Siruba C007K Attachments — Part Book

Siruba C007K Attachments — parts catalog

Page 16 (diagram): This page displays a diagram of sewing machine parts for the CL-K series, including various components labeled with part numbers and reference indicators.
Page 17 (diagram): This page displays a diagram of various machine parts including brackets, screws, nuts, washers, and chains, with labels and reference numbers for identification.
Page 18 (diagram): This page displays a diagram of various machine parts for the CQA-K series, including components labeled CQA04K, CQA02K, CQA09-A, CQA14K, CQA13, CQA09, CQA11, CQA03K, and CQA12K, along with associated hardware like SM480, MQ38*2, WM601, WM641, NM410, SM131*2, SM620, SK250, SM532*2, and SM411*2.
Page 19 (diagram): This page displays a diagram of sewing machine parts for the CQA-K series, including parts like MXXXXK, SM031, CQA08K, PXXXX, EXXXX, MT01A, CQA09K, SK222, DXXXX, HXXXX, MA81, CQA01K, SM432, CQA05K, CQA06K.
Page 20 (diagram): This page displays a diagram of sewing machine parts for the C007K/C007KD and C858K/C858KD series, specifically the CQ-K parts group. It includes various part numbers and their corresponding labels within the diagram.
Page 21 (diagram): This page displays a diagram of various parts for the SIRUBA CR-K series sewing machine, including components like CR305, CR306-A, CR307-E, and CR301, along with their associated part numbers and references.
Page 22 (diagram): This page displays a diagram of various machine parts for the Siruba CR-K series, including components like CR321, JA048, OT2602, and TU20P series parts, along with their corresponding part numbers and references.
Page 23 (diagram): This page displays a diagram of various parts for the SIRUBA CR-K series sewing machines, including components like UT54J-2, JA025, UT54J-A, and others, with reference numbers and part names.
Page 24 (diagram): This page displays a diagram of sewing machine parts, including various components labeled with part numbers and reference indicators. It is part of a larger series for C007K/C007KD and C858K/C858KD models, specifically for the CRL-K group.
Page 25 (diagram): This page displays a diagram of machine parts for the SIRUBA C007K/C007KD C858K/C858KD CRL-K series, with part numbers and references indicated.
Page 26 (diagram): This page displays a diagram of various parts for the CRL-K series, including components like AP604, CR47D, FD161-1-E, and TU20P series parts, along with their associated part numbers and descriptions.
Page 27 (diagram): This page displays a diagram of the CRL-K series parts, including various components like the lift presser foot, loop trimmer, and top cutter, along with their corresponding part numbers and references.
Page 28 (diagram): This page displays a diagram of sewing machine parts for models C007K/C007KD and C858K/C858KD, part of the CW-K series. It includes various components labeled with part numbers and references.
Page 29 (diagram): This page displays a diagram of sewing machine parts for the CW-K series, specifically for models C007K/C007KD and C858K/C858KD. It includes part numbers and references for various components.
Page 30 (diagram): This page displays a diagram of sewing machine parts, including various screws, brackets, and components labeled with part numbers and references.

Page 16 — PARTS LIST

Siruba C007K Attachments parts on page 16
Ref	Part number	Part name	Qty
	CL22K-A1	CL21+CL22K+CL31*2
	CL22K-A2	SM4912+NM4102
	CL46-E	CL46-E
	CL31	CL31
	SM492	SM492
	CL30	CL30
	NM410	NM410
	SM472	SM472
	CL33	CL33
	CL34	CL34
	SM682	SM682
	VCL41-A	VCL41-A
	HE37-E	HE37-E
	SM139*2	SM139*2
	HE37	HE37
	VCL41	VCL41
	OR070	OR070
	NM610	NM610
	CL48	CL48
	NM511	NM511
	NM511	NM511
	LF208-D	LF208-D
	LF210*3	LF210*3
	LF211*6	LF211*6
	LF209*6	LF209*6
	CL44	CL44
	LF210*3	LF210*3
	LF211*6	LF211*6
	LF209*6	LF209*6
	CL45F	CL45F
	LF208	LF208
	SK373*3	SK373*3
	SM681	SM681
	CL25-E	CL25-E
	SM611*2	SM611*2
	SM432	SM432
	CP103	CP103
	CL25	CL25
	CL59	CL59
	CL32	CL32
	CL28E	CL28E
	SM440	SM440
	NM410	NM410
	SM611	SM611
	CL29	CL29
	CL46	CL46
	BR4081B	BR4081B
	CL47	CL47
	CL48	CL48
	CL49	CL49
	CL37F	CL37F
	SK373*3	SK373*3
	CL38	CL38
	CL27	CL27
	EM123	EM123
	CL36	CL36
	CL39H	CL39H
	CL63	CL63
	SM502*2	SM502*2
	SM470	SM470
	CL65	CL65
	SM402*3	SM402*3
	EM090	EM090
	SM461*3	SM461*3
	CL53	CL53
	CL52P	CL52P
	CL52R	CL52R
	CL42	CL42
	CL43	CL43
	CL24E	CL24E
	CL26	CL26
	CL35	CL35
	SM520*2	SM520*2
	WM800	WM800
	CL64	CL64
	SM531*4	SM531*4
	CL40H	CL40H
	SM502	SM502
	NM810*2	NM810*2

SIRUBA Series C007K/C007KD C858K/C858KD PARTS LIST (CL21+CL22K+CL31*2) (SM491*2+NM410*2) #CL22K-A1 #CL22K-A2 (CL46-E) A CL31 SM492 CL30 NM410 SM472 CL33 CL34 SM682 VCL41-A HE37-E SM139*2 HE37 VCL41 OR070 NM610 CL48 NM511 NM511 LF208-D LF210*3 LF211*6 LF209*6 CL44 LF210*3 LF211*6 LF209*6 CL45F LF208 SK373*3 Parts Group CL-K CL28E SM611 CL46 BR4081B CL37F SK373*3 CL32 SM440 NM410 SM611 CL49 CL47 CL38 CL40H Subclass / Remark : Use for CLA : Use for UTP/UTQ #: Use for allocation PM301 CL25 CL59 CL25-E CL27 EM123 CL36 CL39H CL63 SM502 SM617 SM502*2 SM470 CL65 SM402*3 EM090 SM461*3 CL53 #CL52P CL52R CL42 CL43 Page 2/2 Date 2012/11/01 SM611*2 ASM432 CP103 CL24E CL26 CL35 SM520*2 WM800 CL64 SM531*4 jintex.in

Page 17 — PARTS LIST

Siruba C007K Attachments parts on page 17
Ref	Part number	Part name
NM410	NM410	NUT
CMR01-A	CMR01-A	BRACKET
WM600*2	WM600*2	WASHER
BR3050*2	BR3050*2	PIN
SK392*2	SK392*2	SCREW
CMR03	CMR03	SHAFT
CFC45-A	CFC45-A	BRACKET
SM883	SM883	SHAFT
WMCO1	WMCO1	WASHER
CZ116	CZ116	SPRING PIN
PM502	PM502	PIN
SM603	SM603	SPRING
SM490	SM490	PIN
CZ115	CZ115	BRACKET
SM470	SM470	PIN
WM600	WM600	WASHER
SK392	SK392	SCREW
WM800	WM800	WASHER
NM810	NM810	NUT
CFC45	CFC45	BRACKET
SM521	SM521	SCREW
KY21-1	KY21-1	CHAIN ASSEMBLY
CZ119	CZ119	SPRING
FFD23	FFD23	CHAIN
CZ123	CZ123	BRACKET
SM433	SM433	SCREW
EM040	EM040	CIRCLIP
CZ28	CZ28	RING
CZ117	CZ117	LEVER
WM500	WM500	WASHER
SM513	SM513	SCREW
CY112	CY112	COVER
CZ124	CZ124	COVER
CZ122	CZ122	BRACKET

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD S007K/S007KD Parts Group CMR-K Subclass / Remark Page 1/1 Date 2012/11/01 NM410 CMR01-A WM600*2 BR3050*2 SK392*2 CMR03 CFC45-A SM883 WMCO1 CZ116 PM502 SM490 SM470 CZ115 WM600 SK392 WM800 NM810 CFC45 SM521 KY21-1 CZ119 FFD23 CZ123 SM433 EM040 CZ28 CZ117 WM500 SM513 CY112 CZ124 CZ122 E jintex.in

Page 18

Siruba C007K Attachments parts on page 18
Ref	Part number	Part name	Qty
	SM480	SM480
	CQA04K	CQA04K
	CQA02K	CQA02K
	MQ38*2	MQ38*2
	WM601	WM601
	WM641	WM641
	WM601	WM601
	NM410	NM410
	CQA02K-A	CQA02K-A
	CQA14K	CQA14K
	SM131*2	SM131*2
	SM620	SM620
	SK250	SK250
	CQA13	CQA13
	CQA09-A	CQA09-A
	CQA09	CQA09
	SM532*2	SM532*2
	CQA11	CQA11
	CQA03K	CQA03K
	CQA12K	CQA12K
	SM411*2	SM411*2

Series C007K/C007KD C858K/C858KD PARTS LIST SIRUBA Page 1/2 Date 2015/09/07 Parts Group CQA-K Subclass / Remark SM480 CQA04K CQA02K MQ38*2 WM601 WM641 WM601 NM410 CQA02K-A CQA14K SM131*2 SM620 SK250 CQA13 CQA09-A CQA09 SM532*2 CQA11 CQA03K CQA12K SM411*2 1 2 3 4 5 jintex.in

Page 19 — CQA-K

Siruba C007K Attachments parts on page 19
Ref	Part number	Part name	Qty
	MXXXXK	MXXXXK
	SM031	SM031
	CQA08K	CQA08K
	PXXXX	PXXXX
	EXXXX	EXXXX
	MT01A	MT01A
	CQA09K	CQA09K
	SK222	SK222
	DXXXX	DXXXX
	HXXXX	HXXXX
	SM432	SM432
	MA81	MA81
	CQA01K	CQA01K
	CQA05K	CQA05K
	CQA06K	CQA06K

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CQA-K Subclass / Remark Page 2/2 Date 2012/11/01 MXXXXK SM031 CQA08K PXXXX EXXXX MT01A CQA09K SK222 DXXXX HXXXX SM432 MA81 CQA01K CQA05K CQA06K jintex.in

Page 20 — PARTS LIST

Siruba C007K Attachments parts on page 20
Ref	Part number	Part name	Qty
	CQ08K	CQ08K
	SM131*2	SM131*2
	SM620	SM620
	SK250	SK250
	FQ06	FQ06
	CQ11H	CQ11H
	FQ11	FQ11
	SM511	SM511
	CQ16	CQ16
	CQ09K	CQ09K
	NM511	NM511
	CQ15K	CQ15K
	CQ10K	CQ10K
	SM435	SM435
	CQ04K	CQ04K
	WM400	WM400
	SM431	SM431
	FQ12	FQ12
	SM501	SM501
	SM432	SM432
	WM400	WM400
	CQ03K	CQ03K
	MQ12K	MQ12K

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CQ-K Subclass / Remark Page 1/1 Date 2012/11/01 CQ08K SM131*2 SM620 SK250 FQ06 CQ11H FQ11 SM511 CQ16 CQ09K NM511 CQ15K CQ10K SM435 CQ04K WM400 SM431 FQ12 SM501 SM432 WM400 CQ03K MQ12K (A) (A) jintex.in

Page 21

Siruba C007K Attachments parts on page 21
Ref	Part number	Part name	Qty
	MQ38*2	MQ38*2
	CR305	CR305
	CR306-A	CR306-A
	UT817-2*2	UT817-2*2
	CR306	CR306
	E******	E******
	CR307-E	CR307-E
	MV34	MV34
	CR307	CR307
	OP222	OP222
	CR34	CR34
	SM480	SM480
	CR35	CR35
	MQ38*2	MQ38*2
	WM601	WM601
	WM641	WM641
	WM601	WM601
	NM410	NM410
	SM151*3	SM151*3
	CR36	CR36
	CR304	CR304
	CR301	CR301
	CR302	CR302
	CR302-A	CR302-A
	CR302-A1	CR302-A1
	MA19K	MA19K
	SM4405	SM4405
	NM410	NM410
	SM401	SM401
	MQ13K	MQ13K
	SM474	SM474
	CR307-A	CR307-A
	CR308	CR308
	SM433	SM433
	BRA050	BRA050
	CR309	CR309
	CR309-A	CR309-A
	CR313-A	CR313-A
	CR335-A	CR335-A
	CR315K-A	CR315K-A
	CR311	CR311
	SM542	SM542
	WM505	WM505
	NM511	NM511
	PP2050	PP2050
	SM540	SM540
	CR310	CR310
	CR336	CR336
	SM516	SM516
	CR315K	CR315K
	SM471	SM471
	CR114	CR114
	CR334	CR334
	CR317	CR317
	CR318	CR318
	CR319	CR319
	SM332*2	SM332*2
	PP6090	PP6090
	CR314-E	CR314-E
	CR317-A	CR317-A
	CR317-A1	CR317-A1
	CR322K	CR322K
	OR210	OR210
	JA048	JA048
	CR110	CR110
	CR111	CR111
	CR323-A2	CR323-A2
	CR323-A1	CR323-A1
	CR323-A	CR323-A
	CR323	CR323
	SM430	SM430
	CR325	CR325
	SM4652*4	SM4652*4
	CR312 (DENTATE)	CR312 (DENTATE)
	CR312A	CR312A

Series C007K/C007KD C858K/C858KD PARTS LIST CR305 MQ38*2 CR306-A UT817-2*2 CR306 E****** MQ38*2 CR307-E MV34 CR307 Parts Group CR-K Subclass / Remark : Use for Basic CR #: Use for CX ◎: Use for CR/CX ▽: Use for attach FFC ●: Use for allocation CR34 SM480 CR35 MQ38*2 WM601 WM641 WM601 NM410 SM151*3 ▽CR36 CR304 CR301 CR302 CR302-A CR302-A1 MA19K SM4405 NM410 SM401 MQ13K SM474 CR307-A CR308 SM433 BRA050 CR309 CR309-A CR313-A ▽CR335-A CR315K-A CR311 SM542 WM505 NM511 PP2050 SM540 CR310 CR336 SM516 CR315K SM471 CR114 CR317 CR334 CR318 CR319 SM332*2 PP6090 CR314-E CR317-A ▽CR317-A1 CR322K OR210 JA048 CR110 CR111 CR323-A2 #CR323-A1 ◎CR323-A CR323 SM430 CR325 SM4652*4 MEDIUM FABRIC THIN FABRIC 中厚布薄布 CR312 (DENTATE) CR312A Page 1/3 Date 2015/10/02 CR-K系列圖 1 2 3 4 5 jintex.in

Page 22

Siruba C007K Attachments parts on page 22
Ref	Part number	Part name	Qty
	AP605	AP605
	CR321	CR321
	JA048	JA048
	OT2602	OT2602
	SM412*2	SM412*2
	CR41	CR41
	CR42	CR42
	SM502	SM502
	TU20P-1	TU20P-1
	TU20P-4*4	TU20P-4*4
	TU20P-2	TU20P-2
	TU20P-3	TU20P-3
	NK74*2	NK74*2
	SW01	SW01
	CR47D	CR47D
	FD165-2	FD165-2
	NM615	NM615
	CR47D	CR47D
	FD161-1-E	FD161-1-E
	FD161-1	FD161-1
	SK270*2	SK270*2
	CR43	CR43
	CR46-2	CR46-2
	CR46-2	CR46-2
	CR46-1	CR46-1
	TU20P-E	TU20P-E
	CR41-A1	CR41-A1
	UT54J-A	UT54J-A
	ALT104S*6	ALT104S*6
	UT54J-2	UT54J-2
	JA023	JA023
	CR46	CR46
	CR47D	CR47D
	NM615	NM615
	FD165-2	FD165-2
	SW01	SW01
	NK74*2	NK74*2
	JA013	JA013
	JA025	JA025
	UT54J	UT54J
	SK392*2	SK392*2
	JA014	JA014
	AP604	AP604

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD CR321 AP605 JA048 OT2602 SM412*2 CR41 CR42 SM502 F Parts Group CR-K Subclass / Remark :UTP/UTQ is not collocate with Page 2/3 Date 2014/04/30 TU20P-1 TU20P-4*4 TU20P-2 TU20P-3 G NK74*2 SW01 CR47D FD165-2 NM615 CR47D FD161-1-E FD161-1 SK270*2 CR43 CR46-2 CR46-2 CR46-1 TU20P-E CR41-A1 UT54J-A ALT104S*6 UT54J-2 JA023 CR46 CR47D NM615 FD165-2 SW01 NK74*2 JA013 JA025 UT54J SK392*2 JA014 AP604 1 2 3 4 5 jintex.in

Page 23 — PARTS LIST

Siruba C007K Attachments parts on page 23
Part number	Part name	Qty
UT54J-2	UT54J-2
JA025	JA025
ALT255S	ALT255S	6
SK392	SK392	2
JA014	JA014
UT54J-A	UT54J-A
AP604	AP604
AP434	AP434
JA062	JA062	3
AP435	AP435
AP433	AP433
JA021	JA021
AP437	AP437
JA042	JA042
JA192	JA192
EP107	EP107
AP432	AP432
JA021	JA021	2
AP436	AP436
JA047	JA047
CR321	CR321
AP605	AP605
JA048	JA048
OT2602	OT2602
UT951C-E	UT951C-E
UT955C-E	UT955C-E
UT951C	UT951C
JA013	JA013
JA053	JA053	2
SM413	SM413	4
JC150-A	JC150-A
UT261K	UT261K
SM435	SM435	4
JC300-A	JC300-A
TU20P-1	TU20P-1
TU20P-4	TU20P-4
TU20P-2	TU20P-2
TU20P-3	TU20P-3
TU20P-E	TU20P-E

SIRUBA Series C007K/C007KD C858K/C858KD PARTS LIST UT54J-2 JA025 ALT255S×6 SK392×2 JA014 UT54J-A AP604 AP434 JA062×3 AP435 AP433 JA021 AP437 JA042 JA192 EP107 AP432 JA021×2 AP436 CR-K CR321 JA048 OT2602 G Parts Group CR-K Subclass / Remark : Use for H brand motor (HVP-20) ☆:Use for C007KD-CR(CX)/ C858KD-CR(CX) UT951C-E UT955C-E JA013 JA053×2 SM413×4 (T84XXX)用 UT951C (T84XXX)用 1 2 3 4 LIFT PRESSER FOOT (抬壓腳功能) LOOP TRIMMER (下切線功能) TOP CUTTER(WIPER) (上切線或吹氣功能) OPTION (其他選項功能) TO MOTOR "SEWING MACHINE" RECEPTACLE HOUSING (經緯機到馬達插頭) JC150-A UT261K SM435×4 JC300-A TO MOTOR "FOOT LAFTER" RECEPTACLE HOUSING (持縫機到馬達插頭) TU20P-1 TU20P-4 TU20P-2 TU20P-3 Page 3/3 Date 2012/11/01 TU20P-E jintex.in

Page 24 — PARTS LIST

Siruba C007K Attachments parts on page 24
Ref	Part number	Part name	Qty
	CRL01K	CRL01K
	MV36-E*2	MV36-E*2
	MV35K	MV35K
	MV33K-E	MV33K-E
	MV37K	MV37K
	CRL12K	CRL12K
	CRL145K	CRL145K
	CRL166	CRL166
	MT33	MT33
	NM410	NM410
	BRA050	BRA050
	WM808	WM808
	SM4406	SM4406
	CR320	CR320
	FR31	FR31
	FR32	FR32
	SM401	SM401
	SM401*2	SM401*2
	OP211	OP211
	CRL06K	CRL06K
	CRL145K-A	CRL145K-A
	CR115	CR115
	CRL06K-E	CRL06K-E
	FR32-E	FR32-E
	WM500	WM500
	NM511	NM511
	CRL08K-A	CRL08K-A
	CRL08K	CRL08K
	SM5050	SM5050
	CRL103K	CRL103K
	CRL169	CRL169
	CRL115	CRL115
	SM144	SM144
	JA019	JA019
	CRL204	CRL204
	SM370	SM370
	KL23-4	KL23-4
	SM402	SM402
	SM131	SM131
	CRL172	CRL172
	CRL174	CRL174
	CRL167	CRL167
	CRL175	CRL175
	CRL09J	CRL09J
	CRL241	CRL241
	SM4307	SM4307
	SM411	SM411
	SM501*2	SM501*2
	CRL115-A	CRL115-A
	SM512*2	SM512*2
	OR220	OR220
	SM332*2	SM332*2
	CRL 44	CRL 44
	CRL265	CRL265
	CRL241-A1	CRL241-A1
	OR220	OR220

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CRL-K Subclass / Remark #: Use for attached in the accessory case of thin fabric Page 1/4 Date 2015/09/03 CRL01K MV36-E*2 MV35K MV33K-E MV37K CRL12K CRL145K CRL166 MT33 NM410 BRA050 WM808 SM4406 CR320 FR31 FR32 SM401 SM401*2 OP211 CRL06K CRL145K-A CR115 CRL06K-E FR32-E WM500 NM511 CRL08K-A CRL08K SM5050 CRL103K CRL169 CRL115 SM144 JA019 SM402 CRL204 SM370 KL23-4 CRL174 CRL172 SM131 CRL167 CRL09J CRL175 SM4307 SM411 CRL241 SM501*2 CRL115-A SM512*2 OR220 SM332*2 CRL 44 CRL265 CRL241-A1 OR220 1 2 3 4 5 jintex.in

Page 25 — CRL-K 系列圖

Siruba C007K Attachments parts on page 25
Ref	Part number	Part name	Qty
	CRL162	Diagram of part
	E5XXXXXX	Diagram of part
	MQ38*2	Diagram of part
	CRL160-E	Diagram of part
	CRL01K	Diagram of part
	CRL21K-A	Diagram of part
	UT817-2*2	Diagram of part
	CRL21K	Diagram of part
	CRL29K-A	Diagram of part
	CRL29K-E	Diagram of part
	CRL29K	Diagram of part
	MR108K	Diagram of part
	MR14K	Diagram of part
	WM100*2	Diagram of part
	MR12K	Diagram of part
	MR06	Diagram of part
	CRL164	Diagram of part
	SM311*2	Diagram of part
	CRL140K	Diagram of part
	SM430*2	Diagram of part
	MR13K	Diagram of part
	SM137*3	Diagram of part
	CRL125K	Diagram of part
	SM151*2	Diagram of part
	SM4050*2	Diagram of part
	WM406*2	Diagram of part
	CRL135	Diagram of part
	CRL24K-A1	Diagram of part
	SM430	Diagram of part
	WM400	Diagram of part
	CRL143K	Diagram of part
	SM441*2	Diagram of part
	CRL126	Diagram of part
	SM132	Diagram of part
	MA19K	Diagram of part
	SM436	Diagram of part
	SM424	Diagram of part
	NM410	Diagram of part
	CRL193K	Diagram of part
	SM401	Diagram of part
	KP46	Diagram of part
	SM351*2	Diagram of part
	CRL194*2	Diagram of part
	MQ13K	Diagram of part
	SM474	Diagram of part

SIRUBA Series C007K/C007KD C858K/C858KD PARTS LIST Parts Group CRL-K Subclass / Remark : Use for general machine to re-equip Page 2/4 Date 2015/09/07 CRL162 E5XXXXXX MQ38*2 CRL160-E CRL01K CRL21K-A UT817-2*2 CRL21K CRL29K-A CRL29K-E CRL29K MR108K MR14K WM100*2 MR12K MR06 CRL164 SM311*2 CRL140K SM430*2 MR13K SM137*3 CRL125K SM151*2 SM4050*2 WM406*2 CRL135 CRL24K-A1 SM430 WM400 CRL143K SM441*2 CRL126 CRL 24K SM132 MA19K SM436 SM424 NM410 CRL193K SM401 KP46 SM351*2 CRL194*2 MQ13K SM474 1 2 3 4 5 jintex.in

Page 26

Siruba C007K Attachments parts on page 26
Ref	Part number	Part name	Qty
	OT2602	OT2602
	AP604	AP604
	JA222	JA222
	CR47D	CR47D
	FD161-1-E	FD161-1-E
	FD161-1	FD161-1
	SK270*2	SK270*2
	CR43	CR43
	CR46-2	CR46-2
	CR46-2	CR46-2
	CR46-1	CR46-1
	SM412*2	SM412*2
	CR41	CR41
	SM502	SM502
	CR42	CR42
	#CR41-A1	#CR41-A1
	ALT104S*6	ALT104S*6
	TU20P-1	TU20P-1
	TU20P-4*4	TU20P-4*4
	TU20P-2	TU20P-2
	TU20P-3	TU20P-3
	TU20P-E	TU20P-E
	UT54J-A	UT54J-A
	UT54J-2	UT54J-2
	SK392*2	SK392*2
	JA014	JA014
	JA025	JA025
	CR46	CR46
	JA013	JA013
	CR47D	CR47D
	NM615	NM615
	SW01	SW01
	NK74*2	NK74*2
	FD165-2	FD165-2
	NM615	NM615
	SW01	SW01
	NK74*2	NK74*2
	FD165-2	FD165-2
	AP604	AP604

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CRL-K Subclass / Remark # UTP/UTQ is not collocate with Page 3/4 Date 2015/02/24 OT2602 AP604 JA222 CR47D FD161-1-E FD161-1 SK270*2 CR43 CR46-2 CR46-2 CR46-1 SM412*2 CR41 SM502 CR42 #CR41-A1 ALT104S*6 TU20P-1 TU20P-4*4 TU20P-2 TU20P-3 TU20P-E UT54J-A UT54J-2 SK392*2 JA014 JA025 CR47D JA013 CR47D NM615 SW01 NK74*2 FD165-2 NM615 SW01 NK74*2 FD165-2 AP604 1 2 3 4 5 jintex.in

Page 27

Siruba C007K Attachments parts on page 27
Ref	Part number	Part name	Qty
	JA025	UT54J-2
	JA014	UT54J
	AP604	H
	AP434	1
	AP433	3
	AP435	2
	AP437	5
	AP432	4
	AP436	6
	JA222	AP608
	JA019	AP604
	JA042	JA192
	JA021*2	JA018*2
	JA062*3	UT951C-E
	#UT955C-E	UT951C
	JA013	JC150
	SM413*4	JC300
	UT261K	LIFT PRESSER FOOT
	LOOP TRIMMER	(下切線功能)
	TOP CUTTER (WIPER)	(上切線或吹氣功能)
	OPTION	TO MOTOR "SEWING MACHINE" RECEPTACLE HOUSING
	(縫紉機到馬達接頭)	TO MOTOR "FOOT LIFTER" RECEPTACLE HOUSING
	(抬壓腳到馬達接頭)	SM435*4
	CRL-K	CRL241
	OT2602	CRL44
	TU20P-1	TU20P-4
	TU20P-2	TU20P-3

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CRL-K Subclass / Remark Page Use for H brand motor (HVP-20) 4/4 Date Use for C007KD/858KD-CRL 2015/02/24 JA025 UT54J-2 SK392*2 JA014 UT54J-A UT951C-E #UT955C-E UT951C (T84XXX 用) JA062*3 JA018*2 UT54J AP604 JA021 AP434 AP433 JA042 JA192 EP107 AP435 AP437 AP436 JA021*2 JA019 JA222 AP608 AP604 CRL-K CRL241 OT2602 CRL44 TU20P-1 TU20P-4 TU20P-2 TU20P-3 UT261K LIFT PRESSER FOOT (抬壓腳功能) 2 LOOP TRIMMER (下切線功能) 3 TOP CUTTER (WIPER) (上切線或吹氣功能) 4 OPTION TO MOTOR "SEWING MACHINE" RECEPTACLE HOUSING (縫紉機到馬達接頭) JA013 JC150 TO MOTOR "FOOT LIFTER" RECEPTACLE HOUSING (抬壓腳到馬達接頭) SM413*4 JC300 SM435*4 TU20P-E 1 2 3 4 5 jintex.in

Page 28

Siruba C007K Attachments parts on page 28
Ref	Part number	Part name	Qty
	MH75	MH75
	M5XXXX	M5XXXX
	MH05	MH05
	P5XXXX	P5XXXX
	SM160	SM160
	E5XXXX	E5XXXX
	MQ35K	MQ35K
	DX	DX
	HXXXX	HXXXX
	MT01B	MT01B
	SM5051*2	SM5051*2
	FW14K	FW14K
	MQ127	MQ127
	MQ12K	MQ12K

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CW-K Subclass / Remark Page 1/3 Date 2013/11/01 MH75 M5XXXX MH05 P5XXXX SM160 E5XXXX MQ35K DX HXXXX MT01B SM5051*2 FW14K MQ127 MQ12K

Page 29

Siruba C007K Attachments parts on page 29
Ref	Part number	Part name
FW05J-A	FW05J	FW05J
	MK37H	MK37H
	KN37	KN37
	SM430	SM430
	SM432	SM432
	SM430*2	SM430*2
	MK37H*2	MK37H*2
	MK94*2	MK94*2
	FW01H	FW01H
	FW04H	FW04H
	VK09-R1	VK09-R1
	VK09-E1	VK09-E1
	VK09-Y1	VK09-Y1
	KG05-G1	KG05-G1
	VK02J*6	VK02J*6
	VK09-B1	VK09-B1
	VK10*6	VK10*6
	VK09-B1	VK09-B1

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CW-K Subclass / Remark Page 2/3 Date 2014/08/05 FW05J-A FW05J MK37H KN37 SM430 SM432 SM430*2 MK37H*2 MK94*2 FW01J-A FW01H FW04H VK09-R1 VK09-E1 VK09-Y1 KG05-G1 VK02J*6 VK09-B1 VK10*6 VK09-B1 jintex.in

Page 30 — PARTS LIST

Siruba C007K Attachments parts on page 30
Ref	Part number	Part name	Qty
	PM501	PM501
	SM511	SM511
	UT28K	UT28K
	MK39H	MK39H
	UT34H	UT34H
	EM040	EM040
	VJ01-3	VJ01-3
	SM4105	SM4105
	FW34-A	FW34-A
	FW33	FW33
	UT37-2	UT37-2
	UT37	UT37
	FW32	FW32
	VK09-R1	VK09-R1
	SM430	SM430
	SK216	SK216
	VK09-E1	VK09-E1
	VK09-Y1	VK09-Y1
	FW31	FW31
	UT35H-1	UT35H-1
	KG05-G1	KG05-G1
	VK09-B1	VK09-B1
	VK02J*6	VK02J*6
	SM330	SM330
	FW34	FW34
	VK09-B1	VK09-B1
	UT34-3	UT34-3
	SM404	SM404
	VK10*6	VK10*6
	UT38	UT38
	SK216	SK216

SIRUBA PARTS LIST Series C007K/C007KD C858K/C858KD Parts Group CW-K Subclass / Remark For UTQ Page 3/3 Date 2014/08/05 PM501 SM511 UT28K MK39H UT34H EM040 VJ01-3 SM4105 FW34-A FW33 UT37-2 UT37 FW32 VK09-R1 SM430 SK216 VK09-E1 VK09-Y1 FW31 UT35H-1 KG05-G1 VK09-B1 VK02J*6 SM330 FW34 VK09-B1 UT34-3 SM404 VK10*6 UT38 SK216

Part Books

Search
