Page 16 — 七、弯针部件/Needle guard assemblies
Jack K5-UT parts on page 16| Ref | Part number | Part name | Qty |
|---|
| 30210002 | 偏心套 | |
| S10015 | 螺钉M6×0.75×4 | |
| B07009 | 轴承K26×30×12.7 | |
| 30205003 | 连杆 | |
| 30226005 | 滑杆销 | |
| N01004 | 螺母M5 | |
| W01004 | 连杆轴垫圈 | |
| 30201010 | 滑杆架 | |
| 30203045 | 油棉盖 | |
| 30223014 | 油棉 | |
| 12921002 | 回油管 | |
| 30202007 | 下弯针连杆轴 | |
| 30228006 | 垫片 | |
| S05048 | 螺钉M4×10 | |
| W02002 | 垫圈4 | |
| 30228005 | 垫片 | |
| 30204004 | 下弯针轴柄 | |
| S05002 | 螺钉M6×0.75×15.2 | |
| 30201011 | 前挡块 | |
| S04019 | 螺钉M4×12 | |
| 30228003 | 下弯针轴柄垫片 | |
| 30209003 | 弯针滑块 | |
| 30209004 | 弯针滑块螺钉垫 | |
| S10007 | 螺钉M4×4 | |
| 30201012 | 下弯针轴柄后挡块 | |
| 30201101 | 弯针固定架 | |
| 30221018 | 铜油嘴 | |
| 30213050 | 滑杆过线 | |
| S10007 | 螺钉M4×4 | |
| 30217003 | 弯针 | |
| 30228004 | 下弯针轴柄挡块垫片 | |
| 30203007 | 滑杆后套 | |
| S10013 | 螺钉 | |
| 30203044 | 滑杆前套 | |
| 001021 | O型圈12.2×2.4 | |
| 30228002 | 弯针固定架垫片 | |
| 30202006 | 滑杆 | |
| S05046 | 螺钉M3.5×10.5 | |
| S01006 | 螺钉 | |
| 30226017 | 弹性圆柱销 | |
七、弯针部件/Needle guard assemblies
序号
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
部件号
Parts No.
30210002
S10015
B07009
30205003
30226005
N01004
W01004
30201010
30203045
30223014
12921002
30202007
30228006
S05048
W02002
30228005
30204004
S05002
30201011
S04019
30228003
30209003
30209004
S10007
30201012
30201101
30221018
30213050
S10007
30217003
30228004
30203007
S10013
30203044
001021
30228002
30202006
S05046
S01006
30226017
参考件号
Ref.Part.No.
252036-92
7128
206172
252035
252037-91
4805
240062
252039
252044
240232
4524\7110
201252
240231
252046-92
4534
252040-92
7021A
252041
252042
252043
4543
252045-92
7129
257566
252047
252052
252049-91
231011
252055
252048
名称
Description
偏心套
螺钉M6×0.75×4
轴承K26×30×12.7
连杆
滑杆销
螺母M5
连杆轴垫圈
滑杆架
油棉盖
油棉
回油管
下弯针连杆轴
垫片
螺钉M4×10
垫圈4
垫片
下弯针轴柄
螺钉M6×0.75×15.2
前挡块
螺钉M4×12
下弯针轴柄垫片
弯针滑块
弯针滑块螺钉垫
螺钉M4×4
下弯针轴柄后挡块
弯针固定架
铜油嘴
滑杆过线
螺钉M4×4
弯针
下弯针轴柄挡块垫片
滑杆后套
螺钉
滑杆前套
O型圈12.2×2.4
弯针固定架垫片
滑杆
螺钉M3.5×10.5
螺钉
弹性圆柱销
sccentric
screw
needle bearing
rod
pin assembly
nut
washer
guide/looper shaft
oil cover
felt
pipe
shaft
washer
bolt
washer
washer
lever
screw
holder
screw
washer
slider
pin
screw
holder
looper holder
joint screw
threadguide
screw
looper
washer
bushing
screw
bushing
o ring
washer
shaft
screw
screw
pin
数量
Numbe
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
1
1
1
注:点划线框代表暂时不用或以改进零件。
16
jintex.in
Page 17 — 八、护针部件/Feed mechanism
Jack K5-UT parts on page 17| Ref | Part number | Part name | Qty |
|---|
| 1 | 1 | |
| 2 | 2 | |
| 3 | 3 | |
| 4 | 4 | |
| 5 | 5 | |
| 6 | 6 | |
| 7 | 7 | |
| 8 | 8 | |
| 9 | 9 | |
| 10 | 10 | |
| 11 | 11 | |
| 12 | 12 | |
| 13 | 13 | |
| 14 | 14 | |
| 15 | 15 | |
| 16 | 16 | |
| 17 | 17 | |
| 18 | 18 | |
| 19 | 19 | |
| 20 | 20 | |
| 21 | 21 | |
| 22 | 22 | |
| 23 | 23 | |
| 24 | 24 | |
| 25 | 25 | |
| 26 | 26 | |
| 27 | 27 | |
| 28 | 28 | |
| 29 | 29 | |
| 30 | 30 | |
| 31 | 31 | |
| 32 | 32 | |
| 33 | 33 | |
| 34 | 34 | |
| 35 | 35 | |
| 36 | 36 | |
| 37 | 37 | |
| 38 | 38 | |
| 39 | 39 | |
| 40 | 40 | |
| 41 | 41 | |
八、护针部件/Feed mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
注:点划线框不时或以改进零件。
17
