Jack C4 parts on page 1
RefPart numberPart nameQty
20703017螺钉M3×10
20702005上臂衬套
20703009上刀轴右套
20633025透布输送封
20701202下刀座
207513003螺钉M6×25
F03018销钉
20703004销钉
20653001支柱
20703008上刀轴左套
20703008左套
20703003右套
20703003右套
20703002下套左
20703002下套右
20703001下套
13837003机型号
3029263机壳(喷漆)
20713027过线管
20736018下刀轴
211101007压脚
207514001螺钉M4×7.5
20713003导线管
20713002导线管
211101007压脚
20713006导线管
20713007导线管
20727002弹簧
20727003螺钉
20727005弹簧
207510006螺钉
207511007螺钉M3×6
2113013螺钉
20713015螺钉
207513001螺钉
207513001螺钉
211101015压脚
207513003螺钉M4×10
211101015压脚
211120100衬套
207514007螺钉
20603010衬套
W03004垫圈
207513001螺钉
20605006衬套固定块
20652006螺钉
20627003弹簧
20627008垫圈
20627002垫圈
207513003螺钉
207511007螺钉
20622003垫圈
20622003垫圈
207511007螺钉
20638012垫圈
207511014螺钉M4.5×4
207511014螺钉
207513001螺钉
20713002垫圈
21111004护罩
W011011螺母
20751016螺钉M4×16
207513001螺钉
211101015压脚
207514001螺钉M4×7.5
20713003导线管
20713002导线管
211101015压脚
W01011螺钉M3×5
207511007螺钉
207511020螺钉
207511020螺钉
20713011导线架
20713010导线架
207511021螺钉M3.5×6
20713015导线架
20713005导线架
211101012压脚
20713054导线管
20713053导线管
20713012导线架
20713015导线架
W01011螺钉M3×5
W01011螺钉M3×5
207511007螺钉
207511020螺钉
207511020螺钉
20713011导线架
20713010导线架
207511021螺钉M3.5×6
20713015导线架
20713005导线架

Page 3

Jack C4 parts on page 3
RefPart numberPart nameQty
207203023送布垫片
H050000开口挡圈
207202006送布轴
207SL1019送布挡块
207010000送布前挡件
20701010送布前挡
505018螺钉M3×0.75×12
207SL1029螺钉M3×6
20709007调节螺母
207SL1001调节板
207120020垫圈
207SL1005挡块
20704011送布前挡
12929008平垫圈
501001螺母M5
207SL1006调节板
207SL1007调节板
207SL1008调节板
207SL1009调节板
207SL1010调节板
207SL1011调节板
207SL1012调节板
207SL1013调节板
207SL1014调节板
207SL1015调节板
207SL1016调节板
207SL1017调节板
207SL1018调节板
207SL1019调节板
207SL1020调节板
207SL1021调节板
207SL1022调节板
207SL1023调节板
207SL1024调节板
207SL1025调节板
207SL1026调节板
207SL1027调节板
207SL1028调节板
207SL1029调节板
207SL1030调节板
207SL1031调节板
207SL1032调节板
20610018送布挡块
207SL1033送布挡块
207SL1034送布挡块
207SL1035送布挡块
207SL1036送布挡块
207SL1037送布挡块
2113030000送布挡块
207SL1026送布挡块
207202000油壶
207202009上刀架
207SL1019弹簧
207SL1007下刀架
SL00003螺钉M6×0.75×5
207SL1016弹簧
W01011垫圈
207SL1007下刀架
505017螺钉M3×4
20608004上刀架挡块
20612030上刀架挡块(开槽)
207SL1009下刀架
501002螺母M6
207SL1014弹簧
206036016挡块
207SL1004下刀架
207SL1001下刀架
2121001压脚刀
207SL1014弹簧
505018螺钉M5×5
207SL1020下刀架
2111916002调节螺母
001039O型圈12.5×1.8
207SL1001压脚刀
2111616001螺纹套
001008O型圈9×1.8
207SL1001压脚前挡
207SL1002压脚前挡
21103018滑杆套
21112025限位挡板
21112025限位挡板
20607010压杆拨杆
212087010压杆拨杆
21120200压脚拨杆
207SL1003弹簧
207SL1004弹簧
206010004螺钉
207SL1006压脚底板
20701023压脚底板
207SL1008压脚
207SL1009螺钉
207SL1010螺钉
207SL1011螺钉
207SL1012螺钉
207SL1013螺钉
207SL1014螺钉
207SL1015螺钉
207SL1016螺钉
207SL1017螺钉
207SL1018螺钉
207SL1019螺钉
207SL1020螺钉
207SL1021螺钉
207SL1022螺钉
207SL1023螺钉
207SL1024螺钉
207SL1025螺钉
207SL1026螺钉
207SL1027螺钉
207SL1028螺钉
207SL1029螺钉
207SL1030螺钉
207SL1031螺钉
207SL1032螺钉
207SL1033螺钉
207SL1034螺钉
207SL1035螺钉
207SL1036螺钉
2113030000螺钉
207SL1026螺钉
20631018导线管
207202000油壶
207SL1019橡胶垫
207SL1006油孔刮刀
207SL1011毛毡
21131009导线管(加长)
207SL018导线管
21131021导线管
207SL01012导线架(长)
20631018导线管
207SL01011导线管
20631018导线管
21131009导线管(加长)
207SL01020导线管
21131012导线架(长)
207SL01011导线管
20631019导线管
21211202挡板
21123003毛毡
21123003毛毡
21122002挡板
21130005油壶油盖
21130005油壶油盖
21121006导油管
207SL1010螺钉M5×10
207SL1010螺钉M5×10
207SL1010螺钉M5×10
206530099螺钉
20123033油壶
501032螺母
21121006导油管
207SL1010螺钉M5×10
20729005油壶
12921003平垫圈
207SL1008油壶
21211003油壶
211110055油壶
20631018导线管
20720002油壶
207SL1019挡圈
21121006导油管
21123001油壶
207SL1006油孔刮刀
21131009导线管(加长)
207SL018导线管
21131021导线管
20631018导线管
207SL01011导线管
20631018导线管
21131009导线管(加长)
207SL01020导线管
21131012导线架(长)
207SL01011导线管
20631019导线管

Page 4 — 二十四、托盘部件/Part for Semi-Submerged Installation 二十五、专用零件/Specific Parts 二十六、机架部件/Machine Frame & Miscellaneous Cover Components

Jack C4 parts on page 4
RefPart numberPart nameQty
20131076托盘固定螺钉
20122018托盘的固定垫垫
20711058托盘
20712054托架
30122031减震垫圈
20131050防尘盖
20131050防尘盖
20131050防尘盖
20131050防尘盖
20131034废料收集箱
21131005排料槽
21131006排料槽
21131007排料槽I
20731016垫圈
20751005螺钉M4×9
2061601000压脚组件
20616042压脚接件
301029螺钉M3.5×5
20711009销
2071054护料压板
2071051压脚底板
20701055压脚底板
20752002销
2071053压脚挡片
20711055弹簧
20751053螺钉M4×4
207520010轴位螺钉
207511007螺钉M4×4
XXXXXXXX压脚组件
207511038螺钉
20716063压脚架
20716100压脚架
19832111机架连接板
S18002机架上盖板
19832114机架下盖板
19832104支架
20111300变速器
20710000连接杆
20131054脚踏板连接件
19832102机架固定盖板
20822129护板

Jack C4 — parts catalog

Page 1

JACK 快速服务 100% C4超高速包缝机 Super high speed overlock sewing machine 一、机壳部件/Machine Bed Frame 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 20703017 螺钉M3×10 Screw 1 1 1 2 20702005 上臂衬套 Sleeve 1 1 1 3 20703009 上刀轴右套 Sleeve 5 5 5 4 20633025 透布输送封 Plug 1 1 1 5 20701202 下刀座 Bracket Assembly 1 1 1 6 207513003 螺钉M6×25 Screw 2 2 2 7 F03018 销钉 Pin 1 1 1 8 20703004 销钉 Pin 1 1 1 9 20653001 支柱 Bed pin 1 1 1 10 20703008 上刀轴左套 Sleeve 1 1 1 11 20703008 左套 Sleeve 1 1 1 12 20703003 右套 Sleeve 1 1 1 13 20703003 右套 Sleeve 1 1 1 14 20703002 下套左 Sleeve 1 1 1 15 20703002 下套右 Sleeve 1 1 1 16 20703001 下套 Sleeve 1 1 1 17 13837003 机型号 Machine Model Plate 1 1 1 18 3029263 机壳(喷漆) Machine Bed Complete 2 2 2 19 20713027 过线管 Pipe 1 1 1 20 20736018 下刀轴 Pin 1 1 1 四、主轴部件/Machine Bed Frame 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 211101007 压脚 Bracket 1 1 1 2 207514001 螺钉M4×7.5 Screw 1 1 1 3 20713003 导线管 Thread Guide 1 1 1 4 20713002 导线管 Thread Guide 1 1 1 5 211101007 压脚 Bracket 1 1 1 6 20713006 导线管 Thread Guide 1 1 1 7 20713007 导线管 Thread Retainer 1 1 1 8 20727002 弹簧 Spring 1 1 1 9 20727003 螺钉 Screw 1 1 1 10 20727005 弹簧 Spring 1 1 1 11 207510006 螺钉 Screw 1 1 1 12 207511007 螺钉M3×6 Screw 1 1 1 13 2113013 螺钉 Screw Takeup 1 1 1 14 20713015 螺钉 Screw Takeup 1 1 1 三、机壳部件(2)/Cover (2) 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 207513001 螺钉 Screw 4 4 4 2 207513001 螺钉 Screw 1 1 1 3 211101015 压脚 Bed Cover Plate Assy 1 1 1 4 207513003 螺钉M4×10 Screw 1 1 1 5 211101015 压脚 Cover Plate 1 1 1 6 211120100 衬套 Cloth Plate 1 1 1 7 207514007 螺钉 Screw 1 1 1 8 20603010 衬套 Pushing 1 1 1 9 W03004 垫圈 Washer 1 1 1 10 207513001 螺钉 Screw 1 1 1 11 20605006 衬套固定块 Bracket 1 1 1 12 20652006 螺钉 Screw 1 1 1 13 20627003 弹簧 Spring 1 1 1 14 20627008 垫圈 Lever 1 1 1 15 20627002 垫圈 Lever 1 1 1 16 207513003 螺钉 Screw 1 1 1 17 207511007 螺钉 Screw 2 2 2 18 20622003 垫圈 Cushion Rubber 1 1 1 19 20622003 垫圈 Cushion Rubber 1 1 1 20 207511007 螺钉 Screw 3 3 3 21 20638012 垫圈 Washer 3 3 3 22 207511014 螺钉M4.5×4 Screw 1 1 1 23 207511014 螺钉 Latch 1 1 1 24 207513001 螺钉 Screw 1 1 1 25 20713002 垫圈 Plate 1 1 1 26 21111004 护罩 Eye Guide 1 1 1 27 W011011 螺母 Nut 1 1 1 28 20751016 螺钉M4×16 Screw 2 2 2 29 207513001 螺钉 Washer 2 2 2 七、过线机构(2)/Thread Guide and Thread Takeup (2) 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 211101015 压脚 Bracket 1 1 1 2 207514001 螺钉M4×7.5 Screw 1 1 1 3 20713003 导线管 Thread Guide 1 1 1 4 20713002 导线管 Thread Guide 1 1 1 5 211101015 压脚 Bracket 1 1 1 6 W01011 螺钉M3×5 Screw 1 1 1 7 207511007 螺钉 Screw 1 1 1 8 207511020 螺钉 Screw 1 1 1 9 207511020 螺钉 Screw 1 1 1 10 20713011 导线架 Thread Takeup 1 1 1 11 20713010 导线架 Thread Takeup 1 1 1 12 207511021 螺钉M3.5×6 Screw 1 1 1 13 20713015 导线架 Thread Takeup 1 1 1 14 20713005 导线架 Thread Takeup 1 1 1 六、过线机构(1)/Thread Guide and Thread Takeup (1) 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 211101012 压脚 Bracket 1 1 1 八、过线机构(3)/Thread Guide and Thread Takeup (3) 序号 NO. 公司件号 Part NO. 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 20713054 导线管 Thread Guide 1 1 1 2 20713053 导线管 Thread Guide 1 1 1 3 20713012 导线架 Thread Takeup 1 1 1 4 20713015 导线架 Thread Takeup 1 1 1 5 W01011 螺钉M3×5 Screw 1 1 1 6 W01011 螺钉M3×5 Screw 1 1 1 7 207511007 螺钉 Screw 1 1 1 8 207511020 螺钉 Screw 1 1 1 9 207511020 螺钉 Screw 1 1 1 10 20713011 导线架 Thread Takeup 1 1 1 11 20713010 导线架 Thread Takeup 1 1 1 12 207511021 螺钉M3.5×6 Screw 1 1 1 13 20713015 导线架 Thread Takeup 1 1 1 14 20713005 导线架 Thread Takeup 1 1 1 第1页,共4页 jintex.in

Page 3

十七、送布机构/Feed Mechanism 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 (Number) three- thread four- thread five- thread 1 207203023 送布垫片 Plug 1 2 H050000 开口挡圈 Ring 1 3 207202006 送布轴 Shaft 1 4 207SL1019 送布挡块 Lever 1 5 207010000 送布前挡件 Crank 1 6 20701010 送布前挡 Crank 1 7 505018 螺钉M3×0.75×12 Screw 2 8 207SL1029 螺钉M3×6 Screw 2 9 20709007 调节螺母 Nut 1 10 207SL1001 调节板 Regulator Plate 1 11 207120020 垫圈 Spacer 2 12 207SL1005 挡块 Pin 1 13 20704011 送布前挡 Crank 1 14 12929008 平垫圈 Washer 1 15 501001 螺母M5 Nut 1 16 207SL1006 调节板 Regulator Plate 1 17 207SL1007 调节板 Regulator Plate 1 18 207SL1008 调节板 Regulator Plate 1 19 207SL1009 调节板 Regulator Plate 1 20 207SL1010 调节板 Regulator Plate 1 21 207SL1011 调节板 Regulator Plate 1 22 207SL1012 调节板 Regulator Plate 1 23 207SL1013 调节板 Regulator Plate 1 24 207SL1014 调节板 Regulator Plate 1 25 207SL1015 调节板 Regulator Plate 1 26 207SL1016 调节板 Regulator Plate 1 27 207SL1017 调节板 Regulator Plate 1 28 207SL1018 调节板 Regulator Plate 1 29 207SL1019 调节板 Regulator Plate 1 30 207SL1020 调节板 Regulator Plate 1 31 207SL1021 调节板 Regulator Plate 1 32 207SL1022 调节板 Regulator Plate 1 33 207SL1023 调节板 Regulator Plate 1 34 207SL1024 调节板 Regulator Plate 1 35 207SL1025 调节板 Regulator Plate 1 36 207SL1026 调节板 Regulator Plate 1 37 207SL1027 调节板 Regulator Plate 1 38 207SL1028 调节板 Regulator Plate 1 39 207SL1029 调节板 Regulator Plate 1 40 207SL1030 调节板 Regulator Plate 1 41 207SL1031 调节板 Regulator Plate 1 42 207SL1032 调节板 Regulator Plate 1 43 20610018 送布挡块 Lever 1 44 207SL1033 送布挡块 Lever 1 45 207SL1034 送布挡块 Lever 1 46 207SL1035 送布挡块 Lever 1 47 207SL1036 送布挡块 Lever 1 48 207SL1037 送布挡块 Lever 1 49 2113030000 送布挡块 Lever 1 50 207SL1026 送布挡块 Lever 1 (1) Lubrication Mechanism (1) 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 (Number) three- thread four- thread five- thread 1 207202000 油壶 Pump 1 2 207202009 上刀架 Upper Knife Lever 1 3 207SL1019 弹簧 Spring 1 4 207SL1007 下刀架 Lower Knife Lever 1 5 SL00003 螺钉M6×0.75×5 Screw 2 6 207SL1016 弹簧 Spring 1 7 W01011 垫圈 Washer 1 8 207SL1007 下刀架 Lower Knife Lever 1 9 505017 螺钉M3×4 Screw 1 10 20608004 上刀架挡块 Upper Knife Lever Gib 1 11 20612030 上刀架挡块(开槽) Upper Knife Lever Gib 1 12 207SL1009 下刀架 Lower Knife Lever 1 13 501002 螺母M6 Nut 1 14 207SL1014 弹簧 Spring 1 15 206036016 挡块 Pin 1 16 207SL1004 下刀架 Lower Knife Lever 1 17 207SL1001 下刀架 Lower Knife Lever 1 18 2121001 压脚刀 Presser Cutter 1 19 207SL1014 弹簧 Spring 1 20 505018 螺钉M5×5 Screw 2 21 207SL1020 下刀架 Lower Knife Lever 1 22 2111916002 调节螺母 Nut 1 23 001039 O型圈12.5×1.8 O Ring 1 24 207SL1001 压脚刀 Presser Cutter 1 25 2111616001 螺纹套 Thread Sleeve 2 26 001008 O型圈9×1.8 O Ring 2 27 207SL1001 压脚前挡 Presser Foot Guard 1 28 207SL1002 压脚前挡 Presser Foot Guard 1 29 21103018 滑杆套 Slide Sleeve 1 30 21112025 限位挡板 Spacer 1 31 21112025 限位挡板 Spacer 1 32 20607010 压杆拨杆 Lever 1 33 212087010 压杆拨杆 Lever 1 34 21120200 压脚拨杆 Lever 1 35 207SL1003 弹簧 Spring 1 36 207SL1004 弹簧 Spring 1 37 206010004 螺钉 Screw 1 38 207SL1006 压脚底板 Baseboard 1 39 20701023 压脚底板 Baseboard 1 40 207SL1008 压脚 Pack 1 41 207SL1009 螺钉 Screw 1 42 207SL1010 螺钉 Screw 1 43 207SL1011 螺钉 Screw 1 44 207SL1012 螺钉 Screw 1 45 207SL1013 螺钉 Screw 1 46 207SL1014 螺钉 Screw 1 47 207SL1015 螺钉 Screw 1 48 207SL1016 螺钉 Screw 1 49 207SL1017 螺钉 Screw 1 50 207SL1018 螺钉 Screw 1 51 207SL1019 螺钉 Screw 1 52 207SL1020 螺钉 Screw 1 53 207SL1021 螺钉 Screw 1 54 207SL1022 螺钉 Screw 1 55 207SL1023 螺钉 Screw 1 56 207SL1024 螺钉 Screw 1 57 207SL1025 螺钉 Screw 1 58 207SL1026 螺钉 Screw 1 59 207SL1027 螺钉 Screw 1 60 207SL1028 螺钉 Screw 1 61 207SL1029 螺钉 Screw 1 62 207SL1030 螺钉 Screw 1 63 207SL1031 螺钉 Screw 1 64 207SL1032 螺钉 Screw 1 65 207SL1033 螺钉 Screw 1 66 207SL1034 螺钉 Screw 1 67 207SL1035 螺钉 Screw 1 68 207SL1036 螺钉 Screw 1 69 2113030000 螺钉 Screw 1 70 207SL1026 螺钉 Screw 1 十七、送布机构/Feed Mechanism 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 (Number) three- thread four- thread five- thread 1 207203023 送布垫片 Plug 1 2 H050000 开口挡圈 Ring 1 3 207202006 送布轴 Shaft 1 4 207SL1019 送布挡块 Lever 1 5 207010000 送布前挡件 Crank 1 6 20701010 送布前挡 Crank 1 7 505018 螺钉M3×0.75×12 Screw 2 8 207SL1029 螺钉M3×6 Screw 2 9 20709007 调节螺母 Nut 1 10 207SL1001 调节板 Regulator Plate 1 11 207120020 垫圈 Spacer 2 12 207SL1005 挡块 Pin 1 13 20704011 送布前挡 Crank 1 14 12929008 平垫圈 Washer 1 15 501001 螺母M5 Nut 1 16 207SL1006 调节板 Regulator Plate 1 17 207SL1007 调节板 Regulator Plate 1 18 207SL1008 调节板 Regulator Plate 1 19 207SL1009 调节板 Regulator Plate 1 20 207SL1010 调节板 Regulator Plate 1 21 207SL1011 调节板 Regulator Plate 1 22 207SL1012 调节板 Regulator Plate 1 23 207SL1013 调节板 Regulator Plate 1 24 207SL1014 调节板 Regulator Plate 1 25 207SL1015 调节板 Regulator Plate 1 26 207SL1016 调节板 Regulator Plate 1 27 207SL1017 调节板 Regulator Plate 1 28 207SL1018 调节板 Regulator Plate 1 29 207SL1019 调节板 Regulator Plate 1 30 207SL1020 调节板 Regulator Plate 1 31 207SL1021 调节板 Regulator Plate 1 32 207SL1022 调节板 Regulator Plate 1 33 207SL1023 调节板 Regulator Plate 1 34 207SL1024 调节板 Regulator Plate 1 35 207SL1025 调节板 Regulator Plate 1 36 207SL1026 调节板 Regulator Plate 1 37 207SL1027 调节板 Regulator Plate 1 38 207SL1028 调节板 Regulator Plate 1 39 207SL1029 调节板 Regulator Plate 1 40 207SL1030 调节板 Regulator Plate 1 41 207SL1031 调节板 Regulator Plate 1 42 207SL1032 调节板 Regulator Plate 1 43 20610018 送布挡块 Lever 1 44 207SL1033 送布挡块 Lever 1 45 207SL1034 送布挡块 Lever 1 46 207SL1035 送布挡块 Lever 1 47 207SL1036 送布挡块 Lever 1 48 207SL1037 送布挡块 Lever 1 49 2113030000 送布挡块 Lever 1 50 207SL1026 送布挡块 Lever 1 (1) Lubrication Mechanism (1) 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 (Number) three- thread four- thread five- thread 1 207202000 油壶 Pump 1 2 207202009 上刀架 Upper Knife Lever 1 3 207SL1019 弹簧 Spring 1 4 207SL1007 下刀架 Lower Knife Lever 1 5 SL00003 螺钉M6×0.75×5 Screw 2 6 207SL1016 弹簧 Spring 1 7 W01011 垫圈 Washer 1 8 207SL1007 下刀架 Lower Knife Lever 1 9 505017 螺钉M3×4 Screw 1 10 20608004 上刀架挡块 Upper Knife Lever Gib 1 11 20612030 上刀架挡块(开槽) Upper Knife Lever Gib 1 12 207SL1009 下刀架 Lower Knife Lever 1 13 501002 螺母M6 Nut 1 14 207SL1014 弹簧 Spring 1 15 206036016 挡块 Pin 1 16 207SL1004 下刀架 Lower Knife Lever 1 17 207SL1001 下刀架 Lower Knife Lever 1 18 2121001 压脚刀 Presser Cutter 1 19 207SL1014 弹簧 Spring 1 20 505018 螺钉M5×5 Screw 2 21 207SL1020 下刀架 Lower Knife Lever 1 22 2111916002 调节螺母 Nut 1 23 001039 O型圈12.5×1.8 O Ring 1 24 207SL1001 压脚刀 Presser Cutter 1 25 2111616001 螺纹套 Thread Sleeve 2 26 001008 O型圈9×1.8 O Ring 2 27 207SL1001 压脚前挡 Presser Foot Guard 1 28 207SL1002 压脚前挡 Presser Foot Guard 1 29 21103018 滑杆套 Slide Sleeve 1 30 21112025 限位挡板 Spacer 1 31 21112025 限位挡板 Spacer 1 32 20607010 压杆拨杆 Lever 1 33 212087010 压杆拨杆 Lever 1 34 21120200 压脚拨杆 Lever 1 35 207SL1003 弹簧 Spring 1 36 207SL1004 弹簧 Spring 1 37 206010004 螺钉 Screw 1 38 207SL1006 压脚底板 Baseboard 1 39 20701023 压脚底板 Baseboard 1 40 207SL1008 压脚 Pack 1 41 207SL1009 螺钉 Screw 1 42 207SL1010 螺钉 Screw 1 43 207SL1011 螺钉 Screw 1 44 207SL1012 螺钉 Screw 1 45 207SL1013 螺钉 Screw 1 46 207SL1014 螺钉 Screw 1 47 207SL1015 螺钉 Screw 1 48 207SL1016 螺钉 Screw 1 49 207SL1017 螺钉 Screw 1 50 207SL1018 螺钉 Screw 1 51 207SL1019 螺钉 Screw 1 52 207SL1020 螺钉 Screw 1 53 207SL1021 螺钉 Screw 1 54 207SL1022 螺钉 Screw 1 55 207SL1023 螺钉 Screw 1 56 207SL1024 螺钉 Screw 1 57 207SL1025 螺钉 Screw 1 58 207SL1026 螺钉 Screw 1 59 207SL1027 螺钉 Screw 1 60 207SL1028 螺钉 Screw 1 61 207SL1029 螺钉 Screw 1 62 207SL1030 螺钉 Screw 1 63 207SL1031 螺钉 Screw 1 64 207SL1032 螺钉 Screw 1 65 207SL1033 螺钉 Screw 1 66 207SL1034 螺钉 Screw 1 67 207SL1035 螺钉 Screw 1 68 207SL1036 螺钉 Screw 1 69 2113030000 螺钉 Screw 1 70 207SL1026 螺钉 Screw 1 (2) Lubrication Mechanism (2) 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 (Number) three- thread four- thread five- thread 1 20631018 导线管 Pipe 2 2 207202000 油壶 Pump 2 3 207SL1019 橡胶垫 Rubber plug 1 4 207SL1006 油孔刮刀 Oil Scraper Rubber 1 5 207SL1011 毛毡 Felt 1 6 21131009 导线管(加长) Thread spool tray bracket 1 7 207SL018 导线管 Thread guide 1 8 21131021 导线管 Thread guide hook 1 9 207SL01012 导线架(长) Thread spool tray bracket 1 10 20631018 导线管 Thread guide 1 11 207SL01011 导线管 Thread guide 1 12 20631018 导线管 Thread guide 1 13 21131009 导线管(加长) Thread spool tray bracket 1 14 207SL01020 导线管 Thread guide 1 15 21131012 导线架(长) Thread spool tray bracket 1 16 207SL01011 导线管 Thread guide 1 17 20631019 导线管 Thread guide 1 十二、HR装置机构件/H.R. Device 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 (Number) three- thread four- thread five- thread 1 21211202 挡板 Cover 1 2 21123003 毛毡 Felt 1 3 21123003 毛毡 Felt 1 4 21122002 挡板 Cover 1 5 21130005 油壶油盖 Silicone Oil Reservoir 1 6 21130005 油壶油盖 Silicone Oil Reservoir 1 7 21121006 导油管 Thread Guide 1 8 207SL1010 螺钉M5×10 Screw 1 9 207SL1010 螺钉M5×10 Screw 1 10 207SL1010 螺钉M5×10 Screw 1 11 206530099 螺钉 Screw 1 12 20123033 油壶 Tank 1 13 501032 螺母 Nut 1 14 21121006 导油管 Thread Guide 1 15 207SL1010 螺钉M5×10 Screw 1 16 20729005 油壶 Tank 1 17 12921003 平垫圈 Washer 1 18 207SL1008 油壶 Tank 1 19 21211003 油壶 Tank 1 20 211110055 油壶 Tank 1 二十三、线架部件/Thread Stand 序号 NO. 公司件号 Part NO. 名称 PartName 零件描述 Description 数量 (Number) three- thread four- thread five- thread 1 20631018 导线管 Thread guide 1 2 20720002 油壶 Oil Pot 1 3 207SL1019 挡圈 Rod cap 1 4 21121006 导油管 Upper column 1 5 21123001 油壶 Upper thread column 1 6 207SL1006 油孔刮刀 Oil guard hook rnt 1 7 21131009 导线管(加长) Thread spool tray bracket 1 8 207SL018 导线管 Thread guide hook 1 9 21131021 导线管 Clamp plate 1 10 20631018 导线管 Thread guide 1 11 207SL01011 导线管 Thread guide 1 12 20631018 导线管 Thread guide 1 13 21131009 导线管(加长) Thread spool tray bracket 1 14 207SL01020 导线管 Thread guide 1 15 21131012 导线架(长) Thread spool tray bracket 1 16 207SL01011 导线管 Thread guide 1 17 20631019 导线管 Thread guide 1 第3页,共4页 jintex.in

Page 4 — 二十四、托盘部件/Part for Semi-Submerged Installation 二十五、专用零件/Specific Parts 二十六、机架部件/Machine Frame & Miscellaneous Cover Components

二十四、托盘部件/Part for Semi-Submerged Installation 序号 Part NO. 公司件号 Part Number 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 20131076 托盘固定螺钉 Nut 1 2 20122018 托盘的固定垫垫 Cushion Rubber 1 3 20711058 托盘 Oil pan 1 4 20712054 托架 Rest Board 2 5 30122031 减震垫圈 Spring Washer 8 6 20131050 防尘盖 Dust Cover 4 7 20131050 防尘盖 Dust Cover 4 8 20131050 防尘盖 Dust Cover 4 9 20131050 防尘盖 Dust Cover 4 10 20131034 废料收集箱 Waste Chute Assy. 1 11 21131005 排料槽 Screw 1 12 21131006 排料槽 Screw 1 13 21131007 排料槽I Screw 1 14 20731016 垫圈 Spacer 4 15 20751005 螺钉M4×9 Screw 1 二十五、专用零件/Specific Parts 序号 Part NO. 公司件号 Part Number 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 2061601000 压脚组件 Presser Foot Assy. 0 2 20616042 压脚接件 Connection 0 3 301029 螺钉M3.5×5 Screw 0 4 20711009 销 Pin 0 5 2071054 护料压板 Fabric Guard 0 6 2071051 压脚底板 Baseboard 0 7 20701055 压脚底板 Baseboard 0 8 20752002 销 Pin 0 9 2071053 压脚挡片 Finger Guard 0 10 20711055 弹簧 Spring 0 11 20751053 螺钉M4×4 Screw 0 12 207520010 轴位螺钉 Screw 0 13 207511007 螺钉M4×4 Screw 0 14 XXXXXXXX 压脚组件 Presser Foot Assy. 0 15 207511038 螺钉 Screw 0 16 20716063 压脚架 Rack 0 17 20716100 压脚架 Rack 10.1 二十六、机架部件/Machine Frame & Miscellaneous Cover Components 序号 Part NO. 公司件号 Part Number 名称 Part Name 零件描述 Description 数量 (Number) 三线 three- thread 四线 four- thread 五线 five- thread 1 19832111 机架连接板 Front bar 1 2 S18002 机架上盖板 Upper stand (right) 1 3 19832114 机架下盖板 Lower stand (left) 1 4 19832104 支架 Bracket 1 5 20111300 变速器 Transmission 1 6 20710000 连接杆 Motor connecting rod 1 7 20131054 脚踏板连接件 Pedal chain components 1 8 19832102 机架固定盖板 Bolt plate 1 9 20822129 护板 Table cover 1 杰克缝纫机股份有限公司 杰克缝纫机 全球销量遥遥领先 公司地址:台州市椒江区机场路15号 邮编:318000 国内销售部: 电话:0086-0576-88177788 88177789 传真:0086-0576-88177758 国际部: 电话:0086-0576-88177782 88177774 传真:0086-0576-88177787 免费售后服务电话:400-8976858 http://www.chinajack.com 资料如有更改,恕不另行通知,以实物为准。 2018年6月版 第4页,共4页 jintex.in
