Jack H2 — Part Book | Jintex

Jack H2 — parts catalog

Page 16 — 5.上送料部件/Upper feed Parts

Jack H2 parts on page 16
RefPart numberPart nameQty
P03035弹性圆柱销3×8
1147NS20001螺钉 SM1/4×40×7
101S11001螺钉 SM3/16×28 L=9
13526006摆压脚叉形杆销
13505030摆压脚叉形杆(加轴承)
135S20013螺钉 SM1/4×40
135S20014螺钉 SM1/4×40
13505028摆压脚连杆(加轴承)
W02002垫圈4
13601015摆压脚杆座
116S11005螺钉 SM11/64×40×13
114712020提升压脚连接板
114708001压杆压板垫块
13501006压脚杆
135S11030螺钉 SM9/64×40
13516006摆压脚
13516006摆压脚
1147NS20002螺钉 SM1/4×40
114704001压脚送料曲柄(加轴承)
13508008压脚摆动轴前轴套
135S15004螺钉 SM1/4×40×4
13508009底盖
13502023压脚摆动轴
11472200200摆动轴后套油封
13503014压脚摆动中轴套
13504023压脚摆动后曲柄
402S13011螺钉 SM15/64×28×18
135S20005螺钉 SM9/32×28
13505014摆压脚大连杆
135S20004大连杆曲柄连接销
13504022送布曲柄(中)
101S11025螺钉 SM11/64×40×7
116S11005螺钉 SM11/64×40×13
W01002M3垫片

5.上送料部件/Upper feed Parts 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 Number CZ CZZD CZ-12 27 P03035 弹性圆柱销3×8 Spring round pin3×8 2 2 2 28 1147NS20001 螺钉 SM1/4×40×7 Screw SM1/4×40×7 1 1 1 29 101S11001 螺钉 SM3/16×28 L=9 Screw SM3/16×28 L=9 1 1 1 30 13526006 摆压脚叉形杆销 Pin 1 1 1 31 13505030 摆压脚叉形杆(加轴承) Fork lever 1 1 1 32 135S20013 螺钉 SM1/4×40 Screw SM1/4×40 1 1 1 33 135S20014 螺钉 SM1/4×40 Screw SM1/4×40 1 1 1 34 13505028 摆压脚连杆(加轴承) Link of walking foot 1 1 1 35 W02002 垫圈4 Washer 2 2 2 36 13601015 摆压脚杆座 Holder for walking foot bar 1 1 1 37 116S11005 螺钉 SM11/64×40×13 Screw SM11/64×40×13 2 2 2 38 114712020 提升压脚连接板 Lifting presser sway crank guide pin 1 1 1 39 114708001 压杆压板垫块 Shim 2 2 2 40 13501006 压脚杆 Presser rod guide 1 1 1 41 135S11030 螺钉 SM9/64×40 Screw SM9/64×40 1 1 1 42 13516006 摆压脚 Walking foot 1 1 1 13516006 摆压脚 Walking foot 1 1 1 43 1147NS20002 螺钉 SM1/4×40 Screw SM1/4×40 1 1 1 44 114704001 压脚送料曲柄(加轴承) Presser feed crank 1 1 1 45 13508008 压脚摆动轴前轴套 Presser swing shaft front bushing (left) 1 1 1 46 135S15004 螺钉 SM1/4×40×4 Screw SM1/4×40×4 2 2 2 47 13508009 底盖 Shaft washer 1 1 1 48 13502023 压脚摆动轴 Presser swing shaft 1 1 1 49 11472200200 摆动轴后套油封 Oil seal 1 1 1 50 13503014 压脚摆动中轴套 Presser swing middle shaft bushing 1 1 1 51 13504023 压脚摆动后曲柄 Presser swing crank(right) 1 1 1 52 402S13011 螺钉 SM15/64×28×18 Screw SM15/64×28×18 1 1 1 53 135S20005 螺钉 SM9/32×28 Screw SM9/32×28 1 1 1 54 13505014 摆压脚大连杆 Presser swing crank(right)rod 1 1 1 55 135S20004 大连杆曲柄连接销 Pin 1 1 1 56 13504022 送布曲柄(中) Feed rocker shaft crank middle 1 1 1 57 101S11025 螺钉 SM11/64×40×7 Screw SM11/64×40×7 1 1 1 58 116S11005 螺钉 SM11/64×40×13 Screw SM11/64×40×13 1 1 1 59 W01002 M3垫片 Washer 1 1 1 jintex.in

Page 17 — 6.旋接部件/Hook components

Jack H2 parts on page 17
RefPart numberPart nameQty
1SHAFT
2BRACKET
3SCREW
4BRACKET
5SHAFT
6BRACKET
7SHAFT
8SHAFT
9SCREW
10HOUSING
11WASHER
12HOUSING
13BRACKET
14SHAFT
15SHAFT
16SHAFT
17SPRING SEAT
18SPRING
19SHAFT
20SCREW
21SHAFT
22BRACKET
23SHAFT
24PIN
25WASHER
26SPRING SEAT
27HOUSING
28HOUSING
29SPRING
30SCREW
31SHAFT

6.旋接部件/Hook components 3 2 4 9 7 1 9 8 6 22 13 3 21 19 20 5 23 30 24 25 29 26 16 31 14 15 12 11 10 18 17 27 28 jintex.in

Page 18 — 6.旋梭部件/Hook components

Jack H2 parts on page 18
RefPart numberPart nameQty
13502002竖轴
13525001上轴伞齿轮
101s15007螺钉 SM1/4×40×8
13525002竖轴伞齿轮(上)
13525003下轴伞齿轮
13525004竖轴伞齿轮(下)
13503018竖轴轴套(上)
13503019竖轴轴套(下)
135S15008螺钉 SM15/64×28
10818502梭心套组件
10818501梭芯
10818001旋梭(有尾)
13502007下轴
10123003下轴油封
135S20007螺钉 SM3/16×32
13503009下轴前轴套
135S20008螺钉 SM15/64×28
13527005油量调节弹簧
10108002下轴紧固圈
101S11012螺钉 SM11/64×40×4.8
13603025下轴后轴套
135S15009螺钉 SM15/64×28
13502008柱塞
13527006柱塞弹簧
13512009档板
135S11019螺钉 SM15/64×28
13612005旋梭定位勾
101S11011螺钉
W02004档板螺钉弹簧垫圈
13521001下轴油管13612001
10122015下轴油封

6.旋梭部件/Hook components 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 Number CZ CZZD CZ-12 1 13502002 竖轴 Upright shaft 1 1 1 2 13525001 上轴伞齿轮 Gear assembly 1 1 1 3 101s15007 螺钉 SM1/4×40×8 Screw SM1/4×40×8 8 8 8 4 13525002 竖轴伞齿轮(上) Gear 1 1 1 5 13525003 下轴伞齿轮 Pinion 1 1 1 6 13525004 竖轴伞齿轮(下) Gear 1 1 1 7 13503018 竖轴轴套(上) Bushing upper 1 1 1 8 13503019 竖轴轴套(下) Up ring shaft bushing lower 1 1 1 9 135S15008 螺钉 SM15/64×28 Screw SM15/64×28 2 2 2 10 10818502 梭心套组件 Hook assembly 1 1 1 11 10818501 梭芯 Bobbin 1 1 1 12 10818001 旋梭(有尾) Hook assembly (with tail) 1 1 1 13 13502007 下轴 Hook driving shaft 1 1 1 14 10123003 下轴油封 Oil wick 1 1 1 15 135S20007 螺钉 SM3/16×32 Screw SM3/16×32 1 1 1 16 13503009 下轴前轴套 Bushing front 1 1 1 17 135S20008 螺钉 SM15/64×28 Screw SM15/64×28 1 1 1 18 13527005 油量调节弹簧 Spring 1 1 1 19 10108002 下轴紧固圈 Thrust shrink collar 1 1 1 20 101S11012 螺钉 SM11/64×40×4.8 Screw SM11/64×40×4.8 2 2 2 21 13603025 下轴后轴套 Bushing rear 1 1 1 22 135S15009 螺钉 SM15/64×28 Screw SM15/64×28 1 1 1 23 13502008 柱塞 Plunger 1 1 1 24 13527006 柱塞弹簧 Plunger spring 1 1 1 25 13512009 档板 Guide plate 1 1 1 26 135S11019 螺钉 SM15/64×28 Screw SM15/64×28 1 1 1 27 13612005 旋梭定位勾 Rotating hook positioner 1 1 1 28 101S11011 螺钉 Screw 1 1 1 29 W02004 档板螺钉弹簧垫圈 Washer 1 1 1 30 13521001 下轴油管13612001 Oil pipe for hook shaft bushin 1 1 1 31 10122015 下轴油封 Plunger 1 1 1

Page 19 — 7.润滑、供油部件/Oil lubrication components

Jack H2 parts on page 19
RefPart numberPart nameQty
55-55-5
55-65-6
55-15-1
55-25-2
55-35-3
55-45-4
11-11-1
11-21-2
11-31-3
11-41-4
11-51-5
11-61-6
11-71-7
11-81-8
11-91-9
11-101-10
44-14-1
44-24-2
666
777
888
999
101010
111111
121212
131313
141414
151515
161616
171717
181818
191919
202020
212121
222222
232323
242424
252525
262626
272727
282828
292929
303030
111
222
333
444

7.润滑、供油部件/Oil lubrication components 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 6 5-5 5-6 5-1 5-2 5-3 5-4 5 8 9 4 4-1 4-2 1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8 1-9 1-10 2 3 1 jintex.in

Page 20 — 7.润滑、供油部件/Oil lubrication components

Jack H2 parts on page 20
RefPart numberPart nameQty
1352000200油泵组件
13520001油泵体短轴
13520001油泵体
1352006油泵小齿轮
13525005油泵大齿轮
13512021油泵体盖板
13512024油泵滤网
13512022油泵调节板
13512023油泵滤网盖板
S02032油泵体盖板螺钉 M3×6
135S11037螺钉 M3×10
105S11019螺钉 SM11/64×40×13
1352100700上轴油管组件
1362100100下轴油管组件
13621001下轴油管
13636001下轴油管接头
1351202400油线固定板大组件
13512031油线固定板
13512006油线固定板油管(短)
13512005油线固定板油管(长)
13523007油线固定板油线
101S01010复合槽螺钉 SM9/64×40
101S11010油线固定钩
101S11010螺钉 SM9/64×40×11
101S11004螺钉 SM3/16X28 X7
305102小挡油板
14722011油挡板羊毛毡
101S11001螺钉 SM3/16X28×9
304715后盖板
14722006后盖板密封垫片
10111004油窗
10122019油窗O型圈
13522008橡胶塞(Φ25.5)
13522003橡胶塞(Φ8.8)
10122005挑线杆销螺丝塞
13522001面板橡胶塞(Φ19)
13522005橡胶塞(Φ5.7)
14022013A4S-0754孔塞(Φ8.5)
12922001橡胶塞(Φ12.5)
13522002面板橡胶塞(Φ11.8)
201S11014螺钉 SM11/64×40
13512025回油管夹
13523003回油管 Φ3×Φ4
13523003油毡
10423005油线 2.5×260/2.5×290
13522004橡胶塞(Φ27)
112S11014螺钉 SM11/64×40×5.3
13612023挡油板

7.润滑、供油部件/Oil lubrication components 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description CZ 数量 Number CZDD CZ-12 1 1352000200 油泵组件 Oil pump assembly 1 1 1 1-1 13520001 油泵体短轴 Shaft for oil pump 1 1 1 1-2 13520001 油泵体 Oil pump 1 1 1 1-3 1352006 油泵小齿轮 Small gear for oil pump 1 1 1 1-4 13525005 油泵大齿轮 Big gear for oil pump 1 1 1 1-5 13512021 油泵体盖板 Cover for oil pump 1 1 1 1-6 13512024 油泵滤网 Oil pump Filter 1 1 1 1-7 13512022 油泵调节板 Adjusting plate for oil pump 1 1 1 1-8 13512023 油泵滤网盖板 Oil pump Filter cover 1 1 1 1-9 S02032 油泵体盖板螺钉 M3×6 Screw M3×6 2 2 2 1-10 135S11037 螺钉 M3×10 Screw M3×10 3 3 3 2 105S11019 螺钉 SM11/64×40×13 Screw SM11/64×40×13 1 1 1 3 1352100700 上轴油管组件 Oil pipe complete for upper shaft 1 1 1 4 1362100100 下轴油管组件 Oil pipe for arm lower shaft 1 1 1 4-1 13621001 下轴油管 Oil pipe for lower shaft 1 1 1 4-2 13636001 下轴油管接头 Lower shaft Hose connector 1 1 1 5 1351202400 油线固定板大组件 Oil wick set plate complete 1 1 1 5-1 13512031 油线固定板 Oil line fixing plate 1 1 1 5-2 13512006 油线固定板油管(短) Oil line fixing plate oil pipe(short) 1 1 1 5-3 13512005 油线固定板油管(长) Oil line fixing plate oil pipe(long) 1 1 1 5-4 13523007 油线固定板油线 Oil line fixing plate oil line 1 1 1 5-5 101S01010 复合槽螺钉 SM9/64×40 Screw SM9/64×40 1 1 1 5-6 101S11010 油线固定钩 Oil line fixing hook 1 1 1 6 101S11010 螺钉 SM9/64×40×11 Screw SM9/64×40×11 2 2 2 7 101S11004 螺钉 SM3/16X28 X7 Screw SM3/16X28 X7 1 1 1 8 305102 小挡油板 Keep off plate 1 1 1 9 14722011 油挡板羊毛毡 Keep off plate wool felt 1 1 1 10 101S11001 螺钉 SM3/16X28×9 Screw SM3/16X28×9 8 8 8 11 304715 后盖板 Side plate 1 1 1 12 14722006 后盖板密封垫片 Gasket 1 1 1 13 10111004 油窗 Oil sight window 1 1 1 14 10122019 油窗O型圈 O-ring 1 1 1 15 13522008 橡胶塞(Φ25.5) Rubber plug (Φ25.5) 1 1 1 16 13522003 橡胶塞(Φ8.8) Rubber plug (Φ8.8) 1 1 1 17 10122005 挑线杆销螺丝塞 Take-up link pin screw plug 1 1 1 18 13522001 面板橡胶塞(Φ19) Rubber plug (Φ19) 1 1 1 19 13522005 橡胶塞(Φ5.7) Rubber plug (Φ5.7) 2 2 2 20 14022013 A4S-0754孔塞(Φ8.5) Rubber plug (Φ8.5) 1 1 1 21 12922001 橡胶塞(Φ12.5) Rubber plug (Φ12.5) 1 1 1 22 13522002 面板橡胶塞(Φ11.8) Rubber plug (Φ11.8) 1 1 1 23 201S11014 螺钉 SM11/64×40 Screw SM11/64×40 1 1 1 24 13512025 回油管夹 Oil return pipe clamp 1 1 1 25 13523003 回油管 Φ3×Φ4 Oil return pipe Φ3×Φ4 1 1 1 26 13523003 油毡 Oil felt 1 1 1 27 10423005 油线 2.5×260/2.5×290 Oil wick 1 1 1 28 13522004 橡胶塞(Φ27) Rubber plug (Φ27) 1 1 1 29 112S11014 螺钉 SM11/64×40×5.3 Screw SM11/64×40×5.3 2 2 2 30 13612023 挡油板 Keep off plate 1 1 1 jintex.in

Page 21 — 8. 开关组件/Switch components

Jack H2 parts on page 21
RefPart numberPart nameQty
77Screw
66Screw
55Housing
44Bracket
33Screw
22Screw
11Housing

8. 开关组件/Switch components 7 6 5 4 3 2 1 jintex.in

Page 22 — 8.开关组件/Switch components

Jack H2 parts on page 22
RefPart numberPart nameQty
1473000900LED 灯开关组件
101S11004螺钉 SM3/16X28 X7
40112091油管固定架
101S11005螺钉
13628009倒缝电磁铁垫片
302662倒缝电磁铁罩
101S11001螺钉

8.开关组件/Switch components 序 号 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 Number CZ CZZD CZ-12 1 1473000900 LED 灯开关组件 Switch assembly 1 1 1 2 101S11004 螺钉 SM3/16X28 X7 Screw SM3/16X28 X7 2 2 2 3 40112091 油管固定架 Oil tube holder 1 1 1 4 101S11005 螺钉 Screw 1 1 1 5 13628009 倒缝电磁铁垫片 Seals washer 1 1 1 6 302662 倒缝电磁铁罩 Backstitch solenoid cover 1 1 1 7 101S11001 螺钉 Screw 4 4 4 jintex.in

Page 23 — 9.机头附件/Machine head accessories

Jack H2 parts on page 23
RefPart numberPart nameQty
1COVER
2SCREW
3SCREW
4SCREW DRIVER
5NEEDLE
6WASHER
7PRESSER FOOT BAR
7-1PRESSER FOOT BAR HOLDER
7-2PRESSER FOOT BAR
7-3NUT
7-4NUT
8BASE
9SCREW
10WASHER
11COVER
12SCREW
13WASHER
14OIL POT
15BRACKET
16BRACKET
17PRESSER FOOT
18PRESSER FOOT
19COVER
20SPOOL HOLDER
21SPOOL PIN
22THREAD GUIDE
22-1THREAD GUIDE
22-2THREAD GUIDE
22-3THREAD GUIDE
22-4SCREW
23Connecting Rod
24PIN
25BRACKET
26SCREW
27WASHER
28CIRCLIP
29MOTOR
30BRACKET
31SCREW DRIVER

9.机头附件/Machine head accessories 1 2 3 4 5 6 7 7-1 7-2 7-3 7-4 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 22-1 22-2 22-3 22-4 23 24 25 26 27 28 29 30 31 jintex.in

Page 24 — 9.机头附件/Machine head accessories

Jack H2 parts on page 24
RefPart numberPart nameQty
115031022A5-1311 防尘罩
10131004螺钉起子(小)
10131003螺钉起子(中)
20731047螺丝刀
1351203700膝控限位组件
13512026膝控限位夹臂
135S15019膝控限位调节螺钉 M6
N01029螺母 M6
135S12003膝控限位螺钉 M6
1350100900油盘组件
13501007油盘
101S11028放油螺钉 SM5/16×24×7
001047放油螺钉垫圈
13523006油盘垫
13511006膝控提升顶杆
10131001磁块
20131038小油壶
10122060机壳链
1011203100机壳链套
13522001机头防震垫块(大)
10122022机头防震垫块(小)
113511001油袋(600ml)(10#)
1383100300线架组件
10111011机头支柱
1351203800膝控操纵杆组件
13512038膝控操纵杆
10112029膝控磁块
10112030磁块架
101S12004磁块架螺钉 M6×11
13502025膝控铰链轴
13527014膝控复位弹簧
10101008膝控弯杆接头
101S12003螺钉 M8
10122024磁块垫
H05010开口挡圈
11023001700电控脚踏
703725包材
11543100300脚踏连杆
114712003开口扳手(14-10)

9.机头附件/Machine head accessories 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 Number CZ CZZD CZ-12 1 115031022 A5-1311 防尘罩 Machine head cover 1 1 1 2 10131004 螺钉起子(小) Screw driver(small) 1 1 1 3 10131003 螺钉起子(中) Screw driver(middle) 1 1 1 4 20731047 螺丝刀 Screw driver(large) 1 1 1 7 1351203700 膝控限位组件 Knee control limit frame 1 1 1 7-1 13512026 膝控限位夹臂 Knee lifter stop bracket 1 1 1 7-2 135S15019 膝控限位调节螺钉 M6 Screw M6 2 2 2 7-3 N01029 螺母 M6 Nut M6 2 2 2 7-4 135S12003 膝控限位螺钉 M6 Screw M6 1 1 1 1350100900 油盘组件 Oil pan assembly 1 1 1 8 13501007 油盘 Oil reservoir 1 1 1 9 101S11028 放油螺钉 SM5/16×24×7 Screw SM5/16×24×7 1 1 1 10 001047 放油螺钉垫圈 Washer 1 1 1 11 13523006 油盘垫 Gasket 1 1 1 12 13511006 膝控提升顶杆 Knee press lifter rod 1 1 1 13 10131001 磁块 Magnet 1 1 1 14 20131038 小油壶 Oil pot 1 1 1 15 10122060 机壳链 Rubber coat 2 2 2 16 1011203100 机壳链套 Hinge 2 2 2 17 13522001 机头防震垫块(大) Cushion(big) 2 2 2 18 10122022 机头防震垫块(小) Cushion(small) 2 2 2 19 113511001 油袋(600ml)(10#) Oil bag (600ml)(10#) 1 1 1 20 1383100300 线架组件 Spool stand complete 1 1 1 21 10111011 机头支柱 Frame support bar 1 1 1 22 1351203800 膝控操纵杆组件 Joystick assembly 1 1 1 22-1 13512038 膝控操纵杆 Bent rod 1 1 1 22-2 10112029 膝控磁块 Bell 1 1 1 22-3 10112030 磁块架 Bell bracket 1 1 1 22-4 101S12004 磁块架螺钉 M6×11 Screw M6×11 1 1 1 23 13502025 膝控铰链轴 Hinge pin 1 1 1 24 13527014 膝控复位弹簧 Spring 1 1 1 25 10101008 膝控弯杆接头 Connector 1 1 1 26 101S12003 螺钉 M8 Screw M8 2 2 2 27 10122024 磁块垫 Mat 1 1 1 28 H05010 开口挡圈 Split stop ring 1 1 1 29 11023001700 电控脚踏 Electric control pedal 1 1 1 703725 包材 Packaging materials 1 1 1 30 11543100300 脚踏连杆 Pedal connecting rod 1 1 1 31 114712003 开口扳手(14-10) Open wrench 1 1 1
