Juki MF-7523 parts on page 2

Ref	Part number	Part name	Qty
	1	MISCELLANEOUS COVER COMPONENTS (1)
	3	MISCELLANEOUS COVER COMPONENTS (2)
	7	MAIN SHAFT COMPONENTS
	11	NEEDLE BAR & PRESSER COMPONENTS
	15	FEED DRIVE COMPONENTS (1)
	19	FEED DRIVE COMPONENTS (2)
	23	THREAD TAKE-UP LEVER COMPONENTS
	27	SPREADER COMPONENTS
	29	LOWER THREAD CAM COMPONENTS
	31	NEEDLE GUARD COMPONENTS
	33	LOOPER COMPONENTS
	35	THREAD TENSION COMPONENTS
	37	LUBRICATION COMPONENTS
	41	THREAD STAND COMPONENTS
	43	GAUGE PARTS COMPONENTS
	47	NEEDLE COOLING COMPONENTS
	49	ACCESSORIES PARTS COMPONENTS
	51	LIST FOR INFORMATION OF CHANGE
	51	HOW TO MAKE USE OF THIS PARTS LIST

Page 3 — MISCELLANEOUS COVER COMPONENTS (1)

Juki MF-7523 parts on page 3

Ref	Part number	Part name	Qty
2	2	JUKI
3	3	CAP
4	4	SCREW
5	5	COVER
6	6	COVER
7	7	COVER
8	8	SCREW
9	9	CAP
10	10	PACKING
11	11	CAP
12	12	PACKING
13	13	BRACKET
14	14	BRACKET
15	15	BRACKET
16	16	BRACKET
17	17	SCREW
18	18	SCREW
19	19	BRACKET
20	20	SCREW
21	21	SCREW
22	22	COVER
23	23	SCREW
24	24	CAP
25	25	PIN
26	26	COVER
27	27	BRACKET
28	28	BRACKET
29	29	BRACKET
30	30	SCREW
31	31	CAP
32	32	WASHER
33	33	CAP
34	34	CAP

Page 4 — MISCELLANEOUS COVER COMPONENTS (1)

Juki MF-7523 parts on page 4

Ref	Part number	Part name	Qty
	70001411	FACE COVER	1
	22902506	PLATE	1
	TA1050504R0	RUBBER PLUG	1
	SM4041055SP	SCREW	4
	70001416	GASKET H	1
	TA2050406R0	RUBBER PLUG	1
	70001409	TOP COVER	1
	SM4041055SP	SCREW	8
	10753309	WINDOW PLATE RUBBER PLUG	1
	RO195240100	O-RING	1
	22924708	OIL SIGHT WINDOW	1
	13300801	GASKET T	1
	70001421	BRACKET HOLDER	1
	40033341	BRACKET	1
	13301700	PROTECTION SHIELD	1
	WZ0641510KP	WAVED WASHER 6.4X11X0.3	1
	SM4030455SN	SCREW	1
	SM4030855SN	SCREW M3 L=8.0	1
	NM6040000SN	NUT M4	1
	SD0640246SP	SHOULDER SCREW D=6.35 H=2.4	1
	SM4060801SE	SCREW	1
	70001422	THREAD COVER	1
	SM4040655SP	SCREW M4 L=6	1
	TA2351004R0	RUBBER PLUG	1
	CM300200001	FINGER INJURY CAUTION LABEL (16)	1
	CM301300001	SAFETY LABEL	1
	70001837	NEEDLE BAR GUARD ASSY	1
	70001407	NEEDLE BAR GUARD	1
	CM300200001	FINGER INJURY CAUTION LABEL (16)	1
	SM4040855SP	SCREW	2
	TA1250705R0	RUBBER PLUG	2
	TA0850606R0	RUBBER PLUG	3
	TA0850606R0	RUBBER PLUG	1
	22901805	GROUND MARK	1

Page 6

Juki MF-7523 parts on page 6

Ref	Part number	Part name	Qty
	70001420	CLOTH PLATE LEFT	1
	13426903	MESH PLATE	1
	RC1900002KP	C-RING 19(20.5)	1
	WP0531000SD	WASHER M5	4
	13302302	RUBBER BUMPER	2
	SM6041002TP	SCREW M4X0.7 L=10	3
	SM1040800SP	SCREW	1
	70001978	CLOTH PLATE RIGHT	1
	TA0400301M0	PLUG D=4X4.5 L=3	1
	SM6040602TP	SCREW M4X0.7 L=6	1
	SM10414C0SP	SCREW	2
	SM6041002TP	SCREW M4X0.7 L=10	1
	70001415	BED TOP COVER	1
	SM6040800SP	SCREW	11
	70001423	GASKET B	1
	TA2050416R0	RUBBER PLUG	2
	TA1050504R0	RUBBER PLUG	1
	70001424	THROAT PLATE SUPPORT	1
	13302302	RUBBER BUMPER	1
	TA0850604R0	RUBBER PLUG	1
	40082196	ADJUSTING COLLAR	2
	SM60407C0TP	SCREW M4 L=7	2
	SM6050800SP	SCREW M5 L=8	3
	13302203	SCREW	2
	13301809	SUPPORT STUD	4
	70001426	SWING DOWN COVER	1
	70001431	HINGE	1
	13409800	DIFF LINK PIN	1
	70001414	SCREW	1
	WS0510002KP	SPRING WASHER 5.1X9.2X1.3	1
	WP0531000SC	WASHER 5.3X10X1	2
	13304308	LATCH SPRING	1
	13302302	RUBBER BUMPER	2
	SM8040412TP	SET SCREW M4 L=4	2
	SM4040655SP	SCREW M4 L=6	2
	13302302	RUBBER BUMPER	1
	40099371	BRACKET	1
	SM6030800SP	SCREW M3X0.5 L=8	2
	SM6051400SP	SCREW	1
	13302104	PIN	1
	70001418	SIDE COVER	1
	RE0300000K0	E-RING 3	1
	WP0550800SP	WASHER 5.5X10X0.8	1
	70001659	FEED CHAMBER COVER	1
	13305107	PIN FOR SIDE COVER	1
	13302708	RUBBER WASHER	2
	TA0850604R0	RUBBER PLUG	1

Page 7 — MISCELLANEOUS COVER COMPONENTS (2)

Juki MF-7523 parts on page 7

Ref	Part number	Part name	Qty
60	60	COVER
69	69	SCREW
10	10	SCREW
11	11	SCREW
12	12	SCREW
8	8	BRACKET
6	6	SCREW
61	61	WASHER
62	62	SCREW
1	1	COVER
7	7	SCREW
5	5	SCREW
22	22	BRACKET
19	19	SCREW
23	23	WASHER
24	24	SCREW
18	18	BRACKET
21	21	SCREW
20	20	SCREW
17	17	COVER
16	16	COVER
14	14	SCREW
15	15	COVER
63	63	COVER
65	65	COVER
64	64	COVER
59	59	SCREW
4	4	SCREW
58	58	BRACKET
42	42	SCREW
43	43	WASHER
47	47	SCREW
70	70	WASHER
52	52	SCREW
44	44	COVER
50	50	COVER
30	30	SCREW
29	29	SCREW
26	26	BRACKET
31	31	SCREW
32	32	BRACKET
33	33	SCREW
35	35	SCREW
36	36	SCREW
40	40	COVER
3	3	WASHER
2	2	SCREW
9	9	SCREW
25	25	SCREW
53	53	SCREW
68	68	WASHER
67	67	SCREW
51	51	COVER
48	48	SCREW
46	46	SCREW
45	45	SCREW
41	41	COVER
49	49	SCREW
56	56	SCREW
54	54	BRACKET
55	55	SCREW
57	57	SCREW
37	37	BRACKET
38	38	SCREW
27	27	BRACKET
28	28	SCREW
34	34	SCREW
39	39	SCREW
66	66	SCREW

Page 8 — MISCELLANEOUS COVER COMPONENTS (2)

Juki MF-7523 parts on page 8

Ref	Part number	Part name	Qty
	13304308	LATCH SPRING	1
	13302302	RUBBER BUMPER	2
	SM8040312TP	SCREW M4 L=3	1
	SM4040555SP	SCREW	2
	SM4041055SP	SCREW	7
	13302104	PIN	1
	13304209	SUPPORT BRACKET	1
	SM4041055SP	SCREW	1
	SM4041055SP	SCREW M4 L=6	1
	NM6040000SN	NUT M4	1
	700011436	HOUSING	1
	SM6051602TP	SCREW M5X0.8 L=16	4
	70001976	SLIDE COVER	1
	WZ0641510KP	WAVED WASHER 6.4X11X0.3	1
	70004493	SHOULDER SCREW	1
	70001831	DRIVING BELT COVER ASSY	1
	70001830	DRIVING BELT COVER	1
	CM300200001	FINGER INJURY CAUTION LABEL (16)	1
	SM4051055SP	SCREW	3
	TA2101002R0	RUBBER PLUG	1
	TA2050416R0	RUBBER PLUG	2
	WP0501016SD	WASHER 5X10.5X1	1
	TA1050504R0	RUBBER PLUG	2

Page 9 — MAIN SHAFT COMPONENTS

Juki MF-7523 parts on page 9

Ref	Part number	Part name	Qty
	1	MAIN SHAFT
	2	KEY
	3	BEARING
	4	COLLAR
	5	WASHER
	6	BEARING
	7	COLLAR
	8	BEARING
	9	BEARING
	10	COLLAR
	11	COLLAR
	12	WASHER
	13	COLLAR
	14	SCREW
	15	COLLAR
	16	COLLAR
	17	BEARING
	18	COLLAR
	19	SCREW
	20	COLLAR
	21	SCREW
	22	BEARING
	23	COLLAR
	24	PULLEY
	25	COLLAR
	26	HOUSING
	27	BEARING
	28	GASKET
	29	SCREW
	30	BRACKET
	31	COLLAR
	32	SCREW
	33	SCREW
	34	SCREW
	35	COLLAR
	36	SCREW
	37	COLLAR
	38	BEARING
	39	COLLAR
	40	SCREW
	41	BEARING
	42	WASHER
	43	SCREW
	44	COLLAR
	45	SHAFT
	46	BEARING
	47	COLLAR
	48	COLLAR
	49	COLLAR
	50	COLLAR
	51	COLLAR
	52	SCREW
	53	BEARING
	54	COLLAR
	55	COLLAR
	56	COLLAR
	57	COLLAR
	58	SCREW
	59	SHAFT
	60	COLLAR
	61	SCREW
	62	COLLAR
	63	COLLAR
	64	COLLAR
	65	COLLAR
	66	SCREW
	67~69	BEARING
	70	COLLAR
	71	COLLAR
	72	SCREW
	73	SCREW
	74	COLLAR
	75	COLLAR
	76	COLLAR

Page 10 — MAIN SHAFT COMPONENTS

Juki MF-7523 parts on page 10

Ref	Part number	Part name	Qty
	70004635	TIMING BELT	1
	70001445	LOWER MAINSHAFT RIGHT	1
	13406707	LOWER PULLEY	1
	SM8061212TP	SCREW M6X12	2
	40017824	LOOPER LOD STOPPER	1
	70004640	COUPLING E ASSY	1
	SM8060612TP	SCREW M6 L=6	2
	13308457	BEARING ASSY C	1
	70004197	BEARING	1
	40018922	COUPLING C	1
	SM8060612TP	SCREW M6 L=6	1
	RO148240200	O-RING	1
	13307509	JOINT	1
	SM8060612TP	SCREW M6 L=6	4
	70004630	LMS_LEFT_ASSY	1
	70004631	LOWER_MAINSHAFT_LEFT	1
	70004633	LOOPER DRIVE	1
	70004632	LOOPER ROD DRIVE	1
	SM6061402TP	SCREW M6 L=14	1
	SM8040412TP	SCREW M4X4	1
	13324108	SCREW	4
	70003316	FLY WHEEL	1
	SM8060612TP	SCREW M6 L=6	3
	SM4040655SP	SCREW M4 L=6	1
	70001447	BUSHING LMS MIDDLE	1
	70001448	BUSHING LMS LEFT	1
	70005086	BEARING	1
	13308705	GASKET FOR BUSHING LEFT	3
	SM4041055SP	SCREW	1
	70001451	THRUST PLATE	1
	70001453	BEARING HOLDER	1
	SM8060812TP	SCREW M6 L=8	1
	SM8060842TP	SCREW M6 L=8	1
	70004184	LMS SPROCKET	1
	70004489	LMS WORM ASSY	1
	SM8060552TP	SCREW M6 L=5	1
	13308507	COUPLING D	1
	SM8060842TP	SCREW M6 L=8	1
	70004484	BEARING	2
	SM8060612TP	SCREW M6 L=6	1
	SB12000150	BEARING	1
	RO148240200	O-RING	1
	40035711	OIL WICK	2
	70003331	COUPLING B	1
	70001437	UPPER MAINSHAFT RIGHT	1
	70001439	UPPER PULLEY	1
	SM8061212TP	SCREW M6X12	2

Page 11 — MAIN SHAFT COMPONENTS

Juki MF-7523 parts on page 11

Ref	Part number	Part name	Qty
	1	MAIN SHAFT
	2	KEY
	3	BEARING
	4	COLLAR
	5	WASHER
	6	COLLAR
	7	BEARING
	8	BEARING
	9	BEARING
	10	COLLAR
	11	COLLAR
	12	COLLAR
	13	COLLAR
	14	COLLAR
	15	COLLAR
	16	COLLAR
	17	COLLAR
	18	COLLAR
	19	COLLAR
	20	COLLAR
	21	COLLAR
	22	SHAFT
	23	BEARING
	24	PULLEY
	25	COLLAR
	26	COLLAR
	27	BEARING
	28	COLLAR
	29	SCREW
	30	BRACKET
	31	COLLAR
	32	COLLAR
	33	COLLAR
	34	COLLAR
	35	COLLAR
	36	COLLAR
	37	COLLAR
	38	COLLAR
	39	COLLAR
	40	COLLAR
	41	BEARING
	42	COLLAR
	43	COLLAR
	44	COLLAR
	45	SHAFT
	46	COLLAR
	47	COLLAR
	48	COLLAR
	49	COLLAR
	50	COLLAR
	51	COLLAR
	52	COLLAR
	53	COLLAR
	54	COLLAR
	55	COLLAR
	56	COLLAR
	57	COLLAR
	58	COLLAR
	59	SHAFT
	60	COLLAR
	61	COLLAR
	62	COLLAR
	63	COLLAR
	64	COLLAR
	65	COLLAR
	66	COLLAR
	67~69	COLLAR
	70	COLLAR
	71	COLLAR
	72	COLLAR
	73	COLLAR
	74	COLLAR
	75	COLLAR
	76	COLLAR

Page 12 — MAIN SHAFT COMPONENTS

Juki MF-7523 parts on page 12

Ref	Part number	Part name	Qty
	13307251	BEARING ASSY A	1
	SM8060842TP	SCREW M6 L=8	1
	SM8060612TP	SCREW M6 L=6	1
	70001443	COLLAR	1
	SM8060612TP	SCREW M6 L=6	2
	13307301	UMS SPROCKET	1
	SM8060812TP	SCREW M6 L=8	4
	SB120002200	BEARING	1
	70001440	COUPLING B	1
	70001638	BEARING COVER PLATE	1
	SM8060612TP	SCREW M6 L=6	4
	70001441	UPPER MAINSHAFT LEFT	1
	70001442	TAKE UP ROD ASSY	1
	SM6061402TP	SCREW M6 L=14	1
	70001535	CRANK	1
	70001536	ROD	1
	13324108	SCREW	2
	70001444	TAKE UP ECCENTRIC	1
	SM8060612TP	SCREW M6 L=6	2
	13307806	HOUSING A
	13309307	HOUSING B
	13309406	HOUSING C
	SB120001900	BEARING	1
	SM8060842TP	SCREW M6 L=8	1
	SM8060612TP	SCREW M6 L=6	1
	13309208	SCREW FOR COUNTERWEIGHT	1
	SM8080812TP	SCREW M8X8	1
	SM6061200SP	SCREW	1
	13307707	COUNTER WEIGHT	1

Page 13 — NEEDLE BAR & PRESSER COMPONENTS

Juki MF-7523 parts on page 13

Ref	Part number	Part name	Qty
24	24	Screw
29	29	Needle Bar Connecting Link
30	30	Screw
31	31	Needle Bar Connecting Link
32	32	Needle Bar Connecting Link
33	33	Needle Bar Connecting Link
44	44	Screw
43	43	Screw
23	23	Screw
28	28	Screw
27	27	Screw
26	26	Screw
25	25	Screw
22	22	Screw
20	20	Spring
21	21	Spring
34	34	Presser Bar
38	38	Screw
37	37	Presser Bar Holder
35	35	Presser Bar Holder
36	36	Screw
19	19	Washer
18	18	Washer
42	42	Presser Bar Connecting Link
39	39	Screw
40	40	Screw
41	41	Screw
66	66	Presser Bar
1	1	Needle Bar
2	2	Needle Bar
3	3	Needle Bar
4	4	Spring
5	5	Spring
6	6	Needle Bar
7	7	Needle Bar
8	8	Washer
9	9	Presser Foot
10	10	Screw
11	11	Screw
12	12	Screw
13	13	Needle Bar Holder
14	14	Needle Bar Holder
15	15	Presser Foot
16	16	Screw
17	17	Presser Bar Connecting Link
60	60	Screw
61	61	Screw
64	64	Presser Bar
62	62	Presser Bar
65	65	Presser Bar
63	63	Presser Bar
45	45	Presser Bar Connecting Link
49~52	49~52	Presser Bar Connecting Link
47	47	Screw
46	46	Presser Bar Connecting Link
54	54	Screw
53	53	Screw
55~57	55~57	Washer
58	58	Screw
59	59	Screw
67	67	Presser Bar Holder

Page 14 — NEEDLE BAR & PRESSER COMPONENTS

Juki MF-7523 parts on page 14

Ref	Part number	Part name	Qty
	40070574	ADJ SCREW P B NUT ASSY
	40070573	ADJ SCREW P B ASSY
	13313101	LOCKING NUT	1
	13313309	SPRING PRESSER BAR A	1
	70001480	SPRING PRESSER BAR B	1
	70001481	PRESSER BAR	1
	70001499	BUSHING PRESSER BAR	1
	13315908	OIL SEAL	1
	70001483	FINGER GUARD	1
	SM4040655SP	SCREW M4 L=6
	13313804	GUIDE PLATE	2
	SM6041000SP	SCREW M4 L=10	1
	70001485	PRESSER BAR BRACKET	1
	SM6041200SP	SCREW M4 L=12	1
	13314109	LINK	1
	SD070020CTP	SHOULDER SCREW D=7 H=2	2
	13314356	ASSY LIFTER SHAFT	1
	23537202	HOOK SHAFT OIL SEAL	1
	70001486	BUSHING LIFTER FRONT	1
	PS0500142KP	SPRING PIN TYPE W 5X14	1
	70001498	SPRING LIFTER LEVER	1
	70001494	TENSION RELEASE LEVER	1
	SM6041202TP	SCREW M4X0.7 L=12	2
	SD070005CTP	SHOULDER SCREW D=7 H=5.8	1
	70001495	LIFTER LEVER STOPPER
	SM60625COTP	SCREW M6 L=25	1
	NM6060001CP	NUT M6X1 TYPE1	2
	SM6061202TP	SCREW M6 L=12	1
	70001487	LIFTER LEVER ASSY	1
	SM6051002TP	SCREW M5X0.8 L=10
	WP0551016SH	WASHER 5.5X13X1
	70001488	LIFTER LEVER	1
	70001489	LIFTER LEVER SHAFT	1
	70001490	BUSHING LIFTER LEVER	1
	70001478	LIFTER SHAFT LEVER	1
	SM6051202TP	SCREW M5X0.8 L=12	2
	70001477	LIFTER LEVER COLLAR	1
	SM6040800SP	SCREW	1
	70001491	SPACER	2
	WP0450826SC	WASHER 4.5X10X0.8	2
	SM4041055SP	SCREW	1
	70001492	LIFTER LEVER LINK	1
	70001493	MINUTES LIFTING COLLAR	1
	SM8040512TP	SCREW	2
	13311253	ASSY NEEDLE MECH	1
	70004371	ASSY CONNECTING ROD
	13311006	ECCENTRIC PIN

Page 15 — NEEDLE BAR & PRESSER COMPONENTS

Juki MF-7523 parts on page 15

Ref	Part number	Part name	Qty
24	24	SCREW
29	29	NEEDLE BAR GUIDE
30	30	SCREW
31	31	CLAMP
32	32	NEEDLE BAR
33	33	NEEDLE BAR CAP
23	23	SCREW
44	44	SCREW
43	43	SCREW
28	28	SCREW
26	26	SCREW
27	27	WASHER
25	25	BRACKET
20	20	SPRING
22	22	SPRING
21	21	SPRING
34	34	PRESSER FOOT BAR
38	38	SCREW
37	37	PRESSER BAR HOLDER
36	36	SCREW
35	35	PRESSER BAR HOLDER
19	19	WASHER
18	18	WASHER
42	42	LINK
39	39	SCREW
40	40	WASHER
41	41	SCREW
66	66	CYLINDER
1	1	NEEDLE BAR
2	2	NEEDLE BAR CAP
3	3	SPRING
4	4	SPRING
12	12	SCREW
11	11	SPRING
13	13	NEEDLE BAR HOLDER
14	14	SCREW
64	64	CYLINDER
61	61	SCREW
60	60	SPRING
62	62	CYLINDER
65	65	ROD
5	5	SPRING
8	8	WASHER
6	6	CYLINDER
9	9	SCREW
10	10	BRACKET
17	17	LINK
16	16	SCREW
15	15	LINK
45	45	BRACKET
49~52	49~52	PRESSER FOOT BAR
48	48	LINK
47	47	SCREW
46	46	LINK
55~57	55~57	WASHER
59	59	SCREW
58	58	BLOCK
67	67	BRACKET
54	54	LINK
53	53	SCREW

Page 16 — NEEDLE BAR & PRESSER COMPONENTS

Juki MF-7523 parts on page 16

Ref	Part number	Part name	Qty
	13311204	CONNECTING ROD
	SB30800110A	BEARING
	SB30800110B	BEARING
	SB30800110C	BEARING
	SB30800110D	BEARING
	SM6041000SP	SCREW M4 L=10
	13311303	NEEDLE BAR CLAMP
	13312103	THRUST WASHER
	13312202	THRUST WASHER
	13312301	THRUST WASHER
	13311501	SLIDE BLOCK
	SM6051202TP	SCREW M5X0.8 L=12	3
	13326806	NEEDLE BAR EYELET
	SM4030855SN	SCREW M3 L=8.0
	13311956	ASSY BUSHING NB
	13311907	BUSHING NB LOWER
	13311908	BUSHING NB UPPER
	13311451	NEEDLE BAR ASSY
	70001500	BUSHING LIFTER REAR
	13311600	NEEDLE BAR GUIDE

Page 17 — FEED DRIVE COMPONENTS (1)

Juki MF-7523 parts on page 17

Ref	Part number	Part name	Qty
1	1	SHAFT
3	3	COLLAR
4	4	COLLAR
5	5	COLLAR
6	6	COLLAR
7	7	COLLAR
8~10	8~10	BEARING
11	11	PIN
12	12	LINK
13	13	LINK
14~16	14~16	PIN
17	17	PIN
18	18	BRACKET
19	19	LINK
20~22	20~22	PIN
23	23	PIN
24	24	BRACKET
25	25	BRACKET
26	26	BRACKET
27	27	BRACKET
28	28	BRACKET
29	29	BRACKET
30	30	BRACKET
31	31	SCREW
32	32	SHAFT
33	33	SHAFT
34	34	BRACKET
35	35	BRACKET
36	36	BRACKET
37	37	BRACKET
38	38	SCREW
39	39	SCREW
40	40	SCREW
41	41	BEARING
42	42	SHAFT
43	43	SHAFT
44	44	COLLAR
45	45	COLLAR
46	46	COLLAR
47	47	COLLAR
48	48	COLLAR
49	49	COLLAR
50	50	COLLAR
51	51	COLLAR
52	52	COLLAR
53	53	COLLAR
54	54	SCREW
55	55	SHAFT
56	56	SCREW
57	57	BRACKET
58	58	SCREW
59	59	BRACKET
60	60	COLLAR
61	61	SHAFT
62	62	BRACKET
63	63	SPRING
64	64	COLLAR
65	65	SCREW
66	66	COLLAR
67	67	SPRING
68	68	SCREW
69	69	SCREW
70	70	COLLAR
71	71	BRACKET
72	72	SHAFT
73	73	BRACKET
74	74	BRACKET
75	75	BRACKET
76	76	SCREW
77	77	BRACKET
78	78	SCREW
79	79	SHAFT
80	80	COLLAR
81	81	COLLAR
82	82	COLLAR
83	83	COLLAR
84	84	COLLAR
85	85	COLLAR
86	86	COLLAR
87	87	BRACKET
88	88	BRACKET
89	89	SCREW
90	90	SCREW
91	91	BRACKET
92	92	BRACKET
93	93	BRACKET
94	94	BRACKET
95	95	BRACKET
96	96	SCREW
97	97	SCREW
98	98	SCREW
99	99	BRACKET
100	100	BRACKET
101	101	BRACKET

Page 18 — FEED DRIVE COMPONENTS (1)

Juki MF-7523 parts on page 18

Ref	Part number	Part name	Qty
	70001521	FEED ECCENTRIC HORIZON ASSY	1
	70001505	CRNAK ROD	1
	70001522	FEED ECCENTRIC HORIZON	1
	SM8060612TP	SCREW M6 L=6	2
	13323803	CRANK ROD GUIDE	1
	SM8050812TP	SCREW M5X8	1
	RO158240100	O-RING	1
	13323308	FEED ADJ LINK PIN A
	13323407	FEED ADJ LINK PIN B
	13323506	FEED ADJ LINK PIN C
	CQ303000000	COTTON OIL WICK D=3	0.07
	13317201	MAIN FEED DRIVE LINK	1
	SM8050612TP	SCREW M5X6	2
	13318704	MAIN FEED CRANK PIN A
	13318803	MAIN FEED CRANK PIN B
	13318902	MAIN FEED CRANK PIN C
	CQ303000000	COTTON OIL WICK D=3	0.04
	WP0370316SD	WASHER 3.7X8X0.3	1
	13317300	ADJUST LINK	1
	13317409	FEED ADJ LINK PIN A
	13317508	FEED ADJ LINK PIN B
	13317607	FEED ADJ LINK PIN C
	CQ303000000	COTTON OIL WICK D=3	0.08
	13317706	MAIN FEED ADJ LEVER	1
	SM8060552TP	SCREW M6 L=5	2
	70001528	FEED BAR ASSY	1
	70001959	MAIN FEED BAR	1
	13321708	DIFF FEED BAR	1
	70001509	SLIDE BLOCK	1
	13322409	SLIDE BLOCK	1
	SM6041000SP	SCREW M4 L=10	2
	13319702	DIFF FEED LINK	1
	SD0801326TH	SHOULDER SCREW D=8 H=13.2	1
	13319959	DIFF DRIVE ARM ASSY	1
	13319900	DIFF DRIVE ARM	1
	13320007	DIFF FEED PIN	1
	13320106	DIFF FEED PIN PLATE	1
	SM6061402TP	SCREW M6 L=14	1
	SM6030600SP	SCREW M3X0.5 L=6	2
	RC01000001KP	C-RING 10 (9.3)	1
	70001510	BUSHING FEED FRONT	1
	13319009	ROCKER SHAFT	1
	70001511	BUSHING FEED REAR	1
	CS1000881TP	THRUST COLLAR D=10 W=8	1
	SM8060612TP	SCREW M5X6	2
	TA0500601M0	PLUG D=5X5.4 L=6	1
	13318209	BUSHING FEED ADJUST	1

Page 19 — FEED DRIVE COMPONENTS (1)

Juki MF-7523 parts on page 19

Ref	Part number	Part name	Qty
	18	FEED DRIVE COMPONENTS (1)
	96	96
	97	97
	98	98
	101	101
	80	80
	81	81
	83	83
	84	84
	85	85
	82	82
	26	26
	27	27
	28	28
	30	30
	B	B
	29	29
	31	31
	31	31
	78	78
	77	77
	72	72
	75	75
	74	74
	73	73
	76	76
	70	70
	B	B
	69	69
	68	68
	67	67
	66	66
	64	64
	60	60
	63	63
	65	65
	61	61
	59	59
	58	58
	55	55
	54	54
	57	57
	49	49
	47	47
	48	48
	50	50
	51	51
	53	53
	52	52
	25	25
	24	24
	19	19
	20~22	20~22
	23	23
	17	17
	12	12
	13	13
	8~10	8~10
	11	11
	7	7
	6	6
	5	5
	4	4
	3	3
	1	1
	99	99
	91	91
	92	92
	93	93
	C	C
	88	88
	87	87
	89	89
	90	90
	34	34
	38	38
	35	35
	37	37
	39	39
	33	33
	A	A
	100	100
	95	95
	94	94
	45	45
	46	46
	44	44
	43	43
	79	79
	32	32
	36	36
	40	40
	41	41
	42	42
	56	56
	14~16	14~16

Page 20 — FEED DRIVE COMPONENTS (1)

Juki MF-7523 parts on page 20

Ref	Part number	Part name	Qty
	13318001	KNOB FEED ADJUST	1
	13318100	SHAFT FEED ADJUST	1
	SM8040602TP	SCREW M4X0.7 L=6	1
	RO055200100	O-RING	1
	B3215470000	PIN	1
	SM8040412TP	SCREW M4X4	1
	13318308	STOPPER FEED ADJUST	1
	RE0500000K0	E-RING	2
	SM6030402TP	SCREW M3X0.5 L=4	1
	13317904	FEED ADJUST LEVER	1
	PS0300162KH	SPRING PIN 3X16	1
	SM8050612TP	SCREW M5X6	1
	70001512	BUSHING FEED ADJUST	1
	13317805	FEED ADJUST SHAFT	1
	70001510	BUSHING FEED FRONT	1
	13318506	TORSIN SPRING	1
	CS1000881TP	THRUST COLLAR D=10 W=8	1
	SM4051255SP	SCREW	1
	SM8050612TP	SCREW M5X6	1
	B2556280000	SPRING	1
	SM6051602TP	SCREW M5X0.8 L=16	1
	NM6050001SC	NUT M5X0.8 TYPE1	1
	RC0741013KP	C-RING 8 (7.4)	1
	13398409	SHOULDER SCREW	1
	70001513	MAIN FEED ROCKER ASSY	1
	13319405	MAIN FEED ROCKER PIN
	70001506	MAIN FEED ROCKER
	SM6061202TP	SCREW M6 L=12
	13319504	MAIN FEED LINK	1
	13318605	MAIN FEED CRANK	2
	SM80606A2TP	SCREW M6 L=6	1
	13322201	ECCENTRIC PIN	1
	SM8060552TP	SCREW M6 L=5	1
	13322003	FEED BAR SHAFT	1
	RO137230100	O-RING	1
	SM80612TP	SCREW M4 L=6	1
	13322102	WASHER FEED BAR SHAFT	1
	CS1000881TP	THRUST COLLAR D=10 W=8	1
	SM8050612TP	SCREW M5X6	2
	70001523	POSITIONING CAM HORIZON	1
	SM8060612TP	SCREW M6 L=6	2
	70001524	FEED ECCENTRIC SCREW	1
	70001525	FEED ECCENTRIC PIN	1
	70001526	FEED ECCENTRIC	1
	SM8050412TP	SCREW M5 L=4	2
	70001527	POSITIONING CAM VERTICAL	1
	70001507	FEED BAR GUIDE 1	1

Page 21

Juki MF-7523 parts on page 21

Ref	Part number	Part name	Qty
96	96	BRACKET
97	97	BRACKET
98	98	BRACKET
101	101	BRACKET
18	18	BRACKET
80	80	SHAFT
81	81	COLLAR
83	83	COLLAR
82	82	COLLAR
84	84	COLLAR
86	86	SCREW
85	85	SCREW
26	26	BRACKET
27	27	BRACKET
28	28	BRACKET
30	30	BRACKET
29	29	BRACKET
31	31	SCREW
32	32	SHAFT
33	33	BRACKET
79	79	SHAFT
34	34	BRACKET
38	38	SCREW
35	35	BRACKET
37	37	BRACKET
39	39	BRACKET
44	44	BRACKET
46	46	BRACKET
45	45	SCREW
43	43	BRACKET
36	36	BRACKET
56	56	SCREW
100	100	SHAFT
95	95	BRACKET
94	94	BRACKET
78	78	SHAFT
77	77	BRACKET
72	72	BRACKET
40	40	SCREW
41	41	COLLAR
42	42	COLLAR
75	75	BRACKET
74	74	BRACKET
73	73	BRACKET
76	76	SCREW
70	70	BRACKET
71	71	BRACKET
69	69	SCREW
68	68	SCREW
63	63	SPRING
66	66	BRACKET
64	64	COLLAR
60	60	COLLAR
59	59	BRACKET
58	58	SHAFT
55	55	SHAFT
54	54	BRACKET
57	57	BRACKET
65	65	SCREW
61	61	SHAFT
49	49	COLLAR
47	47	COLLAR
50	50	BRACKET
51	51	COLLAR
48	48	BRACKET
53	53	SCREW
52	52	SCREW
25	25	BRACKET
24	24	BRACKET
19	19	BRACKET
20~22	20~22	SCREW
23	23	SCREW
62	62	BRACKET
67	67	SPRING
99	99	BRACKET
91	91	BRACKET
92	92	BRACKET
93	93	BRACKET
1	1	BRACKET
2	2	BRACKET
3	3	BRACKET
4	4	BRACKET
5	5	COLLAR
6	6	SCREW
7	7	BRACKET
8~10	8~10	SCREW
11	11	SCREW
12	12	BRACKET
13	13	BRACKET
14~16	14~16	SCREW
17	17	BRACKET
87	87	BRACKET
88	88	SCREW
89	89	SCREW
90	90	SCREW

Page 22 — FEED DRIVE COMPONENTS (1)

Juki MF-7523 parts on page 22

Ref	Part number	Part name	Qty
	SM8050812TP	SCREW M5X8	1
	70001508	FEED BAR GUIDE 2	1
	WP0480856SP	WASHER 4.8X8.4X0.8	2
	SM6040800SP	SCREW	2
	SM8050412TP	SCREW M5 L=4	2
	70001532	FELT FOR FEED BAR GUIDE	1
	70001533	OIL PROTECTION SHEILD	1

Page 23 — FEED DRIVE COMPONENTS (2)

Juki MF-7523 parts on page 23

Ref	Part number	Part name	Qty
1	1	SHAFT
2	2	WASHER
3	3	BRACKET
4	4	SCREW
5	5	SCREW
6	6	WASHER
7	7	SHAFT
8	8	SPRING
9	9	PIN
10	10	SPRING
11	11	SCREW
12	12	PULLEY
13	13	SCREW
14	14	WASHER
15	15	BRACKET
16	16	WASHER
17	17	SPRING
18	18	BEARING
19	19	ROLLER
20	20	SCREW
21	21	BRACKET
22	22	SCREW
23	23	SCREW
24	24	WASHER
25	25	BEARING
26	26	BRACKET
27	27	SCREW
28	28	BRACKET
29	29	BRACKET
30	30	BRACKET
31	31	BRACKET
32	32	BRACKET
33	33	SCREW
34	34	SCREW

Page 24 — FEED DRIVE COMPONENTS (2)

Juki MF-7523 parts on page 24

Ref	Part number	Part name	Qty
	40040206	DIFF FEED LEVER ASSY	1
	R0068190100	O-RING	1
	40039630	PLATE DIFF FEED LEVER	1
	13321203	STOPPER DIFF ADJ	2
	WP0450826SC	WASHER 4.5X10X0.8	2
	SM5040655SN	SCREW	2
	70001530	SCREW	1
	13217708	DIFFERENTIAL FEED BLOCK	1
	WP0460556SD	WASHER 4.6X7.5X0.5	1
	13123302	ADJUSTING SPRING	1
	RE0300000K0	E-RING 3	1
	13217500	DIFFERENTIAL FEED LOCK NUT	1
	13217401	DIFFERENTIAL FEED HINGE SCREW	1
	SM4051255SP	SCREW	1
	SM7051460TP	SCREW M5 L=14	1
	WP0621016SD	WASHER 6.2X13X1	1
	70001531	ADJUSTING LEVER SPRING	1
	13320304	BUSHING DIFF ADJ LEVER	1
	13320403	DIFF ADJ LEVER	1
	SM8050612TP	SCREW M5X6	1
	40018443	DIFF ADJ LINK	1
	31013808	HINGE SCREW	1
	CS1000881TP	THRUST COLLAR D=10 W=8	2
	SM8050612TP	SCREW M5X6	2
	13323209	BUSHING DIFF ADJ LEVER	1
	70001589	NEEDLE GUARD BASE	1
	TA0750404R0	PLUG D=7.5 L=3.5	2
	70001514	FEED BAR SEAL 1	1
	70001515	FEED BAR SEAL PLATE 1	1
	70001516	FEED BAR SEAL PLATE 2	1
	70001517	FEED BAR SEAL 2	1
	70001518	FEED BAR SEAL PLATE 3	1
	SM1030400SP	SCREW M3 L=4	3
	SM6041000SP	SCREW M4 L=10	3

Page 25

Juki MF-7523 parts on page 25

Ref	Part number	Part name	Qty
	1	Washer
	2	Spring washer
	3	Shaft
	4	Washer
	5	Lever sleeve
	6	Screw
	7	Screw
	8	Lever sleeve
	9	Bearing
	10	Lever bracket
	11	Washer
	12	Spring washer
	13	Thread take-up lever
	14	Lever bracket
	15	Screw
	16	Lever bracket
	17	Screw
	18	Lever bracket
	19	Lever bracket
	20	Lever bracket
	21	Lever bracket
	22	Screw
	23	Screw
	24	Lever bracket
	25	Screw
	26	Screw
	27	Screw
	28	Screw
	29	Lever bracket
	30	Screw
	31	Lever bracket
	32	Lever bracket
	33	Screw
	34	Screw
	35	Lever bracket
	36	Screw
	37	Screw
	38	Screw
	39	Lever bracket
	40	Lever bracket
	41	Washer
	42	Screw
	43	Washer
	44	Screw
	45	Screw
	46	Screw
	47	Screw
	48	Lever bracket
	49	Lever bracket
	50	Lever bracket
	51	Screw
	52	Screw
	53	Screw
	54	Screw
	55	Thread take-up lever
	56	Screw
	57	Washer
	58	Lever bracket
	59	Screw
	60	Screw

Page 26 — THREAD TAKE-UP LEVER COMPONENTS

Juki MF-7523 parts on page 26

Ref	Part number	Part name	Qty
	SM6051002TP	SCREW M5X0.8 L=10	1
	WS0510002KP	SPRING WASHER 5.1X9.2X1.3	1
	70001537	SHAFT	1
	WP0522016SH	WASHER	1
	13324504	BUSHING REAR	1
	CS1000881TP	THRUST COLLAR D=10 W=8	1
	SM8050612TP	SCREW M5X6	2
	13324603	BUSHING FRONT	1
	23612609	FEED CHANGING SHAFT OIL SEAL	1
	13324702	HOLDER TAKE UP EYELET	1
	WS0510002KN	SPRING WASHER M5	1
	SM6051402TP	SCREW M5X0.8 L=14	1
	70001548	NDL THD TAKE UP	1
	13324900	UP LPR THREAD TAKE UP	1
	SM4041055SP	SCREW	2
	13325006	THREAD GUIDE	1
	SM4040655SP	SCREW M4 L=6	2
	70001540	THREAD TENSION GUIDE	1
	13348008	TANK	1
	70001546	SILICONE OIL TANK COVER	1
	B9214850000	HEAT REMOVING FELT	1
	PS0150082KH	SPRING PIN 1.5X8	2
	ST4040851SN	TAPPING SCREW M4X8	1
	13325204	HOLDER	3
	30391601	NEEDLE THREAD EYELET	3
	SM8030312TP	SCREW M3 L=3	1
	SM4030855SN	SCREW M3 L=8.0	2
	SM4040655SP	SCREW M4 L=6	1
	70001541	THREAD GUIDE	1
	SM4040655SP	SCREW M4 L=6	1
	70001542	THREAD GUIDE	1
	70001543	NDL THD STRIKE OFF	1
	SM4040655SP	SCREW M4 L=6	1
	PS0400082KP	SPRING PIN TYPE W 4X8	1
	13326905	NDL THD STRIKE OFF R	1
	WP0280501SC	WASHER M2.6	1
	SM48504C5SP	SCREW	2
	SM1040650TP	SCREW	2
	13326301	THREAD GUIDE UPPER LPR	1
	13326400	THREAD GUIDE	1
	22945802	THREAD TENSION DISK	1
	13326509	TENSION POST	1
	22945505	THREAD TENSION SPRING	1
	13326608	TENSION NUT	1
	NM6050001SC	NUT M5X0.8 TYPE1	2
	WP0450826SC	WASHER 4.5X10X0.8	2
	SM6040800SP	SCREW	2

Page 27 — THREAD TAKE-UP LEVER COMPONENTS

Juki MF-7523 parts on page 27

Ref	Part number	Part name	Qty
1	1	SCREW
2	2	WASHER
4	4	WASHER
5	5	COLLAR
7	7	SCREW
6	6	SPRING
3	3	SHAFT
8	8	BEARING
9	9	BEARING
32	32	BRACKET
35	35	PLATE
36	36	SCREW
37	37	SCREW
33	33	SCREW
34	34	SCREW
25	25	SHAFT
23	23	BRACKET
24	24	BRACKET
26	26	SCREW
22	22	SCREW
20	20	BRACKET
21	21	BRACKET
19	19	BRACKET
18	18	BRACKET
27	27	SCREW
28	28	SCREW
29	29	BRACKET
30	30	SCREW
16	16	LEVER
55	55	LEVER
13	13	LEVER
14	14	BRACKET
15	15	SCREW
10	10	BRACKET
11	11	WASHER
12	12	SPRING
45	45	SPRING
39	39	BRACKET
40	40	LEVER
48	48	BRACKET
49	49	PLATE
50	50	PLATE
51	51	SCREW
52	52	SCREW
53	53	SCREW
54	54	PIN
46	46	SCREW
47	47	SCREW
41	41	SPRING
42	42	SCREW
43	43	WASHER
44	44	SCREW
56	56	SPRING
57	57	SCREW
58	58	BRACKET
59	59	SCREW
60	60	SCREW

Page 28 — THREAD TAKE-UP LEVER COMPONENTS

Juki MF-7523 parts on page 28

Ref	Part number	Part name	Qty
	13325808	NIPPER PLATE SUPPORT	1
	13325907	NIPPER PLATE	1
	13326004	NIPPER GUIDE PLATE	1
	13326103	SPRING	1
	13326202	SHOULDER SCREW	1
	SM4040655SP	SCREW M4 L=6	1
	13326707	THREAD GUIDE	1
	40085995	FINGER GUARD
	SM4040655SP	SCREW	2
	WP0450801SC	WASHER 4.5X10X0.8	2
	70001544	TAKE-UP COVER	1
	SM1040750TP	SCREW M4 L=7	1
	70001545	FINGER GUARD	1

Page 29 — SPREADER COMPONENTS

Juki MF-7523 parts on page 29

Ref	Part number	Part name	Qty
1	1	BRACKET
2	2	BRACKET
3	3	BRACKET
4	4	SHAFT
5	5	COLLAR
6	6	BRACKET
7	7	WASHER
8	8	NUT
9	9	SCREW
10	10	SHAFT
11	11	BEARING
12	12	SCREW
13	13	SLEEVE
14	14	SLEEVE
15	15	BRACKET
16	16	CONNECTING ROD
17	17	SLEEVE
18	18	PIN
19	19	PIN
20	20	SCREW
21	21	WASHER
22	22	SLEEVE
23	23	SEAL
24	24	WASHER
25	25	BRACKET
26	26	SPRING
27	27	BRACKET
28	28	SCREW
29	29	SHAFT
30	30	SCREW
31	31	NUT

Page 30 — SPREADER COMPONENTS

Juki MF-7523 parts on page 30

Ref	Part number	Part name	Qty
	13328158	ASSY UPPER LPR MECH	1
	13328109	CONNROD FOR UPPER LPR	1
	13328000	UPPER LOOPER ECCENTRIC	1
	13328208	STUD	1
	SM8050412TP	SCREW M5 L=4	2
	70001555	DRIVING ARM	1
	WP0550800SP	WASHER 5.5X10X0.8	1
	NM6050001SC	NUT M5X0.8 TYPE1	1
	SM6061402TP	SCREW M6 L=14	1
	70001558	UPPER LOOPER SHAFT	1
	13399209	COLLAR	2
	SM8040412TP	SCREW M4X4	4
	13329008	BUSHING REAR	1
	70001559	BUSHING,FRONT	1
	13328554	ASSY UPPER LPR MECH 2	1
	13328505	CRANK ROD	1
	13328604	UPPER LOOPER ROCKER	1
	13328703	UP LPR SHAFT VERTICAL	1
	CG303000000	COTTON OIL WICK D=3	0.05
	SM9061050TP	SCREW M6 L=10	1
	SM8060612TP	SCREW M6 L=6	1
	13329206	BUSHING VERTICAL	1
	13338900	OIL SEAL	1
	WP1022016SH	WASHER	1
	CS1000881TP	THRUST COLLAR D=10 W=8	1
	SM8050412TP	SCREW M5 L=4	2
	13328802	UPPER LOOPER HOLDER	1
	SM6041200SP	SCREW M4 L=12	1
	70004223	UPPER LOOPER	1
	SM6041000SP	SCREW M4 L=10	1
	70004224	UPPER LOOPER	1

Page 31 — LOWER THREAD CAM COMPONENTS

Juki MF-7523 parts on page 31

Ref	Part number	Part name	Qty
1	1	BELT
4	4	WASHER
5	5	PULLEY
6	6	BEARING
7	7	SHAFT
8	8	COLLAR
9	9	SCREW
10	10	WASHER
11	11	CAM
12	12	SLEEVE
13	13	BEARING
14	14	ARM
15	15	SCREW
16	16	WASHER
17	17	SPRING
18	18	PIN
19	19	BRACKET
20	20	SCREW
21	21	SCREW
22	22	NUT
23	23	WASHER
24	24	PLATE
25	25	BRACKET
26	26	WASHER
27	27	SCREW
28	28	BRACKET
29	29	SPRING
30	30	SCREW
31	31	WASHER
32	32	SCREW
33	33	WASHER
34	34	SCREW
35	35	BRACKET
36	36	SCREW
37	37	BRACKET
38	38	COLLAR
39	39	SCREW
40	40	PULLEY
41	41	WASHER
42	42	SCREW
43	43	SCREW
44	44	BRACKET
45	45	WASHER

Page 32 — LOWER THREAD CAM COMPONENTS

Juki MF-7523 parts on page 32

Ref	Part number	Part name	Qty
	70004637	BELT_TAKE_UP	1
	70001582	THREAD GUIDE PLATE	1
	40087068	CAM THREAD CATCH	1
	70001580	SPROCKET TAKE UP	1
	SM8050612TP	SCREW M5X6	2
	70001581	WASHER	1
	70001572	SHAFT TAKE UP	1
	CS1000881TP	THRUST COLLAR D=10 W=8	1
	SM8050612TP	SCREW M5X6	2
	40023441	OIL SEAL	1
	70001573	BUSHING A TAKE UP	1
	40023481	BUSHING B TAKE UP	1
	40023441	OIL SEAL	1
	13332309	BASE TAKE UP PLATE	1
	SL4041281SC	SCREW M4 L=12	1
	13333208	WASHER	1
	13332903	SPRING	1
	SM4040655SP	SCREW M4 L=6	1
	13332804	BRACKET	1
	SM4040655SP	SCREW M4 L=6	2
	SD064024CSP	SHOULDER SCREW D=6.35 H=2.4	1
	WZ0641510KP	WAVED WASHER 6.4X11X0.3	1
	WP0410516SD	PLAIN WASHER	1
	70001579	TAKE UP PLATE	1
	40100791	EYELET A ASSY	1
	WP0280500SC	WASHER	1
	SM48504C5SP	SCREW	1
	13333307	LPR THD DISC UPPER	1
	40100793	LPR THD GUIDE BASE ASSY	1
	13333505	TENSION POST	1
	13333604	LOOPER CAM SPRING	1
	NM6030001SC	NUT M3X0.5 TYPE1	1
	WP0280500SC	WASHER	1
	SM4850455SP	SCREW	1
	70001575	EYELET C ASSY	1
	SM4040655SP	SCREW M4 L=6	1
	13333703	EYELET D	1
	40019335	ASSY TAKE UP	2
	SM8060552TP	SCREW M6 L=5	1
	TA2101002R0	RUBBER PLUG	1
	70001584	SPRING COLLAR	1
	SM6850802TN	SCREW M2.5 L=8	1
	NM6850001SC	NUT M2.5X0.45 TYPE1	1
	70001585	THREAD GUIDE	1
	70001583	THREAD GUIDE PLATE SPRING	1

Page 33 — NEEDLE GUARD COMPONENTS

Juki MF-7523 parts on page 33

Ref	Part number	Part name	Qty
	1	NEEDLE GUARD COMPONENTS
	2
	3
	4
	5
	6
	7
	8
	9
	10
	11
	12
	13
	14

Page 34 — NEEDLE GUARD COMPONENTS

Juki MF-7523 parts on page 34

Ref	Part number	Part name	Qty
	40052924	REAR NEEDLE GUARD	1
	13334701	FRONT NDL GUARD	1
	SM4850455SP	SCREW	1
	70001592	NEEDLE GUARD BLOCK	1
	70001587	FORK NEEDLE GUARD	1
	SM8050612TP	SCREW M5X6	1
	70001590	NEEDLE GUARD SHAFT	1
	70001591	BUSHING NEEDLE GUARD	1
	RO055200100	O-RING	1
	WP0621016SD	WASHER 6.2X13X1	1
	RE0500000K0	E-RING	1
	70001588	REAR NEEDLE GUARD HOLDER	1
	SM6051000SP	SCREW	1
	SM8040312TP	SCREW M4 L=3	1

Page 35 — LOOPER COMPONENTS

Juki MF-7523 parts on page 35

Ref	Part number	Part name	Qty
1	1	SHAFT
2	2	SLEEVE
3	3	CONNECTING ROD
4	4	SCREW
5	5	WASHER
6	6	SCREW
7	7	CLAMP
8	8	SCREW
9	9	CAP
10	10	SHAFT
11	11	COLLAR
12	12	SPRING
13	13	BRACKET
14	14	SHAFT
15	15	NUT
16	16	NUT
17	17	SHAFT
18	18	COLLAR
19	19	COLLAR
20	20	SCREW
21	21	BRACKET
22	22	SCREW
23	23	COLLAR
24	24	WASHER
25	25	COLLAR
26	26	SHAFT
27	27	COLLAR
28	28	BEARING
29	29	BRACKET
30	30	SPRING
31	31	LOOPER
32	32	SCREW

Page 36 — LOOPER COMPONENTS

Juki MF-7523 parts on page 36

Ref	Part number	Part name	Qty
	13337357	ECC LOOPER AVOID ASSY	1
	13337308	ECC LOOPER AVOID
	13337407	LOOPER ROD AVOID	1
	SM6041202TP	SCREW M4X0.7 L=12	2
	13337506	PIN LOOPER AVOID	1
	SM8060612TP	SCREW M6 L=6	2
	13338801	BALANCE WEIGHT LP	1
	SM6041000SP	SCREW M4 L=10	2
	TA160406R0	PRUG	1
	70001601	BUSHING LPR RIGHT	1
	WP1021026SH	WASHER	1
	RE0700000K0	E-RING 7	1
	13337605	CRANK LOOPER AVOID	1
	SM8050612TP	SCREW M5X6	1
	WP0550800SP	WASHER 5.5X10X0.8	1
	NM6050001SC	NUT M5X0.8 TYPE1	1
	13338504	LOOPER SHAFT AVOID	1
	TA0500601M0	PLUG D=5X5.4 L=6	2
	70001602	BUSHING LPR LEFT	1
	40052522	SCREW	1
	13337704	COLLAR LOOPER AVOID	1
	SM6041000SP	SCREW M4 L=10	1
	13337803	LOOPER AVOID PIN	1
	WP0461516SH	WASHER	2
	70001603	BUSHING LPR SHAFT REAR	1
	40050448	LOOPER SHAFT	1
	70001604	BUSHING LPR SHAFT FRONT	1
	13338900	OIL SEAL	1
	40050449	LOOPER HOLDER	1
	SM6051402TP	SCREW M5X0.8 L=14	1
	13337902	LOOPER	1
	SM6040750TP	SCREW M4 L=7	1

Page 37

Juki MF-7523 parts on page 37

Ref	Part number	Part name	Qty
1	1	SHAFT
2	2	COLLAR
3	3	SCREW
4	4	SPRING
5	5	SPRING
6	6	SPRING
7	7	SPRING
8	8	SHAFT
9	9	CAP
10	10	CAP
11	11	WASHER
12	12	COLLAR
13	13	WASHER
14	14	SPRING
15	15	COLLAR
16	16	SPRING
17	17	SPRING
18	18	PLATE
19	19	PLATE
20	20	SCREW
21	21	BRACKET
22	22	BRACKET
23	23	SCREW

Page 39 — LUBRICATION COMPONENTS

Juki MF-7523 parts on page 39

Ref	Part number	Part name	Qty
1	1	FLANGE
2	2	FLANGE
3	3	FLANGE
4	4	FILTER
5	5	HOSE CLAMP
6	6	BRACKET
7	7	BRACKET
8	8	BRACKET
9	9	BRACKET
10	10	BRACKET
11	11	BRACKET
12	12	BRACKET
13	13	BRACKET
14	14	BRACKET
15	15	BRACKET
16	16	BRACKET
17	17	BRACKET
18	18	BRACKET
19	19	BRACKET
20	20	CLAMP
21	21	BRACKET
22	22	BRACKET
23	23	BRACKET
24	24	BRACKET
25	25	CLAMP
26	26	BRACKET
27	27	CLAMP
28	28	BRACKET
29	29	BRACKET
30	30	BRACKET
31	31	BRACKET
32	32	SCREW
33	33	BRACKET
34	34	COVER
35	35	SCREW
36	36	BRACKET
37	37	BRACKET
38	38	BRACKET
39	39	PUMP
40	40	PUMP BODY
41	41	SHAFT
42	42	BEARING
43	43	SHAFT
44	44	SCREW
45	45	SHAFT
46	46	SHAFT
47	47	BRACKET
48	48	BRACKET
49	49	BRACKET
50	50	SPRING
51	51	SCREW
52	52	SCREW
53	53	BRACKET
54	54	SCREW
55	55	SCREW
56	56	TUBE
57	57	TUBE
58	58	TUBE
59	59	TUBE
60	60	SCREW
61	61	BRACKET
62	62	BRACKET
63	63	BRACKET
64	64	BRACKET
65	65	BRACKET
66	66	BRACKET
67	67	BRACKET
68	68	BRACKET
69	69	BRACKET
70	70	TUBE
71	71	BRACKET
72	72	BRACKET
73	73	BRACKET
74	74	BRACKET
75	75	BRACKET
76	76	BRACKET
77	77	BRACKET
78	78	BRACKET
79	79	BRACKET
80	80	BRACKET
81	81	BRACKET
83	83	BRACKET
84	84	BRACKET
85	85	BRACKET
86	86	BRACKET

Page 40 — LUBRICATION COMPONENTS

Juki MF-7523 parts on page 40

Ref	Part number	Part name	Qty
	13345202	FILTER COVER	1
	SM4041055SP	SCREW	4
	13344809	GASKET O	1
	13142500	CARTRIDGE FILTER	1
	13343801	FITTING FILTER	1
	13346556	ASSY OIL SUPPLY	1
	SM4040655SP	SCREW M4 L=6	1
	13345855	OIL SUPPLY ASSY	1
	SM4040655SP	SCREW M4 L=6	1
	70001634	ASSY OIL PIPE	1
	SQ2060442SD	CONNECTING SCREW	3
	SQ0000454MZ	CONNECTING SCREW	1
	SQ0000453MZ	CONNECTING SCREW	1
	BP30000010R	VINYL PIPE	0.04
	SQ0000452MZ	CONNECTING SCREW	1
	SQ2060441SD	CONNECTING SCREW	1
	BP30000010R	VINYL PIPE	0.12
	BP30000010R	VINYL PIPE	0.12
	BP30000010R	VINYL PIPE	0.19
	23629306	PIPE STOPPER A	17
	BP30000010R	VINYL PIPE	0.1
	BP30000010R	VINYL PIPE	0.2
	23629504	DISTRIBUTOR	3
	13346705	CONNECTING SCR BRACKET	1
	SQ2050452MZ	CONNECTING SCREW	1
	NM6050001SC	NUT M5X0.8 TYPE1	1
	SM4040655SP	SCREW M4 L=6	2
	40024405	ASSY OIL PAN	1
	13345509	OIL PAN	1
	13170105	RUBBER RING	1
	13171004	DRAIN SCREW	1
	SM6061802TP	SCREW M6 L=18	6
	13345608	O RING	1
	13345905	COVER PLATE	1
	SM4040655SP	SCREW M4 L=6	2
	7000636	OIL TUBE HOLDER	1
	SM4040655SP	SCREW	1
	13346101	OIL SIGHT GAUGE	1
	13345459	ASSY PUMP 2-STAGE	1
	13343108	OIL PUMP HOUSING	1
	13343009	WORM WHEEL	2
	SM8050412TP	SCREW M5 L=4	1
	13345400	OIL PUMP SHAFT LARGE	2
	13228309	OIL PUMP PINION	2
	13228200	OIL PUMP PINION	1
	13227905	GEAR PUMP SHAFT	1
	13343405	OIL PUMP SPACER	1

Page 41

Juki MF-7523 parts on page 41

Ref	Part number	Part name	Qty
1	1	FLANGE
2	2	GASKET
3	3	PIPE
4	4	FILTER
5	5	UNION
6	6	BRACKET
7	7	PIPE
8	8	PIPE
9	9	PIPE
10	10	PIPE
11	11	UNION
12	12	UNION
13	13	UNION
14	14	PIPE
15	15	UNION
16	16	UNION
17	17	UNION
18	18	PIPE
19	19	UNION
20	20	CLAMP
21	21	UNION
22	22	UNION
23	23	UNION
24	24	BRACKET
25	25	CLAMP
26	26	UNION
27	27	CLAMP
28	28	PIPE
29	29	PIPE
30	30	UNION
31	31	UNION
32	32	SCREW
33	33	PIPE
34	34	COVER
35	35	SCREW
36	36	UNION
37	37	UNION
38	38	BRACKET
39	39	VALVE
40	40	BODY
41	41	PLUG
42	42	O-RING
43	43	SPRING
44	44	SPRING
45	45	SPRING
46	46	PLUNGER
47	47	BASE
48	48	BODY
49	49	BASE
50	50	SPRING
51	51	SCREW
52	52	UNION
53	53	UNION
54	54	SPRING
55	55	SPRING
56	56	PIPE
57	57	PIPE
58	58	PIPE
59	59	PIPE
60	60	SCREW
61	61	BRACKET
62	62	PIPE
63	63	PIPE
64	64	UNION
65	65	UNION
66	66	PIPE
67	67	PIPE
68	68	UNION
69	69	UNION
70	70	PIPE
71	71	BRACKET
72	72	UNION
73	73	BRACKET
74	74	UNION
75	75	UNION
76	76	UNION
77	77	UNION
78	78	PIPE
79	79	PIPE
80	80	BRACKET
81	81	UNION
82	82	UNION
83	83	UNION
84	84	UNION
85	85	UNION
86	86	SCREW
87	87	UNION
145	145	SPRING

Page 43

Juki MF-7523 parts on page 43

Ref	Part number	Part name	Qty
	1	THREAD STAND COMPONENTS
	2
	3
	4
	5
	6
	7
	8
	9
	10
	11
	12
	13
	14
	15
	16
	17
	18
	19
	20
	21
	22
	23
	24
	25
	26
	27
	28
	29
	30
	31

Page 44 — THREAD STAND COMPONENTS

Juki MF-7523 parts on page 44

Ref	Part number	Part name	Qty
	40106591	THREAD STAND ASM.	1
	40106575	SPOOL REST LONG ARM UPPER	1
	40085794	THREAD GUIDE	5
	40085795	THREAD GUIDE BUSHING	5
	40085787	SPOOL REST ARM UPPER	1
	40085793	SPOOL REST ROD RUBBER CAP	1
	40085785	SPOOL REST ROD UPPER	1
	40085792	SPOOL REST ROD JOINT	1
	40106581	THREAD GUIDE 5	1
	40106580	THREAD GUIDE UNDER BASE	1
	40106576	THREAD GUIDE ARM	1
	40106579	THREAD GUIDE ARM BASE	1
	40085784	SPOOL REST ROD LOWER	1
	40085791	SPOOL RETAINER	5
	40085790	SPOOL PIN	5
	40085789	SPOOL REST CUSHION	5
	40085788	SPOOL REST	5
	40085786	SPOOL REST ARM LOWER	1
	40106574	SPOOL REST LONG ARM LOWER	1
	40096327	SPOOL REST ARM UPPER SCREW	2
	40085796	SPOOL REST ROD RUBBER CUSHION	2
	40096325	SPOOL REST ROD NUT	1
	40096326	SPOOL REST ARM LOWER SCREW	4
	SM4041201SC	SCREW M4X0.7 L=12	3
	SM4051405SE	SCREW M5 L=14	2
	SM4042501SC	SCREW M4X0.7 L=25	1
	NM6040002SC	NUT M4X0.7 TYPE2	4
	NM6050001SE	NUT M5X0.8 TYPE1	11
	WP1612616SE	WASHER 16X30X2.6	2
	WP0531001SC	WASHER M5	5
	WS0510002KN	SPRING WASHER M5	5

Page 45 — GAUGE PARTS COMPONENTS

Juki MF-7523 parts on page 45

Ref	Part number	Part name	Qty
	1-2	1-2
	3-5	3-5
	6	6
	7-8	7-8
	9	9
	10~12	10~12
	13~16	13~16
	17-18	17-18
	19~23	19~23
	24~28	24~28
	29-30	29-30
	31	31
	32	32
	33	33
	34	34
	35-36	35-36
	37	37
	39	39
	39-40	39-40
	41	41
	42	42
	43	43
	44	44
	45	45
	46	46
	47-48	47-48
	49	49
	49-50	49-50
	51	51
	52-53	52-53
	54	54

Page 46

Juki MF-7523 parts on page 46

Ref	Part number	Part name	Qty
	13350004	NEEDLE HEAD 32
	13350103	NEEDLE HEAD 40
	13350202	NEEDLE HEAD 48
	13350301	NEEDLE HEAD 56
	13350400	NEEDLE HEAD 64
	MUY128S1000	NEEDLE UYX128GAS (S BALL POINT) #10S
	MUY128S1000	NEEDLE UYX128GAS (S BALL POINT) #10S
	MUY128S1400	NEEDLE UYX128GAS (S BALL POINT) #14S
	SM8030312TP	SCREW M3 L=3
	40058587	THROAT PLATE
	40058706	THROAT PLATE
	70004610	THROAT_PLATE
	40040514	THROAT PLATE
	40058033	THROAT PLATE
	40040513	THROAT PLATE
	40087878	THROAT PLATE
	40058588	DIFF FEED DOG
	13357603	DIFF FEED DOG
	40090133	PRESSER FOOT ASSY
	40090196	PRESSER FOOT ASSY
	40090197	PRESSER FOOT ASSY
	40082974	PRESSER FOOT ASSY
	70004613	PRESSER FOOT ASSY
	40090130	PRESSER FOOT BOTTOM
	40090131	PRESSER FOOT BOTTOM
	40090132	PRESSER FOOT BOTTOM
	40082975	PRESSER FOOT BOTTOM
	70004612	PRESSER_FOOT_BOTTOM
	40070224	PRESSER FOOT HINGE
	13467907	PRESSER_FOOT_SHANK
	SM6040800SP	SCREW
	13375209	PIVOT PIN
	SM8030412TP	SCREW
	13377106	SPRING
	40070226	P_F YIELDING SECTION
	40038032	YIELDING SECTION
	40070227	GUIDE PLATE
	13468103	YIELDING_SECTION_PLATE
	SM1850600SP	SCREW
	SM1850600SP	SCREW
	40070231	PRESSER FOOT GUIDE
	SM6850400SP	SCREW M2.5 L=4
	WP0280500SC	WASHER
	SM8031002TP	SCREW
	NM6030001SD	NUT M3X0.5 TYPE1
	40070230	SPRING R
	40070229	SPRING L

Page 47 — GAUGE PARTS COMPONENTS

Juki MF-7523 parts on page 47

Ref	Part number	Part name	Qty
	19~23	19~23
	29~30	29~30
	31	31
	32	32
	33	33
	34	34
	44	44
	46	46
	37	37
	49	49
	39	39
	35~36	35~36
	47~48	47~48
	24~28	24~28
	42	42
	43	43
	41	41
	3~5	3~5
	1.2	1.2
	6	6
	9	9
	7.8	7.8
	52~53	52~53
	17~18	17~18
	13~16	13~16
	10~12	10~12
	54	54

Page 48 — GAUGE PARTS COMPONENTS

Juki MF-7523 parts on page 48

Ref	Part number	Part name	Qty
	13375308	SPRING,L
	PS0150065KP	SPRING PIN 1.5X6
	PS0150082KH	SPRING PIN
	SM8030312TP	SCREW M3 L=3
	13354204	MAIN FEED DOG
	13353701	MAIN FEED DOG
	70004611	THROAT PLATE

Page 49 — NEEDLE COOLING COMPONENTS

Juki MF-7523 parts on page 49

Ref	Part number	Part name	Qty
1	1	BRACKET
2	2	COVER
3	3	SCREW
4	4	TUBE
5	5	TUBE
6	6	BRACKET
7	7	TUBE
8	8	BRACKET
9	9	TUBE
10	10	CLAMP
11	11	SCREW

Page 50 — NEEDLE COOLING COMPONENTS

Juki MF-7523 parts on page 50

Ref	Part number	Part name	Qty
	40056919	SILICONE OIL TANK	1
	13429105	SILICONE OIL TANK CAP	1
	SM4050855SP	SCREW	1
	BT0600402EA	URETHANE TUBE CLEAR BLUE 6X4	0.15
	CQ3030000000	COTTON OIL WICK D=3	0.3
	70001644	SILICONE OIL CUP	1
	SM6030600SP	SCREW M3X0.5 L=6	2
	13348305	FELT	1
	11856101	NEEDLE COOLER PIN	1
	B3538112000	OIL RETURN TUBE HOLDER	1
	SM4040655SP	SCREW M4 L=6	1

Page 51

Juki MF-7523 parts on page 51

Ref	Part number	Part name	Qty
1	2	ACCESSORIES PARTS COMPONENTS
3	3	SCREW DRIVER
4	4	SCREW DRIVER
5	5	SPRING
6	6	NEEDLE
7	7	NEEDLE
8	8	OIL BOTTLE
9	9	FOOT
10	10	FOOT
11	11	BOBBIN CASE
12	12	BASE PLATE
13	13	SCREW
14	14	BRACKET
15	15	SCREW DRIVER
16	16	WRENCH
17	17	BRACKET
18	18	BRACKET
19	19	SCREW
20	20	WASHER
21	21	SCREW
22	22	WASHER
23	23	BRACKET
24	24	BRACKET
25	25	BRACKET
26	26	SCREW
27	27	SCREW
28	28	BRACKET
29	29	HOOK
30	30	HOOK
31	31	BRACKET
32	32	HOOK
33	33	HOOK
34	34	HOOK
35	35	SCREW
36	36	FILTER
37	37	NEEDLE
38	38	HOOK
39	39	ACCESSORIES PARTS COMPONENTS
40	40	ACCESSORIES PARTS COMPONENTS
41	41	SCREW DRIVER
42	42	SCREW DRIVER
43	43	NEEDLE

Page 52

Juki MF-7523 parts on page 52

Ref	Part number	Part name	Qty
	40013913	ACCESSORY BAG ASSY	1
	22932800	ACCESSORIE BAG	1
	22933105	SCREW DRIVER	1
	12347308	SCREW DRIVER (SMALL)	1
	13160304	S SHAPED HOOK	2
	70001840	CHAIN	1
	12288403	TWEEZERS	1
	MML018800CB	JU KI CORPORATION GENUINE OIL 18	1
	40072505	ISOLATOR	1
	13155403	ISOLATOR	3
	13348966	ASSY BOLT SET	1
	13348859	SUPPORT PLATE ASSY	2
	13302203	SCREW	1
	B9101490000	DRIVER	1
	40032763	HEXAGONAL DRIVER(1.5)	1
	J106600000B	HEXAGONAL ROD SPANNER KEY 2	1
	40099374	BINDER BRACKET ASSY	1
	40099373	BINDER BRACKET	1
	SM5050855SN	SCREW M5 L=8	2
	WP0550836SC	WASHER 5.5X12X0.8	2
	SM4040855SP	SCREW	2
	WP0450801SP	WASHER	2
	70001964	HEM GUIDE ASSY	1
	70001967	HEM GUIDE	1
	70001962	HEM GUIDE BASE 1	1
	40019379	KNOB SCREW	2
	SM1040801SC	SCREW M4X0.7 L=8	1
	70001963	HEM GUIDE BASE 2	1
	70001813	COVERING GUIDE RIGHT	1
	70001814	COVERING GUIDE LEFT	1
	40099375	BRACKET B	1
	70001838	COVERING GUARD L	1
	70001839	COVERING GUARD R	1
	70001846	BRACKET	1
	SM6040650TP	SCREW	2
	40066644	HEAD COVER	1
	MUY128S1003	NEEDLES(PACKAGE_OF_3)	1
	70001842	GUIDE LEFT	1
	70004227	ACCESSORY BAG ASSY
	22932800	ACCESSORIE BAG	1
	22933105	SCREW DRIVER	1
	12347308	SCREW DRIVER (SMALL)	1
	12288403	TWEEZERS	1

Page 53 — LIST FOR INFORMATION OF CHANGE

Juki MF-7523 parts on page 53

Ref	Part number	Part name	Qty
1	133-08804	133-08804
1	700-04635	700-04635
1	700-01987	700-01987
1	700-04637	700-04637
1	401-06592	401-06592
1	401-06591	401-06591
	133-52307	133-52307
	133-52406	133-52406
	700-01946	700-01946
	700-01947	700-01947

Page 54 — NUMERICAL INDEX OF PARTS

Juki MF-7523 parts on page 54

Ref	Part number	Part name	Qty
9	10753309		2
64	11856101		40
9	11856101		48
43	12288403		50
42	12347308		50
10	13123302		22
5	13140504		36
	13142500		38
9~10	13155403		50
5	13160304		50
30	13170105		38
31	13171004		38
13	13217401		22
12	13217500		22
8	13217708		22
46	13227905		38
45	13228200		38
44	13228309		38
12	13300801		2
13	13301700		2
25	13301809		4
53	13302104		4
53	13302104		6
24	13302203		4
13	13302203		50
49	13302302		4
49	13302302		6
46	13302708		4
54	13304209		6
48	13304308		4
48	13304308		6
45	13305107		4
48	13307251		10
53	13307301		10
13	13307509		8
76	13307707		10
67~69	13307806		10
8	13308457		8
37	13308507		8
28	13308705		8
73	13309208		10
67~69	13309307		10
67~69	13309406		10
47	13311006		12
48	13311204		14
45	13311253		12
54	13311303		14
65	13311451		14
58	13311501		14
67	13311600		14
64	13311808		14
63	13311907		14
62	13311956		14
55~57	13312103		14
55~57	13312202		14
55~57	13312301		14
3	13313101		12
4	13313309		12
11	13313804		12
15	13314109		12
17	13314356		12
8	13315908		12
12	13317201		16
19	13317300		16
20~22	13317409		16
20~22	13317508		16
20~22	13317607		16
24	13317706		16
61	13317805		18
57	13317904		18
48	13318001		18
49	13318100		18
47	13318209		16
54	13318308		18
63	13318506		18
77	13318605		18
14~16	13318704		16
14~16	13318803		16
14~16	13318902		16
42	13319009		16
73	13319405		18
76	13319504		18
32	13319702		16
35	13319900		16
34	13319959		16
36	13320007		16
37	13320106		16
18	13320304		22
19	13320403		22
4	13321203		22
28	13321708		16
81	13322003		18
84	13322102		18
79	13322201		18
30	13322409		16
25	13323209		22
8~10	13323308		16
8~10	13323407		16
8~10	13323506		16
5	13323803		16
64	13324108		8
64	13324108		10
5	13324504		24
8	13324603		24
10	13324702		24
14	13324900		24
16	13325006		24
24	13325204		24
48	13325808		26
49	13325907		26
50	13326004		26
51	13326103		26
52	13326202		26
39	13326301		24
40	13326400		24
42	13326509		24
44	13326608		24
54	13326707		26
60	13326806		14
35	13326905		24
3	13328000		28
2	13328109		28
1	13328158		28
4	13328208		28
16	13328505		28
15	13328554		28
17	13328604		28
18	13328703		28
27	13328802		28
13	13329008		28
22	13329206		28
14	13332309		30
19	13332804		30
17	13332903		30
16	13333208		30

Page 55 — NUMERICAL INDEX OF PARTS

Juki MF-7523 parts on page 55

Ref	Part number	Part name	Qty
28	13333307
30	13333505
31	13333604
37	13333703
2	13334701
2	13337308
1	13337357
3	13337407
5	13337506
13	13337605
21	13337704
23	13337803
31	13337902
17	13338004
7	13338801
23	13338900
28	13338900
21	13340005
22	13340104
6	13340302
41	13340909
40	13343108
48	13343207
49	13343306
47	13343405
62	13343603
5	13343801
61	13343900
66	13344056
71	13344155
68	13344502
67	13344601
69	13344700
3	13344809
78	13345053
1	13345202
43	13345400
39	13345459
29	13345509
33	13345608
49	13345855
34	13345905
38	13346101
6	13346556
24	13346705
19	13348008
8	13348305
12	13348859
11	13348966
1-2	13350004
1-2	13350103
3-5	13350202
3-5	13350301
3-5	13350400
52-53	13353701
52-53	13354204
17-18	13357603
17-18	13358304
32	13375209
47-48	13375308
34	13377106
71	13398409
11	13399209
3	13406707
28	13409800
2	13426903
2	13429105
29-30	13467907
37-38	13468103
34	22901805
2	22902506
11	22924708
40	22932800
41	22933105
43	22945505
41	22945802
18	23537202
9	23612609
76	23629306
76	23629306
23	23629504
70	23630007
7	26019000
25	30391601
22	31013808
53	40004749
1	40013913
5	40017824
21	40018443
10	40018922
38	40019335
26	40019379
13	40023441
12	40023481
28	40024405
15	40032763
14	40033341
43	40035711
35-36	40038032
3	40039630
1	40040206
13-16	40040513
13-16	40040514
9	40042363
10	40042364
11	40042365
12	40042366
26	40050448
29	40050549
20	40052522
1	40052924
1	40056919
13-16	40058033
10-12	40058587
10-12	40058706
2	40065785
36	40066644
29-30	40070224
35-36	40070226
37-38	40070227
47-48	40070229
46	40070230
41	40070231
2	40070573
1	40070574
9-10	40072505
21	40082196
19-23	40082974
24-28	40082975
13-16	40082978
13	40085784
7	40085785
18	40085786
5	40085787
17	40085788

Page 56 — NUMERICAL INDEX OF PARTS

Juki MF-7523 parts on page 56

Ref	Part number	Part name	Qty
16	40085789	70001424
15	40085790	70001426
14	40085791	70001431
8	40085792	70001436
6	40085793	70001437
3	40085794	70001439
4	40085795	70001440
21	40085796	70001441
55	40085995	70001442
3	40087068	70001443
24-28	40090130	70001444
24-28	40090131	70001445
24-28	40090132	70001447
19-23	40090133	70001448
19-23	40090196	70001451
19-23	40090197	70001453
22	40096325	70001477
23	40096326	70001478
20	40096327	70001480
4	40099371	70001481
50	40099373	70001483
50	40099374	70001485
50	40099375	70001486
30	40100791	70001487
30	40100793	70001488
36	40101602	70001489
36	40102003	70001490
42	40106574	70001491
42	40106575	70001492
42	40106576	70001493
42	40106579	70001494
42	40106580	70001495
42	40106581	70001498
42	40106591	70001499
2	70001407	70001500
2	70001409	70001505
2	70001411	70001506
4	70001414	70001507
4	70001415	70001508
2	70001416	70001509
4	70001418	70001510
4	70001420	70001510
2	70001421	70001511
2	70001422	70001512
4	70001423	70001513
18	70001424	70001514
26	70001426	70001515
27	70001431	70001516
58	70001436	70001517
45	70001437	70001518
46	70001439	70001521
44-56	70001440	70001522
59	70001441	70001523
60	70001442	70001524
51	70001443	70001525
65	70001444	70001526
2	70001445	70001527
25	70001447	70001528
26	70001448	70001530
30	70001451	70001531
31	70001453	70001532
37	70001477	70001533
35	70001478	70001535
5	70001480	70001536
6	70001481	70001537
9	70001483	70001540
13	70001485	70001541
19	70001486	70001542
29	70001487	70001543
32	70001488	70001544
33	70001489	70001545
34	70001490	70001546
39	70001491	70001548
42	70001492	70001555
43	70001493	70001558
22	70001494	70001559
25	70001495	70001572
21	70001498	70001573
7	70001499	70001575
66	70001500	70001579
2	70001505	70001580
74	70001506	70001581
94	70001507	70001582
96	70001508	70001583
29	70001509	70001584
62	70001510	70001585
62	70001510	70001587
43	70001511	70001588
60	70001512	70001589
72	70001513	70001590

Page 57 — NUMERICAL INDEX OF PARTS

Juki MF-7523 parts on page 57

Ref	Part number	Part name	Qty
8	70001591	70001591
4	70001592	70001592
10	70001601	70001601
19	70001602	70001602
25	70001603	70001603
27	70001604	70001604
1	70001610	70001610
4	70001612	70001612
18	70001613	70001613
19	70001614	70001614
16	70001615	70001615
17	70001616	70001616
15	70001617	70001617
8	70001620	70001620
63	70001630	70001630
73	70001631	70001631
79	70001632	70001632
80	70001633	70001633
10	70001634	70001634
36	70001636	70001636
57	70001638	70001638
59	70001639	70001639
6	70001644	70001644
44	70001659	70001659
29	70001813	70001813
30	70001814	70001814
64	70001830	70001830
63	70001831	70001831
27	70001837	70001837
32	70001838	70001838
33	70001839	70001839
6	70001840	70001840
38	70001842	70001842
34	70001846	70001846
27	70001959	70001959
25	70001962	70001962
28	70001963	70001963
23	70001964	70001964
24	70001967	70001967
87	70001975	70001975
60	70001976	70001976
8	70001978	70001978
22	70003316	70003316
44-56	70003331	70003331
34	70004184	70004184
9	70004197	70004197
29-31	70004223	70004223
29-31	70004224	70004224
39	70004227	70004227
46	70004371	70004371
39	70004484	70004484
35	70004489	70004489
62	70004493	70004493
10-12	70004610	70004610
54	70004611	70004611
24-28	70004612	70004612
19-23	70004613	70004613
15	70004630	70004630
16	70004631	70004631
18	70004632	70004632
17	70004633	70004633
1	70004635	70004635
1	70004637	70004637
6	70004640	70004640
27	70005086	70005086
67	B2556280000	B2556280000
10	B3215470000	B3215470000
10	B3538112000	B3538112000
14	B9101490000	B9101490000
21	B9214850000	B9214850000
77	BP30000010R	BP30000010R
77	BP30000010R	BP30000010R
4	BT0600402EA	BT0600402EA
29	CM300200001	CM300200001
65	CM30020001	CM30020001
26	CM301300001	CM301300001
23	CQ303000000	CQ303000000
19	CQ303000000	CQ303000000
5	CQ303000000	CQ303000000
85	CS1000881TP	CS1000881TP
85	CS1000881TP	CS1000881TP
23	CS1000881TP	CS1000881TP
6	CS1000881TP	CS1000881TP
25	CS1000881TP	CS1000881TP
8	CS1000881TP	CS1000881TP
60	EA9500B0100	EA9500B0100
16	J106600000B	J106600000B
8	MML018800CB	MML018800CB
7-8	MUY128S1000	MUY128S1000
37	MUY128S1003	MUY128S1003
7-8	MUY128S1400	MUY128S1400
32	NM6030001SC	NM6030001SC
45	NM6030001SD	NM6030001SD
19	NM6040000SN	NM6040000SN
57	NM6040000SN	NM6040000SN
86	NM6040000SN	NM6040000SN
27	NM6040002SC	NM6040002SC
69	NM6050001SC	NM6050001SC
45	NM6050001SC	NM6050001SC
8	NM6050001SC	NM6050001SC
16	NM6050001SC	NM6050001SC
26	NM6050001SC	NM6050001SC
28	NM6050001SE	NM6050001SE
27	NM6060001CP	NM6060001CP
43	NM6850001SC	NM6850001SC
49-50	PS0150065KP	PS0150065KP
22	PS0150082KH	PS0150082KH
49-50	PS0150082KH	PS0150082KH
58	PS0300162KH	PS0300162KH
34	PS0400082KP	PS0400082KP
20	PS0500142KP	PS0500142KP
40	RC0100001KP	RC0100001KP
70	RC0741013KP	RC0741013KP
3	RC1900002KP	RC1900002KP
42	RE0300000KO	RE0300000KO
11	RE0300000KO	RE0300000KO
55	RE0500000KO	RE0500000KO
11	RE0500000KO	RE0500000KO
12	RE0700000KO	RE0700000KO
51	RO055200100	RO055200100
9	RO055200100	RO055200100
2	RO068190100	RO068190100
82	RO137230100	RO137230100
42	RO148240200	RO148240200
7	RO158240100	RO158240100
10	RO195240100	RO195240100
41	SB120001500	SB120001500
70	SB120001900	SB120001900
55	SB120002200	SB120002200
49-52	SB30800110A	SB30800110A
49-52	SB30800110B	SB30800110B
49-52	SB30800110C	SB30800110C
49-52	SB30800110D	SB30800110D
20	SD0640246SP	SD0640246SP
21	SD0640246CSP	SD0640246CSP

Page 58 — NUMERICAL INDEX OF PARTS

Juki MF-7523 parts on page 58

Ref	Part number	Part name	Qty
16	SD070020CTP	SD070020CTP
24	SD070058CTP	SD070058CTP
33	SD0801326TH	SD0801326TH
15	SL4041281SC	SL4041281SC
33	SM1030400SP	SM1030400SP
38	SM1040055SP	SM1040055SP
59	SM1040100TP	SM1040100TP
7	SM1040800SP	SM1040800SP
27	SM1040801SC	SM1040801SC
11	SM10414C0SP	SM10414C0SP
39-40	SM1850600SP	SM1850600SP
17	SM4030455SN	SM4030455SN
18	SM4030855SN	SM4030855SN
61	SM4030855SN	SM4030855SN
27	SM4030855SN	SM4030855SN
82	SM4030855SN	SM4030855SN
51	SM4040555SP	SM4040555SP
56	SM40405C5SP	SM40405C5SP
23	SM4040655SP	SM4040655SP
56	SM4040655SP	SM4040655SP
56	SM4040655SP	SM4040655SP
24	SM4040655SP	SM4040655SP
10	SM4040655SP	SM4040655SP
53	SM4040655SP	SM4040655SP
53	SM4040655SP	SM4040655SP
36	SM4040655SP	SM4040655SP
23	SM4040655SP	SM4040655SP
81	SM4040655SP	SM4040655SP
81	SM4040655SP	SM4040655SP
11	SM4040655SP	SM4040655SP
30	SM4040855SP	SM4040855SP
37	SM4040855SP	SM4040855SP
21	SM4040855SP	SM4040855SP
8	SM4041055SP	SM4041055SP
55	SM4041055SP	SM4041055SP
29	SM4041055SP	SM4041055SP
41	SM4041055SP	SM4041055SP
15	SM4041055SP	SM4041055SP
20	SM4041055SP	SM4041055SP
2	SM4041055SP	SM4041055SP
24	SM404115C	SM404115C
36	SM4041655SP	SM4041655SP
26	SM4042501SC	SM4042501SC
3	SM4050855SP	SM4050855SP
66	SM4051055SP	SM4051055SP
65	SM405125SP	SM405125SP
14	SM405125SP	SM405125SP
25	SM4051405SE	SM4051405SE
21	SM4060801SE	SM4060801SE
34	SM4850455SP	SM4850455SP
3	SM4850455SP	SM4850455SP
37	SM48504C5SP	SM48504C5SP
27	SM48504C5SP	SM48504C5SP
6	SM5050855SN	SM5050855SN
19	SM5050855SN	SM5050855SN
56	SM6030402TP	SM6030402TP
39	SM6030600SP	SM6030600SP
7	SM6030600SP	SM6030600SP
38	SM6030800SP	SM6030800SP
51	SM6040600SP	SM6040600SP
10	SM6040602TP	SM6040602TP
35	SM6040650TP	SM6040650TP
32	SM6040750TP	SM6040750TP
22	SM60407C0TP	SM60407C0TP
14	SM6040800SP	SM6040800SP
38	SM6040800SP	SM6040800SP
47	SM6041000SP	SM6041000SP
31	SM6041000SP	SM6041000SP
53	SM6041000SP	SM6041000SP
53	SM6041000SP	SM6041000SP
31	SM6041000SP	SM6041000SP
34	SM6041000SP	SM6041000SP
30	SM6041000SP	SM6041000SP
22	SM6041000SP	SM6041000SP
12	SM6041002TP	SM6041002TP
14	SM6041200SP	SM6041200SP
28	SM6041200SP	SM6041200SP
84	SM6041200SP	SM6041200SP
23	SM6041202TP	SM6041202TP
4	SM6041202TP	SM6041202TP
50	SM6042000SP	SM6042000SP
23	SM6050800SP	SM6050800SP
13	SM6051000SP	SM6051000SP
30	SM6051002TP	SM6051002TP
1	SM6051002TP	SM6051002TP
59	SM6051202TP	SM6051202TP
59	SM6051202TP	SM6051202TP
39	SM6051400SP	SM6051400SP
12	SM6051402TP	SM6051402TP
30	SM6051402TP	SM6051402TP
59	SM6051602TP	SM6051602TP
68	SM6051602TP	SM6051602TP
55	SM6051602TP	SM6051602TP
75	SM6061200SP	SM6061200SP
28	SM6061200SP	SM6061200SP
75	SM6061200TP	SM6061200TP
61	SM6061402TP	SM6061402TP
61	SM6061402TP	SM6061402TP
38	SM6061402TP	SM6061402TP
9	SM6061402TP	SM6061402TP
32	SM6061802TP	SM6061802TP
26	SM60625C0TP	SM60625C0TP
42	SM6850400SP	SM6850400SP
42	SM6850802TN	SM6850802TN
15	M7051460TP	M7051460TP
26	SM8030312TP	SM8030312TP
51	SM8030312TP	SM8030312TP
51	SM8030312TP	SM8030312TP
33	SM8030412TP	SM8030412TP
44	SM8030412TP	SM8030412TP
50	SM8030412TP	SM8030412TP
20	SM8040412TP	SM8040412TP
53	SM8040512TP	SM8040512TP
12	SM8040612TP	SM8040612TP
44	SM8040612TP	SM8040612TP
50	SM8040612TP	SM8040612TP
83	SM8040612TP	SM8040612TP
99	SM8050412TP	SM8050412TP
99	SM8050412TP	SM8050412TP
26	SM8050412TP	SM8050412TP
42	SM8050412TP	SM8050412TP
86	SM8050612TP	SM8050612TP
86	SM8050612TP	SM8050612TP
7	SM8050612TP	SM8050612TP
9	SM8050612TP	SM8050612TP
6	SM8050612TP	SM8050612TP
14	SM8050612TP	SM8050612TP
95	SM8050812TP	SM8050812TP
95	SM8050812TP	SM8050812TP
36	SM8060552TP	SM8060552TP
80	SM8060552TP	SM8060552TP

Page 59 — NUMERICAL INDEX OF PARTS

Juki MF-7523 parts on page 59

Ref	Part number	Part name	Qty
80	SM8060552TP	SM8060552TP
39	SM8060552TP	SM8060552TP
72	SM8060612TP	SM8060612TP
72	SM8060612TP	SM8060612TP
88	SM8060612TP	SM8060612TP
88	SM8060612TP	SM8060612TP
21	SM8060612TP	SM8060612TP
6	SM8060612TP	SM8060612TP
78	SM80606A2TP	SM80606A2TP
54	SM8060812TP	SM8060812TP
54	SM8060812TP	SM8060812TP
65	SM8060812TP	SM8060812TP
71	SM8060842TP	SM8060842TP
71	SM8060842TP	SM8060842TP
47	SM8061212TP	SM8061212TP
74	SM8080812TP	SM8080812TP
20	SM9061050TP	SM9061050TP
15	SQ0000452MZ	SQ0000452MZ
13	SQ0000453MZ	SQ0000453MZ
12	SQ0000454MZ	SQ0000454MZ
25	SQ2000452MZ	SQ2000452MZ
16	SQ2060441SD	SQ2060441SD
11	SQ2060442SD	SQ2060442SD
52	SQ2060451MZ	SQ2060451MZ
23	ST4040851SN	ST4040851SN
9	TA0400301MO	TA0400301MO
46	TA0500601MO	TA0500601MO
18	TA0500601MO	TA0500601MO
27	TA0750404R0	TA0750404R0
33	TA0850604R0	TA0850604R0
47	TA0850604R0	TA0850604R0
3	TA1050504R0	TA1050504R0
70	TA1050504R0	TA1050504R0
70	TA1050504R0	TA1050504R0
31	TA1250705R0	TA1250705R0
9	TA1600406R0	TA1600406R0
6	TA2050406R0	TA2050406R0
68	TA2050416R0	TA2050416R0
68	TA2050416R0	TA2050416R0
67	TA2101002R0	TA2101002R0
40	TA2101002R0	TA2101002R0
24	TA2351004R0	TA2351004R0
33	WP0280500SC	WP0280500SC
43	WP0280500SC	WP0280500SC
36	WP0280501SC	WP0280501SC
18	WP0370316SD	WP0370316SD
23	WP0410516SD	WP0410516SD
57	WP0450801SC	WP0450801SC
85	WP0450801SC	WP0450801SC
22	WP0450801SP	WP0450801SP
40	WP0450826SC	WP0450826SC
5	WP0450826SC	WP0450826SC
46	WP0450826SC	WP0450826SC
9	WP0460556SD	WP0460556SD
24	WP0461516SH	WP0461516SH
97	WP0480856SP	WP0480856SP
69	WP0501016SD	WP0501016SD
4	WP0522016SH	WP0522016SH
31	WP0531000SC	WP0531000SC
4	WP0531000SD	WP0531000SD
30	WP0531001SC	WP0531001SC
43	WP0550800SP	WP0550800SP
7	WP0550800SP	WP0550800SP
15	WP0550800SP	WP0550800SP
54	WP0550800SP	WP0550800SP
20	WP0550836SC	WP0550836SC
31	WP0551016SH	WP0551016SH
16	WP0621016SD	WP0621016SD
10	WP0621016SD	WP0621016SD
11	WP1021026SH	WP1021026SH
24	WP1022016SH	WP1022016SH
29	WP1612616SE	WP1612616SE
11	WS0510002KN	WS0510002KN
31	WS0510002KN	WS0510002KN
30	WS0510002KP	WS0510002KP
2	WS0510002KP	WS0510002KP
16	WZ0641510KP	WZ0641510KP
61	WZ0641510KP	WZ0641510KP
22	WZ0641510KP	WZ0641510KP

Part BooksPartsSearchNotes

Part Books

×

Search

×

Juki MF-7523 — parts catalog

• Page 1 (cover): This is the cover page for the parts list of the MF-7500 Series, List No. 1595-03, published on 03/05/2018.
• Page 2 (toc): This page contains the table of contents for the parts catalog, listing various component sections and their corresponding page numbers.
• Page 3 (diagram): This page displays a diagram of miscellaneous cover components for an industrial sewing machine, with numbered parts and their corresponding details.
• Page 4 (parts_list): This page lists miscellaneous cover components, including face covers, plates, rubber plugs, screws, gaskets, and labels, with their corresponding part numbers and quantities.
• Page 6 (parts_list): This page lists miscellaneous cover components for an industrial sewing machine, including various screws, washers, plates, and other hardware, with their part numbers, descriptions, and quantities.
• Page 7 (diagram): This page displays a diagram of miscellaneous cover components for an industrial sewing machine, with numbered parts indicated by reference numbers.
• Page 8 (parts_list): This page lists miscellaneous cover components with part numbers, descriptions, and quantities.
• Page 9 (diagram): This page displays a diagram of main shaft components, with numbered parts and their corresponding references.
• Page 10 (parts_list): This page lists main shaft components with part numbers, descriptions, and quantities.
• Page 11 (diagram): This page displays a diagram of main shaft components, illustrating various parts with reference numbers for identification.
• Page 12 (parts_list): This page lists main shaft components with part numbers, descriptions, and quantities.
• Page 13 (diagram): This page displays a diagram of needle bar and presser components, with numbered parts and their corresponding references.
• Page 14 (parts_list): This page lists needle bar and presser components, including part numbers, descriptions, and quantities.
• Page 15 (diagram): This page displays a diagram of needle bar and presser components for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 16 (parts_list): This page lists components for the needle bar and presser, including part numbers, descriptions, remarks, and quantities.
• Page 17 (diagram): This page displays a diagram of feed drive components, with numbered parts and their corresponding references.
• Page 18 (parts_list): This page lists feed drive components with part numbers, descriptions, remarks, and quantities.
• Page 19 (diagram): This page displays a diagram of feed drive components, with numbered parts and their corresponding references.
• Page 20 (parts_list): This page lists feed drive components with part numbers, descriptions, and quantities, ranging from part number 13318100 to 70001507.
• Page 21 (diagram): This page displays a diagram of feed drive components for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 22 (parts_list): This page lists components for the feed drive, including screws, washers, and felt, with their corresponding part numbers and quantities.
• Page 23 (diagram): This page displays a diagram of feed drive components, labeled with reference numbers for identification.
• Page 24 (parts_list): This page lists feed drive components, including part numbers, descriptions, and quantities.
• Page 25 (diagram): This page displays a diagram of thread take-up lever components, with numbered parts indicated for identification.
• Page 26 (parts_list): This page lists components for the thread take-up lever, including part numbers, descriptions, and quantities.
• Page 27 (diagram): This page displays a diagram of thread take-up lever components, with numbered parts and their corresponding references.
• Page 28 (parts_list): This page lists components for the thread take-up lever, including part numbers, names, and quantities.
• Page 29 (diagram): This page displays a diagram of spreader components with numbered parts, including part numbers and descriptions.
• Page 30 (parts_list): This page lists spreader components, including part numbers, descriptions, and quantities.
• Page 31 (diagram): This page displays a diagram of lower thread cam components, with numbered parts and their corresponding references.
• Page 32 (parts_list): This page lists lower thread cam components, including part numbers, descriptions, and quantities.
• Page 33 (diagram): This page displays a diagram of needle guard components, with numbered parts indicated for identification.
• Page 34 (parts_list): This page lists needle guard components, including part numbers, descriptions, and quantities.
• Page 35 (diagram): This page displays a diagram of looper components with numbered parts for identification.
• Page 36 (parts_list): This page lists looper components with their part numbers, names, and quantities.
• Page 37 (diagram): This page displays a diagram of thread tension components, with numbered parts and their corresponding references.
• Page 39 (diagram): This page displays a diagram of lubrication components for a sewing machine, with numbered parts and their corresponding references.
• Page 40 (parts_list): This page lists lubrication components with their part numbers, names, and quantities.
• Page 41 (diagram): This page displays a diagram of lubrication components for a sewing machine, with numbered parts and their corresponding references.
• Page 43 (diagram): This page displays a diagram of thread stand components, illustrating various parts with reference numbers for identification.
• Page 44 (parts_list): This page lists thread stand components, including part numbers, descriptions, and quantities.
• Page 45 (diagram): This page displays a diagram of gauge parts components for an industrial sewing machine, with various parts numbered for identification.
• Page 46 (parts_list): This page lists gauge parts components, including part numbers, names, remarks, and quantities.
• Page 47 (diagram): This page displays a diagram of gauge parts components, with various parts numbered for identification.
• Page 48 (parts_list): This page lists gauge parts components including part numbers, names, remarks, and quantities.
• Page 49 (diagram): This page displays a diagram of needle cooling components, with numbered parts indicated by reference numbers.
• Page 50 (parts_list): This page lists needle cooling components with part numbers, descriptions, and quantities.
• Page 51 (diagram): This page displays a diagram of accessories, parts, and components for an industrial sewing machine, with numbered items indicating specific parts.
• Page 52 (parts_list): This page lists accessory parts components with their part numbers, names, remarks, and quantities.
• Page 53 (parts_list): This page lists parts with their revision numbers, page references, and part numbers. It includes information on obsolete and added parts.
• Page 54 (parts_list): This page contains a numerical index of parts for a sewing machine, listing part numbers, page numbers, and reference numbers.
• Page 55 (parts_list): This page contains a numerical index of parts for an industrial sewing machine, listing part numbers, their corresponding page numbers, and reference numbers.
• Page 56 (parts_list): This page contains a numerical index of parts for the industrial sewing machine, listing part numbers, page numbers, and reference numbers across multiple columns.
• Page 57 (parts_list): This page contains a numerical index of parts for an industrial sewing machine, listing part numbers, their corresponding page numbers, and reference numbers.
• Page 58 (parts_list): This page contains a numerical index of parts for industrial sewing machines, listing part numbers, their corresponding page numbers, and reference numbers.
• Page 59 (index): This page contains a numerical index of parts for industrial sewing machines, listing part numbers, page references, and reference numbers.

Page 1 — PARTS LIST

MODEL : MF-7500 SERIES List No : 1595-03 PARTS LIST Published:03/05/2018 jintex.in

Page 2

CONTENTS MISCELLANEOUS COVER COMPONENTS (1)...###1

Page 3 — MISCELLANEOUS COVER COMPONENTS (1)

MISCELLANEOUS COVER COMPONENTS (1) JIN텍스.in

Page 4 — MISCELLANEOUS COVER COMPONENTS (1)

MISCELLANEOUS COVER COMPONENTS (1) No. Parts No. Parts name Remarks Level Cons Qty 1 70001411 FACE COVER 1 2 22902506 PLATE 1 3 TA1050504R0 RUBBER PLUG 1 4 SM4041055SP SCREW ☆ 4 5 70001416 GASKET H 1 6 TA2050406R0 RUBBER PLUG 1 7 70001409 TOP COVER 1 8 SM4041055SP SCREW 8 9 10753309 WINDOW PLATE RUBBER PLUG 1 10 RO195240100 O-RING 1 11 22924708 OIL SIGHT WINDOW 1 12 13300801 GASKET T 1 13 70001421 BRACKET HOLDER 1 14 40033341 BRACKET 1 15 13301700 PROTECTION SHIELD 1 16 WZ0641510KP WAVED WASHER 6.4X11X0.3 1 17 SM4030455SN SCREW 1 18 SM4030855SN SCREW M3 L=8.0 1 19 NM6040000SN NUT M4 1 20 SD0640246SP SHOULDER SCREW D=6.35 H=2.4 1 21 SM4060801SE SCREW 1 22 70001422 THREAD COVER 1 23 SM4040655SP SCREW M4 L=6 1 24 TA2351004R0 RUBBER PLUG 1 25 CM300200001 FINGER INJURY CAUTION LABEL (16) 1 26 CM301300001 SAFETY LABEL 1 27 70001837 NEEDLE BAR GUARD ASSY 1 28 70001407 NEEDLE BAR GUARD * 1 29 CM300200001 FINGER INJURY CAUTION LABEL (16) * 1 30 SM4040855SP SCREW * 2 31 TA1250705R0 RUBBER PLUG 2 32 TA0850606R0 RUBBER PLUG 3 33 TA0850606R0 RUBBER PLUG 1 34 22901805 GROUND MARK 1

Page 6

MISCELLANEOUS COVER COMPONENTS (2) No. Parts No. Parts name Remarks Level Cons Qty 1 70001420 CLOTH PLATE LEFT 1 2 13426903 MESH PLATE 1 3 RC1900002KP C-RING 19(20.5) 1 4 WP0531000SD WASHER M5 4 5 13302302 RUBBER BUMPER 2 6 SM6041002TP SCREW M4X0.7 L=10 3 7 SM1040800SP SCREW 1 8 70001978 CLOTH PLATE RIGHT 1 9 TA0400301M0 PLUG D=4X4.5 L=3 1 10 SM6040602TP SCREW M4X0.7 L=6 1 11 SM10414C0SP SCREW 2 12 SM6041002TP SCREW M4X0.7 L=10 1 13 70001415 BED TOP COVER 1 14 SM6040800SP SCREW 11 15 70001423 GASKET B 1 16 TA2050416R0 RUBBER PLUG 2 17 TA1050504R0 RUBBER PLUG 1 18 70001424 THROAT PLATE SUPPORT 1 19 13302302 RUBBER BUMPER 1 20 TA0850604R0 RUBBER PLUG 1 21 40082196 ADJUSTING COLLAR 2 22 SM60407C0TP SCREW M4 L=7 2 23 SM6050800SP SCREW M5 L=8 3 24 13302203 SCREW 2 25 13301809 SUPPORT STUD 4 26 70001426 SWING DOWN COVER 1 27 70001431 HINGE 1 28 13409800 DIFF LINK PIN 1 29 70001414 SCREW 1 30 WS0510002KP SPRING WASHER 5.1X9.2X1.3 1 31 WP0531000SC WASHER 5.3X10X1 2 32 13304308 LATCH SPRING 1 33 13302302 RUBBER BUMPER 2 34 SM8040412TP SET SCREW M4 L=4 2 35 SM4040655SP SCREW M4 L=6 2 36 13302302 RUBBER BUMPER 1 37 40099371 BRACKET 1 38 SM6030800SP SCREW M3X0.5 L=8 2 39 SM6051400SP SCREW 1 40 13302104 PIN 1 41 70001418 SIDE COVER 1 42 RE0300000K0 E-RING 3 1 43 WP0550800SP WASHER 5.5X10X0.8 1 44 70001659 FEED CHAMBER COVER 1 45 13305107 PIN FOR SIDE COVER 1 46 13302708 RUBBER WASHER 2 47 TA0850604R0 RUBBER PLUG 1 jintex.in

Page 7 — MISCELLANEOUS COVER COMPONENTS (2)

MISCELLANEOUS COVER COMPONENTS (2) jintex.in

Page 8 — MISCELLANEOUS COVER COMPONENTS (2)

MISCELLANEOUS COVER COMPONENTS (2) No. Parts No. Parts name Remarks Level Cons Qty 48 13304308 LATCH SPRING 1 49 13302302 RUBBER BUMPER 2 50 SM8040312TP SCREW M4 L=3 1 51 SM4040555SP SCREW 2 52 SM4041055SP SCREW 7 53 13302104 PIN 1 54 13304209 SUPPORT BRACKET 1 55 SM4041055SP SCREW 1 56 SM4041055SP SCREW M4 L=6 1 57 NM6040000SN NUT M4 1 58 700011436 HOUSING 1 59 SM6051602TP SCREW M5X0.8 L=16 4 60 70001976 SLIDE COVER 1 61 WZ0641510KP WAVED WASHER 6.4X11X0.3 1 62 70004493 SHOULDER SCREW 1 63 70001831 DRIVING BELT COVER ASSY 1 64 70001830 DRIVING BELT COVER 1 65 CM300200001 FINGER INJURY CAUTION LABEL (16) * * 1 66 SM4051055SP SCREW 3 67 TA2101002R0 RUBBER PLUG 1 68 TA2050416R0 RUBBER PLUG 2 69 WP0501016SD WASHER 5X10.5X1 1 70 TA1050504R0 RUBBER PLUG 2 jintex.in

Page 9 — MAIN SHAFT COMPONENTS

MAIN SHAFT COMPONENTS jintex.in

Page 10 — MAIN SHAFT COMPONENTS

MAIN SHAFT COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 70004635 TIMING BELT 1 2 70001445 LOWER MAINSHAFT RIGHT 1 3 13406707 LOWER PULLEY 1 4 SM8061212TP SCREW M6X12 2 5 40017824 LOOPER LOD STOPPER 1 6 70004640 COUPLING E ASSY 1 7 SM8060612TP SCREW M6 L=6 2 8 13308457 BEARING ASSY C 1 9 70004197 BEARING 1 10 40018922 COUPLING C 1 11 SM8060612TP SCREW M6 L=6 1 12 RO148240200 O-RING 1 13 13307509 JOINT 1 14 SM8060612TP SCREW M6 L=6 4 15 70004630 LMS_LEFT_ASSY 1 16 70004631 LOWER_MAINSHAFT_LEFT 1 17 70004633 LOOPER DRIVE 1 18 70004632 LOOPER ROD DRIVE 1 19 SM6061402TP SCREW M6 L=14 1 20 SM8040412TP SCREW M4X4 1 21 13324108 SCREW 4 22 70003316 FLY WHEEL 1 23 SM8060612TP SCREW M6 L=6 3 24 SM4040655SP SCREW M4 L=6 1 25 70001447 BUSHING LMS MIDDLE 1 26 70001448 BUSHING LMS LEFT 1 27 70005086 BEARING 1 28 13308705 GASKET FOR BUSHING LEFT 3 29 SM4041055SP SCREW 1 30 70001451 THRUST PLATE 1 31 70001453 BEARING HOLDER 1 32 SM8060812TP SCREW M6 L=8 1 33 SM8060842TP SCREW M6 L=8 1 34 70004184 LMS SPROCKET 1 35 70004489 LMS WORM ASSY 1 36 SM8060552TP SCREW M6 L=5 1 37 13308507 COUPLING D 1 38 SM8060842TP SCREW M6 L=8 1 39 70004484 BEARING 2 40 SM8060612TP SCREW M6 L=6 1 41 SB12000150 BEARING 1 42 RO148240200 O-RING 1 43 40035711 OIL WICK 2 44 70003331 COUPLING B 1 45 70001437 UPPER MAINSHAFT RIGHT 1 46 70001439 UPPER PULLEY 1 47 SM8061212TP SCREW M6X12 2 FOR UT35,UT37 jintex.in

Page 11 — MAIN SHAFT COMPONENTS

MAIN SHAFT COMPONENTS jintex.in

Page 12 — MAIN SHAFT COMPONENTS

MAIN SHAFT COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 48 13307251 BEARING ASSY A 1 49 SM8060842TP SCREW M6 L=8 * 1 50 SM8060612TP SCREW M6 L=6 * 1 51 70001443 COLLAR 1 52 SM8060612TP SCREW M6 L=6 2 53 13307301 UMS SPROCKET 1 54 SM8060812TP SCREW M6 L=8 4 55 SB120002200 BEARING 1 56 70001440 COUPLING B 1 57 70001638 BEARING COVER PLATE 1 58 SM8060612TP SCREW M6 L=6 4 59 70001441 UPPER MAINSHAFT LEFT 1 60 70001442 TAKE UP ROD ASSY 1 61 SM6061402TP SCREW M6 L=14 * 1 62 70001535 CRANK * 1 63 70001536 ROD * 1 64 13324108 SCREW * 2 65 70001444 TAKE UP ECCENTRIC * 1 66 SM8060612TP SCREW M6 L=6 * 2 67 13307806 HOUSING A SELECTIVE PARTS 1 68 13309307 HOUSING B SELECTIVE PARTS 1 69 13309406 HOUSING C SELECTIVE PARTS 1 70 SB120001900 BEARING 1 71 SM8060842TP SCREW M6 L=8 1 72 SM8060612TP SCREW M6 L=6 1 73 13309208 SCREW FOR COUNTERWEIGHT 1 74 SM8080812TP SCREW M8X8 1 75 SM6061200SP SCREW 1 76 13307707 COUNTER WEIGHT 1 jintex.in

Page 13 — NEEDLE BAR & PRESSER COMPONENTS

NEEDLE BAR & PRESSER COMPONENTS 24 29 30 31 32 33 2 1 3 12 11 14 13 17 16 15 4 5 8 9 10 6 61 60 64 62 65 63 44 43 44 23 22 21 34 18 19 38 37 35 36 42 39 40 41 66 45 49~52 47 46 54 53 55~57 59 58 59 67 jintex.in

Page 14 — NEEDLE BAR & PRESSER COMPONENTS

NEEDLE BAR & PRESSER COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 40070574 ADJ SCREW P B NUT ASSY * 1 2 40070573 ADJ SCREW P B ASSY * 1 3 13313101 LOCKING NUT 1 4 13313309 SPRING PRESSER BAR A 1 5 70001480 SPRING PRESSER BAR B 1 6 70001481 PRESSER BAR 1 7 70001499 BUSHING PRESSER BAR 1 8 13315908 OIL SEAL 1 9 70001483 FINGER GUARD 1 10 SM4040655SP SCREW M4 L=6 ☆ 1 11 13313804 GUIDE PLATE 2 12 SM6041000SP SCREW M4 L=10 1 13 70001485 PRESSER BAR BRACKET 1 14 SM6041200SP SCREW M4 L=12 1 15 13314109 LINK 1 16 SD070020CTP SHOULDER SCREW D=7 H=2 2 17 13314356 ASSY LIFTER SHAFT 1 18 23537202 HOOK SHAFT OIL SEAL 1 19 70001486 BUSHING LIFTER FRONT 1 20 PS0500142KP SPRING PIN TYPE W 5X14 1 21 70001498 SPRING LIFTER LEVER 1 22 70001494 TENSION RELEASE LEVER 1 23 SM6041202TP SCREW M4X0.7 L=12 2 24 SD070005CTP SHOULDER SCREW D=7 H=5.8 1 25 70001495 LIFTER LEVER STOPPER ☆ 1 26 SM60625COTP SCREW M6 L=25 1 27 NM6060001CP NUT M6X1 TYPE1 2 28 SM6061202TP SCREW M6 L=12 1 29 70001487 LIFTER LEVER ASSY 1 30 SM6051002TP SCREW M5X0.8 L=10 * 1 31 WP0551016SH WASHER 5.5X13X1 * 1 32 70001488 LIFTER LEVER 1 33 70001489 LIFTER LEVER SHAFT 1 34 70001490 BUSHING LIFTER LEVER 1 35 70001478 LIFTER SHAFT LEVER 1 36 SM6051202TP SCREW M5X0.8 L=12 2 37 70001477 LIFTER LEVER COLLAR 1 38 SM6040800SP SCREW 1 39 70001491 SPACER 2 40 WP0450826SC WASHER 4.5X10X0.8 2 41 SM4041055SP SCREW 1 42 70001492 LIFTER LEVER LINK 1 43 70001493 MINUTES LIFTING COLLAR 1 44 SM8040512TP SCREW 2 45 13311253 ASSY NEEDLE MECH 1 46 70004371 ASSY CONNECTING ROD * 1 47 13311006 ECCENTRIC PIN * 1 jintex.in

Page 15 — NEEDLE BAR & PRESSER COMPONENTS

NEEDLE BAR & PRESSER COMPONENTS 24 29 30 31 32 33 23 28 26 27 25 20 22 21 34 36 35 37 19 18 39 40 41 66 39 40 41 1 2 3 4 12 11 13 14 64 61 60 62 65 5 8 6 9 10 17 16 15 45 49~52 48 47 54 46 55~57 59 58 59 67 53 Jinttex.in

Page 16 — NEEDLE BAR & PRESSER COMPONENTS

NEEDLE BAR & PRESSER COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 48 13311204 CONNECTING ROD SELECTIVE PARTS * 1 49 SB30800110A BEARING SELECTIVE PARTS * 1 50 SB30800110B BEARING SELECTIVE PARTS * 1 51 SB30800110C BEARING SELECTIVE PARTS * 1 52 SB30800110D BEARING SELECTIVE PARTS * 1 53 SM6041000SP SCREW M4 L=10 * 1 54 13311303 NEEDLE BAR CLAMP * 1 55 13312103 THRUST WASHER SELECTIVE PARTS * 1 56 13312202 THRUST WASHER SELECTIVE PARTS 1 57 13312301 THRUST WASHER SELECTIVE PARTS 1 58 13311501 SLIDE BLOCK 1 59 SM6051202TP SCREW M5X0.8 L=12 3 60 13326806 NEEDLE BAR EYELET 1 61 SM4030855SN SCREW M3 L=8.0 1 62 13311956 ASSY BUSHING NB 1 63 13311907 BUSHING NB LOWER * 1 64 13311908 BUSHING NB UPPER * 1 65 13311451 NEEDLE BAR ASSY * 1 66 70001500 BUSHING LIFTER REAR 1 67 13311600 NEEDLE BAR GUIDE 1 jintex.in

Page 17 — FEED DRIVE COMPONENTS (1)

FEED DRIVE COMPONENTS (1) 18 80 83 86 85 81 84 82 98 97 96 101 26 27 28 30 B 29 31 31 79 32 33 A 34 38 35 37 39 44 43 45 46 95 100 94 76 70 B 73 74 71 72 69 68 63 66 64 60 59 54 57 55 58 49 47 50 51 48 53 52 65 61 99 91 92 93 C 25 24 19 20~22 17 12 13 8~10 11 7 6 5 3 4 1 88 87 90 89 jintex.in

Page 18 — FEED DRIVE COMPONENTS (1)

FEED DRIVE COMPONENTS (1) No. Parts No. Parts name Remarks Level Cons Qty 1 70001521 FEED ECCENTRIC HORIZON ASSY 1 2 70001505 CRNAK ROD * 1 3 70001522 FEED ECCENTRIC HORIZON * 1 4 SM8060612TP SCREW M6 L=6 * 2 5 13323803 CRANK ROD GUIDE 1 6 SM8050812TP SCREW M5X8 1 7 RO158240100 O-RING 1 8 13323308 FEED ADJ LINK PIN A SELECTIVE PARTS 1 9 13323407 FEED ADJ LINK PIN B SELECTIVE PARTS 1 10 13323506 FEED ADJ LINK PIN C SELECTIVE PARTS 1 11 CQ303000000 COTTON OIL WICK D=3 0.07 12 13317201 MAIN FEED DRIVE LINK 1 13 SM8050612TP SCREW M5X6 2 14 13318704 MAIN FEED CRANK PIN A SELECTIVE PARTS 1 15 13318803 MAIN FEED CRANK PIN B SELECTIVE PARTS 1 16 13318902 MAIN FEED CRANK PIN C SELECTIVE PARTS 1 17 CQ303000000 COTTON OIL WICK D=3 0.04 18 WP0370316SD WASHER 3.7X8X0.3 1 19 13317300 ADJUST LINK 1 20 13317409 FEED ADJ LINK PIN A SELECTIVE PARTS 1 21 13317508 FEED ADJ LINK PIN B SELECTIVE PARTS 1 22 13317607 FEED ADJ LINK PIN C SELECTIVE PARTS 1 23 CQ303000000 COTTON OIL WICK D=3 0.08 24 13317706 MAIN FEED ADJ LEVER 1 25 SM8060552TP SCREW M6 L=5 2 26 70001528 FEED BAR ASSY 1 27 70001959 MAIN FEED BAR * 1 28 13321708 DIFF FEED BAR * 1 29 70001509 SLIDE BLOCK * 1 30 13322409 SLIDE BLOCK * 1 31 SM6041000SP SCREW M4 L=10 2 32 13319702 DIFF FEED LINK 1 33 SD0801326TH SHOULDER SCREW D=8 H=13.2 1 34 13319959 DIFF DRIVE ARM ASSY 1 35 13319900 DIFF DRIVE ARM * 1 36 13320007 DIFF FEED PIN * 1 37 13320106 DIFF FEED PIN PLATE * 1 38 SM6061402TP SCREW M6 L=14 * 1 39 SM6030600SP SCREW M3X0.5 L=6 * 2 40 RC01000001KP C-RING 10 (9.3) 1 41 70001510 BUSHING FEED FRONT 1 42 13319009 ROCKER SHAFT 1 43 70001511 BUSHING FEED REAR 1 44 CS1000881TP THRUST COLLAR D=10 W=8 1 45 SM8060612TP SCREW M5X6 2 46 TA0500601M0 PLUG D=5X5.4 L=6 1 47 13318209 BUSHING FEED ADJUST 1 jintex.in

Page 19 — FEED DRIVE COMPONENTS (1)

FEED DRIVE COMPONENTS (1) 18 96 97 98 101 80 81 83 84 85 82 26 27 28 30 B 29 31 31 78 77 72 75 74 73 76 70 B 69 68 67 66 64 60 63 65 61 59 58 55 54 57 49 47 48 50 51 53 52 25 24 19 20~22 23 17 12 13 8~10 11 7 6 5 4 3 1 99 91 92 93 C 88 87 89 90 34 38 35 37 39 33 A 100 95 94 45 46 44 43 jintex.in

Page 20 — FEED DRIVE COMPONENTS (1)

FEED DRIVE COMPONENTS (1) No. Parts No. Parts name Remarks Level Cons Qty 48 13318001 KNOB FEED ADJUST 1 49 13318100 SHAFT FEED ADJUST 1 50 SM8040602TP SCREW M4X0.7 L=6 1 51 RO055200100 O-RING 1 52 B3215470000 PIN 1 53 SM8040412TP SCREW M4X4 1 54 13318308 STOPPER FEED ADJUST 1 55 RE0500000K0 E-RING 2 56 SM6030402TP SCREW M3X0.5 L=4 1 57 13317904 FEED ADJUST LEVER 1 58 PS0300162KH SPRING PIN 3X16 1 59 SM8050612TP SCREW M5X6 1 60 70001512 BUSHING FEED ADJUST 1 61 13317805 FEED ADJUST SHAFT 1 62 70001510 BUSHING FEED FRONT 1 63 13318506 TORSIN SPRING 1 64 CS1000881TP THRUST COLLAR D=10 W=8 1 65 SM4051255SP SCREW 1 66 SM8050612TP SCREW M5X6 1 67 B2556280000 SPRING 1 68 SM6051602TP SCREW M5X0.8 L=16 1 69 NM6050001SC NUT M5X0.8 TYPE1 1 70 RC0741013KP C-RING 8 (7.4) 1 71 13398409 SHOULDER SCREW 1 72 70001513 MAIN FEED ROCKER ASSY 1 73 13319405 MAIN FEED ROCKER PIN * 1 74 70001506 MAIN FEED ROCKER * 1 75 SM6061202TP SCREW M6 L=12 * 1 76 13319504 MAIN FEED LINK 1 77 13318605 MAIN FEED CRANK 2 78 SM80606A2TP SCREW M6 L=6 1 79 13322201 ECCENTRIC PIN 1 80 SM8060552TP SCREW M6 L=5 1 81 13322003 FEED BAR SHAFT 1 82 RO137230100 O-RING 1 83 SM80612TP SCREW M4 L=6 1 84 13322102 WASHER FEED BAR SHAFT 1 85 CS1000881TP THRUST COLLAR D=10 W=8 1 86 SM8050612TP SCREW M5X6 2 87 70001523 POSITIONING CAM HORIZON 1 88 SM8060612TP SCREW M6 L=6 2 89 70001524 FEED ECCENTRIC SCREW 1 90 70001525 FEED ECCENTRIC PIN 1 91 70001526 FEED ECCENTRIC 1 92 SM8050412TP SCREW M5 L=4 2 93 70001527 POSITIONING CAM VERTICAL 1 94 70001507 FEED BAR GUIDE 1 1 jintex.in

Page 21

FEED DRIVE COMPONENTS (1) jintex.in

Page 22 — FEED DRIVE COMPONENTS (1)

FEED DRIVE COMPONENTS (1) No. Parts No. Parts name Remarks Level Cons Qty 95 SM8050812TP SCREW M5X8 1 96 70001508 FEED BAR GUIDE 2 1 97 WP0480856SP WASHER 4.8X8.4X0.8 2 98 SM6040800SP SCREW 2 99 SM8050412TP SCREW M5 L=4 2 100 70001532 FELT FOR FEED BAR GUIDE 1 101 70001533 OIL PROTECTION SHEILD 1

Page 23 — FEED DRIVE COMPONENTS (2)

FEED DRIVE COMPONENTS (2) jintex.in

Page 24 — FEED DRIVE COMPONENTS (2)

FEED DRIVE COMPONENTS (2) No. Parts No. Parts name Remarks Level Cons Qty 1 40040206 DIFF FEED LEVER ASSY 1 2 R0068190100 O-RING 1 3 40039630 PLATE DIFF FEED LEVER 1 4 13321203 STOPPER DIFF ADJ 2 5 WP0450826SC WASHER 4.5X10X0.8 2 6 SM5040655SN SCREW 2 7 70001530 SCREW 1 8 13217708 DIFFERENTIAL FEED BLOCK 1 9 WP0460556SD WASHER 4.6X7.5X0.5 1 10 13123302 ADJUSTING SPRING 1 11 RE0300000K0 E-RING 3 1 12 13217500 DIFFERENTIAL FEED LOCK NUT 1 13 13217401 DIFFERENTIAL FEED HINGE SCREW 1 14 SM4051255SP SCREW 1 15 SM7051460TP SCREW M5 L=14 1 16 WP0621016SD WASHER 6.2X13X1 1 17 70001531 ADJUSTING LEVER SPRING 1 18 13320304 BUSHING DIFF ADJ LEVER 1 19 13320403 DIFF ADJ LEVER 1 20 SM8050612TP SCREW M5X6 1 21 40018443 DIFF ADJ LINK 1 22 31013808 HINGE SCREW 1 23 CS1000881TP THRUST COLLAR D=10 W=8 2 24 SM8050612TP SCREW M5X6 2 25 13323209 BUSHING DIFF ADJ LEVER 1 26 70001589 NEEDLE GUARD BASE 1 27 TA0750404R0 PLUG D=7.5 L=3.5 2 28 70001514 FEED BAR SEAL 1 1 29 70001515 FEED BAR SEAL PLATE 1 1 30 70001516 FEED BAR SEAL PLATE 2 1 31 70001517 FEED BAR SEAL 2 1 32 70001518 FEED BAR SEAL PLATE 3 1 33 SM1030400SP SCREW M3 L=4 3 34 SM6041000SP SCREW M4 L=10 3

Page 25

THREAD TAKE-UP LEVER COMPONENTS

Page 26 — THREAD TAKE-UP LEVER COMPONENTS

THREAD TAKE-UP LEVER COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 SM6051002TP SCREW M5X0.8 L=10 1 2 WS0510002KP SPRING WASHER 5.1X9.2X1.3 1 3 70001537 SHAFT 1 4 WP0522016SH WASHER 1 5 13324504 BUSHING REAR 1 6 CS1000881TP THRUST COLLAR D=10 W=8 1 7 SM8050612TP SCREW M5X6 2 8 13324603 BUSHING FRONT 1 9 23612609 FEED CHANGING SHAFT OIL SEAL 1 10 13324702 HOLDER TAKE UP EYELET 1 11 WS0510002KN SPRING WASHER M5 1 12 SM6051402TP SCREW M5X0.8 L=14 1 13 70001548 NDL THD TAKE UP 1 14 13324900 UP LPR THREAD TAKE UP 1 15 SM4041055SP SCREW 2 16 13325006 THREAD GUIDE 1 17 SM4040655SP SCREW M4 L=6 2 18 70001540 THREAD TENSION GUIDE 1 19 13348008 TANK 1 20 70001546 SILICONE OIL TANK COVER 1 21 B9214850000 HEAT REMOVING FELT 1 22 PS0150082KH SPRING PIN 1.5X8 2 23 ST4040851SN TAPPING SCREW M4X8 1 24 13325204 HOLDER 3 25 30391601 NEEDLE THREAD EYELET 3 26 SM8030312TP SCREW M3 L=3 1 27 SM4030855SN SCREW M3 L=8.0 2 28 SM4040655SP SCREW M4 L=6 1 29 70001541 THREAD GUIDE 1 30 SM4040655SP SCREW M4 L=6 1 31 70001542 THREAD GUIDE 1 32 70001543 NDL THD STRIKE OFF 1 33 SM4040655SP SCREW M4 L=6 1 34 PS0400082KP SPRING PIN TYPE W 4X8 1 35 13326905 NDL THD STRIKE OFF R 1 36 WP0280501SC WASHER M2.6 1 37 SM48504C5SP SCREW 2 38 SM1040650TP SCREW 2 39 13326301 THREAD GUIDE UPPER LPR 1 40 13326400 THREAD GUIDE 1 41 22945802 THREAD TENSION DISK 1 42 13326509 TENSION POST 1 43 22945505 THREAD TENSION SPRING 1 44 13326608 TENSION NUT 1 45 NM6050001SC NUT M5X0.8 TYPE1 2 46 WP0450826SC WASHER 4.5X10X0.8 2 47 SM6040800SP SCREW jintex.in 24

Page 27 — THREAD TAKE-UP LEVER COMPONENTS

THREAD TAKE-UP LEVER COMPONENTS 1 2 4 5 7 6 3 8 9 B 32 35 36 37 33 34 25 23 24 26 22 20 21 19 18 27 28 29 30 16 55 13 14 15 10 11 12 45 39 40 48 49 50 51 52 53 54 46 47 41 42 43 44 A 56 57 58 59 60 A jintex.in

Page 28 — THREAD TAKE-UP LEVER COMPONENTS

THREAD TAKE-UP LEVER COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 48 13325808 NIPPER PLATE SUPPORT 1 49 13325907 NIPPER PLATE 1 50 13326004 NIPPER GUIDE PLATE 1 51 13326103 SPRING 1 52 13326202 SHOULDER SCREW 1 53 SM4040655SP SCREW M4 L=6 1 54 13326707 THREAD GUIDE 1 55 40085995 FINGER GUARD ☆ 1 56 SM4040655SP SCREW 2 57 WP0450801SC WASHER 4.5X10X0.8 2 58 70001544 TAKE-UP COVER 1 59 SM1040750TP SCREW M4 L=7 1 60 70001545 FINGER GUARD 1

Page 29 — SPREADER COMPONENTS

SPREADER COMPONENTS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 jintex.in

Page 30 — SPREADER COMPONENTS

SPREADER COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 13328158 ASSY UPPER LPR MECH 1 2 13328109 CONNROD FOR UPPER LPR * 1 3 13328000 UPPER LOOPER ECCENTRIC * 1 4 13328208 STUD * 1 5 SM8050412TP SCREW M5 L=4 * 2 6 70001555 DRIVING ARM 1 7 WP0550800SP WASHER 5.5X10X0.8 1 8 NM6050001SC NUT M5X0.8 TYPE1 1 9 SM6061402TP SCREW M6 L=14 1 10 70001558 UPPER LOOPER SHAFT 1 11 13399209 COLLAR 2 12 SM8040412TP SCREW M4X4 4 13 13329008 BUSHING REAR 1 14 70001559 BUSHING,FRONT 1 15 13328554 ASSY UPPER LPR MECH 2 1 16 13328505 CRANK ROD * 1 17 13328604 UPPER LOOPER ROCKER * 1 18 13328703 UP LPR SHAFT VERTICAL * 1 19 CG303000000 COTTON OIL WICK D=3 * 0.05 20 SM9061050TP SCREW M6 L=10 * 1 21 SM8060612TP SCREW M6 L=6 * 1 22 13329206 BUSHING VERTICAL 1 23 13338900 OIL SEAL 1 24 WP1022016SH WASHER 1 25 CS1000881TP THRUST COLLAR D=10 W=8 1 26 SM8050412TP SCREW M5 L=4 2 27 13328802 UPPER LOOPER HOLDER 1 28 SM6041200SP SCREW M4 L=12 ☆ 1 29 70004223 UPPER LOOPER EXCEPT TYPE TURKEY ☆ 1 30 SM6041000SP SCREW M4 L=10 ☆ 1 31 70004224 UPPER LOOPER TYPE TURKEY ☆ 1

Page 31 — LOWER THREAD CAM COMPONENTS

LOWER THREAD CAM COMPONENTS 1 40 5 6 4 10 11 9 8 7 13 12 24 3 20 44 32 29 28 30 31 33 34 45 42 41 43 27 26 25 14 19 23 22 21 15 18 17 16 37 35 36 39 38 39 jintex.in

Page 32 — LOWER THREAD CAM COMPONENTS

LOWER THREAD CAM COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 70004637 BELT_TAKE_UP 1 2 70001582 THREAD GUIDE PLATE 1 3 40087068 CAM THREAD CATCH 1 4 70001580 SPROCKET TAKE UP 1 5 SM8050612TP SCREW M5X6 2 6 70001581 WASHER 1 7 70001572 SHAFT TAKE UP 1 8 CS1000881TP THRUST COLLAR D=10 W=8 1 9 SM8050612TP SCREW M5X6 2 10 40023441 OIL SEAL 1 11 70001573 BUSHING A TAKE UP 1 12 40023481 BUSHING B TAKE UP 1 13 40023441 OIL SEAL 1 14 13332309 BASE TAKE UP PLATE 1 15 SL4041281SC SCREW M4 L=12 1 16 13333208 WASHER 1 17 13332903 SPRING 1 18 SM4040655SP SCREW M4 L=6 1 19 13332804 BRACKET 1 20 SM4040655SP SCREW M4 L=6 2 21 SD064024CSP SHOULDER SCREW D=6.35 H=2.4 1 22 WZ0641510KP WAVED WASHER 6.4X11X0.3 1 23 WP0410516SD PLAIN WASHER 1 24 70001579 TAKE UP PLATE 1 25 40100791 EYELET A ASSY 1 26 WP0280500SC WASHER 1 27 SM48504C5SP SCREW 1 28 13333307 LPR THD DISC UPPER 1 29 40100793 LPR THD GUIDE BASE ASSY 1 30 13333505 TENSION POST 1 31 13333604 LOOPER CAM SPRING 1 32 NM6030001SC NUT M3X0.5 TYPE1 1 33 WP0280500SC WASHER 1 34 SM4850455SP SCREW 1 35 70001575 EYELET C ASSY 1 36 SM4040655SP SCREW M4 L=6 1 37 13333703 EYELET D 1 38 40019335 ASSY TAKE UP 2 39 SM8060552TP SCREW M6 L=5 1 40 TA2101002R0 RUBBER PLUG 1 41 70001584 SPRING COLLAR 1 42 SM6850802TN SCREW M2.5 L=8 1 43 NM6850001SC NUT M2.5X0.45 TYPE1 1 44 70001585 THREAD GUIDE 1 45 70001583 THREAD GUIDE PLATE SPRING 1 jintex.in 20

Page 33 — NEEDLE GUARD COMPONENTS

NEEDLE GUARD COMPONENTS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 jintex.in

Page 34 — NEEDLE GUARD COMPONENTS

NEEDLE GUARD COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 40052924 REAR NEEDLE GUARD 1 2 13334701 FRONT NDL GUARD 1 3 SM4850455SP SCREW 1 4 70001592 NEEDLE GUARD BLOCK 1 5 70001587 FORK NEEDLE GUARD 1 6 SM8050612TP SCREW M5X6 1 7 70001590 NEEDLE GUARD SHAFT 1 8 70001591 BUSHING NEEDLE GUARD 1 9 RO055200100 O-RING 1 10 WP0621016SD WASHER 6.2X13X1 1 11 RE0500000K0 E-RING 1 12 70001588 REAR NEEDLE GUARD HOLDER 1 13 SM6051000SP SCREW 1 14 SM8040312TP SCREW M4 L=3 1 jintex.in

Page 35 — LOOPER COMPONENTS

LOOPER COMPONENTS jintex.in

Page 36 — LOOPER COMPONENTS

LOOPER COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 13337357 ECC LOOPER AVOID ASSY 1 2 13337308 ECC LOOPER AVOID * 1 3 13337407 LOOPER ROD AVOID * 1 4 SM6041202TP SCREW M4X0.7 L=12 * 2 5 13337506 PIN LOOPER AVOID * 1 6 SM8060612TP SCREW M6 L=6 2 7 13338801 BALANCE WEIGHT LP 1 8 SM6041000SP SCREW M4 L=10 2 9 TA160406R0 PRUG 1 10 70001601 BUSHING LPR RIGHT 1 11 WP1021026SH WASHER 1 12 RE0700000K0 E-RING 7 1 13 13337605 CRANK LOOPER AVOID 1 14 SM8050612TP SCREW M5X6 1 15 WP0550800SP WASHER 5.5X10X0.8 1 16 NM6050001SC NUT M5X0.8 TYPE1 1 17 13338504 LOOPER SHAFT AVOID 1 18 TA0500601M0 PLUG D=5X5.4 L=6 2 19 70001602 BUSHING LPR LEFT 1 20 40052522 SCREW 1 21 13337704 COLLAR LOOPER AVOID 1 22 SM6041000SP SCREW M4 L=10 1 23 13337803 LOOPER AVOID PIN 1 24 WP0461516SH WASHER 2 25 70001603 BUSHING LPR SHAFT REAR 1 26 40050448 LOOPER SHAFT 1 27 70001604 BUSHING LPR SHAFT FRONT 1 28 13338900 OIL SEAL 1 29 40050449 LOOPER HOLDER ☆ 1 30 SM6051402TP SCREW M5X0.8 L=14 ☆ 1 31 13337902 LOOPER 1 32 SM6040750TP SCREW M4 L=7 1

Page 37

THREAD TENSION COMPONENTS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 jintex.in

Page 39 — LUBRICATION COMPONENTS

LUBRICATION COMPONENTS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 32 32 33 34 35 35 29 28 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 83 84 85 86 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 30 31 60 A B C jintex.in

Page 40 — LUBRICATION COMPONENTS

LUBRICATION COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 13345202 FILTER COVER 1 2 SM4041055SP SCREW 4 3 13344809 GASKET O 1 4 13142500 CARTRIDGE FILTER 1 5 13343801 FITTING FILTER 1 6 13346556 ASSY OIL SUPPLY 1 7 SM4040655SP SCREW M4 L=6 1 8 13345855 OIL SUPPLY ASSY 1 9 SM4040655SP SCREW M4 L=6 1 10 70001634 ASSY OIL PIPE 1 11 SQ2060442SD CONNECTING SCREW 3 12 SQ0000454MZ CONNECTING SCREW 1 13 SQ0000453MZ CONNECTING SCREW 1 14 BP30000010R VINYL PIPE 0.04 15 SQ0000452MZ CONNECTING SCREW 1 16 SQ2060441SD CONNECTING SCREW 1 17 BP30000010R VINYL PIPE 0.12 18 BP30000010R VINYL PIPE 0.12 19 BP30000010R VINYL PIPE 0.19 20 23629306 PIPE STOPPER A 17 21 BP30000010R VINYL PIPE 0.1 22 BP30000010R VINYL PIPE 0.2 23 23629504 DISTRIBUTOR 3 24 13346705 CONNECTING SCR BRACKET 1 25 SQ2050452MZ CONNECTING SCREW 1 26 NM6050001SC NUT M5X0.8 TYPE1 1 27 SM4040655SP SCREW M4 L=6 2 28 40024405 ASSY OIL PAN 1 29 13345509 OIL PAN 1 30 13170105 RUBBER RING 1 31 13171004 DRAIN SCREW 1 32 SM6061802TP SCREW M6 L=18 6 33 13345608 O RING 1 34 13345905 COVER PLATE 1 35 SM4040655SP SCREW M4 L=6 2 36 7000636 OIL TUBE HOLDER 1 37 SM4040655SP SCREW 1 38 13346101 OIL SIGHT GAUGE 1 39 13345459 ASSY PUMP 2-STAGE 1 40 13343108 OIL PUMP HOUSING 1 41 13343009 WORM WHEEL 2 42 SM8050412TP SCREW M5 L=4 1 43 13345400 OIL PUMP SHAFT LARGE 2 44 13228309 OIL PUMP PINION 2 45 13228200 OIL PUMP PINION 1 46 13227905 GEAR PUMP SHAFT 1 47 13343405 OIL PUMP SPACER jintex.in 20

Page 41

LUBRICATION COMPONENTS jintex.in

Page 43

THREAD STAND COMPONENTS 1 2 3 4 5 6 20 28 28 20 7 8 25 24 12 27 26 11 10 24 27 9 13 14 15 16 17 18 28 19 23 30 31 28 21 28 30 31 28 29 21 22 29 29 21 22 jintex.in

Page 44 — THREAD STAND COMPONENTS

THREAD STAND COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 40106591 THREAD STAND ASM. 1 2 40106575 SPOOL REST LONG ARM UPPER * 1 3 40085794 THREAD GUIDE * 5 4 40085795 THREAD GUIDE BUSHING * 5 5 40085787 SPOOL REST ARM UPPER * 1 6 40085793 SPOOL REST ROD RUBBER CAP * 1 7 40085785 SPOOL REST ROD UPPER * 1 8 40085792 SPOOL REST ROD JOINT * 1 9 40106581 THREAD GUIDE 5 * 1 10 40106580 THREAD GUIDE UNDER BASE * 1 11 40106576 THREAD GUIDE ARM * 1 12 40106579 THREAD GUIDE ARM BASE * 1 13 40085784 SPOOL REST ROD LOWER * 1 14 40085791 SPOOL RETAINER * 5 15 40085790 SPOOL PIN * 5 16 40085789 SPOOL REST CUSHION * 5 17 40085788 SPOOL REST * 5 18 40085786 SPOOL REST ARM LOWER * 1 19 40106574 SPOOL REST LONG ARM LOWER * 1 20 40096327 SPOOL REST ARM UPPER SCREW * 2 21 40085796 SPOOL REST ROD RUBBER CUSHION * 2 22 40096325 SPOOL REST ROD NUT * 1 23 40096326 SPOOL REST ARM LOWER SCREW * 4 24 SM4041201SC SCREW M4X0.7 L=12 * 3 25 SM4051405SE SCREW M5 L=14 * 2 26 SM4042501SC SCREW M4X0.7 L=25 * 1 27 NM6040002SC NUT M4X0.7 TYPE2 * 4 28 NM6050001SE NUT M5X0.8 TYPE1 * 11 29 WP1612616SE WASHER 16X30X2.6 * 2 30 WP0531001SC WASHER M5 * 5 31 WS0510002KN SPRING WASHER M5 * 5 jintex.in

Page 45 — GAUGE PARTS COMPONENTS

GAUGE PARTS COMPONENTS 19~23 29-30 31 33 34 47-48 49-50 39-40 3~5 1-2 6 7-8 9 32 45 44 46 37 39 35-36 24~28 49 42 43 41 52-53 17-18 13~16 10~12 54 jintex.in

Page 46

GAUGE PARTS COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 13350004 NEEDLE HEAD 32 FOR B32 1 2 13350103 NEEDLE HEAD 40 FOR B40 1 3 13350202 NEEDLE HEAD 48 FOR B48 1 4 13350301 NEEDLE HEAD 56 FOR B56 1 5 13350400 NEEDLE HEAD 64 FOR B64 1 6 MUY128S1000 NEEDLE UYX128GAS (S BALL POINT) #10S FOR B32,B40 2 7 MUY128S1000 NEEDLE UYX128GAS (S BALL POINT) #10S FOR B48,B56,B64 3 8 MUY128S1400 NEEDLE UYX128GAS (S BALL POINT) #14S FOR JJ 3 9 SM8030312TP SCREW M3 L=3 FOR B48,B56,B64 3 10 40058587 THROAT PLATE FOR B32 1 11 40058706 THROAT PLATE FOR B40 1 12 70004610 THROAT_PLATE OPTIONAL PARTS 1 13 40040514 THROAT PLATE FOR B48 1 14 40058033 THROAT PLATE FOR B56 1 15 40040513 THROAT PLATE FOR B64 1 16 40087878 THROAT PLATE FOR JJ 1 17 40058588 DIFF FEED DOG FOR B32,B40,B48 1 18 13357603 DIFF FEED DOG FOR B56,B64,JJ 1 19 40090133 PRESSER FOOT ASSY FOR B32 1 20 40090196 PRESSER FOOT ASSY FOR B40 1 21 40090197 PRESSER FOOT ASSY FOR B48 1 22 40082974 PRESSER FOOT ASSY FOR B56,B64,JJ 1 23 70004613 PRESSER FOOT ASSY OPTIONAL PARTS 1 24 40090130 PRESSER FOOT BOTTOM FOR B32 1 25 40090131 PRESSER FOOT BOTTOM FOR B40 1 26 40090132 PRESSER FOOT BOTTOM FOR B48 1 27 40082975 PRESSER FOOT BOTTOM FOR B56,B64,JJ 1 28 70004612 PRESSER_FOOT_BOTTOM OPTIONAL PARTS 1 29 40070224 PRESSER FOOT HINGE EXCEPT OPTIONAL PARTS 1 30 13467907 PRESSER_FOOT_SHANK OPTIONAL PARTS 1 31 SM6040800SP SCREW * 1 32 13375209 PIVOT PIN * 1 33 SM8030412TP SCREW * 1 34 13377106 SPRING * 1 35 40070226 P_F YIELDING SECTION EXCEPT OPTIONAL PARTS 2 36 40038032 YIELDING SECTION OPTIONAL PARTS 1 37 40070227 GUIDE PLATE EXCEPT OPTIONAL PARTS 1 38 13468103 YIELDING_SECTION_PLATE OPTIONAL PARTS 1 39 SM1850600SP SCREW EXCEPT OPTIONAL PARTS 2 40 SM1850600SP SCREW OPTIONAL PARTS 1 41 40070231 PRESSER FOOT GUIDE EXCEPT OPTIONAL PARTS 1 42 SM6850400SP SCREW M2.5 L=4 EXCEPT OPTIONAL PARTS 1 43 WP0280500SC WASHER EXCEPT OPTIONAL PARTS 1 44 SM8031002TP SCREW EXCEPT OPTIONAL PARTS 1 45 NM6030001SD NUT M3X0.5 TYPE1 EXCEPT OPTIONAL PARTS 1 46 40070230 SPRING R EXCEPT OPTIONAL PARTS 1 47 40070229 SPRING L EXCEPT OPTIONAL PARTS 1 jintex.in 44

Page 47 — GAUGE PARTS COMPONENTS

GAUGE PARTS COMPONENTS 19~23 29~30 44 31 32 33 46 37 49 34 39 35~36 47~48 24~28 42 43 41 3~5 1.2 6 9 7.8 52~53 17~18 13~16 10~12 54 jintex.in

Page 48 — GAUGE PARTS COMPONENTS

GAUGE PARTS COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 48 13375308 SPRING,L OPTIONAL PARTS * 1 49 PS0150065KP SPRING PIN 1.5X6 EXCEPT OPTIONAL PARTS * 2 50 PS0150082KH SPRING PIN OPTIONAL PARTS * 1 51 SM8030312TP SCREW M3 L=3 FOR B32,B40 4 52 13354204 MAIN FEED DOG FOR B32,B40,B48 1 53 13353701 MAIN FEED DOG FOR B56,B64,JJ 1 54 70004611 THROAT PLATE OPTIONAL PARTS 1 jintex.in jintex.in

Page 49 — NEEDLE COOLING COMPONENTS

NEEDLE COOLING COMPONENTS 1 2 3 4 5 6 7 8 9 10 11

Page 50 — NEEDLE COOLING COMPONENTS

NEEDLE COOLING COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 40056919 SILICONE OIL TANK 1 2 13429105 SILICONE OIL TANK CAP 1 3 SM4050855SP SCREW 1 4 BT0600402EA URETHANE TUBE CLEAR BLUE 6X4 0.15 5 CQ3030000000 COTTON OIL WICK D=3 0.3 6 70001644 SILICONE OIL CUP 1 7 SM6030600SP SCREW M3X0.5 L=6 2 8 13348305 FELT 1 9 11856101 NEEDLE COOLER PIN 1 10 B3538112000 OIL RETURN TUBE HOLDER 1 11 SM4040655SP SCREW M4 L=6 1 jintex.in

Page 51

ACCESSORIES PARTS COMPONENTS JUKI JUKI 1 2 3 4 7 5 6 39 40 41 42 43 11 36 13 9.10 37 12 14 15 16 17 19 20 18 21 22 29 30 31 24 28 27 23 38 33 34 25 32 26 35 jintex.in

Page 52

ACCESSORIES PARTS COMPONENTS No. Parts No. Parts name Remarks Level Cons Qty 1 40013913 ACCESSORY BAG ASSY 1 2 22932800 ACCESSORIE BAG * 1 3 22933105 SCREW DRIVER * 1 4 12347308 SCREW DRIVER (SMALL) * 1 5 13160304 S SHAPED HOOK * 2 6 70001840 CHAIN * 1 7 12288403 TWEEZERS * 1 8 MML018800CB JU KI CORPORATION GENUINE OIL 18 ☆ 1 9 40072505 ISOLATOR 1 10 13155403 ISOLATOR 3 11 13348966 ASSY BOLT SET 1 12 13348859 SUPPORT PLATE ASSY 2 13 13302203 SCREW 1 14 B9101490000 DRIVER 1 15 40032763 HEXAGONAL DRIVER(1.5) 1 16 J106600000B HEXAGONAL ROD SPANNER KEY 2 1 17 40099374 BINDER BRACKET ASSY 1 18 40099373 BINDER BRACKET * 1 19 SM5050855SN SCREW M5 L=8 * 2 20 WP0550836SC WASHER 5.5X12X0.8 * 2 21 SM4040855SP SCREW * 2 22 WP0450801SP WASHER * 2 23 70001964 HEM GUIDE ASSY 1 24 70001967 HEM GUIDE * 1 25 70001962 HEM GUIDE BASE 1 * 1 26 40019379 KNOB SCREW * 2 27 SM1040801SC SCREW M4X0.7 L=8 * 1 28 70001963 HEM GUIDE BASE 2 * 1 29 70001813 COVERING GUIDE RIGHT ☆ 1 30 70001814 COVERING GUIDE LEFT ☆ 1 31 40099375 BRACKET B ☆ 1 32 70001838 COVERING GUARD L ☆ 1 33 70001839 COVERING GUARD R ☆ 1 34 70001846 BRACKET ☆ 1 35 SM6040650TP SCREW 2 36 40066644 HEAD COVER 1 37 MUY128S1003 NEEDLES(PACKAGE_OF_3) 1 38 70001842 GUIDE LEFT ☆ 1 39 70004227 ACCESSORY BAG ASSY FOR UT35,UT37 1 40 22932800 ACCESSORIE BAG * 1 41 22933105 SCREW DRIVER * 1 42 12347308 SCREW DRIVER (SMALL) * 1 43 12288403 TWEEZERS * 1 jintex.in

Page 53 — LIST FOR INFORMATION OF CHANGE

LIST FOR INFORMATION OF CHANGE As to the place changed,refer to the corresponding Rev.No. When previous parts(Obsoleted part)and new parts(Added parts)are not interchangeable with each other. In this case,even obsoleted parts(D.)can be ordered with the obsoleted part number,so select the parts with changed dates and place your orders. 変更箇所は,該当Rev.No.版をご参照ください。 部品の互換性がない変更の場合は,削除された品番でも、ご注文できます。 No.1595-03 Rev.No. *A:Added parts追加部品/D:Obsoleted parts削除部品/E:Erratum訂正 Rev. Page Ref. No. 頁 No. Parts No. 品 番 Rev. Page Ref. No. 頁 No. Parts No. 品 番 D 02 6 1 133-08804 A 03 6 1 700-04635 D 02 18 1 700-01987 A 03 18 1 700-04637 D 02 26 1 401-06592 A 03 26 1 401-06591 D 02 32 36 133-52307 D 02 32 37 133-52406 D 02 32 38 700-01946 D 02 32 39 700-01947 jintex.in

Page 54 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS PART NO PAGE REF NO. PART NO PAGE REF NO. PART NO PAGE REF NO. 10753309 2 9 13311253 12 45 13321708 16 28 11856101 40 64 13311303 14 54 13322003 18 81 11856101 48 9 13311451 14 65 13322102 18 84 12288403 50 43 13311501 14 58 13322201 18 79 12347308 50 42 13311600 14 67 13322409 16 30 13123302 22 10 13311808 14 64 13323209 22 25 13140504 36 5 13311907 14 63 13323308 16 8~10 13142500 38 13311956 14 62 13323407 16 8~10 13155403 50 9~10 13312103 14 55~57 13323506 16 8~10 13160304 50 5 13312202 14 55~57 13323803 16 5 13170105 38 30 13312301 14 55~57 13324108 8 64 13171004 38 31 13313101 12 3 13324108 10 64 13217401 22 13 13313309 12 4 13324504 24 5 13217500 22 12 13313804 12 11 13324603 24 8 13217708 22 8 13314109 12 15 13324702 24 10 13227905 38 46 13314356 12 17 13324900 24 14 13228200 38 45 13315908 12 8 13325006 24 16 13228309 38 44 13317201 16 12 13325204 24 26 13300801 2 12 13317300 16 19 13325808 26 48 13301700 2 13 13317409 16 20~22 13325907 26 49 13301809 4 25 13317606 16 20~22 13326004 26 50 13302104 4 53 13317607 16 20~22 13326103 26 51 13302104 6 53 13317706 16 24 13326202 26 52 13302203 4 24 13317805 18 61 13326301 24 39 13302203 50 13 13317904 18 57 13326400 24 40 13302302 4 49 13318001 18 48 13326509 24 42 13302302 6 49 13318100 18 49 13326608 24 44 13302708 4 46 13318209 16 47 13326707 26 54 13304209 6 54 13318308 18 54 13326806 14 60 13304308 4 48 13318506 18 63 13326905 24 35 13304308 6 48 13318605 18 77 13328000 28 3 13305107 4 45 13318704 16 14~16 13328109 28 2 13307251 10 48 13318803 16 14~16 13328158 28 1 13307301 10 53 13318902 16 14~16 13328208 28 4 13307509 8 13 13319009 16 42 13328505 28 16 13307707 10 76 13319405 18 73 13328554 28 15 13307806 10 67~69 13319504 18 76 13328604 28 17 13308457 8 8 13319702 16 32 13328703 28 18 13308507 8 37 13319900 16 35 13328802 28 27 13308705 8 28 13319959 16 34 13329008 28 13 13309208 10 73 13320007 16 36 13329206 28 22 13309307 10 67~69 13320106 16 37 13332309 30 14 13309406 10 67~69 13320304 22 18 13332804 30 19 13311006 12 47 13320403 22 19 13332903 30 17 13311204 14 48 13321203 22 4 13333208 30 16 INDEX - 1 jintex.in

Page 55 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS PART NO PAGE REF NO. PART NO PAGE REF NO. PART NO PAGE REF NO. 13333307 30 28 13348008 24 19 40019335 30 38 13333505 30 30 13348305 48 8 40019379 50 26 13333604 30 31 13348859 50 12 40023441 30 13 13333703 30 37 13348966 50 11 40023481 30 12 13334701 32 2 13350004 44 1-2 40024405 38 28 13337308 34 2 13350103 44 1-2 40032763 50 15 13337357 34 1 13350202 44 3-5 40033341 2 14 13337407 34 3 13350301 44 3-5 40035711 8 43 13337506 34 5 13350400 44 3-5 40038032 44 35-36 13337605 34 13 13353701 46 52-53 40039630 22 3 13337704 34 21 13354204 46 52-53 40040206 22 1 13337803 34 23 13357603 44 17-18 40040513 44 13-16 13337902 34 31 13358304 44 17-18 40040514 44 13-16 13338004 34 17 13375209 44 32 40042363 36 9 13338801 34 7 13375308 46 47-48 40042364 36 10 13338900 28 23 13377106 44 34 40042365 36 11 13338900 34 28 13398409 18 71 40042366 36 12 13340005 36 21 13399209 28 11 40050448 34 26 13340104 36 22 13406707 8 3 40050549 34 29 13340302 36 6 13409800 4 28 40052522 34 20 13340909 38 41 13426903 4 2 40052924 32 1 13343108 38 40 13429105 48 2 40056919 48 1 13343207 40 48 13467907 44 29-30 40058033 44 13-16 13343306 40 49 13468103 44 37-38 40058587 44 10-12 13343405 38 47 22901805 2 34 40058706 44 10-12 13343603 40 62 22902506 2 2 40065785 36 2 13343801 38 5 22924708 2 11 40066644 50 36 13343900 40 61 22932800 50 40 40070224 44 29-30 13344056 40 66 22933105 50 41 40070226 44 35-36 13344155 40 71 22945505 24 43 40070227 44 37-38 13344502 40 68 22945802 24 41 40070229 44 47-48 13344601 40 67 23537202 12 18 40070230 44 46 13344700 40 69 23612609 24 9 40070231 44 41 13344809 38 3 23629306 38 76 40070573 12 2 13345053 40 78 23629306 40 76 40070574 12 1 13345202 38 1 23629504 38 23 40072505 50 9-10 13345400 38 43 23630007 40 70 40082196 4 21 13345459 38 39 26019000 36 7 40082974 44 19-23 13345509 38 29 30391601 24 25 40082975 44 24-28 13345608 38 33 31013808 22 22 40082978 44 13-16 13345855 38 49 40004749 40 53 40085784 42 13 13345905 38 34 40013913 50 1 40085785 42 7 13346101 38 38 40017824 8 5 40085786 42 18 13346556 38 6 40018443 22 21 40085787 42 5 13346705 38 24 40018922 8 10 40085788 42 17 INDEX - 2 jintex.in

Page 56 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS PART NO PAGE REF NO. PART NO PAGE REF NO. PART NO PAGE REF NO. 40085789 42 16 70001424 4 18 70001514 22 28 40085790 42 15 70001426 4 26 70001515 22 29 40085791 42 14 70001431 4 27 70001516 22 30 40085792 42 8 70001436 6 58 70001517 22 31 40085793 42 6 70001437 8 45 70001518 22 32 40085794 42 3 70001439 8 46 70001521 16 1 40085795 42 4 70001440 10 44-56 70001522 16 3 40085796 42 21 70001441 10 59 70001523 18 87 40085995 26 55 70001442 10 60 70001524 18 89 40087068 30 3 70001443 10 51 70001525 18 90 40090130 44 24-28 70001444 10 65 70001526 18 91 40090131 44 24-28 70001445 8 2 70001527 18 93 40090132 44 24-28 70001447 8 25 70001528 16 26 40090133 44 19-23 70001448 8 26 70001530 22 7 40090196 44 19-23 70001451 8 30 70001531 22 17 40090197 44 19-23 70001453 8 31 70001532 20 100 40096325 42 22 70001477 12 37 70001533 20 101 40096326 42 23 70001478 12 35 70001535 10 62 40096327 42 20 70001480 12 5 70001536 10 63 40099371 4 37 70001481 12 6 70001537 24 3 40099373 50 18 70001483 12 9 70001540 24 18 40099374 50 17 70001485 12 13 70001541 24 29 40099375 50 31 70001486 12 19 70001542 24 31 40100791 30 25 70001487 12 29 70001543 24 32 40100793 30 29 70001488 12 32 70001544 26 58 40101602 36 13 70001489 12 33 70001545 26 60 40102003 36 14 70001490 12 34 70001546 24 20 40106574 42 19 70001491 12 39 70001548 24 13 40106575 42 2 70001492 12 42 70001555 28 6 40106576 42 11 70001493 12 43 70001558 28 10 40106579 42 12 70001494 12 22 70001559 28 14 40106580 42 10 70001495 12 25 70001572 30 7 40106581 42 9 70001498 12 21 70001573 30 11 40106591 42 1 70001499 12 7 70001575 30 35 70001407 2 28 70001500 14 66 70001579 30 24 70001409 2 7 70001505 16 2 70001580 30 4 70001411 2 1 70001506 18 74 70001581 30 6 70001414 4 29 70001507 18 94 70001582 30 2 70001415 4 13 70001508 20 96 70001583 30 45 70001416 2 5 70001509 16 29 70001584 30 41 70001418 4 41 70001510 16 62 70001585 30 44 70001420 4 1 70001510 18 62 70001587 32 5 70001421 2 13 70001511 16 43 70001588 32 12 70001422 2 22 70001512 18 60 70001589 22 26 70001423 4 15 70001513 18 72 70001590 32 7 INDEX - 3 jintex.in

Page 57 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS PART NO PAGE REF NO. 70001591 32 8 70001592 32 4 70001601 34 10 70001602 34 19 70001603 34 25 70001604 34 27 70001610 36 1 70001612 36 4 70001613 36 18 70001614 36 19 70001615 36 16 70001616 36 17 70001617 36 15 70001620 36 8 70001630 40 63 70001631 40 73 70001632 40 79 70001633 40 80 70001634 38 10 70001636 38 36 70001638 10 57 70001639 40 59 70001644 48 6 70001659 4 44 70001813 50 29 70001814 50 30 70001830 6 64 70001831 6 63 70001837 2 27 70001838 50 32 70001839 50 33 70001840 50 6 70001842 50 38 70001846 50 34 70001959 16 27 70001962 50 25 70001963 50 28 70001964 50 23 70001967 50 24 70001975 40 87 70001976 6 60 70001978 4 8 70003316 8 22 70003331 8 44-56 70004184 8 34 PART NO PAGE REF NO. 70004197 8 9 70004223 28 29-31 70004224 28 29-31 70004227 50 39 70004371 12 46 70004484 8 39 70004489 8 35 70004493 6 62 70004610 44 10-12 70004611 46 54 70004612 44 24-28 70004613 44 19-23 70004630 8 15 70004631 8 16 70004632 8 18 70004633 8 17 70004635 8 1 70004637 30 1 70004640 8 6 70005086 8 27 B2556280000 18 67 B3215470000 48 10 B3538112000 48 10 B9101490000 50 14 B9214850000 24 21 BP30000010R 38 77 BP30000010R 40 77 BT0600402EA 48 4 CM300200001 2 29 CM30020001 6 65 CM301300001 2 26 CQ303000000 16 23 CQ303000000 28 19 CQ303000000 48 5 CS1000881TP 16 85 CS1000881TP 18 85 CS1000881TP 22 23 CS1000881TP 24 6 CS1000881TP 28 25 CS1000881TP 30 8 EA9500B0100 40 60 J106600000B 50 16 MML018800CB 50 8 MUY128S1000 44 7-8 MUY128S1003 50 37 PART NO PAGE REF NO. MUY128S1400 44 7-8 NM6030001SC 30 32 NM6030001SD 44 45 NM6040000SN 2 19 NM6040000SN 6 57 NM6040000SN 40 86 NM6040002SC 42 27 NM6050001SC 18 69 NM6050001SC 24 45 NM6050001SC 28 8 NM6050001SC 34 16 NM6050001SC 38 26 NM6050001SE 42 28 NM6060001CP 12 27 NM6850001SC 30 43 PS0150065KP 46 49-50 PS0150082KH 24 22 PS0150082KH 46 49-50 PS0300162KH 18 58 PS0400082KP 24 34 PS0500142KP 12 20 RC0100001KP 16 40 RC0741013KP 18 70 RC1900002KP 4 3 RE0300000KO 4 42 RE0300000KO 22 11 RE0500000KO 18 55 RE0500000KO 32 11 RE0700000KO 34 12 RO055200100 18 51 RO055200100 32 9 RO068190100 22 2 RO137230100 18 82 RO148240200 8 42 RO158240100 16 7 RO195240100 2 10 SB120001500 8 41 SB120001900 10 70 SB120002200 10 55 SB30800110A 14 49-52 SB30800110B 14 49-52 SB30800110C 14 49-52 SB30800110D 14 49-52 SD0640246SP 2 20 SD0640246CSP 30 21 INDEX - 4 jintex.in

Page 58 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS PART NO PAGE REF NO. PART NO PAGE REF NO. PART NO PAGE REF NO. SD070020CTP 12 16 SM405125SP 18 65 SM6051402TP 34 30 SD070058CTP 12 24 SM405125SP 22 14 SM6051602TP 6 59 SD0801326TH 16 33 SM4051405SE 42 25 SM6051602TP 18 68 SL4041281SC 30 15 SM4060801SE 2 21 SM6051602TP 40 55 SM1030400SP 22 33 SM4850455SP 30 34 SM6061200SP 10 75 SM1040055SP 24 38 SM4850455SP 32 3 SM6061200SP 12 28 SM1040100TP 26 59 SM48504C5SP 24 37 SM6061200TP 18 75 SM1040800SP 4 7 SM48504C5SP 30 27 SM6061402TP 8 61 SM1040801SC 50 27 SM5050855SN 22 6 SM6061402TP 10 61 SM10414C0SP 4 11 SM5050855SN 50 19 SM6061402TP 16 38 SM1850600SP 44 39-40 SM6030402TP 18 56 SM6061402TP 28 9 SM4030455SN 2 17 SM6030600SP 16 39 SM6061802TP 38 32 SM4030855SN 2 18 SM6030600SP 48 7 SM60625C0TP 12 26 SM4030855SN 14 61 SM6030800SP 4 38 SM6850400SP 44 42 SM4030855SN 24 27 SM6040600SP 40 51 SM6850802TN 30 42 SM4030855SN 40 82 SM6040602TP 4 10 M7051460TP 22 15 SM4040555SP 6 51 SM6040650TP 50 35 SM8030312TP 24 26 SM40405C5SP 26 56 SM6040750TP 34 32 SM8030312TP 44 51 SM4040655SP 2 23 SM60407C0TP 4 22 SM8030312TP 46 51 SM4040655SP 4 56 SM6040800SP 4 14 SM8030412TP 44 33 SM4040655SP 6 56 SM6040800SP 12 38 SM8030412TP 44 44 SM4040655SP 8 24 SM6040800SP 20 98 SM8030412TP 6 50 SM4040655SP 12 10 SM6041000SP 24 47 SM8030412TP 12 34 SM4040655SP 24 53 SM6041000SP 44 31 SM8030412TP 4 34 SM4040655SP 26 53 SM6041000SP 12 53 SM8040412TP 8 20 SM4040655SP 30 36 SM6041000SP 14 53 SM8040512TP 18 53 SM4040655SP 36 23 SM6041000SP 16 31 SM8040612TP 28 12 SM4040655SP 38 81 SM6041000SP 22 34 SM8040612TP 12 44 SM4040655SP 40 81 SM6041000SP 28 30 SM8040612TP 18 50 SM4040655SP 48 11 SM6041000SP 34 22 SM8040612TP 18 83 SM4040855SP 2 30 SM6041002TP 4 12 SM8050412TP 18 99 SM4040855SP 38 37 SM6041200SP 12 14 SM8050412TP 20 99 SM4040855SP 50 21 SM6041200SP 28 28 SM8050412TP 28 26 SM4041055SP 2 8 SM6041200SP 40 84 SM8050412TP 38 42 SM4041055SP 6 55 SM6041202TP 12 23 SM8050612TP 16 86 SM4041055SP 8 29 SM6041202TP 34 4 SM8050612TP 18 86 SM4041055SP 12 41 SM6042000SP 40 50 SM8050612TP 24 7 SM4041055SP 24 15 SM6050800SP 4 23 SM8050612TP 32 9 SM4041055SP 36 20 SM6051000SP 32 13 SM8050612TP 30 6 SM4041055SP 38 2 SM6051002TP 12 30 SM8050612TP 32 14 SM404115C 42 24 SM6051002TP 24 1 SM8050612TP 34 14 SM4041655SP 36 3 SM6051202TP 12 59 SM8050812TP 16 95 SM4042501SC 42 26 SM6051202TP 14 59 SM8050812TP 20 95 SM4050855SP 48 3 SM6051400SP 4 39 SM8060552TP 8 36 SM4051055SP 6 66 SM6051402TP 24 12 SM8060552TP 16 80 INDEX - 5 jintex.in

Page 59 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS PART NO PAGE REF NO. PART NO PAGE REF NO. SM8060552TP 18 80 WP0370316SD 16 18 SM8060552TP 30 39 WP0410516SD 30 23 SM8060612TP 8 72 WP0450801SC 26 57 SM8060612TP 10 72 WP0450801SC 40 85 SM8060612TP 16 88 WP0450801SP 50 22 SM8060612TP 18 88 WP0450826SC 12 40 SM8060612TP 28 21 WP0450826SC 22 5 SM8060612TP 34 6 WP0450826SC 24 46 SM80606A2TP 18 78 WP0460556SD 22 9 SM8060812TP 8 54 WP0461516SH 34 24 SM8060812TP 10 54 WP0480856SP 20 97 SM8060812TP 40 65 WP0501016SD 6 69 SM8060842TP 8 71 WP0522016SH 24 4 SM8060842TP 10 71 WP0531000SC 4 31 SM8061212TP 8 47 WP0531000SD 4 4 SM8080812TP 10 74 WP0531001SC 42 30 SM9061050TP 28 20 WP0550800SP 4 43 SQ0000452MZ 38 15 WP0550800SP 28 7 SQ0000453MZ 38 13 WP0550800SP 34 15 SQ0000454MZ 38 12 WP0550800SP 40 54 SQ2000452MZ 38 25 WP0550836SC 50 20 SQ2060441SD 38 16 WP0551016SH 12 31 SQ2060442SD 38 11 WP0621016SD 22 16 SQ2060451MZ 40 52 WP0621016SD 32 10 ST4040851SN 24 23 WP1021026SH 34 11 TA0400301MO 4 9 WP1022016SH 28 24 TA0500601MO 16 46 WP1612616SE 42 29 TA0500601MO 34 18 WS0510002KN 24 11 TA0750404R0 22 27 WS0510002KN 42 31 TA0850604R0 2 33 WS0510002KP 4 30 TA0850604R0 4 47 WS0510002KP 24 2 TA1050504R0 2 3 WZ0641510KP 2 16 TA1050504R0 4 70 WZ0641510KP 6 61 TA1050504R0 6 70 WZ0641510KP 30 22 TA1250705R0 2 31 TA1600406R0 34 9 TA2050406R0 2 6 TA2050416R0 4 68 TA2050416R0 6 68 TA2101002R0 6 67 TA2101002R0 30 40 TA2351004R0 2 24 WP0280500SC 30 33 WP0280500SC 44 43 WP0280501SC 24 36 INDEX - 6 jintex.in
