Jack JK-8569 Parts Book (PDF)

Coverstitch · also listed as JK8569, 8569Download PDF

Text index — Jack JK-8569

Page 5 — 套筒部件 (Bushing assemblies)

Jack JK-8569 parts on page 5
Ref	Part number	Part name	Qty
1	250215-2	machine frame	1
2	30103036	bushing	1
3	30103037	bushing	2
4	210297	bushing	3
5	30103062	bushing	1
6	250141	bushing	2
7	30103017	bushing	1
8	001039	O ring	1
9	30103038	bushing	1
10	30103035	bushing	1
11	30122039	plug	1
12	250135	bushing	1
13	30103010	bushing	1
14	30103019	bushing	1
15	20103014	bushing	3
16	255020	pipe	1
17	P03005	pin	1
18	210586	plug	1
19	301780	machine frame	1

Page 7 — 一、车壳部件(Frame assemblies)

Jack JK-8569 parts on page 7
Ref	Part number	Part name	Qty
1	301S30001	shoulder pin	4
2	30111001	oil level gauge	1
3	30122004	plug	1
4	30122006	plug	4
5	30122008	plug	3
6	30122005	plug	1
7	H01001	ring	3
8	30112001	filter	3
9	30112002	cover	1
10	S01002	screw	2
11	30122010	mark	1
12	R03001	pin	2
13	30137001	sticker	1
14	30122007	plug	1
15	S01004	screw	1
16	W01001	washer	1
17	S12004	screw	2
18	20131063	sticker	1
19	30137003	sticker	1
20	30122036	sticker	1
21	30137004	sticker	1
22	30101005	top cover (right)	1
23	L02001	screw	8
24	30122003	gasket	1
25	30101004	top cover plate (left)	1
26	30122002	gasket	1
27	30131003	name plate	1
28	001001	o ring	1
29	S05001	screw	4
30	W02003	washer	4
31	P01001	pin	2
32	P02001	pin	1

Page 9 — 罩壳部件(Cover assemblies)

Jack JK-8569 parts on page 9
Ref	Part number	Part name	Qty
1	250016-AUD	arm cover (left)	1
2	5242	screw	1
3	250017	o ring	1
4	7021	screw	11
5	240263	washer	1
6	250149	arm cover (top)	1
7	240226	plug	1
8	179107-05	oil sight window	1
9	250019	o ring	1
10	250021-UD	needle bar cover	1
12	7019	screw	3
14	30112083	thread takeup guard	1
15	30112084	finger guard	1
16	S01001	screw	3
17	W01001	washer	3
18	30112085	bracket	1
19	301S11002	screw	1
20	250023	threan takeup cover	1
21	7052	screw	2
22	250005	looper thread guide cover	1
23	207924	washer	1
24	250022	puller cover	1
25	7075	screw	2
26	7089	screw	1
27	250051	flat spring	1
28	7017	screw	2
29	7023	screw	2
30	210025	cushon	2
31	204585	washer	2
32	7024	screw	2
33	250257	eye guard	1
34	S01006	screw	2
35	202875	washer	2
36	250256	bracket	1
37	W03001	washer	2
38	7066	screw	1
39	250255	bracket	1
40	7020	screw	2
41	303448	washer	2
42	30137005	sticker	1
43	30337001	sticker	1
44	250011	arm cover (top)	1
45	300657	bracket	1
46	7021	screw	4

Page 11 — 三、缝台部件(Cloth plate assemblies)

Jack JK-8569 parts on page 11
Ref	Part number	Part name	Qty
1	7020	screw	3
2	7043	screw	1
3	250052-BSD	bed cover(left)	1
4	250074-ASD	bed cover(right)	1
5	7021	screw	9
6	250071-91	cover	1
7	250039-SD	side coverassy	1
8	250037	screw	1
9	201191	spring	2
10	250038	pin	1
11	4535	screw	2
12	7017	screw	2
13	210025	cushon	2
14	7089	screw	1
15	4821	nut	1
16	250047	bracket	1
17	7019	screw	2
18	206023	flat spring	1
19	30112079	bed cover	1
20	20528017	washer	3
21	300793	cover	1
22	3011101900	bed cover	1
23	3011101900	bed cover	1
24	300654	bed cover	1

Page 13 — 四、下轴部件(Hook shaft assemblies)

Jack JK-8569 parts on page 13
Ref	Part number	Part name	Qty
1	400068	crankshaft assy	1
2	400060	connection assy	1
3	201S20015	screw	4
4	30104002	crank	1
5	S05002	screw	1
6	S12002	screw	1
7	30103004	joint	1
8	S12003	screw	2
9	S10029	screw	12
10	3012400300	bearing	1
11	30103006	bushing	1
12	30103008	bushing	1
13	3012400400	bearing	1
14	30125001	gear(lower)	1
15	30103009	bushing	1
16	B01003	bearing	1
17	301S11004	screw	1
18	W02001	washer	1
19	30108001	cover	1
20	S01004	screw	2
21	30101015	machine puller	1
22	S10009	screw	1
23	S12001	screw	1
24	30128005	washer	1
25	S05003	screw	1
26	30102003	shaft	1
27	001001	o ring	1
28	30135002	timing belt	1
29	30126001	adjusting bar	1
30	30109001	guide	1

Page 15 — 五、上轴部件(Main shaft assemblies)

Jack JK-8569 parts on page 15
Ref	Part number	Part name	Qty
1	400307	motion assy	1
2	S10004	screw	2
3	S01011	screw	2
4	S08001	screw	1
5	S11001	screw	1
6	30103015	bushing	1
7	400065	crankshaft	1
8	400061	connection assy	1
9	S01003	screw	2
10	S01008	screw	2
11	30104006	crank assy	1
12	S05002	screw	1
13	30103004	joint	1
14	S12003	screw	3
15	S10029	screw	11
16	30109003	balance weight	1
17	S10002	screw	2
18	30102006	shaft	1
19	3012400400	bushing	1
20	30103012	bushing	1
21	30125002	gear(upper)	1
22	3012400400	bearing	1
23	30103014	bushing	1
24	B01005	bearing	2
25	30102007	shaft	1
26	301434	handwheel	1
27	S12001	screw	1
28	S10009	screw	1
29	W01004	washer	1
30	S05004	screw	1

Page 17 — 六、针杆部件(Needle bar assemblies)

Jack JK-8569 parts on page 17
Ref	Part number	Part name	Qty
1	30102008	needle bar	1
2	30102009		1
3	301S11005	screw	1
4	30105005	link/needle bar drive	1
5	30102010	pin	1
6	B07001	needle bearing	1
7	30128006	washer	1
8	30109004	block	1
9	30109005	guide bloce/needle bar	1
10	301S11024	screw	2
11	S01003	screw	2
12	30127003	latch	1
13	30123002	psponge	1
14	30134001	needle holder	1
15	S10026	screw	2
16	S10026	screw	3
17	30115002	needle plate	1
18	301S17001	screw	2
19	30109006	bracket	1
20	S01004	screw	2
21	30134006	needle holder	1
	30134004	needle holder	1
22	30122018	cushon rubber	1
23	20523005	oil wick	1
24	30112009	oil wick retainer	1

Page 19 — 七、护针部件(Needle guard assemblies)

Jack JK-8569 parts on page 19
Ref	Part number	Part name	Qty
1	B01001	eccentric assy	1
2	4539	screw	2
3	255501-92	connection assy	1
4	7015	screw	2
5	7082	screw	1
6	306093	crank	1
7	5084	screw	2
8	205495	pin	1
9	251518	shaft	1
10	206748	felt	3
11	202176	oil wick	1
12	240102	washer	1
13	205061	ring	1
14	204052A	oil seal	1
15	251519	lever assy	1
16	4500	screw	1
17	303067	washer	1
18	7017	screw	1
19	257551B	needle guard (rear)	1
20	257553	needle guard (front)	1
21	7031	screw	1
22	001001	o ring	1
23	251517	eccentric	1
24	30122017	oil seal	2

Page 21 — 八、弯针部件(Looper assemblies)

Jack JK-8569 parts on page 21
Ref	Part number	Part name	Qty
1	257550-91	looper	1
2	252007	looper holder assy	1
3	7019	screw	1
4	4501	screw	1
5	303067	sring washer	1
6	7085	screw	1
7	20622019	oil seal	1
8	252006	shaft	1
9	252000	eccentric assy	1
10	4539	screw	3
11	252001-92	connection assy	1
12	7015	screw	2
13	252010	balance weight	1
14	7011	screw	2
15	252002	crank	1
16	240102	washer	1
17	179399-05	pin	1
18	240062	washer	1
19	4805	nut	1
20	252003	block pin	1
21	208028	washer	1
22	208029	collar	1
23	5084	screw	1
24	4802	nut	2
25	252004	shaft	1
26	205061	ring	1

Page 23 — 九、牙架部件(Feed dog holder assemblies)

Jack JK-8569 parts on page 23
Ref	Part number	Part name	Qty
1	3011400700	main feed dog assembly	1
2	30114001	main feed dog	1
3	301S30003	screw	2
4	400066	main feed bar assembly	1
5	30114002	differntial feed dog	1
6	20123021	oil wick	1
7	30103022	bushing	1
8	S10006	screw	4
9	30102016	eccentric pin	1
10	301S12001	screw	1
11	30109008	block/feed bar guide	1
12	30128011	washer	1
13	301S17002	screw	1
14	30109009	guide(right)	1
15	30103031	bushing	1
16	30109010	guide(left)	1
17	L02003	screw	2
18	30122020	oilshield	2
19	30109011	cover	1
20	30109012	guide(lower)	1
21	S01005	screw	2
22	B07002	needle bearing	1
23	30109013	block	1
24	30108003	washer	1
25	30104013	link/main feed	1
26	B07003	needle bearing	1
27	30103023	eccentric	1
28	30103024	regulator	1
29	3010306500	eccentric retainer	1
30	301S30004	screw	1
31	30128012	spring	5
32	30103026	spacer	1
33	301S16001	nut	1
34	S10002	screw	1
35	301S30005	screw	1
36	30103027	bushing	1
37	30109014	guide block	1
38	30128013	washer	2
39	301S16002	nut	2
40	301S30006	screw	1
41	30103028	bushing	1
42	30129001	ring	1
43	30105010	link/differental feed	1
44	30109015	bracket	1
45	S01004	screw	3
46	30102017	pin	1
47	30127004	spring	1
48	001004	o ring	1
49	30128032	washer	1
50	H05002	ring	1
51	30103029	pin	1
52	S12005	screw	1
53	3010401500	crank	1
54	S01012	screw	1
55	30102018	shaft	1
56	S10002	screw	1
57	30123002	felt	2
58	30103030	spacer	1
59	30126016	pin	1
60	30127026	spring	1

Page 25 — 十、差动部件(Differential assemblies)

Jack JK-8569 parts on page 25
Ref	Part number	Part name	Qty
1	252531	block	1
2	252532	guide/block	1
3	252533	lever	1
4	4531	screw	1
5	5316	screw	1
6	240271	ring	1
7	35827	screw	1
8	7066	screw	1
9	252536	spring	1
10	240129	o ring	1
11	252539A91	bracket	1
12	7019	screw	5
13	240162	plug	1
14	252664-91	lever assy	1
15	252538	scale plate	1
16	7021	screw	2
17	240124	spacer	2
18	210171	stopper	2
19	2905	screw	2
20	201185	washer	2
21	210167	nut	1
22	5486	screw	1
23	211301	washer	1
24	301S11023	screw	1

Page 27 — 十一、压脚部件(Presser form assemblies)

Jack JK-8569 parts on page 27
Ref	Part number	Part name	Qty
1	253000-91	adjusting bar	1
2	253003	nut	1
3	240112	spring	1
4	206139	presser bar clamp	1
5	S01003	screw	1
6	206157	link	1
7	5386	screw	2
8	30722004	adjusting bar assy	1
9	253005-91	guide assy	1
10	7025	screw	2
11	240113	spring	1
12	253018	oil guard	2
13	240095	o ring	1
14	253004	presser shaft	1
15	253028	finger guard	1
16	7010	screw	1
17	202875	washer	1
18	257460-40	presser foot assy	1
	3011601300	presser foot assy	1
	3011601400	presser foot assy
	30116005	presser foot assy	1
	30116006	presser foot assy	1
	30116003	presser foot assy	1
	30116004	presser foot assy	1
19	1170-3	screw	1
20	253008-1	shaft	1
21	253010	spring	1
22	206156	ring	1
23	5084	screw	3
24	192024	ring	1
25	253008-4	oil seal	3
26	206149	bell crank(upper)	1
27	5187	screw	1
28	253011	link	1
29	5184	screw	2
30	206148	bell crank(lower)	1
31	41386	screw	1
32	253013	shaft	1
33	253014	lever	1
34	7028	screw	1
35	253015	bracket	1
36	7019	screw	2
37	4549	screw	1
38	4805	nut	1

Page 29 — 十二、喂针部件(Needle feeding assemblies)

Jack JK-8569 parts on page 29
Ref	Part number	Part name	Qty
1	257565	spreader	1
2	254516	lever/assy	1
3	7020	screw	1
4	7022	screw	1
5	254508	crankshaft	1
6	212039	collar	1
7	S071	screw	2
8	202176	oil wick	1
9	207925	felt	2
10	233020	o ring	1
11	254506	crank	1
12	4547	screw	2
13	254507	block	1
14	254519	shaft	1
15	206180	washer	1
16	306671	ring	1
17	254501A	eccentric assy	1
18	4514	screw	2
19	254511	connection	1
20	254503	crank	1
21	4534	screw	1
22	254504	screw	1
23	240062	washer	1
24	4805	nut	1
25	30128018	washer	1

Page 31 — 十三、松线部件 (Thread loosing assemblies)

Jack JK-8569 parts on page 31
Ref	Part number	Part name	Qty
1	254000-91	lever	1
2	254022	spacer	1
3	12055	screw	1
4	254003B91	crank	1
5	4531	screw	1
6	202868	washer	1
7	254008	thread guide	1
8	7019	screw	4
9	192120	pipe	2
10	254009	bracket	1
11	7017	screw	1
12	W01001	washer	1
13	254023C9U	tension conrol mechanism	1
14	254023E9U	tension conrol mechanism	1
15	254019	bracket	1
16	244021	thread releaser	1
17	254010C9U	tension spring assy	2
18	254010B9U	tension spring assy	1
19	254212A9U	tension spring assy	1
20	254020	thread guide	4
21	206203	thread guide	4
22	206202	spacer	4
23	306301	spring	1
24	5447	screw	1
25	3011300400	tension spring assy	3
26	254020	thread guide	5
27	206203	thread guide	5
28	206202	spacer	5
29	208447-UA	knob	1
30	1817-2A	screw stud	1
31	210319	tension disc	2
32	208450-UA	spring shield	1
33	201037	spring (heavy)	3
34	201086	spring (medium)	1
35	201068	spring (lifht)	1
36	208448	ratchet	1

Page 33 — 十四、过线部件(Thread loosing assemblies)

Jack JK-8569 parts on page 33
Ref	Part number	Part name	Qty
1	20608003	ring	1
2	301512001	screw	2
3	30102028	shaft	1
4	30128019	washer	1
5	W02002	washer	1
6	S05048	screw
7	20622019	plug	1
8	H05001	ring	1
9	30101018	lever	1
10	S05004	screw	1
11	W02001	washer	1
12	30113009	thread take-up	1
13	S01004	screw	5
14	W01001		2
15	30113010	thread guide	1
16	S01006	screw	1
17	30113011	thread guide	1
18	206S30016	screw	1
19	30112023	thread support	1
20	30128034	washer	1
21	S01006	screw	1
22	30112027	thread guide	1
23	30112104	guard(thread take-up lever)	1
24	W01001	washer	1
25	30113012	holder	1
26	30113013	thread guide	3
27	S10001	screw	3
28	S01006	screw	2
29	30112024	thread tension bracket	1
30	S01001	screw	4
31	30112025	thread guide	1
32	30112026	thread retainer	1
33	30127014	spring	1
34	301S20009	screw	1
35	30112028	thread take-up	1
36	30112030	thread guide	1
37	30112033	thread guide	1
38	30112029	thread guide	1
39	S10005	screw	1
40	30112031	thread guide	1
41	301S16007	knob	1
42	30127016	spring	1
43	30112032	thread guide	1
44	301S30011	screw	1
45	20112033	thread retainer	2
46	3011203200	thread guide	1

Page 35 — 十五、打线凸轮部件(Cam assemblies assemblies)

Jack JK-8569 parts on page 35
Ref	Part number	Part name	Qty
1	253608-91	thread take-up	1
2	4514	screw	2
3	210353	bracket	1
4	253525	shaft	1
5	240115	spring	1
6	303865	o ring	2
7	200555	collar	2
8	4554	screw	3
9	253526	shaft	1
10	253615	thread guide	1
11	7018	screw	1
12	253527	stopper	1
13	253528	spring	1
14	7087	screw	1
15	7023	screw	2
16	210955A	washer	1
17	253612	bracket	1
18	253614	thread guide	1
19	201252	washer	1
20	4325	screw	1
21	253613	thread support	1
22	204107	washer	1
23	253611	bracket	1
24	210353	thread guide	1
25	2921	screw	1
26	253533A	thread guide	2
27	210585	washer	2
28	7031	screw	2
29	5387	screw	1
30	137108	thread retainer	2
31	211388	spring	1
32	5526	knob	1
33	7043	screw	2
34	253536	thread guide	1

Page 37 — 十六、润滑部件(Lubrication assemblies)

Jack JK-8569 parts on page 37
Ref	Part number	Part name	Qty
1	30121012	oil pipe	1
2	30123010	felt	1
3	30126008	pin	1
4	S10002	screw	1
5	30123009	felt	1
6	3012101400	pipe	1
7	30127019	latch	1
8	S01004	screw	1
9	30121007	tube	1
10	30121005	tube	1
11	30121022	tube	1
12	30136002	joint	1
13	20129002	clamp	6
14	30112039	oil guard	1
15	S01002	screw	3
16	3012101500	oil distributor	1
17	N01001	nut	1
18	30121022	tube	1
19	W01001	ring	1
20	30121009	oil distributor	1
21	20122033	washer	6
22	30121021	tube	1
23	30136004	joint	1
24	30129006	clamp	2
25	301S30013	joint screw	2
26	30136003	pipe	1
27	301S30012	screw	1
28	30121021	tube	1
29	30136001	joint	2
30	201S30004	joint screw	1

Page 39 — 十七、油泵部件(Oil pump assemblies)

Jack JK-8569 parts on page 39
Ref	Part number	Part name	Qty
1	3012000100	oil pump assy	1
2	30102031	shaft	1
3	30120004	rotor	1
4	30120007	rotor	1
5	30120005	rotor	2
6	30120008	cover	1
7	301S20011	screw	2
8	S05006	screw	2
9	30125003	worm wheel	1
10	S10002	screw	2
11	S05004	screw	2
12	301S30014	joint screw	1
13	30101023	oil reservoir	1
14	301S11015	screw	1
15	20528014	washer	1
16	S05007	screw	5
17	30122025	o ring	1
18	20136001	filter element	1
19	301S30016	bracket/filter element	1
20	001010	o ring	1
21	300140	cover	1
22	S01003	screw	3
23	30131004	filter seal	1

Page 41 — 十八、硅油盒装置部件(Silicon oil delice assemblies)

Jack JK-8569 parts on page 41
Ref	Part number	Part name	Qty
1	30101027	needle cooler (lower)	1
2	S01015	screw	2
3	30123012	felt	1
4	30126009	pin	1
5	30121021	tube	1
6	30127020	bracket	1
7	S01004	screw	1
8	20123021	oil wick	1
9	30129006	clamp	2
10	30101026	silicone oil reservoir(lower)	1
11	30122026	cap	1
12	S01005	screw	1
13	300141	silicone oil reservoir(upper)	1
14	30112040	cap	1
15	P03008	pin	2
16	30123011	felt	1
17	S01006	screw	2
18	W01001	washer	1

Page 43 — 十九、线架部件(Thread apool assemblies)

Jack JK-8569 parts on page 43
Ref	Part number	Part name	Qty
1	3013102700	thread assy	1
2	30102032	thread bar(loer)	1
3	30128024	washer	2
4	30101028	bracket(3-spool)	1
5	30101029	bracket(3-spool)	1
6	20131006	spool pin	5
7	W02002	washer	5
8	30101030	bracket(3-spool)	1
9	20631025	spool tray	5
10	20631024	cushon	5
11	20131008	spool retaining fin	5
12	L02004	screw	2
13	W01003	washer	2
14	S04001	screw	2
15	30102034	thread bar(upper)	1
16	30129005	joint	1
17	S04002	screw	4
18	N01004	nut	4
19	30111008	bracket	1
20	30113018	thread guide bar	1
21	S04003	screw	1
22	30101031	bracket	1
23	20631017	holder	1
24	S04004	screw	3
25	N01005	nut	9
26	20131036	thread guide bar(5-spool)	1
27	20631019	thread guide bar(6-spool)	1
28	30103045	thread guide	5
29	30122027	rid cap	1
30	N01026	screw	1

Page 45 — 二十、油盘托板部件(Oil plate assemblies)

Jack JK-8569 parts on page 45
Ref	Part number	Part name	Qty
1	3010103200	screw(set)	1
2	20131027	nut	4
3	20131028	bolt	4
4	20131029	washer	8
5	20131030	rubber cushion	4
6	30122031	spacer	4
7	20131056	allen key driver/6mm	1
8	400247	rest board	2
9	301S30018	screw	4
10	30122029	rubber cushion	4
11	30112041	treadle chain guide	2
12	S01011	screw	4
13	20131029	washer	8

Page 47 — 二十一、打线凸轮外移部件Parts

Jack JK-8569 parts on page 47
Ref	Part number	Part name	Qty
1	30102065	shaft	1
2	H03004	ring	1
3	B04017	bracket	2
4	H01011	ring	2
5	30125004	small gear1	1
6	30125005	small gear2	1
7	S10003	screw	4
8	30135005	small timing belt	1
9	30125006	lower gear	1
10	S12005	screw	2
11	30102066	crankshaft	1
12	30103075	recycle sleeve (right)	1
13	30103076	recycle sleeve (left)	1
14	S10014	screw	4
15	B06004	bracket	1
16	20108002	washer	1
17	201S15003	screw	2
18	30103071	thread takeup	1
19	S10002	screw	2
20	30122100	plug	1
21	30112070	bracket	1
22	L02001	screw	1
23	S01004	screw	1
24	301S20020	screw	1
25	W03007	washer	1
26	W01002	washer	1
27	207S11020	screw	4
28	30727006	flat spring	1
29	30112087	bracket	1
30	30112069	bracket	1
31	30112085	thread guide	1
32	30313019	thread guide (left)	1
33	30313020	thread guide (right)	1
34	001026	o ring	2

Page 49 — 二十二、03、08专用部件(03、08 specific parts)

Jack JK-8569 parts on page 49
Ref	Part number	Part name	Qty
1	301S11024	screw	2
2	W01001	washer	2
3	30112065	fabric guide	1
4	30112066	fabric guide	1
5	30109020	fabric guide	1
6	S01036	screw	2
7	30109021	fabric guide	1
8	W01009	washer	2
9	30112064	bracket	1
10	S01011	screw	2

Page 51 — 二十三、01D专用部件(01D specific parts)

Jack JK-8569 parts on page 51
Ref	Part number	Part name	Qty
1	30112151	thread guide	1
2	30113052	holder	1
3	30113056	thread guide	4
4	S10001	screw	4
5	30113053	thread take-up	1
6	30113054	thread guide	1
7	30113057	thread guide	1
8	30134020	needle holder	1
9	301S17050	screw	4
10	3011304200	tension control mechanism	1
11	30113051	bracket	1
12	30112150	thread releaser	1
13	3011300600	tension spring assy	3
14	3011300500	tension spring assy	1
15	3011300400	tension spring assy	1
16	30113007	thread guide	6
17	30113008	thread guide	6
18	30113041	spacer	6
19	30127010	spring	1
20	301S30009	screw	1

Page 53 — 二十四、02专用部件(02 specific parts)

Jack JK-8569 parts on page 53
Ref	Part number	Part name	Qty
1	250033-SD	front cover	1
2	250013	screw	1
3	250014	screw	1
4	201191	spring	2
5	S10002	screw	2
6	250050-SD	front cover(small)	1
7	7028	screw	2
8	206601A	fabric guard	1
9	30112088	fabric guard	1
10	7079	screw	4
11	206439	auxiliary plate/front cover	1
12	204585	washer	1
13	3011206800	bracket assy	1
14	201913	bracket	1
15	5113	screw	2
16	L02009	bolt	1
17	201914	bracket	1
18	206460	washer	1
19	7028	screw	2
20	252007-92	looper holder assy	1
21	S01002	screw	1
22	S05004	screw	1
23	303067	washer	1
24	247-SA	tape disc	1
25	270	washer	1
26	253	tape disc bar	1
27	250	tape disc bar	1
28	1448	bolt	1
29	251-SA	bracket	1
30	4913	screw	3
31	N01001	nut	4
32	253	tape disc bar	4
33	254	holder	2
34	S04004	nut	4
35	255	guider post bar	1
36	256-SA	bracket	1
37	250012	bracket	1
38	3011101800	tape assy	1

Page 55 — 二十五、05 专用部件 (05 specific parts)

Jack JK-8569 parts on page 55
Ref	Part number	Part name	Qty
1	250052	bed cover	1
2	250035A	side cover assy	1
3	301S20004	screw	1
4	301S20005	pin	1
5	201191	spring	2
6	S10001	screw	2
7	250024	front cover assy	1
8	250013	screw	1
9	250014	pin	1
10	201191	spring	2
11	4539	screw	2
12	30122015	cushon	1
13	250025-ME	font cover(small)	1
14	7018	screw	4
15	250026	bracket	1
16	7028	screw	1
17	250027	shaft	1
18	306920	pin	1
19	4514	screw	1
20	250028	stopper	1
21	3012400300	bushing	1
22	202304	spring	1
23	250066	plug	1
24	255517	fabric guide	1
25	7074	screw	2
26	204585	washer	2
27	250501-91	crankshaft assy	1
28	250504	bushing	1
29	4539	screw	2
30	250534	balance weight	1
31	S01009	screw	2
32	001001	O ring	1

Page 57 — 二十六、02D、05专用部件(02D、05 specific parts)

Jack JK-8569 parts on page 57
Ref	Part number	Part name	Qty
1	30117002	needle guard(rear)	1
2	30104709	lever assy	1
3	S05003	bolt	1
4	W02001	washer	1
5	S01002	screw	1
6	30102037	shaft	1
7	W01021	washer	1
8	H05013	ring	1
9	30106003	lever	1
10	S10002	screw	1
11	30101036	bracket	1
12	301S11016	screw	1
13	S01004	screw	3
14	30117003	needle guard(front)	1
15	S01012	screw	1
16	30111013	waste chute top(C)	1
17	301S30020	screw	7
18	30112048	bracket	1
19	30103046	bushing	1
20	3011101400	waste chute assy	1
21	30111014	waste chute top(A)	1
22	30111015	waste chute top(B)	1
23	30128036	washer	1
24	S01005	screw	4

Page 59 — 二十七、02D、05专用部件(02D、05 specific parts)

Jack JK-8569 parts on page 59
Ref	Part number	Part name	Qty
1	255500	eccentric assy	1
2	4539	screw	2
3	400062	eccentric assy	1
4	S01008	screw	4
5	S01010	screw	1
6	30104007	crank	1
7	301S12001	screw	2
8	30126003	pin	1
9	400063	connection assy	1
10	S01008	screw	2
11	255502	shaft	1
12	240102	washer	1
13	H05001	ring	1
14	30209009	ball	1
15	20523005	oil wick	1
16	30123001	felt	3
17	30122019	oil seal	1
18	255503	lever assy	1
19	S05004	screw	1
20	255504	latch	1
21	7009	screw	4
22	30123015	oil wick	2
23	255505	shaft	1
24	30123008	felt	3
25	30101040	bracket assy	1
26	S12002	screw	1
27	3010104000	bracket assy	1
28	30103085	needle bearing	2
29	255508-2	shaft	1
30	S05019	screw	2
31	306105	spring	1
32	192024	ring	1
33	W00024-1	screw	1
34	202522	ring	1
35	207045	washer	1
36	255507-91	upper knife holder	1
37	4547	screw	1
38	306394	upper knife	1
39	5109	screw	1
40	255509	lower knife holder	1
41	7036	screw	1
42	204161	lower knife	1
43	255510	lower knife clamp	1
44	7028	screw	1
45	255513	screw	1
46	255511	guide	1
47	255506	bracket assy	1
48	255515	chip guard	1
49	30101037	upper knife holder	1
50	3010105700	bracket assy	1

Page 61 — 二十八、05、07专用部件(05、07 specific parts)

Jack JK-8569 parts on page 61
Ref	Part number	Part name	Qty
1	3010204100	reel stand assy	1
2	30103047	bracket	1
3	30102042	rod	1
4	N01026	nut	1
5	30111008	bracket	1
6	S04003	screw	1
7	N01005	nut	4
8	S04004	screw	3
9	30122027	rod cap	1
10	30102043	shaft	1
11	30103048	collar	2
12	S01068	screw	2
13	30103064	reel guide	2
14	30111009	bracket	1
15	30113020	rod	1
16	301S30022	screw	3

Page 63 — 二十九、05、07专用部件(05、07 specific parts)

Jack JK-8569 parts on page 63
Ref	Part number	Part name	Qty
1	P03008	pin	2
3	30103049	shaft	1
4	30103050	eccentric assy	1
5	3010501900	connection assy	1
6	S04005	screw	2
7	S10002	screw	3
8	30103051	ball stud	1
9	30103052	bushing	1
10	B07014	needle bearing	1
12	30112052	indicator	1
13	30128027	washer	1
14	301S20012	pin	1
15	301S16009	nut	1
16	30101041	crank	1
17	301S30023	screw	1
18	30112053	set plate	1
19	S01006	screw	2
20	301S11019	screw	6
21	3010305300	clutch assy	1
22	3010104200	clutch	2
23	30126011	pin	6
24	30112054	guide assy	6
25	30127023	spring	12
26	30103053	sleeve	1
27	S10029	screw	3
28	30103054	bushing	1
29	30101043	stopper plate	1
30	B04006	bearing	1
31	30126012	pin	1
32	W01001	washer	2
33	W01001	washer	1
34	201S11016	screw	1
35	3011101600	md cover assy	1
36	30111016	md cover	1
37	30111017	cover	1
38	S01005	screw	2
39	30137006	sticker	1

Page 65 — 三十、05、07专用部件(05、07 specific parts)

Jack JK-8569 parts on page 65
Ref	Part number	Part name	Qty
1	300144	bracket assy	1
2	30103055	bushing	2
5	300143	bracket	1
6	S05019	screw	4
7	3010305700	roller assy	1
8	S10005	screw	6
9	30103059	rooler	1
10	30102045	shaft	1
11	30109018	bracket	2
12	S10002	screw	4
13	30102046	shaft	1
14	W01003	washer	2
15	30112059	lever	1
16	S01015	screw	2
17	301S30027	screw	1
18	301S16011	nut	1
19	30127024	spring	1
20	30126013	shaft	1
21	H05002	ring	1
22	30112055	guide	1
23	30113022	lace guide	1
24	S01002	screw	2
25	301S16010	guide	2
26	301S11018	screw	2
27	S01004	screw	2
28	30128028	stopper	1
29	S01004	screw	2
30	3011205600	bracket assy	1
31	30128020	spring	1
32	S05048	screw	1
33	N01001	nut	1
34	30105017	lace guide	1
35	W01004	washer	2
36	30105018	lace guide	1
37	301S30025	screw	2
39	30112083	thread take-up guard	1
40	30112084	finger guard	1
41	S01001	screw	3
42	W01001	washer	3
43	30112058	bracket	1
45	30103044	shaft	1
46	30128008	washer	1
47	H05001	ring	1
48	301S11020	screw	2
49	30113021	lace guide	1
50	30112058	bracket	1

Page 67 — 三十一、21、22专用部件(21、22 specific parts)

Jack JK-8569 parts on page 67
Ref	Part number	Part name	Qty
1	30102051	shaft	1
2	30122008	oil seal	1
3	30104012	looper holder assy	1
4	S01004	screw	1
5	S05004	screw	1
6	W02001	washer	1
7	3010401500	crank	1
8	S01012	screw	1
9	301S30004	screw	1
10	30121012	oil pipe	1

Page 69 — 三十二、斜饰专用部件(specific parts)

Jack JK-8569 parts on page 69
Ref	Part number	Part name	Qty
1	30112068	thread guide	1
2	3011203200	thread guide	1
3	20112033	tension dist	2
4	30127015	spring	1
5	301S30011	screw	1
6	XXXXXX	spreader	1
7	30104022	lever assy	1
8	30112033	thread takeup	1
9	30109023	thread guide	1
10	30116023	presser foot assy	1
11	30134011	needle holder	1
12	30128035	thread guide	1
13	30115026	thread plate	1
14	30114016	main feed dog	1
15	30114017	differential feed dog	1
16	30104041	looper holder	1
17	30117017	lower looper(front)	1
18	30117018	lower looper(back)	1
19	30117007	lever assy	1
20	30109024	needle guard	1
21	30113034	thread guide	1
22	30113035	thread guide	1
23	30113014	thread guide	1
24	30113014	thread guide	1
25	30104048	thread guide	1

Page 71 — 三十三、附件部件(Accessories assemblies)

Jack JK-8569 parts on page 71
Ref	Part number	Part name	Qty
1	20131037	oil container	1
2	20131038	oiler	1
3	20131039	oil funnel	1
4	20131038	container silicone	1
5	20131051	tweezers	1
6	30131007	allen key driver/1.5mm	1
7	20131046	allen key driver/2mm	1
8	30131010	allen key driver/3mm	1
9	30131012	allen key driver/4mm	1
10	20131047	allen key driver/5mm	1
11	20131056	allen key driver/6mm	1
12	30131009	allen key driver/8mm	1
14	10131003	screwdriver(medium)	1
15	10131004	screwdriver(small)	1
16	20131044	allen key driver driver/1.5mm	1
17	30131018	chain	1
18	10131005	dust cover	1
19	30117001	needle	4
20	20136001	filter element	1
21	30131005	wrench/(6mm-7mm)	1
22	30131006	wrench/(8mm-10mm)	1
24	30135004	leather belt	1
25	S10005	screw	3

Page 72 — GAUGE PARTS LIST (1) / 缝纫组合件表(1)

Jack JK-8569 parts on page 72
Ref	Part number	Part name	Qty
	30134006	NEEDLE HOLDER (gauge 240, 8568-01CB)
	30115016	NEEDLE PLATE (gauge 240, 8568-01CB)
	30114012	MAIN FEED DOG (gauge 240, 8568-01CB)
	30116020	PRESSER FOOT (gauge 240, 8568-01CB)
	30117009 00	LOOPER (gauge 240, 8568-01CB)
	30117002	NEEDLE GUARD REAR
	30117005	SPREADER
	30117001(11#)	NEEDLE

Page 73 — GAUGE PARTS LIST (2)

Jack JK-8569 parts on page 73
Part number	Part name	Qty
30134006	NEEDLE HOLDER	240
30115016	NEEDLE PLATE	240
30114012	MAIN FEED DOG	240
30116020	DIFF. FEED DOG	240
3011700900	PRESSER FOOT	240
30117001	LOOPER	240
30134008	NEEDLE HOLDER	248
30115009	NEEDLE PLATE	248
30114011	MAIN FEED DOG	248
30116026	DIFF. FEED DOG	248
30117002	PRESSER FOOT	248
30117005	LOOPER	248
30117011	NEEDLE	248
30134001	NEEDLE HOLDER	256
30115002	NEEDLE PLATE	256
30114004	MAIN FEED DOG	256
30116009	DIFF. FEED DOG	256
3011700900	PRESSER FOOT	256
30117005	LOOPER	256
30117001	NEEDLE	256
30134002	NEEDLE HOLDER	264
30115003	NEEDLE PLATE	264
30114003	MAIN FEED DOG	264
30116004	DIFF. FEED DOG	264
30117002	PRESSER FOOT	264
30117005	LOOPER	264
30117011	NEEDLE	264
30134001	NEEDLE HOLDER	30134001
30115005	NEEDLE PLATE	30134001
30114005	MAIN FEED DOG	30134001
30116003	DIFF. FEED DOG	30134001
3011700900	PRESSER FOOT	30134001
30117005	LOOPER	30134001
30117001	NEEDLE	30134001
30134002	NEEDLE HOLDER	30134002
30115008	NEEDLE PLATE	30134002
30114012	MAIN FEED DOG	30134002
30116004	DIFF. FEED DOG	30134002
30117002	PRESSER FOOT	30134002
30117005	LOOPER	30134002
30117011	NEEDLE	30134002
30134001	NEEDLE HOLDER	30134001
30115002	NEEDLE PLATE	30134001
3011400700	MAIN FEED DOG	30134001
30116019	DIFF. FEED DOG	30134001
3011700900	PRESSER FOOT	30134001
30117005	LOOPER	30134001
30117001	NEEDLE	30134001
30134007	NEEDLE HOLDER	30134007
30115015	NEEDLE PLATE	30134007
30114012	MAIN FEED DOG	30134007
3011601300	DIFF. FEED DOG	30134007
30117002	PRESSER FOOT	30134007
30117005	LOOPER	30134007
30117011	NEEDLE	30134007
30134001	NEEDLE HOLDER	8568-03DB
30115002	NEEDLE PLATE	8568-03DB
30114008	MAIN FEED DOG	8568-03DB
3011601400	DIFF. FEED DOG	8568-03DB
3011700900	PRESSER FOOT	8568-03DB
30117005	LOOPER	8568-03DB
30117001	NEEDLE	8568-03DB
30134007	NEEDLE HOLDER	8568W-03DB
30115015	NEEDLE PLATE	8568W-03DB
30114012	MAIN FEED DOG	8568W-03DB
3011601400	DIFF. FEED DOG	8568W-03DB
30117002	PRESSER FOOT	8568W-03DB
30117005	LOOPER	8568W-03DB
30117011	NEEDLE	8568W-03DB
30134002	NEEDLE HOLDER	8568-05CB
30115002	NEEDLE PLATE	8568-05CB
30114003	MAIN FEED DOG	8568-05CB
30116007	DIFF. FEED DOG	8568-05CB
3011700900	PRESSER FOOT	8568-05CB
30117005	LOOPER	8568-05CB
30117001	NEEDLE	8568-05CB
30134003	NEEDLE HOLDER	8568W-05CB
30115003	NEEDLE PLATE	8568W-05CB
30114004	MAIN FEED DOG	8568W-05CB
30116017	DIFF. FEED DOG	8568W-05CB
30117002	PRESSER FOOT	8568W-05CB
30117005	LOOPER	8568W-05CB
30117011	NEEDLE	8568W-05CB
30134004	NEEDLE HOLDER	8568-07CB
30115004	NEEDLE PLATE	8568-07CB
30114005	MAIN FEED DOG	8568-07CB
30116019	DIFF. FEED DOG	8568-07CB
3011700900	PRESSER FOOT	8568-07CB
30117005	LOOPER	8568-07CB
30117001	NEEDLE	8568-07CB
30134005	NEEDLE HOLDER	8568W-07CB
30115005	NEEDLE PLATE	8568W-07CB
30114005	MAIN FEED DOG	8568W-07CB
30116017	DIFF. FEED DOG	8568W-07CB
30117002	PRESSER FOOT	8568W-07CB
30117005	LOOPER	8568W-07CB
30117011	NEEDLE	8568W-07CB
30134001	NEEDLE HOLDER	8568-08AC
30115002	NEEDLE PLATE	8568-08AC
3011400700	MAIN FEED DOG	8568-08AC
3011601300	DIFF. FEED DOG	8568-08AC
3011700900	PRESSER FOOT	8568-08AC
30117005	LOOPER	8568-08AC
30117001	NEEDLE	8568-08AC
30134007	NEEDLE HOLDER	8568W-08AC
30115015	NEEDLE PLATE	8568W-08AC
30114012	MAIN FEED DOG	8568W-08AC
3011601400	DIFF. FEED DOG	8568W-08AC
30117002	PRESSER FOOT	8568W-08AC
30117005	LOOPER	8568W-08AC
30117011	NEEDLE	8568W-08AC
30134002	NEEDLE HOLDER	8568-21BB
30115003	NEEDLE PLATE	8568-21BB
30114008	MAIN FEED DOG	8568-21BB
30116007	DIFF. FEED DOG	8568-21BB
3011700900	PRESSER FOOT	8568-21BB
30117005	LOOPER	8568-21BB
30117001	NEEDLE	8568-21BB
30134003	NEEDLE HOLDER	8568W-21BB
30115004	NEEDLE PLATE	8568W-21BB
30114009	MAIN FEED DOG	8568W-21BB
30116017	DIFF. FEED DOG	8568W-21BB
30117002	PRESSER FOOT	8568W-21BB
30117005	LOOPER	8568W-21BB
30117011	NEEDLE	8568W-21BB
30134011	NEEDLE HOLDER	348
30115026	NEEDLE PLATE	348
30114016	MAIN FEED DOG	348
30116023	DIFF. FEED DOG	348
30117014	PRESSER FOOT	348
30117015	LOOPER	348

Page 5 — 套筒部件 (Bushing assemblies)

Page 7 — 一 、车壳部件(Frame assemblies)

Page 9 — 罩壳部件(Cover assemblies)

Page 11 — 三、缝台部件(Cloth plate assemblies)

Page 13 — 四、下轴部件(Hook shaft assemblies)

Page 15 — 五、上轴部件(Main shaft assemblies)

Page 17 — 六 、针杆部件(Needle bar assemblies)

Page 19 — 七、护针部件(Needle guard assemblies)

Page 21 — 八、弯针部件(Looper assemblies)

Page 23 — 九、 牙架部件(Feed dog holder assemblies)

Page 25 — 十、 差动部件(Differential assemblies)

Page 27 — 十一、压脚部件(Presser form assemblies)

Page 29 — 十二、 喂针部件(Needle feeding assemblies)

Page 31 — 十三、松线部件 (Thread loosing assemblies)

Page 33 — 十四、过线部件(Thread loosing assemblies)

Page 35 — 十五、打线凸轮部件(Cam assemblies assemblies)

Page 37 — 十六、润滑部件(Lubrication assemblies)

Page 39 — 十七、油泵部件(Oil pump assemblies)

Page 41 — 十八、硅油盒装置部件(Silicon oil delice assemblies)

Page 43 — 十九、线架部件(Thread apool assemblies)

Page 45 — 二十、油盘托板部件(Oil plate assemblies)

Page 47 — 二十一、打线凸轮外移部件Parts

Page 49 — 二十二、03、08专用部件(03、08 specific parts)

Page 51 — 二十三、01D专用部件(01D specific parts)

Page 53 — 二十四、02专用部件(02 specific parts)

Page 55 — 二十五、05 专用部件 (05 specific parts)

Page 57 — 二十六、02D、05专用部件(02D、05 specific parts)

Page 59 — 二十七、02D、05专用部件(02D、05 specific parts)

Page 61 — 二十八、05、07专用部件(05、07 specific parts)

Page 63 — 二十九、05、07专用部件(05、07 specific parts)

Page 65 — 三十、05、07专用部件(05、07 specific parts)

Page 67 — 三十一、21、22专用部件(21、22 specific parts)

Page 69 — 三十二、 斜饰专用部件(specific parts)

Page 71 — 三十三、 附件部件(Accessories assemblies)

Page 72 — GAUGE PARTS LIST (1) / 缝纫组合件 表(1)

Page 73 — GAUGE PARTS LIST (2)

Jack JK-8569 — parts catalog

Page 7 — 一、车壳部件(Frame assemblies)

Page 17 — 六、针杆部件(Needle bar assemblies)

Page 23 — 九、牙架部件(Feed dog holder assemblies)

Page 25 — 十、差动部件(Differential assemblies)

Page 29 — 十二、喂针部件(Needle feeding assemblies)

Page 69 — 三十二、斜饰专用部件(specific parts)

Page 71 — 三十三、附件部件(Accessories assemblies)

Page 72 — GAUGE PARTS LIST (1) / 缝纫组合件表(1)
