Yamato FD-62G — parts catalog
- Page 1 (cover): This is the cover page for the Yamato FD-62G Feed-Off-The-Arm Machine for Flat Seaming parts list. It features the Yamato logo, the machine model, and a line drawing of the machine.
- Page 2 (cover): This is the cover page of a parts catalog from the library of Superior Sewing Machine & Supply LLC, featuring a watermark of "jintex.in".
- Page 3 (text): This page provides instructions on how to read the parts list, explains symbols used, and gives guidance on how to order parts, specifically mentioning the FD-62G-01MR model.
- Page 4 (toc): This page is a table of contents listing various machine parts and mechanisms, along with their corresponding page numbers. It includes sections for miscellaneous covers, thread eyelets, bushings, crankshaft and needle bar driving mechanisms, presser foot mechanisms, and various driving mechanisms for feeders and controls, as well as lubricating mechanisms. It also lists exclusive parts for specific FD-62G models.
- Page 5 (toc): This page is a table of contents listing various parts and their corresponding page numbers, including exclusive parts, devices, accessories, and tools.
- Page 7 (parts_list): This page lists miscellaneous covers and related parts for an industrial sewing machine, including screws, nuts, gaskets, and other components with their part numbers, descriptions, and quantities required.
- Page 9 (parts_list): This page lists miscellaneous covers and related parts, including screws, seals, nuts, emblems, and guards, with their corresponding part numbers and quantities required.
- Page 13 (parts_list): This page lists miscellaneous thread eyelet parts with their part numbers, descriptions, and quantities required. It includes items like thread guide plates, screws, bushings, and felt components.
- Page 14 (diagram): This page displays a diagram of sewing machine parts, with numbered components and their corresponding part numbers and descriptions.
- Page 15 (parts_list): This page lists miscellaneous thread eyelet parts with their corresponding part numbers, descriptions, and quantities required.
- Page 16 (diagram): This page displays a diagram of sewing machine components, with numbered parts indicated for reference. It includes parts such as bearings, shafts, and housing components.
- Page 17 (parts_list): This page lists miscellaneous bushings and related parts with their part numbers, descriptions, and quantities required. It includes items like adapters, bearings, screws, oil seals, and various types of bushings.
- Page 18 (diagram): This page displays a diagram of various sewing machine components, including gears, shafts, screws, and a needle plate, with reference numbers for each part.
- Page 19 (parts_list): This page lists parts for the Crankshaft & Needle Bar Driving Mechanism, including part numbers, descriptions, and quantities required.
- Page 20 (diagram): This page displays a diagram of various sewing machine parts, including a main assembly and accessory parts, with reference numbers for each component.
- Page 21 (parts_list): This page lists parts for the Presser Foot Mechanism, including part numbers, descriptions, and quantities required.
- Page 22 (diagram): This page displays a diagram of various sewing machine components and accessory parts, with numbered references for each part.
- Page 23 (parts_list): This page lists parts for the Presser Foot Mechanism, including part numbers, descriptions, and quantities required.
- Page 24 (diagram): This page displays a diagram of various sewing machine components, including part numbers and reference numbers for identification.
- Page 25 (parts_list): This page lists parts for the Upper Knife, Carrier and Hook Driving Mechanism, including part numbers, descriptions, and quantities required.
- Page 26 (diagram): This page displays a diagram of various machine components, including part numbers and reference numbers for identification.
- Page 27 (parts_list): This page lists parts for the Looper Driving Mechanism, including part numbers, descriptions, and quantities required.
- Page 28 (diagram): This page displays a diagram of various sewing machine components, including screws, nuts, shafts, and linkages, with reference numbers and some dimensional callouts.
- Page 29 (parts_list): This page lists parts for the FEED DRIVING MECHANISM, including part numbers, descriptions, and quantities required.
- Page 30 (diagram): This page displays a diagram of various sewing machine components, including screws, levers, and brackets, with corresponding reference numbers for identification.
Page 1
Yamato FD-62G parts on page 1| Ref | Part number | Part name | Qty |
|---|
| FD-62G-01MR | FD-62G-01MR | |
| FD-62G-01MS | FD-62G-01MS | |
| FD-62G-03MR | FD-62G-03MR | |
| FD-62G-03MS | FD-62G-03MS | |
| FD-62G-06MR | FD-62G-06MR | |
| FD-62G-07MS | FD-62G-07MS | |
| FD-62G-12MR | FD-62G-12MR | |
| FD-62G-12MS | FD-62G-12MS | |
| FD-62G-12HR | FD-62G-12HR | |
| FD-62G-12HS | FD-62G-12HS | |
| FD-62G-15MS | FD-62G-15MS | |
| FDL-4 | FDL-4 | |
| AC | AC | |
| AC1/SC3 | AC1/SC3 | |
| SC3 | SC3 | |
| SC4 | SC4 | |
| RF | RF | |
| AC16 | AC16 | |
| RF/AC16 | RF/AC16 | |
Yamato
Parts List
FEED-OFF-THE-ARM MACHINE FOR FLAT SEAMING
FD-62G
MODELS & DEVICES
FD-62G-01MR FD-62G-01MS FD-62G-03MR
FD-62G-03MS FD-62G-06MR FD-62G-07MS
FD-62G-12MR FD-62G-12MS FD-62G-12HR
FD-62G-12HS FD-62G-15MS
FDL-4 AC AC1/SC3 SC3 SC4 RF AC16 RF/AC16
YAMATO SEWING MACHINE MFG. CO.,LTD.
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 2
jintex.in
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 3
パーツリストの見方
このパーツリストはFD-62G-01MRを基本モデルにしてイラストを作成しています。
項目1~11には基本モデルを記載しています。
項目12~サブモデル、付帯装置等を記載しています。
パーツリストに記載されているカラーの寸法は内径×外径×幅を表わしています。
記号の説明 (Parts No. の隣に記載されています。)
[ ] 前回 のパーツリストに対して、今回変更された部品を表わしています。
[ ] 内は旧Parts No. 及びネジ類の形状
前回 のパーツリストに対して、今回追加された部品及びモデルを表わしています。
部品注文のご注意
☆ このパーツリストに記載されている部品をご注文の際は、Parts No.(例えば、3020293)でお願いします。
☆ 0068011の場合は、0068011又は68011でご注文下さい。
☆ エアチューブ御注文の際は品番と長さを お知らせ下さい。
なお、このパーツリストの記載事項は、改良により変更される場合がありますのでご了承下さい。
How to use this Parts List
The illustrations on this Parts List are drawn on the basis of FD-62G-01MR.
The items from No.1 to No.11 contain the standerd model.
The following items included No.12 contain the submodel and Devices.
The dimension of Collar on this Parts List shows Inside diameter X Outside
diameter X Width.
Explanation of Marks (marked at the Side of Part No.)
[ ] means this part is changed from the previous Parts List.
Inside of [ ] shows the previous Part No. and the shape of screw or the like.
means this part and model is added to the previous Parts List.
How to place an order for the parts
☆ When placing an order for the parts from this Parts List, please clearly state the Parts No.
(e.g.3020293) which you require so that we can deliver the correct Parts to you.
☆ When the Part No. is "0068011", please place an order for the part by showing "0068011"
or "68011".
☆ When ordering Air Tube, please inform us of the Part No. and the length.
This Parts Listis subject to change without notice.
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 4 — Contents
Yamato FD-62G parts on page 4| Ref | Part number | Part name | Qty |
|---|
| SL-C | 単独台仕様モータ下吊り(クラッチモータ) | |
| SU-C-R | 単独台仕様モータ上乗せ(クラッチモータ) | |
| SU-S | 単独台仕様モータ上乗せ(サーボモータ) | |
| MISCELLANEOUS COVERS(1) | カバー関係 (1) | 1 |
| MISCELLANEOUS COVERS(2) | カバー関係 (2) | 2 |
| MISCELLANEOUS THREAD EYELETS | 糸道関係 | 3 |
| MISCELLANEOUS BUSHINGS | ブッシュ関係 | 4 |
| CRANKSHAFT & NEEDLE BAR DRIVING MECHANISM | シャフト及び針棒機構 | 5 |
| PRESSER FOOT MECHANISM | 押工機構 | 6 |
| UPPER KNIFE, CARRIER AND HOOK DRIVING MECHANISM | 上メス及びキャリアフック機構 | 7 |
| LOOPER DRIVING MECHANISM | ルーパ機構 | 8 |
| FEED DRIVING MECHANISM | 送り機構 | 9 |
| FEED DRIVING CONTROL MECHANISM | 送り調節機構 | 10 |
| LUBRICATING MECHANISM | 給油機構 | 11 |
| FD-62G-01MR-12, 01MR-59 EXCLUSIVE PARTS | サブモデル専用部品 | 12 |
| FD-62G-01MS, 01MS-12 EXCLUSIVE PARTS | サブモデル専用部品 | 13 |
| FD-62G-03MR, 03MS EXCLUSIVE PARTS(1) | サブモデル専用部品(1) | 14 |
| FD-62G-03MR, 03MS EXCLUSIVE PARTS(2) | サブモデル専用部品(2) | 15 |
| FD-62G-06MR EXCLUSIVE PARTS(1) | サブモデル専用部品(1) | 16 |
| FD-62G-06MR EXCLUSIVE PARTS(2) | サブモデル専用部品(2) | 17 |
| FD-62G-07MS, 07MS-1 EXCLUSIVE PARTS | サブモデル専用部品 | 18 |
| FD-62G-12MR EXCLUSIVE PARTS | サブモデル専用部品 | 19 |
| FD-62G-12MR-12 EXCLUSIVE PARTS | サブモデル専用部品 | 20 |
| FD-62G-12MS EXCLUSIVE PARTS | サブモデル専用部品 | 21 |
| FD-62G-12MS-52 EXCLUSIVE PARTS | サブモデル専用部品 | 22 |
| FD-62G-12MS-53 EXCLUSIVE PARTS | サブモデル専用部品 | 23 |
| FD-62G-12HR EXCLUSIVE PARTS(1) | サブモデル専用部品(1) | 24 |
| FD-62G-12HS EXCLUSIVE PARTS(1) | サブモデル専用部品(1) | 25 |
| FD-62G-12HR, 12HS EXCLUSIVE PARTS(2) | サブモデル専用部品(2) | 26 |
Installation セットスタイル
SL-C
(MFS+SL-C1+MLS)
SU-C-R
(SU-C1+Motor and Table)
SU-S
(SU-S1+S-S2)
Contents
MISCELLANEOUS COVERS(1)
MISCELLANEOUS COVERS(2)
MISCELLANEOUS THREAD EYELETS
MISCELLANEOUS BUSHINGS
CRANKSHAFT & NEEDLE BAR DRIVING MECHANISM
PRESSER FOOT MECHANISM
UPPER KNIFE, CARRIER AND HOOK DRIVING MECHANISM
LOOPER DRIVING MECHANISM
FEED DRIVING MECHANISM
FEED DRIVING CONTROL MECHANISM
LUBRICATING MECHANISM
FD-62G-01MR-12, 01MR-59 EXCLUSIVE PARTS
FD-62G-01MS, 01MS-12 EXCLUSIVE PARTS
FD-62G-03MR, 03MS EXCLUSIVE PARTS(1)
FD-62G-03MR, 03MS EXCLUSIVE PARTS(2)
FD-62G-06MR EXCLUSIVE PARTS(1)
FD-62G-06MR EXCLUSIVE PARTS(2)
FD-62G-07MS, 07MS-1 EXCLUSIVE PARTS
FD-62G-12MR EXCLUSIVE PARTS
FD-62G-12MR-12 EXCLUSIVE PARTS
FD-62G-12MS EXCLUSIVE PARTS
FD-62G-12MS-52 EXCLUSIVE PARTS
FD-62G-12MS-53 EXCLUSIVE PARTS
FD-62G-12HR EXCLUSIVE PARTS(1)
FD-62G-12HS EXCLUSIVE PARTS(1)
FD-62G-12HR, 12HS EXCLUSIVE PARTS(2)
From the library of: Superior Sewing Machine & Supply LLC
Jinte.in
目次
単独台仕様モータ下吊り(クラッチモータ)
Table Installation, Motor mounted on bottom of table(Clatch Motor).
単独台仕様モータ上乗せ(クラッチモータ)
Table Installation, Motor mounted on top of table(Clatch Motor).
単独台仕様モータ上乗せ(サーボモータ)
Table Installation, Motor mounted on top of table(Servo Motor).
カバー関係 (1)
カバー関係 (2)
糸道関係
ブッシュ関係
シャフト及び針棒機構
押工機構
上メス及びキャリアフック機構
ルーパ機構
送り機構
送り調節機構
給油機構
サブモデル専用部品
サブモデル専用部品
サブモデル専用部品(1)
サブモデル専用部品(2)
サブモデル専用部品(1)
サブモデル専用部品(2)
サブモデル専用部品
サブモデル専用部品
サブモデル専用部品
サブモデル専用部品
サブモデル専用部品
サブモデル専用部品
サブモデル専用部品(1)
サブモデル専用部品(1)
サブモデル専用部品(2)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Page 5 — Contents
Yamato FD-62G parts on page 5| Ref | Part number | Part name | Qty |
|---|
| FD-62G-15MS | EXCLUSIVE PARTS | |
| FDL-4 | DEVICE | |
| AC | DEVICE | |
| AC1/SC3 | DEVICE(1) | |
| AC1/SC3 | DEVICE(2) | |
| SC3 | DEVICE | |
| SC4 | DEVICE | |
| RF | DEVICE | |
| AC16, RF/AC16 | DEVICE(1) | |
| AC16, RF/AC16 | DEVICE(2) | |
| AC16 | DEVICE(3) | |
| AC16 | DEVICE(4) | |
| RF/AC16 | DEVICE(3) | |
| RF/AC16 | DEVICE(4) | |
| SET STYLE SL-C | EXCLUSIVE PARTS(1) | |
| SET STYLE SL-C | EXCLUSIVE PARTS(2) | |
| SET STYLE SU-C-R | EXCLUSIVE PARTS(1) | |
| SET STYLE SU-C-R | EXCLUSIVE PARTS(2) | |
| SET STYLE SU-S | EXCLUSIVE PARTS | |
| EXTRA PARTS(1) | for SU-C, SU-S | |
| EXTRA PARTS(2) | | |
| EXTRA PARTS(3) | | |
| EXTRA PARTS(4) | | |
| EXTRA PARTS(5) | | |
| EXTRA PARTS(6) | | |
| EXTRA PARTS(7) | | |
| EXTRA PARTS(8) | | |
| THREAD | STAND | |
| ACCESSORIES | | |
| EXTRA TOOLS & GAUGES | | |
| WARNING | LABEL | |
| LIST of MAIN SPARE PARTS | | |
| INDEX | | |
Contents
FD-62G-15MS EXCLUSIVE PARTS
FDL-4 DEVICE
AC DEVICE
AC1/SC3 DEVICE(1)
AC1/SC3 DEVICE(2)
SC3 DEVICE
SC4 DEVICE
RF DEVICE
AC16, RF/AC16 DEVICE(1)
AC16, RF/AC16 DEVICE(2)
AC16 DEVICE(3)
AC16 DEVICE(4)
RF/AC16 DEVICE(3)
RF/AC16 DEVICE(4)
SET STYLE SL-C EXCLUSIVE PARTS(1)
SET STYLE SL-C EXCLUSIVE PARTS(2)
SET STYLE SU-C-R EXCLUSIVE PARTS(1)
SET STYLE SU-C-R EXCLUSIVE PARTS(2)
SET STYLE SU-S EXCLUSIVE PARTS
EXTRA PARTS(1) for SU-C, SU-S
EXTRA PARTS(2)
EXTRA PARTS(3)
EXTRA PARTS(4)
EXTRA PARTS(5)
EXTRA PARTS(6)
EXTRA PARTS(7)
EXTRA PARTS(8)
THREAD STAND
ACCESSORIES
EXTRA TOOLS & GAUGES
WARNING LABEL
LIST of MAIN SPARE PARTS
INDEX
目次
サブモデル専用部品
27
FDL-4 装置
28
AC 装置
29
AC1/SC3 装置(1)
30
AC1/SC3 装置(2)
31
SC3 装置
32
SC4 装置
33
RF 装置
34
AC16, RF/AC16 装置(1)35
AC16, RF/AC16 装置(2)36
AC16 装置(3)
37
AC16 装置(4)
38
RF/AC16 装置(3)
39
RF/AC16 装置(4)
40
SL-C 専用部品(1)
41
SL-C 専用部品(2)
42
SU-C-R 専用部品(1)
43
SU-C-R 専用部品(2)
44
SU-S 専用部品
45
SU-C, SU-S 特注部品(1) 46
特注部品(2)
47
特注部品(3)
48
特注部品(4)
49
特注部品(5)
50
特注部品(6)
51
特注部品(7)
52
特注部品(8)
53
糸立台
54
アクセサリー関係
55
特殊工具及びゲージ
56
警告ラベル
57
主要部品リスト
58
索引
61
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 7 — MISCELLANEOUS COVERS(1)
Yamato FD-62G parts on page 7| Ref | Part number | Part name | Qty |
|---|
| 3021523 | Crank Chamber Cover | 1 |
| 3020444 | Crank Chamber Cover Gasket | 1 |
| 004445 | Screw(11/64-40 × 11) | 5 |
| 004192 | Screw(M12-1.75 × 9) | 2 |
| 0032421 | O-ring(P10) | 2 |
| 0068011 | Oil Sight Top Window | 2 |
| 004352 | Screw(9/64-40 × 11.3) | 10 |
| 3021524 | Top Cover(Middle) | 1 |
| 009853 | Screw(11/64-40 × 6.5) | 2 |
| 000340 | Nut | 2 |
| 004358 | Screw(9/64-40 × 5.6) | 4 |
| 0068013 | Top Cover(Middle) Spring | 1 |
| 000322 | Nut | 2 |
| 0068014 | Top Cover(Middle) Hinge | 1 |
| 004184 | Screw(9/64-40 × 6) | 7 |
| 3021525 | Top Cover(Front) | 1 |
| 004196 | Plug Screw(M12-1.75 × 7) | 1 |
| 3020445 | Top Cover(Front) Gasket | 1 |
| 009104 | Screw(5/16-24 × 32) | 3 |
| 000472 | Washer | 3 |
| 2049401 | Serial Number Plate | 1 |
| 000726 | Rivet | 2 |
| 3020448 | Machine Frame End Cover | 1 |
| 3021526 | Machine Frame End Cover | 1 |
| 3020445 | Looper Lever Shaft Cover Gasket | 1 |
| 3020441 | Looper Lever Shaft Cover | 1 |
| 009142 | Screw(9/64-40 × 7.1) | 13 |
| 0032421 | O-ring(P10) | 1 |
| 005076 | Drain Hole Screw(3/8-24 × 8) | 1 |
| 190036 | Plug Screw(M14-1 × 4) | 2 |
| 004175 | Screw(1/4-28 × 32.5) | 2 |
| 000474 | Washer | 3 |
| 0068307 | Crank Chamber Cover Oil Shield | 1 |
| 0093059 | Oil Seal Plug | 1 |
| 3020434 | Sewing Head Oil Defender | 1 |
| 0068003 | Sewing Head Key | 2 |
| 007621 | Screw(9/64-40 × 8.5) | 2 |
| 004174 | Screw(1/4-28 × 20) | 1 |
| 000479 | Pin | 1 |
| 3021530 | Knife Driving Connection Oil Guard | 1 |
MISCELLANEOUS COVERS(1) カバー関係(1) 1
Ref.No. Parts No. Description Amt. Req
1 3021523 Crank Chamber Cover クランク室カバー 1
2 3020444 Crank Chamber Cover Gasket クランク室カバーパッキン 1
3 004445 Screw(11/64-40 × 11) 止ネジ 5
4 004192 Screw(M12-1.75 × 9) プラグネジ 2
5 0032421 O-ring(P10) Oリング 2
6 0068011 Oil Sight Top Window オイル確認窓 2
7 004352 Screw(9/64-40 × 11.3) 止ネジ 10
8 3021524 Top Cover(Middle) 上カバー(中) 1
9 009853 Screw(11/64-40 × 6.5) 止ネジ 2
10 000340 Nut ナット 2
11 004358 Screw(9/64-40 × 5.6) 止ネジ 4
12 0068013 Top Cover(Middle) Spring 上カバー(中)バネ 1
13 000322 Nut ナット 2
14 0068014 Top Cover(Middle) Hinge 上カバー(中)ヒンジ 1
15 004184 Screw(9/64-40 × 6) 止ネジ 7
16 3021525 Top Cover(Front) 上カバー(前) 1
17 004196 Plug Screw(M12-1.75 × 7) プラグネジ 1
18 3020445 Top Cover(Front) Gasket 上カバー(前)パッキン 1
19 009104 Screw(5/16-24 × 32) 止ネジ 3
20 000472 Washer ワッシャ 3
21 2049401 Serial Number Plate 機番プレート 1
22 000726 Rivet 止メ釘 2
23 3020448 Machine Frame End Cover エンドカバー 1
24 3021526 Machine Frame End Cover エンドカバー 1
25 3020445 Looper Lever Shaft Cover Gasket ルーパレバー軸カバーパッキン 1
26 3020441 Looper Lever Shaft Cover ルーパレバー軸カバー 1
27 009142 Screw(9/64-40 × 7.1) 止ネジ 13
28 0032421 O-ring(P10) Oリング 1
29 005076 Drain Hole Screw(3/8-24 × 8) 油抜キネジ 1
30 190036 Plug Screw(M14-1 × 4) プラグネジ 2
31 004175 Screw(1/4-28 × 32.5) 止ネジ 2
32 000474 Washer ワッシャ 3
33 0068307 Crank Chamber Cover Oil Shield クランク室油除ケ 1
34 0093059 Oil Seal Plug 埋メ座 1
35 3020434 [0068004] Sewing Head Oil Defender ソーイングヘッド防油板 1
36 0068003 Sewing Head Key ソーイングヘッドキー 2
37 007621 Screw(9/64-40 × 8.5) 止ネジ 2
38 004174 Screw(1/4-28 × 20) 止ネジ 1
39 000479 Pin テーパピン 1
40 3021530 Knife Driving Connection Oil Guard 上メスロッド油受ケ 1
Ref. No. 41 to 59 See the following page.
From the library of: Superior Sewing Machine & Supply LLC FD-62G
jintex.in
Page 9 — MISCELLANEOUS COVERS(1)
Yamato FD-62G parts on page 9| Ref | Part number | Part name | Qty |
|---|
| 41 | 0068323 | Knife Driving Connection Felt | 1 |
| 42 | 3020457 | Thread Carrier and Hook Driving Rod Oil Guard | 1 |
| 43 | 001175 | Screw(9/64-40 × 8) | 2 |
| 44 | 000187 | Seal | 2 |
| 45 | 000335 | Nut | 2 |
| 46 | 3020455 | Sewing Head Cover(Left) | 1 |
| 47 | 390207 | "FD-62G" Emblem | 1 |
| 48 | 5544886 | Seal Plug | 1 |
| 49 | 0093864 | Seal Plug | 1 |
| 50 | 0068308 | Oil Guide Wire | 1 |
| 51 | 0068196 | Frame Chip Guard Washer | 1 |
| 52 | 0068191 | Frame Chip Guard | 1 |
| 53 | 0068193 | Frame Chip Guard Spring | 1 |
| 54 | 004188 | Screw(M5-0.8 × 8.7) | 1 |
| 55 | 3020447 | Sewing Head Cover Gasket | 1 |
| 56 | 3020446 | Sewing Head Cover(Front) | 1 |
| 57 | 3020464 | Needle Thrad Take-up Guard | 1 |
| 58 | 110013 | Screw(M4-0.7 × 8) | 2 |
| 59 | 390206 | Brand Name Sticker(95mm) | 1 |
MISCELLANEOUS COVERS(1) カバー関係(1) 1
Ref.No Parts No. Description 品 名 Amt. Req
41 0068323 Knife Driving Connection Felt 上メスロッドフェルト 1
42 3020457 Thread Carrier and Hook Driving Rod Oil Guard キャリア・フックロッド油除ケ 1
43 001175 Screw(9/64-40 × 8) 止ネジ 2
44 000187 Seal パッキン 2
45 000335 Nut ナット 2
46 3020455 Sewing Head Cover(Left) ソーイングヘッド横カバー 1
47 390207 "FD-62G" Emblem FD-62Gエンブレム 1
48 5544886 Seal Plug 詰栓 1
49 0093864 Seal Plug 詰栓 1
50 0068308 Oil Guide Wire オイルガイドワイヤ 1
51 0068196 Frame Chip Guard Washer チップガードワッシャ 1
52 0068191 Frame Chip Guard チップガード 1
53 0068193 Frame Chip Guard Spring チップガードバネ 1
54 004188 Screw(M5-0.8 × 8.7) 止ネジ 1
55 3020447 Sewing Head Cover Gasket ソーイングヘッドカバーパッキン 1
56 3020446 Sewing Head Cover(Front) ソーイングヘッド前カバー 1
57 3020464 Needle Thrad Take-up Guard 針糸繰リガード 1
58 110013 Screw(M4-0.7 × 8) 止ネジ 2
59 390206 Brand Name Sticker(95mm) 銘板 1
From the library of: Superior Sewing Machine & Supply LLC FD-62G
jintex.in
Page 13 — MISCELLANEOUS THREAD EYELETS
Yamato FD-62G parts on page 13| Ref | Part number | Part name | Qty |
|---|
| 0068356 | Thread Guide Plate | |
| 004440 | Screw(11/64-40 × 8.3) | |
| 0068359 | Thread Eyelet Bushing | |
| 0068358 | Thread Eyelet | |
| 0093538 | Thread Pipe | |
| 0093528 | Thread Pipe Stay | |
| 000532 | Washer | |
| 004358 | Screw(9/64-40 × 5.6) | |
| 0068357 | Thread Guide Plate Support | |
| 001601 | Screw(11/64-40 × 7) | |
| 3020034 | Thread Tension Support | |
| 3020035 | Thread Tension Support Bracket | |
| 004552 | Screw(7/32-32 × 9.5) | |
| 0068235 | Tension Release Shaft Spring | |
| 0068234 | Tension Release Shaft | |
| 000485 | Nut | |
| 0068273 | Tension Spring Bushing | |
| 0068244 | Looper Thread Tension Spring | |
| 0068243 | Top Cover Thread Tension Spring | |
| 0068245 | Needle Thread Tension Spring | |
| 0068413 | Tension Release Pin Bushing | |
| 0031111 | Tension Thread Disc | |
| 0068411 | Thread Tension Disc Eyelet | |
| 004206 | Tension Post | |
| 0068412 | Tension Release Pin | |
| 0068355 | SP Device, C. Set | |
| 0068350 | Oil Cup Lid | |
| 001107 | Hinge Pin | |
| 0068353 | SP Felt | |
| 0068403 | SP Felt Stay | |
| 310086 | Oil Wick(Woollen Yarn)(200mm) | |
| 0068349 | SP Container | |
| 0068351 | SP Container Support | |
| 007619 | Screw(9/64-40 × 6.3) | |
| 0068259 | Thread Take-up Eyelet Holder | |
| 0068260 | Thread Take-up Eyelet | |
| 004180 | Screw(1/8-44 × 4.8) | |
| 0068258 | Looper Thread Take-up Guide | |
| 001222 | Screw(1/8-44 × 4.8) | |
MISCELLANEOUS THREAD EYELETS 糸道関係 3
Ref.No Parts No. Description 品 名 Amt. Req
1 0068356 Thread Guide Plate 糸案内板 1
2 004440 Screw(11/64-40 × 8.3) 止ネジ 12
3 0068359 Thread Eyelet Bushing 糸案内糸道ブッシュ 4
4 0068358 Thread Eyelet 糸案内糸道 4
5 0093538 Thread Pipe 糸道パイプ 2
6 0093528 Thread Pipe Stay 糸道パイプ支エ 2
7 000532 Washer ワッシャ 2
8 004358 Screw(9/64-40 × 5.6) 止ネジ 2
9 0068357 Thread Guide Plate Support 糸案内板支工棒 2
10 001601 Screw(11/64-40 × 7) 止ネジ 2
11 3020034 Thread Tension Support 糸調子台 1
12 3020035 Thread Tension Support Bracket 糸調子台ブラケット 2
13 004552 Screw(7/32-32 × 9.5) 止ネジ 4
14
15 0068235 Tension Release Shaft Spring 糸緩メ軸バネ 1
16 0068234 Tension Release Shaft 糸緩メ軸 1
17 000485 Nut ナット 6
18 0068273 Tension Spring Bushing 糸調子ナット廻り止メ 6
19 0068244 Looper Thread Tension Spring ルーパ糸調子バネ 1
20 0068243 Top Cover Thread Tension Spring 飾り糸調子バネ 1
21 0068245 Needle Thread Tension Spring 糸調子バネ 4
22 0068413 Tension Release Pin Bushing 糸緩メピンブッシュ 7
23 0031111 Tension Thread Disc 糸調子皿 12
24 0068411 Thread Tension Disc Eyelet 糸調子台糸道 3
25 004206 Tension Post 糸調子棒 6
26 0068412 Tension Release Pin 糸緩メピン 7
27 0068355 SP Device, C. Set SP装置(組) 1
28 0068350 Oil Cup Lid SPタンク蓋 1
29 001107 Hinge Pin ヒンジピン 2
30 0068353 SP Felt SPフェルト 4
31 0068403 SP Felt Stay SPフェルト受ケ 1
32 310086 Oil Wick(Woollen Yarn)(200mm) 油芯(毛糸) 1
33 0068349 SP Container SPタンク 1
34 0068351 SP Container Support SPタンク取付板 1
35 007619 Screw(9/64-40 × 6.3) 止ネジ 2
36 0068259 Thread Take-up Eyelet Holder 飾り糸調子カム糸道ホルダ 1
37 0068260 Thread Take-up Eyelet 飾り糸調子カム糸道 1
38 004180 Screw(1/8-44 × 4.8) 止ネジ 1
39 0068258 Looper Thread Take-up Guide ルーパ糸調子カム糸案内 1
40 001222 Screw(1/8-44 × 4.8) 止ネジ 4
Ref. No. 41 to 67 See the following page.
From the library of: Superior Sewing Machine & Supply LLC FD-62G
jintex.in
Page 14
Yamato FD-62G parts on page 14| Ref | Part number | Part name | Qty |
|---|
| 2 | 2 | SCREW | |
| 3 | 3 | WASHER | |
| 4 | 4 | SPRING | |
| 5 | 5 | SUPPORT | |
| 6 | 6 | BRACKET | |
| 7 | 7 | WASHER | |
| 8 | 8 | SCREW | |
| 9 | 9 | ROD | |
| 10 | 10 | SCREW | |
| 11 | 11 | BRACKET | |
| 12 | 12 | BRACKET | |
| 13 | 13 | SCREW | |
| 15 | 15 | SHAFT | |
| 16 | 16 | SHAFT | |
| 17 | 17 | COLLAR | |
| 18 | 18 | COLLAR | |
| 19 | 19 | COLLAR | |
| 20 | 20 | SPRING | |
| 21 | 21 | SPRING | |
| 22 | 22 | BRACKET | |
| 23 | 23 | WASHER | |
| 24 | 24 | BRACKET | |
| 25 | 25 | STUD | |
| 26 | 26 | STUD | |
| 27 | 27 | BRACKET | |
| 28 | 28 | BRACKET | |
| 29 | 29 | PIN | |
| 30 | 30 | BLOCK | |
| 31 | 31 | BRACKET | |
| 32 | 32 | BRACKET | |
| 33 | 33 | BRACKET | |
| 34 | 34 | BRACKET | |
| 35 | 35 | SCREW | |
| 36 | 36 | SCREW | |
| 37 | 37 | BRACKET | |
| 38 | 38 | STUD | |
| 39 | 39 | PLATE | |
| 40 | 40 | SCREW | |
| 41 | 41 | BRACKET | |
| 42 | 42 | BRACKET | |
| 43 | 43 | BRACKET | |
| 44 | 44 | BASE PLATE | |
| 45 | 45 | LEVER | |
| 46 | 46 | PIN | |
| 47 | 47 | SPRING | |
| 48 | 48 | WASHER | |
| 49 | 49 | BRACKET | |
| 50 | 50 | BRACKET | |
| 51 | 51 | BRACKET | |
| 52 | 52 | SPRING | |
| 53 | 53 | PIN | |
| 54 | 54 | SPRING | |
| 55 | 55 | SCREW | |
| 56 | 56 | BRACKET | |
| 57 | 57 | BRACKET | |
| 58 | 58 | ROD | |
| 59 | 59 | BRACKET | |
| 60 | 60 | STUD | |
| 61 | 61 | SCREW | |
| 62 | 62 | SPRING | |
| 63 | 63 | SPRING | |
| 64 | 64 | SCREW | |
| 65 | 65 | BRACKET | |
| 66 | 66 | BRACKET | |
| 67 | 67 | NUT | |
3
2
29
30
27
33
34
35
2
3
4
3
4
3
4
3
4
1
17
18
21
23
26
22
24
15
16
2
10
13
12
64
2
9
2
17
18
20
23
25
26
24
22
25
23
9
13
36
38
37
42
41
40
39
44
5
6
7
8
2
6
7
8
13
12
10
2
43
40
46
49
48
47
2
50
51
54
55
53
54
45
60
61
59
58
56
57
62
65
63
66
67
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 15 — MISCELLANEOUS THREAD EYELETS
Yamato FD-62G parts on page 15| Ref | Part number | Part name | Qty |
|---|
| 0068256 | Looper Thread Take-up Eyelet(Front) | 1 |
| 0068257 | Looper Thread Take-up Eyelet(Rear) | 1 |
| 004245 | Screw(1/128-56 × 3.2) | 4 |
| 0068255 | Eyelet Supporting Plate | 1 |
| 0068262 | Looper Thread Guard | 1 |
| 0032339 | Top Cover Thread Pipe | 1 |
| 0068261 | Looper Thread Guide Wire(Upper) | 1 |
| 0068269 | Needle Thread Strike-off Pin Holder Bracket | 1 |
| 0068270 | Needle Thread Strike-off Pin | 4 |
| 004197 | Screw(1/8-44 × 2) | 4 |
| 0068324 | Needle Thread Strike-off Pin Holder | 1 |
| 004187 | Screw(3/32-56 × 6.2) | 2 |
| 0068242 | Needle Thread Guide Wire | 1 |
| 0068267 | Head Cover Thread Eyelet | 1 |
| 009730 | Screw(1/8-44 × 5.3) | 1 |
| 0068246 | Needle Thread Eyelet Holder | 1 |
| 007311 | Screw(11/64-40 × 12.6) | 1 |
| 0068249 | Needle Thread Eyelet | 4 |
| 0068250 | Stitch Unlocking Mounting Bracket | 1 |
| 004191 | Screw(11/128-56 × 2.5) | 1 |
| 004134 | Screw(1/8-44 × 6.5) | 1 |
| 0068251 | Stitch Unlocking Spring | 1 |
| 0068252 | Stitch Unlocking Spring Holder | 1 |
| 004321 | Screw(1/8-44 × 6.4) | 1 |
| 003312 | Screw(1/8-44 × 3.4) | 1 |
| 001196 | Screw(1/8-44 × 6) | 1 |
| 005431 | Screw(1/8-44 × 4.4) | 2 |
MISCELLANEOUS THREAD EYELETS
糸道関係
3
Ref.No
Parts No.
Description
品 名
Amt. Req
41
0068256
Looper Thread Take-up Eyelet(Front)
ルーパ糸調子カム糸道(前)
1
42
0068257
Looper Thread Take-up Eyelet(Rear)
ルーパ糸調子カム糸道(後)
1
43
004245
Screw(1/128-56 × 3.2)
止ネジ
4
44
0068255
Eyelet Supporting Plate
カム糸道取付板
1
45
0068262
Looper Thread Guard
ルーパ糸ガード
1
46
0032339
Top Cover Thread Pipe
飾り糸道パイプ
1
47
0068261
Looper Thread Guide Wire(Upper)
ガイドワイヤ(上)
1
48
0068269
Needle Thread Strike-off Pin Holder Bracket
針糸受ケホルダ取付台
1
49
0068270
Needle Thread Strike-off Pin
針糸受ケ
4
50
004197
Screw(1/8-44 × 2)
止ネジ
4
51
0068324
Needle Thread Strike-off Pin Holder
針糸受ケホルダ
1
52
004187
Screw(3/32-56 × 6.2)
止ネジ
2
53
0068242
Needle Thread Guide Wire
糸道ガイドワイヤ
1
54
0068267
Head Cover Thread Eyelet
ヘッドカバー糸道
1
55
009730
Screw(1/8-44 × 5.3)
止ネジ
1
56
0068246
Needle Thread Eyelet Holder
フレーム針糸道ホルダ
1
57
007311
Screw(11/64-40 × 12.6)
止ネジ
1
58
0068249
Needle Thread Eyelet
フレーム針糸道
4
59
0068250
Stitch Unlocking Mounting Bracket
針糸道バネブラケット
1
60
004191
Screw(11/128-56 × 2.5)
止ネジ
1
61
004134
Screw(1/8-44 × 6.5)
止ネジ
1
62
0068251
Stitch Unlocking Spring
針糸道バネ
1
63
0068252
Stitch Unlocking Spring Holder
針糸道バネホルダ
1
64
004321
Screw(1/8-44 × 6.4)
止ネジ
1
65
003312
Screw(1/8-44 × 3.4)
止ネジ
1
66
001196
Screw(1/8-44 × 6)
止ネジ
1
67
005431
Screw(1/8-44 × 4.4)
止ネジ
2
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
FD-62G
Page 16 — 4
Yamato FD-62G parts on page 16| Ref | Part number | Part name | Qty |
|---|
| 3 | 3 | Screw | |
| 2 | 2 | Shaft | |
| 4 | 4 | Pulley | |
| 6 | 6 | Screw | |
| 5 | 5 | Pulley | |
| 7 | 7 | Bearing | |
| 8 | 8 | Bearing | |
| 13 | 13 | Spring | |
| 21 | 21 | Shaft | |
| 12 | 12 | Spring | |
| 16 | 16 | Shaft | |
| 19 | 19 | Pin | |
| 18 | 18 | Spring | |
| 14 | 14 | Shaft | |
| 22 | 22 | Shaft | |
| 15 | 15 | Shaft | |
| 9 | 9 | Shaft | |
| 10 | 10 | Shaft | |
| 8 | 8 | Bearing | |
| 24 | 24 | Shaft | |
| 23 | 23 | Nut | |
| 25 | 25 | Washer | |
| 26 | 26 | Housing | |
| 27 | 27 | Shaft | |
| 28 | 28 | Bearing | |
| 20 | 20 | Lever | |
| 31 | 31 | Bearing | |
| 32 | 32 | Shaft | |
| 30 | 30 | Shaft | |
| 11 | 11 | Housing | |
| 17 | 17 | Housing | |
| 29 | 29 | Housing | |
4
1
3
2
4
6
5
7
8
13
21
12
16
19
18
12
14
22
15
9
10
8
24
23
25
26
27
28
20
31
32
30
31
11
17
29
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 17 — MISCELLANEOUS BUSHINGS
Yamato FD-62G parts on page 17| Ref | Part number | Part name | Qty |
|---|
| 1 | 3020411 | Adapter, C. Set | 1 |
| 2 | 3020400 | Adapter | 1 |
| 3 | 160003 | Screw(M5-0.8 × 5) | 2 |
| 4 | 3500054 | Ball Bearing | 1 |
| 5 | 3020435 | Bushing Housing | 1 |
| 6 | 004202 | Screw(3/16-32 × 11.5) | 3 |
| 7 | 0068047 | Bushing Housing Gasket | 1 |
| 8 | 3020417 | Oil Seal | 4 |
| 9 | 0068048 | Crankshaft Bushing(Front) | 1 |
| 10 | 3020401 | Main Shaft Bushing(Rear) | 1 |
| 11 | 0068050 | Main Shaft Bushing(Front) | 1 |
| 12 | 310087 | Oil Wick(Woollen Yarn)(320mm) | 2 |
| 13 | 000463 | Oil Wick(Laced Wire) | 1 |
| 14 | 3020402 | Knife Driving Lever Bushing(Rear) | 1 |
| 15 | 3020403 | Knife Driving Lever Bushing(Front) | 1 |
| 16 | 0068139 | Presser Foot Lifter Stop Plunger Bushing | 1 |
| 17 | 0068230 | Looper Driving Lever Shaft Bushing | 1 |
| 18 | 000390 | Oil Wick(φ 9 × 2.5mm) | 1 |
| 19 | 0068035 | Seal Plug | 1 |
| 20 | 310017 | Oil Wick(No.2 -300mm) | 1 |
| 21 | 004440 | Screw(11/64-40 × 8.3) | 1 |
| 22 | 3020097 | Vinyl Tube | 1 |
| 23 | 0068131 | Presser Bar Bushing | 1 |
| 24 | 3020014 | Needle Bar Bushing(Upper) Lid | 1 |
| 25 | 000509 | Gasket | 1 |
| 26 | 3020013 | Needle Bar Bushing(Upper) | 1 |
| 27 | 3020404 | Needle Bar Bushing(Lower) | 1 |
| 28 | 3020416 | Oil Seal | 1 |
| 29 | 0068214 | Looper Rocker Shaft Bushing(Front) | 1 |
| 30 | 3020405 | Looper Rocker Shaft Bushing(Rear) | 1 |
| 31 | 3020418 | Oil Seal | 2 |
| 32 | 3020406 | Feed Bar Eccentric Pin Bushing | 1 |
MISCELLANEOUS BUSHINGS
Ref.No
Parts No.
Description
品 名
Amt. Req
1
3020411
Adapter, C. Set
アダプタ(組)
1
2
3020400
Adapter
アダプタ
1
3
160003
Screw(M5-0.8 × 5)
止ネジ
2
4
3500054
Ball Bearing
ボールベアリング
1
5
3020435
Bushing Housing
ブッシュハウジング
1
6
004202
Screw(3/16-32 × 11.5)
止ネジ
3
7
0068047
Bushing Housing Gasket
ブッシュハウジングパッキン
1
8
3020417
Oil Seal
オイルシール
4
9
0068048
Crankshaft Bushing(Front)
クランクシャフトブッシュ(前)
1
10
3020401
Main Shaft Bushing(Rear)
メインシャフトブッシュ(後)
1
11
0068050
Main Shaft Bushing(Front)
メインシャフトブッシュ(前)
1
12
310087
Oil Wick(Woollen Yarn)(320mm)
油芯(毛糸)
2
13
000463
Oil Wick(Laced Wire)
油芯(モール)
1
14
3020402
Knife Driving Lever Bushing(Rear)
上メスレバーブッシュ(後)
1
15
3020403
Knife Driving Lever Bushing(Front)
上メスレバーブッシュ(前)
1
16
0068139
Presser Foot Lifter Stop Plunger Bushing
ストッププランジャブッシュ
1
17
0068230
Looper Driving Lever Shaft Bushing
ルーパレバー軸ブッシュ
1
18
000390
Oil Wick(φ 9 × 2.5mm)
油芯
1
19
0068035
Seal Plug
詰栓
1
20
310017
Oil Wick(No.2 -300mm)
油芯
1
21
004440
Screw(11/64-40 × 8.3)
止ネジ
1
22
3020097
Vinyl Tube
ビニールパイプ
1
23
0068131
Presser Bar Bushing
押工棒ブッシュ
1
24
3020014
Needle Bar Bushing(Upper) Lid
針棒ブッシュ(上)蓋
1
25
000509
Gasket
パッキン
1
26
3020013
Needle Bar Bushing(Upper)
針棒ブッシュ(上)
1
27
3020404
Needle Bar Bushing(Lower)
針棒ブッシュ(下)
1
28
3020416
Oil Seal
オイルシール
1
29
0068214
Looper Rocker Shaft Bushing(Front)
ルーパ軸ブッシュ(前)
1
30
3020405
Looper Rocker Shaft Bushing(Rear)
ルーパ軸ブッシュ(後)
1
31
3020418
Oil Seal
オイルシール
2
32
3020406
Feed Bar Eccentric Pin Bushing
送り台エキセンピンブッシュ
1
ブッシュ関係
4
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
FD-62G
Page 18
Yamato FD-62G parts on page 18| Ref | Part number | Part name | Qty |
|---|
| 1 | SHAFT | |
| 2 | WASHER | |
| 3 | COVER | |
| 4 | SCREW | |
| 5 | SPRING | |
| 6 | SCREW | |
| 7 | COLLAR | |
| 8 | SPRING | |
| 9 | SHAFT HOUSING | |
| 10 | SCREW | |
| 11 | SCREW | |
| 12 | SPRING | |
| 13 | SPRING | |
| 14 | GEAR | |
| 15 | SCREW | |
| 16 | SHAFT | |
| 17 | BEARING | |
| 18 | HOLDER | |
| 19 | PLATE | |
| 20 | WASHER | |
| 21 | FLYWHEEL | |
| 22 | SPRING | |
| 23 | HOLDER | |
| 24 | SCREW | |
| 25 | BEARING | |
| 26 | CYLINDER | |
| 27 | SPRING | |
| 28 | SCREW | |
| 29 | ARM | |
| 30 | SCREW | |
| 31 | CIR-CLIP | |
| 32 | WASHER | |
| 33 | SHAFT | |
| 34 | SHAFT | |
| 35 | SHAFT | |
| 36 | SCREW | |
| 37 | HOLDER | |
| 38 | SCREW | |
| 39 | ROD | |
| 40 | SCREW | |
| 41 | NEEDLE | |
| 42 | NEEDLE | |
| 43 | SCREW | |
| 44 | NEEDLE PLATE | |
| 45-1 | SCREW | |
| 45-2 | SCREW | |
| 46 | SCREW | |
| 47 | SHAFT | |
| 48 | COLLAR | |
| 49 | SPRING | |
5
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 19 — CRANKSHAFT & NEEDLE BAR DRIVING MECHANISM
Yamato FD-62G parts on page 19| Ref | Part number | Part name | Qty |
|---|
| 0068039 | Main Shaft | |
| 0068033 | O-ring(P12.5) | |
| 0068253 | Looper Thread Take-up | |
| 0068254 | Top Cover Thread Take-up | |
| 008047 | Screw(7/32-32 × 3.6) | |
| 003410 | Positioning Screw(1/8-44 × 4) | |
| 0068043 | Collar(12.7 × 25.4 × 8mm) | |
| 003434 | Screw(11/64-40 × 6) | |
| 0068493 | Main Shaft Coupling, C. Set | |
| 300049 | Washer | |
| 004177 | Screw(11/64-40 × 17) | |
| 003649 | Screw(1/4-28 × 8.5) | |
| 003646 | Screw(1/4-28 × 6.35) | |
| 0068276 | Pump Driving Gear | |
| 004186 | Screw(1/8-44 × 7.7) | |
| 0068038 | Crankshaft | |
| 0068146 | Needle Bearing | |
| 0068145 | Thread Carrier and Hook Driving Rod(Right) | |
| 0068147 | Needle Bearing Retaining Plate | |
| 007619 | Screw(9/64-40 × 3) | |
| 3020087 | Pulley | |
| 004123 | Screw(1/4-28 × 10) | |
| 0068060 | Needle Bar Lever Connecting Rod | |
| 005070 | Screw(3/32-32 × 14) | |
| 0034406 | Needle Bearing | |
| 0068059 | Needle Bar Lever Connecting Rod Pin | |
| 000203 | Oil Wick(4 × 5 × 50mm) | |
| 001170 | Screw(9/64-40 × 12) | |
| 3020431 | Needle Bar Lever | |
| 160009 | Screw(M5-0.8 × 5) | |
| 3160038 | Retaining Ring | |
| 3020432 | Thrust Ring | |
| 0090321 | Needle Bar Connecting Link | |
| 0090320 | Needle Bar Connecting Link Pin | |
| 000278 | Oil Wick(2.5 × 2.5 × 18mm) | |
| 004313 | Screw(1/8-44 × 5) | |
| 0068057 | Needle Bar Connecting Bracket | |
| 004185 | Screw(9/64-40 × 7.2) | |
| 3020422 | Needle Bar | |
| 0068053 | Needle Clamp(5.2) | |
| ---- | Needle(system:UY118GAS) | |
| ---- | Retainer(system:36211) | |
| 004170 | Screw(3/32-56 × 2.5) | |
| 0068490 | Stitch Plate | |
| 0068491 | Stitch Plate Tongue | |
| 3028003 | Stitch Plate Tongue(for woolly thread)(Extra) | |
| 004182 | Screw(3/32-56 × 2.5) | |
| 3020429 | Needle Bar Lever, C. Set | |
| 3020432 | Collar(12.7 × 22 × 8) | |
| 003659 | Screw(M5-0.8 × 5) | |
CRANKSHAFT & NEEDLE BAR DRIVING MECHANISM 5
Ref.No Parts No. Description Amt. Req
1 0068039 Main Shaft メインシャフト 1
2 0068033 O-ring(P12.5) Oリング 1
3 0068253 Looper Thread Take-up ルーパ糸調子カム 1
4 0068254 Top Cover Thread Take-up 飾り糸調子カム 1
5 008047 Screw(7/32-32 × 3.6) 止ネジ 4
6 003410 Positioning Screw(1/8-44 × 4) 位置決メネジ 2
7 0068043 Collar(12.7 × 25.4 × 8mm) カラー 2
8 003434 Screw(11/64-40 × 6) 止ネジ 4
9 0068493 Main Shaft Coupling, C. Set メインシャフトカップリング(組) 1
10 300049 Washer ワッシャ 3
11 004177 Screw(11/64-40 × 17) 止ネジ 3
12 003649 Screw(1/4-28 × 8.5) 決メネジ 2
13 003646 Screw(1/4-28 × 6.35) 止ネジ 4
14 0068276 Pump Driving Gear ポンプ駆動ギア 1
15 004186 Screw(1/8-44 × 7.7) 止ネジ 3
16 0068038 Crankshaft クランクシャフト 1
17 0068146 Needle Bearing ニードルベアリング 1
18 0068145 Thread Carrier and Hook Driving Rod(Right) キャリア・フックロッド(右) 1
19 0068147 Needle Bearing Retaining Plate ベアリング保持板 1
20 007619 Screw(9/64-40 × 3) 止ネジ 2
21 3020087 Pulley プーリー 1
22 004123 Screw(1/4-28 × 10) 止ネジ 2
23 0068060 Needle Bar Lever Connecting Rod 針棒ロッド 1
24 005070 Screw(3/32-32 × 14) 止ネジ 2
25 0034406 Needle Bearing ニードルベアリング 1
26 0068059 Needle Bar Lever Connecting Rod Pin 針棒ロッドピン 1
27 000203 Oil Wick(4 × 5 × 50mm) 油芯 1
28 001170 Screw(9/64-40 × 12) 止ネジ 2
29 3020431 Needle Bar Lever 針棒レバー 1
30 160009 Screw(M5-0.8 × 5) 止ネジ 2
31 3160038 Retaining Ring ストップリング 1
32 3020432 Thrust Ring スラストリング 1
33 0090321 Needle Bar Connecting Link 針棒リンク 1
34 0090320 Needle Bar Connecting Link Pin 針棒リンクピン 2
35 000278 Oil Wick(2.5 × 2.5 × 18mm) 油芯 2
36 004313 Screw(1/8-44 × 5) 止ネジ 2
37 0068057 Needle Bar Connecting Bracket 針棒抱キ 1
38 004185 Screw(9/64-40 × 7.2) 止ネジ 4
39 3020422 Needle Bar 針棒 1
40 0068053 Needle Clamp(5.2) 針止メ 1
41 ---- Needle(system:UY118GAS) 針 4
42 ---- Retainer(system:36211) リテイナ 1
43 004170 Screw(3/32-56 × 2.5) 止ネジ 5
44 0068490 Stitch Plate 針板 1
45-1 0068491 Stitch Plate Tongue 針板爪 1
45-2 3028003 Stitch Plate Tongue(for woolly thread)(Extra) 針板爪(ウーリー糸用)(特注品) 1
46 004182 Screw(3/32-56 × 2.5) 止ネジ 1
47 3020429 Needle Bar Lever, C. Set 針棒レバー(組) 1
48 3020432 Collar(12.7 × 22 × 8) カラー 1
49 003659 Screw(M5-0.8 × 5) 止ネジ 2
From the library of: Superior Sewing Machine & Supply LLC FD-62G
jintex.in
Page 20
Yamato FD-62G parts on page 20| Ref | Part number | Part name | Qty |
|---|
| 1 | Knob | |
| 2 | Washer | |
| 3 | Spring | |
| 4 | Bracket | |
| 5 | Screw | |
| 6 | Shaft | |
| 7 | Pin | |
| 8 | Washer | |
| 9 | Shaft | |
| 10 | Washer | |
| 11 | Knob | |
| 12 | Screw | |
| 13 | Shaft | |
| 14 | Lever | |
| 15 | Shaft | |
| 16 | Lever | |
| 17 | Lever | |
| 18 | Lever | |
| 19 | Pin | |
| 20 | Screw | |
| 21 | Shaft | |
| 22 | Lever | |
| 23 | Screw | |
| 24 | Shaft | |
| 25 | Lever | |
| 26 | Screw | |
| 27 | Bracket | |
| 28 | Plate | |
| 29 | Screw | |
| 30 | Lever | |
| 31 | Pin | |
| 32 | Screw | |
| 33 | Spring | |
| 34 | Shaft | |
| 35 | Lever | |
| 36 | Plate | |
| 37 | Lever | |
| 38 | Screw | |
| 39 | Spring | |
| 40 | Plate | |
| 41 | Spring | |
| 42 | Screw | |
| 43 | Lever | |
| 44 | Screw | |
| 45 | Shaft | |
| 46 | Bracket | |
| 47 | Accessory Part | |
| 48 | Accessory Part | |
| 49 | Bracket | |
| 50 | Screw | |
| 51 | Bracket | |
| 52 | Screw | |
| 53 | Screw | |
| 54 | Lever | |
| 55 | Screw | |
| 56 | Shaft | |
| 57 | Shaft | |
| 58 | Lever | |
| 59 | Screw | |
| 60 | Lever | |
| 61 | Bracket | |
| 62 | Spring | |
| 63 | Screw | |
6
1
2
3
4
5
7
6
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
ACCESSORY PARTS
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 21 — PRESSER FOOT MECHANISM
Yamato FD-62G parts on page 21| Ref | Part number | Part name | Qty |
|---|
| 1 | 004167 | Adjusting Screw(M12-1 × 19.15) | 1 |
| 2 | 100030 | Lock Nut | 1 |
| 3 | 0068132 | Presser Spring | 1 |
| 4 | 3020024 | Presser Bar Connecting Bracket | 1 |
| 5 | 004437 | Screw(1/64-40 × 10) | 1 |
| 6 | 3020021 | Presser Foot Adjusting Screw | 1 |
| 7 | 000039 | Pin | 1 |
| 8 | 3020023 | Connecting Bracket Cushion | 1 |
| 9 | 3020020 | Presser Bar Guide | 1 |
| 10 | 100049 | Lock Nut | 1 |
| 11 | 3020022 | Adjusting Nut | 1 |
| 12 | 160024 | Screw(M6-1 × 8) | 1 |
| 13 | 0068130 | Presser Bar | 1 |
| 14 | 3027092 | Presser Foot, C. Set3 | 1 |
| 15 | 3027090 | Presser Foot | 1 |
| 16 | 009853 | Screw(11/64-40 × 6.5) | 1 |
| 17 | 0068127 | Carrier/Hook Driving Segment | 1 |
| 18 | 0068128 | Carrier/Hook Driving Lever Link | 2 |
| 19 | 0068129 | Link Pin | 4 |
| 20 | 004172 | Screw(3/32-56 × 3.4) | 4 |
| 21 | 0068126 | Thread Hook Driving Lever | 1 |
| 22 | 0068124 | Top Cover Thread Hook | 1 |
| 23 | 004353 | Screw(9/64-40 × 7) | 1 |
| 24 | 0068125 | Top Cover Thread Carrier Driving Lever | 1 |
| 25 | 0068123 | Top Cover Thread Carrier | 1 |
| 26 | 004180 | Screw(1/8-44 × 3.8) | 1 |
| 27 | 0068346 | Presser Foot Attach Piece(Right) | 1 |
| 28 | 0068347 | Presser Foot Attach Piece(Left) | 1 |
| 29 | 004154 | Screw(3/32-56 × 1.5) | 4 |
| 30 | 0068121 | Lower Knife | 1 |
| 31 | 3027123 | Lower Knife Clamp | 1 |
| 32 | 001227 | Screw(1/8-44 × 3.8) | 1 |
| 33 | 0068117 | Yielding Section Spring | 1 |
| 34 | 3027120 | Yielding Section | 1 |
| 35 | 004180 | Screw(1/8-44 × 4.8) | 1 |
| 36 | 0068118 | Presser Foot Spring Plate(A)(Left) | 1 |
| 37 | 0068119 | Presser Foot Spring Plate(A)(Right) | 1 |
| 38 | 004173 | Screw(3/32-56 × 2.4) | 2 |
| 39 | 0068120 | Spring Plate Holder | 1 |
| 40 | 0068187 | Chip Guard | 1 |
PRESSER FOOT MECHANISM
押工機構
6
Ref.No
Parts No.
Description
品
名
Amt. Req
1
004167
Adjusting Screw(M12-1 × 19.15)
調節ネジ
1
2
100030
Lock Nut
ロックナット
1
3
0068132
Presser Spring
押エバネ
1
4
3020024
Presser Bar Connecting Bracket
押工棒抱キ
1
5
004437
Screw(1/64-40 × 10)
止ネジ
1
6
3020021
Presser Foot Adjusting Screw
押工高サ調節ネジ
1
7
000039
Pin
ピン
1
8
3020023
Connecting Bracket Cushion
押工棒抱キクッション
1
9
3020020
Presser Bar Guide
押工棒ガイド
1
10
100049
Lock Nut
ロックナット
1
11
3020022
Adjusting Nut
調節ナット
1
12
160024
Screw(M6-1 × 8)
止ネジ
1
13
0068130
Presser Bar
押工棒
1
14
3027092
Presser Foot, C. Set3
押工(組3)
1
15
3027090
Presser Foot
押工
1
16
009853
Screw(11/64-40 × 6.5)
止ネジ
1
17
0068127
Carrier/Hook Driving Segment
キャリア・フックセグメント
1
18
0068128
Carrier/Hook Driving Lever Link
キャリア・フックレバーリンク
2
19
0068129
Link Pin
リンクピン
4
20
004172
Screw(3/32-56 × 3.4)
止ネジ
4
21
0068126
Thread Hook Driving Lever
飾り糸フックレバー
1
22
0068124
Top Cover Thread Hook
飾り糸フック
1
23
004353
Screw(9/64-40 × 7)
止ネジ
1
24
0068125
Top Cover Thread Carrier Driving Lever
飾り糸キャリアレバー
1
25
0068123
Top Cover Thread Carrier
飾り糸キャリア
1
26
004180
Screw(1/8-44 × 3.8)
止ネジ
1
27
0068346
Presser Foot Attach Piece(Right)
押工ガイド板(右)
1
28
0068347
Presser Foot Attach Piece(Left)
押工ガイド板(左)
1
29
004154
Screw(3/32-56 × 1.5)
止ネジ
4
30
0068121
Lower Knife
下メス
1
31
3027123
Lower Knife Clamp
下メスクランプ
1
32
001227
Screw(1/8-44 × 3.8)
止ネジ
1
33
0068117
Yielding Section Spring
小押エバネ
1
34
3027120
Yielding Section
小押工
1
35
004180
Screw(1/8-44 × 4.8)
止ネジ
1
36
0068118
Presser Foot Spring Plate(A)(Left)
押工板バネ(A)(左)
1
37
0068119
Presser Foot Spring Plate(A)(Right)
押工板バネ(A)(右)
1
38
004173
Screw(3/32-56 × 2.4)
止ネジ
2
39
0068120
Spring Plate Holder
押工板バネホルダ
1
40
0068187
Chip Guard
チップガード
1
Ref. No. 41 to 63 See the following page.
From the library of: Superior Sewing Machine & Supply LLC
FD-62G
Page 22
Yamato FD-62G parts on page 22| Ref | Part number | Part name | Qty |
|---|
| 1 | 1 | SCREW | |
| 2 | 2 | WASHER | |
| 3 | 3 | SPRING | |
| 4 | 4 | BRACKET | |
| 5 | 5 | SCREW | |
| 6 | 6 | COVER | |
| 7 | 7 | PIN | |
| 8 | 8 | WASHER | |
| 9 | 9 | SHAFT | |
| 10 | 10 | WASHER | |
| 11 | 11 | NUT | |
| 12 | 12 | SPRING | |
| 13 | 13 | ROD | |
| 14 | 14 | BRACKET | |
| 15 | 15 | SHAFT | |
| 16 | 16 | BRACKET | |
| 17 | 17 | BRACKET | |
| 18 | 18 | BRACKET | |
| 19 | 19 | PIN | |
| 20 | 20 | SCREW | |
| 21 | 21 | SHAFT | |
| 22 | 22 | BRACKET | |
| 23 | 23 | SCREW | |
| 24 | 24 | BRACKET | |
| 25 | 25 | BRACKET | |
| 26 | 26 | SCREW | |
| 27 | 27 | BRACKET | |
| 28 | 28 | PLATE | |
| 29 | 29 | SCREW | |
| 30 | 30 | PLATE | |
| 31 | 31 | SPRING | |
| 32 | 32 | SPRING | |
| 33 | 33 | SPRING | |
| 34 | 34 | SHAFT | |
| 35 | 35 | SCREW | |
| 36 | 36 | PLATE | |
| 37 | 37 | SCREW | |
| 38 | 38 | SCREW | |
| 39 | 39 | SPRING | |
| 40 | 40 | PLATE | |
| 41 | 41 | SPRING | |
| 42 | 42 | SCREW | |
| 43 | 43 | BRACKET | |
| 44 | 44 | SCREW | |
| 45 | 45 | BRACKET | |
| 46 | 46 | SCREW | |
| 47 | 47 | ACCESSORY PART | |
| 48 | 48 | ACCESSORY PART | |
| 49 | 49 | BRACKET | |
| 50 | 50 | SCREW | |
| 51 | 51 | BRACKET | |
| 52 | 52 | SCREW | |
| 53 | 53 | SCREW | |
| 54 | 54 | SPRING | |
| 55 | 55 | BRACKET | |
| 56 | 56 | SHAFT | |
| 57 | 57 | SHAFT | |
| 58 | 58 | BRACKET | |
| 59 | 59 | BRACKET | |
| 60 | 60 | SCREW | |
| 61 | 61 | BRACKET | |
| 62 | 62 | SPRING | |
| 63 | 63 | SCREW | |
6
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
ACCESSORY PARTS
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 23 — PRESSER FOOT MECHANISM
Yamato FD-62G parts on page 23| Ref | Part number | Part name | Qty |
|---|
| 41 | 3027087 | Chip Guard Spring | 1 |
| 42 | 004166 | Screw(1/8-44 × 3.2) | 1 |
| 43 | 0068135 | Presser Foot Guide(Right) | 1 |
| 44 | 004176 | Screw(M5-0.8 × 12) | 1 |
| 45 | 0068136 | Presser Foot Guide(Left) | 1 |
| 46 | 005650 | Screw(M5-0.8 × 14) | 2 |
| 47 | 0068157 | Presser Foot Spring Plate(B)(Left) | 1 |
| 48 | 0068158 | Presser Foot Spring Plate(B)(Right) | 1 |
| 49 | 0068164 | Lifter Lever Supplementary Plate | 1 |
| 50 | 004216 | Screw(3/16-32 × 4) | 5 |
| 51 | 0068162 | Presser Bar Lifter Lever(Large) | 1 |
| 52 | 005553 | Screw(7/32-32 × 12) | 1 |
| 53 | 0068141 | Stop Plunger Segment Pin | 1 |
| 54 | 160009 | Screw(M5-0.8 × 5) | 1 |
| 55 | 0068140 | Stop Plunger Segment | 1 |
| 56 | 000363 | Nut | 1 |
| 57 | 0068138 | Presser Foot Lifter Stop Plunger | 1 |
| 58 | 0068142 | Presser Foot Lifter Lever Link(Long) | 1 |
| 59 | 004358 | Screw(9/64-40 × 5.6) | 2 |
| 60 | 0068154 | Presser Foot Lifter Lever Link(Short) | 1 |
| 61 | 0068163 | Presser Bar Lifter Lever(Small) | 1 |
| 62 | 003670 | Screw(7/32-32 × 6.3) | 1 |
| 63 | 0068144 | Presser Bar Lifter Lever | 1 |
PRESSER FOOT MECHANISM
押工機構
6
Ref.No
Parts No.
Description
品 名
Amt. Req
41
3027087
Chip Guard Spring
チップガードバネ
1
42
004166
Screw(1/8-44 × 3.2)
止ネジ
1
43
0068135
Presser Foot Guide(Right)
押エガイド(右)
1
44
004176
Screw(M5-0.8 × 12)
止ネジ
1
45
0068136
Presser Foot Guide(Left)
押エガイド(左)
1
46
005650
Screw(M5-0.8 × 14)
止ネジ
2
47
0068157
Presser Foot Spring Plate(B)(Left)
押工板バネ(B)(左)
1
48
0068158
Presser Foot Spring Plate(B)(Right)
押工板バネ(B)(右)
1
49
0068164
Lifter Lever Supplementary Plate
押工場ゲレバー補助板
1
50
004216
Screw(3/16-32 × 4)
止ネジ
5
51
0068162
Presser Bar Lifter Lever(Large)
押工場ゲレバー(大)
1
52
005553
Screw(7/32-32 × 12)
止ネジ
1
53
0068141
Stop Plunger Segment Pin
セグメントピン
1
54
160009
Screw(M5-0.8 × 5)
止ネジ
1
55
0068140
Stop Plunger Segment
ストッププランジャセグメント
1
56
000363
Nut
ナット
1
57
0068138
Presser Foot Lifter Stop Plunger
ストッププランジャ
1
58
0068142
Presser Foot Lifter Lever Link(Long)
押工場ゲリンク(長)
1
59
004358
Screw(9/64-40 × 5.6)
止ネジ
2
60
0068154
Presser Foot Lifter Lever Link(Short)
押工場ゲリンク(短)
1
61
0068163
Presser Bar Lifter Lever(Small)
押工場ゲレバー(小)
1
62
003670
Screw(7/32-32 × 6.3)
止ネジ
1
63
0068144
Presser Bar Lifter Lever
押工場ゲ
1
From the library of: Superior Sewing Machine & Supply LLC
FD-62G
jintex.in
Page 24
Yamato FD-62G parts on page 24| Ref | Part number | Part name | Qty |
|---|
| 1 | 1 | BOLT | |
| 2 | 2 | BRACKET | |
| 3 | 3 | BOLT | |
| 4 | 4 | BRACKET | |
| 5 | 5 | WASHER | |
| 6 | 6 | NUT | |
| 7 | 7 | BRACKET | |
| 8 | 8 | BOLT | |
| 9 | 9 | BRACKET | |
| 10 | 10 | SCREW | |
| 11 | 11 | SCREW | |
| 12 | 12 | BRACKET | |
| 13 | 13 | SHAFT | |
| 14 | 14 | WASHER | |
| 15 | 15 | BRACKET | |
| 16 | 16 | BRACKET | |
| 17 | 17 | BOLT | |
| 18 | 18 | BOLT | |
| 19 | 19 | NUT | |
| 20 | 20 | BOLT | |
| 21 | 21 | NUT | |
| 22 | 22 | BOLT | |
| 23 | 23 | BRACKET | |
| 24 | 24 | BOLT | |
| 25 | 25 | BRACKET | |
| 26 | 26 | CYLINDER | |
| 27 | 27 | WASHER | |
| 28 | 28 | CYLINDER | |
| 29 | 29 | SCREW | |
| 30 | 30 | WASHER | |
| 31 | 31 | WASHER | |
| 32 | 32 | BRACKET | |
| 33 | 33 | BRACKET | |
| 34 | 34 | SPRING | |
| 35 | 35 | BRACKET | |
| 36 | 36 | BRACKET | |
| 37 | 37 | SHAFT | |
| 38 | 38 | BRACKET | |
| 39 | 39 | SCREW | |
| 40 | 40 | BRACKET | |
| 41 | 41 | SPRING | |
| 42 | 42 | BRACKET | |
| 43 | 43 | BRACKET | |
| 44 | 44 | BOLT | |
| 45 | 45 | SPRING | |
7
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
Jinte.in
Page 25 — UPPER KNIFE, CARRIER AND HOOK DRIVING MECHANISM
Yamato FD-62G parts on page 25| Ref | Part number | Part name | Qty |
|---|
| 0068968 | Carrier/Hook Driving Rod(Left), C. Set | 1 |
| 0068148 | Carrier Hook Driving Rod(Left) | 1 |
| 0068174 | Rod Ball(Left) | 1 |
| 001174 | Screw(9/64-40 × 10.3) | 2 |
| 000471 | Nut | 1 |
| 000347 | Nut | 2 |
| 0068150 | Carrier Hook Sleeve Lever | 1 |
| 007609 | Screw(9/64-40 × 9) | 1 |
| 3020425 | Needle Thread Take-up | 1 |
| 110003 | Screw(M3.5-0.6 × 6) | 1 |
| 110004 | Screw(M3.5-0.6 × 8) | 2 |
| 3020426 | Bracket | 1 |
| 3020430 | Knife Driving Lever | 1 |
| 0068176 | Steady Washer | 1 |
| 3020061 | Knife Driving Connection(Right), C. Set | 1 |
| 3020048 | Knife Driving Connection(Right) | 1 |
| 3020047 | Knife Driving Connection Ball(Right) | 1 |
| 120053 | Screw(M3.5-0.6 × 14) | 4 |
| 000356 | Nut(Left-handed Screw) | 1 |
| 0068175 | Knife Driving Connecting Rod | 1 |
| 000355 | Nut | 1 |
| 3020062 | Knife Driving Connection(Left), C. Set | 1 |
| 3020049 | Knife Driving Connection(Left) | 1 |
| 3020050 | Rod Ball(Left) | 1 |
| 3020407 | Knife Holder Bracket, C. Set | 1 |
| 3020410 | Thread Carrier and Hook Sleeve Bushing | 1 |
| 3020409 | Bushing Ring | 1 |
| 3020436 | Carrier/Hook Driving Sleeve | 1 |
| 310113 | Oil Wick | 1 |
| 3020414 | Oil Seal | 1 |
| 3020415 | Oil Seal | 1 |
| 3020002 | Knife Holder Guide Collar, C. Set | 1 |
| 0068348 | Knife Holder Shank Support | 1 |
| 0068181 | Knife Holder Spring | 1 |
| 0068182 | Knife Holder Guide Collar | 1 |
| 004185 | Screw(9/64-40 × 7.2) | 1 |
| 0068180 | Knife Holder Shank | 1 |
| 001175 | Screw(9/64-40 × 8) | 2 |
| 004181 | Screw(3/32-56 × 3.6) | 1 |
| 0068185 | Knife Support | 1 |
| 004179 | Screw(3/32-56 × 1.2) | 1 |
| 0068184 | Upper Knife | 1 |
| 0068183 | Knife Holder | 1 |
| 004171 | Screw(3/32-56 × 13) | 2 |
| 003635 | Screw(1/4-40 × 6) | 1 |
UPPER KNIFE, CARRIER AND HOOK DRIVING MECHANISM 上メス及びキャリア・フック機構 7
Ref.No Parts No. Description 品 名 Amt. Req
1 0068968 Carrier/Hook Driving Rod(Left), C. Set キャリア・フックロッド(左)(組) 1
2 0068148 Carrier Hook Driving Rod(Left) キャリア・フックロッド(左) 1
3 0068174 Rod Ball(Left) ロッド球(左) 1
4 001174 Screw(9/64-40 × 10.3) 止ネジ 2
5 000471 Nut ナット 1
6 000347 Nut ナット 2
7 0068150 Carrier Hook Sleeve Lever スリーブレバー 1
8 007609 Screw(9/64-40 × 9) 止ネジ 1
9 3020425 Needle Thread Take-up 針糸繰り糸道 1
10 110003 Screw(M3.5-0.6 × 6) 止ネジ 1
11 110004 Screw(M3.5-0.6 × 8) 止ネジ 2
12 3020426 Bracket 針糸繰り台 1
13 3020430 Knife Driving Lever 上メスレバー 1
14 0068176 Steady Washer 振れ止めメス 1
15 3020061 Knife Driving Connection(Right), C. Set 上メスロッド(右)(組) 1
16 3020048 Knife Driving Connection(Right) 上メスロッド(右) 1
17 3020047 Knife Driving Connection Ball(Right) 上メスロッド球(右) 1
18 120053 Screw(M3.5-0.6 × 14) 止ネジ 4
19 000356 Nut(Left-handed Screw) ナット(左ネジ) 1
20 0068175 Knife Driving Connecting Rod 上メスロッド連結棒 1
21 000355 Nut ナット 1
22 3020062 Knife Driving Connection(Left), C. Set 上メスロッド(左)(組) 1
23 3020049 Knife Driving Connection(Left) 上メスロッド(左) 1
24 3020050 Rod Ball(Left) ロッド球(左) 1
25 3020407 Knife Holder Bracket, C. Set 上メスホルダブラケット(組) 1
26 3020410 Thread Carrier and Hook Sleeve Bushing キャリア・フックスリーブブッシュ 1
27 3020409 Bushing Ring ブッシングリング 1
28 3020436 Carrier/Hook Driving Sleeve キャリア・フックスリーブ 1
29 310113 Oil Wick 油芯 1
30 3020414 Oil Seal オイルシール 1
31 3020415 Oil Seal オイルシール 1
32 3020002 Knife Holder Guide Collar, C. Set 上メスホルダガイドカラー(組) 1
33 0068348 Knife Holder Shank Support 上メスホルダシャンク台 1
34 0068181 Knife Holder Spring 上メスホルダバネ 1
35 0068182 Knife Holder Guide Collar 上メスホルダガイドカラー 1
36 004185 Screw(9/64-40 × 7.2) 止ネジ 1
37 0068180 Knife Holder Shank 上メスホルダシャンク 1
38 001175 Screw(9/64-40 × 8) 止ネジ 2
39 004181 Screw(3/32-56 × 3.6) 止ネジ 1
40 0068185 Knife Support 上メスサポート 1
41 004179 Screw(3/32-56 × 1.2) 止ネジ 1
42 0068184 Upper Knife 上メス 1
43 0068183 Knife Holder 上メスホルダ 1
44 004171 Screw(3/32-56 × 13) 止ネジ 2
45 003635 Screw(1/4-40 × 6) 止ネジ 1
From the library of: Superior Sewing Machine & Supply LLC FD-62G
jintex.in
Page 26
Yamato FD-62G parts on page 26| Ref | Part number | Part name | Qty |
|---|
| 19 | 21 | SCREW | |
| 20 | 20 | BRACKET | |
| 22 | 22 | SHAFT | |
| 48 | 48 | BRACKET | |
| 9 | 9 | NUT | |
| 24 | 24 | STUD BOLT | |
| 25 | 25 | WASHER | |
| 21 | 21 | SCREW | |
| 26 | 26 | BRACKET | |
| 27 | 27 | SHAFT | |
| 49 | 49 | BRACKET | |
| 30 | 30 | ADJUSTING SCREW | |
| 29 | 29 | BRACKET | |
| 1 | 1 | BRACKET | |
| 2 | 2 | SCREW | |
| 3 | 3 | PIN | |
| 50 | 50 | BRACKET | |
| 4 | 4 | WASHER | |
| 6 | 6 | SCREW | |
| 5 | 5 | BRACKET | |
| 7 | 7 | ARM | |
| 8 | 8 | WASHER | |
| 9 | 9 | NUT | |
| 10 | 10 | CIRCLIP | |
| 11 | 11 | PIN | |
| 14 | 14 | SCREW | |
| 13 | 13 | BEARING | |
| 12 | 12 | SCREW | |
| 18 | 18 | BRACKET | |
| 23 | 23 | BRACKET | |
| 15 | 15 | SHAFT | |
| 17 | 17 | STUD BOLT | |
| 31 | 31 | SHAFT | |
| 28 | 28 | NUT | |
| 46 | 46 | BRACKET | |
| 45 | 45 | BRACKET | |
| 41 | 41 | WASHER | |
| 37 | 37 | BRACKET | |
| 32 | 32 | BRACKET | |
| 35 | 35 | PIN | |
| 36 | 36 | SCREW | |
| 33 | 33 | WASHER | |
| 34 | 34 | SCREW | |
| 38 | 38 | SCREW | |
| 40 | 40 | SCREW | |
| 44 | 44 | BRACKET | |
| 39 | 39 | BRACKET | |
| 42 | 42 | SCREW | |
| 43 | 43 | BRACKET | |
| 47 | 47 | BRACKET | |
8
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
Jinte.in
Page 27 — LOOPER DRIVING MECHANISM
Yamato FD-62G parts on page 27| Ref | Part number | Part name | Qty |
|---|
| 0068197 | Looper Driving Crank Pin | |
| 004165 | Screw(9/64-40 × 16.3) | |
| 000477 | Roll Pin for Main Shaft | |
| 3020040 | Looper Lever Driving Rod, C. Set | |
| 3020042 | Looper Lever Driving Rod Ball | |
| 120053 | Screw(M3.5-0.6 × 14) | |
| 3020041 | Looper Lever Driving Rod | |
| 000586 | Washer | |
| 000356 | Nut(Left-handed Screw) | |
| 0068202 | Retaining Ring | |
| 0068205 | Looper Lever Driving Rod Pin | |
| 001222 | Screw(1/8-44 × 4.8) | |
| 0068207 | Collar(8.1 × 14 × 6.4mm) | |
| 009604 | Screw(11/64-40 × 5.5)[11/64-40 × 3.3] | |
| 0068204 | Looper Lever Shaft | |
| 004164 | Screw(7/32-32 × 20) | |
| 0068203 | Looper Lever | |
| 3020060 | Looper Driving Connection Rod, C. Set | |
| 3020051 | Looper Driving Connection(Upper) | |
| 120053 | Screw(M3.5-0.6 × 14) | |
| 3020047 | Looper Driving Connection Ball(Upper) | |
| 000470 | Nut | |
| 0068175 | Looper Driving Connecting Rod | |
| 000355 | Nut | |
| 3020052 | Looper Driving Connection(Lower) | |
| 3020053 | Looper Driving Connection Ball(Lower) | |
| 000306 | Nut | |
| 0068069 | Steady Fork | |
| 110004 | Screw(M3.5-0.6 × 8) | |
| 0068213 | Looper Rocker Shaft | |
| 0068222 | Looper Rocker Shaft Sleeve | |
| 000548 | Washer | |
| 004352 | Screw(9/64-40 × 11.3) | |
| 0068223 | Looper Rocker Shaft Sleeve Guide | |
| 003473 | Screw(3/16-32 × 7.9) | |
| 0068224 | Collar(9.53 × 16 × 8mm) | |
| 005550 | Screw(11/64-40 × 13.5) | |
| 0068216 | Looper Holder | |
| 005040 | Screw(11/64-40 × 8.5) | |
| 000489 | Packing | |
| 004169 | Adjusting Screw(9/64-40 × 8.2) | |
| 0068217 | Looper | |
| 210007 | Screw(1/4-24 × 20) | |
| 0068218 | Needle Guard(Front) | |
| 004284 | Screw(29/256-48 × 3.2) | |
| 004181 | Screw(3/32-56 × 3.6) | |
| 3020063 | Looper Driving Connection(Upper),C.Set | |
| 3020064 | Looper Driving Connection(Lower),C.Set | |
| 3020043 | Spacer | |
LOOPER DRIVING MECHANISM
ルーパ機構
8
Ref.No
Parts No.
Description
品 名
Amt. Req
1
0068197
Looper Driving Crank Pin
ルーパクランクピン
1
2
004165
Screw(9/64-40 × 16.3)
止ネジ
1
3
000477
Roll Pin for Main Shaft
ピン
1
4
3020040
Looper Lever Driving Rod, C. Set
ルーパレバーロッド(組)
1
5
3020042
Looper Lever Driving Rod Ball
ルーパレバーロッド球
1
6
120053
Screw(M3.5-0.6 × 14)
止ネジ
2
7
3020041
Looper Lever Driving Rod
ルーパレバーロッド
1
8
000586
Washer
ワッシャ
1
9
000356
Nut(Left-handed Screw)
ナット(左ネジ)
2
10
0068202
Retaining Ring
ストップリング
2
11
0068205
Looper Lever Driving Rod Pin
ルーパレバーロッドピン
1
12
001222
Screw(1/8-44 × 4.8)
止ネジ
1
13
0068207
Collar(8.1 × 14 × 6.4mm)
カラー
2
14
009604
[001457]
Screw(11/64-40 × 5.5)[11/64-40 × 3.3]
止ネジ
2
15
0068204
Looper Lever Shaft
ルーパレバー軸
1
16
17
004164
Screw(7/32-32 × 20)
止ネジ
1
18
0068203
Looper Lever
ルーパレバー
1
19
3020060
Looper Driving Connection Rod, C. Set
ルーパロッド(組)
1
20
3020051
Looper Driving Connection(Upper)
ルーパロッド(上)
1
21
120053
Screw(M3.5-0.6 × 14)
止ネジ
4
22
3020047
Looper Driving Connection Ball(Upper)
ルーパロッド球(上)
1
23
000470
Nut
ナット
1
24
0068175
Looper Driving Connecting Rod
ルーパロッド連結棒
1
25
000355
Nut
ナット
1
26
3020052
Looper Driving Connection(Lower)
ルーパロッド(下)
1
27
3020053
Looper Driving Connection Ball(Lower)
ルーパロッド球(下)
1
28
000306
Nut
ナット
1
29
0068069
Steady Fork
振レ止メ
1
30
110004
Screw(M3.5-0.6 × 8)
止ネジ
1
31
0068213
Looper Rocker Shaft
ルーパ軸
1
32
0068222
Looper Rocker Shaft Sleeve
ルーパ軸スリーブ
1
33
000548
Washer
ワッシャ
1
34
004352
Screw(9/64-40 × 11.3)
止ネジ
1
35
0068223
Looper Rocker Shaft Sleeve Guide
ルーパ軸スリーブガイド
1
36
003473
Screw(3/16-32 × 7.9)
止ネジ
1
37
0068224
Collar(9.53 × 16 × 8mm)
カラー
1
38
005550
Screw(11/64-40 × 13.5)
止ネジ
1
39
0068216
Looper Holder
ルーパ台
1
40
005040
Screw(11/64-40 × 8.5)
止ネジ
1
41
000489
Packing
パッキン
1
42
004169
Adjusting Screw(9/64-40 × 8.2)
調節ネジ
1
43
0068217
Looper
ルーパ
1
44
210007
Screw(1/4-24 × 20)
止ネジ
1
45
0068218
Needle Guard(Front)
針受(前)
1
46
004284
Screw(29/256-48 × 3.2)
止ネジ
2
47
004181
Screw(3/32-56 × 3.6)
止ネジ
1
48
3020063
Looper Driving Connection(Upper),C.Set
ルーパロッド(上)(組)
1
49
3020064
Looper Driving Connection(Lower),C.Set
ルーパロッド(下)(組)
1
50
3020043
Spacer
スペーサ
1
From the library of: Superior Sewing Machine & Supply LLC
FD-62G
jintex.in
Page 28
Yamato FD-62G parts on page 28| Ref | Part number | Part name | Qty |
|---|
| 3 | 3 | SCREW | |
| 14 | 14 | SPRING | |
| 2 | 2 | BRACKET | |
| 5 | 5 | SPRING | |
| 17 | 17 | ROLLER | |
| 6 | 6 | NUT | |
| 7 | 7 | SHAFT | |
| 10 | 10 | SCREW | |
| 8 | 8 | NUT | |
| 9 | 9 | BRACKET | |
| 11 | 11 | SHAFT | |
| 12 | 12 | BRACKET | |
| 13 | 13 | SCREW | |
| 19 | 19 | BRACKET | |
| 20 | 20 | SCREW | |
| 21 | 21 | BRACKET | |
| 22 | 22 | WASHER | |
| 23 | 23 | NUT | |
| 25 | 25 | SHAFT | |
| 26 | 26 | BRACKET | |
| 28 | 28 | SCREW | |
| 29 | 29 | SCREW | |
| 24 | 24 | WASHER | |
| 27 | 27 | SHAFT | |
| 35 | 35 | NUT | |
| 31 | 31 | SCREW | |
| 32 | 32 | BUSHING | |
| 33 | 33 | BUSHING | |
| 34 | 34 | LINK | |
9
1
14
36
3
15
2
5
38
2
14
16
24°30'
24°30'
6
7
37
10
8
9
11
9
19
12 13
18
8
39
19
20
10
21 22
23
25
125.4
123.4
26
28
29
27
24
35
30
31
32
33
34
31
32
33
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
Page 29 — FEED DRIVING MECHANISM
Yamato FD-62G parts on page 29| Ref | Part number | Part name | Qty |
|---|
| 3020056 | Feed Lift Eccentric, C. Set | |
| 3020028 | Feed Lift Connection(Upper) | |
| 004441 | Screw(11/64-40 × 16) | |
| 3020029 | Feed Lift Eccentric Ball | |
| 003638 | Screw(11/64-40 × 4) | |
| 000356 | Nut(Lift-handed Screw) | |
| 0068066 | Feed Lift Eccentric Connecting Rod | |
| 000355 | Nut | |
| 3020052 | Feed Lift Connection(Lower) | |
| 120053 | Screw(M3.5-0.6 × 14) | |
| 3020045 | Feed Lift Connection Ball | |
| 0068069 | Steady Fork | |
| 110004 | Screw(M3.5-0.6 × 8) | |
| 310084 | Oil Wick(Woollen Yarn)(70mm) | |
| 000755 | Pin | |
| 3020058 | Feed Drive Eccentric, C. Set | |
| 3020033 | Feed Drive Eccentric Ball | |
| 3020112 | Feed Drive Eccentric Connecting Rod | |
| 3020049 | Feed Drive Connection(Lower) | |
| 3020046 | Feed Drive Connection Ball | |
| 0068076 | Steady Washer | |
| 000474 | Washer | |
| 000306 | Nut | |
| 0068079 | O-ring(P9) | |
| 0068345 | Feed Drive Shaft | |
| 0068077 | Feed Drive/Looper Avoid Lever | |
| 0068080 | Feed Drive Shaft Bushing | |
| 005047 | Screw(3/16-32 × 9.5) | |
| 004203 | Screw(3/16-32 × 9.5) | |
| 0068219 | Looper Avoid Connecting Rod, C. Set | |
| 004162 | Screw(7/32-32 × 15) | |
| 0068221 | Looper Avoid Connecting Rod Bushing | |
| 0068199 | Needle Bearing | |
| 0068220 | Looper Avoid Connecting Rod | |
| 0068228 | Looper Avoid Adjusting Nut | |
| 3020027 | Feed Lift Connection(Upper), C. Set | |
| 3020057 | Feed Lift Connection(Lower), C. Set | |
| 3020032 | Feed Drive Eccentric(Upper), C. Set | |
| 3020059 | Feed Drive Eccentric(Lower), C. Set | |
FEED DRIVING MECHANISM 送り機構 9
Ref.No Parts No. Description 品 名 Amt. Req
1 3020056 Feed Lift Eccentric, C. Set 送り上下ロッド(組) 1
2 3020028 Feed Lift Connection(Upper) 送り上下ロッド(上) 2
3 004441 Screw(11/64-40 × 16) 止ネジ 4
4 3020029 Feed Lift Eccentric Ball 送り上下球エキセン 1
5 003638 Screw(11/64-40 × 4) 止ネジ 4
6 000356 Nut(Lift-handed Screw) ナット(左ネジ) 2
7 0068066 Feed Lift Eccentric Connecting Rod 送り上下ロッド連結棒 1
8 000355 Nut ナット 2
9 3020052 Feed Lift Connection(Lower) 送り上下ロッド(下) 1
10 120053 Screw(M3.5-0.6 × 14) 止ネジ 4
11 3020045 Feed Lift Connection Ball 送り上下ロッド球 1
12 0068069 Steady Fork 振レ止メ 1
13 110004 Screw(M3.5-0.6 × 8) 止ネジ 1
14 310084 Oil Wick(Woollen Yarn)(70mm) 油芯(毛糸) 2
15 000755 Pin 止ピン 2
16 3020058 Feed Drive Eccentric, C. Set 送り前後ロッド(組) 1
17 3020033 Feed Drive Eccentric Ball 送り前後球エキセン 1
18 3020112 Feed Drive Eccentric Connecting Rod 送り前後ロッド連結棒 1
19 3020049 Feed Drive Connection(Lower) 送り前後ロッド(下) 1
20 3020046 Feed Drive Connection Ball 送り前後ロッド球 1
21 0068076 Steady Washer 振レ止メ 1
22 000474 Washer ワッシャ 1
23 000306 Nut ナット 1
24 0068079 O-ring(P9) Oリング 1
25 0068345 Feed Drive Shaft 送リレバー軸 1
26 0068077 Feed Drive/Looper Avoid Lever 送リレバー 1
27 0068080 Feed Drive Shaft Bushing 送リレバー軸ブッシュ 1
28 005047 Screw(3/16-32 × 9.5) 止ネジ 1
29 004203 Screw(3/16-32 × 9.5) 止ネジ 1
30 0068219 Looper Avoid Connecting Rod, C. Set ルーパ前後ロッド(組) 1
31 004162 Screw(7/32-32 × 15) 止ネジ 2
32 0068221 Looper Avoid Connecting Rod Bushing ルーパ前後ロッドブッシュ 2
33 0068199 Needle Bearing ベアリング(G B-65) 2
34 0068220 Looper Avoid Connecting Rod ルーパ前後ロッド 1
35 0068228 Looper Avoid Adjusting Nut 調節ナット 1
36 3020027 Feed Lift Connection(Upper), C. Set 送り上下ロッド(上)(組) 1
37 3020057 Feed Lift Connection(Lower), C. Set 送り上下ロッド(下)(組) 1
38 3020032 Feed Drive Eccentric(Upper), C. Set 送り前後ロッド(上)(組) 1
39 3020059 Feed Drive Eccentric(Lower), C. Set 送り前後ロッド(下)(組) 1
From the library of: Superior Sewing Machine & Supply LLC
jintex.in FD-62G
Page 30
Yamato FD-62G parts on page 30| Ref | Part number | Part name | Qty |
|---|
| 9 | 9 | Screw | |
| 8 | 8 | Feed Dog | |
| 10 | 10 | Feed Dog Holder | |
| 11 | 11 | Screw | |
| 7 | 7 | Feed Dog Holder | |
| 16 | 16 | Cover | |
| 17 | 17 | Screw | |
| 18 | 18 | Screw | |
| 1 | 1 | Frame | |
| 5 | 5 | Screw | |
| 2 | 2 | Link | |
| 3 | 3 | Link | |
| 4 | 4 | Bracket | |
| 12 | 12 | Shaft | |
| 13 | 13 | Screw | |
| 14 | 14 | Washer | |
| 21 | 21 | Link | |
| 22 | 22 | Shaft | |
| 46 | 46 | Screw | |
| 47 | 47 | Screw | |
| 24 | 24 | Shaft | |
| 26 | 26 | Lever | |
| 25 | 25 | Screw | |
| 27 | 27 | Screw | |
| 23 | 23 | Bracket | |
| 32 | 32 | Shaft | |
| 33 | 33 | Link | |
| 31 | 31 | Screw | |
| 20 | 20 | Pin | |
| 17 | 17 | Screw | |
| 34 | 34 | Screw | |
| 35 | 35 | Nut | |
| 38 | 38 | Gasket | |
| 39 | 39 | Disc | |
| 40 | 40 | Screw | |
| 41 | 41 | Washer | |
| 42 | 42 | Washer | |
| 45 | 45 | Shaft | |
| 44 | 44 | Washer | |
| 29 | 29 | Ring | |
| 30 | 30 | Shaft | |
| 19 | 19 | Lever | |
| 20 | 20 | Pin | |
| 6 | 6 | Screw | |
10
9
8
10
11
7
16
17
18
1
5
2
3
4
12
13
14
21
22
46
47
24
26
25
27
23
32
33
31
20
17
34
35
38
39
40
41
42
45
44
29
30
19
20
FD-62G
From the library of: Superior Sewing Machine & Supply LLC
jintex.in
