Pegasus BT Series Backlatcher (EX, EXT, LX) — Part Book

Pegasus BT Series Backlatcher (EX, EXT, LX) — parts catalog

Page 1 (cover): This is the cover page for the BT Series Parts Catalog for Backlatcher models EX(T)5200, EXT5200H, EXT5100T, EX5400, and LX5200.
Page 2 (toc): This page provides an introduction to the parts catalog, explaining how to use it and listing the models covered by the catalog, including EX5200, EXT5200, EXT5200H, EXT5100T, EX5400, and LX5200 series.
Page 3 (toc): This page is a table of contents for a parts catalog, listing various mechanisms and parts with their corresponding page numbers.
Page 4 (diagram): This page displays diagrams of various components for different sewing machine models, including parts for BT103, BT103A, BT184, BT220, BT220A, BT250, and BT250A models, with some parts indicated as packed in accessory.
Page 5 (parts_list): This page lists parts for the Knife & Clamp & Finger Drive Mechanism for BT103, 103A, 184, 220, 220A, 250, 250A models, including part numbers, descriptions in both Japanese and English, and quantities.
Page 6 (diagram): This page displays diagrams of various components for EX5200, EXT5200, EXT5200H, BT250A, and BT220A models, including parts packed as accessories.
Page 7 (parts_list): This page lists parts for the finger drive mechanism, filter/regulator, and solenoid valve for BT220A and BT250A models, including part numbers, descriptions, and quantities.
Page 8 (diagram): This page displays an exploded view diagram of various components for the BT103A (EX5200) model, including several sub-assemblies and individual parts.
Page 9 (parts_list): This page lists parts for the BT103A Thread Tension Mechanism (1-Needle), including tension springs, screws, nuts, and other components, with their part numbers, descriptions, and quantities.
Page 10 (diagram): This page illustrates various components for the BT220 (EX5200) model, including parts for tension assemblies, a spring, and a larger assembly with multiple attached components.
Page 11 (parts_list): This page lists parts for the BT220 Thread Tension Mechanism (1-Needle), including tension springs, screws, levers, and other components.
Page 12 (diagram): This page displays several exploded view diagrams of components for the BT220A(EX5200) model, including various springs, washers, and other parts, with some parts indicated as packed in accessory.
Page 13 (parts_list): This page lists parts for the BT220A Thread Tension Mechanism (1-Needle), including various tension springs, guides, screws, and other related components.
Page 14 (diagram): This page displays an exploded view diagram of various components for BT250 (EX5200, EXT5200) models, including springs, washers, and other assembly parts.
Page 15 (parts_list): This page lists parts for the BT250 Thread Tension Mechanism (2-Needle), including tension springs, screws, levers, and other components, with their part numbers, descriptions, and quantities.
Page 16 (diagram): This page illustrates various components for BT250A (EX5200, EXT5200) and BT250A (EXT5200H) models, including springs, washers, and other parts, with specific diagrams for different series.
Page 17 (parts_list): This page lists parts for the BT250A thread tension mechanism (2-needle), including tension assemblies, springs, screws, and labels.
Page 18 (diagram): This page displays diagrams of various components for BT220, 220A, BT250, BT250A, BT103A, and EX5200 series machines, including cables, covers, and mounting hardware.
Page 19 (parts_list): This page lists sensor sets and specific parts for BT103A, 220, 220A, 250, 250A models, including various screws, grips, cords, needle plates, and waste chute components.
Page 20 (diagram): This page illustrates various components and accessories for BT220, BT220A, BT250, BT250A models, including specifications for different voltages and regions, and packed accessories.
Page 21 (parts_list): This page lists parts for BT220, 220A, 250, 250A BT Controller & Pin, including controllers, labels, brackets, cable stoppers, screws, bands, fuses, power source cords, pin assemblies, O-rings, and indication labels/plates.
Page 22 (diagram): This page displays a diagram of BT184 specific parts for EX5200, EX5400, and LX5200 series machines, including various components and their reference numbers.
Page 23 (parts_list): This page lists parts for the BT184 thread releaser mechanism and specific parts, including part numbers, descriptions in both Japanese and English, and quantities.
Page 24 (diagram): This page displays an exploded view diagram of various components for the BT104(EXT5100T) model, including parts packed in accessories and other individual components.
Page 25 (parts_list): This page lists parts for the cloth plate and specific components, including part numbers, descriptions, and quantities.
Page 26 (index): This page is an index listing part numbers, their corresponding page numbers, and reference numbers.
Page 27 (unknown): This page is blank except for a watermark and a footer with a website address.
Page 28 (cover): This page is the cover of a parts catalog for Pegasus Sewing Machine Mfg. Co., Ltd., indicating it was printed in March 2001 and includes contact information.

Page 1 — BT Series Parts Catalog

BT Series Backlatcher for EX(T)5200,EXT5200H EXT5100T,EX5400,LX5200 Series EX(T)5200,EXT5200H,EXT5100T,EX5400 LX5200 Series バックタック装置 Parts Catalog PEGASUS® jintex.in

Page 2 — INTRODUCTION

パーツカタログの見方 INTRODUCTION このパーツカタログは、2001年3月製造中のEX5200・ 5400・EXT5200・EXT5200H・EXT5100T・LX5200用 BT装置のミシンを次の要領で掲載していま。 2~23頁には部品を機構別に収録し、左頁が部品の分解図、右頁がパーツリストになっています。また、部品分解図に付されている番号は、パーツリストのREF.NO. (参照番号) を示しています。巻末には部品番号インデックスを記載し、部品番号だけで、その図解・名称などが容易に引き出せます。部品を御注文いただく時は、部品番号を明示してください。なお、このパーツカタログの記載事項は改良により、予告なく変更されることがありますので、あらかじめ了承ください。 This parts catalog covers the EX5200・5400 series,EXT5200 series,EXT5200H series EXT5100T series LX5200 series machine manufactured in March, 2001. The components of BT device are arranged according to the mechanism on pages 2-23. The illustrations are on left pages and the part numbers on right pages. The illus- trated part and its part number are assigned the same ref- erence number. The index of part numbers are listed at the back of this book for quick reference. To place an order for any part, please specify the part number. Note that the contents of this book are subject to change without notice. 掲載機種 (Models covered) EX5200 Series BT103 EX5204T-82/223 BT103A EX5204-92M1 BT184 EX5204-82/223,EX5204-82/233 BT220・220A EX5204-82/223,EX5204-82/233 BT250・250A EX5214-83/323,EX5214-84/423 EX5400 Series BT184 EX5404-82/233 EXT5200 Series BT250・250A EXT5214-84/433 EXT5200H Series BT250A EXT5214H-85/535K EXT5100T Series BT104 EXT5104T-02/233N LX5200 Series BT103・184 LX5204-82/233 jintex.in

Page 3 — TABLE OF CONTENTS

目次頁メス・カラ環押ェ・爪駆動機構(2本針) (BT103,103A184,220,220A,250A) ……………… 2~3 爪駆動機構(2本針)・フィルタレギュレータ・電磁弁 (BT220A,250A) ……………………………… 4~5 糸調子機構(1本針) (BT103A) ………………… 6~7 糸調子機構(1本針) (BT220) …………………… 8~9 糸調子機構(1本針) (BT220A) ………………… 10~11 糸調子機構(2本針) (BT250) ………………… 12~13 糸調子機構(2本針) (BT250A) ………………… 14~15 センサーセット・専用部品 (BT103A,220,220A,250,250A) … 16~17 BTコントローラ・ストッパー (BT220,220A,250,250A) … 18~19 糸緩め機構・専用部品 (BT184) ………………… 20~21 クロスプレート・専用部品 (BT104) …………… 22~23 TABLE OF CONTENTS page KNIFE & CLAMP & FINGER DRIVE MECHANISM (2-NEEDLE) (BT103,103A,184,220,220A,250A) 2~3 FINGER DRIVE MECHANISM (2-NEEDLE) & FILTER/REGULATOR & SOLENOID VALVE (BT220A,250A) 4~5 THREAD TENSION MECHANISM (1-NEEDLE) (BT103A) 6~7 THREAD TENSION MECHANISM (1-NEEDLE) (BT220) 8~9 THREAD TENSION MECHANISM (1-NEEDLE) (BT220A) 10~11 THREAD TENSION MECHANISM (2-NEEDLE) (BT250) 12~13 THREAD TENSION MECHANISM (2-NEEDLE) (BT250A) 14~15 SENSOR SET & SPECIFIC PARTS (BT103A,220,220A,250,250A) 16~17 BT CONTROLLER & PIN (BT220,220A,250,250A) 18~19 THREAD RELEASER & SPECIFIC PARTS (BT184) 20~21 CLOTH PLATE & SPECIFIC PARTS (BT104) 22~23 jintex.in

Page 4

1 BT103(EX5200,LX5200) BT103A(EX5200) BT184(EX5200,EX5400,LX5200) BT220,220A(EX5200) 9 8 付属品に梱入 Packd in accessory 12 3 5 2 7 6 12 4 10 11 13 BT250(EX5200,EXT5200) BT250A(EX5200,EXT5200H) 9 8 付属品に梱入 Packd in accessory 12 3 5 14 7 6 12 4 10 11 32 27 26 15 BT250(EX5200,EXT5200) 2本針(2-NEEDLE) 18 付属品に梱入 Packd in accessory 19 22 23 29 30 28 17 25 24 16 付属品に梱入 Packd in accessory 31 27 21 20 jintex.in

Page 5 — KNIFE & CLAMP & FINGER DRIVE MECHANISM

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 5
Ref	Part number	Part name
1	308083-91	KNIFE ASSEMBLY
2	308334	KNIFE GUIDE
3	007041	SCREW
4	308332	BRACKET
5	007041	SCREW
6	308088	LATCH
7	007119	SCREW
8	308333	THREAD CHAIN CLAMP
9	005536	SCREW
10	301902	SPRING
11	005605	NUT
12	308490	KNIFE
13	308084-91	KNIFE ASSEMBLY
14	308335	KNIFE GUIDE
15	302059-9U	CHAINING-FINGER DRIVE SET
16	811035	SOLENOID
17	302060-UD	BRACKET
18	005345	SCREW
19	001174	SCREW
20	303896	BRACKET
21	001216	SCREW
22	303897	LEVER
23	002193	SCREW
24	001170	SCREW
25	003091	NUT
26	303899	COVER
27	005142	SCREW
28	301870	HOOK
29	210307	WASHER
30	005604	SCREW
31	742108	RELAY CORD
32	308086	RETRACTABLE FINGER

BT103,103A,184,220,220A,250,250A メス・カラ環押エ・爪駆動機構 REF.NO. PART NO. 1 308083-91 2 308334 3 007041 4 308332 5 007041 6 308088 7 007119 8 308333 9 005536 10 301902 11 005605 12 308490 13 308084-91 14 308335 15 302059-9U 16 811035 17 302060-UD 18 005345 19 001174 20 303896 21 001216 22 303897 23 002193 24 001170 25 003091 26 303899 27 005142 28 301870 29 210307 30 005604 31 742108 32 308086 部品名称メス(組) メス案内板皿ネジ/M3×6 ブラケット皿ネジ/M3×6 ラッチ皿ネジ/M2×5 空環押エ段付ネジ/C4 圧縮バネ丸ナットメスメス(組) メス案内板爪駆動(組) ソレノイドブラケット平ネジ/C5×11 平ネジ/C4×9.5 ブラケット平ネジ/C4×5.5 レバー六角ネジ/C5×8.5 平ネジ/C4×12 六角ナット/C4 カバー平ネジ/C4×7 フック波板座金段付ネジ/C4 中継コード(中爪移動) 可動爪 BT103,103A,184,220,220A,250,250A KNIFE & CLAMP & FINGER DRIVE MECHANISM DESCRIPTION KNIFE ASSEMBLY KNIFE GUIDE SCREW BRACKET SCREW LATCH SCREW THREAD CHAIN CLAMP SCREW SPRING NUT KNIFE KNIFE ASSEMBLY KNIFE GUIDE CHAINING-FINGER DRIVE SET SOLENOID BRACKET SCREW SCREW BRACKET SCREW LEVER SCREW SCREW NUT COVER SCREW HOOK WASHER SCREW RELAY CORD RETRACTABLE FINGER QT. 1 1 2 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 2 2 1 3 1 1 1 1 1 jintex.in

Page 6

EX5200 EXT5200 EXT5200H 16 17 1 BT250A(EX5200,EXT5200,EXT5200H) 2本針(2-NEEDLE) 附属品を梱入 Packed in accessory 12 15 14 13 11 9 10 3 7 5 8 6 2 4 32 BT220A(EX5200) BT250A(EX5200,EXT5200,EXT5200H) 39 41 附属品を梱入 Packed in accessory 34 37 36 38 40 附属品を梱入 Packed in accessory 33 35 18 BT220A(EX5200) 19 BT250A(EX5200,EXT5200,EXT5200H) 22 20 21 BT220A 23 24 30 31 BT250A 24 25 28 27 23 26 25 28 29 jintex.in

Page 7 — FINGER DRIVE MECHANISM & FILTER/REGULATOR & SOLENOID VALVE

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 7
Ref	Part number	Part name
1	308480-91	爪駆動(組)
2	308481	ブラケット
3	513076	エアーシリンダ
4	007029	平ネジ/M5×12
5	601097A	継手
6	527006	スピードコントローラ
7	755043	マークシール
8	755044	マークシール
9	302902	レバー(A)
10	001222	平ネジ C3×4
11	308482-91	レバー(B)
12	002918	平ネジ/C3×8.5
13	202875	座金
14	005142	平ネジ/C4×7
15	004009-1	平ネジ/C5×7.5
16	308086	可動爪
17	308502-D	可動爪
18	562066-91	電磁弁(組)
19	562066A91	電磁弁(組)
20	562065-91	電磁弁
21	601115	継手
22	600100A	チューブ
23	755045	マークシール
24	755046	マークシール
25	601196	継手
26	755043	マークシール
27	755044	マークシール
28	600147	チューブ
29	004920	木ネジ/3.1
30	601107	継手
31	600147	チューブ
32	522007	フィルタレギュレータ(組)
33	522032	フィルタレギュレータ
34	300590	ブラケット
35	601053	継手
36	601049	ホースジョイント
37	608002	ホースクリップ
38	004910	丸木ネジ
39	004304	六角ボルト/M6×16
40	004806	六角ナット/M6
41	210061	座金

BT220A,250A 爪駆動機構・フィルタレギュレータ・電磁弁 REF.NO. PART NO. 部品名称 1 308480-91 爪駆動(組) 2 308481 ブラケット 3 513076 エアーシリンダ 4 007029 平ネジ/M5×12 5 601097A 継手 6 527006 スピードコントローラ 7 755043 マークシール 8 755044 マークシール 9 302902 レバー(A) 10 001222 平ネジ C3×4 11 308482-91 レバー(B) 12 002918 平ネジ/C3×8.5 13 202875 座金 14 005142 平ネジ/C4×7 15 004009-1 平ネジ/C5×7.5 16 308086 可動爪 17 308502-D 可動爪 18 562066-91 電磁弁(組) 19 562066A91 電磁弁(組) 20 562065-91 電磁弁 21 601115 継手 22 600100A チューブ 23 755045 マークシール 24 755046 マークシール 25 601196 継手 26 755043 マークシール 27 755044 マークシール 28 600147 チューブ 29 004920 木ネジ/3.1 30 601107 継手 31 600147 チューブ 32 522007 フィルタレギュレータ(組) 33 522032 フィルタレギュレータ 34 300590 ブラケット 35 601053 継手 36 601049 ホースジョイント 37 608002 ホースクリップ 38 004910 丸木ネジ 39 004304 六角ボルト/M6×16 40 004806 六角ナット/M6 41 210061 座金 BT220A,250A FINGER DRIVE MECHANISM & FILTER/REGULATOR & SOLENOID VALVE DESCRIPTION QT. FINGER DRIVE ASSEMBLY 1 BRACKET 1 AIR CYLINDER 1 SCREW 2 JOINT 1 SPEED CONTROLLER 1 NUMBERED LABEL 1 NUMBERED LABEL 1 LEVER 1 SCREW 2 LEVER (B) 1 SCREW 2 WASHER 2 SCREW 1 SCREW 1 RETRACTABLE FINGER 1 RETRACTABLE FINGER 1 SOLENOID VALVE ASSEMBLY 1 SOLENOID VALVE ASSEMBLY 1 SOLENOID VALVE 1 JOINT 1 TUBE 1 NUMBERED LABEL 1 NUMBERED LABEL 1 JOINT 2 NUMBERED LABEL 1 NUMBERED LABEL 1 TUBE 4 SCREW 2 JOINT 2 TUBE 2 FILTER REGULATOR ASSEMBLY 1 FILTER REGULATOR 1 BRACKET 1 JOINT 1 CONNECTOR 1 HOSE CLIP 1 SCREW 2 BOLT 2 NUT 2 WASHER 2 jintex.in

Page 8

1 BT103A(EX5200) 2 3 4 5 6 9 7 8 10 11 3 ~ 8 13 14 5 6 15 7 8 16 9 5 ~ 8 14 27 26 19 25 24 22 23 21 20 12 10 18 17 2 16 13 附属品に梱入 Packed in accessory jintex.in

Page 9 — THREAD TENSION MECHANISM(1-NEEDLE)

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 9
Ref	Part number	Part name	Qty
1	308094-9U	糸調子(組)	1
2	210529-9U	糸調子(組)	1
3	005082A	調子棒/C5	1
4	208449	フェルト	1
5	210319	調子皿	2
6	208450-UA	受皿	2
7	208448	ラチェット	2
8	208447-UA	調子ナット	2
9	201037	圧縮バネ(強)	1
10	210530-9U	糸調子(組)	1
11	201086	圧縮バネ(中)	1
12	202849	調子台	3
13	254010C9U	糸調子(組)(弱)	1
14	001817-2A	調子棒	1
15	201068	圧縮バネ(弱)	1
16	254010A9U	糸調子(組)(強)	1
17	208449	フェルト	3
18	202849	調子台	3
19	308096	プレート(組)	1
20	308097	糸緩め板	1
21	007149	段付ネジ/M4	2
22	308098	レバー	1
23	007149	段付ネジ/M4	1
24	005105	平ネジ/C3×3	1
25	302852	板バネ	1
26	007007	平ネジ/M3×3	2
27	308099	銘板	1

BT103A 糸調子機構(1本針) REF.NO. PART NO. 1 308094-9U 2 210529-9U 3 005082A 4 208449 5 210319 6 208450-UA 7 208448 8 208447-UA 9 201037 10 210530-9U 11 201086 12 202849 13 254010C9U 14 001817-2A 15 201068 16 254010A9U 17 208449 18 202849 19 308096 20 308097 21 007149 22 308098 23 007149 24 005105 25 302852 26 007007 27 308099 部品名称糸調子(組) 糸調子(組) 調子棒/C5 フェルト調子皿受皿ラチェット調子ナット圧縮バネ(強) 糸調子(組) 圧縮バネ(中) 調子台糸調子(組)(弱) 調子棒圧縮バネ(弱) 糸調子(組)(強) フェルト調子台プレート(組) 糸緩め板段付ネジ/M4 レバー段付ネジ/M4 平ネジ/C3×3 板バネ平ネジ/M3×3 銘板 THREAD TENSION MECHANISM(1-NEEDLE) DESCRIPTION TENSION SPRING ASSEMBLY TENSION SPRING ASSEMBLY SCREW STUD FELT TENSION DISC CUP RATCHET NUT SPRING (HEAVY) TENSION SPRING ASSEMBLY SPRING (MEDIUM) TENSION GUIDE TENSION SPRING ASSEMBLY (LIGHT) SCREW STUD SPRING (LIGHT) TENSION SPRING ASSEMBLY FELT TENSION GUIDE PLATE ASSEMBLY TENSION RELEASE PLATE SCREW LEVER SCREW SCREW FLAT SPRING SCREW NAME PLATE BT103A QT. 1 1 1 1 2 2 2 2 1 1 1 3 1 1 1 1 3 3 1 1 2 1 1 1 1 2 1 jintex.in

Page 10 — BT220(EX5200)

BT220(EX5200) 3 ~ 8 5 ~ 8 14 付属品に梱入 Packed in accessory jintex.in

Page 11 — THREAD TENSION MECHANISM(1-NEEDLE)

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 11
Ref	Part number	Part name	Qty
1	308081-9U	TENSION SPRING ASSEMBLY	1
2	210529-9U	TENSION SPRING ASSEMBLY	1
3	005082A	SCREW STUD	1
4	208449	FELT	1
5	210319	TENSION DISC	2
6	208450-UA	CUP	1
7	208448	RATCHET	1
8	208447-UA	NUT	1
9	201037	SPRING (HEAVY)	1
10	210530-9U	TENSION SPRING ASSEMBLY	2
11	201086	SPRING (MEDIUM)	2
12	202849	TENSION GUIDE	3
13	254010C9U	TENSION SPRING ASSEMBLY (LIGHT)	1
14	001817-2A	SCREW STUD	1
15	201068	SPRING (LIGHT)	1
16	254010A9U	TENSION SPRING ASSEMBLY (HEAVY)	2
17	208449	FELT	3
18	202849	TENSION GUIDE	3
19	302848A91	PLATE ASSEMBLY	1
20	302849	TENSION RELEASE PLATE	1
21	007149	SCREW	2
22	302854-91	LEVER	1
23	005548	SCREW	1
24	302856	LEVER	1
25	007149	SCREW	1
26	005105	SCREW	1
27	811070-91	SOLENOID ASSEMBLY	1
28	302851	BRACKET	1
29	007018A	SCREW	3
30	302853	LEVER	1
31	004524	BOLT	1
32	748005	NYLON GRIP	1
33	007018A	SCREW	1
34	302852	FLAT SPRING	2
35	007007	SCREW	2
36	742096	RELAY CORD (SOLENOID)	1
37	302857	THREAD GUIDE LABEL	1
38	308422	SAFETY COVER	1
39	007018A	SCREW	3

BT220 糸調子機構(1本針) REF.NO. PART NO. 1 308081-9U 2 210529-9U 3 005082A 4 208449 5 210319 6 208450-UA 7 208448 8 208447-UA 9 201037 10 210530-9U 11 201086 12 202849 13 254010C9U 14 001817-2A 15 201068 16 254010A9U 17 208449 18 202849 19 302848A91 20 302849 21 007149 22 302854-91 23 005548 24 302856 25 007149 26 005105 27 811070-91 28 302851 29 007018A 30 302853 31 004524 32 748005 33 007018A 34 302852 35 007007 36 742096 37 302857 38 308422 39 007018A 部品名称糸調子(組) 糸調子(組) 調子棒/C5 フェルト調子皿受皿ラチェット調子ナット圧縮バネ(強) 糸調子(組) 圧縮バネ(中) 調子台糸調子(組)(弱) 調子棒圧縮バネ(弱) 糸調子(組)(強) フェルト調子台プレート(組) 糸緩め板段付ネジ/M4 レバー段付ネジ/C4 レバー段付ネジ/M4 平ネジ/C3×3 ソレノイド(組) ブラケット平ネジ/M4×6 レバー六角ボルト/M4×10 ナイロングリップ平ネジ/M4×6 板バネ平ネジ/M3×3 中継コード(ソレノイド) 糸調子ラベル安全カバー平ネジ/M4×6 BT220 THREAD TENSION MECHANISM(1-NEEDLE) DESCRIPTION QT. TENSION SPRING ASSEMBLY TENSION SPRING ASSEMBLY SCREW STUD FELT TENSION DISC CUP RATCHET NUT SPRING (HEAVY) TENSION SPRING ASSEMBLY SPRING (MEDIUM) TENSION GUIDE TENSION SPRING ASSEMBLY (LIGHT) SCREW STUD SPRING (LIGHT) TENSION SPRING ASSEMBLY (HEAVY) FELT TENSION GUIDE PLATE ASSEMBLY TENSION RELEASE PLATE SCREW LEVER SCREW LEVER SCREW SCREW SOLENOID ASSEMBLY BRACKET SCREW LEVER BOLT NYLON GRIP SCREW FLAT SPRING SCREW RELAY CORD (SOLENOID) THREAD GUIDE LABEL SAFETY COVER SCREW 1 1 1 1 2 1 1 1 1 2 2 3 1 1 1 2 3 3 1 1 2 1 1 1 1 1 1 1 3 1 1 1 1 2 1 1 1 3 jintex.in

Page 12

1 BT220A(EX5200) 2 3 4 5 6 7 8 9 10 11 3 ~ 8 13 14 5 6 15 7 8 16 9 5 ~ 8 14 27 29 24 30 26 28 19 25 22 32 31 23 21 20 12 10 付属品に梱入 Packed in accessory 18 17 2 16 13 jintex.in

Page 13 — THREAD TENSION MECHANISM(1-NEEDLE)

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 13
Ref	Part number	Part name	Qty
1	308484-9U	THREAD TENSION ASSEMBLY	1
2	210529-9U	TENSION SPRING ASSEMBLY	1
3	005082A	SCREW STUD	1
4	208449	FELT	1
5	210319	TENSION DISC	2
6	208450-UA	CUP	1
7	208448	RATCHET	1
8	208447-UA	NUT	1
9	201037	SPRING (HEAVY)	1
10	210530-9U	TENSION SPRING ASSEMBLY	2
11	201086	SPRING (MEDIUM)	1
12	202849	TENSION GUIDE	3
13	254010C9U	TENSION SPRING ASSEMBLY (LIGHT)	1
14	001817-2A	SCREW STUD	1
15	201068	SPRING (LIGHT)	1
16	254010A9U	TENSION SPRING ASSEMBLY (HEAVY)	2
17	208449	FELT	3
18	202849	TENSION GUIDE	3
19	302848A91	PLATE ASSEMBLY	1
20	302849	TENSION RELEASE PLATE	1
21	007149	SCREW	2
22	308521	LABEL	1
23	513126	AIR CYLINDER	1
24	308485	BRACKET	1
25	007018A	SCREW	2
26	601097A	JOINT	1
27	755046	NUMBERED LABEL	1
28	527006	SPEED CONTROLLER	1
29	755045	NUMBERED LABEL	1
30	308486	KNUCKLE	1
31	308487-91	LEVER	1
32	005548	SCREW	1

BT220A 糸調子機構(1本針) REF.NO. PART NO. 1 308484-9U 2 210529-9U 3 005082A 4 208449 5 210319 6 208450-UA 7 208448 8 208447-UA 9 201037 10 210530-9U 11 201086 12 202849 13 254010C9U 14 001817-2A 15 201068 16 254010A9U 17 208449 18 202849 19 302848A91 20 302849 21 007149 22 308521 23 513126 24 308485 25 007018A 26 601097A 27 755046 28 527006 29 755045 30 308486 31 308487-91 32 005548 部品名称糸調子器(組) 糸調子(組) 調子棒/C5 フェルト調子皿受皿ラチェット調子ナット圧縮バネ(強) 糸調子(組) 圧縮バネ(中) 調子台糸調子(組)(弱) 調子棒圧縮バネ(弱) 糸調子(組)(強) フェルト調子台プレート(組) 糸緩め板段付ネジ/M4 糸調子ラベルエアシリンダブラケット平ネジ/M4×6 継手マークシールスピードコントローラマークシールナックルレバー段付ネジ/C4 BT220A THREAD TENSION MECHANISM(1-NEEDLE) DESCRIPTION THREAD TENSION ASSEMBLY TENSION SPRING ASSEMBLY SCREW STUD FELT TENSION DISC CUP RATCHET NUT SPRING (HEAVY) TENSION SPRING ASSEMBLY SPRING (MEDIUM) TENSION GUIDE TENSION SPRING ASSEMBLY (LIGHT) SCREW STUD SPRING (LIGHT) TENSION SPRING ASSEMBLY (HEAVY) FELT TENSION GUIDE PLATE ASSEMBLY TENSION RELEASE PLATE SCREW LABEL AIR CYLINDER BRACKET SCREW JOINT NUMBERED LABEL SPEED CONTROLLER NUMBERED LABEL KNUCKLE LEVER SCREW QT. 1 1 1 1 2 1 1 1 1 2 1 3 1 1 1 2 3 3 1 1 2 1 1 1 2 1 1 1 1 1 1 1 jintex.in

Page 14

1 BT250(EX5200,EXT5200) 2 3 4 5 6 9 7 8 10 11 3 ~ 8 12 13 3 ~ 8 15 16 5 6 11 7 8 17 9 5 ~ 8 16 34 26 27 25 33 29 31 32 20 30 38 24 36 35 23 28 40 21 22 39 40 14 10 12 附属品に梱入 Packed in accessory 19 18 37 9 2 17 15 jintex.in

Page 15 — THREAD TENSION MECHANISM(2-NEEDLE)

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 15
Ref	Part number	Part name	Qty
1	308081A9U	TENSION SPRING ASSEMBLY	1
2	210529-9U	TENSION SPRING ASSEMBLY	2
3	005082A	SCREW STUD	1
4	208449	FELT	1
5	210319	TENSION DISC	2
6	208450-UA	CUP	1
7	208448	SPRING BUSHING	1
8	208447-UA	NUT	1
9	201037	SPRING (HEAVY)	1
10	210531-9U	TENSION SPRING ASSEMBLY	1
11	201068	SPRING (LIGHT)	1
12	210530A9U	TENSION SPRING ASSEMBLY	1
13	201086A	SPRING (MEDIUM)	1
14	202849	TENSION GUIDE	4
15	254010C9U	TENSION SPRING ASSEMBLY (LIGHT)	2
16	001817-2A	SCREW STUD	1
17	254010A9U	TENSION SPRING ASSEMBLY (HEAVY)	2
18	208449	FELT	4
19	202849	TENSION GUIDE	4
20	302848A91	PLATE ASSEMBLY	1
21	302849	TENSION RELEASE PLATE	1
22	007149	SCREW	2
23	302854-91	LEVER	1
24	005548	SCREW	1
25	302856	LEVER	1
26	007149	SCREW	1
27	005105	SCREW	1
28	811070-91	SOLENOID ASSEMBLY	1
29	302851	BRACKET	1
30	007018A	SCREW	3
31	302853	LEVER	1
32	004524	BOLT	1
33	748005	NYLON GRIP	1
34	007018A	SCREW	1
35	302852	FLAT SPRING	1
36	007007	SCREW	2
37	742096	RELAY CORD (SOLENOID)	1
38	302857	THREAD GUIDE LABEL	1
39	308422	SAFETY COVER	1
40	007018A	SCREW	3

BT250 糸調子機構(2本針) REF.NO. PART NO. 1 308081A9U 2 210529-9U 3 005082A 4 208449 5 210319 6 208450-UA 7 208448 8 208447-UA 9 201037 10 210531-9U 11 201068 12 210530A9U 13 201086A 14 202849 15 254010C9U 16 001817-2A 17 254010A9U 18 208449 19 202849 20 302848A91 21 302849 22 007149 23 302854-91 24 005548 25 302856 26 007149 27 005105 28 811070-91 29 302851 30 007018A 31 302853 32 004524 33 748005 34 007018A 35 302852 36 007007 37 742096 38 302857 39 308422 40 007018A 部品名称糸調子(組) 糸調子(組) 調子棒/C5 フェルト調子皿受皿ラチェット調子ナット圧縮バネ(強) 糸調子(組) 圧縮バネ(弱) 糸調子(組) 圧縮バネ(中) 調子台糸調子(組)(弱) 調子棒糸調子(組)(強) フェルト調子台プレート(組) 糸緩め板段付ネジ/M4 レバー段付ネジ/C4 レバー段付ネジ/M4 平ネジ/C3×3 ソレノイド(組) ブラケット平ネジ/M4×6 レバー六角穴ボルト/M4×10 ナイロングリップ平ネジ/M4×6 板バネ平ネジ/M3×3 中継コード(ソレノイド) 糸調子ラベル安全カバー平ネジ/M4×6 BT250 THREAD TENSION MECHANISM(2-NEEDLE) DESCRIPTION QT. TENSION SPRING ASSEMBLY TENSION SPRING ASSEMBLY SCREW STUD FELT TENSION DISC CUP SPRING BUSHING NUT SPRING (HEAVY) TENSION SPRING ASSEMBLY SPRING (LIGHT) TENSION SPRING ASSEMBLY SPRING (MEDIUM) TENSION GUIDE TENSION SPRING ASSEMBLY (LIGHT) SCREW STUD TENSION SPRING ASSEMBLY (HEAVY) FELT TENSION GUIDE PLATE ASSEMBLY TENSION RELEASE PLATE SCREW LEVER SCREW LEVER SCREW SCREW SOLENOID ASSEMBLY BRACKET SCREW LEVER BOLT NYLON GRIP SCREW FLAT SPRING SCREW RELAY CORD (SOLENOID) THREAD GUIDE LABEL SAFETY COVER SCREW 1 2 1 1 2 1 1 1 1 1 1 1 1 4 2 1 2 4 4 1 1 2 1 1 1 1 1 1 1 3 1 1 1 1 1 2 1 1 1 3 jintex.in

Page 16

1 BT250A(EX5200,EXT5200) 2 BT250A(EXT5200H) 3 4 5 6 7 8 9 10 11 12 4 ~ 10 13 14 4 ~ 10 16 17 6 7 12 9 10 18 8 6 ~ 10 · 17 29 28 31 30 26 32 34 33 21 27 24 25 23 22 15 11 13 EX(T) Series 3 EXT5200H Series 附属品に梱入 Packed in accessory 20 19 18 16 3 jintex.in

Page 17 — THREAD TENSION MECHANISM(2-NEEDLE)

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 17
Ref	Part number	Part name
1	308484A9U	THREAD TENSION ASSEMBLY
2	308484B9U	THREAD TENSION ASSEMBLY
3	210529-9U	TENSION SPRING ASSEMBLY
4	005082A	SCREW STUD
5	208449	FELT
6	210319	TENSION DISC
7	208450-UA	CUP
8	201037	SPRING (HEAVY)
9	208448	RATCHET
10	208447-UA	NUT
11	210531-9U	TENSION SPRING ASSEMBLY
12	201068	SPRING (LIGHT)
13	210530A9U	TENSION SPRING ASSEMBLY
14	201086A	SPRING (MEDIUM)
15	202849	TENSION GUIDE
16	254010C9U	TENSION SPRING ASSEMBLY (LIGHT)
17	001817-2A	SCREW STUD
18	254010A9U	TENSION SPRING ASSEMBLY (HEAVY)
19	208449	FELT
20	202849	TENSION GUIDE
21	302848A91	PLATE ASSEMBLY
22	302849	TENSION RELEASE PLATE
23	007149	SCREW
24	308521	LABEL
25	513126	AIR CYLINDER
26	308485	BRACKET
27	007018A	SCREW
28	601097A	JOINT
29	755046	NUMBERED LABEL
30	527006	SPEED CONTROLLER
31	755045	NUMBERED LABEL
32	308486	KNUCKLE
33	308487-91	LEVER
34	005548	SCREW

BT250A 糸調子機構(2本針) REF.NO. PART NO. 1 308484A9U 2 308484B9U 3 210529-9U 4 005082A 5 208449 6 210319 7 208450-UA 8 201037 9 208448 10 208447-UA 11 210531-9U 12 201068 13 210530A9U 14 201086A 15 202849 16 254010C9U 17 001817-2A 18 254010A9U 19 208449 20 202849 21 302848A91 22 302849 23 007149 24 308521 25 513126 26 308485 27 007018A 28 601097A 29 755046 30 527006 31 755045 32 308486 33 308487-91 34 005548 部品名称糸調子器(組) 糸調子器(組) 糸調子(組) 調子棒/C5 フェルト調子皿受皿圧縮バネ(強) ラチェット調子ナット糸調子(組) 圧縮バネ(弱) 糸調子(組) 圧縮バネ(中) 調子台糸調子(組)(弱) 調子棒糸調子(組)(強) フェルト調子台プレート(組) 糸緩め板段付ネジ/M4 糸調子ラベルエアーシリンダブラケット平ネジ/M4×6 継手マークシールスピードコントローラマークシールナックルレバー段付ネジ/C4 BT250A THREAD TENSION MECHANISM(2-NEEDLE) DESCRIPTION THREAD TENSION ASSEMBLY THREAD TENSION ASSEMBLY TENSION SPRING ASSEMBLY SCREW STUD FELT TENSION DISC CUP SPRING (HEAVY) RATCHET NUT TENSION SPRING ASSEMBLY SPRING (LIGHT) TENSION SPRING ASSEMBLY SPRING (MEDIUM) TENSION GUIDE TENSION SPRING ASSEMBLY (LIGHT) SCREW STUD TENSION SPRING ASSEMBLY (HEAVY) FELT TENSION GUIDE PLATE ASSEMBLY TENSION RELEASE PLATE SCREW LABEL AIR CYLINDER BRACKET SCREW JOINT NUMBERED LABEL SPEED CONTROLLER NUMBERED LABEL KNUCKLE LEVER SCREW QT. 1 1 1 1 1 2 1 1 1 1 1 1 1 1 4 2 1 2 4 4 1 1 2 1 1 1 2 1 1 1 1 1 1 1 jintex.in

Page 18

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 18
Ref	Part number	Part name	Qty
16 17 18	EX5204-82/223
19 20 21	EX5204-82/233

1 BT220,220A(EX5200) BT250(EX5200,EXT5200) BT250A(EX5200,EXT5200,EXT5200H) 4 5 7 8 3 14 2 9 15 6 10 11 12 13 BT220,220A(EX5200) 16 17 18 EX5204-82/223 19 20 21 EX5204-82/233 22 23 BT103A,220,220A(EX5200) BT250(EX5200,EXT5200) BT250A(EX5200,EXT5200,EXT5200H) 26 30 32 31 28 25 24 27 29 jintex.in

Page 19 — BT103A,220,220A,250,250A SENSOR SET & SPECIFIC PARTS

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 19
Ref	Part number	Part name
1	308018-91	SENSOR SET
2	712011B91	CLOTH EDGE DETECTING SENSOR
3	007162	SCREW
4	308043	BRACKET
5	007018A	SCREW
6	007156	SCREW
7	748005	NYLON GRIP
8	007018A	SCREW
9	742294-91	RELAY CORD
10	716007	ROTATION DETECTOR
11	007018A	SCREW
12	748005	NYLON GRIP
13	007018A	SCREW
14	742095	RELAY CORD (ROTATION DETECTOR)
15	748002	BAND
16	277528-30	NEEDLE PLATE
17	277528-40	NEEDLE PLATE
18	277528-50	NEEDLE PLATE
19	277529-30	NEEDLE PLATE
20	277529-40	NEEDLE PLATE
21	277529-50	NEEDLE PLATE
22	270037D	CLOTH PLATE (NARROW)
23	270505B	FAN
24	350188A	SPACER
25	007072	SCREW
26	308177-91	WASTE CHUTE SET
27	276002AUA	WASTE CHUTE TOP
28	004904	SCREW
29	276003-UA	WASTE CHUTE EXTENSION
30	276004	BRACKET
31	004109	SCREW
32	240104	WASHER

BT103A,220,220A,250,250A センサーセット・専用部品 REF.NO. PART NO. 1 308018-91 センサ(セット) 2 712011B91 生地端センサー 3 007162 平ネジ/M3.5×10 4 308043 ブラケット 5 007018A 平ネジ/M4×6 6 007156 平ネジ/M2.5×3.4 7 748005 ナイロンクリップ 8 007018A 平ネジ/M4×6 9 742294-91 中継コード 10 716007 回転検出器 11 007018A 平ネジ/M4×6 12 748005 ナイロンクリップ 13 007018A 平ネジ/M4×6 14 742095 中継コード(回転検出) 15 748002 束線バンド 16 277528-30 針板 17 277528-40 針板 18 277528-50 針板 19 277529-30 針板 20 277529-40 針板 21 277529-50 針板 22 270037D クロスプレート(狭巾) 23 270505B ファン 24 350188A スペーサー 25 007072 平ネジ/M4×35 26 308177-91 切屑受(組) 27 276002AUA シュータ(上) 28 004904 木ネジ/3.5 29 276003-UA シュータ(下) 30 276004 取付板 31 004109 平ネジ/M4×10 32 240104 座金 BT103A,220,220A,250,250A SENSOR SET & SPECIFIC PARTS DESCRIPTION QT. SENSOR SET 1 CLOTH EDGE DETECTING SENSOR 1 SCREW 2 BRACKET 1 SCREW 2 SCREW 2 NYLON GRIP 2 SCREW 2 RELAY CORD 1 ROTATION DETECTOR 1 SCREW 2 NYLON GRIP 2 SCREW 2 RELAY CORD (ROTATION DETECTOR) 1 BAND 2 NEEDLE PLATE 1 NEEDLE PLATE 1 NEEDLE PLATE 1 NEEDLE PLATE 1 NEEDLE PLATE 1 NEEDLE PLATE 1 CLOTH PLATE (NARROW) 1 FAN 1 SPACER 2 SCREW 2 WASTE CHUTE SET 1 WASTE CHUTE TOP 1 SCREW 3 WASTE CHUTE EXTENSION 1 BRACKET 1 SCREW 2 WASHER 2 jintex.in

Page 20 — BT220,220A(EX5200) BT250(EX5200,EXT5200) BT250A(EX5200,EXT5200,EXT5200T)

BT220,220A(EX5200) BT250(EX5200,EXT5200) BT250A(EX5200,EXT5200,EXT5200T) 1 100~240V 2 ヨーロッパ向仕様 220V Specification for Europe ヨーロッパ向仕様 Specification for Europe 19 20 1 3~7 20 2 3 4 8~11 19 付属品に梱入 Packed in accessory 4 5 6 7 11 8 9 10 付属品に梱入 Packed in accessory 12 AC100V 13 AC200V 14 AC220V 15 AC240V 17 18 16 jintex.in

Page 21 — BT220,220A,250,250A BT CONTROLLER & PIN

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 21
Ref	Part number	Part name	Qty
1	760168-9J	BT CONTROLLER	1
2	760168A9J	BT CONTROLLER	1
3	9A3068	ELECTRIC CAUTION LABEL	1
4	303500	BRACKET ASSEMBLY	1
5	748045	CABLE STOPPER	3
6	004920	SCREW	4
7	748042	BAND	6
8	748045	CABLE STOPPER	4
9	748002	BAND	2
10	748004	BAND	3
11	771003	FUSE (1A)	1
12	742257A91	POWER SOURCE CORD	1
13	742257-91	POWER SOURCE CORD	1
14	742257B91	POWER SOURCE CORD	1
15	742257C91	POWER SOURCE CORD	1
16	308243-91	PIN ASSEMBLY	1
17	308244	PIN	1
18	208949	O RING	2
19	9A3053	INDICATION LABEL	1
20	302511	INDICATION PLATE	1

BT220,220A,250,250A BTコントローラ・ストッパー REF.NO. PART NO. 1 760168-9J 2 760168A9J 3 9A3068 4 303500 5 748045 6 004920 7 748042 8 748045 9 748002 10 748004 11 771003 12 742257A91 13 742257-91 14 742257B91 15 742257C91 16 308243-91 17 308244 18 208949 19 9A3053 20 302511 部品名称 BTコントローラ BTコントローラ感電注意ラベルブラケット(組) ケーブルストッパー木ネジ/3.1 束線バンドケーブルストッパー束線バンドビーズバンドヒューズ(1A) 電源コード(AC100V) 電源コード(AC200V) 電源コード(AC220V) 電源コード(AC240V) 段付ピン(組) 段付ピン Oリング表示シールコネクタ表示板 BT220,220A,250,250A BT CONTROLLER & PIN DESCRIPTION BT CONTROLLER BT CONTROLLER ELECTRIC CAUTION LABEL BRACKET ASSEMBLY CABLE STOPPER SCREW BAND CABLE STOPPER BAND BAND FUSE (1A) POWER SOURCE CORD POWER SOURCE CORD POWER SOURCE CORD POWER SOURCE CORD PIN ASSEMBLY PIN O RING INDICATION LABEL INDICATION PLATE QT. 1 1 1 1 3 4 6 4 2 3 1 1 1 1 1 1 1 2 1 1

Page 22 — BT184(EX5200,EX5400,LX5200)

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 22
Ref	Part number	Part name	Qty
22	SM=3mm	SM=3mm
23	SM=4mm・5mm	SM=4mm・5mm

BT184(EX5200,EX5400,LX5200) 1 8 21 LX5200 Series 10 10 11 9 12 7 3 6 19 20 14 18 15 17 16 13 2 4 5 BT184専用部品 BT184 Specific parts 22 SM=3mm 23 SM=4mm・5mm jintex.in

Page 23 — BT184 THREAD RELEASER MECHANISM & SPECIFIC PARTS

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 23
Ref	Part number	Part name	Qty
1	308567-91	糸緩め(組)	1
2	304305	ブラケット	1
3	005117	平ネジ/C5×8.5	1
4	304306	ブレード	1
5	007193	段付ネジ	1
6	304307	ブラケット	1
7	004832	六角ナット	1
8	212435	ケーブル	1
9	240570	圧縮バネ	1
10	212436	ケーブル受ケ	2
11	004806	六角ナット/M6	1
12	275523	ブラケット	1
13	007022	平ネジ/M4×14	2
14	275522	ラッチ	1
15	007164	段付ネジ/M4	1
16	179765-15	ナット/M4	1
17	240104	座金	1
18	007099	段付ネジ/M6	1
19	004806	六角ナット/M6	1
20	202433	座金	1
21	200098	座金	1
22	277116	押工爪	1
23	277109	押工爪	1

BT184 糸緩め機構・専用部品 REF.NO. PART NO. 部品名称 1 308567-91 糸緩め(組) 2 304305 ブラケット 3 005117 平ネジ/C5×8.5 4 304306 ブレード 5 007193 段付ネジ 6 304307 ブラケット 7 004832 六角ナット 8 212435 ケーブル 9 240570 圧縮バネ 10 212436 ケーブル受ケ 11 004806 六角ナット/M6 12 275523 ブラケット 13 007022 平ネジ/M4×14 14 275522 ラッチ 15 007164 段付ネジ/M4 16 179765-15 ナット/M4 17 240104 座金 18 007099 段付ネジ/M6 19 004806 六角ナット/M6 20 202433 座金 21 200098 座金 22 277116 押工爪 23 277109 押工爪 BT184 THREAD RELEASER MECHANISM & SPECIFIC PARTS DESCRIPTION QT. THREAD RELEASER ASSEMBLY 1 BRACKET 1 SCREW 1 BLADE 1 SCREW 1 BRACKET 1 NUT 1 CABLE 1 SPRING 1 CABLE SUPPORT 2 NUT 1 BRACKET 1 SCREW 2 LATCH 1 SCREW 1 NUT 1 WASHER 1 SCREW 1 NUT 1 WASHER 1 WASHER 1 PRESSER FOOT FINGER 1 PRESSER FOOT FINGER 1 jintex.in

Page 24 — BT104(EXT5100T)

BT104(EXT5100T) 1 附属品に梱入 Packed in accessory 2 21 20 14 19 13 8 12 11 17 15 16 9 6 7 18 3 10 22 4 23 5 24 15 25 26 29 28 27 31 30 jintex.in

Page 25 — CLOTH PLATE & SPECIFIC PARTS

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 25
Ref	Part number	Part name	Qty
1	308563-91	クロスプレート (組)	1
2	270170B91	クロスプレート	1
3	204218	板バネ	1
4	200162A	座金	1
5	005053	平ネジ/C4×4.8	2
6	005121A	六角ネジ/C4×16	1
7	003091	六角ナット/C4	1
8	270173	ブラケット	1
9	204888	皿バネ	2
10	004808	六角ナット/M8	2
11	007022A	平ネジ/M4×14	2
12	303448	座金	2
13	308564	メス案内板	1
14	007008	平ネジ/M3×4	2
15	308490	メス	1
16	308088	ラッチ	1
17	007119	皿ネジ/M2×5	1
18	308332B	ブラケット	1
19	007041	皿ネジ/M3×6	2
20	308333AD	空環押エ	1
21	005536	段付ネジ/C4	1
22	301902	圧縮バネ	1
23	005605	丸ナット	1
24	308565-91	ブラケット	1
25	007008	平ネジ/M3×4	2
26	277589-30	針板	1
27	277408B16F	主送り歯 (組)	1
28	277403A16F	主送り歯	1
29	213103-16	補助送り歯	1
30	005492	平ネジ/C1×6	1
31	277404A16F	差動送り歯	1

クロスプレート・専用部品 CLOTH PLATE & SPECIFIC PARTS REF.NO. PART NO. 部品名称 DESCRIPTION QT. 1 308563-91 クロスプレート (組) CLOTH PLATE ASSEMBLY 1 2 270170B91 クロスプレート CLOTH PLATE 1 3 204218 板バネ FLAT SPRING 1 4 200162A 座金 WASHER 1 5 005053 平ネジ/C4×4.8 SCREW 2 6 005121A 六角ネジ/C4×16 SCREW 1 7 003091 六角ナット/C4 NUT 1 8 270173 ブラケット BRACKET 1 9 204888 皿バネ SPRING WASHER 2 10 004808 六角ナット/M8 NUT 2 11 007022A 平ネジ/M4×14 SCREW 2 12 303448 座金 WASHER 2 13 308564 メス案内板 KNIFE GUIDE ASSEMBLY 1 14 007008 平ネジ/M3×4 SCREW 2 15 308490 メス KNIFE 1 16 308088 ラッチ LATCH 1 17 007119 皿ネジ/M2×5 SCREW 1 18 308332B ブラケット BRACKET 1 19 007041 皿ネジ/M3×6 SCREW 2 20 308333AD 空環押エ THREAD CHAIN CLAMP 1 21 005536 段付ネジ/C4 SCREW 1 22 301902 圧縮バネ SPRING 1 23 005605 丸ナット NUT 1 24 308565-91 ブラケット BRACKET 1 25 007008 平ネジ/M3×4 SCREW 2 26 277589-30 針板 PRESSER FOOT 1 27 277408B16F 主送り歯 (組) MAIN FEED DOG ASSEMBLY 1 28 277403A16F 主送り歯 MAIN FEED DOG 1 29 213103-16 補助送り歯 AUXILIARY FEED DOG 1 30 005492 平ネジ/C1×6 SCREW 1 31 277404A16F 差動送り歯 DIFFERENTIAL FEED DOG 1 jintex.in

Page 26 — INDEX

Pegasus BT Series Backlatcher (EX, EXT, LX) parts on page 26
Ref	Part number	Part name	Qty
24	001170
19	001174
21	001216
10	001222
14	001817-2A
14	001817-2A
14	001817-2A
16	001817-2A
17	001817-2A
23	002193
12	002918
25	003091
7	003091
15	004009-1
31	004109
39	004304
31	004524
32	004524
40	004806
11	004806
19	004806
10	004832
7	004832
28	004904
38	004910
29	004920
6	004920
5	005053
3	005082A
3	005082A
3	005082A
3	005082A
4	005082A
24	005105
26	005105
27	005105
3	005117
6	005121A
27	005142
14	005142
18	005345
30	005492
9	005536
21	005536
23	005548
23	005548
32	005548
24	005548
34	005548
30	005604
11	005605
23	005605
26	007007
35	007007
36	007007
14	007008
25	007008
29	007018A
33	007018A
39	007018A
25	007018A
30	007018A
34	007018A
40	007018A
27	007018A
5	007018A
8	007018A
11	007018A
13	007018A
13	007022
11	007022A
4	007029
5	007041
19	007041
25	007072
25	007072
18	007099
7	007119
17	007119
21	007149
23	007149
21	007149
25	007149
21	007149
22	007149
26	007149
23	007149
6	007156
3	007162
15	007164
5	007193
16	179765-15
21	200098
4	200162A
9	201037
9	201037
9	201037
9	201037
8	201037
15	201068
15	201068
15	201068
14	201068
12	201068
11	201086
11	201086
11	201086
13	201086
14	201086A
20	202433
12	202849
18	202849
12	202849
18	202849
18	202849
18	202849
14	202849
19	202849
15	202849
20	202849
13	202875
3	204218
9	204888
8	208447-UA
8	208447-UA
10	208447-UA
10	208447-UA
10	208447-UA
7	208448
7	208448
7	208448
7	208448
7	208448
4	208449
17	208449
17	208449
17	208449
17	208449
23	208449
16	208450-UA
16	208450-UA
16	208450-UA
16	208450-UA
18	208450-UA
14	208450-UA
4	208949
21	210061
29	210307
5	210319
5	210319
5	210319
5	210319
5	210319
2	210529-9U
2	210529-9U
2	210529-9U
2	210529-9U
2	210529-9U
10	210530-9U
10	210530-9U
10	210530-9U
10	210530A9U
10	210530A9U
11	210531-9U
8	212435
10	212436
29	213103-16
32	240104
17	240104
9	240570
16	254010A9U
16	254010A9U
16	254010A9U
17	254010A9U
18	254010A9U
13	254010C9U
13	254010C9U
15	254010C9U
16	254010C9U
2	270170B91
8	270173
23	270505B
14	275522
12	275523
27	276002AUA
29	276003-UA
30	276004
23	277109
22	277116
28	277403A16F
31	277404A16F
27	277408B16F
16	277528-30
17	277528-40
18	277528-50
19	277529-30
20	277529-40
21	277529-50
26	277589-30
34	300590
28	301870
10	301902
15	302059-9U
17	302060-UD
20	302511
19	302848A91
19	302848A91
20	302848A91
20	302849
20	302849
21	302849
22	302849
28	302851
29	302851
25	302852
34	302852
35	302852
30	302853
31	302853
22	302854-91
23	302854-91
24	302856
25	302856
37	302857
38	302857
9	302902
12	303448
4	303500
20	303896
22	303897
26	303899
2	304305
4	304306
6	304307
1	308018-91
4	308043
1	308081-9U
1	308083-91
13	308084-91
16	308086
6	308086
16	308086
1	308094-9U
19	308096
20	308097
22	308098
27	308099
26	308177-91
16	308243-91
17	308244
4	308332
18	308332B
8	308333
20	308333AD
2	308334
14	308335
39	308422
1	308480-91
2	308481
11	308482-91
1	308484-9U
1	308484A9U
2	308484B9U
24	308485
26	308485
30	308486
32	308486
31	308487-91
12	308490
15	308490
17	308502-D
22	308521
24	308521
1	308563-91
13	308564
24	308565-91
1	308567-91
24	350188A
3	513076
23	513126
25	513126
32	522007
33	522032
6	527006
28	527006
30	527006
20	562065-91
18	562066-91
19	562066A91
22	600100A
28	600147
31	600147
36	601049
35	601053
5	601097A
26	601097A
28	601097A
30	601107
21	601115
25	601196
37	608002
2	712011B91
10	716007
11	716007
36	742095
37	742096
31	742096
13	742108
12	742257-91
14	742257B91
15	742257C91
9	742294-91
5	748002
32	748004
33	748005
7	748005
9	748005
10	748005
7	748042
5	748045
8	748045
7	755043
26	755044
8	755044
27	755045
29	755045
31	755045
24	755046
27	755046
29	755046
1	760168-9J
2	760168A9J
11	771003
16	811035
27	811070-91
28	811070-91
19	9A3053
3	9A3068

インデックス INDEX PART NO. PAGE REF. NO. PART NO. PAGE REF. NO. PART NO. PAGE REF. NO. PART NO. PAGE REF. NO. 001170 3 24 179765-15 21 16 254010C9U 11 13 308484-9U 11 1 001174 3 19 200098 21 21 254010C9U 13 15 308484A9U 15 1 001216 3 21 200162A 23 4 254010C9U 15 16 308484B9U 15 2 001222 5 10 201037 7 9 270170B91 23 2 308485 11 24 001817-2A 7 14 201037 9 9 270173 23 8 308485 15 26 001817-2A 9 14 201037 11 9 270505B 17 23 308486 11 30 001817-2A 11 14 201037 13 9 275522 21 14 308486 15 32 001817-2A 13 16 201037 15 8 275523 21 12 308487-91 11 31 001817-2A 15 17 201068 7 15 276002AUA 17 27 308490 3 12 002193 3 23 201068 9 15 276003-UA 17 29 308490 23 15 002918 5 12 201068 11 15 276004 17 30 308502-D 5 17 003091 3 25 201068 13 14 277109 21 23 308521 11 22 003091 23 7 201068 15 12 277116 21 22 308521 15 24 004009-1 5 15 201086 7 11 277403A16F 23 28 308563-91 23 1 004109 17 31 201086 9 11 277404A16F 23 31 308564 23 13 004304 5 39 201086 11 11 277408B16F 23 27 308565-91 23 24 004524 9 31 201086 13 13 277528-30 17 16 308567-91 21 1 004524 13 32 201086A 15 14 277528-40 17 17 350188A 17 24 004806 5 40 202433 21 20 277528-50 17 18 513076 5 3 004806 21 11 202849 7 12 004806 21 19 202849 7 18 277529-30 17 19 513126 11 23 004832 21 10 202849 9 12 277529-40 17 20 513126 15 25 004832 21 7 202849 9 18 277529-50 17 21 522007 5 32 004904 17 28 202849 11 18 277589-30 23 26 522032 5 33 004910 5 38 202849 11 18 300590 5 34 527006 5 6 004920 5 29 202849 13 14 301870 3 28 527006 11 28 004920 19 6 202849 13 19 301902 3 10 527006 15 30 005053 23 5 202849 15 15 302059-9U 3 15 562065-91 5 20 005082A 7 3 202849 15 20 302060-UD 3 17 562066-91 5 18 005082A 9 3 202875 5 13 562066A91 5 19 005082A 11 3 204218 23 3 302511 19 20 600100A 5 22 005082A 13 3 204888 23 9 302848A91 9 19 600147 5 28 005082A 15 4 208447-UA 7 8 302848A91 11 19 600147 5 31 005105 7 24 208447-UA 9 8 302848A91 13 20 601049 5 36 005105 9 26 208447-UA 11 10 302849 9 20 601053 5 35 005105 13 27 208447-UA 13 10 302849 11 20 601097A 5 5 005117 21 3 208447-UA 15 10 302849 13 21 601097A 11 26 005121A 23 6 208448 7 7 302849 15 22 601097A 15 28 005142 3 27 208448 9 7 302851 9 28 601107 5 30 005142 5 14 208448 11 7 601115 5 21 005345 3 18 208448 13 7 302851 13 29 601196 5 25 005492 23 30 208448 15 7 302852 7 25 608002 5 37 005536 3 9 208449 7 4 302852 9 34 712011B91 17 2 005536 23 21 208449 9 17 302852 11 35 716007 17 10 005548 7 23 208449 11 17 302852 13 35 716007 17 11 005548 9 23 208449 13 17 302853 9 30 742095 9 36 005548 11 32 208449 15 17 302853 13 31 742096 13 37 005548 13 24 208449 15 23 302854-91 9 22 742096 3 31 005548 15 34 208450-UA 7 16 302854-91 13 23 742108 19 13 005604 3 30 208450-UA 9 16 302856 9 24 742257-91 19 12 005605 3 11 208450-UA 11 16 302856 13 25 005605 23 23 208450-UA 13 16 302857 9 37 742257B91 19 14 007007 7 26 208450-UA 15 16 302857 13 38 742257C91 19 15 007007 9 35 208450-UA 19 18 302902 5 9 742294-91 17 9 007007 13 36 208450-UA 23 14 303448 23 12 748002 17 5 007008 23 25 208949 19 4 303500 19 4 748004 9 32 007018A 9 29 210061 5 21 303896 3 20 748005 13 33 007018A 9 33 210307 3 29 303897 3 22 748005 17 7 007018A 9 39 303899 3 26 748005 19 9 007018A 11 25 304305 21 2 748005 19 10 007018A 13 30 210319 7 5 304306 21 4 748042 19 7 007018A 13 34 210319 9 5 748045 19 5 007018A 13 40 210319 11 5 308018-91 17 1 748045 19 8 007018A 15 27 210319 13 5 308043 17 4 755043 5 7 007018A 17 5 210319 15 5 308081-9U 9 1 755044 5 26 007018A 17 8 210529-9U 7 2 308083-91 3 1 755044 5 8 007018A 17 11 210529-9U 9 2 308084-91 3 13 755045 5 27 007018A 17 13 210529-9U 11 2 308086 5 16 755045 11 29 007022 21 13 210529-9U 13 2 308086 3 6 755045 15 31 007022A 23 11 210529-9U 15 2 007029 5 4 210530-9U 7 10 308086 23 16 755046 5 24 007041 3 5 210530-9U 9 10 308094-9U 7 1 755046 11 27 007041 23 19 210530-9U 11 10 308096 7 19 755046 15 29 007072 17 25 210530A9U 13 10 308097 7 20 760168-9J 19 1 007072 17 25 210530A9U 15 10 308098 7 22 760168A9J 19 2 007099 21 18 210531-9U 15 11 308099 7 27 771003 19 11 007119 3 7 212435 21 8 308177-91 17 26 811035 3 16 007119 23 17 212436 21 10 308243-91 19 16 811070-91 9 27 007149 7 21 213103-16 23 29 308244 19 17 811070-91 13 28 007149 7 23 308332 3 4 9A3053 19 19 007149 9 21 240104 17 32 007149 9 25 240104 21 17 308332B 23 18 9A3068 19 3 007149 11 21 240570 21 9 308333 3 8 007149 13 22 254010A9U 7 16 308333AD 23 20 007149 13 26 254010A9U 9 16 308334 3 2 007149 15 23 254010A9U 11 16 308335 3 14 007156 17 6 254010A9U 13 17 308422 13 39 007162 17 3 254010A9U 15 18 308480-91 5 1 007164 21 15 254010C9U 7 13 308481 5 2 007193 21 5 254010C9U 9 13 308482-91 5 11 jintex.in

Page 27

jintex.in

Page 28

ペガサスミシン製造株式会社本社〒553-0002 大阪市福島区鷺洲 5-7-2 TEL (06)6458-4739 FAX (06)6454-8785 PEGASUS SEWING MACHINE MFG. CO., LTD. 5-7-2, Sagisu, Fukushima-ku, Osaka 553-0002, Japan. Phone : (06)6458-4739 Telefax: (06)6454-8785 Cat. No. 9734△ ©March 2001 Printed in Japan このパーツカタログに記載されている内容は、改良のため予告なく変更することがあります。 The description in this PARTS CATALOG is subject to change without prior notice for improvement. jintex.in

Part Books

Search
