Brother HE-800A Parts Book (PDF)
Text index — Brother HE-800A
Page 5 — A. 主体関係 / Machine body
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50124001 | FACE PLATE | 1 |
| 2 | 062711012 | SCREW PAN SM4.76-32X10 | 4 |
| 3 | SA4206001 | THREAD TAKE-UP LEVER COVER | 1 |
| 4 | 062680612 | SCREW PAN SM4.37-40X6 | 1 |
| 5 | S50126001 | REAR COVER | 1 |
| 6 | 062711012 | SCREW PAN SM4.76-32X10 | 6 |
| 7 | S50127101 | TOP COVER | 1 |
| 8 | 062711612 | SCREW PAN SM4.76-32X16 | 6 |
| 9 | S50128201 | ROTARY HOOK COVER | 1 |
| 10 | 104450101 | RUBBER CAP, 8 | 1 |
| 11 | 158879001 | SHAFT, ; R-HOOK COVER | 1 |
| 12 | S00306001 | HINGE PLATE SPRING | 1 |
| 13 | 025080132 | WASHER PLAIN S 8 | 1 |
| 14 | 048060342 | RETAINING RING E6 | 1 |
| 15 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 16 | 117143003 | SCREW, FLAT SM4.37 | 2 |
| 17 | 021680202 | NUT 2 SM4.37-40 | 2 |
| 18 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 2 |
| 19 | 158830001 | BED HINGE | 2 |
| 20 | 158831001 | PIN | 2 |
| 21 | 158832000 | PIN SUPPORT RUBBER | 2 |
| 22 | 159150000 | RUBBER CAP, 20.5 | 1 |
| 23 | 159150000 | RUBBER CAP, 20.5 | 1 |
| 24 | 104449001 | RUBBER CAP, 15.5 | 1 |
| 25 | 104451101 | RUBBER CAP, 23.9 | 1 |
| 26 | 104450101 | RUBBER CAP, 8 | 2 |
| 27 | 104450101 | RUBBER CAP, 8 | 2 |
| 28 | 104450101 | RUBBER CAP, 8 | 1 |
| 29 | 104449001 | RUBBER CAP, 15.5 | 1 |
| 30 | 104449001 | RUBBER CAP, 15.5 | 1 |
| 31 | 104450101 | RUBBER CAP, 8 | 1 |
| 32 | 104450101 | RUBBER CAP, 8 | 1 |
| 33 | 104450101 | RUBBER CAP, 8 | 1 |
| 34 | 104450101 | RUBBER CAP, 8 | 2 |
| 35 | 104450101 | RUBBER CAP, 8 | 1 |
| 36 | 104449001 | RUBBER CAP, 15.5 | 2 |
| 37 | S32263001 | RUBBER CAP, 8.5 | 3 |
| 38 | S36924001 | INJURY MARK | 2 |
| 39 | S37060001 | LABEL, GROUNDING | 2 |
| 40 | S50131001 | THREADING DIAGRAM | 1 |
| 41 | 104449001 | RUBBER CAP, 15.5 | 1 |
| 42 | S50340000 | BED BASE CUSHION | 2 |
| 43 | 120263001 | SHOULDER SCREW,SM4.37 | 2 |
| 44 | 117936001 | RUBBER CAP, 9.4 | 1 |
| 45 | SA0793001 | LABEL CAUTION CHN/ENG | 1 |
| 46 | SA0792001 | LABEL CAUTION JPN/ENG | 1 |
Page 7 — Needle bar and thread take-up mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50132000 | THREAD TAKE-UP CRANK | 1 |
| 2 | 100250001 | SCREW, SM7.14 | 1 |
| 3 | 014770632 | SET SCREW SOCKET SM6.35-40X6 | 1 |
| 4 | 110367001 | WASHER, PLAIN SPECIAL 8 | 1 |
| 5 | SA4047301 | NEEDLE BAR CONNECTING ROD SET | 1 |
| 6 | 145465001 | SCREW, SM3.57-40X6 L | 1 |
| 7 | S50136101 | NEEDLE BAR CLAMP SET | 1 |
| 8 | 140004001 | SCREW, SM3.57-40X7 | 1 |
| 9 | S52943101 | SUPPORT SHAFT | 1 |
| 10 | 140430001 | WICK, 3X40 | 1 |
| 11 | S50271000 | WICK, 2X35 | 1 |
| 12 | S50272000 | WICK, 3X15 | 1 |
| 13 | S50142000 | WICK, 3X290 | 1 |
| 14 | S52248001 | N-BAR BRACKET SLIDE BLOCK | 1 |
| 15 | 014770632 | SET SCREW SOCKET SM6.35-40X6 | 2 |
| 16 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 17 | S50143001 | NEEDLE BAR BRACKET SET | 1 |
| 18 | S50144001 | NEEDLE BAR BASE ASSY | 1 |
| 19 | 159624001 | N-BAR BRACKET SLIDE BLOCK | 1 |
| 20 | S50146001 | STOPPER PLATE | 1 |
| 21 | 158888001 | N-BAR BASE SUPPORT SHAFT | 1 |
| 22 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 23 | S50147001 | NEEDLE BAR BASE GUIDE | 1 |
| 24 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 25 | SA2921101 | NEEDLE BAR | 1 |
| 26 | S50149101 | NEEDLE BAR THREAD GUIDE | 1 |
| 27 | 140553102 | SET SCREW, SM3.18 | 1 |
| 28 | S50150001 | CRANK ROD GUIDE | 1 |
| 29 | S31808001 | SCREW, PAN SM4.37-40X25 | 1 |
| 30 | 150382001 | BOLT, SOCKET SM4.37X18 | 2 |
| 31 | S50152001 | NEEDLE BAR GUIDE | 1 |
| 32 | 154965001 | BOLT, SOCKET SM3.57X8 | 2 |
| 33 | S50153101 | STOPPER | 1 |
| 34 | 153483001 | SET SCREW, SM4.76 | 1 |
| 35 | 021710202 | NUT 2 SM4.76-32 | 1 |
| 36 | 013761410 | SET SCREW (CP) SM5.95-28X14 | 1 |
| 37 | 100022005 | NUT, SM5.95 | 1 |
| 38 | 062681012 | SCREW PAN SM4.37-40X10 | 2 |
Page 9 — C. 上軸関係 / Upper shaft mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50154001 | UPPER SHAFT | 1 |
| 2 | 048150142 | RETAINING RING EXTERNAL C15 | 2 |
| 3 | 072630260 | BALL BEARING, THRUST 6302VV | 1 |
| 4 | SA4065001 | BUSH, F | 1 |
| 5 | 158893100 | BUSH M | 1 |
| 6 | S50156001 | SET SCREW COLLAR | 1 |
| 7 | 014780632 | SET SCREW SOCKET SM6.35-28X6 | 2 |
| 8 | S50157001 | PULLEY ASSY | 1 |
| 9 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 2 |
| 10 | S50159001 | T-PULLEY ASSY, U | 1 |
| 11 | S50160001 | T-PULLEY, U | 1 |
| 12 | S48034001 | RING | 2 |
| 13 | 014780632 | SET SCREW SOCKET SM6.35-28X6 | 2 |
| 14 | S50161000 | TIMMING BELT | 1 |
| 15 | S50163001 | TENSION PULLEY PLATE | 1 |
| 16 | S50164001 | TENSION PULLEY | 1 |
| 17 | S50165001 | COLLAR | 1 |
| 18 | 018102536 | BOLT SOCKET M10X25 | 1 |
| 19 | 021100302 | NUT 3 M10 | 1 |
| 20 | 048300242 | RETAINING RING INTERNAL C30 | 2 |
| 21 | 076200800 | BALL BEARING RADIAL 6200ZZ | 1 |
| 22 | 018061632 | BOLT SOCKET M6X16 | 2 |
| 23 | 025060232 | WASHER PLAIN M 6 | 2 |
| 24 | S50166001 | IDLER PULLEY | 1 |
| 25 | S50167001 | SHAFT | 1 |
| 26 | S50168001 | COLLAR | 1 |
| 27 | 070608800 | BALL BEARING RADIAL 608ZZ | 2 |
| 28 | 048220242 | RETAINING RING INTERNAL C22 | 2 |
| 29 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 2 |
| 30 | 111865009 | CAP, 6 | 1 |
Page 11 — D. 針振り関係 / Zigzag mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50169001 | MOTOR BRACKET | |
| 2 | S37940001 | POSITIONING PIN | |
| 3 | 062711212 | SCREW PAN SM4.76-32X12 | |
| 4 | 062711612 | SCREW PAN SM4.76-32X16 | |
| 5 | 018401232 | BOLT SOCKET M4X12 | |
| 6 | 060300612 | SCREW BIND M3X6 | |
| 7 | SA2881001 | MOTOR LEVER | |
| 8 | S50171001 | MOTOR LEVER SHAFT | |
| 9 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | |
| 10 | S50172001 | ZIGZAG CONNECTING ROD | |
| 11 | S51190001 | Z-CONNECTING ROD SHAFT | |
| 12 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | |
| 13 | S50174001 | ZIGZAG LEVER | |
| 14 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | |
| 15 | 118735001 | WASHER | |
| 16 | 018062032 | BOLT SOCKET M6X20 | |
| 17 | S32521001 | WASHER, THRUST | |
| 18 | S50176001 | ZIGZAG LEVER ASSY, F | |
| 19 | S50178001 | Z-LEVER SHAFT | |
| 20 | 159625001 | STUD | |
| 21 | 158945001 | BUSH, F; Z-LEVER | |
| 22 | 158946001 | BUSH, R; Z-LEVER | |
| 23 | S50179001 | Z-SENSOR PLATE |
Page 13 — E. 非常停止関係 / Emergency stop mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50182000 | EMERGENCY STOP COVER | 1 |
| 2 | 062400806 | SCREW PAN M4X8 | 3 |
Page 15 — F. 押え関係 / Presser foot mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50183001 | PRESSER DRIVING ARM | 1 |
| 2 | 018061032 | BOLT SOCKET M6X10 | 4 |
| 3 | S43717201 | GEAR, 15.75 | 1 |
| 4 | 014770632 | SET SCREW SOCKET SM6.35-40X6 | 2 |
| 5 | S50184001 | GUIDE BRACKET | 1 |
| 6 | S42116000 | LINEAR BUSH | 2 |
| 7 | S50185001 | BEARING HOLDER | 1 |
| 8 | 018400832 | BOLT SOCKET M4X8 | 1 |
| 9 | S50186001 | GUIDE SHAFT | 2 |
| 10 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 4 |
| 11 | S50187001 | DRIVING ARM PRESSER | 1 |
| 12 | 110367001 | WASHER, PLAIN SPECIAL 8 | 1 |
| 13 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 14 | 018401232 | BOLT SOCKET M4X12 | 3 |
| 15 | S50189001 | P-LOFTER CONNECTING ROD | 1 |
| 16 | S50190001 | SHOULDER SCREW | 1 |
| 17 | S50191001 | ROLLER | 1 |
| 18 | 110161004 | NUT, SM4.76 | 1 |
| 19 | 028050242 | WASHER SPRING 2-5 | 1 |
| 20 | S50192101 | SPACER | 1 |
| 21 | SA3001001 | WASHER, PLAIN L 4.8: D | 1 |
| 22 | 117363001 | BOLT, SM4.76 | 1 |
| 23 | S38761201 | LIFTER LEVER KNEE | 1 |
| 24 | S50192101 | SPACER | 1 |
| 25 | SA3001001 | WASHER, PLAIN L 4.8: D | 1 |
| 26 | 117363001 | BOLT, SM4.76 | 1 |
| 27 | S50193001 | LIFTER SHAFT, A | 1 |
| 28 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 29 | S50195001 | U-THREAD TRIMMER DRIVING LINK | 1 |
| 30 | S38761201 | LIFTER LEVER KNEE | 1 |
| 31 | 145478101 | SHOULDER SCREW, SOCKET SM4.76 | 1 |
| 32 | S50196001 | LIFTER SHAFT | 1 |
| 33 | 025080132 | WASHER PLAIN S 8 | 1 |
| 34 | 048060342 | RETAINING RING E6 | 1 |
| 35 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 36 | 145478101 | SHOULDER SCREW, SOCKET SM4.76 | 2 |
| 37 | S50198001 | PRESSER BAR GUIDE BRACKET | 1 |
| 38 | S50199101 | PRESSER BAR LINK | 1 |
| 39 | 145478101 | SHOULDER SCREW, SOCKET SM4.76 | 1 |
| 40 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 41 | 111466121 | PRESSER BAR | 1 |
| 42 | SA7607001 | SPRING GUIDE | 1 |
| 43 | S50200001 | PRESSER BAR SPRING | 1 |
| 44 | S31013001 | PRESSER ADJUSTING NUT | 1 |
| 45 | S31012001 | PRESSER ADJUSTING SCREW | 1 |
| 46 | 140407001 | WASHER | 1 |
| 47 | 145472001 | PRESSER BAR BUSH | 1 |
| 48 | S50201001 | P-BAR ROLLER BRACKET | 1 |
| 49 | S50202001 | ROLLER | 1 |
| 50 | 062671212 | SCREW PAN SM3.57-40X12 | 1 |
| 51 | 025060132 | WASHER PLAIN S 6 | 1 |
| 52 | 048060142 | RETAINING RING EXTERNAL C6 | 1 |
| 53 | S50203101 | ROLLER | 1 |
| 54 | S50204001 | ROLLER SHAFT | 1 |
| 55 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 56 | S37927000 | NEEDLE BAR GUIDE | 1 |
| 57 | 100242003 | SCREW, SM3.57-40X5 | 2 |
| 58 | 155578000 | RUBBER CAP, 7.2 | 2 |
| 59 | S50205001 | CLAMP SENSOR DOG | 1 |
| 60 | 060670512 | SCREW BIND SM3.57-40X5 | 2 |
| 61 | S50206001 | CLAMP SENSORPLATE | 1 |
| 62 | 102538002 | SCREW, FLAT SM3.57 | 1 |
| 63 | 025040232 | WASHER PLAIN M 4 | 3 |
Page 17 — G. 送り関係 / Feed mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50207001 | MOTOR MOUNTING BRACKET | |
| 2 | 062761012 | SCREW PAN SM5.95-28X10 | |
| 3 | 025060232 | WASHER PLAIN M 6 | |
| 4 | 018401032 | BOLT SOCKET M4X10 | |
| 5 | S50208001 | PULLEY, A | |
| 6 | 014060632 | SET SCREW SOCKET (CP) M6X6 | |
| 7 | S50110001 | PULLEY, B | |
| 8 | 014060632 | SET SCREW SOCKET (CP) M6X6 | |
| 9 | S50209000 | TIMING BELT | |
| 10 | S50210001 | SUPPORT SHAFT | |
| 11 | 070688850 | BALL BEARING RADIAL 688ZZ | |
| 12 | S50211101 | BELT HOLDER | |
| 13 | S59890001 | BOLT, SOCKET SM4.37-40X8 | |
| 14 | S50212001 | FEED ARM SUPPORT | |
| 15 | S50213001 | FEED GUIDE SHAFT, B | |
| 16 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | |
| 17 | S50214001 | FEED GIIDE SHAFT, A | |
| 18 | S59894001 | BOLT, SOCKET SM4.37-40X12 | |
| 19 | S12004000 | LINEAR BUSH | |
| 20 | S02460001 | RETAINING RING, EXTERNAL C19 | |
| 21 | S35184001 | BALL BEARING STOPPER | |
| 22 | 060660416 | SCREW BIND SM3.18-40X4 | |
| 23 | S50215101 | FEED SENSOR SUPPORT PLATE | |
| 24 | 062680812 | SCREW PAN SM4.37-40X8 | |
| 25 | 025680132 | WASHER PLAIN S SM4.37 | |
| 26 | S50216101 | SUPPORT SHAFT | |
| 27 | 012500536 | SET SCREW SOCKET (FT) M5X5 | |
| 28 | S50217001 | FEED ARM | |
| 29 | S50218001 | SUPPORT PLATE | |
| 30 | S50219101 | CAM | |
| 31 | S59893001 | BOLT, SOCKET SM4.37-40X10 | |
| 32 | S59892001 | BOLT, SOCKET SM4.37-40X5 | |
| 33 | 110735002 | WASHER | |
| 34 | S12004000 | LINEAR BUSH | |
| 35 | S59893001 | BOLT, SOCKET SM4.37-40X10 | |
| 36 | 028680242 | WASHER SPRING 2-4.37 | |
| 37 | S50221101 | FEED PRESSER PLATE | |
| 38 | 105130001 | SCREW, SM3.57 | |
| 39 | S50222001 | FEED ARM SUPPORT | |
| 40 | S50223100 | COVER | |
| 41 | S59890001 | BOLT, SOCKET SM4.37-40X8 | |
| 42 | 025680132 | WASHER PLAIN S SM4.37 | |
| 43 | S50224001 | FEED MOTOR COVER | |
| 44 | 062680812 | SCREW PAN SM4.37-40X8 | |
| 45 | S50562101 | SHOULDER SCREW SM6.35 | |
| 46 | 159080100 | FINGER GUARD, M | |
| 47 | 159078001 | SPRING | |
| 48 | 018502032 | BOLT SOCKET M5X20 | |
| 49 | 021500216 | NUT 2 M5 | |
| 50 | S50220001 | LENGTH FEED PLATE, -2 | |
| 51 | S37100302 | WORK CLAMP ASSY 25RS W/F-G | |
| 52 | 159762002 | WORK CLAMP 25RS | |
| 53 | 159926001 | PIN, L | |
| 54 | 107401001 | SPRING, PLATE | |
| 55 | 107404001 | SCREW, SM1.98-64X2 | |
| 56 | 159927001 | PIN, S |
Page 19 — G. 送り関係 / Feed mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 50 | S50225001 | LENGTH FEED PLATE, -3 | 1 |
| 51 | S37102301 | WORK CLAMP ASSY 25-K W/F-G | 1 |
| 52 | 144630001 | WORK CLAMP 25-K | 1 |
| 53 | 159926001 | PIN, L | 1 |
| 54 | 144707001 | SPRING, PLATE | 2 |
| 55 | 107404001 | SCREW, SM1.98-64X2 | 2 |
| 56 | 159927001 | PIN, S | 1 |
Page 21 — H. カッター関係 / Cutter mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50283001 | CUTTER DRIVING ARM SHAFT | 1 |
| 2 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 3 | S50284101 | CUTTER DRIVING SHAFT | 1 |
| 4 | S50285101 | DRIVING SHAFT HOLDER ASSY | 1 |
| 5 | S50286101 | CUTTER DRIVING SHAFT HOLDER | 1 |
| 6 | S50287001 | CUTTER DRIVING LINK SHAFT | 1 |
| 7 | 014780632 | SET SCREW SOCKET SM6.35-28X6 | 3 |
| 8 | S50288001 | CUTTER DRIVING LINK | 2 |
| 9 | 102630001 | NEEDLE BAR GUIDE SLIDE BLOCK | 1 |
| 10 | SA2385001 | GUIDE, ; C-BAR | 2 |
| 11 | 062761012 | SCREW PAN SM5.95-28X10 | 4 |
| 12 | 159117001 | BUSH, ; C-DRIVING SHAFT | 1 |
| 13 | S50289001 | ADJUSTING SCREW ASSY | 1 |
| 14 | S50290001 | ADJUSTING SCREW | 1 |
| 15 | S50291001 | CUSHION SPRING | 1 |
| 16 | S50292001 | CUSHION SUPPORT | 1 |
| 17 | S50293001 | SHOULDER SCREW, SM3.57 | 1 |
| 18 | 021910302 | NUT 3 SM12.70-20 | 1 |
| 19 | S50294001 | CUTTER HOLDER | 1 |
| 20 | S59893001 | BOLT, SOCKET SM4.37-40X10 | 1 |
| 21 | S50295001 | CUTTER HOLDER, M | 1 |
| 22 | S59891001 | BOLT, SOCKET SM4.37-40X6 | 2 |
| 23 | S50296001 | CUTTER HOLDER, DL | 1 |
| 24 | 153057102 | SCREW, ROUND W/SOCKET SM4.37 | 2 |
| 25 | S51352001 | CUTTER, 1/2 | 1 |
| 26 | 115503001 | SCREW, SM4.37 | 1 |
| 27 | S09212001 | SET SCREW COLLAR | 1 |
| 28 | 014770632 | SET SCREW SOCKET SM6.35-40X6 | 2 |
| 29 | S50298101 | CUTTER DRIVING ARM ASSY | 1 |
| 30 | S50299101 | CUTTER DRIVING ARM | 1 |
| 31 | 159104001 | PIN | 1 |
| 32 | 014680632 | SET SCREW SOCKET SM4.37-40X6 | 1 |
| 33 | 159379001 | PIN, DOWEL BX6X18 | 1 |
| 34 | S50300001 | CUTTER LINK SHAFT | 1 |
| 35 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 36 | 048060342 | RETAINING RING E6 | 1 |
| 37 | 110367001 | WASHER, PLAIN SPECIAL 8 | 1 |
| 38 | SA2412001 | CUTTER LINK BRACKET | 1 |
| 39 | S59894001 | BOLT, SOCKET SM4.37-40X12 | 1 |
| 40 | S50362001 | CUTTER SOLENOID BRACKET | 1 |
| 41 | 062711412 | SCREW PAN SM4.76-32X14 | 4 |
| 42 | 018501032 | BOLT SOCKET M5X10 | 3 |
| 43 | S50363000 | STOPPER CUSHION | 1 |
| 44 | S50364001 | SOLENOID STOPPER | 1 |
| 45 | 028080242 | WASHER SPRING 2-8 | 1 |
| 46 | 021080202 | NUT 2 M8 | 2 |
| 47 | S50365101 | CUTTER SENSOR SETTING PLATE | 1 |
| 48 | 062710812 | SCREW PAN SM4.76-32X8 | 1 |
| 49 | S50366001 | SPRING | 1 |
| 50 | S50297001 | CUTTER HOLDER | 1 |
Page 23 — J. 糸切れ感知関係 / Thread breakage detector mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50273000 | THREAD GUIDE | 1 |
| 2 | 025060232 | WASHER PLAIN M 6 | 1 |
| 3 | 025350332 | WASHER PLAIN L 3.5 | 1 |
| 4 | 060670612 | SCREW BIND SM3.57-40X6 | 1 |
| 5 | 159145001 | TR-BREAKAGE PERCEIVING SHAFT | 1 |
| 6 | 141619001 | FIXEING PLATE, ; C-BAR | 1 |
| 7 | 141620001 | BALANCER | 1 |
| 8 | 101671002 | SCREW, SM4.37 | 1 |
| 9 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 10 | S50274001 | LEVER STOPPER | 2 |
| 11 | 062400612 | SCREW PAN M4X6 | 2 |
| 12 | S50275001 | THREAD BREAKAGE SENSOR PLATE | 1 |
| 13 | 062400612 | SCREW PAN M4X6 | 2 |
Page 25 — K. かま関係 / Rotary hook mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50226001 | ROTARY HOOK SHAFT BUSH | 1 |
| 2 | SA7405001 | ROTARY HOOK JOINT UNIT | 1 |
| 3 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 4 |
| 4 | S56391001 | SET SCREW, SM3.18 | 1 |
| 5 | 021660306 | NUT 3 SM3.18-40 | 1 |
| 6 | SA7402001 | RUBBER CAP 3.7 | 1 |
| 7 | S50230001 | B-CASE HOLDER POSITION BRACKET | 1 |
| 8 | 100644005 | SCREW, SM4.37 | 2 |
| 9 | S50232000 | ROTARY HOOK FELT | 1 |
| 10 | S50231200 | COLLAR | 1 |
| 11 | S07478000 | RUBBER PRESSER | 1 |
| 12 | S54741001 | SCREW, SM6.35 | 1 |
| 13 | S50233001 | SPRING | 1 |
| 14 | S50111100 | SPRING | 1 |
| 15 | SA9138001 | BOBBIN CASE ASSY | 1 |
| 16 | SA8126001 | ANTI-SPIN SPRING | 1 |
| 17 | 183526001 | SCREW | 2 |
| 18 | S50236001 | SCREW | 1 |
| 19 | 183598001 | SCREW | 1 |
| 20 | S09477001 | SPRING | 1 |
| 21 | 180721001 | SCREW | 1 |
| 22 | 183507001 | ADJUSTING SCREW | 1 |
| 23 | 159158051 | BOBBIN | 1 |
| 24 | SA9140001 | ROTARY HOOK ASSY W/BOX SA9139 | 1 |
| 25 | SA9141001 | ROTARY HOOK ASSY W/BOX SA9137 | 1 |
Page 27 — L. 下軸関係 / Lower shaft mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50240001 | LOWER SHAFT | 1 |
| 2 | SA3033001 | TIMMING PULLEY ASSY | 1 |
| 3 | 076002450 | BALL BEARING RADIAL 6002DDNR | 1 |
| 4 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 2 |
| 5 | 183827001 | SET SCREW COLLAR ASSY | 1 |
| 6 | 104521001 | SET SCREW COLLAR | 1 |
| 7 | 014770632 | SET SCREW SOCKET SM6.35-40X6 | 2 |
| 8 | S50243101 | BUSH ASSY M | 1 |
| 9 | S50244101 | BUSH M | 1 |
| 10 | S38735001 | OIL FEEDING PIPE | 4 |
| 11 | 142274101 | RUBBER CAP, 4.2 | 4 |
| 12 | S50245001 | COVER | 1 |
| 13 | 062670612 | SCREW PAN SM3.57-40X6 | 2 |
Page 29 — M. 給油潤滑関係 / Lubrication
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 144875001 | PLUNGER | 2 |
| 2 | S52764001 | SPRING COMPRESSION | 2 |
| 3 | 552907000 | CORD HOLDER #10 | 2 |
| 4 | 062670612 | SCREW PAN SM3.57-40X6 | 2 |
| 5 | 025350132 | WASHER PLAIN S 3.5 | 2 |
| 6 | 112467002 | SCREW, SM6.35X5 | 2 |
| 7 | S50356001 | OIL FILTER BRACKET ASSY | 1 |
| 8 | 062680812 | SCREW PAN SM4.37-40X8 | 3 |
| 9 | 144872101 | PUMP FILTER | 1 |
| 10 | 144874001 | SPRING | 2 |
| 11 | 062670512 | SCREW PAN SM3.57-40X5 | 2 |
| 12 | S50359001 | TUBE SUPPORT, D | 1 |
| 13 | 062680612 | SCREW PAN SM4.37-40X6 | 1 |
| 14 | S50360001 | ROTARY HOOK FELT SUPPORT | 1 |
| 15 | 060670612 | SCREW BIND SM3.57-40X6 | 2 |
| 16 | S50556000 | FELT | 1 |
| 17 | S50563000 | WICK, 4X200 | 1 |
| 18 | SA4063001 | WICK, 2X460 | 1 |
| 19 | S50559001 | TUBE SUPPORT | 1 |
| 20 | 060670612 | SCREW BIND SM3.57-40X6 | 1 |
| 21 | S50557000 | OIL TUBE | 1 |
| 22 | S50558000 | OIL TUBE, L=180 | 1 |
| 23 | S50513100 | FACE PLATE PACKING | 1 |
| 24 | S50514000 | REAR COVER PACKING | 1 |
| 25 | S50515000 | TOP COVER PACKING | 1 |
| 26 | S50516001 | WICK BASE SUPPORT | 1 |
| 27 | 062670612 | SCREW PAN SM3.57-40X6 | 2 |
| 28 | 159187000 | FELT BASE, A | 1 |
| 29 | S50517001 | CAP | 1 |
| 30 | 062680712 | SCREW PAN SM4.37-40X7 | 2 |
| 31 | S50518000 | FELT | 1 |
| 32 | S50519000 | OIL TERMINAL | 1 |
| 33 | 062680612 | SCREW PAN SM4.37-40X6 | 2 |
| 34 | S50520000 | PACKING | 1 |
| 35 | S50521000 | OIL CAP | 1 |
| 36 | 159193000 | OIL PIPE, B | 1 |
| 37 | S50522000 | OIL TUBE | 1 |
| 38 | S52763000 | WICK, 2X140 | 1 |
| 39 | S50524000 | WICK, 3X160 | 1 |
| 40 | S50525000 | WICK, 3X290 | 1 |
| 41 | S50527000 | OIL TUBE | 1 |
| 42 | S50528000 | WICK, 3X280 | 1 |
| 43 | S50529000 | OIL TUBE, L=320 | 1 |
| 44 | S50530000 | WICK, 3X355 | 1 |
| 45 | S50531000 | OIL TUBE | 1 |
| 46 | S50532000 | OIL TUBE | 1 |
| 47 | 228475000 | FASTENING BAND 1.9X80 | 2 |
| 48 | S00480000 | CORD HOLDER 5N | 1 |
| 49 | 062670612 | SCREW PAN SM3.57-40X6 | 1 |
| 50 | 025350132 | WASHER PLAIN S 3.5 | 1 |
| 51 | 106436001 | FELT | 1 |
| 52 | 107149001 | FELT | 2 |
| 53 | 151927001 | FELT, ; CLUTCH | 3 |
| 54 | S50533000 | OIL TUBE ASSY | 1 |
| 55 | S50536001 | FELT HOLDER | 1 |
| 56 | 062670512 | SCREW PAN SM3.57-40X5 | 1 |
| 57 | S25328001 | FELT | 1 |
| 58 | S50537000 | WICK, 4X50 | 1 |
| 59 | S50538001 | OIL WINDOW SUPPORT | 1 |
| 60 | S50539000 | OIL REJECTOR | 2 |
| 61 | S50540001 | TUBE SUPPORT | 1 |
| 62 | 062680612 | SCREW PAN SM4.37-40X6 | 1 |
| 63 | S50541001 | TUBE SUPPORT, U | 1 |
Page 31 — M. 給油潤滑関係 / Lubrication
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 64 | 060670612 | SCREW BIND SM3.57-40X6 | 1 |
| 65 | S50542001 | TUBE SUPPORT, M | 1 |
| 66 | 062400612 | SCREW PAN M4X6 | 1 |
| 67 | S50543001 | FELT SUPPORT | 1 |
| 68 | S50544000 | FELT | 1 |
| 69 | 062400612 | SCREW PAN M4X6 | 1 |
| 70 | S50545000 | WICK, 3X180 | 1 |
| 71 | S50546000 | WICK, 3X370 | 1 |
| 72 | S50537000 | WICK, 4X50 | 1 |
| 73 | S50547000 | OIL TUBE | 1 |
| 74 | 228475000 | FASTENING BAND 1.9X80 | 2 |
| 75 | S50548001 | TUBE SUPPORT, R | 1 |
| 76 | 060670612 | SCREW BIND SM3.57-40X6 | 1 |
| 77 | S50549000 | FELT | 1 |
| 78 | S50550001 | FELT SUPPORT | 1 |
| 79 | 062670512 | SCREW PAN SM3.57-40X5 | 1 |
| 80 | S50551001 | TUBE SUPPORT | 1 |
| 81 | 002300603 | SCREW, PAN M3X6 | 1 |
| 82 | S50552000 | WICK, 4X70 | 1 |
| 83 | S51020000 | COLLAR | 1 |
| 84 | S25328001 | FELT | 2 |
| 85 | SA4066001 | OIL TUBE, L=40 | 1 |
| 86 | SA4067001 | WICK, 3X150 | 1 |
Page 33 — N. 糸通し関係 / Threading mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50368001 | T-RELEASE DRIVING LEVER ASSY | 1 |
| 2 | S50369001 | TENSION RELEASE DRIVING LEVER | 1 |
| 3 | S35095000 | NEEDLE ROLLER, 4X13.8 | 1 |
| 4 | 014400432 | SET SCREW SOCKET (CP) M4X4 | 1 |
| 5 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 6 | S50370001 | TENSION RELEASE SHAFT | 1 |
| 7 | 081005070 | O RING P5 | 1 |
| 8 | S50371101 | TENSION RELEASE CAM | 1 |
| 9 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 10 | S50372101 | LEVER | 1 |
| 11 | S50373101 | ADJUSTING LEVER | 1 |
| 12 | 060670512 | SCREW BIND SM3.57-40X5 | 1 |
| 13 | 100645003 | WASHER | 1 |
| 14 | S50374001 | LEVER LINK | 1 |
| 15 | S50375001 | TENSION TAKE-UP LEVER | 1 |
| 16 | S50376101 | SHOULDER SCREW SM4.37 | 2 |
| 17 | 100645003 | WASHER | 1 |
| 18 | 062680612 | SCREW PAN SM4.37-40X6 | 1 |
| 19 | 025680234 | WASHER PLAIN M SM4.37 | 1 |
| 20 | SA6113001 | SHOULDER SCREW SM4.37-5.5 | 1 |
| 21 | S50377001 | SOLENOID HOLDER | 1 |
| 22 | 062670612 | SCREW PAN SM3.57-40X6 | 2 |
| 23 | S50378001 | PLATE | 1 |
| 24 | 018300636 | BOLT SOCKET M3X6 | 1 |
| 25 | 062300502 | SCREW PAN M3X5 | 2 |
| 26 | SA0992001 | TENSION RELEASE SOLENOID LINK | 1 |
| 27 | S25456001 | PLUNGER PIN | 1 |
| 28 | S50380000 | SPRING | 1 |
| 29 | SA0990001 | TENSION RELEASE RUBBER ASSY | 1 |
| 30 | S50382001 | TENSION RELEASE LINK | 1 |
| 31 | S50376101 | SHOULDER SCREW SM4.37 | 2 |
| 32 | 141590001 | THREADING BAR, U | 1 |
| 33 | 150553003 | NUT, SM5.95 | 1 |
| 34 | S50383001 | THREAD RETAINER | 1 |
| 35 | 062670612 | SCREW PAN SM3.57-40X6 | 2 |
| 36 | S51184201 | SUB THREAD TENSION ASSY | 1 |
| 37 | SA4232001 | SUB TENSION STUD | 1 |
| 38 | 145446001 | DISC, TENSION | 2 |
| 39 | 159805001 | TENSION DISC PRESSER | 1 |
| 40 | 144103009 | TENSION DISC PRESSER | 1 |
| 41 | 144110101 | TENSION ADJUSTING SPRING | 1 |
| 42 | S30564000 | WASHER | 1 |
| 43 | S30565003 | TENSION NUT | 1 |
| 44 | SA4233001 | KNOB NUT STOPPER | 1 |
| 45 | S50384101 | TENSION RELEASE PIN | 1 |
| 46 | S50385001 | TENSION RELEASE LEVER BRACKET | 1 |
| 47 | S51183101 | TENSION STUD ASSY | 1 |
| 48 | 145440001 | TENSION STUD | 1 |
| 49 | 145446001 | DISC, TENSION | 2 |
| 50 | 159805001 | TENSION DISC PRESSER | 1 |
| 51 | 144103009 | TENSION DISC PRESSER | 1 |
| 52 | S50386101 | TENSION SPRING | 1 |
| 53 | S50387001 | COLLAR | 1 |
| 54 | 151148001 | STOPPER ML | 1 |
| 55 | S30565005 | TENSION NUT | 1 |
| 56 | S50388001 | TENSION RELEASE LEVER | 1 |
| 57 | 114988001 | SHOULDER SCREW, M4.37 | 1 |
| 58 | S50389001 | SPRING | 1 |
| 59 | S51182501 | TENSION STUD BRACKET ASSY | 1 |
| 60 | S50391001 | TENSION STUD, L | 1 |
| 61 | 145446001 | DISC, TENSION | 2 |
| 62 | 159805001 | TENSION DISC PRESSER | 1 |
| 63 | 159221101 | TENSION SPRING | 1 |
Page 35 — N. 糸通し関係 / Threading mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 64 | S30564000 | WASHER | 1 |
| 65 | S31032001 | TENSION NUT | 1 |
| 66 | SA9058001 | THREAD TAKE-UP SPRING | 1 |
| 67 | S50390101 | TENSION STUD BRACKET | 1 |
| 68 | 100402004 | SET SCREW, SM3.57 | 1 |
| 69 | 081014870 | O RING S14 | 1 |
| 70 | S50384101 | TENSION RELEASE PIN | 1 |
| 71 | S55975001 | SET SCREW, SOCKET SM5.95 | 1 |
| 72 | 159224001 | THREAD GUIDE, ARM | 1 |
| 73 | S50392001 | ARM THREAD GUIDE | 1 |
| 74 | 060670512 | SCREW BIND SM3.57-40X5 | 1 |
| 75 | 113316001 | ARM THREAD GUIDE | 1 |
| 76 | 060670512 | SCREW BIND SM3.57-40X5 | 1 |
| 77 | S50393000 | THREADING PLATE | 1 |
| 78 | 159917201 | THREAD GUIDE, L ;ARM | 1 |
| 79 | 112751003 | SCREW, SM3.57X7 | 1 |
| 80 | 048060342 | RETAINING RING E6 | 1 |
| 81 | SA3035001 | THREAD GUIDE COVER | 1 |
| 82 | 025030136 | WASHER PLAIN S 3 | 1 |
Page 37 — P. 糸巻関係 / Bobbin winder mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50276001 | B-WINDER SHAFT BRACKET ASSY | 1 |
| 2 | S50278001 | BOBBIN WINDER SHAFT | 1 |
| 3 | S25410050 | BOBBIN WINDER WHEEL | 1 |
| 4 | 012400636 | SET SCREW SOCKET (FT) M4X6 | 2 |
| 5 | S25789000 | RUBBER RING, 29 | 1 |
| 6 | S50279101 | BOBBIN WINDER ARM SHAFT | 1 |
| 7 | 025080132 | WASHER PLAIN S 8 | 1 |
| 8 | 048060342 | RETAINING RING E6 | 1 |
| 9 | S25413101 | BOBBIN PRESSER SHAFT ASSY | 1 |
| 10 | S25417001 | SPRING | 1 |
| 11 | S25418101 | SPRING | 1 |
| 12 | S50280001 | BOBBIN WINDER STOPPER | 1 |
| 13 | 062400816 | SCREW PAN M4X8 | 1 |
| 14 | S25420051 | BOBBIN PRESSER, R | 1 |
| 15 | 062400816 | SCREW PAN M4X8 | 1 |
| 16 | 026040236 | WASHER PLAIN M 4 | 1 |
| 17 | S10174000 | DUST GUARD PLATE | 1 |
| 18 | 157968001 | KNIFE | 1 |
| 19 | 062400616 | SCREW PAN M4X6 | 1 |
| 20 | 047200642 | PIN SPRING ROLL AW2 | 1 |
| 21 | S38736301 | BOBBIN WINDER TENSION ASSY | 1 |
| 22 | 145446002 | DISC, TENSION | 2 |
| 23 | 115188101 | TENSION SPRING | 1 |
| 24 | 108265009 | TENSION NUT | 1 |
| 25 | 012400636 | SET SCREW SOCKET (FT) M4X6 | 1 |
| 26 | 048040342 | RETAINING RING E4 | 1 |
| 27 | S50281000 | BOBBIN WINDER PULLEY | 1 |
| 28 | 014780632 | SET SCREW SOCKET SM6.35-28X6 | 2 |
| 29 | S50282000 | B-WINDER LEVER CUSHION | 1 |
Page 39 — Q. 上糸切り関係 / Upper thread trimmer mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50394001 | UPPER T-TRIMMER FULCRUM SHAFT | 1 |
| 2 | 110027001 | SET SCREW COLLAR | 1 |
| 3 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 2 |
| 4 | S23337001 | RUBBER CAP, 18.5 | 1 |
| 5 | S52761101 | WASHER RECTANGLE 15X32X2.4 | 1 |
| 6 | S19817001 | SHOULDER SCREW, SM5.95 | 2 |
| 7 | S50395201 | U-THREAD TRIMMER LEVER ASSY | 1 |
| 8 | S50398001 | STOP PLATE | 1 |
| 9 | S50399101 | BACK PLATE | 1 |
| 10 | S50400001 | COLLAR | 2 |
| 11 | 062670712 | SCREW PAN SM3.57-40X7 | 2 |
| 12 | S50401001 | SPRING | 1 |
| 13 | SA9165001 | ADJUSTING PLATE | 1 |
| 14 | 144075001 | BOLT, SM3.57 | 2 |
| 15 | 105161003 | WASHER, PLAIN | 2 |
| 16 | S02563001 | SPRING, EXTENSION | 1 |
| 17 | S02563001 | SPRING, EXTENSION | 1 |
| 18 | S50403101 | SETTING PLATE | 1 |
| 19 | 159343001 | SUPPORT STUD | 1 |
| 20 | 021680202 | NUT 2 SM4.37-40 | 1 |
| 21 | 025680132 | WASHER PLAIN S SM4.37 | 1 |
| 22 | 062680612 | SCREW PAN SM4.37-40X6 | 2 |
| 23 | 025680232 | WASHER PLAIN M SM4.37 | 2 |
| 24 | S50404401 | UPPER THREAD TRIMMER ASSY | 1 |
| 25 | S50405301 | THREAD TRIMMER ASSY D | 1 |
| 26 | S50113101 | UPPER THREAD TRIMMER, M | 1 |
| 27 | 141513001 | UPPER THREAD TRIMMER UPPER | 1 |
| 28 | 141514001 | SHOULDER SCREW, SM3.18 | 1 |
| 29 | S52431000 | U-THREAD TRIMMER STOPPER | 1 |
| 30 | 100644005 | SCREW, SM4.37 | 1 |
| 31 | SA9166001 | OPENING CAM SETTING PLATE | 1 |
| 32 | SA9167001 | OPENING CAM | 1 |
| 33 | 018300836 | BOLT SOCKET M3X8 | 2 |
| 34 | SA9168001 | WASHER PLAIN | 1 |
| 35 | 028030246 | WASHER SPRING 2-3 | 2 |
| 36 | 021300206 | NUT 2 M3 | 2 |
| 37 | 107093002 | SCREW, SM4.37 | 2 |
| 38 | 025680232 | WASHER PLAIN M SM4.37 | 1 |
| 39 | 028680242 | WASHER SPRING 2-4.37 | 1 |
| 40 | S50410101 | THREAD TRIMMER DRIVING LEVER | 2 |
| 41 | 117936001 | RUBBER CAP, 9.4 | 2 |
| 42 | S50411101 | DRIVING LEVER ROLLER | 1 |
| 43 | S50412000 | BALL BEARING, 106ZZS | 1 |
| 44 | S50413101 | SHOULDER SCREW | 2 |
| 45 | 081012070 | O RING P12 | 2 |
| 46 | S50414001 | LONGITUDINAL FEED ARM | 1 |
| 47 | S50415001 | L-FEED ARM PIN | 1 |
| 48 | S50416001 | L-FEED ARM ROLLER | 1 |
| 49 | 048040342 | RETAINING RING E4 | 2 |
| 50 | 014680632 | SET SCREW SOCKET SM4.37-40X6 | 1 |
| 51 | 018061632 | BOLT SOCKET M6X16 | 1 |
| 52 | SA9169001 | THREAD TRIMMER DRIVING ARM | 1 |
| 53 | SA9170001 | SUPPORT PLATE | 1 |
| 54 | S59893001 | BOLT, SOCKET SM4.37-40X10 | 1 |
| 55 | 025680132 | WASHER PLAIN S SM4.37 | 1 |
| 56 | SA9172001 | ROLLER SHOULDER SCREW | 1 |
| 57 | 028050243 | WASHER, SPRING 2-5 | 1 |
| 58 | 021500316 | NUT 3 M5 | 1 |
| 59 | S50511101 | DIFFERENTIAL ARM ROLLER | 1 |
| 60 | SA9171001 | STOPPER | 1 |
| 61 | S59893001 | BOLT, SOCKET SM4.37-40X10 | 1 |
| 62 | 025680132 | WASHER PLAIN S SM4.37 | 1 |
| 63 | 018061632 | BOLT SOCKET M6X16 | 1 |
Page 41 — R. 下糸切り関係 / Lower thread trimmer mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50246001 | LOWER THREAD TRIMMER CAM LEVER | 1 |
| 2 | 107744001 | ROLLER | 1 |
| 3 | 141519001 | ROLLER SHAFT | 1 |
| 4 | 110161004 | NUT, SM4.76 | 1 |
| 5 | 048030342 | RETAINING RING E3 | 1 |
| 6 | 159267001 | CAM SHAFT, ; L-TR | 1 |
| 7 | 110494001 | WASHER, PLAIN 9.5 | 1 |
| 8 | 048080342 | RETAINING RING E8 | 1 |
| 9 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 1 |
| 10 | S50247101 | LOWER THREAD TRIMMER CAM | 1 |
| 11 | S50411101 | DRIVING LEVER ROLLER | 1 |
| 12 | 145478101 | SHOULDER SCREW, SOCKET SM4.76 | 1 |
| 13 | S50248101 | L-THREAD TRI.CAM CONNECTIN ROD | 1 |
| 14 | 150491101 | LEVER SHAFT | 2 |
| 15 | 014760632 | SET SCREW SOCKET SM5.95-28X6 | 2 |
| 16 | 159269001 | SHOULDER SCREW, SM4.37 | 1 |
| 17 | S50249201 | LOWER THREAD TRIMMER LINK ASSY | 1 |
| 18 | S59987101 | LOWER THREAD CONNECTING ROD A | 1 |
| 19 | 062680512 | SCREW PAN SM4.37-40X5 | 2 |
| 20 | 149127001 | SHOULDER SCREW, SM6.35 | 1 |
| 21 | S50252001 | KNIFE DRIVING LEVER | 1 |
| 22 | 113730001 | SHOULDER SCREW, SM4.37 | 1 |
| 23 | 159272001 | SHOULDER SCREW | 1 |
| 24 | S00903001 | COLLAR | 1 |
| 25 | S00901001 | WASHER, PLAIN L 6.4: U | 1 |
| 26 | SA3001001 | WASHER, PLAIN L 4.8: D | 1 |
| 27 | S50253001 | LEVER ASSY | 1 |
| 28 | S50257001 | COLLAR | 1 |
| 29 | S00712101 | SCREW, SM4.37 | 1 |
| 30 | S50258201 | LOWER THREAD RETAINER | 1 |
| 31 | 110215002 | SCREW SM3.57 | 2 |
| 32 | S50259101 | LOWER FIXED KNIFE UNIT | 1 |
| 33 | S50260101 | LOWER FIXED KNIFE ASSY | 1 |
| 34 | S50263001 | MOVABLE KNIFE | 1 |
| 35 | S50264000 | WASHER | 1 |
| 36 | 025040132 | WASHER PLAIN S 4 | 1 |
| 37 | 060630312 | SCREW BIND SM2.38-56X3 | 1 |
| 38 | 060670412 | SCREW BIND SM3.57-40X4 | 2 |
| 39 | S50265001 | LOWER THREAD CLAMP PLATE ASSY | 1 |
| 40 | 141514001 | SHOULDER SCREW, SM3.18 | 1 |
| 41 | 025040132 | WASHER PLAIN S 4 | 1 |
| 42 | S50269000 | WASHER | 1 |
| 43 | S50270000 | LOWER THREAD PRESSER | 1 |
| 44 | 145371001 | SHOULDER SCREW, SM2.38 | 1 |
| 45 | 110215002 | SCREW SM3.57 | 1 |
| 46 | S52433001 | OPENING PLATE A | 1 |
| 47 | 110167001 | ROLLER | 1 |
| 48 | 110168001 | ROLLER SHAFT | 1 |
| 49 | S52434001 | OPENING PLATE, B | 1 |
| 50 | 141514001 | SHOULDER SCREW, SM3.18 | 1 |
| 51 | 123185001 | SCREW, ROUND SM3.57X4.5 | 1 |
| 52 | 149127001 | SHOULDER SCREW, SM6.35 | 1 |
| 53 | 105970001 | SCREW, SM2.38 | 1 |
| 54 | S52778101 | BASE PLATE ASSY | 1 |
| 55 | S50303101 | BASE PLATE | 1 |
| 56 | S52770000 | NEEDLE PLATE COVER | 1 |
| 57 | 106629002 | SCREW, SM4.37 | 4 |
| 58 | S01696001 | SCREW, FLAT SM3.57X6 | 2 |
| 59 | S50323000 | BOBBIN PRESSER | 1 |
| 60 | S01998001 | SET SCREW, SM3.57-40X6 | 1 |
| 61 | S50324001 | BOBBIN PRESSER BRACKET | 1 |
| 62 | 107639001 | SPRING HOOK, U | 1 |
| 63 | 159924001 | SHOULDER SCREW | 1 |
Page 43 — R. 下糸切り関係 / Lower thread trimmer mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 64 | 062671612 | SCREW PAN SM3.57-40X16 | 1 |
| 65 | 021670202 | NUT 2 SM3.57-40 | 2 |
| 66 | 062680512 | SCREW PAN SM4.37-40X5 | 2 |
| 67 | S50325001 | AUXILIARY PLATE | 1 |
| 68 | S50326001 | OPENING PLATE | 1 |
| 69 | 159113101 | SHOULDER SCREW SM3.18 | 1 |
| 70 | 105237002 | SHOULDER SCREW SM3.57 | 1 |
| 71 | 159379001 | PIN, DOWEL BX6X18 | 1 |
| 72 | S50327001 | EXTENSION SPRING | 2 |
| 73 | S50328001 | PLATE SPRING | 1 |
| 74 | 159379001 | PIN, DOWEL BX6X18 | 1 |
| 75 | S50329000 | COVER | 1 |
| 76 | S50664001 | NEEDLE PLATE, 1.4S | 1 |
| 76 | S51248101 | NEEDLE PLATE, 1.2S-3 | 1 |
Page 45 — S. 針位置検出器関係 / Synchronizer
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50657001 | SYNCHRONIZER ASSY H80 | 1 |
| 2 | 062400806 | SCREW PAN M4X8 | 2 |
| 3 | S50354000 | MAGNET ASSY, U | 1 |
| 4 | S38082001 | NEEDLE UPPER MAGNET ASSY, U | 1 |
| 5 | 062681412 | SCREW PAN SM4.37-40X14 | 2 |
| 6 | 025680132 | WASHER PLAIN S SM4.37 | 2 |
Page 47 — T1. コントロールボックス関係 / Control box mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | SA4024001 | TRANSFORMER ASSY | 1 |
| 2 | S00554000 | SUPPORT, 6NS | 23 |
| 3 | S47721301 | POWER SUPPLY PCB ASSY EZ | 1 |
| 4 | J03466001 | IPM 6MBP20RH060-50 | 1 |
| 5 | S38201000 | VARISTOR: V14D471 | 4 |
| 6 | SA2870001 | GLASS FUSE,15A | 2 |
| 7 | J02727001 | GLASS FUSE 2A | 2 |
| 8 | S50425101 | POWER SUPPLY PCB ASSY EH | 1 |
| 9 | S38200000 | TRANSISTOR, : 2SK1938 | 2 |
| 10 | 232384001 | SURGE ABSORBER: DSA362MA | 1 |
| 11 | S38201000 | VARISTOR: V14D471 | 2 |
| 12 | S08030000 | GLASS FUSE 5AFB | 1 |
| 46 | SA8886001 | DIODE AR: D20LC40 | 1 |
| 13 | SA2823001 | FUSE, 6A | 2 |
| 14 | S50431101 | SUB PCB ASSY | 1 |
| 15 | SA6302001 | TRANSISTOR, FET: 2SJ350 | 10 |
| 16 | SA6303001 | TRANSISTOR, FET: 2SK2202 | 10 |
| 17 | S38155000 | TRANSISTOR, FET: 2SK1306 | 4 |
| 18 | S50645000 | TRANSISTOR, FET: 2SK1307 | 1 |
| 19 | S49486000 | TRANSISTOR, FET: 2SJ222 | 1 |
| 20 | S50437000 | CORD, PER | 1 |
| 21 | S50438000 | HARNESS, EX32 | 1 |
| 22 | S50439000 | HARNESS, EX26 | 1 |
| 23 | SA8391001 | POWER SUPPLY HARNESS AC | 1 |
| 24 | S50441000 | POWER SUPPLY HARNESS DC | 1 |
| 25 | S50484000 | GROUND WIRE | 1 |
| 26 | S50644001 | GROUND WIRE | 1 |
| 27 | J80814001 | TREALE UNIT EZ | 1 |
| 42 | SA3797001 | DC-FAN MOTOR ASSY | 2 |
| 43 | S37059001 | LABEL, PE | 1 |
| 44 | S37060001 | LABEL, GROUNDING | 2 |
| 45 | J04115001 | LABEL, ELEC. SHOCK 6 LANG. | 2 |
| 28 | SA3101001 | PROM ASSY C 800A | 1 |
| 28 | SA3079001 | PROM ASSY, 800A | 1 |
| 29 | S38146000 | CONNECTOR: 3191-04R | 2 |
| 30 | SA3189001 | CORD EMC-PER | 1 |
| 31 | SA3196001 | HARNESS EMC-EZACIN | 1 |
| 32 | SA3195001 | HARNESS EMC-EZMT | 1 |
| 33 | SA3921001 | HARNESS EMC-CUTTER | 1 |
| 34 | SA3193001 | HARNESS EMC-FTPM | 1 |
| 35 | SA3192001 | HARNESS EMC-FDPM | 1 |
| 36 | SA3191001 | HARNESS EMC-EX26 | 1 |
| 37 | SA3190001 | HARNESS EMC-EX32 | 1 |
| 38 | SA3176101 | PH PCB ASSY | 1 |
| 39 | S50498001 | NOISE FILTER ASSY EH | 1 |
| 40 | S40620000 | PCB SETTING PLATE | 1 |
| 41 | SA3194001 | HARNESS EMC-NPM | 1 |
Page 49 — T2. コントロールボックス関係 / Control box mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50442001 | POWER SUPPLY SWITCH ASSY A | 1 |
| 2 | S50444001 | POWER SUPPLY SWITCH ASSY B | 1 |
| 3 | S50446001 | POWER SUPPLY SWITCH ASSY C | 1 |
| 4 | SA3966001 | TRANSFORMER PACKAGE ASSY B1 | 1 |
| 5 | SA3967001 | TRANSFORMER ASSY, B110: CONV. | 1 |
| 6 | S50447001 | POWER SUPPLY SWITCH ASSY D | 1 |
| 7 | S50442001 | POWER SUPPLY SWITCH ASSY A | 1 |
| 8 | SA4020001 | TRANSFORMER ASSY C380 :CONV. | 1 |
| 9 | SA3969001 | TRANSFORMER PACKAGE ASSY E | 1 |
Page 51 — T3. コントロールボックス関係 (電源基板) / Control box (PCB) mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S53902301 | SUPPLY MAIN PCB ASSY | 1 |
| 2 | S46455000 | TRANSITOR, FET: FK10KM-10 | 10 |
| 3 | S38155000 | TRANSISTOR, FE: 2SK1306 | 1 |
| 4 | S38200000 | TRANSISTOR, : 2SK1938 | 1 |
| 5 | S47668000 | DIODE, AR: PA905C6 | 1 |
| 6 | S47680000 | GLASS FUSE, 8A | 1 |
Page 53 — U. 電装品関係 / Power supply equipment mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50458100 | PULSE MOTOR ASSY FD | 1 |
| 2 | S50459100 | PULSE MOTOR ASSY FT | 1 |
| 3 | S50460000 | PULSE MOTOR ASSY N | 1 |
| 4 | S50461000 | CUTTER SOLENOID | 1 |
| 5 | S50462000 | TENSION RELEASE SOLENOID | 1 |
| 6 | 228475000 | FASTENING BAND 1.9X80 | 1 |
| 7 | S50463000 | SENSOR ASSY | 1 |
| 8 | S50464000 | SENSOR, GL-N12 | 1 |
| 9 | 062300806 | SCREW PAN M3X8 | 1 |
| 10 | S50465000 | SENSOR, GL-N12 | 1 |
| 11 | 062300806 | SCREW PAN M3X8 | 1 |
| 12 | S50464000 | SENSOR, GL-N12 | 1 |
| 13 | 062300806 | SCREW PAN M3X8 | 1 |
| 14 | 625010000 | NYLON CLAMP NK-2N | 1 |
| 15 | 062670812 | SCREW PAN SM3.57-40X8 | 1 |
| 16 | 025350132 | WASHER PLAIN S 3.5 | 1 |
| 17 | S50466000 | CUTTER SENSOR ASSY | 1 |
| 18 | S50467000 | SENSOR, GL-N12 | 1 |
| 19 | 062300806 | SCREW PAN M3X8 | 1 |
| 20 | S50468000 | DC FAN MOTOR ASSY 40 | 1 |
| 21 | 0A5302005 | SCREW PAN (S/P WASHER) M3X20 | 2 |
| 22 | S00480000 | CORD HOLDER 5N | 3 |
| 23 | 062670612 | SCREW PAN SM3.57-40X6 | 3 |
| 24 | 025350132 | WASHER PLAIN S 3.5 | 3 |
| 25 | SA3113001 | STOP SWITCH HARNESS ASSY | 1 |
| 26 | SA7488001 | SWITCH HW1B-M211B | 1 |
| 27 | S50472000 | SWITCH HARNESS EM | 1 |
| 28 | S50473000 | SENSOR, GL-N12 | 1 |
| 29 | 062300806 | SCREW PAN M3X8 | 1 |
| 30 | S10243000 | CORD HOLDER: NK-3N | 4 |
| 31 | 0A5400806 | SCREW PAN (S/P WASHER) M4X8 | 4 |
| 32 | 152969001 | CORD HOLDER | 1 |
| 33 | 002300603 | SCREW, PAN M3X6 | 1 |
| 34 | 228475000 | FASTENING BAND 1.9X80 | 2 |
| 35 | 218859001 | BINDER M150 | 1 |
| 36 | S50565001 | CORD BUSH | 1 |
| 37 | 552907000 | CORD HOLDER #10 | 2 |
| 38 | 0A5401006 | SCREW PAN (S/P WASHER) M4X10 | 2 |
| 39 | 552908000 | CORD HOLDER #14 | 1 |
| 40 | 0A5401006 | SCREW PAN (S/P WASHER) M4X10 | 1 |
| 41 | 552908000 | CORD HOLDER #14 | 1 |
| 42 | 0A5401006 | SCREW PAN (S/P WASHER) M4X10 | 1 |
| 43 | S38145000 | GROUND WIRE 2 | 1 |
| 44 | 0A5401006 | SCREW PAN (S/P WASHER) M4X10 | 2 |
| 45 | S41216000 | GROUND WIRE | 1 |
| 46 | S50644000 | GROUND WIRE | 1 |
| 47 | SA0287000 | QUICK TUBE ASSY, 30X350 | 1 |
Page 55 — V 操作パネル関係 / Operation panel mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | SA3081001 | OPERATION PANEL UNIT | 1 |
| 2 | 087310816 | TAPTITE CUP B M3X8 | 2 |
| 3 | 0A4400606 | SCREW PAN (S/P WASHER) M4X6 | 1 |
| 4 | S50453100 | PANEL PCB ASSY | 1 |
| 5 | S50457000 | PANEL CABLE ASSY | 1 |
| 6 | 087311016 | TAPTITE CUP B M3X10 | 2 |
| 7 | 062300806 | SCREW PAN M3X8 | 4 |
Page 57 — W. モータ関係 / Motor mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | J80863001 | MOTOR ASSY, INV#EH | 1 |
| 2 | J00107001 | MD806 BASE #2 | 1 |
| 3 | J02517001 | PIN, 9.9X116 | 1 |
| 4 | J03275001 | BOLT ASSY, L M10-V | 1 |
| 5 | 021100206 | NUT, 2 M10 | 1 |
| 6 | 025100236 | WASHER, PLAIN L 10 | 2 |
| 7 | 028100246 | WASHER, SPRING 2-10 | 1 |
| 8 | J03410001 | SETTING PLATE, EZ-MOTOR | 1 |
| 9 | 062401063 | SCREW, PAN M4X10 | 1 |
| 10 | 028040245 | WASHER, SPRING 2-4 | 1 |
| 11 | 025040173 | WASHER, PLAIN S 4 | 1 |
| 12 | 002401006 | SCREW, PAN M4X10 | 1 |
| 13 | 215082001 | SCREW 4 X 12 | 1 |
Page 59 — X. カバー関係/Safety cover
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | J02513001 | MOTOR COVER, INV | 1 |
| 2 | 0A4401605 | SCREW, PAN (S/P WASHE) M4X16 | 3 |
| 3 | J03763001 | BELT COVER | 1 |
| 4 | 229017001 | SCREW, PAN (S/P WASHER) M4X10 | 1 |
| 5 | 217071001 | SCREW 4X18DA | 1 |
| 6 | J03764001 | BELT SUB COVER | 1 |
| 7 | J02293001 | FINGER PROTECTION BAR | 1 |
| 8 | 229017001 | SCREW, PAN (S/P WASHER) M4X10 | 1 |
| 9 | J00351001 | BELT CLAMP PLATE 2 | 1 |
| 10 | 229017001 | SCREW, PAN (S/P WASHER) M4X10 | 1 |
Page 61 — Y. 付属装置関係 (オプション部品) / Attachment set (Option parts)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S51361001 | NEEDL PLATE SET, 1.2RB | 1 |
| 2 | S50304001 | NEEDLE PLATE ASSY, 1.2S-RB | 1 |
| 3 | S50297001 | CUTTER HOLDER | 1 |
| 4 | S50341001 | POSITIONING PLATE | 1 |
| 1 | S51362001 | NEEDLE PLATE SET, 1.4RB | 1 |
| 2 | S50309001 | NEEDLE PLATE ASSY, 1.4S-RB | 1 |
| 3 | S50297001 | CUTTER HOLDER | 1 |
| 4 | S50341001 | POSITIONING PLATE | 1 |
| 1 | S51363001 | NEEDLE PLATE SET, 1.6RB | 1 |
| 2 | S50311001 | NEEDLE PLATE ASSY, 1.6S-RB | 1 |
| 3 | S50297001 | CUTTER HOLDER | 1 |
| 4 | S50341001 | POSITIONING PLATE | 1 |
| 1 | S51364001 | NEEDLE PLATE SET, 1.2RB-3 | 1 |
| 2 | S50313101 | NEEDLE PLATE ASSY, 1.2-RB-3 | 1 |
| 3 | S50297001 | CUTTER HOLDER | 1 |
| 4 | S50341001 | POSITIONING PLATE | 1 |
| 1 | S51365001 | NEEDLE PLATE SET, 1.4RB-3 | 1 |
| 2 | S50317101 | NEEDLE PLATE ASSY, 1.4S-RB-3 | 1 |
| 3 | S50297001 | CUTTER HOLDER | 1 |
| 4 | S50341001 | POSITIONING PLATE | 1 |
| 1 | S51366001 | NEEDLE PLATE SET, 1.6RB-3 | 1 |
| 2 | S50319101 | NEEDLE PLATE ASSY, 1.6S-RB-3 | 1 |
| 3 | S50297001 | CUTTER HOLDER | 1 |
| 4 | S50341001 | POSITIONING PLATE | 1 |
| 5 | J80380040 | PEDAL STAND OPE DD 3P VARI 40 | 1 |
| 5 | J803800E0 | PEDAL STAND OPE DD 3P VARI 40 | 1 |
| 6 | S47750000 | S-OPE. HARNESS | 1 |
Page 63 — Z1. 付属品関係 / Accessories
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50330101 | BED BASE ASSY | 1 |
| 2 | S50331000 | BED BASE | 1 |
| 3 | S50332000 | OIL PACKING | 1 |
| 4 | S54768001 | DRAIN PLATE | 1 |
| 5 | S50334000 | PACKING | 1 |
| 6 | 037401415 | TAPPING SCREW PAN V M4X14 | 3 |
| 7 | 081007070 | O RING P7 | 1 |
| 8 | 140518001 | SCREW, SM7.94X10 | 1 |
| 9 | S50335000 | BED BASE CUSHION, A | 5 |
| 10 | S50336000 | BED BASE CUSHION, B | 4 |
| 11 | S50337000 | BED BASE CUSHION, C | 2 |
| 12 | S50338000 | OIL STOPPER PLATE | 1 |
| 13 | S24250001 | BOLT M8X90 | 4 |
| 14 | S50342000 | FLANGE NUT, M8 | 4 |
| 15 | 028080246 | WASHER SPRING 2-8 | 4 |
| 16 | 101118001 | WOOD SCREW, ROUND M4.5X20 | 3 |
| 17 | S50339001 | COLLAR | 4 |
| 18 | 104449001 | RUBBER CAP, 15.5 | 2 |
| 19 | 025050236 | WASHER PLAIN M 5 | 3 |
| 20 | S18707153 | BELT, VM WHITE | 1 |
| 21 | 142443001 | SCREW-DRIVER, 1.9X52 | 1 |
| 22 | 118837001 | SCREW-DRIVER, 3.4X70 | 1 |
| 23 | 101572102 | SCREW-DRIVER 5.5X190 | 1 |
| 24 | 159158051 | BOBBIN | 1 |
| 25 | 117466000 | PINCETTE | 1 |
| 26 | S51290001 | CUTTER, 3/8 | 1 |
| 27 | S51354001 | CUTTER, 5/8 | 1 |
| 28 | S51358001 | CUTTER, 1 | 1 |
| 29 | S51356001 | CUTTER, 3/4 | 1 |
| 30 | S55663001 | OIL TANK ASSY | 1 |
| 31 | 114483002 | OILER ASSY | 1 |
| 32 | 159384009 | HEAD REST | 1 |
| 33 | 133740006 | BOLT SQUARE M6X70 | 4 |
| 34 | 021060106 | NUT 1 M6 | 8 |
| 35 | 025060336 | WASHER PLAIN L 6 | 4 |
| 36 | S00617000 | RUBBER COLLAR | 4 |
| 37 | 146256001 | CUSHION COLLAR | 4 |
| 38 | 146255000 | CUSHION | 4 |
| 39 | SA9254014 | NEEDLE 4PIECE ASSY SA9253: #14 NM90 | 1 |
| 40 | S13595201 | TIMING GAUGE, -2 | 1 |
| 39 | SA9254011 | NEEDLE 4PIECE ASSY SA9253: #11 NM75 | 1 |
| 40 | S13596201 | TIMING GAUGE, -3 | 1 |
Page 65 — Z2. 付属品関係 / Accessories
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S02761509 | COTTON STAND ASSY 2 | 1 |
| 2 | 150189109 | COTTON STAND BRACKET | 1 |
| 3 | 062060804 | SCREW PAN M6X8 | 2 |
| 4 | 031452204 | WOOD SCREW ROUND M4.5X22 | 3 |
| 5 | S51283001 | SPOOL STAND BASE | 2 |
| 6 | 150182000 | SPOOL MAT | 2 |
| 7 | S51282101 | SPOOL CUSHION | 2 |
| 8 | 150172003 | COLUMN PIPE | 1 |
| 9 | 150174000 | COLUMN CAP | 1 |
| 10 | SA6606001 | COLUMN JOINT | 1 |
| 11 | 150179002 | SPOOL SHAFT B | 2 |
| 12 | 028050244 | WASHER SPRING 2-5 | 2 |
| 13 | 021500104 | NUT 1 M5 | 2 |
| 14 | SA6607001 | SPOOL HOLDER 2 | 1 |
| 15 | SA6607001 | SPOOL HOLDER 2 | 1 |
| 16 | 150183000 | THREAD HANGER BASE | 2 |
| 17 | 142990001 | THREAD BUSH | 2 |
| 18 | SA6609001 | SPOOL HOLDER SUPPORTER | 2 |
| 19 | 150172003 | COLUMN PIPE | 1 |
| 20 | 021500104 | NUT 1 M5 | 2 |
| 21 | 062061604 | SCREW PAN M6X16 | 2 |
| 22 | 062501404 | SCREW PAN M5X14 | 2 |
| 23 | SA9157001 | BELT COVER | 1 |
| 24 | SA9158001 | BELT COVER D | 1 |
| 25 | SA9159001 | BELT COVER D PLATE | 1 |
| 26 | 100666002 | WOOD SCREW, ROUND M5.5X20 | 2 |
| 27 | SA3025001 | SCREW PAN (S/P WASHER) M4X10 | 3 |
| 28 | 104450101 | RUBBER CAP, 8 | 2 |
| 29 | S50344001 | BELT COVER PLATE | 1 |
| 30 | 032461606 | WOOD SCREW ROUND 2 M4.5X16 | 2 |
| 31 | 200190001 | STAPLE 10X20 | 6 |
| 32 | S37111001 | EYE GUARD ASSY | 1 |
| 33 | S01700001 | SCREW, OVAL SM3.18X7 | 2 |
| 34 | 025030232 | WASHER PLAIN M 3 | 2 |
| 35 | 021660102 | NUT 1 SM3.18-40 | 2 |
| 36 | 062710612 | SCREW PAN SM4.76-32X6 | 1 |
| 37 | 148847001 | WASHER PLAIN 4.76 | 1 |
| 38 | S50345001 | EYE GUARD SUPPORT | 1 |
| 39 | 062680812 | SCREW PAN SM4.37-40X8 | 1 |
| 40 | SA2870001 | GLASS FUSE 15A | 2 |
| 41 | S08030000 | GLASS FUSE 5AFB | 1 |
| 42 | 153242000 | GLASS FUSE 6A | 2 |
| 43 | J03411001 | SETTING PLATE, EZ-TREADLE | 1 |
| 44 | J00353001 | SCREW PAN (S/P WASHER) M5X14 | 3 |
| 45 | J02036001 | BUSHING, V CORD | 1 |
| 46 | 112525000 | MAGNET | 1 |
| 47 | S54767000 | AUXILIARY SHEET | 1 |
| 48 | 144226001 | HEAD COVER | 1 |
| 49 | SA9160001 | AUXILIARY TABLE | 1 |
| 50 | SA9161001 | TABLE SUPPORT PLATE | 2 |
| 51 | 018400636 | BOLT SOCKET M4X6 | 2 |
| 52 | 018061036 | BOLT SOCKET M6X10 | 2 |
| 53 | 032461606 | WOOD SCREW ROUND 2 M4.5X16 | 2 |
| 54 | 031412506 | WOOD SCREW ROUND M4.1X25 | 4 |
Page 67 — Z3. 付属品関係 / Accessories
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S50346001 | TAPE GUARD WINDER ASSY | 1 |
| 2 | S51896001 | TAPE GUARD ASSY | 1 |
| 3 | 144998001 | TAPE GUARD, B | 1 |
| 4 | 105288002 | SCREW SM2.38 | 2 |
| 5 | 144997001 | TAPE GUARD, A | 1 |
| 6 | 122771051 | SCREW, SM2.38 | 2 |
| 7 | 144999001 | TAPE GUIDE, C | 1 |
| 8 | 144628001 | TAPE GUARD, F | 1 |
| 9 | 122771051 | SCREW, SM2.38 | 1 |
| 10 | 105970001 | SCREW, SM2.38 | 1 |
| 11 | 110067001 | COLLAR | 1 |
| 12 | 143749001 | TAPE GUIDE, LOWER | 1 |
| 13 | 143748001 | TAPE GUIDE, UPPER | 1 |
| 14 | 062660412 | SCREW PAN SM3.18-40X4 | 2 |
| 15 | 143767102 | TAPE WINDER ASSY | 1 |
| 16 | 143980001 | SCREW | 1 |
| 17 | 108494001 | WASHER | 1 |
| 18 | 108495001 | SPRING, COMPRESSION | 1 |
| 19 | 100136001 | TENSION NUT | 1 |
| 20 | S50348001 | TAPE GUIDE, U | 1 |
| 21 | 062400812 | SCREW PAN M4X8 | 1 |
| 22 | S50349001 | TAPE WINDER SETTING PLATE | 1 |
| 23 | 062400812 | SCREW PAN M4X8 | 1 |
| 24 | 107407003 | SCREW, SM4.37X9 | 2 |
| 25 | S50477001 | RULER ASSY | 1 |
| 26 | S06139001 | RULER, A | 1 |
| 27 | S06140001 | RULER, B | 1 |
| 28 | 062680512 | SCREW PAN SM4.37-40X5 | 2 |
| 29 | 025680232 | WASHER PLAIN M SM4.37 | 2 |
| 30 | 146000001 | THREAD TRIMMER SUPPORT | 1 |
| 31 | 062670412 | SCREW PAN SM3.57-40X4 | 2 |
| 32 | 105161003 | WASHER, PLAIN | 2 |
| 33 | 141620001 | BALANCER | 1 |
| 34 | 101671002 | SCREW, SM4.37 | 2 |
| 35 | 025680132 | WASHER PLAIN S SM4.37 | 2 |
| 36 | S36522001 | SCREW, SM4.37 | 2 |
| 37 | S50350001 | RULER ASSY, 800E | 1 |
| 38 | S50476001 | RULER | 1 |
| 39 | S36522001 | SCREW, SM4.37 | 2 |
| 40 | S50351001 | RULER SPACER | 1 |
| 41 | 133797121 | CONNECTING ROD ASSY | 1 |
| 42 | 119710021 | CONNECTING ROD ASSY | 1 |
| 43 | 119711021 | CONNECTING ROD | 2 |
| 44 | S36119021 | NUT 1 M6 | 2 |
| 45 | 119101021 | CONNECTING ROD CLAMP | 1 |
| 46 | S36114021 | BOLT M8X16 | 1 |
| 47 | S36120021 | NUT 1 M8 | 1 |
| 48 | 133792121 | JOINT ASSY | 2 |
| 49 | S36119021 | NUT 1 M6 | 2 |
| 50 | S36121021 | WASHER SPRING 2-6 | 2 |
| 51 | 114859001 | COLLAR | 1 |
| 52 | S55361200 | PANEL LABEL | 1 |
Page 68 — Ga1 . ゲージ部品一覧表 / Gauge parts list
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| S51117-001 | |||
| S51290-001 | |||
| S51351-001 | |||
| S51352-001 | |||
| S51353-001 | |||
| S51354-001 | |||
| S51355-001 | |||
| S51356-001 | |||
| S25642-001 | |||
| S51357-001 | |||
| S51358-001 | |||
| S51359-001 | |||
| S51360-001 | |||
| S01271-001 | |||
| S01272-001 | |||
| S01273-001 | |||
| S03280-001 | |||
| S01274-001 | |||
| S01275-001 | |||
| S01276-001 | |||
| S35630-001 |
Page 69 — Ga2. ゲージ部品一覧表 / Gauge parts list
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S5350-201 | Work clamp assy, W/F-G (25mmW) | |
| ※ 1 | S37101-202 | (16mmRS) | |
| ※ 2 | 159079-100 | Finger guard | |
| ※ 3 | 159761-002 | Work clamp | |
| ※ 1 | S37100-302 | (25mmRS) | |
| ※ 2 | 159080-100 | Finger guard | |
| ※ 3 | 159762-002 | Work clamp | |
| ※ 1 | S55347-202 | (25mmRSW) | |
| ※ 2 | 159080-100 | Finger guard | |
| ※ 3 | S55345-002 | Work clamp | |
| ※ 1 | S37109-202 | (32mmRS) | |
| ※ 2 | 159081-100 | Finger guard | |
| ※ 3 | 159763-002 | Work clamp | |
| ※ 1 | S37103-201 | (16mm) | |
| ※ 2 | 159079-100 | Finger guard | |
| ※ 3 | 145136-001 | Work clamp | |
| ※ 1 | S37102-301 | (25mm) | |
| ※ 2 | 159080-100 | Finger guard | |
| ※ 3 | 144630-001 | Work clamp | |
| ※ 1 | S55350-201 | (25mmW) | |
| ※ 2 | 159080-100 | Finger guard | |
| ※ 3 | S55348-001 | Work clamp | |
| ※ 1 | S37110-201 | (32mm) | |
| ※ 2 | 159081-100 | Finger guard | |
| ※ 3 | 144632-001 | Work clamp |
Page 70 — Ga3 . ゲージ部品一覧表 / Gauge parts list
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| S50663-001 | |||
| S50664-001 | |||
| S50665-001 | |||
| S51248-101 | |||
| S51249-101 | |||
| S51250-101 | |||
| S50321-001 | |||
| 151843-001 | |||
| S50322-101 | |||
| 156612-001 |
Page 71 — 警告ラベル / Warning labels
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| J04115-001 | Label, elec. shock 6 lang | ||
| SA0792-001 | Label, caution Jpn / Eng | ||
| SA0793-001 | Label, caution Chn / Eng | ||
| S36924-001 | Mark, injury | ||
| S37059-001 | Label, PE | ||
| S37060-001 | Label, grounding |
Page 73 — 索引 / Index
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| - 62 | 102538002 | F | |
| - 9 | 102630001 | H | |
| - 24 | 104449001 | A | |
| A | |||
| A | |||
| A | |||
| A | |||
| Z1 | |||
| - 10 | 104450101 | A | |
| A | |||
| A | |||
| A | |||
| A | |||
| A | |||
| A | |||
| A | |||
| A | |||
| Z2 | |||
| - 25 | 104451101 | A | |
| - 6 | 104521001 | L | |
| - 38 | 105130001 | G | |
| - 15 | 105161003 | Q | |
| Z3 | |||
| - 70 | 105237002 | R | |
| - 4 | 105288002 | Z3 | |
| - 53 | 105970001 | R | |
| Z3 | |||
| - 51 | 106436001 | M | |
| - 57 | 106629002 | R | |
| - 37 | 107093002 | Q | |
| - 52 | 107149001 | M | |
| - 54 | 107401001 | G | |
| - 55 | 107404001 | G | |
| G | |||
| - 24 | 107407003 | Z3 | |
| - 62 | 107639001 | R | |
| - 2 | 107744001 | R | |
| - 24 | 108265009 | P | |
| - 17 | 108494001 | Z3 | |
| - 18 | 108495001 | Z3 | |
| - 2 | 110027001 | Q | |
| Z3 | |||
| - 18 | 110161004 | F | |
| R | |||
| - 47 | 110167001 | R | |
| - 48 | 110168001 | R | |
| - 31 | 110215002 | R | |
| R | |||
| - 4 | 110367001 | B | |
| F | |||
| H | |||
| - 7 | 110494001 | R | |
| - 33 | 110735002 | G | |
| - 41 | 111466121 | F | |
| - 30 | 111865009 | C | |
| - 6 | 112467002 | M | |
| - 46 | 112525000 | Z2 | |
| - 79 | 112751003 | N | |
| - 75 | 113316001 | N | |
| - 22 | 113730001 | R | |
| - 31 | 114483002 | Z1 | |
| - 51 | 114859001 | Z3 | |
| - 57 | 114988001 | N | |
| - 23 | 115188101 | P | |
| - 26 | 115503001 | H | |
| - 16 | 117143003 | A | |
| - 22 | 117363001 | F | |
| F | |||
| - 25 | 117466000 | Z1 | |
| - 44 | 117936001 | A | |
| Q | |||
| - 15 | 118735001 | D | |
| - 22 | 118837001 | Z1 | |
| - 45 | 119101021 | Z3 | |
| - 42 | 119710021 | Z3 | |
| - 43 | 119711021 | Z3 | |
| - 43 | 120263001 | A | |
| - 6 | 122771051 | Z3 | |
| Z3 | |||
| - 51 | 123185001 | R | |
| - 33 | 133740006 | Z1 | |
| - 48 | 133792121 | Z3 | |
| Z3 | |||
| - 8 | 140004001 | B | |
| - 46 | 140407001 | F | |
| - 10 | 140430001 | B | |
| - 8 | 140518001 | Z1 | |
| - 27 | 140553102 | B | |
| - 27 | 141513001 | Q | |
| - 28 | 141514001 | Q | |
| R | |||
| R | |||
| - 3 | 141519001 | R | |
| - 32 | 141590001 | N | |
| - 6 | 141619001 | J | |
| - 7 | 141620001 | J | |
| Z3 | |||
| - 11 | 142274101 | L | |
| - 21 | 142443001 | Z1 | |
| - 17 | 142990001 | Z2 | |
| - 13 | 143748001 | Z3 | |
| - 12 | 143749001 | Z3 | |
| - 15 | 143767102 | Z3 | |
| - 16 | 143980001 | Z3 | |
| - 14 | 144075001 | Q | |
| - 40 | 144103009 | N | |
| N | |||
| - 41 | 144110101 | N | |
| - 48 | 144226001 | Z2 | |
| - 8 | 144628001 | Z3 | |
| - 52 | 144630001 | G | |
| Ga2 | |||
| 144632001 | Ga2 | ||
| - 54 | 144707001 | G | |
| - 9 | 144872101 | M | |
| - 10 | 144874001 | M | |
| - 1 | 144875001 | M | |
| - 5 | 144997001 | Z3 | |
| - 3 | 144998001 | Z3 | |
| - 7 | 144999001 | Z3 | |
| 145136001 | Ga2 | ||
| - 44 | 145371001 | R | |
| - 48 | 145440001 | N | |
| - 49 | 145446001 | N | |
| N | |||
| N | |||
| - 22 | 145446002 | P | |
| - 6 | 145465001 | B | |
| - 47 | 145472001 | F | |
| - 31 | 145478101 | F | |
| F | |||
| F | |||
| R | |||
| - 30 | 146000001 | Z3 | |
| - 38 | 146255000 | Z1 | |
| - 37 | 146256001 | Z1 | |
| - 37 | 148847001 | Z2 | |
| - 20 | 149127001 | R | |
| R | |||
| - 8 | 150172003 | Z2 | |
| Z2 | |||
| - 9 | 150174000 | Z2 | |
| - 11 | 150179002 | Z2 | |
| - 6 | 150182000 | Z2 | |
| - 16 | 150183000 | Z2 | |
| - 2 | 150189109 | Z2 | |
| - 30 | 150382001 | B | |
| - 14 | 150491101 | R | |
| - 33 | 150553003 | N | |
| - 54 | 151148001 | N | |
| 151843001 | Ga3 | ||
| - 53 | 151927001 | M | |
| - 32 | 152969001 | U | |
| - 24 | 153057102 | H | |
| - 42 | 153242000 | Z2 | |
| - 34 | 153483001 | B | |
| - 32 | 154965001 | B | |
| - 58 | 155578000 | F | |
| 156612001 | Ga3 | ||
| - 18 | 157968001 | P | |
| - 19 | 158830001 | A | |
| - 20 | 158831001 | A | |
| - 21 | 158832000 | A | |
| - 11 | 158879001 | A | |
| - 21 | 158880001 | B | |
| - 5 | 158893100 | C | |
| - 21 | 158945001 | D | |
| - 22 | 158946001 | D | |
| - 47 | 159078001 | G | |
| 159079100 | Ga2 | ||
| - 46 | 159080100 | G | |
| Ga2 | |||
| 159081100 | Ga2 | ||
| - 31 | 159104001 | H | |
| - 69 | 159113101 | R | |
| - 12 | 159117001 | H | |
| - 5 | 159145001 | J | |
| - 22 | 159150000 | A | |
| A | |||
| - 23 | 159158051 | K | |
| Z1 | |||
| - 28 | 159187000 | M | |
| - 36 | 159193000 | M | |
| - 63 | 159221101 | N | |
| - 72 | 159224001 | N | |
| - 6 | 159267001 | R | |
| - 16 | 159269001 | R | |
| - 23 | 159272001 | R | |
| - 19 | 159343001 | Q | |
| - 33 | 159379001 | H | |
| R | |||
| R | |||
| - 32 | 159384009 | Z1 | |
| - 19 | 159624001 | B | |
| - 20 | 159625001 | D | |
| 159761002 | Ga2 | ||
| - 52 | 159762002 | G | |
| Ga2 | |||
| 159763002 | Ga2 | ||
| - 39 | 159805001 | N | |
| N | |||
| N | |||
| - 78 | 159917201 | N | |
| - 63 | 159924001 | R | |
| - 53 | 159926001 | G | |
| G | |||
| - 56 | 159927001 | G | |
| G | |||
| - 21 | 180721001 | K | |
| - 22 | 183507001 | K | |
| - 17 | 183526001 | K | |
| - 19 | 183598001 | K | |
| - 5 | 183827001 | L | |
| - 31 | 200190001 | Z2 | |
| - 13 | 215082001 | W | |
| - 5 | 217071001 | X | |
| - 35 | 218859001 | U | |
| - 47 | 228475000 | M | |
| M | |||
| U | |||
| U | |||
| - 4 | 229017001 | X | |
| X | |||
| X | |||
| - 10 | 232384001 | T1 | |
| - 3 | 552907000 | M | |
| U | |||
| - 39 | 552908000 | U | |
| U | |||
| - 14 | 625010000 | U | |
| - 2 | J00107001 | W | |
| - 9 | J00351001 | X | |
| - 44 | J00353001 | Z2 | |
| - 45 | J02036001 | Z2 | |
| - 7 | J02293001 | X | |
| - 1 | J02513001 | X | |
| - 3 | J02517001 | W | |
| - 7 | J02727001 | T1 | |
| - 4 | J0275001 | T1 | |
| - 8 | J0310001 | W | |
| - 43 | J03410001 | Z2 | |
| - 43 | J03410001 | T1 | |
| - 4 | J03466001 | T1 | |
| - 3 | J03763001 | X | |
| - 6 | J03764001 | X | |
| - 45 | J04115001 | T1 | |
| Wa | |||
| - 5 | J80380040 | Y | |
| - 5 | J803800E0 | Y | |
| - 27 | J80814001 | T1 | |
| - 1 | J80863001 | W | |
| - 12 | S00306001 | A | |
| - 48 | S00480000 | M |
Page 74 — 索引 / Index
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| - 22 | S0048000 | U | |
| - 2 | S00554000 | T1 | |
| - 36 | S00617000 | Z1 | |
| - 29 | S00712101 | R | |
| - 25 | S00901001 | R | |
| - 24 | S00903001 | R | |
| S01271001 | Ga1 | ||
| S01272001 | Ga1 | ||
| S01273001 | Ga1 | ||
| S01274001 | Ga1 | ||
| S01275001 | Ga1 | ||
| S01276001 | Ga1 | ||
| - 58 | S01696001 | R | |
| - 33 | S01700001 | Z2 | |
| - 60 | S01998001 | R | |
| - 20 | S02460001 | G | |
| - 16 | S02563001 | Q | |
| - 17 | S02563001 | Q | |
| - 1 | S02761509 | Z2 | |
| S03280001 | Ga1 | ||
| - 26 | S06139001 | Z3 | |
| - 27 | S06140001 | Z3 | |
| - 11 | S07478000 | K | |
| - 12 | S08030000 | T1 | |
| - 41 | S08030000 | Z2 | |
| - 27 | S09212001 | H | |
| - 20 | S09477001 | K | |
| - 17 | S10174000 | P | |
| - 30 | S10243000 | U | |
| - 19 | S12004000 | G | |
| - 34 | S12004000 | G | |
| - 40 | S13592001 | Z1 | |
| - 40 | S13596201 | Z1 | |
| - 20 | S18707153 | Z1 | |
| - 6 | S19817001 | Q | |
| - 4 | S23337001 | Q | |
| - 13 | S24250001 | Z1 | |
| - 57 | S25328001 | M | |
| - 84 | S25328001 | M | |
| - 3 | S25410050 | P | |
| - 9 | S25413101 | P | |
| - 10 | S25417001 | P | |
| - 11 | S25418101 | P | |
| - 14 | S25420051 | P | |
| - 27 | S25456001 | N | |
| S25642001 | Ga1 | ||
| - 5 | S25789000 | P | |
| - 42 | S30564000 | N | |
| - 64 | S30564000 | N | |
| - 43 | S30565003 | N | |
| - 55 | S30565005 | N | |
| - 45 | S31012001 | F | |
| - 44 | S31013001 | F | |
| - 65 | S31032001 | N | |
| - 29 | S31808001 | B | |
| - 37 | S32263001 | A | |
| - 17 | S32521001 | D | |
| - 3 | S35095000 | N | |
| - 21 | S35184001 | G | |
| S35630001 | Ga1 | ||
| - 46 | S36114021 | Z3 | |
| - 44 | S36119021 | Z3 | |
| - 49 | S36119021 | Z3 | |
| - 47 | S36120021 | Z3 | |
| - 50 | S36121021 | Z3 | |
| - 36 | S36522001 | Z3 | |
| - 39 | S36522001 | Z3 | |
| - 38 | S36924001 | A | |
| S36924001 | Wa | ||
| - 43 | S37059001 | T1 | |
| S37059001 | Wa | ||
| - 39 | S37060001 | T1 | |
| S37060001 | Wa | ||
| - 51 | S37100302 | G | |
| S37100302 | Ga2 | ||
| S37101202 | Ga2 | ||
| - 51 | S37102301 | G | |
| S37102301 | Ga2 | ||
| S37103201 | Ga2 | ||
| S37109202 | Ga2 | ||
| S37110201 | Ga2 | ||
| - 32 | S37111001 | Z2 | |
| - 56 | S37927000 | F | |
| - 2 | S37940001 | D | |
| - 4 | S38082001 | S | |
| - 43 | S38145000 | U | |
| - 29 | S38146000 | T1 | |
| - 17 | S38155000 | T1 | |
| - 3 | S38155000 | T3 | |
| - 9 | S38200000 | T1 | |
| - 4 | S38200000 | T3 | |
| - 5 | S38201000 | T1 | |
| - 11 | S38201000 | T1 | |
| - 10 | S38735001 | L | |
| - 21 | S38736301 | P | |
| - 23 | S38761201 | F | |
| - 30 | S38761201 | F | |
| - 40 | S40620000 | T1 | |
| - 45 | S41216000 | U | |
| - 6 | S42116000 | F | |
| - 3 | S43717201 | F | |
| - 2 | S46455000 | T3 | |
| - 5 | S47668000 | T3 | |
| - 6 | S47680000 | T3 | |
| - 3 | S47721301 | T1 | |
| - 6 | S47750000 | Y | |
| - 12 | S48034001 | C | |
| - 19 | S49486000 | T1 | |
| - 7 | S50110001 | G | |
| - 14 | S50111100 | K | |
| - 26 | S50113101 | Q | |
| - 1 | S50123001 | A | |
| - 5 | S50124000 | A | |
| - 7 | S50127101 | A | |
| - 9 | S50128201 | A | |
| - 40 | S50131001 | A | |
| - 1 | S50132000 | B | |
| - 7 | S50136101 | B | |
| - 13 | S50142000 | B | |
| - 17 | S50143001 | B | |
| - 18 | S50144001 | B | |
| - 20 | S50146001 | B | |
| - 23 | S50147001 | B | |
| - 26 | S50149101 | B | |
| - 28 | S50150001 | B | |
| - 31 | S50152001 | B | |
| - 33 | S50153101 | B | |
| - 1 | S50154001 | C | |
| - 6 | S50156001 | C | |
| - 8 | S50157001 | C | |
| - 10 | S50159001 | C | |
| - 11 | S50160001 | C | |
| - 14 | S50161000 | C | |
| - 15 | S50163001 | C | |
| - 16 | S50164001 | C | |
| - 17 | S50165001 | C | |
| - 24 | S50166001 | C | |
| - 25 | S50167001 | C | |
| - 26 | S50168001 | C | |
| - 1 | S50169001 | D | |
| - 8 | S50171001 | D | |
| - 10 | S50172001 | D | |
| - 13 | S50174001 | D | |
| - 18 | S50176001 | D | |
| - 19 | S50178001 | D | |
| - 23 | S50179001 | D | |
| - 1 | S50182000 | E | |
| - 1 | S50183001 | F | |
| - 5 | S50184001 | F | |
| - 7 | S50185001 | F | |
| - 9 | S50186001 | F | |
| - 11 | S50187001 | F | |
| - 15 | S50189001 | F | |
| - 16 | S50190001 | F | |
| - 17 | S50191001 | F | |
| - 20 | S50192101 | F | |
| - 24 | S50192101 | F | |
| - 27 | S50193001 | F | |
| - 29 | S50195001 | F | |
| - 32 | S50196001 | F | |
| - 37 | S50198001 | F | |
| - 38 | S50199101 | F | |
| - 43 | S50200001 | F | |
| - 48 | S50201001 | F | |
| - 49 | S50202001 | F | |
| - 53 | S50203101 | F | |
| - 54 | S50204001 | F | |
| - 59 | S50205001 | F | |
| - 61 | S50206001 | F | |
| - 1 | S50207001 | G | |
| - 5 | S50208001 | G | |
| - 9 | S50209000 | G | |
| - 10 | S50210001 | G | |
| - 12 | S50211101 | G | |
| - 14 | S50212001 | G | |
| - 15 | S50213001 | G | |
| - 17 | S50214001 | G | |
| - 23 | S50215101 | G | |
| - 26 | S50216101 | G | |
| - 28 | S50217001 | G | |
| - 29 | S50218001 | G | |
| - 30 | S50219101 | G | |
| - 50 | S50220001 | G | |
| - 37 | S50221101 | G | |
| - 39 | S50222001 | G | |
| - 40 | S50223100 | G | |
| - 43 | S50224001 | G | |
| - 50 | S50225001 | G | |
| - 1 | S50226001 | K | |
| - 7 | S50230001 | K | |
| - 10 | S50231200 | K | |
| - 9 | S50232000 | K | |
| - 13 | S50233001 | K | |
| - 18 | S50236001 | K | |
| - 1 | S50240001 | L | |
| - 8 | S50243101 | L | |
| - 9 | S50244101 | L | |
| - 12 | S50245001 | L | |
| - 1 | S50246001 | R | |
| - 10 | S50247101 | R | |
| - 13 | S50248101 | R | |
| - 17 | S50249201 | R | |
| - 21 | S50252001 | R | |
| - 27 | S50253001 | R | |
| - 28 | S50257001 | R | |
| - 30 | S50258201 | R | |
| - 32 | S50259101 | R | |
| - 33 | S50260101 | R | |
| - 34 | S50263001 | R | |
| - 35 | S50264000 | R | |
| - 39 | S50265001 | R | |
| - 42 | S50269000 | R | |
| - 43 | S50270000 | R | |
| - 11 | S50271000 | B | |
| - 12 | S50272000 | B | |
| - 1 | S50273000 | J | |
| - 10 | S50274001 | J | |
| - 12 | S50275001 | J | |
| - 1 | S50276001 | P | |
| - 2 | S50278001 | P | |
| - 6 | S50279101 | P | |
| - 12 | S50280001 | P | |
| - 27 | S50281000 | P | |
| - 29 | S50282000 | P | |
| - 1 | S50283001 | H | |
| - 3 | S50284101 | H | |
| - 4 | S50285101 | H | |
| - 5 | S50286101 | H | |
| - 6 | S50287001 | H | |
| - 8 | S50288001 | H | |
| - 13 | S50289001 | H | |
| - 14 | S50290001 | H | |
| - 15 | S50291001 | H | |
| - 16 | S50292001 | H | |
| - 17 | S50293001 | H | |
| - 19 | S50294001 | H | |
| - 21 | S50295001 | H | |
| - 23 | S50296001 | H | |
| - 50 | S50297001 | H | |
| - 3 | S50297001 | Y | |
| - 29 | S50298101 | H | |
| - 30 | S50299101 | H | |
| - 34 | S50300001 | H | |
| - 55 | S50303101 | R | |
| - 2 | S50304001 | Y | |
| - 2 | S50309001 | Y | |
| - 2 | S50311001 | Y | |
| - 2 | S50313101 | Y | |
| - 2 | S50317101 | Y | |
| - 2 | S50319101 | Y | |
| S50321001 | Ga3 |
Page 75 — 索引 / Index
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| Ga3 | S50322101 | ||
| R - 59 | S50323000 | ||
| R - 61 | S50324001 | ||
| R - 67 | S50325001 | ||
| R - 68 | S50326001 | ||
| R - 72 | S50327001 | ||
| R - 73 | S50328001 | ||
| R - 75 | S50329000 | ||
| Z1 - 1 | S50330101 | ||
| Z1 - 2 | S50331000 | ||
| Z1 - 3 | S50332000 | ||
| Z1 - 4 | S50333000 | ||
| Z1 - 9 | S50335000 | ||
| Z1 - 10 | S50336000 | ||
| Z1 - 11 | S50337000 | ||
| Z1 - 12 | S50338000 | ||
| Z1 - 17 | S50339001 | ||
| A - 42 | S50340000 | ||
| Y - 4 | S50341001 | ||
| Z1 - 14 | S50342000 | ||
| Z2 - 28 | S50343001 | ||
| Z2 - 29 | S50344001 | ||
| Z2 - 38 | S50345001 | ||
| Z3 - 1 | S50346001 | ||
| Z3 - 20 | S50348001 | ||
| Z3 - 22 | S50349001 | ||
| Z3 - 37 | S50350001 | ||
| Z3 - 40 | S50351001 | ||
| S - 3 | S50354000 | ||
| M - 7 | S50356001 | ||
| M - 12 | S50359001 | ||
| M - 14 | S50360001 | ||
| H - 40 | S50362001 | ||
| H - 43 | S50363000 | ||
| H - 44 | S50364001 | ||
| H - 47 | S50365101 | ||
| H - 49 | S50366001 | ||
| N - 1 | S50368001 | ||
| N - 2 | S50369001 | ||
| N - 6 | S50370001 | ||
| N - 8 | S50371101 | ||
| N - 10 | S50372101 | ||
| N - 11 | S50373101 | ||
| N - 14 | S50374001 | ||
| N - 15 | S50375001 | ||
| N - 16 | S50376101 | ||
| - 31 | N | ||
| N - 21 | S50377001 | ||
| N - 23 | S50378001 | ||
| N - 28 | S50380000 | ||
| N - 30 | S50382001 | ||
| N - 34 | S50383001 | ||
| N - 45 | S50384101 | ||
| - 70 | N | ||
| N - 46 | S50385001 | ||
| N - 52 | S50386101 | ||
| N - 53 | S50387001 | ||
| N - 56 | S50388001 | ||
| N - 58 | S50389001 | ||
| N - 67 | S50390101 | ||
| N - 60 | S50391001 | ||
| N - 73 | S50392001 | ||
| N - 77 | S50393000 | ||
| Q - 1 | S50394001 | ||
| Q - 7 | S50395201 | ||
| Q - 8 | S50398001 | ||
| Q - 9 | S50399101 | ||
| Q - 10 | S50400001 | ||
| Q - 12 | S50401001 | ||
| Q - 18 | S50403101 | ||
| Q - 24 | S50404401 | ||
| Q - 25 | S50405301 | ||
| Q - 40 | S50410101 | ||
| Q - 42 | S50411101 | ||
| - 11 | R | ||
| Q - 43 | S50412000 | ||
| Q - 44 | S50413101 | ||
| Q - 46 | S50414001 | ||
| Q - 47 | S50415001 | ||
| Q - 48 | S50416001 | ||
| T1 - 8 | S50425101 | ||
| T1 - 14 | S50431101 | ||
| T1 - 20 | S50437000 | ||
| T1 - 21 | S50438000 | ||
| T1 - 22 | S50439000 | ||
| T1 - 24 | S50441000 | ||
| T2 - 1 | S50442001 | ||
| - 7 | T2 | ||
| T2 - 2 | S50444001 | ||
| T2 - 3 | S50446001 | ||
| T2 - 6 | S50447001 | ||
| V - 4 | S50453100 | ||
| V - 5 | S50457000 | ||
| U - 1 | S50458100 | ||
| U - 2 | S50459100 | ||
| U - 3 | S50460000 | ||
| U - 4 | S50461000 | ||
| U - 5 | S50462000 | ||
| U - 7 | S50463000 | ||
| U - 8 | S50464000 | ||
| - 12 | U | ||
| U - 10 | S50465000 | ||
| U - 17 | S50466000 | ||
| U - 18 | S50467000 | ||
| U - 20 | S50468000 | ||
| U - 27 | S50472000 | ||
| U - 28 | S50473000 | ||
| Z3 - 38 | S50476001 | ||
| Z3 - 25 | S50477001 | ||
| T1 - 25 | S50484000 | ||
| T1 - 39 | S50498001 | ||
| Q - 59 | S50511101 | ||
| M - 23 | S50513100 | ||
| M - 24 | S50514000 | ||
| M - 25 | S50515000 | ||
| M - 26 | S50516001 | ||
| M - 29 | S50517001 | ||
| M - 31 | S50518000 | ||
| M - 32 | S50519000 | ||
| M - 34 | S50520000 | ||
| M - 35 | S50521000 | ||
| M - 37 | S50522000 | ||
| M - 39 | S50524000 | ||
| M - 40 | S50525000 | ||
| M - 41 | S50527000 | ||
| M - 42 | S50528000 | ||
| M - 43 | S50529000 | ||
| M - 44 | S50530000 | ||
| M - 45 | S50531000 | ||
| M - 46 | S50532000 | ||
| M - 54 | S50533000 | ||
| M - 55 | S50536001 | ||
| M - 58 | S50537000 | ||
| - 72 | M | ||
| M - 59 | S50538001 | ||
| M - 60 | S50539000 | ||
| M - 61 | S50540001 | ||
| M - 63 | S50541001 | ||
| M - 65 | S50542001 | ||
| M - 67 | S50543001 | ||
| M - 68 | S50544000 | ||
| M - 70 | S50545000 | ||
| M - 71 | S50546000 | ||
| M - 73 | S50547000 | ||
| M - 75 | S50548001 | ||
| M - 77 | S50549000 | ||
| M - 78 | S50550001 | ||
| M - 80 | S50551001 | ||
| M - 82 | S50552000 | ||
| M - 16 | S50556000 | ||
| M - 21 | S50557000 | ||
| M - 22 | S50558000 | ||
| M - 19 | S50559001 | ||
| G - 45 | S50562101 | ||
| M - 17 | S50563000 | ||
| U - 36 | S50565001 | ||
| U - 46 | S50644000 | ||
| T1 - 26 | S50644001 | ||
| T1 - 18 | S50645000 | ||
| S - 1 | S50657001 | ||
| Ga3 | S50663001 | ||
| R - 76 | S50664001 | ||
| Ga3 | |||
| Ga3 | S50665001 | ||
| M - 83 | S51020000 | ||
| Ga1 | S51117001 | ||
| N - 59 | S51182501 | ||
| N - 47 | S51183101 | ||
| N - 36 | S51184201 | ||
| D - 11 | S51190001 | ||
| R - 76 | S51248101 | ||
| Ga3 | |||
| Ga3 | S51249101 | ||
| Ga3 | S51250101 | ||
| Z2 - 7 | S51282101 | ||
| Z2 - 5 | S51283001 | ||
| Z1 - 26 | S51290001 | ||
| Ga1 | |||
| Z1 - 25 | S51351001 | ||
| H - 25 | S51352001 | ||
| Ga1 | |||
| Ga1 | S51353001 | ||
| Z1 - 27 | S51354001 | ||
| Ga1 | |||
| Ga1 | S51355001 | ||
| Z1 - 29 | S51356001 | ||
| Ga1 | |||
| Ga1 | S51357001 | ||
| Z1 - 28 | S51358001 | ||
| Ga1 | |||
| Ga1 | S51359001 | ||
| Ga1 | S51360001 | ||
| Y - 1 | S51361001 | ||
| Y - 1 | S51362001 | ||
| Y - 1 | S51363001 | ||
| Y - 1 | S51364001 | ||
| Y - 1 | S51365001 | ||
| Y - 1 | S51366001 | ||
| Z3 - 2 | S51896001 | ||
| B - 14 | S52248001 | ||
| Q - 29 | S52431000 | ||
| R - 46 | S52433001 | ||
| R - 49 | S52434001 | ||
| Q - 5 | S52761101 | ||
| M - 38 | S52763000 | ||
| M - 2 | S52764001 | ||
| R - 56 | S52770000 | ||
| R - 54 | S52778101 | ||
| B - 9 | S52943101 | ||
| T3 - 1 | S53902301 | ||
| K - 12 | S54741001 | ||
| Z2 - 47 | S54767000 | ||
| Z1 - 4 | S54768001 | ||
| Ga2 | S55345002 | ||
| Ga2 | S55347202 | ||
| Ga2 | S55348001 | ||
| Ga2 | S55350201 | ||
| Z3 - 52 | S55361200 | ||
| Z1 - 30 | S55663001 | ||
| N - 71 | S55975001 | ||
| K - 4 | S56391001 | ||
| G - 13 | S59890001 | ||
| - 41 | G | ||
| H - 22 | S59891001 | ||
| G - 32 | S59892001 | ||
| G - 31 | S59893001 | ||
| - 35 | G | ||
| - 24 | G | ||
| - 61 | Q | ||
| G - 18 | S59894001 | ||
| - 39 | H | ||
| R - 18 | S59987101 | ||
| U - 47 | SA0287000 | ||
| A - 46 | SA0792001 | ||
| Wa | |||
| A - 45 | SA0793001 | ||
| Wa | |||
| N - 29 | SA0990001 | ||
| N - 26 | SA0992001 | ||
| H - 10 | SA2385001 | ||
| H - 38 | SA2412001 | ||
| T1 - 13 | SA2823001 | ||
| T1 - 6 | SA2870001 | ||
| - 40 | Z2 | ||
| D - 7 | SA2881001 | ||
| B - 25 | SA2921101 | ||
| F - 21 | SA3001001 | ||
| - 25 | F | ||
| - 26 | R | ||
| Z2 - 27 | SA3025001 | ||
| L - 2 | SA3033001 | ||
| N - 81 | SA3035001 |
Page 76 — 索引 / Index
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| T1 - 28 | SA3079001 | ||
| V - 1 | SA3081001 | ||
| T1 - 28 | SA3101001 | ||
| U - 25 | SA3113001 | ||
| T1 - 38 | SA3176101 | ||
| T1 - 30 | SA3189001 | ||
| T1 - 37 | SA3190001 | ||
| T1 - 36 | SA3191001 | ||
| T1 - 35 | SA3192001 | ||
| T1 - 34 | SA3193001 | ||
| T1 - 41 | SA3194001 | ||
| T1 - 32 | SA3195001 | ||
| T1 - 31 | SA3196001 | ||
| T1 - 42 | SA3797001 | ||
| T1 - 33 | SA3921001 | ||
| T2 - 4 | SA3966001 | ||
| T2 - 5 | SA3967001 | ||
| T2 - 9 | SA3969001 | ||
| T2 - 8 | SA4020001 | ||
| T1 - 1 | SA4024001 | ||
| B - 5 | SA4047301 | ||
| M - 18 | SA4063001 | ||
| C - 4 | SA4065001 | ||
| M - 85 | SA4066001 | ||
| M - 86 | SA4067001 | ||
| A - 3 | SA4206001 | ||
| N - 37 | SA4232001 | ||
| N - 44 | SA4233001 | ||
| N - 20 | SA6113001 | ||
| T1 - 15 | SA6302001 | ||
| T1 - 16 | SA6303001 | ||
| Z2 - 10 | SA6606001 | ||
| Z2 - 14 | SA6607001 | ||
| - 15 | Z2 | ||
| Z2 - 18 | SA6609001 | ||
| K - 6 | SA7402001 | ||
| K - 2 | SA7405001 | ||
| U - 26 | SA7488001 | ||
| F - 42 | SA7607001 | ||
| K - 16 | SA8126001 | ||
| T1 - 23 | SA8391001 | ||
| T1 - 46 | SA8886001 | ||
| N - 66 | SA9058001 | ||
| K - 15 | SA9138001 | ||
| K - 24 | SA9140001 | ||
| K - 25 | SA9141001 | ||
| Z2 - 23 | SA9157001 | ||
| Z2 - 24 | SA9158001 | ||
| Z2 - 25 | SA9159001 | ||
| Z2 - 49 | SA9160001 | ||
| Z2 - 50 | SA9161001 | ||
| Q - 13 | SA9165001 | ||
| Q - 31 | SA9166001 | ||
| Q - 32 | SA9167001 | ||
| Q - 34 | SA9168001 | ||
| Q - 52 | SA9169001 | ||
| Q - 53 | SA9170001 | ||
| Q - 60 | SA9171001 | ||
| Q - 56 | SA9172001 | ||
| Z1 - 39 | SA9254011 | ||
| Z1 - 39 | SA9254014 |
Brother HE-800A — parts catalog
- Page 1 (cover): This is the cover page for the Brother HE-800A Electronic Lockstitch Button Holder parts book, providing information on where to find the latest parts information.
- Page 2 (toc): This page is a table of contents for the parts book, listing various sections related to machine components and their corresponding page numbers, along with general notes about the parts book.
- Page 3 (toc): This page provides notes for using the parts book and a table of contents listing various mechanisms and accessories with their corresponding page numbers.
- Page 4 (diagram): This page displays a diagram of the machine body with various components labeled with reference numbers.
- Page 5 (parts_list): This page lists parts for the machine body, including screws, covers, caps, shafts, hinges, and various labels.
- Page 6 (diagram): This page illustrates the needle bar and thread take-up mechanism of an industrial sewing machine, showing various components with reference numbers.
- Page 7 (parts_list): This page lists parts for the needle bar and thread take-up mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 8 (diagram): This page illustrates the upper shaft mechanism of an industrial sewing machine, showing various components such as shafts, pulleys, bearings, and belts with corresponding reference numbers.
- Page 9 (parts_list): This page lists parts for the upper shaft mechanism, including various shafts, rings, bearings, bushes, screws, pulleys, belts, nuts, and collars.
- Page 10 (diagram): This page displays a diagram of the zigzag mechanism components for an industrial sewing machine.
- Page 11 (parts_list): This page lists parts for the Zigzag mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 12 (diagram): This page displays a diagram of an emergency stop mechanism, showing two components labeled with reference numbers 1 and 2.
- Page 13 (parts_list): This page lists parts for the emergency stop mechanism, including an emergency stop cover and a pan head screw.
- Page 14 (diagram): This page illustrates the presser foot mechanism with an exploded view, showing various components and their reference numbers.
- Page 15 (parts_list): This page lists parts for the presser foot mechanism, including various bolts, washers, shafts, and other components.
- Page 16 (diagram): This page illustrates the feed mechanism components for an industrial sewing machine, showing an exploded view of various parts and their reference numbers.
- Page 17 (parts_list): This page lists parts for the feed mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 18 (diagram): This page illustrates the feed mechanism components with an exploded view diagram and corresponding reference numbers.
- Page 19 (parts_list): This page lists parts for the feed mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 20 (diagram): This page illustrates the cutter mechanism of the sewing machine, showing various components and their assembly.
- Page 21 (parts_list): This page lists parts for the cutter mechanism, including various shafts, screws, holders, and springs, with their part numbers, quantities, and descriptions.
- Page 22 (diagram): This page illustrates the thread breakage detector mechanism with a diagram showing various components and their reference numbers.
- Page 23 (parts_list): This page lists parts for the thread breakage detector mechanism, including thread guides, washers, screws, and levers.
- Page 24 (diagram): This page illustrates the rotary hook mechanism and related supply parts for the HE-800A-301 model, showing an exploded view of various components.
- Page 25 (parts_list): This page lists parts for the K. rotary hook mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 26 (diagram): This page illustrates the lower shaft mechanism with a diagram showing various components and their reference numbers.
- Page 27 (parts_list): This page lists parts for the lower shaft mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 28 (diagram): This page illustrates the lubrication system of the sewing machine, showing various components such as tubes, oil filters, and related parts with their corresponding reference numbers.
- Page 29 (parts_list): This page lists parts related to lubrication for the HE-800A-350 model, including plungers, springs, screws, filters, tubes, felts, packings, and wicks.
- Page 30 (diagram): This page illustrates the lubrication system components for the HE-800A-350 model, showing various parts such as oil filters, tubes, and related fittings.
- Page 31 (parts_list): This page lists lubrication-related parts with their reference numbers, part numbers, quantities, Japanese names, and English names.
- Page 32 (diagram): This page illustrates the threading mechanism of the sewing machine with a detailed diagram and reference numbers for various components.
- Page 33 (parts_list): This page lists parts related to the threading mechanism, including various levers, screws, washers, and tension components.
- Page 34 (diagram): This page illustrates the threading mechanism of an industrial sewing machine, showing various components and their reference numbers.
- Page 35 (parts_list): This page lists parts for the threading mechanism, including washers, tension nuts, springs, screws, O-rings, and various guides and plates.
- Page 36 (diagram): This page illustrates the bobbin winder mechanism with a detailed diagram showing various components and their reference numbers.
- Page 37 (parts_list): This page lists parts for the bobbin winder mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 38 (diagram): This page illustrates the upper thread trimmer mechanism with a detailed exploded view and corresponding reference numbers.
- Page 39 (parts_list): This page lists parts for the upper thread trimmer mechanism, including part numbers, quantities, and descriptions.
- Page 40 (diagram): This page illustrates the lower thread trimmer mechanism with a detailed diagram and reference numbers for various components.
- Page 41 (parts_list): This page lists parts for the lower thread trimmer mechanism, including part numbers, quantities, and descriptions.
- Page 42 (diagram): This page illustrates the lower thread trimmer mechanism with an exploded view diagram and corresponding reference numbers.
- Page 43 (parts_list): This page lists parts for the lower thread trimmer mechanism, including screws, plates, pins, and springs, with their corresponding part numbers, quantities, and descriptions.
- Page 44 (diagram): This page displays a diagram of the synchronizer components, including the synchronizer itself, screws, and other related parts.
- Page 45 (parts_list): This page lists parts related to the synchronizer, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 46 (diagram): This page illustrates the control box mechanism with an exploded view of its components, including various electrical parts and connectors.
- Page 47 (parts_list): This page lists parts for the T1. Control box mechanism, including transformers, power supply PCBs, varistors, fuses, transistors, harnesses, and other electrical components.
- Page 48 (diagram): This page illustrates various control box mechanisms for different voltage specifications, including 3-Phase 200V AC, 1-Phase 110V/220V AC, 1-Phase 100V AC (Japan), 1-Phase 110V AC, 3-Phase 380V AC, 3-Phase 400V AC, and 3-Phase 220V AC.
- Page 49 (parts_list): This page lists parts for the control box mechanism, including power supply switches and transformers for various AC voltages.
- Page 50 (diagram): This page illustrates the control box (PCB) mechanism with a diagram showing various components and their reference numbers.
- Page 51 (parts_list): This page lists parts for the T3 Control Box (PCB) mechanism, including part numbers, quantities, and descriptions for components like the main PCB assembly, transistors, diode, and glass fuse.
- Page 52 (diagram): This page illustrates the power supply equipment mechanism with a detailed diagram showing various electrical components and their connections.
- Page 53 (parts_list): This page lists parts for the power supply equipment mechanism, including pulse motors, sensors, screws, and various other electrical components.
- Page 54 (diagram): This page displays a diagram of the operation panel mechanism, showing various components and their interconnections.
- Page 55 (parts_list): This page lists parts for the operation panel mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 56 (diagram): This page illustrates the motor mechanism with a diagram showing various components and their reference numbers.
- Page 57 (parts_list): This page lists parts related to the motor mechanism, including part numbers, quantities, and descriptions in both Japanese and English.
- Page 58 (diagram): This page displays a diagram of a safety cover assembly, showing various components and their reference numbers.
- Page 59 (parts_list): This page lists safety cover parts, including motor covers, belt covers, and various screws, with their corresponding part numbers, quantities, and descriptions.
- Page 60 (diagram): This page illustrates attachment sets for general materials, knitted materials, and standing operation, showing various components with reference numbers.
- Page 61 (parts_list): This page lists attachment set option parts for general materials and knitted materials, including needle plates, cutter holders, and positioning plates, along with parts for standing operation.
- Page 62 (diagram): This page displays an exploded view diagram of various accessories for a sewing machine, including tools, oil, and other components.
- Page 63 (parts_list): This page lists accessories and parts for a sewing machine, including bed base components, screws, washers, cutters, and control box attachments.
- Page 64 (diagram): This page displays a diagram of accessories for an industrial sewing machine, including thread stands, tables, and other components.
- Page 65 (parts_list): This page lists accessories for the HE-800A-910 model, including various screws, bolts, covers, and other components, with their part numbers, quantities, and descriptions.
- Page 66 (diagram): This page displays a diagram of accessories for an industrial sewing machine, including various components like thread guides, tension springs, and other attachments.
- Page 67 (parts_list): This page lists accessories and parts for a sewing machine, including tape guides, screws, washers, rulers, and connecting rods.
- Page 68 (parts_list): This page displays a gauge parts list for cutters, featuring various part numbers with corresponding diagrams and dimensions.
- Page 69 (parts_list): This page lists gauge parts for different models, including work clamp assemblies, finger guards, and work clamps, with corresponding part numbers and descriptions.
- Page 70 (parts_list): This page displays gauge parts lists for needle plates and flat cutters, categorized by different specifications and models.
- Page 71 (parts_list): This page lists various warning labels, their names, sizes, and corresponding codes.
- Page 72 (index): This page is an index providing a lookup for part codes, their reference numbers, and the page where they can be found.
- Page 73 (index): This page is an index listing part codes, reference numbers, and their corresponding page numbers.
- Page 74 (index): This page is an index listing part numbers, their corresponding reference numbers, and the page where they can be found.
- Page 75 (index): This page is an index listing part codes, their reference numbers, and the page where they can be found.
- Page 76 (index): This page is an index listing part codes, reference numbers, and their corresponding page numbers.
- Page 77 (text): This page is a memo page with the word "MEMO" centered at the top.
- Page 78 (text): This page is a blank memo page with the word "MEMO" at the top and a watermark of "jintex.in" diagonally across the page.
- Page 79 (text): This page is a blank memo page with a watermark and page number 76.
- Page 80 (cover): This is the cover page for the Brother Parts Book, providing contact information for Brother Industries, Ltd. and identifying the document as SA9164001, dated 2007.11.B (1).
