brother LK3-B430 高速本縫筒型閂止ミシン HIGH SPEED BAR TACKING MACHINE VERRIEGELUNGSSCHNELLNÄHER MACHINE À COUDRE À POINTS D'ARRÊT À GRANDE VITESSE DU TYPE BRAS LIBRE MÁQUINA PRESILLADORA DE DOBLE PESPUINTE DE ALTA VELOCIDAD CON BARRA DE BRAZO LIBRE パーツブック PARTS BOOK TEILEKATALOG LIVRE DES PIECES LIBRO DE REFERENCIA DE PIEZAS P430501 jintex.in
jintex.in
パーツブックご利用に際して 1. この本は、この本の表紙(正誤表の挿入されている場合は正誤表)に記載さ れているものと同じプレートが取り付けられているミシンのためのものです。 2. 部品コード欄が*となっている場合は、ゲージ部品一覧表(41~44ページ) でお調べ下さい。 3. この本は1991年1月のデータに基づいて作成されたものです。 4. 部品は、予告なしに設計変更される場合があります。 目 次 A. 主体関係 B. クラッチ関係 C. 上軸・針棒関係 D. 動車・遊車関係 E. 補給部品 F. 送り関係 G. 押工上ゲ関係 H. カム伝導関係 J. パワー押工関係 K. 下軸関係 L. 給油潤滑関係 M. 糸通シ関係 N. 糸巻キ関係 P. 糸切り関係 Q. 糸払イ関係 R. 糸締メ関係 S. 付属装置セット T. 特別注文部品 Z. 付属品関係 仕様別部品一覧表 オプションパーツ 索引 2 6 10 12 12 14 18 20 22 24 26 30 32 34 36 36 38 38 40 41~44 45 46~53 jintex.in
Notes for using this parts book 1. This book is applicable to sewing machines which have the same plate number as shown on the cover of this book (or correction sheet). 2. If the symbol * is found in the “Parts No.” column, refer to the different pats list on page 41~44. 3. This book was prepared based on information available in January 1991. 4. Parts are subject to changes in design without prior notice. CONTENTS A. Machine body .................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
Hinweise zur Verwendung dieser Teileiste 1. Dieses Buch bezieht sich auf die Nähmaschinen mit derselben Kennungsnummer wie auf diesem Buchumschlag (oder auf dem Korrekturblatt). 2. Dieses Zeichen * in der Spalte “Parts No. (Teilnummer)” verweist auf Gesonderte Stückliste auf Seite 41~44. 3. Dieses Buch basiert auf den Informationen vom Januar 1991. 4. Modelländerungen sind vorbehalten. INHALTSVERZEICHNIS A. Maschinengehäuse 2 B. Kupplungsvorrichtung 6 C. Obere Welle und Nadelstangenvorrichtung 10 D. Antriebsriemenscheibe und Riemenscheibe 12 E. Lieferteile 12 F. Transportvorrichtung 14 G. Stoffhalterhebevorrichtung 18 H. Vertikale Welle 20 J. Heberbetätigungsvorrichtung 22 K. Untere Welle 24 L. Schmierung 26 M. Fadenführungsvorrichtung 30 N. Spuler 32 P. Fadenabschneidevorrichtung 34 Q. Fadenwischvorrichtung 36 R. Fadenspannvorrichtung 36 S. Anbausatz 38 T. Sonderzubehör 38 Z. Zubehör 40 ZUBEHÖRLISTE 41 ~ 44 SONDERZUBEHÖR 45 VERZEICHNIS 46 ~ 53 jintex.in
Notes sur l'utilisation de ce manuel de pièces détachées 1. Ce manuel est destiné aux machines à coudre ayant le même numéro de plaque montré sur la couverture de ce manuel (ou sur la feuille de corrections). 2. Si le symbole * se trouve dans la colonne “Parts No. (N° de pièce)”, veuillez vous référer à la liste de pièces annexe page 41~44. 3. Ce manuel a été fait d'après les renseignements valables au mois de Janvier 1991. 4. Les pièces peuvent être sujettes à des modification sans préavis. TABLE DES MATIERES A. Corps de la machine ................................................................... 2 B. Mécanisme de l'embrayage ........................................................ 6 C. Mécanisme de arbre supérieur et barre à aiguille ........................ 10 D. Mécanisme de poulie d'entraînement et poulie folle ................... 12 E. Pièces fournies .......................................................................... 12 F. Mécanisme de l'entraînement .................................................... 14 G. Mécanisme de leveur du pinceur ................................................ 18 H. Mécanisme d'arbre vertical ........................................................ 20 J. Mécanisme de leveur ................................................................ 22 K. Mécanisme de l'arbre inférieur .................................................. 24 L. Lubrification .............................................................................. 26 M. Mécanisme de l'enfilage ............................................................ 30 N. Mécanisme de bobineur ............................................................ 32 P. Mécanisme de coupe-fil ............................................................ 34 Q. Mécanisme de tire-fil ................................................................ 36 R. Mécanisme de pince-fil ............................................................ 36 S. Jeu d'accessoires ...................................................................... 38 T. Pièces en option ........................................................................ 38 Z. Accessoires .............................................................................. 40 LISTE DES PIECES ACCESSOIRES ...................................... 41 ~ 44 PIÈCES EN OPTION ................................................................. 45 INDEX ...................................................................................... 46 ~ 53 jintex.in
Notas para usar este Manual de Piezas 1. Este libro sirve para todas las máquinas de coser que llevan la misma placa de identi- ficación que la que se puede ver en la tapa de este libro (o en la hoja de erratas). 2. De haber un símbolo * junto al “Parts No. (Número de pieza)”, habrá que mirar la lista de piezas separada de la página 41~44. 3. Este libro ha sido compilado basándose en los datos de que se disponía en enero de 1991. 4. Las piezas quedan sujetas a cambios de diseño sin aviso previo. INDICE A. Cuerpo de la máquina ................................................................. 2 B. Mecanismo de embrague ............................................................ 6 C. Mecanismo del eje superior y barra de aguja .............................. 10 D. Mecanismo de polea impulsora y polea tensora .......................... 12 E. Piezas de suministro ................................................................... 12 F. Mecanismo de la alimentación .................................................... 14 G. Mecanismo del levantador de ménsula de trabajo ........................ 18 H. Mecanismo de eje vertical .......................................................... 20 J. Mecanismo de carrera de potencia .............................................. 22 K. Mecanismo del eje inferior ........................................................ 24 L. Lubricación ................................................................................ 26 M. Mecanismo del enhebrado .......................................................... 30 N. Mecanismo del devanador de la canilla ...................................... 32 P. Mecanismo de la cortadura de hilos ............................................ 34 Q. Mecanismo del limpiador de hilo ................................................ 36 R. Mecanismo de la mordaza para hilo ............................................ 36 S. Juego de fijación ........................................................................ 38 T. Piezas opcionales ........................................................................ 38 Z. Accesorios .................................................................................. 40 LISTA DE PIEZAS ACCESORIAS ............................................ 41 ~ 44 PIEZAS OPCIONALES ................................................................ 45 INDICE ........................................................................................ 46 ~ 53 jintex.in
A. 主体関係/Machine body/Maschinengehäuse/Corps de la machine/Cuerpo de la máquina 2 74 3 4-2 27 8 7 -75 19 20 22 27 15 29 29 6 4-1 28 14 Brother 27 輸出用 FOR EXPORT 57 56-1 56-4 77 56-3 56-2 66 68 16 27 27 54 63 21 30 62 53 55 12 64 65 10 31 32-10 18 17 9 61 11 60 13 58 59 32-1 32-14 32-3 32-5 32-15 32-4 32-16 51 32-8 52 70 32-11 32-2-1 32-2-2 32-9 32-7 32-6 32-16 32-17 32-15 71 32-2 32-13 32-12 72 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2 | 152830109 | TOP COVER | 1 |
| 3 | 062761412 | SCREW 595X14 | 6 |
| 4 | 152831009 | FACE PLATE ASSEMBLE | 1 |
| 4-1 | 152832109 | FACE PLATE | 1 |
| 4-2 | 152833001 | PACKING | 1 |
| 5 | 062711412 | SCREW 4.76X14 | 2 |
| 6 | 062710712 | SCREW 4.76X7 | 1 |
| 7 | 152834009 | FRAME SIDE COVER | 1 |
| 8 | 062711412 | SCREW 4.76X14 | 4 |
| 9 | 152835009 | BED COVER(R) | 1 |
| 10 | 100315002 | WAVE SPRING | 1 |
| 11 | 025770232 | PLAIN WASHER 6.35 | 1 |
| 12 | 145480001 | STUD SCREW 6.35 | 1 |
| 13 | 152836009 | BED COVER (L) ASSEMBLY | 1 |
| 14 | 152841009 | THREAD TAKE-UP COVER | 1 |
| 15 | 062670812 | SCREW 357X8 | 1 |
| 16 | 152842009 | LARGE SHUTTLE HOOK COVER ASSEMBLY (B) | 1 |
| 17 | 115493002 | STUD SCREW 5.95 | 2 |
| 18 | 109239002 | SPRING WASHER | 2 |
| 19 | 152846009 | BELT COVER | 1 |
| 20 | 152989001 | SPRING PLATE | 1 |
| 21 | 152986001 | SPRING SUPPORT | 1 |
| 22 | 062680812 | SCREW 437X8 | 1 |
| 27 | 117936009 | OIL CAP | 15 |
| 28 | 140392009 | OIL CAP | 1 |
| 29 | 117934009 | OIL CAP | 2 |
| 30 | 108520009 | OIL CAP | 1 |
| 31 | 104450109 | OIL CAP | 1 |
| 32 | 159808109 | OIL PAN ASSEMBLY | 1 |
| 32-1 | 154738109 | OIL PAN | 1 |
| 32-2 | 152852101 | TENSION PULLEY ASSEMBLY | 1 |
| 32-2-1 | 048320242 | STOP RING C32 | 1 |
| 32-2-2 | 141860001 | SCREW 6.35 | 1 |
| 32-3 | 018081222 | BOLT 8X12 | 1 |
| 32-4 | 025080232 | PLAIN WASHER 8 | 1 |
| 32-5 | 028080242 | SPRING WASHER 2-8 | 1 |
| 32-6 | 152857001 | HEAD SUPPORT LEVER | 1 |
| 32-7 | 018700112 | HEAD SUPPORT LEVER SHAFT | 1 |
| 32-8 | 013719412 | SET SCREW 4.76 | 1 |
| 32-9 | 152859001 | SPRING | 1 |
| 32-10 | 152860009 | BED CUSHION | 4 |
| 32-11 | 152861101 | MOTOR BASE PLATE | 1 |
| 32-12 | 152862001 | MOTOR BASE PLATE SHAFT | 1 |
| 32-13 | 048100142 | STOP RING C10 | 2 |
| 32-14 | 152865101 | (L) BOLT M10 | 1 |
| 32-15 | 021100202 | NUT 10 | 2 |
| 32-16 | 025100132 | PLAIN WASHER 10 | 2 |
| 32-17 | 028100242 | SPRING WASHER 2-10 | 1 |
| 51 | 152866001 | PIN | 1 |
| 52 | 013760612 | SET SCREW 5.95 | 1 |
| 53 | 152867000 | HINGE SHAFT | 2 |
| 54 | 151604002 | SET SCREW 5.95 | 2 |
| 55 | 152868009 | HINGE CUSHION | 2 |
| 56 | 153100000 | EYE GUARD ASSEMBLY | 1 |
| 56-1 | 153102001 | EYE GUARD HINGE ASSEMBLY | 1 |
| 56-2 | 153098000 | EYE GUARD | 1 |
| 56-3 | 102538007 | SCREW 3.57 | 2 |
| 56-4 | 106129001 | NUT 3.57 | 2 |
| 57 | 062670512 | SCREW 357X5 | 2 |
| 58 | 114985001 | SPRING | 1 |
| 59 | 062680612 | SCREW 437X6 | 1 |
| 60 | 152838001 | DOWEL PIN | 1 |
A. 主体関係/Machine body/Maschinengehäuse/Corps de la machine/Cuerpo de la máquina REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 2 152830109 1 ウワフタ TOP COVER 3 062761412 6 ナベコ595-28X14 SCREW 595X14 4 152831009 1 メンイタクミ FACE PLATE ASSEMBLE 4-1 152832109 1 メンイタ FACE PLATE 4-2 152833001 1 メンイタパツキン PACKING 5 062711412 2 ナベコ4.76-32X14 SCREW 4.76X14 6 062710712 1 ナベコ4.76-32X7 SCREW 4.76X7 7 152834009 1 ソクメンカバー FRAME SIDE COVER 8 062711412 4 ナベコ4.76-32X14 SCREW 4.76X14 9 152835009 1 ベツドカバーR BED COVER(R) 10 100315002 1 ナミバネ WAVE SPRING 11 025770232 1 ヒラザガネチユウ6.35 PLAIN WASHER 6.35 12 145480001 1 ダンネジ6.35 STUD SCREW 6.35 13 152836009 1 ベツドカバーLクミ BED COVER (L) ASSEMBLY 14 152841009 1 テンビンカバー THREAD TAKE-UP COVER 15 062670812 1 ナベコ357-40X8 SCREW 357X8 16 152842009 1 オオカマカバークミ LARGE SHUTTLE HOOK COVER ASSEMBLY (B) 17 115493002 2 ダンネジ5.95 STUD SCREW 5.95 18 109239002 2 ナミバネザガネ SPRING WASHER 19 152846009 1 ベルトカバー BELT COVER 20 152989001 1 ベルトカバーハネウケ SPRING PLATE 21 152986001 1 ベルトカバーハネササエ SPRING SUPPORT 22 062680812 1 ナベコ437-40X8 SCREW 437X8 27 117936009 15 メクラセン OIL CAP 28 140392009 1 オイルフタ OIL CAP 29 117934009 2 メクラセン OIL CAP 30 108520009 1 メクラセン OIL CAP 31 104450109 1 メクラセン OIL CAP 32 159808109 1 オイルパンクミ OIL PAN ASSEMBLY 32-1 154738109 1 オイルパン OIL PAN 32-2 152852101 1 テンションプーリクミ TENSION PULLEY ASSEMBLY 32-2-1 048320242 1 トメワアナヨウC32 STOP RING C32 32-2-2 141860001 1 シメネジ6.35 SCREW 6.35 32-3 018081222 1 アナボルト8X12 BOLT 8X12 32-4 025080232 1 ヒラザガネチユウ8 PLAIN WASHER 8 32-5 028080242 1 バネザガネ2-8 SPRING WASHER 2-8 32-6 152857001 1 トウブササエレバー HEAD SUPPORT LEVER 32-7 018700112 1 トウブササエレバーシク HEAD SUPPORT LEVER SHAFT 32-8 013719412 1 トメネジ4.76クボミ SET SCREW 4.76 32-9 152859001 1 トウブササエレバーバネ SPRING 32-10 152860009 4 ベツドクツシヨン BED CUSHION 32-11 152861101 1 モータダイ MOTOR BASE PLATE 32-12 152862001 1 モータダイジク MOTOR BASE PLATE SHAFT 32-13 048100142 2 トメワジクヨウC10 STOP RING C10 32-14 152865101 1 LガタボルトM10 (L) BOLT M10 32-15 021100202 2 ナツト2シユ10 NUT 10 32-16 025100132 2 ヒラザガネシヨウ10 PLAIN WASHER 10 32-17 028100242 1 バネザガネ2-10 SPRING WASHER 2-10 51 152866001 1 トウブササエピン PIN 52 013760612 1 トメネジ5.95クボミ SET SCREW 5.95 53 152867000 2 ベツドヒンジジク HINGE SHAFT 54 151604002 2 トメネジ5.95 SET SCREW 5.95 55 152868009 2 ベツドヒンジクツシヨン HINGE CUSHION 56 153100000 1 -------- EYE GUARD ASSEMBLY 56-1 153102001 1 -------- EYE GUARD HINGE ASSEMBLY 56-2 153098000 1 -------- EYE GUARD 56-3 102538007 2 -------- SCREW 3.57 56-4 106129001 2 -------- NUT 3.57 57 062670512 2 -------- SCREW 357X5 58 114985001 1 ベツトカバーハネ SPRING 59 062680612 1 ナベコ4.37-40X6 SCREW 437X6 60 152838001 1 ミゾツキピン DOWEL PIN jintex.in
A. 主体関係/Machine body/Maschinengehäuse/Corps de la machine/Cuerpo de la máquina 2 74 3 4-2 27 8 7 75 19 20 22 27 15 29 5 29 6 4-1 28 14 brother 輸出用 FOR EXPORT 27 57 56-1 56-4 56-3 56-2 66 16 27 30 62 77 66 27 54 63 21 53 55 12 64 18 31 32-10 17 65 10 9 60 61 11 32-1 13 58 59 32-14 32-3 32-5 32-15 32-4 32-16 51 32-8 52 32-11 32-2-1 32-2-2 32-9 32-7 32-6 32-18 32-17 32-15 71 32-2 32-13 32-12 70 72 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 61 | 152839001 | BED COVER SHAFT | 1 |
| 62 | * | LABEL | 1 |
| 63 | 152848001 | SPRING | 1 |
| 64 | 062680812 | SCREW 437X8 | 2 |
| 65 | 025080132 | WASHER 8 | 1 |
| 66 | 104450109 | OIL CAP | 2 |
| 70 | 154465001 | DUST OILER SUPPORT ASSEMBLY | 1 |
| 71 | 114486002 | OILER | 1 |
| 72 | 062710612 | SCREW 476X6 | 2 |
| 74 | 154785000 | FELT | 2 |
| 75 | 047501242 | SPRING PIN AW5 | 2 |
| 77 | 152847009 | PACKING | 2 |
A. 主体関係/Machine body/Maschinengehäuse/Corps de la machine/Cuerpo de la máquina REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 61 152839001 1 ベッド"カバー"ジク BED COVER SHAFT 62 * 1 ショウラベル LABEL 63 152848001 1 ベルトカバーバネ SPRING 64 062680812 2 ナベ"コ"437-40X8 SCREW 437X8 65 025080132 1 ヒラザガネショウ8 WASHER 8 66 104450109 2 メクラセン OIL CAP 70 154465001 1 ハイユキャップササエグミ DUST OILER SUPPORT ASSEMBLY 71 114486002 1 ホリオイラータイ OILER 72 062710612 2 ナベ"コ"476-32X6 SCREW 476X6 74 154785000 2 フェルト FELT 75 047501242 2 スプリング"ピン"AW5 SPRING PIN AW5 77 152847009 2 ベルトカバーゴムザ PACKING jintex.in
B. クラッチ関係/Clutch mechanism/Kupplungsvorrichtung/Mécanisme de l'embrayage/Mecanismo de embrague 39-4 39-5 39-2 39-3 43 45 44 54 39-1 42 41 40 52 39-6 39-7 52-1 29 31 30 53 55-3 24 30 31 32 15 25 55 55-1 38 28 27 26 27 37 36 35 55-2 21 10 33 13 14 2 6 12 11 34 7 8 9 4 3 5 16 19 18 20 22 23 47 17 48 46-2 18 46-3 58 60 61 59 46-1 71 73 80 82 64 67 74 70 71 75 57 72 51 50 49 63 62 65 66 85 86 76 78 79 77 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 151886001 | CLUTCH LEVER | 1 |
| 2 | 151927001 | CLUTCH FELT | 1 |
| 3 | 151887001 | CLUTCH LEVER SHAFT | 1 |
| 4 | 048180142 | STOP RING C18 | 1 |
| 5 | 152756001 | THRUST WASHER 18 | 1 |
| 6 | 014821022 | SET SCREW 7.94 | 1 |
| 7 | 151929000 | THRUST WASHER 18 | 1 |
| 8 | 152728001 | THRUST WASHER 8 | 1 |
| 9 | 151163001 | BOLT 8X15 | 1 |
| 10 | 151888101 | BALL PRESSER PLATE | 1 |
| 11 | 018082522 | BOLT 8X25 | 2 |
| 12 | 028080242 | SPRING WASHER 2-8 | 2 |
| 13 | 115012002 | SET SCREW 6.35 | 1 |
| 14 | 150554002 | NUT 6.35 | 1 |
| 15 | 151889001 | CLUTCH STOPPER | 1 |
| 16 | 151900000 | STOPPER RUBBER | 1 |
| 17 | 151891001 | SPRING | 1 |
| 18 | 151892001 | SPRING HOOK | 2 |
| 19 | 115018001 | CUSHION RUBBER | 2 |
| 20 | 025800332 | PLAIN WASHER 7.14 | 1 |
| 21 | 151893001 | STOPPER SHAFT | 1 |
| 22 | 021800102 | NUT 7.14 | 1 |
| 23 | 104689002 | NUT 7.14 | 1 |
| 24 | 151894101 | BRAKE LEVER | 1 |
| 25 | 151895000 | BRAKE ASSEMBLY | 1 |
| 26 | 151898001 | BRAKE SHAFT | 1 |
| 27 | 048040342 | STOP RING E4 | 2 |
| 28 | 151899001 | SPRING | 1 |
| 29 | 151900001 | BRAKE LEVER SHAFT | 1 |
| 30 | 142628001 | FEED ROCK CRANK RING | 2 |
| 31 | 048110142 | STOP RING C11 | 2 |
| 32 | 013761410 | SET SCREW 5.95 | 1 |
| 33 | 151901001 | PIN | 1 |
| 34 | 014760622 | SET SCREW 5.95 | 1 |
| 35 | 151902001 | SPRING | 1 |
| 36 | 151903001 | SCREW | 1 |
| 37 | 106147002 | NUT 7.94 | 1 |
| 38 | 110251001 | SPRING HOOK | 1 |
| 39 | 151904101 | CLUTCH LEVER ROD ASSEMBLY | 1 |
| 39-1 | 151905101 | CLUTCH LEVER ROD | 1 |
| 39-2 | 107744001 | ROLLER | 1 |
| 39-3 | 151906101 | ROLLER SHAFT | 1 |
| 39-4 | 048030342 | STOP RING E3 | 1 |
| 39-5 | 113431002 | WASHER | 1 |
| 39-6 | 025680132 | PLAIN WASHER 4.37 | 1 |
| 39-7 | 021680202 | NUT 4.37 | 1 |
| 40 | 151907001 | STUD SCREW 5.95 | 1 |
| 41 | 151908001 | NUT 5.95 | 1 |
| 42 | 155501001 | SPRING | 1 |
| 43 | 151910001 | SPRING HOOK | 1 |
| 44 | 117363001 | BOLT 4.76 | 2 |
| 45 | 028050242 | SPRING WASHER 2-5 | 2 |
| 46 | 152888101 | ADJUST ROD ASSEMBLY | 1 |
| 46-1 | 154332001 | PRESSER BAR LIFTER ADJUST ROD | 1 |
| 46-2 | 154333001 | PRESSER BAR LIFTER ADJUST JOINT | 1 |
| 46-3 | 150556001 | NUT 6.35 | 1 |
| 47 | 151912001 | STUD SCREW 6.35 | 1 |
| 48 | 150556001 | NUT 6.35 | 1 |
| 49 | 151913001 | STUD SCREW 6.35 | 1 |
| 50 | 151914001 | COLLAR 13 | 1 |
| 51 | 150556001 | NUT 6.35 | 1 |
| 52 | 151915101 | CLUTCH ACTUATING LEVER ASSEMBLY | 1 |
B. クラッチ関係/Clutch mechanism/Kupplungsvorrichtung/Mécanisme de l'embrayage/Mecanismo de embrague REF.NO. CODE Q'TY NAME OF PARTS RMKS 1 151886001 1 クラッチレバー CLUTCH LEVER 2 151927001 1 クラッチフェルト CLUTCH FELT 3 151887001 1 クラッチレバーシク CLUTCH LEVER SHAFT 4 048180142 1 トメワC18 STOP RING C18 5 152756001 1 スラストザガネ18 THRUST WASHER 18 6 014821022 1 アナトメネジ"7.94クボミ SET SCREW 7.94 7 151929000 1 スラストザガネ18 THRUST WASHER 18 8 152728001 1 スラストザガネ8 THRUST WASHER 8 9 151163001 1 アナボルト8X15 BOLT 8X15 10 151888101 1 ボールオサエイタ BALL PRESSER PLATE 11 018082522 2 アナボルト8X25 BOLT 8X25 12 028080242 2 バネザガネ2-8 SPRING WASHER 2-8 13 115012002 1 トメネジ6.35 SET SCREW 6.35 14 150554002 1 ナット6.35 NUT 6.35 15 151889001 1 ストッパタイ CLUTCH STOPPER 16 151900000 1 ストッパゴム STOPPER RUBBER 17 151891001 1 クラッチバネ SPRING 18 151892001 2 バネウケ SPRING HOOK 19 115018001 2 カンショウゴム CUSHION RUBBER 20 025800332 1 ヒラザガネダイ7.14 PLAIN WASHER 7.14 21 151893001 1 ストッパシク STOPPER SHAFT 22 021800102 1 ナット1シュ7.14 NUT 7.14 23 104689002 1 ナット7.14 NUT 7.14 24 151894101 1 ブレーキレバー BRAKE LEVER 25 151895000 1 ブレーキクミ BRAKE ASSEMBLY 26 151898001 1 ブレーキシク BRAKE SHAFT 27 048040342 2 トメワE4 STOP RING E4 28 151899001 1 ブレーキシューバネ SPRING 29 151900001 1 ブレーキレバーシク BRAKE LEVER SHAFT 30 142628001 2 スイヘイオクリクランクリング FEED ROCK CRANK RING 31 048110142 2 トメワジクウC11 STOP RING C11 32 013761410 1 トメネジ"5.95クボミ SET SCREW 5.95 33 151901001 1 ブレーキサトーピン PIN 34 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 35 151902001 1 ブレーキバネ SPRING 36 151903001 1 ブレーキバネカケネジ SCREW 37 106147002 1 ナット7.94 NUT 7.94 38 110251001 1 ヌノサエウデバネカケ SPRING HOOK 39 151904101 1 クラッチレバーレンカンクミ CLUTCH LEVER ROD ASSEMBLY 39-1 151905101 1 クラッチレバーレンカン CLUTCH LEVER ROD 39-2 107744001 1 コロ ROLLER 39-3 151906101 1 レンカンコロジク ROLLER SHAFT 39-4 048030342 1 トメワE3 STOP RING E3 39-5 113431002 1 ザガネ WASHER 39-6 025680132 1 ヒラザガネショウ4.37 PLAIN WASHER 4.37 39-7 021680202 1 ナット2シュ4.37 NUT 4.37 40 151907001 1 ダンネジ5.95 STUD SCREW 5.95 41 151908001 1 ナット5.95 NUT 5.95 42 155501001 1 クラッチレバーバネ SPRING 43 151910001 1 クラッチレバーバネカケ SPRING HOOK 44 117363001 2 ボルト4.76 BOLT 4.76 45 028050242 2 バネザガネ2-5 SPRING WASHER 2-5 46 152888101 1 チョウセツロッドクミ ADJUST ROD ASSEMBLY 46-1 154332001 1 オサエアゲチョウセツロッド PRESSER BAR LIFTER ADJUST ROD 46-2 154333001 1 オサエアゲチョウセツキテ PRESSER BAR LIFTER ADJUST JOINT 46-3 150556001 1 ナット6.35 NUT 6.35 47 151912001 1 ヘンシンダンネジ"6.35 STUD SCREW 6.35 48 150556001 1 ナット6.35 NUT 6.35 49 151913001 1 ダンネジ"6.35 STUD SCREW 6.35 50 151914001 1 カラー13 COLLAR 13 51 150556001 1 ナット6.35 NUT 6.35 52 151915101 1 クラッチサドーレバークミ CLUTCH ACTUATING LEVER ASSEMBLY jintex.in
B. クラッチ関係/Clutch mechanism/Kupplungsvorrichtung/ Mécanisme de l'embrayage/Mecanismo de embrague 39-4 39-5 39-2 39-3 54 43 45 44 39-1 42 41 40 52 39-6 39-7 52-1 29 31 30 53 55-3 24 30 31 32 25 55 15 38 28 27 26 27 55-1 37 36 35 55-2 21 10 33 13 14 2 6 12 11 3 5 34 7 8 9 4 16 19 18 20 22 23 47 17 48 46-2 69 68 46-3 18 58 60 61 59 46-1 71 73 80 82 64 67 74 70 71 75 57 72 51 50 49 63 62 65 66 76 78 79 77 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 52-1 | 152980001 | WICK 6X6 (L=150) | 1 |
| 53 | 150553001 | NUT 5.95 | 1 |
| 54 | 151907001 | STUD SCREW 5.95 | 1 |
| 55 | 151939101 | CLUTCH CAM LEVER ASSEMBLY | 1 |
| 55-1 | 152914001 | ROLLER | 1 |
| 55-2 | 048040342 | STOP RING E4 | 1 |
| 55-3 | 018062022 | BOLT 6X20 | 1 |
| 57 | 151919101 | STARTING LEVER | 1 |
| 58 | 151920001 | STARTING SAFETY LEVER | 1 |
| 59 | 017711412 | BOLT 4.76X14 | 2 |
| 60 | 028050242 | SPRING WASHER 2-5 | 2 |
| 61 | 113431002 | WASHER | 2 |
| 62 | 155499001 | STARTING LEVER PLATE | 1 |
| 63 | 154155101 | STOPPER SCREW | 1 |
| 64 | 150553001 | NUT 5.95 | 1 |
| 65 | 151922001 | CHAIN HOOK COLLAR | 1 |
| 66 | 017762202 | BOLT 5.95X22 | 1 |
| 67 | 110251001 | SPRING HOOK | 1 |
| 68 | 151923001 | SPRING | 1 |
| 69 | 151924001 | SPRING HOOK | 1 |
| 70 | 151925001 | STARTING LEVER SHAFT | 1 |
| 71 | 142628001 | FEED ROCK CRANK RING | 2 |
| 72 | 110505001 | WASHER | 1 |
| 73 | 048110142 | STOP RING C11 | 1 |
| 74 | 014760622 | SET SCREW 5.95 | 1 |
| 75 | 111865009 | OIL CAP | 1 |
| 76 | 155500001 | STARTING LEVER STOPPER | 1 |
| 77 | 018061622 | BOLT 6X16 | 2 |
| 78 | 025060132 | PLAIN WASHER 6 | 2 |
| 79 | 028060242 | SPRING WASHER 2-6 | 2 |
| 80 | 025060232 | PLAIN WASHER 6 | 1 |
| 82 | 028060242 | SPRING WASHER 2-6 | 1 |
B. クラッチ関係/Clutch mechanism/Kupplungsvorrichtung/ Mécanisme de l'embrayage/Mecanismo de embrague REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 52-1 152980001 1 クミヒモ6X6 (L=150) WICK 6X6 (L=150) 53 150553001 1 ナット5.95 NUT 5.95 54 151907001 1 ダンネジ5.95 STUD SCREW 5.95 55 151939101 1 クラッチカムレバークミ CLUTCH CAM LEVER ASSEMBLY 55-1 152914001 1 コロ ROLLER 55-2 048040342 1 トメワE4 STOP RING E4 55-3 018062022 1 アナボルト6X20 BOLT 6X20 57 151919101 1 キドーレバー STARTING LEVER 58 151920001 1 キドーセイフレバー STARTING SAFETY LEVER 59 017711412 2 ボルト4.76X14 BOLT 4.76X14 60 028050242 2 バネザガネ2-5 SPRING WASHER 2-5 61 113431002 2 ザガネ WASHER 62 155499001 1 Pサドーレバー STARTING LEVER PLATE 63 154155101 1 ストッパネジ STOPPER SCREW 64 150553001 1 ナット5.95 NUT 5.95 65 151922001 1 クサリカケカラー CHAIN HOOK COLLAR 66 017762202 1 ボルト5.95X22 BOLT 5.95X22 67 110251001 1 ヌノサエウデバネカケ SPRING HOOK 68 151923001 1 サドーレバーバネ SPRING 69 151924001 1 キドーレバーバネカケ SPRING HOOK 70 151925001 1 キドーレバージク STARTING LEVER SHAFT 71 142628001 2 スイヘイオクリクランクリング FEED ROCK CRANK RING 72 110505001 1 ザガネ WASHER 73 048110142 1 トメワジヨウC11 STOP RING C11 74 014760622 1 アナトメネジ5.95 SET SCREW 5.95 75 111865009 1 オイルメクラセン OIL CAP 76 155500001 1 キドーストッパ STARTING LEVER STOPPER 77 018061622 2 アナボルト6X16 BOLT 6X16 78 025060132 2 ヒラザガネチユウ6 PLAIN WASHER 6 79 028060242 2 バネザガネ2-6 SPRING WASHER 2-6 80 025060232 1 ヒラザガネチユウ6 PLAIN WASHER 6 82 028060242 1 バネザガネ2-6 SPRING WASHER 2-6 jintex.in
C. 上軸・針棒関係/Upper shaft and needle bar mechanism/Obere Welle und Nadelstangenrichtung/ Mécanisme de arbre supérieur et barre à aiguille/Mecanismo del eje superior y barra de aguja 3 36 4 5 6 5 7 8 14 13 1 11 2-1 2 25 22 35 34 20 21 17 19 15 16 20-2 20-1 26 20-4 20-3 24 18 33 27 20-7 20-6 20-5 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 151995001 | UPPER SHAFT | 1 |
| 2 | 153040001 | CRANK ROD ASSEMBLY | 1 |
| 2-1 | 144712002 | SCREW 4.76 | 2 |
| 3 | 048150142 | STOP RING C15 | 1 |
| 4 | 151997000 | BALL BEARING CASE | 1 |
| 5 | 072630260 | BEARING 6302VV | 2 |
| 6 | 151998000 | BEARING COLLAR | 1 |
| 7 | 151999001 | BALL BEARING CAP | 1 |
| 8 | 102843004 | SCREW 3.57 | 3 |
| 9 | 017761412 | BOLT 5.95X14 | 3 |
| 10 | 025060232 | PLAIN WASHER 6 | 3 |
| 11 | 140726000 | UPPER SHAFT BUSH (M) | 1 |
| 13 | 152000001 | UPPER SHAFT BUSH (F) | 1 |
| 14 | 013761412 | SET SCREW 5.95 | 1 |
| 15 | 152231000 | COUNTER WEIGHT | 1 |
| 16 | 100250001 | SCREW 7.14 | 1 |
| 17 | 014770622 | SET SCREW 6.35 | 1 |
| 18 | 101706001 | SET SCREW 6.35 | 1 |
| 19 | 014770622 | SET SCREW 6.35 | 1 |
| 20 | 152232001 | THREAD TAKE-UP LEVER ASSEMBLY | 1 |
| 20-1 | 153330001 | THREAD TAKE-UP ASSEMBLY | 1 |
| 20-2 | 152236001 | THREAD TAKE-UP SUPPORT STUD | 1 |
| 20-3 | 152237001 | NEEDLE BAR CRANK | 1 |
| 20-4 | 132051001 | SCREW 3.57L | 1 |
| 20-5 | 152238001 | THREAD TAKE-UP LEVER | 1 |
| 20-6 | 152239001 | NEEDLE BAR CLAMP | 1 |
| 20-7 | 062680812 | SCREW 437X8 | 1 |
| 21 | 013761412 | SET SCREW 5.95 | 1 |
| 22 | 152240001 | NEEDLE BAR (A) | 1 |
| 24 | 144458001 | SET SCREW 3.57 | 1 |
| 25 | 152242001 | NEEDLE BAR BUSH (U) | 1 |
| 26 | 152243001 | NEEDLE BAR BUSH (D) | 1 |
| 27 | * | NEEDLE DP | 1 |
| 33 | 142211001 | SLIDE BLOCK | 1 |
| 34 | 152244000 | NEEDLE BAR GUIDE | 1 |
| 35 | 062781412 | SCREW 635X14 | 2 |
| 36 | 116920001 | THRUST RING | 1 |
C. 上軸・針棒関係/Upper shaft and needle bar mechanism/Obere Welle und Nadelstangen vorrichtung/Mécanisme de arbre supérieur et barre à aiguille/Mecanismo del eje superior y barra de aguja REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 151995001 1 ウワジク UPPER SHAFT 2 153040001 1 クランクロッドクミ CRANK ROD ASSEMBLY 2-1 144712002 2 シメネジ4.76 SCREW 4.76 3 048150142 1 トメワジクC15 STOP RING C15 4 151997000 1 タマシジクウケケース BALL BEARING CASE 5 072630260 2 ベアリング6302VV BEARING 6302VV 6 151998000 1 ベアリングカンザ BEARING COLLAR 7 151999001 1 タマシジクフタ BALL BEARING CAP 8 102843004 3 サラネジ3.57 SCREW 3.57 9 017761412 3 ボルト5.95X14 BOLT 5.95X14 10 025060232 3 ヒラザガネチュウ6 PLAIN WASHER 6 11 140726000 1 ウワジクメタルM UPPER SHAFT BUSH (M) 13 152000001 1 ウワジクメタルF UPPER SHAFT BUSH (F) 14 013761412 1 トメネジ5.95クボミ SET SCREW 5.95 15 152231000 1 ツリアイクランク COUNTER WEIGHT 16 100250001 1 シメネジ7.14 SCREW 7.14 17 014770622 1 アナトメネジ6.35クボミ SET SCREW 6.35 18 101706001 1 トメネジ6.35 SET SCREW 6.35 19 014770622 1 アナトメネジ6.35クボミ SET SCREW 6.35 20 152232001 1 ハリボウレンカンクミ THREAD TAKE-UP LEVER ASSEMBLY 20-1 153330001 1 テンビンクミ THREAD TAKE-UP ASSEMBLY 20-2 152236001 1 テンビンササエジク THREAD TAKE-UP SUPPORT STUD 20-3 152237001 1 ハリボウクランク NEEDLE BAR CRANK 20-4 132051001 1 +サラネジ3.57L SCREW 3.57L 20-5 152238001 1 ハリボウレンカン THREAD TAKE-UP LEVER 20-6 152239001 1 ハリボウダキ NEEDLE BAR CLAMP 20-7 062680812 1 ナベコ437-40X8 SCREW 437X8 21 013761412 1 トメネジ5.95クボミ SET SCREW 5.95 22 152240001 1 ハリボウA NEEDLE BAR (A) 24 144458001 1 アタマツキトメネジ3.57 SET SCREW 3.57 25 152242001 1 ハリボウメタルU NEEDLE BAR BUSH (U) 26 152243001 1 ハリボウメタルD NEEDLE BAR BUSH (D) 27 * 1 ミシンハリDP NEEDLE DP 33 142211001 1 カクコマ SLIDE BLOCK 34 152244000 1 ハリボウアンナイ NEEDLE BAR GUIDE 35 062781412 2 ナベコ635-28X14 SCREW 635X14 36 116920001 1 オクリジクスラストリング THRUST RING jintex.in
D. 駆動・遊車関係/Drive pulley and idler pulley mechanism/Antriebsriemenscheibe und Riemenscheibe/ Mécanisme de poulie d'entraînement et poulie folle/Mecanismo de polea impulsora y polea tensora 17 18 9-7 9-3 21 19 26 24 9-6 20 22 23 25 8 7 1 1-2 1-1 1-4 1-5 1-3 9-1 9-4 9-2 9-5 9-2 9-4 9-1 E. 補給部品/Supply parts/Lieferteile/Pièces fournies/Piezas de suministro jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 153044001 | STOP CAM ASSEMBLY | 1 |
| 1-1 | 152693001 | BRAKE CAM SEGMENT | 1 |
| 1-2 | 152694001 | SPRING | 1 |
| 1-3 | 115003001 | FLANGE CAM SEGMENT | 1 |
| 1-4 | 153058001 | CAM SEGMENT STUD | 2 |
| 1-5 | 048040342 | STOP RING E4 | 2 |
| 7 | 147111001 | TAPER PIN 6X35 | 1 |
| 8 | 014770622 | SET SCREW 6.35 | 1 |
| 9 | 183686001 | PULLEY DEVICE SET | 1 |
| 9-1 | 152695201 | PULLEY DEVICE ASSEMBLY | 2 |
| 9-2 | 072600760 | BALL BEARING 6007VV | 2 |
| 9-3 | 152698001 | SLIDE BUSH | 1 |
| 9-4 | 048350142 | STOP RING C35 | 2 |
| 9-5 | 152699001 | WASHER | 1 |
| 9-6 | 048240242 | STOP RING C24 | 1 |
| 9-7 | 152700000 | SLIDE BUSH (A) | 1 |
| 17 | 151946000 | SLIDE BUSH (B) | 1 |
| 18 | 152701001 | SPRING | 1 |
| 19 | 152702001 | CLUTCH PLATE | 1 |
| 20 | 152703100 | SPACER | 5 |
| 21 | S02878000 | KEY 3X3X13 | 1 |
| 22 | 152705101 | NUT 10 | 1 |
| 23 | 152706001 | BALL BEARING | 1 |
| 24 | 062660712 | SCREW 318X7 | 4 |
| 25 | 071095250 | STEEL BALL 3/8" | 1 |
| 26 | S21120001 | WASHER | 1 |
| 1 | S01688001 | UPPER SHAFT ASSEMBLY B430 | 1 |
D. 動車・遊車関係/Drive pulley and idler pulley mechanism/Antriebsriemenscheibe und Riemenscheibe/ Mécanisme de poulie d'entraînement et poulie folle/Mecanismo de polea impulsora y polea tensora REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 153044001 1 ストップカムクミ STOP CAM ASSEMBLY 1-1 152693001 1 セイトウカムヘン BRAKE CAM SEGMENT 1-2 152694001 1 セイトウカムヘンバネ SPRING 1-3 115003001 1 カンショウカムヘン FLANGE CAM SEGMENT 1-4 153058001 2 カムヘンジク CAM SEGMENT STUD 1-5 048040342 2 トメワE4 STOP RING E4 7 147111001 1 テーパピン6X35 TAPER PIN 6X35 8 014770622 1 アナトメネジ6.35クボミ SET SCREW 6.35 9 183686001 1 プーリオクミ PULLEY DEVICE SET 9-1 152695201 2 プーリクミ PULLEY DEVICE ASSEMBLY 9-2 072600760 2 タマシジウケ6007VV BALL BEARING 6007VV 9-3 152698001 1 スライドメタル SLIDE BUSH 9-4 048350142 2 トメワC35 STOP RING C35 9-5 152699001 1 ナミワツシヤ WASHER 9-6 048240242 1 トメワアナC24 STOP RING C24 9-7 152700000 1 スライドブッシュA SLIDE BUSH (A) 17 151946000 1 スライドブッシュB SLIDE BUSH (B) 18 152701001 1 クラッチハンバネ SPRING 19 152702001 1 クラッチハン CLUTCH PLATE 20 152703100 5 スペーサ SPACER 21 S02878000 1 ヘイコウキ3X3X13 KEY 3X3X13 22 152705101 1 ナット10ヒタツリ NUT 10 23 152706001 1 ボールウケ BALL BEARING 24 062660712 4 ナベコ318-40X7 SCREW 318X7 25 071095250 1 コウキユウ3/8 STEEL BALL 3/8" 26 S21120001 1 ザガネ WASHER E. 補給部品/Supply parts/Lieferteile/Pièces fournies/Piezas de suministro REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 S01688001 1 ウワジククミ430 UPPER SHAFT ASSEMBLY B430 jintex.in
F. 送り関係/Feed mechanism/Transportvorrichtung/ Mécanisme de l'entraînement/Mecanismo de la alimentacion 35-8 35-5 35-3 35-4 35-7 35-13 35-1 35-16 35-12 35-17 35-10 35-11 35-10 40 39 35-20 35-14 35-18 35-9 35-15 35-2 35-8 25 35-19 22 24 28 21 27 43 44 42 16 17 18 19 33 20 26-1 34 23 26-2-1 26-2 38 37 36-3 36-2 32 31 36 36-1 1-2 1-5 30-1 1-3 1-4 1-1 10 9 8 4-1 7 4 6-1 6-2-1 6-2-2 6-2-4 6-2-3 3 2 11 12 12-1 14 15 30-2 30-3 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 152741101 | TACK LENGTH LEVER ASSEMBLY | 1 |
| 1-1 | 152742001 | TACK LENGTH LEVER | 1 |
| 1-2 | 153041001 | TACK LENGTH SLIDE BLOCK ASSEMBLY | 1 |
| 1-3 | 151602002 | SET SCREW 4.37 | 1 |
| 1-4 | 153924001 | FELT | 1 |
| 1-5 | 153921001 | WICK 4X4 (L=150) | 1 |
| 2 | 152745001 | FEED BUSH | 1 |
| 3 | 014760622 | SET SCREW 5.95 | 1 |
| 4 | 153762101 | TACK LENGTH REGULATOR LEVER ASSEMBLY | 1 |
| 4-1 | 018082022 | BOLT 8X20 | 1 |
| 6 | 153047001 | TACK LENGTH REGULATOR ASSEMBLY | 1 |
| 6-1 | 153042001 | TACK ADJUST SHAFT ASSEMBLY | 1 |
| 6-2 | 152751101 | SLIDE BLOCK ROLLER STUD ASSEMBLY | 1 |
| 6-2-1 | 152752001 | TACK LENGTH LEVER | 1 |
| 6-2-2 | 153043001 | FEED CAM ROLLER SHAFT ASSEMBLY | 1 |
| 6-2-3 | 014760622 | SET SCREW 5.95 | 1 |
| 6-2-4 | 152980001 | WICK 6X6 (L=150) | 1 |
| 7 | 152749001 | FEED ADJUST WASHER | 1 |
| 8 | 152750001 | FEED ADJUST NUT | 1 |
| 9 | 153045001 | TACK LENGTH LEVER STOPPER | 1 |
| 10 | 105451002 | SCREW 3.57 | 1 |
| 11 | 152755001 | TACK LENGTH LEVER SHAFT | 1 |
| 12 | S09132001 | PINCH SLEEVE ASSEMBLY | 1 |
| 12-1 | 018063022 | BOLT 6X30 | 1 |
| 14 | 152756001 | THRUST WASHER 18 | 1 |
| 15 | 048180142 | STOP RING C18 | 1 |
| 16 | 152758001 | TACK WIDTH FEED LEVER | 1 |
| 17 | 152759001 | TACK WIDTH FEED SHAFT | 1 |
| 18 | 014760622 | SET SCREW 5.95 | 1 |
| 19 | 152756001 | THRUST WASHER 18 | 1 |
| 20 | 152760001 | TACK WIDTH LEVER SHAFT | 1 |
| 21 | 152756001 | THRUST WASHER 18 | 1 |
| 22 | 048180142 | STOP RING C18 | 1 |
| 23 | 014760622 | SET SCREW 5.95 | 1 |
| 24 | 153045001 | TACK LENGTH LEVER STOPPER | 1 |
| 25 | 105451002 | SCREW 3.57 | 1 |
| 26 | 153048001 | TACK WIDTH REGULATOR LEVER ASSEMBLY | 1 |
| 26-1 | 153042001 | TACK ADJUST SHAFT ASSEMBLY | 1 |
| 26-2 | 153757001 | TACK WIDTH ADJUST ASSEMBLY | 1 |
| 26-2-1 | 018082022 | BOLT 8X20 | 1 |
| 27 | 152749001 | FEED ADJUST WASHER | 1 |
| 28 | 152750001 | FEED ADJUST NUT | 1 |
| 30 | 152762001 | TACK LENGTH CAM LEVER ASSEMBLY | 1 |
| 30-1 | 153331001 | TACK WIDTH FEED SHAFT ASSEMBLY | 1 |
| 30-2 | 153043001 | FEED CAM ROLLER SHAFT ASSEMBLY | 1 |
| 30-3 | 014760622 | SET SCREW 5.95 | 1 |
| 31 | 152745001 | FEED BUSH | 1 |
| 32 | 014760622 | SET SCREW 5.95 | 1 |
| 33 | 152766001 | FEED BAR GUIDE PLATE | 1 |
| 34 | 145318001 | SCREW 4.37 | 8 |
| 35 | * | PRESSER ARM ASSEMBLY | 1 |
| 35-1 | 152768009 | PRESSER ARM | 1 |
| 35-2 | 152774001 | PRESSER ARM LEVER (R) | 1 |
| 35-3 | 152775001 | PRESSER ARM LEVER (L) | 1 |
| 35-4 | 152776001 | PRESSER ARM LEVER SHAFT | 1 |
| 35-5 | 143591001 | THRUST RING | 2 |
| 35-6 | 048050342 | STOP RING E5 | 2 |
| 35-7 | 014760622 | SET SCREW 5.95 | 1 |
| 35-8 | * | WORK CLAMP (R) | 1 |
| 35-9 | * | WORK CLAMP (L) | 1 |
| 35-10 | 152783001 | WORK CLAMP GUIDE BRACKET (A) | 2 |
| 35-11 | 152784001 | WORK CLAMP GUIDE BRACKET (B) | 1 |
F. 送り関係/Feed mechanism/Transportvorrichtung/ Mécanisme de l'entraînement/Mecanismo de la alimentacion REF.NO. CODE Q'TY ヒンメイ NAME RMKS 1 152741101 1 ヨコオクリレバークミ TACK LENGTH LEVER ASSEMBLY 1-1 152742001 1 ヨコオクリレバー TACK LENGTH LEVER 1-2 153041001 1 ヨコオクリカクゴマクミ TACK LENGTH SLIDE BLOCK ASSEMBLY 1-3 151602002 1 トメネジ4.37 SET SCREW 4.37 1-4 153924001 1 フエルト FELT 1-5 153921001 1 クミヒモ4X4 (L=150) WICK 4X4 (L=150) 2 152745001 1 オクリメタル FEED BUSH 3 014760622 1 アナトメネジ5.95 SET SCREW 5.95 4 153762101 1 ヨコオクリチョウセツレバークミ TACK LENGTH REGULATOR LEVER ASSEMBLY 4-1 018082022 1 アナボルト8X20 BOLT 8X20 6 153047001 1 ヨコオクリチョウセツクミ TACK LENGTH REGULATOR ASSEMBLY 6-1 153042001 1 オクリチョウセツジククミ TACK ADJUST SHAFT ASSEMBLY 6-2 152751101 1 ヨコオクリカムレバークミ SLIDE BLOCK ROLLER STUD ASSEMBLY 6-2-1 152752001 1 ヨコオクリカムレバー TACK LENGTH LEVER 6-2-2 153043001 1 オクリカムコロジククミ FEED CAM ROLLER SHAFT ASSEMBLY 6-2-3 014760622 1 アナトメネジ5.95 SET SCREW 5.95 6-2-4 152980001 1 クミヒモ6X6 (L=150) WICK 6X6 (L=150) 7 152749001 1 オクリチョウセツザガネ FEED ADJUST WASHER 8 152750001 1 オクリチョウセツナット FEED ADJUST NUT 9 153045001 1 オクリレバーストッパ TACK LENGTH LEVER STOPPER 10 105451002 1 シメネジ3.57 SCREW 3.57 11 152755001 1 ヨコオクリレバージク TACK LENGTH LEVER SHAFT 12 S09132001 1 ピンチスリーブクミ PINCH SLEEVE ASSEMBLY 12-1 018063022 1 アナボルト6X30 BOLT 6X30 14 152756001 1 スラストザガネ18 THRUST WASHER 18 15 048180142 1 トメワC18 STOP RING C18 16 152758001 1 タテオクリレバー TACK WIDTH FEED LEVER 17 152759001 1 タテオクリジク TACK WIDTH FEED SHAFT 18 014760622 1 アナトメネジ5.95 SET SCREW 5.95 19 152756001 1 スラストザガネ18 THRUST WASHER 18 20 152760001 1 タテオクリレバージク TACK WIDTH LEVER SHAFT 21 152756001 1 スラストザガネ18 THRUST WASHER 18 22 048180142 1 トメワC18 STOP RING C18 23 014760622 1 アナトメネジ5.95 SET SCREW 5.95 24 153045001 1 オクリレバーストッパ TACK LENGTH LEVER STOPPER 25 105451002 1 シメネジ3.57 SCREW 3.57 26 153048001 1 タテオクリチョウセツクミ TACK WIDTH REGULATOR LEVER ASSEMBLY 26-1 153042001 1 オクリチョウセツジククミ TACK ADJUST SHAFT ASSEMBLY 26-2 153757001 1 タテオクリチョウセツレバークミ TACK WIDTH ADJUST ASSEMBLY 26-2-1 018082022 1 アナボルト8X20 BOLT 8X20 27 152749001 1 オクリチョウセツザガネ FEED ADJUST WASHER 28 152750001 1 オクリチョウセツナット FEED ADJUST NUT 30 152762001 1 タテオクリカムレバークミ TACK LENGTH CAM LEVER ASSEMBLY 30-1 153331001 1 タテオクリカムレバージククミ TACK WIDTH FEED SHAFT ASSEMBLY 30-2 153043001 1 オクリカムコロジククミ FEED CAM ROLLER SHAFT ASSEMBLY 30-3 014760622 1 アナトメネジ5.95 SET SCREW 5.95 31 152745001 1 オクリメタル FEED BUSH 32 014760622 1 アナトメネジ5.95 SET SCREW 5.95 33 152766001 1 オクリバーアンナイイタ FEED BAR GUIDE PLATE 34 145318001 8 シメネジ4.37 SCREW 4.37 35 * 1 オサエウデクミ PRESSER ARM ASSEMBLY 35-1 152768009 1 オサエウデ PRESSER ARM 35-2 152774001 1 オサエウデレバーミギ PRESSER ARM LEVER (R) 35-3 152775001 1 オサエウデレバーヒダリ PRESSER ARM LEVER (L) 35-4 152776001 1 オサエウデレバージク PRESSER ARM LEVER SHAFT 35-5 143591001 2 スラストリング THRUST RING 35-6 048050342 2 トメワE5 STOP RING E5 35-7 014760622 1 アナトメネジ5.95 SET SCREW 5.95 35-8 * 1 オサエアシR WORK CLAMP (R) 35-9 * 1 オサエアシL WORK CLAMP (L) 35-10 152783001 2 オサエアシオサエイタA WORK CLAMP GUIDE BRACKET (A) 35-11 152784001 1 オサエアシオサエイタB WORK CLAMP GUIDE BRACKET (B) jintex.in
F. 送り関係/Feed mechanism/Transportvorrichtung/ Mécanisme de l'entraînement/Mecanismo de la alimentacion 35-6 35-5 35-3 35-4 35-7 35-13 35-1 35-16 35-12 35-17 35-10 35-11 35-10 40 39 35-14 35-20 35-9 35-15 35-18 35-2 35-8 25 22 24 28 35-19 42 21 27 43 44 17 16 19 33 20 26-1 34 23 26-2-1 26-2 38 37 36-3 36-2 32 31 36 36-1 1-2 1-5 1-3 1-4 1-1 10 9 4-1 8 7 30-1 4 6-1 6-2-1 6-2-2 30-3 30-2 6-2-4 6-2-3 3 2 11 12 12-1 14 15 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 35-12 | 107038003 | SCREW 3.57 | 6 |
| 35-13 | 153571001 | PRESSER ARM LEVER PLATE | 2 |
| 35-14 | 140407002 | WASHER | 2 |
| 35-15 | 018500822 | BOLT 5X8 | 2 |
| 35-16 | 153570001 | SPRING GUIDE ROD | 2 |
| 35-17 | 145478001 | STUD SCREW 4.76 | 2 |
| 35-18 | * | SPRING | 2 |
| 35-19 | 152788000 | SPRING COLLAR | 2 |
| 35-20 | 153567000 | SPRING COLLAR | 2 |
| 36 | 152769001 | FEED BAR GUIDE ASSEMBLY | 1 |
| 36-1 | 152771000 | COLLAR | 2 |
| 36-2 | 152773000 | BUSH | 1 |
| 36-3 | 141331001 | BUSH | 1 |
| 37 | 152772001 | WASHER | 2 |
| 38 | 071047650 | STEEL BALL 3/16" | 2 |
| 39 | 025060232 | PLAIN WASHER 6 | 2 |
| 40 | 017761412 | BOLT 5.95X14 | 2 |
| 42 | 153057002 | SCREW | 2 |
| 43 | 153035000 | PRESSER ARM FELT | 1 |
| 44 | * | FEED PLATE | 1 |
F. 送り関係/Feed mechanism/Transportvorrichtung/Mécanisme de l'entraînement/Mecanismo de la alimentacion REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 35-12 107038003 6 サラネジ3.57 SCREW 3.57 35-13 153571001 2 オサエウデレバーイタ PRESSER ARM LEVER PLATE 35-14 140407002 2 ザガネ WASHER 35-15 018500822 2 アナボルト5X8 BOLT 5X8 35-16 153570001 2 オサエハネアンナイロッド SPRING GUIDE ROD 35-17 145478001 2 ダンネジ4.76 STUD SCREW 4.76 35-18 * 2 オサエバネ SPRING 35-19 152788000 2 オサエバネカンザ SPRING COLLAR 35-20 153567000 2 オサエバネカラー SPRING COLLAR 36 152769001 1 オクリダイクミ FEED BAR GUIDE ASSEMBLY 36-1 152771000 2 オクリダイカンザ COLLAR 36-2 152773000 1 キュウメンブッシュメタル BUSH 36-3 141331001 1 キュウメンブッシュ BUSH 37 152772001 2 カンザ WASHER 38 071047650 2 コウキュウ3/16 STEEL BALL 3/16" 39 025060232 2 ヒラザガネチュウ6 PLAIN WASHER 6 40 017761412 2 ボルト5.95X14 BOLT 5.95X14 42 153057002 2 オクリイタシメネジ SCREW 43 153035000 1 オサエウデフェルト PRESSER ARM FELT 44 * 1 オクリイタ FEED PLATE jintex.in
G. 押工上ゲ関係/Work clamp lifter mechanism/Stoffhalterhebervorrichtung/ Mécanisme de leveur du pinceur/Mecanismo del levantador de ménsula de trabajo 16 15 14-1 14-2 12 11 13 9 10 18 19 2-1 2-2 8 7 5 19 18 3 14-2 6 20-1 20-3 20-2 23 21 22 28 24 26 27 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 152794001 | WORK CLAMP LIFTER PLATE ASSEMBLY | 1 |
| 2 | 152797001 | WORK CLAMP LIFTER LEVER ASSEMBLY | 1 |
| 2-1 | 152798001 | WORK CLAMP LIFTER LEVER | 1 |
| 2-2 | 152744001 | PIN | 1 |
| 3 | 152799001 | WORK CLAMP LIFTER LEVER SHAFT | 1 |
| 4 | 014760622 | SET SCREW 5.95 | 1 |
| 5 | 013760612 | SET SCREW 5.95 | 1 |
| 6 | 152800201 | SPRING | 1 |
| 7 | 152801001 | PIN | 1 |
| 8 | 102630001 | NEEDLE BAR GUIDE SLIDE BLOCK | 1 |
| 9 | 152802001 | WORK CLAMP LIFTER ROD SHAFT (A) | 1 |
| 10 | 014760622 | SET SCREW 5.95 | 1 |
| 11 | 107153002 | WASHER | 1 |
| 12 | 048060342 | STOP RING E6 | 1 |
| 13 | 152803001 | WORK CLAMP LIFTER ROD (A) | 1 |
| 14-1 | 152805101 | CONNECTING LEVER | 1 |
| 14-2 | 152806001 | CONNECTING LEVER SHAFT (B) | 2 |
| 15 | 158686001 | LIFTING LEVER SHAFT | 1 |
| 16 | 014760622 | SET SCREW 5.95 | 1 |
| 18 | 107153002 | WASHER | 2 |
| 19 | 048060342 | STOP RING E6 | 2 |
| 20 | 152808101 | ADJUST ROD ASSEMBLY | 1 |
| 20-1 | 154332001 | PRESSER BAR LIFTER ADJUST ROD | 1 |
| 20-2 | 154333001 | PRESSER BAR LIFTER ADJUST JOINT | 1 |
| 20-3 | 150568001 | NUT 6.35 | 1 |
| 21 | 141583001 | STUD SCREW 6.35 | 1 |
| 22 | 150556001 | NUT 6.35 | 1 |
| 23 | 152811001 | CONNECTING LEVER ASSEMBLY | 1 |
| 24 | 158687001 | DRIVING SHAFT | 1 |
| 26 | 142628001 | FEED ROCK CRANK RING | 1 |
| 27 | 048110142 | STOP RING C11 | 1 |
| 28 | 014760622 | SET SCREW 5.95 | 1 |
G. 押工上げ関係/Work clamp lifter mechanism/Stoffhalterhebervorrichtung/ Mécanisme de leveur du pinceur/Mecanismo del levantador de ménsula de trabajo REF.NO. CODE Q'TY NAME OF PARTS RMKS 1 152794001 1 WORK CLAMP LIFTER PLATE ASSEMBLY 2 152797001 1 WORK CLAMP LIFTER LEVER ASSEMBLY 2-1 152798001 1 WORK CLAMP LIFTER LEVER 2-2 152744001 1 PIN 3 152799001 1 WORK CLAMP LIFTER LEVER SHAFT 4 014760622 1 SET SCREW 5.95 5 013760612 1 SET SCREW 5.95 6 152800201 1 SPRING 7 152801001 1 PIN 8 102630001 1 NEEDLE BAR GUIDE SLIDE BLOCK 9 152802001 1 WORK CLAMP LIFTER ROD SHAFT (A) 10 014760622 1 SET SCREW 5.95 11 107153002 1 WASHER 12 048060342 1 STOP RING E6 13 152803001 1 WORK CLAMP LIFTER ROD (A) 14-1 152805101 1 CONNECTING LEVER 14-2 152806001 2 CONNECTING LEVER SHAFT (B) 15 158686001 1 LIFTING LEVER SHAFT 16 014760622 1 SET SCREW 5.95 18 107153002 2 WASHER 19 048060342 2 STOP RING E6 20 152808101 1 ADJUST ROD ASSEMBLY 20-1 154332001 1 PRESSER BAR LIFTER ADJUST ROD 20-2 154333001 1 PRESSER BAR LIFTER ADJUST JOINT 20-3 150568001 1 NUT 6.35 21 141583001 1 STUD SCREW 6.35 22 150556001 1 NUT 6.35 23 152811001 1 CONNECTING LEVER ASSEMBLY 24 158687001 1 DRIVING SHAFT 26 142628001 1 FEED ROCK CRANK RING 27 048110142 1 STOP RING C11 28 014760622 1 SET SCREW 5.95 jintex.in
H. カム伝導関係/Vertical shaft mechanism/Vertikale Welle/ Mécanisme d'arbre vertical/Mecanismo de eje vertical 6 4 7 8 5 3 2 10 9 49 48 39 36 40 37 38 12 28 35 52 29-1 29 20 34 11 13 19 20-1 16 22 15 17 18 輸出用/FOR EXPORT 26 27 23 25 24 51 42 41 44 45 43-1 43-5 47 46 43-2 43-3 43-4 32-1 32 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 152707001 | WORM | 1 |
| 2 | 152718001 | SET SCREW 5.95 | 6 |
| 3 | 147151000 | WASHER | 1 |
| 4 | 152708000 | WORM WHEEL | 1 |
| 5 | 152713001 | THRUST WASHER | 1 |
| 6 | 152709000 | SLEEVE | 1 |
| 7 | 152710001 | WASHER | 1 |
| 8 | 018062022 | BOLT 6X20 | 1 |
| 9 | 159977000 | VERTICAL SHAFT BUSH (U) | 1 |
| 10 | 014760622 | SET SCREW 5.95 | 1 |
| 11 | 159978001 | VERTICAL SHAFT BUSH (L) | 1 |
| 12 | 159979001 | VERTICAL SHAFT ASSEMBLY | 1 |
| 13 | 159984001 | THRUST WASHER 40 | 1 |
| 15 | * | CHANGE GEAR (W) | 1 |
| 16 | * | CHANGE GEAR (C) | 1 |
| 17 | 153104001 | WASHER | 1 |
| 18 | 018062222 | BOLT 6X22 | 3 |
| 19 | 152724001 | TACK LENGTH FEED CAM SHAFT | 1 |
| 20 | S09132001 | PINCH SLEEVE ASSEMBLY | 1 |
| 20-1 | 018063022 | BOLT 6X30 | 1 |
| 22 | * | FEED CAM | 1 |
| 23 | 152728001 | THRUST WASHER 8 | 1 |
| 24 | 151163001 | BOLT 8X15 | 1 |
| 25 | 018062022 | BOLT 6X20 | 3 |
| 26 | 109893002 | WASHER | 3 |
| 27 | 028060242 | SPRING WASHER 2-6 | 3 |
| 28 | 152729001 | CLUTCH CAM | 1 |
| 29 | S09132001 | PINCH SLEEVE ASSEMBLY | 1 |
| 29-1 | 018063022 | BOLT 6X30 | 1 |
| 32 | S09132001 | PINCH SLEEVE ASSEMBLY | 1 |
| 32-1 | 018063022 | BOLT 6X30 | 1 |
| 34 | 152723001 | STOP RING | 1 |
| 35 | 152731001 | ROLLER HOLDER | 1 |
| 36 | 152732001 | ROLLER SHAFT | 1 |
| 37 | 013710712 | SET SCREW 4.76 | 1 |
| 38 | 152914001 | ROLLER | 1 |
| 39 | 152733001 | EMERGENCY STOP LEVER | 1 |
| 40 | 013710712 | SET SCREW 4.76 | 1 |
| 41 | 152734001 | ROLLER HOLDER LEVER | 1 |
| 42 | 018061622 | BOLT 6X16 | 1 |
| 43 | 152735101 | ROLLER HOLDER CAM LEVER ASSEMBLY | 1 |
| 43-1 | 153332001 | ROLLER HOLDER CAM LEVER SHAFT ASSEMBLY | 1 |
| 43-2 | 152739001 | ROLLER SHAFT | 1 |
| 43-3 | 153195001 | ROLLER | 1 |
| 43-4 | 048040342 | STOP RING E4 | 1 |
| 43-5 | 155337001 | SPRING HOOK | 1 |
| 44 | 110027001 | SET COLLAR | 1 |
| 45 | 014760622 | SET SCREW 5.95 | 2 |
| 46 | 155336001 | SPRING | 1 |
| 47 | 141334001 | SPRING HOOK | 1 |
| 48 | 153141001 | ROLLER HOLDER COVER | 1 |
| 49 | 062670412 | SCREW 357X4 | 2 |
| 51 | S07813001 | CLUTCH CAM (SP) | 1 |
| 52 | S07814001 | KNIFE CAM (SP) | 1 |
H. カム伝導関係/Vertical shaft mechanism/Vertikale Welle/ Mécanisme d'arbre vertical/Mecanismo de eje vertical REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 152707001 1 ウォーム WORM 2 152718001 6 アナトメネジ5.95 SET SCREW 5.95 3 147151000 1 トメザガネ WASHER 4 152708000 1 ウォームホイール WORM WHEEL 5 152713001 1 スラストザガネ THRUST WASHER 6 152709000 1 スリーブ SLEEVE 7 152710001 1 ザガネ WASHER 8 018062022 1 アナボルト6X20 BOLT 6X20 9 159977000 1 タテジクメタルU VERTICAL SHAFT BUSH (U) 10 014760622 1 アナトメネジ5.95 SET SCREW 5.95 11 159978001 1 タテジクメタルL VERTICAL SHAFT BUSH (L) 12 159979001 1 タテジククミ VERTICAL SHAFT ASSEMBLY 13 159984001 1 スラストザガネ40 THRUST WASHER 40 15 * 1 チェンジギヤW CHANGE GEAR (W) 16 * 1 チェンジギヤC CHANGE GEAR (C) 17 153104001 1 チェンジギヤザガネ WASHER 18 018062222 3 アナボルト6X22 BOLT 6X22 19 152724001 1 カムジク TACK LENGTH FEED CAM SHAFT 20 S09132001 1 ピンチスリーブクミ PINCH SLEEVE ASSEMBLY 20-1 018063022 1 アナボルト6X30 BOLT 6X30 22 * 1 オクリカム FEED CAM 23 152728001 1 スラストザガネ8 THRUST WASHER 8 24 151163001 1 アナボルト8X15 BOLT 8X15 25 018062022 3 アナボルト6X20 BOLT 6X20 26 109893002 3 ザガネ WASHER 27 028060242 3 バネザガネ2-6 SPRING WASHER 2-6 28 152729001 1 クラッチカム CLUTCH CAM 29 S09132001 1 ピンチスリーブクミ PINCH SLEEVE ASSEMBLY 29-1 018063022 1 アナボルト6X30 BOLT 6X30 32 S09132001 1 ピンチスリーブクミ PINCH SLEEVE ASSEMBLY 32-1 018063022 1 アナボルト6X30 BOLT 6X30 34 152723001 1 イトキリカムトメリング STOP RING 35 152731001 1 セイギョタイ ROLLER HOLDER 36 152732001 1 セイギョタイコロジク ROLLER SHAFT 37 013710712 1 トメネジ4.76クボミ SET SCREW 4.76 38 152914001 1 コロ ROLLER 39 152733001 1 ヒジョウテイシレバー EMERGENCY STOP LEVER 40 013710712 1 トメネジ4.76クボミ SET SCREW 4.76 41 152734001 1 セイギョレバー ROLLER HOLDER LEVER 42 018061622 1 アナボルト6X16 BOLT 6X16 43 152735101 1 セイギョカムレバークミ ROLLER HOLDER CAM LEVER ASSEMBLY 43-1 153332001 1 セイギョカムレバージククミ ROLLER HOLDER CAM LEVER SHAFT ASSEMBLY 43-2 152739001 1 コロジク ROLLER SHAFT 43-3 153195001 1 コロ ROLLER 43-4 048040342 1 トメワE4 STOP RING E4 43-5 155337001 1 バネカケ SPRING HOOK 44 110027001 1 セットカラー SET COLLAR 45 014760622 2 アナトメネジ5.95 SET SCREW 5.95 46 155336001 1 セイギョバネ SPRING 47 141334001 1 バネカケ SPRING HOOK 48 153141001 1 セイギョタイカバー ROLLER HOLDER COVER 49 062670412 2 ナベコ357-40X4 SCREW 357X4 51 S07813001 1 イトキリカムSP CLUTCH CAM (SP) 52 S07814001 1 イトキリカムSP KNIFE CAM (SP) jintex.in
J. パワー押工関係/Power lift mechanism/Heberbetätigungsvorrichtung/ Mécanisme de leveur/Mecanismo de carrera de potencia 10-3 10-2 10-4 2 12 11 13 10-1-1 30 1 2 10-1 3-1 3-2 8 9 23 22 23 19 27 19-1 19-2 19-3 20 25 26 28 24 29 26 25 21 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 151928001 | POWER PULLEY SHAFT | 1 |
| 2 | 048170142 | STOP RING C17 | 2 |
| 3 | 156936101 | POWER PULLEY ASSEMBLY | 1 |
| 3-1 | 151930201 | POWER PULLEY ASSEMBLY | 1 |
| 3-2 | 072600360 | BALL BEARING 6003VV | 1 |
| 8 | 151932001 | BEARING COVER | 1 |
| 9 | 107231002 | SCREW 4.76 | 1 |
| 10 | * | POWER CAM SET | 1 |
| 10-1 | * | POWER CAM ASSEMBLY | 1 |
| 10-1-1 | 151935000 | (DV) BUSH | 2 |
| 10-2 | 151940001 | POWER CAM STOPPER (A) | 1 |
| 10-3 | 018060822 | BOLT 6X8 | 1 |
| 10-4 | 151941101 | POWER CAM STOPPER (B) ASSEMBLY | 1 |
| 11 | 151936001 | SPRING | 1 |
| 12 | 151937001 | THRUST WASHER 17 | 1 |
| 13 | 151938001 | WASHER | 1 |
| 19 | 151944001 | CLUTCH ACTUATING LEVER ASSEMBLY | 1 |
| 19-1 | 151947101 | ROLLER (11) | 2 |
| 19-2 | 151948001 | ROLLER SHAFT | 2 |
| 19-3 | 014760622 | SET SCREW 5.95 | 2 |
| 20 | 151949001 | ROLLER SHAFT ASSEMBLY | 1 |
| 21 | 014760622 | SET SCREW 5.95 | 1 |
| 22 | 151951001 | SPRING | 1 |
| 23 | 141472002 | SPRING HOOK | 2 |
| 24 | 151952001 | CLUTCH ACTUATING LEVER SHAFT | 1 |
| 25 | 151953001 | THRUST WASHER 16 | 2 |
| 26 | 048160142 | STOP RING C16 | 2 |
| 27 | 107149001 | FELT | 1 |
| 28 | 151954001 | SCREW | 1 |
| 29 | 014821022 | SET SCREW 7.94 | 1 |
| 30 | 014760622 | SET SCREW 5.95 | 1 |
J. パワー押工関係/Power lift mechanism/Heberbetätigungsvorrichtung/ Mécanisme de leveur/Mecanismo de carrera de potencia REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 151928001 1 Pプーリジク POWER PULLEY SHAFT 2 048170142 2 トメワジクC17 STOP RING C17 3 156936101 1 Pプーリクミ POWER PULLEY ASSEMBLY 3-1 151930201 1 Pプーリクミ POWER PULLEY ASSEMBLY 3-2 072600360 1 タマジクウケ6003VV BALL BEARING 6003VV 8 151932001 1 ジクウケフタ BEARING COVER 9 107231002 1 ザラネジ4.76 SCREW 4.76 10 * 1 パワーカムセット POWER CAM SET 10-1 * 1 パワーカムクミ POWER CAM ASSEMBLY 10-1-1 151935000 2 DVブッシュ (DV) BUSH 10-2 151940001 1 パワーカムストッパA POWER CAM STOPPER (A) 10-3 018060822 1 アナボルト6X8 BOLT 6X8 10-4 151941101 1 パワーカムストッパBクミ POWER CAM STOPPER (B) ASSEMBLY 11 151936001 1 Pクラッチバネ SPRING 12 151937001 1 スラストザガネ17 THRUST WASHER 17 13 151938001 1 ザガネ WASHER 19 151944001 1 クドーレバークミ CLUTCH ACTUATING LEVER ASSEMBLY 19-1 151947101 2 コロ11 ROLLER (11) 19-2 151948001 2 クドーレバーコロジク ROLLER SHAFT 19-3 014760622 2 アナトメネジ5.95 SET SCREW 5.95 20 151949001 1 オサエアゲコロジククミ ROLLER SHAFT ASSEMBLY 21 014760622 1 アナトメネジ5.95 SET SCREW 5.95 22 151951001 1 クドーレバーヒキバネ SPRING 23 141472002 2 シタイトキリレバーハネカケ SPRING HOOK 24 151952001 1 クドーレバージク CLUTCH ACTUATING LEVER SHAFT 25 151953001 2 スラストザガネ16 THRUST WASHER 16 26 048160142 2 トメワジクC16 STOP RING C16 27 107149001 1 フエルト FELT 28 151954001 1 アンナイヒンネジ SCREW 29 014821022 1 アナトメネジ7.94クボミ SET SCREW 7.94 30 014760622 1 アナトメネジ5.95 SET SCREW 5.95 jintex.in
K. 下軸関係/Lower shaft mechanism/Untere Welle/ Mécanisme de l'arbre inférieur/Mecanismo del eje inferior 35 35-2 35-3 16-9 16-3 16-4 16-2 16-1 34 24 25 10 14 15 23 16-7 13 12 11 17 18 19 16-6 16-8 36 26 31 16-5 16-10 16-11 9 3 2 1 7 8 4 5 6 22 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 141786001 | CRANK ROD STUD SCREW | 1 |
| 2 | 104689002 | NUT 7.14 | 1 |
| 3 | 014680622 | SET SCREW 4.37 | 1 |
| 4 | 152245001 | ROCK GEAR | 1 |
| 5 | 152246001 | ROCK GEAR SHAFT | 1 |
| 6 | 014760622 | SET SCREW 5.95 | 1 |
| 7 | 152247001 | ROCK SHAFT BUSH | 1 |
| 8 | 014760622 | SET SCREW 5.95 | 1 |
| 9 | 152191101 | LOWER SHAFT ASSEMBLY | 1 |
| 10 | 152250001 | LOWER SHAFT BUSH | 1 |
| 11 | 014760622 | SET SCREW 5.95 | 1 |
| 12 | 152678001 | SHUTTLE HOOK ADJUST STUD | 1 |
| 13 | 081003670 | O RING PW3 | 1 |
| 14 | 110495003 | SET COLLAR | 1 |
| 15 | 014770622 | SET SCREW 6.35 | 2 |
| 16 | S00327001 | SHUTTLE RACE BASE ASSEMBLY | 1 |
| 16-1 | 152677001 | SHUTTLE RACE BASE | 1 |
| 16-2 | 152679001 | SHUTTLE RACE THREAD GUIDE (R) | 1 |
| 16-3 | 152680001 | SHUTTLE RACE THREAD GUIDE (L) | 1 |
| 16-4 | 062660412 | SCREW 318X4 | 2 |
| 16-5 | 152683001 | LARGE SHUTTLE HOOK SET CLAW | 2 |
| 16-6 | 152684001 | SPRING | 2 |
| 16-7 | 402887001 | WASHER 3.2 | 2 |
| 16-8 | 062660712 | SCREW 318X7 | 2 |
| 16-9 | 153050000 | SHUTTLE RACE BASE FELT | 2 |
| 16-10 | 155489000 | WICK (L=270) | 1 |
| 16-11 | S00400000 | WICK 2.5X220 | 1 |
| 17 | 014760622 | SET SCREW 5.95 | 1 |
| 18 | 152678001 | SHUTTLE HOOK ADJUST STUD | 1 |
| 19 | 081003670 | O RING PW3 | 1 |
| 23 | 048080342 | STOP RING E8 | 1 |
| 24 | 152681201 | DRIVER | 1 |
| 25 | 018501422 | BOLT 5X14 | 1 |
| 26 | * | LARGE SHUTTLE HOOK | 1 |
| 31 | * | INNER ROTARY HOOK | 1 |
| 34 | 141808001 | PIN | 1 |
| 35 | 159610101 | BOBBIN CASE ASSEMBLY (A) | 1 |
| 35-1 | 154339001 | TENSION SPRING | 1 |
| 35-2 | 154341001 | SCREW | 1 |
| 35-3 | 159612001 | BOBBIN TENSION SPRING | 1 |
| 36 | 159613001 | BOBBIN | 1 |
K. 下軸関係/Lower shaft mechanism/Untere Welle/ Mécanisme de l'arbre inférieur REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 141786001 1 クランクロット"ダンネジ" CRANK ROD STUD SCREW 2 104689002 1 ナット7.14 NUT 7.14 3 014680622 1 アナトメネジ"4.37クボミ SET SCREW 4.37 4 152245001 1 ヨウト"ウキヤ ROCK GEAR 5 152246001 1 ヨウト"ウキヤージジク ROCK GEAR SHAFT 6 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 7 152247001 1 ヨウト"ウジクメタル ROCK SHAFT BUSH 8 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 9 152191101 1 シタジククミ LOWER SHAFT ASSEMBLY 10 152250001 1 シタジクメタル LOWER SHAFT BUSH 11 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 12 152678001 1 カマチョウセツジク SHUTTLE HOOK ADJUST STUD 13 081003670 1 OリングPW3 O RING PW3 14 110495003 1 セットカラー SET COLLAR 15 014770622 2 アナトメネジ"6.35クボミ SET SCREW 6.35 16 S00327001 1 オオカマタイクミ SHUTTLE RACE BASE ASSEMBLY 16-1 152677001 1 オオカマタイ SHUTTLE RACE BASE 16-2 152679001 1 カマイトアンナイR SHUTTLE RACE THREAD GUIDE (R) 16-3 152680001 1 カマイトアンナイL SHUTTLE RACE THREAD GUIDE (L) 16-4 062660412 2 ナベコ318-40X4 SCREW 318X4 16-5 152683001 2 オオカマトツケツメ LARGE SHUTTLE HOOK SET CLAW 16-6 152684001 2 オオカマトツケツハネ SPRING 16-7 402887001 2 ザガネ3.2 WASHER 3.2 16-8 062660712 2 ナベコ318-40X7 SCREW 318X7 16-9 153050000 2 オオカマタイフエルト SHUTTLE RACE BASE FELT 16-10 155489000 1 クミヒモ(L=270) WICK (L=270) 16-11 S00400000 1 クミヒモ2.5X220 WICK 2.5X220 17 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 18 152678001 1 カマチョウセツジク SHUTTLE HOOK ADJUST STUD 19 081003670 1 OリングPW3 O RING PW3 23 048080342 1 トメワE8 STOP RING E8 24 152681201 1 ドライバー DRIVER 25 018501422 1 アナボルト5X14 BOLT 5X14 26 * 1 オオカマ LARGE SHUTTLE HOOK 31 * 1 ナカカマ INNER ROTARY HOOK 34 141808001 1 オオカマアンナイピン PIN 35 159610101 1 ボビンケースクミA BOBBIN CASE ASSEMBLY (A) 35-1 154339001 1 ボビンケーススチョウシハネ TENSION SPRING 35-2 154341001 1 ボビンケースハネネジ SCREW 35-3 159612001 1 クウテンボウシハネ BOBBIN TENSION SPRING 36 159613001 1 ボビン BOBBIN 24 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2-7 | 2-7 | ||
| 2-6 | 2-6 | ||
| 2-3 | 2-3 | ||
| 2-4 | 2-4 | ||
| 2-2 | 2-2 | ||
| 2-1 | 2-1 | ||
| 64 | 64 | ||
| 49 | 49 | ||
| 51 | 51 | ||
| 50 | 50 | ||
| 52 | 52 | ||
| 62 | 62 | ||
| 4-1 | 4-1 | ||
| 4-3 | 4-3 | ||
| 5 | 5 | ||
| 4-2 | 4-2 | ||
| 1 | 1 | ||
| 6 | 6 | ||
| 68 | 68 | ||
| 59 | 59 | ||
| 61 | 61 | ||
| 60 | 60 | ||
| 23 | 23 | ||
| 26 | 26 | ||
| 25 | 25 | ||
| 21 | 21 | ||
| 20 | 20 | ||
| 15 | 15 | ||
| 14 | 14 | ||
| 22 | 22 | ||
| 17 | 17 | ||
| 19 | 19 | ||
| 37 | 37 | ||
| 41 | 41 | ||
| 42 | 42 | ||
| 34 | 34 | ||
| 39 | 39 | ||
| 43 | 43 | ||
| 45 | 45 | ||
| 40 | 40 | ||
| 70 | 70 | ||
| 58 | 58 | ||
| 54 | 54 | ||
| 53 | 53 | ||
| 56 | 56 | ||
| 29 | 29 | ||
| 31 | 31 | ||
| 33 | 33 | ||
| 32 | 32 | ||
| 28 | 28 | ||
| 11 | 11 | ||
| 69 | 69 | ||
| 36 | 36 | ||
| 38 | 38 | ||
| 47 | 47 | ||
| 65 | 65 | ||
| 46 | 46 | ||
| 48 | 48 | ||
| 63-1 | 63-1 | ||
| 63-2 | 63-2 | ||
| 13 | 13 | ||
| 12-1 | 12-1 | ||
| 12-5 | 12-5 | ||
| 12-2 | 12-2 | ||
| 12-4 | 12-4 | ||
| 12-3 | 12-3 | ||
| 12-6 | 12-6 | ||
| 12-4 | 12-4 | ||
| 12-8 | 12-8 | ||
| 12-7 | 12-7 |
L. 給油潤滑関係 / Lubrication/Schmierung/Lubrication/Lubricación 2-7 2-6 2-3 2-4 2-2 2-1 64 49 51 50 52 62 4-1 4-3 5 4-2 1 6 68 59 61 60 23 26 25 21 20 15 14 22 17 19 37 41 42 34 39 43 45 40 70 58 54 53 56 29 31 33 32 28 11 69 36 38 47 65 46 48 63-1 63-2 13 12-1 12-5 12-2 12-4 12-3 12-6 12-4 12-8 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 152948001 | OIL GAUGE WINDOW | 1 | |
| 152949001 | WICK SUPPORT ASSEMBLY | 1 | |
| 152950001 | WICK SUPPORT | 1 | |
| 152951001 | FELT | 1 | |
| 152952001 | FELT | 1 | |
| 153918001 | WICK 6X6 (L=660) | 1 | |
| 140423000 | OIL TUBE | 1 | |
| 147745000 | OIL TUBE (L) | 1 | |
| 153919001 | WICK 6X6 (L=370) | 1 | |
| 062680812 | SCREW 437X8 | 2 | |
| 152958001 | WICK SUPPORT ASSEMBLY | 1 | |
| 152959001 | WICK SUPPORT | 1 | |
| 152956001 | FLAT WICK (L=210) | 1 | |
| 152956001 | WICK 4X4 (L=500) | 1 | |
| 062680812 | SCREW 437X6 | 1 | |
| 144694001 | OIL TUBE | 1 | |
| 152956001 | WICK 4X4 (L=500) | 1 | |
| 152962001 | WICK SUPPORT | 1 | |
| 152960001 | FLAT WICK (L=40) | 1 | |
| 104567001 | WICK SUPPORT | 1 | |
| 152948001 | OIL GAUGE WINDOW | 1 | |
| 152961001 | FELT SUPPORT ASSEMBLY | 1 | |
| 152966001 | FELT SUPPORT | 1 | |
| 152967001 | FELT | 1 | |
| 062670812 | SCREW 357X8 | 2 | |
| 025350332 | PLAIN WASHER 3.5 | 3 | |
| 152963001 | WICK 4X4 (L=600) | 1 | |
| 141692001 | OIL SUPPORT (C) | 1 | |
| 021670202 | NUT 3.57 | 1 | |
| 062671412 | SCREW 357X14 | 1 | |
| 062670512 | SCREW 357X5 | 2 | |
| 148921000 | OIL TUBE | 1 | |
| 147745000 | OIL TUBE (L) | 1 | |
| 152964001 | WICK 6X6 (L=310) | 1 | |
| 152965001 | WICK 4X4 (L=400) | 1 | |
| 152964001 | WICK 6X6 (L=310) | 1 | |
| 152969001 | CORD SUPPORT | 1 | |
| 062670512 | SCREW 357X5 | 1 | |
| 104567001 | WICK SUPPORT | 1 | |
| 146375000 | OIL TUBE | 1 | |
| 152992001 | FLAT WICK (L=760) | 1 | |
| 117150001 | CORD SUPPORT | 1 | |
| 062670512 | SCREW 357X5 | 1 | |
| 140423000 | OIL TUBE | 2 | |
| 152971001 | WICK 4X4 (L=480) | 1 | |
| 112669001 | OIL TUBE | 1 | |
| 152969001 | CORD SUPPORT | 1 | |
| 062670512 | SCREW 357X5 | 1 | |
| 113006001 | FELT | 1 | |
| 152973001 | WICK 4X4 (L=170) | 1 | |
| 047251640 | SPRING PIN AW2.5 | 2 | |
| 117150001 | CORD SUPPORT | 1 | |
| 062670512 | SCREW 357X5 | 1 | |
| 104567001 | WICK SUPPORT | 1 | |
| 152974001 | WICK 4X4 (L=350) | 1 | |
| 112669001 | OIL TUBE | 1 | |
| 147745000 | OIL TUBE (L) | 1 | |
| 153922001 | WICK 6X6 (L=500) | 1 | |
| 152953001 | WICK 6X6 (L=360) | 1 | |
| 152985001 | WICK 4X4 (L=120) | 1 | |
| 153763001 | WICK SUPPORT | 1 | |
| 062670512 | SCREW 357X5 | 1 |
L. 給油潤滑関係/Lubrication/Schmierung/Lubrication/Lubricación REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 152948001 1 オイルポツトマ OIL GAUGE WINDOW 2 152949001 1 ウワジクキュウユササエ WICK SUPPORT ASSEMBLY 2-1 152950001 1 ウワジクキュウユササエ WICK SUPPORT 2-2 152951001 1 ウオームキュウユフエルト FELT 2-3 152952001 1 ロツト"キュウユフエルト FELT 2-4 153918001 1 クミヒモ6X6 (L=660) WICK 6X6 (L=660) 2-5 140423000 1 ビニルチューブ OIL TUBE 2-6 147745000 1 ハイユパイプL OIL TUBE (L) 2-7 153919001 1 クミヒモ6X6 (L=370) WICK 6X6 (L=370) 3 062680812 2 ナベコ3.437-40X8 SCREW 437X8 4 152958001 1 テンビンキュウユササエ WICK SUPPORT ASSEMBLY 4-1 152959001 1 テンビンキュウユササエ WICK SUPPORT 4-2 152956001 1 ヒララクセミモ (L=210) FLAT WICK (L=210) 4-3 152956001 1 クミヒモ4X4 (L=500) WICK 4X4 (L=500) 5 062680812 1 ナベコ3.437-40X6 SCREW 437X6 6 144694001 1 ハイユパイプ OIL TUBE 7 152956001 1 クミヒモ4X4 (L=500) WICK 4X4 (L=500) 8 152962001 1 ハリボウメタルヒモササエ WICK SUPPORT 9 152960001 1 ヒララクセミモ (L=40) FLAT WICK (L=40) 10 104567001 1 クミヒモササエ WICK SUPPORT 11 152948001 1 オイルポツトマ OIL GAUGE WINDOW 12 152961001 1 シタジクキュウユササエ FELT SUPPORT ASSEMBLY 12-1 152966001 1 シタジクキュウユササエ FELT SUPPORT 12-2 152967001 1 シタジクキュウユフエルト FELT 12-3 062670812 2 ナベコ357-40X8 SCREW 357X8 12-4 025350332 3 ヒララツカネダ13.5 PLAIN WASHER 3.5 12-5 152963001 1 クミヒモ4X4 (L=600) WICK 4X4 (L=600) 12-6 141692001 1 ビニルチューブササエC OIL SUPPORT (C) 12-7 021670202 1 ナット3.57 NUT 3.57 12-8 062671412 1 ナベコ357-40X14 SCREW 357X14 13 062670512 2 ナベコ357-40X5 SCREW 357X5 14 148921000 1 ビニルチューブ OIL TUBE 15 147745000 1 ハイユパイプL OIL TUBE (L) 17 152964001 1 クミヒモ6X6 (L=310) WICK 6X6 (L=310) 18 152965001 1 クミヒモ4X4 (L=400) WICK 4X4 (L=400) 19 152964001 1 クミヒモ6X6 (L=310) WICK 6X6 (L=310) 20 152969001 1 コードササエ CORD SUPPORT 21 062670512 1 ナベコ357-40X5 SCREW 357X5 22 104567001 1 クミヒモササエ WICK SUPPORT 23 146375000 1 ビニルチューブ OIL TUBE 24 152992001 1 ヒララクセミモ (L=760) FLAT WICK (L=760) 25 117150001 1 コードササエ CORD SUPPORT 26 062670512 1 ナベコ357-40X5 SCREW 357X5 28 140423000 2 ビニルチューブ OIL TUBE 29 152971001 1 クミヒモ4X4 (L=480) WICK 4X4 (L=480) 31 112669001 1 ビニルチューブ OIL TUBE 32 152969001 1 コードササエ CORD SUPPORT 33 062670512 1 ナベコ357-40X5 SCREW 357X5 34 113006001 1 フエルト FELT 36 152973001 1 クミヒモ4X4 (L=170) WICK 4X4 (L=170) 37 047251640 2 スプリングピンAW2.5 SPRING PIN AW2.5 38 117150001 1 コードササエ CORD SUPPORT 39 062670512 1 ナベコ357-40X5 SCREW 357X5 40 104567001 1 クミヒモササエ WICK SUPPORT 41 152974001 1 クミヒモ4X4 (L=350) WICK 4X4 (L=350) 42 112669001 1 ビニルチューブ OIL TUBE 43 147745000 1 ハイユパイプL OIL TUBE (L) 44 153922001 1 クミヒモ6X6 (L=500) WICK 6X6 (L=500) 45 152953001 1 クミヒモ6X6 (L=360) WICK 6X6 (L=360) 46 152985001 1 クミヒモ4X4 (L=120) WICK 4X4 (L=120) 47 153763001 1 キユウユモササエ WICK SUPPORT 48 062670512 1 ナベコ357-40X5 SCREW 357X5 26 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2-7 | 2-7 | ||
| 2-6 | 2-6 | ||
| 2-3 | 2-3 | ||
| 2-4 | 2-4 | ||
| 2-5 | 2-5 | ||
| 2-2 | 2-2 | ||
| 3 | 3 | ||
| 62 | 62 | ||
| 2-1 | 2-1 | ||
| 64 | 64 | ||
| 4-1 | 4-1 | ||
| 4-3 | 4-3 | ||
| 49 | 49 | ||
| 51 | 51 | ||
| 50 | 50 | ||
| 4-2 | 4-2 | ||
| 68 | 68 | ||
| 59 | 59 | ||
| 61 | 61 | ||
| 60 | 60 | ||
| 23 | 23 | ||
| 26 | 26 | ||
| 25 | 25 | ||
| 37 | 37 | ||
| 41 | 41 | ||
| 42 | 42 | ||
| 21 | 21 | ||
| 20 | 20 | ||
| 15 | 15 | ||
| 14 | 14 | ||
| 22 | 22 | ||
| 19 | 19 | ||
| 58 | 58 | ||
| 54 | 54 | ||
| 53 | 53 | ||
| 56 | 56 | ||
| 31 | 31 | ||
| 33 | 33 | ||
| 32 | 32 | ||
| 69 | 69 | ||
| 36 | 36 | ||
| 38 | 38 | ||
| 40 | 40 | ||
| 29 | 29 | ||
| 34 | 34 | ||
| 28 | 28 | ||
| 11 | 11 | ||
| 39 | 39 | ||
| 43 | 43 | ||
| 45 | 45 | ||
| 70 | 70 | ||
| 63-1 | 63-1 | ||
| 47 | 47 | ||
| 65 | 65 | ||
| 46 | 46 | ||
| 48 | 48 | ||
| 16 | 16 | ||
| 63-2 | 63-2 | ||
| 13 | 13 | ||
| 12-1 | 12-1 | ||
| 12-7 | 12-7 | ||
| 12-5 | 12-5 | ||
| 12-2 | 12-2 | ||
| 12-4 | 12-4 | ||
| 12-3 | 12-3 | ||
| 12-6 | 12-6 | ||
| 12-4 | 12-4 | ||
| 12-8 | 12-8 |
L. 給油潤滑関係/Lubrication/Schmierung/Lubrication/Lubricación 2-7 2-6 2-3 2-4 2-5 2-2 3 62 2-1 64 4-1 4-3 49 51 50 4-2 68 59 61 60 23 26 25 37 41 42 21 20 15 14 22 19 58 54 53 56 31 33 32 69 36 38 40 29 34 28 11 39 43 45 70 63-1 47 65 46 48 16 63-2 13 12-1 12-7 12-5 12-2 12-4 12-3 12-6 12-4 12-8 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 152976001 | ボールキユウユヒモササエ | ||
| 062670512 | ナベコ357-40X5 | 2 | |
| 028040242 | ハネザガネ2-4 | 2 | |
| 152977001 | ヒラユヒモ(L=50) | ||
| 152978001 | チュ-ブオサエ | ||
| 062680812 | ナベコ437-40X8 | ||
| 153927001 | クミヒモ6X6 (L=180) | ||
| 112669001 | ビニルチュ-ブ | ||
| 153922001 | クミヒモ4X4 (L=500) | ||
| 107149001 | フェルト | ||
| 152968001 | クミヒモ4X4 (L=100) | ||
| 153529101 | ホイ-ルキユウスフエルト | ||
| 153530001 | スイアゲフエルト | ||
| 153531001 | ヘツドLフエルト | ||
| 153562001 | ヒラユヒモ(L=150) | ||
| 153528001 | ウオ-ムキユウスフエルトササエ | ||
| 105248003 | ザガネ | ||
| 152973001 | クミヒモ4X4 (L=170) | ||
| 153925001 | クミヒモ4X4 (L=30) | ||
| 153926001 | タコヒモ(L=10) | ||
| 152980001 | クミヒモ6X6 (L=150) |
L. 給油潤滑関係/Lubrication/Schmierung/Lubrication/Lubricación REF. NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 49 152976001 1 ボールキユウユヒモササエ WICK SUPPORT 50 062670512 2 ナベコ357-40X5 SCREW 357X5 51 028040242 2 ハネザガネ2-4 SPRING WASHER 2-4 52 152977001 1 ヒラユヒモ(L=50) WICK (L=50) 53 152978001 1 チュ-ブオサエ TUBE SUPPORT 54 062680812 1 ナベコ437-40X8 SCREW 437X8 55 153927001 1 クミヒモ6X6 (L=180) WICK 6X6 (L=180) 56 112669001 1 ビニルチュ-ブ OIL TUBE 58 153922001 1 クミヒモ4X4 (L=500) WICK 4X4 (L=500) 59 107149001 1 フェルト FELT 60 152968001 1 クミヒモ4X4 (L=100) WICK 4X4 (L=100) 61 153529101 1 ホイ-ルキユウスフエルト FELT 62 153530001 1 スイアゲフエルト FELT 63-1 153531001 1 ヘツドLフエルト BED (L) FELT 63-2 153562001 1 ヒラユヒモ(L=150) FLAT WICK (L=150) 64 153528001 1 ウオ-ムキユウスフエルトササエ FELT SUPPORT 65 105248003 1 ザガネ WASHER 67 152973001 1 クミヒモ4X4 (L=170) WICK 4X4 (L=170) 68 153925001 1 クミヒモ4X4 (L=30) WICK 4X4 (L=30) 69 153926001 1 タコヒモ(L=10) WICK (L=10) 70 152980001 1 クミヒモ6X6 (L=150) WICK 6X6 (L=150) jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 1 | ||
| 2 | 2 | ||
| 3 | 3 | ||
| 4 | 4 | ||
| 5 | 5 | ||
| 6 | 6 | ||
| 7 | 7 | ||
| 8 | 8 | ||
| 9 | 9 | ||
| 10 | 10 | ||
| 11 | 11 | ||
| 12 | 12 | ||
| 13 | 13 | ||
| 14 | 14 | ||
| 15 | 15 | ||
| 16 | 16 | ||
| 17 | 17 | ||
| 18 | 18 | ||
| 19 | 19 | ||
| 20 | 20 | ||
| 21 | 21 | ||
| 22 | 22 | ||
| 23 | 23 | ||
| 24 | 24 | ||
| 25 | 25 | ||
| 26 | 26 | ||
| 27 | 27 | ||
| 28 | 28 | ||
| 29 | 29 | ||
| 30 | 30 | ||
| 31 | 31 | ||
| 32 | 32 | ||
| 33 | 33 | ||
| 34 | 34 | ||
| 35 | 35 | ||
| 36 | 36 | ||
| 37 | 37 | ||
| 38 | 38 | ||
| 39 | 39 | ||
| 40 | 40 | ||
| 41 | 41 | ||
| 42 | 42 | ||
| 43 | 43 | ||
| 44 | 44 | ||
| 45 | 45 | ||
| 46 | 46 |
M. 糸通シ関係/Threading mechanism/Fadenführungsvorrichtung/ Mécanisme de l'enfilage/Mecanismo del enhebrado 19 29 30 32 45 44 43 31 39 40 7 33 34 35 36 21 28 37 38 16 8 17 11 9 12 13 14 15 20 22 46 23 24 25 26 27 10 18 1 2 3 4 5 6 41 42
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 152869001 | アームイトミチ | 1 | |
| 062710712 | ナベコ476-32X7 | 1 | |
| 152870001 | アームイトカク | 1 | |
| 062670612 | ナベコ357-40X6 | 1 | |
| 113316001 | アームイトアンナイ | 1 | |
| 112751003 | シメネジ"3.57 | 1 | |
| 153049001 | ウフイトアンナイボウ | 1 | |
| 152872001 | イトチョウシダイイ | 1 | |
| 100398001 | イトチョウシボウ | 1 | |
| 100402004 | トメネジ"5.95 | 1 | |
| * | イトトリハネ | 1 | |
| 145446001 | イトチョウシサラ | 2 | |
| 159805001 | イトチョウシサラオサエ | 1 | |
| * | イトチョウシハネ | 1 | |
| 100136001 | イトチョウシナット | 1 | |
| 152873001 | イトユルメピン | 1 | |
| 114294001 | Oリング | 1 | |
| 103950003 | トメネジ"5.95 | 1 | |
| 152877001 | フクイトユルメボウ | 1 | |
| 152875001 | フクイトチョウシボウ | 1 | |
| 152876001 | フクイトユルメピン | 1 | |
| 145446001 | イトチョウシサラ | 2 | |
| 152877001 | イトチョウシサラオサエ | 1 | |
| 152878001 | ウフイトオサエハネ | 1 | |
| 152879101 | フクチョウシハネ | 1 | |
| 152880001 | ハネツケ | 1 | |
| 100136001 | イトチョウシナット | 1 | |
| 014680422 | アナトメネジ"4.37クボミ | 1 | |
| 140208001 | ザガネ | 1 | |
| 048040342 | トメワE4 | 1 | |
| 152881001 | エキレイトクミ | 1 | |
| 013760612 | トメネジ"5.95クボミ | 1 | |
| 152886001 | イトイトリアンナイシクウケ | 1 | |
| 014680422 | アナトメネジ"4.37クボミ | 1 | |
| 152887001 | イトイトリアンナイシジク | 1 | |
| 152888101 | イトイトリレバー | 1 | |
| 141528001 | ダンネジ"6.35 | 1 | |
| 115077003 | ダンネジ"4.76 | 1 | |
| 152889001 | ミツメイトカケ | 1 | |
| 062670612 | ナベコ357-40X6 | 2 | |
| 152890001 | ハリボウイトアンナイ | 1 | |
| 152891001 | ハリボウメタルDイトアンナイ | 1 | |
| 152883000 | フエルト8X15.5 | 1 | |
| 152884001 | エキレイトカク | 1 | |
| 062670412 | ナベコ357-40X4 | 1 | |
| 153138001 | ザガネ | 1 |
M. 糸通シ関係 /Threading mechanism/Fadenfuhrungsvorrichtung/ Mecanisme de l'enfilage/Mecanismo del enhebrado REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 152869001 1 アームイトミチ ARM THREAD GUIDE 2 062710712 1 ナベコ476-32X7 SCREW 476X7 3 152870001 1 アームイトカク ARM THREAD GUIDE 4 062670612 1 ナベコ357-40X6 SCREW 357X6 5 113316001 1 アームイトアンナイ ARM THREAD GUIDE 6 112751003 1 シメネジ"3.57 SCREW 3.57 7 153049001 1 ウフイトアンナイボウ NEEDLE THREAD GUIDE BAR 8 152872001 1 イトチョウシダイイ TENSION BRACKET 9 100398001 1 イトチョウシボウ TENSION STUD 10 100402004 1 トメネジ"5.95 SET SCREW 5.95 11 * 1 イトトリハネ SPRING 12 145446001 2 イトチョウシサラ TENSION DISC 13 159805001 1 イトチョウシサラオサエ TENSION DISC PRESSER 14 * 1 イトチョウシハネ TENSION SPRING 15 100136001 1 イトチョウシナット TENSION NUT 16 152873001 1 イトユルメピン TENSION RELEASE PIN 17 114294001 1 Oリング O RING 18 103950003 1 トメネジ"5.95 SET SCREW 5.95 19 152877001 1 フクイトユルメボウ SUB TENSION RELEASE BAR 20 152875001 1 フクイトチョウシボウ SUB TENSION STUD 21 152876001 1 フクイトユルメピン SUB TENSION RELEASE PIN 22 145446001 2 イトチョウシサラ TENSION DISC 23 152877001 1 イトチョウシサラオサエ TENSION DISC WASHER 24 152878001 1 ウフイトオサエハネ NEEDLE THREAD SPRING 25 152879101 1 フクチョウシハネ SUB TENSION SPRING 26 152880001 1 ハネツケ SPRING HOLDER 27 100136001 1 イトチョウシナット TENSION NUT 28 014680422 1 アナトメネジ"4.37クボミ SET SCREW 4.37 29 140208001 1 ザガネ WASHER 30 048040342 1 トメワE4 STOP RING E4 31 152881001 1 エキレイトクミ NEEDLE COOLER ASSEMBLY 32 013760612 1 トメネジ"5.95クボミ SET SCREW 5.95 33 152886001 1 イトイトリアンナイシクウケ THREAD TAKE-UP GUIDE 34 014680422 1 アナトメネジ"4.37クボミ SET SCREW 4.37 35 152887001 1 イトイトリアンナイシジク THREAD TAKE-UP LEVER GUIDE STUD 36 152888101 1 イトイトリレバー THREAD TAKE-UP LEVER 37 141528001 1 ダンネジ"6.35 STUD SCREW 6.35 38 115077003 1 ダンネジ"4.76 STUD SCREW 4.76 39 152889001 1 ミツメイトカケ THREAD RETAINER 40 062670612 2 ナベコ357-40X6 SCREW 357X6 41 152890001 1 ハリボウイトアンナイ NEEDLE BAR THREAD GUIDE (A) 42 152891001 1 ハリボウメタルDイトアンナイ NEEDLE BAR BUSH (D) THREAD GUIDE 43 152883000 1 フエルト8X15.5 FELT 8X15.5 44 152884001 1 エキレイトカク NEEDLE COOLER THREAD GUIDE 45 062670412 1 ナベコ357-40X4 SCREW 357X4 46 153138001 1 ザガネ WASHER jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 7 | 7 | screw | |
| 3-4 | 3-4 | washer | |
| 3-3 | 3-3 | washer | |
| 3-2 | 3-2 | bobbin winder | |
| 3-1 | 3-1 | base | |
| 1-21-2 | 1-21-2 | rubber ring | |
| 1-22 | 1-22 | pin | |
| 1-21-1 | 1-21-1 | lever | |
| 1-18 | 1-18 | screw | |
| 1-5 | 1-5 | lever | |
| 1-4 | 1-4 | lever | |
| 1-2 | 1-2 | screw | |
| 1-9 | 1-9 | screw | |
| 1-8 | 1-8 | washer | |
| 1-7 | 1-7 | plate | |
| 1-3 | 1-3 | shaft | |
| 2 | 2 | screw | |
| 1-17 | 1-17 | clip | |
| 1-20 | 1-20 | spring | |
| 1-16 | 1-16 | lever | |
| 1-14 | 1-14 | spring | |
| 1-12 | 1-12 | spring | |
| 1-6 | 1-6 | lever | |
| 1-13 | 1-13 | screw | |
| 1-1 | 1-1 | frame | |
| 1-10 | 1-10 | screw | |
| 1-11 | 1-11 | screw | |
| 1-15 | 1-15 | shaft | |
| 1-19 | 1-19 | screw |
N. 糸巻キ関係/Bobbin winder mechanism/Spuler/ M ecanisme de bobineur/Mecanismo del devanador de la canilla 7 3-4 3-3 3-2 3-1 1-21-2 1-22 1-21-1 1-18 1-5 1-4 1-2 1-9 1-8 1-7 1-3 2 1-17 1-20 1-16 1-14 1-12 1-6 1-13 1-1 1-10 1-11 1-17 1-15 1-19 31 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 152982109 | イトマキクミ | 1 | |
| 152983009 | イトマキダイ | 1 | |
| 152984001 | イトマキレバー | 1 | |
| 152933001 | イトマキジク | 1 | |
| 152934001 | イトマキレバーシジク | 1 | |
| 102716004 | トメネジ4.37 | 1 | |
| 152935001 | ボビンオサエ | 1 | |
| 152936001 | イタバネ | 1 | |
| 152937001 | ザガネ | 1 | |
| 062670712 | ナベコ357-40X7 | 1 | |
| 152938001 | メス | 1 | |
| 062680712 | ナベコ437-40X7 | 1 | |
| 152939001 | イトマキレバーヒキバネ | 1 | |
| 115138001 | レバーヒキバネカケ | 1 | |
| 141550001 | デイシレバーバネカケ | 1 | |
| 152940001 | イトマキツメジク | 1 | |
| 142566001 | イトマキツメ | 1 | |
| 048050342 | トメワE5 | 2 | |
| 014680422 | アナトメネジ4.37クボミ | 2 | |
| 062670712 | ナベコ357-40X7 | 1 | |
| 152941001 | イトマキツメネジリバネ | 1 | |
| 154528001 | イトマキクルマ | 1 | |
| 120448001 | ゴムワ | 1 | |
| 102716004 | トメネジ4.37 | 2 | |
| 062761412 | ナベコ595-28X14 | 2 | |
| S01300009 | シタイトチョウシンクミ | 1 | |
| 152945001 | シタイトチョウシンダイクミ | 1 | |
| 145446001 | イトチョウサラ | 2 | |
| 104525001 | イトチョウシバネ | 1 | |
| 108265009 | イトチョウシナツト | 1 | |
| 062680812 | ナベコ437-40X8 | 2 |
N. 糸巻関係/Bobbin winder mechanism/Spuler/ M e c a n i s m o de bobineur/Mecanismo del devanador de la canilla REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 152982109 1 イトマキクミ BOBBIN WINDER ASSEMBLY 1-1 152983009 1 イトマキダイ BOBBIN WINDER BRACKET 1-2 152984001 1 イトマキレバー BOBBIN WINDER LEVER 1-3 152933001 1 イトマキジク BOBBIN WINDER SHAFT 1-4 152934001 1 イトマキレバーシジク BOBBIN WINDER LEVER SHAFT 1-5 102716004 1 トメネジ4.37 SET SCREW 4.37 1-6 152935001 1 ボビンオサエ BOBBIN PRESSER 1-7 152936001 1 イタバネ PLATE SPRING 1-8 152937001 1 ザガネ WASHER 1-9 062670712 1 ナベコ357-40X7 SCREW 357X7 1-10 152938001 1 メス KNIFE 1-11 062680712 1 ナベコ437-40X7 SCREW 437X7 1-12 152939001 1 イトマキレバーヒキバネ SPRING 1-13 115138001 1 レバーヒキバネカケ SPRING HOOK 1-14 141550001 1 デイシレバーバネカケ SPRING HOOK 1-15 152940001 1 イトマキツメジク BOBBIN WINDER CLAW STUD 1-16 142566001 1 イトマキツメ BOBBIN WINDER CLAW 1-17 048050342 2 トメワE5 STOP RING E5 1-18 014680422 2 アナトメネジ4.37クボミ SET SCREW 4.37 1-19 062670712 1 ナベコ357-40X7 SCREW 357X7 1-20 152941001 1 イトマキツメネジリバネ TWIST SPRING 1-21-1 154528001 1 イトマキクルマ BOBBIN WINDER WHEEL 1-21-2 120448001 1 ゴムワ RUBBER RING 1-22 102716004 2 トメネジ4.37 SET SCREW 4.37 2 062761412 2 ナベコ595-28X14 SCREW 595X14 3 S01300009 1 シタイトチョウシンクミ LOWER THREAD TENSION ASSEMBLY 3-1 152945001 1 シタイトチョウシンダイクミ LOWER THREAD TENSION BRACKET ASSEMBLY 3-2 145446001 2 イトチョウサラ TENSION DISC 3-3 104525001 1 イトチョウシバネ TENSION SPRING 3-4 108265009 1 イトチョウシナツト TENSION NUT 7 062680812 2 ナベコ437-40X8 SCREW 437X8 jintex.in 22
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 6 | 6 | SCREW | |
| 43 | 43 | SCREW | |
| 16 | 16 | SCREW | |
| 17 | 17 | WASHER | |
| 44 | 44 | SCREW | |
| 9 | 9 | SPRING | |
| 10 | 10 | PLATE | |
| 50 | 50 | LEVER | |
| 53 | 53 | WASHER | |
| 54 | 54 | WASHER | |
| 52 | 52 | RING | |
| 51 | 51 | SCREW | |
| 20 | 20 | SHAFT | |
| 21 | 21 | PIN | |
| 19 | 19 | BRACKET | |
| 25 | 25 | SPRING | |
| 48 | 48 | PIN | |
| 1 | 1 | BLADE | |
| 2 | 2 | SPRING | |
| 5 | 5 | SPRING | |
| 3 | 3 | SCREW | |
| 7 | 7 | LEVER | |
| 8 | 8 | SCREW | |
| 46 | 46 | WASHER | |
| 11 | 11 | SPRING | |
| 18-3 | 18-3 | SPRING | |
| 18-4 | 18-4 | COLLAR | |
| 18-2 | 18-2 | PIN | |
| 18-5 | 18-5 | SCREW | |
| 18-1 | 18-1 | BRACKET | |
| 22 | 22 | SHAFT | |
| 26 | 26 | SCREW | |
| 24 | 24 | RING | |
| 23 | 23 | WASHER | |
| 30 | 30 | SCREW | |
| 18-6 | 18-6 | PIN | |
| 31 | 31 | LEVER | |
| 32 | 32 | SCREW | |
| 29 | 29 | WASHER | |
| 33 | 33 | NUT | |
| 34 | 34 | LEVER | |
| 37 | 37 | WASHER | |
| 36 | 36 | WASHER | |
| 35 | 35 | SCREW | |
| 42 | 42 | SCREW | |
| 38 | 38 | SHAFT | |
| 39 | 39 | WASHER | |
| 40 | 40 | RING | |
| 41 | 41 | SCREW | |
| 27 | 27 | WASHER | |
| 28 | 28 | RING | |
| 12 | 12 | PLATE | |
| 13 | 13 | SCREW | |
| 45 | 45 | WASHER | |
| 4 | 4 | LEVER |
P. 糸切り関係/Thread trimmer mechanism/Fadenabschneidevorrichtung/ Mécanisme de coupe-fil/Mecanismo de la cortadura de hilos 6 43 16 17 44 9 10 50 53 54 52 51 20 21 19 25 48 1 2 5 3 7 8 46 11 18-3 18-4 18-2 18-5 18-1 22 26 24 23 30 18-6 31 32 29 33 34 37 36 35 42 38 39 40 41 27 28 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 152892001 | イトキリレンケツト | ||
| 152896001 | イトキリウデ"Aクミ | ||
| 018681022 | アホホルト4.37X10 | ||
| 152893101 | イトキリウデ"B | ||
| 048050342 | トメワE5 | ||
| 152995001 | ハリイタS | ||
| 152981001 | イトキリウデ"C | ||
| 153222001 | シメネジ"4.37 | ||
| 152897201 | イトキリレンカンクミ | ||
| 152901001 | イトウハクミ | ||
| 152904001 | シメネジ"4.37 | ||
| 152905001 | コテイハ | ||
| 111140002 | シメネジ"2.38 | ||
| 100360003 | シメネジ"2.38 | ||
| * | ハリイタ | ||
| 152912001 | イトキリカムレバー | ||
| 152913001 | コロジク | ||
| 048050342 | トメワE4 | ||
| 152914001 | コロ | ||
| 154788001 | ハネツカク | ||
| 152919001 | イトキリロツド"ピン | ||
| 152915001 | イトキリカムレバーツメ | ||
| 062761412 | スク595-28X14 | ||
| 025060132 | ヒラサカザガネ6 | ||
| 152916001 | イトキリカムレバーシク | ||
| 152917001 | サガネ | ||
| 048120142 | トメワシヨウC12 | ||
| 154788001 | イトキリカムレバーハネ | ||
| 014760622 | アナトメネジ"5.95 | ||
| 140208001 | サガネ | ||
| 048050342 | トメワE5 | ||
| 152920001 | イトキリリンクチヨウセツクミ | ||
| 014760622 | アナトメネジ"5.95 | ||
| 152921001 | イトキリリンク | ||
| 151907001 | ダンネジ"5.95 | ||
| 150553001 | ナツト5.95 | ||
| 152922001 | イトキリサトドーレバー | ||
| 152923001 | イトキリサトドーレバーコロ | ||
| 112468001 | サガネ | ||
| 048050002 | トメワE5 | ||
| 153482001 | イトキリサトドーレバーシク | ||
| 142628001 | スイヘイヨウクランクリング | ||
| 048110142 | トメワシヨウC11 | ||
| 111865009 | オイルメクラセン | ||
| 014760622 | アナトメネジ"5.95 | ||
| 100032004 | シメネジ"4.37 | ||
| 153208002 | シメネジ"4.37 | ||
| 153220001 | イトキリウデ"Cカラー | ||
| 153219001 | イトウハカラー | ||
| 141334001 | ハネツカク | ||
| 152906101 | シイトサハキA | ||
| 153598001 | シメネジ"4.37 | ||
| 081008070 | OリングP8 | ||
| 153597001 | シイトサハキカラー | ||
| 153596001 | サガネ |
P. 糸切り関係/Thread trimmer mechanism/Fadenabschneidevorrichtung/ Mécanisme de coupe-fil/Mecanismo de la cortadura de hilos REF. NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 152892001 1 イトキリレンケツト THREAD TRIMMER CONNECTING ROD 2 152896001 1 イトキリウデ"Aクミ THREAD TRIMMER ARM ASSEMBLY (A) 3 018681022 1 アホホルト4.37X10 BOLT 4.37X10 4 152893101 1 イトキリウデ"B THREAD TRIMMER ARM (B) 5 048050342 1 トメワE5 STOP RING E5 6 152995001 1 ハリイタS NEEDLE PLATE (S) 7 152981001 1 イトキリウデ"C KNIFE ARM (C) 8 153222001 1 シメネジ"4.37 SCREW 4.37 9 152897201 1 イトキリレンカンクミ THREAD TRIMMER CONNECTING ROD ASSEMBLY 10 152901001 1 イトウハクミ MOVABLE KNIFE ASSEMBLY 11 152904001 1 シメネジ"4.37 SCREW 4.37 12 152905001 1 コテイハ FIXED KNIFE 13 111140002 2 シメネジ"2.38 SCREW 2.38 14 100360003 2 シメネジ"2.38 SCREW 2.38 17 * 1 ハリイタ NEEDLE HOLE PLATE 18-1 152912001 1 イトキリカムレバー THREAD TRIMMER CAM LEVER 18-2 152913001 1 コロジク ROLLER SHAFT 18-3 048050342 1 トメワE4 STOP RING E4 18-4 152914001 1 コロ ROLLER 18-5 154788001 1 ハネツカク SPRING HOOK 18-6 152919001 1 イトキリロツド"ピン THREAD TRIMMER ROD PIN 19 152915001 1 イトキリカムレバーツメ THREAD TRIMMER CAM LEVER CLAW 20 062761412 1 スク595-28X14 SCREW 595X14 21 025060132 1 ヒラサカザガネ6 PLAIN WASHER 6 22 152916001 1 イトキリカムレバーシク THREAD TRIMMER CAM LEVER SHAFT 23 152917001 1 サガネ WASHER 24 048120142 1 トメワシヨウC12 STOP RING C12 25 154788001 1 イトキリカムレバーハネ SPRING 26 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 27 140208001 1 サガネ WASHER 28 048050342 1 トメワE5 STOP RING E5 29 152920001 1 イトキリリンクチヨウセツクミ STUD 30 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 31 152921001 1 イトキリリンク THREAD TRIMMER LINK 32 151907001 1 ダンネジ"5.95 STUD SCREW 5.95 33 150553001 1 ナツト5.95 NUT 5.95 34 152922001 1 イトキリサトドーレバー THREAD TRIMMER LEVER 35 152923001 1 イトキリサトドーレバーコロ THREAD TRIMMER ROLLER 36 112468001 1 サガネ WASHER 37 048050002 1 トメワE5 STOP RING E5 38 153482001 1 イトキリサトドーレバーシク DRIVING SHAFT 39 142628001 1 スイヘイヨウクランクリング FEED ROCK CRANK RING 40 048110142 1 トメワシヨウC11 STOP RING C11 41 111865009 1 オイルメクラセン OIL CAP 42 014760622 1 アナトメネジ"5.95 SET SCREW 5.95 43 100032004 2 シメネジ"4.37 SCREW 4.37 44 153208002 2 シメネジ"4.37 SCREW 4.37 45 153220001 1 イトキリウデ"Cカラー KNIFE ARM (C) COLLAR 46 153219001 1 イトウハカラー MOVABLE KNIFE COLLAR 48 141334001 1 ハネツカク SPRING HOOK 50 152906101 1 シイトサハキA LOWER THREAD RETAINER (A) 51 153598001 1 シメネジ"4.37 SCREW 4.37 52 081008070 1 OリングP8 O RING P8 53 153597001 1 シイトサハキカラー LOWER THREAD RETAINER COLLAR 54 153596001 1 サガネ WASHER jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 6 | 6 | PIN | |
| 9 | 9 | SPRING | |
| 11 | 11 | BRACKET | |
| 12 | 12 | COVER | |
| 14 | 14 | LEVER | |
| 15 | 15 | SCREW | |
| 17 | 17 | WASHER | |
| 2 | 2 | BRACKET | |
| 7 | 7 | SHAFT | |
| 8 | 8 | SPRING | |
| 10 | 10 | PIN | |
| 13 | 13 | SCREW | |
| 1 | 1 | SHAFT | |
| 16 | 16 | SCREW | |
| 18 | 18 | WASHER | |
| 5 | 5 | LEVER | |
| 3 | 3 | SCREW | |
| 4 | 4 | WASHER | |
| 1 | 1 | SHAFT | |
| 6 | 6 | SPRING | |
| 8 | 8 | SPRING | |
| 9 | 9 | WASHER | |
| 5 | 5 | LEVER | |
| 10 | 10 | PIN | |
| 7 | 7 | PIN |
Q. 糸払イ関係/Thread wiper mechanism/Fadenwischvorrichtung/ Mécanisme de tire-fil/Mecanismo del limpiador de hilo 12 9 6 11 15 17 14 2 7 8 10 13 輸出用/FOR EXPORT 16 18 R. 糸締メ関係/Thread nipper mechanism/Fadenspannvorrichtung/ Mécanisme de pince-fil/Mecanismo de la mordaza para hilo 1 6 8 9 5 10 7 3 4 2 3 4 5 1 2 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 152815001 | THREAD WIPER ROD SHAFT | 1 | |
| 152816001 | THREAD WIPER ROD ASSEMBLY | 1 | |
| 014680622 | SET SCREW 4.37 | 1 | |
| 048060342 | STOP RING E6 | 1 | |
| 116629001 | WASHER | 2 | |
| 152820001 | THREAD WIPER SHAFT | 1 | |
| 025770232 | PLAIN WASHER 6.35 | 1 | |
| 048040342 | STOP RING E4 | 1 | |
| 014680622 | SET SCREW 4.37 | 1 | |
| 152823001 | THREAD WIPER ARM ASSEMBLY | 1 | |
| 048030342 | STOP RING E3 | 1 | |
| 152827009 | OIL CAP | 1 | |
| 013710712 | SET SCREW 4.76 | 1 | |
| 156206001 | THREAD WIPER (A) | 1 | |
| 062670512 | SCREW 357X5 | 1 | |
| 156495001 | FINGER GUARD | 1 | |
| 025350132 | PLAIN WASHER | 1 | |
| 062671012 | SCREW 357X10 | 2 | |
| 152925101 | NEEDLE THREAD RELEASE SHAFT | 1 | |
| 152926001 | TENSION RELEASE BAR PLATE | 1 | |
| 062671012 | SCREW 357X10 | 2 | |
| 025350332 | PLAIN WASHER 3.5 | 2 | |
| 152988001 | NEEDLE THREAD RELEASE LEVER ASSEMBLY | 1 | |
| 048040342 | STOP RING E4 | 1 | |
| 152929001 | NEEDLE THREAD RELEASE LEVER SHAFT | 1 | |
| 048050342 | STOP RING E5 | 1 | |
| 025770232 | PLAIN WASHER 6.35 | 1 | |
| 014760622 | SET SCREW 5.95 | 1 |
Q. 糸払イ関係/Thread wiper mechanism/Fadenwischvorrichtung/ M ecanisme de tire-fil/Mecanismo del limpiador de hilo REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 152815001 1 ワイパーロツトシシク THREAD WIPER ROD SHAFT 2 152816001 1 ワイパーロツトクミ THREAD WIPER ROD ASSEMBLY 3 014680622 1 アナトメネジ4.37クボミ SET SCREW 4.37 4 048060342 1 トメワE6 STOP RING E6 5 116629001 2 ザガネ WASHER 6 152820001 1 ワイパーシヤフト THREAD WIPER SHAFT 7 025770232 1 ヒラザガネチユウ6.35 PLAIN WASHER 6.35 8 048040342 1 トメワE4 STOP RING E4 9 014680622 1 アナトメネジ4.37クボミ SET SCREW 4.37 10 152823001 1 ワイパーアームクミ THREAD WIPER ARM ASSEMBLY 11 048030342 1 トメワE3 STOP RING E3 12 152827009 1 オイルキリセン OIL CAP 13 013710712 1 トメネジ4.76クボミ SET SCREW 4.76 14 156206001 1 ワイパーA THREAD WIPER (A) 15 062670512 1 ナベコ357-40X5 SCREW 357X5 16 156495001 1 FINGER GUARD 17 025350132 1 ヒラザガネシヨウ PLAIN WASHER 18 062671012 2 SCREW 357X10 R. 糸締メ関係/Thread nipper mechanism/Fadenspannvorrichtung/ M ecanisme de pince-fil/Mecanismo de la mordaza para hilo REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 152925101 1 ウワイトルメルボウ NEEDLE THREAD RELEASE SHAFT 2 152926001 1 ユルメルボウササイタ TENSION RELEASE BAR PLATE 3 062671012 2 ナベコ357-40X10 SCREW 357X10 4 025350332 2 ヒラザガネ3.5 PLAIN WASHER 3.5 5 152988001 1 ウワイトルメルレバークミ NEEDLE THREAD RELEASE LEVER ASSEMBLY 6 048040342 1 トメワE4 STOP RING E4 7 152929001 1 ウワイトルメルレバーシク NEEDLE THREAD RELEASE LEVER SHAFT 8 048050342 1 トメワE5 STOP RING E5 9 025770232 1 ヒラザガネチユウ6.35 PLAIN WASHER 6.35 10 014760622 1 アナトメネジ5.95 SET SCREW 5.95 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1-1 | SPRING | ||
| 1-2 | BRACKET | ||
| 1-3 | SCREW | ||
| 1-4 | WASHER | ||
| 1-5 | PLATE | ||
| 1-6 | PIN | ||
| 1-7 | WASHER | ||
| 1-8 | WASHER | ||
| 1-9 | SCREW | ||
| 1-10 | PLATE | ||
| 1-11 | BRACKET | ||
| 1-12 | CHAIN | ||
| 1-13 | LEVER | ||
| 1-14 | SCREW | ||
| 1-13-1 | SCREW | ||
| 1-13-2 | WASHER | ||
| 1-13-3 | PEDAL | ||
| 1-13-4 | WASHER | ||
| 1-1 | PLATE | ||
| 1-9 | SCREW | ||
| 1-10 | PLATE | ||
| 1-4 | WASHER | ||
| 1-7 | BRACKET | ||
| 1-5 | PLATE | ||
| 1-8 | WASHER | ||
| 1-11 | BRACKET | ||
| 1-2 | BRACKET | ||
| 1-13 | LEVER | ||
| 1-3 | SCREW | ||
| 1-6 | PIN | ||
| 1-12 | WASHER | ||
| 1-16 | WASHER | ||
| 1-17 | WASHER | ||
| 1-15 | WASHER | ||
| 1-14 | SCREW |
S. 付属装置セット/Attachment set/Anbausatz/Jeu d'accessoires/Juego de fijación 1-1 1-2 1-5 1-4 1-6 1-7 1-8 1-9 1-10 1-11 1-3 1-14 1-12 1-13-1 1-13-2 1-13-4 1-13-3 T. 特別注文部品/Option Parts/Sonderzubehör/Pièces en option/Piezas opcionales 1-1 1-9 1-10 1-4 1-7 1-5 1-8 1-11 1-2 1-13 1-3 1-6 1-12 1-16 1-17 1-15 1-14 jintex.in
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 154709002 | MECHANISM TWO PEDALS ASSEMBLY | 1 | |
| 154452001 | SPRING DRIVE LEVER PLATE | 1 | |
| 154448001 | DRIVE LEVER PLATE | 1 | |
| 017762012 | BOLT 5.95X20 | 2 | |
| 025060232 | PLAIN WASHER 6 | 2 | |
| 150553001 | NUT 5.95 | 2 | |
| 154449001 | STOPPER | 2 | |
| 025080232 | PLAIN WASHER 8 | 2 | |
| 028080242 | SPRING WASHER 2-8 | 2 | |
| 105812003 | NUT 7.94 | 2 | |
| 154450001 | RELEASE DRIVE LEVER B | 1 | |
| 154451001 | DRIVE STOPPER (B) | 1 | |
| 149247001 | CHAIN ASSEMBLY | 1 | |
| 116185209 | PEDAL ASSEMBLY | 1 | |
| 117437109 | FOOT PEDAL | 1 | |
| 021400106 | NUT 4 | 2 | |
| 062401416 | SCREW 4X14 | 2 | |
| 116016001 | PEDAL STOPPER | 2 | |
| 154681001 | ROLLER SHAFT ASSEMBLY (B) | 1 | |
| S18426001 | NEEDLE PLATE (S) ASSEMBLY | 1 | |
| 152995001 | NEEDLE PLATE (S) | 1 | |
| 152981001 | KNIFE ARM (C) | 1 | |
| 15322001 | SCREW 4.37 | 1 | |
| 152897201 | KNIFE CONNECTING ROD ASSEMBLY | 1 | |
| 152901001 | MOVABLE KNIFE ASSEMBLY | 1 | |
| 152904001 | SCREW 4.37 | 1 | |
| 152905001 | FIXED KNIFE | 1 | |
| 111140002 | SCREW 2.38 | 2 | |
| 100360003 | SCREW 2.38 | 2 | |
| 156150001 | NEEDLE PLATE (B) | 1 | |
| 153220001 | KNIFE ARM (C) COLLAR | 1 | |
| 153219001 | MOVABLE KNIFE COLLAR | 1 | |
| 152906101 | BOBBIN THREAD RETAINER (A) | 1 | |
| 153598001 | SCREW 4.37 | 1 | |
| 081008070 | O RING P8 | 1 | |
| 153597001 | BOBBIN THREAD RETAINER COLLAR | 1 | |
| 153596001 | WASHER | 1 |
S. 付属装置セット/Attachment set/Anbausatz/Jeu d'accessoires/Juego de fijación REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 154709002 1 メカ2ペダルソウチクミ MECHANISM TWO PEDALS ASSEMBLY 1-1 154452001 1 クトウウレバーイタヒキハネ SPRING DRIVE LEVER PLATE 1-2 154448001 1 クトウウレバーイタ DRIVE LEVER PLATE 1-3 017762012 2 ボルト5.95X20 BOLT 5.95X20 1-4 025060232 2 ヒラサガネチユウ6 PLAIN WASHER 6 1-5 150553001 2 ナツト5.95 NUT 5.95 1-6 154449001 2 ストツパー STOPPER 1-7 025080232 2 ヒラサガネチユウ8 PLAIN WASHER 8 1-8 028080242 2 ハガネ2-8 SPRING WASHER 2-8 1-9 105812003 2 ナツト7.94 NUT 7.94 1-10 154450001 1 P サトウレバーB RELEASE DRIVE LEVER B 1-11 154451001 1 キトウツトツパ-B DRIVE STOPPER (B) 1-12 149247001 1 クサリクミ CHAIN ASSEMBLY 1-13 116185209 1 ペダルクミ PEDAL ASSEMBLY 1-13-1 117437109 1 オサエアゲフミイタ FOOT PEDAL 1-13-2 021400106 2 シユナツト4 NUT 4 1-13-3 062401416 2 ナベ4X14 SCREW 4X14 1-13-4 116016001 2 ペダルトメ PEDAL STOPPER 1-14 154681001 1 オサエアゲコウシクミB ROLLER SHAFT ASSEMBLY (B) T. 特別注文部品/Option Parts/Sonderzubehör/Pièces en option/Piezas opcionales REF.NO. CODE Q'TY ヒンメイ NAME OF PARTS RMKS 1 S18426001 1 ハリイタSクミ NEEDLE PLATE (S) ASSEMBLY 1-1 152995001 1 ハリイタS NEEDLE PLATE (S) 1-2 152981001 1 イトキリウデ"C KNIFE ARM (C) 1-3 15322001 1 シメナツト4.37 SCREW 4.37 1-4 152897201 1 イトキリレンカンクミ KNIFE CONNECTING ROD ASSEMBLY 1-5 152901001 1 イトウハクミ MOVABLE KNIFE ASSEMBLY 1-6 152904001 1 シメナツト4.37 SCREW 4.37 1-7 152905001 1 コテイハ FIXED KNIFE 1-8 111140002 2 シメナツト2.38 SCREW 2.38 1-9 100360003 2 サラナツト2.38 SCREW 2.38 1-10 156150001 1 ハリイタB NEEDLE PLATE (B) 1-11 153220001 1 イトキリウデ"Cカラー KNIFE ARM (C) COLLAR 1-12 153219001 1 イトウハカラー MOVABLE KNIFE COLLAR 1-13 152906101 1 シタイトサバキA BOBBIN THREAD RETAINER (A) 1-14 153598001 1 シメナツト4.37 SCREW 4.37 1-15 081008070 1 OリングP8 O RING P8 1-16 153597001 1 シタイトサバキカラー BOBBIN THREAD RETAINER COLLAR 1-17 153596001 1 サガネ WASHER jintex.in
