Kansai Special DFB-1404 / DFB-1412 Parts Book (PDF)
Text index — Kansai Special DFB-1404 / DFB-1412
Page 3 — 1. フレーム関係(1) FRAME ASSEMBLY (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 01-01 | 02-118 | WASHER | 1 |
| 01-02 | 02-119 | WASHER | 1 |
| 01-03 | 21-266 | NEEDLE BAR COVER | 1 |
| 01-04 | 21-267 | COVER | 1 |
| 01-05 | 21-273 | EYE GUARD | 1 |
| 01-06 | 21-274 | EYE GUARD | 1 |
| 01-07 | 21-275 | BRACKET | 1 |
| 01-08 | 21-276 | BRACKET | 1 |
| 01-09 | 21-934 | COVER | 1 |
| 01-10 | 21-935 | COVER | 1 |
| 01-11 | 21-972 | PULLEY COVER | 1 |
| 01-12 | 21-975 | COVER | 1 |
| 01-13 | 23-157 | GASKET | 1 |
| 01-14 | 23-206 | GASKET | 1 |
| 01-15 | 23-263 | GASKET C | 1 |
| 01-16 | 23-285 | O RING | 1 |
| 01-17 | 23-427 | PLUG | 1 |
| 01-18 | 24-052 | BRAND NAME PLATE | 3 |
| 01-19 | 27-017 | TOP COVER | 1 |
| 01-20 | 27-018 | HEAD COVER | 1 |
| 01-21 | 39-108 | COVER | 1 |
| 01-22 | 39-137 | PIPE SUPPORT | 1 |
| 01-23 | 39-234 | OIL POT | 1 |
| 01-24 | 75-224 | WASHER | 2 |
| 01-25 | 75-455 | WASHER | 2 |
| 01-26 | 84-396 | SCREW | 1 |
| 01-27 | 87-010 | SCREW | 3 |
| 01-28 | 87-092 | BOLT | 2 |
| 01-29 | 87-099 | SCREW | 2 |
| 01-30 | 87-123 | BOLT | 1 |
| 01-31 | 87-129 | BOLT | 9 |
| 01-32 | 87-177 | BOLT | 5 |
| 01-33 | 87-264 | SCREW | 1 |
| 01-34 | 87-409 | SCREW | 1 |
| 01-0102-118 | WASHER | 1 | |
| 01-0202-119 | WASHER | 1 | |
| 01-0321-266 | NEEDLE BAR COVER | 1 | |
| 01-0421-267 | COVER | 1 | |
| 01-0521-273 | COVER | 1 | |
| 01-0621-274 | EYE GUARD | 1 | |
| 01-0721-275 | EYE GUARD | 1 | |
| 01-0821-276 | RACKET | 1 | |
| 01-0921-934 | RACKET | 1 | |
| 01-1021-935 | COVER | 1 | |
| 01-1121-972 | COVER | 1 | |
| 01-1221-975 | COVER | 1 | |
| 01-1323-157 | COVER | 1 | |
| 01-1423-206 | GASKET | 1 | |
| 01-1523-263 | GASKET | 1 | |
| 01-1623-285 | GASKET C | 1 | |
| 01-1723-427 | O-RING | 1 | |
| 01-1824-052 | GASKET | 1 | |
| 01-1927-017 | GRAND NAME PLATE | 3 | |
| 01-2027-018 | TOP COVER | 1 | |
| 01-2139-108 | HEAD COVER | 1 | |
| 01-2239-137 | COVER | 1 | |
| 01-2339-234 | PIPE SUPPORT | 1 | |
| 01-2475-224 | OIL POT | 1 | |
| 01-2575-455 | WASHER | 2 | |
| 01-2684-396 | WASHER | 2 | |
| 01-2787-010 | SCREW | 1 | |
| 01-2887-092 | BOLT | 3 | |
| 01-2987-099 | BOLT | 2 | |
| 01-3087-123 | SCREW | 1 | |
| 01-3187-129 | BOLT | 9 | |
| 01-3287-177 | BOLT | 5 | |
| 01-3387-264 | BOLT | 1 | |
| 01-3487-409 | SCREW | 1 |
Page 4 — 2. フレーム関係(2) FRAME ASSEMBLY (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 02-01 | 02-112 | WASHER | 2 |
| 02-01-112 | |||
| 02-02-14-157 | |||
| 02-03-14-158 | |||
| 02-04-21-137 | |||
| 02-05-21-897 | |||
| 02-06-23-137 | |||
| 02-07-23-229 | |||
| 02-08-24-053 | |||
| 02-09-26-712 | |||
| 02-10-27-042 | |||
| 02-11-27-043 | |||
| 02-12-27-044 | |||
| 02-13-27-045 | |||
| 02-14-27-046 | |||
| 02-15-27-047 | |||
| 02-16-31-438 | |||
| 02-17-71-255 | |||
| 02-18-75-455 | |||
| 02-19-79-521 | 板バネ (A) | ||
| 02-20-79-522 | |||
| 02-21-84-364 | |||
| 02-22-84-761 | |||
| 02-23-84-763 | |||
| 02-24-84-861 | |||
| 02-25-84-862 | |||
| 02-26-85-181 | |||
| 02-27-87-092 | |||
| 02-28-87-098 | |||
| 02-29-87-113 | |||
| 02-30-87-278 | |||
| 02-31-05-061 | |||
| 02-32-87-280 | |||
| 02-33-87-285 | |||
| 02-34-88-146 | |||
| 02-35-88-166 | |||
| 02-36-93-701 | |||
| 02-37-20-0450 | |||
| 02-38-20-0450 | |||
| 02-39-20-0460 | |||
| 02-40-20-0470 | |||
| 02-41-23-512 | |||
| 02-42-75-468 | |||
| 02-43-79-552 | |||
| 02-44-87-287 | |||
| 02-46-87-310 | |||
| 02-47-87-316 | |||
| 02-49-87-177 |
Page 5 — 3. 糸調子機構 (1404) THREAD TENSION MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 03-0123-324 | |||
| 03-0241-101 | |||
| 03-0341-105 | |||
| 03-0441-107 | |||
| 03-0541-110 | |||
| 03-0641-113 | |||
| 03-0741-120 | |||
| 03-0841-123 | |||
| 03-0941-136 | |||
| 03-1041-510 | |||
| 03-1141-701 | |||
| 03-1241-702 | |||
| 03-1345-123 | |||
| 03-1445-133 | |||
| 03-1545-429 | |||
| 03-1645-430 | |||
| 03-1745-431 | |||
| 03-1845-438 | |||
| 03-1947-117 | |||
| 03-2047-413 | |||
| 03-2175-455 | |||
| 03-2284-361 | |||
| 03-2386-411 | |||
| 03-2487-113 | |||
| 03-2587-177 | |||
| 03-2687-293 | |||
| 03-2787-272 | |||
| 03-2840-7370 | |||
| 03-2940-7380 |
Page 6 — 4. 糸調子機構 (1412) THREAD TENSION MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 04-01 | 45-107 | THREAD EYELET | 2 |
| 04-0145-107 | |||
| 04-0245-127 | |||
| 04-0345-432 | |||
| 04-0445-433 | |||
| 04-0545-434 | |||
| 04-0645-435 | |||
| 04-0745-437 | |||
| 04-0847-120 | |||
| 04-0947-408 | |||
| 04-1047-409 | |||
| 04-1147-413 | |||
| 04-1275-455 | |||
| 04-1387-272 | |||
| 04-1484-361 | |||
| 04-1587-113 | |||
| 04-1687-177 | |||
| 04-1787-293 | |||
| 04-1884-374 |
Page 7 — 5. ブッシュ機構 BUSHING
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 05-01 | 04-109 | SUPPORT BRACKET | 1 |
| 05-0104-109 | SUPPORT BRACKET | 1 | |
| 05-004-110 | RETAINER HOLDER BRACKET | 1 | |
| 05-0423-296 | PLUG | 2 | |
| 05-0571-255 | PIN | 2 | |
| 05-0671-262 | PIN | 2 | |
| 05-0775-436 | WASHER | 4 | |
| 05-0881-109 | BUSHING | 1 | |
| 05-0981-133 | BUSHING | 1 | |
| 05-1081-153 | BUSHING | 1 | |
| 05-11 | BUSHING | 1 | |
| 05-1281-180 | BUSHING | 2 | |
| 05-1381-181 | BUSHING | 1 | |
| 05-1481-182 | BUSHING | 1 | |
| 05-1581-190 | BUSHING | 1 | |
| 05-1681-224 | BUSHING | 1 | |
| 05-1781-236 | BUSHING | 1 | |
| 05-1881-237 | BUSHING | 1 | |
| 05-1981-256 | BUSHING | 1 | |
| 05-2081-723 | BUSHING | 1 | |
| 05-2181-717 | BUSHING | 1 | |
| 05-2281-718 | BUSHING | 1 | |
| 05-2381-720 | BUSHING | 1 | |
| 05-2481-735 | BUSHING | 1 | |
| 05-2581-753 | BUSHING | 1 | |
| 05-2687-214 | BOLT | 2 | |
| 05-2787-245 | BOLT | 2 | |
| 05-2887-661 | BOLT | 2 | |
| 05-2994-214 | OIL SEAL | 1~2 | |
| 05-3081-739 | BUSHING | 1 |
Page 8 — 6. 針棒, 弓機構 NEEDLE BAR & LEVER MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 06-01 | 11-400 | NEEDLE BAR | 1 |
| 06-02 | 23-195 | O-RING | 1 |
| 06-03 | 23-341 | FELT | 2 |
| 06-04 | 23-383 | FELT | 1 |
| 06-05 | 61-711 | CONNECTING ROD BALL | 1 |
| 06-06 | 63-713 | BALL JOINT | 1 |
| 06-07 | 65-302 | CONNECTING BAR | 1 |
| 06-08 | 66-111 | CONNECTING LINK | 1 |
| 06-09 | 69-105 | NEEDLE LEVER E | 1 |
| 06-10 | 69-117 | NEEDLE BAR GUIDE | 1 |
| 06-11 | 69-120 | GUIDE | 1 |
| 06-12 | 71-432 | FEED ROCKER LINK PIN | 2 |
| 06-13 | 71-933 | NEEDL LEVER STUD | 1 |
| 06-14 | 73-121 | NEEDLE BAR CLAMP | 1 |
| 06-15 | 75-332 | WASHER | 1 |
| 06-17 | 81-113 | BUSHING | 1 |
| 06-18 | 81-412 | BUSHING | 1 |
| 06-19 | 84-365 | SCREW | 1 |
| 06-20 | 84-366 | SCREW | 1 |
| 06-21 | 84-567 | SCREW | 3 |
| 06-22 | 84-574 | SCREW | 2 |
| 06-23 | 85-181 | SCREW | 1 |
| 06-24 | 86-741 | NUT | 1 |
| 06-25 | 86-742 | NUT | 1 |
| 06-26 | 87-113 | BOLT | 1 |
| 06-27 | 87-172 | SCREW | 1 |
| 06-28 | 87-225 | BOLT | 1 |
| 06-29 | 87-242 | SCREW | 2 |
| 06-30 | 60-3700 | CONNECTING ROD ASS'Y | 1 |
| 06-31 | 69-1050-2 | NEEDLE LEVER (WITH BUSHING) | 1 |
| 06-011-400 | |||
| 06-0223-195 | O-リング | ||
| 06-0323-341 | |||
| 06-0423-383 | |||
| 06-0561-711 | |||
| 06-0663-713 | |||
| 06-0765-302 | |||
| 06-0866-111 | |||
| 06-0969-105 | 弓 E | ||
| 06-1069-117 | |||
| 06-1169-120 | |||
| 06-1271-432 | |||
| 06-1371-933 | 弓ピン C | ||
| 06-1473-121 | |||
| 06-1575-332 | |||
| 06-1781-113 | |||
| 06-1881-412 | |||
| 06-1984-365 | |||
| 06-2084-366 | |||
| 06-2184-567 | |||
| 06-2284-574 | |||
| 06-2385-181 | |||
| 06-2486-741 | |||
| 06-2586-742 | |||
| 06-2687-113 | |||
| 06-2787-172 | |||
| 06-2887-225 | |||
| 06-2987-242 | |||
| 06-3060-3700 | |||
| 06-3169-1050-2 |
Page 9 — CRANKSHAFT MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 07-0123-197 | O-リング | ||
| 07-0223-554 | |||
| 07-0323-384 | |||
| 07-0431-155 | |||
| 07-0551-017 | |||
| 07-0651-031 | |||
| 07-0760-3460 | DFB寄生エキセントリックロッドセット | ||
| 07-0861-532 | |||
| 07-0961-723 | |||
| 07-1063-517 | |||
| 07-1163-621 | |||
| 07-1269-216 | |||
| 07-1369-305 | |||
| 07-1471-612 | |||
| 07-1571-747 | 前下シャフト 4G | ||
| 07-1671-842 | |||
| 07-1771-855 | |||
| 07-1875-101 | |||
| 07-1975-107 | |||
| 07-2075-112 | |||
| 07-2175-327 | |||
| 07-2275-329 | |||
| 07-2375-332 | |||
| 07-2475-452 | |||
| 07-2684-383 | |||
| 07-2784-387 | |||
| 07-2884-568 | |||
| 07-2984-635 | |||
| 07-3084-661 | |||
| 07-3185-212 | |||
| 07-3287-017 | |||
| 07-3387-172 | |||
| 07-3487-177 | |||
| 07-3587-242 | |||
| 07-3687-254 | |||
| 07-3793-264 | |||
| 07-3870-0350 | |||
| 07-3970-0240 | |||
| 07-4323-663 |
Page 10 — 8. 送り機構 FEED MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 08-01 | 23-341 | FELT | 2 |
| 08-02 | 55-041 | SINGLE FEED ROCKER ARM | 1 |
| 08-03 | 55-141 | FEED ROCKER | 1 |
| 08-04 | 55-146 | FEED DOG HOLDER | 1 |
| 08-05 | 61-312 | LOOPER AVOID ECCENTRIC | 1 |
| 08-06 | 61-322 | FEED ECCENTRIC | 1 |
| 08-07 | 63-232 | ECCENTRIC LINK | 1 |
| 08-08 | 63-353 | FEED ROCKER LINK | 1 |
| 08-09 | 67-311 | FEED ROCKER ARM | 1 |
| 08-10 | 71-217 | PIN | 2 |
| 08-11 | 71-351 | SHAFT | 1 |
| 08-12 | 71-431 | PIN | 1 |
| 08-13 | 71-432 | FEED ROCKER LINK PIN | 1 |
| 08-14 | 71-531 | SHAFT | 1 |
| 08-15 | 71-642 | FEED ROCKER ARM SHAFT | 1 |
| 08-16 | 75-139 | COLLAR | 1 |
| 08-17 | 75-235 | ROLLER | 1 |
| 08-18 | 75-455 | WASHER | 1 |
| 08-19 | 75-675 | WASHER | 2 |
| 08-20 | 84-314 | SCREW | 1 |
| 08-21 | 84-364 | SCREW | 2 |
| 08-22 | 84-366 | SCREW | 3 |
| 08-23 | 84-569 | SCREW | 2 |
| 08-24 | 84-588 | SCREW | 1 |
| 08-26 | 87-181 | SCREW | 2 |
| 08-27 | 87-245 | BOLT | 1 |
| 08-28 | 87-252 | BOLT | 1 |
| 08-29 | 87-254 | SCREW | 3 |
| 08-30 | 91-270 | BEARING | 1 |
| 08-31 | 91-406 | BEARING | 1 |
| 08-32 | 93-261 | C-RING | 1 |
| 08-33 | 93-406 | C-RING | 1 |
| 08-34 | 60-0800 | ECCENTRIC LINK ASS'Y | 1 |
| 08-35 | 60-0900 | ECCENTRIC LINK ASS'Y | 1 |
| 08-36 | 63-3530-2 | FEED ROCKER LINK ASS'Y | 1 |
| 08-0123-341 | |||
| 08-0255-041 | |||
| 08-0355-141 | |||
| 08-0455-146 | |||
| 08-0561-312 | |||
| 08-0661-322 | |||
| 08-0763-232 | |||
| 08-0863-353 | 送り連結レバー -A | ||
| 08-0967-311 | 送り連結レバー -A | ||
| 08-1071-217 | |||
| 08-1171-351 | |||
| 08-1271-431 | |||
| 08-1371-432 | |||
| 08-1471-531 | |||
| 08-1571-642 | |||
| 08-1675-139 | |||
| 08-1775-235 | |||
| 08-1875-455 | |||
| 08-1975-675 | |||
| 08-2084-314 | |||
| 08-2184-364 | |||
| 08-2284-366 | |||
| 08-2384-569 | |||
| 08-2484-588 | |||
| 08-2687-181 | |||
| 08-2787-245 | |||
| 08-2887-252 | |||
| 08-2987-254 | |||
| 08-3091-270 | |||
| 08-3191-406 | |||
| 08-3293-261 | Cリング | ||
| 08-3393-406 | |||
| 08-3460-0800 | |||
| 08-3560-0900 | |||
| 08-3663-3530-2 |
Page 11 — 9. ルーパ゛-機構 LOOPER MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 09-01 | 04-106 | LOOPER ROCKER | 1 |
| 09-02 | 04-111 | PLATE | 1 |
| 09-04 | 19-408 | LOOPER ROCKER | 1 |
| 09-05 | 21-126 | COVER | 1 |
| 09-06 | 23-341 | FELT | 4 |
| 09-08 | 47-220 | TAKE-UP ROD | 1 |
| 09-09 | 61-241 | LOOPER AVOID ECCENTRIC | 2 |
| 09-10 | 61-244 | LOOPER AVOID ECCENTRIC | 1 |
| 09-11 | 63-241 | ECCENTRIC LINK | 2 |
| 09-12 | 66-116 | RETAINER CONNECTING LINK | 1 |
| 09-13 | 67-141 | LOOPER ROCKER LEVER | 1 |
| 09-14 | 67-147 | TAKE UP DRIVE LEVER B | 1 |
| 09-15 | 67-235 | RETAINER LEVER B | 1 |
| 09-16 | 71-431 | PIN | 4 |
| 09-17 | 87-245 | BOLT | 1 |
| 09-18 | 71-626 | LOOPER ROCKER SHAFT | 1 |
| 09-19 | 71-911 | SHAFT | 1 |
| 09-20 | 71-913 | LOOPER THROW-OUT ACTUATING SHAFT | 1 |
| 09-22 | 73-116 | RETAINER BAR HOLDER | 1 |
| 09-23 | 75-139 | COLLAR | 1 |
| 09-24 | 75-135 | COLLAR | 2 |
| 09-25 | 75-381 | WASHER | 2 |
| 09-26 | 75-527 | SPRING WASHER | 1 |
| 09-27 | 75-675 | WASHER | 3 |
| 09-28 | 79-161 | SPRING | 1 |
| 09-29 | 79-163 | SPRING | 1 |
| 09-30 | 79-164 | SPRING | 1 |
| 09-31 | 81-142 | BUSHING | 1 |
| 09-32 | 81-143 | BUSHING | 1 |
| 09-33 | 84-366 | SCREW | 4 |
| 09-34 | 87-224 | BOLT | 1 |
| 09-35 | 84-814 | SCREW | 1 |
| 09-36 | 87-173 | BOLT | 1 |
| 09-37 | 87-287 | BOLT | 1 |
| 09-38 | 87-181 | SCREW | 4 |
| 09-39 | 87-254 | SCREW | 4 |
| 09-40 | 91-401 | BEARING | 2 |
| 09-41 | 93-211 | E-RING | 1 |
| 09-42 | 93-401 | SNAP RING | 2 |
| 09-43 | 60-1390 | ECCENTRIC LINK ASS'Y | ※ |
| 09-44 | 60-1410 | ECCENTRIC LINK ASS'Y | 1 |
| 09-46 | 10-9030 | LOOPER ROCKER ASS'Y | 1 |
Page 12 — 10. 押え上げ機構 PRESSER FOOT MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 10-01 | 94-231 | OIL SEAL | 1 |
| 10-02 | 71-542 | PRESSER BAR (SMALL) | 1 |
| 10-03 | 75-180 | WASHER | 1 |
| 10-04 | 77-107 | CONNECTING PLATE | 1 |
| 10-05 | 77-109 | LIFTER LEVER SPRING SUPPORTER | 1 |
| 10-06 | 77-116 | LIFTER LEVER CONNECTING BAR | 1 |
| 10-07 | 77-131 | PLATE | 1 |
| 10-08 | 77-163 | BRACKET | 1 |
| 10-09 | 77-164 | SHAFT | 1 |
| 10-10 | 77-165 | PIPE | 1 |
| 10-11 | 77-509 | BRACKET | 1 |
| 10-12 | 77-516 | GUIDE | 1 |
| 10-13 | 77-517 | PRESSER BAR GUIDE | 1 |
| 10-14 | 77-818 | PRESSER FOOT LIFTER LEVER | 1 |
| 10-15 | 79-121 | PRESSER BAR SPRING | 1 |
| 10-16 | 79-222 | LIFTER LEVER SPRING | 1 |
| 10-17 | 79-550 | SPRING | 1 |
| 10-18 | 84-561 | SCREW | 1 |
| 10-19 | 84-562 | SCREW | 1 |
| 10-20 | 84-563 | SCREW | 1 |
| 10-21 | 84-581 | SCREW | 1 |
| 10-22 | 87-252 | BOLT | 2 |
| 10-23 | 84-813 | SCREW | 1 |
| 10-24 | 85-201 | SCREW | 1 |
| 10-25 | 86-411 | NUT | 1 |
| 10-26 | 87-004 | SCREW | 1 |
| 10-27 | 87-112 | BOLT | 2 |
| 10-28 | 87-177 | BOLT | 2 |
| 10-29 | 84-551 | SCREW | 1 |
| 10-30 | 88-003 | NUT | 1 |
| 10-31 | 93-611 | PIN | 2 |
| 84-564 |
Page 13 — 11. 給油機構 LUBRICATION MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 17-8010-G | |||
| 23-120 | |||
| 23-160 | |||
| 23-304 | |||
| 23-363 | |||
| 23-451 | |||
| 35-257 | パイプ A | ||
| 31-364 | |||
| 30-0120 | |||
| 31-151 | |||
| 31-152 | |||
| 31-153 | |||
| 31-154 | |||
| 31-156 | |||
| 31-157 | |||
| 31-270 | |||
| 31-271 | |||
| 31-314 | |||
| 35-528 | |||
| 31-702 | |||
| 31-705 | |||
| 31-707 | |||
| 35-122 | |||
| 35-361 | |||
| 35-362 | |||
| 35-413 | |||
| 75-536 | |||
| 39-133 | パイプ サポート C | ||
| 39-216 | |||
| 75-185 | |||
| 30-0121 | |||
| 75-452 | |||
| 87-092 | |||
| 87-252 | |||
| 87-173 | |||
| 23-514 | |||
| 87-123 | |||
| 87-129 | |||
| 87-140 | |||
| 87-183 | |||
| 84-363 | |||
| 87-254 | |||
| 87-311 | |||
| 88-137 | |||
| 35-246 | |||
| 35-317 | |||
| 35-318 | |||
| 35-322 | |||
| 35-315 | |||
| 35-343 | |||
| 31-2700-2 |
Page 14 — 12. 後プーラー機構 REAR PULLER MECHANISM (1404)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 12-01 | 01-115 | SLEEVE | 2 |
| 12-02 | 02-278 | COLLAR | 1 |
| 12-03 | 02-117 | PLATE | 1 |
| 12-04 | 02-123 | CLUTCH HOUSING | 1 |
| 12-05 | 02-136 | REAR PULLER(SMOOTH) | 1 |
| 12-06 | 02-151 | REAR PULLER HOLDER | 1 |
| 12-07 | 02-166 | GUIDE BRACKET | 1 |
| 12-08 | 02-486 | UPPER REAR PULLER28 | 1 |
| 12-09 | 02-184 | REAR PULLER(KNURLING) | 1 |
| 12-10 | 02-197 | LOWER REAR PULLER(SMOOTH) | 1 |
| 12-11 | 02-487 | LOWER PULLER GEAR(23 TEETH) | 1 |
| 12-12 | 02-263 | CONNECTING PLATE | 1 |
| 12-13 | 87-214 | BOLT | 1 |
| 12-14 | 71-444 | SHAFT | 1 |
| 12-15 | 71-439 | REAR PULLER SHAFT(S) | 1 |
| 12-16 | 71-921 | PULLER GUIDE PIN | 1 |
| 12-17 | 87-278 | SCREW | 2 |
| 12-18 | 75-451 | WASHER | 1 |
| 12-19 | 75-519 | WASHER | 1 |
| 12-20 | 79-551 | PULLER PLATE SPRING | 1 |
| 12-21 | 81-321 | BUSHING | 1 |
| 12-22 | 81-322 | BUSHING | 1 |
| 12-23 | 81-323 | BUSHING | 1 |
| 12-24 | 84-162 | SCREW | 6 |
| 12-25 | 84-462 | SCREW | 3 |
| 12-26 | 84-573 | SCREW | 1 |
| 12-27 | 87-113 | BOLT | 2 |
| 12-28 | 87-129 | BOLT | 1 |
| 12-29 | 87-181 | SCREW | 1 |
| 12-30 | 87-225 | BOLT | 1 |
| 12-31 | 88-179 | NUT | 2 |
| 12-32 | 91-407 | BEARING | 2 |
| 12-33 | 93-221 | E-RING | 1 |
| 12-34 | 00-2281 | 28TEETH PULLER ASS'Y | 1 |
| 12-35 | 00-2001 | SMOOTH PULLER ASS'Y | 1 |
| 12-36 | 00-2011 | STEEL PULLER ASS'Y | 1 |
| 71-214 |
Page 15 — 13. 後プーラー機構 REAR PULLER MECHANISM (1406~1412)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 01-115 | |||
| 02-278 | カラーB | ||
| 02-117 | |||
| 02-124 | |||
| 02-138 | |||
| 02-263 | |||
| 02-456 | |||
| 02-459 | |||
| 87-214 | |||
| 02-492 | |||
| 02-476 | |||
| 02-493 | |||
| 02-480 | |||
| 71-445 | |||
| 71-440 | |||
| 71-921 | |||
| 87-278 | |||
| 75-451 | |||
| 75-519 | |||
| 79-551 | |||
| 81-321 | |||
| 81-322 | |||
| 81-323 | |||
| 84-162 | |||
| 84-462 | |||
| 84-573 | |||
| 87-113 | |||
| 87-129 | |||
| 87-181 | |||
| 87-225 | |||
| 88-179 | |||
| 91-407 | |||
| 93-221 | |||
| 00-2401 | |||
| 00-2422 | |||
| 00-2423 | |||
| 02-494 | |||
| 02-495 |
Page 16 — 14. 後プーラー機構 REAR PULLER MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 14-01 | 02-112 | WASHER | 1 |
| 14-0102-112 | |||
| 14-0202-204 | |||
| 14-0302-205 | |||
| 14-0402-219 | |||
| 14-0502-408 | |||
| 14-0661-208 | |||
| 14-0761-714 | |||
| 14-0861-810 | |||
| 14-0963-208 | |||
| 14-1063-711 | |||
| 14-1163-810 | |||
| 14-1265-302 | |||
| 14-1367-171 | プーラー連結レバー(FRONT) | ||
| 14-1467-172 | プーラー連結レバー(REAR) | ||
| 14-1571-450 | |||
| 14-1671-691 | |||
| 14-1771-726 | |||
| 14-1875-112 | |||
| 14-1975-211 | |||
| 14-2075-247 | |||
| 14-2175-332 | |||
| 14-2275-458 | |||
| 14-2375-491 | |||
| 14-2475-493 | |||
| 14-2575-515 | |||
| 14-2675-520 | |||
| 14-2775-552 | |||
| 14-2877-419 | |||
| 14-2977-420 | |||
| 14-3077-425 | |||
| 14-3179-425 | |||
| 14-3284-567 | |||
| 14-3384-581 | |||
| 14-3484-582 | |||
| 14-3584-635 | |||
| 14-3685-671 | |||
| 14-3786-411 | |||
| 14-3886-501 | |||
| 14-3986-741 | |||
| 14-4086-742 | |||
| 14-4187-171 | |||
| 14-4287-172 | |||
| 14-4387-173 | |||
| 14-4487-214 | |||
| 14-4587-225 | |||
| 14-4787-254 | |||
| 14-4887-285 | |||
| 14-4987-287 | |||
| 14-5087-291 | |||
| 14-5187-754 | |||
| 14-5288-146 | |||
| 14-5388-157 | |||
| 14-5493-203 | E型止め輪 | ||
| 14-5593-205 | E-リング | ||
| 14-5693-222 | Eリング | ||
| 14-5793-258 |
Page 17 — 15. 前プーラー機構 METERING DEVICE MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 15-01 | 00-1401 | METERING DEVICE ASS'Y | 1 |
| 15-02 | 01-102 | SLEEVE | 1 |
| 15-03 | 01-103 | SLEEVE | 1 |
| 15-04 | 01-111 | BRACKET | 1 |
| 15-05 | 01-116 | PLATE | 1 |
| 15-06 | 01-132 | PULLER | 1 |
| 15-07 | 01-134 | LOWER ROLLER | 1 |
| 15-08 | 01-136 | ROLLER HOLDER | 2 |
| 15-09 | 01-138 | PIVOT SHAFT HOLDER | 2 |
| 15-10 | 01-141 | RUBBER TIGHTENER | 1 |
| 15-11 | 01-143 | ROLLER CONTROLER | 1 |
| 15-12 | 01-145 | LEVER | 1 |
| 15-13 | 01-146 | COVER | 1 |
| 15-14 | 01-147 | PIN | 1 |
| 15-15 | 01-152 | GUIDE | 1 |
| 15-16 | 23-341 | FELT | 1 |
| 15-17 | 60-8271 | CONNECTING ROD ASS'Y | 1 |
| 15-18 | 61-821 | CONNECTING ROD BALL | 1 |
| 15-19 | 63-812 | BALL JOINT | 1 |
| 15-20 | 65-334 | PULLER CONNECTING BAR | 1 |
| 15-21 | 66-131 | CONNECTING LINK | 1 |
| 15-22 | 67-180 | PULLER CONNECTING LEVER | 1 |
| 15-23 | 71-227 | PIN | 1 |
| 15-24 | 71-350 | SHAFT | 1 |
| 15-25 | 71-361 | PIVOT SHAFT (LARGE) | 2 |
| 15-26 | 71-362 | PIVOT SHAFT (SMALL) | 1 |
| 15-27 | 71-432 | FEED ROCKER LINK PIN | 1 |
| 15-28 | 75-381 | WASHER | 1 |
| 15-29 | 75-446 | WASHER | 1 |
| 15-30 | 75-451 | WASHER | 2 |
| 15-31 | 75-468 | WASHER | 2 |
| 15-32 | 75-552 | WASHER | 2 |
| 15-33 | 79-171 | SPRING | 1 |
| 15-34 | 81-125 | BUSHING | 2 |
| 15-35 | 84-162 | SCREW | 3 |
| 15-36 | 84-314 | SCREW | 1 |
| 15-37 | 84-635 | SCREW | 2 |
| 15-38 | 84-813 | SCREW | 2 |
| 15-39 | 86-412 | NUT | 1 |
| 15-40 | 86-501 | NUT | 1 |
| 15-41 | 86-701 | NUT | 1 |
| 15-42 | 87-092 | BOLT | 2 |
| 15-43 | 87-129 | BOLT | 2 |
| 15-44 | 87-177 | BOLT | 2 |
| 15-45 | 87-181 | SCREW | 6 |
| 15-46 | 87-253 | SCREW | 1 |
| 15-47 | 87-254 | SCREW | 1 |
| 15-48 | 87-255 | BOLT | 1 |
| 15-49 | 87-268 | SCREW | 1 |
| 15-50 | 87-456 | SCREW | 1 |
| 15-51 | 88-456 | NUT | 1 |
| 15-52 | 91-405 | BEARING | 2 |
| 15-53 | 93-200 | E-RING | 1 |
| 15-01 00-1401 | PMd装置(組) | ||
| 15-02 01-102 | |||
| 15-03 01-103 | |||
| 15-04 01-111 | |||
| 15-05 01-116 | |||
| 15-06 01-132 | |||
| 15-07 01-134 | |||
| 15-08 01-136 | |||
| 15-09 01-138 | |||
| 15-10 01-141 | |||
| 15-11 01-143 | |||
| 15-12 01-145 | |||
| 15-13 01-146 | |||
| 15-14 01-147 | |||
| 15-15 01-152 | |||
| 15-16 23-341 | |||
| 15-17 60-8271 | |||
| 15-18 61-821 | |||
| 15-19 63-812 | |||
| 15-20 65-334 | |||
| 15-21 66-131 | |||
| 15-22 67-180 | |||
| 15-23 71-227 | |||
| 15-24 71-350 | |||
| 15-25 71-361 | |||
| 15-26 71-362 | |||
| 15-27 71-432 | |||
| 15-28 75-381 | |||
| 15-29 75-446 | |||
| 15-30 75-451 | |||
| 15-31 75-468 | |||
| 15-32 75-552 | |||
| 15-33 79-171 | |||
| 15-34 81-125 | |||
| 15-35 84-162 | |||
| 15-36 84-314 | |||
| 15-37 84-635 | |||
| 15-38 84-813 | |||
| 15-39 86-412 | |||
| 15-40 86-501 | |||
| 15-41 86-701 | |||
| 15-42 87-092 | |||
| 15-43 87-129 | |||
| 15-44 87-177 | |||
| 15-45 87-181 | |||
| 15-46 87-253 | |||
| 15-47 87-254 | |||
| 15-48 87-255 | |||
| 15-49 87-268 | |||
| 15-50 87-456 | |||
| 15-51 88-456 | |||
| 15-52 91-405 | |||
| 15-53 93-200 |
Page 18 — 16. テープガイド"関係 TAPE GUIDE ASSEMBLY
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 16-01 | 87-309 | BRACKET | 2 |
| 16-02 | 26-716 | GUIDE BRACKET | 1 |
| 16-03 | 87-129 | SCREW | 3 |
| 16-04 | 26-719 | GUIDE SHAFT LARGE | 2 |
| 16-05 | 26-720 | GUIDE SHAFT SMALL | 3 |
| 16-06 | 84-521 | SCREW | 7 |
| 16-07 | 75-097 | COLLAR | 8 |
| 16-08 | 84-314 | SCREW | 8 |
| 16-09 | 26-717 | GUIDE FIXING BRACKET | 1 |
| 16-10 | 26-718 | GUIDE CLAMP | 1 |
| 16-11 | 84-571 | SCREW | 3 |
| 16-12 | 26-732 | MOUNTING SLIDE FOR HOLDER | 1 |
| 16-13 | 26-731 | MOUNTING BASE FOR HOLDER | 1 |
| 16-15 | 26-736 | BOLT | 1 |
| 16-16 | 26-733 | MOUNTING BASE FOR HOLDER | 1 |
| 16-18 | 26-726 | FIXING CLAMP | 1 |
| 16-19 | 84-382 | SCREW | 1 |
| 16-20 | 20-6450 | TAPE GUIDE ASS'Y | 1 |
| 16-21 | 20-6020 | TAPE STAND ASS'Y (ES-2) | 1 |
| 16-22 | 20-6030 | TAPE STAND ASS'Y (ES-3) | 1 |
| 16-23 | 20-6400 | MOUNTING BASE ASS'Y FOR HOLDER | 1 |
Page 19 — THREAD STAND AND TABLE
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 17-01 | 42-718 | THREAD STAND ASSEMBLY FOR 8 | 1 |
| 42-704 | |||
| 21-045 | |||
| 80-751 | |||
| 31-163 | |||
| 25-140 | |||
| 21-0450-1 | |||
| 23-121 | テープ取付ゴムA | ||
| 23-122 | テープ取付ゴムB | ||
| 75-535 |
Page 20 — 18. 糸立て及びテーブル (1012, 1406~1412) THREAD STAND AND TABLE
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 18-01 | 23-121 | CUSHION RUBBER | 4 |
| 18-02 | 23-122 | CUSHION RUBBER | 4 |
| 18-03 | 23-324 | FELT | ※ |
| 18-04 | 40-6502 | THREAD STAND FOR MODEL 1406 | 1 |
| 18-05 | 40-6505 | THREAD STAND FOR MODEL 1012 | 1 |
| 18-06 | 41-101 | THREAD TENSION NUT | ※ |
| 18-07 | 41-105 | SPRING POST | ※ |
| 18-08 | 41-107 | SPRING CUP | ※ |
| 18-09 | 41-110 | TENSION DISC | ※ |
| 18-10 | 41-701 | SPRING(HEAVY) | ※ |
| 18-11 | 41-702 | SPRING(LIGHT) | ※ |
| 18-12 | 75-535 | WASHER | 4 |
| 18-13 | 88-157 | NUT | ※ |
| 18-14 | 41-522 | SCREW STUD | ※ |
| 18-15 | 41-523 | SCREW STUD FOR ELASTIC THREAD | 12 |
| 18-16 | 25-140 | MACHINE MOUNT BRACKET | 2 |
| 18-17 | 31-163 | CUSHION RUBBER | 4 |
| 18-18 | 80-751 | BOLT | 4 |
| 18-19 | 21-042 | TABLE | 1 |
| 18-20 | 41-524 | THREAD EYELET | ※ |
| 18-21 | 40-6501 | THREAD STAND FOR MODEL 1412 | 1 |
| 18-0123-121 | テープ取付ゴムA | ||
| 18-0223-122 | テープ取付ゴムB | ||
| 18-0323-324 | |||
| 18-0440-6502 | |||
| 18-0540-6505 | |||
| 18-0641-101 | |||
| 18-0741-105 | |||
| 18-0841-107 | |||
| 18-0941-110 | |||
| 18-1041-701 | |||
| 18-1141-702 | |||
| 18-1275-535 | |||
| 18-1388-157 | |||
| 18-1441-522 | |||
| 18-1541-523 | |||
| 18-1625-140 | |||
| 18-1731-163 | |||
| 18-1880-751 | |||
| 18-1921-042 | |||
| 18-2041-524 | |||
| 18-2140-6501 |
Page 21 — 19. アクセサリー ACCESSORIES
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 19-01 | 25-140 | MACHINE MONUT BRACKET | 2 |
| 28-611 | |||
| 31-163 | |||
| 28-920 | |||
| 20-0020 | |||
| 80-751 | |||
| 28-464 | T型レンチ 10mm | ||
| 28-452 | |||
| 13-0580-5 | 針 DV×57#18 | ||
| 28-011 | |||
| 69-851 | |||
| 28-317 | グリップ付六角レンチ 1.5mm | ||
| 28-311 | 六角レンチ 2mm | ||
| 28-312 | 六角レンチ 2.5mm | ||
| 28-313 | 六角レンチ 3mm | ||
| 28-314 | 六角レンチ 5mm | ||
| 13-1140-6 | 針 UO×113GS#14 | ||
| 69-849 | |||
| 13-0810-5 | 針 DV×57LE #21 | ||
| 13-0540-5 | 針 DV-57 #14 | ||
| 87-104 | |||
| 28-614 | |||
| 28-615 | |||
| 23-121 | テープ付ゴム A | ||
| 23-122 | テープ付ゴム B | ||
| 75-535 | |||
| 13-0520-5 | 針 DV×57#12 | ||
| 13-1140-7 | 針 UY×113GS Nm90 |
Page 22 — 20. MR専用部品(1) MODEL MR EXCLUSIVE PARTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 20-01 | 06-432 | STRIPPER BLADE | 1 |
| 20-0106-432 | |||
| 20-0206-433 | |||
| 20-0306-434 | |||
| 20-0406-435 | |||
| 20-0506-437 | |||
| 20-0606-470 | |||
| 20-0727-123 | |||
| 20-0827-124 | |||
| 20-0927-125 | |||
| 20-1071-241 | |||
| 20-1171-263 | |||
| 20-1271-761 | |||
| 20-1475-452 | |||
| 20-1575-455 | |||
| 20-1681-108 | |||
| 20-1781-431 | |||
| 20-1884-161 | |||
| 20-1985-674 | |||
| 20-2087-092 | |||
| 20-2187-203 | |||
| 20-2287-255 | |||
| 20-2394-214 | |||
| 20-2420-0430 | |||
| 20-2520-0440 |
Page 23 — 21. MR專用部品(2) MODEL MR EXCLUSIVE PARTS (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 21-01 | 06-406 | PLATE | 1 |
| 21-02 | 06-408 | LEVER | 1 |
| 21-03 | 06-409 | BRACKET | 1 |
| 21-04 | 06-410 | PLATE | 1 |
| 21-05 | 06-411 | PLATE | 1 |
| 21-06 | 06-412 | FLAT SPRING | 1 |
| 21-07 | 06-431 | RUFFLER BLADE | 1 |
| 21-08 | 06-438 | PLATE | 1 |
| 21-09 | 06-439 | PLATE | 1 |
| 21-10 | 06-471 | TIMING PULLEY | 1 |
| 21-11 | 06-472 | TIMING PULLEY | 1 |
| 21-12 | 23-341 | FELT | 1 |
| 21-13 | 58-410 | TIMING BELT | 1 |
| 21-14 | 63-409 | BRACKET | 1 |
| 21-15 | 63-410 | BRACKET | 1 |
| 21-16 | 65-402 | CONNECTING BAR | 1 |
| 21-17 | 67-410 | LEVER | 1 |
| 21-18 | 67-427 | LEVER | 1 |
| 21-19 | 71-434 | SHAFT | 1 |
| 21-20 | 71-762 | SHAFT | 1 |
| 21-21 | 75-112 | COLLAR | 2 |
| 21-22 | 75-235 | ROLLER | 1 |
| 21-23 | 75-244 | LINK ROLLER | 1 |
| 21-24 | 75-332 | WASHER | 2 |
| 21-25 | 75-452 | WASHER | 1 |
| 21-26 | 75-942 | WASHER | 1 |
| 21-27 | 84-103 | SCREW | 1 |
| 21-28 | 84-163 | SCREW | 1 |
| 21-29 | 84-313 | SCREW | 1 |
| 21-30 | 84-361 | SCREW | 3 |
| 21-31 | 84-365 | SCREW | 1 |
| 21-32 | 84-379 | SCREW | 2 |
| 21-33 | 84-521 | SCREW | 1 |
| 21-34 | 84-561 | SCREW | 1 |
| 21-35 | 84-571 | SCREW | 2 |
| 21-36 | 84-573 | SCREW | 1 |
| 21-37 | 84-718 | SCREW | 4 |
| 21-38 | 84-831 | SCREW | 1 |
| 21-39 | 85-210 | BOLT | 1 |
| 21-40 | 86-211 | NUT | 1 |
| 21-41 | 86-411 | NUT | 1 |
| 21-42 | 86-412 | NUT | 1 |
| 21-43 | 86-481 | NUT | 1 |
| 21-44 | 87-019 | SCREW | 1 |
| 21-45 | 87-173 | BOLT | 1 |
| 21-46 | 87-254 | SCREW | 4 |
| 21-47 | 91-270 | BEARING | 1 |
| 21-48 | 91-409 | BEARING | 1 |
| 21-49 | 93-203 | E-RING | 1 |
| 21-50 | 06-415 | RUFFLER BLADE | 1 |
| 21-51 | 06-416 | BRACKET | 1 |
| 21-52 | 06-418 | PLATE | 1 |
Page 24 — 22. MR専用部品(3) MODEL MR EXCLUSIVE PARTS (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 22-01 | 01-816 | SCREW | 2 |
| 22-02 | 23-324 | FELT | 4 |
| 22-03 | 41-101 | THREAD TENSION NUT | 4 |
| 22-04 | 41-105 | SPRING POST | 4 |
| 22-05 | 41-107 | SPRING CUP | 4 |
| 22-06 | 41-110 | TENSION DISC | 8 |
| 22-07 | 41-113 | TENSION POST SUPPORT | 1 |
| 22-08 | 41-120 | THREAD EYELET | 4 |
| 22-09 | 41-121 | TENSION POST HOLDER | 1 |
| 22-10 | 41-510 | SCREW STUD | 4 |
| 22-11 | 41-701 | SPRING(HEAVY) | 2 |
| 22-12 | 41-702 | SPRING(LIGHT) | 2 |
| 22-13 | 45-101 | THREAD EYELET | 1 |
| 22-14 | 45-107 | THREAD EYELET | 2 |
| 22-15 | 45-131 | THREAD EYELET | 1 |
| 22-16 | 45-237 | THREAD EYELET | 1 |
| 22-17 | 45-238 | NEEDLE THREAD | 1 |
| 22-18 | 45-261 | THREAD EYELET | 1 |
| 22-19 | 45-262 | THREAD EYELET | 1 |
| 22-20 | 45-263 | THREAD EYELET | 1 |
| 22-21 | 45-264 | THREAD EYELET | 1 |
| 22-22 | 45-429 | THREAD TAKE-UP PLATE | 1 |
| 22-23 | 45-437 | THREAD EYELET | 1 |
| 22-24 | 45-442 | THREAD EYELET | 1 |
| 22-25 | 45-550 | THREAD EYELET | 1 |
| 22-26 | 47-117 | THREAD EYELET | 1 |
| 22-27 | 47-120 | THREAD EYELET | 1 |
| 22-28 | 47-166 | THREAD EYELET | 2 |
| 22-29 | 47-408 | THREAD EYELET | 1 |
| 22-30 | 47-409 | THREAD EYELET | 2 |
| 22-31 | 47-413 | THREAD EYELET | 1 |
| 22-32 | 75-455 | WASHER | 2～4 |
| 22-33 | 77-102 | BRACKET | 1 |
| 22-34 | 77-111 | SHAFT | 1 |
| 22-35 | 77-165 | PIPE | 1 |
| 22-36 | 84-361 | SCREW | 4 |
| 22-37 | 84-521 | SCREW | 2 |
| 22-38 | 84-573 | SCREW | 1 |
| 22-39 | 85-613 | SCREW | 2 |
| 22-40 | 86-411 | NUT | 2 |
| 22-41 | 87-113 | BOLT | 1 |
| 22-42 | 87-177 | BOLT | 3～7 |
| 22-43 | 87-269 | SCREW | 3 |
| 22-44 | 87-272 | SCREW | 1 |
| 22-45 | 87-293 | SCREW | 3 |
| 22-46 | 21-934 | COVER | 1 |
| 22-47 | 21-935 | COVER | 1 |
| 22-48 | 87-092 | BOLT | 2 |
| 22-49 | 40-7370 | TENSION ASS'Y (HEAVY) | 2 |
| 22-50 | 40-7380 | TENSION ASS'Y (LIGHT) | 2 |
| 22-0101-816 | |||
| 22-0223-324 | |||
| 22-0341-105 | |||
| 22-0441-107 | SPRING POST | ||
| 22-0541-110 | SPRING CUP | ||
| 22-0641-113 | |||
| 22-0741-113 | |||
| 22-0841-120 | |||
| 22-0941-121 | |||
| 22-1041-510 | |||
| 22-1141-701 | |||
| 22-1241-702 | |||
| 22-1345-101 | |||
| 22-1445-107 | |||
| 22-1545-131 | |||
| 22-1645-237 | |||
| 22-1745-238 | |||
| 22-1845-261 | |||
| 22-1945-262 | |||
| 22-2045-263 | |||
| 22-2145-264 | |||
| 22-2245-429 | |||
| 22-2345-437 | |||
| 22-2445-442 | |||
| 22-2545-550 | |||
| 22-2647-117 | |||
| 22-2747-120 | |||
| 22-2847-166 | |||
| 22-2947-408 | |||
| 22-3047-409 | |||
| 22-3147-413 | |||
| 22-3275-455 | |||
| 22-3377-102 | |||
| 22-3477-111 | |||
| 22-3577-165 | |||
| 22-3684-361 | |||
| 22-3784-521 | |||
| 22-3884-573 | |||
| 22-3985-613 | |||
| 22-4086-411 | |||
| 22-4187-113 | |||
| 22-4287-177 | |||
| 22-4387-269 | |||
| 22-4487-272 | |||
| 22-4587-293 | |||
| 22-4621-934 | |||
| 22-4721-935 | |||
| 22-4887-092 | |||
| 22-4940-7370 | |||
| 22-5040-7380 |
Page 25 — 23. PQ専用部品(1) MODEL EXCLUSIVE PARTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 23-01 | 02-112 | WASHER | 1 |
| 23-02 | 04-405 | LINK | 1 |
| 23-03 | 04-460 | GUIDE | 2 |
| 23-04 | 04-461 | COVER | 1 |
| 23-05 | 04-462 | HOUSING | 1 |
| 23-06 | 04-463 | GEAR | 1 |
| 23-07 | 04-464 | GEAR | 1 |
| 23-08 | 04-465 | GEAR | 1 |
| 23-09 | 04-466 | BRACKET | 1 |
| 23-10 | 04-467 | GUIDE PLATE | 1 |
| 23-11 | 05-430 | GUIDE ROLLER(S) | 2 |
| 23-12 | 14-161 | NEEDLE SUPPORT BRACKET | 1 |
| 23-13 | 14-468 | NEEDLE PLATE | 1 |
| 23-14 | 14-469 | NEEDLE PLATE | 1 |
| 23-15 | 19-476 | RETAINER | 1 |
| 23-16 | 19-477 | RETAINER | 1 |
| 23-17 | 23-240 | GASKET | 1 |
| 23-18 | 27-047 | COVER | 1 |
| 23-19 | 27-057 | UPPER COVER | 1 |
| 23-20 | 27-058 | FRONT COVER | 1 |
| 23-21 | 27-059 | PLATE | 1 |
| 23-22 | 27-060 | COVER | 1 |
| 23-23 | 27-061 | COVER | 1 |
| 23-24 | 45-242 | THREAD GUIDE | 1 |
| 23-25 | 45-401 | THREAD EYELET | 1 |
| 23-26 | 45-402 | THREAD EYELET | 1 |
| 23-27 | 75-187 | WASHER | 1 |
| 23-28 | 75-189 | COLLAR | 1 |
| 23-29 | 75-224 | WASHER | 2 |
| 23-30 | 75-468 | WASHER | 5 |
| 23-31 | 75-901 | WASHER | 2 |
| 23-32 | 79-521 | PLATE SPRING(A) | 2 |
| 23-33 | 79-522 | SPRING | 1 |
| 23-34 | 81-436 | BUSHING | 1 |
| 23-35 | 84-364 | SCREW | 2 |
| 23-36 | 84-368 | SCREW | 2 |
| 23-37 | 84-370 | SCREW | 2 |
| 23-38 | 84-372 | SCREW | 1 |
| 23-39 | 84-374 | SCREW | 2 |
| 23-40 | 84-521 | SCREW | 2 |
| 23-41 | 84-552 | SCREW | 1 |
| 23-42 | 84-761 | SCREW | 3 |
| 23-43 | 84-763 | SCREW | 2 |
| 23-44 | 84-862 | SCREW | 3 |
| 23-45 | 87-098 | SCREW | 2 |
| 23-46 | 87-123 | BOLT | 2 |
| 23-47 | 87-172 | SCREW | 2 |
| 23-48 | 87-261 | SCREW | 5 |
| 23-49 | 87-280 | SCREW | 1 |
| 23-50 | 87-287 | BOLT | 4 |
| 23-51 | 87-412 | SCREW | 2 |
| 23-52 | 87-415 | SCREW | 3 |
| 23-53 | 88-166 | NUT | 1 |
| 23-54 | 92-233 | BEARING | 1 |
| 23-55 | 93-266 | C-RING | 1 |
| 23-56 | 87-177 | BOLT | 1 |
| 23-57 | 88-146 | NUT | 1 |
| 23-58 | 87-269 | SCREW | 5 |
| 23-047 |
Page 26 — 24. PQ専用部品(2) MODEL PQ EXCLUSIVE PARTS(2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 24-01 | 00-1404 | METERING DEVICE ASS'Y | 1 |
| 24-02 | 01-102 | SLEEVE | 1 |
| 24-03 | 01-103 | SLEEVE | 1 |
| 24-04 | 01-111 | BRACKET | 1 |
| 24-05 | 01-116 | PLATE | 1 |
| 24-06 | 01-132 | PULLER | 1 |
| 24-07 | 01-134 | LOWER ROLLER | 1 |
| 24-08 | 01-136 | ROLLER HOLDER | 2 |
| 24-09 | 01-141 | RUBBER TIGHTENER | 1 |
| 24-10 | 01-143 | ROLLER CONTROLER | 1 |
| 24-11 | 01-145 | LEVER | 1 |
| 24-12 | 01-146 | COVER | 1 |
| 24-13 | 01-147 | PIN | 1 |
| 24-14 | 23-341 | FELT | 1 |
| 24-15 | 45-127 | THREAD EYELET | 2 |
| 24-16 | 60-8271 | CONNECTING ROD ASS'Y | 1 |
| 24-17 | 61-821 | CONNECTING ROD BALL | 1 |
| 24-18 | 63-812 | BALL JOINT | 1 |
| 24-19 | 65-334 | PULLER CONNECTING BAR | 1 |
| 24-20 | 66-131 | CONNECTING LINK | 1 |
| 24-21 | 67-180 | PULLER CONNECTING LEVER | 1 |
| 24-22 | 71-227 | PIN | 1 |
| 24-23 | 71-350 | SHAFT | 1 |
| 24-24 | 71-361 | PIVOT SHAFT(LARGE) | 1 |
| 24-25 | 71-362 | PIVOT SHAFT(SMALL) | 1 |
| 24-26 | 71-432 | FEED ROCKER LINK PIN | 1 |
| 24-27 | 75-381 | WASHER | 1 |
| 24-28 | 75-446 | WASHER | 1 |
| 24-29 | 75-451 | WASHER | 2 |
| 24-30 | 75-468 | WASHER | 2 |
| 24-31 | 75-552 | WASHER | 2 |
| 24-32 | 79-171 | SPRING | 1 |
| 24-33 | 81-125 | BUSHING | 2 |
| 24-34 | 84-162 | SCREW | 3 |
| 24-35 | 84-314 | SCREW | 1 |
| 24-36 | 84-635 | SCREW | 2 |
| 24-37 | 84-813 | SCREW | 2 |
| 24-38 | 86-412 | NUT | 1 |
| 24-39 | 86-501 | NUT | 1 |
| 24-40 | 86-701 | NUT | 1 |
| 24-41 | 87-010 | SCREW | 2 |
| 24-42 | 87-092 | BOLT | 2 |
| 24-43 | 87-129 | BOLT | 2 |
| 24-44 | 87-181 | SCREW | 2 |
| 24-45 | 87-203 | BOLT | 1 |
| 24-46 | 87-253 | SCREW | 1 |
| 24-47 | 87-254 | SCREW | 1 |
| 24-48 | 87-310 | SCREW | 1 |
| 24-49 | 87-456 | SCREW | 1 |
| 24-50 | 88-456 | NUT | 1 |
| 24-51 | 91-405 | BEARING | 2 |
| 24-52 | 93-200 | E-RING | 1 |
| 24-0100-1404 | PMD装置(組) | ||
| 24-0201-102 | |||
| 24-0301-103 | |||
| 24-0401-111 | |||
| 24-0501-116 | |||
| 24-0601-132 | |||
| 24-0701-134 | |||
| 24-0801-136 | |||
| 24-0901-141 | |||
| 24-1001-143 | |||
| 24-1101-145 | |||
| 24-1201-146 | |||
| 24-1301-147 | |||
| 24-1423-341 | |||
| 24-1545-127 | |||
| 24-1660-8271 | |||
| 24-1761-821 | |||
| 24-1863-812 | |||
| 24-1965-334 | |||
| 24-2066-131 | |||
| 24-2167-180 | |||
| 24-2271-227 | |||
| 24-2371-350 | |||
| 24-2471-361 | |||
| 24-2571-362 | |||
| 24-2671-432 | |||
| 24-2775-381 | |||
| 24-2875-446 | |||
| 24-2975-451 | |||
| 24-3075-468 | |||
| 24-3175-552 | |||
| 24-3279-171 | |||
| 24-3381-125 | |||
| 24-3484-162 | |||
| 24-3584-314 | |||
| 24-3684-635 | |||
| 24-3784-813 | |||
| 24-3886-412 | |||
| 24-3986-501 | |||
| 24-4086-701 | |||
| 24-4187-010 | |||
| 24-4287-092 | |||
| 24-4387-129 | |||
| 24-4487-181 | |||
| 24-4587-203 | |||
| 24-4687-253 | |||
| 24-4787-254 | |||
| 24-4887-310 | |||
| 24-4987-456 | |||
| 24-5088-456 | |||
| 24-5191-405 | |||
| 24-5293-200 |
Page 27 — 25. PQ専用部品(3) MODEL PQ EXCLUSIVE PARTS (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 25-01 | 21-040 | TABLE | 1 |
| 25-02 | 21-054 | TABLE | 1 |
| 25-03 | 23-324 | FELT | ※ |
| 25-04 | 40-6501 | THREAD STAND FOR MODEL 1412 | 1 |
| 25-05 | 40-6503 | THREAD STAND FOR MODEL PQ | 1 |
| 25-06 | 40-6504 | THREAD STAND FOR MODEL PSM | 1 |
| 25-07 | 41-101 | THREAD TENSION NUT | ※ |
| 25-08 | 41-105 | SPRING POST | ※ |
| 25-09 | 41-107 | SPRING CUP | ※ |
| 25-10 | 41-110 | TENSION DISC | ※ |
| 25-11 | 41-701 | SPRING(HEAVY) | 12 |
| 25-12 | 41-702 | SPRING(LIGHT) | ※ |
| 25-13 | 88-157 | NUT | ※ |
| 25-14 | 41-522 | SCREW STUD | ※ |
| 25-15 | 41-524 | THREAD EYELET | ※ |
| 25-0121-040 | |||
| 25-0221-054 | |||
| 25-0323-324 | |||
| 25-0440-6501 | |||
| 25-0540-6503 | 12本糸立てセット(PQ) | ||
| 25-0640-6504 | 12本糸立てセット(PSM) | ||
| 25-0741-101 | |||
| 25-0841-105 | |||
| 25-0941-107 | |||
| 25-1041-110 | |||
| 25-1141-701 | |||
| 25-1241-702 | |||
| 25-1388-157 | |||
| 25-1441-522 | |||
| 25-1541-524 |
Page 28 — 26. PTV専用部品 MODEL PTV EXCLUSIVE PARTS
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 27-020 | |||
| 97-4150-0 | |||
| 97-4140-0 | 1412PTV-1-3/16-6ホルダー | ||
| 97-4141-0 | 1406PTV-1-3/8-11ホルダー | ||
| 97-4142-0 | 1412PTV-1-1/4-8ホルダー | ||
| 97-4143-0 | 1406PTV-1-1/2-14ホルダー |
Page 29 — 27. PSM専用部品(1) MODEL PSM EXCLUSIVE PARTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 04-328 | |||
| 04-414 | |||
| 04-416 | |||
| 04-417 | |||
| 04-418 | PREADER C (3/16) | ||
| 04-419 | PREADER B (3/16) | ||
| 04-420 | PREADER A (3/16) | ||
| 04-421 | PREADER C (1/4) | ||
| 04-422 | PREADER B (1/4) | ||
| 04-423 | PREADER A (1/4) | ||
| 23-158 | PASKET | ||
| 27-019 | HEAD COVER | ||
| 27-021 | HEAD COVER | ||
| 41-341 | AR | ||
| 41-439 | RACKET | ||
| 41-461 | RACKET | ||
| 41-462 | AR | ||
| 45-137 | THREAD EYELET | ||
| 45-342 | THREAD EYELET | ||
| 45-343 | THREAD GUIDE | ||
| 45-344 | THREAD EYELET | ||
| 69-324 | RACK HOUSING (1/4) | ||
| 69-325 | PLATE | ||
| 69-326 | GUIDE PLATE | ||
| 71-370 | IN | ||
| 71-457 | RACK SHAFT | ||
| 71-458 | LOOPER SHAFT | ||
| 71-459 | RACK SHAFT | ||
| 71-460 | LOOPER SHAFT | ||
| 75-410 | SPRING WASHER | ||
| 75-455 | WASHER | ||
| 75-522 | WASHER | ||
| 81-435 | BUSHING | ||
| 84-364 | SCREW | ||
| 84-374 | SCREW | ||
| 84-521 | SCREW | ||
| 84-765 | SCREW | ||
| 87-068 | SCREW | ||
| 87-113 | BOLT | ||
| 87-123 | BOLT | ||
| 87-129 | BOLT | ||
| 87-171 | BOLT | ||
| 87-224 | BOLT | ||
| 87-309 | SCREW | ||
| 88-137 | NUT |
Page 30 — 28. PSM専用部品(2) MODEL PSM EXCLUSIVE PARTS (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 04-008 | CAM COLLAR PIN | ||
| 04-004 | CAM 1~13 | ||
| 04-408 | FORM GEAR | ||
| 04-409 | FORM WHEEL | ||
| 04-468 | SPACE COLLAR | ||
| 21-402 | PULLEY COVER | ||
| 21-412 | HOUSING COVER | ||
| 21-489 | CAM COVER | ||
| 23-160 | PLATE | ||
| 23-189 | SEAL WASHER | ||
| 23-304 | O-RING | ||
| 23-384 | SEAL | ||
| 23-412 | FELT | ||
| 23-567 | GASKET | ||
| 35-122 | FELT | ||
| 35-315 | PIPE | ||
| 39-139 | PIPE | ||
| 69-320 | GEAR HOUSING | ||
| 71-208 | PIN | ||
| 71-266 | PIN | ||
| 71-706 | SHAFT | ||
| 71-942 | SHAFT | ||
| 75-112 | COLLAR | ||
| 75-181 | CAM COLLAR (A) | ||
| 75-184 | SPACE COLLAR | ||
| 75-332 | WASHER | ||
| 75-455 | WASHER | ||
| 75-527 | SPRING WASHER | ||
| 75-552 | WASHER | ||
| 77-160 | LEVER | ||
| 77-412 | CHAIN GUIDE | ||
| 81-690 | BUSHING | ||
| 84-361 | SCREW | ||
| 84-363 | SCREW | ||
| 84-566 | SCREW | ||
| 84-579 | SCREW | ||
| 85-522 | SCREW | ||
| 87-113 | BOLT | ||
| 87-171 | SCREW | ||
| 87-172 | BOLT | ||
| 87-173 | SCREW | ||
| 87-254 | SCREW | ||
| 87-311 | SCREW | ||
| 88-462 | NUT |
Page 31 — 29. PSM専用部品 (3) MODEL PSM EXCLUSIVE PARTS (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 04-342 | |||
| 04-348 | |||
| 04-349 | |||
| 04-411 | |||
| 65-341 | |||
| 65-347 | |||
| 65-348 | |||
| 66-433 | |||
| 67-431 | |||
| 67-434 | |||
| 67-435 | |||
| 67-436 | |||
| 67-437 | |||
| 71-529 | |||
| 75-152 | |||
| 75-257 | |||
| 75-260 | |||
| 75-455 | |||
| 75-519 | |||
| 75-452 | |||
| 84-566 | |||
| 84-605 | |||
| 84-606 | |||
| 84-607 | |||
| 87-188 | |||
| 85-627 | |||
| 86-311 | |||
| 87-181 | |||
| 88-157 | |||
| 88-158 | |||
| 85-629 | |||
| 87-173 |
Page 32 — 30. PSM専用部品(4) MODEL PSM EXCLUSIVE PARTS (4)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 30-0121-048 | |||
| 30-0223-048 | |||
| 30-0440-6504 | 12本立て(PSM) | ||
| 30-0440-6505 | |||
| 30-0440-6507 | |||
| 30-0541-101 | |||
| 30-0641-105 | |||
| 30-0641-107 | |||
| 30-0641-108 | |||
| 30-1141-522 | |||
| 30-1141-523 | |||
| 30-1441-524 | |||
| 30-1541-701 | |||
| 30-1541-702 | |||
| 30-1688-157 |
Page 33 — 31. 1403PSM專用部品(1) MODEL 1403PSM EXCLUSIVE PARTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 31-01 | 02-118 | WASHER | 2 |
| 31-0102-118 | |||
| 31-0204-015 | |||
| 31-0304-018 | |||
| 31-0404-476 | |||
| 31-0521-626 | |||
| 31-0623-324 | |||
| 31-0741-101 | |||
| 31-0841-105 | |||
| 31-0941-107 | |||
| 31-1041-110 | |||
| 31-1241-115 | |||
| 31-1341-120 | |||
| 31-1441-123 | |||
| 31-1641-136 | |||
| 31-1741-341 | |||
| 31-1841-429 | |||
| 31-1941-430 | |||
| 31-2041-461 | |||
| 31-2141-508 | |||
| 31-2241-509 | |||
| 31-2341-510 | |||
| 31-2441-701 | |||
| 31-2541-702 | |||
| 31-2645-123 | |||
| 31-2745-137 | |||
| 31-2845-342 | |||
| 31-2945-429 | |||
| 31-3045-438 | |||
| 31-3145-441 | |||
| 31-3245-442 | |||
| 31-3345-523 | |||
| 31-3447-117 | |||
| 31-3547-176 | |||
| 31-3647-413 | |||
| 31-3771-426 | |||
| 31-3875-455 | |||
| 31-3984-361 | |||
| 31-4084-374 | |||
| 31-4184-396 | |||
| 31-4284-521 | |||
| 31-4384-761 | |||
| 31-4484-765 | |||
| 31-4586-211 | |||
| 31-4686-411 | |||
| 31-4787-113 | |||
| 31-4887-129 | |||
| 31-4987-171 | |||
| 31-5087-177 | |||
| 31-5187-272 | |||
| 31-5287-293 | |||
| 31-5340-7370 | |||
| 31-5440-7380 |
Page 34 — 32. 1403PSM專用部品(2) MODEL 1403PSM EXCLUSIVE PARTS (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 32-01 04-043 | |||
| 32-02 04-328 | |||
| 32-03 04-342 | |||
| 32-04 04-348 | |||
| 32-05 04-349 | |||
| 32-06 04-469 | |||
| 32-07 04-470 | |||
| 32-08 04-471 | |||
| 32-09 04-473 | |||
| 32-10 04-474 | |||
| 32-11 04-475 | |||
| 32-12 65-341 | |||
| 32-13 65-347 | |||
| 32-14 66-433 | |||
| 32-15 66-519 | |||
| 32-16 67-430 | |||
| 32-17 67-431 | |||
| 32-18 67-432 | |||
| 32-19 69-324 | |||
| 32-20 69-325 | |||
| 32-21 71-423 | |||
| 32-22 71-529 | |||
| 32-23 75-152 | |||
| 32-24 75-247 | |||
| 32-25 75-257 | |||
| 32-26 75-260 | |||
| 32-28 75-410 | |||
| 32-29 75-452 | |||
| 32-30 75-453 | |||
| 32-31 75-455 | |||
| 32-32 75-468 | |||
| 32-33 75-519 | |||
| 32-34 75-522 | |||
| 32-35 81-435 | |||
| 32-36 84-566 | |||
| 32-37 84-566 | |||
| 32-38 84-583 | |||
| 32-39 84-605 | |||
| 32-40 84-606 | |||
| 32-41 84-607 | |||
| 32-42 85-627 | |||
| 32-43 86-311 | |||
| 32-44 87-068 | |||
| 32-45 87-092 | |||
| 32-46 87-106 | |||
| 32-47 87-113 | |||
| 32-48 87-173 | |||
| 32-49 87-181 | |||
| 32-50 87-188 | |||
| 32-51 87-224 | |||
| 32-52 87-243 | |||
| 32-53 87-266 | |||
| 32-54 88-137 | |||
| 32-55 88-157 | |||
| 32-56 88-158 |
Page 35 — 33. 1403PSM専用部品(3) MODEL 1403PSM EXCLUSIVE PARTS (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 33-01 | 01-103 | SLEEVE | 2 |
| 33-0101-103 | |||
| 33-0202-278 | カラーB | ||
| 33-0302-117 | |||
| 33-0402-189 | |||
| 33-0502-199 | |||
| 33-0602-251 | |||
| 33-0702-263 | |||
| 33-0802-266 | |||
| 33-0971-443 | |||
| 33-1071-439 | |||
| 33-1187-278 | |||
| 33-1275-451 | |||
| 33-1375-519 | |||
| 33-1479-551 | |||
| 33-1581-321 | |||
| 33-1681-322 | |||
| 33-1781-323 | |||
| 33-1884-162 | |||
| 33-1984-573 | |||
| 33-2087-113 | |||
| 33-2187-129 | |||
| 33-2287-181 | |||
| 33-2387-225 | |||
| 33-2488-179 | |||
| 33-2591-405 | |||
| 33-2693-221 | |||
| 33-2700-2002 |
Page 36 — 34. ゲージパーツ (1) GAUGE PARTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 34-02 | 13-0540-5 | NEEDLE | ※ |
| 34-03 | 13-0810-5 | NEEDLE | ※ |
| 34-05 | 13-1140-6 | NEEDLE | ※ |
| 34-06 | 13-1180-5 | NEEDLE | ※ |
| 34-10 | 17-3710-A | SHANK | 1 |
| 34-12 | 17-3710-C | BRACKET | 1 |
| 34-13 | 17-4210-A | BRACKET | 1 |
| 34-14 | 17-4210-C | BRACKET | 2 |
| 34-15 | 17-4210-E | LINK PLATE | 1 |
| 34-16 | 17-4210-G | SLIDE PLATE | 1 |
| 34-19 | 17-4960-A | BRACKET | 1 |
| 34-22 | 87-071 | SCREW | 12 |
| 34-24 | 17-5700-C | SCREW | 1 |
| 34-25 | 17-5810-D | PIN | 2 |
| 34-26 | 17-5810-F | SCREW | 1 |
| 34-27 | 17-8190-F | SPRING | 1 |
| 34-29 | 19-406 | BRACKET | ※ |
| 34-30 | 19-416 | NEEDLE GUARD | ※ |
| 34-35 | 71-215 | PIN | 2 |
| 34-36 | 84-114 | SCREW | 2 |
| 34-37 | 84-161 | SCREW | 2 |
| 34-38 | 84-164 | SCREW | ※ |
| 34-39 | 84-361 | SCREW | 2 |
| 34-40 | 84-364 | SCREW | 1 |
| 34-41 | 84-367 | SCREW | ※ |
| 34-42 | 84-380 | SCREW | ※ |
| 34-43 | 88-146 | NUT | 2 |
| 34-44 | 84-464 | SCREW | 4 |
| 34-45 | 84-521 | SCREW | 2 |
| 34-46 | 88-160 | NUT | 2 |
| 34-47 | 84-588 | SCREW | 1 |
| 34-48 | 84-591 | BOLT | 1 |
| 34-49 | 87-104 | SCREW | ※ |
| 34-50 | 87-113 | BOLT | 1 |
| 34-51 | 87-252 | BOLT | 1 |
| 34-52 | 87-279 | SCREW | 2 |
| 34-53 | 87-289 | SCREW | 2 |
| 34-54 | 13-1140-7 | NEEDLE | ※ |
| 13-1140-5 | 針 (UOX113 #14) | ||
| 17-4210-B |
Page 37 — 35. ゲージパーツ (2) GAUGE PARTS (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 12-409 | |||
| 12-479 | |||
| 14-411 | |||
| 14-415 | |||
| 15-411 | |||
| 15-415 | |||
| 17-4110-1 | |||
| 17-4110-B | |||
| 17-4150-1 | |||
| 17-4430-A | |||
| 17-4150-B | |||
| 17-4150-C | |||
| 17-4960-A | |||
| 17-5700-C | |||
| 18-418 | |||
| 18-496 | |||
| 19-413 | |||
| 19-496 | |||
| 84-382 | |||
| 84-521 | |||
| 84-564 | |||
| 87-252 | |||
| 87-279 | |||
| 88-160 | |||
| 06-003 | |||
| 06-186 | |||
| 06-187 | |||
| 06-188 | |||
| 15-051 | |||
| 17-0510-1 |
Page 38 — 36. ゲージ パーツ (3) GAUGE PARTS (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 04-477 | |||
| 12-435 | |||
| 13-0580-5 | 針(DVX57 #18) | ||
| * | |||
| * | |||
| * | |||
| 17-0470-B | 押え足 (2mm) | ||
| 17-0470-C | 押え足 (3.5mm) | ||
| * | |||
| * | |||
| 17-3710-B | |||
| 17-3710-C | |||
| 17-4150-C | |||
| 17-4350-A | |||
| 17-5700-C | |||
| 17-8190-F | |||
| * | |||
| * | |||
| 71-215 | |||
| 36-20 | |||
| 36-21 | |||
| 17-4330-A | |||
| * | |||
| 36-25 | |||
| 36-26 | |||
| 36-27 | |||
| 36-28 | |||
| 36-29 | |||
| 36-30 | |||
| 36-31 | |||
| 36-32 |
Page 39 — 37. ゲージ部品一覧表(1) GAUGE PARTS TABLE(1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 12-4090-1 | 17-4150-1 | PRESSER FOOT ASS'Y | 115-415 |
| 19-416 | 18-418 | RETAINER | 19-437 |
| 12-4090-1 | 17-3750-1 | PRESSER FOOT ASS'Y | 115-418 |
| 19-416 | 18-418 | RETAINER | 19-437 |
| 12-4210-1 | 17-3710-1 | PRESSER FOOT ASS'Y | 115-421 |
| 19-416 | 18-421 | RETAINER | 19-437 |
| 12-4220-1 | 17-3720-1 | PRESSER FOOT ASS'Y | 115-422 |
| 19-416 | 18-422 | RETAINER | 19-437 |
| 12-4230-1 | 17-3730-1 | PRESSER FOOT ASS'Y | 115-423 |
| 19-416 | 18-423 | RETAINER | 19-437 |
| 12-4240-1 | 17-3740-1 | PRESSER FOOT ASS'Y | 115-424 |
| 19-416 | 18-424 | RETAINER | 19-437 |
| 12-4280-1 | 17-3780-1 | PRESSER FOOT ASS'Y | 115-428 |
| 19-416 | 18-428 | RETAINER | 19-437 |
| 12-4240-1 | 17-3740-1 | PRESSER FOOT ASS'Y | 115-424 |
| 19-416 | 18-424 | RETAINER | 19-437 |
| 12-4300-1 | 17-3890-1 | PRESSER FOOT ASS'Y | 115-430 |
| 19-416 | 18-430 | RETAINER | 19-437 |
| 12-4310-1 | 17-3900-1 | PRESSER FOOT ASS'Y | 115-431 |
| 19-416 | 18-431 | RETAINER | 19-437 |
| 12-4350-1 | 17-3960-1 | PRESSER FOOT ASS'Y | 115-435 |
| 19-416 | 18-435 | RETAINER | 19-437 |
| 12-4980-1 | 17-3970-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-028 | NEEDLE PLATE | 18-496 |
| 12-4980-1 | 17-3960-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-029 | NEEDLE PLATE | 18-497 |
| 12-4980-1 | 17-3760-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-497 |
| 12-4980-1 | 17-3770-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-497 |
| 12-4980-1 | 17-3820-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-426 |
| 12-4980-1 | 17-3810-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-432 |
| 12-4980-1 | 17-3760-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-427 |
| 12-4980-1 | 17-3770-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-427 |
| 12-4980-1 | 17-3820-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-432 |
| 12-4980-1 | 17-3810-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-047 | NEEDLE PLATE | 18-427 |
| 12-4980-1 | 17-4500-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-468 | NEEDLE PLATE | 18-496 |
| 12-4980-1 | 17-4510-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-469 | NEEDLE PLATE | 18-496 |
| 12-4980-1 | 17-4520-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-468 | NEEDLE PLATE | 18-496 |
| 12-4980-1 | 17-4500-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-468 | NEEDLE PLATE | 18-496 |
| 12-4980-1 | 17-4520-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-468 | NEEDLE PLATE | 18-496 |
| 12-4980-1 | 17-4700-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-469 | NEEDLE PLATE | 18-496 |
| 12-4980-1 | 17-4710-1 | PRESSER FOOT ASS'Y | 115-496 |
| 19-431 | 14-468 | NEEDLE PLATE | 18-496 |
Kansai Special DFB-1404 / DFB-1412 — parts catalog
- Page 1 (cover): This is the cover page for the DFB Series of industrial sewing machines, published by KANSAI SPECIAL in September 2007. It includes a part number of No. 070102.
- Page 2 (toc): This page is a table of contents for the parts book, listing mechanisms and their corresponding page numbers.
- Page 3 (diagram): This page displays a diagram of frame assembly components for an industrial sewing machine, with a corresponding parts list detailing part numbers, descriptions, and quantities.
- Page 4 (parts_list): This page lists parts for the frame assembly (2) of the sewing machine, including washers, brackets, covers, gaskets, screws, bolts, nuts, and springs, with their corresponding part numbers and quantities.
- Page 5 (diagram): This page displays a diagram of the thread tension mechanism (1404) with numbered parts and a corresponding parts list detailing part numbers, descriptions, and quantities.
- Page 6 (diagram): This page displays a diagram of the thread tension mechanism (1412) with a corresponding parts list detailing part numbers, descriptions, and quantities.
- Page 7 (parts_list): This page lists parts for the Bushing mechanism, including support brackets, pins, washers, and various bushings, with their corresponding part numbers and quantities.
- Page 8 (diagram): This page displays a diagram of the needle bar and lever mechanism, along with a detailed parts list for its components.
- Page 9 (parts_list): This page contains a parts list for the crankshaft mechanism, detailing part numbers, descriptions, and quantities for various components.
- Page 10 (diagram): This page displays a diagram of the FEED MECHANISM (8) for a sewing machine, along with a detailed parts list including reference numbers, part numbers, descriptions, and quantities.
- Page 11 (diagram): Exploded diagram of the looper mechanism with a companion parts table listing reference numbers, part numbers, Japanese and English names, and quantities for the looper rocker, take-up and eccentric parts, springs, bolts, and bearings.
- Page 12 (diagram): This page displays a diagram of the presser foot mechanism, along with a detailed parts list including part numbers, descriptions, and quantities.
- Page 13 (parts_list): This page lists parts for the lubrication mechanism, including part numbers, descriptions, and quantities.
- Page 14 (diagram): This page displays a diagram of the rear puller mechanism (1404) with numbered parts and a corresponding parts list.
- Page 15 (diagram): This page displays a diagram of the rear puller mechanism (1406-1412) with a detailed parts list including part numbers, descriptions, and quantities.
- Page 16 (parts_list): This page lists parts for the REAR PULLER MECHANISM for models 1402-1404TYPE and 1406-1412TYPE, including part numbers, descriptions, and quantities.
- Page 17 (parts_list): This page contains a parts list for the metering device mechanism, including part numbers, descriptions, and quantities.
- Page 18 (parts_list): This page lists parts for the Tape Guide Assembly, including various screws, brackets, shafts, collars, and mounting components, with part numbers and descriptions.
- Page 19 (parts_list): This page contains a parts list for the thread stand and table assembly, including part numbers, descriptions, and quantities.
- Page 20 (parts_list): This page lists parts for thread stands and tables for models 1406, 1408, 1412, and 1414, including part numbers, descriptions, and quantities.
- Page 21 (parts_list): This page lists accessories for the sewing machine, including brackets, oil, rubber cushions, chains, tools like screwdrivers and Allen keys, and various fasteners.
- Page 22 (parts_list): This page lists parts for models 1402MR and 1412MR, including part numbers, descriptions, and quantities.
- Page 23 (parts_list): This page lists parts for MR exclusive models, including part numbers, descriptions, and quantities, with reference numbers corresponding to a diagram.
- Page 24 (parts_list): This page lists parts for the MR exclusive parts (3) and Model MR exclusive parts (3) with part numbers, descriptions, and quantities.
- Page 25 (parts_list): This page contains a parts list for PQ exclusive parts (1) of a sewing machine, detailing part numbers, descriptions, and quantities.
- Page 26 (parts_list): This page contains a parts list for the metering device assembly, including part numbers, descriptions, quantities, and reference numbers.
- Page 27 (parts_list): This page lists parts for models 1412PQ, 1412PQSM, and 1012PQ, including thread stands, tension nuts, spring cups, and various other components with their respective part numbers and descriptions.
- Page 28 (parts_list): This page lists parts for PTV exclusive parts, model PTV, including head covers and various holder assemblies with their corresponding part numbers and quantities.
- Page 29 (parts_list): This page contains a parts list for PSM exclusive parts (1), detailing items such as pinions, stoppers, rackets, preaders, and various screws and bolts with their corresponding part numbers and descriptions.
- Page 30 (parts_list): This page contains a parts list for PSM exclusive parts (2) for models 1012 and 1403, detailing part numbers, descriptions, and quantities.
- Page 31 (diagram): This page displays a diagram of PSM exclusive parts (3) for model PSM, including a detailed parts list with reference numbers, part numbers, descriptions, and quantities.
- Page 32 (parts_list): This page lists exclusive parts for models 1412PSM, 1403PSM, and 1012PSM, including part numbers, descriptions, and quantities.
- Page 33 (parts_list): This page contains a parts list for the Model 1403PSM exclusive parts (1), including part numbers, descriptions, quantities, and reference numbers.
- Page 34 (parts_list): This page contains a parts list for the 1403PSM exclusive parts (2), detailing part numbers, descriptions, and quantities for various components.
- Page 35 (parts_list): This page contains a parts list for model 1403PSM exclusive parts (3), including part numbers, descriptions, and quantities.
- Page 36 (parts_list): This page contains a parts list for gauge parts (1) with reference numbers, part numbers, descriptions, and quantities for various components.
- Page 37 (parts_list): This page contains a parts list for gauge parts (2), with part numbers, descriptions, and quantities for various components.
- Page 38 (parts_list): This page contains a parts list for gauge parts (3) with reference numbers, part numbers, descriptions, and quantities. It also includes diagrams of various machine components.
- Page 39 (parts_list): This page contains two parts lists, labeled "37. GAUGE PARTS TABLE (1)" and "38. GAUGE PARTS TABLE (2)", detailing various gauge parts for sewing machines, including their model types, gauge sizes, and associated part numbers.
