Ref	Part number	Part name	Qty
	LH-3168-7	FRAME & MISCELLANEOUS COVER COMPONENTS
	LH-3168-7	MAIN SHAFT & THREAD TAKE-UP COMPONENTS
	LH-3168-7	NEEDLE BAR COMPONENTS
	LH-3168-7	TENSION POST COMPONENTS
	LH-3168-7	HOOK & HOOK DRIVING SHAFT COMPONENTS
	LH-3168-7	FEED MECHANISM COMPONENTS
	LH-3168-7	PRESSER BAR & TENSION RELEASE COMPONENTS
	LH-3168-7	THREAD TRIMMER MECHANISM COMPONENTS (FOR LH-3168-7)
	LH-3168-7	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	LH-3168-7	WIPER MECHANISM COMPONENTS (FOR LH-3168-7)
	LH-3168-7	LUBRICATION COMPONENTS
	LH-3168-7	OIL RESERVOIR & KNEE LIFTER COMPONENTS
	LH-3168-7	BELT COVER & BOBBIN WINDER COMPONENTS
	LH-3168-7	THREAD STAND COMPONENTS
	LH-3168-7	MOTOR PULLEY COMPONENTS
	LH-3168-7	TABLE OF EXCHANGING GAUGE PARTS
	LH-3168-7	NUMERICAL INDEX OF PARTS

Page 4 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS

Juki LH-3168 (36 pages) parts on page 4
Ref	Part number	Part name	Qty
	1	FRAME & MISCELLANEOUS COVER COMPONENTS
	2	頭部・外装関係
	3
	4
	5
	6
	7
	8
	9
	10
	11
	12
	13
	14
	15
	16
	17
	18
	19
	20
	21
	22
	23
	24
	25
	26
	27
	28
	29
	30
	31
	32
	33
	34
	35
	36
	37
	38
	39
	40
	41
	42
	43
	44
	45
	46
	47
	48
	49
	50

Page 5

Juki LH-3168 (36 pages) parts on page 5
Ref	Part number	Part name	Qty
1	SS-4110815-SP	SCREW 11/64-40 L=8	7
2	106-02902	SLIDE PLATE	1
3	101-01004	GASKET	1
4	SS-4110815-SP	SCREW 11/64-40 L=8	1
5	SS-6111140-SP	SCREW 11/64-40 L=11	1
6	D2112-555-B00	CORD HOLDER, LARGE	2
7	SS-4120615-SP	SCREW 3/16-28 L=6	1
8	110-44054	GROUND WIRE ASM.	1
9	SS-4120615-SP	SCREW 3/16-28 L=6	1
10	WT-0530002-KS	TOOTHED WASHER	1
11	102-01200	RUBBER PLUG	1
12	TA-0490601-RO	PLUG D=4.9X5.5 L=6	2
13	TA-1250504-RO	RUBBER PLUG	1
14	TA-1270502-RO	RUBBER PLUG	1
15	TA-0750704-RO	RUBBER PLUG	1
16	SS-6151780-SP	SCREW 15/64-28 L=17.0	2
17	226-02007	THREAD TAKE-UP LEVER OIL GUARD	1
18	TA-1250504-RO	RUBBER PLUG	1
19	B3523-280-000	OIL TUBE HOLDER	1
20	226-80250	FACE PLATE ASM.	1
21	SS-4121015-SP	SCREW 3/16-28 L=10	4
22	TA-1250406-RO	RUBBER PLUG	2
23	110-18702	THREE-HOLE THREAD EYELET	2
24	SS-8120740-SP	SCREW 3/16-28 L=7	2
25	226-03005	THREAD GUIDE	1
26	SS-2090710-SP	SCREW 9/64-40 L=7	1
27	226-03104	THREAD GUIDE	1
28	SS-2090810-SP	SCREW 9/64-40 L=7.5	1
29	B1131-057-000	FRAME THREAD GUIDE, LOWER	1
30	SS-5090610-SP	SCREW 9/64-40 L=6	1
31	B1104-051-000	THROAT PLATE PIN	1
32	226-80003	PLATE	2
33	SS-9110460-CP	SCREW 11/64-40 L=4	2
34	226-02106	AUXILIARY COVER	1
35	SS-2090710-SP	SCREW 9/64-40 L=7	2
36	SS-6090630-SP	SCREW 9/64-40 L=6	1
37	SS-2110920-TP	SCREW 11/64-40 L=8.5	1
38	226-01058	BED SLIDE LEFT, ASM., A	1
39	226-50857	BED SLIDE LEFT, ASM., A	1
40	226-25505	THROAT PLATE 1/4	1
41	226-60609	THROAT PLATE 1/4	1
42	226-00555	BED SLIDE RIGHT, ASM., A	1
43	226-50352	BED SLIDE RIGHT, ASM., A	1
44	B1110-051-0A0	BED SLIDE ASM.	1
45	226-50055	BED SLIDE ASM.	1
46	226-02601	BED SCREW STUD	4
47	226-51459	THREAD GUIDE ASM., E	1
48	226-03609	THREAD GUIDE	1
49	226-03708	FELT	1
50	226-03807	LABEL	1

Page 6 — 2. MAIN SHAFT & THREAD TAKE-UP COMPONENTS

Juki LH-3168 (36 pages) parts on page 6
Ref	Part number	Part name	Qty
	1	MAIN SHAFT
	2	COLLAR
	3	KEY
	4	BEARING
	5	BRACKET
	6	BRACKET
	7	WASHER
	8	SUPPORT
	9	SUPPORT
	10	BRACKET
	11	BEARING
	12	COLLAR
	13	COLLAR
	14	COLLAR
	15	RING
	16	SCREW
	17	PULLEY
	18	SCREW
	19	SHAFT
	20	COLLAR
	21	COLLAR
	22	COLLAR
	23	BRACKET
	24	BRACKET
	25	SCREW
	26	BRACKET
	27	SCREW
	28	BRACKET
	29	BRACKET
	30	SHAFT
	31	PIN
	32	BRACKET
	33	BEARING
	34	COLLAR
	35	COLLAR
	36	COLLAR
	37	COLLAR
	38	COLLAR
	39	COLLAR
	40	COLLAR
	41	COLLAR
	42	BELT
	43	BELT
	44	PULLEY
	45	SCREW

Page 7

Juki LH-3168 (36 pages) parts on page 7
Ref	Part number	Part name	Qty
	226-05158	THREAD TAKE-UP LEVER PIN ASM.
	226-05109	THREAD TAKE-UP LEVER PIN
	CQ-2020000-00	OIL WICK
	CQ-2520000-00	OIL WICK
	226-80508	THREAD TAKE-UP LEVER
	226-92909	THREAD TAKE-UP LEVER
	226-05208	TAKE-UP LEVER THEUST PIN
	CQ-2520000-00	OIL WICK
	SS-8151150-TP	SCREW 15/64-28 L=10.5
	226-06107	NEEDLE BAR CRANK ROD
	226-80656	NEEDLE BAR CRANK PIN ASM.
	CQ-5050000-00	OIL WICK
	SS-8680540-SP	SCREW 9/32-28 L=4.5
	B1202-512-000	MAIN SHAFT BUSHING, FRONT
	B1214-019-000	SPROCKET RING
	SS-6661110-SP	SCREW 1/4-40 L=11
	226-04508	HAND WHEEL
	SS-8151550-SP	SCREW 15/64-28 L=15
	226-51566	HAND WHEEL ASM.
	226-51558	HAND WHEEL
	226-51509	HAND WHEEL
	M4002-110-000	GENERATOR ROTOR
	M4007-110-0AA	MAGNET FITTING BASE A ASM.
	M4007-110-0AB	MAGNET FITTING BASE B ASM.
	SS-8151550-SP	SCREW 15/64-28 L=15
	SS-6111210-SP	SCREW 11/64-40 L=12
	VP-0450801-SD	WASHER 4.5X10.0X0.8
	110-32265	GENERATOR STARTER ASM.
	106-04809	SCREW
	226-04706	テンヒンコウカメテル
	226-04805	FELT
	226-04656	THRUST COLLAR ASM.
	226-04607	THRUST COLLAR
	SB-1200001-00	BEARING D=20X47
	RO-4372002-00	RUBBER RING
	SS-8660530-TP	SCREW 1/4-40 L=4.5
	226-04409	COUNTERWEIGHT
	SS-8681650-TP	SCREW 9/32-28 L=16
	SS-7681750-TP	SCREW 9/32-28 L=16.5
	SS-8680810-TP	SCREW 9/32-28 L=8.0
	226-04003	MAIN SHAFT
	226-04102	SPROCKET WHEEL
	226-04300	TIMING BELT
	226-51608	SPROCKET WHEEL
	SS-7120760-SP	SCREW 3/16-28 L=7.0

Page 8 — 3. NEEDLE BAR COMPONENTS

Juki LH-3168 (36 pages) parts on page 8
Ref	Part number	Part name
1	1	NEEDLE BAR GUIDE
2	2	SCREW
3	3	NEEDLE BAR
4	4	NEEDLE BAR CONNECTING PIECE
5	5	NEEDLE BAR CONNECTING PIECE
6	6	NEEDLE BAR CONNECTING PIECE
7	7	NEEDLE BAR CONNECTING PIECE
8	8	NEEDLE BAR CONNECTING PIECE
9	9	NEEDLE BAR CONNECTING PIECE
10	10	NEEDLE BAR CONNECTING PIECE
11	11	NEEDLE BAR CONNECTING PIECE
12	12	NEEDLE BAR CONNECTING PIECE
13	13	NEEDLE BAR CONNECTING PIECE
14	14	NEEDLE BAR CONNECTING PIECE
15	15	NEEDLE BAR CONNECTING PIECE
16	16	NEEDLE BAR CONNECTING PIECE
17	17	NEEDLE BAR CONNECTING PIECE
18	18	NEEDLE BAR CONNECTING PIECE
19	19	NEEDLE BAR CONNECTING PIECE
20	20	NEEDLE BAR CONNECTING PIECE
21	21	NEEDLE BAR CONNECTING PIECE
22	22	NEEDLE BAR CONNECTING PIECE
23	23	NEEDLE BAR CONNECTING PIECE
24	24	NEEDLE BAR CONNECTING PIECE
25	25	NEEDLE BAR CONNECTING PIECE
26	26	NEEDLE BAR CONNECTING PIECE
27	27	NEEDLE BAR CONNECTING PIECE
28	28	NEEDLE BAR CONNECTING PIECE
29	29	NEEDLE BAR CONNECTING PIECE
30	30	NEEDLE BAR CONNECTING PIECE
31	31	NEEDLE BAR CONNECTING PIECE
32	32	NEEDLE BAR CONNECTING PIECE
33	33	NEEDLE BAR CONNECTING PIECE
34	34	NEEDLE BAR CONNECTING PIECE
35	35	NEEDLE BAR CONNECTING PIECE
36	36	NEEDLE BAR CONNECTING PIECE
37	37	NEEDLE BAR CONNECTING PIECE
38	38	NEEDLE BAR CONNECTING PIECE
39	39	NEEDLE BAR CONNECTING PIECE
40	40	NEEDLE BAR CONNECTING PIECE
41	41	NEEDLE BAR CONNECTING PIECE
42	42	NEEDLE BAR CONNECTING PIECE
43	43	NEEDLE BAR CONNECTING PIECE
44	44	NEEDLE BAR CONNECTING PIECE
45	45	NEEDLE BAR CONNECTING PIECE
46	46	NEEDLE BAR CONNECTING PIECE
47	47	NEEDLE BAR CONNECTING PIECE
48	48	NEEDLE BAR CONNECTING PIECE
49	49	NEEDLE BAR CONNECTING PIECE
50	50	NEEDLE BAR CONNECTING PIECE
51	51	NEEDLE BAR CONNECTING PIECE
52	52	NEEDLE BAR CONNECTING PIECE
53	53	NEEDLE BAR CONNECTING PIECE
54	54	NEEDLE BAR CONNECTING PIECE
55	55	NEEDLE BAR CONNECTING PIECE
56	56	NEEDLE BAR CONNECTING PIECE
57	57	NEEDLE BAR CONNECTING PIECE
58	58	NEEDLE BAR CONNECTING PIECE
59	59	NEEDLE BAR CONNECTING PIECE
60	60	NEEDLE BAR CONNECTING PIECE
61	61	NEEDLE BAR CONNECTING PIECE
62	62	NEEDLE BAR CONNECTING PIECE
63	63	NEEDLE BAR CONNECTING PIECE
64	64	NEEDLE BAR CONNECTING PIECE
65	65	NEEDLE BAR CONNECTING PIECE
66	66	NEEDLE BAR CONNECTING PIECE
67	67	NEEDLE BAR CONNECTING PIECE
68	68	NEEDLE BAR CONNECTING PIECE
69	69	NEEDLE BAR CONNECTING PIECE
70	70	NEEDLE BAR CONNECTING PIECE
71	71	NEEDLE BAR CONNECTING PIECE
72	72	NEEDLE BAR CONNECTING PIECE
73	73	NEEDLE BAR CONNECTING PIECE
74	74	NEEDLE BAR CONNECTING PIECE
75	75	NEEDLE BAR CONNECTING PIECE
76	76	NEEDLE BAR CONNECTING PIECE

Page 9

Juki LH-3168 (36 pages) parts on page 9
Ref	Part number	Part name	Qty
	226-81100	NEEDLE BAR GUIDE PLATE	2
	SS-6060510	SCREW 3/32-56 L=4.5	4
	CQ-2020000	OIL WICK	0.1
	SS-4090415	SCREW 9/64-40 L=4	1
	226-81209	FELT COVER	1
	110-02904	ROLLER FELT	2
	226-81605	NEEDLE BAR SWIVEL STOPPER	2
	226-81704	STOPPER SCREW	2
	B1422-512-000	FELT	1
	226-81001	NEEDLE BAR FRAME ASM.	1
	226-81001	NEEDLE BAR FRAME	1
	226-06602	NEEDLE BAR SHAFT	1
	PT-0502700-SO	TAPERED PIN	(1)
#01	226-82157	SLIDE BLOCK
	226-81803	SLIDE BLOCK GUIDE PLATE	(1)
	SS-4090815-SP	SCREW 9/64-40 L=8	1
	226-85903	FELT GUIDE	1
	VP-0450000-SD	WASHER 4.5X8X0.5	1
	SS-7110710-SP	SCREW 11/64-40 L=7	1
	226-86000	NEEDLE BAR OIL SEAL FELT. A	1
	226-85804	NEEDLE BAR OIL SEAL PLATE	1
	SS-6060510-TP	SCREW 3/32-56 L=4.5	1
	226-86158	NEEDLE OIL SEAL FELT. B (クミ)	2
	226-81407	NEEDLE BAR STOPPER	1
	226-81506	STOPPER SPRING	2
	226-81308	STOPPER SPRING COVER	1
	SS-4080610-SP	SCREW 1/8-44 L=6.4	1
#01	B1438-512-BOO	WASHER 17.1X28X1.5
	226-07303	BUSHING	1
	226-07402	BUSHING	1
	226-07006	REAR ARM	1
	SS-6152440-SP	SCREW 15/64-28 L=23.5	1
	SD-0870601-SP	HINGE SCREW D= 8.73 H= 6.0	2
	NS-6150430-SP	NUT 15/64-28	2
	226-07105	CONNECTING ROD	1
	226-07204	DRIVING ARM	1
	SS-6121610-TP	SCREW 3/16-28 L=15.5	1
	226-85150	NEEDLE BAR UNIT, LEFT	1
	226-85101	NEEDLE BAR ASM., LEFT	1
	226-85200	NEEDLE BAR, LEFT	1
	226-85408	SEESAW PLATE	1
	B1416-528-000	NEEDLE BAR PIN	1
	B1425-526-000	COLLAR	1
	B1402-528-FAL-A	NEEDLE CLAMP ASM. 1/4	1
	B1425-526-000	SCREW 1/8-44 L=6	1
	226-85366	NEEDLE BAR UNIT, LEFT	1
	226-85358	NEEDLE BAR ASM., LEFT	1
	226-85309	NEEDLE BAR, RIGHT	1
	226-85200	SEESAW PLATE	1
	226-85408	NEEDLE BAR PIN	1
	B1416-528-000	COLLAR	1
	B1425-526-000	SCREW 1/8-44 L=6	1
	B1402-528-FAR-A	NEEDLE CLAMP ASM. 1/4	1
	B1425-526-000	SCREW 1/8-44 L=6	1
	MDP-500B140	NEEDLE DPX5 #14	2
	226-83056	NEEDLE BAR CONNECTION ASM.	1
	SS-7060310-SP	SCREW 3/32-56 L=3	1
	226-83205	RELEASE PIN COVER	(1)
	226-83304	SPRING	(1)
	226-83106	RELEASE PIN	(2)
	226-83809	SPRING	(2)
	226-83007	NEEDLE BAR CONNECTION	(1)
	226-83403	NEEDLE BAR CONNECTION PIN	(2)
	226-84104	SPRING	(2)
	SS-6080340-SP	SCREW 1/8-44 L=2.9	(2)
	226-84203	SPRING BRACKET	(1)
	226-83908	CLUTCH STOPPER, LEFT	(1)
	226-84005	CLUTCH STOPPER, RIGHT	(1)
	226-83502	NEEDLE BAR CLUTCH	(2)
	226-83700	CLUTCH PIN	(2)
	226-83601	CLUTCH LEVER	(0.1)
	CQ-2520000-00	OIL WICK	1
	226-84609	NEEDLE BAR CRANK ROD	1
#01	226-84906	NEEDLE BAR GUIDE BLOCK
	226-85705	OIL GUARD RUBBER	1

Page 10 — 4. TENSION POST COMPONENTS

Juki LH-3168 (36 pages) parts on page 10
Ref	Part number	Part name	Qty
	1	TENSION POST COMPONENTS
	2	TENSION POST COMPONENTS
	3	TENSION POST COMPONENTS
	4	TENSION POST COMPONENTS
	5	TENSION POST COMPONENTS
	6	TENSION POST COMPONENTS
	7	TENSION POST COMPONENTS
	8	TENSION POST COMPONENTS
	9	TENSION POST COMPONENTS
	10	TENSION POST COMPONENTS
	11	TENSION POST COMPONENTS
	12	TENSION POST COMPONENTS
	13	TENSION POST COMPONENTS
	14	TENSION POST COMPONENTS
	15	TENSION POST COMPONENTS
	16	TENSION POST COMPONENTS
	17	TENSION POST COMPONENTS
	18	TENSION POST COMPONENTS
	19	TENSION POST COMPONENTS
	20	TENSION POST COMPONENTS
	21	TENSION POST COMPONENTS
	22	TENSION POST COMPONENTS
	23	TENSION POST COMPONENTS
	24	TENSION POST COMPONENTS
	25	TENSION POST COMPONENTS
	26	TENSION POST COMPONENTS
	27	TENSION POST COMPONENTS
	28	TENSION POST COMPONENTS
	29	TENSION POST COMPONENTS
	30	TENSION POST COMPONENTS
	31	TENSION POST COMPONENTS
	32	TENSION POST COMPONENTS
	33	TENSION POST COMPONENTS
	34	TENSION POST COMPONENTS
	35	TENSION POST COMPONENTS
	36	TENSION POST COMPONENTS
	37	TENSION POST COMPONENTS
	38	TENSION POST COMPONENTS
	39	TENSION POST COMPONENTS
	40	TENSION POST COMPONENTS
	41	TENSION POST COMPONENTS
	42	TENSION POST COMPONENTS
	43	TENSION POST COMPONENTS
	44	TENSION POST COMPONENTS
	45	TENSION POST COMPONENTS
	46	TENSION POST COMPONENTS
	47	TENSION POST COMPONENTS
	48	TENSION POST COMPONENTS
	49	TENSION POST COMPONENTS
	50	TENSION POST COMPONENTS
	51	TENSION POST COMPONENTS
	52	TENSION POST COMPONENTS
	53	TENSION POST COMPONENTS
	54	TENSION POST COMPONENTS
	55	TENSION POST COMPONENTS
	56	TENSION POST COMPONENTS
	57	TENSION POST COMPONENTS
	58	TENSION POST COMPONENTS
	59	TENSION POST COMPONENTS
	60	TENSION POST COMPONENTS
	61	TENSION POST COMPONENTS
	62	TENSION POST COMPONENTS
	63	TENSION POST COMPONENTS

Page 11

Juki LH-3168 (36 pages) parts on page 11
Ref	Part number	Part name
	226-89061	THREAD TENSION ASM., S
	B3128-051-000	THREAD TAKE-UP SPRING, A
	106-97605	THREAD TAKE-UP SPRING STUD
	226-18201	THREAD RELEASE PIN, A
	226-18300	TENSION RELEASE PIN, B
	226-18102	TENSION RELEASE LEVER
	SD-0470281-SP	HINGE SCREW D=4.7 H=2.8
	NS-6110310-SP	NUT 11/64-40
	226-89053	THREAD TENSION BASE PLATE ASM.
	101-24204	THREAD TENSION POST, A
	B3214-047-000	BOBBIN WINDER TENSION DISC
#01	110-45101	THREAD TENSION SPRING
#02	110-93606	THREAD TENSION SPRING
	110-72402	THREAD TENSION NUT
	101-24303	THREAD TENSION POST, B
	B3126-012-000	THREAD TENSION DISK
	B3132-552-000	THREAD TENSION DISK PRESSER
#02	B3114-232-000	THREAD TENSION SPRING
#03	B3129-012-A00	THREAD TENSION SPRING
#04	D3129-555-D00	THREAD TENSION SPRING
	B3112-704-000	THREAD TENSION BUSHING
	119-56802	THREAD TENSION KNOB, BLUE
	B3125-012-000	THREAD TENSION NUT
	B3125-527-000	TAKE-UP SPRING GUIDE
	B3141-527-000	PRESSER COLLAR
	SS-7080410-SP	SCREW 1/8-44 L=5.5
	SS-8080410-TP	SCREW 1/8-44 L=3.5
	SS-7090520-SP	SCREW 9/64-40 L=4.5
	B3138-527-000	ADJUSTING PLATE B
	B3140-527-000	THREAD TENSION POST
	B3128-527-000	TAKE-UP SPRING GUIDE, B
	B3137-527-0AO	TAKE-UP SPRING GUIDE ASM.
	B3139-527-000	COLLAR
	B3142-527-000	TAKE-UP SPRING GUIDE PLATE
	B3143-527-000	TAKE-UP SPRING GUIDE STUD
	106-97506	THREAD TENSION BRACKET, A
	SS-4110615-SP	SCREW 11/64-40 L=6
	WP-0501015-SP	WASHER 5X10.5X1
	WP-0450801-SP	WASHER
	B1449-526-000	REPOSITIONING LEVER SPRING
	226-89103	REPOSITIONING LEVER
	SD-0601171-SP	HINGE SCREW D=6 H=11.7
	226-89301	LABEL
	226-89202	LEVER PIN SCREW
	NS-6120310-SP	NUT 3/16-28
	SS-4120615-SP	SCREW 3/16-28 L=6
	226-87453	REPOSTINING LEVER ASM.
	SS-6110430-TP	SCREW 11/64-40 L=4
	SS-7110740-TP	SCREW 11/64-40 L=7
	SS-8110520-TP	SCREW 11/64-40 L=4.5
	226-87305	REPOSTINING LEVER SHAFT
	226-87206	REPOSTINING ARM
	SS-7111410-TP	SCREW 11/64-40 L=14
	SD-0640902-TP	HINGE SCREW D=6.35 H=9
	226-87503	SPRING
	226-87701	SPRING SHAFT
	RE-0700000-KO	SNAP RING 7
	226-87602	SPRING BASE
	SS-4120915-SP	SCREW 3/16-28 L=9
	226-87107	REPOSITIONING PLATE
	SD-0640241-SP	HINGE SCREW D=6.35 H=2.4
	226-87008	LEAF SPRING
	SS-9110460-CP	SCREW 11/64-40 L=4

Page 12 — 5. HOOK & HOOK DRIVING SHAFT COMPONENTS

Juki LH-3168 (36 pages) parts on page 12
Ref	Part number	Part name	Qty
	1	HOOK DRIVING SHAFT
	2	SHAFT SLEEVE
	3	KEY
	4	DRIVING GEAR
	5	WASHER
	6	GEAR
	7	SCREW
	8	COLLAR
	9	COLLAR
	10	SHAFT
	11	BEARING
	12	BEARING
	13	COLLAR
	14	COLLAR
	15	SCREW
	16	NUT
	17	WASHER
	18	COLLAR
	19	UPPER LOOPER SHAFT
	20	LOOPER SHAFT
	21	LOOPER SHAFT
	22	LOOPER SHAFT
	23	LOOPER SHAFT
	24	LOOPER SHAFT
	25	LOOPER SHAFT
	26	LOOPER SHAFT
	27	LOOPER SHAFT
	28	LOOPER SHAFT
	29	LOOPER SHAFT
	30	LOOPER SHAFT
	31	LOOPER SHAFT
	32	LOOPER SHAFT
	33	LOOPER SHAFT
	34	THREAD GUIDE
	35	THREAD GUIDE
	36	WASHER
	37	UPPER LOOPER SHAFT
	38	LOOPER SHAFT
	39	LOOPER SHAFT
	40	LOOPER SHAFT
	41	LOOPER SHAFT
	42	LOOPER SHAFT
	43	LOOPER SHAFT
	44	LOOPER SHAFT
	45	LOOPER SHAFT
	46	LOOPER SHAFT
	47	LOOPER SHAFT
	48	LOOPER SHAFT
	49	LOOPER SHAFT
	50	LOOPER SHAFT
	51	LOOPER SHAFT
	52	SCREW
	53	WASHER
	54	BRACKET
	55	SHAFT
	56	SHAFT
	57	SHAFT
	58	COLLAR
	59	COLLAR
	60	COLLAR
	61	SHAFT
	62	SHAFT
	63	SHAFT
	64	SHAFT
	65	COLLAR
	66	COLLAR
	67	COLLAR
	68	COLLAR
	69	BASE PLATE
	70	BASE PLATE
	71	BASE PLATE
	72	BASE PLATE
	73	SCREW
	74	BRACKET
	75	BASE PLATE
	76	BASE PLATE
	77	SCREW
	78	WASHER
	79	WASHER
	80	SCREW
	81	SPRING
	82	SHAFT
	83	BRACKET
	84	BRACKET
	85	SCREW
	86	COLLAR
	87	WASHER
	88	SHAFT
	89	BRACKET
	90	SCREW

Page 13

Juki LH-3168 (36 pages) parts on page 13
Part number	Part name	Qty
01-08512	HOOK DRIVING SHAFT	1
1802-512-0A0-A	BUSHING ASM., FRONT	1
B1810-510-000	HOOK DRIVING SHAFT, LARGE	2
SS-8660530-TP	SCREW 1/4-40 L=10.5	8
1816-512-000	HOOK DRIVING SHAFT, LARGE	1
SS-8660810-TP	SCREW 1/4-40 L=8	4
SS-8660530-TP	SCREW 1/4-40 L=4.5	6
26-09804	FEED DRIVING CAM	1
1803-515-0A0	BUSHING ASM., INTERMEDIATE	1
01-08611	PLUNGER BUSHING	1
SS-8151150-SP	SCREW 15/64-28 L=10.5	2
26-13707	THRUST COLLAR ASM.	2
CS-1471012-SP	THRUST COLLAR D=14.72 W=10	2
1471012-SH	THRUST COLLAR D=14.72 W=10	1
SS-8660530-TP	SCREW 1/4-40 L=4.5	2
8917-051-000	BOBBIN	2
26-88006	HOOK	2
226-88105	TENSION ADJUSTING SPRING	2
226-88402	TENSION ADJUSTING SPRING	2
01-10500	TENSION SPRING INSTALLING SCRE	2
26-88105	BOBBIN CASE	2
26-88204	SPRING	2
SS-6560150-SH	SCREW 3/32-80 L=1.3	2
26-12709	BOBBIN GIB	2
26-12204	HOOK G18	2
01-12803	SCREW	4
101-12902	NEEDLE POSITIONER	2
01-12902	SCREW	2
102-10805	HARD ALUNITE BOBBIN	2
01-11508	SPRING	2
226-53802	SHEET	2
26-93857	HOOK ASM.	2
226-88006	HOOK	2
226-88402	TENSION ADJUSTING SPRING	2
01-10500	TENSION SPRING INSTALLING SCRE	2
26-88105	BOBBIN CASE	2
26-88204	SPRING	2
SS-6560150-SH	SCREW 3/32-80 L=1.3	2
26-53000	SEVING HOOK	2
26-53307	HOOK GIB	2
101-12803	SCREW	4
101-12902	NEEDLE POSITIONER	2
01-12902	SCREW	2
102-10805	HARD ALUNITE BOBBIN	2
01-11508	SPRING	2
SS-606010-SP	SCREW 9/64-40 L=7.5	2
01-07016-SD	WASHER 3.7X8X1	2
101-09808	SADDLE INSTALLING BLOCK, UPPER	2
01-12407	SADDLE INSTALLING BLOCK, LOWER	2
SS-6153040-SP	SCREW 15/64-28 L=30	2
1820-051-000	BOBBIN CASE OPENING LEVER LINK	2
CO-2020000-00	OIL WICK	0.1
1821-051-000	CRANK SCREW STUD	2
1822-051-000	OPENING LEVER CRANK	2
1823-051-000	OIL WICK	0.1
B1-610420-00	NUT 11/64-40	2
01-2020000-00	OIL WICK	2
1823-051-000	OPENING LEVER CRANK PIN	2
26-14101	THRUST WASHER, R	2
01-11201	THRUST WASHER, F	2
226-13251	BUSHING	2
CS-13095301-0C	NEEDLE GEARING 9.525X9.52	2
226-13004	HOOK SHAFT SADDLE, LEFT	1
226-13004	HOOK SHAFT SADDLE, LEFT	1
226-13505	HOOK SHAFT SADDLE, RIGHT	1
226-13505	HOOK SHAFT SADDLE, RIGHT	1
SS-9111820-SP	SCREW 11/64-40 L=18	2
26-15454	RUBBER BUSHING ASM.	2
226-15108	GASKET	2
226-15009	HOOK SHAFT SADDLE COVER	2
226-15306	FELT HOLDER	2
226-15207	OIL ADJUSTING BALL	2
226-15702	OIL ADJUSTING BALL	2
226-15801	PRESSER SPRING	2
226-15801	OIL ADJUSTING SCREW	2
226-15959	OIL VICK HOLDER ASM. LEFT	2
26-26654	OIL VICK HOLDER ASM. RIGHT	2
171-26654	OIL VICK HOLDER ASM. RIGHT	2
01-0850002-SP	WASHER 8.5X18X1.6	2
VP-0850002-SP	WASHER 8.5X18X1.6	2
226-13608	GEAR GUIDE	2
226-7110710-SP	SCREW 11/64-40 L=7	4

Page 14 — 6. FEED MECHANISM COMPONENTS

Juki LH-3168 (36 pages) parts on page 14
Ref	Part number	Part name
1	1	SCREW
2	2	WASHER
3	3	LINK
4	4	LINK
5	5	SCREW
6	6	SPRING
7	7	SPRING
8	8	SHAFT
9	9	SHAFT
10	10	COLLAR
11	11	BRACKET
12	12	SCREW
13	13	SHAFT
14	14	WASHER
15	15	SCREW
16	16	ARM
17	17	RING
18	18	SHAFT
19	19	SPRING
20	20	PIN
21	21	GEAR
22	22	SCREW
23	23	BRACKET
24	24	SCREW
25	25	GEAR
26	26	SHAFT
27	27	SCREW
28	28	SPRING
29	29	SCREW
30	30	SHAFT
31	31	BRACKET
32	32	SCREW
33	33	BRACKET
34	34	BRACKET
35	35	BRACKET
36	36	BRACKET
37	37	BRACKET
38	38	BRACKET
39	39	BRACKET
40	40	SPRING
41	41	SHAFT
42	42	SCREW
43	43	SHAFT
44	44	SCREW
45	45	SCREW
46	46	BRACKET
47	47	SCREW
48	48	SHAFT
49	49	SPRING
50	50	SHAFT
51	51	SCREW
52	52	SHAFT
53	53	BRACKET
54	54	BRACKET
55	55	BRACKET
56	56	SHAFT
57	57	NUT
58	58	SCREW
59	59	SPRING
60	60	SHAFT
61	61	BRACKET
62	62	SCREW
63	63	BRACKET
64	64	BRACKET
65	65	PIN
66	66	SPRING
67	67	CHAIN

Page 15

Juki LH-3168 (36 pages) parts on page 15
Part number	Part name	Qty
SS-6090670-TP	SCREW 9/64-40 L=6	2
226-10109	ROD PIN	1
RE-050000-KO	E-RING	1
226-10208	FEED REGULATOR CONNECTING ROD	1
SD-0800422-CP	HINGE SCREW D= 8 H= 4.2	1
226-10000	FEED REGULATOR	1
SS-7121410-SP	SCREW 3/16-28 L=14	1
226-10307	FEED REGULATOR SPRING	1
226-10604	REVERSE FEED SHAFT	1
226-52101	REVERSE FEED SHAFT
CS-102121A-SH	THRUST COLLAR ASM. D=10.2 W=12	1
SS-8660610-TP	SCREW 1/4-40 L=6	(2)
101-08009	OIL SEAL	1
RE-090000-KO	SNAP RING 9.0	1
SS-8120740-SP	SCREW 3/16-28 L=7	2
226-10505	REVERSE FEED CONTROL LEVER	1
RO-0922702-00	RUBBER RING	1
110-09909	FEED REGULATOR SCREW	1
B1148-555-000	SPRING	1
110-52701	PIN	1
110-71909	FEED DIAL	1
SS-6121860-SP	SCREW	1
226-10406	SPRING BRACKET	2
SS-4110815-SP	SCREW 11/64-40 L=8	1
226-09200	FEED ROCK SHAFT CONNECTING ROD	1
226-52002	FEED DRIVE ECCENTRIC CAM	1
SS-6661110-SP	SCREW 1/4-40 L=11	2
SS-7110710-SP	SCREW 11/64-40 L=7	2
226-09101	CAM COVER	1
B1636-581-B00	NEEDLE BEARING B	1
B1610-512-000	FEED DRIVING SLIDE BLOCK	1
SS-6580752-TP	SCREW 1/8-40 L=7	2
226-30602	FEED DOG 1/4
102-38202	FEED DOG 1/4
226-09754	FEED BAR	1
226-09705	FEED BAR FORK	1
101-07902	SCREW 15/64-28 L=14	(1)
SS-9151440-CP	WASHER 6.2X13X1	(1)
WP-0621016-SD	SNAP RING 5	(1)
RE-0500711-KP	FEED BAR SHAFT	1
B1604-012-000-A	SCREW 3/16-32 L=6	1
SS-8620610-TP	FEED ROCK SHAFT	1
226-09408	NUT 1/8-44	1
NS-6080210-SP	SCREW 1/8-44 L=18.0	1
SS-6081810-SP	FEED ROCKER	2
B1603-512-000	SCREW 11/64-40 L=12.8	2
SS-7111310-TP	BUSHING	1
101-06102	SCREW 15/64-28 L=10.5	1
SS-8151150-SP	THRUST COLLAR ASM. D=14.72 W=12	(2)
CS-147121B-SH	SCREW 1/4-40 L= 4.5	1
SS-8660530-TP	THRUST COLLAR D=14.72 W=10	1
CS-1471012-SH	SCREW 11/64-40 L=8.5	4
SS-7110910-SP	PLATE	2
103-15505	FEED DRIVING ROCKER BLOCK. S	2
226-09606	FEED ROCKER SHAFT CRANK	1
226-09309	NUT 9/32-28	0.5
NS-6680320-SP	SCREW 3/16-28 L=15.5	0.3
SS-6121610-TP	HINGE SCREW D= 9 H= 7	1
SD-0900701-TP	FEED ROCK CONNECTING ROD	1
103-15208	FEED DRIVING ROCKER ASM.	1
103-15455	SCREW 11/64-40 L=5	1
SS-7110510-SP	STOPPER PLATE	2
B1633-470-000	SCREW 1/4-40 L= 4.5	1
SS-8660530-TP	PIN	1
B1653-470-000	OIL WICK	1
CQ-2520000-00	OIL WICK	1
CQ-3030000-00	OIL WICK

Page 16 — 7. PRESSER BAR & TENSION RELEASE COMPONENTS

Juki LH-3168 (36 pages) parts on page 16
Ref	Part number	Part name	Qty
	1	PRESSER BAR & TENSION RELEASE COMPONENTS
	2	押さえ棒・糸ゆるめ関係
	3
	4
	5
	6
	7
	8
	9
	10
	11
	12
	13
	14
	15
	16
	17
	18
	19
	20
	21
	22
	23
	24
	25
	26
	27
	28
	29
	30
	31
	32
	33
	34
	35
	36
	37
	38
	39
	40
	41
	42
	43
	44
	45

Page 17

Juki LH-3168 (36 pages) parts on page 17
Part number	Part name	Qty
110-71800	HAND LIFTER	1
B1521-055-000	SCREW	1
R0-0371801-00	RUBBER RING	1
110-06756	HAND LIFTER CAM ASM.	1
226-08152	LIFTING LEVER ROD ASM.	1
110-06350	HAND LIFTER LINK	(1)
110-06202	LIFTING LEVER	(1)
110-07309	LIFTING LEVER RING	(1)
RE-0500000-KO	E-RING	(1)
226-08103	LIFTING LEVER CONNECTING ROD	(1)
110-06509	LINK SHAFT	2
RE-0500000-KO	E-RING	2
110-07101	HINGE SCREW	1
SD-0720332-SP	HINGE SCREW D= 7.24 H= 3.3	1
110-07002	LIFTING LEVER LINK	1
101-25201	CONNECTING ROD, VERTICAL	1
SD-0600322-SD	HINGE SCREW D=6 H=3.2	3
RE-0500000-KO	E-RING	1
110-18207	TENSION RELEASE RETURN SPRING	1
110-18108	TENSION RELEASE SHAFT	1
226-17104	TENSION RELEASE PLATE	1
226-54909	TENSION RELEASE PLATE ASM.	(1)
226-17104	TENSION RELEASE PLATE	(1)
113-94509	WIRE CABLE	(1)
226-54909	WIRE TUBE	(1)
D3159-555-BOO	SET SCREW	(1)
NS-6620310-SP	NUT 3/16-32	2
D3164-555-BOO	OUTER PRESSER PLATE	2
SS-4110715-SP	SCREW 11/64-40 L=7	2
D3163-555-BOO-A	FLEXIBLE TUBE SUPPORT PLATE	1
SS-4111215-SP	SCREW 11/64-40 L=12	2
113-06206	WIRE CABLE HOLDER	1
SS-4110715-SP	SCREW 11/64-40 L=7	1
226-17005	PUSH BAR	1
PS-0600502-KP	SPRING PIN	1
110-71602	PRESSER SPRING REGULATOR	1
110-71701	NUT	1
B1510-227-000	PRESSER GUIDE BAR	1
B1505-227-000-A	PRESSER SPRING T	1
B1501-581-000	PRESSER BAR	1
226-08004	NEEDLE BAR GUIDE BRACKET	1
SS-8660810-TP	SCREW 1/4-40 L=8	1
B1502-541-000	PRESSER BAR BUSHING, LOWER	1
101-52957	PRESSER FOOT ASM. 1/4"	1
SS-7090910-TP	SCREW 9/64-40 L= 8.5	1

Page 18 — 8. THREAD TRIMMER MECHANISM COMPONENTS (FOR LH-3168-7)

Juki LH-3168 (36 pages) parts on page 18
Ref	Part number	Part name
1	1	SCREW
2	2	SPRING
3	3	SHAFT
4	4	BRACKET
5	5	SPRING
6	6	SPRING
7	7	PIN
8	8	SCREW
9	9	SCREW
10	10	BRACKET
11	11	SCREW
12	12	SCREW
13	13	SCREW
14	14	BRACKET
15	15	SHAFT
16	16	SCREW
17	17	SPRING
18	18	BRACKET
19	19	SCREW
20	20	BRACKET
21	21	SPRING
22	22	BRACKET
23	23	SPRING
24	24	SCREW
25	25	BRACKET
26	26	BRACKET
27	27	SPRING
28	28	SCREW
29	29	BRACKET
30	30	SCREW
31	31	SHAFT
32	32	SPRING
33	33	BRACKET
34	34	SCREW
35	35	SPRING
36	36	SPRING
37	37	SHAFT
38	38	SPRING
39	39	SPRING
40	40	SPRING
41	41	SPRING
42	42	SPRING
43	43	NUT
44	44	BRACKET
45	45	SCREW
46	46	SPRING
47	47	BRACKET
48	48	BRACKET
49	49	BRACKET
50	50	SPRING
51	51	SPRING
52	52	SCREW
53	53	SHAFT
54	54	SCREW
55	55	BRACKET
56	56	CONNECTOR
57	57	CONNECTOR
58	58	SCREW
59	59	SPRING
60	60	SHAFT
61	61	BRACKET
62	62	SPRING
63	63	SPRING
64	64	NUT
65	65	WIRE

Page 19

Juki LH-3168 (36 pages) parts on page 19
Part number	Part name	Qty
SS-2080810-SP	SCREW 1/8-44 L=7.5	4
102-11605	MOVING KNIFE	2
101-16051	MOVING KNIFE SHAFT ASM.	2
226-54255	MOVING KNIFE SUPPORT ASM.	2
226-54206	MOVING KNIFE SUPPORT PLATE	(2)
102-11407	THREAD PRESSER ADJUSTING PLATE	(2)
SS-8080610-SP	SCREW 1/8-44 L=5.5	(2)
SS-9080410-SP	SCREW 1/8-44 L=4.3	(2)
SS-5090610-SP	SCREW 9/64-40 L=6	4
226-55401	THREAD PRESSER	2
226-55302	COUNTER KNIFE	(2)
SS-7090710-SP	SCREW 9/64-40 L=6.8	(2)
SS-6121212-TP	SCREW 3/16-28 L=12.0	1
226-54800	GUIDE PLATE	1
101-16804	SHAFT	1
SS-7151610-SP	SCREW 15/64-28 L=16	2
B3418-180-000	SPRING	1
101-17208	TENSION DISC RELEASE PLATE	1
SD-0600271-SP	SCREW D= 6 H= 2.7	1
226-55153	HINGE INSTALLING BASE ASM.	(1)
SS-8111010-TP	SCREW 11/64-40 L=9.5	(1)
226-55104	TENSION DISC RELEASE ARM	(1)
101-16606	LINK INSTALLING BASE	(1)
101-17109	BUSHING	(1)
PS-0300201-KP	SPRING PIN 3.0X20	(1)
226-54701	STOPPER PLATE	1
SS-2110920-SP	SCREW 11/64-40 L=8.5	1
SS-2110930-SP	SCREW 11/64-40 L=8.7	1
CS-1470710-SH	THRUST COLLAR ASM. D=14.72 W=7	(2)
SS-8110410-TP	SCREW 11/64-40 L=3.5	1
226-54107	THREAD TRIMMER CAM	2
SS-8660810-TP	SCREW 1/4-40 L=8	2
CS-070081B-SH	THRUST COLLAR ASM. D=7 W=8	2
SS-8110510-SP	SCREW 11/64-40 L=5	1
101-16903	SPRING	1
B1853-512-000C	HOOK SHAFT WASHER, C	1
101-16754	CAM INSTALLING LINK ASM.	1
SS-612220-SP	SCREW 15/64-28 L=11.5	(1)
D2430-555-B00	SNAP RING	(1)
101-16705	CAM INSTALLING LINK	(1)
D2428-555-B00-A	CAM ROLLER	(1)
D2427-555-B00	CAM ROLLER	(1)
NM-6050001-SP	NUT M5	2
226-54404	DRIVING ARM, LEFT	1
SS-6121610-TP	SCREW 3/16-28 L=15.5	1
B1515-051-000	HAND LIFTER PIN	2
226-54504	CONNECTING LINK ASM.	1
226-54503	CONNECTING LINK, A	(1)
226-54602	CONNECTING LINK, B	(1)
SS-9111010-SP	SCREW 11/64-40 L=9.5	(2)
VP-0501016-SD	WASHER 5X10.5X1	(2)
SD-0650305-TP	SCREW D=6.5 H= 3	(2)
226-54305	SPRING	1
SS-6121610-TP	SCREW 3/16-28 L=15.5	1
101-17851	SOLENOID ASM.	1
HK-0346400-OB	PIN CONTACT	2
HK-0346101-40	HOUSING 14P	1
SS-6151040-SP	SCREW 15/64-28 L=10	2
B3041-980-000	SPRING	1
226-55005	JOINT ROD	1
226-54008	DRIVING ARM PLATE	1
B3417-051-000	REAR LIFTING BAR ROLLER	1
SS-6120940-SP	SCREW 3/16-28 L=9	1
WP-0501016-SD	WASHER 5X10.5X1	1
EA-9500B01-00	CABLE BAND	2

Page 20 — 9. AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)

Juki LH-3168 (36 pages) parts on page 20
Ref	Part number	Part name	Qty
	1	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	2	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	3	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	4	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	5	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	6	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	7	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	8	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	9	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	10	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	11	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	12	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	13	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	14	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	15	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	16	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	17	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	18	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	19	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	20	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	21	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	22	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	23	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	24	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	25	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	26	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	27	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	28	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	29	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	30	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	31	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	32	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	33	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	34	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	35	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	36	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	37	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	38	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	39	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	40	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	41	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)
	42	AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)

Page 21

Juki LH-3168 (36 pages) parts on page 21
Ref	Part number	Part name	Qty
	226-56557	REVERSE FEED SWITCH ASM.
	110-72501	REVERSE FEED SWITCH COVER
	SS-4110615-SP	SCREW 11/64-40 L=6
	226-56508	REVERSE FEED SWITCH BASE
	111-02100	REVERSE FEED SWITCH SHAFT
	111-02209	REVERSE FEED SWITCH SPRING
	SS-4111815-SP	SCREW 11/64-40 L=18
	SM-4031501-SC	SCREW
	HW-5000700-00	2-CORE CABTYRE CORD
	HA-0019000-00	MICROSWITCH
	111-02308	REVERSE FEED SWITCH PLATE
	226-56607	REVERSE FEED SWITCH LEVER
13	HK-0346400-0B	PIN CONTACT	4
14	SS-4120615-SP	SCREW 3/16-28 L=6	2
15	WP-7110710-SP	SCREW 11/64-40 L=7	4
16	WP-0501016-SD	WASHER 5X10.5X1	4
17	101-61305	SOLENOID COVER	1
18	101-19105	REVERSE FEED SOLENOID, AC24V	1
19	101-19204	SOLENOID INSTALLING PLATE	1
20	WP-0501016-SD	WASHER 5X10.5X1	4
21	SS-9111010-SP	SCREW 11/64-40 L=9.5	4
22	D2464-555-B00	LINK DRIVING MAGNET PIN	1
23	RE-0400000-KO	E-SHAPED SNAP RING (4MM)	1
24	SS-7151510-XP	SCREW 15/64-28 L=12	2
25	WS-0631510-XP	SPRING WASHER	2
26	WP-0621016-SD	WASHER 6.2X13X1	2
27	226-56409	LINK FULCULUM	1
28	226-56300	REVERSE FEED LINK, L	1
29	SS-4153015-SP	PAN-SCREW 15/64-28 L=30	1
30	WS-0610002-KP	SPRING WASHER	1
31	226-56201	WASHER 6.1X18.5X2	1
32	226-56102	REVERSE FEED LINK, (2)	1
33	226-56102	REVERSE FEED LINK, (1)	1
34	SD-0640326-TP	HINGE SCREW	2
35	NS-6110350-SP	NUT 11/64-40	2
36	SS-7120760-SP	SCREW 3/16-28 L=7.0	1
37	111-00500	REVERSE FEED LEVER STOPPER	1
38	SS-6121840-SP	SCREW 3/16-28 L=18.0	1
39	B1506-352-000	TENSION SPRING RACK B	1
40	135-15606	SPRING	1
41	226-56003	SPRING SUSPENSION	1
42	SS-4120615-SP	SCREW 3/16-28 L=6	1

Page 22 — 10. WIPER MECHANISM COMPONENTS (FOR LH-3168-7)

Juki LH-3168 (36 pages) parts on page 22
Ref	Part number	Part name	Qty
	1	COVER
	2	BRACKET
	3	WASHER
	4	BRACKET
	5	BRACKET
	6	BRACKET
	7	BRACKET
	8	SPRING
	9	SPRING
	10	NUT
	11	WASHER
	12	WASHER
	13	MOTOR
	14	SHAFT
	15	BRACKET
	16	BRACKET
	17	BRACKET
	18	BRACKET
	19	BRACKET
	20	BRACKET
	21	WASHER
	22	BRACKET
	23	NUT
	24	HARNESS
	25	SCREW
	26	SCREW
	27	SCREW
	28	BRACKET
	29	BRACKET
	30	SCREW
	31	BRACKET
	32	SHAFT
	33	WASHER
	34	SCREW
	35	SCREW
	36	WASHER
	37	WASHER
	38	NUT

Page 23

Juki LH-3168 (36 pages) parts on page 23
Part number	Part name	Qty
226-57159	VIPER SOLENOID ASM.	1
110-72709	VIPER COVER	(1)
SM-4030601-SN	SCREW M3 X 6	(1)
VP-0320501-SC	WASHER M3	(1)
SD-0650321-TP	HINGE SCREW	(1)
226-57209	VIPER LINK, A	(1)
B2024-771-000	SUSPENSION SCREW	(1)
111-10707	VIPER HINGE SCREW COLLAR	(1)
226-57308	VIPER SPRING	(1)
NS-6110310-SP	NUT 11/64-40	(1)
111-10400	VIPER RUBBER A	(1)
111-10509	VIPER RUBBER B	(1)
111-10301	VIPER SOLENOID	(1)
111-11705	VIPER SOLENOID PIN	(1)
HA-0000900-00	POWER SWITCH	(1)
HW-2003900-00	ELECTRIC WIRE	(0.1)
HW-5000700-00	2-CORE CABTYRE CORD	(1.4)
226-57100	VIPER SOLENOID BASE	(1)
WS-0310002-KR	SPRING WASHER 3.1X5.9X1.4	(3)
SM-4030601-SN	SCREW M3 X 6	(3)
111-11804	VIPER LINK COLLAR	(1)
CS-0300711-SP	THRUST COLLAR	(1)
SS-6080320-SP	SCREW 1/8-44 L= 2.5	(2)
HK-0346400-OB	PIN CONTACT	2
SS-4120615-SP	SCREW 3/16-28 L=6	1
NS-6090310-SP	NUT 9/64-40	1
SD-0500404-SP	HINGE SCREW	1
226-57050	VIPER LINK ASM., 2	1
102-08551	VIPER BASE ASM.	1
SS-9111010-SP	SCREW 11/64-40 L=9.5	2
RE-0320000-KO	SNAP RING 3.2	2
102-08700	VIPER LINK SHAFT	1
SS-3090520-SP	SCREW 9/64-40 L=4.5	2
WP-0371016-SD	WASHER 3.7X8X1	2
102-09203	VIPER 3/32"-3/8"
102-09500	VIPER
102-09807	VIPER
102-09906	VIPER

Page 24 — 11. LUBRICATION COMPONENTS

Juki LH-3168 (36 pages) parts on page 24
Ref	Part number	Part name
60	60	SCREW
59	59	BRACKET
9	9	WASHER
10	10	NUT
20	20	NUT
19	19	WASHER
22	22	SCREW
17	17	BRACKET
21	21	BRACKET
1	1	CAP
15	15	BRACKET
18	18	BRACKET
2	2	GASKET
3	3	PIPE
12	12	SCREW
16	16	NUT
14	14	BRACKET
4	4	PIPE
5	5	PIPE
11	11	BRACKET
6	6	TUBE
7	7	TUBE
13	13	NUT
23	23	BRACKET
24	24	SCREW
25	25	BRACKET
26	26	TUBE
46	46	PIPE
45	45	PIPE
39	39	PIPE
40	40	PIPE
42	42	BRACKET
43	43	BRACKET
44	44	PIPE
47	47	PIPE
41	41	PIPE
35	35	PIPE
28	28	PIPE
29	29	PIPE
30	30	PIPE
31	31	PIPE
32	32	PIPE
33	33	PIPE
36	36	SCREW
37	37	WASHER
38	38	PIPE
49	49	PIPE
50	50	SCREW
48	48	PIPE
56	56	BRACKET
57	57	SCREW
51	51	SPRING
52	52	BRACKET
53	53	SCREW
54	54	SCREW
58	58	CABLE TIE

Page 25

Juki LH-3168 (36 pages) parts on page 25
Part number	Part name	Qty
B3530-555-000	OIL SIGHT WINDOW	1
RO-1952401-00	RUBBER RING	1
SS-4111815-SP	SCREW
102-16703	OIL TANK	1
NS-6110310-SN	NUT
226-20355	OIL PIPE ASM.	1
226-20454	FELT ASM.	1
226-20702	OIL TUBE	1
226-20108	PIPE HOLDER, B	1
SS-4110715-SP	SCREW
226-19209	OIL WICK GUIDE	1
SS-6121610-SP	SCREW
NS-6120310-SP	NUT
226-20504	OIL WICK HOLDER	1
SS-4111215-SP	SCREW
NS-6110430-SP	NUT
226-19308	OIL ADJUSTING FELT	1
226-19407	OIL ADJUSTING SHAFT	1
SS-8701782-TP	SCREW
NS-6700420-SP	NUT
226-20801	PIPE HOLDER	1
SS-6111610-SP	SCREW
226-20009	PIPE HOLDER	1
SS-4110615-SP	SCREW
226-19803	VILENE HOLDER	1
SS-4110715-SP	SCREW
226-19605	VILENE	1
226-19001	SUCTION	1
SS-2110930-SP	SCREW
B1851-512-000	FILTER SCREEN	1
B1850-512-000	BUSHING HOLDER	1
SS-4090915-SP	SCREW
NS-6090310-SP	NUT
106-23403	BASE	1
SS-6111610-SP	SCREW
106-23601	OIL ADJUSTING SCREW	1
NS-6110310-SP	NUT
BT-0500300-EA	OIL TUBE	0.12
SQ-1150451-MZ	CONNECTING SCREW	1
SQ-1110401-MZ	CONNECTING SCREW	2
BT-0500300-EA	OIL TUBE	0.04
BT-0500300-EA	OIL TUBE	0.08
BT-0500300-EA	OIL TUBE	0.09
137-65607	OIL CONNEC. ARM	2
BT-0500300-EA	OIL TUBE	0.47
BT-0500300-EA	OIL TUBE	0.4
BT-0500300-EA	OIL TUBE	0.03
BT-0500300-EA	OIL TUBE	0.21
BT-0500300-EA	OIL TUBE	0.15
SQ-1150451-MZ	CONNECTING SCREW	1
B3534-155-000	PLUNGER	1
B1214-038-000	PLUNGER SPRING	1
B3524-552-000	PLUNGER THRUST PLATE	1
SS-4110815-SP	SCREW
139-41307	OIL RETURN FELT PIPE	1
B3538-112-000	CORD HOLDER	1
SS-4110815-SP	SCREW
EA-9500B01-00	CABLE BAND	1
226-86307	OIL GUIDE	1
SS-7090610-SP	SCREW

Page 26 — 12. OIL RESERVOIR & KNEE LIFTER COMPONENTS

Juki LH-3168 (36 pages) parts on page 26
Part number	Part name	Qty
101-62253	OIL RESERVOIR ASM.	1
101-62204	OIL RESERVOIR	(1)
101-62600	RUBBER CUSHION	(2)
110-47107	RUBBER CUSHION	(2)
SS-6700710-SH	SCREW	(1)
RO-0982401-00	RUBBER RING	(1)
110-24007	CONNECTING ROD, VERTICAL	(1)
110-24106	SPRING	(1)
RE-1000000-KO	E-RING	(1)
110-24502	KNEE PRESS LOD BEARING BRACKET	(1)
SS-9182010-SN	SCREW 9/32-20 L=20	(2)
NS-6150430-SR	NUT 15/64-28	(2)
SS-8153010-SR	SCREW 15/64-28 L=30	(2)
SS-9151810-SR	SCREW	(1)
110-24205	KNEE PRESS ROD	(1)
110-23751	KNEE PRESS PLATE ASM.	1
B3431-552-000-A	KNEE PRESS PLATE COVER	(1)
B3419-122-000	KNEE LIFTER PLATE ROD	(1)
110-24403	RUBBER	(1)
110-23702	KNEE PRESS PLATE	(1)
110-23801	KNEE PRESS PLATE HOLDER	(1)
SS-9151540-SR	SCREW 15/64-28 L=15	1
110-24304	KNEE PRESS LIFTER ROD	1
226-22005	OIL RESERVOIR SPACER, A	1
226-22104	OIL RESERVOIR SPACER, B	1

Page 27 — BELT COVER & BOBBIN WINDER COMPONENTS

Juki LH-3168 (36 pages) parts on page 27
Part number	Part name	Qty
226-03401	BELT COVER A ASM.	1
110-76858	BELT COVER B ASM.	1
226-51350	BELT COVER B ASM.	1
110-76809	BELT COVER B	(1)
226-51301	BELT COVER B	(1)
110-76957	BELT COVER, B COVER ASM.	(1)
SS-4111215-SP	SCREW 11/64-40 L=12	2
SS-4121615-SP	SCREW	1
WS-0451040-KP	SPRING WASHER 4.5X8.5X1	3
VP-0501016-SD	WASHER 5X10.5X1	3
SK-3412000-SC	WOOD SCREW D=4.1 L=20	2
VP-0450826-SC	WASHER 4.5X10X0.8	2
110-77567	BOBBIN WINDER COMPL.	1
110-78250	THREAD TENSION BRACKET ASM.	(1)
SS-7110840-SP	SCREW 11/64-40 L=7.8	(1)
B3126-012-B00	THREAD TENSION SPRING	(1)
B3129-012-B00	THREAD TENSION SPRING	(1)
110-72204	TENSION NUT	(1)
SS-7110350-SP	SCREW 11/64-40 L=3	(1)
110-78102	PRESSER PLATE	1
B3211-555-000	RUBBER BRAKE	(1)
110-78003	POSITIONING FINGER	(1)
SD-0490261-SP	HINGE SCREW D=4.9 H=2.6	(1)
SS-7081310-SP	SCREW 1/8-44 L=12.5	2
VP-0450826-SC	WASHER 4.5X10X0.8	2
SK-3412000-SC	WOOD SCREW D=4.1 L=20	2

Page 28 — 14. THREAD STAND COMPONENTS

Juki LH-3168 (36 pages) parts on page 28
Ref	Part number	Part name	Qty
1	226-21551	THREAD STAND ASM.	1
2	B3319-704-L00	THREAD GUIDE	(3)
3	SM-6061610-SC	SCREW M6 L=16	(2)
4	B3318-704-L00-A	THREAD GUIDE ARM JOINT	(2)
5	111-84108	SPOOL REST ROD RUBBER CAP	(1)
6	111-83704	SPOOL REST ROD, UPPER	(1)
7	B3305-704-000-A	SPOOL REST ROD JOINT	(1)
8	NM-6050001-SE	NUT M5X0.8	(2)
9	SM-4051405-SE	SCREW M5X0.8 L=14	(2)
10	111-84009	SPOOL RETAINER	(3)
11	B3320-704-L00-A	SPOOL PIN	(3)
12	B3311-012-000	SPOOL REST CUSHION	(3)
13	111-83902	SPOOL REST	(3)
14	111-83605	SPOOL REST ROD, LOWER	(1)
15	119-57602	THREAD GUIDE ARM. A	(2)
16	B3317-704-000	NUT C15	(2)
17	WP-1702600-SO	WASHER 17X30X2.6	(2)
18	WS-1643202-KR	SPRING WASHER	(1)
19	MA0-11532000	CORD STAPLE	(3)
20	WS-0510002-KN	SPRING WASHER	(3)
21	NH-6050001-SE	NUT M5X0.8	(3)
22	B3310-555-D00	RUBBER WASHER	(1)
23	B3309-704-0A0	THREAD GUIDE ARM ASM.	1

Page 29 — 15. MOTOR PULLEY COMPONENTS

Juki LH-3168 (36 pages) parts on page 29
Ref	Part number	Part name
1	MTL-2200040S	CLUTCH MOTOR
2	MTK-P0070000	MOTOR PULLEY D=70
3	MTK-P0060000	MOTOR PULLEY D=60
4	MTJ-VH00420A	V-BELT, 42 INCH
5	MTJ-VH00410A	V-BELT, 41 INCH
6	MTJ-VH00400A	V-BELT, 40 INCH
7	MTS-P008000	MOTOR PULLEY ASM. 80

Page 30 — 16. TABLE OF EXCHANGING GAUGE PARTS

Juki LH-3168 (36 pages) parts on page 30
Ref	Part number	Part name
B	226-25107	226-30206
C	226-25205	226-30304
D	226-25305	226-30404
E	226-25404	226-30503
F	226-25503	226-30602
G	226-25602	226-30700
H	226-25701	226-30800
K	226-25800	226-30909
L	226-25906	226-31006
M	226-26105	226-31303
N	226-26204	226-31402
Q	226-26402	226-31709
B	226-37656	101-52759
C	226-37854	101-52759
D	226-37953	101-52858
E	226-37953	101-52957
F	226-38050	101-53054
G	226-38258	101-53153
H	226-38357	101-53252
K	226-38456	101-53450
L	226-38753	101-53559
M	226-38852	101-53658
N	226-38951	101-53856
Q	226-39256	101-53856
B	226-60203	226-65103
C	226-60302	226-65202
D	226-60401	226-65301
E	226-60500	226-65400
F	226-60609	226-65509
G	226-60708	226-65707
H	226-60807	226-65806
K	226-60906	226-65905
L	226-61102	226-66200
M	226-61201	226-66309
N	226-61300	226-66408
Q	226-61508	226-66705
C	102-37907	B1402-528-BA0-A
D	102-38004	102-39101
E	102-38103	102-39200
F	102-38202	102-39309
G	102-38301	102-39408
H	102-38400	102-39507
K	102-38509	102-39606
L	102-38707	102-39804
M	102-38806	102-39903
Q	102-39002	101-71304
B	B1402-528-BA0-A	B1402-528-BA0-A
C	B1402-528-CA0-A	B1402-528-CA0-A
D	B1402-528-DAL-A	B1402-528-DAL-A
E	B1402-528-EAL	B1402-528-EAR
F	B1402-528-FAL	B1402-528-FAR
G	B1402-528-GAL	B1402-528-GAR
H	B1402-528-HAL-A	B1402-528-HAR-A
K	B1402-528-KAL-A	B1402-528-KAR-A
L	B1402-528-LAL	B1402-528-LAR
M	B1402-528-MAL	B1402-528-MAR
N	B1402-528-NAL	B1402-528-NAR
Q	B1402-528-QAL	B1402-528-QAR

Juki LH-3168 (36 pages) — parts catalog

Page 1 — PARTS LIST

JUKI 2-Needle, Needle-feed, Lockstitch Machine with Organized Split Needle Bar, and an Automatic Thread Trimmer 二本針本縫送り角縫い付き自動糸切りミシン LH-3168-7 LH-3168(糸切り無) PARTS LIST 29139706 No.0944-00 From the library of: Superior Sewing Machine & Supply jintex.in

Page 2 — HOW TO MAKE USE OF THIS PARTS LIST

HOW TO MAKE USE OF THIS PARTS LIST 1. An asterisk (*) means that the corresponding part is changed from the previous parts list or is newly added. 2. As to "#01" and "#02," refer to the "Note" given at the bottom of the respective pages. 3. Codes on the "Q ty" column: Each numeral indicates the number of parts required. "0.1" and "2.0" indicate the length (in meters) of the respective parts. 4. Parentheses mean that the corresponding part is a subpart that constructs an assembly part. 5. Dotted lines on the Figures indicate assembly parts. パーツリストご利用に際して 1. Note欄に記載されているリストページの*印は、前回の内容に対して、今回変更または追加された部品であることを意味します。 2. リストページの#01、#02等の印は、各ページの“注記”の説明をご参照ください。 3. 数状の数子は、個数を示し、0.1、2.0等の数値は、長さ(単位メートル)を表します。 4. 数状の( )は、粗部品を構成している子部品であることを意味します。 5. イラストページのーーーーーは、構成であることを意味します。 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 3 — CONTENTS

CONTENTS 目次 1. FRAME & MISCELLANEOUS COVER COMPONENTS ...* **Summary:** This page is a table of contents for a sewing machine parts catalog. It lists the different sections of the catalog, such as

Page 4 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS

1. FRAME & MISCELLANEOUS COVER COMPONENTS 頭部・外装関係 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 5

REF.NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 SS-4110815-SP SCREW 11/64-40 L=8 ナベネジ 7 2 106-02902 SLIDE PLATE マトイタ 1 3 101-01004 GASKET マトイタバ 1 4 #01 SS-4110815-SP SCREW 11/64-40 L=8 ナベネジ 1 5 #02 SS-6111140-SP SCREW 11/64-40 L=11 ヒラネジ 1 6 #02 D2112-555-B00 CORD HOLDER, LARGE コートトメ 2 7 #02 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 1 8 #02 110-44054 GROUND WIRE ASM. アースコードクミ 1 9 #02 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 1 10 #02 WT-0530002-KS TOOTHED WASHER ハワクサ A5.3 1 11 102-01200 RUBBER PLUG ヨート 1 12 #01 TA-0490601-RO PLUG D=4.9X5.5 L=6 トメセン D=4.9X5.5 L=6 2 13 TA-1250504-RO RUBBER PLUG トメセン 1 14 TA-1270502-RO RUBBER PLUG トメセン 1 15 TA-0750704-RO RUBBER PLUG トメセン 1 16 SS-6151780-SP SCREW 15/64-28 L=17.0 ヒラネジ 15/64-28 L=17 2 17 226-02007 THREAD TAKE-UP LEVER OIL GUARD テンビンカルー(28°) 1 18 TA-1250504-RO RUBBER PLUG トメセン 1 19 #05 B3523-280-000 OIL TUBE HOLDER ユシンパイプトメ 1 20 226-80250 FACE PLATE ASM. メンイタ(カクハリ)クミ 1 21 SS-4121015-SP SCREW 3/16-28 L=10 ナベネジ 3/16-28 L=10 4 22 TA-1250406-RO RUBBER PLUG トメセン D=12.5 L=4 2 23 110-18702 THREE-HOLE THREAD EYELET ミツメイトカケ 2 24 SS-8120740-SP SCREW 3/16-28 L=7 ナベネジ 3/16-28 L=7 2 25 226-03005 THREAD GUIDE イトアンナイ(ウエ) 1 26 SS-2090710-SP SCREW 9/64-40 L=7 マルサラネジ 9/64-40 L=7 1 27 226-03104 THREAD GUIDE イトアンナイ(ウエ) 1 28 SS-2090810-SP SCREW 9/64-40 L=7.5 マルサラネジ 9/64 L=7.5 1 29 B1131-057-000 FRAME THREAD GUIDE, LOWER イトアンナイシタ 1 30 SS-5090610-SP SCREW 9/64-40 L=6 マルサラネジ 9/64-40 L=6 1 31 B1104-051-000 THROAT PLATE PIN ハリイタトメセン 1 32 226-80003 PLATE アゴブアテ 2 33 SS-9110460-CP SCREW 11/64-40 L=4 ロツカクボルト 11/64-40 L=4 2 34 226-02106 AUXILIARY COVER ホシジヨカバ 1 35 SS-2090710-SP SCREW 9/64-40 L=7 マルサラネジ 9/64-40 L=7 2 36 SS-6090630-SP SCREW 9/64-40 L=6 ヒラネジ 9/64-40 L=6 1 37 SS-2110920-TP SCREW 11/64-40 L=8.5 マルサラネジ 11/64-40 L=8.5 1 38 #03 226-01058 BED SLIDE LEFT, ASM., A スペリイタ(ヒラハリ) Aクミ 1 39 #04 226-50857 BED SLIDE LEFT, ASM., A イトキリスペリイタ(ミキ) Aクミ 1 40 #03 226-25505 THROAT PLATE 1/4 ハリイタ(イトキリハリ) 1/4" (6.4MM) 1 41 #04 226-60609 THROAT PLATE 1/4 イトキリハリイタ(ミキ) A 1 42 #03 226-00555 BED SLIDE RIGHT, ASM., A スペリイタ(ミキ) Aクミ 1 43 #04 226-50352 BED SLIDE RIGHT, ASM., A イトキリスペリイタ(ミキ) Aクミ 1 44 #01 B1110-051-0A0 BED SLIDE ASM. スペリイタクミ 1 45 #02 226-50055 BED SLIDE ASM. スペリイタ(カマエ)クミ(イトキリツキ) 1 46 226-02601 BED SCREW STUD ベットシタ 4 47 #06 226-51459 THREAD GUIDE ASM., E イトアンナイE(クミ)ハリトオサエ 1 48 #07 226-03609 THREAD GUIDE フエルトイトアンナイ 1 49 #07 226-03708 FELT フエルト 1 50 226-03807 LABEL カマキュウシシラベル 1 Note ( 注記 )#01...FOR LH-3168 #01...FOR LH-3168 #02...FOR LH-3168-7 #02...FOR LH-3168-7 #03...EXCHANGING GAUGE PART FOR LH- 3168 (SEE P.27, 28) #03...交換ゲージ部品 (27, 28ページご参照下さい。) #04...EXCHANGING GAUGE PART FOR LH- 3168-7(SEE P.27, 28) #04...交換ゲージ部品 (27, 28ページご参照下さい。) #05...FOR LH-3168-7-WB, -WO, -OB #05...FOR LH-3168-7-WB, -WO, -OB LH-3168-7-WB, -WO, -OB 用 #06...FOR OPTIONAL PART #06...FOR OPTIONAL PART オプション対応 #07...FOR THE DESTINATION #07...FOR THE DESTINATION 仕向地 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 6 — 2. MAIN SHAFT & THREAD TAKE-UP COMPONENTS

2. MAIN SHAFT & THREAD TAKE-UP COMPONENTS 上軸・天秤関係 1 2 3 7 9 56 10 8 13 14 41 12 11 38 37 39 30 15 40 16 31 15 42 16 43 19 20 21 22 24 23 25 26 27 28 29 17 18 32 33 36 35 34 45 From the library of: Superior-Sewing Machine & Supply LLC jintex.in

Page 7

REF.NO NOTE PART NO. DESCRIPTION Qty 1 226-05158 THREAD TAKE-UP LEVER PIN ASM. テンヒンサオエツケクミ (クミ) 1 2 226-05109 THREAD TAKE-UP LEVER PIN テンヒンサオエツケ 1 3 CQ-2020000-00 OIL WICK ユシン (1) 4 CQ-2520000-00 OIL WICK ユシン (0.31) 5 #01 226-80508 THREAD TAKE-UP LEVER テンヒン (コカマ) 1 6 #02 226-92909 THREAD TAKE-UP LEVER テンヒン (コカマ) イトキリツキ 1 7 226-05208 TAKE-UP LEVER THEUST PIN テンヒンヌスライトニジク 1 8 CQ-2520000-00 OIL WICK ユシン 0.03 9 SS-8151150-TP SCREW 15/64-28 L=10.5 トメネジ 15/64-28 L=10.5 2 10 226-06107 NEEDLE BAR CRANK ROD ハリホウクランクロッド (カタハリナシ) 1 11 226-80656 NEEDLE BAR CRANK PIN ASM. ハリホウクランクピン (カタハリツキ) クミ 1 12 CQ-5050000-00 OIL WICK ユシン (0.1) 13 SS-8680540-SP SCREW 9/32-28 L=4.5 トメネジ 9/32-28 L=4.5 1 14 B1202-512-000 MAIN SHAFT BUSHING, FRONT ウワジクブツシング 1 15 B1214-019-000 SPROCKET RING スプロケツトリング 3 16 SS-6661110-SP SCREW 1/4-40 L=11 トメネジ 1/4-40 L=11 4 17 #01 226-04508 HAND WHEEL ハズミク 1 18 #01 SS-8151550-SP SCREW 15/64-28 L=15 トメネジ 15/64-28 L=15 2 19 #02 226-51566 HAND WHEEL ASM. ハズミク (クミ) イトキリ 1 20 226-51558 HAND WHEEL ハズミク (ケツゴウク) イトキリ (1) 21 226-51509 HAND WHEEL ハズミク (イトキリ) (1) 22 M4002-110-000 GENERATOR ROTOR ハツデンローター (1) 23 M4007-110-0AA MAGNET FITTING BASE A ASM. マクネツトトリツケダイ A クミ (1) 24 M4007-110-0AB MAGNET FITTING BASE B ASM. マクネツトトリツケダイ B クミ (1) 25 SS-8151550-SP SCREW 15/64-28 L=15 トメネジ 15/64-28 L=15 (2) 26 SS-6111210-SP SCREW 11/64-40 L=12 ヒラネジ 11/64-40 L=12 (2) 27 VP-0450801-SD WASHER 4.5X10.0X0.8 ヒラザガネ 4.5X10X0.8 (2) 28 #02 110-32265 GENERATOR STARTER ASM. ハツデンキスタータクミ 1 29 #02 106-04809 SCREW ハツデンキステーラトメネジ 2 30 226-04706 テンヒンコウカメテル 1 31 226-04805 FELT ウワジクカメテルフエルト 1 32 226-04656 THRUST COLLAR ASM. ウワジクフエルト (クミ) 1 33 226-04607 THRUST COLLAR ウワジクフエルト (1) 34 SB-1200001-00 BEARING D=20X47 ボールベアリング D=20X47 (1) 35 RO-4372002-00 RUBBER RING Oリング 1 36 SS-8660530-TP SCREW 1/4-40 L=4.5 トメネジ 1/4-40 L=4.5 (2') 37 226-04409 COUNTERWEIGHT サリアイ 1 38 SS-8681650-TP SCREW 9/32-28 L=16 トメネジ 9/32-28 L=16 1 39 SS-7681750-TP SCREW 9/32-28 L=16.5 マルヒラネジ 9/32-28 L=16.5 1 40 SS-8680810-TP SCREW 9/32-28 L=8.0 トメネジ 9/32-28 L=8 1 41 226-04003 MAIN SHAFT ウシク 1 42 226-04102 SPROCKET WHEEL スプロケツト 1 43 226-04300 TIMING BELT タイミングベルト 1 44 226-51608 SPROCKET WHEEL ジタスプロケツト (マル14.72) 1 45 SS-7120760-SP SCREW 3/16-28 L=7.0 トメネジ 3/16-28 L=7 2 Note ( 注記 )#01...FOR LH-3168 LH-3168 用 #02...FOR LH-3168-7 LH-3168-7 用

Page 8 — 3. NEEDLE BAR COMPONENTS

3. NEEDLE BAR COMPONENTS 針棒関係 1 2 2 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 9

REF.NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 226-81100 NEEDLE BAR GUIDE PLATE ハリホウアウター(カクハリサキ) 2 2 SS-6060510 SCREW 3/32-56 L=4.5 ヒラネジ 3/32-56 L=4.5 4 3 CQ-2020000 OIL WICK ユシン 0.1 4 SS-4090415 SCREW 9/64-40 L=4 ナベネジ 9/64-40 L=4 1 5 226-81209 FELT COVER フェルトカバー 1 6 110-02904 ROLLER FELT メンブユリョウチョウセツフエルト 2 7 226-81605 NEEDLE BAR SWIVEL STOPPER ハリホウクワリトメネジ 2 8 226-81704 STOPPER SCREW ハリホウウマ 2 9 B1422-512-000 FELT ハリホー 1 10 226-81001 NEEDLE BAR FRAME ASM. ハリホウウマ(カクハリサキ)ケツコウ 1 11 226-81001 NEEDLE BAR FRAME ハリホウウマ(カクハリサキ) 1 12 226-06602 NEEDLE BAR SHAFT ハリホウウマウジク 1 13 PT-0502700-SO TAPERED PIN テーパーピン (1) 14 #01 226-82157 SLIDE BLOCK スペリコ(クミ) C (1) 15 226-81803 SLIDE BLOCK GUIDE PLATE スペリコ(クミ) (1) 16 SS-4090815-SP SCREW 9/64-40 L=8 ナベネジ 9/64-40 L=8 1 17 226-85903 FELT GUIDE ハリホウウエルトカイト 1 18 VP-0450000-SD WASHER 4.5X8X0.5 ヒラガネ 4.5X8X0.5 1 19 SS-7110710-SP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 1 20 226-86000 NEEDLE BAR OIL SEAL FELT. A ハリホウウエルト A 1 21 226-85804 NEEDLE BAR OIL SEAL PLATE ハリホウウエルトバン 1 22 SS-6060510-TP SCREW 3/32-56 L=4.5 ヒラネジ 3/32-56 L=4.5 1 23 226-86158 NEEDLE OIL SEAL FELT. B (クミ) ユエオホウエルトB (クミ) 2 24 226-81407 NEEDLE BAR STOPPER ハリホウウマストツパー 1 25 226-81506 STOPPER SPRING ハリホウウマストツパーバネ 2 26 226-81308 STOPPER SPRING COVER ハリホウウマストツパーバネカバー 1 27 SS-4080610-SP SCREW 1/8-44 L=6.4 ナベネジ 1/8-44 L=6.4 1 28 #01 B1438-512-BOO WASHER 17.1X28X1.5 ヨードジメダルダガネ T=1.5 1 29 226-07303 BUSHING ハリホウウジククメエメタル 1 30 226-07402 BUSHING ハリホウウジククシロエメタル 1 31 226-07006 REAR ARM ハリホウウコウブウデ 1 32 SS-6152440-SP SCREW 15/64-28 L=23.5 ヒラネジ 15/64-28 L=23.5 1 33 SD-0870601-SP HINGE SCREW D= 8.73 H= 6.0 タンネジ D=8.73 H=6 2 34 NS-6150430-SP NUT 15/64-28 ロサカクナツト 15/64-28 2 35 226-07105 CONNECTING ROD ハリホウウクロツト 1 36 226-07204 DRIVING ARM ハリホウウヨウウデ 1 37 SS-6121610-TP SCREW 3/16-28 L=15.5 ヒラネジ 3/16-28 L=15.5 1 38 226-85150 NEEDLE BAR UNIT, LEFT ハリホウ(ヒタハリ)クミ 1 39 226-85101 NEEDLE BAR ASM., LEFT ハリホウ(ヒタハリ)ケツコウ 1 40 226-85200 NEEDLE BAR, LEFT ハリホウ(ヒタハリ) 1 41 226-85408 SEESAW PLATE シーソーイタ 1 42 B1416-528-000 NEEDLE BAR PIN ハリホウウマ 1 43 B1425-526-000 COLLAR ハネケツケ 1 44 B1402-528-FAL-A NEEDLE CLAMP ASM. 1/4 ハリトメネジ 1/4 クミ 1 45 B1425-526-000 SCREW 1/8-44 L=6 ハリトメネジ 1 46 B1425-526-000 NEEDLE BAR UNIT, LEFT ハリホウメネジ 1 47 226-85366 NEEDLE BAR ASM., LEFT ハリホウ(ヒタハリ)ケツコウ 1 48 226-85358 NEEDLE BAR, RIGHT ハリホウ(ミキ) 1 49 226-85309 SEESAW PLATE シーソーイタ 1 50 226-85200 NEEDLE BAR PIN ハリホウウマ 1 51 226-85408 COLLAR ハネケツケ 1 52 B1416-528-000 SCREW 1/8-44 L=6 ハリトメネジ 1 53 B1425-526-000 NEEDLE CLAMP ASM. 1/4 ハリトメネジ 1/4 クミ 1 54 B1402-528-FAR-A SCREW 1/8-44 L=6 ハリトメネジ 1 55 B1425-526-000 NEEDLE BAR UNIT, LEFT ハリホウメネジ 1 56 MDP-500B140 NEEDLE DPX5 #14 ハリ DPX5 #14 2 57 226-83056 NEEDLE BAR CONNECTION ASM. ハリホウウマ(クミ) 1 58 SS-7060310-SP SCREW 3/32-56 L=3 マルヒラネジ 3/32-56 L=3 1 59 226-83205 RELEASE PIN COVER リリースピンフタ 1 60 226-83304 SPRING リリースピンバネ 1 61 226-83106 RELEASE PIN リリースピン 2 62 226-83809 SPRING ハリホウテツコウバネ 2 63 226-83007 NEEDLE BAR CONNECTION ハリホウウマ 1 64 226-83403 NEEDLE BAR CONNECTION PIN ハリホウウマキピン 2 65 226-84104 SPRING クラツチテコバネ 2 66 SS-6080340-SP SCREW 1/8-44 L=2.9 クラツチストツパーバネサエ 1 67 226-84203 SPRING BRACKET クラツチストツパー(ヒタハリ) 1 68 226-84005 CLUTCH STOPPER, LEFT ハリホウウマ 1 69 226-84005 CLUTCH STOPPER, RIGHT ハリホウウマ(ミキ) 1 70 226-83502 NEEDLE BAR CLUTCH ハリホウウマクラツチ 2 71 226-83700 CLUTCH PIN ハリホウクラツチピン 2 72 226-83601 CLUTCH LEVER クラツチレバー (0.1) 73 CQ-2520000-00 OIL WICK ユシン 1 74 226-84609 NEEDLE BAR CRANK ROD ハリホウクランクロツト (カクハリサキ) 1 75 #01 226-84906 NEEDLE BAR GUIDE BLOCK テンナイカクゴマ (カクハリサキ) C 1 76 226-85705 OIL GUARD RUBBER ユエオゴム(カスハリツキ) 1 Note (注記)#01...SELECTIVE PART 選択部品 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 10 — 4. TENSION POST COMPONENTS

4. TENSION POST COMPONENTS 糸調子関係 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 11

REF. NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 226-89061 THREAD TENSION ASM., S イトチョウシクミカタハリツキ S 1 2 B3128-051-000 THREAD TAKE-UP SPRING, A イトハリバネ (1) 3 106-97605 THREAD TAKE-UP SPRING STUD イトハリバネジク (1) 4 226-18201 THREAD RELEASE PIN, A イトユルミピン (A) (1) 5 226-18300 TENSION RELEASE PIN, B イトユルミピン (B) (1) 6 226-18102 TENSION RELEASE LEVER イトユルミレバー (1) 7 SD-0470281-SP HINGE SCREW D=4.7 H=2.8 ダンネジ D=4.7 H=2.8 (2) 8 NS-6110310-SP NUT 11/64-40 ロツカクナット 11/64-40 (2) 9 226-89053 THREAD TENSION BASE PLATE ASM. イトチョウシダイプレート (1) 10 101-24204 THREAD TENSION POST, A ダイイトチョウシポスト A (1) 11 B3214-047-000 BOBBIN WINDER TENSION DISC イトチョウシサラ (4) 12 #01 110-45101 THREAD TENSION SPRING ダイイトチョウシバネ (2) 13 #02 110-93606 THREAD TENSION SPRING ダイイトチョウシバネ (2) 14 110-72402 THREAD TENSION NUT ダイイトチョウシナツト (2) 15 101-24303 THREAD TENSION POST, B ダイイトチョウシポスト B (1) 16 B3126-012-000 THREAD TENSION DISK イトチョウシサラ (1) 17 B3132-552-000 THREAD TENSION DISK PRESSER イトチョウシサラオサエ (1) 18 #02 B3114-232-000 THREAD TENSION SPRING イトチョウシバネ (2) 19 #03 B3129-012-A00 THREAD TENSION SPRING イトチョウシバネ (2) 20 #04 D3129-555-D00 THREAD TENSION SPRING イトチョウシバネ (2) 21 B3112-704-000 THREAD TENSION BUSHING ハリバネブツシュ (2) 22 119-56802 THREAD TENSION KNOB, BLUE ウツシツマミ(アオ) (2) 23 B3125-012-000 THREAD TENSION NUT イトチョウシナツト (1) 24 B3125-527-000 TAKE-UP SPRING GUIDE ハリバネアンナイガイド (1) 25 B3141-527-000 PRESSER COLLAR イトトリツケカラー (1) 26 SS-7080410-SP SCREW 1/8-44 L=5.5 トメネジ 1/8-44 L=5.5 (1) 27 SS-8080410-TP SCREW 1/8-44 L=3.5 トメネジ 1/8-44 L=3.5 (1) 28 SS-7090520-SP SCREW 9/64-40 L=4.5 マルヒラネジ 9/64-40 L=4.5 (1) 29 B3138-527-000 ADJUSTING PLATE B イトハリバネチョウセイイタ B (1) 30 B3140-527-000 THREAD TENSION POST イトチョウシポスト (1) 31 B3128-527-000 TAKE-UP SPRING GUIDE, B イトハリバネガイド B (1) 32 B3137-527-0AO TAKE-UP SPRING GUIDE ASM. イトハリバネクミ (2) 33 B3139-527-000 COLLAR イトトリツケカラー (1) 34 B3142-527-000 TAKE-UP SPRING GUIDE PLATE イトハリバネガイドプレート (1) 35 B3143-527-000 TAKE-UP SPRING GUIDE STUD イトハリバネガイドジク (1) 36 106-97506 THREAD TENSION BRACKET, A イトチョウシブラケツト(A) (1) 37 SS-4110615-SP SCREW 11/64-40 L=6 ナベコネジ 11/64-40 L=6 (1) 38 WP-0501015-SP WASHER 5X10.5X1 ヒラザガネ 5X10.5X1 (1) 39 WP-0450801-SP WASHER ヒラザガネ (1) 40 B1449-526-000 REPOSITIONING LEVER SPRING ヘンカンレバーバネ (1) 41 226-89103 REPOSITIONING LEVER ヘンカンレバー (1) 42 SD-0601171-SP HINGE SCREW D=6 H=11.7 タンネジ D=6 H=11.7 (1) 43 226-89301 LABEL カタハリラベル (1) 44 226-89202 LEVER PIN SCREW ヘンカンレバーピンネジ (1) 45 NS-6120310-SP NUT 3/16-28 ロツカクナット 3/16-28 (1) 46 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 (2) 47 226-87453 REPOSTINING LEVER ASM. ヘンカンレバークミ (1) 48 SS-6110430-TP SCREW 11/64-40 L=4 ヒラネジ 11/64-40 L=4 (1) 49 SS-7110740-TP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 (1) 50 SS-8110520-TP SCREW 11/64-40 L=4.5 マルヒラネジ 11/64-40 L=4.5 (1) 51 226-87305 REPOSTINING LEVER SHAFT ヘンカンレバーシャフト (1) 52 226-87206 REPOSTINING ARM ヘンカンアーム (1) 53 SS-7111410-TP SCREW 11/64-40 L=14 マルヒラネジ 11/64-40 L=14 (1) 54 SD-0640902-TP HINGE SCREW D=6.35 H=9 タンネジ D=6.35 H=9 (1) 55 226-87503 SPRING (1) 56 226-87701 SPRING SHAFT ヘンカンシャフト (1) 57 RE-0700000-KO SNAP RING 7 Eガタトメワ 7 (2) 58 226-87602 SPRING BASE ヘンカンバネベース (1) 59 SS-4120915-SP SCREW 3/16-28 L=9 ナベネジ 3/16-28 L=9 (2) 60 226-87107 REPOSITIONING PLATE ヘンカンプレート (1) 61 SD-0640241-SP HINGE SCREW D=6.35 H=2.4 タンネジ D=6.35 H=2.4 (1) 62 226-87008 LEAF SPRING (1) 63 SS-9110460-CP SCREW 11/64-40 L=4 (1) Note ( 注記 )#01...FOR TYPE A, S A, S 仕様用 #02...FOR TYPE G G 仕様用 #03...FOR TYPE S S 仕様用 #04...FOR TYPE A A 仕様用 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 12 — 5. HOOK & HOOK DRIVING SHAFT COMPONENTS

5. HOOK & HOOK DRIVING SHAFT COMPONENTS 釜・下軸関係 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 13

REF. NO NOTE PART NO. DESCRIPTION Qty 1 01-08512 HOOK DRIVING SHAFT 1 2 1802-512-0A0-A BUSHING ASM., FRONT 1 3 B1810-510-000 HOOK DRIVING SHAFT, LARGE 2 4 SS-8660530-TP SCREW 1/4-40 L=10.5 8 5 1816-512-000 HOOK DRIVING SHAFT, LARGE 1 6 SS-8660810-TP SCREW 1/4-40 L=8 4 7 SS-8660530-TP SCREW 1/4-40 L=4.5 6 8 26-09804 FEED DRIVING CAM 1 9 1803-515-0A0 BUSHING ASM., INTERMEDIATE 1 10 01-08611 PLUNGER BUSHING 1 11 SS-8151150-SP SCREW 15/64-28 L=10.5 2 12 26-13707 THRUST COLLAR ASM. 2 13 CS-1471012-SP THRUST COLLAR D=14.72 W=10 2 14 1471012-SH THRUST COLLAR D=14.72 W=10 1 15 SS-8660530-TP SCREW 1/4-40 L=4.5 2 16 8917-051-000 BOBBIN 2 17 26-88006 HOOK 2 18 226-88105 TENSION ADJUSTING SPRING 2 19 226-88402 TENSION ADJUSTING SPRING 2 20 01-10500 TENSION SPRING INSTALLING SCRE 2 21 26-88105 BOBBIN CASE 2 22 26-88204 SPRING 2 23 SS-6560150-SH SCREW 3/32-80 L=1.3 2 24 26-12709 BOBBIN GIB 2 25 26-12204 HOOK G18 2 26 01-12803 SCREW 4 27 101-12902 NEEDLE POSITIONER 2 28 01-12902 SCREW 2 29 102-10805 HARD ALUNITE BOBBIN 2 30 01-11508 SPRING 2 31 226-53802 SHEET 2 32 26-93857 HOOK ASM. 2 33 226-88006 HOOK 2 34 226-88402 TENSION ADJUSTING SPRING 2 35 01-10500 TENSION SPRING INSTALLING SCRE 2 36 26-88105 BOBBIN CASE 2 37 26-88204 SPRING 2 38 SS-6560150-SH SCREW 3/32-80 L=1.3 2 39 26-53000 SEVING HOOK 2 40 26-53307 HOOK GIB 2 41 101-12803 SCREW 4 42 101-12902 NEEDLE POSITIONER 2 43 01-12902 SCREW 2 44 102-10805 HARD ALUNITE BOBBIN 2 45 01-11508 SPRING 2 46 SS-606010-SP SCREW 9/64-40 L=7.5 2 47 01-07016-SD WASHER 3.7X8X1 2 48 101-09808 SADDLE INSTALLING BLOCK, UPPER 2 49 01-12407 SADDLE INSTALLING BLOCK, LOWER 2 50 SS-6153040-SP SCREW 15/64-28 L=30 2 51 1820-051-000 BOBBIN CASE OPENING LEVER LINK 2 52 CO-2020000-00 OIL WICK 0.1 53 1821-051-000 CRANK SCREW STUD 2 54 1822-051-000 OPENING LEVER CRANK 2 55 1823-051-000 OIL WICK 0.1 56 B1-610420-00 NUT 11/64-40 2 57 01-2020000-00 OIL WICK 2 58 1823-051-000 OPENING LEVER CRANK PIN 2 59 26-14101 THRUST WASHER, R 2 60 01-11201 THRUST WASHER, F 2 61 226-13251 BUSHING 2 62 CS-13095301-0C NEEDLE GEARING 9.525X9.52 2 63 226-13004 HOOK SHAFT SADDLE, LEFT 1 64 226-13004 HOOK SHAFT SADDLE, LEFT 1 65 226-13505 HOOK SHAFT SADDLE, RIGHT 1 66 226-13505 HOOK SHAFT SADDLE, RIGHT 1 67 SS-9111820-SP SCREW 11/64-40 L=18 2 68 26-15454 RUBBER BUSHING ASM. 2 69 226-15108 GASKET 2 70 226-15009 HOOK SHAFT SADDLE COVER 2 71 226-15306 FELT HOLDER 2 72 226-15207 OIL ADJUSTING BALL 2 73 226-15702 OIL ADJUSTING BALL 2 74 226-15801 PRESSER SPRING 2 75 226-15801 OIL ADJUSTING SCREW 2 76 226-15959 OIL VICK HOLDER ASM. LEFT 2 77 26-26654 OIL VICK HOLDER ASM. RIGHT 2 78 171-26654 OIL VICK HOLDER ASM. RIGHT 2 79 01-0850002-SP WASHER 8.5X18X1.6 2 80 VP-0850002-SP WASHER 8.5X18X1.6 2 81 226-13608 GEAR GUIDE 2 82 226-7110710-SP SCREW 11/64-40 L=7 4 Note ( 注記 ) #01...FOR LH-3168 7 #02...FOR LH-3168 7 #03...SELECTIVE PART FOR LH-3168 7 #04...SELECTIVE PART FOR LH-3168 7 #05...SELECTIVE PART FOR LH-3168-7 7 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 14 — 6. FEED MECHANISM COMPONENTS

6. FEED MECHANISM COMPONENTS 送り関係 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 15

REF. NO NOTE PART NO. DESCRIPTION Qty 1 SS-6090670-TP SCREW 9/64-40 L=6 2 2 226-10109 ROD PIN 1 3 RE-050000-KO E-RING 1 4 226-10208 FEED REGULATOR CONNECTING ROD 1 5 SD-0800422-CP HINGE SCREW D= 8 H= 4.2 1 6 226-10000 FEED REGULATOR 1 7 SS-7121410-SP SCREW 3/16-28 L=14 1 8 226-10307 FEED REGULATOR SPRING 1 9 226-10604 REVERSE FEED SHAFT 1 10 #01 226-52101 REVERSE FEED SHAFT 1 11 CS-102121A-SH THRUST COLLAR ASM. D=10.2 W=12 1 12 SS-8660610-TP SCREW 1/4-40 L=6 (2) 13 101-08009 OIL SEAL 1 14 RE-090000-KO SNAP RING 9.0 1 15 SS-8120740-SP SCREW 3/16-28 L=7 2 16 226-10505 REVERSE FEED CONTROL LEVER 1 17 RO-0922702-00 RUBBER RING 1 18 110-09909 FEED REGULATOR SCREW 1 19 B1148-555-000 SPRING 1 20 110-52701 PIN 1 21 110-71909 FEED DIAL 1 22 SS-6121860-SP SCREW 1 23 226-10406 SPRING BRACKET 2 24 SS-4110815-SP SCREW 11/64-40 L=8 1 25 226-09200 FEED ROCK SHAFT CONNECTING ROD 1 26 226-52002 FEED DRIVE ECCENTRIC CAM 1 27 SS-6661110-SP SCREW 1/4-40 L=11 2 28 SS-7110710-SP SCREW 11/64-40 L=7 2 29 226-09101 CAM COVER 1 30 B1636-581-B00 NEEDLE BEARING B 1 31 B1610-512-000 FEED DRIVING SLIDE BLOCK 1 32 SS-6580752-TP SCREW 1/8-40 L=7 2 33 #02 226-30602 FEED DOG 1/4 1 34 #03 102-38202 FEED DOG 1/4 1 35 226-09754 FEED BAR 1 36 226-09705 FEED BAR FORK 1 37 101-07902 SCREW 15/64-28 L=14 (1) 38 SS-9151440-CP WASHER 6.2X13X1 (1) 39 WP-0621016-SD SNAP RING 5 (1) 40 RE-0500711-KP FEED BAR SHAFT 1 41 B1604-012-000 SCREW 3/16-32 L=6 1 42 SS-8620610-TP FEED ROCK SHAFT 1 43 226-09408 NUT 1/8-44 1 44 NS-6080210-SP SCREW 1/8-44 L=18.0 1 45 SS-6081810-SP FEED ROCKER 2 46 B1603-512-000 SCREW 11/64-40 L=12.8 2 47 SS-7111310-TP BUSHING 1 48 101-06102 SCREW 15/64-28 L=10.5 1 49 SS-8151150-SP THRUST COLLAR ASM. D=14.72 W=12 (2) 50 CS-147121B-SH SCREW 1/4-40 L= 4.5 1 51 SS-8660530-TP THRUST COLLAR D=14.72 W=10 1 52 CS-1471012-SH SCREW 11/64-40 L=8.5 4 53 SS-7110910-SP PLATE 2 54 103-15505 FEED DRIVING ROCKER BLOCK. S 2 55 226-09606 FEED ROCKER SHAFT CRANK 1 56 226-09309 NUT 9/32-28 0.5 57 NS-6680320-SP SCREW 3/16-28 L=15.5 0.3 58 SS-6121610-TP HINGE SCREW D= 9 H= 7 1 59 SD-0900701-TP FEED ROCK CONNECTING ROD 1 60 103-15208 FEED DRIVING ROCKER ASM. 1 61 103-15455 SCREW 11/64-40 L=5 1 62 SS-7110510-SP STOPPER PLATE 2 63 B1633-470-000 SCREW 1/4-40 L= 4.5 1 64 SS-8660530-TP PIN 1 65 B1653-470-000 OIL WICK 1 66 CQ-2520000-00 OIL WICK 1 67 CQ-3030000-00 Note ( 注記 )#01...FOR LH-3168-7-WB, -OB 用 LH-3168-7-WB, -OB 用交換ゲージ部品 #02...EXCHANGING GAUGE PART FOR LH-3168 LH-3168 用交換ゲージ部品 (SEE P.27, 28) (27, 28 ページご参照下さい。) #03...EXCHANGING GAUGE PART FOR LH- LH-3168-7 用交換ゲージ部品 3168-7(SEE P.27, 28) (27, 28 ページご参照下さい。) From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 16 — 7. PRESSER BAR & TENSION RELEASE COMPONENTS

7. PRESSER BAR & TENSION RELEASE COMPONENTS 押さえ棒・糸ゆるめ関係 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 17

REF. NO NOTE PART NO. D E S C R I P T I O N ヒンメイ Qty 1 110-71800 HAND LIFTER オテエアゲレバー 1 2 B1521-055-000 SCREW オテエアゲレバートメネジ 1 3 R0-0371801-00 RUBBER RING 0リング 1 4 110-06756 HAND LIFTER CAM ASM. オテエアゲカムクミ 1 5 226-08152 LIFTING LEVER ROD ASM. ヒラアゲヨコホク(クミ) 1 6 110-06350 HAND LIFTER LINK ヒラアゲリンククミ (1) 7 110-06202 LIFTING LEVER ヒラアゲイタ (1) 8 110-07309 LIFTING LEVER RING ヒラアゲイタ E リング (1) 9 RE-0500000-KO E-RING Eかタトメワ 5 (1) 10 226-08103 LIFTING LEVER CONNECTING ROD ヒラアゲヨコホク (1) 11 110-06509 LINK SHAFT ヒラアゲリンクシツク 2 12 RE-0500000-KO E-RING Eかタトメワ 5 2 13 110-07101 HINGE SCREW ヒラアゲヨコウネシ 1 14 SD-0720332-SP HINGE SCREW D= 7.24 H= 3.3 タツンネジ D= 7.24 H= 3.3 1 15 110-07002 LIFTING LEVER LINK ヒラアゲリンク 1 16 101-25201 CONNECTING ROD, VERTICAL ヒラアゲヨコホク 1 17 SD-0600322-SD HINGE SCREW D=6 H=3.2 タツンネジ D=6 H=3.2 3 18 RE-0500000-KO E-RING Eかタトメワ 5 1 19 110-18207 TENSION RELEASE RETURN SPRING イトユルメイタシバネ 1 20 110-18108 TENSION RELEASE SHAFT イトユルメイタジツク 1 21 #01 226-17104 TENSION RELEASE PLATE サラユルメイタ 1 22 #02 226-54909 TENSION RELEASE PLATE ASM. サラユルメイタ(クミ) (1) 23 226-17104 TENSION RELEASE PLATE サラユルメイタ (1) 24 113-94509 WIRE CABLE ワイヤーケーブル (ケツコウ) (1) 25 226-54909 WIRE TUBE ワイヤーチューブ (1) 26 D3159-555-BOO SET SCREW ワイヤーセツトネジ (1) 27 #02 NS-6620310-SP NUT 3/16-32 ロツカクナツト 3/16-32 2 28 #02 D3164-555-BOO OUTER PRESSER PLATE アウターオサエ 2 29 #02 SS-4110715-SP SCREW 11/64-40 L=7 ナベネジ 11/64-40 L=7 2 30 #02 D3163-555-BOO-A FLEXIBLE TUBE SUPPORT PLATE フレキシブルトリツケダイ 1 31 #02 SS-4111215-SP SCREW 11/64-40 L=12 ナベネジ 11/64-40 L=12 2 32 #02 113-06206 WIRE CABLE HOLDER ワイヤーケーブルアテ 1 33 #02 SS-4110715-SP SCREW 11/64-40 L=7 ナベネジ 11/64-40 L=7 1 34 226-17005 PUSH BAR オシホウバ 1 35 PS-0600502-KP SPRING PIN スプリングピン 1 36 110-71602 PRESSER SPRING REGULATOR オサエチョウセツネジ 1 37 110-71701 NUT オサエチョウセツネジナツト 1 38 B1510-227-000 PRESSER GUIDE BAR オサエアンナイボー 1 39 B1505-227-000-A PRESSER SPRING T オサエチョーセツバネ 1 40 B1501-581-000 PRESSER BAR オサエボー 1 41 226-08004 NEEDLE BAR GUIDE BRACKET ハリボートウキ 1 42 SS-8660810-TP SCREW 1/4-40 L=8 トメネジ 1/4-40 L=8 1 43 B1502-541-000 PRESSER BAR BUSHING, LOWER オサエボーシタメツル 1 44 #03 101-52957 PRESSER FOOT ASM. 1/4" オサエ (2.0) 1/4 クミ 1 45 SS-7090910-TP SCREW 9/64-40 L= 8.5 マルヒラネジ 9/64-40 L=8.5 1 Note ( 注記 )#01...FOR LH-3168 LH-3168 用 #02...FOR LH-3168-7 LH-3168-7 用 #03...EXCHANGING GAUGE PART 交換ゲージ部品 (SEE P.27, 28) ( 27, 28ページご参照下さい。) From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 18 — 8. THREAD TRIMMER MECHANISM COMPONENTS (FOR LH-3168-7)

8. THREAD TRIMMER MECHANISM COMPONENTS (FOR LH-3168-7) 糸切り装置関係 (LH-3168-7 用) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 19

REF.NO NOTE PART NO. DESCRIPTION HIN MEI Qty -------------------------------------------------------------------------------- 1 SS-2080810-SP SCREW 1/8-44 L=7.5 4 2 102-11605 MOVING KNIFE 2 3 101-16051 MOVING KNIFE SHAFT ASM. 2 4 226-54255 MOVING KNIFE SUPPORT ASM. 2 5 226-54206 MOVING KNIFE SUPPORT PLATE (2) 6 102-11407 THREAD PRESSER ADJUSTING PLATE (2) 7 SS-8080610-SP SCREW 1/8-44 L=5.5 (2) 8 SS-9080410-SP SCREW 1/8-44 L=4.3 (2) 9 SS-5090610-SP SCREW 9/64-40 L=6 4 10 226-55401 THREAD PRESSER 2 11 226-55302 COUNTER KNIFE (2) 12 SS-7090710-SP SCREW 9/64-40 L=6.8 (2) 13 SS-6121212-TP SCREW 3/16-28 L=12.0 1 14 226-54800 GUIDE PLATE 1 15 101-16804 SHAFT 1 16 SS-7151610-SP SCREW 15/64-28 L=16 2 17 B3418-180-000 SPRING 1 18 101-17208 TENSION DISC RELEASE PLATE 1 19 SD-0600271-SP SCREW D= 6 H= 2.7 1 20 226-55153 HINGE INSTALLING BASE ASM. (1) 21 SS-8111010-TP SCREW 11/64-40 L=9.5 (1) 22 226-55104 TENSION DISC RELEASE ARM (1) 23 101-16606 LINK INSTALLING BASE (1) 24 101-17109 BUSHING (1) 25 PS-0300201-KP SPRING PIN 3.0X20 (1) 26 226-54701 STOPPER PLATE 1 27 SS-2110920-SP SCREW 11/64-40 L=8.5 1 28 SS-2110930-SP SCREW 11/64-40 L=8.7 1 29 CS-1470710-SH THRUST COLLAR ASM. D=14.72 W=7 (2) 30 SS-8110410-TP SCREW 11/64-40 L=3.5 1 31 226-54107 THREAD TRIMMER CAM 2 32 SS-8660810-TP SCREW 1/4-40 L=8 2 33 CS-070081B-SH THRUST COLLAR ASM. D=7 W=8 2 34 SS-8110510-SP SCREW 11/64-40 L=5 1 35 101-16903 SPRING 1 36 B1853-512-000C HOOK SHAFT WASHER, C 1 37 101-16754 CAM INSTALLING LINK ASM. 1 38 SS-612220-SP SCREW 15/64-28 L=11.5 (1) 39 D2430-555-B00 SNAP RING (1) 40 101-16705 CAM INSTALLING LINK (1) 41 D2428-555-B00-A CAM ROLLER (1) 42 D2427-555-B00 CAM ROLLER (1) 43 NM-6050001-SP NUT M5 2 44 226-54404 DRIVING ARM, LEFT 1 45 SS-6121610-TP SCREW 3/16-28 L=15.5 1 46 B1515-051-000 HAND LIFTER PIN 2 47 226-54504 CONNECTING LINK ASM. 1 48 226-54503 CONNECTING LINK, A (1) 49 226-54602 CONNECTING LINK, B (1) 50 SS-9111010-SP SCREW 11/64-40 L=9.5 (2) 51 VP-0501016-SD WASHER 5X10.5X1 (2) 52 SD-0650305-TP SCREW D=6.5 H= 3 (2) 53 226-54305 SPRING 1 54 SS-6121610-TP SCREW 3/16-28 L=15.5 1 55 101-17851 SOLENOID ASM. 1 56 HK-0346400-OB PIN CONTACT 2 57 HK-0346101-40 HOUSING 14P 1 58 SS-6151040-SP SCREW 15/64-28 L=10 2 59 B3041-980-000 SPRING 1 60 226-55005 JOINT ROD 1 61 226-54008 DRIVING ARM PLATE 1 62 B3417-051-000 REAR LIFTING BAR ROLLER 1 63 SS-6120940-SP SCREW 3/16-28 L=9 1 64 WP-0501016-SD WASHER 5X10.5X1 1 65 EA-9500B01-00 CABLE BAND 2 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 20 — 9. AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)

9. AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7) 自動逆送り関係 (LH-3168-7 用) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 21

REF.NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 226-56557 REVERSE FEED SWITCH ASM. ギヤウクリスツイツチ(クミ) (1) 2 110-72501 REVERSE FEED SWITCH COVER ギヤウクリスツイツチカバ- (1) 3 SS-4110615-SP SCREW 11/64-40 L=6 ナベコネジ (1) 4 226-56508 REVERSE FEED SWITCH BASE ギヤウクリスツイツチダィ (1) 5 111-02100 REVERSE FEED SWITCH SHAFT ギヤウクリスツイツチジク (1) 6 111-02209 REVERSE FEED SWITCH SPRING ギヤウクリスツイツチバネ (1) 7 SS-4111815-SP SCREW ギヤウクリネジ 11/64-40 L=18 (1) 8 SM-4031501-SC SCREW ナベネジ (2) 9 HW-5000700-00 2-CORE CABTYRE CORD 2シン (1.4) 10 HA-0019000-00 MICROSWITCH マイクロスイツチ (1) 11 111-02308 REVERSE FEED SWITCH PLATE ギヤウクリスツイツチメイツ (1) 12 226-56607 REVERSE FEED SWITCH LEVER ギヤウクリスツイツチレバ- (1) 13 HK-0346400-0B PIN CONTACT ピンコンタクト 4 14 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 2 15 WP-7110710-SP SCREW 11/64-40 L=7 マルヒラネジ 11/64-40 L=7 4 16 WP-0501016-SD WASHER 5X10.5X1 ヒラガネ 5X10.5X1 4 17 101-61305 SOLENOID COVER メツトカバ- 1 18 101-19105 REVERSE FEED SOLENOID, AC24V ギヤウクリマクネツト 24V 1 19 101-19204 SOLENOID INSTALLING PLATE マクネツトトリツケダイ 1 20 WP-0501016-SD WASHER 5X10.5X1 ヒラガネ 5X10.5X1 4 21 SS-9111010-SP SCREW 11/64-40 L=9.5 ロツカクボルト 11/64-40 L=9.5 4 22 D2464-555-B00 LINK DRIVING MAGNET PIN マクネツトリソクピン 1 23 RE-0400000-KO E-SHAPED SNAP RING (4MM) エトメツワ 4 1 24 SS-7151510-XP SCREW 15/64-28 L=12 マルヒラネジ 15/64-28 L=12 2 25 WS-0631510-XP SPRING WASHER ハネガネ 2 26 WP-0621016-SD WASHER 6.2X13X1 ヒラガネ 6.2X13X1 2 27 226-56409 LINK FULCULUM Lリンクシテン 1 28 226-56300 REVERSE FEED LINK, L ジヤクリLリンク 1 29 SS-4153015-SP PAN-SCREW 15/64-28 L=30 ナベネジ 15/64-28 L=30 1 30 WS-0610002-KP SPRING WASHER ハネガネ 1 31 226-56201 WASHER 6.1X18.5X2 ヒラガネ 6.1X18.5X2 1 32 226-56102 REVERSE FEED LINK, (2) ジヤクリリンク(2) 1 33 226-56102 REVERSE FEED LINK, (1) ジヤクリリンク(1) 1 34 SD-0640326-TP HINGE SCREW タンネジ 2 35 NS-6110350-SP NUT 11/64-40 ロツカクナット 11/64-40 2 36 SS-7120760-SP SCREW 3/16-28 L=7.0 マルヒラネジ 3/16-28 L=7 1 37 111-00500 REVERSE FEED LEVER STOPPER レバ-ストツパ- 1 38 SS-6121840-SP SCREW 3/16-28 L=18.0 ヒラネジ 3/16-28 L=18 1 39 B1506-352-000 TENSION SPRING RACK B ヒサツリハネガネ B 1 40 135-15606 SPRING イトキリハネ 1 41 226-56003 SPRING SUSPENSION レバ-ハネガネ 1 42 SS-4120615-SP SCREW 3/16-28 L=6 ナベネジ 3/16-28 L=6 1 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 22 — 10. WIPER MECHANISM COMPONENTS (FOR LH-3168-7)

10. WIPER MECHANISM COMPONENTS (FOR LH-3168-7) ワイパー装置関係 (LH-3168-7 用) 1 2 3 4 25 5 6 7 26 13 14 12 11 10 9 8 15 21 23 22 16 17 18 19 20 24 27 28 30 29 31 32 34 33 34 33 35 36 37 38 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 23

REF.NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 226-57159 VIPER SOLENOID ASM. ワイヤ-ソルノイド (クミ) 1 2 110-72709 VIPER COVER ワイヤ-カバ- (1) 3 SM-4030601-SN SCREW M3 X 6 ナベコネジ M3X0.5 L=6 (1) 4 VP-0320501-SC WASHER M3 ヒラコネジ 3.2X7X0.5 (1) 5 SD-0650321-TP HINGE SCREW ダンネジ (1) 6 226-57209 VIPER LINK, A ワイヤ-リンク A (1) 7 B2024-771-000 SUSPENSION SCREW ウワイトネジ (1) 8 111-10707 VIPER HINGE SCREW COLLAR ワイヤ-ダンネジカラー (1) 9 226-57308 VIPER SPRING ワイヤ-バネ (1) 10 NS-6110310-SP NUT 11/64-40 ロツカツト 11/64-40 (1) 11 111-10400 VIPER RUBBER A ワイヤ-ゴム A (1) 12 111-10509 VIPER RUBBER B ワイヤ-ゴム B (1) 13 111-10301 VIPER SOLENOID ワイヤ-ソルノイド (1) 14 111-11705 VIPER SOLENOID PIN ワイヤ-ソルノイドシン (1) 15 HA-0000900-00 POWER SWITCH デンスイッチ (1) 16 Hw-2003900-00 ELECTRIC WIRE ヒニ-ンデンスセン 17-0.16 シロ (0.1) 17 Hw-5000700-00 2-CORE CABTYRE CORD 2シンキャブタイヤコート (1.4) 18 226-57100 VIPER SOLENOID BASE ワイヤ-ソルノイドベース (1) 19 WS-0310002-KR SPRING WASHER 3.1X5.9X1.4 ハネコネジ 3.1X5.9X0.7 (3) 20 SM-4030601-SN SCREW M3 X 6 ナベコネジ M3X0.5 L=6 (3) 21 111-11804 VIPER LINK COLLAR ワイヤ-リンクカラー (1) 22 CS-0300711-SP THRUST COLLAR スラストカラー (1) 23 SS-6080320-SP SCREW 1/8-44 L= 2.5 ヒラネジ 1/8-44 L=2.5 (2) 24 HK-0346400-OB PIN CONTACT ピンコンタクト 2 25 SS-4120615-SP SCREW 3/16-28 L=6 ピンネジ 3/16-28 L=6 1 26 NS-6090310-SP NUT 9/64-40 ロツカツト 9/64-40 1 27 SD-0500404-SP HINGE SCREW ダンネジ 1 28 226-57050 VIPER LINK ASM., 2 ワイヤ-リンク(2) (クミ) 1 29 102-08551 VIPER BASE ASM. ワイヤ-ベースクミ 1 30 SS-9111010-SP SCREW 11/64-40 L=9.5 ロツカツト 11/64-40 L=9.5 2 31 RE-0320000-KO SNAP RING 3.2 Eナトメワ 3.2 2 32 102-08700 VIPER LINK SHAFT ワイヤ-リンクシヤフト 1 33 SS-3090520-SP SCREW 9/64-40 L=4.5 マルネジ 9/64-40 L=4.5 2 34 WP-0371016-SD WASHER 3.7X8X1 ヒラコネジ 3.7X8X1 2 35 #01 102-09203 VIPER 3/32"-3/8" ワイヤ- 1 36 #01 102-09500 VIPER ワイヤ- 1 37 #01 102-09807 VIPER ワイヤ- 1 38 #01 102-09906 VIPER ワイヤ- 1 Note ( 注記 ) #01...SELECTIVE PART 選択部品 From the library of: Superior-Sewing Machine & Supply LLC jintex.in

Page 24 — 11. LUBRICATION COMPONENTS

11. LUBRICATION COMPONENTS 給油関係 60 59 9 10 20 19 22 17 21 1 15 18 2 3 12 16 14 6 4 5 11 7 13 23 24 25 26 46 45 39 40 42 43 44 47 41 35 28 29 30 31 32 33 36 37 38 49 50 48 56 57 51 52 53 54 58 From the library of: Superior-Sewing Machine & Supply LLC jintex.in

Page 25

REF.NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 B3530-555-000 OIL SIGHT WINDOW アフタマト 1 2 RO-1952401-00 RUBBER RING Oリング 1 3 SS-4111815-SP SCREW ナベネジ 11/64-40 L=18 2 4 102-16703 OIL TANK オイルタンク 1 5 NS-6110310-SN NUT 11/64-40 ロツカナット 11/64-40 2 6 226-20355 OIL PIPE ASM. メンブパイプ (クミ) 1 7 226-20454 FELT ASM. カンリユウフエルト(クミ) 1 8 226-20702 OIL TUBE キユウユウカン 1 9 226-20108 PIPE HOLDER, B カンリユウパイプオオエ B 1 10 SS-4110715-SP SCREW 11/64-40 L=7 ナベネジ 11/64-40 L=7 1 11 226-19209 OIL WICK GUIDE メンブジユシンガイド 1 12 SS-6121610-SP SCREW 3/16-28 L=15.5 ヒラネジ 3/16-28 L=15.5 1 13 NS-6120310-SP NUT 3/16-28 ロツカナット 3/16-28 1 14 226-20504 OIL WICK HOLDER メンブジユシンホルーダー 1 15 SS-4111215-SP SCREW 11/64-40 L=12 ナベネジ 11/64-40 L=12 1 16 NS-6110430-SP NUT 11/64-40 ロツカナット 11/64-40 1 17 226-19308 OIL ADJUSTING FELT メンブジユシンフエルト 1 18 226-19407 OIL ADJUSTING SHAFT ユリヨウジユシンジヤフト 1 19 SS-8701782-TP SCREW 5/16-24 L=17.0 トメネジ 5/16-24 L=17 1 20 NS-6700420-SP NUT 5/16-24 ロツカナット 5/16-24 1 21 226-20801 PIPE HOLDER キユウユウカンオサエ 1 22 SS-6111610-SP SCREW 11/64-40 L=16 ヒラネジ 11/64-40 L=16 1 23 226-20009 PIPE HOLDER メンブジユシンパイプオサエ 1 24 SS-4110615-SP SCREW 11/64-40 L=6 ナベコネジ 11/64-40 L=6 1 25 226-19803 VILENE HOLDER カンリユウイリ-ン 1 26 SS-4110715-SP SCREW 11/64-40 L=7 ナベネジ 11/64-40 L=7 1 27 226-19605 VILENE カンリユウイリ-ン 1 28 226-19001 SUCTION キユウユウ 1 29 SS-2110930-SP SCREW 11/64-40 L=8.75 マルチラネジ 11/64-40 L=8.75 1 30 B1851-512-000 FILTER SCREEN キユウユウアミ 1 31 B1850-512-000 BUSHING HOLDER キユユースホルーダー 1 32 SS-4090915-SP SCREW 9/64-40 L=9 ナベネジ 9/64-40 L=9 1 33 NS-6090310-SP NUT 9/64-40 ロツカナット 9/64-40 1 34 106-23403 BASE アフタパイタン 1 35 SS-6111610-SP SCREW 11/64-40 L=16 ヒラネジ 11/64-40 L=16 2 36 106-23601 OIL ADJUSTING SCREW ユリヨウジユシンネジ 1 37 NS-6110310-SP NUT 11/64-40 ロツカナット 11/64-40 1 38 BT-0500300-EA OIL TUBE チユーブ 0.12 39 SQ-1150451-MZ CONNECTING SCREW チユーブレンケツネジ 1 40 SQ-1110401-MZ CONNECTING SCREW チユーブレンケツネジ 2 41 BT-0500300-EA OIL TUBE チユーブ 0.04 42 BT-0500300-EA OIL TUBE チユーブ 0.08 43 BT-0500300-EA OIL TUBE チユーブ 0.09 44 137-65607 OIL CONNEC. ARM キユウユウサテ 2 45 BT-0500300-EA OIL TUBE チユーブ 0.47 46 BT-0500300-EA OIL TUBE チユーブ 0.4 47 BT-0500300-EA OIL TUBE チユーブ 0.03 48 BT-0500300-EA OIL TUBE チユーブ 0.21 49 BT-0500300-EA OIL TUBE チユーブ 0.15 50 SQ-1150451-MZ CONNECTING SCREW チユーブレンケツネジ 1 51 B3534-155-000 PLUNGER プランジヤ 1 52 B1214-038-000 PLUNGER SPRING プランジヤスプリング 1 53 B3524-552-000 PLUNGER THRUST PLATE プランジヤスラスト 1 54 SS-4110815-SP SCREW 11/64-40 L=8 ナベネジ 11/64-40 L=8 1 55 139-41307 OIL RETURN FELT PIPE カンリユウフエルトパイプ 1 56 B3538-112-000 CORD HOLDER コ-トホルーダー 1 57 SS-4110815-SP SCREW 11/64-40 L=8 ナベネジ 11/64-40 L=8 1 58 EA-9500B01-00 CABLE BAND シユセンバンド 1 59 226-86307 OIL GUIDE メンブジユシンガイド 1 60 SS-7090610-SP SCREW 9/64-40 L=6 マルチラネジ 9/64-40 L=6 1 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 26 — 12. OIL RESERVOIR & KNEE LIFTER COMPONENTS

12. OIL RESERVOIR & KNEE LIFTER COMPONENTS 油潤・膝上げ関係 23- 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 24 25 DESCRIPTION REF.NO NOTE PART NO. 101-62253 101-62204 101-62600 110-47107 SS-6700710-SH RO-0982401-00 110-24007 110-24106 RE-1000000-KO 110-24502 SS-9182010-SN NS-6150430-SR SS-8153010-SR SS-9151810-SR 110-24205 110-23751 B3431-552-000-A B3419-122-000 110-24403 110-23702 110-23801 SS-9151540-SR 110-24304 226-22005 226-22104 OIL RESERVOIR ASM. OIL RESERVOIR RUBBER CUSHION RUBBER CUSHION SCREW RUBBER RING CONNECTING ROD, VERTICAL SPRING E-RING KNEE PRESS LOD BEARING BRACKET SCREW 9/32-20 L=20 NUT 15/64-28 SCREW 15/64-28 L=30 SCREW KNEE PRESS ROD KNEE PRESS PLATE ASM. KNEE PRESS PLATE COVER KNEE LIFTER PLATE ROD RUBBER KNEE PRESS PLATE KNEE PRESS PLATE HOLDER SCREW 15/64-28 L=15 KNEE PRESS LIFTER ROD OIL RESERVOIR SPACER, A OIL RESERVOIR SPACER, B ヒンメイアブラタ(クミ) アブラタトウブサエゴムトウブサエゴムヒラネジ Oリングヒザアゲカイテンウデヒザアゲスプリング E-リングヒザアゲドウシトリツケウデロツカクボルト 9/32-20 L=20 ロツカクナット 15/64-28 トメネジ 15/64-28 L=30 ロツカクボルトヒザアゲロツドヒザアゲプレートアスヒザアゲプレートカバーヒザアゲプレートロツドゴムヒザアゲプレートヒザアゲプレートホルダロツカクボルト 15/64-28 L=15 ヒザアゲリフターロツドアブラタマリガ A アブラタマリガ B Qty 1 (1) (2) (2) (1) (1) (1) (1) (1) (1) (2) (2) (2) (1) (1) 1 (1) (1) (1) (1) (1) 1 1 From the library of: Superb-Sewing Machine & Supply LLC jintex.in

Page 27 — BELT COVER & BOBBIN WINDER COMPONENTS

13. BELT COVER & BOBBIN WINDER COMPONENTS ベルトカバー・糸巻き装置関係 REF.NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 226-03401 BELT COVER A ASM. ベルトカバー A 1 2 #01 110-76858 BELT COVER B ASM. ベルトカバー B ケツゴウ 1 3 #02 226-51350 BELT COVER B ASM. ベルトカバー B (イトキリツキ) クミ 1 4 #01 110-76809 BELT COVER B ベルトカバー B (イトキリツキ) (1) 5 #02 226-51301 BELT COVER B ベルトカバー B (1) 6 110-76957 BELT COVER, B COVER ASM. ベルトカバー, B フタクミ (1) 7 SS-4111215-SP SCREW 11/64-40 L=12 ナベネジ 2 8 SS-4121615-SP SCREW ナベネジ 1 9 WS-0451040-KP SPRING WASHER 4.5X8.5X1 ハネジナガメ 3 10 VP-0501016-SD WASHER 5X10.5X1 ヒラダガネ 3 11 SK-3412000-SC WOOD SCREW D=4.1 L=20 マルモクネジ 2 12 VP-0450826-SC WASHER 4.5X10X0.8 ヒラダガネ 2 13 110-77567 BOBBIN WINDER COMPL. イトマキソウチクミ 1 14 110-78250 THREAD TENSION BRACKET ASM. イトマキイトチョウシブラケットクミ (1) 15 SS-7110840-SP SCREW 11/64-40 L=7.8 マルヒラネジ 11/64-40 L=7.8 (1) 16 B3126-012-B00 THREAD TENSION SPRING イトチョウシバネ (1) 17 B3129-012-B00 THREAD TENSION SPRING イトチョウシバネ (1) 18 110-72204 TENSION NUT イトチョウシナット (1) 19 SS-7110350-SP SCREW 11/64-40 L=3 マルヒラネジ 11/64-40 L=3.5 (1) 20 110-78102 PRESSER PLATE セイトウコﾞム 1 21 B3211-555-000 RUBBER BRAKE ラハ゛ーフ゛レーキ (1) 22 110-78003 POSITIONING FINGER オヒ゛ンオサエ (1) 23 SD-0490261-SP HINGE SCREW D=4.9 H=2.6 ダンネジ D=4.9 H=2.6 (1) 24 SS-7081310-SP SCREW 1/8-44 L=12.5 マルヒラネジ 1/8-44 L=12.5 2 25 VP-0450826-SC WASHER 4.5X10X0.8 ヒラダガネ 2 26 SK-3412000-SC WOOD SCREW D=4.1 L=20 マルモクネジ D=4.1 L=20 2 Note ( 注記 )#01...FOR LH-3168 LH-3168 用 #02...FOR LH-3168-7 LH-3168-7 用 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 28 — 14. THREAD STAND COMPONENTS

14. THREAD STAND COMPONENTS 糸立装置関係 REF.NO NOTE PART NO. DESCRIPTION ヒンメイ Qty 1 226-21551 THREAD STAND ASM. イトタツチ(クミ) 1 2 B3319-704-L00 THREAD GUIDE イトミチ (3) 3 SM-6061610-SC SCREW M6 L=16 ヒラコネジ M6 L=15 (2) 4 B3318-704-L00-A THREAD GUIDE ARM JOINT イトタツチシメカクナク (2) 5 111-84108 SPOOL REST ROD RUBBER CAP イトタツボウホコゴム (1) 6 111-83704 SPOOL REST ROD, UPPER イトタツボウ (ウエ) (1) 7 B3305-704-000-A SPOOL REST ROD JOINT イトタツボウーッギテ (1) 8 NM-6050001-SE NUT M5X0.8 ロツカクナット M5X0.8 1シュ (2) 9 SM-4051405-SE SCREW M5X0.8 L=14 ロツカクネジ M5X0.8 L=14 (2) 10 111-84009 SPOOL RETAINER イトマキフレートメ (3) 11 B3320-704-L00-A SPOOL PIN イトマキウケ (3) 12 B3311-012-000 SPOOL REST CUSHION イトマキウケテ (3) 13 111-83902 SPOOL REST イトマキウケテラ (3) 14 111-83605 SPOOL REST ROD, LOWER イトタツボウ (シタ) (1) 15 119-57602 THREAD GUIDE ARM. A イトタツチアーム (A) (2) 16 B3317-704-000 NUT C15 イトタツチナツト (2) 17 WP-1702600-SO WASHER 17X30X2.6 ヒラワッシャー 17X30X2.6 (2) 18 WS-1643202-KR SPRING WASHER バネワッシャー 16.4X26.6X3.2 (1) 19 MA0-11532000 CORD STAPLE コードステツプル (3) 20 WS-0510002-KN SPRING WASHER バネワッシャー 5.1X9.2X1.3 (3) 21 NH-6050001-SE NUT M5X0.8 ロツカクナット M5X0.8 1シュ (3) 22 B3310-555-D00 RUBBER WASHER イトボウーホーシンゴム (1) 23 B3309-704-0A0 THREAD GUIDE ARM ASM. イトアンナイウデクミ 1 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 29 — 15. MOTOR PULLEY COMPONENTS

15. MOTOR PULLEY COMPONENTS モータープーリー関係 4.5 2.3 6 7 D E S C R I P T I O N ヒンメイ Qty REF.NO NOTE PART NO. 1 #01 MTL-2200040S CLUTCH MOTOR モータクミ (サンソークラッチ) 1 2 #02 MTK-P0070000 MOTOR PULLEY D=70 モータプーリー P.D.C 70 1 3 #03 MTK-P0060000 MOTOR PULLEY D=60 モータプーリー D=60 1 4 #02 MTJ-VH00420A V-BELT, 42 INCH V-ベルト 42インチ 1 5 #03 MTJ-VH00410A V-BELT, 41 INCH V-ベルト 1 6 #04 MTJ-VH00400A V-BELT, 40 INCH V-ベルト 1 7 #04 MTS-P008000 MOTOR PULLEY ASM. 80 モータプーリークミ 80 1 Note (注記) #01...FOR LH-3168 #02...FOR LH-3168 (50HZ) #03...FOR LH-3168 (60HZ) #04...FOR LH-3168-7 LH-3168 用 LH-3168 (50HZ) 用 LH-3168 (60HZ) 用 LH-3168-7 用 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 30 — 16. TABLE OF EXCHANGING GAUGE PARTS

16. TABLE OF EXCHANGING GAUGE PARTS 交換ゲージ部品一覧表 Needle gauge size 針幅 Throat plate 針板 Feed Dog 送り Presser foot asm. 押え (組) Code コード inch mm $1.4 $1.9 $2.2 (Tip-divided) (棒先式分れ) B 32 226-25107 226-30206 226-37656 C 44 226-25205 226-30304 B1613-512-DOH 226-37854 101-52759 226-40353 D 48 226-25305 226-30404 B1613-512-E0H 226-37953 101-52858 226-40452 E 56 226-25404 226-30503 B1613-512-F0H 226-37953 101-52957 226-40551 F 64 226-25503 226-30602 B1613-512-G0H 226-38050 101-53054 226-40759 G 71 226-25602 226-30700 B1613-512-H0H 226-38258 101-53153 226-40858 H 79 226-25701 226-30800 B1613-512-10H 226-38357 101-53252 226-40957 K 95 226-25800 226-30909 B1613-512-K0H 226-38456 101-53450 226-41252 L 127 226-25906 226-31006 B1613-512-L0H 226-38753 101-53559 226-41351 M 159 226-26105 226-31303 B1613-512-M0H 226-38852 101-53658 226-41450 N 191 226-26204 226-31402 B1613-512-N0H 226-38951 101-53856 226-41757 Q 254 226-26402 226-31709 B1613-512-Q0H 226-39256 101-53856 226-41757 Stitch spec. S Spec. common 仕上共通仕上仕様 A G Needle gauge size Throat plate (with Thread Trimmer) Feed dog (with Thread Trimmer) 送り (糸切付) Needle clamp asm. Left 針棒 (組)左 Needle clamp asm. Right 針棒 (組)右針幅 Code コード inch mm B 32 226-60203 226-65103 B1402-528-BA0-A B1402-528-BA0-A C 44 226-60302 226-65202 102-37907 B1402-528-CA0-A B1402-528-CA0-A D 48 226-60401 226-65301 102-38004 102-39101 B1402-528-DAL-A B1402-528-DAL-A E 56 226-60500 226-65400 102-38103 102-39200 B1402-528-EAL B1402-528-EAR F 64 226-60609 226-65509 102-38202 102-39309 B1402-528-FAL B1402-528-FAR G 71 226-60708 226-65707 102-38301 102-39408 B1402-528-GAL B1402-528-GAR H 79 226-60807 226-65806 102-38400 102-39507 B1402-528-HAL-A B1402-528-HAR-A K 95 226-60906 226-65905 102-38509 102-39606 B1402-528-KAL-A B1402-528-KAR-A L 127 226-61102 226-66200 102-38707 102-39804 B1402-528-LAL B1402-528-LAR M 159 226-61201 226-66309 102-38806 102-39903 B1402-528-MAL B1402-528-MAR N 191 226-61300 226-66408 102-38905 102-39903 B1402-528-NAL B1402-528-NAR Q 254 226-61508 226-66705 102-39002 101-71304 B1402-528-QAL B1402-528-QAR Stitch spec. Spec. common 仕上仕様仕上共通 Spec. common 仕上共通 Standard spec. 標準仕様 Substandard spec. 標準仕様 Special order 特別注文 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 35

jintex.in From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 36

JUKI JUKI 株式会社〒182 東京都調布市国領町8-2-1 TEL. 03-3480-1111(代表) 工業製品販売部 TEL. 03-3480-1113(ダイヤルイン) お買い求め、ご相談は To order or for further information, please contact : * このパーツリストは商品改良のため予告なく変更する事があります。 * The description covered in this parts list is subject to change for improvement of the commodity without notice. * このパーツリストは、1993年10月現在の商品仕様で編集・印刷したものです。 * This parts list is edited and printed in accordance with the product specifications as of October 1993. JUKI CORPORATION HEAD OFFICE 8-2-1, KOKURYO-CHO, CHOFU-CITY, TOKYO 182, JAPAN BUSINESS OFFICE 1-23-3, KABUKI-CHO, SHINJUKU-KU, TOKYO 160, JAPAN PHONE : 03(3205)1188, 1189, 1190 FAX : 03(3203)8260, (3205)9131 TELEX : J22967, 232-2391 jintex.in

Page 3 — CONTENTS

Page 4 — 1. FRAME & MISCELLANEOUS COVER COMPONENTS

Page 5

Page 6 — 2. MAIN SHAFT & THREAD TAKE-UP COMPONENTS

Page 7

Page 8 — 3. NEEDLE BAR COMPONENTS

Page 9

Page 10 — 4. TENSION POST COMPONENTS

Page 11

Page 12 — 5. HOOK & HOOK DRIVING SHAFT COMPONENTS

Page 13

Page 14 — 6. FEED MECHANISM COMPONENTS

Page 15

Page 16 — 7. PRESSER BAR & TENSION RELEASE COMPONENTS

Page 17

Page 18 — 8. THREAD TRIMMER MECHANISM COMPONENTS (FOR LH-3168-7)

Page 19

Page 20 — 9. AUTOMATIC REVERSE FEED MECHANISM COMPONENTS (FOR LH-3168-7)

Page 21

Page 22 — 10. WIPER MECHANISM COMPONENTS (FOR LH-3168-7)

Page 23

Page 24 — 11. LUBRICATION COMPONENTS

Page 25

Page 26 — 12. OIL RESERVOIR & KNEE LIFTER COMPONENTS

Page 27 — BELT COVER & BOBBIN WINDER COMPONENTS

Page 28 — 14. THREAD STAND COMPONENTS

Page 29 — 15. MOTOR PULLEY COMPONENTS

Page 30 — 16. TABLE OF EXCHANGING GAUGE PARTS

Part Books

Search
