Brother S-6280A — Part Book

Brother S-6280A — parts catalog

Page 16 (diagram): This page displays a diagram of the feed mechanism components, with various parts labeled with reference numbers and part numbers.
Page 17 (parts_list): This page lists components for the Feed mechanism, including part numbers, names, quantities, and remarks in both English and Chinese.
Page 18 (diagram): This page displays a diagram of the feed mechanism components, with various parts labeled with reference numbers and part numbers.
Page 19 (parts_list): This page lists components for the Feed mechanism, including screws, levers, tooth bases, feed dogs, lifting forks, pins, snap rings, bearing supports, thrust collars, and rocker shafts, with their corresponding part numbers and quantities.
Page 20 (diagram): This page displays a diagram of feed regulating components for an industrial sewing machine, with various parts labeled with reference numbers like G-1 through G-19.
Page 21 (parts_list): This page lists feed regulating components with part numbers, descriptions, and quantities.
Page 22 (diagram): This page displays a diagram of thread trimmer components, with various parts labeled with reference numbers and some part numbers provided.
Page 23 (parts_list): This page lists components for the H. 剪线组件 / Thread trimmer components section, including part numbers, descriptions, and quantities.
Page 24 (diagram): This page displays a diagram of lubrication components for an industrial sewing machine, with various parts labeled with reference numbers like I-1 through I-20.
Page 25 (parts_list): This page lists lubrication components with their reference number, code, quantity, name of parts in English and Chinese, and RM value.
Page 26 (diagram): This page displays a diagram of presser foot components of an oil plate knee lift, with parts labeled J-1 through J-25.
Page 27 (parts_list): This page lists parts for the "Presser foot components of oil plate knee lift" with reference numbers, codes, quantities, names of parts in English and Chinese, and RM values.
Page 28 (diagram): This page displays a diagram of components for a thread-running stand, with various parts labeled with reference numbers and part numbers.
Page 29 (parts_list): This page lists components for a thread-running stand, including part numbers, quantities, and names in both English and Chinese.
Page 30 (diagram): This page displays a diagram of accessories for an industrial sewing machine, labeled L-1 through L-10, including a bottle, nozzle, clips, and screws.

Page 16 — F. 送料分组件 / Feed mechanism components

Brother S-6280A parts on page 16
Ref	Part number	Part name	Qty
	F-1	F-1
	F-2	F-2
	F-3	F-3
	F-4	F-4
	F-5	F-5
	F-6	F-6
	F-7	F-7
	F-8	F-8
	F-9	F-9
	F-10	F-10
	F-11	F-11
	F-12	F-12
	F-13	F-13
	F-14	F-14
	F-15	F-15
	F-16	F-16
	F-17	F-17
	F-18	F-18
	F-19	F-19
	F-20	F-20
	F-21	F-21
	F-22	F-22
	F-23	F-23
	F-24	F-24
	F-25	F-25
	F-26	F-26
	F-27	F-27
	F-28	F-28
	F-29	F-29
	F-30	F-30
	F-31	F-31
	F-32	F-32
	F-33	F-33
	F-34	F-34
	F-35	F-35
	F-36	F-36
	F-37	F-37
	F-38	F-38
	F-39	F-39
	F-40	F-40
	F-41	F-41
	F-42	F-42
	F-43	F-43
	F-44	F-44
	F-45	F-45
	F-46	F-46
	F-47	F-47
	F-48	F-48
	F-49	F-49
	F-50	F-50
	F-51	F-51
	F-52	F-52
	F-53	F-53
	F-54	F-54
	F-55	F-55
	F-56	F-56
	F-57	F-57
	F-58	F-58
	F-59	F-59
	F-60	F-60
	F-61	F-61
	F-62	F-62
	F-63	F-63
	F-64	F-64
	F-65	F-65
	F-66	F-66
	F-67	F-67
	F-68	F-68
	F-69	F-69
	F-70	F-70
	F-71	F-71

F. 送料分组件 / Feed mechanism components F-1 F-2 F-3 F-4 F-5 F-6 F-7 F-8 F-9 F-10 F-11 F-12 F-13 F-14 F-15 F-16 F-17 F-18 F-19 F-20 F-21 F-22 F-23 F-24 F-25 F-26 F-27 F-28 F-29 F-30 F-31 F-31 F-32 F-33 F-34 F-35 F-36 F-37 F-38 F-39 F-40 F-41 F-42 F-43 F-44 F-45 F-46 F-47 F-48 F-49 F-50 F-51 F-52 F-53 F-54 F-55 F-56 F-57 F-58 F-59 F-60 F-61 F-62 F-63 F-64 F-65 F-66 F-67 F-68 F-69 F-70 F-71 13 S-6280A jintex.in

Page 17 — F. 送料分组件 / Feed mechanism components

Brother S-6280A parts on page 17
Part number	Part name	Qty
DD0010089	Snap ring	1
DD0010084	Connecting rod	1
DD0010115	Feed drive eccentric cam	1
DD0010092	Screw	2
DD0010072	Connecting rod	1
DD0010098	Thrust cover	1
DD0010643	Screw	2
DD0008848	Feed regulator	1
DD0051742	Screw	2
DD0026886	Pin	1
DD0008956	Bearing support	1
DD0010238	Screw	1
DD0051621	Spring	1
DD0003650	O-ring	1
DD0062042	Screw	1
DD0013869	Spring	1
DD0013870	Pin	1
D00003255	Knob stop	1
D00003414	Spring	1
D00003216	Feed dial	1
D00003846	Screw	1
DD0010076	Feed rocker	1
DD0010096	Pin	1
DD0010071	Screw	1
DD0010095	Screw	1
DD0010075	Short link	2
DD0008856	Long link	2
DD0010071	Pin	1
DD0010069	Pin	1
DD0008852	Feed adjust rod	1
DD0010649	Snap ring	2
DD0010091	Screw	1
DD0010095	Screw	1
DD0010086	Lifing rocker	1
D00004475	Nut	1
DD0010087	Pin	2
DD0012775	Feed adjusting ASM	1
DD0010102	Pin	1
DD0058783	Pin	1
DD0010678	Screw	2
DD0010071	Screw	2
DD0010282	Plate	1
DD0010285	Screw	2
DD0012796	Spring	1
DD0004430	Spring	1
DD0010235	Plate	1
DD0012990	Spring	1
DD0012991	Spring	1
DD0012987	Plate	1
DD0010287	Pin	1
DD0039853	Reverse feed control lever	1
DD0009008	Screw	1
DD0014119	Bearing support	1
D00003649	O-ring	1
DD0008827	Reverse feed shaft	1
DD0040504	Screw	2
D00003453	Tube	1

F. 送料分组件 / Feed mechanism components REF.NO CODE Q'TY NAME OF PARTS 零件名称 RM 1 DD0010089 1 Snap ring 挡圈 2 DD0010084 1 Connecting rod 拾牙连杆 3 DD0010115 1 Feed drive eccentric cam 送料偏心轮 4 DD0010092 2 Screw 螺钉 5 DD0010072 1 Connecting rod 送料连杆 6 DD0010098 1 Thrust cover 送料偏心轮盖板 7 DD0010643 2 Screw 螺钉 8 DD0008848 1 Feed regulator 送料调节器 9 DD0051742 2 Screw 螺钉 10 DD0026886 1 Pin 偏心销 11 DD0008956 1 Bearing support 轴套 12 DD0010238 1 Screw 螺钉 13 DD0051621 1 Spring 弹簧 14 DD0003650 1 O-ring O形圈 15 DD0062042 1 Screw 送料调节螺柱 16 DD0013869 1 Spring 弹簧 17 DD0013870 1 Pin 销 18 D00003255 1 Knob stop 旋钮止动片 19 D00003414 1 Spring 弹簧 20 D00003216 1 Feed dial 送料距离旋钮 21 D00003846 1 Screw 针距旋钮螺钉 22 DD0010076 1 Feed rocker 送布柄 23 DD0010096 1 Pin 销 24 DD0010071 1 Screw 螺钉 25 DD0010095 1 Screw 螺钉 26 DD0010075 2 Short link 送料短摆动板 27 DD0008856 2 Long link 送料长摆动板 28 DD0010071 1 Pin 销 29 DD0010069 1 Pin 销 30 DD0008852 1 Feed adjust rod 倒送料连杆 31 DD0010649 2 Snap ring 挡圈 32 DD0010091 1 Screw 螺钉 33 DD0010095 1 Screw 螺钉 34 DD0010086 1 Lifing rocker 拾牙后曲柄 35 D00004475 1 Nut 螺母 36 DD0010087 2 Pin 销 37 DD0012775 1 Feed adjusting ASM 送料摆动板座部件 38 DD0010102 1 Pin 销 39 DD0058783 1 Pin 销 40 DD0010678 2 Screw 螺钉 41 DD0010071 2 Screw 螺钉 42 DD0010282 1 Plate 摆动板复位板 43 DD0010285 2 Screw 复位板螺钉 <For -[]03> <用于-[]03> 44+ DD0012796 1 Spring 弹簧 45+ DD0004430 1 Spring 弹簧 46+ DD0010235 1 Plate 拉簧固定板 <For -[]05> <用于-[]05> 44+ DD0012990 1 Spring 弹簧 45+ DD0012991 1 Spring 弹簧 46+ DD0012987 1 Plate 拉簧固定板 47 DD0010287 1 Pin 销 48 DD0039853 1 Reverse feed control lever 倒送料曲柄 49 DD0009008 1 Screw 螺钉 50 DD0014119 1 Bearing support 轴套 51 D00003649 1 O-ring O形圈 52 DD0008827 1 Reverse feed shaft 倒送料轴 53 DD0040504 2 Screw 螺钉 54 D00003453 1 Tube 倒送料扳手挡圈 S-6280A 14 jintex.in

Page 18 — F. 送料分组件 / Feed mechanism components

Brother S-6280A parts on page 18
Ref	Part number	Part name	Qty
	F-1	F-1
	F-2	F-2
	F-3	F-3
	F-4	F-4
	F-5	F-5
	F-6	F-6
	F-7	F-7
	F-8	F-8
	F-9	F-9
	F-10	F-10
	F-11	F-11
	F-12	F-12
	F-13	F-13
	F-14	F-14
	F-15	F-15
	F-16	F-16
	F-17	F-17
	F-18	F-18
	F-19	F-19
	F-20	F-20
	F-21	F-21
	F-22	F-22
	F-23	F-23
	F-24	F-24
	F-25	F-25
	F-26	F-26
	F-27	F-27
	F-28	F-28
	F-29	F-29
	F-30	F-30
	F-31	F-31
	F-32	F-32
	F-33	F-33
	F-34	F-34
	F-35	F-35
	F-36	F-36
	F-37	F-37
	F-38	F-38
	F-39	F-39
	F-40	F-40
	F-41	F-41
	F-42	F-42
	F-43	F-43
	F-44	F-44
	F-45	F-45
	F-46	F-46
	F-47	F-47
	F-48	F-48
	F-49	F-49
	F-50	F-50
	F-51	F-51
	F-52	F-52
	F-53	F-53
	F-54	F-54
	F-55	F-55
	F-56	F-56
	F-57	F-57
	F-58	F-58
	F-59	F-59
	F-60	F-60
	F-61	F-61
	F-62	F-62
	F-63	F-63
	F-64	F-64
	F-65	F-65
	F-66	F-66
	F-67	F-67
	F-68	F-68
	F-69	F-69
	F-70	F-70
	F-71	F-71

Page 19 — F. 送料分组件 / Feed mechanism components

Brother S-6280A parts on page 19
Part number	Part name	Qty
DD0050707	Screw	1
DE0021689	Reverse feed control lever	1
DD0063520	Tooth base	1
DD0010099	Screw	2
DD0052531	Feed dog	1
DD0007322	Feed dog	1
DD0042079	Lifting fork	1
DD004628	Screw	1
DD0004440	Pin	1
DD0004474	Feed bar driving crank	1
DD0010074	Screw	1
DD0004993	Screw	1
DD0010090	Snap ring	2
DD0014116	Bearing support	2
DD0010542	Thrust collar	2
DD0038073	Screw	4
DD0010073	Feed rocker shaft	1
DD0010097	Feed lifting rocker shaft	1

F. 送料分组件 / Feed mechanism components REF.NO CODE Q'TY NAME OF PARTS 零件名称 RM 55 DD0050707 1 Screw 螺钉 56 DE0021689 1 Reverse feed control lever 倒送料扳手 57 DD0063520 1 Tooth base 牙架 58 DD0010099 2 Screw 螺钉 59+ DD0052531 1 <For-[]03> Feed dog <For-[]05> 送料牙 59+ DD0007322 1 Feed dog 送料牙 60 DD0042079 1 Lifting fork 拾牙叉形曲柄组件 61 DD004628 1 Screw 螺钉 62 DD0004440 1 Pin 销 63 DD0004474 1 Feed bar driving crank 牙架座 64 DD0010074 1 Screw 螺钉 65 DD0004993 1 Screw 螺钉 66 DD0010090 2 Snap ring 挡圈 67 DD0014116 2 Bearing support 轴套 68 DD0010542 2 Thrust collar 挡圈 69 DD0038073 4 Screw 螺钉 70 DD0010073 1 Feed rocker shaft 送料轴 71 DD0010097 1 Feed lifting rocker shaft 拾牙轴 S-6280A 16 jintex.in

Page 20 — G. 送料调节组件 / Feed regulating components

Brother S-6280A parts on page 20
Ref	Part number	Part name	Qty
	G-1	G-1
	G-2	G-2
	G-3	G-3
	G-4	G-4
	G-5	G-5
	G-6	G-6
	G-7	G-7
	G-8	G-8
	G-9	G-9
	G-10	G-10
	G-11	G-11
	G-12	G-12
	G-13	G-13
	G-14	G-14
	G-15	G-15
	G-16	G-16
	G-17	G-17
	G-18	G-18
	G-19	G-19

G. 送料调节组件 / Feed regulating components G-1 G-2 G-3 G-4 G-5 G-6 G-7 G-8 G-9 G-10 G-11 G-12 G-13 G-14 G-15 G-16 G-17 G-18 G-19 17 S-6280A jintex.in

Page 21 — G. 送料调节分组件 / Feed regulating components

Brother S-6280A parts on page 21
Part number	Part name	Qty
DD0008934	Screw	1
DD0011168	Washer	1
DNR003720	Led lamp ASM	1
DD0012505	Screw	1
DD0003281	Snap ring	1
DD0024748	Snap ring	1
DD0012985	Nut	2
DD0012983	Screw	1
DD0053339	Reverse feed connecting plate	1
DD0012989	Connecting arm ASM	1
DNR003644	Reverse feed magnet ASM	1
DD0012983	Screw	1
DD0051742	Screw	2
DD0004061	Connecting sleeve	1
DD0013002	Connecting sleeve	1
DD0013001	Screw	1
DD0003281	Snap ring	1
DD0051742	Screw	2
DNR003704	Reverse feed magnet ASM	1
DD0012983	Screw	1

G. 送料调节分组件 / Feed regulating components REF.NO CODE Q'TY NAME OF PARTS 零件名称 RM 1 DD0008934 1 Screw 螺钉 2 DD0011168 1 Washer 垫圈 3 DNR003720 1 Led lamp ASM 机头灯组件 4 DD0012505 1 <For -[]03> Screw <用于-[]03> 油泵连接螺柱 5 DD0003281 1 Snap ring 挡圈 6 DD0024748 1 Snap ring 挡圈 7 DD0012985 2 Nut 螺母 8 DD0012983 1 Screw 螺钉 9 DD0053339 1 Reverse feed connecting plate 自动送料拉杆 10 DD0012989 1 Connecting arm ASM 自动倒送料曲柄 11 DNR003644 1 <For -[]03> Reverse feed magnet ASM <用于-[]03> 倒送料驱动部件 12 DD0012983 1 Screw 螺钉 13 DD0051742 2 Screw 螺钉 14+ DD0004061 1 <For -[]03> Connecting sleeve <用于-[]03> 油泵连接衬套 14+ DD0013002 1 Connecting sleeve <用于-[]05> 油泵连接衬套 15 DD0013001 1 Screw 油泵连接螺柱 16 DD0003281 1 Snap ring 挡圈 17 DD0051742 2 Screw 螺钉 18 DNR003704 1 <For -[]05> Reverse feed magnet ASM <用于-[]05> 倒送料驱动部件 19 DD0012983 1 Screw 螺钉 S-6280A 18 jintex.in

Page 22 — H. 剪线分组件 / Thread trimmer components

Brother S-6280A parts on page 22
Ref	Part number	Part name	Qty
H-10-1	10011494	H-10-1
H-10-2	10030280	H-10-2

H. 剪线分组件 / Thread trimmer components H-1 H-2 H-3 H-4 H-5 H-6 H-7 H-8 H-9 H-10 H-10-1 10011494 14.7 18.3 17.7 (25) (25) H-10-2 10030280 H-11 H-12 H-13 H-14 H-15 H-16 H-17 H-18 H-19 H-20 H-21 H-22 H-23 H-24 H-25 H-26 H-27 H-28 H-29 H-30 H-31 H-32 H-33 H-34 H-35 H-36 H-37 H-38 H-39 H-40 H-41 H-42 H-43 H-44 H-45 H-46 H-47 H-48 H-49 H-50 H-51 H-52 H-53 H-54 19 S-6280A jintex.in

Page 23 — H. 剪线组件 / Thread trimmer components

Brother S-6280A parts on page 23
Part number	Part name	Qty
DD0008866	Trimming crank shaft	1
DD0012454	Short bushing	1
DD0011630	Short bushing	1
DD0011649	Spring	1
DD0008865	Washer	1
DD0011588	Screw	2
DD0058043	Trimming crank	1
DD0011580	Block	1
DD0008863	Scrrew	1
DD0011494	Round knife	1
DD0030280	Round knife	1
DD0004640	Round knife bracket	1
DD0011578	Nut	1
DD0031612	Knife shaft crack rod	1
DD0011514	Screw	2
DD0010900	Screw	2
DD0013154	Washer	2
DD0008856	Knife holder ASM	1
DD0014196	Spring cover	1
DD0008812	Spring	1
DD0011697	Trimming shaft	1
DD0050266	Silencer plug	1
DD0004707	Roller Shaft	1
DD0004651	Roller	1
DD0025576	Washer	1
DD0011578	Nut	3
DD0004648	Trimming cam crank	1
DD0025577	Screw	1
DD0004703	Slide block	1
DD0004704	Pin	1
DD0004705	Roller	1
DD0011650	Washer	1
DD0003031	Washer	1
DD0009654	Snap ring	1
DD0003460	Thread trimmer solenoid ASM	1
DD0009471	Nut	2
DD0008854	Solenoid base	1
DD0011607	Solenoid connecting shaft	1
DNR001201	Thread trimmer solenoid	1
DD0011606	Washer	1
DD0011845	Washer	1
DD0028999	Screw	1
DD0012467	Screw	1
DD0003077	Washer	1
DD0011605	Screw	1
DD0008862	Screw	1
DD0058067	Dispart	1
DD0013154	Washer	1
DD0014474	Screw	1
DD0011421	Fixed knife	1
DD0011422	Screw	1
DD0013465	Screw	2
DD0010736	Thread trimmer cam	1
DD0023739	Cam collar	1
DD0011686	Trimming cam crank ASM	1

H. 剪线组件 / Thread trimmer components REF.NO CODE Q'TY NAME OF PARTS 零件名称 RM 1 DD0008866 1 Trimming crank shaft 切刀驱动曲柄轴 2 DD0012454 1 Short bushing 轴套 3 DD0011630 1 Short bushing 轴套 4 DD0011649 1 Spring 弹簧 5 DD0008865 1 Washer 垫圈 6 DD0011588 2 Screw 螺钉 7 DD0058043 1 Trimming crank 切刀驱动曲柄 8 DD0011580 1 Block 切刀驱动曲柄止动块 9 DD0008863 1 Scrrew 螺钉 <For-[]03> <用于-[]03> 10+ DD0011494 1 Round knife 动刀 10+ DD0030280 1 Round knife <用于-[]05> 动刀 11 DD0004640 1 Round knife bracket 动刀架 12 DD0011578 1 Nut 螺母 13 DD0031612 1 Knife shaft crack rod 刀轴连杆 14 DD0011514 2 Screw 螺钉 15 DD0010900 2 Screw 螺钉 16 DD0013154 2 Washer 垫圈 17 DD0008856 1 Knife holder ASM 刀架压板组件 18 DD0014196 1 Spring cover 扭簧端盖 19 DD0008812 1 Spring 弹簧 20 DD0011697 1 Trimming shaft 切刀驱动轴 21 DD0050266 1 Silencer plug 消音塞 22 DD0004707 1 Roller Shaft 切线凸轮曲柄滚柱 23 DD0004651 1 Roller 滚柱 24 DD0025576 1 Washer 垫圈 25 DD0011578 3 Nut 螺母 26 DD0004648 1 Trimming cam crank 切线凸轮曲柄分组件 27 DD0025577 1 Screw 螺钉 28 DD0004703 1 Slide block 切线凸轮曲柄滑块 29 DD0004704 1 Pin 销 30 DD0004705 1 Roller 切线凸轮左曲柄滚柱 31 DD0011650 1 Washer 垫圈 32 DD0003031 1 Washer 垫圈 33 DD0009654 1 Snap ring 挡圈 34 DD0003460 1 Thread trimmer solenoid ASM 剪线电磁铁组件 35 DD0009471 2 Nut 螺母 36 DD0008854 1 Solenoid base 剪线电磁铁安装座 37 DD0011607 1 Solenoid connecting shaft 剪线电磁铁连接体 38 DNR001201 1 Thread trimmer solenoid 剪线电磁铁 39 DD0011606 1 Washer 垫圈 40 DD0011845 1 Washer 垫圈 41 DD0028999 1 Screw 螺钉 42 DD0012467 1 Screw 螺钉 43 DD0003077 1 Washer 垫圈 44 DD0011605 1 Screw 螺钉 45 DD0008862 1 Screw 螺钉 46 DD0058067 1 Dispart 分线器 47 DD0013154 1 Washer 垫圈 48 DD0014474 1 Screw 螺钉 49 DD0011421 1 Fixed knife 定刀 50 DD0011422 1 Screw 螺钉 51 DD0013465 2 Screw 螺钉 52 DD0010736 1 Thread trimmer cam 剪线凸轮 53 DD0023739 1 Cam collar 剪线凸轮垫 54 DD0011686 1 Trimming cam crank ASM 切线凸轮曲柄组件 S-6280A 20 jintex.in

Page 24 — I. 润滑分组件/ Lubrication components

Brother S-6280A parts on page 24
Ref	Part number	Part name	Qty
	I-1	I-1
	I-2	I-2
	I-3	I-3
	I-4	I-4
	I-5	I-5
	I-6	I-6
	I-7	I-7
	I-8	I-8
	I-9	I-9
	I-10	I-10
	I-11	I-11
	I-12	I-12
	I-13	I-13
	I-14	I-14
	I-15	I-15
	I-16	I-16
	I-17	I-17
	I-18	I-18
	I-19	I-19
	I-20	I-20

I. 润滑分组件/ Lubrication components I-1 I-3 I-2 I-6 I-5 I-4 I-7 I-8 I-15 I-16 I-10 I-11 I-9 I-12 I-13 I-14 I-17 I-18 I-19 I-20 21 S-6280A

Page 25 — I. 润滑分组件 / Lubrication components

Brother S-6280A parts on page 25
Part number	Part name	Qty
DD0014197	Foam rubber	1
DD0005558	Screw	1
D00002229	Oil stoper	1
DD0010294	Felt clip	1
E00003573	Oil return pipe assembly	1
DD0008934	Screw	1
DD0041628	Oil felt preser	1
DD0048653	Main shaft oil tube	1
D00003443	Oil tube holder	1
DD0003077	Washer	1
DD0050422	Screw	1
DD0008817	Oil pump	1
DD0005537	Spring washer	1
DD0010066	Screw	1
DD0008806	Spring	1
DD0008831	Screw	1
DD0008807	Oil tube	1
DD0050424	Tube holder	1
DD0013269	Screw	1

I. 润滑分组件 / Lubrication components REF.NO CODE Q'TY NAME OF PARTS 零件名称 RM 1 DD0014197 1 Foam rubber 挡油海绵 2 DD0005558 1 Screw 螺钉 3 D00002229 1 Oil stoper 面部防油板部件 4 DD0010294 1 Felt clip 毛毡夹 5 E00003573 1 Oil return pipe assembly 回油管组件 6 DD0008934 1 Screw 螺钉 7 DD0041628 1 Oil felt preser 油管夹 8 DD0048653 1 Main shaft oil tube 油管 9 D00003443 1 Oil tube holder 供油管接头 10 DD0003077 1 Washer 垫圈 11 DD0050422 1 Screw 螺钉 12 DD0008817 1 Oil pump 油泵部件 13 DD0005537 1 Spring washer 弹簧垫圈 14 DD0010066 1 Screw 螺钉 15 DD0008806 1 Spring 弹簧 16 DD0008831 1 Screw 螺钉 17 DD0008807 1 Oil tube 油管 18 DD0050424 1 Tube holder 旋栓供油管压板 19 DD0013269 1 Screw 螺钉 S-6280A 22

Page 26 — J. 油盘、膝抬压脚组件 / Presser foot components of oil plate knee lift

Brother S-6280A parts on page 26
Ref	Part number	Part name	Qty
	J-1	J-1
	J-2	J-2
	J-3	J-3
	J-4	J-4
	J-5	J-5
	J-6	J-6
	J-7	J-7
	J-8	J-8
	J-9	J-9
	J-10	J-10
	J-11	J-11
	J-12	J-12
	J-13	J-13
	J-14	J-14
	J-15	J-15
	J-16	J-16
	J-17	J-17
	J-18	J-18
	J-19	J-19
	J-20	J-20
	J-21	J-21
	J-22	J-22
	J-23	J-23
	J-24	J-24
	J-25	J-25

J. 油盘、膝抬压脚组件 / Presser foot components of oil plate knee lift J-1 J-2 J-3 J-4 J-5 J-13 J-12 J-11 J-10 J-6 J-7 J-14 J-9 J-8 J-16 J-15 J-17 J-18 J-19 J-22 J-23 J-21 J-20 J-24 J-25 23 S-6280A jintex.in

Page 27 — J. 油盘、膝抬压脚分组件 / Presser foot components of oil plate knee lift

Brother S-6280A parts on page 27
Part number	Part name	Qty
DD0003841	Oil reservoir	1
DD0014194	Oil reservoir gasket	1
DD0009984	Knee Lifter Complying Bar	1
DD0009991	Screw	1
DD0009988	O-ring	1
DD0002562	Bracket-ASM	1
DD0003896	Bracket	1
DD0002610	Screw	1
DD0002613	Screw	1
DD0003899	Knee pressing shaft	1
DD0003893	Spring	1
DD0002559	Snap ring	1
DD0002563	Crank ASM	1
DD0009987	Crank	1
DD0004047	Screw	1
DD0003895	Screw	1
DD0003898	Screw	1
DD0003890	Nut	3
E00003503	Knee pressing plate ASM	1
DD0003894	Screw	1
DD0003897	Knee pressing plate holder	1
DD0003901	Knee pressing plate rod	1
D00003445	Knee pressing plate rubber	1
DD0003891	Knee pressing plate	1
D00003446	Knee pressing cover	1
D00003753	Lever as-control	1

J. 油盘、膝抬压脚分组件 / Presser foot components of oil plate knee lift REF.NO CODE Q'TY NAME OF PARTS 零件名称 RM 1 DD0003841 1 Oil reservoir 油盘 2 DD0014194 1 Oil reservoir gasket 油盘垫 3 DD0009984 1 Knee Lifter Complying Bar 销 4 DD0009991 1 Screw 螺钉 5 DD0009988 1 O-ring O形圈 6 DD0002562 1 Bracket-ASM 抬压脚操纵杆接头组件 7 DD0003896 1 Bracket 抬压脚操纵接头 8 DD0002610 1 Screw 螺钉 9 DD0002613 1 Screw 螺钉 10 DD0003899 1 Knee pressing shaft 抬压脚轴 11 DD0003893 1 Spring 弹簧 12 DD0002559 1 Snap ring 挡圈 13 DD0002563 1 Crank ASM 抬压脚双向曲柄组件 14 DD0009987 1 Crank 抬压脚双向曲柄 15 DD0004047 1 Screw 螺钉 16 DD0003895 1 Screw 螺钉 17 DD0003898 1 Screw 螺钉 18 DD0003890 3 Nut 螺母 19 E00003503 1 Knee pressing plate ASM 操纵杆部件 20 DD0003894 1 Screw 螺钉 21 DD0003897 1 Knee pressing plate holder 操纵杆接头 22 DD0003901 1 Knee pressing plate rod 操纵杆 23 D00003445 1 Knee pressing plate rubber 操纵杆垫 24 DD0003891 1 Knee pressing plate 操纵板 25 D00003446 1 Knee pressing cover 操纵板软垫 26 D00003753 1 Lever as-control 操纵杆组件 S-6280A 24 jintex.in

Page 28 — K. 过线架分组件 / Components of thread-running stand

Brother S-6280A parts on page 28
Ref	Part number	Part name	Qty
	K-1	K-1
	K-2	K-2
	K-3	K-3
	K-4	K-4
	K-5	K-5
	K-6	K-6
	K-7	K-7
	K-8	K-8
	K-9	K-9
	K-10	K-10
	K-11	K-11
	K-12	K-12
	K-13	K-13
	K-14	K-14
	K-15	K-15
	K-16	K-16
	K-17	K-17
	K-18	K-18
	K-19	K-19
	K-20	K-20
	K-21	K-21

K. 过线架分组件 / Components of thread-running stand K-1 K-2 K-4 K-5 K-7 K-6 K-3 K-8 K-9 K-5 K-6 K-7 K-10 K-3 K-11 K-12 K-4 K-3 K-4 K-3 K-13 K-14 K-15 K-16 K-4 K-3 K-18 K-17 K-17 K-18 K-19 K-20 K-21 25 S-6280A jintex.in

Page 29 — K. 过线架分组件 / Components of thread-running stand

Brother S-6280A parts on page 29
Part number	Part name	Qty
DD0003447	Column cap	1
DD0004293	Column pipe(upper)	1
DD0000953	Nut	6
DD0003022	Washer	4
DD0003301	Screw	3
DD0004285	Thread guide bushing	4
DD0004289	Thread guide pipe	4
DD0004298	Thread hanger(upper)	2
DD0004286	Column pipe connector	1
DD0004291	Column pipe(lower)	1
DD0004284	Thread hanger(lower)	1
DD0003312	Screw	2
DD0004288	Spool pin	2
DD0004287	Spool cushion	2
DD0004281	Spool mat	2
DD0004299	Spool seat disc	2
DD0004295	Washer	2
DD0004290	Washer	2
DD0002985	Nut	1
DD0003447	Column pipe(upper)	1
DD0003519	Wire frame components	1

K. 过线架分组件 / Components of thread-running stand REF.NO CODE Q'TY NAME OF PARTS 零件名称 RM 1 DD0003447 1 Column cap 线架上撑管套 2 DD0004293 1 Column pipe(upper) 线架上撑管 3 DD0000953 6 Nut 螺母 4 DD0003022 4 Washer 垫圈 5 DD0003301 3 Screw 螺钉 6 DD0004285 4 Thread guide bushing 过线管套 7 DD0004289 4 Thread guide pipe 过线管 8 DD0004298 2 Thread hanger(upper) 上过线架 9 DD0004286 1 Column pipe connector 撑管夹 10 DD0004291 1 Column pipe(lower) 线架下撑管 11 DD0004284 1 Thread hanger(lower) 下过线架 12 DD0003312 2 Screw 螺钉 13 DD0004288 2 Spool pin 线轴 14 DD0004287 2 Spool cushion 线盘塑料压块 15 DD0004281 2 Spool mat 线盘软垫 16 DD0004299 2 Spool seat disc 线盘 17 DD0004295 2 Washer 垫圈 18 DD0004290 2 Washer 垫圈 19 DD0002985 1 Nut 螺母 20 DD0003447 1 Column pipe(upper) 线架上撑管套 21 DD0003519 1 Wire frame components 二线线架部件 S-6280A 26

Page 30 — L. 附件 / Accessories

Brother S-6280A parts on page 30
Ref	Part number	Part name	Qty
	L-1	Bottle
	L-2	Nozzle
	L-3	Clip
	L-4	Clip
	L-5	Clip
	L-6	Clip
	L-7	Clip
	L-8	Washer
	L-9	Washer
	L-10	Screw

L. 附件 / Accessories L-1 L-2 L-3 L-4 L-5 L-6 L-7 L-8 L-9 L-10 27 S-6280A jintex.in

Part Books

Search
