Juki MO-2300 Series Parts Book PDF — View & Download

Parts index — Juki MO-2300 Seriestap a row to open its page

Page 1 — PARTS BOOK

Juki MO-2300 Series parts on page 1
Ref	Part number	Part name	Qty
	MO-2303	MO-2303
	MO-2304	MO-2304
	MO-2305	MO-2305
	MO-2312	MO-2312
	MO-2314	MO-2314
	MO-2315	MO-2315
	MO-2316	MO-2316

Page 3

Juki MO-2300 Series parts on page 3
Ref	Part number	Part name	Qty
	B1401-100-000	Needle bar
	B1401-100-000-A	Needle bar
	B1105-200-000	Frame cover
	B1105-300-000	Frame cover
	B1105-500-000	Frame cover
	B1105-600-000	Frame cover

Page 4 — CONTENTS

Juki MO-2300 Series parts on page 4
Ref	Part number	Part name	Qty
	MO-2303-0D4-300	MO-2303-0D4-300
	MO-2304-0A4-150	MO-2304-0A4-150
	MO-2304-0D4-200	MO-2304-0D4-200
	MO-2304-0E4-300	MO-2304-0E4-300
	MO-2304-0F4-300	MO-2304-0F4-300
	MO-2304-0D6-300	MO-2304-0D6-300
	MO-2304-0F6-500	MO-2304-0F6-500
	MO-2305-0D4-210/L001	MO-2305-0D4-210/L001
	MO-2312-CD4-300	MO-2312-CD4-300
	MO-2312-DF6-500	MO-2312-DF6-500
	MO-2314-BD4-200	MO-2314-BD4-200
	MO-2314-BE4-300	MO-2314-BE4-300
	MO-2314-BD6-300	MO-2314-BD6-300
	MO-2314-BD4-207	MO-2314-BD4-207
	MO-2314-BD4-307	MO-2314-BD4-307
	MO-2314-BE4-307	MO-2314-BE4-307
	MO-2314-BD6-307	MO-2314-BD6-307
	MO-2315-DD4-300	MO-2315-DD4-300
	MO-2316-BD4-300	MO-2316-BD4-300
	MO-2316-DD4-100	MO-2316-DD4-100
	MO-2316-DD6-500	MO-2316-DD6-500
	MO-2316-DF4-300	MO-2316-DF4-300
	MO-2316-FF6-500	MO-2316-FF6-500
	MO-2316-FF6-100	MO-2316-FF6-100
	MO-2316-RH6-100	MO-2316-RH6-100
	MO-2304-0D4-300/D025	MO-2304-0D4-300/D025
	MO-2314-BD4-300/D025	MO-2314-BD4-300/D025
	MO-2316-DD4-300/D026	MO-2316-DD4-300/D026
	MO-2314-BD6-340/G02/Q056	MO-2314-BD6-340/G02/Q056
	MO-2314-BD6-347/G02/Q056	MO-2314-BD6-347/G02/Q056
	MO-2304B-0D4-306	MO-2304B-0D4-306
	MO-2304E-0D4-20B/F	MO-2304E-0D4-20B/F
	MO-2314E-BD4-306	MO-2314E-BD4-306
	MO-2314E-BD6-306	MO-2314E-BD6-306
	MO-2314-BD4-307/D025	MO-2314-BD4-307/D025
	MO-2300	Standard model (No. 0203)
	MO-2300	標準機種、(No.0203)

Page 5

Juki MO-2300 Series parts on page 5
Part number	Part name	Qty
SS-7110710-SL	SCREW 11/64-40 L=7.0	1
118-88609	UPPER SPREADER	1
SS-6090630-SP	SCREW 9/64-40 L=6	1
118-76059	PRESSER FOOT ASM.	1
117-92900	STITCH TONGUE	(1)
118-76067	PRESSER FOOT ASM.	1
R4200-HOA-COO	THROAT PLATE	1
118-87007	AUXILIARY FEED DOG	1
MDC-10080800	NEEDLE DCX1 #8	1
118-81455	PRESSER FOOT ASM.	1
118-74609	STITCH TONGUE	(1)
118-81471	PRESSER FOOT ASM.	1
R4200-HOE-DOO	THROAT PLATE	1
118-88906	CHIP GUARD COVER	1
MDC-27080900	NEEDLE DCX?? #9	1
118-76257	PRESSER FOOT ASM.	1
B1509-804-COA	STITCH TONGUE	(1)
118-76265	PRESSER FOOT ASM.	1
R4200-HOF-DOO	THROAT PLATE	1
118-31559	LOOPER HOLDER ASM. B	1
SS-9151210-TP	SCREW 15/64-28 L=11.8	(1)
118-93609	GAUGE	1

Page 6

Juki MO-2300 Series parts on page 6
Part number	Part name	Qty
118-76356	PRESSER FOOT ASM.	1
118-73007	PRESSER FOOT	(1)
B1511-814-000	REAR PRESSER FOOT	1
118-76364	PRESSER FOOT ASM.	1
118-82206	MAIN FEED DOG	1
118-85100	DIFFERENTIAL FEED DOG	1
R4300-H00-E00	THROAT PLATE	1
118-76455	PRESSER FOOT ASM.	(1)
91509-304-COA	STITCH TONGUE	(1)
118-73007	PRESSER FOOT	(1)
B1511-814-000	REAR PRESSER FOOT	1
118-75463	PRESSER FOOT ASM.	1
118-58906	CHIP GUARD COVER	1
R4300-H00-E00	THROAT PLATE	1
118-82206	MAIN FEED DOG	1
118-93303	MAIN FEED DOG	1
118-85100	DIFFERENTIAL FEED DOG	1
118-95605	DIFFERENTIAL FEED DOG	1
MDC-27001400	NEEDLE DCX27 #14	1
118-31559	LOOPER HOLDER ASM. 9	(1)
SS-9151210-TP	SCREW 15/64-28 L=11.9	(1)
118-93609	GAUGE	2
118-78550	PRESSER FOOT ASM.	1
B1507-805-000-A	PRESSER FOOT	(1)
118-74807	STITCH TONGUE	(1)
118-78565	PRESSER FOOT ASM.	1
118-47506	KNIFE	1
118-65906	UPPER KNIFE	1
MAT-30101AB	BLIND HEMMING ATTACHMENT ASM. (9)	1
118-59003	CHIP GUARD COVER	1

Page 7

Juki MO-2300 Series parts on page 7
Ref	Part number	Part name
1	R4206-HOD-EOO	THROAT PLATE
2	118-69757	NEEDLE CLAMP ASM.
3	118-77156	PRESSER FOOT ASM.
4	117-93508	PRESSER FOOT
5	117-93607	STITCH TONGUE
6	118-77164	PRESSER FOOT ASM.
7	118-88005	UPPER LOOPER
8	118-69955	NEEDLE CLAMP ASM.
9	MDC-27081400	NEEDLE DCX27 #14
10	118-90407	NEEDLE GUARD
11	R4205-HDF-EOO	THROAT PLATE
12	119-30604	DIFFERENTIAL FEED DOG
13	119-30505	DIFFERENTIAL FEED DOG
14	118-37205	AUXILIARY FEED DOG
15	PDC-27080900	NEEDLE DCX27 #9
16	118-81554	PRESSER FOOT ASM.
17	118-74708	STITCH TONGUE
18	118-81570	PRESSER FOOT ASM.
19	R4205-HDF-EOO	THROAT PLATE
20	118-93609	GAUGE
21	R4305-HOD-EOO	THROAT PLATE
22	118-82404	MAIN FEED DOG
23	118-36504	DIFFERENTIAL FEED DOG

Page 8

Juki MO-2300 Series parts on page 8
Ref	Part number	Part name
1	118-93302	UPPER LOOPER GUIDE SUPPORT
2	SS-7151310-TP	SCREW
3	B2515-704-00B	UPPER LOOPER GUIDE COVER
4	118-81554	PRESSER FOOT ASM.
5	118-74708	STITCH TONGUE
6	118-93302	UPPER LOOPER GUIDE SUPPORT
7	SS-7151310-TP	SCREW
8	B2515-704-00B	UPPER LOOPER GUIDE COVER
9	R4205-HOE-E00	THPOAT PLATE
10	118-93302	UPPER LOOPER GUIDE SUPPORT
11	SS-7151310-TP	SCREW
12	B2515-704-00B	UPPER LOOPER GUIDE COVER
13	R4205-HOE-E00	THPOAT PLATE
14	118-82404	MAIN FEED DOG
15	118-86504	DIFFERENTIAL FEED DOG
16	118-93302	UPPER LOOPER GUIDE SUPPORT
17	SS-7151310-TP	SCREW
18	B2515-704-00B	UPPER LOOPER GUIDE COVER

Page 9

Juki MO-2300 Series parts on page 9
Ref	Part number	Part name
1	SS-6090630-SP	SCREW 9/64-40 L=6
2	118-88609	UPPER SPREADER
3	SS-7110710-SL	SCREW 11/64-40 L=7.0
4	118-77354	PRESSER FOOT ASM.
5	118-75101	REAR PRESSER FOOT
6	B1507-816-BOC	HINGED TYPE PRESSER FOOT (C)
7	118-77362	PRESSER FOOT ASM.
8	118-70151	NEEDLE CLAMP ASM.
9	118-87304	AUXILIARY FEED DOG
10	118-82602	MAIN FEED DOG
11	R4505-H0D-000	THROAT PLATE
12	118-79756	PRESSER FOOT ASM.
13	118-72603	PRESSER FOOT HINGE
14	SS-6080340-SP	SCREW 1/8-44 L=3.0
15	B1549-816-F00	CHAIN-OF-THREAD PRESSER PLATE
16	B1545-816-F00	SPRING
17	B1530-816-D0B	AUXILIARY STOPPER
18	B1546-816-F00	HINGE SPRING
19	B1507-816-F00	PRESSER FOOT
20	B1508-816-D0Z	CHAIN-OF-THREAD PRESSER
21	B1559-816-000	PIN
22	118-79764	PRESSER FOOT ASM.
23	B1508-816-D00	THROAT PLATE
24	R4508-H00-B00	NEEDLE DCX27 #9
25	MDC-270B0900	NEEDLE DCX27 #9

Page 10

Juki MO-2300 Series parts on page 10
Ref	Part number	Part name
1	B3101-704-080	TENSION CONTROLLER ASM., RED
2	118-45807	UPPER KNIFE
3	118-47407	KNIFE
4	MDC-27081600	NEEDLE DCX27 #16
5	118-82909	MAIN FEED DOG
6	118-85308	DIFFERENTIAL FEED DOG
7	118-85308	DIFFERENTIAL FEED DOG
8	R4608-HOD-F00	THROAT PLATE
9	118-88104	UPPER LOOPER
9	118-67405	CHIP GUARD COVER
10	R4508-HOF-000	THROAT PLATE
11	118-31559	LOOPER HOLDER ASM. 9
12	SS-9151210-TP	SCREW 15/64-28 L=11.5
13	118-93609	GAUGE

Page 11 — 22. MO-2316-FF6-500

Juki MO-2300 Series parts on page 11
Ref	Part number	Part name
1	118-77750	PRESSER FOOT ASM.
2	B1515-816-008	PRESSER FOOT ARM SPRING B
3	118-72207	PRESSER FOOT HINGE
4	118-75507	REAR PRESSER FOOT
5	B1507-816-F0D	HINGED TYPE PRESSER FOOT (D)
6	118-77768	PRESSER FOOT ASM.
7	B3101-704-080	TENSION CONTROLLER ASM., RED
8	118-70458	NEEDLE CLAMP ASM.
9	MDC-27081600	NEEDLE DCx27 #16
10	R4612-HOF-G00	THROAT PLATE
11	118-47407	KNIFE
12	118-45807	UPPER KNIFE
13	118-85407	DIFFERENTIAL FEED DOG
14	118-83006	MAIN FEED DOG
15	118-67405	CHIP GUARD COVER
16	118-31559	UPPER HOLDER ASM. B
17	SS-9151210-TP	SCREW 15/64-28 L=11.8
18	118-93609	GAUGE
19	118-88104	UPPER LOOPER

Page 12 — 23. MO-2316-FF6-100

Juki MO-2300 Series parts on page 12
Ref	Part number	Part name
1	118-80556	PRESSER FOOT ASM.
2	118-72603	PRESSER FOOT HINGE
3	SS-6080340-SP	SCREW 1/8-44 L=3.0
4	B1549-816-F00	CHAIN-OF THREAD PRESSER PLATE
5	B1545-816-F00	SPRING
6	B1530-816-D08	AUXILIARY STOPPER
7	SD-0400261-TP	HINGE SCREW
8	B1546-816-F00	SPRING
9	B1507-816-FCZ	PRESSER FOOT
10	B1559-816-000	PIN
11	B1508-816-FCZ	CHAIN-OF THREAD PRESSER
12	118-80564	PRESSER FOOT ASM.
13	118-84004	MAIN FEED DOG
14	118-86009	DIFFERENTIAL FEED DOG
15	118-45807	UPPER KNIFE
16	118-47407	KNIFE
17	R4612-HOF-B00	THROAT PLATE
18	118-70458	NEEDLE CLAMP ASM.
19	MDC-270B0900	NEEDLE BAR DCX27 #9
20	118-67405	CRISP GUARD COVER
21	118-31559	LOOPER HOLDER ASM. B
22	SS-9151210-TP	SCREW 15/64-28 L=11.8
23	118-93609	GAUGE

Page 13 — 24. MO-2316-RH6-100

Juki MO-2300 Series parts on page 13
Ref	Part number	Part name	Qty
	118-80952	PRESSER FOOT ASM.	(1)
	118-72603	PRESSER FOOT HINGE	(1)
	SS-6080340-SP	SCREW 1/8-44 L=3.0	(1)
	B1549-816-FC0	CHAIN-OF-THREAD PRESSER PLATE	(1)
	B1545-816-FC0	SPRING	(1)
	B1530-816-DCB	AUXILIARY STOPPER	(1)
	SD-0400261-TP	HINGE SCREW	(1)
	B1546-816-FC0	SPRING	(1)
	118-73205	PRESSER FOOT	(1)
	B1559-816-000	PIN	(1)
	118-75606	REAR PRESSER FOOT	(1)
001	118-80960	PRESSER FOOT ASM.
	118-84004	MAIN FEED DOG	1
	118-86009	DIFFERENTIAL FEED DOG	1
002	118-45807	UPPER KNIFE
003	118-47407	KNIFE
	R4617-HOH-BOO	THROAT PLATE	1
	118-70557	NEEDLE CLAMP ASM.	1
	MDC-270B0900	NEEDLE DCX27 #9	2
	118-67504	GUARD COVER	1
	118-93609	GAUGE	1

Page 14

Juki MO-2300 Series parts on page 14
Ref	Part number	Part name
1	R4200-H0D-D0B	THROAT PLATE
2	118-67207	CHIP GUARD COVER
3	118-92205	REGULATOR HOOK
4	SS-5090420-SP	SCREW 9/64-40 L=3.5
5	118-92403	REGULATOR HOOK SET BASE
6	SD-0640211-SP	HINGE SCREW D= 6.35 H= 2.1
7	R4205-H0D-E0A	TROAT PLATE (E08)
8	118-92205	REGULATOR HOOK
9	SS-5090420-SP	SCREW 9/64-40 L=3.5
10	118-92403	REGULATOR HOOK SET BASE
11	SD-0640211-SP	HINGE SCREW D= 6.35 H= 2.1
12	R4508-H0D-DOC	THROAT PLATE
13	118-67405	CHIP GUARD COVER
14	118-92205	REGULATOR HOOK
15	SS-5090420-SP	SCREW 9/64-40 L=3.5
16	118-92403	REGULATOR HOOK SET BASE
17	SD-0640211-SP	HINGE SCREW D= 6.35 H= 2.1

Page 15 — 28. MO-2314-BD6-340, MO-2314-BD6-347

Juki MO-2300 Series parts on page 15
Ref	Part number	Part name	Qty
	118-79251	PRESSER FOOT ASM.
	B1509-814-BOB	STITCH TONGUE
	B1531-814-000	TAPE GUIDE PLATE
	B1507-814-BOB	PRESSER FOOT
	001 118-79269	PRESSER FOOT ASM.
	002 118-93302	UPPER LOOPER GUIDE SUPPORT
	002 SS-7151310-TP	SCREW
	002 B2515-704-00B	UPPER LOOPER GUIDE COVER
	R4305-H0D-E00	THPOAT PLATE
	118-82404	MAIN FEED DOG
	118-86504	DIFFERENTIAL FEED DOG
	MAQ-056010A0	TAPE GUIDE
	NS-6090310-SP	NUT 9/64-40
	WP-0371018-SD	WASHER
	SS-7090910-SP	SCREW 9/64-40 L= 8.5

Page 16 — 29. MO-2304B-0D4-306 30. MO-2304E-0D4-20B/F

Juki MO-2300 Series parts on page 16
Part number	Part name	Qty
R4200-H00-00E	THROAT PLATE	1
MC-0336007-50	NEEDLE B-27 NM75	1
115-97101	MAIN FEED DOG	1
118-86207	DIFFERENTIAL FEED DOG	1
115-50159	TENSION CONTROLLER ASM., ORANGE	1
118-78568	PRESSER FOOT ASM.	1
B1507-805-000-A	PRESSER FOOT	(1)
118-74807	STITCH TONGUE	(1)
118-47506	KNIFE	1
MDC-27080900	NEEDLE DCX27 #9	1
118-89003	CHIP GUARD COVER	1
MAT-80101LAB	BLIND HEMMING ATTACHMENT ASM. (B)	1

Page 17

Juki MO-2300 Series parts on page 17
Ref	Part number	Part name	Qty
	118-98806	DIFFERENTIAL FEED DOG
	118-96900	DIFFERENTIAL FEED DOG
	118-82404	MAIN FEED DOG
	R4205-HOD-EOB	THROAT PLATE
	R4305-HOD-EOC	THROAT PLATE
	MAD-02501DA0	REGULATOR HOOK ASM.
	MAD-02501000	REGULATOR HOOK
	SS-3090420-SP	SCREW 9/64-40 L=3.5
	MAD-02502000	REGULATOR HOOK SET BASE
	SD-0640211-SP	SCREW D= 6.35 H= 2.1
	R4205-HOD-EOA	THROAT PLATE (EOB)
	118-93302	UPPER LOOPER GUIDE SUPPORT
	SS-7151310-TP	SCREW
	B2515-704-009	UPPER LOOPER GUIDE COVER

Page 18 — NUMERICAL INDEX OF PARTS

Juki MO-2300 Series parts on page 18
Ref	Part number	Part name	Qty
22	B1507-805-000-A	B1507-805-000-A	2
22	B1507-805-000-A	B1507-805-000-A	2
4	B1507-814-808	B1507-814-808	11
6	B1507-816-808	B1507-816-808	5
6	B1507-816-BOC	B1507-816-BOC	5
20	B1507-816-DOZ	B1507-816-DOZ	5
5	B1507-816-FOD	B1507-816-FOD	7
9	B1507-816-FOZ	B1507-816-FOZ	3
21	B1508-816-COA	B1508-816-COA	5
11	B1508-816-DOZ	B1508-816-DOZ	8
17	B1509-814-BOB	B1509-814-BOB	1
2	B1509-814-BOB	B1509-814-BOB	11
3	B1511-814-000	B1511-814-000	2
2	B1515-816-DO8	B1515-816-DO8	7
17	B1530-816-DO8	B1530-816-DO8	5
6	B1530-816-DO8	B1530-816-DO8	8
3	B1531-814-000	B1531-814-000	11
16	B1545-816-F00	B1545-816-F00	5
5	B1546-816-F00	B1546-816-F00	8
5	B1546-816-F00	B1546-816-F00	9
19	B1546-816-F00	B1546-816-F00	5
3	B1546-816-F00	B1546-816-F00	8
8	B1546-816-F00	B1546-816-F00	7
15	B1549-816-F00	B1549-816-F00	5
4	B1549-816-F00	B1549-816-F00	8
22	B1559-816-000	B1559-816-000	5
10	B1559-816-000	B1559-816-000	8
10	B1559-816-000	B1559-816-000	9
3	B2515-704-009	B2515-704-009	4
8	B2515-704-009	B2515-704-009	4
12	B2515-704-009	B2515-704-009	4
18	B2515-704-009	B2515-704-009	4
8	B2515-704-009	B2515-704-009	11
14	B2515-704-009	B2515-704-009	13
7	B3101-704-080	B3101-704-080	7
6	MAD-025010A0	MAD-025010A0	13
7	MAD-02501000	MAD-02501000	13
9	MAD-02502000	MAD-02502000	13
12	MAQ-056010A0	MAQ-056010A0	11
27	MAT-80101LAB	MAT-80101LAB	2
12	MAT-80101LAB	MAT-80101LAB	12
2	MDC-0336007-50	MDC-0336007-50	12
9	MDC-10080300	MDC-10080300	1
15	MDC-27080900	MDC-27080900	1
15	MDC-27080900	MDC-27080900	3
25	MDC-27080900	MDC-27080900	5
19	MDC-27080900	MDC-27080900	8
19	MDC-27080900	MDC-27080900	12
10	MDC-27080903	MDC-27080903	12
17	MDC-27081400	MDC-27081400	2
9	MDC-27081400	MDC-27081400	3
4	MDC-27081500	MDC-27081500	6
9	NS-6090313-SP	NS-6090313-SP	7
7	R4200-HOA-COO	R4200-HOA-COO	1
1	R4200-HOD-DOB	R4200-HOD-DOB	12
19	R4200-HOE-DOO	R4200-HOE-DOO	1
7	R4205-HOD-EOA	R4205-HOD-EOA	10
11	R4205-HOD-EOA	R4205-HOD-EOA	13
4	R4205-HOD-EOB	R4205-HOD-EOB	13
19	R4205-HOE-EOC	R4205-HOE-EOC	3
9	R4206-HOD-E00	R4206-HOD-E00	4
1	R4300-HOD-E00	R4300-HOD-E00	3
14	R4300-HOF-E00	R4300-HOF-E00	2
5	R4305-HOD-EOC	R4305-HOD-EOC	13
21	R4305-HOD-E00	R4305-HOD-E00	3
13	R4305-HOD-E00	R4305-HOD-E00	4
9	R4305-H05-E00	R4305-H05-E00	11
11	R4305-HOD-E00	R4305-HOD-E00	3
11	R4305-HOD-B00	R4305-HOD-B00	5
11	R4505-HOD-DOO	R4505-HOD-DOO	5
10	R4508-HOF-DOO	R4508-HOF-DOO	10
10	R4508-HOF-BOO	R4508-HOF-BOO	5
7	R4603-HOD-FOO	R4603-HOD-FOO	6
17	R4612-HOF-GOO	R4612-HOF-GOO	3
17	R4617-HOH-BOO	R4617-HOH-BOO	9
18	SD-0400261-TP	SD-0400261-TP	5
7	SD-0400261-SP	SD-0400261-SP	8
7	SD-0400261-SP	SD-0400261-SP	9
6	SD-0640211-SP	SD-0640211-SP	10
11	SD-0640211-SP	SD-0640211-SP	10
10	SD-0640211-SP	SD-0640211-SP	13
4	SS-5090420-SP	SS-5090420-SP	10
15	SS-5090420-SP	SS-5090420-SP	10
8	SS-5090420-SP	SS-5090420-SP	13
14	SS-6080340-SP	SS-6080340-SP	5
3	SS-6080340-SP	SS-6080340-SP	8
3	SS-6080340-SP	SS-6080340-SP	9
3	SS-6090630-SP	SS-6090630-SP	1
1	SS-6090630-SP	SS-6090630-SP	5
15	SS-7110710-SL	SS-7110710-SL	11
1	SS-7110710-SL	SS-7110710-SL	1
3	SS-7151310-TP	SS-7151310-TP	5
2	SS-7151310-TP	SS-7151310-TP	4
7	SS-7151310-TP	SS-7151310-TP	4
7	SS-7151310-TP	SS-7151310-TP	11
7	SS-7151310-TP	SS-7151310-TP	13
19	SS-9151210-TP	SS-9151210-TP	2
12	SS-9151210-TP	SS-9151210-TP	6
17	SS-9151210-TP	SS-9151210-TP	17
22	SS-9151210-TP	SS-9151210-TP	3
14	WP-0371015-SD	WP-0371015-SD	11
5	115-50159	115-50159	12
3	117-90508	117-90508	12
4	117-90607	117-90607	3
5	117-90706	117-90706	3
12	117-92900	117-92900	1
21	118-31559	118-31559	1
11	118-31559	118-31559	6
16	118-31559	118-31559	7
21	118-31559	118-31559	8
26	118-45807	118-45807	9
2	118-45807	118-45807	2
118-45807	118-45807	118-45807	16
14	118-45807	118-45807	9
4	118-45906	118-45906	12
15	118-47407	118-47407	4
11	118-47407	118-47407	11
11	118-47407	118-47407	13
8	118-47506	118-47506	2
2	118-67207	118-67207	10
18	118-67405	118-67405	13
5	118-67405	118-67405	3
13	118-67405	118-67405	10
10	118-67504	118-67504	7
8	118-69757	118-69757	8
14	118-69955	118-69955	3
19	118-70151	118-70151	7
18	118-70458	118-70458	8
18	118-70557	118-70557	9
3	118-72207	118-72207	7
13	118-72603	118-72603	5
2	118-72603	118-72603	8
2	118-73007	118-73007	2
10	118-73007	118-73007	2
10	118-73205	118-73205	9
11	118-74609	118-74609	1
17	118-74708	118-74708	1
5	118-74708	118-74708	4
23	118-74807	118-74807	2
8	118-74807	118-74807	12
5	118-75101	118-75101	5
4	118-75507	118-75507	7
11	118-75606	118-75606	9
4	118-76059	118-76059	1
6	118-76067	118-76067	1
16	118-76257	118-76257	1
18	118-76265	118-76265	1
1	118-76356	118-76356	2
4	118-76364	118-76364	2
12	118-77156	118-77156	3
6	118-77164	118-77164	3
4	118-77354	118-77354	5
7	118-77362	118-77362	5
1	118-77750	118-77750	7
6	118-77768	118-77768	7
21	118-78550	118-78550	2
24	118-78568	118-78568	12
6	118-78568	118-78568	2
1	118-79251	118-79251	11
5	118-79269	118-79269	11
12	118-79756	118-79756	5
23	118-79764	118-79764	5
12	118-80556	118-80556	3
12	118-80564	118-80564	1
12	118-80952	118-80952	9
12	118-80960	118-80960	9
10	118-81455	118-81455	1
12	118-81471	118-81471	1
16	118-81554	118-81554	3
16	118-81554	118-81554	4
18	118-81570	118-81570	3
5	118-82206	118-82206	2
15	118-82206	118-82206	2
22	118-82404	118-82404	3
14	118-82404	118-82404	4
10	118-82404	118-82404	11
13	118-82404	118-82404	13
13	118-82503	118-82503	3
10	118-82602	118-82602	3
5	118-82909	118-82909	6
14	118-83006	118-83006	7
15	118-33303	118-33303	2
13	118-84004	118-84004	8
13	118-84004	118-84004	9
6	118-85100	118-85100	2
16	118-85100	118-85100	2
6	118-85308	118-85308	6
13	118-85407	118-85407	7
16	118-85605	118-85605	2
14	118-86009	118-86009	3
14	118-86009	118-86009	9
4	118-86207	118-86207	12
23	118-86504	118-86504	3
15	118-86504	118-86504	4
11	118-86504	118-86504	11
8	118-87007	118-87007	1
14	118-87205	118-87205	3
9	118-37304	118-37304	5
7	118-88005	118-88005	3
8	118-88104	118-88104	6
19	118-88104	118-88104	7
14	118-88906	118-88906	1
20	118-88906	118-88906	1
13	118-88906	118-88906	2
28	118-89003	118-89003	2
11	118-89003	118-89003	12
3	118-92205	118-92205	10
8	118-92205	118-92205	10
10	118-92304	118-92304	10
14	118-92304	118-92304	10
5	118-92403	118-92403	10
10	118-92403	118-92403	10
16	118-92403	118-92403	10
1	118-93302	118-93302	4
6	118-93302	118-93302	4
10	118-93302	118-93302	4
16	118-93302	118-93302	4
6	118-93302	118-93302	11
20	118-93609	118-93609	2
20	118-93609	118-93609	3
13	118-93609	118-93609	6
18	118-93609	118-93609	7
23	118-93609	118-93609	8
21	118-93609	118-93609	9
1	118-98806	118-98806	13
13	119-80505	119-80505	3
12	119-80604	119-80604	3
6	119-80302	119-80302	5
6	119-80901	119-80901	6

Juki MO-2300 Series — parts catalog

Page 1 (cover): This is the cover page for the JUKI MO-2300 series subclasses parts book, published in 1985-8.
Page 2 (unknown): This page contains a watermark and a footer indicating it is from the library of Superior Sewing Machine & Supply LLC.
Page 3 (text): This page explains how to use the parts book, including how to interpret codes for part changes and quantities, and provides instructions for ordering spare parts.
Page 4 (toc): This page is a table of contents listing part numbers and their corresponding page numbers. It includes a section for "NUMERICAL INDEX OF PARTS" and a note about other related parts.
Page 5 (parts_list): This page lists parts for sewing machine models MO-2303-0D4-300, MO-2304-0A4-150, MO-2304-0D4-200, MO-2304-0E4-300, and MO-2304-0F4-300, including part numbers, descriptions, and quantities.
Page 6 (parts_list): This page contains parts lists for sewing machine models MO-2304-0D6-300, MO-2304-0F6-500, and MO-2305-0D4-210, including part numbers, descriptions, and quantities.
Page 7 (parts_list): This page contains parts lists and diagrams for MO-2312-CD4-300, MO-2312-DF6-500, MO-2314-BD4-200, MO-2314-BE4-300, and MO-2314-BD6-300 sewing machine models.
Page 8 (parts_list): This page lists parts for models MO-2314-BD4-207, MO-2314-BD4-307, MO-2314-BE4-307, and MO-2314-BD6-307, including part numbers, descriptions, and quantities.
Page 9 (parts_list): This page lists parts for models MO-2315-DD4-300, MO-2316-BD4-300, and MO-2316-DD4-100, including screws, presser feet, needles, and throat plates.
Page 10 (diagram): This page displays diagrams and parts lists for two components: MO-2316-DD6-500 and MO-2316-DF4-300. It includes detailed part numbers, descriptions, and quantities for each.
Page 11 (parts_list): This page lists parts for model MO-2316-FF6-500, including part numbers, descriptions, and quantities.
Page 12 (diagram): This page displays a diagram of sewing machine parts with corresponding part numbers and descriptions, including a parts list table.
Page 13 (diagram): This page displays a diagram of sewing machine parts for model MO-2316-RH6-100 and MO-2316-RH6-100, along with a detailed parts list including part numbers, descriptions, and quantities.
Page 14 (diagram): This page displays diagrams and parts lists for sewing machine components, specifically for models MO-2304-0D4-305/E05, MO-2314-BD4-305/E08, and MO-2316-DD4-305/E07.
Page 15 (parts_list): This page lists parts for MO-2314-BD6-340 and MO-2314-BD6-347, including part numbers, descriptions, and quantities.
Page 16 (diagram): This page contains diagrams and parts lists for sewing machine models MO-2304B-0D4-306 and MO-2304E-0D4-20B/F, detailing components such as throat plates, feed dogs, presser feet, and stitch tongues.
Page 17 (parts_list): This page lists parts for sewing machine models MO-2314E-BD4-306, MO-2314E-BD6-306, and MO-2314-BD4-307/D025, including part numbers, descriptions, and quantities.
Page 18 (parts_list): This page contains a numerical index of parts for industrial sewing machines, listing part numbers, corresponding page numbers, and reference numbers.
Page 19 (cover): This is the cover page of a parts catalog from the library of Superior Sewing Machine & Supply LLC, featuring a watermark of "jintex.in".
Page 20 (cover): This is the cover page of the JUKI TOKYO INDUSTRIAL CO., LTD. catalog, featuring the company logo and address information.

Page 1 — PARTS BOOK

JUKI No.0209-01 1985-8 BE230330PJA model MO-2300 サブクラス SUBCLASSES PARTS BOOK MO-2303 MO-2304 MO-2305 MO-2312 MO-2314 MO-2315 MO-2316 MO 2300 SERIES JUKI MO-2316 Class DD4-300 TOKYO JUKI INDUSTRIAL CO., LTD. From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 2

jinttex.in jinttex.in From the library of: Superior Sewing Machine & Supply LLC Jinttex.in

Page 3

HOW TO MAKE USE OF THIS PARTS BOOK パーツブックの見方 1. The part numbers of parts shown in the figure indicate the corresponding numbers (Ref. No.) shown by the Index. 図に示された部品の品番は、図にふられているNo (Ref.No)に対応するインデックスによって、その品番がわかります。 2. Explanation of codes 記号の説明 1) Codes on the "Note" column “注記”欄の記号 ① ☆... means this part is changed from the previous parts book. 前回のパーツブックに対して今回変更された部品を意味します ② #01... refer to the "Note" explanation at bottom of page. 001 ページ下の“注記”の説明を参照して下さい ③ When previous parts (Obsoleted part) and new parts (Added parts) are not interchangeable with each other: この場合、旧部品と新部品 (追加部品) は互換性がない変更の場合 In this case, even obsoleted part (D.) can be ordered with the obsoleted part number, so select the parts with changed dates and place your orders. この場合は削除(D)された品番でもご注文できますから、変更年月日により、いずれかの部品をご注文して下さい。 Example (例) Ref. No. 注記 Part No. 品番 Description E.C. 変更年月 Amt. Req. 数品名 1 ☆ B1401-100-000 Needle bar D.10/83 ハリホー 1 1-1 ☆ B1401-100-000-A Needle bar D.10/83 ハリホー B1105-200-000 Frame cover D.10/83 B1105-300-000 1 ☆ B1105-300-000 Frame cover A.10/83 フレームカバー 4) In case when previous parts and new part are interchangeable with each other: 部品の互換性がある場合の変更 In this case the new part number is replaced on the “品名 (Japanese)" column of the previous parts book, so please order by the new part number. この場合は、旧部品の注文品番欄にそれにかわる新しい品番が記入されていますので、新しい品番でご注文して下さい。 ⑤ C.10/83 1 B1105-500-000 Frame cover C.10/83 B1105-600-000 1 Correct No. 正しい品番 Wrong No. 誤り品番 Please order by the correct part number. 正しい品番でご注文下さい。 ⑥ M.10/83 The amount required is changed from October, 1983 1983年10月より数量が変更になった The new amount required is shown in the "Amt. Req." column. この場合数量欄には新しい数量が表示してあります。 1983年10月より数量が変更になった Codes on the "Amt. Req." column “数量”欄の記号 1) ① 2 Indicates amount required is 2. 数量、2個を表わします。 2) 2.0 Indicates length in meters. (unit is meter) 長さ、2メートルを表わします。(単位はメートルです) 3) - Indicates parts obsoleted from the parts book. このパーツブックから削除された部品です。 4) (1) Indicates sub parts which construct the assembly part. Assembly part is shown as "asm." and クミ in Japanese, in the "Description" column 部品は品番欄に英文で"asm."とクミで表示してあります。 When Ordering The Spare Parts: In order to ensure that we deliver the correct parts to you, please clearly state when ordering the corresponding PART NUMBER (ex. B1109-012-A00) and also the PARTS BOOK NUMBER (ex. 0010-01, given at the top right of the cover) or the MACHINE SERIAL NUMBER, because there are some parts which have been changed. 補用部品注文の際のご注意このパーツブックに記載されている補用部品をご注文の際は、部品の番号(例えは、B1109-012-A00)でご注文下さい。番号(表紙右上、例えは、No.0010-01)又は、機械番号をご連絡頂ければ幸いです。又、改良のため部品の一部が変更になる場合がありますのでご了承下さい。 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 4 — CONTENTS

CONTENTS 目次 1. MO-2303-0D4-300 1 2. MO-2304-0A4-150 1 3. MO-2304-0D4-200 1 MO-2304-0E4-300 1 4. MO-2304-0F4-300 1 5. MO-2304-0D6-300 2 6. MO-2304-0F6-500 2 7. MO-2305-0D4-210/L001 3 8. MO-2312-CD4-300 3 9. MO-2312-DF6-500 3 10. MO-2314-BD4-200 3 11. MO-2314-BE4-300 3 12. MO-2314-BD6-300 3 13. MO-2314-BD4-207 4 14. MO-2314-BD4-307 4 15. MO-2314-BE4-307 4 16. MO-2314-BD6-307 4 17. MO-2315-DD4-300 5 18. MO-2316-BD4-300 5 19. MO-2316-DD4-100 5 20. MO-2316-DD6-500 5 21. MO-2316-DF4-300 6 22. MO-2316-FF6-500 6 23. MO-2316-FF6-100 7 24. MO-2316-RH6-100 8 25. MO-2304-0D4-300/D025 9 26. MO-2314-BD4-300/D025 10 27. MO-2316-DD4-300/D026 10 28. MO-2314-BD6-340/G02/Q056 11 MO-2314-BD6-347/G02/Q056 11 29. MO-2304B-0D4-306 12 30. MO-2304E-0D4-20B/F 12 31. MO-2314E-BD4-306 13 MO-2314E-BD6-306 13 32. MO-2314-BD4-307/D025 13 NUMERICAL INDEX OF PARTS 14 索引 Other parts related to this model. この機種に関するパーツブックとして下記のパーツブックがあります。 1. MO-2300 Standard model (No. 0203) MO-2300標準機種、(No.0203)

Page 5

1. MO-2303-0D4-300 2 3 1. MO-2303-0D4-300 Ref. No. Part No. 品番 Description E. C. 変更年月品名 Amt. Req. 数量 1 SS-7110710-SL 118-88609 SS-6090630-SP SCREW 11/64-40 L=7.0 UPPER SPREADER SCREW 9/64-40 L=6 マルヒラネシ 11/64-40 L=7 ウワカキルーバヒラネシ 9/64-40 L=6 1 1 2. MO-2304-0A4-150 4 118-76059 PRESSER FOOT ASM. オサエクミ 1 5 117-92900 STITCH TONGUE イトスペリリタイ (1) 6 001 118-76067 PRESSER FOOT ASM. オサエクミ (ユビカ・ートツキ) 1 7 R4200-HOA-COO THROAT PLATE ハリイタ 1 8 118-87007 AUXILIARY FEED DOG ホシバヨクオリハ 1 9 MDC-10080800 NEEDLE DCX1 #8 ハリ DCX1 #8 1 3. MO-2304-0D4-200, MO-2304-0E4-300 10 002 118-81455 PRESSER FOOT ASM. オサエクミ 1 11 002 118-74609 STITCH TONGUE イトスペリリタイ (1) 12 003 118-81471 PRESSER FOOT ASM. オサエクミ 1 13 004 R4200-HOE-DOO THROAT PLATE ハリイタ 1 14 004 118-88906 CHIP GUARD COVER スノクスハカバー 1 15 002 MDC-27080900 NEEDLE DCX?? #9 ハリ DCX?? #9 1 4. MO-2304-0F4-300 16 118-76257 PRESSER FOOT ASM. オサエクミ 1 17 B1509-804-COA STITCH TONGUE イトスペリリタイ (1) 18 001 118-76265 PRESSER FOOT ASM. オサエクミ (ユビカ・ートツキ) 1 19 R4200-HOF-DOO THROAT PLATE ハリイタ 1 20 118-31559 LOOPER HOLDER ASM. B ウワルーハ・ウデクミ 1 21 SS-9151210-TP SCREW 15/64-28 L=11.8 ロッカクボルト 15/64-28 (1) 22 118-93609 GAUGE ウワルーハ・ガイドササエゲーシ 1 国内は特別注文部品 Note (注記) 001... Standard part 001... Standard part OD4-200用 002... For OD4-200 OD4-200用 003... Standard part (OD4-200) OD4-200特別注文部品 004... For OE4-300 OE4-300用 *All parts other than the above are same as those used in 上記以外の部品は、MO-2304-0D4-300 model MO-2304-0D4-300. と同じです。 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 6

5. MO-2304-0D6-300 Ref. No. Note No. Part No. Description E.C. 変更年月品名 Amt. Req. 数量 1 118-76356 PRESSER FOOT ASM. (1) 2 118-73007 PRESSER FOOT (1) 3 B1511-814-000 REAR PRESSER FOOT 1 4 #01 118-76364 PRESSER FOOT ASM. 1 5 118-82206 MAIN FEED DOG 1 6 118-85100 DIFFERENTIAL FEED DOG 1 7 R4300-H00-E00 THROAT PLATE 1 6. MO-2304-0F6-500 8 118-76455 PRESSER FOOT ASM. オキエクミ (1) 9 91509-304-COA STITCH TONGUE イトスペリグイ (1) 10 118-73007 PRESSER FOOT オキエ (1) 11 B1511-814-000 REAR PRESSER FOOT カラカントメ 1 12 #01 118-75463 PRESSER FOOT ASM. オキエクミ (2ヒﾞｰｶﾞｰﾄﾞツキ) 1 13 118-58906 CHIP GUARD COVER スノクスカルバー 1 14 R4300-H00-E00 THROAT PLATE ハリイタ 1 15 118-82206 MAIN FEED DOG D.05/85 118-83303 1 16 118-93303 MAIN FEED DOG D.05/85 119-85605 1 118-85100 DIFFERENTIAL FEED DOG D.05/85 1 118-95605 DIFFERENTIAL FEED DOG フクオクリバ 1 17 MDC-27001400 NEEDLE DCX27 #14 ハリ DCX27 #14 1 18 118-31559 LOOPER HOLDER ASM. 9 ワクルーハクチメ (1) 19 SS-9151210-TP SCREW 15/64-28 L=11.9 コワクネルト (1) 20 118-93609 GAUGE 2 7. MO-2304-0D4-210 21 118-78550 PRESSER FOOT ASM. オキエクミ 1 22 B1507-805-000-A PRESSER FOOT オキエ (1) 23 118-74807 STITCH TONGUE イトスペリグイ (1) 24 #01 118-78565 PRESSER FOOT ASM. オキエクミ (2ヒﾞｰｶﾞｰﾄﾞツキ) 1 25 #02 118-47506 KNIFE ヒラメス 1 26 #03 118-65906 UPPER KNIFE クワメス 1 27 MAT-30101AB BLIND HEMMING ATTACHMENT ASM. (9) スソヒキアタッチメントクミ 1 28 118-59003 CHIP GUARD COVER スノクスカルバー 1 Note (注記) 001... Standard part 国内は特別注文部品 002... For domestic use 国内用 003... For export 輸出用 *All parts other than the above are same as those 上記以外の部品は、MO-2304-0D4-300 used in model MO-2304-0D4-300. と同じです。 -2- From the library of: Superior Sewing Machine & Supply LLC Jinttex.in

Page 7

8. MO-2312-CD4-300 9. MO-2312-DF6-500 10. MO-2314-BD4-200 11. MO-2314-BE4-300 12. MO-2314-BD6-300 Ref. No. Note 注記 Part No. 番 Description E.C. 変更年月 Amt. Req. 数量 1 R4206-HOD-EOO THROAT PLATE ハリイタ 1 118-69757 NEEDLE CLAMP ASM. ニホンバリ 1 9. MO-2312-DF6-500 118-77156 PRESSER FOOT ASM. オウエクミ 1 117-93508 PRESSER FOOT オウエ (1) 117-93607 STITCH TONGUE イトスペリリタイ (1) #31 118-77164 PRESSER FOOT ASM. オウエクミ (スヒカカートワキ) 1 118-88005 UPPER LOOPER ルー 1 118-69955 NEEDLE CLAMP ASM. ニホンバリハリトメクミ 1 MDC-27081400 NEEDLE DCX27 #14 ハリ DCX27 #14 2 118-90407 NEEDLE GUARD ハリツク 1 R4205-HDF-EOO THROAT PLATE ハリイタ 1 119-30604 DIFFERENTIAL FEED DOG 0.05/85 119-80604 1 119-30505 DIFFERENTIAL FEED DOG 0.05/85 119-80505 1 118-37205 AUXILIARY FEED DOG 0.05/85 シエオクリバ 1 10. MO-2314-BD4-200 15 PDC-27080900 NEEDLE DCX27 #9 ハリ DCX27 #9 1 16 118-81554 PRESSER FOOT ASM. オウエクミ (1) 17 118-74708 STITCH TONGUE イトスペリリタイ 1 18 #31 118-81570 PRESSER FOOT ASM. オウエクミ 1 11. MO-2314-BE4-300 19 R4205-HDF-EOO THROAT PLATE ハリイタ 1 20 118-93609 GAUGE フクワリバ 1 12. MO-2314-BD6-300 21 R4305-HOD-EOO THROAT PLATE ハリイタ 1 22 118-82404 MAIN FEED DOG シエオクリバ 1 23 118-36504 DIFFERENTIAL FEED DOG フクオクリバ 1 Note (注記) 001 ... Standard part *All parts other than the above are same as those 国内は特別注文部品 used in model MO-2314-BD4-300. 上記以外は、MO-2314-BD4-300 と同じです。 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 8

13. MO-2314-BD4-207 Ref. No. Part No. 品番 Description E. C. 変更年月 Amt. Req. 数量 1 118-93302 UPPER LOOPER GUIDE SUPPORT ワクルーハーガイドサポート B 1 2 SS-7151310-TP SCREW ワクルーハーガイドサポートクリエション 2 3 B2515-704-00B UPPER LOOPER GUIDE COVER ワクルーハーガイドフタ B 1 4 118-81554 PRESSER FOOT ASM. オサエクミ 1 5 118-74708 STITCH TONGUE イトスペリタイ (1) 14. MO-2314-BD4-307 6 118-93302 UPPER LOOPER GUIDE SUPPORT ワクルーハーガイドサポート B 1 7 SS-7151310-TP SCREW ワクルーハーガイドサポートクリエション 2 8 B2515-704-00B UPPER LOOPER GUIDE COVER ワクルーハーガイドフタ B 1 15. MO-2314-BE4-307 9 R4205-HOE-E00 THPOAT PLATE ハリイタ 1 10 118-93302 UPPER LOOPER GUIDE SUPPORT ワクルーハーガイドサポート B 1 11 SS-7151310-TP SCREW ワクルーハーガイドサポートクリエション 2 12 B2515-704-00B UPPER LOOPER GUIDE COVER ワクルーハーガイドフタ B 1 16. MO-2314-BD6-307 13 R4205-HOE-E00 THPOAT PLATE ハリイタ 1 14 118-82404 MAIN FEED DOG シュオクリハバ 1 15 118-86504 DIFFERENTIAL FEED DOG フクオクリハバ 1 16 118-93302 UPPER LOOPER GUIDE SUPPORT ワクルーハーガイドサポート B 1 17 SS-7151310-TP SCREW ワクルーハーガイドサポートクリエション 2 18 B2515-704-00B UPPER LOOPER GUIDE COVER ワクルーハーガイドフタ B 1 *All parts other than the above are same as those used in model MO-2314-BD4-300. 上記以外の部品は、MO-2314-BD4-300 と同じです。 -4- From the library of: Superior Sewing Machine & Supply LLC Jinte.in

Page 9

17. MO-2315-DD4-300 18. MO-2316-BD4-300 19. MO-2316-DD4-100 Ref. Note No. 注記 Part No. 品番 Description E. C. 変更年月 Amt. Req. 数量 1 SS-6090630-SP 118-88609 SS-7110710-SL SCREW 9/64-40 L=6 UPPER SPREADER SCREW 11/64-40 L=7.0 ヒラネジ 9/64-40 L=6 ウワカギルーハマルヒラネジ 11/64-40 L=7 1 1 1 4 118-77354 PRESSER FOOT ASM. オサエクミ 1 5 118-75101 REAR PRESSER FOOT ウシロオサエ (1) 6 B1507-816-BOC HINGED TYPE PRESSER FOOT (C) シシユウオサエクミ (ユビカ・ートツキ) 1 7 001 118-77362 PRESSER FOOT ASM. オサエクミ 1 8 118-70151 NEEDLE CLAMP ASM. ニシジユウカンハリトメクミ 1 9 118-87304 AUXILIARY FEED DOG ホシバヨウクリハ 1 10 118-82602 MAIN FEED DOG シュウクリハ 1 11 R4505-H0D-000 THROAT PLATE ハリイタ 1 12 118-79756 PRESSER FOOT ASM. オサエクミ 1 13 118-72603 PRESSER FOOT HINGE オサエヒンジ (1) 14 SS-6080340-SP SCREW 1/8-44 L=3.0 ヒラネジ 1/8-44 L=2.9 (1) 15 B1549-816-F00 CHAIN-OF-THREAD PRESSER PLATE カラカンオサエチョウセツイツク (1) 16 B1545-816-F00 SPRING スプリング (1) 17 B1530-816-D0B AUXILIARY STOPPER ホシバトメ (1) 18 B1546-816-F00 HINGE SPRING カラカンオサエハリトメ・メクンニシ (1) 19 B1507-816-F00 PRESSER FOOT オサエ (1) 20 B1508-816-D0Z CHAIN-OF-THREAD PRESSER カラカンオサエ (1) 21 B1559-816-000 PIN ピン 1 22 001 118-79764 PRESSER FOOT ASM. オサエクミ (ユビカ・ートツキ) 1 23 B1508-816-D00 THROAT PLATE ハリイタ 1 24 R4508-H00-B00 NEEDLE DCX27 #9 ハリ DCX27 #9 1 25 MDC-270B0900 Note (注記) 001 ... Standard part 国内は特別注文部品 *All parts other than the above are same as those 上記以外の部品は、MO-2316-DD4-300 used in model MO-2316-DD4-300. と同じです。 -6- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 10

20. MO-2316-DD6-500 21. MO-2316-DF4-300 Ref. No. Note 注記 Part No. 部品番 Description E.C. 変更年月品名 Amt. Req. 数量 1 B3101-704-080 TENSION CONTROLLER ASM., RED イトチョーシバアカクミ 1 2 #J1 118-45807 UPPER KNIFE ウワメス 1 3 #02 118-47407 KNIFE ヒラメス 1 4 MDC-27081600 NEEDLE DCX27 #16 ハリ DCX27 #16 2 5 * 118-82909 MAIN FEED DOG D.05/85 119-80802 1 6 * 118-85308 DIFFERENTIAL FEED DOG D.05/85 119-80901 1 7 * 118-85308 DIFFERENTIAL FEED DOG D.05/85 119-80901 1 8 R4608-HOD-F00 THROAT PLATE A.05/85 フクオクリバ 1 9 118-88104 UPPER LOOPER ウワルーバ 1 10 118-67405 CHIP GUARD COVER スノクス 1 11 H4508-HOF-000 THROAT PLATE ハリタ 1 12 118-31559 LOOPER HOLDER ASM. 9 ウワルーパウテ 1 13 SS-9151210-TP SCREW 15/64-28 L=11.5 ロツカクボルト 15/64-28 (1) 118-93609 GAUGE ハツカカイトウサゲゲージ 1 Note (注記) 001 ... For export 輸出用 002 ... For domestic use 国内用 *All parts other than the above are same as those used in model MO-2316-DD4-300. 上記以外の部品は、MO-2316-DD4-300 と同じです。 -6- From the library of: Superior Sewing Machine & Supply LLC Jinttex.in

Page 11 — 22. MO-2316-FF6-500

22. MO-2316-FF6-500 Ref. Note No. 記 Part No. 品 Description Amt. Req. 数量 1 118-77750 PRESSER FOOT ASM. 1 2 B1515-816-008 PRESSER FOOT ARM SPRING B (1) 3 118-72207 PRESSER FOOT HINGE (1) 4 118-75507 REAR PRESSER FOOT (1) 5 B1507-816-F0D HINGED TYPE PRESSER FOOT (D) (1) 6 001 118-77768 PRESSER FOOT ASM. 1 7 B3101-704-080 TENSION CONTROLLER ASM., RED 1 8 118-70458 NEEDLE CLAMP ASM. 1 9 MDC-27081600 NEEDLE DCx27 #16 2 10 R4612-HOF-G00 THROAT PLATE 1 11 002 118-47407 KNIFE 1 12 003 118-45807 UPPER KNIFE 1 13 118-85407 DIFFERENTIAL FEED DOG 1 14 118-83006 MAIN FEED DOG 1 15 118-67405 CHIP GUARD COVER 1 16 118-31559 UPPER HOLDER ASM. B (1) 17 SS-9151210-TP SCREW 15/64-28 L=11.8 (1) 18 118-93609 GAUGE 1 19 118-88104 UPPER LOOPER 1 Note (注記) 001... Standard part 国内は特別注文部品 002... For domestic use 国内用 003... For export 輸出用 *All parts other than the above are same as those 上記以外の部品は、MO-2316-DD4-300 used in model MO-2316-DD4-300. と同じです。 -7- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 12 — 23. MO-2316-FF6-100

23. MO-2316-FF6-100 Ref. No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Part No. 品番 118-80556 118-72603 SS-6080340-SP B1549-816-F00 B1545-816-F00 B1530-816-D08 SD-0400261-TP B1546-816-F00 B1507-816-FCZ B1559-816-000 B1508-816-FCZ 001 118-80564 118-86009 002 118-45807 118-47407 R4612-HOF-B00 118-70458 MDC-270B0900 118-67405 118-31559 SS-9151210-TP 118-93609 Description PRESSER FOOT ASM. PRESSER FOOT HINGE SCREW 1/8-44 L=3.0 CHAIN-OF THREAD PRESSER PLATE SPRING AUXILIARY STOPPER HINGE SCREW SPRING PRESSER FOOT PIN CHAIN-OF THREAD PRESSER PRESSER FOOT ASM. MAIN FEED DOG DIFFERENTIAL FEED DOG UPPER KNIFE KNIFE THROAT PLATE NEEDLE CLAMP ASM. NEEDLE BAR DCX27 #9 CRISP GUARD COVER LOOPER HOLDER ASM. B SCREW 15/64-28 L=11.8 GAUGE E. C. 変更年月国内は特別注文部品輸出用国内用上記以外の部品は、MO-2316-DD4-300 と同じです。 Amt. Req. 数量 1 (1) (1) (1) (1) (1) (1) (1) (1) (1) (1) 1 1 1 1 1 1 2 1 1 Note (注記) 001... Standard part 002... For export 003... For domestic use *All parts other than the above are same as those used in model MO-2316-DD4-300. -8- From the library of: Superior Sewing Machine & Supply LLC Jinte.in

Page 13 — 24. MO-2316-RH6-100

24. MO-2316-RH6-100 Ref. Note No. 記 1 2 3 4 5 6 7 8 9 10 11 12 001 13 14 15 002 16 003 17 18 19 20 21 Part No. 品番 118-80952 118-72603 SS-6080340-SP B1549-816-FC0 B1545-816-FC0 B1530-816-DCB SD-0400261-TP B1546-816-FC0 118-73205 B1559-816-000 118-75606 118-80960 118-84004 118-86009 118-45807 118-47407 R4617-HOH-BOO 118-70557 MDC-270B0900 118-67504 Description PRESSER FOOT ASM. PRESSER FOOT HINGE SCREW 1/8-44 L=3.0 CHAIN-OF-THREAD PRESSER PLATE SPRING AUXILIARY STOPPER HINGE SCREW SPRING PRESSER FOOT PIN REAR PRESSER FOOT PRESSER FOOT ASM. MAIN FEED DOG DIFFERENTIAL FEED DOG UPPER KNIFE KNIFE THROAT PLATE NEEDLE CLAMP ASM. NEEDLE DCX27 #9 GUARD COVER GAUGE E. C. 変更年月品名オサエクミオサエヒンジヒラネジ 1/8-44 L=2.9 カラカンオサエチョウセツソイノオサエトツケバネホシバトメタイカラカンオサエハネドメクリンネシカラカンオサエハネオサエヒンジピンカラカンオサエオサエクミ (ユビカバートツキ) シュオクリバフクオクリバワクメスヒラメスハリイタニシジユウカンハリトメクミハリ DCX27 #9 スノコカバーラウールハカイトウサエゲージ Amt. Req. 数量 (1) (1) (1) (1) (1) (1) (1) (1) (1) (1) 1 1 1 1 1 1 2 1 Note (注記) 001... Standard part 002... For export *All parts other than the above are same as those used in model MO-2316-DD4-300. 国内は特別注文部品輸出用国内用上記以外の部品は、MO-2316-DD4-300 と同じです。 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 14

25. MO-2304-0D4-305/E05 (3) (3) 1 3 4 2 26. MO-2314-BD4-305/E08 (3) (3) 7 8 9 10 11 5 6 Ref. No. 1 2 3 4 5 6 7 8 9 10 11 Part No. 品 R4200-H0D-D0B 118-67207 118-92205 SS-5090420-SP 118-92403 SD-0640211-SP R4205-H0D-E0A 118-92205 SS-5090420-SP 118-92403 SD-0640211-SP Description THROAT PLATE CHIP GUARD COVER REGULATOR HOOK SCREW 9/64-40 L=3.5 REGULATOR HOOK SET BASE HINGE SCREW D= 6.35 H= 2.1 TROAT PLATE (E08) REGULATOR HOOK SCREW 9/64-40 L=3.5 REGULATOR HOOK SET BASE HINGE SCREW D= 6.35 H= 2.1 *All parts other than the above are same as those used in model MO-2304-0D4-300. E. C. 変更年月ハリイタヌノクシカバーチョウセツツメトラスネジ 9/64-40 L=3.5 チョウセツツメトリツケダイダンネジ D= 6.35 H= 2.1 上記以外の部品は、MO-2304-OD4-300 と同じです。ハリイタ (E-08) チョウセツツメトラスネジ 9/64-40 L=3.5 チョウセツツメトリツケダイダンネジ D= 6.35 H= 2.1 上記以外の部品は、MO-2314-BD4-300 と同じです。 27. MO-2316-DD4-305/E07 12 13 14 15 16 17 12 13 14 15 16 17 R4508-H0D-DOC 118-67405 118-92205 SS-5090420-SP 118-92403 SD-0640211-SP THROAT PLATE CHIP GUARD COVER REGULATOR HOOK SCREW 9/64-40 L=3.5 REGULATOR HOOK SET BASE HINGE SCREW D= 6.35 H= 2.1 ハリイタヌノクシカバーチョウセツツメトラスネジ 9/64-40 L=3.5 チョウセツツメトリツケダイダンネジ D= 6.35 H= 2.1 *All parts other than the above are same as those used in model MO-2316-DD4-300. 上記以外の部品は、MO-2316-DD4-300 と同じです。 Amt. Req. 数量 1 1 1 2 1 2 1 1 1 2 1 2 - 10 - From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 15 — 28. MO-2314-BD6-340, MO-2314-BD6-347

28. MO-2314-BD6-340, MO-2314-BD6-347 Ref. No. Note 品 Part No. 番 Description E. C. 変更年月 Amt. Req. 数量 1 118-79251 PRESSER FOOT ASM. オサエクミ 1 2 B1509-814-BOB STITCH TONGUE イトスヘリダイ (1) 3 B1531-814-000 TAPE GUIDE PLATE テープアンナイタ (1) 4 B1507-814-BOB PRESSER FOOT テーブイレオサエ (1) 5 001 118-79269 PRESSER FOOT ASM. オサエクミ (ユビカートツキ) G02 1 6 002 118-93302 UPPER LOOPER GUIDE SUPPORT ウワルーハガイドササエ B 1 7 002 SS-7151310-TP SCREW ウワルーハガイドササエ B 2 8 002 B2515-704-00B UPPER LOOPER GUIDE COVER ハリイタ 1 9 R4305-H0D-E00 THPOAT PLATE シュオクリハ 1 10 118-82404 MAIN FEED DOG フクオクリハ 1 11 118-86504 DIFFERENTIAL FEED DOG テープアンナイクミ 1 12 MAQ-056010A0 TAPE GUIDE ロツカクナット 9/64-40 (1) 13 NS-6090310-SP NUT 9/64-40 マルヒラネシ 9/64-40 L=8.5 (1) 14 WP-0371018-SD WASHER マルヒラネシ 9/64-40 L=8.5 (1) 15 SS-7090910-SP SCREW 9/64-40 L= 8.5 (1) Note (注記) 001 ... For BD6-340 002 ... For BD6-347 *All parts other than the above are same as those used in model MO-2314-BD4-300. 上記以外の部品は、MO-2314-BD4-300 と同じです。 11 From the library of: Superior Sewing Machine & Supply LLC Jinte.in

Page 16 — 29. MO-2304B-0D4-306 30. MO-2304E-0D4-20B/F

29. MO-2304B-0D4-306 1 3 5 2 4 30. MO-2304E-0D4-20B/F 6 7 8 9 10 11 12 Ref. No. Note 注記 Part No. 品番 Description E. C. 変更年月 Amt. Req. 数量 1 R4200-H00-00E THROAT PLATE ハリイタ 1 2 MC-0336007-50 NEEDLE B-27 NM75 ハリ B-27 75 1 3 115-97101 MAIN FEED DOG シュオクリバ 1 4 118-86207 DIFFERENTIAL FEED DOG フクオクリバ 1 5 115-50159 TENSION CONTROLLER ASM., ORANGE イトチョウバリクミ (ムラサキ) 1 30. MO-2304E-0D4-20B/F 6 118-78568 PRESSER FOOT ASM. オサエツメ (ユビカーラートツキ) 1 7 B1507-805-000-A PRESSER FOOT オサエ (1) 8 118-74807 STITCH TONGUE イトスペリダイ (1) 9 118-47506 KNIFE ヒラメス 1 10 MDC-27080900 NEEDLE DCX27 #9 ハリ DCX27 #9 1 11 118-89003 CHIP GUARD COVER スソカバー 1 12 MAT-80101LAB BLIND HEMMING ATTACHMENT ASM. (B) スソツキアタッチメントクミ 1 *All parts other than the above are same as those used in model MO-2304-0D4-300. 上記以外の部品は、MO-2304-0D4-300 と同じです。 -12- From the library of: Superior Sewing Machine & Supply LLC Jinte x.in

Page 17

31. MO-2314E-BD4-306 MO-2314E-BD6-306 1 3 2 4 5 32. MO-2314-BD4-307/D025 6 7 9 10 8 11 12 13 14 Ref. No. Part No. No. 注記品番 Description E. C. 変更年月 Amt. Req. 数量 1 #01 118-98806 DIFFERENTIAL FEED DOG フクオクリバ (リツプツキ) 1 2 #02 118-96900 DIFFERENTIAL FEED DOG フクオクリバ (リツプツキ) 1 3 #02 118-82404 MAIN FEED DOG シュオクリバ 1 4 #01 R4205-HOD-EOB THROAT PLATE ハリイタ (リツプツキ) 1 5 #02 R4305-HOD-EOC THROAT PLATE ハリイタ (リツプツキ) 1 32. MO-2314-BD4-307/D025 6 MAD-02501DA0 REGULATOR HOOK ASM. チョウセツメクミ 1 7 MAD-02501000 REGULATOR HOOK チョウセツメ (1) 8 SS-3090420-SP SCREW 9/64-40 L=3.5 トラスネシ 9/64-40 L=3.5 (2) 9 MAD-02502000 REGULATOR HOOK SET BASE チョウセツメメトリツケダイ (1) 10 SD-0640211-SP SCREW D= 6.35 H= 2.1 ダンネジ D=6.35 H=2.1 (2) 11 R4205-HOD-EOA THROAT PLATE (EOB) ハリイタ (E-08) 1 12 118-93302 UPPER LOOPER GUIDE SUPPORT ウワールパーガイドササエ B 1 13 SS-7151310-TP SCREW ウワールパーガイドフタ B 2 14 B2515-704-009 UPPER LOOPER GUIDE COVER ウワールパーガイドフタ B 1 - 13 - From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 18 — NUMERICAL INDEX OF PARTS

NUMERICAL INDEX OF PARTS Part No. Page Ref. No. Part No. Page Ref. No. Part No. Page Ref. No. B1507-805-000-A 2 22 R4305-HOD-E00 4 13 118-70458 8 18 118-88906 1 20 B1507-805-000-A 2 22 R4305-H05-E00 11 9 118-70557 9 18 118-88906 1 20 B1507-814-808 11 4 R4305-HOD-E00 3 11 118-72207 7 3 118-88906 2 28 B1507-816-808 5 6 R4305-HOD-B00 5 11 118-72603 5 13 118-89003 2 28 B1507-816-BOC 5 6 R4505-HOD-DOO 5 11 118-72603 8 2 118-89003 12 11 B1507-816-DOZ 5 20 R4508-HOF-DOO 10 10 118-73007 2 2 118-92205 10 3 B1507-816-FOD 7 5 R4508-HOF-BOO 5 10 118-73007 2 10 118-92205 10 8 B1507-816-FOZ 3 9 R4603-HOD-FOO 6 7 118-73205 9 10 118-92304 10 10 B1508-816-COA 5 21 R4612-HOF-GOO 3 17 118-74609 1 11 118-92304 10 14 B1508-816-DOZ 8 11 R4617-HOH-BOO 9 17 118-74708 1 17 118-92403 10 5 B1509-814-BOB 1 17 118-74708 4 5 118-92403 10 10 B1509-814-BOB 11 2 118-74807 2 23 118-92403 10 16 B1511-814-000 2 3 SD-0400261-TP 5 18 118-74807 12 8 118-93302 4 1 B1515-816-DO8 7 2 SD-0400261-SP 8 7 118-75101 5 5 118-93302 4 6 B1530-816-DO8 5 17 SD-0400261-SP 9 7 118-75507 7 4 118-93302 4 10 B1530-816-DO8 8 6 SD-0640211-SP 10 6 118-75606 9 11 118-93302 4 16 B1531-814-000 11 3 SD-0640211-SP 10 11 118-76059 1 4 118-93302 11 6 B1545-816-F00 5 16 SD-0640211-SP 13 10 118-76067 1 6 118-93609 2 20 B1546-816-F00 8 5 SS-5090420-SP 10 4 118-76257 1 16 118-93609 3 20 B1546-816-F00 9 5 SS-5090420-SP 10 15 118-76265 1 18 118-93609 6 13 B1546-816-F00 5 19 SS-5090420-SP 13 8 118-76356 2 1 118-93609 7 18 B1546-816-F00 8 3 SS-6080340-SP 5 14 118-76364 2 4 118-93609 8 23 B1546-816-F00 7 8 SS-6080340-SP 8 3 118-77156 3 12 118-93609 9 21 B1549-816-F00 5 15 SS-6080340-SP 9 3 118-77164 3 6 118-98806 13 1 B1549-816-F00 8 4 SS-6090630-SP 1 3 118-77354 5 4 119-80505 3 13 B1559-816-000 5 22 SS-6090630-SP 5 1 118-77362 5 7 119-80604 3 12 B1559-816-000 8 10 SS-7110710-SL 11 15 118-77750 7 1 119-80302 5 6 B1559-816-000 9 10 SS-7110710-SL 1 1 118-77768 7 6 119-80901 6 6 B2515-704-009 4 3 SS-7151310-TP 5 3 118-78550 2 21 B2515-704-009 4 8 SS-7151310-TP 4 2 118-78568 12 24 B2515-704-009 4 12 SS-7151310-TP 4 7 118-78568 2 6 B2515-704-009 4 18 SS-7151310-TP 11 7 118-79251 11 1 B2515-704-009 11 8 SS-7151310-TP 13 7 118-79269 11 5 B2515-704-009 13 14 SS-7151310-TP 13 13 118-79756 5 12 B3101-704-080 7 7 SS-9151210-TP 2 19 118-79764 5 23 MAD-025010A0 13 6 SS-9151210-TP 6 12 118-80556 3 12 MAD-02501000 13 7 SS-9151210-TP 17 17 118-80952 9 12 MAD-02502000 13 9 SS-9151210-TP 3 22 118-80960 9 12 MAQ-056010A0 11 12 WP-0371015-SD 11 14 118-81455 1 10 MAT-80101LAB 2 27 118-81471 1 12 MAT-80101LAB 12 12 118-81554 3 16 MDC-0336007-50 12 2 118-81554 4 16 MDC-10080300 1 9 115-50159 12 5 118-82206 2 5 MDC-27080900 1 15 117-90508 12 3 118-82206 2 15 MDC-27080900 3 15 117-90607 3 4 118-82404 3 22 MDC-27080900 5 25 117-90706 3 5 118-82404 4 14 MDC-27080900 8 19 117-92900 1 12 118-82404 11 10 MDC-27080900 12 19 118-31559 1 21 118-82503 13 13 MDC-27080903 12 10 118-31559 6 11 118-82602 3 10 MDC-27081400 2 17 118-31559 7 16 118-82909 6 5 MDC-27081400 3 9 118-31559 8 21 118-83006 7 14 MDC-27081500 6 4 118-45807 9 26 118-33303 2 15 NS-6090313-SP 7 9 118-45807 2 2 118-84004 8 13 118-45807 16 118-84004 9 13 118-45807 9 14 118-85100 2 6 118-45906 12 4 118-85100 2 16 118-47407 4 15 118-85308 6 6 R4200-HOA-COO 1 7 118-47407 11 11 118-85407 7 13 R4200-HOD-DOB 12 1 118-47407 13 11 118-85605 2 16 R4200-HOE-DOO 1 19 118-47506 2 8 118-86009 3 14 R4205-HOD-EOA 10 7 118-67207 10 2 118-86009 9 14 R4205-HOD-EOA 13 11 118-67405 13 18 118-86207 12 4 R4205-HOD-EOB 13 4 118-67405 3 5 118-86504 3 23 R4205-HOE-EOC 3 19 118-67405 10 13 118-86504 4 15 R4206-HOD-E00 4 9 118-67504 7 10 118-86504 11 11 R4300-HOD-E00 3 1 118-69757 8 8 118-87007 1 8 R4300-HOF-E00 2 14 118-69955 3 14 118-87205 3 14 R4305-HOD-EOC 13 5 118-70151 7 19 118-88005 3 7 R4305-HOD-E00 3 21 118-70458 8 18 118-88104 6 8 118-88104 7 19 118-88609 1 19 118-88609 5 2 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 19

From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 20

JUKI TOKYO JUKI INDUSTRIAL CO., LTD. Address : 23-3, Kabuki-cho 1-chome, Shinjuku-ku, Tokyo 160, Japan Cable : JUKI TOKYO Telex : J22967, 232-2301 Phone : 03 (205) 1188, 1189, 1190 From the library of: Superior Sewing Machine & Supply LLC jintex.in 東京重機工業株式会社〒182 本社・営業本部東京都調布市国領町8の2の1 TEL (480) 1113(代) Printed in Japan(T)

Page 1 — PARTS BOOK

Page 3

Page 4 — CONTENTS

Page 5

Page 6

Page 7

Page 8

Page 9

Page 10

Page 11 — 22. MO-2316-FF6-500

Page 12 — 23. MO-2316-FF6-100

Page 13 — 24. MO-2316-RH6-100

Page 14

Page 15 — 28. MO-2314-BD6-340, MO-2314-BD6-347

Page 16 — 29. MO-2304B-0D4-306 30. MO-2304E-0D4-20B/F

Page 17

Page 18 — NUMERICAL INDEX OF PARTS

Part Books

Search
