SCREW M5 L=4 | 1 | |
| RC-4881514-KP | C-RING | 1 |
Page 11 — 4. NEEDLE BAR & PRESSER COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 133-11253 | ASSY_NEEDLE_MECH | 1 |
| 2 | 133-11204 | CONNECTING ROD | (1) |
| 3 | 133-11006 | ECCENTRIC PIN | (1) |
| 4 | 133-11303 | NEEDLE BAR CLAMP | (1) |
| 5 | SB-3080011-0A | BEARING | (1) |
| 6 | SB-3080011-0B | BEARING | (1) |
| 7 | SB-3080011-0C | BEARING | (1) |
| 8 | SB-3080011-0D | BEARING | (1) |
| 9 | SM-6041000-SP | SCREW M4 L=10 | (1) |
| 10 | 133-12103 | THRUST_WASHER | 1 |
| 11 | 133-12202 | THRUST_WASHER | 1 |
| 12 | 133-12301 | THRUST_WASHER | 1 |
| 13 | 133-11600 | NEEDLE BAR GUIDE | 1 |
| 14 | 133-11501 | SLIDE BLOCK | 1 |
| 15 | SM-6051000-SP | SCREW | 3 |
| 16 | 133-26806 | NEEDLE BAR EYELET | 1 |
| 17 | SM-4030655-SP | SCREW | 1 |
| 18 | 133-11956 | ASSY_BUSHING_NB | 1 |
| 19 | 133-11907 | BUSHING NB LOWER | (1) |
| 20 | 133-11808 | BUSHING NB UPPER | (1) |
| 21 | 133-11451 | NEEDLE BAR ASSY | (1) |
| 22 | WP-0702026-SP | WASHER 7X15X2 | 1 |
| 23 | WZ-1052010-KP | WAVED WASHER | 1 |
| 24 | 133-13051 | ADJ SCREW P B ASSY | 1 |
| 25 | 133-13101 | LOCKING NUT | 1 |
| 26 | 133-13309 | SPRING PRESSER BAR A | 1 |
| 27 | 133-13408 | SPRING PRESSER BAR B | 1 |
| 28 | 133-13507 | PRESSER BAR | 1 |
| 29 | 133-13705 | BUSHING PRESSER BAR | 1 |
| 30 | 133-15908 | OIL SEAL | 1 |
| 31 | 133-16005 | FINGER GUARD | 1 |
| 32 | SM-4030455-SP | SCREW | 1 |
| 33 | 133-13606 | COLLAR | 1 |
| 34 | 133-16302 | THREAD_TRIMMER | 1 |
| 35 | SM-8040410-TP | SCREW | 2 |
| 36 | SM-6030500-SN | SCREW M3 L=5 | 1 |
| 37 | 133-13804 | GUIDE PLATE | 1 |
| 38 | SM-6041000-SP | SCREW M4 L=10 | 2 |
| 39 | 133-13952 | P_B_BRACKET_ASSY | 1 |
| 40 | 133-13903 | PRESSER BAR BRACKET | (1) |
| 41 | 133-16203 | P_B_BRACKET_PIN | (1) |
| 42 | 133-33208 | WASHER | (1) |
| 43 | SM-6041200-SP | SCREW M4 L=12 | (1) |
| 44 | 133-14109 | LINK | 1 |
| 45 | SD-0700206-TP | SHOULDER SCREW | 2 |
| 46 | 133-14356 | ASSY LIFTER SHAFT | 1 |
| 47 | 133-15205 | SPRING LIFTER LEVER | 1 |
| 48 | SM-6061002-TP | SCREW M6 L=10 | 1 |
| 49 | 133-15007 | LIFTER LEVER | 1 |
| 50 | 235-37202 | HOOK SHAFT OIL SEAL | 1 |
| 51 | 133-14406 | BUSHING LIFTER FRONT | 1 |
| 52 | CS-0800881-TP | THRUST COLLAR | 1 |
| 53 | SM-8050412-TP | SCREW M5 L=4 | 2 |
| 54 | 133-14802 | SPRING PF LIFT | 1 |
| 55 | 133-14752 | LIFTER_SHAFT_LEVER_ASSY | 1 |
| 56 | 133-14703 | LIFTER SHAFT LEVER | (1) |
| 57 | SM-6051202-TP | SCREW M5X0.8 L=12 | (1) |
| 58 | 133-14505 | BUSHING LIFTER REAR | 1 |
| 59 | 133-14901 | LIFTER HOOK | 1 |
| 60 | PS-0500142-KP | SPRING PIN | 1 |
| 61 | 133-15106 | LIFTER LEVER HOLDER | 1 |
| 62 | 133-15353 | TENS_RELEASE_LEVER_ASSY | 1 |
| 63 | 133-15304 | TENSION RELEASE LEVER | (1) |
| 64 | SM-6041202-TP | SCREW M4X0.7 L=12 | (1) |
| 65 | SD-0700586-TP | SHOULDER SCREW | 1 |
| 66 | 133-15551 | STOPPER_ASSY | 1 |
| 67 | 133-15502 | LIFTER LEVER STOPPER | (1) |
| 68 | SM-9062550-TP | SCREW | (1) |
| 69 | NM-6060001-CP | NUT M6 | (1) |
| 70 | SM-6061202-TP | SCREW M6 L=12 | 2 |
| 71 | 133-15650 | MINUTE_LIFTING_ASSY | 1 |
| 72 | 133-15601 | BRACKET | (1) |
| 73 | 133-15700 | SCREW | (1) |
| 74 | 133-15809 | SLIDER | (1) |
| 75 | WP-0460556-SD | WASHER 4.6X7.5X0.5 | (1) |
| 76 | 131-23302 | ADJUSTING SPRING | (1) |
| 77 | RE-0300000-KO | E-RING 3 | (1) |
| 78 | SM-6060800-SP | SCREW M6 L=8 | 2 |
Page 13 — 5. FEED DRIVE COMPONENTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 134-10006 | FEED ECCENTRIC | 1 |
| 2 | SM-8060612-TP | SCREW M6 L=6 | 2 |
| 3 | B1426-180-A00 | NEEDLE BEARING (A) | 1 |
| 4 | B1426-180-B00 | NEEDLE BEARING (B) | 1 |
| 5 | B1426-180-C00 | NEEDLE BEARING (C) | 1 |
| 6 | B1426-180-D00 | NEEDLE BEARING (D) | 1 |
| 7 | RC-2251213-KP | C-RING | 1 |
| 8 | 134-10105 | CRANK ROD | 1 |
| 9 | 133-23308 | FEED ADJ LINK PIN A | 1 |
| 10 | 133-23407 | FEED ADJ LINK PIN B | 1 |
| 11 | 133-23506 | FEED ADJ LINK PIN C | 1 |
| 12 | CQ-3030000-00 | OIL WICK | 0.07 |
| 13 | 134-10204 | MAIN ADJ LINK | 1 |
| 14 | SM-8050512-TP | SCREW | 2 |
| 15 | 133-18704 | MAIN FEED CRANK PIN A | 1 |
| 16 | 133-18803 | MAIN FEED CRANK PIN B | 1 |
| 17 | 133-18902 | MAIN FEED CRANK PIN C | 1 |
| 18 | NM-6040001-SP | NUT M4X0.7 | 1 |
| 19 | CQ-3030000-00 | OIL WICK | 0.04 |
| 20 | SM-8050512-TP | SCREW | 1 |
| 21 | 133-17300 | ADJUST LINK | 1 |
| 22 | 134-10600 | FEED ADJ LINK PIN A | 1 |
| 23 | 134-10709 | FEED ADJ LINK PIN B | 1 |
| 24 | 134-10808 | FEED ADJ LINK PIN C | 1 |
| 25 | CQ-3030000-00 | OIL WICK | 0.07 |
| 26 | 134-15708 | FEED ADJ BLOCK | 1 |
| 27 | 134-11004 | BUSHING MAIN FEED ADJ | 1 |
| 28 | 134-15807 | BUSHING_MAIN_FEED_ADJ | 1 |
| 29 | 134-15906 | SHAFT_FEED_ADJ_BLOCK | 1 |
| 30 | B2546-232-000 | PRESSURE SPRING | 1 |
| 31 | SM-8050512-TP | SCREW | 4 |
| 32 | SM-6051400-SP | SCREW | 1 |
| 33 | NM-6050001-SP | NUT M5 | 1 |
| 34 | 134-11509 | MAIN_FEED_CRANK | 1 |
| 35 | SM-8060552-TP | SCREW M6 L=5 | 2 |
| 36 | 134-14305 | FEED LIFT ROD | 1 |
| 37 | 121-16604 | NEEDLE BEARING | 1 |
| 38 | 121-16703 | NEEDLE BEARING B | 1 |
| 39 | 121-16802 | NEEDLE BEARING.,C. | 1 |
| 40 | 121-16901 | NEEDLE BEARING.,D. | 1 |
| 41 | 121-17008 | NEEDLE BEARING.,E. | 1 |
| 42 | B1248-280-000 | STOP RING | 1 |
| 43 | 134-14404 | FEED LIFT LEVER | 1 |
| 44 | RE-0500000-K0 | E-RING | 1 |
| 45 | SM-8060552-TP | SCREW M6 L=5 | 2 |
| 46 | 134-11608 | MAIN FEED SHAFT | 1 |
| 47 | TA-0500601-M0 | PLUG D=5X5.4 L=6 | 1 |
| 48 | CQ-3000000-01 | OIL WICK | 1 |
| 49 | CQ-2020000-00 | OIL WICK | 0.6 |
| 50 | 134-12002 | MAIN FEED LINK PIN A | 1 |
| 51 | 134-12101 | MAIN FEED LINK PIN B | 1 |
| 52 | 134-12200 | MAIN FEED LINK PIN C | 1 |
| 53 | 134-11905 | MAIN FEED LINK | 1 |
| 54 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
| 55 | SD-0801636-TH | SHOULDER SCREW | 1 |
| 56 | 134-14503 | FEED LIFT SHAFT | 1 |
| 57 | TA-0500601-M0 | PLUG D=5X5.4 L=6 | 1 |
| 58 | CQ-3000000-01 | OIL WICK | 0.67 |
| 59 | 134-11707 | BUSHING FEED MECH | 2 |
| 60 | 134-09206 | BUSHING_FEED_MECH | 1 |
| 61 | 134-09107 | WASHER | 2 |
| 62 | E3025-721-000 | OIL SEAL | 2 |
| 63 | 134-15500 | BUSHING_FEED_MECH | 2 |
| 64 | 134-11806 | COLLAR | 4 |
| 65 | SM-8060412-TP | SCREW | 4 |
| 66 | 134-08802 | BUSHING_FEED_MECH | 1 |
| 67 | 133-18001 | KNOB FEED ADJUST | 1 |
| 68 | SM-8040602-TP | SCREW M4X0.7 L=6 | 1 |
| 69 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
| 70 | B3215-470-000 | PIN | 1 |
| 71 | 134-11400 | BUSHING FEED ADJ | 1 |
| 72 | 134-11301 | SHAFT FEED ADJ | 1 |
| 73 | R0-0552001-00 | RUBBER RING | 1 |
| 74 | RE-0500000-K0 | E-RING | 2 |
| 75 | 133-18308 | STOPPER FEED ADJUST | 1 |
| 76 | 134-11152 | INDICATOR ASSY | 1 |
| 77 | R0-0681901-00 | RUBBER RING | 1 |
| 78 | 134-13950 | FEED_BAR_ASSY | 1 |
| 79 | 134-13901 | MAIN FEED BAR | (1) |
| 80 | 134-14008 | DIFF FEED BAR | (1) |
| 81 | 134-13703 | SLIDE BLOCK 1 | (1) |
| 82 | 134-13802 | SLIDE BLOCK 2 | (1) |
| 83 | SM-6041000-SP | SCREW M4 L=10 | 2 |
| 84 | 134-14107 | FEED BAR GUIDE 1 | 1 |
| 85 | SM-8050812-TP | SCREW M5X8 | 1 |
| 86 | 134-13307 | DIFF_FEED_CRANK | 1 |
| 87 | SM-8060552-TP | SCREW M6 L=5 | 2 |
| 88 | SM-8050512-TP | SCREW | 1 |
| 89 | SM-6042000-SP | SCREW | 1 |
| B1426-180-000 | C-RING | 1 | |
| 133-18503 | MAIN FEED CRANK PIN B | 1 | |
| TA-0500601-K0 | PLUG D=5X5.4 L=6 | 1 | |
| 134-13902 | MAIN FEED BAR | (1) |
Page 15 — 6. FEED DRIVE COMPONENTS (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | RE-0300000-KO | E-RING 3 | 1 |
| 2 | PS-0500202-KP | SPRING PIN 5X20 | 1 |
| 3 | 134-13406 | DIFF FEED SHAFT | 1 |
| 4 | TA-0500601-MO | PLUG D=5X5.4 L=6 | 1 |
| 5 | CQ-3000000-01 | OIL WICK | 1 |
| 6 | 134-13604 | DIFF FEED LINK | 1 |
| 7 | SD-0801866-TH | SHOULDER SCREW | 1 |
| 8 | SD-0800626-TH | SHOULDER SCREW | 1 |
| 9 | 134-11707 | BUSHING FEED MECH | 1 |
| 10 | 134-09206 | BUSHING_FEED_MECH | 1 |
| 11 | 134-09107 | WASHER | 1 |
| 12 | E3025-721-000 | OIL SEAL | 1 |
| 13 | 134-15500 | BUSHING_FEED_MECH | 1 |
| 14 | 134-11806 | COLLAR | 2 |
| 15 | SM-8060412-TP | SCREW | 2 |
| 16 | 134-11202 | PLATE MAIN FEED ADJ | 1 |
| 17 | SM-4051255-SP | SCREW.,M5 L=12. | 2 |
| 18 | SM-4040655-SN | SCREW M4X0.7 L=6 | 1 |
| 19 | NM-6040000-SN | NUT M4 | 1 |
| 20 | 134-14206 | FEED BAR GUIDE 2 | 1 |
| 21 | SM-6040800-SP | SCREW | 2 |
| 22 | WP-0450846-SP | WASHER | 2 |
| 23 | 134-09909 | DIFF_FEED_CRANK_PIN | 1 |
| 24 | SM-8060552-TP | SCREW M6 L=5 | 2 |
| 25 | 134-09602 | DIFF_DRIVE_LINK_L | 1 |
| 26 | 134-09701 | DIFF_DRIVE_LINK_R | 1 |
| 27 | 134-09800 | DIFF_LINK_PIN | 1 |
| 28 | SM-8040412-TP | SET SCREW M4 L=4 | 2 |
| 29 | 134-16052 | DIFF_FEED_ARM_ASSY | 1 |
| 30 | SM-8060552-TP | SCREW M6 L=5 | (2) |
| 31 | 134-16102 | DIFF_FEED_PIN_1 | (1) |
| 32 | 134-16201 | DIFF_FEED_PIN_2 | (1) |
| 33 | SM-6030650-TP | SCREW | (2) |
| 34 | SM-4850455-SP | SCREW | (1) |
| 35 | 134-16458 | SLIDER_GUIDE_ASSY | 1 |
| 36 | SM-8040512-TP | SCREW | 1 |
| 37 | 134-16508 | PIN_DIFF_ADJ | 1 |
| 38 | 134-12705 | SPACER | 1 |
| 39 | 134-13208 | DIFF ADJ LINK | 1 |
| 40 | 134-16854 | DIFF_ADJ_LEVER_ASSY | 1 |
| 41 | 134-16706 | SLIDER_GUIDE_BLOCK | 1 |
| 42 | SM-6051400-SP | SCREW | 2 |
| 43 | 134-15252 | DIFF_ADJ_LEVER_ASSY | 1 |
| 44 | 134-15401 | TORSION SPRING | 1 |
| 45 | RO-0681901-00 | RUBBER RING | 1 |
| 46 | 134-15104 | BUSHING FEED ADJ | 1 |
| 47 | 134-14701 | BUSHING FEED ADJ | 1 |
| 48 | 134-09305 | BUSHING_FEED_ADJ | 1 |
| 49 | CS-1000881-TP | THRUST COLLAR | 1 |
| 50 | SM-8050412-TP | SCREW M5 L=4 | 2 |
| 51 | 134-15302 | PLATE DIFF ADJ LEVER | 1 |
| 52 | SM-4051255-SP | SCREW.,M5 L=12. | 2 |
| 53 | 132-17500 | DIFFERENTIAL FEED LOCK NUT | 1 |
| 54 | 132-17401 | DIFFERENTIAL FEED HINGE SCREW | 1 |
| 55 | 134-17100 | SCREW | 1 |
| 56 | 132-17708 | DIFFERENTIAL FEED BLOCK | 1 |
| 57 | 133-21203 | STOPPER DIFF ADJ | 1 |
| 58 | 131-23302 | ADJUSTING SPRING | 1 |
| 59 | WP-0621016-SD | WASHER 6.2X13X1 | 1 |
| 60 | SM-4040655-SN | SCREW M4X0.7 L=6 | 1 |
| 61 | WP-0450826-SC | WASHER 4.5X10X0.8 | 1 |
| 62 | WP-0460556-SD | WASHER 4.6X7.5X0.5 | 1 |
| 63 | WP-0450826-SC | WASHER 4.5X10X0.8 | 1 |
Page 17 — 7. THREAD TAKE-UP LEVER COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | SM-6051002-TP | SCREW M5X0.8 L=10 | 1 |
| 2 | WS-0510002-KP | SPRING WASHER 5.1X9.2X1.3 | 1 |
| 3 | 133-24306 | SHAFT | 1 |
| 4 | WP-0522016-SH | WASHER | 1 |
| 5 | 133-24504 | BUSHING REAR | 1 |
| 6 | CS-1000881-TP | THRUST COLLAR | 1 |
| 7 | SM-8050412-TP | SCREW M5 L=4 | 2 |
| 8 | 133-24603 | BUSHING FRONT | 1 |
| 9 | 236-12609 | FEED CHANGING SHAFT OIL SEAL | 1 |
| 10 | 133-24702 | HOLDER TAKE UP EYELET | 1 |
| 11 | SM-6051402-TP | SCREW M5X0.8 L=14 | 1 |
| 12 | 133-24801 | NDL THREAD TAKE UP | 1 |
| 13 | 133-24900 | UP LPR THREAD TAKE UP | 1 |
| 14 | SM-4041055-SP | SCREW | 2 |
| 15 | 133-25006 | THREAD GUIDE | 1 |
| 16 | SM-4040655-SP | SCREW M4 L=6 | 2 |
| 17 | 133-25105 | THREAD TENSION GUIDE | 1 |
| 18 | 133-48008 | TANK | 1 |
| 19 | B9213-850-000 | SILICONE OIL TANK COVER, UPPER | 1 |
| 20 | B9214-850-000 | HEAT REMOVING FELT | 1 |
| 21 | PS-0150082-KH | SPRING PIN | 2 |
| 22 | ST-4040851-SN | TAPPING SCREW M4X8 | 2 |
| 23 | 133-25204 | HOLDER | 1 |
| 24 | 303-91601 | NEEDLE THREAD EYELET | 3 |
| 25 | SM-8030350-TP | SCREW | 3 |
| 26 | SM-4030855-SN | SCREW M3 L=8.0 | 1 |
| 27 | SM-4040655-SP | SCREW M4 L=6 | 2 |
| 28 | 133-25402 | THREAD GUIDE | 1 |
| 29 | SM-4040655-SP | SCREW M4 L=6 | 1 |
| 30 | 133-25501 | COVER | 1 |
| 31 | 133-25709 | NDL THD STRIKE OFF | 1 |
| 32 | WP-0320501-SC | WASHER M3 | 1 |
| 33 | SM-4030455-SP | SCREW | 1 |
| 34 | 133-25600 | THD STRIKE OFF PLATE | 1 |
| 35 | WP-0320501-SC | WASHER M3 | 1 |
| 36 | SM-4030655-SP | SCREW | 1 |
| 37 | 133-26905 | NDL THD STRIKE OFF R | 1 |
| 38 | WP-0280501-SC | WASHER M2.6 | 1 |
| 39 | SM-4850455-SP | SCREW | 1 |
| 40 | 133-27002 | THD STRIKE OFF PLATE R | 1 |
| 41 | WP-0280501-SC | WASHER M2.6 | 1 |
| 42 | SM-4850455-SP | SCREW | 1 |
| 43 | 133-27101 | THREAD_GUIDE | 1 |
| 44 | WP-0320501-SC | WASHER M3 | 1 |
| 45 | SM-4030655-SP | SCREW | 1 |
| 46 | SM-1040800-SP | SCREW | 2 |
| 47 | 133-26350 | UP_LPR_TENSION_ASSY | 1 |
| 48 | 133-26301 | THREAD GUIDE UPPER LPR | (1) |
| 49 | 133-26400 | THREAD GUIDE | (1) |
| 50 | 229-45802 | THREAD TENSION DISK | (2) |
| 51 | 133-26509 | TENSION POST | (1) |
| 52 | 229-45505 | THREAD TENSION SPRING | (1) |
| 53 | 133-26608 | TENSION NUT | (1) |
| 54 | NM-6050001-SP | NUT M5 | (1) |
| 55 | WP-0450826-SC | WASHER 4.5X10X0.8 | 2 |
| 56 | SM-6040800-SP | SCREW | 2 |
| 57 | 133-25808 | NIPPER PLATE SUPPORT | 1 |
| 58 | 133-25907 | NIPPER PLATE | 1 |
| 59 | 133-26004 | NIPPER GUIDE PLATE | 1 |
| 60 | 133-26103 | SPRING | 1 |
| 61 | 133-26202 | SHOULDER SCREW | 1 |
| 62 | SM-4040655-SP | SCREW M4 L=6 | 1 |
| 63 | 133-26707 | THREAD GUIDE | 1 |
| SM-4030855-SP | SCREW | 1 |
Page 19 — 8. SPREADER COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 133-28158 | ASSY_UPPPER_LPR_MECH | 1 |
| 2 | SM-8050412-TP | SCREW M5 L=4 | (2) |
| 3 | 133-28000 | UPPER LOOPER ECCENTRIC | (1) |
| 4 | 133-28109 | CONNROD FOR UPPER LPR | (1) |
| 5 | 133-28208 | STUD | (1) |
| 6 | SM-6061402-TP | SCREW M6 L=14 | 1 |
| 7 | 133-28406 | UPPER LOOPER SHAFT | 1 |
| 8 | 133-99209 | COLLAR | 1 |
| 9 | SM-8040410-TP | SCREW | 2 |
| 10 | 133-29008 | BUSHING REAR | 1 |
| 11 | 133-29107 | BUSHING FRONT | 1 |
| 12 | 133-28554 | ASSY_UPPER_LPR_MECH_2 | 1 |
| 13 | CQ-3030000-00 | OIL WICK | (0.05) |
| 14 | SM-9061050-TP | SCREW M6 L=10 | (1) |
| 15 | SM-8060612-TP | SCREW M6 L=6 | (1) |
| 16 | 133-28505 | CRANK ROD | (1) |
| 17 | 133-28604 | UPPER LOOPER ROCKER | (1) |
| 18 | 133-28703 | UP LPR SHAFT VERTICAL | (1) |
| 19 | CS-1000881-TP | THRUST COLLAR | 1 |
| 20 | SM-8050412-TP | SCREW M5 L=4 | 2 |
| 21 | 133-28802 | UPPER LOOPER HOLDER | 1 |
| 22 | SM-6041200-SP | SCREW M4 L=12 | 1 |
| 23 | 133-29404 | UPPER_LOOPER | 1 |
| 24 | SM-6040800-SP | SCREW | 1 |
| 25 | 133-28307 | DRIVING ARM | 1 |
| 26 | WP-0550800-SP | WASHER 5.5X10X0.8 | 1 |
| 27 | NM-6050001-SP | NUT M5 | 1 |
| 28 | 133-29206 | BUSHING VERTICAL | 1 |
| 29 | 133-38900 | OIL SEAL | 1 |
| 30 | WP-1022016-SH | WASHER | 1 |
Page 21 — 9. LOWER THREAD CAM COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 134-17209 | TAKE UP BASE | 1 |
| 2 | 134-18306 | BUMPER | 1 |
| 3 | 134-17308 | TAKE UP BASE GUIDE | 1 |
| 4 | 134-17407 | RESET KNOB | 1 |
| 5 | RO-0371801-00 | RUBBER RING | 1 |
| 6 | PS-0200142-KO | SPRING PIN 2.0X14 | 1 |
| 7 | 134-17704 | SPRING TAKE UP | 1 |
| 8 | 134-17902 | TAKE UP PLATE SHAFT | 1 |
| 9 | RE-0500000-KO | E-RING | 1 |
| 10 | 134-17506 | BASE TAKE UP PLATE | 1 |
| 11 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
| 12 | 134-17605 | TAKE UP PLATE | 1 |
| 13 | SM-6030600-SP | SCREW M3X0.5 L=6 | 2 |
| 14 | 134-17803 | THREAD GUIDE | 1 |
| 15 | SM-6040600-SP | SCREW M4 L=6 | 1 |
| 16 | 134-18108 | EYELET A | 1 |
| 17 | 134-18207 | EYELET B | 1 |
| 18 | WP-0280501-SC | WASHER M2.6 | 2 |
| 19 | SM-4850455-SP | SCREW | 2 |
| 20 | SM-6040800-SP | SCREW | 2 |
| 21 | 134-18009 | LOCATION SPRING | 1 |
| 22 | SM-4040655-SP | SCREW M4 L=6 | 1 |
| 23 | 134-18454 | TAKE UP ASSY | 1 |
| 24 | SM-8050412-TP | SCREW M5 L=4 | 2 |
| 25 | 134-18702 | THREAD_CATCHER | 1 |
| 26 | SM-6030350-SN | SCREW M3 L=2.5 | 1 |
| 27 | WP-0430800-SC | WASHER M4 | 1 |
Page 23 — 10. NEEDLE GUARD COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 134-20401 | FORK FRONT NDL GUARD | 1 |
| 2 | 134-21201 | FELT_FRONT_NDL_GUARD | 1 |
| 3 | 134-20807 | BUSH FRONT NDL GUARD | 1 |
| 4 | SM-6040800-SP | SCREW | 1 |
| 5 | 134-20500 | HOLDER FRONT NDL GUARD | 1 |
| 6 | 134-20609 | FRONT NDL GUARD | 1 |
| 7 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
| 8 | 134-20005 | CAM REAR NDL GUARD | 1 |
| 9 | SM-8040412-TP | SET SCREW M4 L=4 | 2 |
| 10 | 134-21003 | REAR NEEDLE GUARD BLOCK | 1 |
| 11 | 134-20104 | FORK REAR N GUARD | 1 |
| 12 | 134-21300 | FELT_REAR_NDL_GUARD | 1 |
| 13 | SM-8050512-TP | SCREW M5 L=5 | 1 |
| 14 | 134-20708 | BUSH REAR NDL GUARD | 1 |
| 15 | 134-20203 | REAR N GUARD HOLDER | 1 |
| 16 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
| 17 | 134-20302 | REAR NEEDLE GUARD | 1 |
| 18 | 134-20906 | NDL GUARD COVER | 1 |
| 19 | 134-21409 | COLLER_FOR_NDL_GUARD | 1 |
| 20 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
Page 25 — 11. LOOPER COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 134-22001 | LOOPER ADOID ECCENTRIC | 1 |
| 2 | SM-8050612-TP | SCREW M5X6 | 2 |
| 3 | SB-3260002-OA | BEARING | 1 |
| 4 | SB-3260002-OB | BEARING | 1 |
| 5 | SB-3260002-OC | BEARING | 1 |
| 6 | 134-22605 | LOOPER AVOID LINK | 1 |
| 7 | 134-24304 | LOOPER SHAFT | 1 |
| 8 | TA-0400301-MO | PLUG D=4X4.5 L=3 | 2 |
| 9 | CS-1000881-TP | THRUST COLLAR | 1 |
| 10 | SM-8050412-TP | SCREW M5 L=4 | 1 |
| 11 | SM-8050642-TP | SCREW | 1 |
| 12 | 134-24452 | LEVER_ASSY | 1 |
| 13 | 134-24403 | LEVER | (1) |
| 14 | SM-6061402-TP | SCREW M6 L=14 | (1) |
| 15 | 134-24502 | BUSHING FRONT | 1 |
| 16 | 134-22704 | LOOPER AVOID PIN | 1 |
| 17 | PS-0150042-KO | SPRING PIN 1.5X 4 | 1 |
| 18 | 134-22803 | BUSHING | 1 |
| 19 | B2107-816-000 | WASHER | 1 |
| 20 | NM-6050001-SP | NUT M5 | 1 |
| 21 | 134-23009 | BUSHING RIGHT | 1 |
| 22 | SM-8050812-TP | SCREW M5X8 | 1 |
| 23 | 134-22902 | GUIDE LOOPER BAR | 1 |
| 24 | 134-23108 | BUSHING LEFT | 1 |
| 25 | SM-8050812-TP | SCREW M5X8 | 1 |
| 26 | RO-1182401-00 | O-RING | 1 |
| 27 | 134-25202 | LPR_THREAD_GUIDE | 1 |
| 28 | WP-0320500-SC | WASHER M3 | 1 |
| 29 | SM-4030455-SP | SCREW | 1 |
| 30 | 134-24601 | LOOPER BAR | 1 |
| 31 | TA-0600401-RO | PLUG | 1 |
| 32 | 134-23405 | HOLDER | 1 |
| 33 | 134-23801 | WASHER | 1 |
| 34 | SM-6041000-SP | SCREW M4 L=10 | 1 |
| 35 | 134-23603 | WASHER | 2 |
| 36 | 134-23504 | SLIDER HOLDER | 1 |
| 37 | 134-23801 | WASHER | 1 |
| 38 | SM-6041000-SP | SCREW M4 L=10 | 1 |
| 39 | 134-23306 | SLIDER | 1 |
| 40 | 134-23702 | PIN | 1 |
| 41 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
| 42 | 134-24700 | LOOPER HOLDER | 1 |
| 43 | 134-23801 | WASHER | 1 |
| 44 | SM-6041002-TP | SCREW M4 L=10 | 1 |
| 45 | SM-8040412-TP | SET SCREW M4 L=4 | 1 |
| 46 | 134-24809 | LOOPER | 1 |
| 47 | 134-23900 | BUSHING REAR | 1 |
Page 27 — 12. THREAD TENSION COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 133-40005 | THREAD GUIDE PLATE | 1 |
| 2 | 133-40104 | THREAD GUIDE | 1 |
| 3 | SM-4040655-SP | SCREW M4 L=6 | 1 |
| 4 | SM-4040655-SP | SCREW M4 L=6 | 2 |
| 5 | 133-41359 | ASSY PULL OFF LEVER | 1 |
| 6 | 133-41409 | TENS RELEASE ADJ ECC | 1 |
| 7 | 133-41508 | SPRING | 1 |
| 8 | SM-4041655-SP | SCREW M4 L=16 | 1 |
| 9 | WP-0961046-SC | WASHER 9.6X16X1 | 1 |
| 10 | 133-40252 | THREAD TENSION ASSY | 1 |
| 11 | 133-40500 | TENSION DISC EYELET | (2) |
| 12 | B3121-804-000 | TENSION SPRING | (2) |
| 13 | 133-41706 | KNOB | (2) |
| 14 | 133-40203 | TENSION POST SUPPORT | (1) |
| 15 | 133-40302 | SHOULDER SCREW | (1) |
| 16 | B2008-372-000 | THREAD TENSION SPRING | (1) |
| 17 | 133-40401 | TENSION DISC SEPARATOR | (1) |
| 18 | 133-41607 | TENSION_DISC_EYELET_2 | (3) |
| 19 | 133-40609 | THREAD LEAD IN GUIDE | (5) |
| 20 | 133-40708 | SPACER | (5) |
| 21 | 133-40807 | TENSION POST | (5) |
| 22 | 229-28907 | THREAD TENSION DISK | (10) |
| 23 | 131-37609 | THREAD TENSION DISK PRESSER | (5) |
| 24 | 131-37906 | SPRING BUSHING | (5) |
| 25 | 131-40504 | TENSION SPRING | (3) |
| 26 | 133-40906 | KNOB GREEN | (3) |
| 27 | SM-4041055-SP | SCREW | 2 |
Page 29 — 13. LUBRICATION COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 133-43900 | OIL_PROTECTION_SHIELD | 1 |
| 2 | 133-43652 | ASSY_OIL_TUBE | 1 |
| 3 | 133-43603 | OIL TUBE | (1) |
| 4 | 133-44205 | FELT_FOR_HEAD_LUB | (1) |
| 5 | 118-56101 | NEEDLE COOLER PIN | (1) |
| SM-8060812-TP | SCREW M6 L=8 | (1) | |
| 133-44056 | ASSY_HEAD_SUCTION | (1) | |
| 133-44155 | ASSY_HEAD_SUCTION 2 | (1) | |
| 400-19163 | FELT_FOR_HEAD_SUCTION | (1) | |
| 133-46408 | OIL_TUBE_FOR_SUCTION | (1) | |
| 236-30007 | TUBE | (0.43) | |
| 133-44601 | SUCTION_PIPE | (1) | |
| 133-44502 | PIPE_CLAMP | (1) | |
| 133-44700 | BUSHING_FOR_SUCTION | (1) | |
| 134-27257 | ASSY_OIL_PIPE | (1) | |
| SM-4040655-SP | SCREW M4 L=6 | (1) | |
| 133-43504 | OIL_SAUCER | (1) | |
| NM-6040001-SP | NUT M4X0.7 | (1) | |
| 236-29306 | PIPE_STOPPER A | (1) | |
| BP-3000001-OR | VINYL_PIPE | 0.5 | |
| 134-27307 | CONNECTING_SCR_BRACKET | (1) | |
| 133-45053 | ASSY_OIL_SUPPLY_FOR_TOP | (1) | |
| 134-26051 | ASSY_PUMP_3-STAGE | (1) | |
| 133-43009 | WORM_WHEEL | (1) | |
| SM-8050412-TP | SCREW M5 L=4 | (2) | |
| 134-26002 | OIL_PUMP_SHAFT_LARGE | (1) | |
| 133-43108 | OIL_PUMP_HOUSING | (1) | |
| 132-28309 | OIL_PUMP_PINION | (4) | |
| 133-43405 | OIL_PUMP_SPACER | (2) | |
| 134-26101 | OIL_PUMP_SHAFT_SMALL | (1) | |
| 134-26200 | OIL_PUMP_CASING_UPPER | (1) | |
| 132-28200 | OIL_PUMP_PINION | (2) | |
| 133-43207 | OIL_PUMP_CASING | (1) | |
| 133-43306 | OIL_PUMP_COVER | (1) | |
| SM-6043000-SP | SCREW | (2) | |
| SM-6040600-SP | SCREW M4 L=6 | (2) | |
| SQ-0000451-MZ | CONNECTING_SCREW | (1) | |
| SQ-2060443-SD | CONNECTING_SCREW | (1) | |
| SQ-2060451-MZ | CONNECTING_SCREW | (1) | |
| 400-04749 | GASKET | (3) | |
| SQ-2050452-MZ | CONNECTING_SCREW | (1) | |
| NM-6050001-SP | NUT M5 | (2) | |
| WP-0550800-SP | WASHER_5.5X10X0.8 | (2) | |
| SM-6051602-TP | SCREW M5X0.8 L=16 | (1) | |
| 134-26309 | OIL_PAN | (4) | |
| SM-6081802-TP | SCREW | (1) | |
| 134-26408 | O_RING | (1) | |
| 131-70105 | RUBBER_RING | (1) | |
| SM-0081001-SD | SCREW | (1) | |
| 133-46309 | BREEZE_PLATE | (1) | |
| 133-46101 | OIL_SIGHT_GAUGE | (1) | |
| 134-26606 | DUSTPROOF_PLATE | (1) | |
| 134-27604 | TUBE_HOLDER | (1) | |
| 133-43801 | FITTING_FILTER | (1) | |
| 131-42500 | CARTRIDGE_FILTER | (1) | |
| 133-44809 | GASKET_O | (1) | |
| 133-45202 | FILTER_COVER | (1) | |
| SM-4041055-SP | SCREW | (4) | |
| SQ-0000453-MZ | CONNECTING_SCREW | (1) | |
| SQ-0000454-MZ | CONNECTING_SCREW | (1) | |
| SQ-2060442-SD | CONNECTING_SCREW | (1) | |
| SQ-0000452-MZ | CONNECTING_SCREW | (1) | |
| 134-26903 | MESH_PLATE | 1 | |
| RC-1900002-KP | RETAIN_IG-PIN | 1 | |
| 134-27851 | ASSY_BED_SUCTION | (1) | |
| 134-28305 | FELT_FOR_BED_SUCTION | (1) | |
| 137-65607 | OIL_CONNEC. ARM | (1) | |
| 134-26754 | OIL_SUCTION_ASSY | (1) | |
| 134-28255 | ASSY_LOOPER_SUCTION | (1) | |
| 134-27752 | ASSY_CYLINDER_SUCTION | (1) | |
| 134-27703 | FELT_FOR_C_SUCTION | (1) | |
| 134-27455 | ASSY_OIL_SUPPLY_FOR_LMS | 1 | |
| SQ-2050391-SD | CONNECTING_SCREW | 1 | |
| 134-28008 | OIL_SUCTION_FOR_BUSHING | 1 |
Page 31 — 14. THREAD STAND COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 131-68653 | THREAD STAND ASM. | 1 |
| 2 | NM-6050001-SE | NUT M5 | (6) |
| 3 | WS-0510002-KN | SPRING WASHER | (6) |
| 4 | 131-68356 | THREAD STANDING ARM ASM. ,LONG | (2) |
| 5 | 131-68307 | THREAD STANDING ARM ,LONG | (2) |
| 6 | 229-31406 | THREAD STANDING ROD RUBBER CAP | (1) |
| 7 | 229-30408 | THREAD STANDING ROD, UPPER | (1) |
| 8 | 229-31307 | THREAD STANDING ROD JOINT | (1) |
| 9 | 131-67903 | THREAD GUIDE | (1) |
| 10 | 131-68000 | THREAD GUIDE BASE, LOWER | (1) |
| 11 | 131-68109 | THREAD GUIDE ARM | (1) |
| 12 | 131-68208 | THREAD GUIDE ARM BASE | (1) |
| 13 | 229-30309 | THREAD STANDING ROD, LOWER | (1) |
| 14 | 229-31109 | SPOOL RETAINER | (6) |
| 15 | 229-31000 | SPOOL PIN | (6) |
| 16 | 229-30903 | SPOOL REST CUSHION | (6) |
| 17 | 229-30804 | SPOOL REST | (6) |
| 18 | SM-6061610-SC | SCREW M6 L=16 | (4) |
| 19 | SM-4051405-SE | SCREW M5 L=14 | (2) |
| 20 | NM-6050001-SE | NUT M5 | (2) |
| 21 | SM-4041001-SC | SCREW M4X0.7 L=10 | (2) |
| 22 | NM-6040002-SE | NUT M4X0.7 | (2) |
| 23 | SM-4041201-SC | SCREW M4 L=12 | (1) |
| 24 | SM-4042001-SC | SCREW M4 X 20 | (1) |
| 25 | NM-6040002-SE | NUT M4X0.7 | (2) |
| 26 | WP-1612616-SE | WASHER 16X30X2.6 | (2) |
| 27 | WS-1643202-KR | SPRING WASHER | (1) |
| 28 | NM-6160511-SE | NUT M16X1.5 | (1) |
| 29 | 229-30705 | THREAD GUIDE ARM JOINT | (4) |
Page 33 — 15. GAUGE PARTS COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 133-50509 | NEEDLE_HEAD_48 | 1 |
| 2 | MUY-128A1000 | NEEDLE UYX128GAS #10 | 2 |
| 3 | SM-8030350-TP | SCREW | 3 |
| 4 | 133-54709 | THROAT_PLATE | 1 |
| 5 | 134-31200 | MAIN_FEED_DOG | 1 |
| 6 | 134-33503 | DIFF_FEED_DOG | 1 |
| 7 | 133-76058 | PRESSER_FOOT_ASSY | 1 |
| 8 | SM-6040800-SP | SCREW | (1) |
| 9 | 133-76009 | PRESSER_FOOT_BOTTOM | (1) |
| 10 | 133-75100 | P_F_YIELDING_SECTION | (2) |
| 11 | 133-76900 | PRESSER_FOOT_GUIDE | (1) |
| 12 | 133-77106 | SPRING | (1) |
| 13 | 133-75209 | PIVOT_PIN | (1) |
| 14 | 133-75308 | SPRING_L | (1) |
| 15 | 133-75407 | SPRING_R | (1) |
| 16 | 133-75506 | PRESSER_FOOT_HINGE | (1) |
| 17 | SM-8030412-TP | SCREW | (1) |
| 18 | 133-75605 | GUIDE_PLATE_L | (1) |
| 19 | 133-75704 | GUIDE_PLATE_R | (1) |
| 20 | SM-1850600-SP | SCREW | (4) |
| 21 | 133-77007 | SCREW | (1) |
| 22 | 133-50301 | NEEDLE_HEAD_56 | 1 |
| 23 | MUY-128A1000 | NEEDLE UYX128GAS #10 | 3 |
| 24 | SM-8030350-TP | SCREW | 4 |
| 25 | 133-54808 | THROAT_PLATE_56 | 1 |
| 26 | 133-52307 | THROAT PLATE | 1 |
| 27 | 134-31200 | MAIN_FEED_DOG | 1 |
| 28 | 134-30707 | MAIN_FEED_DOG | 1 |
| 29 | 134-33503 | DIFF_FEED_DOG | 1 |
| 30 | 134-32901 | DIFF_FEED_DOG | 1 |
| 31 | 133-75050 | PRESSER_FOOT_ASSY | 1 |
| 32 | 133-75001 | PRESSER_FOOT_BOTTOM | (1) |
| 33 | 133-75506 | PRESSER_FOOT_HINGE | (1) |
| 34 | SM-6040800-SP | SCREW | (1) |
| 35 | 133-75209 | PIVOT_PIN | (1) |
| 36 | SM-8030412-TP | SCREW | (1) |
| 37 | 133-77106 | SPRING | (1) |
| 38 | 133-75100 | P_F_YIELDING_SECTION | (2) |
| 39 | 133-75704 | GUIDE_PLATE_R | (1) |
| 40 | 133-75605 | GUIDE_PLATE_L | (1) |
| 41 | SM-1850600-SP | SCREW | (4) |
| 42 | 133-76900 | PRESSER_FOOT_GUIDE | (1) |
| 43 | 133-77007 | SCREW | (1) |
| 44 | 133-75407 | SPRING_R | (1) |
| 45 | 133-75308 | SPRING_L | (1) |
| 46 | 133-50400 | NEEDLE_HEAD_64 | 1 |
| 47 | MUY-128A1000 | NEEDLE UYX128GAS #10 | 3 |
| 48 | SM-8030350-TP | SCREW | 4 |
| 49 | 133-51200 | THROAT_PLATE | 1 |
| 50 | 134-30103 | MAIN_FEED_DOG | 1 |
| 51 | 134-32109 | DIFF_FEED_DOG | 1 |
| 52 | 133-75050 | PRESSER_FOOT_ASSY | 1 |
| 53 | 133-75001 | PRESSER_FOOT_BOTTOM | (1) |
| 54 | 133-75506 | PRESSER_FOOT_HINGE | (1) |
| 55 | SM-6040800-SP | SCREW | (1) |
| 56 | 133-75209 | PIVOT_PIN | (1) |
| 57 | SM-8030412-TP | SCREW | (1) |
| 58 | 133-77106 | SPRING | (1) |
| 59 | 133-75100 | P_F_YIELDING_SECTION | (2) |
| 60 | 133-75704 | GUIDE_PLATE_R | (1) |
| 61 | 133-75605 | GUIDE_PLATE_L | (1) |
| 62 | SM-1850600-SP | SCREW | (4) |
| 63 | 133-76900 | PRESSER_FOOT_GUIDE | (1) |
| 64 | 133-77007 | SCREW | (1) |
| 65 | 133-75407 | SPRING_R | (1) |
| 66 | 133-75308 | SPRING_L | (1) |
Page 34 — 16. GAUGE PARTS COMPONENTS (2) (FOR MF-7800-K10)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 134-29055 | SILICONE OIL TANK ASSY | 1 |
| 2 | SL-4041081-SC | SCREW M4 L=10 | 2 |
| 3 | 134-29105 | SILICONE OIL TANK CAP | 1 |
| 4 | 134-29204 | SILICONE OIL CUP | 1 |
| 5 | 134-29303 | FELT | 1 |
| 6 | 118-56101 | NEEDLE COOLER PIN | 1 |
| 7 | TA-0290301-M0 | PLUG | 1 |
| 8 | SM-4040655-SP | SCREW M4 L=6 | 1 |
| 9 | BT-0600402-EA | OIL TUBE | 0.03 |
| 10 | CQ-3030000-00 | OIL WICK | 0.1 |
Page 35 — 17. ACCESSORIES PARTS COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 400-13913 | ACCESSORY_BAG_ASSY | 1 |
| 2 | 229-32800 | ACCESSORIE BAG | (1) |
| 3 | 229-33105 | SCREW DRIVER,MIDDLE | (1) |
| 4 | 123-47308 | SCREW DRIVER (SMALL) | (1) |
| 5 | 131-60304 | S SHAPED HOOK | (2) |
| 6 | 260-37903 | CHAIN | (1) |
| 7 | 122-88403 | TWEEZERS | (1) |
| 8 | 229-33006 | SCREW DRIVER,LARGE | 1 |
| 9 | MUY-128S1003 | NEEDLES(PACKAGE_OF_3) | 1 |
| 10 | 229-33303 | VINYL COVER | 1 |
| 11 | 131-60601 | FUNNEL | 1 |
| 12 | 133-08952 | SYNCHRONIZER_STUD_ASSY | 1 |
| 13 | 131-42500 | CARTRIDGE_FILTER | 1 |
| 14 | MML-018900CA | JUKI MACHINE OIL 18 | 1 |
| 15 | B9101-490-000 | DRIVER | 1 |
| 16 | 131-55403 | DUST-PROOF RUBBER | 4 |
| 17 | 134-29709 | BELT_COVER | 1 |
| 18 | 133-49600 | PIN_FOR_RUBBER_CUSHION | 4 |
| 19 | SK-3412001-SE | WOOD SCREW D=4.1 L=20 | 3 |
| 20 | WT-0430002-KN | WASHER M4 | 1 |
| 21 | SM-4040501-SN | SCREW M4X0.7 L=5 | 1 |
| 22 | NM-6080003-SC | NUT M8 | 4 |
| 23 | SM-4040655-SP | SCREW M4 L=6 | 1 |
| 24 | WP-0851216-SC | WASHER 8.5X18.0X1.2 | 4 |
| 25 | WS-0820002-KR | SPRING WASHER, M8 | 4 |
| 26 | 229-33204 | SCREW DRIVER,SMALL | 1 |
| 27 | HX-0015000-0C | CABLE CLIP | 1 |
Juki 7700 — parts catalog
- Page 1 (cover): This is the cover page for the JUKI High-speed, Cylinder-bed Coverstitch Machine MF-7800 Series parts list. It includes instructions on how to use the parts list in both English and Japanese, along with the catalog number.
- Page 2 (unknown): This page contains a watermark and a website address at the bottom.
- Page 3 (toc): This page is a table of contents for a sewing machine parts catalog, listing sections such as Frame & Miscellaneous Cover Components, Main Shaft Components, Feed Drive Components, and Accessories Parts Components, along with their corresponding page numbers.
- Page 4 (diagram): This page displays a diagram of frame and miscellaneous cover components for an industrial sewing machine, with numbered parts indicated for identification.
- Page 5 (parts_list): This page lists parts for the MF-7800-U10 and MF-7800-K10 sewing machines, including part numbers, descriptions, quantities, and notes.
- Page 6 (diagram): This page displays a diagram of frame and miscellaneous cover components for an industrial sewing machine, with numbered parts and their corresponding reference numbers.
- Page 7 (parts_list): This page lists parts for an industrial sewing machine, including screws, gaskets, covers, and plates, with their corresponding part numbers, descriptions, and quantities.
- Page 8 (diagram): This page displays a diagram of main shaft components, including various shafts, pulleys, bearings, and fasteners, with reference numbers for each part.
- Page 9 (parts_list): This page lists parts for the machine, including part numbers, descriptions, and quantities. It covers components from the upper mainshaft right to the lower mainshaft left.
- Page 10 (diagram): This page displays a diagram of needle bar and presser components, with numbered parts and their corresponding references.
- Page 11 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes. It covers items from reference number 1 to 78.
- Page 12 (diagram): This page displays a diagram of feed drive components, including various parts labeled with reference numbers and some part numbers.
- Page 13 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes. It details components like feed eccentric, needle bearings, crank rods, and various screws and pins.
- Page 14 (diagram): This page displays a diagram of feed drive components, including various shafts, linkages, bearings, and fasteners, with corresponding reference numbers for identification.
- Page 15 (parts_list): This page lists parts for a differential feed mechanism, including screws, washers, bushings, and collars, with their corresponding part numbers and descriptions.
- Page 16 (diagram): This page displays a diagram of thread take-up lever components, with numbered parts and their corresponding references.
- Page 17 (parts_list): This page lists parts for an industrial sewing machine, including screws, washers, bushings, and thread guides, with their corresponding part numbers and descriptions.
- Page 18 (diagram): This page displays a diagram of spreader components, with numbered parts and their corresponding references.
- Page 19 (parts_list): This page lists parts for the upper looper mechanism, including screws, shafts, collars, and oil seals, with their corresponding part numbers and quantities.
- Page 20 (diagram): This page displays a diagram of lower thread cam components, with numbered parts and their corresponding references.
- Page 21 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and some Japanese descriptions.
- Page 22 (diagram): This page displays a diagram of needle guard components, with numbered parts indicated for reference.
- Page 23 (parts_list): This page lists parts for needle guards, including part numbers, descriptions, and quantities, with some entries in Japanese.
- Page 24 (diagram): This page displays a diagram of looper components, with numbered parts and their corresponding references.
- Page 25 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, and quantities. It details items such as loopers, screws, bearings, and washers.
- Page 26 (diagram): This page displays a diagram of thread tension components, including various screws, plates, springs, and tension discs, with reference numbers for each part.
- Page 27 (parts_list): This page lists parts for a sewing machine, including thread guides, screws, levers, springs, and tension components, with part numbers, descriptions, and quantities.
- Page 29 (parts_list): This page contains a parts list for industrial sewing machines, detailing part numbers, descriptions, quantities, and remarks for various components.
- Page 30 (diagram): This page displays a diagram of thread stand components, with numbered parts and their corresponding references.
- Page 31 (parts_list): This page lists parts for a sewing machine, including thread stand assemblies, nuts, washers, screws, and thread guides, with their corresponding part numbers, descriptions, and quantities.
- Page 32 (diagram): This page displays diagrams of gauge parts components for sewing machine models MF-7823-U10-B48, MF-7823-U10-B56, MF-7823-K10-B56, and MF-7823-U10-B64, with numbered parts for each section.
- Page 33 (parts_list): This page lists parts for industrial sewing machines, including part numbers, descriptions, quantities, and notes. It details components like needle heads, screws, plates, and springs, with specific model applicability for some items.
- Page 34 (parts_list): This page lists gauge parts components for the MF-7800-K10 machine, including part numbers, descriptions, and quantities.
- Page 35 (parts_list): This page lists accessories and components for industrial sewing machines, including various tools like screwdrivers, a funnel, oil, and hardware such as screws, nuts, and washers, with their corresponding part numbers and quantities.
- Page 39 (unknown): This page contains a watermark and no other discernible text or parts information.
- Page 40 (cover): This is the cover page of a JUKI CORPORATION parts catalog, copyrighted in 2003. It includes contact information for orders and inquiries, and notes that the parts list is subject to change.
