Parts index — Brother BAS-6150tap a row to open its page

Page 2

Brother BAS-6150 parts on page 2

Ref	Part number	Part name	Qty
	1	主体関係
	1	下軸関係
	3	上軸関係
	5	針棒駆動関係
	7	メン関係
	9	ゲージ関係
	11	ケース関係
	13	カマ関係
	15	給油潤滑関係
	19	糸切り関係
	21	糸切り関係
	23	糸切り関係
	25	糸繰り関係
	25	モータ関係
	27	下糸検出関係(Option Parts)
	29	糸切り感知関係(Option parts)
	33	糸切り関係
	35	空圧関係
	39	電装部品関係
	43	布制御関係
	47	プリント基板関係
	51	マーカー関係
	51	操作パネル関係
	53	踏板関係
	53	動力台関係
	55	コーナース関係
	59	送り装置関係
	63	バインダー関係
	7	付属部品
	73	付属部品
	75	ゲージ部品一覧表
	77	ゲージ部品一覧表
	79	警告ラベル
	80	索引

Page 3

Brother BAS-6150 parts on page 3

Ref	Part number	Part name	Qty
	A	Machine body
	B	Lower shaft mechanism
	C	Upper shaft mechanism
	D	Needle bar rocking mechanism
	F	Knife mechanism
	G1	Gauge parts
	G2	Gauge parts
	H	Rotary hook mechanism
	J	Lubrication
	K	Threading mechanism
	L1	Thread trimmer mechanism
	L2	Thread trimmer mechanism
	M	Tension release mechanism
	N	Motor mechanism
	P	Lower thread detector (Option Parts)
	Q	Thread breakage detector (Option parts)
	R	Stacker mechanism (Option parts)
	S	Bobbin winder mechanism
	T	Air pressure mechanism
	U	Power supply equipment mechanism
	V1	Cloth control system mechanism
	V2	Cloth control system mechanism
	W	Printed circuit board mechanism
	X	Marker mechanism
	Y	Operation panel mechanism
	AA	Foot switch pedal mechanism
	AB	Power table
	AC	Corner knife mechanism
	AD	Feed device mechanism
	AE	Binder mechanism
	Z1	Accessories
	Z2	Accessories
	Ga1	Gauge parts List
	Ga2	Gauge parts List
	Wa	Warning labels
	Index	Index

Page 4

Brother BAS-6150 parts on page 4

Ref	Part number	Part name	Qty
	1	Shaft
	2	Screw
	3	Screw
	4	Shaft
	4-1	Pin
	4-2	Pin
	4-3	Pin
	5	Gear assembly
	5-1	Screw
	5-2	Gear
	5-3	Gear
	6	Bearing assembly
	6-1	Collar
	6-2	Bearing
	6-3	Screw
	6-4	Screw
	7	Gear assembly
	7-1	Gear
	7-2	Bearing
	8	Screw
	9	Screw
	10	Block
	11	Screw
	12	Bracket
	13	Screw
	14	Screw
	15	Screw
	16	Screw
	17	Screw

Page 5

Brother BAS-6150 parts on page 5

Ref	Part number	Part name	Qty
	113386000	POSITIONING PIN	1
	153011016	NEEDLE, MTX190 (#16)...<#16>	2
	153011014	NEEDLE, MTX190 (#14)...<#14>	2
	153011018	NEEDLE, MTX190 (#18)...<#18>	2
	104821001	RUBBER CAP, 10.5	1
	159928000	RUBBER CAP, 15	1
	S52523001	HOLDER BLOCK	1
	018501636	BOLT, SOCKET M5X16	2
	S52486101	FACE PLATE	1
	S39110001	BOLT, W/SOCKET SM5.95-28X14	3
	S38295000	BUSH, L;R-HOOK BASE	1
	S48724001	PLUNGER PUMP ASSY	1
	014781032	SET SCREW, SOCKET (CP) SM6.35	2
	S38253001	LOWER SHAFT, TR.	1
	S12445051	SPIRAL GEAR ASSY, A	2
	112684001	SET SCREW, SM6.35	2
	100251001	SET SCREW, (CP) SM6.35-40X6.5	4
	131007001	SET SCREW, (CP) SM6.35	6
	S07446001	BALL BEARING ASSY	1
	S07447001	BUSH, ;BALL BEARING	1
	072600480	BALL BEARING, 6004ZZNR	1
	148821001	SET SCREW, SOCKET (CN) SM6.35	1
	014771022	SET SCREW, SOCKET (CP) SM6.35	1
	S38237001	TIMING PULLEY SET, D	1
	S38245051	TIMING PULLEY ASSY, D	1
	158115001	BALL BEARING, 6204ZZNR	1
	144875001	PLUNGER	1
	S48732001	SPRING, COMPRESSION	1
	112467002	SCREW, SM6.35X5	1
	014771022	SET SCREW, SOCKET (CP) SM6.35	1
	148821001	SET SCREW, SOCKET (CN) SM6.35	1

Page 6 — C.上軸圖系 / Upper shaft mechanism

Brother BAS-6150 parts on page 6

Ref	Part number	Part name	Qty
1	1	SHAFT
2	2	COLLAR
5	5	SHAFT
6	6	BRACKET
7	7	SCREW
8	8	SCREW
9	9	SHAFT
10	10	PIN
11	11	SCREW
12	12	SCREW
13	13	COLLAR
14	14	PULLEY
15	15	SCREW
16	16	PULLEY
17	17	BELT
18	18	PULLEY
19	19	PULLEY
19-1	19-1	SCREW
21	21	BRACKET
21-1	21-1	SHAFT
21-2	21-2	COLLAR
22	22	SHAFT
23	23	BRACKET
24	24	SHAFT
25	25	PIN
26	26	BRACKET
27	27	SCREW
28	28	COLLAR
29	29	SCREW
30	30	WASHER

Page 7 — C.上軸関係 / Upper shaft mechanism

Brother BAS-6150 parts on page 7

Ref	Part number	Part name	Qty
	S38270001	BUSH, L ;U-SHAFT	1
	014781032	SET SCREW, SOCKET (CP) SM6.35	1
	S52487001	UPPER SHAFT	1
	S38396000	THREAD TAKE-UP CRANK	1
	100250001	SCREW, SM7.14	1
	146141001	SET SCREW, SM7.14-28X14	1
	S38398001	CRANKSHAFT, ;N-BAR	1
	113014000	PUSHER	1
	101706001	SET SCREW, SM6.35-40X5.5	1
	100251001	SET SCREW, (CP) SM6.35-40X6.5	1
	112576001	RING, T/TAKE-UP CRANK	1
	S38241051	TIMING PULLEY ASSY, U	1
	014771022	SET SCREW, SOCKET (CP) SM6.35	1
	016771032	SET SCREW, SOCKET (CN) SM6.35	1
	S38241100	TIMING BELT	1
	158115001	BALL BEARING, 6204ZZNR	1
	S57535000	SENSOR DOG ASSY	1
	014761030	SET SCREW,SOCKET(CP)SM5.95X10	2
	S38404001	THREAD TAKE-UP LEVER ASSY, L2	1
	S03289001	WICK, 4X4 L=40	1
	142274101	LUBBER CAP, 4.2	1
	S07334001	SHAFT, T/TAKE-UP LEVER	1
	014781032	SET SCREW, SOCKET (CP) SM6.35	2
	S07338001	SLIDE BLOCK, T/TAKE-UP LEVER	1
	113024000	PUSHER	1
	S07339209	COVER, T/TAKE-UP LEVER	1
	062670512	SCREW, PAN SM3.57-40X5	2
	S52491001	STOPPER COLLAR	1
	018401036	BOLT, SOCKET M4X10	2
	028040246	WASHER, SPRING 2-4	2

Page 8

Brother BAS-6150 parts on page 8

Ref	Part number	Part name	Qty
	1	Needle bar rocking mechanism
	1-1
	1-2
	1-3
	1-4
	1-4-1
	1-4-2
	1-5
	1-6
	1-7
	1-8
	1-9
	1-10
	1-11
	1-12
	1-13
	1-14
	1-15
	2
	200
	201
	202
	202-1
	202-2

Page 9 — D.針棒揺動関係 / Needle bar rocking mechanism

Brother BAS-6150 parts on page 9

Ref	Part number	Part name	Qty
1	S52495101	ROCKER SHAFT ASSY, N-BAR	1
1-1	112590001	GUIDE PLATE	2
1-2	102731004	SCREW, FLAT SM2.38-56X4.5	4
1-3	S59045001	NEEDLE BAR
1-4	S29863001	NEEDLE BAR CLAMP W/SCREW
1-4-1	112592001	NEEDLE BAR CLAMP
1-4-2	062670812	SCREW, PAN SM3.57-40X8
1-5	112593001	CRANK ROD, N-BAR
1-6	112721001	SLIDE BLOCK
1-7	S52497001	KNIFE BAR
1-8	S52498001	GUIDE, K-BAR
1-9	S52499001	CONNECTING ROD, B
1-10	062670812	SCREW, PAN SM3.57-40X8	2
1-11	S52500001	ROCKER SHAFT, L
1-12	014780622	SET SCREW, SOCKET (CP) SM6.35
1-13	S52524001	GUIDE, K-BAR
1-14	062681412	SCREW, PAN SM4.37-40X14	2
1-15	025680132	WASHER, PLAIN S 4.37	2
2	112594051	BUSH, L
200	153012101	STOPPER
201	014781032	SET SCREW, SOCKET (CP) SM6.35
202	S09132051	PINCH SLEEVE ASSY
202-1	152725000	PINCH SLEEVE
202-2	018063022	BOLT, SOCKET M6X30

Page 10 — F.メス関係 / Knife mechanism

Brother BAS-6150 parts on page 10

Ref	Part number	Part name	Qty
1-1	1-1	1-1
1-2	1-2	1-2
1	1	1
2	2	2
3	3	3
4	4	4
5	5	5
6	6	6
8	8	8
9	9	9
10	10	10
11	11	11
12	12	12
13	13	13
14	14	14
15	15	15
17	17	17
18	18	18
19	19	19
23-1	23-1	23-1
24	24	24
25	25	25
26	26	26
27	27	27
28	28	28
28-1	28-1	28-1
28-2	28-2	28-2
28-3	28-3	28-3
29	29	29
30	30	30
31	31	31
32	32	32
33	33	33
34	34	34
35	35	35
36	36	36
37	37	37
38	38	38
39	39	39
40	40	40
41	41	41
42	42	42
43	43	43
44	44	44

Page 11 — F.メス関係 / Knife mechanism

Brother BAS-6150 parts on page 11

Ref	Part number	Part name	Qty
	S52507001	ECCENTRIC WHEEL W/SCREW	1
	S52508001	DRIVING ECCENTRIC WHEEL	1
	014771022	SET SCREW, SOCKET (CP) SM6.35	2
	S48715000	CONNECTING ROD, ;ECCENTRIC	1
	118954000	NEEDLE BEARING	1
	S48716001	ECCENTRIC CRANK	1
	150936001	SCREW, SM6.35-28X14	1
	150937101	COLLAR	1
	150938201	HINGE SCREW	1
	151090001	WASHER, THRUST	1
	107017002	WASHER, WAVE SPRING 6.45	1
	110744002	NUT, SM6.35	1
	S48776000	BUSH, ;U-FEED SHAFT	2
	S52509001	ROCKER ARM	1
	S53180001	COLLAR	1
	S52512001	CONNECTING ROD, A ;I-KNIFE	2
	S16350001	SCREW, SM4.37	2
	S52514001	DRIVING ROD, I-KNIFE	1
	S59149001	KNIFE HOLDER, U	1
	105216001	SCREW, SM3.57X7	1
	S59150001	KNIFE HOLDER, D	1
	S59152001	UPPER KNIFE, C	1
	S59151001	KNIFE SUPPORT	1
	108960002	SCREW, FLAT SM3.57	2
	S36350001	FIXED KNIFE, CERAMIC	1
	148539101	SHOULDER SCREW, SM2.38	2
	S52518000	CYLINDER ASSY	1
	S52519000	CYLINDR,16X45	1
	S53168000	JOINT, KQ2K04M5	1
	S53488000	JOINT	1
	S53167000	NUT, M10	1
	S52520001	CYLINDR BRACKET	1
	062681212	SCREW, PAN SM4.37-40X12	1
	S32843001	CAM ROLLER	2
	153057102	SCREW, ROUND W/SOCKET SM4.37	2
	S53169001	JOINT ASSY, M5	1
	S06994001	SCREW, SM6.35	1
	S52521001	SPACER	1
	S20849101	CYLINDER SUPPORT	3
	S5896001	BOLT, FLANGE M6X16	1
	018401436	STOPPER BRACKET, INNER KNIFE	2
	028040246	WASHER, SPRING 2-4	2
	025040136	WASHER, PLAIN S 4	2
	S14874000	SHOCK ABSORBER	1
	025100232	WASHER, PLAIN M 10	1

Page 12 — G1. ゲージ関係 / Gauge parts

Brother BAS-6150 parts on page 12

Ref	Part number	Part name	Qty
3-3	1-3	OPTION PARTS
7	1-1-1	For Japan only > 10mm
5	4-1	screw
8	4-3	screw
1-2	1-2-1	For Export > 12mm
9	6	screw
8	4-2	screw

Page 13 — G1.ゲージ関係 / Gauge parts

Brother BAS-6150 parts on page 13

Ref	Part number	Part name	Qty
	S59140001	NEEDLE CLAMP ASSY, 10 UP	1
	146427001	SET SCREW, SOCKET (CP) SM3.18	2
	S52562001	NEEDLE PLATE ASSY, 10	1
	S52537001	LOOP GUIDE, 10	1
	S59141001	NEEDLE CLAMP ASSY, 12 UP	1
	146427001	SET SCREW, SOCKET (CP) SM3.18	2
	S52563001	NEEDLE PLATE ASSY, 12	1
	S52538001	LOOP GUIDE, 12	1
	S21921001	SCREW, FLAT SM2.38X8	2
	153208002	SCREW, SM4.37-40X7	2
	S52525001	GUIDE, N-PLATE	1
	153208002	SCREW, SM4.37-40X7	2
	※	NEEDLE CLAMP ASSY	1
	※	NEEDLE PLATE ASSY	1
	※	LOOP GUIDE, 10	1
	※	NEEDLE PLATE SET	1

Page 14 — G2. ゲージ関係 / Gauge parts

Brother BAS-6150 parts on page 14

Ref	Part number	Part name	Qty
	1-1-1-3	1-1 8-12mm
	1-1-1-2	1-1 8-12mm
	1-1-1-4	1-1 8-12mm
	1-1-1	1-1 8-12mm
	1-1-1-1	1-1 8-12mm
	1-1-5	1-1 8-12mm
	1-1-6	1-1 8-12mm
	1-1-7	1-1 8-12mm
	1-1-8	1-1 8-12mm
	1-2-1-3	" オプション部品 / OPTION PARTS "
	1-2-1-2	1-2 14-16mm 18-20mm
	1-2-1-4	1-2 14-16mm 18-20mm
	1-2-1	1-2 14-16mm 18-20mm
	1-2-1-1	1-2 14-16mm 18-20mm
	1-2-4	1-2 14-16mm 18-20mm
	1-2-2	1-2 14-16mm 18-20mm
	1-2-3	1-2 14-16mm 18-20mm
	1-2-5	1-2 14-16mm 18-20mm
	1-2-6	1-2 14-16mm 18-20mm
	1-2-7	1-2 14-16mm 18-20mm
	30	< 国内用 / For Japan only > 10mm
	30-1	両玉縁縫い / Double welting
	30-2	両玉縁縫い / Double welting
	30-3	両玉縁縫い / Double welting
	10	" 補給用部品 / For supply parts "
	10-1	片玉縁縫い / Single welting
	10-2	片玉縁縫い / Single welting
	10-3	片玉縁縫い / Single welting

Page 15 — G2.ゲージ関係 / Gauge parts

Brother BAS-6150 parts on page 15

Ref	Part number	Part name	Qty
	S586750001	スペーリタセット8-12
	S534290001	スペーリタクミ8-12
	S53430001	スペーリタ
	S53431001	シテンピン
	004401414	+サラコ4X14
	021400206	2シュナット4
	S53432000	セパレータ
	S53433000	スペーサA
	S53434000	スペーサB
	004300513	+サラコ3X5	2
	S53518001	イチギメカラー
	018300836	+ボルト3X8
	028030246	バネザガネ2-3
	S59275000	ジヨウキ10W-17
	S59041000	ジヨウキWミ
	S54655000	ジヨウキ10W-17
	W01519001	0サラコ3シュ2X4	5
	S59279000	ジヨウキ12W-21
	S59041000	ジヨウキWミ
	S54659000	ジヨウキ12W-21
	W01519001	0サラコ3シュ2X4	5
	※	"オプション部品"
	※	スペーリタセットXX-YY
	※	スペーリタクミXX-YY
	※	スペーリタ
	S53431001	シテンピン
	004401414	+サラコ4X14
	021400206	2シュナット4
	S53433000	スペーサA
	S53434000	スペーサB
	004300513	+サラコ3X5	2
	S53518001	イチギメカラー
	018300836	+ボルト3X8
	028030246	バネザガネ2-3
	※	"補給部品"
	S59041000	ジヨウキXXW-YY
	※	ジヨウキWミ
	W01519001	0サラコ3シュ2X4	5
	※	ジヨウキXXS-YY
	S59042000	ジヨウキSミ
	※	ジヨウキXXS-YY
	W01519001	0サラコ3シュ2X4	5

Page 16 — H . 力マ関係 / Rotary hook mechanism

Brother BAS-6150 parts on page 16

Ref	Part number	Part name	Qty
23-2	23-2	23-2
23-2-3	23-2-3	23-2-3
23-2-2	23-2-2	23-2-2
23-2-1	23-2-1	23-2-1
23-2-5	23-2-5	23-2-5
23-2-4	23-2-4	23-2-4
41	41	41
42	42	42
16	16	16
23-1-2	23-1-2	23-1-2
23-1-1-1	23-1-1-1	23-1-1-1
12-2	12-2	12-2
11	11	11
6-1	6-1	6-1
2	2	2
7	7	7
8	8	8
5	5	5
27	27	27
27-1	27-1	27-1
26	26	26
24	24	24
12-1	12-1	12-1
12-3	12-3	12-3
12-4	12-4	12-4
17	17	17
3	3	3
4	4	4
9	9	9
10	10	10

Page 17 — H.カマ関係 / Rotary hook mechanism

Brother BAS-6150 parts on page 17

Ref	Part number	Part name	Qty
3	062782512	SCREW, PAN SM6.35-28X25	2
4	100197002	WASHER	2
5	S09259001	BUSH, U	2
6-1	S09260001	THRUST RING, A ;1.2MM	2
6-2	S09261001	THRUST RING, B ;1.4MM	2
7	S07420000	NEEDLE BEARING	2
8	S07419001	RETAINING RING	2
9	S07417001	BUSH, D	2
10	013710512	SET SCREW, (CP) SM4.76-32X5	2
11	150967101	OPENER LINK	2
12-1	S38213051	OPENER LEVER, L	2
12-2	148005001	SHAFT, O-LINK	2
12-3	025710232	WASHER, PLAIN M 4.76	2
12-4	110161006	NUT, SM4.76	2
16	S13021001	SHAFT, O-LEVER	2
17	013711012	SET SCREW, (CP) SM4.76-32X10	2
23	S52675902	ROTARY HOOK ASSY, W/BOX	1
23-1-1	151027001	SET SCREW	4
23-1-2	S09273001	INNER ROTARY HOOK ASSY	2
23-2	S52677001	CAP ASSY	2
23-2-1	155479001	TENSION SPRING	2
23-2-2	151029001	TENSION ADJUSTING SCREW	2
23-2-3	110300001	SET SCREW	2
23-2-4	159802001	SCREW, SM1.59X2	2
23-2-5	S09284001	HOLDING PLATE, ;L-THREAD	2
24	S07436001	GEAR GUIDE, L	1
25	S07437001	GEAR GUIDE, R	1
26	108960002	SCREW, FLAT SM3.57	4
27	S07658001	PINCH SLEEVE ASSY	2
27-1	112700001	SCREW, SM5.95-28X32	2
41	S09285051	BOBBIN, 2	2
42	S09286000	SPRING, ANTI-SPIN	2
50	S38212001	OPENER	1
51	S38212001	OPENER	1
52	154965001	BOLT, SOCKET SM3.57X8	1
53	154965001	BOLT, SOCKET SM3.57X8	1

Page 18 — J. 給油潤滑関係 / Lubrication

Brother BAS-6150 parts on page 18

Ref	Part number	Part name	Qty
11	11	11
9	9	9
10	10	10
37	37	37
25	25	25
201	201	201
202	202	202
131	131	131
148	148	148
147	147	147
132	132	132
48	48	48
69	69	69
57	57	57
56	56	56
29	29	29
24	24	24
38	38	38
39	39	39
58	58	58
61	61	61
78	78	78
76	76	76
40	40	40
150	150	150
151	151	151
152	152	152
133	133	133
55	55	55
22	22	22
64	64	64
134	134	134
82	82	82
83	83	83
70	70	70
63	63	63
91	91	91
200-1	200-1	200-1
200-2	200-2	200-2
200-3	200-3	200-3
200-4	200-4	200-4
200-5	200-5	200-5
135	135	135
119	119	119
41-3	41-3	41-3
41-1	41-1	41-1
41-2	41-2	41-2
41	41	41
45	45	45
46	46	46
47	47	47
50	50	50
43	43	43
42	42	42
44	44	44
49	49	49
30	30	30
31	31	31
16	16	16
17	17	17
6	6	6
5	5	5
7	7	7
36	36	36
35	35	35
4	4	4
109	109	109
111	111	111
108	108	108
110	110	110
3	3	3
120	120	120
123	123	123
121	121	121
123	123	123
129-1	129-1	129-1
129-2	129-2	129-2
129-6	129-6	129-6
129-5	129-5	129-5
129-3	129-3	129-3
129-4	129-4	129-4
129-7	129-7	129-7
139	139	139
140	140	140
130	130	130
124	124	124
125	125	125
126	126	126
143	143	143
144	144	144
145	145	145

Page 19 — J.給油潤滑関係 / Lubrication

Brother BAS-6150 parts on page 19

Ref	Part number	Part name	Qty
3	S38248001	SCREW, PAN (S/P WASHER) SM3.57	8
4	S07477000	RUBBER RING	2
5	S07478000	RUBBER PRESSER	2
6	S38292001	OIL ADJUSTING SCREW	2
7	S38299001	OIL ADJUSTING SPRING	2
9	150988001	OIL STOPPER PLATE	1
10	112717001	HOLDER, O-STOPPER PLATE	1
11	062711212	SCREW, PAN SM4.76-32X12	1
16	112753001	FELT	2
17	S09043000	FELT	2
22	06270512	WICK HOLDER	2
23	062670512	SCREW, PAN SM3.57-40X5	2
24	S5770000	WICK, L = 28	3
25	S5770000	WICK, L = 28	3
29	148394000	CAP, N-BAR	1
30	140890009	OIL CAP	5
31	104821001	RUBBER CAP, 10.5	3
35	S38266000	FELT	2
36	S07476000	FELT	2
37	148762001	FELT	1
38	S38269000	FELT	1
39	S07571000	FELT	1
40	112753001	FELT	2
41	S52550001	OIL TANK ASSY	1
41-1	S52551000	OIL TANK	1
41-2	S07333001	PIPE, S	2
41-3	S52560001	OIL FEEDING PIPE, L	1
42	S52552000	CAP, O-TANK	1
43	S52553000	PACKING	1
44	004401003	SCREW, FLAT M4X10	4
45	S52560000	OIL TUBE, L=340	1
46	S52570000	OIL TUBE, L=580	1
47	S52580000	WICK, L=730	1
48	S52590000	OIL TUBE	1
49	152948001	OIL WINDOW	1
50	013710512	SET SCREW, (CP) SM4.76-32X5	1
55	S07465000	WICK, L=200	1
56	112728001	WICK, L=50	1
57	114693001	WICK, L=30	1
58	112735000	WICK, L=45	1
58	112735000	WICK, L=45	1
61	S53195000	WICK	1
63	S38481000	WICK, L=41	2
64	108802001	WICK, 4X4 L=250	2
69	S07462000	WICK, L=25	1
70	S07463000	WICK, L=70	2
75	S38541000	OIL RING	2
76	S48734000	FELT, D	1
78	062671412	SCREW, PAN SM3.57-40X14	1
82	S21195001	FELT SUPPORT	2
83	062670512	SCREW, PAN SM3.57-40X5	2
91	S07876101	TUBE CLIP	7
101	062670612	SCREW, PAN SM3.57-40X6	2
108	S48737000	PACKING, R	1
109	S48738000	PACKING, L	1
110	S48739001	CAP, R	1
111	S48740000	CAP, L	1
119	S38251000	OIL SEAL	1
120	S38261001	TUBE SUPPORT BRACKET, L	1
121	S38264001	OIL TUBE SUPPORT	1
123	062710612	SCREW, PAN SM4.76-32X6	2

Page 21 — J.給油潤滑関係 / Lubrication

Brother BAS-6150 parts on page 21

Ref	Part number	Part name	Qty
	S38292001	OIL ADJUSTING SCREW	1
	S38299001	OIL ADJUSTING SPRING	1
	S07478000	RUBBER PRESSER	1
	S52679001	OIL CASE ASSY	1
	S48763001	OIL CASE	1
	S53175000	OIL TUBE, L=450	1
	S53176000	OIL TUBE, D; L=355	1
	S53177000	OIL TUBE, U; L=170	1
	S53178000	WICK, L=300	1
	S53179000	DRAIN TUBE, L=300	1
	S07469001	TUBE CALKING	1
	060681212	SCREW, BIND SM4.37-40X12	2
	111865001	CAP, 6	1
	S49564002	RUBBER CAP, 12.5	1
	117934001	RUBBER CAP, 13.5	1
	S21196001	FELT	2
	104821001	RUBBER CAP, 10.5	1
	S02606000	OIL GAUGE WINDOW	1
	081014670	O RING, PW14	1
	112758001	OIL CAP	1
	S07481009	OIL MARK SHEET	1
	S53184001	OIL TUBE JOINT	1
	S07327001	CORD HOLDER, L	1
	062670512	SCREW, PAN SM3.57-40X5	1
	S04557000	BAND, PLT1M	1
	S55898000	FELT	1
	062670612	SCREW, PAN SM3.57-40X6	1
	025040135	WASHER, PLAIN S 4	1
	S54959001	TERMINAL ASSY	1
	S14189100	TERMINAL	1
	S38448000	OIL TUBE, L=200	1
	S07459100	OIL TUBE, L=240	1
	142274101	RUBBER CAP, 4.2	1
	S07464100	WICK, L=530	1
	S55769000	WICK, 4X4	1
	S55769000	WICK, 4X4	1
	S55304000	WICK, 4X4	1

Page 22

Brother BAS-6150 parts on page 22

Ref	Part number	Part name	Qty
1	1-1	SCREW
1	1-2	SCREW
1-3	1-3	SPRING
1-4	1-4	WASHER
1-5	1-5	SCREW
1-6	1-6	SCREW
1-7	1-7	SPRING
1-8	1-8	PLATE
1-9	1-9	SPRING
1-10	1-10	SCREW
1-11	1-11	PIN
1-12	1-12	PIN
1-13	1-13	SPRING
13-1	1-13-1	SPRING
13-2	1-13-2	SPRING
1-14	1-14	WASHER
1-15	1-15	SCREW
1-16	1-16	SPRING
1-17	1-17	SPRING
1-18	1-18	SPRING
1-19	1-19	WASHER
1-20	1-20	SCREW
1-21	1-21	SCREW
1-22	1-22	WASHER
1-23	1-23	WASHER
1-24	1-24	BOBBIN CASE
1-25	1-25	BOBBIN
1-26	1-26	SPRING
1-27	1-27	WASHER
2	2	SCREW
3	3	SPRING
4	4	SCREW
5	5	PIN
6	6	SCREW
7	7	BRACKET
8	8	SCREW
10	10	SCREW
12	12	BRACKET
12-1	12-1	BRACKET
12-2	12-2	BRACKET
12-31	12-31	BRACKET
12-4	12-4	BRACKET
13	13	SPRING

Page 23 — K.糸通し関係 / Threading mechanism

Brother BAS-6150 parts on page 23

Ref	Part number	Part name	Qty
	S15584509	UPPER THREAD TENSION ASSY, D	1
	S08604001	TENSION STUD	1
	S08607001	THREAD TAKE-UP SPRING, L	1
	S08608001	THREAD TAKE-UP SPRING, R	1
	108254001	GUIDE ASSY, ;T/TAKE-UP SPRING	2
	146124001	SCREW, SM2.38	1
	108265009	TENSION NUT	1
	158768001	PIN, 2.6X20	2
	S07487101	TENSION RELEASE PLATE	1
	S38274001	SPRING, T-RELEASE	1
	112712001	SHOULDER SCREW, SM3.57	2
	S07488001	TENSION RELEASE PIN	1
	158769001	TENSION RELEASE PIN, R	1
	145446001	DISC, TENSION	4
	159805001	DISC PRESSER, ;TENSION	2
	149566109	TENSION NUT	2
	144504001	DISC, THREAD GUIDE	4
	154560001	SPRING, ;PRE-TENSION (A)	2
	155510001	TENSION NUT	2
	S07490001	TENSION SPRING	2
	112709001	STOPPER	1
	062670512	SCREW, PAN SM3.57-40X5	1
	S08605101	SPACER	1
	S08606001	COLLAR	1
	S08609201	STOPPER SUPPORT	1
	S08610101	ADJUSTING THUMB	1
	013660612	SET SCREW, (CP) SM3.18	1
	151480001	STOPPER, ML	2
	100064002	SCREW, SM3.57X8	1
	112709001	STOPPER	1
	062670512	SCREW, PAN SM3.57-40X5	1
	S14677001	TENSION RELEASE SHAFT	1
	062680812	SCREW, PAN SM3.57-40X8	1
	108266001	THREAD GUIDE, U ARM	1
	S54023001	THREAD GUIDE, M	1
	108960002	SCREW, FLAT SM3.57	3
	S49529001	THREAD GUIDE ASSY, D	1
	S48760001	THREAD GUIDE, D	1
	S48761001	THREAD CLAMP	1
	112301001	SHOULDER SCREW, SM3.18	1
	S49530001	SPRING, COMPRESSION	1
	S30505001	THREAD RETAINER ASSY	2
	140527001	THREAD RETAINER	2
	150553003	NUT, SM5.95	2

Page 24 — L1. 糸切り関係 / Thread trimmer mechanism

Brother BAS-6150 parts on page 24

Ref	Part number	Part name	Qty
29	29	THREAD TRIMMER LEVER
30	30	SCREW
31	31	PIN
32	32	SPRING
33	33	SPRING
34	34	NUT
35	35	LINK
36	36	SHAFT
37	37	SCREW
38	38	SCREW
39	39	WASHER
40	40	SHAFT
41	41	COLLAR
42	42	SCREW
43	43	BRACKET
44	44	SCREW
45	45	SPRING
46	46	SPRING
47-3	47-3	THREAD TRIMMER LEVER
48	48	PIN
49-1	49-1	SPRING
50	50	SPRING

Page 25 — L1.糸切り関係 / Thread trimmer mechanism

Brother BAS-6150 parts on page 25

Ref	Part number	Part name	Qty
	S38419001	THREAD TRIMMER LEVER, R	1
	S38420001	THREAD TRIMMER LEVER, L	1
	062681212	SCREW, PAN SM4.37-40X12	2
	S07519001	STOPPER SCREW, SM4.76	2
	S07520001	SPRING, EXTENSION	2
	062671412	SCREW, PAN SM3.57-40X14	2
	021670102	NUT, 1 SM3.57	2
	S07521001	CONNECTING ROD, R ;TR	1
	S07522001	CONNECTING ROD, L ;TR	1
	144526001	SHOULDER SCREW, SM4.37	2
	146360002	BOLT, SM4.76X7	2
	025710232	WASHER, PLAIN M 4.76	2
	S53172001	LEVER, KNIFE	2
	120752001	SET SCREW COLLAR	2
	100251001	SET SCREW, (CP) SM6.35-40X6.5	4
	S07524101	MOVABLE KNIFE BRACKET	2
	062670812	SCREW, PAN SM3.57-40X8	4
	S07500000	SPRING, PLATE	2
	141544001	SCREW, SM3.18-40X3	4
	S52549001	MOVABLE KNIFE	2
	148536001	SCREW, W/SOCKET SM4.37-40X4.2	4
	S07527001	FIXED KNIFE	2
	148539101	SHOULDER SCREW, SM2.38	2

Page 26 — L2.糸切り関係 / Thread trimmer mechanism

Brother BAS-6150 parts on page 26

Ref	Part number	Part name	Qty
20-1	20-1	20-1
20-2	20-2	20-2
25	25	25
2-2	2-2	2-2
22	22	22
3-2	3-2	3-2
1	1	1
8	8	8
7	7	7
21	21	21
5	5	5
6	6	6
24	24	24
13	13	13
4-2	4-2	4-2
23	23	23
15-1	15-1	15-1
15-2	15-2	15-2
2-3	2-3	2-3
3-3	3-3	3-3
15	15	15
11	11	11
4-3	4-3	4-3
12	12	12
9	9	9
10	10	10
14	14	14

Page 27 — L2.糸切り関係 / Thread trimmer mechanism

Brother BAS-6150 parts on page 27

Ref	Part number	Part name	Qty
1	S59235001	KNIFE GUIDE	1
2-2	S53494001	FIXED KNIFE, 10-12	1
3-2	S53498001	N/THREAD KNIFE ASSY, 10-12	1
4-2	S53507001	THREAD HOLDING PLATE, 10-12	1
5	S59032000	GUIDE PLATE	1
6	018300636	BOLT, SOCKET M3X6	2
7	S53512101	SETTING SHAFT	1
8	012500536	SET SCREW, SOCKET (FT) M5X5	2
9	S53513001	CYLINDER BASE	1
10	06262012	SCREW, PAN SM4.37-40X20	2
11	S53514001	ECCENTRIC SHAFT	2
12	048060142	RETAINING RING, EXTERNAL C10	1
13	048060142	RETAINING RING, C6	1
14	012060636	SET SCREW, SOCKET (FT) M6X6	1
15	S53515001	CYLINDER ASSY	1
15-1	S53516000	AIR CYLINDER, 15X20	1
15-2	S16603000	TUBE ELBOW, W/VALVE	2
20	S59155000	CYLINDER ASSY	1
20-1	S59156000	AIR CYLINDER, 12X25	1
20-2	S53488000	JOINT	2
21	S59036001	SETTING BASE	1
22	S59158001	COLLAR	1
23	S53492001	SPRING	1
24	012500536	SET SCREW, SOCKET (FT) M5X5	1
25	018301236	BOLT, SOCKET M3X12	2
2-3	※	"OPTION PARTS"	1
3-3	※	FIXED KNIFE, XX-YY	1
4-3	※	N/THREAD KNIFE ASSY, XX-YY	1
4-3	※	THREAD HOLDING PLATE, XX-YY	1

Page 28

Brother BAS-6150 parts on page 28

Ref	Part number	Part name	Qty
1	1-1	Tension release mechanism
1-2	1-2	Tension release mechanism
1-3	1-3	Tension release mechanism
1	1	Motor mechanism
2	2	Motor mechanism
4	4	Motor mechanism
5	5	Motor mechanism
6	6	Motor mechanism
7	7	Motor mechanism
8	8	Motor mechanism
10	10	Motor mechanism
11	11	Motor mechanism
12	12	Motor mechanism

Page 29 — M.糸締め関係 / Tension release mechanism N. モータ関係 / Motor mechanism

Brother BAS-6150 parts on page 29

Ref	Part number	Part name	Qty
1	S53171000	CYLINDER ASSY	1
1-1	S15097000	CYLINDER, 10X5	1
1-2	S53488000	JOINT	1
1-3	S14677001	TENSION RELEASE SHAFT	1
1	S52493001	MOTOR BRACKET, H	1
2	018063036	BOLT, SOCKET M6X30	3
4	152914001	ROLLER	2
5	S59357001	BOLT, TORX SOCKET M4X20	2
6	100645003	WASHER	2
7	028040246	WASHER, SPRING 2-4	2
8	S53166000	COUPLING, 14X15	1
10	018062536	BOLT, SOCKET M6X25	4
11	028060246	WASHER, SPRING 2-6	4
12	J80869001	MOTOR ASSY, CIM	1

Page 30

Brother BAS-6150 parts on page 30

Ref	Part number	Part name	Qty
	1-1	Lower thread detector mechanism (Option parts)
	1-12	Lower thread detector mechanism (Option parts)
	1-21	Lower thread detector mechanism (Option parts)
	1-22	Lower thread detector mechanism (Option parts)
	1-3	Lower thread detector mechanism (Option parts)
	1-14	Lower thread detector mechanism (Option parts)
	1-9	Lower thread detector mechanism (Option parts)
	1-7	Lower thread detector mechanism (Option parts)
	1-6	Lower thread detector mechanism (Option parts)
	1-2	Lower thread detector mechanism (Option parts)
	1-5	Lower thread detector mechanism (Option parts)
	1-10	Lower thread detector mechanism (Option parts)
	1-13	Lower thread detector mechanism (Option parts)
	1-4	Lower thread detector mechanism (Option parts)
	1-8	Lower thread detector mechanism (Option parts)
	1-20	Lower thread detector mechanism (Option parts)
	1	Lower thread detector mechanism (Option parts)
	1-1	Thread breakage detector mechanism (Option parts)
	1-10	Thread breakage detector mechanism (Option parts)
	1-3	Thread breakage detector mechanism (Option parts)
	1-4	Thread breakage detector mechanism (Option parts)
	1-5	Thread breakage detector mechanism (Option parts)
	1-6	Thread breakage detector mechanism (Option parts)
	1-7	Thread breakage detector mechanism (Option parts)
	1-11	Thread breakage detector mechanism (Option parts)
	1-13	Thread breakage detector mechanism (Option parts)
	1-12	Thread breakage detector mechanism (Option parts)
	1-11	Thread breakage detector mechanism (Option parts)
	1-5	Thread breakage detector mechanism (Option parts)
	1	Thread breakage detector mechanism (Option parts)

Page 32 — Stacker mechanism (Option parts)

Brother BAS-6150 parts on page 32

Ref	Part number	Part name	Qty
	1-59-2	1-59-2
	1-59-1	1-59-1
	1-58	1-58
	1-57	1-57
	1-56	1-56
	1-34	1-34
	1-35	1-35
	1-36	1-36
	1-27	1-27
	1-32	1-32
	1-28	1-28
	1-60	1-60
	1-62	1-62
	1-61	1-61
	1-63	1-63
	1-43	1-43
	1-106	1-106
	1-108	1-108
	1-109	1-109
	1-41	1-41
	1-35	1-35
	1-34	1-34
	1-36	1-36
	1-38	1-38
	1-37	1-37
	1-54	1-54
	1-55	1-55
	1-45	1-45
	1-531-52	1-531-52
	1-48	1-48
	1-53	1-53
	1-49	1-49
	1-50	1-50
	1-33	1-33
	1-34	1-34
	1-36	1-36
	1-29	1-29
	1-31	1-31
	1-30	1-30
	1-111-2	1-111-2
	1-112	1-112
	1-111-4	1-111-4
	1-113	1-113
	1-111-5	1-111-5
	1-118	1-118
	1-111-3	1-111-3
	1-118	1-118
	1-111-1	1-111-1
	1-4	1-4
	1-5	1-5
	1-6	1-6
	1-1	1-1
	1-2	1-2
	1-29	1-29
	1-30	1-30
	1-31	1-31
	1-44-3	1-44-3
	1-44-1	1-44-1
	1-117	1-117
	1-44-2	1-44-2
	1-117	1-117
	1-44-2	1-44-2
	1-65	1-65
	1-64	1-64
	1-86	1-86
	1-85	1-85
	1-84	1-84
	1-83	1-83
	1-82	1-82
	1-81	1-81
	1-87	1-87
	1-80	1-80
	1-88	1-88
	1-109	1-109
	1-107	1-107
	1-108	1-108
	1-105	1-105
	1-110	1-110
	1-99	1-99
	1-101	1-101
	1-103	1-103
	1-102	1-102
	1-100	1-100
	1	1
	1-100	1-100
	1-101	1-101
	1-102	1-102
	1-103	1-103
	1-130	1-130
	1-42	1-42
	1-41	1-41
	101	101
	100	100
	13	13
	12	12

Page 33 — R.スタッカー関係(オプション部品) / Stacker mechanism (Option parts)

Brother BAS-6150 parts on page 33

Ref	Part number	Part name	Qty
	S58179001	バー・スタッカーアッセン	1
	S58180001	スタッカーベース	1
	S54115001	タッププレート	1
	018108036	アナボルト M8X80	4
	028100246	バネザガネ2-10	4
	025100236	ヒラザガネチュウ10	4
	S54123001	コテイプレートL	1
	S54122001	コテイプレートR	1
	018100236	アナボルト M10X20	4
	028100246	バネザガネ2-10	4
	025100236	ヒラザガネチュウ10	4
	S54108001	シャフト L=126	1
	S54117001	フルクラムシャフト	1
	018082036	アナボルト 8X20	3
	028080246	バネザガネ2-8	3
	025080236	ヒラザガネチュウ8	3
	018502036	アナボルト 5X20	1
	028050246	バネザガネ2-5	1
	S54596000	セットカラー	2
	018501622	アナボルト 5X16	2
	S54140001	クランプリンク	1
	S54137000	シリンダーアッシー	1
	S54136000	エアシリンダー 20X100	1
	S53981000	エルボ KQL0601S	2
	S54135000	ナックルジョイント	1
	S54118001	シリンダーホルダー	1
	018063036	アナボルト 6X30	1
	S54126001	エンドプレート	1
	S54127001	シャフト	1
	018081636	アナボルト 8X16	1
	028080246	バネザガネ2-8	1
	S54120001	ワイパーリンク	1
	S54595000	ボールベアリング 6004DDUNR	2
	048200142	リテイニングリングC20	1
	S46191001	スペーサー	1
	S54119001	パイプ	1
	S54106001	ホルダー	2
	018061036	アナボルト 6X10	2
	S59031000	シリンダーアッシー	1
	S54592000	エアシリンダー20X150	1
	S53981000	エルボ KQL0601S	2
	S54594000	ロッドエンド	1
	028080246	バネザガネ2-8	1
	025080236	ヒラザガネチュウ8	1
	021080206	2シュナット8	1
	S58181001	スタッカーテーブル	1
	S58182100	スタッカーゴム	1
	S54130001	コンネクティングリンク B	1
	018083036	アナボルト 8X30	1
	028080246	バネザガネ2-8	1
	025080236	ヒラザガネチュウ8	2
	021080206	2シュナット8	1
	018064036	アナボルト 6X40	1
	028060246	バネザガネ2-6	1
	025060236	ヒラザガネチュウ6	2
	021060206	2シュナット6	1
	S54132001	ガード	1
	S54133001	パイプカラー	2
	018083036	アナボルト 8X30	2
	028080246	バネザガネ2-8	2
	025080236	ヒラザガネチュウ8	2

Page 34 — R.スタッカー関係(オプション部品)/Stacker mechanism (Option parts)

Brother BAS-6150 parts on page 34

Ref	Part number	Part name	Qty
	1-59-2	1-59-2
	1-59-1	1-59-1
	1-58	1-58
	1-57	1-57
	1-56	1-56
	1-34	1-34
	1-35	1-35
	1-36	1-36
	1-60	1-60
	1-43	1-43
	1-27	1-27
	1-32	1-32
	1-28	1-28
	1-62	1-62
	1-61	1-61
	1-63	1-63
	1-109	1-109
	1-45	1-45
	1-33	1-33
	1-34	1-34
	1-35	1-35
	1-36	1-36
	1-54	1-54
	1-55	1-55
	1-531-52	1-531-52
	1-48	1-48
	1-53	1-53
	1-49	1-49
	1-50	1-50
	1-111-2	1-111-2
	1-112	1-112
	1-113	1-113
	1-111-4	1-111-4
	1-111-3	1-111-3
	1-111-5	1-111-5
	1-118	1-118
	1-118	1-118
	1-111-1	1-111-1
	1-111-5	1-111-5
	1-4	1-4
	1-5	1-5
	1-6	1-6
	1-1	1-1
	1-44-3	1-44-3
	1-44-1	1-44-1
	1-117	1-117
	1-44-2	1-44-2
	1-117	1-117
	1-44-2	1-44-2
	1-109	1-109
	1-107	1-107
	1-108	1-108
	1-105	1-105
	1-99	1-99
	1-65	1-65
	1-64	1-64
	1-86	1-86
	1-85	1-85
	1-84	1-84
	1-83	1-83
	1-82	1-82
	1-81	1-81
	1-110	1-110
	1-101	1-101
	1-102	1-102
	1-103	1-103
	1-100	1-100
	1	1
	1-42	1-42
	1-41	1-41
	1-87	1-87
	1-80	1-80
	1-88	1-88
	1-130	1-130
	1-100	1-100
	1-103	1-103
	1-102	1-102
	1-101	1-101
	1-2	1-2
	1-38	1-38
	1-37	1-37
	101	101
	100	100
	13	13
	12	12

Page 35 — R.スタッカー関係(オプション部品) / Stacker mechanism (Option parts)

Brother BAS-6150 parts on page 35

Ref	Part number	Part name	Qty
	S54605000	ククリ	1
	018061236	アナルボルト6X12	1
	018063036	アナルボルト6X30	1
	028060246	バネザガネ2-6	2
	025060236	ヒラザガネチュウ6	2
	021060206	2シュナツト6	1
	S58183000	バルブユニット2	1
	S58184000	マニホールド,2	1
	S39116100	バルブVQZ2151S-5	2
	S59368000	コウキ7KQ2H0801S	1
	140682001	サイレンサ	1
	153274001	CAP, 1/8	2
	0180603036	アナルボルト5X30	1
	028050246	バネザガネ2-5	2
	S54602000	エアホース0604U035B	2
	S59387000	エアホース0604U050B	2
	S04557000	バンダイPLT1M	2
	S52991000	ハンスタッカーハーネスL	1
	S58693000	エアホース0806U175B	1
	S39821000	コードクランプ19P7	1
	S04557000	バンダイPLT1M	2

Page 36 — S. 糸巻関係 / Bobbin winder mechanism

Brother BAS-6150 parts on page 36

Ref	Part number	Part name	Qty
	1-24	1-24
	1-22	1-22
	1-23	1-23
	1-20	1-20
	1-19	1-19
	1-18	1-18
	1-17	1-17
	1-25	1-25
	1-3	1-3
	1-16	1-16
	1-9	1-9
	1-8	1-8
	1-15	1-15
	1-10	1-10
	1-11	1-11
	1-33	1-33
	3	3
	1	1
	5	5
	4	4
	1-6	1-6
	1-7	1-7
	1-5	1-5
	1-4	1-4
	1-29	1-29
	1-21	1-21
	1-1	1-1
	1-30	1-30
	1-27	1-27
	1-28	1-28
	1-2	1-2
	1-14	1-14
	1-13	1-13
	1-12	1-12
	1-31	1-31
	1-32	1-32
	1-26	1-26

Page 37 — S.糸巻関係 / Bobbin winder mechanism

Brother BAS-6150 parts on page 37

Ref	Part number	Part name	Qty
	152651401	BOBBIN WINDER ASSY	1
	152356301	BOBBIN WINDER BASE	1
	S39902001	SUPPORT PLATE, ;B-W/MOTOR	1
	004300513	SCREW, FLAT M3X5	4
	154024001	BOBBIN PRESSER	1
	152645001	BOBBIN HOLDER	1
	062300616	SCREW, PAN M3X6	1
	025030233	WASHER, PLAIN M 3	1
	154092001	BOBBIN WINDER CLAW	1
	014680422	SET SCREW, SOCKET (CP) SM4.37	2
	152361001	LEVER, ;B-WINDER	1
	152620001	SHOULDER SCREW	1
	111942001	SPRING, PLATE	1
	111943001	WASHER	1
	060660512	SCREW, BIND SM3.18-40X5	1
	152363001	SPRING, TWIST A	1
	047301042	SPRING PIN	1
	145571101	GUIDE BRACKET ASSY, ;B-WINDER	1
	145446001	DISC, TENSION	2
	100401001	TENSION SPRING	1
	100135001	NUT, TENSION	1
	146197001	THREAD NIPPER ASSY	1
	028040243	WASHER, SPRING 2-4	1
	025040233	WASHER, PLAIN M 4	2
	062401006	SCREW, PAN M4X10	1
	021400103	NUT, 1 M4	1
	S39847001	MOTOR ASSY, ;B-WINDER	1
	S35032101	SCREW, M2.6X5.5	2
	028260242	WASHER, SPRING 2-2.6	2
	S39901001	SHAFT, ;B-WINDER	1
	014300332	SET SCREW, SOCKET (CP) M3X3	2
	152364001	COLLAR	2
	158597001	STOPPER, ;B-WINDER	1
	032311306	PROTECTOR, 0.5A	5
	S52459000	WOOD SCREW, ROUND M3.1X13	1
	S52460000	BOBBIN WINDER HARNESS	1
	0A5400805	SCREW, PAN (S/P WASHER) M4X8	1

Page 38 — T. 空圧関係 / Air pressure mechanism

Brother BAS-6150 parts on page 38

Ref	Part number	Part name	Qty
	1	Air pressure mechanism
	1-1	Solenoid valve
	1-2	Solenoid valve
	1-3	Manifold
	1-4	Manifold
	1-5	Tube fitting
	1-6	Tube fitting
	1-7	Plug
	2	Air cylinder
	2-1	Air cylinder
	2-2	Air cylinder
	2-3	Air cylinder
	2-4	Air cylinder
	2-5	Air cylinder
	3	Bolt
	4	Washer
	5	Air filter
	5-1	Air filter
	5-2	Pressure regulator
	5-3	Pressure regulator
	5-4	Pressure regulator
	5-5	Pressure regulator
	6	Tube fitting
	9	Option parts
	9-1	Spray gun
	9-2	Hose
	9-3	Hose
	9-4	Hose fitting
	9-5	Hose fitting
	13	Plug
	18	Solenoid valve unit
	20	Tube fitting
	21	Solenoid valve
	22	Solenoid valve
	23	Solenoid valve
	24	Solenoid valve
	25	Tube fitting
	26	Tube fitting
	33	Solenoid valve
	34	Solenoid valve
	35	Solenoid valve
	36	Solenoid valve
	37	Air cylinder
	38	Air cylinder
	39	Tube fitting
	40	Air cylinder
	43	Tube fitting
	45	Tube fitting
	47	Tube fitting
	48	Tube fitting
	49	Tube fitting
	50	Tube fitting
	51	Tube fitting
	52	Tube fitting
	53	Tube fitting
	54	Tube fitting
	55	Tube fitting
	56	Tube fitting
	57	Tube fitting
	70	Clamp
	71	Clamp
	72	Clamp
	73	Clamp
	74	Clamp
	75	Clamp
	76	Clamp
	77	Clamp
	78	Screw
	79	Hose

Page 39 — T.空気関係 / Air pressure mechanism

Brother BAS-6150 parts on page 39

Ref	Part number	Part name	Qty
	S55571001	VALVE UNIT, 10	1
	S39116100	VALVE, VQZ2151S-5	3
	S39115100	VALVE, VQZ2151S-5	3
	S53982000	BLANKING PLATE	1
	S53981000	ELBOW, KQL0601S	1
	S53983000	PLUG, 4	3
	140682001	SILENCER	1
	153274001	CAP, 1/8	2
	S55300101	VALVE UNIT, 7	1
	S39115100	VALVE, VQZ2151S-5	4
	S53982000	BLANKING PLATE ASSY	3
	S59372000	ELBOW, KQL0601S	1
	140682001	SILENCER	1
	153274001	CAP, 1/8	2
	018503036	BOLT, SOCKET MEX30	2
	028050246	WASHER, SPRING 2-5	2
	S56868000	FILTER REGULATOR ASSY	1
	S09231000	BALL VALVE, 1/4	1
	153252000	PT-JOINT	1
	S56869000	PLUMBING MODULE ASSY	1
	S59219000	HALE UNION, ;KQ2H08-02S	1
	S53985000	PLUG, 8	1
	S55484001	SCREW, SOCKET (S/P W) M5X10	2
	S59217000	AIR GUN ASSY	1
	S59218000	AIR GUN	1
	S59219000	HALE UNION, ;KQ2H08-02S	1
	S59220000	AIR TUBE, COIL ;TCU0805B	1
	S12506000	AIR GUN HOOK	1
	008400604	SCREW, TRUSS M4X6	2
	S53985000	PLUG, 8	1
	S39116100	VALVE, VQZ2151S-5	2
	149796001	AIR HOSE, W/CONNECTOR	1
	S53960000	AIR TUBE, 0425U045B1	1
	S53961000	AIR TUBE, 0425U045B2	1
	S53962000	AIR TUBE, 0425U025B	1
	S53963000	AIR TUBE, 0425U026B	1
	S58039000	AIR TUBE, 0425S024B	2
	S58040000	AIR TUBE, 0425S028B	2
	S53958000	AIR TUBE, 0425U050B1	1
	S53959000	AIR TUBE, 0425U050B2	1
	S53964000	AIR TUBE, 0425U032B	1
	S53965000	AIR TUBE, 0425U030B	1
	S58037000	AIR TUBE, 0604U128B	1
	S58038000	AIR TUBE, 0604U146B	1
	S58035000	AIR TUBE, 0604U091B	1
	S58036000	AIR TUBE, 0604U103B	1
	S53952000	AIR TUBE, 0425S115B	1
	S58034000	AIR TUBE, 0425S123B	1
	S55010000	AIR TUBE, 0425S066B	1
	S55010000	AIR TUBE, 0425S070B	1
	S53951000	AIR TUBE, 0425S107B	1

Page 40

Brother BAS-6150 parts on page 40

Ref	Part number	Part name	Qty
	1-1	1-1
	1-2	1-2
	1-3	1-3
	1-5	1-5
	1-6	1-6
	1-7	1-7
	54	54
	50	50
	49	49
	43	43
	47	47
	39	39
	37	37
	45	45
	48	48
	40	40
	38	38
	52	52
	53	53
	55	55
	51	51
	2	2
	2-1	2-1
	2-2	2-2
	2-5	2-5
	2-4	2-4
	2-3	2-3
	3	3
	4	4
	18	18
	26	26
	25	25
	25	25
	26	26
	26	26
	25	25
	35	35
	24	24
	22	22
	33	33
	21	21
	22	22
	34	34
	33	33
	23	23
	21	21
	35	35
	36	36
	23	23
	24	24
	57	57
	56	56
	57	57
	5-1	5-1
	5-2	5-2
	5-3	5-3
	5-4	5-4
	5-5	5-5
	6	6
	20	20
	9-1	9-1
	9-2	9-2
	9-3	9-3
	9-4	9-4
	9-5	9-5
	13	13
	75	75
	76	76
	71	71
	70	70
	74	74
	72	72
	73	73
	77	77
	78	78

Page 41 — T.空圧関係 / Air pressure mechanism

Brother BAS-6150 parts on page 41

Ref	Part number	Part name	Qty
	S55013000	エアホース0424S088B	1
	S53954000	エアホース0425S110B	1
	S53952000	エアホース0425S115B	1
	S54614000	エアホース0425S122B	1
	S54615000	エアホース0425S125B	1
	S54615000	エアホース0425S125B	1
	S53973000	エアホース0604S051B	1
	S54104000	エアホース0604U190B	1
	S52973000	リピートタイRF100	3
	S04557000	バンドPLT1M	1
	149287000	ナイロンクランプ	1
	55290000	コードホルダ #14	1
	552581000	コードホルダ 24	1
	0A5401005	ナベザクルミ4X10DB	3
	S39821000	コードクランプ 19P7	2
	S10859001	クランプ	3
	002300603	ナベコ 3X6	3
	S55303000	スパイラル80S	1

Page 42 — U. 電装品関係 / Power supply equipment mechanism

Brother BAS-6150 parts on page 42

Ref	Part number	Part name	Qty
	1	TRANSFORMER
	2	BOLT
	5	BRACKET
	7	BRACKET
	8	TERMINAL BLOCK
	9	TERMINAL BLOCK
	10	TERMINAL BLOCK
	11	TERMINAL BLOCK
	12	BRACKET
	13	TERMINAL BLOCK
	14	BRACKET
	15	BOLT
	16	TERMINAL BLOCK
	17	SWITCH
	18	TERMINAL BLOCK
	19	TERMINAL BLOCK
	20	BRACKET
	21	BRACKET
	23	BOLT
	24	BRACKET
	25	TERMINAL BLOCK
	26	TERMINAL BLOCK
	27	TERMINAL BLOCK
	28	TERMINAL BLOCK
	29	BRACKET
	30	BOLT
	31	WASHER
	32	PLUG
	33	TERMINAL BLOCK
	34	TERMINAL BLOCK
	35	CABLE
	36	TERMINAL BLOCK
	37	TERMINAL BLOCK
	38	RING
	39	BOLT
	40	CABLE
	41	CABLE
	42	BOLT
	43	HARNESS
	44	CONNECTOR
	45	BRACKET
	46	BRACKET
	47	MOTOR
	48	CAPACITOR
	70	TERMINAL BLOCK
	71	CLAMP
	72	BOLT
	73	BOLT
	74	TERMINAL BLOCK
	75	CONNECTOR
	76	BRACKET
	5-1	POWER SUPPLY UNIT
	5-2	POWER SUPPLY UNIT
	7-1	SWITCH
	7-2	SWITCH

Page 43 — U.電装部品関係 / Power supply equipment mechanism

Brother BAS-6150 parts on page 43

Ref	Part number	Part name	Qty
	S52760000	トランス	1
	S55476001	アサボルトザクミ6X12	4
	S52472001	<3相200V, 220V, 380V, 400V, 415V用> デンゲンSW3Pクミ	1
	S52968001	<単相220V用> デンゲンSW2Pクミ	1
	0A5400805	+ナベザクミ4X8DB	2
	S47900000	<200V, 220V用> ブレーカーM10A	1
	S52437000	<380V, 400V, 415V用> ブレーカーM5A	1
	S52727000	タンシカパー	1
	S52475000	ブレーカーNFハーネス	1
	S40620000	セツテイングプレート	1
	0A5400805	+ナベザクミ4X8DB	2
	S40616001	ノイズフィルタEMCクミ	1
	0A5400805	+ナベザクミ4X8DB	2
	S52478000	グラウンドワイヤPE	1
	0A5400805	+ナベザクミ4X8DB	1
	S52476000	NF-Tハーネス	1
	S52439000	AVRハーネス	1
	S52440000	T-PハーネスA	1
	S52441000	T-PハーネスB	1
	S46738000	スイツチングデンゲン	1
	0A5300805	+ナベザクミ3X8DB	2
	S00554000	サポート6NS	7
	S38110000	サポート6S	2
	S52443000	メインパワーハーネス	1
	S52444000	インバーターハーネス	1
	S52457000	フットSWハーネス	1
	0A5400805	+ナベザクミ4X8DB	1
	S52952001	サーボアンプ62Xクミ	1
	018061436	アナホルト6X14	2
	028060246	ワッシャー、スプリング2-6	2
	S52442000	サーボパワーハーネス	1
	S52445000	サーボハーネス	1
	S52447000	エンコーダーハーネス	1
	S52448000	モータパワーハーネス	1
	S52446000	ミシンモーターパワーハーネス	1
	0A5401005	+ナベザクミ4X10DB	1
	S52908000	コードホルダ #14	1
	0A5401005	+ナベザクミ4X10DB	1
	S52732000	アースセン1600	1
	S52733000	アースセン1600	2
	0A5400805	+ナベザクミ4X8DB	4
	S52450000	メインバルブハーネス	1
	S12463001	センサPCBアッシー1	2
	0A4300605	+ナベザクミ3X6DA	2
	S52449000	M/センサーハーネス	1
	S52744000	スイッチA222E-M-11	1
	S52461000	EMSWハーネス	1
	S00480000	コードホルダ #5	2
	552907000	コードホルダ #10	1
	0A5401005	+ナベザクミ4X10DB	3

Page 44 — U. 電装品関係 / Power supply equipment mechanism

Brother BAS-6150 parts on page 44

Ref	Part number	Part name	Qty
	1	TRANSFORMER
	2	SCREW
	5	BRACKET
	6	TERMINAL
	7	BRACKET
	8	TERMINAL
	9	TERMINAL
	10	TERMINAL
	11	TERMINAL
	12	BRACKET
	13	TERMINAL
	14	TERMINAL
	15	TERMINAL
	16	TERMINAL
	17	SCREW
	18	TERMINAL
	19	TERMINAL
	20	BRACKET
	21	TERMINAL
	23	TERMINAL
	24	TERMINAL
	25	TERMINAL
	26	TERMINAL
	27	TERMINAL
	28	TERMINAL
	29	BRACKET
	30	SCREW
	31	WASHER
	32	TERMINAL
	33	TERMINAL
	34	TERMINAL
	35	TERMINAL
	36	TERMINAL
	37	TERMINAL
	38	BRACKET
	39	SCREW
	40	TERMINAL
	41	TERMINAL
	42	TERMINAL
	43	TERMINAL
	44	TERMINAL
	45	TERMINAL
	46	TERMINAL
	47	MOTOR
	48	TERMINAL
	70	TERMINAL
	71	BRACKET
	72	SCREW
	73	TERMINAL
	74	TERMINAL
	75	TERMINAL
	76	TERMINAL
	5-1	POWER SUPPLY UNIT
	5-2	POWER SUPPLY UNIT
	7-1	SWITCH
	7-2	SWITCH

Page 45 — U.電装部品関係 / Power supply equipment mechanism

Brother BAS-6150 parts on page 45

Ref	Part number	Part name	Qty
	149287000	ナイロンクランプ	1
	S09141000	コードクランプ 16L	6
	S09142000	コードクランプ 20L	1
	S31760000	CKSクランプ 26L	4

Page 46 — V1. 布制御関係 / Cloth control system mechanism

Brother BAS-6150 parts on page 46

Ref	Part number	Part name	Qty
	1-2-22-3	1-2-22-3
	1-2-22-1	1-2-22-1
	1-2-22	1-2-22
	1-2-13	1-2-13
	1-2-14	1-2-14
	1-2-15	1-2-15
	1-2-16	1-2-16
	1-2-19	1-2-19
	1-2-12	1-2-12
	1-2-23	1-2-23
	1-2-20	1-2-20
	1-2-24	1-2-24
	1-2-21	1-2-21
	1-2-26	1-2-26
	1-2-27	1-2-27
	1-2-4	1-2-4
	1-2-10	1-2-10
	1-2-8	1-2-8
	1-2-9	1-2-9
	1-2-11	1-2-11
	1-2-18	1-2-18
	1-2-17	1-2-17
	1-2-30	1-2-30
	1-2-29	1-2-29
	1-2-31	1-2-31
	1-2-34	1-2-34
	1-2-35	1-2-35
	1-2-33-1	1-2-33-1
	1-2-33	1-2-33
	1-2-32	1-2-32
	1-2-2	1-2-2
	1-2-3	1-2-3
	1-2-1	1-2-1
	2-6	2-6
	1-1-24	1-1-24
	1-1-27	1-1-27
	1-1-26	1-1-26
	1-1-29	1-1-29
	1-1-30	1-1-30
	1-1-11	1-1-11
	1-1-16	1-1-16
	1-1-15	1-1-15
	1-1-12	1-1-12
	1-1-14	1-1-14
	1-1-13	1-1-13
	1-1-19	1-1-19
	1-1-21	1-1-21
	1-1-23	1-1-23
	1-1-28	1-1-28
	1-1-18	1-1-18
	1-1-17	1-1-17
	1-1-33	1-1-33
	1-1-33-1	1-1-33-1
	1-1-35	1-1-35
	1-1-34	1-1-34
	2-1~2-5	2-1~2-5
	1-1-10	1-1-10
	1-1-8	1-1-8
	1-1-9	1-1-9
	1-1-2	1-1-2
	1-1-1	1-1-1
	1-1-3	1-1-3
	1-1-5	1-1-5
	1-1-6	1-1-6
	1-1-7	1-1-7
	1-1-4	1-1-4
	1-1-32	1-1-32
	1	1

Page 47 — V1.布制御関係 / Cloth control system mechanism

Brother BAS-6150 parts on page 47

Ref	Part number	Part name	Qty
1	S53531000	CARRIAGE FEED ASSY, 220	1
1-1	S53532001	CARRIAGE FEED ASSY, R-220	1
1-1-1	S53558001	CARRIAGE FEED LEVER ASSY, R	1
1-1-2	S53564001	COUPLING	1
1-1-3	012060636	SET SCREW, SOCKET (FT) M6X6	1
1-1-4	S53533001	SETTING LEVER, R	1
1-1-5	018062036	BOLT, SOCKET M6X20	2
1-1-6	028060246	WASHER, SPRING 2-6	2
1-1-7	025060236	WASHER, PLAIN M 6	2
1-1-8	S53534100	CARRIAGE FEED SPRING	1
1-1-9	008400604	SCREW, TRUSS M4X6	2
1-1-10	S53535001	SHOULDER SCREW, SM6.35	1
1-1-11	S53536001	CARRIAGE FEED, R	1
1-1-12	S53537001	SUPPORT BRACKET	1
1-1-13	018501236	BOLT, SOCKET M5X12	2
1-1-14	028050246	WASHER, SPRING 2-5	2
1-1-15	S53538101	STOPPER & POSITIONING PLATE	1
1-1-16	060400812	SCREW, BIND M4X8	2
1-1-17	S53539001	COLLAR	1
1-1-18	S58204001	SCREW, COLLAR PRESS	1
1-1-19	S53540001	CYLINDER BASE	1
1-1-20	115503001	SCREW, SM4.37	1
1-1-21	018501036	BOLT, SOCKET M5X10	1
1-1-22	S53541000	CYLINDER ASSY	1
1-1-22-1	S14666000	CYLINDER, 16X20	1
1-1-22-2	S12150000	TUBE ELBOW, M-5HL-4	1
1-1-22-3	S11433000	HOSE NIPPLE, 4M5	1
1-1-23	S53543001	JOINT	1
1-1-24	S53544001	PIN, 002	1
1-1-25	048025342	RETAINING RING, E2.5	1
1-1-26	S53545001	LINK LEVER	1
1-1-27	002300603	SCREW, PAN M3X6	1
1-1-28	S53546001	LINK SHAFT	1
1-1-29	S53547001	HOLDER PLATE	4
1-1-30	S31258001	SCREW, FLAT M4X6	4
1-1-31	S53548000	SPRING HOLDER PLATE ASSY	4
1-1-32	008300604	SCREW, TRUSS M3X6	4
1-1-33	S55454001	FOLDING PLATE ASSY, R	1
1-1-33-1	S57533000	REFLECTING SHEET	1
1-1-34	S53552000	SPRING, PLATE	2
1-1-35	S53553000	SPRING, PLATE	2
1-2	S53554001	CARRIAGE FEED ASSY, L-220	1
1-2-1	S53562001	CARRIAGE FEED LEVER ASSY, L	1
1-2-2	S53564001	COUPLING	1
1-2-3	012060636	SET SCREW, SOCKET (FT) M6X6	1
1-2-4	S53555001	SETTING LEVER, L	1
1-2-5	018062036	BOLT, SOCKET M6X20	2
1-2-6	028060246	WASHER, SPRING 2-6	2
1-2-7	025060236	WASHER, PLAIN M 6	2
1-2-8	S53534100	CARRIAGE FEED SPRING	1
1-2-9	008400604	SCREW, TRUSS M4X6	2
1-2-10	S53535001	SHOULDER SCREW, SM6.35	1
1-2-11	S53536001	CARRIAGE FEED, L	1
1-2-12	S53537001	SUPPORT BRACKET	1
1-2-13	018501236	BOLT, SOCKET M5X12	2
1-2-14	028050246	WASHER, SPRING 2-5	2
1-2-15	S53538101	STOPPER & POSITIONING PLATE	1
1-2-16	060400812	SCREW, BIND M4X8	2
1-2-17	S53539001	COLLAR	1
1-2-18	S58204001	SCREW, COLLAR PRESS	1
1-19	S53540001	CYLINDER BASE	1

Page 48

Brother BAS-6150 parts on page 48

Ref	Part number	Part name	Qty
	1-2-22-3	1-2-22-3
	1-2-22-1	1-2-22-1
	1-2-22	1-2-22
	1-2-22-2	1-2-22-2
	1-2-13	1-2-13
	1-2-14	1-2-14
	1-2-12	1-2-12
	1-2-19	1-2-19
	1-2-15	1-2-15
	1-2-16	1-2-16
	1-2-21	1-2-21
	1-2-24	1-2-24
	1-2-4	1-2-4
	1-2-10	1-2-10
	1-2-8	1-2-8
	1-2-9	1-2-9
	1-2-30	1-2-30
	1-2-29	1-2-29
	1-2-17	1-2-17
	1-2-18	1-2-18
	2-6	2-6
	3	3
	1-2-11	1-2-11
	1-2-33	1-2-33
	1-2-33-1	1-2-33-1
	1-2-32	1-2-32
	1-2-2	1-2-2
	1-2-3	1-2-3
	1-2-1	1-2-1
	1-2-5	1-2-5
	1-2-6	1-2-6
	1-2-7	1-2-7
	1-2-23	1-2-23
	1-2-20	1-2-20
	1-1-24	1-1-24
	1-1-27	1-1-27
	1-1-26	1-1-26
	1-1-28	1-1-28
	1-1-29	1-1-29
	1-1-30	1-1-30
	1-1-11	1-1-11
	1-1-18	1-1-18
	1-1-17	1-1-17
	1-1-15	1-1-15
	1-1-12	1-1-12
	1-1-13	1-1-13
	1-1-14	1-1-14
	1-1-23	1-1-23
	1-1-21	1-1-21
	1-1-19	1-1-19
	1-1-20	1-1-20
	1-1-16	1-1-16
	1-1-22	1-1-22
	1-1-22-1	1-1-22-1
	1-1-22-2	1-1-22-2
	1-1-22-3	1-1-22-3
	1-1-1	1-1-1
	1-1-2	1-1-2
	1-1-3	1-1-3
	1-1-4	1-1-4
	1-1-8	1-1-8
	1-1-9	1-1-9
	1-1-10	1-1-10
	1-1-5	1-1-5
	1-1-6	1-1-6
	1-1-7	1-1-7
	1-1-32	1-1-32
	1-1-33	1-1-33
	1-1-33-1	1-1-33-1
	1-1-31	1-1-31
	1-1-34	1-1-34
	1-1-35	1-1-35
	2-1~2-5	2-1~2-5
	1-2-31	1-2-31
	1-2-34	1-2-34
	1-2-35	1-2-35

Page 49 — V1.布制御関係 / Cloth control system mechanism

Brother BAS-6150 parts on page 49

Ref	Part number	Part name	Qty
	115503001	SCREW, SM4.37	1
	018501036	BOLT, SOCKET M5X10	1
	S3541000	CYLINDER ASSY	1
	S14666000	CYLINDER, 16X20	1
	S12150000	TUBE ELBOW, M-5HL-4	1
	S11433000	HOSE NIPPLE, 4M5	1
	S3543001	JOINT	1
	S3544001	PIN, 002	1
	048025342	RETAINING RING, E2.5	1
	S3545001	LINK LEVER	1
	002300603	SCREW, PAN M3X6	1
	S3546001	LINK SHAFT	1
	S3547001	HOLDER PLATE	4
	S31258001	SCREW, FLAT M4X6	4
	S35480000	SPRING HOLDER PLATE ASSY	2
	008300604	SCREW, TRUSS M3X6	4
	S5455001	FOLDING PLATE ASSY, L	1
	S5753000	REFLECTING SHEET	1
	S3552000	SPRING, PLATE	2
	S3553000	SPRING, PLATE	2
	S56006000	CARRIAGE FEED RUBBER ASSY, A	2
	S56007000	CARRIAGE FEED RUBBER ASSY, B	2
	S56008000	CARRIAGE FEED RUBBER ASSY, 1.5	2
	S56009000	CARRIAGE FEED RUBBER ASSY, 2	2
	S56010000	CARRIAGE FEED RUBBER ASSY3	2
	S58903000	CARRIAGE FEED RUBBER ASSY, C	2
	S58900006	SCREW, M2	6

Page 50 — V2. 布制御関係(オプション部品)/ Cloth control system mechanism (Option parts)

Brother BAS-6150 parts on page 50

Ref	Part number	Part name	Qty
	50-1	50-1
	50-2	50-2
	50-3	50-3
	50-4	50-4
	50-5	50-5
	50-6	50-6
	50-7	50-7
	50-8	50-8
	50-9	50-9
	50-10	50-10
	50-10-1	50-10-1
	50-10-2	50-10-2
	50-10-3	50-10-3
	50-11	50-11
	50-12	50-12
	50-13	50-13
	50-14	50-14
	50-15	50-15
	50-16	50-16
	50-17	50-17
	50-19	50-19
	50-20	50-20
	50-21	50-21
	50-22	50-22
	50-23	50-23
	51-1	51-1
	51-2	51-2
	51-3	51-3
	51-4	51-4
	51-5	51-5
	51-6	51-6
	51-7	51-7
	51-8	51-8
	51-9	51-9
	51-10-1	51-10-1
	51-10-2	51-10-2
	51-11	51-11
	51-12	51-12
	51-13	51-13
	51-14	51-14
	51-15	51-15
	51-16	51-16
	51-17	51-17
	51-18	51-18
	51-19	51-19
	51-20	51-20
	51-21	51-21
	51-22	51-22
	51-23	51-23
	51-24	51-24
	100	100
	101	101
	102	102
	103	103
	104	104
	105	105
	106	106
	107	107
	108	108
	109	109
	110	110
	111	111
	120	120
	121	121
	122	122

Page 51 — V2.布制御関係(オプション部品)/ Cloth control system mechanism (Option parts)

Brother BAS-6150 parts on page 51

Ref	Part number	Part name	Qty
	S3565000	FLAP CLAMP ASSY, R	1
	S3566000	AUXILIARY PLATE	1
	008400604	SCREW, TRUSS M4X6	5
	S3567001	FULCRUM SHAFT	1
	S3568001	NUT PLATE, M5	1
	004501606	SCREW, FLAT M5X16	2
	S3569001	FLAP CLAMP, R	1
	S3540001	CYLINDER BASE	1
	115503001	SCREW, SM4.37	1
	018501036	BOLT, SOCKET M5X10	1
	S3541000	CYLINDER ASSY	1
	S14666000	CYLINDER, 16X20	1
	S12150000	TUBE ELBOW, M-5HL-4	1
	S3542000	JOINT, W/SCREW M5	1
	S3571001	JOINT	1
	S3572001	SHOULDER SCREW, M5	1
	021500216	NUT, 2 M5	1
	S3573001	FLAP CLAMP BLADE, A	1
	S3574000	FLAP CLAMP BLADE, B	1
	S3575001	FLAP CLAMP BLADE, C	1
	S3598000	SPONGE, 258X8X3	1
	008300604	SCREW, TRUSS M3X6	4
	S3576001	STUD, 8 W/SCREW M5	2
	021500216	NUT, 2 M5	2
	S3577000	FLAP GAUGE ASSY	1
	S3580001	FLAP STOPPER	2
	002300603	SCREW, PAN M3X6	2
	S3581000	FLAP CLAMP ASSY, L	1
	S3566000	AUXILIARY PLATE	1
	008400604	SCREW, TRUSS M4X6	5
	S3567001	FULCRUM SHAFT	1
	S3568001	NUT PLATE, M5	1
	004501606	SCREW, FLAT M5X16	2
	S3582001	FLAP CLAMP, L	1
	S3540001	CYLINDER BASE	1
	115503001	SCREW, SM4.37	1
	018501036	BOLT, SOCKET M5X10	1
	S3541000	CYLINDER ASSY	1
	S14666000	CYLINDER, 16X20	1
	S12150000	TUBE ELBOW, M-5HL-4	1
	S3542000	JOINT, W/SCREW M5	1
	S3571001	JOINT	1
	S3572001	SHOULDER SCREW, M5	1
	021500216	NUT, 2 M5	1
	S3573001	FLAP CLAMP BLADE, A	1
	S3574000	FLAP CLAMP BLADE, B	1
	S3575001	FLAP CLAMP BLADE, C	1
	S3598000	SPONGE, 258X8X3	1
	008300604	SCREW, TRUSS M3X6	4
	S3576001	STUD, 8 W/SCREW M5	2
	021500216	NUT, 2 M5	2
	S3577000	FLAP GAUGE ASSY	1
	S3580001	FLAP STOPPER	2
	002300603	SCREW, PAN M3X6	2
	S2454000	FLAP SENSOR	1
	S2961000	FIBER, FD-G4	2
	S2962000	SIDE LENS	2
	S2965001	DIN RAIL, 75	1
	008400604	SCREW, TRUSS M4X6	2
	S3588000	SPIRAL, 720SS	2
	002300603	SCREW, PAN M3X6	4

Page 52 — V2. 布制制御関係 (オプション部品) / Cloth control system mechanism (Option parts)

Brother BAS-6150 parts on page 52

Ref	Part number	Part name	Qty
	50-1	50-1
	50-2	50-2
	50-3	50-3
	50-4	50-4
	50-5	50-5
	50-6	50-6
	50-7	50-7
	50-8	50-8
	50-9	50-9
	50-10	50-10
	50-10-1	50-10-1
	50-10-2	50-10-2
	50-10-3	50-10-3
	50-11	50-11
	50-12	50-12
	50-13	50-13
	50-14	50-14
	50-15	50-15
	50-16	50-16
	50-17	50-17
	50-18	50-18
	50-19	50-19
	50-20	50-20
	50-21	50-21
	50-22	50-22
	50-23	50-23
	51-1	51-1
	51-2	51-2
	51-5	51-5
	51-6	51-6
	51-7	51-7
	51-8	51-8
	51-9	51-9
	51-10	51-10
	51-10-1	51-10-1
	51-10-2	51-10-2
	51-11	51-11
	51-12	51-12
	51-13	51-13
	51-14	51-14
	51-15	51-15
	51-16	51-16
	51-17	51-17
	51-18	51-18
	51-19	51-19
	51-20	51-20
	51-21	51-21
	51-22	51-22
	51-23	51-23
	51-24	51-24
	100	100
	101	101
	102	102
	103	103
	104	104
	105	105
	106101	106101
	107	107
	108106	108106
	109	109
	110	110
	111	111
	120	120
	121	121
	122	122

Page 53 — V2. 布制御関係(オプション部品) / Cloth control system mechanism (Option parts)

Brother BAS-6150 parts on page 53

Ref	Part number	Part name	Qty
	S53583000	センサーホルダ R	1
	S53584000	センサーホルダ L	1
	S53585001	センサーガイド	2
	018300636	ア+ナホルト3X6	2
	S53586001	センサー スタッド	2
	S10243000	ナイロンクランプ NK-3N	1
	149287000	ナイロンクランプ	1
	0A5400805	+ナベザクミ4X8DB	2

Page 54

Brother BAS-6150 parts on page 54

Ref	Part number	Part name	Qty
	1	PRINTED CIRCUIT BOARD MECHANISM
	2	FAN MOTOR
	3	SCREW
	4	WASHER
	5	CONNECTOR
	6	CONNECTOR
	7	CONNECTOR
	8	PRINTED CIRCUIT BOARD
	8-1	TERMINAL
	8-2	TERMINAL
	8-3	TERMINAL
	8-4	TERMINAL
	8-5	TERMINAL
	8-6	TERMINAL
	8-7	TERMINAL
	9	SCREW
	10	SCREW
	1	MARKER MECHANISM
	1-1	MARKER UNIT
	1-2	MARKER UNIT
	2	BRACKET
	3	SCREW
	4	WASHER
	5	SCREW
	6	WASHER
	7	BRACKET
	10	HARNESS
	11	CLAMP

Page 55 — W.プリント基板関係 / Printed circuit board mechanism X.マーカー関係 / Marker mechanism

Brother BAS-6150 parts on page 55

Ref	Part number	Part name	Qty
	S53000001	メインキバンクミ	1
	S52963000	ファンKD2404	1
	062302506	ナベコ3X25	2
	028030242	バネザガネ2-3	2
	S52750000	PROM620メイン	1
	S52750000	PROM620ホウセイ	1
	S52751000	PROM620モータ	1
	S53007001	デンケンキバンクミ	1
	152566000	ヒューズ C ;2A	1
	152565000	ヒューズ B ;5A	2
	S52741000	GFUSE6A125V	1
	S08030000	ヒューズ 5AFB	1
	153242000	ヒューズ 6A	2
	S30229000	ヒューズホルダ F219P	14
	J02727001	カンヒューズ 2A250V	1
	0A5400805	ナベザガネ4X8DB	5
	0A5401205	ナベザガネ4X12DB	1
	S52989000	マーカー1クミ	2
	S52465000	マーカー-1	2
	S57942000	マーキングホルダ	2
	018400836	アナボルト4X8	2
	025040236	ヒラザガネネチユウ4	2
	S57620001	マーカーベースプレート	1
	018501236	アナボルト5X12	2
	028050246	バネザガネ2-5	2
	S40494000	SWキャップ	1
	S52985000	ライトマーカーハーネスL	1
	S04557000	バンタイPLT1M	1

Page 56 — AA. pedal mechanism / Foot switch pedal mechanism Y. Operation panel mechanism

Brother BAS-6150 parts on page 56

Ref	Part number	Part name	Qty
1-1	1-1	OPERATION PANEL
1-2	1-2	BASE
1-3	1-3	BRACKET
1-4	1-4	BRACKET
1-5	1-5	FOOT SWITCH PEDAL MECHANISM
1-5-1	1-5-1	COVER
1-5-2	1-5-2	SWITCH
1-6	1-6	CORD
1-7	1-7	CIRCUIT BOARD
1-8	1-8	COVER
1-9	1-9	SCREW
1-10	1-10	BRACKET
1-11	1-11	SCREW
1-12	1-12	WASHER
1-13	1-13	SPRING
1-14	1-14	SHAFT
1-15	1-15	SPRING
1-16	1-16	SCREW
1-17	1-17	SCREW
1-18	1-18	CONNECTOR
1-19	1-19	PLUG
1-20	1-20	WASHER
2	2	CONNECTOR
3	3	SCREW
8	8	CORD

Page 57 — Y.操作パネル関係 / Operation panel mechanism AA.踏板関係 / Foot switch pedal mechanism

Brother BAS-6150 parts on page 57

Ref	Part number	Part name	Qty
	S52975001	OPERATION PANEL ASSY, 615	1
	S52976000	FRONT FRAME ASSY	1
	S49491000	FRONT FRAME	1
	S52977000	PANEL SHEET	1
	S52978000	PANEL SHEET BACK PLATE	1
	S52979000	REAR FRAME	1
	S49495000	PANEL SIDE COVER	1
	S49496001	COVR GUIDE, ;SIDE	1
	S52092000	RUBBER SHEET	1
	S53010001	PANEL PCB ASSY	1
	087310815	TAPTITE, CUP B M3X8	2
	087311015	TAPTITE, CUP B M3X10	2
	XA2200500	BOARD PRESSER	2
	0A4400805	SCREW, PAN (S/P WASHER) M4X8	1
	018300636	BOLT, SOCKET M3X6	4
	S52980000	PANEL PROM 6150	1
	032422505	WOOD SCREW, ROUND M4.1X25	4
	S52458000	PANEL HARNESS	1
	S52960001	3-PEDAL FOOT SWITCH	1
	S38166000	FOOT PEDAL BASE	3
	S42867001	TREADLE AUXILIARY PLATE	1
	004400603	SCREW, FLAT M4X6	6
	S38170001	SPRING, COMPRESSION	3
	S52959000	3-PEDAL FOOT SW HARNESS ASSY	1
	S44807000	3-PEDAL FOOT SW HARNESS	1
	S36260000	MICRO SWITCH, VX ;PIN BUTTON	3
	062301205	SCREW, PAN M3X12	6
	228475000	FASTENING BAND, 1.9X80	10
	S38174000	FOOT PEDAL	3
	S38175001	PROTECTION PLATE, ;PEDAL	3
	S38176101	SPRING, PLATE	3
	002300403	SCREW, PAN M3X4	6
	028030246	WASHER, PLAIN M3	6
	025030236	WASHER, PLAIN M3	6
	S38177001	SHAFT, ;F-PEDAL	3
	048050346	STOP RING	3
	052400606	SCREW, PAN (S/P WASHER) M4X6	3
	117936001	RUBBER CAP, 9.4	14
	S52957000	CONNECTOR, 172172-1	1
	S52958000	CONNECTOR COVER, 527163	1
	S38059000	RUBBER CAP, ;NG79F	3

Page 59 — AB.動力台関係 / Power table

Brother BAS-6150 parts on page 59

Ref	Part number	Part name	Qty
	S40884000	CASTER W/STOPPER, 100	4
	S53624001	FULCRUM SHAFT, H	1
	017082016	BOLT, M8X20	2
	028080246	WASHER, SPRING 2-8	2
	025080236	WASHER, PLAIN M 8	2
	S53625001	SET SCREW COLLAR	1
	012060636	SET SCREW, SOCKET (FT) M6X6	2
	S53626001	SPACER, 24	1
	S57538001	SUPPORT PLATE, A	1
	S57539001	SUPPORT PLATE, B	1
	S42446001	BOLT, SOCKET (S/P WASHER)M6X14	4
	S53633001	SUPPORT SHAFT, F	1
	S53635001	SHAFT W/SCREW	1
	S53635001	SHAFT STOPEER	1
	021080206	NUT, M8	1
	025080336	WASHER, PLAIN L 8	1
	S42619001	SET SCREW COLLAR	1
	012400436	SET SCREW, SOCKET (FT) M4X4	4
	153568001	SPRING, A ;COMPRESSION	1
	018401236	BOLT, SOCKET M4X12	1
	S53636001	SPRING HOLDER, A	1
	S53637001	SPRING HOLDER, B	2
	004401003	SCREW, FLAT M4X10	2
	S53627101	TABLE	1
	018102036	BOLT, SOCKET M10X20	2
	025100246	WASHER, PLAIN L 10	2
	028100246	WASHER, SPRING 2-10	2
	S53628001	CONNECTING SHAFT	1
	018103036	BOLT, SOCKET M10X30	1
	028100246	WASHER, SPRING 2-10	1
	025100236	WASHER, PLAIN L 10	1
	S07356001	SET SCREW, (FT) SM6.35-28X17	1
	S53629000	RUBBER LEG	2
	S55485001	SCREW, SOCKET (S/P W) M5X12	2
	S10661109	RUBBER	4
	S03999009	BEAM CAP	3
	S54248000	SUPPORT METAL FITTINGS	1
	S42466001	BOLT, SOCKET (S/P WASHER) M6X1 4	2
	144526001	HOOK	2
	144526001	SHOULDER SCREW, SM4.37	2
	151951001	SPRING, EXTENSION	1
	S53640001	SPRING HOOK	1
	S17971000	SHOCK ABSORBER, GAS	1
	S49638001	LINK SHAFT, D	2
	107153002	WASHER	4
	S37968001	SNAP PIN, 8	4
	S53643001	SUPPORT BASE, D	1
	018500836	BOLT, SOCKET M5X8	2
	S53644001	LEVER, A	1
	S53645001	LEVER, B	1
	159027001	PRESSER ROLLER	3
	017061616	BOLT, M6X16	3
	028060246	WASHER, SPRING 2-6	3
	S53646000	BED SUPPORT	4
	S53647000	CUSHION	4
	S53648001	CUSHIN COLLAR	4
	018063036	BOLT, SOCKET M6X30	4
	028060246	WASHER, SPRING 2-6	4
	154886001	WASHER	4
	S53649001	POSITIONING PLATE	2
	018401636	BOLT, SOCKET M4X16	4

Page 60

Brother BAS-6150 parts on page 60

Ref	Part number	Part name	Qty
	028040246	WASHER, SPRING 2-4	4
	S536500001	CORNRER KNIFE TABLE ASSY	1
	S53651001	CORNRER KNIFE TABLE	1
	118550001	PIN, DOWEL	2
	012081636	SET SCREW, SOCKET (FT) M8X16	4
	S53652001	TABLE SPACER, W/SCREW	3
	021080306	NUT, 3 M8	3
	S53653000	AUXILIARY TABLE, R	1
	S53650001	SET SCREW, M8X16	1
	008400604	SCREW, TRUSS M4X6	3
	S53654001	BRACKET, A	1
	S53655001	BRACKET, B	1
	S55485001	SCREW, SOCKET (S/P W) M5X12	8
	S53656000	AUXILIARY TABLE	1
	008400604	SCREW, TRUSS M4X6	4
	S53659000	SLIDE PLATE, C	1
	008400604	SCREW, TRUSS M4X6	2
	S53660000	TABLE, L	1
	017083016	BOLT, M8X30	3
	028080246	WASHER, SPRING 2-8	3
	025080236	WASHER, PLAIN M8	3
	S53661000	TABLE, R	1
	S55486001	SCREW, SOCKET (S/P W) M5X14	4
	S02738009	ACCESSORY CASE	1
	S02740000	FELT	1
	S02739000	RUBBER MAGNET TAPE	1
	039411215	TAPPING SCREW, TRUSS 1 M4X12	2
	S38820000	BUSHING, 35	3
	S46583000	BUSHING, TB-2533	1
	S52970000	BUSHING, TB-1116	1
	S55310001	HOLE PLUGE, 35	1
	S55310001	BREAKER COVER	1
	008400604	SCREW, TRUSS M4X6	2
	S53671000	HOLDEING BRACKET	1
	018082036	BOLT, SOCKET M8X20	2
	S53672000	CURVED BAR	1
	S53673000	FIXING BLOCK	2
	018501436	BOLT, SOCKET M5X14	2
	S53674000	CLOTH SUPPORTER	1
	004401003	SCREW, FLAT M4X10	4
	S54117001	FULCRUM SHAFT	1
	018501022	BOLT, SOCKET M5X10	1
	159150000	RUBBER CAP, 20.5	2
	S53675001	BOX COVER	1
	008400604	SCREW, TRUSS M4X6	8
	S53676001	ARM COVER	1
	008400604	SCREW, TRUSS M4X6	4
	S55308001	SWITCH COVER	1
	0A5401006	SCREW, PAN (S/P WASHER) M4X10	2
	S53691001	OIL FENCE	1
	105173004	SCREW, SM4.76	2
	S53670001	OIL PAN ASSY, BAS	1
	S53678001	OIL PAN, BAS	1
	153230101	DRAIN	1
	062670512	SCREW, PAN SM3.57-40X5	2
	S53679000	CATCH CLIP	1
	S53680000	HINGE	1
	S53681000	BAND, 252X20X0.5	1

Page 61 — AB.動力台関係 / Power table

Brother BAS-6150 parts on page 61

Ref	Part number	Part name	Qty
	S53682001	ナットA	1
	S53683001	ナットB	1
	018300836	アナボルト3X8	2
	018300636	アナボルト3X6	6
	133172003	アブ・ラサシ・イ	1
	008400604	+トラスコ4X6	1
	S53684001	BAS620モータカバー	1
	S55479001	アナボルトサクミ4X8	2
	S41964000	ブッシュ	1
	008400604	+トラスコ4X6	3
	S53689001	クサリクミ	3
	018300636	アナボルト3X6	2
	S53690001	フッククケ	3
	062400805	ハネザガネ2-4	3
	028040246	ハネザガネ2-4	3
	S08205000	クツシヨン	4
	S39821000	コードクランプ19P7	7

Page 62 — AC . コーナ一メス関係 / Corner knife mechanism

Brother BAS-6150 parts on page 62

Ref	Part number	Part name	Qty
	1-22	1-23
	1-21	1
	124	100
	123	122
	121	120
	125	126
	104	103
	102
	25-2	< 16~20mm用 / For 16mm to 20mm >
	25-1	< 8~14mm用 / For 8mm to 14mm >
	27	26
	28	29
	22	21
	20	23
	1-1
	1-19	1-20
	1-18
	1-16
	1-25	1-24
	1-29	1-26
	1-28	1-27
	1-39
	1-39-2
	1-39-1
	1-17
	1-13	1-15
	1-10	1-11
	1-12	1-10
	1-15	1-13
	1-40	1-2
	1-39
	1-39-2
	1-39-1
	1-6	1-7
	1-8
	1-5
	1-14
	1-9
	1-34	1-33
	1-32
	1-31
	1-35
	1-37	1-38
	1-36
	24-1	8mm
	24-2	10mm
	24-3	12mm
	24-4	14mm
	24-5	16mm
	24-6	18mm
	24-7	20mm

Page 63 — AC.コーナーメス関係 / Corner knife mechanism

Brother BAS-6150 parts on page 63

Ref	Part number	Part name	Qty
	S53700000	CORNER KNIFE DRIVING ASSY, A	1
	S42445001	BOLT, SOCKET (S/P WASHER)M8X25	4
	S53702000	LINEAR GUIDE	1
	018062036	BOLT, SOCKET M6X20	5
	S10133000	X-PULLEY BASE, B	1
	018501636	BOLT, SOCKET M5X16	4
	028050246	WASHER, SPRING 2-5	4
	025050236	WASHER, PLAIN M 5	4
	018501636	BOLT, SOCKET M5X20	1
	530138001	MICRO BEARING	2
	048160242	RETAINING RING, INTERNAL C16	2
	S10087101	TIMING PULLEY, B	1
	012400436	SET SCREW, SOCKET (FT) M4X4	2
	S10134001	X-PULLEY SHAFT, B	1
	048080142	RETAINING RING, C8	2
	S53703000	TIMING BELT	1
	S10078001	SPACER, T-BELT	2
	S10079101	BELT HOLDER	1
	018401036	BOLT, SOCKET M4X10	2
	028040246	WASHER, SPRING 2-4	2
	S43192200	PULSE MOTOR ASSY, A	1
	S27844201	TIMING PULLEY, A	1
	014770622	SET SCREW, SOCKET (CP) SM6.35	2
	018401236	BOLT, SOCKET M4X12	4
	028040246	WASHER, SPRING 2-4	4
	S53705001	CYLINDER SUPPORT, L	1
	018501636	BOLT, SOCKET M5X16	2
	028050246	WASHER, SPRING 2-5	2
	S53706001	SENSOR DOG	1
	008400604	SCREW, TRUSS M4X6	2
	S53707001	FIXING BLOCK	1
	018501436	BOLT, SOCKET M5X14	2
	028040246	WASHER, SPRING 2-4	2
	025050236	WASHER, PLAIN M 5	2
	018502036	BOLT, SOCKET M6X20	1
	S53708001	CYLINDER SUPPORT, R	1
	018501236	BOLT, SOCKET M5X12	2
	028050246	WASHER, SPRING 2-5	2
	S53709000	CYLINDER ASSY, 25X75	2
	S53710000	CYLINDER, 25X75	2
	S53722000	ELBOW, KQ2L06M5	4
	S32294001	BOLT, SOCKET M4X35	8
	S57541001	C-KNIFE SETTING BRACKET	2
	018061436	BOLT, SOCKET M6X14	2
	S14753001	KNIFE BASE SHAFT	2
	012500536	SET SCREW, SOCKET (FT) M5X5	2
	S11521001	KNIFE BASE ASSY, 8	2
	S11522001	KNIFE BASE ASSY, 10	2
	S11523001	KNIFE BASE ASSY, 12	2
	S11524001	KNIFE BASE ASSY, 14	2
	S11525001	KNIFE BASE ASSY, 16	2
	S11526001	KNIFE BASE ASSY, 18	2
	S11527001	KNIFE BASE ASSY, 20	2
	S14050001	CERAMIC CORNER KNIFE, S	4
	S14051001	CERAMIC CORNER KNIFE, L	4

Page 64 — AC . コーナ一メス関係 / Corner knife mechanism

Brother BAS-6150 parts on page 64

Ref	Part number	Part name	Qty
	1-22	1-22
	1-23	1-23
	1-21	1-21
	124	124
	100	100
	123	123
	120	120
	122	122
	121	121
	125	125
	126	126
	104	104
	103	103
	102	102
	25-2	25-2
	25-1	25-1
	27	27
	28	28
	29	29
	26	26
	22	22
	21	21
	20	20
	23	23
	1-1	1-1
	1-6	1-6
	1-7	1-7
	1-8	1-8
	1-9	1-9
	1-5	1-5
	1-14	1-14
	1-15	1-15
	1-10	1-10
	1-11	1-11
	1-12	1-12
	1-13	1-13
	1-16	1-16
	1-17	1-17
	1-18	1-18
	1-19	1-19
	1-20	1-20
	1-24	1-24
	1-25	1-25
	1-26	1-26
	1-29	1-29
	1-27	1-27
	1-28	1-28
	1-39	1-39
	1-39-2	1-39-2
	1-39-1	1-39-1
	1-40	1-40
	1-2	1-2
	1-3	1-3
	1-35	1-35
	1-31	1-31
	1-32	1-32
	1-33	1-33
	1-34	1-34
	1-36	1-36
	1-37	1-37
	1-38	1-38
	24-1	24-1
	24-2	24-2
	24-3	24-3
	24-4	24-4
	24-5	24-5
	24-6	24-6
	24-7	24-7

Page 65 — AC.コーナーメス関係 / Corner knife mechanism

Brother BAS-6150 parts on page 65

Ref	Part number	Part name	Qty
26	111140002	SCREW, SM2.38	4
27	018401236	BOLT, SOCKET M4X12	2
28	028040246	WASHER, SPRING 2-4	2
29	025040236	WASHER, PLAIN M 4	2
100	S52453000	C/K POWER HARNESS, M/PCB-MT	1
102	S52986000	HOME POSITION SENSOR, C/K	1
103	062301006	SCREW, PAN M3X10	1
104	S52724000	SENSOR HARNESS, C/K	1
120	S39821000	CORD CLAMP, 19P7	4
121	625010000	CORD HOLDER, NK-2N	1
122	552907000	CORD HOLDER, 10N	1
123	0A5401005	SCREW, PAN (S/P WASHER) M4X10	2
124	S04557000	BAND, PLT1M	1
125	S55302000	SPIRAL, L=400	1
126	S55305000	SPIRAL, L=220	1

Page 67

Brother BAS-6150 parts on page 67

Ref	Part number	Part name	Qty
	S53742001	PULLEY SETTING BRACKET	1
	018060222	BOLT, SOCKET M6X20	2
	028060236	WASHER, PLAIN M 6	2
	028060246	WASHER, SPRING 2-6	2
	S12078000	BALL BEARING, 2 DEEP GROOVE	2
	S53785001	TIMING PULLEY, A	1
	S12079000	COLLAR, 2	2
	S12076000	PULLEY SHAFT, D	1
	012500536	SET SCREW, SOCKET (FT) M5X5	2
	S53743000	TIMING BELT	1
	076002450	BALL BEARING, 6002DD	2
	S53744001	PULLEY SHAFT	1
	S12067000	KEY, 5X35	1
	04815142	RETAINING RING, EXTERNAL C15	1
	S53787001	TIMING PULLEY, B	1
	116920001	RING, THRUST	1
	012060636	SET SCREW, SOCKET (FT) M6X6	2
	S53745000	SUR GEAR, 66 ;PA	1
	012500536	SET SCREW, SOCKET (FT) M5X5	1
	S53747000	KEY, 5X30	1
	S53748001	MOTOR SETTING PLATE	1
	018501236	BOLT, SOCKET M5X12	4
	S53749000	LINEAR GUIDE, 15X700	2
	018401436	BOLT, SOCKET M4X14	14
	028040246	WASHER, SPRING 2-4	14
	S53750001	FEED BRACKET	1
	018401636	BOLT, SOCKET M4X16	8
	028040246	WASHER, SPRING 2-4	8
	S53751001	BELT HOLDER	1
	018501636	BOLT, SOCKET M5X16	4
	S53752001	LIMIT PLATE	2
	018501236	BOLT, SOCKET M5X12	4
	104821001	RUBBER CAP, 10.5	4
	S53753000	CYLINDER ASSY	2
	S53754000	AIR CYLINDER, 25X12	2
	S53786000	SPEED CONTROLLER	4
	018061422	BOLT, SOCKET M6X14	8
	S53756001	CYLINDER SUPPORT	2
	S53757001	FULCRUM SHAFT	2
	018301036	BOLT, SOCKET M3X10	4
	S53758001	CYLINDER GUIDE	1
	018502036	BOLT, SOCKET M5X20	2
	S53759001	CORD SUPPORT BRACKET	1
	062061012	SCREW, PAN M6X10	2
	S53760000	RUNER FLEX	1
	002501003	SCREW, PAN M5X10	2
	025050236	WASHER, PLAIN M 5	2
	S56861001	SHAFT	1
	018500836	BOLT, SOCKET M5X8	2
	S5682001	SET SCREW COLLAR	6
	012500536	SET SCREW, SOCKET (FT) M5X5	12
	S53773001	SENSOR DOG, F/B	1
	008400604	SCREW, TRUSS M4X6	2
	S53774001	FEED BRACKET COVER, L	1
	018501636	BOLT, SOCKET M5X16	4
	S29742001	BOLT, SOCKET M5X50	1
	021500216	NUT, 2 M5	1
	S53775001	FEED BRACKET COVER, R	1
	018061636	BOLT, SOCKET M6X16	4
	026060136	WASHER, PLAIN S 6	4
	S53783001	SENSOR SETTING PLATE	2

Page 68 — AD. 送り装置関係 / Feed device mechanism

Brother BAS-6150 parts on page 68

Ref	Part number	Part name	Qty
	1-34-2	1-34-2
	1-37	1-37
	1-36	1-36
	1-38	1-38
	1-39	1-39
	1-51	1-51
	1-47	1-47
	1-49	1-49
	1-48	1-48
	1-49	1-49
	1-46	1-46
	1-49	1-49
	1-28	1-28
	1-27	1-27
	1-34	1-34
	1-41	1-41
	1-42	1-42
	1-34-1	1-34-1
	1-50	1-50
	1-30	1-30
	1-29	1-29
	1-51	1-51
	1-44	1-44
	1-45	1-45
	1-43	1-43
	106	106
	107	107
	108	108
	105	105
	102	102
	101	101
	1-59	1-59
	1-60	1-60
	1-33	1-33
	1-32	1-32
	1-31	1-31
	1-10	1-10
	1-11	1-11
	1-12	1-12
	1-14	1-14
	1-13	1-13
	1-20	1-20
	1-15	1-15
	1-16	1-16
	1-17	1-17
	1-19	1-19
	1-18	1-18
	1-22	1-22
	1-21	1-21
	1-23	1-23
	1-56	1-56
	1-57	1-57
	1-58	1-58
	10	10
	1-8	1-8
	1-52	1-52
	1-53	1-53
	1-54	1-54
	1-55	1-55
	1-5	1-5
	6	6
	4	4
	5	5
	1-2	1-2
	1-3	1-3
	1-4	1-4
	1-9	1-9
	1-1	1-1
	10	10
	12	12
	11	11
	13	13
	19	19
	20	20
	21	21
	22	22
	23	23
	24	24
	120	120
	121	121
	122	122
	123	123
	14	14
	14	14

Page 70 — AE . バインダー関係 / Binder mechanism

Brother BAS-6150 parts on page 70

Ref	Part number	Part name	Qty
	9-19	9-19
	9-20	9-20
	9-18	9-18
	9-22	9-22
	9-23	9-23
	9-22	9-22
	9-9	9-9
	9-11	9-11
	9-11-2	9-11-2
	9-21	9-21
	9-24	9-24
	9-11-1	9-11-1
	9-13	9-13
	9-14	9-14
	9-16	9-16
	9-15	9-15
	9-25	9-25
	9-27	9-27
	9-29	9-29
	9-28	9-28
	9-32	9-32
	9-36	9-36
	9-35	9-35
	9-37	9-37
	9-39	9-39
	9-38	9-38
	14	14
	14-1	14-1
	14-2	14-2
	15	15
	110	110
	109	109
	13	13
	12	12
	11	11
	10	10
	17	17
	16	16
	9-2	9-2
	9-10	9-10
	9-82	9-82
	9-81	9-81
	9-3	9-3
	9-4	9-4
	9-9	9-9
	9-1	9-1
	9-33	9-33
	9-2	9-2
	9-42	9-42
	9-40	9-40
	9-39	9-39
	9-41	9-41
	9-60	9-60
	9-59	9-59
	9-64	9-64
	9-65	9-65
	9-56	9-56
	9-85	9-85
	9-62	9-62
	9-71	9-71
	9-63	9-63
	9-74	9-74
	9-53	9-53
	9-44	9-44
	9-45	9-45
	9-46	9-46
	9-48	9-48
	9-49	9-49
	9-47	9-47
	9-64	9-64
	9-65	9-65
	9-57	9-57
	9-58	9-58
	9-90	9-90
	9-61	9-61
	9-72	9-72
	9-63	9-63
	9-70	9-70
	9-68	9-68
	9-77	9-77
	9-76	9-76
	103	103
	104	104
	19	19
	18	18
	100	100
	101	101
	102	102
	9-8	9-8
	9-7	9-7
	9-6	9-6
	9-5	9-5
	9-1	9-1
	9-43	9-43
	9-47	9-47
	9-50	9-50
	9-34	9-34
	9-54	9-54
	9-55	9-55
	9-52	9-52
	9-73	9-73
	9-86	9-86
	9-64	9-64
	9-51	9-51
	9-70	9-70

Page 72 — AE バインダー関係 / Binder mechanism

Brother BAS-6150 parts on page 72

Ref	Part number	Part name	Qty
	15	15
	14-2	14-2
	14-1	14-1
	14-3	14-3
	11	11
	10	10
	13	13
	12	12
	110	110
	109	109
	9-32	9-32
	9-36	9-36
	9-37	9-37
	9-35	9-35
	9-38	9-38
	9-28	9-28
	9-29	9-29
	9-27	9-27
	9-39	9-39
	9-38	9-38
	9-40	9-40
	9-73	9-73
	9-72	9-72
	9-69	9-69
	9-70	9-70
	9-68	9-68
	9-63	9-63
	9-62	9-62
	9-71	9-71
	9-61	9-61
	9-59	9-59
	9-60	9-60
	9-58	9-58
	9-57	9-57
	9-56	9-56
	9-55	9-55
	9-54	9-54
	9-53	9-53
	9-52	9-52
	9-51	9-51
	9-47	9-47
	9-44	9-44
	9-45	9-45
	9-46	9-46
	9-49	9-49
	9-48	9-48
	9-43	9-43
	9-42	9-42
	9-41	9-41
	9-40	9-40
	9-39	9-39
	9-31	9-31
	9-30	9-30
	9-15	9-15
	9-16	9-16
	9-17	9-17
	9-14	9-14
	9-13	9-13
	9-12	9-12
	9-11	9-11
	9-11-1	9-11-1
	9-11-2	9-11-2
	9-25	9-25
	9-24	9-24
	9-21	9-21
	9-20	9-20
	9-19	9-19
	9-18	9-18
	9-23	9-23
	9-22	9-22
	9-22	9-22
	9-1	9-1
	9-5	9-5
	9-6	9-6
	9-7	9-7
	9-8	9-8
	9-81	9-81
	9-82	9-82
	9-2	9-2
	9-3	9-3
	9-4	9-4
	9-10	9-10
	9-33	9-33
	9-34	9-34
	9-50	9-50
	17	17
	16	16
	19	19
	18	18
	100	100
	101	101
	102	102
	103	103
	104	104

Page 73 — AE.バインダー関係 / Binder mechanism

Brother BAS-6150 parts on page 73

Ref	Part number	Part name	Qty
9-59	S59035000	SPRING, PLATE	1
9-60	018301236	BOLT, SOCKET M3X12	2
9-61	S59044001	CLOTH GUIDE ARM, R	1
9-62	S59043001	CLOTH GUIDE ARM, L	1
9-63	018300836	BOLT, SOCKET M3X8	2
9-64	018301236	BOLT, SOCKET M3X12	4
9-65	021300303	NUT, 3 M	4
9-68	S59034000	CLOTH GUIDE, R	1
9-69	S59033000	CLOTH GUIDE, L	1
9-70	S58692001	SCREW, FLAT M2X3	4
9-71	S21008001	FULCRUM SHAFT, C/GUIDE	1
9-72	S21009001	SLEEVE, C/GUIDE	2
9-73	S30014001	SCREW, M3	2
9-74	012400436	SET SCREW, SOCKET (FT) M4X4	1
9-77	018082036	BOLT, SOCKET M8X20	1
9-81	018061436	BOLT, SOCKET M6X14	1
9-82	021060206	NUT, 2 M6	1
9-85	S59047001	BINDER SETTING PLATE, C	1
9-86	004301016	SCREW, FLAT M3X10	2
9-90	025030236	WASHER, PLAIN M 3	2
9-91	025030236	WASHER, PLAIN M 3	2
10	S14703001	THREAD TAKE-UP ARM	1
11	141598001	SHOULDER SCREW, SM4.76	1
12	S53815001	CURVED WIRE	1
13	012300336	SET SCREW, SOCKET (FT) M3X3	2
14	S53816100	CYLINDER ASSY	1
14-1	S53817100	AIR CYLINDER 10X5	1
14-2	S12150000	TUBE ELBOW, M-5HL-4	2
14-3	S39122000	KNUCKLE JOINT, M4	1
15	018400836	BOLT, SOCKET M4X8	2
16	S53818001	FULCRUM PIN	2
17	012500536	SET SCREW, SOCKET (FT) M5X5	4
18	S53686001	POSITIONING PLATE	1
19	S20355002	SCREW, M3X8.5	2
100	S52759000	MICRO SWITCH, D3M-01K2-3	1
101	002021205	SCREW, PAN M2X12	2
102	S52468000	SWITCH HARNESS, SW-M/PCB	1
103	S10243000	CORD HOLDER, NK-3N	1
104	0A5400805	SCREW, PAN (S/P WASHER) M4X8	1
109	625010000	CORD HOLDER, NK-2N	1
110	0A4300605	SCREW, PAN (S/P WASHER) M3X6	1

Page 74 — Z1. 付属品関係 / Accessories

Brother BAS-6150 parts on page 74

Ref	Part number	Part name	Qty
	30	30
	7.1	7.1
	7	7
	8	8
	16	16
	31-11-2	31-11-2
	31-11-3	31-11-3
	31-15	31-15
	31-19-1	31-19-1
	31-7	31-7
	31-16-2	31-16-2
	31-18-1	31-18-1
	31-19-2	31-19-2
	31-18-1	31-18-1
	31-17	31-17
	31-12	31-12
	31-1	31-1
	31-18-3	31-18-3
	31-16-3	31-16-3
	31-10	31-10
	31-18-1	31-18-1
	31-18-2	31-18-2
	31-18-4	31-18-4
	31-19-3	31-19-3
	31-18-6	31-18-6
	31-18-2	31-18-2
	31-9	31-9
	31-9-1	31-9-1
	33	33

Page 75 — Z1.付属品関係 / Accessories

Brother BAS-6150 parts on page 75

Ref	Part number	Part name	Qty
	153011416	ミシンハリMTX190クミ	1
	153011016	ミシンハリMTX190	4
	S09285051	ボビン	4
	S09152001	ウワメスC
	S54022001	イトアンナイ
	S02767409	イトタテクイミ3THF
	150189109	ブラケット
	062060806	ヘコ36X8	2
	S51283001	ウケザラ	3
	150182000	プーマツト	3
	126863001	プーラクツシヨン	3
	S04109001	イトアンナイササエボウ	1
	S40639001	コラムパイプキヤツプツキ	1
	150173003	コラムキヤツプ	1
	S21798001	コラムジヨイント	3
	150179003	スプールネシセット	1
	150179002	スプールシクB	3
	028050246	ハネジナガメ2-5	3
	021500106	1ミユナツト5	3
	150185009	イトアンナイホルター	1
	138843001	ササエホウウツギテ	1
	S02779009	スプールホルター-3	1
	S02788009	スレッドハンガーアツシ、3	1
	S02789009	スレッドハンガー-3	1
	150183000	イトカケハンガーダイ	1
	142990001	スレッドブツシユ	3
	150172003	コラムパイプ	1
	S0641001	スプールシヨウケツトA	1
	021500106	1ミユナツト5	4
	062501406	ナベコ5X14	1
	062503506	ナベコM5X35	1
	062501406	ナベコ5X14	2
	026050136	ヒラサガネコガタS5	2
	S40643001	ホルダージヨイントセツト	1
	014060632	アツクボミ6X6	2
	021500106	1ミユナツト5	1
	062503506	ナベコM5X35	1
	008400604	トラスコ4X6	3

Page 76

Brother BAS-6150 parts on page 76

Ref	Part number	Part name	Qty
	40	"フラップ仕様 オプション部品 / Option parts for flap clamp spec"
	34
	35
	21
	2.4
	2.8
	3.5
	50
	51
	52
	53
	54
	55
	70	"下糸検出器 オプション部品 / Option parts for lower thread detector "
	22
	1
	2
	3
	4
	5
	6
	7
	8
	9
	10
	11
	12
	13
	15
	16
	17
	18
	19

Page 77 — Z2.付属品関係 / Accessories

Brother BAS-6150 parts on page 77

Ref	Part number	Part name	Qty
	115157001	6カクホウ スパナ 6	1
	150335001	6カクホウ スパナ 5	1
	118064001	6カクホウ スパナ 4	1
	142721001	6カクホウ スパナ 3	1
	154125001	6カクホウ スパナ 2.5	1
	142002001	6カクホウ スパナ 2	1
	S07783001	6カクホウ スパナ 1.5	1
	S14696001	スパナ 11X13	1
	107780001	スパナ 10X12	1
	100887001	スパナ 8X9	1
	142205001	スパナ 7X8	1
	S08132001	スパナ 5.5	1
	S08170001	Zガタネジ マワシ	1
	122991001	フクンクヒンポリクロ	1
	142443001	ネジ マワシ 1.9X52	1
	118837001	ネジ マワシ 3.4X70	1
	101572101	ネジ マワシ 5.5X190	1
	S01943001	6カクホウ ウネリ マワシ 1.6	1
	117466000	ピンセット	1
	S55663001	オイルタンククミ	1
	114483002	ポリオイラークミ	1
	114486002	ポリオイラータイ	1
	S59338001	ナカメシグ	1
	S59350001	ゲージ・N-バーゲージ	1
	S57533000	ハンシヤシート	2
	152566000	ヒューズ・C	1
	152565000	ヒューズ・B	2
	S52741000	GFUSE6A125V	1
	S08030000	ヒューズ・5AFB	1
	153242000	ヒューズ・6A	2
	J02727001	ヒューズ・2A250V	1
	S52490001	ボビン	4

Page 78 — Ga1. ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150)

Brother BAS-6150 parts on page 78

Ref	Part number	Part name	Qty
G1-1-3	S59139-001	針抱キ8UP組 Needle clamp assy, 8mm
G1-1-3	S59140-001	針抱キ10UP組 Needle clamp asy, 10mm
G1-1-3	S59141-001	針抱キ12UP組 Needle clamp assy, 12mm
G1-1-3	S59142-001	針抱キ14UP組 Needle clamp assy, 14mm
G1-1-3	S59143-001	針抱キ16UP組 Needle clamp assy, 16mm
G1-6	S52571-001	針板8セット Needle plate set, 8
G1-6	S52572-001	針板10セット Needle plate set, 10
G1-6	S52573-001	針板12セット Needle plate set, 12
G1-6	S52574-001	針板14セット Needle plate set, 14
G1-6	S52575-001	針板16セット Needle plate set, 16
G1-3-3	S52561-001	針板8組 Needle plate assy, 8
G1-3-3	S52562-001	針板10組 Needle plate assy, 10
G1-3-3	S52563-001	針板12組 Needle plate assy, 12
G1-3-3	S52564-001	針板14組 Needle plate assy, 14
G1-3-3	S52565-001	針板16組 Needle plate assy, 16
G1-4-3	S52536-001	ループガイド8 Loop guide, 8
G1-4-3	S52537-001	ループガイド10 Loop guide, 10
G1-4-3	S52538-001	ループガイド12 Loop guide, 12
G1-4-3	S52539-001	ループガイド14 Loop guide, 14
G1-4-3	S52540-001	ループガイド16 Loop guide, 16
G2-1-2	S53428-000	滑り板セット8-12 Slide plate set, 8-12
G2-1-2	S53435-000	滑り板セット14-16 Slide plate set, 14-16
G2-1-2-1	S53429-000	滑り板組8-12 Slide plate assy, 8-12
G2-1-2-1	S53436-000	滑り板組14-16 Slide plate assy, 14-16
G2-1-2-2	S53430-001	生地滑り板 Slide plate
G2-1-2-2	S53430-002	生地滑り板 Slide plate
G2-10	S59271-000	定規組8W-13 Binder assy, 8W-13
G2-10	S59275-000	定規組10W-17 Binder assy, 10W-17
G2-10	S59279-000	定規組12W-21 Binder assy, 12W-21
G2-10	S59283-000	定規組14W-25 Binder assy, 14W-25
G2-10	S59287-000	定規組16W-29 Binder assy, 16W-29
G2-20	S59272-000	定規組8W-14 Binder assy, 8W-14
G2-20	S59276-000	定規組10W-18 Binder assy, 10W-18
G2-20	S59280-000	定規組12W-22 Binder assy, 12W-22
G2-20	S59284-000	定規組14W-26 Binder assy, 14W-26
G2-20	S59288-000	定規組16W-30 Binder assy, 16W-30
G2-20	S59273-000	定規組8S-14 Binder assy, 8S-14
G2-20	S59277-000	定規組10S-18 Binder assy, 10S-18
G2-20	S59281-000	定規組12S-22 Binder assy, 12S-22
G2-20	S59285-000	定規組14S-26 Binder assy, 14S-26
G2-20	S59289-000	定規組16S-30 Binder assy, 16S-30
G2-20	S59274-000	定規組8S-15 Binder assy, 8S-15
G2-20	S59278-000	定規組10S-19 Binder assy, 10S-19
G2-20	S59282-000	定規組12S-23 Binder assy, 12S-23
G2-20	S59286-000	定規組14S-27 Binder assy, 14S-27
G2-20	S59290-000	定規組16S-31 Binder assy, 16S-31
AC-25-1,25-2	S14050-001	セラミックコーナーメスS Ceramic corner knife,S
	S14051-001	セラミック コーナーメスL Ceramic corner knife, L
AC-24	S11521-001	メスダイ組 Knife base assy, 8
AC-24	S11522-001	メスダイ10組 Knife base assy, 10
AC-24	S11523-001	メスダイ12組 Knife base assy, 12
AC-24	S11524-001	メスダイ14組 Knife base assy, 14
AC-24	S11525-001	メスダイ16組 Knife base assy, 16
L2-2-2, 2-3	S53521-001	固定刃8 Fixed knife, 8
L2-2-2, 2-3	S53494-001	固定刃10-12 Fixed knife, 10-12
L2-2-2, 2-3	S53495-001	固定刃14-16 Fixed knife, 14-16
L2-3-2, 3-3	S53522-101	上糸メス組8 N/Thread knife assy, 8
L2-3-2, 3-3	S53498-001	上糸メス10-12組 N/Thread knife assy, 10-12
L2-3-2, 3-3	S53501-101	上糸メス14-16組 N/Thread knife assy, 14-16
L2-4-2, 4-3	S53523-001	糸保持板8 Thread holding plate, 8
L2-4-2, 4-3	S53507-001	糸保持板10-12 Thread holding plate, 10-12
L2-4-2, 4-3	S53508-001	糸保持板14-16 Thread holding plate, 14-16

Page 79 — Ga1. ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150)

Brother BAS-6150 parts on page 79

Ref	Part number	Part name	Qty
	S59144-001	針抱キ18UP組 Needle clamp assy, 18mm
	S59145-001	針抱キ20UP組 Needle clamp assy, 20mm
	S52576-001	針板18セット Needle plate set, 18
	S52577-001	針板20セット Needle plate set, 20
	S52566-001	針板18組 Needle plate assy, 18
	S52567-001	針板20組 Needle plate assy, 20
	S52541-001	ループガイド18 Loop guide, 18
	S52542-001	ループガイド20 Loop guide, 20
	S53437-000	滑り板セット18-20 Slide plate set, 18-20
	S53438-000	滑り板組18-20 Slide plate assy, 18-20
	S53430-003	生地滑り板 Slide plate
	S59291-000	定規組18W-33 Binder assy, 18W-33
	S59296-000	定規組20W-37 Binder assy, 20W-37
	S59292-000	定規組18W-34 Binder assy, 18W-34
	S59293-000	定規組18S-34 Binder assy, 18S-34
	S59297-000	定規組20S-38 Binder assy, 20S-38
	S59294-000	定規組18S-35 Binder assy, 18S-35
	S59298-000	定規組20S-39 Binder assy, 20S-39
	AC-25-1,25-2	セラミックコーナーメス Ceramic corner knife
	S14051-001	セラミックコーナーメス L Ceramic corner knife, L
	AC-24	メスダイ組 Knife base assy
	S11526-001	メスダイ組 Knife base assy, 10
	S11527-001	メスダイ20組 Knife base assy, 20
	L2-2-2, 2-3	固定刃 Fixed knife
	S53496-001	固定刃18-20 Fixed knife, 18-20
	L2-3-2, 3-3	上糸メス N/Thread knife assy
	S53503-101	上糸メス18-20 N/Thread knife assy, 18-20
	L2-4-2, 4-3	糸保持板 Thread holding plate
	S53509-001	糸保持板18-20 Thread holding plate, 18-20

Page 81 — Ga2 . ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150)

Brother BAS-6150 parts on page 81

Ref	Part number	Part name	Qty
	S54671-000	定規 18W-33 Binder, 18W-33
	S54675-000	定規 20W-37 Binder, 20W-37
	S53467-000	定規 18W-34 Binder, 18W-34
	S53471-000	定規 20W-38 Binder, 20W-38
	S54673-000	定規 18S-34 Binder, 18S-34
	S54677-000	定規 20S-38 Binder, 20S-38
	S53469-000	定規 18S-35 Binder, 18S-35
	S53473-000	定規 20S-39 Binder, 20S-39

Page 82 — Wa.警告ラベル / Warning labels

Brother BAS-6150 parts on page 82

Ref	Part number	Part name	Qty
	S37060-001	アースマーク Label, grounding	Ø 12
	S37059-001	PE マーク Label, PE	7.5 X 12.5
	S37058-001	矢印マーク Label, arrow	10 X 30
	S36924-002	ワーニングマーク Mark, injury	L=25
	S36924-001	ワーニングマーク Mark, injury	L=16
	S38571-001	操作注意ラベルBAS・和 Label, operation(BAS)Eng.	40 X 64
	S38352-101	Label, elec. shock 4 lang.	35 X 118
	S38353-101	電撃ラベル・和	40 X 64
	S38571-002	操作注意ラベルBAS・和 Label, operation(BAS)Eng.	52 X 84
	S38357-001	電撃ラベル・和	40 X 64

Page 83 — 索引 / INDEX

Brother BAS-6150 parts on page 83

Ref	Part number	Part name	Qty
	002021205	101
	002300403	1-1
	002300603	1-1-5
	1-1-27	44
	1-2-27	46
	50-23	48
	51-24	48
	106	48
	002501003	5
	004300513	1-1-5
	1-4-3	64
	004301016	1-3
	004400603	1-3
	004401003	44
	1-23	156
	004401414	1-1-1-3
	1-2-1-3	12
	004501003	1-10
	004501016	50-5
	51-5	48
	008300604	1-1-32
	1-2-32	46
	50-18	48
	51-19	48
	008400604	9-5
	1-9	44
	1-2-9	44
	50-2	48
	51-2	48
	104	68
	75	57
	82	57
	101	57
	163	57
	165	57
	181	58
	195	58
	1-30	60
	1-51	64
	1-60	66
	008400804	1-10
	012060636	14
	1-1-3	44
	1-2-3	44
	1-7	56
	1-17	64
	123	66
	9-37	68
	012081636	63
	012300336	13
	012400436	1-18
	1-13	60
	9-74	70
	012500536	8
	30	1-9
	1-19	64
	1-49	64
	17	70
	013660612	1-26
	013710512	10
	50	16
	013711012	50
	014060632	31-19-1
	014300332	1-30
	014680422	1-9
	014761030	1-19
	014770622	1-23
	014771022	B6-4
	B16	2
	15	4
	014780622	1-12
	014781032	1-2
	1-3	2
	1-12	6
	23	201
	016771032	16
	017061616	51
	017082016	51
	017083016	1-3
	018060636	1-58
	018061236	1-106
	018061422	1-35
	018061436	1-50
	018061636	1-51
	018062022	1-2
	018062036	1-5
	1-2-5	57
	1-3	60
	1-35	60
	18	66
	018062536	9-52
	018063022	202-2
	018063036	N2
	1-46	30
	1-107	32
	018064036	1-56
	018081636	1-85
	018082036	1-50
	018083036	1-34
	018102036	1-29
	3	56
	018103036	7
	018108036	1-4
	018300636	6
	1-11	24
	177	64
	201	64
	018300836	1-1-7
	1-2-7	14
	176	16
	9-63	70
	018301036	1-38
	018301236	25
	9-57	60
	9-60	70
	9-64	72
	018400836	X2
	1-19	29
	9-19	30
	1-20	60
	1-24	64
	018401236	27
	1-24	40
	018401436	40
	1-24	40
	018401636	60
	1-27	56
	018500836	1-47
	1-47	57
	018501022	1-57
	018501036	1-21
	1-21	44
	50-5	48
	51-9	48
	9-13	48
	018501236	1-13
	1-2-13	64
	X5	44
	1-37	57
	1-22	64
	1-32	64
	121	56
	018501436	154
	1-32	60
	018501622	1-42
	A11	26
	1-6	30
	018501636	A11
	1-6	30
	1-27	32
	021060206	1-88
	021080206	1-110
	1-84	30
	1-15	56
	9-22	68
	021080306	65
	9-33	68
	021120304	9-65
	021300303	1-25
	021400103	1-25
	021400206	1-1-1-4
	1-2-5	12
	021500106	31-11-3
	31-18-1	72
	31-19-2	72
	021500216	50-13
	50-20	48
	51-14	48
	51-21	48
	1-55	64
	021500316	P1-14
	021670102	34
	025030233	1-7
	025030236	1-13
	X3	29
	025050236	1-8
	1-34	60
	1-45	64
	9-44	68
	025060236	1-87
	1-1-7	44
	1-2-7	44
	1-3	64
	025060236	1-109
	025080236	1-36
	1-62	30
	1-83	30
	1-103	30
	1-5	56
	86	57
	025080336	9-17
	9-23	68
	025100232	1-16
	025100236	1-6
	1-31	30
	4	56
	9	56
	025680132	1-15
	025710232	12-3
	39	22
	026050136	31-18-6
	026060136	1-58

Page 84

Brother BAS-6150 parts on page 84

Ref	Part number	Part name	Qty
52	028030242	W4
12	028030246	1-1-8
12	028030246	1-2-8
68	028040243	9-58
34	028040243	1-22
60	028040243	1-25
4	028040246	30
8	028040246	41
57	028040246	61
58	028040246	204
60	028040246	1-20
60	028040246	1-33
4	028050246	28
64	028050246	1-25
64	028050246	1-28
68	028050246	9-20
26	028050246	N7
36	028050246	4
30	028050246	1-38
44	028050246	1-113
44	028050246	1-1-14
52	028050246	1-2-14
60	028050246	X6
60	028050246	1-7
60	028050246	1-28
60	028050246	1-38
66	028050246	17
68	028050246	9-4
68	028050246	9-14
68	028050246	9-45
68	028050246	9-49
68	028050246	9-55
72	028050246	31-11-2
26	028060246	N11
30	028060246	1-86
32	028060246	1-108
40	028060246	31
44	028060246	1-1-6
44	028060246	1-2-6
56	028060246	52
56	028060246	57
64	028060246	1-4
30	028080246	1-35
30	028080246	1-51
30	028080246	1-61
30	028080246	1-82
30	028080246	1-102
56	028080246	1-4
57	028080246	85
66	028080246	24
68	028100246	9-16
30	028100246	1-5
30	028100246	1-30
56	028100246	5
56	028260242	8
34	028260242	1-28
34	032311306	2
54	032422505	3
57	039411215	94
28	047200642	Q1-7
34	047301042	1-16
44	048025342	1-2-25
54	048050346	1-15
24	048060142	1-13
40	048060142	1-15
24	048100142	1-12
64	048150142	1-14
60	048160242	1-11
30	048200142	1-54
54	052400606	1-16
44	060400812	1-2-16
44	060660512	1-14
18	060681212	1-130
72	062060806	31-3-1
28	062061012	P1-4
28	062300606	P1-8
28	062300606	P1-9
34	062300616	1-6
66	062300806	1-102
66	062301006	102
54	062301205	1-6
52	062302506	W3
58	062400805	203
34	062401006	1-24
72	062501406	31-18-2
72	062503506	31-18-3
72	062670512	31-19-3
4	062670512	27
16	062670612	23
18	062670612	170-3
16	062670812	101
6	062670812	1-4-2
6	062670812	1-10
16	062671412	78
22	062671412	33
20	062680812	6
30	062681212	31
12	062681412	1-14
24	062681412	10
16	062682012	123
16	062710612	11
14	062711212	3
2	062782512	B6-2
64	072600480	1-11
70	076002450	1-7
54	081014670	1-8
40	087310815	45
70	087311015	110
1	0A4300605	4
28	0A4300805	Q1-4
54	0A4400805	1-10
40	0A5300805	21
28	0A5400805	Q1-13
34	0A5400805	5
40	0A5400805	6
40	0A5400805	11
40	0A5400805	13
40	0A5400805	15
40	0A5400805	28
40	0A5400805	42
50	0A5400805	108
38	0A5401005	75
40	0A5401005	37
40	0A5401005	39
40	0A5401005	72
62	0A5401005	123
57	0A5401006	167
52	0A5401205	W10
20	100064002	2
34	100136001	1-20
14	100197002	4
4	100250001	7
2	100251001	B5-2
4	100251001	12
22	100251001	42
18	100401001	1-19
26	100645003	N6
74	100887001	10
74	101572101	18
4	101706001	11
6	102731004	1-2
2	104821001	A8
16	104821001	31
18	104821001	135
64	104821001	1-33
57	105173004	169
8	105216001	19
8	107017002	9
56	107153002	41
74	107780001	9
20	108254001	1-4
20	108265009	1-6
20	108266001	7
16	108802001	64
6	112592001	1-4-1
6	112593001	1-5
6	112594001	6
2	112684001	B5-1
14	112700001	27-1
20	112709001	1-20
20	112709001	3
20	112712001	1-10
16	112717001	10
6	112721001	1-6
16	112728001	56
16	112735001	58
16	112753001	16
16	112753001	40
18	112758001	143
4	113014000	10
4	113024000	25
2	113386000	A2
74	114483002	22
74	114486002	32
16	114693001	57
74	115157001	1
44	115503001	1-20
46	115503001	1-2-20
48	115503001	50-8
48	115503001	51-8
64	116920001	1-16
28	117436001	Q1-5
74	117466000	20
54	117936001	1-17
74	117936001	1-17
74	118064001	3
57	118550001	62-2
74	118837001	17
8	118954000	3
22	120752001	41
74	122991001	15
72	126863001	31-6
2	131007001	B5-3
58	133172003	180
72	138843001	31-13
20	140527001	13-1
32	140682001	1-111-4
36	140682001	1-6
36	140682001	2-4
16	140890009	30
22	141544001	46
70	141598001	11
74	142002001	6
74	142205001	11
4	142274101	21-2
18	142274101	200-4
74	142443001	16
74	142721001	4
72	142990001	31-16-3
20	144504001	1-16
22	144526001	37
2	144875001	B13
20	145446001	1-13
34	145446001	1-18
34	145480001	1-18

Page 85 — 索 引 / INDEX

Brother BAS-6150 parts on page 85

Ref	Part number	Part name	Qty
	145446001	1-18
	145571101	1-17
	146124001	1-5
	146141001	8
	146197001	1-21
	146360002	38
	146427001	1-1
	146427001	1-2-1
	148005001	12-2
	148394000	29
	148536001	48
	148539101	27
	148762001	37
	148821001	B6-3
	148821001	B17
	149287000	72
	149287000	73
	149287000	121
	149566109	1-15
	149796001	20
	150172003	31-17
	150173003	31-10
	150174000	31-9-1
	150179002	31-11-1
	150182000	31-5
	150183000	31-16-2
	150185009	31-12
	150189109	31-1
	150235001	2
	150335001	13-2
	150936001	5
	150937101	6
	150938201	7
	150967101	11
	150988001	9
	151027001	23-1-1-1
	151029001	23-2-2
	151030001	23-2-3
	151090001	8
	151148001	1-27
	151951001	37
	152356301	1-1
	152361001	1-10
	152362001	1-11
	152363001	1-15
	152364001	1-31
	152565000	W8-2
	152566000	W8-1
	152645001	1-5
	152651401	1
	152725000	202-1
	152914001	N4
	153011014	A4-2
	153011016	7-1
	153011016	A4-1
	153011018	A4-3
	153011416	7
	153012101	200
	153057102	33
	153208002	10
	153230101	170-2
	153242000	W8-5
	153252000	5-2
	153274001	1-11-5
	153568001	19
	154024001	1-19
	154125001	1-8
	154250001	1-17
	154560001	1-18
	154886001	58
	154965001	52
	155479001	23-2-1
	15551000	159
	15811500	1-17
	15815000	1-19
	158581001	1-4
	158597001	1-32
	158768001	1-7
	158769001	1-12
	159027001	50
	15915000	159
	159805001	A9
	159805001	1-10
	159928000	1-14
	62501000	121
	J02727001	W8-7
	J80869001	N12
	S00480000	70
	S00554000	73
	S01943001	19
	S02606000	139
	S02738000	91
	S02739000	93
	S02740000	92
	S02767409	31
	S02779000	31-15
	S02788000	31-16
	S02789000	31-16-1
	S03999000	21-1
	S04109000	15
	S04505000	107
	S04557000	71
	S04557000	149
	S04557000	1-130
	S04557000	101
	S04557000	X11
	S06994001	35
	S07327001	147
	S07333001	41-2
	S07334001	22
	S07338001	24
	S07339200	26
	S07417001	9
	S07436001	24
	S07446001	25
	S07459100	200-3
	S07462000	69
	S07463000	70
	S07464100	200-5
	S07465000	55
	S07469001	129-7
	S07471001	22
	S07476000	36
	S07477000	4
	S07478000	5
	S07481009	144
	S07487101	1-8
	S07490001	1-19
	S07519001	31
	S07520001	32
	S07521001	35
	S07522001	36
	S07524101	43
	S07525000	45
	S07527001	49-1
	S07571000	39
	S07658001	27
	S07783001	7
	S07876101	91
	S08030000	W8-4
	S08132001	12
	S08170001	13
	S08205000	205
	S08238000	9-28
	S08239000	9-29
	S08240000	9-30
	S08280000	9-50
	S08320000	9-27
	S08338001	9-35
	S08339001	9-36
	S08342001	9-31
	S08352000	9-12
	S08604001	1-1
	S08605101	1-22
	S08606001	1-23
	S08607001	1-2
	S08608001	1-3
	S08609201	1-24
	S08610101	1-25
	S09043000	17
	S09132051	202
	S09141000	74
	S09142000	75
	S09200001	5-1
	S09259001	5
	S09260001	6-1
	S09261001	6-2
	S09273001	23-1-2
	S09284001	23-2-5
	S09285051	41
	S09295000	42
	S10078001	1-17
	S10079101	1-18
	S10087101	1-12
	S10133000	1-5
	S10134001	1-14
	S10243000	120
	S10243000	103
	S10243000	Q1-12
	S10661109	14
	S10859001	77
	S11433000	1-1-22-3
	S11433000	1-2-22-3
	S11433000	P1-13
	S11521001	24-1
	S11522001	24-2
	S11523001	24-3
	S11524001	24-4
	S11525001	24-5
	S11526001	24-6
	S11527001	24-7
	S12067000	1-13
	S12076000	1-8
	S12078000	1-5
	S12079000	1-7
	S12150000	1-1-22-2
	S12150000	1-2-22-2
	S12150000	50-10-2
	S12150000	51-10-2
	S12150000	14-2
	S12445051	B5
	S12463001	44
	S12506000	9-4
	S13021001	16
	S14050001	25-1

Page 86 — 索引 / INDEX

Brother BAS-6150 parts on page 86

Ref	Part number	Part name	Qty
	S14050001	25-2
	S14051001	Ga1
	S14051001	Ga1
	S14189100	200-1
	S14666000	1-1-22-1
	S14666000	1-2-22-1
	S14666000	50-10-1
	S14666000	51-10-1
	S14677001	5
	S14677001	M1-3
	S14696001	8
	S14703001	10
	S14753001	22
	S14874000	43
	S15097000	M1-1
	S15584509	1
	S16350001	15
	S16603000	15-2
	S16669000	1-33
	S17533000	9-8
	S17971000	39
	S20355002	19
	S20849101	38
	S21008001	9-71
	S21009001	9-72
	S21195001	82
	S21196001	134
	S21798001	31-11
	S21931001	5
	S27844201	1-22
	S29742001	1-54
	S29863001	1-4
	S30014001	9-73
	S30229000	W8-6
	S30505001	13
	S31258001	1-1-30
	S31258001	1-2-30
	S31760000	76
	S31921000	9-38
	S32294001	1-40
	S32843001	32
	S35032101	1-27
	S36260000	1-5-2
	S36355001	26
	S36924001	Wa
	S36924002	Wa
	S37058001	Wa
	S37059001	Wa
	S37060001	Wa
	S37968001	42
	S38059000	1-20
	S3811000	24
	S38166000	1-1
	S38170001	1-4
	S38174001	1-8
	S38175001	1-9
	S38176101	1-10
	S38177001	1-14
	S38212001	50
	S38212001	51
	S38213051	12-1
	S38237001	B7
	S38241051	14
	S38244100	17
	S38245051	B7-1
	S38248001	3
	S38251000	119
	S38253001	B4
	S38261001	120
	S38264001	121
	S38266000	35
	S38270001	38
	S38274001	1-9
	S38292001	6
	S38295000	B1
	S38299001	7
	S38352101	Wa
	S38353101	Wa
	S38357001	Wa
	S38357002	Wa
	S38360001	6
	S38396001	9
	S38398001	1
	S38404001	21
	S38419001	28
	S38420001	29
	S38448000	200-2
	S38541000	75
	S38541007	75
	S38571001	Wa
	S38571002	Wa
	S38820000	95
	S39110001	A13
	S39115100	P1-21
	S39115100	1-2
	S39115100	2-1
	S39116100	1-11-2
	S39116100	1-1
	S39116100	1-1
	S39122000	14-3
	S39821000	100
	S39902001	1-29
	S40494000	X7
	S40583000	98
	S40616001	12
	S40620001	10
	S40639001	31-9
	S40641001	31-18
	S40643001	31-19
	S40884000	1-1
	S41964000	194
	S42445001	1-1
	S42446001	1-11
	S42466001	32
	S42619001	1-17
	S42867001	1-2
	S43192200	1-21
	S44807000	1-5-1
	S46191001	1-55
	S46583000	96
	S46738000	20
	S47900000	7-1
	S48715000	2
	S48716001	A
	S48724001	B2-1
	S48732001	B14
	S48734000	76
	S48737000	108
	S48738000	109
	S48739001	110
	S48740001	111
	S48760001	12-1
	S48761001	12-2
	S48763001	129-1
	S48776000	11
	S49491000	1-1-1
	S49495000	1-3
	S49529001	12
	S49530001	12-4
	S49564002	132
	S49638001	40
	S51283001	31-4
	S52092000	1-5
	S52427000	7-2
	S52439000	17
	S52440000	18
	S52441000	19
	S52442000	32
	S52443000	25
	S52444000	26
	S52445000	33
	S52446000	36
	S52447000	34
	S52448000	35
	S52449000	46
	S52450000	43
	S52451000	109
	S52452000	100
	S52453000	100
	S52454000	100
	S52457000	27
	S52458000	8
	S52459000	3
	S52460000	4
	S52461000	48
	S52462000	Q1-11
	S52465000	X1-1
	S52468000	102
	S52469000	P1-1
	S52470001	5-1
	S52475000	9
	S52476000	16
	S52478000	14
	S52486101	A12
	S52487001	5
	S52490001	P1-20
	S52490001	70
	S52491001	28
	S52493001	N1
	S52495101	1
	S52497001	1-7
	S52498001	1-8
	S52499001	1-9
	S52500001	1-11
	S52507001	1
	S52508001	11-1
	S52509001	12
	S52510001	14
	S52514001	17
	S52518000	28
	S52519000	28-1
	S52521001	30
	S52523001	A10
	S52524001	1-13
	S52525001	8
	S52536001	4-3
	S52536001	Ga1
	S52537001	4-1
	S52537001	Ga1
	S52538001	4-2
	S52538001	Ga1
	S52539001	4-3
	S52539001	Ga1
	S52540001	4-3
	S52540001	Ga1
	S52541001	4-3
	S52541001	Ga1
	S52542001	4-3
	S52542001	Ga1
	S52549001	47-3
	S52550001	41
	S52551000	41-1
	S52552000	42
	S52553000	43
	S52556000	45
	S52557000	46
	S52558000	47
	S52559000	48
	S52560001	41-3
	S52561001	3-3
	S52561001	Ga1

Page 87 — 索引 / INDEX

Brother BAS-6150 parts on page 87

Ref	Part number	Part name	Qty
10	S52571001	6
75	S52572001	Ga1
75	S52573001	Ga1
10	S52574001	6
75	S52575001	Ga1
10	S52576001	6
75	S52577001	Ga1
14	S52579002	23
14	S52675902	23
14	S52677001	23-2
18	S52679001	129
62	S52724000	104
40	S52727000	8
40	S52732000	40
40	S52733000	41
52	S52741000	WB-3
40	S52744000	47
52	S52749000	W5
52	S52750000	W6
52	S52751000	W7
28	S52758000	Q1-3
70	S52759000	100
40	S52760000	1
40	S52952001	29
54	S52957000	1-18
54	S52958000	1-19
54	S52959000	1-5
54	S52960001	1
28	S52961000	P1-2
48	S52962000	P1-3
48	S52963000	101
52	S52963000	102
48	S52965001	103
28	S52966000	Q1-2
40	S52968001	5-2
57	S52970000	97
38	S52973000	70
66	S52974000	120
54	S52975001	1
54	S52976000	1-1
54	S52977000	1-1-2
54	S52978000	1-1-3
54	S52979000	1-2
54	S52980000	2
52	S52985000	X10
62	S52986000	102
52	S52989000	X1
32	S52991000	12
52	S53000001	W1
52	S53007001	W8
54	S53010001	1-6
26	S53166000	N8
8	S53167000	29
8	S53168000	28-2
8	S53169001	34
26	S53171000	M1
22	S53172001	40
18	S53174000	36
18	S53175000	129-2
18	S53176000	129-3
18	S53177000	129-4
18	S53178000	129-5
18	S53179000	129-6
8	S53180000	13
18	S53195000	145
28	S53422000	P1-6
28	S53423000	P1-7
28	S53425001	Q1
28	S53426001	Q1-1
28	S53427001	Q1-6
75	S53428000	Ga1
12	S53430001	1-1-1
12	S53430001	1-1-1-1
12	S53430002	1-2-1-1
75	S53430002	Ga1
12	S53431001	1-1-2
76	S53431001	Ga1
12	S53432000	1-2-3
12	S53432000	Ga1
12	S53434000	1-3-4
12	S53434000	Ga1
12	S53435000	1-2
12	S53436000	1-2-1
75	S53436000	Ga1
12	S53437000	1-2-3
76	S53438000	Ga1
12	S53445000	10-2
77	S53445000	Ga2
77	S53449000	20-2
12	S53451000	10-2
77	S53453000	Ga2
12	S53460000	10-2
77	S53460000	Ga2
12	S53461000	10-2
77	S53461000	Ga2
12	S53463000	10-2
77	S53463000	Ga2
12	S53465000	10-2
77	S53465000	Ga2
12	S3467000	10-2
78	S3467000	Ga2
12	S53469000	20-2
78	S53469000	Ga2
12	S53471000	10-2
78	S53471000	Ga2
12	S53473000	20-2
78	S53473000	Ga2
12	S53488000	28-3
46	S53488000	20-2
24	S53490001	M1-2
75	S53490001	23
24	S53490001	Ga1
75	S53495001	23
28	S53495001	Ga1
24	S53496001	2-3
75	S53496001	Ga1
24	S53498001	3-2
75	S53498001	Ga1
24	S53501101	3-3
75	S53501101	Ga1
24	S53503101	3-3
75	S53503101	Ga1
24	S53507001	4-2
75	S53507001	Ga1
24	S53508001	4-3
76	S53508001	Ga1
24	S53509001	4-3
75	S53509001	Ga1
44	S53541000	1-1-22
46	S53541000	1-2-22
48	S53541000	50-10
48	S53541000	50-11
48	S53542000	50-10-3
48	S53542000	51-11
44	S53543001	1-1-23
46	S53543001	1-2-23
44	S53544001	1-1-24
46	S53544001	1-2-24
44	S53545001	1-1-26
46	S53545001	1-2-26
44	S53546001	1-1-28
46	S53546001	1-2-28
44	S53547001	1-1-29
46	S53547001	1-2-29
44	S53548000	1-1-31
46	S53548000	1-2-31
44	S53552000	1-1-34
46	S53552000	1-2-34
44	S53553000	1-1-35
46	S53553000	1-2-35
44	S53554001	1-2
46	S53554001	1-2-4
44	S53555001	1-2-4
44	S53560001	1-2-11
44	S53562001	1-2-1
44	S53564001	1-1-2
44	S53564001	1-2-2
48	S53565000	50
48	S53566000	50-1
48	S53567001	50-3
48	S53567001	51-3
48	S53568001	50-4
48	S53568001	51-4
48	S53569001	50-6
48	S53571001	50-11
48	S53571001	51-12
48	S53572001	50-12
48	S53572001	51-13
48	S53573001	50-14
48	S53573001	51-15
48	S53574000	50-15
48	S53574000	51-16
48	S53575001	50-16
48	S53575001	51-17
48	S53576001	50-19
48	S53576001	51-20
48	S53577000	50-21
48	S53577000	51-22
48	S53580001	50-22
48	S53580001	51-23
50	S53581000	51
48	S53581000	51-6
50	S53582001	107
50	S53584000	108
50	S53585001	109
50	S53586001	111
48	S53588000	105
28	S53617000	P1-10

Page 89 — 索引 / INDEX

Brother BAS-6150 parts on page 89

Ref	Part number	Part name	Qty
	S57938000	9-11-1
	S57942000	X1-2
	S58034000	45
	S58035000	39
	S58036000	40
	S58037000	37
	S58038000	38
	S58039000	25
	S58040000	26
	S58179001	1-1
	S58180001	1-1
	S58181001	1-64
	S58181101	1-65
	S58183000	1-111
	S58184000	1-111-1
	S58204001	1-1-18
	S58204001	1-2-18
	S58594000	9-43
	S58675000	1-1
	S58692001	9-70
	S58693000	13
	S58900000	3
	S58903000	2-6
	S59031000	1-59
	S59032000	5
	S59033000	9-69
	S59034000	9-68
	S59035000	9-59
	S59036001	21
	S59041000	10-1
	S59041000	30-1
	S59041000	50-1
	S59042000	20-1
	S59043001	9-62
	S59044001	9-61
	S59045001	1-3
	S59046001	9-53
	S59047001	9-85
	S59048001	9-56
	S59139001	1-3
	S59139001	Ga1
	S59140001	1-1
	S59140001	Ga1
	S59141001	1-2
	S59141001	Ga1
	S59142001	1-3
	S59142001	Ga1
	S59143001	1-3
	S59143001	Ga1
	S59144001	1-3
	S59144001	Ga1
	S59145001	1-3
	S59145001	Ga1
	S59149001	18
	S59150001	22
	S59151001	23
	S59152001	16
	S59155000	20
	S59156000	20-1
	S59158001	22
	S59217000	9
	S59218000	9-1
	S59219000	5-4
	S59235001	9-2
	S59271000	10
	S59271000	10
	S59271000	Ga1
	S59272000	10
	S59272000	Ga1
	S59273000	20
	S59273000	Ga1
	S59274000	10
	S59274000	Ga1
	S59275000	10
	S59275000	30
	S59275000	Ga1
	S59276000	10
	S59276000	Ga1
	S59277000	20
	S59277000	Ga1
	S59278000	20
	S59278000	Ga1
	S59279000	10
	S59279000	50
	S59279000	Ga1
	S59280000	10
	S59280000	Ga1
	S59281000	20
	S59281000	Ga1
	S59282000	20
	S59282000	Ga1
	S59283000	10
	S59283000	Ga1
	S59284000	20
	S59284000	Ga1
	S59285000	10
	S59285000	Ga1
	S59286000	20
	S59286000	Ga1
	S59287000	10
	S59287000	Ga1
	S59288000	10
	S59288000	Ga1
	S59289000	20
	S59289000	Ga1
	S59290000	10
	S59290000	Ga1
	S59291000	20
	S59291000	Ga1
	S59292000	10
	S59292000	Ga1
	S59293000	20
	S59293000	Ga1
	S59294000	10
	S59294000	Ga1
	S59295000	20
	S59295000	Ga1
	S59296000	10
	S59296000	Ga1
	S59297000	20
	S59297000	Ga1
	S59298000	20
	S59298000	Ga1
	S59338001	34
	S59350001	35
	S59357001	N5
	S59368000	1-111-3
	S59371001	P1
	S59372000	2-3
	S59387000	1-118
	W01519001	10-3
	W01519001	20-3
	W01519001	30-3
	W01519001	50-3
	XA2220050	1-9

Part BooksPartsSearchNotes

Part Books

×

Search

×

Brother BAS-6150 — parts catalog

• Page 1 (cover): This is the cover page for the Brother BAS-6150 Automatic Lockstitch Pocket Welt Sewer Parts Book.
• Page 2 (toc): This page contains the table of contents for the parts book, listing various sections and their corresponding page numbers.
• Page 3 (toc): This page is a table of contents for the parts book, listing various mechanisms and components with their corresponding page numbers. It also includes notes for using the parts book.
• Page 4 (diagram): This page displays diagrams of the machine body and lower shaft mechanism, with numbered parts for identification.
• Page 5 (parts_list): This page lists parts for the Machine body and Lower shaft mechanism, including part numbers, descriptions, and quantities.
• Page 6 (diagram): This page displays a diagram of the upper shaft mechanism, detailing various components with reference numbers and part numbers.
• Page 7 (parts_list): This page lists parts for the Upper shaft mechanism, including part numbers, quantities, and names, with items like bushings, set screws, shafts, and washers.
• Page 8 (diagram): This page displays a diagram of the needle bar rocking mechanism, illustrating various components with reference numbers and part numbers.
• Page 9 (parts_list): This page lists parts for the needle bar rocking mechanism, including part numbers, descriptions, and quantities.
• Page 10 (diagram): This page displays a diagram of the knife mechanism, with numbered parts and their corresponding references.
• Page 11 (parts_list): This page lists parts for the Knife mechanism, including reference numbers, codes, quantities, Japanese names, and English names.
• Page 12 (diagram): This page displays diagrams of gauge parts, including options for Japan and export, with associated part numbers and descriptions.
• Page 13 (parts_list): This page lists gauge parts for sewing machines, including part numbers, descriptions, quantities, and applicable models for Japan and export markets.
• Page 14 (diagram): This page displays diagrams of gauge parts, including components for 8-12mm and 14-16mm/18-20mm gauges, as well as parts for domestic and export use, and supply parts for single and double welting.
• Page 15 (parts_list): This page lists gauge parts with reference numbers, codes, quantities, and names in both Japanese and English, including parts for Japan standard and export.
• Page 16 (diagram): This page displays a diagram of the rotary hook mechanism, detailing various components with their corresponding reference numbers and part numbers.
• Page 17 (parts_list): This page lists parts for the H. Cam mechanism / Rotary hook mechanism, including part numbers, descriptions, and quantities.
• Page 18 (diagram): This page displays a diagram of lubrication components for an industrial sewing machine, with numbered parts and their corresponding references.
• Page 19 (parts_list): This page lists lubrication and related parts for industrial sewing machines, including part numbers, descriptions, and quantities.
• Page 21 (parts_list): This page lists lubrication parts for a sewing machine, including part numbers, descriptions, and quantities.
• Page 22 (diagram): This page displays a diagram of the threading mechanism, showing various components labeled with reference numbers and part numbers.
• Page 23 (parts_list): This page lists parts for the threading mechanism, including part numbers, descriptions, and quantities.
• Page 24 (diagram): This page displays a diagram of the L1 thread trimmer mechanism, showing various components with their corresponding reference numbers and part numbers.
• Page 25 (parts_list): This page lists parts for the thread trimmer mechanism, including part numbers, quantities, and names.
• Page 26 (diagram): This page displays a diagram of the thread trimmer mechanism, including various numbered parts and their corresponding references.
• Page 27 (parts_list): This page lists parts for the thread trimmer mechanism, including knife guides, fixed knives, thread holding plates, bolts, screws, and cylinders, with their corresponding part numbers and quantities.
• Page 28 (diagram): This page contains diagrams for the Tension release mechanism and the Motor mechanism, with numbered parts indicated for reference.
• Page 29 (parts_list): This page contains parts lists for the Tension release mechanism and the Motor mechanism, including part numbers, descriptions, and quantities.
• Page 30 (diagram): This page displays diagrams for the P. Lower thread detector mechanism (Option parts) and Q. Thread breakage detector mechanism (Option parts).
• Page 32 (diagram): This page displays a diagram of the stacker mechanism and its option parts, with various components labeled with reference numbers and part numbers.
• Page 33 (parts_list): This page lists parts for the R. Stacker mechanism (Option parts), including part numbers, descriptions, and quantities.
• Page 34 (diagram): This page displays a diagram of the stacker mechanism, including various components and their reference numbers.
• Page 35 (parts_list): This page lists parts for the R. Stacker mechanism (Option parts), including reference numbers, codes, quantities, and names of parts.
• Page 36 (diagram): This page displays a diagram of the bobbin winder mechanism, with various parts labeled with reference numbers and part numbers.
• Page 37 (parts_list): This page lists parts for the Bobbin winder mechanism, including part numbers, descriptions, and quantities.
• Page 38 (diagram): This page displays a diagram of the air pressure mechanism, illustrating various components and their connections, including solenoid valves, cylinders, and option parts.
• Page 39 (parts_list): This page lists parts for air pressure mechanism, including valve units, blanking plates, elbows, plugs, silencers, caps, and various air tubes and hoses, with their corresponding part numbers and names.
• Page 40 (diagram): This page displays a diagram of the air pressure mechanism, illustrating various components and their connections with reference numbers.
• Page 41 (parts_list): This page lists parts for air pressure mechanism, including air tubes, repeat cables, cord holders, and screws, with their corresponding codes and quantities.
• Page 42 (diagram): This page displays a diagram of the power supply equipment mechanism, detailing various components with reference numbers and some part descriptions.
• Page 43 (parts_list): This page lists parts for power supply equipment mechanism, including transformers, screws, harnesses, and other components with their respective part numbers, quantities, and descriptions.
• Page 44 (diagram): This page displays a diagram of the power supply equipment mechanism, illustrating various components with reference numbers and labels.
• Page 45 (parts_list): This page lists parts for the Power supply equipment mechanism, including part numbers, quantities, and names.
• Page 46 (diagram): This page displays a diagram of the cloth control system mechanism, detailing various parts with their corresponding numbers and references.
• Page 47 (parts_list): This page lists parts for the cloth control system mechanism, including part numbers, descriptions, quantities, and reference numbers.
• Page 48 (diagram): This page displays a diagram of the cloth control system mechanism, detailing various parts with their corresponding reference numbers and part numbers.
• Page 49 (parts_list): This page lists parts for the cloth control system mechanism, including screws, bolts, cylinders, and various plates and levers, with their corresponding codes and quantities.
• Page 50 (diagram): This page displays a diagram of the cloth control system mechanism, including various numbered parts and their corresponding part numbers.
• Page 51 (parts_list): This page lists parts for the V2 cloth control system mechanism, including flap clamps, screws, nuts, and cylinders, with their corresponding part numbers and descriptions.
• Page 52 (diagram): This page displays a diagram of the cloth control system mechanism, including various parts labeled with reference numbers and part numbers.
• Page 53 (parts_list): This page lists parts for the V2. Cloth control system mechanism (Option parts), including reference numbers, codes, quantities, and names of parts.
• Page 54 (diagram): This page contains diagrams and parts lists for the printed circuit board mechanism and the marker mechanism of an industrial sewing machine.
• Page 55 (parts_list): This page lists parts for the W. Printed circuit board mechanism and the X. Marker mechanism, including part numbers, descriptions, and quantities.
• Page 56 (diagram): This page displays a diagram of the operation panel mechanism and foot switch pedal mechanism, with various parts labeled with reference numbers and part numbers.
• Page 57 (parts_list): This page lists parts for the Operation panel mechanism and Foot switch pedal mechanism, including part numbers, descriptions, and quantities.
• Page 59 (parts_list): This page lists parts for the AB.動力台関係 / Power table section, including part numbers, descriptions, quantities, and other details.
• Page 60 (parts_list): This page lists parts for the AB.動力台関係 / Power table section, including part numbers, descriptions, and quantities.
• Page 61 (parts_list): This page contains a parts list for the Power table, including reference numbers, part codes, quantities, and names of parts.
• Page 62 (diagram): This page displays a diagram of the AC corner knife mechanism, detailing various components and their reference numbers, along with a section for optional parts.
• Page 63 (parts_list): This page lists parts for the AC Corner Knife Mechanism, including part numbers, descriptions, and quantities.
• Page 64 (diagram): This page displays a diagram of the AC corner knife mechanism, detailing various components with their respective part numbers and reference indicators.
• Page 65 (parts_list): This page lists parts for the AC Corner mechanism, including screws, bolts, washers, harnesses, and clamps, with their corresponding codes, quantities, and names.
• Page 67 (parts_list): This page lists parts for the Feed device mechanism, including reference numbers, codes, quantities, Japanese names, and English names.
• Page 68 (diagram): This page displays a diagram of the feed device mechanism for a Brother sewing machine, with various components labeled with part numbers and reference numbers.
• Page 70 (diagram): This page displays a diagram of the binder mechanism, with various parts labeled with reference numbers and part numbers.
• Page 72 (diagram): This page displays a diagram of the binder mechanism, showing various components with their corresponding part numbers and reference numbers.
• Page 73 (parts_list): This page lists parts for the AE Binder mechanism, including part numbers, descriptions, quantities, and reference numbers.
• Page 74 (diagram): This page displays a diagram of various machine parts and accessories, including components labeled with part numbers such as 30, 7.1, 7, 8, 16, 33, and a series of parts numbered in the 31- range.
• Page 75 (parts_list): This page lists accessories for the sewing machine, including needles, bobbins, thread guides, screws, and other hardware, with their corresponding part numbers and descriptions.
• Page 76 (diagram): This page displays a diagram of various accessories and optional parts for the sewing machine, including tools like wrenches and screwdrivers, as well as specialized components for specific functions.
• Page 77 (parts_list): This page lists accessories for the sewing machine, including various wrenches, screwdrivers, an oil tank assembly, an oiler, a jig, a gauge, and fuses.
• Page 78 (parts_list): This page lists gauge parts for the BAS-6150 sewing machine, including needle clamp assemblies, needle plate sets, loop guides, slide plates, binder assemblies, and ceramic corner knives, categorized by needle gauge size.
• Page 79 (parts_list): This page lists parts for the BAS-6150 gauge, including needle clamp assemblies, needle plates, loop guides, slide plates, binder assemblies, ceramic corner knives, knife base assemblies, fixed knives, N/Thread knife assemblies, and thread holding plates, with corresponding part numbers and descriptions for different needle gauges (18mm and 20mm).
• Page 81 (parts_list): This page lists gauge parts for the BAS-6150 model, including parts for 18mm and 20mm needle gauges, categorized by material type (Medium-weight materials and Light-weight materials).
• Page 82 (parts_list): This page lists various labels and their corresponding part numbers, sizes, and descriptions, including grounding labels, arrow labels, warning labels, and electrical shock warning labels.
• Page 83 (index): This page is an index listing part numbers and their corresponding page numbers in the catalog. It is organized into columns for easy reference.
• Page 84 (index): This page contains an index of parts for an industrial sewing machine, listing part codes, reference numbers, and corresponding page numbers.
• Page 85 (index): This page is an index of part numbers, listing codes, reference numbers, and corresponding page numbers for various machine parts.
• Page 86 (index): This page is an index of parts for an industrial sewing machine, listing part numbers, reference numbers, and page numbers where they can be found in the catalog.
• Page 87 (index): This page contains an index of parts for an industrial sewing machine, listing part numbers, reference numbers, and corresponding page numbers.
• Page 89 (index): This page is an index of parts for an industrial sewing machine, listing part codes, reference numbers, and page numbers.
• Page 90 (cover): This is the cover page of a Brother Industries, LTD parts book. It features the Brother logo, a graphic of a screw, and contact information for the company in Japan.

Page 1

BAS-6150 自動本縫玉縁機 AUTOMATIC LOCKSTITCH POCKET WELT SEWER パーツブック PARTS BOOK brother. jintex.in

Page 2

パーツブックご利用に際して 1 この本は、2001年11月のデータに基づいて作成されたものです。 2 部品は予告なしに設計変更される場合があります。 3 組単位で補給する部品は、「―」で補給単価で示しております。 4 部品コード欄が「*」となっている場合は、ゲージ部品一覧表(75~78ページ)でお調べください。 目 次 A. 主体関係 1 T. 空圧関係 35 B. 下軸関係 1 U. 電装部品関係 39 C. 上軸関係 3 V1. 布制御関係 43 D. 針棒駆動関係 5 V2. プリント基板関係 47 F. メン関係 7 W. マーカー関係 51 G1. ゲージ関係 9 X. 操作パネル関係 51 G2. ケース関係 11 AA. 踏板関係 53 H. カマ関係 13 AB. 動力台関係 53 J. 給油潤滑関係 15 AC. コーナース関係 55 K. 糸切り関係 19 AD. 送り装置関係 59 L1. 糸切り関係 21 AE. バインダー関係 63 L2. 糸切り関係 23 Z1. 付属部品 7 M. 糸繰り関係 25 Z2. 付属部品 73 N. モータ関係 25 Ga1. ゲージ部品一覧表 75 P. 下糸検出関係(Option Parts) 27 Ga2. ゲージ部品一覧表 77 Q. 糸切り感知関係(Option parts) 29 Wa. 警告ラベル 79 S. 糸切り関係 33 索引 80

Page 3

Notes for using this parts book 1 This book was prepared based on information available in November 2001. 2 Parts are subject to changes in design without prior notice. 3 Parts supplied as complete assemblies are circled by a dotted line: 4 If the symbol * is found in the "Parts No." column, refer to the different parts lists, gauge parts list on page 75-78. CONTENTS A. Machine body...{

Page 4

A. 主体関係 / Machine body B. 下軸関係 / Lower shaft mechanism 1 3 5-3 5-2 5-1 5-3 5-1 5-2 2-1 13 12 11 4-1 4-2 4-3 "オプション部品 / OPTION PARTS" 10 8 9 6 6-1 6-3 6-4 6-2 7-2 7-1 7 16 17 15 14 13 118-U73-305 118-U73-050

Page 5

A. 主体関係 / Machine body REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 2 113386000 1 ハリタイチメピン POSITIONING PIN 4-1 153011016 2 ミシンハリMTX190...<#16> NEEDLE, MTX190 (#16)...<#16> 4-2 153011014 2 "オプション部品" "OPTION PARTS" ミシンハリMTX190...<#14> NEEDLE, MTX190 (#14)...<#14> 4-3 153011018 2 ミシンハリMTX190...<#18> NEEDLE, MTX190 (#18)...<#18> 8 104821001 1 ゴムセン 10.5 RUBBER CAP, 10.5 9 159928000 1 ゴムセン 15 RUBBER CAP, 15 10 S52523001 1 イトリツジ・ダイ HOLDER BLOCK 11 018501636 2 ボルト 5X16 BOLT, SOCKET M5X16 12 S52486101 1 メンタ FACE PLATE 13 S39110001 3 ボルト 595-28X14 BOLT, W/SOCKET SM5.95-28X14 118-U73-050 B. 下軸関係 / Lower shaft mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S38295000 1 カマド・ダイメタル L BUSH, L;R-HOOK BASE 2-1 S48724001 1 プランジャーポンプクミ PLUNGER PUMP ASSY 3 014781032 2 アナトメシ 635-28X10 SET SCREW, SOCKET (CP) SM6.35 4 S38253001 1 シク LOWER SHAFT, TR. 5 S12445051 2 スパイラルギヤクミ A SPIRAL GEAR ASSY, A 5-1 112684001 2 トメネジ 6.35 SET SCREW, SM6.35 5-2 100251001 4 トメネジ 6.35 SET SCREW, (CP) SM6.35-40X6.5 5-3 131007001 6 トメネジ 6.35ホミ SET SCREW, (CP) SM6.35 6 S07446001 1 タマシ・クウケクミ BALL BEARING ASSY 6-1 S07447001 1 タマシ・クウケブッシュ BUSH, ;BALL BEARING 6-2 072600480 1 タマシ・クウケ6004ZZNR BALL BEARING, 6004ZZNR 6-3 148821001 1 アナトメネジ 6.35トカリ SET SCREW, SOCKET (CN) SM6.35 6-4 014771022 1 アナトメネジ 6.35ホミ SET SCREW, SOCKET (CP) SM6.35 7 S38237001 1 タイミングプーリDオケミ TIMING PULLEY SET, D 7-1 S38245051 1 タイミングプーリD TIMING PULLEY ASSY, D 7-2 158115001 1 タマシ・クウケ6204ZZNR BALL BEARING, 6204ZZNR 13 144875001 1 プランジャー PLUNGER 14 S48732001 1 プランジャー・バネ SPRING, COMPRESSION 15 112467002 1 シメネジ 6.35 SCREW, SM6.35X5 16 014771022 1 アナトメネジ 6.35ホミ SET SCREW, SOCKET (CP) SM6.35 17 148821001 1 アナトメネジ 6.35トカリ SET SCREW, SOCKET (CN) SM6.35 118-U73-305 2 jintex.in

Page 6 — C.上軸圖系 / Upper shaft mechanism

3 C.上軸圖系 / Upper shaft mechanism 10 9 8 11 6 12 7 13 2 1 17 16 14 5 21-1 21-2 22 23 21 24 25 26 27 15 28 19-1 19 30 29 18 118-U73-109 jintex.in

Page 7 — C.上軸関係 / Upper shaft mechanism

C.上軸関係 / Upper shaft mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S38270001 1 ウツシメタル BUSH, L ;U-SHAFT 2 014781032 1 アナツボミ635-28X10 SET SCREW, SOCKET (CP) SM6.35 5 S52487001 1 ウツシク UPPER SHAFT 6 S38396000 1 テンビンクランク THREAD TAKE-UP CRANK 7 100250001 1 シメネジ 7.14 SCREW, SM7.14 8 146141001 1 アナツメネジ 7.14 SET SCREW, SM7.14-28X14 9 S38398001 1 クミヒモクランク CRANKSHAFT, ;N-BAR 10 113014000 1 クミヒモフタ PUSHER 11 101706001 1 トメネジ 6.35 SET SCREW, SM6.35-40X5.5 12 100251001 1 トメネジ 6.35 SET SCREW, (CP) SM6.35-40X6.5 13 112576001 1 テンビンクランクリング RING, T/TAKE-UP CRANK 14 S38241051 1 タイミングプーリUクミ TIMING PULLEY ASSY, U 15 014771022 1 アナトメネジ 6.35×ミ SET SCREW, SOCKET (CP) SM6.35 16 016771032 1 アナトメネジ635X10 SET SCREW, SOCKET (CN) SM6.35 17 S38241100 1 タイミングベルト TIMING BELT 18 158115001 1 タマヅケ6204ZZNR BALL BEARING, 6204ZZNR 19 S57535000 1 センサトクミ SENSOR DOG ASSY 19-1 014761030 2 アナツメネジ595-28X10 SET SCREW,SOCKET(CP)SM5.95X10 21 S38404001 1 テンビンL2クミ THREAD TAKE-UP LEVER ASSY, L2 21-1 S03289001 1 クミモミ4X4 WICK, 4X4 L=40 21-2 142274101 1 ゴムセン 4.2 LUBBER CAP, 4.2 22 S07334001 1 テンビンク SHAFT, T/TAKE-UP LEVER 23 014781032 2 アナツメネジ635-28X10 SET SCREW, SOCKET (CP) SM6.35 24 S07338001 1 スライドスベリコ SLIDE BLOCK, T/TAKE-UP LEVER 25 113024000 1 クミヒモフタ PUSHER 26 S07339209 1 テンビンカバー COVER, T/TAKE-UP LEVER 27 062670512 2 ナベコ357-40X5 SCREW, PAN SM3.57-40X5 28 S52491001 1 センサトメカラー STOPPER COLLAR 29 018401036 2 アナボルト4X10 BOLT, SOCKET M4X10 30 028040246 2 バネザガネ2-4 WASHER, SPRING 2-4 118-U73-109 4 jintex.in

Page 8

D. 針棒揺動関係 / Needle bar rocking mechanism 118-U73-115 1 1-3 1-1 1-5 1-6 1-2 1-4-1 1-4-2 1-4 1-12 1-11 1-13 1-14 1-15 1-7 1-8 1-9 1-10 202 202-1 202-2 200 201 2 5

Page 9 — D.針棒揺動関係 / Needle bar rocking mechanism

D.針棒揺動関係 / Needle bar rocking mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S52495101 1 ハリボウヨウ ウシクミ ROCKER SHAFT ASSY, N-BAR 1-1 112590001 2 ハリボウ ウアンナイタ GUIDE PLATE 1-2 102731004 4 サラネジ 2.38 SCREW, FLAT SM2.38-56X4.5 1-3 S59045001 1 ハリボウ NEEDLE BAR 1-4 S29863001 1 ハリボウ ウタクネシツキ NEEDLE BAR CLAMP W/SCREW 1-4-1 112592001 1 ハリボウ ウタク NEEDLE BAR CLAMP 1-4-2 062670812 1 ナベコ3.57-40X8 SCREW, PAN SM3.57-40X8 1-5 112593001 1 ハリボウ ウクランクツト CRANK ROD, N-BAR 1-6 112721001 1 ハリボウ ウレンカンカクコマ SLIDE BLOCK 1-7 S52497001 1 メスボウ KNIFE BAR 1-8 S52498001 1 メスボウアンナイ GUIDE, K-BAR 1-9 S52499001 1 ナカメスレンカ CONNECTING ROD, B 1-10 062670812 2 ナベコ3.57-40X8 SCREW, PAN SM3.57-40X8 1-11 S52500001 1 ハリボウ ウツクミCL ROCKER SHAFT, L 1-12 014780622 1 アナトメネジ 6.35クホミ SET SCREW, SOCKET (CP) SM6.35 1-13 S52524001 1 メスボウガイド GUIDE, K-BAR 1-14 062681412 2 ナベコ437-40X14 SCREW, PAN SM4.37-40X14 1-15 025680132 2 ヒラザガネショウ4.37 WASHER, PLAIN S 4.37 2 112594051 1 ヨウト ウシクメタル BUSH, L 200 153012101 1 ヨウト ウシクストツパ STOPPER 201 014781032 1 アナクボミミ635-28X10 SET SCREW, SOCKET (CP) SM6.35 202 S09132051 1 ピンチスリーブクミ PINCH SLEEVE ASSY 202-1 152725000 1 ピンチスリーブ PINCH SLEEVE 202-2 018063022 1 アナボルト6X30 BOLT, SOCKET M6X30 118-U73-115 6 jintex.in

Page 10 — F.メス関係 / Knife mechanism

7 F.メス関係 / Knife mechanism jintex.in 118-U73-225 25 18 24 23-1 26 27 19 31 30 29 44 28-1 28-2 28-3 28 36 34 35 33 32 38 37 39 40 41 42 43 1-1 1-2 1 3 2 4 6 5 8 9 10 12 13 11 14 15 17 14 15 14

Page 11 — F.メス関係 / Knife mechanism

F.メス関係 / Knife mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S52507001 1 ヘンシンリンネツキ ECCENTRIC WHEEL W/SCREW 1-1 S52508001 1 ナカメスクウヘンシンリン DRIVING ECCENTRIC WHEEL 1-2 014771022 2 アナトメキシ6.35 SET SCREW, SOCKET (CP) SM6.35 2 S48715000 1 ウワオクリヘンシンリンカン CONNECTING ROD, ;ECCENTRIC 3 118954000 1 ニードルベアリング NEEDLE BEARING 4 S48716001 1 ウワオクリヘンシンリンクランク ECCENTRIC CRANK 5 150936001 1 スクリュー6.35 SCREW, SM6.35-28X14 6 150937101 1 カラー COLLAR 7 150938201 1 ヒンジネシ HINGE SCREW 8 151090001 1 スラストサガネ WASHER, THRUST 9 107017002 1 ナミナミサガネ WASHER, WAVE SPRING 6.45 10 110744002 1 ナット6.35 NUT, SM6.35 11 S48776000 2 ウワオクリシメクタル BUSH, ;U-FEED SHAFT 12 S52509001 1 ロツトクランク ROCKER ARM 13 S53180001 1 カラー COLLAR 14 S52512001 2 ナカメスレンカンA CONNECTING ROD, A ;I-KNIFE 15 S16350001 2 シメネジ4.37 SCREW, SM4.37 17 S52514001 1 ナカメスクトウレンカン DRIVING ROD, I-KNIFE 18 S59149001 1 メスホルター-U KNIFE HOLDER, U 19 105216001 1 シメネジ3.57 SCREW, SM3.57X7 22 S59150001 1 メスホルター-D KNIFE HOLDER, D 23 S59152001 1 ウワメスC UPPER KNIFE, C 24 S59151001 1 ナカメサオエ KNIFE SUPPORT 25 108960002 2 サラネジ3.57 SCREW, FLAT SM3.57 26 S36350001 1 セラミックコテイハ FIXED KNIFE, CERAMIC 27 148539101 2 ダンネジ2.38 SHOULDER SCREW, SM2.38 28 S52518000 1 シリンダクミ CYLINDER ASSY 28-1 S52519000 1 シリンダ16X45 CYLINDR,16X45 28-2 S53168000 1 ツキテKQ2K04M5 JOINT, KQ2K04M5 28-3 S53488000 1 ツキテ JOINT 29 S53167000 1 ナットM10 NUT, M10 30 S52520001 1 シリンダダイ CYLINDR BRACKET 31 062681212 1 ナベコ437-40X12 SCREW, PAN SM4.37-40X12 32 S32843001 2 カムコロ CAM ROLLER 33 153057102 2 オククイタンメシ SCREW, ROUND W/SOCKET SM4.37 34 S53169001 1 タマツキM5クミ JOINT ASSY, M5 35 S06994001 1 シメネジ6.35 SCREW, SM6.35 36 S52521001 1 スペーサ SPACER 37 S20849101 3 ナカメシリンダササエ CYLINDER SUPPORT 38 S5896001 1 フランジボルト6X16ホソメ BOLT, FLANGE M6X16 39 018401436 2 ナカメストツパーダイ STOPPER BRACKET, INNER KNIFE 40 018401436 2 アナボルト4X14 BOLT, SOCKET M4X14 41 028040246 2 バネサガネ2-4 WASHER, SPRING 2-4 42 025040136 2 ヒラサガネショウ4 WASHER, PLAIN S 4 43 S14874000 1 ショツクアブソーバ SHOCK ABSORBER 44 025100232 1 ヒラサガネ10 WASHER, PLAIN M 10 118-U73-225 8 jintex.in

Page 12 — G1. ゲージ関係 / Gauge parts

9 G1. ゲージ関係 / Gauge parts "オプション部品 / OPTION PARTS " <国内用 / For Japan only > 10mm <輸出用 / For Export > 12mm 3-3 1-3 4-1 1-1-1 5 7 4-3 8 9 5 7 1-2-1 6 3-2 1-2 "輸出部品 / For supply parts " 4-2 8 6 118-U73-231

Page 13 — G1.ゲージ関係 / Gauge parts

G1.ゲージ関係 / Gauge parts REF.NO CODE Q'TY ヒンメイ NAME OF PARTS RM 1-1 S59140001 1 <国内用> <For Japan only> 1-1-1 146427001 2 ハリダキ10UPクミ NEEDLE CLAMP ASSY, 10 UP 3-1 S52562001 1 アナトメネジ 3.18クホミ SET SCREW, SOCKET (CP) SM3.18 4-1 S52537001 1 ハリダキ10クミ NEEDLE PLATE ASSY, 10 ループガイド 10 LOOP GUIDE, 10 <輸出用> <For Export> 1-2 S59141001 1 ハリダキ12UPクミ NEEDLE CLAMP ASSY, 12 UP 1-2-1 146427001 2 アナトメネジ 3.18クホミ SET SCREW, SOCKET (CP) SM3.18 3-2 S52563001 1 ハリダキ12クミ NEEDLE PLATE ASSY, 12 4-2 S52538001 1 ループガイド 12 LOOP GUIDE, 12 5 S21921001 2 サラネジ 2.38X8 SCREW, FLAT SM2.38X8 7 153208002 2 シメネジ 4.37 SCREW, SM4.37-40X7 8 S52525001 1 ハリダクイト GUIDE, N-PLATE 9 153208002 2 シメネジ 4.37 SCREW, SM4.37-40X7 1-3 ※ 1 “オプション部品” "OPTION PARTS" 3-3 ※ 1 ハリダキクミ NEEDLE CLAMP ASSY 4-3 ※ 1 ハリタクミ NEEDLE PLATE ASSY ループガイド LOOP GUIDE, 10 6 ※ 1 “補給用部品” "For Supply parts" ハリイセット NEEDLE PLATE SET 118-U73-231 10 jintex.in

Page 14 — G2. ゲージ関係 / Gauge parts

G2. ゲージ関係 / Gauge parts 1-1 8-12mm 1-1-1-3 1-1-1-2 1-1-1-4 1-1-1 1-1-1-1 1-1-5 1-1-6 1-1-7 1-1-8 " オプション部品 / OPTION PARTS " 1-2 14-16mm 18-20mm 1-2-1-2 1-2-1-4 1-2-1 1-2-1-1 1-2-4 1-2-2 1-2-3 1-2-5 1-2-6 1-2-7 < 国内用 / For Japan only > 10mm 両玉縁縫い / Double welting 30 30-1 30-2 30-3 " 補給用部品 / For supply parts " 片玉縁縫い / Single welting 10 10-1 10-2 10-3 151-615-231 jintex.in 11

Page 15 — G2.ゲージ関係 / Gauge parts

G2.ゲージ関係 / Gauge parts REF.NO CODE Q'TY ヒンメイ NAME OF PARTS RM 1-1 S586750001 1 スペーリタセット8-12 SLIDE PLATE SET, 8-12 1-1-1 S534290001 1 スペーリタクミ8-12 SLIDE PLATE ASSY, 8-12 1-1-1-1 S53430001 1 スペーリタ SLIDE PLATE 1-1-1-2 S53431001 1 シテンピン PIN 1-1-1-3 004401414 1 +サラコ4X14 SCREW, FLAT M4X14 1-1-1-4 021400206 1 2シュナット4 NUT, 2 M4 1-1-2 S53432000 1 セパレータ SEPARATOR 1-1-3 S53433000 1 スペーサA SPACER, A 1-1-4 S53434000 1 スペーサB SPACER, B 1-1-5 004300513 2 +サラコ3X5 SCREW, FLAT M3X5 1-1-6 S53518001 1 イチギメカラー COLLAR 1-1-7 018300836 1 +ボルト3X8 BOLT, SOCKET M3X8 1-1-8 028030246 1 バネザガネ2-3 WASHER, SPRING 2-3 <国内用標準> <For Japan stndard> 30 S59275000 1 ジヨウキ10W-17 30-1 S59041000 1 ジヨウキWミ 30-2 S54655000 1 ジヨウキ10W-17 30-3 W01519001 5 0サラコ3シュ2X4 <輸出用> <For Export standard> 50 S59279000 1 ジヨウキ12W-21 BINDER ASSY, 12W-21 50-1 S59041000 1 ジヨウキWミ BINDER ASSY, W 50-2 S54659000 1 ジヨウキ12W-21 BINDER, 12W-21 50-3 W01519001 5 0サラコ3シュ2X4 SCREW, FLAT #0 M2X4 1-2 ※ 1 "オプション部品" "OPTION PARTS" 1-2-1 ※ 1 スペーリタセットXX-YY SLIDE PLATE SET, XX-YY 1-2-1-1 ※ 1 スペーリタクミXX-YY SLIDE PLATE ASSY, XX-YY 1-2-1-2 ※ 1 スペーリタ SLIDE PLATE 1-2-1-3 S53431001 1 シテンピン PIN 1-2-1-4 004401414 1 +サラコ4X14 SCREW, FLAT M4X14 1-2-2 021400206 1 2シュナット4 NUT, 2 M4 1-2-3 S53433000 1 スペーサA SPACER, A 1-2-4 S53434000 1 スペーサB SPACER, B 1-2-5 004300513 2 +サラコ3X5 SCREW, FLAT M3X5 1-2-6 S53518001 1 イチギメカラー COLLAR 1-2-7 018300836 1 +ボルト3X8 BOLT, SOCKET M3X8 1-2-8 028030246 1 バネザガネ2-3 WASHER, SPRING 2-3 10 ※ 1 "補給部品" "For Supply parts" 10-1 S59041000 1 ジヨウキXXW-YY BINDER ASSY, XXW-YY 10-2 ※ 1 ジヨウキWミ BINDER ASSY, W 10-3 W01519001 5 0サラコ3シュ2X4 SCREW, FLAT #0 M2X4 20 ※ 1 ジヨウキXXS-YY BINDER ASSY, XXS-YY 20-1 S59042000 1 ジヨウキSミ BINDER ASSY, S 20-2 ※ 1 ジヨウキXXS-YY BINDER ASSY, XXS-YY 20-3 W01519001 5 0サラコ3シュ2X4 SCREW, FLAT #0 M2X4 151-615-231 12 jintex.in

Page 16 — H . 力マ関係 / Rotary hook mechanism

H . 力マ関係 / Rotary hook mechanism 23-2 23-2-3 23-2-2 23-2-1 23-2-5 23-2-4 41 42 16 23-1-2 23-1-1-1 12-2 11 6-1 27 7 8 5 27-1 26 24 12-1 12-3 12-4 17 3 4 9 10 118-U73-301 13 jintex.in

Page 17 — H.カマ関係 / Rotary hook mechanism

H.カマ関係 / Rotary hook mechanism REF.NO CODE Q'TY ヒンメイ NAME OF PARTS RM 3 062782512 2 ナベコ35-28X25 SCREW, PAN SM6.35-28X25 4 100197002 2 ザガネ WASHER 5 S09259001 2 カシメジュウU BUSH, U 6-1 S09260001 2 スラストリング A THRUST RING, A ;1.2MM 6-2 S09261001 2 スラストリング B THRUST RING, B ;1.4MM 7 S07420000 2 ニードルベアリング NEEDLE BEARING 8 S07419001 2 ストップリング RETAINING RING 9 S07417001 2 カシメジュウD BUSH, D 10 013710512 2 トメネジ 4.76ホウミ SET SCREW, (CP) SM4.76-32X5 11 150967101 2 オープナーリンク OPENER LINK 12-1 S38213051 2 オープナーレバー OPENER LEVER, L 12-2 148005001 2 オープナーリンク SHAFT, O-LINK 12-3 025710232 2 ヒラザガネ 4.76 WASHER, PLAIN M 4.76 12-4 110161006 2 ナット4.76 NUT, SM4.76 16 S13021001 2 オープナーリンク SHAFT, O-LEVER 17 013711012 2 トメネジ 4.76ホウミ SET SCREW, (CP) SM4.76-32X10 23 S52675902 1 ニホンハリハマコウミ ROTARY HOOK ASSY, W/BOX 23-1-1 151027001 4 ウチカマオサエトメネジ SET SCREW 23-1-2 S09273001 2 ウチカマオサエ INNER ROTARY HOOK ASSY 23-2 S52677001 2 キャップ アサ CAP ASSY 23-2-1 155479001 2 テンションスプリング TENSION SPRING 23-2-2 151029001 2 テンションアジャスティング TENSION ADJUSTING SCREW 23-2-3 110300001 2 セットネジ SET SCREW 23-2-4 159802001 2 スクリュー, SM1.59X2 SCREW, SM1.59X2 23-2-5 S09284001 2 サイトホシイタ HOLDING PLATE, ;L-THREAD 24 S07436001 1 ギヤアンナイL GEAR GUIDE, L 25 S07437001 1 ギヤアンナイR GEAR GUIDE, R 26 108960002 4 サラネジ 3.57 SCREW, FLAT SM3.57 27 S07658001 2 ピンチスリーブ クミ PINCH SLEEVE ASSY 27-1 112700001 2 シメネジ 5.95 SCREW, SM5.95-28X32 41 S09285051 2 <標準用> ボビン <Standard parts> BOBBIN, 2 42 S09286000 2 クウテンボウシバネ SPRING, ANTI-SPIN 50 S38212001 1 オープナー OPENER 51 S38212001 1 オープナー OPENER 52 154965001 1 アナボルト3.57X8 BOLT, SOCKET SM3.57X8 53 154965001 1 アナボルト3.57X8 BOLT, SOCKET SM3.57X8 118-U73-301 14

Page 18 — J. 給油潤滑関係 / Lubrication

J. 給油潤滑関係 / Lubrication 118-U73-350 15 129-1 129-2 129-6 129-5 129-3 129-4 129-7 139 140 130 124 125 126 131 202 11 9 10 37 25 201 148 147 48 69 57 56 29 132 24 38 61 58 78 76 40 150 151 152 133 22 64 134 82 83 70 63 70 91 91 41-3 41-1 41-2 41 45 46 47 43 42 44 49 30 31 16 17 6 5 7 36 35 4 30 31 16 17 6 5 7 36 35 4 109 111 108 110 3 3 120 123 121 123 119 200-1 200-2 200-3 200-4 200-5 135 143 144 145 jintex.in

Page 19 — J.給油潤滑関係 / Lubrication

J.給油潤滑関係 / Lubrication REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 3 S38248001 8 ナベザグリ3.57X8 SCREW, PAN (S/P WASHER) SM3.57 4 S07477000 2 ゴムリング RUBBER RING 5 S07478000 2 ゴムオサエ RUBBER PRESSER 6 S38292001 2 オイルヨウセツネジナシ OIL ADJUSTING SCREW 7 S38299001 2 オイルヨウセツネジナシ OIL ADJUSTING SPRING 9 150988001 1 オイルヨウストツパープレート OIL STOPPER PLATE 10 112717001 1 ホルダ・オーストッププレート HOLDER, O-STOPPER PLATE 11 062711212 1 ヘコ476-32X12 SCREW, PAN SM4.76-32X12 16 112753001 2 フエルト FELT 17 S09043000 2 フエルト FELT 22 06270512 2 ヒモヨウセツ WICK HOLDER 23 062670512 2 ヘコ357-40X5 SCREW, PAN SM3.57-40X5 24 S5770000 3 クミヒモ4X4 WICK, L = 28 25 S5770000 3 クミヒモ4X4 WICK, L = 28 29 148394000 1 ハリボウセン CAP, N-BAR 30 140890009 5 オイルカップ OIL CAP 31 104821001 3 ゴムセン10.5 RUBBER CAP, 10.5 35 S38266000 2 カマシフエルト FELT 36 S07476000 2 フエルト FELT 37 148762001 1 テンビンフエルト FELT 38 S38269000 1 ウワジクフエルト FELT 39 S07571000 1 フエルト FELT 40 112753001 2 フエルト FELT 41 S52550001 1 オイルタンククミ OIL TANK ASSY 41-1 S52551000 1 オイルタンク OIL TANK 41-2 S07333001 2 オイルクチパイプ'S PIPE, S 41-3 S52560001 1 オイルクチパイプ'L OIL FEEDING PIPE, L 42 S52552000 1 オイルタンクフタ CAP, O-TANK 43 S52553000 1 パツキン PACKING 44 004401003 4 ザガネツキM4X10 SCREW, FLAT M4X10 45 S52560000 1 ビニールチューブ OIL TUBE, L=340 46 S52570000 1 ビニールチューブ OIL TUBE, L=580 47 S52580000 1 クミヒモ WICK, L=730 48 S52590000 1 ビニールチューブ OIL TUBE 49 152948001 1 オイルポットマド OIL WINDOW 50 013710512 1 トメネジ4.76クボミ SET SCREW, (CP) SM4.76-32X5 55 S07465000 1 クミヒモ WICK, L=200 56 112728001 1 クミヒモ WICK, L=50 57 114693001 1 クミヒモ WICK, L=30 58 112735000 1 クミヒモ WICK, L=45 58 112735000 1 クミヒモ WICK, L=45 61 S53195000 1 クミヒモ WICK 63 S38481000 2 クミヒモ WICK, L=41 64 108802001 2 クミヒモ4X4 WICK, 4X4 L=250 69 S07462000 1 クミヒモ WICK, L=25 70 S07463000 2 クミヒモ WICK, L=70 75 S38541000 2 オイルリング OIL RING 76 S48734000 1 フエルトD FELT, D 78 062671412 1 ヘコ357-40X14 SCREW, PAN SM3.57-40X14 82 S21195001 2 フエルトオサエ FELT SUPPORT 83 062670512 2 ヘコ357-40X5 SCREW, PAN SM3.57-40X5 91 S07876101 7 チューブストツパー TUBE CLIP 101 062670612 2 ヘコ357-40X6 SCREW, PAN SM3.57-40X6 108 S48737000 1 カマドダイパツキンR PACKING, R 109 S48738000 1 カマドダイパツキンL PACKING, L 110 S48739001 1 カマドダイフタR CAP, R 111 S48740000 1 カマドダイフタL CAP, L 119 S38251000 1 オイルシール OIL SEAL 120 S38261001 1 チューブトツキシ TUBE SUPPORT BRACKET, L 121 S38264001 1 オイルチューブササエ OIL TUBE SUPPORT 123 062710612 2 ヘコ476-32X6 SCREW, PAN SM4.76-32X6 118-U73-350 jintex.in 16

Page 21 — J.給油潤滑関係 / Lubrication

J.給油潤滑関係 / Lubrication REF.NO CODE Q'TY ヒンメイ NAME OF PARTS RM 124 S38292001 1 オイルヨウセツネシ OIL ADJUSTING SCREW 125 S38299001 1 オイルヨウセツハネ OIL ADJUSTING SPRING 126 S07478000 1 ゴムオサエ RUBBER PRESSER 129 S52679001 1 オイルフキタシケースクミ OIL CASE ASSY 129-1 S48763001 1 オイルフキタシケース OIL CASE 129-2 S53175000 1 フキタシチューブ L=450 OIL TUBE, L=450 129-3 S53176000 1 ビニルチューブ D OIL TUBE, D; L=355 129-4 S53177000 1 ビニルチューブ U OIL TUBE, U; L=170 129-5 S53178000 1 クミヒモ4X4 WICK, L=300 129-6 S53179000 1 ドレンチューブ DRAIN TUBE, L=300 129-7 S07469001 1 チューブ カンメ TUBE CALKING 130 060681212 2 ハインド 437-40X12 SCREW, BIND SM4.37-40X12 131 111865001 1 セン 6 CAP, 6 132 S49564002 1 ゴムセン 12.5 RUBBER CAP, 12.5 133 117934001 1 ゴムセン 13.5 RUBBER CAP, 13.5 134 S21196001 2 フエルト FELT 135 104821001 1 ゴムセン 10.5 RUBBER CAP, 10.5 139 S02606000 1 ユリヨウケイマド OIL GAUGE WINDOW 140 081014670 1 Oリング PW14 O RING, PW14 143 112758001 1 オイルフタ OIL CAP 144 S07481009 1 オイルシート OIL MARK SHEET 145 S53184001 1 オイルチューブ OIL TUBE JOINT 147 S07327001 1 コード オサエ L CORD HOLDER, L 148 062670512 1 ハコ 357-40X5 SCREW, PAN SM3.57-40X5 149 S04557000 1 バンタイPLT1M BAND, PLT1M 150 S55898000 1 フエルト FELT 151 062670612 1 ハコ 357-40X6 SCREW, PAN SM3.57-40X6 152 025040135 1 ヒラザガネショウ4 WASHER, PLAIN S 4 200 S54959001 1 キュウユターミナルクミ TERMINAL ASSY 200-1 S14189100 1 ターミナル TERMINAL 200-2 S38448000 1 ビニルチューブ OIL TUBE, L=200 200-3 S07459100 1 ビニルチューブ OIL TUBE, L=240 200-4 142274101 1 ゴムセン 4.2 RUBBER CAP, 4.2 200-5 S07464100 1 クミヒモ WICK, L=530 201 S55769000 1 クミヒモ4X4 WICK, 4X4 202 S55769000 1 クミヒモ4X4 WICK, 4X4 203 S55304000 1 クミヒモ4X4 WICK, 4X4 118-U73-350 18 jintex.in

Page 22

118-U73-401 jintex.in K. 糸通シ関係 / Threading mechanism 1 1-16 1-17 1-18 1-7 1-19 1-14 1-13 1-15 1-27 1-6 1-25 1-24 1-13-1 13-2 13 1-12 1-26 1-3 1-4 1-23 1-22 1-20 1-21 1-11 1-10 1-8 1-9 2 1-2 1-1 12-31 12-1 12-2 12-4 12 10 8 7 6 5 3 4 19

Page 23 — K.糸通し関係 / Threading mechanism

K.糸通し関係 / Threading mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S15584509 1 ウワイトチョウシクミ UPPER THREAD TENSION ASSY, D 1-1 S08604001 1 チョウシンク TENSION STUD 1-2 S08607001 1 イトトリバネ THREAD TAKE-UP SPRING, L 1-3 S08608001 1 イトトリバネ THREAD TAKE-UP SPRING, R 1-4 108254001 2 イトトリバネネアンナイグミ GUIDE ASSY, ;T/TAKE-UP SPRING 1-5 146124001 1 シメネジ 2.38 SCREW, SM2.38 1-6 108265009 1 チョウシンク TENSION NUT 1-7 158768001 2 ピン 2.6X20 PIN, 2.6X20 1-8 S07487101 1 イトトルメ TENSION RELEASE PLATE 1-9 S38274001 1 イトトルメバネ SPRING, T-RELEASE 1-10 112712001 2 ダンネジ 3.57 SHOULDER SCREW, SM3.57 1-11 S07488001 1 イトトルメ TENSION RELEASE PIN 1-12 158769001 1 イトトルメバネ TENSION RELEASE PIN, R 1-13 145446001 4 イトチョウシサラ DISC, TENSION 1-14 159805001 2 イトチョウシサラオサエ DISC PRESSER, ;TENSION 1-15 149566109 2 チョウシンクナット TENSION NUT 1-16 144504001 4 イトアンナイサラ DISC, THREAD GUIDE 1-17 154560001 2 プレテンションバネA SPRING, ;PRE-TENSION (A) 1-18 155510001 2 チョウシンクナット TENSION NUT 1-19 S07490001 2 イトチョウシバネ TENSION SPRING 1-20 112709001 1 イトトリバネネストツパ STOPPER 1-21 062670512 1 ナベコ357-40X5 SCREW, PAN SM3.57-40X5 1-22 S08605101 1 スペーサー SPACER 1-23 S08606001 1 カラー COLLAR 1-24 S08609201 1 ストツパウケ STOPPER SUPPORT 1-25 S08610101 1 チョウセツツマミ ADJUSTING THUMB 1-26 013660612 1 トメネジ 3.18ホウミ SET SCREW, (CP) SM3.18 1-27 151480001 2 マワリトメ STOPPER, ML 2 100064002 1 シメネジ 3.57 SCREW, SM3.57X8 3 112709001 1 イトトリバネネストツパ STOPPER 4 062670512 1 ナベコ357-40X5 SCREW, PAN SM3.57-40X5 5 S14677001 1 イトトルメジク TENSION RELEASE SHAFT 6 062680812 1 ナベコ357-40X8 SCREW, PAN SM3.57-40X8 7 108266001 1 アームイトアンナイM THREAD GUIDE, U ARM 8 S54023001 1 アームイトアンナイM THREAD GUIDE, M 10 108960002 3 サラネジ 3.57 SCREW, FLAT SM3.57 12 S49529001 1 アームイトアンナイDクミ THREAD GUIDE ASSY, D 12-1 S48760001 1 アームイトアンナイD THREAD GUIDE, D 12-2 S48761001 1 アームイトアンナイD THREAD CLAMP 12-3 112301001 1 ダンネジ 3.18 SHOULDER SCREW, SM3.18 12-4 S49530001 1 ハリイトアンナイオシバネ SPRING, COMPRESSION 13 S30505001 2 ミツメイトカケ THREAD RETAINER ASSY 13-1 140527001 2 ミツメイトカケ THREAD RETAINER 13-2 150553003 2 ナット5.95 NUT, SM5.95 118-U73-401 20 jintex.in

Page 24 — L1. 糸切り関係 / Thread trimmer mechanism

21 L1. 糸切り関係 / Thread trimmer mechanism 118-U73-403 30 29 31 37 36 39 38 35 33 32 34 33 32 34 28 30 42 41 42 40 47.3 48 49.1 50 46 45 44 43 44 43 46 45 44 49.1 30 48 47.3

Page 25 — L1.糸切り関係 / Thread trimmer mechanism

L1.糸切り関係 / Thread trimmer mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 28 S38419001 1 イトキリハ-R THREAD TRIMMER LEVER, R 29 S38420001 1 イトキリハ-L THREAD TRIMMER LEVER, L 30 062681212 2 ナベコ437-40X12 SCREW, PAN SM4.37-40X12 31 S07519001 2 ストツパ-ネジ 4.76 STOPPER SCREW, SM4.76 32 S07520001 2 イトキリハ-バネ SPRING, EXTENSION 33 062671412 2 ナベコ357-40X14 SCREW, PAN SM3.57-40X14 34 021670102 2 ナット1シュ3.57 NUT, 1 SM3.57 35 S07521001 1 イトキリレンカR CONNECTING ROD, R ;TR 36 S07522001 1 イトキリレンカL CONNECTING ROD, L ;TR 37 144526001 2 ダンネジ 4.37 SHOULDER SCREW, SM4.37 38 146360002 2 ボルト4.76X7 BOLT, SM4.76X7 39 025710232 2 ヒラザガネ24.76 WASHER, PLAIN M 4.76 40 S53172001 2 イトキリハレバー LEVER, KNIFE 41 120752001 2 セットカラー SET SCREW COLLAR 42 100251001 4 トメネジ 6.35 SET SCREW, (CP) SM6.35-40X6.5 43 S07524101 2 イトキリハクケ MOVABLE KNIFE BRACKET 44 062670812 4 ナベコ3.57-40X8 SCREW, PAN SM3.57-40X8 45 S07500000 2 シタホシハネ SPRING, PLATE 46 141544001 4 ナベネジ 3.18 SCREW, SM3.18-40X3 47-3 S52549001 2 イトキリハ MOVABLE KNIFE 48 148536001 4 シメネジ 4.37 SCREW, W/SOCKET SM4.37-40X4.2 49-1 S07527001 2 コテイハ FIXED KNIFE 50 148539101 2 ダンネジ 2.38 SHOULDER SCREW, SM2.38 118-U73-403 22 Jinttex.in

Page 26 — L2.糸切り関係 / Thread trimmer mechanism

L2.糸切り関係 / Thread trimmer mechanism 20 20-1 20-2 25 2-2 22 3-2 1 8 7 21 5 6 24 13 4-2 23 " オプション部品 / OPTION PARTS " 15-1 15-2 2-3 3-3 15 11 4-3 12 9 10 14 23 151-615-403 jintex.in

Page 27 — L2.糸切り関係 / Thread trimmer mechanism

L2.糸切り関係 / Thread trimmer mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S59235001 1 ウツメスカイド KNIFE GUIDE 2-2 S53494001 1 コテイハ10-12 FIXED KNIFE, 10-12 3-2 S53498001 1 ワイトメス10-12クミ N/THREAD KNIFE ASSY, 10-12 4-2 S53507001 1 イトホシイタ10-12 THREAD HOLDING PLATE, 10-12 5 S59032000 1 キジカキ GUIDE PLATE 6 018300636 2 アナホルト3X6 BOLT, SOCKET M3X6 7 S53512101 1 イトキリツケジク SETTING SHAFT 8 012500536 2 アナヒラ5X5 SET SCREW, SOCKET (FT) M5X5 9 S53513001 1 イトキリシリンダーダイ CYLINDER BASE 10 06262012 2 スクリュー、パン SM4.37-40X20 SCREW, PAN SM4.37-40X20 11 S53514001 2 エキセントリックシヤフト ECCENTRIC SHAFT 12 048060142 1 トメワシヨウクミ C6 RETAINING RING, EXTERNAL C10 13 048060142 1 トメワシヨウクミ C6 RETAINING RING, C6 14 012060636 1 アナヒラ5X6 SET SCREW, SOCKET (FT) M6X6 15 S53515001 1 シリンダークミ CYLINDER ASSY 15-1 S53516000 1 エアシリンダ 15X20 AIR CYLINDER, 15X20 15-2 S16603000 2 コウシヨウエルボ TUBE ELBOW, W/VALVE 20 S59155000 1 シリンダーグミ CYLINDER ASSY 20-1 S59156000 1 エアシリンダ 12X25 AIR CYLINDER, 12X25 20-2 S53488000 2 ツキテ JOINT 21 S59036001 1 イトキリツケダイ SETTING BASE 22 S59158001 1 イトキリカラー COLLAR 23 S53492001 1 イトホシハネ SPRING 24 012500536 1 アナヒラ5X5 SET SCREW, SOCKET (FT) M5X5 25 018301236 2 アナホルト3X12 BOLT, SOCKET M3X12 2-3 ※ 1 "オプシヨン部品" "OPTION PARTS" 3-3 ※ 1 コテイハXX-YY FIXED KNIFE, XX-YY 4-3 ※ 1 ワイトメスXX-YYクミ N/THREAD KNIFE ASSY, XX-YY 4-3 ※ 1 イトホシイタXX-YY THREAD HOLDING PLATE, XX-YY 151-615-403 24 jintex.in

Page 28

M. 糸繰メ関係 / Tension release mechanism 1-1 1-2 1-3 1 N. モータ関係 / Motor mechanism 8 10 11 1 2 4 6 7 5 4 6 7 5 12 118-U73-404 118-U73-650 25 jintex.in

Page 29 — M.糸締め関係 / Tension release mechanism N. モータ関係 / Motor mechanism

M.糸締め関係 / Tension release mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S53171000 1 シリンダアッ CYLINDER ASSY 1-1 S15097000 1 シリンダ, 10X5 CYLINDER, 10X5 1-2 S53488000 1 ツキ JOINT 1-3 S14677001 1 イトコルメシク TENSION RELEASE SHAFT 118-U73-404 N. モータ関係 / Motor mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S52493001 1 トウブモータブラケット MOTOR BRACKET, H 2 018063036 3 アナボルト6X30 BOLT, SOCKET M6X30 4 152914001 2 コロ ROLLER 5 S59357001 2 トルクスM4-20 BOLT, TORX SOCKET M4X20 6 100645003 2 サガネ WASHER 7 028040246 2 ハネサガネ2-4 WASHER, SPRING 2-4 8 S53166000 1 カップリング 14X15 COUPLING, 14X15 10 018062536 4 アナボルト6X25 BOLT, SOCKET M6X25 11 028060246 4 ハネサガネ2-6 WASHER, SPRING 2-6 12 J80869001 1 CIMモータタクミホ MOTOR ASSY, CIM 118-U73-650 26

Page 30

P. 下糸検出関係 (オプション部品) / Lower thread detector mechanism (Option parts) 1-1 1-12 1-21 1-22 1-3 1-14 1-9 1-7 1-6 1-2 1-5 1-10 1-13 1-4 1-8 1-20 1 Q. 糸切れ検知関係 (オプション部品) / Thread breakage detector mechanism (Option parts) 151-615-213 1-10 1-3 1-4 1-5 1-6 1-7 1-11 1-13 1-12 1-11 1-5 1 151-615-219 27

Page 32 — Stacker mechanism (Option parts)

R.スタッカー関係 (オプション部品) / Stacker mechanism (Option parts) 1-59-2 1-59-1 1-58 1-57 1-56 1-34 1-35 1-36 1-27 1-32 1-28 1-60 1-62 1-61 1-63 1-43 1-106 1-108 1-109 1-41 1-35 1-34 1-36 1-38 1-37 1-54 1-55 1-45 1-531-52 1-48 1-53 1-49 1-50 1-33 1-34 1-36 1-29 1-31 1-30 1-111-2 1-112 1-111-4 1-113 1-111-5 1-118 1-111-3 1-118 1-111-1 1-4 1-5 1-6 1-1 1-29 1-30 1-31 1-44-3 1-44-1 1-117 1-44-2 1-117 1-44-2 1-65 1-64 1-86 1-85 1-84 1-83 1-82 1-81 1-87 1-80 1-88 1-109 1-107 1-108 1-105 1-110 1-99 1-101 1-103 1-102 1-100 1 1-100 1-101 1-102 1-103 1-130 1-42 1-41 29 jintex.in 151-615-240

Page 33 — R.スタッカー関係(オプション部品) / Stacker mechanism (Option parts)

R.スタッカー関係(オプション部品) / Stacker mechanism (Option parts) REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S58179001 1 バー・スタッカーアッセン BAR STACKER ASSY, L 1-1 S58180001 1 スタッカーベース STACKER BASE 1-2 S54115001 1 タッププレート TAP PLATE 1-4 018108036 4 アナボルト M8X80 SCREW, SOCKET M10X80 1-5 028100246 4 バネザガネ2-10 WASHER, SPRING 2-10 1-6 025100236 4 ヒラザガネチュウ10 WASHER, PLAIN L 10 1-27 S54123001 1 コテイプレートL FIXING PLATE, L 1-28 S54122001 1 コテイプレートR FIXING PLATE, R 1-29 018100236 4 アナボルト M10X20 BOLT, SOCKET M10X20 1-30 028100246 4 バネザガネ2-10 WASHER, SPRING 2-10 1-31 025100236 4 ヒラザガネチュウ10 WASHER, PLAIN L 10 1-32 S54108001 1 シャフト L=126 SHAFT, L=126 1-33 S54117001 1 フルクラムシャフト FULCRUM SHAFT 1-34 018082036 3 アナボルト 8X20 BOLT, SOCKET M8X20 1-35 028080246 3 バネザガネ2-8 WASHER, SPRING 2-8 1-36 025080236 3 ヒラザガネチュウ8 WASHER, PLAIN M 8 1-37 018502036 1 アナボルト 5X20 BOLT, SOCKET M5X20 1-38 028050246 1 バネザガネ2-5 WASHER, SPRING 2-5 1-41 S54596000 2 セットカラー SET SCREW COLLAR 1-42 018501622 2 アナボルト 5X16 BOLT, SOCKET M5X16 1-43 S54140001 1 クランプリンク CLAMP LINK 1-44 S54137000 1 シリンダーアッシー CYLINDER ASSY 1-44-1 S54136000 1 エアシリンダー 20X100 AIR CYLINDER, 20X100 1-44-2 S53981000 2 エルボ KQL0601S ELBOW, KQL0601S 1-44-3 S54135000 1 ナックルジョイント KNUCKLE JOINT 1-45 S54118001 1 シリンダーホルダー CYLINDER HOLDER 1-46 018063036 1 アナボルト 6X30 BOLT, SOCKET M6X30 1-48 S54126001 1 エンドプレート END PLATE 1-49 S54127001 1 シャフト SHAFT 1-50 018081636 1 アナボルト 8X16 BOLT, SOCKET M8X16 1-51 028080246 1 バネザガネ2-8 WASHER, SPRING 2-8 1-52 S54120001 1 ワイパーリンク WIPER LINK 1-53 S54595000 2 ボールベアリング 6004DDUNR BALL BEARING, 6004DDUNR 1-54 048200142 1 リテイニングリングC20 RETAINING RING, EXTERNAL C20 1-55 S46191001 1 スペーサー SPACER 1-56 S54119001 1 パイプ PIPE 1-57 S54106001 2 ホルダー HOLDER 1-58 018061036 2 アナボルト 6X10 BOLT, SOCKET M6X10 1-59 S59031000 1 シリンダーアッシー CYLINDER ASSY 1-59-1 S54592000 1 エアシリンダー20X150 AIR CYLINDER, 20X150 1-59-2 S53981000 2 エルボ KQL0601S ELBOW, KQL0601S 1-60 S54594000 1 ロッドエンド ROD END 1-61 028080246 1 バネザガネ2-8 WASHER, SPRING 2-8 1-62 025080236 1 ヒラザガネチュウ8 WASHER, PLAIN M 8 1-63 021080206 1 2シュナット8 NUT, 2 M8 1-64 S58181001 1 スタッカーテーブル STACKER TABLE 1-65 S58182100 1 スタッカーゴム STACKER RUBBER 1-80 S54130001 1 コンネクティングリンク B CONNECTING LINK, B 1-81 018083036 1 アナボルト 8X30 BOLT, SOCKET M8X30 1-82 028080246 1 バネザガネ2-8 WASHER, SPRING 2-8 1-83 025080236 2 ヒラザガネチュウ8 WASHER, PLAIN M 8 1-84 021080206 1 2シュナット8 NUT, 2 M8 1-85 018064036 1 アナボルト 6X40 BOLT, SOCKET M6X40 1-86 028060246 1 バネザガネ2-6 WASHER, SPRING 2-6 1-87 025060236 2 ヒラザガネチュウ6 WASHER, PLAIN M 6 1-88 021060206 1 2シュナット6 NUT, 2 M6 1-89 S54132001 1 ガード GUARD 1-100 S54133001 2 パイプカラー PIPE COLLAR 1-101 018083036 2 アナボルト 8X30 BOLT, SOCKET M8X30 1-102 028080246 2 バネザガネ2-8 WASHER, SPRING 2-8 1-103 025080236 2 ヒラザガネチュウ8 WASHER, PLAIN M 8 151-615-240 30 jintex.in

Page 34 — R.スタッカー関係(オプション部品)/Stacker mechanism (Option parts)

R.スタッカー関係(オプション部品)/Stacker mechanism (Option parts) 1-59-2 1-59-1 1-58 1-57 1-56 1-34 1-35 1-36 1-60 1-43 1-27 1-32 1-28 1-62 1-61 1-63 1-109 1-45 1-33 1-34 1-35 1-36 1-54 1-55 1-531-52 1-48 1-53 1-49 1-50 1-111-2 1-112 1-113 1-111-4 1-111-3 1-111-5 1-118 1-118 1-111-1 1-111-5 1-30 1-29 1-31 1-30 1-4 1-5 1-6 1-1 1-44-3 1-44-1 1-117 1-44-2 1-117 1-44-2 1-109 1-107 1-108 1-105 1-99 1-65 1-64 1-86 1-85 1-84 1-83 1-82 1-81 1-110 1-101 1-102 1-103 1-100 1 1-42 1-41 1-87 1-80 1-88 1-130 1-100 1-103 1-102 1-101 1-2 1-38 1-37 31 jintex.in 151-615-240

Page 35 — R.スタッカー関係(オプション部品) / Stacker mechanism (Option parts)

R.スタッカー関係(オプション部品) / Stacker mechanism (Option parts) REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1-105 S54605000 1 ククリ CHAIN 1-106 018061236 1 アナルボルト6X12 BOLT, SOCKET M6X12 1-107 018063036 1 アナルボルト6X30 BOLT, SOCKET M6X30 1-108 028060246 2 バネザガネ2-6 WASHER, SPRING 2-6 1-109 025060236 2 ヒラザガネチュウ6 WASHER, PLAIN M 6 1-110 021060206 1 2シュナツト6 NUT, 2 M6 1-111 S58183000 1 バルブユニット2 VALVE UNIT, 2 1-111-1 S58184000 1 マニホールド,2 MANIFOLD, 2 1-111-2 S39116100 2 バルブVQZ2151S-5 VALVE, VQZ2151S-5 1-111-3 S59368000 1 コウキ7KQ2H0801S JOINT, KQ2H0801S 1-111-4 140682001 1 サイレンサ SILENCER 1-111-5 153274001 2 CAP, 1/8 1-112 0180603036 1 アナルボルト5X30 BOLT, SOCKET M5X30 1-113 028050246 2 バネザガネ2-5 WASHER, SPRING 2-5 1-117 S54602000 2 エアホース0604U035B AIR TUBE, 060U035B 1-118 S59387000 2 エアホース0604U050B AIR TUBE, 060U050B 1-130 S04557000 2 バンダイPLT1M BAND, PLT1M 12 S52991000 1 ハンスタッカーハーネスL STACKER HARNESS, L 13 S58693000 1 エアホース0806U175B AIR TUBE, 0806U175B 100 S39821000 1 コードクランプ19P7 CORD CLAMP, 19P7 101 S04557000 2 バンダイPLT1M BAND, PLT1M 151-615-240 jintex.in 32

Page 36 — S. 糸巻関係 / Bobbin winder mechanism

S. 糸巻関係 / Bobbin winder mechanism 1-24 1-22 1-23 1-20 1-19 1-18 1-17 1-25 1-3 1-16 1-9 1-8 1-15 1-10 1-11 1-33 3 1 5 4 1-6 1-7 1-5 1-4 1-29 1-21 1-1 1-30 1-27 1-28 1-2 1-14 1-13 1-12 1-31 1-32 1-26 151-615-402 33 jintex.in

Page 37 — S.糸巻関係 / Bobbin winder mechanism

S.糸巻関係 / Bobbin winder mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 152651401 1 イトマキソウチクミ BOBBIN WINDER ASSY 1-1 152356301 1 イトマキト・ダイ BOBBIN WINDER BASE 1-2 S39902001 1 イトマキモーダシイタ SUPPORT PLATE, ;B-W/MOTOR 1-3 004300513 4 +サラコ3X5 SCREW, FLAT M3X5 1-4 154024001 1 ホビンオサエ BOBBIN PRESSER 1-5 152645001 1 ホビンオサエイタ BOBBIN HOLDER 1-6 062300616 1 ナベコM3X6 SCREW, PAN M3X6 1-7 025030233 1 ヒラザガネチユウ3 WASHER, PLAIN M 3 1-8 154092001 1 イトマキツメツキ BOBBIN WINDER CLAW 1-9 014680422 2 アナトメネジ 4.37クボミ SET SCREW, SOCKET (CP) SM4.37 1-10 152361001 1 イトマキレバー LEVER, ;B-WINDER 1-11 152620001 1 イトマキダシネジ SHOULDER SCREW 1-12 111942001 1 イトマキイタ SPRING, PLATE 1-13 111943001 1 イトマキガネ WASHER 1-14 060660512 1 インド 318-40X5 SCREW, BIND SM3.18-40X5 1-15 152363001 1 スプリングツイス SPRING, TWIST A 1-16 047301042 1 スプリングピン SPRING PIN 1-17 145571101 1 イトマキアンナイイクミ GUIDE BRACKET ASSY, ;B-WINDER 1-18 145446001 2 ディスクテンション DISC, TENSION 1-19 100401001 1 イトマキテンションハネ TENSION SPRING 1-20 100135001 1 イトマキテンションナット NUT, TENSION 1-21 146197001 1 イトマキツカミ THREAD NIPPER ASSY 1-22 028040243 1 ハガネガネ2-4 WASHER, SPRING 2-4 1-23 025040233 2 ヒラザガネチユウ4 WASHER, PLAIN M 4 1-24 062401006 1 ナベコ4X10 SCREW, PAN M4X10 1-25 021400103 1 ナット1シュ4 NUT, 1 M4 1-26 S39847001 1 イトマキモーダクミ MOTOR ASSY, ;B-WINDER 1-27 S35032101 2 ネジ 2.6X5.5 SCREW, M2.6X5.5 1-28 028260242 2 ハガネガネ2-2.6 WASHER, SPRING 2-2.6 1-29 S39901001 1 イトマキシャフト SHAFT, ;B-WINDER 1-30 014300332 2 アナトメネジ3X3 SET SCREW, SOCKET (CP) M3X3 1-31 152364001 2 カラー COLLAR 1-32 158597001 1 イトマキストツパー STOPPER, ;B-WINDER 2 032311306 5 +プロテクタ0.5A PROTECTOR, 0.5A 3 S52459000 1 +マルモクネジ3.1X13 WOOD SCREW, ROUND M3.1X13 4 S52460000 1 イトマキハーネス BOBBIN WINDER HARNESS 5 0A5400805 1 +アースセン110 GROUND WIRE +ナベサク4X8DB SCREW, PAN (S/P WASHER) M4X8 151-615-402 34 jintex.in

Page 38 — T. 空圧関係 / Air pressure mechanism

T. 空圧関係 / Air pressure mechanism 1 1-1 1-2 1-3 1-7 1-2 1-5 1-61-4 1-5 26 25 25 26 3 4 18 2-5 2-4 26 25 35 24 22 33 36 23 21 34 56 39 37 45 48 40 38 52 53 55 51 2-1 2-2 2-5 2-3 57 35 36 23 24 75 72 73 74 70 71 78 77 76 <スタッカーなし用 / For without stacker > 13 2 43 47 40 39 38 79 37 57 56 5-3 5-2 5-4 5-5 6 5-1 20 "オプション部品 / OPTION PARTS " 9-5-0 9-4 9-1 9-3 9-2 9 35 151-615-514 jintex.in

Page 39 — T.空気関係 / Air pressure mechanism

T.空気関係 / Air pressure mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S55571001 1 バルブ・ユニット10 VALVE UNIT, 10 1-1 S39116100 3 バルブ VQZ2151S-5 VALVE, VQZ2151S-5 1-2 S39115100 3 バルブ VQZ2151S-5 VALVE, VQZ2151S-5 1-3 S53982000 1 ブランキング・プレートクレミ BLANKING PLATE 1-4 S53981000 1 エルボ KQL0601S ELBOW, KQL0601S 1-5 S53983000 3 プラグ・4 PLUG, 4 1-6 140682001 1 サイレンサ SILENCER 1-7 153274001 2 1/8トマトセン CAP, 1/8 2 S55300101 1 バルブ・ユニット7 VALVE UNIT, 7 2-1 S39115100 4 バルブ VQZ2151S-5 VALVE, VQZ2151S-5 2-2 S53982000 3 ブランキング・プレートクレミ BLANKING PLATE ASSY 2-3 S59372000 1 エルボ KQL0601S ELBOW, KQL0601S 2-4 140682001 1 サイレンサ SILENCER 2-5 153274001 2 1/8トマトセン CAP, 1/8 3 018503036 2 アナルボルト 5X30 BOLT, SOCKET MEX30 4 028050246 2 ワッシャー・スプリング 2-5 WASHER, SPRING 2-5 5 S56868000 1 フィルターレギュレータークレミ FILTER REGULATOR ASSY 5-1 S09231000 1 ボールバルブ 1/4 BALL VALVE, 1/4 5-2 153252000 1 PT-ジョイント PT-JOINT 5-3 S56869000 1 プレミング・モジュールクレミ PLUMBING MODULE ASSY 5-4 S59219000 1 ハーフユニオン 08-PT1/4 HALE UNION, ;KQ2H08-02S 5-5 S53985000 1 プラグ・8 PLUG, 8 6 S55484001 2 アナルボルトサクミ5X10 SCREW, SOCKET (S/P W) M5X10 <オプション部品> <OPTION PARTS> 9 S59217000 1 エアガン クミ AIR GUN ASSY 9-1 S59218000 1 エアガン AIR GUN 9-2 S59219000 1 ハーフユニオン 08-PT1/4 HALE UNION, ;KQ2H08-02S 9-3 S59220000 1 リウレタンコイルチューブ AIR TUBE, COIL ;TCU0805B 9-4 S12506000 1 エアガンフック AIR GUN HOOK 9-5 008400604 2 トラスコ4X6 SCREW, TRUSS M4X6 13 <スタッカーなし用> <For without stacker> S53985000 1 プラグ・8 PLUG, 8 18 <オプション部品/フラップ用> <OPTION PARTS/ For flap clamp> S39116100 2 バルブ VQZ2151S-5 VALVE, VQZ2151S-5 20 149796001 1 ゴムホースカナクツキ AIR HOSE, W/CONNECTOR 21 S53960000 1 エアーホース0425U045B1 AIR TUBE, 0425U045B1 22 S53961000 1 エアーホース0425U045B2 AIR TUBE, 0425U045B2 23 S53962000 1 エアーホース0425U025B AIR TUBE, 0425U025B 24 S53963000 1 エアーホース0425U026B AIR TUBE, 0425U026B 25 S58039000 2 エアーホース0425S024B AIR TUBE, 0425S024B 26 S58040000 2 エアーホース0425S028B AIR TUBE, 0425S028B 33 <オプション部品/フラップ用> <OPTION PARTS/ For flap clamp> S53958000 1 エアーホース0425U050B1 AIR TUBE, 0425U050B1 34 S53959000 1 エアーホース0425U050B2 AIR TUBE, 0425U050B2 35 S53964000 1 エアーホース0425U032B AIR TUBE, 0425U032B 36 S53965000 1 エアーホース0425U030B AIR TUBE, 0425U030B 37 S58037000 1 エアーホース0604U128B AIR TUBE, 0604U128B 38 S58038000 1 エアーホース0604U146B AIR TUBE, 0604U146B 39 S58035000 1 エアーホース0604U091B AIR TUBE, 0604U091B 40 S58036000 1 エアーホース0604U103B AIR TUBE, 0604U103B 43 S53952000 1 エアーホース0425S115B AIR TUBE, 0425S115B 45 S58034000 1 エアーホース0425S123B AIR TUBE, 0425S123B 47 S55010000 1 エアーホース0425S066B AIR TUBE, 0425S066B 48 S55010000 1 エアーホース0425S070B AIR TUBE, 0425S070B 49 S53951000 1 エアーホース0425S107B AIR TUBE, 0425S107B 151-615-514 36 jintex.in

Page 40

T . 空圧関係 / Air pressure mechanism 1 1-1 1-2 1-3 1-5 1-6 1-7 54 50 49 43 47 39 37 45 48 40 38 52 53 55 51 2 2-1 2-2 2-5 2-4 2-3 3 4 18 26 25 25 26 26 25 35 24 22 33 21 22 34 33 23 21 35 36 23 24 57 56 57 5-1 5-2 5-3 5-4 5-5 6 20 "オプション部品 / OPTION PARTS " 9-1 9-2 9-3 9-4 9-5 9 13 <スタッカーなし用 / For without stacker > 75 76 71 70 74 72 73 77 78 151-615-514 37 jintex.in

Page 41 — T.空圧関係 / Air pressure mechanism

T.空圧関係 / Air pressure mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 50 S55013000 1 エアホース0424S088B AIR TUBE, 0424S088B 51 S53954000 1 エアホース0425S110B AIR TUBE, 0254S110B 52 S53952000 1 エアホース0425S115B AIR TUBE, 0425S115B 53 S54614000 1 エアホース0425S122B AIR TUBE, 0425S122B 54 S54615000 1 エアホース0425S125B AIR TUBE, 0425S125B 55 S54615000 1 エアホース0425S125B AIR TUBE, 0425S125B 56 S53973000 1 エアホース0604S051B AIR TUBE, 0604S051B 57 S54104000 1 エアホース0604U190B AIR TUBE, 0604U190B 70 S52973000 3 リピートタイRF100 REPEAT CABLE TIE, RF100 71 S04557000 1 バンドPLT1M BAND, PLT1M 72 149287000 1 ナイロンクランプ CORD HOLDER, 7N 73 55290000 1 コードホルダ #14 CORD HOLDER, 14N 74 552581000 1 コードホルダ 24 CORD HOLDER, 24N 75 0A5401005 3 ナベザクルミ4X10DB SCREW, PAN (S/P WASHER) M4X10 76 S39821000 2 コードクランプ 19P7 CORD CLAMP, 19P7 77 S10859001 3 クランプ CLAMP 78 002300603 3 ナベコ 3X6 SCREW, PAN M3X6 79 S55303000 1 スパイラル80S SPIRAL, 80S 151-615-514 38 jintex.in

Page 42 — U. 電装品関係 / Power supply equipment mechanism

U. 電装品関係 / Power supply equipment mechanism 29 12 20 1 7 5 47 45 44 45 44 46 71 72 33 34 35 30 31 10 13 11 12 16 39 38 14 15 5-1 < 三相200V, 220V, 380V, 400V, 415V用 / For "3-pahse 200V AC, 220V AC, 380V AC, 400V AC & 415V AC" > 5-2 < 単相220V用 / For "2-pahse 220V AC" > 7-1 < 200V, 220V用 / For "200V AC & 220V AC" > 7-2 < 380V, 400V, 415V用 / For "380V AC, 400V AC & 415V AC" > 32 29 75 1 2 17 19 18 21 20 25 26 43 76 24 23 74 27 28 48 8 47 70 42 40 41 73 39 151-615-515 jintex.in

Page 43 — U.電装部品関係 / Power supply equipment mechanism

U.電装部品関係 / Power supply equipment mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S52760000 1 トランス TRANSFORMER, 1.4KVA 2 S55476001 4 アサボルトザクミ6X12 BOLT, SOCKET(S/P WASHER)M6X12 5-1 S52472001 1 <3相200V, 220V, 380V, 400V, 415V用> デンゲンSW3Pクミ <For "3-phase 200V AC, 220V AC, 380V AC, 400V AC & 415V AC"> POWER SUPPLY SWITCH ASSY, 3P 5-2 S52968001 1 <単相220V用> デンゲンSW2Pクミ <For "Single phase 220V AC"> POWER SUPPLY SWITCH ASSY, 2P 6 0A5400805 2 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 7-1 S47900000 1 <200V, 220V用> ブレーカーM10A <For "200V AC & 220V AC"> BREAKER, M;10A 7-2 S52437000 1 <380V, 400V, 415V用> ブレーカーM5A <For "380V AC, 400V AC & 415V AC"> BRAEKER, M ;5A 8 S52727000 1 タンシカパー TERMINAL COVER 9 S52475000 1 ブレーカーNFハーネス HARNESS, BR-NF 10 S40620000 1 セツテイングプレート SETTING PLATE, PCB 11 0A5400805 2 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 12 S40616001 1 ノイズフィルタEMCクミ NOISE FILTER ASSY, EMC 13 0A5400805 2 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 14 S52478000 1 グラウンドワイヤPE GROUND WIRE, PE 15 0A5400805 1 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 16 S52476000 1 NF-Tハーネス HARNESS, NF-T 17 S52439000 1 AVRハーネス HARNESS, T-AVR 18 S52440000 1 T-PハーネスA PCB HARNESS, A T-P/PCB 19 S52441000 1 T-PハーネスB PCB HARNESS, B T-P/PCB 20 S46738000 1 スイツチングデンゲン POWER SUPPLY, SWITCHING 21 0A5300805 2 +ナベザクミ3X8DB SCREW, PAN (S/P WASHER) M3X8 23 S00554000 7 サポート6NS SUPPORT, 6NS 24 S38110000 2 サポート6S SUPPORT, 6S 25 S52443000 1 メインパワーハーネス POWER SUPPLY HARNESS, P-M/PCB 26 S52444000 1 インバーターハーネス INVERTER HARNESS, P-M/PCB 27 S52457000 1 フットSWハーネス FOOT SW HARNESS, M/PCB-BOX 28 0A5400805 1 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 29 S52952001 1 サーボアンプ62Xクミ SERVO AMPLIFIER ASSY, 62X 30 018061436 2 アナホルト6X14 BOLT, SOCKET M6X14 31 028060246 2 ワッシャー、スプリング2-6 WASHER, SPRING 2-6 32 S52442000 1 サーボパワーハーネス SERVO POWER HARNESS, T-AMP 33 S52445000 1 サーボハーネス SERVO HARNESS, M/PCB-AMP 34 S52447000 1 エンコーダーハーネス ENCODER HARNESS, AMP-MOT 35 S52448000 1 モータパワーハーネス M/POWER HARNESS, AMP-MOT 36 S52446000 1 ミシンモーターパワーハーネス MOTOR POWER HARNESS, P/PCB-MOT 37 0A5401005 1 +ナベザクミ4X10DB SCREW, PAN (S/P WASHER) M4X10 38 S52908000 1 コードホルダ #14 CORD HOLDER, 14N 39 0A5401005 1 +ナベザクミ4X10DB SCREW, PAN (S/P WASHER) M4X10 40 S52732000 1 アースセン1600 GROUND WIRE, L=1600 41 S52733000 2 アースセン1600 GROUND WIRE, L=1050 42 0A5400805 4 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 43 S52450000 1 メインバルブハーネス MAIN VALVE HARNESS 44 S12463001 2 センサPCBアッシー1 SENSOR PCB ASSY, 1 45 0A4300605 2 +ナベザクミ3X6DA SCREW, PAN (S/P WASHER) M3X6 46 S52449000 1 M/センサーハーネス M/SENSOR HARNESS, CYC-M/PCB 47 S52744000 1 スイッチA222E-M-11 SWITCH, A222E-M-11 48 S52461000 1 EMSWハーネス EM/SW HARNESS, EM/SW-M/PCB 70 S00480000 2 コードホルダ #5 CORD HOLDER, 5N 71 552907000 1 コードホルダ #10 CORD HOLDER, 10N 72 0A5401005 3 +ナベザクミ4X10DB SCREW, PAN (S/P WASHER) M4X10 151-615-515 jintex.in 40

Page 44 — U. 電装品関係 / Power supply equipment mechanism

U. 電装品関係 / Power supply equipment mechanism 45 44 45 29 12 20 7 5 47 46 71 72 33 34 35 30 31 10 13 9 11 12 16 39 38 14 15 5-1 < 三相200V, 220V, 380V, 400V, 415V用 / For "3-pahse 200V AC, 220V AC, 380V AC, 400V AC & 415V AC" > 5-2 < 単相220V用 / For "2-pahse 220V AC" > 6 32 29 75 1 17 7-1 < 200V, 220V用 / For "200V AC & 220V AC" > 7-2 < 380V, 400V, 415V用 / For "380V AC, 400V AC & 415V AC" > 43 76 24 23 74 27 28 19 18 21 20 25 26 8 48 47 42 40 41 73 70 72 41 151-615-515 jintex.in

Page 45 — U.電装部品関係 / Power supply equipment mechanism

U.電装部品関係 / Power supply equipment mechanism REF.NO CODE Q'TY ヒンメイ NAME OF PARTS RM 73 149287000 1 ナイロンクランプ CORD HOLDER, 7N 74 S09141000 6 コードクランプ 16L CORD CLAMP, 16-L 75 S09142000 1 コードクランプ 20L CORD CLAMP, 20-L 76 S31760000 4 CKSクランプ 26L CORD CLAMP, 26-L 151-615-515 42 jintex.in

Page 46 — V1. 布制御関係 / Cloth control system mechanism

43 V1. 布制御関係 / Cloth control system mechanism 1-2-22-3 1-2-22-1 1-2-22 1-2-13 1-2-14 1-2-15 1-2-16 1-2-19 1-2-12 1-2-23 1-2-20 1-2-24 1-2-21 1-2-26 1-2-27 1-2-4 1-2-10 1-2-8 1-2-9 1-2-11 1-2-18 1-2-17 1-2-30 1-2-29 1-2-31 1-2-34 1-2-35 1-2-33-1 1-2-33 1-2-32 3 1-2-2 1-2-3 1-2-1 2-6 1-2 1-1-24 1-1-27 1-1-26 1-1-29 1-1-30 1-1-11 1-1-16 1-1-15 1-1-12 1-1-14 1-1-13 1-1-19 1-1-21 1-1-23 1-1-28 1-1-18 1-1-17 1-1-33 1-1-33-1 1-1-35 1-1-34 2-1~2-5 " オプション部品 / OPTION PARTS " 1-1-10 1-1-8 1-1-9 1-1-2 1-1-1 1-1-3 1-1-5 1-1-6 1-1-7 1-1-4 1-1-32 1 jintex.in 151-615-516

Page 47 — V1.布制御関係 / Cloth control system mechanism

V1.布制御関係 / Cloth control system mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S53531000 1 オオサエ220クミ CARRIAGE FEED ASSY, 220 1-1 S53532001 1 オオサエ220Rクミ CARRIAGE FEED ASSY, R-220 1-1-1 S53558001 1 オオサエレバー-Rクミ CARRIAGE FEED LEVER ASSY, R 1-1-2 S53564001 1 オサウテツキテ COUPLING 1-1-3 012060636 1 アテヒラ6X6 SET SCREW, SOCKET (FT) M6X6 1-1-4 S53533001 1 オオサエトリツケレバー-R SETTING LEVER, R 1-1-5 018062036 2 アホホルト6X20 BOLT, SOCKET M6X20 1-1-6 028060246 2 バネザガネ2-6 WASHER, SPRING 2-6 1-1-7 025060236 2 ヒラザガネチュウ6 WASHER, PLAIN M 6 1-1-8 S53534100 1 オオサエハネ CARRIAGE FEED SPRING 1-1-9 008400604 2 +トラスコ4X6 SCREW, TRUSS M4X6 1-1-10 S53535001 1 ダンネジ6.35 SHOULDER SCREW, SM6.35 1-1-11 S53536001 1 オオサエハネ CARRIAGE FEED, R 1-1-12 S53537001 1 シノタイ SUPPORT BRACKET 1-1-13 018501236 2 アホホルト5X12 BOLT, SOCKET M5X12 1-1-14 028050246 2 バネザガネ2-5 WASHER, SPRING 2-5 1-1-15 S53538101 1 ストツパー STOPPER & POSITIONING PLATE 1-1-16 060400812 2 ハインドM4X8 SCREW, BIND M4X8 1-1-17 S53539001 1 カラー COLLAR 1-1-18 S58204001 1 カラーオサエネジ SCREW, COLLAR PRESS 1-1-19 S53540001 1 シリンダータイ CYLINDER BASE 1-1-20 115503001 1 シメネジ4.37 SCREW, SM4.37 1-1-21 018501036 1 アホホルト5X10 BOLT, SOCKET M5X10 1-1-22 S53541000 1 シリンダーアッシー CYLINDER ASSY 1-1-22-1 S14666000 1 シリンダ 16X20 CYLINDER, 16X20 1-1-22-2 S12150000 1 チューブエルボM-5HL-4 TUBE ELBOW, M-5HL-4 1-1-22-3 S11433000 1 ホースニツプル4M5 HOSE NIPPLE, 4M5 1-1-23 S53543001 1 リンクレバーツキテ JOINT 1-1-24 S53544001 1 ピン002 PIN, 002 1-1-25 048025342 1 トメワE2.5 RETAINING RING, E2.5 1-1-26 S53545001 1 リンクレバー LINK LEVER 1-1-27 002300603 1 +ナベコ3X6 SCREW, PAN M3X6 1-1-28 S53546001 1 オリコミタリンクジク LINK SHAFT 1-1-29 S53547001 4 リンクオサエタ HOLDER PLATE 1-1-30 S31258001 4 +サラコ4X6 SCREW, FLAT M4X6 1-1-31 S53548000 4 バネオサエタケミ SPRING HOLDER PLATE ASSY 1-1-32 008300604 4 トラスコ3X6 SCREW, TRUSS M3X6 1-1-33 S55454001 1 オリコミタプレートRクミ FOLDING PLATE ASSY, R 1-1-33-1 S57533000 1 リフレクテイングシート REFLECTING SHEET 1-1-34 S53552000 2 レンケイタイハネ SPRING, PLATE 1-1-35 S53553000 2 リンクオサエハネ SPRING, PLATE 1-2 S53554001 1 オオサエ220Lクミ CARRIAGE FEED ASSY, L-220 1-2-1 S53562001 1 オオサエレバー-Lクミ CARRIAGE FEED LEVER ASSY, L 1-2-2 S53564001 1 オサウテツキテ COUPLING 1-2-3 012060636 1 アテヒラ6X6 SET SCREW, SOCKET (FT) M6X6 1-2-4 S53555001 1 オオサエトリツケレバー-L SETTING LEVER, L 1-2-5 018062036 2 アホホルト6X20 BOLT, SOCKET M6X20 1-2-6 028060246 2 バネザガネ2-6 WASHER, SPRING 2-6 1-2-7 025060236 2 ヒラザガネチュウ6 WASHER, PLAIN M 6 1-2-8 S53534100 1 オオサエハネ CARRIAGE FEED SPRING 1-2-9 008400604 2 +トラスコ4X6 SCREW, TRUSS M4X6 1-2-10 S53535001 1 ダンネジ6.35 SHOULDER SCREW, SM6.35 1-2-11 S53536001 1 オオサエL CARRIAGE FEED, L 1-2-12 S53537001 1 シノタイ SUPPORT BRACKET 1-2-13 018501236 2 アホホルト5X12 BOLT, SOCKET M5X12 1-2-14 028050246 2 バネザガネ2-5 WASHER, SPRING 2-5 1-2-15 S53538101 1 ストツパー STOPPER & POSITIONING PLATE 1-2-16 060400812 2 ハインドM4X8 SCREW, BIND M4X8 1-2-17 S53539001 1 カラー COLLAR 1-2-18 S58204001 1 カラーオサエネジ SCREW, COLLAR PRESS 1-19 S53540001 1 シリンダータイ CYLINDER BASE 151-615-516 44 Jintex.in

Page 48

V1. 布制御関係 / Cloth control system mechanism 45 1-2-22-3 1-2-22-1 1-2-22 1-2-22-2 1-2-13 1-2-14 1-2-12 1-2-19 1-2-15 1-2-16 1-2-21 1-2-24 1-2-4 1-2-10 1-2-8 1-2-9 1-2-30 1-2-29 1-2-17 1-2-18 2-6 3 1-2-11 1-2-33 1-2-33-1 1-2-32 151-615-516 1-2-2 1-2-3 1-2-1 1-2-5 1-2-6 1-2-7 1-2-23 1-2-20 1-1-24 1-1-27 1-1-26 1-1-28 1-1-29 1-1-30 1-1-11 1-1-18 1-1-17 1-1-15 1-1-12 1-1-13 1-1-14 1-1-23 1-1-21 1-1-19 1-1-20 1-1-16 1-1-1-22 1-1-22-1 1-1-22-2 1-1-22-3 1-1-1 1-1-2 1-1-3 1-1-4 1-1-8 1-1-9 1-1-10 1-1-5 1-1-6 1-1-7 1-1-32 1-1-33 1-1-33-1 1-1-31 1-1-34 1-1-35 2-1~2-5 "オプション部品" / OPTION PARTS " 5

Page 49 — V1.布制御関係 / Cloth control system mechanism

V1.布制御関係 / Cloth control system mechanism REF. NO CODE QTY ヒンメイ NAME OF PARTS RM 1-2-20 115503001 1 シメネジ 4.37 SCREW, SM4.37 1-2-21 018501036 1 アナルボルト 5X10 BOLT, SOCKET M5X10 1-2-22 S3541000 1 シリンダー CYLINDER ASSY 1-2-22-1 S14666000 1 シリンダー 16X20 CYLINDER, 16X20 1-2-22-2 S12150000 1 ホースエルボ M-5HL-4 TUBE ELBOW, M-5HL-4 1-2-22-3 S11433000 1 ホースニップル 4M5 HOSE NIPPLE, 4M5 1-2-23 S3543001 1 リンクレバーギテ JOINT 1-2-24 S3544001 1 ピン 002 PIN, 002 1-2-25 048025342 1 トメワE2.5 RETAINING RING, E2.5 1-2-26 S3545001 1 リンクレバー LINK LEVER 1-2-27 002300603 1 ナベコ 3X6 SCREW, PAN M3X6 1-2-28 S3546001 1 オリコミリンクリンク LINK SHAFT 1-2-29 S3547001 4 リンクオサエイタ HOLDER PLATE 1-2-30 S31258001 4 +サラコ 4X6 SCREW, FLAT M4X6 1-2-31 S35480000 2 ハネオサエイタクミ SPRING HOLDER PLATE ASSY 1-2-32 008300604 4 +トラスコ 3X6 SCREW, TRUSS M3X6 1-2-33 S5455001 1 オリコミイタLクミ FOLDING PLATE ASSY, L 1-2-33-1 S5753000 1 ハンシャシート REFLECTING SHEET 1-2-34 S3552000 2 リンクイタハネ SPRING, PLATE 1-2-35 S3553000 2 リンクイタハネ SPRING, PLATE 2-1 S56006000 2 <オプション部品> <OPTION PARTS> オオサエゴムAクミ CARRIAGE FEED RUBBER ASSY, A 2-2 S56007000 2 オオサエゴムBクミ CARRIAGE FEED RUBBER ASSY, B 2-3 S56008000 2 オオサエゴム1.5クミ CARRIAGE FEED RUBBER ASSY, 1.5 2-4 S56009000 2 オオサエゴム2クミ CARRIAGE FEED RUBBER ASSY, 2 2-5 S56010000 2 オオサエゴム3クミ CARRIAGE FEED RUBBER ASSY3 2-6 S58903000 2 オオサエゴムCクミ CARRIAGE FEED RUBBER ASSY, C 3 S58900006 6 セイイッタイ M2 SCREW, M2 151-615-516 46 jintex.in

Page 50 — V2. 布制御関係(オプション部品)/ Cloth control system mechanism (Option parts)

47 V2. 布制御関係(オプション部品)/ Cloth control system mechanism (Option parts) 101 106 101 102 111 110 109 108106 111 110 109 120 121 122 151-615-516 50 51 51-8 51-11 51-10-2 51-10-1 51-9 51-7 51-13 51-12 51-14 51-6 51-16 51-18 51-17 51-15 51-19 51-21 51-2 51-3 51-4 51-1 51-20 51-22 51-23 51-24 50-8 50-7 50-10-3 50-10-2 50-9 50-10 50-12 50-11 50-18 50-14 50-17 50-16 50-15 50-6 50-13 50-1 50-3 50-4 50-20 50-19 50-1 50-2 50-21 50-22 50-23 50-10-1 50-5 100 103 104 105

Page 51 — V2.布制御関係(オプション部品)/ Cloth control system mechanism (Option parts)

V2.布制御関係(オプション部品)/ Cloth control system mechanism (Option parts) REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 50 S3565000 1 フラップオサエRクミ FLAP CLAMP ASSY, R 50-1 S3566000 1 オオサエホシヨイタ AUXILIARY PLATE 50-2 008400604 5 +トラスコ4X6 SCREW, TRUSS M4X6 50-3 S3567001 1 フラツプシテンシク FULCRUM SHAFT 50-4 S3568001 1 ウラナットM5 NUT PLATE, M5 50-5 004501606 2 +サラコ5X16 SCREW, FLAT M5X16 50-6 S3569001 1 フラツプオサエR FLAP CLAMP, R 50-7 S3540001 1 シリンダーダイ CYLINDER BASE 50-8 115503001 1 シメネジ 4.37 SCREW, SM4.37 50-9 018501036 1 アナホルト5X10 BOLT, SOCKET M5X10 50-10 S3541000 1 シリンダーアツミ CYLINDER ASSY 50-10-1 S14666000 1 シリンダー 16X20 CYLINDER, 16X20 50-10-2 S12150000 1 ホースエルボ M-5HL-4 TUBE ELBOW, M-5HL-4 50-10-3 S3542000 1 キツテM5H4 JOINT, W/SCREW M5 50-11 S3571001 1 シリンダツキテ JOINT 50-12 S3572001 1 タンネジ SHOULDER SCREW, M5 50-13 021500216 1 シュナツト5 NUT, 2 M5 50-14 S3573001 1 フラツプオサエブレード A FLAP CLAMP BLADE, A 50-15 S3574000 1 フラツプオサエブレード B FLAP CLAMP BLADE, B 50-16 S3575001 1 フラツプオサエブレード C FLAP CLAMP BLADE, C 50-17 S3598000 1 フラツプオサエスボンジ SPONGE, 258X8X3 50-18 008300604 4 +トラスコ3X6 SCREW, TRUSS M3X6 50-19 S3576001 2 スタツト 8 STUD, 8 W/SCREW M5 50-20 021500216 2 シュナツト5 NUT, 2 M5 50-21 S3577000 1 フラツプゲージクミ FLAP GAUGE ASSY 50-22 S3580001 2 フラツプストツパー FLAP STOPPER 50-23 002300603 2 +ナベコ3X6 SCREW, PAN M3X6 51 S3581000 1 フラツプオサエLクミ FLAP CLAMP ASSY, L 51-1 S3566000 1 オオサエホシヨイタ AUXILIARY PLATE 51-2 008400604 5 +トラスコ4X6 SCREW, TRUSS M4X6 51-3 S3567001 1 フラツプシテンシク FULCRUM SHAFT 51-4 S3568001 1 ウラナットM5 NUT PLATE, M5 51-5 004501606 2 +サラコ5X16 SCREW, FLAT M5X16 51-6 S3582001 1 フラツプオサエL FLAP CLAMP, L 51-7 S3540001 1 シリンダーダイ CYLINDER BASE 51-8 115503001 1 シメネジ 4.37 SCREW, SM4.37 51-9 018501036 1 アナホルト5X10 BOLT, SOCKET M5X10 51-10 S3541000 1 シリンダーアツミ CYLINDER ASSY 51-10-1 S14666000 1 シリンダー 16X20 CYLINDER, 16X20 51-10-2 S12150000 1 ホースエルボ M-5HL-4 TUBE ELBOW, M-5HL-4 51-11 S3542000 1 キツテM5H4 JOINT, W/SCREW M5 51-12 S3571001 1 シリンダツキテ JOINT 51-13 S3572001 1 タンネジ SHOULDER SCREW, M5 51-14 021500216 1 シュナツト5 NUT, 2 M5 51-15 S3573001 1 フラツプオサエブレード A FLAP CLAMP BLADE, A 51-16 S3574000 1 フラツプオサエブレード B FLAP CLAMP BLADE, B 51-17 S3575001 1 フラツプオサエブレード C FLAP CLAMP BLADE, C 51-18 S3598000 1 フラツプオサエスボンジ SPONGE, 258X8X3 51-19 008300604 4 +トラスコ3X6 SCREW, TRUSS M3X6 51-20 S3576001 2 スタツト 8 STUD, 8 W/SCREW M5 51-21 021500216 2 シュナツト5 NUT, 2 M5 51-22 S3577000 1 フラツプゲージクミ FLAP GAUGE ASSY 51-23 S3580001 2 フラツプストツパー FLAP STOPPER 51-24 002300603 2 +ナベコ3X6 SCREW, PAN M3X6 100 S2454000 1 フラツプセンサ FLAP SENSOR 101 S2961000 2 アイバFD-G4 FIBER, FD-G4 102 S2962000 2 サイトレンズFX-MR5 SIDE LENS 103 S2965001 1 DINレール75 DIN RAIL, 75 104 008400604 2 +トラスコ4X6 SCREW, TRUSS M4X6 105 S3588000 2 スパイラル720SS SPIRAL, 720SS 106 002300603 4 +ナベコ3X6 SCREW, PAN M3X6 151-615-516 48 jintex.in

Page 52 — V2. 布制制御関係 (オプション部品) / Cloth control system mechanism (Option parts)

V2. 布制制御関係 (オプション部品) / Cloth control system mechanism (Option parts) 50 50-19 50-21 50-2 50-20 50-1 50-3 50-4 50-23 50-22 50-5 50-10-1 50-10-3 50-10-2 50-6 50-10 50-9 50-14 50-17 50-16 50-7 50-18 50-11 50-12 50-13 50-15 51-1 51-20 51-2 51-19 51-21 51-15 51-24 51-23 51-1 51-5 51-9 51-13 51-7 51-10 51-11 51-10-1 51-10-2 51-8 51-14 51-6 100 103 104 105 111 110 109 101 107 108106 102 106101 109 111 122 121 120 151-615-516 jintex.in 49

Page 53 — V2. 布制御関係(オプション部品) / Cloth control system mechanism (Option parts)

V2. 布制御関係(オプション部品) / Cloth control system mechanism (Option parts) REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 107 S53583000 1 センサーホルダ R SENSOR HOLDER, R 108 S53584000 1 センサーホルダ L SENSOR HOLDER, L 109 S53585001 2 センサーガイド SENSOR GUIDE 110 018300636 2 ア+ナホルト3X6 BOLT, SOCKET M3X6 111 S53586001 2 センサー スタッド SENSOR STUD, M5 120 S10243000 1 ナイロンクランプ NK-3N CORD HOLDER, NK-3N 121 149287000 1 ナイロンクランプ CORD HOLDER, 7N 122 0A5400805 2 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 151-615-516 50 jintex.in

Page 54

W.プリント基板関係 / Printed circuit board mechanism 151-615-518 X. マーカー関係 / Marker mechanism 151-615-521 51 jintex.in

Page 55 — W.プリント基板関係 / Printed circuit board mechanism X.マーカー関係 / Marker mechanism

W.プリント基板関係 / Printed circuit board mechanism REF.NO CODE Q'TY ヒンメイ NAME OF PARTS RM 1 S53000001 1 メインキバンクミ MAIN PCB ASSY 2 S52963000 1 ファンKD2404 FAN, KD2404 3 062302506 2 ナベコ3X25 SCREW, PAN M3X25 4 028030242 2 バネザガネ2-3 WASHER, SPRIN 2-3 5 S52750000 1 PROM620メイン PROM, BAS620 ;MAIN 6 S52750000 1 PROM620ホウセイ PROM, BAS620 ;SEW 7 S52751000 1 PROM620モータ PROM, BAS620 ;MT 8 S53007001 1 デンケンキバンクミ POWER SUPPLY PCB ASSY 8-1 152566000 1 ヒューズ C ;2A FUSE, C ;2A/125V 8-2 152565000 2 ヒューズ B ;5A FUSE, B ;5A/125V 8-3 S52741000 1 GFUSE6A125V GLASS FUSE, 6A/125V 8-4 S08030000 1 ヒューズ 5AFB FUSE, 5A ;FB 8-5 153242000 2 ヒューズ 6A FUSE, 6A 8-6 S30229000 14 ヒューズホルダ F219P FUSE HOLDER, ;F219P 8-7 J02727001 1 カンヒューズ 2A250V GLASS FUSE, 2A/250V 9 0A5400805 5 ナベザガネ4X8DB SCREW, PAN (S/P WASHER) M4X8 10 0A5401205 1 ナベザガネ4X12DB SCREW, PAN (S/P WASHER) M4X12 151-615-518 X.マーカー関係 / Marker mechanism REF.NO CODE Q'TY ヒンメイ NAME OF PARTS RM 1 S52989000 2 マーカー1クミ MARKING LIGHT ASSY, 1 1-1 S52465000 2 マーカー-1 MARKING LIGHT, 1 1-2 S57942000 2 マーキングホルダ MARKING HOLDER 2 018400836 2 アナボルト4X8 BOLT, SOCKET M4X8 3 025040236 2 ヒラザガネネチユウ4 WASHER, PLAIN M 4 4 S57620001 1 マーカーベースプレート MARKING LIGHT BASE PLATE 5 018501236 2 アナボルト5X12 BOLT, SOCKET M5X12 6 028050246 2 バネザガネ2-5 WASHER, SPRING 2-5 7 S40494000 1 SWキャップ SWITCH CAP 10 S52985000 1 ライトマーカーハーネスL ML-HARNESS, L ;M/PCB-ML 11 S04557000 1 バンタイPLT1M BAND, PLT1M 151-615-521 52 jintex.in

Page 56 — AA. pedal mechanism / Foot switch pedal mechanism Y. Operation panel mechanism

53 AA. pedal mechanism / Foot switch pedal mechanism Y. Operation panel mechanism 1-18 1-19 1-5-1 1-5-2 1-6 1-17 1-20 1-1 1-2 1-3 1-16 1-6 1-5-2 1-10 1-8 1-9 1-11 1-12 1-13 1-14 1-15 1-5 1-2 1-1 1-11 1-4 1-10 2 3 8 1-1 1-3 1-2 1-1 1-17 151-615-651 151-615-530

Page 57 — Y.操作パネル関係 / Operation panel mechanism AA.踏板関係 / Foot switch pedal mechanism

Y.操作パネル関係 / Operation panel mechanism REF.NO CODE Q'TY HINMEI NAME OF PARTS RM 1 S52975001 1 サパネ OPERATION PANEL ASSY, 615 1-1 S52976000 1 パネルマエフレーム FRONT FRAME ASSY 1-1-1 S49491000 1 サパネマエフレーム FRONT FRAME 1-1-2 S52977000 1 パネルシート PANEL SHEET 1-1-3 S52978000 1 パネルシートバックライタ PANEL SHEET BACK PLATE 1-2 S52979000 1 サパネルウシロ REAR FRAME 1-3 S49495000 1 パネルヨコカバー PANEL SIDE COVER 1-4 S49496001 1 パネルヨコカバーガイド COVR GUIDE, ;SIDE 1-5 S52092000 1 ゴムシート RUBBER SHEET 1-6 S53010001 1 パネルキバンクミ PANEL PCB ASSY 1-7 087310815 2 カツプBタイト3X8 TAPTITE, CUP B M3X8 1-8 087311015 2 カツプBタイト3X10 TAPTITE, CUP B M3X10 1-9 XA2200500 2 キンオサエ BOARD PRESSER 1-10 0A4400805 1 ナベザクミ4X8DA SCREW, PAN (S/P WASHER) M4X8 1-11 018300636 4 アナボルト3X6 BOLT, SOCKET M3X6 2 S52980000 1 PROM6150パネル PANEL PROM 6150 3 032422505 4 マルモクネジ 4.1X25 WOOD SCREW, ROUND M4.1X25 8 S52458000 1 パネルハーネス PANEL HARNESS 151-615-530 AA.踏板関係 / Foot switch pedal mechanism REF.NO CODE Q'TY HINMEI NAME OF PARTS RM 1 S52960001 1 3レンフットSW 3-PEDAL FOOT SWITCH 1-1 S38166000 3 フットペダルダイ FOOT PEDAL BASE 1-2 S42867001 1 フミイタヨウシタ TREADLE AUXILIARY PLATE 1-3 004400603 6 サラコネジ 4X6 SCREW, FLAT M4X6 1-4 S38170001 3 フットペダルバネ SPRING, COMPRESSION 1-5 S52959000 1 3レンフットSWハーネスクミ 3-PEDAL FOOT SW HARNESS ASSY 1-5-1 S44807000 1 3レンフットSWハーネス 3-PEDAL FOOT SW HARNESS 1-5-2 S36260000 3 スイッチVXピンボタン MICRO SWITCH, VX ;PIN BUTTON 1-6 062301205 6 ナベコ3X12 SCREW, PAN M3X12 1-7 228475000 10 ケツツクバンド 1.9X80 FASTENING BAND, 1.9X80 1-8 S38174000 3 フットペダル FOOT PEDAL 1-9 S38175001 3 ペダルホゴイタ PROTECTION PLATE, ;PEDAL 1-10 S38176101 3 スプリングオサエバネ SPRING, PLATE 1-11 002300403 6 ナベコ3X4 SCREW, PAN M3X4 1-12 028030246 6 ヒラザガネチュウ3 WASHER, PLAIN M3 1-13 025030236 6 ヒラザガネチュウ3 WASHER, PLAIN M3 1-14 S38177001 3 フットペダルジク SHAFT, ;F-PEDAL 1-15 048050346 3 トメワE5 STOP RING 1-16 052400606 3 ナベコハネ3X6 SCREW, PAN (S/P WASHER) M4X6 1-17 117936001 14 ゴムセン 9.4 RUBBER CAP, 9.4 1-18 S52957000 1 コネクタ172171-1 CONNECTOR, 172172-1 1-19 S52958000 1 コネクタカバー-527163 CONNECTOR COVER, 527163 1-20 S38059000 3 グロメットNG79F RUBBER CAP, ;NG79F 151-615-651 54 jintex.in

Page 59 — AB.動力台関係 / Power table

AB.動力台関係 / Power table REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1-1 S40884000 4 ストツパツキヤスター-100 CASTER W/STOPPER, 100 1-2 S53624001 1 トウフシテンジク FULCRUM SHAFT, H 1-3 017082016 2 ボルト 8X20 BOLT, M8X20 1-4 028080246 2 バネザガネ2-8 WASHER, SPRING 2-8 1-5 025080236 2 ワッシャー M 8 WASHER, PLAIN M 8 1-6 S53625001 1 セットカラ SET SCREW COLLAR 1-7 012060636 2 アセヒラ6X6 SET SCREW, SOCKET (FT) M6X6 1-8 S53626001 1 スペーサ 24 SPACER, 24 1-9 S57538001 1 サポートプレートA SUPPORT PLATE, A 1-10 S57539001 1 サポートプレートB SUPPORT PLATE, B 1-11 S42446001 4 アセボルトザクミ6X14 BOLT, SOCKET (S/P WASHER)M6X14 1-12 S53633001 1 フレームササエ SUPPORT SHAFT, F 1-13 S53635001 1 シャフト W/SCREW SHAFT W/SCREW 1-14 S53635001 1 シャフトストツパー SHAFT STOPEER 1-15 021080206 1 ナット M8 NUT, M8 1-16 025080336 1 ワッシャー L 8 WASHER, PLAIN L 8 1-17 S42619001 1 セットカラー SET SCREW COLLAR 1-18 012400436 4 アセヒラ4X4 SET SCREW, SOCKET (FT) M4X4 1-19 153568001 1 スプリング A ;コンプレツシヨン SPRING, A ;COMPRESSION 1-20 018401236 1 アセボルト4X12 BOLT, SOCKET M4X12 1-21 S53636001 1 スプリングホルダー A SPRING HOLDER, A 1-22 S53637001 2 スプリングホルダー B SPRING HOLDER, B 1-23 004401003 2 サラネジ4X10 SCREW, FLAT M4X10 2 S53627101 1 テーブル TABLE 3 018102036 2 アセボルト10X20 BOLT, SOCKET M10X20 4 025100246 2 ヒラザガネネユウ10 WASHER, PLAIN L 10 5 028100246 2 バネザガネ2-10 WASHER, SPRING 2-10 6 S53628001 1 ヘツトツナギシク CONNECTING SHAFT 7 018103036 1 アセボルト10X30 BOLT, SOCKET M10X30 8 028100246 1 バネザガネ2-10 WASHER, SPRING 2-10 9 025100236 1 ヒラザガネネユウ10 WASHER, PLAIN L 10 10 S07356001 1 トメネジ6.35X5 SET SCREW, (FT) SM6.35-28X17 11 S53629000 2 ゴムアシ RUBBER LEG 12 S55485001 2 アセボルトザクミ5X12 SCREW, SOCKET (S/P W) M5X12 14 S10661109 4 ソトアシゴム RUBBER 15 S03999009 3 ハリキヤツプ BEAM CAP 31 S54248000 1 サポートメタルフイツチング SUPPORT METAL FITTINGS 32 S42466001 2 アセボルトザクミ6X14 BOLT, SOCKET (S/P WASHER) M6X1 4 35 144526001 2 フツク HOOK 36 144526001 2 ダンネジ4.37 SHOULDER SCREW, SM4.37 37 151951001 1 スプリング・エキステンシヨン SPRING, EXTENSION 38 S53640001 1 スプリングフツク SPRING HOOK 39 S17971000 1 ショツクアブソーバー、ガス SHOCK ABSORBER, GAS 40 S49638001 2 リンクシヤフトD LINK SHAFT, D 41 107153002 4 ワツシヤー WASHER 42 S37968001 4 スナツプピン8 SNAP PIN, 8 44 S53643001 1 サポートベースD SUPPORT BASE, D 45 018500836 2 アセボルトM5X8 BOLT, SOCKET M5X8 48 S53644001 1 トウフササエレバー-A LEVER, A 49 S53645001 1 トウフササエレバー-B LEVER, B 50 159027001 3 オサエローラ PRESSER ROLLER 51 017061616 3 ボルト6X16 BOLT, M6X16 52 028060246 3 バネザガネ2-6 WASHER, SPRING 2-6 53 S53646000 4 ヘツトツケ BED SUPPORT 54 S53647000 4 クツシヨン CUSHION 55 S53648001 4 クツシヨンカラー CUSHIN COLLAR 56 018063036 4 アセボルト6X30 BOLT, SOCKET M6X30 57 028060246 4 バネザガネ2-6 WASHER, SPRING 2-6 58 154886001 4 ワツシヤー WASHER 59 S53649001 2 テーブルイイチメ-タ POSITIONING PLATE 60 018401636 4 アセボルト4X16 BOLT, SOCKET M4X16 151-615-652 56 jintex.in

Page 60

AB.動力台関係 / Power table REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 61 028040246 4 ハネザガネ2-4 WASHER, SPRING 2-4 62 S536500001 1 コーナーステーブルクミ CORNRER KNIFE TABLE ASSY 62-1 S53651001 1 コーナーステーブル CORNRER KNIFE TABLE 62-2 118550001 2 ミゾツキヒン PIN, DOWEL 63 012081636 4 アトビ8X16 SET SCREW, SOCKET (FT) M8X16 64 S53652001 3 テーブルスペーサ TABLE SPACER, W/SCREW 65 021080306 3 ナット3M8 NUT, 3 M8 66 S53653000 1 サブテーブルーR AUXILIARY TABLE, R 67 S53650001 1 トメネジ8X16 SET SCREW, M8X16 68 008400604 3 +トラスコ4X6 SCREW, TRUSS M4X6 69 S53654001 1 テーブルブラケットA BRACKET, A 70 S53655001 1 テーブルブラケットHB BRACKET, B 71 S55485001 8 ボルトザクミ5X12 SCREW, SOCKET (S/P W) M5X12 74 S53656000 1 サブテーブルーL AUXILIARY TABLE 75 008400604 4 +トラスコ4X6 SCREW, TRUSS M4X6 81 S53659000 1 キジスペリイタC SLIDE PLATE, C 82 008400604 2 +トラスコ4X6 SCREW, TRUSS M4X6 83 S53660000 1 テーブル L TABLE, L 84 017083016 3 ボルトM8X30 BOLT, M8X30 85 028080246 3 ハネザガネ2-8 WASHER, SPRING 2-8 86 025080236 3 ヒラザガネ WASHER, PLAIN M8 87 S53661000 1 テーブルR TABLE, R 88 S55486001 4 ボルトザクミ5X14 SCREW, SOCKET (S/P W) M5X14 91 S02738009 1 コモノケース ACCESSORY CASE 92 S02740000 1 フェルト FELT 93 S02739000 1 ゴムシヤープ RUBBER MAGNET TAPE 94 039411215 2 1トラスツビ4X12 TAPPING SCREW, TRUSS 1 M4X12 95 S38820000 3 ブッシュ35 BUSHING, 35 96 S46583000 1 ブッシュTB-2533 BUSHING, TB-2533 97 S52970000 1 ブッシュTB-1116 BUSHING, TB-1116 98 S55310001 1 ホールプラグ35 HOLE PLUGE, 35 100 S55310001 1 ブレーカーカバー BREAKER COVER 101 008400604 2 +トラスコ4X6 SCREW, TRUSS M4X6 <オプション部品> <OPTION PARTS> 150 S53671000 1 ウケサホシブラケット HOLDEING BRACKET 151 018082036 2 アトビボルト8X20 BOLT, SOCKET M8X20 152 S53672000 1 ウケサホシシンク CURVED BAR 153 S53673000 2 キジヨウケ FIXING BLOCK 154 018501436 2 アトビボルト5X14 BOLT, SOCKET M5X14 155 S53674000 1 キジウケ CLOTH SUPPORTER 156 004401003 4 +サラネシ4X10 SCREW, FLAT M4X10 157 S54117001 1 リンクテンシンク FULCRUM SHAFT 158 018501022 1 アトボルト5X10 BOLT, SOCKET M5X10 159 159150000 2 ゴムセン20.5 RUBBER CAP, 20.5 162 S53675001 1 ボックスカバー BOX COVER 163 008400604 8 +トラスコ4X6 SCREW, TRUSS M4X6 164 S53676001 1 アームカバー ARM COVER 165 008400604 4 +トラスコ4X6 SCREW, TRUSS M4X6 166 S55308001 1 スイッチカバー SWITCH COVER 167 0A5401006 2 ナベコハネ24X10 SCREW, PAN (S/P WASHER) M4X10 168 S53691001 1 オイルフェンス OIL FENCE 169 105173004 2 シメネジ4.76 SCREW, SM4.76 170 S53670001 1 アブラウケASSY OIL PAN ASSY, BAS 170-1 S53678001 1 アブラウケBAS OIL PAN, BAS 170-2 153230101 1 オイルニシク DRAIN 170-3 062670512 2 ナベコ357-40X5 SCREW, PAN SM3.57-40X5 171 S53679000 1 キャッチクリップ CATCH CLIP 172 S53680000 1 ヒンジ HINGE 173 S53681000 1 アブラウケバンド BAND, 252X20X0.5 57 151-615-652 jintex.in

Page 61 — AB.動力台関係 / Power table

AB.動力台関係 / Power table REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 174 S53682001 1 ナットA NUT PLATE, A 175 S53683001 1 ナットB NUT PLATE, B 176 018300836 2 アナボルト3X8 BOLT, SOCKET M3X8 177 018300636 6 アナボルト3X6 BOLT, SOCKET M3X6 180 133172003 1 アブ・ラサシ・イ BRACKET, ;OIL 181 008400604 1 +トラスコ4X6 SCREW, TRUSS M4X6 190 S53684001 1 BAS620モータカバー MOTOR COVER, BAS620 191 S55479001 2 アナボルトサクミ4X8 SCREW, SOCKET (S/P W) M4X8 194 S41964000 1 ブッシュ BUSH 195 008400604 3 +トラスコ4X6 SCREW, TRUSS M4X6 200 S53689001 3 クサリクミ CHAIN ASSY 201 018300636 2 アナボルト3X6 BOLT, SOCKET M3X6 202 S53690001 3 フッククケ HOOK HOLDER 203 062400805 3 ハネザガネ2-4 SCREW, 4X8 204 028040246 3 ハネザガネ2-4 WASHER, SPRING 2-4 205 S08205000 4 クツシヨン CUSHION 210 S39821000 7 コードクランプ19P7 CORD CLAMP, 19P7 151-615-652 58

Page 62 — AC . コーナ一メス関係 / Corner knife mechanism

AC . コーナ一メス関係 / Corner knife mechanism 1-22 1-23 1 1-21 124 100 123 122 121 125 126 104 103 102 < 16~20mm用 / For 16mm to 20mm > 25-2 < 8~14mm用 / For 8mm to 14mm > 25-1 27 26 28 29 22 21 20 23 1-1 1-19 1-20 1-18 1-16 1-25 1-24 1-29 1-26 1-28 1-27 1-39 1-39-2 1-39-1 1-17 1-13 1-15 1-10 1-11 1-12 1-10 1-15 1-13 1-40 1-2 1-39 1-39-2 1-39-1 1-6 1-7 1-8 1-5 1-14 1-9 1-34 1-33 1-32 1-31 1-35 1-371-38 1-36 ” オプション部品 / OPTION PARTS " 25-1 25-2 23 24-1 8mm 24-2 10mm 24-3 12mm 24-4 14mm 24-5 16mm 24-6 18mm 24-7 20mm 59 jintex.in 151-615-656

Page 63 — AC.コーナーメス関係 / Corner knife mechanism

AC.コーナーメス関係 / Corner knife mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 S53700000 1 コーナーメスアセンブリ CORNER KNIFE DRIVING ASSY, A 1-1 S42445001 4 アナルボルトサクミ8X25 BOLT, SOCKET (S/P WASHER)M8X25 1-2 S53702000 1 リニアガイド LINEAR GUIDE 1-3 018062036 5 アナルボルトM6X20 BOLT, SOCKET M6X20 1-5 S10133000 1 XプーリーゲトB X-PULLEY BASE, B 1-6 018501636 4 アナルボルトM5X16 BOLT, SOCKET M5X16 1-7 028050246 4 ハネサガネ2-5 WASHER, SPRING 2-5 1-8 025050236 4 ヒラザガネチュウ5 WASHER, PLAIN M 5 1-9 018501636 1 アナルボルトM5X20 BOLT, SOCKET M5X20 1-10 530138001 2 マイクロベアリング8 MICRO BEARING 1-11 048160242 2 トメワアウタクC16 RETAINING RING, INTERNAL C16 1-12 S10087101 1 タイミングプーリーB TIMING PULLEY, B 1-13 012400436 2 アナルボルト4X4 SET SCREW, SOCKET (FT) M4X4 1-14 S10134001 1 Xプーリーゲト X-PULLEY SHAFT, B 1-15 048080142 2 トメワアウタクC8 RETAINING RING, C8 1-16 S53703000 1 タイミングベルト TIMING BELT 1-17 S10078001 2 Tベルトスペーサ SPACER, T-BELT 1-18 S10079101 1 ベルトホルダ BELT HOLDER 1-19 018401036 2 アナルボルトM4X10 BOLT, SOCKET M4X10 1-20 028040246 2 ハネサガネ2-4 WASHER, SPRING 2-4 1-21 S43192200 1 パルスモータアセンブリA PULSE MOTOR ASSY, A 1-22 S27844201 1 タイミングプーリーA TIMING PULLEY, A 1-23 014770622 2 アナルボルト6.35Xクミ SET SCREW, SOCKET (CP) SM6.35 1-24 018401236 4 アナルボルト4X12 BOLT, SOCKET M4X12 1-25 028040246 4 ハネサガネ2-4 WASHER, SPRING 2-4 1-26 S53705001 1 シリンダーサポ-トL CYLINDER SUPPORT, L 1-27 018501636 2 アナルボルトM5X16 BOLT, SOCKET M5X16 1-28 028050246 2 ハネサガネ2-5 WASHER, SPRING 2-5 1-29 S53706001 1 センサー ドグ SENSOR DOG 1-30 008400604 2 スクリュー、トラスM4X6 SCREW, TRUSS M4X6 1-31 S53707001 1 フィクシングロック FIXING BLOCK 1-32 018501436 2 アナルボルトM5X14 BOLT, SOCKET M5X14 1-33 028040246 2 ハネサガネ2-4 WASHER, SPRING 2-4 1-34 025050236 2 ヒラザガネチュウ5 WASHER, PLAIN M 5 1-35 018502036 1 アナルボルトM6X20 BOLT, SOCKET M6X20 1-36 S53708001 1 シリンダーサポ-トR CYLINDER SUPPORT, R 1-37 018501236 2 アナルボルト5X12 BOLT, SOCKET M5X12 1-38 028050246 2 ハネサガネ2-5 WASHER, SPRING 2-5 1-39 S53709000 2 シリンダー-25X75クミ CYLINDER ASSY, 25X75 1-39-1 S53710000 2 シリンダー-25X75 CYLINDER, 25X75 1-39-2 S53722000 4 エルボKQ2L06M5 ELBOW, KQ2L06M5 1-40 S32294001 8 アナルボルト4X35 BOLT, SOCKET M4X35 20 S57541001 2 コーナーメストリツケダイ C-KNIFE SETTING BRACKET 21 018061436 2 アナルボルトM6X14 BOLT, SOCKET M6X14 22 S14753001 2 メスダイシク KNIFE BASE SHAFT 23 012500536 2 アナルボルト5X5 SET SCREW, SOCKET (FT) M5X5 <オプション部品> <OPTION PARTS> 24-1 S11521001 2 メスダイ8ケミ KNIFE BASE ASSY, 8 24-2 S11522001 2 メスダイ10ケミ KNIFE BASE ASSY, 10 24-3 S11523001 2 メスダイ12ケミ KNIFE BASE ASSY, 12 24-4 S11524001 2 メスダイ14ケミ KNIFE BASE ASSY, 14 24-5 S11525001 2 メスダイ16ケミ KNIFE BASE ASSY, 16 24-6 S11526001 2 メスダイ18ケミ KNIFE BASE ASSY, 18 24-7 S11527001 2 メスダイ20ケミ KNIFE BASE ASSY, 20 <8-14mm用> <For 8mm to 14mm> 25-1 S14050001 4 セラミックコーナーメスS CERAMIC CORNER KNIFE, S <16-20mm用> <For 16mm to 20mm> 25-2 S14051001 4 セラミックコーナーメスL CERAMIC CORNER KNIFE, L 151-615-656 60 jintex.in

Page 64 — AC . コーナ一メス関係 / Corner knife mechanism

AC . コーナ一メス関係 / Corner knife mechanism 1-22 1-23 1 1-21 124 100 123 120 122 121 125 126 104 103 102 < 16~20mm用 / For 16mm to 20mm > 25-2 < 8~14mm用 / For 8mm to 14mm > 25-1 27 28 29 26 22 21 20 23 1-17 1-18 1-19 1-20 1-16 1-25 1-24 1-26 1-29 1-28 1-27 1-39 1-39-2 1-39-1 1-1 1-3 1-13 1-15 1-10 1-11 1-12 1-13 1-10 1-15 1-14 1-9 1-5 1-34 1-33 1-32 1-40 1-2 1-39 1-31 1-35 1-39-1 1-371-38 1-36 ” オプション部品 / OPTION PARTS " 25-1 26 22 21 20 23 24-1 8mm 24-2 10mm 24-3 12mm 24-4 14mm 24-5 16mm 24-6 18mm 24-7 20mm 61 jintex.in 151-615-656

Page 65 — AC.コーナーメス関係 / Corner knife mechanism

AC.コーナーメス関係 / Corner knife mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 26 111140002 4 シメネジ 2.38 SCREW, SM2.38 27 018401236 2 アナボルト 4X12 BOLT, SOCKET M4X12 28 028040246 2 ワッシャー スプリング 2-4 WASHER, SPRING 2-4 29 025040236 2 ヒラザガネツチ4 WASHER, PLAIN M 4 100 S52453000 1 コーナーメスパワーハーネス C/K POWER HARNESS, M/PCB-MT 102 S52986000 1 コーナーメス テンションセンサー HOME POSITION SENSOR, C/K 103 062301006 1 ナベコ3X10 SCREW, PAN M3X10 104 S52724000 1 コーナーメスセンサーハーネス SENSOR HARNESS, C/K 120 S39821000 4 コードクランプ 19P7 CORD CLAMP, 19P7 121 625010000 1 ナイロンクランプ NK-2N CORD HOLDER, NK-2N 122 552907000 1 コードホルダ #10 CORD HOLDER, 10N 123 0A5401005 2 +バツサミ4X10DB SCREW, PAN (S/P WASHER) M4X10 124 S04557000 1 バンダイPLT1M BAND, PLT1M 125 S55302000 1 スパイラル400L SPIRAL, L=400 126 S55305000 1 スパイラル220L SPIRAL, L=220 151-615-656 62

Page 67

AD.送り装置関係 / Feed device mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1-1 S53742001 1 プーリーサ PULLEY SETTING BRACKET 1-2 018060222 2 アサボルト6X20 BOLT, SOCKET M6X20 1-3 028060236 2 ワッシャM6 WASHER, PLAIN M 6 1-4 028060246 2 バネワッシャ2-6 WASHER, SPRING 2-6 1-5 S12078000 2 フカミゾウクウケ2 BALL BEARING, 2 DEEP GROOVE 1-6 S53785001 1 プーリー-A TIMING PULLEY, A 1-7 S12079000 2 カラー-2 COLLAR, 2 1-8 S12076000 1 プーリージクD PULLEY SHAFT, D 1-9 012500536 2 アサヒラ5X5 SET SCREW, SOCKET (FT) M5X5 1-10 S53743000 1 タイミングベルト TIMING BELT 1-11 076002450 2 クウケ6002DD BALL BEARING, 6002DD 1-12 S53744001 1 プーリージク PULLEY SHAFT 1-13 S12067000 1 キー KEY, 5X35 1-14 04815142 1 トメワシクウケC15 RETAINING RING, EXTERNAL C15 1-15 S53787001 1 プーリー-B TIMING PULLEY, B 1-16 116920001 1 オクリジク・スラストリング RING, THRUST 1-17 012060636 2 アナヒラ6X6 SET SCREW, SOCKET (FT) M6X6 1-18 S53745000 1 サラコウ66;PA SUR GEAR, 66 ;PA 1-19 012500536 1 アサヒラ5X5 SET SCREW, SOCKET (FT) M5X5 1-20 S53747000 1 キー-5X30 KEY, 5X30 1-21 S53748001 1 モータトリツケイタ MOTOR SETTING PLATE 1-22 018501236 4 アサボルト5X12 BOLT, SOCKET M5X12 1-23 S53749000 2 リニアガイド 15X700 LINEAR GUIDE, 15X700 1-24 018401436 14 アサボルト4X14 BOLT, SOCKET M4X14 1-25 028040246 14 バネワッシャ2-4 WASHER, SPRING 2-4 1-26 S53750001 1 オオサエオクリダイ FEED BRACKET 1-27 018401636 8 アサボルト4X16 BOLT, SOCKET M4X16 1-28 028040246 8 バネワッシャ2-4 WASHER, SPRING 2-4 1-29 S53751001 1 ベルトホジイタ BELT HOLDER 1-30 018501636 4 アサボルト5X16 BOLT, SOCKET M5X16 1-31 S53752001 2 リミットプレート LIMIT PLATE 1-32 018501236 4 アサボルト5X12 BOLT, SOCKET M5X12 1-33 104821001 4 ゴムセン10.5 RUBBER CAP, 10.5 1-34 S53753000 2 シリンダーグミ CYLINDER ASSY 1-34-1 S53754000 2 エアシリンダ25X15 AIR CYLINDER, 25X12 1-34-2 S53786000 4 スピードコントローラ SPEED CONTROLLER 1-35 018061422 8 アサボルト6X14 BOLT, SOCKET M6X14 1-36 S53756001 2 シリンダツキテ CYLINDER SUPPORT 1-37 S53757001 2 テンシク FULCRUM SHAFT 1-38 018301036 4 アサボルト3X10 BOLT, SOCKET M3X10 1-39 S53758001 1 シリンダーガイド CYLINDER GUIDE 1-40 018502036 2 アサボルト5X20 BOLT, SOCKET M5X20 1-41 S53759001 1 コードササエイタ CORD SUPPORT BRACKET 1-42 062061012 2 ナベコ6X10 SCREW, PAN M6X10 1-43 S53760000 1 ランナーフレックス RUNER FLEX 1-44 002501003 2 ナベコ5X10 SCREW, PAN M5X10 1-45 025050236 2 ヒラザガネチュウ5 WASHER, PLAIN M 5 1-46 S56861001 1 オオサエオクリダイ SHAFT 1-47 018500836 2 アサボルト5X8 BOLT, SOCKET M5X8 1-48 S5682001 6 セットカラー SET SCREW COLLAR 1-49 012500536 12 アサヒラ5X5 SET SCREW, SOCKET (FT) M5X5 1-50 S53773001 1 オクリダイセンサードグ SENSOR DOG, F/B 1-51 008400604 2 +トラスコ4X6 SCREW, TRUSS M4X6 1-52 S53774001 1 オクリダイカバー-L FEED BRACKET COVER, L 1-53 018501636 4 アサボルト5X16 BOLT, SOCKET M5X16 1-54 S29742001 1 アサボルト5X50 BOLT, SOCKET M5X50 1-55 021500216 1 2シュナツト5 NUT, 2 M5 1-56 S53775001 1 オクリダイカバー-R FEED BRACKET COVER, R 1-57 018061636 4 アサボルト6X16 BOLT, SOCKET M6X16 1-58 026060136 4 ヒラザガネコウ6 WASHER, PLAIN S 6 1-59 S53783001 2 センサーリツケプレート SENSOR SETTING PLATE 151-615-657 64 jintex.in

Page 68 — AD. 送り装置関係 / Feed device mechanism

65 AD. 送り装置関係 / Feed device mechanism jintex.in 1-34-2 1-37 1-36 1-38 1-39 1-51 1-47 1-49 1-48 1-49 1-46 1-49 1-28 1-27 1-34 1-41 1-42 1-34-1 1-50 1-30 1-29 1-51 1-44 1-45 1-43 106 107 108 105 102 101 1-59 1-60 1-33 1-32 1-31 1-10 1-11 1-12 1-14 1-13 1-20 1-15 1-16 1-17 1-19 1-18 1-22 1-21 1-23 1-56 1-57 1-58 10 1-8 1-52 1-53 1-54 1-55 1-5 6 4 5 1-2 1-3 1-4 1-9 1-1 10 12 11 13 19 20 21 22 23 24 120 121 122 123 14 14 151-615-657

Page 70 — AE . バインダー関係 / Binder mechanism

AE . バインダー関係 / Binder mechanism 9-19 9-20 9-18 9-22 9-23 9-22 9-9 9-11 9-11-2 9-21 9-24 9-16 9-15 9-25 9-27 9-29 9-28 9-32 9-36 9-35 9-37 9-39 9-38 14 14-1 14-2 15 110 109 9-11-3 9-13 9-14 9-12 9-30 9-31 9-26 9-73 9-72 9-69 9-70 13 12 11 10 17 16 9-2 9-10 9-82 9-81 9-3 9-4 9-9 9-1 9-33 9-2 9-42 9-40 9-39 9-41 9-60 9-59 9-64 9-65 9-56 9-85 9-62 9-71 9-63 9-74 9-53 9-44 9-45 9-46 9-48 9-49 9-47 9-64 9-65 9-57 9-58 9-90 9-61 9-72 9-63 9-70 9-68 9-77 9-76 103 104 19 18 100 101 102 9-8 9-7 9-6 9-5 9-1 9-43 9-47 9-50 9-34 9-54 9-55 9-52 9-73 9-86 9-64 9-51 9-70 151-615-658 67 Jinte.in

Page 72 — AE バインダー関係 / Binder mechanism

69 AE バインダー関係 / Binder mechanism 15 14-2 14-1 14-3 11 10 13 12 110 109 14 9-32 9-36 9-37 9-35 9-38 9-28 9-29 9-27 9-39 9-38 9-40 9-73 9-72 9-69 9-70 9-68 9-63 9-62 9-71 9-61 9-59 9-60 9-58 9-57 9-56 9-55 9-54 9-53 9-52 9-51 9-47 9-44 9-45 9-46 9-49 9-48 9-43 9-42 9-41 9-40 9-39 9-31 9-30 9-15 9-16 9-17 9-14 9-13 9-12 9-11 9-11-1 9-11-2 9-25 9-24 9-21 9-20 9-19 9-18 9-23 9-22 9-22 9-1 9-5 9-6 9-7 9-8 9-81 9-82 9-2 9-3 9-4 9-10 9-33 9-34 9-50 17 16 19 18 100 101 102 103 104 151-615-658 jintex.in

Page 73 — AE.バインダー関係 / Binder mechanism

AE.バインダー関係 / Binder mechanism REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 9-59 S59035000 1 イタバネ SPRING, PLATE 9-60 018301236 2 アナルボルト3X12 BOLT, SOCKET M3X12 9-61 S59044001 1 キンガイ ドアームR CLOTH GUIDE ARM, R 9-62 S59043001 1 キンガイ ドアームL CLOTH GUIDE ARM, L 9-63 018300836 2 アナルボルト3X8 BOLT, SOCKET M3X8 9-64 018301236 4 アナルボルト3X12 BOLT, SOCKET M3X12 9-65 021300303 4 NUT, 3 M NUT, 3 M 9-68 S59034000 1 キンガイ ドR CLOTH GUIDE, R 9-69 S59033000 1 キンガイ ドL CLOTH GUIDE, L 9-70 S58692001 4 サニコ23X3 SCREW, FLAT M2X3 9-71 S21008001 1 キンガイ ドンテンシク FULCRUM SHAFT, C/GUIDE 9-72 S21009001 2 キンガイ ドウスリーフ SLEEVE, C/GUIDE 9-73 S30014001 2 フタネシ M3 SCREW, M3 9-74 012400436 1 アナルヒラ4X4 SET SCREW, SOCKET (FT) M4X4 9-77 018082036 1 アナルボルト8X20 BOLT, SOCKET M8X20 9-81 018061436 1 アナルボルト6X14 BOLT, SOCKET M6X14 9-82 021060206 1 シュナツト6 NUT, 2 M6 9-85 S59047001 1 ジヨウキ トリツケイタC BINDER SETTING PLATE, C 9-86 004301016 2 サラコ3X10 SCREW, FLAT M3X10 9-90 025030236 2 サラガネチュウ3 WASHER, PLAIN M 3 9-91 025030236 2 サラガネチュウ3 WASHER, PLAIN M 3 10 S14703001 1 イトクリタ シンテ THREAD TAKE-UP ARM 11 141598001 1 シン 4.76 SHOULDER SCREW, SM4.76 12 S53815001 1 イトクリタシ CURVED WIRE 13 012300336 2 アナルヒラ3X3 SET SCREW, SOCKET (FT) M3X3 14 S53816100 1 シリンダークミ CYLINDER ASSY 14-1 S53817100 1 エアシリンダー10X5 AIR CYLINDER 10X5 14-2 S12150000 2 ホースエルボ M-5HL-4 TUBE ELBOW, M-5HL-4 14-3 S39122000 1 クツルシ ジョイントM4 KNUCKLE JOINT, M4 15 018400836 2 アナルボルト4X8 BOLT, SOCKET M4X8 16 S53818001 2 シテンピン FULCRUM PIN 17 012500536 4 アナルヒラ5X5 SET SCREW, SOCKET (FT) M5X5 18 S53686001 1 イチギメイタ POSITIONING PLATE 19 S20355002 2 シメネジ3X8.5 SCREW, M3X8.5 100 S52759000 1 SW-D3M-01K2-3 MICRO SWITCH, D3M-01K2-3 101 002021205 2 ナベコ2X12 SCREW, PAN M2X12 102 S52468000 1 メンタSWハーネス SWITCH HARNESS, SW-M/PCB 103 S10243000 1 ナイロンクランプNK-3N CORD HOLDER, NK-3N 104 0A5400805 1 +ナベザクミ4X8DB SCREW, PAN (S/P WASHER) M4X8 109 625010000 1 ナイロンクランプNK-2N CORD HOLDER, NK-2N 110 0A4300605 1 +ナベザクミ3X6DA SCREW, PAN (S/P WASHER) M3X6 151-615-658 70 jintex.in

Page 74 — Z1. 付属品関係 / Accessories

71 Z1. 付属品関係 / Accessories 30 7.1 7 8 16 31-11-2 31-11-3 31-15 31-19-1 31-7 31-16-2 31-18-1 31-19-2 31-18-1 31-17 31-12 31-1 31-18-3 31-16-3 31-10 31-18-1 31-18-2 31-18-4 31-19-3 31-18-6 31-18-2 31-9 31-9-1 33 118-U73-910

Page 75 — Z1.付属品関係 / Accessories

Z1.付属品関係 / Accessories * 付属品の明細は変更することがあります / The details of included accessories are subject to change. REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 7 153011416 1 ミシンハリMTX190クミ NEEDLE ASSY, MTX190 (#16) 7-1 153011016 4 ミシンハリMTX190 NEEDLE, MTX190 (#16) 8 S09285051 4 <標準品> ボビン <Standard parts> BOBBIN, 2 16 S09152001 1 ウワメスC UPPER KNIFE, C 30 S54022001 1 イトアンナイ THREAD GUIDE 31 S02767409 1 イトタテクイミ3THF COTTON SATND ASSY, 3THF 31-1 150189109 1 ブラケット COTTON STAND BRACKET 31-3 062060806 2 ヘコ36X8 SCREW, PAN M6X8 31-5 S51283001 3 ウケザラ SPOOL MAT 31-5 150182000 3 プーマツト SPOOL MAT 31-6 126863001 3 プーラクツシヨン SPOOL CUSHION 31-9 S04109001 1 イトアンナイササエボウ SUPPORT BAR, ;TR-GUIDE 31-9-1 S40639001 1 コラムパイプキヤツプツキ COLUMN PIPE W/CAP 31-10 150173003 1 コラムキヤツプ COLUMN CAP 31-11 S21798001 3 コラムジヨイント COLUMN JOINT 31-11 150179003 1 スプールネシセット SPOOL & SCREW SET 31-11-1 150179002 3 スプールシクB SPOOL SHAFT, B 31-11-2 028050246 3 ハネジナガメ2-5 WASHER, SPRING 2-5 31-11-3 021500106 3 1ミユナツト5 NUT, 1 M5 31-12 150185009 1 イトアンナイホルター THREAD GUIDE HOLDER 31-13 138843001 1 ササエホウウツギテ JOINT 31-15 S02779009 1 スプールホルター-3 SPOOL HOLDER, 3 31-16 S02788009 1 スレッドハンガーアツシ、3 THREAD HANGER ASSY, 3 31-16-1 S02789009 1 スレッドハンガー-3 THREAD HANGER, 3 31-16-2 150183000 1 イトカケハンガーダイ THREAD HANGER BASE 31-16-3 142990001 3 スレッドブツシユ THREAD BUSH 31-17 150172003 1 コラムパイプ COLUMN PIPE 31-18 S0641001 1 スプールシヨウケツトA SPOOL SHAFT & SCREW SET, A 31-18-1 021500106 4 1ミユナツト5 NUT, 1 M5 31-18-2 062501406 1 ナベコ5X14 SCREW, PAN M5X14 31-18-3 062503506 1 ナベコM5X35 SCREW, PAN M5X35 31-18-4 062501406 2 ナベコ5X14 SCREW, PAN M5X14 31-18-6 026050136 2 ヒラサガネコガタS5 WASHER, PLAIN S 5 31-19 S40643001 1 ホルダージヨイントセツト HOLDER JOINT & SCREW SET 31-19-1 014060632 2 アツクボミ6X6 SET SCREW, SOCKET (CP) M6X6 31-19-2 021500106 1 1ミユナツト5 NUT, 1 M5 31-19-3 062503506 1 ナベコM5X35 SCREW, PAN M5X35 33 008400604 3 トラスコ4X6 SCREW, TRUSS M4X6 118-U73-910 72

Page 76

73 Z2. 付属品関係 / Accessories 40 "フラップ仕様 オプション部品 / Option parts for flap clamp spec" 34 35 2.4 2.8 3.5 21 50 51 52 53 54 55 "下糸検出器 オプション部品 / Option parts for lower thread detector " 70 22 1 2 3 4 5 6 7 8 9 10 11 12 13 15 16 17 18 19 151-615-910

Page 77 — Z2.付属品関係 / Accessories

Z2.付属品関係 / Accessories *付属品の明細は変更することがあります / The details of included accessories are subject to change. REF.NO CODE QTY ヒンメイ NAME OF PARTS RM 1 115157001 1 6カクホウ スパナ 6 HEXAGONAL WRENCH, 6 2 150335001 1 6カクホウ スパナ 5 HEXAGONAL WRENCH, 5 3 118064001 1 6カクホウ スパナ 4 HEXAGONAL WRENCH, 4 4 142721001 1 6カクホウ スパナ 3 HEXAGONAL WRENCH, 3 5 154125001 1 6カクホウ スパナ 2.5 HEXAGONAL WRENCH, 2.5 6 142002001 1 6カクホウ スパナ 2 HEXAGONAL WRENCH, 2 7 S07783001 1 6カクホウ スパナ 1.5 HEXAGONAL WRENCH, 1.5 8 S14696001 1 スパナ 11X13 SPANNER 11X13 9 107780001 1 スパナ 10X12 WRENCH, 10X12 10 100887001 1 スパナ 8X9 WRENCH, 8X9 11 142205001 1 スパナ 7X8 WRENCH, 7X8 12 S08132001 1 スパナ 5.5 WRENCH, 5.5 13 S08170001 1 Zガタネジ マワシ SCREW DRIVER, ;Z-TYPE 15 122991001 1 フクンクヒンポリクロ ACCESSORY BAG 16 142443001 1 ネジ マワシ 1.9X52 SCREW DRIVER, 1.9X52 17 118837001 1 ネジ マワシ 3.4X70 SCREW DRIVER, 3.4X70 18 101572101 1 ネジ マワシ 5.5X190 SCREW DRIVER, 5.5X190 19 S01943001 1 6カクホウ ウネリ マワシ 1.6 SCREW DRIVER, HEX. 1.6 20 117466000 1 ピンセット PINCETTE 21 S55663001 1 オイルタンククミ OIL TANK ASSY 22 114483002 1 ポリオイラークミ OILER ASSY 32 114486002 1 ポリオイラータイ OILER 34 S59338001 1 ナカメシグ JIG, CENTER KNIFE 35 S59350001 1 ゲージ・N-バーゲージ GAUGE, N-BAR HIGHT 40 S57533000 2 <フラップ仕様 (OP) の場合> ハンシヤシート <Option parts for flap clamp spec> REFLECTING SHEET 50 152566000 1 ヒューズ・C FUSE, C ;2A/125V 51 152565000 2 ヒューズ・B FUSE, B ;3A/125V 52 S52741000 1 GFUSE6A125V GLASS FUSE, 6A/125V 53 S08030000 1 ヒューズ・5AFB FUSE, 5A ;FB 54 153242000 2 ヒューズ・6A FUSE, 6A 55 J02727001 1 ヒューズ・2A250V GLASS FUSE, 2A/250V 70 S52490001 4 <下糸検出器 (OP) の場合> ボビン <Option parts for lower thread detector> BOBBIN 151-615-910 jintex.in 74

Page 78 — Ga1. ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150)

Ga1. ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150) 針幅8mm Needle gauge : 8mm 針幅10mm Needle gauge : 10mm 針幅12mm Needle gauge : 12mm 針幅14mm Needle gauge : 14mm 針幅16mm Needle gauge : 16mm G1-1-3 針抱キ組 Needle clamp assy S59139-001 針抱キ8UP組 Needle clamp assy, 8mm S59140-001 針抱キ10UP組 Needle clamp asy, 10mm S59141-001 針抱キ12UP組 Needle clamp assy, 12mm S59142-001 針抱キ14UP組 Needle clamp assy, 14mm S59143-001 針抱キ16UP組 Needle clamp assy, 16mm G1-6 Needle plate set S52571-001 針板8セット Needle plate set, 8 S52572-001 針板10セット Needle plate set, 10 S52573-001 針板12セット Needle plate set, 12 S52574-001 針板14セット Needle plate set, 14 S52575-001 針板16セット Needle plate set, 16 G1-3-3 Needle plate assy S52561-001 針板8組 Needle plate assy, 8 S52562-001 針板10組 Needle plate assy, 10 S52563-001 針板12組 Needle plate assy, 12 S52564-001 針板14組 Needle plate assy, 14 S52565-001 針板16組 Needle plate assy, 16 G1-4-3 ループガイド Loop guide S52536-001 ループガイド8 Loop guide, 8 S52537-001 ループガイド10 Loop guide, 10 S52538-001 ループガイド12 Loop guide, 12 S52539-001 ループガイド14 Loop guide, 14 S52540-001 ループガイド16 Loop guide, 16 G2-1-2 滑り板セット Slide plate set S53428-000 滑り板セット8-12 Slide plate set, 8-12 S53435-000 滑り板セット14-16 Slide plate set, 14-16 G2-1-2-1 滑り板組 Slide plate assy S53429-000 滑り板組8-12 Slide plate assy, 8-12 S53436-000 滑り板組14-16 Slide plate assy, 14-16 G2-1-2-2 滑り板 Slide plate S53430-001 生地滑り板 Slide plate S53430-002 生地滑り板 Slide plate 定規/Binder 薄物用 Medium-weight materials 中厚物用 Medium-weight materials 薄物用 Light-weight materials G2-10 両玉縁縫い Double welting S59271-000 定規組8W-13 Binder assy, 8W-13 S59275-000 定規組10W-17 Binder assy, 10W-17 S59279-000 定規組12W-21 Binder assy, 12W-21 S59283-000 定規組14W-25 Binder assy, 14W-25 S59287-000 定規組16W-29 Binder assy, 16W-29 S59272-000 定規組8W-14 Binder assy, 8W-14 S59276-000 定規組10W-18 Binder assy, 10W-18 S59280-000 定規組12W-22 Binder assy, 12W-22 S59284-000 定規組14W-26 Binder assy, 14W-26 S59288-000 定規組16W-30 Binder assy, 16W-30 G2-20 片玉縁縫い Single welting 薄物用 Light-weight materials S59273-000 定規組8S-14 Binder assy, 8S-14 S59277-000 定規組10S-18 Binder assy, 10S-18 S59281-000 定規組12S-22 Binder assy, 12S-22 S59285-000 定規組14S-26 Binder assy, 14S-26 S59289-000 定規組16S-30 Binder assy, 16S-30 薄物用 Light-weight materials S59274-000 定規組8S-15 Binder assy, 8S-15 S59278-000 定規組10S-19 Binder assy, 10S-19 S59282-000 定規組12S-23 Binder assy, 12S-23 S59286-000 定規組14S-27 Binder assy, 14S-27 S59290-000 定規組16S-31 Binder assy, 16S-31 AC-25-1,25-2 セラミックコーナーメス Ceramic corner knife S14050-001 セラミックコーナーメスS Ceramic corner knife,S S14051-001 セラミック コーナーメスL Ceramic corner knife, L AC-24 メスダイ組 Knife base assy S11521-001 メスダイ組 Knife base assy, 8 S11522-001 メスダイ10組 Knife base assy, 10 S11523-001 メスダイ12組 Knife base assy, 12 S11524-001 メスダイ14組 Knife base assy, 14 S11525-001 メスダイ16組 Knife base assy, 16 L2-2-2, 2-3 固定刃 Fixed knife S53521-001 固定刃8 Fixed knife, 8 S53494-001 固定刃10-12 Fixed knife, 10-12 S53495-001 固定刃14-16 Fixed knife, 14-16 L2-3-2, 3-3 上糸メス組 N/Thread knife assy S53522-101 上糸メス組8 N/Thread knife assy, 8 S53498-001 上糸メス10-12組 N/Thread knife assy, 10-12 S53501-101 上糸メス14-16組 N/Thread knife assy, 14-16 L2-4-2, 4-3 糸保持板 Thread holding plate S53523-001 糸保持板8 Thread holding plate, 8 S53507-001 糸保持板10-12 Thread holding plate, 10-12 S53508-001 糸保持板14-16 Thread holding plate, 14-16 75 jintex.in 151-615-Ga1

Page 79 — Ga1. ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150)

Ga1. ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150) 針幅18mm Needle gauge : 18mm 針幅20mm Needle gauge : 20mm G1-1-3 針抱キ組 Needle clamp assy S59144-001 針抱キ18UP組 Needle clamp assy, 18mm S59145-001 針抱キ20UP組 Needle clamp assy, 20mm G1-6 針板セット Needle plate set S52576-001 針板18セット Needle plate set, 18 S52577-001 針板20セット Needle plate set, 20 G1-3-3 針板組 Needle plate assy S52566-001 針板18組 Needle plate assy, 18 S52567-001 針板20組 Needle plate assy, 20 G1-4-3 ループガイド Loop guide S52541-001 ループガイド18 Loop guide, 18 S52542-001 ループガイド20 Loop guide, 20 G2-1-2 滑り板セット Slide plate set S53437-000 滑り板セット18-20 Slide plate set, 18-20 G2-1-2-1 滑り板組 Slide plate assy S53438-000 滑り板組18-20 Slide plate assy, 18-20 G2-1-2-2 滑り板 Slide plate S53430-003 生地滑り板 Slide plate 定規/Binder 薄物用 Medium-weight materials 中厚物用 Medium-weight materials G2-10 両玉縫い Double welting S59291-000 定規組18W-33 Binder assy, 18W-33 S59296-000 定規組20W-37 Binder assy, 20W-37 G2-20 片玉縫い Single welting 薄物用 Light-weight materials S59292-000 定規組18W-34 Binder assy, 18W-34 S59293-000 定規組18S-34 Binder assy, 18S-34 S59297-000 定規組20S-38 Binder assy, 20S-38 薄物用 Light-weight materials S59294-000 定規組18S-35 Binder assy, 18S-35 S59298-000 定規組20S-39 Binder assy, 20S-39 AC-25-1,25-2 セラミックコーナーメス Ceramic corner knife S14051-001 セラミックコーナーメス L Ceramic corner knife, L AC-24 メスダイ組 Knife base assy S11526-001 メスダイ組 Knife base assy, 10 S11527-001 メスダイ20組 Knife base assy, 20 L2-2-2, 2-3 固定刃 Fixed knife S53496-001 固定刃18-20 Fixed knife, 18-20 L2-3-2, 3-3 上糸メス N/Thread knife assy S53503-101 上糸メス18-20 N/Thread knife assy, 18-20 L2-4-2, 4-3 糸保持板 Thread holding plate S53509-001 糸保持板18-20 Thread holding plate, 18-20 151-615-Ga1 76 jintex.in

Page 81 — Ga2 . ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150)

Ga2 . ゲージ部品一覧表 (BAS-6150) / Gauge parts List (BAS-6150) 針幅18mm Needle gauge : 18mm 針幅20mm Needle gauge : 20mm S54671-000 定規 18W-33 Binder, 18W-33 S54675-000 定規 20W-37 Binder, 20W-37 33 16.5 18 18 37 18.5 20 中厚物用 Medium-weight materials G2-10-2 片玉縁縫い Double welting S53467-000 定規 18W-34 Binder, 18W-34 S53471-000 定規 20W-38 Binder, 20W-38 34 17 19 18 20 薄物用 Light-weight materials 定規/Binder S54673-000 定規 18S-34 Binder, 18S-34 S54677-000 定規 20S-38 Binder, 20S-38 34 25 38 28 18 20 中厚物用 Medium-weight materials S53469-000 定規 18S-35 Binder, 18S-35 S53473-000 定規 20S-39 Binder, 20S-39 35 26 39 29 18 20 151-615-Ga2 jintex.in 78

Page 82 — Wa.警告ラベル / Warning labels

79 Wa.警告ラベル / Warning labels 品名 / Name of parts 電撃ラベル・和 Size(mm) Code PE マーク Label, PE アースマーク Label, grounding 矢印マーク Label, arrow ワーニングマーク Mark, injury 操作注意ラベルBAS・和 Label, operation(BAS)Eng. Label, elec. shock 4 lang. Ø 12 7.5 X 12.5 10 X 30 L=25 L=16 40 X 64 35 X 118 40 X 64 52 X 84 40 X 64 S37060-001 S37059-001 S37058-001 S36924-002 S36924-001 S38571-001 S38352-101 S38353-101 S38571-002 S38357-001 151-615-Wa

Page 83 — 索引 / INDEX

索引 / INDEX CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page 002021205 101 70 012500536 8 24 018300636 6 110 24 021060206 1-88 30 002300403 1-1 54 30 1-9 64 1-11 177 54 021080206 1-110 32 002300603 1-1-5 38 1-19 64 177 58 1-84 30 1-1-27 44 1-49 64 201 1-15 56 1-2-27 46 17 70 018300836 1-1-7 58 9-22 68 50-23 48 013660612 1-26 20 1-2-7 12 021080306 65 57 51-24 48 013710512 10 14 176 58 021120304 9-33 68 106 48 50 16 9-63 70 021300303 9-65 70 002501003 5 66 013711012 50 17 14 018301036 1-38 24 021400103 1-25 34 004300513 1-1-5 12 014060632 31-19-1 72 018301236 25 64 021400206 1-1-1-4 12 1-4-3 64 014300332 1-30 34 9-57 60 1-2-5 12 004301016 1-3 54 014680422 1-9 4 9-60 70 021500106 31-11-3 72 004400603 1-3 70 014761030 1-19 4 9-64 72 31-18-1 72 004401003 44 54 014770622 1-23 60 018400836 X2 15 31-19-2 72 1-23 156 56 014771022 B6-4 2 1-19 29 021500216 50-13 48 156 57 B16 2 9-19 30 50-20 48 004401414 1-1-1-3 12 15 4 1-20 60 51-14 48 1-2-1-3 12 014780622 1-12 8 1-24 64 51-21 48 004501003 1-10 64 014781032 1-2 6 60 1-55 64 9-10 48 1-3 2 4 1-27 62 021500316 P1-14 28 004501016 50-5 48 1-12 6 1-24 40 021670102 34 22 51-5 48 23 201 018401436 1-24 40 025030233 1-7 34 008300604 1-1-32 44 16 4 025030236 1-13 52 1-2-32 46 016771032 16 018401636 60 1-27 56 025040135 1-8 60 50-18 48 017061616 51 1-27 57 1-34 60 51-19 48 017082016 51 018500836 1-57 64 9-90 70 008400604 9-5 56 1-3 23 56 1-47 64 9-91 70 1-9 44 017083016 84 018501022 1-47 57 025040136 152 18 1-2-9 44 018060636 1-58 30 018501036 1-21 44 025040136 42 8 50-2 48 018061236 1-106 32 1-21 44 025040233 1-23 34 51-2 48 018061422 1-35 54 9-9 48 025040236 52 52 104 68 018061436 1-50 40 9-13 48 60 75 57 1-34 30 018501236 1-13 68 025050236 1-29 60 82 57 018061636 1-51 70 9-42 64 1-34 60 101 57 018062022 1-2 64 1-2-13 44 1-45 64 163 57 018062036 1-5 44 X5 44 9-44 68 165 57 1-2-5 60 1-37 57 025060236 1-8 30 181 58 1-3 60 1-22 64 1-34 30 195 58 1-35 60 1-32 64 1-62 30 1-30 60 18 66 121 56 025060236 1-109 32 1-51 64 018062536 9-52 68 018501436 154 57 1-36 30 1-60 66 018063022 202-2 26 1-32 60 1-62 30 12 66 018063036 N2 26 018501622 1-42 60 1-83 30 14 72 1-46 26 A11 30 1-103 30 33 72 1-107 32 1-6 30 1-5 56 008400804 1-10 80 018064036 1-56 30 1-27 60 86 57 012060636 14 018081636 1-85 30 9-17 68 1-3 44 018082036 1-50 30 025080336 9-17 68 1-2-3 44 018083036 1-34 30 9-23 68 1-7 56 018083036 1-54 30 025100232 1-16 56 1-17 64 151 57 9-54 68 025100236 1-6 30 123 66 9-77 70 018502036 1-37 56 1-31 30 9-37 68 018082536 9-15 70 1-9 64 9 56 012081636 63 018083036 1-101 57 1-40 60 025680132 1-15 6 012300336 13 1-81 30 16 60 025710232 12-3 14 012400436 1-18 60 018102036 1-29 30 018503036 1-112 32 025710232 39 1-13 60 3 56 3 22 9-74 70 018103036 7 56 9-6 60 025050136 31-18-6 72 23 60 018108036 1-4 30 021060206 9-82 70 026060136 1-58 64 jintex.in 80

Page 84

索引 / INDEX CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page 028030242 W4 52 047200642 Q1-7 28 0A4300805 Q1-4 28 112592001 1-4-1 6 028030246 1-1-8 12 047301042 1-16 34 0A4400805 1-10 54 112593001 1-5 6 1-2-8 12 048025342 1-2-25 44 0A5300805 21 6 112684001 B5-1 2 9-58 68 048050346 1-15 54 0A5400805 Q1-13 5 112700001 27-1 14 028040243 1-22 34 048060142 1-13 24 112709001 1-20 20 1-25 60 1-15 40 3 20 028040246 30 4 048100142 1-12 24 112712001 1-10 20 41 8 048150142 1-14 64 112717001 10 16 61 57 048160242 1-11 60 112721001 1-6 6 204 58 048200142 1-54 30 112728001 56 16 1-20 60 052400606 1-16 54 112735001 58 16 1-33 60 060400812 1-2-16 44 112753001 16 28 060660512 1-14 44 112753001 16 1-25 64 060681212 1-130 18 113014000 10 4 1-28 64 062060806 31-3-1 72 113024000 25 4 9-20 68 062061012 P1-4 28 113386000 A2 2 N7 26 062300606 P1-8 28 114483002 22 74 028050246 4 36 062300606 P1-9 28 114486002 32 74 1-38 30 062300616 1-6 34 114693001 57 16 1-113 44 062300806 1-102 66 115157001 1 74 1-14 44 062301006 102 66 100064002 2 115503001 1-20 44 1-2-14 52 062301205 1-6 54 100136001 1-20 46 1-4-1 48 X6 60 062302506 W3 52 100250001 7 116920001 1-16 64 1-7 60 062400805 203 58 100251001 B5-2 4 1-28 60 062401006 1-24 34 117436001 Q1-5 28 1-38 60 062501406 31-18-2 72 117466000 20 74 17 66 100401001 1-19 18 117936001 1-17 54 9-4 68 062503506 31-18-3 72 100645003 N6 26 117936001 1-17 74 9-14 68 062670512 31-19-3 72 100887001 10 74 118064001 3 57 9-45 68 101572101 18 74 118550001 62-2 74 9-55 68 101706001 11 4 118837001 17 74 31-11-2 72 23 102731004 1-2 6 118954000 3 8 028060246 N11 26 104821001 A8 2 120752001 41 22 1-86 30 148 31 16 122991001 15 74 1-108 32 170-3 135 18 126863001 31-6 72 31 40 105173004 169 58 131007001 B5-3 2 1-1-6 44 062670612 101 105173004 169 57 133172003 180 58 1-2-6 44 151 105216001 19 8 138843001 31-13 72 52 062670812 1-4-2 16 107017002 9 64 140527001 13-1 20 57 1-10 6 107153002 41 56 140682001 1-111-4 32 1-4 64 107780001 9 74 1-6 36 028080246 1-35 30 062671412 78 108254001 1-4 20 2-4 36 1-51 30 33 108265009 1-6 20 140890009 30 16 1-61 30 062680812 6 108266001 64 141544001 46 22 1-82 30 062681212 31 108802001 64 141598001 11 70 1-102 30 30 110064002 25 142002001 6 1-4 56 062681412 1-4 26 142205001 11 74 85 57 062681412 1-10 10 142274101 21-2 4 24 66 062710612 1-23 110161006 12-4 18 200-4 18 9-16 68 062711212 11 110744002 10 142443001 16 74 028100246 5 30 062782512 30 111140002 26 142721001 4 74 1-5 30 072600480 B6-2 111865001 131 62 142990001 31-16-3 72 1-30 5 076002450 1-11 111942001 1-12 34 144504001 1-16 20 5 56 081014670 1-7 111943001 1-13 34 144526001 37 22 028260242 8 087310815 1-8 112301001 12-3 20 144875001 B13 2 1-28 34 087311015 1-10 112467002 B15 4 145446001 1-13 20 032311306 2 34 112576001 13 6 145446001 1-18 34 032422505 3 54 0A4300605 45 112590001 1-1 40 145480001 1-18 34 039411215 94 57 110 112590001 1-1 40 81 jintex.in

Page 85 — 索 引 / INDEX

索 引 / INDEX CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page 145446001 1-18 34 153012101 200 6 S04557000 149 18 S08604001 1-1 20 145571101 1-17 34 153057102 33 8 1-130 32 S08605101 1-22 20 146124001 1-5 20 153208002 10 101 32 S08606001 1-23 20 146141001 8 4 X11 62 S08607001 1-2 20 146197001 1-21 34 153230101 170-2 57 S06994001 35 20 S08608001 1-3 20 146360002 38 153242000 W8-5 74 S07327001 147 16 S08609201 1-24 20 146427001 1-1 10 S07333001 41-2 36 S08610101 1-25 20 1-2-1 10 S07334001 22 18 S09043000 17 16 148005001 12-2 14 153252000 5-2 36 S07338001 24 4 S09132051 202 6 148394000 29 16 S07339200 26 14 S09141000 74 42 148536001 48 22 153274001 1-11-5 52 S07417001 9 14 S09142000 75 42 148539101 27 153568001 19 56 S07436001 24 14 S09200001 5-1 14 148762001 37 154024001 1-19 57 S07446001 25 14 S09259001 5 14 B17 16 154125001 1-8 74 S07459100 200-3 14 S09260001 6-1 14 148821001 37 154250001 1-17 20 S07462000 69 14 S09261001 6-2 14 B6-3 2 154560001 1-18 20 S07463000 70 14 S09273001 23-1-2 14 B17 2 154886001 58 56 S07464100 200-5 38 S09284001 23-2-5 14 149287000 72 154965001 52 14 S07465000 55 38 S09285051 41 14 73 121 155479001 23-2-1 14 S07469001 129-7 70 S09295000 42 14 149566109 1-15 20 15551000 159 72 S07471001 22 16 S10078001 1-17 60 149796001 20 15811500 1-17 72 S07476000 36 16 S10079101 1-18 60 150172003 31-17 72 15815000 1-19 72 S07477000 4 60 S10133000 1-5 60 150173003 31-10 72 158581000 1-4 74 S07478000 5 60 S10134001 1-14 60 150174000 31-9-1 72 158597001 1-32 56 S07481009 144 40 S10243000 120 50 150179002 31-11-1 72 158768001 1-7 60 S07487101 1-8 64 S10243000 Q1-12 28 150182000 31-5 72 158769001 1-12 60 S07490001 1-19 60 S10661109 14 56 150183000 31-16-2 72 159027001 50 60 S07519001 31 60 S10859001 77 38 150185009 31-12 72 15915000 159 75 S07520001 32 60 S11433000 1-1-22-3 44 150189109 31-1 74 159805001 A9 75 S07521001 35 46 S11433000 1-2-22-3 46 150235001 2 8 159805001 1-10 70 S07522001 36 60 S11521001 24-1 75 150335001 2 159928000 1-14 70 S07524101 43 60 S11522001 24-2 75 150553003 13-2 20 159928000 1-14 70 S07525000 45 75 S11523001 24-3 75 150936001 5 8 62501000 121 75 S07527001 49-1 75 S11524001 24-4 75 150937101 6 8 J02727001 W8-7 75 S07571000 39 75 S11525001 24-5 60 150938201 7 14 J80869001 N12 75 S07658001 27 60 S11526001 24-6 60 150967101 11 14 S00480000 70 75 S07783001 7 60 S11527001 24-7 60 150988001 9 14 S00554000 73 76 S07876101 91 60 S12067000 1-13 64 151027001 23-1-1-1 14 S01943001 19 76 S08030000 W8-4 53 64 S12076000 1-8 64 151029001 23-2-2 14 S02606000 139 76 S08132001 12 64 S12078000 1-5 64 151030001 23-2-3 14 S02738000 91 76 S08170001 13 64 S12079000 1-7 64 151090001 8 16 S02739000 93 76 S08205000 205 44 S12150000 1-1-22-2 44 151148001 1-27 20 S02740000 92 72 S08238000 9-28 68 S12150000 1-2-22-2 46 151951001 37 56 S02767409 31 72 S08239000 9-29 68 S12150000 50-10-2 48 152356301 1-1 34 S02779000 31-15 72 9-30 68 S12150000 51-10-2 48 152361001 1-10 34 S02788000 31-16 72 S08240000 9-30 68 S12445051 B5 70 152362001 1-11 34 S02789000 31-16-1 72 S08280000 9-50 68 S12463001 44 2 152363001 1-15 34 S03999000 21-1 72 S08320000 9-27 40 S12463001 44 2 152364001 1-31 72 S04109000 15 72 S08338001 9-35 36 S12506000 9-4 14 152565000 W8-2 52 S04505000 107 72 S08339001 9-36 14 S13021001 16 60 152566000 W8-1 50 S04557000 71 72 S08342001 9-31 60 S14050001 25-1 60 152645001 1-5 74 S08352000 9-12 60 152651401 1 34 152725000 202-1 6 152914001 N4 26 153011014 A4-2 2 153011016 7-1 A4-1 2 153011018 A4-3 2 153011416 7 72 jintex.in 82

Page 86 — 索引 / INDEX

索引 / INDEX CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page S14050001 25-2 60 S38213051 12-1 14 S42466001 32 56 S52486101 A12 2 S14051001 Ga1 75 S38237001 B7 2 S42619001 1-17 56 S52487001 5 4 Ga1 75 S38241051 14 4 S42867001 1-2 54 S52490001 P1-20 28 S14189100 200-1 18 S38244100 17 4 S43192200 1-21 60 70 S14666000 1-1-22-1 44 S38245051 B7-1 2 S44807000 1-5-1 54 S52491001 28 4 1-2-22-1 46 S38248001 3 16 S46191001 1-55 30 S52493001 N1 26 6 50-10-1 48 S38251000 119 16 S46583000 96 57 S52495101 1 6 51-10-1 48 S38253001 B4 2 S46738000 20 40 S52497001 1-7 6 S14677001 5 20 S38261001 120 16 S47900000 7-1 40 S52498001 1-8 6 M1-3 26 S38264001 121 16 S48715000 2 8 S52499001 1-9 6 S14696001 8 74 S38266000 35 16 S48716001 A 8 S52500001 1-11 6 S14703001 10 70 S38270001 38 16 S48724001 B2-1 2 S52507001 1 8 S14753001 22 60 S38274001 1-9 16 S48732001 B14 16 S52508001 11-1 8 S14874000 43 8 S38292001 6 16 S48734000 76 16 S52509001 12 8 S15097000 M1-1 26 124 S48737000 108 16 S52510001 14 8 S15584509 1 20 S38295000 B1 2 S48738000 109 16 S52514001 17 8 S16350001 15 8 S38299001 7 16 S48739001 110 16 S52518000 28 8 S16603000 15-2 24 S38352101 Wa 79 S48740001 111 16 S52519000 28-1 8 S16669000 1-33 34 S38353101 Wa 79 S48760001 12-1 20 S52521001 30 8 S17533000 9-8 68 S38357001 Wa 79 S48761001 12-2 20 S52523001 A10 2 S17971000 39 56 S38357002 Wa 79 S48763001 129-1 18 S52524001 1-13 6 S20355002 19 70 S38360001 6 4 S48776000 11 8 S52525001 8 10 S20849101 38 8 S38396001 9 4 S49491000 1-1-1 54 S52536001 4-3 10 S21008001 9-71 70 S38398001 1 4 S49495000 1-3 54 Ga1 75 S21009001 9-72 70 S38404001 21 4 S49529001 12 20 S52537001 4-1 10 S21195001 82 16 S38419001 28 22 S49530001 12-4 20 Ga1 75 S21196001 134 18 S38420001 29 22 S49564002 132 18 S52538001 4-2 10 S21798001 31-11 72 S38448000 200-2 18 S49638001 40 56 Ga1 75 S21931001 5 10 S38541000 75 16 S51283001 31-4 72 S52539001 4-3 10 S27844201 1-22 60 S38541007 75 16 S52427000 7-2 40 Ga1 75 S29742001 1-54 64 S38571001 Wa 79 S52439000 17 40 S52540001 4-3 10 S29863001 1-4 6 S38571002 Wa 79 S52440000 18 40 Ga1 75 S30014001 9-73 70 S38820000 95 57 S52441000 19 40 S52541001 4-3 10 S30229000 W8-6 52 S39110001 A13 2 S52442000 32 40 Ga1 75 S30505001 13 20 S39115100 P1-21 28 S52443000 25 40 S52542001 4-3 10 S31258001 1-1-30 44 1-2 36 S52444000 26 40 Ga1 76 S31258001 1-2-30 46 2-1 36 S52445000 33 40 S52549001 47-3 22 S31760000 76 42 S39116100 1-11-2 32 S52446000 36 40 S52550001 41 16 S31921000 9-38 68 1-1 36 S52447000 34 40 S52551000 41-1 16 S32294001 1-40 60 1-1 36 S52448000 35 40 S52552000 42 16 S32843001 32 8 S39122000 14-3 70 S52449000 46 40 S52553000 43 16 S35032101 1-27 34 S39821000 100 32 S52450000 43 40 S52556000 45 16 S36260000 1-5-2 54 76 S52451000 109 66 S52557000 46 16 S36355001 26 8 S39847001 1-26 34 S52452000 100 66 S52558000 47 16 S36924001 Wa 79 210 62 S52453000 100 62 S52559000 48 16 S36924002 Wa 79 S39902001 1-29 72 S52454000 100 48 S52560001 41-3 16 S37058001 Wa 79 S40494000 X7 52 S52457000 27 40 S52561001 3-3 10 S37059001 Wa 79 S40583000 98 57 S52458000 8 54 Ga1 75 S37060001 Wa 79 S40616001 12 40 S52459000 3 34 S52562001 3-1 1 10 S37968001 42 56 S40620001 10 40 S52460000 4 34 Ga1 75 S38059000 1-20 54 S40639001 31-9 72 S52461000 48 40 S52563001 3-2 10 S3811000 24 40 S40641001 31-18 72 S52462000 Q1-11 28 S52564001 3-3 10 S38166000 1-1 54 S40643001 31-19 72 S52465000 X1-1 52 Ga1 75 S38170001 1-4 54 S40884000 1-1 56 S52468000 102 70 S52565001 3-3 10 S38174001 1-8 54 S41964000 194 58 S52469000 P1-1 28 Ga1 75 S38175001 1-9 54 S42445001 1-1 60 S52470001 5-1 40 S52566001 3-3 10 S38176101 1-10 54 S42446001 1-11 21 S52475000 9 40 Ga1 76 S38177001 1-14 54 S52450000 100 40 S52567001 3-3 10 S38212001 50 14 S52453000 100 40 Ga1 76 83 jintex.in

Page 87 — 索引 / INDEX

索引 / INDEX CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page S52571001 6 10 S53171000 M1 26 S3467000 10-2 12 S53541000 1-1-22 44 S52572001 Ga1 75 S53172001 40 22 S53469000 Ga2 78 1-2-22 46 S52573001 Ga1 75 S53174000 36 18 S53469000 20-2 12 S53541000 50-10 48 S52574001 6 10 S53175000 129-2 18 S53471000 Ga2 78 50-11 48 S52575001 Ga1 75 S53176000 129-3 18 S53471000 10-2 12 S53542000 50-10-3 48 S52576001 6 10 S53177000 129-4 18 S53473000 Ga2 78 51-11 48 S52577001 Ga1 75 S53178000 129-5 18 S53473000 20-2 12 S53543001 1-1-23 44 S52579002 23 14 S53179000 129-6 18 S53488000 Ga2 78 1-2-23 46 S52675902 23 14 S53180000 13 8 S53488000 28-3 12 1-24 44 S52677001 23-2 14 S53195000 145 18 20-2 46 S52679001 129 18 S53490001 24 S53545001 1-1-26 44 S52724000 104 62 S53422000 P1-6 28 Ga1 75 1-2-26 46 S52727000 8 40 S53423000 P1-7 28 S53490001 23 24 S53546001 1-1-28 44 S52732000 40 40 S53425001 Q1 28 Ga1 75 1-2-28 46 S52733000 41 40 S53426001 Q1-1 28 S53495001 23 24 S53547001 1-1-29 44 S52741000 WB-3 52 S53427001 Q1-6 28 Ga1 75 1-2-29 46 S52744000 47 40 S53428000 Ga1 28 S53496001 2-3 24 S53548000 1-1-31 44 S52749000 W5 52 S53430001 1-1-1 75 Ga1 75 1-2-31 46 S52750000 W6 52 S53430001 1-1-1-1 12 S53498001 3-2 24 S53552000 1-1-34 44 S52751000 W7 52 S53430002 1-2-1-1 75 Ga1 75 1-2-34 46 S52758000 Q1-3 28 Ga1 12 S53501101 3-3 24 S53553000 1-1-35 44 S52759000 100 70 Ga1 12 Ga1 75 1-2-35 46 S52760000 1 40 S53431001 1-1-2 75 S53503101 3-3 24 S53554001 1-2 44 S52952001 29 40 Ga1 12 Ga1 75 1-2-4 46 S52957000 1-18 54 S53432000 1-2-3 12 S53507001 4-2 24 S53555001 1-1-1 44 S52958000 1-19 54 Ga1 12 S53508001 4-3 75 1-2-1 46 S52959000 1-5 54 S53434000 1-3-4 12 S53512101 7 24 S53560000 50-1 48 S52960001 1 54 Ga1 12 S53513001 9 24 51-1 48 S52961000 P1-2 28 S53435000 1-2 12 S53514001 11 24 S53567001 50-3 48 S52962000 P1-3 48 S53436000 1-2-1 12 S53515000 15 24 51-3 48 S52963000 101 48 Ga1 75 S53516000 15-1 24 S53568001 50-4 48 S52963000 102 52 S53437000 1-2-3 12 S53518001 1-1-6 75 51-4 48 S52965001 103 48 Ga1 12 1-2-6 46 S53569001 50-6 48 S52966000 Q1-2 28 S53438000 1-2 12 S53521001 2-3 24 50-11 48 S52970000 5-2 40 Ga1 12 Ga1 75 S53571001 50-12 48 S52973000 97 57 S53445000 10-2 12 S53523001 3-3 24 51-13 48 S52973000 70 38 Ga2 77 Ga1 75 S53572001 50-13 48 S52974000 120 66 S53449000 20-2 77 S53531000 1 24 51-14 48 S52975001 1 54 S53451000 10-2 12 S53532001 1-1 75 S53573001 50-14 48 S52976000 1-1 54 Ga2 77 1-1-4 24 51-15 48 S52977000 1-1-2 54 S53453000 10-2 12 S53533001 1-1-4 75 S53574000 50-15 48 S52978000 1-1-3 54 Ga2 77 1-2-17 44 51-16 48 S52979000 1-2 54 S53455000 10-2 12 S53534100 1-1-8 24 S53575001 50-16 48 S52980000 2 54 Ga2 77 1-2-8 46 51-17 48 S52985000 X10 52 S53460000 10-2 12 S53535001 1-1-10 44 S53576001 50-19 48 S52986000 102 62 S53457000 20-2 77 1-2-10 46 51-20 48 S52989000 X1 52 S53461000 10-2 12 S53536001 1-1-11 44 S53577000 50-21 48 S52991000 12 32 Ga2 77 1-2-11 46 51-22 48 S53000001 W1 52 S53463000 10-2 12 S53537001 1-1-12 44 S53580001 50-22 48 S53007001 W8 52 Ga2 77 1-2-12 46 51-23 48 S53010001 1-6 54 S53465000 10-2 12 S53538101 1-1-15 44 S53581000 51 50 S53166000 N8 26 Ga2 77 1-2-15 46 51-6 50 S53167000 29 8 S53469000 10-2 12 S53539001 1-1-17 44 S53582001 107 50 S53168000 28-2 8 Ga2 77 1-2-17 46 108 50 S53169001 34 8 S53540001 1-1-19 44 S53584000 109 50 1-2-19 44 S53585001 111 50 50-7 48 S53586000 105 48 51-7 48 S53617000 P1-10 28 jintex.in 84

Page 89 — 索引 / INDEX

索引 / INDEX CODE REF.NO Page CODE REF.NO Page CODE REF.NO Page S57938000 9-11-1 68 S59217000 9 36 S59297000 Ga1 76 S57942000 X1-2 52 S59218000 9-1 36 S59298000 20 12 S58034000 45 S59219000 5-4 36 Ga1 76 S58035000 39 9-2 36 S59338001 34 74 S58036000 40 S59235001 9-3 36 S59350001 35 74 S58037000 37 S59271000 10 36 S59357001 N5 26 S58038000 38 10 12 S59368000 1-11-3 32 S58040000 26 Ga1 75 S59371001 P1 28 S58040000 26 S59272000 10 12 S59372000 2-3 36 S58179001 1-1 30 Ga1 75 S59387000 1-118 32 S58180001 1-1 30 S59273000 20 12 W01519001 10-3 12 S58181001 1-64 30 Ga1 75 20-3 12 S58181101 1-65 30 S59274000 10 12 30-3 12 S58183000 1-111 32 Ga1 75 50-3 12 S58184000 1-111-1 32 S59275000 10 12 XA2220050 1-9 54 S58204001 1-1-18 44 30 Ga1 75 1-2-18 44 Ga1 75 S58594000 9-43 68 S59276000 10 12 S58675000 1-1 12 Ga1 75 S58692001 9-70 70 S59277000 20 12 S58693000 13 32 Ga1 75 S58900000 3 46 S59278000 20 12 S58903000 2-6 46 Ga1 75 S59031000 1-59 30 S59279000 10 12 S59032000 5 24 50 12 S59033000 9-69 70 Ga1 75 S59034000 9-68 70 S59280000 10 12 S59035000 9-59 70 Ga1 75 S59036001 21 24 S59281000 20 12 S59041000 10-1 12 Ga1 75 30-1 12 S59282000 20 12 50-1 12 Ga1 75 S59042000 20-1 12 S59283000 10 12 S59043001 9-62 70 Ga1 75 S59044001 9-61 70 S59284000 20 12 S59045001 1-3 6 Ga1 75 S59046001 9-53 68 S59285000 10 12 S59047001 9-85 70 Ga1 75 S59048001 9-56 68 S59286000 20 12 S59139001 1-3 10 Ga1 75 Ga1 75 S59287000 10 12 S59140001 1-1 10 Ga1 75 Ga1 75 S59288000 10 12 1-1 10 Ga1 75 Ga1 75 S59141001 1-2 10 S59289000 20 12 Ga1 75 Ga1 75 S59142001 1-3 10 S59290000 10 12 Ga1 75 Ga1 75 S59143001 1-3 10 S59291000 20 12 Ga1 75 Ga1 75 S59144001 1-3 10 S59292000 10 12 Ga1 75 Ga1 75 S59145001 1-3 10 S59293000 20 12 Ga1 75 Ga1 75 S59149001 18 8 S59294000 10 12 S59150001 22 8 Ga1 75 S59151001 23 8 S59295000 20 12 S59152001 16 72 Ga1 75 S59155000 20 24 S59296000 10 12 S59156000 20-1 24 Ga1 75 S59158001 22 24 S59297000 20 12 86 Jjnte.in

Page 90

brother. パーツブック PARTS BOOK ブラザー工業株式会社 〒467-8561 名古屋市瑞穂区苗代町 15番1号 TEL (052) 824-2392 BROTHER INDUSTRIES, LTD 15-1, Naeshiro-cho, Mizuho-ku, Nagoya 467-8561, Japan. Phone : 81-52-824-2177 Printed in Japan 151-615 S98615-001 2001.11. F (1) jintex.in
