Page 95 — A、机体部分/Machine body

Jack JK-T1310 / JK-T2210 parts on page 95
Ref	Part number	Part name	Qty
1	41703001	BUSHING U	1
2	41729001	DOWEL PIN	1
3	41722001	RUBBER CAP 20-15	1
4	41722002	RUBBER CAP 13.5	1
5	41722003	RUBBER CAP 10. 5	3
6	41711205	MOTOR COVER QR	1
7	S04038	SCREW PAN M6 X 10	4
8	41711206	MOTOR COVER QL	1
9	S04038	SCREW PAN M6 X 10	4
10	304727	FACE PLATE	1
11	41722004	RUBBER CAP 15. 5	1
12	41712003	F-PLATE PACKING	1
13	S04038	SCREW PAN M6 X 10	3
14	301383	SHUTTLE RACE COVER	1
15	41712005	SHUTTLE RACE COVER HOOK D	1
16	S02031	SCREW PAN M3 X 5	2
17	41712006	NUT PLATE	1
18	4171220200	HINGE	1
19	NO1013	STEPPING COVER	2
20	S04082	SCREW PAN M3 X 6	2
23	301384	THREAD TAKE-UP COVER	1
24	S04079	SCREW PAN M4 X 10	1
25	41711207	STEPPING COVER Q	1
26	417S30012	SHOULDER SCREW 7-3	1
27	41728020	SPRING WASHER	1
28	41728035	WAHER PLAIN	1
29	41711208	SCREW M5 Q	1
30	41737001	MARK INJURY	1
31	20131063	WARNING SIGN	1
33	41722009	RUBBER CAP 13	1
34	41712009	FINGER GUARD	1
35	41728025	WASHER PLAIN L3. 5	2
36	41712010	HEAD REST	1
37	417S30037	BOLT SOCKET(S /P WASHER)M6 X 14	4
38	S04075	SCREW PAN M3 X 5	2
39	41722006	RUBBER CAP 26	1
40	41722007	RUBBER CAP 11.5	2
41	41722008	RUBBER CAP	2
42	41722009	RUBBER CAP 13	1

Page 97 — B. 上轴·针杆装置/Upper shaft and needle bar mechanism

Jack JK-T1310 / JK-T2210 parts on page 97
Ref	Part number	Part name	Qty
1	41702001	UPPER SHUFT	1
2	4170501100	CRANK ROD ASSY	1
3	S05124	BOLT SOCKET M5 X 16	2
4	41724001	NEEDLE BEARTNG:BLUE	1
4	41724001	NEEDLE BEARING:BLACK	1
4	41724001	NEEDLE BEARING:GRAY	1
4	41724001	NEEDLE BEARING:YELLOW	1
5	41703002	BALL BEARING BUSH	1
6	B10014	BALL BEARING 6904DDUNR	1
7	B06005	BALL BEARING 6904DDU	1
8	S10018	SET SCREW SOCKET (FT) M6 X 6	2
9	41703002	BALL BEARING BUSH	1
10	B10012	BALL BEAR1NG 6004DDUNR	1
11	S10018	SET SCREW SOCKET (FT) M6 X 6	2
12	41703004	J01NT G	1
13	B10013	BALL BEARING 6204DDUNR	1
14	S10018	SET SCREW SOCKET (FT)M6 X 6	4
15	417S30002	SCREW，M8	1
16	41704001	THREAD TAKE-UP CRANK G	1
17	S10018	SET SCREW SOCKET (FT) M6 X 6	4
18	41712133	WASHER，PLAIN SPECIAL 8	1
19	14170500400	THREAD TAKE-UP LEVER FK SET	1
19-1	41726021	TAKE-UP RACK PIN	1
19-2	41712103	THREAD RACK	1
19-3	4171210400	TAKE-UP ROD ASSEMBLY	1
19-4	41724003	NEEDLE ROLLER BEARING K8X 12 X 7. 7	2
19-5	41712102	PICK CRANK	1
19-6	41705101	NEEDLE BAR LINKAGE	1
19-7	41704100	NEEDLE BAR CONNECTOR	1
20	417S17003	SCREW FLAT M5 X 6	1
21	S09019	SET SCREW SOCKET (FT) M5 X 5	1
22	S04078	SCREW PAN M4 X 8	1
23	417S14001	SCREW SM3. 57-40 X 6L	1
24	S10019	SET SCREW SOCKET (FT) M6 X 6	2
25	41709001	SLIDE BLOCK	1
26	41709002	SLIDE BLOCK GUIDE	1
27	S05118	BOLT SOCKET M4 X 16	2
28	41702002	NEEDLE BAR	1
29	417S15002	SET SCREW，SM3. 57-40 X 4. 5	1
30	41703005	NEEDLE BAR BUSH UK	1
31	41703006	NEEDLE，RAR RUSH D	1
32	41217002	NEEDLE	1
33	12411002	FAN	1
34	S04078	SCREW PAN M4 X 8	3
35	41225010	PULLEY GEAR R	1
36	S09019	SET SCREW SOCKET (FT) M5 X 5	2
37	41702003	PULLEY SHUFT	1
38	41703007	PULLEY BUSH	1
39	41727001	PULLEY SPRING	1
40	41703008	PULLEY BASE	1
41	P03027	PTN SPRJNG ROLL AW4	1
42	41725002	PULLEY GE\RL	1
43	S09019	SET SCREW SOCKET (FT) M5 X 5	2
44	S10018	SET SCREW SOCKET (FT) M6 X 6	2
45	41711001	PULLEY	1
46	S04079	SCREW PAN M4 X 10	3
47	41728024	WASHER PLAIN L4	3
48	S10019	SET SCREW SOCKET (FT)M6 X 6	1
49	S05124	BOLT SOCKET M5 X 16	4
50	41712011	FRIES WHEEL 2	2
51	403S11043	SCREW PAN M4 X 12	3
52	S09041	SET SCREW SOCKET (FT) M6 X 5	1

Page 99 — C1、送料装置 / Feed mechanism

Jack JK-T1310 / JK-T2210 parts on page 99
Part number	Part name	Qty
400994
42224502	X-LM 导轨	2
413S14012	螺栓 M3 X 14	15
4170 1003	送布台(X)	1
S05192	螺栓 M3 X 6	8
S02032	螺钉 M3 X 6	8
41709004	传感器板(X)	1
S02032	螺钉 M3 X 6	2
41709005		1
S05116	螺栓 M4 X 8	2
41735001	X-GT 皮带	1
41712012	皮带支架板(X)	1
S05116	螺栓 M4 X 8	2
42224501	花键轴组件C	1
B06006	球轴承 6000VV	1
41728001		1
H03008	轴用挡圈 C10	1
4173500200	X-左轮组件	1
S10019	螺栓 M6 X 6	1
B06007	球轴承 6806VV	2
H01004	孔用挡圈 C42	2
41701013	X-轮基座	1
S05035	螺栓 M5 X 16	2
W01009	平垫圈 M5	2
4173500200	X-右轮组件	1
41728001		1
S10015	球轴承 6900ZZNR	2
41702005	X-轮支点轴	1
S10019	螺钉 M6 X 6	2
41712013	Y-传感器板	1
S05119	螺栓 M4 X 20	2
42224503	Y-LM 导向	2
41728002	Y-LM 垫片	2
S02032	螺钉 M3 X 6	16
S05119	螺栓 M4 X 20	8
W01006		8
W02008		8
4 1709032
S05119	螺栓 M4 X 20
41711062		2
41726020		4
S09005	螺钉 M3 X 5	4

Page 101 — C2、送料装置 / Feed mechanism

Jack JK-T1310 / JK-T2210 parts on page 101
Ref	Part number	Part name	Qty
1	S05111	BOLT SOCKET M6 X 20	4
2	41725003	X-FEED GEAR	1
3	S10019	SET SCREW SOCKET (FT) M6 X 6	2
4	B10015	BALL BEARING 6900ZZNR	2
5	41725004	Y-FEED GEAR	1
6	S10019	SET SCREW SOCKET (FT) M6 X 6	2
7	B10015	BALL BEARING 6900ZZNR	2
8	H05011	RETAINING RING 9	1
9	4173501100	Y-PULLEY ASSY	1
10	S10019	SET SCREW SOCKET (FT) M6 X 6	4
11	41703009	Y-PULLEY COLLAR	1
12	41702006	Y-PULLEY DRIVING SHAFT	1
13	41701005	Y-PULLEY BRACKET	1
14	810015	BALL BEARING 6900ZZNR	2
15	4173502100	Y-PULLEY ASSY	1
16	S10019	SET SCREW SOCKET (FT)M6 X 6	2
17	41702007	Y-PULLEY FULCRUM SHAFT	1
18	41735005	Y-GT BELT	1
19	4 1712014	BELT SUPPORT PLATEY	1
20	41712015	Y-BELT WORK CLAMP PLATE	1
21	S05116	BOLT SOCKET M4 X 8	4
22	417S30304	B0LT SOCKET(S/P WASHER) M6 X 20	2
23	S05119	B0LT SOCKET M4 X 20	4
24	41711204	COVER RAIL Q	2
25	41712017	FIXATION R	1
26	41712018	FIXATION L	1
	403S11043	SCREW FAN M4 X 10	12
28	417S30009	SCREW FAN M4 X 6	4
29	41711201	INSIDE COVER QR	1
30	41711202	INSIDE COVER QL	1
31	41711203	OUTSDE COVER Q ASSY	2
32	41711002	BELT COVER Y	1
33	417S30025	SCREW PAJ (S/P WASHER) M4 X 10	2
34	41712022	AUXI LIARY PLATE	1
35	41722010	AUXILIARY PLATE CUSHION	10
36	417S15003	SCREW M4 X 12	10
37	417N01002	LOCKNUT	10
38	41712023	AUXILIARY PLATE BRACKET	4
38	41712064	L TYPE BRACKET	2
39	417S30304	BOLT SOCKET(S/P IVASHER) M6 X 20	6
40	41712024	SUPPORT PLATE GUIDE U	2
41	4 1712025	SUPPORT PLATE GUIOE D	2
42	417S30035	BOLT SOCKET (S/P IVA5HER) M5 X 10	4
43	417S30304	BOLT SOCKET(S/P IVASHER) M6 X 20	4
44	41722011	BELLOW	1
45	41712026	BELLOW PRESSER R	1
46	41712027	BELLOW PRES5ER F	1
47	41712060	BELLOW NUT	2
48	S04036	SCREW FAN M3 X 4	4
	417S30009	SCREW FAN M4 X 6	4
50	141733002	PULSE MOTOR X	1
51	41712029	MOTOR BRACKET PLATE	1
52	S05048	B0LT SocKET M4 X 10	4
53	41725005	GEAR 16	1
54	S09041	SET SCREIV SOCKET (FT) M6 X 5	2
55	141733003	PULSE MOTOR Y	1
56	41712029	MOTOR BRACET PLATE	1
57	S05048	BOLT SOCKET M4 X 10	4
58	41725005	GEAR 16	1
59	S09041	SET SCREIV SOCKET (FT) M6 X 5	2
60	417S30304	B0LT SOCKET(S/P IVASHER) M6 X 20	6

Page 103 — C2、送料装置 / Feed mechanism

Jack JK-T1310 / JK-T2210 parts on page 103
Ref	Part number	Part name	Qty
61	41712030	COVER CONNECT PLATE	1
62	417S15006	SCREW M4 X 5	2
63	41728012	WASHER	4
65	41712100	BEARING HOLDER BASE	2
66	S05121	BOLT SOCKET M5 X 10	4
67	41712101	BEARING HOLDER	2
67	41724005	BALL BEARING 126	2
68	S05048	BOLT SOCKET M4 X 10	4
70	417S30037	BOLT SOCKET M6 X 14	10

Page 105 — C3、送料装置/Feed mechanism (T1310)

Jack JK-T1310 / JK-T2210 parts on page 105
Ref	Part number	Part name	Qty
1	41701006	WORK CLAMP	1
2	41711007	SLIDER	1
3	H03008	RETAINING RING EXTERNAL C10	1
4	41712031	SUPPORT SLIDER	1
5	41726001	SUPPORT SHAFT SL DER	1
6	H03018	RETAINING RING EXTERNAL C4	2
7	41712032	WORK CLAMP LIFTER LEVER R	1
8	41712033	WORK CLAMP LIFTER LEVER L	1
9	41702012	WORK CLAMP LIFTER SHAFT	1
10	S10019	SET SCREW SOCKET (FT) M6 X 6	1
11	H03006	RETAINING RING EXTERNAL C8	1
12	41712133	WASHER PLAIN SPECIAL 8	1
13	41708002	SET SCREW COLLAR B	1
14	S09041	SET SCREW SOCKET (FT) M6 X 5	2
15	41712034	CONNECTING ROD	2
16	41702021	SPR NG HOLDER SHAFT A	1
17	417S30003	SHOULDER SCREW M5	2
18	41702009	SPRING HOLDER SHAFT B	1
19	S10019	SET SCREW SOCKET (FT) M6 X 6	2
20	41727002	SPRING LIFT	1
21	41712035	CONNECTING LINK	2
22	417S12002	WORK CLAMP SPRING HOLDER	2
23	N01017	NUT 2 M5	2
24	41727003	WORK CLAMP SPRING	2
25	41712036	WORK CLAMP LIFTER LEVER R	1
26	41712037	WORK CLAMP LIFTER LEVER L	1
27	41702012	WORK CLAMP LIFTER LEVER	1
28	S10019	SET SCREW SOCKET (FT) M6 X 6	1
29	H03006	RETAINING RING EXTERNAL C8	1
30	41712133	WASHER PLA IN SPECIAL 8	1
31	41708002	SET SCREW COLLAR B	1
32	S09041	SET SCREW SOCKET (FT)M6 X 5	2
33	41712038	STOPPER	2
34	S05120	BOLT SOCKET M5 X 8	4
35	W01009	IVASHER PLAIN M5	4
36	W02001	WASHER SPRING 2-5	4
37	4170901300	WORK CLAMP GUIDE A ASSY	1
38	417S15003	SCREW M4 X 16	2
39	4170901400	WORK CLAMP GUIDE B ASSY	2
40	417S30034	BOLT SOCKET(S/P WASHER) M4 X 14	4
41	4170901500	WORK CLAMP SUDER ASSY R	1
42	4170901600	WORK CLAMP SLIDER ASSY L	1
43	141712271	IVORK CLAMP RETAINER ASSY	4
44	41712039	WORK CLAMP	1
45	417S30035	BOLT S0CKET (S/P WASHER) M5 X 10	2
46	S09009	SET SCREW SOCKET (FT)M5 X 10	2
47	N01017	NUT 2 M5	2
48	417S20001	SHOULDER SCREW	2
49	401219	WORK CLAMP 1310 ASSY	1
50	417S30035	BOLT SOCKET(S/P WASHER) M5 X 10	2
51	L02006	BOLT M5 X 16	4
52	W01009	WASHER PLAIN M5	4
53	W02001	WASHER SPRING 2-5	4
54	400992	FEED PLATE 1310	1
55	417S30035	BOLT SOCKET(S/P WASHER) M5 X 10	2
55	41728004	WASHER	2

Page 107 — C4、送料装置/Feed mechanism

Jack JK-T1310 / JK-T2210 parts on page 107
Ref	Part number	Part name	Qty
SA4686101	41701006	WORK CLAMP	1
SA4717001	41702011	CYLINOER SHAFT	1
12060636	S10019	SET SCREW SOCKET (FT) M6 X 6	2
	40736004	Φ4可调节气管接头(螺纹M5)	2
SA4719001	41730035	AIR CYLINDER ASSY	2
48050142	H03019	RETAINING RING EXTE AL C5	2
SA4720001	41709012	CYLINDER JOINT	2
SA4721001	41726002	CYL NDER JOINT SHAFT	2
48060142	H05027	RETAINING RING EXTE AL C6	4
SA4722001	41712042	WORK CLAMP LIFTER LEVER R AIR	1
SA4723001	41712043	WORK CLAMP LIFTER LEVER L AIR	1
SA4724001	41712044	WORK CLAMP LIFTER SHAFT A R	2
S55479001	413S13008	BOLT SOCKET (S/P WASHER) M4 X 8	2
SA4692001	41702012	WORK CLAMP LIFTER SHAFT	1
12060636	S10019	SET SCREW SOCKET (FT) M6 X 6	1
48080142	H03006	RETA NING RING EXTERNAL C8	1
110367001	41712133	WASHER PLAIN SPECIAL 8	1
SA3231001	41708002	SET SCREW COLLAR B	1
12060536	S09041	SET SCREW SOCKET (FT)M6 X 5	2
SA4863001	4170901300	WORK CLAMP GUIOE A ASSY	1
S23849001	417S15003	SCREW M4 X 12	2
SA4864001	4170901400	WORK CLMP GUIOE B ASSY	2
S55482001	417S30034	BOLT SOCKET(S/P WASHER) M4X 14	4
SA4712001	4170901500	WORK CLAMP SLIDER ASSY R	1
SA4714001	4170901600	WORK CLAMP SLIDER ASSY L	1
SA4706101	I41712271	WORK CLAMP SLIDER ASSY	4
SA4725001	41712045	WORK CLAMP R	1
S55485001	417S30036	BOLT SOCKET(S/P WASHER) M5 X 12	1
12501031	S09009	SET SCREW SOCKET (FT) M5 X 10	2
21500216	N01017	NUT 2 M5	2
SA4709001	417S20001	SHOULDER SCREW	2
SA4726001	41712046	WORK CLAMP L	1
S55485001	417S30036	BOLT SOCKET (S/P WASHER) M5 X 12	1
12501031	S09009	SET SCREW SOCKET (FT)M5 X 10	2
21500216	N01017	NUT 2 M5	2
SA4709001	417S20001	SHOULDER SCREW	2
SA4868101	401219	WORK CLAMP 311R ASSY	1
S55484002	417S30035	BOLT SOCKET(S/P WASHER) M5 X 10	4
17501616	L01011	BOLT M5X16	4
25050236	W01009	WASHER PLAIN M5	4
28050246	W02001	WASHER SPRING 2-5	4
SA4715001	400996	FEED PLATE 311G	1
S55484002	417S30035	BOLT SOCKET(S/P WASHER) M5 X 10	2
SA4870101	41712441	WORK CLAMP 2210R ASSY	I
SA4871101	41712442	WORK CLMP 2210L ASSY	1
S55484002	417S30035	BOLT SOCKET (S/P WASHER) M5 X 10	4
17501616	L02006	BOLT M5 X 16	4
25050236	WOI009	WASHER PLAIN M5	4
28050246	W02001	WASHER SPRING 2-5	4
S55484002	417S30035	BOLT SOCKET(S/P WASHER) M5X 10	2
SA4852001	400996	FEED PLATE 2210	1

Page 109 — D1、拾压脚装置/Work clamp lifter mechanism

Jack JK-T1310 / JK-T2210 parts on page 109
Ref	Part number	Part name	Qty
1	41710001	STEPPING CLAM CAM	1
2	41705001	STEPPINGCLAMP CON. ROD	1
3	41728003	WASHER STEPPING CLAMP CAM	1
4	B06008	BALL BEARING 6805VV	1
5	S10018	SET SCREW SOCKET (FT) M6 X 6	2
6	S04035	SCREW PAN M4 X 6	2
7	41726003	ROLLER SHAFT STEPPING CLAMP	1
8	41703010	ROLLER STEPPING CLAMP	1
9	41728004	WASHER	2
10	N01021	NUT 1 M6	1
11	41709017	STEPPING CLAMP ARM R	1
12	L02032	BOLT M6 X 12	1
13	41702013	STEPP NG CLAMP ARM F	1
14	S10019	SET SCREW SOCKET(FT)M6 X 6	1
15	S10018	SET SCREW SOCKET (FT) M6 X 6	1
16	41703011	BUSH STEPPING CLAMP F	1
17	41703012	BUSH STEPPING CLMW R	1
18	41712053	STEPP NG CLAMP LINK A	1
19	417S30007	SHOULDER SCREW 6	4
20	S04036	SCREIV PAN M3 X 4	4
21	41712054	STEPPING CLAMP LINK B	1
22	41712055	STEPPING CLAMP LINK	1
23	41726004	SHAFT STEPPING CLAMP LINK	1
24	S10019	SET SCREW SOCKET (FT)M6 X 6	1
25	S09006	SET SCREW SOCKET (FT)M4 X 4	1
26	41709018	STEPP NG CLAMP LIFTER LINK	1
27	41702014	SHAFT STEPPING CLAMP LIFTER LINK	1
28	41728031	WASHER	1
29	H03006	RETA NING RING EXTERNAL C8	1
30	S10019	SET SCREW SOCKET (FT) M6 X 6	1
31	S09006	SET SCREW SOCKET (FT) M4 X 4	1
32	41709019	STEPPING CLAMP LIFTER	1
33	41703013	ROLLER STEPPING CLAMP LIFTER	1
34	41726005	ROLLER	1
35	41702015	SHAFT STEPPING CLAMP LIFTER	1
36	S10019	SET SCREW SOCKET (FT) M6 X 6	1
37	S02039	SCREW FLAT M4	1
38	41702016	STEPPING CLAMP LIFTER ROD	1
39	417S12003	JOINT STEPP NG CLAMP LIFTER	1
40	4170500300	BALL JOINT ASSY	2
41	N01021	NUT M6	2
42	417S16001	NUT (FT) M6	1
43	417S30008	SHOULDER SCREW	1
44	417S12005	SHOULDER SCREW B M6	1
45	L01007	BOLT M6 X 50	1
46	N01021	NUT 1 M6	1
47	41709020	PRESSER BAR CLAMP	1
48	S05116	BOLT SOCKET M4 X 8	1
49	123S30002	PESSER ADJUSTING SCREW M14	1
50	129S16001	ADJUST SCREW NUT	1
51	41727004	PRESSER BAR SPRING	1
52	41702017	PRESSER BAR SPRING GUIOE	1
53	41703014	COLLAR PRESSER BAR SPRING	1
54	41703015	PRESSER BAR BUSH	1
55	S09041	SET SCREW SOCKET (FT)M6 X 5	1
56	41702018	PRESSER BAR	1
57	41716001	WORK CLAMP	1
58	417S15011	SCREW SM3. 57 X 12	1
59	41728032	WASHER	1

Page 111 — D2、拾压装置/Work clamp lifter mechanism (T1310)

Jack JK-T1310 / JK-T2210 parts on page 111
Ref	Part number	Part name	Qty
1	41724004	SLIDE BUSH	1
2	S05048	BOLT SOCKET M4 X 10	4
3	41712056	WORK CLAMP LIFTER PATE ASSY	1
3-1	41702008	PRESSER LIFT SHAFT	1
3-2	41712076	PRESSER FOOT LIFT PLATE	1
4	400993	SEAT E	1
5	S04080	SCREW PAN M4 X 4	1
6	41709021	WORK CLAMP LIFTER LEVER	1
7	41726006	PIN	1
8	41709022	NEEDLE BAR GUIDE SLIDE BLOCK	1
9	41702019	WORK CLAMP LEVER SHAFT B	1
10	S10019	SET SCREW SOCKET (FT)M6 X 6	1
11	41728001	WASHER PLAIN 10	1
12	H05033	RETAIN NG RING E8	1
13	S10019	SET SCREW SOCKET (FT) M6 X 6	2
14	41729002	DOWEL PIN	1
15	41712058	WORK CLAMP LIFTER PATE ASSY	1
16	417S20010	SHOULDER SCREW	2
17	41727005	PRESSER BAR SPRING	1
18	41701008	MOTOR BRACKET	1
19	41712063	WORK CLAMP MOTOR PLATE	1
20	S05121	BOLT SOCKET M5 X 10	2
21	141733010	PULSE MOTOR ASSY Z	1
22	41730044	MOTOI HARNESS P	1
23	S05133	BOLT SOCKET M4 X 12	4
24	41725009	WORK CLAMP DRIV NG GEAR	1
25	S10019	SET SCREW SOCKET (FT) M6 X 6	2
26	41702020	WORK CLAMP FULCRUM SHAFT	1
27	B10015	BALL BEARING 6900ZZ	2
28	H03008	RETAIN NG RING EXTERNAL C10	2
29	S04035	SCREW PAIN M4 X 6	1
30	W01001	WAS也R PLAIN M4	1
31	41725010	WORK CLAMP CAM GEAR	1
32	S10021	SET SCREW SOCKET (CN) M6 X 10	1
33	S10019	SET SCREW SOCK ET (FT)M6 X 6	1
34	4171000200	WORK CLAMP CAM	1
37	S10019	SET SCREW SOCKET (FT)M6 X 6	1
38	4170301700	WORK CLAMP H-POS TION DOG	1
39	S05115	BOLT SOCKET M4X 6	1
40	41702025	WORK CLAMP LEVER SHAFT	1
41	S10019	SET SCREW SOCKET (FT) M6 X 6	1
42	41709023	STEPPING W-CLAMP DRIVING LEVER	1
43	41702022	W-CLAMP LIFTER ROLLER SHAFT	1
44	B04026	BALL BEARING RAD AL 696ZZ	1
45	41728005	WASHER	1
46	S09019	SET SCREW SOCKET (FT) M5 X 5	1
47	400683	WORK CLAMP DRIVING SHAFT	1
48	41702022	W-CLAMP LIFTER ROLLER SHAFT	1
49	B04026	BALL BEARING RAD AL 696ZZ	1
50	41728005	WASHER	1
51	S09019	SET SCREW SOCKET (FT) M5 X 5	1
52	41728001	WASHER PLAIN 10	1
53	41712061	WORK CLAMP CAM STOPPER	1
54	S04035	SCREW PAN M4 X 6	2
55	41712062	WORK CLAMP SENSOR PLATE	1
56	S04035	SCREW PAN M4 X 6	2
57	S10019	SET SCREW SOCKET (FT) M6 X 6	1
59	S05110	BOLT SOCKET M6 X 12	2

Page 113 — D3、抬压装置/Work clamp lifter mechanism

Jack JK-T1310 / JK-T2210 parts on page 113
Ref	Part number	Part name	Qty
1	41701008	MOTOR BRACKET	1
2	41712063	WORK CLAMP MOTOR PLATE	1
3	S05121	BOLT SOCKET M5X10	2
6	S05133	BOLT SOCKET M4X10	4
7	41725009	WORK CLAMP DRIVING GEAR	1
8	S10019	SET SCREW SOCKET M6X6	2
9	41702020	WORK CLAMP FULCRUM SHAFT	1
10	B10015	BALL BEARING 6900ZZNR	2
11	H03008	RETAINING RING EXTERNAL C10	2
12	S04035	SCREW PAN M4X6	1
13	W01001	WASHER PLAIN M4	1
14	41725010	WORK CLAMP CAM GEAR	1
15	S10021	SET SCREW SOCKET M6X10	1
16	S10019	SET SCREW SOCKET M6X6	1
17	4170301700	WORK CLAMP H-POSITION DOG	1
18	S05115	BOLT SOCKET M4X6	1
19	41702025	WORK CLAMP LEVER SHAFT	1
20	S10019	SET SCREW SOCKET M6X6	1
21	41709023	STEPPING W-CLAMP DRIVING LEVER	1
22	41702022	W-CLAMP LIFTER ROLLER SHAFT	1
23	B04026	BALL BEARING RADIAL 696ZZ	1
24	41728005	WASHER	1
25	S09019	SET SCREW SOCKET M5X5	1
26	41712062	WORK CLAMP SENSOR PLATE	1
27	S04035	SCREW PAN M4X6	2
29	S05110	BOLT SOCKET M6X12	2
33	41708302	SET SCREW COLLAR	1
34	S10019	SET SCREW SOCKET M6X6	2
35	S10019	SET SCREW SOCKET M6X6	1
40	41728001	WASHER PLAIN 10	1

Page 115 — E、下轴装置/Lower shaf t mechan sm

Jack JK-T1310 / JK-T2210 parts on page 115
Ref	Part number	Part name	Qty
1	417S20062	SHOULDER SCREW	1
2	417S16001	NUT(FT) M6	1
3	41725011	ROCK GEAR	1
4	41702027	ROCK GEAR SHAFT	1
5	41708002	SET SCREW COLLAR 8	1
6	S09041	SET SCREW SOCKET (FT) M6 X 5	2
7	41708006	SET SCREW COLLAR	1
8	S10018	SET SCREW SOCKET (FT) M6 X 6	2
9	S10019	SET SCREW SOCKET (FT) M6 X 6	2
10	4170202800	LOWER SHAFT ASSY	1
10-1	41702028	LOWER SHAFT	1
10-2	S09019	SET SCREW SOCKET (FT) M5 X 5	1
12	41703019	LOWER SHAFT BUSH	1
13	S10019	SET SCREW SOCKET (FT) M6 X 6	1
14	41702029	ADJUSTING STUD	2
15	41722015	o RING PW3	2
16	41701009	SHUTTLE RACE BASE ASSY G	1
17	41712190	SHUTTLE RACE THREAD GUIDE	1
18	417S15007	SCREW M3 X 4	2
19	41712601500	S-RACE BASE SETTING CLAW	2
20	41727006	COMPRESSION SPRING	2
21	W01002	WASHER PLAIN M3	2
22	S04082	SCREW PAN M3 X 6	2
23	41723013	S-RACE BASE FELT	2
29	41723012	FELT L=360	2
30	S10019	SET SCREW SOCKET (FT) M6 X 6	1
31	H05032	RETAINING RING E7	1
32	41718001	DRWER D	1
33	S05122	80LT SOCKET M5 X 12	1
34	41718002	SHUTTLE RACE BASE	1
35	4171801700	BOBBIN CASE ASSY	1
36	41727015	TENSION SPRING	1
37	417S30005	SCREW	1
38	41727016	ANTI-SPIN SPRING	1
39	41718004	BOBBIN	1
40	41703020	SET SCREW COLLAR R	1
41	S09019	SET SCREW SOCKET (FT) M5 X 5	1
42	41718018	SHUTTLE HOOK	1
43	12923018	W ICK 4X4 L=400	1
44	41711027	BUSH	1
45	41724008	NEEDLE BEARING	2
46	41711028	SPACER COLLER	2
47	41729005	RETAINING RING	2

Page 117 — F、供油润滑装置 / Lubrication

Jack JK-T1310 / JK-T2210 parts on page 117
Ref	Part number	Part name	Qty
1	417S30022	SET SCREW	1
2	41712065	CRANK COVER	1
3	S04038	SCREW PAN M6X10	3
4	41712066	CRANK WICK PLATE	1
5	S04035	SCREW PAN M4X6	2
6	41723027	FLAT WICK	0.27
7	41723005	FELT	1
8	41712067	LOWER SHAFT WICK SUPPORT	1
9	41723006	LOWER SHAFT GEAR FELT	1
10	S04035	BOLT SOCKET M4X6	2
11	41712068	WICK SUPPORT	1
12	S04035	SCREW PAN M4X6	1
14	41723026	FLAT WICK	1
16	12921002	OIL TUBE	0.21
17	41712069	WICK SUPPORT	1
18	41712070	WICK SUPPORT	1
19	41711003	OIL GAUGE WINDOW	1
19	41711021		1
19	41722030		1
20	41711004	OIL GAUGE WINDOW	1
20	41711022		1
20	41722031		1
23	12923018	WICK 4X4	0.68
24	12921002	OIL TUBE	0.45
25	12921005	OIL TUBE	0.3
25	12923018	WICK 4X4	0.4
26	12923019	WICK 6X6	0.3
27	41723011	FELT	4
30	41712071	GEAR WICK SUPPORT	1
31	41723031	GEAR FELT	1
32	41712072	LOWER SHAFT WICK SUPPORT B	1
33	S04033	SCREW PAN M6X8	1
34	41712073	TUBE HOLDER	1
35	S04035	SCREW PAN M4X6	1
36	12923019	WICK 6X6	0.7
37	12921005	OIL TUBE	0.82
38	41711014	CORD HOLDER 6.4	1
39	41711016	CORD HOLDER 8.4	1
40	417S30025	SCREW PAN(S/P WASHER) M4X10	1
40	417S30025	SCREW PAN(S/P WASHER) M4X10	6
41	41711014	CORD HOLDER6.4	1
42	417S30025	SCREW PAN(S/P WASHER) M4X10	5
43	41712074	OIL COVER	1
45	403S11043	SCREW PAN M4X10	5
46	41736001	TERMINAL L	1
47	41722016	RUBBER CAP 4.2	1
52	41723026	WICK 2.5X200	0.2
53	12921002	OIL TUBE	0.11
54	41736002	OIL FEEDING PIPE	1
55	41711016	CORD HOLDER 8.4	2
60	12921002	OIL TUBE	0.3
61	41711015	CORD HOLDER 13.2	6
63	41712110	WICK SUPPORT L	1
64	41723024	FELT BED L	1
65	S04035	SCREW PAN M4X6	3

Page 119 — F、供油润滑装置 / Lubrication

Jack JK-T1310 / JK-T2210 parts on page 119
Ref	Part number	Part name	Qty
66	028040246	WASHER SPRING 2-4	3
67	SA6582001	WICK SUPPORT R	1
68	SA6584001	FELT BED R	1
69	S25310101	SCREW FLAT M4X9	3

Page 121 — G. 穿线装置/Threading mechanism

Jack JK-T1310 / JK-T2210 parts on page 121
Ref	Part number	Part name	Qty
1	41712077	ARM THREAD GUIDE A	1
2	S04030	SCREW PAN M5 X 6	1
3	41712078	ARM THREAD GUIDE B	1
4	S04030	SCREW PAN M5 X 6	1
5	41712079	ARM THREAD GUIDE C	1
6	S04030	SCREW PAN M5 X 6	1
7	41702030	UPPER THREAD GUIDE STUD	1
8	41713001	TENSION BRACKET	1
9	41713002	THREAD TAKE-UP SPRING	1
10	41713003	TENSION STUP	1
11	138S16013	TENSION NUT	1
12	41713005	TENSION DISC PRESSER	1
13	41713006	DISC TENSION	1
14	417515012	SET SCREW SM3. 75	1
15	S12001	SET SCREW (FT) M6 X 8	1
16	41702031	TEN5ION RELEASE PIN	1
17	41713007	TENSION STUD A	1
18	41713006	DISC TENSION	2
19	41712080	THREAD GUIDE ARM	1
19	41722320	RUBBER	1
19	N01024	NUT M4	1
20	41726014	NEEOLE SLEEVE	1
21	41712082	N-BAR BUSH THREAD GUIDE D	1
22	41203018	NEEDLE COOLER ASSY	1
22	41222019	RUBBER	1
23	S10019	SET SCREW S0CKET (FT) M6 X 6	1
24	41223043	FELT 8 X 15.5	1
25	41213008	NEEDLE COOLER THREAD GUIDE	1
26	409S11017	SCREW PAN SM3. 57-40 X 4	1
27	41713009	TENSION NUT	1
28	41713012	SUB TENSION SPRING	1
29	41713011	WASHER	1
30	41713010	TENSION SPRING	1
31	4171302000	MAIN TENSION ASSY Q	1
32	4171301400	DEPUTY TENSION ASSY	1

Page 123 — H、卷线装置/Bobbin winder mechanism

Jack JK-T1310 / JK-T2210 parts on page 123
Ref	Part number	Part name	Qty
1	301382	TOP COVER	1
2	41702033	SHAFT BW-LEVER	1
3	S09019	SET SCREW SOCKET (FT) M5 X 5	1
4	41709026	BOBBIN WINDER LEVER	1
5	41702034	SPRING HOOK	1
6	41712084	PLATE SPRING	1
7	41712085	WASHER	1
8	S04077	SCREW PAN M3. 5 X 6	1
9	W01015	WASHER	1
10	H05006	RETAINING RING E5	1
11	41702035	STUD B-WINDER	1
12	41709027	BOBBINPRESSER ARM	1
13	S01081	SCREW PAN 4 X 12	1
14	41712086	BOBBIN PRESSER	1
15	417S15006	SCREW M4 X 5	1
16	41709028	CLAW B-WINDER	1
17	S09006	SET SCR EW SOCKET (FT)M4 X 4	2
18	41727007	SPRING TWIST	1
19	H05006	RETA NING RING E5	2
20	41708025	SPRCER COLLER	1
21	41702036	BOBBIN WINDER SHAFT	1
22	11703021	WHEEL B-WINDER	1
23	41722017	BOBBIN WINDER RUBBER BAND	1
24	S09006	SET SCREW SOCKET (FT) M4 X 4	2
25	W01015	WASHER	2
26	41711063	BOBBIN SUPPORT	1
27	41727008	SPRING	1
28	41702037	STPPER SHAFT B-WINDER	1
29	41719001	KNIFT	1
30	S04030	SCREW PAN M5 X 6	1
31	4171302100	BOBBIN WINDER TENS ON ASSY Q	1
32	41713006	DISC TENSION	2
33	12927016	TENSION SPR NG	1
34	138S16013	TENSION NUT	1
35	41713011	WASHER	1
36	S09019	SET SCREW SOCKET (FT) M5 X 5	1
37	S04038	SCREW PAN M6 X 10	6
38	41704002	DR VING WHEEL B-WINDER	1
39	S10018	SET SCREW SOCKET (FT) M6 X 6	2

Page 125 — J、切线装置 / Thread trimmer mechanism

Jack JK-T1310 / JK-T2210 parts on page 125
Ref	Part number	Part name	Qty
1	41710003	THREAD TRIMMER CAM	1
2	S10018	SET SCREW SOCKET (FT) M6 X 6	3
3	41712087	SETTING PLATE SOLENOID	1
4	41730001	THREAD TRIMMER SOLENOID	1
5	L02031	BOLT M4X8	2
6	W02008	WASHER SPRING 2-4	4
7	W01001	WASHER PLAIN M4	2
8	41702038	SOLENOID LEVER	1
9	S09006	SET SCREW SOCKET (FT) M4 X 4	1
11	41728033	WASHEWR	1
13	417S30306	BOLT SCREW SOCKET M5 X 10	2
14	41712088	PUSHING LEVER D-LEVER	1
15	417S30012	SHOULDER SCREW 7-3	1
16	4171211100	TR-DRIVING LEVER	1
17	41703022	COLLAR TR-TRIMMER	1
18	41702039	COLLAR SHAFT	1
19	417S12009	SET SCREW M4 X 5	1
20	H05029	RETAINING RING E4	1
21	41702040	TIIREAD TRIMMER RODV	1
22	4170500300	BALL JOINT ASSY	2
23	N01021	NUT 1 M6	2
24	417S12005	SHOULDER SCREW B M6	1
25	N01012	NUT 3 M6	1
26	S10018	SET SCREW SOCKET (FT) M6 X 6	1
27	41703023	BUSH 8X15	1
28	41702041	GUIDE SHAFT	1
29	41727009	SPRING COMPRESSION	1
30	41722018	CUSHION	1
31	417S12005	SHOULDER SCREW B M6	1
32	N01012	NUT 3 M6	1
33	417S10003	SET SCREW M6 x 19	1
34	N01021	NUT 1 M6	1
35	41712089	THREAD TRIMMER LEVER V	1
36	41712090	THREAD TRIMMER LEVER H	1
37	41712091	THREAD TRIMMER ROD H	1
38	4170500300	BALL JOTNT ASSY	2
39	N01021	NUT 1 M6	2
40	417S12005	SHOULDER SCREW B M6	1
41	N01012	NUT 3 M6	1
42	41702042	SHAFT TR-TRIMMER LEVER	1
43	41728023	SPACER	2
44	H03006	RETAINING RING EXTERNAL C8	1
45	S10019	SET SCREW SOCKET (FT) M6 X 6	2
46	41712092	SPRING HOOK	1
47	41727010	SPRING EXTENSION	1
48	S05123	BOLT SOCKET M5 x 12	1
49	W02001	WASHER SPRING 2-5	1

Page 127 — J, 切线装置 / Thread trimmer mechanism

Jack JK-T1310 / JK-T2210 parts on page 127
Ref	Part number	Part name	Qty
50	41728028	WASHER PLAIN 5	1
51	41709029	MOVING KNIFE LEVER	1
52	417S12007	SHOULDER SCREW 6. 35-6	1
53	41702043	SHAFT MOVABLE KNIFE LEVER	1
54	S10019	SET SCREW SOCKET M6X6	1
55	41712093	M-KNIFE CONNECTINC PLATE	1
56	417S30013	SHOULDER SCREW 6—1.8	1
57	4171500100	NEEDLE PLATE A	1
58	4170903000	MOVABLE KNIFE ASSY F	1
59	417S30014	MOVABLE KNIFE SHOULDER SCREW	1
60	41728007	THRUST WASHER	1
61	41728008	MOVABLE KNIFE COLLAR	1
62	41728009	M-KNIFE SPACER T0.2	1
62	41728009	M-KNIFE SPACER T0.3	1
62	41728009	M-KNIFE SPACER T0.4	1
63	41719002	FIXED KNIFE F	1
64	S04036	SCREW PAN M3 x 4	2
65	W01002	WASHER PLAIN M3	2
66	41712094	NEEDLE HOLE PLATE	1
67	417S17001	SCREW	2
68	S02039	BOLT SOCKET M4 x 9	2
69	417S15008	BOLT SOCKET M4 x 8	2
70	41712095	SHUTTLE BASE COVER HOOK U	1
71	w02007	WASHER SPRING 2-3	2
72	W01002	WASHER PLAIN M3	2
73	S04036	SCREW PAN M3 X 4	2

Page 129 — K, 扫线装置/Thread wiper mechanism

Jack JK-T1310 / JK-T2210 parts on page 129
Ref	Part number	Part name	Qty
1	41730002	THREAD WIPER SOLENOIO ASSY	1
1-2	41727011	THREAD WIPER SPRING	1
3	41728011	WASHER PLAIN	1
1-4	41726007	PLUNGER PIN	3
5	41712210	T-WIPER SOLENOID SETTING PLATE	1
6	41711210	SOLENOIO COVER Q	1
7	S04082	SCREW PAN M3 X 6	6
8	41712096	THREAD WIPER SHAFT BRACKET	1
9	S05116	BOLT SOCKET M4x8	1
10	W01001	WAS HER PLAN M4	1
11	4170204400	THREAD WIPER CRANK ASSY	1
12	H05029	RETAINING RING E4	1
13	41708007	SET SCREW COLLAR	1
14	417S15005	SET SCREW (CP)M3. 5-5	1
15	41727012	SPRING	1
16	41722012	RUBBER WASHER	1
17	41712097	THREAD WIPER ROD	1
18	W01024	WASHER	1
19	H05002	RETAINING RING E3	1
20	41712098	WIPER	1
21	417S15013	SCREW BIND M4 X 5	1
22	41708008	THREAD WIPER STUD COLLAR	1
23	41728034	WASHER	1
24	41730003	STOP SWITCH ASSY	1
25	417S30306	BOLT SOCKET (S/P WASHER) M5 X 15	2
26	41730022	SOLENOID VALVE WIRING	1
27	41730059	WIPER SWITCH PLUG INS B	1
28	141730001	STOP SWITCH PLUG INS B	1

Page 131 — L, 松线装置/Tension release mechanism

Jack JK-T1310 / JK-T2210 parts on page 131
Ref	Part number	Part name	Qty
1	SA485500 1	TENSION RELEASE SOLENOID HV	1
2	17400802	BOLT M4 X 8	2
3	28040246	WASHER SPRINC 2-4	2
4	25040236	WASHER PLAIN M4	2
5	17401415	BOLT M4 X 18	1
1-6	21400306	NUT 3 M4	1
1-7	25040236	WASHER PLANT M4	1
1-8	154599000	SOLENOID CUSHION	1
9	SA6389001	SETTING PLATE SOLENOID	1
1-10	S04159000	BAND 1M	1
11	SA3347001	TENSION RELEASE BAR	1
12	48040342	RETA INING RING E4	1
13	25050236	WASHER PLAIN M5	1
14	SA3348001	SPRING COMPRESSION	1
15	SA3349001	SOLENOID COVER	1
16	SA3306001	SHOULDE SCREW 7-3	2
17	81007070	O RING P7	2
1-18	218859001	BINOER M150	1

Page 133 — M、电控装置/Electronic control device

Jack JK-T1310 / JK-T2210 parts on page 133
Ref	Part number	Part name	Qty
1	41730450	BASE PLATE	1
2	41330121	SHORT COLUMNS	5
3	41730451	FRONT PLATE	1
4	41330124	LONG COLUMNS	7
5	41730449	PCB 1	1
6	41730452	COVER	1
7	41330129	SCREW	12
8	41730453	BACK PLATE	1
9	41730448	PCB 2	1
10	4173044800	CONTROL PANEL	1
11	41730446	TOUCH-SCREEN	1
12	41730454	FRONT COVER	1
13	810087	SUPPORT STRIP	1
14	41730447	PCB 3	1
15	41730455	BACK COVER	1
16	810530	CONNECTERS	1

Page 135 — P、空压装置/Air pressure mechanism

Jack JK-T1310 / JK-T2210 parts on page 135
Ref	Part number	Part name	Qty
1	42130096	VALVE VHK3	1
2	141845004	AIR VALVE	1
3	417S30026	TOINT	1
4	407S12002	SCREW	2
5	41730014	MANIFOLD2	1
6	40728003	SILENCER	2
7	41730012	VALVE M5B075-02-R-B	2
8	41730013	VALVE CONNECTOR	4
9	41730033	BLANK NG PLATE ASSY	3
10	417S30024	80LT SOCKET M4 X 30	2
11	41712106	SETTING PLATE VALVE	1
12	N01024	NUT M4	2
13	417S30025	SCREW PAN M4X10	1
14	41711016	CORD HOLDER 13.2	1
17	61911006	AIR TUBE L	2
18	61911006	AIR TUBE R	2
19	61911006	AIR TUBE R	2
20	61911006	AIR TUBE L	2

Page 137 — Q、电气部品装置/Power supply equipment mechanism

Jack JK-T1310 / JK-T2210 parts on page 137
Ref	Part number	Part name	Qty
1	525567000	CORD HOLDER 13.2	3
2	149547000	CORD HOLDER 6.4	1
3	525567000	CORD HOLDER 16	3
4	OA5401006	SCREW PAN M4X10DB	7
5	SA4830001	H-POSITION SENSOR ASSY	1
6	62300816	SCREW PAN M3X8	3
7	SA3481001	SWITCH ASSY MACHINE HEAD	1
8	OA5301605	SCREW PAN(S/PWASHER) M4X16DB	2
9	OA5401006	SCREW PAN(S/PWASHER) M4X10DB	2
10	SA4824001	HEAD DETECTOR UNIT ASSY	1
11	SA5210001	THREAD WIPER SOLENOID HARNESS	1
12	SA521400 1	STOP SWITCH HARNESS	1
13	SA5261001	GROUND WIRE 450	1
14	OA5401006	SCREW PAN(S/P WASHER) M4 X 10D8	1
15	554482000	CORD HOLDER 19	1
16	554482000	CORD HOLDER 23	1
17	OA5401006	SCREW PAN(S/P WASHER)M4X 10	2
21	S04159000	BAND	8

Page 139 — S、马达装置/Motor mechanism

Jack JK-T1310 / JK-T2210 parts on page 139
Ref	Part number	Part name	Qty
1	4173004700	MOTOR ASSY CDD-430D	1
2	41730048	DRUM CDD	1
3	S09044	SET SCREW SOCKET (CP)M4X6	1
4	41730049	MAGNET 180P36	1
5	41730050	MR SENSOR ASSY 180P	1
6	S13003	SCREW PAN(S/P WASHER)M3X8	1
7	41730051	SHIELD PLATE CDD	1
8	417S30017	SCREW PAN(S/P WASHER)M2.6X10	3
9	41730052	NEC PCB ASSY 430D#2	1
10	417S30018	SCREW PAN(S/P WASHER)M3X6	3
11	41712118	CORD HOLDER CDD-HT	1
12	417S30019	SCREW PAN(S/P WASHER)M4X10	3
13	41730053	ENCODER COVER 430D	1
14	S13003	SCREW PAN(S/P WASHER)M3X8	3
15	41709003	PULLEY HOLDER ASSY 430D	1
16	S09045	SET SCREW SOCKET (CP)M5X6	2

Page 141 — T、踏板关系/Foot switch pedal mechanism

Jack JK-T1310 / JK-T2210 parts on page 141
Ref	Part number	Part name	Qty
1	4173001200	TREADLE UINT.A ASSY	1
2	4173004500	2-PEDAL FOOT SWITCH SW ASSY	1
3	41727018	SPRING COMPRESSION 10×30	1
4	41727018	FOOT PEDAL SPRING	2
5	41730046	PIN BUTTON MICRO SWITCH VX	3
6	41712115	FOOT PEDAL	2
7	41712116	PROTECTION PLATE PEDAL	2
8	41712117	SPRING PLATE	2

Page 143 — Z、附件/Accessories

Jack JK-T1310 / JK-T2210 parts on page 143
Ref	Part number	Part name	Qty
1	41711212	MOTOR COVER Q	1
3	S04038	SCREW PAN M6 X 10	4
4	41711031	OIL PAN	1
5	41711006	DUST OILER COVER	1
7	41722005	RUBBER CUSHION	3
8	101530010	NAIL	7
9	41711066	DUST OILER	1
10	20131076	ACCESSORY BAG	1
11	41712355	SCREW-DRIVER FOR	1
12	41718004	BOBBIN LAN	3
13	41532020	CASTERS	4
14	41217002	NEEDLE	5
15	11631008	OILER ASSY	1
16	1011101200	OIL TANK ASSY	1
17	10131004	SCREW-DRIVER 1.9 X 52	1
18	10131003	SCREW-DRIVER 3.4 X 70	1
19	10131002	SCREW-DRIVER 5.5 X 190	1
20	30131005	WRENCH 6 X 7	1
21	30131006	WRENCH 8 X 10	1
22	20131051	TWEEZERS	1
23	30131007	HEXAGONAL WRENCH 1.5	1
24	20131046	HEXAGONAL WRENCH 2	1
25	30131010	HEXAGONAL WRENCH 2.5	1
26	30131012	HEXAGONAL WRENCH 3	1
27	30131047	HEXAGONAL WRENCH 4	1
28	20131056	HEXAGONAL WRENCH 5	1
29	1383100300	COTTON STAND ASSY	1
30	40730010	SPIRAL TUBE	1
31	40736001	SPIRAL TUBE JOINT	1
78	140744001	RUST-PROOF BAG	1
82	4121208400	EYE GUARD ASSY	1
83	4121208100	HINGE ASSY	1
84	41212082	EYE GUARD HINGE	1
88	41211005	EYE GUARD	1
89	412S17004	SCREW FLAT SM3. 18-40 X 8	2
90	412S16012	NUT M3. 18	2
91	41228047	WASHER PLAIN M3	2
92	41211005	EYE GUARD HOLDER A	2
93	401S11022	SCREW PAN SM3.57-40 X 5	2
94	S04035	SCREW PAN M4 X 6	2

Page 145 — Z、附件/Accessories

Jack JK-T1310 / JK-T2210 parts on page 145
Ref	Part number	Part name	Qty
97	SA3395001	RUBBER CUSHION	2
98	SA3392001	SPACER	2
99	SA3384001	PIN	2
100	12060636	SET SCREW SOCKET (CP) M6 X 6	2
101	SA3385001	HINGE HOLDER	2
102	18066036	BOLT SOCKET M6 X 50	4
103	213650001	WASHER 2.3 X 8.5 X 38	4
105	21060106	NUT M6	4
106	SA3540001	RUBBER CUSHION	4
107	SA4845001	SHOCK ABSORBER GAS	1
108	41712113	HOLDER ABSORBER	2
109	SA5251001	SPACER	I
110	18064031	BOLT SOCKET M6 X 40	1
111	21060106	NUT 1 M6	1
112	SA4847001	SHAFT U	I
113	12060636	SET SCREW SOCKET (CP) M6 X 6	1
114	S17974001	SHAFT D	1
115	S17975100	SHAFT COLLAR GAS	2
116	25080132	WASHER PLAIN S8	2
117	48060342	RETAINING RING E6	2
118	SA3387001	BOLT SOCKET M6 X 60	2
119	25060236	WASHER PLAIN M6	2
120	213650001	WASHER 2.3 X 8.5 X38	2
121	28060246	WASHER SPRING 2-6	2
122	21060106	NUT 1 M6	2
128	41712114	HOLDER ABSORBER COVER	1
129	S55479001	BOLT SOCKET(S/P WASHER)M4 X 8	6

Page 146 — Ga. 工具一览表 / Gauge parts list

Jack JK-T1310 / JK-T2210 parts on page 146
Ref	Part number	Part name	Qty
	S42843-001
	S42844-001
	S42845-001
	S42846-001
	S42847-001
	157237-001
	158592-001
	S42848-001
	S40214-001	A-CUT
	S49448-001	B-L
	S42849-101	XA
	SA4811-001	H
	SA3336-001	2.4 C0.4
	SA5221-001
	SA5222-001	3.0 C1.5

Jack JK-T1310 / JK-T2210 Parts Book (PDF)

Page 95 — A、机体部分/Machine body

Page 97 — B. 上轴·针杆装置/Upper shaft and needle bar mechanism

Page 99 — C1、送料装置 / Feed mechanism

Page 101 — C2、送料装置 / Feed mechanism

Page 103 — C2、送料装置 / Feed mechanism

Page 105 — C3、送料装置/Feed mechanism (T1310)

Page 107 — C4、送料装置/Feed mechanism

Page 109 — D1、拾压脚装置/Work clamp lifter mechanism

Page 111 — D2、拾压装置/Work clamp lifter mechanism (T1310)

Page 113 — D3、抬压装置/Work clamp lifter mechanism

Page 115 — E、下轴装置/Lower shaf t mechan sm

Page 117 — F、供油润滑装置 / Lubrication

Page 119 — F、供油润滑装置 / Lubrication

Page 121 — G. 穿线装置/Threading mechanism

Page 123 — H、卷线装置/Bobbin winder mechanism

Page 125 — J、切线装置 / Thread trimmer mechanism

Page 127 — J, 切线装置 / Thread trimmer mechanism

Page 129 — K, 扫线装置/Thread wiper mechanism

Page 131 — L, 松线装置/Tension release mechanism

Page 133 — M、电控装置/Electronic control device

Page 135 — P、空压装置/Air pressure mechanism

Page 137 — Q、电气部品装置/Power supply equipment mechanism

Page 139 — S、马达装置/Motor mechanism

Page 141 — T、踏板关系/Foot switch pedal mechanism

Page 143 — Z、附件/Accessories

Page 145 — Z、附件/Accessories

Page 146 — Ga. 工具一览表 / Gauge parts list

Part Books

Search

Parts on page 1

Parts on page 1

Page 95 — A、机体部分/Machine body

Page 97 — B. 上轴·针杆装置/Upper shaft and needle bar mechanism

Page 99 — C1、送料装置 / Feed mechanism

Page 101 — C2、送料装置 / Feed mechanism

Page 103 — C2、送料装置 / Feed mechanism

Page 105 — C3、送料装置/Feed mechanism (T1310)

Page 107 — C4、送料装置/Feed mechanism

Page 109 — D1、拾压脚装置/Work clamp lifter mechanism

Page 111 — D2、拾压装置/Work clamp lifter mechanism (T1310)

Page 113 — D3、抬压装置/Work clamp lifter mechanism

Page 115 — E、下轴装置/Lower shaf t mechan sm

Page 117 — F、供油润滑装置 / Lubrication

Page 119 — F、供油润滑装置 / Lubrication

Page 121 — G. 穿线装置/Threading mechanism

Page 123 — H、卷线装置/Bobbin winder mechanism

Page 125 — J、切线装置 / Thread trimmer mechanism

Page 127 — J, 切线装置 / Thread trimmer mechanism

Page 129 — K, 扫线装置/Thread wiper mechanism

Page 131 — L, 松线装置/Tension release mechanism

Page 133 — M、电控装置/Electronic control device

Page 135 — P、空压装置/Air pressure mechanism

Page 137 — Q、电气部品装置/Power supply equipment mechanism

Page 139 — S、马达装置/Motor mechanism

Page 141 — T、踏板关系/Foot switch pedal mechanism

Page 143 — Z、附件/Accessories

Page 145 — Z、附件/Accessories

Page 146 — Ga. 工具一览表 / Gauge parts list

Jack JK-T1310 / JK-T2210 — parts catalog
