Juki LK-1900 Parts Book (PDF)
Text index — Juki LK-1900
Page 7 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-00457 | MOTOR COVER ASM. | 1 |
| 2 | 141-00408 | MOTOR COVER | (1) |
| 3 | SS-6111140-SP | SCREW 11/64-40 L=11 | (4) |
| 4 | M8002-430-000 | STOPPER | (4) |
| 5 | 141-00754 | OIL PAN ASM. | 1 |
| 141-00705 | OIL PAN | (1) | |
| CQ-2522000-00 | OIL WICK | (1) | |
| 141-00903 | BED COVER PACKING A | 1 | |
| 141-01000 | BED COVER PACKING B | 1 | |
| B1115-210-D00 | HINGE RUBBER | 2 | |
| 100-04109 | GROUND MARK | 2 | |
| B1116-210-D00 | FRAME SUPPORT RUBBER | 2 | |
| 135-02307 | FACE PACKING | 1 | |
| 137-86306 | THREAD GUIDE NO.1 | 2 | |
| B1111-210-D00 | BED HINGE | 2 | |
| B2707-761-000 | HINGE STUD | 2 | |
| SS-7110730-SP | SCREW 11/64-40 L= 6.5 | 2 | |
| SM-6067552-TP | HEXAGONAL-HOLE BOLT M6 L=75 | 4 | |
| WP-0651646-SC | WASHER | 4 | |
| NM-6060001-SC | NUT M6 | 8 | |
| SK-3382001-SE | SCREW D=3.8 L=20 | 4 | |
| 141-01208 | HEAD SUPPORT BAR | 1 | |
| 138-16764 | FACE COVER ASM. | 1 | |
| 138-16608 | BALANCE COVER | 1 | |
| B1111-232-000 | THREAD GUIDE PLATE | 1 | |
| B1124-280-000 | ARM THREAD GUIDE B | 1 | |
| B1125-280-000 | L-SHAPED THREAD GUIDE A | 1 | |
| 110-18504 | THREAD GUIDE | 1 | |
| B3114-771-000 | THREAD GUIDE | 1 | |
| CM-3002001-01 | SAFETY LABEL,1 (SMALL). | 1 | |
| CM-3002001-A1 | SAFETY LABEL,3 (SMALL). | 1 | |
| NS-6090310-SP | NUT 9/64-40 | 1 | |
| CM-3002000-B2 | LABEL (25) | 1 | |
| CM-3002000-02 | CAUTION LABEL (25) | 1 | |
| SS-6110610-TP | SCREW 11/64-40 L=6 | 1 | |
| SS-4090715-SP | SCREW 9/64-40 L=7 | 2 | |
| SS-4111015-SP | SCREW 11/64-40 L=10 | 2 | |
| 141-00309 | TOP COVER | 1 | |
| SS-4150715-SP | SCREW 15/64-28 L=7 | 1 | |
| SS-4151215-SP | SCREW 15/64-28 L=12 | 1 | |
| SS-7110840-SP | SCREW 11/64-40 L=7.8 | 1 | |
| 105-02300 | THREAD CUTTER | 1 | |
| TA-1250406-RO | RUBBER PLUG D=12.5 L=4 | 1 | |
| TA-1470704-RO | RUBBER PLUG | 1 | |
| TA-2100904-RO | RUBBER PLUG | 1 | |
| TA-1050504-RO | RUBBER PLUG | 1 | |
| 141-00606 | COVER B | 1 | |
| 141-00507 | COVER A | 1 | |
| 141-13666 | BOBBIN WINDER ASM. | (1) | |
| 141-13658 | BOBBIN WINDER SHAFT COMPL. | (1) | |
| 135-07504 | WASHER | (1) | |
| B3212-761-000 | CH SPRING | (1) | |
| 225-37658 | BOBBIN FITTING BASIS COMPL. | (1) | |
| 225-38151 | BOBBIN CAM SHAFT COMPL. | (1) | |
| 225-38300 | BOBBIN LEVER | (1) | |
| 225-38409 | ADJUSTING PLATE | (1) | |
| A3216-001-00A | RUBBER PLUG | (1) | |
| B1148-555-000 | SPRING | (1) | |
| B1529-890-00C-A | PRESSUR FOOT SPRING | (1) | |
| B3205-210-000 | CUSHION | (1) | |
| RC-0560711-KP | RETAINING RING | (1) | |
| RE-0500000-KO | E-RING | (1) | |
| RO-0922702-00 | RUBBER RING | (1) | |
| SS-8110422-TP | SCREW 11/64-40 L=4 | (1) | |
| 141-13468 | BOBBIN THREAD TENSION ASM. | 1 | |
| 141-13450 | BOBBIN THREAD TENSION ROD ASM. | (1) | |
| D7133-555-B00 | CONNECTING ROD SPRING | (1) | |
| B3126-012-000 | THREAD TENSION NUT | (1) | |
| 110-72402 | NUT 11/64-40 | (1) | |
| NS-6110310-SP | NUT 11/64-40 | (1) |
Page 9 — 2. MAIM SHAFT & NEEDLE BAR COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-02404 | MAIN SHAFT SLIT PLATE | 1 |
| 2 | 141-02107 | MAIN SHAFT | 1 |
| 3 | 141-02206 | MAIN SHAFT BUSHING, FRONT | 1 |
| 4 | 141-02305 | MAIN SHAFT BUSHING, MIDDLE | 1 |
| 5 | 141-02503 | SENSOR INSTALLING BASE | 1 |
| 6 | 141-02602 | HAND PULLEY SHAFT | 1 |
| 7 | 141-02701 | HAND PULLEY GEAR A | 1 |
| 8 | 141-02800 | HAND PULLEY GEAR B | 1 |
| 9 | B1230-210-D00 | MAIN MOTOR | 1 |
| 10 | B1231-210-D00 | COUPLING | 1 |
| 11 | B1202-280-000 | COUNTER WEIGHT | 1 |
| 12 | B1206-210-D00 | COUNTER WEIGHT | 1 |
| 13 | B1223-771-000 | NEEDLE ROD CRANK WASHER | 1 |
| 14 | B1901-280-0B0 | LINK BALANCE ASM. | 1 |
| 15 | B1901-280-000 | THREAD TAKE-UP LEVER | (1) |
| 16 | B1903-280-000 | THREAD TAKE-UP CRANK | (1) |
| 17 | B1903-552-000 | LEFT SCREW | (1) |
| 18 | B1905-541-000 | NEEDLE BUSHING | (1) |
| 19 | B1411-804-000 | NEEDLE DRIVING LEVER BEARING | (1) |
| 20 | B1203-280-000 | NEEDLE ROD CRANK | (1) |
| 21 | B1404-280-000 | NEEDLE BAR CRANK ROD | (1) |
| 22 | B1901-210-DC0 | LINK THREAD TAKE-UP | 1 |
| 23 | B1901-210-DA0 | THREAD TAKE-UP LEVER COMPL. | (1) |
| 24 | B1407-210-D00 | NEEDLE BAR CRANK | (1) |
| 25 | B1903-210-000 | THREAD TAKE-UP CRANK | (1) |
| 26 | B1905-541-000 | NEEDLE BUSHING | (1) |
| 27 | B1411-804-000 | NEEDLE DRIVING LEVER BEARING | (1) |
| 28 | B1903-552-000 | LEFT SCREW | (1) |
| 29 | B1404-280-000 | NEEDLE BAR CRANK ROD | (1) |
| 30 | B1904-280-000 | BALANCE CRANK PIN | (1) |
| 31 | B1904-280-000 | BALANCE CRANK PIN | 1 |
| 32 | SS-6151412-TP | SCREW 15/64-28 L=14 | 1 |
| 33 | SS-6681712-TP | SCREW 9/32-28 L=16.5 | 1 |
| 34 | SS-8660530-TP | SCREW 1/4-40 L= 4.5 | 1 |
| 35 | SS-8660610-TP | SCREW 1/4-40 L=6 | 1 |
| 36 | SS-7151120-SP | SCREW 15/64-28 L=11 | 1 |
| 37 | CS-147121A-SH | THRUST COLLAR ASM.D=14.72 W=12 | 1 |
| 38 | G1216-870-000 | UPPER SHAFT REAR BEARING | 1 |
| 39 | SM-8060612-TP | SCREW M6 L=6 | 2 |
| 40 | SM-8061612-TP | SCREW M6X16 | 2 |
| 41 | HD-0019300-00 | PHOTO SENSOR | 1 |
| 42 | SL-4041291-SC | SCREW M4 L=12 | 1 |
| 43 | SL-4061091-SC | SCREW | 2 |
| 44 | 141-14508 | MAIN SHAFT SENSOR COVER | 1 |
| 45 | SS-7111410-TP | SCREW 11/64-40 L=14 | 4 |
| 46 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 1 |
| 47 | A1230-500-000-A | HANDWHEEL SETSCREW | 1 |
| 48 | B1144-210-000 | REVOLVING DIRECTION LABEL | 1 |
| 49 | B1212-210-D00 | PULLEY | 1 |
| 50 | GAF-01007000 | SPRING | 1 |
| 51 | PS-0400142-KH | SPRING PIN 4X14 | 1 |
| 52 | SS-8110310-SP | SCREW 11/64-40 L= 2.8 | 2 |
| 53 | SS-8110310-SP | SCREW 11/64-40 L= 2.8 | 2 |
| 54 | RO-1542401-00 | RUBBER RING | 1 |
| 55 | B1401-280-000 | NEEDLE BAR | 1 |
| 56 | D1401-L7V-V00 | NEEDLE BAR | 1 |
| 57 | B1402-280-000 | NEEDLE ROD METAL | 1 |
| 58 | B1403-280-000 | NEEDLE ROD LOWER METAL | 1 |
| 59 | B1405-280-000 | NEEDLE BAR THREAD GUIDE | 1 |
| 60 | D1405-L7A-M00 | NEEDLE BAR THREAD GUIDE | 1 |
| 61 | B1411-552-0A0 | NEEDLE BAR CONNECTING ASM. | 1 |
| 62 | B1411-552-000 | NEEDLE BAR CLAMP | (1) |
| 63 | SS-6090670-TP | SCREW 9/64-40 L=6 | (1) |
| 64 | B1414-232-000 | SQUARE BLOCK | 1 |
| 65 | MDP-500B1100 | NEEDLE DPX5 #11 | 1 |
| 66 | MDP-500B1400 | NEEDLE DPX5 #14 | 1 |
| 67 | MDP-500B1600 | NEEDLE DPX5 #16 | 1 |
| 68 | MDP-170B1900 | NEEDLE DPX17 #19 | 1 |
| 69 | SS-2060510-SP | SCREW 3/32-56 L=4.5 | 1 |
| 70 | SS-6080340-SP | SCREW 1/8-44 L=2.9 | 1 |
| 71 | SS-7080510-TP | SCREW 1/8-44 L=4.5 | 1 |
| 72 | B3213-205-000 | BOBBIN WINDER DRIVING WHEEL | 1 |
| 73 | SS-8111610-SP | SCREW 11/64-40 L=15.5 | 2 |
| 74 | SS-9661230-CP | SCREW 1/4-40 L=12 | 1 |
| 75 | 141-15364 | UPPER SHAFT SENSOR CABLE ASM. | 1 |
Page 11 — 3. PRESSER LIFTER COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-04152 | PRESSER LIFTING SOLENOID ASM. | 1 |
| 2 | 141-04202 | LOWERING FOOT | 1 |
| 3 | 141-04301 | LOWERING ARM | 1 |
| 4 | 141-04400 | CONNECTING LINK | 1 |
| 5 | 141-04509 | CONNECTING SHAFT | 1 |
| 6 | 141-04608 | RETURN SPRING HOOK | 1 |
| 7 | 141-05100 | LINK D | 1 |
| 8 | 141-04707 | SOLENOID LINK | 1 |
| 9 | 141-04905 | LINK B | 1 |
| 10 | 141-05001 | LINK C | 1 |
| 11 | 141-04806 | LINK A | 1 |
| 12 | 141-05852 | PRESSER LIFTING CYLINDER ASM. | 1 |
| 13 | PA-2502507-A0 | AIR CYLINDER | (1) |
| 14 | PJ-3040605-02 | ELBOW UNION 6XM5 | (2) |
| 15 | 141-05209 | PRESSER SENSOR SLIT | 1 |
| 16 | 141-05308 | SENSOR INSTALLING PLATE | 1 |
| 17 | HD-0005700-0A | PHOTO SENSOR | 1 |
| 18 | SS-6110610-TP | SCREW 11/64-40 L=6 | 1 |
| 19 | 113-92107 | OIL PUMP SUPPORT | 1 |
| 20 | 135-06415 | CONNECTING ARM | 1 |
| 21 | 141-05704 | STOPPER RUBBER SET WASHER | 1 |
| 22 | 135-44705 | SPRING | 1 |
| 23 | B1513-210-D00 | MAGNET PIN | 1 |
| 24 | D2502-232-D00 | SHAFT BLOCK SHAFT | 2 |
| 25 | NS-6150310-SP | NUT 15/64-28 | 1 |
| 26 | B1515-210-D00 | PIN | 2 |
| 27 | SD-0640391-TP | HINGE SCREW D= 6.35 H= 3.9 | 1 |
| 28 | SD-0790601-SP | HINGE SCREW D=7.94 H=6 | 1 |
| 29 | CS-079101A-SH | THRUST COLLAR ASM. D=7.94 W=10 | 2 |
| 30 | SD-0800341-SP | HINGE SCREW D=8 H=3.4 | 4 |
| 31 | SD-0800341-SP | HINGE SCREW D=8 H=3.4 | 3 |
| 32 | SD-1000401-SP | HINGE SCREW D=10 H= 4 | 2 |
| 33 | SL-4031291-SC | SCREW M3X12 | 1 |
| 34 | 138-60200 | CYLINDER PUSHING PLATE | 1 |
| 35 | 138-60606 | PIN | 1 |
| 36 | SM-6061802-TP | SCREW M6 L=18 | 1 |
| 37 | SM-6061802-TP | SCREW M6 L=18 | 1 |
| 38 | HX-0033900-00 | STUD | 1 |
| 39 | SS-8150822-TP | SCREW 15/64-28 L=8 | 2 |
| 40 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 2 |
| 41 | SS-4151215-SP | SCREW 15/64-28 L=12 | 4 |
| 42 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 2 |
| 43 | WP-0560860-SE | WASHER 5.6X12X0.8 | 2 |
| 44 | 141-05605 | PRESSER LIFTING STOPPER RUBBER | 1 |
| 45 | SM-6061602-TP | SCREW M6 L=16 | 2 |
| 46 | SD-0800342-TP | HINGE SCREW D=8 H=3.2 | 1 |
| 47 | SS-4151215-SP | SCREW 15/64-28 L=12 | 2 |
| 48 | NM-6540023-SB | NUT | 1 |
| 49 | RE-0600000-KO | E-RING 6 | 2 |
| 50 | SS-4150715-SP | SCREW 15/64-28 L=7 | 3 |
| 51 | 141-05506 | PLATE | 1 |
| 52 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 2 |
| 53 | 141-06108 | PLATE | 1 |
| 54 | 141-05902 | CYLINDER BASE A | 1 |
| 55 | 141-06009 | CYLINDER BASE B | 1 |
| 56 | RO-0481901-00 | RUBBER RING | 1 |
Page 13 — 4. SHUTTLE DRIVER SHAFT COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-03402 | OSCILLATOR | 1 |
| 2 | 141-03055 | SHUTTLE ASM. | 1 |
| 3 | 141-03006 | SHUTTLE | (1) |
| 4 | B1813-980-000 | SHUTTLE NEEDLE OUTER RING | (1) |
| 5 | B3505-280-000 | SHUTTLE LUBRICATING PLATE | (1) |
| 6 | 141-03907 | SHUTTLE ONCE THROUGH OIL FELT | (1) |
| 7 | SS-4090415-SP | SCREW 9/64-40 L=4 | (2) |
| 8 | WP-0952616-SD | WASHER 9.5X14.8X2.6 | (1) |
| 9 | CQ-2020000-00 | OIL WICK | (1.06) |
| 10 | B1820-210-D00 | SHUTTLE OIL FELT,A | (2) |
| 11 | BP-3000000-00 | VINYL PIPE | (0.66) |
| 12 | B1821-210-D00 | SHUTTLE OIL FELT,B | (1) |
| 13 | B1820-215-PAO-A | INNER HOOK PRESSER ASM. | (2) |
| 14 | B1822-215-POO | INNER HOOK PRESSER SPRING | (2) |
| 15 | RE-0300000-KO | E-RING 3 | (2) |
| 16 | CQ-2000000-00 | OIL WICK | (0.43) |
| 17 | 141-04004 | ONCE THROUGH OIL FELT PRESSER | (1) |
| 18 | SS-6060410-TP | SCREW 3/32-56 L= 3.5 | (2) |
| 19 | BT-0500300-EA | OIL TUBE | (0.19) |
| 20 | 105-23504 | WASHER | 1 |
| 21 | 138-16855 | CYLINDER ARM CAP | 1 |
| 22 | 135-08700 | HOOK COVER PRESSER SPRING PIN | 1 |
| 23 | 135-08809 | HOOK COVER PRESSER SPRING A | 1 |
| 24 | 135-08908 | HOOK COVER PRESSER SPRING B | 1 |
| 25 | 135-08403 | LOWER SHAFT REAR METAL | 1 |
| 26 | 135-09153 | LOWER SHAFT GEAR A ASM. | 1 |
| 27 | B1411-804-A00 | BEARING (A) | 3 |
| 28 | B1411-804-B00 | NEEDLE DRIVING LEVER BEARING B | 3 |
| 29 | B1411-804-C00 | NEEDLE DRIVING LEVER BEARING C | 3 |
| 30 | B1411-804-D00 | BEARING (D) | 3 |
| 31 | B1808-980-000 | LOWER SHAFT THRUST WASHER | 1 |
| 32 | B1812-980-0AO | DRIVER ASM. | 1 |
| 33 | B1812-980-000 | SHUTTLE DRIVER | (1) |
| 34 | SS-6121212-TP | SCREW 3/16-28 L=12.0 | (1) |
| 35 | B1815-980-000 | SHUTTLE UPPER SPRING | 1 |
| 36 | 141-03501 | SHUTTLE UPPER SPRING (F TYPE) | 1 |
| 37 | B1816-980-000 | AUXILIARY SHUTTLE RACE SPRING | 1 |
| 38 | B1818-280-000 | INNER HOOK | 1 |
| 39 | D1818-282-N00 | SHUTTLE | 1 |
| 40 | B1819-280-000 | SHUTTLE RACE ADJUSTING SHAFT | 1 |
| 41 | 138-12102 | BOBBIN | 1 |
| 42 | B1828-980-0BB | BOBBIN CASE ASM. (RACING PREVE | 1 |
| 43 | CS-080081C-SH | THRUST COLLAR ASM. D=8.0 W=8 | 1 |
| 44 | CS-1000811-SP | THRUST COLLAR | 1 |
| 45 | CS-1201010-SH | THRUST COLLAR ASM. D=12 W=10 | 1 |
| 46 | SS-8110520-TP | SCREW 11/64-40 L= 4.5 | 2 |
| 47 | NS-6660430-SP | NUT 1/4-40 | 1 |
| 48 | RE-0900000-KO | E-RING 9 | 1 |
| 49 | SD-0801021-TP | HINGE SCREW D= 8 H=10.2 | 1 |
| 50 | SS-6060410-TP | SCREW 3/32-56 L= 3.5 | 2 |
| 51 | SS-6110480-SP | SCREW 11/64-40 L=4.3 | 1 |
| 52 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 1 |
| 53 | SS-6151220-SP | SCREW 15/64-28 L=11.5 | 1 |
| 54 | SS-8150822-TP | SCREW 15/64-28 L=8 | 2 |
| 55 | SS-7111110-TP | SCREW 11/64-40 L=10.5 | 2 |
| 56 | 141-03659 | SHUTTLE RACE RING ASM.,C | 1 |
| 57 | 141-03253 | INNER HOOK PRESSER ASM., A | 1 |
| 58 | 141-03352 | INNER HOOK PRESSER ASM., B | 1 |
| 59 | B1836-210-D00 | OSCILLATING ECCENTRIC SHAFT | 1 |
| 60 | B1802-210-D00 | CRANK ROD | 1 |
Page 14 — 5. WIPER MECHANISM COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 135-09500 | WIPER CONNECTING LINK | 1 |
| 2 | 135-09609 | WIPER CONNECTING PLATE | 1 |
| 3 | 135-09708 | SPRING | 1 |
| 4 | 135-09807 | OIL SHIELD CAP | 1 |
| 5 | 135-09955 | WIPER CONNECTING ARM ASM. | 1 |
| 6 | B1229-232-000 | SNAP RING | 1 |
| 7 | B2101-280-0A0 | WIPER ASM. | 1 |
| 8 | D2101-L7A-MA0 | WIPER ASM. | 1 |
| 9 | 135-74009 | WIPER BASE PLATE | 1 |
| 10 | B2109-280-000 | WIPER CONNECTING SCREW | 1 |
| 11 | RC-0470611-KP | RETAINING RING 4.7 | 2 |
| 12 | SD-0530221-SP | HINGE SCREW D= 5.3 H= 2.2 | 1 |
| 13 | SD-0640211-SP | HINGE SCREW D= 6.35 H= 2.1 | 1 |
| 14 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 1 |
| B122-232-000 | SNAP RING | ||
| B2101-L7A-MAO | WIPER ASM. |
Page 15 — 6. TENSION RELEASE & THREAD TENSION COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-07502 | STOPPER | 1 |
| 2 | 141-07700 | CONNECTING BAR | 1 |
| 3 | B2304-210-D00 | TENSION RELEASE LINK | 1 |
| 4 | B2306-210-D00 | TENSION RELEASE ADJUSTING ARM | 2 |
| 5 | 135-13205 | TENSION RELEASE BAR | 1 |
| 6 | 135-13304 | THREAD TENSION ARM | 1 |
| 7 | B2545-280-000 | PRESSURE SPRING | 1 |
| 8 | WP-0482086-SD | WASHER 4.8X11.5X2 | 1 |
| 9 | B2302-280-0A0 | SECOND THREAD TENSION ASM. | 1 |
| 10 | B2302-205-0A0 | TENSION CONTROLLER NO.2 ASM. | 1 |
| 11 | B2302-280-000 | SECOND THREAD TENSION ROD | (1) |
| 12 | SS-8090610-SP | SCREW 9/64-40 L=5.9 | (1) |
| 13 | B2313-280-000 | THREAD TENSION ROD, LARGE | (1) |
| 14 | B3107-804-000 | THREAD TENSION DISK PRESSER | (1) |
| 15 | B3112-761-000 | THREAD TAKE-UP SPRING | (1) |
| 16 | B3112-L48-B00 | TAKE-UP SPRING (HEAVY) | (1) |
| 17 | B3114-232-000 | THREAD TENSION SPRING | (1) |
| 18 | B3129-053-000 | TENSION SPRING | (1) |
| 19 | B3119-771-000 | THREAD TENSION NUT | (1) |
| 20 | B3120-125-000 | ROTATING STOPPER | (1) |
| 21 | B3126-012-000 | THREAD TENSION DISK | (2) |
| 22 | B3132-552-000 | THREAD TENSION DISK PRESSER | (1) |
| 23 | B2303-280-000 | TENSION RELEASE PIN | 1 |
| 24 | B3413-552-000 | SUSPENSION SCREW | 1 |
| 25 | SD-0530221-SP | HINGE SCREW D= 5.3 H= 2.2 | 1 |
| 26 | SD-0720321-TP | HINGE SCREW | 1 |
| 27 | SD-0640391-TP | HINGE SCREW D= 6.35 H= 3.9 | 1 |
| 28 | SD-0640482-SP | HINGE SCREW D= 6.35 H= 4.8 | 1 |
| 29 | SS-6110810-TP | SCREW 11/64-40 L=8 | 2 |
| 30 | SS-4090515-SP | SCREW 9/64-40 L=5 | 2 |
| 31 | SS-7111120-TP | SCREW | 1 |
| 32 | SS-6151812-TP | SCREW 15/64-28 L=18 | 1 |
| 33 | NS-6120310-SP | NUT 3/16-28 | 1 |
| 34 | WP-0651056-SD | WASHER 6.5X11X1 | 1 |
| D3112-L4B-E00 | TAKE-UP SPRING (HEAVY) | (1) |
Page 17 — 7. TENSION RELEASE & THREAD TRIMMER MECHANISM COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-08401 | CAM FOLLOWER STOPPER | 1 |
| 2 | 141-08500 | SOLENOID ARM | 1 |
| 3 | 141-08609 | CONNECTING ROD | 1 |
| 4 | 141-08708 | CONNECTING BAR | 1 |
| 5 | 141-08955 | THREAD TRIMMING SOLENOID ASM. | 1 |
| 6 | 141-08807 | SOLENOID INSTALLING BASE | (1) |
| 7 | 141-08906 | SOLENOID FOR THREAD TRIMMING | (1) |
| 8 | 110-43304 | SOLENOID RUBBER | (1) |
| 9 | NS-6660410-SH | NUT | (1) |
| 10 | NW-6040000-SN | NUT M4 | (2) |
| 11 | NS-6660430-SP | NUT 1/4-40 | (1) |
| 12 | WP-0450000-SD | WASHER 4.5X8X0.5 | (2) |
| 13 | HK-0346100-20 | 2-POLE NYLON PLUG | (1) |
| 14 | HK-0346400-00 | PIN CONTACT | (2) |
| 15 | B1652-704-000 | SPRING | (1) |
| 16 | 141-09300 | THREAD TRIM LINK SPRING | 1 |
| 17 | B2401-210-D00 | THREAD TRIMMER CAM | 1 |
| 18 | B2408-210-D00 | THREAD TRIMMER SHAFT | 1 |
| 19 | SM-8053002-TP | SCREW M5 L=30 | 1 |
| 20 | 110-43007 | SOLENOID PIN | 1 |
| 21 | 135-15507 | NEEDLE PLATE | 1 |
| 22 | B1223-771-000 | NEEDLE ROD CRANK WASHER | 1 |
| 23 | B1116-804-000 | CLOTH PLATE WASHER | 1 |
| 24 | B1649-161-000 | TENSION SPRING ADJUSTING SCREW | 1 |
| 25 | B2411-210-000 | THREAD TRIMMER LINK | 1 |
| 26 | B2414-280-0A0 | THREAD CUTTER LEVER ASM., LARG | 1 |
| 27 | B2415-280-0A0 | THREAD CUTTER LEVER ASM., SMAL | 1 |
| 28 | B2416-280-000 | THREAD CUTTING LEVER RING | 1 |
| 29 | B2417-280-000 | THREAD CUTTER LEVER SHAFT | 1 |
| 30 | B2418-280-000 | MOVING KNIFE LINK | 1 |
| 31 | B2421-280-0A0 | MOVING KNIFE ASM. | 1 |
| 32 | B2423-280-00A | MOVING KNIFE WASHER A | 1 |
| 33 | B2423-280-00B | MOVING KNIFE WASHER B | 1 |
| 34 | B2423-280-00C | MOVING KNIFE WASHER C | 1 |
| 35 | B2423-280-00D | MOVING KNIFE WASHER D | 1 |
| 36 | B2423-280-00E | MOVING KNIFE WASHER E | 1 |
| 37 | B2424-280-000 | FIXING KNIFE | 1 |
| 38 | D2587-L8W-B00 | ROLLER | 1 |
| 39 | D2588-L8W-B00 | ROLLER SHAFT | 1 |
| 40 | NM-6050001-SP | NUT M5 | 1 |
| 41 | NS-6110420-SP | NUT 11/64-40 | 1 |
| 42 | NS-6110420-SP | NUT 11/64-40 | 2 |
| 43 | NS-6120310-SP | NUT 3/16-28 | 1 |
| 44 | RE-0500000-KO | E-RING | 1 |
| 45 | WP-0501016-SD | WASHER 5X10.5X1 | 1 |
| 46 | SD-0500091-TP | HINGE SCREW D= 5.0 H= 0.9 | 1 |
| 47 | SD-0500803-TP | HINGE SCREW D=5 H=8 | 2 |
| 48 | SD-0650305-TP | HINGE SCREW D= 6.5 H= 3 | 1 |
| 49 | SD-0790311-TP | HINGE SCREW D= 7.94 H= 3.1 | 1 |
| 50 | SD-1100301-TP | HINGE SCREW H=11 W=3 | 1 |
| 51 | SS-1060210-TP | SCREW 3/32-56 L=2.2 | 2 |
| 52 | SS-1110640-TP | SCREW 11/64-40 L= 5.5 | 4 |
| 53 | SS-6110430-TP | SCREW 11/64-40 L= 4.0 | 1 |
| 54 | SS-7110740-TP | SCREW 11/64-40 L=7 | 1 |
| 55 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 2 |
| 56 | SS-6120930-SP | SCREW 3/16-28 L=9 | 2 |
| 57 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | 2 |
| 58 | SS-7110740-TP | SCREW 11/64-40 L=7 | 1 |
| 59 | SS-8150822-TP | SCREW 15/64-28 L=8 | 1 |
| 60 | SS-8661012-TP | SCREW | 2 |
| 61 | WP-0450846-SP | WASHER | 1 |
| 62 | WP-0553216-SD | WASHER | 1 |
| 63 | B2426-280-000 | NEEDLE HOLE GUIDE | 1 |
| 64 | 141-09607 | NEEDLE HOLE GUIDE | 1 |
| 65 | D2426-282-C00 | NEEDLE HOLE GUIDE | 1 |
| 66 | 141-07601 | THREAD RELEASE ARM | 1 |
| 67 | B2312-210-D00 | TENSION RELEASE NOTCH | 1 |
| 68 | B1115-232-0A0 | FIRST THREAD TENSION ASM. | 1 |
| 69 | A3125-002-000 | TENSION NUT, NO.1 | (1) |
| 70 | B3126-012-000 | THREAD TENSION DISK | (2) |
| 71 | B3123-352-000 | THREAD TENSION ROD | (1) |
| 72 | B1115-232-000 | FIRST THREAD TENSION SPRING | (1) |
| 73 | 141-07809 | TENSION RELEASE ARM PIN | 1 |
| 74 | CS-080081B-SH | THRUST COLLAR ASM. D=8.0 W=8 | 1 |
| 75 | NS-6150310-SP | NUT 15/64-28 | 1 |
| 76 | SM-6040602-TP | SCREW M4 L=6 | 2 |
| 77 | B2617-771-000 | TRIPPING LEVER TENSION SPRING | 1 |
| 78 | 141-09250 | CAM FOLLOWER ASM. | 1 |
| NM-6040000-SN | NUT M4 | (2) | |
| BI115-232-0A0 | FIRST THREAD TENSION ASM. | (1) | |
| BI115-232-000 | FIRST THREAD RELEASE ARM PIN | (1) |
Page 19 — 8. FEED MECHANISM COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-10001 | CROSSFEED ARM | 1 |
| 01 | 141-16107 | FEED PLATE A | 1 |
| 2 | 141-10308 | CROSSFEED GEAR | 1 |
| 02 | 135-54803 | FEED PLATE B | 1 |
| 02 | 135-42015 | WORK CLAMP FOOT, RIGHT | 1 |
| 02 | 135-43012 | WORK CLAMP FOOT, LEFT | 1 |
| 3 | 141-10100 | LENGTHWISE FEED ARM | 1 |
| 03 | 135-17206 | FEED PLATE | 1 |
| 03 | 135-48102 | WORK CLAMP FOOT, RIGHT | 1 |
| 03 | 135-48201 | WORK CLAMP FOOT, LEFT | 1 |
| 03 | 135-48300 | FINGER GUARD | 1 |
| 4 | 141-10209 | LENGTHWISE FEED SHAFT | 1 |
| 04 | B2557-280-00A | WASHER FOR DRIVING ARM | 2 |
| 04 | B2557-280-00B | WASHER | 2 |
| 04 | B2557-280-00C | WASHER D | 2 |
| 04 | B2557-280-00D | WASHER | 2 |
| 04 | B2557-280-00E | WASHER | 2 |
| 5 | 141-10407 | LENGTHWISE FEED GEAR | 1 |
| 05 | 141-16404 | FEED PLATE D | 1 |
| 06 | 135-18600 | WORK CLAMP FOOT, RIGHT | 1 |
| 06 | 135-18709 | WORK CLAMP FOOT, LEFT | 1 |
| 07 | 141-16800 | FEED PLATE H | 1 |
| 08 | 135-33104 | FINGER GUARDE | 1 |
| 141-12304 | X FEED STEPPING MOTOR | 1 | |
| 141-12403 | Y FEED STEPPING MOTOR | 1 | |
| 141-11504 | CROSSFEED SENSOR SLIT | 1 | |
| 141-11702 | SENSOR INSTALLING BASE | 1 | |
| 141-36402 | LENGTHWISE FEED SENSOR SLIT | 1 | |
| 141-11801 | SENSOR INSTALLING BASE | 1 | |
| 141-10704 | CLOTH FEED SUPPORT PLATE | 1 | |
| 141-10811 | CLOTH FEED PLATE | 1 | |
| B1414-232-000 | SQUARE BLOCK | 1 | |
| B2509-704-000 | BUSHING, REAR | 2 | |
| 135-17404 | HINGE STUD | 1 | |
| 135-62400 | CLOTH FEED PRESSER PLATE | 1 | |
| 135-18907 | SUPPORT PLATE | 1 | |
| 135-16208 | FEED DRIVING ARM SHAFT | 7 | |
| B2548-280-000 | BALL RETAINER | 2 | |
| B2549-280-000 | WORK CLAMP FOOT MOUNTING BASE | 2 | |
| RE-0700000-KO | E-RING | 7 | |
| SS-2110930-SP | SCREW 11/64-40 L=8.75 | 5 | |
| SS-8150510-TP | SCREW 15/64-28 L=4.7 | 1 | |
| SS-7110740-TP | SCREW 11/64-40 L=7 | 4 | |
| 135-17800 | FEED BRACKET | 1 | |
| 135-17909 | LIFTING LEVER, RIGHT | 1 | |
| 135-18006 | LIFTING LEVER, LEFT | 1 | |
| 135-18105 | LIFTING LEVER SHAFT | 1 | |
| 135-18501 | SPRING SUSPENSION | 1 | |
| 135-18808 | WORK CLAMP FOOT FACE PLATE | 2 | |
| 135-18352 | WORK CLAMP FOOT, RIGHT | 1 | |
| 141-05407 | CLOTH PRESSER SPRING | 2 | |
| SM-8060612-TP | SCREW M6 L=6 | 2 | |
| SS-8660612-TP | SCREW 1/4-40 L=6 | 2 | |
| HD-0019300-00 | PHOTO SENSOR | 1 | |
| HD-0005700-0A | PHOTO SENSOR | 1 | |
| SL-4041291-SC | SCREW M4 L=12 | 1 | |
| SS-4031291-SC | SCREW 11/64-40 L=7 | 2 | |
| SS-4110715-SP | SCREW 11/64-40 L=7 | 1 | |
| SS-6111140-SP | SCREW 11/64-40 L=11 | 1 | |
| SM-6061802-TP | SCREW M6 L=18 | 1 | |
| SS-6110610-TP | SCREW 11/64-40 L=6 | 3 | |
| SS-2110920-TP | SCREW 11/64-40 L=8.5 | 2 | |
| SM-3061052-TP | SCREW M6 L=10 | 1 | |
| SS-6110480-SP | SCREW 11/64-40 L=4.3 | 6 | |
| SS-6110420-TP | SCREW 11/64-40 L=4.8 | 1 | |
| SS-6151142-TP | SCREW 15/64-28 L=10.5 | 1 | |
| SS-6151220-SP | SCREW 15/64-28 L=11.5 | 2 | |
| SS-8080310-TP | SCREW 1/8-44 L=2.8 | 1 | |
| WP-0621016-SD | WASHER 6.2X13X1 | 1 | |
| WP-0650876-SD | WASHER 6.5X13X0.8 | 1 | |
| RO-0691801-00 | RUBBER RING | 1 | |
| CS-0950817-SH | THRUST COLLAR ASM. D=9.53 W=8 | 1 | |
| SS-8110410-TP | SCREW 11/64-40 L=3.5 | (2) | |
| 141-12502 | RUBBER WASHER | (2) |
Page 21 — 9. LUBRICATION COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-14102 | OIL SHIELD | 1 |
| 2 | 141-14201 | OIL SHIELD | 1 |
| 3 | 141-14300 | OIL FELT | 1 |
| 4 | 141-14409 | FELT PRESSER | 1 |
| 5 | SS-4110515-SP | SCREW 11/64-40 L=5 | 2 |
| 6 | SS-6120930-SP | SCREW 3/16-28 L=9 | 1 |
| 7 | B3509-210-D00 | OIL FELT | 1 |
| 8 | 135-29003 | ONCE THROUGH OIL FELT | 0.56 |
| 9 | B3509-220-000 | OIL SPONGE | 1 |
| 10 | B3501-210-000 | OIL GAUGE | 2 |
| 11 | B1419-026-000 | OIL WICK PRESSER | 3 |
| 12 | B3506-280-000 | OIL WICK PRESSER | 1 |
| 13 | 141-14607 | FACE FELT | 1 |
| 14 | SS-4110715-SP | SCREW 11/64-40 L=7 | 2 |
| 15 | CQ-2000000-00 | OIL WICK | 1.8 |
| 16 | B3508-280-000 | BALANCE LUBRICATING PLATE | 1 |
| 17 | B3509-280-000 | NEEDLE ROD CRANK LUBRICATING | 1 |
| 18 | B3518-280-000 | BALANCE LUBRICATING | 1 |
| 19 | BP-3000001-00 | VINYL TUBE | 0.7 |
| 20 | BP-6000000-00 | VINYL PIPE | 0.72 |
| 21 | CQ-2522000-00 | OIL WICK | 1.6 |
| 22 | EA-9500B01-00 | CABLE BAND | 2 |
| 23 | SS-4110715-SP | SCREW 11/64-40 L=7 | 2 |
| 24 | SS-6092120-SP | SCREW 9/64-40 L=21.2 | 1 |
| 25 | CQ-2020000-00 | OIL WICK | 1.06 |
Page 22 — 10. SENSOR & EXTENSION CABLE COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-15752 | X SENSOR CABLE ASM. | 1 |
| 2 | 141-15257 | Y SENSOR CABLE ASM. | 1 |
| 3 | 141-15364 | UPPER SHAFT SENSOR CABLE ASM. | 1 |
| 4 | 141-15554 | HEAD GROUND CABLE A ASM. | 1 |
| 5 | 141-15653 | HEAD GROUND CABLE B ASM. | 1 |
| 6 | 141-15455 | OUTER PRESSER SENSOR CABLE ASM | 1 |
| 7 | EA-9500B01-00 | CABLE BAND | 1 |
| 8 | SS-4110515-SP | SCREW 11/64-40 L=5 | 3 |
| 9 | HX-0015000-0G | CABLE CLIP | 1 |
| 10 | SS-4110715-SP | SCREW 11/64-40 L=7 | 3 |
| 11 | HX-0015000-0K | CABLE CLIP | 1 |
| 12 | HX-0015000-0H | CABLE CLIP | 1 |
| 13 | M8598-590-0A0 | EXTENSION CABLE COMPL. ASM. | 1 |
| 14 | M9047-590-0A0 | SENSOR EXTENION CABLE ASM. | (1) |
| 15 | M9041-590-0A0 | EXTENION CABLE ASM. | (1) |
| 16 | M9042-590-0A0 | EXTENION CABLE ASM. | (1) |
| 17 | M9043-590-0A0 | SOLENOID EXTENION CABLE ASM. | (1) |
| 18 | M9640-510-00A | CABLE CLIP | (1) |
| 19 | SK-3382001-SE | SCREW D=3.8 L=20 | (2) |
| 20 | M9044-590-0A0 | SENSOR EXTENION CABLE ASM. | (1) |
Page 23 — 11. THREAD STAND COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 229-30358 | THREAD STAND ASM. | 1 |
| 2 | 229-31109 | SPOOL RETAINER | (2) |
| 3 | 229-31000 | SPOOL PIN | (2) |
| 4 | 229-30903 | SPOOL REST CUSHION | (2) |
| 5 | 229-30804 | SPOOL REST | (2) |
| 6 | SM-6061610-SC | SCREW M6 L=16 | (2) |
| 7 | 229-30705 | THREAD GUIDE ARM JOINT | (2) |
| 8 | 229-31406 | SPOOL REST ROD RUBBER CAP | (1) |
| 9 | 229-30507 | SPOOL REST ARM | (2) |
| 10 | 229-30408 | SPOOL REST ROD, UPPER | (1) |
| 11 | 229-31307 | SPOOL REST ROD JOINT | (1) |
| 12 | SM-4051405-SE | SCREW M5 L=14 | (2) |
| 13 | NM-6050001-SE | NUT M5 | (2) |
| 14 | 229-30309 | SPOOL REST ROD, LOWER | (1) |
| 15 | 229-31208 | THREAD GUIDE | (2) |
| 16 | WS-0510002-KN | SPRING WASHER | (2) |
| 17 | NM-6050001-SE | NUT M5 | (2) |
| 18 | NM-6160511-SE | NUT M16X1.5 | (1) |
| 19 | WP-1702600-SO | WASHER 17X30X2.6 | (2) |
Page 25 — 12. CONTROL BOX COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | M8601-590-AAO | MAIN CIRCUIT BOARD ASM., A | 1 |
| 2 | M8910-590-0AO | THERMOSTAT ASM. | (1) |
| 3 | M8604-590-0AO | POWER CIRCUIT BOARD ASM. | 1 |
| 4 | M8604-590-AAO | POWER CIRCUIT BOARD ASM., A | 1 |
| 5 | M1001-590-000 | CONTROL BOX | 1 |
| 6 | M1002-580-0AO | CONTROL BOX COVER ASM. | 1 |
| 7 | M1003-590-000 | CONTROL BOX PANEL | 1 |
| 8 | M3003-590-00A | SEAL A | 1 |
| 9 | M3002-580-00B | SEAL B | 1 |
| 10 | M8540-590-0AO | FAN ASM. | 1 |
| 11 | M8901-590-AAO-A | POWER TRANSFORMER A ASM. | 1 |
| 12 | M8901-590-BAO-A | POWER TRANSFORMER B ASM. | 1 |
| 13 | 178-45009 | CORD FITTING PLATE | 1 |
| 14 | CM-2001000-01 | PE MARK LABEL | 1 |
| 15 | CM-3001000-01 | LABEL | 1 |
| 16 | E9567-319-000 | EARTH MARK | 1 |
| 17 | E9609-603-000 | STICKER (LARGE) | 2 |
| 18 | EA-9500B01-00 | CABLE BAND | 1 |
| 19 | HK-0266500-80 | TERMINAL BASE 8P | 1 |
| 20 | HK-0542500-40 | TERMINAL BASE | 2 |
| 21 | HM-0008600-10 | FAN FILTER | 1 |
| 22 | HX-0005600-0B | SPACER | 4 |
| 23 | HX-0014700-0C | SPACER | 4 |
| 24 | HX-0040700-00 | BUSH | 1 |
| 25 | HX-0041000-00 | BUSH | 1 |
| 26 | HA-0042500-00 | SWITCH | 1 |
| 27 | NM-3034000-SF | FLANGE NUT | 4 |
| 28 | NM-6030003-SC | NUT M3 | 2 |
| 29 | SL-4030681-SF | SCREW M3 L=6 | 4 |
| 30 | SL-4030891-SC | SCREW M3X8 | 4 |
| 31 | SL-4040881-SF | SCREW M4 L=8 | 4 |
| 32 | SL-4041091-SC | SCREW M4 L=10 | 7 |
| 33 | SL-4041081-SF | SCREW M4 L=10 | 2 |
| 34 | SM-4031851-SR | SCREW | 4 |
| 35 | WS-0310702-KS | SPRING WASHER | 4 |
| 36 | SL-4040681-SC | COMBINATION SCREW M4 X 8 | 4 |
| 37 | SL-4041091-SC | SCREW M4 L=10 | 2 |
| 38 | SL-4041091-SC | SCREW M4 L=10 | 6 |
| 39 | SL-4051091-SC | SCREW M5X0.8 L=10 | 4 |
| 40 | SM-1033501-SC | SCREW M3X0.5 L=35 | 2 |
| 41 | HX-0012300-0B | CABLE CLIP | 1 |
| 42 | SK-3482001-SE | WOOD SCREW D=4.8 L=20 | 2 |
| 43 | CM-3001001-01 | DANGER LABEL (SMALL) | 1 |
| 44 | G6705-152-U0A | LABEL | 1 |
| 45 | SM-3065052-TC | SCREW | 4 |
| 46 | WP-0651001-SC | WASHER | 4 |
| 47 | WS-0610002-KN | SPRING WASHER 6.1X12.2X1.5 | 4 |
| 48 | NM-6060001-SE | NUT M6 | 4 |
| 49 | M8602-590-AAO | SERVO CIRCUIT BOARD ASM., A | 1 |
Page 27 — 13. OPERATION BOX & PEDAL COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | M8510-590-AAO | OPERATION BOX A ASM. | 1 |
| 2 | M8510-590-BAO | OPERATION BOX B ASM. | 1 |
| 3 | M8606-590-0AO | OPERATION CIRCUIT BOARD ASM. | (1) |
| 4 | M3002-590-00A | OPERATION PANEL SHEET(JAPAN) | (1) |
| 5 | M3002-590-00B | OPERATION PANEL SHEET(ENG) | (1) |
| 6 | M1010-590-000 | OPERATION BOX A | (1) |
| 7 | M1011-590-000 | OPERATION BOX B | (1) |
| 8 | M1012-590-000 | OPERATION PANEL PLATE | (1) |
| 9 | SL-4030881-SF | SCREW M3 L=8 | (4) |
| 10 | ST-4031611-OR | TAPPING SCREW D=3 L=16 | (4) |
| 11 | EA-9502B05-00 | CABLE CLIP | (1) |
| 12 | SV-4031006-SR | SCREW M3 L=10 | (1) |
| 13 | SK-3382001-SE | SCREW D=3.8 L=20 | 4 |
| 14 | SK-3482001-SE | WOOD SCREW D=4.8 L=20 | 2 |
| 15 | M8599-590-0AO | ACCESSORIES PART ASM. | 1 |
| 16 | M8599-590-AA0 | ACCESSORIES PART A ASM. | 1 |
| 17 | HF-0013010-00 | TIMING LAG FUSE | (1) |
| 18 | HF-0041080-PO | FUSE 8A | (1) |
| 19 | E8523-304-000 | FUSE 10A | (1) |
| 20 | M3004-511-00A | VOLTAGE INDICATION CARD,A | (1) |
| 21 | M3003-580-000 | VOLTAGE INDICATION CARD,B | (1) |
| 22 | M8520-590-0AO | 1-PEDAL ASM. | 1 |
| 23 | M1030-590-000 | PEDAL SWITCH FRAME | (1) |
| 24 | M1031-590-000 | PEDAL SWITCH LEVER | (1) |
| 25 | M9011-590-0AO-A | PEDAL SWITCH CABLE ASM. | (1) |
| 26 | HD-0019300-00 | PHOTO SENSOR | (2) |
| 27 | HX-0012300-00 | CABLE CLIP | (1) |
| 28 | B2583-210-D00 | SPRING | (1) |
| 29 | SD-0800331-TH | HINGE SCREW D=8 H=3.25 | (1) |
| 30 | SM-4040601-SC | SCREW M4X0.7 L=6 | (1) |
| 31 | SL-4041291-SC | SCREW M4 L=12 | (2) |
| 32 | WP-0430801-SC | WASHER 4.3X9X0.8 | (1) |
| 33 | M9013-590-0AO | PK57 TRANSFER CABLE ASM. | 1 |
| 34 | M8520-580-0AO | 2-PEDAL ASM. | 1 |
| 35 | M9012-590-0AO | PEDAL SWITCH CHANGE CABLE ASM. | 1 |
| 36 | GPK-570010B0 | PEDAL SWITCH ASM. | 1 |
| 37 | E9607-603-000 | STICKER (SMALL) | 2 |
| EK-0012300-00 | CABLE CLIP | (1) | |
| B2582-210-000 | SPRING | (1) | |
| GPK-57001080 | PEDAL SWITCH ASM. | 1 |
Page 29
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | M9001-590-0A0 | MAIN POWER CORD ASM. | 1 |
| 2 | M9003-590-0A0 | SERVO MOTOR CABLE ASM. | 1 |
| 3 | M9004-590-0A0 | ENCODER CONNECTING CABLE ASM. | 1 |
| 4 | M9008-580-0A0 | SERVO SIGNAL CORD ASM. | 1 |
| 5 | M9020-580-0A0 | TRANSFORMER POWER CORD ASM. | 1 |
| 6 | M9020-580-AA0 | TRANSFORMER POWER CORD ASM.,A | 1 |
| 7 | M9022-590-0A0 | POWER CORD ASM. | 1 |
| 8 | M9023-590-0A0 | POWER CORD A ASM. | 1 |
| 9 | M9002-580-0A0 | SERVO POWER CORD ASM.,B | 1 |
| 10 | M9031-590-0A0 | SERVO POWER CORD ASM.,A | 1 |
| 11 | M8520-590-0A0 | 1-PEDAL ASM. | 1 |
| 12 | M9017-580-0A0 | POWER CABLE ASM. | 1 |
| 13 | M9028-580-0A0 | POWER CABLE ASM. | 1 |
| 14 | M9024-580-0A0 | POWER CABLE ASM.,100V | 1 |
| 15 | M9021-580-0A0 | VOLTAGE TRANSFER CORD ASM. | 1 |
| 16 | HA-0042500-00 | SWITCH | 1 |
| 17 | HA-0030300-0A | SWITCH | 1 |
| 18 | M8520-580-0A0 | 2-PEDAL ASM. | 1 |
| 19 | M9012-590-0A0 | PEDAL SWITCH CHANGE CABLE ASM. | 1 |
| 20 | GPK-570010B0 | PEDAL SWITCH ASM. | 1 |
| 21 | M9013-590-0A0 | PK57 TRANSFER CABLE ASM. | 1 |
| 22 | M9035-580-0A0 | POWER SOURCE CORD ASM. | 1 |
| 23 | M9034-580-0A0 | GROUND CORD ASM. | 1 |
| 24 | M8597-590-0A0 | CABLE WHOLE ASM. | 1 |
| 25 | M9051-590-0A0 | CABLE ASM. | (1) |
| 26 | M9052-590-0A0 | CABLE ASM. | (1) |
Page 31 — 15. ACCESSORIE PART COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 135-51254 | SAFETY PLATE ASM. | 1 |
| 2 | 135-51205 | SAFETY PLATE INSTALLING BASE | (1) |
| 3 | B3120-372-000 | SAFETY PLATE | (1) |
| 4 | B3121-372-000 | SAFETY PLATE INSTALLING PLATE | (1) |
| 5 | 139-43204 | SAFETY PLATE RETURN SPRING | (1) |
| 6 | PS-0200062-KH | SPRING PIN 2X6 | (1) |
| 7 | SS-4110715-SP | SCREW 11/64-40 L=7 | (2) |
| 8 | SS-4110715-SP | SCREW 11/64-40 L=7 | (2) |
| 9 | NS-6110310-SP | NUT 11/64-40 | (1) |
| 10 | WP-0450801-SD | WASHER 4.5X10X0.8 | (2) |
| 11 | SD-0601021-SP | HINGE SCREW D=6 H=10.2 | (1) |
| 12 | B1506-352-000 | TENSION SPRING RACK B | (1) |
| 13 | NS-6120310-SP | NUT 3/16-28 | (1) |
| 14 | WP-0740516-SP | WASHER 7.4X11.8X0.5 | (1) |
| 15 | 138-12102 | BOBBIN | 1 |
| 16 | B8202-205-000 | OIL MANAGEMENT | 1 |
| 17 | B9101-552-000 | ACCESSORY BOX | 1 |
| 18 | B9109-555-000 | SCREW DRIVER, LARGE | 1 |
| 19 | B9110-012-000 | SCREW DRIVER, MIDDLE | 1 |
| 20 | B9111-012-000 | SCREW DRIVER, SMALL | 1 |
| 21 | B9113-012-000 | WRENCH (9X10) | 1 |
| 22 | B9121-012-000 | OIL CAN | 1 |
| 23 | B9140-372-000 | HEXAGONAL WRENCH, SMALL | 1 |
| 24 | B9141-372-000 | HEXAGONAL WRENCH, LARGE | 1 |
| 25 | GCT-02906000 | HEXAGONAL SPANNER | 1 |
| 26 | B9121-220-0A0 | OILER (CONTAINING NO.2 OIL) | 1 |
| 27 | MDP-500B1402 | NEEDLE DPX5#14-2 | 1 |
| 28 | MDP-500B1602 | NEEDLE DPX5#16-2 | 1 |
| 29 | MDP-170B1902 | NEEDLE DPX17#19-2 | 1 |
| 30 | MDP-500B1102 | DPX5#11-2 | 1 |
| 31 | SK-3311601-SE | WOOD SCREW D=3.1 L=16 | 4 |
| 32 | B8103-980-000 | CHAIN | 1 |
| 33 | B8133-019-000 | S SHAPED HOOK | 2 |
| 34 | SM-6067552-TP | HEXAGONAL-HOLE BOLT M6 L=75 | 1 |
| 35 | NM-6060001-SC | NUT M6 | 1 |
| 36 | WP-0651646-SC | WASHER | 1 |
| 37 | 141-06553 | AIR REGULATOR ASM. | 1 |
| 38 | 138-60408 | REGULATOR BRACKET | (1) |
| 39 | 141-06561 | AIR REGULATOR A ASM. | (1) |
| 40 | SM-6051202-TP | SCREW M5X0.8 L=12 | (2) |
| 41 | NM-6050001-SP | NUT M5 | (2) |
| 42 | WS-0510002-KN | SPRING WASHER | (2) |
| 43 | 141-06652 | SOLENOID VALVE ASM. | 1 |
| 44 | 141-06603 | PRESSER LIFTER SOLENOID VALVE | (1) |
| 45 | HK-0165101-20 | HOUSING 12P | (1) |
| 46 | HK-0165400-00 | RECEPTABLE CONTACT | (2) |
| 47 | 141-16909 | FEED PLATE I | 1 |
| 48 | 141-16503 | FEED PLATE E | 1 |
| 49 | 135-73407 | FINGER GUARD | 1 |
| 50 | 135-72003 | CLOTH PRESSER FOOT (LEFT) | 1 |
| 51 | BT-0600401-EB | TUBE | 2 |
| 52 | PB-0000100-00 | HOSE BAND | 1 |
| 53 | PJ-0325260-01 | HOSE NIPPLE | 1 |
| 54 | PJ-3090052-01 | PLUG | 1 |
| 55 | SK-3482001-SE | WOOD SCREW D=4.8 L=20 | 2 |
| 56 | SK-3311601-SE | WOOD SCREW D=3.1 L=16 | 2 |
| 57 | 135-71906 | CLOTH PRESSER FOOT (RIGHT) | 1 |
| 58 | B9118-232-000 | VINYL COVER | 1 |
| 59 | MAO-11532000 | CORD STAPLE | 7 |
| 60 | EA-9500B02-00 | CABLE BAND 150 | 2 |
| B9T2T-220-0A0 | OILER (CONTAINING NO.2 OIL) | (1) |
Page 33 — 16. OPTION COMPONENTS(1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 135-18659 | WORK CLAMP FOOT ASM. | 1 |
| 2 | 135-18600 | WORK CLAMP FOOT, RIGHT | (1) |
| 3 | 135-18709 | WORK CLAMP FOOT, LEFT | (1) |
| 4 | 135-48557 | WORK CLAMP FOOT ASM. | 1 |
| 5 | 135-48508 | WORK CLAMP FOOT, RIGHT | (1) |
| 6 | 135-48607 | WORK CLAMP FOOT, LEFT | (1) |
| 7 | 135-48151 | CLOTH PRESSER FOOT ASM. | 1 |
| 8 | 135-48102 | WORK CLAMP FOOT, RIGHT | (1) |
| 9 | 135-48201 | WORK CLAMP FOOT LEFT | (1) |
| 10 | 135-42451 | WORK CLAMP FOOT ASM. | 1 |
| 11 | 135-42402 | WORK CLAMP FOOT, RIGHT | (1) |
| 12 | 135-42501 | WORK CLAMP FOOT, LEFT | (1) |
| 13 | 135-42964 | PRESSER ASM. | 1 |
| 14 | 135-42915 | WORK CLAMP FOOT, RIGHT | (1) |
| 15 | 135-43012 | WORK CLAMP FOOT, LEFT | (1) |
| 16 | 135-71955 | WORK CLAMP FOOT ASM. | 1 |
| 17 | 135-71906 | CLOTH PRESSER FOOT (RIGHT) | (1) |
| 18 | 135-72003 | CLOTH PRESSER FOOT (LEFT) | (1) |
| 19 | 135-61360 | WORK CLAMP FOOT ASM. | 1 |
| 20 | 135-61352 | WORK CLAMP FOOT ASM.,RIGHT | (1) |
| 21 | 135-61303 | CLOTH PRESSER FOOT (RIGHT) | (1) |
| 22 | 135-62509 | PRESSER FOOT SLIDING PLATE (R) | (1) |
| 23 | SS-1110640-TP | SCREW 11/64-40 L= 5.5 | (1) |
| 24 | 135-61451 | WORK CLAMP FOOT ASM.,LEFT | (1) |
| 25 | 135-61402 | CLOTH PRESSER FOOT (LEFT) | (1) |
| 26 | 135-62608 | PRESSER FOOT SLIDING PLATE (L) | (1) |
| 27 | SS-1110640-TP | SCREW 11/64-40 L= 5.5 | (1) |
| 28 | 141-16107 | FEED PLATE A | 1 |
| 29 | 141-16404 | FEED PLATE D | 1 |
| 30 | 141-16305 | FEED PLATE C | 1 |
| 31 | 135-48003 | FEED PLATE | 1 |
| 32 | 135-54506 | FEED PLATE | 1 |
| 33 | 141-16602 | FEED PLATE F | 1 |
| 34 | 141-16206 | FEED PLATE B | 1 |
| 35 | 141-16503 | FEED PLATE E | 1 |
| 36 | 141-16701 | FEED PLATE G | 1 |
| 37 | 135-33104 | FINGER GUARDE | 1 |
| 38 | 135-48300 | FINGER GUARD | 1 |
| 39 | 135-73407 | FINGER GUARD | 1 |
| 40 | 141-20000 | FINGER GUARD | 1 |
| 41 | SS-8110310-SP | SCREW 11/64-40 L= 2.8 | 1 |
| 42 | B2426-280-000 | NEEDLE HOLE GUIDE | 1 |
| 43 | B2426-280-00B | NEEDLE HOLE GUIDE B | 1 |
| 44 | 141-09607 | NEEDLE HOLE GUIDE | 1 |
| 45 | D2426-282-C00 | NEEDLE HOLE GUIDE | 1 |
| 46 | D2426-MMC-K00 | NEEDLE HOLE GUIDE | 1 |
| 47 | 141-03253 | INNER HOOK PRESSER ASM., A | 1 |
| 48 | 141-03352 | INNER HOOK PRESSER ASM., B | 1 |
| 49 | 141-03659 | SHUTTLE RACE RING ASM.,C | 1 |
| 50 | B1817-210-DAD | SHUTTLE RACE RING ASM.,D | 1 |
| 51 | 141-20109 | FEED PLATE BLANK A | 1 |
| 52 | 141-20208 | FEED PLATE BLANK B | 1 |
| 53 | 141-20505 | FEED PLATE BLANK C | 1 |
| 54 | 141-20307 | FEED PLATE BLANK D | 1 |
| 55 | 141-20406 | FEED PLATE BLANK E | 1 |
| 56 | 141-21701 | CLOTH PRESSER BLANK,R(SURFACE) | 1 |
| 57 | 141-21800 | CLOTH PRESSER BLANK,L(SURFACE) | 1 |
| 58 | 141-21909 | CLOTH PRESSER BLANK,RIGHT | 1 |
| 59 | 141-22006 | CLOTH PRESSER BLANK,LEFT | 1 |
| 60 | 141-21263 | WORK CLAMP FOOT ASM. | 1 |
| 61 | 141-21255 | WORK CLAMP FOOT ASM.,RIGHT | (1) |
| 62 | 141-21354 | WORK CLAMP FOOT ASM.,LEFT | (1) |
| 63 | WS-0451040-KP | SPRING WASHER 4.5X8.5X1 | (2) |
| 64 | SS-7110710-SP | SCREW 11/64-40 L=7 | (2) |
| 65 | 141-16800 | FEED PLATE H | 1 |
| 66 | 141-16909 | FEED PLATE I | 1 |
| 67 | 135-54803 | FEED PLATE | 1 |
| 68 | 141-07155 | SOLENOIDE PLUNGER ASM. | 1 |
| 69 | 141-07106 | SOLENOIDE PLUNGER | (1) |
| 70 | 141-07205 | RUBBER PRESSER | (1) |
| 71 | RE-1500000-KO | E-SHAPED SNAP RING | (1) |
| 72 | 141-07304 | PRESSER RUBBER | 1 |
| 135-48507 | WORK CLAMP FOOT, LEFT | (1) | |
| D2426-282-K00 | NEEDLE HOLE GUIDE | 1 |
Page 35 — 17. OPTION COMPONENTS(2)(FOR LK-1900,1901,1902)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-22550 | MAGNET WIPER ASM. | 1 |
| 2 | SS-6111010-TP | SCREW 11/64-40 L= 9.5 | (2) |
| 3 | B2102-205-00A | WIPER ARM | (1) |
| 4 | SS-7111120-SP | SCREW 11/64-40 L=10.5 | (1) |
| 5 | 141-47607 | WIPER LINK | (1) |
| 6 | SD-0600181-TP | HINGE SCREW | (2) |
| 7 | 141-47508 | WIPER | (1) |
| 8 | 141-47805 | SPRING | (1) |
| 9 | SS-7060310-SP | SCREW 3/32-56 L=3 | (2) |
| 10 | NS-6110310-SP | NUT 11/64-40 | (1) |
| 11 | TA-1250705-RO | RUBBER PLUG | (1) |
| 12 | HX-0012300-0C | CABLE CLIP | (3) |
| 13 | SS-4110615-SP | SCREW 11/64-40 L=6 | (3) |
| 14 | 141-42251 | SOLENOID RELAY CABLE ASM. | (1) |
| 15 | 141-47755 | SOLENOID FOR WIPER ASM. | (1) |
| 16 | 138-64509 | SOLENOID FITTING PLATE | (1) |
| 17 | WP-0450801-SD | WASHER 4.5X10X0.8 | (2) |
| 18 | WS-0451040-KP | SPRING WASHER 4.5X8.5X1 | (2) |
| 19 | SD-0640261-SP | HINGE SCREW D=3.65 H=2.6 | (1) |
| 20 | WZ-0640200-KP | WAVE WASHER | (1) |
| 21 | NS-6120310-SP | NUT 3/16-28 | (1) |
| 22 | NM-6040003-SC | NUT M4 | (2) |
| 23 | WS-0410002-KS | SPRING WASHER M4 | (2) |
Page 37 — 18. TABLE COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-17519 | UPRIGHT TABLE | 1 |
| 2 | 141-18053 | T-STAND COMPL. | 1 |
| 3 | 141-18152 | UPPER STAND ASM.,RIGHT | (1) |
| 4 | 141-18251 | STAND ASM.,RIGHT | (1) |
| 5 | B8101-210-AAB | UPPER STAND ASM. | (1) |
| 6 | B8105-210-AAA | STAND ASM. | (1) |
| 7 | 111-58300 | STAND SIDE SUPPORT | (1) |
| 8 | 111-58409 | STAND SIDE SUPPORT | (1) |
| 9 | 111-58607 | RUBBER CAP | (4) |
| 10 | 170-07402 | NUT | (2) |
| 11 | 111-58516 | UPPER STAND PLATE | (2) |
| 12 | SL-9082091-SE | WASHER HEXAGONAL BOLT | (12) |
| 13 | 138-17754 | Z-STAND PEDAL ASM. | (1) |
| 14 | 111-59001 | PEDAL SHAFT BRACKET | (2) |
| 15 | B8153-771-000 | PEDAL CONNECTING ROD | (1) |
| 16 | D8113-555-B00 | PEDAL BUSHING | (2) |
| 17 | GPF-06080000 | PEDAL ADJUSTING PLATE | (1) |
| 18 | GPF-060600A0 | PEDAL ASM. | (1) |
| 19 | SM-9061203-SE | SCREW M6 L=12 | (2) |
| 20 | WP-0671016-SE | WASHER 6.7X13X1 | (2) |
| 21 | WS-0621210-KR | SPRING WASHER 6.2X11.4X1.2 | (2) |
| 22 | SM-9082023-SE | SCREW M8 L=20 | (2) |
| 23 | WP-0871602-SE | WASHER 8.7X18X1.6 | (4) |
| 24 | WS-0861410-KR | SPRING WASHER 8.6X15X1.4 | (2) |
| 25 | NM-6080721-SE | NUT M8 | (2) |
| 26 | B8108-555-0A0 | ADJUSTING SCREW ASM. WITH CAP | (4) |
| 27 | NM-6120001-SE | NUT M12 | (4) |
| 28 | WP-1302501-SE | WASHER M12 | (4) |
| 29 | WS-1253010-KN | SPRING WASHER 12.5X21.5X3 | (4) |
| 30 | 111-55108 | DRAWER | 1 |
| 31 | 111-55207 | DRAWER SUPPORT | 2 |
| 32 | D8204-555-D00 | DRAWER STOPPER | 1 |
| 33 | SK-3311601-SE | WOOD SCREW D=3.1 L=16 | 6 |
| 34 | SK-3513201-SE | WOOD SCREW D=5.1 L=32 | 4 |
Page 39 — 19. LK-1901SΔ : WORK CLAMP MECHANISM COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-40263 | PICK-UP DEVICE | 1 |
| 2 | 135-41602 | WORK CLAMP FOOT SPRING HOLDER | (1) |
| 3 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | (2) |
| 4 | D2529-232-D00 | PRESSER SPRING | (1) |
| 5 | D2528-232-D00 | SHAFT | (1) |
| 6 | D2527-232-D00 | SLEEVE | (1) |
| 7 | B3117-352-000 | THREAD TENSION POST NUT | (2) |
| 8 | 141-40255 | WORK CLAMP FOOT BRACKET COMPL. | (1) |
| 9 | 135-41404 | WORK CLAMP FOOT LIFTING PLATE | (1) |
| 10 | SS-9151120-CP | SCREW 15/64-28 L=11 | (2) |
| 11 | WP-0612516-SD | WASHER 6.1X15.2X2.5 | (2) |
| 12 | D2545-232-DOA | HINGE SCREW | (2) |
| 13 | D2545-232-DOB | HINGE SCREW | (2) |
| 14 | D2545-232-DOC | HINGE SCREW | (2) |
| 15 | 141-41055 | PULLING PLATE COMPL. | (1) |
| 16 | NS-6110530-SP | NUT 11/64-40 | (1) |
| 17 | 141-41105 | FIXING HOOK | (1) |
| 18 | D2512-232-D00 | TORSION SPRING | (1) |
| 19 | D2511-232-D00 | SCREW | (1) |
| 20 | 141-40354 | INSTALLING BASE COMPL. | (1) |
| 21 | 141-41402 | INSTALLING SHAFT | (1) |
| 22 | RE-0700000-KO | E-RING 7 | (2) |
| 23 | SS-9110920-CP | SCREW 11/64-40 L=9 | (1) |
| 24 | 141-40909 | ADJUSTING PLATE | (1) |
| 25 | D2515-232-D00 | TORSION SPRING | (1) |
| 26 | SS-7110510-SP | SCREW 11/64-40 L=5 | (2) |
| 27 | 135-41107 | WORK CLAMP FOOT SPRING HOLDER | (1) |
| 28 | 141-40552 | PICK-UP GUIDE COMPL. | (1) |
| 29 | SS-1110640-TP | SCREW 11/64-40 L=5.5 | (2) |
| 30 | D2520-232-DAO | WORK CLAMP FOOT(LEFT)ASM. | (1) |
| 31 | D2521-232-DAO | WORK CLAMP FOOT(RIGHT)ASM. | (1) |
| 32 | SD-0550271-TP | HINGE SCREW D= 5.50 H= 2.7 | (2) |
| 33 | 141-41204 | PLATE CAM | (1) |
| 34 | NS-6120480-SP | NUT 3/16-28 | (2) |
| 35 | 141-40750 | PREVENTING PLATE COMPL. | (1) |
| 36 | SS-9110460-CP | SCREW 11/64-40 L=4 | (2) |
| 37 | SM-9061403-CP | SCREW M6 L=14 | (1) |
| 38 | SM-6061202-TP | SCREW M6 L=12 | (1) |
| 39 | WP-0612516-SD | WASHER 6.1X15.2X2.5 | (2) |
| 40 | 141-40206 | PICK-UP INSTALLING BASE | (1) |
| 41 | 141-41501 | FINGER GUARD | (1) |
| 42 | SS-7090610-SP | SCREW 9/64-40 L=6 | (2) |
| 43 | 135-41503 | FEED PLATE | (1) |
| 44 | SS-9110460-CP | SCREW 11/64-40 L=4 | (1) |
| 45 | WP-0501016-SD | WASHER 5X10.5X1 | (1) |
| 46 | 135-41313 | CONNECTING ARM | 1 |
| 47 | SM-6061802-TP | SCREW M6 L=18 | 1 |
| 48 | SD-1201501-SP | HINGE SCREW D=12 H=15 | 1 |
| 49 | WP-0651056-SH | WASHER 6.5X11X1 | 1 |
| 50 | 135-40604 | DRIVING BAR B | 1 |
| 51 | PD-0201000-OB | SPLIT PIN | 1 |
| 52 | SS-7090850-SP | SCREW 9/64-40 L=8 | 2 |
| 53 | 135-17602 | FEED PLATE PRESSER PLATE | 1 |
| 54 | 100-87906 | TENTION SPRING | 1 |
Page 41 — 20. LK-1901:WORK CLAMP SOLENOID COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-41857 | SOLENOID FOR PICK-UP ASM. | 1 |
| 2 | 141-41758 | SOLENOID FOR PICK-UP COMPL. | (1) |
| 3 | HK-0346100-4A | HOUSING,BLUE 4P | (1) |
| 4 | HK-0346400-00 | PIN CONTACT | (2) |
| 5 | 141-41907 | SOLENOID INSTALLING BASE | (1) |
| 6 | SL-4030881-SC | SCREW M3X8 | (4) |
| 7 | TA-0550604-RO | RUBBER PLUG | (1) |
| 8 | 141-42103 | CONNECTING LINK GUIDE | 1 |
| 9 | SL-4030681-SC | SCREW M3 L=6 | 2 |
| 10 | B1657-506-E00 | SPRING | 1 |
| 11 | SS-4151215-SP | SCREW 15/64-28 L=12 | 3 |
| 12 | 141-42251 | SOLENOID RELAY CABLE ASM. | 1 |
| 13 | B3027-450-00B | PIN | 1 |
| 14 | RC-0410415-KP | C-RING | 2 |
| 15 | 141-42004 | WORK CLAMP CONNECTING LINK | 1 |
| 16 | RO-0442401-00 | RUBBER RING | 1 |
| 17 | 141-47003 | SOLENOID LINK | 1 |
| 18 | 141-47102 | CYLINDER KNUCKLE | 1 |
| 19 | 141-48407 | VERTICAL FEED SHAFT SPRING | 1 |
| 20 | 141-47359 | PRESSER LIFTING CYLINDER ASM. | 1 |
| 21 | PA-2502007-AO | AIR CYLINDER | (1) |
| 22 | PJ-3040605-02 | ELBOW UNION 6XM5 | (2) |
| 23 | 141-47201 | PRESSER LIFTER CYLINDER BASE | 1 |
| 24 | SM-6061602-TP | SCREW M6 L=16 | 2 |
Page 43 — 21. LK-1902SA
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | B1114-581-000 | THREAD GUIDE PLATE | 1 |
| 2 | 135-43764 | CLOTH FEED BASE ASM. | 1 |
| 3 | 135-44465 | CLOTH PRESSER FOOT ASM. | (1) |
| 4 | SS-2110930-SP | SCREW 11/64-40 L=8.7 | (4) |
| 5 | 135-44614 | CLOTH FEED BASE COVER | (1) |
| 6 | 135-43715 | CLOTH FEED BASE | (1) |
| 7 | B2539-280-000 | STUD | (1) |
| 8 | CS-087101B-SH | THRUST COLLAR ASM. D=8.73 W=10 | (1) |
| 9 | SS-8150822-TP | SCREW 15/64-28 L=8 | (2) |
| 10 | 135-43806 | BALL HOLDER | (1) |
| 11 | SS-7151210-SP | SCREW 15/64-28 L=12 | (1) |
| 12 | B2549-280-000 | WORK CLAMP FOOT MOUNTING BASE | (7) |
| 13 | B2548-280-000 | BALL RETAINER | (1) |
| 14 | SS-7110740-TP | SCREW 11/64-40 L=7 | (1) |
| 15 | 135-43905 | SPRING SUSPENSION | (1) |
| 16 | SS-6120940-SP | SCREW 3/16-28 L=9 | (2) |
| 17 | 135-44705 | SPRING | (1) |
| 18 | B3413-552-000 | SUSPENSION SCREW | (1) |
| 19 | 135-44051 | LIFTING LEVER ASM. | (1) |
| 20 | SS-8150822-TP | SCREW 15/64-28 L=8 | (2) |
| 21 | B1816-280-000 | GUIDE PIN | (2) |
| 22 | 141-44000 | LATERA INSTALLATION TYPE TABLE | 1 |
| 23 | 141-43002 | FEED PLATE | 1 |
| 24 | 100-87906 | TENTION SPRING | 1 |
| 25 | 137-86306 | THREAD GUIDE NO.1 | 1 |
| 26 | SS-4150915-SP | SCREW 15/64-28 L=9 | 1 |
| 27 | 141-18350 | T-STAND COMPL. | 1 |
| 28 | B8101-210-AAB | UPPER STAND ASM. | (2) |
| 29 | B8105-210-AAA | STAND ASM. | (2) |
| 30 | 111-58300 | STAND SIDE SUPPORT | (1) |
| 31 | 111-58409 | STAND SIDE SUPPORT | (1) |
| 32 | 111-58607 | RUBBER CAP | (4) |
| 33 | 170-07402 | NUT | (2) |
| 34 | 111-58516 | UPPER STAND PLATE | (2) |
| 35 | SL-9082091-SE | WASHER HEXAGONAL BOLT | (12) |
| 36 | 138-17754 | Z-STAND PEDAL ASM. | (1) |
| 37 | GPF-060600AO | PEDAL ASM. | (1) |
| 38 | GPF-06080000 | PEDAL ADJUSTING PLATE | (1) |
| 39 | 111-59001 | PEDAL SHAFT BRACKET | (2) |
| 40 | B8153-771-000 | PEDAL CONNECTING ROD | (1) |
| 41 | D8113-555-B00 | PEDAL BUSHING | (2) |
| 42 | SM-9061203-SE | SCREW M6 L=12 | (2) |
| 43 | WP-0671016-SE | WASHER 6.7X13X1 | (2) |
| 44 | WS-0621210-KR | SPRING WASHER 6.2X11.4X1.2 | (2) |
| 45 | SM-9082023-SE | SCREW M8 L=20 | (2) |
| 46 | WP-0871602-SE | WASHER 8.7X18X1.6 | (4) |
| 47 | WS-0861410-KR | SPRING WASHER 8.6X15X1.4 | (2) |
| 48 | NM-6080721-SE | NUT M8 | (2) |
| 49 | B8108-555-0AO | ADJUSTING SCREW ASM. WITH CAP | (4) |
| 50 | NM-6120001-SE | NUT M12 | (4) |
| 51 | WP-1302501-SE | WASHER M12 | (4) |
| 52 | WS-1253010-KN | SPRING WASHER 12.5X21.5X3 | (4) |
Page 45 — 22. LK-1902HΔ
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | D1401-L7V-V00 | NEEDLE BAR | 1 |
| 2 | D1405-L7A-M00 | NEEDLE BAR THREAD GUIDE | 1 |
| 3 | SS-7080510-TP | SCREW 1/8-44 L=4.5 | 1 |
| 4 | MDP-170B1900 | NEEDLE DPX17 #19 | 1 |
| 5 | 141-09607 | NEEDLE HOLE GUIDE | 1 |
| 6 | D2101-L7A-MAO | WIPER ASM. | 1 |
| 7 | D1818-282-N00 | SHUTTLE | 1 |
| 8 | 135-43764 | CLOTH FEED BASE ASM. | 1 |
| 9 | 135-44465 | CLOTH PRESSER FOOT ASM. | (1) |
| 10 | B1114-581-000 | THREAD GUIDE PLATE | 1 |
| 11 | 141-43002 | FEED PLATE | 1 |
| 12 | 141-44000 | LATERA INSTALLATION TYPE TABLE | 1 |
| 13 | 135-45660 | WORK CLAMP FOOT ASM. | 1 |
| 14 | 135-47161 | WORK CLAMP FOOT ASM. | 1 |
| 15 | 135-45504 | FEED PLATE | 1 |
| 16 | 135-45801 | FEED PLATE | 1 |
| 17 | 135-47005 | FEED PLATE | 1 |
| 18 | 135-46700 | CLOTH PRESSER PLATE | 1 |
| 19 | 135-48706 | CLOTH PRESSER LOWER PLATE | 1 |
| 20 | B2302-205-0A0 | TENSION CONTROLLER NO.2 ASM. | 1 |
| 21 | 100-87906 | TENTION SPRING | 1 |
| 22 | 141-03659 | SHUTTLE RACE RING ASM.,C | 1 |
| 23 | 137-86306 | THREAD GUIDE NO.1 | 1 |
| 24 | SS-4150915-SP | SCREW 15/64-28 L=9 | 1 |
Page 47
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | D1405-M7W-F00 | NEEDLE BAR THREAD GUIDE | 1 |
| 2 | SS-7080510-TP | SCREW 1/8-44 L=4.5 | 1 |
| 3 | D1901-L7V-VB0 | THREAD TAKE-UP LEVER ASM. | 1 |
| 4 | D1904-L7V-V00 | LINK TAKE-UP LEVER PIN, HEAVY | 1 |
| 5 | D1906-L7V-V00 | SET SCREW | 1 |
| 6 | D1401-L7V-V00 | NEEDLE BAR | 1 |
| 7 | MDP-170B1400 | NEEDLE DPX17 #14 | 1 |
| 8 | B2302-205-0A0 | TENSION CONTROLLER NO.2 ASM. | 1 |
| 9 | B1853-512-00E | HOOK SHAFT WASHER | 1 |
| 10 | B2619-372-000 | STOP MOTION TRIPPING LEVER CAM | 1 |
| 11 | SD-0791271-SP | HINGE SCREW D= 7.94 H=12.7 | 1 |
| 12 | 141-47003 | SOLENOID LINK | 1 |
| 13 | 141-47102 | CYLINDER KNUCKLE | 1 |
| 14 | 100-87906 | TENTION SPRING | 1 |
| 15 | 141-47359 | PRESSER LIFTING CYLINDER ASM. | 1 |
| 16 | PA-2502007-A0 | AIR CYLINDER | (1) |
| 17 | PJ-3040605-02 | ELBOW UNION 6XM5 | (2) |
| 18 | 141-47201 | PRESSER LIFTER CYLINDER BASE | 1 |
| 19 | SM-6061602-TP | SCREW M6 L=16 | 2 |
| 20 | 135-41313 | CONNECTING ARM | 1 |
| 21 | 141-47805 | SPRING | 1 |
| 22 | SS-7060310-SP | SCREW 3/32-56 L=3 | 2 |
| 23 | NS-6110310-SP | NUT 11/64-40 | 1 |
| 24 | TA-1250705-RO | RUBBER PLUG | 1 |
| 25 | HX-0012300-OC | CABLE CLIP | 3 |
| 26 | SS-4110615-SP | SCREW 11/64-40 L=6 | 3 |
| 27 | 141-42251 | SOLENOID RELAY CABLE ASM. | 1 |
| 28 | 141-47755 | SOLENOID FOR WIPER ASM. | 1 |
| 29 | NM-6040003-SC | NUT M4 | 2 |
| 30 | WS-0410002-KS | SPRING WASHER M4 | 2 |
| 31 | 138-64509 | SOLENOID FITTING PLATE | 1 |
| 32 | SS-6111010-TP | SCREW 11/64-40 L= 9.5 | 2 |
| 33 | B2102-205-00A | WIPER ARM | 1 |
| 34 | SS-7111120-SP | SCREW 11/64-40 L=10.5 | 1 |
| 35 | 141-47607 | WIPER LINK | 1 |
| 36 | WP-0280500-SC | WASHER | 1 |
| 37 | WP-0450801-SD | WASHER 4.5X10X0.8 | 2 |
| 38 | WS-0451040-KP | SPRING WASHER 4.5X8.5X1 | 2 |
| 39 | SD-0640261-SP | HINGE SCREW D=3.65 H=2.6 | 1 |
| 40 | WZ-0640200-KP | WAVE WASHER | 1 |
| 41 | NS-6120310-SP | NUT 3/16-28 | 1 |
| 42 | SD-0600181-TP | HINGE SCREW | 2 |
| 43 | 141-47508 | WIPER | 1 |
| 44 | 141-48407 | VERTICAL FEED SHAFT SPRING | 1 |
Page 49 — 26. LK-1903-301:BUTTON CLAMP COMPL. FOR SMALL-BUTTONS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-45106 | CLOTH FEED PLATE | 1 |
| 2 | 135-17602 | FEED PLATE PRESSER PLATE | 1 |
| 3 | MAZ-15501000 | GUIDE | 1 |
| 4 | MAZ-15502000 | PRESSURE PLATE | 1 |
| 5 | 141-45551 | SMALL CLAMP MECHANISM ASM. | 1 |
| 6 | 141-45650 | MEDIUM CLAMP MECHANISM ASM. | 1 |
| 7 | 141-45759 | LARGE CLAMP MECHANISM ASM. | 1 |
| 8 | 141-45858 | VERY SMALL CLAMP MECHANISM ASM | 1 |
| 9 | 141-46203 | PICK-UP FOOT INSTALLING BASE | (1) |
| 10 | 141-46104 | PICK-UP INSTALLING BASE | (1) |
| 11 | 141-41402 | INSTALLING SHAFT | (1) |
| 12 | RE-0700000-KO | E-RING 7 | (2) |
| 13 | 141-46302 | PICK-UP FOOT INSTALLING BASE | (1) |
| 14 | B2552-372-000 | BUTTON CLAMP SLIDE | (1) |
| 15 | 141-48852 | SMALL CLAMP JAW LEVER ASM.,R | (1) |
| 16 | MAZ-15507000 | SMALL CLAMP JAW LEVER ASM.,L | (1) |
| 17 | MAZ-15509000 | SPRING, RIGHT | (1) |
| 18 | 141-48803 | PLATE K, R | (1) |
| 19 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 20 | SS-2060310-SP | SCREW 3/32-56 L=3 | (1) |
| 21 | SD-0550301-SP | HINGE SCREW D=5.5 H=3 | (1) |
| 22 | SD-0640391-TP | HINGE SCREW D= 6.35 H= 3.9 | (2) |
| 23 | 141-48951 | SMALL CLAMP JAW LEVER ASM.,L | (1) |
| 24 | MAZ-15508000 | SMALL CLAMP JAW LEVER, L | (1) |
| 25 | 141-48902 | PLATE K, L | (1) |
| 26 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 27 | MAZ-15510000 | SPRING, LEFT | (1) |
| 28 | SS-2060310-SP | SCREW 3/32-56 L=3 | (1) |
| 29 | MAZ-15513000 | BUTTON CLAMP JAW LEVER SPRING | (1) |
| 30 | MAZ-15514000 | SUPPORT PLATE | (1) |
| 31 | MAZ-15515000 | SLIDE BLOCK | (1) |
| 32 | 141-46401 | PRESSER PLATE | (1) |
| 33 | 135-40901 | STATIONING BLOCK SHAFT | (1) |
| 34 | B2548-372-000 | SNAP FASTENER CLAMP STOP LEVER | (1) |
| 35 | B2549-372-000 | CLAMP SCREW A | (1) |
| 36 | B2553-372-000 | NUT | (1) |
| 37 | B2560-372-000 | BUTTON CLAMP STOP PIN | (2) |
| 38 | D2548-232-D00 | SNAP RING,FOR CONNECTING ROD | (1) |
| 39 | NS-6150310-SP | NUT 15/64-28 | (1) |
| 40 | SS-9110460-CP | SCREW 11/64-40 L=4 | (2) |
| 41 | SS-9621413-SP | SCREW 3/16-32 L=13.5 | (2) |
| 42 | D3130-M1Y-C00 | FINGER GUARD | (1) |
| 43 | SS-9151120-CP | SCREW 15/64-28 L=11 | 2 |
| 44 | WP-0612516-SD | WASHER 6.1X15.2X2.5 | 2 |
| 45 | 138-11906 | ACCEPT PLATE, UPPER | 1 |
| 46 | 138-12003 | PRESSURE SPRING | 1 |
| 47 | B3125-012-000 | THREAD TENSION NUT | 2 |
| 48 | D2527-232-D00 | SLEEVE | 1 |
| 49 | 141-46906 | ADJUSTING SHAFT | 1 |
| 50 | SS-7110840-SP | SCREW 11/64-40 L=7.8 | 2 |
| 51 | SS-9110543-CP | SCREW 11/64-40 L=5.3 | 1 |
| 52 | SM-6061202-TP | SCREW M6 L=12 | 1 |
| 53 | WP-0501016-SD | WASHER 5X10.5X1 | 1 |
| 54 | WP-0612516-SD | WASHER 6.1X15.2X2.5 | 1 |
| 55 | MAZ-15516000 | MOVING PLATE | 1 |
| 56 | TA-2100904-RO | RUBBER PLUG | 1 |
| 57 | SD-0550181-SP | HINGE SCREW D= 5.50 H= 1.8 | (1) |
| 58 | WP-0501016-SD | WASHER 5X10.5X1 | (2) |
| 59 | 141-49603 | NEEDLE HOLE GUIDE | 1 |
Page 51
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | MAZ-15601000 | GUIDE | 1 |
| 2 | MAZ-15602000 | PRESSURE PLATE | 1 |
| 3 | MAZ-155080B0 | SMALL CLAMP JAW LEVER ASM.,L | 1 |
| 4 | MAZ-155080A0 | SMALL CLAMP JAW LEVER ASM.,L | (1) |
| 5 | MAZ-15510000 | SPRING, LEFT | (1) |
| 6 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 7 | 141-49157 | MIDDLE CLAMP JAW LEVER ASM.,L | 1 |
| 8 | MAZ-15508000 | SMALL CLAMP JAW LEVER, L | (1) |
| 9 | MAZ-15510000 | SPRING, LEFT | (1) |
| 10 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 11 | 141-49108 | PLATE L, L | (1) |
| 12 | SS-2060310-SP | SCREW 3/32-56 L=3 | (1) |
| 13 | MAZ-155070B0 | SMALL CLAMP JAW LEVER ASM.,R | 1 |
| 14 | MAZ-155070A0 | SMALL CLAMP JAW LEVER ASM.,R | (1) |
| 15 | MAZ-15509000 | SPRING, RIGHT | (1) |
| 16 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 17 | 141-49058 | MIDDLE CLAMP JAW LEVER ASM.,R | 1 |
| 18 | MAZ-15507000 | SMALL CLAMP JAW LEVER ASM.,R | (1) |
| 19 | MAZ-15507000 | SMALL CLAMP JAW LEVER ASM.,L | (1) |
| 20 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 21 | 141-49009 | PLATE L, R | (1) |
| 22 | SS-2060310-SP | SCREW 3/32-56 L=3 | (1) |
| 23 | MAZ-15701000 | GUIDE | 1 |
| 24 | MAZ-15702000 | PRESSURE PLATE | 1 |
| 25 | MAZ-157070BB | LARGE CLAMP JAW LEVER ASM.,R | 1 |
| 26 | MAZ-157070BA | LARGE CLAMP JAW LEVER ASM.,R | 1 |
| 27 | MAZ-157070AA | LARGE CLAMP JAW LEVER ASM.,R | (1) |
| 28 | MAZ-157070AB | LARGE CLAMP JAW LEVER ASM.,R | (1) |
| 29 | MAZ-15709000 | SPRING,RIGHT | (1) |
| 30 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 31 | MAZ-15715000 | SPACER | 1 |
| 32 | MAZ-157080BA | LARGE CLAMP JAW LEVER ASM.,L | 1 |
| 33 | MAZ-157080BB | LARGE CLAMP JAW LEVER ASM.,L | 1 |
| 34 | MAZ-157080AA | LARGE CLAMP JAW LEVER ASM.,R | (1) |
| 35 | MAZ-157080AB | LARGE CLAMP JAW LEVER ASM.,R | (1) |
| 36 | MAZ-15710000 | SPRING,LEFT | (1) |
| 37 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 38 | MAZ-15715000 | SPACER | 1 |
| 39 | MAZ-158070BB | EXTRA SMALL CLAMP LEVER ASM.,R | 1 |
| 40 | MAZ-158070BA | EXTRA SMALL CLAMP LEVER ASM.,R | 1 |
| 41 | MAZ-158070AB | EXTRA SMALL CLAMP LEVER ASM.,L | (1) |
| 42 | MAZ-158070AA | EXTRA SMALL CLAMP LEVER ASM.,L | (1) |
| 43 | MAZ-15809000 | SPRING,RIGHT | (1) |
| 44 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 45 | MAZ-15801000 | GUIDE | 1 |
| 46 | MAZ-158080BB | EXTRA SMALL CLAMP LEVER ASM.,L | 1 |
| 47 | MAZ-158080BA | EXTRA SMALL CLAMP LEVER ASM.,L | 1 |
| 48 | MAZ-158080AB | EXTRA SMALL CLAMP LEVER ASM.,L | (1) |
| 49 | MAZ-158080AA | EXTRA SMALL CLAMP LEVER ASM.,L | (1) |
| 50 | MAZ-15810000 | SPRING,LEFT | (1) |
| 51 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 52 | 141-49900 | NEEDLE HOLE GUIDE | 1 |
| 53 | 141-48852 | SMALL CLAMP JAW LEVER ASM.,R | 1 |
| 54 | MAZ-15507000 | SMALL CLAMP JAW LEVER ASM.,L | (1) |
| 55 | MAZ-15509000 | SPRING, RIGHT | (1) |
| 56 | 141-48803 | PLATE K, R | (1) |
| 57 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 58 | SS-2060310-SP | SCREW 3/32-56 L=3 | (1) |
| 59 | 141-48951 | SMALL CLAMP JAW LEVER ASM.,L | 1 |
| 60 | MAZ-15508000 | SMALL CLAMP JAW LEVER, L | (1) |
| 61 | 141-48902 | PLATE K, L | (1) |
| 62 | SS-7090410-SP | SCREW 9/64-40 L= 3.5 | (1) |
| 63 | MAZ-15510000 | SPRING, LEFT | (1) |
| 64 | SS-2060310-SP | SCREW 3/32-56 L=3 | (1) |
Page 53 — 30. LK-1903-305:SHANK BUTTON CLAMP MECHANISM COMPONENTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-46054 | PICK-UP DEVICE COMPL. | 1 |
| 2 | SS-7110740-TP | SCREW 11/64-40 L=7 | (2) |
| 3 | MAZ-16012000 | LEVER SPRING HOOK | (1) |
| 4 | MAZ-16013000 | BUTTON SUPPORT LEVER SPRING | (1) |
| 5 | 141-46203 | PICK-UP FOOT INSTALLING BASE | (1) |
| 6 | 141-46104 | PICK-UP INSTALLING BASE | (1) |
| 7 | 141-41402 | INSTALLING SHAFT | (1) |
| 8 | RE-0700000-KO | E-RING 7 | (2) |
| 9 | MAZ-15515000 | SLIDE BLOCK | (1) |
| 10 | 141-46401 | PRESSER PLATE | (1) |
| 11 | MAZ-16014000 | BUTTON SUPPORT RELEASE LEVER | (1) |
| 12 | SS-7110740-TP | SCREW 11/64-40 L=7 | (1) |
| 13 | MAZ-16011000 | BUTTON SUPPORT LEVER SHAFT | (1) |
| 14 | SS-7110740-TP | SCREW 11/64-40 L=7 | (1) |
| 15 | MAZ-16004000 | BUTTON CLAMP BASE | (1) |
| 16 | SS-6111052-TP | SCREW | (1) |
| 17 | WP-0482086-SD | WASHER 4.8X11.5X2 | (1) |
| 18 | MAZ-16005000 | BUTTON CLAMP BASE | (1) |
| 19 | SS-7090510-SP | SCREW 9/64-40 L= 4.6 | (1) |
| 20 | CS-0640811-SP | THRUST COLLAR D=6.35 W=8 | (1) |
| 21 | SS-8110410-TP | SCREW 11/64-40 L= 3.5 | (1) |
| 22 | MAZ-16010000 | BUTTON SUPPORT LEVER | (1) |
| 23 | MAZ-160090A0 | BUTTON SUPPORT RUBBER ASM. | (1) |
| 24 | MAZ-16009000 | BUTTON SUPPORT RUBBER | (1) |
| 25 | B2406-372-000 | SHANK BUTTON HOLDING CLAMP | (1) |
| 26 | SS-7110740-TP | SCREW 11/64-40 L=7 | (1) |
| 27 | MAZ-16002000 | FEED PLATE | (1) |
| 28 | MAZ-1600300A | FEED PLATE, A | (1) |
| 29 | SS-6110480-SP | SCREW 11/64-40 L=4.3 | (1) |
| 30 | SS-9111010-SP | SCREW 11/64-40 L=9.5 | (1) |
| 31 | WP-0482086-SD | WASHER 4.8X11.5X2 | (1) |
| 32 | WP-0501016-SD | WASHER 5X10.5X1 | (2) |
| 33 | MAZ-15514000 | SUPPORT PLATE | (1) |
| 34 | 135-40901 | STATIONING BLOCK SHAFT | (1) |
| 35 | D2548-232-D00 | SNAP RING,FOR CONNECTING ROD | (1) |
| 36 | NS-6150310-SP | NUT 15/64-28 | (1) |
| 37 | SS-9110460-CP | SCREW 11/64-40 L=4 | (2) |
| 38 | SS-9621413-SP | SCREW 3/16-32 L=13.5 | (2) |
| 39 | MAZ-16022000 | BUTTON CLAMP SUPPORT, FRONT | (1) |
| 40 | MAZ-16023000 | BUTTON CLAMP SUPPORT, REAR | (1) |
| 41 | D1401-M1Y-C0A | NEEDLE BAR | 1 |
| 42 | 141-47904 | WIPER | 1 |
| 43 | 138-10908 | MOVING PLATE LINK A | 1 |
| 44 | SS-6090612-TP | SCREW 9/64-40 L=6 | 2 |
| 45 | MAZ-16015000 | BUTTON SUPPORT LINK | 1 |
| 46 | SD-0640321-TP | HINGE SCREW D=6.35 H=3.2 | 1 |
| 47 | MAZ-16021000 | NEEDLE HOLE GUIDE | 1 |
| 48 | MTQ-300B1400 | NEEDLE TQX3 #14 | 1 |
| 49 | 141-48209 | BUSHING | 1 |
| 50 | 141-48100 | CONNECTING LINK | 1 |
| 51 | SD-0700271-TP | HINGE SCREW | 2 |
| 52 | 138-64400 | WIPER LINK | 1 |
| MAZ-16008000 | BUTTON SUPPORT RUBBER | (1) | |
| SS-9110460-SP | SCREW 11/64-40 L=4 | (2) | |
| D1401-MIY-COA | NEEDLE BAR | 1 |
Page 55 — 31. LK-1904
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141-36709 | CLOTH FEED BASE | 1 |
| 2 | 141-37053 | LEVER DRIVING PLATE COMPL.,L | 1 |
| 3 | 141-36956 | LEVER DRIVING PLATE COMPL.,R | 1 |
| 4 | 141-37608 | WORK CLAMP FOOT A ,LEFT | 1 |
| 5 | 141-37509 | WORK CLAMP FOOT A ,RIGHT | 1 |
| 6 | 141-36808 | SUPPORT PLATE | 1 |
| 7 | SS-6111010-TP | SCREW 11/64-40 L= 9.5 | 2 |
| 8 | 141-35503 | LOWERING FOOT | 1 |
| 9 | 141-35602 | LOWERING ARM | 1 |
| 10 | 141-35305 | FINGER GUARDE | 1 |
| 11 | SS-8110422-TP | SCREW 11/64-40 L=4 | 1 |
| 12 | CM-3002000-B2 | LABEL(25). | 1 |
| 13 | CM-3002000-02 | CAUTION LABEL(25) | 1 |
| 14 | 141-37806 | CLOTH PRESSER FOOT B ,RIGHT | 1 |
| 15 | 141-36303 | CLOTH FEED PRESSER PLATE ,L | 1 |
| 16 | 141-36204 | CLOTH FEED PRESSER PLATE ,R | 1 |
| 17 | SS-2110920-TP | SCREW 11/64-40 L=8.5 | 4 |
| 18 | SS-4110615-SP | SCREW 11/64-40 L=6 | 2 |
| 19 | 141-35701 | CONNECTING BAR | 1 |
| 20 | 141-36113 | CLOTH FEED PLATE | 1 |
| 21 | 141-36006 | CLOTH FEED SUPPORT PLATE | 1 |
| 22 | 141-37707 | CLOTH PRESSER LOWER PLATE A | 1 |
| 23 | 141-38002 | CLOTH PRESSER LOWER PLATE B | 1 |
| 24 | 141-37905 | CLOTH PRESSER FOOT B ,LEFT | 1 |
Page 56 — 32. ACCESSORIES PARTS FOR LK-1900 SUB CLASSES
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | MDP-170B1402 | NEEDLE DPX17#14-2 | 1 |
| 2 | MTQ-300B1402 | TQX3#14-2 | 1 |
| 3 | 141-46757 | BUTTON RISING BAR ASM. | 1 |
| 4 | 141-46807 | INSTALLING BASE | (1) |
| 5 | 141-46708 | BUTTON RISING BAR | (1) |
| 6 | SS-6080340-SP | SCREW 1/8-44 L=2.9 | (1) |
| 7 | WP-0370316-SD | WASHER 3.7X8X0.3 | (2) |
| 8 | SS-9090813-TP | SCREW 9/64-40 L=8 | (1) |
| 9 | MAZ-1600300B | FEED PLATE, B | 1 |
| 10 | 178-48458 | BUTTON TRAY ASM. | 1 |
| 11 | 178-48508 | BUTTON TRAY BASE | 1 |
| 12 | SK-3412001-SE | WOOD SCREW D=4.1 L=20 | 2 |
| 13 | SS-9151210-TP | SCREW 15/64-28 L=11.8 | 1 |
| 14 | 138-63758 | SHAFT PLATE COMPL. | 1 |
| 15 | 138-63709 | SAFETY PLATE INSTALLING PLATE | (1) |
| 16 | 138-89407 | SAFETY PLATE | (1) |
| 17 | B3121-980-000 | SAFETY PLATE INSTALLING PLATE | (1) |
| 18 | 138-63808 | SAFETY PLATE BACK SPRING | (1) |
| 19 | PS-0200062-KH | SPRING PIN 2X6 | (1) |
| 20 | SS-4110715-SP | SCREW 11/64-40 L=7 | (2) |
| 21 | SS-6110810-TP | SCREW 11/64-40 L=8 | (2) |
| 22 | NS-6110310-SP | NUT 11/64-40 | (1) |
| 23 | WP-0450801-SD | WASHER 4.5X10X0.8 | (2) |
| 24 | SD-0601021-SP | HINGE SCREW D=6 H=10.2 | (1) |
| 25 | B1506-352-000 | TENSION SPRING RACK B | (1) |
| 26 | NS-6120310-SP | NUT 3/16-28 | (1) |
| 27 | WP-0740516-SP | WASHER 7.4X11.8X0.5 | (1) |
| 28 | MDP-170B1902 | NEEDLE DPX17#19-2 | 1 |
| 29 | 141-38101 | PRESSER PLATE COVER | 1 |
| 30 | 141-16909 | FEED PLATE I | 1 |
Page 57 — 33. LIST FOR INFORMATION OF CHANGE
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 17 | SS-8110422-TP | SS-8110422-TP | |
| 22 | 112-80856 | ||
| 23 | 135-38152 | ||
| 37 | SS-4090515-SP | SS-4090515-SP | |
| 55 | WP-0480856-SP | WP-0480856-SP | |
| 41 | HD-0013500-00 | HD-0013500-00 | |
| 21 | WP-0560860-SE | WP-0560860-SE | |
| 44 | 135-00400 | ||
| 2 | 141-03154 | ||
| 3 | 141-03105 | ||
| 6 | B3504-280-000 | B3504-280-000 | |
| 7 | SS-6090440-SP | SS-6090440-SP | |
| 9 | CQ-2522000-00 | CQ-2522000-00 | |
| 74 | CS-080081C-SH | CS-080081C-SH | |
| 53 | HD-0013500-00 | HD-0013500-00 | |
| 9 | 135-30357 | ||
| 13 | B3507-280-000 | B3507-280-000 | |
| 1 | 141-15158 | ||
| 3 | 141-15356 | ||
| 10 | M8540-580-0A0 | M8540-580-0A0 | |
| 11 | M8901-590-AA0 | M8901-590-AA0 | |
| 12 | M8901-590-BA0 | M8901-590-BA0 | |
| 36 | SL-4040681-SF | SL-4040681-SF | |
| 39 | SL-4051091-SF | SL-4051091-SF | |
| 49 | M1022-590-000 | M1022-590-000 | |
| 50 | SL-4031081-SF | SL-4031081-SF | |
| 25 | M9011-590-0A0 | M9011-590-0A0 | |
| 26 | HD-0013500-00 | HD-0013500-00 | |
| 17 | SS-7110730-SP | SS-7110730-SP | |
| 22 | 141-01208 | ||
| 23 | 138-16764 | ||
| 37 | SS-4090715-SP | SS-4090715-SP | |
| 41 | HD-0019300-00 | HD-0019300-00 | |
| 75 | 141-15364 | ||
| 21 | 141-05704 | ||
| 44 | 141-05605 | ||
| 56 | RO-0481901-00 | RO-0481901-00 | |
| 2 | 141-03006 | ||
| 3 | 141-03907 | ||
| 6 | 141-03907 | ||
| 7 | SS-4090415-SP | SS-4090415-SP | |
| 9 | CQ-2020000-00 | CQ-2020000-00 | |
| 16 | CQ-2000000-00 | CQ-2000000-00 | |
| 17 | 141-04004 | ||
| 18 | SS-6060410-TP | SS-6060410-TP | |
| 19 | BT-0500300-EA | BT-0500300-EA | |
| 74 | CS-080081B-SH | CS-080081B-SH | |
| 53 | HD-0019300-00 | HD-0019300-00 | |
| 9 | B3509-220-000 | B3509-220-000 | |
| 13 | 141-14607 | ||
| 25 | CQ-2020000-00 | CQ-2020000-00 | |
| 1 | 141-15752 | ||
| 3 | 141-15364 | ||
| 2 | M8910-590-0A0 | M8910-590-0A0 | |
| 10 | M8540-590-0A0 | M8540-590-0A0 | |
| 11 | M8901-590-AA0-A | M8901-590-AA0-A | |
| 12 | M8901-590-BA0-A | M8901-590-BA0-A | |
| 36 | SL-4040681-SC | SL-4040681-SC | |
| 39 | SL-4051091-SC | SL-4051091-SC | |
| 25 | M9011-590-0A0-A | M9011-590-0A0-A | |
| 26 | HD-0019300-00 | HD-0019300-00 |
Page 58
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 27 | HX-0012300-0B | ||
| 1 | 141-17501 | ||
| 33 | B2102-205-000 | ||
| 34 | SS-6621220-SP | ||
| 6 | B2559-372-000 | ||
| 18 | B2559-372-000 | ||
| 33 | B2559-372-000 | ||
| 41 | B2559-372-000 | ||
| 43 | MAZ-158070BA | ||
| 44 | MAZ-158070BB | ||
| 45 | MAZ-158070AA | ||
| 46 | MAZ-158070AB | ||
| 49 | B2559-372-000 | ||
| 51 | MAZ-158080BA | ||
| 52 | MAZ-158080BB | ||
| 53 | MAZ-158080AA | ||
| 54 | MAZ-158080AB | ||
| 57 | B2559-372-000 | ||
| 27 | HD-0012300-00 | ||
| 68 | 141-07155 | ||
| 69 | 141-07106 | ||
| 70 | 141-07205 | ||
| 71 | RE-1500000-KO | ||
| 72 | 141-07304 | ||
| 1 | 141-22550 | ||
| 1 | 141-17519 | ||
| 33 | B2102-205-00A | ||
| 34 | SS-7111120-SP | ||
| 59 | 141-49603 | ||
| 39 | MAZ-158070BB | ||
| 40 | MAZ-158070BA | ||
| 41 | MAZ-15807-AB | ||
| 42 | MAZ-15807-AA | ||
| 46 | MAZ-158080BB | ||
| 47 | MAZ-158080BA | ||
| 48 | MAZ-158080AB | ||
| 49 | MAZ-158080AA | ||
| 52 | 141-49900 | ||
| 53 | 141-48852 | ||
| 59 | 141-48951 | ||
| 30 | 141-16909 |
Page 63 — NUMERICAL INDEX OF PARTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 9 | 141-46203 | ||
| 5 | 141-46203 | ||
| 13 | 141-46302 | ||
| 32 | 141-46401 | ||
| 10 | 141-46401 | ||
| 5 | 141-46708 | ||
| 3 | 141-46757 | ||
| 4 | 141-46807 | ||
| 49 | 141-46906 | ||
| 17 | 141-47003 | ||
| 12 | 141-47003 | ||
| 18 | 141-47102 | ||
| 13 | 141-47102 | ||
| 23 | 141-47201 | ||
| 18 | 141-47201 | ||
| 20 | 141-47359 | ||
| 15 | 141-47359 | ||
| 7 | 141-47508 | ||
| 43 | 141-47508 | ||
| 5 | 141-47607 | ||
| 35 | 141-47607 | ||
| 15 | 141-47755 | ||
| 28 | 141-47755 | ||
| 8 | 141-47805 | ||
| 21 | 141-47805 | ||
| 42 | 141-47904 | ||
| 50 | 141-48100 | ||
| 49 | 141-48209 | ||
| 19 | 141-48407 | ||
| 44 | 141-48407 | ||
| 18 | 141-48803 | ||
| 56 | 141-48803 | ||
| 15 | 141-48852 | ||
| 53 | 141-48852 | ||
| 25 | 141-48902 | ||
| 61 | 141-48902 | ||
| 23 | 141-48951 | ||
| 59 | 141-48951 | ||
| 21 | 141-49009 | ||
| 17 | 141-49058 | ||
| 11 | 141-49108 | ||
| 7 | 141-49157 | ||
| 59 | 141-49603 | ||
| 52 | 141-49900 | ||
| 10 | 170-07402 | ||
| 33 | 170-07402 | ||
| 13 | 178-45009 | ||
| 10 | 178-48458 | ||
| 11 | 178-48508 | ||
| 61 | 225-37658 | ||
| 62 | 225-38100 | ||
| 63 | 225-38300 | ||
| 64 | 225-38409 | ||
| 14 | 229-30309 | ||
| 1 | 229-30358 | ||
| 10 | 229-30408 | ||
| 9 | 229-30507 | ||
| 7 | 229-30705 | ||
| 5 | 229-30804 | ||
| 4 | 229-30903 | ||
| 3 | 229-31000 | ||
| 2 | 229-31109 | ||
| 15 | 229-31208 | ||
| 11 | 229-31307 | ||
| 8 | 229-31406 |
Juki LK-1900 — parts catalog
- Page 1 (cover): This is the cover page for the JUKI LK-1900 Series Industrial Sewing Machine Parts List. It includes the JUKI logo and the machine model information.
- Page 2 (unknown): This page contains a watermark and a website address at the bottom.
- Page 3 (text): This page provides instructions on how to use the parts list, explaining codes and symbols used in the catalog, including explanations for asterisk marks, '01' codes, quantity notations, and dotted lines in diagrams.
- Page 4 (toc): This page is a table of contents for a parts catalog, listing sections from Frame & Miscellaneous Cover Components to LK-1901:Work Clamp Solenoid Components, along with their corresponding page numbers.
- Page 6 (diagram): This page displays a diagram of frame and miscellaneous cover components for an industrial sewing machine, with numbered parts and their corresponding references.
- Page 7 (parts_list): This page lists parts for a sewing machine, including motor covers, oil pans, screws, nuts, and various other components with their corresponding part numbers and descriptions.
- Page 8 (diagram): This page displays a diagram of main shaft and needle bar components, with numbered parts for identification.
- Page 9 (parts_list): Parts list page 4 of the LK-1900 series, giving reference numbers, maker part numbers, English and Japanese descriptions, quantities and model notes for the main shaft, needle bar, thread take-up and screw items.
- Page 10 (diagram): This page displays a diagram of presser lifter components, with numbered parts and their corresponding references.
- Page 11 (parts_list): This page lists parts for the LK-1900 series sewing machines, including solenoids, links, cylinders, screws, and nuts, with part numbers, descriptions, and quantities.
- Page 12 (diagram): This page displays a diagram of shuttle driver shaft components, with numbered parts and their corresponding references.
- Page 13 (parts_list): This page contains a parts list for various components of an industrial sewing machine, including oscillators, shuttles, screws, washers, and bearings, with their corresponding part numbers, descriptions, and quantities.
- Page 14 (diagram): This page displays a diagram of the wiper mechanism components, along with a parts list detailing part numbers, descriptions, quantities, and applicable models.
- Page 15 (diagram): This page displays a diagram of tension release and thread tension components, along with a detailed parts list including part numbers, descriptions, and quantities.
- Page 16 (diagram): This page displays a diagram of tension release and thread trimmer mechanism components, with numbered parts and their corresponding references.
- Page 17 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, and quantities. It covers components like solenoids, screws, washers, and various assemblies.
- Page 18 (diagram): This page displays a diagram of the feed mechanism components, with numbered parts and their corresponding references.
- Page 19 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, and quantities. It also includes notes and references for specific models.
- Page 20 (diagram): This page displays a diagram of lubrication components, with numbered parts and their corresponding references.
- Page 21 (parts_list): This page lists parts for an industrial sewing machine, including oil shields, felt, screws, oil wicks, and balance lubricating plates, with their corresponding part numbers, descriptions, and quantities.
- Page 22 (parts_list): This page lists sensor and extension cable components, including part numbers, descriptions, and quantities, with some Japanese text annotations.
- Page 23 (diagram): This page displays a diagram of thread stand components, with a corresponding parts list detailing reference numbers, part numbers, descriptions, and quantities.
- Page 24 (diagram): This page displays a diagram of control box components, including fans, screws, brackets, transformers, and other electrical parts, with corresponding reference numbers for identification.
- Page 25 (parts_list): This page lists various parts for an industrial sewing machine, including circuit boards, transformers, screws, washers, and labels, along with their part numbers, descriptions, and quantities.
- Page 26 (diagram): This page displays a diagram of operation box and pedal components, with numbered parts and their corresponding references.
- Page 27 (parts_list): This page lists parts for sewing machines, including operation boxes, screws, fuses, and cables, with their corresponding part numbers, descriptions, and quantities.
- Page 28 (diagram): This page displays a wiring diagram for the industrial sewing machine, illustrating connections between various components like circuit boards, motors, transformers, and optional parts.
- Page 29 (parts_list): This page lists parts for a sewing machine, including various cables, switches, and optional components, with their corresponding part numbers and descriptions.
- Page 30 (diagram): This page displays a diagram of accessory part components for a JUKI sewing machine, with numbered parts and their corresponding references.
- Page 31 (parts_list): This page lists parts for industrial sewing machines, including safety plates, screws, nuts, washers, and various assemblies like regulators and solenoids, with part numbers, descriptions, and quantities.
- Page 32 (diagram): This page displays a diagram of optional components for an industrial sewing machine, including various brackets, blades, and fasteners, with reference numbers for each part.
- Page 33 (parts_list): This page lists various parts for industrial sewing machines, including work clamp feet, presser feet, feed plates, finger guards, needle hole guides, inner hook presser assemblies, shuttle race rings, cloth presser blanks, work clamp foot assemblies, springs, screws, feed plates, and solenoids. Each entry includes a reference number, part number, description, and quantity.
- Page 34 (diagram): This page displays a diagram of option components for LK-1900, 1901, and 1902 sewing machines, with numbered parts indicated.
- Page 35 (parts_list): This page lists parts for a sewing machine, including magnet wiper assemblies, screws, arms, links, hinges, springs, nuts, and washers, with their corresponding part numbers and quantities.
- Page 36 (diagram): This page displays a diagram of table components, including the main table surface, various support structures, and fastening hardware, with numbered references for each part.
- Page 37 (parts_list): This page lists parts for an industrial sewing machine, including part numbers, descriptions, quantities, and some Japanese text.
- Page 38 (diagram): This page displays a diagram of work clamp mechanism components for the LK-1901SΔ sewing machine, with numbered parts indicated.
- Page 39 (parts_list): This page lists parts for the LK-1900 standard model, including part numbers, descriptions, and quantities, with notes for selective and solenoid type parts.
- Page 40 (diagram): This page displays a diagram of work clamp solenoid components, with numbered parts and their corresponding references.
- Page 41 (parts_list): This page lists parts for solenoid and cylinder types, including solenoids, housing, pins, screws, springs, and cylinders, with their corresponding part numbers and descriptions.
- Page 42 (diagram): This page displays a diagram of various machine parts, including frames, springs, and brackets, with reference numbers and part numbers for identification.
- Page 43 (parts_list): This page lists parts for a solenoid type machine, including part numbers, descriptions, and quantities. It also notes that parts not listed are the same as the standard model.
- Page 44 (diagram): This page displays a diagram of sewing machine parts, with items numbered from 1 to 24, and includes part numbers and descriptions.
- Page 45 (parts_list): This page lists parts for an industrial sewing machine, including part numbers, descriptions, quantities, and remarks. It also includes notes about common use and special order parts.
- Page 46 (diagram): This page displays diagrams for tension components, presser lifter components, and wiper mechanism components for the LK-1903SA-30A sewing machine.
- Page 47 (parts_list): This page lists parts for a sewing machine, including needle bars, screws, levers, solenoids, cylinders, and washers, with their corresponding part numbers, descriptions, and quantities.
- Page 48 (diagram): This page displays a diagram of button clamp components for small buttons, with part numbers ranging from 1 to 56.
- Page 49 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes. It covers items from reference number 1 to 59.
- Page 50 (diagram): This page contains diagrams and parts lists for button clamp assemblies for medium, large, and very small sized buttons, with part numbers ranging from LK-1903-302 to LK-1903-304.
- Page 51 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes. It details various clamp jaw levers, screws, plates, and guides.
- Page 52 (diagram): This page displays a diagram of the shank button clamp mechanism components, with numbered parts and their corresponding part numbers and descriptions.
- Page 53 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, and quantities. It covers items from reference number 1 to 52.
- Page 54 (diagram): This page displays a diagram of sewing machine parts, with reference numbers and illustrations for each component. It includes parts numbered 1 through 24.
- Page 55 (parts_list): Parts list page of a sewing machine part book listing cloth feed, presser foot, lowering and screw parts with reference numbers, part numbers, English and Japanese descriptions, and quantities.
- Page 56 (parts_list): This page lists accessories and parts for the LK-1900 Sub Classes, including part numbers, descriptions, and quantities.
- Page 57 (text): This page contains a list of parts for information of change, including obsolete and added parts with their corresponding revision numbers, page numbers, reference numbers, and part numbers.
- Page 58 (parts_list): This page contains a parts list for various components, including part numbers like HD-0012300-00, 141-07155, and B2559-372-000, along with their corresponding descriptions and reference numbers.
- Page 63 (parts_list): This page contains a numerical index of parts for an industrial sewing machine, listing part numbers, page references, and reference numbers in diagrams.
- Page 64 (cover): This is the cover page of a JUKI CORPORATION parts catalog, featuring the JUKI logo and copyright information.
