Page 5

Juki MO-6716 (53 pages) parts on page 5

Ref	Part number	Part name	Qty
	MO-6716S	THREAD STAND COMPONENTS (FOR MO-6716S)
	MO-6716S	糸立装置関係(MO-6716S用)
	MO-6716S SPECIAL ORDER PARTS	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	MO-6716S 特別注文部品	糸立装置関係(MO-6716S 特別注文部品)
	SPECIAL ORDER PARTS COMPONENTS	SPECIAL ORDER PARTS COMPONENTS
	SPECIAL ORDER PARTS COMPONENTS	特別注文部品関係
	ACCESSORIES PARTS COMPONENTS	ACCESSORIES PARTS COMPONENTS
	ACCESSORIES PARTS COMPONENTS	付属品関係
	LIST FOR INFORMATION OF CHANGE	LIST FOR INFORMATION OF CHANGE
	LIST FOR INFORMATION OF CHANGE	変更情報リスト
	NUMERICAL INDEX OF PARTS	NUMERICAL INDEX OF PARTS
	NUMERICAL INDEX OF PARTS	索引

Page 6 — 1. MISCELLANEOUS COVER COMPONENTS (1)

Juki MO-6716 (53 pages) parts on page 6

Ref	Part number	Part name	Qty
9	9	9
10	10	10
7	7	7
8	8	8
43	43	43
41	41	41
42	42	42
34	34	34
11	11	11
12	12	12
35	35	35
23	23	23
36	36	36
37	37	37
39	39	39
38	38	38
44	44	44
13	13	13
14	14	14
45	45	45
46	46	46
47	47	47
28	28	28
29	29	29
51	51	51
48~50	48~50	48~50
18	18	18
1	1	1
3	3	3
5	5	5
6	6	6
2	2	2
4	4	4
19	19	19
20	20	20
15	15	15
21	21	21
22	22	22
24	24	24
16	16	16
17	17	17
25	25	25
26	26	26
27	27	27
30	30	30
31	31	31

Page 7

Juki MO-6716 (53 pages) parts on page 7

Ref	Part number	Part name	Qty
	131-04005	CLOTH WASTE COVER	1
	131-04203	CLOTH WASTE COVER	1
	131-02405	CROTH WASTE COVER STOPPER	1
	SS-2090520-SL	SCREW 9/64-40 L=5	1
	NS-6090310-SN	NUT 9/64-40	1
	SS-3090610-SP	SCREW 9/64-40 L=6	2
	132-00704	FEED MECHANISM COVER	1
	132-00803	FEED MECHANISM COVER GASKET	1
	SM-4040855-SP	SCREW	4
	SM-1040801-SC	SCREW M4X0.7 L=8	1
	123-42101	CLOTH BASE SIDE COVER	1
	SS-4120615-SP	SCREW 3/16-28 L=6	2
	131-03809	CLOTH BASE COVER	1
	SS-4091015-SP	SCREW 9/64-40 L=10	2
	131-00904	LOOPER COVER	1
	131-00805	LOOPER COVER BRACKET	1
	SM-4041055-SP	SCREW M4 L=10	3
	131-01209	LOOPER COVER SPRING	1
	131-01407	LOOPER COVER PRESSER PLATE	1
	SS-7090530-SP	SCREW 9/64-40 L=4.5	1
	131-01001	LOOPER COVER GUIDE PLATE	1
	SS-7090610-SP	SCREW 9/64-40 L=6	1
	SS-8110410-TP	SCREW 11/64-40 L=3.5	1
	SS-8110410-TP	SCREW 11/64-40 L=3.5	1
	131-01506	CLOTH WASTE COVER, LEFT	1
	131-01605	CLOTH WASTE COVER, LEFT	1
	SS-7110510-SP	SCREW 11/64-40 L=5	2
	121-03305	CLOTH BASE SWITCH-TYPE STOPPER	1
	SS-7110710-SP	SCREW 11/64-40 L=7	2
	131-01308	LOOPER COVER PRESSER SPRING	1
	SM-4040655-SP	SCREW M4 L=6	1
	131-01803	CROTH BASE SUPPORT PLATE	1
	SS-7091410-SP	SCREW 9/64-40 L=13.5	1
	131-03650	CLOTH BASE CMPL.	1
	131-02058	CLOTH BASE ASM.	1
	131-01902	CLOTH BASE ECCENTRIC BUSHING	1
	WZ-0420350-KP	DISC SPRING	(1)
	131-72903	CLOTH BASE HINGE SHAFT COLLAR	(1)
	SM-8040302-TP	SETSCREW	(1)
	CM-3002000-01	ATTENTION SEAL	1
	132-01504	ADJUSTING HOLE COVER	1
	132-01603	ADJUSTING HOLE COVER GASKET	1
	SM-4040855-SP	SCREW	4
	131-04302	CLOTH BASE COVER RUBBER PLUG	1
	131-02207	CLOTH BASE SWITCH-TYPE SPRING	1
	NS-6110420-SP	NUT 11/64-40	1
	SS-6111440-SP	SCREW 11/64-40 L=14.0	1
	132-40007	LOOPER COVER HINGE SHAFT A	1
	132-40106	LOOPER COVER HINGE SHAFT B	1
	132-40205	LOOPER COVER HINGE SHAFT C	1
	131-04104	CLOTH WASTE COVER	1

Page 8 — 2. MISCELLANEOUS COVER COMPONENTS (2)

Juki MO-6716 (53 pages) parts on page 8

Ref	Part number	Part name	Qty
1	1	COVER, SIDE
2	2	COVER, FRONT
3	3	BRACKET, COVER
4	4	SCREW
5	5	COVER, UPPER
6	6	GASKET
7	7	SCREW
8	8	COVER, NEEDLE BAR
9	9	RING
10	10	SCREW
11	11	WASHER
12	12	COVER, MOTOR
13	13	SCREW
14	14	SCREW
15	15	COVER, SIDE
16	16	COVER, SIDE
17	17	BRACKET
18	18	SCREW
19	19	COVER, BASE
20	20	COVER, BASE
21	21	SCREW
22	22	SCREW
23	23	GASKET
24	24	BOLT
25	25	WASHER
26	26	WASHER
27	27	NUT
28	28	BRACKET
29	29	BRACKET
30	30	SCREW
31	31	SCREW
32	32	BRACKET
33	33	BRACKET
34	34	BRACKET
35	35	BRACKET
36	36	BRACKET
37	37	BRACKET
38	38	BOLT
39	39	CAP
40	40	SCREW
41	41	CAP
42	42	CAP
43	43	BRACKET

Page 9

Juki MO-6716 (53 pages) parts on page 9

Ref	Part number	Part name	Qty
	132-00209	SIDE COVER	1
	132-00308	SIDE COVER GASKET	1
	SM-4040855-SP	SCREW	3
	SM-1040801-SC	SCREW M4X0.7 L=8	1
	132-00506	UPPER COVER	1
	132-00605	UPPER COVER GASKET	1
	SM-4051255-SP	SCREW M5 L=12.	5
	229-24708	OIL SIGHT WINDOW	1
	131-70006	RUBBER RING	1
	131-04500	OIL DRAIN SCREW	1
	131-70204	RUBBER RING	1
	132-01009	COOLING FAN PLATE	1
	SM-1040801-SC	SCREW M4X0.7 L=8	1
	SM-4040855-SP	SCREW	2
	132-01454	BELT COVER ASM.	1
	132-01405	BELT COVER	1
	CM-3002000-A1	CAUTION LABEL (16)	(1)
	SS-4151215-SP	SCREW 15/64-28 L=12	(1)
	131-02553	OIL RESERVOIR ASM.	3
	131-02504	OIL RESERVOIR	(1)
	131-70105	RUBBER RING	(1)
	131-71004	DRAIN SCREW	(1)
	131-02603	OIL RESERVOIR GASKET	1
	131-03908	SCREW STUD	4
	WP-0751576-SD	WASHER 7.5X19X1.5	4
	WS-0822010-KP	SPRING WASHER 8.2X15X2	4
	NS-6680410-SP	NUT 9/32-28	4
	132-01108	SAFETY PLATE BRACKET	1
	131-04807	SAFETY PLATE BRACKET COLLAR	1
	WZ-0850302-K0	WAVED WASHER 8.5X12.5X0.3	1
	SS-5110710-SP	SCREW 11/64-40 L=7	1
	132-01306	SAFETY PLATE	1
	132-01207	SAFETY PLATE	1
	SS-7090611-SL	SCREW 9/64-40 L=6.1	2
	132-04003	SAFETY PLATE BUSH	1
	CM-3002001-B1	SAFETY LABEL 12	1
	229-01805	GROUND MARK	1
	131-02900	THREAD GUIDE, LARGE	2
	107-53309	WINDOW PLATE RUBBER PLUG	1
	SK-3412001-SE	WOOD SCREW D=4.1 L=20	2
	TA-1871602-R0	RUBBER PLUG	1
	TA-2050805-R0	RUBBER PLUG	1
	131-60700	BELT COVER (B)	1

Page 10 — 3. CRANKSHAFT COMPONENTS

Juki MO-6716 (53 pages) parts on page 10

Ref	Part number	Part name	Qty
45	45	SCREW
46	46	SCREW
47	47	BRACKET
42	42	WASHER
43	43	CONNECTING ROD
44	44	SCREW
48	48	BRACKET
1	1	CRANKSHAFT
2	2	CRANKSHAFT
3	3	CRANKSHAFT
28	28	CONNECTING ROD
23	23	COVER
29	29	SCREW
19	19	BEARING
20	20	PIN
30	30	CONNECTING ROD
31	31	SCREW
41	41	WASHER
21	21	BEARING
22	22	BEARING
34	34	CONNECTING ROD
35	35	SCREW
41	41	WASHER
33	33	SCREW
32	32	SCREW
25	25	COVER
24	24	COVER
26	26	SCREW
11	11	SCREW
38	38	CONNECTING ROD
39	39	SCREW
36	36	SCREW
37	37	SCREW
41	41	WASHER
5	5	WEIGHT
13	13	WASHER
12	12	WEIGHT
10	10	FLYWHEEL
17	17	BEARING
18	18	BEARING
A	A	BEARING
6	6	WEIGHT
9	9	WEIGHT
8	8	WEIGHT
14	14	WEIGHT
4	4	WEIGHT
7	7	SCREW
15	15	GASKET
27	27	WASHER
16	16	BEARING
A	A	BEARING

Page 11

Juki MO-6716 (53 pages) parts on page 11

Ref	Part number	Part name	Qty
	400-23235	MAIN SHAFT ASM.	1
	400-23234	MAIN SHAFT (300)	(1)
	SS-5080212-TP	SCREW 1/8-44 L=2	(5)
	131-07602	HANDWHEE (A)	1
	SS-8151150-TP	SCREW 15/64-28 L=10.5	2
	131-07800	THRUST COLLAR	1
	SM-4050855-SP	SCREW M5 L=8	3
	131-08402	COOLING FAN	1
	131-08501	CRANKSHFT OIL SHIELD	1
	131-07701	HANDWHEEL	1
	SS-7111810-TP	SCREW 11/64-40 L=18	3
	SS-9681610-TP	SCREW 9/32-28 L=16	1
	WP-0764016-SP	WASHER	1
	131-70303	RUBBER RING	1
	WZ-2640310-KH	WAVED WASHER 26.4X33.9X3.5	1
	B1211-804-000	BALL BEARING B	1
	B1212-704-000	BEARING RETAINER	1
	B1211-804-000	BALL BEARING B	1
	132-05406	CRANKSHAFT BUSHING C	1
	131-04906	OIL ADJUSTING BAR	1
	B1215-804-000	BALL BEARING D	1
	SB-1100003-00	BALL BEARING	1
	131-08006	CRANKSHAFT BUSHING D	1
	131-08105	CRANKSHAFT BUSHING D	1
	131-08204	CRANKSHAFT BUSHING GASKET	1
	SM-4040855-SP	SCREW	3
	131-08303	BEARING HOLDING PLATE	1
	121-09153	CONNECTING ROD ASM.	1
	SS-7111810-TP	SCREW 11/64-40 L=18	(2)
	121-22362	UPPER LOOPER ROD ASM.	1
	SS-7111810-TP	SCREW 11/64-40 L=18	(2)
	SS-7111410-TP	SCREW 11/64-40 L=14	(2)
	SM-6061202-TP	SCREW M6 L=12	(1)
	121-23360	LOWER LOOPER ROD ASM., A	1
	SS-7111810-TP	SCREW 11/64-40 L=18	(2)
	SS-7111410-TP	SCREW 11/64-40 L=14	(2)
	SM-6061202-TP	SCREW M6 L=12	(1)
	121-20150	LOWER LOOPER ROD ASM., B	1
	SS-7111810-TP	SCREW 11/64-40 L=18	(2)
	SS-7111410-TP	SCREW 11/64-40 L=14	(2)
	400-17824	LOOPER LOD STOPPER	4
	SS-6081210-TP	SCREW 1/8-44 L=12	2
	121-32155	KNIFE DRIVING ROD ASM.	1
	SS-7111810-TP	SCREW 11/64-40 L=18	(2)
	SS-7110840-SP	SCREW 11/64-40 L=7.8	1
	SS-7110840-SP	SCREW 11/64-40 L=7.8	1
	400-17714	BALANCER	1
	400-35711	OIL WICK	1

Page 12 — 4. NEEDLE DRIVING SHAFT COMPONENTS

Juki MO-6716 (53 pages) parts on page 12

Ref	Part number	Part name	Qty
20	20	SCREW
19	19	SLEEVE
6	6	BRACKET
8	8	SCREW
15	15	SHAFT
7	7	SHAFT
58	58	PIN
9~11	9~11	BEARING
57	57	SPRING
58	58	PIN
9~11	9~11	BEARING
17	17	WASHER
60	60	SHAFT
12~14	12~14	COLLAR
16	16	SHAFT
1	1	BRACKET
3	3	SPRING
2	2	SHAFT
49~52	49~52	PIN
57	57	SPRING
17	17	WASHER
68	68	LINK
54	54	COLLAR
56	56	SCREW
55	55	COLLAR
56	56	SCREW
54	54	COLLAR
42	42	SHAFT
46	46	COLLAR
45	45	SHAFT
47	47	RING
44	44	SHAFT
48	48	SCREW
43	43	BRACKET
30	30	BRACKET
29	29	BRACKET
28	28	BRACKET
31	31	BRACKET
32	32	SCREW
33	33	SCREW
25	25	BRACKET
24	24	BRACKET
27	27	SPRING
26	26	PIN
61	61	SPRING
21	21	SHAFT
23	23	COLLAR
22	22	COLLAR
64	64	SHAFT
63	63	SHAFT
62	62	SHAFT
67	67	SCREW
67	67	SCREW
65	65	SPRING
53	53	SHAFT
66	66	NEEDLE
34	34	BRACKET
37	37	SCREW
35	35	BRACKET
36	36	BRACKET
38	38	BRACKET
41	41	SCREW
39	39	BRACKET
40	40	BRACKET

Page 13

Juki MO-6716 (53 pages) parts on page 13

Ref	Part number	Part name	Qty
	131-10556	FEED FORKED CRANK ASM.	1
	131-10507	NEEDLE DRIVING BRANCH CRANK	(1)
	SM-6061402-TP	SCREW M6 L=14	(1)
	131-10606	NEEDLE DRIVING SHAFT	1
	131-10101	BUSHING, REAR	1
	132-09853	NEEDLE DRIVING ARM ASM.	1
	132-09804	NEEDLE DRIVING ARM	(1)
	SM-6061402-TP	SCREW M6 L=14	(1)
9	132-09101	NEEDLE DRIVING ARM PIN A	2
10	132-09200	NEEDLE DRIVING ARM PIN B	2
11	132-09309	NEEDLE DRIVING ARM PIN C	2
12	132-09408	NEEDLE DRIVING PIN A	1
13	132-09507	NEEDLE DRIVING PIN B	1
14	132-09606	NEEDLE DRIVING PIN C	1
	131-10002	BUSHING, REAR	1
	132-08350	NEEDLE ROD (A) ASM.	1
	132-08103	NEEDLE DRIVING LINK WASHER	2
	EA-9500B01-00	CABLE BAND	1
	132-09705	NEEDLE ROD BUSHING, UPPER	1
	132-07808	NEEDLE ROD BUSHING CAP SCREW	1
	131-10259	NEEDLE CLAMP HOLDER ASM.	1
	131-10200	NEEDLE CLAMP HOLDER	(1)
	SS-6080720-SP	SCREW 1/8-44 L=7	(1)
24	131-10705	NEEDLE THREAD PRESSER GUIDE A	1
25	131-10804	NEEDLE THREAD PRESSER GUIDE B	1
	131-10903	NEEDLE THREAD PRESSER PLATE A	1
	131-11000	NEEDLE THREAD PRESSER PLATE B	1
28	132-08806	NEEDLE THREAD GUIDE	1
29	132-08905	THREAD GUIDE, 2-NEEDLE	1
	132-08707	NEEDLE THREAD GUIDE BASE	1
31	131-11109	THREAD GUIDE, CHAIN LOOPER	1
	SM-4040855-SP	SCREW	2
33	SS-4110515-SP	SCREW 11/64-40 L=5	1
34	131-11208	NEEDLE THREAD TAKE-UP LEVER	1
35	131-11307	TAKE-UP LEVER, CHAIN LOOP	1
36	131-11406	TAKE-UP LEVER, CHAIN LOOP	1
	SS-6090670-TP	SCREW 9/64-40 L=6	2
38	131-11505	NEEDLE THREAD BALANCE GUIDE	1
39	131-11604	TAKE-UP LEVER GUIDE, 2-NEEDLE	1
40	131-11703	TAKE-UP LEVER GUIDE, CHAIN LOOP	1
	SM-4040855-SP	SCREW	1
	132-08459	ONCE THROUGH OIL PIPE ASM.	(1)
	132-08509	ONCE THROUGH OIL COVER	(1)
	CQ-2000000-00	OIL WICK	(0.8)
	236-30007	TUBE	(0.39)
	132-44009	ONCE THROUGH OIL PIPE BUSHING	(1)
	132-08608	ONCE THROUGH OIL FELT	(1)
	131-42609	PIPE CLAMP	1
49	131-22007	FEED BRANCH CRANK PIN A	1
50	131-22106	FEED BRANCH CRANK PIN B	1
51	131-22205	FEED BRANCH CRANK PIN C	1
52	131-22304	FEED BRANCH CRANK PIN D	1
53	MDC-270B1100	NEEDLE DCX27 #11	2
	131-72754	THRUST COLLAR ASM.	2
	131-72705	THRUST COLLAR	(1)
	SS-8060610-TP	SCREW 1/4-40 L=6	(2)
57	SS-8090530-TP	SCREW 9/64-40 L=5.0	2
	CQ-2020000-00	OIL WICK	0.09
59	SS-8090530-TP	SCREW 9/64-40 L=5.0	1
	CQ-2520000-00	OIL WICK	0.04
	SD-0280401-SL	HINGE SCREW D=2.8 H=4	1
62	131-75005	NEEDLE CLAMP, 1-NEEDLE	1
63	122-56905	NEEDLE CLAMP, 2-NEEDLE(BE6)	1
64	122-57002	CHAIN LOOPER NEEDLE CLAMP, DEA	1
65	SS-8080310-TP	SCREW 1/8-44 L=2.8	1
66	MDC-270B1100	NEEDLE DCX27 #11	1
67	SS-8080310-TP	SCREW 1/8-44 L=2.8	2
	132-08004	NEEDLE DRIVING LINK	1

Page 14 — 5. FEED MECHANISM COMPONENTS (1)

Juki MO-6716 (53 pages) parts on page 14

Ref	Part number	Part name	Qty
3	3	SCREW
2	2	WASHER
4	4	BRACKET
42	42	LINK
43	43	BUSH
32	32	BRACKET
34	34	SCREW
33	33	CAM LEVER
41	41	WASHER
40	40	NUT
39	39	SCREW
5	5	SHAFT
6	6	SHAFT
35~38	35~38	SHAFT
7	7	PIN
8	8	COVER
9	9	COLLAR
10	10	COLLAR
11	11	PIN
24	24	ROLLER
23	23	SHAFT
17	17	SCREW
16	16	ARM
18~22	18~22	NEEDLE ROLLER BEARING
15	15	SCREW
14	14	SPRING
1	1	SHAFT
13	13	SPRING
12	12	BRACKET
31	31	BRACKET
25	25	TUBE
26	26	PIN
27	27	SCREW
28	28	SPRING
29	29	WASHER
30	30	WASHER

Page 15

Juki MO-6716 (53 pages) parts on page 15

Ref	Part number	Part name	Qty
	131-18054	FEED ECCENTRIC BODY ASM.	1
	131-20605	WASHER	1
	SS-6121220-TP	SCREW 3/16-28 L=11.5	1
	131-22452	FEED BRANCH CRANK ASM.	1
	131-22403	FEED BRANCH CRANK	(1)
	SM-6061402-TP	SCREW M6 L=14	(1)
	TA-1030402-RO	RUBBER PLUG D=10.3 L=4	1
	TA-2050416-RO	RUBBER PLUG	1
	131-72556	FEED SHAFT THRUST COLLAR ASM.	2
	131-72507	FEED SHAFT THRUST COLLAR	(1)
	SS-8110410-TP	SCREW 11/64-40 L= 3.5	(2)
01	132-17807	SLIDE BLOCK A	1
	131-22502	RATCHET PAWL SPRING	1
	131-19300	RATCHET GEAR SPRING	1
	SS-6080320-SP	SCREW 1/8-44 L= 2.5	1
	131-18708	FEED CRANK ROD	1
	SS-7110910-TP	SCREW 11/64-40 L= 8.5	1
01	121-16604	NEEDLE BEARING	1
01	121-16703	NEEDLE BEARING B	1
01	121-16802	NEEDLE BEARING.,C.	1
01	121-16901	NEEDLE BEARING.,D.	1
01	121-17008	NEEDLE BEARING.,E.	1
	131-19409	FEED SHAFT METAL, FRONT	1
	131-19508	FEED SHAFT METAL, REAR	1
	131-19607	FEED SHAFT	1
	132-16809	PUSH BUTTON SHAFT	1
	SM-4041455-SN	SCREW M4 L=14	1
	132-16600	PUSH BUTTON SPRING	1
	132-16700	PUSH BUTTON SHAFT WASHER	1
	132-44108	RUBBER RING	1
01	132-17906	SLIDE BLOCK B	1
	131-19953	MAIN FEED ARM ASM.	1
	131-19904	MAIN FEED ARM	1
	SM-6051202-TP	SCREW M5X0.8 L=12	(1)
01	131-22007	CRANK PIN A	1
01	131-22106	CRANK PIN B	1
01	131-22205	CRANK PIN C	1
01	131-22304	CRANK PIN D	1
	131-19706	MAIN FEED ARM PIN	1
	NS-6620320-SP	NUT 3/16-32	1
	131-20001	WASHER B	1
	131-19805	MAIN FEED LINK	1
	B1620-804-000	PIN COLLAR	1

Page 16 — 6. FEED MECHANISM COMPONENTS (2)

Juki MO-6716 (53 pages) parts on page 16

Ref	Part number	Part name	Qty
	33	BLOCK
	53	WASHER
	35	SCREW
	52	COLLAR
	29	SHAFT
	30	BRACKET
	32	SCREW
	34	WASHER
	31	COLLAR
	50	BRACKET
	56	BLOCK
	22	BRACKET
	21	PLATE
	16	PLATE
	1	BRACKET
	19	PLATE
	20	SCREW
	42	BRACKET
	44	SCREW
	43	COLLAR
	64	BRACKET
	51	SCREW
	70	BRACKET
	2	BRACKET
	66	BRACKET
	65	BRACKET
	71	BRACKET
	40	BRACKET
	41	CLIP
	59	SCREW
	11	PLATE
	10	PLATE
	14	BRACKET
	13	BRACKET
	23	BRACKET
	67	BRACKET
	3	SCREW
	68	BRACKET
	69	BRACKET
	5	BRACKET
	6	BRACKET
	7	BRACKET
	4	BRACKET
	62	WASHER
	60	SCREW
	17	PLATE
	54	WASHER
	15	SCREW
	12	SCREW
	55	SCREW
	38	KNOB
	26	BRACKET
	24	SHAFT
	25	SCREW
	28	WASHER
	27	SCREW
	58	GEAR
	63	WASHER
	36	COLLAR
	61	SPRING
	39	SPRING
	27	SCREW
	28	WASHER
	26	BRACKET
	37	SCREW
	48	WASHER
	47	BRACKET
	18	COLLAR
	45	COLLAR
	46	SCREW
	49	SPRING
	57	SCREW

Page 17

Juki MO-6716 (53 pages) parts on page 17

Ref	Part number	Part name	Qty
	132-15157	FEED ROCKER ASM.
	SS-4080620-TP	SCREW 1/8-44 L=6
	SS-9111010-SP	SCREW 11/64-40 L=9.5
	132-15306	RUBBER CASE
	132-15405	RUBBER CASE GASKET
	132-15504	FEED BAR SUPPORT, RIGHT
	132-15603	FEED BAR SUPPORT, LEFT
	SS-6090620-TP	SCREW
	121-18303	DUST-PROOF RUBBER
	121-18204	OIL SHIELD RUBBER
	132-15702	RUBBER HOLDING PLATE
	SS-7060310-SP	SCREW 3/32-56 L=3
	132-15900	OIL SHIELD CASE
	132-16007	OIL SHIELD CASE GASKET
	SM-4040855-SP	SCREW
	SM-4030455-SP	SCREW
	132-15801	THROAT PLATE SUPPORT
	131-22700	ADJUSTING SHAFT METAL
	132-16106	OIL SHIELD PLATE
	SS-1060610-SP	SCREW 3/32-56 L=5.5
	132-16205	FEED CAM OIL SHIELD PLATE
	SM-6040600-SP	OIL SHIELD PLATE
	132-16304	OIL SHIELD PLATE
	131-22809	DIFFERENTIAL FEED GRADUATION
	SM-4051255-SP	SCREW M5 L=12
	131-21405	ADJUSTING STOPPER
	SS-4090515-SP	SCREW 9/64-40 L=5
	WP-0371016-SD	WASHER 3 7X8X1
	131-20902	SUPPORT SHAFT
	131-21058	HRUST COLLAR ASM.
	131-21058	HRUST COLLAR
	SS-8660330-SP	SCREW 1/4-40 L=3.0
	131-20803	SLIDE BLOCK
	131-70204	RUBBER RING
	SM-4040855-SP	SCREW
	132-17708	DIFFERENTIAL FEED BLOCK
	RE-0300000-KO	E-RING 3
	132-13012	ADJUSTING SCREW
	131-23302	DIFFERENTIAL FEED SCREW SPRING
	131-21306	ADJUSTING LINK
	RE-0500000-KO	E-RING 5
	131-21256	SUPPORT SHAFT COLLAR ASM.
	131-21207	SUPPORT SHAFT COLLAR
	SS-8110410-TP	SCREW 11/64-40 L=3.5
	131-21900	DIFFERENTIAL FEED ROCKER
	SS-6661110-SP	SCREW 1/4-40 L=11
	132-17351	ROCKER SHAFT ASM.
	131-70501	RUBBER RING
	131-18052	ADJUSTING LEVER SPRING
	132-15805	DIFFERENTIAL FEED ARM ASM.
	SS-9111050-SP	SCREW 11/64-40 L=9.5
	131-21108	WASHER
	TA-0800504-RO	PLUG D=8 L=4.5
	132-00902	FEED MECHANISM COVER PRESSER
	SS-6080340-SP	SCREW 1/8-44 L=2.9
	132-18102	SLIDE BLOCK
	132-17401	DIFFERENTIAL FEED HINGE SCREW
	132-17500	DIFFERENTIAL FEED LOCK NUT
	SD-0720271-SP	HINGE SCREW D=7.2 H=2.7
	SM-4041055-SP	WASHER M4 L=10
	WP-0460556-SD	WASHER 4.6X7.5X0.5
	WP-0480856-SP	WASHER 4.8X8.4X0.8
	WP-0621016-SD	WASHER 6.2X13X1
	131-91606	MAIN FEED DOG
	119-49807	MAIN FEED DOG (F-25)
	131-92406	MAIN FEED DOG
	131-92802	DIFFERENTIAL FEED DOG
	131-93206	DIFFERENTIAL FEED DOG
	131-93602	DIFFERENTIAL FEED DOG
	131-91408	AUXILIARY FEED DOG

Page 18 — 7. UPPER & LOWER LOOPER COMPONENTS

Juki MO-6716 (53 pages) parts on page 18

Ref	Part number	Part name	Qty
3	3	UPPER LOOPER
2	2	LOWER LOOPER
59	59	LOOPER SHAFT
61	61	SET SCREW
60	60	COLLAR
66	66	LOOPER SHAFT
67	67	LOOPER SHAFT
68	68	LOOPER SHAFT
10	10	LOOPER SHAFT
11	11	LOOPER SHAFT
43	43	SCREW
23	23	BRACKET
37	37	LOOPER SHAFT
38	38	LOOPER SHAFT
39	39	LOOPER SHAFT
40	40	LOOPER SHAFT
41	41	LOOPER SHAFT
4	4	BRACKET
6	6	SCREW
5	5	LOOPER ARM
8	8	LOOPER ARM
7	7	LOOPER ARM
9	9	SCREW
57	57	LOOPER SHAFT
58	58	LOOPER SHAFT
44	44	SCREW
48	48	BRACKET
49	49	SCREW
53	53	COVER
52	52	BRACKET
54	54	SCREW
72	72	WASHER
15	15	LOOPER DRIVING LEVER
14	14	LOOPER DRIVING LEVER
46	46	SCREW
45	45	BRACKET
47	47	WASHER
12	12	BRACKET
24	24	BRACKET
50	50	SCREW
31	31	BRACKET
32	32	SCREW
33	33	BRACKET
29	29	BRACKET
51	51	SCREW
56	56	BRACKET
30	30	SCREW
27	27	BRACKET
28	28	SCREW
34	34	SCREW
19	19	LOOPER DRIVING LEVER
18	18	SCREW
1	1	LOOPER DRIVING LEVER
20	20	LOOPER DRIVING LEVER
21	21	WASHER
22	22	SCREW
13	13	LOOPER DRIVING LEVER
65	65	SCREW
25	25	BRACKET
26	26	SCREW
35	35	SCREW
36	36	SCREW
55	55	RING
16	16	PIN
3	3	COLLAR
62	62	SCREW
64	64	COLLAR
63	63	COLLAR
69	69	LOOPER SHAFT
70	70	LOOPER SHAFT
71	71	LOOPER SHAFT

Page 19 — D E S C R I P T I O N

Juki MO-6716 (53 pages) parts on page 19

Ref	Part number	Part name	Qty
	118-90001	TRAVELING NEEDLE GUARD	1
	132-22609	LOOPER SHAFT FRONT BUSHING	2
	132-22708	LOOPER SHAFT REAR BUSHING	2
	131-31057	UPPER LOOPER ARM A ASM.	1
	131-31008	UPPER LOOPER ARM A	(1)
	SS-9151210-TP	SCREW 15/64-28 L=11.8	(1)
	131-31156	UPPER LOOPER ARM B ASM.	(1)
	131-31107	UPPER LOOPER ARM B	(1)
	SS-9151210-TP	SCREW 15/64-28 L=11.8	(1)
	400-15637	GUIDE SUPPORT ASM.	1
	400-16841	GUIDE SUPPORT B ASM	1
	SS-6090630-TP	SCREW 9/64-40 L=6	4
	119-99307	LOWER LOOPER	1
	118-88104	UPPER LOOPER	1
	121-76004	UPPER LOOPER	1
	PS-0300062-KH	SPRING PIN 3X6	1
	131-70600	RUBBER RING	1
	SS-6060440-TP	SCREW 3/32-56 L=3.5	2
	131-32550	LOWER LOOPER SUPPORT ARM ASM.	(1)
	131-32501	LOWER LOOPER SUPPORT ARM	(1)
	131-29309	WASHER	(1)
	SS-9151210-TP	SCREW 15/64-28 L=11.8	(1)
	SM-6061200-SP	SCREW M6 L=12	2
	121-23659	OIL SHIELD PLATE ASM.	1
	123-40600	UPPER LOOPER THREAD GUIDE	1
	SS-7090850-SP	SCREW 9/64-40 L=8	1
	123-40709	LOWER LOOPER THREAD TAKE-UP	1
	SS-6080410-SP	SCREW 1/8-44 L=4	1
	132-22401	LOOPER THREAD TAKE-UP COVER	2
	SM-4040655-SP	SCREW M4 L=6	1
	123-40303	THREAD GUIDE, RIGHT	1
	SS-3090610-SP	SCREW 9/64-40 L=6	1
	123-40402	THREAD TAKE-UP, RIGHT	1
	SS-7110840-SP	SCREW 11/64-40 L=7.8	1
	123-40907	LOWER THREAD TAKE-UP, LEFT	1
	SS-7110840-SP	SCREW 11/64-40 L=7.8	1
	131-31206	UPPER LOOPER HOLDER PIN A	1
	131-31305	UPPER LOOPER HOLDER PIN B	1
	131-31404	UPPER LOOPER HOLDER PIN C	1
	131-31503	UPPER LOOPER HOLDER PIN D	1
	131-31602	UPPER LOOPER HOLDER PIN E	1
	SS-9090610-TP	SCREW 9/64-40 L=5.5	1
	SS-9090410-TP	SCREW	1
	131-31701	OIL WICK STOPPER BALL	1
	131-31909	GUIDE SUPPORT GAUGE	1
	131-31800	GAUGE FIXING PIN	1
	131-32006	GUIDE SUPPORT GAUGE	1
	123-40501	THREAD GUIDE, UPPER	1
	SS-4090615-SP	SCREW 9/64-40 L=6	1
	123-40808	THREAD GUIDE	1
	SS-3090610-SP	SCREW 9/64-40 L=6	1
	132-22203	UPPER LOOPER GAUGE COVER	1
	132-22302	UPPER LOOPER GAUGE COVER B	1
	SS-7060610-SP	SCREW 3/32-56 L=5.5	2
	400-10804	OIL SEAL RING	1
	131-32709	UPPER LOOPER SHAFT RUBBER RING	1
	CQ-2000000-00	OIL WICK	0.04
	CQ-2020000-00	OIL WICK	0.04
	131-72853	THRUST COLLAR ASM.	2
	131-72804	THRUST COLLAR	(1)
	SS-8660610-TP	SCREW 1/4-40 L=6	(1)
	131-72853	THRUST COLLAR ASM.	(1)
	131-72804	THRUST COLLAR	(1)
	SS-8660610-TP	SCREW 1/4-40 L=6	(1)
	SS-6090620-TP	SCREW 1/4-40 L=6	1
	132-21403	UPPER LOOPER GUIDE A	1
	132-21502	UPPER LOOPER GUIDE B	1
	132-21601	UPPER LOOPER GUIDE C	1
	132-21700	UPPER LOOPER GUIDE A	1
	132-21809	UPPER LOOPER GUIDE B	1
	132-21908	UPPER LOOPER GUIDE C	1
	400-11234	DUST SEALING FELT	1

Page 21 — 9. PRESSER FOOT COMPONENTS (1)

Juki MO-6716 (53 pages) parts on page 21

Ref	Part number	Part name	Qty
	131-15001	PRESSER FOOT SHAFT
	131-15100	PRESSER FOOT SHAFT BUSHING
	131-15256	THRUST ARM
	131-15209	THRUST ARM
	SS-6110710-TP	SCREW 11/64-40 L= 6.5
	SS-91512TO-TP	SCREW 15/64-28 L=11.8
	131-16801	LIFTING ARM
	131-15407	PRESSER FOOT ARM HINGE SHAFT
	131-15753	PRESSER LIFTING LEVER BASE ASM
	131-15803	PRESSER LIFTING LEVER BASE
	131-15902	PRESSER LIFTING LEVER
	131-16009	PRESSER ARM STOPPER
	131-16108	PRESSER FOOT LIFTING SPRING
	SS-7110510-SP	SCREW 11/64-40 L=5
	SD-0640241-SP	HINGE SCREW D= 6.35 H= 2.4
	PS-0300142-KH	SPRING PIN 0.3 X 14
	SS-6080340-SP	SCREW 1/8-44 L=2.9
	131-16207	PRESSER FOOT SPRING
	131-17007	PRESSER LIFTING LEVER SCREW
	131-16306	PRESSER LIFTING LEVER SPRING
	131-16900	PRESSER LIFTING LEVER
	131-16405	PRESSER LIFTING HOOK
	131-16504	LIFTING LEVER ARM SPRING
	131-16603	PRESSER LIFTING LEVER SPRING
	NM-6060003-SC	NUT M6
	NS-6110420-SP	SCREW 11/64-40 L=7.8
	SM-6061200-SP	SCREW 11/64-40 L=14
	SS-7110840-SP	SCREW 11/64-40 L=4.5
	SS-7111410-TP	SCREW 11/64-40 L=7.8
	SS-8110520-TP	SCREW 11/64-40 L=14
	132-12600	PRESSER REGULATOR SCREW
	131-15654	PRESSER BAR ASM.
	122-88700	PRESSER REGULATOR SCREW WASHER
	131-17106	PRESSER REGULATOR NUT
	132-12709	PRESSER BAR COVER
	131-70402	RUBBER RING
	131-70402	RUBBER RING
	SN-8040402-TP	SCREW M4X0.7 L=4
	132-12501	PRESSER BAR BUSHING
	SS-6121020-SP	SCREW 3/16-28 L= 9.5
	132-12808	ADJUSTING BASE
	132-13012	ADJUSTING SCREW
	132-12915	ADJUSTING BLOCK
	131-23302	ADJUSTING SPRING
	SS-7150740-SP	SCREW 15/64-28 L=7
	WP-0460556-SD	WASHER 4.5X7.5X0.5
	RE-0300000-KO	E-RING 3
	SS-7161040-SP	SCREW 1/4-24 L= 9.5

Page 22 — 10. PRESSER FOOT COMPONENTS (2)

Juki MO-6716 (53 pages) parts on page 22

Ref	Part number	Part name	Qty
	1	PRESSER BAR GUIDE
	2	SPRING
	3	SCREW
	4	PRESSER FOOT
	5	PRESSER BAR
	6	SCREW
	7	PRESSER BAR HOLDER
	8	SCREW
	9	PRESSER BAR GUIDE
	10	PRESSER BAR GUIDE
	11	PLATE
	12	PRESSER FOOT
	13	SPRING
	14	SPRING
	15	PRESSER FOOT
	16	PLATE
	17	PLATE
	18	SPRING
	19	PRESSER FOOT
	20	PRESSER BAR GUIDE
	21	PRESSER BAR GUIDE
	22	SPRING
	23	SCREW
	24	PRESSER BAR GUIDE
	25	SCREW
	26	PLATE
	27	PRESSER FOOT
	28	SCREW
	29	SPRING
	30	PLATE
	31	SCREW
	32	PRESSER FOOT
	33	SPRING
	34	PLATE
	35	PRESSER FOOT
	36	SCREW
	37	PRESSER FOOT
	38	SPRING
	39	SCREW
	40	SCREW
	41	PRESSER FOOT
	42	SPRING
	43	SCREW
	44	PLATE
	45	PLATE
	46	PLATE
	47	SPRING
	48	PRESSER BAR GUIDE

Page 23

Juki MO-6716 (53 pages) parts on page 23

Ref	Part number	Part name	Qty
	122-53829	PURESSER FOOT ARM	1
	131-16702	THREAD TRIMMER	1
	SS-7060510-SP	SCREW 3/32-56 L=4.8	1
01	118-76166	PRESSER FOOT ASM.	1
	118-76009	PRESSER FOOT HINGE	1
	SS-6090670-TP	SCREW 9/64-40 L=6	(1)
	B1530-804-000	STOPPER	(1)
	WP-0250516-SD	WASHER 2.5X6X0.5	(1)
	SS-7060610-SP	SCREW 3/32-56 L=5.5	(1)
	SS-6060210-SP	SCREW 3/32-56 L=1.9	(1)
	B1511-814-000	REAR PRESSER FOOT	(1)
	B1507-804-C00	PRESSER FOOT	(1)
	SS-7080520-SP	SCREW 1/8-44 L=4.9	(1)
	B1508-804-00B	SPRING	(1)
	B1509-804-C00	STITCH TONGUE	(1)
	SS-6060440-TP	SCREW 3/32-56 L=3.5	(1)
	B1510-814-000	CURL GUARD	(1)
	131-78306	FINGER GUIDE	(1)
02	118-76869	PRESSER FOOT ASM.	1
	118-72009	PRESSER FOOT HINGE	(1)
	SS-6090670-TP	SCREW 9/64-40 L=6	(1)
	B1530-804-000	STOPPER	(1)
	WP-0250516-SD	WASHER 2.5X6X0.5	(1)
	SS-7060610-SP	SCREW 3/32-56 L=5.5	(1)
	SS-6060210-SP	SCREW 3/32-56 L=1.9	(1)
	B1511-814-000	REAR PRESSER FOOT	(1)
	B1507-814-00P	PRESSER FOOT	(1)
	SS-4080620-TP	SCREW 1/8-44 L=6	(1)
	B1508-804-00B	SPRING	(1)
	B1509-814-00P	STITCH TONGUE	(1)
	SS-6060440-TP	SCREW 3/32-56 L=3.5	(1)
	B1510-814-000	CURL GUARD	(1)
	131-78306	FINGER GUIDE	(1)
03	400-30533	PRESSER FOOT AUXILIARY PLATE	(1)
	121-53763	PRESSER FOOT ASM.	1
	SS-6090670-TP	SCREW 9/64-40 L=6	(1)
	121-64802	REAR PRESSER FOOT	(1)
	121-67805	SPRING, FOR REAR PRESSER FOOT	(1)
	B1513-816-000	NUT, FOR REAR PRESSER FOOT	(1)
	121-67409	HINGE PIN	(1)
	121-62202	PRESSER FOOT	(1)
	121-67607	PRESSER FOOT ARM SPRING	(1)
	121-67508	HINGE SCREW	(1)
	SS-6060340-SP	SCREW 3/32-56 L=2.5	(1)
	B1514-816-000	SCREW	(1)
	121-67706	PRESSER FOOT	(1)
	131-78405	FINGER GUIDE	(1)
	121-56907	PRESSER FOOT HINGE	(1)

Page 24 — 11. THREAD TENSION COMPONENTS

Juki MO-6716 (53 pages) parts on page 24

Ref	Part number	Part name	Qty
2	M0-6704S	THREAD TENSION COMPONENTS
3	M0-6704S	THREAD TENSION COMPONENTS
4	M0-6704S	THREAD TENSION COMPONENTS
29	M0-6704S	THREAD TENSION COMPONENTS
2	M0-6714S	THREAD TENSION COMPONENTS
3	M0-6714S	THREAD TENSION COMPONENTS
4	M0-6714S	THREAD TENSION COMPONENTS
2	M0-6716S	THREAD TENSION COMPONENTS
3	M0-6716S	THREAD TENSION COMPONENTS
4	M0-6716S	THREAD TENSION COMPONENTS
	1	THREAD TENSION COMPONENTS
	2	THREAD TENSION COMPONENTS
	3	THREAD TENSION COMPONENTS
	4	THREAD TENSION COMPONENTS
	5	THREAD TENSION COMPONENTS
	6	THREAD TENSION COMPONENTS
	7	THREAD TENSION COMPONENTS
	8	THREAD TENSION COMPONENTS
	9	THREAD TENSION COMPONENTS
	10	THREAD TENSION COMPONENTS
	11	THREAD TENSION COMPONENTS
	12	THREAD TENSION COMPONENTS
	13	THREAD TENSION COMPONENTS
	14	THREAD TENSION COMPONENTS
	15	THREAD TENSION COMPONENTS
	16	THREAD TENSION COMPONENTS
	17	THREAD TENSION COMPONENTS
	18	THREAD TENSION COMPONENTS
	19	THREAD TENSION COMPONENTS
	20	THREAD TENSION COMPONENTS
	21	THREAD TENSION COMPONENTS
	22	THREAD TENSION COMPONENTS
	23	THREAD TENSION COMPONENTS
	24	THREAD TENSION COMPONENTS
	25	THREAD TENSION COMPONENTS
	26	THREAD TENSION COMPONENTS
	27	THREAD TENSION COMPONENTS
	28	THREAD TENSION COMPONENTS
	30	THREAD TENSION COMPONENTS
	31	THREAD TENSION COMPONENTS
	32	THREAD TENSION COMPONENTS
	33	THREAD TENSION COMPONENTS
	34	THREAD TENSION COMPONENTS
	35	THREAD TENSION COMPONENTS
	36	THREAD TENSION COMPONENTS
	37	THREAD TENSION COMPONENTS
	38	THREAD TENSION COMPONENTS
	39	THREAD TENSION COMPONENTS
	40	THREAD TENSION COMPONENTS
	41	THREAD TENSION COMPONENTS
	42	THREAD TENSION COMPONENTS
	43	THREAD TENSION COMPONENTS
	44	THREAD TENSION COMPONENTS
	45	THREAD TENSION COMPONENTS
	46	THREAD TENSION COMPONENTS
	47	THREAD TENSION COMPONENTS
	48	THREAD TENSION COMPONENTS
	50	THREAD TENSION COMPONENTS

Page 25

Juki MO-6716 (53 pages) parts on page 25

Ref	Part number	Part name	Qty
	132-25008	CENTER THREAD GUIDE	1
	131-37559	THREAD TENSION SPRING COMPL.	(1)
	131-38359	THREAD TENSION SPRING COMPL.	(1)
	131-38656	THREAD TENSION SPRING COMPL.	(1)
	131-37807	THREAD TENSION SPRING, RED	(1)
	131-38508	THREAD TENSION SPRING, YELLOW	(1)
	131-38805	THREAD TENSION SPRING, BLUE	(1)
	131-37708	THREAD TENSION KNOB, RED	(1)
	131-38409	THREAD TENSION KNOB, YELLOW	(1)
	131-38706	THREAD TENSION KNOB, BLUE	(1)
	131-38904	THREAD TENSION BAR	(1)
	131-37609	THREAD TENSION DISK PRESSER	(1)
	131-37906	SPRING BUSHING	(1)
	131-38102	THREAD TENSION SPRING FELT	(1)
	131-38201	THREAD TENSION DISK	(2)
	131-38003	THREAD TENSION RUBBER WASHER	(1)
	SS-8110410-TP	SCREW 11/64-40 L=3.5	2
	132-25107	TENSION DISK THREAD GUIDE	3
	132-25107	TENSION DISK THREAD GUIDE	4
	131-39555	THREAD TENSION POST CONPL.	(1)
	131-40009	THREAD TENSION POST	(1)
	131-39605	TENSION DISK THREAD GUIDE	(1)
	131-39902	THREAD TENSION SPRING FELT	(1)
	131-39803	THREAD TENSION NUT	(1)
	131-39704	THREAD TENSION SPRING	(1)
	229-21407	ROTATION STOPPER	(1)
	131-38201	THREAD TENSION DISK	(2)
	PS-0200052-KH	SPRING PIN 2.3X5	1
	SS-7110710-SL	SCREW 11/64-40 L=7.0	1
	SS-4110615-SP	SCREW 11/64-40 L=6	2
	131-28202	THREAD CAM THREAD GUIDE BASE	(1)
	131-28301	THREAD CAM THREAD GUIDE A	(1)
	131-28400	THREAD CAM THREAD GUIDE B	(1)
	131-28509	LOWER THREAD CAM HOOK	(1)
	131-28608	LOWER THREAD GUIDE	(1)
	131-28707	THREAD GUIDE BASE SPRING	(1)
	131-28805	LOOPER THREAD CAM COMPL.	(1)
	131-29457	LOWER THREAD CAM COMPL.	(1)
	B2202-816-000	SHAFT	(1)
	131-29101	LOWER THREAD CONDUIT GUIDE	(1)
	131-29200	MOUNTING BRACKET	(1)
	SD-0600341-TP	HINGE SCREW D=6.0 H=3.4	(1)
	WZ-0640312-KO	WAVED WASHER	(1)
	SM-4050855-SP	SCREW M5 L=8	(1)
	SS-4090415-SP	SCREW 9/64-40 L=4	(1)
	SS-4090415-SP	SCREW 9/64-40 L=4	(1)
	SS-4090415-SP	SCREW 9/64-40 L=4	(1)
	SS-4090415-SP	SCREW 9/64-40 L=4	(1)
	SS-4110515-SP	SCREW 11/64-40 L=5	(1)
	SS-5150510-SP	SCREW 15/64-28 L=5	(1)

Page 26 — 12. LOWER KNIFE COMPONENTS

Juki MO-6716 (53 pages) parts on page 26

Ref	Part number	Part name	Qty
1	1	LOWER KNIFE COMPONENTS
2	2	LOWER KNIFE COMPONENTS
3	3	LOWER KNIFE COMPONENTS
4	4	SCREW
5	5	BRACKET
6	6	SCREW
7	7	BRACKET
8	8	SCREW
9	9	SPRING
10	10	SPRING
11	11	BRACKET
12	12	SCREW
13	13	SCREW
14	14	SPRING
15	15	BRACKET
16	16	BRACKET
17	17	SCREW
18	18	WASHER
19	19	SCREW
20	20	PIN
21	21	SCREW
22	22	BRACKET
23	23	SCREW
24	24	BRACKET
25	25	SCREW
26	26	PIN
27	27	BRACKET
28	28	PIN
29	29	SHAFT
30	30	SCREW
31	31	BRACKET
32	32	SPRING
33	33	PIN
34	34	SCREW
35	35	BRACKET
36	36	SCREW
37	37	BRACKET
38	38	BRACKET
39	39	BRACKET
40	40	BRACKET
41	41	BRACKET
42	42	SCREW
43	43	SCREW
44	44	SCREW
45	45	BLADE
46	46	WASHER

Page 27

Juki MO-6716 (53 pages) parts on page 27

Ref	Part number	Part name	Qty
	R4200-J6E-D00	THROAT PLATE
	R4305-J6E-E00	THROAT PLATE
	R4508-J6E-D00	THROAT PLATE
	SS-2110910-SL	SCREW 11/64-40 L=9
	131-51204	THROAT PLATE BASE B
	SS-6110610-TP	SCREW 11/64-40 L=6
	122-88908	THROAT PLATE BASE B SUPPORT
	SM-4051055-SP	SCREW
	123-47167	LOWER KNIFE BRACKET ASM.
	123-47266	LOWER KNIFE BRACKET ASM.
	121-33211	SPRING STOPPER
	118-06304	PLUG
	SS-7110720-SP	SCREW 11/64-40 L=7
	118-46607	SPRING
	121-32619	LOWER KNIFE BRACKET
	121-02208	THROAT PLATE BASE A
	SS-6110610-TP	SCREW 11/64-40 L=6
	121-03701	RUBBER PLUG B
	132-35304	RUBBER PLUG A
	121-32700	LOWER KNIFE SLIDE STUD
	SS-9111010-SP	SCREW 11/64-40 L=9.5
	121-33104	LOWER KNIFE PRESSER PLATE
	121-02810	LEVER SHAFT
	121-32908	ROTATING STOPPER
	SS-7090710-SP	SCREW 9/64-40 L=6.8
	121-32809	LOWER KNIFE SLIDE STUD
	121-33005	ROTATING STOPPER
	118-46805	HOLDER PIN
	121-03107	RUBBER PLUG
	SS-7151120-SP	SCREW 15/64-28 L=11
	121-02950	LEVER ASM.
	118-02006	LEVER SPRING
	118-46805	HOLDER PIN
	SS-6151440-SP	SCREW 15/64-28 L=14
	131-51105	NEEDLE HOLDER SUPPORT
	SS-7110840-SP	SCREW 11/64-40 L=7.8
	118-90100	NEEDLE GUARD
	118-90308	NEEDLE GUARD
	120-15400	NEEDLE HOLDER
	121-77903	NEEDLE HOLDER
	121-77903	NEEDLE HOLDER
	SS-7090510-SP	SCREW 9/64-40 L=4.6
	SS-7060510-SP	SCREW 3/32-56 L=4.8
	SS-7090610-SP	SCREW 9/64-40 L=6
	131-50701	LOWER KNIFE
	131-02702	THROAT PLATE COVER

Page 28 — 13. UPPER KNIFE COMPONENTS

Juki MO-6716 (53 pages) parts on page 28

Ref	Part number	Part name	Qty
	131-47558	FEED FORKED ARM ASM.	1
	131-47509	FEED FORKED ARM	1
	SM-6061402-TP	SCREW M6 L=14	1
	131-51303	KNIFE DRIVING ARM SHAFT	1
	131-50909	BUSHING, FRONT	1
	131-51006	BUSHING, REAR	1
7	131-47400	PLAIN KNIFE SUPPORT A	1
8	SS-6111040-SP	SCREW 11/64-40 L= 9.5	1
9	131-47301	PLAIN KNIFE SUPPORT	1
10	SS-6111610-SP	SCREW 11/64-40 L=16	1
11	131-50800	UPPER KNIFE GUIDE SHAFT	1
12	115-66809	OIL SEAL	1
13	131-22007	CRANK PIN A	1
14	131-22106	CRANK PIN B	1
15	131-22205	CRANK PIN C	1
16	131-22304	CRANK PIN D	1
17	131-50503	PLAIN KNIFE	1
18	131-50602	PLAIN KNIFE	1
19	SS-9090823-TP	BOLT 9/64-40 L=8	1
20	WP-0370316-SD	WASHER 3.7X8X0.3	1
21	CS-1111019-SH	THRUST COLLAR D=11.11 W=10	(1)
22	CS-1111019-SH	THRUST COLLAR D=11.11 W=10	(1)
23	SS-8660330-SP	SCREW 1/4-40 L= 3.0	(1)

Page 29 — 14. NEEDLE COOLING MECHANISM COMPONENTS (FOR SH)

Juki MO-6716 (53 pages) parts on page 29

Ref	Part number	Part name	Qty
	131-63456	SILICON TANK ASM.	1
	131-63803	NEEDLE THREAD FELT	1
	131-63902	NEEDLE THREAD FELT PRESSER	1
	TA-0950806-RO	RUBBER PLUG	1
	SM-4040855-SP	SCREW	1
	131-62557	NEEDLE COOLER UNIT ASM. (OVER)	(1)
	131-62565	NEEDLE COOLER UNIT COMPL.	(1)
	131-62573	NEEDLE COOLER UNIT ASM. (OVER)	(1)
	131-62805	NEEDLE COOLER SUPPORT	(1)
	SS-7090610-SP	SCREW 9/64-40 L=6	(1)
	131-62904	TANK	(1)
	131-63001	TANK COVER	(1)
	SS-4091015-SP	SCREW 9/64-40 L=10	1
	WP-0371026-SD	WASHER 3.7X7X1	1
	131-63159	NEEDLE COOLER UNIT ASM. (INTER)	1
	131-63167	NEEDLE COOLER COMPL. (INTER)	(1)
	131-63175	NEEDLE COOLER ASM. (INTER)	(1)
	131-62805	NEEDLE COOLER SUPPORT	(1)
	SS-7090610-SP	SCREW 9/64-40 L=6	(1)
	131-62904	TANK	(1)
	131-63001	TANK COVER	(1)
	SS-4091015-SP	SCREW 9/64-40 L=10	1
	WP-0371026-SD	WASHER 3.7X7X1	1
	SS-7110840-SP	SCREW 11/64-40 L=7.8	1

Page 30 — 15. LUBRICATION MECHANISM COMPONENTS

Juki MO-6716 (53 pages) parts on page 30

Ref	Part number	Part name	Qty
1	1	CAP
2	2	FILTER
3	3	BODY
4	4	FILTER
5	5	SCREW
6	6	SHAFT
7	7	GEAR
8	8	GEAR
9	9	PIN
10	10	PLATE
11	11	PLATE
12	12	SCREW
13	13	SCREW
14	14	SCREW
15	15	SCREW
16	16	PLATE
17	17	BODY
18	18	SHAFT
19	19	BRACKET
20	20	BODY
21	21	BODY
22	22	WASHER
23	23	TUBE
24	24	TUBE
25	25	FILTER
26	26	SCREW
27	27	BRACKET
28	28	SCREW
29	29	SHAFT
30	30	WASHER
31	31	SCREW
32	32	NUT
33	33	BODY
34	34	O-RING
35	35	SCREW
36	36	SCREW
37	37	SCREW
38	38	SPRING
39	39	SHAFT
40	40	BLOCK
41	41	PIN
42	42	PIN
43	43	BODY
44	44	BLOCK
45	45	PIN
46	46	BODY
47	47	SPRING
48	48	BLOCK
49	49	SCREW
50	50	SCREW
51	51	BRACKET
52	52	NUT
53	53	NUT
54	54	TUBE
55	55	BRACKET
56	56	SCREW
57	57	BLOCK
58	58	BAR
59	59	SPRING
60	60	SCREW
61	61	SHAFT
62	62	TUBE
63	63	BODY
64	64	CAP

Page 31

Juki MO-6716 (53 pages) parts on page 31

Ref	Part number	Part name	Qty
	132-30305	WORM
	400-18044	OIL PUMP ASM.
	123-15909	OIL PUMP
	133-43009	WORM WHEEL
	SM-8050412-TP	SCREW M5 L=4
	119-18109	GEAR PUMP SHAFT LARGE
	B3534-352-000	PINION GEAR
	118-40303	OIL PUMP PINION
	123-17004	GEAR PUMP SHAFT
	123-16006	PINION SPACER
	123-16105	CASING
	400-16762	PUMP COVER
	SS-4112215-SP	SCREW 11/64-40 L=22
	SS-6090810-SP	SCREW 9/64-40 L=7.5
	SQ-1110401-MZ	CONNECTING SCREW
	400-16763	PUMP NET
	132-29356	FLOAT ASM.
	121-29904	OIL GAUGE BAR
	132-29307	FLOAT SUPPORT
	121-29805	FLOAT
	SM-6061802-TP	SCREW M6 L=18
	WP-0651056-SD	WASHER 6.5X11X1
	132-28655	LUBRICATION MECHANISM PIPE ASM.
	BP-3000001-OR	VINYL PIPE
	131-42500	CARTRIDGE FILTER
	SQ-1150454-SD	CONNECTING SCREW
	131-43805	EXHAUST PORT SUPPORT
	SM-4060855-SP	SCREW
	131-43300	OIL GAUGE
	131-44001	OIL GAUGE GASKET
	SQ-1110451-MZ	CONNECTING SCREW
	NS-6110310-SP	NUT 11/64-40
	131-42955	FILTER GUIDE ASM.
	131-70808	RUBBER RING
	SM-4051601-SC	SCREW M5X0.8 L=16
	SQ-1110451-MZ	CONNECTING SCREW
	SQ-1150451-MZ	CONNECTING SCREW
	131-42609	OIL TUBE HOLDER
	131-44100	OILING PIN
	131-44209	OIL FELT
	TA-0400301-MO	PLUG D=4X4.5 L=3
	SM-8050502-TP	SCREW M5 L=5
	131-43417	UPPER LOOPER OILING PIN
	131-43508	OIL FELT
	132-30107	UPPER LOOPER OILING PIN PLUG
	SS-6121020-SP	SCREW 3/16-28 L=9.5
	131-43607	OIL FELT PRESSER
	131-43706	OIL FELT
	SS-7060310-SP	SCREW 3/32-56 L=3
	SQ-1150441-SD	CONNECTING SCREW
	132-29208	WORM EXHAUST PORT GUIDE
	NS-6110310-SP	NUT 11/64-40
	SQ-1110451-MZ	CONNECTING SCREW
	236-30007	TUBE
	132-28804	OIL FELT GUIDE
	310-18005	SCREW
	132-29109	OIL FELT B
	132-29406	OIL FELT A
	132-28903	OIL FELT PRESSER
	310-18005	SCREW
	132-29000	FELT PRESSER SPACER
	BP-3000001-OR	VINYL PIPE
	SQ-0000451-MZ	CONNECTING SCREW
	SM-4060801-SE	SCREW

Page 32 — 16. SEMI-SUNKEN TYPE TABLE COMPONENTS

Juki MO-6716 (53 pages) parts on page 32

Ref	Part number	Part name	Qty
	131-61005	CASE SPONGE
	131-60908	COOLING FAN CASE
	131-61153	FRAME SUPPORT PLATE ASM.
01	123-41954	CLOTH WASTE CHUTE ASM.
	123-41905	CLOTH WASTE CHUTE(SEMI-SUNKEN)
	123-41806	CLOTH WASTE CHUTE
02	131-55759	CLOTH WASTE CHUTE ASM.
	131-55601	CLOTH WASTE CHUTE INLET
	131-55700	CLOTH WASTE CHUTE, UPPER
	131-55502	CHUTE SUPPORT
	SS-5090610-SP	SCREW 9/64-40 L=6
	NS-609040-SP	NUT 9/64-40
	131-55403	DUST-PROOF RUBBER
	131-56500	DUST-PROOF RUBBER SPACER
	131-55007	HOLDING PLATE BOLT
02	123-41806	CLOTH WASTE CHUTE
02	SS-5110710-SP	SCREW 11/64-40 L=7
02	SK-2351600-SC	WOOD SCREW D=3.5 L=16
	111-55108	DRAWER
	111-55207	DRAWER SUPPORT
	119-59400	TABLE (SEMI-SUNKEN)
	D8204-555-D00	DRAWER STOPPER
	NS-6240630-SE	NUT 3/8-18
01	SK-2351600-SC	WOOD SCREW D=3.5 L=16
	SK-3311500-SC	WOOD SCREW D=3.1 L=15
	SK-3513200-SC	WOOD SCREW D=5.1 L=32
	SS-6090630-TP	SCREW 9/64-40 G=6
	WP-1002036-SE	WASHER 10X21X2
	WS-1002560-KR	SPRING WASHER 10X18X2.5

Page 33 — 17. FULLY-SUNKEN TYPE TABLE COMPONENTS

Juki MO-6716 (53 pages) parts on page 33

Ref	Part number	Part name	Qty
	131-61005	CASE SPONGE	1
	131-60908	CLOTH FAN CASE	2
	SS-5110710-SP	SCREW 11/64-40 L=7	2
4	SK-2351600-SC	WOOD SCREW D=3.5 L=16	3
5	131-55858	CLOTH WASTE CHUTE ASM.	(1)
	131-56203	CLOTH WASTE CHUTE	(1)
	131-56302	CLOTH WASTE CHUTE INLET	(1)
	131-55908	CHUTE INLET LEVER	(1)
	131-56104	CHUTE INLET SPRING	(1)
	131-56104	CHUTE INLET RUBBER	(1)
	SS-6090420-SP	SCREW 9/64-40 L=4.0	(2)
	ST-6030821-0A	SCREW D=3-24 L=8	(2)
	ST-6030821-0A	SCREW D=3-24 L=8	(1)
	WP-0370316-SD	WASHER 3.7X8X0.3	(1)
	119-59558	TABLE ASM.	1
	131-55403	DUST-PROOF RUBBER	4
	131-55106	HOLDING PLATE BOLT C	2
	131-55205	HOLDING PLATE BOLT D	2
19	131-55759	CLOTH WASTE CHUTE ASM.	(1)
	131-55601	CLOTH WASTE CHUTE INLET	(1)
	131-55700	CLOTH WASTE CHUTE, UPPER	(1)
	131-55502	CHUTE SUPPORT	(1)
	SS-5090610-SP	SCREW 9/64-40 L=6	(3)
	NS-6090310-SP	NUT 9/64-40	(3)
25	123-41806	CLOTH WASTE CHUTE	1
	131-61153	FRAME SUPPORT PLATE ASM.	1
	131-55304	FRAME HOLDING PLATE COUPLING	1
	SM-9082513-CF	SCREW M8 L=25	4
	NM-6080600-SM	NUT M8	4
	WP-0850002-SC	WASHER 8.5X18X1.6	4
	SK-3313200-SC	WOOD SCREW D=5.1 L=32	4
	111-55108	DRAWER	1
	111-55207	DRAWER SUPPORT	2
	D8204-555-D00	DRAWER STOPPER	1
	SK-3311500-SC	WOOD SCREW D=3.1 L=15	6
	WS-1002560-KR	SPRING WASHER 10X18X2.5	5
	SS-6090630-TP	SCREW 9/64-40 L=6	5
	SS-5110710-SP	SCREW 11/64-40 L=7	12
	WP-1002036-SE	WASHER 10X21X2	12
	NS-6240630-SE	NUT 3/8-18	12

Page 34 — 18. STAND COMPONENTS (Z T)

Juki MO-6716 (53 pages) parts on page 34

Ref	Part number	Part name	Qty
	1	STAND COMPONENTS (Z T)
	2	STAND COMPONENTS (Z T)
	3	STAND COMPONENTS (Z T)
	4	STAND COMPONENTS (Z T)
	5	STAND COMPONENTS (Z T)
	6	STAND COMPONENTS (Z T)
	7	STAND COMPONENTS (Z T)
	8	STAND COMPONENTS (Z T)
	9	STAND COMPONENTS (Z T)
	10	STAND COMPONENTS (Z T)
	11	STAND COMPONENTS (Z T)
	12	STAND COMPONENTS (Z T)
	13	STAND COMPONENTS (Z T)
	14	STAND COMPONENTS (Z T)
	15	STAND COMPONENTS (Z T)
	16	STAND COMPONENTS (Z T)
	17	STAND COMPONENTS (Z T)
	18	STAND COMPONENTS (Z T)
	19	STAND COMPONENTS (Z T)
	20	STAND COMPONENTS (Z T)
	21	STAND COMPONENTS (Z T)
	22	STAND COMPONENTS (Z T)
	23	STAND COMPONENTS (Z T)
	24	STAND COMPONENTS (Z T)
	25	STAND COMPONENTS (Z T)
	26	STAND COMPONENTS (Z T)
	27	STAND COMPONENTS (Z T)
	28	STAND COMPONENTS (Z T)
	29	STAND COMPONENTS (Z T)
	30	STAND COMPONENTS (Z T)
	31	STAND COMPONENTS (Z T)
	32	STAND COMPONENTS (Z T)
	33	STAND COMPONENTS (Z T)
	34	STAND COMPONENTS (Z T)
	35	STAND COMPONENTS (Z T)
	36	STAND COMPONENTS (Z T)
	37	STAND COMPONENTS (Z T)
	38	STAND COMPONENTS (Z T)
	39	STAND COMPONENTS (Z T)
	40	STAND COMPONENTS (Z T)

Page 35

Juki MO-6716 (53 pages) parts on page 35

Ref	Part number	Part name	Qty
	119-60655	T STAND JUNCTION	1
	111-57567	T LEG JUNCTION	(1)
	GPF-06060000	PEDAL	(1)
	GPF-06070000	PEDAL MAT	(1)
	GPF-06080000	PEDAL ADJUSTING PLATE	(1)
	111-59001	PEDAL SHAFT BRACKET	(2)
	D8113-555-B00	PEDAL BUSHING	(2)
	B8153-771-000	PEDAL CONNECTING ROD	(1)
	NM-6080001-SE	NUT M8	(2)
	SL-9082091-SE	WASHER HEXAGONAL BOLT	(2)
	WP-0871602-SE	WASHER 8.7X18X1.6	(2)
	SL-9061291-SE	WASHER HEXAGONAL BOLT M6 L=12	(2)
	119-60754	T STAND JUNCTION(WITH CASTER)	1
	111-59365	T STAND JUNCTION	(1)
	GPF-06060000	PEDAL	(1)
	GPF-06070000	PEDAL MAT	(1)
	GPF-06080000	PEDAL ADJUSTING PLATE	(1)
	111-59001	PEDAL SHAFT BRACKET	(2)
	D8113-555-B00	PEDAL BUSHING	(2)
	B8153-771-000	PEDAL CONNECTING ROD	(1)
	NM-6080001-SE	NUT M8	(2)
	SL-9082091-SE	WASHER HEXAGONAL BOLT	(2)
	WP-0871602-SE	WASHER 8.7X18X1.6	(2)
	SL-9061291-SE	WASHER HEXAGONAL BOLT M6 L=12	(2)
	B7114-012-0A0	MOTOR CONNECTING ROD ASM.	1
	111-51065	Z LEG JUNCTION (B)	1
	B8151-771-0A0	PEDAL ASM.	1
	SM-9082023-SE	SCREW M8 L=20	(2)
	WS-0861410-KR	SPRING WASHER 8.6X15X1.4	(2)
	WP-0871602-SE	WASHER 8.7X18X1.6	(4)
	111-51909	PEDAL SHAFT BRACKET	(2)
	NM-6080721-SE	NUT M8	(2)
	D8113-555-B00	PEDAL BUSHING	(2)
	SM-9061203-SE	SCREW M6 L=12	(2)
	WS-0621210-KR	SPRING WASHER 6.2X11.4X1.2	(2)
	WP-0671016-SE	WASHER 6.7X13X1	(2)
	112-46600	PEDAL ADJUSTING PLATE	(1)
	112-46501	PEDAL	(1)
	B8152-771-000	PEDAL MAT	(1)
	B8153-771-000	PEDAL CONNECTING ROD	(1)

Page 36 — 19. THREAD STAND COMPONENTS (FOR MO-6704S,MO-6714S)

Juki MO-6716 (53 pages) parts on page 36

Ref	Part number	Part name	Qty
	1	THREAD STAND COMPONENTS
	2	MAIN SHAFT BRACKET
	3	BRACKET
	4	CLAMP
	5	CAP
	6	SHAFT
	7	BRACKET
	8	BRACKET
	9	BRACKET
	10	ARM
	11	BRACKET
	12	SHAFT
	13	THREAD GUIDE
	14	SHAFT
	15	WASHER
	16	WASHER
	17	SCREW
	18	SCREW
	19	SCREW
	20	SCREW
	21	SCREW
	22	SCREW
	23	SCREW
	24	NUT
	25	WASHER
	26	WASHER
	27	WASHER
	28	NUT
	29	NUT

Page 37

Juki MO-6716 (53 pages) parts on page 37

Ref	Part number	Part name	Qty
1	131-67556	THREAD STANDING DEVICE ASM.
2	229-30556	SPOOL REST ARM ASM.
3	229-30507	SPOOL REST ARM
4	229-30705	THREAD GUIDE ARM JOINT
5	229-31406	THREAD STANDING ROD RUBBER CAP
6	229-30408	THREAD STANDING ROD, UPPER
7	229-31307	THREAD STANDING ROD JOINT
8	131-67903	THREAD STANDING THREAD GUIDE
9	131-68000	THREAD STANDING GUIDE BASE
10	131-68109	THREAD STANDING GUIDE ARM
11	131-68208	THREAD STANDING GUIDE ARM BASE
12	229-30309	THREAD STANDING ROD, LOWER
13	229-31109	SPOOL RETAINER
14	229-31000	SPOOL PIN
15	229-30903	SPOOL REST CUSHION
16	229-30804	SPOOL REST
17	SM-6061610-SC	SCREW M6 L=16
18	SM-4051405-SE	SCREW M5 L=14
19	NM-6050001-SE	NUT M5
20	SM-4041001-SC	SCREW M4X0.7 L=10
21	NM-6040002-SE	NUT M4X0.7
22	SM-4041201-SC	SCREW M4 L=12
23	SM-4042001-SC	SCREW M4 X 20
24	NM-6040002-SE	NUT M4X0.7
25	WP-1612616-SE	WASHER 16X30X2.6
26	WS-1643202-KR	SPRING WASHER
27	NM-6160511-SE	NUT M16X1.5
28	NM-6050001-SE	NUT M5
29	WS-0510002-KN	SPRING WASHER

Page 38 — 20. THREAD STAND COMPONENTS (MO-6704S,MO-6714S SPECIAL ORDER PARTS)

Juki MO-6716 (53 pages) parts on page 38

Ref	Part number	Part name	Qty
	1	THREAD STAND COMPONENTS
	2	THREAD STAND COMPONENTS
	3	THREAD STAND COMPONENTS
	4	THREAD STAND COMPONENTS
	5	CLAMP
	6	COLLAR
	7	COLLAR
	8	BRACKET
	9	THREAD STAND COMPONENTS
	10	BRACKET
	11	THREAD STAND COMPONENTS
	12	BRACKET
	13	THREAD STAND COMPONENTS
	14	THREAD STAND COMPONENTS
	15	THREAD STAND COMPONENTS
	16	WASHER
	17	WASHER
	18	BRACKET
	19	SCREW
	20	SCREW
	21	SCREW
	22	SCREW
	23	SCREW
	24	SCREW
	25	SCREW
	26	SCREW
	27	WASHER
	28	WASHER
	29	WASHER
	30	NUT
	31	NUT
	32	SCREW
	33	SCREW
	34	NUT

Page 39

Juki MO-6716 (53 pages) parts on page 39

Ref	Part number	Part name	Qty
	131-67754	THREAD STANDING DEVICE ASM.	1
	131-68851	THREAD STANDING ARM ASM., LONG	(2)
	131-68505	THREAD GUIDE ARM B	(1)
	131-68802	THREAD STANDING ARM, LONG	(2)
	229-30705	THREAD GUIDE ARM JOINT	(4)
	229-31406	THREAD STANDING ROD RUBBER CAP	(1)
	229-30408	THREAD STANDING ROD, UPPER	(1)
	229-31307	THREAD STANDING ROD JOINT	(1)
	131-67903	THREAD GUIDE	(1)
	131-68000	THREAD GUIDE BASE, LOWER	(1)
	131-68109	THREAD GUIDE ARM	(1)
	131-68208	THREAD GUIDE ARM BASE	(1)
	229-30309	THREAD STANDING ROD, LOWER	(1)
	229-31109	SPOOL RETAINER	(4)
	229-31000	SPOOL PIN	(4)
	229-30903	SPOOL REST CUSHION	(4)
	229-30804	SPOOL REST	(1)
	131-68406	THREAD STANDING ARM SUPPORT, A	(4)
	SM-6061610-SC	SCREW M6 L=16	(2)
	SM-4051405-SE	SCREW M5 L=14	(2)
	NM-6050001-SE	NUT M5	(2)
	SM-4041001-SC	SCREW M4X0.7 L=10	(2)
	NM-6040002-SE	NUT M4X0.7	(2)
	SM-4041201-SC	SCREW M4 L=12	(1)
	SM-4042001-SC	SCREW M4 X 20	(1)
	NM-6040002-SE	NUT M4X0.7	(2)
	WP-1612616-SE	WASHER 16X30X2.6	(2)
	WS-1643202-KR	SPRING WASHER	(1)
	NM-6160511-SE	NUT M16X1.5	(1)
	NM-6050001-SE	NUT M5	(4)
	WS-0510002-KN	SPRING WASHER	(4)
	SK-3382001-SE	SCREW D=3.8 L=20	(2)
	SM-4061201-SE	SCREW M6 L=12	(2)
	NM-6060001-SE	NUT M6	(2)

Page 40 — 21. THREAD STAND COMPONENTS (FOR MO-6716S)

Juki MO-6716 (53 pages) parts on page 40

Ref	Part number	Part name	Qty
1	1	THREAD STAND COMPONENTS
2	2	THREAD STAND COMPONENTS
3	3	THREAD STAND COMPONENTS
4	4	THREAD STAND COMPONENTS
5	5	CLAMP
6	6	THREAD GUIDE
7	7	THREAD GUIDE
8	8	THREAD GUIDE
9	9	THREAD GUIDE
10	10	THREAD GUIDE
11	11	THREAD GUIDE
12	12	THREAD GUIDE
13	13	THREAD GUIDE
14	14	THREAD GUIDE
15	15	THREAD GUIDE
16	16	THREAD GUIDE
17	17	THREAD GUIDE
18	18	SCREW
19	19	SCREW
20	20	SCREW
21	21	SCREW
22	22	SCREW
23	23	SCREW
24	24	SCREW
25	25	SCREW
26	26	WASHER
27	27	WASHER
28	28	WASHER
29	29	NUT
30	30	NUT
31	31	NUT

Page 41

Juki MO-6716 (53 pages) parts on page 41

Ref	Part number	Part name	Qty
	131-67655	THREAD STANDING DEVICE ASM.	(1)
	229-30556	THREAD STANDING ARM ASM.	(1)
	131-68356	THREAD STANDING ARM ASM., LONG	(1)
	229-30507	THREAD STANDING ARM	(1)
	229-30705	THREAD GUIDE ARM JOINT	(4)
	229-31406	THREAD STANDING ROD RUBBER CAP	(1)
	229-30408	THREAD STANDING ROD, UPPER	(1)
	229-31307	THREAD STANDING ROD JOINT	(1)
	131-67903	THREAD GUIDE	(1)
	131-68000	THREAD GUIDE BASE, LOWER	(1)
	131-68109	THREAD GUIDE ARM	(1)
	131-68208	THREAD GUIDE ARM BASE	(1)
	229-30309	THREAD STANDING ROD, LOWER	(1)
	229-31109	SPOOL RETAINER	(5)
	229-31000	SPOOL PIN	(5)
	229-30903	SPOOL REST CUSHION	(5)
	229-30804	SPOOL REST	(5)
	SM-6061610-SC	SCREW M6 L=16	(4)
	SM-4051405-SE	SCREW M5 L=14	(2)
	NM-6050001-SE	NUT M5	(2)
	SM-4041001-SC	SCREW M4X0.7 L=10	(2)
	NM-6040002-SE	NUT M4X0.7	(2)
	SM-4041201-SC	SCREW M4 L=12	(1)
	SM-4042001-SC	SCREW M4 X 20	(1)
	NM-6040002-SE	NUT M4X0.7	(2)
	WP-1612616-SE	WASHER 16X30X2.6	(2)
	WS-1643202-KR	SPRING WASHER	(1)
	NM-6160511-SE	NUT M16X1.5	(1)
	NM-6050001-SE	NUT M5	(5)
	WS-0510002-KN	SPRING WASHER	(5)
	131-68307	THREAD STANDING ARM, LONG	(1)

Page 42 — 22. THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)

Juki MO-6716 (53 pages) parts on page 42

Ref	Part number	Part name	Qty
	1	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	2	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	3	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	4	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	5	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	6	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	7	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	8	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	9	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	10	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	11	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	12	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	13	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	14	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	15	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	16	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	17	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	18	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	19	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	20	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	21	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	22	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	23	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	24	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	25	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	26	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	27	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	28	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	29	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	30	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	31	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	32	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	33	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	34	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	35	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)
	36	THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)

Page 43

Juki MO-6716 (53 pages) parts on page 43

Ref	Part number	Part name	Qty
	131-67853	THREAD STANDING DEVICE ASM.	1
	131-68851	THREAD STANDING ARM ASM., LONG	(2)
	131-68505	THREAD STANDING ARM SUPPORT B	(1)
	131-68802	THREAD STANDING ARM, LONG	(2)
	229-30705	THREAD GUIDE ARM JOINT	(6)
	229-31406	THREAD STANDING ROD RUBBER CAP	(1)
	229-30408	THREAD STANDING ROD, UPPER	(1)
	229-31307	THREAD STANDING ROD JOINT	(1)
	131-67903	THREAD STANDING THREAD GUIDE	(1)
	131-68000	THREAD GUIDE BASE, LOWER	(1)
	131-68109	THREAD GUIDE ARM BASE	(1)
	131-68208	THREAD GUIDE ARM BASE	(1)
	229-30309	THREAD STANDING ROD, LOWER	(1)
	229-31109	SPOOL RETAINER	(5)
	229-31000	SPOOL PIN	(5)
	229-30903	SPOOL REST CUSHION	(5)
	229-30804	SPOOL REST	(5)
	131-68406	THREAD STANDING ARM SUPPORT A	(1)
	131-68950	THREAD STANDING ARM A ASM.	(1)
	SM-6061610-SC	SCREW M6 L=16	(6)
	SM-4051405-SE	SCREW M5 L=14	(2)
	NM-6050001-SE	NUT M5	(2)
	SM-4041001-SC	SCREW M4X0.7 L=10	(2)
	NM-6040002-SE	NUT M4X0.7	(2)
	SM-4041201-SC	SCREW M4 L=12	(1)
	SM-4042001-SC	SCREW M4 X 20	(1)
	NM-6040002-SE	NUT M4X0.7	(2)
	WP-1612616-SE	WASHER 16X30X2.6	(2)
	WS-1643202-KR	SPRING WASHER	(1)
	NM-6160511-SE	NUT M16X1.5	(1)
	NM-6050001-SE	NUT M5	(5)
	WS-0510002-KN	SPRING WASHER	(5)
	SK-3382001-SE	SCREW D=3.8 L=20	(2)
	SM-4061201-SE	SCREW M6 L=12	(2)
	NM-6060001-SE	NUT M6	(2)
	131-68901	THREAD STANDING ARM A	(1)

Page 44 — 23. SPECIAL ORDER PARTS COMPONENTS

Juki MO-6716 (53 pages) parts on page 44

Ref	Part number	Part name	Qty
	1	1
	2	2
	3	3
	5	5
	12	12
	11	11
	6	6
	64	64
	7	7
	20	20
	10	10
	13	13
	14	14
	15	15
	16	16
	18	18
	17	17
	19	19
	8	8
	4	4
	9	9
	22	22
	21	21
	23	23
	24	24
	26	26
	25	25
	27	27
	28	28
	29	29
	30	30
	31	31
	32	32
	33	33
	34	34
	35	35
	36	36
	37	37
	38	38
	39	39
	40	40
	41	41
	42	42
	43	43
	44	44
	55	55
	45	45
	48	48
	46	46
	49	49
	52	52
	54	54
	51	51
	53	53
	47	47
	50	50
	59	59
	58	58
	60	60
	56	56
	57	57
	62	62
	61	61
	63	63

Page 45

Juki MO-6716 (53 pages) parts on page 45

Ref	Part number	Part name	Qty
	SS-8080322-TP	SCREW 1/8-44 L=3.2	1
	SS-8080322-TP	SCREW 1/8-44 L=3.2	2
	B9112-804-000	SPANNER	1
	121-20713	CHAIN LOOPER	1
	115-44707	UPPER LOOPER SUPPORT ARM	1
01	118-98103	PRESSER FOOT AUXILIARY PLATE	1
	121-23709	LOWER LOOPER SUPPORT ARM	1
03	B2519-804-000	UPPER LOOPER	1
04	B2519-814-000	UPPER LOOPER	1
	B2521-804-000	LOWER LOOPER	1
01	SS-4080620-TP	SCREW 1/8-44 L=6	1
	SS-6080410-SP	SCREW 1/8-44 L=4	1
	118-47605	LOWER KNIFE	1
	119-64509	CERAMIC LOWER KNIFE	1
	119-92005	LOWER KNIFE	1
	119-65753	PEDAL ASM.	1
	SM-9061203-SE	SCREW M6 L=12	(2)
	119-65704	PEDAL	(2)
	119-65803	PEDAL THRUST COLLAR	(2)
	PS-0200062-KH	SPRING PIN 2X6	1
05	121-05458	CLOTH PLATE ASM.	(1)
	121-04550	CLOTH PLATE ASM.	(1)
	115-01301	ECCENTRIC BUSHING	(1)
	WZ-0420350-KP	DISC SPRING	(1)
	CS-0400671-SD	THRUST HOLDER	(1)
	SM-8040302-TP	SETSCREW	(1)
05	119-49104	CLOTH BASE COVER	1
01	B1539-804-000	PRESSER FOOT FIXING PLATE	1
01	SS-6060410-TP	SCREW 3/32-56 L=3.5	1
04	121-52468	PRESSER FOOT, (FINGER GUARD).	1
	118-72009	PRESSER FOOT HINGE	(1)
	SS-6090670-TP	SCREW 9/64-40 L=6	(1)
	B1530-804-000	STOPPER	(1)
	WP-0250516-SD	WASHER 2.5X6X0.5	(1)
	SS-7060610-SP	SCREW 3/32-56 L=5.5	(1)
	SS-6060210-SP	SCREW 3/32-56 L=1.9	(1)
	B1511-814-000	REAR PRESSER FOOT	(1)
	B1507-814-00P	PRESSER FOOT	(1)
	SS-7080520-SP	SCREW 1/8-44 L=4.9	(1)
	B1508-804-00B	SPRING	(1)
	121-60008	STITCH TONGUE	(1)
	SS-6060440-TP	SCREW 3/32-56 L=3.5	1
	B1510-814-000	CURL GUARD	1
	131-78306	FINGER GUARD	1
01	115-98000	UPPER KNIFE SUPPORT	1
01	118-45807	UPPER KNIFE	1
01	SS-9111610-SP	SCREW 11/64-40 L=16	1
05	118-45500	UPPER KNIFE SUPPORT	1
05	118-45906	UPPER KNIFE	1
05	SS-9112310-SP	SCREW 11/64-40 L=23	1
05	115-65504	UPPER KNIFE PRESSER PLATE	1
	115-65702	WASHER	1
	118-48405	UPPER KNIFE COVER	1
	SS-4060310-SP	SCREW 3/32-56 L=2.5	1
	SS-4060310-SP	SCREW 3/32-56 L=2.5	1
	400-25294	SYNCHRONIZER TURN STOPPER ASM.	(1)
*	400-11755	SYNCHRONIZER TURN STOPPER ASM.	(1)
	400-11757	SYNCHRONIZER STOPPER BASE	(1)
	400-22255	SYNCHRONIZER STOPPER	(1)
	SS-5120810-SP	SCREW	(1)
	SS-9154540-SP	SCREW 15/64-28 L=45	(1)
	400-11758	SYNCHRONIZER BASE COLLAR	(1)
*	400-36778	V BELT SLIDER	1
*04	400-30533	PRESSER FOOT AUXILIARY PLATE	1

Page 46 — 24. ACCESSORIES PARTS COMPONENTS

Juki MO-6716 (53 pages) parts on page 46

Ref	Part number	Part name	Qty
1	131-60858	ACCESSORIE BAG ASM.
2	131-60007	RING SPANNER
3	131-60205	PIN SPANNER
4	229-32800	ACCESSORIE BAG
5	229-33105	SCREW DRIVER, MIDDLE
6	123-47308	SCREW DRIVER (SMALL)
7	131-60106	SPANNER (5X6)
8	131-60304	S SHAPED HOOK
9	131-60403	CHAIN
10	122-88403	TWEEZERS
11	131-60601	FUNNEL
12	229-33006	SCREW DRIVER, LARGE
13	229-33303	VINYL COVER
14	MDC-270B1104	NEEDLE DCX27 #11-4EA.
15	MML-018900CA	JUKI MACHINE OIL 18
16	131-42500	CARTRIDGE FILTER

Page 47 — 25. LIST FOR INFORMATION OF CHANGE

Juki MO-6716 (53 pages) parts on page 47

Ref	Part number	Part name	Qty
28	SS-7080520-SP	SS-7080520-SP
4	122-56103	122-56103
5	SS-8110410-TP	SS-8110410-TP
4	119-96907	119-96907
48	400-35711	400-35711
28	SS-4080620-TP	SS-4080620-TP
34	400-30533	400-30533
4	133-43009	133-43009
5	SM-8050412-TP	SM-8050412-TP
4	121-20713	121-20713
57	400-11755	400-11755
63	400-36778	400-36778
64	400-30533	400-30533

Page 51 — NUMERICAL INDEX OF PARTS

Juki MO-6716 (53 pages) parts on page 51

Ref	Part number	Part name	Qty
35	132-04003	132-04003	4
19	132-05406	132-05406	6
68	132-07808	132-07808	8
17	132-08004	132-08004	8
17	132-08103	132-08103	8
16	132-08350	132-08350	8
42	132-08459	132-08459	8
43	132-08509	132-08509	8
47	132-08608	132-08608	8
30	132-08707	132-08707	8
28	132-08806	132-08806	8
9	132-09101	132-09101	8
11	132-09309	132-09309	8
11	132-09309	132-09309	8
13	132-09507	132-09507	8
13	132-09507	132-09507	8
14	132-09606	132-09606	8
19	132-09705	132-09705	8
6	132-09853	132-09853	8
39	132-12501	132-12501	16
31	132-12600	132-12600	16
35	132-12709	132-12709	16
41	132-12808	132-12808	16
43	132-12915	132-12915	16
38	132-13012	132-13012	12
42	132-13012	132-13012	16
1	132-15157	132-15157	12
5	132-15405	132-15405	12
5	132-15405	132-15405	12
6	132-15504	132-15504	12
7	132-15603	132-15603	12
11	132-15702	132-15702	12
17	132-15801	132-15801	12
13	132-15900	132-15900	12
14	132-16007	132-16007	12
19	132-16106	132-16106	12
21	132-16205	132-16205	12
23	132-16304	132-16304	12
28	132-16601	132-16601	10
29	132-16700	132-16700	10
26	132-16809	132-16809	10
47	132-17351	132-17351	12
57	132-17401	132-17401	12
58	132-17500	132-17500	12
36	132-17708	132-17708	12
12	132-17807	132-17807	10
31	132-17906	132-17906	10
50	132-18052	132-18052	12
56	132-18102	132-18102	12
15	132-20009	132-20009	15
66	132-21403	132-21403	14
67	132-21502	132-21502	14
68	132-21601	132-21601	14
69	132-21700	132-21700	14
70	132-21809	132-21809	14
71	132-21908	132-21908	14
52	132-22203	132-22203	14
53	132-22302	132-22302	14
29	132-22401	132-22401	14
2	132-22609	132-22609	14
3	132-22708	132-22708	14
1	132-25008	132-25008	20
18	132-25107	132-25107	20
19	132-25107	132-25107	20
23	132-28655	132-28655	26
59	132-28903	132-28903	26
61	132-29000	132-29000	26
57	132-29109	132-29109	26
51	132-29208	132-29208	26
19	132-29307	132-29307	26
17	132-29356	132-29356	26
58	132-29406	132-29406	26
45	132-30107	132-30107	26
1	132-30305	132-30305	26
19	132-35304	132-35304	22
48	132-40007	132-40007	2
49	132-40106	132-40106	2
50	132-40106	132-40106	2
30	132-41109	132-41109	10
36	132-41109	132-41109	10
4	133-43009	133-43009	26
37	229-01805	229-01805	4
26	229-21407	229-21407	20
8	229-24708	229-24708	4
12	229-30309	229-30309	32
13	229-30309	229-30309	34
6	229-30408	229-30408	32
7	229-30408	229-30408	34
7	229-30408	229-30408	36
7	229-30408	229-30408	38
3	229-30507	229-30507	32
4	229-30507	229-30507	36
2	229-30556	229-30556	32
2	229-30556	229-30556	36
4	229-30705	229-30705	32
5	229-30705	229-30705	34
5	229-30705	229-30705	36
5	229-30705	229-30705	38
16	229-30804	229-30804	32
17	229-30804	229-30804	34
17	229-30804	229-30804	36
17	229-30804	229-30804	38
15	229-30903	229-30903	32
16	229-30903	229-30903	34
16	229-30903	229-30903	36
16	229-30903	229-30903	38
14	229-31000	229-31000	32
15	229-31000	229-31000	34
15	229-31000	229-31000	36
15	229-31000	229-31000	38
13	229-31109	229-31109	32
14	229-31109	229-31109	34
14	229-31109	229-31109	36
14	229-31109	229-31109	38
7	229-31307	229-31307	32
8	229-31307	229-31307	34
8	229-31307	229-31307	36
8	229-31307	229-31307	38
5	229-31406	229-31406	32
6	229-31406	229-31406	34
6	229-31406	229-31406	36
6	229-31406	229-31406	38
4	229-32800	229-32800	41
12	229-33006	229-33006	41
5	229-33105	229-33105	41
13	229-33303	229-33303	41
45	236-30007	236-30007	8
54	236-30007	236-30007	26
56	310-18005	310-18005	26
60	310-18005	310-18005	26
55	400-10804	400-10804	14
72	400-11234	400-11234	14
57	400-11755	400-11755	40
58	400-11757	400-11757	40
62	400-11758	400-11758	40
10	400-15637	400-15637	14
12	400-16762	400-16762	26
16	400-16763	400-16763	26
11	400-16841	400-16841	14
47	400-17714	400-17714	6
41	400-17824	400-17824	6
2	400-18044	400-18044	26
59	400-22255	400-22255	40
2	400-23234	400-23234	6
1	400-23235	400-23235	6
56	400-25294	400-25294	40
34	400-30533	400-30533	18
64	400-30533	400-30533	40
48	400-35711	400-35711	6
63	400-36778	400-36778	40

Part BooksPartsSearchNotes

Part Books

×

Search

×

Juki MO-6716 (53 pages) — parts catalog

• Page 1 (cover): This is the cover page for the JUKI High-speed 1-Needle, Overedging Industrial Sewing Machine MO-6704S-0E4, High-speed 2-Needle, Overedging Industrial Sewing Machine MO-6714S-BE6, and High-speed Safety Stitch Industrial Sewing Machine MO-6716S-DE4 parts list. It includes the JUKI logo and the title "PARTS LIST".
• Page 2 (unknown): This page contains a watermark and no other discernible text or parts information.
• Page 3 (text): This page provides instructions on how to use the parts list, explaining codes and symbols used in the catalog.
• Page 5 (toc): This page is a table of contents listing sections 21 through 25, including Thread Stand Components, Special Order Parts Components, Accessories Parts Components, and List for Information of Change, along with a Numerical Index of Parts.
• Page 6 (diagram): This page displays a diagram of miscellaneous cover components for a JUKI sewing machine, with numbered parts and their corresponding references.
• Page 7 (parts_list): This page lists parts for the sewing machine, including cloth waste covers, screws, nuts, and various covers and plates, with part numbers, descriptions, and quantities.
• Page 8 (diagram): This page displays a diagram of miscellaneous cover components for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 9 (parts_list): This page lists parts for industrial sewing machines, including screws, covers, gaskets, and plates, with their corresponding part numbers, descriptions, quantities, and notes.
• Page 10 (diagram): This page displays a diagram of crankshaft components, including various parts like the crankshaft itself, connecting rods, bearings, and fasteners, each identified by a reference number.
• Page 11 (parts_list): This page lists parts for industrial sewing machines, including main shafts, screws, washers, and bearings, with their corresponding part numbers and descriptions.
• Page 12 (diagram): This page displays a diagram of needle driving shaft components, with numbered parts and their corresponding references.
• Page 13 (parts_list): This page lists parts for sewing machines, including part numbers, descriptions, and quantities. It also includes notes regarding specific models and ordering information.
• Page 14 (diagram): This page displays a diagram of the feed mechanism components (1) of an industrial sewing machine, with numbered parts for identification.
• Page 15 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes. It details various screws, bearings, shafts, and other components.
• Page 16 (diagram): This page displays a diagram of the feed mechanism components (2) for an industrial sewing machine, with numbered parts for identification.
• Page 17 (parts_list): This page contains a parts list for various components of the sewing machine, including screws, washers, rubber parts, and feed mechanisms, with corresponding part numbers and descriptions.
• Page 18 (diagram): This page displays a diagram of upper and lower looper components, with numbered parts and their corresponding references.
• Page 19 (parts_list): This page lists parts for sewing machines, including part numbers, descriptions, quantities, and notes. It details various components like needle guards, loopers, screws, and oil seals, with specific notes for models MO-6704S, MO-6716S, and MO-6714S.
• Page 21 (parts_list): This page lists presser foot components for a sewing machine, including part numbers, descriptions, and quantities.
• Page 22 (diagram): This page displays a diagram of presser foot components, numbered 1 through 48, with detailed illustrations of various parts and their sub-assemblies.
• Page 23 (parts_list): This page lists parts for sewing machines, including part numbers, descriptions, quantities, and notes. It details various screws, feet, springs, and other components, with specific applicability to models MO-6704S, MO-6714S, and MO-6716S.
• Page 24 (diagram): This page displays a diagram of thread tension components, including various parts labeled with reference numbers and some part numbers like M0-6704S, M0-6714S, and M0-6716S.
• Page 25 (parts_list): This page lists parts for sewing machines, including various screws, springs, guides, and other components with their part numbers and descriptions.
• Page 26 (diagram): This page displays a diagram of lower knife components, with numbered parts and their corresponding references.
• Page 27 (parts_list): This page lists parts for sewing machine models MO-6704S, MO-6714S, and MO-6716S, including throat plates, screws, brackets, and holders.
• Page 28 (parts_list): This page lists upper knife components with part numbers, descriptions, and quantities.
• Page 29 (parts_list): This page lists needle cooling mechanism components, including part numbers, descriptions, and quantities for various models.
• Page 30 (diagram): This page displays a diagram of lubrication mechanism components, with numbered parts and their corresponding references.
• Page 31 (parts_list): This page lists parts for a sewing machine, including various screws, gears, pumps, and oil-related components, with their corresponding part numbers and descriptions.
• Page 32 (diagram): This page displays a diagram of semi-sunken type table components, with a corresponding parts list detailing part numbers, descriptions, and quantities.
• Page 33 (diagram): This page displays a diagram of fully-sunken type table components, with a corresponding parts list detailing part numbers, descriptions, and quantities.
• Page 34 (diagram): This page displays a diagram of stand components (Z.T) for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 35 (parts_list): This page lists parts for an industrial sewing machine, including various pedals, washers, bolts, and junction components, with their corresponding part numbers, descriptions, and quantities.
• Page 36 (diagram): This page displays a diagram of thread stand components for MO-6704S and MO-6714S sewing machines, with numbered parts indicated.
• Page 37 (parts_list): This page lists parts for a sewing machine, including thread standing devices, spool rests, thread guides, and various screws, nuts, and washers, with their corresponding part numbers and descriptions.
• Page 38 (diagram): This page displays a diagram of thread stand components for MO-6704S and MO-6714S special order parts, with numbered parts and their corresponding references.
• Page 39 (parts_list): This page lists parts for a sewing machine, including thread standing devices, arms, rods, screws, nuts, and washers, with their corresponding part numbers, descriptions, and quantities.
• Page 40 (diagram): This page displays a diagram of thread stand components for model MO-6716S, with numbered parts and their corresponding references.
• Page 41 (parts_list): This page lists parts for a sewing machine, including thread standing devices, arms, rods, screws, nuts, and washers, with their corresponding part numbers and quantities.
• Page 42 (diagram): This page displays a diagram of thread stand components for the MO-6716S model, listing various parts with their reference numbers.
• Page 43 (parts_list): This page lists parts for a sewing machine, including thread standing devices, arms, rods, spools, screws, nuts, and washers, with their corresponding part numbers, descriptions, and quantities.
• Page 44 (diagram): This page displays a diagram of special order parts components for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 45 (parts_list): This page lists parts for sewing machines, including screws, plates, loopers, knives, and synchronizer components, with their corresponding part numbers and descriptions.
• Page 46 (parts_list): This page lists accessories and components for an industrial sewing machine, including part numbers, descriptions in English and Japanese, and quantities.
• Page 47 (parts_list): This page contains a list of added and obsolete parts with their corresponding revision numbers, page numbers, reference numbers, and part numbers.
• Page 51 (parts_list): This page contains a numerical index of parts for an industrial sewing machine, listing part numbers, page references, and reference numbers from diagrams.
• Page 52 (cover): This is the cover page of a JUKI CORPORATION parts list, copyrighted between 2002-2006. It includes contact information for orders and inquiries, and states that the parts list is edited in accordance with product specifications as of March 2006. The page is printed in Japan.
• Page 53 (cover): This is the cover page for the JUKI 1-Needle Lockstitch Straight Button-Holing Industrial Sewing Machine, models LBH-761, LBH-762, and LBH-763 & Subclasses. It includes the document number BE7610TOPJA No.0029-12.

Page 1 — PARTS LIST

High-speed 1-Needle, Overedging Industrial Sewing Machine 高速一本針オーバーロックミシン MO-6704S-0E4 High-speed 2-Needle, Overedging Industrial Sewing Machine 高速二本針オーバーロックミシン MO-6714S-BE6 High-speed Safety Stitch Industrial Sewing Machine 高速安全縫ミシン MO-6716S-DE4 PARTS LIST JUKI 29355401 No.1329-03 jintex.in

Page 2

jinte x.in jintex.in

Page 3 — HOW TO MAKE USE OF THIS PARTS LIST

HOW TO MAKE USE OF THIS PARTS LIST 1. Explanation of codes 1) "*" mark...means this part is changed from the previous parts book. As to the details of the change,refer to "List for information of change". 2) "01" ...refer to "Note" explanation at bottom of page. 2. Codes on the "Qty" column Each numeral indicates the number of parts required. "0.1" and "2.5" indicate the length (in meters) of the respective parts. 3. Parentheses mean that the corresponding part is a subpart that constructs an assembly part. 4. Dotted lines on the Figures indicate assembly parts. パーツリストご利用に際して 1."注記"欄の記号説明 1)"* 印...前回 のパーツブックに比較して今回変更された部品を意味します。 変更内容は"変更情報リスト"を参照してください。 2)"01" ...ページ下の"注記"の説明を参照してください。 2. 数量欄の数字は、個数を表し、0.1、2.5等の数値は、長さ(単位メートル)を表します。 3. 数量欄の( )は、組部品を構成している子部品であることを意味します。 4. イラストページの- - - 枠は、組構成であることを意味します。

Page 5

21. THREAD STAND COMPONENTS (FOR MO-6716S) 35 糸立装置関係(MO-6716S用) 22. THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS) 37 糸立装置関係(MO-6716S 特別注文部品) 23. SPECIAL ORDER PARTS COMPONENTS 39 特別注文部品関係 24. ACCESSORIES PARTS COMPONENTS 41 付属品関係 25. LIST FOR INFORMATION OF CHANGE 42 変更情報リスト NUMERICAL INDEX OF PARTS 43 索引

Page 6 — 1. MISCELLANEOUS COVER COMPONENTS (1)

1. MISCELLANEOUS COVER COMPONENTS (1) 外装関係 (1) 9 10 7 8 43 41 42 JUKI 34 11 12 35 23 36 37 39 38 44 13 14 45 46 47 28 29 51 48~50 18 1 3 5 6 2 4 19 20 15 21 22 24 16 17 25 26 27 30 31 -1- jintex.in

Page 7

REF. NO. NOTE PART NO. D E S C R I P T I O N Qty 1 131-04005 CLOTH WASTE COVER 1 2 02 131-04203 CLOTH WASTE COVER 1 3 131-02405 CROTH WASTE COVER STOPPER 1 4 SS-2090520-SL SCREW 9/64-40 L=5 1 5 NS-6090310-SN NUT 9/64-40 1 6 SS-3090610-SP SCREW 9/64-40 L=6 2 7 132-00704 FEED MECHANISM COVER 1 8 132-00803 FEED MECHANISM COVER GASKET 1 9 SM-4040855-SP SCREW 4 10 SM-1040801-SC SCREW M4X0.7 L=8 1 11 123-42101 CLOTH BASE SIDE COVER 1 12 SS-4120615-SP SCREW 3/16-28 L=6 2 13 131-03809 CLOTH BASE COVER 1 14 SS-4091015-SP SCREW 9/64-40 L=10 2 15 131-00904 LOOPER COVER 1 16 131-00805 LOOPER COVER BRACKET 1 17 SM-4041055-SP SCREW M4 L=10 3 18 131-01209 LOOPER COVER SPRING 1 19 131-01407 LOOPER COVER PRESSER PLATE 1 20 SS-7090530-SP SCREW 9/64-40 L=4.5 1 21 131-01001 LOOPER COVER GUIDE PLATE 1 22 SS-7090610-SP SCREW 9/64-40 L=6 1 23 SS-8110410-TP SCREW 11/64-40 L=3.5 1 24 SS-8110410-TP SCREW 11/64-40 L=3.5 1 25 01 131-01506 CLOTH WASTE COVER, LEFT 1 26 02 131-01605 CLOTH WASTE COVER, LEFT 1 27 SS-7110510-SP SCREW 11/64-40 L=5 2 28 121-03305 CLOTH BASE SWITCH-TYPE STOPPER 1 29 SS-7110710-SP SCREW 11/64-40 L=7 2 30 131-01308 LOOPER COVER PRESSER SPRING 1 31 SM-4040655-SP SCREW M4 L=6 1 32 131-01803 CROTH BASE SUPPORT PLATE 1 33 SS-7091410-SP SCREW 9/64-40 L=13.5 1 34 131-03650 CLOTH BASE CMPL. 1 35 131-02058 CLOTH BASE ASM. 1 36 131-01902 CLOTH BASE ECCENTRIC BUSHING 1 37 WZ-0420350-KP DISC SPRING (1) 38 131-72903 CLOTH BASE HINGE SHAFT COLLAR (1) 39 SM-8040302-TP SETSCREW (1) 40 CM-3002000-01 ATTENTION SEAL 1 41 132-01504 ADJUSTING HOLE COVER 1 42 132-01603 ADJUSTING HOLE COVER GASKET 1 43 SM-4040855-SP SCREW 4 44 131-04302 CLOTH BASE COVER RUBBER PLUG 1 45 131-02207 CLOTH BASE SWITCH-TYPE SPRING 1 46 NS-6110420-SP NUT 11/64-40 1 47 SS-6111440-SP SCREW 11/64-40 L=14.0 1 48 03 132-40007 LOOPER COVER HINGE SHAFT A 1 49 03 132-40106 LOOPER COVER HINGE SHAFT B 1 50 03 132-40205 LOOPER COVER HINGE SHAFT C 1 51 05 131-04104 CLOTH WASTE COVER 1 NOTE (注記) 01. . . FOR MO-6704S, MO-6714S MO-6704S, MO-6714S用 02. . . FOR MO-6716S MO-6716S用 03. . . SELECTIVE PARTS 選択部品 04. . . FOR MO-6704S, MO-6714S MO-6704S, MO-6714S用 (EXCEPT TYPE SH) (SH仕様を除く) 05. . . FOR MO-6704S, MO-6714S MO-6704S, MO-6714S用 (FOR TYPE SH) (SH仕様のみ) -2- jintex.in

Page 8 — 2. MISCELLANEOUS COVER COMPONENTS (2)

2. MISCELLANEOUS COVER COMPONENTS (2) 外装関係 (2) MO-6700 Series -3- jintex.in

Page 9

REF. NO. NOTE PART NO. D E S C R I P T I O N Qty 1 132-00209 SIDE COVER ソクメンカバー 1 2 132-00308 SIDE COVER GASKET ソクメンカバーパッキン 1 3 SM-4040855-SP SCREW ナベネジ 3 4 SM-1040801-SC SCREW M4X0.7 L=8 サラコネジ M4X0.7 L=8 1 5 132-00506 UPPER COVER ウワカバー 1 6 132-00605 UPPER COVER GASKET ウワカバーパッキン 1 7 SM-4051255-SP SCREW M5 L=12. ナベネジ M5 L=12 5 8 229-24708 OIL SIGHT WINDOW アブ・ラマド 1 9 131-70006 RUBBER RING Oリング 1 10 131-04500 OIL DRAIN SCREW フィルターサゲハイユネジ 1 11 131-70204 RUBBER RING Oリング 1 12 132-01009 COOLING FAN PLATE レイキャクファンイタ 1 13 SM-1040801-SC SCREW M4X0.7 L=8 サラコネジ M4X0.7 L=8 1 14 SM-4040855-SP SCREW ナベネジ 2 15 132-01454 BELT COVER ASM. ベルトカバー(クミ) 1 16 132-01405 BELT COVER ベルトカバー 1 17 CM-3002000-A1 CAUTION LABEL (16) マキコミユシール(16) (1) 18 SS-4151215-SP SCREW 15/64-28 L=12 ナベネジ 15/64-28 L=12 (1) 19 131-02553 OIL RESERVOIR ASM. アブ・ラダ・マリクミ 3 20 131-02504 OIL RESERVOIR アブ・ラダ・マリ (1) 21 131-70105 RUBBER RING Oリング (1) 22 131-71004 DRAIN SCREW ハイユネジ (1) 23 131-02603 OIL RESERVOIR GASKET アブ・ラダ・マリパッキン 1 24 131-03908 SCREW STUD シチュウボルト 4 25 WP-0751576-SD WASHER 7.5X19X1.5 ヒラサカネ 7.5X19X1.5 4 26 WS-0822010-KP SPRING WASHER 8.2X15X2 ハネサカネ 8.2X15X2 4 27 NS-6680410-SP NUT 9/32-28 ロツカクナット 9/32-28 4 28 132-01108 SAFETY PLATE BRACKET メホコカバー・ダイ 1 29 131-04807 SAFETY PLATE BRACKET COLLAR メホコカバー・ダイイカラー 1 30 WZ-0850302-K0 WAVED WASHER 8.5X12.5X0.3 ナミサカネ 8.5X12.5X0.3 1 31 SS-5110710-SP SCREW 11/64-40 L=7 トラスネジ 11/64-40 L=7 1 32 02 132-01306 SAFETY PLATE メホコカバー 1 33 01 132-01207 SAFETY PLATE メホコカバー 1 34 SS-7090611-SL SCREW 9/64-40 L=6.1 マルヒラネジ 9/64-40 L=6.1 2 35 132-04003 SAFETY PLATE BUSH メホコカバーブッシュ 1 36 CM-3002001-B1 SAFETY LABEL 12 アンゼンラベル12 1 37 229-01805 GROUND MARK グランドマーク 1 38 131-02900 THREAD GUIDE, LARGE イトミチ(ダイ) 39 107-53309 WINDOW PLATE RUBBER PLUG マト・イタトメセン 1 40 SK-3412001-SE WOOD SCREW D=4.1 L=20 カマト リケビス 2 41 01 TA-1871602-R0 RUBBER PLUG トメセン D=18.7 L=16 1 42 TA-2050805-R0 RUBBER PLUG トメセン D=20.5 L=8 1 43 131-60700 BELT COVER (B) ベルトカバー(B) 1 NOTE (注記) 01...FOR MO-6704S, MO-6714S MO-6704S, MO-6714S用 02...FOR MO-6716S MO-6716S用 -4- jintex.in

Page 10 — 3. CRANKSHAFT COMPONENTS

3. CRANKSHAFT COMPONENTS 主軸関係 45 46 47 42 43 44 48 1 2 3 28 23 29 21 22 19 20 30 31 41 34 35 41 33 32 25 24 26 38 39 36 37 41 5 13 12 10 11 9 8 6 14 15 27 16 A -5- jintex.in

Page 11

REF. NO NOTE PART NO. DESCRIPTION Qty. 1 400-23235 MAIN SHAFT ASM. シュ-ジクミ 1 2 400-23234 MAIN SHAFT (300) シュ-ジク (1) 3 SS-5080212-TP SCREW 1/8-44 L=2 ハ・イント・ネジ (5) 4 131-07602 HANDWHEE (A) ハズ・ミク・ルマ(A) 1 5 SS-8151150-TP SCREW 15/64-28 L=10.5 トメネジ 15/64-28 L=10.5 2 6 131-07800 THRUST COLLAR スラストウク 1 7 SM-4050855-SP SCREW M5 L=8 ナベネジ M5 L=8 3 8 131-08402 COOLING FAN レイキャクファン 1 9 131-08501 CRANKSHFT OIL SHIELD シュ-ジク・クア・ラキリ 1 10 131-07701 HANDWHEEL ハズ・ミク・ルマ 1 11 SS-7111810-TP SCREW 11/64-40 L=18 マルヒラネジ 11/64-40 L=18 3 12 SS-9681610-TP SCREW 9/32-28 L=16 ロツカクボルト 9/32-28 L=16 1 13 WP-0764016-SP WASHER ヒラザ・ガネ 76X20X4 1 14 131-70303 RUBBER RING Oリング 1 15 WZ-2640310-KH WAVED WASHER 26.4X33.9X3.5 ナミカ・タダ・ガネ 26.4X33.9X3.5 1 16 B1211-804-000 BALL BEARING B シュ-ジク・ボール・ベアリング B 1 17 B1212-704-000 BEARING RETAINER ホ・ール・ベアリング・トメワ 1 18 B1211-804-000 BALL BEARING B シュ-ジク・ボール・ベアリング B 1 19 132-05406 CRANKSHAFT BUSHING C Cメタル 1 20 131-04906 OIL ADJUSTING BAR ユリョウチョウセツボウ・ク 1 21 01 B1215-804-000 BALL BEARING D シュ-ジク・ボール・ベアリング D 1 22 02 SB-1100003-00 BALL BEARING ホ・ール・ベアリング 1 23 01 131-08006 CRANKSHAFT BUSHING D Dメタル 1 24 02 131-08105 CRANKSHAFT BUSHING D Dメタル 1 25 131-08204 CRANKSHAFT BUSHING GASKET Dメタルハツキン 1 26 SM-4040855-SP SCREW ナベネジ 3 27 131-08303 BEARING HOLDING PLATE ベアリング・ウケイタ 1 28 121-09153 CONNECTING ROD ASM. ハリク・ト・ウ・ロッド・クミ 1 29 SS-7111810-TP SCREW 11/64-40 L=18 マルヒラネジ 11/64-40 L=18 (2) 30 121-22362 UPPER LOOPER ROD ASM. ウワルー・パ・ー・タマウデ (クミ) 1 31 SS-7111810-TP SCREW 11/64-40 L=18 マルヒラネジ 11/64-40 L=18 (2) 32 SS-7111410-TP SCREW 11/64-40 L=14 マルヒラネジ 11/64-40 L=14 (2) 33 SM-6061202-TP SCREW M6 L=12 ロツカクアナボルト M6 L=12 (1) 34 01 121-23360 LOWER LOOPER ROD ASM., A シタル・ルー・タマウデ A (クミ) 1 35 SS-7111810-TP SCREW 11/64-40 L=18 マルヒラネジ 11/64-40 L=18 (2) 36 SS-7111410-TP SCREW 11/64-40 L=14 マルヒラネジ 11/64-40 L=14 (2) 37 SM-6061202-TP SCREW M6 L=12 ロツカクアナボルト M6 L=12 (1) 38 02 121-20150 LOWER LOOPER ROD ASM., B シタル・ルー・タマウデ B クミ 1 39 SS-7111810-TP SCREW 11/64-40 L=18 マルヒラネジ 11/64-40 L=18 (2) 40 SS-7111410-TP SCREW 11/64-40 L=14 マルヒラネジ 11/64-40 L=14 (2) 41 400-17824 LOOPER LOD STOPPER ルー・パ・ー・ロッド・ブレド・メ 4 42 SS-6081210-TP SCREW 1/8-44 L=12 ヒラザネジ 1/8-44 L=12 2 43 121-32155 KNIFE DRIVING ROD ASM. ウエ・メスロット・クミ 1 44 SS-7111810-TP SCREW 11/64-40 L=18 マルヒラネジ 11/64-40 L=18 (2) 45 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 1 46 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 1 47 400-17714 BALANCER ハ・ランサー 1 48 * 400-35711 OIL WICK ユリョウチョウセツシン 1 NOTE (注記) 01...FOR MO-6704S, MO-6714S MO-6704S, MO-6714S用 02...FOR MO-6716S MO-6716S用 FOR NO.28,30,34,38,43, ORDER FOR SET ONLY CAN BE ACCEPTED NO.28,30,34,38,43、は、セットのみの注文になります。 -6- jintex.in

Page 12 — 4. NEEDLE DRIVING SHAFT COMPONENTS

4. NEEDLE DRIVING SHAFT COMPONENTS 針駆動軸関係 20 19 6 15 8 7 9~11 58 57 9~11 58 17 60 12~14 16 1 3 2 49~52 57 17 68 54 56 55 56 54 42 46 45 47 44 48 43 30 29 28 31 32 33 25 24 27 26 61 21 23 22 64 63 62 67 67 65 53 66 34 37 35 36 38 39 40 41 -7- jintex.in

Page 13

REF. NO. NOTE PART NO. DESCRIPTION Qty 1 131-10556 FEED FORKED CRANK ASM. ハリクト・ウフタマタクランククミ 1 2 131-10507 NEEDLE DRIVING BRANCH CRANK ハリクト・ウフタマタクランク (1) 3 SM-6061402-TP SCREW M6 L=14 ロクアカアナネジ M6 L=14 (1) 4 131-10606 NEEDLE DRIVING SHAFT ハリクト・ウシク 1 5 131-10101 BUSHING, REAR ハリクト・ウシク クシロメタル 1 6 132-09853 NEEDLE DRIVING ARM ASM. ハリクト・ウデテ 1 7 132-09804 NEEDLE DRIVING ARM ハリクト・ウデ (1) 8 SM-6061402-TP SCREW M6 L=14 ロクアカアナネジ M6 L=14 (1) 9 07 132-09101 NEEDLE DRIVING ARM PIN A ハリクト・ウデ・ピンA 2 10 07 132-09200 NEEDLE DRIVING ARM PIN B ハリクト・ウデ・ピンB 2 11 07 132-09309 NEEDLE DRIVING ARM PIN C ハリクト・ウデ・ピンC 2 12 07 132-09408 NEEDLE DRIVING PIN A ハリクト・ウビンA 1 13 07 132-09507 NEEDLE DRIVING PIN B ハリクト・ウビンB 1 14 07 132-09606 NEEDLE DRIVING PIN C ハリクト・ウビンC 1 15 131-10002 BUSHING, REAR ハリクト・ウシク クマエメタル 1 16 132-08350 NEEDLE ROD (A) ASM. ハリクト・ウ(A)クミ 1 17 132-08103 NEEDLE DRIVING LINK WASHER ハリクト・ウサンクザ・ガネ 2 18 EA-9500B01-00 CABLE BAND ソクセンバンド 1 19 132-09705 NEEDLE ROD BUSHING, UPPER ハリクト・ウワメタクル 1 20 132-07808 NEEDLE ROD BUSHING CAP SCREW ハリクト・ウワメタクルキャップ・ネジ 1 21 131-10259 NEEDLE CLAMP HOLDER ASM. ハリト・メ・キグミ 1 22 131-10200 NEEDLE CLAMP HOLDER ハリト・メ・キ (1) 23 SS-6080720-SP SCREW 1/8-44 L=7 ヒラネジ 1/8-44 L=7 (1) 24 01 131-10705 NEEDLE THREAD PRESSER GUIDE A ハリトオサエイトアンナイA 1 25 02 131-10804 NEEDLE THREAD PRESSER GUIDE B ハリトオサエイトアンナイB 1 26 131-10903 NEEDLE THREAD PRESSER PLATE A ハリトオサエタ 1 27 131-11000 NEEDLE THREAD PRESSER PLATE B ハリトオサエタ 1 28 03 132-08806 NEEDLE THREAD GUIDE ハリトアンナイ 1 29 04 132-08905 THREAD GUIDE, 2-NEEDLE ニホンハ・リハリトアンナイ 1 30 132-08707 NEEDLE THREAD GUIDE BASE ハリトアンナイダイ 1 31 02 131-11109 THREAD GUIDE, CHAIN LOOPER ニジユウカンハリトアンナイ 1 32 SM-4040855-SP SCREW ナベネジ 2 33 SS-4110515-SP SCREW 11/64-40 L=5 ナベネジ 11/64-40 L=5 1 34 05 131-11208 NEEDLE THREAD TAKE-UP LEVER ハリトテンピン 1 35 04 131-11307 TAKE-UP LEVER, CHAIN LOOP ニホンハ・ハリトテンピン 1 36 02 131-11406 TAKE-UP LEVER, CHAIN LOOP ニジユウカンハリトテンピン 1 37 SS-6090670-TP SCREW 9/64-40 L=6 ヒラネジ 9/64-40 L=6 2 38 03 131-11505 NEEDLE THREAD BALANCE GUIDE ハリトテンピンガイ ド 1 39 04 131-11604 TAKE-UP LEVER GUIDE, 2-NEEDLE ニホンハ・ハリトテンピンガイ ド 1 40 02 131-11703 TAKE-UP LEVER GUIDE, CHAIN LOOP ニジユウカンハリトテンピンガイ ド 1 41 SM-4040855-SP SCREW ナベネジ 1 42 132-08459 ONCE THROUGH OIL PIPE ASM. ハリカンジユウハ・イプクミ (1) 43 132-08509 ONCE THROUGH OIL COVER ハリカンジユウカバ- (1) 44 CQ-2000000-00 OIL WICK ユシン (0.8) 45 236-30007 TUBE チューブ (0.39) 46 132-44009 ONCE THROUGH OIL PIPE BUSHING ハリカンジユウハ・イプブツシユ (1) 47 132-08608 ONCE THROUGH OIL FELT ハリカンジユウフエルト (1) 48 131-42609 PIPE CLAMP パイアトメ 1 49 07 131-22007 FEED BRANCH CRANK PIN A オクリフタマタクランクピンA 1 50 07 131-22106 FEED BRANCH CRANK PIN B オクリフタマタクランクピンB 1 51 07 131-22205 FEED BRANCH CRANK PIN C オクリフタマタクランクピンC 1 52 07 131-22304 FEED BRANCH CRANK PIN D オクリフタマタクランクピンD 1 53 06 MDC-270B1100 NEEDLE DCX27 #11 ハリDCX27 #11 2 54 131-72754 THRUST COLLAR ASM. ハリクト・ウシク クラス トカラー (クミ) 2 55 131-72705 THRUST COLLAR ハリクト・ウシク クラス トカラー (1) 56 SS-8060610-TP SCREW 1/4-40 L=6 トメネジ 1/4-40 L=6 (2) 57 SS-8090530-TP SCREW 9/64-40 L=5.0 トメネジ 9/64-40 L=5.0 2 58 CQ-2020000-00 OIL WICK ユシン 0.09 59 SS-8090530-TP SCREW 9/64-40 L=5.0 トメネジ 9/64-40 L=5.0 1 60 CQ-2520000-00 OIL WICK ユシン 0.04 61 SD-0280401-SL HINGE SCREW D=2.8 H=4 ダソネジソク D=2.8 H=4 1 62 05 131-75005 NEEDLE CLAMP, 1-NEEDLE イッポンハ・リハルトメ 1 63 04 122-56905 NEEDLE CLAMP, 2-NEEDLE(BE6) ニホンハ・リハルトメ(BE6) 1 64 02 122-57002 CHAIN LOOPER NEEDLE CLAMP, DEA ニジユウカンハリトメ(DEA) 1 65 05 SS-8080310-TP SCREW 1/8-44 L=2.8 トメネジ 1/8-44 L=2.8 1 66 05 MDC-270B1100 NEEDLE DCX27 #11 ハリDCX27 #11 1 67 06 SS-8080310-TP SCREW 1/8-44 L=2.8 トメネジ 1/8-44 L=2.8 2 68 132-08004 NEEDLE DRIVING LINK ハリクト・ウリンク 1 NOTE (注記) 01...FOR MO-6704S, MO-6714S MO-6704S, MO-6716S用 02...FOR MO-6716S MO-6716S用 03...FOR MO-6704S, MO-6716S MO-6704S, MO-6716S用 04...FOR MO-6714S MO-6714S用 05...FOR MO-6704S MO-6704S用 06...FOR MO-6714S, MO-6716S MO-6714S, MO-6716S用 07...SELECTIVE PARTS 選択部品 FOR NO.16, ORDER FOR SET ONLY CAN BE ACCEPTED NO.16は、セットのみの注文になります。 -8- jintex.in

Page 14 — 5. FEED MECHANISM COMPONENTS (1)

5. FEED MECHANISM COMPONENTS (1) 送り関係 (1) 3 2 32 34 33 42 43 41 40 39 4 35~38 5 7 8 23 9 10 11 24 17 16 18~22 15 14 1 13 12 31 25 26 27 28 29 30 -9- jintex.in

Page 15

REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 131-18054 FEED ECCENTRIC BODY ASM. オクリカムシ・ダイクミ 1 2 131-20605 WASHER ニジユウカンロッド・ザ・ガネ 1 3 SS-6121220-TP SCREW 3/16-28 L=11.5 ヒラネジ 3/16-28 L=11.5 1 4 131-22452 FEED BRANCH CRANK ASM. オクリフタマタクランククミ 1 5 131-22403 FEED BRANCH CRANK オクリフタマタクランク (1) 6 SM-6061402-TP SCREW M6 L=14 ロツカクアナネジ M6 L=14 (1) 7 TA-1030402-RO RUBBER PLUG D=10.3 L=4 トメセン D=10.3 L=4 1 8 TA-2050416-RO RUBBER PLUG トメセン 1 9 131-72556 FEED SHAFT THRUST COLLAR ASM. オクリジ・クスラトカラー(クミ) 2 10 131-72507 FEED SHAFT THRUST COLLAR オクリジ・クスラトカラー (1) 11 SS-8110410-TP SCREW 11/64-40 L= 3.5 トメネジ 11/64-40 L=3.5 (2) 12 01 132-17807 SLIDE BLOCK A ジヨウゲ・オクリカクゴ・マ A 1 13 131-22502 RATCHET PAWL SPRING ラチエットオサエバネ 1 14 131-19300 RATCHET GEAR SPRING ラチエツトギヤ・バネ 1 15 SS-6080320-SP SCREW 1/8-44 L= 2.5 ヒラネジ 1/8-44 L=2.5 1 16 131-18708 FEED CRANK ROD オクリクランクツロツド 1 17 SS-7110910-TP SCREW 11/64-40 L= 8.5 マルヒラネジ 11/64-40 L=8.5 1 18 01 121-16604 NEEDLE BEARING マルヒラ・アリンゲ A 1 19 01 121-16703 NEEDLE BEARING B オクリヘ・アリンゲ B 1 20 01 121-16802 NEEDLE BEARING.,C. オクリヘ・アリンゲ C 1 21 01 121-16901 NEEDLE BEARING.,D. オクリヘ・アリンゲ D 1 22 01 121-17008 NEEDLE BEARING.,E. オクリヘ・アリンゲ E 1 23 131-19409 FEED SHAFT METAL, FRONT オクリジ・クメエメタル 1 24 131-19508 FEED SHAFT METAL, REAR オクリジ・クウシロメタル 1 25 131-19607 FEED SHAFT オクリジ・ク 1 26 132-16809 PUSH BUTTON SHAFT オシボ・タンジ・ク 1 27 SM-4041455-SN SCREW M4 L=14 ナベネジ M4 L=14 1 28 132-16600 PUSH BUTTON SPRING オシボ・タンバ・ネ 1 29 132-16700 PUSH BUTTON SHAFT WASHER オシボ・タンシ・クザ 1 30 132-44108 RUBBER RING Oリング 1 31 01 132-17906 SLIDE BLOCK B ジヨウゲ・オクリカクゴ・マ B 1 32 131-19953 MAIN FEED ARM ASM. ジユオクリウデ・クミ 1 33 131-19904 MAIN FEED ARM ジユオクリウデ 1 34 SM-6051202-TP SCREW M5X0.8 L=12 ロツカクアナボルト M5X0.8 L=12 (1) 35 01 131-22007 CRANK PIN A オクリフタマタクランクピン A 1 36 01 131-22106 CRANK PIN B オクリフタマタクランクピン B 1 37 01 131-22205 CRANK PIN C オクリフタマタクランクピン C 1 38 01 131-22304 CRANK PIN D オクリフタマタクランクピン D 1 39 131-19706 MAIN FEED ARM PIN ジユオクリウデ・ピン 1 40 NS-6620320-SP NUT 3/16-32 ロツカクアナツト 3/16-32 1 41 131-20001 WASHER B ジユオクリウデ・ザ・ガネ(B) 1 42 131-19805 MAIN FEED LINK ジユオクリリンク 1 43 B1620-804-000 PIN COLLAR ジユオクリ・ピンカラー 1 NOTE (注記) 01...SELECTIVE PARTS 選択部品 FOR NO.1,ORDER FOR SET ONLY CAN BE ACCEPTED NO.1は、セットのみの注文になります。 - 10 - jintex.in

Page 16 — 6. FEED MECHANISM COMPONENTS (2)

6. FEED MECHANISM COMPONENTS (2) 送り関係 (2) 33 53 35 52 29 30 34 31 50 56 22 21 16 1 19 20 64 51 70 2 66 65 71 40 41 59 11 10 14 13 23 67 3 68 69 5 6 7 4 62 60 17 54 15 12 55 62 60 38 26 24 25 28 27 58 63 36 61 39 27 28 26 37 48 47 18 45 46 49 - 11 - jintex.in

Page 17

REF. NO. NOTE DESCRIPTION Qty 1 132-15157 FEED ROCKER ASM. オクリヨウ ト ウカンクミ 1 2 SS-4080620-TP SCREW 1/8-44 L=6 ナベネジ 1/8-44 L=6 1 3 SS-9111010-SP SCREW 11/64-40 L=9.5 ロツカクボルト 11/64-40 L=9.5 1 4 132-15306 RUBBER CASE ボウシンゴムケース 1 5 132-15405 RUBBER CASE GASKET ボウシンゴムケースパツキン 1 6 132-15504 FEED BAR SUPPORT, RIGHT ヨウド ウカンオタエミギ 1 7 132-15603 FEED BAR SUPPORT, LEFT ヨウド ウカンオタエヒダリ 1 8 SS-6090620-TP SCREW ヒラネジ 4 9 121-18303 DUST-PROOF RUBBER ボウシンゴム 1 10 121-18204 OIL SHIELD RUBBER アブ ラキリゴム 3 11 132-15702 RUBBER HOLDING PLATE アブ ラキリゴムケイタ 1 12 SS-7060310-SP SCREW マルヒラネジ 3/32-56 L=3 2 13 132-15900 OIL SHIELD CASE エボ ウケース 1 14 132-16007 OIL SHIELD CASE GASKET エボ ウケースパツキン 1 15 SM-4040855-SP SCREW ナベネジ 1 16 SM-4030455-SP SCREW ナベコネジ M3 L=4 2 17 132-15801 THROAT PLATE SUPPORT ハリイタササエ 1 18 131-22700 ADJUSTING SHAFT METAL サト ウチョウセツケメタル 1 19 132-16106 OIL SHIELD PLATE ヨウド ウカンコウパツイン 1 20 SS-1060610-SP SCREW 3/32-56 L=5.5 サラネジ 3/32-56 L=5.5 2 21 132-16205 FEED CAM OIL SHIELD PLATE オクリカムエボウパツイン 2 22 SM-6040600-SP OIL SHIELD PLATE アブ ラキリゴムケイタエボウパツイン 1 23 132-16304 OIL SHIELD PLATE アブ ラキリゴムケイタエボウパツイン 1 24 131-22809 DIFFERENTIAL FEED GRADUATION サト ウチョウセツケメモリ 1 25 SM-4051255-SP SCREW M5 L=12 ナベネジ M5 L=12 2 26 131-21405 ADJUSTING STOPPER サト ウチョウセツケストツパー 2 27 SS-4090515-SP SCREW 9/64-40 L=5 ナベネジ 9/64-40 L=5 2 28 WP-0371016-SD WASHER 3 7X8X1 ヒラザガネ 3 7X8X1 2 29 131-20902 SUPPORT SHAFT ヨウド ウカンササエジク 1 30 131-21058 HRUST COLLAR ASM. ササエジク クイヂメカラー (クミ) 1 31 131-21058 HRUST COLLAR (1) ササエジク クイヂメカラー (1) 32 SS-8660330-SP SCREW 1/4-40 L=3.0 トメネジ 1/4-40 L=3 1 33 131-20803 SLIDE BLOCK ヨウド ウカンササエカクコマ 1 34 131-70204 RUBBER RING Oリング 1 35 SM-4040855-SP SCREW ナベネジ 1 36 132-17708 DIFFERENTIAL FEED BLOCK サト ウヒチョウセツケコマ 1 37 RE-0300000-KO E-RING 3 Eガ タトメワ 3 1 38 132-13012 ADJUSTING SCREW ヒチョウセツネツ 1 39 131-23302 DIFFERENTIAL FEED SCREW SPRING サト ウチョウセツケバネ 1 40 131-21306 ADJUSTING LINK サト ウチョウセツケリンク 1 41 RE-0500000-KO E-RING 5 Eガ タトメワ 5 1 42 131-21256 SUPPORT SHAFT COLLAR ASM. ヨウド ウカンササエカラー (クミ) 1 43 131-21207 SUPPORT SHAFT COLLAR ヨウド ウカンササエカラー (1) 44 SS-8110410-TP SCREW 11/64-40 L=3.5 トメネジ 11/64-40 L=3.5 1 45 131-21900 DIFFERENTIAL FEED ROCKER サト ウヒチョウセツケコマ 1 46 SS-6661110-SP SCREW 1/4-40 L=11 ヒラネジ 1/4-40 L=11 1 47 132-17351 ROCKER SHAFT ASM. サト ウチョウセツケクミ 1 48 131-70501 RUBBER RING Oリング 1 49 131-18052 ADJUSTING LEVER SPRING サト ウチョウセツケレバーハネ 1 50 132-15805 DIFFERENTIAL FEED ARM ASM. フクオクリクデクミ 1 51 SS-9111050-SP SCREW 11/64-40 L=9.5 ロツカクボルト 11/64-40 L=9.5 1 52 131-21108 WASHER ヨウド ウカンササエカネ 1 53 TA-0800504-RO PLUG D=8 L=4.5 トメネジ D=8X4.5 1 54 132-00902 FEED MECHANISM COVER PRESSER オクリフタオサエ 1 55 SS-6080340-SP SCREW 1/8-44 L=2.9 ヒラネジ 1/8-44 L=2.9 1 56 132-18102 SLIDE BLOCK フクオクリクビツクコマ 1 57 132-17401 DIFFERENTIAL FEED HINGE SCREW サト ウヒチョウセツネツ 1 58 132-17500 DIFFERENTIAL FEED LOCK NUT サト ウヒチョウロツクナット 1 59 SD-0720271-SP HINGE SCREW D=7.2 H=2.7 ダンネジ D=7.2 H=2.7 1 60 SM-4041055-SP WASHER M4 L=10 ナベネジ M4 L=10 4 61 WP-0460556-SD WASHER 4.6X7.5X0.5 ヒラザガネ 4.6X7.5X0.5 1 62 WP-0480856-SP WASHER 4.8X8.4X0.8 ヒラザガネ 4.8X8.4X0.8 4 63 WP-0621016-SD WASHER 6.2X13X1 ヒラザガネ 6.2X13X1 1 64 131-91606 MAIN FEED DOG シュオクリバ 1 65 119-49807 MAIN FEED DOG (F-25) シュオクリバ (F-25) 1 66 131-92406 MAIN FEED DOG シュオクリバ 1 67 131-92802 DIFFERENTIAL FEED DOG フクオクリバ 1 68 131-93206 DIFFERENTIAL FEED DOG フクオクリバ 1 69 131-93602 DIFFERENTIAL FEED DOG フクオクリバ 1 70 131-91408 AUXILIARY FEED DOG ホンヨウオクリバ 1 71 01...FOR MO-6704S, MO-6714S MO-6704S, MO-6714S用 02...FOR MO-6716S MO-6716S用 03...FOR MO-6704S MO-6704S用 04...FOR MO-6714S MO-6714S用 FOR NO 1,50, ORDER FOR SET ONLY CAN BE ACCEPTED NO.1,50は、セットのみの注文になります。 - 12 - jintex.in

Page 18 — 7. UPPER & LOWER LOOPER COMPONENTS

7. UPPER & LOWER LOOPER COMPONENTS 上ルーパ、下ルーパ関係 10. 11 43 3 59 61 60 2 66~68 23 37~41 4 48 49 53 57.58 72 52 54 7 46 45 15 14 47 12 24 50 31 32 33 29 51 56 19 18 27 28 30 55 16 20 13 65 25 26 22 21 35 36 3 62 64 63 64 69~71 - 13 - jintex.in

Page 19 — D E S C R I P T I O N

REF. NO. NOTE PART NO. DESCRIPTION Qty 1 118-90001 TRAVELING NEEDLE GUARD 1 2 132-22609 LOOPER SHAFT FRONT BUSHING 2 3 132-22708 LOOPER SHAFT REAR BUSHING 2 4 01 131-31057 UPPER LOOPER ARM A ASM. 1 5 131-31008 UPPER LOOPER ARM A (1) 6 SS-9151210-TP SCREW 15/64-28 L=11.8 (1) 7 02 131-31156 UPPER LOOPER ARM B ASM. (1) 8 131-31107 UPPER LOOPER ARM B (1) 9 SS-9151210-TP SCREW 15/64-28 L=11.8 (1) 10 01 400-15637 GUIDE SUPPORT ASM. 1 11 02 400-16841 GUIDE SUPPORT B ASM 1 12 SS-6090630-TP SCREW 9/64-40 L=6 4 13 119-99307 LOWER LOOPER 1 14 01 118-88104 UPPER LOOPER 1 15 02 121-76004 UPPER LOOPER 1 16 PS-0300062-KH SPRING PIN 3X6 1 17 131-70600 RUBBER RING 1 18 SS-6060440-TP SCREW 3/32-56 L=3.5 2 19 131-32550 LOWER LOOPER SUPPORT ARM ASM. (1) 20 131-32501 LOWER LOOPER SUPPORT ARM (1) 21 131-29309 WASHER (1) 22 SS-9151210-TP SCREW 15/64-28 L=11.8 (1) 23 SM-6061200-SP SCREW M6 L=12 2 24 121-23659 OIL SHIELD PLATE ASM. 1 25 123-40600 UPPER LOOPER THREAD GUIDE 1 26 SS-7090850-SP SCREW 9/64-40 L=8 1 27 123-40709 LOWER LOOPER THREAD TAKE-UP 1 28 SS-6080410-SP SCREW 1/8-44 L=4 1 29 132-22401 LOOPER THREAD TAKE-UP COVER 2 30 SM-4040655-SP SCREW M4 L=6 1 31 123-40303 THREAD GUIDE, RIGHT 1 32 SS-3090610-SP SCREW 9/64-40 L=6 1 33 123-40402 THREAD TAKE-UP, RIGHT 1 34 SS-7110840-SP SCREW 11/64-40 L=7.8 1 35 123-40907 LOWER THREAD TAKE-UP, LEFT 1 36 SS-7110840-SP SCREW 11/64-40 L=7.8 1 37 03 131-31206 UPPER LOOPER HOLDER PIN A 1 38 03 131-31305 UPPER LOOPER HOLDER PIN B 1 39 03 131-31404 UPPER LOOPER HOLDER PIN C 1 40 03 131-31503 UPPER LOOPER HOLDER PIN D 1 41 03 131-31602 UPPER LOOPER HOLDER PIN E 1 42 SS-9090610-TP SCREW 9/64-40 L=5.5 1 43 SS-9090410-TP SCREW 1 44 131-31701 OIL WICK STOPPER BALL 1 45 04 131-31909 GUIDE SUPPORT GAUGE 1 46 131-31800 GAUGE FIXING PIN 1 47 05 131-32006 GUIDE SUPPORT GAUGE 1 48 123-40501 THREAD GUIDE, UPPER 1 49 SS-4090615-SP SCREW 9/64-40 L=6 1 50 123-40808 THREAD GUIDE 1 51 SS-3090610-SP SCREW 9/64-40 L=6 1 52 132-22203 UPPER LOOPER GAUGE COVER 1 53 02 132-22302 UPPER LOOPER GAUGE COVER B 1 54 SS-7060610-SP SCREW 3/32-56 L=5.5 2 55 400-10804 OIL SEAL RING 1 56 131-32709 UPPER LOOPER SHAFT RUBBER RING 1 57 CQ-2000000-00 OIL WICK 0.04 58 CQ-2020000-00 OIL WICK 0.04 59 04 131-72853 THRUST COLLAR ASM. 2 60 131-72804 THRUST COLLAR (1) 61 SS-8660610-TP SCREW 1/4-40 L=6 (1) 62 05 131-72853 THRUST COLLAR ASM. (1) 63 131-72804 THRUST COLLAR (1) 64 SS-8660610-TP SCREW 1/4-40 L=6 (1) 65 SS-6090620-TP SCREW 1/4-40 L=6 1 66 03 132-21403 UPPER LOOPER GUIDE A 1 67 03 132-21502 UPPER LOOPER GUIDE B 1 68 03 132-21601 UPPER LOOPER GUIDE C 1 69 03 132-21700 UPPER LOOPER GUIDE A 1 70 03 132-21809 UPPER LOOPER GUIDE B 1 71 03 132-21908 UPPER LOOPER GUIDE C 1 72 400-11234 DUST SEALING FELT 1 NOTE (注記) 01...FOR MO-6704S,MO-6716S MO-6704S,MO-6716S 02...FOR MO-6714S MO-6714S 03...SELECTIVE PARTS 選択部品 04...FOR MO-6704S,MO-6714S MO-6704S,MO-6714S 05...FOR MO-6716S MO-6716S FOR NO.10,11, ORDER FOR SET ONLY CAN BE ACCEPTED NO.10,11は、セットのみの注文になります。 - 14 - jintex.in

Page 21 — 9. PRESSER FOOT COMPONENTS (1)

9. PRESSER FOOT COMPONENTS (1) 押さえ関係 (1) REF. NO. PART NO. D E S C R I P T I O N Qty 1 131-15001 PRESSER FOOT SHAFT オサエ クシタル 1 2 131-15100 PRESSER FOOT SHAFT BUSHING オサエ クシタル クミ 1 3 131-15256 THRUST ARM オサエ クシタル クミ (1) 4 131-15209 THRUST ARM オサエ クシタル クミ (1) 5 SS-6110710-TP SCREW 11/64-40 L= 6.5 ヒラネジ 11/64-40 L=6.5 (1) 6 SS-91512TO-TP SCREW 15/64-28 L=11.8 ロブカクネ 15/64-28 (1) 7 131-16801 LIFTING ARM オサエ アゲ ウデ 1 8 131-15407 PRESSER FOOT ARM HINGE SHAFT オサエ アゲ ウデ ヒンジ グク 1 9 131-15753 PRESSER LIFTING LEVER BASE ASM オサエヒキアゲ レバー ダイクミ 1 10 131-15803 PRESSER LIFTING LEVER BASE オサエヒキアゲ レバー ダイ (1) 11 131-15902 PRESSER LIFTING LEVER オサエヒキアゲ レバー (1) 12 131-16009 PRESSER ARM STOPPER オサエヒキアゲ ストツパー (1) 13 131-16108 PRESSER FOOT LIFTING SPRING オサエヒキアゲ ハネ (1) 14 SS-7110510-SP SCREW 11/64-40 L=5 マルヒラネジ 11/64-40 L=5 (2) 15 SD-0640241-SP HINGE SCREW D= 6.35 H= 2.4 ダンネジ D=6.35 H=2.4 (1) 16 PS-0300142-KH SPRING PIN 0.3 X 14 スプ リングピン 3X14 (1) 17 SS-6080340-SP SCREW 1/8-44 L=2.9 ヒラネジ 1/8-44 L=2.9 (1) 18 131-16207 PRESSER FOOT SPRING オサエハネ 1 19 131-17007 PRESSER LIFTING LEVER SCREW オサエヒキアゲ レバー ネジ 1 20 131-16306 PRESSER LIFTING LEVER SPRING オサエヒキアゲ レバー ハネ 1 21 131-16900 PRESSER LIFTING LEVER オサエヒキアゲ レバー 1 22 131-16405 PRESSER LIFTING HOOK オサエヒキアゲ フツク 1 23 131-16504 LIFTING LEVER ARM SPRING オサエヒキアゲ ウデ ハネ 1 24 131-16603 PRESSER LIFTING LEVER SPRING オサエヒキアゲ レバー ハネ 1 25 NM-6060003-SC NUT M6 ロブカクナット M6 1 26 NS-6110420-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 2 27 SM-6061200-SP SCREW 11/64-40 L=14 マルヒラネジ 11/64-40 L=14 1 28 SS-7110840-SP SCREW 11/64-40 L=4.5 マルヒラネジ 11/64-40 L=4.5 1 29 SS-7111410-TP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 2 30 SS-8110520-TP SCREW 11/64-40 L=14 マルヒラネジ 11/64-40 L=14 1 31 132-12600 PRESSER REGULATOR SCREW オサエチョウセツネジ 1 32 131-15654 PRESSER BAR ASM. オサエチョウセツクミ 1 33 122-88700 PRESSER REGULATOR SCREW WASHER オサエチョウセツワッシャー 1 34 131-17106 PRESSER REGULATOR NUT オサエチョウセツナット 1 35 132-12709 PRESSER BAR COVER オサエ バー カバー 1 36 131-70402 RUBBER RING Oリング 2 37 131-70402 RUBBER RING Oリング 1 38 SN-8040402-TP SCREW M4X0.7 L=4 トメネジ M4X0.7 L=4 1 39 132-12501 PRESSER BAR BUSHING オサエ バー クシタル 1 40 SS-6121020-SP SCREW 3/16-28 L= 9.5 ヒラネジ 3/16-28 L=9.5 1 41 132-12808 ADJUSTING BASE ピツチョウセツダイ 1 42 132-13012 ADJUSTING SCREW ピツチョウセツネジ 1 43 132-12915 ADJUSTING BLOCK ピツチョウセツブロック 1 44 131-23302 ADJUSTING SPRING ピツチョウセツバネ 1 45 SS-7150740-SP SCREW 15/64-28 L=7 マルヒラネジ 15/64-28 L=7 2 46 WP-0460556-SD WASHER 4.5X7.5X0.5 ヒツタワッシャー 4.5X7.5X0.5 1 47 RE-0300000-KO E-RING 3 E-リング 3 1 48 SS-7161040-SP SCREW 1/4-24 L= 9.5 マルヒラネジ 1/4-24 L=9.5 1 - 16 - jintex.in

Page 22 — 10. PRESSER FOOT COMPONENTS (2)

10. PRESSER FOOT COMPONENTS (2) 押さえ関係 (2) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 - 17 - jintex.in

Page 23

REF. NO NOTE PART NO. DESCRIPTION Qty. 1 122-53829 PURESSER FOOT ARM オサエウデ 1 2 131-16702 THREAD TRIMMER イトキリハ 1 3 SS-7060510-SP SCREW 3/32-56 L=4.8 マルヒラネジ 3/32-56 L=4.8 1 4 01 118-76166 PRESSER FOOT ASM. オサエ クミ 1 5 118-76009 PRESSER FOOT HINGE オサエヒンジ 1 6 SS-6090670-TP SCREW 9/64-40 L=6 ヒラネジ 9/64-40 L=6 (1) 7 B1530-804-000 STOPPER オサエ ストツパー (1) 8 WP-0250516-SD WASHER 2.5X6X0.5 ヒラサカガネ 2.5X6X0.5 (1) 9 SS-7060610-SP SCREW 3/32-56 L=5.5 マルヒラネジ 3/32-56 L=5.5 (1) 10 SS-6060210-SP SCREW 3/32-56 L=1.9 ヒラネジ 3/32-56 L=1.9 (1) 11 B1511-814-000 REAR PRESSER FOOT カラカントメ (1) 12 B1507-804-C00 PRESSER FOOT オサエ (1) 13 SS-7080520-SP SCREW 1/8-44 L=4.9 マルヒラネジ 1/8-44 L=4.9 (1) 14 B1508-804-00B SPRING オサエトリツケバネ (1) 15 B1509-804-C00 STITCH TONGUE イトスベリダイ (1) 16 SS-6060440-TP SCREW 3/32-56 L=3.5 ヒラネジ (1) 17 B1510-814-000 CURL GUARD カールトメ (1) 18 131-78306 FINGER GUIDE ユビガード (1) 19 02 118-76869 PRESSER FOOT ASM. オサエ クミ 1 20 118-72009 PRESSER FOOT HINGE オサエヒンジ (1) 21 SS-6090670-TP SCREW 9/64-40 L=6 ヒラネジ 9/64-40 L=6 (1) 22 B1530-804-000 STOPPER オサエ ストツパー (1) 23 WP-0250516-SD WASHER 2.5X6X0.5 ヒラサカガネ 2.5X6X0.5 (1) 24 SS-7060610-SP SCREW 3/32-56 L=5.5 マルヒラネジ 3/32-56 L=5.5 (1) 25 SS-6060210-SP SCREW 3/32-56 L=1.9 ヒラネジ 3/32-56 L=1.9 (1) 26 B1511-814-000 REAR PRESSER FOOT カラカントメ (1) 27 B1507-814-00P PRESSER FOOT オサエ (1) 28 * SS-4080620-TP SCREW 1/8-44 L=6 ナベネジ 1/8-44 L=6 (1) 29 B1508-804-00B SPRING オサエトリツケバネ (1) 30 B1509-814-00P STITCH TONGUE イトスベリダイ (1) 31 SS-6060440-TP SCREW 3/32-56 L=3.5 ヒラネジ (1) 32 B1510-814-000 CURL GUARD カールトメ (1) 33 131-78306 FINGER GUIDE ユビガード (1) 34 * 400-30533 PRESSER FOOT AUXILIARY PLATE オサエホジヨイタ (1) 35 03 121-53763 PRESSER FOOT ASM. ユウオサエクミ(ユビガードツキ) 1 36 SS-6090670-TP SCREW 9/64-40 L=6 ヒラネジ 9/64-40 L=6 (1) 37 121-64802 REAR PRESSER FOOT Uシロ オサエ (1) 38 121-67805 SPRING ウンオサエハネ (1) 39 B1513-816-000 NUT, FOR REAR PRESSER FOOT ダンオサエ ヒンジ ネジ ナツト (1) 40 121-67409 HINGE PIN ユウオサエ ヒンジ ピン (1) 41 121-62202 PRESSER FOOT ユウオサエ (1) 42 121-67607 PRESSER FOOT ARM SPRING オサエウデハネ (1) 43 121-67508 HINGE SCREW ダンオサエ ヒンジ ネジ (1) 44 SS-6060340-SP SCREW 3/32-56 L=2.5 ヒラネジ 3/32-56 L=2.5 (1) 45 B1514-816-000 SCREW オサエウデ パネ トリツケネジ (1) 46 121-67706 PRESSER FOOT オサエ (1) 47 131-78405 FINGER GUIDE ユビガード (1) 48 121-56907 PRESSER FOOT HINGE ユウオサエ ヒンジ (1) NOTE (注記) 01...FOR MO-6704S MO-6704S用 02...FOR MO-6714S MO-6714S用 03...FOR MO-6716S MO-6716S用 - 18 - jintex.in

Page 24 — 11. THREAD TENSION COMPONENTS

11. THREAD TENSION COMPONENTS 糸調子関係 M0 - 6704S 2 29 3 4 M0 - 6714S 2 3 4 M0 - 6716S 2 3 4 20 21 22 23 24 25 26 27 30 1 18-19 11 16 15 14 12 13 5-6-7 8-9-10 44 41 37 40 50 47 32 33 31 48 34 42 43 35 28 45 36 39 38 - 19 - jintex.in

Page 25

REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 132-25008 CENTER THREAD GUIDE チュウカンイトアンナイ 1 2 131-37559 THREAD TENSION SPRING COMPL. イトチョウシハネケヅウク(アカ) (1) 3 01 131-38359 THREAD TENSION SPRING COMPL. イトチョウシハネケヅウク(キ) (1) 4 131-38656 THREAD TENSION SPRING COMPL. イトチョウシハネケヅウク(アオ) (1) 5 131-37807 THREAD TENSION SPRING, RED イトチョウシハネ(アカ) (1) 6 131-38508 THREAD TENSION SPRING, YELLOW イトチョウシハネ(キ) (1) 7 131-38805 THREAD TENSION SPRING, BLUE イトチョウシハネ(アオ) (1) 8 131-37708 THREAD TENSION KNOB, RED イトチョウシツマミ(アカ) (1) 9 131-38409 THREAD TENSION KNOB, YELLOW イトチョウシツマミ(キ) (1) 10 131-38706 THREAD TENSION KNOB, BLUE イトチョウシツマミ(アオ) (1) 11 131-38904 THREAD TENSION BAR イトチョウシボウ (1) 12 131-37609 THREAD TENSION DISK PRESSER イトチョウシラオサエ (1) 13 131-37906 SPRING BUSHING ハネネプツシュ (1) 14 131-38102 THREAD TENSION SPRING FELT イトチョウシハネネザフェルト (1) 15 131-38201 THREAD TENSION DISK イトチョウシラ (2) 16 131-38003 THREAD TENSION RUBBER WASHER トメネジ 11/64-40 L=3.5 (1) 17 04 SS-8110410-TP SCREW 11/64-40 L=3.5 トメネジ 11/64-40 L=3.5 2 18 02 132-25107 TENSION DISK THREAD GUIDE チョウシラアイトアンナイ 3 19 03 132-25107 TENSION DISK THREAD GUIDE チョウシラアイトアンナイ 4 20 04 131-39555 THREAD TENSION POST CONPL. シタイトチョウシボウケツゴウ (1) 21 131-40009 THREAD TENSION POST シタイトチョウシボウ (1) 22 131-39605 TENSION DISK THREAD GUIDE チョウシラアイトアンナイ (1) 23 131-39902 THREAD TENSION SPRING FELT イトチョウシハネネザフェルト (1) 24 131-39803 THREAD TENSION NUT シタイトチョウシナット (1) 25 131-39704 THREAD TENSION SPRING シタイトチョウシハネ (1) 26 229-21407 ROTATION STOPPER イトチョウシラカイテンドメ (1) 27 131-38201 THREAD TENSION DISK イトチョウシラ (2) 28 04 PS-0200052-KH SPRING PIN 2.3X5 スプリングピン 2.3X5 1 29 02 SS-7110710-SL SCREW 11/64-40 L=7.0 マルヒラネジ 11/64-40 L=7 1 30 04 SS-4110615-SP SCREW 11/64-40 L=6 ナベコネジ 11/64-40 L=6 2 31 04 131-28202 THREAD CAM THREAD GUIDE BASE シタイトカムイトアンナイダイ (1) 32 04 131-28301 THREAD CAM THREAD GUIDE A シタイトカムイトアンナイ A (1) 33 04 131-28400 THREAD CAM THREAD GUIDE B シタイトカムイトアンナイ B (1) 34 04 131-28509 LOWER THREAD CAM HOOK シタイトカムツメ (1) 35 04 131-28608 LOWER THREAD GUIDE シタイトアンナイ (1) 36 04 131-28707 THREAD GUIDE BASE SPRING イトアンナイイトメハネ (1) 37 04 131-28805 LOOPER THREAD CAM COMPL. シタイトカムイットウカン (1) 38 04 131-29457 LOWER THREAD CAM COMPL. シタイトカムケツゴウ (1) 39 04 B2202-816-000 SHAFT シタイトカムジク (1) 40 04 131-29101 LOWER THREAD CONDUIT GUIDE シタイトド・ウカンアンナイ (1) 41 04 131-29200 MOUNTING BRACKET シタールーバーイトウカンダイ (1) 42 04 SD-0600341-TP HINGE SCREW D=6.0 H=3.4 タンネジ (1) 43 04 WZ-0640312-KO WAVED WASHER ナミカザカネ 6.4X11X0.3 1 44 04 SM-4050855-SP SCREW M5 L=8 ナベネジ M5 L=8 1 45 04 SS-4090415-SP SCREW 9/64-40 L=4 ナベネジ 9/64-40 L=4 1 46 04 SS-4090415-SP SCREW 9/64-40 L=4 ナベネジ 9/64-40 L=4 1 47 04 SS-4090415-SP SCREW 9/64-40 L=4 ナベネジ 9/64-40 L=4 1 48 04 SS-4090415-SP SCREW 9/64-40 L=4 ナベネジ 9/64-40 L=4 1 49 04 SS-4110515-SP SCREW 11/64-40 L=5 ナベネジ 11/64-40 L=5 1 50 04 SS-5150510-SP SCREW 15/64-28 L=5 トラスネジ 15/64-28 L=5 1 NOTE (注記) 01...FOR MO-6704S(1 PC. IS USED.) MO-6704S用 (1個使い) FOR MO-6714S, MO-6716S MO-6714S, MO-6716S用 (2個使い) 02...FOR MO-6704S MO-6704S用 03...FOR MO-6714S, MO-6716S MO-6714S, MO-6716S用 04...FOR MO-6716S MO-6716S用 - 20 - jintex.in

Page 26 — 12. LOWER KNIFE COMPONENTS

12. LOWER KNIFE COMPONENTS 下メス関係 1 2 3 4 46 6 5 7 8 34 9 10 16 17 18 19 20 26 22 21 27 24 25 28 30 29 31 32 33 11 12 13 14 15 23 - 21 - jintex.in

Page 27

REF. NO NOTE PART NO. DESCRIPTION Qty. 1 01 R4200-J6E-D00 THROAT PLATE ハリイタ 1 2 02 R4305-J6E-E00 THROAT PLATE ハリイタ 1 3 03 R4508-J6E-D00 THROAT PLATE ハリイタ 1 4 SS-2110910-SL SCREW 11/64-40 L=9 マルサラネジ 11/64-40 L=8.5 2 5 131-51204 THROAT PLATE BASE B ハリイタダイ(B) 1 6 SS-6110610-TP SCREW 11/64-40 L=6 ヒラネジ 11/64-40 L=6 2 7 122-88908 THROAT PLATE BASE B SUPPORT ハリイタダイ(B)チサエ 1 8 SM-4051055-SP SCREW ナベネジ 2 9 04 123-47167 LOWER KNIFE BRACKET ASM. シタメスリツケダイクミ 1 10 03 123-47266 LOWER KNIFE BRACKET ASM. シタメスリツケダイクミ 1 11 121-33211 SPRING STOPPER シタメスバネトメ 1 12 118-06304 PLUG ハリイタフタ (1) 13 SS-7110720-SP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 (1) 14 118-46607 SPRING シタメス スライドジク クマノテ (1) 15 121-32619 LOWER KNIFE BRACKET シタメスリツケダイ (1) 16 121-02208 THROAT PLATE BASE A ハリイタダイ A (1) 17 SS-6110610-TP SCREW 11/64-40 L=6 ヒラネジ 11/64-40 L=6 (2) 18 121-03701 RUBBER PLUG B ヌノダイホウシンゴム B (1) 19 132-35304 RUBBER PLUG A ヌノダイホウシンゴム AA (1) 20 04 121-32700 LOWER KNIFE SLIDE STUD シタメス スライド ジク (1) 21 SS-9111010-SP SCREW 11/64-40 L=9.5 ロクカクボルト 11/64-40 L=9.5 (1) 22 121-33104 LOWER KNIFE PRESSER PLATE シタメス オサエ (1) 23 121-02810 LEVER SHAFT ヌノダイ イカイヘレバージク (1) 24 04 121-32908 ROTATING STOPPER シタメス スライド ジク マクリトメ (1) 25 SS-7090710-SP SCREW 9/64-40 L=6.8 マルヒラネジ 9/64-40 L=6.8 (2) 26 03 121-32809 LOWER KNIFE SLIDE STUD シタメス スライド ジク (1) 27 03 121-33005 ROTATING STOPPER シタメス スライド ジク マクリトメ (1) 28 118-46805 HOLDER PIN ササエピン (2) 29 121-03107 RUBBER PLUG カイヘレバボーウシンブッシュ (1) 30 SS-7151120-SP SCREW 15/64-28 L=11 マルヒラネジ 15/64-28 L=11 (1) 31 121-02950 LEVER ASM. ヌノダイ イカイヘレバ ー クミ (1) 32 118-02006 LEVER SPRING ヌノダイ イカイヘレバ ー ハネ (1) 33 118-46805 HOLDER PIN ササエピン (1) 34 SS-6151440-SP SCREW 15/64-28 L=14 ヒラネジ 15/64-28 L=14 2 35 131-51105 NEEDLE HOLDER SUPPORT ハリウケササエ 1 36 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 1 37 01 118-90100 NEEDLE GUARD ハリウケ 1 38 02 118-90308 NEEDLE GUARD ハリウケ 1 39 03 120-15400 NEEDLE HOLDER ハリウケ 1 40 03 121-77903 NEEDLE HOLDER ハリウケ 1 41 03 121-77903 NEEDLE HOLDER ハリウケ 1 42 03 SS-7090510-SP SCREW 9/64-40 L=4.6 マルヒラネジ 9/64-40 L=4.6 1 43 03 SS-7060510-SP SCREW 3/32-56 L=4.8 マルヒラネジ 3/32-56 L=4.8 2 44 SS-7090610-SP SCREW 9/64-40 L=6 マルヒラネジ 9/64-40 L=6 1 45 131-50701 LOWER KNIFE シタメス 1 46 131-02702 THROAT PLATE COVER ハリイタフタ 2 NOTE (注記) 01...FOR MO-6704S MO-6704S用 02...FOR MO-6714S MO-6714S用 03...FOR MO-6716S MO-6716S用 04...FOR MO-6704S,MO-6714S MO-6704S,MO-6714S用 - 22 - jintex.in

Page 28 — 13. UPPER KNIFE COMPONENTS

13. UPPER KNIFE COMPONENTS 上メス関係 REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 131-47558 FEED FORKED ARM ASM. ウワメスフタマタウデ (1) 2 131-47509 FEED FORKED ARM ウワメスフタマタ (1) 3 SM-6061402-TP SCREW M6 L=14 ロツカアナ M6 L=14 (1) 4 131-51303 KNIFE DRIVING ARM SHAFT ヌウデ・シク 1 5 131-50909 BUSHING, FRONT ウワメスジ クマエメタル 1 6 131-51006 BUSHING, REAR ウワメスジ クマエメタル 1 7 01 131-47400 PLAIN KNIFE SUPPORT A ヒラメスササエ(A) 1 8 01 SS-6111040-SP SCREW 11/64-40 L= 9.5 ヒラメネジ 11/64-40 L=9.5 1 9 02 131-47301 PLAIN KNIFE SUPPORT ヒラメスササエ 1 10 02 SS-6111610-SP SCREW 11/64-40 L=16 ヒラメネジ 11/64-40 L=16 1 11 131-50800 UPPER KNIFE GUIDE SHAFT ウワメスガイドシク 1 12 115-66809 OIL SEAL ウワメスジ クオイルシール 1 13 03 131-22007 CRANK PIN A オク リフタマククランクピン A 1 14 03 131-22106 CRANK PIN B オク リフタマククランクピン B 1 15 03 131-22205 CRANK PIN C オク リフタマククランクピン C 1 16 03 131-22304 CRANK PIN D オク リフタマククランクピン D 1 17 01 131-50503 PLAIN KNIFE ヒラメス 1 18 02 131-50602 PLAIN KNIFE ヒラメス 1 19 SS-9090823-TP BOLT 9/64-40 L=8 ロツカボルト 1 20 WP-0370316-SD WASHER 3.7X8X0.3 ヒラザガネ 3.7X8X0.3 1 21 CS-1111019-SH THRUST COLLAR D=11.11 W=10 スラストウケ D=11.11 W=10 (1) 22 CS-1111019-SH THRUST COLLAR D=11.11 W=10 スラストウケ D=11.11 W=10 (1) 23 SS-8660330-SP SCREW 1/4-40 L= 3.0 トメネジ 1/4-40 L=3 (1) NOTE (注記) 01...FOR MO-6704S,MO-6714S MO-6704S,MO-6714S用 02...FOR MO-6716S MO-6716S用 03...SELECTIVE PARTS 選択部品 - 23 - jintex.in

Page 29 — 14. NEEDLE COOLING MECHANISM COMPONENTS (FOR SH)

14. NEEDLE COOLING MECHANISM COMPONENTS (FOR SH) 針冷却装置関係 (SH用) REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 131-63456 SILICON TANK ASM. ハリライトタンククミ 1 2 131-63803 NEEDLE THREAD FELT ハリライトフェルト 1 3 131-63902 NEEDLE THREAD FELT PRESSER ハリライトフェルトオサエ 1 4 TA-0950806-RO RUBBER PLUG トメセン 1 5 SM-4040855-SP SCREW ナベネジ 1 6 01 131-62557 NEEDLE COOLER UNIT ASM. (OVER) ハリレイキャクウチ(オーバー)クミ (1) 7 131-62565 NEEDLE COOLER UNIT COMPL. ハリレイキャクウチ(オーバー)ケツゴウ (1) 8 131-62573 NEEDLE COOLER UNIT ASM. (OVER) ハリレイキャクウチ(オーバー)クミ (1) 9 131-62805 NEEDLE COOLER SUPPORT ハリレイキャクダサエ (1) 10 SS-7090610-SP SCREW 9/64-40 L=6 マルヒラネジ 9/64-40 L=6 (1) 11 131-62904 TANK エスレンタンク (1) 12 131-63001 TANK COVER エスレンタンクフタ (1) 13 SS-4091015-SP SCREW 9/64-40 L=10 ナベネジ 9/64-40 L=10 1 14 WP-0371026-SD WASHER 3.7X7X1 ヒラザガネ 3.7X7X1 1 15 02 131-63159 NEEDLE COOLER UNIT ASM. (INTER) ハリレイキャクウチ(インター)クミ 1 16 131-63167 NEEDLE COOLER COMPL. (INTER) ハリレイキャクウチ(インター)ケツゴウ (1) 17 131-63175 NEEDLE COOLER ASM. (INTER) ハリレイキャクチ(インター)クミ (1) 18 131-62805 NEEDLE COOLER SUPPORT ハリレイキャクダサエ (1) 19 SS-7090610-SP SCREW 9/64-40 L=6 マルヒラネジ 9/64-40 L=6 (1) 20 131-62904 TANK エスレンタンク (1) 21 131-63001 TANK COVER エスレンタンクフタ (1) 22 SS-4091015-SP SCREW 9/64-40 L=10 ナベネジ 9/64-40 L=10 1 23 WP-0371026-SD WASHER 3.7X7X1 ヒラザガネ 3.7X7X1 1 24 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 1 NOTE (注記) 01...FOR MO-6704S,MO-6714S用 MO-6704S,MO-6714S用 02...FOR MO-6716S MO-6716S用 - 24 - jintex.in

Page 30 — 15. LUBRICATION MECHANISM COMPONENTS

15. LUBRICATION MECHANISM COMPONENTS 給油装置関係 25 29 30 48 33 35 47 28 49 27 34 32 36 31 41 37 54 40 38 17 39 51 45 52 36 18 44 24 43 38 19 46 20 63 38 62 64 58 26 57 23 55 56 59 61 60 9 7 8 10 11 12 13 16 14 - 25 - jintex.in

Page 31

REF. NO. NOTE DESCRIPTION Qty. 1 132-30305 WORM ウォーム A 1 2 400-18044 OIL PUMP ASM. キュウユポンプ タイケツゴウ (1) 3 123-15909 OIL PUMP キュウユポンプ タイ (1) 4 133-43009 WORM WHEEL ウォームホイール (1) 5 * SM-8050412-TP SCREW M5 L=4 トメネジ M5 L=4 (2) 6 119-18109 GEAR PUMP SHAFT LARGE ギヤポンプ シャフト タイ (1) 7 B3534-352-000 PINION GEAR ピニオン (2) 8 118-40303 OIL PUMP PINION ボンブ ヨウ ピニオン (2) 9 123-17004 GEAR PUMP SHAFT ギヤポンプ シャフト (ショウ) (1) 10 123-16006 PINION SPACER ピニオン スペーサー (1) 11 123-16105 CASING ケージング (1) 12 400-16762 PUMP COVER ボンブ カバー (1) 13 SS-4112215-SP SCREW 11/64-40 L=22 ナベネジ 11/64-40 L=22 (2) 14 SS-6090810-SP SCREW 9/64-40 L=7.5 ヒラネジ 9/64-40 L=7.5 (3) 15 SQ-1110401-MZ CONNECTING SCREW チューブ レンケツネジ (1) 16 400-16763 PUMP NET ボンブ アミ (1) 17 132-29356 FLOAT ASM. ウキコグミ 1 18 121-29904 OIL GAUGE BAR ユリョウゲージ バー (1) 19 132-29307 FLOAT SUPPORT ウキコ タエ (1) 20 121-29805 FLOAT ウキコ (1) 21 SM-6061802-TP SCREW M6 L=18 ロツカアナボルト 2 22 WP-0651056-SD WASHER 6.5X11X1 ヒラガネ 6.5X11X1 2 23 132-28655 LUBRICATION MECHANISM PIPE ASM. キュウユメカニズムパイプ (1) 24 BP-3000001-OR VINYL PIPE ビニールパイプ 0.03 25 131-42500 CARTRIDGE FILTER カートリッジ フィルタ 1 26 SQ-1150454-SD CONNECTING SCREW ハ イプ レンケツネジ 2 27 131-43805 EXHAUST PORT SUPPORT トシュウケ チササエ 1 28 SM-4060855-SP SCREW ナベネジ M5 L=8 1 29 131-43300 OIL GAUGE オイルゲージ 1 30 131-44001 OIL GAUGE GASKET オイルゲージ パッキン 1 31 SQ-1110451-MZ CONNECTING SCREW ハ イプ レンケツネジ 1 32 NS-6110310-SP NUT 11/64-40 ロツカクナット 11/64-40 1 33 131-42955 FILTER GUIDE ASM. フィルタガイド (クミ) 1 34 131-70808 RUBBER RING Oリング 1 35 SM-4051601-SC SCREW M5X0.8 L=16 ナベネジ M5X0.8 L=16 1 36 SQ-1110451-MZ CONNECTING SCREW ハ イプ レンケツネジ 2 37 SQ-1150451-MZ CONNECTING SCREW チューブ レンケツネジ 3 38 131-42609 OIL TUBE HOLDER ハ イプ ドメ 1 39 131-44100 OILING PIN ハリキュウピン 1 40 131-44209 OIL FELT ハリキュウヒンフェルト 1 41 TA-0400301-MO PLUG D=4X4.5 L=3 トメネジ D=4X4.5 L=3 1 42 SM-8050502-TP SCREW M5 L=5 トメネジ 1 43 131-43417 UPPER LOOPER OILING PIN ウワルーパ キュウユピン 1 44 131-43508 OIL FELT ウワルーパ キュウユフェルト 1 45 132-30107 UPPER LOOPER OILING PIN PLUG ウワルーパ キュウユフェルトンメネジ 1 46 SS-6121020-SP SCREW 3/16-28 L=9.5 ヒラネジ 3/16-28 L=9.5 1 47 131-43607 OIL FELT PRESSER ウワルーパ キュウユフェルトオサエ 1 48 131-43706 OIL FELT ウワルーパ キュウユフェルト 1 49 SS-7060310-SP SCREW 3/32-56 L=3 マルヒラネジ 3/32-56 L=3 1 50 SQ-1150441-SD CONNECTING SCREW ハ イプ レンケツネジ 1 51 132-29208 WORM EXHAUST PORT GUIDE ウオーム トシュウケ ガイド 1 52 NS-6110310-SP NUT 11/64-40 ロツカクナット 11/64-40 1 53 SQ-1110451-MZ CONNECTING SCREW ハ イプ レンケツネジ 0.17 54 236-30007 TUBE チューブ 1 55 132-28804 OIL FELT GUIDE ハリクト ウビン キュウユフェルトガイド 1 56 310-18005 SCREW ナベネジ 2 57 132-29109 OIL FELT B ハリクト ウリンクン キュウユフェルトB 1 58 132-29406 OIL FELT A ハリクト ウリンクン キュウユフェルトA 1 59 132-28903 OIL FELT PRESSER ハリクト ウビン キュウユフェルトオサエ 2 60 310-18005 SCREW ナベネジ 1 61 132-29000 FELT PRESSER SPACER ハリキュウフェルトオサエスペーサー 1 62 BP-3000001-OR VINYL PIPE ビニールパイプ 0.29 63 SQ-0000451-MZ CONNECTING SCREW ハ イプ レンケツネジ 1 64 SM-4060801-SE SCREW ナベネジ 1 - 26 - jintex.in

Page 32 — 16. SEMI-SUNKEN TYPE TABLE COMPONENTS

16. SEMI-SUNKEN TYPE TABLE COMPONENTS 卓上式テーブル関係 15- 21 20 22 26 25 19 13 14 27 2 3 28- 29- 23- REF. NO NOTE PART NO. DESCRIPTION Qty 1 131-61005 CASE SPONGE ケーススポンジ 1 2 131-60908 COOLING FAN CASE クーラーケース 1 3 131-61153 FRAME SUPPORT PLATE ASM. フレームサポートプレートクミ 1 4 01 123-41954 CLOTH WASTE CHUTE ASM. クロスシュート(クミ) (1) 5 123-41905 CLOTH WASTE CHUTE(SEMI-SUNKEN) クロスシュート(セミ・シンケン) (1) 6 123-41806 CLOTH WASTE CHUTE クロスシュート (1) 7 02 131-55759 CLOTH WASTE CHUTE ASM. クロスシュートクミ (1) 8 131-55601 CLOTH WASTE CHUTE INLET クロスシュートインレット (1) 9 131-55700 CLOTH WASTE CHUTE, UPPER クロスシュートウエ (1) 10 131-55502 CHUTE SUPPORT シュートタテ (1) 11 SS-5090610-SP SCREW 9/64-40 L=6 トラスネジ 9/64-40 L=6 (3) 12 NS-609040-SP NUT 9/64-40 ロツカクナット 9/64-40 (3) 13 131-55403 DUST-PROOF RUBBER 防振ゴム 4 14 131-56500 DUST-PROOF RUBBER SPACER 防振ゴムスペーサー 4 15 131-55007 HOLDING PLATE BOLT ウケイタボルト 4 16 02 123-41806 CLOTH WASTE CHUTE クロスシュート 1 17 02 SS-5110710-SP SCREW 11/64-40 L=7 トラスネジ 11/64-40 L=7 2 18 02 SK-2351600-SC WOOD SCREW D=3.5 L=16 マルモクネジ 3 19 111-55108 DRAWER ヒキダシ 1 20 111-55207 DRAWER SUPPORT ヒキダシササエ 2 21 119-59400 TABLE (SEMI-SUNKEN) テーブル(セミ・シンケン) 1 22 D8204-555-D00 DRAWER STOPPER ヒキダシストツパー 1 23 NS-6240630-SE NUT 3/8-18 ロツカクナット 4 24 01 SK-2351600-SC WOOD SCREW D=3.5 L=16 マルモクネジ 6 25 SK-3311500-SC WOOD SCREW D=3.1 L=15 マルモクネジ D=3.1 L=15 6 26 SK-3513200-SC WOOD SCREW D=5.1 L=32 マルモクネジ D=5.1 L=32 4 27 SS-6090630-TP SCREW 9/64-40 G=6 ネジ 9/64-40 G=6 5 28 WP-1002036-SE WASHER 10X21X2 ヒラザガネ 4 29 WS-1002560-KR SPRING WASHER 10X18X2.5 バネザガネ 10X18X2.5 4 NOTE (注記) 01...EXCEPT JE JEは除く 02...FOR JE JE用 - 27 - jintex.in

Page 33 — 17. FULLY-SUNKEN TYPE TABLE COMPONENTS

17. FULLY-SUNKEN TYPE TABLE COMPONENTS 全沈式テーブル関係 17 18 15 19 20 23 24 21 3 25 33 31 34 39 30 16 36 39 27 35 26 39 40 REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 131-61005 CASE SPONGE 1 2 131-60908 CLOTH FAN CASE 2 3 SS-5110710-SP SCREW 11/64-40 L=7 2 4 02 SK-2351600-SC WOOD SCREW D=3.5 L=16 3 5 01 131-55858 CLOTH WASTE CHUTE ASM. (1) 6 131-56203 CLOTH WASTE CHUTE (1) 7 131-56302 CLOTH WASTE CHUTE INLET (1) 8 131-55908 CHUTE INLET LEVER (1) 9 131-56104 CHUTE INLET SPRING (1) 10 131-56104 CHUTE INLET RUBBER (1) 11 SS-6090420-SP SCREW 9/64-40 L=4.0 (2) 12 ST-6030821-0A SCREW D=3-24 L=8 (2) 13 ST-6030821-0A SCREW D=3-24 L=8 (1) 14 WP-0370316-SD WASHER 3.7X8X0.3 (1) 15 119-59558 TABLE ASM. 1 16 131-55403 DUST-PROOF RUBBER 4 17 131-55106 HOLDING PLATE BOLT C 2 18 131-55205 HOLDING PLATE BOLT D 2 19 02 131-55759 CLOTH WASTE CHUTE ASM. (1) 20 131-55601 CLOTH WASTE CHUTE INLET (1) 21 131-55700 CLOTH WASTE CHUTE, UPPER (1) 22 131-55502 CHUTE SUPPORT (1) 23 SS-5090610-SP SCREW 9/64-40 L=6 (3) 24 NS-6090310-SP NUT 9/64-40 (3) 25 02 123-41806 CLOTH WASTE CHUTE 1 26 131-61153 FRAME SUPPORT PLATE ASM. 1 27 131-55304 FRAME HOLDING PLATE COUPLING 1 28 SM-9082513-CF SCREW M8 L=25 4 29 NM-6080600-SM NUT M8 4 30 WP-0850002-SC WASHER 8.5X18X1.6 4 31 SK-3313200-SC WOOD SCREW D=5.1 L=32 4 32 111-55108 DRAWER 1 33 111-55207 DRAWER SUPPORT 2 34 D8204-555-D00 DRAWER STOPPER 1 35 SK-3311500-SC WOOD SCREW D=3.1 L=15 6 36 WS-1002560-KR SPRING WASHER 10X18X2.5 5 37 SS-6090630-TP SCREW 9/64-40 L=6 5 38 SS-5110710-SP SCREW 11/64-40 L=7 12 39 WP-1002036-SE WASHER 10X21X2 12 40 NS-6240630-SE NUT 3/8-18 12 NOTE (注記) 01...EXCEPT JE JEは除く 02...FOR JE JE用 - 28 - jintex.in

Page 34 — 18. STAND COMPONENTS (Z T)

18. STAND COMPONENTS (Z T) 脚関係 (Z T) 1 2 9 11 12 10 6 7 8 3 4 5 13 14 15 16 17 24 22 18 19 20 21 23 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 - 29 - jintex.in

Page 35

REF_NO NOTE PART NO. D E S C R I P T I O N Qty 1 119-60655 T STAND JUNCTION Tキヤクケツゴウ 1 2 111-57567 T LEG JUNCTION Tキヤクケツゴウ (1) 3 GPF-06060000 PEDAL (1) 4 GPF-06070000 PEDAL MAT (1) 5 GPF-06080000 PEDAL ADJUSTING PLATE 77177 チョウセツバン (1) 6 111-59001 PEDAL SHAFT BRACKET 77177 ジクケ (2) 7 D8113-555-B00 PEDAL BUSHING 77177 プツシユ (2) 8 B8153-771-000 PEDAL CONNECTING ROD (1) 9 NM-6080001-SE NUT M8 (2) 10 SL-9082091-SE WASHER HEXAGONAL BOLT (2) 11 WP-0871602-SE WASHER 8.7X18X1.6 (2) 12 SL-9061291-SE WASHER HEXAGONAL BOLT M6 L=12 (2) 13 119-60754 T STAND JUNCTION(WITH CASTER) Tキヤクケツゴウ(キヤスターツキ) 1 14 111-59365 T STAND JUNCTION Tキヤクケツゴウ (1) 15 GPF-06060000 PEDAL (1) 16 GPF-06070000 PEDAL MAT (1) 17 GPF-06080000 PEDAL ADJUSTING PLATE 77177 チョウセツバン (1) 18 111-59001 PEDAL SHAFT BRACKET 77177 ジクケ (2) 19 D8113-555-B00 PEDAL BUSHING 77177 プツシユ (2) 20 B8153-771-000 PEDAL CONNECTING ROD (1) 21 NM-6080001-SE NUT M8 (2) 22 SL-9082091-SE WASHER HEXAGONAL BOLT (2) 23 WP-0871602-SE WASHER 8.7X18X1.6 (2) 24 SL-9061291-SE WASHER HEXAGONAL BOLT M6 L=12 (2) 25 B7114-012-0A0 MOTOR CONNECTING ROD ASM. レンケツボートーヅキテクセミ 1 26 111-51065 Z LEG JUNCTION (B) Zキヤクケツゴウ(B) 1 27 B8151-771-0A0 PEDAL ASM. Zキヤクヨーペダルクミ 1 28 SM-9082023-SE SCREW M8 L=20 (2) 29 WS-0861410-KR SPRING WASHER 8.6X15X1.4 (2) 30 WP-0871602-SE WASHER 8.7X18X1.6 (4) 31 111-51909 PEDAL SHAFT BRACKET 77177 ジクケ (2) 32 NM-6080721-SE NUT M8 (2) 33 D8113-555-B00 PEDAL BUSHING 77177 プツシユ (2) 34 SM-9061203-SE SCREW M6 L=12 (2) 35 WS-0621210-KR SPRING WASHER 6.2X11.4X1.2 (2) 36 WP-0671016-SE WASHER 6.7X13X1 (2) 37 112-46600 PEDAL ADJUSTING PLATE 77177 チョウセツイタ (1) 38 112-46501 PEDAL (1) 39 B8152-771-000 PEDAL MAT (1) 40 B8153-771-000 PEDAL CONNECTING ROD (1) - 30 - jintex.in

Page 36 — 19. THREAD STAND COMPONENTS (FOR MO-6704S,MO-6714S)

19. THREAD STAND COMPONENTS (FOR MO-6704S,MO-6714S) 糸立装置関係(MO-6704S,MO-6714S用) 1 5 17 4 2 17 4 19 7 22 18 11 24 10 23 21 9 8 13 14 15 16 4 17 4 12 29 3 28 29 3 28 25 25 26 27 29 28 - 31 - jintex.in

Page 37

REF. NO. NOTE PART NO. DESCRIPTION 1 131-67556 THREAD STANDING DEVICE ASM. 2 229-30556 SPOOL REST ARM ASM. 3 229-30507 SPOOL REST ARM 4 229-30705 THREAD GUIDE ARM JOINT 5 229-31406 THREAD STANDING ROD RUBBER CAP 6 229-30408 THREAD STANDING ROD, UPPER 7 229-31307 THREAD STANDING ROD JOINT 8 131-67903 THREAD STANDING THREAD GUIDE 9 131-68000 THREAD STANDING GUIDE BASE 10 131-68109 THREAD STANDING GUIDE ARM 11 131-68208 THREAD STANDING GUIDE ARM BASE 12 229-30309 THREAD STANDING ROD, LOWER 13 229-31109 SPOOL RETAINER 14 229-31000 SPOOL PIN 15 229-30903 SPOOL REST CUSHION 16 229-30804 SPOOL REST 17 SM-6061610-SC SCREW M6 L=16 18 SM-4051405-SE SCREW M5 L=14 19 NM-6050001-SE NUT M5 20 SM-4041001-SC SCREW M4X0.7 L=10 21 NM-6040002-SE NUT M4X0.7 22 SM-4041201-SC SCREW M4 L=12 23 SM-4042001-SC SCREW M4 X 20 24 NM-6040002-SE NUT M4X0.7 25 WP-1612616-SE WASHER 16X30X2.6 26 WS-1643202-KR SPRING WASHER 27 NM-6160511-SE NUT M16X1.5 28 NM-6050001-SE NUT M5 29 WS-0510002-KN SPRING WASHER - 32 - jintex.in

Page 38 — 20. THREAD STAND COMPONENTS (MO-6704S,MO-6714S SPECIAL ORDER PARTS)

20. THREAD STAND COMPONENTS (MO-6704S,MO-6714S SPECIAL ORDER PARTS) 糸立装置関係(MO-6704S,MO-6714 特別注文部品) - 33 - jintex.in

Page 39

REF. NO. NOTE PART NO. DESCRIPTION Qty 1 131-67754 THREAD STANDING DEVICE ASM. 1 2 131-68851 THREAD STANDING ARM ASM., LONG (2) 3 131-68505 THREAD GUIDE ARM B (1) 4 131-68802 THREAD STANDING ARM, LONG (2) 5 229-30705 THREAD GUIDE ARM JOINT (4) 6 229-31406 THREAD STANDING ROD RUBBER CAP (1) 7 229-30408 THREAD STANDING ROD, UPPER (1) 8 229-31307 THREAD STANDING ROD JOINT (1) 9 131-67903 THREAD GUIDE (1) 10 131-68000 THREAD GUIDE BASE, LOWER (1) 11 131-68109 THREAD GUIDE ARM (1) 12 131-68208 THREAD GUIDE ARM BASE (1) 13 229-30309 THREAD STANDING ROD, LOWER (1) 14 229-31109 SPOOL RETAINER (4) 15 229-31000 SPOOL PIN (4) 16 229-30903 SPOOL REST CUSHION (4) 17 229-30804 SPOOL REST (1) 18 131-68406 THREAD STANDING ARM SUPPORT, A (4) 19 SM-6061610-SC SCREW M6 L=16 (2) 20 SM-4051405-SE SCREW M5 L=14 (2) 21 NM-6050001-SE NUT M5 (2) 22 SM-4041001-SC SCREW M4X0.7 L=10 (2) 23 NM-6040002-SE NUT M4X0.7 (2) 24 SM-4041201-SC SCREW M4 L=12 (1) 25 SM-4042001-SC SCREW M4 X 20 (1) 26 NM-6040002-SE NUT M4X0.7 (2) 27 WP-1612616-SE WASHER 16X30X2.6 (2) 28 WS-1643202-KR SPRING WASHER (1) 29 NM-6160511-SE NUT M16X1.5 (1) 30 NM-6050001-SE NUT M5 (4) 31 WS-0510002-KN SPRING WASHER (4) 32 SK-3382001-SE SCREW D=3.8 L=20 (2) 33 SM-4061201-SE SCREW M6 L=12 (2) 34 NM-6060001-SE NUT M6 (2) - 34 - jintex.in

Page 40 — 21. THREAD STAND COMPONENTS (FOR MO-6716S)

21. THREAD STAND COMPONENTS (FOR MO-6716S) 糸立装置関係(MO-6716S用) 1 18 5 6 3 2 18 5 8 7 19 20 23 25 12 24 11 22 10 21 9 13 14 15 16 17 4 30 29 30 29 31 26 26 27 28 -35- jintex.in

Page 41

REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 131-67655 THREAD STANDING DEVICE ASM. イトタテウチ(クミ) (1) 2 229-30556 THREAD STANDING ARM ASM. イトタテウデ(クミ) (1) 3 131-68356 THREAD STANDING ARM ASM., LONG イトタテウデ(チョウ)クミ (1) 4 229-30507 THREAD STANDING ARM イトタテウデ (1) 5 229-30705 THREAD GUIDE ARM JOINT イトタテウチ ウシメカクナク (4) 6 229-31406 THREAD STANDING ROD RUBBER CAP イトタテウチ ウホコ・ゴ・ム (1) 7 229-30408 THREAD STANDING ROD, UPPER イトタテウデ ウ(ウエ) (1) 8 229-31307 THREAD STANDING ROD JOINT イトタテウデ ウツギテ (1) 9 131-67903 THREAD GUIDE イトタテイトアンナイ (1) 10 131-68000 THREAD GUIDE BASE, LOWER イトタテイトアンナイ(シタ)ダイ (1) 11 131-68109 THREAD GUIDE ARM イトタテイトアンナイウデ (1) 12 131-68208 THREAD GUIDE ARM BASE イトタテイトアンナイウデ・ダイ (1) 13 229-30309 THREAD STANDING ROD, LOWER イトタテウデ ウ(シタ) (1) 14 229-31109 SPOOL RETAINER イトマキフレド・メ (5) 15 229-31000 SPOOL PIN イトマキウケホク (5) 16 229-30903 SPOOL REST CUSHION イトマキウケザ ラククツション (5) 17 229-30804 SPOOL REST イトマキウケザラ (5) 18 SM-6061610-SC SCREW M6 L=16 セラコネジ M6 L=14 (4) 19 SM-4051405-SE SCREW M5 L=14 ナベコネジ M5 L=14 (2) 20 NM-6050001-SE NUT M5 ロクカクナット M5 (2) 21 SM-4041001-SC SCREW M4X0.7 L=10 ナベコネジ M4X0.7 L=10 (2) 22 NM-6040002-SE NUT M4X0.7 ロクカクナット M4X0.7 2シュ (2) 23 SM-4041201-SC SCREW M4 L=12 ナベコネジ M4 L=12 (1) 24 SM-4042001-SC SCREW M4 X 20 ナベコネジ M4X0.7 L=20 (1) 25 NM-6040002-SE NUT M4X0.7 ロクカクナット M4X0.7 2シュ (2) 26 WP-1612616-SE WASHER 16X30X2.6 ヒラザガネ (2) 27 WS-1643202-KR SPRING WASHER ハネジナガネ 16.4X26.6X3.2 (1) 28 NM-6160511-SE NUT M16X1.5 ロクカクナット M16X1.5 1シュ (1) 29 NM-6050001-SE NUT M5 ロクカクナット M5 (5) 30 WS-0510002-KN SPRING WASHER ハネジナガネ 5.1X9.2X1.3 (5) 31 131-68307 THREAD STANDING ARM, LONG イトタテウデ (チョウ) (1) - 36 - jintex.in

Page 42 — 22. THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS)

22. THREAD STAND COMPONENTS (MO-6716S SPECIAL ORDER PARTS) 糸立装置関係(MO-6716S 特別注文部品) 1 19 6 20 5 20 5 2 20 7 22 8 21 25 27 12 14 27 15 11 24 16 10 23 9 13 20 36 5 32 31 5 20 35 4 32 31 35 33 18 34 32 31 34 4 32 31 35 28 28 29 30 3 33 31 - 37 - jintex.in

Page 43

REF. NO. NOTE PART NO. DESCRIPTION Qty. 1 131-67853 THREAD STANDING DEVICE ASM. 1 2 131-68851 THREAD STANDING ARM ASM., LONG (2) 3 131-68505 THREAD STANDING ARM SUPPORT B (1) 4 131-68802 THREAD STANDING ARM, LONG (2) 5 229-30705 THREAD GUIDE ARM JOINT (6) 6 229-31406 THREAD STANDING ROD RUBBER CAP (1) 7 229-30408 THREAD STANDING ROD, UPPER (1) 8 229-31307 THREAD STANDING ROD JOINT (1) 9 131-67903 THREAD STANDING THREAD GUIDE (1) 10 131-68000 THREAD GUIDE BASE, LOWER (1) 11 131-68109 THREAD GUIDE ARM BASE (1) 12 131-68208 THREAD GUIDE ARM BASE (1) 13 229-30309 THREAD STANDING ROD, LOWER (1) 14 229-31109 SPOOL RETAINER (5) 15 229-31000 SPOOL PIN (5) 16 229-30903 SPOOL REST CUSHION (5) 17 229-30804 SPOOL REST (5) 18 131-68406 THREAD STANDING ARM SUPPORT A (1) 19 131-68950 THREAD STANDING ARM A ASM. (1) 20 SM-6061610-SC SCREW M6 L=16 (6) 21 SM-4051405-SE SCREW M5 L=14 (2) 22 NM-6050001-SE NUT M5 (2) 23 SM-4041001-SC SCREW M4X0.7 L=10 (2) 24 NM-6040002-SE NUT M4X0.7 (2) 25 SM-4041201-SC SCREW M4 L=12 (1) 26 SM-4042001-SC SCREW M4 X 20 (1) 27 NM-6040002-SE NUT M4X0.7 (2) 28 WP-1612616-SE WASHER 16X30X2.6 (2) 29 WS-1643202-KR SPRING WASHER (1) 30 NM-6160511-SE NUT M16X1.5 (1) 31 NM-6050001-SE NUT M5 (5) 32 WS-0510002-KN SPRING WASHER (5) 33 SK-3382001-SE SCREW D=3.8 L=20 (2) 34 SM-4061201-SE SCREW M6 L=12 (2) 35 NM-6060001-SE NUT M6 (2) 36 131-68901 THREAD STANDING ARM A (1) - 38 - jintex.in

Page 44 — 23. SPECIAL ORDER PARTS COMPONENTS

23. SPECIAL ORDER PARTS COMPONENTS 特別注文部品関係 1 2 3 5 12 6 64 11 7 20 10 13 14 15 16 8 18 17 19 4 9 22 21 23 24 26 25 27 55 45 48 46 49 52 54 51 53 47 50 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 56 57 59 58 60 62 61 - 39 - jintex.in

Page 45

REF. NO NOTE PART NO. DESCRIPTION Qty. 1 SS-8080322-TP SCREW 1/8-44 L=3.2 1 2 SS-8080322-TP SCREW 1/8-44 L=3.2 2 3 B9112-804-000 SPANNER 1 4 121-20713 CHAIN LOOPER 1 5 115-44707 UPPER LOOPER SUPPORT ARM 1 6 01 118-98103 PRESSER FOOT AUXILIARY PLATE 1 7 121-23709 LOWER LOOPER SUPPORT ARM 1 8 B2519-804-000 UPPER LOOPER 1 9 03 B2519-814-000 UPPER LOOPER 1 10 B2521-804-000 LOWER LOOPER 1 11 01 SS-4080620-TP SCREW 1/8-44 L=6 1 12 SS-6080410-SP SCREW 1/8-44 L=4 1 13 118-47605 LOWER KNIFE 1 14 119-64509 CERAMIC LOWER KNIFE 1 15 119-92005 LOWER KNIFE 1 16 119-65753 PEDAL ASM. 1 17 SM-9061203-SE SCREW M6 L=12 (2) 18 119-65704 PEDAL (2) 19 119-65803 PEDAL THRUST COLLAR 20 PS-0200062-KH SPRING PIN 2X6 1 21 05 121-05458 CLOTH PLATE ASM. (1) 22 121-04550 CLOTH PLATE ASM. (1) 23 115-01301 ECCENTRIC BUSHING (1) 24 WZ-0420350-KP DISC SPRING (1) 25 CS-0400671-SD THRUST HOLDER (1) 26 SM-8040302-TP SETSCREW (1) 27 05 119-49104 CLOTH BASE COVER 1 28 01 B1539-804-000 PRESSER FOOT FIXING PLATE 1 29 01 SS-6060410-TP SCREW 3/32-56 L=3.5 1 30 04 121-52468 PRESSER FOOT, (FINGER GUARD). 1 31 118-72009 PRESSER FOOT HINGE (1) 32 SS-6090670-TP SCREW 9/64-40 L=6 (1) 33 B1530-804-000 STOPPER (1) 34 WP-0250516-SD WASHER 2.5X6X0.5 (1) 35 SS-7060610-SP SCREW 3/32-56 L=5.5 (1) 36 SS-6060210-SP SCREW 3/32-56 L=1.9 (1) 37 B1511-814-000 REAR PRESSER FOOT (1) 38 B1507-814-00P PRESSER FOOT (1) 39 SS-7080520-SP SCREW 1/8-44 L=4.9 (1) 40 B1508-804-00B SPRING (1) 41 121-60008 STITCH TONGUE (1) 42 SS-6060440-TP SCREW 3/32-56 L=3.5 1 43 B1510-814-000 CURL GUARD 1 44 131-78306 FINGER GUARD 1 45 01 115-98000 UPPER KNIFE SUPPORT 1 46 01 118-45807 UPPER KNIFE 1 47 01 SS-9111610-SP SCREW 11/64-40 L=16 1 48 05 118-45500 UPPER KNIFE SUPPORT 1 49 118-45906 UPPER KNIFE 1 50 05 SS-9112310-SP SCREW 11/64-40 L=23 1 51 05 115-65504 UPPER KNIFE PRESSER PLATE 1 52 115-65702 WASHER 1 53 118-48405 UPPER KNIFE COVER 1 54 SS-4060310-SP SCREW 3/32-56 L=2.5 1 55 SS-4060310-SP SCREW 3/32-56 L=2.5 1 56 400-25294 SYNCHRONIZER TURN STOPPER ASM. (1) 57 * 400-11755 SYNCHRONIZER TURN STOPPER ASM. (1) 58 400-11757 SYNCHRONIZER STOPPER BASE (1) 59 400-22255 SYNCHRONIZER STOPPER (1) 60 SS-5120810-SP SCREW (1) 61 SS-9154540-SP SCREW 15/64-28 L=45 (1) 62 400-11758 SYNCHRONIZER BASE COLLAR (1) 63 * 400-36778 V BELT SLIDER 1 64 *04 400-30533 PRESSER FOOT AUXILIARY PLATE 1 NOTE (注記) 01...FOR MO-6704S MO-6704S用 02...FOR MO-6714S, MO-6716S MO-6714S, MO-6716S用 03...FOR MO-6704S, MO-6716S MO-6704S, MO-6716S用 04...FOR MO-6714S MO-6714S用 05...FOR MO-6716S MO-6716S用 - 40 - jntex.in

Page 46 — 24. ACCESSORIES PARTS COMPONENTS

24. ACCESSORIES PARTS COMPONENTS 付属品関係 REF. NO. NOTE PART NO. DESCRIPTION Qty 1 131-60858 ACCESSORIE BAG ASM. フツク クレンツク"(クミ) 1 2 131-60007 RING SPANNER メカ"ネレンチ(7X7) (1) 3 131-60205 PIN SPANNER シュオクリクテ"ピンヌハナ (1) 4 229-32800 ACCESSORIE BAG フツク クレンツク" (1) 5 229-33105 SCREW DRIVER, MIDDLE ト"ライバー(チュウ) (1) 6 123-47308 SCREW DRIVER (SMALL) ト"ライバー(シヨウ) (1) 7 131-60106 SPANNER (5X6) スハ"ナ(5X6) (1) 8 131-60304 S SHAPED HOOK S"カ"タカナク" (2) 9 131-60403 CHAIN クサリ (1) 10 122-88403 TWEEZERS ピンセット (1) 11 131-60601 FUNNEL ジ"ョーゴ 1 12 229-33006 SCREW DRIVER, LARGE ト"ライバー-(タイ) 1 13 229-33303 VINYL COVER トウフ"ア"ビニールカハ"ー 1 14 MDC-270B1104 NEEDLE DCX27 #11-4EA. ハリ DCX27 #11-4 1 15 MML-018900CA JUKI MACHINE OIL 18 JUKI MACHINE OIL 18 1 16 131-42500 CARTRIDGE FILTER カートリツジ フィルタ 1 - 41 - jintex.in

Page 47 — 25. LIST FOR INFORMATION OF CHANGE

25. LIST FOR INFORMATION OF CHANGE 変更情報リスト As to the place changed, refer to the corresponding Rev.No. When previous parts(Obsoleted part)and new parts(Added parts)are not interchangeable with each other: In this case,even obsoleted parts(D.)can be ordered with the obsoleted part number,so select the parts with changed dates and place your orders. 変更箇所は、該当Rev.No.版をご参照ください。 部品の互換性がない変更の場合は、削除された品番でも、ご注文できます。 29355401 No.1329-03 Rev.No. *A: Added parts追加部品/D:Obsoleted parts削除部品/E:Erratum訂正 Rev. Page Ref. Parts No. No. 頁 No. 品 番 D 02 18 28 SS-7080520-SP D 02 26 4 122-56103 D 02 26 5 SS-8110410-TP D 02 40 4 119-96907 Rev. Page Ref. Parts No. No. 頁 No. 品 番 A 03 6 48 400-35711 A 03 18 28 SS-4080620-TP A 03 18 34 400-30533 A 03 26 4 133-43009 A 03 26 5 SM-8050412-TP A 03 40 4 121-20713 A 03 40 57 400-11755 A 03 40 63 400-36778 A 03 40 64 400-30533 - 42 - jintex.in

Page 51 — NUMERICAL INDEX OF PARTS

N U M E R I C A L I N D E X O F P A R T S 索引 PART NO PAGE REF PART NO PAGE REF PART NO PAGE REF 品番頁 NO 品番頁 NO 品番頁 NO 132-04003 4 35 132-30305 26 1 400-23234 6 2 132-05406 6 19 132-35304 22 19 400-23235 6 1 132-07808 8 68 132-40106 2 48 400-25294 40 56 132-08004 8 17 132-40106 2 49 400-30533 18 34 132-08103 8 17 132-40106 2 50 400-30533 40 64 132-08350 8 16 132-41109 10 30 400-35711 6 48 132-08459 8 42 132-41109 10 36 400-36778 40 63 132-08509 8 43 133-43009 26 4 132-08608 8 47 132-08707 8 30 229-01805 4 37 132-08806 8 28 229-21407 20 26 132-09101 8 9 229-24708 4 8 132-09309 8 11 229-30309 32 12 132-09309 8 11 229-30309 34 13 132-09507 8 13 229-30408 32 6 132-09507 8 13 229-30408 34 7 132-09606 8 14 229-30408 36 7 132-09705 8 19 229-30408 38 7 132-09853 8 6 229-30507 32 3 132-12501 16 39 229-30507 36 4 132-12600 16 31 229-30556 32 2 132-12709 16 35 229-30556 36 2 132-12808 16 41 229-30705 32 4 132-12915 16 43 229-30705 34 5 132-13012 12 38 229-30705 36 5 132-13012 16 42 229-30705 38 5 132-15157 12 1 229-30804 32 16 132-15405 12 5 229-30804 34 17 132-15405 12 5 229-30804 36 17 132-15504 12 6 229-30804 38 17 132-15603 12 7 229-30903 32 16 132-15702 12 11 229-30903 34 16 132-15801 12 17 229-30903 36 16 132-15900 12 13 229-30903 38 16 132-16007 12 14 229-31000 32 14 132-16106 12 19 229-31000 34 15 132-16205 12 21 229-31000 36 15 132-16304 12 23 229-31000 38 15 132-16601 10 28 229-31109 32 13 132-16700 10 29 229-31109 34 14 132-16809 10 26 229-31109 36 14 132-17351 12 47 229-31109 38 14 132-17401 12 57 229-31307 32 7 132-17500 12 58 229-31307 34 8 132-17708 12 36 229-31307 36 8 132-17807 10 12 229-31307 38 8 132-17906 10 31 229-31406 32 5 132-18052 12 50 229-31406 34 6 132-18102 12 56 229-31406 36 6 132-20009 15 15 229-31406 38 6 132-21403 14 66 229-32800 41 4 132-21502 14 67 229-33006 41 12 132-21601 14 68 229-33105 41 5 132-21700 14 69 229-33303 41 13 132-21809 14 70 236-30007 8 45 132-21908 14 71 236-30007 26 54 132-22203 14 52 132-22302 14 53 310-18005 26 56 132-22401 14 29 310-18005 26 60 132-22609 14 2 132-22708 14 3 400-10804 14 55 132-25008 20 1 400-11234 14 72 132-25107 20 18 400-11755 40 57 132-25107 20 19 400-11757 40 58 132-28655 26 23 400-11758 40 62 132-28903 26 59 400-15637 14 10 132-29000 26 61 400-16763 26 16 132-29109 26 57 400-16763 26 16 132-29208 26 51 400-17714 14 11 132-29307 26 19 400-17714 6 47 132-29356 26 17 400-17824 6 41 132-29406 26 58 400-18044 26 2 132-30107 26 45 400-22255 40 59 - 46 - jintex.in

Page 52

JUKI JUKI CORPORATION Copyright © 2002-2006 JUKI CORP. 本書の内容を無断で転載、複写すること を禁止します。 All rights reserved throughout the world. JUKI株式会社 お買い求め、ご相談は To order or for further information, please contact : ※このパーツリストは商品改良のため予告なく変更する事があります。 *The description covered in this parts list is subject to change for improvement of the commodity without notice. ※このパーツリストは、2006年3月現在の商品仕様で編集したものです。 *This parts list is edited in accordance with the product specifications as of March 2006. Printed in Japan jintex.in

Page 53 — PARTS LIST

JUKI 1-Needle Lockstitch Straight Button-Holing Industrial Sewing Machine 高速一本針本縫眠り穴かがりミシン LBH-761 LBH-762 LBH-763 & Subclasses PARTS LIST BE7610TOPJA No.0029-12 jintex.in
