Page 7 — A. フレーム関係 / Machine body
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2 | S39605001 | TOP COVER | 1 |
| 3 | S02606020 | OIL GAUGE WINDOW | 1 |
| 4 | 062401012 | SCREW, PAN M4X10 | 6 |
| 5 | S39606020 | PACKING | 1 |
| 6 | 081014670 | O RING, PW14 | 1 |
| 7 | S23337001 | RUBBER CAP, 18.5 | 1 |
| 8 | S39607001 | SIDE COVER, FRAME | 1 |
| 9 | 062400812 | SCREW, PAN M4X8 | 5 |
| 10 | S20345001 | RUBBER CAP, 14 | 1 |
| 11 | S39608021 | FACE PLATE COVER | 1 |
| 12 | 060400612 | SCREW, BIND M4X6 | 1 |
| 13 | S20310001 | COVER, B ;FEED MECHANISM | 1 |
| 14 | S20311000 | PACKING | 1 |
| 15 | 060400812 | SCREW, BIND M4X8 | 6 |
| 19 | S44778000 | PACKING, FEED BAR | 1 |
| 20 | 018400832 | BOLT, SOCKET M4X8 | 1 |
| 21 | S44779001 | FEED BAR COVER | 1 |
| 22-1 | 060400812 | SCREW, BIND M4X8 | 5 |
| 22-2 | S44535001 | SCREW, BIND M4X8 SEAL | 1 |
| 3 | S39564021 | INSIDE COVER | 1 |
| 4 | S44536000 | PACKING, INSIDE COVER | 1 |
| 25-1 | 060401012 | SCREW, BIND M4X10 | 3 |
| 25-2 | S23616101 | SCREW, M4X10 | 1 |
| 25-3 | S44535001 | SCREW, BIND M4X8 SEAL | 1 |
| 26 | 061400812 | SCREW, FLAT M4X8 | 1 |
| 27 | S39611001 | FRONT COVER ASSY, L | 1 |
| 27-1 | S39612001 | FRONT COVER, L | 1 |
| 27-2 | S39613001 | HINGE SHAFT, FRONT COVER | 1 |
| 27-3 | S20319001 | HINGE, FRONT COVER | 1 |
| 27-4 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 2 |
| 27-5 | S20320101 | STOPPER, FRONT COVER | 1 |
| 27-6 | S20321001 | SPRING, FRONT COVER | 1 |
| 27-7 | 060400612 | SCREW, BIND M4X6 | 1 |
| 27-8 | S20327101 | STOPPER PLATE, FRONT COVER | 1 |
| 27-9 | 060400612 | SCREW, BIND M4X6 | 1 |
| 28 | 060401412 | SCREW, BIND M4X14 | 3 |
| 29-1 | S38305001 | FRONT COVER, S | 1 |
| 29-2 | S42050001 | FRONT COVER, S | 1 |
| 30 | 062400612 | SCREW, PAN M4X6 | 2 |
| 31 | 012400832 | SET SCREW, SOCKET (FT) M4X8 | 1 |
| 32 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 1 |
| 33 | S20324101 | GUIDE, L F-VOVER | 1 |
| 34 | 060400612 | SCREW, BIND M4X6 | 2 |
| 35 | S20325001 | SPRING, PLATE | 1 |
| 36 | 060400612 | SCREW, BIND M4X6 | 1 |
| 37 | S39562001 | CLOTH PLATE | 1 |
| 38 | S39623001 | CLOTH PLATE SHAFT | 1 |
| 39 | 141183000 | CLOTH PLATE SHEET | 1 |
| 40 | 100032003 | SCREW, FLAT SM4.37-40X8 | 1 |
| 41 | 100315002 | WASHER | 1 |
| 42 | S39624021 | SET SCREW COLLAR | 1 |
| 43 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 2 |
| 44 | S38301020 | CLOTH PLATE, LOWER | 1 |
| 46 | 060400612 | SCREW, BIND M4X6 | 4 |
| 48 | S20412000 | RUBBER CAP, 3.7 | 2 |
| 49 | S39625151 | SPRING, PLATE | 1 |
| 50 | 060400612 | SCREW, BIND M4X6 | 2 |
Page 9 — A. フレーム関係 / Machine body
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 51 | 156482000 | CAP, 4 | 1 |
| 52 | 062401212 | SCREW, PAN M4X12 | 1 |
| 53 | 021400212 | NUT, 2 M4 | 1 |
| 54 | 047602042 | PIN, SPRING ROLL 6X10 | 1 |
| 55 | S20412000 | RUBBER CAP, 3.7 | 1 |
| 58 | S39626021 | CLOTH GUIDE | 1 |
| 59 | 060400612 | SCREW, BIND M4X6 | 2 |
| 60 | 060400512 | SCREW, BIND M4X5 | 1 |
| 61 | S20338200 | OIL PAN | 1 |
| 62 | S20339000 | PACKING | 1 |
| 63 | S23350001 | MACHINE BODY LEG | 4 |
| 64 | 017501212 | BOLT, M5X12 | 4 |
| 65 | S23351001 | WASHER | 4 |
| 66 | S00075000 | EYE GUARD | 1 |
| 67 | 060350812 | SCREW, BIND M3.5X8 | 2 |
| 68 | 025350332 | WASHER, PLAIN L 3.5 | 2 |
| 69 | S20340001 | EYE GUARD SUPPORT PLATE | 1 |
| 70 | S20342001 | SHOULDER SCREW, M4 | 1 |
| 71 | 146598001 | WASHER, BOWL SPRING | 1 |
| 72 | 025050132 | WASHER, PLAIN S 5 | 1 |
| 74 | S20344001 | RUBBER CAP, 16 | 1 |
| 75 | S20345001 | RUBBER CAP, 14 | 1 |
| 76 | S23337001 | RUBBER CAP, 18.5 | 1 |
| 77 | 081009070 | 0 RING P9 | 1 |
| 78 | S23357001 | SCREW, M10 | 1 |
| 79 | S20346000 | OIL RESERVOIR, N-BAR | 1 |
| 80 | 062401612 | SCREW, PAN M4X16 | 1 |
| 81 | S20878000 | RUBBER CAP, 5.3 | 1 |
| 92 | S39785001 | THREADING DIAGRAM LABEL, D | 1 |
| 92 | S39786001 | THREADING DIAGRAM LABEL, E | 1 |
| 92 | S39787001 | THREADING DIAGRAM LABEL, F | 1 |
| 93 | S25184001 | THREADING DIAGRAM LABEL, DL | 1 |
| 94 | S44821001 | LABEL,CLEANING | 1 |
Page 11 — B. 駆動軸関係 / Crankshaft mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S54001001 | CRANKSHAFT, R | 1 |
| 1 | S54002001 | CRANKSHAFT,S | |
| 3 | S39629021 | BEARING CAP | 1 |
| 4 | 081031870 | O RING, S31.5 | 1 |
| 5 | 062400812 | SCREW, PAN M4X8 | 2 |
| 6 | 061400812 | SCREW, FLAT M4X8 | 1 |
| 7 | 072600000 | BALL BEARING, 6000 | 1 |
| 10 | S39630000 | BUSH, CRANKSHAFT | 1 |
| 11 | S20356001 | WASHER, PLAIN 10 | 1 |
| 12 | 155559001 | WASHER, PLAIN | 1 |
| 13 | S46900001 | SHAFT, D/C STITCH THR/TAKE-UP | 1 |
| 14 | 048400242 | RETAINING RING, INTERNAL C40 | 1 |
| 15 | 076203000 | BALL BEARING, 6203 | 1 |
| 16 | S27868001 | BALL BEARING, 6203V | 1 |
| 17 | S20361001 | SPRING, WAVE | 1 |
| 18 | S20362151 | OIL REJECTOR, CRANKSHAFT | 1 |
| 20 | S39631000 | HOLDER, BEARING | 1 |
| 21 | S20353000 | O RING | 1 |
| 22 | 062401012 | SCREW, PAN M4X10 | 3 |
| 24-1 | S39775001 | PULLEY | 1 |
| 24-2 | S39565101 | PULLEY | 1 |
| 26 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 1 |
| 25 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 1 |
| 27 | 028060242 | WASHER, SPRING 2-6 | 1 |
| 28 | 018062532 | BOLT, SOCKET M6X25 | 1 |
| 065550001 | 1 | ||
| S25081001 | 1 |
Page 13 — C. 針棒関係 / Needle bar mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S54003001 | NEEDLE D/CRANK ROD ASSY, S | 1 |
| 1 | S54006001 | NEEDLE D/CRANK ROD ASSY, H | 1 |
| 1 | S54007001 | NEEDLE D/CRANK ROD ASSY, E | 1 |
| 1-1 | 018401622 | BOLT, SOCKET M4X16 | 2 |
| 1-2 | S23342001 | SET SCREW, SOCKET (CN) M4X5 | 1 |
| 1-3-1 | 017061612 | BOLT, M6X16 | 1 |
| 1-3-2 | 118735002 | WASHER, PLAIN | 1 |
| 2 | S39644021 | BUSH, L ;NEEDLE SHAFT | 1 |
| 3 | S39645021 | BUSH, R ;NEEDLE SHAFT | 1 |
| 4 | S39646021 | NEEDLE SHAFT | 1 |
| 5 | S39647000 | WASHER | 1 |
| 6 | 146293001 | RETAINING RING, E10 | 1 |
| 7 | S39566001 | NEEDLE BAR CLAMP ASSY | 1 |
| 7-1 | S23342001 | SET SCREW, SOCKET (CN) M4X5 | 2 |
| 7-2 | S46899001 | BOLT, (W/WASHER) M6X16 | 1 |
| 7-3 | 062350812 | SCREW, PAN M3.5X8 | 1 |
| 7-4 | S20391001 | SPACER | 1 |
| 7-5 | S20392000 | FELT | 2 |
| 7-6 | 155162001 | SPACER | 1 |
| 8 | S39574001 | NEEDLE BAR | 1 |
| 9 | S39648021 | BUSH, D ;NEEDLE BAR | 1 |
| 10 | S39571021 | BUSH, U ;NEEDLE BAR | 1 |
| 11 | 104450101 | RUBBER CAP, 8 | 1 |
| 12-1 | 146427001 | SET SCREW, SOCKET (CP) SM3.18 | 2 |
| 15 | S39649021 | SUPPORT BRACKET, N-PLATE | 1 |
| 16 | 018062532 | BOLT, SOCKET M6X25 | 2 |
| 17 | S39650051 | NEEDLE PLATE SUPPORT, F | 1 |
| 18 | S39652021 | NEEDLE PLATE SUPPORT, B | 1 |
| 20 | 062401012 | SCREW, PAN M4X10 | 4 |
| 21 | S20415101 | NEEDLE GUARD, MOVABLE | 1 |
| 22 | S20416101 | BOLT, M3.5X10 | 1 |
| 23 | S20418051 | NEEDLE GUARD, F | 1 |
| 24 | S23456101 | SCREW, PAN M2.5X6 | 2 |
| 25 | S38306051 | D-CHAIN STITCH N/GUARD, F | 1 |
| 26 | 062350812 | SCREW, PAN M3.5X8 | 1 |
| 27 | S38307001 | D-CHAIN STITCH N/GUARD, B | 1 |
| 28 | 062300812 | SCREW, PAN M3X8 | 2 |
| 29 | S39654051 | NEEDLE GUARD BRACKET | 1 |
| 30 | 062401012 | SCREW, PAN M4X10 | 1 |
| 33 | 100032003 | SCREW, FLAT SM4.37-40X8 | 2 |
Page 15 — D. 針冷却関係 / Needle cooler E. 縁ガリ定規関係 / Serging attachment
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S43525001 | NEEDLE COOLER SET, S | 1 |
| 1-1 | S20468001 | FELT SUPPORT ASSY | 1 |
| 1-1-1 | S20460000 | CAP, SILICONE TANK | 1 |
| 1-2 | S23418002 | SCREW, M4X5 | 2 |
| 1-3 | 060401012 | SCREW, BIND M4X10 | 1 |
| 1-4 | S06704001 | SILICONE OIL | 1 |
| 1 | S32140001 | EDGE GUIDE ASSY | 1 |
| 1-1 | S23896101 | SETTING PLATE, ;EDGE GUIDE | 1 |
| 1-2 | S23773001 | SHOULDER SCREW, M4 | 1 |
| 1-3 | 146598001 | WASHER, BOWL SPRING | 1 |
| 1-4 | S23897001 | EDGE GUIDE SUPPORT | 1 |
| -5 | 021400212 | NUT, 2 M4 | 1 |
| 1-6 | S21341001 | STOPPER | 1 |
| 1-7 | 062300512 | SCREW, PAN M3X5 | 1 |
| 1-8 | 146600001 | EDGE GUIDE | 1 |
| 1-9 | 062350612 | SCREW, PAN M3.5X6 | 1 |
| 2 | 062401012 | SCREW, PAN M4X10 | 1 |
Page 17 — F1. 押工関係 / Presser foot mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S39658001 | ADJUSTING SCREW, PRESSER | 1 |
| 2 | S39575001 | PRESSER BAR ASSY | 1 |
| 2-1 | S39577000 | CUSHION | 1 |
| 2-2 | 047301642 | SPRING PIN AW3 | 1 |
| 3 | 105161004 | WASHER, PLAIN | 1 |
| 4 | S20476001 | PRESSER SPRING | 1 |
| 5 | S38308121 | MAIN PRESSER ARM | 1 |
| 6 | S39659021 | PRESSER BAR LIFTER | 1 |
| 7 | S39660001 | SPRING, PRESSER BAR LIFTER | 1 |
| 8 | S39661001 | SHOULDER SCREW, M4 | 1 |
| 9 | S39662001 | MAIN PRESSER ARM STOPPER | 1 |
| 10 | 060400612 | SCREW, BIND M4X6 | 1 |
| 11 | S39663121 | PRESSER FOOT LIFTER LEVER | 1 |
| 12 | S39664101 | COLLAR | 1 |
| 13 | 018062532 | BOLT, SOCKET M6X25 | 1 |
| 14 | 025060332 | WASHER, PLAIN L 6 | 1 |
| 15 | S39665001 | SPRING | 1 |
| 16 | 047502542 | PIN, SPRING ROLL AW5 | 1 |
| 17 | S39770001 | SCREW, M4 | 1 |
| 18 | 021400212 | NUT, 2 M4 | 1 |
| 19 | S20485001 | PRESSER BAR LIFTER LINK | 1 |
| 20 | S39666001 | LIFTER LEVER, ;P-BAR | 1 |
| 21 | S39667021 | LIFTER ARM ASSY, ;P-BAR | 1 |
| 21-1 | 047401442 | PIN, DOWEL ;AW4 | 1 |
| 22 | 018061632 | BOLT, SOCKET M6X16 | 1 |
| 23 | S39669101 | SPRING | 1 |
| 24 | S39670000 | BUSH, ;P-ARM SHAFT | 1 |
| 25 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 1 |
| 26 | S39671121 | PRESSER ARM SHAFT | 1 |
| 27 | 048090342 | RETAINING RING, E9 | 2 |
| 28 | S30562000 | WASHER | 1 |
| 29 | S39672001 | PIN, ;P-ARM | 1 |
| 30 | S46903001 | SET SCREW, M4X5 | 1 |
| 34 | S37070121 | FINGER GUARD, V | 1 |
| 35 | 060300412 | SCREW, BIND M3X4 | 1 |
| 38-1 | S44744001 | SPRING, TWIST | 1 |
| 38-2 | S20115001 | SPRING, TWIST | 1 |
| 38-3 | S20117001 | SPRING, TWIST | 1 |
| 38-4 | S30889001 | SPRING, TWIST | 1 |
| 39 | 060300612 | SCREW, BIND M3X6 | 1 |
| 40 | S30888001 | SUB PRESSER ARM | 1 |
| 41 | 062670712 | SCREW, PAN SM3.57-40X7 | 1 |
| 44 | S23364000 | TAPE GUIDE | 1 |
Page 19 — F2. 押工関係 / Presser foot mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 50-1 | * | PRESSER FOOT ASSY | 1 |
| 50-1-1 | S19311101 | SCREW | 1 |
| 50-1-2 | * | PRESSER FOOT, F | 1 |
| 50-1-3 | 105288001 | SCREW, SM2.38 | 1 |
| 50-1-4 | S19307001 | SCREW | 1 |
| 50-1-5 | S19308001 | NUT, 2 SM3.18-44 | 1 |
| 50-1-6 | S19309001 | SPRING, TWIST | 1 |
| 50-1-7 | 062670712 | SCREW, PAN SM3.57-40X7 | 1 |
| 50-5 | * | PRESSER FOOT ASSY | 1 |
| 50-5-1 | S19311101 | SCREW | 3 |
| 50-5-2 | * | PRESSER FOOT, F | 1 |
| 50-5-3 | 106640001 | SCREW, SM3.18 | 1 |
| 50-5-4 | 062670712 | SCREW, PAN SM3.57-40X7 | 1 |
| 50-6 | * | PRESSER FOOT ASSY | 1 |
| 50-6-1 | S19311101 | SCREW | 1 |
| 50-6-2 | * | PRESSER FOOT, F | 1 |
| 50-6-3 | 140530002 | SCREW, SM2.38 | 1 |
| 50-6-4 | S19307001 | SCREW | 1 |
| 50-6-5 | S19308001 | NUT, 2 SM3.18-44 | 1 |
| 50-6-6 | S19309001 | SPRING, TWIST | 1 |
| 50-6-7 | 062670712 | SCREW, PAN SM3.57-40X7 | 1 |
| 50-10 | * | PRESSER FOOT ASSY | 1 |
| 50-10-1 | S19311101 | SCREW | 1 |
| 50-10-2 | * | PRESSER FOOT, F | 1 |
| 50-10-3 | 105288001 | SCREW, SM2.38 | 1 |
| 50-10-4 | 025660132 | WASHER, PLAIN S 3.18 | 1 |
| 50-10-5 | 106640001 | SCREW, SM3.18 | 1 |
| 50-10-6 | 062670712 | SCREW, PAN SM3.57-40X7 | 1 |
| 50-15 | * | PRESSER FOOT ASSY | 1 |
| 50-15-1 | S19311101 | SCREW | 3 |
| 50-15-2 | * | PRESSER FOOT, F | 1 |
| 50-15-3 | 100080004 | SCREW, SM3.18-44X6.5 | 2 |
| 50-15-4 | 062670712 | SCREW, PAN SM3.57-40X7 | 1 |
| 50-16 | * | PRESSER FOOT ASSY | 1 |
| 50-16-1 | * | STITCH TONGUE | 1 |
| 50-16-2 | S19368001 | PRESSER FOOT PLATE | 1 |
| 50-16-3 | 025030132 | WASHER, PLAIN S 3 | 1 |
| 50-16-4 | 150755001 | SCREW, SM3.18 | 1 |
| 50-16-5 | S30590001 | SUPPORT SCREW | 1 |
| 50-16-6 | 500296002 | NUT | 1 |
| 50-16-7 | 047161042 | PIN, SPRING ROLL AW1.6 | 1 |
| 50-16-8 | S53955001 | SPRING, TWIST | 1 |
Page 21 — G. Feed mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S39578001 | ECCENTRIC WHEEL ASSY | 1 |
| 1-1 | 047301242 | PIN, SPRING ROLL AW3 | 2 |
| 1-2 | 047301242 | PIN, SPRING ROLL AW3 | 1 |
| 1-3 | S39585001 | SPRING, TWIST | 1 |
| 1-4 | S39586001 | SCREW, M3 | 1 |
| 2 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 2 |
| 5 | S39673020 | BALANCE WEIGHT | 1 |
| 6 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 2 |
| 8 | S39589021 | FEED ARM ASSY | 1 |
| 8-1 | 018061632 | BOLT, SOCKET M6X16 | 1 |
| 9 | S39674001 | FEED ADJUSTING SHAFT | 1 |
| 10 | S39675001 | SPRING, COMPRESSION | 1 |
| 11 | 081005070 | O RING, P5 | 1 |
| 12 | 025710232 | WASHER, PLAIN M 4.76 | 1 |
| 13 | 025710232 | WASHER, PLAIN M 4.76 | 1 |
| 14 | 048040342 | RETAINING RING, E4 | 1 |
| 15 | S39676121 | FEED SHAFT | 1 |
| 16 | S39677021 | BUSH, 11.11-17 | 1 |
| 17 | S39678021 | BUSH, L ;FEED SHAFT | 1 |
| 18 | S30562000 | WASHER | 1 |
| 19 | 048090342 | RETAINING RING, E9 | 1 |
| 20 | S39679001 | CAP | 1 |
| 21 | 081020070 | O RING, P20 | 1 |
| 22 | 060400612 | SCREW, BIND M4X6 | 3 |
| 23 | S50091001 | FEED BRACKET ASSY | 1 |
| 24 | S38312050 | SLIDE BLOCK, F-LIFTING | 1 |
| 25-1 | S44955001 | SET SCREW COLLAR | 1 |
| 25-2 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 1 |
| 26 | S39683000 | SLIDE BLOCK, F-BAR | 1 |
| 27 | S39684021 | SHAFT, ;SLIDE BLOCK | 1 |
| 28 | S39685001 | SET SCREW COLLAR | 1 |
| 29 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 1 |
| 30 | S20530001 | WASHER | 1 |
| 31 | 004350812 | SCREW, FLAT M3.5X8 | 1 |
| 32 | 012400832 | SET SCREW, SOCKET (FT) M4X8 | 1 |
| 33 | S42042021 | MAIN FEED ARM | 1 |
| 34 | 018061632 | BOLT, SOCKET M6X16 | 1 |
| 35 | S39773001 | MAIN FEED LINK ASSY | 1 |
| 36 | S39690021 | WASHER | 1 |
| 37 | S23360001 | BOLT, M5X15 | 1 |
| 38 | S02573020 | WASHER | 1 |
| 39 | S39691001 | NUT, M5 | 1 |
| 40 | S39769051 | DIF. FEED ARM LINK ASSY | 1 |
| 40-1 | 018061632 | BOLT, SOCKET M6X16 | 1 |
| 41 | S39690021 | WASHER | 1 |
| 42 | S23360001 | BOLT, M5X15 | 1 |
| 43 | S38311100 | COVER, FEED BAR GUIDE | 1 |
| 44 | S39686000 | FEED BAR GUIDE, L | 1 |
| 45 | S39687000 | FEED BAR GUIDE, R | 1 |
| 46 | S39688001 | FRAGMENT PROTECTOR PLATE | 1 |
| 47 | S20526000 | FRAGMENT PROTECTOR PLATE | 3 |
| 48-1 | S43916001 | BOLT, SOCKET M4X8 SEAL | 4 |
| 48-2 | 018400832 | BOLT, SOCKET M4X8 | 2 |
| 49 | 025040132 | WASHER, PLAIN S 4 | 2 |
| 50 | S39692021 | DIF. FEED ADJUSTING LINK | 1 |
| 51 | S20543101 | SCREW, M5 | 1 |
| 52 | S20544000 | DIFFERENTIAL LINK LEVER | 1 |
| 53 | 018061432 | BOLT, SOCKET M6X14 | 1 |
| 54 | S39593021 | DIF. FEED ADJUSTING LEVER ASSY | 1 |
| 54-1 | S39596021 | NUT, ROUND M6 | 1 |
| 55 | S20547001 | SPRING | 1 |
| S39684001 | SHAFT, SLIDE BLOCK | 1 |
Page 23 — G. 送り関係 / Feed mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 56 | 081005670 | O RING, PW5 | 1 |
| 57 | 047502542 | PIN, SPRING ROLL AW5 | 1 |
| 58 | S39693001 | DIFFERENTIAL STITCH CONTROL | 1 |
| 59 | S20548001 | COLLAR | 2 |
| 60 | 018061632 | BOLT, SOCKET M6X16 | 2 |
| 61 | S25818051 | STOPPER, ;ADJUSTING LEVER | 2 |
| 62 | 060350812 | SCREW, BIND M3.5X8 | 2 |
| 63 | 025350332 | WASHER, PLAIN L 3.5 | 2 |
| 64 | S39694021 | KNOB, SCREW | 1 |
| 65 | S39695001 | SET SCREW | 1 |
| 66 | S20560001 | WASHER, FLAT SPRING | 1 |
| 69 | S23628101 | FEED DOG SETTING BASE | 1 |
| 70 | S23621101 | BOLT, M3.5X8 | 1 |
| 75-1 | 060630712 | SCREW, BIND SM2.38-56X7 | 1 |
| 76 | S23621101 | BOLT, M3.5X8 | 1 |
| 78 | S23621101 | BOLT, M3.5X8 | 1 |
| S39694001 | KNOB, SCREW | 1 |
Page 25 — H. 上メス・下メス関係 / Knife mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S54011001 | UPPER KNIFE CRANK ROD ASSY, I | 1 |
| 1-1 | 018401622 | BOLT, SOCKET M4X16 | 2 |
| 1-2-1 | 017061612 | BOLT, M6X16 | 1 |
| 1-2-2 | 118735002 | WASHER, PLAIN | 1 |
| 1-3 | S23342001 | SET SCREW, SOCKET (CN) M4X5 | 1 |
| 1-1 | 010401001 | アナホルト4X16 | |
| 2 | S20571101 | UPPER KNIFE DIFFERENTIAL ARM | 1 |
| 3 | 155247000 | DUST SEAL | 1 |
| 4 | S39704021 | UPPER KNIFE BUSH, L | 1 |
| 5 | S39677021 | BUSH, 11.11-17 | 1 |
| 6 | S43527001 | SET SCREW COLLAR ASSY | 1 |
| 6-1 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 2 |
| 8 | S20574001 | NUT | 1 |
| 9-1 | S20589101 | UPPER KNIFE HOLDER | 1 |
| 10-1 | 062401212 | SCREW, PAN M4X12 | 1 |
| 11-1 | 025040132 | WASHER, PLAIN S 4 | 1 |
| 15-1 | 144074350 | UPPER KNIFE | 1 |
| 16-1 | S23621101 | BOLT, M3.5X8 | 1 |
| 9-2 | S20590101 | UPPER KNIFE HOLDER | 1 |
| 10-2 | 062402512 | SCREW, PAN M4X25 | 1 |
| 11-2 | 125324001 | WASHER | 1 |
| 12 | S20577001 | UPPER KNIFE PRESSER | 1 |
| 13 | S20578101 | UPPER KNIFE PRESSER PLATE | 1 |
| 14 | 025030132 | WASHER, PLAIN S 3 | 1 |
| 16-2 | 062300412 | SCREW, PAN M3X4 | 1 |
| 17 | S20591101 | LOWER KNIFE HOLDER | 1 |
| 18 | 062060812 | SCREW, PAN M6X8 | 1 |
| 19 | S39707001 | LOWER KNIFE HOLDER GUIDE | 1 |
| 21 | 062060812 | SCREW, PAN M6X8 | 2 |
| 25 | S39708001 | LOWER KNIFE PRESSER | 1 |
| 26 | 017500812 | BOLT, M5X8 | 1 |
| 27 | S20585001 | SPRING, COMPRESSION | 1 |
| 28 | S39709021 | SPRING HOLDER | 1 |
| 29 | 060400812 | SCREW, BIND M4X8 | 1 |
| 15-2 | S20896101 | ANGLE KNIFE, NARROW | 1 |
| 15-3 | S20897101 | ANGLE KNIFE, NARROW WAVE EDGE | 1 |
| 15-4 | S20579101 | ANGLE KNIFE, WIDE | 1 |
| 15-5 | S20898101 | ANGLE KNIFE, WIDE WAVE EDGE | 1 |
| 15-6 | S30890000 | UPPER KNIFE | 1 |
Page 27 — J. ラッパー関係 / Lapper mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 4 | S29824000 | LAPPER ASSY, 8............ | 1 |
| 4 | S29827000 | LAPPER ASSY, 10.......... | 1 |
| 5 | S29835001 | LAPPER GUIDE PLATE | 1 |
| 6 | S23418002 | SCREW, M4X5 | 1 |
| 7 | S29831000 | LAPPER GUIDE ASSY | 1 |
| 8 | 060400612 | SCREW, BIND M4X6 | 1 |
Page 29 — K. 上ルーバー関係 / Over looper mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S54012001 | OVER LOOPER CON. ROD ASSY, S | 1 |
| 1-1 | 018401622 | BOLT, SOCKET M4X16 | 4 |
| 1-2 | S23346101 | BOLT, SOCKET M6X14 | 1 |
| 1 | S54015001 | OVER LOOPER CON. ROD ASSY, HE | 1 |
| 1-1 | 018401622 | BOLT, SOCKET M4X16 | 4 |
| 1-2 | S23346101 | BOLT, SOCKET M6X14 | 1 |
| 2 | S20598000 | ROD STOPPER | 2 |
| 3 | S39728021 | BUSH, 11.11-18 | 1 |
| 4 | S39677021 | BUSH, 11.11-17 | 1 |
| 5 | S20601001 | OVER LOOPER SHAFT | 1 |
| 6 | S43527001 | SET SCREW COLLAR ASSY | 1 |
| 6-1 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 2 |
| 7 | S23626001 | WASHER | 1 |
| 8 | 017060812 | BOLT, M6X8 | 1 |
| 9 | S52053001 | OVER LOOPER SET, SH | 1 |
| 9-1 | S52054001 | OVER LOOPER ASSY | 1 |
| 9-2 | S52060001 | OVER LOOPER ARM ASSY, SH | 1 |
| 13 | S46903001 | SET SCREW, M4X5 | 1 |
| 9 | S52062001 | OVER LOOPER SET, E | 1 |
| 9-1 | S52054001 | OVER LOOPER ASSY | 1 |
| 9-2 | S52063001 | OVER LOOPER | 1 |
| 13 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 1 |
| 9-2-1 | S46899001 | BOLT, (W/WASHER) M6X16 | 1 |
| 9-2-2 | 155162001 | SPACER | 1 |
| 9-3 | S29700000 | FELT | 2 |
| 9-4 | S23342001 | SET SCREW, SOCKET (CN) M4X5 | 1 |
| 9-5 | S52059001 | OVER LOOPER GUIDE SUPPORT | 1 |
| 9-6 | S20355002 | SCREW, M3X8.5 | 2 |
| 10 | 018061432 | BOLT, SOCKET M6X14 | 2 |
| 11 | 155247000 | DUST SEAL | 1 |
| 12 | * | OVER LOOPER | 1 |
| 14 | 118550001 | PIN, DOWEL | 1 |
Page 31 — L. 下ルーバー関係 / Under looper mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S54018001 | U/LOOPER CON. ROD ASSY, ISH | 1 |
| 1-1 | 018401622 | BOLT, SOCKET M4X16 | 4 |
| 1 | S54019001 | U/LOOPER CON. ROD ASSY, IE | 1 |
| 1-1 | 018401622 | BOLT, SOCKET M4X16 | 4 |
| 2 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 2 |
| 3 | S20598000 | ROD STOPPER | 2 |
| 5 | S46904001 | UNDER LOOPER SHAFT | 1 |
| 6 | S23626001 | WASHER | 1 |
| 7 | 017060812 | BOLT, M6X8 | 1 |
| 8 | S39728021 | BUSH, 11.11-18 | 1 |
| 9 | S39677021 | BUSH, 11.11-17 | 1 |
| 10 | 155247000 | DUST SEAL | 1 |
| 11 | S20625151 | UNDER LOOPER HOLDER | 1 |
| 12 | S23614101 | BOLT, M5X14 | 1 |
| 13 | 148782001 | SPACER | 1 |
| 14-1 | S20626001 | UNDER LOOPER | 1 |
| 15 | 060351012 | SCREW, BIND M3.5X10 | 1 |
| 14-2 | S20627001 | UNDER LOOPER | 1 |
Page 33 — M. 二重環ルーパ関係 / Double chain stitch looper mechanism
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S39729021 | LONGITUDINAL FEED ROD ASSY | 1 |
| 3 | S39732021 | LONGITUDINAL FEED ARM | 1 |
| 4 | S39733001 | SET SCREW COLLAR | 1 |
| 5 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 2 |
| 6 | S29102001 | LONGITUDINAL FEED ROD BUSH | 1 |
| 7 | S39734021 | LONGITUDINAL FEED SCREW | 1 |
| 8 | S39690021 | WASHER | 1 |
| 9 | 021500216 | NUT, 2 M5 | 1 |
| 10 | S39735050 | LONGITUDINAL FEED SLIDE BLOCK | 1 |
| 11 | S20641001 | SHOULDER SCREW 5 | 1 |
| 12 | S31881101 | SLIDE BLOCK HOLDER | 1 |
| 12-1 | 018061432 | BOLT, SOCKET M6X14 | 1 |
| 12-2 | 155162001 | SPACER | 1 |
| 14 | S44935101 | D-CHAIN STITCH LOOPER LEVER | 1 |
| 14-1 | 018061432 | BOLT, SOCKET M6X14 | 1 |
| 14-2 | 155162001 | SPACER | 1 |
| 15 | S44937101 | D-CHAIN STITCH LOOPER LINK | 1 |
| 16 | S44939001 | SHAFT | 1 |
| 17 | 062300612 | SCREW, PAN M3X6 | 1 |
| 18 | S23360001 | BOLT, M5X15 | 1 |
| 19 | S57922001 | WASHER | 1 |
| 20 | S39740021 | LONGITUDINAL FEED SHAFT | 1 |
| 21 | S39741021 | LONGITUDINAL FEED SHAFT BUSH,F | 1 |
| 22 | S39742021 | LONGITUDINAL FEED SHAFT BUSH, B | 1 |
| 23 | 155261000 | DUST SEAL | 1 |
| 24 | S20652001 | D-CHAIN STITCH LOOPER HOLDER | 1 |
| 25 | S23614101 | BOLT, M5X14 | 1 |
| 26 | 148782001 | SPACER | 1 |
| 27 | S20653001 | D-CHAIN STITCH LOOPER | 1 |
| 28 | 060350812 | SCREW, BIND M3.5X8 | 1 |
| 29 | S20654001 | WASHER | 1 |
| 30 | S23456101 | SCREW, PAN M2.5X6 | 1 |
| S39740001 | 1 |
Page 35 — N. 給油潤滑関係 / Lubrication
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S20655101 | WORM | 1 |
| 2 | 012500532 | SET SCREW, SOCKET (FT) M5X5 | 2 |
| 3 | S39743001 | COLLAR | 1 |
| 4 | S39597001 | PUMP ASSY | 1 |
| 4-1 | S20657001 | WORM WHEEL | 1 |
| 4-2 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 2 |
| 4-3 | S39599001 | PUMP INNER ROTER ASSY | 1 |
| 4-4 | S39598000 | PUMP CASE | 1 |
| 4-5 | S39601000 | PUMP BODY COVER | 1 |
| 4-6 | 062400812 | SCREW, PAN M4X8 | 3 |
| 4-7 | S39602000 | OIL FILTER | 1 |
| 4-8 | S39603001 | OIL FILTER FLANGE | 1 |
| 4-9 | 062401212 | SCREW, PAN M4X12 | 1 |
| 6 | 018061432 | BOLT, SOCKET M6X14 | 2 |
| 7 | S39744021 | OIL PIPE JOINT | 1 |
| 8 | S39745001 | OIL TUBE ASSY | 1 |
| 8-1 | 147942001 | STOP RING | 2 |
| 9 | S20199001 | OIL PIPE JOINT | 1 |
| 10 | S39747001 | OIL TUBE ASSY | 1 |
| 10-1 | 147942001 | STOP RING | 2 |
| 11 | S39751021 | OIL PIPE | 1 |
| 12 | S39744021 | OIL PIPE JOINT | 1 |
| 13 | S39749001 | OIL PIPE ASSY | 1 |
| 13-1 | 147942001 | STOP RING | 2 |
| 14 | S20199001 | OIL PIPE JOINT | 2 |
| 15 | S39752021 | OIL PIPE | 1 |
| 16 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 1 |
| 17 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 1 |
| 18 | 148084001 | OIL GAUGE WINDOW | 1 |
| 19 | S20668200 | FELT, ;N-BAR LINK | 1 |
| 20 | 061400812 | SCREW, FLAT M4X8 | 1 |
| 21 | S49337000 | WICK, L=70 | 1 |
| 22 | S20671000 | WICK, L=100 | 1 |
| 23 | S20669000 | FELT | 1 |
| 24 | 060400812 | SCREW, BIND M4X8 | 1 |
| 25 | S20392000 | FELT | 1 |
| 29 | S43523000 | FILTER ASSY | 1 |
| 29-1 | S43521000 | FILTER, D | 1 |
| 29-2 | S43522000 | OIL FILTER | 1 |
Page 37 — P. 糸調子関係 / Thread tension
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S38328051 | MAIN THREAD GUIDE | 1 |
| 9 | S20676051 | TENSION STUD | 4 |
| 10 | S20677000 | FELT, T-DISC | 4 |
| 11 | S20673001 | TENSION DISC | 8 |
| 12 | 110832009 | FELT, ;T-DISC | 4 |
| 13 | 144103009 | DISC PRESSER, ;TENSION | 4 |
| 14 | S20678001 | TENSION SPRING, L | 1 |
| 15 | S32276001 | TENSION SPRING, LL | 1 |
| 16 | S20679001 | TENSION SPRING, M | 1 |
| 17 | S20679001 | TENSION SPRING, M | 1 |
| 18 | S20681000 | WASHER | 4 |
| 19-1 | S20682103 | TENSION NUT, RED | 1 |
| 19-2 | S20682101 | TENSION NUT, LIGHT BLUE | 1 |
| 19-3 | S20682104 | TENSION NUT, YELLOW | 1 |
| 19-4 | S20682102 | TENSION NUT, GREEN | 1 |
| 21 | 146592001 | THREAD GUIDE PIPE | 2 |
| 22 | S23452002 | SET SCREW, SOCKET (FT) M4X3.2 | 2 |
| 23 | S20684101 | THREAD GUIDE BRACKET | 1 |
| 24 | 060400612 | SCREW, BIND M4X6 | 2 |
| 25 | S20685001 | UNDER LOOPER THREAD GUIDE, R | 1 |
| 26 | S20686001 | OVER LOOPER THREAD GUIDE, R | 1 |
| 27 | S23418002 | SCREW, M4X5 | 2 |
| 28 | S21133001 | OVER LOOPER THREAD TAKE-UP, R | 1 |
| 29 | S21134001 | UNDER LOOPER THREAD TAKE-UP,R | 1 |
| 30 | 060300412 | SCREW, BIND M3X4 | 1 |
| 31 | S21135001 | LOOPER THREAD TAKE-UP, L | 1 |
| 32 | 060400612 | SCREW, BIND M4X6 | 2 |
| 33 | S21137001 | LOOPER THREAD GUIDE, M1 | 1 |
| 35 | S21136101 | OVER LOOPER THREAD GUIDE, L | 1 |
| 36 | 060400612 | SCREW, BIND M4X6 | 1 |
| 37 | S20687001 | UNDER LOOPER THREAD GUIDE, L | 1 |
| 38 | S38329001 | NEEDLE THREAD GUIDE, C | 1 |
| 39 | 060400612 | SCREW, BIND M4X6 | 1 |
| 40-1 | S21126001 | NEEDLE THREAD GUIDE, B | 1 |
| 41 | 060400612 | SCREW, BIND M4X6 | 1 |
| 42 | S21130051 | NEEDLE THREAD TAKE-UP, A | 1 |
| 43 | 060400612 | SCREW, BIND M4X6 | 2 |
| 44-1 | S21125001 | NEEDLE THREAD GUIDE, A | 1 |
| 45 | 060400612 | SCREW, BIND M4X6 | 1 |
| 46 | S38330050 | NEEDLE THREAD PRESSER HOLDER | 1 |
| 47 | 146427001 | SET SCREW, SOCKET (CP) SM3.18 | 2 |
| 48 | S20689001 | NEEDLE THREAD PRESSER COLLAR | 1 |
| 49 | S20690001 | SPRING, COMPRESSION | 1 |
| 50 | S20691001 | NEEDLE THREAD PRESSER PLATE | 1 |
| 51 | S20743001 | NEEDLE THREAD GUIDE | 1 |
| 52 | 060300612 | SCREW, BIND M3X6 | 1 |
| 53 | S20694001 | CHAIN STITCH THREAD GUIDE, B | 1 |
| 54 | 060400612 | SCREW, BIND M4X6 | 1 |
| 55 | S20695001 | THREAD GUIDE PIPE | 1 |
| 56 | S20696001 | PIPE SUPPORT, ;TR-GUIDE | 1 |
| 57 | 060400612 | SCREW, BIND M4X6 | 1 |
| 58 | S20697001 | LOOPER THREAD GUIDE | 1 |
| 59 | S20698121 | TENSION STUD | 1 |
| 60 | 144504001 | DISC, THREAD GUIDE | 2 |
| 61 | 158782151 | PRE-TENSION SPRING | 1 |
| 62 | 155510001 | TENSION NUT | 1 |
| 63 | S39756021 | THREAD HANDLER BRACKET | 1 |
| 64 | 028050242 | WASHER, SPRING 2-5 | 1 |
| 65 | S20342001 | SHOULDER SCREW, M4 | 1 |
| 66 | S20701001 | THREAD HANDLER | 1 |
| 67 | S39757001 | COLLAR | 1 |
| 10832009 | 4 | ||
| 060400412 | バインド M3X4 | 1 |
Page 39 — P. 糸調子関係 / Thread tension
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 68 | 060401412 | SCREW, BIND M4X14 | 1 |
| 69 | 150813001 | SPRING | 1 |
| 70 | 062350612 | SCREW, PAN M3.5X6 | 1 |
| 71 | S20702001 | THREAD TAKE-UP GUIDE | 2 |
| 72 | S20158101 | SCREW, PAN M2.5X3 | 2 |
| 73 | S20703051 | THREAD TAKE-UP LEVER ASSY, DL | 1 |
| 74 | S23452002 | SET SCREW, SOCKET (FT) M4X3.2 | 2 |
| 75 | S20707001 | THREAD GUIDE, A ;DL | 1 |
| 76 | 060400612 | SCREW, BIND M4X6 | 1 |
| 8 | S20675001 | TENSION DISC THREAD GUIDE | 1 |
| 9 | S20676051 | TENSION STUD | 5 |
| 10 | S20677000 | FELT, T-DISC | 5 |
| 11 | S20673001 | TENSION DISC | 10 |
| 12 | 110832009 | FELT, ;T-DISC | 5 |
| 13 | 144103009 | DISC PRESSER, ;TENSION | 5 |
| 14 | S20678001 | TENSION SPRING, L | 2 |
| 18 | S20681000 | WASHER | 5 |
| 19-5 | S20682103 | TENSION NUT, RED | 2 |
| 40-2 | S21129001 | NEEDLE THREAD GUIDE, B | 1 |
| 44-2 | S21128001 | NEEDLE THREAD GUIDE, A | 1 |
Page 41 — Q1. ラフラー装置関係 / Ruffling attachment
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S30304001 | RUFFLER ASSY | 1 |
| 1-1 | S21293001 | RUFFLER DEVICE SET | 1 |
| 1-1-1 | S21294001 | RUFFLING BLADE BRACKET | 1 |
| 1-1-2 | S21295001 | RUFFLING BLADE BASE SHAFT | 1 |
| 1-1-3 | S21305001 | SPRING BASE | 1 |
| 1-1-4 | S23777101 | SET SCREW, M6 | 2 |
| 1-1-5 | S20676051 | TENSION STUD | 1 |
| 1-1-6 | S23775001 | SPRING, COIL | 1 |
| 1-1-7 | S20681000 | WASHER | 1 |
| 1-1-8 | S20682105 | TENSION NUT | 1 |
| 1-1-9 | S21296001 | RUFFLING BLADE | 1 |
| 1-1-10 | 144784001 | WASHER | 1 |
| 1-1-11 | 062300812 | SCREW, PAN M3X8 | 2 |
| 1-1-12 | S21297001 | RUFFLER BASE | 1 |
| 1-1-13 | S21306001 | SHOULDER SCREW, M6 | 1 |
| 1-1-14 | S21307001 | WASHER, SPRING | 2 |
| 1-1-15 | S21298001 | RUFFLING BLADE GUIDE | 1 |
| 1-1-16 | 062400812 | SCREW, PAN M4X8 | 1 |
| 1-1-17 | S21299001 | CLOTH PRESSER BAR LIFTER | 1 |
| 1-1-18 | S23651002 | SET SCREW, SOCKET (FT) M6X5 | 2 |
| 1-1-19 | S21300001 | HANDLE SETTING PLATE | 1 |
| 1-1-20 | 021060302 | NUT, 3 M6 | 1 |
| 1-1-21 | 062401612 | SCREW, PAN M4X16 | 1 |
| 1-1-22 | 021400212 | NUT, 2 M4 | 1 |
| 1-1-23 | S21301001 | SPRING, TWIST | 1 |
| 1-1-24 | S21302001 | SPRING, PLATE (U) | 1 |
| 1-1-25 | 062400612 | SCREW, PAN M4X6 | 1 |
| 1-1-26 | S21303001 | SPRING, PLATE (D) | 1 |
| 1-1-27 | 062350512 | SCREW, PAN M3.5X5 | 2 |
| 1-1-28 | S21304001 | COLLAR | 1 |
| 1-2 | 018401222 | BOLT, SOCKET M4X12 | 2 |
| 1-4 | S21590000 | RUFFLER GUIDE | 1 |
| 1-5 | S23418002 | SCREW, M4X5 | 2 |
| 1-6 | S23779001 | HANDLE | 1 |
| 1-7 | 021060302 | NUT, 3 M6 | 1 |
| 1-8 | 102707002 | WASHER, PLAIN 4 | 1 |
| 2 | S43530001 | RUFFLER INTERLOCKING PARTS SET | 1 |
| 2-1 | S21310001 | CLOTH PRESSER BAR LIFTER LEVER | 1 |
| 2-2 | S21311001 | PRESSER BAR LIFTER BRACKET | 1 |
| 2-3 | S21312001 | PIN, 6.35 | 1 |
| 2-4 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 1 |
| 2-5 | 062350812 | SCREW, PAN M3.5X8 | 2 |
| 2-6 | S39795001 | WIRE SETTING PLATE | 1 |
| 2-7 | S21314001 | FLEXIBLE WIRE ASSY | 1 |
| 2-8 | S23774001 | SHOULDER SCREW, M3.5 | 1 |
| 2-9 | S21315001 | STUD, M4 | 1 |
| 2-10 | 021400432 | NUT, 2 M4 | 1 |
| 2-11 | S21316001 | WIRE STOPPER | 1 |
| 2-12 | 012400432 | SET SCREW, SOCKET (FT) M4X4 | 1 |
| 2-13 | S23349001 | LEVER ADJUSTING PLATE | 1 |
| 2-14 | 060400812 | SCREW, BIND M4X8 | 2 |
| 2-15 | S39796001 | SPACER | 1 |
| 2-16 | 060400812 | SCREW, BIND M4X8 | 1 |
| 2-17 | 011502012 | SET SCREW, (FT) M5X20 | 2 |
| 2-18 | 021500312 | NUT, 3 M5 | 2 |
| 062060632 | アナヒラ6X6 | 1 |
Page 43 — Q2. ラフラー装置関係 / Ruffing attachment
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 3-1 | S30135101 | DIFFERENTIAL ADJUSTING SET | 1 |
| 3-1-1 | S21373101 | DIFFERENTIAL FEED ADJUSTER | 1 |
| 3-1-1-1 | 155197101 | KNEE LIFTER SHAFT BRACKET | 1 |
| 3-1-1-2 | S21375001 | KNEE LIFTER SHAFT | 1 |
| 3-1-1-3 | 155199101 | BRACKET, KNEE LIFTER | 1 |
| 3-1-1-4 | 017781412 | BOLT, SM6.35X14 | 2 |
| 3-1-1-5 | 148797001 | KNEE LIFTER BAR, S | 1 |
| 3-1-1-6 | 014780622 | SET SCREW, SOCKET (CP) SM6.35 | 1 |
| 3-1-1-7 | 148798109 | KNEE LIFTER PLATE, L | 1 |
| 3-1-1-8 | 017081606 | BOLT, M8X16 | 1 |
| 3-1-1-9 | S21376001 | KNEE LIFTER LEVER | 1 |
| 3-1-1-10 | 017781412 | BOLT, SM6.35X14 | 2 |
| 3-1-1-11 | S21377001 | SPRING, TWIST | 1 |
| 3-1-1-12 | S21378001 | COLLAR | 2 |
| 3-1-1-13 | 017781412 | BOLT, SM6.35X14 | 4 |
| 3-1-2 | S21379001 | CONNECTING BAR | 1 |
| 3-1-3 | 021400202 | NUT, 2 M4 | 2 |
| 3-1-4 | 062401012 | SCREW, PAN M4X10 | 4 |
| 3-2 | S30135102 | DIF.ADJUSTING SET, FULL | 1 |
| 3-2-1 | S21380101 | DIFFERENTIAL FEED ADJUSTER | 1 |
| 3-2-1-1 | 155197101 | KNEE LIFTER SHAFT BRACKET | 1 |
| 3-2-1-2 | S21375001 | KNEE LIFTER SHAFT | 1 |
| 3-2-1-3 | 155199101 | BRACKET, KNEE LIFTER | 1 |
| 3-2-1-4 | 017781412 | BOLT, SM6.35X14 | 2 |
| 3-2-1-5 | 148797001 | KNEE LIFTER BAR, S | 1 |
| 3-2-1-6 | 014780622 | SET SCREW, SOCKET (CP) SM6.35 | 1 |
| 3-2-1-7 | 148798109 | KNEE LIFTER PLATE, L | 1 |
| 3-2-1-8 | 017081606 | BOLT, M8X16 | 1 |
| 3-2-1-9 | S21376001 | KNEE LIFTER LEVER | 1 |
| 3-2-1-10 | 017781412 | BOLT, SM6.35X14 | 2 |
| 3-2-1-11 | S21377001 | SPRING, TWIST | 1 |
| 3-2-1-12 | S21378001 | COLLAR | 2 |
| 3-2-1-13 | 017781412 | BOLT, SM6.35X14 | 4 |
| 3-2-2 | S21381001 | CONNECTING BAR | 1 |
| 3-2-3 | 021400202 | NUT, 2 M4 | 2 |
| 3-2-4 | 062401012 | SCREW, PAN M4X10 | 4 |
Page 45 — Q3. ラフラー装置関係 / Ruffling attachment
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | S43539001 | ラフラーシュウセット/Ruffler set | 1 |
| 1 | S30304001 | ラフラークミ/Ruffler assy | 1 |
| 1 | S43539004 | ラフラーシュウセット/Ruffler set | 1 |
| 1 | S43540004 | P.ラフラーシュウセット/Piping ruffler set | 1 |
| 2 | S43530001 | ラフラーオサエレンドウクミ/Riffling device set | 2 |
| 3 | S30135101 | サドウチョウセツト/Differential adjusting set | 3 |
| 4 | S30303001 | PIPING PARTS ASSY | 1 |
| 4-1 | 143767102 | TAPE WINDER ASSY | 1 |
| 4-1-1 | 143980001 | SCREW | 1 |
| 4-1-2 | 108494001 | WASHER | 1 |
| 4-1-3 | 108495001 | SPRING, COMPRESSION | 1 |
| 4-1-4 | 100136001 | NUT, TENSION | 1 |
| 4-2 | 101118001 | WOOD SCREW, ROUND M4.5X20 | 2 |
| 4-3 | S21318000 | LAPPER ASSY | 1 |
| 4-4 | 062400812 | SCREW, PAN M4X8 | 2 |
| 4-5 | 025040232 | WASHER, PLAIN M 4 | 2 |
| 4-6 | S20130009 | COTTON STAND ASSY, W/SCREW | 1 |
| 4-6-1 | S20131009 | COTTON STAND ASSY | 1 |
| 4-6-1-1 | S20134001 | SCREW, W4.76-24X10 | 1 |
| 4-6-1-2 | S20135001 | SPOOL PIN | 1 |
| 4-6-2 | 034422006 | WOOD SCREW, FLAT 2 M4.1X20 | 2 |
| 4-8 | S25019001 | LAPPER BASE | 1 |
| 4-9 | S23651002 | SET SCREW, SOCKET (FT) M6X5 | 2 |
| 5 | S30297004 | RUFFLER GAUGE ASSY | 1 |
| 5 | S30297004 | PIPING RUFFLER GAUGE ASSY | 1 |
| 5-1 | * | NEEDLE CLAMP ASSY | 1 |
| 5-2 | * | NEEDLE PLATE | 1 |
| 5-3 | * | PRESSER FOOT ASSY | 1 |
| 5-4 | * | MAIN FEED DOG ASSY | 1 |
| 5-5 | * | DIFFERENTIAL FEED DOG | 1 |
| 5 | S30296001 | ラフラーゲージクミ/Ruffler gauge assy | 5 |
| 5 | S30296004 | ラフラーゲージクミ/Ruffler gauge assy | 5 |
Page 47 — Z1. 付属部品関係 / Accessories
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | * | NEEDLE ASSY | 2 |
| 1-1 | * | NEEDLE | 8 |
| 4 | * | LOWER KNIFE, T=1.5 | 1 |
| 5 | 101572101 | SCREW DRIVER, 5.5X190 | 1 |
| 7 | S01943001 | SCREW DRIVER, HEX. 1.6 | 1 |
| 8 | 142002001 | HEXAGONAL WRENCH, 2 | 1 |
| 9 | 149570001 | HEXAGONAL WRENCH, 5 | 1 |
| 10 | S23356001 | DOUBLE WRENCH, 8X10 | 1 |
| 11 | S46907001 | WRENCH, 5X6 | 1 |
| 12 | S20723001 | DOUBLE WRENCH, 8 | 1 |
| 13 | 117466000 | PINCETTE | 1 |
| 14 | S24473000 | THREADER | 1 |
| 18 | S06701000 | POLY OILER ASSY | 1 |
| 19 | S55666002 | OIL TANK ASSY, B | 1 |
| 24 | 142262001 | CHAIN ASSY, F | 1 |
| 25 | 122991001 | ACCESSORY BAG | 1 |
| 27 | S20718000 | HEAD PLATE | 1 |
| 29 | S35997001 | BOLT, M8X85 | 4 |
| 31 | 213650001 | WASHER, 2.3X8.5X38ST | 4 |
| 32 | 028080242 | WASHER, SPRING 2-8 | 4 |
| 33 | 021080106 | NUT, 1 M8 | 4 |
| 40 | S20769000 | FUNNEL | 1 |
| 41 | 144225002 | HEAD COVER | 1 |
| 48-1 | 147919051 | RUBBER CUSHION | 1 |
| 48-2 | 147919052 | RUBBER CUSHION | 3 |
| 56 | 183797009 | DUSTER CHUTE ASSY | 1 |
| 57 | 031411304 | WOOD SCREW, ROUND M4.1X13 | 3 |
| 58 | S23353001 | DUSTER SHOOT SUPPORT, S | 1 |
| 59 | 062400612 | SCREW, PAN M4X6 | 2 |
| 60 | 025040332 | WASHER, PLAIN L 4 | 2 |
| 65 | S38302020 | BELT COVER | 1 |
| 66 | 062061412 | SCREW, PAN M6X14 | 3 |
| 67 | S20412000 | RUBBER CAP, 3.7 | 1 |
| 91 | S20118151 | TRIMMING KNIFE | 1 |
| 92 | 060300512 | SCREW, BIND M3X5 | 1 |
| 69 | 147893009 | TREADLE PEDAL | 1 |
| 70 | 021400106 | NUT, 1 M4 | 2 |
| 71 | 062401406 | SCREW, PAN M4X14 | 2 |
| 72 | 116016001 | PEDAL STOPPER | 2 |
Page 49 — Z2. 付属部品関係 / Accessories
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 42 | S45953001 | COTTON STAND ASSY, 5DTHF | 1 |
| 42-1 | 150172023 | COLUMN PIPE | 1 |
| 42-2 | S36064021 | COLUMN PIPE, D | 1 |
| 42-3 | 150206022 | WASHER, PLAIN 16 | 1 |
| 42-4 | S36062021 | NUT, M16 | 1 |
| 42-5 | S35635020 | COLUMN CAP | 2 |
| 42-6 | 150173023 | COLUMN JOINT | 1 |
| 42-7 | S35826021 | SCREW, PAN M5X14 | 2 |
| 42-8 | S35827021 | NUT, 1 M5 | 2 |
| 42-9 | S02778022 | SPOOL HOLDER, 2 | 1 |
| 42-10 | S45970001 | THREAD HANGER ASSY, 2 | 1 |
| 42-10-1 | S35832021 | SCREW, PAN (S/P WASHER) M5X14 | 1 |
| 42-10-2 | S35827021 | NUT, 1 M5 | 1 |
| 42-11 | S02779009 | SPOOL HOLDER, 3 | 1 |
| 42-12 | S35831021 | SCREW, PAN (S/P WASHER) M5X30 | 1 |
| 42-13 | S35827021 | NUT, 1 M5 | 1 |
| 42-14 | S45964001 | THREAD HANGER ASSY, 3 | 1 |
| 42-14-1 | S35832021 | SCREW, PAN (S/P WASHER) M5X14 | 1 |
| 42-14-2 | S35827021 | NUT, 1 M5 | 1 |
| 42-15 | 150179022 | SPOOL SHAFT, B | 2 |
| 42-16 | 028050246 | WASHER, SPRING 2-5 | 2 |
| 42-17 | S35827021 | NUT, 1 M5 | 2 |
| 42-18 | 126863021 | SPOOL CUSHION | 2 |
| 42-19 | 150180021 | SPOOL STAND BASE | 2 |
| 42-20 | 150182020 | SPOOL MAT | 2 |
| 42-21 | 150185009 | THREAD GUIDE HOLDER | 1 |
| 42-22 | S35831021 | SCREW, PAN (S/P WASHER) M5X30 | 1 |
| 42-23 | S35827021 | NUT, 1 M5 | 1 |
| 42-24 | S04109001 | SUPPORT BAR, ;TR-GUIDE JOINT | 1 |
| 42-25 | S45961001 | JOINT | 1 |
| 42-26 | 012060632 | SET SCREW, SOCKET (FT) M6X6 | 2 |
| 42-27 | 142999101 | THREAD GUIDE, 5 | 1 |
| 42-28 | 150188009 | SPOOL HOLDER SUPPORT, A | 1 |
| 42-29 | S35826021 | SCREW, PAN M5X14 | 1 |
| 42-30 | S35827021 | NUT, 1 M5 | 1 |
| 42-31 | 031452206 | WOOD SCREW, ROUND M4.5X22 | 1 |
| 42 | S45954001 | COTTON STAND ASSY, 6DTHF | 1 |
| 42-27 | S02783001 | THREAD GUIDE, 6 | 1 |
| 42-32 | 150194009 | SPOOL HOLDER SUPPORT, B | 1 |
| 64-1 | 183798001 | FULL SUBMERGED SET | 1 |
| 64-1 | S20721001 | HEAD PLATE SUPPORT | 1 |
| 64-2 | 153318201 | BOLT | 4 |
| 64-3 | S35997001 | BOLT, M8X85 | 1 |
| 64-4 | S36007001 | BOLT, M8X55 | 1 |
| 64-5 | 017085502 | BOLT, M8X55 | 1 |
| 64-6 | 025080236 | WASHER, PLAIN M 8 | 11 |
| 64-7 | 028080242 | WASHER, SPRING 2-8 | 7 |
| 64-8 | 021080106 | NUT, 1 M8 | 15 |
| 64-9 | 213650001 | WASHER, 2.3X8.5X38ST | 8 |
| 64-10 | S20722001 | DUSTER SHOOT SUPPORT, L | 1 |
| 64-11 | 060400812 | SCREW, BIND M4X8 | 2 |
| 64-12 | 060400812 | SCREW, BIND M4X8 | 3 |
| S02778009 | SPOOL HOLDER, 3 | 1 | |
| 150182009 | SPOOL MAT | 2 |
Page 50 — Ga1. ゲージ部品一覧表 / Gauge parts List
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 151474-011 | Needle (Q'ty 2) | 2 |
| 1 | 151474-014 | Needle (Q'ty 2) | 2 |
| 2 | S19304-101 | Presser Foot Assy | |
| 2 | S19313-201 | Presser Foot Assy | |
| 2 | S25557-001 | Presser Foot Assy | |
| 2 | S25548-101 | Presser Foot Assy | |
| 2 | S19317-101 | (S19312-001) | |
| 2 | S19334-001 | (S19340-001) | |
| 3 | S29146-001 | Needle Clamp Assy | |
| 3 | S20404-001 | Needle Clamp Assy | |
| 3 | S20406-001 | Needle Clamp Assy | |
| 3 | S29631-001 | Needle Clamp Assy | |
| 3 | S21104-001 | Needle Clamp Assy | |
| 3 | S29146-001 | Needle Clamp Assy | |
| 3 針止メ組 Needle Clamp Assy | S25195-001 | ||
| 3 針止メ組 Needle Clamp Assy | S19174-001 | ||
| 3 針止メ組 Needle Clamp Assy | S19175-001 | ||
| 3 針止メ組 Needle Clamp Assy | S20235-001 | ||
| 3 針止メ組 Needle Clamp Assy | S20236-001 | ||
| 3 針止メ組 Needle Clamp Assy | S35651-001 | ||
| 3 針止メ組 Needle Clamp Assy | S27968-001 | ||
| 3 針止メ組 Needle Clamp Assy | S20232-001 | ||
| 3 針止メ組 Needle Clamp Assy | S20233-001 | ||
| 3 針止メ組 Needle Clamp Assy | S25197-001 | ||
| 3 針止メ組 Needle Clamp Assy | S25201-001 | ||
| 4 | S25194-001 | Needle Plate | 2 |
| 4 | S20234-001 | Needle Plate | 3 |
| 4 | S20231-001 | Needle Plate | 4 |
| 4 | S25200-001 | Needle Plate | 3 |
| 4 | S19185-001 | Needle Plate | 5 |
| 4 | S25198-001 | Needle Plate | 4 |
| 4 針板 Needle Plate | S19186-001 | ||
| 4 針板 Needle Plate | S19187-001 | ||
| 4 針板 Needle Plate | S25199-001 | ||
| 5 | S19221-201 | Main Feed Dog Assy | |
| 5 | S20241-101 | Main Feed Dog Assy | |
| 5 | S20239-101 | Main Feed Dog Assy | |
| 5 | S19228-101 | Main Feed Dog Assy | |
| 5 | S19224-201 | Main Feed Dog Assy | |
| 6 | S19245-001 | Differential Feed Dog | |
| 6 | S20245-001 | Differential Feed Dog | |
| 6 | S20244-001 | Differential Feed Dog | |
| 6 | S25566-001 | Differential Feed Dog | |
| 6 | S19247-001 | Differential Feed Dog | |
| 6 | S19246-001 | Differential Feed Dog | |
| 7 | 144074-350 | Upper knife | |
| 7 | S20898-101 | Angle knife | |
| 7 上メス Upper Knife | 角メス Angle knife S20898-101 | 7 上メス Upper Knife | |
| 7 上メス Upper Knife | 上メス Upper knife 144074-350 | 7 上メス Upper Knife | |
| 8 | S20899-001 | Lower Knife (T=1.0) | |
| 8 | S20582-001 | Lower Knife (T=1.5) | |
| 8 | S20899-001 | Lower Knife (T=1.0) | |
| 8 | S20582-001 | Lower Knife (T=1.5) | |
| 8 | S20582-001 | Lower Knife (T=1.5) | |
| 8 | S20583-001 | Lower Knife (T=1.5) | |
| 8 | S20582-001 | Lower Knife (T=1.5) | |
| 9 | S20421-001 | Over Looper | |
| 9 | S20423-001 | Over Looper | |
| 9 | S20423-001 | Over Looper | |
| 9 | S20429-001 | Over Looper | |
| 9 | S20423-001 | Over Looper | |
| 4010-22-S2F | -23-S2F -24-S2F -25-S2F | 2 | |
| 4020-33-S3F | -34-S3F -35-S3F -36-H3F -37-H3F | 3 | |
| 4030-54-S2F | -55-S2F -56-H3F -57-H3F | 5 | |
| 4050-55-E3W | -56-E3W -57-E3W | 3 | |
| 4420-24-S3F | -25-S3F | 2 | |
| 151474-016 | 151474-016 (2) | ||
| 151474-018 | 151474-018 (2) |
Page 51 — Ga2 . ゲージ部品一覧表 / Gauge parts List
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 151474-014 | Needle ( Q'ty 2 ) | 2 | |
| 151474-016 | Needle ( Q'ty 2 ) | 2 | |
| 2 | S19321-101 | Presser Foot Assy | |
| 2 | S19326-101 | Presser Foot Assy | |
| 2 | S19330-201 | Presser Foot Assy | |
| 2 | S20882-201 | Presser Foot Assy | |
| 2 | S25550-001 | Presser Foot Assy | |
| 4420-34-S3F-3S-S3F | Sub-Class | ||
| 4430-55-S3F-56-H3F | Sub-Class | ||
| 4520-34-S3F-35-S3F | Sub-Class | ||
| 4530-54-S3F-55-S3F-56-H3F | Sub-Class | ||
| 4620-35-H3F | Sub-Class | ||
| 151474-014 (2) | Needle (Q'ty) | ||
| 151474-016 (2) | Needle (Q'ty) | ||
| S19321-101 (S19325-001) | Presser Foot Assy | ||
| S19326-101 (S19325-001) | Presser Foot Assy | ||
| S19330-201 (S30971-001) | Presser Foot Assy | ||
| S20882-201 (S30971-001) | Presser Foot Assy | ||
| S25550-001 (S25553-001) | Presser Foot Assy | ||
| S20404-001 | Presser Foot F | ||
| S20406-001 | Presser Foot F | ||
| S19497-001 (4) S19182-001 (5) | Needle Clamp Assy | ||
| S19183-001 (5) S19184-001 (6) | Needle Clamp Assy | ||
| S20235-001 (4) S20236-001 (5) | Needle Clamp Assy | ||
| S20231-001 (4) S20232-001 (5) S20233-001 (6) | Needle Clamp Assy | ||
| S19182-001 (5) | Needle Clamp Assy | ||
| S19224-201 (S19225-201) (S33172-001) L | Main Feed Dog Assy | ||
| S19226-101 (5) (S19227-101) (S19223-101) F | Main Feed Dog Assy | ||
| S19224-201 (6) (S19225-201) (S33172-101) L | Main Feed Dog Assy | ||
| S20241-101 (S20242-101) (S20243-101) H | Main Feed Dog Assy | ||
| S20239-101 (S20240-101) (S19223-101) F | Main Feed Dog Assy | ||
| S19246-001 | Differential Feed Dog | ||
| S20245-001 | Differential Feed Dog | ||
| S20244-001 | Differential Feed Dog | ||
| 144074-350 | Upper Knife | ||
| S20582-001 (T=1.5) | Lower Knife | ||
| S20423-001 M | Over Looper | ||
| S20423-001 (4, 5) M S20421-001 (6) L | Over Looper |
Page 52 — Ga3 . ゲージ 部品 一覧表 / Gauge parts List
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2 | S25553-001 | Presser Foot Assy | |
| 2 | S19312-001 | Presser Foot Assy | |
| 2 | S19312-001 | Presser Foot Assy | |
| 2 | S30586-101 | Presser Foot Assy | |
| 3 | S20406-001 | Needle Clamp Assy | |
| 3 | S20404-001 | Needle Clamp Assy | |
| 3 | S29146-001 | Needle Clamp Assy | |
| 4 | S19184-001 | Needle Plate | 5 / 6 |
| 4 | S25203-001 | Needle Plate | 4 / 5 |
| 4 | S25194-001 | Needle Plate | 2 |
| 5 | S19227-101 | Main Feed Dog Assy | 5 |
| 5 | S19225-201 | Main Feed Dog Assy | 6 |
| 5 | S19222-201 | Main Feed Dog Assy | |
| 6 | S19246-001 | Differential Feed Dog | |
| 6 | S19245-001 | Differential Feed Dog | |
| 7 | 144074-350 | Upper Knife | |
| 8 | S20582-001 | Lower Knife | |
| 8 | S20899-001 | Lower Knife | |
| 9 | S20423-001 | Over Looper | |
| 9 | S20422-001 | Over Looper | |
| 4630-55-S3F | Sub-Class | ||
| 4720-34-S2F | Sub-Class | ||
| 5010-22-S2F | Sub-Class | ||
| 5011-22-S2F | Sub-Class | ||
| 151474-014 | Needle (Q'ty) | 2 | |
| 151474-011 | Needle (Q'ty) | 2 | |
| S25195-001 | Needle Plate | ||
| S19174-001 | Needle Plate | ||
| S19175-001 | Needle Plate |
Page 53 — Ga4. ゲージ部品一覧表 / Gauge parts List
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 5 Threads | 5020-33-S2F | -34-S3F -35-S2F | 5 |
| 5 Threads | 5021-33-S2F | -34-S2F -35-S2F | 5 |
| 5 Threads | 5030-54-S3F | -55-S3F -56-H3F -57-H3F | 5 |
| 5 Threads | 5033-54-H3A | -55-H3A -56-H3A -57-H3A | 5 |
| 5 Threads | 5050-33-E2W | -35-E2W | 5 |
| S19313-201 | Presser Foot Assy | ||
| S20404-001 | Needle Clamp Assy | ||
| S20234-001 | Needle Plate | ||
| S20241-101 | Main Feed Dog Assy | ||
| S20245-001 | Differential Feed Dog | ||
| 144074-350 | Upper Knife | ||
| S20899-001 | Lower Knife | ||
| S20424-001 | Over Looper | ||
| 151474-014 (2) | Needle (Qty.) | 3 | |
| 151474-016 (2) | Needle (Qty.) | 3 | |
| 151474-018 (2) | Needle (Qty.) | 3 | |
| S30594-101 (3, 4) | ツメ Stitch Tongue S30588-001 S30597-101 (5, 6) ツメ Stitch Tongue S30593-001 | ||
| S19317-101 | Presser Foot Assy | ||
| S25557-001 | Presser Foot Assy | ||
| S20406-001 | Needle Clamp Assy | ||
| S21104-001 | Needle Clamp Assy | ||
| S29631-001 | Needle Clamp Assy | ||
| S20234-001 (3) | 4 針板 Needle Plate | ||
| S19176-001 (3) | Needle Plate | ||
| S20231-001 (4) | Needle Plate | ||
| S25200-001 (3) | Needle Plate | ||
| S19221-201 | Main Feed Dog Assy | ||
| S20239-101 | Main Feed Dog Assy | ||
| S35840-001 | Main Feed Dog Assy | ||
| S19228-101 | Main Feed Dog Assy | ||
| S19245-001 | Differential Feed Dog | ||
| S20244-001 | Differential Feed Dog | ||
| S35992-001 | Differential Feed Dog | ||
| S25566-001 | Differential Feed Dog | ||
| S20896-101 | 角メス Angle knife | ||
| S20898-101 | 角メス Angle knife | ||
| S20582-001 (T=1.5) | Lower Knife | ||
| S20583-001 (T=1.5) | Lower Knife | ||
| S20424-001 (3,4,5) | 9 上ルーパ Over Looper | ||
| S20428-001 (6,7) | Over Looper | ||
| S20424-001 (4,5) | Over Looper | ||
| S20428-001 | Over Looper |
Page 54 — Ga5 . ゲージ部品一覧表 / Gauge parts List
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 151474-018 | Needle | |
| 5050-55-E3W | Sub-Class (Extra Heavy, 5 Threads) | ||
| 4050-55-E3W | Sub-Class (For Vertical Pocket) | ||
| 5420-24-S3F | Sub-Class (Ruffling, 5 Threads) | ||
| 5420-34-S3F | Sub-Class (Ruffling, 5 Threads) | ||
| 1 | 151474-014 | Needle | 2 |
| 1 | 151474-014 | Needle | 2 |
| 2 | S19334-001 | Presser Foot Assy | |
| 2 | S30525-001 | Presser Foot Assy | |
| 2 | S25548-101 | Presser Foot Assy | |
| 2 | S19321-101 | Presser Foot Assy | |
| 3 | S21104-001 | Needle Clamp Assy | |
| 3 | S29146-001 | Needle Clamp Assy | |
| 3 | S20404-001 | Needle Clamp Assy | |
| 4 | S19185-001 | Needle Plate | 5 |
| 4 | S25198-001 | Needle Plate | 4 |
| 4 | S19497-001 | Needle Plate | 4 |
| 5 | S19228-101 | Main Feed Dog Assy | |
| 5 | S38595-001 | Main Feed Dog Assy | |
| 5 | S19224-201 | Main Feed Dog Assy | |
| 6 | S19247-001 | Differential Feed Dog | |
| 6 | S19246-001 | Differential Feed Dog | |
| 6 | S38597-001 | Differential Feed Dog (Option, Wet suit) | |
| 7 | S20898-101 | Angle Knife | |
| 7 | 144074-350 | Upper Knife | |
| 8 | S20583-001 | Lower Knife | |
| 8 | S20582-001 | Lower Knife | |
| 9 | S20438-101 | Over Looper | |
| 9 | S20424-001 | Over Looper | |
| S19186-001 | Needle Plate | ||
| S19187-001 | Needle Plate | ||
| S25199-001 | Needle Plate | ||
| S19182-001 | Needle Plate |
Page 55 — Ga6 . ゲージ部品一覧表 / Gauge parts List
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 151474-014 (2) | Needle | |
| 1 | 151474-016 (2) | Needle | |
| 1 | 151474-014 (2) | Needle | |
| 1 | 5430-55-S3F-56-H3F | Sub-Class | 5 |
| 1 | 5520-34-S3F-35-S3F | Sub-Class | 3 |
| 1 | 5530-54-S3F-55-S3F-56-H3F | Sub-Class | 3 |
| 1 | 5620-35-S3F | Sub-Class | 3 |
| 2 | S19326-101 (S19325-001) | Presser Foot Assy | |
| 2 | S19330-201 (S30971-001) | Presser Foot Assy | |
| 2 | S20882-201 (S30971-001) | Presser Foot Assy | |
| 2 | S25550-001 (S25553-001) | Presser Foot Assy | |
| 3 | S20406-001 | Needle Clamp Assy | |
| 3 | S20404-001 | Needle Clamp Assy | |
| 3 | S20406-001 | Needle Clamp Assy | |
| 3 | S20404-001 | Needle Clamp Assy | |
| 4 | S19183-001 (5) | Needle Plate | 5 |
| 4 | S19184-001 (6) | Needle Plate | 6 |
| 4 | S20235-001 (4) | Needle Plate | 4 |
| 4 | S20236-001 (4) | Needle Plate | 5 |
| 4 | S19183-001 | Needle Plate | 4 |
| 4 | S20232-001 (5) | Needle Plate | 5 |
| 4 | S20233-001 (6) | Needle Plate | 6 |
| 4 | S19182-001 (5) | Needle Plate | 5 |
| 5 | S19226-101 (5) | Main Feed Dog Assy | 5 |
| 5 | S19224-201 (6) | Main Feed Dog Assy | 6 |
| 5 | S20241-101 | Main Feed Dog Assy | |
| 5 | S20239-101 | Main Feed Dog Assy | |
| 5 | S19223-101 | Main Feed Dog Assy | |
| 5 | S19227-101 | Main Feed Dog Assy | |
| 5 | S19225-201 | Main Feed Dog Assy | |
| 5 | S20242-101 | Main Feed Dog Assy | |
| 5 | S20243-101 | Main Feed Dog Assy | |
| 5 | S20236-101 | Main Feed Dog Assy | |
| 6 | S19246-001 | Differential Feed Dog | |
| 6 | S20245-001 | Differential Feed Dog | |
| 6 | S20244-001 | Differential Feed Dog | |
| 6 | S19246-001 | Differential Feed Dog | |
| 7 | 144074-350 | Upper Knife | |
| 8 | S20582-001 (T=1.5) | Lower Knife | |
| 9 | S20424-001 (5) | Over Looper | 5 |
| 9 | S20424-001 | Over Looper | |
| 9 | S20424-001 (4, 5) | Over Looper | 4, 5 |
| 9 | S20424-001 | Over Looper | |
| 9 | S20424-001 (6) | Over Looper |
Page 56 — Ga7. ゲージ部品一覧表 / Gauge parts List
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2 | S25555-001 | Presser Foot Assy | |
| 2 | S25560-101 | Presser Foot Assy | |
| 2 | S25562-101 | Presser Foot Assy | |
| 2 | S31981-001 | Presser Foot Assy | |
| 3 | S20406-001 | Needle Clamp Assy | |
| 3 | S20404-001 | Needle Clamp Assy | |
| 3 | S29148-001 | Needle Clamp Assy | |
| 3 | S29148-001 | Needle Clamp Assy | |
| 4 | S19183-001 | Needle Plate | 5 / 6 |
| 4 | S25202-001 | Needle Plate | 4 / 5 |
| 4 | S25204-001 | Needle Plate | |
| 4 | S31975-001 | Needle Plate | |
| 4 | S31979-001 | Needle Plate | |
| 5 | S19226-101 | Main Feed Dog Assy | 5 |
| 5 | S19224-201 | Main Feed Dog Assy | 6 |
| 5 | S19221-201 | Main Feed Dog Assy | |
| 5 | S19221-201 | Main Feed Dog Assy | |
| 5 | S20239-101 | Main Feed Dog Assy | |
| 5 | S19226-101 | Main Feed Dog Assy | |
| 6 | S19246-001 | Differential Feed Dog | |
| 6 | S19245-001 | Differential Feed Dog | |
| 6 | S19245-001 | Differential Feed Dog | |
| 6 | S20244-001 | Differential Feed Dog | |
| 6 | S19246-001 | Differential Feed Dog | |
| 7 | 144074-350 | Upper knife / Angle knife | |
| 8 | S20582-001 | Lower Knife | |
| 9 | S20424-001 | Over Looper | 5 / 6 |
| 5630-55-S3F | 56-H3F | ||
| 5720-34-S2F | -35-S2F | ||
| 6030-B5-H2F | 6030-B5-H3F | ||
| 6430-B5-H3A | 6430-B5-H3A | ||
| 151474-014 | 2 | ||
| 151474-016 | 3 | ||
| (S33172-001) | L | ||
| (S19223-101) | F | ||
| S20430-001 | D |
Page 57 — Wa. 警告ラベル / Warning labels
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| S38350-001 | |||
| S38349-001 | Label, operation Eng. | ||
| S37060-001 | Mark, grounding |
Page 58 — INDEX
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 31 | 004350812 | G | |
| 2-17 | 011502012 | Q1 | |
| 43 | 012060632 | A | |
| 26 | 012060632 | B | |
| 25 | 012060632 | B | |
| 25 | 012060632 | F1 | |
| 2 | 012060632 | G | |
| 6 | 012060632 | G | |
| 25-2 | 012060632 | G | |
| 6-1 | 012060632 | H | |
| 6-1 | 012060632 | K | |
| 2 | 012060632 | L | |
| 17 | 012060632 | N | |
| 2-4 | 012060632 | Q1 | |
| 42-26 | 012060632 | Z2 | |
| 27-4 | 012400432 | A | |
| 32 | 012400432 | A | |
| 29 | 012400432 | G | |
| 13 | 012400432 | K | |
| 5 | 012400432 | M | |
| 4-2 | 012400432 | N | |
| 16 | 012400432 | N | |
| 2-12 | 012400432 | Q1 | |
| 31 | 012400832 | A | |
| 32 | 012400832 | G | |
| 2 | 012500532 | N | |
| 3-1-1-6 | 014780622 | Q2 | |
| 3-2-1-6 | 014780622 | Q2 | |
| 8 | 017060812 | K | |
| 7 | 017060812 | L | |
| 1-3-1 | 017061612 | C | |
| 1-2-1 | 017061612 | H | |
| 3-1-1-8 | 017081606 | Q2 | |
| 3-2-1-8 | 017081606 | Q2 | |
| 64-5 | 017085502 | Z2 | |
| 26 | 017500812 | H | |
| 64 | 017501212 | A | |
| 3-1-1-4 | 017781412 | Q2 | |
| 3-1-1-10 | 017781412 | Q2 | |
| 3-1-1-13 | 017781412 | Q2 | |
| 3-2-1-4 | 017781412 | Q2 | |
| 3-2-1-10 | 017781412 | Q2 | |
| 3-2-1-13 | 017781412 | Q2 | |
| 53 | 018061432 | G | |
| 10 | 018061432 | K | |
| 12-1 | 018061432 | M | |
| 14-1 | 018061432 | M | |
| 6 | 018061432 | N | |
| 22 | 018061632 | F1 | |
| 8-1 | 018061632 | G | |
| 34 | 018061632 | G | |
| 40-1 | 018061632 | G | |
| 60 | 018061632 | G | |
| 28 | 018062532 | B | |
| 16 | 018062532 | C | |
| 13 | 018062532 | F1 | |
| 20 | 018400832 | A | |
| 48-2 | 018400832 | G | |
| 1-2 | 018401222 | Q1 | |
| 1-1 | 018401622 | C | |
| 1-1 | 018401622 | H | |
| 1-1 | 018401622 | K | |
| 1-1 | 018401622 | L | |
| 1-1-20 | 021060302 | Q1 | |
| 1-7 | 021060302 | Q1 | |
| 33 | 021080106 | Z1 | |
| 64-8 | 021080106 | Z2 | |
| 70 | 021400106 | Z1 | |
| 3-1-3 | 021400202 | Q2 | |
| 3-2-3 | 021400202 | Q2 | |
| 53 | 021400212 | A | |
| 1-5 | 021400212 | E | |
| 18 | 021400212 | F1 | |
| 1-1-22 | 021400212 | Q1 | |
| 2-10 | 021400432 | Q1 | |
| 9 | 021500216 | M | |
| 2-18 | 021500312 | Q1 | |
| 50-16-3 | 025030132 | F2 | |
| 14 | 025030132 | H | |
| 49 | 025040132 | G | |
| 11-1 | 025040132 | H | |
| 4-5 | 025040232 | Q3 | |
| 60 | 025040332 | Z1 | |
| 72 | 025050132 | A | |
| 14 | 025060332 | F1 | |
| 64-6 | 025080236 | Z2 | |
| 68 | 025350332 | A | |
| 63 | 025350332 | G | |
| 50-10-4 | 025660132 | F2 | |
| 12 | 025710232 | G | |
| 13 | 025710232 | G | |
| 64 | 028050242 | P | |
| 42-16 | 028050246 | Z2 | |
| 27 | 028060242 | B | |
| 32 | 028080242 | Z1 | |
| 64-7 | 028080242 | Z2 | |
| 57 | 031411304 | Z1 | |
| 42-31 | 031452206 | Z2 | |
| 4-6-2 | 034422006 | Q3 | |
| 50-16-7 | 047161042 | F2 | |
| 1-1 | 047301242 | G | |
| 1-2 | 047301242 | G | |
| 2-2 | 047401642 | F1 | |
| 21-1 | 047401442 | F1 | |
| 16 | 047502542 | F1 | |
| 57 | 047502542 | G | |
| 54 | 047602042 | A | |
| 14 | 048040342 | G | |
| 27 | 048090342 | F1 | |
| 19 | 048090342 | G | |
| 14 | 048400242 | B | |
| 46 | 060400612 | A | |
| 50 | 060400612 | A | |
| 59 | 060400612 | A | |
| 10 | 060400612 | F1 | |
| 22 | 060400612 | G | |
| 8 | 060400612 | J | |
| 24 | 060400612 | P | |
| 32 | 060400612 | P | |
| 36 | 060400612 | P | |
| 39 | 060400612 | P | |
| 41 | 060400612 | P | |
| 43 | 060400612 | P | |
| 15 | 060400812 | A | |
| 22-1 | 060400812 | A | |
| 29 | 060400812 | H | |
| 24 | 060400812 | N | |
| 2-14 | 060400812 | Q1 | |
| 2-16 | 060400812 | Q1 | |
| 64-11 | 060400812 | Z2 | |
| 64-12 | 060400812 | Z2 | |
| 25-1 | 060401012 | A | |
| 1-3 | 060401012 | D | |
| 28 | 060401412 | A | |
| 68 | 060401412 | P | |
| 75-1 | 060630712 | G | |
| 26 | 061400812 | A | |
| 6 | 062060812 | B | |
| 20 | 062060812 | N | |
| 18 | 062060812 | H | |
| 21 | 062060812 | H | |
| 66 | 062061412 | Z1 | |
| 16-2 | 062300412 | H | |
| 1-7 | 062300512 | E | |
| 17 | 062300612 | M | |
| 28 | 062300812 | C | |
| 1-11 | 062300812 | Q1 | |
| 1-27 | 062350512 | Q1 | |
| 1-9 | 062350612 | E | |
| 70 | 062350612 | P | |
| 7-3 | 062350812 | C | |
| 26 | 062350812 | C | |
| 2-5 | 062350812 | Q1 | |
| 30 | 062400612 | A | |
| 1-1-25 | 062400612 | Q1 | |
| 59 | 062400612 | Z1 | |
| 9 | 062400812 | A | |
| 5 | 062400812 | B | |
| 4-6 | 062400812 | N | |
| 1-1-16 | 062400812 | Q1 | |
| 4-4 | 062400812 | Q3 | |
| 4 | 062401012 | A | |
| 22 | 062401012 | B | |
| 20 | 062401012 | C | |
| 30 | 062401012 | C | |
| 2 | 062401012 | E | |
| 3-1-4 | 062401012 | Q2 | |
| 3-2-4 | 062401012 | Q2 | |
| 52 | 062401212 | A | |
| 10-1 | 062401212 | H | |
| 35 | 060300412 | F1 | |
| 30 | 060300412 | P | |
| 92 | 060300512 | Z1 | |
| 39 | 060300612 | F1 | |
| 52 | 060300612 | P | |
| 67 | 060350812 | A | |
| 62 | 060350812 | G | |
| 28 | 060350812 | M | |
| 15 | 060351012 | L | |
| 60 | 060400512 | A | |
| 12 | 060400612 | A | |
| 27-7 | 060400612 | A | |
| 27-9 | 060400612 | A | |
| 34 | 060400612 | A | |
| 36 | 060400612 | A |
Page 59
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 4-9 | 062401212 | N | |
| 71 | 062401406 | Z1 | |
| 80 | 062401612 | A | |
| 1-1-21 | 062401612 | Q1 | |
| 10-2 | 062402512 | H | |
| 41 | 062670712 | F1 | |
| 50-1-7 | 062670712 | F2 | |
| 50-5-4 | 062670712 | F2 | |
| 50-6-7 | 062670712 | F2 | |
| 50-10-6 | 062670712 | F2 | |
| 50-15-4 | 062670712 | F2 | |
| 15 | 072600000 | B | |
| 15 | 076203000 | B | |
| 11 | 081005070 | G | |
| 56 | 081005670 | G | |
| 77 | 081009070 | A | |
| 6 | 081014670 | A | |
| 21 | 081020070 | G | |
| 4 | 081031870 | B | |
| 40 | 100032003 | A | |
| 33 | 100032003 | C | |
| 50-15-3 | 100080004 | F2 | |
| 4-1-4 | 100136001 | Q3 | |
| 41 | 100315002 | A | |
| 4-2 | 101118001 | Q3 | |
| 5 | 101572101 | Z1 | |
| 1-8 | 102707002 | Q1 | |
| 11 | 104450101 | C | |
| 3 | 105161004 | F1 | |
| 50-1-3 | 105288001 | F2 | |
| 50-10-3 | 106640001 | F2 | |
| 50-5-3 | 106640001 | F2 | |
| 50-10-5 | 106640001 | F2 | |
| 4-1-2 | 108494001 | Q3 | |
| 4-1-3 | 108495001 | Q3 | |
| 12 | 110832009 | P | |
| 12 | 110832009 | P | |
| 72 | 116016001 | Z1 | |
| 13 | 117466000 | Z1 | |
| 14 | 118550001 | K | |
| 1-3-2 | 18735002 | C | |
| 1-2-2 | 18735002 | H | |
| 25 | 122991001 | Z1 | |
| 11-2 | 125324001 | H | |
| 42-18 | 126863021 | Z2 | |
| 50-6-3 | 140530002 | F2 | |
| 39 | 141183000 | A | |
| 8 | 142002001 | Z1 | |
| 24 | 142262001 | Z1 | |
| 42-27 | 142999101 | Z2 | |
| 4-1 | 143767102 | Q3 | |
| 4-1-1 | 143980001 | Q3 | |
| 7 | 144074350 | Ga1 | |
| 7 | 144074350 | Ga2 | |
| 7 | 144074350 | Ga3 | |
| 7 | 144074350 | Ga4 | |
| 7 | 144074350 | Ga5 | |
| 7 | 144074350 | Ga6 | |
| 15-1 | 144103009 | H | |
| 13 | 144103009 | P | |
| 13 | 144103009 | P | |
| 41 | 144225002 | Z1 | |
| 60 | 144504001 | P | |
| 1-1-10 | 144784001 | Q1 | |
| 6 | 146293001 | C | |
| 12-1 | 146427001 | C | |
| 47 | 146427001 | P | |
| 21 | 146592001 | P | |
| 71 | 146598001 | A | |
| 1-3 | 146598001 | E | |
| 1-8 | 146600001 | E | |
| 69 | 147893009 | Z1 | |
| 48-1 | 147919051 | Z1 | |
| 48-2 | 147919052 | Z1 | |
| 8-1 | 147942001 | N | |
| 10-1 | 147942001 | N | |
| 13-1 | 147942001 | N | |
| 18 | 148084001 | N | |
| 13 | 148782001 | L | |
| 26 | 148782001 | M | |
| 3-1-1-5 | 148797001 | Q2 | |
| 3-2-1-5 | 148797001 | Q2 | |
| 3-1-1-7 | 148798109 | Q2 | |
| 3-2-1-7 | 148798109 | Q2 | |
| 9 | 149570001 | Z1 | |
| 42-1 | 150172023 | Z2 | |
| 42-6 | 150173023 | Z2 | |
| 42-15 | 150179022 | Z2 | |
| 42-19 | 150180021 | Z2 | |
| 42-20 | 150182020 | Z2 | |
| 42-21 | 150185009 | Z2 | |
| 42-28 | 150188009 | Z2 | |
| 42-32 | 150194009 | Z2 | |
| 42-3 | 150206022 | Z2 | |
| 50-16-4 | 150755001 | F2 | |
| 69 | 150813001 | P | |
| 1 | 151474011 | Ga1 | |
| 1 | 151474014 | Ga1 | |
| 1 | 151474016 | Ga1 | |
| 1 | 151474018 | Ga1 | |
| 64-2 | 153318201 | Z2 | |
| 7-6 | 155162001 | C | |
| 9-2-2 | 155162001 | K | |
| 12-2 | 155162001 | M | |
| 14-2 | 155162001 | M | |
| 3-1-1-1 | 155197101 | Q2 | |
| 3-2-1-1 | 155197101 | Q2 | |
| 3-1-1-3 | 155199101 | Q2 | |
| 3-2-1-3 | 155199101 | Q2 | |
| 3 | 155247000 | K | |
| 10 | 155247000 | K | |
| 10 | 155247000 | K | |
| 23 | 155261000 | M | |
| 62 | 155510001 | P | |
| 12 | 15559001 | B | |
| 51 | 156482000 | A | |
| 61 | 158782151 | P | |
| 56 | 183797009 | Z1 | |
| 64-1 | 183798001 | Z2 | |
| 31 | 213650001 | Z1 | |
| 64-9 | 213650001 | Z2 | |
| 50-16-6 | 500296002 | F2 | |
| 66 | S00075000 | A | |
| 7 | S01943001 | Z1 | |
| 38 | S02573020 | G | |
| 3 | S02606020 | A | |
| 42-9 | S02778022 | Z2 | |
| 42-11 | S02779009 | Z2 | |
| 42-27 | S02783001 | Z2 | |
| 42-24 | S04109001 | Z2 | |
| 18 | S06701000 | Z1 | |
| 1-4 | S06704001 | D | |
| 4 | S19174001 | Ga1 | |
| 4 | S19174001 | Ga3 | |
| 4 | S19175001 | Ga1 | |
| 4 | S19175001 | Ga3 | |
| 4 | S19177001 | Ga4 | |
| 4 | S19178001 | Ga4 | |
| 4 | S19182001 | Ga2 | |
| 4 | S19182001 | Ga5 | |
| 4 | S19183001 | Ga2 | |
| 4 | S19183001 | Ga3 | |
| 4 | S19183001 | Ga6 | |
| 4 | S19184001 | Ga2 | |
| 4 | S19184001 | Ga3 | |
| 4 | S19184001 | Ga6 | |
| 4 | S19185001 | Ga1 | |
| 4 | S19185001 | Ga5 | |
| 4 | S19186001 | Ga1 | |
| 4 | S19186001 | Ga5 | |
| 4 | S19187001 | Ga1 | |
| 4 | S19187001 | Ga5 | |
| 5 | S19221201 | Ga1 | |
| 5 | S19221201 | Ga3 | |
| 5 | S19221201 | Ga4 | |
| 5 | S19221201 | Ga7 | |
| 5 | S19222201 | Ga1 | |
| 5 | S19222201 | Ga3 | |
| 5 | S19222201 | Ga4 | |
| 5 | S19222201 | Ga7 | |
| 5 | S19223101 | Ga1 | |
| 5 | S19223101 | Ga2 | |
| 5 | S19223101 | Ga3 | |
| 5 | S19223101 | Ga4 | |
| 5 | S19223101 | Ga5 | |
| 5 | S19223101 | Ga6 | |
| 5 | S19223101 | Ga7 | |
| 5 | S19224201 | Ga1 | |
| 5 | S19224201 | Ga2 | |
| 5 | S19224201 | Ga3 | |
| 5 | S19224201 | Ga5 | |
| 5 | S19224201 | Ga6 | |
| 5 | S19225201 | Ga1 | |
| 5 | S19225201 | Ga2 | |
| 5 | S19225201 | Ga2 | |
| 5 | S19225201 | Ga3 | |
| 5 | S19225201 | Ga5 | |
| 5 | S19225201 | Ga6 | |
| 5 | S19226101 | Ga2 | |
| 5 | S19226101 | Ga3 | |
| 5 | S19226101 | Ga6 | |
| 5 | S19226101 | Ga7 | |
| 5 | S19227101 | Ga2 | |
| 5 | S19227101 | Ga3 | |
| 5 | S19227101 | Ga6 | |
| 5 | S19227101 | Ga7 | |
| 5 | S19228101 | Ga1 |
Page 60 — INDEX
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| S19228101 | Ga4 5 | ||
| S19228101 | Ga5 5 | ||
| S19229001 | Ga1 5 | ||
| S19229001 | Ga4 5 | ||
| S19229001 | Ga5 5 | ||
| S19245001 | Ga1 6 | ||
| S19245001 | Ga3 6 | ||
| S19245001 | Ga4 6 | ||
| S19245001 | Ga7 6 | ||
| S19246001 | Ga1 6 | ||
| S19246001 | Ga2 6 | ||
| S19246001 | Ga3 6 | ||
| S19246001 | Ga5 6 | ||
| S19246001 | Ga6 6 | ||
| S19247001 | Ga1 6 | ||
| S19247001 | Ga5 6 | ||
| S19304101 | Ga1 2 | ||
| S19304101 | Ga3 2 | ||
| S19307001 | F2 50-1-4 | ||
| S19307001 | F2 50-1-4 | ||
| S19308001 | F2 50-6-4 | ||
| S19308001 | F2 50-1-5 | ||
| S19309001 | F2 50-1-6 | ||
| S19309001 | F2 50-6-6 | ||
| S19311101 | F2 50-1-1 | ||
| S19311101 | F2 50-5-1 | ||
| S19311101 | F2 50-6-1 | ||
| S19311101 | F2 50-10-1 | ||
| S19311101 | F2 50-15-1 | ||
| S19312001 | Ga1 2 | ||
| S19312001 | Ga3 2 | ||
| S19312001 | Ga4 2 | ||
| S19312001 | Ga7 2 | ||
| S19313201 | Ga1 2 | ||
| S19313201 | Ga4 2 | ||
| S19317101 | Ga1 2 | ||
| S19317101 | Ga4 2 | ||
| S19321101 | Ga1 2 | ||
| S19321101 | Ga2 2 | ||
| S19325001 | Ga1 2 | ||
| S19325001 | Ga2 2 | ||
| S19325001 | Ga5 2 | ||
| S19325001 | Ga6 2 | ||
| S19325001 | Ga7 2 | ||
| S19326101 | Ga2 2 | ||
| S19326101 | Ga6 2 | ||
| S19330201 | Ga2 2 | ||
| S19330201 | Ga6 2 | ||
| S19334001 | Ga1 2 | ||
| S19334001 | Ga4 2 | ||
| S19334001 | Ga5 2 | ||
| S19340001 | Ga1 2 | ||
| S19340001 | Ga4 2 | ||
| S19340001 | Ga5 2 | ||
| S19368001 | F2 50-16-2 | ||
| S19497001 | Ga2 4 | ||
| S19497001 | Ga5 4 | ||
| S20115001 | F1 38-2 | ||
| S20117001 | F1 38-3 | ||
| S20118151 | Z1 91 | ||
| S20130009 | Q3 4-6 | ||
| S20131009 | Q3 4-6-1 | ||
| S20134001 | Q3 4-6-1-1 | ||
| S20135001 | Q3 4-6-1-2 | ||
| S20158101 | P 72 | ||
| S20199001 | N 9 | ||
| S20199001 | N 14 | ||
| S20231001 | Ga1 4 | ||
| S20231001 | Ga2 4 | ||
| S20231001 | Ga4 4 | ||
| S20231001 | Ga6 4 | ||
| S20232001 | Ga1 4 | ||
| S20232001 | Ga2 4 | ||
| S20232001 | Ga4 4 | ||
| S20232001 | Ga6 4 | ||
| S20233001 | Ga2 4 | ||
| S20233001 | Ga4 4 | ||
| S20233001 | Ga6 4 | ||
| S20234001 | Ga1 4 | ||
| S20234001 | Ga2 4 | ||
| S20234001 | Ga4 4 | ||
| S20234001 | Ga6 4 | ||
| S20235001 | Ga1 4 | ||
| S20235001 | Ga2 4 | ||
| S20235001 | Ga4 4 | ||
| S20235001 | Ga6 4 | ||
| S20236001 | Ga1 4 | ||
| S20236001 | Ga2 4 | ||
| S20236001 | Ga4 4 | ||
| S20236001 | Ga6 4 | ||
| S20239101 | Ga1 5 | ||
| S20239101 | Ga2 5 | ||
| S20239101 | Ga4 5 | ||
| S20239101 | Ga6 5 | ||
| S20239101 | Ga7 5 | ||
| S20240101 | Ga1 5 | ||
| S20240101 | Ga2 5 | ||
| S20240101 | Ga4 5 | ||
| S20240101 | Ga6 5 | ||
| S20241101 | Ga1 5 | ||
| S20241101 | Ga2 5 | ||
| S20241101 | Ga4 5 | ||
| S20241101 | Ga6 5 | ||
| S20242101 | Ga1 5 | ||
| S20242101 | Ga2 5 | ||
| S20242101 | Ga4 5 | ||
| S20242101 | Ga6 5 | ||
| S20243101 | Ga1 5 | ||
| S20243101 | Ga2 5 | ||
| S20243101 | Ga4 5 | ||
| S20243101 | Ga6 5 | ||
| S20244001 | Ga1 6 | ||
| S20244001 | Ga2 6 | ||
| S20244001 | Ga4 6 | ||
| S20244001 | Ga6 6 | ||
| S20245001 | Ga1 6 | ||
| S20245001 | Ga2 6 | ||
| S20245001 | Ga4 6 | ||
| S20245001 | Ga6 6 | ||
| S20310001 | A 13 | ||
| S20311000 | A 14 | ||
| S20319001 | A 27-3 | ||
| S20320101 | A 27-5 | ||
| S20321001 | A 27-6 | ||
| S20324101 | A 33 | ||
| S20325001 | A 35 | ||
| S20327101 | A 27-8 | ||
| S20338200 | A 61 | ||
| S20339000 | A 62 | ||
| S20340001 | A 69 | ||
| S20342001 | A 70 | ||
| S20344001 | A 74 | ||
| S20345001 | A 10 | ||
| S20345001 | A 75 | ||
| S20346000 | A 79 | ||
| S20353000 | B 21 | ||
| S20355002 | K 9-6 | ||
| S20356001 | B 11 | ||
| S20361001 | B 17 | ||
| S20362151 | B 18 | ||
| S20391001 | C 7-4 | ||
| S20392000 | C 7-5 | ||
| S20392000 | N 25 | ||
| S20404001 | Ga1 3 | ||
| S20404001 | Ga2 3 | ||
| S20404001 | Ga3 3 | ||
| S20404001 | Ga4 3 | ||
| S20404001 | Ga5 3 | ||
| S20404001 | Ga6 2 | ||
| S20404001 | Ga6 3 | ||
| S20406001 | Ga1 3 | ||
| S20406001 | Ga2 3 | ||
| S20406001 | Ga3 3 | ||
| S20406001 | Ga4 3 | ||
| S20406001 | Ga6 2 | ||
| S20406001 | Ga6 3 | ||
| S20412000 | A 48 | ||
| S20412000 | A 55 | ||
| S20412000 | Z1 67 | ||
| S20415101 | C 21 | ||
| S20416101 | C 22 | ||
| S20418051 | C 23 | ||
| S20421001 | Ga1 9 | ||
| S20421001 | Ga2 9 | ||
| S20422001 | Ga3 9 | ||
| S20423001 | Ga1 9 | ||
| S20423001 | Ga2 9 | ||
| S20423001 | Ga3 9 | ||
| S20424001 | Ga4 9 | ||
| S20424001 | Ga5 9 | ||
| S20424001 | Ga6 9 | ||
| S20428001 | Ga4 9 | ||
| S20428001 | Ga6 9 | ||
| S20429001 | Ga1 9 | ||
| S20430001 | Ga7 9 | ||
| S20438101 | Ga4 9 | ||
| S20438101 | Ga5 9 | ||
| S20460000 | D 1-1-1 | ||
| S20468001 | D 1-1 | ||
| S20476001 | F1 4 | ||
| S20485001 | F1 19 | ||
| S20526000 | G 47 | ||
| S20530001 | G 30 | ||
| S20543101 | G 51 | ||
| S20544000 | G 52 | ||
| S20547001 | G 55 | ||
| S20548001 | G 59 | ||
| S20560001 | G 66 | ||
| S20571101 | H 2 | ||
| S20574001 | H 8 | ||
| S20577001 | H 12 |
Page 61
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 13 | S20578101 | H | |
| 15-4 | S20579101 | H | |
| 8 | S20582001 | Ga1 | |
| 8 | S20582001 | Ga2 | |
| 8 | S20582001 | Ga3 | |
| 8 | S20582001 | Ga4 | |
| 8 | S20582001 | Ga5 | |
| 8 | S20582001 | Ga6 | |
| 8 | S20583001 | Ga1 | |
| 8 | S20583001 | Ga4 | |
| 8 | S20583001 | Ga5 | |
| 27 | S20585001 | H | |
| 9-1 | S20589101 | H | |
| 9-2 | S20590101 | H | |
| 17 | S20591101 | H | |
| 2 | S20598000 | K | |
| 3 | S20598000 | L | |
| 5 | S20601001 | K | |
| 11 | S20625151 | L | |
| 14-1 | 20626001 | L | |
| 14-2 | 20627001 | L | |
| 11 | 20641001 | M | |
| 24 | 20652001 | M | |
| 27 | 20653001 | M | |
| 29 | 20654001 | M | |
| 1 | 20655101 | N | |
| 4-1 | 20657001 | N | |
| 19 | 20668200 | N | |
| 23 | 20669000 | N | |
| 22 | 20670001 | N | |
| 11 | 20673001 | P | |
| 8 | 20675001 | P | |
| 9 | 20676051 | P | |
| 9 | 20676051 | P | |
| 1-1-5 | 20676051 | Q1 | |
| 10 | 20677000 | P | |
| 10 | 20677000 | P | |
| 14 | 20678001 | P | |
| 14 | 20678001 | P | |
| 16 | 20679001 | P | |
| 17 | 20679001 | P | |
| 18 | 20681000 | P | |
| 18 | 20681000 | P | |
| 1-1-7 | 20681000 | Q1 | |
| 19-2 | 20682101 | P | |
| 19-4 | 20682102 | P | |
| 19-1 | 20682103 | P | |
| 19-5 | 20682104 | P | |
| 1-1-8 | 20682105 | Q1 | |
| 23 | 20684101 | P | |
| 25 | 20685001 | P | |
| 26 | 20686001 | P | |
| 37 | 20687001 | P | |
| 48 | 20689001 | P | |
| 49 | 20690001 | P | |
| 50 | 20691001 | P | |
| 53 | 20694001 | P | |
| 55 | 20695001 | P | |
| 56 | 20696001 | P | |
| 58 | 20697001 | P | |
| 59 | 20698121 | P | |
| 66 | S20701001 | P | |
| 71 | S20702001 | P | |
| 73 | S20703051 | P | |
| 75 | S20707001 | P | |
| 27 | S20718000 | Z1 | |
| 64-1 | S20721001 | Z2 | |
| 64-10 | S20722001 | Z2 | |
| 12 | S20723001 | Z1 | |
| 51 | S20743001 | P | |
| 40 | S20769000 | Z1 | |
| 81 | S20878000 | A | |
| 2 | S20882201 | Ga2 | |
| 15-2 | S20896101 | H | |
| 7 | S20896101 | Ga4 | |
| 7 | S20896101 | Ga7 | |
| 15-3 | S20897101 | H | |
| 15-5 | S20898101 | H | |
| 7 | S20898101 | Ga1 | |
| 7 | S20898101 | Ga4 | |
| 7 | S20898101 | Ga5 | |
| 8 | S20899001 | Ga1 | |
| 8 | S20899001 | Ga3 | |
| 8 | S20899001 | Ga4 | |
| 3 | S21104001 | Ga1 | |
| 3 | S21104001 | Ga4 | |
| 3 | S21104001 | Ga5 | |
| 40-1 | S21125001 | P | |
| 44-1 | S21126001 | P | |
| 40-2 | S21128001 | P | |
| 40-2 | S21129001 | P | |
| 42 | S21130051 | P | |
| 28 | S21133001 | P | |
| 29 | S21134001 | P | |
| 31 | S21135001 | P | |
| 35 | S21136101 | P | |
| 33 | S21137001 | P | |
| 1-1 | S21293001 | Q1 | |
| 1-1-1 | S21294001 | Q1 | |
| 1-1-2 | S21295001 | Q1 | |
| 1-1-9 | S21296001 | Q1 | |
| 1-1-12 | S21297001 | Q1 | |
| 1-1-15 | S21298001 | Q1 | |
| 1-1-17 | S21299001 | Q1 | |
| 1-1-19 | S21300001 | Q1 | |
| 1-1-23 | S21301001 | Q1 | |
| 1-1-24 | S21302001 | Q1 | |
| 1-1-26 | S21303001 | Q1 | |
| 1-1-28 | S21304001 | Q1 | |
| 1-1-3 | S21305001 | Q1 | |
| 1-1-13 | S21306001 | Q1 | |
| 1-1-14 | S21307001 | Q1 | |
| 2-1 | S21310001 | Q1 | |
| 2-2 | S21311001 | Q1 | |
| 2-3 | S21312001 | Q1 | |
| 2-7 | S21314001 | Q1 | |
| 2-9 | S21315001 | Q1 | |
| 2-11 | S21316001 | Q1 | |
| 4-3 | S21318000 | Q3 | |
| 1-6 | S21341001 | E | |
| 3-1-1 | S21373101 | Q2 | |
| 3-1-1-2 | S21375001 | Q2 | |
| 3-2-1-2 | S21375001 | Q2 | |
| 3-1-1-9 | S21376001 | Q2 | |
| 3-2-1-9 | S21376001 | Q2 | |
| 3-1-1-11 | S21377001 | Q2 | |
| 3-2-1-11 | S21377001 | Q2 | |
| 3-1-1-12 | S21378001 | Q2 | |
| 3-2-1-12 | S21378001 | Q2 | |
| 3-1-2 | S21379001 | Q2 | |
| 3-2-1 | S21380101 | Q2 | |
| 3-2-2 | S21381001 | Q2 | |
| 1-4 | S21590000 | Q1 | |
| 4 | S23233001 | Ga1 | |
| 7 | S2337001 | A | |
| 76 | S2337001 | A | |
| 1-2 | S23342001 | C | |
| 7-1 | S23342001 | C | |
| 1-3 | S23342001 | H | |
| 1-2 | S23346101 | K | |
| 2-13 | S23349001 | Q1 | |
| 63 | S23350001 | A | |
| 65 | S23351001 | A | |
| 58 | S23353001 | Z1 | |
| 10 | S23356001 | Z1 | |
| 78 | S23357001 | A | |
| 37 | S23360001 | G | |
| 42 | S23360001 | G | |
| 18 | S23360001 | M | |
| 44 | S23364000 | F1 | |
| 1-2 | S23418002 | D | |
| 6 | S23418002 | J | |
| 1-2 | S23773001 | Q1 | |
| 2-8 | S23774001 | Q1 | |
| 1-1-6 | S23775001 | Q1 | |
| 1-1-4 | S23777101 | Q1 | |
| 1-6 | S23779001 | Q1 | |
| 1-1 | S23896101 | E | |
| 1-4 | S23897001 | E | |
| 14 | S24473000 | Z1 | |
| 4-8 | S25019001 | Q3 | |
| 93 | S25184001 | A | |
| 4 | S25194001 | Ga1 | |
| 4 | S25194001 | Ga3 | |
| 4 | S25194001 | Ga3 | |
| 4 | S25195001 | Ga1 | |
| 4 | S25195001 | Ga3 |
Page 62 — 索引 / INDEX
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| S25196001 | Ga1 4 | ||
| S25196001 | Ga4 4 | ||
| S25197001 | Ga1 4 | ||
| S25197001 | Ga4 4 | ||
| S25198001 | Ga1 4 | ||
| S25198001 | Ga5 4 | ||
| S25199001 | Ga1 4 | ||
| S25199001 | Ga5 4 | ||
| S25200001 | Ga1 4 | ||
| S25200001 | Ga4 4 | ||
| S25201001 | Ga1 4 | ||
| S25201001 | Ga4 4 | ||
| S25202001 | Ga3 4 | ||
| S25202001 | Ga7 4 | ||
| S25203001 | Ga3 4 | ||
| S25203001 | Ga7 4 | ||
| S25204001 | Ga7 4 | ||
| S25548101 | Ga1 2 | ||
| S25548101 | Ga5 2 | ||
| S25550001 | Ga2 2 | ||
| S25550001 | Ga6 2 | ||
| S25553001 | Ga2 2 | ||
| S25553001 | Ga3 2 | ||
| S25553001 | Ga6 2 | ||
| S25553001 | Ga7 2 | ||
| S25555001 | Ga3 2 | ||
| S25555001 | Ga7 2 | ||
| S25557001 | Ga1 2 | ||
| S25557001 | Ga4 2 | ||
| S25560101 | Ga3 2 | ||
| S25560101 | Ga7 2 | ||
| S25562101 | Ga7 2 | ||
| S25566001 | Ga1 6 | ||
| S25566001 | Ga4 6 | ||
| S25818051 | G 61 | ||
| S27868001 | B 16 | ||
| S29102001 | M 6 | ||
| S29146001 | Ga1 3 | ||
| S29148001 | Ga7 3 | ||
| S29631001 | Ga1 3 | ||
| S29631001 | Ga4 3 | ||
| S29700000 | K 9-3 | ||
| S29824000 | J 4 | ||
| S29827000 | J 4 | ||
| S29831000 | J 7 | ||
| S29835001 | J 5 | ||
| S30135101 | Q2 3-1 | ||
| S30135101 | Q3 3 | ||
| S30135102 | Q2 3-2 | ||
| S30135102 | Q3 3 | ||
| S30296001 | Q3 5 | ||
| S30296002 | Q3 5 | ||
| S30296003 | Q3 5 | ||
| S30296004 | Q3 5 | ||
| S30296005 | Q3 5 | ||
| S30296006 | Q3 5 | ||
| S30297002 | Q3 5 | ||
| S30297004 | Q3 5 | ||
| S30297006 | Q3 5 | ||
| S30303001 | Q3 4 | ||
| S30304001 | Q1 1 | ||
| S30304001 | Q3 1 | ||
| S30525001 | Ga5 2 | ||
| S30532001 | Ga5 2 | ||
| S30562000 | F1 28 | ||
| S30562000 | G 18 | ||
| S30586101 | Ga3 2 | ||
| S30588001 | Ga4 2 | ||
| S30590001 | F2 50-16-5 | ||
| S30592101 | Ga3 2 | ||
| S30593001 | Ga3 2 | ||
| S30593001 | Ga4 2 | ||
| S30594101 | Ga4 2 | ||
| S30888001 | F1 40 | ||
| S30890000 | F1 38-4 | ||
| S30971001 | Ga1 2 | ||
| S30971001 | Ga2 2 | ||
| S30971001 | Ga4 2 | ||
| S30971001 | Ga6 2 | ||
| S30971001 | Ga6 2 | ||
| S31881101 | M 12 | ||
| S31975001 | Ga7 4 | ||
| S31979001 | Ga7 4 | ||
| S31981001 | Ga7 2 | ||
| S32140001 | E 1 | ||
| S32276001 | P 15 | ||
| S33172001 | Ga1 5 | ||
| S33172001 | Ga2 5 | ||
| S33172001 | Ga3 5 | ||
| S33172001 | Ga4 5 | ||
| S33172001 | Ga5 5 | ||
| S33172001 | Ga6 5 | ||
| S35635020 | Z2 42-5 | ||
| S35651001 | Ga1 4 | ||
| S35651001 | Ga4 4 | ||
| S35826021 | Z2 42-7 | ||
| S35826021 | Z2 42-29 | ||
| S35827021 | Z2 42-8 | ||
| S35827021 | Z2 42-10-2 | ||
| S35827021 | Z2 42-13 | ||
| S35827021 | Z2 42-14-2 | ||
| S35827021 | Z2 42-17 | ||
| S35827021 | Z2 42-23 | ||
| S35827021 | Z2 42-30 | ||
| S35831021 | Z2 42-12 | ||
| S35831021 | Z2 42-22 | ||
| S35832021 | Z2 42-10-1 | ||
| S35832021 | Z2 42-14-1 | ||
| S35840001 | Ga4 5 | ||
| S35991001 | Ga4 5 | ||
| S35992001 | Ga4 6 | ||
| S35997001 | Z1 29 | ||
| S35997001 | Z2 64-3 | ||
| S36007001 | Z2 64-4 | ||
| S36062021 | Z2 42-4 | ||
| S36064021 | Z2 42-2 | ||
| S37070121 | F1 34 | ||
| S38301020 | A 44 | ||
| S38302020 | Z1 65 | ||
| S38305001 | A 29-1 | ||
| S38306051 | C 25 | ||
| S38307001 | C 27 | ||
| S38308121 | F1 5 | ||
| S38311100 | G 43 | ||
| S38312050 | G 24 | ||
| S38328051 | P 1 | ||
| S38329001 | P- 38 | ||
| S38330050 | P 46 | ||
| S38595001 | Ga5 5 | ||
| S38596001 | Ga5 5 | ||
| S38597001 | Ga5 6 | ||
| S39562001 | A 37 | ||
| S39564021 | A 23 | ||
| S39565101 | B 24-2 | ||
| S39566001 | C 7 | ||
| S39571021 | C 10 | ||
| S39574001 | C 8 | ||
| S39575001 | F1 2 | ||
| S39577000 | F1 2-1 | ||
| S39578001 | G 1 | ||
| S39585001 | G 1-3 | ||
| S39586001 | G 1-4 | ||
| S39589021 | G 8 | ||
| S39593021 | G 54 | ||
| S39596021 | G 54-1 | ||
| S39597001 | N 4 | ||
| S39598000 | N 4-4 | ||
| S39599001 | N 4-3 | ||
| S39601000 | N 4-5 | ||
| S39602000 | N 4-7 | ||
| S39603001 | N 4-8 | ||
| S39605001 | A 2 | ||
| S39606020 | A 5 | ||
| S39607001 | A 8 | ||
| S39608021 | A 11 | ||
| S39611001 | A 27 | ||
| S39612001 | A 27-1 | ||
| S39613001 | A 27-2 | ||
| S39623001 | A 38 | ||
| S39624021 | A 42 | ||
| S39625151 | A 49 | ||
| S39626021 | A 58 | ||
| S39629021 | B 3 | ||
| S39630000 | B 10 | ||
| S39631000 | B 20 | ||
| S39644021 | C 2 | ||
| S39645021 | C 3 | ||
| S39646021 | C 4 | ||
| S39647000 | C 5 | ||
| S39648021 | C 9 | ||
| S39649021 | C 15 | ||
| S39650001 | C 17 | ||
| S39652021 | C 18 | ||
| S39654051 | C 29 | ||
| S39658001 | F1 1 | ||
| S39659021 | F1 6 | ||
| S39660001 | F1 7 | ||
| S39661001 | F1 8 | ||
| S39662001 | F1 9 | ||
| S39663121 | F1 11 | ||
| S39664101 | F1 12 | ||
| S39665001 | F1 15 | ||
| S39666001 | F1 20 | ||
| S39667021 | F1 21 | ||
| S39669101 | F1 23 | ||
| S39670000 | F1 24 |
Page 63
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 26 | S39671121 | F1 | |
| 29 | S39672001 | F1 | |
| 5 | S39673020 | G | |
| 9 | S39674001 | G | |
| 10 | S39675001 | G | |
| 15 | S39676121 | G | |
| 16 | S39677021 | G | |
| 17 | S39678021 | G | |
| 20 | S39679001 | G | |
| 26 | S39680001 | G | |
| 27 | S39684021 | G | |
| 28 | S39685001 | G | |
| 44 | S39686000 | G | |
| 45 | S39687000 | G | |
| 46 | S39688001 | G | |
| 36 | S39690021 | G | |
| 8 | S39691001 | M | |
| 39 | S39691001 | G | |
| 50 | S39692021 | G | |
| 58 | S39693001 | G | |
| 64 | S39694021 | G | |
| 65 | S39695001 | G | |
| 4 | S39704021 | H | |
| 19 | S39707001 | H | |
| 25 | S39708001 | H | |
| 28 | S39709021 | K | |
| 3 | S39728021 | K | |
| 8 | S39729021 | L | |
| 1 | S39732021 | M | |
| 3 | S39733001 | M | |
| 4 | S39734021 | M | |
| 7 | S39735050 | M | |
| 10 | S39740021 | M | |
| 20 | S39741021 | M | |
| 21 | S39742021 | M | |
| 22 | S39743001 | M | |
| 3 | 39743001 | N | |
| 7 | 39744021 | N | |
| 8 | S39745001 | N | |
| 10 | S39747001 | N | |
| 13 | S39749001 | N | |
| 11 | S39751021 | N | |
| 15 | S39752021 | N | |
| 63 | S39756021 | P | |
| 67 | S39757001 | P | |
| 40 | S39769051 | G | |
| 17 | S39770001 | F1 | |
| 35 | S39773001 | G | |
| 24-1 | S39775001 | B | |
| 92 | S39785001 | A | |
| 92 | S39786001 | A | |
| 92 | S39787001 | A | |
| 2-6 | S39795001 | Q1 | |
| 2-15 | S39796001 | Q1 | |
| 33 | S42042021 | G | |
| 29-2 | S42050001 | A | |
| 29-1 | S43521000 | N | |
| 29-2 | S43522000 | N | |
| 29 | S43523000 | N | |
| 1 | S43525001 | D | |
| 6 | S43527001 | H | |
| 2 | S43530001 | Q1 | |
| 2 | S43530001 | Q3 | |
| 40 | S43539001 | Q3 | |
| 40 | S43539003 | Q3 | |
| 40 | S43539004 | Q3 | |
| 40 | S43539005 | Q3 | |
| 40 | S43539006 | Q3 | |
| 40 | S43540001 | Q3 | |
| 40 | S43540005 | Q3 | |
| 40 | S43541001 | Q3 | |
| 40 | S43541002 | Q3 | |
| 40 | S43541003 | Q3 | |
| 40 | S43541004 | Q3 | |
| 40 | S43541005 | Q3 | |
| 40 | S43542004 | Q3 | |
| 40 | S43542005 | Q3 | |
| 40 | S43542006 | Q3 | |
| 48-1 | S43916001 | G | |
| 22-2 | S44535001 | A | |
| 25-3 | S44536000 | A | |
| 24 | S44744001 | A | |
| 38-1 | S44744001 | F1 | |
| 19 | S44778000 | A | |
| 21 | S44779001 | A | |
| 94 | S44821001 | A | |
| 14 | S44935101 | M | |
| 15 | S44937101 | M | |
| 16 | S44939001 | M | |
| 25-1 | S44955001 | G | |
| 42 | S45953001 | Z2 | |
| 42 | S45954001 | Z2 | |
| 42-25 | S45961001 | Z2 | |
| 42-14 | S45964001 | Z2 | |
| 42-10 | S45970001 | Z2 | |
| 7-2 | S46899001 | C | |
| 9-2-1 | S46900001 | K | |
| 30 | S46903001 | F1 | |
| 13 | S46904001 | K | |
| 5 | S46904001 | L | |
| 11 | S46907001 | Z1 | |
| 21 | S49337000 | N | |
| 23 | S50091001 | K | |
| 9 | S52053001 | K | |
| 9-1 | S52054001 | K | |
| 9-5 | S52059001 | K | |
| 9-2 | S52060001 | K | |
| 9 | S52062001 | K | |
| 9-2 | S52063001 | K | |
| 50-16-8 | S53955001 | F2 | |
| 1 | S54001001 | B | |
| 1 | S54002001 | B | |
| 1 | S54003001 | C | |
| 1 | S54006001 | C | |
| 1 | S54007001 | C | |
| 1 | S54011001 | H |
Brother MA4-N31 (64 pages) — parts catalog
- Page 1 (cover): This is the cover page for the Brother FB-N310 High Speed Safety Stitch Sewing Machine Parts Book.
- Page 2 (unknown): This page contains a watermark and no other discernible text or parts information.
- Page 3 (text): This page lists various specifications and applications for the Brother FB-N310 sewing machine, including stitch form, applications, sewing materials, special uses, needle gauge, stitch width, over-looper locus, differential feed dog, and upper knife shape.
- Page 4 (toc): This page is a table of contents for a parts book, listing various sections and their corresponding page numbers.
- Page 6 (diagram): This page displays a diagram of the machine body and related frame components, with numbered parts for identification.
- Page 7 (parts_list): This page lists parts for the machine body, including various screws, covers, and plates, with their corresponding part numbers and descriptions.
- Page 8 (diagram): This page displays a diagram of the machine body and related components, with numbered parts for identification.
- Page 9 (parts_list): This page lists parts for the Machine body, including screws, nuts, pins, rubber caps, and labels, with their corresponding part numbers, quantities, and descriptions.
- Page 10 (diagram): This page displays a diagram of the crankshaft mechanism, illustrating various components with reference numbers for identification.
- Page 11 (parts_list): This page lists parts for the Crankshaft mechanism, including part numbers, descriptions, and quantities for various components like bearings, rings, screws, and pulleys.
- Page 12 (diagram): This page displays a diagram of the needle bar mechanism, illustrating various components with reference numbers and part numbers for identification and assembly.
- Page 13 (parts_list): This page lists parts for the needle bar mechanism, including various screws, bolts, washers, and specialized components like needle plates and guards, with their corresponding part numbers and descriptions.
- Page 14 (diagram): This page contains diagrams and parts lists for the Needle cooler and Serging attachment, including option parts for both.
- Page 15 (parts_list): This page contains parts lists for the Needle cooler and Serging attachment sections, detailing part numbers, descriptions, and quantities.
- Page 16 (diagram): This page displays a diagram of the presser foot mechanism, detailing various components with their corresponding reference numbers and part numbers.
- Page 17 (parts_list): This page lists parts for the F1. Presser foot mechanism, including part numbers, descriptions, and quantities.
- Page 18 (diagram): This page displays diagrams and part numbers for various presser foot mechanisms, including parts for models 4020, 4030, 4420, 4430, 4720, 5020, 5030, 5420, 5720, 6030, 6430, 4010, 4520, 4530, 5010, 5520, 5530, 4050, 5050, 4620, 4630, 5620, 5630, 5051, and for small type machines.
- Page 19 (parts_list): This page lists parts for the Presser foot mechanism, including part numbers, descriptions, and quantities for various components.
- Page 20 (diagram): This page displays a diagram of the feed mechanism, with numbered parts and their corresponding references.
- Page 21 (parts_list): This page lists parts for the G. Feed mechanism, including part numbers, descriptions, quantities, and reference numbers.
- Page 22 (diagram): This page displays a diagram of the feed mechanism components for an industrial sewing machine, with various parts numbered for identification.
- Page 23 (parts_list): This page lists parts for the Feed mechanism, including part numbers, descriptions, quantities, and reference numbers.
- Page 24 (diagram): This page displays a diagram of the knife mechanism, including various parts and their reference numbers, with a section dedicated to optional parts for small type and angle knife.
- Page 25 (parts_list): This page lists parts for the Knife mechanism, including upper and lower knife parts, screws, washers, and bolts.
- Page 26 (diagram): This page displays a diagram of the Lapper mechanism for binding, with numbered parts including a lapper, a screw, and a bracket.
- Page 27 (parts_list): This page lists parts for the Lapper mechanism, including part numbers, descriptions in Japanese and English, and quantities.
- Page 28 (diagram): This page displays a diagram of the over looper mechanism and extra high lift components for an industrial sewing machine, with numbered parts and their corresponding references.
- Page 29 (parts_list): This page lists parts for the K. Over looper mechanism, including part numbers, quantities, descriptions in Japanese and English, and applicable models.
- Page 30 (diagram): This page displays a diagram of the under looper mechanism for an industrial sewing machine, with numbered parts and their corresponding references.
- Page 31 (parts_list): This page lists parts for the under looper mechanism, including part numbers, descriptions, and quantities for different machine models.
- Page 32 (diagram): This page displays a diagram of the double chain stitch looper mechanism, with numbered parts indicated for identification.
- Page 33 (parts_list): This page lists parts for the Double chain stitch looper mechanism, including part numbers, descriptions, and quantities.
- Page 34 (diagram): This page displays a diagram of lubrication components for an industrial sewing machine, with numbered parts and their corresponding references.
- Page 35 (parts_list): This page lists parts for lubrication, including part numbers, descriptions, and quantities.
- Page 36 (diagram): This page displays a diagram of thread tension components for a sewing machine, specifically for "3 Needles", with various parts numbered from 1 to 76.
- Page 37 (parts_list): This page lists parts related to thread tension, including part numbers, descriptions, and quantities.
- Page 38 (diagram): This page displays a diagram of thread tension components for a sewing machine, including parts numbered 1 through 76, with specific callouts for "For "3 Needles"" configurations.
- Page 39 (parts_list): This page lists parts for thread tension, including screws, springs, and guides, with their corresponding codes and names.
- Page 40 (diagram): This page displays a diagram of the ruffling attachment components, with parts numbered from 1-1-1 to 2-18.
- Page 41 (parts_list): This page lists parts for the Ruffler attachment, including part numbers, descriptions, and quantities.
- Page 42 (diagram): This page displays diagrams for the "Ruffling attachment" for both semi-submerged and fully-submerged machine types, detailing various components with their respective part numbers and reference designators.
- Page 43 (parts_list): This page lists parts for the Ruffing attachment, including part numbers, descriptions, and quantities for various components like adjusting sets, knee lifters, brackets, bolts, nuts, and screws.
- Page 44 (diagram): This page displays a diagram of ruffling attachment components, including various screws, a spool holder, and different presser feet, with reference numbers and part numbers indicated for each item.
- Page 45 (parts_list): This page lists parts for Ruffler attachment, including piping parts, tape winder, screws, washers, nuts, and various assemblies like the needle clamp, needle plate, and presser foot. It also details parts for different machine models and configurations.
- Page 46 (diagram): This page displays a diagram of accessories and optional parts for a Brother sewing machine, including various tools, a cloth, a bottle of oil, and a foot pedal.
- Page 47 (parts_list): This page lists accessories for the Z1 sewing machine, including needles, screws, wrenches, and other components with their respective part numbers and descriptions.
- Page 48 (diagram): This page displays a diagram of accessories and option parts for the sewing machine, including various screws, nuts, washers, and mounting components with their corresponding part numbers.
- Page 49 (parts_list): This page lists parts for Z2. Accessories, including part numbers, descriptions, and quantities for various components like screws, nuts, washers, and specialized parts.
- Page 50 (parts_list): This page lists parts for sewing machines, categorized by application and sub-class, including needle gauges, presser foot assemblies, needle clamps, needle plates, feed dogs, knives, and loopers.
- Page 51 (parts_list): This page lists parts for sewing machine models under the Ga2. Gauge Parts List section, detailing various components like presser foot assy, needle clamp assy, needle plate, main feed dog assy, differential feed dog, upper knife, lower knife, and over looper, along with their respective part numbers and quantities.
- Page 52 (parts_list): This page lists parts for sewing machine models, categorized by application such as Ruffing W/Piping, Binding, and Thin. It includes part numbers, names, and quantities for various components like Presser Foot Assy, Needle Clamp Assy, Needle Plate, Feed Dogs, and Knives.
- Page 53 (parts_list): This page lists parts for sewing machines, categorized by application and thickness, including needle gauges, presser foot assemblies, needle clamps, needle plates, feed dogs, and knives.
- Page 54 (parts_list): This page lists parts for sewing machine models under the "Ga5" series, categorized by application like "5 Threads", "Extra Heavy", and "Ruffing". It includes part numbers, names, and diagrams for items such as needles, presser feet, needle clamps, needle plates, feed dogs, and knives.
- Page 55 (parts_list): This page lists parts for the Ga6 gauge, including presser foot assy, needle clamp assy, needle plate, main feed dog assy, differential feed dog, upper knife, lower knife, and over looper.
- Page 56 (parts_list): This page lists parts for various sewing machine applications including piping, binding, and ruffling, with part numbers, descriptions, and diagrams.
- Page 57 (parts_list): This page lists warning labels and their corresponding codes and sizes, including operation caution labels and grounding marks.
- Page 58 (index): This page is an index of part numbers and their corresponding reference numbers and page numbers in the catalog.
- Page 59 (parts_list): This page contains a parts list with columns for CODE, REF.NO, and page, listing various part numbers and their corresponding references and page numbers.
- Page 60 (index): This page is an index of machine parts, listing part numbers, reference numbers, and corresponding page numbers.
- Page 61 (parts_list): This page lists parts with codes such as S20578101, S20701001, and S21376001, along with their reference numbers and page numbers.
- Page 62 (index): This page is an index of parts for an industrial sewing machine, listing part codes, reference numbers, and corresponding page numbers.
- Page 63 (parts_list): This page contains a parts list with part numbers, reference numbers, and page numbers for various components, organized into columns for CODE, REF.NO, and page.
- Page 64 (cover): This is the cover page of the Brother Parts Book, featuring the Brother logo, a graphic of a screw, and the title "PARTS BOOK". It also includes the company name "BROTHER INDUSTRIES LTD" and printing information.
