Page 6 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS (1)

Juki LZ-2290A parts on page 6

Ref	Part number	Part name	Qty
	30	53
	45	42
	51	35
	60	40
	47	54
	44	43
	2	61
	58	63
	67	68
	64	70
	66	65
	69	56
	36	34
	55	3
	57	50
	52	49
	59	7~25
	26	27
	41	6
	39	37
	29	28
	31	4
	5	33
	32	50
	81	73
	79	75
	76	74
	77	71 72
	83	84
	82	80
	78	38

Page 7

Juki LZ-2290A parts on page 7

Ref	Part number	Part name	Qty
	235-00978	FACE PLATE COMPL.
	235-26205	SIDE PLATE
	235-26403	BED SUPPORT PLATE
	235-26403	BED SUPPORT PLATE B
	400-11123	THREAD RELEASE AUXILIARY PIN
	225-28764	PRE-TENSION CONTROLLER ASM.
#02	M6095-350-CAA	RESISTANCE PACK CA ASM.
#03	M6096-350-CAL	RESISTANCE PACK CL ASM.
#05	M6095-350-CAF	RESISTANCE PACK CF ASM.
#03	M6096-350-CAF	RESISTANCE PACK CF ASM.
#04	400-03625	RESISTANCE PACK CB 40
#04	400-03626	RESISTANCE PACK CB 45
#05	400-03623	RESISTANCE PACK CB 40U
#05	400-03624	RESISTANCE PACK CB 45U
#07	M6100-350-CAA	RESISTANCE PACK CA ASM.
#08	M6095-350-CAF	RESISTANCE PACK CF ASM.
#09	M6099-350-CAF	RESISTANCE PACK CF ASM.
#10	M6099-350-CAF	RESISTANCE PACK CF ASM.
#11	M6099-350-CAL	RESISTANCE PACK CL ASM.
#11	M6098-350-CAF	RESISTANCE PACK CF ASM.
#11	M6098-350-CAA	RESISTANCE PACK CA ASM.
#12	400-17100	RESISTANCE PACK WB40
#01	400-17101	RESISTANCE PACK CB40
#01	400-17102	RESISTANCE PACK CB45
	400-00004	PULLEY COVER
	236-00604	BOLT
	SL-6052592-TN	AIR-DISCHARGING CAP
	236-01305	AIR-DISCHARGING
	236-29900	AIR-DISCHARGING
	100-01709	TAKE-UP THREAD CUTTER
	TA-1250705-RO	RUBBER PLUG
	137-47308	SUSPENSION SCREW
	229-20409	THREAD RELEASE PIN SPRING
	SS-8110750-SP	SCREW 11/64-40 L=6.5
	CM-30002000-01	ATTENTION SEAL
	GPR-01015000	RUBBER RING
	RO-0801502-00	RUBBER RING
	RO-1331701-00	SPRING PIN 8X20
	PS-0800202-KH	HINGE SCREW D=6.35 H=7.5
	SD-0640751-SP	CABLE BAND
	EA-9500B01-00	SCREW 11/64-40 L=7
	SS-1110710-SP	SCREW 9/64-40 L=7.2
	SS-2090710-TP	SCREW 11/64-40 L=9
	SS-410915-SP	BALANCE COVER BASE
	263-05102	BALANCE THREAD GUIDE B
	263-05409	BALANCE COVER
	SS-4120615-SP	SCREW 3/16-28 L=6
	SS-4120915-SP	SCREW 3/16-28 L=9
	SS-4121015-SP	SCREW 3/16-28 L=10
	SS-4150915-SP	SCREW 15/64-28 L=9
	225-02108	BALANCE COVER
	225-27401	FACE PLATE PACKING
	TA-7080410-SP	SCREW 1/8-44 L=3.8
	263-05300	BALANCE COVER STOPPER SPRING
	400-03588	HEAD SUPPORT A POKING
	TA-0800504-RO	PLUG D=8 L=4.5
	TA-1250406-RO	RUBBER PLUG D=12.5 L=4
	WP-0501016-SD	WASHER 5X10.5X1
	WP-0651056-SD	WASHER 6.5X11X1
	D2112-555-B00	CORD HOLDER LARGE
	WZ-0641510-KP	WAVED WASHER 6.4X11X0.3
	400-22407	CORD HOLDER
	WP-0330500-0E	WASHER 3.3X6X0.5
#06	225-29000	SUPPORT BALANCE
#06	225-29101	SUPPORT BALANCE BASE
#06	225-29200	MOUNTING BASE
#06	SS-6090540-SP	SCREW 11/64-40 L=9
#06	SS-6580752-TP	SCREW 9/64-40 L=5.0
#06	400-03633	THREAD TENSION ASM. B
#06	400-03634	THREAD TENSION ASM. A
#06	SS-8090670-SP	SCREW 1/8-40 L=7
#06	235-38309	THREAD TAKE-UP SPRING
#06	235-47557	FELT
#06	225-28509	ROTATION STOPPER
#06	229-21407	THREAD TENSION ROD BASE ASM.
#06	235-37665	THREAD TENSION ROD COMPL.
#06	235-37756	THREAD RELEASE PIN
#06	235-37814	THREAD TENSION NUT
#06	B3121-352-000	TENSION SPRING
#06	B3129-012-A00	TENSION SPRING
#01	LZ-2290A-SR-7-CB	VARIOUS NOS. FOR DESTINATIONS
#02	LZ-2290A-SU-OB,	VARIOUS NOS. FOR DESTINATIONS
	LZ-2290A-SU-7-WB	VARIOUS NOS. FOR DESTINATIONS
#03	LZ-2290A-SS-7-CB	VARIOUS NOS. FOR DESTINATIONS
#04	LZ-2290A-DS-7-CB,	VARIOUS NOS. FOR DESTINATIONS
#05	LZ-2290A-DS-OB,	VARIOUS NOS. FOR DESTINATIONS
	LZ-2290A-DU-	VARIOUS NOS. FOR DESTINATIONS
#06	LZ-2290A-DU-7-WB	VARIOUS NOS. FOR DESTINATIONS
#07	LZ-2290A-DU-7-CB	VARIOUS NOS. FOR DESTINATIONS
#08	LZ-2290A-SS,	VARIOUS NOS. FOR DESTINATIONS
#09	LZ-2290A-SS-OB	VARIOUS NOS. FOR DESTINATIONS
#10	LZ-2290A-SU,	VARIOUS NOS. FOR DESTINATIONS
#11	LZ-2290A-SU-OB	VARIOUS NOS. FOR DESTINATIONS
#12	LZ-2290A-SR-7-WB	VARIOUS NOS. FOR DESTINATIONS

Page 8 — 2. FRAME & MISCELLANEOUS COVER COMPONENTS (2)

Juki LZ-2290A parts on page 8

Ref	Part number	Part name	Qty
48	48	SCREW
47	47	WASHER
39	39	SPRING
29	29	BOBBIN CASE
40	40	PLATE
38	38	SHAFT
43	43	COLLAR
31	31	SPRING
37	37	SHAFT
30	30	SUPPORT
44	44	SPRING
33	33	SPRING
41	41	BEARING
49	49	COLLAR
36	36	COLLAR
35	35	SPRING
32	32	SHAFT
46	46	SPRING
50	50	COLLAR
34	34	RING
42	42	RING
59	59	BRACKET
90	90	SCREW
89	89	WASHER
88	88	COVER
87	87	COVER
18	18	SCREW
17	17	SCREW
10	10	BASE PLATE
9	9	PLATE
7	7	PLATE
12	12	PLATE
11	11	PLATE
13	13	BRACKET
27	27	BRACKET
24	24	RING
76	76	SHAFT
77	77	SHAFT
58	58	SCREW
57	57	SCREW
56	56	LEVER
52	52	SCREW
83	83	WASHER
53	53	RING
55	55	SCREW
54	54	SCREW
4	4	COVER
2	2	GASKET
1	1	COVER
14	14	PLATE
21	21	SCREW
22	22	SCREW
5	5	PLATE
20	20	SCREW
23	23	SCREW
63	63	SCREW
62	62	BRACKET
60	60	ROD
75	75	BRACKET
19	19	SCREW
6	6	ROD
8	8	RING
15	15	PLATE
25	25	PLATE
26	26	SCREW
97	97	SCREW
85	85	PLATE
61	61	GUIDE
64	64	BRACKET
65	65	BRACKET
69	69	PLATE
66	66	SPRING
67	67	SPRING
68	68	SCREW
73	73	BRACKET
70	70	ROD
71	71	ROD
72	72	ROD
74	74	BRACKET
3	3	COVER
79	79	WIRE HARNESS
80	80	WIRE HARNESS
81	81	BRACKET
82	82	PLATE
86	86	SCREW
51	51	SPRING
91	91	SHAFT
95	95	COLLAR
94	94	COLLAR
93	93	COLLAR
92	92	COLLAR
96	96	SPRING
28	28	COVER

Page 9

Juki LZ-2290A parts on page 9

Ref	Part number	Part name	Qty
	400-11345	GEAR BOX (LARGE) COVER
	235-26601	GEAR BOX (LARGE) PACKING
	400-28463	GEAR BOX (SMALL) COVER
	235-26809	GEAR BOX (SMALL) PACKING
	235-27203	PIPE GUIDE PLATE
	M8524-476-AA0	GROUND WIRE A ASM.
	225-83407	NEEDLE PLATE
	229-01805	GROUND MARK
	263-00103	SEMILUNAR PLATE
	263-14757	BED SLIDE ASM.
	110-01609	BED SLIDE SPRING
	SS-6060210-SP	SCREW 3/32-56 L=1.9
	CM-3002000-01	ATTENTION SEAL
	262-30409	LUBRICATING OIL WICK STOPPER
	CM-3013000-01	SAFETY LABEL
	CM-3013000-01	SAFETY LABEL
	SS-2090810-SP	SCREW 9/64-40 L=7.5
	SS-2090810-SP	SCREW 9/64-40 L=7.5
	SS-4120615-SP	SCREW 3/16-28 L=6
	SS-4120615-SP	SCREW 3/16-28 L=6
	SS-4120615-SP	SCREW 3/16-28 L=6
	SS-4120915-SP	SCREW 3/16-28 L=9
	SS-4120915-SP	SCREW 3/16-28 L=9
	400-28294	FEED_ADJUSTING_CAP
	260-25106	SPACER
	SL-4051091-SC	SCREW M5X0.8 L=10
	225-03908	SPACER
	400-26835	BOBBIN WINDER UNIT
	262-60109	BTW_BASE
	262-60208	BTW_CAM_PLATE
	262-60307	BTW_BASE_SHAFT
	262-60406	BTW_SHAFT_BASE
	262-60505	BTW_CAM_LEVER
	262-60604	BTW_WHEEL
	400-11144	BTW_TORSION_SPRING
	262-60802	BTW_BEARING_SPACER
	400-14837	BTW_SHAFT
	262-61008	BTW_LEVER_SHAFT
	400-21933	BTW_LEVER
	262-61206	BTW_SPACER
	262-61305	BTW_BEARING
	262-61503	BTW_WHEEL_RUBBER
	262-61602	BOBBIN_SPRING
	262-61701	BTW_SPRING
	RC-0560711-KP	RETAINING RING
	RE-0400000-KO	E-RING 4
	WP-0450826-SC	WASHER 4.5X10X0.8
	SM-5040655-SN	SCREW
	SM-8050502-TP	SCREW M5 L=5
	SM-8040802-TP	SCREW M4X8
	SS-7090410-SP	SCREW 9/64-40 L=3.5
	SM-4040655-SP	SCREW M4 L=6
	110-33008	MAGNET
	400-24644	MAGNET WASHER
	ST-4040821-SS	TAPPING SCREW
	400-37008	THREAD_CUTTER
	SM-0051001-SC	SCREW
	SM-0051001-SC	SCREW
	SS-8111251-SP	SCREW 11/64-40 L=12.0
	EA-9500B02-00	CABLE BAND 150
	236-29108	OIL SIGHT WINDOW
	235-39901	HEAD LUBRICATION PPE STOPPER
	SS-4120615-SP	SCREW 3/16-28 L=6
	235-41352	SAFETY SWITCH ASM.
	235-41303	SAFETY SWITCH BASE
	236-38109	SAFETY SWITCH ARM.
	236-38208	SAFETY SWITCH SPRING
	236-38307	SAFETY SWITCH ARM SHAFT
	236-38406	SAFETY SWITCH STOPPER PLATE
	235-41451	SAFETY SWITCH CORD ASM.
	HK-0346100-60	HOUSING 6P
	EA-9500B01-00	CABLE BAND
	SM-4021201-SC	SCREW M2 L=12
	SS-4120915-SP	SCREW 3/16-28 L=9
	CM-3002000-03	ATTENTION LABEL
	229-58300	NEEDLE THREAD GUIDE PIN
	225-02504	THREAD GUIDE BAR
	225-02702	SPRING GUARD
	400-06012	PM RELAY CABLE A ASM.
	400-06013	PM RELAY CABLE B ASM.
	263-12504	BALANCE THREAD GUIDE
	225-04104	BALANCE THREAD GUIDE A
	400-35589	RULER PLATE
	110-43601	RUBBER STOPPER
	401-16677	GOST_SAFETY_LABEL_S
	SS-1110840-SP	SCREW 11/64-40 L=8
	400-26836	BOBBIN WINDER DRIVING WHEEL ASM.
	400-20454	BTW DRIVING WHEEL ASM.
	235-28607	BOBBIN DRIVING BLADE
	SM-4030501-SN	SCREW M3 L=5
	225-29481	BOBBIN THREAD TENSION ASM.
	225-29473	BOBBIN THREAD TENSION ROD ASM.
	B3214-047-000	BOBBIN WINDER TENSION DISC
	110-93606	THREAD TENSION SPRING
	110-72402	THREAD TENSION NUT
	NS-6110310-SP	NUT 11/64-40
	CM-6001001-01	WEEE MARK LABEL S

Page 10 — 3. MAIN SHAFT & THREAD TAKE-UP & NEEDLE BAR COMPONENTS

Juki LZ-2290A parts on page 10

Ref	Part number	Part name	Qty
	1	MAIN SHAFT
	2	THREAD TAKE-UP LEVER
	3	BELT PULLEY
	4	CRANK
	5	NEEDLE BAR
	6	NEEDLE BAR BUSHING
	7	NEEDLE BAR BUSHING
	8	WASHER
	9	NEEDLE BAR CONNECTING ROD
	10	NEEDLE BAR CONNECTING ROD BUSHING
	11	SCREW
	12	SCREW
	13	SCREW
	14	BEARING
	15	BEARING
	16	BRACKET
	17	BELT
	18	MOTOR HOUSING
	19	MOTOR BRACKET
	20	SCREW
	21	PULLEY
	22	BEARING
	23	MOTOR BRACKET
	24	SCREW
	25	PLATE
	26	SCREW
	27	NEEDLE BAR
	28	SCREW
	29	SCREW
	30	THREAD TAKE-UP LEVER BRACKET
	31	SCREW
	32	SCREW
	33	THREAD TAKE-UP LEVER BRACKET
	34	THREAD TAKE-UP LEVER BRACKET
	35	BEARING
	36	BRACKET
	37	SCREW
	38	NEEDLE BAR CONNECTING ROD
	39	SCREW
	40	SCREW
	41	SCREW
	42	SCREW
	43	SCREW
	44	NEEDLE BAR
	45	NEEDLE BAR
	46	BEARING
	47	SCREW
	48	SCREW
	49	SCREW
	50	SCREW
	51	NEEDLE BAR
	52	NEEDLE BAR
	53	NEEDLE BAR
	54	NEEDLE BAR
	55	NEEDLE BAR
	56	NEEDLE BAR
	57	NEEDLE BAR
	58	NEEDLE BAR
	59	SLEEVE
	60	BEARING
	61	NEEDLE BAR
	62	NEEDLE BAR
	63	SCREW
	64	NEEDLE BAR
	65	SCREW
	66	BEARING
	67	SPRING
	68	SCREW
	69	NUT
	70	NEEDLE BAR

Page 11

Juki LZ-2290A parts on page 11

Ref	Part number	Part name	Qty
	235-27906	UPPER SHAFT	1
	400-10324	COUNTER WEIGHT	1
	401-60261	UPPER_SHAFT_SPROCKET	1
	235-28102	NEEDLE ROD CRANK	1
	235-28250	HAND WHEEL ASM	1
	235-28359	MAGNET FITTING BASE COMPL. U	(1)
	235-28458	MAGNET FITTING BASE COMPL. D	(1)
	236-05009	HAND WHEEL WASHER	(2)
	236-04804	BALANCE PLATE	(1)
	235-28201	HAND WHEEL	(1)
	SL-4040881-SC	SCREW M4 L=8	(2)
	SL-4040881-SC	SCREW M4 L=8	(2)
	SM-8060812-TP	SCREW M6 L=8	(2)
	SB-1200013-CO	BEARING	1
	236-04200	MAIN SHAFT BEARING SUPPORT	1
	225-06208	BALANCE V	1
	225-05705	TIMING BELT	1
	M6801-471-0A0	AC SERVO MOTOR	1
	EA-9500B01-00	SYNC ASM.	1
	SB-1200008-CO	CABLE BAND	1
	236-05207	BEARING	1
	SL-4040881-SC	BEARING HOLDER	2
	SL-6052592-TN	SCREW M4 L=8	3
	100-08753	BOLT	1
	SS-1090930-SP	TAKE-UP COUNTERWEIGHT ASM.	3
	400-15494	SCREW 9/64-40 L=8.6	1
	SM-8060812-TP	NEEDLE BAR	2
	SS-7681650-TP	SCREW M6 L=8	1
	SS-8680730-SP	SCREW 9/32-28 L=16	1
	SM-8060812-TP	SCREW 9/32-28 L=7	4
	SS-8660610-TP	SCREW M6 L=8	2
	235-28755	SCREW 1/4-40 L=6	(1)
	235-28706	NEEDLE ROD CRANK ASM.	(1)
	SB-1080019-00	NEEDLE ROD CRANK ROD	1
	400-10281	BEARING	1
	225-08006	NEEDLE ROD CRANK ROD GUIDE	1
	225-07701	NEEDLE BAR CONNECTION GUIDE	1
	225-07404	THRED RACK RIGHT	1
	SL-6052092-TN	THREAD RACK	1
	400-70532	SCREW	(1)
	400-56873	NEEDLE_BAR_CONNECTION_ASM.	(1)
	SS-7090910-TP	NEEDLE BAR CONNECTION	(1)
	MC-2005F07-00	SCREW 9/64-40 L=8.5	(1)
	MDP-500B1000	NEEDLE 134SUK 70	(2)
	235-44901	NEEDLE DPX5 #10	1
	SS-7080520-SP	THRUST BUSH	1
	SS-7060310-SP	SCREW 1/8-44 L=4.9	1
	SS-4110915-SP	SCREW 3/32-56 L=3	2
	SS-4110915-SP	SCREW 11/64-40 L=9	2
	235-29159	NEEDLE ROD SUPPORT BASE ASM.	1
	235-29100	NEEDLE ROD SUPPORT BASE	(1)
	235-29209	NEEDLE ROD SUPPORT BASE SHAFT	(1)
	235-29308	SUPPORT BASE GUIDE SHAFT	(1)
	235-29506	NEEDLE ROD METAL	(1)
	235-29407	NEEDLE ROD SUPPORT BASE FELT	(2)
	PS-0400222-KO	SPRING PIN	(1)
	SS-8120740-SP	SCREW 3/16-28 L=7	(1)
	400-10315	SUPPORT BASE SHAFT FRONT METAL	1
	235-31114	SUPPORT BASE SHAFT REAR METAL	2
	400-10297	SUPPORT BASE GUIDE PIN A	1
	400-10296	SUPPORT BASE GUIDE PIN B	1
	RO-0371801-00	RUBBER RING	1
	SS-8151230-SP	SCREW 15/64-28 L=12	1
	SM-8061212-TP	SCREW M6X12	1
	400-03618	METAL B	1
	400-10322	SPRING	1
	WP-0720516-SD	PLAIN WASHER	1
	NM-6060001-SC	NUT M6	1
	CQ-2020000-00	OIL WICK	0.15

Page 12 — 4. NEEDLE VIBRATOR COMPONENTS

Juki LZ-2290A parts on page 12

Ref	Part number	Part name	Qty
1	1	BRACKET
2	2	BRACKET
3	3	BRACKET
4~7	4	SPRING
4~7	5	SPRING
4~7	6	SPRING
4~7	7	SPRING
8	8	SHAFT
9	9	NEEDLE
10	10	WASHER
11~13	11	COLLAR
11~13	12	COLLAR
11~13	13	COLLAR
14	14	SHAFT
15	15	BRACKET
16	16	PLATE
17	17	SPRING
18	18	MOTOR
19	19	BRACKET
20	20	SCREW
21	21	SCREW
22	22	SCREW
23	23	SCREW
24	24	SCREW
25	25	SCREW
26	26	SCREW
27	27	PIN
28	28	WASHER
29	29	WASHER
30	30	WASHER
31	31	BEARING
32	32	CAP
33	33	COVER
34	34	CAP
35	35	SCREW

Page 13

Juki LZ-2290A parts on page 13

Ref	Part number	Part name	Qty
	401-49235	NEEDLE_VIBRATOR_UNIT	1
	401-49234	NEEDLE_VIBRATOR_UNIT_BASIS	(1)
	400-10278	MOTOR LINK	(1)
	400-10286	JUNCTION SHAFT A
	400-10287	JUNCTION SHAFT B
	400-10288	JUNCTION SHAFT C
	400-10289	JUNCTION SHAFT D
	400-08169	SHAFT CONNECTION LINK
	EA-9500B01-00	CABLE BAND
	WP-0520656-SA	WASHER 5.2X9.5X0.6
	400-08119	JUNCTION SHAFT A
	400-08120	JUNCTION SHAFT B
	400-08121	JUNCTION SHAFT C
	400-08118	SUPPORT BASE SHAFT CONNECTION
	235-30702	SENSOR FITTING PLATE
	235-30801	SENSOR SLIT
	235-31007	CORD CLAMP
	KM-0000003-50	PULSE MOTOR
	M8523-476-AA0	ZERO SENSOR A ASM.
	SS-4110615-SP	SCREW 11/64-40 L=6
	SS-7121410-TP	SCREW 3/16-28 L=14
	SM-4030655-SP	SCREW
	SM-4051255-SP	SCREW M5 L=12
	SM-4860801-SN	SCREW M4 L=10
	SM-6041002-TP	SCREW M4X0.7 L=10
	SS-7110740-TP	SCREW 11/64-40 L=7
	SM-8050612-TP	SCREW M5X6
	WP-0482016-SZ	WASHER
	NM-6040001-SN	NUT M4X0.7
	SS-8090670-SP	SCREW 9/64-40 L=5.5
	400-10298	JUNCTION SHAFT COLLAR
	SM-6041402-TP	SCREW M4 L=14
	401-49236	NEEDLE_VIBRATOR_UNIT_COVER
	SM-6061002-TP	SCREW M6 L=10	3
	SS-4121215-SP	SCREW 3/16-28 L=12	4

Page 14 — 5. HAND LIFTER COMPONENTS

Juki LZ-2290A parts on page 14

Ref	Part number	Part name	Qty
	5	HAND LIFTER COMPONENTS
	10	押え上げ関係
	5	SCREW
	10	WASHER
	20	ROD
	38	SPRING
	43	SPRING
	6	COLLAR
	17	BRACKET
	19	SCREW
	16	TUBE
	37	SCREW
	11	PRESSER FOOT
	12	PRESSER FOOT
	13	PRESSER FOOT
	14	PRESSER FOOT
	15	PRESSER FOOT
	42	PRESSER FOOT
	23	SCREW
	41	WASHER
	9	HOLDER
	8	SHAFT
	32	RING
	40	SPRING
	39	SPRING
	22	SCREW
	27	WASHER
	21	BRACKET
	24	SPRING
	31	SPRING
	36	SCREW
	7	BRACKET
	35	SCREW
	34	SCREW
	1	ARM
	2	BRACKET
	3	SPRING
	33	SCREW
	25	SCREW
	30	CLIP
	28	SCREW
	26	SHAFT
	29	NUT
	4	ROD

Page 15

Juki LZ-2290A parts on page 15

Ref	Part number	Part name	Qty
	235-31304	KNEE LIFTING SIDE ROD LINK
	235-31403	KNEE LIFTING LINK
	235-31502	KNEE LIFTING LINK SPRING
	400-03601	KNEE LIFTING JUNCTION ROD
	236-09209	PRESSER SPRING REGULATOR
	236-09001	BUSHING
	263-08007	LIFTING PLATE
	263-07850	PRESSER LIFTER CAM COMPL.
	229-07802	HAND LIFTER
	229-07604	PRESSER SPRING REGULATOR NUT
#01	100-55051	PRESSER FOOT ASM.
#02	225-80864	PRESSER FOOT ASM.
#03	225-80864	PRESSER ASM.
#04	235-03154	PRESSER ASM.
#04	235-03162	PRESSER ASM.
	401-25469	PRESSER_BAR
	400-70531	PRESSER_BAR_CONNECTION_ASM.
	263-02901	PRESSER BAR HOLDER
	SS-7111110-TP	SCREW 11/64-40 L=10.5
	229-07703	PRESSER GUIDE BAR
	B1516-552-000	LIFTING LEVER LINK
	B1517-552-000	HINGE PIN
	B1521-555-000	SCREW
	B1523-226-000	SNAP RING
	B3416-552-000	CONNECTING ROD HINGE SCREW
	B3416-555-000	SWIVEL
	B3431-581-000	LIFTING LEVER GASKET
	BAK-33041000	KNEE LIFTING LINK STEP-SCREW
	NS-6620310-SP	NUT 3/16-32
	RE-0500000-K0	E-RING
	RE-0600000-K0	E-RING 6
	RO-0371801-00	RUBBER RING
	SD-0600341-TP	HINGE SCREW D=6.0 H=3.4
	SD-0630275-SP	HINGE SCREW D=6.35 H=2.7
	SD-0630301-SP	HINGE SCREW D=6.35 H=3
	SD-0630371-SP	HINGE SCREW
	SS-7090910-TP	SCREW 9/64-40 L=8.5
#05	B1505-227-T00-A	PRESSER SPRING T
	SS-8150510-TP	SCREW 15/64-28 L=4.7
	SS-8152030-SP	SCREW 15/64-28 L=20
	WP-0740516-SP	WASHER 7.4X11.8X0.5
#06	225-80369	PRESSER FOOT ASM.
#05	229-07406	PRESSER SPRING

Page 16 — 6. FEED MECHANISM COMPONENTS (1)

Juki LZ-2290A parts on page 16

Ref	Part number	Part name	Qty
	65	65
	2	2
	25	25
	23	23
	67	67
	72	72
	53	53
	46	46
	39	39
	26	26
	49	49
	40	40
	68	68
	33	33
	47	47
	35	35
	34	34
	37	37
	36	36
	55	55
	66	66
	20	20
	21	21
	50	50
	73	73
	41	41
	45	45
	32	32
	49	49
	54	54
	9	9
	30	30
	29	29
	17	17
	31	31
	16	16
	18	18
	69	69
	22	22
	70	70
	8	8
	64	64
	11	11
	30	30
	63	63
	12	12
	28	28
	27	27
	62	62
	13	13
	15	15
	14	14
	19	19
	48	48
	61	61
	38	38
	71	71
	6	6
	10	10
	58	58
	52	52
	51	51
	7	7
	61	61
	38	38
	5	5
	56	56
	1	1
	3	3
	4	4
	57	57
	57	57

Page 17

Juki LZ-2290A parts on page 17

Ref	Part number	Part name	Qty
	235-32500	FEED ADJUSTING SPRING
	400-10311	FEED HORIZONTAL SHAFT
	235-32906	REGULATE PLATE
	235-33003	REGULATE PLATE
	235-32609	FEED SPRING RACK
	235-32807	FEED REVERSAL LINK
	400-10318	FEED ADJUSTING A
	401-49246	HORIZONTAL FEED CAM
	235-32401	HORIZONTAL FEED CAM COVER
	235-32203	FEED ADJUSTING PRESSER
	400-10313	FEED CHANGE ARM
	400-10268	FEED CHANGE ARM A クミ
	400-10269	FEED CHANGE ARM A
	229-10509	FEED ADJUSTING LINK PIN
	SS-7121410-TP	SCREW 3/16-28 L=14
	400-10270	FEED CHANGE ARM B ASM.
	400-10271	FEED CHANGE ARM B
	SS-8660612-TP	SCREW 1/4-40 L=6
	235-32708	FEED ADJUSTING ARM
	401-49244	FEED BASE ASM.
	401-49245	FEED BASE
	SS-7091110-TP	SCREW 9/64-40 L=10.5
	400-10276	FEED DOG
	SS-7091110-TP	FEED DOG
	RC-0150001-KP	RETAINING RING 13.8
	401-39216	OIL SEAL
	236-12609	FEED CHANGING SHAFT OIL SEAL
	236-12807	METAL A
	236-12906	METAL B
	236-13102	FEED CHANGING SHAFT ARM B PIN
	NS-6150310-SP	NUT 15/64-28
	263-00509	FEED ROD
	236-16709	FEED ROCKER SHAFT
	401-25485	FEED BASE ASM.
	229-40654	FEED ROCKER ASM.
	SS-7121410-TP	SCREW 3/16-28 L=14
	WP-0480856-SD	WASHER 4.8X8.4X0.8
	100-27308	PLATE A
	400-50457	FEED DRIVING ROCKER BLOCK
	B1608-555-0A0	FEED ROCKER SHAFT CRANK ASM.
	SB-3220002-CA	BEARING
	SB-3220002-CB	BEARING
	SB-3220002-CC	BEARING
	SB-3220002-CD	BEARING
	SB-3220002-CE	BEARING
	B1653-470-000	PIN
	CS-1470710-SH	THRUST COLLAR ASM. D=14.72 W=7
	NS-6120310-SP	NUT 9/32-28
	NS-6680410-SP	E-RING 3
	RE-0300000-KO	E-RING
	RE-0500000-KO	HINGE SCREW D=6 H=3.2
	SD-0600321-SP	HINGE SCREW D=9 N=7
	SD-0900701-TP	SCREW 1/8-44 L=6
	SS-4080620-TP	SCREW 11/64-40 L=7
	SS-7110740-TP	SCREW 15/64-28 L=9
	SS-4150915-SP	SCREW 15/64-28 L=9
	SS-4150915-SP	SCREW 11/64-40 L=6
	SS-4110615-SP	SCREW 1/8-40 L=7
	SS-6580752-TP	SCREW 11/64-40 L=8.5
	SS-7110910-TP	SCREW 11/64-40 L=9
	SS-4110915-SP	THRUST COLLAR
	CS-1000881-TP	SCREW M5 L=6
	SM-80506A2-TP	SCREW 1/4-40 L=8
	SS-8660810-TP	HORIZONTAL FEED SHAFT U
	400-10312	HORIZONTAL FEED SHAFT METAL B
	235-45304	HORIZONTAL FEED JUNCTION ROD
	263-03206	FEED ROCKER SHAFT CRANK
	100-27100	VERTICAL FEED LINK
	263-03107	VERTICAL FEED LINK
	401-25483	FEED ADJUSTING OIL SEAL
	235-32005	CONNECTING ROD
	400-11850	FEED DOG

Page 18 — 7. FEED MECHANISM COMPONENTS (2)(EXCEPT LZ-2290A-SR-7)

Juki LZ-2290A parts on page 18

Ref	Part number	Part name	Qty
	1	CYLINDER
	2	CYLINDER
	3	ARM
	4	SCREW
	5	31
	6	PLATE
	7	PIN
	8	32
	9	CYLINDER
	10	BRACKET
	11	CAM
	12	SCREW
	13	FRAME
	14	SHAFT
	15	COLLAR
	16	BRACKET
	17	SCREW
	18	NUT
	19	SHAFT
	20	33
	21	COLLAR
	22	SHAFT
	23	COLLAR
	24	SCREW
	25	SCREW
	26	SCREW
	27	SCREW
	28	SCREW
	29	WASHER
	30	SPRING

Page 19

Juki LZ-2290A parts on page 19

Ref	Part number	Part name	Qty
	235-33706	FEED ADJUSTING SHAFT METAL
	235-33805	FEED ADJUSTING SHAFT
	235-33409	FEED ADJUSTING ROD
	235-33904	FEED ADJUSTING SCREW
	400-10272	FEED BLIND CONTROLLER
	235-34019	FEED ADJUSTING BASE
	PS-0300122-KH	SPRING PIN 3X12
	235-34407	CONDENS DIAL
	235-34308	CONDENS ADJUSTING SHAFT
	235-34258	CONDENS STOPPER ASM.
	235-34209	CONDENS STOPPER
	SS-7121410-TP	SCREW 3/16-28 L=14
	236-13607	FEED LEVER
	236-13706	FEED LEVER SHAFT
	236-13805	FEED LEVER SHAFT METAL
	236-13953	FEED LEVER ARM ASM.
	SS-6150310-SP	SCREW 3/16-28 L=15.5
	NS-6150310-SP	NUT 15/64-28
	235-33607	FEED ADJUSTING SHAFT
	110-71909	FEED DIAL
	229-52501	BACK LEVER STOPPER
	113-02700	SPRING
	SM-8060812-TP	SCREW M6 L=8
	SS-6121840-SP	SCREW 3/16-28 L=18
	SS-6121860-SP	SCREW 3/16-28 L=18
	SS-7121410-TP	SCREW 3/16-28 L=14
	SS-6121860-SP	SCREW 3/16-28 L=18
	SS-1110710-SP	SCREW 11/64-40 L=7
	WP-1651616-SD	WASHER
	235-34506	FEED DIAL SPRING
	400-10273	FEED BLIND CONTROLLER U
	235-45007	CONDENS DIAL U
	263-02000	FEED DIAL

Page 20 — 8. FEED MECHANISM COMPONENTS (3)(FOR LZ-2290A-SR-7)

Juki LZ-2290A parts on page 20

Ref	Part number	Part name	Qty
	17	17
	16	16
	8	8
	9	9
	10	10
	14	14
	15	15
	14	14
	24~27	24~27
	23	23
	29	29
	5	5
	30	30
	1	1
	2	2
	3	3
	4	4
	14	14
	20	20
	19	19
	21	21
	18	18
	31	31
	22	22
	28	28
	33	33
	36	36
	35	35
	34	34
	37	37
	41	41
	38	38
	39	39
	40	40
	1	1
	12	12
	13	13
	12	12
	48	48
	42	42
	32	32
	6	6
	43	43
	45	45
	44	44
	47	47
	46	46

Page 21

Juki LZ-2290A parts on page 21

Ref	Part number	Part name	Qty
	400-11831	ASSY FEED PULSE MOTOR UNIT	1
	400-11832	FEED PULSE MOTOR BASE	(1)
	400-09305	SUSPENSION SCREW	(1)
	NS-6090310-SP	NUT 9/64-40	(1)
	WP-0460556-SD	WASHER 4.6X7.5X0.5	(2)
	SL-4040891-SC	SCREW M4 L=8	(2)
	400-11839	SENSOR BASE	(1)
	M8523-476-AA0	ZERO SENSOR A ASM.	(1)
	SM-4860801-SN	SCRER M2.6 L=8	(1)
	SL-4040891-SC	SCREW M4 L=8	(1)
	KM-000003-50	PULSE MOTOR	(1)
	SM-6042502-TP	SCREW M4X0.7 L=25	(2)
	SM-6041602-TP	SCREW M4X0.7 L=16	(2)
	NM-6040000-SN	NUT M4	(4)
	400-11843	PIPE GUIDE PLATE C	(1)
	400-22407	CORD HOLDER	(4)
	SL-4040891-SC	SCREW M4 L=8	(4)
	400-11836	PULSE MOTOR LINK B	(1)
	400-11840	SENSOR SLIT	(1)
	SL-4030581-SC	COMBINATION SCREW M3X5	(1)
	SM-8050612-TP	SCREW M5X6	(1)
	SM-4051655-SP	SCREW M5 L=16	(1)
	400-11833	ASSY PULSE MOTOR LINK A	(1)
	400-10286	JUNCTION SHAFT A	(1)
	400-10287	JUNCTION SHAFT B	(1)
	400-10288	JUNCTION SHAFT C	(1)
	400-10289	JUNCTION SHAFT D	(1)
	400-11838	FEED LINK SHAFT	(1)
	400-11837	PULSE MOTOR LINK C	(1)
	SM-8050612-TP	SCREW M5X6	(2)
	SS-7111810-TP	SCREW 11/64-40 L=18	(2)
	235-41352	SAFETY SWITCH ASM.	(1)
	235-41303	SAFETY SWITCH BASE	(1)
	235-38109	SAFETY SWITCH ARM	(1)
	235-38208	SAFETY SWITCH SPRING	(1)
	235-38307	SAFETY SWITCH ARM SHAFT	(1)
	235-38406	SAFETY SWITCH NUT	(1)
	235-41451	SAFETY SWITCH CORD ASM.	(1)
	HK-0346100-60	HOUSING 6P	(1)
	EA-9500B01-00	CABLE BAND	(2)
	SM-4021201-SC	SCREW M2 L=12	(2)
	SS-4151215-SP	SCREW 15/64-28 L=12	3
	400-17098	BTPM RELAY CABLE ASM.	1
	B3508-220-000	OIL TUBE HOLDER	1
	SS-4120615-SP	SCREW 3/16-28 L=6	1
	400-11841	BED SUPPORT PLATE B	(1)
	400-11842	PIPE GUIDE PLATE B	(1)
	CM-3003000-03	ATTENTION SEAL 2(31.5)	1

Page 22 — 9. FEED MECHANISM COMPONENTS (4)(FOR LZ-2290A-SR-7)

Juki LZ-2290A parts on page 22

Ref	Part number	Part name	Qty
1	1	BRACKET
2	2	ARM
3	3	SHAFT
4	4	PIN
5	5	SPRING
6	6	SHAFT
7	7	BRACKET
8	8	SHAFT
9	9	PIN
10	10	BRACKET
11	11	SHAFT
12	12	ROD
13	13	BRACKET
14	14	SENSOR UNIT
15	15	WASHER
16	16	SCREW
17	17	COLLAR
18	18	BRACKET
19	19	COLLAR
20	20	SHAFT
21	21	BRACKET
22	22	SCREW

Page 23

Juki LZ-2290A parts on page 23

Ref	Part number	Part name	Qty
	400-11847	ASSY FEED LEVER ROD	1
	400-11848	FEED LEVER ROD	(1)
	118-46805	HOLDER PIN	(1)
	SM-8060612-TP	SCREW M6 L=6	(1)
	110-50705	LEVER RETURN SPRING	1
	400-11849	FEED LEVER SHAFT	1
	B1114-280-000	PIN	1
	400-11844	VOLUME LINK	1
	SM-8060612-TP	SCREW M5X6	1
	400-11846	LEVER SENSOR PLATE	1
	SL-6051092-TN	BOLT	1
	EA-9500B01-00	CABLE BAND	2
	HD-0015300-00	SENSOR	1
	400-16039	FEED LEVER SENSOR ASSY	1
	TA-1250406-R0	RUBBER PLUG D=12.5 L=4	1
	025-52501	SCREW 3/16-28 L=18	1
	229-52501	BACK LEVER STOPPER	1
	236-13607	FEED LEVER	2
	SM-8060812-TP	SCREW M6 L=8	1
	236-13805	FEED LEVER SHAFT METAL	1
	236-13953	FEED LEVER ARM ASM.	(1)
	SS-6121610-SP	SCREW 3/16-28 L=15.5	(1)

Page 24 — 10. HOOK DRIVING SHAFT COMPONENTS (1)

Juki LZ-2290A parts on page 24

Ref	Part number	Part name	Qty
1	1	HOUSING
2	2	SHAFT
3	3	SHAFT
4	4	SHAFT
5	5	SHAFT
6~11	6~11	BEARING
12	12	HOUSING
13	13	HOUSING
14	14	HOUSING
15	15	HOUSING
16	16	BRACKET
17	17	GEAR
18	18	GEAR
19	19	GEAR
20	20	SHAFT
21	21	SHAFT
22	22	SHAFT
23	23	SHAFT
24	24	SHAFT
25	25	PIN
26	26	PIN
27	27	PIN
28	28	BEARING
29	29	BEARING
30	30	HOUSING
31	31	HOUSING
32	32	SCREW
33	33	SPRING
34	34	SPRING
35	35	WASHER
36	36	RING
37	37	SPRING
38	38	SPRING
39	39	BEARING
40	40	BEARING
41	41	SHAFT
42	42	BEARING

Page 25

Juki LZ-2290A parts on page 25

Ref	Part number	Part name	Qty
	235-35107	HOOK SHAFT FRONT METAL	1
	400-03590	HOOK SHAFT BEARING ASM.	2
	235-35602	HOOK DRIVING SHAFT REAR METAL	1
	400-10283	HOOK SHAFT	1
#02	400-03567	HOOK DRIVING SHAFT
#02	235-36303	HOOK DRIVING GEAR (SMALL) A
#02	235-36402	HOOK DRIVING GEAR (SMALL) B
#02	235-36501	HOOK DRIVING GEAR (SMALL) C
#02	235-36600	HOOK DRIVING GEAR (SMALL) D
#02	235-36709	HOOK DRIVING GEAR (SMALL) E
#02	235-36808	HOOK DRIVING GEAR (SMALL) F
	400-03599	BOBBIN CASE COMPL.	1
#01	400-03598	BOBBIN CASE ASM.
	225-25877	HOOK COMPL. V	1
	225-96704	BOBBIN S	1
	235-03402	INNER HOOK STOPPER	1
	B1308-155-000	GEAR ASM. LARGE	1
	B1307-155-0A0	GEAR ASM. LARGE	(2)
	SS-8660810-TP	SCREW 1/4-40 L=8	1
	110-15906	OIL WICK	1
	229-16506	SET SCREW	1
	RO-0360802-00	RUBBER RING	1
	RO-0481901-00	RUBBER RING	2
	SS-4110915-SP	SCREW 11/64-40 L=9	1
	SS-8110520-TP	SCREW 11/64-40 L=4.5	4
	SS-8660810-TP	SCREW 1/4-40 L=8	2
	SS-8660810-TP	SCREW 1/4-40 L=8	2
	401-20730	HOOK SHAFT OIL SEAL	2
	400-10282	OIL SEAL COLLAR	2
	400-10261	PUMP METAL ASM.	1
	400-10262	PUMP METAL	(1)
	TA-0180401-MO	NEEDLE COOLER PLUG CAP	(7)
	236-28902	PLUNGER SPRING	3
	236-29009	PLUNGER SCREW	3
	RO-0681901-00	RUBBER RING	3
	RO-1721801-00	RUBBER RING	1
	SS-8111251-SP	SCREW 11/64-40 L=12.0	1
	TA-0850604-RO	RUBBER PLUG	1
#02	235-38903	HOOK DRIVING GEAR (SMALL) S
	228-90008	HOOK DRIVING SHAFT OIL SEAL	2
	236-28803	PLUNGER	2
	400-11424	Hook GEAR BOX OIL SEAL	2

Page 26 — 11. HOOK DRIVING SHAFT COMPONENTS (2)

Juki LZ-2290A parts on page 26

Ref	Part number	Part name	Qty
1	1	COLLAR
2	2	COLLAR
3	3	WASHER
4	4	COLLAR
5	5	COLLAR
6	6	SHAFT
7~10	7~10	BEARING
11	11	COLLAR
12	12	COLLAR
13	13	SCREW
14	14	WASHER
15	15	PIN
16	16	COLLAR
17	17	HOOK DRIVING SHAFT
18	18	COLLAR
19	19	SCREW
20	20	GEAR
21	21	COLLAR
22	22	BEARING
23	23	WASHER
9	9	COLLAR

Page 27

Juki LZ-2290A parts on page 27

Ref	Part number	Part name	Qty
	400-10316	LOWER SHAFT FRONT BEARING BUSH
	400-10314	LOWER SHAFT INNER METAL
	235-36055	LOWER SHAFT INNER BEARING ASM.
	235-36105	LOWER SHAFT REAR BUSH
	235-36253	LOWER SHAFT REAR BEARING ASM.
6	400-10303	LOWER SHAFT
7	401-49251	HELICAL GEAR A
8	401-49252	HELICAL GEAR B
9	401-49253	HELICAL GEAR C
10	401-49254	HELICAL GEAR D
11	G1615-880-000	OIL SEAL
12	SB-3100010-C0	BEARING
13	SS-6660710-TP	SCREW 1/4-40 L=7
14	SS-8110750-SP	SCREW 11/64-40 L=6.5
15	SS-8660810-TP	SCREW 1/4-40 L=8
16	SM-8060812-TP	SCREW M6 L=8
17	235-41709	THREAD TRIMMER CAM
18	CS-1000881-TP	THRUST COLLAR
19	SS-6660710-TP	SCREW 1/4-40 L=7
20	401-60262	LOWER SHAFT SPROCKET
21	B2508-704-000	OIL SEAL
22	G1615-880-000	OIL SEAL
23	SM-80506A2-TP	SCREW M5 L=6
	#01	FOR LZ-2290A-SS, LZ-2290A-SS-7, LZ-2290A-SR-7
	#02	SELECTIVE PARTS

Page 28 — 12. THREAD TRIMMER MECHANISM COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7)

Juki LZ-2290A parts on page 28

Ref	Part number	Part name	Qty
36	36	SCREW
9	9	BRACKET
39	39	NUT
1	1	BRACKET
46	46	WASHER
10	10	COVER
3	3	SPRING
2	2	SHAFT
4	4	SPRING
43	43	CLIP
44	44	SCREW
47	47	SCREW
19	19	PLATE
22	22	BLADE
21	21	BLADE
23	23	BRACKET
33	33	SPRING
25	25	SPRING
24	24	BRACKET
20	20	BASE
35	35	WASHER
26	26	BRACKET
29	29	SCREW
30	30	SCREW
27	27	SPRING
28	28	BRACKET
34	34	NUT
32	32	NUT
31	31	SCREW
15	15	ARM
53	53	SPRING
45	45	SHAFT
18	18	BRACKET
16	16	BRACKET
42	42	CLIP
40	40	CLIP
14	14	SPRING
13	13	SHAFT
49	49	SCREW
50	50	SCREW
8	8	SHAFT
7	7	BRACKET
51	51	SCREW
11	11	SCREW
6	6	BRACKET
12	12	WASHER
5	5	BRACKET
52	52	WASHER
37	37	NUT
38	38	WASHER
54	54	SPRING
48	48	SCREW
17	17	PLATE

Page 29

Juki LZ-2290A parts on page 29

Ref	Part number	Part name	Qty
	400-10290	BASE PLATE ASM.	1
	235-42053	CLUTCH PLATE ASM.	1
	235-42103	CLUTCH RETURN SPRING	1
	235-42202	KNIFE RETURN SPARING	1
	235-41808	MOVING KNIFE LINK	1
	110-40854	KNIFE DRIVING ARM ASM.	1
	229-49002	ROLLER ARM SEAT	1
	229-49101	ROLLER FULCRUM SHAFT	1
	225-54505	CLUTCH LINK	1
	235-42301	THREAD TRIMMER SOLENOID	1
	400-10295	MOVING KNIFE LINK PIN	1
	225-54802	MOVING KNIFE LINK BASE	1
	225-54901	DRIVING ARM STOPPER	1
	225-55304	ROLLER RETURN SPRING	1
	225-55551	FORK KNIFE ASM.	1
	225-55858	ROLLER ARM ASM.	1
	225-56906	FIXED PLATE	1
	225-57458	KNIFE UNIT	(1)
	225-58308	SLIDING PLATE	(1)
	225-58407	KNIFE BASE	(1)
	225-57557	DRIVING KNIFE ASM.	(1)
	225-57706	FIXED KNIFE	(1)
	225-57805	KNIFE STOPPER RIGHT	(1)
	225-57904	KNIFE STOPPER LEFT	(1)
	225-58209	SPRING	(1)
	225-58159	CLAMP PLATE ASM.	(1)
	225-58001	FELT	(1)
	225-58100	CLAMP PLATE	(1)
	SS-7090610-SP	SCREW 9/64-40 L=6	(2)
	SS-1090510-SP	SCREW 9/64-40 L=5	(2)
	SS-7060310-SP	SCREW 3/32-56 L=5	(1)
	SS-7060310-SP	SCREW 3/32-56 L=3	(1)
	NP-2103000-00	LOCATING SPRING WASHER	(1)
	WS-0270002-KN	SPRING WASHER M2.6	(1)
	D2056-772-B0B	WASHER B T=0.4	(1)
	235-42418	CLUTCH LINK PIN	1
	NS-6150310-SP	NUT 15/64-28	1
	NS-6150430-SP	NUT 15/64-28	1
	NM-6030001-SB	NUT M3	2
	RE-0400000-KO	E-RING 4	2
	RE-0500000-KO	E-RING 5	1
	RE-0600000-KO	E-RING 6	1
	RE-0600000-KO	E-RING 6	1
	SD-0600291-TP	HINGE SCKEW D=6 H=2.9	1
	SD-0791503-SP	HINGE SCREW D=7.94 H=15	1
	SM-4040601-SC	SCREW M4X0.7 L=6	3
	SS-2110920-TP	SCREW 11/64-40 L=8.5	1
	SS-2111010-TP	SCREW 11/64-40 L=9.5	1
	SS-4110915-SP	SCREW 11/64-40 L=9	2
	SS-4150915-SP	SCREW 15/64-28 L=9	2
	SS-7090610-SP	SCREW 9/64-40 L=6	1
	WP-0621016-SH	WASHER	1
	229-19203	OIL PROTECTING RUBBER	1
	BP-6000000-00	VINYL PIPE	1

Page 30 — 13. FEED MECHANISM COMPONENTS

Juki LZ-2290A parts on page 30

Ref	Part number	Part name	Qty
	100-25906	SPACER
	235-01901	FEED BASE
	229-13206	FEED BASE SHAFT
	235-01802	FEED BASE SHAFT B
	229-13107	FEED BASE ARM
	SS-7110740-TP	SCREW 11/64-40 L=7
	235-45403	VERTICAL FEED ARM
	235-01356	VERTICAL FEED CAM ASM.
	112-14806	PIN
	235-01703	LINK B
	235-01604	FEED BASE LINK
	SS-7121410-TP	SCREW 3/16-28 L=14
	SS-6110820-TP	SCREW 11/64-40 L=8
	RC-0330415-KP	SNAP RING
	SM-8050612-TP	SCREW M5X6
	WP-0480856-SP	WASHER 4.8X8.4X0.8
	WP-0500916-SD	WASHER 5X7X0.9
	235-45106	LOWER SHAFT U
	400-10264	VERTICAL FEED LINK
	235-58406	VERTICAL FEED LINK SHAFT D
	SS-7121410-TP	SCREW 3/16-28 L=14
	235-59909	VERTICAL FEED ROD PIN DU
	RE-0300000-KO	E-RING 3

Page 31 — 14. AUTOMATIC REVERSE FEED MECHANISM COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7)

Juki LZ-2290A parts on page 31

Ref	Part number	Part name	Qty
	235-42509	AUTOMATIC REVERSE FEED LINK	1
	400-10307	AUTOMATIC REVERSE FEED ARM	1
	400-08596	SOLENOID BASE ASM.	1
	401-08063	REVERSE FEED SOLENOID	(1)
	401-08064	REVERSE FEED SOLENOID PLUNGER	(1)
	235-42707	REVERSE FEED SOLENOID BASE	(1)
	D2468-555-B00	RUBBER PLUNGER	(1)
	RE-1200000-KO	E-RING 12	(1)
	SS-7110740-TP	SCREW 11/64-40 L=7	(3)
	WP-1703001-SC	WASHER 17X30X3	(1)
	HK-0346400-0B	PIN CONTACT	(2)
	CM-3003000-03	ATTENTION SEAL 2(3.15)	(1)
	113-14408	PLUNGER ARM PIN	1
	NS-6110350-SP	NUT 11/64-40	2
	SD-0600452-TP	HINGE SCREW D=6 H=4.5	2
	SD-0951501-SP	HINGE SCREW D=9.53 H=15	1
	SS-4150915-SP	SCREW 15/64-28 L=9	2
	400-10280	SOLENOID BASE STUD	2

Page 32 — 15. THREAD FEEDER COMPONENTS

Juki LZ-2290A parts on page 32

Ref	Part number	Part name	Qty
1	235-38457	FEEDER SOLENOID ASM.	1
2	400-10321	FEEDER WIRE FITTING BASE	1
3	235-38606	FEEDER WIRE	1
4	SS-6110650-TP	SCREW 11/64-40 L=5.5	1
5	SS-8151230-SP	SCREW 11/64-40 L=12	1
6	SS-8110422-TP	SCREW 11/64-40 L=4	2

Page 33 — 16. MANUAL SWITCH COMPONENTS (FOR LZ-2290A-SS,LZ-2290A-SU)

Juki LZ-2290A parts on page 33

Ref	Part number	Part name	Qty
1	400-03582	MANUAL SWITCH BASE COMPL.
2	400-03570	SWLED CABLE A ASM.
3	400-03583	MANUAL SWITCH BASE ASM.
4	400-03575	UP-AND-DOWN SWITCH BASE
5	400-03578	MANUAL SWITCH BASE
6	SS-4110515-SP	SCREW 11/64-40 L=5
7	EA-9500B01-00	CABLE BAND
8	HK-0346101-20	HOUSING 12P

Page 34 — 17. MANUAL SWITCH COMPONENTS

Juki LZ-2290A parts on page 34

Ref	Part number	Part name	Qty
	1	MANUAL SWITCH COMPONENTS
	2	CABLE
	3	CABLE
	4	BRACKET
	5	BRACKET
	6	BRACKET
	7	BRACKET
	8	CABLE
	9	SWITCH BASE
	10	KNOB
	11	SWITCH
	12	BRACKET
	13	BRACKET
	14	SPRING
	15	SCREW
	16	CABLE TIE
	17	CONNECTOR
	18	CABLE
	19	CABLE
	20	BRACKET
	21	SWITCH BODY
	22	BRACKET
	23	CABLE
	24	SWITCH BASE
	25	KNOB
	26	SWITCH
	27	BRACKET
	28	CABLE TIE
	29	SCREW
	30	SCREW
	31	CABLE
	32	CONNECTOR
	33	WASHER
	34	SCREW

Page 35

Juki LZ-2290A parts on page 35

Ref	Part number	Part name	Qty
1	400-03574	MANUAL SWITCH BASE COMPL. A	1
2	400-03570	SWLED CABLE A ASM.	(1)
3	400-03577	MANUAL SWITCH BASE ASM. A	(1)
4	400-03575	UP-AND-DOWN SWITCH BASE	(1)
5	400-03578	MANUAL SWITCH BASE	(1)
6	400-03579	TOUCH BACK SWITCH BASE ASM.	(1)
7	400-03580	TOUCH BACK SWITCH BASE	(1)
8	400-03581	REVERSE FEED CORD ASM.	(1)
9	236-31708	REVERSE FEED SWITCH COVER	(1)
10	236-31807	REVERSE FEED SWITCH SHAFT	(1)
11	236-31906	REVERSE FEED SWITCH SUPPORT	(1)
12	236-32102	REVERSE FEED SWITCH BASE GUIDE	(1)
13	EA-9500B01-00	CABLE BAND	(1)
14	SS-7110740-TP	SCREW 11/64-40 L=7	(1)
15	SS-4110515-SP	SCREW 11/64-40 L=5	(3)
16	EA-9500B01-00	CABLE BAND	(1)
17	HK-0346101-20	HOUSING 12P	(1)
18	400-03570	MANUAL SWITCH BASE COMPL. B	1
19	400-03570	SWLED CABLE A ASM.	(1)
20	400-03576	MANUAL SWITCH BASE ASM. B	(1)
21	400-03575	UP-AND-DOWN SWITCH BASE	(1)
22	400-03578	MANUAL SWITCH BASE	(1)
23	400-03581	REVERSE FEED CORD ASM.	(1)
24	236-31708	REVERSE FEED SWITCH COVER	(1)
25	236-31807	REVERSE FEED SWITCH SHAFT	(1)
26	236-31906	REVERSE FEED SWITCH SUPPORT	(1)
27	236-32102	REVERSE FEED SWITCH BASE GUIDE	(1)
28	EA-9500B01-00	CABLE BAND	(1)
29	SS-4110515-SP	SCREW 11/64-40 L=5	(1)
30	SS-7110740-TP	SCREW 11/64-40 L=7	(1)
31	EA-9500B01-00	CABLE BAND	(1)
32	HK-0346101-20	HOUSING 12P	(1)
33	TA-0950806-R0	RUBBER PLUG	(1)
34	SS-4120615-SP	SCREW 3/16-28 L=6	2

Page 36 — 18. THREAD RELEASE SOLENOID COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7)

Juki LZ-2290A parts on page 36

Ref	Part number	Part name	Qty
	1	SOLENOID ASSY
	2	BRACKET
	3	SPRING
	4	BRACKET
	5	BRACKET
	6	BRACKET
	7	CLAMP
	8	BRACKET
	9	CORD
	10	BASE
	11	COVER
	12	COVER
	13	CLAMP
	14	CLAMP
	15	SCREW
	16	SCREW
	17	CORD
	18	CONNECTOR
	19	BRACKET
	20	BRACKET
	21	BRACKET
	22	BRACKET
	23	WASHER
	24	SCREW
	25	SCREW
	26	CORD
	27	BRACKET
	28	CORD
	29	BRACKET
	30	BRACKET
	31	BRACKET
	32	CORD
	33	BRACKET
	34	BRACKET
	35	BRACKET
	36	BRACKET
	37	CORD
	38	WASHER
	39	SCREW
	40	CORD
	41	CONNECTOR
	42	WASHER
	43	BRACKET
	44	BRACKET
	45	BRACKET
	46	WASHER
	47	SCREW
	48	SCREW

Page 37

Juki LZ-2290A parts on page 37

Ref	Part number	Part name	Qty
	400-03572	SOLENOID COMPL. A	1
	400-03574	MANUAL SWITCH BASE COMPL. A	(1)
	400-03570	SWLED CABLE A AKMI	(1)
	400-03575	MANUAL SWITCH BASE ASM. A	(1)
	400-03576	UP-AND-DOWN SWITCH BASE	(1)
	400-03578	MANUAL SWITCH BASE	(1)
	400-03579	TOUCH BACK SWITCH BASE ASM.	(1)
	400-03580	TOUCH BACK SWITCH BASE	(1)
	400-03581	REVERSE FEED CORD ASM.	(1)
	236-31708	REVERSE FEED SWITCH COVER	(1)
	236-31807	REVERSE FEED SWITCH SHAFT	(1)
	236-31906	REVERSE FEED SWITCH SUPPORT	(1)
	236-32102	REVERSE FEED SWITCH BASE GUIDE	(1)
	EA-9500B01-00	CABLE BAND	(1)
	SS-7110740-TP	SCREW 11/64-40 L=7	(3)
	SS-4110515-SP	SCREW 11/64-40 L=5	(1)
	EA-9500B01-00	CABLE BAND	(1)
	HK-0346101-20	HOUSING 12P	(1)
	137-05603	FRAME SIDE COVER GASKET	(2)
	225-52905	THREAD RELEASE PUSH PLATE	(1)
	400-03651	THREAD RELEASE SOLENOID ASM.	(1)
	NM-6030001-SC	NUT M3	(2)
	NM-6040001-SN	NUT M4X0.7	(1)
	SS-4121015-SP	SCREW 3/16-28 L=10	(4)
	PS-0300182-KF	SPRING PIN 3X18	1
	400-03571	SOLENOID COMPL. B	1
	400-03573	MANUAL SWITCH BASE COMPL. B	(1)
	400-03570	SWLED CABLE A AKMI	(1)
	400-03576	MANUAL SWITCH BASE ASM. B	(1)
	400-03575	UP-AND-DOWN SWITCH BASE	(1)
	400-03578	MANUAL SWITCH BASE	(1)
	400-03581	REVERSE FEED CORD ASM.	(1)
	236-31708	REVERSE FEED SWITCH COVER	(1)
	236-31807	REVERSE FEED SWITCH SHAFT	(1)
	236-31906	REVERSE FEED SWITCH SUPPORT	(1)
	236-32102	REVERSE FEED SWITCH BASE GUIDE	(1)
	EA-9500B01-00	CABLE BAND	(1)
	SS-4110515-SP	SCREW 11/64-40 L=5	(1)
	SS-7110740-TP	SCREW 11/64-40 L=7	(1)
	EA-9500B01-00	CABLE BAND	(1)
	HK-0346101-20	HOUSING 12P	(1)
	137-05603	FRAME SIDE COVER GASKET	(1)
	225-52905	THREAD RELEASE PUSH PLATE	(1)
	400-03651	THREAD RELEASE SOLENOID ASM.	(1)
	NM-6030001-SC	NUT M3	(1)
	NM-6040001-SN	NUT M4X0.7	(1)
	SS-4121015-SP	SCREW 3/16-28 L=10	(1)
	PS-0300182-KF	SPRING PIN 3X18	(1)

Page 38 — 19.LUBRICATION COMPONENTS(EXCEPT LZ-2290A-DS,LZ-2290A-DS-7,LZ-2290A-DU,LZ-2290A-DU-7)

Juki LZ-2290A parts on page 38

Ref	Part number	Part name	Qty
	1	LUBRICATION COMPONENTS
	2	LUBRICATION COMPONENTS
	3	LUBRICATION COMPONENTS
	4	LUBRICATION COMPONENTS
	5	LUBRICATION COMPONENTS
	6	LUBRICATION COMPONENTS
	7	LUBRICATION COMPONENTS
	8	LUBRICATION COMPONENTS
	9	LUBRICATION COMPONENTS
	10	LUBRICATION COMPONENTS
	11	LUBRICATION COMPONENTS
	12	LUBRICATION COMPONENTS
	13	LUBRICATION COMPONENTS
	14	LUBRICATION COMPONENTS
	15	LUBRICATION COMPONENTS
	16	LUBRICATION COMPONENTS
	17	LUBRICATION COMPONENTS
	18	LUBRICATION COMPONENTS
	19	LUBRICATION COMPONENTS
	20	LUBRICATION COMPONENTS
	21	LUBRICATION COMPONENTS
	22	LUBRICATION COMPONENTS
	23	LUBRICATION COMPONENTS
	24	LUBRICATION COMPONENTS
	25	LUBRICATION COMPONENTS
	26	LUBRICATION COMPONENTS
	27	LUBRICATION COMPONENTS
	28	LUBRICATION COMPONENTS
	29	LUBRICATION COMPONENTS
	30	LUBRICATION COMPONENTS
	31	LUBRICATION COMPONENTS
	32	LUBRICATION COMPONENTS
	33	LUBRICATION COMPONENTS
	34	LUBRICATION COMPONENTS
	35	LUBRICATION COMPONENTS
	36	LUBRICATION COMPONENTS
	37	LUBRICATION COMPONENTS
	38	LUBRICATION COMPONENTS
	39	LUBRICATION COMPONENTS
	40	LUBRICATION COMPONENTS
	41	LUBRICATION COMPONENTS
	42	LUBRICATION COMPONENTS
	43	LUBRICATION COMPONENTS
	44	LUBRICATION COMPONENTS
	45	LUBRICATION COMPONENTS
	46	LUBRICATION COMPONENTS
	47	LUBRICATION COMPONENTS
	48	LUBRICATION COMPONENTS
	49	LUBRICATION COMPONENTS
	50	LUBRICATION COMPONENTS
	51	LUBRICATION COMPONENTS
	52	LUBRICATION COMPONENTS
	53	LUBRICATION COMPONENTS
	54	LUBRICATION COMPONENTS
	55	LUBRICATION COMPONENTS
	56	LUBRICATION COMPONENTS
	57	LUBRICATION COMPONENTS
	58	LUBRICATION COMPONENTS
	59	LUBRICATION COMPONENTS
	60	LUBRICATION COMPONENTS
	61	LUBRICATION COMPONENTS
	62	LUBRICATION COMPONENTS
	63	LUBRICATION COMPONENTS
	64	LUBRICATION COMPONENTS
	65	LUBRICATION COMPONENTS
	66	LUBRICATION COMPONENTS

Page 39

Juki LZ-2290A parts on page 39

Ref	Part number	Part name	Qty
	401-75861	OIL_TANK	1
	235-39372	HOOK OIL REGULATING ASM.	1
	235-39315	HOOK OIL REGULATING	(1)
	235-39414	HOOK OIL REGULATING SCREW	(2)
	236-29801	LUBRICATION CONNECTOR	(5)
	RO-0371801-00	RUBBER RING	(2)
	SS-4120615-SP	SCREW 3/16-28 L=6	2
	236-30106	TUBE B	0.39
	400-00344	LUBRICATING INLET CAP	1
	WP-0460556-SD	WASHER 4.6X7.5X0.5	3
	235-40305	FLOATER CASE CAP	1
	SL-6052092-TN	SCREW	2
	235-40057	ONCE THROUGH OIL FELT ASM.	1
	235-40008	ONCE THROUGH OIL FELT	(1)
	236-30007	TUBE	(1.07)
	B3536-122-000	FLOATER	1
	236-28357	FLOATER ASM.	1
	236-28704	FLOATER CASE	15
	236-29306	PIPE STOPPER A	3
	236-29405	PIPE STOPPER B	1
	235-39703	LUBRICATION TANK PIPE GUIDE	1
	235-40107	ONCE THROUGH OIL FELT PRESSER	1
	RO-0481901-00	RUBBER RING	1
	400-00343	LUBRICATING INLET	5
	236-29801	LUBRICATION CONNECTOR	1
	400-13595	OIL_EXIT_CAP	1
	RO-0982401-00	RUBBER RING	1
	RO-1952401-00	RUBBER RING	2
	SS-4110615-SP	SCREW 11/64-40 L=6	2
	SS-4110815-SP	SCREW 11/64-40 L=8	2
	SS-4121615-SP	SCREW 3/16-28 L=16	1
	SS-4110615-SP	SCREW 11/64-40 L=6	0.07
	SS-4111415-SP	SCREW 11/64-40 L=14	0.16
	M8002-430-000	STOPPER	0.16
	236-30007	TUBE	1
	236-30007	TUBE	0.18
	236-30007	TUBE	0.3
	236-29801	LUBRICATION CONNECTOR	1
	236-30106	TUBE	(1)
	401-49239	TUBE B	(2)
	400-50598	FACE LUBRICATION TANK ASM.	(1)
	SM-0081001-SD	LUBRICATION CONNECTOR	(0.475)
	TA-0850604-RO	SCREW	(0.188)
	401-49240	RUBBER PLUG	(1)
	400-22407	FACE LUBRICATION TANK	(1)
	236-30007	CORD HOLDER	(1)
	236-30007	TUBE	(1)
	RO-0982401-00	TUBE	(1)
	SL-4051091-SC	RUBBER RING	(0.42)
	235-39562	SCREW M5X0.8 L=10	(0.46)
	235-39513	FACE LUBRICATION PRESSER ASM.	(1)
	B3518-280-000	FACE LUBRICATION PRESSER	(2)
	236-30007	BALANCE LUBRICATING	1
	CQ-2200000-00	TUBE	(0.04)
	236-29306	OUL WICK	(2)
	101-26803	PIPE STOPPER A	1
	236-30452	OIL TUBE HOLDER	(1)
	236-30106	OIL FILTER ASM.	(1)
	236-29405	TUBE B	(0.09)
	236-30650	PIPE STOPPER B	1
	236-30601	OIL FILTER JOINT ASM.	1
	236-30007	OIL FILTER JOINT	1
	401-76805	TUBE	0.11
	TA-0750404-RO	OIL_TANK_PLATE	1
	EA-9500B01-00	PLUG D=7.5 L=3.5	1
	236-30007	TUBE	1

Page 40 — 20. WIPER MECHANISM COMPONENTS

Juki LZ-2290A parts on page 40

Ref	Part number	Part name	Qty
	1	BRACKET
	2	BRACKET
	3	BRACKET
	4	BRACKET
	5	BUSH
	6	CIR-CLIP
	7	BRACKET
	8	BRACKET
	9	BRACKET
	10	BRACKET
	11	SHAFT
	12	SHAFT
	13	SCREW
	14	WASHER
	15	BRACKET
	16	BRACKET
	17	COVER
	18	BUSH
	19	BUSH
	20	BRACKET
	21	BUSH
	22	SPRING
	23	BRACKET
	24	SCREW
	25	SWITCH
	26	SCREW
	27	SCREW
	28	SCREW
	29	NUT
	30	SCREW
	31	SCREW
	32	WASHER
	33	NUT
	34	BUSH
	35	SPRING

Page 41

Juki LZ-2290A parts on page 41

Ref	Part number	Part name	Qty
	225-61757	WIPER ASM.
	225-61856	WIPER BASE ASM.
	225-61807	WIPER BASE
	102-08601	WIPER LINK 1
	D2107-490-D00	PIN
	RE-0320000-K0	E-RING 3.2
	225-61955	WIPER LINK COMPL.
	102-08858	WIPER LINK ASM. 2
	225-61906	WIPER LINK
	D2107-490-D00	PIN
	102-08700	WIPER LINK SHAFT
	WP-0371016-SD	WASHER 3.7X8X1
	SS-3090520-SP	SCREW 9/64-40 L=4.5
	225-61708	WIPER
	400-03653	WIPER SOLENOID ASM.
	225-62102	WIPER BASE
	401-06937	WIPER SOLENOID ASM.
	229-55900	WIPER RUBBER A
	229-56007	WIPER RUBBER B
	225-62201	WIPER LINK
	229-56205	WIPER HINGE SCREW COLLAR
	229-56304	WIPER SPRING
	229-56504	WIPER COVER
	SL-4030631-SC	SCREW M3X6
	HA-0060000-0A	SWITCH
	229-57203	WIPER LINK COLLAR
	SD-0500481-TP	HINGE SCREW D=5 H=4.8
	229-57104	WIPER SOLENOID SHAFT
	NS-6110310-SP	NUT 11/64-40
	SD-0650321-TP	HINGE SCREW D=6.5 H=3.2
	SL-4030641-SE	SCREW
	MAO-91003000	BSW PRESSER PLATE WASHER
	NS-6110310-SP	NUT 11/64-40
	SD-0600271-SP	HINGE SCREW D=6 H=2.7
	SS-4120615-SP	SCREW 3/16-28 L=6

Page 42 — 21. UNDER COVER COMPONENTS

Juki LZ-2290A parts on page 42

Ref	Part number	Part name	Qty
1	1	UNDER COVER COMPONENTS
2	2	UNDER COVER COMPONENTS
3	3	UNDER COVER COMPONENTS
4	4	UNDER COVER COMPONENTS
5	5	UNDER COVER COMPONENTS
6	6	UNDER COVER COMPONENTS
7	7	UNDER COVER COMPONENTS
8	8	UNDER COVER COMPONENTS
9	9	UNDER COVER COMPONENTS
10	10	UNDER COVER COMPONENTS
11	11	UNDER COVER COMPONENTS
12	12	UNDER COVER COMPONENTS
13	13	UNDER COVER COMPONENTS
14	14	UNDER COVER COMPONENTS
15	15	UNDER COVER COMPONENTS
16	16	UNDER COVER COMPONENTS
17	17	UNDER COVER COMPONENTS
18	18	UNDER COVER COMPONENTS
19	19	UNDER COVER COMPONENTS
20	20	UNDER COVER COMPONENTS
21	21	UNDER COVER COMPONENTS
22	22	UNDER COVER COMPONENTS
23	23	UNDER COVER COMPONENTS
24	24	UNDER COVER COMPONENTS
25	25	UNDER COVER COMPONENTS
26	26	UNDER COVER COMPONENTS
27	27	UNDER COVER COMPONENTS
28	28	UNDER COVER COMPONENTS
29	29	UNDER COVER COMPONENTS
30	30	UNDER COVER COMPONENTS
31	31	UNDER COVER COMPONENTS
32	32	UNDER COVER COMPONENTS
33	33	UNDER COVER COMPONENTS
34	34	UNDER COVER COMPONENTS
35	35	UNDER COVER COMPONENTS
36	36	UNDER COVER COMPONENTS

Page 43

Juki LZ-2290A parts on page 43

Ref	Part number	Part name	Qty
	400-03603	UNDER COVER ASM.	(1)
	400-03604	UNDER COVER	(1)
	110-47107	RUBBER CUSHION	(2)
	101-62600	RUBBER CUSHION	(2)
	229-32453	BRACKET ASM.	(1)
	229-32404	BRACKET	(1)
	SM-9062053-SR	SCREW M6 L=20	(2)
	400-03606	KNEE LIFTER ROTATING ARM ASM.	(1)
	236-39107	BRACKET	(1)
	SM-8063012-TR	SCREW M6 L=30	(2)
	NM-6060001-SE	NUT M6	(2)
	236-39206	CONNECTING ROT	(1)
	236-39305	KNEE PRESS ROD	(1)
	236-39404	SHAFT	(1)
	236-39503	SPRING	(1)
	236-39602	CONNECTING ROD	(1)
	NS-6150310-SP	NUT 15/64-28	(2)
	RE-1000000-KO	E-RING 10	(2)
	RE-1000000-KO	E-RING 10	(1)
	SD-0720331-SP	HINGE SCREW D=7.24 H=3.3	(2)
	SM-9061853-SR	SCREW M6 L=17.5	(1)
	SM-9061853-SR	SCREW M6 L=17.5	(1)
	WP-0650876-SD	WASHER 6.5X13X0.8	(2)
	400-03605	COOLING FAN	(1)
	400-03607	FILTER	(2)
	HM-0008600-10	WIRE PRESSER A	(1)
	SM-1044050-SM	FAN FILTER	(2)
	SM-4040601-SC	SCREW M4X0.7 L=40	(2)
	229-34251	SCREW M4X0.7 L=6	(2)
	SM-9061203-SE	KNEE PAD PLATE ASM.	1
	229-34202	SCREW M6 L=12	(1)
	229-34301	KNEE PAD PLATE	(1)
	229-34400	KNEE PAD PLATE SUPPORT	(1)
	229-34509	KNEE PAD PLATE RUBBER	(1)
	229-34608	KNEE PAD PLATE COVER	(1)
	229-34608	KNEE PAD UPRIGHT SHAFT	(1)

Page 44 — 22. THREAD STAND COMPONENTS

Juki LZ-2290A parts on page 44

Ref	Part number	Part name	Qty
	229-30358	THREAD STAND ASM.	(2)
	229-31109	SPOOL PIN	(2)
	229-31000	SPOOL PIN	(2)
	229-30903	SPOOL REST CUSHION	(2)
	229-30804	SPOOL REST	(2)
	SM-6061610-SC	SCREW M6 L=16	(2)
	229-30705	THREAD REST ARM JOINT	(2)
	229-31406	SPOOL REST ROD RUBBER CAP	(1)
	229-30507	SPOOL REST ARM	(2)
	229-30408	SPOOL REST ROD UPPER	(1)
	229-31307	SPOOL REST ROD JOINT	(1)
	SM-4051405-SE	SCREW M5 L=14	(2)
	NM-6050001-SE	NUT M5	(2)
	229-30309	SPOOL REST ROD LOWER	(1)
	229-31208	THREAD GUIDE	(2)
	WS-0510002-KN	SPRING WASHER	(2)
	NM-6050001-SE	NUT M5	(2)
	NM-6160511-SE	NUT M16X1.5	(1)
	WP-1702600-SO	WASHER 17X30X2.6	(2)
	WS-1643202-KR	SPRING WASHER	(1)
	269-10059	THREAD GUIDE ARM ASM.	1
	401-06583	THREAD GUIDE	(1)
	401-06580	THREAD GUIDE UNDER BASE	(1)
	401-06576	THREAD GUIDE ARM	(1)
	401-06579	THREAD GUIDE ARM BASE	(1)
	SM-4041201-SC	SCREW M4X0.7 L=12	(2)
	NM-6040002-SE	NUT M4X0.7	(2)
	SM-4041201-SC	SCREW M4X0.7 L=12	(1)
	SM-4042501-SC	SCREW M4X0.7 L=25	(1)
	NM-6040002-SE	NUT M4X0.7	(2)

Page 45 — IP-100 PANEL COMPONENTS

Juki LZ-2290A parts on page 45

Ref	Part number	Part name	Qty
	401-22922	PANEL D ASSY	1
	401-22923	PANEL E ASSY	1
	401-06878	PANEL ASSY	(1)
	401-06879	PANEL PCB ASSY	(1)
	401-05700	FRONT PANEL	(1)
	401-06354	MEMBRANE SWITCH	(1)
	401-05715	LCD COVER	(1)
	401-05720	LCD MODULE	(1)
	ST-4030851-SN	SCREW	(4)
	401-05717	ONLINE INDICATOR	(1)
	401-09555	METAL FOIL SHEET	(1)
	SM-4030401-SN	SCREW M3 L=4	(1)
	401-05714	CONNECTOR COVER B	(1)
	401-05716	POWER INDICATOR	(1)
	401-05707	BACK PANEL	(1)
	SV-4032001-SN	SCREW	(4)
	ST-4030851-SN	SCREW	(1)
	401-05713	CONNECTOR COVER A	(1)
	400-05848	D-SUB 9P COVER	(1)
	401-05188	CORD EXIT COVER	(1)
	401-23001	PANEL BRACKET	(1)
	SV-4031001-SN	SCREW	(4)
	401-19704	CONVERTER_CABLE ASSY	(1)
	CM-5001000-03	CE LABEL	(1)
	401-15767	TYPE LABEL DOC	(1)
	400-24479	TYPE LABEL EOA	(1)
	400-55293	CF TYPE-D	1
	400-55295	CF TYPE-D	1
	400-08168	OP SWITCH CABLE A ASSY	1

Page 46 — 24. SC-915/SC-916 TRANSMISSION COMPONENTS (1)

Juki LZ-2290A parts on page 46

Ref	Part number	Part name	Qty
	47	A
	44
	46
	49
	45
	43
	50
	22
	21
	5~8
	10~12
	9
	1.35
	A
	31
	13
	15
	17
	29
	26
	32
	33
	34
	38
	37
	36
	14
	16
	20
	23
	24
	25
	28
	19
	27
	4
	18
	39
	42
	40
	41

Page 47

Juki LZ-2290A parts on page 47

Ref	Part number	Part name	Qty
	400-05951	CTL PCB A ASM.
	400-00056	FLT-T PCB A ASS'Y
	400-00046	FLT-S PCB A ASS'Y
	400-05979	REGENERATIVE RESISTANCE A ASM.
	400-06000	REAR COVER A ASM.
	400-06001	REAR COVER 200V 1-PHASE ASM.
	400-12697	REAR COVER A ASSY
	400-12698	REAR COVER B ASSY
	400-15548	REAR COVER
	CM-3001004-01	LABEL 3 (LARGE)
	CM-3001000-03	VOLTAGE WARNING LABEL(25)
	CM-3004006-01	VOLTAGE CAUTION LABEL
	HX-0022200-0B	CABLE CLAMP
	SL-4040881-SC	SCREW M4 L=8
	400-03451	CONTROL BOX
	M3801-476-000	TRANSMISSION BOX FITTING PLATE
	401-54493	FAN ASSY
	HM-000800-10	SPACER
	HX-0033700-0B	SPACER
	SL-6083092-TN	SCREW
	WS-0410002-KN	SPRING WASHER
	WP-0430801-SC	WASHER 4.3X9X0.8
	M4206-461-000	WASHER
	WP-0841601-SC	WASHER 8.4X17.4X1.6
	NM-6080001-SC	NUT M8X1.25
	SL-4040891-SC	SCREW M4 L=8
	SL-4040891-SC	SCREW M4 L=8
	SL-4040881-SC	SCREW M4 L=8
	NM-3040520-SF	FLANGE NUT M4
	SL-4044091-SE	SCREW M4 L=40
	SL-4040891-SC	SCREW M4 L=8
	400-05987	PDD RELAY CORD A ASM.
	400-05985	DC85 VOLT CORD A ASM.
	400-05986	DC33 VOLT CORD A ASM.
	400-16451	CTL PCB A ASSY
	HX-0051100-00	WIRE SADDLE
	400-06003	CTL CLAMP HOLDER PLATE
	400-15544	BTPM POWER CABLE ASSY
	401-54493	FAN ASSY
	400-05404	FAN MOTOR BRACKET
	SL-4040891-SC	SCREW M4 L=8
	SL-4033091-SC	SCREW M3 X 0.5 L=30
	400-13881	BTPM PCB A ASSY
	400-13864	BTPM PCB HOLDER BOARD
	HX-0014700-OC	SPACER
	HX-0033900-00	STUD
	HX-0059400-00	SPACER
	SL-4040881-SC	SCREW M4 L=8
	SL-4040891-SC	SCREW M4 L=8
	SM-9041050-SC	SCREW M4X0.7 L=10

Page 48 — 25. SC-915/SC-916 TRANSMISSION COMPONENTS (2)

Juki LZ-2290A parts on page 48

Ref	Part number	Part name	Qty
	31	SCREW
	32	BRACKET
	41	HOLDER
	39	COVER
	38	GROMMET
	40	CLIP
	34	SCREW
	36	WASHER
	21	HARNESS
	22	HARNESS
	33	HARNESS
	23	PANEL
	24	PANEL
	35	CLAMP
	1	COVER
	29	BRACKET
	25	PANEL
	30	BRACKET
	19	SCREW
	3	BRACKET
	9	BRACKET
	28	GROMMET
	17	SCREW
	11	WASHER
	16	SPRING
	13	SHAFT
	14	SHAFT
	26	LABEL
	27	LABEL
	20	SCREW
	12	SPRING
	8	LEVER
	7	BASE
	6	BRACKET
	5	SWITCH
	15	BRACKET
	10	BRACKET
	18	SCREW
	4	BRACKET
	2	BRACKET
	37	FOOT

Page 49

Juki LZ-2290A parts on page 49

Ref	Part number	Part name	Qty
	400-06021	PWR CIRCUIT BOARD A ASM.
	400-05980	PEDAL SENSOR UNIT A ASM.
	SM-8040802-TP	SCREW M4X8
	400-05981	SENSOR FITTING PLATE A ASM.
	M4006-461-000	SENSOR INSTALLING PLATE
	EA-9500B01-00	CABLE BAND
	M4001-461-000	PEDAL SENSOR BASE
	M4002-461-000	PEDAL LEVER
	M4004-461-000	PEDAL RING
	M4005-461-000	VOLUME LINK
	M2010-110-000	ADJUST NUT
	M4007-351-000	FRONT SPRING
	M4008-351-000-A	SPRING SHAFT A
	M4009-351-000-A	SPRING SHAFT B
	SV-4030601-SR	SCREW M3 L=6
	M4011-351-000	SPRING B
	M4012-351-000	ADJUST SCREW
	SM-4030801-SF	SCREW M3X0.5 L=8
	SL-4040881-SC	SCREW M4 L=8
	SL-4041681-SF	SCREW M4 L=16
	400-05975	AC INPUT 1-PHASE CORD A ASM.
	400-05976	AC INPUT 1-PHASE CORD A ASM.
	400-05990	FRONT COVER A ASM.
	400-05992	FRONT COVER 200V 1-PHASE ASM.
	400-05991	TRANSMISSION BOX FRONT COVER
	CM-3001000-03	VOLTAGE WARNING LABEL(25)
	CM-3001004-01	LABEL 3 (LARGE)
	HX-0040700-00	BUSH
	178-45009	CORD FITTING PLATE
	SL-4042091-SC	SCREW M4X0.7 L=20
	SL-4041091-SE	SCREW M4 L=10
	SL-4040891-SC	SCREW M4 L=8
	400-05977	AC INPUT 1-PHASE CORD CE ASM.
	CM-2001000-01	PE MARK LABEL
	HX-0041000-0A	STRAIN RELIEF BUSHING
	E9567-319-000	EARTH MARK
	SL-4040891-SC	SCREW M4 L=8
	HX-0018800-0D	BUSH
	400-06002	BOX HORIZONTAL COVER
	HX-0022200-0A	CABLE CLAMP
	HX-0051100-00	WIRE SADDLE

Page 50 — 26. SC-915/SC-916 ACCESSORIE PARTS COMPONENTS

Juki LZ-2290A parts on page 50

Ref	Part number	Part name	Qty
	400-05390	POWER CABLE JE ASM.
	401-13427	BOX ACCESSORIE PART A ASM.
	400-06010	CONNECTING ROD ASM. B
	229-58458	CONNECTING ROD ASM. B
	HF-0013010-00	TIMING LAG FUSE 10A
	HF-0078020-PO	FUSE 2A
	MTS-HJ10003	BOLT
	NM-6080002-SC	NUT M8
	WP-0852086-SC	WASHER M8
	WS-0820002-KR	SPRING WASHER M8
	SM-6084002-TN	SCREW M8 L=40
	WS-0820002-KR	SPRING WASHER M8
	WP-0841601-SC	WASHER 8.4X17.4X1.6
	SK-3512001-SE	WOOD SCREW D=5.1 L=20
	MAO-11532000	CORD STAPLE
	HX-0051000-00	OMEGALOCK
	400-05988	HEAD FAN RELAY CORD A ASM.
	M9034-580-0A0	GROUND CORD ASM.
	M9024-580-0A0	POWER CABLE ASM. 100V
	M9017-580-0A0	POWER CABLE ASM.
	M9035-580-0A0	POWER SOURCE CORD ASM.

Page 51 — 27. ACCESSORIE PARTS COMPONENTS

Juki LZ-2290A parts on page 51

Ref	Part number	Part name	Qty
	225-87174	ACCESSORIE BAG
	225-96704	BOBBIN S
	229-33204	SCREW DRIVER SMALL
	236-39701	KNEE LIFTER PRESSER ROD
	229-32800	ACCESSORIE BAG
	B9102-057-000	WRENCH (3/32)
	229-58052	RUBBER HINGE ASM.
	229-58003	FRAME BUBBER CUSHION
	229-26208	NAIL
	229-26356	HINGE COMPL.
	229-26505	WASHER
	229-26000	RUBBER CUSHION
	262-34005	VINYL COVER
	MDP-500B1002	NEEDLE DPX5 #10-2
	236-40006	SHEET
	100-25906	SPACER
	225-36502	TIMING GAUGE E
	141-01208	HEAD SUPPORT BAR
	MDF-RX1200C0	NEW DEFRIX OIL NO.1 (200ML)
	B9121-012-0A0	OILER ASM.
	400-06323	JUKE GREASE A TUBE
	225-03908	SPACER
	MC-1923007-52	NEEDLE 438 #75-2

Page 52 — 28. COMMON PARTS FOR LZ-2290A-DS,LZ-2290A-DS-7,LZ-2290A-DU,LZ-2290A-DU-7

Juki LZ-2290A parts on page 52

Ref	Part number	Part name	Qty
	235-56053	NEEDLE ROD SUPPORT BASE D ASM.
	235-56004	NEEDLE ROD METAL D
	235-56301	SUPPORT BASE GUIDE SHAFT D
	235-56202	NEEDLE ROD CRANK ROD GUIDE D
	235-56103	NEEDLE ROD HOLDER D
	235-58109	INNER HOOK STOPPER D
	400-03609	BOBBIN CASE D3 COMPL.
	400-03610	BOBBIN CASE D3 ASM.
	235-57259	Hook COMPL. D
#01	SS-4120915-SP	SCREW 3/16-28 L=9
	235-58208	FEED D
	235-58000	FEED BASE D
#01	235-58406	VERTICAL FEED LINK SHAFT D
#01	400-10264	VERTICAL FEED LINK
	235-57101	OIL SEAL COLLAR D
	235-57051	BEARING D ASM.
	SS-8110410-TP	SCREW 11/64-40 L=3.5
	235-35255	Hook SHAFT BEARING ASM.
	SS-8110510-SP	SCREW 11/64-40 L=5

Page 53 — 29. CB TYPE (1) (PRESSER FOOT COMPONENTS)

Juki LZ-2290A parts on page 53

Ref	Part number	Part name	Qty
	400-03542	WIDE KNIFE PRESSER ASM.	(1)
	400-03543	PRESSER (UPPER)	(1)
	400-03544	PRESSER (LOWER) WIDE	(1)
	400-03545	FINGER GUARD	(1)
	400-03547	FIXING PLATE (WIDE) COMPL.	(1)
	400-03546	KNIFE FIXING PLATE (WIDE)	(1)
	400-03553	KNIFE STOPPER SCREW	(2)
	114-34206	THREAD CUTTER KNIFE	(2)
	400-03554	STOPPER SCREW	(2)
	100-56109	PRESSER PIN A	(1)
	B1525-582-000	SPRING	(1)
	SS-6090810-SP	SCREW 9/64-40 L=7.5	(1)
	400-03549	NARROW KNIFE PRESSER ASM.	1
	400-03543	PRESSER (UPPER)	(1)
	400-03545	FINGER GUARD	(1)
	400-03552	PRESSER LOWER (NARROW)	(1)
	400-03551	FIXING PLATE (NARROW) COMPL.	(1)
	400-03550	KNIFE FIXING PLATE (NARROW)	(1)
	400-03553	KNIFE STOPPER SCREW	(1)
	114-34206	THREAD CUTTER KNIFE	(1)
	400-03554	STOPPER SCREW	(2)
	225-47806	PRESSER PIN	(1)
	B1525-582-000	SPRING	(1)
	SS-6090810-SP	SCREW 9/64-40 L=7.5	(1)

Page 54 — 30. CB TYPE (2) (THREAD HOLDER & AIR COMPONENTS)

Juki LZ-2290A parts on page 54

Ref	Part number	Part name	Qty
1	1	CONNECTOR
2	2	VALVE
3	3	BRACKET
4	4	BRACKET
5	5	CONNECTOR
6	6	WASHER
7	7	SCREW
8	8	TUBE
9	9	CONNECTOR
10	10	WASHER
11	11	BRACKET
12	12	BRACKET
13	13	BRACKET
14	14	BRACKET
15	15	BRACKET
16	16	VALVE
17	17	CONNECTOR
18	18	BRACKET
19	19	SCREW
20	20	BRACKET
21	21	CONNECTOR
22	22	SCREW
23	23	BRACKET
24	24	REGULATOR
25	25	BRACKET
26	26	CONNECTOR
27	27	TUBE
28	28	SCREW
29	29	SCREW
30	30	CABLE
31	31	SCREW
32	32	BRACKET
33	33	SCREW
34	34	BAG
35	35	CONNECTOR
36	36	CHAIN
37	37	TUBE
38	38	BRACKET
39	39	TUBE
40	40	CONNECTOR
41	41	TUBE
42	42	TUBE
43	43	TUBE
44	44	TUBE
45	45	CONNECTOR
46	46	TUBE
47	47	BRACKET

Page 55

Juki LZ-2290A parts on page 55

Ref	Part number	Part name	Qty
	PJ-0325260-01	HOSE NIPPLE	1
	114-29305	CLAMP HEAD	1
	400-03536	CLAMP BASE A	1
	400-03537	CLAMP BASE B	1
	114-29008	CLAMP CYLINDER	1
	114-28505	CLAMP BALL	1
	SS-7110840-SP	SCREW 11/64-40 L=7.8	2
	PJ-3090405-01	ELBOW UNION	1
	400-03538	HEAD COVER	1
	114-27705	HEAD BUSH	1
	400-03562	ELECTROMAGNETIC VALVE COMPL.	1
	400-03565	FITTING PLATE	(1)
	PV-1352070-00	3-PORT ELECTROMAGNETIC VALVE	(1)
	PV-1305390-00	3-PORT ELECTROMAGNETIC VALVE	(1)
	PJ-3010852-01	HALE UNION	(1)
	PJ-3040652-01	ELBOW UNION 6XPT1/4	(1)
	PJ-3010605-01	HALE UNION	(1)
	PX-0505010-00	SILENCER	(1)
	SL-4850891-SC	SCREW M2.5 L=8	(2)
	PJ-0251000-02	PLUG R 1/8	(1)
	SL-4030891-SC	SCREW M3X8	(2)
	NM-6030001-SC	NUT M3	(2)
	400-03560	REGULATOR ASM.	1
	PF-0152030-A0	FILTER REGULATOR	(1)
	PF-9020050-00	REGULATOR BRACKET	(1)
	PJ-3080800-01	UNION Y	1
	F1012-003-0A0	NOZZLE ASM.	1
	B1155-771-000	CUSHION	1
	SK-3412000-SC	WOOD SCREW D=4.1 L=20	2
	400-03564	CORD ASM.	1
	SS-7110840-SP	SCREW 11/64-40 L=7.8	2
	SS-4110715-SP	SCREW 11/64-40 L=7	1
	SK-3412000-SC	WOOD SCREW D=4.1 L=20	2
	114-28802	DUST BAG	1
	PJ-3010800-01	REDUCER	1
	HX-0028900-00	BEADE BAND	1
	BT-1601001-Z0	TUBE	0.4
	BT-0400251-EB	URETHANE HOSE BLACK	1.5
	BT-0600401-EB	TUBE	0.14
	BT-0800501-EB	VINYL TUBE	1
	PX-9500090-00	VINYL TUBE	0.06
	BT-0800501-EB	TUBE	0.3
	BT-0800501-EB	VINYL TUBE	0.13
	BT-0600401-EB	TUBE	1.3
	BT-0800501-EB	VINYL TUBE	1
	BT-1601001-Z0	UNION Y	0.15
	D8204-555-D00	DRAWER STOPPER	2

Page 56 — 31. CB TYPE (3) (WIPER MECHANISM COMPONENTS)

Juki LZ-2290A parts on page 56

Ref	Part number	Part name	Qty
	1	BRACKET, MOTOR
	2	BRACKET, MOTOR
	3	SCREW, PAN HEAD, 4X10
	4	BOLT, HEX HEAD, 5X16
	5	NUT, HEX, 5MM
	6	BRACKET, LINK
	7	LINK, WIPER
	8	SCREW, PAN HEAD, 3X6
	9	SCREW, PAN HEAD, 4X12
	10	BUSHING
	11	SPRING, TORSION
	12	NUT, HEX, 6MM
	13	WASHER, THRUST
	14	WASHER, THRUST
	15	BRACKET, MOTOR
	16	SHAFT, MOTOR
	17	SWITCH, ROCKER
	18	WIRE HARNESS
	19	WIRE HARNESS
	20	BRACKET, MOTOR
	21	SPRING, COMPRESSION
	22	SCREW, PAN HEAD, 4X8
	23	WIRE HARNESS
	24	BRACKET, WIPER
	25	SCREW, PAN HEAD, 4X10
	26	BUSHING
	27	SHAFT, WIPER
	28	BUSHING
	29	SPRING, TORSION
	30	BRACKET, SPRING
	31	MOTOR, WIPER
	32	BRACKET, MOTOR

Page 57

Juki LZ-2290A parts on page 57

Ref	Part number	Part name	Qty
	400-03534	WIPER FITTING BASE ASM.	1
	114-25907	WIPER COVER	1
	SL-4030631-SC	SCREW M3X6	1
	SD-0650321-TP	HINGE SCREW D=6.5 H=3.2	1
	NS-6090310-SP	NUT 9/64-40	1
	229-56106	WIPER LINK A	1
	400-03529	WIPER LINK B	1
	RE-0250000-KO	E-RING 2.5	1
	229-56908	WIPER LINK B HINGE SCREW	1
	229-56205	WIPER HINGE SCREW COLLAR	1
	229-56304	WIPER SPRING	1
	NS-6110310-SP	NUT 11/64-40	1
	229-55900	WIPER RUBBER A	1
	229-56007	WIPER RUBBER B	1
	401-06937	WIPER SOLENOID ASM.	1
	229-57104	WIPER SOLENOID SHAFT	1
	HA-0060000-0A	SWITCH	1
	HW-2003900-00	ELECTRIC WIRE	0.04
	HW-5F18S12-28	TWO-CORE CORD	1.7
	400-03528	WIPER BASE	2
	SS-8080310-TP	SCREW 1/8-44 L=2.8	4
	SL-4030641-SE	SCREW	2
	HK-0346400-0B	PIN CONTACT	1
	400-03539	WIPER	1
	SS-6090540-SP	SCREW 9/64-40 L=5.0	1
	229-56809	WIPER COLLAR	1
	400-03540	WIPER SHAFT ASM.	1
	229-57203	WIPER LINK COLLAR	1
	114-29107	SLIDE SPRING	1
	114-22706	STOPPER SPRING B	1
	400-03530	RATCHET COMPL.	1
	114-25451	FOLLOWER ASM.	1

Page 58 — 32. SPECIAL ORDER PARTS LZ-2290A (1)

Juki LZ-2290A parts on page 58

Ref	Part number	Part name	Qty
	1	A
	2	B
	3	C
	4	D
	5	E
	6
	7
	8
	9
	10.21
	11
	12
	13
	14
	15
	16
	17
	18
	19
	20
	21
	22
	23
	24
	25
	26
	27
	28
	29
	30~34
	35
	36
	37
	38
	39
	40
	41
	42
	43
	44
	45
	46
	47
	48
	49
	50
	51
	52
	53
	54
	55
	56.57
	57
	58
	59
	60.61
	61
	62
	63
	64
	65
	66
	67
	68
	69
	70
	71
	72
	73
	74
	75
	76
	77
	78
	79
	80.81
	81
	82
	83
	84
	85
	86
	87
	88
	89
	90
	91
	92
	93

Page 59

Juki LZ-2290A parts on page 59

Ref	Part number	Part name	Qty
	225-35801	TIMING GAUGE
	225-86705	TIMING GAUGE
	225-35900	TIMING GAUGE RIGHT
	225-36403	TIMING GAUGE D
	225-36502	TIMING GAUGE E
	B1551-586-000	PRESER FOOT JOINT
	SS-7090910-SP	PRESSER BAR
	D1501-583-H00	PRESSER BAR
	D1502-583-H00	PRESSER ADJUSTING SPRING
	B1505-227-00A	KNIFE UNIT
	225-56054	FIXED KNIFE
	225-56302	CLAMP PLATE ASM.
	225-56450	SLIDING PLATE
	225-56609	DRIVING BASE
	225-56708	DRIVING BASE
	225-56807	SCREW 9/64-40 L=5
	SS-1090510-SP	SCREW 9/64-40 L=4.0
	SS-6090420-SP	SCREW 9/64-40 L=6.8
	SS-7090710-SP	DRIVING KNIFE ASM.
	225-56153	SPRING
	111-62104	DRIVER
	B9101-490-000	NEEDLE HOLDER ASM.
	225-25455	NEEDLE GUARD
	225-25406	SCREW M3X0.5 L=6
	SM-6030602-TP	WASHER M3
	WS-0310702-KS	SPRING WASHER
	WP-0320500-SC	WASHER M3
	100-25906	SPACER
	225-03908	SPACER
	225-25059	HOOK COMPL. V(LASTIC HOOK)
	225-26677	HOOK COMPL. V(HARD POINT)
	225-26578	HOOK COMBINATION (HARD POINT)
	225-25257	HOOK COMPL. V(PLASTIC HOOK)
	225-25752	HOOK COMPL. V(PLASTIC HOOK)
	225-25968	OUTER HOOK V.
	225-25919	ROTATING HOOK V ASM.
	235-03501	OUTER HOOK V.
	100-33009	INNER HOOK V.
	225-26206	HOOK GIB SCREW
	100-33108	REVERSE PLATE V
	225-26008	HOOK COUNTER BALANCE SCREW
	SS-8110422-TP	INNER HOOK V.
	SS-8110520-TP	SCREW 11/64-40 L=4.5
	225-07701	THREAD RACK RIGHT.
	225-03353	SAFETY PLATE ASM.
	235-22550	NOT TURN BOBBIN CASE ASM.
	235-23004	NOT TURN BOBBIN.
	235-23152	NOT TURN BOBBIN HOOK COMPL. V.
	225-25919	OUTER HOOK V.
	235-03501	INNER HOOK PRESSER V-S
	100-33009	HOOK GIB SCREW.
	235-23202	NOT TURN BOBBIN INNER HOOK V
	100-33108	HOOK COUNTER BALANCE SCREW.
	225-26008	INNER HOOK V.
	SS-8110422-TP	SCREW 11/64-40 L=4
	235-02958	HOOK CONNECTION K
	235-03709	OUTER HOOK S
	235-03808	INNER HOOK S
	235-03907	INNER HOOK PRESSER S
	235-03006	INNER HOOK PRESSER K
	235-04004	INNER HOOK PRESSER K
	235-04103	BACK PLATE S
	235-04301	INNER HOOK PRESSER SETSCREW S
	235-04400	OUTER HOOK SETSCREWS
	235-04657	BOBBIN CASE WITH SPRING
	235-34951	R FEED KITS
	235-34902	FEED BASE SHAFT R
	225-19706	FEED BASE
	100-26508	LINK PIN
	198-00903	LC-601-1/ LATCH LEVER
	198-01000	LC-602-2/ LATCH
	198-01307	SMS-801-B/ SETSCREW PICK-UP
	198-01109	LSP-4/ LATCH SPRING
	198-01208	LFP-1/ LATCH PIN
	198-01406	TSP-604-B/ TENSION SPRING
	198-01505	SMS-608-B/ TENSION SCREW
	198-01604	BOBBIN
	225-24201	REVERSE PLATE
	225-24805	REVERSE PLATE V
	225-26206	INNER PRESSER V-S4
	235-03303	OP SWITCH CABLE A ASM.
	400-17095	THREAD TENSION DISK ASM
	400-17095	SMARTMEDIA CARD
	HX-0057500-00	PRESSER FOOT ASM.
	225-91564	FEED DOG
	100-64004	THROAT PLATE ASM.
	MAM-09700BA0	FAGOTTING FOLDER ASM.
	SS-5110710-SP	SCREW 11/64-40 L=7
	MAM-097000A0	FAGOTTING FELLER
	400-16408	HOOK GIB VS
	400-91888	FAN RELAY CABLE

Page 60 — 33. SPECIAL ORDER PARTS LZ-2290A (2)

Juki LZ-2290A parts on page 60

Ref	Part number	Part name	Qty
1	400-23431	HOOK COOLING UNIT	(1)
2	400-23432	FILTER REGULATOR ASM.	(1)
3	PV-0151220-00	FINGER VALVE	(1)
4	PF-0551060-A0	FILTER REGULATOR	(1)
5	PF-9020050-00	REGULATOR BRACKET	(1)
6	PJ-0251000-03	PLUG	(1)
7	400-23433	PIPE BRACKET ASM.	(1)
8	400-23434	PIPE BRACKET	(1)
9	400-23435	BLOWING PIPE	(1)
10	110-45408	WIRE HOLDER A	(1)
11	BT-0400251-EB	URETHANE HOSE BLACK	(1)
12	SS-4110715-SP	SCREW 11/64-40 L=7	(2)
13	SK-3412001-SE	WOOD SCREW D=4.1 L=20	(2)
14	SS-4111215-SP	SCREW 11/64-40 L=12	(2)
15	WP-0450801-SD	WASHER 4.5X10X0.8	(2)
16	B4122-804-000	ROLLER	(2)
17	MA-0115320-00	STAPLE	(2)
18	EA-9500B01-00	CABLE BAND	(2)

Page 61 — 34. SPECIAL ORDER PARTS LZ-2290A (3)

Juki LZ-2290A parts on page 61

Ref	Part number	Part name	Qty
	400-25920	TWO NEEDLES BAR SET	(1)
	400-25762	THREAD TENSION ASM.	(1)
	400-25763	TENSION BASE PLATE	(1)
	225-28764	PRE-TENSION CONTROLLER ASM.	(1)
	400-25764	TWO NEEDLES CLAMP ASM.	(1)
	400-99885	NEEDLE CLAMP ASM.	(1)
	400-25768	GUIDE BLOCK R	(1)
	400-25767	GUIDE BLOCK R	(1)
	400-25765	NEEDLE CLAMP	(1)
	400-25766	TWO NEEDLES CLAMP PLATE	(1)
	SS-4060310-SP	SCREW 3/32-56 L=2.5	(2)
	SS-8080410-TP	SCREW 1/8-44 L=3.5	(2)
	B1401-380-000	NEEDLE BAR	(1)
	400-25769	GUIDE BLOCK SCREW	(1)
	400-25913	THREAD TENSION ASM.C	(1)
	235-47557	THREAD TENSION T COMPL.	(2)
	225-28509	FELT	(4)
	229-21407	ROTATION STOPPER	(1)
	235-37665	THREAD TENSION ROD BASE ASM.	(1)
	235-37756	THREAD TENSION ROD COMPL.	(1)
	400-25915	THREAD TENSION PIN	(1)
	236-26005	TENSION NUT	(1)
	B3129-012-A00	THREAD SPRING	(1)
	SS-8090670-SP	SCREW 9/64-40 L=5.5	(1)
	RO-1331701-00	RUBBER RING	(1)
	100-06005	TENSION DISC HOLDER	(1)
	235-38309	THREAD TAKE-UP SPRING	(1)
	400-25923	TWO NEEDLES BAR SET INSTRUCTIO	(1)
	SS-6620730-SP	SCREW 3/16-32 L=7.0	(1)

Page 62 — 35. LIST FOR INFORMATION OF CHANGE

Juki LZ-2290A parts on page 62

Ref	Part number	Part name	Qty
14	293-42409

Page 67

Juki LZ-2290A parts on page 67

Ref	Part number	Part name	Qty
43	400-10261	400-17008	16
22	400-10262	400-17100	2
23	400-10264	400-17101	2
24	400-10264	400-17102	2
25	400-10268	400-17103	2
73	400-10269	400-18430	12
88	400-10270	400-20454	4
39	400-10271	400-21933	4
63	400-10272	400-22407	2
16	400-10273	400-22407	16
46	400-10276	400-22407	34
1	400-10278	400-23431	55
2	400-10280	400-23432	55
7	400-10281	400-23433	55
8	400-10282	400-23434	55
9	400-10283	400-23435	55
26	400-10286	400-24479	40
54	400-10287	400-24644	4
2	400-10287	400-25762	56
3	400-10288	400-25763	56
5	400-10289	400-25764	56
9	400-10289	400-25765	56
10	400-10290	400-25766	56
8	400-10295	400-25767	56
7	400-10296	400-25768	56
14	400-10297	400-25915	56
21	400-10298	400-25920	56
28	400-10303	400-25923	56
28	400-10307	400-26835	4
87	400-10311	400-26836	4
18	400-10312	400-28014	6
24	400-10313	400-28294	4
3	400-10314	400-28463	4
83	400-10315	400-35589	4
56	400-10316	400-37008	4
39	400-10318	400-50457	12
42	400-10321	400-50598	34
27	400-10322	400-55293	40
28	400-10324	400-55295	40
42	400-11123	400-56873	6
17	400-11144	400-70531	10
41	400-11345	400-70532	6
93	400-11424	400-91888	54
6	400-11831	400-99885	56
20	400-11832	401-05188	40
15	400-11833	401-05707	40
13	400-11836	401-05713	40
18	400-11837	401-05714	40
7	400-11838	401-05715	40
13	400-11839	401-05715	40
14	400-11840	401-05716	40
10	400-11841	401-05717	40
8	400-11842	401-05720	40
6	400-11843	401-06354	40
24	400-11844	401-06576	39
25	400-11846	401-06579	39
23	400-11847	401-06580	39
22	400-11848	401-06583	39
17	400-11849	401-06937	36
15	400-11850	401-06937	52
4	400-12697	401-08063	26
5	400-12698	401-08064	26
3	400-13595	401-08879	40
4	400-13864	401-08880	40
11	400-13881	401-09555	40
2	400-14837	401-13427	45
25	400-15494	401-15767	40
85	400-15544	401-16677	4
23	400-15548	401-19704	40
28	400-16039	401-20730	20
1	400-16408	401-22922	40
2	400-16451	401-22923	40
21	400-17095	401-23001	40
16	400-10261	401-25469	10
70	400-10262	401-25483	12
34	400-10264	401-39216	12
26	400-10264	401-49234	12
2	400-10268	401-49235	8
1	400-10269	401-49236	8
33	400-10270	401-49239	8
41	400-10271	401-49240	34
45	400-10272	401-49245	34
20	400-10273	401-49244	12
21	400-10276	401-49245	12
8	400-10278	401-49251	12
7	400-10280	401-49252	22
9	400-10281	401-49253	22
10	400-10282	401-49253	22
17	400-10283	401-54492	42
39	400-10286	401-54492	42
3	400-10287	401-60261	6
20	400-10287	401-60262	22
1	400-10288	401-75861	34
64	400-10289	401-76805	34

Part BooksPartsSearchNotes

Part Books

×

Search

×

Juki LZ-2290A — parts catalog

• Page 1 (cover): This is the cover page for the LZ-2290A Series Parts List, providing information on how to access the online parts book.
• Page 2 (unknown): This page contains a watermark and a website address at the bottom.
• Page 3 (text): This page explains how to use the parts list, including codes for changed parts, quantity column explanations, and how to interpret diagrams.
• Page 6 (diagram): This page displays a diagram of frame and miscellaneous cover components for an industrial sewing machine, with numbered parts indicated for identification.
• Page 7 (parts_list): This page lists various parts for industrial sewing machines, including screws, bolts, washers, and specialized components like resistance packs and thread tension parts, along with their part numbers and descriptions.
• Page 8 (diagram): This page displays a diagram of frame and miscellaneous cover components for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 9 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes. It covers a wide range of components from gear boxes and screws to safety switches and labels.
• Page 10 (diagram): This page displays a diagram of main shaft and thread take-up and needle bar components, with numbered parts for identification.
• Page 11 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes. It covers items from reference number 1 to 70.
• Page 12 (diagram): This page displays a diagram of needle vibrator components, with numbered parts and their corresponding references.
• Page 13 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, and quantities. It details items like needle vibrator units, shafts, screws, and washers.
• Page 14 (diagram): This page displays a diagram of hand lifter components, with numbered parts and their corresponding part numbers and descriptions.
• Page 15 (parts_list): This page lists parts for sewing machines, including part numbers, descriptions, and quantities. It details components like knee lifting links, presser feet, and various screws and hardware, with specific notes for different machine models.
• Page 16 (diagram): This page displays a diagram of feed mechanism components, with numbered parts and their corresponding references.
• Page 17 (parts_list): This page lists parts for various sewing machine models, including feed adjusting springs, shafts, plates, screws, and bearings, with their corresponding part numbers and quantities.
• Page 18 (diagram): This page displays a diagram of feed mechanism components, specifically for models except LZ-2290A-SR-7, with numbered parts for identification.
• Page 19 (parts_list): This page lists parts for the sewing machine, including feed adjusting shafts, screws, levers, and condensers, with their corresponding part numbers, descriptions, and quantities.
• Page 20 (diagram): This page displays a diagram of feed mechanism components for the LZ-2290A-SR-7 sewing machine, with numbered parts indicated.
• Page 21 (parts_list): This page lists parts for the sewing machine, including part numbers, descriptions, and quantities. It covers items from reference number 1 to 48, with a note at the end indicating selective parts.
• Page 22 (diagram): This page displays a diagram of feed mechanism components for the LZ-2290A-SR-7 sewing machine, with numbered parts indicated.
• Page 23 (parts_list): This page lists parts for an industrial sewing machine, including part numbers, descriptions, quantities, and reference numbers. It details items such as feed lever rods, screws, springs, and sensors.
• Page 24 (diagram): This page displays a diagram of hook driving shaft components, with numbered parts and their corresponding references.
• Page 25 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, and quantities. It also includes notes regarding specific models.
• Page 26 (diagram): This page displays a diagram of hook driving shaft components, with numbered parts and their corresponding references.
• Page 27 (parts_list): This page lists parts for the lower shaft, including bearings, gears, screws, and oil seals, with their corresponding part numbers and quantities.
• Page 28 (diagram): This page displays a diagram of thread trimmer mechanism components for LZ-2290A-SS-7, LZ-2290A-SU-7, and LZ-2290A-SR-7 models.
• Page 29 (parts_list): This page lists parts for an industrial sewing machine, including part numbers, descriptions, and quantities. It covers items from reference number 1 to 54.
• Page 30 (parts_list): This page lists feed mechanism components for LZ-2290A-SU, LZ-2290A-SU-7, LZ-2290A-DU, and LZ-2290A-DU-7 models, including part numbers, descriptions, and quantities.
• Page 31 (diagram): This page displays a diagram of automatic reverse feed mechanism components for LZ-2290A-SS-7 and LZ-2290A-SU-7 models, along with a parts list detailing part numbers, descriptions, and quantities.
• Page 32 (parts_list): This page lists components for thread feeder components, including part numbers, descriptions, and quantities.
• Page 33 (diagram): This page displays a diagram of manual switch components for LZ-2290A-SS and LZ-2290A-SU models, along with a parts list detailing part numbers, descriptions, and quantities.
• Page 34 (diagram): This page displays a diagram of manual switch components for models LZ-2290A-SS-0B and LZ-2290A-SU-0B, with numbered parts indicated.
• Page 35 (parts_list): This page lists parts for a sewing machine, including manual switch bases, cables, screws, and rubber plugs, with their corresponding part numbers and descriptions.
• Page 36 (diagram): This page displays a diagram of thread release solenoid components for LZ-2290A-SS-7, LZ-2290A-SU-7, and LZ-2290A-SR-7 models, with numbered parts indicated.
• Page 37 (parts_list): This page lists parts for a sewing machine, including solenoids, switch bases, cables, screws, nuts, and pins, with their corresponding part numbers and descriptions.
• Page 38 (diagram): This page displays a diagram of lubrication components, including various fittings, tubes, and mounting hardware, with reference numbers for each part.
• Page 39 (parts_list): This page lists parts for the lubrication system, including oil tanks, regulators, screws, tubes, and connectors, with part numbers, descriptions, and quantities.
• Page 40 (diagram): This page displays a diagram of wiper mechanism components for LZ-2290A-SS-7-WB, LZ-2290A-SU-7-WB, and LZ-2290A-SR-7-WB models, with numbered parts indicated.
• Page 41 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, and quantities. It details various wiper components, screws, nuts, and washers.
• Page 42 (diagram): This page displays a diagram of under cover components for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 43 (parts_list): This page lists parts for an industrial sewing machine, including covers, cushions, brackets, screws, and various specialized components like knee lifters and connecting rods, with their corresponding part numbers and quantities.
• Page 44 (diagram): This page displays the components of the thread stand, including a diagram and a parts list with part numbers, descriptions, and quantities.
• Page 45 (diagram): This page displays a diagram of IP-100 panel components and a detailed parts list with part numbers, descriptions, and quantities.
• Page 46 (diagram): This page displays a diagram of SC-915/SC-916 transmission components, detailing various parts with reference numbers and descriptions.
• Page 47 (parts_list): This page contains a parts list for various components of an industrial sewing machine, including control boards, covers, screws, washers, and other hardware, with part numbers, descriptions, and quantities.
• Page 48 (diagram): This page displays a diagram of SC-915/SC-916 transmission components, detailing various parts with reference numbers and labels.
• Page 49 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and notes.
• Page 50 (parts_list): This page lists accessories and components for SC-915/SC-916 models, including various cables, screws, washers, and other hardware, with their corresponding part numbers and descriptions.
• Page 51 (parts_list): This page lists accessory parts components for a sewing machine, including part numbers, descriptions, quantities, and remarks.
• Page 52 (diagram): This page displays a diagram of common parts for LZ-2290A-DS, LZ-2290A-DS-7, LZ-2290A-DU, and LZ-2290A-DU-7 sewing machines, along with a detailed parts list.
• Page 53 (diagram): This page displays a diagram and parts list for CB type (1) presser foot components, including part numbers, descriptions, and quantities.
• Page 54 (diagram): This page displays a diagram of CB Type 2 thread holder and air components, with numbered parts and their corresponding references.
• Page 55 (parts_list): This page contains a parts list for various components of an industrial sewing machine, including nipples, clamps, screws, unions, valves, regulators, tubes, and stoppers, along with their part numbers and quantities.
• Page 56 (diagram): This page displays a diagram of CB Type (3) wiper mechanism components, with numbered parts and their corresponding details.
• Page 57 (parts_list): This page lists parts for a wiper system, including fitting bases, covers, screws, nuts, links, rings, springs, solenoids, and followers, with part numbers, descriptions, and quantities.
• Page 58 (diagram): This page displays a diagram of special order parts for the LZ-2290A (1) sewing machine, with reference numbers and part names for various components.
• Page 59 (parts_list): This page lists various parts for an industrial sewing machine, including timing gauges, presser foot components, knives, screws, hooks, and other miscellaneous items, with their corresponding part numbers and descriptions.
• Page 60 (diagram): This page displays a diagram of special order parts for the LZ-2290A (2) model, along with a detailed parts list including part numbers, descriptions, and quantities.
• Page 61 (diagram): This page displays a diagram of special order parts for the LZ-2290A (3) sewing machine, along with a detailed parts list including part numbers, descriptions, and quantities.
• Page 62 (parts_list): This page contains a list for information of change, detailing added and obsolete parts with their corresponding revision numbers, page references, and part numbers.
• Page 67 (parts_list): This page contains a numerical index of parts for a sewing machine, listing part numbers, page numbers, and reference numbers across multiple columns.

Page 1 — LZ-2290A Series PARTS LIST

PARTS LIST LZ-2290A Series PARTS LIST 下記URL(PARTS Website/PCサイト)より、便利な検索機能のついた Web Parts Book をご利用頂けます。 ご利用には会員登録が必要です。(無料) https://juki.aftama.com/JUKI/JA You can use a Web Parts Book with a convenient search function from the URLs (PARTS Website/PC-site) below. To use the PARTS Website, free membership registration is required. https://juki.aftama.com/JUKI/EN No.1361-13 jintex.in

Page 2

jinttex.in jintex.in

Page 3 — HOW TO MAKE USE OF THIS PARTS LIST

HOW TO MAKE USE OF THIS PARTS LIST 1.Explanation of codes 1)"*".means this part is changed from the previous parts book. As to the details of the change, refer to the "List for information of change". 2)"#01"...refer to "Note" explanation at bottom of page. 2.Codes on the "Qty" column • Each numeral indicates the number of parts required. • "0.1" and "2.5" indicate the length (in meters) of the respective parts. 3.Parentheses mean that the corresponding part is a subpart that constructs an assembly part. 4.Dotted lines on the Figures indicate assembly parts. パーツリストご利用に際して 1."注記"欄の記号説明 1) "*"印...前回のパーツブックに比較して今回変更された部品を意味します。 変更内容は、“変更情報リスト”を参照してください。 2)"#01"...ページ下の“注記”の説明を参照してください。 2.数量欄の数字は、個数を表し、0.1、2.5等の数値は、長さ(単位メートル)を表します。 3.数量欄の（ ）は、組部品を構成している子部品であることを意味します。 4.イラストページのーーーー枠は、組構成であることを意味します。

Page 6 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS (1)

1. FRAME & MISCELLANEOUS COVER COMPONENTS (1) 頭部・外装関係 (1) 30 53 45 42 51 35 40 60 47 54 44 43 2 61 58 63 67 68 64 70 66 65 69 56 36 34 55 3 57 50 52 49 59 7~25 26 27 41 6 39 37 29 28 31 4 5 33 32 50 81 73 79 75 76 74 77 71 72 83 84 82 80 78 38 - 1 - jintex.in

Page 7

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 235-00978 FACE PLATE COMPL. メンイタ (ケツゴウ) 1 2 235-26205 SIDE PLATE マドイタ 1 3 235-26403 BED SUPPORT PLATE ベッドササエイタ 1 4 235-26403 BED SUPPORT PLATE B ベッドササエイタ B 1 5 400-11123 THREAD RELEASE AUXILIARY PIN イトユルヌメホジヨピン 1 6 225-28764 PRE-TENSION CONTROLLER ASM. プリテンシヨン (クミ) 1 7 #02 M6095-350-CAA RESISTANCE PACK CA ASM. テイコウパツク CAクミ 1 8 #03 M6096-350-CAL RESISTANCE PACK CL ASM. テイコウパツク CLクミ 1 9 #05 M6095-350-CAF RESISTANCE PACK CF ASM. テイコウパツク CFクミ 1 10 #03 M6096-350-CAF RESISTANCE PACK CF ASM. テイコウパツク CFクミ 1 11 #04 400-03625 RESISTANCE PACK CB 40 テイコウパツク CB40 1 12 #04 400-03626 RESISTANCE PACK CB 45 テイコウパツク CB45 1 13 #05 400-03623 RESISTANCE PACK CB 40U テイコウパツク CB40U 1 14 #05 400-03624 RESISTANCE PACK CB 45U テイコウパツク CB45U 1 15 #07 M6100-350-CAA RESISTANCE PACK CA ASM. テイコウパツク CAクミ 1 16 #08 M6095-350-CAF RESISTANCE PACK CF ASM. テイコウパツク CFクミ 1 17 #09 M6099-350-CAF RESISTANCE PACK CF ASM. テイコウパツク CFクミ 1 18 #10 M6099-350-CAF RESISTANCE PACK CF ASM. テイコウパツク CFクミ 1 19 #11 M6099-350-CAL RESISTANCE PACK CL ASM. テイコウパツク CLクミ 1 20 #11 M6098-350-CAF RESISTANCE PACK CF ASM. テイコウパツク CFクミ 1 21 #11 M6098-350-CAA RESISTANCE PACK CA ASM. テイコウパツク CAクミ 1 22 #12 400-17100 RESISTANCE PACK WB40 テイコウパツク WB40 1 23 #01 400-17101 RESISTANCE PACK CB40 テイコウパツク CB40 1 24 #01 400-17102 RESISTANCE PACK CB45 テイコウパツク CB45 1 25 #01 400-00004 PULLEY COVER プーリーカバー 1 26 236-00604 BOLT ボルト 4 27 SL-6052592-TN AIR-DISCHARGING CAP エアーヌキツツキヤツプ 1 28 236-01305 AIR-DISCHARGING エアーヌキ 1 29 236-29900 AIR-DISCHARGING エアーヌキ 1 30 100-01709 TAKE-UP THREAD CUTTER テンビンメス 1 31 TA-1250705-RO RUBBER PLUG トメセン 1 32 137-47308 SUSPENSION SCREW メス クドウ フツクバネ カケ 1 33 229-20409 THREAD RELEASE PIN SPRING イトユルヌメピンバネ 1 34 SS-8110750-SP SCREW 11/64-40 L=6.5 トメネジ 11/64-40 L=6.5 1 35 CM-30002000-01 ATTENTION SEAL キユウイシール (16) 2 36 GPR-01015000 RUBBER RING ○リング 1 37 RO-0801502-00 RUBBER RING ○リング 1 38 RO-1331701-00 SPRING PIN 8X20 スプリングピン 8X20 1 39 PS-0800202-KH HINGE SCREW D=6.35 H=7.5 ダンネジ D=6.35 H=7.5 1 40 SD-0640751-SP CABLE BAND ソクセンバンド 1 41 EA-9500B01-00 SCREW 11/64-40 L=7 皿ネジ 11/64-40 L=7 7 42 SS-1110710-SP SCREW 9/64-40 L=7.2 マルサラネジ 9/64-40 L=7.2 1 43 SS-2090710-TP SCREW 11/64-40 L=9 マルサラネジ 11/64-40 L=9 2 44 SS-410915-SP BALANCE COVER BASE テンビンカバーダイ 1 45 263-05102 BALANCE THREAD GUIDE B テンビンイトアンナイ B 1 46 263-05409 BALANCE COVER テンビンカバー 1 47 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 1 48 SS-4120915-SP SCREW 3/16-28 L=9 ナベネジ 3/16-28 L=9 4 49 SS-4121015-SP SCREW 3/16-28 L=10 ナベネジ 3/16-28 L=10 4 50 SS-4150915-SP SCREW 15/64-28 L=9 ナベネジ 15/64-28 L=9 4 51 225-02108 BALANCE COVER テンビンカバー 1 52 225-27401 FACE PLATE PACKING メンイタパツキン 1 53 TA-7080410-SP SCREW 1/8-44 L=3.8 マルヒラネジ 1/8-44 L=3.8 1 54 263-05300 BALANCE COVER STOPPER SPRING テンビンカバー ストツパーバネ 1 55 400-03588 HEAD SUPPORT A POKING ヘッドササエ A パツキン 1 56 TA-0800504-RO PLUG D=8 L=4.5 トメセン D=8 X4.5 1 57 TA-1250406-RO RUBBER PLUG D=12.5 L=4 トメセン D=12.5 L=4 1 58 WP-0501016-SD WASHER 5X10.5X1 ヒラサガネ 5X10.5X1 3 59 WP-0651056-SD WASHER 6.5X11X1 ヒラサガネ 6.5 X 11 X 1 1 60 D2112-555-B00 CORD HOLDER LARGE コード ホルダー ラージ 2 61 WZ-0641510-KP WAVED WASHER 6.4X11X0.3 ナミガタサガネ 6.4X11X0.3 1 62 400-22407 CORD HOLDER コード オサエ 1 63 WP-0330500-0E WASHER 3.3X6X0.5 ヒラサガネ 3.3X6X0.5 2 64 #06 225-29000 SUPPORT BALANCE ホジヨンプイン 1 65 #06 225-29101 SUPPORT BALANCE BASE ホジヨンプイン トリツケダイ 1 66 #06 225-29200 MOUNTING BASE ホジヨンプイン 1 67 SS-6090540-SP SCREW 11/64-40 L=9 ナベネジ 11/64-40 L=9 1 68 SS-6580752-TP SCREW 9/64-40 L=5.0 ヒラネジ 9/64-40 L=5.0 1 69 400-03633 THREAD TENSION ASM. B イトチョウシ (クミ) B (1) 70 400-03634 THREAD TENSION ASM. A イトチョウシ (クミ) A (1) 71 SS-8090670-SP SCREW 1/8-40 L=7 ロツカクアナボルト 1/8-40 L=7 (1) 72 235-38309 THREAD TAKE-UP SPRING イトリトリバネ (1) 73 235-47557 FELT イトチョウシサラフエルト (4) 74 225-28509 ROTATION STOPPER イトチョウシカイテンドメ (1) 75 229-21407 THREAD TENSION ROD BASE ASM. イトチョウシボウダイ (クミ) (1) 76 235-37665 THREAD TENSION ROD COMPL. イトチョウシボウケツゴウ (1) 77 235-37756 THREAD RELEASE PIN イトユルヌメピン (1) 78 235-37814 THREAD TENSION NUT イトチョウシナット (1) 79 B3121-352-000 TENSION SPRING ウワールーパイトーシバネ (1) 80 B3129-012-A00 TENSION SPRING イトチョーシバネ A (1) 81 NOTE(注記) #01...FOR LZ-2290A-SR-7-CB LZ-2290A-SR-7-CB用 82 VARIOUS NOS. FOR DESTINATIONS 仕向地により異なる 83 #02...FOR LZ-2290A-SU-OB, LZ-2290A-SU-OB用 84 LZ-2290A-SU-7-WB 仕向地により異なる 85 VARIOUS NOS. FOR DESTINATIONS LZ-2290A-SS-7-CB用 86 #03...FOR LZ-2290A-SS-7-CB 仕向地により異なる 87 VARIOUS NOS. FOR DESTINATIONS LZ-2290A-DS-7-CB用 88 #04...FOR LZ-2290A-DS-7-CB, 仕向地により異なる 89 LZ-2290A-DS-OB, LZ-2290A-DS-OB用 90 LZ-2290A-DU- 仕向地により異なる 91 VARIOUS NOS. FOR DESTINATIONS LZ-2290A-DU-7-WB用 92 #05...FOR LZ-2290A-DU-7-WB, 仕向地により異なる 93 LZ-2290A-DU-7-CB LZ-2290A-SS用 94 VARIOUS NOS. FOR DESTINATIONS 仕向地により異なる 95 #06...FOR LZ-2290A-SS, LZ-2290A-SS-OB用 96 LZ-2290A-SS-OB 仕向地により異なる 97 VARIOUS NOS. FOR DESTINATIONS LZ-2290A-SU用 98 #07...FOR LZ-2290A-SU, LZ-2290A-SU-OB用 99 LZ-2290A-SU-OB 仕向地により異なる 100 VARIOUS NOS. FOR DESTINATIONS LZ-2290A-SR-7-WB用 101 #08...FOR LZ-2290A-SR-7-WB 仕向地により異なる 102 VARIOUS NOS. FOR DESTINATIONS - 2 - jintex.in

Page 8 — 2. FRAME & MISCELLANEOUS COVER COMPONENTS (2)

2. FRAME & MISCELLANEOUS COVER COMPONENTS (2) 頭部・外装関係 (2) 39 48 47 28 38 43 31 37 30 33 44 41 49 36 35 32 46 50 34 42 59 90 89 88 87 18 17 10 9 7 12 11 13 27 24 76 77 58 57 56 52 53 55 54 4 2 1 14 21 22 5 20 23 63 62 60 75 19 6 8 15 25 26 85 97 61 64 65 69 66 67 68 73 70 71 72 74 3 79 80 81 82 86 51 3- jintex.in

Page 9

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 400-11345 GEAR BOX (LARGE) COVER ギヤボックス (ダイ) フタ 1 2 235-26601 GEAR BOX (LARGE) PACKING ギヤボックス (ダイ) パッキン 1 3 400-28463 GEAR BOX (SMALL) COVER ギヤボックス (ショウ) フタ 1 4 235-26809 GEAR BOX (SMALL) PACKING ギヤボックス (ショウ) パッキン 1 5 235-27203 PIPE GUIDE PLATE パイプガイドイタ 1 6 M8524-476-AA0 GROUND WIRE A ASM. アースコードAクミ 1 7 225-83407 NEEDLE PLATE ハリイタ 1 8 229-01805 GROUND MARK グランドマーク 1 9 263-00103 SEMILUNAR PLATE ハンゲツパン 1 10 263-14757 BED SLIDE ASM. スベリイタ (クミ) 1 11 110-01609 BED SLIDE SPRING スベリイタ バネ 1 12 SS-6060210-SP SCREW 3/32-56 L=1.9 ヒラネジ 3/32-56 L=1.9 (1) 13 CM-3002000-01 ATTENTION SEAL コビケカクウイシール (16) 1 14 262-30409 LUBRICATING OIL WICK STOPPER キュウユユコシントメ 1 15 CM-3013000-01 SAFETY LABEL トウブチュウイアンゼンシール (ヨコ) 1 16 CM-3013000-01 SAFETY LABEL トウブチュウイアンゼンシール (ヨコ) 1 17 SS-2090810-SP SCREW 9/64-40 L=7.5 マルサラネジ 9/40 L=7.5 2 18 SS-2090810-SP SCREW 9/64-40 L=7.5 マルサラネジ 9/40 L=7.5 1 19 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 1 20 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 1 21 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 4 22 SS-4120915-SP SCREW 3/16-28 L=9 ナベネジ 3/16-28 L=9 12 23 SS-4120915-SP SCREW 3/16-28 L=9 ナベネジ 3/16-28 L=9 1 24 400-28294 FEED_ADJUSTING_CAP 送り調節体キャップ 1 25 260-25106 SPACER スペーサー 1 26 SL-4051091-SC SCREW M5X0.8 L=10 ナベネジ セムス M5X0.8 L=10 1 27 225-03908 SPACER スペーサー 1 28 400-26835 BOBBIN WINDER UNIT イトマキウチクミ 1 29 262-60109 BTW_BASE イトマキベ-ス 1 30 262-60208 BTW_CAM_PLATE イトマキチョウセツイタ 1 31 262-60307 BTW_BASE_SHAFT イトマキベ-スジク 1 32 262-60406 BTW_SHAFT_BASE イトマキジクベ-ス 1 33 262-60505 BTW_CAM_LEVER イトマキカムレバ- 1 34 262-60604 BTW_WHEEL イトマキグルマ 1 35 400-11144 BTW_TORSION_SPRING イトマキネジリバネ 1 36 262-60802 BTW_BEARING_SPACER ベアリングスペーサー 1 37 400-14837 BTW_SHAFT イトマキジク 1 38 262-61008 BTW_LEVER_SHAFT イトマキレバ-ジク 1 39 400-21933 BTW_LEVER イトマキレバ- 1 40 262-61206 BTW_SPACER ボビンザ 1 41 262-61305 BTW_BEARING イトマキジクベアリング 1 42 262-61503 BTW_WHEEL_RUBBER イトマキサツグルマ 1 43 262-61602 BOBBIN_SPRING ボビントメバネ 1 44 262-61701 BTW_SPRING イトマキチョウセツイタモドシバネ 1 45 RC-0560711-KP RETAINING RING Cガタトメワ 1 46 RE-0400000-KO E-RING 4 Eガタトメワ 4 1 47 WP-0450826-SC WASHER 4.5X10X0.8 ヒラザガネ 4.5X10X0.8 (1) 48 SM-5040655-SN SCREW ヒラザガネ 4.5X10X0.8 (3) 49 SM-8050502-TP SCREW M5 L=5 トメネジ 1 50 SM-8040802-TP SCREW M4X8 トメネジ M4X0.7 L=8 (2) 51 SS-7090410-SP SCREW 9/64-40 L=3.5 マルサラネジ 9/64-40 L=3.5 1 52 SM-4040655-SP SCREW M4 L=6 なべ小ねじ M4 L=6 1 53 110-33008 MAGNET マグネット 1 54 400-24644 MAGNET WASHER マグネットオサエガネ 1 55 ST-4040821-SS TAPPING SCREW タツピンネジ 1 56 400-37008 THREAD_CUTTER 糸切り保持板 1 57 SM-0051001-SC SCREW トラスねじ M5 L=10 2 58 SM-0051001-SC SCREW M5 L=10 トラスねじ M5 L=10 3 59 SS-8111251-SP SCREW 11/64-40 L=12.0 トメネジ 11/64-40 L=12 1 60 EA-9500B02-00 CABLE BAND 150 ケツソウバンド 150 2 61 236-29108 OIL SIGHT WINDOW コリヨウシジマド 1 62 235-39901 HEAD LUBRICATION PPE STOPPER トウブキュウユシトメ 1 63 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 1 64 235-41352 SAFETY SWITCH ASM. アンゼンスイッチクミ 1 65 235-41303 SAFETY SWITCH BASE アンゼンスイッチベ-ス 1 66 236-38109 SAFETY SWITCH ARM. アンゼンスイッチアーム 1 67 236-38208 SAFETY SWITCH SPRING アンゼンスイッチスプリング 1 68 236-38307 SAFETY SWITCH ARM SHAFT アンゼンスイッチウデジク 1 69 236-38406 SAFETY SWITCH STOPPER PLATE アンゼンスイッチトメワ 1 70 235-41451 SAFETY SWITCH CORD ASM. アンゼンスイッチコードクミ 1 71 HK-0346100-60 HOUSING 6P ハウジング 6P 1 72 EA-9500B01-00 CABLE BAND ソクセンバンド 1 73 SM-4021201-SC SCREW M2 L=12 ナベコネジ M2 L=12 (2) 74 SS-4120915-SP SCREW 3/16-28 L=9 ナベネジ 3/16-28 L=9 2 75 CM-3002000-03 ATTENTION LABEL 指怪我注意シール (31.5) 1 76 229-58300 NEEDLE THREAD GUIDE PIN イトアンナイボウ 1 77 225-02504 THREAD GUIDE BAR イトトリバネ ガード 1 78 225-02702 SPRING GUARD PMリケイブルAクミ 1 79 400-06012 PM RELAY CABLE A ASM. PMリケイブルBクミ 1 80 400-06013 PM RELAY CABLE B ASM. テンピンイトアンナイ 1 81 263-12504 BALANCE THREAD GUIDE テンピンイトアンナイA 1 82 225-04104 BALANCE THREAD GUIDE A 定規板 1 83 400-35589 RULER PLATE ストツパーゴム 1 84 110-43601 RUBBER STOPPER GOST安全ラベルS 1 85 401-16677 GOST_SAFETY_LABEL_S サラネジ T11/64-40 L=8 2 86 SS-1110840-SP SCREW 11/64-40 L=8 イトマキドウクルクミ 1 87 400-26836 BOBBIN WINDER DRIVING WHEEL ASM. イトマキドウシヤクミ 1 88 400-20454 BTW DRIVING WHEEL ASM. イトマキドウシヤハネ 1 89 235-28607 BOBBIN DRIVING BLADE (3) 90 SM-4030501-SN SCREW M3 L=5 ナベコネジ M3X0.5 L=5 (1) 91 225-29481 BOBBIN THREAD TENSION ASM. イトマキイトチョウシクミ 1 92 225-29473 BOBBIN THREAD TENSION ROD ASM. イトマキイトチョウシロツドクミ 1 93 B3214-047-000 BOBBIN WINDER TENSION DISC イトマキチョウシサラ 1 94 110-93606 THREAD TENSION SPRING ダイ 1イトチョウシバネ 1 95 110-72402 THREAD TENSION NUT ロツカクナット 1 96 NS-6110310-SP NUT 11/64-40 1 97 CM-6001001-01 WEEE MARK LABEL S WEEE マーク ラベル S 1 NOTE(注記) #01...FOR LZ-2290A-SS,LZ-2290A-SU, LZ-2290A-SS,LZ-2290A-SU用 #02...FOR LZ-2290A-SS,LZ-2290A-SU-7, LZ-2290A-SU-7用 #03...FOR LZ-2290A-SU-7, LZ-2290A-SU-7用 #04...VARIOUS NOS.FOR DESTINATIONS 仕地により異なる #05...FOR LZ-2290A-SS,LZ-2290A-SU-7, LZ-2290A-SU-7, LZ-2290A-DS-7,LZ-2290A-DU-7, LZ-2290A-DS-7,LZ-2290A-DU-7用 #06...FOR LZ-2290A-SS,LZ-2290A-SS-OB, LZ-2290A-SS,LZ-2290A-SS-OB, LZ-2290A-SU,LZ-2290A-DS-OB, LZ-2290A-SU,LZ-2290A-DS-OB, LZ-2290A-DS,LZ-2290A-DU-OB, LZ-2290A-DS,LZ-2290A-DU-OB用 - 4 - jintex.in

Page 10 — 3. MAIN SHAFT & THREAD TAKE-UP & NEEDLE BAR COMPONENTS

3. MAIN SHAFT & THREAD TAKE-UP & NEEDLE BAR COMPONENTS 上軸・天秤・針棒関係 1 2 3 4 25 16 26 33 34 35 32 30 37 36 50 31 29 31 15 31 22 14 31 21 17 13 12 8 11 9 6 7 10 13 23 19 24 18 40 59 60 46 65 69 67 68 46 60 5 51 56 57 53 55 62 64 58 54 52 61 63 70 20 - 5 - jintex.in

Page 11

REF.NO NOTE PART NO DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 235-27906 400-10324 401-60261 235-28102 235-28250 235-28359 235-28458 236-05009 236-04804 235-28201 SL-4040881-SC SL-4040881-SC SM-8060812-TP SB-1200013-CO 236-04200 225-06208 225-05705 M6801-471-0A0 EA-9500B01-00 SB-1200008-CO 236-05207 SL-4040881-SC SL-6052592-TN 100-08753 SS-1090930-SP 400-15494 SM-8060812-TP SS-7681650-TP SS-8680730-SP SM-8060812-TP SS-8660610-TP 235-28755 235-28706 SB-1080019-00 400-10281 225-08006 #01 225-07701 #01 225-07404 SL-6052092-TN 400-70532 400-56873 SS-7090910-TP MC-2005F07-00 #01 MDP-500B1000 #01 235-44901 SS-7080520-SP SS-7060310-SP #01 SS-4110915-SP SS-4110915-SP 235-29159 235-29100 235-29209 235-29308 235-29506 235-29407 PS-0400222-KO SS-8120740-SP 400-10315 235-31114 400-10297 400-10296 RO-0371801-00 SS-8151230-SP SM-8061212-TP 400-03618 400-10322 WP-0720516-SD NM-6060001-SC CQ-2020000-00 NOTE(注記) UPPER SHAFT COUNTER WEIGHT UPPER_SHAFT_SPROCKET NEEDLE ROD CRANK HAND WHEEL ASM MAGNET FITTING BASE COMPL. U MAGNET FITTING BASE COMPL. D HAND WHEEL WASHER BALANCE PLATE HAND WHEEL SL-4040881-SC SCREW M4 L=8 SCREW M6 L=8 BEARING MAIN SHAFT BEARING SUPPORT BALANCE V TIMING BELT AC SERVO MOTOR SYNC ASM. CABLE BAND BEARING BEARING HOLDER SCREW M4 L=8 BOLT TAKE-UP COUNTERWEIGHT ASM. SCREW 9/64-40 L=8.6 NEEDLE BAR SCREW M6 L=8 SCREW 9/32-28 L=16 SCREW 9/32-28 L=7 SCREW M6 L=8 SCREW 1/4-40 L=6 NEEDLE ROD CRANK ASM. NEEDLE ROD CRANK ROD BEARING NEEDLE ROD CRANK ROD GUIDE NEEDLE BAR CONNECTION GUIDE THRED RACK RIGHT THREAD RACK SCREW NEEDLE_BAR_CONNECTION_ASM. NEEDLE BAR CONNECTION SCREW 9/64-40 L=8.5 NEEDLE 134SUK 70 NEEDLE DPX5 #10 THRUST BUSH SCREW 1/8-44 L=4.9 SCREW 3/32-56 L=3 SCREW 11/64-40 L=9 SCREW 11/64-40 L=9 NEEDLE ROD SUPPORT BASE ASM. NEEDLE ROD SUPPORT BASE NEEDLE ROD SUPPORT BASE SHAFT SUPPORT BASE GUIDE SHAFT NEEDLE ROD METAL NEEDLE ROD SUPPORT BASE FELT SPRING PIN SCREW 3/16-28 L=7 SUPPORT BASE SHAFT FRONT METAL SUPPORT BASE SHAFT REAR METAL SUPPORT BASE GUIDE PIN A SUPPORT BASE GUIDE PIN B RUBBER RING SCREW 15/64-28 L=12 SCREW M6X12 METAL B SPRING PLAIN WASHER NUT M6 OIL WICK #01...VARIOUS NOS.FOR DESTINATIONS Qty 1 1 1 1 1 (1) (1) (2) (1) (1) (2) (2) (2) 1 1 1 1 1 1 1 1 2 3 1 3 2 1 1 4 2 (1) (1) 1 1 1 1 1 1 (1) (1) (1) (1) (1) (2) 1 1 1 1 1 1 1 1 0.15 - 6 - jintex.in

Page 12 — 4. NEEDLE VIBRATOR COMPONENTS

4. NEEDLE VIBRATOR COMPONENTS 針振り関係 34 32 18 9 1 2 17 25 28 22 15 23 19 24 11~13 20 16 21 10 14 30 26 31 35 33 - 7 - jintex.in

Page 13

REF.NO NOTE PART NO DESCRIPTION 品名 Qty 1 401-49235 NEEDLE_VIBRATOR_UNIT 針振りユニット 1 2 401-49234 NEEDLE_VIBRATOR_UNIT_BASIS 針振りユニット土台 (1) 3 400-10278 MOTOR LINK モータリンク (1) 4 #01 400-10286 JUNCTION SHAFT A ハリフリレンケツジク A (1) 5 #01 400-10287 JUNCTION SHAFT B ハリフリレンケツジク B (1) 6 400-10288 JUNCTION SHAFT C ハリフリレンケツジク C (1) 7 #01 400-10289 JUNCTION SHAFT D ハリフリレンケツジク D (1) 8 400-08169 SHAFT CONNECTION LINK ハリボウシジダイジクダキリンク (1) 9 EA-9500B01-00 CABLE BAND ソクセンバンド (2) 10 WP-0520656-SA WASHER 5.2X9.5X0.6 ヒラサガネ 5.2×9.5×0.6 (1) 11 #01 400-08119 JUNCTION SHAFT A ハリボウシジダイジクダキピン A (1) 12 #01 400-08120 JUNCTION SHAFT B ハリボウシジダイジクダキピン B (1) 13 #01 400-08121 JUNCTION SHAFT C ハリボウシジダイジクダキピン C (1) 14 400-08118 SUPPORT BASE SHAFT CONNECTION ハリボウシジダイジクダキ (1) 15 235-30702 SENSOR FITTING PLATE センサー フイッテイングプレート (1) 16 235-30801 SENSOR SLIT センサー スリット (1) 17 235-31007 CORD CLAMP コードクランプ (1) 18 KM-0000003-50 PULSE MOTOR パルスモータ (1) 19 M8523-476-AA0 ZERO SENSOR A ASM. ゲンテンセンサ-Aクミ (1) 20 SS-4110615-SP SCREW 11/64-40 L=6 なべ小ねじ 11/64-40 L=6 (1) 21 SS-7121410-TP SCREW 3/16-28 L=14 マルヒラネジ 3/16-28 L=14 (1) 22 SM-4030655-SP SCREW ナベコネジ M3 L=6 (2) 23 SM-4051255-SP SCREW M5 L=12 ナベネジ M5 L=12 (1) 24 SM-4860801-SN SCREW M4 L=10 ナベネジ (1) 25 SM-6041002-TP SCREW M4X0.7 L=10 ロツカクアナボルト M4X0.7 L=10 (3) 26 SS-7110740-TP SCREW 11/64-40 L=7 丸平ねじ 11/64-40 L=7 (2) 27 SM-8050612-TP SCREW M5X6 トメネジ M5X6 (1) 28 WP-0482016-SZ WASHER ヒラサガネ (2) 29 NM-6040001-SN NUT M4X0.7 6カクナット M4 (1) 30 SS-8090670-SP SCREW 9/64-40 L=5.5 トメネジ 9/64-40 L=5.5 (1) 31 400-10298 JUNCTION SHAFT COLLAR ハリボウシジダイジクダキカラー (1) 32 SM-6041402-TP SCREW M4 L=14 ロツカクアナボルト M4 (1) 33 401-49236 NEEDLE_VIBRATOR_UNIT_COVER 針振りユニットカバー 1 34 SM-6061002-TP SCREW M6 L=10 六角穴ボルト M6 L=10 3 35 SS-4121215-SP SCREW 3/16-28 L=12 ナベネジ 3/16-28 L=12 4 NOTE(注記) #01...SELECTIVE PARTS 選択部品 - 8 - jintex.in

Page 14 — 5. HAND LIFTER COMPONENTS

5. HAND LIFTER COMPONENTS 押え上げ関係 5 10 20 38 43 6 17 19 16 37 11 12 13 14 15 42 23 41 9 8 32 40 39 22 27 21 24 31 36 7 35 34 1 2 3 33 25 30 28 26 29 4 - 9 - jintex.in

Page 15

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 235-31304 KNEE LIFTING SIDE ROD LINK ヒザアゲヨコボウリンク 1 2 235-31403 KNEE LIFTING LINK ヒザアゲリンク 1 3 235-31502 KNEE LIFTING LINK SPRING ヒザアゲリンクバネ 1 4 400-03601 KNEE LIFTING JUNCTION ROD ヒザアゲレンケツボウ 1 5 236-09209 PRESSER SPRING REGULATOR オサエチョウセツネジ 1 6 236-09001 BUSHING バウメタル 1 7 263-08007 LIFTING PLATE ヒキアゲイタ 1 8 263-07850 PRESSER LIFTER CAM COMPL. オサエアゲカム (ケツゴウ) 1 9 229-07802 HAND LIFTER オサエアゲレバー 1 10 229-07604 PRESSER SPRING REGULATOR NUT オサエチョウセツネジナット 1 11 #01 100-55051 PRESSER FOOT ASM. オサエ A 1 12 #02 225-80864 PRESSER FOOT ASM. オサエ (クミ) 1 13 #03 225-80864 PRESSER ASM. オサエ (クミ) 1 14 #04 235-03154 PRESSER ASM. オサエ (クミ) 1 15 #04 235-03162 PRESSER ASM. オサエ (クミ) 1 16 401-25469 PRESSER_BAR オサエ棒 1 17 400-70531 PRESSER_BAR_CONNECTION_ASM. オサエボウダキクミ 1 18 263-02901 PRESSER BAR HOLDER オサエボウダキ (1) 19 SS-7111110-TP SCREW 11/64-40 L=10.5 マルヒラネジ 11/64-40 L=10 (1) 20 229-07703 PRESSER GUIDE BAR オサエアンナイボウ 1 21 B1516-552-000 LIFTING LEVER LINK ヒキアゲリンク 1 22 B1517-552-000 HINGE PIN ヒンジピン 1 23 B1521-555-000 SCREW オサエアゲレバー トメネジ 1 24 B1523-226-000 SNAP RING トメワ B 1 25 B3416-552-000 CONNECTING ROD HINGE SCREW ヒザアゲ ヨコボー ダンネジ 1 26 B3416-555-000 SWIVEL ツリボーダルマ 1 27 B3431-581-000 LIFTING LEVER GASKET パッキン 1 28 BAK-33041000 KNEE LIFTING LINK STEP-SCREW ヒザアゲリンク ダンネジ 1 29 NS-6620310-SP NUT 3/16-32 ロツカクナット 3/16-32 1 30 RE-0500000-K0 E-RING Eトメワ 5 1 31 RE-0600000-K0 E-RING 6 Eガタトメワ 6 1 32 RO-0371801-00 RUBBER RING Oリング 1 33 SD-0600341-TP HINGE SCREW D=6.0 H=3.4 ダンネジ 1 34 SD-0630275-SP HINGE SCREW D=6.35 H=2.7 ダンネジ D=6.35 H=2.7 1 35 SD-0630301-SP HINGE SCREW D=6.35 H=3 ダンネジ D=6.35 H=3 1 36 SD-0630371-SP HINGE SCREW ダンネジ 1 37 SS-7090910-TP SCREW 9/64-40 L=8.5 マルヒラネジ 9/64-40 L=8.5 1 38 #05 B1505-227-T00-A PRESSER SPRING T オサエ チョーセツバネ 1 39 SS-8150510-TP SCREW 15/64-28 L=4.7 トメネジ 15/64-28 L=4.7 1 40 SS-8152030-SP SCREW 15/64-28 L=20 止めねじ 15/64-28 L=20 1 41 WP-0740516-SP WASHER 7.4X11.8X0.5 ヒラガネ 7.4X11.8X0.5 1 42 #06 225-80369 PRESSER FOOT ASM. オサエ (クミ) 1 43 #05 229-07406 PRESSER SPRING オサエチョウセツバネ 1 NOTE(注記) #01...FOR LZ-2290A-SS, LZ-2290A-SS, -7-0 B用 VARIOUS NOS.FOR DESTINATIONS 仕地により異なる #02...FOR LZ-2290A-SS, LZ-2290A-SS VARIOUS NOS.FOR DESTINATIONS 仕地により異なる #03...FOR LZ-2290A-SS-7-OB LZ-2290A-SS-7-0 B用 VARIOUS NOS.FOR DESTINATIONS 仕地により異なる #04...FOR LZ-2290A-SU, LZ-2290A-SU, VARIOUS NOS.FOR DESTINATIONS 仕地により異なる LZ-2290A-SU-7用 #05...FOR LZ-2290A-SS-7-OB LZ-2290A-SS-7-0 B用 VARIOUS NOS.FOR DESTINATIONS 仕地により異なる #06...FOR LZ-2290A-SR-7 LZ-2290A-SR-7用 - 10 - jintex.in

Page 16 — 6. FEED MECHANISM COMPONENTS (1)

6. FEED MECHANISM COMPONENTS (1) 送り関係 (1) 65 2 25 23-67-72 53 46 39 26 49 40-68 33 47 35 34 37 36 55 66 20 21 50 73 41-45 32 49 54 9 30 29 17 31 16 18 69 22 70 64 8 11 30 63 12 28 27 62 13 71 15 14 19 48 61 38 6 10 58 52 51 7 61 38 5-56 1 3 4 57 57 - 11 - jintex.in

Page 17

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 #05 235-32500 FEED ADJUSTING SPRING オクリヨウセツタイバネ 1 2 #01 400-10311 FEED HORIZONTAL SHAFT スイエイオクリジク 1 3 #05 235-32906 REGULATE PLATE セイオリヨウキセイバン 1 4 235-33003 REGULATE PLATE ギヤオクリヨウキセイバン 1 5 235-32609 FEED SPRING RACK オクリバネカケ 1 6 #05 235-32807 FEED REVERSAL LINK オクリヘンカンリンク 1 7 400-10318 FEED ADJUSTING A オクリヨウセツタイ A 1 8 401-49246 HORIZONTAL FEED CAM 水平送りカム 1 9 235-32401 HORIZONTAL FEED CAM COVER スイエイオクリカムフタ 1 10 235-32203 FEED ADJUSTING PRESSER オクリヨウセツタイサエ 1 11 #05 400-10313 FEED CHANGE ARM オクリヘンカンウデ 1 12 #05 400-10268 FEED CHANGE ARM A クミ (1) 13 400-10269 FEED CHANGE ARM A オクリヘンカンデ A (1) 14 229-10509 FEED ADJUSTING LINK PIN ヨウセツリンクピン (1) 15 SS-7121410-TP SCREW 3/16-28 L=14 マルヒラネジ 3/16-28 L=14 (1) 16 #05 400-10270 FEED CHANGE ARM B ASM. オクリヘンカンウデ B クミ 1 17 400-10271 FEED CHANGE ARM B オクリヘンカンウデ B (1) 18 SS-8660612-TP SCREW 1/4-40 L=6 トメネジ 1/4-40 L=6 (1) 19 #05 235-32708 FEED ADJUSTING ARM オクリヨウセツタイウデ 1 20 #01 401-49244 FEED BASE ASM. 送り台 (組) 1 21 401-49245 FEED BASE 送り台 1 22 SS-7091110-TP SCREW 9/64-40 L=10.5 丸平ねじ 9/64-40 L=10.5 (1) 23 #01 400-10276 FEED DOG オクリレンケツカン 1 24 SS-7091110-TP FEED DOG メワ 13.8 1 25 #02 RC-0150001-KP RETAINING RING 13.8 Cガタトメワ 1 26 401-39216 OIL SEAL オイルシール 1 27 #05 236-12609 FEED CHANGING SHAFT OIL SEAL ヘンカンジクオイルシール 1 28 #05 236-12807 METAL A オクリヘンカンジクメタル A 1 29 #05 236-12906 METAL B オクリヘンカンジクメタル B 1 30 #05 236-13102 FEED CHANGING SHAFT ARM B PIN オクリヘンカンウデBピン 2 31 #05 NS-6150310-SP NUT 15/64-28 ナツト 15/64-28 2 32 263-00509 FEED ROD オクリロツド 1 33 236-16709 FEED ROCKER SHAFT オクリジクメタル 1 34 #01 401-25485 FEED BASE ASM. 送り台 (組) 1 35 #01 229-40654 FEED ROCKER ASM. 送り台 1 36 SS-7121410-TP SCREW 3/16-28 L=14 マルヒラネジ 3/16-28 L=14 (1) 37 WP-0480856-SD WASHER 4.8X8.4X0.8 平座金 4.8 8.4 0.8 (1) 38 100-27308 PLATE A オクリチョーセツタイ A 2 39 400-50457 FEED DRIVING ROCKER BLOCK オクリチョウセツタイカクコマ 1 40 #01 B1608-555-0A0 FEED ROCKER SHAFT CRANK ASM. スイエイオクリウデクミ 1 41 #03 SB-3220002-CA BEARING ころがり軸受 2 42 #03 SB-3220002-CB BEARING ころがり軸受 1 43 #03 SB-3220002-CC BEARING ころがり軸受 1 44 #03 SB-3220002-CD BEARING ころがり軸受 1 45 #03 SB-3220002-CE BEARING ころがり軸受 1 46 B1653-470-000 PIN カクゴマピン 1 47 CS-1470710-SH THRUST COLLAR ASM. D=14.72 W=7 スラストウデ D=14.72 W=7 クミ 2 48 #05 NS-6120310-SP NUT 9/32-28 ロツカクナット 9/32-28 1 49 NS-6680410-SP E-RING 3 Eガタトメワ 3 2 50 RE-0300000-KO E-RING Eガタトメワ 5 1 51 #05 RE-0500000-KO HINGE SCREW D=6 H=3.2 ダンネジ D=6 H=3.2 1 52 #05 SD-0600321-SP HINGE SCREW D=9 N=7 ダンネジ D=9 N=7 2 53 SD-0900701-TP SCREW 1/8-44 L=6 ナベネジ 1/8-44 L=6 2 54 SS-4080620-TP SCREW 11/64-40 L=7 ナベネジ 11/64-40 L=7 1 55 #01 SS-7110740-TP SCREW 15/64-28 L=9 ナベネジ 15/64-28 L=9 1 56 #05 SS-4150915-SP SCREW 15/64-28 L=9 ナベネジ 15/64-28 L=9 2 57 #05 SS-4150915-SP SCREW 11/64-40 L=6 なべ小ねじ 11/64-40 L=6 1 58 SS-4110615-SP SCREW 1/8-40 L=7 アナボルト 1/8-40 L=7 2 59 SS-6580752-TP SCREW 11/64-40 L=8.5 マルヒラネジ 11/64-40 L=8.5 2 60 #05 SS-7110910-TP SCREW 11/64-40 L=9 なべ小ねじ 11/64-40 L=9 4 61 SS-4110915-SP THRUST COLLAR スラスト受 D=10 W=8 1 62 CS-1000881-TP SCREW M5 L=6 六角穴付き止めねじ M5 L=6 2 63 #05 SM-80506A2-TP SCREW 1/4-40 L=8 トメネジ 1/4-40 L=8 2 64 SS-8660810-TP HORIZONTAL FEED SHAFT U スイエイオクリジク U 1 65 400-10312 HORIZONTAL FEED SHAFT METAL B スイエイオクリジクメタル B 1 66 #02 235-45304 HORIZONTAL FEED JUNCTION ROD スイエイオクリレンケツカン 1 67 #02 263-03206 FEED ROCKER SHAFT CRANK スイエイオクリウデ 1 68 #02 100-27100 VERTICAL FEED LINK リンク軸 1 69 263-03107 VERTICAL FEED LINK リンク 1 70 401-25483 FEED ADJUSTING OIL SEAL ジヨウセツタイオイルシール 1 71 235-32005 CONNECTING ROD レンケツカン 1 72 #04 400-11850 FEED DOG オクリ 1 73 #04 400-18430 NOTE(注記) #01...FOR LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SR-7用 LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SR-7用 #02...FOR LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SR-7用 LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SR-7用 #03...SELECTIVE PARTS 選択部品 #04...FOR LZ-2290A-SR-7, LZ-2290A-SU, LZ-2290A-SS, LZ-2290A-SR-7用 LZ-2290A-SR-7, LZ-2290A-SU, LZ-2290A-SS, LZ-2290A-SR-7用 #05...FOR LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SR-7用 LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SR-7用 - 12 - jintex.in

Page 18 — 7. FEED MECHANISM COMPONENTS (2)(EXCEPT LZ-2290A-SR-7)

7. FEED MECHANISM COMPONENTS (2)(EXCEPT LZ-2290A-SR-7) 送り関係 (2) (LZ-2290A-SR-7 を除く) 13 jintex.in

Page 19

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 235-33706 FEED ADJUSTING SHAFT METAL オクリチョウセツジク メタル 1 2 235-33805 FEED ADJUSTING SHAFT オクリチョウセツジク 1 3 235-33409 FEED ADJUSTING ROD オクリチョウセツロッド 1 4 235-33904 FEED ADJUSTING SCREW オクリチョウセツネジ 2 5 400-10272 FEED BLIND CONTROLLER オクリチョウセツキ 1 6 235-34019 FEED ADJUSTING BASE オクリチョウセツダイ 2 7 PS-0300122-KH SPRING PIN 3X12 スプリングピン 3X12 2 8 #01 235-34407 CONDENS DIAL コンデン スダイヤル 1 9 235-34308 CONDENS ADJUSTING SHAFT コンデン スチョウセツジク 1 10 235-34258 CONDENS STOPPER ASM. コンデン スストッパー クミ 1 11 235-34209 CONDENS STOPPER コンデン スストッパー (1) 12 SS-7121410-TP SCREW 3/16-28 L=14 マルヒラネジ 3/16-28 L=14 (1) 13 236-13607 FEED LEVER 送リレバー 1 14 236-13706 FEED LEVER SHAFT オクリレバーシ 1 15 236-13805 FEED LEVER SHAFT METAL オクリレバーシ メタル 1 16 236-13953 FEED LEVER ARM ASM. オクリレバー ウデ (クミ) 1 17 SS-6150310-SP SCREW 3/16-28 L=15.5 ヒラネジ 3/16-28 L=15.5 (1) 18 NS-6150310-SP NUT 15/64-28 ロツカク ナツト 15/64-28 1 19 235-33607 FEED ADJUSTING SHAFT オクリチョウセツジク 1 20 #01 110-71909 FEED DIAL オクリダイヤル 1 21 229-52501 BACK LEVER STOPPER バックレバーストップパー 1 22 113-02700 SPRING オクリレバーバネ 2 23 SM-8060812-TP SCREW M6 L=8 トメネジ M6 L=8 1 24 SS-6121840-SP SCREW 3/16-28 L=18 ヒラネジ 3/16-28 L=18 1 25 SS-6121860-SP SCREW 3/16-28 L=18 ヒラネジ 3/16-28 L=18 1 26 SS-7121410-TP SCREW 3/16-28 L=14 マルヒラネジ 3/16-28 L=14 1 27 SS-6121860-SP SCREW 3/16-28 L=18 ヒラネジ 3/16-28 L=18 4 28 SS-1110710-SP SCREW 11/64-40 L=7 皿ねじ 11/64-40 L=7 3 29 WP-1651616-SD WASHER ヒラザガネ 3 30 235-34506 FEED DIAL SPRING オクリダイヤルバネ 2 31 #02 400-10273 FEED BLIND CONTROLLER U オクリチョウセツキ U 1 32 #02 235-45007 CONDENS DIAL U コンデン スダイヤル U 1 33 #02 263-02000 FEED DIAL オクリダイヤル 1 NOTE(注記) #01...FOR LZ-2290A-SS/ LZ-2290A-SS-7用 #02...FOR LZ-2290A-SU/ LZ-2290A-SU-7用 LZ-2290A-SU-7 LZ-2290A-SU-7用 - 14 - jintex.in

Page 20 — 8. FEED MECHANISM COMPONENTS (3)(FOR LZ-2290A-SR-7)

8. FEED MECHANISM COMPONENTS (3)(FOR LZ-2290A-SR-7) 送り関係 (3) (LZ-2290A-SR-7 用) 17 16 8 9 10 14 15 14 24~27 23 29 5 30 1 2 3 4 14 20 19 21 18 31 22 28 33 36 35 34 37 41 38 39 40 1 12 13 12 48 42 32 6 43 45 44 47 46 - 15 - jintex.in

Page 21

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 400-11831 ASSY FEED PULSE MOTOR UNIT オクリパルスモータユニットクミ 1 2 400-11832 FEED PULSE MOTOR BASE オクリパルスモータダイ (1) 3 400-09305 SUSPENSION SCREW フックヒツパリバネカケ (1) 4 NS-6090310-SP NUT 9/64-40 ロツカクナツト 9/64-40 (1) 5 WP-0460556-SD WASHER 4.6X7.5X0.5 ヒラサガネ 4.6X7.5X0.5 (2) 6 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 (2) 7 400-11839 SENSOR BASE センサーリツケイタ (1) 8 M8523-476-AA0 ZERO SENSOR A ASM. ゲンテンセンサーAクミ (1) 9 SM-4860801-SN SCRER M2.6 L=8 ナベネジ (1) 10 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 (1) 11 KM-000003-50 PULSE MOTOR ザガネツキ (1) 12 SM-6042502-TP SCREW M4X0.7 L=25 ロツカクアナボルト M4X0.7 L=25 (2) 13 SM-6041602-TP SCREW M4X0.7 L=16 ロツカクアナボルト M4X0.7 L=16 (2) 14 NM-6040000-SN NUT M4 ロツカクナツト M4 (4) 15 400-11843 PIPE GUIDE PLATE C パイプガイドイタ C (1) 16 400-22407 CORD HOLDER コードオサエ (4) 17 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 (4) 18 400-11836 PULSE MOTOR LINK B パルスモータリンク B (1) 19 400-11840 SENSOR SLIT センサーリツト (1) 20 SL-4030581-SC COMBINATION SCREW M3X5 ナベコネジ セムス M3X0.5 L=5 (1) 21 SM-8050612-TP SCREW M5X6 トメネジ M5X6 (1) 22 SM-4051655-SP SCREW M5 L=16 ナベネジ M5 L=16 (1) 23 400-11833 ASSY PULSE MOTOR LINK A パルスモータリンク A クミ (1) 24 #01 400-10286 JUNCTION SHAFT A ハリフリレンケツジクA (1) 25 #01 400-10287 JUNCTION SHAFT B ハリフリレンケツジクB (1) 26 #01 400-10288 JUNCTION SHAFT C ハリフリレンケツジクC (1) 27 #01 400-10289 JUNCTION SHAFT D ハリフリレンケツジクD (1) 28 400-11838 FEED LINK SHAFT オクリチョウセツタイヘンシンジク (1) 29 400-11837 PULSE MOTOR LINK C パルスモータリンク C (1) 30 SM-8050612-TP SCREW M5X6 トメネジ M5X6 (2) 31 SS-7111810-TP SCREW 11/64-40 L=18 マルヒラネジ 11/64-40 L=18 (2) 32 235-41352 SAFETY SWITCH ASM. アンゼンイツチクミ (1) 33 235-41303 SAFETY SWITCH BASE アンゼンイツチダイ (1) 34 235-38109 SAFETY SWITCH ARM アンゼンイツチウデ (1) 35 235-38208 SAFETY SWITCH SPRING アンゼンイツチモドシバネ (1) 36 235-38307 SAFETY SWITCH ARM SHAFT アンゼンイツチウデシテンジク (1) 37 235-38406 SAFETY SWITCH NUT アンゼンイツチトメイタ (1) 38 235-41451 SAFETY SWITCH CORD ASM. アンゼンイツチコードクミ (1) 39 HK-0346100-60 HOUSING 6P ハウジング 6P (1) 40 EA-9500B01-00 CABLE BAND ソクセンバン (2) 41 SM-4021201-SC SCREW M2 L=12 ナベネジ M2 L=12 (2) 42 SS-4151215-SP SCREW 15/64-28 L=12 バックパルスモータチュウケイケーブル (クミ) 3 43 400-17098 BTPM RELAY CABLE ASM. バックパルスモータチュウケイケーブル (クミ) 1 44 B3508-220-000 OIL TUBE HOLDER ビニール パイプ オサエ 1 45 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 1 46 400-11841 BED SUPPORT PLATE B ベツドササエタ B (1) 47 400-11842 PIPE GUIDE PLATE B パイプガイドイタ B (1) 48 CM-3003000-03 ATTENTION SEAL 2(31.5) コウオンチユウイシール2 (31.5) 1 NOTE(注記) #01...SELECTIVE PARTS 選択部品 - 16 - jintex.in

Page 22 — 9. FEED MECHANISM COMPONENTS (4)(FOR LZ-2290A-SR-7)

9. FEED MECHANISM COMPONENTS (4)(FOR LZ-2290A-SR-7) 送り関係 (4) (LZ-2290A-SR-7 用) 1 10 13 8 9 11 3 22 4 2 21 15 5 6 20 14 19 17 16 18 12 7 - 17 - jintex.in

Page 23

REF.NO NOTE PART NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 400-11847 400-11848 118-46805 SM-8060612-TP 110-50705 400-11849 B1114-280-000 400-11844 SM-8060612-TP 400-11846 SL-6051092-TN EA-9500B01-00 HD-0015300-00 400-16039 TA-1250406-R0 025-52501 229-52501 236-13607 SM-8060812-TP 236-13805 236-13953 SS-6121610-SP DESCRIPTION ASSY FEED LEVER ROD FEED LEVER ROD HOLDER PIN SCREW M6 L=6 LEVER RETURN SPRING FEED LEVER SHAFT PIN VOLUME LINK SCREW M5X6 LEVER SENSOR PLATE BOLT CABLE BAND SENSOR FEED LEVER SENSOR ASSY RUBBER PLUG D=12.5 L=4 SCREW 3/16-28 L=18 BACK LEVER STOPPER FEED LEVER SCREW M6 L=8 FEED LEVER SHAFT METAL FEED LEVER ARM ASM. SCREW 3/16-28 L=15.5 品 名 Qty オク リレバーロッド クミ 1 オク リレバーロッド (1) ササエピン (1) トメネジ M6 L=6 (1) レバーモドシバネ 1 オク リレバーシジク 1 ピン 1 ボリュ ムリンク 1 トメネジ M5X0.8 L=6 1 オク リレバーセンサートリツケイタ 1 ザガネツキカクアナボルト 2 ンバンド 1 ホールPOT 1 オク リレバーセンサー クミ 1 トメセン D=12.5 L=4 1 ヒラネジ 3/16-28 L=18 1 バックレバーストッパー 1 オク リレバー 2 トメネジ M6 L=8 1 オク リレバーシジクメタル 1 レバーウデ (クミ) (1) ヒラネジ 3/16-28 L=15.5 - 18 - jintex.in

Page 24 — 10. HOOK DRIVING SHAFT COMPONENTS (1)

10. HOOK DRIVING SHAFT COMPONENTS (1) 下軸関係 (1) 13 12 16 24 15 14 22 21 20 23 4 19 18 28 1 28 27 42 29 17 25 2 42 29 3 5 6~11.39 36 30 40 32 32 31 32 41 33 34 35 37 38 25 2 - 19 - jintex.in

Page 25

REF.NO NOTE PART NO DESCRIPTION 品名 Qty 1 235-35107 HOOK SHAFT FRONT METAL カマジクエメタル 1 2 400-03590 HOOK SHAFT BEARING ASM. カマジクジクウケ (クミ) 2 3 235-35602 HOOK DRIVING SHAFT REAR METAL カマクドウジクアトメタル 1 4 400-10283 HOOK SHAFT カマクドウジク 1 5 #02 400-03567 HOOK DRIVING SHAFT カマクドウジク 1 6 #02 235-36303 HOOK DRIVING GEAR (SMALL) A カサクドウハグルマ (ショウ) A 1 7 #02 235-36402 HOOK DRIVING GEAR (SMALL) B カサクドウハグルマ (ショウ) B 1 8 #02 235-36501 HOOK DRIVING GEAR (SMALL) C カサクドウハグルマ (ショウ) C 1 9 #02 235-36600 HOOK DRIVING GEAR (SMALL) D カサクドウハグルマ (ショウ) D 1 10 #02 235-36709 HOOK DRIVING GEAR (SMALL) E カサクドウハグルマ (ショウ) E 1 11 #02 235-36808 HOOK DRIVING GEAR (SMALL) F カサクドウハグルマ (ショウ) F 1 12 400-03599 BOBBIN CASE COMPL. ボビンケースケツゴウ 1 13 #01 400-03598 BOBBIN CASE ASM. ボビンケースクミ 1 14 225-25877 HOOK COMPL. V カマケツゴウV 1 15 225-96704 BOBBIN S ボビン S 1 16 235-03402 INNER HOOK STOPPER ウチガマトメ 1 17 B1308-155-000 GEAR ASM. LARGE シタカサハグルマ ダイ クミ 1 18 B1307-155-0A0 GEAR ASM. LARGE シタカサハグルマ ダイ クミ (2) 19 SS-8660810-TP SCREW 1/4-40 L=8 トメネジ 1/4-40 L=8 1 20 110-15906 OIL WICK シモジクメトメネジシン 1 21 229-16506 SET SCREW シモジクメトメネジシン 1 22 RO-0360802-00 RUBBER RING Oリング 1 23 RO-0481901-00 RUBBER RING Oリング 2 24 SS-4110915-SP SCREW 11/64-40 L=9 トメネジ 11/64-40 L=9 1 25 SS-8110520-TP SCREW 11/64-40 L=4.5 トメネジ 11/64-40 L=4.5 4 26 SS-8660810-TP SCREW 1/4-40 L=8 トメネジ 1/4-40 L=8 2 27 SS-8660810-TP SCREW 1/4-40 L=8 トメネジ 1/4-40 L=8 2 28 401-20730 HOOK SHAFT OIL SEAL カマクドウジクオイルシール 2 29 400-10282 OIL SEAL COLLAR カマクジククミオイルシールカラー 2 30 400-10261 PUMP METAL ASM. ポンプメタルクミ 1 31 400-10262 PUMP METAL ポンプメタル (1) 32 TA-0180401-MO NEEDLE COOLER PLUG CAP トメセン D=1.8X2.1 L=4.3 (7) 33 236-28902 PLUNGER SPRING プランジャーバネ 3 34 236-29009 PLUNGER SCREW プランジャーネジ 3 35 RO-0681901-00 RUBBER RING Oリング 3 36 RO-1721801-00 RUBBER RING Oリング 1 37 SS-8111251-SP SCREW 11/64-40 L=12.0 トメネジ 11/64-40 L=12 1 38 TA-0850604-RO RUBBER PLUG トメセン 1 39 #02 235-38903 HOOK DRIVING GEAR (SMALL) S カマクドウハグルマ (ショウ) S 1 40 228-90008 HOOK DRIVING SHAFT OIL SEAL カマクドウジクオイルシール 2 41 236-28803 PLUNGER プランジャー 2 42 400-11424 Hook GEAR BOX OIL SEAL カマギヤボックスオイルシール 2 NOTE(注記) #01...FOR LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SS-7, LZ-2290A-SU-7, LZ-2290A-SR-7用 LZ-2290A-SS, LZ-2290A-SU, LZ-2290A-SS-7, LZ-2290A-SU-7, LZ-2290A-SR-7 #02...SELECTIVE PARTS 選択部品 - 20 - jintex.in

Page 26 — 11. HOOK DRIVING SHAFT COMPONENTS (2)

11. HOOK DRIVING SHAFT COMPONENTS (2) 下軸関係 (2) 13 13 16 16 20 5 11 4 15 15 7~10 2 22 14 19 23 3 14 18 17 6 21 1 12 12 9 - 21 - jintex.in

Page 27

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 400-10316 LOWER SHAFT FRONT BEARING BUSH シモジクマエジクウケブツシュ 1 2 400-10314 LOWER SHAFT INNER METAL シモジクナカメタル 1 3 235-36055 LOWER SHAFT INNER BEARING ASM. シモジクナカジクウケケクミ 1 4 235-36105 LOWER SHAFT REAR BUSH シモジクアトブツシュ 1 5 235-36253 LOWER SHAFT REAR BEARING ASM. シモジクアトジクウケケクミ 1 6 #01 400-10303 LOWER SHAFT シモジク 1 7 #02 401-49251 HELICAL GEAR A 釜駆動歯車大A 1 8 #02 401-49252 HELICAL GEAR B 釜駆動歯車大B 1 9 #02 401-49253 HELICAL GEAR C 釜駆動歯車大C 1 10 #02 401-49254 HELICAL GEAR D 釜駆動歯車大D 1 11 G1615-880-000 OIL SEAL オイルシール 1 12 SB-3100010-C0 BEARING ころがり軸受 2 13 SS-6660710-TP SCREW 1/4-40 L=7 ヒラネジ 1/4-40 L=7 2 14 SS-8110750-SP SCREW 11/64-40 L=6.5 トメネジ 11/64-40 L=6.5 2 15 SS-8660810-TP SCREW 1/4-40 L=8 トメネジ 1/4-40 L=8 2 16 SM-8060812-TP SCREW M6 L=8 トメネジ M6 L=8 2 17 235-41709 THREAD TRIMMER CAM イトキリカム 1 18 CS-1000881-TP THRUST COLLAR スラスト受 D=10 W=8 1 19 SS-6660710-TP SCREW 1/4-40 L=7 ヒラネジ 1/4-40 L=7 2 20 401-60262 LOWER SHAFT SPROCKET 下軸スプロケット 1 21 B2508-704-000 OIL SEAL ルーバジク オイルシール 2 22 G1615-880-000 OIL SEAL オイルシール 1 23 SM-80506A2-TP SCREW M5 L=6 六角付きねじ M5 L=6 2 NOTE(注記) #01...FOR LZ-2290A-SS, LZ-2290A-SS, LZ-2290A-SR-7用 #02...SELECTIVE PARTS 選択部品

Page 28 — 12. THREAD TRIMMER MECHANISM COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7)

12. THREAD TRIMMER MECHANISM COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7) 糸切り関係 (LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7 用) 36 9 39 1 46 10 3 2 4 43 44 47 19 22 21 23 33 25 24 20 35 26 29 30 27 28 34 32 31 15 53 45 18 16 42 40 14 13 49 50 8 7 51 11 6 12 5 52 37 38 54 - 23 - jintex.in

Page 29

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 400-10290 BASE PLATE ASM. ベースイタ クミ 1 2 235-42053 CLUTCH PLATE ASM. クラッチバン クミ 1 3 235-42103 CLUTCH RETURN SPRING クラッチトドシバネ 1 4 235-42202 KNIFE RETURN SPARING メスドシバネ 1 5 235-41808 MOVING KNIFE LINK ドウメスリンク 1 6 110-40854 KNIFE DRIVING ARM ASM. メス クドウデ クミ 1 7 229-49002 ROLLER ARM SEAT コロウデザ 1 8 229-49101 ROLLER FULCRUM SHAFT コロシテンジク 1 9 225-54505 CLUTCH LINK クラッチリンク 1 10 235-42301 THREAD TRIMMER SOLENOID イトキリソレノイド 1 11 400-10295 MOVING KNIFE LINK PIN ドウメスリンクピン 1 12 225-54802 MOVING KNIFE LINK BASE ドウメスリンク ザ 1 13 225-54901 DRIVING ARM STOPPER クドウデストッパー 1 14 225-55304 ROLLER RETURN SPRING コロ モドシバネ 1 15 225-55551 FORK KNIFE ASM. メスフタマタ (クミ) 1 16 225-55858 ROLLER ARM ASM. コロウデ (クミ) 1 17 225-56906 FIXED PLATE コテイイタ 1 18 225-57458 KNIFE UNIT メスユニット (1) 19 225-58308 SLIDING PLATE スベリイタ (1) 20 225-58407 KNIFE BASE メスダイ (1) 21 225-57557 DRIVING KNIFE ASM. ドウメス (クミ) (1) 22 225-57706 FIXED KNIFE コテイメス (1) 23 225-57805 KNIFE STOPPER RIGHT メスケイタ (ミギ) (1) 24 225-57904 KNIFE STOPPER LEFT メスケイタ (ヒダリ) (1) 25 225-58209 SPRING メスバネ (1) 26 225-58159 CLAMP PLATE ASM. クランプイタ (クミ) (1) 27 225-58001 FELT クランプフエルト (1) 28 225-58100 CLAMP PLATE クランプイタ (1) 29 SS-7090610-SP SCREW 9/64-40 L=6 マルヒラネジ 9/64-40 L=6 (2) 30 SS-1090510-SP SCREW 9/64-40 L=5 サラネジ 9/64-40 L=5 (2) 31 SS-7060310-SP SCREW 3/32-56 L=5 マルヒラネジ 3/32-56 L=5 (1) 32 SS-7060310-SP SCREW 3/32-56 L=3 マルヒラネジ 3/32-56 L=3 (1) 33 NP-2103000-00 LOCATING SPRING WASHER ブツシュナツト (1) 34 WS-0270002-KN SPRING WASHER M2.6 シンヒモオサエバネ ザガネ T=0.4 (1) 35 D2056-772-B0B WASHER B T=0.4 シンヒモオサエバネ ザガネ T=0.4 (1) 36 235-42418 CLUTCH LINK PIN クラッチリンピン 1 37 NS-6150310-SP NUT 15/64-28 ロッカクナット 15/64-28 1 38 NS-6150430-SP NUT 15/64-28 ロッカクナット 15/64-28 1 39 NM-6030001-SB NUT M3 ロッカクナット M3X0.5 1シュ 2 40 RE-0400000-KO E-RING 4 Eガタトメワ 4 2 41 RE-0500000-KO E-RING 5 Eガタトメワ 5 1 42 RE-0600000-KO E-RING 6 Eガタトメワ 6 1 43 RE-0600000-KO E-RING 6 Eガタトメワ 6 1 44 SD-0600291-TP HINGE SCKEW D=6 H=2.9 ダンネジ D=6 H=2.9 1 45 SD-0791503-SP HINGE SCREW D=7.94 H=15 ダンネジ D=7.94 H=15 1 46 SM-4040601-SC SCREW M4X0.7 L=6 ナベコネジ M4X0.7 L=6 3 47 SS-2110920-TP SCREW 11/64-40 L=8.5 マルサラネジ 11/64-40 L=8.5 1 48 SS-2111010-TP SCREW 11/64-40 L=9.5 マルサラネジ 11/64-40 L=9.5 1 49 SS-4110915-SP SCREW 11/64-40 L=9 ナベネジ 11/64-40 L=9 2 50 SS-4150915-SP SCREW 15/64-28 L=9 ナベネジ 15/64-28 L=9 2 51 SS-7090610-SP SCREW 9/64-40 L=6 マルヒラネジ 9/64-40 L=6 1 52 WP-0621016-SH WASHER ヒラサガネ 1 53 229-19203 OIL PROTECTING RUBBER テンビンアブラリコム 1 54 BP-6000000-00 VINYL PIPE ビニール パイプ 1 - 24 - jintex.in

Page 30 — 13. FEED MECHANISM COMPONENTS

13. FEED MECHANISM COMPONENTS(FOR LZ-2290A-SU,LZ-2290A-SU-7,LZ-2290A-DU,LZ-2290A-DU-7) 送り関係 (LZ-2290A-SU,LZ-2290A-SU-7,LZ-2290A-DU,LZ-2290A-DU-7用) REF.NO NOTE PART NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 #01 #01 #01 #02 #02 100-25906 235-01901 229-13206 235-01802 229-13107 SS-7110740-TP 235-45403 235-01356 112-14806 235-01703 235-01604 SS-7121410-TP SS-6110820-TP RC-0330415-KP SM-8050612-TP WP-0480856-SP WP-0500916-SD 235-45106 400-10264 235-58406 SS-7121410-TP 235-59909 RE-0300000-KO NOTE(注記) DESCRIPTION SPACER FEED BASE FEED BASE SHAFT FEED BASE SHAFT B FEED BASE ARM SCREW 11/64-40 L=7 VERTICAL FEED ARM VERTICAL FEED CAM ASM. PIN LINK B FEED BASE LINK SCREW 3/16-28 L=14 SCREW 11/64-40 L=8 SNAP RING SCREW M5X6 WASHER 4.8X8.4X0.8 WASHER 5X7X0.9 LOWER SHAFT U VERTICAL FEED LINK VERTICAL FEED LINK SHAFT D SCREW 3/16-28 L=14 VERTICAL FEED ROD PIN DU E-RING 3 #01...FOR LZ-2290A-SU, LZ-2290A-SU-7 #02...FOR LZ-2290A-DU, LZ-2290A-DU-7 品名 オクりダイスペーサー オク リダイ オク リダイジク オク リダイジク B オク リダイ ウデ マルヒラネジ 11/64-40 L=7 ジョウゲオク リウデ ジョウゲオク リカム (クミ) スイヘイボウ ピン ジョウゲオク リリンク B オク リダイリンク マルヒラネジ 3/16-28 L=14 ヒラネジ 11/64-40 L=8 トメネジ トメネジ M5X6 ヒラザガネ 4.8X8.4X0.8 ヒラザガネ 5X7X0.9 シモジク U ジョウゲオク リリンク ジョウゲオク リリンクジク D マルヒラネジ 3/16-28 L=14 ジョウゲオク リロツドピン DU Eガタワフ 3 LZ-2290A-SU, LZ-2290A-SU-7用 LZ-2290A-DU, LZ-2290A-DU-7用 Qty 1 1 1 1 1 1 1 1 1 1 1 1 2 2 2 1 1 1 2 1 2 - 25 - jintex.in

Page 31 — 14. AUTOMATIC REVERSE FEED MECHANISM COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7)

14. AUTOMATIC REVERSE FEED MECHANISM COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 REF.NO NOTE PART NO DESCRIPTION 235-42509 400-10307 400-08596 401-08063 401-08064 235-42707 D2468-555-B00 RE-1200000-KO SS-7110740-TP WP-1703001-SC HK-0346400-0B CM-3003000-03 113-14408 NS-6110350-SP SD-0600452-TP SD-0951501-SP SS-4150915-SP 400-10280 AUTOMATIC REVERSE FEED LINK AUTOMATIC REVERSE FEED ARM SOLENOID BASE ASM. REVERSE FEED SOLENOID REVERSE FEED SOLENOID PLUNGER REVERSE FEED SOLENOID BASE RUBBER PLUNGER E-RING 12 SCREW 11/64-40 L=7 WASHER 17X30X3 PIN CONTACT ATTENTION SEAL 2(3.15) PLUNGER ARM PIN NUT 11/64-40 HINGE SCREW D=6 H=4.5 HINGE SCREW D=9.53 H=15 SCREW 15/64-28 L=9 SOLENOID BASE STUD 品 名 Qty ギアクオクリック ギアクオクリック オクリソレノイドダイ クミ 逆ソレノイド プランジャー オクリソレノイドダイ プランジャー ゴム Eガタトメワ 12 マルヒラネジ 11/64-40 L=7 ヒラザガネ 17X30X3 ピンコンタクト コウオンチュウイシール2(31.5) マグネットリンクピン ロツカクナット 11/64-40 ダンネジ D=6 H=4.5 ダンネジ D=9.53 H=15 ネジ 15/64-28 L=9 ソレノイドダイシチュウ 1 1 1 (1) (1) (1) (1) (3) (1) (2) (1) 1 2 2 1 2 2 - 26 - jintex.in

Page 32 — 15. THREAD FEEDER COMPONENTS

15. THREAD FEEDER COMPONENTS 糸繰り出し関係 REF.NO NOTE PART NO DESCRIPTION Qty 1 #01 235-38457 FEEDER SOLENOID ASM. 1 2 #01 400-10321 FEEDER WIRE FITTING BASE 1 3 #01 235-38606 FEEDER WIRE 1 4 #01 SS-6110650-TP SCREW 11/64-40 L=5.5 1 5 #01 SS-8151230-SP SCREW 11/64-40 L=12 2 6 #01 SS-8110422-TP SCREW 11/64-40 L=4 NOTE(注記) #01...FOR LZ-2290A-SS-7, LZ-2290A-SU-7, LZ-2290A-SR-7 - 27 - jintex.in

Page 33 — 16. MANUAL SWITCH COMPONENTS (FOR LZ-2290A-SS,LZ-2290A-SU)

16. MANUAL SWITCH COMPONENTS (FOR LZ-2290A-SS,LZ-2290A-SU) 手元スイッチ関係 (LZ-2290A-SS,LZ-2290A-SU 用) REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 400-03582 MANUAL SWITCH BASE COMPL. テモトスイッチダイ (ケツゴウ) (1) 2 400-03570 SWLED CABLE A ASM. SWLEDケーブルAクミ (1) 3 400-03583 MANUAL SWITCH BASE ASM. テモトスイッチダイ (クミ) (1) 4 400-03575 UP-AND-DOWN SWITCH BASE ショウコウスイッチダイ (1) 5 400-03578 MANUAL SWITCH BASE テモトスイッチダイ (1) 6 SS-4110515-SP SCREW 11/64-40 L=5 ナベネジ T 11/64-40 L=5 (1) 7 EA-9500B01-00 CABLE BAND ソクセンバンド (1) 8 HK-0346101-20 HOUSING 12P ハウジング 12P (1) - 28 - jintex.in

Page 34 — 17. MANUAL SWITCH COMPONENTS

17. MANUAL SWITCH COMPONENTS (FOR LZ-2290A-SS-0B,LZ-2290A-SU-0B) 手元スイッチ関係 (LZ-2290A-SS-0B,LZ-2290A-SU-0B 用) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 - 29 - jintex.in

Page 35

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 #01 400-03574 MANUAL SWITCH BASE COMPL. A テモトスイツチダイ(ケツゴウ) A 1 2 400-03570 SWLED CABLE A ASM. SWLEDケーブルAクミ (1) 3 400-03577 MANUAL SWITCH BASE ASM. A スイツチダイ(クミ) A (1) 4 400-03575 UP-AND-DOWN SWITCH BASE シヨウコウスイツチダイ (1) 5 400-03578 MANUAL SWITCH BASE テモトスイツチダイ (1) 6 400-03579 TOUCH BACK SWITCH BASE ASM. タツチバツクスイツチダイ(クミ) (1) 7 400-03580 TOUCH BACK SWITCH BASE タツチバツクスイツチダイ (1) 8 400-03581 REVERSE FEED CORD ASM. ギヤクオクリスコード(クミ) (1) 9 236-31708 REVERSE FEED SWITCH COVER ギヤクオクリスイツチカバー (1) 10 236-31807 REVERSE FEED SWITCH SHAFT ギヤクオクリスイツチジク (1) 11 236-31906 REVERSE FEED SWITCH SUPPORT ギヤクオクリスイツチウケ (1) 12 236-32102 REVERSE FEED SWITCH BASE GUIDE ギヤクオクリスイツチダイガイド (1) 13 EA-9500B01-00 CABLE BAND ソクセンバン ド (1) 14 SS-7110740-TP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 (1) 15 SS-4110515-SP SCREW 11/64-40 L=5 ナベネジ 11/64-40 L=5 (3) 16 EA-9500B01-00 CABLE BAND ソクセンバン ド (1) 17 HK-0346101-20 HOUSING 12P ハウジング 12P (1) 18 #01 400-03570 MANUAL SWITCH BASE COMPL. B テモトスイツチダイ(ケツゴウ) B 1 19 400-03570 SWLED CABLE A ASM. SWLEDケーブルAクミ (1) 20 400-03576 MANUAL SWITCH BASE ASM. B スイツチダイ(クミ) B (1) 21 400-03575 UP-AND-DOWN SWITCH BASE シヨウコウスイツチダイ (1) 22 400-03578 MANUAL SWITCH BASE テモトスイツチダイ (1) 23 400-03581 REVERSE FEED CORD ASM. ギヤクオクリスコード(クミ) (1) 24 236-31708 REVERSE FEED SWITCH COVER ギヤクオクリスイツチカバー (1) 25 236-31807 REVERSE FEED SWITCH SHAFT ギヤクオクリスイツチジク (1) 26 236-31906 REVERSE FEED SWITCH SUPPORT ギヤクオクリスイツチウケ (1) 27 236-32102 REVERSE FEED SWITCH BASE GUIDE ギヤクオクリスイツチダイガイド (1) 28 EA-9500B01-00 CABLE BAND ソクセンバン ド (1) 29 SS-4110515-SP SCREW 11/64-40 L=5 ナベネジ 11/64-40 L=5 (1) 30 SS-7110740-TP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 (1) 31 EA-9500B01-00 CABLE BAND ソクセンバン ド (1) 32 HK-0346101-20 HOUSING 12P ハウジング 12P (1) 33 TA-0950806-R0 RUBBER PLUG 止メ栓 (1) 34 SS-4120615-SP SCREW 3/16-28 L=6 なべネジ 3/16-28 L=6 2 NOTE(注記) #01...VARIOUS NOS.FOR DESTINATIONS 仕向地により異なる - 30 - jintex.in

Page 36 — 18. THREAD RELEASE SOLENOID COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7)

18. THREAD RELEASE SOLENOID COMPONENTS(FOR LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7) 糸緩めソレノイド関係 (LZ-2290A-SS-7,LZ-2290A-SU-7,LZ-2290A-SR-7 用) 17 18 2 1 3 6 14 13 7 5 16 8 9 12 10 4 15 40 41 28 31 26 47 44 32 45 37 30 33 38 39 35 34 29 27 42 43 46 48 20 23 25 24 22 21 - 31 - jintex.in

Page 37

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 #01 400-03572 SOLENOID COMPL. A 1 2 400-03574 MANUAL SWITCH BASE COMPL. A (1) 3 400-03570 SWLED CABLE A AKMI (1) 4 400-03575 MANUAL SWITCH BASE ASM. A (1) 5 400-03576 UP-AND-DOWN SWITCH BASE (1) 6 400-03578 MANUAL SWITCH BASE (1) 7 400-03579 TOUCH BACK SWITCH BASE ASM. (1) 8 400-03580 TOUCH BACK SWITCH BASE (1) 9 400-03581 REVERSE FEED CORD ASM. (1) 10 236-31708 REVERSE FEED SWITCH COVER (1) 11 236-31807 REVERSE FEED SWITCH SHAFT (1) 12 236-31906 REVERSE FEED SWITCH SUPPORT (1) 13 236-32102 REVERSE FEED SWITCH BASE GUIDE (1) 14 EA-9500B01-00 CABLE BAND (1) 15 SS-7110740-TP SCREW 11/64-40 L=7 (3) 16 SS-4110515-SP SCREW 11/64-40 L=5 (1) 17 EA-9500B01-00 CABLE BAND (1) 18 HK-0346101-20 HOUSING 12P (1) 19 137-05603 FRAME SIDE COVER GASKET (2) 20 225-52905 THREAD RELEASE PUSH PLATE (1) 21 400-03651 THREAD RELEASE SOLENOID ASM. (1) 22 NM-6030001-SC NUT M3 (2) 23 NM-6040001-SN NUT M4X0.7 (1) 24 SS-4121015-SP SCREW 3/16-28 L=10 (4) 25 PS-0300182-KF SPRING PIN 3X18 1 26 #01 400-03571 SOLENOID COMPL. B 1 27 400-03573 MANUAL SWITCH BASE COMPL. B (1) 28 400-03570 SWLED CABLE A AKMI (1) 29 400-03576 MANUAL SWITCH BASE ASM. B (1) 30 400-03575 UP-AND-DOWN SWITCH BASE (1) 31 400-03578 MANUAL SWITCH BASE (1) 32 400-03581 REVERSE FEED CORD ASM. (1) 33 236-31708 REVERSE FEED SWITCH COVER (1) 34 236-31807 REVERSE FEED SWITCH SHAFT (1) 35 236-31906 REVERSE FEED SWITCH SUPPORT (1) 36 236-32102 REVERSE FEED SWITCH BASE GUIDE (1) 37 EA-9500B01-00 CABLE BAND (1) 38 SS-4110515-SP SCREW 11/64-40 L=5 (1) 39 SS-7110740-TP SCREW 11/64-40 L=7 (1) 40 EA-9500B01-00 CABLE BAND (1) 41 HK-0346101-20 HOUSING 12P (1) 42 137-05603 FRAME SIDE COVER GASKET (1) 43 225-52905 THREAD RELEASE PUSH PLATE (1) 44 400-03651 THREAD RELEASE SOLENOID ASM. (1) 45 NM-6030001-SC NUT M3 (1) 46 NM-6040001-SN NUT M4X0.7 (1) 47 SS-4121015-SP SCREW 3/16-28 L=10 (1) 48 PS-0300182-KF SPRING PIN 3X18 (1) NOTE(注記) #01...VARIOUS NOS.FOR DESTINATIONS 仕向地により異なる

Page 38 — 19.LUBRICATION COMPONENTS(EXCEPT LZ-2290A-DS,LZ-2290A-DS-7,LZ-2290A-DU,LZ-2290A-DU-7)

19.LUBRICATION COMPONENTS(EXCEPT LZ-2290A-DS,LZ-2290A-DS-7,LZ-2290A-DU,LZ-2290A-DU-7) 給油関係 (LZ-2290A-DS,LZ-2290A-DS-7,LZ-2290A-DU,LZ-2290A-DU-7 を除く) 41 52 54 53 51 7 21 25 32 50 55 25 19 46 56 22 57 42 43 19 49 13 25 47 57 29 19 63 14 15 19 61 45 16 59 60 44 34 62 24 60 8 64 67 63 10 27 30 58 20 19 17 19 23 36 9 1 37 19 10 30 19 2 19 5 3 6 4 38 5 65 19 5 31 35 40 18 28 19 11 20 66 33 jintex.in

Page 39

REF.NO NOTE PART NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 401-75861 235-39372 235-39315 235-39414 236-29801 RO-0371801-00 SS-4120615-SP 236-30106 400-00344 WP-0460556-SD 235-40305 SL-6052092-TN 235-40057 235-40008 236-30007 B3536-122-000 236-28357 236-28704 236-29306 236-29405 235-39703 235-40107 RO-0481901-00 400-00343 236-29801 400-13595 RO-0982401-00 RO-1952401-00 SS-4110615-SP SS-4110815-SP SS-4121615-SP SS-4110615-SP SS-4111415-SP M8002-430-000 236-30007 236-30007 236-30007 236-29801 236-30106 401-49239 400-50598 SM-0081001-SD TA-0850604-RO 401-49240 400-22407 236-30007 236-30007 RO-0982401-00 SL-4051091-SC 235-39562 235-39513 B3518-280-000 236-30007 CQ-2200000-00 236-29306 101-26803 236-30452 236-30106 236-29405 236-30650 236-30601 236-30007 401-76805 TA-0750404-RO EA-9500B01-00 DESCRIPTION OIL_TANK HOOK OIL REGULATING ASM. HOOK OIL REGULATING HOOK OIL REGULATING SCREW LUBRICATION CONNECTOR RUBBER RING SCREW 3/16-28 L=6 TUBE B LUBRICATING INLET CAP WASHER 4.6X7.5X0.5 FLOATER CASE CAP SCREW ONCE THROUGH OIL FELT ASM. ONCE THROUGH OIL FELT TUBE FLOATER FLOATER ASM. FLOATER CASE PIPE STOPPER A PIPE STOPPER B LUBRICATION TANK PIPE GUIDE ONCE THROUGH OIL FELT PRESSER RUBBER RING LUBRICATING INLET LUBRICATION CONNECTOR OIL_EXIT_CAP RUBBER RING RUBBER RING SCREW 11/64-40 L=6 SCREW 11/64-40 L=8 SCREW 3/16-28 L=16 SCREW 11/64-40 L=6 SCREW 11/64-40 L=14 STOPPER TUBE TUBE TUBE LUBRICATION CONNECTOR TUBE TUBE B FACE LUBRICATION TANK ASM. LUBRICATION CONNECTOR SCREW RUBBER PLUG FACE LUBRICATION TANK CORD HOLDER TUBE TUBE RUBBER RING SCREW M5X0.8 L=10 FACE LUBRICATION PRESSER ASM. FACE LUBRICATION PRESSER BALANCE LUBRICATING TUBE OUL WICK PIPE STOPPER A OIL TUBE HOLDER OIL FILTER ASM. TUBE B PIPE STOPPER B OIL FILTER JOINT ASM. OIL FILTER JOINT TUBE OIL_TANK_PLATE PLUG D=7.5 L=3.5 CABLE BAND TUBE 品 名 オイルタンク カマユリョウチョウセツキ (クミ) カマユリョウチョウセツタイ カマユリョウチョウセツネジ キュウユツギテ Oリング ナベネジ 3/16-28 L=6 チューブB キュウユウキャップ ヒラサガネ 4.6X7.5X0.5 ウキケースキャップ ザガネツキロッカクアナボルト カンリュウフエルトクミ カンリュウフエルト チューブ フロアター フロアターアセンブリ ウキケース パイプストッパA パイプストッパB メンブキュウタンクパイプガイド カンリュウフエルトオサエ Oリング キュウユウ キュウユツギテ 排油キャップ Oリング Oリング ナベネジ 11/64-40 L=6 ナベネジ 11/64-40 L=8 SCREW 3/16-28 L=16 ナベネジ 11/64-40 L=6 ナベネジ 11/64-40 L=14 ストッパ チューブ チューブ チューブ キュウユツギテ チューブ チューブB 面部給油タンク (組) キュウユツギテ トラスねじ M8 L=10 トメセン 面部給油タンク コードオサエ チューブ チューブ Oリング ナベネジ セムス M5X0.8 L=10 メンブキュウオサエ (クミ) テンビン キユーバイリーン チューブ ユシン パイプトメA パイプ止め オイルフィルター (クミ) チューブB パイプストッパB オイルフィルタージョイント (クミ) オイルフィルタージョイント チューブ オイルタンク止め板 トメセン D=7.5 L=3.5 ソクセンバンド チューブ Qty 1 1 (1) (2) (5) (2) 2 0.39 1 3 1 2 1 (1) (1.07) 1 1 15 3 1 1 1 5 1 1 1 2 2 2 1 0.07 0.16 0.16 1 0.18 0.3 1 (1) (2) (1) (0.475) (0.188) (1) (1) (1) (1) (1) (0.42) (0.46) (1) (2) 1 (0.04) (2) (1) (1) (0.09) 1 1 1 0.11 - 34 - jintex.in

Page 40 — 20. WIPER MECHANISM COMPONENTS

20. WIPER MECHANISM COMPONENTS(FOR LZ-2290A-SS-7-WB,LZ-2290A-SU-7-WB,LZ-2290A-SR-7-WB) ワイパー関係 (LZ-2290A-SS-7-WB,LZ-2290A-SU-7-WB,LZ-2290A-SR-7-WB 用) 15 23 24 17 35 25 16 34 30 19 26 28 31 21 22 20 29 27 32 33 1 4 3 2 6 11 7 12 14 13 8 9 10 - 35 - jintex.in

Page 41

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 225-61757 WIPER ASM. ワイパー (クミ) 1 2 225-61856 WIPER BASE ASM. ワイパーベース ケツゴウ (1) 3 225-61807 WIPER BASE ワイパーダイ (1) 4 102-08601 WIPER LINK 1 ワイパーリンク (1) 5 D2107-490-D00 PIN ワイパーリンク カシメピン (2) 6 RE-0320000-K0 E-RING 3.2 Eガタトメワ 3.2 (2) 7 225-61955 WIPER LINK COMPL. ワイパーリンク B (ケツゴウ) (1) 8 102-08858 WIPER LINK ASM. 2 ワイパーリンク (2) クミ (1) 9 225-61906 WIPER LINK ワイパーリンク B (1) 10 D2107-490-D00 PIN ワイパーリンク カシメピン (1) 11 102-08700 WIPER LINK SHAFT ワイパーリンクジク (1) 12 WP-0371016-SD WASHER 3.7X8X1 ヒラサガネ 3.7X8X1 (2) 13 SS-3090520-SP SCREW 9/64-40 L=4.5 マルネジ 9/64-40 L=4.5 (2) 14 225-61708 WIPER ワイパー (1) 15 400-03653 WIPER SOLENOID ASM. ワイパーソルノイド (クミ) 1 16 225-62102 WIPER BASE ワイパーダイ (1) 17 401-06937 WIPER SOLENOID ASM. ワイパーソルノイド (組) (1) 18 229-55900 WIPER RUBBER A ワイパーゴム A (1) 19 229-56007 WIPER RUBBER B ワイパーゴム B (1) 20 225-62201 WIPER LINK ワイパーリンク A (1) 21 229-56205 WIPER HINGE SCREW COLLAR ワイパーダンネジカラー (1) 22 229-56304 WIPER SPRING ワイパーバネ (1) 23 229-56504 WIPER COVER ワイパーカバー (1) 24 SL-4030631-SC SCREW M3X6 ザガネツキ ナベコネジ M3 L=6 (1) 25 HA-0060000-0A SWITCH スイッチ (1) 26 229-57203 WIPER LINK COLLAR ワイパーリンクカラー (1) 27 SD-0500481-TP HINGE SCREW D=5 H=4.8 ダンネジ D=5 H=4.8 (1) 28 229-57104 WIPER SOLENOID SHAFT ワイパーソルノイドジク (1) 29 NS-6110310-SP NUT 11/64-40 ロツカクナット 11/64-40 (1) 30 SD-0650321-TP HINGE SCREW D=6.5 H=3.2 ダンネジ D=6.5 H=3.2 (1) 31 SL-4030641-SE SCREW ザガネツキネジ (4) 32 MAO-91003000 BSW PRESSER PLATE WASHER B スイツチ オシイタザガネ 2 33 NS-6110310-SP NUT 11/64-40 ロツカクナット 11/64-40 1 34 SD-0600271-SP HINGE SCREW D=6 H=2.7 ダンネジ D=6 H=2.7 1 35 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 2 - 36 - jintex.in

Page 42 — 21. UNDER COVER COMPONENTS

21. UNDER COVER COMPONENTS アンダーカバー関係 1 2 3 4 5 6 7 25 24 26 29 27 28 17 12 14 19 16 23 20 20 15 17 18 9 11 10 8 21 36 35 31 33 32 34 30 13 - 37 - jintex.in

Page 43

REF.NO NOTE PART NO DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 400-03603 400-03604 110-47107 101-62600 229-32453 229-32404 SM-9062053-SR 400-03606 236-39107 SM-8063012-TR NM-6060001-SE 236-39206 236-39305 236-39404 236-39503 236-39602 NS-6150310-SP RE-1000000-KO RE-1000000-KO SD-0720331-SP SM-9061853-SR SM-9061853-SR WP-0650876-SD 400-03605 400-03607 HM-0008600-10 SM-1044050-SM SM-4040601-SC 229-34251 SM-9061203-SE 229-34202 229-34301 229-34400 229-34509 229-34608 UNDER COVER ASM. UNDER COVER RUBBER CUSHION RUBBER CUSHION BRACKET ASM. BRACKET SCREW M6 L=20 KNEE LIFTER ROTATING ARM ASM. BRACKET SCREW M6 L=30 NUT M6 CONNECTING ROT KNEE PRESS ROD SHAFT SPRING CONNECTING ROD NUT 15/64-28 E-RING 10 E-RING 10 HINGE SCREW D=7.24 H=3.3 SCREW M6 L=17.5 SCREW M6 L=17.5 WASHER 6.5X13X0.8 COOLING FAN FILTER WIRE PRESSER A FAN FILTER SCREW M4X0.7 L=40 SCREW M4X0.7 L=6 KNEE PAD PLATE ASM. SCREW M6 L=12 KNEE PAD PLATE KNEE PAD PLATE SUPPORT KNEE PAD PLATE RUBBER KNEE PAD PLATE COVER KNEE PAD UPRIGHT SHAFT 品 名 アンダーカバー (クミ) アンダーカバー トウブサエゴム トウブサエゴム ヒザアテテジク トリックウデ (クミ) ヒザアテテジク トリックウデ ロツカクボルト ヒザアゲカイテンウデ (クミ) ヒザアゲカイテンウデ トメネジ ロツカクナツト M6 1シユ ヒザアゲテコジク ヒザアテヨコジク ヒザアゲサドウジク ヒザアゲカイテンウデバネ ヒザアゲレンケツロツド ロツカクナツト 15/64-28 Eガタトメワ 10 Eガタトメワ 10 ダンネジ D=7.24 H=3.3 ロツカクボルト ロツカクボルト ヒラガネ 6.5X13X0.8 ヒヤクフアン フイルター ワイヤーオサエ A モータパーツ サラコネジ M4X0.7 L=40 ナベコネジ M4X0.7 L=6 ヒザアテタイタ (クミ) ロツカクボルト M6 L=12 ヒザアテタイタ ヒザアテタイタササエ ヒザアテタイタゴム ヒザアテタイタカバー ヒザアテテジク Qty (1) (1) (2) (2) (1) (1) (2) (1) (1) (2) (2) (1) (1) (1) (1) (1) (2) (2) (1) (2) (1) (1) (2) (1) (2) (1) (2) (2) 1 (1) (1) (1) (1) (1) - 38 - jintex.in

Page 44 — 22. THREAD STAND COMPONENTS

22. THREAD STAND COMPONENTS 糸立装置関係 REF. NO NOTE PART NO DESCRIPTION 品 名 Qty 1 229-30358 THREAD STAND ASM. イトタテツウチ (クミ) (2) 2 229-31109 SPOOL PIN イトマキフレドメ (2) 3 229-31000 SPOOL PIN イトマキフレドメ (2) 4 229-30903 SPOOL REST CUSHION イトマキヨウクザラツクシヨン (2) 5 229-30804 SPOOL REST イトマキヨウクザラ (2) 6 SM-6061610-SC SCREW M6 L=16 ヒラコネジ M6 L=15 (2) 7 229-30705 THREAD REST ARM JOINT イトタテボウシメカナグ (2) 8 229-31406 SPOOL REST ROD RUBBER CAP イトタテボウホコゴム (1) 9 229-30507 SPOOL REST ARM イトタテボウデ (2) 10 229-30408 SPOOL REST ROD UPPER イトタテボウ (ウエ) (1) 11 229-31307 SPOOL REST ROD JOINT イトタテボウツギテ (1) 12 SM-4051405-SE SCREW M5 L=14 ナベコネジ M5 L=14 (2) 13 NM-6050001-SE NUT M5 ロッカクナット M5 (2) 14 229-30309 SPOOL REST ROD LOWER イトタテボウ (シタ) (1) 15 229-31208 THREAD GUIDE イトミチ (2) 16 WS-0510002-KN SPRING WASHER バネザガネ 5. 1X9. 2X1. 3 (2) 17 NM-6050001-SE NUT M5 ロッカクナット M5 (2) 18 NM-6160511-SE NUT M16X1.5 ロッカクナット M16X1.5 1シュ (1) 19 WP-1702600-SO WASHER 17X30X2.6 ヒラザガネ 17X30X2.6 (2) 20 WS-1643202-KR SPRING WASHER バネザガネ 16. 4X26. 6X3. 2 (1) 21 269-10059 THREAD GUIDE ARM ASM. 糸立案内腕 (組) 1 22 401-06583 THREAD GUIDE 糸立案内内台 (1) 23 401-06580 THREAD GUIDE UNDER BASE 糸立案内下台 (1) 24 401-06576 THREAD GUIDE ARM 糸立案内腕 (1) 25 401-06579 THREAD GUIDE ARM BASE 糸立案内腕基 (1) 26 SM-4041201-SC SCREW M4X0.7 L=12 なべ小ねじ M4X0.7 L=12 (2) 27 NM-6040002-SE NUT M4X0.7 六角ナット M4X0.7 2種 (2) 28 SM-4041201-SC SCREW M4X0.7 L=12 なべ小ねじ M4X0.7 L=12 (1) 29 SM-4042501-SC SCREW M4X0.7 L=25 なべ小ねじ M4X0.7 L=25 (1) 30 NM-6040002-SE NUT M4X0.7 六角ナット M4X0.7 2種 (2) - 39 - jintex.in

Page 45 — IP-100 PANEL COMPONENTS

23. IP-100 PANEL COMPONENTS IP-100 パネル関係 1.2 3 5 6 7 8 9 10 11 12 13 14 15 16 19 20 21 22 23 24 25 26 27 28 REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 401-22922 PANEL D ASSY IT-100 パネルD組 1 2 401-22923 PANEL E ASSY IT-100 パネルE組 1 3 401-06878 PANEL ASSY IT-100 パネル組 (1) 4 401-06879 PANEL PCB ASSY IT-100 パネル基板組 (1) 5 401-05700 FRONT PANEL フロントパネル (1) 6 401-06354 MEMBRANE SWITCH IT-100 メンブレンスイッチ (1) 7 401-05715 LCD COVER LCDカバー (1) 8 401-05720 LCD MODULE LCDモジュール (1) 9 ST-4030851-SN SCREW タッピンねじ D=3-24 L=8 (4) 10 401-05717 ONLINE INDICATOR 通信インジケータ (1) 11 401-09555 METAL FOIL SHEET 金属箔シート (1) 12 SM-4030401-SN SCREW M3 L=4 なべ小ねじ M3 L=4 (1) 13 401-05714 CONNECTOR COVER B USBカバー B (1) 14 401-05716 POWER INDICATOR 電源インジケータ (1) 15 401-05707 BACK PANEL バックパネル (1) 16 SV-4032001-SN SCREW 座付きタッピンねじ (4) 17 ST-4030851-SN SCREW タッピンねじ D=3-24 L=8 (1) 18 401-05713 CONNECTOR COVER A USBカバー A (1) 19 400-05848 D-SUB 9P COVER D-SUB 9P カバー (1) 20 401-05188 CORD EXIT COVER コード出口カバー (1) 21 401-23001 PANEL BRACKET パネルブラケット (1) 22 SV-4031001-SN SCREW 座付きタッピンねじ (4) 23 401-19704 CONVERTER_CABLE ASSY コンバータケーブル組 (1) 24 CM-5001000-03 CE LABEL CEラベル (1) 25 401-15767 TYPE LABEL DOC タイプラベル DOC (1) 26 400-24479 TYPE LABEL EOA タイプラベル EOA (1) 27 #03 400-55293 CF TYPE-D コンパクトフラッシュ タイプ-D 1 28 #04 400-55295 CF TYPE-D コンパクトフラッシュ タイプ-D 1 29 400-08168 OP SWITCH CABLE A ASSY オプションスイッチケーブルAクミ 1 NOTE(注記) #01...FOR SC-915 SC-915用 #02...FOR SC-916 SC-916用 #03...FOR SC-915 OPTIONAL PARTS SC-915用オプション部品 #04...FOR SC-916 OPTIONAL PARTS SC-916用オプション部品 - 40 - jintex.in

Page 46 — 24. SC-915/SC-916 TRANSMISSION COMPONENTS (1)

24. SC-915/SC-916 TRANSMISSION COMPONENTS (1) SC-915/SC-916 電装関係 (1) 47 A 44 46 49 45 43 50 22 21 5~8 10~12 9 1.35 A 31 13 15 17 29 26 32 33 34 38 41 37 36 14 16 20 23 24 25 28 19 27 4 18 39 42 40 - 41 - jintex.in

Page 47

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 #05 400-05951 CTL PCB A ASM. CTLキバンAクミ 1 2 #01 400-00056 FLT-T PCB A ASS'Y FLT-TキバンAクミ 1 3 #02 400-00046 FLT-S PCB A ASS'Y FLT-SキバンAクミ 1 4 400-05979 REGENERATIVE RESISTANCE A ASM. カイセイテイコウAグミ 1 5 #03 400-06000 REAR COVER A ASM. デンソウボックスウシロフタAクミ 1 6 #04 400-06001 REAR COVER 200V 1-PHASE ASM. デンソウボックスウシロフタ200V1クミ 1 7 #07 400-12697 REAR COVER A ASSY ウシロフタAクミ 1 8 #08 400-12698 REAR COVER B ASSY ウシロフタBクミ 1 9 400-15548 REAR COVER ウシロフタ 1 10 #01 CM-3001004-01 LABEL 3 (LARGE) デンゲキキケンラベル3 (ダイ) (1) 11 #02 CM-3001000-03 VOLTAGE WARNING LABEL(25) キケンデンアツケイコクシール (25) (1) 12 #02 CM-3004006-01 VOLTAGE CAUTION LABEL キケンデンアツケイコクシール (1) 13 HX-0022200-0B CABLE CLAMP クランプ (1) 14 SL-4040881-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 7 15 400-03451 CONTROL BOX コントロールボックス 1 16 M3801-476-000 TRANSMISSION BOX FITTING PLATE デンソウボックスストリツケイタ 1 17 401-54493 FAN ASSY ファンモータ組 1 18 HM-000800-10 SPACER スペーサ 6 19 HX-0033700-0B SPACER スペーサ 4 20 SL-6083092-TN SCREW ザガネツキ ロツクアナボルト 4 21 #06 WS-0410002-KN SPRING WASHER バネザガネ M4 4 22 #06 WP-0430801-SC WASHER 4.3X9X0.8 ヒラザガネ 4.3X9X0.8 4 23 M4206-461-000 WASHER ヒラザガネ 4 24 WP-0841601-SC WASHER 8.4X17.4X1.6 ゴムツキザガネ 4 25 NM-6080001-SC NUT M8X1.25 ロツカクナット M8 1シュ 8 26 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 6 27 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 1 28 SL-4040881-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 1 29 NM-3040520-SF FLANGE NUT M4 フランジナツト 4 30 SL-4044091-SE SCREW M4 L=40 ザガネツキ ナベコネジ 4 31 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 4 32 400-05987 PDD RELAY CORD A ASM. PDDリレーコードAクミ 1 33 400-05985 DC85 VOLT CORD A ASM. DC85ボルトコードAクミ 1 34 400-05986 DC33 VOLT CORD A ASM. DC33ボルトコードAクミ 1 35 #06 400-16451 CTL PCB A ASSY コントロールキバンAクミ 1 36 HX-0051100-00 WIRE SADDLE ワイヤサドル 2 37 400-06003 CTL CLAMP HOLDER PLATE CTLクランプウケイタ 1 38 400-15544 BTPM POWER CABLE ASSY BTPMデンゲンコードクミ 1 39 401-54493 FAN ASSY ファンモータ組 1 40 #06 400-05404 FAN MOTOR BRACKET ファンモータブラケット 1 41 #06 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 2 42 #06 SL-4033091-SC SCREW M3 X 0.5 L=30 ナベコネジ セムス M3X0.5 L=30 4 43 #06 400-13881 BTPM PCB A ASSY BTPMキバンAクミ 1 44 #06 400-13864 BTPM PCB HOLDER BOARD BTPMキバンサホエイタ 1 45 HX-0014700-OC SPACER スペーサ 2 46 #06 HX-0033900-00 STUD キバンパーツ 4 47 #06 HX-0059400-00 SPACER スペーサ 4 48 #06 SL-4040881-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 4 49 #06 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 4 50 #06 SM-9041050-SC SCREW M4X0.7 L=10 ロツカクボルト M4X0.7 L=10 4 NOTE(注記) #01...FOR USE IN JAPAN,JUS,EXPORT 日本、JUS、輸出(3相)用 (3-PHASE) #02...FOR EXPORT(1-PHASE),CE 輸出(単相)、CE用 #03...FOR SC-915 日本、JUS、輸出(3相)用 USE IN JAPAN,JUS,EXPORT (3-PHASE) #04...FOR SC-915 SC-915 EXPORT(1-PHASE),CE (単相)、CE用 #05...FOR SC-915 SC-915 SC-916 SC-916 #06...FOR SC-916 SC-916 #07...FOR SC-916 日本、JUS、輸出(3相)用 USE IN JAPAN,JUS,EXPORT (3-PHASE) #08...FOR SC-916 SC-916 EXPORT(1-PHASE),CE (単相)、CE用 - 42 - jintex.in

Page 48 — 25. SC-915/SC-916 TRANSMISSION COMPONENTS (2)

25. SC-915/SC-916 TRANSMISSION COMPONENTS (2) SC-915/SC-916 電装関係 (2) 31 32 41 41 41 39 38 40 40 34 36 40 21 22 33 23 24 35 1 29 25 30 19 3 9 28 17 11 16 13 17 11 16 14 19 26 27 20 12 8 7 6 5 15 10 18 4 2 37 43 jintex.in

Page 49

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 #06 400-06021 PWR CIRCUIT BOARD A ASM. PWRキバンAクミ 1 2 400-05980 PEDAL SENSOR UNIT A ASM. ペダルセンサーユニットAクミ 1 3 SM-8040802-TP SCREW M4X8 ペダルセンサーユニットAクミ (2) 4 400-05981 SENSOR FITTING PLATE A ASM. ペダルセンサーリツケバンAクミ (1) 5 M4006-461-000 SENSOR INSTALLING PLATE センサーリツケイタ (1) 6 EA-9500B01-00 CABLE BAND ゾクセンバンド (1) 7 M4001-461-000 PEDAL SENSOR BASE ペダルセンサーダイ (1) 8 M4002-461-000 PEDAL LEVER ペダルレバー (1) 9 M4004-461-000 PEDAL RING ペダルリング (1) 10 M4005-461-000 VOLUME LINK ボリュームリンク (1) 11 M2010-110-000 ADJUST NUT フミカエシアツ チヨーセツナット (2) 12 M4007-351-000 FRONT SPRING マエフミバネ (1) 13 M4008-351-000-A SPRING SHAFT A バネジクA (1) 14 M4009-351-000-A SPRING SHAFT B バネジクB (1) 15 SV-4030601-SR SCREW M3 L=6 ザツキタツピンネジ (2) 16 M4011-351-000 SPRING B フミカエシバネB (2) 17 M4012-351-000 ADJUST SCREW フミカエシチヨウセイネジ (2) 18 SM-4030801-SF SCREW M3X0.5 L=8 ナベコネジ M3X0.5 L=8 9 19 SL-4040881-SC SCREW M4 L=8 ザガネツキ M4 L=8 3 20 SL-4041681-SF SCREW M4 L=16 ナベコネジ セムス M4 L=16 21 #01 400-05975 AC INPUT 1-PHASE CORD A ASM. ACニュウリヨク1フアイコードAクミ 1 22 #03 400-05976 AC INPUT 1-PHASE CORD A ASM. ACニュウリヨク1フアイコードAクミ 1 23 #01 400-05990 FRONT COVER A ASM. デンソウボツクスエフタAクミ 1 24 #04 400-05992 FRONT COVER 200V 1-PHASE ASM. デンソウボツクスエフタ200V1クミ 1 25 400-05991 TRANSMISSION BOX FRONT COVER デンソウボツクスエフタ (1) 26 #04 CM-3001000-03 VOLTAGE WARNING LABEL(25) キンデンアツケイコウシール (25) (1) 27 #01 CM-3001004-01 LABEL 3 (LARGE) デンゲキキケンラベル3 (ダイ) (1) 28 HX-0040700-00 BUSH ブツシユ (1) 29 178-45009 CORD FITTING PLATE コードトメイタ (1) 30 SL-4042091-SC SCREW M4X0.7 L=20 ナベコネジ セムス M4X0.7 L=20 (2) 31 SL-4041091-SE SCREW M4 L=10 ザガネツキネジ (2) 32 SL-4040891-SC SCREW M4 L=8 ザガネツキネジ 3 33 #02 400-05977 AC INPUT 1-PHASE CORD CE ASM. ACニュウリヨク1フアイコードCEクミ 2 34 #02 CM-2001000-01 PE MARK LABEL PEマークシール 1 35 HX-0041000-0A STRAIN RELIEF BUSHING ストレーンリリーフブツシング 1 36 #05 E9567-319-000 EARTH MARK アース マーク 1 37 SL-4040891-SC SCREW M4 L=8 ザガネツキ ナベコネジ M4 L=8 6 38 HX-0018800-0D BUSH ブツシユ 1 39 400-06002 BOX HORIZONTAL COVER ボツクスヨコカバー 1 40 HX-0022200-0A CABLE CLAMP ゾクセンクランプ 4 41 HX-0051100-00 WIRE SADDLE ワイヤサドル 4 NOTE(注記) #01...FOR USE IN JAPAN,JUS,EXPORT 日本, JUS, 輸出(3相)用 #02...FOR CE CE用 #03...FOR EXPORT(1-PHASE) 輸出(単相)用 #04...FOR EXPORT(1-PHASE),CE 輸出(単相),CE用 #05...EXCEPT CE CEを除く #06...FOR SC-916(FROM REV.03) SC-916用(REV.03以降) - 44 - jintex.in

Page 50 — 26. SC-915/SC-916 ACCESSORIE PARTS COMPONENTS

26. SC-915/SC-916 ACCESSORIE PARTS COMPONENTS SC-915/SC-916 付属吕関係 REF.NO NOTE PART NO DESCRIPTION 品名 Qty 1 #01 400-05390 POWER CABLE JE ASM. デンゲンケーブルJEクミ 1 2 #03 401-13427 BOX ACCESSORIE PART A ASM. ボックスフゾクヒンAクミ 1 3 400-06010 CONNECTING ROD ASM. B レンケツボウB(クミ) 1 4 229-58458 CONNECTING ROD ASM. B レンケツボウB(クミ) 1 5 HF-0013010-00 TIMING LAG FUSE 10A タイムラグヒューズ 10A (1) 6 HF-0078020-PO FUSE 2A タイムラグヒューズ 2A (1) 7 MTS-HJ10003 BOLT モータ トリツケボルト (1) 8 NM-6080002-SC NUT M8 ロッカクナット M8 2シュ (2) 9 WP-0852086-SC WASHER M8 ヒラザガネ (2) 10 WS-0820002-KR SPRING WASHER M8 バネザガネ 8.2X15.4X2 (2) 11 SM-6084002-TN SCREW M8 L=40 ロッカクアナボルト M8 L=40 (1) 12 WS-0820002-KR SPRING WASHER M8 バネザガネ 8.2X15.4X2 (2) 13 WP-0841601-SC WASHER 8.4X17.4X1.6 ヒラザガネ 8.4X17.4X1.6 (1) 14 SK-3512001-SE WOOD SCREW D=5.1 L=20 マルモクネジ D=5.1 L=20 (2) 15 MAO-11532000 CORD STAPLE コードステツプル (5) 16 HX-0051000-00 OMEGALOCK オメガロック (1) 17 400-05988 HEAD FAN RELAY CORD A ASM. トウブFANチュウケイコードAクミ (1) 18 #04 M9034-580-0A0 GROUND CORD ASM. 100Vヨウアースコードクミ 1 19 #02 M9024-580-0A0 POWER CABLE ASM. 100V デンゲンケーブル 100Vヨウクミ 1 20 #05 M9017-580-0A0 POWER CABLE ASM. デンゲンケーブルクミ 1 21 #04 M9035-580-0A0 POWER SOURCE CORD ASM. 100Vヨウデンゲンコードクミ 1 NOTE(注記) #01: FOR CE用 #02: FOR EXPORT(1-PHASE) 輸出(単相)用 #03: EXCEPT CE CEを除く #04: FOR 3-PHASE (USE IN JAPAN,JUS) 3相(日本,JUS,輸出)用 #05: FOR 3-PHASE 3相 (USE IN JAPAN,JUS,EXPORT) - 45 - jintex.in

Page 51 — 27. ACCESSORIE PARTS COMPONENTS

27. ACCESSORIE PARTS COMPONENTS 付属品関係 1 3 5 4 6 2 7 12 10 8 9 11 19 17 13 14 23 20 18 15 16 22 REF.NO NOTE PART NO DESCRIPTION Qty 1 225-87174 ACCESSORIE BAG LZ-2290A付属品バッグ 1 2 225-96704 BOBBIN S ボビン S (1) 3 229-33204 SCREW DRIVER SMALL ドライバー (シヨウ) (1) 4 236-39701 KNEE LIFTER PRESSER ROD ヒザアゲオシボウ (1) 5 229-32800 ACCESSORIE BAG フゾクヒンバッグ (1) 6 B9102-057-000 WRENCH (3/32) ロッカクボースパナ 3/32 (1) 7 #02 229-58052 RUBBER HINGE ASM. ラバーヒンジ (クミ) 1 8 229-58003 FRAME BUBBER CUSHION ゴムヒンジサエコムザ (2) 9 229-26208 NAIL ゴムヒンジウチクギ (8) 10 229-26356 HINGE COMPL. ヒンジケツゴウ (2) 11 229-26505 WASHER トウブクツションザ (2) 12 229-26000 RUBBER CUSHION ゴムヒンジザ 1 13 #02 262-34005 VINYL COVER トウブビニールカバー 1 14 #02 MDP-500B1002 NEEDLE DPX5 #10-2 ハリ DPX5 #10-2 1 15 236-40006 SHEET ヌキキャップチュウイシート 1 16 #01 100-25906 SPACER オクリダイスペーサ 1 17 225-36502 TIMING GAUGE E タイミングゲージ E 1 18 141-01208 HEAD SUPPORT BAR 頭部支え棒 1 19 MDF-RX1200C0 NEW DEFRIX OIL NO.1 (200ML) デフレックスオイルNO. 1 (200ML) 1 20 B9121-012-0A0 OILER ASM. アブラサシ クミ 1 21 400-06323 JUKE GREASE A TUBE ジューキグリースAチューブ 1 22 225-03908 SPACER ハリイタスペーサー 1 23 #01 MC-1923007-52 NEEDLE 438 #75-2 ハリ (シュメツツ) 438 #75-2 1 NOTE(注記) #01...FOR LZ-2290A-SU-7, LZ-2290A-DU-7用 #02...VARIOUS NOS.FOR DESTINATIONS 仕向地により異なる 46 jintex.in

Page 52 — 28. COMMON PARTS FOR LZ-2290A-DS,LZ-2290A-DS-7,LZ-2290A-DU,LZ-2290A-DU-7

28. COMMON PARTS FOR LZ-2290A-DS,LZ-2290A-DS-7,LZ-2290A-DU,LZ-2290A-DU-7 REF NO NOTE PART NO DESCRIPTION 品 名 Qty 1 235-56053 NEEDLE ROD SUPPORT BASE D ASM. ハリボウジダイロ (クミ) (2) 2 235-56004 NEEDLE ROD METAL D ハリボウメタルD (1) 3 235-56301 SUPPORT BASE GUIDE SHAFT D ハリボウシジダイアツナイド (1) 4 235-56202 NEEDLE ROD CRANK ROD GUIDE D ハリボウクランクロツドアンナイD 1 5 235-56103 NEEDLE ROD HOLDER D ハリボウダキD 1 6 235-58109 INNER HOOK STOPPER D ウチガマトメD 1 7 400-03609 BOBBIN CASE D3 COMPL. ボビンケースD3 (ケツゴウ) 1 8 400-03610 BOBBIN CASE D3 ASM. ボビンケースD3 (クミ) 1 9 235-57259 Hook COMPL. D カマケツゴウD 1 10 #01 SS-4120915-SP SCREW 3/16-28 L=9 ナベネジ 3/16-28 L=9 2 11 235-58208 FEED D オク リダイD 1 12 235-58000 FEED BASE D オクリダイD 1 13 #01 235-58406 VERTICAL FEED LINK SHAFT D ジヨウゲオクリリンクジヨD 1 14 #01 400-10264 VERTICAL FEED LINK ジヨウゲオクリリンク 1 15 235-57101 OIL SEAL COLLAR D カマクドジユウオイ ルカラーD 1 16 235-57051 BEARING D ASM. カマジク マエジクウケD (クミ) 1 17 SS-8110410-TP SCREW 11/64-40 L=3.5 トメネジ 11/64-40 L=3.5 2 18 235-35255 Hook SHAFT BEARING ASM. カマジクジクウケケミ 1 19 SS-8110510-SP SCREW 11/64-40 L=5 トメネジ 11/64-40 L=5 2 NOTE(注記) #01...FOR LZ-2290A-DS, LZ-2290A-DS-7 #01...FOR LZ-2290A-DS, LZ-2290A-DS-7用 - 47 - jintex.in

Page 53 — 29. CB TYPE (1) (PRESSER FOOT COMPONENTS)

29. CB TYPE (1) (PRESSER FOOT COMPONENTS) CB 仕様 (1) (押え関係) REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 400-03542 WIDE KNIFE PRESSER ASM. ハバヒロメスツキオサエ (クミ) (1) 2 400-03543 PRESSER (UPPER) オサエ (ウエ) (1) 3 400-03544 PRESSER (LOWER) WIDE オサエ (シタ) ヒロハバ (1) 4 400-03545 FINGER GUARD ユビガード (1) 5 400-03547 FIXING PLATE (WIDE) COMPL. メスコティイタ (ヒロハバ) ケツゴウ (1) 6 400-03546 KNIFE FIXING PLATE (WIDE) メスコティイタ (ヒロハバ) (1) 7 400-03553 KNIFE STOPPER SCREW メストメネジ (2) 8 114-34206 THREAD CUTTER KNIFE ウワイトキリ メス (2) 9 400-03554 STOPPER SCREW メスコティイタトメネジ (2) 10 100-56109 PRESSER PIN A オサエピン A (1) 11 B1525-582-000 SPRING オサエバネ (1) 12 SS-6090810-SP SCREW 9/64-40 L=7.5 ヒラネジ 9/64-40 L=7.5 (1) 13 #01 400-03549 NARROW KNIFE PRESSER ASM. ホンハバメスツキオサエ (クミ) 1 14 400-03543 PRESSER (UPPER) オサエ (ウエ) (1) 15 400-03545 FINGER GUARD ユビガード (1) 16 400-03552 PRESSER LOWER (NARROW) オサエシタ (ホンハバ) (1) 17 400-03551 FIXING PLATE (NARROW) COMPL. メスコティイタ (ホンハバ) ケツゴウ (1) 18 400-03550 KNIFE FIXING PLATE (NARROW) メスコティイタ (ホンハバ) (1) 19 400-03553 KNIFE STOPPER SCREW メストメネジ (1) 20 114-34206 THREAD CUTTER KNIFE ウワイトキリ メス (1) 21 400-03554 STOPPER SCREW メスコティイタトメネジ (2) 22 225-47806 PRESSER PIN オサエピン (1) 23 B1525-582-000 SPRING オサエバネ (1) 24 SS-6090810-SP SCREW 9/64-40 L=7.5 ヒラネジ 9/64-40 L=7.5 (1) NOTE(注記) #01...OPTIONAL PARTS オプション部品 - 48 - jintex.in

Page 54 — 30. CB TYPE (2) (THREAD HOLDER & AIR COMPONENTS)

30. CB TYPE (2) (THREAD HOLDER & AIR COMPONENTS) CB 仕様 (2) (糸保持・エアー関係) 38 8 5 31 7 3 4 44 10 6 2 9 32 19 12 11 22 1 18 17 B 28 43 16 14 A 21 15 20 13 33 39 42 27 35 46 23 29 25 24 45 41 26 40 34 36 30 B A 47 - 49 - jintex.in

Page 55

REF.NO NOTE PART NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 PJ-0325260-01 114-29305 400-03536 400-03537 114-29008 114-28505 SS-7110840-SP PJ-3090405-01 400-03538 114-27705 400-03562 400-03565 PV-1352070-00 PV-1305390-00 PJ-3010852-01 PJ-3040652-01 PJ-3010605-01 PX-0505010-00 SL-4850891-SC PJ-0251000-02 SL-4030891-SC NM-6030001-SC 400-03560 PF-0152030-A0 PF-9020050-00 PJ-3080800-01 F1012-003-0A0 B1155-771-000 SK-3412000-SC 400-03564 SS-7110840-SP SS-4110715-SP SK-3412000-SC 114-28802 PJ-3010800-01 HX-0028900-00 BT-1601001-Z0 BT-0400251-EB BT-0600401-EB BT-0800501-EB PX-9500090-00 BT-0800501-EB BT-0800501-EB BT-0600401-EB BT-0800501-EB BT-1601001-Z0 D8204-555-D00 DESCRIPTION HOSE NIPPLE CLAMP HEAD CLAMP BASE A CLAMP BASE B CLAMP CYLINDER CLAMP BALL SCREW 11/64-40 L=7.8 ELBOW UNION HEAD COVER HEAD BUSH ELECTROMAGNETIC VALVE COMPL. FITTING PLATE 3-PORT ELECTROMAGNETIC VALVE 3-PORT ELECTROMAGNETIC VALVE HALE UNION ELBOW UNION 6XPT1/4 HALE UNION SILENCER SCREW M2.5 L=8 PLUG R 1/8 SCREW M3X8 NUT M3 REGULATOR ASM. FILTER REGULATOR REGULATOR BRACKET UNION Y NOZZLE ASM. CUSHION WOOD SCREW D=4.1 L=20 CORD ASM. SCREW 11/64-40 L=7.8 SCREW 11/64-40 L=7 WOOD SCREW D=4.1 L=20 DUST BAG REDUCER BEADE BAND TUBE URETHANE HOSE BLACK TUBE VINYL TUBE VINYL TUBE TUBE VINYL TUBE UNION Y TUBE DRAWER STOPPER 品 名 Qty ホースニップル 1 クランプヘッド 1 クランプダイA 1 クランプダイB 1 クランプ シリンダ 1 クランプ ボール 1 マルヒラネジ 11/64-40 L=7.8 2 45 ドエルユニオン 1 ヘッドカバー 1 ヘッドブッシュ 1 ベンツケツコウ 1 デンジベントリツケイタ (1) 3ポートデンジベン (1) 3ポートデンジベン (1) ハーフユニオン (1) エルボユニオン (1) ハーフ ユニオン (1) ショウユニオン (1) ザガネツキネジ M2.5 L=8 (2) プラグ R 1/8 (1) ナベコネジ セムス M3 L=8 (2) ロツカクナツト M3X0.5 1シュ (2) レギュレーター クミ 1 フイルタツキ ゲンアツペン (1) レギュレーターブラケツト (1) ユニオン ワイ 1 エアーノズル クミ 1 ソクメンカバー トメネジ クツシヨン 1 マルモクネジ D=4.1 L=20 2 デンシコードクミ 1 マルヒラネジ 11/64-40 L=7.8 2 ナベネジ 11/64-40 L=7 1 マルモクネジ D=4.1 L=20 2 ダストバッグ 1 レデユーサー 1 バンド 1 ビニールホース トウメイ 0.4 ウレタンホース クロ 1.5 チューブ 0.14 チューブ 1 チューブ 0.06 チューブ 0.3 チューブ 0.13 チューブ 1.3 ブランチワイ 1 ビニールホース トウメイ 0.15 ヒキジストツパー 2 - 50 - jintex.in

Page 56 — 31. CB TYPE (3) (WIPER MECHANISM COMPONENTS)

31. CB TYPE (3) (WIPER MECHANISM COMPONENTS) CB 仕様 (3) (ワイパー関係) - 51 - jintex.in

Page 57

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 400-03534 WIPER FITTING BASE ASM. ワイパートリツケダイ (クミ) 1 2 114-25907 WIPER COVER ワイパーカバー 1 3 SL-4030631-SC SCREW M3X6 ザガネツキ ナベコネジ M3 L=6 1 4 SD-0650321-TP HINGE SCREW D=6.5 H=3.2 ダンネジ D=6.5 H=3.2 1 5 NS-6090310-SP NUT 9/64-40 ロツカクナツト 9/64-40 1 6 229-56106 WIPER LINK A ワイパーリンクA 1 7 400-03529 WIPER LINK B ワイパーリンクB 1 8 RE-0250000-KO E-RING 2.5 Eガタトメワ 2.5 1 9 229-56908 WIPER LINK B HINGE SCREW ワイパーリンクBダンネジ 1 10 229-56205 WIPER HINGE SCREW COLLAR ワイパーダンネジカラー 1 11 229-56304 WIPER SPRING ワイパーバネ 1 12 NS-6110310-SP NUT 11/64-40 ロツカクナツト 11/64-40 1 13 229-55900 WIPER RUBBER A ワイパーゴムA 1 14 229-56007 WIPER RUBBER B ワイパーゴムB 1 15 401-06937 WIPER SOLENOID ASM. ワイパーソレノイド(組) 1 16 229-57104 WIPER SOLENOID SHAFT ワイパーソレノイドジク 1 17 HA-0060000-0A SWITCH スイツチ 1 18 Hw-2003900-00 ELECTRIC WIRE ビニールデンセン 17-0.16 シロ 0.04 19 Hw-5F18S12-28 TWO-CORE CORD キヤブタイヤコード 0.18X19X2 1.7 20 400-03528 WIPER BASE ワイパーダイ 2 21 SS-8080310-TP SCREW 1/8-44 L=2.8 トメネジ 1/8-44 L=2.8 4 22 SL-4030641-SE SCREW ザガネツキネジ 2 23 Hk-0346400-0B PIN CONTACT ピンコンタクト 1 24 400-03539 WIPER ワイパー 1 25 SS-6090540-SP SCREW 9/64-40 L=5.0 ヒラネジ 9/64-40 L=5 1 26 229-56809 WIPER COLLAR ワイパーカラー 1 27 400-03540 WIPER SHAFT ASM. ワイパーシヤフトクミ 1 28 229-57203 WIPER LINK COLLAR ワイパーリンクカラー 1 29 114-29107 SLIDE SPRING スライドスプリング 1 30 114-22706 STOPPER SPRING B ラチエツトストツパー バネB 1 31 400-03530 RATCHET COMPL. ラチエツトケツコウ 1 32 114-25451 FOLLOWER ASM. フォロワ-クミ 1 - 52 - jintex.in

Page 58 — 32. SPECIAL ORDER PARTS LZ-2290A (1)

32. SPECIAL ORDER PARTS LZ-2290A (1) 特别注文部品 LZ-2290A (1) 1 2 3 4 5 6 7 79 8 9 10.21 44 22 29 46 47 28 83 86 85 71 72 73 74 75 76 77 78 93 89 90 91 JUKI M097 53 jintex.in 2 3 42.43 37 36 35 30~34 59 58 56.57 50 54 49 51 48 52 53 55 66 60.61 64 63 62 65 64 11 18 14 16 12 13 19 17 15 20 67 69 68 70 80.81 24 26 23 27 25 92 82 84 87 88

Page 59

REF.NO NOTE PART NO DESCRIPTION 品 名 Qty 1 225-35801 TIMING GAUGE タイミングゲージ 1 2 225-86705 TIMING GAUGE タイミングゲージ R 1 3 225-35900 TIMING GAUGE RIGHT タイミングゲージ D 1 4 225-36403 TIMING GAUGE D タイミングゲージ E 1 5 225-36502 TIMING GAUGE E オサエレンケツアッシ 1 6 B1551-586-000 PRESER FOOT JOINT マルヒラネジ 9/64-40 L=8.5 1 7 SS-7090910-SP PRESSER BAR 1 8 D1501-583-H00 PRESSER BAR オサエボー 1 9 D1502-583-H00 PRESSER ADJUSTING SPRING オサエチョウセツバネ 1 10 B1505-227-00A KNIFE UNIT メスユニット 1 11 225-56054 FIXED KNIFE コテイ メス (1) 12 225-56302 CLAMP PLATE ASM. クランプイタ (クミ) (1) 13 225-56450 SLIDING PLATE スベリイタ (1) 14 225-56609 DRIVING BASE ドウメスダイ (1) 15 225-56708 DRIVING BASE ドウメスダイ (1) 16 225-56807 SCREW 9/64-40 L=5 サラネジ 9/64-40 L=5 (2) 17 SS-1090510-SP SCREW 9/64-40 L=4.0 ヒラネジ 9/64-40 L=4 (2) 18 SS-6090420-SP SCREW 9/64-40 L=6.8 マルヒラネジ 9/64-40 L=6.8 (2) 19 SS-7090710-SP DRIVING KNIFE ASM. ドウメス (クミ) (1) 20 225-56153 SPRING オサエチョウセツバネ 1 21 111-62104 DRIVER リタイオウハリウケ (クミ) 1 22 B9101-490-000 NEEDLE HOLDER ASM. リタイオウハリウケ 1 23 225-25455 NEEDLE GUARD ハリマハリタイ (1) 24 225-25406 SCREW M3X0.5 L=6 ロツカクアナボルト M3X0.5 L=6 (1) 25 SM-6030602-TP WASHER M3 ヒラネジ 3.1X5.9X0.7 (1) 26 WS-0310702-KS SPRING WASHER バネザガネ 3 (2) 27 WP-0320500-SC WASHER M3 ヒラガネ コガタマル M3 (1) 28 100-25906 SPACER イスペーサ 1 29 225-03908 SPACER ハリイタスペーサ 1 30 225-25059 HOOK COMPL. V(LASTIC HOOK) カマケツツゴウV (プラスチツクガマ) 1 31 225-26677 HOOK COMPL. V(HARD POINT) カマケツツゴウV (ハードポイント) 1 32 225-26578 HOOK COMBINATION (HARD POINT) カマケツツゴウV (ハードポイント) 1 33 225-25257 HOOK COMPL. V(PLASTIC HOOK) カマケツツゴウV (プラスチツクガマ) 1 34 225-25752 HOOK COMPL. V(PLASTIC HOOK) カマケツツゴウV (プラスチツクガマ) 1 35 225-25968 OUTER HOOK V. ソトガマV 1 36 225-25919 ROTATING HOOK V ASM. ソトガマVクミ (1) 37 235-03501 OUTER HOOK V. オサエイ-V-S (1) 38 100-33009 INNER HOOK V. ウチガマオサエイ V-S (1) 39 225-26206 HOOK GIB SCREW ウチガマオサエ トメネジ (2) 40 100-33108 REVERSE PLATE V. ウライタV (1) 41 225-26008 HOOK COUNTER BALANCE SCREW ウライタ トメネジ (1) 42 SS-8110422-TP INNER HOOK V. ウチガマV (1) 43 SS-8110520-TP SCREW 11/64-40 L=4.5 トメネジ 11/64-40 L=4.5 (2) 44 225-07701 THREAD RACK RIGHT. ハリホワイトカケ R (1) 45 225-03353 SAFETY PLATE ASM. アンゼンブレート (ケツゴウ) 1 46 235-22550 NOT TURN BOBBIN CASE ASM. ムカイテンボビンケースクミ 1 47 235-23004 NOT TURN BOBBIN. ムカイテンボビン 1 48 235-23152 NOT TURN BOBBIN HOOK COMPL. V. ムカイテンボビンガマケツゴウV 1 49 225-25919 OUTER HOOK V. ソトガマV 1 50 235-03501 INNER HOOK PRESSER V-S. ウチガマオサエイ-V-S (1) 51 100-33009 HOOK GIB SCREW. ウチガマオサエ トメネジ (2) 52 235-23202 NOT TURN BOBBIN INNER HOOK V. ムカイテンボビンウチガマV (1) 53 100-33108 HOOK COUNTER BALANCE SCREW. ウライタ トメネジ (1) 54 225-26008 INNER HOOK V. ウチガマV (1) 55 SS-8110422-TP SCREW 11/64-40 L=4. トメネジ 11/64-40 L=4 (2) 56 #01 235-02958 HOOK CONNECTION K. カマケツツゴウK 1 57 #02 235-02958 HOOK CONNECTION K. カマケツツゴウK 1 58 235-03709 OUTER HOOK S. ソトガマS (1) 59 235-03808 INNER HOOK S. ウチガマS (1) 60 #01 235-03907 INNER HOOK PRESSER S. オサエイス (1) 61 #02 235-03006 INNER HOOK PRESSER K. オサエイク (1) 62 235-04004 INNER HOOK PRESSER K. オサエイク (1) 63 235-04103 BACK PLATE S. ウライタS (1) 64 235-04301 INNER HOOK PRESSER SETSCREW S. ウチガマオサエトメネジS (3) 65 235-04400 OUTER HOOK SETSCREWS. ソトガマトメネジS (2) 66 235-04657 BOBBIN CASE WITH SPRING. ボビンケースクウテンボウシバネ (1) 67 235-34951 R FEED KITS. Rオクリキット (1) 68 235-34902 FEED BASE SHAFT R. オクリダイジクR (1) 69 225-19706 FEED BASE. オクリダイ (1) 70 100-26508 LINK PIN. ジヨージオクリリンク (1) 71 198-00903 LC-601-1/ LATCH LEVER. LC-601-1/ ラツチレバー 1 72 198-01000 LC-602-2/ LATCH. LC-602-2/ ラツチ 1 73 198-01307 SMS-801-B/ SETSCREW PICK-UP. SMS-801-B/ トメネジツマミ 1 74 198-01109 LSP-4/ LATCH SPRING. LSP-4/ ラツチスプリング 1 75 198-01208 LFP-1/ LATCH PIN. LFP-1/ ラツチピン 1 76 198-01406 TSP-604-B/ TENSION SPRING. TSP-604-B/ チヨウシバネ 1 77 198-01505 SMS-608-B/ TENSION SCREW. SMS-608-B/ トメネジチヨウシバネ 1 78 198-01604 BOBBIN. ボビン 1 79 225-24201 REVERSE PLATE. ウライタV 1 80 225-24805 REVERSE PLATE V. ウライタV 1 81 225-26206 INNER PRESSER V-S4. ウチガマオサエイ-V-S4 1 82 235-03303 OP SWITCH CABLE A ASM. OPスイッチケーブルA クミ 1 83 400-17095 THREAD TENSION DISK ASM. イトチョウシクミ (クミ) 1 84 400-17095 SMARTMEDIA CARD. スマートメディアカード 1 85 HX-0057500-00 PRESSER FOOT ASM. オサエ (クミ) 1 86 #03 225-91564 FEED DOG. オクリバ 1 87 #03 100-64004 THROAT PLATE ASM. ハリイタ クミ 1 88 #03 MAM-09700BA0 FAGOTTING FOLDER ASM. ファゴツト ウワマキホルダー クミ 1 89 #03 SS-5110710-SP SCREW 11/64-40 L=7 トラスネジ 11/64-40 L=7 2 90 #03 MAM-097000A0 FAGOTTING FELLER. ファゴツトヌイホルダー クミ 1 91 400-16408 HOOK GIB VS. フツクギブ 1 92 400-91888 FAN RELAY CABLE. フアンリレーコード (LZ用) 1 93 NOTE(注記) #01...FOR INNER HOOK S. 内釜S用 #02...FOR INNER HOOK K. 内釜K用 #03...FOR LZ-2290A-SR-7用 LZ-2290A-SR-7用 - 54 - jintex.in

Page 60 — 33. SPECIAL ORDER PARTS LZ-2290A (2)

33. SPECIAL ORDER PARTS LZ-2290A (2) 特别注文部品 LZ-2290A (2) 9 10 7 13 2 5 12 8 11 3 4 1 16 15 14 18 REF NO NOTE PART NO DESCRIPTION 品名 Qty 1 400-23431 HOOK COOLING UNIT カマレイクキャクユニット (1) 2 400-23432 FILTER REGULATOR ASM. フィルターレギュレータ-クミ (1) 3 PV-0151220-00 FINGER VALVE フィンガバルブ (1) 4 PF-0551060-A0 FILTER REGULATOR フィルタレギュレータ (1) 5 PF-9020050-00 REGULATOR BRACKET レギュレータブラケット (1) 6 PJ-0251000-03 PLUG プラグ (1) 7 400-23433 PIPE BRACKET ASM. パイプブラケットクミ (1) 8 400-23434 PIPE BRACKET パイプブラケット (1) 9 400-23435 BLOWING PIPE ブローイングパイプ (1) 10 110-45408 WIRE HOLDER A ワイヤ オサエ A (1) 11 BT-0400251-EB URETHANE HOSE BLACK ウレタンホース クロ (1) 12 SS-4110715-SP SCREW 11/64-40 L=7 ナベネジ 11/64-40 L=7 (2) 13 SK-3412001-SE WOOD SCREW D=4.1 L=20 カマト リツケビス (2) 14 SS-4111215-SP SCREW 11/64-40 L=12 ナベネジ 11/64-40 L=12 (2) 15 WP-0450801-SD WASHER 4.5X10X0.8 ヒラザガネ 4.5X10X0.8 (2) 16 B4122-804-000 ROLLER ヌノダイ ストツパー コロ (2) 17 MA-0115320-00 STAPLE ステツプル (2) 18 EA-9500B01-00 CABLE BAND ソクセンバンド (2) - 55 - jintex.in

Page 61 — 34. SPECIAL ORDER PARTS LZ-2290A (3)

34. SPECIAL ORDER PARTS LZ-2290A (3) 特别注文部品 LZ-2290A (3) REF.NO NOTE PART NO DESCRIPTION Qty 1 400-25920 TWO NEEDLES BAR SET 2ホンハリセット (1) 2 400-25762 THREAD TENSION ASM. イトチョウシクミ (1) 3 400-25763 TENSION BASE PLATE テンション ベース イタ (1) 4 225-28764 PRE-TENSION CONTROLLER ASM. プリテンション (クミ) (1) 5 400-25764 TWO NEEDLES CLAMP ASM. 2ハリ ボウ クミ (1) 6 400-99885 NEEDLE CLAMP ASM. ハリトメ クミ (1) 7 400-25768 GUIDE BLOCK R スライドコマ ヒダリ (1) 8 400-25767 GUIDE BLOCK R スライドコマ ミギ (1) 9 400-25765 NEEDLE CLAMP ハリトメ (1) 10 400-25766 TWO NEEDLES CLAMP PLATE 2ハリ クランプ イタ (1) 11 SS-4060310-SP SCREW 3/32-56 L=2.5 ナベネジ 3/32-56 L=2.5 (2) 12 SS-8080410-TP SCREW 1/8-44 L=3.5 トメネジ 1/8-44 L=3.5 (2) 13 B1401-380-000 NEEDLE BAR ハリボー (1) 14 400-25769 GUIDE BLOCK SCREW スライドコマネジ (1) 15 400-25913 THREAD TENSION ASM.C イトチョウシ クミ (1) 16 235-47557 THREAD TENSION T COMPL. イトチョウシT (ケツゴウ) (2) 17 225-28509 FELT イトチョウシサラフェルト (4) 18 229-21407 ROTATION STOPPER イトチョウシザラカイテンドメ (1) 19 235-37665 THREAD TENSION ROD BASE ASM. イトチョウシボウダイ (クミ) (1) 20 235-37756 THREAD TENSION ROD COMPL. イトチョウシボウケツゴウ (1) 21 400-25915 THREAD TENSION PIN イトトルメピン (1) 22 236-26005 TENSION NUT イトチョウシナツト (1) 23 B3129-012-A00 THREAD SPRING イトチョウシバネ A (1) 24 SS-8090670-SP SCREW 9/64-40 L=5.5 トメネジ 9/64-40 L=5.5 (1) 25 RO-1331701-00 RUBBER RING Oリング (1) 26 100-06005 TENSION DISC HOLDER イトチョウシザラ オサエ (1) 27 235-38309 THREAD TAKE-UP SPRING イトトリバネ (1) 28 400-25923 TWO NEEDLES BAR SET INSTRUCTIO 2ホンハリセットトリアツカイセツメイショ (1) 29 SS-6620730-SP SCREW 3/16-32 L=7.0 ヒラネジ 3/16-32 L=7 (1) - 56 - jintex.in

Page 62 — 35. LIST FOR INFORMATION OF CHANGE

35. LIST FOR INFORMATION OF CHANGE 変更情報リスト As to the place changed, refer to the corresponding Rev. No. When previous parts (Obsoleted part) and new parts (Added parts) are not interchangeable with each other: In this case, even obsoleted parts can be ordered with the obsoleted part number, so select the parts with changed dates and place your orders. 変更箇所は、該当Rev. No. をご参照ください。 部品の互換性がない変更の場合は、削除された品番でも、ご注文できます。 40003523 No. 1361-13 Rev. No. *A: Added parts追加部品/D: Obsoleted parts削除部品/E: Erratum訂正 Rev. No. Page 頁 Ref. No. Parts No. 品 番 Rev. No. Page 頁 Ref. No. Parts No. 品 番 D 13 46 14 293-42409 - 57 - jintex.in

Page 67

NUMERICAL INDEX OF PARTS 索引 PART NO PAGE REF PART NO PAGE REF PART NO PAGE REF PART NO PAGE REF 品番 頁 NO 品番 頁 NO 品番 頁 NO 品番 頁 NO 400-10261 20 30 400-17008 16 43 401-25489 10 16 400-10262 20 31 400-17100 2 22 401-25483 12 70 400-10264 19 400-17101 2 23 401-39216 12 34 400-10264 47 14 400-17102 2 24 401-49234 12 26 400-10268 12 12 400-17103 2 25 401-49235 8 2 400-10269 12 13 400-18430 12 73 401-49236 8 1 400-10270 12 16 400-20454 4 88 401-49239 8 33 400-10271 12 17 400-21933 4 39 401-49240 34 41 400-10272 14 5 400-22407 2 63 401-49245 34 45 400-10273 14 31 400-22407 16 16 401-49244 12 20 400-10276 12 23 400-22407 34 46 401-49245 12 21 400-10278 8 3 400-23431 55 1 401-49251 12 8 400-10280 26 18 400-23432 55 2 401-49252 22 7 400-10281 6 36 400-23433 55 7 401-49253 22 9 400-10282 20 29 400-23434 55 8 401-49253 22 10 400-10283 20 4 400-23435 55 9 401-54492 42 17 400-10286 16 24 400-24479 40 26 401-54492 42 39 400-10287 8 5 400-24644 4 54 401-60261 6 3 400-10287 16 25 400-25762 56 2 401-60262 22 20 400-10288 16 26 400-25763 56 3 401-75861 34 1 400-10289 8 7 400-25764 56 5 401-76805 34 64 400-10289 16 27 400-25765 56 9 400-10290 24 1 400-25766 56 10 400-10295 24 11 400-25767 56 8 400-10296 6 62 400-25768 56 7 400-10297 6 61 400-25915 56 14 400-10298 8 31 400-25920 56 21 400-10303 22 6 400-25923 56 28 400-10307 26 2 400-26835 4 28 400-10311 12 2 400-26836 4 87 400-10312 12 65 400-28014 6 18 400-10313 12 11 400-28294 4 24 400-10314 22 2 400-28463 4 3 400-10315 6 59 400-35589 4 83 400-10316 22 1 400-37008 4 56 400-10318 12 7 400-50457 12 39 400-10321 27 2 400-50598 34 42 400-10322 6 67 400-55293 40 27 400-10324 6 2 400-55295 40 28 400-11123 2 5 400-56873 6 42 400-11144 4 35 400-70531 10 17 400-11345 4 1 400-70532 6 41 400-11424 20 42 400-91888 54 93 400-11831 16 1 400-99885 56 6 400-11832 16 2 401-05188 40 20 400-11833 16 23 401-05707 40 15 400-11836 16 18 401-05713 40 13 400-11837 16 29 401-05714 40 18 400-11838 16 28 401-05715 40 7 400-11839 16 7 401-05715 40 13 400-11840 16 19 401-05716 40 14 400-11841 16 46 401-05717 40 10 400-11842 16 47 401-05720 40 8 400-11843 16 15 401-06354 40 6 400-11844 18 10 401-06576 39 24 400-11846 18 10 401-06579 39 25 400-11847 18 1 401-06580 39 23 400-11848 18 2 401-06583 39 22 400-11849 18 6 401-06937 36 17 400-11850 12 72 401-06937 52 15 400-12697 42 7 401-08063 26 4 400-12698 42 8 401-08064 26 5 400-13595 34 26 401-08879 40 3 400-13864 42 44 401-08880 40 4 400-13881 42 43 401-09555 40 11 400-14837 4 37 401-13427 45 2 400-15494 6 27 401-15767 40 25 400-15544 42 38 401-16677 4 85 400-15548 42 9 401-19704 40 23 400-16039 18 14 401-20730 20 28 400-16408 54 92 401-22922 40 1 400-16451 42 35 401-22923 40 2 400-17095 54 84 401-23001 40 21 - 62 - jintex.in
