Pegasus EX3200 Series Parts Book (PDF)
Text index — Pegasus EX3200 Series
Page 5 — MACHINE BED FRAME
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| *1 | 270001-9S | MACHINE BED COMPLETE | 1 |
| *2 | 270001A9S | MACHINE BED COMPLETE | 1 |
| *3 | 270055-9S | MACHINE BED COMPLETE | 1 |
| *4 | 270055A9S | MACHINE BED COMPLETE | 1 |
| 5 | 240333 | ROD | 1 |
| 6 | 201002 | PIN | 1 |
| 7 | 210194 | INDICATOR GUIDE | 1 |
| 8 | 240325 | PIPE | 2 |
| 9 | 240299 | PIN | 1 |
| 10 | 208173 | PLUG | 1 |
| 11 | 270008-91 | BRACKET ASSEMBLY | 1 |
| 12 | 4511 | SCREW | 2 |
| 13 | 270047 | BED PIN | 4 |
Page 7 — COVER (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 270020-SD | TOP COVER | 1 |
| 2 | 7022 | SCREW | 4 |
| 3 | 270021 | GASKET | 1 |
| 4 | 240305 | CUSHION RUBBER | 3 |
| 5 | 179107-05 | OIL SIGHT WINDOW | 1 |
| 6 | 240110 | PLUG | 1 |
| 7 | 270010-UD | SIDE COVER | 1 |
| 8 | 7044 | SCREW | 4 |
| 9 | 270024-9U | BELT COVER ASSEMBLY | 1 |
| *10 | 270024-UB | BELT COVER | 1 |
| 11 | 240305 | CUSHION RUBBER | 1 |
| 12 | 7176 | SCREW | 3 |
| 13 | 270025 | FAN COVER | 1 |
| 14 | 7019 | SCREW | 2 |
| 15 | 270011-UD | FRONT COVER (RIGHT) | 1 |
| 16 | 270014 | HINGE | 1 |
| 17 | 7021 | SCREW | 3 |
| 18 | 240043 | PIN | 1 |
| 19 | 4543 | SCREW | 2 |
| 20 | 240301 | SPRING | 1 |
| 21 | 270018 | LATCH | 1 |
| 22 | 7009 | SCREW | 1 |
| 23 | 4574 | SCREW | 1 |
| 24 | 4535 | SCREW | 1 |
| 25 | 270017 | LATCH | 1 |
| 26 | 7017 | SCREW | 1 |
| 27 | 210044 | FLAT SPRING | 1 |
| 28 | 7017 | SCREW | 1 |
| 29 | 270012 | FRONT COVER (LEFT) | 1 |
| 30 | 7018 | SCREW | 2 |
| 31 | 270028 | COVER | 1 |
| 32 | 7019 | SCREW | 2 |
| 33 | 7020 | SCREW | 1 |
| 34 | 7021 | SCREW | 1 |
| 35 | 270013 | FRONT COVER (LEFT) | 1 |
| 36 | 270010AUD | SIDE COVER | 1 |
Page 9 — COVER (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 270035 | CLOTH PLATE (WIDE) | 1 |
| 2 | 270037 | CLOTH PLATE (NARROW) | 1 |
| 3 | 270042 | BUSHING | 1 |
| 4 | 4543 | SCREW | 1 |
| 5 | 210307 | WASHER | 1 |
| 6 | 240303 | COLLAR | 1 |
| 7 | 4543 | SCREW | 1 |
| 8 | 240305 | CUSHION RUBBER | 1 |
| 9 | 270030-UB | SIDE COVER | 1 |
| 10 | 270031-UB | SIDE COVER | 1 |
| 11 | 7025 | SCREW | 1 |
| 12 | 201252 | SPRING WASHER | 1 |
| 13 | 7018 | SCREW | 2 |
| 14 | 240343 | WASHER | 2 |
| 15 | 240305 | CUSHION RUBBER | 1 |
| 16 | 270048 | LATCH | 1 |
| 17 | 7008 | SCREW | 1 |
| 18 | 270049 | LATCH | 1 |
| 19 | 7180 | SCREW | 1 |
| 20 | 270015 | PLATE | 1 |
| 21 | 7077 | SCREW | 2 |
| 22 | 270043 | LEVER | 1 |
| 23 | 7172 | SCREW | 1 |
| 24 | 270044 | SPRING | 1 |
| 25 | 270045 | BRACKET | 1 |
| 26 | 270019 | FABRIC GUARD | 1 |
| 27 | 7019 | SCREW | 2 |
| 28 | 270032 | EYE GUARD | 1 |
| 29 | 7062 | SCREW | 2 |
| 30 | 202875 | WASHER | 2 |
| 31 | 270034 | BRACKET | 1 |
| 32 | 7066 | SCREW | 1 |
| 33 | 210307 | WASHER | 2 |
| 34 | 270022 | BED COVER PLATE ASSEMBLY | 1 |
| 35 | 7084 | SCREW | 5 |
| 36 | 270023 | GASKET | 1 |
| 37 | 270046 | COVER/FEED ECCENTRIC | 1 |
| 38 | 7018 | SCREW | 2 |
| 39 | 270026 | COVER PLATE | 1 |
| 40 | 7020 | SCREW | 4 |
| 41 | 7023 | SCREW | 1 |
| 42 | 4821 | NUT | 1 |
| 43 | 270052 | NAME PLATE | 1 |
| 44 | 270053 | NAME PLATE | 1 |
| 45 | 210679 | PIN | 2 |
| 46 | 250233 | TYPE PLATE | 1 |
| 47 | 210679 | PIN | 2 |
| 48 | 230047A | SERIAL NUMBER PLATE | 1 |
| 49 | 210679 | PIN | 2 |
| 50 | 202526 | NAME PLATE | 1 |
| 51 | 270030-UB | SIDE COVER | 1 |
| 52 | 270033 | EYE GUARD | 1 |
Page 11 — CRANKSHAFT DRIVE MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 270500A | CRANKSHAFT | 1 |
| 2 | 270500B | CRANKSHAFT | 1 |
| 3 | 270512A | CRANKSHAFT | |
| 4 | 7151 | SCREW | 5 |
| 5 | 270502 | BALANCE WEIGHT | 2 |
| 6 | 7011 | SCREW | 4 |
| 7 | 270503 | PIN | 1 |
| 8 | 4541 | SCREW | 1 |
| 9 | 270508 | COVER | 1 |
| 10 | 7019 | SCREW | 3 |
| 11 | 240340 | O RING | 1 |
| 12 | 270507-91 | BALL BEARING COMPLETE | 1 |
| 13 | 4572 | SCREW | 2 |
| 14 | 4514 | SCREW | 1 |
| 15 | 240335 | RING | 1 |
| 16 | 212987 | BALL BEARING | 1 |
| 17 | 211526 | BALL BEARING | 1 |
| 18 | 240306 | WASHER | 1 |
| 19 | 210056 | OIL SEAL | 1 |
| 20 | 210057 | O RING | 1 |
| 21 | 240340 | O RING | 1 |
| 22 | 211528 | BALL BEARING RETAINER | 1 |
| 23 | 7020 | SCREW | 3 |
| 24 | 270505 | FAN COMPLETE | 1 |
| 25 | 270504-UD | MACHINE PULLEY | 1 |
| 26 | 4541 | SCREW | 2 |
| 27 | 4523 | BOLT | 1 |
| 28 | 204293 | SPRING WASHER | 1 |
| 29 | 270510 | PIN | 1 |
| 30 | 270509 | COVER | 1 |
| 31 | 7044 | SCREW | 2 |
| 32 | 7020 | SCREW | 1 |
Page 13 — THREAD TENSION MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 210529-9U | THREAD TENSION COMPLETE | 1 |
| 2 | 208447-UA | POST NUT | 1 |
| 3 | 208448 | SPRING BUSHING | 1 |
| 4 | 208450-UA | CUP | 1 |
| 5 | 210319 | TENSION DISC | 2 |
| 6 | 208449 | FELT | 1 |
| 7 | 5082A | SCREW STUD | 1 |
| 8 | 201037 | SPRING (HEAVY) | 1 |
| 9 | 210530-9U | THREAD TENSION COMPLETE | 1 |
| 10 | 201086 | SPRING (MEDIUM) | 1 |
| 11 | 275000 | THREAD EYELET | 1 |
| 12 | 7018 | SCREW | 1 |
| 13 | 275001 | THREAD EYELET | 1 |
| 14 | 202849 | TENSION GUIDE | 1 |
| 15 | 4009-HC | SCREW | 1 |
| 16 | 275041 | THREAD EYELET | 1 |
| 17 | 7018 | SCREW | 1 |
| 18 | 275040 | THREAD EYELET | 1 |
| 19 | 3044 | NUT | 1 |
Page 15 — Thread Guide & Thread Takeup (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275021 | BRACKET | 1 |
| 2 | 7082 | SCREW | 2 |
| 3 | 275024 | THREAD GUIDE | 1 |
| 4 | 275042 | THREAD EYELET | 1 |
| 5 | 4543 | SCREW | 1 |
| 6 | 275026 | BRACKET | 1 |
| 7 | 7017 | SCREW | 1 |
| 8 | 275022 | THREAD GUIDE | 1 |
| 9 | 4543 | SCREW | 1 |
| 10 | 275029 | THREAD GUIDE | 1 |
| 11 | 275029A | THREAD EYELET | 1 |
| 12 | 275052 | THREAD EYELET | 1 |
| 13 | 7017 | SCREW | 1 |
| 14 | 275028 | THREAD GUIDE | 1 |
| 15 | 275057 | THREAD EYELET | 1 |
| 16 | 7017 | SCREW | 1 |
| 17 | 275011 | BRACKET | 1 |
| 18 | 275012 | THREAD RETAINER | 1 |
| 19 | 7163 | SCREW | 1 |
| 20 | 240326 | SPRING | 1 |
| 21 | 275027 | THREAD TAKEUP | 1 |
| 22 | 275044 | THREAD TAKEUP | 1 |
| 23 | 7062 | SCREW | 2 |
| 24 | 275049 | THREAD TAKEUP | 1 |
| 25 | 7041 | SCREW | 1 |
| 26 | 7062 | SCREW | 1 |
Page 17 — THREAD GUIDE & THREAD TAKEUP (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275013A | THREAD EYELET | 1 |
| 2 | 275013 | THREAD EYELET | 1 |
| 3 | 4543 | SCREW | 1 |
| 4 | 275015 | BRACKET | 1 |
| 5 | 7082 | SCREW | 1 |
| 6 | 275018 | THREAD EYELET | 1 |
| 7 | 275018A | THREAD EYELET | 1 |
| 8 | 275051A | THREAD EYELET | 1 |
| 9 | 7082 | SCREW | 1 |
| 10 | 275011 | BRACKET | 1 |
| 11 | 275012 | THREAD RETAINER | 1 |
| 12 | 7163 | SCREW | 1 |
| 13 | 240326 | SPRING | 1 |
| 14 | 275016 | THREAD TAKEUP | 1 |
| 15 | 275017 | THREAD TAKEUP | 1 |
| 16 | 7062 | SCREW | 2 |
| 17 | 275017A | THREAD TAKEUP | 1 |
| 18 | 7041 | SCREW | 1 |
| 19 | 7062 | SCREW | 1 |
Page 19 — THREAD GUIDE & THREAD TAKEUP (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275004 | BRACKET | 1 |
| 2 | 275047 | THREAD GUIDE (RIGHT) | 2 |
| 3 | 7008 | SCREW | 2 |
| 4 | 202875 | WASHER | 2 |
| 5 | 275005 | THREAD TAKEUP | 1 |
| 6 | 7019 | SCREW | 1 |
| 7 | 275006 | THREAD EYELET | 1 |
| 8 | 7008 | SCREW | 1 |
| 9 | 275007 | THREAD EYELET | 1 |
| 10 | 275008 | THREAD EYELET | 1 |
| 11 | 275055 | THREAD EYELET | 1 |
| 12 | 275010 | THREAD EYELET | 1 |
| 13 | 275056 | THREAD EYELET | 1 |
| 14 | 275009 | THREAD TAKEUP | 1 |
| 15 | 275054 | THREAD TAKEUP | 1 |
| 16 | 7012 | SCREW | 1 |
Page 21 — NEEDLE DRIVE MECHANISM (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 271000-92 | CONNECTION | 1 |
| 2 | 7023 | SCREW | 2 |
| 3 | 271001 | PIN | 1 |
| 4 | 4538 | SCREW | 1 |
| 5 | 271002-92 | CRANK | 1 |
| 6 | 4533 | SCREW | 1 |
| 7 | 271003 | SHAFT | 1 |
| 8 | 240308 | COLLAR | 1 |
| 9 | 4543 | SCREW | 2 |
| 10 | 208235 | WASHER | 1 |
| 11 | 202577 | RING | 1 |
| 12 | 271004-92 | LEVER | 1 |
| 13 | 7150 | BOLT | 1 |
| 14 | 271022-91 | SHAFT ASSEMBLY | 1 |
| 15 | 271008-T | SHAFT | 1 |
| 16 | 202177 | OIL WICK | 2 |
| 17 | 271005-91T | BUSHING ASSEMBLY | 1 |
| 18 | 271006-T | NEEDLE BAR | 1 |
| 19 | 271007 | BUSHING | 1 |
| 20 | 4546 | SCREW | 1 |
| 21 | 201022 | O RING | 1 |
| 22 | 179009-05 | OIL FELT | 1 |
| 23 | 271009-92 | RING | 1 |
| 24 | 7035 | SCREW | 1 |
| 25 | 240310 | PLUG | 1 |
Page 23 — NEEDLE DRIVE MECHANISM (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 271000-92 | CONNECTION | 1 |
| 2 | 7023 | SCREW | 2 |
| 3 | 271001 | PIN | 1 |
| 4 | 4538 | SCREW | 1 |
| 5 | 271002-92 | CRANK | 1 |
| 6 | 4533 | SCREW | 1 |
| 7 | 271003 | SHAFT | 1 |
| 8 | 240308 | COLLAR | 1 |
| 9 | 4543 | SCREW | 2 |
| 10 | 208235 | WASHER | 1 |
| 11 | 202577 | RING | 1 |
| 12 | 271015-92 | LEVER | 1 |
| 13 | 7150 | BOLT | 1 |
| 14 | 271016 | LINK | 1 |
| 15 | 271017 | PIN | 2 |
| 16 | 7185 | SCREW | 2 |
| 17 | 271023-91 | SHAFT ASSEMBLY | 1 |
| 18 | 271021 | PIN | 1 |
| 19 | 202176 | OIL WICK | 2 |
| 20 | 4545 | SCREW | 1 |
| 21 | 271018-91 | BUSHING ASSEMBLY | 1 |
| 22 | 271020 | BUSHING | 1 |
| 23 | 271019 | NEEDLE BAR | 1 |
| 24 | 4546 | SCREW | 1 |
| 25 | 201022 | O RING | 1 |
| 26 | 179009-05 | OIL FELT | 1 |
| 27 | 271009-92 | RING | 1 |
| 28 | 7035 | SCREW | 1 |
| 29 | 240310 | PLUG | 1 |
Page 25 — 針振り機構(3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | NEEDLE HOLDER ASSEMBLY | 1 |
| 2 | 4554 | SCREW | 2 |
| 3 | 275030 | THREAD GUIDE | 1 |
| 4 | 7119 | SCREW | 1 |
| 5 | XXXXXX | NEEDLE | 2 |
| 6 | XXXXXX | NEEDLE HOLDER ASSEMBLY | 1 |
| 7 | 4554 | SCREW | 3 |
| 8 | 275030 | THREAD GUIDE | 1 |
| 9 | 7119 | SCREW | 1 |
| 10 | XXXXXX | NEEDLE HOLDER ASSEMBLY | 1 |
| 11 | 4554 | SCREW | 1 |
| 12 | 275019A | THREAD GUIDE | 1 |
| 13 | 7120 | SCREW | 1 |
| 14 | XXXXXX | NEEDLE | 1 |
| 15 | XXXXXX | NEEDLE | 1 |
| 16 | 4554 | SCREW | 2 |
| 17 | 275019B | THREAD GUIDE | 1 |
| 18 | 7120 | SCREW | 1 |
| 19 | XXXXXX | NEEDLE HOLDER | 1 |
| 20 | 4554 | SCREW | 2 |
| 21 | 275019C | THREAD GUIDE | 1 |
| 22 | 7120 | SCREW | 1 |
Page 27 — NEEDLE DRIVE MECHANISM (4)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | NEEDLE PLATE | 1 |
| 2 | 7170 | SCREW | 2 |
| 3 | 271010 | BRACKET (FRONT) | 1 |
| 4 | 7019 | SCREW | 2 |
| 5 | 240305 | CUSHION RUBBER | 2 |
| 6 | 271011 | BRACKET (REAR) | 1 |
| 7 | 7019 | SCREW | 2 |
| 8 | 7019 | SCREW | 1 |
| 9 | XXXXXX | NEEDLE GUARD (FRONT) | 1 |
| 10 | 7010 | SCREW | 2 |
| 11 | XXXXXX | NEEDLE GUARD (REAR) | 1 |
| 12 | 7259 | BOLT | 1 |
| 13 | 240222 | SPRING WSASHER | 1 |
| 14 | 7165 | SCREW | 1 |
| 15 | XXXXXX | NEEDLE GUARD (FRONT) | 1 |
| 16 | 7019 | SCREW | 1 |
| 17 | XXXXXX | NEEDLE GUARD (REAR) | 1 |
| 18 | 7010 | SCREW | 2 |
| 19 | 271013 | BRACKET | 1 |
| 20 | 7114 | SCREW | 2 |
| 21 | XXXXXX | NEEDLE PLATE | 1 |
| 22 | 7170 | SCREW | 2 |
| 23 | 271010 | BRACKET (FRONT) | 1 |
| 24 | 7019 | SCREW | 2 |
| 25 | 240305 | CUSHION RUBBER | 2 |
| 26 | 271011 | BRACKET (REAR) | 1 |
| 27 | 7019 | SCREW | 2 |
| 28 | 271012 | STOPPER | 1 |
| 29 | 7019 | SCREW | 1 |
| 30 | XXXXXX | NEEDLE GUARD (FRONT) | 1 |
| 31 | 7019 | SCREW | 1 |
| 32 | XXXXXX | NEEDLE GUARD (REAR) | 1 |
| 33 | 7259 | BOLT | 1 |
| 34 | 240222 | SPRING WSASHER | 1 |
| 35 | 7165 | SCREW | 1 |
Page 29 — UPPER LOOPER DRIVE MECHANISM (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 271500-92 | CONNECTION | 1 |
| 2 | 7023 | SCREW | 2 |
| 3 | 7022 | SCREW | 2 |
| 4 | 271501 | GUIDE | 1 |
| 5 | 7041 | SCREW | 2 |
| 6 | 271502-92 | CRANK | 1 |
| 7 | 271503-92 | CRANK | 1 |
| 8 | 4533 | SCREW | 1 |
| 9 | 271504 | SHAFT | 1 |
| 10 | 240338 | WASHER | 1 |
| 11 | 7174 | SCREW | 1 |
| 12 | 303067 | SPRING WASHER | 1 |
| 13 | 275540 | PLUG | 1 |
| 14 | 275541 | FILTER | 1 |
| 15 | 210122 | SPACER | 1 |
| 16 | 240312 | WASHER | 1 |
| 17 | 240102 | WASHER | 1 |
| 18 | 210586A | OIL SEAL | 1 |
| 19 | 271517-91 | UPPER LOOPER HOLDER ASSEMBLY | 1 |
| 20 | 271505-92 | LEVER | 1 |
| 21 | 7150 | BOLT | 1 |
| 22 | 179136-01 | PIN ASSEMBLY | 1 |
| 23 | 179137-05 | PIN | 1 |
| 24 | 202176 | OIL WICK | 2 |
| 25 | 4545 | SCREW | 1 |
| 26 | 271506-91 | UPPER LOOPER HOLDER ASSEMBLY | 1 |
| 27 | 271507 | UPPER LOOPER HOLDER | 1 |
| 28 | 179129-05 | GUIDE/UPPER LOOPER HOLDER | 1 |
| 29 | 179130-05 | OIL FELT | 1 |
| 30 | 7054 | SCREW | 1 |
| 31 | XXXXXX | UPPER LOOPER | 1 |
| 32 | 271510 | BASE/UPPER LOOPER HOLDER | 1 |
| 33 | 271510A | BASE/UPPER LOOPER HOLDER | 1 |
| 34 | 271510B | BASE/UPPER LOOPER HOLDER | 1 |
| 35 | 4510 | SCREW | 2 |
| 36 | 271511 | COVER | 1 |
| 37 | 7039 | SCREW | 1 |
| 38 | 7033 | SCREW | 1 |
| 39 | 8421 | OIL MARK | 1 |
Page 31 — 上ルーパー機構(2) / UPPER LOOPER DRIVE MECHANISM (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 271500A92 | CONNECTION | 1 |
| 2 | 7023 | SCREW | 2 |
| 3 | 7022 | SCREW | 2 |
| 4 | 271501 | GUIDE | 1 |
| 5 | 7041 | SCREW | 2 |
| 6 | 271512-92 | CRANK | 1 |
| 7 | 4533 | SCREW | 1 |
| 8 | 271504 | SHAFT | 1 |
| 9 | 240338 | WASHER | 1 |
| 10 | 7174 | SCREW | 1 |
| 11 | 303067 | SPRING WASHER | 1 |
| 12 | 275540 | PLUG | 1 |
| 13 | 275541 | FILTER | 1 |
| 14 | 210122 | SPACER | 1 |
| 15 | 240312 | WASHER | 1 |
| 16 | 210586A | OIL SEAL | 1 |
| 17 | 271518-91 | UPPER LOOPER HOLDER ASSEMBLY | 1 |
| *18 | 271505-92 | LEVER | 1 |
| 19 | 7150 | BOLT | 1 |
| 20 | 179136-01 | PIN ASSEMBLY | 1 |
| *21 | 179137-05 | PIN | 1 |
| 22 | 202176 | OIL WICK | 2 |
| 23 | 4545 | SCREW | 1 |
| *24 | 271513-91 | UPPER LOOPER HOLDER ASSEMBLY | 1 |
| *25 | 271514 | UPPER LOOPER HOLDER | 1 |
| *26 | 179129-05 | GUIDE/UPPER LOOPER HOLDER | 1 |
| 27 | 179130-05 | OIL FELT | 1 |
| 28 | 7054 | SCREW | 1 |
| 29 | XXXXXX | UPPER LOOPER | 1 |
| 30 | 271510C | BASE/UPPER LOOPER HOLDER | 1 |
| 31 | 4510 | SCREW | 2 |
| 32 | 271511A | COVER | 1 |
| 33 | 7039 | SCREW | 1 |
| 34 | 7033 | SCREW | 1 |
| 35 | 8421 | OIL MARK | 1 |
Page 33 — LOWER LOOPER DRIVE MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 271500-92 | CONNECTION | 1 |
| 2 | 7023 | SCREW | 2 |
| 3 | 7022 | SCREW | 2 |
| 4 | 271501 | GUIDE | 1 |
| 5 | 7041 | SCREW | 2 |
| 6 | 272000-92 | CRANK | 1 |
| 7 | 4533 | SCREW | 1 |
| 8 | 271504 | SHAFT | 1 |
| 9 | 240338 | WASHER | 1 |
| 10 | 7174 | SCREW | 1 |
| 11 | 303067 | SPRING WASHER | 1 |
| 12 | 240311 | WASHER | 1 |
| 13 | 210586A | OIL SEAL | 1 |
| 14 | XXXXXX | LOWER LOOPER | 1 |
| 15 | 7168 | SCREW | 1 |
| 16 | 272001-92 | LOWER LOOPER HOLDER ASSEMBLY | 1 |
| 17 | 7055 | SCREW | 1 |
| 18 | 7169 | SCREW | 1 |
| 19 | 273511-92 | CRANK | 1 |
| 20 | 4533 | SCREW | 1 |
| 21 | 4514 | SCREW | 1 |
Page 35 — 二重環ルーパー機構(1) / CHAINSTITCH LOOPER DRIVE MECHANISM (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 273500 | CONNECTION | 1 |
| 2 | 205015 | NEEDLE BEARING | 1 |
| 3 | 273501 | CRANK | 1 |
| 4 | 179160-05 | BUSHING | 1 |
| 5 | 7056 | SCREW | 1 |
| 6 | 240039 | WASHER | 1 |
| 7 | 273502 | SLIDER | 1 |
| 8 | 4531 | BOLT | 1 |
| 9 | 240062 | WASHER | 1 |
| 10 | 303067 | SPRING WASHER | 1 |
| 11 | 252515 | PIN | 1 |
| 12 | 208949 | O RING | 1 |
| 13 | 273504 | SHAFT | 1 |
| 14 | 273505-92 | HOLDER | 1 |
| 15 | 4533 | SCREW | 1 |
| 16 | 273509-92 | CRANK | 1 |
| 17 | 4533 | SCREW | 1 |
| 18 | 272517 | LINK | 1 |
| 19 | 179160-05 | BUSHING | 1 |
| 20 | 7056 | SCREW | 1 |
| 21 | 240039 | WASHER | 1 |
| 22 | 273506 | SHAFT | 1 |
| 23 | 204052A | OIL SEAL | 1 |
| 24 | XXXXXX | DOUBLE CHAINSTITCH LOOPER | 1 |
| 25 | 7168 | SCREW | 1 |
| 26 | 273510-92 | LOOPER HOLDER | 1 |
| 27 | 7055 | SCREW | 1 |
| 28 | 240337 | SPACER | 1 |
| 29 | 7169 | SCREW | 1 |
Page 37 — CHAINSTITCH LOOPER DRIVE MECHANISM (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275031 | THREAD GUIDE | 1 |
| 2 | 7019 | SCREW | 1 |
| 3 | 275032 | THREAD GUIDE | 1 |
| 4 | 206115 | HOLDER | 2 |
| 5 | 275033 | BRACKET | 1 |
| 6 | 7066 | SCREW | 1 |
| 7 | 210307 | WASHER | 2 |
| 8 | 7167 | SCREW | 1 |
| 9 | 137108 | TENSION DISC | 2 |
| 10 | 211388 | SPRING | 1 |
| 11 | 275034 | KNOB | 1 |
| 12 | 275035 | THREAD GUIDE | 1 |
| 13 | 7017 | SCREW | 1 |
| 14 | 275036 | THREAD GUIDE | 1 |
| 15 | 7008 | SCREW | 1 |
| 16 | 275039 | THREAD GUIDE | 1 |
| 17 | 7008 | SCREW | 1 |
| 18 | 179498-92 | LOOPER THREAD TAKEUP ASSEMBLY | 1 |
| 19 | 4554 | SCREW | 2 |
| 20 | 275037 | SPRING | 1 |
| 21 | 275038 | THREAD GUIDE | 1 |
Page 39 — FEED MECHANISM (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 272500 | CONNECTION | 1 |
| 2 | 271001 | PIN | 1 |
| 3 | 4538 | SCREW | 1 |
| 4 | 240012 | NEEDLE BEARING | 1 |
| 5 | 272501 | ECCENTRIC | 1 |
| 6 | 210129 | GUIDE/FEED ECCENTRIC | 1 |
| 7 | 210130 | FLAT SPRING | 1 |
| 8 | 4535 | SCREW | 1 |
| 9 | 4535 | SCREW | 1 |
| 10 | 272506-91 | REGULATOR | 1 |
| 11 | 4514 | SCREW | 2 |
| 12 | 272504-91 | ECCENTRIC ASSEMBLY | 1 |
| 13 | 272503 | SPRING | 1 |
| 14 | 7038 | SCREW | 1 |
| 15 | 272502 | RATCHET | 1 |
| 16 | 272509 | PUSH BUTTON | 1 |
| 17 | 240315 | GASKET | 1 |
| 18 | 240314 | WASHER | 1 |
| 19 | 240317 | SPRING | 1 |
| 20 | 200555 | RING | 1 |
| 21 | 272529 | LINK | 1 |
| 22 | 7058 | SCREW | 1 |
| 23 | 202522 | RING | 1 |
| 24 | 272530A92 | LEVER | 1 |
| 25 | 4533 | SCREW | 1 |
| 26 | 272532 | LEVER | 1 |
| 27 | 7161 | SCREW | 1 |
| 28 | 272533A | SHAFT | 1 |
| 29 | 204185 | O RING | 1 |
| 30 | 272534 | SPRING | 1 |
| 31 | 272535 | REGULATOR PLATE | 1 |
| 32 | 7021 | SCREW | 2 |
| 33 | 240321 | SPACER | 2 |
| 34 | 179202-25 | NUT | 1 |
| 35 | 7059 | SCREW | 1 |
| 36 | 211301 | SPRING WASHER | 1 |
| 37 | 252658 | STOPPER | 2 |
| 38 | 7018 | SCREW | 2 |
| 39 | 303448 | WASHER | 2 |
| 40 | 272538A | ADJUSTING BAR | 1 |
| 41 | 240322 | SEAL | 1 |
| 42 | 200555 | RING | 1 |
| 43 | 210533 | SPRING | 1 |
| 44 | 272539A | PIN | 1 |
Page 41 — FEED MECHANISM (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 272516 | SHAFT | 1 |
| 2 | 205061 | RING | 1 |
| 3 | 208173 | PLUG | 1 |
| 4 | 240311 | WASHER | 2 |
| 5 | 272510-91 | CRANK | 1 |
| 6 | 272511 | CRANK | 1 |
| 7 | 4534 | SCREW | 1 |
| 8 | 272512 | CRANK PIN | 1 |
| 9 | 272513 | CRANK PIN | 1 |
| 10 | 7010 | SCREW | 2 |
| 11 | 272518 | BLOCK | 1 |
| 12 | 272514-92 | CRANK | 1 |
| 13 | 4533 | SCREW | 1 |
| 14 | 272515 | PIN | 1 |
| 15 | 4805 | NUT | 1 |
| 16 | 240062 | WASHER | 1 |
| 17 | 272525 | PIN | 1 |
| 18 | 7238 | SCREW | 1 |
| 19 | 240318 | GASKET | 1 |
| 20 | 240319 | RING | 1 |
| 21 | 201022 | O RING | 1 |
| 22 | 272526 | BLOCK | 1 |
| 23 | 240303 | COLLAR | 2 |
| 24 | 4543 | SCREW | 2 |
| 25 | 272517 | LINK | 1 |
| 26 | 179160-05 | BUSHING | 1 |
| 27 | 7056 | SCREW | 1 |
| 28 | 240039 | WASHER | 1 |
| 29 | 272527 | MAIN FEED BAR | 1 |
| 30 | XXXXXX | MAIN FEED DOG COMPLETE | 1 |
| 31 | XXXXXX | MAIN FEED DOG | 1 |
| 32 | XXXXXX | AUXILIARY FEED DOG | 1 |
| 33 | 7010 | SCREW | 1 |
| 34 | 7013 | SCREW | 1 |
| 35 | 272528 | DIFFERENTIAL FEED BAR | 1 |
| 36 | XXXXXX | DIFFERENTIAL FEED DOG | 1 |
| 37 | 7013 | SCREW | 1 |
| 38 | 272524 | BLOCK | 1 |
| 39 | 272519 | GUIDE/FEED BAR | 1 |
| 40 | 7110 | SCREW | 2 |
| 41 | 272520 | GUIDE (LEFT)/FEED BAR | 1 |
| 42 | 7110 | SCREW | 2 |
| 43 | 272523 | GUIDE/FEED BAR OIL SEAL | 1 |
| 44 | 272521 | OIL SEAL | 2 |
| 45 | 272522 | GUIDE/FEED BAR OIL SEAL | 1 |
| 46 | 4573 | SCREW | 2 |
Page 43 — KNIFE DRIVE MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 273000-92 | CONNECTION | 1 |
| 2 | 7023 | SCREW | 2 |
| 3 | 273001-92 | CRANK | 1 |
| 4 | 273002-92 | CRANK | 1 |
| 5 | 4533 | SCREW | 1 |
| 6 | 271001 | PIN | 1 |
| 7 | 4538 | SCREW | 1 |
| 8 | 240235-92 | COLLAR | 1 |
| 9 | 4547 | SCREW | 1 |
| 10 | 273003 | UPPER KNIFE LEVER | 1 |
| 11 | 273004 | UPPER KNIFE LEVER | 1 |
| 12 | 308036 | SCREW | 1 |
| 13 | 273006 | PIN | 1 |
| 14 | 179712-05 | UPPER KNIFE CLAMP | 1 |
| 15 | 179713-05 | UPPER KNIFE CLAMP | 1 |
| 16 | 7021 | SCREW | 1 |
| 17 | XXXXXX | UPPER KNIFE | 1 |
| 18 | 7013 | SCREW | 1 |
| 19 | 210756 | ANGLED UPPER KNIFE CLAMP | 1 |
| 20 | 210757 | ANGLED UPPER KNIFE CLAMP | 1 |
| 21 | XXXXXX | ANGLED KNIFE | 1 |
| 22 | 1227 | SCREW | 1 |
| 23 | 210758 | ANGLED UPPER KNIFE GIB | 1 |
| 24 | 179341-15 | WASTE GUARD | 1 |
| 25 | 7023 | SCREW | 1 |
| 26 | 7213 | SCREW | 1 |
| 27 | 300248 | WASHER | 1 |
| 28 | 273008 | LOWER KNIFE HOLDER | 1 |
| 29 | 273009 | LOWER KNIFE HOLDER | 1 |
| 30 | 7019 | SCREW | 1 |
| 31 | 273010 | GUIDE/LOWER KNIFE HOLDER | 1 |
| 32 | 7019 | SCREW | 2 |
| 33 | 240324 | SPRING | 1 |
| 34 | 273007 | PLATE | 1 |
| 35 | 7019 | SCREW | 1 |
| 36 | XXXXXX | LOWER KNIFE/THICK | 1 |
| 37 | 273012 | LOWER KNIFE CLAMP | 1 |
| 38 | 7173 | SCREW | 1 |
Page 45 — 押ェ機構 / PRESSER FOOT MECHANISM
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 274007 | LEVER | 1 |
| 2 | 7060 | SCREW | 1 |
| 3 | 274008 | SPRING | 1 |
| 4 | 274009 | STOPPER | 1 |
| 5 | 7020 | SCREW | 2 |
| 6 | 7175 | SCREW | 1 |
| 7 | 4805 | NUT | 1 |
| 8 | 274006 | LINK | 1 |
| 9 | 274004 | LEVER | 1 |
| 10 | 274003-92 | COLLAR | 1 |
| 11 | 4534 | SCREW | 1 |
| 12 | 274005 | SPRING | 1 |
| 13 | 274002 | BUSHING | 1 |
| 14 | 7020 | SCREW | 1 |
| 15 | 274001 | SHAFT | 1 |
| 16 | 274000-B | PRESSER ARM | 1 |
| 17 | 208549 | PIN | 1 |
| 18 | 4543 | SCREW | 1 |
| 19 | 202451 | CHAIN CUTTER | 1 |
| 20 | 7008 | SCREW | 1 |
| 21 | 274018-92B | HOLDER | 1 |
| 22 | 7013 | SCREW | 1 |
| 23 | 274033 | FINGER GUARD | 1 |
| 24 | 274020 | STOPPER | 1 |
| 25 | 7009 | SCREW | 1 |
| 26 | 7008 | SCREW | 1 |
| 27 | 274019 | FLAT SPRING | 1 |
| 28 | 5089 | SCREW | 1 |
| 29 | 274011-91 | PRESSER BAR | 1 |
| 30 | 208773A | SPRING | 1 |
| 31 | 274014 | ADJUSTING SCREW | 1 |
| 32 | 274015 | NUT | 1 |
| 33 | 274016 | LEVER | 1 |
| 34 | 7171 | SCREW | 1 |
| 35 | 274017 | SPRING | 1 |
| 36 | 274010 | STOPPER | 1 |
| 37 | 7019 | SCREW | 1 |
| 38 | 274039 | LEVER | 1 |
| 39 | 274040 | STOPPER | 1 |
Page 47 — LUBRICATION MECHANISM (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 274505-91 | PUMP | 1 |
| 2 | 211618 | WORM WHEEL | 1 |
| 3 | 5060 | SCREW | 2 |
| 4 | 274506 | PUMP BODY | 1 |
| 5 | 212978-91 | ROTOR (INSIDE) SHAFT | 1 |
| 6 | 212981 | ROTOR (OUTSIDE) | 1 |
| 7 | 274508 | CASING PLATE | 1 |
| 8 | 213578 | FILTER | 1 |
| 9 | 213579 | GUIDE | 1 |
| 10 | 7013 | SCREW | 3 |
| 11 | 4529 | SCREW | 2 |
| 12 | 274509 | TANK | 1 |
| 13 | 7021 | SCREW | 2 |
| 14 | 206233 | OIL FILTER | 1 |
| 15 | 274510 | COVER | 1 |
| 16 | 7018 | SCREW | 3 |
| 17 | 240307 | O RING | 1 |
| 18 | 200136 | JOINT | 2 |
| 19 | 240328 | SCREW | 2 |
| 20 | 202199 | CLAMP | 2 |
| 21 | 240327 | TUBE | 1 |
| 22 | 200136 | JOINT | 2 |
| 23 | 240328 | SCREW | 2 |
| 24 | 202199 | CLAMP | 2 |
| 25 | 240135 | TUBE | 1 |
| 26 | 200136 | JOINT | 1 |
| 27 | 240328 | SCREW | 1 |
| 28 | 202199 | CLAMP | 2 |
| 29 | 240334 | TUBE | 1 |
| 30 | 274512 | JOINT | 1 |
| 31 | 240020 | O RING | 1 |
| 32 | 7021 | SCREW | 1 |
| 33 | 303448 | WASHER | 1 |
| 34 | 274515-91 | OIL DISTRIBUTOR COMPLETE | 1 |
| 35 | 274511 | OIL DISTRIBUTOR | 1 |
| 36 | 210214 | PLUG | 2 |
| 37 | 7023 | SCREW | 1 |
| 38 | 303448 | WASHER | 1 |
| 39 | 240328 | SCREW | 1 |
Page 49 — LUBRICATION MECHANISM (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 274502 | OIL SIGHT GAUGE | 1 |
| 2 | 230043 | O RING | 1 |
| 3 | 210193 | INDICATOR COMPLETE | 1 |
| 4 | 210510 | INDICATOR SUPPORT | 1 |
| 5 | 7021 | SCREW | 2 |
| 6 | 303448 | WASHER | 2 |
| 7 | 274503-91 | OIL RESERVOIR ASSEMBLY | 1 |
| 8 | 274500 | OIL RESERVOIR | 1 |
| 9 | 5138B | SCREW | 1 |
| 10 | 202287A | GASKET | 1 |
| 11 | 4531 | BOLT | 4 |
| 12 | 240339 | WASHER | 4 |
| 13 | 274501 | GASKET | 1 |
| 14 | 274504 | WORM | 1 |
| 15 | 4514 | SCREW | 1 |
| 16 | 274517A91 | PIPE ASSEMBLY | 1 |
| 17 | 274514 | PIPE | 1 |
| 18 | 202175 | OIL WICK | 1 |
| 19 | 240038 | PLUG | 1 |
| 20 | 4543 | SCREW | 1 |
| 21 | 274517-91 | PIPE ASSEMBLY | 1 |
| 22 | 274516-91 | PIPE ASSEMBLY | 1 |
| 23 | 274513 | PIPE | 1 |
| 24 | 202175 | OIL WICK | 1 |
| 25 | 240097 | PLUG | 2 |
| 26 | 4543 | SCREW | 1 |
| 27 | 274523-91 | JOINT | 1 |
| 28 | 274518 | JOINT | 1 |
| 29 | 274522 | OIL FELT | 1 |
| 30 | 204185 | O RING | 1 |
| 31 | 7019 | SCREW | 1 |
| 32 | 202175 | OIL WICK | 1 |
| 33 | 274529 | OIL FELT | 1 |
| 34 | 274530 | COVER | 1 |
| 35 | 7192 | SCREW | 1 |
| 36 | 274551-91 | JOINT | 1 |
| 37 | 274552-91 | JOINT | 1 |
| 38 | 274556 | OIL FELT | 1 |
| 39 | 204185 | O RING | 1 |
| 40 | 4543 | SCREW | 1 |
Page 51 — H.R.装置
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275500 | SILICONE OIL RESERVOIR (UPPER) | 1 |
| 2 | 275501 | COVER | 1 |
| 3 | 275503 | FELT | 1 |
| 4 | 275508 | FELT | 1 |
| 5 | 275546 | FELT | 1 |
| 6 | 275502 | THREAD GUIDE | 1 |
| 7 | 275507 | THREAD GUIDE | 1 |
| 8 | 7020 | SCREW | 1 |
| 9 | 275504 | SILICONE OIL RESERVOIR (LOWER) | 1 |
| 10 | 275505 | COVER | 1 |
| 11 | 7020 | SCREW | 1 |
| 12 | 303448 | WASHER | 1 |
| 13 | 202175 | OIL WICK | 1 |
| 14 | 240331 | TUBE | 1 |
| 15 | 200155 | TUBE CLAMP | 2 |
| 16 | 275506 | NEEDLE THREAD LUBRICATOR | 1 |
| 17 | 7021 | SCREW | 2 |
| 18 | 210214 | PLUG | 1 |
| 19 | 204466 | OIL WICK | 1 |
| 20 | 210766 | PIN | 1 |
| 21 | 275509 | NEEDLE THREAD LUBRICATOR | 1 |
| 22 | 7019 | SCREW | 2 |
| 23 | 210214 | PLUG | 1 |
| 24 | 204466 | OIL WICK | 1 |
| 25 | 210766 | PIN | 1 |
Page 53 — THREAD STAND
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 486-9C | THREAD STAND ASS. (6-SPOOLS) | 1 | |
| 486A9C | THREAD STAND ASS. (5-SPOOLS) | 1 | |
| 486B9C | THREAD STAND ASS. (4-SPOOLS) | 1 | |
| 486C9C | THREAD STAND ASS. (3-SPOOLS) | 1 | |
| 1 | 503-CA | THREAD STAND ROD (LOWER) | 1 1 1 1 |
| 2 | 509 | WASHER | 1 1 1 1 |
| 3 | 5476 | NUT | 1 1 1 1 |
| 4 | 505-CA | BRACKET | 1 - 1 1 |
| 5 | 505ACA | BRACKET | - 2 1 - |
| 6 | 380A | SPOOL PIN | 3 4 5 6 |
| 7 | 201252 | SPRING WASHER | 3 4 5 6 |
| 8 | 4803 | NUT | 3 4 5 6 |
| 9 | 381-CA | SPOOL TRAY | 3 4 5 6 |
| 10 | 507 | CUSHION | 3 4 5 6 |
| 11 | 382-CA | SPOOL RETAINING FIN | 3 4 5 6 |
| 12 | 7102 | SCREW | 1 2 2 2 |
| 13 | 512 | WASHER | 1 2 2 2 |
| 14 | 4022 | SCREW | 1 2 2 2 |
| 15 | 502-CA | THREAD STAND ROD (UPPER) | 1 1 1 1 |
| 16 | 504-CA | JOINT | 1 1 1 1 |
| 17 | 4021 | SCREW | 2 2 2 2 |
| 18 | 4805 | NUT | 2 2 2 2 |
| 19 | 383-CA | BRACKET | 1 1 1 1 |
| 20 | 4014 | SCREW | 1 1 1 1 |
| 21 | 4803 | NUT | 1 1 1 1 |
| 22 | 384 | THREAD GUIDE BAR ROD | 1 1 1 1 |
| 23 | 4012 | SCREW | 2 2 2 2 |
| 24 | 4803 | NUT | 2 2 2 2 |
| 25 | 233-CA | HOLDER | 1 1 1 1 |
| 26 | 4012 | SCREW | 1 1 1 1 |
| 27 | 4803 | NUT | 1 1 1 1 |
| 28 | 293 | THREAD GUIDE BAR (6-SPOOLS) | 1 |
| 29 | 293A | THREAD GUIDE BAR (5-SPOOLS) | 1 |
| 30 | 293B | THREAD GUIDE BAR (4-SPOOLS) | 1 |
| 31 | 293C | THREAD GUIDE BAR (3-SPOOLS) | 1 |
| 32 | 4012 | SCREW | 1 1 1 1 |
| 33 | 4803 | NUT | 1 1 1 1 |
| 34 | 527-CA | BRACKET | 1 - 1 - |
| 35 | 527ACA | BRACKET | - 2 1 - |
| 36 | 506 | THREAD GUIDE | 3 4 5 6 |
| 37 | 4117 | SCREW | 1 2 2 2 |
| 38 | 4805 | NUT | 1 2 2 2 |
| 39 | 386 | ROD CAP | 1 1 1 1 |
Page 55 — PARTS FOR SEMI-SUBMERGED INSTALLATION
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 276001 | REST BOARD | 1 |
| 2 | 179483-05 | CUSHION RUBBER | 4 |
| 3 | 206336 | NUT | 4 |
| 4 | 205467 | SPACER | 4 |
| 5 | 4575 | BOLT | 4 |
| 6 | 240304 | WASHER | 4 |
| 7 | 276002-UA | WASTE CHUTE | 1 |
| 8 | 276003-UA | WASTE CHUTE | 1 |
| 9 | 4904 | SCREW | 3 |
| 10 | 276004 | BRACKET | 1 |
| 11 | 4109 | SCREW | 2 |
| 12 | 240104 | WASHER | 2 |
| 13 | 206337 | WASHER | 4 |
| 14 | 201447 | SPRING WASHER | 4 |
Page 57 — 全沈床式据付付属品
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 276001 | REST BOARD | 1 |
| 2 | 179483-05 | CUSHION RUBBER | 4 |
| 3 | 7237 | BOLT | 1 |
| 4 | 7236 | BOLT | 4 |
| 5 | 202700 | WASHER | 15 |
| 6 | 4816 | NUT | 15 |
| 7 | 276012 | PLATE | 1 |
| 8 | 4575 | BOLT | 3 |
| 9 | 240304 | WASHER | 3 |
| 10 | 4808 | NUT | 3 |
| 11 | 276013 | ANGLED UPPER KNIFE PLATE | 1 |
| 12 | 4575 | BOLT | 2 |
| 13 | 240304 | WASHER | 2 |
| 14 | 4808 | NUT | 2 |
| 15 | 4512 | SCREW | 3 |
| 16 | 276014 | BRACKET | 1 |
| 17 | 4109 | SCREW | 3 |
| 18 | 240104 | WASHER | 3 |
| 19 | 276002-UA | WASTE CHUTE | 1 |
| 20 | 276003-UA | WASTE CHUTE | 1 |
| 21 | 7013 | SCREW | 3 |
| 22 | 167066 | WASHER | 3 |
Page 59 — SPECIFIC PARTS (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | PRESSER FOOT | 1 |
| 2 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 3 | 277126 | FABRIC GUARD | 1 |
| 4 | 1231 | SCREW | 1 |
| 5 | 211600 | UNCURLER | 1 |
| 6 | 5030 | SCREW | 1 |
| 7 | 271014-92 | CRANK | 1 |
| 8 | 4533 | SCREW | 1 |
| 9 | XXXXXX | PRESSER FOOT COMPLETE | 1 |
| 10 | 7013 | SCREW | 1 |
| 11 | 208958-B | SCREW | 1 |
| 12 | 212499-B | PIN | 1 |
| 13 | 5409 | NUT | 1 |
| 14 | 212498 | LATCH | 1 |
| 15 | 274028 | SPRING | 1 |
| 16 | 3153 | NUT | 1 |
| 17 | 208531 | FABRIC GUARD | 1 |
| 18 | 5030 | SCREW | 1 |
| 19 | 274022 | SPRING | 1 |
| 20 | 7009 | SCREW | 1 |
| 21 | 274026 | FINGER GUARD | 1 |
| 22 | 7008 | SCREW | 1 |
| 23 | 275528 | FELT | 1 |
| 24 | 274021-92 | HOLDER | 1 |
| 25 | 7013 | SCREW | 1 |
| 26 | 274023 | SPRING | 1 |
| 27 | 7009 | SCREW | 1 |
| 28 | 274025 | FINGER GUARD | 1 |
| 29 | 7008 | SCREW | 1 |
| 30 | XXXXXX | PRESSER FOOT | 1 |
| 31 | 211919 | PIN | 1 |
| 32 | 211918 | SPRING | 1 |
| 33 | 3150 | NUT | 1 |
| 34 | 211920 | PIN | 1 |
| 35 | 211915 | PRESSER FOOT FINGER | 1 |
| 36 | 211916 | PRESSER FOOT FINGER | 1 |
| 37 | 211917 | BRACKET | 1 |
| 38 | 5089 | SCREW | 1 |
| 39 | 300248 | WASHER | 1 |
Page 61 — SPECIFIC PARTS (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | PRESSER FOOT | 1 |
| 2 | 211994 | FABRIC GUARD | 1 |
| 3 | 1333 | SCREW | 1 |
| 4 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 5 | 211600 | UNCURLER | 1 |
| 6 | 5030 | SCREW | 1 |
| 7 | 210685 | CLOTH GUIDE BRACKET ASSEMBLY | 1 |
| 8 | 210680 | CLOTH GUIDE BRACKET | 1 |
| 9 | 210681 | HINGE/EDGE GUIDE BRACKET | 1 |
| 10 | 5184 | SCREW | 1 |
| 11 | 201191 | SPRING | 1 |
| 12 | 3044 | NUT | 1 |
| 13 | 210682 | STOPPER | 1 |
| 14 | 5053 | SCREW | 1 |
| 15 | 210683 | PIN | 1 |
| 16 | 210684 | FLAT SPRING | 1 |
| 17 | 2906 | SCREW | 1 |
| 18 | 7020 | SCREW | 1 |
| 19 | 201252 | SPRING WASHER | 1 |
| 20 | 212265 | CLOTH GUIDE COMPLETE | 1 |
| 21 | 210690 | BRACKET | 1 |
| 22 | 5088 | SCREW | 2 |
| 23 | 167066 | WASHER | 2 |
| 24 | 212266 | CLOTH GUIDE | 1 |
| 25 | 5057 | SCREW | 1 |
| 26 | 210689 | ADJUSTING PLATE | 1 |
| 27 | 5157 | SCREW | 2 |
| 28 | 5363 | SCREW | 1 |
| 29 | 2905 | SCREW | 1 |
| 30 | 137142 | WASHER | 1 |
| 31 | 212267 | STOPPER | 1 |
| 32 | 1206 | SCREW | 1 |
| 33 | 212268A91 | FOLDER COMPLETE (36MM) | 1 |
| 34 | 205835A | AUXILIARY PLATE | 1 |
| 35 | 5299 | SCREW | 1 |
Page 63 — SPECIFIC PARTS (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 210530A9U | THREAD TENSION COMPLETE | 1 |
| 2 | 208447-UA | POST NUT | 1 |
| 3 | 208448 | SPRING BUSHING | 1 |
| 4 | 208450-UA | CUP | 1 |
| 5 | 210319 | TENSION DISC | 2 |
| 6 | 208449 | FELT | 1 |
| 7 | 5082A | SCREW STUD | 1 |
| 8 | 201086A | SPRING (MEDIUM) | 1 |
| 9 | 210531-9U | THREAD TENSION COMPLETE | 1 |
| 10 | 201068 | SPRING (LIGHT) | 1 |
| 11 | XXXXXX | PRESSER FOOT COMPLETE | 1 |
| 12 | 7013 | SCREW | 1 |
| 13 | 208958-B | SCREW | 3 |
| 14 | 277108 | FABRIC GUARD | 1 |
| 15 | 202875 | WASHER | 1 |
| 16 | 5157 | SCREW | 1 |
| 17 | 274024 | SPRING | 1 |
| 18 | 7166 | SCREW | 1 |
| 19 | 274034 | SPRING | 1 |
| 20 | 7009 | SCREW | 1 |
| 21 | 274027 | FINGER GUARD | 1 |
| 22 | 7008 | SCREW | 1 |
| 23 | 240347 | SPRING | 1 |
| 24 | 210337A | SPRING | 1 |
| 25 | 273009A | LOWER KNIFE HOLDER | 1 |
| 26 | 275030A | THREAD EYELET | 1 |
| 27 | 240302 | SPACER | 1 |
| 28 | 270500C | CRANKSHAFT | 1 |
| 29 | 270512B | CRANKSHAFT | 1 |
| 30 | 7151 | SCREW | 5 |
Page 65 — SPECIFIC PARTS (4)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 210530A9U | THREAD TENSION COMPLETE | 1 |
| 2 | 208447-UA | POST NUT | 1 |
| 3 | 208448 | SPRING BUSHING | 1 |
| 4 | 208450-UA | CUP | 1 |
| 5 | 210319 | TENSION DISC | 2 |
| 6 | 208449 | FELT | 1 |
| 7 | 5082A | SCREW STUD | 1 |
| 8 | 201086A | SPRING (MEDIUM) | 1 |
| 9 | 210531-9U | THREAD TENSION COMPLETE | 1 |
| 10 | 201068 | SPRING (LIGHT) | 1 |
| 11 | XXXXXX | PRESSER FOOT COMPLETE | 1 |
| 12 | 7013 | SCREW | 1 |
| 13 | 208958-B | SCREW | 3 |
| 14 | 274024 | SPRING | 1 |
| 15 | 7166 | SCREW | 1 |
| 16 | 274027 | FINGER GUARD | 1 |
| 17 | 7008 | SCREW | 1 |
| 18 | 210337A | SPRING | 1 |
| 19 | 273009A | LOWER KNIFE HOLDER | 1 |
| 20 | 275030A | THREAD EYELET | 1 |
| 21 | 275528 | FELT | 1 |
| 22 | 240302 | SPACER | 1 |
| 23 | 277500C | SHAFT | 1 |
| 24 | 7151 | SCREW | 5 |
Page 67 — 専用部品(5)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 210685 | CLOTH GUIDE BRACKET ASSEMBLY | 1 |
| 2 | 210680 | CLOTH GUIDE BRACKET | 1 |
| 3 | 210681 | HINGE/EDGE GUIDE BRACKET | 1 |
| 4 | 5184 | SCREW | 1 |
| 5 | 201191 | SPRING | 1 |
| 6 | 3044 | NUT | 1 |
| 7 | 210682 | STOPPER | 1 |
| 8 | 5053 | SCREW | 1 |
| 9 | 210683 | PIN | 1 |
| 10 | 210684 | FLAT SPRING | 1 |
| 11 | 2906 | SCREW | 1 |
| 12 | 7020 | SCREW | 1 |
| 13 | 201252 | SPRING WASHER | 1 |
| 14 | 210691 | CLOTH GUIDE COMPLETE | 1 |
| 15 | 210690 | BRACKET | 1 |
| 16 | 5088 | SCREW | 2 |
| 17 | 167066 | WASHER | 2 |
| 18 | 205361 | CLOTH GUIDE | 1 |
| 19 | 5057 | SCREW | 1 |
| 20 | 210689 | ADJUSTING PLATE | 1 |
| 21 | 5157 | SCREW | 2 |
| 22 | 2430 | SCREW | 1 |
| 23 | 2905 | SCREW | 1 |
| 24 | 137142 | WASHER | 1 |
| 25 | 210692 | STOPPER | 1 |
| 26 | 1206 | SCREW | 1 |
| 27 | 201211C91 | FOLDER COMPLETE (40MM) | 1 |
| 28 | 205835 | AUXILIARY PLATE | 1 |
| 29 | 5299 | SCREW | 1 |
| 30 | 303312A | REGULATOR | 1 |
| 31 | 303313 | FLAT SPRING | 1 |
| 32 | XXXXXX | PRESSER FOOT | 1 |
| 33 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 34 | 210584 | UNCURLER | 1 |
| 35 | 5030 | SCREW | 1 |
| 36 | 210585 | WASHER | 1 |
Page 69 — SPECIFIC PARTS (6)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | PRESSER FOOT | 1 |
| 2 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 3 | 277126 | FABRIC GUARD | 1 |
| 4 | 1231 | SCREW | 1 |
| 5 | 211600 | UNCURLER | 1 |
| 6 | 5030 | SCREW | 1 |
| 7 | 277128 | FABRIC GUARD | 1 |
| 8 | 210530A9U | THREAD TENSION COMPLETE | 1 |
| 9 | 208447-UA | POST NUT | 1 |
| 10 | 208448 | SPRING BUSHING | 1 |
| 11 | 208450-UA | CUP | 1 |
| 12 | 210319 | TENSION DISC | 2 |
| 13 | 208449 | FELT | 1 |
| 14 | 5082A | SCREW STUD | 1 |
| 15 | 201086A | SPRING (MEDIUM) | 1 |
| 16 | 210531-9U | THREAD TENSION COMPLETE | 1 |
| 17 | 201068 | SPRING (LIGHT) | 1 |
| 18 | 240302 | SPACER | 1 |
| 19 | 273008A | LOWER KNIFE HOLDER | 1 |
| 20 | XXXXXX | PRESSER FOOT | 1 |
| 21 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 22 | 277126 | FABRIC GUARD | 1 |
| 23 | 1231 | SCREW | 1 |
| 24 | 211600 | UNCURLER | 1 |
| 25 | 5030 | SCREW | 1 |
Page 71 — SPECIFIC PARTS (7)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275514-91 | SHIRRING ATTACHMENT COMPLETE | 1 |
| 2 | 275515 | BRACKET | 1 |
| 3 | 7022 | SCREW | 1 |
| 4 | 240332 | SPACER | 1 |
| 5 | 7191 | SCREW | 1 |
| 6 | 210947 | FLAT SPRING | 1 |
| 7 | 1206 | SCREW | 2 |
| 8 | 275516 | BRACKET | 1 |
| 9 | 7160 | SCREW | 1 |
| 10 | 204888 | SPRING | 2 |
| 11 | 4806 | NUT | 1 |
| 12 | 210945 | STOPPER | 1 |
| 13 | 5328 | SCREW | 2 |
| 14 | 210946 | FLAT SPRING | 1 |
| 15 | 1206 | SCREW | 1 |
| 16 | 275517-92 | SPRING GUIDE | 1 |
| 17 | 7021 | SCREW | 1 |
| 18 | 208447-UA | POST NUT | 1 |
| 19 | 208448 | SPRING BUSHING | 1 |
| 20 | 210940 | SPRING | 1 |
| 21 | 204091 | WASHER | 1 |
| 22 | 5082A | SCREW STUD | 1 |
| 23 | 210944 | WASHER | 1 |
| 24 | 275518 | LEVER | 1 |
| 25 | 4806 | NUT | 1 |
| 26 | 275520 | BRACKET | 1 |
| 27 | 240320 | SPRING | 1 |
| 28 | 275521 | SHAFT | 1 |
| 29 | 202522 | RING | 1 |
| 30 | 207045 | WASHER | 1 |
| 31 | 240323 | SPRING | 1 |
| 32 | 206225 | COLLAR | 1 |
| 33 | 1457-1 | SCREW | 2 |
| 34 | 210955 | WASHER | 1 |
| 35 | 5029 | SCREW | 2 |
| 36 | 212435 | CABLE | 1 |
| 37 | 212436 | CABLE SUPPORT | 2 |
| 38 | 7099 | SCREW | 1 |
| 39 | 202433 | WASHER | 1 |
| 40 | 4806 | NUT | 1 |
| 41 | 275522 | LATCH | 1 |
| 42 | 179765-15 | NUT | 1 |
| 43 | 7164 | SCREW | 1 |
| 44 | 240104 | WASHER | 1 |
| 45 | 275523 | BRACKET | 1 |
| 46 | 7022 | SCREW | 2 |
| 47 | 210961 | CLOTH GUIDE | 1 |
| 48 | 7012 | SCREW | 2 |
| 49 | 137906 | WASHER | 2 |
| 50 | 275524 | BLADE | 1 |
| 51 | 275525 | BLADE | 1 |
| 52 | 200098 | WASHER | 1 |
| 53 | 270035B | CLOTH PLATE | 1 |
| 54 | 210962 | BRACKET/BINDER | 1 |
| 55 | 5210 | SCREW | 2 |
| 56 | 211885 | BINDER (20) | 1 |
| 57 | 1202 | SCREW | 2 |
| 58 | 167066 | WASHER | 2 |
Page 73 — 専用部品(8)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | PRESSER FOOT | 1 |
| 2 | 211600 | UNCURLER | 1 |
| 3 | 5030 | SCREW | 1 |
| 4 | 274025 | FINGER GUARD | 1 |
| 5 | XXXXXX | PRESSER FOOT | 1 |
| 6 | 7013 | SCREW | 1 |
| 7 | 208958-B | SCREW | 1 |
| 8 | 212499-B | PIN | 1 |
| 9 | 5409 | NUT | 1 |
| 10 | 212498 | LATCH | 1 |
| 11 | 274028 | SPRING | 1 |
| 12 | 3153 | NUT | 1 |
| 13 | 208532 | PRESSER FOOT FABRIC GUARD | 1 |
| 14 | 5030 | SCREW | 1 |
| 15 | 274022 | SPRING | 1 |
| 16 | 7009 | SCREW | 1 |
| 17 | 274026 | FINGER GUARD | 1 |
| 18 | 7008 | SCREW | 1 |
| 19 | XXXXXX | PRESSER FOOT | 1 |
| 20 | 202588 | WASHER | 1 |
| 21 | 274025 | FINGER GUARD | 1 |
| 22 | 413 | TAPE INSERTING TOOL | 1 |
| 23 | 403-9S | TAPE DISC ASSEMBLY | 1 |
| 24 | 406 | FELT | 1 |
| 25 | 404 | TAPE DISC | 1 |
| 26 | 4012 | SCREW | 1 |
| 27 | 407 | COLLAR | 1 |
| 28 | 408 | ADJUSTING SCREW | 1 |
| 29 | 405 | FIXING ROD | 1 |
| 30 | 409 | SHAFT | 1 |
| 31 | 4818 | NUT | 1 |
| 32 | 410-JA | BRACKET | 1 |
| 33 | 4908 | SCREW | 3 |
Page 75 — SPECIFIC PARTS (9)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275512 | TAPE GUIDE | 1 |
| 2 | 7180 | SCREW | 2 |
| 3 | 209200 | BINDER (10) | 1 |
| 4 | 208994 | BINDER (8) | 1 |
| 5 | 1216 | SCREW | 1 |
| 6 | 208997 | BINDER GUIDE | 1 |
| 7 | 270013A | FRONT COVER (LEFT) | 1 |
| 8 | XXXXXX | PRESSER FOOT COMPLETE | 1 |
| 9 | 7013 | SCREW | 1 |
| 10 | 208958-B | SCREW | 1 |
| 11 | 212499-B | PIN | 1 |
| 12 | 5409 | NUT | 1 |
| 13 | 212498 | LATCH | 1 |
| 14 | 274028 | SPRING | 1 |
| 15 | 3153 | NUT | 1 |
| 16 | 208531 | FABRIC GUARD | 1 |
| 17 | 5030 | SCREW | 1 |
| 18 | 274022 | SPRING | 1 |
| 19 | 7009 | SCREW | 1 |
| 20 | 274026 | FINGER GUARD | 1 |
| 21 | 7008 | SCREW | 1 |
| 22 | 337 | TAPE DISC ASSEMBLY | 1 |
| 23 | 344 | BRACKET | 1 |
| 24 | 4911 | SCREW | 2 |
| 25 | 341 | ROD | 1 |
| 26 | 189 | WASHER | 1 |
| 27 | 303067 | SPRING WASHER | 1 |
| 28 | 4805 | NUT | 1 |
| 29 | 338 | TAPE DISC | 1 |
| 30 | 339 | SCREW | 1 |
| 31 | 340 | TAPE DISC COVER | 1 |
| 32 | 467 | SPRING SEAT | 1 |
| 33 | 343 | SPRING | 1 |
| 34 | 468 | COLLAR | 1 |
| 35 | 339 | SCREW | 1 |
| 2755512 | 1 |
Page 77 — SPECIFIC PARTS (10)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 275542-91 | TAPE GUIDE ASSEMBLY | 1 |
| 2 | 245510 | TAPE GUIDE ASSEMBLY | 1 |
| 3 | 7066 | SCREW | 1 |
| 4 | 210307 | WASHER | 2 |
| 5 | 275511 | TAPE GUIDE | 1 |
| 6 | 211267 | TAPE TAKEUP | 1 |
| 7 | 208735 | FABRIC GURAD | 1 |
| 8 | 1333 | SCREW | 1 |
| 9 | XXXXXX | PRESSER FOOT | 1 |
| 10 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 11 | 211600 | UNCURLER | 1 |
| 12 | 5030 | SCREW | 1 |
Page 79 — SPECIFIC PARTS (11)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 210530A9U | THREAD TENSION COMPLETE | 1 |
| 2 | 208447-UA | POST NUT | 1 |
| 3 | 208448 | SPRING BUSHING | 1 |
| 4 | 208450-UA | CUP | 1 |
| 5 | 210319 | TENSION DISC | 2 |
| 6 | 208449 | FELT | 1 |
| 7 | 5082A | SCREW STUD | 1 |
| 8 | 201086A | SPRING (MEDIUM) | 1 |
| 9 | 210531-9U | THREAD TENSION COMPLETE | 1 |
| 10 | 201068 | SPRING (LIGHT) | 1 |
| 11 | 211941A | SPRING | 1 |
| 12 | 240302 | SPACER | 1 |
| 13 | 272528A | DIFFERENTIAL FEED BAR | 1 |
| 14 | 272501A | ECCENTRIC | 1 |
| 15 | 273008A | LOWER KNIFE HOLDER | 1 |
Page 81 — 専用部品 (12)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 270037C | CLOTH PLATE (NARROW) | 1 |
| 2 | 271010A | BRACKET | 1 |
| 3 | 270037D | CLOTH PLATE (NARROW) | 1 |
| 4 | 308093 | LEVER | 1 |
| 5 | 308085 | BRACKET/NEEDLE PLATE | 1 |
| 6 | XXXXXX | PRESSER FOOT | 1 |
| 7 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 8 | 277126 | FABRIC GUARD | 1 |
| 9 | 1231 | SCREW | 1 |
| 10 | XXXXXX | PRESSER FOOT | 1 |
| 11 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 12 | 273008B | LOWER KNIFE HOLDER | 1 |
| 13 | 210530A9U | THREAD TENSION COMPLETE | 1 |
| 14 | 208447-UA | POST NUT | 1 |
| 15 | 208448 | SPRING BUSHING | 1 |
| 16 | 208450-UA | CUP | 1 |
| 17 | 210319 | TENSION DISC | 2 |
| 18 | 208449 | FELT | 1 |
| 19 | 5082A | SCREW STUD | 1 |
| 20 | 201086A | SPRING (MEDIUM) | 1 |
| 21 | 210531-9U | THREAD TENSION COMPLETE | 1 |
| 22 | 201068 | SPRING (LIGHT) | 1 |
| 23 | 211941A | SPRING | 1 |
| 24 | XXXXXX | NEEDLE PLATE | 1 |
Page 83 — 専用部品(13) / SPECIFIC PARTS (13)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | PRESSER FOOT | 1 |
| 2 | 211994 | FABRIC GUARD | 1 |
| 3 | 1333 | SCREW | 1 |
| 4 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 5 | 211600 | UNCURLER | 1 |
| 6 | 5030 | SCREW | 1 |
| 7 | 270037C | CLOTH PLATE (NARROW) | 1 |
| 8 | 271010A | BRACKET | 1 |
| 9 | 273008B | LOWER KNIFE HOLDER | 1 |
| 10 | 210685 | CLOTH GUIDE BRACKET ASSEMBLY | 1 |
| 11 | 210680 | CLOTH GUIDE BRACKET | 1 |
| 12 | 210681 | HINGE/EDGE GUIDE BRACKET | 1 |
| 13 | 5184 | SCREW | 1 |
| 14 | 201191 | SPRING | 1 |
| 15 | 3044 | NUT | 1 |
| 16 | 210682 | STOPPER | 1 |
| 17 | 5053 | SCREW | 1 |
| 18 | 210683 | PIN | 1 |
| 19 | 210684 | FLAT SPRING | 1 |
| 20 | 2906 | SCREW | 1 |
| 21 | 7020 | SCREW | 1 |
| 22 | 201252 | SPRING WASHER | 1 |
| 23 | 275529-91 | CLOTH GUIDE | 1 |
| 24 | 210690A | BRACKET | 1 |
| 25 | 5088 | SCREW | 2 |
| 26 | 167066 | WASHER | 2 |
| 27 | 212266 | CLOTH GUIDE | 1 |
| 28 | 5057 | SCREW | 1 |
| 29 | 275530 | ADJUSTING PLATE | 1 |
| 30 | 5157 | SCREW | 2 |
| 31 | 5363 | SCREW | 1 |
| 32 | 2905 | SCREW | 1 |
| 33 | 137142 | WASHER | 1 |
| 34 | 212267 | STOPPER | 1 |
| 35 | 1206 | SCREW | 1 |
| 36 | 212268A91 | FOLDER COMPLETE (36MM) | 1 |
| 37 | 205835A | AUXILIARY PLATE | 1 |
| 38 | 5299 | SCREW | 1 |
Page 85 — SPECIFIC PARTS (14)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | XXXXXX | PRESSER FOOT | 1 |
| 2 | XXXXXX | PRESSER FOOT FINGER | 1 |
| 3 | 210584 | UNCURLER | 1 |
| 4 | 5030 | SCREW | 1 |
| 5 | 210585 | WASHER | 1 |
| 6 | 210685 | CLOTH GUIDE BRACKET ASSEMBLY | 1 |
| 7 | 210680 | CLOTH GUIDE BRACKET | 1 |
| 8 | 210681 | HINGE/EDGE GUIDE BRACKET | 1 |
| 9 | 5184 | SCREW | 1 |
| 10 | 201191 | SPRING | 1 |
| 11 | 3044 | NUT | 1 |
| 12 | 210682 | STOPPER | 1 |
| 13 | 5053 | SCREW | 1 |
| 14 | 210683 | PIN | 1 |
| 15 | 210684 | FLAT SPRING | 1 |
| 16 | 2906 | SCREW | 1 |
| 17 | 7020 | SCREW | 1 |
| 18 | 201252 | SPRING WASHER | 1 |
| 19 | 210691 | CLOTH GUIDE COMPLETE | 1 |
| 20 | 210690 | BRACKET | 1 |
| 21 | 5088 | SCREW | 2 |
| 22 | 167066 | WASHER | 2 |
| 23 | 205361 | CLOTH GUIDE | 1 |
| 24 | 5057 | SCREW | 1 |
| 25 | 210689 | ADJUSTING PLATE | 1 |
| 26 | 5157 | SCREW | 2 |
| 27 | 2430 | SCREW | 1 |
| 28 | 2905 | SCREW | 1 |
| 29 | 137142 | WASHER | 1 |
| 30 | 210692 | STOPPER | 1 |
| 31 | 1206 | SCREW | 1 |
| 32 | 201211C91 | FOLDER COMPLETE (40MM) | 1 |
| 33 | 205835 | AUXILIARY PLATE | 1 |
| 34 | 5299 | SCREW | 1 |
| 35 | 303312A | REGULATOR | 1 |
| 36 | 303313 | FLAT SPRING | 1 |
Page 87 — 当定規
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 1 | 210685 | CLOTH GUIDE BRACKET ASSEMBLY | 1 |
| 2 | 210680 | CLOTH GUIDE BRACKET | 1 |
| 3 | 210681 | HINGE/EDGE GUIDE BRACKET | 1 |
| 4 | 5184 | SCREW | 1 |
| 5 | 201191 | SPRING | 1 |
| 6 | 3044 | NUT | 1 |
| 7 | 210682 | STOPPER | 1 |
| 8 | 5053 | SCREW | 1 |
| 9 | 210683 | PIN | 1 |
| 10 | 210684 | FLAT SPRING | 1 |
| 11 | 2906 | SCREW | 1 |
| 12 | 7020 | SCREW | 1 |
| 13 | 201252 | SPRING WASHER | 1 |
| 14 | 210686 | BRACKET COMPLETE/EDGE GUIDE | 1 |
| 15 | 210687 | BRACKET/EDGE GUIDE | 1 |
| 16 | 5088 | SCREW | 2 |
| 17 | 167066 | WASHER | 2 |
| 18 | 1202 | SCREW | 1 |
| 19 | 167066 | WASHER | 1 |
| 20 | 204667 | EDGE GUIDE | 1 |
| 21 | 201233A | EDGE GUIDE | 1 |
Page 88 — GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277514P30 | |||
| 277514P40 | |||
| 277515P30 | |||
| 277513P40 | |||
| 277513P50 | |||
| 277514R30 | |||
| 277514R40 | |||
| 277515R30 | |||
| 277513R40 | |||
| 277513R50 | |||
| 277323-13 | |||
| 277324-13 | |||
| 277318-13 | |||
| 277323-16 | |||
| 277324-16 | |||
| 277318-13 | |||
| 277326-13 | |||
| 277325-13 | |||
| 277326-16 | |||
| 277325-16 | |||
| 277117 | |||
| 277117 | |||
| 277118 | |||
| 277118 | |||
| 277118 |
Page 89 — PLAIN SEAMING (EXTRA LIGHT WEIGHT FABRIC) / PLAIN SEAMING (LIGHT WEIGHT FABRIC) / OVERLOCK NEEDLE GUARD / CHAINSTITCH NEEDLE GUARD
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277026-92 | |||
| 275030 | |||
| 277027-92 | |||
| 275030 | |||
| 277014A | |||
| 277010 | |||
| 277015 | |||
| 277018 | |||
| 201121A | |||
| 210755 | |||
| 202295 | |||
| 277007 | |||
| 277004 | |||
| 277008 | |||
| 277006 |
Page 90 — GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277514P30 | |||
| 277514P40 | |||
| 277515P30 | |||
| 277513P40 | |||
| 277513P50 | |||
| 277514R30 | |||
| 277514R40 | |||
| 277515R30 | |||
| 277513R40 | |||
| 277513R50 | |||
| 277323-13 | |||
| 277324-13 | |||
| 277318-13 | |||
| 277323-16 | |||
| 277324-16 | |||
| 277318-13 | |||
| 277326-13 | |||
| 277325-13 | |||
| 277326-16 | |||
| 277325-16 | |||
| 211907 | |||
| 211909 | |||
| 211910 |
Page 91 — EX3215-01A/222 and EX3215-02A/223 (EX3215, EX3216 plain seaming presser feet and blades)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2 | 277026-92 | ||
| 275030 | |||
| 3 | 277027-92 | ||
| 275030 | |||
| 277014A | |||
| 277010 | |||
| 277015 | |||
| 277018 | |||
| 202527A | |||
| 202295 |
Page 92 — EX3200 Series / ゲージーパーツ 系列構成図 GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277517R40 | |||
| 277517R50 | |||
| 277517R40 | |||
| 277516R50 | |||
| 277516R60 | |||
| 277516R50 | |||
| 277327-16 | |||
| 277328-16 | |||
| 277318-13 | |||
| 277330-16 | |||
| 277329-16 | |||
| 277118 | |||
| 277119 |
Page 93 — PLAIN SEAMING (MEDIUM WEIGHT FABRIC)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277027-92 | 3 | ||
| 275030 | |||
| 277028-92 | 5 | ||
| 275030 | |||
| 277014B | |||
| 277010A | |||
| 277014A | |||
| 277010 | |||
| 277015 | |||
| 277018 | |||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 94 — EX3200 Series GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277524T50 | |||
| 277524T60 | |||
| 277524T50 | |||
| 277524T60 | |||
| 277524T70 | |||
| 277337-25 | |||
| 277338-25 | |||
| 277318-13 | |||
| 277339-25 | |||
| 277122 | |||
| 277122 | |||
| 277129 | |||
| 277129 | |||
| 277129 |
Page 95 — EX3215-04/435(K) EX3216 / EX3215H-05/535(K) EX3216H
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277029-92 | 5 | ||
| 275030A | |||
| #1 | 277014 | ||
| #3 | 277011 | ||
| #8 | 277014A | ||
| #11 | 277017 | ||
| 277015 | |||
| 277018-C | |||
| 277015A | |||
| 277018-C | |||
| 277000 | |||
| 211662 | |||
| 277009 |
Page 96 — PLAIN SEAMING(3-NEEDLE) / GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277518R40 | |||
| 277519R40 | |||
| 277525T40 | |||
| 277327-16 | |||
| 277328-16 | |||
| 277318-13 | |||
| 277337-25 | |||
| 277338-25 | |||
| 277318-13 | |||
| 277329-16 | |||
| 277339-25 | |||
| 277118A | |||
| 277119A | |||
| 277123 |
Page 97 — EX3244-03/333(K) / EX3244-04/435(K)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277030-92 | |||
| 275030 | |||
| 277031-92 | |||
| 275030 | |||
| 277010A | |||
| 277015 | |||
| 277018 | |||
| 201121A | |||
| 210755 | |||
| 202295 | |||
| 277032-92 | |||
| 275030A | |||
| 277011 | |||
| 277015 | |||
| 277018-C | |||
| 277000 | |||
| 211662 | |||
| 277009 |
Page 98 — EX3200 Series GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277334-16 | |||
| 277335-16 | |||
| 277318-13 | |||
| 277336-16 | |||
| 277120 | |||
| 277331-16 | |||
| 277332-16 | |||
| 277333-16 | |||
| 277121 | |||
| 277331-25 | |||
| 277332-25 | |||
| 277333-25 |
Page 99 — EX3215-42/233(K) EX3216 / EX3215-43/335(K) EX3216
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 3 | 277027-92 | ||
| 275030 | |||
| 5 | 277028-92 | ||
| 275030 | |||
| #9 | 277014B | ||
| #5 | 277010A | ||
| #8 | 277014A | ||
| #2 | 277010 | ||
| 277015 | |||
| 277018 | |||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 100 — EX3200 Series
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277523R40 | |||
| 277523R50 | |||
| 277522R50 | |||
| 277327-16 | |||
| 277328-16 | |||
| 277318-13 | |||
| 277330A16 | |||
| 277329A16 | |||
| 277118B | |||
| 277119B |
Page 101 — EX3216-53/233(K)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277027-92 | 3 | ||
| 275030 | |||
| 277028-92 | 5 | ||
| 275030 | |||
| 277010 | |||
| 277015 | |||
| 277018 | |||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 102 — EX5200 Series
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277500P30 | |||
| 277500P40 | |||
| 277500P50 | |||
| 277500P30 | |||
| 277500P40 | |||
| 277504R30 | |||
| 277504R40 | |||
| 277504R50 | |||
| 277300-16F | |||
| 277301-16F | |||
| 277318-13 | |||
| 277303-16F | |||
| 277304-16F | |||
| 277318-13 | |||
| 277302-16F | |||
| 277305-16F | |||
| 201230C | |||
| 211991A | |||
| 210370 | |||
| 210371 | |||
| 210371 | |||
| 277115A | |||
| 277103A |
Page 103 — PLAIN SEAMING
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 179630-92 | |||
| 275019A | |||
| 277010 | |||
| 277015 | |||
| 201121A | |||
| 210755 | |||
| 202295 | |||
| 201121A | |||
| 210755 | |||
| 201127 | |||
| 202295 | |||
| 202295 | |||
| 277005 | |||
| 277004 | |||
| 277010 #2 |
Page 104 — EX5200 Series
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277505P30 | |||
| 277505P40 | |||
| 277505R30 | |||
| 277505R40 | |||
| 277505R50 | |||
| 277303-16F | |||
| 277304-16F | |||
| 277318-13 | |||
| 277305-16F | |||
| 201230C | |||
| 3 | 201396B | ||
| 4 | 201310A | ||
| 3 | 210503 | ||
| 4 | 210374 | ||
| 5 | 210374 |
Page 105 — PLAIN SEAMING (EXTRA LIGHT WEIGHT FABRIC / LIGHT WEIGHT FABRIC)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 2 | 277022-92 | 2 | |
| 275019B | |||
| 277010B | |||
| 277013 | |||
| 277015 | |||
| 201121A | |||
| 210755 | |||
| 202295 | |||
| 277010B #6 | |||
| 277013 #7 |
Page 106 — EX5200 Series
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277505R30 | |||
| 277505R40 | |||
| 277505R50 | |||
| 277303-16F | |||
| 277304-16F | |||
| 277318-13 | |||
| 277305-16F | |||
| 201230C | |||
| 3 | 210503 | ||
| 4 | 210374 | ||
| 5 | 210374 |
Page 107 — PLAIN SEAMING (MEDIUM WEIGHT FABRIC)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277022-92 | 2 | ||
| 275019B | |||
| 277010A #5 | |||
| 277015 | |||
| 277034 | |||
| 201121 A | |||
| 210755 | |||
| 202295 |
Page 108 — EX5200 Series
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277500P30 | |||
| 277500P40 | |||
| 277504R50 | |||
| 277504R60 | |||
| 277511S70 | |||
| 277511S80 | |||
| 277510S40 | |||
| 277510S50 | |||
| 277300-16F | |||
| 277301-16F | |||
| 277318-13 | |||
| 277303A16 | |||
| 277304-16 | |||
| 277318A13 | |||
| 277309-25F | |||
| 277310-25F | |||
| 277318A13 | |||
| 277302-16F | |||
| 277305-16F | |||
| 277311-25F | |||
| 201152E | |||
| 202799 | |||
| 277110 | |||
| 277115 | |||
| 277103 | |||
| 210371 | |||
| 210372 | |||
| 210372 | |||
| 210372 | |||
| 210376 | |||
| 210376 |
Page 109 — BLINDSTITCH HEMMING / SERGING
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 179630-92 | |||
| 275019A | |||
| 3 | 277024-92 | ||
| 275019C | |||
| 277014A | |||
| 277010 | |||
| 277014B | |||
| 277011 | |||
| 277015 | |||
| 201121A | |||
| 210755 | |||
| 202295 | |||
| 277000 | |||
| 211662 | |||
| 277009 |
Page 110 — EX5200 Series
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277503S30 | 3 | ||
| 277512P15 | 1.5 | ||
| 277502P15 | 1.5 | ||
| 277300-16F | |||
| 277301-16F | |||
| 277318-13 | |||
| 277315-16F | |||
| 277301-16F | |||
| 277319-13 | |||
| 277302-16F | |||
| 202799 | |||
| 210761 | 3 | ||
| 205525 | 1.5 |
Page 111 — 下巻縫用(薄生地) TURN DOWN HEMMING (LIGHT WEIGHT FABRIC)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 179630-92 | |||
| 275019A | |||
| 277010A | |||
| 277010 | |||
| 277015 | |||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 112 — GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277505R30 | |||
| 277505R40 | |||
| 277306-16 | |||
| 277307-16 | |||
| 277318-13 | |||
| 277308-16 | |||
| 277124 | |||
| 277124 | |||
| 277125 | |||
| 277125 |
Page 113 — SHIRRING / SHIRRING•PIPING (MEDIUM WEIGHT FABRIC)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277022-92 | 2 | ||
| 275019B | |||
| 277010A | |||
| 277015 | |||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 114 — EX5200 Series / GAUGE PARTS CONSTRUCTION CHART / ゲージーパーツ 系列構成図 / ATTACHING TAPE / テープ付用
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277505R30 | |||
| 277505R40 | |||
| 277505R50 | |||
| 277303-16F | |||
| 277304-16F | |||
| 277318-13 | |||
| 277305-16F | |||
| 277112 | |||
| 277159 | |||
| 208651 | |||
| 208651 |
Page 115
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277022-92 | 2 | ||
| 275019B | |||
| 277010A | |||
| 277015 | |||
| 277034 | |||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 116 — GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277505R30 | |||
| 277505R40 | |||
| 277505R50 | |||
| 277507R30 | |||
| 277507R40 | |||
| 277507R50 | |||
| 277508R35 | |||
| 277508R45 | |||
| 277526S35 | |||
| 277526S45 | |||
| 277510S40 | |||
| 277510S50 | |||
| 277303-16F | |||
| 277304-16F | |||
| 277318-13 | |||
| 277351-16F | |||
| 277352-16F | |||
| 277318-13 | |||
| 277351-25F | |||
| 277352-25F | |||
| 277318-13 | |||
| 277316-16F | |||
| 277353-16F | |||
| 277353A25F | |||
| 277112 | |||
| 277111 | |||
| 277127 | |||
| 277159 | |||
| 208651 | |||
| 208651 | |||
| 277159 | |||
| 277104 | |||
| 277104 | |||
| 277105 | |||
| 277105 | |||
| 277157 | |||
| 277158 | |||
| 277158 | |||
| 277158 | |||
| 277105 | |||
| 277105 |
Page 117
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277022-92 | |||
| 275019B | |||
| 277023-92 | |||
| 275019C | |||
| 277024-92 | |||
| 275019C | |||
| 277011 | |||
| 277019 | |||
| 277012 | |||
| 277015 | |||
| 277016A | |||
| 277016 | |||
| 201121A | |||
| 210755 | |||
| 202295 | |||
| 277000 | |||
| 211662 | |||
| 202295 |
Page 118 — ゲージーパーツ 系列構成図 / GAUGE PARTS CONSTRUCTION CHART
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277532-30 | |||
| 277532-40 | |||
| 277532-50 | |||
| 277531-30 | |||
| 277531-40 | |||
| 277531-50 | |||
| 277530-30 | |||
| 277530-40 | |||
| 277303B16F | |||
| 277304A16F | |||
| 277318-13 | |||
| 277340-16F | |||
| 277341-16F | |||
| 277318-13 | |||
| 277305A16F | |||
| 277342-16F | |||
| 277317-16F | |||
| 277114 | |||
| 277113 | |||
| 277115 | |||
| 277103 | |||
| 277103 | |||
| 301510 | |||
| 277160 |
Page 119 — BACKLATCHING
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 179630-92 | |||
| 275019A | |||
| 2 | 277022-92 | ||
| 275019B | |||
| #2 | 277010 | ||
| #5 | 277010A | ||
| #3 | 277011 | ||
| 277015 | |||
| 201121A | |||
| 210755 | |||
| 3 | 201127 | ||
| 4 | 202295 | ||
| 5 | 202295 | ||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 120 — EX5200 Series
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 3 | 277531-30 | ||
| 4 | 277531-40 | ||
| 277340-16F | |||
| 277341-16F | |||
| 277318-13 | |||
| 277342-16F | |||
| 211991A | |||
| 3 | 277115A #12 | ||
| 4 | 277103A #13 | ||
| 2×3 | 277501R30 | ||
| 2×4 | 277501R40 | ||
| 277300-16F | |||
| 277301-16F | |||
| 277318-13 | |||
| 277302-16F | |||
| 201152E | |||
| 3 | 201396B | ||
| 4 | 201310A |
Page 121
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 179630-92 | |||
| 275019A | |||
| 277022-92 | 2 | ||
| 275019B | |||
| 277010 | |||
| 277010B | |||
| 277015 | |||
| 201121A | |||
| 210755 | |||
| 202295 |
Page 122 — GAUGE PARTS LIST (1) / ゲージパーツ表 (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| DC X 27 #11 | NEEDLE | ||
| DC X 27 #11 | NEEDLE | ||
| 275030 | THREAD GUIDE (NDL HOLDER) | ||
| 275030 | THREAD GUIDE (NDL HOLDER) | ||
| 277026-92 | NEEDLE HOLDER | ||
| 277027-92 | NEEDLE HOLDER | ||
| 277026-92 | NEEDLE HOLDER | ||
| 277027-92 | NEEDLE HOLDER | ||
| 277006 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277006 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 202527A | FLAT KNIFE |
Page 123 — EX3200 Series GAUGE PARTS LIST (2) / ゲージパーツ表 (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277018 | CHAINSTITCH LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277014A #8 | UPPER SPREADER | ||
| 277010 #2 | UPPER LOOPER | ||
| 277117 | PRESSER FOOT ASS. | ||
| 277118 | PRESSER FOOT ASS. | ||
| 211907 | PRESSER FOOT ASS. | ||
| 211909 | PRESSER FOOT ASS. | ||
| 211910 | PRESSER FOOT ASS. | ||
| 277326-16 | DIFF. FEED DOG | ||
| 277325-16 | DIFF. FEED DOG | ||
| 277318-13 | AUX. FEED DOG | ||
| 277324-16 | MAIN FEED DOG | ||
| 277323-16 | MAIN FEED DOG ASS. | ||
| 277514R30 | NEEDLE PLATE | ||
| 277515R30 | NEEDLE PLATE | ||
| 277513R40 | NEEDLE PLATE | ||
| 275030 | THREAD GUIDE (NDL HOLDER) | ||
| 277026-92 | NEEDLE HOLDER | ||
| 277006 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 202527A | FLAT KNIFE | ||
| DC × 27 #11 | NEEDLE |
Page 124 — EX3200 Series ゲージパーツ表 (3) / EX3200 Series GAUGE PARTS LIST (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| DC X 27 #14 | NEEDLE | ||
| 275030 | THREAD GUIDE (NDL HOLDER) | ||
| 277027-92 | NEEDLE HOLDER | ||
| 277028-92 | NEEDLE HOLDER | ||
| 277008 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 277018 | CHAINSTITCH LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277010A #5 | UPPER LOOPER | ||
| 277014B #9 | UPPER SPREADER | ||
| 277118 | PRESSER FOOT ASS. | ||
| 277330-18 | DIFF. FEED DOG | ||
| 277327-16 | MAIN FEED DOG ASS. | ||
| 277517R40 | NEEDLE PLATE |
Page 125 — GAUGE PARTS LIST (4)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| DC X 27 # 21 | NEEDLE | ||
| 275030A | THREAD GUIDE (NDL HOLDER) | ||
| 277029-92 | NEEDLE HOLDER | ||
| 277006 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 277009 | LOWER KNIFE | ||
| 211682 | ANGLED KNIFE | ||
| 277000 | FLAT KNIFE | ||
| 277337-25 | MAIN FEED DOG ASS. | 5 | |
| 277338-25 | MAIN FEED DOG | 8 | |
| 277318-13 | AUX. FEED DOG | 6 | |
| 277015 | LOWER LOOPER | 5 | |
| 277018-C | CHAINSTITCH LOOPER | 8 | |
| 277014A #8 | UPPER SPREADER | 5 | |
| 277017 #11 | UPPER LOOPER | 8 | |
| 277011 #3 | UPPER LOOPER | 6 | |
| 277122 | PRESSER FOOT ASS. | 7 | |
| 277123 | PRESSER FOOT ASS. | 6 | |
| 277029-26 | NEEDLE HOLDER (NDL HOLDER) | 5 | |
| 277032-26 | THREAD GUIDE (NDL HOLDER) | 8 | |
| 211662 | UPPER KNIFE | 7 |
Page 126 — EX3200 Series GAUGE PARTS LIST (5) / ゲージパーツ表 (5)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277018 | CHAINSTITCH LOOPER | ||
| 277018 | CHAINSTITCH LOOPER | ||
| 277018 | CHAINSTITCH LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277014B #9 | UPPER SPREADER | ||
| 277014A #8 | UPPER SPREADER | ||
| 277010A #5 | UPPER LOOPER | ||
| 277010 #2 | UPPER LOOPER | ||
| 277010 #2 | UPPER LOOPER | ||
| 277120 | PRESSER FOOT ASS. | ||
| 277121 | PRESSER FOOT ASS. | ||
| 277121 | PRESSER FOOT ASS. | ||
| 277118B | PRESSER FOOT ASS. | ||
| 277119B | PRESSER FOOT ASS. | ||
| 277336-16 | DIFF. FEED DOG | ||
| 277333-16 | DIFF. FEED DOG | ||
| 277333-25 | DIFF. FEED DOG | ||
| 277330A16 | DIFF. FEED DOG | ||
| 277329A16 | DIFF. FEED DOG | ||
| (277318-13) | AUX. FEED DOG | ||
| (277318-13) | AUX. FEED DOG | ||
| (277318-13) | AUX. FEED DOG | ||
| (277335-16) | MAIN FEED DOG | ||
| (277332-16) | MAIN FEED DOG | ||
| (277332-25) | MAIN FEED DOG | ||
| (277328-16) | MAIN FEED DOG | ||
| 277334-16 | MAIN FEED DOG ASS. | ||
| 277331-16 | MAIN FEED DOG ASS. | ||
| 277331-25 | MAIN FEED DOG ASS. | ||
| 277327-16 | MAIN FEED DOG ASS. | ||
| 277521R40 | NEEDLE PLATE | ||
| 277520R50 | NEEDLE PLATE | ||
| 277520S50 | NEEDLE PLATE | ||
| 277523R40 | NEEDLE PLATE | ||
| 277522R50 | NEEDLE PLATE | ||
| DC X 27 #14 | NEEDLE | ||
| DC X 27 #16 | NEEDLE | ||
| DC X 27 #11 | NEEDLE | ||
| 275030 | THREAD GUIDE (NDL HOLDER) | ||
| 275030 | THREAD GUIDE (NDL HOLDER) | ||
| 275030 | THREAD GUIDE (NDL HOLDER) | ||
| 277027-92 | NEEDLE HOLDER | ||
| 277028-92 | NEEDLE HOLDER | ||
| 277028-92 | NEEDLE HOLDER | ||
| 277027-92 | NEEDLE HOLDER | ||
| 277028-92 | NEEDLE HOLDER | ||
| 277006 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277006 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277006 | CHAINSTITCH NEEDLE GUARD REAR | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277008 | CHAINSTITCH NEEDLE GUARD FRONT | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277004 | OVERLOCK NEEDLE GUARD REAR | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 277007 | OVERLOCK NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 201121A | FLAT KNIFE |
Page 127 — GAUGE PARTS LIST (1)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 9 | 201396B | PRESSER FOOT FINGER | 4 |
| 13 | 277010 #1 | UPPER LOOPER | 5 |
| 15 | 277010B #8 | UPPER LOOPER | 4 |
| 25 | 210735 | UPPER KNIFE | 4 |
| 31 | 179630-92 | NEEDLE HOLDER | 5 |
| 33 | 277019A | NEEDLE PLATE | 2 |
| 34 | 277019B | NEEDLE PLATE | 2 |
| 277500P30 | NEEDLE PLATE | ||
| 277505P30 | NEEDLE PLATE | ||
| 277300-16F | MAIN FEED DOG ASS. | ||
| 277303-16F | MAIN FEED DOG ASS. | ||
| 277301-16F | MAIN FEED DOG | ||
| 277304-16F | MAIN FEED DOG | ||
| 277318-13 | AUX. FEED DOG | ||
| 277318-13 | AUX. FEED DOG | ||
| 277302-16F | DIFF. FEED DOG | ||
| 277305-16F | DIFF. FEED DOG | ||
| 201230C | PRESSER FOOT | ||
| 201230C | PRESSER FOOT | ||
| 210370 #1 | PRESSER FOOT FINGER | ||
| 210371 #2 | PRESSER FOOT FINGER | ||
| 201398B | PRESSER FOOT FINGER | ||
| 201310A | PRESSER FOOT FINGER | ||
| 277010 #2 | UPPER LOOPER | ||
| 277010B #6 | UPPER LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277015 | LOWER LOOPER | ||
| DC x 27 #9 | NEEDLE | ||
| DC x 27 #9 | NEEDLE | ||
| 275019A | THREAD GUIDE (NDL HOLDER) | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 179830-92 | NEEDLE HOLDER | ||
| 277022-92 | NEEDLE HOLDER | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 201121A | FLAT KNIFE |
Page 128 — EX5200 Series GAUGE PARTS LIST (2)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| DC X 27 #9 | NEEDLE | ||
| 179830-92 | NEEDLE HOLDER | ||
| 275019A | THREAD GUIDE (NDL HOLDER) | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE |
Page 129 — EX5200 Series GAUGE PARTS LIST (3) / ゲージパーツ表 (3)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| DC X 27 #9 | NEEDLE | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 277022-92 | NEEDLE HOLDER | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| DC X 27 #11 | NEEDLE | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 277022-92 | NEEDLE HOLDER | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| DC X 27 #9 | NEEDLE | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 277022-92 | NEEDLE HOLDER | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| DC X 27 #11 | NEEDLE | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 277022-92 | NEEDLE HOLDER | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE |
Page 130 — EX5200 Series ゲージパーツ表 (4) / EX5200 Series GAUGE PARTS LIST (4)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277500P30 | NEEDLE PLATE | ||
| 277300-16F | MAIN FEED DOG ASS. | ||
| 277301-16F | MAIN FEED DOG | ||
| 277318-13 | AUX. FEED DOG | ||
| 277302-16F | DIFF. FEED DOG | ||
| 201152E | PRESSER FOOT | ||
| 277115 | PRESSER FOOT FINGER | ||
| 277010 | UPPER LOOPER | ||
| 277015 | LOWER LOOPER | ||
| DC X 27 #9 | NEEDLE | ||
| 179830-92 | NEEDLE HOLDER | ||
| 275019A | THREAD GUIDE (NDL HOLDER) | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE |
Page 131 — EX5200 Series ゲージパーツ表 (5) / EX5200 Series GAUGE PARTS LIST (5)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277503S30 | NEEDLE PLATE | ||
| 277502P15 | NEEDLE PLATE | ||
| 277512P15 | NEEDLE PLATE | ||
| 277505R30 | NEEDLE PLATE | ||
| 277505R30 | NEEDLE PLATE | ||
| 277505R30 | NEEDLE PLATE | ||
| 210762 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE |
Page 132 — GAUGE PARTS LIST (6)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277505R30 | NEEDLE PLATE | ||
| 277303-16F | MAIN FEED DOG ASS'Y | ||
| (277304-16F) | MAIN FEED DOG | ||
| (277318-13) | AUX. FEED DOG | ||
| 277305-16F | DIFF. FEED DOG | ||
| 277112 | PRESSER FOOT | ||
| 277159 #22 | PRESSER FOOT FINGER | ||
| 208651 | PRESSER FOOT FINGER | ||
| 277010A #5 | UPPER LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277505R30 | NEEDLE PLATE | ||
| 277303-16F | MAIN FEED DOG ASS'Y | ||
| 277015 | LOWER LOOPER | ||
| 277034 | LOWER LOOPER | ||
| 277034 | LOWER LOOPER | ||
| 277004 | FLAT KNIFE | 2 | |
| 202295 | LOWER KNIFE | 2 | |
| 210755 | ANGLED KNIFE | 2 | |
| 2775050 | NEEDLE PLATE | 2 | |
| 275019B | THREAD GUIDE (NDL HOLDER) | 2 | |
| 277022-92 | NEEDLE HOLDER | 2 |
Page 133 — EX5200 Series GAUGE PARTS LIST (7)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277505R30 | NEEDLE PLATE | ||
| 277303-16F | MAIN FEED DOG ASS'Y | ||
| 277318-13 | AUX. FEED DOG | ||
| 277316-16F | DIFF. FEED DOG | ||
| 277112 | PRESSER FOOT | ||
| 277015 | LOWER LOOPER | ||
| 277011 #3 | UPPER LOOPER | ||
| DC×27 #11 | NEEDLE | ||
| 277022-92 | NEEDLE HOLDER | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 277004 | REAR | ||
| 277005 | FRONT | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE |
Page 134 — EX5200 Series GAUGE PARTS LIST (8)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| DC x 27 #9 | NEEDLE | ||
| DC x 27 #9 | NEEDLE | ||
| DC x 27 #9 | NEEDLE | ||
| DC x 27 #11 | NEEDLE | ||
| 275019A | THREAD GUIDE (NDL HOLDER) | ||
| 275019A | THREAD GUIDE (NDL HOLDER) | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 275019B | THREAD GUIDE (NDL HOLDER) | ||
| 179630-92 | NEEDLE HOLDER | ||
| 179630-92 | NEEDLE HOLDER | ||
| 277022-92 | NEEDLE HOLDER | ||
| 277022-92 | NEEDLE HOLDER | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277004 | NEEDLE GUARD REAR | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 277005 | NEEDLE GUARD FRONT | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 202295 | LOWER KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 210755 | ANGLED KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 201121A | FLAT KNIFE | ||
| 201121A | FLAT KNIFE |
Page 135 — ゲージパーツ表 (9) / GAUGE PARTS LIST (9)
| Ref | Part number | Part name | Qty |
|---|---|---|---|
| 277531-30 | NEEDLE PLATE | ||
| 277531-40 | NEEDLE PLATE | ||
| 277501R30 | NEEDLE PLATE | ||
| 277531-40 | NEEDLE PLATE | ||
| 277340-16F | MAIN FEED DOG ASS. | ||
| 277300-16F | MAIN FEED DOG ASS. | ||
| (277341-16F) | MAIN FEED DOG | ||
| (277301-16F) | MAIN FEED DOG | ||
| (277318-13) | AUX. FEED DOG | ||
| (277318-13) | AUX. FEED DOG | ||
| 277342-16F | DIFF. FEED DOG | ||
| 277302-16F | DIFF. FEED DOG | ||
| 211991A | PRESSER FOOT | ||
| 201152E | PRESSER FOOT | ||
| 277115A #12 | PRESSER FOOT FINGER | ||
| 277103A #13 | PRESSER FOOT FINGER | ||
| 201396B | PRESSER FOOT FINGER | ||
| 201310A | PRESSER FOOT FINGER | ||
| 277010 #2 | UPPER LOOPER | ||
| 277010B #6 | UPPER LOOPER | ||
| 277015 | LOWER LOOPER | ||
| 277015 | LOWER LOOPER |
Pegasus EX3200 Series — parts catalog
- Page 1 (cover): This is the cover page for the Pegasus EX Series Parts Catalog, specifically for machine models EX3200 and EX5200, published in December 1993. It features an image of an EX series sewing machine and the Pegasus logo.
- Page 2 (text): This page contains introductory information about the parts catalog, including how to use it, and lists the machine models covered by the EX3200(H) and EX5200(H) series.
- Page 3 (toc): This page contains the table of contents for the parts catalog, listing various machine mechanisms and parts with their corresponding page numbers.
- Page 4 (diagram): This page displays a diagram of machine components with reference numbers and associated part series information.
- Page 5 (parts_list): This page lists parts for the MACHINE BED FRAME, including part numbers, names, and quantities.
- Page 6 (diagram): This page displays a diagram of various components and their assembly, with numbered references for each part. It also lists specific machine series to which certain parts apply.
- Page 7 (parts_list): This page lists parts for COVER (1) including screws, gaskets, covers, and other components with their part numbers, descriptions, and quantities.
- Page 8 (diagram): This page displays a diagram of various machine components, including part numbers, descriptions, and model applicability for the EX5200(H) and EX3200(H) series.
- Page 9 (parts_list): This page lists parts for COVER (2) with part numbers, names, and quantities. It includes items like cloth plates, screws, washers, and covers.
- Page 10 (diagram): This page displays a diagram of various components for EX3200(H) and EX5200(H) series sewing machines, including part numbers and reference indicators.
- Page 11 (parts_list): This page lists parts for the Crankshaft Drive Mechanism, including crankshafts, screws, pins, bearings, and other components with their respective part numbers, names, and quantities.
- Page 12 (diagram): This page displays diagrams of needle sets and associated parts for industrial sewing machines, including part numbers and model applicability.
- Page 13 (parts_list): This page lists parts for the Thread Tension Mechanism, including part numbers, names, and quantities.
- Page 14 (diagram): This page displays a diagram of the EX3200(H) Series sewing machine parts, with numbered components and their corresponding part numbers and descriptions.
- Page 15 (parts_list): This page lists parts for the Thread Guide & Thread Takeup (1) section, including brackets, screws, thread guides, and springs with their corresponding part numbers and quantities.
- Page 16 (diagram): This page displays a diagram of components for the EX5200(H) Series sewing machines, detailing parts for both EX5200 Series and EX5200H Series models.
- Page 17 (parts_list): This page lists parts for thread guide and thread takeup, including part numbers, names, and quantities.
- Page 18 (diagram): This page displays a diagram of various sewing machine parts, including different lift types and their corresponding components, with reference numbers and descriptions.
- Page 19 (parts_list): This page lists parts for the Thread Guide & Thread Takeup (3) assembly, including part numbers, names, and quantities.
- Page 20 (diagram): This page displays a diagram of various components for the EX3200 and EX5200 series sewing machines, with numbered parts indicated for reference.
- Page 21 (parts_list): This page lists parts for the Needle Drive Mechanism (1), including part numbers, names, and quantities.
- Page 22 (diagram): This page displays a diagram of various components for the EX3200H and EX5200H Series sewing machines, with numbered parts indicated for reference.
- Page 23 (parts_list): This page lists parts for the Needle Drive Mechanism (2), including part numbers, names, and quantities.
- Page 24 (diagram): This page displays diagrams and parts lists for the EX3200(H) and EX5200(H) series sewing machines, detailing components for 2-needle and 3-needle configurations.
- Page 25 (parts_list): This page lists parts for the Needle Drive Mechanism (3), including part numbers, names, and quantities.
- Page 26 (diagram): This page displays diagrams of parts for the EX3200(H) Series and EX5200(H) Series sewing machines, detailing various components and their reference numbers.
- Page 27 (parts_list): This page lists parts for the Needle Drive Mechanism (4), including part numbers, names, and quantities.
- Page 28 (diagram): This page displays a diagram of the EX3200 and EX5200 series sewing machine parts, detailing various components and their reference numbers.
- Page 29 (parts_list): This page lists parts for the Upper Looper Drive Mechanism (1), including part numbers, names, and quantities.
- Page 30 (diagram): This page displays a diagram of the EX3200H and EX5200H series sewing machine parts, specifically detailing components for the ultra-high lift function.
- Page 31 (parts_list): Parts list for the upper looper drive mechanism (2), giving reference numbers, part numbers, Japanese and English names and quantities for 35 items.
- Page 32 (diagram): This page displays a diagram of various sewing machine parts, with reference numbers and model applicability indicated for some components.
- Page 33 (parts_list): This page lists parts for the Lower Looper Drive Mechanism, including part numbers, names, and quantities.
- Page 34 (diagram): This page displays a diagram of the EX3200(H) Series sewing machine parts, with numbered components indicating their positions and relationships within the machine's assembly.
- Page 35 (parts_list): Parts list for the chainstitch looper drive mechanism (1), giving reference numbers, part numbers, Japanese and English names and quantities for 29 items.
- Page 36 (diagram): This page displays a diagram of various parts for the EX3200(H) Series sewing machine, with numbered components indicating their positions.
- Page 37 (parts_list): This page lists parts for the CHAINSTITCH LOOPER DRIVE MECHANISM (2), including part numbers, names, and quantities.
- Page 38 (diagram): This page displays a diagram of various machine parts, including levers, shafts, springs, and fasteners, with reference numbers for identification.
- Page 39 (parts_list): This page lists parts for the FEED MECHANISM (1) with part numbers, names, and quantities.
- Page 40 (diagram): This page displays a diagram of various machine parts, including components labeled with reference numbers, part numbers, and descriptions. It also includes specific model information for certain parts.
- Page 41 (parts_list): This page lists parts for the FEED MECHANISM (2) with part numbers, names, and quantities.
- Page 42 (diagram): This page displays a diagram of various machine parts, including screws, linkages, and other components, with corresponding part numbers and series information for EX5200 and EX3200 models.
- Page 43 (parts_list): This page lists parts for the KNIFE DRIVE MECHANISM, including part numbers, names, and quantities.
- Page 44 (diagram): This page displays a diagram of various machine parts, including screws, levers, and assemblies, with reference numbers and part numbers for models EX5214, EX3200H, and EX5200H series.
- Page 45 (parts_list): This page lists parts for the Presser Foot Mechanism, including part numbers, names, and quantities.
- Page 46 (diagram): This page displays a diagram of various machine components, including shafts, housings, filters, screws, and linkages, with reference numbers for each part.
- Page 47 (parts_list): This page lists parts for the Lubrication Mechanism (1), including pumps, screws, filters, and tubes, with their corresponding part numbers and quantities.
- Page 48 (diagram): This page displays diagrams of components for the EX3200 and EX3200H series sewing machines, including lift mechanisms and base components, with associated part numbers and reference indicators.
- Page 49 (parts_list): This page lists parts for the lubrication mechanism (2) of an industrial sewing machine, including part numbers, names, quantities, and remarks.
- Page 50 (diagram): This page displays a diagram of various components for the EX5200(H) Series and EX3200(H) Series sewing machines, with numbered parts and their corresponding model series indicated.
- Page 51 (parts_list): This page lists parts for the H.R. Device, including part numbers, names, and quantities.
- Page 52 (diagram): This page displays a diagram of various machine components, including arms, supports, discs, and fasteners, with reference numbers for each part.
- Page 53 (parts_list): This page lists parts for the Thread Stand, including part numbers, names, and quantities for various components like nuts, screws, brackets, and thread guide bars.
- Page 54 (diagram): This page displays a diagram of special washers for a table 35mm thick, along with various screws, washers, and other components labeled with reference numbers.
- Page 55 (parts_list): This page lists parts for semi-submerged installation, including part numbers, names, and quantities.
- Page 56 (diagram): This page displays a diagram of various machine components, including screws, nuts, washers, plates, and a motor, with reference numbers for each part.
- Page 57 (parts_list): This page lists parts for fully-submerged installation, including part numbers, names, and quantities.
- Page 58 (diagram): This page displays diagrams of various sewing machine parts, including components for plain seaming, and lists their corresponding part numbers and reference numbers.
- Page 59 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities. It also notes that 'XXXXXX' parts are gauge parts and should be confirmed on pages 120-133.
- Page 60 (diagram): This page contains diagrams and part information for blindhemming and plain seaming operations on the EX5204-02H sewing machine.
- Page 61 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, quantities, and some details like screw sizes and material types.
- Page 62 (diagram): This page displays a diagram of plain seaming components for the EX3215-3216-04 and EX3215H-3216H-05 sewing machine models, with numbered parts and their corresponding part numbers and descriptions.
- Page 63 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities.
- Page 64 (diagram): This page displays a diagram of plain seaming components for the EX3244-04 model, with numbered parts and their descriptions.
- Page 65 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some Japanese and English descriptions.
- Page 66 (diagram): This page contains a diagram of blind hemming components for the EX5203 and 5205 sewing machine models, with various parts numbered for identification.
- Page 67 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities. It also contains a note about gauge parts and their confirmation on pages 120-133.
- Page 68 (diagram): This page displays diagrams of serging parts for models EX5203-22, EX5204-5214-24, EX5214-24, EX5204-24, and turn down hemming parts for EX5204-32R1, 32R2.
- Page 69 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities, with some parts designated as gauge parts.
- Page 70 (diagram): This page displays a diagram of shirting components for models EX5214-43,43P1,43P2 and EX3215-3216-42,43, with numbered parts and their corresponding references.
- Page 71 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, quantities, and reference numbers. It contains items from reference number 1 to 58.
- Page 72 (diagram): This page displays diagrams for the EX5214-43 (Shirring) and EX3215-3216-42,43 models, as well as the Piping EX5214-43P1,43P2.
- Page 73 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some parts marked as gauge parts.
- Page 74 (diagram): This page displays a diagram of components for attaching U-shaped tape to the EX3216-53 model, including various screws, brackets, and discs.
- Page 75 (parts_list): This page lists specific parts for industrial sewing machines, including part numbers, names, and quantities. It also notes that 'XXXXXX' parts are gauge parts and should be confirmed on pages 120-133.
- Page 76 (diagram): This page displays a diagram of attaching tape components for various sewing machine models including EX5214-53, 53C3,54, M53, M53C3,84, and EX5214H-55.
- Page 77 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some parts noted as gauge parts.
- Page 78 (diagram): This page displays a diagram of attaching tape components for models EX5214-54 and EX5214H-55, with numbered parts and associated part numbers.
- Page 79 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities.
- Page 80 (diagram): This page displays diagrams of various machine parts for models EX5204-82, EX5214-83, and EX5214-84, with numbered references for each component.
- Page 81 (parts_list): This page lists specific parts for a sewing machine, including part numbers, names, and quantities, with some parts marked as gauge parts.
- Page 82 (diagram): This page displays diagrams of parts for blind hemming on the EX5204-92M1 sewing machine, including components labeled with reference numbers.
- Page 83 (parts_list): Specific parts list (13) giving reference numbers, part numbers, Japanese and English names and quantities for presser foot, cloth guide, folder and related items, with a gauge parts note.
- Page 84 (diagram): This page displays diagrams of sewing machine parts for plain seaming and blind hemming, specifically for the EX5214-92M2 model, with numbered components.
- Page 85 (parts_list): This page lists specific parts for an industrial sewing machine, including part numbers, names, and quantities, with some parts marked as not for sale.
- Page 86 (diagram): This page displays a diagram of optional parts for various EX series sewing machines, including part numbers and reference numbers.
- Page 87 (parts_list): This page lists parts for the FABRIC EDGE GUIDE, including part numbers, names, and quantities.
- Page 88 (diagram): This page displays a construction chart for gauge parts for the EX3200 Series, specifically for the EX3215 and EX3216 models, showing various configurations and part numbers.
- Page 89 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needle guards and other parts for different models like EX3215 and EX3216, with descriptions for plain seaming and overlock applications.
- Page 90 (diagram): This page displays a construction chart for gauge parts of the EX3200 Series, specifically for models EX3215-01A/222 and EX3216, showing various components with their part numbers and diagrams.
- Page 91 (diagram): This page displays diagrams of various sewing machine parts, including needle plates, presser feet, and other components, with their corresponding part numbers and model applicability.
- Page 92 (diagram): This page displays a construction chart for gauge parts for the EX3200 Series sewing machine, showing various components with their part numbers and diagrams.
- Page 93 (diagram): This page displays diagrams of various sewing machine parts, including needle plates, presser feet, and other components, with their corresponding part numbers and model applicability for EX3215 and EX3216 machines.
- Page 94 (diagram): Gauge parts construction chart for the EX3200 Series plain seaming machines, showing gauge part assemblies and their part-number labels for the EX3215/EX3216 and EX3215H/EX3216H variants.
- Page 95 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needle guards, presser feet, and other specialized parts, with model applicability indicated for some.
- Page 96 (diagram): Gauge parts construction chart for the EX3200 Series plain seaming (3-needle) machines, showing the gauge part numbers and their assembly relationships for the EX3244-03/333(K) and EX3244-04/435(K) models.
- Page 97 (diagram): This page displays diagrams and part numbers for various components of the EX3244-03/333(K) and EX3244-04/435(K) sewing machines, categorized for plain seaming on medium and heavy weight fabrics.
- Page 98 (diagram): This page displays construction diagrams for EX3200 Series Gauge Parts, detailing various components with their respective part numbers and associated models.
- Page 99 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needle plates, presser feet, and shirting attachments for models EX3215 and EX3216.
- Page 100 (diagram): This page contains a construction chart for the EX3200 Series, specifically detailing gauge parts with diagrams and part numbers.
- Page 101 (diagram): This page displays diagrams of various sewing machine parts, including part numbers and descriptions, with some parts specified for models -53/233 and -53/233K.
- Page 102 (diagram): This page displays construction diagrams for gauge parts for the EX5200 Series sewing machine, specifically for plain seaming with one needle.
- Page 103 (diagram): This page displays a diagram of sewing machine parts, including part numbers, descriptions, and associated machine models, with specific sections for different fabric types.
- Page 104 (diagram): This page displays construction charts for gauge parts of the EX5200 series sewing machine, including diagrams and part numbers for various components.
- Page 105 (diagram): This page displays diagrams of various sewing machine parts, including part numbers and descriptions for different fabric types.
- Page 106 (diagram): This page displays a construction chart for the EX5200 Series, specifically for plain seaming with two needles. It includes diagrams and part numbers for various components.
- Page 107 (diagram): This page displays diagrams of various sewing machine parts, including part numbers like 277022-92, 275019B, 277010A #5, 277015, 277034, 201121A, 210755, and 202295, along with their descriptions and applicable models.
- Page 108 (diagram): This page displays a construction chart for gauge parts of the EX5200 Series sewing machines, detailing various components with their part numbers and associated models.
- Page 109 (diagram): This page displays a diagram of various sewing machine parts, including part numbers, descriptions, and associated machine models. It details components for blindstitch hemming and serging on light and heavy weight fabrics.
- Page 110 (diagram): This page displays a construction chart for EX5200 Series gauge parts, featuring diagrams and part numbers for various components.
- Page 111 (diagram): This page displays a diagram of various sewing machine parts, including part numbers and their corresponding descriptions, with specific models listed for some parts.
- Page 112 (diagram): This page displays a construction chart for gauge parts of the EX5200 Series, showing various components with their part numbers and diagrams.
- Page 113 (diagram): This page displays diagrams and part numbers for various sewing machine components, including parts for models EX5214-43/333(K), EX5214-43P1/333(K), and EX5214-43P2/333(K). It details parts like 277022-92, 275019B, 277010A #5, 277015, 201121A, 210755, and 202295, with descriptions for shirring and shirring/piping applications on medium weight fabric.
- Page 114 (diagram): Gauge parts construction chart for the EX5200 Series attaching tape machines, showing the NG×SW gauge, spring and gear assemblies, and the 277112 and SW parts with their part-number labels.
- Page 115 (diagram): This page displays diagrams and part numbers for various sewing machine components, including needles, presser feet, and tape attachments for different fabric weights.
- Page 116 (diagram): This page displays a construction chart for gauge parts of the EX5200 Series, featuring diagrams and part numbers for various components.
- Page 117 (diagram): This page displays diagrams of various sewing machine parts, categorized by model numbers such as EX5214-54/433(K), EX5214-54/443(K), EX5214H-55/545(K), and EX5214-54/445(K). It includes part numbers, descriptions, and illustrations for components like attaching tape for heavy weight fabric.
- Page 118 (diagram): Gauge parts construction chart for the EX5200 Series backlatching units, showing part-number labels on exploded drawings for each model group.
- Page 119 (diagram): This page displays diagrams of various sewing machine parts, categorized by model numbers such as EX5204-82/233(K), EX5214-83/323(K), and EX5214-84/423(K). It includes part numbers, descriptions, and application notes for different fabric weights.
- Page 120 (diagram): This page displays diagrams and part numbers for the EX5200 Series, specifically for models EX5204-92M1/223(K) and EX5214-92M2/223(K). It includes various components with their respective part numbers and some descriptive text.
- Page 121 (diagram): This page displays diagrams of various sewing machine parts, including part numbers and model applicability, for models EX5204-92M1/223(K) and EX5214-92M2/223(K).
- Page 122 (parts_list): Gauge parts list for EX3200 Series machines, giving needle, thread guide, needle holder, chainstitch and overlock needle guards, lower, angled and flat knives, and gauge settings by machine type.
- Page 123 (parts_list): Gauge parts list (2) for the EX3200 Series showing looper, spreader, presser foot, feed dog, needle plate, needle, needle guard, and knife part numbers by machine type and gauge.
- Page 124 (parts_list): Gauge parts list (3) for EX3200 series machines, showing needle, needle holder, thread guide, needle guards, knives, and gauge part numbers for the left-hand loopers, feed dogs, presser feet and needle plates.
- Page 125 (parts_list): This page lists gauge parts for the EX3200 Series, including various loopers, feed dogs, needles, and thread guides with their corresponding part numbers and specifications for different machine types.
- Page 126 (parts_list): Gauge parts list (5) for EX3200 series sewing machines, giving needle plate, feed dog, presser foot, looper, spreader, needle, needle guard and knife part numbers by machine type.
- Page 127 (parts_list): This page lists gauge parts for the EX5200 Series, including various components like feed dogs, presser feet, loopers, and knives, along with their part numbers and specifications for different machine types.
- Page 128 (parts_list): Gauge parts list (2) for the EX5200 Series, tabulating needle, needle holder, thread guide, needle guard, and knife part numbers by machine type and gauge.
- Page 129 (parts_list): Gauge parts table for EX5200 Series machines (EX5214 types) listing needle, needle holder, thread guide, needle guard, knives and needle plate part numbers by gauge and machine type, with a second table of needle plates, feed dogs, presser parts and loopers on the left.
- Page 130 (parts_list): Two rotated gauge parts tables for EX5200 series machines (EX5205, EX5203, EX5204, EX5214), listing needle plates, feed dogs, presser feet, loopers, needles, needle holders, thread guides, needle guards and knives by gauge and machine type; only the EX5205-12/223(K) column is transcribed here.
- Page 131 (parts_list): Gauge parts list (5) for EX5200 series machines, giving needle plates, feed dogs, presser feet, loopers, needle guards, knives and needles by machine type and gauge.
- Page 132 (parts_list): This page lists gauge parts for the EX5200 Series sewing machines, including part numbers, descriptions, and quantities for various machine types and specifications.
- Page 133 (parts_list): Gauge parts list (7) for EX5200 Series sewing machines, giving needle plate, feed dog, presser foot, looper, needle, knife and needle guard part numbers by machine type and gauge.
- Page 134 (parts_list): Gauge parts list (8) for EX5200 Series machines, giving needle, needle holder, thread guide, needle guard, lower knife, angled knife and flat knife part numbers by machine type and gauge.
- Page 135 (parts_list): Gauge parts list (9) for the EX5200 Series showing gauge part numbers for needle plate, main feed dog, aux and diff feed dogs, presser foot and finger, and upper and lower loopers, by machine type.
- Page 139 (unknown): This page contains a watermark and a website address at the bottom.
- Page 140 (cover): This is the cover page of a parts catalog for PEGASUS SEWING MACHINE MFG. CO., LTD., catalog number 9605, dated December 1993. It also lists the publication dates for the first, second, and third editions.
