Jack JK-804 / JK-805 Parts Book (PDF)
Text index — Jack JK-804 / JK-805
Page 8 — 一、机壳部件 Machine Bed Frame
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 302531 | Machine Bed Complete | 1/1/1 |
| 2 | 20122005 | Oil seal | 1/1/1 |
| 3 | 20111010 | Oil sight | 1/1/1 |
| 4 | 20137001 | Machine model plate | 1/1/1 |
| 5 | R03001 | Rivet | 2/2/2 |
| 6 | 20103009 | Sleeve | 1/1/1 |
| 7 | 20703001 | Sleeve | 1/1/1 |
| 8 | 20122025 | Oil seal | 1/1/1 |
| 9 | 20103015 | Sleeve | 1/1/1 |
| 10 | 20103011 | Sleeve | 1/1/1 |
| 11 | 20622019 | Oil seal | 1/1/1 |
| 12 | 20622019 | Oil seal | 0/0/1 |
| 13 | 20122040 | Oil seal | 1/1/0 |
| 14 | 20103013 | Sleeve | 0/0/1 |
| 15 | 20103014 | Sleeve | 0/0/1 |
| 16 | 2012603100 | Oil filter pin component | 1/1/1 |
| 17 | 201S30006 | Screw | 4/4/4 |
| 18 | 20129001 | Ring | 1/1/1 |
| 19 | 20103003 | Sleeve | 1/1/1 |
| 20 | 20103017 | Sleeve | 1/1/1 |
| 21 | 20122008 | Oil seal | 1/1/0 |
| 22 | 20103016 | Sleeve | 0/0/1 |
| 23 | 20103015 | Sleeve | 0/0/1 |
| 24 | 20122009 | Oil seal | 1/1/1 |
| 25 | 20103019 | Sleeve | 1/1/1 |
| 26 | 20103020 | Sleeve | 1/1/1 |
| 27 | 20122008 | Oil seal | 1/1/1 |
| 28 | 20703002 | Sleeve | 1/1/1 |
| 29 | 20703001 | Sleeve | 1/1/1 |
| 30 | P03042 | Pin | 1/1/1 |
| 31 | 20103023 | Sleeve | 1/1/1 |
| 32 | 20103024 | Sleeve | 1/1/1 |
| 33 | 20122003 | Oil seal | 1/1/1 |
| 34 | 20113013 | Pipe | 2/2/2 |
| 35 | 201S11039 | Pipe | 1/1/1 |
| 36 | 20722004 | Oil seal | 1/1/1 |
Page 10 — Cover Assemblies (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 302036 | Side Cover | 1 / 1 / 1 |
| 2 | 207S17005 | Screw | 4 / 4 / 4 |
| 3 | 201S11025 | Screw | 4 / 4 / 4 |
| 4 | 20111005 | Oil sight window | 1 / 1 / 1 |
| 5 | 20122018 | Oil level gauge washer | 1 / 1 / 1 |
| 6 | 20113030 | Thread guide supporter | 1 / 1 / 1 |
| 7 | 206S11005 | Screw | 2 / 2 / 2 |
| 8 | 302529 | Upper cover | 1 / 1 / 1 |
| 8 | 302638 | Upper cover | 1 / 1 / 1 |
| 9 | 20112103 | Oil guard | 1 / 1 / 1 |
| 10 | S01035 | Screw | 3 / 3 / 3 |
| 11 | 20122202 | Upper cover washer | 1 / 1 / 1 |
| 12 | 20112020 | Front cover snap guard | 1 / 1 / 1 |
| 13 | 201S11014 | Screw | 1 / 1 / 1 |
| 14 | 20112091 | Right Cover | 1 / 1 / 1 |
| 15 | 20111054 | Belt Cover Assembly | 1 / 1 / 1 |
| 15 | 20111060 | Belt Cover Assembly | 1 / 1 / 1 |
| 16 | 20112012 | Upper looper sealing plate | 1 / 1 / 1 |
| 17 | 201S11016 | Screw | 2 / 2 / 2 |
| 18 | 201S11009 | Screw | 4 / 4 / 4 |
| 19 | 20112017 | Front spring | 1 / 1 / 1 |
| 20 | 301642 | Front cover | 1 / 1 / 1 |
| 21 | 20112100 | Front cover guard | 1 / 1 / 0 |
| 21 | 20112101 | Front cover guard | 0 / 0 / 1 |
| 22 | 20126003 | Pin | 1 / 1 / 1 |
| 23 | 201S15001 | Screw | 3 / 3 / 3 |
| 24 | 20101007 | Front cover hinge | 1 / 1 / 1 |
| 25 | 201S11038 | Screw | 3 / 3 / 3 |
| 26 | 20122017 | Front cover hinge washer | 1 / 1 / 1 |
| 27 | H05002 | Snap spring | 1 / 1 / 1 |
| 28 | 20127005 | Front cover hinge spring | 1 / 1 / 1 |
| 29 | 20126004 | Hinge Pin | 1 / 1 / 1 |
| 30 | 201S11018 | Screw | 3 / 3 / 3 |
| 31 | 20122015 | Upper looper sealing plate washer | 1 / 1 / 1 |
| 32 | S01010 | Screw | 2 / 2 / 2 |
Page 12 — 三、罩壳部件 (2) Cover Assemblies (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 201S11016 | Screw | 6 / 6 / 6 |
| 2 | 20101054 | Cover | 1 / 1 / 1 |
| 2 | 20101004 | Cover | 1 / 1 / 1 |
| 3 | 20122024 | Plate washer | 1 / 1 / 1 |
| 4 | 20101019 | Plate | 1 / 1 / 1 |
| 5 | 201S12009 | Screw | 2 / 2 / 2 |
| 6 | 206S20004 | Screw | 1 / 1 / 1 |
| 7 | 20128015 | Washer | 1 / 1 / 1 |
| 8 | 20112098 | Bracket | 1 / 1 / 1 |
| 9 | 20711005 | Eye guide | 1 / 1 / 0 |
| 9 | 20711019 | Eye guide | 0 / 0 / 1 |
| 10 | S01034 | Screw | 2 / 2 / 2 |
| 11 | W01011 | Washer | 2 / 2 / 2 |
| 12 | 201S17004 | Screw | 2 / 2 / 2 |
| 13 | 20111003 | Oil baffle cover | 1 / 1 / 1 |
| 14 | 20128030 | Washer | 2 / 2 / 2 |
| 15 | 20127004 | Cloth Plate cover spring | 1 / 1 / 1 |
| 16 | 20112011 | Cloth Plate slider cover | 1 / 1 / 1 |
| 17 | 201S20003 | Screw | 1 / 1 / 1 |
| 18 | 20122011 | Rubber bushing | 1 / 1 / 1 |
| 19 | 201S30011 | Screw | 1 / 1 / 1 |
| 20 | 201S16003 | Nut | 1 / 1 / 1 |
| 21 | 20122012 | Rubber bushing | 1 / 1 / 1 |
| 22 | 201S30007 | Screw | 1 / 1 / 1 |
| 23 | 201S16001 | Nut | 1 / 1 / 1 |
| 24 | 201S11006 | Screw | 2 / 2 / 2 |
| 25 | 20127003 | Spring | 1 / 1 / 1 |
| 26 | 20112009 | Pedestal | 1 / 1 / 1 |
| 27 | 20122013 | Rubber bushing | 1 / 1 / 1 |
| 28 | 201S11037 | Screw | 3 / 3 / 3 |
| 29 | 20128019 | Washer | 3 / 3 / 3 |
| 30 | 20111206 | Cloth palte lower Plate | 1 / 1 / 1 |
| 31 | 20112008 | Casing connection plate | 3 / 3 / 3 |
| 32 | 201S20010 | Screw | 1 / 1 / 1 |
| 33 | W02004 | Washer | 1 / 1 / 1 |
| 34 | 201S14002 | Screw | 1 / 1 / 1 |
| 35 | 20103001 | Sleeve | 1 / 1 / 1 |
| 36 | 20112006 | Bed cover plate | 1 / 1 / 1 |
| 37 | 2011208100 | Cloth Plate | 1 / 1 / 1 |
| 38 | 20112202 | Fabric Guide | 1 / 1 / 1 |
| 39 | S01002 | Screw | 3 / 3 / 3 |
| 40 | 20112002 | Cover Plate | 1 / 1 / 1 |
| 41 | 201S11016 | Screw | 6 / 6 / 6 |
| 42 | 20122007 | Cover Washer | 1 / 1 / 1 |
Page 14 — 四、主轴部分 Main Shaft Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20102205 | Main shaft | 1 / 1 / 1 |
| 1 | 20102204 | Main shaft | 0 / 0 / 1 |
| 2 | B03001 | Bearing | 2 / 2 / 2 |
| 3 | 20125001 | Oil Pump worm | 1 / 1 / 1 |
| 4 | 20128002 | Main shaft spring washer | 1 / 1 / 1 |
| 5 | 20103002 | Main shaft bysgubg asm | 1 / 1 / 1 |
| 6 | 001003 | Seal ring | 1 / 1 / 1 |
| 7 | 20122019 | Washer | 1 / 1 / 1 |
| 8 | 20101008 | Rear shaft spring cover | 1 / 1 / 1 |
| 8 | 20101074 | Rear shaft spring cover | 1 / 1 / 1 |
| 9 | 20111008 | Wheel | 1 / 1 / 1 |
| 10 | 20101012 | Key | 1 / 1 / 1 |
| 11 | 300076 | Pulley | 1 / 1 / 1 |
| 12 | 20128024 | Washer | 1 / 1 / 1 |
| 13 | 201S11034 | Screw | 1 / 1 / 1 |
| 14 | 201S15004 | Screw | 2 / 2 / 2 |
| 15 | 201S11016 | Screw | 3 / 3 / 3 |
| 16 | 201S14002 | Screw | 1 / 1 / 1 |
| 17 | 20124003 | Bearing | 1 / 1 / 1 |
| 18 | 20122046 | Washer | 1 / 1 / 1 |
| 19 | 201S11069 | Screw | 1 / 1 / 0 |
| 20 | 20112106 | Cover | 1 / 1 / 0 |
| 21 | S01010 | Screw | 3 / 3 / 0 |
| 22 | 20126024 | Bulgy pulley shaft | 0 / 0 / 1 |
| 23 | 20112107 | Cover | 0 / 0 / 1 |
| 24 | S02004 | Screw | 0 / 0 / 2 |
| 25 | S01010 | Screw | 0 / 0 / 1 |
Page 16 — 五、过线部件 (1) Thread Guide and Thread Takeup (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 400662 | Tension Spring Assembly（Yellow） | 0 / 1 / 1 |
| 2 | 400661 | Tension Spring Assembly（Red） | 1 / 1 / 1 |
| 3 | 400663 | Tension Spring Assembly（Blue） | 1 / 1 / 1 |
| 4 | 400668 | Tension Spring Assembly（Green） | 1 / 1 / 1 |
| 5 | 20711034 | Knob | 3 / 4 / 4 |
| 6 | 30111006 | Rachet | 3 / 4 / 4 |
| 7 | 20127018 | Thread tension spring | 2 / 2 / 2 |
| 8 | 30111005 | Cup | 3 / 4 / 4 |
| 9 | 20112057 | Tension Disc | 6 / 8 / 8 |
| 10 | 20623008 | Felt | 3 / 4 / 4 |
| 11 | 201S30016 | Screw Stud | 3 / 4 / 4 |
| 12 | 20113002 | Thread guide | 3 / 4 / 4 |
| 13 | 20127020 | Thread tension spring | 1 / 1 / 1 |
| 14 | 20127019 | Thread tension spring | 1 / 1 / 1 |
| 15 | 20113016 | Lower looper thread guide | 1 / 1 / 1 |
| 16 | 206S11002 | Lower looper | 1 / 1 / 1 |
| 17 | 20113032 | Thread guide | 1 / 1 / 1 |
| 18 | 20113033 | Lower looper3-thread guide | 1 / 1 / 1 |
| 19 | 20113034 | Thread guide | 1 / 1 / 1 |
| 20 | 201S11016 | Screw | 1 / 1 / 1 |
| 21 | 20113035 | Upper looper thread guard | 1 / 1 / 1 |
| 22 | 20128020 | Thread guide washer | 2 / 2 / 2 |
| 23 | 201S11006 | Thread guide screw | 2 / 2 / 2 |
| 24 | 20112027 | Thread amount regulating plate | 1 / 1 / 1 |
| 25 | 201S11014 | Screw | 1 / 1 / 1 |
| 26 | 20113015 | Lower looper thread guide | 1 / 1 / 1 |
| 27 | 201S11016 | Screw | 1 / 1 / 1 |
Page 18 — 六、过线部件 (2) Thread Guide and Thread Takeup (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20113208 | Thread Guide | 1 / 0 / 0 |
| 1 | 20113207 | Thread Guide | 0 / 1 / 0 |
| 2 | 207S11019 | Screw | 1 / 1 / 0 |
| 3 | 20701010 | Bracket | 1 / 1 / 0 |
| 4 | 207S11019 | Screw | 1 / 1 / 0 |
| 5 | S10007 | Screw | 1 / 1 / 0 |
| 6 | 20713002 | Thread Guide | 1 / 0 / 0 |
| 6 | 20713003 | Thread Guide | 0 / 1 / 0 |
| 7 | 207S20003 | Screw | 1 / 1 / 0 |
| 8 | 20727002 | Spring | 1 / 1 / 0 |
| 9 | 20713007 | Thread Retainer | 1 / 1 / 0 |
| 10 | 20713006 | Bracket | 1 / 1 / 0 |
| 11 | 201S11009 | Screw | 2 / 2 / 0 |
| 12 | 20113204 | Thread Takeup | 1 / 0 / 0 |
| 12 | 20113203 | Thread Takeup | 0 / 1 / 0 |
Page 20 — 七、过线部件 (3) Thread Guide and Thread Takeup (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20701029 | Bracket | 0 / 0 / 1 |
| 2 | 20713021 | Thread Guide | 0 / 0 / 1 |
| 3 | 20713022 | Thread Guide | 0 / 0 / 1 |
| 3 | 20713050 | Thread Guide | 0 / 0 / 1 |
| 4 | S01031 | Screw | 0 / 0 / 3 |
| 5 | 20713023 | Thread Guide | 0 / 0 / 1 |
| 5 | 20713051 | Thread Guide | 0 / 0 / 1 |
| 6 | 20113205 | Thread Takeup | 0 / 0 / 1 |
| 6 | 20113206 | Thread Takeup | 0 / 0 / 1 |
| 7 | S10007 | Screw | 0 / 0 / 2 |
| 8 | 20713020 | Thread Guide | 0 / 0 / 1 |
| 9 | 20701030 | Bracket | 0 / 0 / 1 |
| 10 | 207S11019 | Screw | 0 / 0 / 2 |
Page 22 — 八、针杆部件 (1) Needle Drive Mechanism (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 207S11023 | Screw | 1 / 1 / 1 |
| 20708005 | |||
| 20723003 | |||
| 207S14008 | 螺钉M4×5 | ||
| 001026 | O型圈11.5×1.5 | ||
| 20726003 | |||
| 20523005 | |||
| 20702003 | |||
| 20603030 | |||
| 20704002 | |||
| 207S12002 | 螺钉M6×0.75×12 | ||
| 20702002 | |||
| 20104201 | |||
| 20104204 | |||
| S05017 | 螺钉M6×0.75×13.5 | ||
| 20708004 | |||
| S10007 | 螺钉M4×4 | ||
| 20628014 | |||
| H05008 | |||
| 20126025 | |||
| S10008 | 螺钉M4×6 | ||
| 20105203 | |||
| 201S20015 | 螺钉M4×16 |
Page 24 — 九、针杆部件 (2) Needle Drive Mechanism (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | **** | Needle Holder Assembly | 0/1/0 |
| 1 | **** | Needle Holder Assembly | 1/0/0 |
| 1 | **** | Needle Holder Assembly | 0/0/1 |
| 1 | **** | Needle Holder Assembly | 0/0/1 |
| 1 | **** | Needle Holder Assembly | 0/0/1 |
| 2 | S10026 | Screw | 2/2/2 |
| 3 | **** | Needle | 0/2/0 |
| 3 | **** | Needle | 1/0/0 |
| 3 | **** | Needle | 0/0/2 |
| 3 | **** | Needle | 0/0/2 |
| 4 | 20713018 | Thread Guide | 0/1/0 |
| 4 | 20713038 | Thread Guide | 1/0/0 |
| 4 | 20713017 | Thread Guide | 0/0/1 |
| 5 | 207S11024 | Screw | 1/1/1 |
Page 26 — 十、针杆部件 (3) Needle Drive Mechanism (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 201S17005 | Throat screw | 2/2/2 |
| 2 | **** | Needle plate | 1/0/0 |
| 2 | **** | Needle plate | 1/0/0 |
| 2 | **** | Needle plate | 0/1/0 |
| 2 | **** | Needle plate | 0/0/1 |
| 2 | **** | Needle plate | 0/0/1 |
| 2 | **** | Needle plate | 0/0/1 |
| 3 | 201S11018 | Throat plate bracket screw | 2/2/2 |
| 4 | 201S11008 | Front needle snap screw | 1/1/1 |
| 5 | **** | Front needle guard | 1/1/0 |
| 5 | **** | Front needle guard | 0/0/1 |
| 6 | 20101016 | Throat plate bracket | 1/1/1 |
| 7 | 20122011 | Rubber bushing | 2/2/2 |
| 8 | 20101017 | Needle guard bracket | 1/1/0 |
| 8 | 20101018 | Needle guard bracket | 0/0/1 |
| 9 | 201S11022 | screw | 2/2/2 |
| 10 | **** | Needle guard II | 0/0/1 |
| 11 | 201S11003 | screw | 0/0/2 |
| 12 | **** | Needle guard I | 0/0/1 |
| 13 | 201S11003 | screw | 0/0/2 |
| 14 | 201S12009 | screw | 1/1/1 |
| 15 | **** | Teat needle guard | 1/1/1 |
Page 28 — 十一、上弯针部分 Upper Looper Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 201S12005 | Upper looper shaft screw | 1 / 1 / 1 |
| 2 | 20128007 | Big washer | 1 / 1 / 1 |
| 3 | 20102006 | Upper looper shaft | 1 / 1 / 1 |
| 4 | 20128005 | Thickness washer | 1 / 1 / 1 |
| 5 | 201S13003 | Screw | 3 / 3 / 3 |
| 6 | 400337 | Upper looper crank bearing | 0 / 1 / 1 |
| 6 | 400457 | Upper looper crank bearing | 1 / 0 / 0 |
| 7 | 400017 | Looper link | 1 / 1 / 1 |
| 8 | 201S20015 | Shaft screw | 4 / 4 / 4 |
| 9 | 20126010 | Looper link holder | 1 / 1 / 1 |
| 10 | 201S11035 | Screw | 1 / 1 / 1 |
| 11 | 20104004 | Upper looper shaft crank | 1 / 1 / 1 |
| 12 | 201S12007 | Screw | 1 / 1 / 1 |
| 13 | 20128021 | Washer | 1 / 1 / 1 |
| 14 | 20126011 | Connecting rod shaft pin | 1 / 1 / 1 |
| 15 | 20123021 | Oil wick | 1 / 1 / 1 |
| 16 | 2010121000 | Upper looper slide crank component | 1 / 1 / 1 |
| 17 | 201S11007 | Screw | 1 / 1 / 1 |
| 18 | 20112023 | Washer | 1 / 1 / 1 |
| 19 | S10005 | Link pin set screw | 1 / 1 / 1 |
| 20 | 20123009 | Oil felt | 1 / 1 / 1 |
| 21 | **** | Looper | 1 / 1 / 1 |
| 21 | **** | Looper | 1 / 1 / 1 |
| 22 | 201S17006 | Screw | 1 / 1 / 1 |
| 23 | 20112026 | Thread holder snap plate | 1 / 1 / 1 |
| 24 | 201S11005 | Screw | 1 / 1 / 1 |
| 25 | 20122026 | Oil wick | 1 / 1 / 1 |
| 26 | 20101206 | Upper looper shaft slide bar bracket | 1 / 1 / 1 |
| 27 | 20109001 | Upper looper slide block | 1 / 1 / 1 |
| 28 | 20104005 | Upper looper shaft bar | 1 / 1 / 1 |
Page 30 — 十二、下弯针部分 Lower Looper Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 201S12005 | Low looper shaft screw | 1 / 1 / 1 |
| 2 | 20128007 | Lower looper shaft washer | 1 / 1 / 1 |
| 3 | 20102007 | Lower looper shaft | 1 / 1 / 0 |
| 3 | 20102008 | Lower looper shaft | 0 / 0 / 1 |
| 4 | 20128009 | Washer | 1 / 1 / 1 |
| 5 | 400223 | Lower looper crank | 1 / 1 / 0 |
| 6 | 201S13003 | Screw | 1 / 1 / 1 |
| 7 | 400017 | Looper link | 1 / 1 / 1 |
| 8 | 201S20015 | Shaft screw | 4 / 4 / 4 |
| 9 | 20126010 | Looper link holder | 1 / 1 / 1 |
| 10 | 201S11035 | Screw | 1 / 1 / 1 |
| 11 | 201S12007 | Screw | 1 / 1 / 1 |
| 12 | 20128021 | Lower looper holder washer | 2 / 2 / 2 |
| 13 | 20104008 | Lower looper holder | 1 / 1 / 0 |
| 13 | 20104025 | Lower looper holder | 0 / 0 / 1 |
| 14 | **** | Lower looper | 1 / 1 / 0 |
| 14 | **** | Lower looper | 0 / 0 / 1 |
| 15 | 20104010 | Lower looper crank | 0 / 0 / 1 |
| 16 | 201S11007 | Screw | 0 / 0 / 2 |
| 17 | 301S20013 | Screw | 2 / 2 / 2 |
Page 32 — 十三、前弯针部分 Front Looper Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 201S12002 | Front looper crank screw | 0/0/4 |
| 2 | 20108001 | Snap ring | 0/0/1 |
| 3 | 20109002 | Front looper slide block | 0/0/1 |
| 4 | 20104013 | Driving crank | 0/0/1 |
| 5 | 20101021 | Driving lever | 0/0/1 |
| 6 | 201S14002 | Driving lever set screw | 0/0/3 |
| 7 | 20129003 | Snap ring | 0/0/1 |
| 8 | 201S30009 | Driving lever set screw | 0/0/1 |
| 9 | 20102010 | Horizontal shaft | 0/0/1 |
| 10 | 201S16002 | Nut | 0/0/1 |
| 11 | 20104014 | Horizontal shaft crank | 0/0/1 |
| 12 | 20126014 | Pin | 0/0/1 |
| 13 | 2010402300 | Shaft link crank | 0/0/1 |
| 14 | 20105003 | Horizontal shaft link | 0/0/1 |
| 15 | 20124002 | Needle bearing | 0/0/1 |
| 16 | 20112028 | Snap ring | 0/0/1 |
| 17 | 201S17001 | Screw | 0/0/2 |
| 18 | 20102009 | Front looper shaft | 0/0/1 |
| 19 | 20609017 | Regulating plate | 0/0/1 |
| 20 | 20126013 | Regulating plate pin | 0/0/2 |
| 21 | **** | Front looper | 0/0/1 |
| 22 | 20128014 | Washer | 0/0/1 |
| 23 | 201S11008 | Screw | 0/0/1 |
| 24 | 201S11003 | Screw | 0/0/1 |
| 25 | 201S12007 | Screw | 0/0/1 |
| 26 | 20128021 | Washer | 0/0/1 |
| 27 | 20104011 | Front looper shaft holder | 0/0/1 |
| 28 | 20126022 | Pin | 0/0/1 |
| 29 | 20123021 | Oil felt | 0/0/1 |
| 30 | 201S12005 | Screw | 0/0/1 |
| 31 | 201S13003 | Screw | 0/0/1 |
| 32 | 20104012 | Front looper crank | 0/0/1 |
Page 34 — 十四、打线凸轮部分 Cam Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20613015 | Thread guide pipe | 0/0/1 |
| 2 | S01010 | Screw | 0/0/1 |
| 3 | 20113026 | Thread pipe | 0/0/1 |
| 4 | 20113025 | Thread pipe cover | 0/0/2 |
| 5 | 20112031 | Bracket | 0/0/2 |
| 6 | 2061205700 | Bracket assemblies | 0/0/1 |
| 7 | S01022 | Screw | 0/0/1 |
| 8 | 20613017 | Thread guide | 0/0/1 |
| 9 | 20612057 | Bracket | 0/0/1 |
| 10 | 206S30015 | Screw | 0/0/1 |
| 11 | 20612055 | Tension disc | 0/0/2 |
| 12 | 30127016 | Spring | 0/0/1 |
| 13 | 206S16004 | Nut | 0/0/1 |
| 14 | S01031 | Screw | 0/0/1 |
| 15 | 20113023 | Thread guide | 0/0/1 |
| 16 | 20612056 | Thread guide | 0/0/1 |
| 17 | 201S11014 | Screw | 0/0/1 |
| 18 | 206S20004 | Screw | 0/0/1 |
| 19 | 20128015 | Flat spring | 0/0/2 |
| 20 | 201S14001 | Cam set Screw | 0/0/2 |
| 21 | 2011301800 | Looper thread take-up cam | 0/0/1 |
| 22 | 20629005 | Flat spring | 0/0/1 |
| 23 | 20629004 | Thread guide | 0/0/1 |
| 24 | S01022 | Screw | 0/0/1 |
| 25 | 20629003 | Bracket | 0/0/1 |
| 26 | 20611010 | Thread guide pipe bushing | 0/0/2 |
Page 36 — 十五、差动送布部件 (1) Different Feed Assemblies (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 2010500900 | Stitch length regulation cam asm | 1/1/1 |
| 2 | 201S14002 | Screw | 4/4/4 |
| 3 | 20109005 | Stitch length regulating block | 1/1/1 |
| 4 | 20105004 | Feed link | 1/1/1 |
| 5 | 20110003 | Feed length cam | 1/1/1 |
| 6 | 20112035 | Feed cam spring | 1/1/1 |
| 7 | B07007 | Feed rod rolling pin bearing | 1/1/1 |
| 8 | 20110002 | Stitch length cam | 1/1/1 |
| 9 | 20127009 | Stitch length regulating block spring | 2/2/2 |
| 10 | 20125002 | Annular gear coil | 1/1/1 |
| 11 | 20101022 | Annular gear coil chassis | 1/1/1 |
| 12 | 400439 | Feed bam pack | 1/1/0 |
| 13 | 20110004 | Feed bam | 1/1/0 |
| 14 | 201S14002 | Screw | 2/2/0 |
| 15 | P01004 | Feed cam pin | 1/1/0 |
| 16 | 201S12005 | Screw | 1/1/1 |
| 17 | 20112034 | Stitch length regulating plate | 1/1/1 |
| 18 | 20127008 | Spring | 1/1/1 |
| 19 | 001016 | O Ring | 1/1/1 |
| 20 | 20102011 | Stitch length regulating shaft | 1/1/1 |
| 21 | 201S20008 | Screw | 1/1/1 |
| 22 | 20105005 | Differential link | 1/1/1 |
| 23 | 20104016 | Differential crank | 1/1/1 |
| 24 | 201S13003 | Screw | 1/1/1 |
| 25 | 20108005 | Snap ring | 1/1/1 |
| 26 | 201S12002 | Screw | 1/1/1 |
| 27 | 20127010 | Spring | 1/1/1 |
| 28 | 20103017 | Differential shaft bearing | 1/1/1 |
| 29 | 20122029 | Oil seal | 1/1/1 |
| 30 | 20102012 | Differential shaft | 1/1/1 |
| 31 | 20122038 | Washer | 1/1/1 |
| 32 | 20112037 | Differential regulating link | 1/1/1 |
| 33 | W01006 | Washer | 2/2/2 |
| 34 | 20128034 | Washer | 1/1/1 |
| 35 | 20127011 | Regulating screw spring | 1/1/1 |
| 36 | 201S11018 | Screw | 1/1/1 |
| 37 | 201S11016 | Screw | 2/2/2 |
| 38 | 20628009 | Washer | 1/1/1 |
| 39 | 201S16008 | Washer | 1/1/1 |
| 40 | 201S30005 | Screw | 1/1/1 |
| 41 | 20128027 | Washer | 1/1/1 |
| 42 | 20109005 | Regulating block | 1/1/1 |
| 43 | 20112036 | Differential regulation holder | 1/1/1 |
| 44 | 201S11005 | Screw | 1/1/1 |
| 45 | 201S30013 | Screw | 1/1/0 |
| 45 | 201S30022 | Screw | 0/0/1 |
| 46 | 20137004 | Mard plate | 1/1/1 |
Page 38 — 十六、差动送布部件（2）Different Feed Assemblies（2）
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S10007 | Screw | 2 / 2 / 2 |
| 2 | 20708004 | Collar | 1 / 1 / 1 |
| 3 | 20102014 | Feed shaft | 1 / 1 / 1 |
| 4 | 20104017 | Feed regulating crank | 1 / 1 / 1 |
| 5 | 20102015 | Feed dog link eccentric shaft | 1 / 1 / 1 |
| 6 | 201S13003 | Screw | 3 / 3 / 3 |
| 7 | 20128021 | Washer | 1 / 1 / 1 |
| 8 | 201S16002 | Nut | 1 / 1 / 1 |
| 9 | 2010402400 | Differential feed regulating crank | 1 / 1 / 1 |
| 10 | 20112039 | Crank slide block cover | 1 / 1 / 1 |
| 11 | 20109010 | Crank slide block | 1 / 1 / 1 |
| 12 | 201S11051 | Screw | 2 / 2 / 2 |
| 13 | 20104018 | Crank slide | 1 / 1 / 1 |
| 14 | 20104015 | Feed crank | 1 / 1 / 1 |
| 15 | 20103018 | Slid block eccentric shaft bushing | 1 / 1 / 1 |
| 16 | 201S12002 | Screw | 1 / 1 / 1 |
| 17 | 20102013 | Slid block eccentric shaft | 1 / 1 / 1 |
| 18 | 2010600300 | Dog spur pack | 1 / 1 / 1 |
| 19 | 20106002 | Differential feed dog holder | 1 / 1 / 1 |
| 20 | 201S12003 | Screw | 1 / 1 / 1 |
| 21 | 20105006 | Feed dog holder link | 1 / 1 / 1 |
| 22 | 20103021 | Feed dog holder link bushing | 1 / 1 / 1 |
| 23 | 20106001 | Feed dog holder | 1 / 1 / 1 |
| 24 | 20109008 | Differential feed slide block | 1 / 1 / 1 |
| 25 | 20628013 | Washer | 1 / 1 / 1 |
| 26 | 201S17003 | Screw | 1 / 1 / 1 |
| 27 | 201S12004 | Screw | 1 / 1 / 1 |
| 28 | 20128030 | Washer | 2 / 2 / 2 |
| 29 | 20105007 | Differentrial feed dog holder link | 1 / 1 / 1 |
| 30 | 20103022 | Differentrial feed dog holder link bushing | 1 / 1 / 1 |
| 31 | 20128029 | Washer | 1 / 1 / 1 |
| 32 | 20109022 | Feed dog lift slide block | 1 / 1 / 1 |
| 33 | 20109006 | Dog link plate | 1 / 1 / 1 |
| 34 | 201S11012 | Screw | 1 / 1 / 1 |
| 35 | **** | Feed form | 1 / 1 / 0 |
| 35 | **** | Feed form | 1 / 0 / 0 |
| 35 | **** | Feed form | 0 / 0 / 1 |
| 35 | **** | Feed form | 0 / 0 / 1 |
| 36 | 201S11038 | Screw | 1 / 1 / 1 |
| 37 | **** | Main feed dog | 1 / 1 / 1 |
| 38 | **** | Main feed dog | 1 / 1 / 1 |
| 39 | 201S11003 | Screw | 1 / 1 / 1 |
| 40 | 201S11038 | Screw | 1 / 1 / 1 |
| 41 | **** | Differential feed dog | 1 / 1 / 1 |
| 42 | 201S11023 | Screw | 1 / 1 / 1 |
| 43 | 201S11018 | Screw | 1 / 1 / 1 |
| 44 | 20109012 | Sealing connecting rod | 1 / 1 / 1 |
| 45 | 201S11005 | Screw | 1 / 1 / 1 |
| 46 | 20122031 | Adjustable oil seal | 2 / 2 / 2 |
| 47 | 20122050 | Adjustable oil seal | 1 / 1 / 1 |
| 48 | 20122030 | Sealing connecting ring | 1 / 1 / 1 |
| 49 | 20101023 | Screw oil plate | 1 / 1 / 1 |
| 50 | 201S11016 | Screw | 2 / 2 / 2 |
| 51 | 20109011 | Feed dog carrier connection rod | 1 / 1 / 1 |
| 52 | 201S11021 | Screw | 1 / 1 / 1 |
| 53 | 20128007 | Washer | 1 / 1 / 1 |
| 54 | 201S11016 | Screw | 1 / 1 / 1 |
Page 40 — 十七、剪切部件 Knife Drive Mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20105202 | Connection | 1/1/1 |
| 2 | 201S20015 | Screw | 2/2/2 |
| 3 | 20122021 | Oil seal | 1/1/1 |
| 4 | 20126026 | Pin | 1/1/1 |
| 5 | 20104202 | Upper knife crank | 1/1/0 |
| 5 | 20104203 | Upper knife crank | 0/0/1 |
| 6 | 201S12006 | Screw | 1/1/1 |
| 7 | S10003 | Screw | 2/2/2 |
| 8 | 20108007 | Collar | 2/2/2 |
| 9 | S05017 | Screw | 1/1/1 |
| 10 | 201S11022 | Screw | 2/2/2 |
| 11 | 20101024 | Upper Knife Clamp | 1/1/0 |
| 11 | 20101025 | Upper Knife Clamp | 0/0/1 |
| 11 | 20101053 | Upper Knife Clamp | 0/0/1 |
| 12 | **** | Upper Knife | 1/1/1 |
| 12 | **** | Upper Knife | 0/0/1 |
| 13 | 201S12001 | Screw | 1/1/1 |
| 14 | 20128020 | Washer | 1/1/1 |
| 15 | 20126016 | Pin | 1/1/1 |
| 16 | 20102017 | Upper knife feame rock shaft | 1/1/1 |
| 17 | 201S12005 | Screw | 1/1/1 |
| 18 | 20101026 | Lower knife holder lock plate | 0/0/1 |
| 19 | **** | Lower knife | 1/1/1 |
| 19 | **** | Lower knife | 0/0/1 |
| 20 | 20102018 | Lower Knife Holder | 1/1/1 |
| 20 | 20102019 | Lower Knife Holder | 0/0/1 |
| 21 | 20127012 | Spring | 1/1/1 |
| 22 | 20112040 | Screw | 1/1/1 |
| 23 | 201S11018 | Screw | 1/1/1 |
| 24 | 201S16001 | Nut | 1/1/1 |
| 25 | W01006 | Washer | 1/1/1 |
| 26 | 20103025 | Bushing | 1/1/1 |
| 27 | 201S11015 | Screw | 1/1/1 |
Page 42 — 十八、抬压脚部件 Presser Foot Mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20126018 | Hook | 1/1/1 |
| 2 | 20112041 | Presser foot lifting lever | 1/1/1 |
| 3 | S01010 | Screw | 2/2/2 |
| 4 | 20112104 | Stopper | 1/1/1 |
| 5 | 201S11016 | Screw | 2/2/2 |
| 6 | N01004 | Nut | 1/1/1 |
| 7 | 20626016 | Pin | 1/1/1 |
| 8 | S10011 | Screw | 1/1/1 |
| 9 | 20102035 | Shaft | 1/1/1 |
| 10 | 20127031 | Spring | 1/1/1 |
| 11 | S10002 | Screw | 1/1/1 |
| 12 | 20103036 | Bushing | 1/1/1 |
| 13 | 20627009 | Spring | 1/1/1 |
| 14 | 201S20004 | Screw | 1/1/1 |
| 15 | 20612030 | Shaft | 1/1/1 |
| 16 | S05017 | Screw | 1/1/1 |
| 17 | 20608004 | Collar | 1/1/1 |
| 18 | 20101202 | Presser arm | 1/1/1 |
| 19 | 20119003 | Chain cutter | 1/1/1 |
| 20 | 207S11020 | Screw | 1/1/1 |
| 21 | **** | Presser foot assy | 1/0/0 |
| 21 | **** | Presser foot assy | 0/1/0 |
| 21 | **** | Presser foot assy | 0/0/1 |
| 21 | **** | Presser foot assy | 0/0/1 |
| 21 | **** | Presser foot assy | 0/0/1 |
| 21 | **** | Presser foot assy | 1/0/0 |
| 22 | 207S11020 | Screw | 1/1/1 |
| 23 | 20612083 | Stopper | 1/1/1 |
| 24 | 207S11009 | Screw | 1/1/1 |
| 25 | 20712026 | Lever | 1/1/1 |
| 26 | 20127032 | Spring | 1/1/1 |
| 27 | 20612034 | Lever | 1/1/1 |
| 28 | 206S30017 | Screw | 1/1/1 |
| 29 | 20627010 | Spring | 1/1/1 |
| 30 | S01002 | Screw | 1/1/1 |
| 31 | 20612090 | Stopper | 1/1/1 |
| 32 | P03006 | Screw | 1/1/1 |
| 33 | 207S11007 | Screw | 1/1/1 |
| 34 | 20103202 | Lever | 1/1/1 |
| 35 | 207S16003 | Nut | 1/1/1 |
| 36 | 20702014 | Screw | 1/1/1 |
Page 44 — 十九、供油部件 (1) Lubrication Assemblies (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20320001 | Oil pump | 1 / 1 / 1 |
| 2 | 203s20002 | Screw SM3/16x32 | 2 / 2 / 2 |
| 3 | 20320011 | Pump turbine | 1 / 1 / 1 |
| 4 | 20320017 | Punp body | 1 / 1 / 1 |
| 5 | 20320012 | Pump spindle | 1 / 1 / 1 |
| 6 | 20320021 | Pump impeller sleeve | 1 / 1 / 1 |
| 7 | 20320014 | Pump plate | 1 / 1 / 1 |
| 8 | 20320018 | Oil strainer | 1 / 1 / 1 |
| 9 | 20320016 | Oil pump cover | 1 / 1 / 1 |
| 10 | 207S11017 | Screw M3x8 | 3 / 3 / 3 |
| 11 | 20121001 | Needle bar return pipe | 1 / 1 / 1 |
| 12 | 20121004 | Upper screem | 1 / 1 / 1 |
| 13 | 20321003 | Lower screem | 1 / 1 / 1 |
| 14 | 203S30004 | Screw SM11/64x40 | 1 / 1 / 1 |
| 15 | 20301006 | Lubrcate bushing | 1 / 1 / 1 |
| 16 | 20101207 | Oil screen cover | 1 / 1 / 1 |
| 17 | 201S11019 | Screw SM11/64x40 | 3 / 3 / 3 |
| 18 | 20322004 | Seal ring | 1 / 1 / 1 |
| 19 | 20136001 | Oil clearer | 1 / 1 / 1 |
| 20 | 201S30030 | Oil cljerner joint | 1 / 1 / 1 |
| 21 | 20122038 | O ring | 1 / 1 / 1 |
| 22 | 20136007 | Oil tube joint | 3 / 3 / 3 |
| 23 | 20122033 | Washer (red) | 6 / 6 / 6 |
| 24 | 203S30003 | Screw SM1/4x40 | 1 / 1 / 1 |
| 25 | 30129003 | Oil tube shape ring | 3 / 3 / 3 |
| 26 | 201S11025 | Screw SM11/64x40 | 1 / 1 / 1 |
| 27 | 30121022 | Tubing | 1 / 1 / 1 |
| 28 | 301S30013 | Screw SM1/4x40 | 2 / 2 / 2 |
Page 46 — 二十、供油部件 (2) Lubrication Assemblies (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S10007 | Screw M4×4 | 1 / 1 / 1 |
| 2 | 20621010 | Through tubing | 1 / 1 / 1 |
| 3 | #### | Pin | 1 / 1 / 1 |
| 4 | 20723011 | Oil Felt | 1 / 1 / 1 |
| 5 | 2071203800 | Joint | 1 / 1 / 1 |
| 6 | 20622010 | O ring | 1 / 1 / 1 |
| 7 | 20112050 | Oil pan magnet cover | 1 / 1 / 1 |
| 8 | 105S11019 | Screw SM11/64×40 | 1 / 1 / 1 |
| 9 | 20131083 | Oil pan magnet | 2 / 2 / 2 |
| 10 | 20122048 | Oil pan washer | 1 / 1 / 1 |
| 11 | 207S11011 | Screw M4×5 | 1 / 1 / 1 |
| 12 | 20123021 | Oil wick | 0.02 / 0.02 / 0.02 |
| 13 | 20626007 | Pin | 1 / 1 / 1 |
| 14 | S10007 | Screw M4×4 | 1 / 1 / 1 |
| 15 | 20128023 | Washer | 4 / 4 / 4 |
| 16 | 201S13002 | Screw SM15/64×28 | 4 / 4 / 4 |
| 17 | 201S11031 | Screw SM3/8×28 | 1 / 1 / 1 |
| 18 | 20122036 | Washer | 1 / 1 / 1 |
| 19 | 20101035 | Oil reservoir | 1 / 1 / 1 |
Page 48 — 二十一、HR部件 H.R.Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S01010 | Screw M4×8 | 1 / 1 / 1 |
| 2 | 20712040 | Thread guide | 1 / 1 / 0 |
| 2 | 20713019 | Thread guide | 0 / 0 / 1 |
| 3 | 20711015 | Cover | 1 / 1 / 1 |
| 4 | 20111205 | Oil reservoir | 1 / 1 / 1 |
| 5 | 20723008 | Felt | 1 / 1 / 1 |
| 6 | 20112105 | Coner | 1 / 1 / 1 |
| 7 | 201S11018 | Screw SM11/64×40 | 2 / 2 / 2 |
| 8 | 20101037 | Needle cooler | 1 / 1 / 0 |
| 9 | 20123014 | Oil felt | 1 / 1 / 0 |
| 10 | #### | Pin | 1 / 1 / 1 |
| 11 | 20129002 | Shape ring | 2 / 2 / 2 |
| 12 | 30121021 | Clamp | 1 / 1 / 1 |
| 13 | 20123017 | Oil felt block | 1 / 1 / 1 |
| 14 | 20111011 | Lower oil box cover | 1 / 1 / 1 |
| 15 | 20111012 | Oil box | 1 / 1 / 1 |
| 16 | 201S11018 | Screw SM11/64×40 | 1 / 1 / 1 |
| 17 | 20123021 | Oil wick | 1 / 1 / 1 |
| 18 | 20123012 | Plug | 1 / 1 / 1 |
| 19 | 20101038 | Needle cooler | 0 / 0 / 1 |
| 20 | 20123015 | Oil felt | 0 / 0 / 1 |
Page 50 — 二十二、直驱部件 Direct Drive Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S01010 | Screw M4×8 | 1 / 1 / 1 |
| 2 | 20612062 | Washer | 1 / 1 / 1 |
| 3 | 2013001000 | LED lamp | 1 / 1 / 1 |
| 4 | 20711210 | Clamp | 3 / 3 / 3 |
| 5 | 20111059 | Cover | 1 / 1 / 1 |
| 5 | 20111060 | Cover | 1 / 1 / 1 |
| 6 | 2033300200 | Direct drive moter | 1 / 1 / 1 |
| 7 | 201S11034 | Screw SM15/64×28 | 1 / 1 / 1 |
| 8 | 20711207 | Tie | 0.85 / 0.85 / 0.85 |
| 9 | S01083 | Screw M4×8 | 3 / 3 / 3 |
| 10 | 301S11009 | Screw | 3 / 3 / 3 |
Page 52 — 二十三、倒回缝部件 Back Latch Components
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 201S14002 | Screw | 1 / 1 / 0 |
| 2 | 20103029 | Collar | 1 / 1 / 0 |
| 3 | 20112058 | Bracket | 1 / 1 / 0 |
| 4 | 201S30018 | Screw | 2 / 2 / 0 |
| 5 | 20112059 | Sleeve | 1 / 1 / 0 |
| 6 | 20112207 | Thread guide plate | 1 / 1 / 0 |
| 7 | 20112208 | Thread tension plate | 1 / 1 / 0 |
| 8 | 201S16003 | Nut | 1 / 1 / 0 |
| 9 | 20112209 | Frong frame | 1 / 1 / 0 |
| 10 | 20112063 | Thread tension releasing lever | 1 / 1 / 0 |
| 11 | 201S20012 | Screw | 1 / 1 / 0 |
| 12 | 20127021 | Spring | 1 / 1 / 0 |
| 13 | 201S20013 | Screw | 1 / 1 / 0 |
| 14 | 201S14003 | Screw | 2 / 2 / 0 |
| 15 | 201S20014 | Screw | 1 / 1 / 0 |
| 16 | 20101039 | Connector | 1 / 1 / 0 |
| 17 | 205S30007 | Pressure line plate screw | 1 / 1 / 0 |
| 18 | 20113209 | Pressure line plate | 1 / 1 / 0 |
| 19 | S02007 | Screw | 4 / 4 / 0 |
| 20 | 20112210 | Cutter location positioning plate | 1 / 1 / 0 |
| 21 | 205S30008 | Pressure plate screw | 1 / 1 / 0 |
| 22 | 20519002 | Knife | 1 / 1 / 0 |
| 23 | 20512003 | Pressure plate | 1 / 1 / 0 |
| 24 | 20109102 | Knife rack | 1 / 1 / 0 |
| 25 | 20527003 | Spring | 1 / 1 / 0 |
| 26 | 301S16007 | Clamp nut | 1 / 1 / 0 |
| 27 | 20116004 | Presser foot form | 1 / 0 / 0 |
| 27 | 20116005 | Presser foot form | 0 / 1 / 0 |
| 28 | **** | Needle plate | 1 / 0 / 0 |
| 28 | **** | Needle plate | 0 / 1 / 0 |
| 29 | 20109025 | Bracket | 1 / 1 / 0 |
| 30 | **** | Feed form | 1 / 1 / 0 |
| 31 | 20102040 | Lower knife holder | 1 / 1 / 0 |
| 32 | 20109103 | Needle guard bracket | 1 / 1 / 0 |
| 33 | 2011209000 | Cloth plate | 1 / 1 / 0 |
Page 53 — 二十四、800E专用部件 800E Specific Parts
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 21 | 219001 | BRACKET | |
| 22 | 219002 | BRACKET | |
| 23 | 219003 | BRACKET | |
| 24 | 219004 | BRACKET | |
| 25 | 219005 | BRACKET | |
| 26 | 219006 | BRACKET | |
| 27 | 219007 | BRACKET | |
| 28 | 219008 | BRACKET | |
| 29 | 219009 | BRACKET | |
| 30 | 219010 | BRACKET | |
| 31 | 219011 | BRACKET | |
| 32 | 219012 | BRACKET | |
| 33 | 219013 | BRACKET | |
| 34 | 219014 | BRACKET | |
| 35 | 219015 | BRACKET | |
| 36 | 219016 | BRACKET | |
| 37 | 219017 | BRACKET | |
| 38 | 219018 | BRACKET | |
| 39 | 219019 | BRACKET | |
| 40 | 219020 | BRACKET | |
| 41 | 219021 | BRACKET | |
| 42 | 219022 | BRACKET | |
| 43 | 219023 | BRACKET | |
| 44 | 219024 | BRACKET | |
| 45 | 219025 | BRACKET | |
| 1 | 219026 | BRACKET | |
| 2 | 219027 | BRACKET | |
| 3 | 219028 | BRACKET | |
| 4 | 219029 | BRACKET | |
| 5 | 219030 | BRACKET | |
| 6 | 219031 | BRACKET | |
| 7 | 219032 | BRACKET | |
| 8 | 219033 | BRACKET | |
| 9 | 219034 | BRACKET | |
| 10 | 219035 | BRACKET | |
| 11 | 219036 | BRACKET | |
| 12 | 219037 | BRACKET | |
| 13 | 219038 | BRACKET | |
| 14 | 219039 | BRACKET | |
| 15 | 219040 | BRACKET | |
| 16 | 219041 | BRACKET | |
| 17 | 219042 | BRACKET | |
| 18 | 219043 | BRACKET | |
| 19 | 219044 | BRACKET | |
| 20 | 219045 | BRACKET |
Page 54 — 二十四、800E专用部件 800E Specific Parts
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20130020 | Panel assembly | 1 / 1 / 1 |
| 2 | 20112099 | Panel holder | 1 / 1 / 1 |
| 3 | 206S11021 | Screw M4×10 | 4 / 4 / 4 |
| 4 | S05232 | Screw M6×12 | 2 / 2 / 2 |
| 5 | 20630027 | Interconnecting device | 1 / 1 / 1 |
| 6 | 206S11022 | Screw M3×8 | 4 / 4 / 4 |
| 7 | S01031 | Screw M4×4.7 | 4 / 4 / 4 |
| 8 | 2063002000 | Solenoid | 1 / 1 / 1 |
| 9 | S05010 | Screw M4×9 | 1 / 1 / 1 |
| 10 | S05019 | Screw M6×16.3 | 1 / 1 / 1 |
| 11 | 20726001 | Pin | 1 / 1 / 1 |
| 12 | 2011900800 | Cutter assembly | 1 / 1 / 1 |
| 13 | 201S11019 | Screw M4 | 2 / 2 / 2 |
| 14 | 20104100 | Crank | 1 / 1 / 1 |
| 15 | 20101302 | Bracket | 1 / 1 / 1 |
| 16 | S05232 | Screw M6×12 | 2 / 2 / 2 |
| 17 | 20630023 | Back emission | 1 / 1 / 1 |
| 18 | S01027 | Screw M3 | 2 / 2 / 2 |
| 19 | 20630024 | Back sensor | 1 / 1 / 1 |
| 20 | S02007 | Screw M3×5 | 2 / 2 / 2 |
| 21 | S01003 | Screw M4×12 | 2 / 2 / 2 |
| 22 | 2011106600 | Trimmer switch sensor | 1 / 1 / 1 |
| 23 | 20711202 | Eye guide | 1 / 1 / 1 |
| 24 | W01011 | Washer | 2 / 2 / 2 |
| 25 | S01034 | Screw M3×5.7 | 2 / 2 / 2 |
| 26 | 20612107 | Bracket | 1 / 1 / 1 |
| 27 | S01031 | Screw M4×4.7 | 1 / 1 / 1 |
| 28 | S01002 | Screw M4×6.5 | 4 / 4 / 4 |
| 29 | 20630025 | Presser foot safety switch | 1 / 1 / 1 |
| 30 | 30130017 | Magnetic iron | 2 / 2 / 2 |
| 31 | 20701203 | Bracket | 1 / 1 / 1 |
| 32 | 30228009 | Washer | 1 / 1 / 1 |
| 33 | 207S11007 | Screw M4×7.5 | 1 / 1 / 1 |
| 34 | S01006 | Screw M3×4.5 | 1 / 1 / 1 |
| 35 | 20612108 | Bracket | 1 / 1 / 1 |
| 36 | 20101055 | Cover plate | 1 / 1 / 1 |
| 37 | 20130026 | Cloth plate safety switch | 1 / 1 / 1 |
| 38 | 20130021 | Front sensor | 1 / 1 / 1 |
| 39 | 20130022 | Middle sensor | 1 / 1 / 1 |
| 40 | 2011208700 | Cloth plate assembly | 1 / 1 / 1 |
| 41 | 201S11043 | Screw M4×4.5 | 1 / 1 / 1 |
| 42 | S02007 | Screw M3×5 | 2 / 2 / 2 |
| 43 | 20109024 | Bracket | 1 / 1 / 1 |
| 44 | 20109023 | Bracket | 1 / 1 / 1 |
| 45 | 20112204 | Cloth Plate slider cover | 1 / 1 / 1 |
Page 56 — 二十五、托盘、排料部件 Plate Row Material Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20131025 | Machine head plate | 1 / 1 / 1 |
| 2 | 20131026 | Head shockproof cushion | 3 / 3 / 3 |
| 3 | 20131028 | Screw | 4 / 4 / 4 |
| 4 | 20131057 | Washer | 1 / 1 / 1 |
| 5 | 20131030 | Plate dog link bushing | 4 / 4 / 4 |
| 6 | 20131029 | Big washer | 12 / 12 / 12 |
| 7 | 20131027 | Screw | 4 / 4 / 4 |
| 8 | 20131034 | Screw | 7 / 7 / 7 |
| 9 | 20131031 | Row material trollgh bracket | 1 / 1 / 1 |
| 10 | 20128022 | Washer | 7 / 7 / 7 |
| 11 | 20131032 | Row material trough I | 1 / 1 / 1 |
| 12 | 20131033 | Row material trough II | 1 / 1 / 1 |
| 13 | 20131094 | Row material component | 1 / 1 / 1 |
Page 58 — Thread Spool Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 20631018 | Thread guide | 1 / 0 / 0 |
| 2 | 30113019 | Thread guide | 0 / 0 / 1 |
| 3 | 20131019 | Rod Cap | 1 / 1 / 1 |
| 4 | 20131001 | Upper thread column | 1 / 1 / 1 |
| 5 | 201S16006 | Thread guide hook nut | 4 / 4 / 4 |
| 6 | 20131016 | Thread spool tray bracket | 1 / 1 / 1 |
| 7 | 20131018 | Thread guide hook | 3 / 4 / 5 |
| 8 | 20131021 | Screw | 2 / 2 / 2 |
| 9 | 20131009 | Clamp plate | 1 / 1 / 1 |
| 10 | 201S16004 | Nut | 4 / 4 / 4 |
| 11 | 20131022 | Screw | 2 / 2 / 2 |
| 12 | 201S16004 | Nut | 4 / 4 / 4 |
| 13 | 20131005 | Thread guide hook | 4 / 4 / 4 |
| 14 | 20131020 | Screw | 4 / 4 / 4 |
| 15 | 20131015 | Thread spool tray bracket | 1 / 1 / 1 |
| 16 | 20131011 | Thread guide bar | 1 / 1 / 1 |
| 17 | 20631019 | Thread guide | 0 / 1 / 0 |
| 18 | 20131012 | Thread guide joint | 1 / 1 / 1 |
| 19 | S04050 | Screw M5×15 | 2 / 2 / 2 |
| 20 | 20131003 | Bushing | 1 / 1 / 1 |
| 21 | N01030 | Nut | 2 / 2 / 2 |
| 22 | 20131008 | Spool Cushion | 3 / 4 / 5 |
| 23 | 20131006 | Spool pin | 3 / 4 / 5 |
| 24 | 20131010 | Spool tray cushing | 3 / 4 / 5 |
| 25 | 20131007 | Spool tray | 3 / 4 / 5 |
| 26 | 20131004 | Thread spool tray bracket | 1 / 1 / 1 |
| 27 | 201S16004 | Nut | 3 / 4 / 5 |
| 28 | 20128018 | Washer | 3 / 4 / 5 |
| 29 | 20131002 | Lower thread cloumn | 1 / 1 / 1 |
| 30 | 201S16005 | Nut | 1 / 1 / 1 |
| 31 | 20128025 | Lower washer | 2 / 2 / 2 |
| 32 | 20131017 | Thread spool tray bracket | 1 / 1 / 1 |
| 33 | 20122049 | Plate dog link washer | 2 / 2 / 2 |
| 34 | 20131090 | Thread stand component | 1 / 0 / 0 |
| 34 | 20131091 | Thread stand component | 0 / 1 / 0 |
| 34 | 20131074 | Thread stand component | 0 / 0 / 1 |
Page 60 — 二十七、随机附件 Accessories Assemblies
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 10131002 | screw driver（L） | 1/1/1 |
| 10131003 | |||
| 10131004 | |||
| 20131044 | 直柄内六角螺丝刀(1.5mm) | ||
| 20131045 | 直柄内六角螺丝刀(1.6mm) | ||
| 20131037 | |||
| 20131038 | |||
| 20131039 | |||
| 20131051 | |||
| 20131043 | 扳手(8mm) | ||
| 20131042 | 扳手(7mm) | ||
| 20131041 | 扳手(6mm) | ||
| 20131046 | 内六角扳手(2mm) | ||
| 20131056 | 内六角扳手(6mm) | ||
| 30131026 | 内六角扳手(8mm) | ||
| 20131054 | |||
| S10005 | |||
| 20136001 | |||
| 2033000200 | |||
| 20130033 | |||
| 20130039 | 直驱专用部件(E) | ||
| 20131052 | |||
| 10131005 | |||
| 20131055 | |||
| 20131062 | |||
| 20131040 | 油壶/50cc |
Page 61 — 800 SERIES GAUGE PARTS LIST
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 20115006 | NEEDLE PLATE | ||
| 20115001 | NEEDLE PLATE | ||
| 20115004 | NEEDLE PLATE | ||
| 20115005 | NEEDLE PLATE | ||
| 20115002 | NEEDLE PLATE | ||
| 20115003 | NEEDLE PLATE | ||
| 20115008 | NEEDLE PLATE | ||
| 20115007 | NEEDLE PLATE | ||
| 20115026 | NEEDLE PLATE | ||
| 20115025 | NEEDLE PLATE | ||
| 20115027 | NEEDLE PLATE | ||
| 20115028 | NEEDLE PLATE | ||
| 20115029 | NEEDLE PLATE | ||
| 2011401800 | MAIN FEED DOG ASS | ||
| 2071601000 | PRESSER FOOT ASS | ||
| 20117025 | UPPER LOOPER | ||
| 20117008 | LOWER LOOPER | ||
| 2011401700 | MAIN FEED DOG ASS | ||
| 2071600500 | PRESSER FOOT ASS | ||
| 2011402100 | MAIN FEED DOG ASS | ||
| 20116004 | PRESSER FOOT ASS | ||
| 20116005 | PRESSER FOOT ASS | 2 | |
| 20117007 | UPPER LOOPER | 2 | |
| 2101600300 | PRESSER FOOT ASS | 2 | |
| 2011401900 | MAIN FEED DOG ASS | 3 | |
| 2071600600 | PRESSER FOOT ASS | 3 | |
| 20117009 | LOWER LOOPER | 3 | |
| 20117010 | CHAINSTITCH LOOPER | 3 | |
| 2071601500 | PRESSER FOOT ASS | 5 | |
| 2011402000 | MAIN FEED DOG ASS | 5 | |
| 2061604000 | PRESSER FOOT ASS | 5 | |
| 2011402300 | MAIN FEED DOG ASS | ||
| 2071608600 | PRESSER FOOT ASS | ||
| 2071609400 | PRESSER FOOT ASS | 2 | |
| 2011403600 | MAIN FEED DOG ASS | 3 | |
| 2011403900 | MAIN FEED DOG ASS | 5 |
Page 62
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 20634022 | NEEDLE HOLDER | ||
| 20634022 | NEEDLE HOLDER | ||
| 20634022 | NEEDLE HOLDER | ||
| 20734002 | NEEDLE HOLDER | ||
| 20734002 | NEEDLE HOLDER | ||
| 20734003 | NEEDLE HOLDER | ||
| 20734004 | NEEDLE HOLDER | ||
| 20719056 | NEEDLE HOLDER | ||
| 20634022 | NEEDLE HOLDER | ||
| 20734002 | NEEDLE HOLDER | ||
| 20734003 | NEEDLE HOLDER | ||
| 20734004 | NEEDLE HOLDER | ||
| 20719056 | NEEDLE HOLDER | ||
| 20119001 | UPPER KINIFE | ||
| 20119002 | LOWER KINIFE | ||
| 20117003 | OVERLOCK NEEDLE GUARO FRONT | ||
| 20117002 | OVERLOCK NEEDLE GUARO REAR | ||
| 20117005 | OVERLOCK NEEDLE GUARO FRONT | ||
| 20117006 | OVERLOCK NEEDLE GUARO REAR | ||
| 20117004 | CHAINSTITCH NEEDLE FRONT | ||
| 20119005 | UPPER KINIFE | ||
| 20119006 | LOWER KINIFE | ||
| 20117022 | OVERLOCK NEEDLE GUARO FRONT | ||
| 20117023 | CHAINSTITCH NEEDLE FRONT |
Jack JK-804 / JK-805 — parts catalog
- Page 1 (cover): This is the cover page for the JACK JK-800 Series Parts Manual, featuring an image of the sewing machine and the JACK logo.
- Page 2 (toc): This page is a table of contents for a parts manual, listing 27 sections with their corresponding page numbers, covering various machine components and accessories.
- Page 3 (unknown): This page contains a watermark with the text "jintex.in" and a black bar at the bottom with the same text. There is no other discernible content on the page.
- Page 4 (text): This page contains safety precautions for operating and maintaining the sewing machine, including instructions for turning off the power, removing the foot presser, and checking the ground connection. It also includes diagrams and text related to the machine's lubrication system.
- Page 5 (text): This page contains instructions and diagrams for filling the HR device with silicon oil, adjusting the differential feed ratio, adjusting the presser foot pressure, and adjusting the stitch length.
- Page 6 (text): This page provides instructions for adjusting thread tension, cleaning the machine, checking and replacing the oil filter, replacing the lower knife, replacing the needle, and replacing the oil, along with a diagram of the E Series electrical wiring.
- Page 7 (diagram): This page displays a diagram of various components of an industrial sewing machine, with numbered parts indicated for reference.
- Page 8 (parts_list): This page lists machine bed frame parts, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 9 (diagram): This page displays a diagram of various components of an industrial sewing machine, including screws, a fuel tank assembly, a cover, and other mechanical parts, each identified by a reference number.
- Page 10 (parts_list): This page lists parts for Cover Assemblies (1), including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 11 (diagram): This page displays a diagram of various machine components, including brackets, plates, screws, and other hardware, with reference numbers indicating their positions.
- Page 12 (parts_list): This page lists cover assemblies (2) with part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 13 (diagram): This page displays a diagram of various components of an industrial sewing machine, including shafts, bearings, gears, and fasteners, with reference numbers for each part.
- Page 14 (parts_list): This page lists parts for the Main Shaft Assemblies, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 15 (diagram): This page contains diagrams of various sewing machine components, including assemblies with parts numbered 1 through 14, and another assembly with parts numbered 15 through 27. The diagrams illustrate mechanical parts and their arrangement.
- Page 16 (parts_list): This page lists parts for thread guide and thread takeup components, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 17 (diagram): This page displays diagrams of parts for the Three-thread/Four-thread Series sewing machines, with numbered parts and their corresponding labels.
- Page 18 (parts_list): This page lists thread guide and thread takeup components for industrial sewing machines, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 19 (diagram): This page displays a diagram of components for the Five-thread Series of industrial sewing machines, with specific illustrations for the Five-thread (35/55) Series and Five-thread (56) Series.
- Page 20 (parts_list): This page lists parts for Thread Guide and Thread Takeup (3), including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 21 (diagram): This page displays a diagram of various machine components, including a connecting rod assembly, a shaft, and several smaller parts like bolts, pins, and rings, each labeled with a reference number.
- Page 22 (parts_list): This page lists parts for Needle Drive Mechanism (1), including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 23 (diagram): This page displays diagrams of needle and thread components for three-thread/four-thread series and five-thread series sewing machines.
- Page 24 (parts_list): This page lists parts for the Needle Drive Mechanism (2), including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 25 (diagram): This page displays a diagram of various machine components, including levers, brackets, and fasteners, with reference numbers for each part.
- Page 26 (parts_list): This page lists parts for the Needle Drive Mechanism (3) of an industrial sewing machine, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 27 (diagram): This page displays a diagram of various machine parts, including screws, washers, rods, and linkages, with reference numbers for each component.
- Page 28 (parts_list): This page lists parts for Upper Looper Assemblies, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 29 (diagram): This page displays a diagram of various sewing machine components, including screws, bearings, shafts, and levers, with reference numbers for identification.
- Page 30 (parts_list): This page lists lower looper assemblies with part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 31 (diagram): This page displays a diagram of various machine components, including screws, linkages, shafts, and bearings, with reference numbers for each part.
- Page 32 (parts_list): This page lists parts for Front Looper Assemblies, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 33 (diagram): This page displays a diagram of various sewing machine parts, with reference numbers indicating their positions. It includes components like a cylinder, bracket, springs, gears, and a brake assembly, numbered from 1 to 26.
- Page 34 (parts_list): This page lists parts for Cam Assemblies, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 35 (diagram): This page displays a diagram of various sewing machine components, including a crankshaft assembly, needle bar linkage, and presser foot assembly, with numbered references for each part.
- Page 36 (parts_list): This page lists parts for different feed assemblies, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 37 (diagram): This page displays a diagram of various machine parts, including components like screws, brackets, shafts, and linkages, with reference numbers for identification.
- Page 38 (parts_list): Parts list for Different Feed Assemblies (2), giving reference numbers, part numbers, English and Chinese names, and quantities for three-, four-, and five-thread models.
- Page 39 (diagram): This page displays a diagram of various machine parts, including screws, shafts, and brackets, with reference numbers and some descriptive text like "three/four-thread" and "five-thread".
- Page 40 (parts_list): This page lists parts for the Knife Drive Mechanism, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 41 (diagram): This page displays a diagram of various sewing machine components, including levers, springs, screws, and other hardware, with reference numbers for each part.
- Page 42 (parts_list): This page lists parts for the Presser Foot Mechanism, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 44 (parts_list): This page lists lubrication assemblies for industrial sewing machines, including part numbers, descriptions, and quantities for different thread types.
- Page 45 (diagram): This page displays a diagram of various components of an industrial sewing machine, including levers, switches, a gasket, and fasteners, with reference numbers for each part.
- Page 46 (parts_list): This page lists lubrication assemblies for industrial sewing machines, including part numbers, descriptions, and quantities for different thread types.
- Page 47 (diagram): This page displays a diagram of various sewing machine components, with numbered references for each part.
- Page 48 (parts_list): This page lists HR. Assemblies parts with their part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 49 (diagram): This page displays a diagram of various components, including a main machine housing, a bearing assembly, and smaller parts like screws and clips, labeled with reference numbers from 1 to 10.
- Page 50 (parts_list): This page lists parts for Direct Drive Assemblies, including screws, washers, LED lamps, clamps, covers, motors, and ties, with quantities specified for three-thread, four-thread, and five-thread configurations.
- Page 51 (diagram): This page displays a diagram of various machine parts, including levers, plates, screws, and other components, with reference numbers from 1 to 33.
- Page 52 (parts_list): This page lists back latch components for industrial sewing machines, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 53 (diagram): This page displays a diagram of various machine components, including covers, brackets, and fasteners, with reference numbers for each part.
- Page 54 (parts_list): This page lists parts for the 800E Specific Parts, including part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 55 (diagram): This page displays a diagram of various components, including screws, brackets, and other hardware, with reference numbers from 1 to 13.
- Page 56 (parts_list): This page lists plate row material assemblies with part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 57 (diagram): This page displays a diagram of various components of an industrial sewing machine, including frame parts, spools, and mounting hardware, with reference numbers for each part.
- Page 58 (parts_list): This page lists thread spool assemblies with part numbers, descriptions, and quantities for three-thread, four-thread, and five-thread configurations.
- Page 59 (diagram): This page displays a diagram of various parts and accessories for a machine, including a fuel can, funnels, screwdrivers, wrenches, a chain, a filter, and other components, each identified by a reference number.
- Page 60 (parts_list): This page lists accessories and parts for industrial sewing machines, including various wrenches, screwdrivers, oil containers, needles, and other components with their part numbers and descriptions.
- Page 61 (parts_list): This page lists parts for the 800 Series Gauge Parts, including machine types, gauge specifications, and various part numbers for needle plates, feed dog assemblies, upper loopers, lower loopers, and chainstitch loopers.
- Page 62 (parts_list): This page lists parts for various machine types including Upper Knife, Lower Knife, Overlock Needle Guard (Front and Rear), Chainstitch Needle (Front and Rear), Needle Holder, and Needle. It provides part numbers for each component across different machine specifications.
- Page 63 (cover): This is the cover page for JACK SEWING MACHINE CO., LTD. It includes the company's standard product code, website, address, and contact information.
