Hirose Hook Catalog Parts Book (PDF)

Text index — Hirose Hook Catalog

Page 2 — INDEX

Hirose Hook Catalog parts on page 2
Ref	Part number	Part name	Qty
	1~55	ITEM LIST & PHOTOS 分类与图片
	3	HORIZONTAL AXIS ROTARY HOOK (DB TYPE) 垂直回转式拨头 (DB 型) HIGH SPEED TYPE 高速缝拨头
	7	LARGE TYPE 大型拨头
	9	LOW SPEED TYPE 低速缝拨头
	12	HORIZONTAL AXIS ROTARY HOOK (DP TYPE) 垂直回转式拨头 (DP 型) HIGH SPEED ZIGZAG TYPE 高速人字型缝拨头
	14	VERTICAL AXIS ROTARY HOOK 水平回转式拨头 STANDARD TYPE with SHANK 短轴小型拨头
	16	STANDARD TYPE with SHAFT 长轴小型拨头
	19	STANDARD TYPE with BOSS (HUB) 轴套小型拨头
	20	LARGE TYPE with SHANK 短轴大型拨头
	21	LARGE TYPE with SHAFT 长轴大型拨头
	24	SHUTTLE 摆梭
	25	OTHERS 其他
	26	BOBBIN CASE/CAP 梭芯套/梭帽
	57~112	REFERENCE TABLE 拨头与机种对照表
	113~117	USER'S GUIDANCE 使用说明
	118	COMPONENT PARTS 各零件的名称
	119	HIROSE INNOVATIONS 广濑独创的产品 OIL-FREE HOOK 无需注油拨头
	120	HTH-SERIES HOOK SETS HTH 系列拨头
	121	HTM-SERIES HOOK SETS HTM 系列拨头
	122	SUPER HARD POINT HOOK 硬尖拨头

Page 3 — ITEM LIST & PHOTOS

Hirose Hook Catalog parts on page 3
Ref	Part number	Part name	Qty
	HAD-396	DURKOPP/ADLER
	HAD-396(H)	DURKOPP/ADLER
	HDU-211	DURKOPP/ADLER
	HDU-211(1)	DURKOPP/ADLER
	HDU-271	DURKOPP/ADLER
	HDU-271(QRP)	DURKOPP/ADLER
	HDU-272	DURKOPP/ADLER
	HNE-830	NECCHI
	HNE-835	NECCHI
	HPF-480	PFAFF
	HSH-7.24BJ	JU KI
	HSH-7.24BJZ	JU KI
	HSH-7.94A	JANOME
	HSH-7.94A	SINGER
	HSH-7.94A	TYPICAL BROTHER
	HSH-7.94A	CHUAN NENG
	HSH-7.94A	SIRUBA
	HSH-7.94A(TS)	MITSUBISHI
	HSH-7.94A(TS)	UNICORN
	HSH-7.94A1	HSH-7.94A1
	HSH-7.94AO	HSH-7.94AO
	HSH-7.94AOTR	HSH-7.94AOTR
	HSH-7.94ATR	CHUAN NENG
	HSH-7.94ATR	SIRUBA
	HSH-7.94B	JANOME
	HSH-7.94B	JU KI
	HSH-7.94B	MITSUBISHI
	HSH-7.94B	SINGER
	HSH-7.94B	TOYOTA
	HSH-7.94B	GEMSY
	HSH-7.94B	HIGHLEAD
	HSH-7.94B	JACK
	HSH-7.94B	PROTEX
	HSH-7.94B	SHANGGONG
	HSH-7.94B	TYPICAL
	HSH-7.94B	WANPING
	HSH-7.94B	ZOJE
	HSH-7.94B	SUNSTAR
	HSH-7.94B	UNICORN
	HSH-7.94B	CHUAN NENG
	HSH-7.94B	KINGTEX
	HSH-7.94B	SIRUBA
	HSH-7.94B(1)	HSH-7.94B(1)
	HSH-7.94B(1)TR	HSH-7.94B(1)TR

Page 4 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Hirose Hook Catalog parts on page 4
Ref	Part number	Part name	Qty
1.9	HSH-7.94B(2SPH)	DDL-5530H, DDL-5550H	10.0
1.82	HSH-7.94B(391)	281,391U	6.8
1.82	HSH-7.94B(491)	491, 491UX330, 591D	6.8
1.9	HSH-7.94B(660)		6.8
1.85	HSH-7.94B(7)		8.0
1.65	HSH-7.94B(AC)		6.8
1.9	HSH-7.94B(HP)	super hard point hook	6.8
1.6	HSH-7.94B(K)	for heavy materials, sports shoes & bag	6.8
1.65	HSH-7.94B(KSN)	591C200,591D308AD/AF	10.0
1.9	HSH-7.94B(NK)	with 3 hook setting screws	6.8
1.6	HSH-7.94B(Q)	D1412-41, D1512-41	6.8
1.6	HSH-7.94B(RT)	DB2-B736-1,DB2-B773,DB2-B777A	6.8
1.6	TYPICAL BROTHER	DB2-C101-3	6.8
1.6	UNICORN	LS2-H530	6.8
1.9	HSH-7.94B(SPH)	DDL-5530H	10.0
1.9	HSH-7.94B(SPHA)	for light materials, handkerchieves	6.8
1.9	HSH-7.94B(TS)	with teflon coated base	6.8
2.3	HSH-7.94B1	for extra heavy materials	6.8
1.9	HSH-7.94BKTR	for heavy materials, sports shoes & bag	10.0
1.9	HSH-7.94BKTR(2)	DLN-5410NH-7	10.0
1.65	HSH-7.94BKTR(H)	for heavy materials, sports shoes & bag	6.8
1.9	HSH-7.94BN	281,400W/402W/451K	6.8
1.9	HSH-7.94BO	full automatic open type lubricating system with 3 hook setting screws	6.8
1.6	HSH-7.94BOH	JK8500H	6.8
1.6	PROTEX	TY1130H,TY2000-5,TY2000-6	6.8
1.6	SHANGGONG	GC15-3,GC15-4	6.8
1.6	ZOJE	GC80-5,GC5580-5,ZJ8500-5	6.8
1.6	SUNSTAR	KM-123B	6.8
1.9	HSH-7.94BOH(1)	DB2-B736-5,SL-1010-5	6.8
1.9	TYPICAL	GC6100HD	6.8
1.9	TYPICAL BROTHER	DB2-C101-5	6.8
1.6	HSH-7.94BOHN	DLN-415H	10.0
1.6	HSH-7.94BOHN(1)	DLN-415L	10.0
1.6	SUNSTAR	KM-350B	10.0
1.9	HSH-7.94BOHNTR	DDL-5580H,DLN-415H	10.0
1.9	MITSUBISHI	LS2-1180-H	10.0
1.9	TOYOTA	AD340B,AD340B-22	10.0
1.9	TYPICAL	GC6-8-D2	10.0
1.9	SUNSTAR	KM-235B	10.0
1.9	UNICORN	LS2-H5100(H)/H5150H	10.0
1.9	HSH-7.94BOHNTR(B)	DB2-B737-5,SL-737A-5,SL-2010-5 7200A-405	10.0
1.9	TYPICAL	GC6160H	10.0
1.9	TYPICAL BROTHER	DB2-C201-5	10.0
1.45	HSH-7.94BRN	TY-B721-3	8.0
1.9	HSH-7.94BRN(H)	GC0618,GC0618-1	10.0
1.9	PROTEX	TY-B721-5	10.0

Page 5 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Hirose Hook Catalog parts on page 5
Ref	Part number	Part name	Qty
	HSH-7.94BSN	JUKI
	HSH-7.94BTR	SUNSTAR
	HSH-7.94BTR	JUKI
	HSH-7.94BTR	MITSUBISHI
	HSH-7.94BTR	SINGER
	HSH-7.94BTR	TOYOTA
	HSH-7.94BTR	GEMY
	HSH-7.94BTR	JACK
	HSH-7.94BTR	PROTEX
	HSH-7.94BTR	SHANGGONG
	HSH-7.94BTR	ZOJE
	HSH-7.94BTR	SUNSTAR
	HSH-7.94BTR	UNICORN
	HSH-7.94BTR	CHUAN NENG
	HSH-7.94BTR	KINGTEX
	HSH-7.94BTR(1RPWL)	BROTHER
	HSH-7.94BTR(2QSP)	JUKI
	HSH-7.94BTR(2QSPFB)	JUKI
	HSH-7.94BTR(2SPFB)	JUKI
	HSH-7.94BTR(2SPRPWS)	JUKI
	HSH-7.94BTR(3)	HIGHLEAD
	HSH-7.94BTR(3)	TYPICAL
	HSH-7.94BTR(491)	SINGER
	HSH-7.94BTR(591B)	SINGER
	HSH-7.94BTR(591D)	SINGER
	HSH-7.94BTR(591DT)	SINGER
	HSH-7.94BTR(737)	BROTHER
	HSH-7.94BTR(737SPQ)	TYPICAL BROTHER
	HSH-7.94BTR(CR)	BROTHER
	HSH-7.94BTR(HP)	TYPICAL BROTHER
	HSH-7.94BTR(N)	SUNSTAR
	HSH-7.94BTR(PFQL)	PFAFF
	HSH-7.94BTR(Q)	JUKI
	HSH-7.94BTR(QSP)	JUKI
	HSH-7.94BTR(R)	BROTHER
	HSH-7.94BTR(RPW)	BROTHER
	HSH-7.94BTR(SP)	BROTHER
	HSH-7.94BTR(SPH)	JUKI
	HSH-7.94BTR(T)	JUKI
	HSH-7.94BTR(TIN)	JUKI

Page 6 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Hirose Hook Catalog parts on page 6
Ref	Part number	Part name	Qty
	HSH-7.94BTR(TS)	with teflon coated base
	HSH-7.94C	281,400W/402W/451K
	HSH-7.94C(L)	281,400W/402W/451K
	HSH-7.94C(TS)	281,400W/402W/451K
	HSH-7.94CO	full automatic open type lubricating system with 3 hook setting screw
	HSH-7.94CO(L)	with teflon coated base
	HSH-7.94CO(TS)	with teflon coated base
	HSH-7.94COTR	for under trimming machine
	HSH-7.94CTR	DDL-5550U
	HSH-7.94CTR(TS)	with teflon coated base
	HSH-7.94D	281,400W/402W/451K
	HSH-7.94DRN(1)	DB2-B771,SN-771A-3
	HSH-7.94DRNTR	DB2-B790-3-0, B790-303, B791-3-0
	HSH-7.94DTR(1Q)	DB2-B772,SN-772A-3
	HSH-7.94DTR(Q)	DB2-B791-1
	HTE-833
	HTH-614BTR(1.7QE)	63900AML HTH-series hook. for thin needle
	HTH-614BTR(2E)	DLN-6390-7 HTH-series hook
	HTH-614BTR(QE)	63900AML HTH-series hook
	HTH-ATR(E)	HTH-series hook
	HTH-BTR(2SPHPN G20E)	AVP-875A HTH-series hook. super hard point hook
	HTH-BTR(E)	HTH-series hook
	HTH-BTR(HPNG)	BAS-7610
	HUN-614B
	HUN-614B(L)	61200/31300,61400/61900,63400/63900 for synthetic fabrics
	HUN-614C
	HUN-614C(L)	61200/31300,61400/61900,63400/63900 for synthetic fabrics
	HUN-614C(TS)	61200/31300,61400/61900,63400/63900 with teflon coated base

Page 7 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) 垂直回转式梭头 (DB 型)

Hirose Hook Catalog parts on page 7
Ref	Part number	Part name
	DBM-A(Z14)	DBL-C
DBM-A(Z14)	SZ-21-5-5WN,SZ-21-1BN,SZ-21-3BNL SZ-21-5-4NL,SZ-21-5N,SZ-21-5NL	STAGER
	H-301,H-305	TONY
	DBM-A(Z17)	DBM-A(Z17)
HDU-M265	265-108	DURKOPP/ADLER
HPF-3518	3518	PFAFF
HPF-418	417~419,417~900~419-900	PFAFF
HSM-A	NCL-2BL	SEIKO
	GC20601	FLYINGMAN
	7-18A	GEMSY
	GC0318-1,GC0388,GC188-B	HIGHLEAD
	JK6318	JACK
	CS-350L,CS-3811,CS-6100	GOLDEN WHEEL
	MS-370L	MILLION SPECIAL
	DY-3300,TC-1530,TC-2530	NITAKA
	WR-3750,WR-5705	SHIANG WANG
	YLM-340,YLM-350-22	YULUN
HSM-A(3)	KM-640BL	SUNSTAR
	DB2-H312/H510XH/H515XH	UNICORN
	L819-X2,YF616-X2,YF619-X2	SIRUBA
HSM-A(5)	STH-series	SEIKO
HSM-A(6)	DNU-241HS	JUki
	CK-8BL,CK-8BL-1,STH-8BL	CHIKON
	TK-8BL	TAKING
	HSM-A(M2QTS)	BARUDAN
	HSM-A(MQ2L)	BARUDAN
HSM-A1	DB2-B797	BROTHER
	DU-141NH,DU-580	JUki
	H-2B,H-2BL	SEIKO
	GC6-5,GC6-6,GC6-7	WANPING
HSM-A1HMTR	DY-359-22,LY3-6840-B0T PLK-E2010R,PLK-E2516R	MITSUBISHI
	SPS/C-5050	SUNSTAR
HSM-A1HTR	GC0388-D,GC128-B-D3	HIGHLEAD
	GC6-9-D2	TYPICAL
	GN2301,GN2603	WANPING
	KM-640BL-7	SUNSTAR
	LS2-H540/H5400/H5100XH/H5150XH/ H5110XH	UNICORN
	L819-X2,YF616-X2,YF619-X2-U	SIRUBA
HSM-A1HTR(T)	LY3-6850-B1T	MITSUBISHI
	YC619-X2	SIRUBA
HSM-A1SH	DDL-201S,DSU-144N	JUki
HSM-A1TR(280)	DNU-1541,DNU-241H,DNU-261H DSC-246,246V	JUki
	KM-590BL	SUNSTAR

Page 8 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) LARGE TYPE

Hirose Hook Catalog parts on page 8
Ref	Part number	Part name	Qty
	HSM-AM(3)	for skip-free stitching
	HSM-AR(1.7)	for skip-free stitching
	HSM-AR(2.1)	for skip-free stitching
	HSM-AR(PNG)	for skip-free stitching
	HSM-ARTR(1.7)	for skip-free stitching
	HSM-ARTR(2.1)	for skip-free stitching
	HSM-ARTR(ABHP)	SUPER HARD POINT HOOK,FOR SKIP-FREE STITCHING
	HSM-ATR(1Q)	with teflon coated base
	HSM-ATR(1QTS)
	HSM-ATR(MQ1L)
	HSM-ATR(PFNGOPS)L
	HSM-B
	HSM-B(1SU)
	HSM-B(IE)
	HSM-B(Q)TR
	HSM-B(SU)
	HSM-B(Z17)
	HSM-B1
	HSM-B1H
	HSM-B1H(1)
	HSM-B1HTR
	HSM-B1HTR(1Q)
	HSM-B1HTR(2)
	HSM-B1HTR(BB)	for pocket setter machine
	HSM-BRTR(1.7)	for skip-free stitching
	HSM-BRTR(2.1)	for skip-free stitching
	HSM-BRTR(HP370)	super hard point hook
	HSM-Z17	with short hook gib
	HST-A
	HST-A(C)
	HST-A(CNG)
	HST-A(HPQC)	super hard point hook
	HST-A(LP)	with long hook point
	HST-A(ME)	for quilting machine
	HST-B1(HPA)
	HTM-A	HTM-series hook
	HTM-A1HTR	HTM-series hook
	HTM-BTR(HP761)

Page 9 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Hirose Hook Catalog parts on page 9
Ref	Part number	Part name	Qty
	CU-865-12	DA1-A
	95-40/96-40	DA1-A
	195K,196K	DA1-A(7.94)
	for thick thread sewing	DA1-A(7.94ST)
	for extra heavy materials	DA1-A1
	for heavy materials,bag	DA1-AH
	380,380L	DA1-ATR
	PR-600	DA1-ATR(1QB)
	96,206,207	DA1-B
	TA-J761,TA-J763,TA-J766	DA1-B
	DDL-115	DA1-B
	LX2-371-MO	DA1-B
	800,801,810,813	DA1-B
	95-40/96-40	DA1-B
	CS-3600,CS-8000-20,CS-8000-30	DA1-B
	102,109	DA1-B(109)
	195K,196K	DA1-B(7.94)
	for extra heavy materials, sports shoes & bag	DA1-B(K)
	127, 157	DA1-BOH(AL)
	KM-380	DA1-BTR
	95-40/96-40	DA1-C
	127,157	DA1-C(AL)
	TA2-B623	DA1-CTR
	103K,95-10/96-10	DA2-A (TA1-A)
	203,204,205	DA2-B (TA1-B)
	103K,95-10/96-10	DA2-B (TA1-B)
	103K,95-10/96-10	DA2-C (TA1-C)
	20U13/23	DB1-BZ(20)
	GG20U	DB1-BZ(20)
	CS-2180	DB1-BZ(20)
	MS-20U143	DB1-BZ(20)
	20U31/33/34	DB1-BZ(20L)
	20U13/23	DB1-Z(20)
	JL-20U	DB1-Z(20)
	20U43,20UX143	DB1-Z(20L)
	199,289,489	DB1-Z16
	LZ-271	DB1-Z16
	533,720,840	DB1-Z16
	G15-2	DB1-Z16
	GG1-1,GG1-2	DB1-Z16
	KLZ-371	DB1-Z16
	LZ2-H272	DB1-Z16
	with long hook point	DB1-Z16(LP)
	with teflon coated base	DB1-Z16(TS)
	SE-12,SZ-21-1N,SZ-21-4N,SZ-72N	DB1-Z16(TU)
	TZ1-B652	DB1-Z16B
	TZ1-B652	DB1-Z16B

Page 10 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) LOW SPEED TYPE

Hirose Hook Catalog parts on page 10
Ref	Part number	Part name	Qty
	DB1-Z16B	MILLION SPECIAL
	DB1-Z16B	YULUN
	DB1-Z39	JUki
	DB1-Z710	JUki
	HDU-265	DURKOPP/ADLER
	HDU-265Y	YAMATO
	HM2-F10(EL)	ALFA
	HM2-FATR(1)	BROTHER
	HM2-FBTR(SS)	SINGER
	HPF-134	PFAFF
	HPF-134	ZSK
	HPF-230(W)	PFAFF
	HPF-234	PFAFF
	HPF-238	PFAFF
	HPF-335	PFAFF
	HPF-335	WANPING
	HPF-335(5)	DURKOPP/ADLER
	HPF-335(5)	SEIKO
	HPF-335(5)	WANPING
	HPF-438	PFAFF
	HPF-438(CR)	PFAFF
	HPF-563TR(RP)	PFAFF
	HSH-7.94A(M1Q)	for embroidery machine
	HSH-7.94A(M1QTS)	for embroidery machine with teflon coated base
	HSH-7.94A(M3Q)	HAPPY
	HSH-7.94A(MTQ)	for embroidery machine
	HSH-7.94ATR(M1Q)	BARUDAN
	HSH-7.94ATR(M1QH)	BARUDAN
	HSH-7.94ATR(M1QTS)	BARUDAN
	HSH-7.94ATR(M1QTSL)	for embroidery machine,with teflon coated base,with lubricating channel
	HSH-7.94ATR(M3Q)	HAPPY
	HSH-7.94ATR(MQ2)	BARUDAN
	HSH-7.94ATR(MQRP)	RP-series oil free hook for embroidery machine
	HSH-7.94ATR(MQRPHW)	for embroidery machine
	HSH-7.94ATR(MQSU)	SWF
	HSH-7.94ATR(MQSU)	SWF
	HSH-7.94ATR(MQSUNL)	SWF
	HSH-7.94ATR(MTQ)	for embroidery machine
	HSH-7.94ATR(MTQEL)	TAJIMA
	HSH-7.94ATR(MTQETA)	TAJIMA
	HSH-7.94ATR(MTQRP)	RP-series oil free hook for embroidery machine

Page 11 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Hirose Hook Catalog parts on page 11
Ref	Part number	Part name	Qty
	HSH-7.94ATR(MTQTS)	for embroidery machine with teflon coated base
	HSH-7.94B(188UL)	188U
	HSM-ATR(MQRPN)	for embroidery machine
	HSM-ATR(MTQ)	for embroidery machine
	HSM-ATR(MTQTS)	for embroidery machine with teflon coated base
	HTH-ATR(MQE)	HTH-series hook, for embroidery machine
	HTH-ATR(MQESU)	SWF/C-WE1206-75,SWF/H-WD920-55 SWF/B-UK1204-45
	HTH-ATR(MQESUL)	SWF/C-WE1206-75,SWF/H-WD920-55 SWF/B-UK1204-45
	HTH-ATR(MQESUNL)	SWF/B-UK1204-45,SWF/C-WE1204-55/75 SWF/H-WD920-55
	TA1-Z16	306M,319,320

Page 12 — HORIZONTAL AXIS ROTARY HOOK (DP TYPE) 垂直回转式梭头 (DP 型) HIGH SPEED ZIGZAG TYPE 高速人字型缝纫头

Hirose Hook Catalog parts on page 12
Ref	Part number	Part name	Qty
	91,253,255	DP2
	DPS-2,DPS-3,DPS-4	DP2
	107G,107W1/3/5/17	DP2
	DP-2,DP-3	DP2
	DPK-2	DP2
	DL1-B832,B813,LZ1-B851	DP2(B)
	for heavy materials	DP2(H)
	DP-2,DP-3	DP2(HS)
	457A,457G	DP2-457(HP)
	457A,457G	DP2-457(LHP)
	457A	DP2-457U(T)
	JK457	DP2-457U(T)
	ZJ457A135,ZJ457A143,ZJ457A125/105	DP2-457U(T)
	475A-505-PBG-NHL,475A-625-NCB-LG	DP2-457U(T)
	457U, 457G	DP2-457UTR
	457G	DP2-57(2)
	for lingerie sewing	DP2-57(2)IN
	super hard point hook with teflon coated base	DP2-57(2HPTS)
	457G	DP2-57(2LP)
	475A-125L,475A-140L,YLM-457A	DP2-57(2LP)
	SZ-310-11N,SZ-310-1N,SZ-310-3N	DP2-57(2LPA)
	457G	DP2-57(2LPRP)
	LG2125 LW	DP2-57(2LPY)
	RP-series oil free hook	DP2-57(2RP)
	LZ-1280	DP2-57(3LP)
	LZ-2280	DP2-57(3LP2)
	LZ-2280N, 2281N	DP2-57(3LP2R)
	2284,2284-7	DP2-57(3LP2R)
	475A-143NL,475A-643-NCB-LG	DP2-57(3LP2R)
	super hard point hook	DP2-57(3LP2RHP)
	LZ-2282N-7, 2284N-7,LZ-2290A-SR-7-CB LZ-2290A-SS,LZ-2290A-SU	DP2-57(3LP2V)
	LZ-2282N-7, 2284N-7 super hard point hook	DP2-57(3LP2VHP)
	LZ-2290A-DS-7-CB,LZ-2290A-DU-7-CB RP-series oil free hook	DP2-57(3LP2VRPW)
	271K	DP2-71
	HE-8000-2,HE-8000-3,HE-8000-5	DP2-800FR
	BH/3000	DP2-800FR
	LH4-B815	DP2-815
	LH4-B815	DP2-815(FR)
	BAS-511,LH4-B816	DP2-816
	BAS-511,LH4-B816	DP2-816(FR)
	LH4-B817	DP2-817
	HM-8180	DP2-818(FR)
	ZE-855A,ZE-8570	DP2-855
	KM-2070	DP2-855

Page 13 — HORIZONTAL AXIS ROTARY HOOK (DP TYPE) 垂直回转式梭头 (DP 型) HIGH SPEED ZIGZAG TYPE 高速人字型缝纫梭头

Hirose Hook Catalog parts on page 13
Ref	Part number	Part name	Qty
	DP2-856TR	BROTHER
	DP2-856TR	SUNSTAR
	DP2-L(N)	SINGER
	DP2-LB	BROTHER
	DP2-NJ	JU KI
	DP2-NJ	SHANGGONG
	DP2-NJ(790)	JU KI
	DP2-NJ(791K)	JU KI
	DP2-NJ771	JU KI
	DP2-NJ771	DALIAN
	DP2-NJ771	JACK
	DP2-NJ771	SHANGGONG
	DP2-NJ771	K-CHANCE
	DP2-NJ771	PANDA
	DP2-NJ771	TAKING
	HDU-556	DURKOPP/ADLER
	HPF-3114	PFAFF
	HPF-3116	PFAFF
	HSH-102	SINGER
	HSH-51-1	SINGER
	HSH-8-20	DURKOPP/ADLER
	HSH-8-20	SINGER
	HSH-8-20(K)	SINGER

Page 14 — VERTICAL AXIS ROTARY HOOK 水平回转式拨头 STANDARD TYPE with SHANK 短轴小型拨头

Hirose Hook Catalog parts on page 14
Ref	Part number	Part name	Qty
	HAD-68	DURKOPP/ADLER
	HDU-249	DURKOPP/ADLER
	HPF-151	PFAFF
	HPF-442	PFAFF
	HPF-442TR	PFAFF
	HPF-442TR(L)	PFAFF
	HPF-490	PFAFF
	HPF-490	SEIKO
	HPF-490(5)TR	SEIKO
	HPF-490(5)TR	UNICORN
	HPF-490(A)	PFAFF
	HPF-490(A)	SEIKO
	HPF-490(A)	HIGHLEAD
	HPF-490(A)	WANPING
	HPF-490(A)	SUNSTAR
	HPF-490(A)	GOLDEN WHEEL
	HPF-490(A)	MILLION SPECIAL
	HPF-490(A)	NITAKA
	HPF-490(A)	TAKING
	HPF-490(A)	YULUN
	HPF-490A(5)TR	SUNSTAR
	HPF-490A(5)TR	GOLDEN WHEEL
	HPF-490A(5)TR	MILLION SPECIAL
	HPF-490A(5)TR	SHIANG WANG
	HPF-490A(N)	SIRUBA
	HPF-490AH(N)	SIRUBA
	HPF-490TR	SIRUBA
	HPF-490TR	PFAFF
	HSH-10-100	SINGER
	HSH-10-100(A)	SINGER
	HSH-10-100(A)	SINGER
	HSH-10-100M	MITSUBISHI
	HSH-18-4	SINGER
	HSH-18-4A	SINGER
	HSH-18-4C	SINGER
	HSH-19	SINGER
	HSH-2-12	SINGER
	HSH-22-21	SINGER
	HSH-31	SINGER
	HSH-31(12)	SEIKO
	HSH-31(12)	SINGER
	HSH-31(12)	WANPING
	HSH-31(12)	SUNSTAR
	HSH-31(12)	FENG YING
	HSH-31(12)	GOLDEN WHEEL
	HSH-31(12)	KING'S

Page 15 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHANK

Hirose Hook Catalog parts on page 15
Ref	Part number	Part name	Qty
	HSH-31(12)	MILLION SPECIAL
	HSH-31(12)	NITAKA
	HSH-31(12)	TAKING
	HSH-31(12)	YULUN
	HSH-31(6)	JU KI
	HSH-31(6)	HIGHLEAD
	HSH-31(6)	GOLDEN WHEEL
	HSH-31(6)	NITAKA
	HSH-31(6)	SHIANG WANG
	HSH-31(6)	SIRUBA
	HSH-31(B)	SEIKO
	HSH-31(B)	SINGER
	HSH-31(B)	WANPING
	HSH-31(B12)	SEIKO
	HSH-31(B12)	UNICORN
	HSH-36-1	SINGER
	HSH-36-2	SINGER
	HSH-5-16	SINGER
	HSH-68-1	SINGER

Page 16 — VERTICAL AXIS ROTARY HOOK, STANDARD TYPE with SHAFT

Hirose Hook Catalog parts on page 16
Ref	Part number	Part name	Qty
	H12-15L	JUKI
	H12-15L(TR2)	JUKI
	H12-15L(TR2AE)	JUKI
	H12-15L(TR2FB)	JUKI
	H12-15LC	JUKI
	H12-15LCTR2	JUKI
	H12L(1)	JUKI
	HG12-15L	BROTHER
	HG12-15L	JACK
	HG12-15L	PROTEX
	HG12-15L	TYPICAL
	HG12-15L	ZOJE
	HG12-15L	SIRUBA
	HG12-15L(H)	BROTHER
	HG12-15L(H)	PROTEX
	HG12-15L(H)	TYPICAL
	HG12-15L(H)	ZOJE
	HG12-15L(TR1)	BROTHER
	HG12-15L(TR1)	GEMSY
	HG12-15L(TR1)	WANPING
	HG12-15L(TR1)	ZOJE
	HG12-15L(TR1)	MILLION SPECIAL
	HG12-15L(TR1)	NITAKA
	HG12-15L(TR1)	SICAMA
	HG12-15L(TR1)	SIRUBA
	HG12-15LC	BROTHER
	HG12-15LC	GEMSY
	HG12-15LC	JACK
	HG12-15LC	TYPICAL
	HG12-15LC	WANPING
	HG12-15LC	ZOJE
	HG12-15LC	SIRUBA
	HG12-15LCTR1	BROTHER
	HG12-15LCTR1	JACK
	HG12-15LCTR1	PROTEX
	HG12-15LCTR1	TYPICAL
	HG12-15LCTR1	WANPING
	HG12-15LCTR1	ZOJE
	HG12-15LCTR1	SICAMA
	HG12-15LCTR1	SIRUBA
	HG12L(1)	BROTHER
	HG12L(1)	SIRUBA
	HG12L(1)TR1	BROTHER
	HG12L(1)TR1	TYPICAL
	HG12L(1)TR1	SICAMA
	HG12L(1)TR1	SIRUBA

Page 17 — VERTICAL AXIS ROTARY HOOK - STANDARD TYPE with SHAFT

Hirose Hook Catalog parts on page 17
Ref	Part number	Part name	Qty
	T-8420A-003,T-8420A-00F,T-8420A-033 T-8421A-T03,TN-842A-003	BROTHER
	KM-750	SUNSTAR
	T-8420A-005,T-8421A-T05,TN-842A-005	BROTHER
	T-8422A-403,TN-842B-403	BROTHER
	KM-750-7	SUNSTAR
	T-8420A-005,T-8450A-005,TN-845A-003 TN-845A-005	BROTHER
	KM-790	SUNSTAR
	T-8452A-403,T-8452A-433,TN-845B-401 TN-845B-403	BROTHER
	KM-790-7	SUNSTAR
	T-8421A-T03	BROTHER
	T-8422A-403,TN-842B-40F	BROTHER
	111W150~151	SINGER
	111W100~103,111W153~154	SINGER
	STW-6,STW-7,STW-8,STW-8BV STW-8V	SEIKO
	111W155/156,211G155/156 211U341/365	SINGER
	LH-525N,LH-529	JU KI
	LH-1152	JU KI
	LH-1152-4	JU KI
	APW-192N~196N,APW-231N~239N LH-570, 571	JU KI
	DU-100, DU-105, DU120	MITSUBISHI
	112W115~139	SINGER
	LH-1152	JU KI
	LH-1152-4	JU KI
	112W110,112W115~139 with short hook gib	SINGER
	LT2-B831	BROTHER
	LTW-26,LTW-27	SEIKO
	KM-740	SUNSTAR
	LT2-B842	SICAMA
	LT2-B831-5	BROTHER
	CS-3100-3,CS-872-3	GOLDEN WHEEL
	LT2-B832-3-0, 401, 403	BROTHER
	LT2-B832-3-0(A), 400	BROTHER
	JK5842-5,JK5842D-3	JACK
	LT2-B835	BROTHER
	LTW-27BK	SEIKO
	CS-3150,CS-3150-5,CS-875-3	GOLDEN WHEEL
	TC2-B845	NITAKA
	LT2-B835-3-0, -5-0, -400	BROTHER
	LT2-B835-3-0(A), -5-0(A)	BROTHER
	LT2-B832-5-0, -405	BROTHER
	LT2-2220-MOB	MITSUBISHI
	211A,212A141BA,412U	SINGER
	2000-1M	GEMSY

Page 18 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHAFT

Hirose Hook Catalog parts on page 18
Ref	Part number	Part name	Qty
	HSH-12-15M	HIGHLEAD
	HSH-12-15M	TYPICAL
	HSH-12-15M	UNICORN
	HSH-12-15M	GOLDEN WHEEL
	HSH-12-15M	MILLION SPECIAL
	HSH-12-15M	TAKING
	HSH-12-15M(3)	MITSUBISHI
	HSH-12-15M(3)	TYPICAL
	HSH-12-15M(3UC)	UNICORN
	HSH-12-15MTR	MITSUBISHI
	HSH-12-15MTR(3)	MITSUBISHI
	HSH-12-15MTR(3)	TYPICAL
	HSH-12-15MTR(3)	UNICORN
	HSH-12-40	SINGER
	HSH-12-62C(L)	JU KI
	HSH-12-62C(R)	JU KI
	HSH-12-62CTR(L)	JU KI
	HSH-12-62CTR(R)	JU KI
	HSH-12-68	SINGER
	HSH-12C	MITSUBISHI
	HSH-12C	GEMY
	HSH-12C	HIGHLEAD
	HSH-12C	TYPICAL
	HSH-12C	UNICORN
	HSH-12C	GOLDEN WHEEL
	HSH-12C	MILLION SPECIAL
	HSH-12C	NITAKA
	HSH-12L(1)	BROTHER
	HSH-12L(1)TR	BROTHER
	HSH-12L(1)TR1	BROTHER

Page 19 — VERTICAL AXIS ROTARY HOOK 水平回转式梭头 STANDARD TYPE with BOSS (HUB) 轴套小型梭头

Hirose Hook Catalog parts on page 19
Ref	Part number	Part name	Qty
	HSH-21-40	SINGER
	HSH-21-40(2)	JUKI
	HSH-21-40(AJ)	JUKI
	HSH-21-40(HP)	SINGER
	HSH-21-40(J)	JUKI
	HSH-21-40(S)C	SHANGGONG
	HSH-21-40A(2)	SINGER
	HSH-21-40TR	JUKI
	HUN-622	UNION SPECIAL

Page 20 — VERTICAL AXIS ROTARY HOOK 水平回转式拨头 LARGE TYPE with SHANK 短轴大型拨头

Hirose Hook Catalog parts on page 20
Ref	Part number	Part name	Qty
	HAD-160(1341A)	JU KI
	HAD-160(6)	JU KI
	HAD-160TR(6)	JU KI
	HAD-161(6)	JU KI
	HAD-166TR	JU KI
	HAD-167	DURKOPP/ADLER
	HAD-167TR	DURKOPP/ADLER
	HAD-267TR	DURKOPP/ADLER
	HPF-1242	PFAFF
	HPF-1242(A)	PFAFF
	HPF-1242(A)	WANPING
	HPF-1242(A)	MILLION SPECIAL
	HPF-1242(A)	TAKING
	HPF-1242(A)	YULUN
	HPF-1242(A)TR	PFAFF
	HPF-1242TR	PFAFF
	HPF-545	PFAFF
	HPF-545	KING'S
	HPF-545	TAKING
	HSH-12-15MM(S)	SINGER
	HSH-12-15MM(S)C	SINGER
	HSH-12MS	SINGER
	HSH-12MS(5)	SINGER
	HSH-31MMB(5)	SEIKO
	HSH-31MMB(5)	SUNSTAR
	HYM-1341ATR(6)	JU KI
	HYM-1341AY	WANPING
	HYM-1341AY(6)	JU KI
	HYM-1341BTR(6)	JU KI
	HYM-1341BY	JU KI
	HYM-1341BY(6)	JU KI

Page 21 — VERTICAL AXIS ROTARY HOOK 水平回转式梭头 LARGE TYPE with SHAFT 长轴大型梭头

Hirose Hook Catalog parts on page 21
Ref	Part number	Part name	Qty
	LH-2178-7	H12M-78TR
	LH-3178,LH-3188	H12MC(2)
	LH-3178-7,LH-3188-7	H12MC(2)TR
	LH-3178	H12MM(2)
	LH-3178-7	H12MM(2)TR
	LT2-B872	HG12M(BR)
	872	GEMSY
	JK5872-3	JACK
	TY-B872-5	PROTEX
	GC6872H,GC6872M	TYPICAL
	872	ZOJE
	T828-72-HL,T828-72-ML	SIRUBA
	BAS-612,613,LT2-B875	HG12MC(1)
	875	GEMSY
	JK5875-3	JACK
	TY-B875-5	PROTEX
	GC6875H,GC6875M	TYPICAL
	TW2-B875	WANPING
	875	ZOJE
	T828-75H,T828-75M,T828-75X	SIRUBA
	BAS-6200,LT2-B872,LT2-B875	HG12MC(1)TR
	872-875-7	GEMSY
	JK5872-5,JK5875-5	JACK
	GC6872MD3,GC6875HD3,GC6875MD3	TYPICAL
	872,875	WANPING
	875-D3	ZOJE
	MS-B872-403,MS-B872-405,MS-B875-403 MS-B875-405	MILLION SPECIAL
	TC-B872-403,TC-B875-403,TC-B875-405	NITAKA
	T828-72-H-U,T828-75-M-U,T828-75-X-U	SIRUBA
	T-8720A-003,T-8720A-005,TN-872A-003	HR12M(BR)
	KM-750BL	SUNSTAR
	T-8750A-003,TN-875A-003	HR12MC(1)
	KM-790BL	SUNSTAR
	T-8722A-403,T-8752A-403,T-8752A-405 TN-872B-403	HR12MC(1)TR
	KM-790BL-7	SUNSTAR
	LT2-2220-BOB	HSH-12-15MM
	GC20508-C	BAOMA
	QJ2230B	CHURCHILL
	2001-1B	GEMSY
	GC20528-B	HIGHLEAD
	GC20202	TYPICAL
	KM-740BL	SUNSTAR
	DB2-H322/323,LS2-H620(H)	UNICORN
	CS-3100L,CS-871L,CS-872L	GOLDEN WHEEL
	MS-B872-3,MS-B875-5	MILLION SPECIAL
	TC2-B935	NITAKA

Page 22 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHAFT

Hirose Hook Catalog parts on page 22
Ref	Part number	Part name	Qty
	HSH-12-15MM	TAKING
	HSH-12-15MM(3)TR	MITSUBISHI
	TYPICAL	GC6220BD
	UNCORN	LT2-H6200(H)
	HSH-12-15MM(410)	HIGHLEAD
	HSH-12-15MM(410M)	SIRUBA
	HSH-12-15MM(410M2)	MITSUBISHI
	HSH-12-15MM(5)	BROTHER
	PRINCE	PLM-100
	SEIKO	LLW-28L-TA,LLW-8BL,LLW-8L-TA,LLW-8BL-TA,LSW-26BL,LSW-6L,LSW-7BL-T,LSW-7L-T,LSW-8BL,LSW-8BLV,LSW-8L,LSW-8LV,LSW-8LVMF
	SUNSTAR	KM-560
	NITAKA	TC-2508,TC-28B,TC-8B
	HSH-12-15MM(5)SS	TOYOTA
	HSH-12-15MM(5)TR1	BROTHER
	HSH-12-15MM(A)	with short hook gib
	HSH-12-15MM(V)	MITSUBISHI
	HIGHLEAD	GC20618-1,GC20618-2
	WANPING	GC20606
	GOLDEN WHEEL	CS3L-7241,CSU-4101
	HSH-12-15MMB(5)	BROTHER
	SEIKO	LLW-28,LLW-28BL,LSW-27BL,LSW-27L,LSW-28BL,LSW-28L,LTW-27BLM
	HSH-12-15MMB(5)TR1	BROTHER
	HSH-12-15MMB(5)TR4	TOYOTA
	SUNSTAR	KM-560-7
	HSH-12-15MMJ	JU KI
	HSH-12-15MMJ(A)	JU KI
	SINGER	211U867,211UX567,212U539A/839A
	HSH-12M(3)	MITSUBISHI
	HSH-12M(BR)	BROTHER
	HSH-12M-82C(L)	JU KI
	HSH-12M-82C(R)	JU KI
	HSH-12M-82CTR(L)	JU KI
	SHANGGONG	GD8-1,GD8-4,GD8-7
	HSH-12M-82CTR(R)	JU KI
	SHANGGONG	GD8-1,GD8-4,GD8-7
	HSH-12MA(3)	MITSUBISHI
	HSH-12MC	MITSUBISHI
	GEMSY	2000-2B
	HIGHLEAD	GC20518-B
	TYPICAL	GC6240B
	UNICORN	LT2-H625(H)
	GOLDEN WHEEL	CS-3150-L,CS-7175,CS-875L
	MILLION SPECIAL	MS-B875-5
	NITAKA	TC2-B1885,TC2-B875

Page 23 — VERTICAL AXIS ROTARY HOOK

Hirose Hook Catalog parts on page 23
Ref	Part number	Part name	Qty
	HSH-12MC	SICAMA
	HSH-12MC(1)	BROTHER
	HSH-12MC(2)	JU KI
	HSH-12MC(3)	MITSUBISHI
	HIGHLEAD	GC20628-D-B
	HSH-12MC(5)	SICAMA
	HSH-12MCA(2)	SEIKO
	HSH-12MCA(5)	JU KI
	※ HSH-12MM(6)TR	SEIKO
	※ HSH-12MMA(6)TR	JU KI
	HSH-445	JU KI
	HSH-445(6SP)	DURKOPP/ADLER
	HSH-445(SP)	SINGER
	HSH-445-59	JU KI
	SINGER	144W,145W
	JU KI	LT-591

Page 24 — SHUTTLE 摆梭

Hirose Hook Catalog parts on page 24
Ref	Part number	Part name	Qty
	DD1	SINGER
	DD1(6)	YAKUMO
	DD1-OP	SINGER
	HAD-204	DURKOPP/ADLER
	HAD-204	SEIKO
	HAD-204	CHIKON
	HAD-204(273)	JUKI
	HAD-204(273)	WANPING
	HAD-204(6)	CHIKON
	HAD-204(OP)	SEIKO
	HSH-1-1	SINGER
	HSH-7-3	DURKOPP/ADLER
	HSH-7-3	SEIKO
	HSH-7-3	SINGER
	HSH-7-3	WANPING
	HSH-7-3	CHIKON
	TC-310(AF)	BROTHER
	TC-310(BG)	BROTHER
	TC-LK(BUC)	UNICORN
	TC-LK(SUA)	SUNSTAR
	TC-LK(SUB)	SUNSTAR
	TF1	DURKOPP/ADLER
	TF1	SEIKO
	TF1	SINGER

Page 25 — OTHERS 其他

Hirose Hook Catalog parts on page 25
Ref	Part number	Part name	Qty
	HAD-467CTR(SU)	HAD-467CTR(SU)
	HAD-467TR	HAD-467TR
	HAD-467TR(1B)	HAD-467TR(1B)
	HAD-467TR(1B)	HAD-467TR(1B)
	HAD-467TR(1B)	HAD-467TR(1B)
	HAD-467TR(1B)	HAD-467TR(1B)
	HAD-467TR(6A)	HAD-467TR(6A)
	HAD-M467TR(6)	HAD-M467TR(6)
	HBA-1	HBA-1
	HLE-16	HLE-16
	HLE-16(170UN)	HLE-16(170UN)
	HLE-170	HLE-170
	HLE-30(UN)	HLE-30(UN)
	HMU-1	HMU-1
	HSH-32	HSH-32
	HSH-32	HSH-32
	HSH-32	HSH-32
	HSH-32	HSH-32
	HSH-32(26)	HSH-32(26)
	HSH-33	HSH-33
	HSH-33	HSH-33
	HSH-33(3)	HSH-33(3)
	HSH-33(3)	HSH-33(3)
	HTT-12(21)	HTT-12(21)
	HTT-18	HTT-18
	HTT-20	HTT-20
	HTT-21(K)	HTT-21(K)
	KN-SCT	KN-SCT
	L-BQ1U	L-BQ1U
	L-BQ1U	L-BQ1U
	L-BQ1U	L-BQ1U
	L-BSR(503)	L-BSR(503)
	L-BTM(5/32)	L-BTM(5/32)
	L-CS2	L-CS2
	RE-DP855	RE-DP855

Page 26 — BOBBIN CASE / CAP 梭芯套/梭帽

Hirose Hook Catalog parts on page 26
Ref	Part number	Part name	Qty
	BC-102	BOBBIN CASE / CAP
	BC-12L(TR2FB)	BOBBIN CASE / CAP
	BC-310(ANC)	BOBBIN CASE / CAP
	BC-310(AND)	BOBBIN CASE / CAP
	BC-DB1(MFB)2	BOBBIN CASE / CAP
	BC-DP2	BOBBIN CASE / CAP
	BC-DP2(2)	BOBBIN CASE / CAP
	BC-DP2(3B)	BOBBIN CASE / CAP
	BC-DP57	BOBBIN CASE / CAP
	BC-DP800	BOBBIN CASE / CAP
	BC-DP815	BOBBIN CASE / CAP
	BC-DP815(P)	BOBBIN CASE / CAP
	BC-DP855	BOBBIN CASE / CAP
	BC-DP856	BOBBIN CASE / CAP
	BC-HBA1	BOBBIN CASE / CAP
	BC-HDU551	BOBBIN CASE / CAP
	BC-HDU556	BOBBIN CASE / CAP
	BC-HPF3114	BOBBIN CASE / CAP
	BC-HST(2)	BOBBIN CASE / CAP
	BC-HST(A1)	BOBBIN CASE / CAP
	BC-HTH(B1)	BOBBIN CASE / CAP
	BC-HTH(2E)	BOBBIN CASE / CAP
	BC-HTH(2EA)	BOBBIN CASE / CAP
	BC-HTH(E)	BOBBIN CASE / CAP
	BC-HTH(HPNG)	BOBBIN CASE / CAP
	BC-HTH(ZE)	BOBBIN CASE / CAP
	BC-HTH(ZEH)	BOBBIN CASE / CAP
	BC-HTM(761)	BOBBIN CASE / CAP
	BC-HTT12(21)	BOBBIN CASE / CAP
	BC-HTT18	BOBBIN CASE / CAP
	BC-HTT20	BOBBIN CASE / CAP

Page 27 — BOBBIN CASE / CAP 梭芯套/梭帽

Hirose Hook Catalog parts on page 27
Part number	Part name	Qty
BC-HTT21(K)	BOBBIN CASE / CAP
BC-TCLK(B)	BOBBIN CASE / CAP
SPS/A-1306(GP),SPS/A-1306(GS),SPS/A-1306(HS)	BOBBIN CASE / CAP	53
UAS-H1407(H)	BOBBIN CASE / CAP	53
LH-1152,LH-1152-4	BOBBIN CASE / CAP	54
LX2-630-M1	BOBBIN CASE / CAP	54
APW-192N~196N,APW-231N~239N APW-297,298,LH-570, 571	BOBBIN CASE / CAP	54
LT2-B835	BOBBIN CASE / CAP	54
LT2-2240-MOB,LT2-2250-M1TW	BOBBIN CASE / CAP	54
LTW-27BK	BOBBIN CASE / CAP	54
212U143A/144,212U443A/444	BOBBIN CASE / CAP	54
2000-2M	BOBBIN CASE / CAP	54
GC20528-M	BOBBIN CASE / CAP	54
GC6240M,GC6240MD	BOBBIN CASE / CAP	54
LT2-H625(M)	BOBBIN CASE / CAP	54
CS-3150,CS-7165,CS-875-3	BOBBIN CASE / CAP	54
MS-B845	BOBBIN CASE / CAP	54
TC2-B845,TC2-B1883	BOBBIN CASE / CAP	54
LT2-B835-3-0	BOBBIN CASE / CAP	54
LT2-B845-380	BOBBIN CASE / CAP	54
LT2-B832-1,-3,-5	BOBBIN CASE / CAP	54
LT2-B832-3-0	BOBBIN CASE / CAP	54
LU2-430-B1T,LU2-4410-B1T,PLK-E7191 PLY-1185,PLY-7181	BOBBIN CASE / CAP	54
LH-527,LU-1565N,LUH-521,LUH-526	BOBBIN CASE / CAP	54
LT2-2240-BOB,PLY-501F	BOBBIN CASE / CAP	54
2000-2B	BOBBIN CASE / CAP	54
GC20518-B	BOBBIN CASE / CAP	54
GC6240B	BOBBIN CASE / CAP	54
LT2-H625(H)	BOBBIN CASE / CAP	54
CS-3150-L,CS-7175,CS-875L	BOBBIN CASE / CAP	54
MS-B875-5	BOBBIN CASE / CAP	54
TC2-B875,TC2-B1885	BOBBIN CASE / CAP	54
LT2-B836	BOBBIN CASE / CAP	54
LT2-2250-B1T	BOBBIN CASE / CAP	54
GC20528-B-D	BOBBIN CASE / CAP	54
CS-7175-BT,CS-7175H-BT	BOBBIN CASE / CAP	54
LT2-B875-380,LT2-B875-580	BOBBIN CASE / CAP	54
LSW-26BL-R,LSW-27BLK,LSW-6L-G	BOBBIN CASE / CAP	54
212U543A/544,212U843A	BOBBIN CASE / CAP	54
51W,136W,236W	BOBBIN CASE / CAP	54
21W162,22W	BOBBIN CASE / CAP	54
LH-525N,LH-529	BOBBIN CASE / CAP	54
211G451/457,212G140/141/145/440,212U441	BOBBIN CASE / CAP	54
LH-1162,LH-1162-4	BOBBIN CASE / CAP	54
112W115-139,138G101,167G/W	BOBBIN CASE / CAP	54
LT2-B845,T-8450A-003,TN-845A-003	BOBBIN CASE / CAP	54
845	BOBBIN CASE / CAP	54

Page 28 — BOBBIN CASE / CAP

Hirose Hook Catalog parts on page 28
Ref	Part number	Part name	Qty
	JK5845-3	JK5845-3
	GC6845H	GC6845H
	TW2-B845-5	TW2-B845-5
	845
	T828-45-H,T828-48-L	T828-45-H,T828-48-L
	LH-3162-7,LH-3168,LH-3168-7	LH-3162-7,LH-3168,LH-3168-7
	KM-790,KM-790-7	KM-790,KM-790-7
	LT2-H6250(M)	LT2-H6250(M)
	LT2-B845,T-8452A-403,TN-845B-401	LT2-B845,T-8452A-403,TN-845B-401
	JK5845-5	JK5845-5
	TY-B845-403	TY-B845-403
	GC6845HD3,GC6845MD3	GC6845HD3,GC6845MD3
	845
	845-D3	845-D3
	BEISLER 845,YAZICI 845	BEISLER 845,YAZICI 845
	T828-45-H-U,T828-45-M-U,T828-45-L-U	T828-45-H-U,T828-45-M-U,T828-45-L-U
	LT2-B841,LT2-B842,T-8421A-T03,TN-842B-40F	LT2-B841,LT2-B842,T-8421A-T03,TN-842B-40F
	GC6842HD3,GC6842MD3	GC6842HD3,GC6842MD3
	BEISLER 842,YAZICI 842	BEISLER 842,YAZICI 842
	T828-41,T828-42,T828-47	T828-41,T828-42,T828-47
	LH-3128,LH-3128-7	LH-3128,LH-3128-7
	LH-3178	LH-3178
	LT2-B872,T-8722A-403,TN-872B-403	LT2-B872,T-8722A-403,TN-872B-403
	872-7
	JK5872-5,JK5875-5	JK5872-5,JK5875-5
	872
	872-D3	872-D3
	MS-B872-403,MS-B872-405	MS-B872-403,MS-B872-405
	TC-B872-403,TC-B872-405	TC-B872-403,TC-B872-405
	T828-72-H-U,T828-72-M-U	T828-72-H-U,T828-72-M-U
	BAS-612,613,LT2-B875,T-8750A-003,TN-875A-003	BAS-612,613,LT2-B875,T-8750A-003,TN-875A-003
	875
	JK5875-3	JK5875-3
	TY-B875-5	TY-B875-5
	GC6875H,GC6875M	GC6875H,GC6875M
	TW2-B875	TW2-B875
	875
	T828-75H,T828-75M,T828-75X	T828-75H,T828-75M,T828-75X
	BAS-6150,BAS-6200,LT2-B875,T-8752A-403	BAS-6150,BAS-6200,LT2-B875,T-8752A-403
	875-7
	GC6872MD3,GC6875HD3,GC6875MD3	GC6872MD3,GC6875HD3,GC6875MD3
	875
	875-D3	875-D3
	KM-790BL,KM-790BL-7	KM-790BL,KM-790BL-7
	LT2-H6250(H)	LT2-H6250(H)
	MS-B875-3,MS-B875-403,MS-B875-405	MS-B875-3,MS-B875-403,MS-B875-405
	TC-B875-403,TC-B875-405	TC-B875-403,TC-B875-405

Page 29 — BOBBIN CASE / CAP 梭芯套/梭帽

Hirose Hook Catalog parts on page 29
Ref	Part number	Part name	Qty
	CP-G12MC(1)TR	BOBBIN CASE / CAP
	CP-G12MC(1)TR	BOBBIN CASE / CAP
	CP-G12MC(2)	BOBBIN CASE / CAP
	CP-HAD161(6)	BOBBIN CASE / CAP
	CP-HAD167	BOBBIN CASE / CAP
	CP-HAD167(6)	BOBBIN CASE / CAP
	CP-HAD167CTR	BOBBIN CASE / CAP
	CP-HAD167TR	BOBBIN CASE / CAP
	CP-HAD267TR	BOBBIN CASE / CAP
	CP-HAD467TR	BOBBIN CASE / CAP
	CP-HAD68	BOBBIN CASE / CAP
	CP-HAD68(6)	BOBBIN CASE / CAP
	CP-HDU249	BOBBIN CASE / CAP
	CP-HDU381	BOBBIN CASE / CAP
	CP-HPF1242TR	BOBBIN CASE / CAP
	CP-HPF144TR	BOBBIN CASE / CAP
	CP-HPF151	BOBBIN CASE / CAP
	CP-HPF151TR	BOBBIN CASE / CAP
	CP-HPF190	BOBBIN CASE / CAP
	CP-HPF442TR	BOBBIN CASE / CAP
	CP-HPF490	BOBBIN CASE / CAP
	CP-HPF545	BOBBIN CASE / CAP

Page 30 — BOBBIN CASE / CAP 梭芯套/梭帽

Hirose Hook Catalog parts on page 30
Ref	Part number	Part name	Qty
	CP-HPF545
	CP-M82C
	SHANGGONG	GD8-1,GD8-4,GD8-7

Page 31 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) HIGH SPEED TYPE 垂直回转式梭头(DB 型) 高速缝梭头

Hirose Hook Catalog parts on page 31
Ref	Part number	Part name	Qty
	HAD-396
	HAD-396(H)
	HDU-211
	HDU-211(1)
	HDU-271
	HDU-272
	HDU-271(ORP)
	HNE-830
	HNE-835
	HPF-480
	HSH-7.24BJ
	HSH-7.24BJZ
	HSH-7.94A
	HSH-7.94A(3)
	HSH-7.94A(TS)
	HSH-7.94A1
	HSH-7.94AO
	HSH-7.94AOTR
	HSH-7.94ATR
	HSH-7.94B
	HSH-7.94B(1)
	HSH-7.94B(1)TR
	HSH-7.94B(2SPH)
	HSH-7.94B(391)
	HSH-7.94B(491)
	HSH-7.94B(660)
	HSH-7.94B(7)
	HSH-7.94B(AC)

Page 32 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) HIGH SPEED TYPE

Hirose Hook Catalog parts on page 32
Ref	Part number	Part name	Qty
	HSH-7.94B(HP)
	HSH-7.94B(K)
	HSH-7.94B(KSN)
	HSH-7.94B(NK)
	HSH-7.94BO
	HSH-7.94B(RT)
	HSH-7.94B(SPH)
	HSH-7.94B(SPHA)
	HSH-7.94B(TS)
	HSH-7.94B1
	HSH-7.94BKTR
	HSH-7.94BKTR(2)
	HSH-7.94BKTR(H)
	HSH-7.94BN
	HSH-7.94BO
	HSH-7.94BOH
	HSH-7.94BOH(1)
	HSH-7.94BOHN
	HSH-7.94BOHN(1)
	HSH-7.94BOHNTR
	HSH-7.94BOHNTR(B)
	HSH-7.94BRN
	HSH-7.94BRN(H)
	HSH-7.94BSN
	HSH-7.94BTR
	HSH-7.94BTR(1RPWL)
	*HSH-7.94BTR(2QSP)
	*HSH-7.94BTR(2QSPFB)

Page 33 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) HIGH SPEED TYPE 垂直回转式拨头 (DB 型) 高速缝头

Hirose Hook Catalog parts on page 33
Ref	Part number	Part name	Qty
	HSH-7.94BTR(2SPFB)
	HSH-7.94BTR(2SPRPWS)
	HSH-7.94BTR(3)
	HSH-7.94BTR(491)
	HSH-7.94BTR(591B)
	HSH-7.94BTR(591D)
	HSH-7.94BTR(591DT)
	HSH-7.94BTR(737)
	HSH-7.94BTR(737SPQ)
	HSH-7.94BTR(CR)
	HSH-7.94BTR(HP)
	HSH-7.94BTR(N)
	HSH-7.94BTR(PFQL)
	HSH-7.94BTR(Q)
	HSH-7.94BTR(QSP)
	HSH-7.94BTR(R)
	HSH-7.94BTR(RPW)
	HSH-7.94BTR(SP)
	HSH-7.94BTR(SPH)
	HSH-7.94BTR(T)
	HSH-7.94BTR(TIN)
	HSH-7.94BTR(TS)
	HSH-7.94C
	HSH-7.94C(L)
	HSH-7.94C(TS)
	HSH-7.94CO
	HSH-7.94CO(L)
	HSH-7.94CO(TS)

Page 34 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) HIGH SPEED TYPE 垂直回转式梭头 (DB 型) 高速缝梭头

Hirose Hook Catalog parts on page 34
Ref	Part number	Part name	Qty
	HSH-7.94COTR
	HSH-7.94CTR
	HSH-7.94CTR(TS)
	HSH-7.94D
	HSH-7.94DRN(1)
	HSH-7.94DRNTR
	HSH-7.94DTR(1Q)
	HSH-7.94DTR(Q)
	HTE-833
	HTH-614BTR(1.7QE)
	HTH-614BTR(2E)
	HTH-614BTR(QE)
	HTH-ATR(E)
	HTH-BTR(2SPHPNG20E)
	HTH-BTR(E)
	HTH-BTR(HPNG)
	HUN-614B
	HUN-614B(L)
	HUN-614C
	HUN-614C(L)
	HUN-614C(TS)

Page 35 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LARGE TYPE

Hirose Hook Catalog parts on page 35
Ref	Part number	Part name	Qty
	DBL-C
	DBM-A(Z14)
	DBM-A(Z17)
	DBM-ATR(7.94)
	HDU-M265
	HPF-3518
	HPF-418
	HSM-A
	HSM-A(3)
	HSM-A(5)
	HSM-A(6)
	HSM-A(M2QTS)
	HSM-A(MQ2L)
	HSM-A1
	HSM-A1HTR
	HSM-A1HMTR
	HSM-A1HTR(T)
	HSM-A1SH
	HSM-A1TR(280)
	HSM-AM(3)
	HSM-AR(1.7)
	HSM-AR(2.1)
	HSM-AR(PNG)
	HSM-ARTR(1.7)
	HSM-ARTR(2.1)
	HSM-ARTR(ABHP)
	HSM-ATR(1Q)
	HSM-ATR(1QTS)

Page 36 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LARGE TYPE

Hirose Hook Catalog parts on page 36
Ref	Part number	Part name	Qty
	HSM-ATR(MQ1L)
	HSM-ATR(PFNGOPTS)L
	HSM-B
	HSM-B(1SU)
	HSM-B(IE)
	HSM-B(Q)TR
	HSM-B(SU)
	HSM-B(Z17)
	HSM-B1
	HSM-B1H
	HSM-B1H(1)
	HSM-B1HTR
	HSM-B1HTR(1Q)
	HSM-B1HTR(2)
	HSM-B1HTR(BB)
	HSM-BRTR(1.7)
	HSM-BRTR(2.1)
	HSM-BRTR(HP370)
	HSM-Z17
	HST-A
	HST-A(C)
	HST-A(CNG)
	HST-A(HPQC)
	HST-A(LP)
	HST-A(ME)
	HST-B1(HPA)
	HTM-A
	HTM-A1HTR

Page 37 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LARGE TYPE 垂直回转式梭头(DB 型)大型梭头

Hirose Hook Catalog parts on page 37
Ref	Part number	Part name	Qty
	HTM-BTR(HP761)	HTM series hook (1.4 times thread)

Page 38 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LOW SPEED TYPE 垂直回转式梭头(DB 型)低速缝梭头

Hirose Hook Catalog parts on page 38
Ref	Part number	Part name	Qty
	DA1-A	DA1-A
	DA1-A(7.94)	DA1-A(7.94)
	DA1-A(7.94ST)	DA1-A(7.94ST)
	DA1-A1	DA1-A1
	DA1-AH	DA1-AH
	DA1-ATR	DA1-ATR
	DA1-ATR(1DB)	DA1-ATR(1DB)
	DA1-B	DA1-B
	DA1-B(109)	DA1-B(109)
	DA1-B(7.94)	DA1-B(7.94)
	DA1-B(K)	DA1-B(K)
	DA1-BOH(AL)	DA1-BOH(AL)
	DA1-BTR	DA1-BTR
	DA1-C	DA1-C
	DA1-C(AL)	DA1-C(AL)
	DA1-CTR	DA1-CTR
	DA2-A(TA1-A)	DA2-A(TA1-A)
	DA2-B(TA1-B)	DA2-B(TA1-B)
	DA2-C(TA1-C)	DA2-C(TA1-C)
	DB1-BZ(20)	DB1-BZ(20)
	DB1-BZ(20L)	DB1-BZ(20L)
	DB1-Z(20)	DB1-Z(20)
	DB1-Z(20L)	DB1-Z(20L)
	DB1-Z16	DB1-Z16
	DB1-Z16(LP)	DB1-Z16(LP)
	DB1-Z16(TS)	DB1-Z16(TS)
	DB1-Z16(TU)	DB1-Z16(TU)
	DB1-Z16B	DB1-Z16B

Page 39 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LOW SPEED TYPE

Hirose Hook Catalog parts on page 39
Ref	Part number	Part name	Qty
	DB1-Z39
	DB1-Z710
	HDU-265
	HDU-265Y
	HM2-F10(EL)
	HM2-FATR(1)
	HM2-FBTR(SS)
	HPF-134
	HPF-230W
	HPF-234
	HPF-238
	HPF-335
	HPF-335(5)
	HPF-438
	HPF-438(CR)
	HPF-563TR(RP)
	HSH-7.94A(M1Q)
	HSH-7.94A(M1QTS)
	HSH-7.94A(M3Q)
	HSH-7.94A(MTQ)
	HSH-7.94ATR(M1Q)
	HSH-7.94ATR(M1QH)
	HSH-7.94ATR(M1QTS)
	HSH-7.94ATR(M1QTSL)
	HSH-7.94ATR(M3Q)
	HSH-7.94ATR(MQ2)
	HSH-7.94ATR(MQRP)
	HSH-7.94ATR(MQRPW)

Page 40 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LOW SPEED TYPE

Hirose Hook Catalog parts on page 40
Ref	Part number	Part name	Qty
	HSH-7.94ATR(MQSU)
	HSH-7.94ATR(MQSUL)
	HSH-7.94ATR(MQSUNL)
	HSH-7.94ATR(MTQ)
	HSH-7.94ATR(MTQEL)
	HSH-7.94ATR(MTQETA)
	HSH-7.94ATR(MTQRP)
	HSH-7.94ATR(MTQTS)
	HSH-7.94B(188UL)
	HSM-ATR(MQRPLN)
	HSM-ATR(MTQ)
	HSM-ATR(MTQTS)
	HTH-ATR(MQE)
	HTH-ATR(MQESU)
	HTH-ATR(MQESUL)
	HTH-ATR(MQESUNL)
	TA1-Z16

Page 41 — HORIZONTAL AXIS ROTARY HOOK(DP TYPE) HIGH SPEED ZIGZAG TYPE 垂直回转式梭头(DP型)高速人字型缝纫梭头

Hirose Hook Catalog parts on page 41
Ref	Part number	Part name	Qty
	DP2
	DP2(B)
	DP2(H)
	DP2(HS)
	DP2-457(HP)
	DP2-457(LHP)
	DP2-457U(T)
	DP2-457UTR
	DP2-57(2)
	DP2-57(2)IN
	DP2-57(2HPTS)
	DP2-57(2LP)
	DP2-57(2LPA)
	DP2-57(2LPRP)
	DP2-57(2LPY)
	DP2-57(2RP)
	DP2-57(3LP)
	DP2-57(3LP2)
	DP2-57(3LP2R)
	DP2-57(3LP2RHP)
	DP2-57(3LP2V)
	DP2-57(3LP2VHP)
	DP2-57(3LP2VRPW)
	DP2-71
	DP2-800FR
	DP2-815
	DP2-815(FR)
	DP2-816

Page 42 — HORIZONTAL AXIS ROTARY HOOK(DP TYPE) HIGH SPEED ZIGZAG TYPE 垂直回转式梭头(DP型)高速人字型缝纫梭头

Hirose Hook Catalog parts on page 42
Ref	Part number	Part name	Qty
	DP2-816(FR)
	DP2-817
	DP2-818FR
	DP2-855
	DP2-856TR
	DP2-L(N)
	DP2-LB
	DP2-NJ
	DP2-NJ(790)
	DP2-NJ(791K)
	DP2-NJ771
	HDU-556
	HPF-3114
	HPF-3116
	HSH-102
	HSH-51-1
	HSH-8-20
	HSH-8-20(K)

Page 43 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHANK

Hirose Hook Catalog parts on page 43
Ref	Part number	Part name	Qty
	HAD-68
	HDU-249
	HPF-151
	HPF-442
	HPF-442TR
	HPF-442TR(L)
	HPF-490
	HPF-490(5)TR
	HPF-490(A)
	HPF-490A(5)TR
	HPF-490A(N)
	HPF-490AH(N)
	HPF-490TR
	HSH-10-100
	HSH-10-100A
	HSH-10-100M
	HSH-18-4
	HSH-18-4A
	HSH-18-4C
	HSH-19
	HSH-2-12
	HSH-22-21
	HSH-31
	HSH-31(12)
	HSH-31(6)
	HSH-31(B)
	HSH-31(B12)
	HSH-36-1

Page 44 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHANK

Hirose Hook Catalog parts on page 44
Ref	Part number	Part name	Qty
	HSH-36-2
	HSH-5-16
	HSH-68-1

Page 45 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHAFT

Hirose Hook Catalog parts on page 45
Ref	Part number	Part name	Qty
	H12-15L
	H12-15L(TR2)
	H12-15L(TR2AE)
	H12-15L(TR2FB)
	H12-15LC
	H12-15LCTR2
	H12L(1)
	HG12-15L
	HG12-15L(H)
	HG12-15L(TR1)
	HG12-15LC
	HG12-15LCTR1
	HG12L(1)
	HG12L(1)TR1
	HR12-15L
	HR12-15L(H)
	HR12-15L(TR1)
	HR12-15LC
	HR12-15LCTR1
	HR12L(1)
	HR12L(1)TR1
	HSH-11-51
	HSH-11-53
	HSH-11-55
	HSH-11-55M(2)
	HSH-12(2)
	HSH-12(2)TR
	HSH-12(570)

Page 46 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHAFT

Hirose Hook Catalog parts on page 46
Ref	Part number	Part name	Qty
	HSH-12-11M
	HSH-12-15
	HSH-12-15(2)
	HSH-12-15(2)TR
	HSH-12-15(A)
	HSH-12-15L
	HSH-12-15L(H)
	HSH-12-15L(TR)
	HSH-12-15L(TR1)
	HSH-12-15LC
	HSH-12-15LCTR
	HSH-12-15LCTR1
	HSH-12-15LTR(H)
	HSH-12-15M
	HSH-12-15M(3)
	HSH-12-15M(3UC)
	HSH-12-15MTR
	HSH-12-15MTR(3)
	HSH-12-40
	HSH-12-62C(L)
	HSH-12-62C(R)
	HSH-12-62CTR(L)
	HSH-12-62CTR(R)
	HSH-12-68
	HSH-12C
	HSH-12L(1)
	HSH-12L(1)TR
	HSH-12L(1)TR1

Page 47 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with BOSS(HUB) 水平回转式梭头轴套小型梭头

Hirose Hook Catalog parts on page 47
Ref	Part number	Part name	Qty
	HSH-21-40
	HSH-21-40(2)
	HSH-21-40(AJ)
	HSH-21-40(HP)
	HSH-21-40(J)
	HSH-21-40(S)C
	HSH-21-40A(2)
	HSH-21-40TR
	HUN-622

Page 48 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHANK

Hirose Hook Catalog parts on page 48
Ref	Part number	Part name	Qty
	HAD-160(1341A)
	HAD-160(6)
	HAD-160TR(6)
	HAD-161(6)
	HAD-166TR
	HAD-167
	HAD-167TR
	HAD-267TR
	HPF-1242
	HPF-1242(A)
	HPF-1242(A)TR
	HPF-1242TR
	HPF-545
	HSH-12MS
	HSH-12MS(5)
	HSH-12-15MM(S)
	HSH-12-15MM(S)C
	HSH-31MMB(5)
	HYM-1341ATR(6)
	HYM-1341AY
	HYM-1341AY(6)
	HYM-1341BTR(6)
	HYM-1341BY
	HYM-1341BY(6)

Page 49 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHAFT

Hirose Hook Catalog parts on page 49
Ref	Part number	Part name	Qty
	H12M-78TR
	H12MC(2)
	H12MC(2)TR
	H12MM(2)
	H12MM(2)TR
	HG12M(BR)
	HG12MC(1)
	HG12MC(1)TR
	HR12M(BR)
	HR12MC(1)
	HR12MC(1)TR
	HSH-12-15MM
	HSH-12-15MM(3)TR
	HSH-12-15MM(410)
	HSH-12-15MM(410M)
	HSH-12-15MM(410M2)
	HSH-12-15MM(5)
	HSH-12-15MM(5)SS
	HSH-12-15MM(5)TR1
	HSH-12-15MM(A)
	HSH-12-15MM(V)
	HSH-12-15MMB(5)
	HSH-12-15MMB(5)TR1
	HSH-12-15MMB(5)TR4
	HSH-12-15MMJ
	HSH-12-15MMJ(A)
	HSH-12M(3)
	HSH-12M(BR)

Page 50 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHAFT

Hirose Hook Catalog parts on page 50
Ref	Part number	Part name	Qty
	HSH-12M-82C(L)
	HSH-12M-82C(R)
	HSH-12M-82CTR(L)
	HSH-12M-82CTR(R)
	HSH-12MA(3)
	HSH-12MC
	HSH-12MC(1)
	HSH-12MC(2)
	HSH-12MC(3)
	HSH-12MC(5)
	HSH-12MCA(2)
	HSH-12MCA(5)
	HSH-12MM(6)TR
	HSH-12MMA(6)TR
	HSH-445
	HSH-445(SP)
	HSH-445-59

Page 51 — SHUTTLE 搜

Hirose Hook Catalog parts on page 51
Ref	Part number	Part name	Qty
	DD1
	DD1(6)
	DD1-OP
	HAD-204
	HAD-204(273)
	HAD-204(6)
	HAD-204(OP)
	HSH-1-1
	HSH-7-3
	TC-310(AF)
	TC-310(BG)
	TC-LK(BUC)
	TC-LK(SUA)
	TC-LK(SUB)
	TF1

Page 52 — OTHERS 其他

Hirose Hook Catalog parts on page 52
Ref	Part number	Part name	Qty
	HAD-467CTR(SU)
	HAD-467TR
	HAD-467TR(1B)
	HAD-467TR(6A)
	HAD-M467TR(6)
	HBA-1
	HLE-16
	HLE-16(170UN)
	HLE-170
	HLE-30(UN)
	HMU-1
	HSH-32
	HSH-32(26)
	HSH-33
	HSH-33(3)
	HTT-12(21)
	HTT-18
	HTT-20
	HTT-21(K)
	KN-SCT
	L-BQ1U
	L-BSR(503)
	L-BTM(5/32)
	L-CS2
	RE-DP855

Page 53 — BOBBIN CASE / CAP 梭芯套/梭帽

Hirose Hook Catalog parts on page 53
Ref	Part number	Part name	Qty
	BC-102
	BC-12L(TR2FB)
	BC-310(ANC)
	BC-310(AND)
	BC-DB1(MFB)2
	BC-DP2
	BC-DP2(2)
	BC-DP2(3B)
	BC-DP57
	BC-DP800
	BC-DP815
	BC-DP855
	BC-DP856
	BC-HBA1
	BC-HDU556
	BC-HPF3114
	BC-HST(2)
	BC-HST(A1)
	BC-HST(B1)
	BC-HTH(E)
	BC-HTH(HPNG)
	BC-HTH(ZEH)
	BC-HTM(761)
	BC-TCLK(B)
	BC-HTT12(21)
	BC-HTT18
	BC-HTT20
	BC-HTT21(K)

Page 54 — BOBBIN CASE／CAP 梭芯套/梭帽

Hirose Hook Catalog parts on page 54
Ref	Part number	Part name	Qty
	CP-12(2)
	CP-12(3)
	CP-12(570)TC
	CP-12C
	CP-12CTR
	CP-12CTR(1)
	CP-12L(1)
	CP-12L(1)TR1
	CP-12M(230)
	CP-12MC
	CP-12MC(1)
	CP-12MC(3)
	CP-12MC(5)
	CP-18
	CP-2
	CP-62C
	CP-68
	CP-G12C
	CP-G12C(2)
	CP-G12CTR(1)
	CP-G12L(1)
	CP-G12L(2)
	CP-G12M(2)TR
	CP-G12M(BR)TR
	CP-G12MC(1)
	CP-G12MC(1)TR
	CP-G12MC(2)
	CP-HAD161(6)

Page 55 — BOBBIN CASE/ CAP 梭芯套/梭帽

Hirose Hook Catalog parts on page 55
Ref	Part number	Part name	Qty
	CP-HAD167
	CP-HAD167(6)
	CP-HAD167CTR
	CP-HAD167TR
	CP-HAD267TR
	CP-HAD467TR
	CP-HAD68
	CP-HDU249
	CP-HPF1242TR
	CP-HPF144TR
	CP-HPF151
	CP-HPF442TR
	CP-HPF490
	CP-HPF545
	CP-M82C

Page 57 — REFERENCE TABLE

Hirose Hook Catalog parts on page 57
Ref	Part number	Part name	Qty
	58	ALFA
	58	ALTIN (TEXTIMA)
	58	BARATTO
	58	BARUDAN
	59	BROTHER
	63	DURKOPP / ADLER
	65	HAPPY
	65	JANOME
	66	JU KI
	70	MAMMUT
	70	MARCO
	71	MITSUBISHI
	73	NECCHI
	73	PEGASUS
	74	PFAFF
	76	PRINCE
	77	SEIKO
	79	SINGER
	84	STAGER
	84	TAJIMA
	85	TOYOTA
	85	TREASURE
	86	UNION SPECIAL
	86	YAMATO
	87~98	CHINESE BRAND
	BAOMA 宝马	GEMY 宝石
	BUTTERFLY 蝴蝶	HIGHLEAD 海菱
	CHURCHILL 永精	HUANAN 华南
	DADILI 大地利	JACK 杰克
	DALIAN 大连	JINSHI 金狮
	FEIQUI 飞球	MEIJIA 美佳
	FEIYUE 飞跃	PEMAL 良机
	FLYINGMAN 飞人	PROTEX 通宇
	FOMAX	SANGOOD 双角
	SHANGGONG 上工	SHEEN 盛铭
	TYPICAL 标准	TYPICAL BROTHER 兄弟标准
	WANPING 菀坪	ZGM 珠光
	ZOJE 中捷
	99~100	KOREAN BRAND
	SUNSTAR	SWF
	UNICORN
	101~112	TAIWANESE BRAND
	CHIKON 奇钢	KERDER 客德
	CHUAN NENG 傳能	KING'S 王品
	FANG HUNG 方宏	KINGTEX 精機
	FENG YING 鋒穎	MILLION SPECIAL 萬特
	GOLDEN WHEEL 金輪	MITSUTOMO 三友
	JASON SEWING 貴峰	NITAKA 日高
	JIN MING 進明	PANDA 建聯
	K-CHANCE 高機	SHIANG WANG 象王
	SICAMA 寶隆	SIRUBA 銀箭
	SUNNUN 信能	TAKING 天王星
	TONY 輝煌	YULUNG 友倫

Page 58

Hirose Hook Catalog parts on page 58
Ref	Part number	Part name	Qty
	211234	DA1-B(109)
	211234	DA1-B(109)
	112329	DA1-C(AL)
	112329	DA1-C(AL)
	8427 0226	HTE-833
	LB220020	HSH-7.94ATR(M1QH)
	KF220700	HSH-7.94ATR(M1QTS)
	KF221000	HSH-7.94ATR(MQ2)
	KF220700	HSH-7.94ATR(M1QTS)
	LB220020	HSH-7.94ATR(M1QH)
	KF220700	HSH-7.94ATR(M1QTS)
	LB220020	HSH-7.94ATR(M1QH)
	KF221000	HSH-7.94ATR(MQ2)
	KF220700	HSH-7.94ATR(M1QTS)
	KF220700	HSH-7.94ATR(M1QTS)
	KF220700	HSH-7.94ATR(M1QTS)

Page 59

Hirose Hook Catalog parts on page 59
Ref	Part number	Part name	Qty
	SA2173-101	TC-310(AF)
	SA1890-101	TC-310(BG)
	SA1890-101	TC-310(BG)
	SA2173-101	TC-310(AF)
	SA2173-101	TC-310(AF)
	SA1890-101	TC-310(BG)
	SA2173-101	TC-310(AF)
	SA2173-101	TC-310(AF)
	SA1884-001	HSM-BRTR(HP370)
	SA1885-001	HSM-B1HTR(HPNG)
	SA1886-001	HSM-BRTR(HP370H)
	SA1888-001	HSM-BRTR(HP370H7)
	S19893-911	DP2-816
	S19893-911	DP2-816
	S19897-911	DP2-816(FR)
	S19897-911	DP2-816(FR)
	SA1692-002	HG12MC(1)
	SA1694-002	HG12MC(1)TR
	SA1694-002	HG12MC(1)TR
	SA2173-101	TC-310(AF)
	SA1890-101	TC-310(BG)
	SA1628-001	HSM-7.94BTR(737QHP)
	SA1624-001	HTM-BTR(HP761)
	SA1625-201	HTH-BTR(HPNG)
	SA1624-301	HTM-BTR(HP761)
	SA1646-001	HSM-ATR(1Q)
	SA1646-001	HSM-ATR(1Q)
	SA3669-001	HSM-ATR(MQ1L)
	SA3669-001	HSM-ATR(MQ1L)
	115069-901	L-BQ1U
	115069-901	L-BQ1U
	SA1706-001	HSH-7.94B(RT)
	SA1706-001	HSH-7.94B(RT)
	SA1708-001	HSH-7.94BOH(1)
	SA1709-001	HSH-7.94BTR(737SPQ)
	SA1891-001	HSH-7.94BTR(737)
	SA1704-001	HSH-7.94BOHMTR(B)
	SA1723-001	HSM-B1HTR
	SA1722-001	HSH-B1HTR
	SA1715-001	HSH-7.94DRN(1)
	SA1716-001	HSH-7.94DTR(1Q)
	SA1706-001	HSH-7.94B(RT)
	SA1931-001	HSH-7.94BTR(737)
	SA1931-001	HSH-7.94BTR(737)
	SA1931-001	HSH-7.94BTR(737)
	SA1706-001	HSH-7.94B(RT)

Page 60 — BROTHER

Hirose Hook Catalog parts on page 60
Ref	Part number	Part name	Qty
	SA1931-001	HSH-7.94BTR(737)
	SA1720-001	HSM-A1
	SA1722-001	HSM-B1HTR
	SA1718-001	HTH-BTR(NG23)
	SA1718-001	HTH-BTR(NG23)
	SA1931-001	HSH-7.94BTR(737)
	SA1744-001	DP2-800FR
	SA1744-001	DP2-800FR
	SA1744-001	DP2-800FR
	SA1747-001	DP2-818(FR)
	SA2036-101	HST-A(C)
	141307-901	DP2-LB
	S19893-911	DP2-816
	S19893-911	DP2-816
	S19897-911	DP2-816(FR)
	S19897-911	DP2-816(FR)
	S33032-901	DP2-817
	S00688-901	HST-A
	SA2036-101	HST-A(C)
	S00689-901	HST-B
	SA1429-001	HAD-467TR(1B)
	112691-901	HSH-12-15L
	144903-901	HSH-12-15L(H)
	150371-901	HSH-12-15LC
	155466-901	HSH-12MC(1)
	150966-901	HSH-12-15MM(5)
	156379-911	HSH-12-15MM(5)TR1
	153912-901	HSH-12-15MMB(5)
	SA1670-011	HG12L(1)
	SA1668-011	HG12-15L
	SA1669-011	HG12-15L(H)
	SA1677-011	HG12-15L(TR1)
	SA1678-011	HG12L(1)TR1
	SA1668-011	HG12-15L
	SA1669-011	HG12-15L(H)
	SA1681-011	HG12-15LC
	SA1683-011	HG12-15LCTR1
	SA1685-002	HG12M(BR)
	SA1689-002	HG12MC(1)TR
	SA1692-002	HG12MC(1)
	SA1694-002	HG12MC(1)TR
	156514-901	HSH-12M(BR)
	SA1429-001	HAD-467TR(1B)
	XC6924-001	DA1-ATR(1QB)
	SA1391-002	HSH-7.94BTR(737)
	SA1704-001	HSH-7.94BOHNTR(B)
	SA1931-002	HSH-7.94BTR(737)
	SA1709-001	HSH-7.94BTR(737SPQ)
	S52063-001	HSH-7.94BTR(1RPWL)
	S52063-001	HSH-7.94BTR(1RPWL)
	148350-101	BC-DB1-NBL6
	147790-001	BC-DBM(1)
	151845-101	BC-DBM(1)-NBL1
	S24904-201	BC-HTH(HPNG)
	S50237-001	BC-DP800
	S00691-401	BC-HST(B1)
	107097-101	BC-DP2(3B)
	159157-001	BC-DP815
	S01870-001	BC-DP815(P)
	S00690-301	BC-HST(A1)
	151041-001	CP-12C
	155476-001	CP-12MC(1)
	S07740-001	CP-G12L(1)
	S07741-001	CP-G12C
	S07742-001	CP-G12CTR1
	S09278-001	CP-G12M(BR)TR
	S09279-001	CP-G12MC(1)
	S09280-001	CP-G12MC(1)TR
	XC7206-001	BC-HR5-NBL9

Page 61 — BROTHER

Hirose Hook Catalog parts on page 61
Ref	Part number	Part name	Qty
	SA1718-001	HTH-BTR(NG23)
	SA1706-001	HSH-7.94B(RT)
	SA1708-001	HSH-7.94BOH(1)
	SA1391-002	HSH-7.94BTR(737)
	SA1704-001	HSH-7.94BOHNTR(B)
	SA1709-001	HSH-7.94BTR(737SPQ)
	SA1391-002	HSH-7.94BTR(737)
	SA1704-001	HSH-7.94BOHNTR(B)
	SA1723-001	HSM-B1H(1)
	SA1706-001	HSH-7.94B(RT)
	SA1391-002	HSH-7.94BTR(737)
	SA1722-001	HSM-B1HTR
	SA1722-001	HSM-B1HTR
	SA1715-001	HSH-7.94DRN(1)
	SA1715-001	HSH-7.94DTR(1Q)
	SA1668-111	HR12-15L
	SA1669-111	HR12-15L(H)
	SA1668-111	HR12-15L
	SA1668-111	HR12-15L
	SA1668-111	HR12-15L
	SA1668-111	HR12-15L
	SA1670-111	HR12L(1)
	SA1669-111	HR12-15L(H)
	SA1668-111	HR12-15L
	SA1668-111	HR12-15L
	SA1677-111	HR12-15L(TR1)
	SA1678 111	HR12L(1)TR1
	SA1677-111	HR12-15L(TR1)
	SA1677-111	HR12-15L(TR1)
	SA1681-111	HR12-15LC
	SA1681-111	HR12-15LC
	SA1681-111	HR12-15LC
	SA1683-111	HR12-15LCTR1
	SA1683-111	HR12-15LCTR1
	SA1683-111	HR12-15LCTR1
	SA1685-102	HR12M(BR)
	SA1685-102	HR12M(BR)
	SA1689-102	HR12MC(1)TR
	SA1689-102	HR12MC(1)TR
	SA1692-102	HR12MC(1)
	SA1692-102	HR12MC(1)
	SA1694-102	HR12MC(1)TR
	SA1694-102	HR12MC(1)TR
	SA1668-111	HR12-15L
	SA1669-111	HR12-15L(H)
	SA1668-111	HR12-15L
	SA1670-011	HR12-15L(TR1)
	SA1670-011	HR12-15L(TR1)
	SA1677-111	HR12-15L(TR1)
	SA1678 111	HR12L(1)TR1

Page 62 — BROTHER

Hirose Hook Catalog parts on page 62
Ref	Part number	Part name	Qty
	SA1681-111	HR12-15LC
	SA1681-111	HR12-15LC
	SA1683-111	HR12-15LCTR1
	SA1683-111	HR12-15LCTR1
	SA1683-111	HR12-15LCTR1
	SA1685-102	HR12M(BR)
	SA1685-102	HR12M(BR)
	SA1689-102	HR12MC(1)TR
	SA1689-102	HR12MC(1)TR
	SA1692-102	HR12MC(1)
	SA1692-102	HR12MC(1)
	112041-901	DB1-Z16B
	SA1852-001	DP2-855
	SA1853-001	DP2-856TR
	SA1852-001	DP2-855
	SA1853-001	DP2-856TR

Page 63 — DURKOPP / ADLER (ADLER)

Hirose Hook Catalog parts on page 63
Ref	Part number	Part name	Qty
	DD1(AD)
	DD1(AD)
	HWG-1
	HSH-7-3
	HSH-7-3
	HWG-1
	TF1
	HWG-1
	HWG-1
	HAD-68
	HAD-68
	HPF-335(5)
	DP2
	DA1-B
	DP2
	DD1-OP(2)
	DD1-OP(2)
	DD1(AD)
	DD1-OP(2)
	HAD-167
	HAD-167
	HAD-167TR
	HAD-167TR
	HAD-167TR
	HAD-196B
	DB1-Z16
	HAD-204
	HAD-204
	HSH-445
	HSH-32
	HAD-167
	HAD-167TR
	HAD-167
	HAD-267TR
	DB1-Z16
	HAD-396
	HAD-396
	HAD-396H
	HAD-467TR
	DB1-Z16

Page 64 — DURKOPP / ADLER (DURKOPP)

Hirose Hook Catalog parts on page 64
Ref	Part number	Part name	Qty
	L-97(Hook) 6-11 (Base)	HWG-1
	065-00-185-4	DD1-OP(2)
	065-00-185-4	DD1-OP(2)
	204325	DA2-B(TA1-B)
	204325	DA2-B(TA1-B)
	204325	DA2-B(TA1-B)
	204695	DA1-B
	204695	DA1-B
	211261	HDU-211
	211912	HDU-211(1)
	211261	HDU-211
	211261	HDU-211
	211261	HDU-211
	216161	HDU-216
	211261	HDU-211
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	252781	DP2
	252781	DP2
	252781	DP2
	252781	DP2
	211912	HDU-211(1)
	252781	DP2
	265951	HDU-265
	265771	HDU-M265
	204695	DA1-B
	271751	HDU-271
	0271150054	HDU-271(QRP)
	2721121	HDU-272
	249592	HDU-249
	0381150204	HDU-381(RP)
	460243	HSH-8-20
	460312	HSH-8-20(S)
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	249592	HDU-249
	555901	HDU-551
	555901	HDU-551
	5565001	HDU-556

Page 65

Hirose Hook Catalog parts on page 65
Ref	Part number	Part name	Qty
	ESMPZ00050	HSH-7.94A(M3Q)
	ESMPZ01260	HSH-7.94A(M3QTS)
	ESHSA04010	HSH-7.94ATR(M3Q)
	ESMPZ00050	HSH-7.94A(M3Q)
	ESMPZ01260	HSH-7.94A(M3QTS)
	ESHSA04010	HSH-7.94ATR(M3Q)
	ESHSA04010	HSH-7.94ATR(M3Q)
	ESHSA04010	HSH-7.94ATR(M3Q)
	701-505-004	HSH-7.94B
	701-505-004	HSH-7.94B
	701-505-004	HSH-7.94B
	701-505-004	HSH-7.94B
	703-504-009	HSH-7.94A
	703-504-009	HSH-7.94A
	701-505-004	HSH-7.94B
	701-505-004	HSH-7.94B
	761-510-008	DA1-B
	761-510-008	DA1-B
	761-510-008	DA1-B

Page 66

Hirose Hook Catalog parts on page 66
Ref	Part number	Part name	Qty
	G18301160B0	CP-21(2)
	16421760	CP-12(570TC)
	16421760	CP-12(570TC)
	25443953	CP-12(570TC)
	G181487000A	UNAVAILABLE
	G181487000A	BC-HTH(2E)
	G1814875AA0	BC-HTH(2E)
	G1814875AA0	BC-HTH(2E)
	G1814875AB	UNAVAILABLE
	G18148800AB	BC-DB1
	B18300120A0	BC-DB1
	B18300090A0	BC-DB1
	B18301270A0	BC-DB1
	B18302010A0	BC-DBM(1)
	B1830201HA0	BC-DBM(1)
	B1830201SA0	BC-DBM(1)
	11038650	BC-DB1-NBL7
	11092459	BC-DB1-NBL7
	B18301270A0	BC-DB1
	B18301270A0	BC-DB1
	11092251	BC-DB1-NBL7
	D1830555BAG	BC-DB1-NBL6
	11038650	BC-DB1-NBL6
	D1830555BA0	BC-DB1-NBL6
	11038650	BC-DB1-NBL6
	11079456	BC-DB1-NBL6
	11038650	BC-DB1-NBL6
	11038650	BC-DB1-NBL6
	D1830415BAH	BC-DLN-NBL
	11038650	BC-DB1-NBL6
	B18302010A0	BC-DBM(1)-NBL1
	D1830560EA0	BC-DBM(1)-NBL1
	B18302010A0	BC-DBM(1)-NBL1
	D1830560EA0	BC-DBM(1)-NBL1
	11038650	BC-DB1-NBL6
	22890206	BC-DB1-NBL7
	22890305	BC-DB1-NBL7
	11092251	BC-DB1-NBL7
	11038650	BC-DB1-NBL7
	11141355	BC-DB1-NBL6
	23621303	BC-DB1
	B18301270A0	BC-DB1
	B18301270A0	BC-DB1-NBL6
	11038650	BC-DB1-NBL6
	11141355	BC-DB1
	B18301270A0	BC-DB1

Page 67 — JUKI

Hirose Hook Catalog parts on page 67
Ref	Part number	Part name
31	B18370120A0	BC-DB1
32	B1837555BAA	BC-DB1-NBL6
32	B18370410A0	BC-DLN
32	B1837415DAL	BC-DLN-NBL
32	11038759	BC-DB1-NBL7
34	40003895	BC-HTH(2EA)
35	B18372010A0	BC-DBM(1)
36	B1837241H00	BC-DBM(2)-NBL1
42	B18087710A0	DP2-NJ771
42	13729769	BC-LBH790
42	B18107610A0	BC-107(2)
42	B18107710A0	BC-LBH771
45	10110252	CP-12(2)
	B18301270A0	HSH-7.94B
	B18301270A0	HSH-7.94B
	11038650	HSH-7.94BTR
	11141355	HSH-7.94BTR(QSP)
	11038650	HSH-7.94BTR
	11141355	HSH-7.94BTR(QSP)
	B18304120A0	HSH-7.94DN
	B18304150A0	HSH-7.94BSN
	B1830415BAH	HSH-7.94BOHNTR
	B1830415LA0	HSH-7.94BOHN(1)
	B18304150A0	HSH-7.94BSN
	11038650	HSH-7.94BTR
	11321452	HSH-7.94BKTR(2)
	D1830560EA0	HSM-B1HTR(2)
	40003894	HTH-614BTR(2E)
	11092251	HSH-7.94BTR(SPH)
	11038650	HSH-7.94BTR
	11141355	HSH-7.94BTR(QSP)
	B18301270A0	HSH-7.94B
	11038650	HSH-7.94BTR
	11038650	HSH-7.94BTR
	11038650	HSH-7.94BTR
	11141355	HSH-7.94BTR(QSP)
	B1830241HA0	HSM-A1TR(280)
	B1830241HA0	HSM-A1TR(280)
	B1830241HA0	HSM-A1TR(280)
	B1830241SA0	HSM-A(6)
	B1830241HA0	HSM-A1TR(280)
	B1830241HA0	HSM-A1TR(280)
	B1830201SA0	HSM-A1SH
	D1830560EA0	HSM-B1HTR(2)
	D1830560EA0	HSM-B1HTR(2)
	B1830141HA0	HSM-A1
	B1830141HA0	HSM-A1
	13729066	DP2-NJ(790)
	13729066	DP2-NJ(790)
	13782065	DP2-NJ(791K)
	B18017610A0	DP2-NJ
	B18087710AC	DP2-NJ771
	B18087710AC	DP2-NJ771
	13729066	DP2-NJ(790)
	13729066	DP2-NJ(790)
	B1830057SA0	HSH-445(6SP)
	B1830057SA0	HSH-445(6SP)
	B1830057SA0	HSH-445(6SP)
	10110153	HSH-12(2)
	10197655	HSH-12-15(2)
	10110054	HSH-12(2)TR

Page 68 — JUKI

Hirose Hook Catalog parts on page 68
Ref	Part number	Part name	Qty
	10195154	HSH-12-15(2)TR
	10207959	HSH-12-62C(L)
	10208056	HSH-12-62C(R)
	10207751	HSH-12-62CTR(L)
	10207850	HSH-12-62CTR(R)
	10232957	HSH-12M-82C(L)
	10233054	HSH-12M-82C(R)
	10231058	HSH-12M-82CTR(L)
	10331157	HSH-12M-82CTR(R)
	22612055	H12-15L
	22612055	H12-15L
	23209455	H12-15L(TR2AE)
	22612055	H12-15L
	22612758	H12L(1)
	22653158	H12-15L(TR2)
	22653059	H12-15LCTR2
	22693857	H12-15LCTR2
	22688253	H12-15LC
	22693857	H12-15LCTR2
	22813455	H12MM(2)
	22814255	H12MC(2)
	22831259	H12MC(2)TR
	22820666	H12MM(2)TR
	22827158	H12MC(2)
	22831259	H12MC(2)TR
	B18305120A0	HSH-21-40(J)
	B18305120AH	HSH-21-40(AJ)
	G18301190A0	HSH-11-55M(2)
	B18305210A0	HSH-12MC(2)
	B18305280A0	HSH-21-40(2)
	G18301190A0	HSH-11-55M(2)
	16421760	HSH-12(570)
	14436158	HST-A(HPD)
	14436307	HST-A(HPQC)
	14436554	HST-B1(HPA)
	14436703	HST-B1(HPQB)
	21431358	HYM-1341BY
	21431457	HYM-1341BY(6)
	21435458	HYM-1341AY(6)
	21441753	HYM-1341BTR(6)
	21435854	HYM-1341ATR(6)
	23102353	HYM-341TR
	B18300590A0	HSH-445-59
	B1830563BA0	HSH-12-15MMJ(A)
	B18305630A0	HSH-12-15MMJ
	B18305630A0	HSH-12-15MMJ
	21387055	HSH-12MMA(6)TR
	21393756	HSH-12MMJ(6)TR
	B18305630A0	HSH-12-15MMJ
	21387055	HSH-12MMA(6)TR

Page 69 — JUKI

Hirose Hook Catalog parts on page 69
Ref	Part number	Part name	Qty
	B18305210A0	HSH-12MCA(2)
	10761252	HAD-467TR(6A)
	10756757	HAD-M467TR(6)
	10761252	HAD-467TR(6A)
	10761252	HAD-467TR(6A)
	10756757	HAD-M467TR(6)
	10761252	HAD-467TR(6A)
	B18305630A0	HSH-12-15MMJ
	B1830563BA0	HSH-12-15MMJ(A)
	B1830521HA0	HSH-12MCA(2)
	B18305210A0	HSH-12MC(2)
	10032555	DP2-57(3LP)
	22525059	DP2-57(3LP2R)
	22525877	DP2-57(3LP2V)
	22526677	DP2-57(3LP2VRP)
	22526578	DP2-57(3LP2VRP)
	22525059	DP2-57(3LP2R)
	23557259	DP2-57(3LP2VRPW)
	23557259	DP2-57(3LP2VRPW)
	23557259	DP2-57(3LP2VRPW)
	23557259	DP2-57(3LP2VRPW)
	23557259	DP2-57(3LP2VRPW)
	23557259	DP2-57(3LP2VRPW)
	22525877	DP2-57(3LP2V)
	22525877	DP2-57(3LP2V)
	22525877	DP2-57(3LP2V)
	22525877	DP2-57(3LP2V)
	22525877	DP2-57(3LP2V)
	22525877	DP2-57(3LP2V)
	22525877	DP2-57(3LP2V)
	22525877	DP2-57(3LP2V)
	B18300270A0	DB1-Z16
	B18300270A0	DB1-Z16
	B18307100A0	DB1-Z710
	B18307100A0	DB1-Z710
	B1830581BA0	HSH-7.24BJZ
	B1239372000	L-BQ1U
	23039159	HAD-161(6)
	23025059	HAD-160TR(6)
	23026057	HAD-166BTR
	23039159	HAD-161(6)
	23025059	HAD-160TR(6)
	23027568	HAD-166TR
	23028053	HAD-160(6)
	23029051	HAD-160(6)
	23039159	HAD-161(6)
	23044159	HAD-68(6)
	23058555	HAD-160(1341A)
	21010251	HSH-31(6)
	21010251	HSH-31(6)

Page 70 — JUKI / MAMMUT / MARCO

Hirose Hook Catalog parts on page 70
Ref	Part number	Part name	Qty
	21010251	HSH-31(6)
	21010251	HSH-31(6)
	21041850	HAD-204(273)
	21041850	HAD-204(273)
	21041850	HAD-204(273)
	21041850	HAD-204(273)
	21041850	HAD-204(273)
	21041850	HAD-204(273)
	21041850	HAD-204(273)
	HMU-1	HMU-1
	HMU-2	HMU-2
	HMA-1	HMA-1

Page 71 — MITSUBISHI

Hirose Hook Catalog parts on page 71
Ref	Part number	Part name	Qty
	P975003X01	HSH-32
	A190D302P01	HSH-7.94A(3)
	A190D305P01	HSM-AM(3)
	A190D522P01	HSM-A1HMTR
	A190D359P02	HSH-7.94BTR
	A190D359P02	HSH-7.94BTR
	A190D305P01	HSM-AM(3)
	A190D305P01	HSM-AM(3)
	A190D305P01	HSM-AM(3)
	A190D302P01	HSH-7.94A(3)
	A190D302P01	HSH-7.94A(3)
	P975007X01	HSH-7.94B
	P975007X01	HSH-7.94B
	P975025X02	HSH-7.94BOHNTR
	A190D359P02	HSH-7.94BTR
	A190D359P02	HSH-7.94BTR
	A190D359P02	HSH-7.94BTR
	A190D359P02	HSH-7.94BTR
	A190D223P01	HSH-7.94BTR(210)
	A190D223P01	HSH-7.94BTR(210)
	A190D111P01	HSH-12-15MM
	A190D110P01	HSH-12-15M
	A190D298P01	HSH-12-15MM(3)TR
	A190D434P01	HSH-12-15MTR(3)
	A190D434P01	HSH-12-15MTR(3)
	P975042X02	HSH-12MC
	P975041X01	HSH-12C
	A190D091P01	HSH-12MC(3)
	A190D071P01	HSH-12-15M(3)
	A190D071P01	HSH-12-15M(3)
	P975012X01	DA1-B
	P975019X01	HPF-190
	P975034X01	HSH-12-15MM(V)
	A190D571P01	HSH-12-15MM(410M2)
	P975034X02	HSH-12-15MM(V)
	A190D090P01	HSH-12M(3)
	A190D090P01	HSH-12M(3)
	A190D097P01	HSH-12MA(3)
	A190D571P01	HSH-12-15MM(410M2)
	P975034X01	HSH-12-15MM(V)
	P975034X01	HSH-12-15MM(V)
	A190D571P01	HSH-12-15MM(410M2)
	A190D571P01	HSH-12-15MM(410M2)
	A190D571P01	HSH-12-15MM(410M2)
	A190D571P01	HSH-12-15MM(410M2)
	A190D571P01	HSH-12-15MM(410M2)
	P976009X01	MF10E0125
	P976015X01	MF25E0125
	A190D175P01	MG44E0125
	P976006X02	MF40E0125
	A190D222P01	MN35A0125
	MN26A0125	CP-12MC
	MN27A0125	CP-12C
	MN62A0125	CP-12MC(3)
	MN60A0125	CP-12C
	MN50E0125	CP-12(3)
	CP-HPF190	CP-HPF190
	MN52E0125	CP-12M(230)

Page 72 — MITSUBISHI

Hirose Hook Catalog parts on page 72
Ref	Part number	Part name	Qty
	HSM-A1HMTR
	HSM-A1HTR(T)
	HSM-A1HMTR
	DA1-A
	HSM-AM(3)
	HSH-12MC
	HSH-12MC(3)
	HSH-12MC(3)
	HSH-12MC(3)
	HSH-12MC(3)
	HSH-12MC(3)
	HSH-12MC(3)
	HSM-A1HMTR
	HSM-A1HMTR
	HSM-A1HMTR
	HSM-A1HMTR
	HAD-204(273M)
	HSH-33(3)SF
	HSH-12MC(3)
	HSH-12MC(3)
	HSH-12MC(3)
	A190D522P01	MG44B0120
	P975001X01	MF65B0120
	P975033X01	MF65B0120
	E000056H01	MN26B0120

Page 73

Hirose Hook Catalog parts on page 73
Part number	Part name	Qty
522514	DA1-B
522514	DA1-B
522514	DA1-B
522514	DA1-B
522514	DA1-B
121524-4	HNE-835
121524-4	HNE-835
121524-4	HNE-835
121524-4	HNE-835
121524-4	HNE-835
121524-4	HNE-835
121524-4	HNE-835
121524-4	HNE-835
522514	DA1-B
522514	DA1-B
522514	DA1-B
522514	DA1-B
HSM-B(IE)	HSM-B(IE)
179077000009	DP2	41
179077000009	DP2	41
179077000009	DP2	41

Page 74 — PFAFF

Hirose Hook Catalog parts on page 74
Ref	Part number	Part name
	91-004317-91	HPF-28
	91-004317-91	HPF-28
	91-005870-91	HPF-70
42	91-008250-91	HPF-3114
42	91-008243-91	BC-PF3114
42	91-008250-91	HPF-3114
42	91-008243-91	BC-PF3114
42	91-008250-91	HPF-3114
42	91-008243-91	BC-PF3114
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
39	HPF-230(W)	HPF-230(W)
39	91-064662-91	HPF-238
39	91-009076-91	BC-PF9076(14)
39	91-009246-91	HPF-134
39	91-009076-91	BC-PF9076
39	91-009246-91	HPF-134
39	91-009076-91	BC-PF9076
39	91-105490-91	HPF-335
39	91-009076-91	BC-PF9076
39	HPF-230(W)	HPF-230(W)
39	91-064662-91	HPF-238
39	91-009076-91	BC-PF9076
	91-010896-91	HPF-144
	91-010159-91	CP-HPF151
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
	91-010850-91	HPF-145
	91-010159-91	CP-HPF151
	91-010896-91	HPF-144
	91-010159-91	CP-HPF151
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
	91-010850-91	HPF-145
	91-010159-91	CP-HPF151
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
	91-113414-91	HPF-151TR
	91-140650-91	CP-HPF151TR
	91-113414-91	HPF-151TR
	91-140650-91	CP-HPF151TR
	91-113414-91	HPF-151TR
	91-140650-91	CP-HPF151TR
	91-113414-91	HPF-151TR
	91-140650-91	CP-HPF151TR
	91-113192-91	HPF-144TR
	91-113192-91	CP-HPF144TR
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
43	91-010165-91	HPF-151
43	91-010159-91	CP-HPF151
	91-015023-91	HPF-190
39	91-064662-91	HPF-238
39	91-009076-91	BC-PF9076
39	91-063090-91	HPF-234
39	91-009076-91	BC-PF9076
39	91-105490-91	HPF-335
39	91-009076-91	BC-PF9076
39	91-064661-91	HPF-238
39	91-009076-91	BC-PF9076
39	91-105490-91	HPF-335
39	91-009076-91	BC-PF9076
39	91-105490-91	HPF-335
39	91-009076-91	BC-PF9076
39	91-105490-91	HPF-335
39	91-009076-91	BC-PF9076
39	91-105490-91	HPF-335
39	91-009076-91	BC-PF9076
	91-014192-91	HPF-345
	91-010159-91	CP-HPF151
	91-014192-91	HPF-345
	91-010159-91	CP-HPF151
	HPF-390	HPF-390
35	91-168888-91	HPF-418
35	91-168628-91	BC-PF418
35	91-168888-91	HPF-418
35	91-168628-91	BC-PF418
39	91-168885-91	HPF-438
39	91-009076-91	BC-PF9076
39	HPF-438(CR)	HPF-438(CR)
39	91-009076-91	BC-PF9076

Page 75 — SEIKO

Hirose Hook Catalog parts on page 75
Ref	Part number	Part name	Qty
	994485
	994485
	28837C
	28091C
	2530
	13086
	18849
	19985
	13719
	13719
	15040
	15040
	15040
	15040
	15502
	15502
	15040
	15502
	15040
	12032
	12032
	12032
	12530
	12530
	12530
	12530
	12530
	12530
	17033
	17033
	15040
	15850
	15040
	15040
	15040
	15850
	15040
	15255
	15255
	15040
	15040
	15040
	15040
	15040
	15040
	15040
	15040

Page 76 — SEIKO

Hirose Hook Catalog parts on page 76
Ref	Part number	Part name	Qty
	15040	HSH-12-15MM(5)
	15040	HSH-12-15MM(5)
	15040	HSH-12-15MM(5)
	15040	HSH-12-15MM(5)
	15040	HSH-12-15MM(5)
	15850	HSH-12MC(5)
	15502	HSH-12-15MMB(5)
	16407	HSH-12MCA(5)
	15502	HSH-12-15MMB(5)
	15502	HSH-12-15MMB(5)
	16407	HSH-12MCA(5)
	15502	HSH-12-15MMB(5)
	11124	HSH-12-15L
	11124	HSH-12-15L
	16291	HSH-12-15LC
	15502	HSH-12-15MMB(5)
	11124	HSH-12-15L
	18849	HSM-A
	12032	HSH-31(12)
	12032	HSH-31(12)
	12032	HSH-31(12)
	12032	HSH-31(12)
	12530	HSH-31(B12)
	12530	HSH-31(B12)
	12530	HSH-31(B12)
	37256	HPF-490(A)
	37735	HPF-490(5)TR
	37735	HPF-490(5)TR
	37735	HPF-490(5)TR
	37255	HPF-490
	1343	HSH-32
	1526	HSH-32(26)
	1526	HSH-32(26)
	35222	HSH-7-3
	18033	HSM-A(5)
	10655	HSH-11-55
	10655	HSH-11-55
	10655	HSH-11-55
	10945	HSH-11-55B
	10655	HSH-11-55
	10945	HSH-11-55B
	10655	HSH-11-55
	10945	HSH-11-55B
	10945	HSH-11-55B
	10945	HSH-11-55B
	8028	TF1
	8028	TF1
	28837C	HAD-204
	CP-HPF151	HPF-490(A)
	CP-HPF144TR	HPF-490(5)TR

Page 77 — SINGER

Hirose Hook Catalog parts on page 77
Ref	Part number	Part name	Qty
	547772	TF1
	32389	HSH-7.94B(281)
	143342	HSH-7.94C
	149173	HSH-7.94B(AC)
	545991	HSH-7.94B(391)
	143342FG	HSH-7.94B
	143342FG	HSH-7.94BN
	143342LS	HSH-7.94CO
	143342SN	HSH-7.94C(L)
	143342SNS	HSH-7.94D
	143342TS	HSH-7.94C(TS)
	143342FG	HSH-7.94B
	239727	HSM-B(Q)TR
	174091	HSH-7.94B(660)
	513170	HSH-7.94B(7)
	58786	HSH-7-2
	58662(19568)	HSH-7-7R
	58665(19560)	HSH-7-7L
	14530/14528	HSH-1-1
	52089 (142020)	DA2-A (TA1-A)
	52089 (142020)	DA2-C (TA1-C)
	52089FG (142020FG)	DA2-B (TA1-B)
	224443	DP2-L(N)
	224459	DP2
	224459HSB	DP2-HSP
	224443	DP2-L(N)
	224459	DP2
	224459HSB	DP2-HSP
	224325	HSH-102
	224750	HSH-8-20
	244088	HSH-8-20(K)
	237796	HSH-10-100(A)
	237796FG	HSH-10-100
	237796	HSH-10-100(A)
	237796FG	HSH-10-100
	247675	HSH-19
	240207	HSH-11-53
	240240	HSH-11-51
	240207	HSH-11-53
	240558	HSH-11-55
	240558HP	HSH-11-55HP
	240091	HSH-12-15(A)
	34797	HSH-12-68
	240091	HSH-12-15(A)
	237204	HSH-12-15
	248463	HSH-12-40
	235797	HSH-18-4
	247675	HSH-19
	239727	HSM-B(Q)TR
	52089 (142020FG)	DA2-C (TA1-C)

Page 78 — SINGER

Hirose Hook Catalog parts on page 78
Ref	Part number	Part name	Qty
	239727
	236121
	238250
	244521
	236121
	103123
	103120
	240904
	264725
	264726
	34799
	249118
	264161
	34815
	264161
	34816
	264161
	224443
	265361
	265361HP
	265361
	265361HP
	224579
	224579
	238250
	238250
	264414
	264245
	546794
	547772
	414126
	414126
	414126
	174046
	174046
	541674
	541968
	410140
	410054
	410054
	510008
	CH319995
	244711
	244711HP
	240558
	240558HP
	244711
	244711
	244711HP

Page 79 — SINGER

Hirose Hook Catalog parts on page 79
Ref	Part number	Part name	Qty
	244711	HSH-21-40
	514200	HPF-545S
	34804	HSH-21-40TR
	514200	HPF-545S
	510008	HSH-12-15MM(S)
	34823	HSH-21-40TR(S)
	514200	HPF-545S
	510008	HSH-12-15MM(S)
	34823	HSH-21-40TR(S)
	514200	HPF-545S
	34823	HSH-21-40TR(S)
	514200	HPF-545S
	510008	HSH-12-15MM(S)
	244711	HSH-21-40
	34823	HSH-21-40TR(S)
	510008	HSH-12-15MM(S)
	244711	HSH-21-40
	244711	HSH-21-40
	244711HP	HSH-21-40(HP)
	240558	HSH-11-55
	240558HP	HSH-11-55HP
	244711	HSH-21-40
	244711HP	HSH-21-40(HP)
	240558	HSH-11-55
	240558HP	HSH-11-55HP
	510008	HSH-12-15MM(S)
	412307	HSH-12-15MMJ(A)
	510008	HSH-12-15MM(S)
	412307	HSH-12-15MMJ(A)
	244711	HSH-21-40
	244711HP	HSH-21-40(HP)
	240558	HSH-11-55
	240558HP	HSH-11-55HP
	510008	HSH-12-15MM(S)
	412307	HSH-12-15MMJ(A)
	240558	HSH-11-55
	240558HP	HSH-11-55HP
	CH319995	HSH-12-15M
	CH319995	HSH-12-15M
	281049	HSH-12-15MMB(5)S
	281049	HSH-12-15MMB(5)S
	34804	HSH-21-40TR
	244711HP	HSH-21-40(HP)
	267357	HSH-21-40
	34823	HSH-21-40TR(S)
	510008	HSH-12-15MM(S)
	514200	HPF-545S
	34823	HSH-21-40TR(S)
	514200	HPF-545S
	510008	HSH-12-15MM(S)

Page 80 — SINGER

Hirose Hook Catalog parts on page 80
Part number	Part name	Qty
34823	HSH-21-40TR(S)
514200	HPF-545S
510008	HSH-12-15MM(S)	48
267357	HSH-21-40	47
514200	HPF-545S
267357	HSH-21-40	47
412433	HSH-21-40(S)C	47
267357	HSH-21-40	47
514109	HSH-21-40TR	47
412433	HSH-21-40(S)C	47
412307	HSH-12-15MMJ(A)	49
416520	HSH-12-15MM(S)C	48
510008	HSH-12-15MM(S)	48
416520	HSH-12-15MM(S)C	48
267357	HSH-21-40	47
244711HP	HSH-21-40(HP)	47
203290	HSH-2-12	43
203804	HSH-22-21	43
237796	HSH-10-100(A)	43
237796FG	HSH-10-100	43
238250	HSH-31	43
414126	HSH-7.94B	31
414126	HSH-7.94B	31
230290	HSH-2-12	43
263464	HSH-36-2	44
263464	HSH-36-2	44
263464	HSH-36-2	44
241691	HSH-5-16(B)
107122	DP2-71	41
545991	HSH-7.94B(391)	31
545991	HSH-7.94B(391)	31
545990	HSH-7.94B(391)	31
143342	HSH-7.94C	33
143342FG	HSH-7.94B	31
143342FG	HSH-7.94BN	32
143342LS	HSH-7.94CO	33
143342SNS	HSH-7.94C(L)	33
143342TS	HSH-7.94D	34
143342TS	HSH-7.94C(TS)	33
414424	HSH-7.94A	31
554507	HSH-12-15M	46
282293	DP2-457U(T)	41
34822	DP2-57(2LP)	41
34822	DP2-57(2LPRP)	41
502718	DP2-57(2)	41
34802HP	DP2-457LHP	41
502718HP	DP2-457HP	41
502718RP	DP2-57(2RP)	41
417664	DP2-457UTT	502530
98622	DD1	51

Page 81 — SINGER

Hirose Hook Catalog parts on page 81
Ref	Part number	Part name	Qty
	98623	DD1-OP
	238250	HSH-31
	244521	HSH-31(B)
	414126	HSH-7.94B
	52237	BC-DB1
	414126	HSH-7.94B
	52237	BC-DB1
	540733	HSH-7.94BTR(491)
	52237NBL	BC-DB1-NBL6
	540733	HSH-7.94BTR(491)
	52237NBL	BC-DB1-NBL6
	540733	HSH-7.94BTR(491)
	52237NBL	BC-DB1-NBL6
	241691	HSH-5-16(B)
	CP-18
	264161	HSH-5-16
	241676	CP-18
	264161	HSH-5-16
	241676	CP-18
	238250	HSH-31
	414070	HSH-7.94BTR(591B)
	52237NBL	BC-DB1-NBL6
	543381	HSH-7.94B(KSN)
	52237NBL	BC-DB1-NBL6
	414070	HSH-7.94BTR(591B)
	52237NBL	BC-DB1-NBL6
	414070	HSH-7.94BTR(591B)
	52237NBL	BC-DB1-NBL6
	543381	HSH-7.94B(KSN)
	52237NBL	BC-DB1-NBL6
	543381	HSH-7.94B(KSN)
	52237NBL	BC-DB1-NBL6
	414070	HSH-7.94BTR(591B)
	52237NBL	BC-DB1-NBL6
	414070	HSH-7.94BTR(591B)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94B
	52237	BC-DB1
	414126	HSH-7.94B
	52237	BC-DB1
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	414126	HSH-7.94B
	52237	BC-DB1
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	414126	HSH-7.94B
	52237	BC-DB1
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94B(KSN)
	52237NBL	BC-DB1-NBL6
	543381	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	414126	HSH-7.94B
	52237	BC-DB1
	414430	HSH-7.94BTR(591DT)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	544784	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	143342FG	HSH-7.94BTR
	52237	BC-DB1
	414430(544784)	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	414430(544784)	HSH-7.94BTR(591D)
	52237NBL	BC-DB1-NBL6
	368132	HSH-7.94BTR
	52237	BC-DB1
	58669	HSH-7-3
	52089 (142020)	DA2-A(TA1-A)
	52237	BC-DB1
	52089 (142020)	DA2-B(TA1-B)
	52237	BC-DB1
	52089FG (142020FG)	DA2-C(TA1-C)
	52237	BC-DB1
	127119	DA1-A
	52237	BC-DB1
	127119	DA1-C
	52237	BC-DB1
	127119FG	DA1-B
	52237	BC-DB1

Page 82 — STAGER

Hirose Hook Catalog parts on page 82
Ref	Part number	Part name	Qty
	SE-12	DB1-Z16
	SZ-21-1N	DB1-Z16
	SZ-21-2N	DB1-Z16
	SZ-21-3N	DB1-Z16
	SZ-21-4N	DB1-Z16
	SZ-21-5N	DBM-A(Z14)
	SZ-21-1BN	DBM-A(Z14)
	SZ-21-1BNL	DBM-A(Z14)
	SZ-21-3BNL	DBM-A(Z14)
	SZ-21-4BNL	DBM-A(Z14)
	SZ-21-5N	DBM-A(Z14)
	SZ21-5-3N	DBM-A(Z14)
	SZ21-5-4N	DBM-A(Z14)
	SZ21-5-5WN	DBM-A(Z14)
	SZ-21-5NL	DBM-A(Z14)
	SZ-21-5-3NL	DBM-A(Z14)
	SZ-21-5-4NL	DBM-A(Z14)
	SZ-25N	DB1-Z16
	SZ-72N	DB1-Z16
	SZ-72N-8N	DB1-Z16
	SZ-310-1N	DP2-57(2LPA)
	SZ-310-3N	DP2-57(2LPA)
	SZ-310-4N	DP2-57(2LPA)
	SZ-310-5-1N	DP2-57(2LPA)
	SZ-310-5-3N	DP2-57(2LPA)
	SZ-310-5-4N	DP2-57(2LPA)
	SZ-310-5-1WN	DP2-57(2LPA)
	SZ-310-11N	DP2-57(2LPA)
	050210140016	HSL-ATR(MTQETA)
	050210150000	HSL-ATR(MTQEL)/TA
	05022006J016	HSM-ATR(MTQETA)
	050220080024	HSM-ATR(MTQETA)/TA
	05022009J016	HSM-ATR(MTQTA)
	050210160016	HSL-ATR(MTQTA)

Page 83 — TOYOTA

Hirose Hook Catalog parts on page 83
Ref	Part number	Part name	Qty
	2113004-310	HSH-7.94B
	2110904-310	HSH-7.94BOH(4)
	2120604-310	HSH-7.94B
	2110904-310	HSH-7.94BOH(4)
	2120604-310	HSH-7.94B
	2111104-310	HSH-7.94BTR
	2114304-310B	HSH-7.94BTR(4HP)
	2114314-310	HSH-7.94BTR(4RP)
	2123704-310A	HSH-12-15MMB(5)TR4
	2122314-310	HSM-A1HTR(4)
	2123704-310A	HSH-12-15MMB(5)TR4
	2121414-310A	HSH-12-15MM(5)SS
	2121414-310A	HSH-12-15MM(5)SS
	2123704-310A	HSH-12-15MMB(5)TR4
	2121414-310A	HSH-12-15MM(5)SS
	2121414-310A	HSH-12-15MM(5)SS
	2121604-310B	HSH-7.94BSN(4)
	2121614-310	HSH-7.94BOHMTR
	2121614-310	HSH-7.94BOHMTR
	2121604-310B	HSH-7.94BSN(4)
	2120604-310	HSH-7.94B
	2111104-310	HSH-7.94BTR
	2120604-310	HSH-7.94B
	2130504-310	DP2-57(T)
	2130504-310	DP2-57(T)
	2130704-310A	DP2-57(2LPTC)
	2130714-310	DP2-57(2LPTB)
	2140114-310	HSH-21-40(T)
	2120304-310B	HBM-B
	2130104-300B	HSM-B(Z17)
	2130104-300B	HSM-B(Z17)
	2130104-300B	HSM-B(Z17)
	2130104-300B	HSM-B(Z17)
	2130104-300B	HSM-B(Z17)
	BS-170	HLE-170
	BS-1700	HLE-170
	BS-170C	HLE-170
	BS-170J	HLE-170
	BS-170LA	HLE-170
	BS-170PB	HLE-170
	BS-170SF	HLE-170
	BS-171	HLE-170
	BS-172	HLE-170

Page 84 — UNION SPECIAL / YAMATO

Hirose Hook Catalog parts on page 84
Ref	Part number	Part name	Qty
	1040A-1L	HLE-16
	1040A-2L	HLE-16(170UN)
	906A-1L	HLE-30(UN)
	409-27-1	HLE-170
	61407BFG	HUN-614B
	61407BFGSN	HUN-614B(L)
	61407B	HUN-614C
	61407BSN	HUN-614C(L)
	61407BTS	HUN-614C(TS)
	29474AC	HUN-622
	29474AH	HTH-614BTR(QE)
	K74753	HTH-614BTR(1.7QE)
	75126	DP2
	76626	DP2(HS)
	75126	DP2
	76626	DP2(HS)
	77305	HDU-265Y
	77305	HDU-265Y
	77305	HDU-265Y
	77305	HDU-265Y
	4109300	L-BQ1U
	4109300	L-BQ1U
	Y5555332	DP2-457U(TAY)
	Y5555332	DP2-457U(TAY)
	Y5009300	DP2-57(2LPY)
	61413E	BC-UN614E
	BC-DB1	BC-DB1
	63913E	BC-HTH(E)-U
	75128	BC-DP2(2)
	77309	BC-HDU265
	BC-DP57	BC-DP57

Page 85 — BAOMA 宝马 / BUTTERFLY 蝴蝶

Hirose Hook Catalog parts on page 85
Part number	Part name	Qty
GC0378-1
HSH-32
GC128-M
HSH-7.94AO
HSH-7.94AOTR
HSH-7.94B
HSH-7.94BTR
HSH-31(12)
HSH-12-15MM
GC20508-C
HSH-12MC
HSH-12C
HSH-12-15MM(V)
HSH-12-15MM(V)
HSH-31(12)
GC2638-1
GC2638-2
HG128
HSH-7.94AO
HSH-7.94B
HSH-7.94B
HSH-7.94B
HSH-7.94B
DB1-Z16
DB1-Z16
HSH-7.94ATR(MTQ)
DP2-57(2)
DP2-NJ771
GC0318-1	HSH-7.94DRN
GC158-B	HSH-7.94AO	31
GC158-BD	HSH-7.94AOTR	31
GC158-M	HSH-7.94B	31
GC158-MD	HSH-31(12)	32
GC2018	HSH-31(12)	43
GC20508-M	HSH-12-15M	46
GC20538-C	HSH-12MO	50
GC20538-M	HSH-120	46
GC20608-1	HSH-12-15MM(V)	49
GC20608-2	HSH-12-15MM(V)	49
GC2318	HSH-31(12)	43
HG128-B	HSH-7.94AO	31
HG128-M	HSH-7.94B	31
GC25-1	HSH-7.94B	31
GC25-2	HSH-7.94B	31
GC2601	HSH-7.94B	31
GC57-1	DB1-Z16	38
GG2-1	DB1-Z16	38
GG305-1	HSH-7.94ATR(MTQ)	40
GG3-1	DP2-57(2)	41
GY4-1	DP2-NJ771	42

Page 86

Hirose Hook Catalog parts on page 86
Ref	Part number	Part name	Qty
	QJ2230B	HSH-12-15MM
	QJ2230M	HSH-12-15M
	QJ2250	HSH-12C
	CP-12C	CP-12C
	QJ2250B	HSH-12MC
	CP-12MC	CP-12MC
	QJ5200	HSH-7.94B
	BC-DB1	BC-DB1
	QJ5500	HSH-7.94B
	BC-DB1	BC-DB1
	QJ842-3	HG12-15L
	QJ842-5	HG12-15L(H)
	QJ845	HG12-15LC
	CP-G12C	CP-G12C
	QJ8700	HSH-7.94B
	BC-DB1	BC-DB1
	QJ872	HG12M(BR)
	QJ875	HG12MC(1)
	CP-G12MC(1)	CP-G12MC(1)
	QJ8900	HSH-7.94B
	BC-DB1	BC-DB1
	DB2-B111-3	HSH-7.94B
	BC-DB1	BC-DB1
	DB2-B111-5	HSH-7.94AO
	BC-DB1	BC-DB1
	LT2-B842-3	HG12-15L
	CP-G12C	CP-G12C
	LT2-B842-5	HG12-15L(H)
	CP-G12C	CP-G12C
	LT2-B845-3	HG12-15LC
	LT2-B845-5	HG12-15LC
	CP-G12MC(1)	CP-G12MC(1)
	LT2-B872-3	HG12M(BR)
	LT2-B872-5	HG12M(BR)
	LT2-B875-3	HG12MC(1)
	CP-G12MC(1)	CP-G12MC(1)
	LT2-B875-5	HG12MC(1)
	G18	DP2-NJ771
	BC-LBH771	BC-LBH771
	GC158-1	HSH-7.94B
	BC-DB1	BC-DB1
	GC1-6	HSH-7.94B
	BC-DB1	BC-DB1
	GC668-1	HSH-7.94B
	BC-DB1	BC-DB1
	GC668-28	HSH-7.94BOH
	BC-DB1	BC-DB1
	G0668-5	HSH-7.94BOH
	BC-DB1	BC-DB1
	GCL-5550N	HSH-7.94B
	BC-DB1	BC-DB1

Page 87

Hirose Hook Catalog parts on page 87
Ref	Part number	Part name	Qty
	GC1-5	DA1-B
	GC15-1	HSH-7.94B
	GC15-2	HSH-7.94B
	GC15-3	HSH-7.94BOH
	GC15-4	HSH-7.94B
	GC1-6	DA1-B
	GC28-1	HSH-7.94BOH
	GC28-3	HSH-7.94BOH
	GC290	HSH-7.94B
	GC5530	HSH-7.94B
	GC5550	HSH-7.94B
	GG28-1	DB1-Z16
	GG28-2	DB1-Z16
	GG28-3	DB1-Z16
	GG29-1	DB1-Z16
	GG30	DB1-Z16
	GC20502-4	HSH-12-15M
	GC20601	HSM-A
	GC51-1	HSH-7.94B
	GC9002	HSH-7.94B
	GC9002H	HSH-7.94AO
	GG0802	DB1-Z16
	GG302	DP2-57(2)
	KDD-5570	HSH-7.94B
	KDD-5570-7	HSH-7.94BTR
	KDD-5570H	HSH-7.94BOH
	KDD-5570H-7	HSH-7.94BOHN
	KDD-5570HB	HSM-A

Page 88 — GEMSY 宝石

Hirose Hook Catalog parts on page 88
Ref	Part number	Part name	Qty
	HSH-7.94B
	HG12-15L(TR1)
	HG12-15LC
	HG12M(BR)
	HG12MC(1)
	DP2-57(3LP2R)
	5550
	HSH-7.94B
	7080
	HSH-7.94B
	HSH-7.94B
	HSH-7.94B
	HSH-7.94B
	HSH-7.94B
	DP2-57(3LP2R)
	HSH-7.94BTR
	2000-1M
	HSH-12MC
	HSH-12C
	HSH-12-15MM
	HSH-7.94AO
	5590H
	HSH-7.94AO
	HSH-7.94AO
	HG12MC(1)TR
	HG12MC(1)TR
	HSH-7.94AO
	HSH-7.94BTR(10SPH)
	HSH-7.94BTR(RPW)
	HSH-7.94B
	GEM5550
	2284	DP2-57(3LP2R)
	7070	HSH-7.94B
	8500	HSH-7.94B
	8700	HSH-7.94B
	8900	HSH-7.94B
	2284-7	DP2-57(3LP2R)
	8900-7	HSH-7.94BTR
	2000-2B	HSH-12MC
	2000-2M	HSH-12C
	2001-1B	HSH-12-15MM
	7-18A	HSM-A
	7-28H	HSH-7.94AO
	8700H	HSH-7.94AO
	872-7	HG12MC(1)TR
	875-7	HG12MC(1)TR
	8900H	HSH-7.94AO
	8900H-7	HSH-7.94BTR(10SPH)
	9000W-7	HSH-7.94BTR(RPW)
	GEMS	HSH-7.94B

Page 89 — HIGHLEAD

Hirose Hook Catalog parts on page 89
Ref	Part number	Part name	Qty
	GC0318-1	HSM-A
	GC0318-8	HSM-A
	GC0388	HSM-A
	GC0388-D	HSM-A1HTR
	GC0518	HSH-7.94DRN
	GC0618	HSH-7.94BRNH
	GC0618-1	HSH-7.94BRNH
	GC128-B	HSM-A
	GC128-B-D3	HSM-A1HTR
	GC128-H	HSH-7.94A
	GC128-M	HSH-7.94B
	GC128-M-D3	HSH-7.94BTR(3)
	GC188-B	HSM-A
	GC188-H	HSH-7.94AO
	GC188-M	HSH-7.94B
	GC188-MC	HSH-7.94B
	GC20518-B	HSH-12MC
	GC20518-M	HSH-12-15M
	GC20518-M	HSH-12-15M
	GC20528-B	HSH-12-15MM
	GC20528-B-D	HSH-12MC(3)
	GC20528-M	HSH-12C
	GC20618-1	HSH-12-15MM(V)
	GC20618-1D	HSH-12-15MM(410)
	GC20618-2	HSH-12-15MM(V)
	GC24018	HSH-31(6)
	GC24018-1	HSH-31(6)
	GC24518-1	HSH-31(6)
	GC24518-2	HSH-31(6)
	GC24618	HPF-490(A)
	GC24618-1	HPF-490(A)
	GC6-28	HSH-7.94B

Page 90

Hirose Hook Catalog parts on page 90
Ref	Part number	Part name	Qty
	G16-1	DP2-NJ
	GC0301-1	HSH-7.94DRN
	GC10-1	HSH-7.94B
	GC10-1B	HSH-7.94B
	GC10-1H	HSH-7.94A
	GC10-1P	HSH-7.94A
	GC10-1S	HSH-7.94B
	GC20505-1	HG12L(1)
	GC20505-1	HG12L(1)
	GC24010-1	HSH-31(12)
	GC24011-1	HSH-31(12)
	GC24301-2	HPF-490(A)
	GC281	HSH-7.94B
	GC28-1	HSH-7.94B
	GC281B	HSH-7.94B
	GC281H	HSH-7.94B
	GC281P	HSH-7.94B
	GC281S	HSH-7.94B
	GC28-3	HSH-7.94B
	GC28-3B	HSH-7.94B
	GC28-3H	HSH-7.94B
	GC28-3P	HSH-7.94B
	GC28-3S	HSH-7.94B
	GC48-1	HSH-7.94B
	JK457	DP2-457U(T)
	JK781	DP2-NJ771
	JK5842-3	HG12-15L
	JK6318	HSM-A
	JK8500	HSH-7.94B
	JK8500H	HSH-7.94BOH
	JK5845-3	HG12-15L
	JK5845-5	HG12-15LCTR1
	JK5872-3	HG12M(BR)
	JK5872-5	HG12M(BR)TR
	JK5875-3	HG12MC(1)
	JK5875-5	HG12MC(1)TR
	JK8900D	HSH-7.94BTR
	JK5842-5	HSH-12-15L(TR1)
	JK5842D-3	HSH-12-15L(TR1)

Page 91

Hirose Hook Catalog parts on page 91
Ref	Part number	Part name	Qty
	212-18	HSM-A
	212-3	HSH-7.94B
	212-3B	HSH-7.94BOH
	212-5H	HSH-12-15M
	212-8	HSH-7.94B
	212-8B	HSH-7.94BOH
	212-9	HSH-7.94BOH
	G15-2	DB1-Z16
	GG70701	HSH-7.94A(MTQ)
	CDL-1388N	HSH-7.94A
	CDL-5550N	HSH-7.94B
	LT2-B842-3	HSH-12-15M
	LT2-B845-3	HSH-12-15MM
	LT2-B872	HSH-12-15M
	LT2-B875	HSH-12-15MM
	PM-780	DP2-NJ

Page 92

Hirose Hook Catalog parts on page 92
Ref	Part number	Part name	Qty
	CP-G12CTR(1)	TY-B872-5
	CP-G12MC(1)	TY-B875-5

Page 93 — SHANGGONG 上工

Hirose Hook Catalog parts on page 93
Ref	Part number	Part name	Qty
	HSH-7.94B
	DP2-NJ
	HSH-7.94DRN
	HSH-7.94DRN
	GC1-3
	HSH-7.94B
	HSH-7.94B
	HSH-7.94BOH
	HSH-7.94BOH
	HSH-21-40(J)
	HSH-7.94B
	HSH-7.94B
	HSH-7.94B
	HSH-7.94B
	HSH-7.94BTR
	HSH-7.94B
	HSH-7.94DRN
	HSH-7.94B
	HSH-7.94BTR
	HSH-7.94B
	HSH-12M-82CTR(L)
	HSH-12M-82CTR(R)
	HSH-12M-82CTR(L)
	HSH-12M-82CTR(R)
	HSH-12M-82CTR(L)
	HSH-12M-82CTR(R)
	HSH-21-40(J)
	HSH-21-40(J)
	DP2-NJ771
	HSH-7.94AO
	HSH-7.94ATR(MTQ)
	8800	HSH-7.94B
	GC0301	HSH-7.94DRN
	GC0601-1	HSH-7.94DRN
	GC15-1	HSH-7.94B
	GC15-2	HSH-7.94B
	GC15-3	HSH-7.94BOH
	GC15-4	HSH-7.94BOH
	GC15-5-4D	HSH-21-40(J)
	GC22	HSH-7.94B
	GC30-1	HSH-7.94B
	GC30-2	HSH-7.94B
	GC30-3	HSH-7.94B
	GC-30-4-5D	HSH-7.94BTR
	GC45-1	HSH-7.94B
	GC505-1	HSH-7.94DRN
	GC5550	HSH-7.94B
	GC555-4-5D	HSH-7.94BTR
	GD8-1	HSH-7.94B
	GD8-4	HSH-12M-82CTR(L)
	GD8-7	HSH-12M-82CTR(L)
	GF108	DP2-NJ771
	GG758-615	HSH-7.94AO
	GG758-920	HSH-7.94ATR(MTQ)

Page 94 — TYPICAL / TYPICAL BROTHER

Hirose Hook Catalog parts on page 94
Ref	Part number	Part name	Qty
	GC20201	HSH-12-15MM
	GC20202	HSH-12-15MM
	GC6-1	HSH-7.94B
	GC6100HD	HSH-7.94BOH(1)
	GC6160H	HSH-7.94BOH(1)
	GC6160MD3	HSH-7.94BTR(210)
	GC6-1-D3	HSH-7.94BTR(210)
	GC6220BD	HSH-12-15MM(3)TR
	GC6220MD	HSH-12-15MTR(3)
	GC6240B	HSH-12MC
	GC6240M	HSH-12C
	GC6240MD	HSH-12-15M(3)
	GC6-28	HSH-7.94B
	GC6-8	HSH-7.94AO
	GC6842H	HG12-15L(H)
	GC6842HD3	HG12L(1)TR1
	GC6842M	HG12-15L
	GC6842MD3	HG12L(1)TR1
	GC6845H	HG12-15LC
	GC6845HD3	HG12-15LCTR1
	GC6845MD3	HG12-15LCTR1
	GC6872H	HG12M(BR)
	GC6872M	HG12M(BR)
	GC6872MD3	HG12MC(1)TR
	GC6875H	HG12MC(1)
	GC6875HD3	HG12MC(1)TR
	GC6875M	HG12MC(1)
	GC6875MD3	HG12MC(1)TR
	GC6-8-D2	HSH-7.94BOH
	GC69-1	HSH-7.94B
	GC6-9-D2	HSM-A1HTR
	GG1-1	DB1-Z16
	GG1-2	DB1-Z16
	GYD12-6	HSH-7.94A(MTQ)
	GYD20-6	HSH-7.94A(MTQ)
	GYD7-6	HSH-7.94A(MTQ)
	DB2-C101-3	HSH-7.94B(RT)
	DB2-C101-5	HSH-7.94BOH(1)
	DB2-C101-6	HSH-7.94A
	DB2-C101-7	HSH-7.94A
	DB2-C201-1	HSH-7.94BTR(737SPQ)
	DB2-C201-3	HSH-7.94BTR(737)
	DB2-C201-5	HSH-7.94BOH

Page 95 — WANPING 苑坪

Hirose Hook Catalog parts on page 95
Ref	Part number	Part name	Qty
	HG12-15L(TR1)
	HG12-15LCTR1
	HG12MC(1)TR
	HG12MC(1)TR
	HPF-1242(A)
	HSH-7-3
	HSM-B1H
	HSM-B1H
	GC0302-D2
	HSH-7.94AO
	HSH-7.94B
	HSH-12-15MM(V)
	HSH-31(12)
	HPF-490(A)
	HPF-490(A)
	HSM-A1
	HSM-A1
	HSM-A1
	HSM-A1HTR
	HSM-A1HTR
	HPF-490(A)
	HSH-32
	HG12-15L
	HG12-15LC
	HG12M(BR)
	HG12MC(1)
	HAD-204(273)
	HPF-335(5)
	HYM-1341AY
	HAD-204(273)
	HAD-204(273)
	HSH-31(B)
	HPF-335
	HSH-31(12)
	HPF-490(A)
	HSH-7.94ATR(MTQ)
	HSH-7.94AOTR
	HSH-7.94AO
	1245	HPF-1242(A)
	733R	HSH-7-3
	GC0302	HSM-B1H
	GC203	HSH-7.94AO
	GC20606	HSH-12-15MM(V)
	GC24016	HSH-31(12)
	GC24660	HPF-490(A)
	GC24680	HPF-490(A)
	GC6-5	HSM-A1
	GC6-6	HSM-A1
	GC6-7	HSM-A1
	GN2301	HSM-A1HTR
	GN2603	HSM-A1HTR
	TW2-B845-5	HG12-15LC
	TW3-243	HAD-204(273)
	TW3-335V	HPF-335(5)
	TW3-341	HYM-1341AY
	TW3-441	HAD-204(273)
	TW3-471	HAD-204(273)
	TW3-P335	HPF-335
	TWB-22GW	HPF-490(A)
	GG798-1	HSH-7.94ATR(MTQ)
	GG798-2	HSH-7.94AOTR
	GG798-3	HSH-7.94AO

Page 96 — ZOJE 中捷

Hirose Hook Catalog parts on page 96
Ref	Part number	Part name	Qty
	HG12-15LC
	HG12M(BR)
	HG12MC(1)
	HG12-15L(H)
	HG12-15L(TR1)
	HG12-15LCTR1
	HG12MC(1)TR
	HG12MC(1)TR
	HSH-7.94B
	HSH-7.94B
	HSH-7.94BOH
	HSH-7.94B
	HSH-7.94BOH
	HSH-7.94B
	HSH-7.94BOH
	HSH-7.94B
	DP2-457U(T)
	DP2-457U(T)
	DP2-457U(T)
	HSH-7.94BTR
	HSH-7.94B
	DP2-457U(T)
	HSH-7.94B
	HSH-7.94B
	HSH-7.94BTR
	HSH-7.94BTR
	HSH-7.94BOH
	HSH-7.94BOH
	HG12-15L
	HSH-7.94BOH
	HSH-7.94B
	HSH-7.94BTR
	HSH-7.94B
	HSH-7.94B
	ZJ80-1
	842-5	HG12-15L(H)
	842-D3	HG12-15L(TR1)
	845-D3	HG12-15LCTR1
	872-D3	HG12MC(1)TR
	875-D3	HG12MC(1)TR
	GC15-1	HSH-7.94B
	GC5580	HSH-7.94B
	GC5580-5	HSH-7.94BOH
	GC80-1	HSH-7.94B
	GC80-5	HSH-7.94BOH
	GC90-1	HSH-7.94B
	GC90-5	HSH-7.94BOH
	GCZ201-1	HSH-7.94B
	GG457	DP2-457U(T)
	ZJ457A135	DP2-457U(T)
	ZJ457A143	DP2-457U(T)
	ZJ5580-D3	HSH-7.94BTR
	ZJ15-1	HSH-7.94B
	ZJ457A125/105	DP2-457U(T)
	ZJ5550	HSH-7.94B
	ZJ5580	HSH-7.94B
	ZJ5580-5-D3	HSH-7.94BTR
	ZJ5600N	HSH-7.94BOH
	ZJ5580-5	HSH-7.94BOH
	ZJ842	HG12-15L
	ZJ8500-5	HSH-7.94BOH
	ZJ8500N	HSH-7.94B
	ZJ8850-5-D3	HSH-7.94BTR
	ZJ90-1	HSH-7.94B
	ZJ999	HSH-7.94B

Page 97 — SUNSTAR

Hirose Hook Catalog parts on page 97
Ref	Part number	Part name	Qty
	DP2-800FR	DP2-800FR
	DP2	DP2
	DB1-Z16	DB1-Z16
	HAD-467TR(1B)	HAD-467TR(1B)
	HAD-467CTR(SU)	HAD-467CTR(SU)
	CP-HAD467TR	CP-HAD467TR
	HSH-7.94B	HSH-7.94B
	BC-DB1	BC-DB1
	HSH-7.94BOH	HSH-7.94BOH
	BC-DB1	BC-DB1
	HSH-B(1SU)	HSH-B(1SU)
	BC-DBM(1)	BC-DBM(1)
	DP2-855	DP2-855
	BC-DP855	BC-DP855
	DP2-856TR	DP2-856TR
	BC-DP856	BC-DP856
	HSH-7.94BTR	HSH-7.94BTR
	BC-DB1-NBL6	BC-DB1-NBL6
	HSH-7.94BOHNTR	HSH-7.94BOHNTR
	BC-DLN-NBL	BC-DLN-NBL
	HSH-7.94BTR(P)	HSH-7.94BTR(P)
	BC-DB1-NBL6	BC-DB1-NBL6
	HSH-7.94BSN	HSH-7.94BSN
	BC-DLN	BC-DLN
	HSH-7.94BTR(N)	HSH-7.94BTR(N)
	BC-DLN(NBL)	BC-DLN(NBL)
	HSH-7.94BOHN(1)	HSH-7.94BOHN(1)
	BC-DB1	BC-DB1
	DA1-BTR	DA1-BTR
	BC-NJ(380)	BC-NJ(380)
	HSH-B(SU)	HSH-B(SU)
	BC-DBM(1)	BC-DBM(1)
	HSH-31MMB(5)	HSH-31MMB(5)
	HSH-12-15MM(5)	HSH-12-15MM(5)
	HSH-12-15MMB(5)TR4	HSH-12-15MMB(5)TR4
	HSM-A1TR(280)	HSM-A1TR(280)
	BC-NJ280L-NBL3	BC-NJ280L-NBL3
	HSM-A(3)	HSM-A(3)
	BC-DBM(1)	BC-DBM(1)
	HSM-A1HTR	HSM-A1HTR
	BC-DBM(1)-NBL	BC-DBM(1)-NBL
	HSH-12-15L	HSH-12-15L
	HSH-12-15MM	HSH-12-15MM
	HR12-15L	HR12-15L
	HR12-15L(TR1)	HR12-15L(TR1)
	HR12M(BR)	HR12M(BR)
	HR12-15LC	HR12-15LC
	CP-G12C(2)	CP-G12C(2)
	HR12-15LCTR1	HR12-15LCTR1
	CP-G12C(2)	CP-G12C(2)
	HR12MC(1)	HR12MC(1)
	CP-G12MC(1)TR	CP-G12MC(1)TR
	HR12MC(1)TR	HR12MC(1)TR
	CP-G12MC(1)TR	CP-G12MC(1)TR
	HSH-31(12)	HSH-31(12)
	CP-HPF144TR	CP-HPF144TR
	HPF-490A(5)TR	HPF-490A(5)TR
	CP-HPF151	CP-HPF151
	HPF-490(A)	HPF-490(A)
	BC-TCLK(B)	BC-TCLK(B)
	TO-PSR(SUA)	TO-PSR(SUA)
	BC-TCLK(B)	BC-TCLK(B)
	TC-LK(SUA)	TC-LK(SUA)
	BC-TCLK(B)	BC-TCLK(B)
	TC-PSR(SUB)	TC-PSR(SUB)
	BC-TCLK(B)	BC-TCLK(B)
	TC-LK(SUB)	TC-LK(SUB)
	BC-TCLK(B)	BC-TCLK(B)
	HSM-A1HMTR	HSM-A1HMTR
	BC-DBM(1)-NBL	BC-DBM(1)-NBL

Page 98

Hirose Hook Catalog parts on page 98
Ref	Part number	Part name	Qty
	SWF/B-T1201	HSH-7.94ATR(MOSU)
	SWF/B-T1201C	HSH-7.94ATR(MOSUL)
	SWF/B-UI1212-45	HSH-7.94ATR(MQSU)
	SWF/B-UK1202-45	HTH-ATR(MQESU)
	SWF/B-UK1204-45	HTH-ATR(MQESUL)
	SWF/B-UK1206-45	HTH-ATR(MQESUNL)
	SWF/C-WD920-55	BC-DBZ(3)NBL6
	SWF/C-WE1204-55/75	BC-DBZ(3)NBL6
	SWF/C-WE1206-75	BC-DBZ(3)NBL6
	SWF/H-WD920-55	BC-HTH(ZEH)
	SWF/H-WD920-55	BC-HTH(ZEH)
	SWF/H-WD920-55	BC-HTH(ZEH)
	TZ1-B652	DB1-Z16B
	TZ1-B652XH	HTD-Z16B(E)
	LZ2-H272	DB1-Z16
	DB2-H310/H510/H515	HSH-7.94B
	DB2-H311/H510H/H515H	HSH-7.94A(3)
	LS2-H5100M/H5150M	HSH-7.94BTR
	LS2-H5200/H5300	HSH-7.94BTR
	LS2-H5100H/H5150H	HSH-7.94BOHMTR
	LS2-H530	HSH-7.94B(RT)
	LS2-H520	HSH-7.94DRN
	DB2-H312/H510XH/H515XH	HSM-A(3)
	LS2-H540/H5400/H5100XH	HSM-A1HTR
	LS2-H5150XH/H5110XH	HSM-A1HTR
	UAS-H1407(H)	TC-LK(BUC)
	UAS-H1407(M)	TC-LK(A)
	DB2-H320/321	HSH-12-15M
	LS2-H620(M)	BC-DBZ(1)
	DB2-H322/323	HSH-12-15MM
	LS2-H620(H)	BC-DB1
	LT2-H625(M)	HSH-12C
	LT2-H625(H)	HSH-12MC
	PLN-7B/27B	HSH-31(B12)
	LT5-H710/H720	BC-DB1
	LT5-H7200/H7600	HPF-490(5)TR
	LT2-H6200(H)	HSH-12-15MM(3)TR
	LT2-H6200(M)	HSH-12-15MTR(3)
	LT2-H6250(H)	HSH-12MCA(3UC)
	LT2-H6250(M)	HSH-12-15M(3UC)
	TZ1-B652	BC-DBZ(1)
	TZ1-B652XH	BC-HTH(ZEH)
	LZ2-H272	BC-DB1
	DB2-H310/H510/H515	BC-DB1
	DB2-H311/H510H/H515H	BC-DB1
	LS2-H5100M/H5150M	BC-DB1-NBL6
	LS2-H5200/H5300	BC-DB1-NBL6
	LS2-H5100H/H5150H	BC-DB1-NBL6
	LS2-H530	BC-DB1
	LS2-H520	BC-DB1
	DB2-H312/H510XH/H515XH	BC-DBM(1)
	LS2-H540/H5400/H5100XH	BC-DBM(1)-NBL
	LS2-H5150XH/H5110XH	BC-DBM(1)-NBL
	UAS-H1407(H)	BC-TCLK(B)
	UAS-H1407(M)	BC-TCLK(B)
	LT2-H625(M)	CP-12C
	LT2-H625(H)	CP-12MC
	LT5-H7200/H7600	CP-HPFF144TR
	LT2-H6250(H)	CP-G12MC(1)TR
	LT2-H6250(M)	CP-G12C(2SU)

Page 99

Hirose Hook Catalog parts on page 99
Ref	Part number	Part name	Qty
	CK-1461	HAD-204
	CK-1508	HSH-12-15MMJ(A)
	CK-1560	HSH-12-15MMJ(A)
	CK-243	HAD-204(6)
	CK-273	HAD-204(6)
	CK-441	HAD-204(6)
	CK-461	HAD-204(6)
	CK-471	HAD-204(6)
	CK-563	HSH-12-15MMJ
	CK-767	HSH-7-3
	CK-8BL	HSM-A(6)
	CK-8BL-1	HSM-A(6)
	SD-767TR	HSH-7-3
	SLH-2B	HSH-7-3
	SLH-767R	HSH-7-3
	STH-8BL	HSM-A(6)
	CN-915-3	HSM-B(Z17)
	CN-915-5	HSM-B(Z17)
	CN-990-3	HSH-7.94B
	CN-990-5	HSH-7.94A
	CN-990-7	HSH-7.94A
	CN-991-3	HSH-7.94ATR
	CN-991-3	HSH-7.94BTR
	CN-991-5	HSH-7.94ATR
	CN-991-7	HSH-7.94ATR
	CN-992-3	HSH-7.94BTR
	CN-992-5	HSH-7.94ATR
	CN-992-7	HSH-7.94ATR
	TJ-3300	HSM-A
	TJ-335	DB1-Z16B
	TJ-335H-BH	DB1-Z16B
	TJ-457	DP2-57(2LP)
	TJ-457A	DP2-457U(T)
	TJ-652	DB1-Z16B
	TJ-842	HSH-12-15L
	TJ-845	HSH-12-15LC
	TJ-8700	HSH-7.94B
	TJ-8700-7	HSH-7.94BTR

Page 100 — FENG YING 鋒穎

Hirose Hook Catalog parts on page 100
Ref	Part number	Part name	Qty
	FY-241	HSM-A1TR(280)
	FY-341	HYM-1341AY
	FY-810	HSH-31(12)
	FY-820	HSH-31(12)

Page 101 — GOLDEN WHEEL

Hirose Hook Catalog parts on page 101
Ref	Part number	Part name
31	HSH-7.94B	BC-DB1
31	HSH-7.94A	BC-DB1
31	HSH-7.94A	BC-DB1
38	DB1-BZ(20)	BC-DBZ(1)
38	HSH-7.94A	BC-DBZ(1)
39	HPF-335(5)	BC-PF9076(14)
46	HSH-12-15L(H)
49	HSH-12-15MM
46	HSH-12-15LC	CP-12C
46	HSH-12-15LC	CP-12C
46	HSH-12-15LC	CP-12C
50	HSH-12MC	CP-12MC
38	DB1-Z16B	BC-DBZ(1)
38	DA1-A	BC-DB1
35	HSM-A	BC-DBM(1)
35	HSM-A1HTR	BC-DBM(1)-NBL
38	DA1-B	BC-DB1
43	HSH-31(12)
35	HSM-A	BC-DBM(1)-NBL
49	HSH-12-15MM(V)
49	HSH-12-15MMJ(A)
31	HSH-7.94B	BC-DB1
43	HSH-31(6)
43	HSH-31(6)
31	HSH-7.94A	BC-DB1
34	HSH-7.94CTR	BC-DB1-NBL6
35	HSM-A	BC-DBM(1)
35	HSM-A	BC-DBM(1)
35	HSM-A	BC-DBM(1)
43	HPF-490A(5)TR	CP-HPF144TR
43	HPF-490A(5)TR	CP-HPF144TR
43	HPF-490A(5)TR	CP-HPF144TR
43	HPF-490A(5)TR	CP-HPF144TR
43	HPF-490A(5)TR	CP-HPF144TR
43	HPF-490A(5)TR	CP-HPF144TR
35	HSM-A	BC-DBM(1)
46	HSH-12-15M
46	HSH-12-15M
46	HSH-12-15M(3)	CP-12C
50	HSH-12MC	CP-12MC
50	HSH-12MC(3)	CP-12MC(3)
50	HSH-12MC(3)	CP-12MC(3)
43	HSH-31(6)
43	HSH-31(6)
38	DA1-B	BC-DB1
38	DA1-B	BC-DB1

Page 102

Hirose Hook Catalog parts on page 102
Ref	Part number	Part name	Qty
	CS-8000-30	DA1-B
	CS-810	HSH-31(6)
	CS-820	HSH-31(6)
	CS-821	HSH-31(6)
	CS-822	HSH-31(6)
	CS-861	HPF-490(A)
	CS-862	HPF-490(A)
	CS-8703	DB1-Z16B
	CS-871L	HSH-12-15MM
	CS-872-3	HSH-12-15MM
	CS-872L	HSH-12-15MM
	CS-875-3	HSH-12-15LC
	CS-875-5	HSH-12-15LC
	CS-875L	HSH-12MC
	CS-8810	HPF-490(A)
	CS-8810	HPF-490(A)
	CS-8BH	HSH-31(12)
	CS-8BH	HSH-31(12)
	CSH-7800	DP2-NJ771
	CSL-1720	HSH-12C
	CSL-1800	HSH-32
	CSL-1801	HSH-32
	CSU-4101	HSH-12-15MM(V)
	GF-204	HAD-204(6)
	GF-205	HAD-204(6)
	GF-205-335	HAD-204(6)
	GF-205-370	HAD-204(6)
	GF-205-380	HAD-204(6)
	JM-810	HSH-31(6)
	JM-820	HSH-31(6)
	JM-8810	HPF-490(A)
	JM-8820	HPF-490(A)

Page 103

Hirose Hook Catalog parts on page 103
Ref	Part number	Part name	Qty
	KBH-780	DP2-NJ771
	BC-LBH771	null
	null	DB1-Z(20)
	BC-DBZ(1)	null
	null	HSH-31(12)
	null	HSH-7.94B
	BC-DB1	null
	null	HSH-7.94A
	BC-DB1	null
	null	HSH-7.94A
	BC-DB1	null
	null	HSH-31(12)
	null	DB1-Z16B
	BC-DBZ(2)	null
	null	HPF-490(A)
	CP-HPF151	null
	null	HPF-490(A)
	CP-HPF151	null
	null	HPF-490(A)
	CP-HPF151	null
	null	HPF-545
	CP-HPF545	null
	null	HPF-545
	CP-HPF545	null
	null	HSH-31(12)
	null	HSH-31(12)
	null	HSH-31(12)
	null	HSH-31(12)
	null	HSH-12-15M
	null	HSH-12-15MM
	null	HSH-31(12)
	null	HSH-31(12)
	600-03040	HSH-7.94B
	600-03041	BC-DB1
	600-03040	HSH-7.94B
	600-03041	BC-DB1
	HK111-0002B	HSH-7.94BTR
	HK111-0001B	BC-DB1-NBL6
	600-03040	HSH-7.94B
	600-03041	BC-DB1
	600-03040	HSH-7.94B
	600-03041	BC-DB1

Page 104 — MILLION SPECIAL

Hirose Hook Catalog parts on page 104
Ref	Part number	Part name	Qty
	MS-1245	HPF-1242(A)
	MS-335	DB1-Z16B
	MS-474-500	HPF-490(A)
	MS-491-800	HPF-490(A)(5)TR
	MS-810	HSH-31(12)
	MS-820	HSH-31(12)
	MS-B842-3	HSH-12-15MM
	MS-B845	HSH-12C
	MS-B872-3	HSH-12-15MM
	MS-B875-5	HSH-12MC
	MS-491-830	HPF-490A(5)TR
	MS-474-530	HPF-490A(5)TR
	MS-691-800	HPF-490(A)
	MS-691-830	HPF-490(A)(5)TR
	MS-674-500	HSH-12C
	MS-674-530	HPF-490A(5)TR
	MS-735	HSH-7.94AO
	MS-370L	HSM-A
	MS-B842-403	HG12-15L(TR1)
	MS-B842-5	HSH-12-15M
	MS-B842-405	HG12-15L(TR1)
	MS-B845-3	HSH-12C
	MS-B845-5	HSH-12C
	MS-B872-403	HG12MC(1)TR
	MS-B872-5	HSH-12-15MM
	MS-B872-405	HG12MC(1)TR
	MS-B875-3	HG12MC(1)TR
	MS-B875-403	HG12MC(1)TR
	MS-B875-405	HG12MC(1)TR
	MS-20U143	DB1-BZ(20)
	MS-B652	DB1-Z16B
	MT-810	HSH-31(12)
	MT-820	HSH-31(12)

Page 105

Hirose Hook Catalog parts on page 105
Ref	Part number	Part name	Qty
	DY-3300	HSM-A
	DY-350L	HSM-A
	DY-370L	HSM-A
	DY-3811-L	HSM-A
	TC-1341	HYM-1341AY
	TC-1508	HSH-12-15MM(5)
	TC-1530	HSM-A
	TO-2508	HSH-12-15MM(5)
	TO-2530	HSM-A
	TC-28B	HSH-12-15MM(5)
	TC2-B1883	HSH-12C
	TC2-B1885	HSH-12MC
	TC2-B845	HSH-12-15LC
	TC2-B875	HSH-12MC
	TC2-B935	HSH-12-15MM
	TC-8B	HSH-31(12)
	TC-810	HSH-31(8)
	TC-810S	HSH-31(12)
	TC-820	HSH-31(6)
	TC-820S	HPF-490(A)
	TC-881	HPF-490(A)
	TC-882	HSH-12-15MM(5)
	TC-88B	HSH-12-15L(TR1)
	TC-B842-403	HG12-15L(TR1)
	TC-B842-405	HG12MC(1)TR
	TC-B872-403	HG12MC(1)TR
	TC-B872-405	HG12MC(1)TR
	TC-B875-403	HG12MC(1)TR
	TC-B875-405	HG12MC(1)TR
	JL-20U	DB1-Z(20)
	JL-457A	DP2-57(2LP)
	JL-781	DP2-NJ771

Page 106

Hirose Hook Catalog parts on page 106
Ref	Part number	Part name	Qty
	WR-3750	HSM-A
	WR-467	HAD-467TR
	WR-5705	HSM-A
	WR-652	DB1-Z16B
	WR-810	HSH-31(6)
	WR-820	HSH-31(6)
	WR-9910-1	HPF-490(A)
	WR-9910-T	HPF-490A(5)TR
	WR-9918-1	HPF-490(A)
	WR-991-T	HPF-490A(5)TR
	WR-992	HPF-490(A)
	WR-9920-1	HPF-490(A)
	WR-9920-T	HPF-490A(5)TR
	WR-992-T	HPF-490A(5)TR
	BEISLER 842	HG12L(1)TR1
	BEISLER 845	HG12-15LCTR1
	LT2-B842	HSH-12-15L
	LT2-B842-5	HSH-12-15M
	LT2-B842-580	HSH-12-15L
	LT2-B845	HSH-12-15LC
	LT2-B845-380	HSH-12-15LCTR1
	LT2-B848-3	HSH-12-15M
	LT2-B848-380	HSH-12-15L
	LT2-B849-380	HSH-12-15L(TR1)
	LT2-B872	HSH-12-15MM
	LT2-B872-380	HSH-12-15MM(3)TR
	LT2-B872-580	HG12MC(1)TR
	LT2-B875	HSH-12MC
	LT2-B875-380	HSH-12MC(3)
	LT2-B875-5	HSH-12MC
	LT2-B875-580	HSH-12MC(3)
	YAZICI 842	HG12L(1)TR1
	YAZICI 845	HG12-15LCTR1

Page 107 — SIRUBA

Hirose Hook Catalog parts on page 107
Ref	Part number	Part name	Qty
	G111	BC-DB1
	G112J	BC-DB1
	G122J	BC-DB1-NBL6
	G111	BC-DB1
	G121	BC-DB1-NBL6
	G111	BC-DB1
	G121	BC-DB1-NBL6
	G111	BC-DB1
	G121	BC-DB1-NBL6
	G112J	BC-DB1
	G122J	BC-DB1-NBL6
	G131	BC-DBM(1)
	G132	BC-DBM(4)-NBL3
	G151
	G151
	G401	CP-HPF151(A)
	G401	CP-HPF151(A)
	G401	CP-HPF144TR
	G401	CP-HPF151(A)
	G401	CP-HPF151(A)
	G401	CP-HPF151(A)
	G403	CP-HPF144TR
	G401	CP-HPF151(A)
	G406	CP-G12L(1)
	G161	HG12-15L
	G161	HG12-15L
	G406	CP-G12L(1)
	G163	HG12-15L(TR1)
	G161	HG12-15L
	G163	HG12-15L(TR1)
	G161	HG12-15L
	G163	HG12-15L(TR1)
	G406	CP-G12L(1)
	G409	CP-G12C
	G410	CP-G12CTR(1)
	G409	CP-G12C
	G409	CP-G12C
	G410	CP-G12CTR(1)
	G409	CP-G12C
	G410	CP-G12CTR(1)
	G406	CP-G12L(1)
	G163	HG12-15L(TR1)

Page 108 — SIRUBA 銀箭 / SUNNUN 信能

Hirose Hook Catalog parts on page 108
Ref	Part number	Part name	Qty
	G161	HG12-15L
	G163	HG12-15L(TR1)
	G161	HG12-15L
	G163	HG12-15L(TR1)
	G164	HG12L(1)TR1
	G169	HG12-15LC
	G170	HG12-15LCTR1
	G165	HG12M(BR)
	G168-A	HG12MC(1)TR
	G165	HG12M(BR)
	G168-A	HG12MC(1)TR
	G166	HG12MC(1)
	G168-A1	HG12MC(1)TR
	G166	HG12MC(1)
	G168-A1	HG12MC(1)TR
	G166	HG12MC(1)
	G168-A1	HG12MC(1)TR
	G173	HSH-12-15MM(410M)
	G175	HAD-467TR(1B)
	G175	HAD-467TR(1B)
	G173	HSH-12-15MM(410M)
	G175	HAD-467TR(1B)
	G175	HAD-467TR(1B)
	G135	HSM-A1HTR(T)
	G131	HSM-A(3)
	G132	HSM-A1HTR
	G131	HSM-A(3)
	G132	HSM-A1HTR
	G406	CP-G12L(1)
	G409	CP-G12C
	G410	CP-G12CTR(1)
	G411	CP-G12M(BR)TR
	G407	CP-G12MC(1)
	G408	CP-G12MC(1)TR
	G205	BC-DBM(4)-NBL3
	G204	BC-DBM(1)
	EB-883	DB1-Z16
	YU-740	HSM-A

Page 109 — TAKING / TONY bobbin case and hook cross-reference

Hirose Hook Catalog parts on page 109
Ref	Part number	Part name	Qty
	TK-1245	HPF-1242(A)
	TK-1246	HPF-1242(A)
	TK-545	HPF-545
	TK-546	HPF-545
	TK-591	HPF-490(A)
	TK-591T	HPF-490(5)TR
	TK-592	HPF-490(A)
	TK-592T	HPF-490(5)TR
	TK-691	HPF-490(A)
	TK-691T	HPF-490(5)TR
	TK-692	HPF-490(A)
	TK-692T	HPF-490(5)TR
	TK-810	HSH-31(12)
	TK-820	HSH-31(12)
	TK-832	HSH-12-15M
	TK-832-LB5	HSH-12-15MM
	TK-86	HSH-12-15MMJ
	TK-872	HSH-12-15MM
	TK-888	DP2-NJ771
	TK-89	HSH-7.94B
	TK-8BL	HSM-A(6)
	TK-991	HPF-490(A)
	TK-992	HPF-490(A)
	H-130-LHA	HSH-7.94A
	H-301	DBM-A(Z14)
	H-305	DBM-A(Z14)
	H-370-LHA	HSM-A

Page 110 — YULUN 友倫

Hirose Hook Catalog parts on page 110
Ref	Part number	Part name	Qty
	DP2-57(2LP)
	DP2-57(2LP)
	DP2-57(2LP)
	DP2-57(2LP)
	DP2-57(3LP2R)
	DP2-457U(T)
	DP2-457U(T)
	DP2-57(3LP2R)
	DP2-57(3LP2R)
	DP2-457U(T)
	DP2-457U(T)
	DP2-57(3LP2R)
	DP2-57(3LP2R)
	DP2-57(2YLMH)
	HPF-1242(A)
	HPF-1242(A)
	DB1-Z16B
	HSM-A
	HSM-A
	DP2-57(2LP)
	HPF-1242(A)
	HPF-1242(A)
	HPF-490(A)
	HPF-490(A)
	HSH-31(12)
	YLM-810-G

Page 116 — COMPONENT PARTS

Hirose Hook Catalog parts on page 116
Ref	Part number	Part name	Qty
	1	Bobbin case/cap
	2	Inner hook
	3	Outer hook
	4	Hook gib
	5	Hook gib screw
	6	Thread guard
	7	Thread guard screw
	8	Set screw
	9	Needle guard
	10	Needle guard screw
	11	Tension spring
	12	Tension spring screw
	13	Regulating screw
	14	Thread control spring
	15	Thread control spring screw

Page 117 — OIL-FREE HOOK

Hirose Hook Catalog parts on page 117
Ref	Part number	Part name	Qty
	S-7200A-435,S-7200A-45S	BROTHER
	271	DURKOPP/ADLER
	DDL-9000DF,DS	JUKI
	1053	PFAFF
	487NL,489NL,563NL	PFAFF
	HSH-7.94BTR(RPW)	ITEM
	HSH-7.94BTR(1RPWL)	ITEM
	HDU-271(QRP)	ITEM
	HSH-7.94BTR(2SPRPWS)	ITEM
	HSH-7.94BTR(RPW)	ITEM
	HPF-563TR(RP)	ITEM
	HSH-7.94ATR(MQRP)	ITEM
	HSH-7.94ATR(MQRPW)	ITEM
	HSH-7.94ATR(MTQRP)	ITEM
	DP2-57(2RP)	ITEM
	DP2-57(2LPRP)	ITEM
	DP2-57(3LP2VRPW)	ITEM
	LZ-2290A-DS-7-CB,LZ-2290A-DU-7-CB	JUKI

Page 118 — HTH-SERIES HOOK SETS

Hirose Hook Catalog parts on page 118
Ref	Part number	Part name
1	HSH-7.94BTR	CONVENTIONAL
2	HTH-BTR(E)	HTH-series
3	BC-DB1-NBL6	CONVENTIONAL
4	BC-HTH(E)	HTH-series
5	BO-95(A)	CONVENTIONAL
6	BO-HTH(A)	HTH-series
	HTH-BTR(E)	For under trimming machine usable in place of conventional hook HSH-7.94BTR
	HTH-ATR(E)	For under trimming machine usable in place of conventional hook HSH-7.94BTR
	HTH-BTR(HPNG)	For under trimming machine usable in place of conventional hook HSH-7.94BTR
	HTH-BTR(2SPHPNG20E)	For under trimming machine usable in place of conventional hook HSH-7.94BTR
	HTH-614BTR(2E)	For under trimming machine usable in place of conventional hook HSH-7.94BTR
	HTH-614BTR(QE)	For under trimming machine usable in place of conventional hook HSH-7.94BTR
	HTH-614BTR(1.7QE)	For under trimming machine usable in place of conventional hook HSH-7.94BTR
	HTH-ATR(MQE)	For embroidery machine usable in place of conventional hook HSH-7.94ATR(MTQ)
	HTH-ATR(MQESU)	For embroidery machine usable in place of conventional hook HSH-7.94ATR(MTQ)
	HTH-ATR(MQESUL)	For embroidery machine usable in place of conventional hook HSH-7.94ATR(MTQ)
	HTH-ATR(MQESUNL)	For embroidery machine usable in place of conventional hook HSH-7.94ATR(MTQ)

Page 119 — HTM-SERIES HOOK SETS

Hirose Hook Catalog parts on page 119
Ref	Part number	Part name	Qty
	HSM-A	HOOK
	HTM-A	HOOK
	BC-DBM(1)	BOBBIN CASE
	BC-HTM(761)	BOBBIN CASE
	BO-HSM(A)	BOBBIN
	BO-HTM(A)	BOBBIN
	HTM-A	HOOK
	HTM-A1HTR	HOOK
	HTM-BTR(HP761)	HOOK

Page 120 — HP SERIES SUPER HARD POINT HOOK 硬尖梭头

Hirose Hook Catalog parts on page 120
Ref	Part number	Part name	Qty
	HSH-7.94B(HP)
	HSH-7.94BTR(HP)
	HTH-BTR(HPNG)
	HSM-BRTR(HP370)
	HTH-BTR(2SPHPNG20E)
	DP2-457(HP)
	DP2-457(LHP)
	DP2-57(2HPTS)
	DP2-57(3LP2RHP)
	DP2-57(3LP2VHP)
	HSH-21-40(HP)

Page 2 — INDEX

Page 3 — ITEM LIST & PHOTOS

Page 4 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Page 5 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Page 6 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Page 7 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) 垂直回转式梭头 (DB 型)

Page 8 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) LARGE TYPE

Page 9 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Page 10 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) LOW SPEED TYPE

Page 11 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE)

Page 12 — HORIZONTAL AXIS ROTARY HOOK (DP TYPE) 垂直回转式梭头 (DP 型) HIGH SPEED ZIGZAG TYPE 高速人字型缝纫头

Page 13 — HORIZONTAL AXIS ROTARY HOOK (DP TYPE) 垂直回转式梭头 (DP 型) HIGH SPEED ZIGZAG TYPE 高速人字型缝纫梭头

Page 14 — VERTICAL AXIS ROTARY HOOK 水平回转式拨头 STANDARD TYPE with SHANK 短轴小型拨头

Page 15 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHANK

Page 16 — VERTICAL AXIS ROTARY HOOK, STANDARD TYPE with SHAFT

Page 17 — VERTICAL AXIS ROTARY HOOK - STANDARD TYPE with SHAFT

Page 18 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHAFT

Page 19 — VERTICAL AXIS ROTARY HOOK 水平回转式梭头 STANDARD TYPE with BOSS (HUB) 轴套小型梭头

Page 20 — VERTICAL AXIS ROTARY HOOK 水平回转式拨头 LARGE TYPE with SHANK 短轴大型拨头

Page 21 — VERTICAL AXIS ROTARY HOOK 水平回转式梭头 LARGE TYPE with SHAFT 长轴大型梭头

Page 22 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHAFT

Page 23 — VERTICAL AXIS ROTARY HOOK

Page 24 — SHUTTLE 摆梭

Page 25 — OTHERS 其他

Page 26 — BOBBIN CASE / CAP 梭芯套/梭帽

Page 27 — BOBBIN CASE / CAP 梭芯套/梭帽

Page 28 — BOBBIN CASE / CAP

Page 29 — BOBBIN CASE / CAP 梭芯套/梭帽

Page 30 — BOBBIN CASE / CAP 梭芯套/梭帽

Page 31 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) HIGH SPEED TYPE 垂直回转式梭头(DB 型) 高速缝梭头

Page 32 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) HIGH SPEED TYPE

Page 33 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) HIGH SPEED TYPE 垂直回转式拨头 (DB 型) 高速缝头

Page 34 — HORIZONTAL AXIS ROTARY HOOK (DB TYPE) HIGH SPEED TYPE 垂直回转式梭头 (DB 型) 高速缝梭头

Page 35 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LARGE TYPE

Page 36 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LARGE TYPE

Page 37 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LARGE TYPE 垂直回转式梭头(DB 型)大型梭头

Page 38 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LOW SPEED TYPE 垂直回转式梭头(DB 型)低速缝梭头

Page 39 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LOW SPEED TYPE

Page 40 — HORIZONTAL AXIS ROTARY HOOK(DB TYPE) LOW SPEED TYPE

Page 41 — HORIZONTAL AXIS ROTARY HOOK(DP TYPE) HIGH SPEED ZIGZAG TYPE 垂直回转式梭头(DP型)高速人字型缝纫梭头

Page 42 — HORIZONTAL AXIS ROTARY HOOK(DP TYPE) HIGH SPEED ZIGZAG TYPE 垂直回转式梭头(DP型)高速人字型缝纫梭头

Page 43 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHANK

Page 44 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHANK

Page 45 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHAFT

Page 46 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with SHAFT

Page 47 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with BOSS(HUB) 水平回转式梭头 轴套小型梭头

Page 48 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHANK

Page 49 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHAFT

Page 50 — VERTICAL AXIS ROTARY HOOK LARGE TYPE with SHAFT

Page 51 — SHUTTLE 搜

Page 52 — OTHERS 其他

Page 53 — BOBBIN CASE / CAP 梭芯套/梭帽

Page 54 — BOBBIN CASE／CAP 梭芯套/梭帽

Page 55 — BOBBIN CASE/ CAP 梭芯套/梭帽

Page 57 — REFERENCE TABLE

Page 58

Page 59

Page 60 — BROTHER

Page 61 — BROTHER

Page 62 — BROTHER

Page 63 — DURKOPP / ADLER (ADLER)

Page 64 — DURKOPP / ADLER (DURKOPP)

Page 65

Page 66

Page 67 — JUKI

Page 68 — JUKI

Page 69 — JUKI

Page 70 — JUKI / MAMMUT / MARCO

Page 71 — MITSUBISHI

Page 72 — MITSUBISHI

Page 73

Page 74 — PFAFF

Page 75 — SEIKO

Page 76 — SEIKO

Page 77 — SINGER

Page 78 — SINGER

Page 79 — SINGER

Page 80 — SINGER

Page 81 — SINGER

Page 82 — STAGER

Page 47 — VERTICAL AXIS ROTARY HOOK STANDARD TYPE with BOSS(HUB) 水平回转式梭头轴套小型梭头
