Page 1 — MF-7800 Series PARTS LIST
JUKI
High-speed, Cylinder-bed Coverstitch Machine
高速シリンダーベッド飾り縫いミシン
MF-7800
Series
PARTS LIST
HOW TO MAKE USE OF THIS PARTS LIST
1. As to "#01" and "#02" refer to the "Note" given at the bottom of the respective pages.
2. Codes on the "Qty" column
Each numeral indicates the number of parts required.
"0.1" and "2.5" indicate the length (in meters) of the respective parts.
3. Parentheses mean that the corresponding part is a subpart that constructs an assembly part.
4. Dotted lines on the Figures indicate assembly parts.
パーツリストご利用に際して
1. リストページの#01、#02等の印は、ページ下の"注記"の説明をご参照下さい。
2. 数量欄の数字は、個数を表し、0.1、2.5等の数値は、長さ(単位メートル)を表します。
3. 数量欄の( )は、組部品を構成している子部品であることを意味します。
4. イラストページのーーー棒は、組構成であることを意味します。
13450200
No.1380-00
jintex.in
Page 2
jinttex.in
jintex.in
Page 3 — CONTENTS
CONTENTS
目 次
1. FRAME & MISCELLANEOUS COVER COMPONENTS (1) 1
頭部・外装関係 (1)
2. FRAME & MISCELLANEOUS COVER COMPONENTS (2) 3
頭部・外装関係 (2)
3. MAIN SHAFT COMPONENTS 5
主軸関係
4. NEEDLE BAR & PRESSER COMPONENTS 7
針棒・押え関係
5. FEED DRIVE COMPONENTS (1) 9
送り関係 (1)
6. FEED DRIVE COMPONENTS (2) 11
送り関係 (2)
7. THREAD TAKE-UP LEVER COMPONENTS 13
天秤関係
8. SPREADER COMPONENTS 15
スプレッダー関係
9. LOWER THREAD CAM COMPONENTS 17
下糸カム関係
10. NEEDLE GUARD COMPONENTS 19
針受け関係
11. LOOPER COMPONENTS 21
ルーバー関係
12. THREAD TENSION COMPONENTS 23
糸調子関係
13. LUBRICATION COMPONENTS 25
給油関係
14. THREAD STAND COMPONENTS 27
糸立装置関係
15. GAUGE PARTS COMPONENTS 29
ゲージ関係
16. NEEDLE COOLING MECHANISM COMPONENTS 31
針冷却装置関係
17. ACCESSORIES PARTS COMPONENTS 32
付属品関係
NUMERICAL INDEX OF PARTS 33
索引
Page 4 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS (1)
1. FRAME & MISCELLANEOUS COVER COMPONENTS (1)
頭部・外装関係 (1)
54
15
56
55
16
57
8
4
28
9
14
29
10
13
11
12
26
27
50
51
53
18
19
21
24
25
20 22
17
37
36
38
33
39
42
32
41
49
44
43
40
31
34 35
45
46
47
48
2
1
-1-
jintex.in
Page 5
REF. NO NOTE PART NO. DESCRIPTION Qty.
1 #02 134-38007 COVERING GUARD R 1
2 #02 134-38106 COVERING GUARD L 1
3 SM-8040412-TP SET SCREW M4 L=4 3
4 TA-2050406-RO RUBBER PLUG D=12.5 L=4 1
5 TA-1250406-RO RUBBER PLUG D=12.5 L=4 2
6 TA-1701002-RO RUBBER PLUG 1
7 229-01805 GROUND MARK 1
8 CM-3002000-01 ATTENTION SEAL 2
9 133-00959 ASSY HEAD COVER 1
10 133-00900 HEAD COVER (1)
11 229-02506 FACE PLATE (1)
12 TA-1050504-RO RUBBER PLUG (1)
13 SM-4041055-SP SCREW (1)
14 133-01007 GASKET II 4
15 133-01304 NEEDLE BAR GUARD 1
16 SM-4040655-SP SCREW M4 L=6 2
17 133-01759 PROTECTION SHIELD_ASSY 1
18 133-01502 BRACKET HOLDER (1)
19 133-01601 BRACKET (1)
20 133-01700 PROTECTION SHIELD (1)
21 WZ-0641510-KP WAVED WASHER 6.4X11X0.3 2
22 SM-4030455-SN SCREW (1)
23 NM-6040001-SP NUT M4X0.7 1
24 SD-0640246-SP HINGE SCREW D=6.35 H=2.4 1
25 SM-8060800-SP SCREW M6 L=8 1
26 133-01403 THREAD COVER 1
27 SM-4040655-SP SCREW M4 L=6 1
28 133-02401 LMS FAN COVER 1
29 SM-4040655-SP SCREW M4 L=6 2
30 133-01809 SUPPORT STUD 4
31 134-00957 SWING DOWN COVER ASSY 1
32 134-00908 SWING DOWN COVER (1)
33 133-02302 RUBBER BUMPER (1)
34 134-01203 HINGE (1)
35 SM-8040360-TP SCREW (1)
36 134-01005 CLOTH PLATE FRONT (1)
37 SM-1040080-SP SCREW 3
38 134-02706 PIN FOR COVER (3)
39 SM-8040360-TP SCREW (1)
40 134-03506 PIN FOR S D COVER (1)
41 RE-030000-KO E-RING 3 (1)
42 WP-0550800-SP WASHER 5.5X10X0.8 (1)
43 133-02708 RUBBER WASHER (2)
44 134-03605 RUBBER PLATE (1)
45 SM-6051400-SP SCREW 2
46 134-02904 BRACKET N 1
47 #01 134-01104 BRACKET 1
48 SM-6030600-SP SCREW M3X0.5 L=6 2
49 SL-4040805-SC SCREW 2
50 SM-4041055-SP SCREW 1
51 NM-6040001-SP NUT M4X0.7 1
52 133-02302 RUBBER BUMPER 1
53 TA-1900502-RO RUBBER PLUG (1)
54 133-02658 DRIVING BELT COVER ASSY (1)
55 133-02609 DRIVING BELT COVER (1)
56 CM-3002000-A1 CAUTION LABEL(16) (1)
57 SM-4051255-SP SCREW, M5 L=12. 2
58 SM-4050855-SP SCREW. 1
NOTE (注記) #01...FOR MF-7800-U10 MF-7800-U10
#02...FOR MF-7800-K10 MF-7800-K10用
- 2 -
jintex.in
Page 6 — 2. FRAME & MISCELLANEOUS COVER COMPONENTS (2)
2. FRAME & MISCELLANEOUS COVER COMPONENTS (2)
頭部・外装関係 (2)
-3-
jintex.in
Page 7
REF. NO NOTE PART NO. DESCRIPTION Qty.
1 TA-0850604-RO RUBBER PLUG トメセン 3
2 107-53309 WINDOW PLATE RUBBER PLUG マト・イタトメセン 1
3 TA-2351004-RO RUBBER PLUG トメセン 1
4 SM-8060612-TP SCREW M6 L=6 トメネジ M6 L=6 2
5 CM-3002001-B1 SAFETY LABEL 12 アンセノラベル 12 1
6 133-00702 TOP COVER トップカバー 1
7 SM-4041055-SP SCREW ナベネジ M4 L=10 8
8 107-53309 WINDOW PLATE RUBBER PLUG マト・イタトメセン 1
9 RO-1952401-00 RUBBER RING Oリング 1
10 229-24708 OIL SIGHT WINDOW アブ・ラマド 1
11 133-00801 GASKET T ガスケツトT 1
12 133-01106 PULLER DRIVE COVER プーラー ドライブ カバー 1
13 SM-6060800-SP SCREW M6 L=8 ヒラネジ M6 L=8 6
14 133-01205 GASKET P ガスケツトP 1
15 134-01757 SIDE COVER ASSY サイ ドカバーアツシー 1
16 134-0150 CYLINDER COVER シリンダーカバー (1)
17 134-01807 CYLINDER COVER PLATE シリンダー・カバー・プレート (1)
18 SM-4040655-SP SCREW M4 L=6 ナベネジ M4 L=6 (2)
19 134-01708 SIDE COVER サイ ドカバー (1)
20 134-01906 LATCH SPRING 2 ラツチスプリング (1)
21 SM-4040655-SP SCREW M4 L=6 ナベネジ M4 L=6 (1)
22 PH-0300252-CO PARALLEL PIN ヘイコウピン マル3X25 (2)
23 SM-8040360-TP SCREW トメネジ M4 L=3 (2)
24 RO-0371801-00 RUBBER RING Oリング (2)
25 134-01609 GASKET ガスケツト 1
26 SM-4041055-SP SCREW ナベネジ M4 L=10 4
27 134-00650 ASSY_TP_SUPPORT アツシーTPサポート 1
28 134-00601 THROAT PLATE SUPPORT スロートプレートサポート (1)
29 133-01908 DOWEL PIN タウエルピン (1)
30 133-02500 DOWEL PIN 2 タウエルピン2 (1)
31 236-30007 TUBE チューブ (0.01)
32 134-03407 SLIDE COVER_SUPPORT スライドカバーサポート (1)
33 SM-4030655-SP SCREW ナベネジ M3 L=6 (2)
34 134-03605 RUBBER_PLATE ラバープレート (1)
35 133-02203 SCREW スクリユウ 2
36 SM-4040855-SP SCREW ナベネジ 3
37 134-00700 BED TOP COVER ヘツドトップカバー 1
38 134-00809 GASKET B ガスケツトB 1
39 SM-6040870-SP SCREW ヒラネジ M4 L=8 1
40 134-02300 NIPPER PLATE ニツパープレート 1
41 134-02409 SPRING スプリング 1
42 134-02409 NIPPER SPRING PLATE ニツパー・スプリング・プレート 2
43 133-26202 SHOULDER SCREW ショルダースクリユー 1
44 134-02003 LATCH SPRING ラツチスプリング 1
45 SM-1040860-SP SCREW サラコネジ M4 L=8 9
46 134-01351 CLOTH PLATE ASSY クロスプレートアツシー 1
47 134-01302 CLOTH PLATE REAR クロスプレートリア (1)
48 134-02102 THD GUIDE スレッドガイド (1)
49 PS-0150042-KO SPRING PIN 1.5X 4 スプリング・ピン 1.5X 4 (1)
50 134-01401 SLIDE COVER スライドカバー 1
51 SM-4041055-SP SCREW ナベネジ M4 L=6 3
52 134-02201 LOOPER THD GUIDE ルーバー・スレッドガイド 1
53 SM-4040655-SP SCREW M4 L=6 ナベネジ M4 L=6 1
- 4 -
jintex.in
Page 8 — 3. MAIN SHAFT COMPONENTS
3. MAIN SHAFT COMPONENTS
主軸関係
- 5 -
jintex.in
Page 9
REF. NO. NOTE PART NO. DESCRIPTION Qty
1 133-07004 UPPER MAINSHAFT RIGHT 1
2 134-06608 UPPER_PULLEY 2
3 SM-8061212-TP SCREW M6X12 (1)
4 133-07251 BEARING ASSY A (1)
5 SM-8060842-TP SCREW M6 L=8 (1)
6 SM-8060612-TP SCREW M6 L=6 (1)
7 133-07301 UMS SPROCKET (1)
8 SM-8060812-TP SCREW M6 L=8 4
9 133-07459 BEARING ASSY B (1)
10 SM-8060612-TP SCREW M6 L=6 (2)
11 133-07509 JOINT 1
12 SM-8060612-TP SCREW M6 L=6 4
13 133-07657 UMS_LEFT_ROD_ASSY 1
14 133-24108 SCREW (4)
15 SM-6061402-TP SCREW M6 L=14 (1)
16 133-07608 UPPER MAINSHAFT LEFT (1)
17 133-24009 ROD (1)
18 133-24207 CRANK (1)
19 SM-1200019-00 BEARING (1)
20 SM-8060842-TP SCREW M6 L=8 1
21 SM-8060612-TP SCREW M6 L=6 1
22 133-07707 COUNTER WEIGHT 1
23 133-09208 SCREW FOR COUNTERWEIGHT 1
24 SM-8080812-TP SCREW M8X8 1
25 SM-6061200-SP SCREW 1
26 134-08307 BALANCE WEIGHT UMS 2
27 SM-8060812-TP SCREW M6 L=8 1
28 134-06905 TIMING BELT 1
29 134-07101 LOWER MAINSHAFT RIGHT 1
30 134-06707 LOWER PULLEY 1
31 SM-8061212-TP SCREW M6X12 2
32 133-09158 BEARING ASSY_F (1)
33 SM-8060842-TP SCREW M6 L=8 (1)
34 SM-8060612-TP SCREW M6 L=6 (1)
35 133-09000 LMS_FAN (1)
36 PS-0400082-KP SPRING PIN (1)
37 133-08309 LMS SPROCKET 1
38 SM-8060812-TP SCREW M6 L=8 4
39 134-07457 BEARING ASSY E 1
40 SM-8060612-TP SCREW M6 L=6 (2)
41 134-08406 BALANCE_WEIGHT_LMS_1 (1)
42 SM-8050512-TP SCREW M5 L=5 2
43 134-08505 BALANCE_WEIGHT_LMS_2 2
44 SM-8050512-TP SCREW M5 L=5 2
45 134-07507 JOINT GEAR 1
46 SM-8060552-TP SCREW M6 L=5 3
47 SM-8060842-TP SCREW M6 L=8 1
48 SM-8060552-TP SCREW M6 L=5 2
49 SB-1150023-00 - BEARING 2
50 134-07259 CRANK JOINT ROD ASSY 1
51 133-24108 SCREW (2)
52 SD-0550906-TP SHOULDER SCREW (2)
53 133-37100 GUIDE LOOPER ROD (1)
54 WS-0510002-KP SPRING WASHER 5.1X9.2X1.3 (1)
55 SM-4051055-SP SCREW (1)
56 134-07200 CRANK JOINT (1)
57 134-24205 ROD (1)
58 134-24106 CRANK (1)
59 134-07705 BUSHING LMS MIDDLE 1
60 134-08703 OIL SEAL 1
61 134-07804 BUSHING LMS LEFT 1
62 134-07903 OIL SEAL 1
63 134-08604 FELT LMS LEFT BUSH 1
64 PS-0300122-KH SPRING PIN 3X12 1
65 134-06806 COVER LMS M BUSH 1
66 #01 133-07806 HOUSING A 1
67 #01 133-09307 HOUSING B 1
68 #01 133-09406 HOUSING C 1
69 SM-8550952-TP SCREW 1
70 134-07606 LOWER MAINSHAFT LEFT 1
71 SM-8050412-TP SCREW M5 L=4 1
72 RC-4881514-KP C-RING 1
73 RC-4881514-KP C-RING 1
NOTE (注記) #01...SELECTIVE PARTS 選択部品
- 6 -
jintex.in
Page 10 — 4. NEEDLE BAR & PRESSER COMPONENTS
4. NEEDLE BAR & PRESSER COMPONENTS
針棒・押関係
65
62
48
22
23
49
61
60
47
64
63
78
72
73
71
74
75
76
77
55
56
57
59
58
53
54
52
51
66
67
68
69
70
46
17
16
24
18
21
20
29
30
33
35
34
32
31
36
37
38
39
40
41
42
43
10~12
1
2
5~8
3
15
14
13
9
4
19
-7-
jintex.in
Page 11
REF. NO. NOTE PART NO. DESCRIPTION Qty.
1 133-11253 ASSY NEEDLE MECH (1)
2 133-11204 CONNECTING ROD (1)
3 133-11006 ECCENTRIC PIN (1)
4 133-11303 NEEDLE BAR CLAMP (1)
5 #01 SB-3080011-0A BEARING (1)
6 #01 SB-3080011-0B BEARING (1)
7 #01 SB-3080011-0C BEARING (1)
8 #01 SB-3080011-0D BEARING (1)
9 SM-6041000-SP SCREW M4 L=10 (1)
10 #01 133-12103 THRUST WASHER 1
11 #01 133-12202 THRUST WASHER 1
12 #01 133-12301 THRUST WASHER 1
13 133-11600 NEEDLE BAR GUIDE 1
14 133-11501 SLIDE BLOCK 1
15 SM-6051000-SP SCREW M5 L=10 3
16 133-26806 NEEDLE BAR EYELET 1
17 SM-4030655-SP SCREW M3 L=6 1
18 133-11956 ASSY BUSHING NB 1
19 133-11808 BUSHING NB UPPER (1)
20 133-11808 BUSHING NB LOWER (1)
21 133-11451 NEEDLE BAR ASSY (1)
22 WP-0702026-SP WASHER 7X15X2 1
23 WZ-1052010-KP WAVED WASHER 1
24 133-13051 ADJ SCREW P B ASSY 1
25 133-13101 LOCKING NUT 1
26 133-13309 SPRING PRESSER BAR A 1
27 133-13408 SPRING PRESSER BAR B 1
28 133-13507 PRESSER BAR 1
29 133-13705 BUSHING PRESSER BAR 1
30 133-15908 OIL SEAL 1
31 133-16005 FINGER GUARD 1
32 SM-4030455-SP SCREW 1
33 133-13606 COLLAR 1
34 133-16302 THREAD TRIMMER 1
35 SM-8040410-TP SCREW 2
36 SM-6030500-SN GUIDE PLATE 1
37 133-13804 P B BRACKET ASSY 1
38 SM-6041000-SP P B BRACKET 2
39 133-13952 P B BRACKET PIN (1)
40 133-13903 WASHER (1)
41 133-16203 SCREW M4 L=12 (1)
42 133-33208 LINK (1)
43 SM-6041200-SP SHOULDER SCREW 2
44 133-14109 ASSY LIFTER SHAFT 1
45 SD-0700206-TP SPRING LIFTER LEVER 1
46 133-14356 SCREW M6 L=10 1
47 133-15205 LIFTER LEVER (1)
48 SM-6061002-TP HOOK SHAFT OIL SEAL (1)
49 133-15007 BUSHING LIFTER FRONT 1
50 235-37202 THRUST COLLAR 1
51 133-14406 SCREW M5 L=4 2
52 CS-0800881-TP SPRING PF LIFT 1
53 SM-8050412-TP LIFTER SHAFT LEVER ASSY 1
54 133-14802 LIFTER SHAFT LEVER (1)
55 133-14752 SCREW M5X0.8 L=12 (1)
56 133-14703 BUSHING LIFTER REAR 1
57 SM-6051202-TP LIFTER HOOK 1
58 133-14505 SPRING PIN 1
59 133-14901 LIFTER LEVER HOLDER 1
60 PS-0500142-KP TENS RELEASE LEVER ASSY 1
61 133-15106 TENSION RELEASE LEVER (1)
62 133-15353 SCREW M4X0.7 L=12 (1)
63 133-15304 SHOULDER SCREW 1
64 SM-6041202-TP STOPPER ASSY 1
65 SD-0700586-TP LIFTER LEVER STOPPER (1)
66 133-15551 SCREW (1)
67 133-15502 NUT M6 (1)
68 SM-9062550-TP SCREW M6 L=12 2
69 NM-6060001-CP MINUTE LIFTING ASSY 1
70 SM-6061202-TP BRACKET (1)
71 133-15650 SCREW (1)
72 133-15601 SLIDER (1)
73 133-15700 WASHER 4.6X7.5X0.5 (1)
74 133-15809 ADJUSTING SPRING (1)
75 WP-0460556-SD E-RING 3 (1)
76 131-23302 SCREW M6 L=8 2
77 RE-0300000-KO
78 SM-6060800-SP
NOTE (注記) #01...SELECTIVE PARTS 選択部品
-8-
jintex.in
Page 12 — 5. FEED DRIVE COMPONENTS (1)
5. FEED DRIVE COMPONENTS (1)
送り関係 (1)
-9-
jintex.in
Page 13
REF. NO NOTE PART NO. DESCRIPTION Qty
1 134-10006 FEED ECCENTRIC フィード・エキセントリック 1
2 SM-8060612-TP SCREW M6 L=6 トメネジ M6 L=6 2
3 B1426-180-A00 NEEDLE BEARING (A) ヘリコータ・ニードルベアリング A 1
4 B1426-180-B00 NEEDLE BEARING (B) ヘリコータ・ニードルベアリング B 1
5 B1426-180-C00 NEEDLE BEARING (C) ヘリコータ・ニードルベアリング C 1
6 B1426-180-D00 NEEDLE BEARING (D) ヘリコータ・ニードルベアリング D 1
7 B1426-180-000 C-RING Cカバー・リング 1
8 RC-2251213-KP CRANK ROD クランク・ロッド 1
9 134-10105 FEED ADJ. LINK PIN A フィード・アジャスト・リンク・ピン A 1
10 133-23308 FEED ADJ. LINK PIN B フィード・アジャスト・リンク・ピン B 1
11 133-23407 FEED ADJ. LINK PIN C フィード・アジャスト・リンク・ピン C 1
12 CQ-3030000-00 OIL WICK ユシン 0.07
13 134-10204 MAIN ADJ. LINK メイン・アジャスト・リンク 1
14 SM-8050512-TP SCREW トメネジ M5 L=5 2
15 133-18704 MAIN FEED CRANK PIN A メイン・フィード・クランク・ピン A 1
16 133-18503 MAIN FEED CRANK PIN B メイン・フィード・クランク・ピン B 1
17 133-18902 MAIN FEED CRANK PIN C メイン・フィード・クランク・ピン C 1
18 NM-6040001-SP NUT M4X0.7 ロクカクナット M4X0.7 1
19 CQ-3030000-00 OIL WICK ユシン 0.04
20 SM-8050512-TP SCREW トメネジ M5 L=5 1
21 133-17300 ADJUST LINK アジャスト・リンク 1
22 134-10600 FEED ADJ. LINK PIN A フィード・アジャスト・リンク・ピン A 1
23 134-10709 FEED ADJ. LINK PIN B フィード・アジャスト・リンク・ピン B 1
24 134-10808 FEED ADJ. LINK PIN C フィード・アジャスト・リンク・ピン C 1
25 CQ-3030000-00 OIL WICK ユシン 0.07
26 134-15708 FEED ADJ. BLOCK フィード・アジャスト・ブロック 1
27 134-11004 BUSHING MAIN FEED ADJ ブッシング・メイン・フィード・アジャスト 1
28 134-15807 BUSHING MAIN FEED ADJ ブッシング・メイン・フィード・アジャスト 1
29 134-15906 SHAFT FEED ADJ. BLOCK シャフト・フィード・アジャスト・ブロック 1
30 B2546-232-000 PRESSURE SPRING オゲナ・スプリング 1
31 SM-8050512-TP SCREW トメネジ M5 L=5 4
32 SM-6051400-SP SCREW ヒラネジ 1
33 NM-6050001-SP NUT M5 ロクカクナット M5X0.8 1シュ 1
34 134-11509 MAIN FEED CRANK メイン・フィード・クランク 1
35 SM-8060552-TP SCREW M6 L=5 トメネジ M6 L=5 2
36 134-14305 FEED LIFT ROD フィード・リフト・ロッド 1
37 121-16604 NEEDLE BEARING オクリベア・リング A 1
38 121-16703 NEEDLE BEARING B オクリベア・リング B 1
39 121-16802 NEEDLE BEARING.,C. オクリベア・リング C 1
40 121-16901 NEEDLE BEARING.,D. オクリベア・リング D 1
41 121-17008 NEEDLE BEARING.,E. オクリベア・リング E 1
42 B1248-280-000 STOP RING フェルト・トメネジ 1
43 134-14404 FEED LIFT LEVER フィード・リフト・レバー 1
44 RE-0500000-K0 E-RING Eガ・トメネジ 5 1
45 SM-8060552-TP SCREW M6 L=5 トメネジ M6 L=5 2
46 134-11608 MAIN FEED SHAFT メイン・フィード・シャフト 1
47 TA-0500601-K0 PLUG D=5X5.4 L=6 トメネジ D=8 H=16.3 1
48 CQ-3000000-01 OIL WICK ユシン 0.67
49 CQ-2020000-00 OIL WICK ユシン 1
50 134-12002 MAIN FEED LINK PIN A メイン・フィード・リンク・ピン A 1
51 134-12101 MAIN FEED LINK PIN B メイン・フィード・リンク・ピン B 1
52 134-12200 MAIN FEED LINK PIN C メイン・フィード・リンク・ピン C 1
53 134-11905 MAIN FEED LINK メイン・フィード・リンク 1
54 SM-8040412-TP SET SCREW M4 L=4 タンネジ D=8 H=16.3 1
55 SD-0801636-TH SHOULDER SCREW フィード・リフト・シャフト 1
56 134-14503 FEED LIFT SHAFT トメネジ D=5X5.4 L=6 1
57 TA-0500601-K0 PLUG D=5X5.4 L=6 ユシン マル3 0.67
58 CQ-3000000-01 OIL WICK ブッシング・フィード・メカ 2
59 134-11707 BUSHING FEED MECH ブッシング・フィード・メカ 1
60 134-09206 BUSHING FEED MECH ブッシング・フィード・メカ 1
61 134-09107 WASHER ワッシャー 2
62 E3025-721-000 OIL SEAL オイル・シール 2
63 134-15500 BUSHING FEED MECH ブッシング・フィード・メカ 2
64 134-11806 COLLAR カラー 4
65 SM-8060412-TP SCREW トメネジ M6 L=4 4
66 134-08802 BUSHING FEED MECH ブッシング・フィード・メカ 1
67 133-18001 KNOB FEED ADJUST ノブ・フィード・アジャスト 1
68 SM-8040602-TP SCREW M4X0.7 L=6 トメネジ 1
69 SM-8040412-TP SET SCREW M4 L=4 トメネジ 1
70 B3215-470-000 PIN イトマキ・ピン 1
71 134-11400 BUSHING FEED ADJ ブッシング・フィード・アジャスト 1
72 134-11301 SHAFT FEED ADJ. シャフト・フィード・アジャスト 1
73 R0-0552001-00 RUBBER RING Oリング 1
74 RE-0500000-K0 E-RING Eガ・トメネジ 5 2
75 133-18308 STOPPER FEED ADJUST ストッパー・フィード・アジャスト 1
76 134-11152 INDICATOR ASSY インジケータ・アッシー 1
77 R0-0681901-00 RUBBER RING Oリング 1
78 134-13901 FEED BAR ASSY フィード・バー・アッシー (1)
79 134-13902 MAIN FEED BAR メイン・フィード・バー (1)
80 134-13703 DIFF FEED BAR デフ・フィード・バー (1)
81 134-14107 SLIDE BLOCK 1 スライド・ブロック 1 (1)
82 134-13802 SLIDE BLOCK 2 スライド・ブロック 2 (1)
83 SM-6041000-SP SCREW M4 L=10 ヒラネジ M4 L=10 2
84 134-14107 FEED BAR GUIDE 1 フィード・バー・ガイド 1 1
85 SM-8050812-TP SCREW M5X0.8 L=8 トメネジ M5X0.8 L=8 1
86 134-13307 DIFF FEED CRANK ディフ・フィード・クランク 1
87 SM-8060552-TP SCREW M6 L=5 トメネジ M6 L=5 1
88 SM-8050512-TP SCREW トメネジ 2
89 SM-6042000-SP SCREW ヒラネジ M4 L=20 1
NOTE (注記) #01...SELECTIVE PARTS 選択部品
- 10 -
jintex.in
Page 14 — 6. FEED DRIVE COMPONENTS (2)
6. FEED DRIVE COMPONENTS (2)
送り関係 (2)
- 11 -
jintex.in
Page 15
REF. NO. NOTE PART NO. DESCRIPTION Qty.
1 RE-0300000-KO E-RING 3 Eガ タトメワ 3 1
2 PS-0500202-KP SPRING PIN 5X20 スプ リング ピン 5.0X20 1
3 134-13406 DIFF FEED SHAFT デイアフィード シャフト 1
4 TA-0500601-MO PLUG D=5X5.4 L=6 トメセン D=5X5.4 L=6 1
5 CQ-3000000-01 OIL WICK ユシン マル3 1
6 134-13604 DIFF FEED LINK デイアフィードリンク 1
7 SD-0801866-TH SHOULDER SCREW ダンネジ D=8 H=18.6 1
8 SD-0800626-TH SHOULDER SCREW ダンネジ D=8 H=6.2 1
9 134-11707 BUSHING FEED MECH ブツシング フィード メカ 1
10 134-09206 BUSHING FEED MECH ブツシング フィード メカ 1
11 134-09107 WASHER ワツシャー 1
12 E3025-721-000 OIL SEAL オイルシール 1
13 134-15500 BUSHING FEED MECH ブツシング フィード メカ 1
14 134-11806 COLLAR カラー 2
15 SM-8060412-TP SCREW トメネジ M6 L=4 2
16 134-11202 PLATE MAIN FEED ADJ プレートメインフィード アジャスト 1
17 SM-4051255-SP SCREW M5 L=12. ナベネジ M5 L=12 2
18 SM-4040655-SN SCREW M4X0.7 L=6 ナベネジ M4 L=6 1
19 NM-6040000-SN NUT M4 ロツカクナット M4 1
20 134-14206 FEED BAR GUIDE 2 フィード バー ガイド 2 1
21 SM-6040800-SP SCREW ヒラネジ 2
22 WP-0450846-SP WASHER ヒラサガネ 2
23 134-09909 DIFF FEED CRANK PIN デイアフィード クランクピン 1
24 SM-8060552-TP SCREW トメネジ 2
25 134-09602 DIFF DRIVE LINK L デイア ドライブ リンク L 1
26 134-09701 DIFF DRIVE LINK R デイア ドライブ リンク R 1
27 134-09800 DIFF LINK PIN デイアリンクピン 1
28 SM-8040412-TP SET SCREW M4 L=4 トメネジ M4 L=4 2
29 134-16052 DIFF FEED ARM ASSY デイアフィード アームアツシー 1
30 SM-8060552-TP SCREW M6 L=5 トメネジ 1
31 134-16102 DIFF FEED PIN 1 デイアフィード ピン 1 (1)
32 134-16201 DIFF FEED PIN 2 デイアフィード ピン 2 (1)
33 SM-6030650-TP SCREW ヒラネジ M3 L=6 (2)
34 SM-4850455-SP SCREW ナベネジ (1)
35 134-16458 SLIDER GUIDE ASSY スライダ ガイド アツシー 1
36 SM-8040512-TP SCREW トメネジ M4 L=5 1
37 134-16508 PIN DIFF ADJ ピン ディフ ADJ 1
38 134-16606 SPACER スペーサー 1
39 134-13208 DIFF ADJ LINK デイアアジヤストリンク 1
40 134-16854 DIFF ADJ LEVER ASSY デイアADJ レバーアツシー 1
41 134-16706 SLIDER GUIDE BLOCK スライダ ガイド ブロツク 1
42 SM-6041200-SP SCREW ヒラネジ 2
43 134-15252 DIFF ADJ LEVER ASSY デイアADJ レバーアツシー 1
44 134-15401 TORSION SPRING トーションスプ リング 1
45 RO-0681901-00 RUBBER RING Oリング 1
46 134-15104 BUSHING FEED ADJ ブツシング フィード アジヤスト 1
47 134-15401 BUSHING FEED ADJ ブツシング フィード アジヤスト 1
48 134-09305 BUSHING FEED ADJ ブツシング フィード ADJ 1
49 CS-1000881-TP THRUST COLLAR スラストウク D=10 W=8 1
50 SM-8040512-TP SCREW M5 L=4 トメネジ M5 L=4 2
51 134-15302 PLATE DIFF ADJ LEVER プレート ディフアジヤストレバー 1
52 SM-4051255-SP SCREW M5 L=12. ナベネジ M5 L=12 2
53 132-17500 DIFFERENTIAL FEED LOCK NUT ナツト ウロツクナツト 1
54 132-17401 DIFFERENTIAL FEED HINGE SCREW ナツト ウタンネジ 1
55 134-17100 SCREW スクリュー 1
56 132-17708 DIFFERENTIAL FEED BLOCK ナツトウビ チョウセツコマ 1
57 133-21203 STOPPER DIFF ADJ ストツパー ディフアジヤスト 1
58 131-23302 ADJUSTING SPRING ナツトウビ チョウセツネジ ハネ 1
59 WP-0621016-SD WASHER 6.2X13X1 ヒラサガネ 6.2X13X1 1
60 SM-4040655-SN SCREW M4X0.7 L=6 ナベネジ M4 L=6 1
61 WP-0450826-SC WASHER 4.5X10X0.8 ヒラサガネ 4.5X10X0.8 1
62 WP-0460556-SD WASHER 4.6X7.5X0.5 ヒラサガネ 4.6X7.5X0.5 1
63 WP-0450826-SC WASHER 4.5X10X0.8 ヒラサガネ 4.5X10X0.8 1
- 12 -
jintex.in
Page 16 — 7. THREAD TAKE-UP LEVER COMPONENTS
7. THREAD TAKE-UP LEVER COMPONENTS
天秤関係
- 13 -
jintex.in
Page 17
REF. NO. NOTE PART NO. DESCRIPTION Qty
1 SM-6051002-TP SCREW M5X0.8 L=10 1
2 WS-0510002-KP SPRING WASHER 5.1X9.2X1.3 1
3 133-24306 SHAFT 1
4 WP-0522016-SH WASHER 1
5 133-24504 BUSHING REAR 1
6 CS-1000881-TP THRUST COLLAR 1
7 SM-8050412-TP SCREW M5 L=4 2
8 133-24603 BUSHING FRONT 1
9 236-12609 FEED CHANGING SHAFT OIL SEAL 1
10 133-24702 HOLDER TAKE UP EYELET 1
11 SM-6051402-TP SCREW M5X0.8 L=14 1
12 133-24801 NDL THREAD TAKE UP 1
13 133-24900 UP LPR THREAD TAKE UP 1
14 SM-4041055-SP SCREW 2
15 133-25006 THREAD GUIDE 1
16 SM-4040655-SP SCREW M4 L=6 2
17 133-25105 THREAD TENSION GUIDE 1
18 133-48008 TANK 1
19 B9213-850-000 SILICONE OIL TANK COVER, UPPER 1
20 B9214-850-000 HEAT REMOVING FELT 1
21 PS-0150082-KH SPRING PIN 2
22 ST-4040851-SN TAPPING SCREW M4X8 2
23 133-25204 HOLDER 1
24 303-91601 NEEDLE THREAD EYELET 3
25 SM-8030350-TP SCREW 3
26 SM-4030855-SN SCREW M3 L=8.0 1
27 SM-4040655-SP SCREW M4 L=6 2
28 133-25402 THREAD GUIDE 1
29 SM-4040655-SP SCREW M4 L=6 1
30 133-25501 COVER 1
31 133-25709 NDL THD STRIKE OFF 1
32 WP-0320501-SC WASHER M3 1
33 SM-4030855-SP SCREW 1
34 133-25600 THD STRIKE OFF PLATE 1
35 WP-0320501-SC WASHER M3 1
36 SM-4030655-SP SCREW 1
37 133-26905 NDL THD STRIKE OFF R 1
38 WP-0280501-SC WASHER M2.6 1
39 SM-4850455-SP SCREW 1
40 133-27002 THD STRIKE OFF PLATE R 1
41 WP-0280501-SC WASHER M2.6 1
42 SM-4850455-SP SCREW 1
43 133-27101 THREAD GUIDE 1
44 WP-0320501-SC WASHER M3 1
45 SM-4030655-SP SCREW 1
46 SM-1040800-SP SCREW 2
47 133-26350 UP LPR TENSION ASSY 1
48 133-26301 THREAD GUIDE UPPER LPR 1
49 133-26400 THREAD GUIDE 1
50 229-45802 THREAD TENSION DISK 1
51 133-26509 TENSION POST 1
52 229-45505 THREAD TENSION SPRING 1
53 133-26608 TENSION NUT 1
54 NM-6050001-SP NUT M5 1
55 WP-0450826-SC WASHER 4.5X10X0.8 2
56 SM-6040800-SP SCREW 2
57 133-25808 NIPPER PLATE SUPPORT 1
58 133-25907 NIPPER PLATE 1
59 133-26004 NIPPER GUIDE PLATE 1
60 133-26103 SPRING 1
61 133-26202 SHOULDER SCREW 1
62 SM-4040655-SP SCREW M4 L=6 1
63 133-26707 THREAD GUIDE 1
- 14 -
jintex.in
Page 18 — 8. SPREADER COMPONENTS
8. SPREADER COMPONENTS
スプレッダー関係
12
14
15
13
16
17
18
28
29
20
30
20
19
21
24
22
23
6
25
27
8
9
10
9
26
2
3
4
5
7
11
- 15 -
jintex.in
Page 19
REF. NO. NOTE PART NO. D E S C R I P T I O N Qty.
1 133-28158 ASSY.UPPPER_LPR_MECH アッシーアッパルーパメーカ (1)
2 SM-8050412-TP SCREW M5 L=4 トメネジ M5 L=4 (2)
3 133-28000 UPPER LOOPER ECCENTRIC アッパルーパエキセントリック (1)
4 133-28109 CONNROD FOR UPPER LPR コンロツドフオーアツパルーパ (1)
5 133-28208 STUD スタツト (1)
6 SM-6061402-TP SCREW M6 L=14 ロツカクアナメジ M6 L=14 1
7 133-28406 UPPER LOOPER SHAFT アッパルーパシヤフト 1
8 133-99209 COLLAR カラー 1
9 SM-8040410-TP SCREW トメネジ M4 L=4 2
10 133-29008 BUSHING REAR フツシング・リア 1
11 133-29107 BUSHING FRONT フツシング・フロント 1
12 133-28554 ASSY.UPPER_LPR_MECH_2 アツシーアツパルーパメーカ2 1
13 CQ-3030000-00 OIL WICK ユシン (0.05)
14 SM-9061050-TP SCREW M6 L=10 ロツカクボルト M6 L=10 (1)
15 SM-8060612-TP SCREW M6 L=6 トメネジ M6 L=6 (1)
16 133-28505 CRANK ROD クランクロツト (1)
17 133-28604 UPPER LOOPER ROCKER アッパルーパ・ロツカー (1)
18 133-28703 UP LPR SHAFT VERTICAL アッパルーパシヤフトバーチカル (1)
19 CS-1000881-TP THRUST COLLAR スラストウケ D=10 W=8 1
20 SM-8050412-TP SCREW M5 L=4 トメネジ M5 L=4 2
21 133-28802 UPPER LOOPER HOLDER アッパルーパ・ホルダー 1
22 SM-6041200-SP SCREW M4 L=12 ヒラネジ M4 L=12 1
23 133-29404 UPPER LOOPER アッパルーパ 1
24 SM-6040800-SP SCREW ヒラネジ 1
25 133-28307 DRIVING ARM ト・ライビング・アーム 1
26 WP-0550800-SP WASHER 5.5X10X0.8 ヒラザガネ 5.5X10X0.8 1
27 NM-6050001-SP NUT M5 ロツカクナット M5X0.8 1シュ 1
28 133-29206 BUSHING VERTICAL プツシング・バーチカル 1
29 133-38900 OIL SEAL オイルシール 1
30 WP-1022016-SH WASHER ヒラザガネ 1
- 16 -
jintex.in
Page 20 — 9. LOWER THREAD CAM COMPONENTS
9. LOWER THREAD CAM COMPONENTS
下糸カム関係
4
5
3
20
1
2
11
10
7
8
9
13
26
13
17
18
19
16
25
12
27
14
15
23
24
22
21
- 17 -
jintex.in
Page 21
REF. NO NOTE PART NO. DESCRIPTION Qty.
1 134-17209 TAKE UP BASE テイクアップ ベース 1
2 134-18306 BUMPER ハンパー 1
3 134-17308 TAKE UP BASE GUIDE テイクアップ ベース ガイド 1
4 134-17407 RESET KNOB リセットノブ 1
5 RO-0371801-00 RUBBER RING Oリング 1
6 PS-0200142-KO SPRING PIN 2.0X14 スプ リング ピン 2.0X14 1
7 134-17704 SPRING TAKE UP スプ リング テイクアップ 1
8 134-17902 TAKE UP PLATE SHAFT テイクアップ プレート シャフト 1
9 RE-0500000-KO E-RING Eガ タトメワ 5 1
10 134-17506 BASE TAKE UP PLATE ベース テイクアップ プレート 1
11 SM-8040412-TP SCREW M4 L=4 トメネジ 1
12 134-17605 TAKE UP PLATE テイクアップ プレート 1
13 SM-6030600-SP SCREW M3X0.5 L=6 ヒラコネジ M3X0.5 L=6 2
14 134-17803 THREAD GUIDE スレッド ガイド 1
15 SM-6040600-SP SCREW M4 L=6 スレッド ガイド 1
16 134-18108 EYELET A アイレットA 1
17 134-18207 EYELET B アイレットB 1
18 WP-0280501-SC WASHER M2.6 ヒラザガネ ミカ*マル M2.6 2
19 SM-4850455-SP SCREW ナベネジ 2
20 SM-6040800-SP SCREW ヒラネジ 2
21 134-18009 LOCATION SPRING ロケーションスプリング 1
22 SM-4040655-SP SCREW M4 L=6 ナベコネジ M4 L=6 1
23 134-18454 TAKE UP ASSY テイクアップ アッシー 1
24 SM-8050412-TP SCREW M5 L=4 トメネジ M5 L=4 2
25 134-18702 THREAD CATCHER スレッド キャッチャー 1
26 SM-6030350-SN SCREW M3 L=2.5 ヒラネジ M3 L=2.5 1
27 WP-0430800-SC WASHER M4 ヒラザガネ コ*タマル M4 1
- 18 -
jintex.in
Page 22 — 10. NEEDLE GUARD COMPONENTS
10. NEEDLE GUARD COMPONENTS
針受け関係
18
2
1
6
3
7
5
16
17
15
10
9
9
8
12
13
19
20
11
14
- 19 -
jintex.in
Page 23
REF. NO. NOTE PART NO. DESCRIPTION Qty.
1 134-20401 FORK FRONT NDL GUARD 1
2 134-21201 FELT FRONT NDL GUARD 1
3 134-20807 BUSH FRONT NDL GUARD 1
4 SM-6040800-SP SCREW 1
5 134-20500 HOLDER FRONT NDL GUARD 1
6 134-20609 FRONT NDL GUARD 1
7 SM-8040412-TP SET SCREW M4 L=4 1
8 134-20005 CAM REAR NDL GUARD 1
9 SM-8040412-TP SET SCREW M4 L=4 2
10 134-21003 REAR NEEDLE GUARD BLOCK 1
11 134-20104 FORK REAR N GUARD 1
12 134-21300 FELT REAR NDL GUARD 1
13 SM-8050512-TP SCREW 1
14 134-20708 BUSH REAR NDL GUARD 1
15 134-20203 REAR N GUARD HOLDER 1
16 SM-8040412-TP SET SCREW M4 L=4 1
17 134-20302 REAR NEEDLE GUARD 1
18 134-20906 NDL GUARD COVER 1
19 134-21409 COLLAR FOR NDL GUARD 1
20 SM-8040412-TP SET SCREW M4 L=4 1
- 20 -
jintex.in
Page 24 — 11. LOOPER COMPONENTS
11. LOOPER COMPONENTS
ルーバー関係
9 10
11
47
8
7
19
18
6
3~5
20
2
1
2
30
12
14
13
15
22
21
31
29
28
27
16
17
25
23
41
40
39
38
32
33
34
35
46
42
43
24
26
36
37
- 21 -
jintex.in
Page 25
REF. NO NOTE PART NO. D E S C R I P T I O N Qty
1 134-22001 LOOPER ADOID ECCENTRIC ルーパ-アボイド・エキセントリック 1
2 SM-8050612-TP SCREW M5X6 トメネジ M5X6 L=6 2
3 #01 SB-3260002-OA BEARING コロカ・リシ・クウケ 1
4 #01 SB-3260002-OB BEARING コロカ・リシ・クウケ 1
5 #01 SB-3260002-OC BEARING コロカ・リシ・クウケ 1
6 134-22605 LOOPER AVOID LINK ルーパ-アボイド・リンク 1
7 134-24304 LOOPER SHAFT ルーパ-シャフト 1
8 TA-0400301-MO PLUG D=4X4.5 L=3 トメネジ D=4X4.5 L=3 2
9 CS-1000881-TP THRUST COLLAR スラストウケ D=10 W=8 1
10 SM-8050412-TP SCREW M5 L=4 トメネジ M5 L=4 1
11 SM-8050412-TP SCREW トメネジ M5 L=6 1
12 134-24452 LEVER ASSY レバ-アツシー 1
13 134-24453 LEVER レバ- (1)
14 SM-6061402-TP SCREW M6 L=14 ロツカクアナメネジ M6 L=14 (1)
15 134-24502 BUSHING FRONT ブツシング・フロント 1
16 134-22704 LOOPER AVOID PIN ルーパ-アボイド・ピン 1
17 PS-0150042-KO SPRING PIN 1.5X 4 スプリング・ピン 1.5X 4 1
18 134-22803 BUSHING ブツシング 1
19 B2107-816-000 WASHER ザ・カネ 1
20 NM-6050001-SP NUT M5 ロツカクアナツト M5X0.8 1シュ 1
21 134-23009 BUSHING RIGHT ブツシング・ライト 1
22 SM-8050812-TP SCREW M5X8 トメネジ M5X0.8 L=8 1
23 134-23308 GUIDE LOOPER BAR ガイド・ルーパ-バ- 1
24 134-23309 BUSHING LEFT ブツシング・レフト 1
25 SM-6050812-TP SCREW M5X8 トメネジ M5X0.8 L=8 1
26 RO-1182401-00 O-RING Oリンク 1
27 134-25202 LPR_THREAD_GUIDE LPRスレッド・ガイド 1
28 WP-0320500-SC WASHER M3 ヒラサ・カネ コカ・タマ儿 M3 1
29 SM-4030455-SP SCREW ヒラサ・カネ M3 L=4 1
30 134-24601 LOOPER BAR ルーパ-バ- 1
31 TA-0600401-RO PLUG トメネジ D=6 L=4 1
32 134-23405 HOLDER ネルダ- 1
33 134-23801 WASHER ワツシャー 1
34 SM-6041000-SP SCREW M4 L=10 ヒラサネジ M4 L=10 1
35 134-23603 WASHER ワツシャー 2
36 134-23504 SLIDER HOLDER スライダ-ホルダ- 1
37 134-23801 WASHER ワツシャー 1
38 SM-6041000-SP SCREW M4 L=10 ヒラサネジ M4 L=10 1
39 134-23306 SLIDER スライダ- 1
40 134-23702 PIN ピン 1
41 SM-8040412-TP SET SCREW M4 L=4 トメネジ 1
42 134-24700 LOOPER HOLDER ルーパ-ホルダ- 1
43 134-23801 WASHER ワツシャー 1
44 SM-6041002-TP SCREW M4 L=10 ロツカクアナボルト M4X0.7 L=10 1
45 SM-8040412-TP SET SCREW M4 L=4 トメネジ 1
46 134-24809 LOOPER ルーパ- 1
47 134-23900 BUSHING REAR ブツシング・リア 1
NOTE (注記) #01...SELECTIVE PARTS 選択部品
- 22 -
jintex.in
Page 26 — 12. THREAD TENSION COMPONENTS
12. THREAD TENSION COMPONENTS
糸調子関係
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
- 23 -
jintex.in
Page 27
REF. NO NOTE PART NO. DESCRIPTION Qty.
1 133-40005 THREAD GUIDE PLATE 1
2 133-40104 THREAD GUIDE 1
3 SM-4040655-SP SCREW M4 L=6 1
4 SM-4040655-SP SCREW M4 L=6 2
5 133-41359 ASSY PULL OFF LEVER 1
6 133-41409 TENS RELEASE ADJ ECC 1
7 133-41508 SPRING 1
8 SM-4041655-SP SCREW M4 L=16 1
9 WP-0961046-SC WASHER 9.6X16X1 1
10 133-40252 THREAD TENSION ASSY 1
11 133-40500 TENSION DISC EYELET (2)
12 B3121-804-000 TENSION SPRING (2)
13 133-41706 KNOB (2)
14 133-40203 TENSION POST SUPPORT (1)
15 133-40302 SHOULDER SCREW (1)
16 B2008-372-000 THREAD TENSION SPRING (1)
17 133-40401 TENSION DISC SEPARATOR (1)
18 133-41607 TENSION DISC EYELET 2 (3)
19 133-40609 THREAD LEAD IN GUIDE (5)
20 133-40708 SPACER (5)
21 133-40807 TENSION POST (5)
22 229-28907 THREAD TENSION DISK (10)
23 131-37609 THREAD TENSION DISK PRESSER (5)
24 131-37906 SPRING BUSHING (5)
25 131-40504 TENSION SPRING (3)
26 133-40906 KNOB GREEN (3)
27 SM-4041055-SP SCREW M4 L=10 2
- 24 -
jintex.in
Page 29
REF. NO. NOTE PART NO. DESCRIPTION Qty.
1 133-43900 OIL_PROTECTION_SHIELD (1)
2 133-43652 ASSY_OIL_TUBE (1)
3 133-43603 OIL_TUBE (1)
4 133-44205 FELT_FOR_HEAD_LUB (1)
5 118-56101 NEEDLE_COOLER_PIN (1)
6 SM-8060812-TP SCREW M6 L=8 (1)
7 133-44056 ASSY_HEAD_SUCTION (1)
8 133-44155 ASSY_HEAD_SUCTION 2 (1)
9 400-19163 FELT_FOR_HEAD_SUCTION (1)
10 133-46408 OIL_TUBE_FOR_SUCTION (1)
11 236-30007 TUBE (0.43)
12 133-44601 SUCTION_PIPE (1)
13 133-44502 PIPE_CLAMP (1)
14 133-44700 BUSHING_FOR_SUCTION (1)
15 134-27257 ASSY_OIL_PIPE (1)
16 SM-4040655-SP SCREW M4 L=6 (1)
17 133-43504 OIL_SAUCER (1)
18 SM-4040655-SP SCREW M4 L=6 (2)
19 NM-6040001-SP NUT M4X0.7 (1)
20 236-29306 PIPE_STOPPER A (1)
21 BP-3000001-OR VINYL_PIPE 0.5
22 134-27307 CONNECTING_SCR_BRACKET (1)
23 133-45053 ASSY_OIL_SUPPLY_FOR_TOP (1)
24 134-26051 ASSY_PUMP_3-STAGE (1)
25 133-43009 WORM_WHEEL (1)
26 SM-8050412-TP SCREW M5 L=4 (2)
27 134-26002 OIL_PUMP_SHAFT_LARGE (1)
28 133-43108 OIL_PUMP_HOUSING (1)
29 132-28309 OIL_PUMP_PINION (4)
30 133-43405 OIL_PUMP_SPACER (2)
31 134-26101 OIL_PUMP_SHAFT_SMALL (1)
32 134-26200 OIL_PUMP_CASING_UPPER (1)
33 132-28200 OIL_PUMP_PINION (2)
34 133-43207 OIL_PUMP_CASING (1)
35 133-43306 OIL_PUMP_COVER (1)
36 SM-6043000-SP SCREW (2)
37 SM-6040600-SP SCREW M4 L=6 (2)
38 SQ-0000451-MZ CONNECTING_SCREW (1)
39 SQ-2060443-SD CONNECTING_SCREW (1)
40 SQ-2060451-MZ CONNECTING_SCREW (1)
41 400-04749 GASKET (3)
42 SQ-2050452-MZ CONNECTING_SCREW (1)
43 SM-4040655-SP SCREW M4 L=6 (2)
44 NM-6050001-SP NUT M5 (2)
45 WP-0550800-SP WASHER_5.5X10X0.8 (2)
46 SM-6051602-TP SCREW M5X0.8 L=16 (1)
47 134-26309 OIL_PAN (4)
48 SM-6081802-TP SCREW (1)
49 134-26408 O_RING (1)
50 131-70105 RUBBER_RING (1)
51 SM-0081001-SD SCREW (1)
52 133-46309 BREEZE_PLATE (1)
53 SM-4040655-SP SCREW M4 L=6 (2)
54 133-46101 OIL_SIGHT_GAUGE (1)
55 134-26606 DUSTPROOF_PLATE (1)
56 SM-4040655-SP SCREW M4 L=6 (3)
57 134-27604 TUBE_HOLDER (1)
58 133-43801 FITTING_FILTER (1)
59 131-42500 CARTRIDGE_FILTER (1)
60 133-44809 GASKET_O (1)
61 133-45202 FILTER_COVER (1)
62 SM-4041055-SP SCREW (4)
63 SQ-0000453-MZ CONNECTING_SCREW (1)
64 SQ-0000454-MZ CONNECTING_SCREW (1)
65 SQ-2060442-SD CONNECTING_SCREW (1)
66 SQ-0000452-MZ CONNECTING_SCREW (1)
67 SQ-2060443-SD CONNECTING_SCREW (1)
68 236-29306 PIPE_STOPPER A (7)
69 236-30007 TUBE (0.2)
70 BP-3000001-OR VINYL_PIPE (0.09)
71 BP-3000001-OR VINYL_PIPE (0.14)
72 BP-3000001-OR VINYL_PIPE (0.13)
73 134-26903 MESH_PLATE (1)
74 RC-1900002-KP RETAIN_IG-PIN (1)
75 134-27851 ASSY_BED_SUCTION (1)
76 134-28305 FELT_FOR_BED_SUCTION (1)
77 134-28305 OIL_TUBE_FOR_SUCTION (1)
78 137-65607 OIL_CONNEC. ARM (1)
79 134-26754 OIL_SUCTION_ASSY (1)
80 236-30007 TUBE (0.03)
81 134-28255 ASSY_LOOPER_SUCTION (1)
82 134-27752 ASSY_CYLINDER_SUCTION (1)
83 134-27703 FELT_FOR_C_SUCTION (1)
84 133-46408 OIL_TUBE_FOR_SUCTION (1)
85 SQ-2060442-SD CONNECTING_SCREW (2)
86 134-27455 ASSY_OIL_SUPPLY_FOR_LMS (1)
87 SQ-2050391-SD CONNECTING_SCREW (1)
88 134-28008 OIL_SUCTION_FOR_BUSHING (1)
89 236-30007 TUBE (0.02)
90 SM-4040655-SP SCREW M4 L=6 (1)
- 26 -
jintex.in
Page 30 — 14. THREAD STAND COMPONENTS
14. THREAD STAND COMPONENTS
糸立装置関係
1
18
29
6
4
18
29
7
8
19
25
23
12
11
22
10
21
13
9
4
20
24
15
14
16
17
5
3
2
5
3
2
26
26
27
28
- 27 -
jintex.in
Page 31
REF. NO. NOTE PART NO. D E S C R I P T I O N Qty.
1 131-68653 THREAD STAND ASM. 1
2 NM-6050001-SE NUT M5 (6)
3 WS-0510002-KN SPRING WASHER (6)
4 131-68356 THREAD STANDING ARM ASM., LONG (6)
5 131-68307 THREAD STANDING ARM, LONG (2)
6 229-31406 THREAD STANDING ROD RUBBER CAP (1)
7 229-30408 THREAD STANDING ROD, UPPER (1)
8 229-31307 THREAD STANDING ROD JOINT (1)
9 131-67903 THREAD GUIDE (1)
10 131-68000 THREAD GUIDE BASE, LOWER (1)
11 131-68109 THREAD GUIDE ARM (1)
12 131-68208 THREAD GUIDE ARM BASE (1)
13 229-30309 THREAD STANDING ROD, LOWER (6)
14 229-31109 SPOOL RETAINER (1)
15 229-31000 SPOOL PIN (6)
16 229-30903 SPOOL REST CUSHION (6)
17 229-30804 SPOOL REST (6)
18 SM-6061610-SC SCREW M6 L=16 (4)
19 SM-4051405-SE SCREW M5 L=14 (2)
20 NM-6050001-SE NUT M5 (2)
21 SM-4041001-SC SCREW M4X0.7 L=10 (2)
22 NM-6040002-SE NUT M4X0.7 (2)
23 SM-4041201-SC SCREW M4 L=12 (1)
24 SM-4042001-SC SCREW M4 X 20 (1)
25 NM-6040002-SE NUT M4X0.7 (2)
26 WP-1612616-SE WASHER 16X30X2.6 (2)
27 WS-1643202-KR SPRING WASHER (1)
28 NM-6160511-SE NUT M16X1.5 (1)
29 229-30705 THREAD GUIDE ARM JOINT (4)
- 28 -
jintex.in
Page 32 — 15. GAUGE PARTS COMPONENTS
15. GAUGE PARTS COMPONENTS
ゲージ関係
MF-7823-U10-B48
MF-7823-U10-B56
MF-7823-K10-B56
1
2
3
4
5
6
8
16
17 21
12
19
20
18
13
9
14
10
7
22
23
24
24
25. 26
27
28
29
30
33
34
36 43
39
37
41
42
44
40
45
35
32
38
31
MF-7823-U10-B64
46
48
47
48
5
49
51
54
55
57
64
63
60
65
61
58
62
59
53
56
52
59
- 29 -
jintex.in
Page 33
REF. NO NOTE PART NO. DESCRIPTION Qty.
1 133-50509 NEEDLE HEAD 48 ニードルヘッド 48-2 1
2 MUY-128A1000 NEEDLE UYX128GAS #10 ハリ UYX128GAS #10 2
3 SM-8030350-TP SCREW トメネジ M3 L=2.5 3
4 133-54709 THROAT PLATE スロートプレート LN48-3 1
5 134-31200 MAIN FEED DOG メインフィードドッグ LN48 1
6 134-33503 DIFF FEED DOG ディフィードドッグ LN48 1
7 133-76058 PRESSER FOOT ASSY MF-7723-U10-B48 1
8 SM-6040800-SP SCREW ヒラネジ (1)
9 133-76009 PRESSER FOOT BOTTOM プレッシャーフットボトム (1)
10 133-75100 P.F YIELDING SECTION P.F イエールドイング セクション (2)
11 133-76900 PRESSER FOOT GUIDE プレッシャーガイド (1)
12 133-77106 SPRING スプリング (1)
13 133-75209 PIVOT PIN ピボットピン (1)
14 133-75308 SPRING L スプリング L (1)
15 133-75407 SPRING R スプリング R (1)
16 133-75506 PRESSER FOOT HINGE プレッシャーフットヒンジ (1)
17 SM-8030412-TP SCREW (1)
18 133-75605 GUIDE PLATE L ガイドプレート L (1)
19 133-75704 GUIDE PLATE R ガイドプレート R (1)
20 SM-1850600-SP SCREW (4)
21 133-77007 SCREW (1)
22 133-50301 NEEDLE HEAD 56 ニードルヘッド 56 1
23 MUY-128A1000 NEEDLE UYX128GAS #10 ハリ UYX128GAS #10 3
24 SM-8030350-TP SCREW トメネジ M3 L=2.5 4
25 #01 133-54808 THROAT PLATE スロートプレート LN56 1
26 #02 133-52307 SCREW (1)
27 #01 134-31200 MAIN FEED DOG メインフィードドッグ LN48 1
28 #02 134-30707 DIFF FEED DOG ディフィードドッグ K56 1
29 #01 134-33503 DIFF FEED DOG ディフィードドッグ LN48 1
30 #02 134-32901 DIFF FEED DOG ディフィードドッグ K56 1
31 133-75050 PRESSER FOOT ASSY (1)
32 133-75001 PRESSER FOOT BOTTOM プレッシャーフットボトム A (1)
33 133-75506 PRESSER FOOT HINGE プレッシャーフットヒンジ (1)
34 SM-6040800-SP SCREW ヒラネジ (1)
35 133-75209 PIVOT PIN ピボットピン (1)
36 SM-8030412-TP SCREW (1)
37 133-77106 SPRING スプリング (1)
38 133-75100 P.F YIELDING SECTION P.F イエールドイング セクション (2)
39 133-75704 GUIDE PLATE R ガイドプレート R (1)
40 133-75605 GUIDE PLATE L ガイドプレート L (1)
41 SM-1850600-SP SCREW (4)
42 133-76900 PRESSER FOOT GUIDE プレッシャーフットガイド (1)
43 133-77007 SCREW (1)
44 133-75407 SPRING R スプリング R (1)
45 133-75308 SPRING L スプリング L (1)
46 133-50400 NEEDLE HEAD 64 ニードルヘッド 64 1
47 MUY-128A1000 NEEDLE UYX128GAS #10 ハリ UYX128GAS #10 3
48 SM-8030350-TP SCREW トメネジ M3 L=2.5 4
49 133-51200 THROAT PLATE スロートプレート LW64 1
50 134-30103 MAIN FEED DOG メインフィードドッグ LW56 1
51 134-32109 DIFF FEED DOG ディフィードドッグ LW56 1
52 133-75050 PRESSER FOOT ASSY MF-7723-U10-B56 1
53 133-75001 PRESSER FOOT BOTTOM プレッシャーフットボトム A (1)
54 133-75506 PRESSER FOOT HINGE プレッシャーフットヒンジ (1)
55 SM-6040800-SP SCREW ヒラネジ (1)
56 133-75209 PIVOT PIN ピボットピン (1)
57 SM-8030412-TP SCREW (1)
58 133-77106 SPRING スプリング (1)
59 133-75100 P.F YIELDING SECTION P.F イエールドイング セクション (2)
60 133-75704 GUIDE PLATE R ガイドプレート R (1)
61 133-75605 GUIDE PLATE L ガイドプレート L (1)
62 SM-1850600-SP SCREW (4)
63 133-76900 PRESSER FOOT GUIDE プレッシャーフットガイド (1)
64 133-77007 SCREW (1)
65 133-75407 SPRING R スプリング R (1)
66 133-75308 SPRING L スプリング L (1)
NOTE (注記) #01...FOR MF-7823-U10-B56 MF-7823-U10-B56用
#02...FOR MF-7823-K10-B56 MF-7823-K10-B56用
- 30 -
jintex.in
Page 34 — 16. GAUGE PARTS COMPONENTS (2) (FOR MF-7800-K10)
16. GAUGE PARTS COMPONENTS (2) (FOR MF-7800-K10)
ゲージ関係 (2) (MF-7800-K10用)
REF. NO. NOTE PART NO. DESCRIPTION Qty
1 134-29055 SILICONE OIL TANK ASSY シリコンオイルタンクアッシー 1
2 SL-4041081-SC SCREW M4 L=10 ナベコネジ セムス M4 L=10 2
3 134-29105 SILICONE OIL TANK CAP シリコンオイルタンクキャップ 1
4 134-29204 SILICONE OIL CUP シリコンオイルカップ 1
5 134-29303 FELT フェルト 1
6 118-56101 NEEDLE COOLER PIN ハリレイキフェルトメピン 1
7 TA-0290301-M0 PLUG トメセン D=2.9X3.2 L=3 1
8 SM-4040655-SP SCREW M4 L=6 ナベコネジ M4 L=6 1
9 BT-0600402-EA OIL TUBE チューブ 0.03
10 CQ-3030000-00 OIL WICK ユシ 0.1
- 31 -
jintex.in
Page 35 — 17. ACCESSORIES PARTS COMPONENTS
17. ACCESSORIES PARTS COMPONENTS
付属品関係
REF. NO.
NOTE
PART NO.
DESCRIPTION
QTY.
1
400-13913
ACCESSORY BAG ASSY
1
2
229-32800
ACCESSORIE BAG
(1)
3
229-33105
SCREW DRIVER, MIDDLE
(1)
4
123-47308
SCREW DRIVER (SMALL)
(1)
5
131-60304
S SHAPED HOOK
(2)
6
260-37903
CHAIN
1
7
122-88903
TWEÉZERS
1
8
229-33006
SCREW DRIVER, LARGE
1
9
MUY-128S1003
NEEDLES(PACKAGE_OF_3)
1
10
229-33303
VINYL COVER
1
11
131-60601
FUNNEL
1
12
133-08952
SYNCHRONIZER STUD ASSY
1
13
131-42500
CARTRIDGE FILTER
1
14
MML-018900CA
JUKI MACHINE OIL 18
1
15
B9101-490-000
DRIVER
1
16
131-55403
DUST PROOF RUBBER
4
17
134-29709
BELT COVER
1
18
133-49600
PIN FOR RUBBER CUSHION
4
19
SK-3412001-SE
WOOD SCREW D=4.1 L=20
3
20
WT-0430002-KN
WASHER M4
1
21
SM-4040501-SN
SCREW M4X0.7 L=5
1
22
NM-6080003-SC
NUT M8
4
23
SM-4040655-SP
SCREW M4 L=6
1
24
WP-0851216-SC
WASHER 8.5X18.0X1.2
4
25
WS-0820002-KR
SPRING WASHER, M8
4
26
229-33204
SCREW DRIVER, SMALL
1
27
HX-0015000-0C
CABLE CLIP
1
- 32 -
jintex.in
Page 39
jinttex.in
jintex.in
Page 40
JUKI
JUKI CORPORATION
Copyright © 2003 JUKI CORP.
本書の内容を無断で転載、複写することを
禁じます。
All rights reserved throughout the world.
JUKI株式会社
お買い求め、ご相談は
To order or for further
information,
please contact:
※このパーツリストは商品改良のため予告なく変更する事があります。
*The description covered in this parts list is subject to change for improvement of the commodity without notice.
※このパーツリストは、2003年12月現在の商品仕様で編集したものです。
*This parts list is edited in accordance with the product specifications as of December 2003.
Printed in Japan
jintex.in
