Page 1 — Parts Checker
M932 952 M932 Series 安全縫いミシン Safety Stitch Machines M952 Series オーバーロックミシン Overedgers Parts Checker PEGASUS jintex.in
Pegasus M900 Series — parts catalog
- Page 1 (cover): This is the cover page for the Parts Checker manual for the Pegasus M932 Series Safety Stitch Machines and M952 Series Overedgers.
- Page 2 (cover): This is the cover page of the CSMP industrial sewing machine parts catalog, featuring the company logo and website.
- Page 3 (diagram): This page displays diagrams of various machine components, including frame parts, covers, and internal mechanisms, with corresponding part numbers and descriptions.
- Page 4 (diagram): This page displays diagrams and parts lists for components labeled with numbers 5, 6, 7, and 8, including various needle guards, needle plates, and looper parts.
- Page 8 (diagram): This page displays diagrams and part numbers for various components of sewing machine models M932-38, 48, 48P2, 70, 355, 551, and M932-48, 48P2.
- Page 9 (diagram): This page displays diagrams and parts lists for various components of industrial sewing machines, including presser foot assemblies, looper mechanisms, and other miscellaneous parts, with part numbers and descriptions for models M932-86, M932-551, M932-355,551, M952-01, and M952-13,13H,13,52.
- Page 10 (diagram): This page displays diagrams and parts lists for various components of sewing machine models M952-13H, 52H, M952-16S2, 17, 23B, M952-23B, and M952-90.
- Page 11 (diagram): This page displays diagrams and parts lists for various components of sewing machines, including parts for M952-90, M952-180,181 (/BT), M952-181/BT9B, and M952-181/BT9C models.
- Page 13 (parts_list): This page contains a parts list for M952 gauge parts, including machine type, gauge specifications, needle guards, needle holders, and needles.
- Page 14 (cover): This is the cover page of the CSMP industrial sewing machine parts catalog, featuring the company logo and website.
- Page 16 (cover): This is the cover page for a parts catalog from PEGASUS SEWING MACHINE MFG. CO., LTD., dated September 2014. It includes the catalog number 9B104100001 and contact information for the company.
Page 2
CSMP jintex.in
Page 3
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 9A30710 | O-RING | ||
| 2106790 | SCREW | ||
| 2403250 | PIN | ||
| 2081731 | PIN | ||
| 2700470 | PIN | ||
| 2403361 | SCREW | ||
| 2095380 | SCREW | ||
| 6R000600000 | COVER | ||
| 1L401700000 | CAP | ||
| 6F00050VD00 | COVER | ||
| 6F00050BD00 | COVER | ||
| 6G0096AVD00 | COVER | ||
| 6G0096ABD00 | COVER | ||
| 007020A0 | SCREW | ||
| 1B001100000 | BRACKET | ||
| M932 | SCREW | ||
| 6K005509100 | SCREW | ||
| 2100440 | BRACKET | ||
| 007017A0 | SCREW | ||
| 2095180 | SCREW | ||
| 007019A0 | SCREW | ||
| 2096800 | SCREW | ||
| 2400430 | PIN | ||
| 9A30460 | PLATE | ||
| M932 | SCREW | ||
| 6K005409100 | SCREW | ||
| 2090840 | BRACKET | ||
| 0045110 | SCREW | ||
| 2403361 | SCREW | ||
| 2095370 | SCREW | ||
| M932 | SCREW | ||
| 007019A0 | SCREW | ||
| 2095171 | BRACKET | ||
| 007020A0 | SCREW | ||
| 2096871 | BRACKET | ||
| 0048210 | SCREW | ||
| 007023A0 | SCREW | ||
| M932 | SCREW | ||
| 6E00160PB00 | COVER | ||
| 2700420 | PIN | ||
| 2103070 | PIN | ||
| 0070660 | SCREW | ||
| 2700431 | BRACKET | ||
| 2700440 | BRACKET | ||
| 0071720 | SCREW | ||
| 2012520 | SCREW | ||
| 007025A0 | SCREW | ||
| M952 | COVER | ||
| 209571-910 | COVER | ||
| M932,M952-90 | BRACKET | ||
| 6G005400001 | BRACKET | ||
| 2700342 | BRACKET | ||
| 2028750 | SCREW | ||
| 0070620 | SCREW | ||
| M952 | BRACKET | ||
| 6G005500001 | BRACKET | ||
| 2700450 | COVER | ||
| 2403050 | SCREW | ||
| 2700490 | BRACKET | ||
| 007180A0 | SCREW | ||
| 2403050 | SCREW | ||
| 2700480 | BRACKET | ||
| 007008A0 | SCREW | ||
| 2403050 | SCREW | ||
| 2700430 | BRACKET | ||
| 007018A0 | SCREW | ||
| 2095431 | SCREW | ||
| 9A31261 | LABEL | ||
| 007024A0 | SCREW | ||
| 6G010709P00 | ACCESSORY | ||
| 1B003600000 | COVER | ||
| 9A30690 | SCREW | ||
| 007019A0 | SCREW | ||
| 2100440 | BRACKET | ||
| 007019A0 | SCREW | ||
| 2095180 | SCREW | ||
| 007019A0 | SCREW | ||
| 6G008600000 | BRACKET | ||
| 007020A0 | SCREW | ||
| M932 | SCREW | ||
| 007019A0 | SCREW | ||
| M952 | SCREW | ||
| 0071510 | SHAFT | ||
| 4P000400000 | RING | ||
| 209591-910 | BRACKET | ||
| 0045720 | SCREW | ||
| 0045140 | PULLEY | ||
| 2405520 | BEARING | ||
| 1L90170D000 | PULLEY | ||
| 2096060 | BEARING | ||
| 2403400 | SPRING | ||
| 2040180 | BEARING | ||
| 204019A0 | BEARING | ||
| 0045560 | SCREW | ||
| 2405360 | WASHER | ||
| 0045100 | SCREW | ||
| 2096050 | PULLEY | ||
| 007105A0 | SCREW | ||
| 209514-PD0 | HOUSING | ||
| 0045410 | SCREW | ||
| 2094810 | BRACKET | ||
| 2082720 | SCREW | ||
| 2084761 | SCREW |
1 9A30710 2106790 2403250 2081731 2700470 2403361 2095380 2 6R000600000 1L401700000 6F00050VD00 /Z055 6F00050BD00 6G0096AVD00 /Z055 6G0096ABD00 007020A0 M932 6K005509100 1B001100000 2100440 007017A0 2095180 007019A0 2403336 M932 6K005409100 M932-13,23B,52,52H,90,181 Except M932-13,23B,52,52H,90,181 2090840 0045110 2403361 2095370 M932 3 007019A0 2095171 007020A0 2096871 0048210 007023A0 M932 (広巾) (Wide) 6E00160PB00 M952-01,180,181を除く Except M952-01,180,181 2700420 2103070 0070660 2700431 2700440 0071720 2012520 007025A0 M952 (広巾) (Wide) 209571-910 M952-01,180,181を除く Except M952-01,180,181 2700342 2028750 0070620 M932,M952-90 6G005400001 2700450 2403050 2700490 007180A0 2403050 2700480 007008A0 2403050 2700430 007018A0 2095431 2095160 2403010 007021A0 4 9A31261 007024A0 付属 品に Packe d in accessory 6G010709P00 1B003600000 9A30690 007019A0 2100440 007019A0 2095180 007019A0 2096800 2400430 9A30460 M932-38,48,48P2 9C801000000 M932-86 9C801100000 M932-355,551 9C801400000 M952-13,52,23B 9C801300000 M952-01,16S2,17,180 9C801200000 M952-90 9C801700000 M952-181 9C801500000 M952-13H,52H 9C801900000 6G008600000 007020A0 M932 007019A0 M952 0071510 4P000400000 209591-910 0045720 0045140 2405520 1L90170D000 2096060 2403400 2040180 204019A0 0045560 2405360 0045100 2096050 007105A0 209514-PD0 0045410 2094810 2082720 2084761 jintex.in
Page 4
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 0045430 | 0045430 | ||
| 2095820 | 2095820 | ||
| 4M002109200 | 4M002109200 | ||
| 0071500 | 0071500 | ||
| 1L200700000 | 1L200700000 | ||
| 2710010 | 2710010 | ||
| 0045430 | 0045430 | ||
| 0045430 | 0045430 | ||
| 2102140 | 2102140 | ||
| 2405370 | 2405370 | ||
| 1G000600000 | 1G000600000 | ||
| 2025770 | 2025770 | ||
| 0045330 | 0045330 | ||
| 4B002909200 | 4B002909200 | ||
| 007023A0 | 007023A0 | ||
| 209552A920 | M932-86,355,551 M952-13H,23B,52H,90を除く Except M932-86,355,551 &M952-13H,23B,52H,90 | ||
| 209690-911 | 209690-911 | ||
| 0045450 | 0045450 | ||
| 1X000800000 | 1X000800000 | ||
| 2096460 | 2096460 | ||
| 007018A0 | 007018A0 | ||
| 4S00700C000 | 4S00700C000 | ||
| 271009-920 | 271009-920 | ||
| 0070350 | 0070350 | ||
| 0045540 | 0045540 | ||
| 0045540 | 0045540 | ||
| 0055010 | 0055010 | ||
| 2109300 | 2109300 | ||
| 007010A0 | 007010A0 | ||
| 0070320 | 0070320 | ||
| 007019A0 | 007019A0 | ||
| 2095410 | 2095410 | ||
| 6A023700000 | 6A023700000 | ||
| 2403050 | 2403050 | ||
| 007020A0 | 007020A0 | ||
| 007010A0 | 007010A0 | ||
| 2095400 | 2095400 | ||
| 007020A0 | 007020A0 | ||
| 007019A0 | 007019A0 | ||
| 2089351 | 2089351 | ||
| 004009-1HC0 | 004009-1HC0 | ||
| 007012A0 | 007012A0 | ||
| 007020A0 | 007020A0 | ||
| 007012A0 | 007012A0 | ||
| 2046310 | M952-90,180,181を除く Except M952-90,180,181 | ||
| 2095390 | M952-180,181を除く Except M952-180,181 | ||
| 2755400 | 2755400 | ||
| 2755410 | 2755410 | ||
| 0071740 | 0071740 | ||
| 3030670 | 3030670 | ||
| 2403380 | 2403380 | ||
| 2096600 | 2096600 | ||
| 007023A0 | 007023A0 | ||
| 4B003309200 | 4B003309200 | ||
| 007023A0 | 007023A0 | ||
| 2718190 | 2718190 | ||
| 2096690 | 2096690 | ||
| 0045100 | 0045100 | ||
| 210566A0 | 210566A0 | ||
| 2095890 | 2095890 | ||
| 2095901 | 2095901 | ||
| 209560-920 | M932-86,355,551 M952-13H,23B,52, 52H,90 Except M932-86,355,551 &M952-13H,23B,52, 52H,90 209560-920 | ||
| 0073690 | 0073690 | ||
| 210586A0 | 210586A0 | ||
| 179130-050 | 179130-050 | ||
| 001998-20 | 001998-20 | ||
| 2102140 | 2102140 | ||
| 209703-910 | 209703-910 | ||
| 0045430 | 0045430 | ||
| 2096531 | 2096531 | ||
| 007018A0 | 007018A0 | ||
| 2715460 | 2715460 | ||
| 2096600 | 2096600 | ||
| 007023A0 | 007023A0 | ||
| 4B003309200 | 4B003309200 | ||
| 007023A0 | 007023A0 | ||
| 2095830 | 2095830 | ||
| 209568-920 | 209568-920 | ||
| 0071500 | 0071500 | ||
| 209007-911 | 209007-911 | ||
| 2090830 | 2090830 | ||
| 0071500 | 0071500 | ||
| 2082590 | 2082590 | ||
| 0073690 | 0073690 | ||
| 209563-920 | M932 209563-920 209560-920 M952-13H,23B,52,52H,90,180,181を除く Except M952-13H,23B,52,52H,90,181 | ||
| 210586A0 | 210586A0 | ||
| 001175-30 | 001175-30 |
5 G ゲージパーツ表参照 Refer to the gauge parts list. 0045430 2095820 4M002109200 0071500 1L200700000 2710010 0045430 0045430 2102140 2405370 1G000600000 2025770 0045330 209552A920 M932-86,355,551 M952-13H,23B,52H,90を除く Except M932-86,355,551 &M952-13H,23B,52H,90 4B002909200 007023A0 209690-911 0045450 1X000800000 2096460 007018A0 4S00700C000 271009-920 0070350 0045540 0045540 G 針留 Needle holder M952 2本針(2-Needle) G 針留 Needle holder M952 1本針(1-Needle) 6 OM932 ★ 0055010 2109300 G オーバー針受(前) Overlock needle guard (front) G 二重環針受(後) Chainstitch needle guard (rear) 007010A0 0070320 007019A0 2095410 6A023700000 2403050 007020A0 007010A0 2095400 007020A0 OM952 2089351 6A023700000 007019A0 G オーバー針受(後) Overlock needle guard (rear) ★ 004009-1HC0 針板 Needle plate 007012A0 M952-180,181を除く Except M952-180,181 007020A0 007012A0 M952-90,180,181を除く Except M952-90,180,181 2046310 M952-180,181を除く Except M952-180,181 2095390 7 2755400 2755410 0071740 3030670 2403380 2096600 007023A0 4B003309200 007023A0 2718190 2096690 0045100 210566A0 2095890 2095901 210586A0 M932-86,355,551 M952-13H,23B,52,52H,90 Except M932-86,355,551 &M952-13H,23B,52, 52H,90 209560-920 0073690 179130-050 001998-20 上ルーバー Upper looper G 2102140 209703-910 0045430 2096531 007018A0 2715460 8 ★印はインチ系です。 ★=inch size G ゲージパーツ表参照 Refer to the gauge parts list. 2096600 007023A0 4B003309200 007023A0 2095830 209568-920 0071500 209007-911 2090830 0071500 2082590 0073690 M932 209563-920 209560-920 M952-13H,23B,52,52H,90,180,181を除く Except M952-13H,23B,52,52H,90,181 210586A0 001175-30 下ルーバー Lower looper G jintex.in
Page 8
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 9E0026A9Q00 | 5本立(5-spool) | ||
| 0048030 | 0048030 | ||
| 0041130 | 0041130 | ||
| 004065-HU0 | 004065-HU0 | ||
| 004067-HU0 | 004067-HU0 | ||
| 004066-HU0 | 004066-HU0 | ||
| 2063360 | 2063360 | ||
| 179483-050 | 179483-050 | ||
| 9E000609100 | 9E000609100 | ||
| 2760010 | 2760010 | ||
| 9E001109-00- | 9E001109-00- | ||
| 2403040 | 2403040 | ||
| 2405650 | 2405650 | ||
| 2014770 | 2014770 | ||
| 0045750 | 0045750 | ||
| 276004A0 | 276004A0 | ||
| 2401040 | 2401040 | ||
| 0041090 | 0041090 | ||
| 276002-PA0 | 276002-PA0 | ||
| 276003-PA0 | 276003-PA0 | ||
| M932-38,48,48P2,70,355,551 | M932-38,48,48P2,70,355,551 | ||
| 2095960B0 | 2095960B0 | ||
| M932-48 | M932-48 | ||
| 押え(組) | Presser foot assembly | ||
| 2771000 | 2771000 | ||
| 0050300 | 0050300 | ||
| 2085320 | 2085320 | ||
| 0031530 | 0031530 | ||
| 2740280 | 2740280 | ||
| 2124980 | 2124980 | ||
| 212499-B0 | 212499-B0 | ||
| 209576A910 | (広巾) (Wide) | ||
| 007009A0 | 007009A0 | ||
| 007008A0 | 007008A0 | ||
| 208958-B0 | 208958-B0 | ||
| 274103-910 | 274103-910 | ||
| 0070130 | 0070130 | ||
| 2740270 | 2740270 | ||
| 00403-9S0 | 00403-9S0 | ||
| 004060 | 004060 | ||
| 004050 | 004050 | ||
| 004040 | 004040 | ||
| 0040120 | 0040120 | ||
| 004080 | 004080 | ||
| 004070 | 004070 | ||
| 004090 | 004090 | ||
| 0049080 | 0049080 | ||
| 00410-SA0 | 00410-SA0 | ||
| 0048180 | 0048180 | ||
| M932-48,48P2 | M932-48,48P2 | ||
| 275514-911 | 275514-911 | ||
| 2124360 | 2124360 | ||
| 0048060 | 0048060 | ||
| 2024330 | 2024330 | ||
| 0070990 | 0070990 | ||
| 0071640 | 0071640 | ||
| 2755220 | 2755220 | ||
| 2401040 | 2401040 | ||
| 2755230 | 2755230 | ||
| 2403200 | 2403200 | ||
| 2124360 | 2124360 | ||
| 2755150 | 2755150 | ||
| 2000980 | 2000980 | ||
| 0071910 | 0071910 | ||
| 2025220 | 2025220 | ||
| 2755210 | 2755210 | ||
| 2070450 | 2070450 | ||
| 007022A | 007022A | ||
| 2109470 | 2109470 | ||
| 2124350 | 2124350 | ||
| 2755160 | 2755160 | ||
| 2109460 | 2109460 | ||
| 0012060 | 0012060 | ||
| 2109450 | 2109450 | ||
| 0053280 | 0053280 | ||
| 007022A0 | 007022A0 | ||
| 2403200 | 2403200 | ||
| 2403230 | 2403230 | ||
| 275517-920 | 275517-920 | ||
| 2109400 | 2109400 | ||
| 2040910 | 2040910 | ||
| 2084480 | 2084480 | ||
| 263543-TA0 | 263543-TA0 | ||
| 2755180 | 2755180 | ||
| 005082A0 | 005082A0 | ||
| 2109440 | 2109440 | ||
| 0048060 | 0048060 | ||
| 2109550 | 2109550 | ||
| 0050290 | 0050290 | ||
| 2109610 | 2109610 | ||
| 1379060 | 1379060 | ||
| 0070120 | 0070120 | ||
| M932-48P2 | M932-48P2 | ||
| 0012020 | 0012020 | ||
| 1670660 | 1670660 | ||
| 2118860 | 2118860 | ||
| 2109620 | 2109620 | ||
| 0052100 | 0052100 | ||
| 004130 | 004130 |
21 5本立(5-spool) 9E0026A9Q00 付属 Packed in accessory 0048030 0041130 0048030 004065-HU0 004067-HU0 004065-HU0 004066-HU0 004065-HU0 004066-HU0 SET UP INSTRUCTIONS 取付説明書 22 付属 Packed in accessory 2760010 9E001109-00- 2403040 2405650 2014770 0045750 ※ ※ SET UP INSTRUCTIONS 取付説明書 2063360 179483-050 9E000609100 2405650 2403040 2014770 0045750 276004A0 2401040 0041090 276002-PA0 276003-PA0 23 M932-38,48,48P2,70,355,551 ●★印はインチ系です。 ★=inch size ●★印はインチ系です。 ★=inch size 24 M932-48,48P2 2095960B0 M932-48 押え(組) Presser foot assembly 2771000 0050300 2085320 0031530 2740280 2124980 212499-B0 0070130 2740270 209576A910 (広巾) (Wide) 007009A0 007008A0 274103-910 0070130 2740270 208958-B0 00403-9S0 004060 004050 004040 0040120 004080 004070 004090 0049080 00410-SA0 0048180 2 押え Presser foot 275514-911 2124360 0048060 0070990 2755220 2401040 2755230 2403200 2124360 2755150 2000980 0071910 2025220 2755210 2070450 2000980 2109470 2403200 2755200 007022A 2109460 2124350 2755160 2109450 0053280 2109440 0070210A0 2403230 2109400 2040910 275517-920 263543-TA0 2084480 2755180 2109550 0050290 2109610 1379060 0070120 M932-48P2 jintex.in
Page 9
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 275030A1 | 押え(組) | ||
| 0051570 | |||
| 2028750 | |||
| 0070130 | |||
| 2771080 | |||
| 2740240 | |||
| 2740270 | |||
| 0071660 | |||
| 007008A0 | |||
| 208958-B0 | トラクター押え | ||
| 2750570 | |||
| 2751220 | |||
| 209562-920 | 上ルーバー機構 | ||
| 0073690 | |||
| 0077700 | |||
| 1K5015A0000 | |||
| 1K507900000 | |||
| 2028490 | |||
| 210529-9T0 | |||
| 000403-9S0 | |||
| 0004060 | |||
| 0004050 | |||
| 275500A0 | |||
| 0004040 | |||
| 0004120 | |||
| 0004080 | |||
| 179713A050 | |||
| 0004090 | |||
| 00049080 | |||
| 000410-SA0 | |||
| 00048180 | |||
| 1B005900000 | |||
| 1670660 | |||
| 0070120 | |||
| 209665A0 | |||
| 2106910 | |||
| 0012060-3 | |||
| 1670660 | |||
| 2106920 | |||
| 0029050 | |||
| 1371420 | |||
| 0050880 | |||
| 2011910 | |||
| 0051570 | |||
| 2106900 | |||
| 0024300 | |||
| 2106820 | |||
| 2106810 | |||
| 0050570 | |||
| 2106830 | |||
| 2106840 | |||
| 0029060 | |||
| 2053610 | |||
| 201211C910(40mm) | |||
| 0052990 | |||
| 3033130 | |||
| 2058350 | |||
| 303312A0 | |||
| 209574-910 | (狭巾) | ||
| 2105850 | |||
| 2105840 | |||
| 6E00170PB00 | (狭巾) | ||
| 0050300 | 押え爪 | ||
| 0013330 | |||
| 2087350 | |||
| 押え | Presser foot | ||
| 6K0054B9101 | |||
| 1K507900000 | |||
| 0071700 | |||
| 210530-9T0 | |||
| 2028490 | |||
| 210529-9T0 | |||
| 209562-920 | 下ルーバー機構 | ||
| 0073690 | |||
| 209562-920 | 上ルーバー機構 | ||
| 0073690 |
25 M932-86 ★印はインチ系です。 ★=inch size G ゲージパーツ表参照。 Refer to the gauge parts list. 押え(組) Presser foot assembly 275030A1 0070130 2771080 2740240 0071660 2740270 007008A0 208958-B0 トラクター押え Tractor presser foot 0051570 2028750 2750570 2751220 M932-86,355,551 上ルーバー機構 Upper looper mechanism 209562-920 0073690 M932-355,551 1K507900000 0077700 1K5015A0000 2028490 210529-9T0 27 M952-01 ★印はインチ系です。 ★=inch size G ゲージパーツ表参照。 Refer to the gauge parts list. 2106910 0012060-31670660 2106920 0029050 1371420 0050880 2011910 0051570 2106900 0024300 2106820 2106810 2106830 0050570 2106840 0029060 2053610 201211C910(40mm) 0052990 3033130 2058350 303312A0 (狭巾)(Narrow) 209574-910 2105850 2105840 (狭巾)(Narrow) 6E00170PB00 0050300 押え爪 Presser foot finger 押え Presser foot 26 M932-551 G ゲージパーツ表参照。 Refer to the gauge parts list. 000403-9S0 0004060 0004050 275500A0 0004040 0004120 0004080 179713A050 0004090 00049080 000410-SA0 00048180 1B005900000 1670660 0070120 付属吕に挿入 Packed in accessory 209665A0 28 M952-13,13H 0013330 2087350 押え Presser foot 6K0054B9101 M952-13,52 1K507900000 0071700 210530-9T0 2028490 210529-9T0 209562-920 下ルーバー機構 Lower looper mechanism 0073690 10073690 209562-920 上ルーバー機構 Upper looper mechanism jintex.in
Page 10
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1K507900000 | M952-13H,52H | ||
| 2028490 | |||
| 0071700 | |||
| 210530A9T0 | |||
| 210530-9T0 | |||
| 210529-9T0 | |||
| 209553A920 | |||
| 4C004909200 | Upper looper mechanism | ||
| 0073690 | |||
| 209562-920 | Lower looper mechanism | ||
| 0073690 | |||
| 209664B1 | |||
| 1K503400001 | |||
| 5K004500000 | M952-13,13H,52,52H | ||
| 2103070 | |||
| 0070660 | |||
| 5K005309100 | |||
| 2112670 | |||
| 2755110 | |||
| M952-16S2,17,23B | |||
| 0012310 | |||
| 201265B0 | |||
| M952-23B | |||
| 209562-920 | Upper looper mechanism | ||
| 0073690 | |||
| 209562-920 | Lower looper mechanism | ||
| 0073690 | |||
| 209553A920 | |||
| 0045330 | |||
| 2101470 | |||
| 2097310 | |||
| 209564A920 | |||
| 0045330 | |||
| 209666A0 | |||
| 6K0054B9101 | |||
| M952-90 | |||
| 274034A0 | |||
| 0070320 | |||
| 204631B0 | |||
| 208851A0 | |||
| M952-52,52H | |||
| 0050300 | Presser foot finger | ||
| 2116000 | |||
| 0013330 | |||
| 2087350 | |||
| 6K0054A9101 | |||
| Presser foot |
29 M952-13H,52H 1K507900000 2028490 210530-9T0 210529-9T0 0071700 210530A9T0 209553A920 4C004909200- 0073690 Upper looper mechanism 209562-920- 0073690 Lower looper mechanism 209664B1 1K503400001 30 ※印は非売品です。 ※=Not for sale ※印はインチ系です。 ※=inch size G ゲージパーツ表参照 Refer to the gauge parts list. M952-13,13H,52,52H 5K004500000 2103070 0070660 5K005309100 2112670 2755110 付属 品に Packed in accessory 個人 SET UP INSTRUCTIONS 取付説明書 M952-16S2,17,23B 0012310 201265B0 G 押え Presser foot 31 ※印はインチ系です。 ※=inch size G ゲージパーツ表参照 Refer to the gauge parts list. 32 M952-23B M952-90 209562-920- 0073690 上ルーバー機構 Upper looper mechanism 下ルーバー機構 Lower looper mechanism 209562-920- 0073690 209553A920 0045330 2101470 2097310 209564A920 0045330 209666A0- 6K0054B9101 274034A0 0070320 204631B0 208851A0 2116000 2087350 押え G Presser foot finger 6K0054A9101 jintex.in
Page 11
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2750210 | 2750210 | BRACKET | |
| 2750260 | 2750260 | BRACKET | |
| 0070820 | 0070820 | SCREW | |
| 2750240 | 2750240 | BRACKET | |
| 0070170 | 0070170 | SCREW | |
| 2750290 | 2750290 | BRACKET | |
| 0070170 | 0070170 | SCREW | |
| 1K60140000 | 1K60140000 | BRACKET | |
| 2103531 | 2103531 | BRACKET | |
| 2635530 | 2635530 | BRACKET | |
| 1K600900000 | 1K600900000 | BRACKET | |
| 1K507900000 | 1K507900000 | COVER | |
| 0071700 | 0071700 | SCREW | |
| 210530-9T0 | 210530-9T0 | SPRING | |
| 209574B910 | 209574B910 | COVER | |
| 6E00170PB00 | 6E00170PB00 | COVER | |
| 209664A2 | 209664A2 | COVER | |
| 2097140 | 2097140 | BRACKET | |
| 204631A0 | 204631A0 | BRACKET | |
| 2097430 | 2097430 | COLLAR | |
| 308083A910 | 308083A910 | COVER | |
| 3084900 | 3084900 | COVER | |
| 308243-911 | ACCESSORY | ||
| 2089490 | 2089490 | SHAFT | |
| 3082440 | 3082440 | BRACKET | |
| 2750260 | 2750260 | BRACKET | |
| 2042930 | 2042930 | COLLAR | |
| 0045230 | 0045230 | SCREW | |
| 270504-PD0 | 270504-PD0 | BRACKET | |
| 2705260 | 2705260 | BRACKET | |
| 0070410 | 0070410 | SCREW | |
| 3083330 | 3083330 | BRACKET | |
| 0071190 | 0071190 | SCREW | |
| 3080880 | 3080880 | BRACKET | |
| 308334A0 | 308334A0 | BRACKET | |
| 3084900 | 3084900 | COVER | |
| 2405710 | 2405710 | SPRING | |
| 0056050 | 0056050 | NUT | |
| 308332A0 | 308332A0 | BRACKET | |
| 0048060 | 0048060 | SCREW | |
| 2755220 | 2755220 | BRACKET | |
| 2124360 | 2124360 | ROD | |
| 2024330 | 2024330 | WASHER | |
| 0070990 | 0070990 | SCREW | |
| 2124350 | 2124350 | BRACKET | |
| 2755230 | 2755230 | BRACKET | |
| 0071640 | 0071640 | SCREW | |
| 2401040 | 2401040 | BRACKET | |
| 179765-150 | 179765-150 | BRACKET | |
| 007022A0 | 007022A0 | SCREW | |
| 3043050 | 3043050 | BRACKET | |
| 0048320 | 0048320 | SCREW | |
| 0071931 | 0071931 | SCREW | |
| 3043070 | 3043070 | BRACKET | |
| 2124360 | 2124360 | ROD | |
| 0048060 | 0048060 | SCREW | |
| 3043160 | 3043160 | BRACKET | |
| 3043150 | 3043150 | BRACKET | |
| 3043180 | 3043180 | SPRING | |
| 0073720 | 0073720 | SCREW | |
| 0051170 | 0051170 | SCREW | |
| 6K0054A9101 | 6K0054A9101 | COVER | |
| 0012310 | 0012310 | SCREW | |
| 201265B0 | 201265B0 | BRACKET | |
| 0073690 | 0073690 | SCREW | |
| 209562-920 | 209562-920 | SHAFT | |
| 1K503100000 | 1K503100000 | COVER | |
| 0071700 | 0071700 | SCREW | |
| 210530-9T0 | 210530-9T0 | SPRING | |
| 210529-9T0 | 210529-9T0 | SPRING | |
| 2028490 | 2028490 | BRACKET | |
| 1K503400001 | 1K503400001 | BRACKET | |
| 005091-HC0 | 005091-HC0 | SCREW | |
| 210529-9T0 | 210529-9T0 | SPRING |
33 M952-90 2750210 2750260 0070820 2750240 0070170 2750290 0070170 1K60140000 2103531 2635530 1K600900000 1K507900000 0071700 210530-9T0 35 308567-910 M952-180/BT9B 0048060 2755220 2124360 2024330 0070990 2124350 0071640 2401040 179765-150 007022A0 3043050 0048320 0071931 3043070 3043160 3043150 3043180 0073720 304314A910 M952-181/BT9C 34 M952-180,181 (/BT) (狭巾) (Narrow) 209574B910 (狭巾) (Narrow) 6E00170PB00 209664A2 2097140 204631A0 2097430 308083A910 3084900 3082443-911 付属品に梱入 Packed in accessory 2089490 3082440 2750260 2042930 0045230 270504-PD0 2705260 0070410 3083330 0071190 3080880 308334A0 3084900 2405710 0056050 308332A0 ★印はインチ系です。 ★=inch size 36 M952-181/BT9C 6K0054A9101 ★0012310 201265B0 G押え Presser foot 下ルーバー機構 Lower looper mechanism 0073690 209562-920 1K503100000 0071700 210530-9T0 210529-9T0 2028490 1K503400001 ★005091-HC0 210529-9T0 jintex.in
Page 13 — M952 ゲージパーツ表 (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 208079-BF0 | MAIN FEED DOG ASSY | ||
| 2046770 | AUX. FEED DOG | ||
| 204676-BF0 | DIFF. FEED DOG | ||
| 2093860 | PRESSER FOOT | ||
| 201310A0 #55 | PRESSER FOOT FINGER | ||
| 2F000300000 | UPPER LOOPER | ||
| 2040720 | LOWER LOOPER | ||
| 201121A0 | UPPER KNIFE | ||
| 2052441 | MAIN FEED DOG | ||
| 2046770 | AUX. FEED DOG | ||
| 204676-BF0 | DIFF. FEED DOG | ||
| 2772960 | PRESSER FOOT | ||
| 2T000300000 #55 | PRESSER FOOT FINGER | ||
| 2F000200000 #17 | UPPER LOOPER | ||
| 2040720 | LOWER LOOPER | ||
| 201121A0 | UPPER KNIFE | ||
| 202618A1 | MAIN FEED DOG ASSY | ||
| (204729B16F0) | MAIN FEED DOG | ||
| (2046740) | AUX. FEED DOG | ||
| 204730A16F0 | DIFF. FEED DOG | ||
| 201473B0 | PRESSER FOOT | ||
| 3014330 | PRESSER FOOT FINGER | ||
| 2040620 #2 | UPPER LOOPER | ||
| 2040720 | LOWER LOOPER | ||
| 201121A0 | UPPER KNIFE | ||
| 2097321 | MAIN FEED DOG ASSY | ||
| (209741-16F0) | MAIN FEED DOG | ||
| (2046770) | AUX. FEED DOG | ||
| 209742-16F0 | DIFF. FEED DOG | ||
| 2052530 | PRESSER FOOT | ||
| 2097340 #66 | PRESSER FOOT FINGER | ||
| 2049631 #81 | UPPER LOOPER | ||
| 2040720 | LOWER LOOPER | ||
| 201121A0 | UPPER KNIFE | ||
| 2022950 | LOWER KNIFE | ||
| 2046591 | NEEDLE GUARD FRONT | ||
| 2090090 | NEEDLE GUARD REAR | ||
| 277022-920 | NEEDLE HOLDER | ||
| DC×27 #9 | NEEDLE | ||
| 2052441 | LOWER KNIFE | ||
| 2046591 | NEEDLE GUARD FRONT | ||
| 2090090 | NEEDLE GUARD REAR | ||
| 277066-920 | NEEDLE HOLDER | ||
| DC×27 #14 | NEEDLE | ||
| 2770091 | LOWER KNIFE | ||
| 2046591 | NEEDLE GUARD FRONT | ||
| 2090090 | NEEDLE GUARD REAR | ||
| 179630-920 | NEEDLE HOLDER | ||
| DC×27 #9 | NEEDLE | ||
| 2022950 | LOWER KNIFE | ||
| 2046591 | NEEDLE GUARD FRONT | ||
| 2090090 | NEEDLE GUARD REAR | ||
| 277022-920 | NEEDLE HOLDER | ||
| DC×27 #9 | NEEDLE | ||
| 2022950 | LOWER KNIFE | ||
| 2046591 | NEEDLE GUARD FRONT | ||
| 2090090 | NEEDLE GUARD REAR | ||
| 277022-920 | NEEDLE HOLDER | ||
| DC×27 #9 | NEEDLE |
M952 ゲージパーツ表 (2) M952 GAUGE PARTS LIST(2) ミシン形式 ゲージ 下メス 針受 針留 針 MACHINE TYPE /SPEC NG SW LOWER KNIFE 前 後 NEEDLE HOLDER NEEDLE FRONT REAR M952-52H 2 4 2022950 2046591 2090090 277022-920 DC×27 #9 M952-52H 2 5 2052441 2046591 2090090 277066-920 DC×27 #14 M952-90 6 2770091 2046591 2090090 179630-920 DC×27 #9 M952-180 4 2022950 2046591 2090090 277022-920 DC×27 #9 M952-181 2 4 2022950 2046591 2090090 277022-920 DC×27 #9 ミシン形式 ゲージ 下メス 針受 針留 針 MACHINE TYPE /SPEC NG SW LOWER KNIFE 前 後 NEEDLE HOLDER NEEDLE FRONT REAR M952-52H 2 4 2022950 2046591 2090090 277022-920 DC×27 #9 M952-52H 2 5 2052441 2046591 2090090 277066-920 DC×27 #14 M952-90 6 2770091 2046591 2090090 179630-920 DC×27 #9 M952-180 4 2022950 2046591 2090090 277022-920 DC×27 #9 M952-181 2 4 2022950 2046591 2090090 277022-920 DC×27 #9 MAIN FEED DOG ASSY MAIN FEED DOG AUX. FEED DOG DIFF. FEED DOG PRESSER FOOT PRESSER FOOT FINGER UPPER LOOPER LOWER LOOPER UPPER KNIFE 208079-BF0 (204675ABF0) (2046770) 204676-BF0 2093860 201310A0 #55 2F000300000 2040720 201121A0 2052441 2046770 204676-BF0 2772960 2T000300000 #55 2F000200000 #17 2040720 201121A0 202618A1 208090A16F0 (204729B16F0) (2046740) 204730A16F0 201473B0 3014330 2040620 #2 2040720 201121A0 2097321 209740-16F0 (209741-16F0) (2046770) 209742-16F0 2052530 2097340 #66 2049631 #81 2040720 201121A0 jintex.in
Page 14
CSMP jintex.in
Page 16
ペガサスミシン製造株式会社 本社 〒 553-0002 大阪市福島区鷺洲 5-7-2 TEL (06)6458-4739 FAX (06)6454-8785 PEGASUS SEWING MACHINE MFG. CO., LTD. 5-7-2, Sagisu, Fukushima-ku, Osaka 553-0002, Japan. Phone :(06)6458-4739 Fax :(06)6454-8785 Cat. No. 9B104100001 September 2014 ©2014 PEGASUS SEWING MACHINE MFG. CO., LTD. このパーツチェッカーに記載されている内容は、改良のため予告なく変更することがあります。 The description in this PARTS CHECKER is subject to change without prior notice for improvement. jintex.in
