Jack MX-100A — parts catalog
- Page 1 (toc): This page contains the table of contents for the industrial sewing machine parts catalog, listing various machine parts and their corresponding page numbers.
- Page 2 (diagram): This page displays a diagram of machine body components, with numbered parts indicated by reference numbers.
- Page 3 (parts_list): This page lists machine body parts, including part numbers, descriptions, quantities, and remarks. It contains 33 items.
- Page 4 (diagram): This page displays a diagram of the upper shaft mechanism, illustrating various components with reference numbers for identification.
- Page 5 (parts_list): This page lists parts for the upper shaft mechanism, including part numbers, descriptions, quantities, and remarks.
- Page 6 (diagram): This page displays a diagram of the needle bar mechanism, illustrating various components with reference numbers for identification.
- Page 7 (parts_list): This page lists parts for the C. Needle bar mechanism, including part numbers, names, quantities, and remarks.
- Page 8 (diagram): This page displays a diagram of the work clamp lifter mechanism, illustrating various components labeled with reference numbers.
- Page 9 (parts_list): This page lists parts for the D2, electronic middle presser foot clamp lifter mechanism, including part numbers, descriptions, quantities, and remarks.
- Page 10 (diagram): This page displays a diagram of the threading mechanism, with numbered parts indicated by reference numbers.
- Page 11 (parts_list): This page lists parts for the E, Threading mechanism, including part numbers, names, quantities, and remarks.
- Page 12 (diagram): This page displays a diagram of the thread trimmer mechanism, with numbered parts indicated for identification.
- Page 13 (parts_list): This page lists parts for the F, thread trimmer mechanism, including part numbers, names, quantities, and remarks.
- Page 14 (diagram): This page displays a diagram of the tension release mechanism, with numbered parts including bolts, washers, a spring, and a shaft.
- Page 15 (parts_list): This page lists parts for the G, Tension release mechanism, including part numbers, descriptions, quantities, and remarks.
- Page 16 (diagram): This page displays a diagram of the external work clamp mechanism, with numbered parts and their corresponding references.
- Page 17 (parts_list): This page lists parts for the external work clamp mechanism, including part numbers, names, quantities, and remarks.
- Page 18 (diagram): This page displays a diagram of the tread breakage detector mechanism, with numbered parts including a bracket, spring, and screw.
- Page 19 (parts_list): This page lists parts for the Tread breakage detector mechanism, including part numbers, names, quantities, and remarks.
- Page 20 (diagram): This page displays a diagram of the lower shaft mechanism, illustrating various components with reference numbers.
- Page 21 (parts_list): This page lists parts for the lower shaft mechanism, including part numbers, names, quantities, and remarks.
- Page 22 (diagram): This page displays a diagram of the thread trimmer mechanism, with numbered parts and their corresponding references.
- Page 23 (parts_list): This page lists parts for the K, cutting device / Thread trimmer mechanism, including part numbers, names, quantities, and remarks.
- Page 24 (diagram): This page displays a diagram of the thread trimmer mechanism, with numbered parts and their corresponding references.
- Page 25 (parts_list): This page lists parts for the K, cutting device / Thread trimmer mechanism, including part numbers, names, quantities, and remarks.
- Page 26 (diagram): This page displays a diagram of the rotating mechanism, with numbered parts and their corresponding labels.
- Page 27 (parts_list): This page lists parts for the L, Lower Rotating Mechanism, including part numbers, names, quantities, and remarks.
- Page 28 (diagram): This page displays a diagram of the rotating mechanism, with numbered parts and their corresponding labels.
- Page 29 (parts_list): This page lists parts for a sewing machine, including part numbers, descriptions, quantities, and some additional reference numbers.
- Page 30 (diagram): This page displays a diagram of the fusier oil supply mechanism, with numbered parts and their corresponding references.
- Page 31 (parts_list): This page lists parts for the M,旋梭供油装置 / Fusier oil supply mechanism, including part numbers, names, quantities, and remarks.
- Page 32 (diagram): This page displays a diagram of the N1, X Feed mechanism (S), showing various components with reference numbers for identification.
- Page 33 (parts_list): This page contains a parts list for the N1, X Feed mechanism (S) / X Feed mechanism (S) with part numbers, names, quantities, and remarks.
- Page 34 (diagram): This page displays a diagram of the N1, X Feed mechanism (S), illustrating various components with reference numbers for identification.
- Page 35 (parts_list): This page contains a parts list for various screws, nuts, gaskets, and other components, with part numbers, descriptions, and quantities.
- Page 36 (diagram): This page displays a diagram of the N2, X Feed mechanism (T), illustrating various components with reference numbers for identification.
- Page 37 (parts_list): This page lists parts for the N2, X Feed mechanism (T) / X Feed mechanism (T) with part numbers, descriptions, quantities, and remarks.
- Page 38 (diagram): This page displays a diagram of the N3, Y Feed mechanism, illustrating various components with reference numbers.
- Page 39 (parts_list): This page lists parts for the N3, Y Feed mechanism, including part numbers, names, quantities, and remarks.
- Page 40 (diagram): This page displays a diagram of the clamping fixture mechanism (S), with numbered parts indicated for identification.
- Page 41 (parts_list): This page lists parts for the N4, Clamping fixture mechanism (S) with part numbers, descriptions, quantities, and remarks.
- Page 42 (diagram): This page displays a diagram of the clamping fixture mechanism, illustrating various components with reference numbers.
- Page 43 (parts_list): This page contains a parts list for the N5, Clamping fixture mechanism (S) with columns for Part No., Part Name, Name of Parts, Quantity (Amt.), and Remarks.
- Page 44 (diagram): This page displays a diagram of the clamping fixture mechanism (T), with numbered parts indicated for reference.
- Page 45 (parts_list): This page lists parts for the N6, Clamping fixture mechanism (T), including part numbers, descriptions, quantities, and remarks.
- Page 46 (diagram): This page displays a diagram of the clamping fixture mechanism (T) with numbered parts. It includes components such as cylinders, brackets, screws, and rods, with reference numbers ranging from 1 to 37.
- Page 47 (parts_list): This page lists parts for the N7, Clamping fixture mechanism (T) / Clamping fixture mechanism (T) with part numbers, descriptions, quantities, and remarks.
- Page 48 (diagram): This page displays a diagram of the N8, X synchronous belt device (T) / X Feed mechanism (T), with numbered parts indicated.
- Page 49 (parts_list): This page lists parts for the N8, X synchronous belt device (T) / X Feed mechanism (T), including part numbers, descriptions, quantities, and remarks.
- Page 50 (diagram): This page displays a diagram of the machine body and table structure, with numbered parts indicated for identification.
- Page 51 (parts_list): This page lists parts for the main body/table structure of a sewing machine, including part numbers, names, quantities, and remarks.
- Page 52 (diagram): This page displays a diagram of the front table mechanism, with numbered parts and their corresponding references.
- Page 53 (parts_list): This page lists parts for the Front table mechanism, including part numbers, names, quantities, and remarks.
- Page 55 (parts_list): This page lists parts for the auxiliary table mechanism, including part numbers, names, quantities, and remarks.
- Page 56 (diagram): This page displays a diagram of the table mechanism and its components, with numbered parts for identification.
- Page 57 (parts_list): This page lists parts for the P1, machine frame/table mechanism, including part numbers, names, quantities, and remarks.
- Page 58 (diagram): This page displays a diagram of the electric control box mechanism, illustrating various components with reference numbers.
- Page 59 (parts_list): This page lists parts for the P2, Electric control box mechanism, including part numbers, names, quantities, and remarks.
- Page 60 (diagram): This page displays a diagram of the control box mechanism (X) with numbered components.
- Page 61 (parts_list): This page lists parts for the Control box mechanism (X), including part numbers, names, quantities, and remarks.
- Page 62 (diagram): This page displays a diagram of the operation interface mechanism, with numbered parts indicated by reference numbers.
- Page 63 (parts_list): This page lists parts for the R, Operation Interface Mechanism, including part numbers, names, quantities, and remarks.
- Page 64 (diagram): This page displays a diagram of power supply equipment mechanisms, illustrating various components with reference numbers.
- Page 65 (parts_list): This page lists parts for S, 电器部品装置 / Power supply equitment mechanism, including part numbers, descriptions, quantities, and remarks.
- Page 66 (diagram): This page displays a diagram of air pressure mechanism components, with numbered parts and their corresponding references.
- Page 67 (parts_list): This page lists parts for the Air pressure mechanism, including solenoid valve assemblies, screws, connectors, and tubing, with their corresponding part numbers, names, quantities, and remarks.
- Page 68 (diagram): This page displays a diagram of the bobbin winder mechanism, with numbered parts indicating components.
- Page 69 (parts_list): This page lists parts for the U, Bobbin winder mechanism, including part numbers, names, quantities, and remarks.
- Page 70 (diagram): This page displays a diagram of the bottom line detection mechanism, illustrating various components labeled with reference numbers.
- Page 71 (parts_list): This page lists parts for the X1, Bottom line detection mechanism, including part numbers, names, quantities, and remarks.
- Page 72 (diagram): This page displays a diagram of the laser cutting mechanism for the X2 machine, with numbered parts indicated.
- Page 73 (parts_list): This page lists parts for the X2 Laser Cutting Mechanism, including part numbers, names, quantities, and remarks.
- Page 74 (diagram): This page displays a diagram of the laser cutting mechanism, with numbered parts indicated by reference numbers.
- Page 75 (parts_list): This page lists parts for a sewing machine, including flat washers, screws, shell panels, integrated potentiometers, inching switches, and light outlets, with their corresponding part numbers and quantities.
- Page 76 (diagram): This page displays a diagram of the X6 laser cutting control part, with numbered components and their corresponding parts.
- Page 77 (parts_list): This page contains a parts list for the X6, Laser cutting control part, listing part numbers, names, quantities, and remarks.
- Page 78 (diagram): This page displays a diagram of laser cutting smoke exhaust parts, with numbered components and their corresponding labels.
- Page 79 (parts_list): This page lists parts for the X3 Laser cutting smoke exhaust part, including part numbers, names, quantities, and remarks.
- Page 80 (diagram): This page displays a diagram of laser cutting smoke exhaust parts, with numbered components and their corresponding part numbers and descriptions.
- Page 81 (parts_list): This page lists parts with numbers 142012173 and 142037005, described as 'Light barrier' and 'label' respectively, with a quantity of 1 for each.
- Page 82 (diagram): This page displays a diagram of the point pen mechanism, with numbered parts indicated by reference numbers.
- Page 83 (parts_list): This page lists parts for the X4, Point Pen Mechanism, including part numbers, descriptions, quantities, and remarks.
- Page 84 (diagram): This page displays a diagram of the X5, Internet of Things components, including a circuit board, connectors, and cables, labeled with reference numbers 1 through 5.
- Page 85 (parts_list): This page lists parts for the X5, Internet of Things device, including part numbers, names, quantities, and remarks.
- Page 87 (parts_list): This page lists accessories for the sewing machine, including various tools, fasteners, and labels, with their corresponding part numbers and quantities.
Page 1 — 目錄/CONTENTS
目錄/CONTENTS
A、机体部分 / Machine body
B、上轴装置 / Upper shaft mechanism
C、针杆装置 / Needle bar mechanism
D2、电子中压脚装置/ Work clamp lifter mechanism
E、穿线装置/ Threading mechanism
F、扫线装置/ Thread trimmer mechanism
G、松线装置/ Tension release mechanism
H、大压脚装置/ External work clamp mechanism
I、断线感应装置/Tread breakage dectetor mechanism
J、下轴装置/Lower shaft mechanism
K、切线装置/Thread trimmer mechanism
K、切线装置/Thread trimmer mechanism
L、下旋转装置/Lower shaft mechanism
L、下旋转装置/Lower shaft mechanism
M、旋梭供油装置/Fusier oil supply mechanism
N1、X送料装置(S)/X Feed mechanism (S)
N1、X送料装置(S)/X Feed mechanism (S)
N2、X送料装置(T)/X Feed mechanism (T)
N3、Y送料装置/Y Feed mechanism
N4、压框夹具装置(S)/Clamping fixture (S)
N5、夹扣夹具装置(S)/Clamping fixture (S)
N6、压紧夹具装置(T)/Clamping fixture mechanism (T)
N7、夹扣夹具装置(T)/Clamping fixture mechanism (T)
N8、X同步带装置(T)/X Feed mechanism (T)
01、主台面部分/Machine body (Table structure)
02、前台面部分/Front table mechanism
03、辅助台面部分/Auxiliary table mechanism
P1、机架部件/Table mechanism
P2、电控柜装置/Electric control box mechanism
Q、控制箱装置(X)/Control box mechanism (X)
R、操作界面装置/Operation interface mechanism
S、电器部品装置/Power supply equitment mechanism
T、空压装置/Air pressure mechanism
U、卷线装置/Bobbin winder mechanism
X1、底线检测装置/Bottom line detection mechanism
X2、激光切割装置/Laser Cutting Device
X6、激光控制部分/Laser cutting control part
X3、激光切割吸风装置/LASER CUTTING SUCTION DEVICE
X4、点笔装置/Pint Pen Mechanism
X5、物联网装置/The Internet of Things
Z、附件/Accessories
jintex.in
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
61
63
65
67
69
71
75
77
81
83
85
Page 2 — A1、机体部分 / Machine body
A1、机体部分 / Machine body
3
4
1
2
5
6
1
7
8
9
10
14
15
16
32
17
11
18
19
20
21
22
23
25
26
1
24
28
27
25
29
26
24
30
31
25
3
jintex.in
Page 3 — A、机体部分 / Machine body
A、机体部分 / Machine body
序号
No.
件号
Part. No.
零部件名称
1
2
3
4
5
6
7
8
9
10
11
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
S04078
930000811
417S30306
930000812
141912078
930000813
S04029
14437001
930000814
141922012
417S15008
S05133
S02918
930000959
42536004
421S11011
141944002
S05123
141901096
41722003
40622014
930000544
421S13012
930000478
S04029
141944004
930000444
P02012
S05275
141912182
141937003
螺钉M4×8
挑线杆轴侧盖板
螺钉M5×15
侧窗盖板
挑线杆保护罩
挑线杆罩壳
螺钉M5×12
面板商标牌
机头前盖板
机头面板垫片
螺钉M4×8
螺钉M4×12
螺钉M4×8
针杆同步带罩壳
气管接头(直角)
螺钉M4×6
针杆电机罩壳
螺钉M5×12
针杆旋转电机安装座B
橡皮塞10.5
油封
机身铸造孔盖板
螺钉M4×10
机身侧盖板
螺钉M5×12
后罩
机头底座后盖板
销子
螺钉M20×55
气管接头安装板
蓝条
NAME OF PARTS
Screw M4 × 8
Side cover plate of take-up rod shaft
Screw M5 * 12
Side window cover
Wire rod protection cover
Wire rod housing
Screw M5 * 12
Panel trademark
Head front cover plate
Head panel gasket
M4x 8
Screw M4 × 12
Screw M4 × 8
Needle rod synchronous belt housing
Air pipe joint (right Angle)
Screw M4 × 10
Needle bar motor cover
Screw M5 * 12
Needle bar rotary motor mounting seat
Rubber plug 10.5
Oil seal
Fuselage side cover
Screw M4 × 10
Fuselage side cover
Screw M5 * 12
Back cover
Rear cover plate of machine base
pin
Screw M20 x 55
Air pipe connector mounting plate
Blue bar
数量
Amt.
16
1
6
1
1
1
1
3
1
1
1
2
3
3
1
1
3
1
4
1
7
1
2
12
2
1
2
6
1
1
备注
Remarks
141912242
141901100
141901103
141901108
141912208
141912194
142012083
930000805
jintex.in
Page 4 — B、上轴装置 / Upper shaft mechanism
B、上轴装置 / Upper shaft mechanism
19
20
23
24
25
26
22
21
29
31
27
28
7
12
7
10
7
8
39
7
6
14
15
7
5
4
3
2
13
7
5
4
3
2
16
17
9
10
18
33
34
35
36
36
37
38
E
jintex.in
Page 5 — B、上轴装置 / Upper shaft mechanism
B、上轴装置 / Upper shaft mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
141902026
挑线杆轴
Thread take-up shaft
1
2
418S30218
螺钉M4×4
Screw M4 × 7
4
3
B10014
深沟球轴承6904-DDUNR
Deep groove ball bearing 6904-DDUNR
2
4
B06005
深沟球轴承6904-DDU
Deep groove ball bearing 6904-DDU
2
5
41803211
轴承套
Bearing sleeve
2
6
141935008
上轴同步带
Upper axle synchronous belt
1
7
S10019
螺钉M6×6
Screw M6 × 6
14
8
141935009
针杆同步轮
Needle bar synchronizer wheel
1
9
141903019
轴承套
Bearing sleeve
2
10
B01024
深沟球轴承6804Z
Deep groove ball bearing 6804Z
1
11
141901101
手轮
The handwheel
1
12
403S11003
开槽大圆柱头螺钉
Slotted large cylindrical head screw
1
13
141902027
针杆轴
Needle bar shaft
1
14
S05123
螺钉M5×12
Screw M5 × 12
2
15
141904011
机头上节偏心轮夹板
Upper Eccentric wheel plate
1
16
141904010
机头上节偏心轮
Upper Eccentric wheel
1
17
14193500700
挑线杆轴同步轮组件
Reel shaft synchronous wheel assembly
1
18
141903014
主轴电机联轴器
Spindle motor coupling
1
19
S05040
螺钉M6×16
Screw M6 × 16
2
20
141901102
张紧轮调节座
Tensioner adjusting seat
1
21
L02032
螺钉M6×12
Screw M6 × 12
2
22
141901104
张紧轮座
The tension wheel
1
23
42528003
轴承垫圈
Bearing washer
1
24
B03005
轴承
Bearing
2
25
141903018
张紧轮
Tension wheel
1
26
421S13057
内六角圆柱头螺钉
Hexagon socket cylindrical head screw
1
27
S05035
螺钉M5×25
Screw M5x 25
4
28
141901105
上轴电机安装座
Upper shaft motor mounting base
1
29
S05123
螺钉M5×12
Screw M5×12
4
31
141933013
下轴电机
The shaft motor
1
33
40322027
橡皮塞
Rubber plug
1
34
421S13003
螺钉M4×8
Screw M4 × 8
2
35
14191101600
油壶
Oil can
1
36
10122005
橡皮塞
Rubber plug
3
37
417S30036
螺钉M5×12
Screw M5×12
2
38
141912203
油壶安装支架
Oil pot mounting bracket
1
39
141902029
同步轮顶柱
Synchronous wheel top column
2
I
jintex.in
Page 6 — C、针杆装置 / Needle bar mechanism
C、针杆装置 / Needle bar mechanism
jintex.in
Page 7 — C. 针杆装置 / Needle bar mechanism
C. 针杆装置 / Needle bar mechanism
序号
No.
件号
Part. No.
零部件名称
零 部 件 名 称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
14193800300
挑线杆连杆组件
Take-up lever assembly
1
15
141904004
挑线曲柄
Take up crank
1
16
409s14003
针杆曲柄螺钉
Needle bar crank screw
4
17
141912201
针杆曲柄垫圈
Needle bar crank washer
1
18
101S15004
针杆曲柄固定螺钉
Needle bar crank setting screw
2
19
135S11002
针杆曲柄定位螺钉
Needle bar crank setting screw
2
20
141904005
针杆曲柄
Needle bar crank
1
21
41703005
针杆上套
Needle bar position
1
22
141902028
旋转针杆
Rotate needle bar
1
23
201S15001
夹线螺钉紧固螺钉
Clamp screw fastening screw
1
24
42217504
机针
needle
1
25
141901076
针杆紧圈E
Needle bar tightening ring E
1
26
S05133
螺钉M4×12
Screw M4 × 12
2
27
141904013
针杆接头C
Pin connector assembly
1
28
141912167
针杆零位感应片
Needle bar zero sensor
1
29
141909013
旋转针杆夹块B
Rotate pin clamp
1
30
141903029
针杆下套B
Needle bar under cover B
1
33
B06043
61902-2Z
61902-2Z
1
34
141908005
针杆旋转轴承挡圈
Needle bar rotate bearing retainer
1
35
B10051
6902LLUNR
6902LLUNR
1
36
418S30218
一字球面螺钉M4×7
Spherical screw M4×7
2
37
S10007
内六角凹端紧定螺钉M4×4
Hexagon socket set screw M4×4
2
38
S09012
内六角紧定螺钉M4×5
Inner hexangular set screw M4×5
1
39
141935027
针杆同步轮
Needle bar synchronizer wheel
1
40
141935022
针杆旋转同步带
Needle bar rotate synchronous belt
1
41
42230534
针杆旋转电机
Needle bar rotating motor
1
43
S05218
螺钉M5×22
Screw M5 * 22
4
44
14193502000
旋转电机同步轮组件B
Rotating motor synchronous wheel assembly
1
45
421S13035
螺钉M4×8
Screw M4 x 8
3
46
141912237
传感器安装板
Sensor mounting plate
1
47
41730851
传感器
Sensor
1
48
S04076
螺钉M3×8
Screw M3 x 8
1
49
14193800400
针杆连杆组件
Pin rod connecting rod assembly
1
50
41709001
滑块
sider
1
51
207S11008
螺钉M4×12
Screw M4 x 12
2
52
142009004
针杆滑块导向
Needle bar slider guide
1
53
14198S0001
针杆螺钉
Slot screws M4 x 10
2
54
141912202
板螺母
pate nut
2
55
41712069
油线挂钩
Oil line hook
1
56
41712070
油线支架
Oil line support
1
57
12923018
油线
Oil thread
1.9
58
12921002
油管
Oil tube
1.7
61
S10006
螺钉M5×6
Screw M5 x 6
1
62
141912241
针杆传感器保护板
Needle bar sensor protection plate
1
63
40322031
油封
oil seal
1
64
H01118
孔用弹性挡圈
Circlip for hole
1
Page 8 — D2、电子中压脚装置 / Work clamp lifter mechanism
D2、电子中压脚装置 / Work clamp lifter mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
24
15
16
17
14
18
19
20
21
22
23
21
L
jintex.in
Page 9 — D2、电子中压脚装置 / Work clamp lifter mechanism
D2、电子中压脚装置 / Work clamp lifter mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
141904007
中压脚摇杆
Middle presser foot rocker
1
2
B04036
轴承61900
Bearing 61900
1
3
142003011
轴承挡套
Bearing block
1
4
S05124
螺钉M5×16
Screw the M5 * 16
4
5
141912152
中压脚电机安装板
Middle presser foot motor mounting plate
1
6
142033004
中压脚步进电机
Middle presser foot feed motor
1
7
S05123
螺钉M5×12
Screw M5 * 12
1
8
S09019
锁紧螺钉M5×5
Locking screw M5×5
1
9
S05004
螺钉M5×14
Screw M5 * 14
1
10
142026002
连杆销
The connecting rod pin
1
11
142003006
工程塑料轴套GLW-0709-05
Engineering plastic shaft sleeve GLW-0709-05
2
12
142005001
中压脚连杆
Middle presser foot link
1
13
1420NS20001
轴位螺钉M6×0.75
Axial screw M6×0.75
1
14
41822101
橡胶套
Rubber sleeve
1
15
421S13035
螺钉M4×8
Screw the M4 x 8
1
16
41709020
压紧接头
Tighten rod joint
1
17
141902011
中压脚杆A
Middle presser foot bar A
1
18
41803031
中压杆轴套
Middle pressure shaft sleeve
1
19
41822612
油封
Oil seal
1
20
141901019
中压脚转接块
Intermediate presser foot transfer block
1
21
417S15011
螺钉SM9-64
Screw SM9-64
2
22
41728025
平垫圈
Flat washer
1
23
141916003
中压脚
Middle presser foot
1
24
14200500100
中压脚连杆组件
Middle presser foot connecting rod assembly
1
jintex.in
Page 10 — E、穿线装置 / Threading mechanism
E、穿线装置 / Threading mechanism
19 5 20 21 22 3 5 4 2 6 1 18 7 8 9 11 10 12 13 14 15 16 5 17 1
E
jintex.in
Page 11 — E, 穿线装置/ Threading mechanism
E, 穿线装置/ Threading mechanism
No.
序号
Part. No.
件号
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
40322027
橡胶塞
Rubber plug
2
2
141945013
夹线气缸B
Wire clamping cylinder B
1
3
42536004
气管接头
Tracheal joint
1
4
141912239
小夹线气缸安装板
Mounting plate of small wire clamping cylinder
1
5
S04078
螺钉M4×8
Screw M4 x 8
5
6
142345002
气管接头
Tracheal joint
1
7
41712077
过线导向板
Line guide plate
1
8
S04028
螺钉M5×8
Screw the M5 x 8
2
9
4171301400
副夹线器组件
Auxiliary clamp assembly
1
10
S0019
螺钉M6×6
Screw M6 x 6
1
11
141901029
夹线器安装座
Clamp mounting seat
1
12
S05962
螺钉M6×12
Screw M6 x 12
1
13
41813613
松线销
Loose thread pin
1
14
4181361200
夹线器
Thread clamp device
1
15
41712079
过线器C
Wire passer C
1
16
141912108
夹线器过线勾
Clamp wire hook
1
17
141926012
过线柱
Wire passer column
2
18
S09019
螺钉M5×5
Screw M5 x 5
1
19
S05192
螺钉M3×6
Screw M3 x 6
2
20
141912238
夹线气缸电磁阀支撑座
support seat
1
21
141945019
双通电磁阀
Two way solenoid valve
1
22
1421300100
上过线组件
Upper threading assembly
1
jintex.in
Page 12 — F、扫线装置/ Thread trimmer mechanism
F、扫线装置/ Thread trimmer mechanism
1
4
9
10
30
7
29
8
11
12
25
16
15
17
14
19
20
26
27
28
21
23
24
22
jintex.in
Page 13 — F、扫线装置/ Thread trimmer mechanism
F、扫线装置/ Thread trimmer mechanism
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
141930029
扫线电磁铁2.9
wiper electromagnet 2.9
1
4
41811213
电磁铁盖
Electromagnet cover
1
6
W01002
M3垫片
The M3 gasket
1
7
4181226100
扫线电磁铁安装板组件
Sweep electromagnet mounting plate assembly
1
8
41822213
缓冲块
Buffer block
1
9
W01002
M3垫片
The M3 gasket
1
10
S04082
螺钉M3×6
Screw M3 * 6
4
11
41826215
销子
pin
1
12
41803223
铜垫圈
Copper gaskets
1
13
418S20213
轴位螺钉B
Shaft screw B
1
14
41812264
驱动摆杆
Drive the swinging rod
1
15
41803225
套管
casing
1
16
41827212
扭簧
1
17
418S20212
轴位螺钉A
Shaft screw A
1
18
141912170
扫线连杆
Sweep line connecting rod
1
19
H03057
开口挡圈3
Open retainer 3
1
20
4180421400
扫线曲柄组件
Sweep crank assembly
1
21
H05006
挡圈5
Retaining ring 5
1
22
41827211
扫线钢丝
Sweep line wire
1
23
41803220
挡线轴挡圈
Spool retainer
1
24
417S15013
螺钉M4×5
Screw the M4 x 5
1
25
417S30036
螺栓(带垫圈)M5×12
Bolt (with washer)M5 x 12
2
26
41845232
T形接管KJT04
T-junction KJT04
1
27
S01591
螺钉M3×18
Screw M3 by 18
1
28
W01002
M3垫片
The M3 gasket
1
29
141912088
扫线装置支架
Wire sweeping device bracket
1
30
S05123
螺钉M5×12
Screw M5 * 12
2
Page 14 — G、松线装置/ Tension release mechanism
G、松线装置/ Tension release mechanism
1
3
2
4
14
13
14
15
16
5
6
7
8
9
10
11
12
Page 15 — G、松线装置/ Tension release mechanism
G、松线装置/ Tension release mechanism
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
417S30012
段螺钉7-3
7-3 section of the screw
2
2
41722021
0形圈P7
O ring P7
1
3
41711211
电磁铁盖
Electromagnet cover
1
4
141930030
松线电磁铁HV2.9m
Loose wire electromagnet HV2.9m
1
5
41712099
电磁铁安装板
Electromagnet mounting plate
1
6
W01001
平垫圈M4
Flat washer M4
2
7
W02008
弹簧垫圈2-4
Spring washer 2-4
2
8
L02031
螺栓M4×8
Bolt the M4 x 8
2
9
41722020
电磁铁缓冲垫圈
Electromagnet buffer washer
1
10
W01001
平垫圈M4
Flat washer M4
1
11
N01024
六角螺母M4
Hexagon nut M4
1
12
L02036
螺栓M4×14
Bolt M4 x 14
1
13
H05029
挡圈E4
Retaining ring E4
1
14
W01009
平垫圈M5
Flat washer M5
1
15
141926007
松线杆
Pine pole
2
16
41727013
弹簧
spring
1
jintex.in
Page 16 — H、大压脚装置 / External work clamp mechanism
H、大压脚装置 / External work clamp mechanism
1
1
2
3
4
5
6
7
16
9
8
10
11
14
15
12
13
支
jintex.in
Page 17 — H、大压脚装置 / External work clamp mechanism
H、大压脚装置 / External work clamp mechanism
序号
No.
件号
Part. No.
零部件名称
零
NAME OF PARTS
数量
Amt.
备注
Remarts
1
141936002
排气调速接头
Exhaust gas speed regulating joint
2
2
141945015
中压脚升降气缸
Middle presser foot lift cylinder
1
3
S05123
螺钉M5×12
Screw M5 × 12
2
4
141912240
大压脚气缸安装板
Large presser foot cylinder mounting plate
1
5
141902025
大压脚脚杆
Large presser foot rod
1
6
4250400600
浮动接头
Floating joint
1
7
41709020
压紧接头
Tighten rod joint
1
8
S05118
螺钉M4×16
Screw the M4 × 16
4
9
41801064
铜管压板
Copper tube pressing plate
1
10
141845007
软管TUS0425N
Hose tus0425n
1
11
141921007
吹气铜管
Blowing copper pipe
1
12
14191600400
大压脚
Big presser foot
1
13
S05192
螺钉M3×6
Screw M3 × 6
2
14
S05115
螺钉M4×6
Screw M4 * 6
2
15
41703015
压紧杆轴套
Compression rod shaft sleeve
1
16
421S13035
螺钉M4×8
Screw the M4 × 8
1
jintex.in
元
Page 18 — I、断线感应装置/Tread breakage dectetor mechanism
I、断线感应装置/Tread breakage dectetor mechanism
1
2
3
4
5
6
jintex.in
Page 19 — I、断线感应装置/Tread breakage dectetor mechanism
I、断线感应装置/Tread breakage dectetor mechanism
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
41711054
传感器内绝缘片
Sensor internal insulation sheet
1
2
42212837
感应铜片
Induction of copper
1
3
141830008
单芯线(0.2mm)
Single core wire (0.2mm)
3
4
41711053
传感器外绝缘片
Sensor outer insulation sheet
1
5
W01001
M4垫片
The M4 gasket
1
6
S04078
螺钉M4×8
Screw M4 x 8
1
九
jintex.in
Page 20 — J、下轴装置 / Lower shaft mechanism
J、下轴装置 / Lower shaft mechanism
jintex.in
Page 21 — J、下轴装置 / Lower shaft mechanism
J、下轴装置 / Lower shaft mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
11510001
凸轮
CAM
1
2
11309030
凸轮顶柱
CAM needle
2
3
116S14005
螺钉SM1/4(40)×10
Screw SM1/4 x 10 (40)
2
4
H01106
孔用弹性挡圈24
Elastic retainer for hole 24
1
5
113S14002
螺钉SM11/64(40)×5.5
Screw SM11/64 x 5.5 (40)
2
6
141903007
下轴轴承套
Lower shaft bearing sleeve
1
7
B01060
轴承61901-2RZ
Rz bearing 61901-2
2
8
413S14006
螺钉M4×4
Screw the M4 x 4
2
9
42508003
挑线连杆销紧圈
Connecting rod pin tightening ring
1
10
418S30218
螺钉M4×7
Screw the M4 x 7
2
11
42218002
梭芯组件
Bobbin sleeve assembly
1
12
10818501
梭芯
The bobbin
1
13
42218003
旋梭组件
Hook component
1
14
11522001
油封
Oil seal
1
15
42203509
下轴前轴套
Lower shaft front sleeve
1
16
1142201400
下轴前轴套油封
Oil seal for lower shaft front sleeve
1
17
141903009
下轴油芯套
Lower shaft oil mandrel
1
18
141822002
0形圈
o-ring
1
19
141823001
下轴限油芯
Lower shaft limiting oil core
1
20
141902002
下轴
The shaft
1
21
141935001
下节小同步轮
Lower section small sync wheel
1
22
S09019
螺钉M5×5
Screw M5 x5
3
23
S05124
螺钉M5×16
Screw M5 * 16
4
24
141933013
下轴电机
The shaft motor
1
25
14193500200
下节同步轮组件
Next section large synchronous wheel assembly
1
26
S10009
螺钉M6×8
Screw M6 x 8
4
27
141935004
下节同步带15-300-S3M
The next section of the synchronous belt is 15-300-S3M
1
28
141903008
下节张紧轮轴套
Lower section tensioning wheel shaft sleeve
1
29
42528003
轴承垫圈
Bearing washer
1
30
B03005
轴承608Z
Bearing 608 z
2
31
141903018
张紧轮
Tension wheel
1
32
421S13057
螺钉M8×30
Screw the M8 by 30
1
33
421S13035
螺钉M3×6
Screw M3 * 6
4
34
9300000423
下轴电机盖板
Lower shaft motor cover plate
1
141912135
35
141912134
侧盖板
The side cover
1
36
421S13035
螺钉M4×8
Screw M4 x 8
4
jintex.in
Page 22 — K、切线装置 / Thread trimmer mechanism
K、切线装置 / Thread trimmer mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
22
22
22
22
jintex.in
Page 23 — K,切线装置 / Thread trimmer mechanism
K,切线装置 / Thread trimmer mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
141915001
针板
The needle plate
1
2
41815011
针孔板Φ1.8T2.0
1.8T2.0pinhole plate phi
1
3
417S17001
螺钉SM2.38
Screw SM2.38
2
4
417S15008
螺钉M4×8
Screw the M4 x 8
5
5
142001008
定位勾组件安装座
Locating hook assembly mounting seat
1
6
413S11003
螺钉M5×16
Screw the M5 * 16
3
7
13112007
护针片
needle protection plate
1
8
114S11009
挂板螺钉
Hanging screw
1
9
141812022
定位勾
Positioning hook
1
10
402S11037
绕线器安装螺钉M5×10
Mounting screw M5×10 for winder
1
11
142012085
定刀垫片
fixed knife gasket
1
12
13119001
定刀
fixed knife
1
13
141909001
定刀压板
fixed knife holder
1
14
422S30514
螺钉SM1/8×44
SM1/8 x 44 screw
1
15
116S11005
牙架曲柄螺钉
Bracket crank screw
1
16
409S16025
螺母SM1/8×44
Nut SM1/8 x 44
1
17
S02031
螺钉M3×5
Screw M3 x 5
3
18
42212668
异形刀架压板
Special-shaped tool holder press plate
1
19
13119004
动刀
moving knife
1
20
1419NS17001
活动刀固定螺钉
Movable knife fixing screw
2
21
13107002
剪线刀架
Trimming knife rack
1
22
421S13035
螺钉M4×8
Screw the M4 x 8
8
23
141909005
剪线刀架支座
trimming knife holder
1
24
141912040
剪线刀架支座垫片
trimming knife holder gasket
1
25
11503004
切刀驱动轴套
Cutter drive shaft sleeve
1
26
11322002
扭簧端盖
1
27
141927001
剪线弹簧
Trimming spring
1
28
141902001
切线驱动轴
Tangential drive shaft
1
29
1150400200
切线凸轮曲柄组件
Tangential CAM crank assembly
1
30
409S14003
针杆曲柄定位螺钉
Needle bar crank pin setting screw
1
31
H05031
挡圈E6
Retaining ring E6
1
32
10112003
针杆曲柄护板
Needle bar crank guard
1
33
11322003
电磁铁缓冲垫
Electromagnet cushion
1
34
S02039
螺钉M4×9
M4 x 9 screw
4
35
141912110
剪线气缸安装板
Wire cutting cylinder mounting plate
1
36
141930005
切线气缸
The tangent cylinder
1
37
42230519
微型接头M-5HLH-4
Miniature connector M-5HLH-4
2
38
417S30036
螺钉M5×12
screw M5 * 12
2
jintex.in
Page 24 — K、切线装置 / Thread trimmer mechanism
K、切线装置 / Thread trimmer mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
22
22
56
56
7E
jintex.in
Page 25 — K, 切线装置 / Thread trimmer mechanism
K, 切线装置 / Thread trimmer mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
39
113S20001
连杆螺钉
The connecting rod screws
2
40
11505001
连杆
Connecting rod
1
41
13128003
连杆垫片
Connecting rod gasket
1
42
141903024
剪线曲柄轴止动块B
Shear line crank shaft stop B
1
43
S10019
螺钉M6×6
Screw M6 x 6
1
44
141904003
剪线曲柄
Trimming the crank
1
45
S05004
螺钉M5×14
Trimming the crank
1
46
141903002
切线轴套
Tangent collar
1
47
42203517
切线曲柄轴短套
Tangent crank shaft stub sleeve
1
48
141903025
切线凸轮曲柄轴B
Tangent CAM crank shaft B
1
49
11527001
复位弹簧
Reset spring
1
50
141912013
剪线曲柄复位弹簧安装板
Shear line crank reset spring mounting plate
1
51
141922008
缓冲垫
cushion
1
52
N01021
螺母M6
Nut M6
2
53
S05073
螺钉M6×40
Screw M6 x 40
1
54
141912136
切线调节盖板
Tangent adjustment cover plate
1
55
141921003
吹气铜管左
Blow brass left
1
56
418S30218
螺钉M4×7
Screw the M4 x 7
6
57
141921002
吹气铜管右
Blow brass right
1
58
41711014
电线夹6.4
Wire clip 6.4
1
59
417S30025
螺栓(带垫圈)M4×10DB
Bolt (with washer)M4×10DB
2
60
41711015
电线夹13.2
Wire clip 13.2
1
61
141912205
切线调节盖板垫片
Tangent regulating cover gasket
1
jintex.in
Page 26 — L、下旋转装置 / Rotating mechanism
L、下旋转装置 / Rotating mechanism
2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
62
16
17
18
19
20
21
22
11
23
24
25
26
29
28
25
32
33
34
35
36
37
38
39
40
41
42
43
25
27
59
31
30
25
11
44
45
46
47
48
18
49
1
57
58
50
51
52
53
54
55
2
60
61
27
jintex.in
Page 27 — L, 下旋转装置 / Rotating mechanism
L, 下旋转装置 / Rotating mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
S05085
螺钉M6×15
Screw M6 x 15
15
2
S05123
螺钉M5×12
Screw M5 x 12
13
3
141912156
旋转法兰盘C
Rotating flange C
1
4
141903052
下节旋套D
Lower section rotary sleeve D
1
5
B04074
轴承6013-2RS
Bearing 6013-2RS
1
6
141935025
同步带615-5M-30
Synchronous belt 615-5M-30
1
7
417S30002
螺钉M8×14
Screw M8 x 14
2
8
S10025
螺钉M8×8
Screw M8 x 8
1
9
14193502400
下节旋转大同步轮组件
Next rotary Datong step wheel assembly
1
10
B06049
轴承6912-2RS
Bearing
11
418S30218
螺钉M4×7
Screw M4 x 7
11
12
141908002
下机头旋套挡圈
Lower nose rotary retainer ring
1
13
S10002
螺钉M6×6
Screw M6 x 6
3
14
141903012
下节滑环转接板
Lower slide ring adapter plate
1
15
413S13011
螺钉M4×12
Screw M4 x 12
4
16
S05073
螺钉M6×40
Screw M6 x 40
2
17
413S13013
螺钉M6×25
Screw M6 x 25
2
18
N01021
螺母M6
Nut M6
10
19
141912143
调节板C
Adjustment plate C
2
20
S05993
螺栓M16×55
Bolt M6 x 55
4
21
417S30025
螺栓(带垫圈)M4×10DB
Bolt (with washer) M4 x 10DB
1
22
41311001
线夹
Wire clip
1
23
421S10005
螺钉M3×6
Screw M6 x 25
1
24
41730851
传感器
The sensor
1
25
421S13012
螺钉M4×10
Screw M4 x 10
16
26
41812023
Y传感器安装座
Y sensor mounting seat
1
27
141912091
下旋转感应片
Lower rotation sensor
1
28
930000849
下节同步轮箱盖板B
Cover plate B of lower synchronous wheel box
1
141912255
29
141912256
下节同步轮箱垫片
Lower synchronous wheel box gasket
1
30
12936004
油管嘴
Tubing mouth
1
31
141912259
同步带测量孔盖板B
Timing belt measuring hole cover plate B
1
32
421S13035
螺钉M4×8
Screw M4 x 8
4
33
930000834
小同步轮盖板
Small synchronous wheel seat cover plate
1
141912128
34
141901110
小同步轮轴承座B
Small synchronous wheel bearing seat B
1
35
B04118
轴承6005-2Z
Bearing 6005-2Z
1
36
141935026
下节旋转小同步轮B
Rotating small synchronous wheel B in the next section
1
37
S10019
螺钉M6×6
Screw M6 x 6
4
38
141933008
下节旋转电机B
Lower rotary motor B
1
39
S05111
螺钉M6×20
Screw M6 x 20
12
40
S05118
螺钉M4×16
Screw M4 x 16
4
41
141930031
滑环
Slip ring
1
42
42536004
气管接头
Tracheal joint
4
43
141912254
止转板C
Stop turning plate
1
44
N01011
螺母M8
Nut M8
2
45
141926009
止转杆
Anti rotation rod
1
46
141903017
止转尼龙套
Non-rotating nylon sleeve
1
47
13829001
轴用弹性挡圈6
Circlip 6 for shaft
1
48
14112090
调节板B
Adjusting plate B
2
49
S05998
螺钉M6×65
Screw M6 x 65
2
50
141903053
下节同步带张紧轮
Lower synchronous belt tensioner
1
51
H01011
孔用弹性挡圈28
Circlip for hole 28
2
52
B01058
轴承(6001-Z)
Bearing (6001-Z)
2
jintex.in
Page 28 — L、下旋转装置 / Rotating mechanism
L、下旋转装置 / Rotating mechanism
2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
62
16
17
18
19
20
21
22
11
23
24
25
26
59
31
25
30
11
44
45
46
47
48
18
49
57
58
50
51
52
53
54
2
55
28
25
32
29
56
33
2
34
60
35
36
37
40
41
42
43
25
39
27
jintex.in
27
Page 29
53 141901048 下节同步带张紧轮座 Lower synchronous belt tensioner seat 1
54 141912253 张紧轮调节板B Tensioning wheel adjusting plate B 1
55 421S13065 螺钉M5×16 Screw M5 x 16 2
56 930000830 下节同步轮箱盖板B Cover plate B of lower synchronous wheel box 1 141901111
57 S05110 螺钉M6×12 Screw M6 x 12 1
58 W01021 垫圈6.3×18×1.2 Washer6.3×18×1.2 1
59 930000821 下节同步轮箱体B(喷漆) Lower synchronous wheel box B 1 141901112
60 40736048 接头KJS4-M5 Joint KJS4 - M5 4
61 141903041 滑环安装孔绝缘法兰 Slip ring mounting hole insulating flange 4
62 141911024 滑环绝缘垫片 Slip ring insulating gasket 1
63 41828013 大垫片 The big washer 4
jintex.in
Page 30
M、旋梭供油装置 / Fusier oil supply mechanism
1
2
3
4
5
6
7
27
35 36
22
23
24
25
22
23
24
14
18
19
20
21
9
13
6
34
7
8
17
24
7
15
26
27
28
29
30
31
16
12
11
10
32
33
jintex.in
Page 31 — M、旋梭供油装置 / Fusier oil supply mechanism
M、旋梭供油装置 / Fusier oil supply mechanism
序号
No.
件号
Part. No.
零部件名称
1
10526003
柱塞
2
11427021
柱塞弹簧
3
10122010
0形圈
4
114S30010
插座螺钉
5
114S30009
润滑连接器
6
11412055
Φ5.7油管卡簧
7
12921002
维尼龙油管(Φ3×Φ5)
8
4183601700
滤网组件
9
41836015
油管嘴M5
10
142009002
调节阀座A
11
001004
0形圈
12
418S30612
调节螺钉
13
S04030
复合槽螺钉M5×6
14
141912249
油壶安装板
15
S05120
螺钉M5×8
16
421S13035
螺钉M4×8
17
40322027
橡皮塞
18
N01011
螺母M8
19
141911029
油壶C
20
915624
磁铁15×1
21
421S13003
螺钉M4×8
22
12936004
油管嘴
23
12912038
油管夹
24
12921006
维尼龙油管(Φ6×Φ8)
25
12923018
油线4×4
26
12921005
维尼龙油管(Φ4×Φ6)
27
41812014
废油壶安装板
28
40311010
油壶接头
29
421S10005
螺钉M3×6
30
40311011
回油油壶
31
421S13017
螺钉M5×10
32
141937007
油量标贴
33
41837101
油量调节标签
34
10123006
回油毡
35
12912326
线夹
36
421S13012
螺钉M4×10
NAME OF PARTS
Amt.
备注
plunger
1
Plunger spring
1
o-ring
1
Socket screws
1
Lubricating connector
3
5.7 Tubing spring
5
Vinylon tubing (3×5)
4
Filter elements
1
The line M5
2
Regulating seat A
1
o-ring
1
Adjusting screw
1
Composite slotted screw M5×6
1
Oil pot mounting plate
1
Screw the M5 x 8
2
Screw the M4 x 8
2
Rubber plug
5
Nut M8
1
Oil can C
1
The magnet 15 x 1
5
Screw the M4 x 8
6
Tubing mouth
2
Tubing clamps
3
Vinylon tubing (6×8)
2
Line 4 x 4
2
Vinylon tubing (4×6)
1
Waste oil pot mounting plate
1
The oil can joint
1
Screw M3 x 6
4
Oil return can
1
Screw the M5 * 10
2
Oil labeling
1
Fuel regulation label
1
Return felt
1
clamp
1
Screw M5 x 8
1
Jinttex.in
Page 32 — N1、X送料装置(S) / X Feed mechanism (S)
N1、X送料装置(S) / X Feed mechanism (S)
67
64
59
58
57
66
65
56
77
74
73
72
71
70
69
14
68
13
3
6
9
10
11
12
75
76
53
1
55
54
78
63
3
2
4
5
6
7
8
16
15
21
22
23
62
61
37
16
15
17
18
19
20
34
35
39
41
40
36
43
44
45
46
47
48
50
49
52
51
53
29
30
31
32
33
38
jintex.in
Page 33 — N1、X送料装置(S) / X Feed mechanism (S)
N1、X送料装置(S) / X Feed mechanism (S)
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
141801044
丝杆罩壳
Screw housing
1
2
141801051
端盖
End cap
1
3
S05124
螺钉M5×16
Screw M5×16
8
4
141812259
防尘钢带
Dust proof steel strip
1
5
141812260
钢压紧板
Steel bar pressing plate
1
6
S02039
沉头螺钉M4×9
Screw M4×9
4
7
141824012
导轨轴
Guide
2
8
141822019
软磁条
Soft magnetic stripe
2
9
141801050
电机安装座
Motor mounting base
1
10
141812260
传感器安装板
Sensor mounting plate
1
11
41730851
传感器
Sensor
1
12
421S10005
螺钉M3×6
Screw M3×6
1
13
930000441
电机罩壳
Motor housing
1
141812273
14
417S30025
螺钉(带垫圈)M4×10
Screw M4×10
3
15
141801045
轴承座
Bearing pedestal
2
16
417S30036
螺钉M5×10
Screw M5×10
8
17
B11011
轴承7001C DB
Bearing
2
18
141812258
轴承挡板
Bearing baffle
1
19
421S13035
螺钉M4×8
Screw M4×8
4
20
141824017
丝杆锁紧螺母
Screw lock nut
1
21
141824018
丝杆组件
Screw assembly
1
22
141801046
丝杆螺母安装座
Screw nut mounting base
1
23
141802030
轴位螺钉M5
Screw M5
4
24
W01001
平垫圈4
Washer 4
4
25
B01058
轴承6001ZZ
Bearing
2
26
142003007
联轴器
Coupling
1
27
142033005
X丝杆电机
X screw motor
1
28
S05118
螺钉M4×16
Screw M4×16
4
29
S02032
螺钉M3×5
Screw M3×5
8
30
141812281
油盒盖板B
Oil box cover plate B
1
31
141801067
油盒B
Oil box B
1
32
141823006
油毡
Asphalt felt
4
33
S05052
螺钉M3×10
Screw M3×10
4
34
141812280
油盒盖板A
Oil box cover plate A
1
35
141801066
油盒A
Oil box A
1
36
141801054
钢带压块
Steel strip pressing block
2
37
421S13059
螺钉M5×20
Screw M5×20
1
38
S05133
螺钉M4×12
Screw M4×12
14
39
141826009
圆柱销3
Cylindrical pin
4
40
W01002
平垫圈3
Washer 3
12
41
141844010
塑料轴套P210RLM-0309-50
Plastic bushing P210RLM-0309-50
4
42
S09103
螺钉M4×4
Screw M4×4
8
43
141801048
移动块B
Moving block B
1
44
141824014
轴位螺钉M6
Axial screw
8
45
B01057
轴承SG66
Bearing
8
46
141812263
平垫圈
Washer
8
47
141801047
移动块A
Moving block A
1
48
141810001
调节螺母
Adjusting nut
4
49
S10006
螺钉M5×6
Screw M5×6
4
50
141844011
塑料轴套GSM-0608-10
Plastic bushing GSM-0608-10
4
51
141801049
移动块盖板
Moving block cover plate
1
52
141812262
传感器感应片
Sensor plate
1
jintex.in
Page 34 — N1、X送料装置(S) / X Feed mechanism (S)
N1、X送料装置(S) / X Feed mechanism (S)
67
64
59
58
57
66
65
77
76
75
53
63
78
55
54
1
7
8
16
15
2
3
4
5
6
16
17
15
19
20
34
21
37
39
41
35
30
29
31
32
33
14
68
69
71
70
73
72
74
13
3
6
9
10
11
12
26
25
27
24
28
22
23
62
61
44
45
46
43
40
36
47
48
49
50
51
52
53
38
王
jintex.in
Page 35
53 421S13035 螺钉M4×8 Screw M4×8 4
54 41812146 储油脂安装板 Mounting plate for grease box 1
55 S04076 螺钉M3×6 Screw M3×6 4
56 141801052 丝杆送料联接座 Screw feed connection seat 2
57 41728033 垫片M6 Gasket M6 4
58 S05111 螺钉M6×20 Screw M6×20 4
59 421S13065 螺钉(带垫圈)M5×16 Screw (with washer) M5×16 8
61 417S30003 段螺钉 Screw 2
62 41722021 0形圈P7
63 141912151 拖链支架 Drag chain bracket 1
64 N01024 六角螺母M4 Hexagon nut M4 1
65 141812169 横梁调节板 Beam regulating plate 1
66 S05133 螺钉M4×12 Screw the M4 x 12 1
67 S05119 螺钉M4×20 Screw the M4 x 20 1
68 S04125 十字槽盘头螺钉M4/50 Cross grooved disc head screw M4/50 1
69 N01024 六角螺母M4 Hexagon nut M4 1
70 S04076 螺钉M3×8 Screw M3×8 4
71 41812145 储油脂盖板 Grease box cover plate 1
72 41822042 活芯子 The live core 1
73 41822016 0型圈17×2.65 17 * 2.65 o-rings 2
74 41842041 Y丝杠储油脂盒 Y lead screw grease box 1
75 41836011 铜卡套式直通油管接头M6 Copper clamped through tubing connector M6 1
76 141822015 组合垫片 Composite gasket 1
77 S04038 螺钉M6×10 Screw M6 x 10 1
78 417S30302 螺钉M4×12 Screw the M4 x 12 8
79 417S15008 螺钉M4×8 Screw the M4 x 8 2
80 S05124 螺钉M5×16 Screw M5×16 4
jintex.in
Page 36 — N2, X Feed mechanism (T)
N2、X送料装置 (T) / X Feed mechanism (T)
1
2
3
5
6
10
11
12
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
EX
jintex.in
Page 37 — N2、X送料装置(T)/X Feed mechanism (T)
N2、X送料装置(T)/X Feed mechanism (T)
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
141811006
线槽盖40L700
40 1700 slot cover
1
2
S05115
螺栓M4×6
Bolt M4 x 6
5
3
W01001
平垫圈4
Flat washer 4
3
4
61910026
粘式配线固定座HC-101WP
Adhesive wiring fixator HC-101WP
1
5
141811005
线槽4030L120
4030 1120 slot
1
6
141811004
线槽4030L480
4030 1480 slot
1
10
N08008
螺母M3
Nut M3
4
11
S02127
沉头螺钉M3×10
Countersunk head screw M3×10
4
12
4184205000
同步带送料模组
Synchronous belt feeding module
1
14
S05035
螺钉M5×25
Screw the M5 * 25
2
15
S05124
螺钉M5×16
Screw the M5 * 16
2
16
142033003
模组电机
Module, motor
1
17
10122005
孔塞
plug
1
18
41837614
机械防撞标贴
Mechanical anti-collision labeling
2
19
141842001
X传感器安装板
X sensor mounting plate
1
20
W01001
平垫圈4
Flat washer 4
2
21
413S13011
螺钉M4×12
Screw the M4 x 12
2
22
41730851
传感器
The sensor
1
23
S04076
M3×8
The M3 x 8
1
24
930000855
拖链支持板(同步带)
Drag chain support plate (synchronous belt)
1
142012185
25
421S13012
螺钉M4×8
Screw the M4 x 8
2
26
142011014
Y向拖链
Y-direction drag chain
1
27
421S13035
M4×8
The M4 x 8
2
28
S02032
螺钉M3×6(镀镍)
Screw M3×6(Nickel plating)
4
29
141812035
储油脂盒安装板(长)
Grease box mounting plate (length)
1
30
421S13003
螺钉M4×8
Bolt the M4 x 8
2
31
S04125
十字槽盘头螺钉M4/50
Cross grooved disc head screw M4/50
1
32
N01024
六角螺母M4
Hexagon nut M4
1
33
S04076
螺钉M3X8
Screw M3X8
4
34
41812145
储油脂盒盖板
Grease box cover plate
1
35
41842042
活芯子
The live core
1
36
41822016
0型圈17×2.65
17 * 2.65 o-rings
2
37
41842041
Y丝杠储油脂盒
Y lead screw grease box
1
38
41836011
铜卡套式直通油管接头M6
Copper clamped through tubing connector M6
1
39
141822015
组合垫片
Composite gasket
1
40
S04038
螺钉M6×10
Screw M6 x 10
1
41
141801052
丝杆送料联接座
Screw feed coupling seat
1
42
41728033
垫片M6
Gasket M6
1
43
S05111
螺钉M6×16
Bolt M6 x 16
2
44
417S30034
螺栓M4×14(带垫圈)
Bolt M4×14(with washer)
4
45
N01001
六角螺母M4
Hexagon nut M4
2
46
S05119
螺钉M4×20
Screw the M4 x 20
1
47
141812169
横梁调节板
Beam regulating plate
1
48
S05133
螺钉M4×12
Screw the M4 x 12
1
49
141912151
拖链支架
Drag chain bracket
1
50
417S30302
螺钉M4×12
Screw the M4 x 12
4
51
417S30302
螺钉M4×12
Screw the M4 x 12
2
52
407N01002
自锁螺母
self-locking nut
2
Page 38 — N3, Y Feed mechanism
N3、Y送料装置 / Y Feed mechanism
jintex.in
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
丑
Page 39 — N3、Y送料装置/ Y Feed mechanism
N3、Y送料装置/ Y Feed mechanism
序号
No.
件号
Part. No.
零部件名称
零 部 件 名 称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
41801044
Y丝杆同步带驱动座
Y lead synchronous belt drive seat
1
2
4181202900
Y传感器板组件
Y sensor board assembly
1
3
S05133
螺钉M4×12
Screw the M4 x 12
2
4
41801041
Y丝杆固定端轴承组件
Y-screw fixed end bearing assembly
1
5
4180301200
梅花联轴器组件
Plum coupler assembly
1
6
142001016
Y丝杆电机座
Y lead motor seat
1
7
142033006
Y伺服电机
Y servo motor
1
8
S05124
螺钉M5×16
Bolt M5 x 16
4
9
S05074
螺钉M8×20
Bolt M8 x 20
8
10
41826224
销子8×25
Pin 8 x 25
2
11
H05031
挡圈E6
Retaining ring E6
2
12
S05139
螺钉M8×55
Bolt M8 x 55
4
13
417S30025
螺钉M4×10DB
Bolt the M4 x 10 db
1
14
417S30025
螺钉(带垫圈)M4×10DB
Bolt (with washer)M4×10DB
2
15
12912326
管夹
Pipe clamp
1
16
41812667
油管支架
Tubing stent
1
17
41826011
圆柱销6×15
The cylindrical pin 6 x 15
1
18
S05123
螺钉5×12
Screw 5 x 12
16
19
41808011
挡圈
Retaining ring
1
20
41801042
Y丝杆支撑端轴承座
Y lead rod support end bearing block
1
21
141801015
Y丝杆前支撑座
Front support for Y lead rod
1
22
S05133
螺钉M4×12
Screw the M4 x 12
1
23
S05040
螺钉M6×16
Bolt M6 x 16
4
24
B01033
轴承6203
Bearing 6203
1
25
141821006
油管
The tubing
1
26
41836011
铜卡套式直通油管接头M6
Copper clamped through tubing connector M6
1
27
421S13059
螺栓M5×20
Bolt the M5 * 20
4
28
141924001
Y丝杆组件
Y lead component
1
29
N01021
M6螺母
M6 nut
8
30
141822009
橡胶头螺钉M6×65
Rubber head screw M6×65
4
31
S05124
螺栓M5×16
Bolt the M5 * 16
22
32
142024001
Y导轨
Y guide
2
33
417S30036
螺钉M5×12
Screw the M5 * 12
8
34
142012057
Y前限位板
Y front limit plate
2
35
41812028
Y限位板B
Y limit plate B
2
36
41812023
Y传感器安装板X
Y sensor mounting plate X
1
37
417S30302
M4×12
The M4 x 12
2
38
421S10005
螺栓M3×6
Bolt M3 * 6
1
39
41730851
传感器
The sensor
1
40
141912250
模组调节板
1
41
S05085
螺钉6×15
Screw 6 x 15
2
jintex.in
Page 40 — N4、压紧夹具装置(S) / Clamping fixture mechanism (S)
N4、压紧夹具装置(S) / Clamping fixture mechanism (S)
jintex.in
Page 41 — N4、压紧夹具装置(S) / Clamping fixture mechanism (S)
N4、压紧夹具装置(S) / Clamping fixture mechanism (S)
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
142011014
Y向拖链
screw M4×8
1
2
421S13003
螺钉M4×8
screw M5×12
2
3
417S30036
螺钉M5×12
1
4
930000569
Y拖链支架C
screw M4×8
2
5
421S13003
螺钉M4×8
1
6
141811001
小拖链
7
421S13035
螺钉M4×8
Screw M4×8
2
8
142012183
丝杆拖链挡板
Drag chain bracket
1
9
141811018
线槽3030L200
Wire slot3030L200
1
10
141811017
线槽3030L550
Wire slot 3030L550
1
11
141811019
线槽盖30L845
Trunk cover30L845
1
12
S05115
螺钉M4×6
Screw M4×6
5
13
42536004
气管接头
PIPE JOINTS
2
14
41845223
气管Φ4×2.5透明蓝
tube Φ4×2.5 transparent blue
1
15
41845224
气管Φ4×2.5黑色
tube Φ4×2.5 black
1
16
42536003
气管接头
tube joint
4
17
417S30023
螺钉M3×16
Screw M3×16
2
18
40736036
气管接头(三通)
tube joint
2
19
142042021
压框架
Pressure frame
1
20
4254500400
气缸
air cylinder
4
21
S05124
螺钉M5×16
screw M5×16
16
22
41728028
垫圈5
washer 5
8
23
S05123
螺钉M5×12
screw M4×12
8
24
42512028
限位支座
Limit bearing
1
25
S09019
螺钉M5×5
screw M5×5
1
26
42526008
限位销
Limit pin
4
27
417S30034
螺钉M4×14
screw M4×14
2
28
142045005
气缸MSD16×5
Air cylinder MSD16×5
2
29
S05119
螺钉M4×20
Screw M4×20
4
30
42230519
微型接头M-5HLH-4
Mini connector M-5HLH-4
2
31
141812199
顶模板气缸安装板
Top template cylinder mounting plate
2
32
141812196
螺纹板
Threaded plate
2
33
S05118
螺钉M4×16
Screw M4×16
4
34
41842038
顶柱
Rod
2
35
W01001
垫片
Gasket
9
36
41836501
管接头PU4
Weasand connector PU4
2
37
41845223
气管Φ4×2.5透明蓝
tube Φ4×2.5 transparent blue
1.2
38
41845224
气管Φ4×2.5黑色
tube Φ4×2.5 black
1.2
39
407N01002
自锁螺母
4
jintex.in
Page 42 — N5、夹扣夹具装置(S) / Clamping fixture mechanism (S)
N5、夹扣夹具装置(S) / Clamping fixture mechanism (S)
jintex.in
Page 43 — N5、夹扣夹具装置 (S) / Clamping fixture mechanism (S)
N5、夹扣夹具装置 (S) / Clamping fixture mechanism (S)
序号
No.
件号
Part. No.
零部件名称
零
部
件
名
称
NAME OF PARTS
数量
Amt.
备注
1
142011014
Y向拖链
screw M4×8
1
2
421S13003
螺钉M4×8
screw M4×8
2
3
417S30036
螺钉M5×12
screw M5×12
2
4
930000569
Y拖链支架C
1
5
421S13003
螺钉M4×8
screw M4×8
2
6
141811001
小拖链
1
7
421S13035
螺钉M4×8
Screw M4×8
4
8
142012183
丝杆拖链挡板
Drag chain bracket
1
9
141811018
线槽3030L200
Wire slot3030L200
1
10
141811017
线槽3030L550
Wire slot 3030L550
1
11
141811019
线槽盖30L845
Trunk cover30L845
1
12
S05115
螺钉(带垫圈)M4×10
Screw M4×10
5
13
141845002
气管接头(三通)
Trachea joint
2
14
407S04053
螺钉M3×25
Screw M3×25
2
16
S05121
螺钉M5×10
Bolt M5×10
12
17
41842218
夹具连接板B
Clamp Connection plate B
2
18
W01009
垫圈5
Washer
8
19
S05124
螺钉M5×16
Bolt M5×16
8
20
42212607
夹紧杆挡板
Press bar Baffle
2
21
42212813
夹紧杆
Press bar
2
22
42228811
转动垫圈
Moving washer
6
23
42212538
夹具安装板L
Clamp Installation board L
2
24
S05123
螺钉M5×12
Bolt M5×12
6
25
42226811
接头销
Pin
2
26
401727
接头
Connecter
2
27
42128003
垫圈
Washer
4
28
W02008
弹簧垫圈2-4
Spring Washer
4
29
S05065
螺钉M4×40
Screw M4×40
4
30
42536004
气管接头
Weasand connector
4
31
41730441
气缸CU16-15D
Cylinder CU16-15D
2
32
41836501
管接头PU4
Weasand connector PU4
2
33
41845224
气管φ4×2.5黑色
Black weasand φ4×2.5
2.2
34
41845223
气管φ4×2.5透明蓝
Blue weasand φ4×2.5
2.2
35
W01001
垫片
Gasket
5
jintex.in
Page 44 — N6、压紧夹具装置(T) / Clamping fixture mechanism (T)
N6、压紧夹具装置(T) / Clamping fixture mechanism (T)
1
2
3
4
5
6
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
正
jintex.in
Page 45 — N6、压紧夹具装置(T) / Clamping fixture mechanism (T)
N6、压紧夹具装置(T) / Clamping fixture mechanism (T)
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
41836501
管接头PU4
Pipe joint PU4
2
2
41845223
气管φ4×2.5透明蓝
Trachea 4×2.5 transparent blue
1.2
3
41845224
气管φ4×2.5黑色
Trachea 4×2.5 black
1.2
4
141811001
小坦克链
A small tank chain
1
5
42012184
沉头螺钉M3×10
Countersunk head screw M3×10
4
6
142012184
同步带拖链挡板
Countersunk head screw M4 x 10
1
9
407S17001
沉头螺钉M4×10
Tracheal joint
4
10
42536004
气管接头
Screw the M5 * 16
2
11
S05124
螺钉M5×16
Screw the M5 * 16
16
12
41845210
夹口专用垫块
Screw the M5 * 16
1
13
41845223
气管φ4×2.5透明蓝
Trachea 4×2.5 transparent blue
1
14
41845224
气管φ4×2.5黑色
Trachea 4×2.5 black
1
15
42536003
气管接头
Tracheal joint
6
16
142042021
压框架L
Pressure framework
1
17
4254500400
气缸
cylinder
4
18
S09019
螺钉M5×5
Screw the M5 x5
1
19
42512028
限位支座
Limit bearing
1
20
42526008
限位销
Limit pin
1
21
417S30034
螺钉M4×12
Screw the M4 x 12
4
22
S05124
螺钉M5×16
Screw the M5 * 16
8
23
41728028
垫圈5
Washer 5
8
24
141812196
螺纹板
Thread plate
2
25
141812199
顶模板气缸安装板
Top formwork cylinder mounting plate
2
26
42230519
微型接头M-5HLH-4
Miniature connector M-5HLH-4
2
27
142045005
气缸
cylinder
2
28
S05119
螺钉M4×20
Bolt the M4 x 20
2
29
41842038
顶柱
needle
2
30
S05118
螺钉M4×16
Screw the M4 x 16
4
31
40736036
气管接头APY4(Y型三通)
Air pipe connector APY4(Y-type tee)
2
32
41845223
气管φ4×2.5透明蓝
Trachea 4×2.5 transparent blue
5.8
jintex.in
III
Page 46 — N7、夹扣夹具装置 (T) / Clamping fixture mechanism (T)
N7、夹扣夹具装置 (T) / Clamping fixture mechanism (T)
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
30
31
32
33
34
35
36
37
正
jintex.in
Page 47 — N7、夹扣夹具装置 (T) / Clamping fixture mechanism (T)
N7、夹扣夹具装置 (T) / Clamping fixture mechanism (T)
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
41836501
管接头PU4
Pipe joint PU4
2
1.2
2
41845224
气管φ4×2.5透明蓝
Trachea 4×2.5 transparent blue
1.2
3
41845224
气管φ4×2.5黑色
Trachea 4×2.5 black
1.2
4
141811001
小坦克链
A small tank chain
1
5
421S13003
沉头螺钉M3×10
Countersunk head screw M3×10
4
7
42536003
气管接头
Tracheal joint
2
8
S05121
螺栓M5×10
Bolt the M5 * 10
12
9
41842218
夹具连接板B
Fixture connection plate B
2
10
W01001
垫圈5
Washer 5
8
11
S05123
螺栓M5×12
Bolt the M5 * 12
8
12
42212813
夹紧杆
The clamping lever
2
13
42228811
转动垫圈
Turn the washer
6
14
42212538
夹具安装板L
Fixture mounting plate L
2
15
42212607
夹紧杆挡板
Clamp lever baffle
2
16
S05123
螺栓M5×12
Bolt the M5 * 12
6
17
42226811
接头销
The joint pin
2
18
401727
接头
joint
2
19
41730441
气缸CU16-15D
Cylinder CU16-15 d
2
20
42536004
气管接头
Tracheal joint
2
21
42128003
垫圈
The gasket
4
22
W02008
弹簧垫圈2-4
Spring washer 2-4
4
23
S05065
螺钉M4×40
Screw the M4 x 40
4
24
41711014
电线夹6.4
Wire clip 6.4
3
25
417S30025
螺栓(带垫圈)M4×10
Bolt (with washer)M4 x 10
3
26
41842510
夹扣专用垫块
Special pad for clamp
3
27
142012184
同步带拖链挡板
1
28
407S04001
沉头螺钉M4×16
Countersunk head screw M4×16
3
30
41845224
气管φ4×2.5黑色
Trachea 4×2.5 black
1
31
41845223
气管φ4×2.5透明蓝
Trachea 4×2.5 transparent blue
1
32
141812049
垫板
plate
1
33
141812048
夹扣感应片
Clip sensor
1
34
141842007
支撑座
brackets
1
35
42128003
垫圈
The gasket
2
36
421S13035
螺钉M4×8
Screw M4 x 8
2
37
S02039
螺钉M4×9
Screw M4 x 9
1
표
jintex.in
Page 48 — N8、X同步带装置(T) / X Feed mechanism (T)
N8、X同步带装置(T) / X Feed mechanism (T)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
ㅍ
jintex.in
Page 49 — N8, X同步带装置(T) / X Feed mechanism (T)
N8, X同步带装置(T) / X Feed mechanism (T)
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
41842500
横梁
Beam
1
2
S17013
螺钉M4×6
Screw M4×6
12
3
42512019
齿轮箱盖板
Gear box cover plate
3
4
42501008
X同步带被动轮箱
X Synchronizing wheel box
1
5
41842501
压框连接板
Press frame Connecting
1
6
42526010
同步带拉紧销
Synchronorous belt pin
2
7
S05010
螺钉M4×12
Screw M4×12
2
8
S05116
螺钉M4×8
Screw M4×8
8
9
42547003
X感应磁铁
Magnet
1
10
S05059
螺钉M4×12
Screw M4×12
2
11
42526011
同步带销
Synchronorous belt pin
1
12
42512020
同步带扣
Synchronorous belt clasp
2
13
S05152
螺钉M6×65
Screw M6×65
2
14
41824500
X导轨
X Guide
1
15
S05058
螺钉M4×10
Screw M4×10
31
16
425S10001
方形螺母块
Square nut block
31
17
W03008
波形垫圈
Wave washer
3
18
4253500700
主动同步轮组件
Driving Synchronizing wheel
1
19
B01010
轴承6003
Bearing 6003
4
20
409S14001
紧定螺钉SM1/4×40×6
Screw SM1/4×40×6
3
21
42525004
驱动齿轮
Driving gear
1
22
42512023
齿轮箱盖板
Bearing cover plate
1
23
S05034
螺钉M5×15
Screw M5×15
2
24
42525005
被动齿轮
Passive gear
1
25
409S14001
紧定螺钉SM1/4×40×6
Screw SM1/4×40×6
2
26
42529001
齿轮箱用挡圈
Washer
1
27
K01006
键5×5×16
Key 5×5×16
1
28
4253500900
X同步带被动组件
X Synchronizing wheel box
1
29
41835500
X轴同步带
X Synchronizing
1
30
42501007
齿轮箱
Gear box
1
31
701S13045
螺钉M5×60
Screw M5×60
8
jintex.in
Page 50 — 01、主台面部分 / Machine body (Table structure)
01、主台面部分 / Machine body (Table structure)
1
2
3
3
6
3
4
19
17
8
7
17
9
10
5
11
13
12
12
14
12
16
12
15
20
21
22
21
23
27
24
26
25
28
正
jintex.in
Page 51 — 01、主台面部分 / Machine body (Table structure)
01、主台面部分 / Machine body (Table structure)
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
141932115
主台面
Master surface
1
2
141911005
旋梭后盖板
Shuttle back cover
1
3
S02039
螺钉M4×9
Screw the M4 × 9
12
4
141932044
圆形盖板
Circular plate
2
5
142026004
滚花螺纹套M4
Knurled thread sleeve M4
10
6
141911006
旋梭前盖板
Shuttle front cover plate
1
7
915624
磁体15×1
The magnet 15 x 1
6
8
S05124
螺钉M5×16
Screw the M5 * 16
12
9
142031002
合页A
Hinge A
3
10
417S30036
螺钉(带垫圈)M5×12
Screw (with washer)M5 x 12
12
11
930000413
肋板
floor
2
142012087
12
417S30306
螺钉(带垫圈)M5×15
Screw (with washer)M5 x 15
32
13
930000513
托板连接板B
Supporting plate coupling B
1
141912193
14
930000302
台面中托板
Mesa support plate
2
142012015
15
930000301
台面托板支架组件
Table plate bracket assembly
2
14201201300
16
417S30306
螺钉(带垫圈)M5×15
Screw (with washer)M5 x 15
8
17
142026005
滚花螺纹套M5
Knurled thread sleeve M5
14
19
141932063
后台面
Back table
1
20
S05123
螺钉M5×12
Screw the M5 * 12
20
21
41828611
平垫圈M5
Flat washer M5
30
22
930000303
台面左右支撑板
Mesa left and right support plate
4
142012022
23
142012031
螺纹板M5
The M5 threaded board
8
24
142001007
滑杆轴支座
Slide shaft support
8
25
S05035
螺钉M5×25
Screw the M5 * 25
16
26
S09041
螺钉M6×5
Screw M6 x 5
16
27
S05026
螺钉M5×20
Screw the M5 * 20
26
28
142002008
滑杆轴
Slide bar shaft
2
jintex.in
Page 52 — 02、 台面部分 / Front table mechanism
02、 台面部分 / Front table mechanism
1
2
3
19
4
5
3
6
7
12
10
11
13
14
15
12
16
18
17
13
14
7
13
14
jintex.in
Page 53 — 02、前台面部分 / Front table mechanism
02、前台面部分 / Front table mechanism
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
142032002
前辅助台面
Front auxiliary mesa
1
2
142031002
合页A
Hinge A.
2
3
S16022
螺钉ST5×14
Screw ST5×14
16
4
142032003
开合台面
Retractable table
1
5
142012128
开合台面限位板
Limit plate of Retractable table
1
6
42231512
压紧夹具
Clamping fixture
1
7
417S30036
螺钉(带垫圈)M5×12
Screw (with washer)M5 × 12
12
8
S05026
螺钉M5×20
Screw the M5 × 20
6
9
930000306
折叠杆支架B
Folding rod bracket B
2
142012019
10
142012031
螺纹板M5
The M5 thread board
3
11
1420NS20003
轴位螺钉M5B
Shaft screw M5B
4
12
41728028
垫圈5
Washer 5
6
13
407N01001
自锁螺母M5
Self-locking nut M5
6
14
930000439
折叠杆B
Folding rod B
2
141912147
15
930000439
折叠杆A
A folding stem
2
141912146
16
930000304
折叠杆支架A
Folding rod bracket A
2
142012017
17
1420NS20002
轴位螺钉M5A
Axial screw M5A
2
18
141937004
开箱调试说明标签
Unpacking debugging instructions label
1
19
jintex.in
Page 55 — 03、辅助台面部分 / Auxiliary table mechanism
03、辅助台面部分 / Auxiliary table mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
141932061
左辅助台面
1
2
141932062
右辅助台面
1
3
S05035
螺钉M5×22
12
4
421S17009
螺钉M5×10
6
5
142012032
滑动座垫板
6
6
141803017
滑竿轴套
8
7
141803007
辅助台面连接轴套
6
8
407N01001
自锁螺母M5
32
9
142003016
工程塑料轴套GFM1214-20
4
10
41812624
左右板拼接板
4
11
S05035
螺钉M5×22
12
12
141831010
内六角螺钉M5防尘盖
30
13
S05026
螺钉M5×20
8
14
41812080
辅助支撑铰链支架
4
15
41728028
垫圈5
8
16
417S30304
螺钉M6×20
8
17
930000225
支撑柱组件
4
14193200600
18
41832020
脚垫M12
4
jintex.in
Page 56 — P1、机架部件/Table mechanism
P1、机架部件/Table mechanism
32
33
34
35
36
37
3
4
7
2
7
6
5
8
10
9
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
1
12
11
호
jintex.in
Page 57
P1、机架部件/Table mechanism
序号
No.
件号
Part. No.
零件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
930000311
机架组件
Rack components
1
14204200100
2
930000818
机架前盖板
Rack front cover plate
1
141912236
3
41812131
机架后盖固定板B
Fixed plate B for rear cover of the rack
8
4
421S13012
螺钉(带垫圈)M4 × 10
Screw (with washer)M4 × 10
16
5
141912169
机架前盖板支架
Frame front cover bracket
2
6
S05123
螺钉(带垫圈)M5 × 12
Screw (with washer)M5 × 12
4
7
1420NS10001
十字大扁头螺钉M5 × 10
Cross large flat head screw M5 × 10
10
8
141831042
脚垫M20
Mats M20
4
9
701S13002
螺钉M8 × 12
Screw the M8 × 12
16
10
42232502
脚轮
castor
4
11
1420NS10003
十字大扁头螺钉M5 × 25
Cross large flat head screw M5 × 25
16
12
930000316
机架侧盖
Frame side cover
4
142012037
13
930000321
电控柜左前侧盖
Front left cover of electric control cabinet
1
142012039
14
930000320
电控柜右前侧盖
Rear left side cover of electric control cabinet
1
142012040
15
1420NS10003
十字大扁头螺钉M5 × 25
Cross large flat head screw M5 × 20
8
16
407N01002
自锁螺母
Self-locking nut
3
17
142012041
电控门限位板
Electric control threshold plate
3
18
142047002
圆磁铁15
Round magnet 15
3
19
407S17001
螺钉M4 × 10
Screw M4 × 10
3
20
421S13012
螺钉(带垫圈)M4 × 10
Screw (with washer)M4 × 10
6
21
930000317
电控柜左门
Left door of electric control cabinet
1
142012033
22
930000318
电控柜右门
Right door of electric control cabinet
1
142012034
23
41831014
电控柜锁
Electric control cabinet lock
1
24
417S17852
螺钉M5 × 15
Screw the M5 × 15
24
25
41831016
电控柜合页
Electronic control cabinet hinge
6
26
41728028
垫圈5
Washer 5
12
27
407N01001
自锁螺母M5
Self-locking nut M5
12
28
417S30025
螺钉(带垫圈)M4×10DB
Screw (with washer)M4×10DB
2
29
41831013
风扇网罩
Fan net
4
30
304219
机架后盖组件
Rack rear cover assembly
1
31
930000319
电控柜右侧门
Door on the right side of the electric control
cabinet
1
142012038
32
S05993
螺钉M16 × 55
Screw the M16 × 55
6
33
41828013
大垫圈
The big washer
6
34
142003018
定位套
Locating sleeve
6
35
41803019
管套
Pipe sleeve
12
36
41822014
减震橡胶垫
Vibration damping rubber pad
6
37
417S13301
螺钉M5 × 12
Screw M5 * 12
12
jintex.in
Page 58 — P2、电控柜装置/ Electric control box mechanism
P2、电控柜装置/ Electric control box mechanism
1
2
3
4
5
6
7
8
9
10
jintex.in
호
Page 59 — P2、电控柜装置 / Electric control box mechanism
P2、电控柜装置 / Electric control box mechanism
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
407N01002
自锁螺母
self-locking nut
4
2
S02117
十字槽沉头螺钉 M4×50
Cross grooved countersunk head screw M4 x 50
4
3
41811013
风扇防尘网组件
Fan dust cover assembly
1
4
41830012
风扇
fan
1
5
14201008
线槽5040-320
Trough. 5040-320
1
6
41845022
气管接头穿通板PM8
The air pipe joint goes through PM8
1
7
41811215
出口
outlet
1
8
14201009
线槽5040-750
Trough. 5040-750
1
9
142011005
线槽4040-300
Trough. 4040-300
1
10
417S30025
螺栓(带垫圈)M4×10
Bolt (with washer)M4×10DB
9
jintex.in
Page 60 — Control box mechanism (X)
Q、控制箱装置(X) / Control box mechanism (X)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
하
jintex.in
Page 61 — Q、控制箱装置(X) / Control box mechanism (X)
Q、控制箱装置(X) / Control box mechanism (X)
序号
No.
件号
Part. No.
零部件名称
零
Parts
数量
Amt.
备注
Remarts
1
141930042
AK05-B高压电控
AK05-B high voltage electric control
1
双丝杆
1
141930043
BK05-B高压电控
BK05-B high voltage electric control
1
单丝杆
2
141930021
控制箱体
Control cabinet
1
2
141930044
二代AK05款主板
Second-generation AK05 motherboard
1
双丝杆
3
141930045
二代BK05款主板
Second-generation BK05 motherboard
1
单丝杆
4
141930047
二合一低压伺服控制板
Two-in-one low-pressure servo control panel
1
5
141830022
风扇V2BP
Fan V2BP
1
6
141930048
集成Y电源板
The power supply board
1
双丝杆
6
141930024
第三代电源板
The power supply board
1
单丝杆
7
141930046
二合一高压伺服驱动板
Two-in-one high-voltage servo drive plate
1
8
141930026
控制箱盖板
Control box cover plate
1
9
417S30025
螺钉M4×10
Screw M4×10
6
10
41830641
显示屏V2CP
Display the V2CP
1
11
142030004
射频装置
Radio frequency device
1
12
417S30302
螺钉(带垫圈)M4×12DB
Bolt (with washer)M4×12DB
4
13
S02039
螺钉M4×9(镀镍)
Screw M4×9(Nickel plating)
4
14
42230512
主电源开关线(6M)
Main power switching wire (6M)
1
15
41830213
押扣开关
press button switch
1
16
141947001
磁环
Magnetic ring
1
jintex.in
Page 62 — R、操作界面装置/ Operation interface mechanism
R、操作界面装置/ Operation interface mechanism
1
2
3
4
5
6
7
9
11
12
13
14
10
15
16
17
18
19
20
21
22
23
25
26
27
28
29
30
24
jintex.in
Page 63 — R、操作界面装置／ Operation interface mechanism
R、操作界面装置／ Operation interface mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
417S30306
螺栓M5×12
Bolt M5 * 12
4
2
417S30302
螺栓M4×12
Bolt M4 * 12
4
3
304058
操作屏V2支架
Operate screen V2 bracket
1
4181241300
4
417S15008
螺钉M4×8
Bolt M4 * 8
4
5
142010050
压板2M
Pressing plate
2
6
142022003
减振垫
Damping pad
2
7
142012051
压板2孔
Pressing plate
2
9
930000817
操作屏支座
Operate screen support
1
141912244
10
417S30306
螺钉M5×15
Screw M5 * 15
4
11
S05123
螺钉M5×12(滚花)
Screw M5×12(Knurled)
2
12
141912085
吹气开关安装板
Air on/off valve mounting plate
1
13
S05120
螺钉M5×8(滚花)
Screw M5×8(Knurled)
2
14
42536004
气管接头
Tracheal joint
2
15
141930017
吹气开关阀
Air on/off valve
1
16
42230519
微型接头M-5HLH-4
Miniature connector M-5HLH-4
1
17
141945020
压力调节器
Pressure regulator
1
18
S05115
螺钉M4×6(滚花)
Screw M4×6(Knurled)
2
19
41830214
按钮开关
button switch
2
20
41830215
急停开关
Emergency stop switch
1
21
41811216
开关标牌框组件
Switch label frame assembly
2
22
417S30302
螺栓(带垫圈)M4×12
Bolt (with washer)M4 x 12
4
23
41811214
按钮开关盒
Button switch box
1
24
41811215
出线口
outlet
1
25
41812061
开关盒安装板A
Switch box mounting plate A
1
26
W01001
M4垫片(普通)
M4 gasket (ordinary)
3
27
142012031
螺纹板M5
The M5 thread board
1
28
421S13035
螺钉M4×8(滚花,镀镍)
Bolt M4×8(Knurled, Nickel plated)
3
29
41812062
按钮盒安装板B
Button box mounting plate B
1
30
S05026
内六角螺钉M5×20
Hexagon socket screw M5 x 20
2
jintex.in
Page 64 — S、电器部品装置 / Power supply equitment mechanism
S、电器部品装置 / Power supply equitment mechanism
LIE
jintex.in
Page 65 — S、电器部品装置 / Power supply equitment mechanism
S、电器部品装置 / Power supply equitment mechanism
序号
No.
件号
Part. No.
零部件名称
零
Parts
数量
Amt.
备注
Remarts
1
407N01002
自锁螺母
Self-locking nuts
2
2
41812060
电源开关支架
Power switch bracket
1
3
417S30036
螺栓M5×12(带垫圈)
Bolt M5×16(with washer)
2
4
99200037
EC4控制器电源线
EC4 controller power cord
0.4
5
41828611
平垫圈M5
Flat washer M5
1
6
42212620
挂钩
hook
1
7
41830021
插线板A01
Lug plate A01
1
8
421S13012
螺栓(带垫圈)M4×10
Bolt (with washer)M4×10DB
2
9
417S30025
螺栓(带垫圈)M4×10
Bolt (with washer)M4×10DB
1
10
S05118
螺栓M4×16(滚花,镀镍)
Bolt M4×16(Knurled, Nickel plated)
1
11
142011007
线槽4040-1300
Trough. 4040-1300
3
12
417S30025
螺栓(带垫圈)M4×10
Bolt (with washer)M4×10DB
16
13
142011006
线槽4040-750
Trough. 4040-750
1
14
142011005
线槽4040-300
Trough. 4040-300
1
15
41711025
电线夹19
Wire clip 19
2
16
417S30302
螺栓(带垫圈)M4×12
Bolt (with washer)M4 x 12
1
17
142030001
LED灯
LED lights
1
18
421S13003
螺钉带垫M4×8
Screw with cushion M4 x 8
1
19
42311004
缠绕管φ10
Winding pipe φ10
1
JINTEX.IN
Page 66 — T、空压装置/ Air pressure mechanism
T、空压装置/ Air pressure mechanism
1
2
3
4
9
10
11
13
14
15
16
17
18
20
21
5
6
7
8
19
LLE
jintex.in
Page 67 — T、空压装置 / Air pressure mechanismS
T、空压装置 / Air pressure mechanismS
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
14194501700
六位四通电磁阀组件
Six-way solenoid valve assembly
1
(普通款)
1
14204501400
六位五通电磁阀组件
Six-bit five-way solenoid valve assembly
1
(点笔)
1
14194501800
六位六通电磁阀组件
Six-bit six-way solenoid valve assembly
1
(激光款)
1
14204501500
八位七通电磁阀组件
Eight-bit seven-way solenoid valve assembly
1
(激光款+点笔)
2
421S11013
螺钉M4×35
Screw M4 ×35
4
3
14204501200
气源处理元件组件
Gas source processing component components
1
4
417S30025
螺栓(带垫圈)M4×10DB
Bolt (with washer) M4×10DB
2
5
41845220
气枪AG-B
Air gun AG-B
1
6
40736018
螺纹直通APC6-02
Threads go straight through APC6-02
1
7
42211540
螺旋气管6×4
Spiral trachea 6×4
1
8
40736022
气管接头APG6
Trachea connector APG6
1
9
40736036
气管接头APY4(Y型三通)
Trachea connector API4 (Y-type tee)
3
10
140736004
气管接头PYW6-4
Trachea connector PYW6-4
1
11
141936003
气管接头PEG8-4
Trachea connector PEG8-4
1
12
142045007
气管接头三通
Trachea connector tee
1
13
S01591
螺钉 M3×18 10.9级 镀锌锌
Screw M3 ×18
1
14
41845232
T形接管KJT04
T-shaped takeover KJT04
1
15
41845225
气管$4×2.5透明蓝
The trachea is 4×2.5 transparent blue
22
16
41845224
气管$4×2.5黑色
The trachea is 4× 2.5 black
23
17
42221503
气管$8
Trachea 8
10
18
142045009
气管$6
Trachea 6
2
19
41730022
电磁阀接线
Solenoid valve connection
1
(点笔)
19
41730022
电磁阀接线
Solenoid valve connection
14
(激光款)
19
41730022
电磁阀接线
Solenoid valve connection
15
(激光款+点笔)
20
142122003
号码管4
Number tube 4
0.3
21
142144001
号码管色带
Number tube ribbon
0.3
jintex.in
Page 68 — U、卷线装置 / Bobbin winder mechanism
U、卷线装置 / Bobbin winder mechanism
1
2
3
LL
jintex.in
Page 69 — U、卷线装置 / Bobbin winder mechanism
U、卷线装置 / Bobbin winder mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
41831222
自动绕线器
1
2
S05026
螺栓M5×20
4
3
407N01001
自锁螺母M5
4
LID
jintex.in
Page 70 — X1、底线检测装置 / Bottom line detection mechanism
X1、底线检测装置 / Bottom line detection mechanism
1
2
3
4
5
6
7
8
9
10
jintex.in
Page 71 — X1、底线检测装置/Bottom line detection mechanism
X1、底线检测装置/Bottom line detection mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
Remarts
1
418S30218
螺钉M4×7
2
2
141921001
底线检测传感器吹气铜管
1
3
41845224
气管φ4×2.5黑色
0.1m
4
N08008
六角锁紧螺母M3
1
5
141912020
底线检测传感器安装板
1
6
S05116
螺钉M4×8
2
7
413S14012
螺钉M3×14
3
8
14183000400
底线检测传感器
1
9
41818621
两倍拨芯 A
5
10
42130028
反射纸
20
L区
jintex.in
Page 72 — X2、激光切割装置 / Laser cutting mechanism
X2、激光切割装置 / Laser cutting mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
LG
jintex.in
Page 73 — X2、激光切割装置 / Laser cutting mechanism
X2、激光切割装置 / Laser cutting mechanism
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
41822701
水管
Water pipe
8
2
142032075
上吸烟管A
Upper suction duct A
1
3
142030020
激光管A2S
Laser tube A2S
1
3
142030015
激光管A4S
Laser tube A4S
1
F11B
4
930000536
腔体上盖C
Upper cover of shell C
1
142012127
4
930000537
腔体上盖A
Upper cover of shell A
1
142012106(F11B)
5
421S10022
螺钉M4×6
Screw M4×6
26
6
930000538
腔体上盖B
Upper cover of shell B
1
142012107
7
142042008
腔体后盖板
Chamber rear cover plate
1
8
S05118
螺钉M4×16
Screw M4×16
4
9
142042019
激光壳体底板100W
Shell bottom plate 100W
1
F11B
9
142042015
腔体底板
Shell bottom plate
1
10
421S13059
螺钉(带垫圈)M5×20
Screw (with washer) M5×20
4
11
142042016
腔体面板A
Shell panel A
1
12
S05026
螺钉M5×20
Screw M5×20
2
13
S05026
螺钉M5×20
Screw M5×20
4
14
S05124
螺钉M5×16
Screw M5×16
4
15
142009008
气缸安装座
Cylinder mounting base
1
16
142030019
气缸
Cylinder
1
17
41845231
接头ASL4-M5
Connector ASL4-M5
2
18
142036002
浮动接头
Floating joint
1
19
142042005
浮动接头连接座
Floating joint connector
1
20
421S17005
沉头螺钉M5×16
Screw M5×16
2
21
142008001
上银导轨MGN12H
Guide
2
22
S05094
螺钉M3×8
Screw M3×8
8
23
142042007
导轨联动板
Guide rail linkage plate
1
24
421S11001
螺钉
Screw
8
25
1420NS20004
激光调节铜螺钉
Screw
3
26
142009007
反射镜安装板
Reflector mounting plate
1
27
142008004
反射镜固定圈
Mirror fixing ring
1
28
41811631
反射镜
Silicon mirror
1
29
S05064
螺钉M4×30
Screw M4×30
3
30
142027002
反射镜弹簧
Mirror spring
3
31
142001017
反射镜安装座
Reflector mounting base
1
32
142042009
出光筒固定座
Fixing seat of light output cylinder
1
33
S05124
螺钉M5×16
Screw M5×16
2
34
S05124
螺钉M5×16
Screw M5×16
1
35
S10019
紧定螺钉M6×6
Screw M6×6
3
36
142042010
吸烟罩A
Smoking hood A
1
37
142002015
镜筒A
Lens barrel A
1
38
41830701
聚焦镜
Focusing lens
1
39
42230519
微型接头
Mini connector
1
40
142002014
出光口A
Light outlet A
1
41
142008003
聚焦镜固定圈
Fixed ring of focusing lens
1
42
142042011
上吸烟管接口
Smoking pipe connection
1
43
41831409
抱箍25-38
Hoop 25-38
1
44
142011017
吸烟软管32
Hose 32
0.5
45
421S13059
螺钉(带垫圈)M5×20
Screw (with washer) M5×20
8
46
142011015
激光管支架80
Laser tube bracket 80
2
47
S05133
螺钉M4×12
Screw M4×12
8
48
142042014
上吸烟管安装座B
Smoking pipe mounting base B
2
49
142042013
上吸烟管安装座A
Smoking pipe mounting base A
2
50
142012105
吸烟管座安装板
Mounting plate for smoking socket
2
LE
jintex.in
Page 74 — X2、激光切割装置 / Laser cutting mechanism
X2、激光切割装置 / Laser cutting mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
LIE
jintex.in
Page 75
51 41828611 平垫圈M5 Flat washer M5 4
52 417S30306 螺钉(带垫圈)M5×15 Screw (with washer) M5×15 4
53 142042017 腔体面板B Shell panel B 1
54 S05133 螺钉M4×12 Screw M4×12 1
55 142030011 一体式电位器 Integrated potentiometer 3
56 142030014 点动开关 Inching switch 1
57 142002016 出光口B Light outlet B 1
58 41845222 螺钉直通APC4-01 1
LO
jintex.in
Page 76 — X6、激光切割控制部分 / Laser cutting control part
X6、激光切割控制部分 / Laser cutting control part
1
2
3
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
CW3000
L
jintex.in
Page 77 — X6、激光切割控制部分 / Laser cutting control part
X6、激光切割控制部分 / Laser cutting control part
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
41822012
减振垫圈
Damping washer
6
142012055
2
9300000323
腔体后支架
Cavity rear bracket
1
142012055
3
417S30306
螺钉(带垫圈)M5×15
Screw (with washer) M5×15
14
4
9300000442
腔体前支架
Cavity front bracket
1
141912153
5
9300000539
激光电源安装板A
Laser power supply mounting plate
1
142012108
6
142030016
激光电源箱120W
Laser power supply 120W
1
7
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
8
8
142011006
线槽4040-850
Trunk 4040-850
1
9
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
2
10
141830013
公牛插板3插孔
Bull plug 3 jack
1
11
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
2
12
142030017
网线
Network cable
1
13
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
5
14
41711025
电线夹19
Wire clip 19
5
15
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
4
16
142011016
扎带固定座
Cable tie holder
4
17
41845232
接头
Tracheal connector
1
18
S01591
螺钉M3×18
Screw M3×18
2
19
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
2
20
142012052
电气安装板
Electrical mounting plate
1
21
141830037
卡件
Card
2
22
空气开关
Air switch
1
23
41830302
中间继电器
Intermediate relay
2
24
41830303
中间继电器座
Intermediate relay seat
2
25
41830703
3000型水箱
3000 type water tank
1
26
9300000326
水箱安装板组件
Water tank mounting plate assembly
1
14201206700
27
417S30036
螺钉(带垫圈)M5×12
Screw (with washer) M5×12
8
28
142012084
合页垫板
Hinge pad
2
29
142031002
合页A
Hinge A
2
31
142012064
水箱拉杆支架
Water tank lever bracket
2
30
142012182
拉杆钢A
Wire A
2
32
421S17009
螺钉M5×10
Screw M5×10
8
33
41730059
扫线开关接插件A
1
34
61807020
红头簧片
20
LIC
jintex.in
Page 78 — X3、激光切割吸烟装置 / Laser cutting smoke exhaust part
X3、激光切割吸烟装置 / Laser cutting smoke exhaust part
32
33
34
31
36
35
30
29
28
27
3
1
2
4
5
6
7
8
9
10
37
56
55
54
53
50
51
52
57
58
41
40
39
38
44
43
42
26
25
24
23
21
20
19
18
17
16
15
14
13
12
11
45
46
LIC
jintex.in
Page 79 — X3、激光切割吸风装置 / Laser cutting smoke exhaust part
X3、激光切割吸风装置 / Laser cutting smoke exhaust part
序号
No.
件号
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
141812017
吸风口板-中厚料
Suction port plate-medium thick material
1
2
41831019
强力磁铁6×12
Powerful magnet 6×12
4
3
S05123
螺钉M5×12
Screw M5×12
4
4
930000327
集尘盒组件M
Dust box assembly M
1
14201207100
5
42230519
微型接头M-5HLH-4
Mini connector M-5HLH-4
1
6
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
2
7
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
2
8
142012070
集尘盒固定板
Dust box fixing plate
1
9
930000328
集尘筒
Dust collector
1
142012075
10
141822006
橡皮塞31
Rubber stopper 31
1
11
41830705
离心风机650W
Centrifugal fan 650W
1
12
417S30037
螺钉(带垫圈)M6×14
Screw (with washer) M6×14
4
13
930000325
风机安装板S
Fan mounting plate S
1
142012060
14
40931008
电机座垫
Motor base
4
15
417S30306
螺钉(带垫圈)M5×15
Screw (with washer) M5×15
6
16
41831408
钢丝软管Φ32
Steel wire hose Φ32
3M
17
41831409
抱箍25-38
Hoop 25-38
7
18
41831408
钢丝软管Φ32
Steel wire hose Φ32
1.5M
19
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
4
20
930000045
离心风机进风口组件
Centrifugal fan air inlet assembly
1
4181256000
21
930000046
离心风机出风口组件
Centrifugal fan outlet assembly
1
4181256100
22
407N01001
自锁螺母M5
Self-locking nut M5
4
23
41828611
平垫圈M5
Flat washer M5
8
24
S05124
螺钉M5×16
Screw M5×16
4
25
141831039
抱箍40-63
Hoop 40-63
1
26
141831038
软管50
Hose 50
5M
27
417S00022
电磁阀接线
Solenoid valve wire
15M
28
62800019
单芯线
Single core wire
5M
29
41845223
气管Φ4×2.5透明蓝
Trachea Φ4×2.5 transparent blue
4M
30
41845224
气管Φ4×2.5黑色
Trachea Φ4×2.5 black
4M
31
41845224
气管Φ4×2.5黑色
Trachea Φ4×2.5 black
5M
32
40736036
气管接头APY4(Y型三通)
Trachea joint APY4 (Y type tee)
1
36
421S11013
螺钉M4×35
Screw M4×35
4
37
41812551
吸风口板
Suction board
1
38
142037003
激光标识贴
Laser label
1
39
141823002
擦镜纸
Mirror cleaning paper
5
40
41837617
激光设备注意事项贴
Precautions for laser equipment
1
41
41837616
三角高压危险标贴
Triangular high-pressure hazard label
3
42
141837004
IN标贴
In label
2
43
141837005
OUT标贴
Out label
2
44
42230512
主电源开关线(5M)
Main power switch line (5M)
2
45
41830021
插线板A01
Plug board A01
1
46
417S30302
螺钉(带垫圈)M4×12
Screw (with washer) M4×12
10
47
S02039
螺钉M4×9
Screw M4×9
4
48
142047002
圆磁铁15
Round magnet 15
4
49
142012136
磁铁安装板
Magnet mounting plate
4
50
930000563
烟雾过滤箱面板
Smoke filter box panel
1
142012129
51
1420NS30002
梅花螺钉M5×15
Plum blossom screw M5×15
1
52
S02032
螺钉M3×6
Screw M3×6
8
53
41831012
铜合页1.5寸
Copper hinge
2
54
142022004
密封条D型
Sealing strip
1M
55
930000562
烟雾过滤箱
Smoke filter box
1
14201213000
56
417S30036
螺钉(带垫圈)M5×12
Screw (with washer) M5×12
2
57
142022005
过滤盒塑料盒
Filter box plastic box
1
58
14201213300
烟雾过滤网60目组件
Smoke filter 60 mesh
1
LD
jintex.in
Page 80 — X3、激光切割吸烟装置 / Laser cutting smoke exhaust part
X3、激光切割吸烟装置 / Laser cutting smoke exhaust part
33
32
28
3
1
34
31
2
4
36
35
30
29
27
5
47
48
46
49
37
56
55
54
53
50
51
57
58
41
40
39
38
44
43
42
26
25
24
23
22
21
20
19
18
17
16
15
14
13
11
12
45
46
LE
jintex.in
Page 81
59
142012173
集尘盒挡光板
Light barrier
1
60
142037005
过滤箱标贴
label
1
Page 82 — X4、点笔装置 / Point pen mechanism
X4、点笔装置 / Point pen mechanism
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
jintex.in
Page 83 — X4、点笔装置/Pint Pen Mechanism
X4、点笔装置/Pint Pen Mechanism
序号
No.
件号
Part. No.
对象描述
Description
数量
Amt.
备注
Remarts
1
41845231
接头ASL4-M5
Joint ASL4 - M5
2
2
2
S05119
内六角圆柱头螺钉M4×20
Hexagon socket head screw M4×20
2
3
142012009
点笔装置安装板
Mounting plate for pen - pointing device
1
4
S05133
内六角圆柱头螺钉M4×12
Hexagon socket head screw M4×12
2
5
41708002
紧圈B
Tight circle B
1
6
S10019
螺钉M6×6
Screw M6×6
2
7
41722020
电磁铁缓冲垫圈
Electromagnetic iron buffer washer
1
8
142045001
气缸CMDD16×25
Cylinder CMDD16 x 25
1
9
141812215
气缸调节片
Cylinder adjusting piece
1
10
N02030
螺母M8×1
Nut M8 x 1
1
11
41827032
点笔弹簧
Point pen spring
1
12
41811302
点笔笔芯
Point pen ink
1
13
418S16304
点笔杆锁帽
Tap the penholder to lock the cap
1
14
41845224
气管φ4×2.5黑色
Trachea 4×2.5 black
3
15
41845223
气管φ4×2.5透明蓝
Trachea 4×2.5 transparent blue
3
DBF
jintex.in
Page 84 — X5、物联网/The Internet of Things
X5、物联网/The Internet of Things
1
2
3
4
5
jintex.in
口旺
Page 85 — X5、物联网装置/The Internet of Things
X5、物联网装置/The Internet of Things
序号
No.
件号
Part. No.
零部件名称
零
部件名称
NAME OF PARTS
数量
Amt.
备注
Remarks
1
61807032
铜柱16mm (10mm+6mm)
16 mm copper column (10 mm + 6 mm)
2
2
141830042
物联网电路板
Internet of Things circuit board
2
3
S04075
螺钉M3×6
Screw M3 * 5
1
4
141830044
电源线(示意图)
Power cord (Schematic diagram)
1
5
141830043
信号线(示意图)
Signal line (Schematic diagram)
1
Page 87 — Z、附件/Accessories
Z、附件/Accessories
序号
No.
附件
Part. No.
零部件名称
NAME OF PARTS
数量
Amt.
备注
1
10131004
JK-5550-1018螺丝刀(小)
1
2
10131003
螺丝刀(中)
1
3
10131002
螺丝刀(大)
1
4
30131007
内六角扳手(1.5mm)
1
5
20131046
JK-795-1911内六角扳手2mm
1
6
30131010
GB/T 5356内六角扳手2.5mm
1
7
30131012
GB/T 5356内六角扳手3mm
1
8
20131047
JK-800-1922内六角扳手4mm
1
9
20131056
JK-800-1912内六角扳手5mm
1
10
30131005
扳手(6mm~7mm)
1
11
30131006
JK-8569-W21-3双开口扳手(8-10mm)
1
12
41712355
JK-T3020-31-065针板专用螺丝刀
1
13
20131051
JK-795-1916镊子
1
14
11631008
JK-58420-Z33油壶组件
1
15
20131038
小油壶(尖嘴)
1
16
1011101200
JK-5550-1022-00油壶组件
1
17
11411029
JK-8990注射器
6
18
40730010
JK-5878螺旋气管
1
19
40736001
JK-5878-0115螺纹套管接头
1
20
41830017
JK-T12090-21-005电子标签卡
30
21
417S30036
JK-T1310-05-045螺栓(带垫圈)M5×12
4
22
407N01001
JK-T5878-58B-0104-02自锁螺母M5
12
23
S05124
GB/T 70.1-2000螺栓M5×16(滚花,镀镍)
12
24
42217504
MS-90A-0532机针DP×5 8#
4
25
10818501
梭心605.609大梭心
3
26
41815022
MS-90A-03-022孔板Φ1.7T2.5
1
27
20131076
15×9袋
7
28
20131077
20×15袋
2
29
61910003
JK-T5878-58B-0812扎带(小)
5
30
42130028
JK-T5878-68-2611反射纸0.254m×45.72m(欧倍丽)
10
31
141803006
MT-90C-11-027下轴油芯套
2
32
141822002
MT-90C-11-0230形圈3.6×0.8
2
33
141823001
MT-90C-11-030下轴油芯
2
34
141931002
MX-100A-40-002水平泡
1
35
41726014
JK-T2210-12-020针套
1
36
141931003
MX-100A-ZP48内六角扳手14mm
1
37
12921006
维尼龙油管(Φ6×Φ8)(进口)
0.5
38
915305
工业白油
0.5
39
41731015
JK-T2210-28-003花样机附件箱
1
40
141831017
MT-90C-31-014X送料同步带模组附件箱
1
41
41837613
MT-90C-31-009重心标贴
1
42
140237002
JK-T781-FJ20警告牌(护手)
1
43
41837615
MT-90C-31-011电线警告标贴
1
44
41837102
MS-90A-3702导轨注油标签
1
45
42131008
干燥剂(100克)
2
46
142037004
MS-100A-0232台面折叠注意标贴
2
47
141845007
MT-90C-24-013软管TUS0425N
2
48
20131063
JK-8777-0111警告牌
0.2
49
141916005
大压脚B
3
jintex.in
