FR Fabric tensioner device 布張りローラー装置 Machine models EX(T)5100 Series Parts Catalog PEGASUS jintex.in
Pegasus FR002 / FR151 — parts catalog
- Page 1 (cover): This is the cover page for the FR Fabric Tensioner Device Parts Catalog for Pegasus EX(T)5100 Series machine models.
- Page 2 (toc): This page provides an introduction to the parts catalog, explaining how to use it, and lists the models covered by the catalog.
- Page 3 (toc): This page is a table of contents for a parts catalog, listing various assemblies and their corresponding page numbers.
- Page 4 (parts_list): This page provides application tables for FR/EX5100 and FR/EXT5100 models, detailing features and component parts for different types.
- Page 5 (unknown): This page is blank except for a watermark 'jintex.in' and a footer with the same text.
- Page 6 (diagram): This page displays two diagrams, FR002 and FR151, illustrating various components and their assembly.
- Page 7 (parts_list): This page lists parts for the FR002 and FR151 rear roller assembly, including part numbers, descriptions, and quantities.
- Page 8 (diagram): This page displays two diagrams, FR002 and FR151, showing various components and their assembly, with a note about packed accessories.
- Page 9 (parts_list): This page lists parts for the FR002 and FR151 models, specifically for the front roller assembly and lower roller assembly, including part numbers, descriptions, and quantities.
- Page 10 (diagram): This page displays an exploded view diagram of the FR151 assembly, showing various components and accessories.
- Page 11 (parts_list): This page lists parts for the FR151 Lower Roller Assembly, including part numbers, descriptions, and quantities.
- Page 12 (diagram): This page displays two diagrams, FR002 and FR002, illustrating various components and their assembly with numbered references.
- Page 13 (parts_list): This page lists parts for the FR002 Edge Guide Assembly and Erastic Guide Assembly, including part numbers, descriptions, and quantities.
- Page 14 (diagram): This page displays two diagrams, FR151, illustrating various components and their assembly.
- Page 15 (parts_list): This page lists parts for the FR151 Edge Guide Assy. and Knee Switch Assy., including screws, washers, nuts, brackets, and other components with their respective part numbers and quantities.
- Page 16 (diagram): This page displays a diagram of various components, including a bracket, screws, nuts, washers, rods, and a valve assembly, with reference numbers for each part.
- Page 17 (parts_list): This page lists parts for the FR151 Valve Set, including part numbers, descriptions in Japanese and English, and quantities.
- Page 18 (diagram): This page displays a diagram of components for FR002 and FR151 models, showing various parts with reference numbers.
- Page 19 (parts_list): This page lists parts for the FR002 and FR151 models, specifically for the table and waste chute assembly, including part numbers, descriptions, and quantities.
- Page 20 (index): This page is an index listing part numbers, their corresponding page numbers, and reference numbers.
- Page 21 (unknown): This page is blank except for a watermark 'jintex.in' and a footer 'jintex.in'.
- Page 22 (unknown): This page is blank except for a watermark and a footer.
- Page 23 (unknown): This page is blank except for a watermark 'jintex.in' and a footer with the same text.
- Page 24 (cover): This page is the cover of a parts catalog from Pegasus Sewing Machine Mfg. Co., Ltd., published in February 2007, and includes contact information for their main office.
Page 2
パーツカタログの見方 ■このパーツカタログは、2007年2月製造中のFR装置の構成部品を次の要領で編集しています。 ■4 ~ 17 頁には部品を機種別に収録し、左頁が部品の分解図、右頁がパーツリストになっています。また、部品分 解図に付されている番号は、パーツリストのREF.NO. (参 照番号) を示しています。 ■巻末には部品番号インデックスを記載し、部品番号だけ で、その図解・名称などが容易に引き出せます。 ■部品を御注文いただく時は、部品番号を明示してくださ い。なお、このパーツカタログの記載事項は改良により、 予告なく変更されることがありますので、あらかじめご 了承ください。 INTRODUCTION ■ This parts catalog covers the FR device which are manufactured in February, 2006. ■ The components are shown on pages 4 - 17. The illustrations are on left pages and the part numbers on right pages. The illustrated part and its part number are assigned the same reference number. ■ The index of part numbers are listed at the back of this book for quick reference. ■ When placing an order for any part, please specify the part number. Note that the contents of this book are subject to change for improvement without prior notice. 掲載機種 (Models inserted) FR/EX(T)5100 Series FR002 FR151 jintex.in
Page 3 — TABLE OF CONTENTS
目 次 FR 装置適用一覧 & 装置構成部品一覧表 ……………… 2 後ローラー(組) (FR002, FR151) ……………… 4 ~ 5 前ローラー(組) ……………… 6 ~ 7 下ローラー(組) (FR002, FR151) 下ローラー(組) (FR151) ……………… 8 ~ 9 当定規(組)・ゴム案内(組) (FR002) ……………… 10 ~ 11 当定規(組)・ヒザスイッチ(組) (FR151) ……………… 12 ~ 13 バルブセット (FR151) ……………… 14 ~ 15 テーブル・切屑受(組) (FR002, FR151) ……………… 16 ~ 17 部品番号インデックス ……………… 18 TABLE OF CONTENTS page APPLICATIN TABLE & COMPONENT PARTS LIST FOR FR … 2 REAR ROLLER ASSY. (FR002, FR151) ……………… 4 ~ 5 FRONT ROLLER ASSY. LOWER ROLLER ASSY. (FR002, FR151) ……………… 6 ~ 7 LOWER ROLLER ASSY. (FR151) ……………… 8 ~ 9 EGDE GUIDE ASSY. • ERASTIC GUIDE ASSY. (FR002) … 10 ~ 11 EDGE GUIDE ASSY. • KNEE SWITCH ASSY. (FR151) … 12 ~ 13 VALVE SET (FR151) ……………… 14 ~ 15 TABLE • WASTE CHUTE ASSY. (FR002, FR151) … 16 ~ 17 PARTS NUMBER INDEX ……………… 18 1 jintex.in
Page 4 — Application table for FR/EX5100 FR/EXT5100
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 308543-910 | Rear roller assy. | ||
| 308541-910 | Lower roller assy. | ||
| 305206-910 | Front roller assy. | ||
| 302474-910 | Erastic guide assy. | ||
| 302500-910 | Edge guide assy. | ||
| 9A20500 | Table diagram | ||
| 302459A9R0 | Waste chute assy. | ||
| 305211-910 | Rear roller assy. | ||
| 305199A910 | Lower roller assy. | ||
| 305226A910 | Edge guide assy. | ||
| 302477A910 | Valve set | ||
| 350645-910 | Knee switch assy. | ||
| 6010890 | Joint |
装置適用一覧 Application table for FR/EX5100 FR/EXT5100 地縫い Plain seaming FR 002 FR 151 EX5104 〇 〇 EX5114 〇 〇 地縫い Plain seaming FR 002 FR 151 EXT5104 〇 〇 EXT5114 〇 〇 2 装置構成部品一覧表 Component parts list for FR 特徴 Features 形式 Type 駆動方式 Driving system 操作方法 Operating system 備考 Remarks FR002 — — 大口径平ゴム・リブ 付固定式ローラー Fixed roller for attaching large diameter flat elastic or rib knit FR151 圧搾空気 Pneumatic 足ペダル・ヒザスイッチ Pedal・Knee switch 大口径リブ付用下・後 ローラー移動式 Movable rear and lower rollers for attaching large diameter rib knit 構成部品 Component parts 専用部品 Special parts 装置形式 Type 後下ローラー (組) Rear roller assy. 下ローラー (組) Lower roller assy. 前ローラー (組) Front roller assy. ゴム案内 (組) Erastic guide assy. 当定規 (組) Edge guide assy. バルブセット Valve set ヒザスイッチ (組) Knee switch assy. 継手 Joint 専用テーブル図 Table diagram 切屑受 (組) Waste chute assy. FR002 308543-910 308541-910 305206-910 302474-910 302500-910 — — — 9A20500 302459A9R0 FR151 305211-910 305199A910 305206-910 — 305226A910 302477A910 350645-910 6010890 9A20500 302459A9R0 jintex.in
Page 5
jintex.in jintex.in
Page 6
FR002 FR151 4 jintex.in
Page 7 — FR002, FR151 REAR ROLLER ASSY.
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 308543-910 | REAR ROLLER ASSY. | 1 |
| 2 | 308544-910 | BRACKET | 1 |
| 3 | 0049050 | SCREW | 3 |
| 4 | 3024490 | BRACKET | 1 |
| 5 | 2404820 | CLAMP LEVER | 1 |
| 6 | 3033350 | WASHER | 1 |
| 7 | 3024510 | ROLLER | 1 |
| 8 | 3024520 | ROLLER | 1 |
| 9 | 0055460 | SCREW | 1 |
| 10 | 2400620 | WASHER | 1 |
| 11 | 305211-910 | REAR ROLLER ASSY. | 1 |
| 12 | 305212-910 | ROLLER | 1 |
| 13 | 0071300 | SCREW | 1 |
| 14 | 2011850 | WASHER | 1 |
| 15 | 3052020 | SHAFT | 1 |
| 16 | 2025220 | RING | 1 |
| 17 | 305205-920 | HING | 1 |
| 18 | 0070730 | SCREW | 1 |
| 19 | 3052090 | ARM | 2 |
| 20 | 0071300 | SCREW | 1 |
| 21 | 3052100 | BRACKET | 1 |
| 22 | 5131070 | AIR CYLINDER | 1 |
| 23 | 5270020 | SPEED CONTROLLER | 2 |
| 24 | 6001750 | TUBE | 2 |
| 25 | 3052250 | SHAFT | 1 |
| 26 | 0045380 | SCREW | 2 |
| 27 | 2404750 | CILLAR | 1 |
| 28 | 2404810 | URETHAN WASHER | 1 |
| 29 | 3052150 | BRACKET | 1 |
| 30 | 0040260 | BOLT | 2 |
| 31 | 3033350 | WASHER | 2 |
| 32 | 2404730 | BUSHING | 1 |
| 33 | 0070110 | SCREW | 2 |
| 34 | 305216-910 | BRACKET | 1 |
| 35 | 2404820 | CLAMP LEVER | 1 |
| 36 | 2007280 | WASHER | 1 |
| 37 | 3052180 | BRACKET | 1 |
| 38 | 0049050 | SCREW | 4 |
| 39 | 9A30690 | CAUTION LABEL | 1 |
FR002, FR151 後ローラー (組) REF.NO. PART NO. 1 308543-910 2 308544-910 3 0049050 4 3024490 5 2404820 6 3033350 7 3024510 8 3024520 9 0055460 10 2400620 11 305211-910 12 305212-910 13 0071300 14 2011850 15 3052020 16 2025220 17 305205-920 18 0070730 19 3052090 20 0071300 21 3052100 22 5131070 23 5270020 24 6001750 25 3052250 26 0045380 27 2404750 28 2404810 29 3052150 30 0040260 31 3033350 32 2404730 33 0070110 34 305216-910 35 2404820 36 2007280 37 3052180 38 0049050 39 9A30690 部品名称 後ローラー (組) ブラケット 丸木ネジ/4.5 ブラケット クランプレバー 座金 ローラー 軸 平ネジ/C5 X 10 座金 後ローラー (組) ローラー 平小ネジ/M4 X 7 座金 軸 止め輪 生地ガイド 六角穴止ネジ/M3 X 5 アーム 平小ネジ/M4 X 7 ブラケット エアシリンダ スピードコントローラ チューブ/φ6 X 700 軸 六角穴止ネジ/M4 X 6 カラー ウレタンワッシャ ブラケット 六角穴ボルト/M6 X 12 座金 リニアブッシュ 平小ネジ/M3 X 8 ブラケット クランプレバー 座金 土台 丸木ネジ/4.5 ケガ注意ラベル FR002, FR151 REAR ROLLER ASSY. DESCRIPTION REAR ROLLER ASSY. BRACKET SCREW BRACKET CLAMP LEVER WASHER ROLLER ROLLER SCREW WASHER REAR ROLLER ASSY. ROLLER SCREW WASHER SHAFT RING HING SCREW ARM SCREW BRACKET AIR CYLINDER SPEED CONTROLLER TUBE SHAFT SCREW CILLAR URETHAN WASHER BRACKET BOLT WASHER BUSHING SCREW BRACKET CLAMP LEVER WASHER BRACKET SCREW CAUTION LABEL QT. 1 1 3 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 2 2 1 2 1 1 1 2 2 1 2 1 1 1 1 4 1 5 jintex.in
Page 8
FR002 FR151 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 FR002 24 25 26 27 28 29 30 31 32 33 34 35 36 付属品に梱入 Packed in accessory 6 jintex.in
Page 9 — FRONT ROLLER ASSY. • LOWER ROLLER ASSY.
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 305206-910 | FRONT ROLLER ASSY. | 1 |
| 2 | 2590360 | ROLLER | 1 |
| 3 | 2590380 | COLLAR | 2 |
| 4 | 0045540 | SCREW | 2 |
| 5 | 2045200 | WASHER | 1 |
| 6 | 0053320 | SCREW | 1 |
| 7 | 2590140 | COLLAR | 1 |
| 8 | 0045430 | SCREW | 1 |
| 9 | 3069260 | SHAFT | 1 |
| 10 | 2590060 | JOINT | 1 |
| 11 | 0045110 | BOLT | 1 |
| 12 | 259015A0 | CLAMP LEVER | 1 |
| 13 | 0070680 | BOLT | 2 |
| 14 | 3052190 | SHAFT | 1 |
| 15 | 259006A0 | JOINT | 1 |
| 16 | 0045110 | BOLT | 1 |
| 17 | 259015A0 | CLAMP LEVER | 1 |
| 18 | 0070680 | BOLT | 2 |
| 19 | 259005B0 | SHAFT | 1 |
| 20 | 0070680 | BOLT | 1 |
| 21 | 2590040 | BRACKET | 1 |
| 22 | 0049050 | SCREW | 2 |
| 23 | 308541-910 | LOWER ROLLER ASSY. | 1 |
| 24 | 308542-910 | BRACKET | 1 |
| 25 | 0045020 | BOLT | 4 |
| 26 | 0048200 | BOLT | 4 |
| 27 | 3033350 | WASHER | 4 |
| 28 | 3030670 | WASHER | 4 |
| 29 | 3068290 | BRACKET | 1 |
| 30 | 306830B | SCREW | 1 |
| 31 | 3085480 | CLAMP LEVER | 1 |
| 32 | 2007280 | WASHER | 1 |
| 33 | 302445A0 | ROLLER | 1 |
| 34 | 302444A0 | SHAFT | 1 |
| 35 | 0053320 | SCREW | 1 |
| 36 | 2045200 | WASHER | 1 |
FR002, FR151 FR002, FR151 前ローラー(組)・下ローラー(組) FRONT ROLLER ASSY. • LOWER ROLLER ASSY. REF.NO. PART NO. 部品名称 DESCRIPTION QT. 1 305206-910 前ローラー(組) FRONT ROLLER ASSY. 1 2 2590360 ローラー ROLLER 1 3 2590380 カラー COLLAR 2 4 0045540 六角穴止ネジ/M3 X 3 SCREW 2 5 2045200 座金 WASHER 1 6 0053320 平ネジ/C 10 X 7 SCREW 1 7 2590140 カラー COLLAR 1 8 0045430 六角穴止ネジ/M4 X 4 SCREW 1 9 3069260 軸 SHAFT 1 10 2590060 継手 JOINT 1 11 0045110 六角穴ボルト/M6 X 25 BOLT 1 12 259015A0 クランプレバー CLAMP LEVER 1 13 0070680 六角ボルト/M5 X 10 BOLT 2 14 3052190 軸 SHAFT 1 15 259006A0 継手 JOINT 1 16 0045110 六角穴ボルト/M6 X 25 BOLT 1 17 259015A0 クランプレバー CLAMP LEVER 1 18 0070680 六角ボルト/M5 X 10 BOLT 2 19 259005B0 軸 SHAFT 1 20 0070680 六角ボルト/M5 X 10 BOLT 1 21 2590040 ブラケット BRACKET 1 22 0049050 丸木ネジ/4.5 SCREW 2 23 308541-910 下ローラー(組) LOWER ROLLER ASSY. 1 24 308542-910 ブラケット BRACKET 1 25 0045020 六角穴ボルト/M5 X 30 BOLT 4 26 0048200 六角ナット/M5 BOLT 4 27 3033350 座金 WASHER 4 28 3030670 バネ座金 WASHER 4 29 3068290 ブラケット BRACKET 1 30 306830B 段ネジ/M6 SCREW 1 31 3085480 クランプレバー CLAMP LEVER 1 32 2007280 座金 WASHER 1 33 302445A0 ローラー ROLLER 1 34 302444A0 軸 SHAFT 1 35 0053320 平ネジ/C 10 X 7 SCREW 1 36 2045200 座金 WASHER 1 7 jintex.in
Page 10 — FR151
FR151 付属品に梱入 Packed in accccessory 付属品に梱入 Packed in accccessory 8 jintex.in
Page 11 — FR151 LOWER ROLLER ASSY.
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 305199A910 | LOWER ROLLER ASSY. | 1 |
| 2 | 305200-910 | ROLLER | 2 |
| 3 | 0071300 | SCREW | 2 |
| 4 | 2011850 | WASHER | 2 |
| 5 | 3052020 | SHAFT | 2 |
| 6 | 2025220 | RING | 2 |
| 7 | 305205-920 | FABLIC GUIDE | 2 |
| 8 | 0070730 | SCREW | 2 |
| 9 | 3052030 | BRACKET | 1 |
| 10 | 0072800 | SCREW | 1 |
| 11 | 259015A0 | CLAMP LEVER | 1 |
| 12 | 2040230 | WASHER | 1 |
| 13 | 3052200 | BRACKET | 1 |
| 14 | 0070200 | SCREW | 2 |
| 15 | 2011850 | WASHER | 2 |
| 16 | 5140010 | CYLINDER | 1 |
| 17 | 3052210 | BRACKET | 2 |
| 18 | 0071300 | SCREW | 4 |
| 19 | 2011850 | WASHER | 4 |
| 20 | 5270020 | SPEED CONTROLLER | 2 |
| 21 | 6000320 | TUBE | 1 |
| 22 | 6001010 | TUBE | 1 |
| 23 | 7480020 | BAND | 2 |
| 24 | 6011200 | JOINT | 2 |
| 25 | 3052240 | HOUSING | 1 |
| 26 | 3052230 | SHEET | 1 |
| 27 | 3506650 | SEAL | 1 |
| 28 | 0040260 | BOLT | 2 |
| 29 | 3033350 | WASHER | 2 |
| 30 | 2042930 | WASHER | 2 |
| 31 | 3052220 | STOPPER | 1 |
| 32 | 2403050 | RUBBER CUSHION | 2 |
| 33 | 2404820 | CLAMP LEVER | 1 |
| 34 | 2040230 | WASHER | 1 |
| 35 | 3052040 | BRACKET | 1 |
| 36 | 0045020 | BOLT | 4 |
| 37 | 3033350 | WASHER | 4 |
| 38 | 3030670 | WASHER | 4 |
| 39 | 0048200 | NUT | 4 |
| 40 | 7480150 | BAND | 5 |
| 41 | 0049200 | SCREW | 3 |
| 42 | 7480420 | BAND | 3 |
| 43 | 9A30690 | CAUTION LABEL | 1 |
FR151 FR151 下ローラー(組) LOWER ROLLER ASSY. REF.NO. PART NO. 部品名称 DESCRIPTION QT 1 305199A910 下ローラー(組) LOWER ROLLER ASSY. 1 2 305200-910 ローラー ROLLER 2 3 0071300 平小ネジ/M4 X 7 SCREW 2 4 2011850 座金 WASHER 2 5 3052020 軸 SHAFT 2 6 2025220 止め輪 RING 2 7 305205-920 生地ガイド FABLIC GUIDE 2 8 0070730 六角穴止ネジ/M3 X 5 SCREW 2 9 3052030 ブラケット BRACKET 1 10 0072800 段ネジ/M6 SCREW 1 11 259015A0 クランプレバー CLAMP LEVER 1 12 2040230 座金 WASHER 1 13 3052200 ブラケット BRACKET 1 14 0070200 平小ネジ/M4 X 10 SCREW 2 15 2011850 座金 WASHER 2 16 5140010 ロッドレスシリンダ CYLINDER 1 17 3052210 ブラケット BRACKET 2 18 0071300 平小ネジ/M4 X 7 SCREW 4 19 2011850 座金 WASHER 4 20 5270020 スピードコントローラ SPEED CONTROLLER 2 21 6000320 チューブ/φ6 X 500 TUBE 1 22 6001010 チューブ/φ6 X 1010 TUBE 1 23 7480020 束線バンド BAND 2 24 6011200 継手 JOINT 2 25 3052240 ハウジング HOUSING 1 26 3052230 スライダーシート SHEET 1 27 3506650 目盛シール SEAL 1 28 0040260 六角穴ボルト/M6 X 12 BOLT 2 29 3033350 座金 WASHER 2 30 2042930 バネ座金 WASHER 2 31 3052220 ストッパ STOPPER 1 32 2403050 防振ゴム RUBBER CUSHION 2 33 2404820 クランプレバー CLAMP LEVER 1 34 2040230 座金 WASHER 1 35 3052040 ブラケット BRACKET 1 36 0045020 六角穴ボルト/M5 X 30 BOLT 4 37 3033350 座金 WASHER 4 38 3030670 バネ座金 WASHER 4 39 0048200 六角ナット/M5 NUT 4 40 7480150 束線バンド BAND 5 41 0049200 木ネジ/3.1 SCREW 3 42 7480420 束線バンド BAND 3 43 9A30690 ケガ注意ラベル CAUTION LABEL 1 9 jintex.in
Page 12
FR002 15 19 20 16 18 17 21 2 3 8 9 4 10 11 12 5 6 7 14 13 22 FR002 26 23 25 24 27 28 10 jintex.in
Page 13 — FR002 EGDE GUIDE ASSY. • ERASTIC GUIDE ASSY.
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 302500-910 | EDGE GUIDE ASSY. | 1 |
| 2 | 2106850 | BRACKET ASSY. | 1 |
| 3 | 2106800 | BRACKET | 1 |
| 4 | 2106810 | HINGE | 1 |
| 5 | 0051840 | SCREW | 1 |
| 6 | 2011910 | SPRING | 1 |
| 7 | 0030440 | NUT | 1 |
| 8 | 2106820 | WASHER | 1 |
| 9 | 0050530 | SCREW | 1 |
| 10 | 2106830 | PIN | 1 |
| 11 | 2106840 | FLAT SPRING | 1 |
| 12 | 0029060 | SCREW | 1 |
| 13 | 007021A0 | SCREW | 1 |
| 14 | 2022860 | WASHER | 1 |
| 15 | 2106860 | BRACKET ASSY. | 1 |
| 16 | 2106870 | BRACKET | 1 |
| 17 | 0050880 | BOLT | 2 |
| 18 | 1670660 | WASHER | 2 |
| 19 | 0012020 | SCREW | 1 |
| 20 | 1670660 | WASHER | 1 |
| 21 | 3024480 | EDGE GUIDE | 1 |
| 22 | 302474-910 | ERASTIC GUIDE ASSY. | 1 |
| 23 | 3024550 | BRACKET | 1 |
| 24 | 007018A0 | SCREW | 2 |
| 25 | 2011850 | WASHER | 2 |
| 26 | 3024560 | ERASTIC GUIDE | 1 |
| 27 | 0050120 | SCREW | 1 |
| 28 | 2028750 | WASHER | 1 |
FR002 当定規(組)・ゴム案内(組) REF.NO. PART NO. 1 302500-910 2 2106850 3 2106800 4 2106810 5 0051840 6 2011910 7 0030440 8 2106820 9 0050530 10 2106830 11 2106840 12 0029060 13 007021A0 14 2022860 15 2106860 16 2106870 17 0050880 18 1670660 19 0012020 20 1670660 21 3024480 22 302474-910 23 3024550 24 007018A0 25 2011850 26 3024560 27 0050120 28 2028750 部品名称 当定規(組) ブラケット(組) ブラケット ヒンジ 段ネジ/C5 皿バネ 六角ナット/C5 座金 平小ネジ/C4 X 4.8 ピン 板バネ 平小ネジ/C4 X 2.6 十字穴ナベ小ネジ/M4 X 12 バネ座金 ブラケット(組) ブラケット 六角ボルト/C4 X 7.5 座金 平小ネジ/C4 X 7 座金 当定規 ゴム案内(組) ブラケット 十字穴ナベ小ネジ/M4 X 6 座金 ゴム案内 平ネジ/C3 X 5.5 座金 EGDE GUIDE ASSY. • ERASTIC GUIDE ASSY. DESCRIPTION EDGE GUIDE ASSY. BRACKET ASSY. BRACKET HINGE SCREW SPRING NUT WASHER SCREW PIN FLAT SPRING SCREW SCREW WASHER BRACKET ASSY. BRACKET BOLT WASHER SCREW WASHER EDGE GUIDE ERASTIC GUIDE ASSY. BRACKET SCREW WASHER ERASTIC GUIDE SCREW WASHER FR002 QT. 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 1 1 1 2 2 1 1 1 11 jintex.in
Page 14
FR151 31 34 29 30 33 35 36 37 40 41 43 38 39 28 27 26 22 23 24 25 32 13 14 11 4 7 9 10 2 3 5 21 15 12 42 8 19 16 20 18 17 6 44 FR151 45 47 46 53 51 50 52 53 60 58 54 57 55 56 59 61 62 48 49 12 jintex.in
Page 15 — FR151 EDGE GUIDE ASSY. • KNEE SWITCH ASSY.
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 305226A910 | EDGE GUIDE ASSY. | |
| 2 | 3052270 | BRACKET | |
| 3 | 0070260 | SCREW | |
| 4 | 2403320 | SPACER | |
| 5 | 0070200 | SCREW | |
| 6 | 305228-910 | BRACKET | |
| 7 | 0071600 | SCREW | |
| 8 | 0048180 | NUT | |
| 9 | 2048880 | SPRING | |
| 10 | 2060550 | WASHER | |
| 11 | 0W00128-20 | SCREW | |
| 12 | 3052300 | PLATE | |
| 13 | 0071900 | SCREW | |
| 14 | 2011850 | WASHER | |
| 15 | 3052340 | SPACER | |
| 16 | 3052310 | GUIDE (LEFT) | |
| 17 | 0071430 | SCREW | |
| 18 | 2011850 | WASHER | |
| 19 | 3052320 | BRACKET | |
| 20 | 0071430 | SCREW | |
| 21 | 3052330 | GUIDE (RIGHT) | |
| 22 | 0070240 | SCREW | |
| 23 | 2011850 | WASHER | |
| 24 | 2052340 | SPACER | |
| 25 | 3052350 | SEPARATER | |
| 26 | 3052360 | AUXILIARY GUIDE | |
| 27 | 3503360 | LATCH | |
| 28 | 0045270 | BOLT | |
| 29 | 3052380 | STOPPER | |
| 30 | 2403050 | RUBBER CUSHION | |
| 31 | 0070210 | SCREW | |
| 32 | 0072810 | NUT | |
| 33 | 3052390 | SPRING | |
| 34 | 0045540 | SCREW | |
| 35 | 5131080 | AIR CYLINDER | |
| 36 | 2109300 | WASHER | |
| 37 | 2011850 | WASHER | |
| 38 | 5270060 | SPEED CONTROLLER | |
| 39 | 6010970 | JOINT | |
| 40 | 3052370 | BRACKET | |
| 41 | 0070210 | SCREW | |
| 42 | 0072810 | NUT | |
| 43 | 2011850 | WASHER | |
| 44 | 350645-910 | KNEE SWITCH ASSY. | |
| 45 | 0001970 | BRACKET | |
| 46 | 0049100 | SCREW | |
| 47 | 2045850 | WASHER | |
| 48 | 3506430 | BRACKET | |
| 49 | 3002200 | VALVE ACTUATOR ASSY. | |
| 50 | 0051830 | SCREW | |
| 51 | 0030440 | NUT | |
| 52 | 0051180 | SCREW | |
| 53 | 1371420 | WASHER | |
| 54 | 7E2004A0000 | SWITCH | |
| 55 | 6A028100000 | BRACKET | |
| 56 | 5320010 | AIR VALVE | |
| 57 | 1D001400000 | NUT | |
| 58 | 6011150 | JOINT | |
| 59 | 6011070 | JOINT | |
| 60 | 6000320 | TUBE | |
| 61 | 6000780 | TUBE | |
| 62 | 6000770 | TUBE |
FR151 FR151 当定規(組)・膝スイッチ(組) EDGE GUIDE ASSY. • KNEE SWITCH ASSY. REF.NO. PART NO. 部品名称 DESCRIPTION QT. 1 305226A910 当定規(組) EDGE GUIDE ASSY. 1 2 3052270 土台 BRACKET 1 3 0070260 平小ネジ/M4 X 25 SCREW 1 4 2403320 スペーサ SPACER 1 5 0070200 平小ネジ/M4 X 10 SCREW 1 6 305228-910 ブラケット BRACKET 1 7 0071600 段ネジ/M6 SCREW 1 8 0048180 六角ナット/M6 NUT 1 9 2048880 皿バネ SPRING 2 10 2060550 座金 WASHER 1 11 0W00128-20 段付ネジ/W2 SCREW 1 12 3052300 プレート PLATE 1 13 0071900 平小ネジ/M4 X 7 SCREW 1 14 2011850 座金 WASHER 1 15 3052340 スペーサ SPACER 1 16 3052310 ガイド(左) GUIDE (LEFT) 1 17 0071430 ナベ小ネジ/M4 X 5.5 SCREW 1 18 2011850 座金 WASHER 1 19 3052320 ブラケット BRACKET 1 20 0071430 ナベ小ネジ/M4 X 5.5 SCREW 1 21 3052330 ガイド(右) GUIDE (RIGHT) 2 22 0070240 平小ネジ/M4 X 18 SCREW 1 23 2011850 座金 WASHER 1 24 2052340 スペーサ SPACER 1 25 3052350 セパレーター板 SEPARATER 1 26 3052360 補助ガイド AUXILIARY GUIDE 1 27 3503360 止め具 LATCH 1 28 0045270 六角穴ボルト/M4 X 8 BOLT 1 29 3052380 ストッパ STOPPER 1 30 2403050 防振ゴム RUBBER CUSHION 1 31 0070210 平小ネジ/M4 X 12 SCREW 1 32 0072810 丸ナット/M4 NUT 1 33 3052390 カール防止バネ SPRING 1 34 0045540 六角穴止めネジ/M3 X 3 SCREW 2 35 5131080 エアシリンダ AIR CYLINDER 1 36 2109300 座金 WASHER 2 37 2011850 座金 WASHER 2 38 5270060 スピードコントローラ SPEED CONTROLLER 1 39 6010970 継手 JOINT 1 40 3052370 ブラケット BRACKET 1 41 0070210 平小ネジ/M4 X 12 SCREW 2 42 0072810 丸ナット/M4 NUT 2 43 2011850 座金 WASHER 2 44 350645-910 膝スイッチ(組) KNEE SWITCH ASSY. 1 45 0001970 ブラケット BRACKET 1 46 0049100 丸木ネジ/5.1 SCREW 2 47 2045850 座金 WASHER 2 48 3506430 ブラケット BRACKET 1 49 3002200 バルブアクチュエータ(組) VALVE ACTUATOR ASSY. 1 50 0051830 平ネジ/C5 X 17 SCREW 1 51 0030440 六角ナット/C5 NUT 1 52 0051180 平ネジ/C5 X 12 SCREW 1 53 1371420 座金 WASHER 2 54 7E2004A0000 スイッチ SWITCH 1 55 6A028100000 ブラケット BRACKET 1 56 5320010 エアーバルブ AIR VALVE 1 57 1D001400000 六角ナット/M12 NUT 1 58 6011150 継手 JOINT 1 59 6011070 継手 JOINT 2 60 6000320 チューブ/φ6 X 500 TUBE 1 61 6000780 チューブ/φ4 X 700 TUBE 1 62 6000770 チューブ/φ4 X 550 TUBE 1 13 jintex.in
Page 16
FR151 14 jintex.in
Page 17 — FR151 VALVE SET
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 302477A910 | VALVE SET | 1 |
| 2 | 532007-910 | AIR VALVE ASSY. | 1 |
| 3 | 5320010 | AIR VALVE | 1 |
| 4 | 3067310 | BRACKET | 1 |
| 5 | 3004690 | STOPPER | 1 |
| 6 | 3004680 | ACTUATOR | 1 |
| 7 | 3067330 | PITMAN ROD | 1 |
| 8 | 6010020 | JOINT | 3 |
| 9 | 2017590 | WASHER | 3 |
| 10 | 6010430 | SLEEVE | 3 |
| 11 | 3039910 | JOINT | 2 |
| 12 | 6000150 | TUBE | 2 |
| 13 | 306733A0 | PITMAN ROD | 1 |
| 14 | 1375580 | SPRING | 1 |
| 15 | 6000240 | TUBE | 1 |
| 16 | 0043200 | BOLT | 3 |
| 17 | 3024690 | BRACKET | 1 |
| 18 | 0049210 | SCREW | 2 |
| 19 | 0045020 | BOLT | 2 |
| 20 | 3030670 | WASHER | 2 |
| 21 | 0048200 | NUT | 2 |
| 22 | 3024700 | BRACKET | 1 |
| 23 | 6010890 | JOINT | 1 |
FR151 バルブセット REF.NO. PART NO. 1 302477A910 2 532007-910 3 5320010 4 3067310 5 3004690 6 3004680 7 3067330 8 6010020 9 2017590 10 6010430 11 3039910 12 6000150 13 306733A0 14 1375580 15 6000240 16 0043200 17 3024690 18 0049210 19 0045020 20 3030670 21 0048200 22 3024700 23 6010890 部品名称 バルブセット エアバルブ (組) エアーバルブ ブラケット ストッパ アクチュエータ ピットマンロッド 継手 座金 スリーブ ボールジョイント チューブ/φ6 X 830 ピットマンロッド 圧縮バネ チューブ/φ6 X 200 六角ボルト/M6 X 10 ブラケット 木ネジ/5.8 六角穴ボルト/M5 X 30 バネ座金 六角ナット/M5 ブラケット 継手 FR151 VALVE SET DESCRIPTION VALVE SET AIR VALVE ASSY. AIR VALVE BRACKET STOPPER ACTUATOR PITMAN ROD JOINT WASHER SLEEVE JOINT TUBE PITMAN ROD SPRING TUBE BOLT BRACKET SCREW BOLT WASHER NUT BRACKET JOINT QT. 1 1 1 1 1 1 1 3 3 3 2 2 1 1 1 3 1 2 2 2 2 1 1 15 jintex.in
Page 18
FR002 FR151 16 jintex.in
Page 19 — TABLE • WASTE CHUTE ASSY.
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 9A90500 | テーブル | 1 |
| 2 | 202459A9R0 | 切屑受(組) | 1 |
| 3 | 302453-RA0 | 切屑受 | 1 |
| 4 | 302454-RA0 | 切屑受 | 1 |
| 5 | 0030440 | 六角ナット/C5 | 4 |
| 6 | 0054530 | 平ネジ/C5 X 6.5 | 4 |
| 7 | 3030670 | バネ座金 | 4 |
| 8 | 3053600 | ブラケット | 1 |
| 9 | 0041090 | 十字穴バインド小ネジ/M4 X 10 | 2 |
| 10 | 2401040 | 座金 | 2 |
| 11 | 0048210 | 六角ナット/M4 | 2 |
| 12 | 0049050 | 丸木ネジ/4.5 | 2 |
FR002, FR151 テーブル・切屑受(組) REF.NO. PART NO. 1 9A90500 2 202459A9R0 3 302453-RA0 4 302454-RA0 5 0030440 6 0054530 7 3030670 8 3053600 9 0041090 10 2401040 11 0048210 12 0049050 部品名称 テーブル 切屑受(組) 切屑受 切屑受 六角ナット/C5 平ネジ/C5 X 6.5 バネ座金 ブラケット 十字穴バインド小ネジ/M4 X 10 座金 六角ナット/M4 丸木ネジ/4.5 FR002, FR151 TABLE • WASTE CHUTE ASSY. DESCRIPTION TABLE WASTE CHUTE ASSY. WASTE CHUTE WASTE CHUTE NUT SCREW WASHER BRACKET SCREW WASHER NUT SCREW QT. 1 1 1 1 4 4 4 1 2 2 2 2 17 jintex.in
Page 20 — INDEX
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 45 | 0001970 | ||
| 19 | 0012020 | ||
| 12 | 0029060 | ||
| 7 | 0030440 | ||
| 51 | 0030440 | ||
| 5 | 0030440 | ||
| 30 | 0040260 | ||
| 28 | 0040260 | ||
| 9 | 0041090 | ||
| 16 | 0043200 | ||
| 25 | 0045020 | ||
| 36 | 0045020 | ||
| 19 | 0045020 | ||
| 11 | 0045110 | ||
| 16 | 0045110 | ||
| 28 | 0045270 | ||
| 26 | 0045380 | ||
| 8 | 0045430 | ||
| 4 | 0045540 | ||
| 34 | 0045540 | ||
| 8 | 0048180 | ||
| 26 | 0048200 | ||
| 39 | 0048200 | ||
| 21 | 0048200 | ||
| 11 | 0048210 | ||
| 3 | 0049050 | ||
| 38 | 0049050 | ||
| 22 | 0049050 | ||
| 12 | 0049050 | ||
| 46 | 0049100 | ||
| 41 | 0049200 | ||
| 18 | 0049210 | ||
| 27 | 0050120 | ||
| 9 | 0050530 | ||
| 17 | 0050880 | ||
| 52 | 0051180 | ||
| 50 | 0051830 | ||
| 5 | 0051840 | ||
| 6 | 0053320 | ||
| 35 | 0053320 | ||
| 6 | 0054530 | ||
| 9 | 0055460 | ||
| 33 | 0070110 | ||
| 24 | 007018A0 | ||
| 14 | 0070200 | ||
| 5 | 0070200 | ||
| 31 | 0070210 | ||
| 41 | 0070210 | ||
| 13 | 007021A0 | ||
| 22 | 0070240 | ||
| 3 | 0070260 | ||
| 13 | 0070680 | ||
| 18 | 0070680 | ||
| 20 | 0070680 | ||
| 18 | 0070730 | ||
| 8 | 0070730 | ||
| 13 | 0071300 | ||
| 20 | 0071300 | ||
| 3 | 0071300 | ||
| 18 | 0071300 | ||
| 13 | 0071300 | ||
| 17 | 0071430 | ||
| 20 | 0071430 | ||
| 7 | 0071600 | ||
| 10 | 0072800 | ||
| 32 | 0072810 | ||
| 42 | 0072810 | ||
| 11 | 0W00128-20 | ||
| 53 | 1371420 | ||
| 14 | 1375580 | ||
| 18 | 1670660 | ||
| 20 | 1670660 | ||
| 57 | 1D001400000 | ||
| 36 | 2007280 | ||
| 32 | 2007280 | ||
| 14 | 2011850 | ||
| 4 | 2011850 | ||
| 15 | 2011850 | ||
| 19 | 2011850 | ||
| 25 | 2011850 | ||
| 14 | 2011850 | ||
| 18 | 2011850 | ||
| 23 | 2011850 | ||
| 37 | 2011850 | ||
| 43 | 2011850 | ||
| 6 | 2011910 | ||
| 9 | 2017590 | ||
| 14 | 2022860 | ||
| 2 | 202459A9R0 | ||
| 16 | 2025220 | ||
| 6 | 2025220 | ||
| 28 | 2028750 | ||
| 12 | 2040230 | ||
| 34 | 2040230 | ||
| 30 | 2042930 | ||
| 5 | 2045200 | ||
| 36 | 2045200 | ||
| 47 | 2045850 | ||
| 9 | 2048880 | ||
| 24 | 2052340 | ||
| 15 | 2052340 | ||
| 10 | 2060550 | ||
| 3 | 2106800 | ||
| 4 | 2106810 | ||
| 8 | 2106820 | ||
| 10 | 2106830 | ||
| 11 | 2106840 | ||
| 2 | 2106850 | ||
| 15 | 2106860 | ||
| 16 | 2106870 | ||
| 36 | 2109300 | ||
| 10 | 2400620 | ||
| 10 | 2401040 | ||
| 32 | 2403050 | ||
| 30 | 2403320 | ||
| 4 | 2403330 | ||
| 32 | 2404730 | ||
| 27 | 2404750 | ||
| 28 | 2404810 | ||
| 35 | 2404820 | ||
| 33 | 2404820 | ||
| 21 | 2404820 | ||
| 19 | 2590040 | ||
| 10 | 259005B0 | ||
| 15 | 2590060 | ||
| 7 | 259006A0 | ||
| 12 | 2590140 | ||
| 17 | 259015A0 | ||
| 11 | 259015A0 | ||
| 2 | 259015A0 | ||
| 3 | 2590360 | ||
| 13 | 2590380 | ||
| 49 | 3002200 | ||
| 6 | 3004680 | ||
| 5 | 3004690 | ||
| 34 | 302444A0 | ||
| 33 | 302445A0 | ||
| 21 | 3024480 | ||
| 4 | 3024490 | ||
| 7 | 3024510 | ||
| 8 | 3024520 | ||
| 3 | 302453-RA0 | ||
| 4 | 302454-RA0 | ||
| 23 | 3024550 | ||
| 26 | 3024560 | ||
| 17 | 3024690 | ||
| 22 | 3024700 | ||
| 22 | 302474-910 | ||
| 1 | 302477A910 | ||
| 1 | 302500-910 | ||
| 28 | 3030670 | ||
| 38 | 3030670 | ||
| 20 | 3030670 | ||
| 7 | 3030670 | ||
| 6 | 3033350 | ||
| 31 | 3033350 | ||
| 27 | 3033350 | ||
| 29 | 3033350 | ||
| 37 | 3033350 | ||
| 11 | 3039910 | ||
| 1 | 305199A910 | ||
| 2 | 305200-910 | ||
| 15 | 3052020 | ||
| 5 | 3052020 | ||
| 35 | 3052030 | ||
| 7 | 3052040 | ||
| 1 | 305205-920 | ||
| 19 | 305205-920 | ||
| 1 | 305206-910 | ||
| 19 | 3052090 | ||
| 21 | 3052100 | ||
| 11 | 305211-910 | ||
| 12 | 305212-910 | ||
| 29 | 3052150 | ||
| 34 | 305216-910 | ||
| 37 | 3052180 | ||
| 14 | 3052190 | ||
| 13 | 3052200 | ||
| 17 | 3052210 | ||
| 31 | 3052220 | ||
| 26 | 3052230 | ||
| 25 | 3052240 | ||
| 25 | 3052250 | ||
| 1 | 305226A910 | ||
| 2 | 3052270 | ||
| 6 | 305228-910 | ||
| 12 | 3052300 | ||
| 16 | 3052310 | ||
| 19 | 3052320 | ||
| 21 | 3052330 | ||
| 15 | 3052340 | ||
| 25 | 3052350 | ||
| 26 | 3052360 | ||
| 40 | 3052370 | ||
| 29 | 3052380 | ||
| 33 | 3052390 | ||
| 8 | 3053600 | ||
| 4 | 3067310 | ||
| 7 | 3067330 | ||
| 13 | 306733A0 | ||
| 29 | 3068290 | ||
| 30 | 306830B | ||
| 9 | 3069260 | ||
| 23 | 308541-910 | ||
| 24 | 308542-910 | ||
| 1 | 308543-910 | ||
| 2 | 308544-910 | ||
| 31 | 3085480 | ||
| 27 | 3503360 | ||
| 48 | 3506430 | ||
| 44 | 350645-910 | ||
| 27 | 3506650 | ||
| 22 | 5131070 | ||
| 35 | 5131080 | ||
| 16 | 5140010 | ||
| 20 | 5270020 | ||
| 23 | 5270020 | ||
| 38 | 5270060 | ||
| 56 | 5320010 | ||
| 3 | 5320010 | ||
| 2 | 532007-910 | ||
| 12 | 6000150 | ||
| 15 | 6000240 | ||
| 21 | 6000320 | ||
| 60 | 6000320 | ||
| 62 | 6000770 | ||
| 61 | 6000780 | ||
| 22 | 6001010 | ||
| 24 | 6001750 | ||
| 8 | 6010020 | ||
| 10 | 6010430 | ||
| 23 | 6010890 | ||
| 39 | 6010970 | ||
| 59 | 6011070 | ||
| 58 | 6011150 | ||
| 24 | 6011200 | ||
| 55 | 6A028100000 | ||
| 23 | 7480020 | ||
| 40 | 7480150 | ||
| 42 | 7480420 | ||
| 54 | 7E2004A0000 | ||
| 39 | 9A30690 | ||
| 43 | 9A30690 | ||
| 1 | 9A90500 |
インデックス INDEX PART NO. PAGE REF.NO. PART NO. PAGE REF.NO. PART NO. PAGE REF.NO. 0001970 13 45 2025220 9 6 3052240 9 25 0012020 11 19 2028750 11 28 3052250 5 25 0029060 11 12 2040230 9 12 305226A910 13 1 0030440 11 7 2040230 9 34 3052270 13 2 0030440 13 51 2042930 9 30 305228-910 13 6 0030440 17 5 2045200 7 5 3052300 13 12 0040260 5 30 2045200 7 36 3052310 13 16 0040260 9 28 2045850 13 47 3052320 13 19 0041090 17 9 2048880 13 9 3052330 13 21 0043200 15 16 2052340 13 24 3052340 13 15 0045020 7 25 2060550 13 10 3052350 13 25 0045020 9 36 2106800 11 3 3052360 13 26 0045020 15 19 2106810 11 4 3052370 13 40 0045110 7 11 2106820 11 8 3052380 13 29 0045110 7 16 2106830 11 10 3052390 13 33 0045270 13 28 2106840 11 11 3053600 17 8 0045380 5 26 2106850 11 2 3067310 15 4 0045430 7 8 2106860 11 15 3067330 15 7 0045540 7 4 2106870 11 16 306733A0 15 13 0045540 13 34 2109300 13 36 3068290 7 29 0048180 13 8 2400620 5 10 306830B 7 30 0048200 7 26 2401040 17 10 3069260 7 9 0048200 9 39 2403050 9 32 308541-910 7 23 0048200 15 21 2403320 13 30 308542-910 7 24 0048210 17 11 2403330 13 4 308543-910 5 1 0049050 5 3 2404730 5 32 308544-910 5 2 0049050 5 38 2404750 5 27 3085480 7 31 0049050 7 22 2404810 5 28 3503360 13 27 0049050 17 12 2404820 5 35 3506430 13 48 0049100 13 46 2404820 9 33 350645-910 13 44 0049200 9 41 2404820 7 21 3506650 9 27 0049210 15 18 2590040 7 19 5131070 5 22 0050120 11 27 259005B0 7 10 5131080 13 35 0050530 11 9 2590060 7 15 5140010 9 16 0050880 11 17 259006A0 7 7 5270020 9 20 0051180 13 52 2590140 7 12 5270020 5 23 0051830 13 50 259015A0 7 17 5270060 13 38 0051840 11 5 259015A0 9 11 5320010 15 56 0053320 7 6 259015A0 7 2 5320010 15 3 0053320 7 35 2590360 7 3 532007-910 15 2 0054530 17 6 2590380 7 13 6000150 15 12 0055460 5 9 3002200 13 49 6000240 15 15 0070110 5 33 3004680 15 6 6000320 9 21 007018A0 11 24 3004690 15 5 6000320 13 60 0070200 9 14 302444A0 7 34 6000770 13 62 0070200 13 5 302445A0 7 33 6000780 13 61 0070210 13 31 3024480 11 21 6001010 9 22 0070210 13 41 3024490 5 4 6001750 5 24 007021A0 11 13 3024510 5 7 6010020 15 8 0070240 13 22 3024520 5 8 6010430 15 10 0070260 13 3 302453-RA0 17 3 6010890 15 23 0070680 7 13 302454-RA0 17 4 6010970 13 39 0070680 7 18 3024550 11 23 6011070 13 59 0070680 7 20 3024560 11 26 6011150 13 58 0070730 5 18 3024690 15 17 6011200 9 24 0070730 9 8 3024700 15 22 6A028100000 13 55 0071300 5 13 302474-910 11 22 7480020 9 23 0071300 5 20 302477A910 15 1 7480150 9 40 0071300 9 3 302500-910 11 1 7480420 9 42 0071300 9 18 3030670 7 28 7E2004A0000 13 54 0071300 13 13 3030670 9 38 9A30690 5 39 0071430 13 17 3030670 15 20 9A30690 9 43 0071430 13 20 3030670 17 7 9A90500 17 1 0071600 13 7 3033350 5 6 0072800 9 10 3033350 5 31 0072810 13 32 3033350 7 27 0072810 13 42 3033350 9 29 0W00128-20 13 11 3033350 9 37 1371420 13 53 3039910 15 11 1375580 15 14 305199A910 9 1 1670660 11 18 305200-910 9 2 1670660 11 20 3052020 5 15 1D001400000 13 57 3052020 9 5 2007280 5 36 3052030 9 35 2007280 7 32 3052040 9 7 2011850 5 14 305205-920 5 1 2011850 9 4 305205-920 9 19 2011850 9 15 305206-910 7 1 2011850 9 19 3052090 5 19 2011850 11 25 3052100 5 21 2011850 13 14 305211-910 5 11 2011850 13 18 305212-910 5 12 2011850 13 23 3052150 5 29 2011850 13 37 305216-910 5 34 2011850 13 43 3052180 5 37 2011910 11 6 3052190 7 14 2017590 15 9 3052200 9 13 2022860 11 14 3052210 9 17 202459A9R0 17 2 3052220 9 31 2025220 5 16 3052230 9 26 18 jintex.in
Page 21
jintex.in jintex.in
Page 22
jintex.in
Page 23
jintex.in jintex.in
Page 24
ペガサスミシン製造株式会社 本社 〒 553-0002 大阪市福島区鷺洲 5-7-2 TEL (06)6458-4739 FAX (06)6454-8785 PEGASUS SEWING MACHINE MFG. CO., LTD. 5-7-2, Sagisu, Fukushima-ku, Osaka 553-0002, Japan. Phone : (06)6458-4739 Telefax: (06)6454-8785 Cat. No. 97520 February 2007 © 1997 PEGASUS SEWING MACHINE MFG. CO., LTD. このパーツカタログに記載されている内容は、改良のため予告なく変更することがあります。 The description in this PARTS CATALOG is subject to change without prior notice. jintex.in
