Parts index — Pegasus EX3200 Seriestap a row to open its page

Page 2

Pegasus EX3200 Series parts on page 2

Ref	Part number	Part name	Qty
	EX3216-01/222	EX3216-01/222
	EX3216-01A/222	EX3216-01A/222
	EX3216-02/223	EX3216-02/223
	EX3216-02A/223	EX3216-02A/223
	EX3216-03/233	EX3216-03/233
	EX3216-03/333	EX3216-03/333
	EX3244-03/333	EX3244-03/333
	EX3216-04/435	EX3216-04/435
	EX3216H-05/535	EX3216H-05/535
	EX3216-42/233	EX3216-42/233
	EX3216-43/335	EX3216-43/335
	EX3216-53/233	EX3216-53/233
	EX5204-01/223	EX5204-01/223
	EX5214-01/233	EX5214-01/233
	EX5204-02/233	EX5204-02/233
	EX5204-02H/233	EX5204-02H/233
	EX5212-02/333	EX5212-02/333
	EX5214-03/333	EX5214-03/333
	EX5214-03C3/333	EX5214-03C3/333
	EX5214-M03/333	EX5214-M03/333
	EX5214-M03C3/333	EX5214-M03C3/333
	EX5205-12/223	EX5205-12/223
	EX5203-12/223	EX5203-12/223
	EX5203-22/233	EX5203-22/233
	EX5204-24/445	EX5204-24/445
	EX5214-24/445	EX5214-24/445
	EX5204-32R1/223	EX5204-32R1/223
	EX5204-32R2/223	EX5204-32R2/223
	EX5204-32R2/223L	EX5204-32R2/223L
	EX5214-43/333	EX5214-43/333
	EX5214-43P1/333	EX5214-43P1/333
	EX5214-43P2/333	EX5214-43P2/333
	EX5214-53/333	EX5214-53/333
	EX5214-53C3/333	EX5214-53C3/333
	EX5214-M53/333	EX5214-M53/333
	EX5214-M53C3/333	EX5214-M53C3/333
	EX5214-54/433	EX5214-54/433
	EX5214-54/443	EX5214-54/443
	EX5214-54/445	EX5214-54/445
	EX5214H-55/545	EX5214H-55/545
	EX5204-82/223	EX5204-82/223
	EX5204-82/233	EX5204-82/233
	EX5214-83/323	EX5214-83/323
	EX5214-84/423	EX5214-84/423
	EX5204-92M1/223	EX5204-92M1/223
	EX5204-92M2/223	EX5204-92M2/223

Page 3 — TABLE OF CONTENTS

Pegasus EX3200 Series parts on page 3

Ref	Part number	Part name	Qty
	2-3	ベッド機構
	4-7	カバー機構(1)~(2)
	8-9	クランクシャフト機構(1)
	10-11	糸調子機構
	12-17	糸道,糸繰り(1)~(3)
	18-25	針振り機構(1)~(4)
	26-29	上ルーパー機構(1)~(2)
	30-31	下ルーパー機構
	32-35	二重環ルーパー機構(1)~(2)
	36-39	送り機構(1)~(2)
	40-41	上下メス機構
	42-43	押エ機構
	44-47	給油機構(1)~(2)
	48-49	H.R.装置
	50-51	糸立台
	52-53	半沈床式据付付属品
	54-55	全沈床式据付付属品
	56-83	専用部品(1)~(14)
	84-85	当定規
	86-119	ゲージパーツ系列構成図
	120-133	ゲージパーツ表
	134-	部品番号インデックス
	2-3	MACHINE BED FRAME
	4-7	COVER(1)-(2)
	8-9	CRANKSHAFT DRIVE MECHANISM
	10-11	THREAD TENTION MECHANISM
	12-17	THREAD GUIDE & THREAD TAKEUP(1)-(3)
	18-25	NEEDLE DRIVE MECHANISM(1)-(4)
	26-29	UPPER LOOPER DRIVE MECHANISM(1)-(2)
	30-31	LOWER LOOPER DRIVE MECHANISM
	32-35	CHAINSTITH LOOPER DRIVE MECHANISM(1)-(2)
	36-39	FEED MECHANISM(1)-(2)
	40-41	KNIFE DRIVE MECHANISM
	42-43	PRESSER FOOT MECHANISM
	44-47	LUBRICATION MECHANISM(1)-(2)
	48-49	H.R. DEVICE
	50-51	THREAD STAND
	52-53	PARTS FOR SEMI-SUBMERGED INSTALLATION
	54-55	PARTS FOR FULLY-SUBMERGED INSTALLATION
	56-83	SPECIFIC PARTS(1)-(14)
	84-85	FABRIC EDGE GUIDE
	86-119	GAUGE PARTS CONSTRUCTION CHART
	120-133	GAUGE PARTS LIST
	134-	PART NUMBER INDEX

Page 4

Pegasus EX3200 Series parts on page 4

Ref	Part number	Part name	Qty
	1	EX5200 Series
	2	EX3200 Series
	3	EX5200H Series
	4	EX3200H Series
	5	EX3200 Series EX5200 Series
	6	6
	7	7
	8	8
	9	9
	10	EX5200(H) Series
	11	11
	12	12
	13	13

Page 5 — MACHINE BED FRAME

Pegasus EX3200 Series parts on page 5

Ref	Part number	Part name	Qty
	270001-9S	ベッド(組)
	270001A9S	ベッド(組)
	270055-9S	ベッド(組)
	270055A9S	ベッド(組)
	240333	ノッチ棒	1
	201002	スプリングピン	1
	210194	案内/オイル指示	1
	240325	パイプ	2
	240299	ピン	1
	208173	栓	1
	270008-91	ブラケット(組)	1
	4511	平ネジ/M6×25	2
	270047	足ピン	4

Page 6

Pegasus EX3200 Series parts on page 6

Ref	Part number	Part name	Qty
1	1	SCREW
2	2	SCREW
3	3	BRACKET
4	4	SCREW
5	5	CAP
6	6	GASKET
7	7	BRACKET
8	8	SCREW
9	9	COVER
10	10	COVER
11	11	COVER
12	12	SCREW
13	13	BRACKET
14	14	BRACKET
15	15	BRACKET
16	16	BRACKET
17	17	SCREW
18	18	SHAFT
19	19	BRACKET
20	20	SPRING
21	21	BRACKET
22	22	SCREW
23	23	SPRING
24	24	PIN
25	25	BRACKET
26	26	BRACKET
27	27	BRACKET
28	28	BRACKET
29	29	BRACKET
30	30	SCREW
31	31	SCREW
32	32	SCREW
33	33	SCREW
34	34	BRACKET
35	35	BRACKET
36	36	BRACKET
38	38	BRACKET

Page 7 — COVER (1)

Pegasus EX3200 Series parts on page 7

Ref	Part number	Part name	Qty
	270020-SD	上カバー
	7022	平ネジ/M4×14
	270021	ガスケット
	240305	防振ゴム
	179107-05	オイル窓
	240110	栓
	270010-UD	側面カバー
	7044	皿ネジ/M4×10
	270024-9U	ベルトカバー(組)
	270024-UB	ベルトカバー
	240305	防振ゴム
	7176	平ネジ/M6×14
	270025	ファンカバー
	7019	平ネジ/M4×10
	270011-UD	前カバー(右)
	270014	ヒンジ
	7021	平ネジ/M4×12
	240043	平行ピン
	4543	止ネジ
	240301	圧縮バネ
	270018	ラッチ
	7009	平ネジ/M3×4
	4574	止ネジ/M3×12
	4535	止ネジ/M3×4
	270017	ラッチ
	7017	平ネジ/M4×5
	210044	板バネ
	7017	平ネジ/M4×5
	270012	前カバー(左)
	7018	平ネジ/M4×6
	270028	カバー
	7019	平ネジ/M4×10
	7020	平ネジ/M4×10
	7021	平ネジ/M4×12
	270013	前カバー(左)
	270010AUD	側面カバー

Page 8

Pegasus EX3200 Series parts on page 8

Ref	Part number	Part name	Qty
	1	EX3200(H) Series
	2	EX5200(H) Series
	3	EX3200(H) Series
	4	EX3215-3216-42,43 を除く Except EX3215-3216-42,43
	5
	6
	7
	8
	9	EX5200(H) Series
	10	EX5200(H) Series
	11
	12
	13
	14
	15
	16
	17
	18
	19
	20
	21
	22	EX5214-83,84 を除く Except EX5214-83,84
	23
	24
	25
	26
	27
	28	EX5200(H) Series
	29
	30
	31
	32
	33
	34
	35
	36
	37
	38
	39
	40
	41
	42
	43
	44
	45
	46
	47
	48
	49
	50
	51	EX3200(H) Series
	52	EX3200(H) Series

Page 9 — COVER (2)

Pegasus EX3200 Series parts on page 9

Ref	Part number	Part name	Qty
	270035	CLOTH PLATE (WIDE)	1
	270037	CLOTH PLATE (NARROW)	1
	270042	BUSHING	1
	4543	SCREW	1
	210307	WASHER	1
	240303	COLLAR	1
	4543	SCREW	1
	240305	CUSHION RUBBER	1
	270030-UB	SIDE COVER	1
	270031-UB	SIDE COVER	1
	7025	SCREW	1
	201252	SPRING WASHER	2
	7018	SCREW	1
	240343	WASHER	1
	240305	CUSHION RUBBER	1
	270048	LATCH	1
	7008	SCREW	1
	270049	LATCH	1
	7180	SCREW	1
	270015	PLATE	1
	7077	SCREW	2
	270043	LEVER	1
	7172	SCREW	1
	270044	SPRING	1
	270045	BRACKET	1
	270019	FABRIC GUARD	1
	7019	SCREW	2
	270032	EYE GUARD	1
	7062	SCREW	1
	202875	WASHER	2
	270034	BRACKET	1
	7066	SCREW	1
	210307	WASHER	2
	270022	BED COVER PLATE ASSEMBLY	1
	7084	SCREW	5
	270023	GASKET	1
	270046	COVER/FEED ECCENTRIC	1
	7018	SCREW	2
	270026	COVER PLATE	1
	7020	SCREW	4
	7023	SCREW	1
	4821	NUT	1
	270052	NAME PLATE	1
	270053	NAME PLATE	2
	210679	PIN	1
	250233	TYPE PLATE	1
	210679	PIN	2
	230047A	SERIAL NUMBER PLATE	1
	210679	PIN	2
	202526	NAME PLATE	1
	270030-UB	SIDE COVEF	1
	270033	EYE GUARD	1

Page 10

Pegasus EX3200 Series parts on page 10

Ref	Part number	Part name	Qty
	EX3215-3216-04	EX3244-04 を除く
	EX3215H-3216H-05	を除く
	1	スタンダードリフト・ハイリフト
	2	超ハイリフト
	3	ウルトラハイリフト
	4	スタンダードリフト (Standad lift)
	5	ハイリフト (High lift)
	6	超ハイリフト (Extra-high lift)
	7	ウルトラハイリフト (Ultra-high lift)
	8	EX5200(H) Series
	9	EX3200(H) Series
	10	EX3200(H) Series
	11	EX5200(H) Series
	12	EX5200(H) Series
	13	EX5200(H) Series
	14	EX5200(H) Series
	15	EX5200(H) Series
	16	EX5200(H) Series
	17	EX5200(H) Series
	18	EX5200(H) Series
	19	EX5200(H) Series
	20	EX5200(H) Series
	21	EX5200(H) Series
	22	EX5200(H) Series
	23	EX5200(H) Series
	24	EX5200(H) Series
	25	EX5200(H) Series
	26	EX5200(H) Series
	27	EX5200(H) Series
	28	EX5200(H) Series
	29	EX3200(H) Series
	30	EX3200(H) Series
	31	EX3200(H) Series
	32	EX3200(H) Series

Page 11 — CRANKSHAFT DRIVE MECHANISM

Pegasus EX3200 Series parts on page 11

Ref	Part number	Part name	Qty
	270500A	クランク軸	1
	270500B	クランク軸	1
	270512A	クランク軸	1
	7151	止ネジ	5
	270502	バランスウエイト	2
	7011	平ネジ/M3×8	4
	270503	段付ピン	1
	4541	止ネジ/M6×8	1
	270508	蓋	1
	7019	平ネジ/M4×10	3
	240340	Oリング	1
	270507-91	ボールベアリング(組)	1
	4572	止ネジ/M5×10	2
	4514	止ネジ/M5×5	1
	240335	止メ輪	1
	212987	ボールベアリング	1
	211526	ボールベアリング	1
	240306	波板座金	1
	210056	油切り	1
	210057	Oリング	1
	240340	Oリング	1
	211528	ハウジング	1
	7020	平ネジ/M4×10	3
	270505	ファン(組)	1
	270504-UD	プーリー	1
	4541	止ネジ/M6×8	2
	4523	六角穴ボルト/M6×35	1
	204293	バネ座金	1
	270510	段付ピン	1
	270509	蓋	1
	7044	皿ネジ/M4×10	2
	7020	平ネジ/M4×10	1

Page 12

Pegasus EX3200 Series parts on page 12

Ref	Part number	Part name	Qty
	EX5203-5204-5205	1 本針 (1-needle)
	EX5212-5214 EX3215-3216	2 本針 (2-needle)
	EX3244	3 本針 (3-needle)

Page 13 — THREAD TENSION MECHANISM

Pegasus EX3200 Series parts on page 13

Ref	Part number	Part name	Qty
1	210529-9U	糸調子(組)	1
2	208447-UA	調子ナット	1
3	208448	ラチェット	1
4	208450-UA	受皿	1
5	210319	調子皿	2
6	208449	フェルト	1
7	5082A	調子棒/C5	1
8	201037	圧縮バネ(強)	1
9	210530-9U	糸調子(組)	1
10	201086	圧縮バネ(中)	1
11	275000	糸道	1
12	7018	平ネジ/M4×6	1
13	275001	糸道	1
14	202849	調子台	1
15	4009-HC	平ネジ/C5×7.5	1
16	275041	糸道	1
17	7018	平ネジ/M4×6	1
18	275040	糸道	1
19	3044	六角ナット/C5	1

Page 14 — EX3200(H) Series

Pegasus EX3200 Series parts on page 14

Ref	Part number	Part name	Qty
2	EX3215(H)-3216(H)	2 本針 (2-needle)
3	EX3244	3 本針 (3-needle)
10	EX3215-3216	EX3215-3216
11	EX3244	EX3244
12	EX3215H-3216H	EX3215H-3216H
14	EX3215-3216	EX3215-3216
15	EX3244	EX3244
3	2 本針 (2-needle)	2 本針 (2-needle)
4	3 本針 (3-needle)	3 本針 (3-needle)
21	EX3215-3216	EX3215-3216
22	EX3244	EX3244

Page 15 — Thread Guide & Thread Takeup (1)

Pegasus EX3200 Series parts on page 15

Ref	Part number	Part name	Qty
1	275021	ブラケット	1
2	7012	平ネジ / M 4 × 8	2
3	275024	糸道	1
4	275042	糸道	1
5	4543	止ネジ	1
6	275026	ブラケット	1
7	7017	平ネジ / M 4 × 5	1
8	275022	糸道	1
9	4543	止ネジ	1
10	275029	糸道	1
11	275029A	糸道	1
12	275052	糸道	1
13	7017	平ネジ / M 4 × 5	1
14	275028	糸道	1
15	275057	糸道	1
16	7017	平ネジ / M 4 × 5	1
17	275011	小調子台	1
18	275012	小調子皿	1
19	7163	段付ネジ / M 2	1
20	240326	圧縮バネ	1
21	275027	針糸繰り	1
22	275044	針糸繰り	1
23	7062	平ネジ / M 3 × 6	2
24	275049	針糸繰り	1
25	7041	皿ネジ / M 3 × 6	1
26	7062	平ネジ / M 3 × 6	1

Page 16 — EX5200(H) Series

Pegasus EX3200 Series parts on page 16

Ref	Part number	Part name	Qty
6	EX5203-5204-5205	1 needle
6	5205	1 needle
7	EX5212-5214	2-needle
8	EX5214H	2-needle
14	EX5203-5204-5205	1 needle
14	5205	1 needle
15	EX5212-5214	2-needle
1	1	1 needle
2	2	2-needle
3	3	screw
4	4	screw
5	5	screw
9	9	bracket
10	10	screw
11	11	washer
12	12	screw
13	13	screw
16	16	screw
17	17	screw
18	18	screw
19	19	screw

Page 17 — THREAD GUIDE & THREAD TAKEUP (2)

Pegasus EX3200 Series parts on page 17

Ref	Part number	Part name	Qty
1	275013A	糸道
2	275013	糸道
3	4543	止ネジ
4	275015	ブラケット
5	7082	平ネジ/M4×8
6	275018	糸道
7	275018A	糸道
8	275051A	糸道
9	7082	平ネジ/M4×8
10	275011	小調子皿
11	275012	小調子皿
12	7163	段付ネジ/M2
13	240326	圧縮バネ
14	275016	針糸締り
15	275017	針糸締り
16	7062	平ネジ/M3×6
17	275017A	針糸締り
18	7041	皿ネジ/M3×6
19	7062	平ネジ/M3×6

Page 18

Pegasus EX3200 Series parts on page 18

Ref	Part number	Part name	Qty
	2	スタンダードリフト (Standad lift)
	3	ハイリフト (High lift)
	4	超ハイリフト (Extra-high lift)
	5	ウルトラハイリフト (Ultra-high lift)
	12	スタンダードリフト ハイリフト・超ハイリフト Standard lift・High lift Extra-high lift
	13	ウルトラハイリフト Ultra-high lift
	14	スタンダードリフト ハイリフト・超ハイリフト Standard lift・High lift Extra-high lift
	15	ウルトラハイリフト Ultra-high lift
	11	ウルトラハイリフト Ultra-high lift
	10	超ハイリフト Extra-high lift
	9	スタンダードリフト・ハイリフト Standard lift・High lift
	1	EX5212 を除く Except EX5212
	2	2
	4	4
	3	3
	5	5
	6	6
	7	7
	8	8
	16	16

Page 19 — THREAD GUIDE & THREAD TAKEUP (3)

Pegasus EX3200 Series parts on page 19

Ref	Part number	Part name	Qty
1	275004	ブラケット
2	275047	糸道
3	7008	平ネジ/C3×5
4	202875	座金
5	275005	糸繰り
6	7019	平ネジ/M4×10
7	275006	糸道
8	7008	平ネジ/C3×5
9	275007	糸道
10	275008	糸道
11	275055	糸道
12	275010	糸道
13	275056	糸道
14	275009	糸繰り
15	275054	糸繰り
16	7012	平ネジ/M3.5×6

Page 20

Pegasus EX3200 Series parts on page 20

Ref	Part number	Part name	Qty
1	1	Connecting Rod
2	2	Bolt
3	3	Pin
4	4	Screw
5	5	Lever
6	6	Screw
7	7	Shaft
8	8	Lever
9	9	Screw
10	10	Washer
11	11	Clip
12	12	Lever
13	13	Screw
14	14	Shaft
15	15	Spring
16	16	Lever
17	17	Shaft
18	18	Shaft
19	19	Lever
20	20	Screw
21	21	Washer
22	22	Shaft
23	23	Lever
24	24	Screw
25	25	Cap

Page 21 — NEEDLE DRIVE MECHANISM (1)

Pegasus EX3200 Series parts on page 21

Ref	Part number	Part name	Qty
	271000-92	ロッド (組)	1
	7023	平ネジ / M4×16	2
	271001	ピン	1
	4538	止ネジ / M4×6	1
	271002-92	クランク (組)	1
	4533	平ネジ	1
	271003	軸	1
	240308	カラー	1
	4543	止ネジ	2
	208235	座金	1
	202577	止メ輪	1
	271004-92	レバー	1
	7150	六角ボルト	1
	271022-91	軸 (組)	1
	271008-T	軸	1
	202177	給油紐	1
	271005-91T	ブッシュ (組) / 針棒	2
	271006-T	針棒	1
	271007	ブッシュ	1
	4546	止ネジ / M4×5	1
	201022	Oリング	1
	179009-05	フェルト	1
	271009-92	リング	1
	7035	平ネジ / M3×6	1
	240310	栓	1

Page 22

Pegasus EX3200 Series parts on page 22

Ref	Part number	Part name	Qty
1	1	BOLT
2	2	BOLT
3	3	PIN
4	4	SPRING
5	5	BRACKET
6	6	SHAFT
7	7	SHAFT
8	8	BOLT
9	9	SPRING
10	10	COLLAR
11	11	CIR-CLIP
12	12	BRACKET
13	13	BOLT
14	14	BRACKET
15	15	COLLAR
16	16	COLLAR
17	17	SHAFT
18	18	SPRING
19	19	SPRING
20	20	COLLAR
21	21	BRACKET
22	22	COLLAR
23	23	COLLAR
24	24	BOLT
25	25	COLLAR
26	26	COLLAR
27	27	BRACKET
28	28	BOLT
29	29	COLLAR

Page 23 — NEEDLE DRIVE MECHANISM (2)

Pegasus EX3200 Series parts on page 23

Ref	Part number	Part name	Qty
1	271000-92	ロッド(組)	1
2	7023	平ネジ/M4×16	2
3	271001	ピン	1
4	4538	止ネジ/M4×6	1
5	271002-92	クランク(組)	1
6	4533	平ネジ	1
7	271003	軸	1
8	240308	カラー	1
9	4543	止ネジ	2
10	208235	座金	1
11	202577	止メ輪	1
12	271015-92	レバー	1
13	7150	六角ボルト	1
14	271016	リンク	1
15	271017	段付ピン	2
16	7185	平ネジ/M3×4	2
17	271023-91	軸(組)	1
*18	271021	平行ピン	1
19	202176	給油紐	2
20	4545	止ネジ/M3×4	1
21	271018-91	ブッシュ(組)/針棒	1
*22	271020	ブッシュ	1
*23	271019	針棒	1
24	4546	止ネジ/M4×5	1
25	201022	Oリング	1
26	179009-05	フエルト	1
27	271009-92	リング	1
28	7035	平ネジ/M3×6	1
29	240310	栓	1

Page 24

Pegasus EX3200 Series parts on page 24

Ref	Part number	Part name	Qty
	EX3215-3216-04	EX3215-3216-04
	EX3215-3216-04	EX3215-3216-04
	EX3244-04	EX3244-04 を除く Except EX3244-04
	EX5203-5204-5205	EX5203-5204-5205
15	NG=2mm	NG=2mm
19	NG=2.5mm	NG=2.5mm
19	NG=3mm	NG=3mm
	EX5212-5214	EX5212-5214

Page 25 — 針振り機構(3)

Pegasus EX3200 Series parts on page 25

Ref	Part number	Part name	Qty
	XXXXXX	針留(組)	1
	4554	止ネジ/M3×3	2
	275030	糸道	1
	7119	皿ネジ/M2×5	1
	XXXXXX	針	2
	XXXXXX	針留(組)	1
	4554	止ネジ/M3×3	3
	275030	糸道	1
	7119	皿ネジ/M2×5	1
	XXXXXX	針留(組)	1
	4554	止ネジ/M3×3	1
	275019A	糸道	1
	7120	平ネジ/M2×3	1
	XXXXXX	針	1
	XXXXXX	針留	1
	4554	止ネジ/M3×3	2
	275019B	糸道	1
	7120	平ネジ/M2×3	1
	XXXXXX	針留	2
	4554	止ネジ/M3×3	1
	275019C	糸道	1
	7120	平ネジ/M2×3	1

Page 26

Pegasus EX3200 Series parts on page 26

Ref	Part number	Part name	Qty
23	EX5204-83,84

Page 27 — NEEDLE DRIVE MECHANISM (4)

Pegasus EX3200 Series parts on page 27

Ref	Part number	Part name	Qty
	XXXXXX	針板
	7170	皿ネジ/M4×7.5
	271010	取付板(前)
	7019	平ネジ/M4×10
	240305	防振ゴム
	271011	取付板(後)
	7019	平ネジ/M4×10
	7019	平ネジ/M4×10
	XXXXXX	針受(前)
	7010	平ネジ/M3×6
	XXXXXX	針受(後)
	7259	六角ボルト
	240222	皿バネ
	7165	段付ネジ/M3
	XXXXXX	針受(前)
	7019	平ネジ/M4×10
	XXXXXX	針受(後)
	7010	平ネジ/M3×6
	271013	ブラケット
	7114	平ネジ/M4×10
	XXXXXX	針板
	7170	皿ネジ/M4×7.5
	271010	取付板(前)
	7019	平ネジ/M4×10
	240305	防振ゴム
	271011	取付板(後)
	7019	平ネジ/M4×10
	271012	ストッパー
	7019	平ネジ/M4×10
	XXXXXX	針受(前)
	7019	平ネジ/M4×10
	XXXXXX	針受(後)
	7259	六角ボルト
	240222	皿バネ
	7165	段付ネジ/M3

Page 28

Pegasus EX3200 Series parts on page 28

Ref	Part number	Part name	Qty
	1	STANDAD LIFT
	2	スタンダードリフト (Standad lift)
	3	ハイリフト (High lift)
	4	超ハイリフト (Extra-high lift)
	5	ウルトラハイリフト (Ultra-high lift)
	6	スタンダードリフト Standard lift
	7	ハイリフト High lift Extra-high lift
	8	EX3244-04
	9	EX3200 Series 3 本針 (3-needle)
	10	EX5200 Series 2 本針 (2-needle)
	11	スタンダードリフト Standard lift
	12	ハイリフト・超ハイリフト High lift・Extra-high lift
	13	EX5204-24
	14	EX5214-24,54/445
	15	EX3215-3216-04
	16	EX3244-04 を除く
	17	Except
	18	EX5204-24
	19	EX5214-24,54/445
	20	EX3215-3216-04
	21	EX3244-04
	22	スタンダードリフト
	23	Standard lift
	24	ハイリフト
	25	High lift
	27	超ハイリフト
	28	Extra-high lift
	29	EX3200 Series
	30	3 本針 (3-needle)
	31	EX5200 Series 2 本針 (2-needle)
	32	スタンダードリフト
	33	Standard lift
	34	ハイリフト・超ハイリフト
	35	High lift・Extra-high lift
	36	EX3200 Series
	37	3 本針 (3-needle)
	38	EX5200 Series 2 本針 (2-needle)
	39	スタンダードリフト

Page 29 — UPPER LOOPER DRIVE MECHANISM (1)

Pegasus EX3200 Series parts on page 29

Ref	Part number	Part name	Qty
	271500-92	ロッド	1
	7023	平ネジ/M4×16	2
	7022	平ネジ/M4×14	2
	271501	振止メ	1
	7041	皿ネジ/M3×6	2
	271502-92	クランク	1
	271503-92	クランク	1
	4533	平ネジ	1
	271504	軸	1
	240338	座金	1
	7174	六角ネジ/M4×10	1
	303067	バネ座金	1
	275540	栓	1
	275541	フィルター	1
	210122	スペーサー	1
	240312	座金	1
	240102	座金	1
	210586A	オイルシール	1
	271517-91	上ルーバー台(セット)	1
	271505-92	レバー	1
	7150	六角ボルト	1
	179136-01	平行ピン(組)	1
	179137-05	平行ピン	1
	202176	給油紐	2
	4545	止ネジ/M3×4	1
	271506-91	上ルーバー	1
	271507	上ルーバー	1
	179129-05	上ルーバー台	1
	179130-05	上ルーバー台案内	1
	7054	フェルト	1
	XXXXXX	上ルーバー	1
	271510	上ルーバー	1
	271510A	上ルーバー台	1
	271510B	上ルーバー台	1
	4510	上ルーバー台	2
	271511	カバー	1
	7039	皿ネジ/M2.5×6	1
	7033	平ネジ/M2.5×8	1
	8421	オイルマーク	1

Page 30

Pegasus EX3200 Series parts on page 30

Ref	Part number	Part name	Qty
1	1	Lever
2	2	Screw
3	3	Screw
5	5	Lever
6	6	Screw
8	8	Shaft
9	9	Washer
10	10	Screw
11	11	Washer
12	12	Pulley
13	13	Washer
14	14	Ring
15	15	Lever
16	16	Bearing
17	17	Base
18	18	Lever
19	19	Screw
20	20	Spring
21	21	Pin
22	22	Spring
23	23	Screw
24	24	Shaft
25	25	Shaft
26	26	Shaft
27	27	Collar
28	28	Lever
29	29	Lever
30	30	Housing
31	31	Screw
32	32	Screw
33	33	Screw
34	34	Lever
35	35	Oil hole

Page 32

Pegasus EX3200 Series parts on page 32

Ref	Part number	Part name	Qty
6	6	EX5200(H)Series
7	7	7
19	19	EX3200(H)Series
21	21	21
20	20	20
1	1	1
2	2	2
3	3	3
4	4	4
5	5	5
12	12	12
13	13	13
14	14	14
15	15	15
16	16	16
17	17	17
18	18	18
9	9	9
10	10	10
11	11	11
8	8	8

Page 33 — LOWER LOOPER DRIVE MECHANISM

Pegasus EX3200 Series parts on page 33

Ref	Part number	Part name	Qty
1	271500-92	ロッド
2	7023	平ネジ/M4×16
3	7022	平ネジ/M4×14
4	271501	振止メ
5	7041	皿ネジ/M3×6
6	272000-92	クランク
7	4533	平ネジ
8	271504	軸
9	240338	座金
10	7174	六角ネジ/M4×10
11	303067	バネ座金
12	240311	座金
13	210586A	オイルシール
14	XXXXXX	下ルーパー
15	7168	止ネジ/M3.5×6.
16	272001-92	下ルーパー合(組)
17	7055	六角ネジ/M5×13
18	7169	平ネジ/M4×7
19	273511-92	クランク
20	4533	平ネジ
21	4514	止ネジ/M5×5

Page 34 — EX3200(H) Series

Pegasus EX3200 Series parts on page 34

Ref	Part number	Part name	Qty
1	1	BEARING
2	2	GEAR
3	3	SHAFT
4	4	COLLAR
5	5	SCREW
6	6	WASHER
7	7	BRACKET
8	8	SCREW
9	9	WASHER
10	10	WASHER
11	11	PIN
12	12	SPRING
13	13	SHAFT
14	14	BRACKET
15	15	SCREW
17	17	SCREW
18	18	SHAFT
19	19	COLLAR
20	20	SCREW
21	21	WASHER
22	22	SHAFT
23	23	BEARING
24	24	BRACKET
25	25	SCREW
26	26	SPRING
27	27	SCREW
28	28	BRACKET
29	29	SCREW

Page 36

Pegasus EX3200 Series parts on page 36

Ref	Part number	Part name	Qty
1	1	BRACKET
2	2	SCREW
3	3	SHAFT
4	4	SCREW
5	5	BRACKET
6	6	WASHER
7	7	SPRING
8	8	SCREW
9	9	WASHER
10	10	SPRING
11	11	CAP
12	12	SCREW
13	13	BRACKET
14	14	PLATE
15	15	SCREW
16	16	BRACKET
17	17	SCREW
18	18	BRACKET
19	19	SCREW
20	20	SCREW
21	21	BRACKET

Page 37 — CHAINSTITCH LOOPER DRIVE MECHANISM (2)

Pegasus EX3200 Series parts on page 37

Ref	Part number	Part name	Qty
	275031	糸道
	7019	平ネジ/M4×8
	275032	糸道パイプ
	206115	ホルダー
	275033	ブラケット
	7066	段付ネジ/M4
	210307	波座金
	7167	段付ネジ/M3
	137108	調子皿
	211388	圧縮バネ
	275034	ツマミ
	275035	糸受
	7017	平ネジ/M4×5
	275036	糸道
	7008	平ネジ/M3×4
	275039	糸道
	7008	平ネジ/M3×4
	179498-92	ルーパー糸繰り(組)
	4554	止ネジ/M3×3
	275037	板バネ
	275038	糸道

Page 38

Pegasus EX3200 Series parts on page 38

Ref	Part number	Part name	Qty
2	2	SHAFT
3	3	LEVER
4	4	GEAR
5	5	SHAFT
6	6	BEARING
7	7	SHAFT
8	8	COLLAR
9	9	SCREW
10	10	SCREW
11	11	SCREW
12	12	SHAFT
13	13	SPRING
14	14	SCREW
15	15	BRACKET
16	16	SHAFT
17	17	BEARING
18	18	WASHER
19	19	SPRING
20	20	SHAFT
21	21	LEVER
22	22	LEVER
23	23	BRACKET
24	24	BRACKET
25	25	SCREW
26	26	LEVER
27	27	SCREW
28	28	SHAFT
29	29	COLLAR
30	30	SPRING
31	31	SHAFT
32	32	SCREW
33	33	BRACKET
34	34	WASHER
35	35	SCREW
36	36	WASHER
37	37	BRACKET
38	38	SCREW
39	39	SCREW
40	40	SCREW
41	41	WASHER
42	42	SPRING
43	43	WASHER
44	44	SHAFT

Page 39 — FEED MECHANISM (1)

Pegasus EX3200 Series parts on page 39

Ref	Part number	Part name	Qty
	272500	ロッド
	271001	ピン
	4538	止ネジ/M4×6
	240012	ニードルベアリング
	272501	エキセン
	210129	案内/送リエキセン
	210130	板バネ
	4535	止ネジ/M3×4
	4535	止ネジ/M3×4
	272506-91	調節台
	4514	止ネジ/M5×5
	272504-91	エキセン(組)
	272503	ネジリバネ
	7038	平ネジ/M2
	272502	ラチェット
	272509	プッシュボタン
	240315	ガスケット
	240314	座金
	240317	圧縮バネ
	200555	止メ輪
	272529	リンク
	7058	段付ネジ/M5
	202522	止メ輪
	272530A92	レバー
	4533	平ネジ
	272532	レバー
	7161	段付ネジ/M5
	272533A	軸
	204185	Oリング
	272534	ネジリバネ
	272535	調節板
	7021	平ネジ/M4×12
	240321	スペーサー
	179202-25	ナット
	7059	段付ネジ/4.5
	211301	皿バネ
	252658	ストッパー
	7018	平ネジ/M4×6
	303448	座金
	272538A	調節棒
	240322	シール
	200555	止メ輪
	210533	圧縮バネ
	272539A	段付ピン

Page 40

Pegasus EX3200 Series parts on page 40

Ref	Part number	Part name	Qty
	EX5214-54/445	EX5214H-55 を除く
	EX5214-54/445	EX5214H-55

Page 41 — FEED MECHANISM (2)

Pegasus EX3200 Series parts on page 41

Ref	Part number	Part name	Qty
	272516	軸	1
	205061	止メ輪	1
	208173	栓	1
	240311	座金	2
	272510-91	クランク	1
	272511	クランク本体	1
	4534	平ネジ/M6×14	1
	272512	クランクピン	1
	272513	クランクピン	1
	7010	平ネジ/M3×6	2
	272518	角駒	1
	272514-92	クランク	1
	4533	平ネジ/M6×12	1
	272515	ピン	1
	4805	六角ナット/M5	1
	240062	座金	1
	272525	段付ピン	1
	7238	止ネジ	1
	240318	ガスケット	1
	240319	止メ輪	1
	201022	Oリング	1
	272526	角駒	1
	240303	カラー	2
	4543	止ネジ/M4×4	2
	272517	リンク	1
	179160-05	ブッシュ	1
	7056	六角ネジ/M5×13	1
	240039	座金	1
	272527	主送り台	1
	XXXXXX	主送り歯(組)	1
	XXXXXX	主送り歯	1
	XXXXXX	補助送り歯	1
	7010	平ネジ/M3×6	1
	7013	平ネジ/M3.5×8	1
	272528	差動送り台	1
	XXXXXX	差動送り歯	1
	7013	平ネジ/M3.5×8	1
	272524	角駒	1
	272519	送り台案内	1
	7110	平ネジ/M4×9	2
	272520	案内(左)/送り台	1
	7110	平ネジ/M4×9	2
	272523	油切り案内	1
	272521	油切り	2
	272522	油切り案内	1
	4573	平ネジ/M4×5	2

Page 42

Pegasus EX3200 Series parts on page 42

Ref	Part number	Part name	Qty
	1	EX3100H Series
	2	EX5200 Series
	3	EX3200 Series
	4	EX5200 Series
	5	EX3200 Series
	6	EX5200 Series
	7	EX3200 Series
	8	EX5200 Series
	9	EX3200 Series
	10	EX5200 Series
	11	EX3200 Series
	12	EX5200 Series
	13	EX3200 Series
	14	EX5200(H)Series
	15	EX3200(H)Series
	16	EX5200 Series
	17	EX3200 Series
	18	EX5200 Series
	19	EX5200(H)Series
	20	EX3200(H)Series
	21	EX5200 Series
	22	EX3200 Series
	23	EX5200 Series
	24	EX3200 Series
	25	EX5200(H)Series
	26	EX3200(H)Series
	27	EX3215-3216-04 EX3215H-3216H-05 EX5204-24 EX5214-24,54/445 EX5214H-55
	28	EX5200 Series EX5204-24,82,92M1 EX5214-24,54/445,83,84 EX5214H-55 を除く Except EX5204-24,82,92M1 EX5214-24,54/445,83,84 EX5214H-55
	29	EX3200 Series EX3215-3216-04 EX3215H-3216H-05 EX3244-04 を除く Except EX3215-3216-04 EX3215H-3216H-05 EX3244-04
	30	EX5200 Series
	31	EX3200 Series
	32	EX5200 Series
	33	EX3200 Series
	34	EX5200 Series
	35	EX3200 Series
	36	EX5200 Series
	37	EX3200 Series
	38	EX5200 Series

Page 43 — KNIFE DRIVE MECHANISM

Pegasus EX3200 Series parts on page 43

Ref	Part number	Part name	Qty
1	273000-92	ロッド	1
2	7023	平ネジ / M4×16	2
3	273001-92	クランク	1
4	273002-92	クランク	1
5	4533	平ネジ	1
6	271001	ピン	1
7	4538	止ネジ / M4×6	1
8	240235-92	カラー	1
9	4547	止ネジ / M6×5	1
10	273003	上メス台	1
11	273004	上メス台	1
12	308036	ピン付ネジ	1
13	273006	案内ピン	1
14	179712-05	上メス抱キ	1
15	179713-05	上メス抱キ	1
16	7021	平ネジ / M4×12	1
17	XXXXXX	上メス	1
18	7013	平ネジ / M3.5×8	1
19	210756	角メス抱キ	1
20	210757	角メス抱キ	1
21	XXXXXX	角メス	1
22	1227	平ネジ / C3×3.7	1
23	210758	角メス押エ	1
24	179341-15	切屑押シ	1
25	7023	平ネジ / M4×16	1
26	7213	平ネジ / M4×16	1
27	300248	座金	1
28	273008	下メス台	1
29	273009	下メス台	1
30	7019	平ネジ / M4×10	1
31	273010	案内/下メス台	1
32	7019	平ネジ / M4×10	2
33	240324	圧縮バネ	1
34	273007	当板	1
35	7019	平ネジ / M4×10	1
36	XXXXXX	下メス/厚メス	1
37	273012	下メス押エ	1
38	7173	六角ネジ / M5×8	1

Page 44

Pegasus EX3200 Series parts on page 44

Ref	Part number	Part name	Qty
	EX5214-54,84	EX5214H-55

Page 45

Pegasus EX3200 Series parts on page 45

Ref	Part number	Part name	Qty
1	274007	レバー	1
2	7060	段付ネジ/ M10	1
3	274008	ネジリバネ	1
4	274009	ストッパー	1
5	7020	平ネジ/M4×10	2
6	7175	平ネジ/M5×24	1
7	4805	六角ナット/M5	1
8	274006	リンク	1
9	274004	レバー	1
10	274003-92	カラー	1
11	4534	平ネジ/M6×14	1
12	274005	ネジリバネ	1
13	274002	ブッシュ	1
14	7020	平ネジ/M4×10	1
15	274001	軸/押エ台	1
16	274000-B	押エ台	1
17	208549	平行ピン	1
18	4543	止ネジ	1
19	202451	チェーンカッター	1
20	7008	平ネジ/C3×5	1
21	274018-92B	ホルダー	1
22	7013	平ネジ/M3.5×8	1
23	274033	フィンガーガード	1
24	274020	ストッパー	1
25	7009	平ネジ/M3×4	1
26	7008	平ネジ/C3×5	1
27	274019	板バネ	1
28	5089	平ネジ	1
29	274011-91	押エ棒	1
30	208773A	圧縮バネ	1
31	274014	調節ネジ	1
32	274015	ナット	1
33	274016	レバー	1
34	7171	段付ネジ/M4	1
35	274017	ネジリバネ	1
36	274010	ストッパー	1
37	7019	平ネジ/M4×10	1
38	274039	レバー	1
39	274040	ストッパー	1

Page 46

Pegasus EX3200 Series parts on page 46

Ref	Part number	Part name	Qty
1	1	SHAFT HOUSING
2	2	SHAFT
3	3	SCREW
4	4	BRACKET
5	5	SHAFT
6	6	GEAR
7	7	PLATE
8	8	HOUSING
9	9	CLAMP
10	10	SCREW
11	11	SCREW
12	12	HOUSING
13	13	SCREW
14	14	FILTER
15	15	COVER
16	16	COVER
17	17	COVER
18	18	JOINT
19	19	SCREW
20	20	JOINT
21	21	SHAFT
22	22	JOINT
23	23	SCREW
24	24	JOINT
25	25	SHAFT
27	27	JOINT
28	28	SCREW
29	29	SCREW
30	30	SHAFT
31	31	BRACKET
32	32	SCREW
33	33	SCREW
34	34	SHAFT
35	35	SHAFT
36	36	SHAFT
37	37	SCREW
38	38	WASHER
39	39	SCREW

Page 47 — LUBRICATION MECHANISM (1)

Pegasus EX3200 Series parts on page 47

Ref	Part number	Part name	Qty
	274505-91	ポンプ
	211618	ウォームホイール
	5060	止ネジ/C8×4.5
	274506	ポンプ本体
	212978-91	ローター(内)軸
	212981	ローター(外)
	274508	側板
	213578	フィルター
	213579	当金
	7013	平ネジ/M3.5×8
	4529	平ネジ/M4×16
	274509	タンク
	7021	平ネジ/M4×12
	206233	エレメント
	274510	蓋
	7018	平ネジ/M4×6
	240307	Oリング
	200136	継手
	240328	継手ネジ
	202199	クランプ
	240327	チューブ
	200136	継手
	240328	継手ネジ
	202199	クランプ
	240135	チューブ
	200136	継手
	240328	継手ネジ
	202199	クランプ
	240334	チューブ
	274512	継手
	240020	Oリング
	7021	平ネジ/M4×12
	303448	座金
	274515-91	油分配器(組)
	274511	油分配器
	210214	栓
	7023	平ネジ/M4×16
	303448	座金
	240328	継手ネジ

Page 48

Pegasus EX3200 Series parts on page 48

Ref	Part number	Part name	Qty
23	23	23
25	25	25
24	24	24
27	27	27
29	29	29
30	30	30
31	31	31
32	32	32
38	38	38
37	37	37
39	39	39
35	35	35
34	34	34
40	40	40
16	16	16
19	19	19
17	17	17
20	20	20
21	21	21
18	18	18
17	17	17
19	19	19
15	15	15
1	1	1
2	2	2
3	3	3
4	4	4
6	6	6
5	5	5
13	13	13
8	8	8
7	7	7
10	10	10
9	9	9
11	11	11
12	12	12

Page 49 — LUBRICATION MECHANISM (2)

Pegasus EX3200 Series parts on page 49

Ref	Part number	Part name	Qty
	274502	オイルゲージ
	230043	Oリング
	210193	オイル指示(組)
	210510	オイル指示受
	7021	平ネジ/M4×12
	303448	座金
	274503-91	オイルパン(組)
	274500	オイルパン
	5138B	平ネジ/H11×12
	202287A	ガスケット
	4531	六角穴ボルト/M5×12
	240339	座金
	274501	ガスケット
	274504	ウォーム
	4514	止ネジ/M5×5
	274517A91	パイプ(組)
	274514	パイプ
	202175	給油紐
	240038	栓
	4543	止ネジ/M4×4
	274517-91	パイプ(組)
	274516-91	パイプ(組)
	274513	パイプ
	202175	給油紐
	240097	栓
	4543	止ネジ/M4×4
	274523-91	継手(組)
	274518	継手
	274522	フェルト
	204185	Oリング
	7019	平ネジ/M4×8
	202175	給油紐
	274529	フェルト
	274530	カバー
	7192	段付ネジ/M4
	274551-91	継手(組)
	274552-91	継手
	274556	フェルト
	204185	Oリング
	4543	止ネジ/M4×4

Page 50

Pegasus EX3200 Series parts on page 50

Ref	Part number	Part name	Qty
	3	EX5200(H) Series
	4	EX3200 Series
	5	EX3200(H) Series
	6	EX5200(H) Series
	7	EX3200(H) Series
	8
	9
	10
	11
	12
	13
	14
	15
	16
	17
	18
	19
	20
	21
	22
	23
	24	EX3244-03, 04 を除く Except EX3244-03, 04
	25

Page 51 — H.R.装置

Pegasus EX3200 Series parts on page 51

Ref	Part number	Part name	Qty
	275500	シリコンタンク(上)
	275501	蓋
	275503	フェルト
	275508	フェルト
	275546	フェルト
	275502	糸案内
	275507	糸案内
	7020	平ネジ/M4×10
	275504	シリコンタンク(下)
	275505	蓋
	7020	平ネジ/M4×10
	303448	座金
	202175	給油紐
	240331	チューブ
	200155	クランプ
	275506	針冷却器
	7021	平ネジ/M4×12
	210214	栓
	204466	給油フェルト
	210766	止ピン
	275509	針冷却器
	7019	平ネジ/M4×10
	210214	栓
	204466	給油フェルト
	210766	止ピン

Page 52

Pegasus EX3200 Series parts on page 52

Ref	Part number	Part name	Qty
1	1	BOLT
2	2	WASHER
3	3	NUT
4	4	NUT
5	5	BRACKET
6	6	ROD
7	7	NUT
8	8	WASHER
9	9	DISC
10	10	DISC
11	11	CAP
12	12	BOLT
13	13	WASHER
14	14	BOLT
15	15	POST
16	16	CLAMP
17	17	BOLT
18	18	BRACKET
19	19	BRACKET
20	20	BOLT
21	21	BOLT
22	22	ROD
23	23	WASHER
24	24	NUT
25	25	BOLT
26	26	BRACKET
27	27	BOLT
28	28	ARM
29	29	BRACKET
30	30	ARM
31	31	ARM
32	32	CLAMP
33	33	BOLT
34	34	ARM
35	35	ARM
36	36	NUT
37	37	BOLT
38	38	BOLT
39	39	COLLAR

Page 53 — THREAD STAND

Pegasus EX3200 Series parts on page 53

Ref	Part number	Part name	Qty
	486-9C	糸立(組)(6本立)
	486A9C	糸立(組)(5本立)
	486B9C	糸立(組)(4本立)
	486C9C	糸立(組)(3本立)
1	503-CA	スタンド棒(下)
2	509	座金
3	5476	六角ナット
4	505-CA	ブラケット(3本立)
5	505ACA	ブラケット(2本立)
6	380A	糸立棒
7	201252	バネ座金
8	4803	六角ナット/M4
9	381-CA	受皿
10	507	ウレタン
11	382-CA	ユ止メ
12	7102	六角ネジ/M6×32
13	512	座金
14	4022	平ネジ/M6×10
15	502-CA	スタンド棒(上)
16	504-CA	ジョイント
17	4021	平ネジ/M5×16
18	4805	六角ナット/M5
19	383-CA	ブラケット
20	4014	平ネジ/M4×25
21	4803	六角ナット/M4
22	384	糸道棒
23	4012	平ネジ/M4×12
24	4803	六角ナット/M4
25	233-CA	ホルダー
26	4012	平ネジ/M4×12
27	4803	六角ナット/M4
28	293	糸道棒(6本立)
29	293A	糸道棒(5本立)
30	293B	糸道棒(4本立)
31	293C	糸道棒(3本立)
32	4012	平ネジ/M4×12
33	4803	六角ナット/M4
34	527-CA	ブラケット(3本立)
35	527ACA	ブラケット(2本立)
36	506	糸道
37	4117	止ネジ/M5×12
38	4805	六角ナット/M5
39	386	キャップ

Page 54

Pegasus EX3200 Series parts on page 54

Ref	Part number	Part name	Qty
1	1	Base
2	2	Knob
3	3	Screw
4	4	Special washers for a table 35mm thick
5	5	Screw
6	6	Washer
7	7	Bracket
8	8	Bracket
9	9	Screw
10	10	Bracket
11	11	Screw
12	12	Washer
13	13	Washer
14	14	Washer

Page 55 — PARTS FOR SEMI-SUBMERGED INSTALLATION

Pegasus EX3200 Series parts on page 55

Ref	Part number	Part name	Qty
	276001	据付板
	179483-05	クッションゴム
	206336	半沈用ナツ
	205467	スペーサー
	4575	ボルト/M8×45
	240304	ワッシャー
	276002-UA	シューター(上)
	276003-UA	シューター(下)
	4904	木ネジ(皿)/3.5
	276004	取付板
	4109	平ネジ/M4×10
	240104	座金
	206337	座金
	201447	バネ座金

Page 56

Pegasus EX3200 Series parts on page 56

Ref	Part number	Part name	Qty
3	3	Screw
4	4	Screw
5	5	Washer
6	6	Nut
7	7	Base Plate
8	8	Screw
9	9	Washer
10	10	Plate
11	11	Screw
12	12	Screw
13	13	Washer
14	14	Washer
15	15	Screw
16	16	Washer
17	17	Screw
18	18	Washer
19	19	Cover
20	20	Cover
21	21	Bracket
22	22	Bracket
1	1	Support
2	2	Support

Page 57 — 全沈床式据付付属品

Pegasus EX3200 Series parts on page 57

Ref	Part number	Part name	Qty
	276001	据付板
	179483-05	クッションゴム
	7237	ボルト
	7236	ボルト
	202700	座金
	4816	六角ナット/M10
	276012	補助板
	4575	ボルト/M8×45
	240304	歯付座金
	4808	六角ナット/M8
	276013	補助板
	4575	ボルト/M8×45
	240304	歯付座金
	4808	六角ナット/M8
	4512	平ネジ/M8×55
	276014	取付板
	4109	平ネジ/M4×10
	240104	座金
	276002-UA	シューター(上)
	276003-UA	シューター(下)
	7013	平ネジ/M3.5×8
	167066	座金

Page 58 — 地縫い (Plain seaming)

Pegasus EX3200 Series parts on page 58

Ref	Part number	Part name	Qty
7	EX5204-01,02	EX5212-02
23	EX5214-01,03,03CM03,M03C3	EX3244-03
11	EX3215-3216-01,02,03	EX3244-03
35	EX3215-3216-01A,02A	SW=3・4mm
36	EX3215-3216-01A,02A	SW=5・6mm

Page 59 — SPECIFIC PARTS (1)

Pegasus EX3200 Series parts on page 59

Ref	Part number	Part name	Qty
1	XXXXXX	押工
2	XXXXXX	押工爪
3	277126	補助押工
4	1231	平ネジ/C1×3.4
5	211600	押工補助板
6	5030	平ネジ/C1×2.3
7	271014-92	クランク
8	4533	平ネジ
9	XXXXXX	押工(組)
10	7013	平ネジ/M3.5×8
11	208958-B	ピン付ネジ/C3
12	212499-B	段付ピン
13	5409	六角ナット/C3
14	212498	ラッチ
15	274028	ネジリバネ
16	3153	ナット
17	208531	補助押工
18	5030	平ネジ/C1×2.3
19	274022	ネジリバネ
20	7009	平ネジ/M3×4
21	274026	フィンガーガード
22	7008	平ネジ/C3×5
23	275528	フェルト
24	274021-92	ホルダー
25	7013	平ネジ/M3.5×8
26	274023	ネジリバネ
27	7009	平ネジ/M3×4
28	274025	フィンガーガード
29	7008	平ネジ/C3×5
30	XXXXXX	押工
31	211919	段付ピン
32	211918	ネジリバネ
33	3150	六角ナット/C1
34	211920	スプリングピン
35	211915	押工爪
36	211916	押工爪
37	211917	取付板
38	5089	平ネジ
39	300248	座金

Page 60

Pegasus EX3200 Series parts on page 60

Ref	Part number	Part name	Qty
1	1	Base
2	2	Guide
3	3	Screw
4	4	Bracket
5	5	Presser Foot
6	6	Screw
7	7	Base
8	8	Bracket
9	9	Lever
10	10	Screw
11	11	Washer
12	12	Screw
13	13	Pin
14	14	Screw
15	15	Screw
16	16	Link
17	17	Screw
18	18	Screw
19	19	Washer
20	20	Blind Hemmer
21	21	Base
22	22	Screw
23	23	Washer
24	24	Base
25	25	Screw
26	26	Screw
27	27	Screw
28	28	Screw
29	29	Screw
30	30	Washer
31	31	Lever
32	32	Screw
33	33	Guide
34	34	Guide
35	35	Screw

Page 61 — SPECIFIC PARTS (2)

Pegasus EX3200 Series parts on page 61

Ref	Part number	Part name	Qty
	XXXXXX	押工	1
	211994	補助押工	1
	1333	平ネジ/C1×4	1
	XXXXXX	押工爪	1
	211600	押工補助板	1
	5030	平ネジ/C1×2.3	1
	210685	定規ブラケット(組)	1
	210680	定規ブラケット	1
	210681	ヒンジ/定規ブラケット	1
	5184	段付ネジ/C5	1
	201191	皿バネ	1
	3044	六角ナット/C5	1
	210682	ストッパー	1
	5053	平ネジ/C4×4.8	1
	210683	段付ピン	1
	210684	板バネ	1
	2906	平ネジ/C4×2.6	1
	7020	平ネジ/M4×10	1
	201252	バネ座金	1
	212265	裾引定規台(組)	1
	210690	ブラケット	1
	5088	六角ネジ/C4×7.5	2
	167066	座金	2
	212266	裾引定規台	1
	5057	平ネジ/C3×5	1
	210689	調節板	1
	5157	平ネジ/C3×4.5	2
	5363	調節ネジ	1
	2905	平ネジ/C5×4.5	1
	137142	座金	1
	212267	ストッパー	1
	1206	平ネジ/C4×5.3	1
	212268A91	定規羽根(36MM)	1
	205835A	補助羽根	1
	5299	平ネジ/C3×2.6	1

Page 62

Pegasus EX3200 Series parts on page 62

Ref	Part number	Part name	Qty
	EX3215-3216-04	Plain seaming
	EX3215H-3216H-05	Plain seaming
13	EX3215-3216-04	Tractor presser foot
24	EX3215-3216-04	Spring
23	EX3215H-3216H-05	Spring
28	EX3215-3216-04	Parts
29	EX3215H-3216H-05	Parts

Page 63 — SPECIFIC PARTS (3)

Pegasus EX3200 Series parts on page 63

Ref	Part number	Part name	Qty
	210530A9U	糸調子(組)	1
	208447-UA	調子ナット	1
	208448	ラチェット	1
	208450-UA	受皿	1
	210319	調子皿	2
	208449	フェルト	1
	5082A	調子棒/C5	1
	201086A	圧縮バネ(中)	1
	210531-9U	糸調子(組)	1
	201068	圧縮バネ(弱)	1
	XXXXXX	押エ(組)	1
	7013	平ネジ/M3.5×8	1
	208958-B	ピン付ネジ	3
	277108	補助押エ	1
	202875	座金	1
	5157	平ネジ/C3×4.5	1
	274024	ネジリバネ	1
	7166	段付ネジ/M3	1
	274034	ネジリバネ	1
	7009	平ネジ/M3×4	1
	274027	フィンガーガード	1
	7008	平ネジ/C3×5	1
	240347	圧縮バネ	1
	210337A	圧縮バネ	1
	273009A	下メス台	1
	275030A	糸道	1
	240302	スペーサー	1
	270500C	クランク軸	1
	270512B	クランク軸	1
	7151	止ネジ	5

Page 64

Pegasus EX3200 Series parts on page 64

Ref	Part number	Part name	Qty
1	1	1
1	1	1
2	2	2
3	3	3
4	4	4
5	5	5
6	6	6
7	7	7
7	7	7
8	8	8
9	9	9
9	9	9
10	10	10
11	11	11
12	12	12
13	13	13
14	14	14
15	15	15
16	16	16
17	17	17
18	18	18
19	19	19
20	20	20
21	21	21
22	22	22
23	23	23
24	24	24

Page 65 — SPECIFIC PARTS (4)

Pegasus EX3200 Series parts on page 65

Ref	Part number	Part name	Qty
	210530A9U	糸調子(組) THREAD TENSION COMPLETE	1
	208447-UA	調子ナット POST NUT	1
	208448	ラチェット SPRING BUSHING	1
	208450-UA	受皿 CUP	1
	210319	調子皿 TENSION DISC	2
	208449	フェルト FELT	1
	5082A	調子棒/C5 SCREW STUD	1
	201086A	圧縮バネ(中) SPRING (MEDIUM)	1
	210531-9U	糸調子(組) THREAD TENSION COMPLETE	1
	201068	圧縮バネ(弱) SPRING (LIGHT)	1
	XXXXXX	押エ(組) PRESSER FOOT COMPLETE	1
	7013	平ネジ/M3.5×8 SCREW	1
	208958-B	ピン付ネジ/C3 SCREW	3
	274024	ネジリバネ SPRING	1
	7166	段付ネジ/M3 SCREW	1
	274027	フィンガーガード FINGER GUARD	1
	7008	平ネジ/C3×5 SCREW	1
	210337A	圧縮バネ SPRING	1
	273009A	下メス台 LOWER KNIFE HOLDER	1
	275030A	糸道 THREAD EYELET	1
	275528	フェルト FELT	1
	240302	スペーサー SPACER	1
	277500C	クランク軸 SHAFT	1
	7151	止ネジ SCREW	5

Page 66

Pegasus EX3200 Series parts on page 66

Ref	Part number	Part name	Qty
1	1	BASE
2	2	GUIDE
3	3	GUIDE
4	4	SCREW
5	5	WASHER
6	6	GUIDE
7	7	SPRING
8	8	SCREW
9	9	SPRING
10	10	GUIDE
11	11	GUIDE
12	12	SCREW
13	13	WASHER
14	14	BLIND HEMMING
15	15	GUIDE
16	16	SCREW
17	17	WASHER
18	18	GUIDE
19	19	GUIDE
20	20	GUIDE
21	21	GUIDE
22	22	ADJUSTING SCREW
23	23	SCREW
24	24	WASHER
25	25	GUIDE
26	26	GUIDE
27	27	40mm
28	28	GUIDE
29	29	SCREW
30	30	GUIDE
31	31	GUIDE
32	32	GUIDE
33	33	GUIDE
34	34	GUIDE
35	35	SCREW
36	36	WASHER

Page 67 — 専用部品(5)

Pegasus EX3200 Series parts on page 67

Ref	Part number	Part name	Qty
	210685	定規ブラケット (組)
	210680	定規ブラケット
	210681	ヒンジ/定規ブラケット
	5184	段付ネジ/C5
	201191	皿バネ
	3044	六角ナット/C5
	210682	ストッパー/ヒンジ
	5053	平ネジ/C4×4.8
	210683	段付ピン
	210684	板バネ
	2906	平ネジ/C4×2.6
	7020	平ネジ/M4×10
	201252	バネ座金
	210691	裾引定規台(組)
	210690	ブラケット
	5088	六角ネジ/C4×7.5
	167066	座金
	205361	裾引定規台
	5057	平ネジ/C3×5
	210689	調節板
	5157	平ネジ/C3×4.5
	2430	調節ネジ/C3
	2905	平ネジ/C5×4.5
	137142	座金
	210692	ストッパー
	1206	平ネジ/C4×5.3
	201211C91	定規羽根(40MM)
	205835	補助羽根
	5299	平ネジ/C3×2.6
	303312A	羽根駒
	303313	板バネ
	XXXXXX	押エ
	XXXXXX	押エ爪
	210584	押工補助板
	5030	平ネジ/C1×2.3
	210585	座金

Page 68

Pegasus EX3200 Series parts on page 68

Ref	Part number	Part name	Qty
1	1	Base Plate
2	2	Cover
3	3	Guide
4	4	Screw
5	5	Cover
6	6	Screw
1	1	Base Plate
2	2	Cover
4	4	Screw
5	5	Cover
6	6	Screw
7	7	Guide
8	8	Roller
8	8	Roller
10	10	Washer
11	11	Roller
12	12	Washer
13	13	Washer
14	14	Screw
14	14	Screw
15	15	Spring
16	16	Roller
16	16	Roller
17	17	Spring
18	18	Roller
19	19	Guide
20	20	Base Plate
21	21	Cover
22	22	Guide
23	23	Screw
24	24	Cover
25	25	Screw

Page 69 — SPECIFIC PARTS (6)

Pegasus EX3200 Series parts on page 69

Ref	Part number	Part name	Qty
	XXXXXX	押工	1
	XXXXXX	押工爪	1
	277126	補助押工	1
	1231	平ネジ/C1×3.4	1
	211600	押工補助板	1
	5030	平ネジ/C1×2.3	1
	277128	補助押工	1
	210530A9U	糸調子(組)	1
	208447-UA	調子ナット	1
	208448	ラチェット	1
	208450-UA	受皿	1
	210319	調子皿	2
	208449	フェルト	1
	5082A	調子棒/C5	1
	201086A	圧縮バネ(中)	1
	210531-9U	糸調子(組)	1
	201068	圧縮バネ(弱)	1
	240302	スペーサー	1
	273008A	下メス台	1
	XXXXXX	押工	1
	XXXXXX	押工爪	1
	277126	補助押工	1
	1231	平ネジ/C1×3.4	1
	211600	押工補助板	1
	5030	平ネジ/C1×2.3	1

Page 70 — ヒダ取り (Shirring)

Pegasus EX3200 Series parts on page 70

Ref	Part number	Part name	Qty
1	1	Shirring
2	2	SCREW
3	3	SCREW
4	4	SCREW
5	5	SCREW
6	6	SCREW
7	7	SCREW
8	8	SCREW
9	9	SCREW
10	10	WASHER
11	11	SCREW
12	12	SCREW
13	13	SCREW
14	14	SCREW
15	15	SCREW
16	16	PIN
17	17	SPRING
18	18	SCREW
19	19	COLLAR
20	20	SPRING
21	21	WASHER
22	22	SCREW
23	23	SCREW
24	24	HANDLE
25	25	NUT
26	26	BRACKET
27	27	SPRING
28	28	SHAFT
29	29	SCREW
30	30	WASHER
31	31	SPRING
32	32	SCREW
33	33	SCREW
34	34	SCREW
35	35	SCREW
36	36	SPRING
37	37	SPRING
38	38	SCREW
39	39	WASHER
40	40	WASHER
41	41	SCREW
42	42	COLLAR
43	43	SCREW
44	44	BRACKET
45	45	SCREW
46	46	SCREW
47	47	SCREW
48	48	SCREW
49	49	WASHER
50	50	EX5214-43P1,43P2
51	51	EX3215-3216-42,43
52	52	SCREW
53	53	BASE
54	54	SCREW
55	55	SCREW
56	56	SHIRRING
57	57	SCREW
58	58	WASHER

Page 71 — SPECIFIC PARTS (7)

Pegasus EX3200 Series parts on page 71

Ref	Part number	Part name	Qty
1	275514-91	SHIRRING ATTACHMENT COMPLETE	1
2	275515	BRACKET	1
3	7022	SCREW	1
4	240332	SPACER	1
5	7191	SCREW	1
6	210947	FLAT SPRING	1
7	1206	SCREW	2
8	275516	BRACKET	1
9	7160	SCREW	1
10	204888	SPRING	2
11	4806	NUT	1
12	210945	STOPPER	1
13	5328	SCREW	1
14	210946	FLAT SPRING	1
15	1206	SCREW	1
16	275517-92	SPRING GUIDE	1
17	7021	SCREW	1
18	208447-UA	POST NUT	1
19	208448	SPRING BUSHING	1
20	210940	SPRING	1
21	204091	WASHER	1
22	5082A	SCREW STUD	1
23	210944	WASHER	1
24	275518	LEVER	1
25	4806	NUT	1
26	275520	BRACKET	1
27	240320	SPRING	1
28	275521	SHAFT	1
29	202522	RING	1
30	207045	WASHER	1
31	240323	SPRING	1
32	206225	COLLAR	1
33	1457-1	SCREW	1
34	210955	WASHER	1
35	5029	SCREW	1
36	212435	CABLE	1
37	212436	CABLE SUPPORT	1
38	7099	SCREW	2
39	202433	WASHER	1
40	4806	NUT	2
41	275522	LATCH	1
42	179765-15	NUT	2
43	7164	SCREW	1
44	240104	WASHER	1
45	275523	BRACKET	1
46	7022	SCREW	2
47	210961	CLOTH GUIDE	1
48	7012	SCREW	1
49	137906	WASHER	1
50	275524	BLADE	1
51	275525	BLADE	1
52	200098	WASHER	1
53	270035B	CLOTH PLATE	1
54	210962	BRACKET/BINDER	1
55	5210	SCREW	2
56	211885	BINDER (20)	1
57	1202	SCREW	2
58	167066	WASHER	2

Page 72

Pegasus EX3200 Series parts on page 72

Ref	Part number	Part name	Qty
4	EX5214-43	Shirring
3	EX5214-43	Shirring
2	EX5214-43	Shirring
1	EX5214-43	Shirring
5	EX3215-3216-42,43	Shirring
6	EX3215-3216-42,43	Shirring
8	EX3215-3216-42,43	Shirring
9	EX3215-3216-42,43	Shirring
7	EX3215-3216-42,43	Shirring
10	EX3215-3216-42,43	Shirring
11	EX3215-3216-42,43	Shirring
12	EX3215-3216-42,43	Shirring
13	EX3215-3216-42,43	Shirring
14	EX3215-3216-42,43	Shirring
15	EX3215-3216-42,43	Shirring
16	EX3215-3216-42,43	Shirring
17	EX3215-3216-42,43	Shirring
18	EX3215-3216-42,43	Shirring
21	EX5214-43P1,43P2	Piping
20	EX5214-43P1,43P2	Piping
19	EX5214-43P1,43P2	Piping
22	EX5214-43P1,43P2	Piping
23	EX5214-43P1,43P2	Piping
24	EX5214-43P1,43P2	Piping
25	EX5214-43P1,43P2	Piping
26	EX5214-43P1,43P2	Piping
27	EX5214-43P1,43P2	Piping
28	EX5214-43P1,43P2	Piping
29	EX5214-43P1,43P2	Piping
30	EX5214-43P1,43P2	Piping
31	EX5214-43P1,43P2	Piping
32	EX5214-43P1,43P2	Piping
33	EX5214-43P1,43P2	Piping

Page 73 — 専用部品(8)

Pegasus EX3200 Series parts on page 73

Ref	Part number	Part name	Qty
1	XXXXXX	押工	1
2	211600	押工 補助板	1
3	5030	平ネジ/C1×2.3	1
4	274025	フィンガーガード	1
5	XXXXXX	押工	1
6	7013	平ネジ/M3.5×8	1
7	208958-B	ピン付ネジ/C3	1
8	212499-B	段付ピン	1
9	5409	六角ナット	1
10	212498	ラッチ	1
11	274028	ネジリバネ	1
12	3153	ナット	1
13	208532	補助押工(ヒダ用)	1
14	5030	平ネジ/C1×2.3	1
15	274022	ネジリバネ	1
16	7009	平ネジ/M3×4	1
17	274026	フィンガーガード	1
18	7008	平ネジ/C3×5	1
19	XXXXXX	押工	1
20	202588	座金	1
21	274025	フィンガーガード	1
22	413	テープ通シ具	1
23	403-9S	テープガイド(組)	1
24	406	フェルト	1
25	404	カノコ台	1
26	4012	平ネジ/M4×12	1
27	407	カラー	1
28	408	調節ネジ	1
29	405	取付棒	1
30	409	軸	1
31	4818	六角ナット	1
32	410-JA	ブラケット	1
33	4908	木ネジ(皿)/4.5	3

Page 74

Pegasus EX3200 Series parts on page 74

Ref	Part number	Part name	Qty
	1	U-shaped tape attachment component
	2	Screw
	3	SW=5mm
	4	SW=4mm
	5	Screw
	6	Bracket component
	7	Bracket component
	8	Component group
	9	Screw
	10	Shaft component
	11	Shaft component
	12	Lever component
	13	Washer
	14	Nut
	15	Screw
	17	Screw
	18	Spring component
	19	Screw
	20	Lever component
	21	Screw
	22	Main component group
	23	Bracket component
	24	Screw
	25	Shaft component
	26	Washer
	27	Nut
	28	Screw
	29	Disc component
	30	Screw
	31	Disc component
	32	Washer
	33	Shaft component
	34	Shaft component
	35	Screw

Page 75 — SPECIFIC PARTS (9)

Pegasus EX3200 Series parts on page 75

Ref	Part number	Part name	Qty
	2755512	テープ 案内	1
	7180	平ネジ/M3.5×4	2
	209200	バインダー(袋縫10)	1
	208994	バインダー(袋縫8)	1
	1216	平ネジ/C4×5.5	1
	208997	案内板/バインダー	1
	270013A	前カバー(左)	1
	XXXXXX	押エ(組)	1
	7013	平ネジ/M3.5×8	1
	208958-B	ピン付ネジ	1
	212499-B	段付ピン	1
	5409	六角ナット/C3	1
	212498	ラッチ	1
	274028	ネジリバネ	1
	3153	ナット	1
	208531	補助押エ	1
	5030	平ネジ/C1×2.3	1
	274022	ネジリバネ	1
	7009	平ネジ/M3×4	1
	274026	フィンガーガード	1
	7008	平ネジ/C3×5	1
	337	テープ台(組)	1
	344	ブラケット	1
	4911	木ネジ(平)/4.1	2
	341	軸	1
	189	座金	1
	303067	バネ座金	1
	4805	六角ナット/M5	1
	338	カノコ台	1
	339	段付ネジ	1
	340	カノコ台	1
	467	バネ受ケ	1
	343	圧縮バネ	1
	468	カラー	1
	339	段付ネジ	1

Page 76

Pegasus EX3200 Series parts on page 76

Ref	Part number	Part name	Qty
	1	Attaching tape
	2	Attaching tape
	3	Screw
	4	Washer
	5	Bracket
	6	Bracket
	7	Screw
	8	Washer
	9	Bracket
	10	Bracket
	11	Bracket
	12	Screw

Page 77 — SPECIFIC PARTS (10)

Pegasus EX3200 Series parts on page 77

Ref	Part number	Part name	Qty
	275542-91	テープ 案内 (組)
	245510	テープ 案内
	7066	段付ネジ/M 4
	210307	波板座金
	275511	テープ 案内
	211267	テープ 繰り
	208735	補助押エ
	1333	平ネジ/C1×4
	XXXXXX	押エ
	XXXXXX	押工爪
	211600	押工 補助 板
	5030	平ネジ/C1×2.3

Page 78

Pegasus EX3200 Series parts on page 78

Ref	Part number	Part name	Qty
1	1	ASSY, TAPE GUIDE
2	2	COLLAR
3	3	WASHER
4	4	COLLAR
5	5	WASHER
6	6	WASHER
7	7	SCREW
8	8	SPRING
9	9	COLLAR
10	10	SPRING
11	11	SCREW
12	EX5214-54/445	ASSY, TAPE GUIDE
13	EX5214-54/445	ASSY, TAPE GUIDE
14	EX5214-54/445	ASSY, TAPE GUIDE
15	EX5214-54/445	ASSY, TAPE GUIDE

Page 79 — SPECIFIC PARTS (11)

Pegasus EX3200 Series parts on page 79

Ref	Part number	Part name	Qty
	210530A9U	糸調子(組)
	208447-UA	調子ナット
	208448	ラチェット
	208450-UA	受皿
	210319	調子皿
	208449	フェルト
	5082A	調子棒/C5
	201086A	圧縮バネ(中)
	210531-9U	糸調子(組)
	201068	圧縮バネ(弱)
	211941A	圧縮バネ
	240302	スペーサー
	272528A	差動送り台
	272501A	エキセン
	273008A	下メス台

Page 80

Pegasus EX3200 Series parts on page 80

Ref	Part number	Part name	Qty
1	1	COVER
2	2	BRACKET
3	3	COVER
4	4	BRACKET
5	5	BRACKET
6	6	BRACKET
7	7	SPRING
8	8	BRACKET
9	9	SPRING
10	10	BRACKET
11	11	BRACKET
12	12	BRACKET
13	13	SPRING
14	14	COVER
15	15	WASHER
16	16	COVER
17	17	WASHER
18	18	WASHER
19	19	SCREW
20	20	SPRING
21	21	WASHER
22	22	SPRING
23	23	SPRING
24	24	BRACKET

Page 81 — 専用部品 (12)

Pegasus EX3200 Series parts on page 81

Ref	Part number	Part name	Qty
	270037C	クロスプレート (狭巾)
	271010A	取付板(前)
	270037D	クロスプレート(狭巾)
	308093	レバー
	308085	針板ブラケット
	XXXXXX	押エ
	XXXXXX	押エ爪
	277126	補助押エ
	1231	平ネジ/C1×3.4
	XXXXXX	押エ
	XXXXXX	押エ爪
	273008B	下メス台
	210530A9U	糸調子(組)
	208447-UA	調子ナット
	208448	ラチェット
	208450-UA	受皿
	210319	調子皿
	208449	フェルト
	5082A	調子棒/C5
	201086A	圧縮バネ(中)
	210531-9U	糸調子(組)
	201068	圧縮バネ(弱)
	211941A	圧縮バネ
	XXXXXX	針板

Page 82

Pegasus EX3200 Series parts on page 82

Ref	Part number	Part name	Qty
1	1	BASE PLATE
2	2	NEEDLE PLATE
3	3	PRESSER FOOT
4	4	GUIDE
5	5	SPRING
6	6	SCREW
7	7	ARM COVER
8	8	BASE
9	9	GUIDE
10	10	BASE PLATE
11	11	GUIDE HOLDER
12	12	GUIDE
13	13	SCREW
14	14	WASHER
15	15	NUT
16	16	SPRING
17	17	SCREW
18	18	SCREW
19	19	LINK
20	20	SCREW
21	21	SCREW
22	22	WASHER
23	23	BLIND HEMMING ATTACHMENT
24	24	GUIDE
25	25	SCREW
26	26	SCREW
27	27	BASE
28	28	SPRING
29	29	GUIDE
30	30	SCREW
31	31	SCREW
32	32	SCREW
33	33	SPRING
34	34	GUIDE
35	35	SCREW
36	36	36mm
37	37	GUIDE
38	38	SCREW

Page 84

Pegasus EX3200 Series parts on page 84

Ref	Part number	Part name	Qty
1	1	Blind Hemmer
2	2	Blind Hemmer
3	3	Blind Hemmer
4	4	Screw
5	5	Washer
6	6	Blind Hemmer
7	7	Blind Hemmer
8	8	Blind Hemmer
9	9	Screw
10	10	Screw
11	11	Screw
12	12	Washer
13	13	Screw
14	14	Screw
15	15	Screw
16	16	Screw
17	17	Screw
18	18	Washer
19	19	Blind Hemmer
20	20	Blind Hemmer
21	21	Screw
22	22	Screw
23	23	Blind Hemmer
24	24	Screw
25	25	Screw
26	26	Screw
27	27	Screw
28	28	Screw
29	29	Washer
30	30	Screw
31	31	Screw
32	32	40mm
33	33	Blind Hemmer
34	34	Screw
35	35	Blind Hemmer
36	36	Blind Hemmer

Page 85 — SPECIFIC PARTS (14)

Pegasus EX3200 Series parts on page 85

Ref	Part number	Part name	Qty
	XXXXXX	押工
	XXXXXX	押工爪
	210584	押工補助板
	5030	平ネジ / C1×2.3
	210585	座金
	210685	定規ブラケット (組)
	210680	定規ブラケット
	210681	ヒンジ / 定規ブラケット
	5184	段付ネジ / C5
	201191	皿バネ
	3044	六角ナット / C5
	210682	ストッパー / ヒンジ
	5053	平ネジ / C4×4.8
	210683	段付ピン
	210684	板バネ
	2906	平ネジ / C4×2.6
	7020	平ネジ / M4×10
	201252	バネ座金
	210691	裾引定規台 (組)
	210690	ブラケット
	5088	六角ネジ / C4×7.5
	167066	座金
	205361	裾引定規台
	5057	平ネジ / C3×5
	210689	調節板
	5157	平ネジ / C3×4.5
	2430	調節ネジ / C3
	2905	平ネジ / C5×4.5
	137142	座金
	210692	ストッパー
	1206	平ネジ / C4×5.3
	201211C91	定規羽根 (40MM)
	205835	補助羽根
	5299	平ネジ / C3×2.6
	303312A	羽根駒
	303313	板バネ

Page 86 — オプション (Option)

Pegasus EX3200 Series parts on page 86

Ref	Part number	Part name	Qty
	EX5203-22	EX5203-22
	EX5212-02	EX5212-02
	EX5214-01,03,03C3,M03,M03C3,24	EX5214-01,03,03C3,M03,M03C3,24 53,53C3,M53,M53C3,54,
	EX5214H-55	EX5214H-55
	EX3215-3216-01,01A,02,02A,03,04	EX3215-3216-01,01A,02,02A,03,04
	EX3215H-3216H-05	EX3215H-3216H-05
	20	EX5200(H) Series
	21	EX3200(H) Series
1	1	1
2	2	2
3	3	3
4	4	4
5	5	5
6	6	6
7	7	7
8	8	8
9	9	9
10	10	10
11	11	11
12	12	12
13	13	13
14	14	14
15	15	15
16	16	16
17	17	17
18	18	18
19	19	19

Page 87 — 当定規

Pegasus EX3200 Series parts on page 87

Ref	Part number	Part name	Qty
	210685	CLOTH GUIDE BRACKET ASSEMBLY	1
	210680	CLOTH GUIDE BRACKET	1
	210681	HINGE/EDGE GUIDE BRACKET	1
	5184	SCREW	1
	201191	SPRING	1
	3044	NUT	1
	210682	STOPPER	1
	5053	SCREW	1
	210683	PIN	1
	210684	FLAT SPRING	1
	2906	SCREW	1
	7020	SCREW	1
	201252	SPRING WASHER	1
	210686	BRACKET COMPLETE/EDGE GUIDE	1
	210687	BRACKET/EDGE GUIDE	1
	5088	SCREW	2
	167066	WASHER	2
	1202	SCREW	1
	167066	WASHER	1
	204667	EDGE GUIDE	1
	201233A	EDGE GUIDE	1

Page 88 — GAUGE PARTS CONSTRUCTION CHART

Pegasus EX3200 Series parts on page 88

Ref	Part number	Part name	Qty
	277514P30	NGXSW 2X4
	277514P40	NGXSW 2X4
	277513P30	NGXSW 3X3
	277513P40	NGXSW 3X4
	277513P50	NGXSW 3X5
	277514R30	NGXSW 2X3
	277514R40	NGXSW 2X4
	277515R30	NGXSW 3X3
	277513R40	NGXSW 3X4
	277513R50	NGXSW 3X5
	277323-13	Part
	277324-13	Part
	277318-13	Part
	277323-16	Part
	277324-16	Part
	277318-13	Part
	277326-13	Part
	277325-13	Part
	277326-16	Part
	277325-16	Part
	277117	NGXSW 2X3
	277117	NGXSW 2X4
	277118	NGXSW 3X3
	277118	NGXSW 3X4
	277118	NGXSW 3X5

Page 89

Pegasus EX3200 Series parts on page 89

Ref	Part number	Part name	Qty
	277026-92	NG
	275030	NG
	277027-92	NG
	275030	NG
	277014A	#8
	277010	#2
	277015
	277018
	201121A	-01/222 -02/223
	210755	-01/222K -02/223K
	202295
	277007	OVERLOCK NEEDLE GUARD
	277008	CHAINSTITCH NEEDLE GUARD
	277006

Page 90 — GAUGE PARTS CONSTRUCTION CHART

Pegasus EX3200 Series parts on page 90

Ref	Part number	Part name	Qty
	277514P40	NGXSW 2×3
	277514P40	NGXSW 2×4
	277515P40	NGXSW 3×3
	277514R30	NGXSW 2×3
	277514R40	NGXSW 2×4
	277515R30	NGXSW 3×3
	277513R40	NGXSW 3×4
	277513R50	NGXSW 3×5
	277323-13
	277324-13
	277318-13
	277323-16
	277324-16
	277318-13
	277326-13
	277325-13
	277326-16
	277325-16
	211907	NGXSW 2×3
	211907	NGXSW 2×4
	211909	NGXSW 3×3
	211909	NGXSW 3×4
	211910	NGXSW 3×5

Page 91

Pegasus EX3200 Series parts on page 91

Ref	Part number	Part name	Qty
2	277026-92	275030
3	277027-92	275030
	277014A	#8
	277010	#2
	277015
	277018
	202527A
	202295

Page 92

Pegasus EX3200 Series parts on page 92

Ref	Part number	Part name	Qty
	277517	R40
	277517	R50
	277516	R50
	277516	R60
	277516	R50
	277327-16	277327-16
	277328-16	277328-16
	277318-13	277318-13
	277330-16	277330-16
	277329-16	277329-16
	277118	277118
	277119	277119

Page 93

Pegasus EX3200 Series parts on page 93

Ref	Part number	Part name	Qty
	277027-92	NG
	275030	NG
	277014B	#9
	277010A	#5
201121A	277015	-03/233 -03/333
	277028-92	NG
	275030	NG
	277014A	#8
	277010	#2
210755	277018	-03/233K -03/333K
	202295

Page 95

Pegasus EX3200 Series parts on page 95

Ref	Part number	Part name	Qty
5	277029-92	NG
	275030A	NG
	277014	#1
	277011	#3
	277014A	#8
	277017	#11
	277015	277015
	277018-C	277018-C
	277015A	277015A
	277018-C	277018-C
	277000	-04/435 -05/535
	211662	-04/435K -05/535K
	277009	277009

Page 97

Pegasus EX3200 Series parts on page 97

Ref	Part number	Part name	Qty
	277030-92	NG
	275030	NG
	277031-92	NG
	275030A	NG
	277032-92	NG
	277010A	#5
	277011	#3
	277015	277015
	277018	277018
	277015	277015
	277018-C	277018-C
	201121A	-03/333
	210755	-03/333K
	202295	202295
	277000	-04/435
	211662	-04/435K
	277009	277009

Page 98 — EX3200 Series GAUGE PARTS CONSTRUCTION CHART

Pegasus EX3200 Series parts on page 98

Ref	Part number	Part name	Qty
	277521	R40
	277521	R50
	277335	16
	277318	13
	277520	R50
	277520	R60
	277332	16
	277318	13
	277520	S50
	277520	S60
	277332	25
	277318	13
	277336	16
	277333	16
	277333	25
	277120	3x4
	277120	3x5
	277121	5x5
	277121	5x6

Page 99

Pegasus EX3200 Series parts on page 99

Ref	Part number	Part name	Qty
	277027-92	NG
	275030	NG
	277028-92	NG
	275030	NG
	277014B	NG
	277010A	NG
	277014A	NG
	277010	NG
	277015	-42/233 -43/335
	210755	-42/233K -43/335K
	202295	ヒダ取り用(薄生地) SHIRRING (LIGHT WEIGHT FABRIC)
	202295	ヒダ取り用(中厚生地) SHIRRING (MEDIUM WEIGHT FABRIC)

Page 100 — EX3200 Series

Pegasus EX3200 Series parts on page 100

Ref	Part number	Part name	Qty
	277523R40	NGXSW 3x4
	277523R50	NGXSW 3x5
	277522R50	NGXSW 5x5
	277327-16
	277328-16
	277318-13
	277330A16
	277329A16
	277118B
	277119B

Page 101 — EX3216-53/233(K)

Pegasus EX3200 Series parts on page 101

Ref	Part number	Part name	Qty
3	277027-92	NG
	275030	NG
5	277028-92	NG
	275030	NG
	277010	#2
	277015
	277018
	201121A
	210755
	202295

Page 102 — EX5200 Series

Pegasus EX3200 Series parts on page 102

Ref	Part number	Part name	Qty
3	277500P30	SW
4	277500P40	SW
5	277500P50	SW
3	277500P30	SW
4	277500P40	SW
3	277504R30	SW
4	277504R40	SW
5	277504R50	SW
3	277301-16F	SW
4	277318-13	SW
3	277304-16F	SW
4	277318-13	SW
3	201230C	SW
	210370	SW
	210371	SW
	210371	SW
	277115A	SW
	277103A	SW

Page 103

Pegasus EX3200 Series parts on page 103

Ref	Part number	Part name	Qty
	179630-92	179630-92
	275019A	275019A
	277010 #2	277010 #2
	277015	277015
	201121A	201121A
	210755	210755
	202295	202295
SW 3	201127	201127
SW 4	202295	202295
SW 5	202295	202295
	277005	277005
	277004	277004

Page 104 — EX5200 Series

Pegasus EX3200 Series parts on page 104

Ref	Part number	Part name	Qty
SW	277505P30	NGXSW 2×3
NG	277505P40	NGXSW 2×4
SW	277505R30	NGXSW 2×3
NG	277505R40	NGXSW 2×4
	277505R50	NGXSW 2×5
	277303-16F	277303-16F
	277304-16F	277304-16F
	277318-13	277318-13
	277305-16F	277305-16F
	201230C	201230C
SW	201396B	SW 3
SW	201310A	SW 4
SW	210503 #5	SW 3
SW	210374 #7	4
SW	210374 #7	5

Page 105

Pegasus EX3200 Series parts on page 105

Ref	Part number	Part name	Qty
	277022-92	NG	2
	275019B	NG
	277010B #6
	277013 #7
	277015
	201121A	-01/233 -02/333
	210755	-01/233K -02/333K
	202295

Page 106 — EX5200 Series

Pegasus EX3200 Series parts on page 106

Ref	Part number	Part name	Qty
	277505	R30
	277505	R40
	277505	R50
	277303	16F
	277304	16F
	277318	13
	277305	16F
	201230C
	210503	#5
	210374	#7
	210374	#7

Page 107

Pegasus EX3200 Series parts on page 107

Ref	Part number	Part name	Qty
	277022-92	NG
	275019B	NG
	277010A #5
	277015
	277034
	201121 A	-03-03C3/333 -M03-M03C3/333
	210755	-03-03C3/333K -M03-M03C3/333K
	202295

Page 108 — EX5200 Series

Pegasus EX3200 Series parts on page 108

Ref	Part number	Part name	Qty
3	277500P30	SW	3
4	277500P40	SW	4
5	277504R50	SW	5
6	277504R60	SW	6
7	277511S70	SW	7
8	277511S80	SW	8
3	277510S40	NGXSW	3X4
3	277510S50	NGXSW	3X5
1.6	277301-16F	277300-16F	1.6
1.25	277318-13	277300-16F	1.25
1.6	277304-16	277303A 16	1.6
1.25	277318A13	277303A 16	1.25
2.5	277310-25F	277309-25F	2.5
1.25	277318A13	277309-25F	1.25
1.6	277302-16F	277302-16F	1.6
1.6	277305-16F	277305-16F	1.6
2.5	277311-25F	277311-25F	2.5
	201152E	201152E
	202799	202799
	277110	277110
3	277115 #10	SW	3
4	277103 #11	SW	4
5	210371 #2	SW	5
6	210372 #3	SW	6
7	210372 #3	SW	7
8	210372 #3	SW	8
4	210376 #8	SW	4
5	210376 #8	SW	5

Page 109

Pegasus EX3200 Series parts on page 109

Ref	Part number	Part name	Qty
	179630-92	NG
	275019A	NG
	277024-92	NG
	275019C	NG
	277014A	#8
	277010	#2
	277014B	#9
	277011	#3
	277015
	201121A
	210755
	202295
	277000
	211662
	277009

Page 110 — EX5200 Series

Pegasus EX3200 Series parts on page 110

Ref	Part number	Part name	Qty
3	277503	S30
1.5	277512	P15
1.5	277502	P15
	277301	16F
	277318	13
	277301	16F
	277319	13
	277302	16F
	202799
3	210761
1.5	205525

Page 111

Pegasus EX3200 Series parts on page 111

Ref	Part number	Part name	Qty
	179630-92	N/A
	275019A	N/A
	277010A #5	N/A
	277010 #2	N/A
	277015	N/A
	201121A	N/A
	210755	N/A
	202295	N/A

Page 112 — GAUGE PARTS CONSTRUCTION CHART

Pegasus EX3200 Series parts on page 112

Ref	Part number	Part name	Qty
1	277505R30	NGXSW 2×3
2	277505R40	NGXSW 2×4
1	277306-16	Part
2	277307-16	Part
3	277318-13	Part
4	277308-16	Part
3	277124	SW	3
4	277124	SW	4
3	277125	SW	3
4	277125	SW	4

Page 113

Pegasus EX3200 Series parts on page 113

Ref	Part number	Part name	Qty
	277022-92	NG
	275019B	NG
	277010A #5
	277015
	201121A
	210755
	202295

Page 115

Pegasus EX3200 Series parts on page 115

Ref	Part number	Part name	Qty
2	277022-92	NG
	275019B	NG
	277010A #5
	277015
	277034
	201121A	-53-53C3/333 -M53-M53C3/333
	210755	-53-53C3/333K -M53-M53C3/333K
	202295

Page 116

Pegasus EX3200 Series parts on page 116

Ref	Part number	Part name	Qty
	277503	R30
	277503	R40
	277503	R50
	277507	R30
	277507	R40
	277507	R50
	277526	S35
	277526	S45
	277510	S40
	277510	S50
	277304	16F
	277318	13
	277352	16F
	277318	13
	277352	25F
	277318	13
	277316	16F
	277353	A25F
	277112
	277111
	277127
	277159	#22
	208651
	208651
	277159	#22
	277104	#16
	277104	#16
	277105	#17
	277105	#17
	277157	#19
	277158	#20
	277158	#20
	277105	#17
	277105	#17

Page 117

Pegasus EX3200 Series parts on page 117

Ref	Part number	Part name	Qty
275019B	277022-92	NG	2
275019C	277023-92	NG	2.5
275019C	277024-92	NG	3
277011	277011	#3
277019	277019	#12
277012	277012	#4
	277015	277015
	277016A	277016A
	277016	277016
	201121A	-54/433 -54/443
	210755	-54/433K -54/443K
	202295	テープ付用(厚生地) ATTACHING TAPE (HEAVY WEIGHT FABRIC)
	277000	-54/445 -55/545
	211662	-54/445K -55/545K
	202295	テープ付用(厚生地) ATTACHING TAPE (HEAVY WEIGHT FABRIC)

Page 119

Pegasus EX3200 Series parts on page 119

Ref	Part number	Part name	Qty
179630-92	179630-92	N/A
275019A	275019A	N/A
277022-92	277022-92	N/A
275019B	275019B	N/A
277010 #2	277010	#2
277010A #5	277010A	#5
277011 #3	277011	#3
201121A	201121A	N/A
210755	210755	N/A
201127	201127	N/A
202295	202295	N/A
202295	202295	N/A
201121A	201121A	N/A
210755	210755	N/A
202295	202295	N/A

Page 120 — EX5200 Series

Pegasus EX3200 Series parts on page 120

Ref	Part number	Part name	Qty
SW	277531-30	SW	3
SW	277531-40	SW	4
SW	277501R30	NGXSW	2x3
NG	277501R40	NGXSW	2x4
	277341-16F	277340-16F
	277318-13	277340-16F
	277301-16F	277300-16F
	277318-13	277300-16F
	277342-16F	277342-16F
	277302-16F	277302-16F
	211991A	211991A
	201152E	201152E
SW	277115A #12	SW	3
SW	277103A #13	SW	4
SW	201396B	SW	3
SW	201310A	SW	4

Page 121

Pegasus EX3200 Series parts on page 121

Ref	Part number	Part name	Qty
	179630-92	NG
	275019A	NG
	277022-92	NG
	275019B	NG
	277010 #2	NG
	277010B #6	NG
	277015	NG
	201121A	NG
	210755	NG
	202295	NG

Page 127 — GAUGE PARTS LIST (1)

Pegasus EX3200 Series parts on page 127

Ref	Part number	Part name	Qty
1	277300-16F	MAIN FEED DOG ASS.	40
2	277303-16F	MAIN FEED DOG ASS.	40
3	277302-16F	MAIN FEED DOG	50
4	277305-16F	MAIN FEED DOG	40
5	277318-13	DIFF. FEED DOG	3
6	277318-13	DIFF. FEED DOG	3
7	201230C	PRESSER FOOT	2
8	201230C	PRESSER FOOT	2
9	201396B	PRESSER FOOT FINGER	4
10	201310A	PRESSER FOOT FINGER	4
11	277015	LOWER LOOPER	3
12	277015	LOWER LOOPER	3
13	277010 #1	UPPER LOOPER	5
14	277010 #2	UPPER LOOPER	5
15	277010B #8	UPPER LOOPER	4
16	277010B #8	UPPER LOOPER	4
17	277004	FRONT	3
18	277004	FRONT	3
19	277005	GUARD	4
20	277005	GUARD	4
21	202295	LOWER KNIFE	5
22	202295	LOWER KNIFE	5
23	210755	ANGLED KNIFE	3
24	210755	ANGLED KNIFE	3
25	210735	UPPER KNIFE	4
26	210735	UPPER KNIFE	4
27	275019A	THREAD GUIDE (NDL HOLDER)	3
28	275019B	THREAD GUIDE (NDL HOLDER)	3
29	DC x 27 #9	NEEDLE HOLDER	4
30	DC x 27 #9	NEEDLE HOLDER	4
31	179630-92	NEEDLE HOLDER	5
32	277022-92	NEEDLE HOLDER	5
33	277019A	NEEDLE PLATE	2
34	277019B	NEEDLE PLATE	2

Part BooksPartsSearchNotes

Part Books

×

Search

×

Pegasus EX3200 Series — parts catalog

• Page 1 (cover): This is the cover page for the Pegasus EX Series Parts Catalog, specifically for machine models EX3200 and EX5200, published in December 1993. It features an image of an EX series sewing machine and the Pegasus logo.
• Page 2 (text): This page contains introductory information about the parts catalog, including how to use it, and lists the machine models covered by the EX3200(H) and EX5200(H) series.
• Page 3 (toc): This page contains the table of contents for the parts catalog, listing various machine mechanisms and parts with their corresponding page numbers.
• Page 4 (diagram): This page displays a diagram of machine components with reference numbers and associated part series information.
• Page 5 (parts_list): This page lists parts for the MACHINE BED FRAME, including part numbers, names, and quantities.
• Page 6 (diagram): This page displays a diagram of various components and their assembly, with numbered references for each part. It also lists specific machine series to which certain parts apply.
• Page 7 (parts_list): This page lists parts for COVER (1) including screws, gaskets, covers, and other components with their part numbers, descriptions, and quantities.
• Page 8 (diagram): This page displays a diagram of various machine components, including part numbers, descriptions, and model applicability for the EX5200(H) and EX3200(H) series.
• Page 9 (parts_list): This page lists parts for COVER (2) with part numbers, names, and quantities. It includes items like cloth plates, screws, washers, and covers.
• Page 10 (diagram): This page displays a diagram of various components for EX3200(H) and EX5200(H) series sewing machines, including part numbers and reference indicators.
• Page 11 (parts_list): This page lists parts for the Crankshaft Drive Mechanism, including crankshafts, screws, pins, bearings, and other components with their respective part numbers, names, and quantities.
• Page 12 (diagram): This page displays diagrams of needle sets and associated parts for industrial sewing machines, including part numbers and model applicability.
• Page 13 (parts_list): This page lists parts for the Thread Tension Mechanism, including part numbers, names, and quantities.
• Page 14 (diagram): This page displays a diagram of the EX3200(H) Series sewing machine parts, with numbered components and their corresponding part numbers and descriptions.
• Page 15 (parts_list): This page lists parts for the Thread Guide & Thread Takeup (1) section, including brackets, screws, thread guides, and springs with their corresponding part numbers and quantities.
• Page 16 (diagram): This page displays a diagram of components for the EX5200(H) Series sewing machines, detailing parts for both EX5200 Series and EX5200H Series models.
• Page 17 (parts_list): This page lists parts for thread guide and thread takeup, including part numbers, names, and quantities.
• Page 18 (diagram): This page displays a diagram of various sewing machine parts, including different lift types and their corresponding components, with reference numbers and descriptions.
• Page 19 (parts_list): This page lists parts for the Thread Guide & Thread Takeup (3) assembly, including part numbers, names, and quantities.
• Page 20 (diagram): This page displays a diagram of various components for the EX3200 and EX5200 series sewing machines, with numbered parts indicated for reference.
• Page 21 (parts_list): This page lists parts for the Needle Drive Mechanism (1), including part numbers, names, and quantities.
• Page 22 (diagram): This page displays a diagram of various components for the EX3200H and EX5200H Series sewing machines, with numbered parts indicated for reference.
• Page 23 (parts_list): This page lists parts for the Needle Drive Mechanism (2), including part numbers, names, and quantities.
• Page 24 (diagram): This page displays diagrams and parts lists for the EX3200(H) and EX5200(H) series sewing machines, detailing components for 2-needle and 3-needle configurations.
• Page 25 (parts_list): This page lists parts for the Needle Drive Mechanism (3), including part numbers, names, and quantities.
• Page 26 (diagram): This page displays diagrams of parts for the EX3200(H) Series and EX5200(H) Series sewing machines, detailing various components and their reference numbers.
• Page 27 (parts_list): This page lists parts for the Needle Drive Mechanism (4), including part numbers, names, and quantities.
• Page 28 (diagram): This page displays a diagram of the EX3200 and EX5200 series sewing machine parts, detailing various components and their reference numbers.
• Page 29 (parts_list): This page lists parts for the Upper Looper Drive Mechanism (1), including part numbers, names, and quantities.
• Page 30 (diagram): This page displays a diagram of the EX3200H and EX5200H series sewing machine parts, specifically detailing components for the ultra-high lift function.
• Page 32 (diagram): This page displays a diagram of various sewing machine parts, with reference numbers and model applicability indicated for some components.
• Page 33 (parts_list): This page lists parts for the Lower Looper Drive Mechanism, including part numbers, names, and quantities.
• Page 34 (diagram): This page displays a diagram of the EX3200(H) Series sewing machine parts, with numbered components indicating their positions and relationships within the machine's assembly.
• Page 36 (diagram): This page displays a diagram of various parts for the EX3200(H) Series sewing machine, with numbered components indicating their positions.
• Page 37 (parts_list): This page lists parts for the CHAINSTITCH LOOPER DRIVE MECHANISM (2), including part numbers, names, and quantities.
• Page 38 (diagram): This page displays a diagram of various machine parts, including levers, shafts, springs, and fasteners, with reference numbers for identification.
• Page 39 (parts_list): This page lists parts for the FEED MECHANISM (1) with part numbers, names, and quantities.
• Page 40 (diagram): This page displays a diagram of various machine parts, including components labeled with reference numbers, part numbers, and descriptions. It also includes specific model information for certain parts.
• Page 41 (parts_list): This page lists parts for the FEED MECHANISM (2) with part numbers, names, and quantities.
• Page 42 (diagram): This page displays a diagram of various machine parts, including screws, linkages, and other components, with corresponding part numbers and series information for EX5200 and EX3200 models.
• Page 43 (parts_list): This page lists parts for the KNIFE DRIVE MECHANISM, including part numbers, names, and quantities.
• Page 44 (diagram): This page displays a diagram of various machine parts, including screws, levers, and assemblies, with reference numbers and part numbers for models EX5214, EX3200H, and EX5200H series.
• Page 45 (parts_list): This page lists parts for the Presser Foot Mechanism, including part numbers, names, and quantities.
• Page 46 (diagram): This page displays a diagram of various machine components, including shafts, housings, filters, screws, and linkages, with reference numbers for each part.
• Page 47 (parts_list): This page lists parts for the Lubrication Mechanism (1), including pumps, screws, filters, and tubes, with their corresponding part numbers and quantities.
• Page 48 (diagram): This page displays diagrams of components for the EX3200 and EX3200H series sewing machines, including lift mechanisms and base components, with associated part numbers and reference indicators.
• Page 49 (parts_list): This page lists parts for the lubrication mechanism (2) of an industrial sewing machine, including part numbers, names, quantities, and remarks.
• Page 50 (diagram): This page displays a diagram of various components for the EX5200(H) Series and EX3200(H) Series sewing machines, with numbered parts and their corresponding model series indicated.
• Page 51 (parts_list): This page lists parts for the H.R. Device, including part numbers, names, and quantities.
• Page 52 (diagram): This page displays a diagram of various machine components, including arms, supports, discs, and fasteners, with reference numbers for each part.
• Page 53 (parts_list): This page lists parts for the Thread Stand, including part numbers, names, and quantities for various components like nuts, screws, brackets, and thread guide bars.
• Page 54 (diagram): This page displays a diagram of special washers for a table 35mm thick, along with various screws, washers, and other components labeled with reference numbers.
• Page 55 (parts_list): This page lists parts for semi-submerged installation, including part numbers, names, and quantities.
• Page 56 (diagram): This page displays a diagram of various machine components, including screws, nuts, washers, plates, and a motor, with reference numbers for each part.
• Page 57 (parts_list): This page lists parts for fully-submerged installation, including part numbers, names, and quantities.
• Page 58 (diagram): This page displays diagrams of various sewing machine parts, including components for plain seaming, and lists their corresponding part numbers and reference numbers.
• Page 59 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities. It also notes that 'XXXXXX' parts are gauge parts and should be confirmed on pages 120-133.
• Page 60 (diagram): This page contains diagrams and part information for blindhemming and plain seaming operations on the EX5204-02H sewing machine.
• Page 61 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, quantities, and some details like screw sizes and material types.
• Page 62 (diagram): This page displays a diagram of plain seaming components for the EX3215-3216-04 and EX3215H-3216H-05 sewing machine models, with numbered parts and their corresponding part numbers and descriptions.
• Page 63 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities.
• Page 64 (diagram): This page displays a diagram of plain seaming components for the EX3244-04 model, with numbered parts and their descriptions.
• Page 65 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some Japanese and English descriptions.
• Page 66 (diagram): This page contains a diagram of blind hemming components for the EX5203 and 5205 sewing machine models, with various parts numbered for identification.
• Page 67 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities. It also contains a note about gauge parts and their confirmation on pages 120-133.
• Page 68 (diagram): This page displays diagrams of serging parts for models EX5203-22, EX5204-5214-24, EX5214-24, EX5204-24, and turn down hemming parts for EX5204-32R1, 32R2.
• Page 69 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities, with some parts designated as gauge parts.
• Page 70 (diagram): This page displays a diagram of shirting components for models EX5214-43,43P1,43P2 and EX3215-3216-42,43, with numbered parts and their corresponding references.
• Page 71 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, quantities, and reference numbers. It contains items from reference number 1 to 58.
• Page 72 (diagram): This page displays diagrams for the EX5214-43 (Shirring) and EX3215-3216-42,43 models, as well as the Piping EX5214-43P1,43P2.
• Page 73 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some parts marked as gauge parts.
• Page 74 (diagram): This page displays a diagram of components for attaching U-shaped tape to the EX3216-53 model, including various screws, brackets, and discs.
• Page 75 (parts_list): This page lists specific parts for industrial sewing machines, including part numbers, names, and quantities. It also notes that 'XXXXXX' parts are gauge parts and should be confirmed on pages 120-133.
• Page 76 (diagram): This page displays a diagram of attaching tape components for various sewing machine models including EX5214-53, 53C3,54, M53, M53C3,84, and EX5214H-55.
• Page 77 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some parts noted as gauge parts.
• Page 78 (diagram): This page displays a diagram of attaching tape components for models EX5214-54 and EX5214H-55, with numbered parts and associated part numbers.
• Page 79 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities.
• Page 80 (diagram): This page displays diagrams of various machine parts for models EX5204-82, EX5214-83, and EX5214-84, with numbered references for each component.
• Page 81 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some parts marked as gauge parts.
• Page 82 (diagram): This page displays diagrams of parts for blind hemming on the EX5204-92M1 sewing machine, including components labeled with reference numbers.
• Page 84 (diagram): This page displays diagrams of sewing machine parts for plain seaming and blind hemming, specifically for the EX5214-92M2 model, with numbered components.
• Page 85 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities, with some parts marked as not for sale.
• Page 86 (diagram): This page displays a diagram of optional parts for various EX series sewing machines, including part numbers and reference numbers.
• Page 87 (parts_list): This page lists parts for the FABRIC EDGE GUIDE, including part numbers, names, and quantities.
• Page 88 (diagram): This page displays a construction chart for gauge parts for the EX3200 Series, specifically for the EX3215 and EX3216 models, showing various configurations and part numbers.
• Page 89 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needle guards and other parts for different models like EX3215 and EX3216, with descriptions for plain seaming and overlock applications.
• Page 90 (diagram): This page displays a construction chart for gauge parts of the EX3200 Series, specifically for models EX3215-01A/222 and EX3216, showing various components with their part numbers and diagrams.
• Page 91 (diagram): This page displays diagrams of various sewing machine parts, including needle plates, presser feet, and other components, with their corresponding part numbers and model applicability.
• Page 92 (diagram): This page displays a construction chart for gauge parts for the EX3200 Series sewing machine, showing various components with their part numbers and diagrams.
• Page 93 (diagram): This page displays diagrams of various sewing machine parts, including needle plates, presser feet, and other components, with their corresponding part numbers and model applicability for EX3215 and EX3216 machines.
• Page 95 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needle guards, presser feet, and other specialized parts, with model applicability indicated for some.
• Page 97 (diagram): This page displays diagrams and part numbers for various components of the EX3244-03/333(K) and EX3244-04/435(K) sewing machines, categorized for plain seaming on medium and heavy weight fabrics.
• Page 98 (diagram): This page displays construction diagrams for EX3200 Series Gauge Parts, detailing various components with their respective part numbers and associated models.
• Page 99 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needle plates, presser feet, and shirting attachments for models EX3215 and EX3216.
• Page 100 (diagram): This page contains a construction chart for the EX3200 Series, specifically detailing gauge parts with diagrams and part numbers.
• Page 101 (diagram): This page displays diagrams of various sewing machine parts, including part numbers and descriptions, with some parts specified for models -53/233 and -53/233K.
• Page 102 (diagram): This page displays construction diagrams for gauge parts for the EX5200 Series sewing machine, specifically for plain seaming with one needle.
• Page 103 (diagram): This page displays a diagram of sewing machine parts, including part numbers, descriptions, and associated machine models, with specific sections for different fabric types.
• Page 104 (diagram): This page displays construction charts for gauge parts of the EX5200 series sewing machine, including diagrams and part numbers for various components.
• Page 105 (diagram): This page displays diagrams of various sewing machine parts, including part numbers and descriptions for different fabric types.
• Page 106 (diagram): This page displays a construction chart for the EX5200 Series, specifically for plain seaming with two needles. It includes diagrams and part numbers for various components.
• Page 107 (diagram): This page displays diagrams of various sewing machine parts, including part numbers like 277022-92, 275019B, 277010A #5, 277015, 277034, 201121A, 210755, and 202295, along with their descriptions and applicable models.
• Page 108 (diagram): This page displays a construction chart for gauge parts of the EX5200 Series sewing machines, detailing various components with their part numbers and associated models.
• Page 109 (diagram): This page displays a diagram of various sewing machine parts, including part numbers, descriptions, and associated machine models. It details components for blindstitch hemming and serging on light and heavy weight fabrics.
• Page 110 (diagram): This page displays a construction chart for EX5200 Series gauge parts, featuring diagrams and part numbers for various components.
• Page 111 (diagram): This page displays a diagram of various sewing machine parts, including part numbers and their corresponding descriptions, with specific models listed for some parts.
• Page 112 (diagram): This page displays a construction chart for gauge parts of the EX5200 Series, showing various components with their part numbers and diagrams.
• Page 113 (diagram): This page displays diagrams and part numbers for various sewing machine components, including parts for models EX5214-43/333(K), EX5214-43P1/333(K), and EX5214-43P2/333(K). It details parts like 277022-92, 275019B, 277010A #5, 277015, 201121A, 210755, and 202295, with descriptions for shirring and shirring/piping applications on medium weight fabric.
• Page 115 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needles, presser feet, and tape attachments for different fabric weights.
• Page 116 (diagram): This page displays a construction chart for gauge parts of the EX5200 Series, featuring diagrams and part numbers for various components.
• Page 117 (diagram): This page displays diagrams of various sewing machine parts, categorized by model numbers such as EX5214-54/433(K), EX5214-54/443(K), EX5214H-55/545(K), and EX5214-54/445(K). It includes part numbers, descriptions, and illustrations for components like attaching tape for heavy weight fabric.
• Page 119 (diagram): This page displays diagrams of various sewing machine parts, categorized by model numbers such as EX5204-82/233(K), EX5214-83/323(K), and EX5214-84/423(K). It includes part numbers, descriptions, and application notes for different fabric weights.
• Page 120 (diagram): This page displays diagrams and part numbers for the EX5200 Series, specifically for models EX5204-92M1/223(K) and EX5214-92M2/223(K). It includes various components with their respective part numbers and some descriptive text.
• Page 121 (diagram): This page displays diagrams of various sewing machine parts, including part numbers and model applicability, for models EX5204-92M1/223(K) and EX5214-92M2/223(K).
• Page 127 (parts_list): This page lists gauge parts for the EX5200 Series, including various components like feed dogs, presser feet, loopers, and knives, along with their part numbers and specifications for different machine types.
• Page 139 (unknown): This page contains a watermark and a website address at the bottom.
• Page 140 (cover): This is the cover page of a parts catalog for PEGASUS SEWING MACHINE MFG. CO., LTD., catalog number 9605, dated December 1993. It also lists the publication dates for the first, second, and third editions.

Page 1 — EX SERIES MACHINE MODELS: EX3200 5200 SERIES

PARTS CATALOG Cat. No. 9605 A December, 1993 EX SERIES MACHINE MODELS: EX3200 5200 SERIES JIN.TEX.IN

Page 2

パーツカタログの見方 このパーツカタログは,1993年12月製造中の EX3200(H)・5200(H)シリーズのミシンを次 ています。 2~85頁には部品を機構別に収録し、左頁が部品の分解図、右 頁がパーツリストになっています。 また、部品分解図に付されている番号は、パーツリストの REF. NO.(参照番号)を示しています。 ゲージパーツ系列構成図・ゲージパーツ表(86~133頁) これらの部品は、特定の形式にのみ使用されている部品で、 系列構成図は86~119頁に、ゲージパーツ表は120~133頁に 一括して記載しています。 134頁以降には部品番号インデックスを記載し、部品番号だ けで、その図解、名称などが容易に引き出せます。 部品を御注文いただくときは、必ず部品番号だけを明示して下 さい。 なお、このパーツカタログの記載事項は改良により、予告な く変更されることがありますので、あらかじめご了承くださ い。 INTRODUCTION This parts catalog covers the EX3200(H) 5200(H) series machine manufactured December, 1993. On pages 2~85, each mechanism is arranged on facing pages, the first page containing the illustrations and the second page containing the data of the individual parts. The number given to each illustrations is the REF. NO. on the parts list. Gauge parts construction charts / gauge parts list. Gauge parts are used in some machine types and sewing gauges only. Pages 86~119 contain the gauge parts construction charts in order to know the illustrations and the combinations of the parts, and pages 120~133 contain the gauge parts lists to obtain the data at a glance. A part number index is attached to the back of this catalog for convenience. When placing orders for parts from this catalog, use ONLY THE PART NUMBER. This parts catalog is applicable to your machine and is subject to change without notice. 掲載機種 (Models inserted) EX3200(H) Series EX5200(H) Series (15) EX3216-01/222 EX5204-01/223 EX5214-43/333 (15) EX3216-01A/222 EX5214-43P1/333 EX5204-02/233 (15) EX3216-02/223 EX5214-43P2/333 EX5204-02H/233 (15) EX3216-02A/223 EX5214-53/333 EX5212-02/333 (15) EX3216-03/233 EX5214-53C3/333 EX5214-03/333 (15) EX3216-03/333 EX5214-M53/333 EX5214-03C3/333 EX3244-03/333 EX5214-M53C3/333 EX5214-04/435 EX5214-M03/333 (15) EX3216H-05/535 EX5214-54/433 EX5214-M03C3/333 (15) EX3216-42/233 EX5214-54/443 EX5205-12/223 (15) EX3216-43/335 EX5214-54/445 EX5203-12/223 EX5214H-55/545 EX5203-22/233 EX3216-53/233 EX5204-82/223 EX5204-24/445 EX5204-82/233 EX5214-24/445 EX5214-83/323 EX5204-32R1/223 EX5214-84/423 EX5204-32R2/223 EX5204-92M1/223 EX5204-32R2/223L EX5204-92M2/223 jintex.in

Page 3 — TABLE OF CONTENTS

目 次 頁 TABLE OF CONTENTS Page ベッド機構 2-3 MACHINE BED FRAME 2-3 カバー機構(1)~(2) 4-7 COVER(1)-(2) 4-7 クランクシャフト機構(1) 8-9 CRANKSHAFT DRIVE MECHANISM 8-9 糸調子機構 10-11 THREAD TENTION MECHANISM 10-11 糸道,糸繰り(1)~(3) 12-17 THREAD GUIDE & THREAD TAKEUP(1)-(3) 12-17 針振り機構(1)~(4) 18-25 NEEDLE DRIVE MECHANISM(1)-(4) 18-25 上ルーパー機構(1)~(2) 26-29 UPPER LOOPER DRIVE MECHANISM(1)-(2) 26-29 下ルーパー機構 30-31 LOWER LOOPER DRIVE MECHANISM 30-31 二重環ルーパー機構(1)~(2) 32-35 CHAINSTITH LOOPER DRIVE MECHANISM(1)-(2) 32-35 送り機構(1)~(2) 36-39 FEED MECHANISM(1)-(2) 36-39 上下メス機構 40-41 KNIFE DRIVE MECHANISM 40-41 押エ機構 42-43 PRESSER FOOT MECHANISM 42-43 給油機構(1)~(2) 44-47 LUBRICATION MECHANISM(1)-(2) 44-47 H.R.装置 48-49 H.R. DEVICE 48-49 糸立台 50-51 THREAD STAND 50-51 半沈床式据付付属品 52-53 PARTS FOR SEMI-SUBMERGED INSTALLATION 52-53 全沈床式据付付属品 54-55 PARTS FOR FULLY-SUBMERGED INSTALLATION 54-55 専用部品(1)~(14) 56-83 SPECIFIC PARTS(1)-(14) 56-83 当定規 84-85 FABRIC EDGE GUIDE 84-85 ゲージパーツ系列構成図 86-119 GAUGE PARTS CONSTRUCTION CHART 86-119 ゲージパーツ表 120-133 GAUGE PARTS LIST 120-133 部品番号インデックス 134- PART NUMBER INDEX 134- -1- jintex.in

Page 4

EX5200 Series 1 EX3200 Series 2 EX5200H Series 3 EX3200H Series 4 EX3200 Series EX5200 Series 5 8 7 10 EX5200(H) Series 13 9 6 12 11 jintex.in

Page 5 — MACHINE BED FRAME

MACHINE BED FRAME ベッド機構 *=原則販売不可(Not for sale basically) REF. PART NO. NO. 部品番号 NAME QT. * 1 270001-9S ベッド(組) MACHINE BED COMPLETE 1 * 2 270001A9S ベッド(組) MACHINE BED COMPLETE 1 * 3 270055-9S ベッド(組) MACHINE BED COMPLETE 1 * 4 270055A9S ベッド(組) MACHINE BED COMPLETE 1 5 240333 ノッチ棒 ROD 1 6 201002 スプリングピン PIN 1 7 210194 案内/オイル指示 INDICATOR GUIDE 1 8 240325 パイプ PIPE 2 9 240299 ピン PIN 1 10 208173 栓 PLUG 1 11 270008-91 ブラケット(組) BRACKET ASSEMBLY 1 12 4511 平ネジ/M6×25 SCREW 2 13 270047 足ピン BED PIN 4 3 jintex.in

Page 6

EX3200 Series EX5200 Series 7 EX3200H Series 36 EX5200H Series EX5200(H) Series 29 EX3200(H) Series 38 EX3216-53 を除く Except EX3216-53 EX3200(H) Series 35 jintex.in

Page 7 — COVER (1)

COVER (1) REF. PART NO. NAME QT. NO. 部品番号 名 称 1 270020-SD 上カバー TOP COVER 1 2 7022 平ネジ/M4×14 SCREW 4 3 270021 ガスケット GASKET 1 4 240305 防振ゴム CUSHION RUBBER 3 5 179107-05 オイル窓 OIL SIGHT WINDOW 1 6 240110 栓 PLUG 1 7 270010-UD 側面カバー SIDE COVER 1 8 7044 皿ネジ/M4×10 SCREW 4 9 270024-9U ベルトカバー(組) BELT COVER ASSEMBLY 1 *10 270024-UB ベルトカバー BELT COVER 1 11 240305 防振ゴム CUSHION RUBBER 1 12 7176 平ネジ/M6×14 SCREW 3 13 270025 ファンカバー FAN COVER 1 14 7019 平ネジ/M4×10 SCREW 2 15 270011-UD 前カバー(右) FRONT COVER (RIGHT) 1 16 270014 ヒンジ HINGE 1 17 7021 平ネジ/M4×12 SCREW 3 18 240043 平行ピン PIN 1 19 4543 止ネジ SCREW 2 20 240301 圧縮バネ SPRING 1 21 270018 ラッチ LATCH 1 22 7009 平ネジ/M3×4 SCREW 1 23 4574 止ネジ/M3×12 SCREW 1 24 4535 止ネジ/M3×4 SCREW 1 25 270017 ラッチ LATCH 1 26 7017 平ネジ/M4×5 SCREW 1 27 210044 板バネ FLAT SPRING 1 28 7017 平ネジ/M4×5 SCREW 1 29 270012 前カバー(左) FRONT COVER (LEFT) 1 30 7018 平ネジ/M4×6 SCREW 2 31 270028 カバー COVER 1 32 7019 平ネジ/M4×10 SCREW 2 33 7020 平ネジ/M4×10 SCREW 1 34 7021 平ネジ/M4×12 SCREW 1 35 270013 前カバー(左) FRONT COVER (LEFT) 1 36 270010AUD 側面カバー SIDE COVER 1

Page 8

EX5204-82,92M1 EX5214-43,43P1,43P2 83,84 を除く Except EX5204-82,92M1 EX5214-43,43P1,43P2 83,84 EX5200(H) Series 広巾 (Wide) 1 狭巾 (Narrow) 2 EX3200(H) Series 1 EX3215-3216-42,43 を除く Except EX3215-3216-42,43 35 34 36 38 37 26 27 40 39 2 49 48 50 43 EX SERIES 52 EX3200(H) Series 28 EX5200(H) Series 32 33 31 42 41 25 24 8 19 18 22 EX5214-83,84 を除く Except EX5214-83,84 3 4 5 6 7 14 13 15 23 16 17 12 11 EX5200(H) Series 広巾 (Wide) 9 狭巾 (Narrow) 10 EX3200(H) Series 51 44 45 46 47 jintex.in

Page 9 — COVER (2)

カバー機構 (2) * =原則販売不可 (Not for sale basically) COVER (2) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 270035 2 270037 3 270042 4 4543 5 210307 6 240303 7 4543 8 240305 9 270030-UB 10 270031-UB 11 7025 12 201252 13 7018 14 240343 15 240305 16 270048 17 7008 18 270049 19 7180 20 270015 21 7077 22 270043 23 7172 24 270044 25 270045 26 270019 27 7019 28 270032 29 7062 30 202875 31 270034 32 7066 33 210307 34 270022 35 7084 36 270023 37 270046 38 7018 39 270026 40 7020 41 7023 42 4821 43 270052 *44 270053 45 210679 *46 250233 47 210679 *48 230047A 49 210679 *50 202526 51 270030-UB 52 270033 クロスプレート (広巾) クロスプレート (狭巾) ブッシュ 止ネジ 波板座金 カラー 止ネジ 防振ゴム 横カバー (広巾) 横カバー (狭巾) 平ネジ / M4 × 20 バネ座金 平ネジ / M4 × 6 座金 防振ゴム ラッチ 平ネジ / C3 × 5 ラッチ 平ネジ / M3.5 × 4.5 当板 皿ネジ / M4 × 7 レバー 段付ネジ / M4 ネジリバネ ブラケット 布案内 平ネジ / M4 × 10 アイガード 平ネジ / M3 × 6 座金 ブラケット 段付ネジ / M4 波板座金 上蓋 (組) 六角ネジ / M4 × 8 ガスケット 送リェキセンカバー 平ネジ / M4 × 6 後蓋 平ネジ / M4 × 10 平ネジ / M4 × 16 六角ナット / M4 銘板 銘板 止ピン 形式板 止ピン 機番板 止ピン 記銘板 横カバー (広巾) アイガード CLOTH PLATE (WIDE) CLOTH PLATE (NARROW) BUSHING SCREW WASHER COLLAR SCREW CUSHION RUBBER SIDE COVER SIDE COVER SCREW SPRING WASHER SCREW WASHER CUSHION RUBBER LATCH SCREW LATCH SCREW PLATE SCREW LEVER SCREW SPRING BRACKET FABRIC GUARD SCREW EYE GUARD SCREW WASHER BRACKET SCREW WASHER BED COVER PLATE ASSEMBLY SCREW GASKET COVER/FEED ECCENTRIC SCREW COVER PLATE SCREW SCREW NUT NAME PLATE NAME PLATE PIN TYPE PLATE PIN SERIAL NUMBER PLATE PIN NAME PLATE SIDE COVEF EYE GUARD 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 2 1 5 1 1 2 1 4 1 1 1 2 1 1 1 1 jintex.in

Page 10

EX32□□(H) □□-□□/□□□ EX52□□(H) □□-□□/□□□ 2: スタンダードリフト (Standad lift) 3: ハイリフト (High lift) 4: 超ハイリフト (Extra-high lift) 5: ウルトラハイリフト (Ultra-high lift) 2 EX3215-3216-04 EX3244-04 を除く Except EX3215-3216-04 EX3244-04 3 EX3215H-3216H-05 を除く Except EX3215H-3216H-05 1 スタンダードリフト・ハイリフト Standard lift High lift 2 超ハイリフト Extra-high lift 3 ウルトラハイリフト Ultra-high lift EX3200(H) Series EX5200(H) Series EX5200(H) Series 8 EX3200(H) Series 29 jintex.in

Page 11 — CRANKSHAFT DRIVE MECHANISM

クランクシャフト機構 CRANKSHAFT DRIVE MECHANISM REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 270500A クランク軸 CRANKSHAFT 1 2 270500B クランク軸 CRANKSHAFT 1 3 270512A クランク軸 CRANKSHAFT 1 4 7151 止ネジ SCREW 5 5 270502 バランスウエイト BALANCE WEIGHT 2 6 7011 平ネジ/M3×8 SCREW 4 7 270503 段付ピン PIN 1 8 4541 止ネジ/M6×8 SCREW 1 9 270508 蓋 COVER 1 10 7019 平ネジ/M4×10 SCREW 3 11 240340 Oリング O RING 1 12 270507-91 ボールベアリング(組) BALL BEARING COMPLETE 1 13 4572 止ネジ/M5×10 SCREW 2 14 4514 止ネジ/M5×5 SCREW 1 15 240335 止メ輪 RING 1 16 212987 ボールベアリング BALL BEARING 1 17 211526 ボールベアリング BALL BEARING 1 18 240306 波板座金 WASHER 1 19 210056 油切り OIL SEAL 1 20 210057 Oリング O RING 1 21 240340 Oリング O RING 1 22 211528 ハウジング BALL BEARING RETAINER 1 23 7020 平ネジ/M4×10 SCREW 3 24 270505 ファン(組) FAN COMPLETE 1 25 270504-UD プーリー MACHINE PULLEY 1 26 4541 止ネジ/M6×8 SCREW 2 27 4523 六角穴ボルト/M6×35 BOLT 1 28 204293 バネ座金 SPRING WASHER 1 29 270510 段付ピン PIN 1 30 270509 蓋 COVER 1 31 7044 皿ネジ/M4×10 SCREW 2 32 7020 平ネジ/M4×10 SCREW 1 jintex.in

Page 12

1 本針 (1-needle) EX5203-5204-5205 9 EX5204-24 を除く Except EX5204-24 2 本針 (2-needle) EX5212-5214 EX3215-3216 EX5214-24,54,84 EX5214H-55 EX3215-3216-04 EX3215H-3216H-05 を除く Except EX5214-24,54,84 EX5214H-55 EX3215-3216-04 9 EX3215H-3216H-05 3 本針 (3-needle) EX3244 9 EX3244-04 を除く Except EX3244-04 jintex.in

Page 13 — THREAD TENSION MECHANISM

糸調子機構 THREAD TENSION MECHANISM *=原則販売不可 (Not for sale basically) REF. PART NO. NO. 部品番号 名 称 QT. 1 210529-9U 糸調子(組) THREAD TENSION COMPLETE 1 2 208447-UA 調子ナット POST NUT 1 3 208448 ラチェット SPRING BUSHING 1 4 208450-UA 受皿 CUP 1 5 210319 調子皿 TENSION DISC 2 6 208449 フェルト FELT 1 7 5082A 調子棒/C5 SCREW STUD 1 8 201037 圧縮バネ(強) SPRING (HEAVY) 1 9 210530-9U 糸調子(組) THREAD TENSION COMPLETE 1 10 201086 圧縮バネ(中) SPRING (MEDIUM) 1 11 275000 糸道 THREAD EYELET 1 12 7018 平ネジ/M4×6 SCREW 1 13 275001 糸道 THREAD EYELET 1 14 202849 調子台 TENSION GUIDE 1 15 4009-HC 平ネジ/C5×7.5 SCREW 1 16 275041 糸道 THREAD EYELET 1 17 7018 平ネジ/M4×6 SCREW 1 18 275040 糸道 THREAD EYELET 1 19 3044 六角ナット/C5 NUT 1 jintex.in

Page 14 — EX3200(H) Series

EX3200(H) Series 2 本針 (2-needle) EX3215(H)-3216(H) 3 本針 (3-needle) EX3244 EX3215-3216 10 EX3244 11 EX3215H-3216H 12 13 14 EX3215-3216 EX3244 15 EX3215H-3216H 3 2 本針 (2-needle) 4 3 本針 (3-needle) 16 17 18 20 19 EX3200 Series 21 EX3215-3216 22 EX3244 EX3200H Series 23 24 25 26 jintex.in

Page 15 — Thread Guide & Thread Takeup (1)

Thread Guide & Thread Takeup (1) REF. PART NO. NO. 部品番号 名 称 1 275021 ブラケット 2 7012 平ネジ / M 4 × 8 3 275024 糸道 4 275042 糸道 5 4543 止ネジ 6 275026 ブラケット 7 7017 平ネジ / M 4 × 5 8 275022 糸道 9 4543 止ネジ 10 275029 糸道 11 275029A 糸道 12 275052 糸道 13 7017 平ネジ / M 4 × 5 14 275028 糸道 15 275057 糸道 16 7017 平ネジ / M 4 × 5 17 275011 小調子台 18 275012 小調子皿 19 7163 段付ネジ / M 2 20 240326 圧縮バネ 21 275027 針糸繰り 22 275044 針糸繰り 23 7062 平ネジ / M 3 × 6 24 275049 針糸繰り 25 7041 皿ネジ / M 3 × 6 26 7062 平ネジ / M 3 × 6 NAME BRACKET SCREW THREAD GUIDE THREAD EYELET SCREW BRACKET SCREW THREAD GUIDE SCREW THREAD GUIDE THREAD EYELET SCREW THREAD GUIDE THREAD EYELET SCREW SCREW BRACKET THREAD RETAINER SCREW SPRING THREAD TAKEU THREAD TAKEU SCREW THREAD TAKEU SCREW SCREW QT. 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1

Page 16 — EX5200(H) Series

EX5200(H) Series 1 本針 (1-needle) 2 本針 (2-needle) EX5203-5204-5205 5205 EX5212-5214 EX5214H EX5200 Series EX5200H Series 14 EX5203-5204- 5205 15 EX5212-5214 9 4 5 3 1 2 16 18 17 19 jintex.in

Page 17 — THREAD GUIDE & THREAD TAKEUP (2)

糸道・糸締り (2) REF. PART NO. NO. 部品番号 1 275013A 2 275013 3 4543 4 275015 5 7082 6 275018 7 275018A 8 275051A 9 7082 10 275011 11 275012 12 7163 13 240326 14 275016 15 275017 16 7062 17 275017A 18 7041 19 7062 名 称 糸道 糸道 止ネジ ブラケット 平ネジ/M4×8 糸道 糸道 糸道 平ネジ/M4×8 小調子皿 小調子皿 段付ネジ/ 圧縮バネ 針糸締り 針糸締り 平ネジ/M3×6 針糸締り 皿ネジ/M3×6 平ネジ/M3×6 THREAD GUIDE & THREAD TAKEUP (2) NAME THREAD EYELET THREAD EYELET SCREW BRACKET SCREW THREAD EYELET THREAD EYELET THREAD EYELET SCREW BRACKET THREAD RETAINER SCREW SPRING THREAD TAKEU THREAD TAKEU SCREW THREAD TAKEU SCREW SCREW QT. 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1

Page 18

EX32 EX52 (H) (H) 2: スタンダードリフト (Standad lift) 3: ハイリフト (High lift) 4: 超ハイリフト (Extra-high lift) 5: ウルトラハイリフト (Ultra-high lift) 11 10 9 スタンダードリフト ハイリフト・超ハイリフト Standard lift・High lift Extra-high lift 12 ウルトラハイリフト Ultra-high lift 13 スタンダードリフト ハイリフト・超ハイリフト Standard lift・High lift Extra-high lift 14 ウルトラハイリフト Ultra-high lift 15 EX5212 を除く Except EX5212 2 1 4 3 5 6 7 8 16 jintex.in

Page 19 — THREAD GUIDE & THREAD TAKEUP (3)

糸道・糸繰り (3) THREAD GUIDE & THREAD TAKEUP (3) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 275004 ブラケット BRACKET 1 2 275047 糸道 THREAD GUIDE (RIGHT) 2 3 7008 平ネジ/C3×5 SCREW 2 4 202875 座金 WASHER 2 5 275005 糸繰り THREAD TAKEUP 1 6 7019 平ネジ/M4×10 SCREW 1 7 275006 糸道 THREAD EYELET 1 8 7008 平ネジ/C3×5 SCREW 1 9 275007 糸道 THREAD EYELET 1 10 275008 糸道 THREAD EYELET 1 11 275055 糸道 THREAD EYELET 1 12 275010 糸道 THREAD EYELET 1 13 275056 糸道 THREAD EYELET 1 14 275009 糸繰り THREAD TAKEUP 1 15 275054 糸繰り THREAD TAKEUP 1 16 7012 平ネジ/M3.5×6 SCREW 1 jintex.in

Page 20

EX3200 Series EX5200 Series EX5212-02 を除く Except EX5212-02 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 jintex.in

Page 21 — NEEDLE DRIVE MECHANISM (1)

針振リ機構(1) * =原則販売不可(Not for sale basically) REF. PART NO. 名 称 NO. 部品番号 1 271000-92 ロッド (組) 2 7023 平ネジ / M4×16 3 271001 ピン 4 4538 止ネジ / M4×6 5 271002-92 クランク (組) 6 4533 平ネジ 7 271003 軸 8 240308 カラー 9 4543 止ネジ 10 208235 座金 11 202577 止メ輪 12 271004-92 レバー 13 7150 六角ボルト 14 271022-91 軸 (組) *15 271008-T 軸 16 202177 給油紐 17 271005-91T ブッシュ (組) / 針棒 *18 271006-T 針棒 *19 271007 ブッシュ 20 4546 止ネジ / M4×5 21 201022 Oリング 22 179009-05 フェルト 23 271009-92 リング 24 7035 平ネジ / M3×6 25 240310 栓 NEEDLE DRIVE MECHANISM (1) NAME QT. CONNECTION 1 SCREW 2 PIN 1 SCREW 1 CRANK 1 SCREW 1 SHAFT 1 COLLAR 1 SCREW 2 WASHER 1 RING 1 LEVER 1 BOLT 1 SHAFT ASSEMBLY 1 SHAFT 1 OIL WICK 1 BUSHING ASSEMBLY 2 NEEDLE BAR 1 BUSHING 1 SCREW 1 O RING 1 OIL FELT 1 RING 1 SCREW 1 PLUG 1

Page 22

EX3200H Series EX5200H Series jintex.in

Page 23 — NEEDLE DRIVE MECHANISM (2)

針振り機構(2) * =原則販売不可(Not for sale basically) REF. PART NO. NO. 部品番号 1 271000-92 2 7023 3 271001 4 4538 5 271002-92 6 4533 7 271003 8 240308 9 4543 10 208235 11 202577 12 271015-92 13 7150 14 271016 15 271017 16 7185 17 271023-91 *18 271021 19 202176 20 4545 21 271018-91 *22 271020 *23 271019 24 4546 25 201022 26 179009-05 27 271009-92 28 7035 29 240310 NEEDLE DRIVE MECHANISM (2) NAME QT. ロッド(組) CONNECTION 1 平ネジ/M4×16 SCREW 2 ピン PIN 1 止ネジ/M4×6 SCREW 1 クランク(組) CRANK 1 平ネジ SCREW 1 軸 SHAFT 1 カラー COLLAR 1 止ネジ SCREW 2 座金 WASHER 1 止メ輪 RING 1 レバー LEVER 1 六角ボルト BOLT 1 リンク LINK 1 段付ピン PIN 2 平ネジ/M3×4 SCREW 2 軸(組) SHAFT ASSEMBLY 1 平行ピン PIN 1 給油紐 OIL WICK 2 止ネジ/M3×4 SCREW 1 ブッシュ(組)/針棒 BUSHING ASSEMBLY 1 ブッシュ BUSHING 1 針棒 NEEDLE BAR 1 止ネジ/M4×5 SCREW 1 Oリング O RING 1 フエルト OIL FELT 1 リング RING 1 平ネジ/M3×6 SCREW 1 栓 PLUG 1

Page 24

EX3200(H) Series 2 本針 (2-needle) EX3215(H)•3216(H) 3 本針 (3-needle) EX3244 EX3215-3216-04 EX3215H-3216H-05 を除く Except EX3215-3216-04 EX3215H-3216H-05 2 3 4 5 6 7 8 9 EX3244-04 を除く Except EX3244-04 5 EX5200(H) Series 1 本針 (1-needle) EX5203-5204-5205 10 11 12 13 14 2 本針 (2-needle) EX5212-5214 NG=2mm 15 16 14 17 18 NG=2.5mm NG=3mm 19 20 21 22 jintex.in

Page 25 — 針振り機構(3)

針振り機構(3) REF. PART NO. NO. 部品番号 1 XXXXXX 2 4554 3 275030 4 7119 5 XXXXXX 6 XXXXXX 7 4554 8 275030 9 7119 10 XXXXXX 11 4554 12 275019A 13 7120 14 XXXXXX 15 XXXXXX 16 4554 17 275019B 18 7120 19 XXXXXX 20 4554 21 275019C 22 7120 名 称 針留(組) 止ネジ/M3×3 糸道 皿ネジ/M2×5 針 針留(組) 止ネジ/M3×3 糸道 皿ネジ/M2×5 針留(組) 止ネジ/M3×3 糸道 平ネジ/M2×3 針 針留 止ネジ/M3×3 糸道 平ネジ/M2×3 針留 止ネジ/M3×3 糸道 平ネジ/M2×3 NEEDLE DRIVE MECHANISM (3) NAME NEEDLE HOLDER ASSEMBLY SCREW THREAD GUIDE SCREW NEEDLE NEEDLE HOLDER ASSEMBLY SCREW THREAD GUIDE SCREW NEEDLE HOLDER SCREW THREAD GUIDE SCREW NEEDLE HOLDER SCREW THREAD GUIDE SCREW QT. 1 2 1 1 2 1 3 1 1 1 1 1 1 1 1 2 1 1 2 1 1 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120~133. jintex.in

Page 26

EX3200(H) Series EX5200(H) Series EX5204-82,92M1 EX5204-83,84 を除く Except EX5204-82,92M1 EX5204-83,84 jintex.in

Page 27 — NEEDLE DRIVE MECHANISM (4)

針振り機構(4) NEEDLE DRIVE MECHANISM (4) REF. PART NO. 名 称 NAME QT. NO. 部品番号 1 XXXXXX 針板 NEEDLE PLATE 1 2 7170 皿ネジ/M4×7.5 SCREW 2 3 271010 取付板(前) BRACKET (FRONT) 1 4 7019 平ネジ/M4×10 SCREW 2 5 240305 防振ゴム CUSHION RUBBER 2 6 271011 取付板(後) BRACKET (REAR) 1 7 7019 平ネジ/M4×10 SCREW 2 8 7019 平ネジ/M4×10 SCREW 1 9 XXXXXX 針受(前) NEEDLE GUARD (FRONT) 1 10 7010 平ネジ/M3×6 SCREW 2 11 XXXXXX 針受(後) NEEDLE GUARD (REAR) 1 12 7259 六角ボルト BOLT 1 13 240222 皿バネ SPRING WSASHER 1 14 7165 段付ネジ/M3 SCREW 1 15 XXXXXX 針受(前) NEEDLE GUARD (FRONT) 1 16 7019 平ネジ/M4×10 SCREW 1 17 XXXXXX 針受(後) NEEDLE GUARD (REAR) 1 18 7010 平ネジ/M3×6 SCREW 1 19 271013 ブラケット BRACKET 1 20 7114 平ネジ/M4×10 SCREW 2 21 XXXXXX 針板 NEEDLE PLATE 1 22 7170 皿ネジ/M4×7.5 SCREW 2 23 271010 取付板(前) BRACKET (FRONT) 1 24 7019 平ネジ/M4×10 SCREW 2 25 240305 防振ゴム CUSHION RUBBER 2 26 271011 取付板(後) BRACKET (REAR) 1 27 7019 平ネジ/M4×10 SCREW 2 28 271012 ストッパー STOPPER 1 29 7019 平ネジ/M4×10 SCREW 1 30 XXXXXX 針受(前) NEEDLE GUARD (FRONT) 1 31 7019 平ネジ/M4×10 SCREW 1 32 XXXXXX 針受(後) NEEDLE GUARD (REAR) 1 33 7259 六角ボルト BOLT 1 34 240222 皿バネ SPRING WSASHER 1 35 7165 段付ネジ/M3 SCREW 1 XXXXXX はゲージパーツです。 120-133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in

Page 28

EX3200 Series EX5200 Series EX32 EX52 (H) (H) 2: スタンダードリフト (Standad lift) 3: ハイリフト (High lift) 4: 超ハイリフト (Extra-high lift) 5: ウルトラハイリフト (Ultra-high lift) 13 14 11 12 10 9 EX3200 Series 3 本針 (3-needle) 16 EX5200 Series 2 本針 (2-needle) スタンダードリフト Standard lift 17 ハイリフト・超ハイリフト High lift・Extra-high lift 16 EX5204-24 EX5214-24,54/445 EX3215-3216-04 EX3244-04 を除く スタンダードリフト Standard lift 6 ハイリフト High lift 7 超ハイリフト Extra-high lift 32 33 34 Except EX5204-24 EX5214-24,54/445 EX3215-3216-04 EX3244-04 15 39 35 36 38 37 18 19 28 29 27 30 21 20 25 23 22 24 jintex.in

Page 29 — UPPER LOOPER DRIVE MECHANISM (1)

上ルーパー機構 (1) UPPER LOOPER DRIVE MECHANISM (1) *=原則販売不可(Not for sale basically) REF. PART NO. NO. 部品番号 名 称 QT. 1 271500-92 2 7023 3 7022 4 271501 5 7041 6 271502-92 7 271503-92 8 4533 9 271504 10 240338 11 7174 12 303067 13 275540 14 275541 15 210122 16 240312 17 240102 18 210586A 19 271517-91 *20 271505-92 21 7150 22 179136-01 *23 179137-05 24 202176 25 4545 *26 271506-91 *27 271507 *28 179129-05 29 179130-05 30 7054 31 XXXXXX 32 271510 33 271510A 34 271510B 35 4510 36 271511 37 7039 38 7033 39 8421 ロッド 平ネジ/M4×16 平ネジ/M4×14 振止メ 皿ネジ/M3×6 クランク クランク 平ネジ 軸 座金 六角ネジ/M4×10 バネ座金 栓 フィルター スペーサー 座金 座金 オイルシール 上ルーバー台(セット) レバー 六角ボルト 平行ピン(組) 平行ピン 給油紐 止ネジ/M3×4 上ルーバー 上ルーバー 上ルーバー台 上ルーバー台案内 フェルト 平ネジ/M3.5×6.7 上ルーバー 上ルーバー 上ルーバー台 上ルーバー台 上ルーバー台 カバー 皿ネジ/M2.5×6 平ネジ/M2.5×8 オイルマーク CONNECTION SCREW SCREW GUIDE SCREW CRANK CRANK SCREW SHAFT WASHER SCREW SPRING WASHER PLUG FILTER SPACER WASHER WASHER OIL SEAL UPPER LOOPER HOLDER ASSEMBLY LEVER BOLT PIN ASSEMBLY PIN OIL WICK SCREW UPPER LOOPER HOLDER ASSEMBLY UPPER LOOPER HOLDER GUIDE/UPPER LOOPER HOLDER OIL FELT SCREW UPPER LOOPER BASE/UPPER LOOPER HOLDER BASE/UPPER LOOPER HOLDER BASE/UPPER LOOPER HOLDER SCREW COVER SCREW SCREW OIL MARK 1 2 2 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 XXXXXXはゲージパーツです。 120~133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120~133. jintex.in 87

Page 30

EX3200H Series EX5200H Series EX5200H Series 2 本針 (2-needle) ウルトラハイリフト Ultra-high lift jintex.in

Page 32

EX5200(H)Series 6 7 EX3200(H)Series 19 21 20 1 2 3 4 5 12 13 14 15 16 17 18 9 10 11 8 30 jintex.in

Page 33 — LOWER LOOPER DRIVE MECHANISM

下ルーパー機構 LOWER LOOPER DRIVE MECHANISM REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 271500-92 2 7023 3 7022 4 271501 5 7041 ロッド 平ネジ/M4×16 平ネジ/M4×14 振止メ 皿ネジ/M3×6 CONNECTION SCREW SCREW GUIDE SCREW 1 2 2 1 2 6 272000-92 7 4533 8 271504 9 240338 10 7174 クランク 平ネジ 軸 座金 六角ネジ/M4×10 CRANK SCREW SHAFT WASHER SCREW 1 1 1 1 1 11 303067 12 240311 13 210586A 14 XXXXXX 15 7168 バネ座金 座金 オイルシール 下ルーパー 止ネジ/M3.5×6. SPRING WASHER WASHER OIL SEAL LOWER LOOPER 5 SCREW 1 1 1 1 1 16 272001-92 17 7055 18 7169 19 273511-92 20 4533 下ルーパー合(組) 六角ネジ/M5×13 平ネジ/M4×7 クランク 平ネジ LOWER LOOPER HOLDER ASSEMBLY SCREW SCREW CRANK SCREW 1 1 1 1 1 21 4514 止ネジ/M5×5 SCREW 1 XXXXXXはゲージパーツです。 120-133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in

Page 34 — EX3200(H) Series

EX3200(H) Series jintex.in

Page 36

EX3200(H) Series jintex.in

Page 37 — CHAINSTITCH LOOPER DRIVE MECHANISM (2)

二重環ルーパー機構(2) CHAINSTITCH LOOPER DRIVE MECHANISM (2) * =原則販売不可 (Not for sale basically) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 275031 糸道 THREAD GUIDE 1 2 7019 平ネジ/M4×8 SCREW 1 3 275032 糸道パイプ THREAD GUIDE 1 4 206115 ホルダー HOLDER 2 5 275033 ブラケット BRACKET 1 6 7066 段付ネジ/M4 SCREW 1 7 210307 波座金 WASHER 2 8 7167 段付ネジ/M3 SCREW 1 9 137108 調子皿 TENSION DISC 2 10 211388 圧縮バネ SPRING 1 11 275034 ツマミ KNOB 1 12 275035 糸受 THREAD GUIDE 1 13 7017 平ネジ/M4×5 SCREW 1 14 275036 糸道 THREAD GUIDE 1 15 7008 平ネジ/M3×4 SCREW 1 16 275039 糸道 THREAD GUIDE 1 17 7008 平ネジ/M3×4 SCREW 1 18 179498-92 ルーパー糸繰り(組) LOOPER THREAD TAKEUP ASSEMBLY 1 19 4554 止ネジ/M3×3 SCREW 2 20 275037 板バネ SPRING 1 21 275038 糸道 THREAD GUIDE 1

Page 38

5 EX5214-54/445 EX5214H-55 を除く Except EX5214-54/445 EX5214H-55 jintex.in

Page 39 — FEED MECHANISM (1)

FEED MECHANISM (1) REF. PART NO. NO. 部品番号 名 称 QT. 1 272500 ロッド CONNECTION 1 2 271001 ピン PIN 1 3 4538 止ネジ/M4×6 SCREW 1 4 240012 ニードルベアリング NEEDLE BEARING 1 5 272501 エキセン ECCENTRIC 1 6 210129 案内/送リエキセン GUIDE/FEED ECCENTRIC 1 7 210130 板バネ FLAT SPRING 1 8 4535 止ネジ/M3×4 SCREW 1 9 4535 止ネジ/M3×4 SCREW 1 10 272506-91 調節台 REGULATOR 1 11 4514 止ネジ/M5×5 SCREW 2 12 272504-91 エキセン(組) ECCENTRIC ASSEMBLY 1 13 272503 ネジリバネ SPRING 1 14 7038 平ネジ/M2 SCREW 1 15 272502 ラチェット RATCHET 1 16 272509 プッシュボタン PUSH BUTTON 1 17 240315 ガスケット GASKET 1 18 240314 座金 WASHER 1 19 240317 圧縮バネ SPRING 1 20 200555 止メ輪 RING 1 21 272529 リンク LINK 1 22 7058 段付ネジ/M5 SCREW 1 23 202522 止メ輪 RING 1 24 272530A92 レバー LEVER 1 25 4533 平ネジ SCREW 1 26 272532 レバー LEVER 1 27 7161 段付ネジ/M5 SHAFT 1 28 272533A 軸 O RING 1 29 204185 Oリング SPRING 1 30 272534 ネジリバネ REGULATOR PLATE 1 31 272535 調節板 SCREW 1 32 7021 平ネジ/M4×12 SPACER 2 33 240321 スペーサー NUT 2 34 179202-25 ナット SCREW 1 35 7059 段付ネジ/4.5 SPRING WASHER 1 36 211301 皿バネ STOPPER 1 37 252658 ストッパー SCREW 2 38 7018 平ネジ/M4×6 WASHER 2 39 303448 座金 ADJUSTING BAR 1 40 272538A 調節棒 SEAL 1 41 240322 シール RING 1 42 200555 止メ輪 SPRING 1 43 210533 圧縮バネ PIN 1 44 272539A 段付ピン 27 jintex.in

Page 40

EX5214-54/445 EX5214H-55 を除く Except EX5214-54/445 EX5214H-55 jintex.in

Page 41 — FEED MECHANISM (2)

FEED MECHANISM (2) * = 原則販売不可 (Not for sale basically) REF. PART NO. NO. 部品番号 名 称 QT. 1 272516 軸 1 2 205061 止メ輪 1 3 208173 栓 1 4 240311 座金 2 5 272510-91 クランク 1 * 6 272511 クランク本体 1 7 4534 平ネジ/M6×14 1 * 8 272512 クランクピン 1 * 9 272513 クランクピン 1 10 7010 平ネジ/M3×6 2 11 272518 角駒 1 12 272514-92 クランク 1 13 4533 平ネジ/M6×12 1 14 272515 ピン 1 15 4805 六角ナット/M5 1 16 240062 座金 1 17 272525 段付ピン 1 18 7238 止ネジ 1 19 240318 ガスケット 1 20 240319 止メ輪 1 21 201022 Oリング 1 22 272526 角駒 1 23 240303 カラー 2 24 4543 止ネジ/M4×4 2 25 272517 リンク 1 26 179160-05 ブッシュ 1 27 7056 六角ネジ/M5×13 1 28 240039 座金 1 29 272527 主送り台 1 30 XXXXXX 主送り歯(組) 1 31 XXXXXX 主送り歯 1 32 XXXXXX 補助送り歯 1 33 7010 平ネジ/M3×6 1 34 7013 平ネジ/M3.5×8 1 35 272528 差動送り台 1 36 XXXXXX 差動送り歯 1 37 7013 平ネジ/M3.5×8 1 38 272524 角駒 1 39 272519 送り台案内 1 40 7110 平ネジ/M4×9 2 41 272520 案内(左)/送り台 1 42 7110 平ネジ/M4×9 2 43 272523 油切り案内 1 44 272521 油切り 2 45 272522 油切り案内 1 46 4573 平ネジ/M4×5 2 XXXXXXはゲージパーツです。 120~133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120~133. jintex.in

Page 42

7 1 2 9 8 EX3100H Series EX5200 Series EX3200 Series EX5200 Series 10 11 12 13 18 17 16 14 EX5200(H)Series 15 EX3200(H)Series 3 EX5200(H)Series 4 EX3200(H)Series 5 6 8 19 EX5200(H)Series 22 20 EX3200(H)Series 21 23 24 25 EX5200(H)Series 26 EX3200(H)Series 27 EX3215-3216-04 EX3215H-3216H-05 EX5204-24 EX5214-24,54/445 EX5214H-55 28 EX5200 Series EX5204-24,82,92M1 EX5214-24,54/445,83,84 EX5214H-55 を除く Except EX5204-24,82,92M1 EX5214-24,54/445,83,84 EX5214H-55 29 EX3200 Series EX3215-3216-04 EX3215H-3216H-05 EX3244-04 を除く Except EX3215-3216-04 EX3215H-3216H-05 EX3244-04 30 31 32 33 36 37 38 35 34 jintex.in

Page 43 — KNIFE DRIVE MECHANISM

* = 原則販売不可 (Not for sale basically) REF. PART NO. NO. 部品番号 名 称 1 273000-92 ロッド 2 7023 平ネジ / M4×16 3 273001-92 クランク 4 273002-92 クランク 5 4533 平ネジ 6 271001 ピン 7 4538 止ネジ / M4×6 8 240235-92 カラー 9 4547 止ネジ / M6×5 10 273003 上メス台 11 273004 上メス台 12 308036 ピン付ネジ 13 273006 案内ピン 14 179712-05 上メス抱キ 15 179713-05 上メス抱キ 16 7021 平ネジ / M4×12 17 XXXXXX 上メス 18 7013 平ネジ / M3.5×8 19 210756 角メス抱キ 20 210757 角メス抱キ 21 XXXXXX 角メス 22 1227 平ネジ / C3×3.7 23 210758 角メス押エ 24 179341-15 切屑押シ 25 7023 平ネジ / M4×16 26 7213 平ネジ / M4×16 27 300248 座金 28 273008 下メス台 29 273009 下メス台 30 7019 平ネジ / M4×10 31 273010 案内/下メス台 32 7019 平ネジ / M4×10 33 240324 圧縮バネ 34 273007 当板 35 7019 平ネジ / M4×10 36 XXXXXX 下メス/厚メス 37 273012 下メス押エ 38 7173 六角ネジ / M5×8 NAME QT. CONNECTION 1 SCREW 2 CRANK 1 CRANK 1 SCREW 1 PIN 1 SCREW 1 COLLAR 1 SCREW 1 UPPER KNIFE LEVER 1 UPPER KNIFE LEVER 1 SCREW 1 PIN 1 UPPER KNIFE CLAMP 1 UPPER KNIFE CLAMP 1 SCREW 1 UPPER KNIFE 1 SCREW 1 ANGLED UPPER KNIFE CLAMP 1 ANGLED UPPER KNIFE CLAMP 1 ANGLED KNIFE 1 SCREW 1 ANGLED UPPER KNIFE GIB 1 WASTE GUARD 1 SCREW 1 SCREW 1 WASHER 1 LOWER KNIFE HOLDER 1 LOWER KNIFE HOLDER 1 SCREW 1 GUIDE/LOWER KNIFE HOLDER 1 SCREW 2 SPRING 1 PLATE 1 SCREW 1 LOWER KNIFE/THICK 1 LOWER KNIFE CLAMP 1 SCREW 1 XXXXXXはゲージパーツです。 XXXXXX is one of the gauge parts. 120~133頁のゲージパーツ表で確認してください。 Please confirm the correct part by the gauge parts lists on pages 120~133. 41 jintex.in

Page 44

EX5214 -43,43P1,43P2 を除く Except EX5214-43,43P1,43P2 21 22 23 24 25 26 28 27 EX5200(H) Series EX3200H-5200H Series 30 31 32 33 34 35 36 37 38 39 29 42 jintex.in EX5214-54,84 EX5214H-55 EX3215-3216-04 EX3215H-3216H-05 EX3244-04 を除く Except EX5214-54,84 EX5214H-55 EX3215-3216-04 EX3215H-3216H-05 EX3244-04

Page 45

押エ機構 PRESSER FOOT MECHANISM REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 274007 レバー LEVER 1 2 7060 段付ネジ/ M10 SCREW 1 3 274008 ネジリバネ SPRING 1 4 274009 ストッパー STOPPER 1 5 7020 平ネジ/M4×10 SCREW 2 6 7175 平ネジ/M5×24 SCREW 1 7 4805 六角ナット/M5 NUT 1 8 274006 リンク LINK 1 9 274004 レバー LEVER 1 10 274003-92 カラー COLLAR 1 11 4534 平ネジ/M6×14 SCREW 1 12 274005 ネジリバネ SPRING 1 13 274002 ブッシュ BUSHING 1 14 7020 平ネジ/M4×10 SCREW 1 15 274001 軸/押エ台 SHAFT 1 16 274000-B 押エ台 PRESSER ARM 1 17 208549 平行ピン PIN 1 18 4543 止ネジ SCREW 1 19 202451 チェーンカッター CHAIN CUTTER 1 20 7008 平ネジ/C3×5 SCREW 1 21 274018-92B ホルダー HOLDER 1 22 7013 平ネジ/M3.5×8 SCREW 1 23 274033 フィンガーガード FINGER GUARD 1 24 274020 ストッパー STOPPER 1 25 7009 平ネジ/M3×4 SCREW 1 26 7008 平ネジ/C3×5 SCREW 1 27 274019 板バネ FLAT SPRING 1 28 5089 平ネジ SCREW 1 29 274011-91 押エ棒 PRESSER BAR 1 30 208773A 圧縮バネ SPRING 1 31 274014 調節ネジ ADJUSTING SCREW 1 32 274015 ナット NUT 1 33 274016 レバー LEVER 1 34 7171 段付ネジ/M4 SCREW 1 35 274017 ネジリバネ SPRING 1 36 274010 ストッパー STOPPER 1 37 7019 平ネジ/M4×10 SCREW 1 38 274039 レバー LEVER 1 39 274040 ストッパー STOPPER 1

Page 46

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 27 28 29 30 31 32 33 34 35 36 37 38 39 jintex.in

Page 47 — LUBRICATION MECHANISM (1)

*=Original Purchase Not Available (Not for sale basically) REF. PART NO. NAME QT. NO. 部品番号 名称 1 274505-91 ポンプ PUMP 1 2 211618 ウォームホイール WORM WHEEL 1 3 5060 止ネジ/C8×4.5 SCREW 2 4 274506 ポンプ本体 PUMP BODY 1 5 212978-91 ローター(内)軸 ROTOR (INSIDE) SHAFT 1 * 6 212981 ローター(外) ROTOR (OUTSIDE) 1 * 7 274508 側板 CASING PLATE 1 8 213578 フィルター FILTER 1 9 213579 当金 GUIDE 1 10 7013 平ネジ/M3.5×8 SCREW 3 11 4529 平ネジ/M4×16 SCREW 2 12 274509 タンク TANK 1 13 7021 平ネジ/M4×12 SCREW 2 14 206233 エレメント OIL FILTER 1 15 274510 蓋 COVER 1 16 7018 平ネジ/M4×6 SCREW 3 17 240307 Oリング O RING 1 18 200136 継手 JOINT 2 19 240328 継手ネジ SCREW 2 20 202199 クランプ CLAMP 2 21 240327 チューブ TUBE 1 22 200136 継手 JOINT 2 23 240328 継手ネジ SCREW 2 24 202199 クランプ CLAMP 2 25 240135 チューブ TUBE 1 26 200136 継手 JOINT 1 27 240328 継手ネジ SCREW 2 28 202199 クランプ CLAMP 2 29 240334 チューブ TUBE 1 30 274512 継手 JOINT 1 31 240020 Oリング O RING 1 32 7021 平ネジ/M4×12 SCREW 1 33 303448 座金 WASHER 1 34 274515-91 油分配器(組) OIL DISTRIBUTOR COMPLETE 1 *35 274511 油分配器 OIL DISTRIBUTOR 1 36 210214 栓 PLUG 2 37 7023 平ネジ/M4×16 SCREW 1 38 303448 座金 WASHER 1 39 240328 継手ネジ SCREW 1

Page 48

EX3200 Series EX5200 Series EX3200H Series EX5200H Series スタンダード ドリフト Standard lift ハイリフト・超ハイリフト ウルトラハイリフト High lift Extra-high lift Ultra-high lift EX32 EX52 (H) (H) 2: スタンダードリフト (Standard lift) 3: ハイリフト (High lift) 4: 超ハイリフト (Extra-high lift) 5: ウルトラハイリフト (Ultra-high lift) jintex.in

Page 49 — LUBRICATION MECHANISM (2)

給油機構 (2) * =原則販売不可 (Not for sale basically) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 274502 オイルゲージ OIL SIGHT GAUGE 1 2 230043 Oリング O RING 1 3 210193 オイル指示(組) INDICATOR COMPLETE 1 4 210510 オイル指示受 INDICATOR SUPPORT 1 5 7021 平ネジ/M4×12 SCREW 2 6 303448 座金 WASHER 2 7 274503-91 オイルパン(組) OIL RESERVOIR ASSEMBLY 1 * 8 274500 オイルパン OIL RESERVOIR 1 9 5138B 平ネジ/H11×12 SCREW 1 10 202287A ガスケット GASKET 1 11 4531 六角穴ボルト/M5×12 BOLT 4 12 240339 座金 WASHER 4 13 274501 ガスケット GASKET 1 14 274504 ウォーム WORM 1 15 4514 止ネジ/M5×5 SCREW 1 16 274517A91 パイプ(組) PIPE ASSEMBLY 1 *17 274514 パイプ PIPE 1 18 202175 給油紐 OIL WICK 1 19 240038 栓 PLUG 1 20 4543 止ネジ/M4×4 SCREW 1 21 274517-91 パイプ(組) PIPE ASSEMBLY 1 22 274516-91 パイプ(組) PIPE ASSEMBLY 1 *23 274513 パイプ PIPE 1 24 202175 給油紐 OIL WICK 1 25 240097 栓 PLUG 2 26 4543 止ネジ/M4×4 SCREW 1 27 274523-91 継手(組) JOINT 1 *28 274518 継手 JOINT 1 29 274522 フェルト OIL FELT 1 30 204185 Oリング O RING 1 31 7019 平ネジ/M4×8 SCREW 1 32 202175 給油紐 OIL WICK 1 33 274529 フェルト OIL FELT 1 34 274530 カバー COVER 1 35 7192 段付ネジ/M4 SCREW 1 36 274551-91 継手(組) JOINT 1 *37 274552-91 継手 JOINT 1 38 274556 フェルト OIL FELT 1 39 204185 Oリング O RING 1 40 4543 止ネジ/M4×4 SCREW 1 LUBRICATION MECHANISM (2) jintex.in

Page 50

EX5200(H) Series 3 EX3200 Series 4 EX3200(H) Series 5 6 EX5200(H) Series 7 EX3200(H) Series 8 EX5200(H) Series EX3200(H) Series 19 20 24 EX3244-03, 04 を除く Except EX3244-03, 04 16 25 17 21 18 22 23 10 15 14 13 9 12 11 48 jintex.in

Page 51 — H.R.装置

H.R.装置 H.R. DEVICE REF. PART NO. NO. 部品番号 NAME QT. 1 275500 シリコンタンク(上) SILICONE OIL RESERVOIR (UPPER) 1 2 275501 蓋 COVER 1 3 275503 フェルト FELT 1 4 275508 フェルト FELT 1 5 275546 フェルト FELT 1 6 275502 糸案内 THREAD GUIDE 1 7 275507 糸案内 THREAD GUIDE 1 8 7020 平ネジ/M4×10 SCREW 1 9 275504 シリコンタンク(下) SILICONE OIL RESERVOIR (LOWER) 1 10 275505 蓋 COVER 1 11 7020 平ネジ/M4×10 SCREW 1 12 303448 座金 WASHER 1 13 202175 給油紐 OIL WICK 1 14 240331 チューブ TUBE 1 15 200155 クランプ TUBE CLAMP 2 16 275506 針冷却器 NEEDLE THREAD LUBRICATOR 1 17 7021 平ネジ/M4×12 SCREW 2 18 210214 栓 PLUG 1 19 204466 給油フェルト OIL WICK 1 20 210766 止ピン PIN 1 21 275509 針冷却器 NEEDLE THREAD LUBRICATOR 1 22 7019 平ネジ/M4×10 SCREW 2 23 210214 栓 PLUG 1 24 204466 給油フェルト OIL WICK 1 25 210766 止ピン PIN 1 jintex.in

Page 52

31 30 28 38 39 15 37 35 38 34 36 20 21 23 19 24 22 18 16 17 27 25 33 26 29 11 6 10 9 14 14 13 12 4 1 2 3 13 12 5 7 8 11 6 10 9 7 8 jintex.in

Page 53 — THREAD STAND

THREAD STAND REF. PART NO. NAME QT. NO. 部品番号 名 称 486-9C 糸立(組)(6本立) THREAD STAND ASS. (6-SPOOLS) 1 486A9C 糸立(組)(5本立) THREAD STAND ASS. (5-SPOOLS) 1 486B9C 糸立(組)(4本立) THREAD STAND ASS. (4-SPOOLS) 1 486C9C 糸立(組)(3本立) THREAD STAND ASS. (3-SPOOLS) 1 1 503-CA スタンド棒(下) THREAD STAND ROD (LOWER) 1 1 1 1 2 509 座金 WASHER 1 1 1 1 3 5476 六角ナット NUT 1 1 1 1 4 505-CA ブラケット(3本立) BRACKET 1 5 505ACA ブラケット(2本立) BRACKET 1 6 380A 糸立棒 SPOOL PIN 3 4 5 6 7 201252 バネ座金 SPRING WASHER 3 4 5 6 8 4803 六角ナット/M4 NUT 3 4 5 6 9 381-CA 受皿 SPOOL TRAY 3 4 5 6 10 507 ウレタン CUSHION 3 4 5 6 11 382-CA ユ止メ SPOOL RETAINING FIN 3 4 5 6 12 7102 六角ネジ/M6×32 SCREW 1 2 2 2 13 512 座金 WASHER 1 2 2 2 14 4022 平ネジ/M6×10 SCREW 1 2 2 2 15 502-CA スタンド棒(上) THREAD STAND ROD (UPPER) 1 1 1 1 16 504-CA ジョイント JOINT 1 1 1 1 17 4021 平ネジ/M5×16 SCREW 2 2 2 2 18 4805 六角ナット/M5 NUT 2 2 2 2 19 383-CA ブラケット BRACKET 1 1 1 1 20 4014 平ネジ/M4×25 SCREW 1 1 1 1 21 4803 六角ナット/M4 NUT 1 1 1 1 22 384 糸道棒THREAD GUIDE BAR ROD 1 1 1 1 23 4012 平ネジ/M4×12 SCREW 1 1 1 1 24 4803 六角ナット/M4 NUT 1 1 1 1 25 233-CA ホルダー HOLDER 1 1 1 1 26 4012 平ネジ/M4×12 SCREW 1 1 1 1 27 4803 六角ナット/M4 NUT 1 1 1 1 28 293 糸道棒(6本立) THREAD GUIDE BAR (6-SPOOLS) 1 1 1 1 29 293A 糸道棒(5本立) THREAD GUIDE BAR (5-SPOOLS) 1 30 293B 糸道棒(4本立) THREAD GUIDE BAR (4-SPOOLS) 1 31 293C 糸道棒(3本立) THREAD GUIDE BAR (3-SPOOLS) 1 32 4012 平ネジ/M4×12 SCREW 1 1 1 1 33 4803 六角ナット/M4 NUT 1 1 1 1 34 527-CA ブラケット(3本立) BRACKET 1 1 35 527ACA ブラケット(2本立) BRACKET 2 1 36 506 糸道 THREAD GUIDE 3 4 5 6 37 4117 止ネジ/M5×12 SCREW 1 2 2 2 38 4805 六角ナット/M5 NUT 1 2 2 2 39 386 キャップ ROD CAP 1 1 1 1

Page 54

テーブル板厚 35mm 用 Special washers for a table 35mm thick 2 1 3 4 6 13 14 5 10 12 11 9 7 8 jintex.in

Page 55 — PARTS FOR SEMI-SUBMERGED INSTALLATION

半沈床式据付付属品 PARTS FOR SEMI-SUBMERGED INSTALLATION REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 276001 据付板 REST BOARD 1 2 179483-05 クッションゴム CUSHION RUBBER 4 3 206336 半沈用ナツ NUT 4 4 205467 スペーサー SPACER 4 5 4575 ボルト/M8×45 BOLT 4 6 240304 ワッシャー WASHER 4 7 276002-UA シューター(上) WASTE CHUTE 1 8 276003-UA シューター(下) WASTE CHUTE 1 9 4904 木ネジ(皿)/3.5 SCREW 3 10 276004 取付板 BRACKET 1 11 4109 平ネジ/M4×10 SCREW 2 12 240104 座金 WASHER 2 13 206337 座金 WASHER 4 14 201447 バネ座金 SPRING WASHER 4 jintex.in

Page 56

3 4 5 6 5 6 10 7 9 8 15 14 11 1 2 13 12 16 18 17 19 20 21 22 jintex.in

Page 57 — 全沈床式据付付属品

全沈床式据付付属品 PARTS FOR FULLY-SUBMERGED INSTALLATION REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 276001 据付板 REST BOARD 1 2 179483-05 クッションゴム CUSHION RUBBER 4 3 7237 ボルト BOLT 1 4 7236 ボルト BOLT 4 5 202700 座金 WASHER 15 6 4816 六角ナット/M10 NUT 15 7 276012 補助板 PLATE 1 8 4575 ボルト/M8×45 BOLT 3 9 240304 歯付座金 WASHER 3 10 4808 六角ナット/M8 NUT 3 11 276013 補助板 ANGLED UPPER KNIFE PLATE 1 12 4575 ボルト/M8×45 BOLT 2 13 240304 歯付座金 WASHER 2 14 4808 六角ナット/M8 NUT 2 15 4512 平ネジ/M8×55 SCREW 3 16 276014 取付板 BRACKET 1 17 4109 平ネジ/M4×10 SCREW 3 18 240104 座金 WASHER 3 19 276002-UA シューター(上) WASTE CHUTE 1 20 276003-UA シューター(下) WASTE CHUTE 1 21 7013 平ネジ/M3.5×8 SCREW 3 22 167066 座金 WASHER 3 55 jintex.in

Page 58 — 地縫い (Plain seaming)

地縫い (Plain seaming) EX5204-01,02 EX5212-02 EX5214-01,03,03CM03,M03C3 EX3244-03 EX3215-3216-01,02,03 EX3244-03 SW=3・4mm SW=5・6mm EX3215-3216-01A,02A jintex.in

Page 59 — SPECIFIC PARTS (1)

*=原則販売不可(Not for sale basically) REF. PART NO. NO. 部品番号 1 XXXXXX 2 XXXXXX 3 277126 4 1231 5 211600 6 5030 7 271014-92 8 4533 9 XXXXXX 10 7013 11 208958-B 12 212499-B 13 5409 14 212498 15 274028 16 3153 17 208531 18 5030 19 274022 20 7009 21 274026 22 7008 23 275528 24 274021-92 25 7013 26 274023 27 7009 28 274025 29 7008 30 XXXXXX 31 211919 32 211918 33 3150 34 211920 35 211915 36 211916 37 211917 38 5089 39 300248 NAME 押工 押工爪 補助押工 平ネジ/C1×3.4 押工補助板 平ネジ/C1×2.3 クランク 平ネジ 押工(組) 平ネジ/M3.5×8 ピン付ネジ/C3 段付ピン 六角ナット/C3 ラッチ ネジリバネ ナット 補助押工 平ネジ/C1×2.3 ネジリバネ 平ネジ/M3×4 フィンガーガード 平ネジ/C3×5 フェルト ホルダー 平ネジ/M3.5×8 ネジリバネ 平ネジ/M3×4 フィンガーガード 平ネジ/C3×5 押工 段付ピン ネジリバネ 六角ナット/C1 スプリングピン 押工爪 押工爪 取付板 平ネジ 座金 PRESSER FOOT PRESSER FOOT FINGER FABRIC GUARD SCREW UNCURLER SCREW CRANK SCREW PRESSER FOOT COMPLETE SCREW SCREW PIN NUT LATCH SPRING NUT FABRIC GUARD SCREW SPRING SCREW FINGER GUARD SCREW FELT HOLDER SCREW SPRING SCREW FINGER GUARD SCREW PRESSER FOOT PIN SPRING NUT PIN PRESSER FOOT FINGER PRESSER FOOT FINGER BRACKET SCREW WASHER QT. 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 XXXXXXはゲージパーツです。 120-133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in

Page 60

地縫い (Plain seaming) 裾引き (Blindhemming) EX5204-02H 裾引き (Blindhemming) 33 36mm 35 34 6 5 4 3 2 1 20 32 31 22 23 28 21 27 26 25 24 7 10 11 8 13 14 9 12 15 16 17 18 19 jintex.in

Page 61 — SPECIFIC PARTS (2)

*=販売不可 (Not for sale basically) REF. PART NO. NO. 部品番号 1 XXXXXXX 2 211994 3 1333 4 XXXXXX 5 211600 6 5030 7 210685 8 210680 9 210681 10 5184 11 201191 12 3044 13 210682 14 5053 15 210683 16 210684 17 2906 18 7020 19 201252 20 212265 21 210690 22 5088 23 167066 24 212266 25 5057 26 210689 27 5157 28 5363 29 2905 30 137142 31 212267 32 1206 33 212268A91 34 205835A 35 5299 専用部品(2) NAME 押工 補助押工 平ネジ/C1×4 押工爪 押工補助板 平ネジ/C1×2.3 定規ブラケット(組) 定規ブラケット ヒンジ/定規ブラケット 段付ネジ/C5 皿バネ 六角ナット/C5 ストッパー 平ネジ/C4×4.8 段付ピン 板バネ 平ネジ/C4×2.6 平ネジ/M4×10 バネ座金 裾引定規台(組) ブラケット 六角ネジ/C4×7.5 座金 裾引定規台 平ネジ/C3×5 調節板 平ネジ/C3×4.5 調節ネジ 平ネジ/C5×4.5 座金 ストッパー 平ネジ/C4×5.3 定規羽根(36MM) 補助羽根 平ネジ/C3×2.6 PRESSER FOOT FABRIC GUARD SCREW PRESSER FOOT FINGER UNCURLER SCREW CLOTH GUIDE BRACKET ASSEMBLY CLOTH GUIDE BRACKET HINGE/EDGE GUIDE BRACKET SCREW SPRING NUT STOPPER SCREW PIN FLAT SPRING SCREW SCREW SPRING WASHER CLOTH GUIDE COMPLETE BRACKET SCREW WASHER CLOTH GUIDE SCREW ADJUSTING PLATE SCREW SCREW SCREW WASHER STOPPER SCREW FOLDER COMPLETE (36MM) AUXILIARY PLATE SCREW SPECIFIC PARTS (2) QT. 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 1 2 1 1 1 1 1 1 1 1 XXXXXはゲージパーツです。 120-133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in

Page 62

地縫い (Plain seaming) EX3215-3216-04 EX3215H-3216H-05 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 20 21 22 23 24 25 26 27 28 29 30 EX3215-3216-04 EX3215H-3216H-05 EX3215-3216-04 EX3215H-3216H-05 トラクター押エ Tractor presser foot jintex.in

Page 63 — SPECIFIC PARTS (3)

専用部品(3)SPECIFIC PARTS (3) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 210530A9U 2 208447-UA 3 208448 4 208450-UA 5 210319 6 208449 7 5082A 8 201086A 9 210531-9U 10 201068 11 XXXXXX 12 7013 13 208958-B 14 277108 15 202875 16 5157 17 274024 18 7166 19 274034 20 7009 21 274027 22 7008 23 240347 24 210337A 25 273009A 26 275030A 27 240302 28 270500C 29 270512B 30 7151 糸調子(組) 調子ナット ラチェット 受皿 調子皿 フェルト 調子棒/C5 圧縮バネ(中) 糸調子(組) 圧縮バネ(弱) 押エ(組) 平ネジ/M3.5×8 ピン付ネジ 補助押エ 座金 平ネジ/C3×4.5 ネジリバネ 段付ネジ/M3 ネジリバネ 平ネジ/M3×4 フィンガーガード 平ネジ/C3×5 圧縮バネ 圧縮バネ 下メス台 糸道 スペーサー クランク軸 クランク軸 止ネジ THREAD TENSION COMPLETE POST NUT SPRING BUSHING CUP TENSION DISC FELT SCREW STUD SPRING (MEDIUM) THREAD TENSION COMPLETE SPRING (LIGHT) PRESSER FOOT COMPLETE SCREW SCREW FABRIC GUARD WASHER SCREW SPRING SCREW SPRING SCREW FINGER GUARD SCREW SPRING SPRING LOWER KNIFE HOLDER THREAD EYELET SPACER CRANKSHAFT CRANKSHAFT SCREW 1 1 1 1 2 1 1 1 1 1 1 1 3 1 1 1 1 1 1 1 1 1 1 1 1 1 1 5 XXXXXXはゲージパーツです。 120-133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in

Page 64

地縫い (Plain seaming) EX3244-04 1 6 5 1 7 4 8 3 2 9 7 8 9 10 3 2 11 12 13 トラクター押エ Tractor presser foot 14 15 16 17 20 21 22 23 24 62 jintex.in

Page 65 — SPECIFIC PARTS (4)

専用部品(4) SPECIFIC PARTS (4) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 210530A9U 糸調子(組) THREAD TENSION COMPLETE 1 2 208447-UA 調子ナット POST NUT 1 3 208448 ラチェット SPRING BUSHING 1 4 208450-UA 受皿 CUP 1 5 210319 調子皿 TENSION DISC 2 6 208449 フェルト FELT 1 7 5082A 調子棒/C5 SCREW STUD 1 8 201086A 圧縮バネ(中) SPRING (MEDIUM) 1 9 210531-9U 糸調子(組) THREAD TENSION COMPLETE 1 10 201068 圧縮バネ(弱) SPRING (LIGHT) 1 11 XXXXXX 押エ(組) PRESSER FOOT COMPLETE 1 12 7013 平ネジ/M3.5×8 SCREW 1 13 208958-B ピン付ネジ/C3 SCREW 3 14 274024 ネジリバネ SPRING 1 15 7166 段付ネジ/M3 SCREW 1 16 274027 フィンガーガード FINGER GUARD 1 17 7008 平ネジ/C3×5 SCREW 1 18 210337A 圧縮バネ SPRING 1 19 273009A 下メス台 LOWER KNIFE HOLDER 1 20 275030A 糸道 THREAD EYELET 1 21 275528 フェルト FELT 1 22 240302 スペーサー SPACER 1 23 277500C クランク軸 SHAFT 1 24 7151 止ネジ SCREW 5 XXXXXXはゲージパーツです。 120-133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in

Page 66

裾引き (Blindhemming) EX5203•5205-12 14 26 25 23 24 18 21 20 19 15 22 1 4 5 2 7 8 3 9 10 11 13 12 27 40mm 29 28 31 30 35 36 34 32 33 jintex.in

Page 67 — 専用部品(5)

*=原則販売不可 (Not for sale basically) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 210685 定規ブラケット (組) CLOTH GUIDE BRACKET ASSEMBLY 1 2 210680 定規ブラケット CLOTH GUIDE BRACKET 1 3 210681 ヒンジ/定規ブラケット HINGE/EDGE GUIDE BRACKET 1 4 5184 段付ネジ/C5 SCREW 1 5 201191 皿バネ SPRING 1 6 3044 六角ナット/C5 NUT 1 7 210682 ストッパー/ヒンジ STOPPER 1 8 5053 平ネジ/C4×4.8 SCREW 1 9 210683 段付ピン PIN 1 10 210684 板バネ FLAT SPRING 1 11 2906 平ネジ/C4×2.6 SCREW 1 12 7020 平ネジ/M4×10 SCREW 1 13 201252 バネ座金 SPRING WASHER 1 14 210691 裾引定規台(組) CLOTH GUIDE COMPLETE 1 15 210690 ブラケット BRACKET 1 16 5088 六角ネジ/C4×7.5 SCREW 2 17 167066 座金 WASHER 2 18 205361 裾引定規台 CLOTH GUIDE 1 19 5057 平ネジ/C3×5 SCREW 1 20 210689 調節板 ADJUSTING PLATE 1 21 5157 平ネジ/C3×4.5 SCREW 2 22 2430 調節ネジ/C3 SCREW 1 23 2905 平ネジ/C5×4.5 SCREW 1 24 137142 座金 WASHER 1 25 210692 ストッパー STOPPER 1 26 1206 平ネジ/C4×5.3 SCREW 1 27 201211C91 定規羽根(40MM) FOLDER COMPLETE (40MM) 1 28 205835 補助羽根 AUXILIARY PLATE 1 29 5299 平ネジ/C3×2.6 SCREW 1 30 303312A 羽根駒 REGULATOR 1 31 303313 板バネ FLAT SPRING 1 32 XXXXXX 押エ PRESSER FOOT 1 33 XXXXXX 押エ爪 PRESSER FOOT FINGER 1 34 210584 押工補助板 UNCURLER 1 35 5030 平ネジ/C1×2.3 SCREW 1 36 210585 座金 WASHER 1 XXXXXXはゲージパーツです。 120~133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in 65

Page 68

サージング (Serging) EX5203-22 EX5204-5214-24 EX5214-24 EX5204-24 巻き縫い (Turn down hemming) EX5204-32R1,32R2 jintex.in

Page 69 — SPECIFIC PARTS (6)

専用部品(6) REF. PART NO. NO. 部品番号 1 XXXXXX 2 XXXXXX 3 277126 4 1231 5 211600 6 5030 7 277128 8 210530A9U 9 208447-UA 10 208448 11 208450-UA 12 210319 13 208449 14 5082A 15 201086A 16 210531-9U 17 201068 18 240302 19 273008A 20 XXXXXX 21 XXXXXX 22 277126 23 1231 24 211600 25 5030 SPECIFIC PARTS (6) 名 称 押工 押工爪 補助押工 平ネジ/C1×3.4 押工補助板 平ネジ/C1×2.3 補助押工 糸調子(組) 調子ナット ラチェット 受皿 調子皿 フェルト 調子棒/C5 圧縮バネ(中) 糸調子(組) 圧縮バネ(弱) スペーサー 下メス台 押工 押工爪 補助押工 平ネジ/C1×3.4 押工補助板 平ネジ/C1×2.3 NAME QT. PRESSER FOOT PRESSER FOOT FINGER FABRIC GUARD SCREW UNCURLER SCREW FABRIC GUARD THREAD TENSION COMPLETE POST NUT SPRING BUSHING CUP TENSION DISC FELT SCREW STUD SPRING (MEDIUM) THREAD TENSION COMPLETE SPRING (LIGHT) SPACER LOWER KNIFE HOLDER PRESSER FOOT PRESSER FOOT FINGER FABRIC GUARD SCREW UNCURLER SCREW 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 XXXXXXはゲージパーツです。 120~133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120~133. jintex.in 67

Page 70 — ヒダ取り (Shirring)

ヒダ取り (Shirring) EX5214-43,43P1,43P2 EX3215-3216-42,43 EX5214-43P1,43P2 50 EX3215-3216 -42,43 51 EX5214-43,43P1,43P2 56 55 54 53 ★ EX5214-43P1 の場合 56 は注文品です。 jintex.in

Page 71 — SPECIFIC PARTS (7)

専用部品 (7) SPECIFIC PARTS (7) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 275514-91 2 275515 3 7022 4 240332 5 7191 6 210947 7 1206 8 275516 9 7160 10 204888 11 4806 12 210945 13 5328 14 210946 15 1206 16 275517-92 17 7021 18 208447-UA 19 208448 20 210940 21 204091 22 5082A 23 210944 24 275518 25 4806 26 275520 27 240320 28 275521 29 202522 30 207045 31 240323 32 206225 33 1457-1 34 210955 35 5029 36 212435 37 212436 38 7099 39 202433 40 4806 41 275522 42 179765-15 43 7164 44 240104 45 275523 46 7022 47 210961 48 7012 49 137906 50 275524 51 275525 52 200098 53 270035B 54 210962 55 5210 56 211885 57 1202 58 167066 ヒダ取り付け装置(組) ブラケット 平ネジ/M4×14 スペーサー 平ネジ/M4×27 板バネ 平ネジ/C4×5.3 ブラケット 段付ネジ/M6 皿バネ 六角ナット/M6 ストッパー 平ネジ/C4×5.5 板バネ 平ネジ/C4×5.3 バネ案内 平ネジ/M4×12 調子ナット ラチェット 圧縮バネ 座金 調子棒/C5 座金 レバー 六角ナット/M6 ブラケット 圧縮バネ 軸 座金 座金 圧縮バネ カラー 止ネジ/C5×3.3 座金 平ネジ/C3×7.5 ケーブル ケーブル受ケ 段付ネジ/M6 座金 六角ナット/M6 ラッチ ナット/M4 段付ネジ/M4 座金 ブラケット 平ネジ/M4×14 布案内 平ネジ/M3.5×6 座金 ブレード ブレード 座金 クロスプレート ブラケット/バインダー 止ネジ/C7×4 バインダー(20) 平ネジ/C4×7 SHIRRING ATTACHMENT COMPLETE BRACKET SCREW SPACER SCREW FLAT SPRING SCREW BRACKET SCREW SPRING NUT STOPPER SCREW FLAT SPRING SCREW SPRING GUIDE SCREW POST NUT SPRING BUSHING SPRING WASHER SCREW STUD WASHER LEVER NUT BRACKET SPRING SHAFT RING WASHER SPRING COLLAR SCREW WASHER SCREW CABLE CABLE SUPPORT SCREW WASHER NUT LATCH NUT SCREW WASHER BRACKET SCREW CLOTH GUIDE SCREW WASHER BLADE BLADE WASHER CLOTH PLATE BRACKET/BINDER SCREW BINDER (20) SCREW WASHER 1 1 1 1 1 1 2 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 2 2 -69- jintex.in

Page 72

ヒダ取り (Shirring) EX5214-43 パイピング (Piping) EX5214-43P1,43P2 EX5214-43P2 22 ★ ★ EX5214-43P1 の場合 22 は注文品です。 22 is option for EX5214-43P1 EX3215-3216-42,43 jintex.in

Page 73 — 専用部品(8)

専用部品(8) SPECIFIC PARTS (8) REF. PART NO. NO. 部品番号 名 称 QT. 1 XXXXXX 押工 PRESSER FOOT 1 2 211600 押工 補助板 UNCURERLER 1 3 5030 平ネジ/C1×2.3 SCREW 1 4 274025 フィンガーガード FINGER GUARD 1 5 XXXXXX 押工 PRESSER FOOT 1 6 7013 平ネジ/M3.5×8 SCREW 1 7 208958-B ピン付ネジ/C3 SCREW 1 8 212499-B 段付ピン PIN 1 9 5409 六角ナット NUT 1 10 212498 ラッチ LATCH 1 11 274028 ネジリバネ SPRING 1 12 3153 ナット NUT 1 13 208532 補助押工(ヒダ用) PRESSER FOOT FABRIC GUARD 1 14 5030 平ネジ/C1×2.3 SCREW 1 15 274022 ネジリバネ SPRING 1 16 7009 平ネジ/M3×4 SCREW 1 17 274026 フィンガーガード FINGER GUARD 1 18 7008 平ネジ/C3×5 SCREW 1 19 XXXXXX 押工 PRESSER FOOT 1 20 202588 座金 WASHER 1 21 274025 フィンガーガード FINGER GUARD 1 22 413 テープ通シ具 TAPE INSERTING TOOL 1 23 403-9S テープガイド(組) TAPE DISC ASSEMBLY 1 24 406 フェルト FELT 1 25 404 カノコ台 TAPE DISC 1 26 4012 平ネジ/M4×12 SCREW 1 27 407 カラー COLLAR 1 28 408 調節ネジ ADJUSTING SCREW 1 29 405 取付棒 FIXING ROD 1 30 409 軸 SHAFT 1 31 4818 六角ナット NUT 1 32 410-JA ブラケット BRACKET 1 33 4908 木ネジ(皿)/4.5 SCREW 3 XXXXXX はゲージパーツです。 Please confirm the correct part by the gauge parts lists on pages 120~133. 120~133頁のゲージパーツ表で確認してください。 jinte.in

Page 74

Uテープ付け (Attaching U-shaped tape) EX3216-53 SW=5mm 3 SW=4mm 4 1 2 8 7 6 9 17 18 19 20 21 11 13 14 15 12 10 8 22 31 35 33 32 34 29 27 26 23 25 24 30 jintex.in

Page 75 — SPECIFIC PARTS (9)

*=Original sale not possible (Not for sale basically) REF. PART NO. NO. 部品番号 1 2755512 2 7180 3 209200 4 208994 5 1216 6 208997 7 270013A 8 XXXXXX 9 7013 10 208958-B 11 212499-B 12 5409 13 212498 14 274028 15 3153 16 208531 17 5030 18 274022 19 7009 20 274026 21 7008 22 337 23 344 24 4911 25 341 26 189 27 303067 28 4805 29 338 30 339 31 340 32 467 33 343 34 468 35 339 NAME テープ 案内 平ネジ/M3.5×4 バインダー(袋縫10) バインダー(袋縫8) 平ネジ/C4×5.5 案内板/バインダー 前カバー(左) 押エ(組) 平ネジ/M3.5×8 ピン付ネジ 段付ピン 六角ナット/C3 ラッチ ネジリバネ ナット 補助押エ 平ネジ/C1×2.3 ネジリバネ 平ネジ/M3×4 フィンガーガード 平ネジ/C3×5 テープ台(組) ブラケット 木ネジ(平)/4.1 軸 座金 バネ座金 六角ナット/M5 カノコ台 段付ネジ カノコ台 バネ受ケ 圧縮バネ カラー 段付ネジ TAPE GUIDE SCREW BINDER (10) BINDER (8) SCREW BINDER GUIDE FRONT COVER (LEFT) PRESSER FOOT COMPLETE SCREW SCREW PIN NUT LATCH SPRING NUT FABRIC GUARD SCREW SPRING SCREW FINGER GUARD SCREW TAPE DISC ASSEMBLY BRACKET SCREW ROD WASHER SPRING WASHER NUT TAPE DISC SCREW TAPE DISC COVER SPRING SEAT SPRING COLLAR SCREW QT. 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 XXXXXXはゲージパーツです。 120~133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120~133.

Page 76

テープ付け (Attaching tape) EX5214-53,53C3,54,M53,M53C3,84 EX5214H-55 1 3 4 2 6 5 12 11 10 8 7 9 74 jintex.in

Page 77 — SPECIFIC PARTS (10)

専用部品(10) SPECIFIC PARTS (10) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 275542-91 テープ 案内 (組) TAPE GUIDE ASSEMBLY 1 2 245510 テープ 案内 TAPE GUIDE ASSEMBLY 1 3 7066 段付ネジ/M 4 SCREW 1 4 210307 波板座金 WASHER 2 5 275511 テープ 案内 TAPE GUIDE 1 6 211267 テープ 繰り TAPE TAKEUP 1 7 208735 補助押エ FABRIC GURAD 1 8 1333 平ネジ/C1×4 SCREW 1 9 XXXXXX 押エ PRESSER FOOT 1 10 XXXXXX 押工爪 PRESSER FOOT FINGER 1 11 211600 押工 補助 板 UNCURLER 1 12 5030 平ネジ/C1×2.3 SCREW 1 X X X X X X はゲージパーツです。 X X X X X X is one of the gauge parts. 120-133 頁のゲージパーツ表で確認してください。 Please confirm the correct part by the gauge parts lists on pages 120-133. jintex.in

Page 78

テープ付け (Attaching tape) EX5214-54 EX5214H-55 1 2 3 4 5 6 7 8 9 10 11 12 EX5214-54/445 EX5214-54/445 EX5214H-55 13 14 15 jintex.in

Page 79 — SPECIFIC PARTS (11)

専用部品 SPECIFIC PARTS (11) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 210530A9U 糸調子(組) THREAD TENSION COMPLETE 1 2 208447-UA 調子ナット POST NUT 1 3 208448 ラチェット SPRING BUSHING 1 4 208450-UA 受皿 CUP 1 5 210319 調子皿 TENSION DISC 2 6 208449 フェルト FELT 1 7 5082A 調子棒/C5 SCREW STUD 1 8 201086A 圧縮バネ(中) SPRING (MEDIUM) 1 9 210531-9U 糸調子(組) THREAD TENSION COMPLETE 1 10 201068 圧縮バネ(弱) SPRING (LIGHT) 1 11 211941A 圧縮バネ SPRING 1 12 240302 スペーサー SPACER 1 13 272528A 差動送り台 DIFFERENTIAL FEED BAR 1 14 272501A エキセン ECCENTRIC 1 15 273008A 下メス台 LOWER KNIFE HOLDER 1 -77- jintex.in

Page 80

EX5204-82 EX5214-83 EX5204-82 EX5214-83,84 EX5214-84 EX5204-82 EX5214-83,84 78 jintex.in

Page 81 — 専用部品 (12)

専用部品 (12) SPECIFIC PARTS (12) REF. PART NO. NO. 部品番号 名 称 NAME QT. 1 270037C クロスプレート (狭巾) CLOTH PLATE (NARROW) 1 2 271010A 取付板(前) BRACKET 1 3 270037D クロスプレート(狭巾) CLOTH PLATE (NARROW) 1 4 308093 レバー LEVER 1 5 308085 針板ブラケット BRACKET/NEEDLE PLATE 1 6 XXXXXX 押エ PRESSER FOOT 1 7 XXXXXX 押エ爪 PRESSER FOOT FINGER 1 8 277126 補助押エ FABRIC GUARD 1 9 1231 平ネジ/C1×3.4 SCREW 1 10 XXXXXX 押エ PRESSER FOOT 1 11 XXXXXX 押エ爪 PRESSER FOOT FINGER 1 12 273008B 下メス台 LOWER KNIFE HOLDER 1 13 210530A9U 糸調子(組) THREAD TENSION COMPLETE 1 14 208447-UA 調子ナット POST NUT 1 15 208448 ラチェット SPRING BUSHING 1 16 208450-UA 受皿 CUP 1 17 210319 調子皿 TENSION DISC 2 18 208449 フェルト FELT 1 19 5082A 調子棒/C5 SCREW STUD 1 20 201086A 圧縮バネ(中) SPRING (MEDIUM) 1 21 210531-9U 糸調子(組) THREAD TENSION COMPLETE 1 22 201068 圧縮バネ(弱) SPRING (LIGHT) 1 23 211941A 圧縮バネ SPRING 1 24 XXXXXX 針板 NEEDLE PLATE 1 XXXXXX はゲージパーツです。 XXXXXX is one of the gauge parts. 120-133頁のゲージパーツ表で確認してください。 Please confirm the correct part by the gauge parts lists on pages 120-133. -79- jintex.in

Page 82

地縫い・バックタック・裾引き (Plain seaming・Backlatching・Blindhemming) EX5204-92M1 裾引き (Blindhemming) jintex.in

Page 84

地縫い・裾引き (Plain seaming・Blindhemming) EX5214-92M2 裾引き (Blindhemming) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 40mm 33 34 35 36 jintex.in

Page 85 — SPECIFIC PARTS (14)

専用部品 (14) SPECIFIC PARTS (14) * = 原則販売不可 (not for sale basically) REF. PART NO. NO. 部品番号 名 称 QT. 1 XXXXXX 押工 1 2 XXXXXX 押工爪 PRESSER FOOT PRESSER FOOT FINGER 1 3 210584 押工補助板 UNCURLER 1 4 5030 平ネジ / C1×2.3 SCREW 1 5 210585 座金 WASHER 1 6 210685 定規ブラケット (組) CLOTH GUIDE BRACKET ASSEMBLY 1 7 210680 定規ブラケット CLOTH GUIDE BRACKET 1 8 210681 ヒンジ / 定規ブラケット HINGE/EDGE GUIDE BRACKET 1 9 5184 段付ネジ / C5 SCREW 1 10 201191 皿バネ SPRING 1 11 3044 六角ナット / C5 NUT 1 12 210682 ストッパー / ヒンジ STOPPER 1 13 5053 平ネジ / C4×4.8 SCREW 1 14 210683 段付ピン PIN 1 15 210684 板バネ FLAT SPRING 1 16 2906 平ネジ / C4×2.6 SCREW 1 17 7020 平ネジ / M4×10 SCREW 1 18 201252 バネ座金 SPRING WASHER 1 19 210691 裾引定規台 (組) CLOTH GUIDE COMPLETE 1 20 210690 ブラケット BRACKET 1 21 5088 六角ネジ / C4×7.5 SCREW 2 22 167066 座金 WASHER 2 23 205361 裾引定規台 CLOTH GUIDE 1 24 5057 平ネジ / C3×5 SCREW 1 25 210689 調節板 ADJUSTING PLATE 1 26 5157 平ネジ / C3×4.5 SCREW 2 27 2430 調節ネジ / C3 SCREW 1 28 2905 平ネジ / C5×4.5 SCREW 1 29 137142 座金 WASHER 1 30 210692 ストッパー STOPPER 1 31 1206 平ネジ / C4×5.3 SCREW 1 32 201211C91 定規羽根 (40MM) FOLDER COMPLETE (40MM) 1 33 205835 補助羽根 AUXILIARY PLATE 1 34 5299 平ネジ / C3×2.6 SCREW 1 35 303312A 羽根駒 REGULATOR 1 36 303313 板バネ FLAT SPRING 1 XXXXXX はゲージパーツです。 120-133頁のゲージパーツ表で確認してください。 XXXXXX is one of the gauge parts. Please confirm the correct part by the gauge parts lists on pages 120-133. 83 jintex.in

Page 86 — オプション (Option)

オプション (Option) EX5203-22 EX5204-01,02,24,32R1,32R2 EX5212-02 EX5214-01,03,03C3,M03,M03C3,24 53,53C3,M53,M53C3,54, EX5214H-55 EX3215-3216-01,01A,02,02A,03,04 EX3244-03,04 EX3215H-3216H-05 EX5200(H) Series 20 EX3200(H) Series 21 14 18 19 1 4 5 2 7 8 3 9 10 11 12 13 15 16 17

Page 87 — 当定規

当定規 FABRIC EDGE GUIDE REF. PART NO. NO. 部品番号 1 210685 2 210680 3 210681 4 5184 5 201191 6 3044 7 210682 8 5053 9 210683 10 210684 11 2906 12 7020 13 201252 14 210686 15 210687 16 5088 17 167066 18 1202 19 167066 20 204667 21 201233A NAME 定規ブラケット(組) 定規ブラケット ヒンジ/定規ブラケット 段付ネジ/C5 皿バネ 六角ナット/C5 ストッパー/ヒンジ 平ネジ/C4×4.8 段付ピン 板バネ 平ネジ/C4×2.6 平ネジ/M4×10 バネ座金 当定規台(組) 当定規台 六角ネジ/C4×7.5 座金 平ネジ/C4×7 座金 当定規 当定規 QT. CLOTH GUIDE BRACKET ASSEMBLY CLOTH GUIDE BRACKET HINGE/EDGE GUIDE BRACKET SCREW SPRING NUT STOPPER SCREW PIN FLAT SPRING SCREW SCREW SPRING WASHER BRACKET COMPLETE/EDGE GUIDE BRACKET/EDGE GUIDE SCREW WASHER SCREW WASHER EDGE GUIDE EDGE GUIDE 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 1 jintex.in

Page 88 — GAUGE PARTS CONSTRUCTION CHART

地縫用 (2本針) PLAIN SEAMING (2- NEEDLE) EX3200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX3215-01/222(K) EX3216 EX3215-02/223(K) EX3216 NGXSW 2X4 277514P30 2X4 277514P40 SW NG NGXSW 3X3 277513P30 SW NG NGXSW 3X4 277513P40 3X5 277513P50 SW NG NGXSW 2X3 277514R30 2X4 277514R40 SW NG NGXSW 3X3 277515R30 SW NG NGXSW 3X4 277513R40 3X5 277513R50 SW NG 277323-13 277324-13 277318-13 1.25 1.25 277323-16 277324-16 277318-13 1.6 1.25 277326-13 277325-13 1.5 1.6 277326-16 277325-16 1.6 NGXSW 2X3 277117 2X4 277117 NG NGXSW 3X3 277118 3X4 277118 3X5 277118 NG jintex.in

Page 89

EX3215 - 01/222(K) EX3216 NG 2 277026-92 275030 NG EX3215 - 02/223(K) EX3216 NG 3 277027-92 275030 EX3215 277014A #8 EX 3216 277010 #2 277015 277018 -01/222 -02/223 -01/222K -02/223K 201121A 210755 202295 地縫用(極薄生地) PLAIN SEAMING (EXTRA LIGHT WEIGHT FABRIC) 地縫用(薄生地) PLAIN SEAMING (LIGHT WEIGHT FABRIC) オーバーロック針受 OVERLOCK NEEDLE GUARD 277007 二重環針受 CHAINSTITCH NEEDLE GUARD 277008 277006 - 87 - jintex.in

Page 90 — GAUGE PARTS CONSTRUCTION CHART

地縫用(小廻り仕様) PLAIN SEAMING (SMALL FOOT) EX3200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX3215-01A/222 EX3216 EX3215-02A/223 EX3216 NGXSW 2×3 277514P40 2×4 277514P40 SW NG NGXSW 3×3 277515P40 SW NG NGXSW 2×3 277514R30 2×4 277514R40 SW NG NGXSW 3×3 277515R30 SW NG NGXSW 3×4 277513R40 3×5 277513R50 SW NG 277323-13 277324-13 277318-13 1.25 1.25 277323-16 277324-16 277318-13 1.6 1.25 277326-13 277325-13 277326-16 277325-16 1.6 1.6 NGXSW 2×3 211907 2×4 211907 NG NGXSW 3×3 211909 3×4 211909 NG NGXSW 3×5 211910 NG jintex.in

Page 91

EX3215 - 01A/222 EX3216 NG 2 277026-92 275030 NG EX3215 - 02A/223 EX3216 NG 3 277027-92 275030 EX3215 277014A #8 EX3216 277010 #2 277015 277018 202527A 202295 地縫用(極薄生地) PLAIN SEAMING (EXTRA LIGHT WEIGHT FABRIC) SMALL FOOT (GOOD FOR CURVING) 地縫用(薄生地) PLAIN SEAMING (LIGHT WEIGHT FABRIC) SMALL FOOT (GOOD FOR CURVING) 90 jintex.in

Page 92

地縫用 (2本針) PLAIN SEAMING (2- NEEDLE) EX3200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX3215-03/233(K) EX3216 NGXSW 3×4 277517R40 3×5 277517R50 SW NG NGXSW 3×4 277516R50 3×6 277516R60 SW NG NGXSW 5×5 277516R50 SW NG 277327-16 277328-16 277318-13 1.6 1.25 277330-16 277329-16 277118 NG 277119 NG jintex.in

Page 93

EX3215 - 03/233(K) EX3216 NG 3 277027-92 275030 EX3215 277014B #9 EX3216 277010A #5 277015 -03/233 -03/333 201121A EX3215 - 03/333(K) EX3216 NG 5 277028-92 275030 EX3215 277014A #8 EX3216 277010 #2 277018 -03/233K -03/333K 210755 202295 地縫用(中厚生地) PLAIN SEAMING (MEDIUM WEIGHT FABRIC) 地縫用(中厚生地) PLAIN SEAMING (MEDIUM WEIGHT FABRIC) 01 jintex.in

Page 95

EX3215-04/435(K) EX3216 EX3215H-05/535(K) EX3216H NG 5 277029-92 275030A NG EX3215 277014 #1 EX3216 277011 #3 EX3215 277014A #8 EX3216 277017 #11 277015 277018-C 277015A 277018-C -04/435 -05/535 -04/435K -05/535K 277000 211662 277009 地縫用(厚生地) PLAIN SEAMING (HEAVY WEIGHT FABRIC) 地縫用(極厚生地) PLAIN SEAMING (EXTRA HEAVY WEIGHT FABRIC) 02 jintex.in

Page 97

EX3244-03/333(K) NG 3X2 277030-92 275030 NG NG EX3244-04/435(K) NG 5X3 277032-92 275030A NG NG 277010A #5 277011 #3 277015 277018 277015 277018-C -03/333 201121A -03/333K 210755 202295 -04/435 277000 -04/435K 211662 277009 地縫用(中厚生地) PLAIN SEAMING (MEDIUM WEIGHT FABRIC) 地縫用(厚生地) PLAIN SEAMING (HEAVY WEIGHT FABRIC) jintex.in

Page 98 — EX3200 Series GAUGE PARTS CONSTRUCTION CHART

ヒダ取り用 SHIRRING EX3200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX3215-42/233(K) EX3216 NGXSW 3×4 277521R40 3×5 277521R50 SW NG 277334-16 277335-16 1.6 277318-13 NGXSW 5×5 277520R50 5×6 277520R60 SW NG 277331-16 277332-16 1.25 277318-13 EX3215-43/335(K) EX3216 NGXSW 5×5 277520S50 5×6 277520S60 SW NG 277331-25 277332-25 2.5 277318-13 1.25 277336-16 277333-16 277333-25 NGXSW 3×4 277120 3×5 277120 NG NGXSW 5×5 277121 5×6 277121 NG jintex.in

Page 99

EX3215 - 42/233(K) EX3216 NG 3 277027-92 275030 NG EX3215 277014B #9 EX3216 277010A #5 EX3215 - 43/335(K) EX3216 NG 5 277028-92 275030 NG EX3215 277014A #8 EX3216 277010 #2 277015 277018 -42/233 -43/335 201121A -42/233K -43/335K 210755 202295 ヒダ取り用(薄生地) SHIRRING (LIGHT WEIGHT FABRIC) ヒダ取り用(中厚生地) SHIRRING (MEDIUM WEIGHT FABRIC) 07 jintex.in

Page 100 — EX3200 Series

テープ付用 ATTACHING TAPE EX3200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX3216-53/233(K) NGXSW 3×4 277523R40 3×5 277523R50 SW NG NGXSW 5×5 277522R50 SW NG 277327-16 277328-16 277318-13 1.6 1.25 277330A16 277329A16 277118B 277119B NG jintex.in

Page 101 — EX3216-53/233(K)

EX3216-53/233(K) NG 3 277027-92 275030 NG NG 5 277028-92 275030 277010 #2 277015 277018 -53/233 -53/233K 201121A 210755 202295 テープ付用(中厚生地) ATTACHING TAPE (MEDIUM WEIGHT FABRIC) 06 jintex.in

Page 102 — EX5200 Series

地縫用 (1 本針) PLAIN SEAMING (1 - NEEDLE) EX5200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX5204-01/223(K) SW 3 277500P30 4 277500P40 5 277500P50 SW EX5204-02H/223(K) SW 3 277500P30 4 277500P40 SW EX5204-02/233(K) SW 3 277504R30 4 277504R40 5 277504R50 SW 277300-16F 277301-16F 277318-13 1.6 1.25 277303-16F 277304-16F 277318-13 1.6 1.25 277302-16F 277305-16F 201230C 211991A SW 3 210370 #1 4 210371 #2 5 210371 #2 SW 3 277115A #12 4 277103A #13 jintex.in

Page 103

EX5204-01/223(K) EX5204-02H/223(K) EX5204-02/233(K) 179630-92 275019A 277010 #2 277015 -01/223 -02H/223 201121A -01/223K -02H/223K 210755 202295 -02/233 201121A -02/233K 210755 SW 3 201127 SW 4 202295 5 202295 地縫用(極薄生地) PLAIN SEAMING (EXTRA LIGHT WEIGHT FABRIC) 地縫用(薄生地) PLAIN SEAMING (LIGHT WEIGHT FABRIC) 地縫用(薄生地) PLAIN SEAMING (LIGHT WEIGHT FABRIC) 277005 277004 101 jintex.in

Page 104 — EX5200 Series

地縫用 (2本針) PLAIN SEAMING (2- NEEDLE) EX5200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX5214-01/233(K) NGXSW 2×3 277505P30 2×4 277505P40 SW NG EX5212-02/333(K) NGXSW 2×3 277505R30 2×4 277505R40 2×5 277505R50 SW NG 277303-16F 277304-16F 277318-13 1.6 1.25 277305-16F 201230C SW 3 201396B 4 201310A SW 3 210503 #5 4 210374 #7 5 210374 #7 jintex.in

Page 105

EX5214-01/233(K) EX5212-02/333(K) NG 2 277022-92 275019B NG 277010B #6 277013 #7 277015 -01/233 -02/333 -01/233K -02/333K 201121A 210755 202295 地縫用(極薄生地) PLAIN SEAMING (EXTRA LIGHT WEIGHT FABRIC) 地縫用(薄生地) PLAIN SEAMING (LIGHT WEIGHT FABRIC) - 103 - jintex.in

Page 106 — EX5200 Series

地縫用 (2本針) PLAIN SEAMING (2- NEEDLE) EX5200 Series EX524-03/333(K) EX5214-03C3/333(K) ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX5214-M03/333(K) EX5214-M03C3/333(K) NGXSW 2×3 277505 R30 2×4 277505 R40 2×5 277505 R50 SW NG 277303-16F 277304-16F 277318-13 1.6 1.25 277305-16F 1.6 201230C SW 3 210503 #5 4 210374 #7 5 210374 #7 jintex.in

Page 107

EX5214-03/333(K) EX5214-03C3/333(K) NG 2 277022-92 275019B NG EX5214-M03/333(K) EX5214-M03C3/333(K) 277010A #5 277015 277034 -03-03C3/333 -M03-M03C3/333 -03-03C3/333K -M03-M03C3/333K 201121 A 210755 202295 地縫用(中厚生地) PLAIN SEAMING (MEDIUM WEIGHT FABRIC) 地縫用(中厚生地) PLAIN SEAMING (MEDIUM WEIGHT FABRIC) 105 jintex.in

Page 108 — EX5200 Series

掲引用 サージング用 BLINDSTITCH HEMMING SERGING EX5205- 12/223(K) EX5203- 12/223(K) EX5200 Series EX5203- 22/233(K) EX5204- 24/445(K) EX5214- 24/445(K) SW 3 277500P30 4 277500P40 SW 5 277504R50 6 277504R60 SW 7 277511S70 8 277511S80 NGXSW 3X4 277510S40 3X5 277510S50 SW SW SW NG 277300-16F 277301-16F 277318-13 1.6 277303A 16 277304-16 277318A13 1.25 277309-25F 277310-25F 277318A13 2.5 1.25 277302-16F 277305-16F 277311-25F 2.5 201152E 202799 277110 SW 3 277115 #10 4 277103 #11 SW 5 210371 #2 6 210372 #3 SW 7 210372 #3 8 210372 #3 SW 4 210376 #8 5 210376 #8 ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART jintex.in

Page 109

EX5205-12/223(K) EX5203-12/223(K) 179630-92 275019A EX5203-22/233(K) EX5204-24/445(K) EX5214-24/445(K) NG 3 277024-92 275019C NG EX5203 277014A #8 EX5205 277010 #2 277014B #9 277011 #3 277015 -12/223 -22/233 -24/445 -24/445K 201121A 210755 202295 277000 211662 277009 锯引用(薄生地) BLINDSTITCH HEMMING (LIGHT WEIGHT FABRIC) サージング用(薄生地) SERGING (LIGHT WEIGHT FABRIC) サージング用(厚生地) SERGING (HEAVY WEIGHT FABRIC) 107 jintex.in

Page 110 — EX5200 Series

下巻縫用 TURN DOWN HEMMING EX5200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX5204-32R1/223(K) SW 3 277503 S30 EX5204-32R2/223(K) SW 1.5 277512P15 SW EX5204-32R2/223L(K) SW 1.5 277502P15 277300-16F 277301-16F 277318-13 277315-16F 277301-16F 277319-13 277302-16F 202799 SW 3 210761 SW 1.5 205525 jintex.in

Page 111

EX5204-32R1/223(K) EX5204-32R2/233L(K) EX5204-32R2/223(K) 179630-92 275019A 277010A #5 277010 #2 277015 -32R1/223 -32R2/233L -32R2/223 201121A -32R1/223K -32R2/233LK -32R2/223K 210755 202295 下巻縫用(薄生地) TURN DOWN HEMMING (LIGHT WEIGHT FABRIC) 下巻縫用(薄生地) TURN DOWN HEMMING (LIGHT WEIGHT FABRIC) 下巻縫用(薄生地) TURN DOWN HEMMING (LIGHT WEIGHT FABRIC) 109 jintex.in

Page 112 — GAUGE PARTS CONSTRUCTION CHART

ヒダ取り用 ヒダ取り・パイピング用 SHIRRING SHIRRING・PIPING EX5200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX5214-43/333(K) EX5214-43P1/333(K) EX5214-43P2/333(K) NGXSW 2×3 277505R30 2×4 277505R40 SW NG 277306-16 277307-16 277318-13 1.6 1.25 277308-16 SW 3 277124 4 277124 SW 3 277125 4 277125 jintex.in

Page 113

EX5214-43/333(K) EX5214-43P1/333(K) EX5214-43P2/333(K) NG 2 277022-92 275019B NG 277010A #5 277015 -43/333 -43P1-43P2/333 201121A -43/333K -43P1-43P2/333K 210755 202295 ヒダ取り用(中厚生地) SHIRRING (MEDIUM WEIGHT FABRIC) ヒダ取り・パイピング用 (中厚生地) SHIRRING PIPING (MEDIUM WEIGHT FABRIC) ヒダ取り・パイピング用 (中厚生地) SHIRRING PIPING (MEDIUM WEIGHT FABRIC) 111 jintex.in

Page 115

EX5214-53/333(K) EX5214-53C3/333(K) NG 2 277022-92 275019B NG 277010A #5 277015 277034 -53-53C3/333 -M53-M53C3/333 201121A -53-53C3/333K -M53-M53C3/333K 210755 202295 EX5214-M53/333(K) EX5214-M53C3/333(K) テープ付用(中厚生地) ATTACHING TAPE (MEDIUM WEIGHT FABRIC) テープ付用(中厚生地) ATTACHING TAPE (MEDIUM WEIGHT FABRIC) jintex.in

Page 116

テープ付用 ATTACHING TAPE EX5200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX5214-54/433(K) NGXSW 2×3 277503 R30 2×4 277503 R40 2×5 277503 R50 SW NG EX5214-54/443(K) NGXSW 2.5×3 277507R30 2.5×4 277507R40 2.5×5 277507R50 SW NG EX5214H-55/545(K) NGXSW 2.5×3.5 277526 S35 2.5×4.5 277526 S45 SW NG EX5214-54/445(K) NGXSW 3×4 277510 S40 3×5 277510 S50 SW NG 277303-16F 277304-16F 277318-13 1.6 1.25 277351-16F 277352-16F 277318-13 1.6 1.25 277351-25F 277352-25F 277318-13 2.5 1.25 277316-16F 277353A25F 277112 277111 277127 SW 3 277159 #22 4 208651 5 208651 SW 3 277159 #22 4 277104 #16 5 277104 #16 SW 3.5 277105 #17 4.5 277105 #17 SW 3.5 277157 #19 4 277158 #20 5 277158 #20 SW 3.5 277105 #17 4.5 277105 #17 jintex.in

Page 117

EX5214-54/433(K) EX5214-54/443(K) EX5214H-55/545(K) EX5214-54/445(K) NG 2 277022-92 275019B NG 2.5 277023-92 275019C NG 3 277024-92 275019C NG NG 277011 #3 277019 #12 277012 #4 277015 277016A 277016 -54/433 -54/443 -54/433K -54/443K -54/445 -55/545 -54/445K -55/545K 201121A 210755 202295 277000 211662 202295 テープ付用(厚生地) ATTACHING TAPE (HEAVY WEIGHT FABRIC) テープ付用(極厚生地) ATTACHING TAPE (EXTRA HEAVY WEIGHT FABRIC) テープ付用(厚生地) ATTACHING TAPE (HEAVY WEIGHT FABRIC) 115 jintex.in

Page 119

EX5204-82/233(K) EX5204-82/223(K) EX5214-83/323(K) EX5214-84/423(K) 179630-92 275019A NG 2 277022-92 275019B NG 277010 #2 277010A #5 277011 #3 277015 -82/233 201121A -82/233K 210755 SW 3 201127 4 202295 5 202295 -82/223 -83/323 -84/423 201121A 210755 202295 バックタック用(薄生地) BACKLATCHING (LIGHT WEIGHT FABRIC) バックタック用(中厚生地) BACKLATCHING (MEDIUM WEIGHT FABRIC) バックタック用(厚生地) BACKLATCHING (HEAVY WEIGHT FABRIC) 117 jintez.in

Page 120 — EX5200 Series

多用途 MULTI-USE EX5200 Series ゲージパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART EX5204-92M1/223(K) SW 3 277531-30 4 277531-40 SW EX5214-92M2/223(K) NGXSW 2×3 277501R30 2×4 277501R40 SW NG 277340-16F 277341-16F 277318-13 1.6 277300-16F 277301-16F 277318-13 1.6 1.25 277342-16F 277302-16F 1.6 211991A 201152E SW SW 3 277115A #12 4 277103A #13 SW 3 201396B 4 201310A jintex.in

Page 121

EX5204-92M1/223(K) 179630-92 275019A 277010 #2 -92M1/223 -92M2/223 201121A 多用途用(薄生地) MULTI-USE (LIGHT WEIGHT FABRIC) EX5214-92M2/223(K) NG 2 277022-92 275019B NG 277010B #6 277015 -92M1/223K -92M2/223K 210755 202295 多用途用(薄生地) MULTI-USE (LIGHT WEIGHT FABRIC) 110 jintex.in

Page 127 — GAUGE PARTS LIST (1)

EX5200 Series ゲージパーツ表 (1) EX5200 Series GAUGE PARTS LIST (1) 差動送り歯 主送り歯本体 主送り歯(組) 差動送り歯 押工爪 下ルーバー 押工爪 下ルーバー 押工 押工 DIFF. FEED DOG MAIN FEED DOG MAIN FEED DOG ASS. DIFF. FEED DOG PRESSER FOOT FINGER LOWER LOOPER PRESSER FOOT 押工 押工 GAUGE GAUGE GAUGE GAUGE GAUGE GAUGE GAUGE GAUGE MACHINE TYPE /SPEC. MACHINE TYPE /SPEC. NG SW NG SW NG SW NG SW EX5204-01/223(K) EX5204-01/233(K) 277302-16F 277305-16F 277300-16F 277303-16F 277318-13 277318-13 277015 277015 277010 #1 277010 #2 277010B #8 277010B #8 201230C 201230C 201396B 201310A 201230C 201230C 201396B 201310A 40 50 4 3 3 2 4 4 2 3 4 5 3 4 針 針 針 針 下メス 下メス 上メス 上メス 後 前 針 針 THREAD NEEDLE HOLDER NEEDLE HOLDER GUARD FRONT LOWER KNIFE UPPER KNIFE ANGLED KNIFE NEEDLE (NDL HOLDER) GUIDE 277005 277005 277004 277004 202295 202295 210755 210755 210735 210735 275019A 275019B DC x 27 #9 DC x 27 #9 EX5204-01/223(K) EX5204-01/233(K) 179630-92 277022-92 277019A 277019B 3 4 5 3 4 2 3 4 5 3 4 2 - 125 - jintex.in

Page 139

jinte x.in jintex.in

Page 140

PEGASUS SEWING MACHINE MFG. CO., LTD. Cat. No.9605 December, 1993 © 1993 PEGASUS SEWING MACHINE MFG. CO., LTD. First edition ; issued in January 1991 Second edition ; issued in December 1992 Third edition ; issued in December 1993 初版(1991年1月発行) 第二版(1992年12月発行) 第三版(1993年12月発行) jintex.in
