Parts index — Yamato VC3611tap a row to open its page

Page 2

Yamato VC3611 parts on page 2

Ref	Part number	Part name	Qty
	(1)	MISCELLANEOUS COVERS
	(2)	MISCELLANEOUS COVERS
	カバー関係(1)	カバー関係
	(2)	カバー関係
	糸道関係	MISCELLANEOUS THREAD EYELETS
	プッシュ及びアイガード関係	MISCELLANEOUS BUSHINGS & EYE GUARD
	下軸機構	MAIN SHAFT DRIVING MECHANISM
	上軸及び針糸繰り機構	UPPER SHAFT & NEEDLE THREAD TAKE-UP MECHANISM
	針棒機構	NEEDLE BAR MECHANISM
	押工機構	PRESSER FOOT MECHANISM
	ルーパ機構	LOOPER DRIVING MECHANISM
	前送り調節機構	FEED DRIVING CONTROL MECHANISM
	針受及び送り機構	NEEDLE GUARD & FEED DRIVING MECHANISM
	メス機構	KNIFE DRIVING MECHANISM
	吸込管関係	MISCELLANEOUS SUCTION PIPE
	給油機構	LUBRICATING MECHANISM
	飾り糸ルーパ機構	SPREADER MECHANISM
	飾り糸関係	MISCELLANEOUS TOP COVER THREAD
	(1)	PULLER MECHANISM EXCLUSIVE PARTS
	(2)	PULLER MECHANISM EXCLUSIVE PARTS
	(3)	PULLER MECHANISM EXCLUSIVE PARTS
	プラー機構専用部品(1)	PULLER MECHANISM EXCLUSIVE PARTS
	(2)	PULLER MECHANISM EXCLUSIVE PARTS
	(3)	PULLER MECHANISM EXCLUSIVE PARTS
	サブモデル専用部品	VC3611-156L-D, 145L-D, VC3711-148L-D, 156L-D EXCLUSIVE PARTS
	サブモデル専用部品(1)	VC3645P-D EXCLUSIVE PARTS
	(2)	VC3645P-D EXCLUSIVE PARTS
	(1)	"UT" DEVICE
	(2)	"UT" DEVICE
	(3)	"UT" DEVICE
	(4)	"UT" DEVICE
	"UT"装置(1)	"UT" DEVICE
	(2)	"UT" DEVICE
	(3)	"UT" DEVICE
	(4)	"UT" DEVICE
	(1)	"UT-A" DEVICE
	(2)	"UT-A" DEVICE
	(3)	"UT-A" DEVICE
	(4)	"UT-A" DEVICE
	"UT-A"装置(1)	"UT-A" DEVICE
	(2)	"UT-A" DEVICE
	(3)	"UT-A" DEVICE
	(4)	"UT-A" DEVICE
	特注部品	"AS3" DEVICE
	EXTRA PARTS	EXTRA PARTS
	糸立台及び受ケ板	THREAD STAND & SUPPORTING BOARD
	主要部品リスト	LIST of MAIN SPARE PARTS
	索引	INDEX

Page 3 — MISCELLANEOUS COVERS (1)

Yamato VC3611 parts on page 3

Ref	Part number	Part name	Qty
1	3100012	Top Cover	1
2	110045	Screw (M4-0.7×12)	11
3	3100013	Top Cover Gasket	1
4	0068011	Oil Sight Window	1
5	0020759	Top Cover Seal Plug	1
6	390069	Brand Name Plate (76.5)	1
7	3100010	Head Cover	1
8	3100011	Head Cover Gasket	1
9	0093864	Head Cover Seal Plug	1
10	390072	"VC" Emblem	1
11	3100040	Side Cover Hinge	1
12	3100041	Side Cover Hinge Gasket	1
13	110048	Screw (M4-0.7×10)	2
14	3100042	Side Cover Hinge Pin	1
15	160000	Screw (M3-0.5×3)	1
16	3100043	Side Cover	1
17	3100044	Side Cover Gasket	1
18	000924	Seal Plug (Rubber)	1
19	3110160	Cloth Plate	1
20	110041	Screw (M4-0.7×8)	2
21	0094201	Cover Latch Spring	1
22	110015	Screw (M4-0.7×5)	1
23	3100046	Side Cover Hook	1
24	300101	Conical Spring Washer	1
25	170002	Screw (M4-0.7×5)	1
26	3100004	Oil Reservoir	1
27	3100005	Oil Reservoir Gasket	1
28	0020143	Magnet	1
29	0020144	Magnet Holder	1
30	110013	Screw (M4-0.7×8)	1
31	0020137	Drain Hole Seal	1
32	005075	Screw (3/8-24×8)	3
33	4109403	Model Plate (See the below)	1
34	000726	Rivet	3
35	3110150	Machine Frame Unit	1
36	120016	Screw (M8-1.25×20)	4
37	340000	Machine Frame Supporting Bar	4
38	3110185	Supplementary Cloth Plate	1
39	006233	Screw (M3-0.5×5)	2

Page 4 — MISCELLANEOUS COVERS (2)

Yamato VC3611 parts on page 4

Ref	Part number	Part name	Qty
41	3110072	Edge Guide Chip
42	004182	Screw (3/32-56×1.5)
43	000005	Washer
44	110008	Screw (M4-0.7×5.4)
45	3110108	Fabric Guide Holder
46	000538	Washer
47	110009	Screw (M4-0.7×8)
48	3110115	Fabric Guide
49	000535	Washer
50	000644	Spring Washer
51	004358	Screw (9/64-40×5.6)
52	3110109	Fabric Guide (Right)
53	110043	Screw (M4-0.7×14)
54	2100265	Spacer
55	000629	Seal Plug
56	160007	Screw (M6-1×6)
57	390067	Brand Name Plate (10)
58	390068	Brand Name Plate (92)

Page 6 — MISCELLANEOUS BUSHINGS & EYE GUARD

Yamato VC3611 parts on page 6

Ref	Part number	Part name	Qty
	3100106	Needle Bar Bushing (Upper)	1
	3100107	Needle Bar Bushing (Lower)	1
	0030291	Presser Bar Bushing	1
	000091	Oil Seal	1
	0063548	Seal Plug	2
	0094604	Seal Plug	1
	3100108	Foot Lifter Lever Bushing	1
	0093201	Needle Thread Take-up Bushing (Front)	1
	3100098	Needle Thread Take-up Bushing (Rear)	1
	3100090	Lower Shaft Bushing (Left)	1
	3100091	Lower Shaft Bushing (Right)	1
	3100094	Feed Bar Shaft Bushing (Left)	1
	3100095	Feed Bar Shaft Bushing (Right)	1
	3100096	Feed Bar Lift Shaft Bushing (Left)	1
	3100097	Feed Bar Lift Shaft Bushing (Right)	1
	000006	Seal Plug	2
	3100092	Looper Driving Shaft Bushing (Front)	1
	3100093	Looper Driving Shaft Bushing (Rear)	1
	3100105	Adjusting Screw Bushing	1
	3200251	Eye Guard, Complete Set	1
	3101200	Safety Plate Support	1
	009784	Screw (M6×1×10)	2
	3200252	Safety Plate	1
	001230	Screw (3/32-56×3.8)	2
	0060175	Safety Plate Holder	1
	006004	Screw (11/64-40×9.7)	1
	000010	Conical Spring Washer	1
	000547	Washer	1
	000334	Nut	1

Page 7 — MAIN SHAFT DRIVING MECHANISM

Yamato VC3611 parts on page 7

Ref	Part number	Part name	Qty
1	3100130	Pulley	1
2	160005	Screw (M6-1×8)	4
3	160007	Screw (M6-1×6)	6
4	0093089	Ball Bearing (Right)	1
5	3100128	Main Shaft Sprocket	1
6	0093090	Ball Bearing (Middle)	1
7	3100132	Lower Shaft (Right)	1
8	3100122	Oil Pump Driving Worm	1
9	3100127	Counterweight (Small)	1
10	110009	Screw (M4-0.7×8)	2
11	3100123	Ball Bearing (Left)	1
12	3100121	Lower Crankshaft	1
13	160004	Screw (M6-1×4.8)	2
14	001107	Roll Pin	3
15	330001	Seal Plug	1
16	3100120	Lower Shaft (Left)	1
17	000397	Oil Wick	3
18	000304	Oil Wick	1
19	000730	Seal Plug	1
20	3100126	Collar (14×21×5.5mm)	1
21	160000	Screw (M3-0.5×3)	2
22	3100125	Looper Thread Take-up	1
23	150000	Screw (M5-0.8×4)	2
24	3100263	Supporting Plate	1
25	110002	Screw (M3-0.5×5)	3
26	000463	Laced Wire	1
27	3100264	Thread Take-up Eyelet (Left)	1
28	3100265	Thread Take-up Eyelet (Right)	1
29	110027	Screw (M2.5-0.45×3.5)	2
30	3100262	Supporting Plate Basement	1
31	160001	Screw (M4-0.7×4)	1
32	160008	Stop Screw (M3-0.5×15)	1
33	100003	Lock Nut	1
34	3100267	Supporting Plate Return Spring	1
35	3100266	Screw (M3-0.6×6)	1
36	340004	Pin	1
37	3100260	Basement Shaft	1
38	3100261	Collar (6×11×5mm)	1
39	3100266	Cast-off Plate	1
40	000531	Washer	1
41	3100268	Stop Bracket	1
42	110041	Screw (M4-0.7×8)	2
43	3100270	Supporting Plate Stop	1
44	3100269	Stop Spring	1
45	170003	Screw (M3-0.5×3)	1
46	3100272	Supporting Plate Basement Cushion	1

Page 8 — UPPER SHAFT & NEEDLE THREAD TAKE-UP MECHANISM

Yamato VC3611 parts on page 8

Ref	Part number	Part name	Qty
1	3100280	Handwheel	1
2	160005	Screw (M6-1×8)	2
3	160007	Screw (M6-1×6)	10
4	000989	Handwheel Mark	1
5	0093090	Ball Bearing	2
6	3100129	Handwheel Adapter	1
7	0095214	Timing Belt	1
8	3100281	Upper Shaft Sprocket (Upper)	1
9	3100282	Upper Shaft (Right)	1
10	3100283	Upper Shaft Joint	1
11	3100127	Counterweight (Small)	1
12	110009	Screw (M4-0.7×8)	2
13	3100284	Upper Crankshaft	1
14	0060057	Retaining Ring	1
15	0093154	Ball Bearing	2
16	160004	Screw (M6-1×4.8)	2
17	000926	Rubber Seat	1
18	260000	Screw (5/16-24×15.88)	2
19	0095170	Connecting Rod	1
20	005071	Screw (11/64-32×14)	2
21	001174	Screw (9/64-40×10.3)	2
22	0095168	Guide Fork	1
23	004312	Screw (1/8-44×7.9)	2
24	3100285	Driving Lever	1
25	120013	Screw (M6-1×15)	1
26	120015	Screw (M5-0.8×10)	1
27	000555	Washer	1
28	3100286	Spacer	1
29	3100287	Driving Shaft	1
30	3100078	Bracket	1
31	000600	Spring Washer	1
32	005650	Screw (M5-0.8×14)	1
33	0063096	Needle Thread Take-up	1
34	000532	Washer	2
35	110004	Screw (M3.5-0.6×8)	2

Page 9 — NEEDLE BAR MECHANISM

Yamato VC3611 parts on page 9

Ref	Part number	Part name	Qty
	0065340	Needle Bar
	004358	Screw (9/64-40×5.6)
	0063044	Needle Bar Thread Eyelet
	000548	Washer
	0093184	Needle Bar Bracket
	002043	Screw (11/64-40×11)
	0093352	Needle Clamp (56)
	0093353	"
	3009101	"
	001900	Screw (1/8-44×2.4)
	3118021	Stitch Plate (40L)
	3118022	"
	3118023	"
	009142	Screw (9/64-40×4.8)
	110059	Screw (M3.5-0.6×7)
	3100293	Counterweight, Complete Set
	0093215	Counterweight
	003647	Screw (1/4-28×4.8)
	0093214	Connecting Rod Ring
	3100291	Connecting Rod, Complete Set
	3100290	Connecting Rod
	0093212	Roller Bearing
	0093213	Connecting Rod Pin
	000321	Oil Wick
	0093186	Slide Block
	0093179	Needle Bar Guide
	110010	Screw (M4-0.7×16)
	3100256	HR Device, Complete Set
	3100254	HR Container
	110013	Screw (M4-0.7×8)
	0010017	Pipe Joint
	3100253	Oil Tube
	310007	Felt
	3100250	HR Cup
	310006	HR Felt
	000637	Seal Plug
	110009	Screw (M4-0.7×8)

Page 10 — PRESSER FOOT MECHANISM

Yamato VC3611 parts on page 10

Ref	Part number	Part name	Qty
1	0077270	Presser Spring Regulator	1
2	0090620	Cotter Pin	1
3	000445	Lock Nut	1
4	0065372	Presser Bar Spring (Outer)	1
5	0063087	Presser Bar Connecting Bracket	1
6	004440	Screw(11/64-40×8.3)	1
7	0093483	Presser Bar Guide	1
8	004441	Screw(11/64-40×16)	1
9	0060142	Presser Bar Spring (Inner)	1
10	0093480	Presser Bar	1
11	0093611	Oil Protector Ring	1
12	0063079	Stop Collar (9×15×7mm)	1
13	001459	Screw(9/64-40×3)	2
14-1	3117076	Presser Foot, Complete Set (048)	1
14-2	3117078	"	1
14-3	3117080	"	1
15	001186	Screw(9/64-40×7.8)	1
16	0063280	Presser Foot Spring	1
17	0093487	Lifter Link	1
18	006038	Screw(3/16-32×2.2)	2
19	0063083	Lifter Link Lever	1
20	000690	Fastener Pin	1
21	0063084	Lifter Spring	1
22	0093491	Collar (8×16×8mm)	2
23	009604	Screw(11/64-40×5.5)	2
24	0093479	Lifter Shaft	1
25	003433	Screw(11/64-40×4)	2
26	3100294	Intermediate Lever	1
27	120017	Screw(M5-0.8×15)	1
28	0077179	Retaining Ring	1
29	0093509	Connecting Pin	2
30	0093507	Connecting Plate	1
31	0093508	Lifter Lever (Small)	1
32	004591	Screw(15/64-28×9.5)	1
33	0066560	Lifter Lever	1
34	0066561	Lifter Lever Stop	1
35	004358	Screw(9/64-40×5.6)	2
36	0090801	Tension Release Lever	1
37	005542	Screw(11/64-40×14.5)	1
38	0093545	Tension Release Shaft	1
39	0090824	Swing-proof Spring	1
40	0065366	Presser Foot Guide Locking Pin	1
41	0063282	Presser Foot Hinge Pin	1
42	000327	Lock Nut	1
43	003302	Adjusting Screw(1/8-44×11)	1
44	3117084	Fabric Presser	1
45	001228	Screw(3/32-56×3.2)	2

Page 11

Yamato VC3611 parts on page 11

Ref	Part number	Part name	Qty
	3109300	Looper	1
	110020	Screw(M3.5-0.6×6)	1
	3100162	Looper Holder	1
	3100555	" (with "UT" Device)	1
	110039	Screw(M3.5-0.6×10)	1
	000417	Spacer(Fiber)	1
	3100154	Looper Bar Bushing	1
	160007	Screw(M6-1×6)	4
	3100410	Looper Thread Eyelet	1
	110101	Screw(M3-0.5×3)	1
	340008	Roll Pin	1
	3100156	Bushing Spacer	1
	3100152	Looper Bar Guide	1
	3100157	Slider	1
	3100158	Slider Holder	1
	110005	Screw(M3.5-0.6×12)	1
	300500	Spacer(Fiber)	1
	3100159	Slider Presser	1
	160001	Screw(M4-0.7×4)	1
	3100160	Thrust Washer	1
	330002	Seal Plug(Kurk)	1
	3100161	Looper Bar	1
	3100153	Guide Shaft Bushing	1
	3100155	Looper Bar Guide Shaft	1
	110019	Screw(M5-0.8×35)	1
	300000	Washer	2
	3100151	Looper Rocker Adjusting Pin	1
	340001	Roll Pin	1
	100002	Nut	1
	3100150	Looper Rocker Connecting Rod, C. Set	1
	3100147	Looper Rocker Regulating Eccentric	1
	160003	Screw(M5-0.8×5)	1
	0065389	Roller Bearing	1
	3100149	Looper Rocker Connecting Rod	1
	3100140	Looper Connecting Rod	1
	005071	Screw(11/64-32×14)	4
	3100355	Oil Slasher	1
	3100141	Guide Fork	1
	004440	Screw(11/64-40×8.3)	2
	3100142	Looper Driving Lever	1
	000637	Seal Plug	1
	3100143	Looper Rocker Arm	1
	120011	Screw(M6-1×18)	1
	3100146	Thrust Plate	3
	3100145	Thrust Roller Bearing	2
	3100144	Looper Shaft	1
	000740	Seal Plug	2

Page 12 — FEED DRIVING CONTROL MECHANISM

Yamato VC3611 parts on page 12

Ref	Part number	Part name	Qty
1	3100217	Feed Lift Lever
2	160007	Screw(M6-1×6)
3	0032799	Connecting Rod Pin
4	160002	Screw(M4-0.7×2)
5	3100216	Feed Lift Connecting Rod
6	3100192	Retaining Ring
7	3100190	Roller Bearing
8	3100189	Differential Feed Eccentric
9	006212	Screw(M5-0.8×6)
10	3100191	Differential Feed Connecting Rod
11	3100193	Connecting Rod Pin
12	3100194	Lever Link(Long)
13	3100195	Lever Link(Short)
14	3100196	Lever Link Pin
15	300006	Washer
16	110009	Screw(M4-0.7×8)
17	3100197	Differential Feed Shaft Lever
18	120009	Screw(M4-0.7×12)
19	3100199	Control Bracket
20	3100202	Connecting Rod Guide
21	3100200	Control Bracket Spring
22	340003	Pin
23	3100103	Control Lever Shaft Bushing
24	3100104	O-ring(P16)
25	0093303	Oil Seal
26	3100201	Control Lever Shaft
27	3100211	Control Link Pin
28	3100203	Control Link
29	3100208	Control Nut
30	001107	Roll Pin
31	3100205	O-ring(P12)
32	3100204	Adjusting Screw
33	3100207	Adjusting Stop Pin
34	150001	Screw(M4-0.7×4)
35	3100206	Adjusting Knob
36	130002	Screw(M3-0.5×4)
37	3100235	Differential Feed Control Lever, C. Set
38	3100210	Differential Feed Control Lever
39	3100209	Differential Feed Graduations
40	130004	Screw(M4-0.7×11)
41	000505	Spacer
42	0020350	Control Lever Stop
43	000669	Washer
44	000600	Spring Washer
45	005049	Screw(M5-0.8×8)
46	190004	Screw(M6-1×7.5, M4.5-0.5×3)
47	100005	Nut
48	000010	Conical Spring Washer

Page 13 — NEEDLE GUARD & FEED DRIVING MECHANISM

Yamato VC3611 parts on page 13

Ref	Part number	Part name	Qty
	3100243	Needle Guard (Front) Eccentric	1
	160003	Screw (M5-0.8×5)	2
	3100242	Needle Guard (Front) Lever	1
	110022	Screw (M3-0.5×10)	2
	3100241	Needle Guard (Front) Holder	1
	3109200	Needle Guard (Front)	1
	110036	Screw (M3-0.5×6.5)	2
	3100245	Needle Guard (Rear) Lever	1
	3100246	Needle Guard (Rear) Holder	1
	3109201	Needle Guard (Rear)	1
	3109210	" " " (Extra)	1
	3100187	Feed Regulating Stop	1
	110004	Screw (M3.5-0.6×8)	3
	340001	Roll Pin	1
	3100186	Conical Spring Presser	1
	130005	Screw (M2-0.4×4)	2
	3100185	Conical Spring	1
	3100183	Eccentric Cam	1
	000723	Stop Pin	1
	3100184	Eccentric Pin	1
	3100182	Main Feed Eccentric, Complete Set	1
	110072	Screw (M3.5-0.6×5)	1
	110023	Screw (M3.5-0.6×5)	1
	009736	Screw (M4-0.7×6)	2
	3100188	Main Feed Bar Driving Connection	1
	110021	Screw (M5-0.8×18)	2
	0032853	Driving Connection Bushing	1
	3100225	Feed Bar Guide (Upper)	1
	160007	Screw (M6-1×6)	2
	3100227	Feed Bar, Complete Set	1
	3100221	Differential Feed Bar	1
	3100222	Main Feed Bar	1
	3100231	Feed Dog Key	2
	3100224	Feed Lift Block (Rear)	1
	3119021	Main Feed Dog (40, 48, 56)	1
	3119020	Differential Feed Dog (40, 48, 56)	1
	3100226	Feed Bar Guide (Lower)	1
	110035	Screw (M4-0.7×10)	2
	3100213	Differential Feed Bar Driving Connection	1
	3100215	Oscillation Adjusting Eccentric	1
	000199	Oil Wick	1
	3100214	Driving Connection Pin	1
	160006	Screw (M3-0.5×6)	1
	000750	Seal Plug	4
	3100212	Differential Feed Shaft	1
	0093389	Feed Lift Block (Front)	1
	3100218	Feed Lift Shaft	1
	000397	Oil Wick	1
	3100219	Collar (11×18×11mm)	2
	160004	Screw (M6-1×4.8)	2
	3101300	Feed Bar Guide (Upper) (Right)	1

Page 15 — MISCELLANEOUS SUCTION PIPE

Yamato VC3611 parts on page 15

Ref	Part number	Part name	Qty
	3110171	Suction Pipe Holder	1
	120018	Screw (M4-0.7×10)	2
	3110169	Suction Pipe (Upper)	1
	009736	Screw (M4-0.7×6)	1
	3110180	Oil Defender	1
	110008	Screw (M4-0.7×5)	2
	3120033	Suction Pipe (Right)	1
	0012480	Dust Hose (1500mm)	1
	0013648	Hose Band	2
	006921	Wood Screw (φ 4.8×25)	4
	0010260	Vinyl Tube (4×2.5mm)	1
	1094002	Reducer (φ6×4)	1
	1098012	Hand Valve	1
	350006	Wood Screw (φ 3.5×32)	2
	0010261	Vinyl Tube (6×4mm)

Page 16

Yamato VC3611 parts on page 16

Ref	Part number	Part name	Qty
	0065453	Oil Receiver	1
	110012	Screw(M4-0.7×5)	6
	000234	Nut	1
	3100350	Needle Bar Connecting Rod Oil Pipe	1
	160001	Screw(M4-0.7×4)	1
	310027	Oil Wick	1
	0020551	O-ring	1
	0063251	Oil Tube Stay	1
	3100346	Oil Wick Holder	1
	004353	Screw(9/64-40×7)	1
	3100060	Oil Filter Cap	1
	110031	Screw(M4-0.7×12)	3
	3100061	O-ring	1
	3100345	Oil Filter	1
	3100329	Oil Filter Connector	1
	0063217	Oil Filter Screen Clamp	1
	0063216	Oil Filter Screen	1
	0063234	Felt	1
	0063235	Oil Tube (4×5×500mm)	1
	0065452	Draining Pipe	1
	3100353	Oil Sight Top Nozzle	1
	3100357	Oil Tube (Long), Complete Set	1
	0031831	Oil Tube Clamp	12
	3100335	Oil Tube (4×6×290mm)	1
	0090930	Non-Return Valve Unit	1
	3100336	Oil Tube (4×6×75mm)	1
	0037668	Oil Tube Joint, Two Way	1
	3100332	Oil Tube (4×6×37mm)	1
	0037669	Oil Tube Joint, One Way	4
	3100342	Lower Shaft Oiling Outlet	1
	3100358	Oil Tube (Middle), Complete Set	1
	3100331	Oil Tube (4×6×31mm)	2
	3100343	Lower Shaft Oiling Shower	1
	3100334	Oil Tube (4×6×110mm)	1
	110009	Screw (M4-0.7×8)	3
	004124	Fitting Stud (Short)	10
	000567	Seal	10
	004126	Fitting Stud (Long)	1
	3100356	Oil Tube (Short), Complete Set	1
	3100338	Oil Pump, Complete Set	1
	000711	Oil Pump Driving Worm Gear	1
	009526	Screw(9/64-40×4.4)	3
	120013	Screw(M6×15)	2
	0090918	Suction Pipe	1
	000419	Nut	1
	3100349	Oil Nozzle for Worm Gear	1
	3100344	Dustproof Plate	1
	3100330	Oil Tube Stay	1
	0021010	Oil Sight Gauge	1
	310026	Oil Wick	1

Page 17 — 飾り糸ルーパ機構

Yamato VC3611 parts on page 17

Ref	Part number	Part name	Qty
1	3100302	Connecting Rod, Complete Set	1
2	3100300	Eccentric	1
3	160003	Screw(M5-0.8×5)	2
4	0077322	Roller Bearing	1
5	3100301	Connecting Rod	1
6	0094566	Retaining Ring	1
7	110009	Screw(M4-0.7×8)	1
8	300006	Washer	1
9	3100309	Adjusting Lever Pin	1
10	000528	Washer	1
11	100003	Nut (M6-1.0)	1
12	0032646	Collar(12×20×8mm)	1
13	009604	Screw(11/64-40×5.5)	2
14	3100303	Adjusting Lever	1
15	120013	Screw(M6-1×15)	1
16	3100304	Driving Shaft	1
17	3100305	Rocking Arm	1
18	160007	Screw(M6×6)	2
19	0063051	Rocking Pin	1
20	0063053	Spreader Bar	1
21	0063056	Bushing Ring	1
22	0063057	Collar(10×18×7mm)	1
23	009526	Screw(9/64-40×4.4)	2
24	3100307	Spreader Holder	1
25	3109310	Spreader	1
26	110031	Screw(M4-0.7×12)	2
27	3100306	Rocking Arm, Complete Set	1

Page 18 — MISCELLANEOUS TOP COVER THREAD

Yamato VC3611 parts on page 18

Ref	Part number	Part name	Qty
	0093863	Thread Tension Spring Cap
	3100086	Top Cover Thread Tension Spring
	0090071	Thread Tension Spring Retainer
	000177	Felt
	0031111	Tension Disc
	009835	Tension Post
	0090812	Tension Post Ferrule
	0090856	Tension Disc Eyelet
	0090807	Thread Lead-in Guide
	3200048	Top Cover Thread Eyelet (Left)
	110009	Screw(M4-0.7×8)
	3200049	Top Cover Thread Take-up
	0020119	Thread Eyelet Pipe(Short)
	0093528	Thread Eyelet Pipe Stay
	004353	Screw(9/64-40×7)
	000532	Washer
	3200047	Top Cover Thread Eyelet (Right)
	000541	Washer
	0093365	Top Cover Thread Eyelet
	001900	Screw(1/8-44×2.4)
	3100100	Spreader Driving Bar Bushing
	0063055	Oil Seal
	3200063	Spreader Shaft Bushing(Left)
	3200064	Spreader Shaft Bushing(Right)
	3100081	Top Cover Thread Guide
	0063074	Supplementary Thread Guide
	001818	Tension Post
	0037108	Supplementary Tension Disc
	0035813	Supplementary Tension Spring
	000360	Nut

Page 19 — PULLER MECHANISM(1)

Yamato VC3611 parts on page 19

Ref	Part number	Part name	Qty
	3100625	Upper Feed Roller Shaft Bracket
	120019	Screw(M6-1×18)
	000779	Knock Pin
	3100006	Seal Plug
	3100607	Roller Shaft Bushing (Right)
	3100604	Upper Feed Roller Shaft Lever
	160007	Screw(M6-1×6)
	0065398	Collar(14×22×10mm)
	009604	Screw(11/64-40×5.5)
	3100626	Roller Shaft Bushing (Left)
	0065395	Oil Seal
	3100605	Upper Feed Roller Shaft
	3100608	Upper Feed Roller Lever
	120012	Screw(M6-1×20)
	0065400	Upper Feed Roller Lever Rod
	001174	Screw(9/64-40×10.3)
	0060109	Ball Stud
	0065401	Upper Feed Roller Pin
	0065402	Upper Feed Roller Rod Sleeve
	000613	Washer
	000306	Nut
	0032921	Upper Feed Roller Driving Rod Pin
	160001	Screw(M4-0.7×4)
	3100602	Upper Feed Roller Driving Rod
	310192	Retaining Ring
	3100623	Roller Bearing
	3100603	Upper Feed Roller Regulator, Complete Set
	3100601	Upper Feed Roller Eccentric
	3100600	Upper Feed Roller Regulator
	160003	Screw(M5-0.8×5)
	190007	Adjusting Screw(M5-0.8×6)
	120008	Screw(M4-0.7×8)
	000530	Washer
	3100636	Upper Feed Roller Shaft Bracket, C. Set
	---	See page 19

Page 20 — PULLER MECHANISM (2)

Yamato VC3611 parts on page 20

Ref	Part number	Part name	Qty
1	3100611	Upper Feed Roller Yoke
2	120012	Screw(M6-1×20)
3	3100612	Upper Feed Roller Yoke Guide
4	110009	Screw(M4-0.7×8)
5	3100613	Upper Feed Roller Yoke Pin
6	003662	Screw(M6-1×6)
7	0090620	Cotter Pin
8	006270	Screw(9/64-40×0.5)
9	160001	Screw(M4-0.7×4)
10	0060056	Retaining Ring
11	3100617	Clutch Driving Shaft
12	3100616	Clutch Driving Shaft Bushing (Left)
13	0065414	Clutch Driving Shaft Bushing (Right)
14	0065421	Clutch Tension Sleeve
15	000145	Adjusting Nut
16	0065420	Clutch Tension Spring
17	3100615	Clutch Driving Lever
18	000306	Nut
19	007621	Screw(9/64-40×0.5)
20	0095061	Clutch
21	3010022	Clutch Spring (Thick)
22	0095066	Clutch Spring Seat
23	0065417	Clutch Roller
24	3100618	Clutch Spacer
25	160005	Screw(M6-1×8)
26	0095065	Clutch Spring
27	0065415	Clutch Sleeve
28	0065418	Clutch Check Plate
29-1	0065422	Upper Feed Roller (30 teeth)
29-2	3101354	"
29-3	0065468	"
29-4	0066735	"
29-5	0066737	"
30	3100638	Lower Feed Roller Support, C. Set
31-1	0065461	Lower Feed Roller (15 teeth)
31-2	3101355	"
31-3	0065469	"
31-4	0066736	"
31-5	0066738	"
32	000492	Corrugated Washer
33	3100620	Lower Feed Roller Support
34	120006	Screw(M6-1×12)
35	000779	Knock Pin
36	3100622	Lower Feed Roller Shaft
37	150001	Screw(M4-0.7×4)
38	3100621	Lower Feed Roller Cover
39	130002	Screw(M3-0.5×6)
40	0065431	Supplementary Roller Support

Page 21 — PULLER MECHANISM (2)

Yamato VC3611 parts on page 21

Ref	Part number	Part name	Qty
41	000538	Washer	2
42	0065435	Supplementary Roller	1
43	0065436	Supplementary Roller Stay (A)	1
44	0065437	Supplementary Roller Stay (B)	1
45	009730	Screw (1/8-44×5.3)	4

Page 22 — PULLER MECHANISM EXCLUSIVE PARTS (3)

Yamato VC3611 parts on page 22

Ref	Part number	Part name	Qty
	0065381	Upper Feed Roller Lifter (Right)
	004440	Screw(11/64-40×8.3)
	000538	Washer
	000334	Nut
	0034979	Flexible Wire Clamp Bushing
	006075	Screw(11/64-40×6)
	0067126	Lifter Connecting Plate
	0065374	Upper Feed Roller Lifter (left)
	0065375	Upper Feed Roller Lifter Pin
	0095027	Retaining Ring
	0065376	Lifter Connecting Plate
	006038	Screw(3/16-32×2.2)
	0056507	Roller Press Bar Bracket
	005650	Screw(M5×8×14)
	0065402	Lifting Lever Sleeve
	006411	Screw(11/64-40×5.5)
	000340	Nut
	009931	Stop Screw(11/64-40×6)
	3100614	Roller Press Spring
	3100610	Upper Feed Roller Bracket
	009753	Screw(M6-1×35)
	000779	Knock Pin
	0065405	Roller Press Bar Bushing (Upper)
	160007	Screw(M6-1×6)
	3100609	Roller Press Bar Bushing (Lower)
	0056504	Upper Feed Roller Bar
	0034117	Retaining Ring
	000690	Stop Pin
	000613	Washer
	0067111	Upper Feed Roller Lifter Lever
	3101220	"
	000487	Corrugated Washer
	170008	Screw(M6-1×9)
	3100637	Upper Feed Roller Bracket, C. Set

Page 23

Yamato VC3611 parts on page 23

Ref	Part number	Part name	Qty
	3117088	Presser Foot, Complete Set (156)	1
	001186	Screw (9/64-40×7.8)	1
	0063280	Presser Foot Spring	1
	0065366	Presser Foot Guide Locking Pin	1
	0063282	Presser Foot Hinge Pin	1
	000327	Lock Nut	1
	003302	Adjusting Screw (1/8-44×1.1)	1
	3117084	Fabric Presser	1
	001228	Screw (3/32-56×3.2)	2
	3097052	Presser Foot, Complete Set (145)	1
	3099104	Needle Clamp (45)	1
	3098044	Stitch Plate (45L)	1
	0093356	Needle Clamp (48)	1
	0093357	"	1
	001900	Screw (1/8-44×2.4)	3
	3117122	Presser Foot, Complete Set (148)	1
	3117124	"	1
	3118024	Stitch Plate (48L)	1
	3118025	"	1
	0093863	Thread Tension Spring Cap	1
	0090814	Needle Thread Tension Spring	1
	0090071	Thread Tension Spring Retainer	1
	000177	Felt	1
	0031111	Tension Disc	2
	009835	Tension Post	1
	0090812	Tension Post Ferrule	1
	0090806	Tension Disc Eyelet	1
	0090807	Thread Lead-in Guide	1

Page 24 — VC3645P-D EXCLUSIVE PARTS (1)

Yamato VC3611 parts on page 24

Ref	Part number	Part name	Qty
	3110196	Front Cover (Upper)	1
	3110199	Fabric Guide (Left)	1
	000538	Washer	6
	L10009	Screw (M4-0.7×8)	4
	190056	Screw (M4-0.7×5)	1
	110012	Screw (M4-0.7×5)	1
	0094201	Cover Latch Spring	1
	3110197	Cylinder Holder	1
	110011	Screw (M5-0.8×10)	2
	000669	Washer	2
	3110198	Fabric Guide Holder	1
	0065233	Fabric Guide	1
	000535	Washer	1
	000644	Spring Washer	3
	004358	Screw (9/64-40×5.6)	2
	0094664	Collar (6.1×12×8)	1
	009604	Screw (11/64-40×5.5)	1
	000588	Anti-shock Rubber	1
	0067031	Cylinder Guide Bar Bushing	3
	3101260	Cylinder Guide Bar	1
	000009	Nut	2
	000426	Washer	2
	3110195	Elastic Tape Guide Bracket (Lower)	1
	3110194	Spacer	1
	110035	Screw (M4-0.7×10)	2
	3110193	Elastic Tape Guide Bracket (Upper)	1
	3110192	Elastic Tape Guide Bracket Cover	1
	3110191	Elastic Tape Holder	1
	3110190	Elastic Tape Guide	1
	130007	Screw (M4-0.7×10)	2
	3117094	Presser Foot, Complete Set (040)	1
	3117092	"	1
	3117090	"	1
	001186	Screw (9/64-40×7.9)	1
	0063280	Presser Foot Spring	1
	0065366	Presser Foot Locking Pin	1
	0063282	Presser Foot Hinge Pin	1
	000327	Lock Nut	1
	003302	Adjusting Screw (1/8-44×11)	1
	3110201	Fabric Presser Spacer	1
	3117048	Fabric Presser	1
	001228	Screw (3/32-56×3.2)	2
	3110200	Suction Pipe (Right)	1

Page 25 — VC3645P-D EXCLUSIVE PARTS (2)

Yamato VC3611 parts on page 25

Ref	Part number	Part name	Qty
	3100767	Tension Roller (Upper), C. Set (2)	1
	3100768	Tension Roller (Upper), C. Set (1)	1
	3100769	Tension Roller (Upper)	1
	3100770	Tension Roller Ball Bearing	4
	009220	Screw (11/64-40×8)	3
	0063469	Tension Roller Shaft	2
	000145	Nut	4
	0064173	Tension Roller Slider	2
	006475	Screw (M8-1.25×10)	2
	009980	Guide Screw (M6-1×10)	1
	3300101	Tension Roller Holder	1
	009955	Screw (M8-1.25×65)	2
	000443	Washer	4
	0031015	Slider Stop	2
	0031015	Slider Stop Handle	2
	009853	Screw (11/64-40×6.5)	2
	3110130	Tension Roller (Lower), C. Set (2)	1
	3120240	Tension Roller (Lower), C. Set (1)	1
	3120241	Tension Roller (Lower)	1
	0065258	Roller Holder (Lower)	1
	000428	Washer	2
	006920	Wood Screw (φ5.8×32)	2
	3120114	Elastic Tape Roller, C. Set	1
	0065253	Front Roller (Long)	1
	0067140	"	1
	0032719	Collar (10×16×6mm)	1
	001459	Screw (9/64-40×3)	1
	0067023	Elastic Tape Guide (Front)	1
	003638	Screw (11/64-40×4)	2
	3120244	Front Roller Shaft	1
	3120245	Front Roller Shaft Connector	1
	000429	Washer	1
	009936	Screw (M8-1.25×20)	1
	160007	Screw (M6-1×6)	3
	3120245	Front Roller Holding Shaft	1
	0067025	Bracket	2
	009877	Knob Bolt (M10-1.5×20)	2
	009947	Wood Screw (φ5.1×25)	4

Page 26 — "UT" DEVICE (1)

Yamato VC3611 parts on page 26

Ref	Part number	Part name	Qty
1	0065373	Lifter Lever
2	0093499	Lifter Lever Stop
3	004358	Screw(9/64-40×5.6)
4	3100533	Tension Release Lever
5	120001	Screw(M4-0.7×14)
6	3100526	Tension Release Block
7	007610	Screw(M4-0.7×10)
8	3100525	Tension Release Connecting Plate
9	110009	Screw(M4-0.7×8)
10	170009	Screw(M4-0.7×4)
11	3100536	Terminal Holder, Complete Set
12	3100535	Terminal Holder Support
13	0063586	Terminal Holder
14	009985	Screw(M2.5-0.45×10)
15	110012	Screw(M4-0.7×5)
16	0063612	Cord Clamp(4N-φ 6.8)
17	0094491	Cord Clamp(4N-φ 3.4)
18	0022836	Synchroniser Timing Pin
19	0022837	Synchroniser Cushion
20	0094387	Tension Release Shaft
21	3100529	Thread Pull-off Eyelet
22	0067101	Thread Pull-off Bar
23	0063076	Swing-proof Spring
24	0094433	Collar(4×11×7mm)
25	001208	Screw(9/64-40×5)

Page 27 — "UT" DEVICE (1)

Yamato VC3611 parts on page 27

Ref	Part number	Part name	Qty
	3101275	Thread Pull-off Hook Unit (See table)
	001459	Screw (9/64-40×3) (See table)
	3101276	Thread Pull-off Hook Unit (See table)
	0094396	Thread Pull-off Bar Holder
	0033024	Retaining Ring
	0063515	Thread Pull-off Lever
	000690	Dowel Pin
	0094390	Tension Release Adjusting Eccentric Screw
	0095334	Swing-proof Spring
	001170	Screw (9/64-40×12)
	3100528	Tension Disc Separator
	3100527	Tension Post Support
	110014	Screw (M4-0.7×18)
	000505	Spacer
	3101202	Connector Supporting Plate (Extra)
	110013	Screw (M4-0.7×8) (Extra)

Page 29

Yamato VC3611 parts on page 29

Ref	Part number	Part name	Qty
1	3100506	Lower Knife Driving Lever
2	170005	Screw(M4-0.7×6)
3	3100502	Lower Knife Carrier
4	3100514	Lower Knife Holder
5	3100513	Lower Knife
6	110030	Screw(M4-0.7×2.6)
7	3100501	Upper Knife Carrier
8	190006	Screw(M4-0.7×4)
9	100006	Nut
10	3100503	Knife Guide Lever
11	3100504	Knife Guide Lever Ring (Left)
12	3100505	Knife Guide Lever Ring (Right)
13	130003	Screw(M4-0.7×7.3)
14	3100515	Upper Knife Carrier Spring
15	3100506	Screw(M4-0.7×3)
16	170006	Screw(M4-0.7×2.5)
17	3100531	Upper Knife Carrier Stop
18	110008	Screw(M4-0.7×5)
19	3100517	Lower Knife Carrier Guide
20	110009	Screw(M4-0.7×8)
21	3100518	Lower Knife Carrier Guide (Upper)
22	110002	Screw(M3-0.5×5)
23	3100512	Upper Knife
24	110024	Screw(M2-0.4×6)
25	110025	Screw(M2-0.4×10)
26	110023	Screw(M2-0.4×3.5)
27	3100507	Upper Knife Guide
28	3100508	Clamp Spring
29	3100509	Clamp Spring Pressure
30	3100510	Clamp Spring Pressure Holder
31	3100511	Clamp Spring Pressure Adjusting Piece
32	130005	Screw(M2-0.4×4)
33	3100516	Lower Knife Carrier Support Spring
34	110034	Screw(M2-0.4×2)
35	3100565	Supplementary Spring
36	110031	Screw(M4-0.7×12)
37	3100560	Trimming Mechanism, C. Set
38	3100530	Looper Thread Pull-off

Page 30

Yamato VC3611 parts on page 30

Ref	Part number	Part name	Qty
39	3100541	Soleno id Support	1
40	0010841	Wiper Solenoid	1
41	000002	Spring Washer	2
42	000012	Nut	2
43	3100546	Wiper Solenoid Lever	1
44	120007	Screw (M3-0.5×10)	1
45	3100542	Wiper Link	1
46	170007	Screw (M3-0.5×2.5)	3
47	3100543	Wiper Bracket	1
48	3100548	Wiper Thread Guide	1
49	3100544	Wiper	1
50	3100545	Wiper Fixing Washer	1
51	110007	Screw (M2.5-0.45×6)	2
52	3100547	Thread Clamp Spring Plate	1
53	000531	Washer	1
54	3109930	Wiper Mechanism, Complete Set	1

Page 31 — "UT" DEVICE (4)

Yamato VC3611 parts on page 31

Ref	Part number	Part name	Qty
	3100571	Presser Foot Lifter Solenoid, C. Set
	3100570	Solenoid Support
	000070	Hanging Nut
	000429	Washer
	000016	Nut
	009865	Hanging Bolt
	000676	Spring Washer
	0011733	Presser Foot Lifter Solenoid
	009970	Screw(M6-1×20)
	000011	Nut
	000528	Washer
	000588	Anti-shock Rubber
	000306	Nut
	0064045	Lifter Connecting Rod
	0064046	Lifter Connecting Link
	0035301	Connecting Link Pin
	0033024	Retaining Ring
	0064047	Presser Foot Lifter Solenoid Lever
	009853	Screw(M6-40×6.5)
	0032786	Solenoid Lever Pin
	0037912	Chain

Page 32 — "UT-A" DEVICE (1)

Yamato VC3611 parts on page 32

Ref	Part number	Part name	Qty
	0065373	Lifter Lever	1
	0037912	Chain	1
	0093499	Lifter Lever Stop	1
	004358	Screw (9/64-40×5.6)	2
	3100523	Tension Release Lever	1
	120001	Screw (M4-0.7×14)	1
	3100526	Tension Release Block	1
	007610	Screw (M4-0.7×10)	2
	3100065	Tension Release Connecting Plate	1
	110009	Screw (M4-0.7×8)	2
	170009	Screw (M4-0.7×4)	1
	0094491	Cord Clamp (2N-φ3.4)	2
	110012	Screw (M4-0.7×5)	4
	0022836	Synchronizer Positioning Pin	1
	0022837	Synchronizer Cushion	1
	190009	Screw (M4-0.7×7)	1
	0096358	Air Wiper Bracket	1
	009747	Screw (M4-0.7×10)	1
	000644	Spring Washer	1
	000532	Washer	1
	0096357	Air Wiper	1
	009744	Screw (M3-0.5×10)	1
	000002	Spring Washer	1
	000014	Washer	1
	3100529	Thread Pull-off Eyelet	1

Page 33 — "UT-A" DEVICE (1)

Yamato VC3611 parts on page 33

Ref	Part number	Part name	Qty
	0067101	Thread Pull-off Bar
	0063076	Swing-proof Spring
	0094433	Collar (4×11×7mm)
	001208	Screw (9/64-40×5)
	3101275	Thread Pull-off Hook Unit (See table)
	001459	Screw (9/64-40×3) (See table)
	3101276	Thread Pull-off Hook Unit (See table)
	0094396	Thread Pull-off Bar Holder
	0033024	Retaining Ring
	0063515	Thread Pull-off Lever
	000690	Dowel Pin
	0094390	Tension Release Adjusting Eccentric
	0095334	Swing-proof Spring
	001170	Screw (9/64-40×12)
	3100528	Tension Disc Separator
	3100527	Tension Post Support
	110014	Screw (M4-0.7×18)
	000505	Spacer
	0094387	Tension Release Shaft

Page 34 — "UT-A" DEVICE (2)

Yamato VC3611 parts on page 34

Ref	Part number	Part name	Qty
	1091002	Trimming Cylinder, Complete Set
	0010340	Trimming Cylinder
	0010057	Elbow Connector
	0010143	Silencer
	000389	Spacer
	0014120	Anti-shock Rubber
	0033104	Collar(10×18×9mm)
	005550	Screw(11/64-40×13.5)
	0096355	Cylinder Bracket
	005650	Screw(M5-0.8×14)
	3100524	Trimming Cylinder Support
	120013	Screw(M6-1×15)
	0063610	Switch, Complete Set
	0063607	Switch Support
	110004	Screw(M3.5-0.6×8)
	0063606	Switch
	0063609	Switch Cover
	009984	Screw(M2.3-0.4×10)
	0063608	Switch Guide
	110002	Screw(M3-0.5×5)
	0036133	Cord Clamp(5N-φ 8.4)
	000145	Nut
	0095388	Plunger Connecting Rod
	001457	Packing Screw(11/64-40×3.3)
	0095389	Plunger Connecting Rod Pin
	3100520	Plunger
	160002	Screw(M4-0.7×5)
	3100532	Cylinder Return Shaft
	0093491	Collar(8×16×8mm)
	009508	Screw(11/64-40×7.5)
	0095336	Cylinder Return Spring
	180006	Screwed Pin(M5-0.8×6)
	3100523	Connecting Block(Right) Support
	3100522	Connecting Block(Right)
	100001	Nut
	190008	Connecting Rod
	3100521	Connecting Block(Left)

Page 35 — UT-A DEVICE (3)

Yamato VC3611 parts on page 35

Ref	Part number	Part name	Qty
	3100506	Lower Knife Driving Lever
	170005	Screw(M4-0.7×6)
	3100502	Lower Knife Carrier
	3100514	Lower Knife Holder
	3100513	Lower Knife
	110030	Screw(M3-0.5×2.6)
	3100501	Upper Knife Carrier
	190006	Screw(M4-0.7×4)
	100006	Nut
	3100503	Knife Guide Lever
	3100504	Knife Guide Lever Ring(Left)
	3100505	Knife Guide Lever Ring(Right)
	130003	Screw(M4-0.7×7.3)
	3100515	Upper Knife Carrier Spring
	170006	Screw(M4-0.7×2.5)
	3100500	Crank Chamber Cover
	3100531	Upper Knife Carrier Stop
	110008	Screw(M4-0.7×5)
	3100517	Lower Knife Carrier Guide
	110009	Screw(M4-0.7×8)
	3100518	Lower Knife Carrier Guide (Upper)
	110002	Screw(M3-0.5×5)
	3100512	Upper Knife
	110024	Screw(M2-0.4×6)
	110025	Screw(M2-0.4×10)
	110023	Screw(M2-0.4×3.5)
	3100507	Upper Knife Guide
	3100508	Clamp Spring
	3100509	Clamp Spring Pressure
	3100510	Clamp Spring Pressure Holder
	3100511	Clamp Spring Pressure Adjusting Piece
	130005	Screw(M2-0.4×4)
	3100516	Lower Knife Carrier Support Spring
	110034	Screw(M2-0.4×2)
	3100560	Supplementary Spring
	110031	Screw(M4-0.7×12)
	3100565	Trimming Mechanism, C. Set
	3100530	Looper Thread Pull-off

Page 36

Yamato VC3611 parts on page 36

Ref	Part number	Part name	Qty
	0010073	Regulator	1
	009973	Screw (M5-0.8×10)	2
	000669	Washer	2
	000600	Spring Washer	2
	000009	Nut	2
	0013218	Regulator Support	1
	009937	Wood Screw (φ3.8×20)	2
	0033939	Hose Band	1
	0010108	Hose Connector(φ8-1/4)	1
	0010289	T-Joint	1
	3201035	Presser Foot Lifter Cylinder, C. Set	1
	0033104	Cylinder Stop Collar	1
	005550	Screw(11/64-40×13.5)	1
	1091050	Rubber Cushion	1
	3201037	Presser Foot Lifter Cylinder	1
	3201037	Cylinder Rod Chip	1
	3201036	Cylinder Bracket	1
	120013	Screw(M6-1×15)	2
	000425	Washer	2
	0010057	Elbow Connector	5
	0010343	Electromagnetic Valve, C. Set (UT-A2)	1
	1090012	Manifold	1
	009880	Wood Screw (φ4.5×40)	2
	0010143	Silencer	2
	0010263	Connector(φ6-PT1/8)	1
	0010119	Seal Plug	3
	1090011	Electromagnetic Valve	3
	1090011	"	4
	0010254	Speed Controller (UT-A2)	1
	0010254	"	3
	0010868	Cord (A)	1
	0010869	Cord (B)	1
	0010261	Vinyl Tube (6×4mm)
	0010260	Vinyl Tube (4×2.5mm)
	1090100	Electromagnetic Valve, C. Set (UT-A2)	1
	1090013	Manifold	1
	1200003	Cord (C)	1

Page 37 — AS3 DEVICE

Yamato VC3611 parts on page 37

Ref	Part number	Part name	Qty
	0010073	Regulator	1
	0013218	Regulator Support	1
	009973	Screw (M5-0.8×10)	2
	000669	Washer	2
	000600	Spring Washer	2
	000009	Nut	4
	006905	Wood Screw (φ 5.1×20)	6
	0033939	Hose Band(1/4inch)	1
	0010108	Joint	1
	0010078	Joint	1
	0010260	Vinyl Tube (4×2.5mm)	1
	1090010	Electromagnetic Valve, C. Set	1
	0010120	Electromagnetic Valve	1
	0010055	Straight Joint	2
	0010119	Seal Plug	1
	0010254	Speed Controller (SPC4-1/8)	1
	009937	Wood Screw (φ 3.8×20)	1
	1094000	Joint	2
	000623	Gasket	1
	0010048	Air Cylinder (MS-16ND-45)	1
	000426	Washer	2
	0010019	L-Connector (M-5UL)	1
	0010258	Connector	1
	0011709	Control Box Stay	2
	0011341	Control Box, Complete Set	1
	0011340	Control Board	1
	0010565	Knee Switch, Complete Set	1
	0010564	Knee Switch	1
	000538	Washer	4
	000644	Spring Washer	2
	000023	Wing Nut	2
	0092232	Knee Switch Holder	1
	006910	Wood Screw (φ 6.8×26)	2
	0011943	Power Cord (for 100 Voltage)	1
	0011944	"
	0011945	"
	0011946	"

Page 38 — EXTRA PARTS

Yamato VC3611 parts on page 38

Ref	Part number	Part name	Qty
1	0022836	Synchronizer Positioning Pin
2	0022837	Synchronizer Cushion
3	007610	Screw (M4-0.7×10)
4	0093690	Timing Gauge
5	0095220	Looper Timing Gauge
6	3100490	Timing Gauge
7	3200242	Chain Guide
8	110009	Screw (M4-0.7×8)
9	000541	Washer
10	1090101	Electromagnetic Valve, C. Set
11	0010120	Electromagnetic Valve
12	009937	Wood Screw (φ3.8×20)
13	0010263	Connector (φ6-PT1/8)
14	0010143	Silencer
15	0010119	Seal Plug
16	0010254	Speed Controller (SPCA-1/8)

Page 39 — THREAD STAND & SUPPORTING BOARD

Yamato VC3611 parts on page 39

Ref	Part number	Part name	Qty
	0099056	Thread Stand, Complete Set (5 Spools Type)
	0099048	Thread Stand, Complete Set (6 Spools Type)
	0099057	Column Cap
	0099058	Column Pipe (Upper)
	0099060	Thread Hanger (3 Spools Type)
	0099059	Thread Hanger (2 Spools Type)
	000147	Screw
	000148	Washer
	0099061	Column Pipe Connector
	000149	Screw
	000152	Nut
	0099062	Thread Guide Holder
	0099063	Column Pipe (Lower)
	000154	Washer
	000153	Nut
	0099030	Thread Guide Bar
	0099031	Thread Guide Bar Bracket
	0099064	Thread Guide
	003632	Screw (1/4-40×10)
	0099065	Spool Cushion
	0099066	Spool Pin
	000157	Spring Washer
	0099067	Spool Mat
	0099068	Spool Seat Disc
	0099069	Spool Holder Stay
	000158	Screw
	000159	Wood Screw
	0099070	Spool Holder (3 Spools type)
	0099071	Spool Holder (2 Spools type)
	0063031	Belt Cover
	110028	Screw (M6-1×46)
	3100008	Supporting Board
	180009	Setting Screw (M6-1×19)
	0063009	Oil Reservoir Rubber Cushion
	000070	Hanging Nut
	009858	Hanging Bolt (M8-1.25×75)
	000429	Washer
	0020064	Supporting Board Rubber Cushion
	0063010	Supporting Board Rubber Cushion (Lower)
	000016	Nut
	180008	Setting Screw (M6-1×63)
	000528	Washer
	000667	Spring Washer
	000011	Nut

Page 40 — VC3611-D CLASS LIST of MAIN SPARE PARTS

Yamato VC3611 parts on page 40

Ref	Part number	Part name	Qty
3118021	0093352	3117076
3118022	0093353	3117078
3118023	3009101	3117080
3098044	3099104	3097052
3118033	3099101	3117088
3118021	0093352	3117094
3118022	0093353	3117092
3118023	3009101	3117090
3118024	0093356	3117122
3118025	0093357	3117124
41	000002	000002
23	000002	000002
43	000005	000005
24	000009	000009
8	000009	000009
29	000010	000010
48	000010	000010
10	000011	000011
45	000011	000011
38	000014	000014
24	000014	000014
5	000016	000016
41	000016	000016
31	000023	000023
3	000070	000070
36	000070	000070
4	000140	000140
15	000145	000145
7	000145	000145
20	000145	000145
22	000145	000145
6	000147	000147
7	000148	000148
10	000149	000149
16	000152	000152
15	000153	000153
23	000154	000154
27	000157	000157
5	000158	000158
4	000159	000159
20	000177	000177
4	000177	000177
5	000177	000177
40	000199	000199
3	000234	000234
18	000304	000304
21	000306	000306
18	000306	000306
13	000306	000306
21	000321	000321
42	000327	000327
6	000327	000327
39	000327	000327
31	000334	000334
4	000334	000334
17	000340	000340
31	000360	000360
5	000389	000389
17	000397	000397
47	000397	000397
5	000417	000417
45	000419	000419
19	000425	000425
25	000426	000426
21	000426	000426
21	000429	000429
22	000429	000429
21	000429	000429
33	000433	000433
38	000443	000443
8	000445	000445
26	000463	000463
31	000487	000487
32	000505	000505
39	000505	000505
23	000528	000528
10	000528	000528
15	000528	000528
33	000528	000528
17	000530	000530
5	000531	000531
53	000531	000531
3	000532	000532
6	000532	000532
16	000532	000532
27	000532	000532
2	000535	000535
21	000535	000535
3	000538	000538
18	000538	000538
19	000538	000538
21	000538	000538
16	000541	000541
32	000541	000541
4	000547	000547
7	000548	000548
6	000555	000555
14	000567	000567
21	000588	000588
26	000588	000588
24	000597	000597
24	000598	000598
6	000600	000600
10	000600	000600
30	000600	000600
17	000613	000613
17	000613	000613
31	000623	000623
7	000629	000629
7	000637	000637
7	000637	000637
2	000644	000644
21	000644	000644
30	000644	000644
30	000644	000644
17	000651	000651
38	000651	000651
12	000652	000652
44	000667	000667
43	000669	000669
13	000669	000669
3	000669	000669
4	000669	000669
20	000690	000690
28	000690	000690
32	000690	000690
36	000690	000690
18	000723	000723
34	000726	000726
19	000730	000730
46	000740	000740
43	000750	000750
3	000779	000779
3	000779	000779
35	000779	000779
18	000924	000924
18	000924	000924
17	000926	000926
4	000989	000989
47	001093	001093
14	001107	001107
30	001107	001107
35	001107	001107
39	001170	001170
21	001174	001174
16	001174	001174
15	001186	001186
2	001186	001186
35	001186	001186
25	001208	001208
29	001208	001208
18	001227	001227
45	001228	001228
9	001228	001228
43	001228	001228
26	001230	001230
22	001457	001457
24	001457	001457
13	001459	001459
26	001459	001459
27	001459	001459
28	001818	001818
9	001900	001900
21	001900	001900

Page 44 — INDEX

Yamato VC3611 parts on page 44

Ref	Part number	Part name	Qty
14	3100515	3100515	29
14	3100515	3100515	29
33	3100516	3100516	25
33	3100516	3100516	29
19	3100517	3100517	25
19	3100517	3100517	29
21	3100518	3100518	25
21	3100518	3100518	29
24	3100520	3100520	24
24	3100520	3100520	29
35	3100521	3100521	24
37	3100521	3100521	28
32	3100522	3100522	24
32	3100522	3100522	28
31	3100523	3100523	24
33	3100523	3100523	28
9	3100524	3100524	24
11	3100524	3100524	28
8	3100525	3100525	23
9	3100525	3100525	27
6	3100526	3100526	23
7	3100526	3100526	27
37	3100527	3100527	23
41	3100527	3100527	27
26	3100528	3100528	23
36	3100528	3100528	27
21	3100529	3100529	23
25	3100529	3100529	27
38	3100530	3100530	25
38	3100530	3100530	29
17	3100531	3100531	25
17	3100531	3100531	29
26	3100532	3100532	24
26	3100532	3100532	28
4	3100533	3100533	23
5	3100533	3100533	27
12	3100535	3100535	23
11	3100536	3100536	23
39	3100541	3100541	25
45	3100542	3100542	25
47	3100543	3100543	25
49	3100544	3100544	25
50	3100545	3100545	25
43	3100546	3100546	25
52	3100547	3100547	25
48	3100548	3100548	25
3-2	3100555	3100555	9
35	3100560	3100560	25
35	3100560	3100560	29
37	3100565	3100565	25
37	3100565	3100565	29
2	3100570	3100570	26
1	3100571	3100571	26
29	3100600	3100600	17
28	3100601	3100601	17
24	3100602	3100602	17
27	3100603	3100603	17
6	3100604	3100604	17
12	3100605	3100605	17
5	3100607	3100607	17
13	3100608	3100608	17
20	3100609	3100609	18
20	3100610	3100610	19
1	3100611	3100611	18
3	3100612	3100612	18
5	3100613	3100613	18
19	3100614	3100614	18
17	3100615	3100615	18
12	3100616	3100616	18
11	3100617	3100617	18
24	3100618	3100618	18
33	3100619	3100619	18
10	3100620	3100620	17
36	3100621	3100621	17
26	3100622	3100622	17
17	3100623	3100623	17
10	3100626	3100626	17
33	3100636	3100636	19
33	3100637	3100637	19
30	3100638	3100638	18
1	3100767	3100767	22
2	3100768	3100768	22
3	3100769	3100769	22
4	3100770	3100770	22
23	3101200	3101200	4
40	3101202	3101202	4
30-2	3101220	3101220	19
23	3101260	3101260	21
26	3101275	3101275	23
30	3101275	3101275	27
28	3101276	3101276	28
27	3101276	3101276	27
50	3101300	3101300	11
29-2	3101354	3101354	18
31-2	3101355	3101355	18
6	3109200	3109200	11
10-1	3109201	3109201	11
10-2	3109210	3109210	11
1	3109300	3109300	9
25	3109310	3109310	15
54	3109930	3109930	25
28	3110010	3110010	2
37	3110012	3110012	2
14	3110014	3110014	2
18	3110031	3110031	12
4	3110032	3110032	12
7	3110033	3110033	12
1	3110034	3110034	12
2	3110037	3110037	12
5	3110038	3110038	12
19	3110039	3110039	12
16	3110051	3110051	12
40	3110070	3110070	2
41	3110072	3110072	2
45	3110108	3110108	2
52	3110109	3110109	2
17	3110130	3110130	22
35	3110150	3110150	1
19	3110160	3110160	1
35	3110161	3110161	2
3	3110162	3110162	2
15	3110163	3110163	2
3	3110169	3110169	13
10	3110170	3110170	12
1	3110171	3110171	13
30	3110172	3110172	12
25	3110173	3110173	12
20	3110174	3110174	12
5	3110180	3110180	13
38	3110185	3110185	1
32	3110190	3110190	21
31	3110191	3110191	21
30	3110192	3110192	21
29	3110193	3110193	21
27	3110194	3110194	21
26	3110195	3110195	21
1	3110196	3110196	21
11	3110197	3110197	21
14	3110198	3110198	21
2	3110199	3110199	21
44	3110200	3110200	21
41	3110201	3110201	21
42	3117048	3117048	21
15-2	3117070	3117070	20
14-1	3117076	3117076	8
14-1	3117078	3117078	8
14-2	3117078	3117078	8
14-3	3117080	3117080	8
44	3117084	3117084	8
8	3117084	3117084	20
1	3117088	3117088	20
34-3	3117090	3117090	21
34-2	3117092	3117092	21
34-1	3117094	3117094	21
10-1	3118021	3118021	7
10-2	3118022	3118022	7
10-3	3118023	3118023	7
16-1	3118024	3118024	20
16-2	3118025	3118025	20
35	3119020	3119020	11
34	3119021	3119021	11
7	3120033	3120033	13
23	3120114	3120114	22
18	3120240	3120240	22
19	3120241	3120241	22
30	3120243	3120243	22
29	3120244	3120244	22
34	3120245	3120245	22
17	3200047	3200047	16
10	3200048	3200048	16
12	3200049	3200049	16
24	3200063	3200063	16
25	3200064	3200064	16
13	3200086	3200086	12
7	3200242	3200242	32
22	3200251	3200251	4
25	3200252	3200252	4
11	3201035	3201035	30
17	3201036	3201036	30
16	3201037	3201037	30
11	3300101	3300101	22
33	4109403	4109403	1

Part BooksPartsSearchNotes

Part Books

×

Search

×

Yamato VC3611 — parts catalog

• Page 1 (cover): This is the cover page for the Illustrated Spare Parts List for Yamato Industrial Sewing Machine, High Speed Cylinder Bed Interlock Machine with Differential Feeding, Models VC3611-D, VC3711-D, and VC3645P-D.
• Page 2 (toc): This page contains the table of contents for a parts book, listing various mechanisms and components with corresponding page numbers. It also mentions the specific models the parts book is based on.
• Page 3 (parts_list): This page lists miscellaneous covers and related parts for an industrial sewing machine, including part numbers, descriptions, and quantities required.
• Page 4 (parts_list): This page lists miscellaneous covers and related parts for an industrial sewing machine, including screws, washers, and guides, with part numbers, descriptions, and quantities.
• Page 6 (parts_list): This page lists miscellaneous bushings and eye guards for industrial sewing machines, including part numbers, descriptions, and quantities.
• Page 7 (parts_list): This page lists parts for the Main Shaft Driving Mechanism, including pulleys, screws, bearings, shafts, and other components with their corresponding part numbers and descriptions.
• Page 8 (diagram): This page displays a diagram and parts list for the upper shaft and needle thread take-up mechanism, detailing components such as handwheels, screws, bearings, shafts, and connecting rods.
• Page 9 (parts_list): This page lists parts for the Needle Bar Mechanism, including part numbers, descriptions, and quantities.
• Page 10 (diagram): This page contains a diagram and parts list for the Presser Foot Mechanism, detailing various screws, springs, levers, and other components with their respective part numbers and descriptions.
• Page 11 (parts_list): This page lists parts for the Looper Driving Mechanism, including part numbers, descriptions, and quantities.
• Page 12 (diagram): This page contains a diagram and parts list for the Feed Driving Control Mechanism, with part numbers, descriptions, and quantities.
• Page 13 (parts_list): This page lists parts for the Needle Guard & Feed Driving Mechanism, including part numbers, descriptions, and quantities.
• Page 15 (parts_list): This page lists miscellaneous suction pipe components with their part numbers, descriptions, and quantities. It includes screws, pipes, hoses, and valves, with a note regarding vinyl tube orders.
• Page 16 (diagram): This page displays a diagram of the lubricating mechanism with a corresponding parts list, detailing components like oil receivers, screws, nuts, oil wicks, and various oil tubes and filters.
• Page 17 (parts_list): This page lists parts for the Spreader Mechanism, including part numbers, descriptions, quantities, and applicable models.
• Page 18 (parts_list): This page lists miscellaneous top cover thread parts for sewing machines, including part numbers, descriptions, and quantities. It also specifies applicable models.
• Page 19 (diagram): This page contains a diagram of the puller mechanism (1) with associated parts listed in a table, including part numbers, descriptions, and quantities.
• Page 20 (parts_list): This page lists parts for the Puller Mechanism (2), including various screws, rollers, shafts, and clutch components with their corresponding part numbers and descriptions.
• Page 21 (diagram): This page contains a diagram of the puller mechanism (2) and a list of exclusive parts for the puller mechanism, including part numbers, descriptions, and quantities.
• Page 22 (parts_list): This page lists parts for the Puller Mechanism (3) and Puller Mechanism Exclusive Parts (3), including part numbers, descriptions, and quantities.
• Page 23 (parts_list): This page lists parts for various sewing machine models including VC3611-156L-D, VC3611-145L-D, VC3711-148L-D, and VC3711-156L-D, detailing part numbers, descriptions, and quantities.
• Page 24 (parts_list): This page lists exclusive parts for the VC3645P-D model, including front covers, fabric guides, screws, washers, and other components with their respective part numbers and quantities.
• Page 25 (parts_list): This page lists exclusive parts for the VC3645P-D model, including tension rollers, screws, nuts, washers, and other components with their corresponding part numbers and descriptions.
• Page 26 (diagram): This page displays a diagram of the "UT" DEVICE (1) with a corresponding parts list detailing items 1 through 25, and a device classification table.
• Page 27 (diagram): This page displays a diagram of the "UT" Device (1) with associated parts listed and described. It includes a table detailing quantities for different needle configurations.
• Page 29 (parts_list): This page lists parts for the "UT" DEVICE (3) with part numbers, descriptions, and quantities. It includes items from reference number 1 to 38.
• Page 30 (diagram): This page contains a diagram of the "UT" DEVICE (3) and EXTRA PARTS, with associated part numbers and descriptions.
• Page 31 (diagram): This page displays a diagram of the "UT" DEVICE (4) with a corresponding parts list detailing components such as the Presser Foot Lifter Solenoid, Solenoid Support, and various nuts, washers, and screws.
• Page 32 (diagram): This page contains a diagram of the "UT-A" DEVICE (1) with a parts list detailing components such as lifter levers, chains, screws, and washers, along with a device classification table.
• Page 33 (diagram): This page displays a diagram of the "UT-A" DEVICE (1) with corresponding parts listed in a table, including part numbers, descriptions, and quantities.
• Page 34 (diagram): This page displays a diagram of the "UT-A" DEVICE (2) with a corresponding parts list detailing 37 components, including cylinders, screws, switches, and connecting blocks.
• Page 35 (parts_list): This page lists parts for the "UT-A" DEVICE (3) with part numbers, descriptions, and quantities.
• Page 36 (parts_list): This page lists parts for the "UT-A" DEVICE (4) and "UT-A" 装置 (4), including regulators, screws, washers, nuts, hose connectors, cylinders, manifolds, and vinyl tubes, with corresponding part numbers and quantities.
• Page 37 (parts_list): This page lists parts for the "AS3" DEVICE, including part numbers, descriptions, and quantities. It also contains diagrams of the device and its components.
• Page 38 (parts_list): This page lists extra parts for an industrial sewing machine, including synchronizer positioning pins, timing gauges, screws, washers, chain guides, connectors, silencers, seal plugs, and speed controllers, along with their part numbers and quantities.
• Page 39 (parts_list): This page lists parts for the Thread Stand & Supporting Board, including part numbers, descriptions, and quantities.
• Page 40 (parts_list): This page contains a parts list for the VC3611-D class, including main parts, needle clamp, presser foot C. set, stitch plate, differential feed dog, main feed dog, and looper, along with an index of parts with their corresponding page and reference numbers.
• Page 44 (parts_list): This page contains a parts list for an industrial sewing machine, with part numbers, page references, and weights listed for various components. It is part of a larger index, with this page being page 8 and page 9 of the index.

Page 1 — ILLUSTRATED SPARE PARTS LIST FOR HIGH SPEED CYLINDER BED INTERLOCK MACHINE WITH DIFFERENTIAL FEEDING

yamato INDUSTRIAL SEWING MACHINE ILLUSTRATED SPARE PARTS LIST FOR HIGH SPEED CYLINDER BED INTERLOCK MACHINE WITH DIFFERENTIAL FEEDING MODELS & DEVICES VC3611-D VC3711-D VC3645P-D UT UT-A AS3 No. 2-1 jintex.in

Page 2

CONTENTS MISCELLANEOUS COVERS (1) " " (2) MISCELLANEOUS THREAD EYELETS MISCELLANEOUS BUSHINGS & EYE GUARD MAIN SHAFT DRIVING MECHANISM UPPER SHAFT & NEEDLE THREAD TAKE-UP MECHANISM NEEDLE BAR MECHANISM PRESSER FOOT MECHANISM LOOPER DRIVING MECHANISM FEED DRIVING CONTROL MECHANISM NEEDLE GUARD & FEED DRIVING MECHANISM KNIFE DRIVING MECHANISM MISCELLANEOUS SUCTION PIPE LUBRICATING MECHANISM SPREADER MECHANISM MISCELLANEOUS TOP COVER THREAD PULLER MECHANISM EXCLUSIVE PARTS (1) " " (2) " " (3) VC3611-156L-D, 145L-D, VC3711-148L-D, 156L-D EXCLUSIVE PARTS VC3645P-D EXCLUSIVE PARTS (1) "UT" DEVICE (1) " " (2) " " (3) " " (4) "UT-A" DEVICE (1) " " (2) " " (3) " " (4) "AS3" DEVICE EXTRA PARTS THREAD STAND & SUPPORTING BOARD LIST of MAIN SPARE PARTS INDEX 目 次 カバー関係(1) 1 " " (2) 2 ・糸道関係 3 ・プッシュ及びアイガード関係 4 ・下軸機構 5 ・上軸及び針糸繰り機構 6 ・針棒機構 7 ・押工機構 8 ・ルーパ機構 9 ・前送り調節機構 10 ・針受及び送り機構 11 ・メス機構 12 ・吸込管関係 13 ・給油機構 14 ・飾り糸ルーパ機構 15 ・飾り糸関係 16 ・プラー機構専用部品(1) 17 " " (2) 18 " " (3) 19 サブモデル専用部品 20 サブモデル専用部品(1) 21 " " (2) 22 "UT"装置(1) 23 " " (2) 24 " " (3) 25 " " (4) 26 "UT-A"装置(1) 27 " " (2) 28 " " (3) 29 " " (4) 30 "AS3"装置 31 ・特注部品 32 ・糸立台及び受ケ板 33 ・主要部品リスト 34 ・索引 35 Illustration of this Parts Book is based on the Model VC3611-040L (048L, 056L)-D. このパーツブックは VC3611-040L (048L, 056L)-Dを基本モデルにしてイラストを作成して おります。 jintex.in

Page 3 — MISCELLANEOUS COVERS (1)

1 Amt. Req. MISCELLANEOUS COVERS (1) カバー関係(1) Ref. No Parts No Description 品 名 1 3100012 Top Cover 上カバー 11 2 110045 Screw (M4-0.7×12) 止ネジ 1 3 3100013 Top Cover Gasket 上カバーパッキン 1 4 0068011 Oil Sight Window オイル確認窓 1 5 0020759 Top Cover Seal Plug 上カバー詰栓 1 6 390069 Brand Name Plate (76.5) 銘板 1 7 3100010 Head Cover ヘッドカバー 1 8 3100011 Head Cover Gasket ヘッドカバーパッキン 1 9 0093864 Head Cover Seal Plug 詰栓 1 10 390072 "VC" Emblem VCエンブレム 1 11 3100040 Side Cover Hinge 横開キカバーヒンジ 1 12 3100041 Side Cover Hinge Gasket 横開キカバーヒンジパッキン 1 13 110048 Screw (M4-0.7×10) 止ネジ 2 14 3100042 Side Cover Hinge Pin 横開キカバーヒンジピン 1 15 160000 Screw (M3-0.5×3) 止ネジ 1 16 3100043 Side Cover 横開キカバー 1 17 3100044 Side Cover Gasket 横開キカバーパッキン 1 18 000924 Seal Plug (Rubber) 詰栓(ゴム) 1 19 3110160 Cloth Plate クロスプレート 1 20 110041 Screw (M4-0.7×8) 止ネジ 2 21 0094201 Cover Latch Spring カバーラッチバネ 1 22 110015 Screw (M4-0.7×5) 止ネジ 1 23 3100046 Side Cover Hook 横開キカバーフック 1 24 300101 Conical Spring Washer 皿バネワッシャ 1 25 170002 Screw (M4-0.7×5) 止ネジ 1 26 3100004 Oil Reservoir 油受 1 27 3100005 Oil Reservoir Gasket 油受ケパッキン 1 28 0020143 Magnet マグネット 1 29 0020144 Magnet Holder マグネット押エ 1 30 110013 Screw (M4-0.7×8) 止ネジ 1 31 0020137 Drain Hole Seal 油抜キネジパッキン 1 32 005075 Screw (3/8-24×8) 油抜キネジ 3 33 4109403 Model Plate (See the below) 型式板(下記参照) 1 34 000726 Rivet 止メ鋲 3 35 3110150 Machine Frame Unit アームベッド(組) 1 36 120016 Screw (M8-1.25×20) 止ネジ 4 37 340000 Machine Frame Supporting Bar ベッド支エ棒 4 38 3110185 Supplementary Cloth Plate クロスプレート補助板 1 39 006233 Screw (M3-0.5×5) 止ネジ 2 (注) 型式板を御注文の際機種名(ゲージ記号、付属品含む)をお知らせ下さい。 Note: Order for Model Plate must be accompanied by model designation(including symbols of gauge and devices).

Page 4 — MISCELLANEOUS COVERS (2)

2 MISCELLANEOUS COVERS (2) カバー関係(2) Ref. No. Parts No. Description Amt. Req. 41 3110072 Edge Guide Chip 定規チップ 1 42 004182 Screw (3/32-56×1.5) 止ネジ 1 43 000005 Washer ワッシャ 2 44 110008 Screw (M4-0.7×5.4) 止ネジ 2 45 3110108 Fabric Guide Holder 布ガイド台 1 46 000538 Washer ワッシャ 4 47 110009 Screw (M4-0.7×8) 止ネジ 2 48 3110115 Fabric Guide 布ガイド 1 49 000535 Washer ワッシャ 2 50 000644 Spring Washer スプリングワッシャ 2 51 004358 Screw (9/64-40×5.6) 止ネジ 2 52 3110109 Fabric Guide (Right) 布ガイド(右) 1 53 110043 Screw (M4-0.7×14) 止ネジ 2 54 2100265 Spacer スペーサ 2 55 000629 Seal Plug 詰栓 1 56 160007 Screw (M6-1×6) 詰ネジ 1 57 390067 Brand Name Plate (10) 銘板 1 58 390068 Brand Name Plate (92) 銘板 1 * Ref. No. 1 to 40 See the preceding page.

Page 6 — MISCELLANEOUS BUSHINGS & EYE GUARD

4 MISCELLANEOUS BUSHINGS & EYE GUARD ブッシュ及びアイガード関係 4 Ref. No. Parts No. Description Amt. Req. 1 3100106 Needle Bar Bushing (Upper) 針棒ブッシュ(上) 1 2 3100107 Needle Bar Bushing (Lower) 針棒ブッシュ(下) 1 3 0030291 Presser Bar Bushing 押エ棒ブッシュ 1 4 000091 Oil Seal オイルシール 1 5 0063548 Seal Plug 詰栓 2 6 0094604 Seal Plug 詰栓 1 7 8 9 3100108 Foot Lifter Lever Bushing 押エ場ゲ軸ブッシュ 1 10 0093201 Needle Thread Take-up Bushing (Front) 針糸繰り軸ブッシュ(前) 1 11 3100098 Needle Thread Take-up Bushing (Rear) 針糸繰り軸ブッシュ(後) 1 12 3100090 Lower Shaft Bushing (Left) 下軸ブッシュ(左) 1 13 3100091 Lower Shaft Bushing (Right) 下軸ブッシュ(右) 1 14 3100094 Feed Bar Shaft Bushing (Left) 前送り軸ブッシュ(左) 1 15 3100095 Feed Bar Shaft Bushing (Right) 前送り軸ブッシュ(右) 1 16 3100096 Feed Bar Lift Shaft Bushing (Left) 送り上下軸ブッシュ(左) 1 17 3100097 Feed Bar Lift Shaft Bushing (Right) 送り上下軸ブッシュ(右) 1 18 000006 Seal Plug 詰栓 2 19 3100092 Looper Driving Shaft Bushing (Front) ルーパ軸ブッシュ(前) 1 20 3100093 Looper Driving Shaft Bushing (Rear) ルーパ軸ブッシュ(後) 1 21 3100105 Adjusting Screw Bushing 前送り調節ネジブッシュ 1 22 3200251 Eye Guard, Complete Set アイガード(組) 1 23 3101200 Safety Plate Support セーフティプレート取付板 1 24 009784 Screw (M6×1×10) 止ネジ 2 25 3200252 Safety Plate セーフティプレート 1 26 001230 Screw (3/32-56×3.8) 止ネジ 2 27 0060175 Safety Plate Holder セーフティプレートホルダ 1 28 006004 Screw (11/64-40×9.7) 止ネジ 1 29 000010 Conical Spring Washer 皿バネワッシャ 1 30 000547 Washer ワッシャ 1 31 000334 Nut ナット 1

Page 7 — MAIN SHAFT DRIVING MECHANISM

5 MAIN SHAFT DRIVING MECHANISM Ref. No Parts No Description 下軸機構 Amt. Reg. 1 3100130 Pulley プーリー 1 2 160005 Screw (M6-1×8) 止ネジ 4 3 160007 Screw (M6-1×6) 止ネジ 6 4 0093089 Ball Bearing (Right) ・ボールベアリング(右) 1 5 3100128 Main Shaft Sprocket ・ベルトプーリ(下) 1 6 0093090 Ball Bearing (Middle) ・ボールベアリング(中) 1 7 3100132 Lower Shaft (Right) ・下軸(右) 1 8 3100122 Oil Pump Driving Worm ウオーム 1 9 3100127 Counterweight (Small) バランスウエイト(小) 1 10 110009 Screw (M4-0.7×8) 止ネジ 2 11 3100123 Ball Bearing (Left) ・ボールベアリング(左) 1 12 3100121 Lower Crankshaft 下軸クランク 1 13 160004 Screw (M6-1×4.8) 止ネジ 2 14 001107 Roll Pin ロールピン 3 15 330001 Seal Plug 詰栓 1 16 3100120 Lower Shaft (Left) 下軸(左) 1 17 000397 Oil Wick 油芯 3 18 000304 Oil Wick 油芯 1 19 000730 Seal Plug 詰栓 1 20 3100126 Collar (14×21×5.5mm) カラー 1 21 160000 Screw (M3-0.5×3) 止ネジ 2 22 3100125 Looper Thread Take-up 下糸調子カム 1 23 150000 Screw (M5-0.8×4) 止ネジ 2 24 3100263 Supporting Plate カム糸調取付板 1 25 110002 Screw (M3-0.5×5) 止ネジ 3 26 000463 Laced Wire モール(糸巻付防止) 1 27 3100264 Thread Take-up Eyelet (Left) カム糸道(左) 1 28 3100265 Thread Take-up Eyelet (Right) カム糸道(右) 1 29 110027 Screw (M2.5-0.45×3.5) 止ネジ 2 30 3100262 Supporting Plate Basement カム糸道取付台 1 31 160001 Screw (M4-0.7×4) ストップネジ 1 32 160008 Stop Screw (M3-0.5×15) ストップネジ 1 33 100003 Lock Nut ロックナット 1 34 3100267 Supporting Plate Return Spring 戻シバネ 1 35 3100266 Screw (M3-0.6×6) 止ネジ 1 36 340004 Pin ピン 1 37 3100260 Basement Shaft 取付台軸 1 38 3100261 Collar (6×11×5mm) カラー 1 39 3100266 Cast-off Plate 糸案内 1 40 000531 Washer ワッシャ 1 41 3100268 Stop Bracket ストップ台 1 42 110041 Screw (M4-0.7×8) 止ネジ 2 43 3100270 Supporting Plate Stop 取付板ストップ 1 44 3100269 Stop Spring 取付板ストップバネ 1 45 170003 Screw (M3-0.5×3) 止ネジ 1 46 3100272 Supporting Plate Basement Cushion 取付台クッション 1 (注) カラーの寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. ×Outside dia. ×Thickness. Jinte.in

Page 8 — UPPER SHAFT & NEEDLE THREAD TAKE-UP MECHANISM

6 UPPER SHAFT & NEEDLE THREAD TAKE-UP MECHANISM 上軸及び針糸繰り機構 Ref. Parts No. No. Description Amt. Req. 1 3100280 Handwheel 1 2 160005 Screw (M6-1×8) 2 3 160007 Screw (M6-1×6) 10 4 000989 Handwheel Mark 1 5 0093090 Ball Bearing 2 6 3100129 Handwheel Adapter 1 7 0095214 Timing Belt 1 8 3100281 Upper Shaft Sprocket (Upper) 1 9 3100282 Upper Shaft (Right) 1 10 3100283 Upper Shaft Joint 1 11 3100127 Counterweight (Small) 1 12 110009 Screw (M4-0.7×8) 2 13 3100284 Upper Crankshaft 1 14 0060057 Retaining Ring 1 15 0093154 Ball Bearing 2 16 160004 Screw (M6-1×4.8) 2 17 000926 Rubber Seat 1 18 260000 Screw (5/16-24×15.88) 2 19 0095170 Connecting Rod 1 20 005071 Screw (11/64-32×14) 2 21 001174 Screw (9/64-40×10.3) 2 22 0095168 Guide Fork 1 23 004312 Screw (1/8-44×7.9) 2 24 3100285 Driving Lever 1 25 120013 Screw (M6-1×15) 1 26 120015 Screw (M5-0.8×10) 1 27 000555 Washer 1 28 3100286 Spacer 1 29 3100287 Driving Shaft 1 30 3100078 Bracket 1 31 000600 Spring Washer 1 32 005650 Screw (M5-0.8×14) 1 33 0063096 Needle Thread Take-up 1 34 000532 Washer 2 35 110004 Screw (M3.5-0.6×8) 2

Page 9 — NEEDLE BAR MECHANISM

7 NEEDLE BAR MECHANISM Amt. Ref. Parts Description Req. No No 1 0065340 Needle Bar 針棒 1 2 004358 Screw (9/64-40×5.6) 止ネジ 1 3 0063044 Needle Bar Thread Eyelet 針棒糸通 1 4 000548 Washer ワッシャ 1 5 0093184 Needle Bar Bracket 針棒抱キ 1 6 002043 Screw (11/64-40×11) 止ネジ 1 7-1 0093352 Needle Clamp (56) 針止メ 1 7-2 0093353 " (48) 止ネジ 1 7-3 3009101 " (56) 止ネジ 1 8 - Needle (UY128 GAS) 針 2 9 001900 Screw (1/8-44×2.4) 止ネジ 2 10-1 3118021 Stitch Plate (40L) 針板 1 10-2 3118022 " (48L) 1 10-3 3118023 " (56L) 1 11 009142 Screw (9/64-40×4.8) 止ネジ 2 12 110059 Screw (M3.5-0.6×7) 止ネジ 1 13 3100293 Counterweight, Complete Set バランスウエイト(組) 1 14 0093215 Counterweight バランスウエイト 1 15 003647 Screw (1/4-28×4.8) 止ネジ 2 16 0093214 Connecting Rod Ring 針棒ロッドリング 1 17 3100291 Connecting Rod, Complete Set 針棒ロッド(組) 1 18 3100290 Connecting Rod 針棒ロッド 1 19 0093212 Roller Bearing ニードルベアリング 1 20 0093213 Connecting Rod Pin 針棒ロッドピン 1 21 000321 Oil Wick 油芯 1 22 0093186 Slide Block 針棒案内 1 23 0093179 Needle Bar Guide 針棒案内 1 24 110010 Screw (M4-0.7×16) 止ネジ 2 25 3100256 HR Device, Complete Set HR装置(組) 1 26 3100254 HR Container HRタンク 1 27 110013 Screw (M4-0.7×8) 止ネジ 2 28 0010017 Pipe Joint パイプ継手 1 29 3100253 Oil Tube 給油パイプ 1 30 310007 Felt フェルト 1 31 3100250 HR Cup HRカップ 1 32 310006 HR Felt HRフェルト 1 33 000637 Seal Plug 詰栓 1 34 110009 Screw (M4-0.7×8) 止ネジ 1

Page 10 — PRESSER FOOT MECHANISM

PRESSER FOOT MECHANISM 8 Ref. Parts Amt. No No Description Req. 1 0077270 Presser Spring Regulator ・押工調節ネジ 1 2 0090620 Cotter Pin ・割リピン 1 3 000445 Lock Nut ・ロックナット 1 4 0065372 Presser Bar Spring (Outer) ・押工棒バネ(太) 1 5 0063087 Presser Bar Connecting Bracket ・押工棒抱キ 1 6 004440 Screw(11/64-40×8.3) ・止ネジ 1 7 0093483 Presser Bar Guide ・押工案内 1 8 004441 Screw(11/64-40×16) ・止ネジ 1 9 0060142 Presser Bar Spring (Inner) ・押工棒バネ(細) 1 10 0093480 Presser Bar ・押工棒 1 11 0093611 Oil Protector Ring ・油切リリング 1 12 0063079 Stop Collar (9×15×7mm) ・ストツプカラー 1 13 001459 Screw(9/64-40×3) ・止ネジ 2 14-1 3117076 Presser Foot, Complete Set (048) ・押工(組) 1 14-2 3117078 (048) 〃 1 14-3 3117080 (056) 〃 1 15 001186 Screw(9/64-40×7.8) ・止ネジ 1 16 0063280 Presser Foot Spring ・小押工バネ 1 17 0093487 Lifter Link ・吊リリンク 1 18 006038 Screw(3/16-32×2.2) ・止ネジ 2 19 0063083 Lifter Link Lever ・吊リリンクレバー 1 20 000690 Fastener Pin ・止メピン 1 21 0063084 Lifter Spring ・押工揚ゲバネ 1 22 0093491 Collar (8×16×8mm) ・カラー 2 23 009604 Screw(11/64-40×5.5) ・止ネジ 2 24 0093479 Lifter Shaft ・押工揚ゲ軸 1 25 003433 Screw(11/64-40×4) ・止ネジ 2 26 3100294 Intermediate Lever ・押工揚ゲレバー 1 27 120017 Screw(M5-0.8×15) ・止ネジ 1 28 0077179 Retaining Ring ・止メ輪 1 29 0093509 Connecting Pin ・連結ピン 2 30 0093507 Connecting Plate ・連結桿 1 31 0093508 Lifter Lever (Small) ・押工揚ゲレバー(小) 1 32 004591 Screw(15/64-28×9.5) ・止ネジ 1 33 0066560 Lifter Lever ・押工揚ゲレバー 1 34 0066561 Lifter Lever Stop ・押工揚ゲレバーストツプ 1 35 004358 Screw(9/64-40×5.6) ・止ネジ 2 36 0090801 Tension Release Lever ・糸緩メ腕 1 37 005542 Screw(11/64-40×14.5) ・止ネジ 1 38 0093545 Tension Release Shaft ・糸緩メ軸 1 39 0090824 Swing-proof Spring ・防振バネ 1 40 0065366 Presser Foot Guide Locking Pin ・回リ止メピン 1 41 0063282 Presser Foot Hinge Pin ・押工ヒンジピン 1 42 000327 Lock Nut ・ロックナット 1 43 003302 Adjusting Screw(1/8-44×11) ・調節ネジ 1 44 3117084 Fabric Presser ・布押工 1 45 001228 Screw(3/32-56×3.2) ・止ネジ 2 (注) カラーの寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. ×Outside dia. ×Thickness.

Page 11

9 LOOPER DRIVING MECHANISM ルーパ機構 Amt. Ref. Parts Description Req. No No 1 3109300 Looper 1 2 110020 Screw(M3.5-0.6×6) 1 3-1 3100162 Looper Holder 1 3-2 3100555 " (with "UT" Device) 1 4 110039 Screw(M3.5-0.6×10) 1 5 000417 Spacer(Fiber) 1 6 3100154 Looper Bar Bushing 1 7 160007 Screw(M6-1×6) 4 8 3100410 Looper Thread Eyelet 1 9 110101 Screw(M3-0.5×3) 1 10 340008 Roll Pin 1 11 3100156 Bushing Spacer 1 12 3100152 Looper Bar Guide 1 13 3100157 Slider 1 14 3100158 Slider Holder 1 15 110005 Screw(M3.5-0.6×12) 1 16 300500 Spacer(Fiber) 1 17 3100159 Slider Presser 1 18 160001 Screw(M4-0.7×4) 1 19 3100160 Thrust Washer 1 20 330002 Seal Plug(Kurk) 1 21 3100161 Looper Bar 1 22 3100153 Guide Shaft Bushing 1 23 3100155 Looper Bar Guide Shaft 1 24 110019 Screw(M5-0.8×35) 1 25 300000 Washer 2 26 3100151 Looper Rocker Adjusting Pin 1 27 340001 Roll Pin 1 28 100002 Nut 1 29 3100150 Looper Rocker Connecting Rod, C. Set 1 30 3100147 Looper Rocker Regulating Eccentric 1 31 160003 Screw(M5-0.8×5) 1 32 0065389 Roller Bearing 1 33 3100149 Looper Rocker Connecting Rod 1 34 3100140 Looper Connecting Rod 1 35 005071 Screw(11/64-32×14) 4 36 3100355 Oil Slasher 1 37 3100141 Guide Fork 1 38 004440 Screw(11/64-40×8.3) 2 39 3100142 Looper Driving Lever 1 40 000637 Seal Plug 1 41 3100143 Looper Rocker Arm 1 42 120011 Screw(M6-1×18) 1 43 3100146 Thrust Plate 3 44 3100145 Thrust Roller Bearing 2 45 3100144 Looper Shaft 1 46 000740 Seal Plug 2

Page 12 — FEED DRIVING CONTROL MECHANISM

FEED DRIVING CONTROL MECHANISM 前送り調節機構 10 Amt. Ref. Parts Reg. No No Description 1 3100217 Feed Lift Lever 送り上下腕袖 1 2 160007 Screw(M6-1×6) 止ネジ 5 3 0032799 Connecting Rod Pin ロッドピン 1 4 160002 Screw(M4-0.7×2) 止ネジ 4 5 3100216 Feed Lift Connecting Rod 送り上下ロッド 1 6 3100192 Retaining Ring 止メ輪 2 7 3100190 Roller Bearing ニードルベアリング 2 8 3100189 Differential Feed Eccentric 前送りリエキセン 1 9 006212 Screw(M5-0.8×6) 止ネジ 2 10 3100191 Differential Feed Connecting Rod 前送りロッド 1 11 3100193 Connecting Rod Pin ロッドピン 2 12 3100194 Lever Link(Long) 前送りレバーリンク(長) 1 13 3100195 Lever Link(Short) 前送りレバーリンク(短) 1 14 3100196 Lever Link Pin 前送りレバーリンクピン 1 15 300006 Washer ワッシャ 1 16 110009 Screw(M4-0.7×8) 止ネジ 2 17 3100197 Differential Feed Shaft Lever 前送り軸レバー 1 18 120009 Screw(M4-0.7×12) 止ネジ 1 19 3100199 Control Bracket 送り調節ブラケット 1 20 3100202 Connecting Rod Guide 送りロッドガイド 1 21 3100200 Control Bracket Spring ブラケットバネ 1 22 340003 Pin ピン 2 23 3100103 Control Lever Shaft Bushing 調節レバー軸ブッシュ 1 24 3100104 O-ring(P16) ○リング 1 25 0093303 Oil Seal オイルシール 1 26 3100201 Control Lever Shaft 前送り調節レバー軸 1 27 3100211 Control Link Pin 送り調節リンクピン 1 28 3100203 Control Link 送り調節リンク 1 29 3100208 Control Nut 送り調節ナット 1 30 001107 Roll Pin ロールピン 1 31 3100205 O-ring(P12) ○リング 1 32 3100204 Adjusting Screw 調節ネジ 1 33 3100207 Adjusting Stop Pin ストップピン 1 34 150001 Screw(M4-0.7×4) 止ネジ 1 35 3100206 Adjusting Knob 調節ツマミ 1 36 130002 Screw(M3-0.5×4) 止ネジ 1 37 3100235 Differential Feed Control Lever, C. Set 前送り調節レバー(組) 1 38 3100210 Differential Feed Control Lever 前送り調節レバー 1 39 3100209 Differential Feed Graduations 前送り目盛板 1 40 130004 Screw(M4-0.7×11) 止ネジ 2 41 000505 Spacer スペーサ 2 42 0020350 Control Lever Stop 送り調節レバー・ストップ 1 43 000669 Washer ワッシャ 1 44 000600 Spring Washer スプリングワッシャ 1 45 005049 Screw(M5-0.8×8) 止ネジ 1 46 190004 Screw(M6-1×7.5, M4.5-0.5×3) 止ネジ 1 47 100005 Nut ナット 1 48 000010 Conical Spring Washer 皿バネワッシャ 1

Page 13 — NEEDLE GUARD & FEED DRIVING MECHANISM

11 NEEDLE GUARD & FEED DRIVING MECHANISM Ref. No. Parts No. Description Amt. Req. 1 3100243 Needle Guard (Front) Eccentric 針受ケ(前)エキセン 1 2 160003 Screw (M5-0.8×5) 止ネジ 2 3 3100242 Needle Guard (Front) Lever 針受ケ(前)腕 1 4 110022 Screw (M3-0.5×10) 止ネジ 2 5 3100241 Needle Guard (Front) Holder 針受ケ(前)台 1 6 3109200 Needle Guard (Front) 針受ケ(前) 1 7 110036 Screw (M3-0.5×6.5) 止ネジ 2 8 3100245 Needle Guard (Rear) Lever 針受ケ(後)腕 1 9 3100246 Needle Guard (Rear) Holder 針受ケ(後)台 1 10-1 3109201 Needle Guard (Rear) 針受ケ(後) 1 10-2 3109210 " " " (Extra) " " (特注品) 1 11 3100187 Feed Regulating Stop 送り調節ストップ 1 12 110004 Screw (M3.5-0.6×8) 止ネジ 3 13 340001 Roll Pin ロールピン 1 14 3100186 Conical Spring Presser 皿バネ押エ 1 15 130005 Screw (M2-0.4×4) 止ネジ 2 16 3100185 Conical Spring 皿バネ 1 17 3100183 Eccentric Cam 送りエキセンカム 1 18 000723 Stop Pin ストツプピン 1 19 3100184 Eccentric Pin 送りエキセンピン 1 20 3100182 Main Feed Eccentric, Complete Set 送リ工キセン(組) 1 21 110072 Screw (M3.5-0.6×5) 止ネジ 1 22 110023 Screw (M3.5-0.6×5) 止ネジ 1 23 009736 Screw (M4-0.7×6) 止ネジ 2 24 3100188 Main Feed Bar Driving Connection 後送りリンク 1 25 110021 Screw (M5-0.8×18) 止ネジ 2 26 0032853 Driving Connection Bushing 後送りリンクブツシュ 1 27 3100225 Feed Bar Guide (Upper) 送リ台ガイド(上) 1 28 160007 Screw (M6-1×6) 止ネジ 2 29 3100227 Feed Bar, Complete Set 送リ台(組) 1 30 3100221 Differential Feed Bar 前送り台 1 31 3100222 Main Feed Bar 後送り台 1 32 3100231 Feed Dog Key キー 2 33 3100224 Feed Lift Block (Rear) 角駒(後) 1 34 3119021 Main Feed Dog (40, 48, 56) 前送りリ 1 35 3119020 Differential Feed Dog (40, 48, 56) 前送り 1 36 3100226 Feed Bar Guide (Lower) 送リ台ガイド(下) 1 37 110035 Screw (M4-0.7×10) 止ネジ 2 38 3100213 Differential Feed Bar Driving Connection 前送りリンク 1 39 3100215 Oscillation Adjusting Eccentric 前送り・後送り調節エキセン 1 40 000199 Oil Wick 油芯 1 41 3100214 Driving Connection Pin 前送りリンクピン 1 42 160006 Screw (M3-0.5×6) 止ネジ 1 43 000750 Seal Plug 詰栓 4 44 3100212 Differential Feed Shaft 前送り軸 1 45 0093389 Feed Lift Block (Front) 角駒(前) 1 46 3100218 Feed Lift Shaft 送り上軸 1 47 000397 Oil Wick 油芯 1 48 3100219 Collar (11×18×11mm) カラー 2 49 160004 Screw (M6-1×4.8) 止ネジ 2 50 3101300 Feed Bar Guide (Upper) (Right) 送リ台ガイド(上)(右) 1 (注) カラーの寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. ×Outside dia. ×Thickness.

Page 15 — MISCELLANEOUS SUCTION PIPE

13. MISCELLANEOUS SUCTION PIPE 吸込管関係 13 Ref. No. Parts No. Description Amt. Req. 1 3110171 Suction Pipe Holder 吸込管取付台 1 2 120018 Screw (M4-0.7×10) 止ネジ 2 3 3110169 Suction Pipe (Upper) 吸込管(上) 1 4 009736 Screw (M4-0.7×6) 止ネジ 1 5 3110180 Oil Defender 送り台油除ケ 1 6 110008 Screw (M4-0.7×5) 止ネジ 2 7 3120033 Suction Pipe (Right) 吸込管(右) 1 8 0012480 Dust Hose (1500mm) 集塵ホース 1 9 0013648 Hose Band ホースバンド 2 10 006921 Wood Screw (φ 4.8×25) 木ネジ 4 11 0010260 Vinyl Tube (4×2.5mm) ビニールパイプ 1 12 1094002 Reducer (φ6×4) レデューサ 1 13 1098012 Hand Valve ハンドバルブ 1 14 350006 Wood Screw (φ 3.5×32) 木ネジ 2 15 0010261 Vinyl Tube (6×4mm) ビニールパイプ - (注) ビニールパイプ御注文の際は品番と長さを お知らせ下さい。 Note: As for Vinyl Tube, your order must be accompanied with No. and length.

Page 16

14 LUBRICATING MECHANISM 給油機構 14 Ref. No Parts No Description Amt. Req. 1 0065453 Oil Receiver 1 2 110012 Screw(M4-0.7×5) 6 3 000234 Nut 1 4 3100350 Needle Bar Connecting Rod Oil Pipe 1 5 160001 Screw(M4-0.7×4) 1 6 310027 Oil Wick 1 7 0020551 O-ring 1 8 0063251 Oil Tube Stay 1 9 3100346 Oil Wick Holder 1 10 004353 Screw(9/64-40×7) 1 11 3100060 Oil Filter Cap 1 12 110031 Screw(M4-0.7×12) 3 13 3100061 O-ring 1 14 3100345 Oil Filter 1 15 3100329 Oil Filter Connector 1 16 0063217 Oil Filter Screen Clamp 1 17 0063216 Oil Filter Screen 1 18 0063234 Felt 1 19 0063235 Oil Tube (4×5×500mm) 1 20 0065452 Draining Pipe 1 21 3100353 Oil Sight Top Nozzle 1 22 3100357 Oil Tube (Long), Complete Set 1 23 0031831 Oil Tube Clamp 12 24 3100335 Oil Tube (4×6×290mm) 1 25 0090930 Non-Return Valve Unit 1 26 3100336 Oil Tube (4×6×75mm) 1 27 0037668 Oil Tube Joint, Two Way 1 28 3100332 Oil Tube (4×6×37mm) 1 29 0037669 Oil Tube Joint, One Way 4 30 3100342 Lower Shaft Oiling Outlet 1 31 3100358 Oil Tube (Middle), Complete Set 1 32 3100331 Oil Tube (4×6×31mm) 2 33 3100343 Lower Shaft Oiling Shower 1 34 3100334 Oil Tube (4×6×110mm) 1 35 110009 Screw (M4-0.7×8) 3 36 004124 Fitting Stud (Short) 10 37 000567 Seal 10 38 004126 Fitting Stud (Long) 1 39 3100356 Oil Tube (Short), Complete Set 1 40 3100338 Oil Pump, Complete Set 1 41 000711 Oil Pump Driving Worm Gear 1 42 009526 Screw(9/64-40×4.4) 3 43 120013 Screw(M6×15) 2 44 0090918 Suction Pipe 1 45 000419 Nut 1 46 3100349 Oil Nozzle for Worm Gear 1 47 3100344 Dustproof Plate 1 48 3100330 Oil Tube Stay 1 49 0021010 Oil Sight Gauge 1 50 310026 Oil Wick 1 jntex.in

Page 17 — 飾り糸ルーパ機構

15 SPREADER MECHANISM No. Ref. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 Parts No. 3100302 3100300 160003 0077322 3100301 0094566 110009 300006 3100309 000528 100003 0032646 009604 3100303 120013 3100304 3100305 160007 0063051 0063053 0063056 0063057 009526 3100307 3109310 110031 3100306 Description Connecting Rod, Complete Set Eccentric Screw(M5-0.8×5) Roller Bearing Connecting Rod Retaining Ring Screw(M4-0.7×8) Washer Adjusting Lever Pin Washer Nut (M6-1.0) Collar(12×20×8mm) Screw(11/64-40×5.5) Adjusting Lever Screw(M6-1×15) Driving Shaft Rocking Arm Screw(M6×6) Rocking Pin Spreader Bar Bushing Ring Collar(10×18×7mm) Screw(9/64-40×4.4) Spreader Holder Spreader Screw(M4-0.7×12) Rocking Arm, Complete Set ※ Applicable Models (適用機種) VC3611-145L-D VC3711-148L-D VC3611-156L-D VC3711-156L-D (注) カラーの寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. ×Outside dia. ×Thickness. jinte.in 飾り糸ルーパ機構 Amt. Req. 1 1 2 1 1 1 1 1 1 1 1 1 2 1 1 1 1 2 1 1 1 1 2 1 1 1 15

Page 18 — MISCELLANEOUS TOP COVER THREAD

16 MISCELLANEOUS TOP COVER THREAD 飾り糸関係 16 Amt. Ref. No Parts No Description 品 名 Req. 1 0093863 Thread Tension Spring Cap ・糸調子バネキャップ(上) 1 2 3100086 Top Cover Thread Tension Spring ・飾り糸調子バネ 1 3 0090071 Thread Tension Spring Retainer ・飾り糸調子バネキャップ(下) 1 4 000177 Felt ・フェルト 1 5 0031111 Tension Disc ・糸調子皿 2 6 009835 Tension Post ・糸調子棒 1 7 0090812 Tension Post Ferrule ・糸調子棒糸摺レ 1 8 0090856 Tension Disc Eyelet ・糸調子皿糸道 1 9 0090807 Thread Lead-in Guide ・糸調子台糸道 1 10 3200048 Top Cover Thread Eyelet (Left) ・飾り糸道(左) 1 11 110009 Screw(M4-0.7×8) ・止ネジ 4 12 3200049 Top Cover Thread Take-up ・飾り糸繰り 1 13 0020119 Thread Eyelet Pipe(Short) ・糸道パイプ(短) 1 14 0093528 Thread Eyelet Pipe Stay ・糸道パイプ支エ 1 15 004353 Screw(9/64-40×7) ・止ネジ 1 16 000532 Washer ・ワッシャ 1 17 3200047 Top Cover Thread Eyelet (Right) ・飾り糸道(右) 1 18 000541 Washer ・ワッシャ 1 19 1 20 0093365 Top Cover Thread Eyelet ・飾り糸道 1 21 001900 Screw(1/8-44×2.4) ・止ネジ 1 22 3100100 Spreader Driving Bar Bushing ・飾り糸ルーパ棒ブッシュ 1 23 0063055 Oil Seal ・オイルシール 1 24 3200063 Spreader Shaft Bushing(Left) ・飾り糸ルーパ棒ブッシュ(左) 1 25 3200064 Spreader Shaft Bushing(Right) ・飾り糸ルーパ棒ブッシュ(右) 1 26 3100081 Top Cover Thread Guide ・飾り糸案内 1 27 0063074 Supplementary Thread Guide ・小調子台糸道 1 28 001818 Tension Post ・糸調子棒 1 29 0037108 Supplementary Tension Disc ・小調子皿 2 30 0035813 Supplementary Tension Spring ・飾り糸調子バネ 1 31 000360 Nut ・ナット 1 ※ Applicable Models(適用機種) VC3611-145L-D VC3611-156L-D VC3711-148L-D VC3711-156L-D

Page 19 — PULLER MECHANISM(1)

17 PULLER MECHANISM(1) プルラー機構専用部品(1) Amt. Ref. Req. No. Parts No. Description 品 名 1 3100625 Upper Feed Roller Shaft Bracket 上ローラ軸ブラケット 1 2 120019 Screw(M6-1×18) 止ネジ 4 3 000779 Knock Pin ノツクピン 2 4 3100006 Seal Plug 詰栓 1 5 3100607 Roller Shaft Bushing (Right) 上ローラ軸ブツシュ(右) 1 6 3100604 Upper Feed Roller Shaft Lever 上ローラ軸腕 1 7 160007 Screw(M6-1×6) 止ネジ 2 8 0065398 Collar(14×22×10mm) カラー 1 9 009604 Screw(11/64-40×5.5) 止ネジ 2 10 3100626 Roller Shaft Bushing (Left) 上ローラ軸ブツシュ(左) 1 11 0065395 Oil Seal オイルシール 1 12 3100605 Upper Feed Roller Shaft 上ローラ軸 1 13 3100608 Upper Feed Roller Lever 上ローラレバー 1 14 120012 Screw(M6-1×20) 止ネジ 1 15 0065400 Upper Feed Roller Lever Rod 上ローラレバーロツド 1 16 001174 Screw(9/64-40×10.3) 止ネジ 2 17 0060109 Ball Stud 上ローラレバートド球 1 18 0065401 Upper Feed Roller Pin 上ローラレバーピン 1 19 0065402 Upper Feed Roller Rod Sleeve レバーロツドスリ-ブ 1 20 000613 Washer ワツシヤ 1 21 000306 Nut ナット 1 22 0032921 Upper Feed Roller Driving Rod Pin 上ローラロツドピン 1 23 160001 Screw(M4-0.7×4) 止ネジ 1 24 3100602 Upper Feed Roller Driving Rod 上ローラロツド 1 25 310192 Retaining Ring ストツプリング 1 26 3100623 Roller Bearing ニードルベアリング 1 27 3100603 Upper Feed Roller Regulator, Complete Set 上ローラ調節器(組) 1 28 3100601 Upper Feed Roller Eccentric 上ローラエキセン 1 29 3100600 Upper Feed Roller Regulator 上ローラ調節器 1 30 160003 Screw(M5-0.8×5) 止ネジ 2 31 190007 Adjusting Screw(M5-0.8×6) 調節ネジ 1 32 120008 Screw(M4-0.7×8) 止ネジ 1 33 000530 Washer ワツシヤ 1 34 3100636 Upper Feed Roller Shaft Bracket, C. Set 上ローラ軸ブラケット 1 35 See page 19 19ページ参照

Page 20 — PULLER MECHANISM (2)

18 PULLER MECHANISM (2) PULLER MECHANISM EXCLUSIVE PARTS (2) Ref. No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29-1 29-2 29-3 29-4 29-5 30 31-1 31-2 31-3 31-4 31-5 32 33 34 35 36 37 38 39 40 Parts No. 3100611 120012 3100612 110009 3100613 003662 0090620 006270 160001 0060056 3100617 3100616 0065414 0065421 000145 0065420 3100615 000306 007621 0095061 3010022 0095066 0065417 3100618 160005 0095065 0065415 0065418 0065422 3101354 0065468 0066735 0066737 3100638 0065461 3101355 0065469 0066736 0066738 000492 3100620 120006 000779 3100622 150001 3100621 130002 0065431 Description Upper Feed Roller Yoke Screw(M6-1×20) Upper Feed Roller Yoke Guide Screw(M4-0.7×8) Upper Feed Roller Yoke Pin Screw(M6-1×6) Cotter Pin Screw(9/64-40×0.5) Screw(M4-0.7×4) Retaining Ring Clutch Driving Shaft Clutch Driving Shaft Bushing (Left) Clutch Driving Shaft Bushing (Right) Clutch Tension Sleeve Adjusting Nut Clutch Tension Spring Clutch Driving Lever Nut Screw(9/64-40×0.5) Clutch Clutch Spring (Thick) Clutch Spring Seat Clutch Roller Clutch Spacer Screw(M6-1×8) Clutch Spring Clutch Sleeve Clutch Check Plate Upper Feed Roller (30 teeth) (50 teeth) (Extra) (26 teeth) ( " ) (24 teeth) ( " ) (20 teeth) ( " ) Lower Feed Roller Support, C. Set Lower Feed Roller (15 teeth) (25 teeth) (Extra) (15 teeth) ( " ) (13 teeth) ( " ) (12 teeth) ( " ) Corrugated Washer Lower Feed Roller Support Screw(M6-1×12) Knock Pin Lower Feed Roller Shaft Screw(M4-0.7×4) Lower Feed Roller Cover Screw(M3-0.5×6) Supplementary Roller Support プラ-機轉用部品(2) 品 名 上ローラヨーク 止ネジ 上ローラヨークガイド 止ネジ 上ローラヨークピン 止ネジ 割リピン 止ネジ 止ネジ ストツプリング クラッチ軸 クラッチ軸ブツシユ(左) クラッチ軸ブツシユ(右) クラッチテンシヨンスリ-ブ 調節ナット クラツチテンシヨンバネ クラツチ板(右) ナット 止ネジ クラツチ クラツチバネ(太) クラツチバネ座 クラツチローラ クラツチスペーサ 止ネジ クラツチバネ クラツチスリ-ブ クラツチ板(左) 上ローラ(30山) (特注品) (26山)(" ) (24山)(" ) (20山)(" ) 下ローラサポート(組) 下ローラ(15山) (25山)(" ) (15山)(" ) (13山)(" ) (12山)(" ) 波形ワツシヤ 下ローラサポート 止ネジ ノツクピン 下ローラ軸 止ネジ 下ローラ補助カバー 止ネジ 補助ローラ取付板 18 Amt. Req. 1 1 1 5 1 1 1 1 2 1 1 1 1 2 1 1 1 1 12 2 6 6 6 1 1 6 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 2 1 Ref. No. 41 to 48 See the following page. Jinftex.in

Page 21 — PULLER MECHANISM (2)

18 PULLER MECHANISM (2) PULLER MECHANISM EXCLUSIVE PARTS (2) Ref. No. 41 42 43 44 45 46 47 48 Parts No. 000538 0065435 0065436 0065437 009730 Description Washer Supplementary Roller Supplementary Roller Stay (A) Supplementary Roller Stay (B) Screw (1/8-44×5.3) See page 19 プラ一機構専用部品(2) 品 名 ワッシャ 補助ローラ 補助ローラ支工(A) 補助ローラ支工(B) 止ネジ 19ページ参照 18 Amt. Req. 2 1 1 1 4 ※ Ref. No. 1 to 40 See the preceding page.

Page 22 — PULLER MECHANISM EXCLUSIVE PARTS (3)

19 PULLER MECHANISM (3) Ref. No Parts No Description Amt. Req. 0065381 Upper Feed Roller Lifter (Right) ・上ローラ揚ゲ(右)・ 1 004440 Screw(11/64-40×8.3) 止ネジ 2 000538 Washer ワッシャ 3 000334 Nut ナット 2 0034979 Flexible Wire Clamp Bushing ワイヤ止メブッシュ 2 006075 Screw(11/64-40×6) 止ネジ 2 0067126 Lifter Connecting Plate 上ローラ揚ゲ連結板 1 0065374 Upper Feed Roller Lifter (left) 上ローラ揚ゲ(左) 1 0065375 Upper Feed Roller Lifter Pin 上ローラ揚ゲピン 1 0095027 Retaining Ring ストップリング 2 11 0065376 Lifter Connecting Plate 上ローラ吊リ 1 12 006038 Screw(3/16-32×2.2) 止ネジ 2 13 0056507 Roller Press Bar Bracket 上ローラ押エ棒掛ケ 1 14 005650 Screw(M5×8×14) 止ネジ 1 15 0065402 Lifting Lever Sleeve 止ローラレバースリーブ 1 16 006411 Screw(11/64-40×5.5) 止ネジ 1 17 000340 Nut ロックナット 1 18 009931 Stop Screw(11/64-40×6) ストツパネジ 1 19 3100614 Roller Press Spring 上ローラ押エバネ 1 20 3100610 Upper Feed Roller Bracket 上ローラブラケット 1 21 009753 Screw(M6-1×35) 止ネジ 2 22 000779 Knock Pin ノツクピン 2 23 0065405 Roller Press Bar Bushing (Upper) 上ローラ押エ棒ブツシュ(上) 1 24 160007 Screw(M6-1×6) 止ネジ 1 25 3100609 Roller Press Bar Bushing (Lower) 上ローラ押エ棒ブツシュ(下) 1 26 0056504 Upper Feed Roller Bar 上ローラ押エ棒 1 27 0034117 Retaining Ring ストツプリング 1 28 000690 Stop Pin ストツプピン 1 29 000613 Washer ワツシャ 1 30-1 0067111 Upper Feed Roller Lifter Lever 手揚け 1 30-2 3101220 (for ST-A) 〃 (ST-Aの時使用) 1 31 000487 Corrugated Washer 波形ワツシャ 1 32 170008 Screw(M6-1×9) 止ネジ 1 33 3100637 Upper Feed Roller Bracket, C. Set 上ローラブラケット(組) 1 (注) Ref. No. 33/Part No. 3100637は17ページのRef. No. 35及び18ページのRef. No. 48の 部分を含んだPart No. です。 Note: Part No. 3100637 of Ref. No. 33 contains the part number of Ref. No. 35 on page 17 and Ref. No. 48 on page 18.

Page 23

20 VC3611-156L-D VC3611-145L-D VC3711-148L-D VC3711-156L-D VC3611-156L-D, 145L-D, VC3711-148L-D, 156L-D EXCLUSIVE PARTS Ref. No. 1 2 3 4 5 6 7 8 9 10 11 12 13-1 13-2 14 15-1 15-2 16-1 16-2 17 18 19 20 21 22 23 24 25 Parts No. 3117088 001186 0063280 0065366 0063282 000327 003302 3117084 001228 3097052 3099104 3098044 0093356 0093357 001900 3117122 3117124 3118024 3118025 0093863 0090814 0090071 000177 0031111 009835 0090812 0090806 0090807 Description Presser Foot, Complete Set (156) Screw (9/64-40×7.8) Presser Foot Spring Presser Foot Guide Locking Pin Presser Foot Hinge Pin Lock Nut Adjusting Screw (1/8-44×1.1) Fabric Presser Screw (3/32-56×3.2) Presser Foot, Complete Set (145) Needle Clamp (45) Stitch Plate (45L) Needle Clamp (48) " (56) Screw (1/8-44×2.4) Presser Foot, Complete Set (148) " (156) Stitch Plate (48L) " (56L) Thread Tension Spring Cap Needle Thread Tension Spring Thread Tension Spring Retainer Felt Tension Disc Tension Post Tension Post Ferrule Tension Disc Eyelet Thread Lead-in Guide サブモデル専用部品 20 Amt. Req. 押工(組) 止ネジ 小押エバネ 回リ止メピン 押エヒンジピン ロツクナット 調節ネジ 布押エ 止ネジ 押工(組) 止メネジ 針板 止ネジ " 止ネジ 押工(組) 押工(組) 針板 " 糸調子バネキャップ(上) 糸調子バネ 糸調子バネキャップ(下) フエルト 糸調子皿 糸調子棒 糸調子棒sess 糸調子皿糸道 糸調子台糸道 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 3 1 1 1 1 1 1 1 2 1 1 1 1 1

Page 24 — VC3645P-D EXCLUSIVE PARTS (1)

2 1 VC3645P-D(1) VC3645P-D EXCLUSIVE PARTS (1) Ref. No Parts No Description サブモデル専用部品 (1) Amt. Req. 品 名 1 3110196 Front Cover (Upper) ·開 キヤ バ 一 (上) 1 2 3110199 Fabric Guide (Left) ·布 ガ イ ド (左) 1 3 000538 Washer ワッシャ 6 4 L10009 Screw (M4-0.7×8) 止ネジ 4 5 6 7 8 190056 Screw (M4-0.7×5) バネ掛ケネジ 1 9 110012 Screw (M4-0.7×5) 止ネジ 1 10 0094201 Cover Latch Spring カバーラツチバネ 1 11 3110197 Cylinder Holder シリンダ台 1 12 110011 Screw (M5-0.8×10) 止ネジ 2 13 000669 Washer ワッシャ 2 14 3110198 Fabric Guide Holder 布 ガ イ ド 台 1 15 0065233 Fabric Guide 布 ガ イ ド 1 16 000535 Washer ワッシャ 1 17 000644 Spring Washer スプリングワッシャ 3 18 004358 Screw (9/64-40×5.6) 止ネジ 2 19 0094664 Collar (6.1×12×8) カラー 1 20 009604 Screw (11/64-40×5.5) 止ネジ 1 21 000588 Anti-shock Rubber 緩衝ゴム 1 22 0067031 Cylinder Guide Bar Bushing ブツシュ 3 23 3101260 Cylinder Guide Bar シリンダガイド 1 24 000009 Nut ナット 2 25 000426 Washer ワッシャ 2 26 3110195 Elastic Tape Guide Bracket (Lower) 定規台(下) 1 27 3110194 Spacer スペーサ 1 28 110035 Screw (M4-0.7×10) 止ネジ 2 29 3110193 Elastic Tape Guide Bracket (Upper) 定規台(上) 1 30 3110192 Elastic Tape Guide Bracket Cover 定規台カバー 1 31 3110191 Elastic Tape Holder テープ受 1 32 3110190 Elastic Tape Guide 可動ゴムガイド 1 33 130007 Screw (M4-0.7×10) 止ネジ 2 34-1 3117094 Presser Foot, Complete Set (040) 押工(組) 1 34-2 3117092 〃 (048) 1 34-3 3117090 〃 (056) 1 35 001186 Screw (9/64-40×7.9) 止ネジ 1 36 0063280 Presser Foot Spring 小押エバネ 1 37 0065366 Presser Foot Locking Pin 回リ止メピン 1 38 0063282 Presser Foot Hinge Pin 押工ヒンジピン 1 39 000327 Lock Nut ロックナット 1 40 003302 Adjusting Screw (1/8-44×11) 調節ネジ 1 41 3110201 Fabric Presser Spacer 布押エスペーサ 1 42 3117048 Fabric Presser 布押工 1 43 001228 Screw (3/32-56×3.2) 止ネジ 2 44 3110200 Suction Pipe (Right) 吸込管(右) 1 (注) カラーの寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. ×Outside dia. ×Thickness.

Page 25 — VC3645P-D EXCLUSIVE PARTS (2)

VC3645P-D EXCLUSIVE PARTS (2) サブモデル専用部品 (2) 22 Ref. Parts Amt. No No Description Req. 1 3100767 Tension Roller (Upper), C. Set (2) 品 名 テンションローラ(上)(組2) 1 2 3100768 Tension Roller (Upper), C. Set (1) テンションローラ(上)(組1) 1 3 3100769 Tension Roller (Upper) テンションローラ(上) 1 4 3100770 Tension Roller Ball Bearing ボールベアリング 4 5 009220 Screw (11/64-40×8) 止ネジ 3 6 0063469 Tension Roller Shaft テンションローラ軸 2 7 000145 Nut ナット 4 8 0064173 Tension Roller Slider . スライダ 2 9 006475 Screw (M8-1.25×10) 止ネジ 2 10 009980 Guide Screw (M6-1×10) ガイドネジ 1 11 3300101 Tension Roller Holder ホルダ 1 12 009955 Screw (M8-1.25×65) 止ネジ 2 13 000443 Washer ワッシャ 4 14 0031015 Slider Stop . スライダストップ 2 15 0031015 Slider Stop Handle . スライダストップハンドル 2 16 009853 Screw (11/64-40×6.5) 止ネジ 2 17 3110130 Tension Roller (Lower), C. Set (2) テンションローラ(下)(組2) 1 18 3120240 Tension Roller (Lower), C. Set (1) テンションローラ(下)(組1) 1 19 3120241 Tension Roller (Lower) テンションローラ(下) 1 20 0065258 Roller Holder (Lower) 下ローラ台 1 21 000428 Washer ワッシャ 2 22 006920 Wood Screw (φ5.8×32) 木ネジ 2 23 3120114 Elastic Tape Roller, C. Set 前ローラ(組) 1 24-1 0065253 Front Roller (Long) 前ローラ(長) 1 24-2 0067140 " " (Short) " " (短) 1 25 0032719 Collar (10×16×6mm) カラー 1 26 001459 Screw (9/64-40×3) 止ネジ 1 27 0067023 Elastic Tape Guide (Front) ゴムガイド(前) 1 28 003638 Screw (11/64-40×4) 止ネジ 2 29 3120244 Front Roller Shaft 前ローラ軸 1 30 3120245 Front Roller Shaft Connector 前ローラ軸継手 1 31 000429 Washer ワッシャ 1 32 009936 Screw (M8-1.25×20) 止ネジ 1 33 160007 Screw (M6-1×6) 止ネジ 3 34 3120245 Front Roller Holding Shaft 前ローラ支工軸 1 35 0067025 Bracket ブラケット 2 36 009877 Knob Bolt (M10-1.5×20) ノブボルト 2 37 009947 Wood Screw (φ5.1×25) 木ネジ 4 (注) カラー の寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. Outside dia. ×Thickness.

Page 26 — "UT" DEVICE (1)

23 "UT" DEVICE (1) Ref. Parts No 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 0065373 0093499 004358 3100533 120001 3100526 007610 3100525 110009 170009 3100536 3100535 0063586 009985 110012 0063612 0094491 0022836 0022837 0094387 3100529 0067101 0063076 0094433 001208 Description Lifter Lever Lifter Lever Stop Screw(9/64-40×5.6) Tension Release Lever Screw(M4-0.7×14)

Page 27 — "UT" DEVICE (1)

23 "UT" DEVICE (1) "UT"装置(1) 23 Ref. Parts No. No. Description Amt. Req. 26 3101275 Thread Pull-off Hook Unit (See table) 糸緩メフック (組) (下調整) - 27 001459 Screw (9/64-40×3) (See table) 止ネジ (下表参照) - 28 3101276 Thread Pull-off Hook Unit (See table) 糸緩メフック (組) (下調整) - 29 0094396 Thread Pull-off Bar Holder 糸緩メ棒連結片 1 30 0033024 Retaining Ring ・ ・ ・ ストツプリング 1 31 0063515 Thread Pull-off Lever ・ ・ ・ 糸緩メレバー 1 32 000690 Dowel Pin ・ ・ ・ 止メピン 1 33 0094390 Tension Release Adjusting Eccentric Screw 糸緩メ板調節コロ 1 34 0095334 Swing-proof Spring ・ ・ ・ 糸緩メ板防振バネ 1 35 001170 Screw (9/64-40×12) ・ ・ ・ 止ネジ 1 36 3100528 Tension Disc Separator ・ ・ ・ 糸緩メ板・ 1 37 3100527 Tension Post Support ・ ・ ・ 糸調子台 1 38 110014 Screw (M4-0.7×18) ・ ・ ・ 止ネジ 2 39 000505 Spacer ・ ・ ・ スペーサ 2 40 3101202 Connector Supporting Plate (Extra)取付板(特注品) 1 41 110013 Screw (M4-0.7×8) (Extra) ・ ・ 止ネジ(特注品) 2 ※ Ref. No. 1 to 25 See the preceding page. Parts No 3101275 001459 3101276 2 Needle 2 3 1 without Spreader pcs. pcs. pc. 3 Needle 3 4 1 without Spreader 2 Needle 2 4 2 with Spreader pcs. 3 Needle 3 5 2 with Spreader

Page 29

2,5 "UT" DEVICE (3) EXTRA PARTS Ref. No Parts No Description Amt. Req. 1 3100506 Lower Knife Driving Lever 下メス駆動レバー 1 2 170005 Screw(M4-0.7×6) 止ネジ 2 3 3100502 Lower Knife Carrier 下メス台 1 4 3100514 Lower Knife Holder 下メス取付板 1 5 3100513 Lower Knife 下メス 1 6 110030 Screw(M4-0.7×2.6) 止ネジ 2 7 3100501 Upper Knife Carrier 上メス台 1 8 190006 Screw(M4-0.7×4) 止ネジ 2 9 100006 Nut ナット 2 10 3100503 Knife Guide Lever メスガイドレバー 2 11 3100504 Knife Guide Lever Ring (Left) メスガイドレバーリング(左) 1 12 3100505 Knife Guide Lever Ring (Right) メスガイドレバーリング(右) 1 13 130003 Screw(M4-0.7×7.3) 止ネジ 2 14 3100515 Upper Knife Carrier Spring 上メス台バネ 1 15 3100506 Screw(M4-0.7×3) 止ネジ 1 16 170006 Screw(M4-0.7×2.5) 止ネジ 1 17 3100531 Upper Knife Carrier Stop 上メス台ストッパ 1 18 110008 Screw(M4-0.7×5) 止ネジ 1 19 3100517 Lower Knife Carrier Guide 下メス台ガイド 1 20 110009 Screw(M4-0.7×8) 止ネジ 4 21 3100518 Lower Knife Carrier Guide (Upper) 下メス台ガイド(上) 1 22 110002 Screw(M3-0.5×5) 止ネジ 2 23 3100512 Upper Knife 上メス 1 24 110024 Screw(M2-0.4×6) 止ネジ 2 25 110025 Screw(M2-0.4×10) 止ネジ 2 26 110023 Screw(M2-0.4×3.5) 止ネジ 1 27 3100507 Upper Knife Guide 上メスガイド 1 28 3100508 Clamp Spring 糸挟ミバネ 1 29 3100509 Clamp Spring Pressure 糸挟ミバネ押シ 1 30 3100510 Clamp Spring Pressure Holder 糸挟ミバネ押シ取付板 1 31 3100511 Clamp Spring Pressure Adjusting Piece 糸挟ミバネ押シ調節節片 1 32 130005 Screw(M2-0.4×4) 止ネジ 2 33 3100516 Lower Knife Carrier Support Spring 下メス台支エバネ 1 34 110034 Screw(M2-0.4×2) 止ネジ 2 35 3100565 Supplementary Spring 上メス台補助バネ 1 36 110031 Screw(M4-0.7×12) 止ネジ 1 37 3100560 Trimming Mechanism, C. Set UT機構(組) 1 38 3100530 Looper Thread Pull-off ルーパ糸緩メ片 1 ※ Ref. No. 39 to 54 ... See the following page.

Page 30

25 "UT" DEVICE (3) EXTRA PARTS "UT" DEVICE (3) Ref. No Parts No Description Amt. Req. 39 3100541 Soleno id Support 1 40 0010841 Wiper Solenoid 1 41 000002 Spring Washer 2 42 000012 Nut 2 43 3100546 Wiper Solenoid Lever 1 44 120007 Screw (M3-0.5×10) 1 45 3100542 Wiper Link 1 46 170007 Screw (M3-0.5×2.5) 3 47 3100543 Wiper Bracket 1 48 3100548 Wiper Thread Guide 1 49 3100544 Wiper 1 50 3100545 Wiper Fixing Washer 1 51 110007 Screw (M2.5-0.45×6) 2 52 3100547 Thread Clamp Spring Plate 1 53 000531 Washer 1 54 3109930 Wiper Mechanism, Complete Set 1 ※ Ref. No. 1 to 38 ... See the preceding page.

Page 31 — "UT" DEVICE (4)

26 "UT" DEVICE (4) "UT"装置(4) Amt. Ref. Parts No. No. Description Req. 1 3100571 Presser Foot Lifter Solenoid, C. Set 押エ場ゲソレノイド(組)・1 2 3100570 Solenoid Support ・ソレノイド台 1 3 000070 Hanging Nut ・吊リナツト 4 4 000429 Washer ワツシヤ 8 5 000016 Nut ナツト 12 6 009865 Hanging Bolt 吊リボルト 4 7 000676 Spring Washer スプリングワツシヤ 8 8 0011733 Presser Foot Lifter Solenoid 押エ場ゲソレノイド 1 9 009970 Screw(M6-1×20) 止ネジ 4 10 000011 Nut ナツト 1 11 000528 Washer ワツシヤ 1 12 000588 Anti-shock Rubber 緩衝ゴム 2 13 000306 Nut ナツト 1 14 0064045 Lifter Connecting Rod 押エ場ゲ連結桿 1 15 0064046 Lifter Connecting Link 押エ場ゲリンク 2 16 0035301 Connecting Link Pin 押エ場ゲリンクピン 2 17 0033024 Retaining Ring ストツプリング 2 18 0064047 Presser Foot Lifter Solenoid Lever 押エ場ゲソレノイドレバー 1 19 009853 Screw(M6-40×6.5) 止ネジ 1 20 0032786 Solenoid Lever Pin ソレノイドレバーピン 1 21 0037912 Chain 鎖 1

Page 32 — "UT-A" DEVICE (1)

2.7 "UT-A" DEVICE (1) "UT-A"装置(1) 27 Amt. Ref. No. Parts No. Description Reg. 1 0065373 Lifter Lever 押工揚レバー 1 2 0037912 Chain 鎖 1 3 0093499 Lifter Lever Stop 押工揚レバーストップ 1 4 004358 Screw (9/64-40×5.6) 止ネジ 2 5 3100523 Tension Release Lever 糸繰メ腕 1 6 120001 Screw (M4-0.7×14) 止ネジ 1 7 3100526 Tension Release Block 糸繰メブロック 1 8 007610 Screw (M4-0.7×10) 止ネジ 2 9 3100065 Tension Release Connecting Plate 糸繰メ連結板 1 10 110009 Screw (M4-0.7×8) 止ネジ 2 11 170009 Screw (M4-0.7×4) 止ネジ 1 12 0094491 Cord Clamp (2N-φ3.4) コードクランプ 2 13 110012 Screw (M4-0.7×5) 止ネジ 4 14 0022836 Synchronizer Positioning Pin ポジショナピン 1 15 0022837 Synchronizer Cushion ポジショニククッション 1 16 190009 Screw (M4-0.7×7) 止ネジ 1 17 0096358 Air Wiper Bracket エアワイパ取付台 1 18 009747 Screw (M4-0.7×10) 止ネジ 1 19 000644 Spring Washer スプリングワッシャ 1 20 000532 Washer ワッシャ 1 21 0096357 Air Wiper エアワイパ 1 22 009744 Screw (M3-0.5×10) 止ネジ 1 23 000002 Spring Washer スプリングワッシャ 1 24 000014 Washer ワッシャ 1 25 3100529 Thread Pull-off Eyelet 糸繰メ糸道 1 ※ Ref. No. 26 to 44 ... See the following page. Device classification 装置の種類 Mark Trimming Wiper Foot 記号 Cylinder, C. Set Lifter UT-A1 1091002 1091005 UT-A1 X O UT-A2 O O UT-A3 O X UT-A4 O X UT-A5 O X O... Assembled 有り X... Non-assembled 無し (注) ワイパはエア吹き付け式になっておりエアシリンダを使用していません。 Note: For Wiper, the air blowing system is used instead of Air Cylinder. jinte.in

Page 33 — "UT-A" DEVICE (1)

27 "UT-A" DEVICE (1) Ref. No. 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 Parts No 0067101 0063076 0094433 001208 3101275 001459 3101276 0094396 0033024 0063515 000690 0094390 0095334 001170 3100528 3100527 110014 000505 0094387 "UT-A"装置(1) Description Thread Pull-off Bar Swing-proof Spring Collar (4×11×7mm) Screw (9/64-40×5) Thread Pull-off Hook Unit (See table) Screw (9/64-40×3) (See table) Thread Pull-off Hook Unit (See table) Thread Pull-off Bar Holder Retaining Ring Thread Pull-off Lever Dowel Pin Tension Release Adjusting Eccentric Swing-proof Spring Screw (9/64-40×12) Tension Disc Separator Tension Post Support Screw (M4-0.7×18) Spacer Tension Release Shaft 27 Amt. Req. 1 1 1 2 - - 1 1 1 1 1 1 1 1 1 1 2 2 1 品 名 糸繰棒 糸繰メ防振バネ カラー 止ネジ 糸繰メフック(組)(下参照) 止ネジ(下表参照) 糸繰メフック(組)(下参照) 糸繰棒連結片 ストップリング 糸繰メレバー 止メピン 糸繰メ板調節コロ 糸繰メ防振バネ 止ネジ 糸繰メ板 糸調子台 止ネジ スペーサ 糸繰メ軸 ※ Ref. No. 1 to 25 See the preceding page. Parts No 3101275 001459 3101276 001459 2 Needle without Spreader 3 Needle without Spreader 2 Needle with Spreader 3 Needle with Spreader 3101275 2個 pcs. 3 2 3 001459 3個 pcs. 4 5 3101276 1個 pcs. 1 2 2 (注) カラーの寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. Outside dia. X Thickness.

Page 34 — "UT-A" DEVICE (2)

28 "UT-A" DEVICE (1) "UT-A" 装置(2) 28 Ref. Parts Amt. No No Description Req. 1 1091002 Trimming Cylinder, Complete Set · 糸切リシリンダ(組) 1 2 0010340 Trimming Cylinder 糸切リシリンダ 1 3 0010057 Elbow Connector エルボ継手 1 4 0010143 Silencer サイレンサ 1 5 000389 Spacer スペーサ 1 6 0014120 Anti-shock Rubber 緩衝ゴム 1 7 0033104 Collar(10×18×9mm) カラー 1 8 005550 Screw(11/64-40×13.5) 止ネジ 1 9 0096355 Cylinder Bracket シリンダブラケット 1 10 005650 Screw(M5-0.8×14) 止ネジ 3 11 3100524 Trimming Cylinder Support シリンダ取付台 1 12 120013 Screw(M6-1×15) 止ネジ 2 13 0063610 Switch, Complete Set スイッチ(組) 1 14 0063607 Switch Support スイッチ取付板 1 15 110004 Screw(M3.5-0.6×8) 止ネジ 3 16 0063606 Switch スイッチ 1 17 0063609 Switch Cover スイッチカバー 1 18 009984 Screw(M2.3-0.4×10) 止ネジ 2 19 0063608 Switch Guide スイッチガイド 1 20 110002 Screw(M3-0.5×5) 止ネジ 2 21 0036133 Cord Clamp(5N-φ 8.4) コードクランプ 1 22 000145 Nut ナット 2 23 0095388 Plunger Connecting Rod プランジャロッド 1 24 001457 Packing Screw(11/64-40×3.3) 締ネジ 2 25 0095389 Plunger Connecting Rod Pin プランジャロッドピン 1 26 3100520 Plunger プランジャ 1 27 160002 Screw(M4-0.7×5) 止ネジ 2 28 3100532 Cylinder Return Shaft シリンダ戻リシャフト 1 29 0093491 Collar(8×16×8mm) カラー 1 30 009508 Screw(11/64-40×7.5) 止ネジ 1 31 0095336 Cylinder Return Spring シリンダ戻リバネ 1 32 180006 Screwed Pin(M5-0.8×6) ピンネジ 1 33 3100523 Connecting Block(Right) Support 連結ブロック支エバネ 1 34 3100522 Connecting Block(Right) 連結ブロック(右) 1 35 100001 Nut ナット 3 36 190008 Connecting Rod 連結棒 1 37 3100521 Connecting Block(Left) 連結ブロック(左) 1 (注) カラーの寸法は内径×外径×幅を表しています。 Note: Size of Collar Inside dia. ×Outside dia. ×Thickness.

Page 35 — UT-A DEVICE (3)

29 "UT-A" DEVICE (3) "UT-A"装置(3) Amt. Ref. Parts Description 品 名 Req. No No 1 3100506 Lower Knife Driving Lever 下メス駆動レバー 1 2 170005 Screw(M4-0.7×6) 止ネジ 2 3 3100502 Lower Knife Carrier 下メス台 1 4 3100514 Lower Knife Holder 下メス取付板 1 5 3100513 Lower Knife 下メス 1 6 110030 Screw(M3-0.5×2.6) 止ネジ 3 7 3100501 Upper Knife Carrier 上メス台 1 8 190006 Screw(M4-0.7×4) 止ネジ 2 9 100006 Nut ナット 2 10 3100503 Knife Guide Lever メスガイドレバー 2 11 3100504 Knife Guide Lever Ring(Left) メスガイドレバーリング(左) 1 12 3100505 Knife Guide Lever Ring(Right) メスガイドレバーリング(右) 1 13 130003 Screw(M4-0.7×7.3) 止ネジ 2 14 3100515 Upper Knife Carrier Spring 上メス台バネ 1 15 170006 Screw(M4-0.7×2.5) 止ネジ 1 16 3100500 Crank Chamber Cover ナカカバー 1 17 3100531 Upper Knife Carrier Stop 上メス台ストッパ 1 18 110008 Screw(M4-0.7×5) 止ネジ 1 19 3100517 Lower Knife Carrier Guide 下メス台ガイド 1 20 110009 Screw(M4-0.7×8) 止ネジ 2 21 3100518 Lower Knife Carrier Guide (Upper) 下メス台ガイド(上) 1 22 110002 Screw(M3-0.5×5) 止ネジ 1 23 3100512 Upper Knife 上メス 1 24 110024 Screw(M2-0.4×6) 止ネジ 2 25 110025 Screw(M2-0.4×10) 止ネジ 1 26 110023 Screw(M2-0.4×3.5) 止ネジ 1 27 3100507 Upper Knife Guide 下メス台ガイド 1 28 3100508 Clamp Spring 糸挟ミバネ 1 29 3100509 Clamp Spring Pressure 糸挟ミバネ押シ 1 30 3100510 Clamp Spring Pressure Holder 糸挟ミバネ押シ取付板 1 31 3100511 Clamp Spring Pressure Adjusting Piece 糸挟ミバネ押シ調節片 1 32 130005 Screw(M2-0.4×4) 止ネジ 2 33 3100516 Lower Knife Carrier Support Spring 下メス台支エバネ 1 34 110034 Screw(M2-0.4×2) 止ネジ 2 35 3100560 Supplementary Spring 上メス台補助バネ 1 36 110031 Screw(M4-0.7×12) 止ネジ 1 37 3100565 Trimming Mechanism, C. Set UT機構(組) 1 38 3100530 Looper Thread Pull-off ルーパ糸緩メ片 1

Page 36

30 “UT-A” DEVICE (4) “UT-A” 装置 (4) 30 Amt. Ref. No Parts No Description Req. 1 0010073 Regulator レギュレータ 1 2 009973 Screw (M5-0.8×10) 止ネジ 2 3 000669 Washer ワッシャ 2 4 000600 Spring Washer スプリングワッシャ 2 5 000009 Nut ナット 2 6 0013218 Regulator Support レギュレータ取付板 1 7 009937 Wood Screw (φ3.8×20) 木ネジ 2 8 0033939 Hose Band ホースバンド 1 9 0010108 Hose Connector(φ8-1/4) ホースユニオン 1 10 0010289 T-Joint T継手 1 11 3201035 Presser Foot Lifter Cylinder, C. Set 押エ揚ゲゲシリンダ(組) 1 12 0033104 Cylinder Stop Collar シリンダストッパカラー 1 13 005550 Screw(11/64-40×13.5) 止ネジ 1 14 1091050 Rubber Cushion 緩衝ゴム 1 15 3201037 Presser Foot Lifter Cylinder 押エ揚ゲシリンダ 1 16 3201037 Cylinder Rod Chip シリンダロッドチップ 1 17 3201036 Cylinder Bracket シリンダ取付台 1 18 120013 Screw(M6-1×15) 止ネジ 2 19 000425 Washer ワッシャ 2 20 0010057 Elbow Connector エルボ継手 5 21 0010343 Electromagnetic Valve, C. Set (UT-A2) 電磁弁(組) 1 22 1090012 Manifold マニフォールド 1 23 009880 Wood Screw (φ4.5×40) 木ネジ 2 24 0010143 Silencer サイレンサ 2 25 0010263 Connector(φ6-PT1/8) コネクタ 1 26 0010119 Seal Plug メクラプラグ 3 27-1 1090011 Electromagnetic Valve (UT-A2) 電磁弁 3 27-2 1090011 〃 (UT-A2/AS3) 〃 4 28-1 0010254 Speed Controller (UT-A2) スピードコントローラ 1 28-2 0010254 〃 (UT-A2/AS3) 〃 3 29 0010868 Cord (A) コード(A) 1 30 0010869 Cord (B) コード(B) 1 31 0010261 Vinyl Tube (6×4mm) ビニールパイプ 32 0010260 Vinyl Tube (4×2.5mm) ビニールパイプ 33 1090100 Electromagnetic Valve, C. Set (UT-A2) 電磁弁(組) 1 34 1090013 Manifold マニフォールド 1 35 1200003 Cord (C) コード(C) 1 (注) ビニールパイプ御注文の際は品番と長さを お知らせ下さい。 Note: As for Vinyl Tube, your order must be accompanied with No. and length. (注) Ref. No. 33の電磁弁(組)は、“UT-A2/AS3”用のもので31ページの関連部品と共に 使用します。 Note: The Electromagnetic Valve, Complete Set of Ref. No. 33 is for “UT-A2/AS3” and is to be used together with related parts on page 31.

Page 37 — AS3 DEVICE

31 "AS3" DEVICE for "UT-A2/AS3" DEVICE Ref. No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34-1 34-2 34-3 34-4 Parts No. 0010073 0013218 009973 000669 000600 000009 006905 0033939 0010108 0010078 0010260 1090010 0010120 0010055 0010119 0010254 009937 1094000 000623 0010048 000426 0010019 0010258 0011709 0011341 0011340 0010565 0010564 000538 000644 000023 0092232 006910 0011943 0011944 0011945 0011946 "AS3"装置 Description Regulator Regulator Support Screw (M5-0.8×10) Washer Spring Washer Nut Wood Screw (φ 5.1×20) Hose Band(1/4inch) Joint Joint Vinyl Tube (4×2.5mm) Electromagnetic Valve, C. Set Electromagnetic Valve Straight Joint Seal Plug Speed Controller (SPC4-1/8) Wood Screw (φ 3.8×20) Joint Gasket Air Cylinder (MS-16ND-45) Washer L-Connector (M-5UL) Connector Control Box Stay Control Box, Complete Set Control Board Knee Switch, Complete Set Knee Switch Washer Spring Washer Wing Nut Knee Switch Holder Wood Screw (φ 6.8×26) Power Cord (for 100 Voltage) " ( 200 ) " ( 220 ) " ( 380 ) Amt. Req. 1 1 2 2 2 4 6 1 1 1 1 1 1 2 1 1 1 2 1 1 2 1 1 2 1 1 1 1 4 2 2 1 2 1 1 1 1 (注) ビニールパイプ御注文の際は品番と長さを お知らせ下さい。 Note: As for Vinyl Tube, your order must be accompanied with No. and length. jinte.in

Page 38 — EXTRA PARTS

32 EXTRA PARTS 特注部品 32 Amt. Ref. No Parts No Description Req. 1 0022836 Synchronizer Positioning Pin ポジョショナピン 1 2 0022837 Synchronizer Cushion ポジョショナピンクツシヨン 1 3 007610 Screw (M4-0.7×10) 止ネジ 1 4 0093690 Timing Gauge タイミングゲージ 1 5 0095220 Looper Timing Gauge ルーパタイミングゲージ 1 6 3100490 Timing Gauge タイミングゲージ 1 7 3200242 Chain Guide 鎖ガイド 1 8 110009 Screw (M4-0.7×8) 止ネジ 2 9 000541 Washer ワッシャ 2 10 1090101 Electromagnetic Valve, C. Set 電磁弁(組) 1 11 0010120 Electromagnetic Valve 電磁弁 1 12 009937 Wood Screw (φ3.8×20) 木ネジ 2 13 0010263 Connector (φ6-PT1/8) コネクタ 1 14 0010143 Silencer サイレンサ 2 15 0010119 Seal Plug メクラプラグ 1 16 0010254 Speed Controller (SPCA-1/8) スピードコントローラ 1 (注) Ref. No. 10の電磁弁(組)は、切屑吸込管用です。 (踏込み出力のあるモータを使用している場合に、この電磁弁(組)を使用するとエアが 節約できます。) Note: Electromagnetic Valve, Complete Set is for Dust Suction Pipe. (In case of using motor with treadle output, the air consumption is saved by using this Electromagnetic Valve, Complete Set.)

Page 39 — THREAD STAND & SUPPORTING BOARD

3.3 糸立及び受ケ板 Ref. No. Parts No. Description Amt. Req. 1-1 0099056 Thread Stand, Complete Set (5 Spools Type) 糸立台(組)(5本組) 1 1-2 0099048 " (6 Spools Type) " " (6本組) 1 2 0099057 Column Cap コラムキャップ 2 3 0099058 Column Pipe (Upper) コラムパイプ(上) 1 4 0099060 Thread Hanger (3 Spools Type) スレッドハンガ (3本用) 1 5 0099059 Thread Hanger (2 Spools Type) " (2本用) 1 6 000147 Screw 止ネジ 5 7 000148 Washer ワッシャ 4 8 0099061 Column Pipe Connector コラムパイプ継手 1 9 000149 Screw 止ネジ 2 10 000152 Nut ナット 9 11 0099062 Thread Guide Holder 糸案内ホルダ 1 12 13 14 0099063 Column Pipe (Lower) コラムパイプ(下) 1 15 000154 Washer ワッシャ 2 16 000153 Nut ナット 2 17 0099030 Thread Guide Bar 糸案内支棒 1 18 0099031 Thread Guide Bar Bracket 支棒継点 1 19 0099064 Thread Guide 糸案内 1 20 003632 Screw (1/4-40×10) 止ネジ 5 21 0099065 Spool Cushion スプールクッション 5 22 0099066 Spool Pin スプール軸 5 23 000157 Spring Washer スプリングワッシャ 5 24 0099067 Spool Mat スプールマット 5 25 0099068 Spool Seat Disc 受皿 5 26 0099069 Spool Holder Stay スプールホルダ支工 1 27 000158 Screw 止ネジ 1 28 000159 Wood Screw 木ネジ 1 29 0099070 Spool Holder (3 Spools type) スプールホルダ (3本用) 1 30 0099071 Spool Holder (2 Spools type) スプールホルダ (2本用) 1 31 0063031 Belt Cover ベルトカバー 1 32 110028 Screw (M6-1×46) 止ネジ 2 33 3100008 Supporting Board 油受ケ板 2 34 180009 Setting Screw (M6-1×19) 取付ケネジ 4 35 0063009 Oil Reservoir Rubber Cushion ゴム座 4 36 000070 Hanging Nut 吊りナット 4 37 009858 Hanging Bolt (M8-1.25×75) 吊りボルト 4 38 000429 Washer ワッシャ 8 39 0020064 Supporting Board Rubber Cushion 受ケ板ゴム座 4 40 0063010 Supporting Board Rubber Cushion (Lower) 受ケ板ゴム座(下) 4 41 000016 Nut ナット 8 42 180008 Setting Screw (M6-1×63) 取付ケネジ 4 43 000528 Washer ワッシャ 8 44 000667 Spring Washer スプリングワッシャ 4 45 000011 Nut ナット 4 Setting on the Table(上乗せ式)

Page 40 — VC3611-D CLASS LIST of MAIN SPARE PARTS

34 V C 3 6 1 1 - D C L A S S L I S T of M A I N S P A R T S (主要部品リスト) V C 3 6 1 1 - D INDEX PAGE = 1 Main Parts Needle Presser Foot, Stitch Differen- tial Main Looper Parts Page Ref. Weight Parts Page Ref. Weight Models Clamp C. Set Plate Feed Dog Feed Dog No. No. No. (g) No. No. No. (g) 針止メ 押工(組) 前送リ 後送リ ルーパ 000002 25 41 000426 21 25 000644 31 30 VC3611-040L-D 0093352 3117076 3118021 3119020 3119021 3109300 000002 27 23 000426 31 21 000644 31 30 048L-D 0093353 3117078 3118022 〃 〃 〃 000005 2 43 000429 22 21 000651 2 17 056L-D 3009101 3117080 3118023 〃 〃 〃 000009 21 24 000429 22 22 000651 3 38 145L-D 3099104 3097052 3098044 〃 〃 〃 000009 30 8 000429 26 21 000652 12 12 156L-D 3099101 3117088 3118033 〃 〃 〃 000010 4 29 000433 22 33 000667 33 44 000010 10 48 000443 13 38 000669 10 43 3645P-040L-D 0093352 3117094 3118021 〃 〃 〃 000011 26 10 000445 8 8 000669 21 13 048L-D 0093353 3117092 3118022 〃 〃 〃 000011 33 45 000463 5 26 000669 30 3 056L-D 3009101 3117090 3118023 〃 〃 〃 000014 2 38 000487 19 31 000669 31 4 3711-148L-D 0093356 3117122 3118024 〃 〃 〃 000014 27 24 000505 10 32 000690 8 20 156L-D 0093357 3117124 3118025 〃 〃 〃 000016 26 5 000505 23 39 000690 19 28 000016 33 41 000505 27 43 000690 23 32 000023 31 31 000528 12 23 000690 27 36 000070 26 3 000528 18 10 000723 11 18 000070 33 36 000528 21 15 000726 1 34 000140 24 4 000531 5 40 000730 5 19 000145 18 15 000531 25 53 000740 9 46 000145 22 7 000531 25 53 000750 11 43 000145 24 20 000532 3 26 000779 17 3 000145 28 22 000532 6 34 000779 17 3 000148 33 6 000532 16 16 000779 18 35 000149 33 7 000532 27 20 000924 1 18 000152 33 10 000535 2 49 000924 1 18 000153 33 16 000535 21 16 000926 6 17 000154 33 15 000538 2 46 000989 6 4 000157 33 23 000538 3 36 000158 33 27 000538 18 41 001093 3 47 000159 33 28 000538 19 41 001107 5 14 000177 3 5 000538 21 31 001107 10 30 000177 16 4 000541 16 32 001107 23 35 000177 20 20 000541 32 9 001170 27 39 000199 11 40 000547 4 30 001174 6 21 000234 14 3 000548 7 4 001174 17 16 000304 5 18 000555 6 27 001186 8 15 000306 17 21 000567 14 37 001186 20 2 000306 18 18 000588 21 21 001208 23 25 000306 26 13 000588 26 12 001208 27 29 000321 7 21 000597 24 6 001227 24 18 000327 8 42 000598 24 5 001228 8 45 000327 20 6 000600 6 31 001228 20 9 000327 21 39 000600 10 44 001228 21 43 000334 4 31 000600 30 4 001230 4 26 000334 19 4 000613 17 5 001457 24 22 000340 19 17 000613 17 20 001457 28 24 000360 16 31 000613 19 29 001459 8 13 000389 28 5 000623 31 19 001459 22 26 000397 5 17 000629 7 55 001459 23 27 000397 11 47 000637 7 33 001459 27 31 000417 9 5 000637 7 33 001818 16 28 000419 14 45 000644 2 50 001900 7 9 000425 30 19 000644 21 17 001900 16 21

Page 44 — INDEX

INDEX Page = 8 INDEX Page = 9 Parts Page Ref. Weight| Parts Page Ref. Weight| Parts Page Ref. Weight| Parts Page Ref. Weight No. No. No. (g) | No. No. No. (g) | No. No. No. (g) | No. No. No. (g) 3100515 29 14 | 3100602 17 24 | 3110034 12 1 | 3119020 11 35 3100515 29 14 | 3100603 17 27 | 3110037 12 2 | 3119021 11 34 3100516 25 33 | 3100604 17 6 | 3110038 12 5 3100516 29 33 | 3100605 17 12 | 3110039 12 19 3100517 25 19 | 3100607 17 5 | 3110051 12 16 3120033 13 7 3100517 29 19 | 3100608 17 13 | 3110070 2 40 3120114 22 23 3100518 25 21 | 3100609 18 20 | 3110072 2 41 3120240 22 18 3100518 29 21 | 3100610 19 20 | 3110108 2 45 3120241 22 19 3100520 24 24 | 3100611 18 1 | 3110109 2 52 3120243 22 30 3100520 29 24 | 3100612 18 3 | 3110130 22 17 3120244 22 29 3100521 24 35 | 3100613 18 5 | 3110150 1 35 3120245 22 34 3100521 28 37 | 3100614 18 19 | 3110160 1 19 3100522 24 32 | 3100615 18 17 | 3110160 1 19 3200047 16 17 3100522 28 32 | 3100616 18 12 | 3110161 2 35 3200048 16 10 3100523 24 31 | 3100617 18 11 | 3110162 2 3 3200049 16 12 3100523 28 33 | 3100618 18 24 | 3110163 2 15 3200063 16 24 3100524 24 9 | 3100619 18 33 | 3110169 13 3 3200064 16 25 3100524 28 11 | 3100620 17 10 | 3110170 12 10 3200086 12 13 3100525 23 8 | 3100621 17 36 | 3110171 13 1 3200242 32 7 3100525 27 9 | 3100622 17 26 | 3110172 12 30 3200251 4 22 3100526 23 6 | 3100623 17 17 | 3110173 12 25 3200252 4 25 3100526 27 7 | 3100626 17 10 | 3110174 12 20 3100527 23 37 | 3100636 19 33 | 3110180 13 5 3100527 27 41 | 3100637 19 33 | 3110185 1 38 3201035 30 11 3100528 23 26 | 3100638 18 30 | 3110190 21 32 3201036 30 17 3100528 27 36 | 3100767 22 1 | 3110191 21 31 3201037 30 16 3100529 23 21 | 3100768 22 2 | 3110192 21 30 3100529 27 25 | 3100769 22 3 | 3110193 21 29 3300101 22 11 3100530 25 38 | 3100770 22 4 | 3110194 21 27 3100530 29 38 | | 3110195 21 26 4109403 1 33 3100531 25 17 | 3101200 4 23 | 3110196 21 26 3100531 29 17 | 3101202 4 40 | 3110197 21 11 3100532 24 26 | 3101220 19 30-2 | 3110198 21 14 3100532 28 26 | 3101260 21 23 | 3110199 21 2 3100533 23 4 | 3101275 23 26 | 3110200 21 44 3100533 27 5 | 3101275 27 30 | 3110201 21 41 3100535 23 12 | 3101276 28 28 | | 3100536 23 11 | 3101276 27 27 | 3117048 21 42 3100541 25 39 | 3101300 11 50 | 3117070 20 15-2 3100542 25 45 | 3101354 18 29-2 | 3117076 8 14-1 3100543 25 47 | 3101355 18 31-2 | 3117078 8 14-1 3100544 25 49 | | 3117078 8 14-2 3100545 25 50 | 3109200 11 6 | 3117080 8 14-3 3100546 25 43 | 3109201 11 10-1 | 3117084 8 44 3100547 25 52 | 3109210 11 10-2 | 3117084 20 8 3100555 9 3-2 | 3109300 9 1 | 3117088 20 1 3100560 25 35 | 3109310 15 25 | 3117090 21 34-3 3100560 29 35 | 3109930 25 54 | 3117092 21 34-2 3100565 25 37 | | 3117094 21 34-1 3100565 29 37 | 3110010 2 28 | | 3100570 26 2 | 3110012 2 37 | 3118021 7 10-1 3100571 26 1 | 3110014 2 14 | 3118022 7 10-2 3100600 17 29 | 3110031 12 18 | 3118023 7 10-3 3100601 17 28 | 3110032 12 4 | 3118024 20 16-1 | | 3110033 12 7 | 3118025 20 16-2
