Pegasus R57L — Part Book

Pegasus R57L — parts catalog

Page 16 (diagram): This page contains a diagram of various sewing machine parts, with reference numbers indicating their location. The page is numbered 14.
Page 17 (parts_list): This page lists parts for the Lower Looper Drive Mechanism, including part numbers, names, quantities, and torque specifications.
Page 18 (diagram): This page displays a diagram of sewing machine parts, with numbered components and their corresponding part numbers and descriptions.
Page 19 (parts_list): This page lists parts for the Feed Drive Mechanism (For R57L-14S and R57L-19 only), including part numbers, names, and quantities.
Page 20 (diagram): This page contains a diagram of various sewing machine parts, including screws, nuts, bearings, and levers, with reference numbers for each component.
Page 21 (parts_list): This page lists parts for the Feed Drive Mechanism (R57L-02) with part numbers, names, and quantities.
Page 22 (diagram): This page displays a diagram of various sewing machine components, with numbered references for each part.
Page 23 (parts_list): This page lists parts for the Upper and Lower Knife Drive Mechanism, including part numbers, names, quantities, and torque specifications.
Page 24 (diagram): This page displays a diagram of various sewing machine parts, including levers, springs, screws, and brackets, with reference numbers for each component.
Page 25 (parts_list): This page lists parts for the Presser Foot and Lift Mechanism, including part numbers, names, quantities, and torque specifications.
Page 26 (diagram): This page displays a diagram of various sewing machine components, including a filter assembly, pump housing, and gasket, with numbered references for each part.
Page 27 (parts_list): This page lists parts for the Pump Lubricating Mechanism, including part numbers, names, quantities, and torque specifications.
Page 28 (diagram): This page displays a diagram of various machine parts, including screws, brackets, and covers, with reference numbers for identification.
Page 29 (parts_list): This page lists accessories for semi-submerged installation, including machine rest boards, bolts, nuts, washers, and screws, with their respective part numbers, quantities, and descriptions.
Page 30 (diagram): This page displays a diagram of various sewing machine parts, including screws, nuts, brackets, and other components, identified by reference numbers.

Page 16

Pegasus R57L parts on page 16
Ref	Part number	Part name
1	1	CLAMP
2	2	SCREW
3	3	SCREW
4	4	SCREW
5	5	SCREW
6	6	WASHER
7	7	SHAFT
8	8	SCREW
9	9	COLLAR
10	10	BRACKET
11	11	SHAFT
12	12	COLLAR
13	13	COLLAR
14	14	WASHER
15	15	BRACKET
16	16	SCREW
17	17	LEVER
18	18	SCREW
19	19	BRACKET
20	20	SPRING
21	21	WASHER
22	22	COLLAR
23	23	WASHER
24	24	SPRING
25	25	PLATE
26	26	BRACKET
28	28	SCREW
29	29	SCREW
30	30	SCREW
31	31	SCREW
32	32	BRACKET
33	33	SCREW
34	34	WASHER
35	35	BRACKET
36	36	SCREW
37	37	BRACKET
38	38	SCREW
39	39	SHAFT
40	40	BRACKET
41	41	BRACKET
42	42	SCREW

14- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 17 — LOWER LOOPER DRIVE MECHANISM

Pegasus R57L parts on page 17
Ref	Part number	Part name
1	201073 B	Lower looper drive connection
2	5002	cap screw (large)
3	1170-1	" (small)
4	201074 A	guide
5	1156	" screw
6	202286	" spring washer
7	201075	ball stud
8	5048	" screw
9	205592	Lower looper drive crank
10	5385	screw
11	205593	Lower looper lever shaft
12	201081 A	bushing
13	202923	oil seal
14	206055	thrust washer
15	205594	Lower looper lever
16	5274	clamp screw
17	205655	Lower looper
18	5328	screw
18	202480	Lower looper thread tension, complete with 201035A, 202278, 201086 201039, 201482×2 & 5082A
19	201035 A	nut
20	202278	spring bushing
21	201086	spring (middle)
22	201039	spring cup
23	201482	disc
24	5082 A	post
25	202849	guide
26	201089	Lower looper thread guide
27	2921	screw
28	202875	" washer
29	201048 A	Lower looper thread eyelet
30	201048 A	Lower looper thread eyelet
31	1459	screw
32	202860	Lower looper thread guide
33	2921	" screw
34	202875	" washer
35	205596	Lower looper thread takeup
36	2921	screw
37	201088	bracket
38	1202	screw
39	201091	Lower looper thread tube
40	1892	screw
41	205597	bracket
42	1175-2	screw

LOWER LOOPER DRIVE MECHANISM Ref. No. Part No. Name 参照番号部品番号 1 201073 B Lower looper drive connection 2 5002 cap screw (large) 3 1170-1 " (small) 4 201074 A guide 5 1156 " screw 6 202286 " spring washer 7 201075 ball stud 8 5048 " screw 9 205592 Lower looper drive crank 10 5385 screw 11 205593 Lower looper lever shaft 12 201081 A bushing 13 202923 oil seal 14 206055 thrust washer 15 205594 Lower looper lever 16 5274 clamp screw 17 205655 Lower looper 18 5328 screw 202480 Lower looper thread tension, complete with 201035A, 202278, 201086 201039, 201482×2 & 5082A 19 201035 A nut 20 202278 spring bushing 21 201086 spring (middle) 22 201039 spring cup 23 201482 disc 24 5082 A post 25 202849 guide 26 201089 Lower looper thread guide 27 2921 screw 28 202875 " washer 29 201048 A Lower looper thread eyelet 30 201048 A Lower looper thread eyelet 31 1459 screw 32 202860 Lower looper thread guide 33 2921 " screw 34 202875 " washer 35 205596 Lower looper thread takeup 36 2921 screw 37 201088 bracket 38 1202 screw 39 201091 Lower looper thread tube 40 1892 screw 41 205597 bracket 42 1175-2 screw -15- From the library of: Superior Sewing Machine & Supply LLC jintex.in 名称トルク Qt. 数量下ルーバーロッド 1 蓋止ネジ (大) (35kg-cm) 2 蓋止ネジ (小) (30kg-cm) 2 振止メ 1 止ネジ (35kg-cm) 1 バネ座金 1 球 1 止ネジ (30kg-cm) 1 下ルーバークランク 2 止ネジ (80kg-cm) 1 下ルーバー台軸 1 ブッシュ 2 油受 1 スラスト座金 1 下ルーバー台 1 抱締ネジ (70kg-cm) 1 下ルーバー 1 止ネジ (25kg-cm) 1 下ルーバー糸調子(組)(34頁参照) 1 201035 A, 202278, 201086 201039, 201482×2, 5082 A/組ナット 1 止パイプ 1 バネ (中) 1 受皿 1 皿 1 棒 (25kg-cm) 1 台 1 下ルーバー糸道 1 止ネジ (20kg-cm) 1 座金 1 下ルーバー上糸道 1 下ルーバー前糸道 1 止ネジ (15kg-cm) 1 補助糸道(A) 1 止ネジ (20kg-cm) 1 座金 1 下ルーバー糸捌キ 1 止ネジ (20kg-cm) 1 取付台 1 止ネジ (25kg-cm) 1 下ルーバー糸道パイプ(長) 1 止ネジ (15kg-cm) 1 取付台 1 止ネジ (25kg-cm) 2

Page 18

Pegasus R57L parts on page 18
Ref	Part number	Part name
2	R57L-19	2
3	3	3
4	4	4
1	1	1
18	18	18
19	19	19
20	20	20
21	21	21
22	22	22
23	23	23
24	24	24
25	25	25
26	26	26
13	13	13
14	14	14
12	12	12
10	10	10
11	11	11
5	5	5
15	15	15
16	16	16
6	6	6
8	8	8
9	9	9

R57L-19 2 3 4 2 1 18 19 20 21 22 23 24 25 26 13 14 12 10 11 5 15 16 6 8 9 -16- From the library of: Superior Sewing Machine & Supply LLC JIntex.in

Page 19 — FEED DRIVE MECHANISM

Pegasus R57L parts on page 19
Ref	Part number	Part name
1	205598	Feed bar
2	205599	Feed dog
3	205656	Feed dog
4	1202	screw
5	205498	Feed connecting link
6	201099	bushing
7	201100	screw
8	3044	nut
9	200098	washer
10	205500-5	Feed eccentric #5
11	205500-6	Feed eccentric #6
12	205501	needle bearing
13	205587	Feed connecting link collar
14	5213	Feed eccentric lock nut
15	206126	washer
16	205600	Feed bar lift block
17	205601	needle bearing
18	205602	retaining ring
19	201107	Feed bar guide block
20	202566	collar
21	202200	pin
22	2022	screw
23	205603	Feed bar guide (left)
24	1175-3	screw
25	167066	washer
26	205604	Feed bar guide (right)
27	5095	screw

FEED DRIVE MECHANISM (For R57L-14S and R57L-19 only) 1枚送り機構 (R57L-14S, 19用) Ref. No. Part No. Name Torque Qt. 参照番号部品番号名称トルク数量 1 205598 Feed bar 送り台 1 2 205599 Feed dog 送り歯 1 3 205656 Feed dog 1 4 1202 screw 止ネジ (20kg-cm) 1 5 205498 Feed connecting link 送り連結杆 1 6 201099 bushing ブッシュ 1 7 201100 screw 止ネジ 1 8 3044 nut ナット (30kg-cm) 1 9 200098 washer 座金 1 10 205500-5 Feed eccentric #5 送りエキセン #5 1 11 205500-6 Feed eccentric #6 #6 1 12 205501 needle bearing ニードルベアリング 1 13 205587 Feed connecting link collar 送り連結杆カラー 1 14 5213 Feed eccentric lock nut 送りエキセン止ナット (35kg-cm) 1 15 206126 washer 座金 1 16 205600 Feed bar lift block 送り上下角玉 1 17 205601 needle bearing ニードルベアリング 1 18 205602 retaining ring 止輪 1 19 201107 Feed bar guide block 送り台案内角玉 1 20 202566 collar カラー 1 21 202200 pin ピン 1 22 2022 screw 止ネジ (25kg-cm) 1 23 205603 Feed bar guide (left) 送り台案内(左) 2 24 1175-3 screw 止ネジ (25kg-cm) 2 25 167066 washer 座金 2 26 205604 Feed bar guide (right) 送り台案内(右) 1 27 5095 screw 止ネジ (35kg-cm) 2 印意味 Meaning Mark ① R57L-14S専用部品 Parts for R57L-14S only ② R57L-19専用部品 Parts for R57L-19 only ③ R57L-02専用部品 Parts for R57L-02 only -17- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 20

Pegasus R57L parts on page 20
Ref	Part number	Part name
35	35	Screw
30	30	Screw
34	34	Lever
17	17	Nut
18	18	Washer
15	15	Screw
16	16	Lever
23	23	Nut
24	24	Washer
22	22	Bearing
21	21	Shaft
14	14	Housing
19	19	Screw
20	20	Gear
13	13	Washer
12	12	Nut
10	10	Pin
27	27	Nut
25	25	Washer
26	26	Bearing
9	9	Spring
8	8	Screw
7	7	Lever
6	6	Screw
5	5	Lever
3	3	Lever
4	4	Screw
2	2	Lever
1	1	Lever
11	11	Screw
28	28	Nut
29	29	Pin
31	31	Screw
33	33	Washer
32	32	Screw

18 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 21 — FEED DRIVE MECHANISM (FOR R57L-02 ONLY)

Pegasus R57L parts on page 21
Ref	Part number	Part name
1	205664	Main feed bar
2	205598	Differential feed bar
3	205660	Main feed dog
4	1175-2	screw
5	205661	Auxiliary feed dog
6	2922	screw
7	205662	Diff. feed dog
8	1202	screw
9	205499	Main feed connecting link
10	201099	bushing
11	201100	screw
12	3044	nut
13	200098	washer
14	205498	Diff. feed connecting link
15	201099	bushing
16	201100	screw
17	3044	nut
18	200098	washer
19	205500-12	Main feed eccentric #12
20	205501	needle bearing
21	205500-10	Diff. feed eccentric #10
22	205501	needle bearing
23	5213	Feed eccentric lock nut
24	206126	washer
25	205600	Feed bar lift block
26	205601	needle bearing
27	205602	retaining ring
28	201107	Feed bar guide block
29	202200	pin
30	2022	screw
31	205603	Feed bar guide (left)
32	1175-3	screw
33	167066	washer
34	205604	Feed bar guide (right)
35	5095	screw

FEED DRIVE MECHANISM (FOR R57L-02 ONLY) 2 枚送り機構 (R57L-02用) Ref. No. 参照番号 Part No. 部品番号 Name 称 Torque トルク Qt. 数量 1 205664 Main feed bar 主送り台 1 2 205598 Differential feed bar 差動送り台 1 3 205660 Main feed dog 主送り歯 1 4 1175-2 screw 止ネジ (25kg-cm) 1 5 205661 Auxiliary feed dog 補助送り歯 1 6 2922 screw 止ネジ (15kg-cm) 1 7 205662 Diff. feed dog 差動送り歯 1 8 1202 screw 止ネジ (25kg-cm) 1 9 205499 Main feed connecting link 主送り連結杆 1 10 201099 bushing ブッシュ 1 11 201100 " screw 止ネジ 1 12 3044 " nut ナット (30kg-cm) 1 13 200098 " washer 座金 1 14 205498 Diff. feed connecting link 差動送り連結杆 1 15 201099 bushing ブッシュ 1 16 201100 " screw 止ネジ 1 17 3044 " nut ナット (30kg-cm) 1 18 200098 " washer 座金 1 19 205500-12 Main feed eccentric #12 主送りエキセン #12 1 20 205501 needle bearing ニードルベアリング 1 21 205500-10 Diff. feed eccentric #10 差動送りエキセン #10 1 22 205501 needle bearing ニードルベアリング 1 23 5213 Feed eccentric lock nut 送りエキセンロックナット (35kg-cm) 1 24 206126 washer 座金 1 25 205600 Feed bar lift block 送り上昇角玉 1 26 205601 needle bearing ニードルベアリング 1 27 205602 retaining ring 止メ輪 2 28 201107 Feed bar guide block 送り台案内角玉 1 29 202200 pin ピン 1 30 2022 screw 止ネジ (25kg-cm) 1 31 205603 Feed bar guide (left) 送り台案内 (左) 1 32 1175-3 screw 止ネジ (25kg-cm) 2 33 167066 washer 座金 2 34 205604 Feed bar guide (right) 送り台案内 (右) 1 35 5095 screw 止ネジ (35kg-cm) 2 印 Mark 意 Meaning 味 ① R57L-14S専用部品 Parts for R57L-14S only ② R57L-19 専用部品 Parts for R57L-19 only ③ R57L-02 専用部品 Parts for R57L-02 only -19- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 22

Pegasus R57L parts on page 22
Ref	Part number	Part name
1	1	SCREW
2	2	SCREW
3	3	SHAFT
4	4	SCREW
5	5	BRACKET
6	6	SCREW
7	7	LEVER
8	8	COLLAR
9	9	RING
10	10	COLLAR
11	11	SCREW
12	12	ARM
13	13	SCREW
14	14	PLATE
15	15	SCREW
16	16	BRACKET
17	17	SCREW
18	18	BRACKET
19	19	SCREW
20	20	SCREW
21	21	PLATE
22	22	SHAFT
23	23	SCREW
24	24	SPRING
25	25	BRACKET
26	26	SCREW
27	27	BRACKET
28	28	SCREW
29	29	SHAFT
30	30	COLLAR
31	31	WASHER

From the library of: Superior Sewing Machine & Supply LLC jintex.in - 20 -

Page 23 — UPPER AND LOWER KNIFE DRIVE MECHANISM

Pegasus R57L parts on page 23
Ref	Part number	Part name
1	202925	Upper knife drive connection
2	5187	cap screw
3	205495	pin
4	1457	screw
5	201360 B	Upper knife drive crank
6	5381	clamp screw
7	205605	Upper knife lever
8	201115 A	shaft bushing
9	202927	oil seal
10	201117	thrust collar
11	5084	screw
12	205606	Upper knife lever guide
13	2022	screw
14	205607	Upper knife
15	5088	screw
16	205608	clamp holder
17	1175-2	clamp screw
18	202638 B	guide
19	1189	screw
20	201125	pin
21	205609	Lower knife
22	205610	holder
23	4009-1	screw
24	201129	spring
25	201130 A	retainer
26	1175-3	screw
27	205611	guide
28	1175-3	screw
29	201132 B	clamp stud
30	5260	nut
31	201134	washer

UPPER AND LOWER KNIFE DRIVE MECHANISM Ref. No. 参照番号 Part No. 部品番号 Name 1 202925 Upper knife drive connection 2 5187 cap screw 3 205495 pin 4 1457 " screw 5 201360 B Upper knife drive crank 6 5381 clamp screw 7 205605 Upper knife lever 8 201115 A shaft bushing 9 202927 oil seal 10 201117 thrust collar 11 5084 " screw 12 205606 Upper knife lever guide 13 2022 screw 14 205607 Upper knife 15 5088 screw 16 205608 clamp holder 17 1175-2 " clamp screw 18 202638 B " guide 19 1189 " screw 20 201125 " pin 21 205609 Lower knife 22 205610 holder 23 4009-1 " screw 24 201129 " spring 25 201130 A " retainer 26 1175-3 " screw 27 205611 " guide 28 1175-3 " screw 29 201132 B clamp stud 30 5260 " nut 31 201134 " washer 名称 Torque トルク Qt. 数量上メスロッド 1 蓋止ネジ (35kg-cm) 2 ピン 1 止ネジ (30kg-cm) 1 上メスクランク 1 抱締ネジ (100kg-cm) 1 上メス台 (34頁参照) 1 軸ブッシュ 2 オイルシール 1 スラストカラー 1 止ネジ (25kg-cm) 2 上メス台案内 1 止ネジ 1 上メス (30kg-cm) 1 止ネジ 1 抱キ 1 抱締ネジ (25kg-cm) 1 抱キ案内 1 止ネジ (20kg-cm) 1 ピン 1 下メス 1 台 1 止ネジ (25kg-cm) 1 押バネ 1 押工 1 止ネジ (25kg-cm) 1 案内板 2 止ネジ (25kg-cm) 1 止ピン 1 ナット (25kg-cm) 1 座金 1 -21- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 24

Pegasus R57L parts on page 24
Ref	Part number	Part name	Qty
	1	Lever
	2	Bracket
	3	Screw
	4	Pin
	5	Screw
	6	Screw
	7	Washer
	8	Lever
	9	Screw
	10	Bracket
	11	Bracket
	12	Bracket
	13	Screw
	14	Screw
	15	Lever
	16	Screw
	17	Lever
	18	Collar
	19	Collar
	20	Screw
	21	Lever
	22	Screw
	23	Sleeve
	24	Washer
	25	Bracket
	26	Screw
	27	Screw
	28	Screw
	29	Lever
	30	Washer
	31	Pin
	32	Screw
	33	Spring
	34	Lever
	35	Lever
	36	Bracket
	37	Lever
	38	Screw
	39	Washer
	40	Lever
	41	Bracket
	42	Lever

R57L-19 2 -22- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 25 — PRESSER FOOT AND LIFT MECHANISM

Pegasus R57L parts on page 25
Ref	Part number	Part name
1	205615	Presser arm
2	205529	stopper
3	4009-1	" screw
4	208549	hinge pin
5	5167	" screw
6	202451	Chain cutter knife
7	2921	" screw
8	208525	Presser foot holder
9	5136	clamp screw
10	205612	Presser foot
11	205657	Presser foot
12	205675	chaining-off finger
13	205613	" spring
14	5157	" screw
15	205614	regulator
16	1229	" screw
17	205618	Foot lift lever shaft
18	202589	bushing
19	201139	thrust collar
20	5084	" screw
21	205595	Presser bar, complete
22	208540	spring
23	205622	thumb screw
24	205549	" lock nut
25	205623	hand lift lever
26	5256	" " screw
27	202683	" " stopper
28	5345	" "
29	205624	Foot lift lever
30	202868	washer
31	201161	pin
32	2022	" screw
33	205625	spring
34	201165	connecting pin
35	201166	split pin
36	201167 A	bracket
37	5142	" screw
38	5097	regulating screw
39	3044	" lock nut
40	201163	Foot lift intermediate lever
41	205626	collar
42	5001	clamp screw

PRESSER FOOT AND LIFT MECHANISM 押工機構 Ref. No. 参照番号 Part No. 部品番号 Name 名称 Torque トルク Qt. 数量 1 205615 Presser arm 押工 1 2 205529 stopper ストッパー 1 3 4009-1 " screw 止ネジ 2 4 208549 hinge pin ヒンジピン 1 5 5167 " screw 止ネジ (25kg-cm) 1 6 202451 Chain cutter knife チェーンカッター 1 7 2921 " screw 止ネジ (20kg-cm) 1 8 208525 Presser foot holder 押工取付台 1 9 5136 clamp screw 締結ネジ 1 10 205612 Presser foot 押工 1 11 205657 Presser foot 押工 1 12 205675 chaining-off finger 爪 1 13 205613 " spring 取付板 1 14 5157 " screw 止ネジ (15kg-cm) 1 15 205614 regulator " screw 固定金 1 16 1229 " screw 止ネジ (25kg-cm) 1 17 205618 Foot lift lever shaft 押工台軸 1 18 202589 bushing ブッシュ 3 19 201139 thrust collar スラストカラー 1 20 5084 " screw 止ネジ (30kg-cm) 2 21 205595 Presser bar, complete 押工棒(組)(34頁参照) 1 22 208540 spring バネ 1 23 205622 thumb screw キャップ 1 24 205549 " lock nut ロックナット 1 25 205623 hand lift lever 手揚 1 26 5256 " " screw 段ネジ (30kg-cm) 1 27 202683 " " stopper ストッパー 1 28 5345 " " 足揚(大) 1 29 205624 Foot lift lever 足揚 1 30 202868 washer 座金 1 31 201161 pin ピン 1 32 2022 " screw 止ネジ (25kg-cm) 1 33 205625 spring バネ 1 34 201165 connecting pin 連結ピン 2 35 201166 split pin 割ピン 2 36 201167 A bracket 調節台 1 37 5142 " screw 止ネジ (25kg-cm) 2 38 5097 regulating screw 調節ネジ 2 39 3044 " lock nut ナット (30kg-cm) 2 40 201163 Foot lift intermediate lever 足揚(小) 1 41 205626 collar カラー 1 42 5001 clamp screw 抱締ネジ (35kg-cm) 1 印 Mark 意味 Meaning ① R57L-14S 專用部品 Parts for R57L-14S only ② R57L-19 專用部品 Parts for R57L-19 only ③ R57L-02 專用部品 Parts for R57L-02 only -23- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 26

Pegasus R57L parts on page 26
Ref	Part number	Part name
1	1	PUMP HOUSING
2	2	COVER
3	3	SCREW
4	4	SHAFT
5	5	GEAR
6	6	SHAFT
7	7	WASHER
8	8	SHAFT
9	9	PIN
10	10	FILTER
11	11	SCREW
12	12	SCREW
13	13	WASHER
14	14	TUBE
15	15	FILTER
16	16	HOUSING
17	17	COVER
18	18	O-RING
19	19	SCREW
20	20	WASHER
21	21	SCREW
22	22	BRACKET
23	23	PIN
24	24	BRACKET
25	25	BRACKET
26	26	SCREW
27	27	WASHER
28	28	HOUSING
29	29	GASKET
30	30	PLUG
31	31	WASHER
32	32	TUBE
33	33	CLAMP
34	34	TUBE
35	35	SPRING
36	36	PIN
37	37	FILTER
38	38	SPRING
39	39	VALVE
40	40	PIN

24 From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 27 — PUMP LUBRICATING MECHANISM

Pegasus R57L parts on page 27
Part number	Part name	Qty
205627	Gear pump, complete with parts of Ref. Nos. 1-11	1
205628	Gear pump housing, complete	2
201293 A	plate	1
5117	" screw	4
201294	Pump gear (left)	1
201295	Pump gear (right)	1
205631	Pump gear shaft (long), set with 201009	1
201009	key	1
204184	Pump gear shaft (short)	1
1458	screw	2
205632	Worm wheel	1
5060	screw	2
5094	Gear pump housing screw	2
204185	Pump outlet o ring	1
205635	Oil releif valve, complete	1
206233	Oil cleaner	1
206429	box	1
206430	" cover	1
206431	" o ring	1
5010	" screw	3
204185	" o ring	2
5186	" screw	2
205640	Oil distributor	1
202903	Oil plug	1
200152	screw	1
205535	Oil splash pipe, complete	1
201758	oil splash screw	1
201759	" washer	2
205641	Oil pan	1
208238	gasket	1
5138 B	oil drain screw	1
202287 A	" washer	1
205648	Oil pipe	1
1457	screw	1
202176	oil wick	1
205665	Oil level gauge	1
205666	bar, complete	1
205669	sight window	1
1435	" screw	1
205670	float, complete	1
205534	float guide pin	1

PUMP LUBRICATING MECHANISM 給油機構 Ref. No. 参照番号 Part No. 部品番号 Name 名称 Torque トルク Qt. 数量 1 205627 Gear pump, complete with parts of Ref. Nos. 1-11 ギャーポンプ(組)(34頁参照) 1 2 205628 Gear pump housing, complete ケーシング(組)(34頁参照) 2 3 201293 A plate 側板 1 4 5117 " screw 止ネジ (30kg-cm) 4 5 201294 Pump gear (left) ポンプギヤ(A) 1 6 201295 Pump gear (right) ポンプギヤ(B) 1 7 205631 Pump gear shaft (long), set with 201009 ギャーシャフト(A) 201009 トノ組 1 8 201009 key キー 1 9 204184 Pump gear shaft (short) ギャーシャフト(B) 1 10 1458 screw 止ネジ (25kg-cm) 2 11 205632 Worm wheel ウォームホイール 1 12 5060 screw 止ネジ (30kg-cm) 2 13 5094 Gear pump housing screw ケーシング(組)止ネジ (30kg-cm) 2 14 204185 Pump outlet o ring ポンプ吐出口 Oリング 1 15 205635 Oil releif valve, complete 安全弁(組)(34参照) 1 16 206233 Oil cleaner エレメント 1 17 206429 box ボックス 1 18 206430 " cover 蓋 1 19 206431 " o ring Oリング 1 20 5010 " screw 止ネジ (25kg-cm) 3 21 204185 " o ring Oリング 2 22 5186 " screw 止ネジ (50kg-cm) 2 23 205640 Oil distributor 油配分器 1 24 202903 Oil plug 油栓 1 25 200152 screw 止ネジ (35kg-cm) 1 26 205535 Oil splash pipe, complete 噴油管(組)(34頁参照) 1 27 201758 oil splash screw 継手(雄) (30kg-cm) 1 28 201759 " washer パッキン 2 29 205641 Oil pan オイルパン 1 30 208238 gasket パッキン 1 31 5138 B oil drain screw 排油穴蓋ネジ (35kg-cm) 1 32 202287 A " washer パッキン 1 33 205648 Oil pipe 送り台案内角玉給油パイプ 1 34 1457 screw 止ネジ (20kg-cm) 1 35 202176 oil wick 給油紐 1 36 205665 Oil level gauge オイルゲージ 1 37 205666 bar, complete 棒(組)(34頁参照) 1 38 205669 sight window 窓 1 39 1435 " screw 止ネジ (20kg-cm) 1 40 205670 float, complete フロート(組)(34頁参照) 1 41 205534 float guide pin 案内ピン 1 -25- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 28

Pegasus R57L parts on page 28
Ref	Part number	Part name
1	1	SCREW
2	2	SCREW
3	3	SCREW
4	4	SCREW
5	5	SCREW
6	6	SCREW
7	7	SCREW
8	8	SCREW
9	9	SCREW
10	10	SCREW
11	11	SCREW
12	12	COVER
13	13	SCREW
14	14	COVER

11 5 10 8 9 4 7 6 3 2 1 13 12 14 - 26 - From the library of: Superior Sewing Machine & Supply LLC jintex.in

Page 29 — ACCESSORIES FOR SEMI-SUBMERGED INSTALLATION

Pegasus R57L parts on page 29
Ref	Part number	Part name
1	208231	Machine rest board
	9008	bolt set, with
2	206335	bolt
3	202700	nut washer (large)
4	206337	" " (small)
5	206336	" nut
	9002	cushion rubber set, with
6	202765	cushion rubber (upper)
7	202693 A	" " (lower)
	9016	cushion rubber set, with
8	206338	Machine cushion rubber
9	5232	guide pin
10	205470	Waste chute top
11	175	screw
12	205468	Waste chute
13	5019	screw
14	205469	Waste chute extension

ACCESSORIES FOR SEMI-SUBMERGED INSTALLATION 半沈床式据付付属品 Ref. No. 参照番号 Part No. 部品番号 Name 名称 Torque トルク Qt. 数量 1 208231 9008 Machine rest board bolt set, with 206335×4, 206336×4, 206337×4 & 202700×4 半沈床式ミシン取付板ボルト(組)(34頁参照) 206335×4、206336×4 206337×4、202700×4/組 2 206335 bolt 4 3 202700 " nut washer (large) 座金 4 4 206337 " " (small) 4 5 206336 " nut ナット 4 9002 cushion rubber set, with 202693A×4 & 202765×4 クッションゴム(組)(34頁参照) 202693 A×4、202765×4/組 1 6 202765 cushion rubber (upper) クッションゴム 4 7 202693 A " " (lower) 4 9016 cushion rubber set, with 206338×4 クッションゴム(組)(34頁参照) 206338×4/組 1 8 206338 Machine cushion rubber クッションゴム 4 9 5232 guide pin 案内ピン 4 10 205470 Waste chute top 切クズ受(C) 1 11 175 screw 止ネジ 2 12 205468 Waste chute 切クズ受(A) 1 13 5019 screw 止ネジ 3 14 205469 Waste chute extension 切クズ受(B) 1 -27- From the library: Superior Sewing Machine & Supply LLC jintex.in

Page 30

Pegasus R57L parts on page 30
Ref	Part number	Part name
1	1	Rod
2	2	Nut
3	3	Rod
4	4	Bracket
5	5	Screw
6	6	Screw
7	7	Bracket
8	8	Rod
9	9	Nut
10	10	Nut
11	11	Nut
12	12	Base
13	13	Wing Nut
14	14	Lever
15	15	Screw
16	16	Shaft
17	17	Arm
18	18	Screw
19	19	Screw
20	20	Bracket
21	21	Screw
22	22	Nut
23	23	Screw
24	24	Screw
25	25	Nut
27	27	Screw
28	28	Lever
29	29	Screw
30	30	Bracket
31	31	Screw
32	32	Bracket
33	33	Screw
34	34	Screw

28 27 28 30 31 18 18 14 15 19 24 22 20 21 23 25 13 12 8 9 10 11 1 2 3 5 4 6 7 33 32 34 -28- From the library of: Superior Sewing Machine & Supply LLC jintex.in

Part Books

Search
